Cabletron Systems TPXMIM-22 Specifications

EMME/EMM-E6

Management Module Guide

®

Notice

Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, firmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL,

INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT

NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR

THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN

ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH

DAMAGES.

Virus Disclaimer

Cabletron has tested its software with current virus checking technologies. However, because no anti-virus system is 100% reliable, we strongly caution you to write protect and then verify that the Licensed Software, prior to installing it, is virus-free with an anti-virus system in which you have confidence.

Cabletron Systems makes no representations or warranties to the effect that the Licensed

Software is virus-free.

Copyright © April 1998, by Cabletron Systems, Inc. All rights reserved.

Printed in the United States of America.

Order Number: 9031111 E7

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03866-5005

SPECTRUM , the SPECTRUM IMT/VNM logo, DCM , IMT , and VNM are registered trademarks, and SpectroGRAPH , SpectroSERVER , Inductive Modeling Technology ,

Device Communications Manager , and Virtual Network Machine are trademarks of

Cabletron Systems, Inc.

C++ is a trademark of American Telephone and Telegraph, Inc.

UNIX is a trademark of UNIX System Laboratories, Inc.

OSF/Motif and Motif are trademarks of the Open Software Foundation, Inc.

X Window System is a trademark of X Consortium, Inc.

Ethernet is a trademark of Xerox Corporation.

9031111 E7 i

ii

Restricted Rights Notice

(Applicable to licenses to the United States Government only.)

1.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at

DFARS 252.227-7013.

Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03866-5005.

2.

(a) This computer software is submitted with restricted rights. It may not be used, reproduced, or disclosed by the Government except as provided in paragraph (b) of this

Notice or as otherwise expressly stated in the contract.

(b) This computer software may be:

(1) Used or copied for use in or with the computer or computers for which it was acquired, including use at any Government installation to which such computer or computers may be transferred;

(2) Used or copied for use in a backup computer if any computer for which it was acquired is inoperative;

(3) Reproduced for safekeeping (archives) or backup purposes;

(4) Modified, adapted, or combined with other computer software, provided that the modified, combined, or adapted portions of the derivative software incorporating restricted computer software are made subject to the same restricted rights;

(5) Disclosed to and reproduced for use by support service contractors in accordance with subparagraphs (b) (1) through (4) of this clause, provided the Government makes such disclosure or reproduction subject to these restricted rights; and

(6) Used or copied for use in or transferred to a replacement computer.

(c) Notwithstanding the foregoing, if this computer software is published copyrighted computer software, it is licensed to the Government, without disclosure prohibitions, with the minimum rights set forth in paragraph (b) of this clause.

(d) Any other rights or limitations regarding the use, duplication, or disclosure of this computer software are to be expressly stated in, or incorporated in, the contract.

(e) This Notice shall be marked on any reproduction of this computer software, in whole or in part.

EMME/EMM-E6

Management Module Guide

Contents

Preface

What Is in This Guide .......................................................................................................... xi

Conventions ......................................................................................................................... xii

Related SPECTRUM Documentation................................................................................. xii

Other Related Documentation ........................................................................................... xiii

Chapter 1 Introduction

What Is in This Chapter..................................................................................................... 1-1

EMME/EMM-E6 ................................................................................................................. 1-2

SPECTRUM Support.......................................................................................................... 1-3

Modeling Instructions .................................................................................................. 1-3

Accessing SPECTRUM Views from the Device Icon .................................................. 1-4

Accessing Device-Specific Subviews............................................................................ 1-6

SPECTRUM Views Roadmap ............................................................................................ 1-7

SPMA Support .................................................................................................................... 1-9

Chapter 2 Device Views


Chassis Device View ........................................................................................................... 2-2

EMME/EMM-E6 Module Icon ..................................................................................... 2-4

EMME/EMM-E6 Module Identification Labels ................................................... 2-7

EMME/EMM-E6 Chassis Module Icon Subviews Menu ..................................... 2-7

Application Label................................................................................................... 2-8

Interface Labels ..................................................................................................... 2-9

Repeater Label..................................................................................................... 2-11

BRIM Label (exclusive to EMM-E6) ................................................................... 2-16

BRIM Port Label.................................................................................................. 2-18

MIM Icon .................................................................................................................... 2-19

MIM Identification Labels................................................................................... 2-20

MIM Icon Subviews Menu .................................................................................. 2-21

Repeater Port Labels ........................................................................................... 2-23

TPXMIM ..................................................................................................................... 2-25

TPXMIM Identification Labels ........................................................................... 2-27

TPXMIM Icon Subviews Menu ........................................................................... 2-27

TPXMIM Port Labels........................................................................................... 2-28

Interface Device View ....................................................................................................... 2-30

Interface Icons ............................................................................................................ 2-32

Interface Icon Subviews Menu............................................................................ 2-33

9031111 E7 iii

Interface Label .....................................................................................................2-33

Administrative Status Label ...............................................................................2-33

Interface Type Label ............................................................................................2-34

MAC Address Label .............................................................................................2-36

Network Address Label........................................................................................2-36

Gauge Label..........................................................................................................2-36

Interface Options Panel..............................................................................................2-37

Gauge Control Panel ..................................................................................................2-37

Physical Device View ........................................................................................................2-41

Chapter 3 Configuration Views

What Is in This Chapter .....................................................................................................3-1

EMME/EMM-E6 Device Configuration View ....................................................................3-2

Interface Configuration Table ......................................................................................3-3

Chassis Configuration View (EMME only) ........................................................................3-3

Module and Port Configuration Views ...............................................................................3-4

Module Management (Module Configuration View Only)..........................................3-5

Port Management (Port Configuration View Only) ....................................................3-5

Trap Configuration .......................................................................................................3-6

Alarm Configuration.....................................................................................................3-6

Error Source..................................................................................................................3-8

Repeater Configuration View .............................................................................................3-8

Repeater Management .................................................................................................3-9

Source Address Management.......................................................................................3-9

Trap Configuration .....................................................................................................3-10

Alarm Configuration...................................................................................................3-10

Error Source................................................................................................................3-11

Board Map...................................................................................................................3-12

Manages ......................................................................................................................3-12

CSI Isolated Repeater Configuration View......................................................................3-12

Repeater Management ...............................................................................................3-12

Manages ......................................................................................................................3-13

Interface Configuration Views (EMM-E6 only) ...............................................................3-13

Port Configuration View (for FDDI) .................................................................................3-14

SMT Device Configuration View ......................................................................................3-16

Station Configuration View........................................................................................3-16

SMT Information ........................................................................................................3-18

ATM Client Application Configuration View ...................................................................3-19

Chapter 4 Event and Alarm Messages

What Is in This Chapter .....................................................................................................4-1

Device Events and Alarms..................................................................................................4-1

iv

EMME/EMM-E6


Chapter 5 Application View


Applications Not Covered in This Chapter ....................................................................... 5-2

Device Application View ..................................................................................................... 5-2

Network (A, B, or C) Application........................................................................................ 5-5

Isolated Repeater Application............................................................................................ 5-6

Creating an Isolated Repeater .................................................................................... 5-7

DownLoad Application ....................................................................................................... 5-8

ATM Client Application...................................................................................................... 5-8

ATM Client Application Virtual Channel Link View ................................................. 5-9

FddiSMT Application ....................................................................................................... 5-13

Index

9031111 E7 v

vi

EMME/EMM-E6


Figures

Chapter 1 Introduction

Figure 1-1.

Figure 1-2.

Figure 1-3.

Figure 1-4.

Figure 1-5.

Figure 1-6.

Example of an EMME Model Configuration ....................................................... 1-4

Using Double-Click Zones to Access SPECTRUM Views ................................... 1-5

Using the Icon Subviews Menu to Access SPECTRUM Views .......................... 1-6

Accessing Device-Specific Subviews .................................................................... 1-7

SPECTRUM Views Roadmap .............................................................................. 1-8

SPMA Applications View ...................................................................................... 1-9


Figure 2-1.

Figure 2-2.

Figure 2-3.

Figure 2-4.

Figure 2-5.

Figure 2-6.

Figure 2-7.

Figure 2-8.

Figure 2-9.

Chassis Device View ............................................................................................. 2-3

EMME Module Icon .............................................................................................. 2-5

EMM-E6 Module Icon ........................................................................................... 2-6

MIM Icon ............................................................................................................. 2-20

TPXMIM Icon ...................................................................................................... 2-26

EMME/EMM-E6 Interface Device View ............................................................ 2-31

Interface Icon ...................................................................................................... 2-32

Gauge Control Panel ........................................................................................... 2-38

Physical Device View .......................................................................................... 2-41


Figure 3-1.

Link Error Rate Estimate .................................................................................. 3-15


Figure 5-1.

Figure 5-2.

Device Application View Icon Mode) .................................................................... 5-3

Device Application View (List Mode) ................................................................... 5-4

9031111 E7 vii

viii

EMME/EMM-E6


Tables


Table 2-1.

Table 2-2.

Table 2-3.

Table 2-4.

Table 2-5.

Table 2-6.

Table 2-7.

Table 2-8.

Table 2-9.

Table 2-10.

Table 2-11.

Table 2-12.

Table 2-13.

Table 2-14.

Table 2-15.

Table 2-16.

Table 2-17.

Table 2-18.

Table 2-19.

Table 2-20.

Table 2-21.

Table 2-22.

Table 2-23.

EMME/EMM-E6 Module Icon Subviews Menu ................................................... 2-7

Bridge Menu Selections......................................................................................... 2-8

Interface Status for the Bridging Application ..................................................... 2-9

Interface Status for the Physical or MIB II Application ................................... 2-10

AUI Port Subviews Menu.................................................................................... 2-10

Repeater Menu Selections................................................................................... 2-11

Repeater Port Channel Label & Background Colors......................................... 2-15

FDDI Label Icon Subviews Menu ....................................................................... 2-16

ATM Label Icon Subviews Menu ........................................................................ 2-17

BRIM Port Label Subviews Menu ...................................................................... 2-18

BRIM Port Status Descriptions .......................................................................... 2-18

MIM Icon Subviews Menu .................................................................................. 2-21

MIM Module Icon Subviews (Repeater option).................................................. 2-22

Repeater Port Icon Subviews Menu ................................................................... 2-23

TPXMIM Icon Subviews Menu ........................................................................... 2-27

TPXMIM Icon Subviews Menu (Module Segment Details option) ................... 2-28

TPXMIM Port Icon Subviews Menu ................................................................... 2-28

Interface Icon Subviews Menu............................................................................ 2-33

Administrative Status for the Physical or MIB II Application ......................... 2-34

Administrative Status for the Bridging Application ......................................... 2-34

Interface Types .................................................................................................... 2-34

Rates Gauge Mode: Attributes and Corresponding Colors ............................... 2-39

Totals Gauge Mode: Attributes and Corresponding Colors .............................. 2-39


Table 3-1.

Table 3-2.

Table 3-3.

Interface Configuration Views ............................................................................ 3-13

FDDI Ring States ................................................................................................ 3-16

SMT MAC Configurations................................................................................... 3-17

Chapter 4 Event and Alarm Messages

Table 4-1.

EMME/EMM-E6 Events and Alarms ................................................................... 4-1


Table 5-1.

Table 5-2.

Network (A, B, or C) Application Subviews Menu............................................... 5-5

Network (A, B, or C) Application Subviews Menu (Performance Option).......... 5-6

9031111 E7 ix

Table 5-3.

Table 5-4.

Table 5-5.

Table 5-6.

Table 5-7.

Isolated Repeater Application Subviews Menu....................................................5-6

Download Application Subviews Menu.................................................................5-8

ATM Client Application Subviews Menu .............................................................5-8

ATM Client Application Subviews Menu (Interfaces option) ..............................5-9

FddiSMT Application Icon Subviews Menu .......................................................5-13

x

EMME/EMM-E6


Preface

Use this guide as a reference for the SPECTRUM EMME/EMM-E6 management software. Before using this guide, you should be familiar with

SPECTRUM’s functions and navigational techniques.

For the purposes of this guide, EMME/EMM-E6 is referred to as “device.”

What Is in This Guide

The following outlines the organization of the EMME/EMM-E6

Management Module Guide :

Chapter

Chapter 1

Introduction

Chapter 2

Device Views

Chapter 3

Configuration Views

Chapter 4

Event and Alarm Messages

Chapter 5

Application View

Description

Describes the device, the management module software, and model types.

Describes the Device views representing the device, connected repeaters, and other views and information accessed from these views.

Describes the Configuration views for the device and the network management information provided by these views.

Lists and explains the event and alarm messages generated in the Event Log of

Alarm Manager for the device model type.

Describes the Application view and application-specific information within the

Application view for this device.

9031111 E7 xi

Conventions

Conventions

In this manual the following conventions are used.

• Menu selections and buttons referenced in text appear in bold ; for example, Configuration or Detail .

• Buttons’ names appear in shadowed boxes when introducing paragraphs describing their use; for example,

Detail

• Menu navigation appears in order of selection; for example, Icon

Subviews -> Utilities -> Application .

• Referenced chapter titles and section headings appear in italics.

• Referenced documents appear in bold italics .

• EMME/EMM-E6 is referred to as “device.”

Related SPECTRUM Documentation

It is important when using this guide that you have a clear understanding of

SPECTRUM functionality and navigational techniques as described in the

Administration, Operation, and following documentation:

Report Generator User’s Guide

Getting Started with SPECTRUM 5.0 for Operators

Getting Started with SPECTRUM 5.0 for Administrators

How to Manage Your Network with SPECTRUM

This guide also references the following documents:

SPECTRUM Portable Management Application for the EMME User’s

Guide

SPECTRUM Portable Management Application for the EMM-E6 User’s

Guide

SPECTRUM Portable Management Application Tools Guide

How to Manage Your Network with SPECTRUM

Routing Services Management Module Guide

Preface xii

EMME/EMM-E6


Other Related Documentation

Other Related Documentation

Refer to the following documentation for more information on managing

TCP/IP-based networks:

Martin, James, Kathleen Kavanagh Chapman, Joe Leben.

Local Area

Networks: Architectures and Implementations , 2d ed. Englewood Cliffs,

NJ: Prentice Hall, 1994.

Rose, Marshall T. The Simple Book: An Introduction to Management of

TCP/IP-based Internets . Englewood Cliffs, NJ: Prentice Hall, 1991.

Stallings, William. Data and Computer Communications , 4th ed. New

York: Macmillan Publishing Company, 1994.

Tanenbaum, Andrew S.

Computer Networks , 3d ed. Englewood Cliffs, NJ:

Prentice Hall, 1996.

9031111 E7 Preface xiii

Other Related Documentation

Preface xiv

EMME/EMM-E6


Chapter 1

Introduction

What Is in This Chapter

This chapter introduces the SPECTRUM Management Module for the

EMME/EMM-E6. It describes the following:

• EMME/EMM-E6

• SPECTRUM Support

- Modeling Instructions

- Accessing SPECTRUM views from the Device Icon

- Accessing Device-Specific Subviews

• SPECTRUM Views Roadmap

• SPMA Support

9031111 E7

1-1

EMME/EMM-E6

EMME/EMM-E6

The EMME (Ethernet Management Module for Ethernet) and EMM-E6

(Ethernet Management Module for Ethernet with six ports) are multi-port intelligent bridging modules installed in the right most slot of an MMAC FNB chassis. They have channels which act as bridge ports (Channels A, B, C, D, E, and F). Channels A, B, and C also act as repeater ports and direct traffic over the MMAC Flexible Network Bus (or backplane). Additionally, Cabletron

Systems FDDI modules for the MMAC FNB provide Ethernet to Fiber

Distributed Data Interface (FDDI) bridging capabilities.

With the addition of Repeater Management Control module (RMIM)in the chassis, the EMME and EMM-E6 function as bridges between up to three

Ethernet 802.3 subnetworks and an Ethernet backbone (fourth) network. The

Repeater MIMs use and control Channels B and C. Other modules use

Channel A and are controlled by the EMME or EMM-E6. Channels D1 and D2 are the AUI ports on the EMME and EMM-E6, and direct traffic to one of two external Ethernet Port Interface Modules (EPIMs). One D port is operational at a time, while the other D port is the redundant port and is in STDBY

(standby) or OFF .

The EMM-E6 allows you to monitor, configure, and bridge/route between channels A, B, and C on the backplane, a fourth external Ethernet via an

EPIM, and two BRIM ports. Optional BRIMs perform the same bridging functions as EPIMs; they transfer packets between different channels.

However, unlike EPIMs, BRIMs bridge these packets from one technology to another (e.g., Ethernet to FDDI network backbones, Asynchronous Transfer

Mode [ATM] to Wide Area, etc.). These BRIMs occupy the E and F channels.

The following BRIMs may be installed:

• BRIM-E6 : Ethernet interface

• BRIM-W6 : WAN interface (not supported at this time)

• BRIM-A6 : ATM interface

• BRIM-F6: FDDI interface

Introduction

1-2

EMME/EMM-E6


SPECTRUM Support

SPECTRUM Support

The following model type names refer to the models used to specify attributes, actions, and associations for the EMME and EMM-E6 devices in SPECTRUM:

• HubCSIEMME (EMME)

• BRtrCSIEMM_E6 (EMM-E6)

Standard RMON (RMONApp) DLM (DLM_Agent) and Routing Services

(CtRouter) are also supported and may be purchased separately.

Modeling Instructions

It is recommended that you model all devices in SPECTRUM using the

AutoDiscovery. However, if you wish to model your device manually, follow the steps below.

1.

Model an EMME/EMM-E6. (Refer to How to Manage Your Network

with SPECTRUM for basic modeling instructions.)

2.

Access the EMME/EMM-E6 Device Topology view to determine how many repeater ports are being used on the backplane of this device.

3.

For each repeater connection (Network A, B, or C) shown in the Device

Topology view, model a separate LAN icon (LAN_802_3) on the same hierarchical level as the EMME/EMM-E6 device icon. (The names of the

LANs should correspond with the names of repeater ports they will be connected to.)

4.

Within the EMME/EMM-E6 Device Topology (DevTop) view, select File ->

Edit to enter the edit mode.

5.

Highlight a single repeater icon.

6.

Select Edit -> Copy.

7.

Click OK in the confirmation window to override the buffer.

8.

Open the LAN model created in step 3 with name that corresponds with the name of the repeater you copied in the previous step.

9.

Enter the edit mode by selecting File -> Edit.

10. Select Edit -> Paste to paste the repeater icon into the LAN.

11. Select File -> Save and Close to complete the pasting process. The off-page EMME/EMM-E6 icon (in shape of the triangle) should appear, signifying the connection between the repeater and the EMME/EMM-E6 backplane.

9031111 E7 Introduction

1-3

SPECTRUM Support

Accessing SPECTRUM Views from the Device Icon

Figure 1-1.

Repeat the same actions for each repeater icon found in the Device Topology view of the EMME/EMM-E6. The connections established will appear in the topology view where EMME/EMM-E6 and network LAN icons were originally modeled, as well as in the EMME/EMM-E6 Device Topology (Dev Top) view.

Figure 1-1 shows an example of the EMME model configuration that includes

three channels connected to three repeaters. The EMM-E6 may have additional BRIM channel connections, which are not shown in this example.

Example of an EMME Model Configuration

Model Name

LAN 802.3

Channel A

Model Name

EMM-E6

EMME/EMM-E6

Model Name

LAN 802.3

Channel B

Model Name

LAN 802.3

Channel C

Accessing SPECTRUM Views from the Device Icon

The Device icon provides access to SPECTRUM views that display device-specific information. Access these views through double-click zones

(Figure 1-2) or the Icon Subviews menus (Figure 1-3). Placing your cursor over

a double-click zone lets you see the name of the view accessed by double-clicking that zone.

To access the Icon Subviews menu, as shown in Figure 1-4, do the following:

1.

Highlight the icon.

2.

From the View menu select Icon Subviews or click the applicable mouse button (middle or right). Refer to Getting Started with SPECTRUM for

Operator’s for information on configuring your mouse.

Introduction

1-4

EMME/EMM-E6


Figure 1-2.

SPECTRUM Support

Accessing SPECTRUM Views from the Device Icon

Using Double-Click Zones to Access SPECTRUM Views

Accesses the EMME/EMM-E6 Device

Configuration View; see Chapter 3,

Configuration View.

Accesses the Device Topology view; see SPECTRUM Views.

Model Name

Accesses the Chassis Device View;

see Chapter 2, Device Views.

HubCSIEMME

Accesses the Performance view;

SPECTRUM Views.

Accesses the Device Application View;

see Chapter 5, Application View.

Accesses the EMME/EMM-E6 Device

Configuration View; see Chapter 3,

Configuration Views.

Accesses theChassis Device

View; see Chapter 2, Device

Views.

Model Name

HubCSIEMME

Accesses the Performance view; see

SPECTRUM Views.

Accesses the Device Topology view; see SPECTRUM Views.

Accesses the Device Application

View; see Chapter 5, Application

View.


1-5

SPECTRUM Support

Accessing Device-Specific Subviews

Figure 1-3.

Using the Icon Subviews Menu to Access SPECTRUM Views

Model Name

EMM-E6

View

Go Back

Go Up

Icon Subviews

View Path

Ctrl+b

New View

Bookmarks

View History

Current View Info...

Notes...

Jump by name...

Map Hierarchy

Zoom

Page

Close Ctrl+c

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Device

DevTop

Chassis

Interface

Physical

Accessing Device-Specific Subviews

Icon Subviews menus provide access to views that display device-specific

information. Figure 1-4 shows an example of an Icon Subviews menu for an

Application label on the Chassis Module icon located in the Chassis Device view. The device-specific Icon Subviews menu selections are described under the applicable section within this guide. The menu selections that are common to all devices are described in SPECTRUM Menus.

To access the Icon Subviews menu using the View menu, do the following:

1.

Highlight the icon.

2.

From the View menu, select Icon Subviews.

To access the Icon Subviews menu using the mouse button, do the following:

1.

Position the mouse pointer on the icon.

2.

Click the applicable mouse button (middle or right). Refer to Getting

Started with SPECTRUM for Operator’s for information on configuring your mouse.

Introduction

1-6

EMME/EMM-E6


Figure 1-4.

SPECTRUM Views Roadmap

Accessing Device-Specific Subviews

1

EMME

Bridging

A

B

C

FWD

FWD

FWD

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Ctrl +c

Bridge Performance

Bridge Model Information

Special Database

Spanning Tree Information

Static Database Table

Transparent Bridge Info

Common

Device-Specific

SPECTRUM Views Roadmap

Figure 1-5 shows a “roadmap” of the SPECTRUM views for this device. These

views are accessible from double-click zones (Figure 1-2) and Icon Subviews

menus (Figure 1-3 and Figure 1-4).


1-7

SPECTRUM Views Roadmap

Figure 1-5.

SPECTRUM Views Roadmap

Performance View; refer to

SPECTRUM Views .

Model Name

EMM-E6

DevTop View; refer to

SPECTRUM Views.

.

Introduction

1-8

Device Views; see

Chapter 2, Device Views

Configuration Views; see

Chapter 3, Configuration

Views .

Application View; see

Chapter 5, Application

View .

.

Chassis Device View

Interface Device View

Physical Device View

EMME/EMM-E6 Device

Configuration View

Chassis Configuration View

(EMME only)

Module Configuration View

Port Configuration View

Repeater Configuration View

CSI Isolated Repeater


Interface Configuration Views

(EMM-E6 only)

Port Configuration View (for FDDI)

SMT Device Configuration View

ATM Client Application


Network (A, B, or C) Application

DownLoad Application

Isolated Repeater Application


FddiSMT Application

EMME/EMM-E6


SPMA Support

SPMA Support

SPECTRUM also supports SPECTRUM Portable Management Application

(SPMA) functionality for the EMME/EMM-E6. To open the SPMA

Applications view from any SPECTRUM view, do the following:

1.

Highlight the Device icon.

2.

From the View menu, select Icon Subviews -> Utilities ->

Applications....

Figure 1-6 shows an example of an SPMA Applications view.

Figure 1-6.

SPMA Applications View

Applications

132.177.118.24 of type BRtrCSIEMME_E6

Community Names Hub View

CtRouter of type CTRouterApp

Basic Configuration

Bridging of type CSIBridge

Basic Alarms Bridge View

Network A of type CSIRptr

Alarm Configuration

Link/Seg Traps

Redundancy

Source Addressing

Network C of type CSIRptr

Alarm Configuration

Link/Seg Traps

Redundancy

Source Addressing

Download App of type CmDownLoadApp

TFTP Download

Front Panel Redundancy

Port Source Address

Security Configuration

Port Source Address


Close


1-9

SPMA Support

The buttons within the SPMA Applications view provide access to

SPMA-specific views and dialog boxes. The Application view for a particular device may include different buttons depending upon the applications available, the BRIMs installed, and the configuration of your device. Refer to the following documentation for information on the SPMA views accessible from the Applications view:

SPECTRUM Portable Management Application for the EMME User’s

Guide

SPECTRUM Portable Management Application for the EMM-E6 User’s

Guide

SPECTRUM Portable Management Application Tools Guide

Introduction

1-10

EMME/EMM-E6


Chapter 2

Device Views


This chapter describes the following Device views available for the

EMME/EMM-E6:

• Chassis Device view

• Interface Device view

• Physical Device view

See Chapter 1, Introduction, for information on Accessing SPECTRUM Views

from the Device Icon and Accessing Device-Specific Subviews

Each Device view provides a representation of the EMME/EMM-E6’s configuration and menu access to the views that monitor and control the

EMME/EMM-E6, its modules, and the module’s ports. If the configuration changes (e.g., a board is pulled from or added to the MMAC), the corresponding change(s) is displayed.

Only the port or application status is updated every polling cycle. Board or application icons change when a model reconfiguration occurs.

NOTE

9031111 E7

2-1


Chassis Device View

This view is a logical representation of the MMAC FNB chassis and the modules it contains. The Chassis Device view provides both menu access and double-click zone access to the views that monitor the modules, interfaces or ports.

Figure 2-1 shows an example of the Chassis Device view including an EMME

installed in slot number one and Management Interface modules (MIMs) it manages. MIMs are connected to the EMME via the Chassis FNB Backplane.

Device Views

2-2

EMME/EMM-E6



Figure 2-1.

Chassis Device View

Primary Landscape 0x00400000 - VNM Host - EMME of type CSIEMME

* File View

Model Name

Contact

Description

Location

Net Addr

Prime-App

Sys Up Time

Manufacturer

Device Type

Serial Number

5 Iso ReptrB

TPXMIM22

1 LNK

2 0

3 LNK

0

4 LNK

0

0

5

6

7 LNK

9

LNK

8 LNK

LNK

0

0

0

0

0

10 LNK

11 LNK

12 LNK

13 LNK

14 LNK

15 LNK

0

0

0

0

0

0

0 16 LNK

17 LNK

18 LNK

19 LNK

20 LNK

21 LNK

0

0

0

0

0

22 LNK 0

4

Network A

TPT

1 SEG

2

SEG

3

SEG

4

SEG

7

8

5 SEG

6

SEG

SEG

SEG

9 SEG

10 SEG

11

SEG

0

0

0

0

0

0

0

10

0 11

0

0

0

12 SEG 0

3 Network A

10BT-24

10 LNK

11 LNK

12

13

LNK

LNK

14 LNK

15 LNK

16 LNK

17

18

LNK

LNK

19 LNK

20

21

LNK

LNK

22

LNK

1

2

LNK

LNK

5

6

3

4

LNK

LNK

LNK

7 LNK

8 LNK

9 LNK

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

2 Network B

TPR-20

1

LNK

2 LNK

3 LNK

4 LNK

5

6

9

LNK

LNK

7 LNK

8 LNK

LNK

10 LNK

0

0

0

0

0

0

0

0

0

0

1

EMME

Bridging

A

B

FWD

B

C

D1

D2

FWD

FWD

FWD

OFF

Repeaters

UNLOCKED

UNLOCKED

Help?

9031111 E7 Device Views

2-3


EMME/EMM-E6 Module Icon

EMME/EMM-E6 Module Icon

This icon is a logical representation of the physical module, its location in the

MMAC FNB chassis and its front and back panel interfaces or ports.

Figure 2-2 shows an example of an EMME module and Figure 2-3 shows an

example of an EMM-E6 module as seen in the Chassis Device View.

NOTES

The callouts in the illustrations that follow identify the labels and, when applicable, the views to which they provide double-click access. Example: Slot

Number/Notes View - displays the slot number and provides double-click access to the Notes view.

The menus displayed in these illustrations are the icon subviews menus for the corresponding labels or the Chassis Module icon.

Device Views

2-4

EMME/EMM-E6




Figure 2-2.

EMME Module Icon

Module

Identification

Labels

Slot Number

Notes View

/

Model Type/

Model Info. View

Application Label/

Performance View

Interface

Channel

Interface Status

Interface

Labels

EPIM Ports/

Notes View

Repeater

Port Labels

Repeater Label

Port Channel/

Rptr. Config View

Port Status/

Performance View

1

EMME

Bridging

FWD

B

C

D1

D2

FWD

FWD

FWD

OFF

Repeaters

A

B

UNLOCKED

UNLOCKED

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Bridge Performance





Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Configuration

Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Ctrl +c

Module Notes

EMME Application

EMME Configuration

EMME Model Information

EMME Front Panel Redundancy

Chassis Configuration

Application Display

Gauge Control Panel

Physical

Bridging

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Redund Configuration

Configuration

Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Ctrl +c

Zoom

Repeater Notes

Repeater Events

Repeater Alarms

Repeater Performance

Repeater Frame & Error Breakdown

Repeater Frame Size & Protocols

Repeater Configuration

Repeater Model Information

Repeater Redundancy

Repeater Source Address

Repeater Security Configuration


2-5



Figure 2-3.

EMM-E6 Module Icon

Module

Identification

Labels

Slot Number

Notes View

/

Model Type/

Device Config. View

Application Label/

Performance View

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Ctrl +c

Module Notes

EMM-E6 Application

EMM-E6 Configuration

EMM-E6 Model Information

EMM-E6 Front Panel Redundancy

Application Display

Gauge Control Panel

2

EMM-E6

Bridging

1

FWD

Interface Channel

B

FWD

Interface Status

Interface

Labels

C FWD

D1

FWD

EPIM Ports/

Notes View

D2 OFF

Repeater

BRIM

Port

Repeater Label

Port Label

Port Channel/

Rptr. Config View

Port Status/

Performance View

BRIM Label/

Performance View

BRIM Port Labels

E Fddi FWD

Repeaters

A UNLOCKED

1

2

FDDI

A CON

B CON

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Bridge Performance

Bridge Detail





Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Configuration

Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Redund Configuration

Configuration

Ctrl +c

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Port Notes

Ctrl +c

Enable/Disable Port

Port Configuration View

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

FDDI Performance

Ctrl +c

FDDI Configuration

FDDI Station List

FDDI Model Information

Hub Detail

Close

Navigate

Alarms

Performance

Notes...

Ctrl +c

Utilities

Zoom

Repeater Notes

Repeater Events

Repeater Alarms

Repeater Performance

Repeater Frame & Error Breakdown

Repeater Frame Size & Protocols


Repeater Model Information

Repeater Redundancy

Repeater Source Address

Repeater Security Configuration

Device Views

2-6

EMME/EMM-E6




EMME/EMM-E6 Module Identification Labels

These labels provide the following information (refer to Figure 2-1 and

Figure 2-3):

Slot Number

Displays the number of the MMAC FNB slot that the module is connected to.

Double-click this area to open the Notes view described in SPECTRUM

Views.

Model Type

Identifies the type of module in this MMAC FNB slot (e.g., EMM-E6).

Double-click this area of the EMME to open the Model Information view.

Double-click this area of the EMM-E6 to open the EMME/EMM-E6 Device

Configuration View described in Chapter 3, Configuration Views.

EMME/EMM-E6 Chassis Module Icon Subviews Menu

Table 2-1.

Table 2-1 lists each of the device-specific Icon Subviews menu selections

available for EMME/EMM-E6. See Chapter 1, Introduction, for information on

Accessing Device-Specific Subviews.

EMME/EMM-E6 Module Icon Subviews Menu

Menu Selection Description

Module Notes

EMME/EMM-E6 Application

Opens the Notes view described in SPECTRUM

Views.

Opens the Device Application View described in

Chapter 5, Application View.

EMME/EMM-E6 Configuration

Opens the EMME/EMM-E6 Device Configuration

View described in Chapter 3, Configuration Views.

EMME/EMM-E6 Model

Information

EMME/EMM-E6 Front Panel

Redundancy

Opens the EMME/EMM-E6 Model Information view described in the SPECTRUM Views.

Opens the EMME/EMM-E6 Front Panel

Redundancy view described in the SPECTRUM

Portable Management Application for the

EMME User’s Guide or the SPECTRUM

Portable Management Application for the

EMM-E6 User’s Guide.

Chassis Configuration

(EMME only)

Application Display

Gauge Control Panel

Opens the Chassis Configuration View (EMME

only) described in Chapter 3, Configuration Views.

Opens the Application Display submenu, allowing you to chose the application to be displayed e.g.,

Physical (MIB-II) or Bridging.

Opens the Gauge Control Panel described in this

chapter.


2-7



Application Label

Table 2-2.

Application label provides access to the Icon Subviews menu for the

application displayed (refer to Figure 2-2

and Figure 2-3). Double-click the

Application label to open the Performance view described in SPECTRUM

Views. The application selected determines the information displayed and the menu selections available. To select the application, highlight the Chassis

Logical Module and select View -> Icon Subviews -> Application Display.

The default application for this view is Bridging.

Table 2-2 describes the Bridging Application Icon Subviews menu selections.

See Chapter 1, Introduction, for information on Accessing Device-Specific

Subviews. There are no specific Icon Subviews menu selections for the

Physical Application.

Bridge Menu Selections


Bridge Performance

Bridge Detail

(for EMM-E6 only)

Opens the Performance view described in SPECTRUM

Views.

Opens the Detail view described in MIB II Applications,

Bridging Applications, and Miscellaneous

Applications.

Bridge Model Information Opens the Model Information view described in

SPECTRUM Views.

Spanning Tree

Information

Opens the Spanning Tree Information view described in

MIB II Applications, Bridging Applications, and

Miscellaneous Applications.

Static Database Table Opens the Static Database Table view described in MIB

II Applications, Bridging Applications, and

Miscellaneous Applications.

Transparent Bridge Info Opens the Transparent Bridge Information view, with

Forwarding Database and Port Tables described in MIB

II Applications, Bridging Applications, and


Device Views

2-8

EMME/EMM-E6




Interface Labels

These labels represent up to six Ethernet Bridging Channels, managed by the

EMME/EMM-E6, that are located on the front panel of the device as well as within the hub. The Interface labels provide access to the Icon Subviews menu for the interface and display two information labels: an Interface Channel label and an Interface Status label.

The menu selection for an Interface Label is Configuration. It opens the

Configuration dialog box, which allows you to enable or disable bridging for

the selected port. See Chapter 1, Introduction, for information on Accessing

Device-Specific Subviews.

Table 2-3.

Interface Channel

This label identifies one of six channels connected to the EMME/EMM-E6

(refer to Figure 2-2 and Figure 2-3). The A, B, C labels refer to three Ethernet

channels in the MMAC hub, the D1 and D2 labels refer to the redundant

EPIM connection and are described separately in this section. The “E” label refers to the connection to one of the BRIMs located on the front panel of the device. In addition, the Interface Channel label for channel “E” provides information on what kind of BRIM (Ethernet, FDDI, ATM) is attached to this device.

Interface Status

This label indicates the port activity status. Table 2-3 and Table 2-4 list the

possible states relative to the application selected. Refer to the Application

Label, described previously in this chapter, for information on selecting the

application to be displayed.

Interface Status for the Bridging Application

Color

Green

Blue

Yellow

Yellow

Yellow

Yellow

Red

Blue

Status

FWD

DIS

LSTN

LRN

STBY

BLK

BRKN

UNK

Description

Bridge port is forwarding network traffic.

Port is disabled.

Bridge is in the listening mode.

Bridge is in the learning mode

Bridge port is in the standby mode.

Bridge port is in the blocking mode.

Bridge port is broken.

The status is unknown.


2-9



Table 2-4.

Interface Status for the Physical or MIB II Application

Color

Green

Blue

Yellow

ON

OFF

TST

Status Description

Port is operational.

Port is disabled.

Port is in the test mode.

Table 2-5.

EPIM Ports

These labels represent the connection to the EPIM ports located on the front panel of the device, which direct traffic to one of two external Ethernet Port

Interface Modules (EPIMs). One D port is operational (FWD) while the other

D port is redundant (STBY) or inactive (OFF). See Table 2-3 for interface

status label descriptions.

Table 2-5 lists the Subviews menu selections available from this label. See

Chapter 1, Introduction, for information on Accessing Device-Specific

Subviews.

AUI Port Subviews Menu


Redund Configuration Opens the Front Panel Redundancy view described in the

SPECTRUM Portable Management Application for

the EMME User’s Guide or the SPECTRUM Portable

Management Application for the EMM-E6 User’s

Guide.

Configuration Opens the Configuration dialog box, which allows you to enable or disable bridging for the selected port.

BRIM Port

This label represent the connection to one of two BRIM ports located on the front panel of the EMME/EMM-E6, which direct traffic to the optional external Bridge/Router Interface Module (BRIM). A second interface provided by the other BRIM port (forming channel F) will be implemented in the future.

Device Views

2-10

EMME/EMM-E6




Repeater Label

Table 2-6.

This label represents the Repeater application that allows for transfer of information between the repeaters in the MMAC chassis and

EMME/EMM-E6. The repeater label provides access to the Icon Subviews

menu for this application. Table 2-6 lists specific Subviews menu selections for

the Repeater Label. See Chapter 1, Introduction, for information on Accessing

Device-Specific Subviews.

Repeater Menu Selections


Repeater Notes

Repeater Events

Opens the Notes view described in SPECTRUM Views.

Opens the Event Log window described in SPECTRUM

Views.

Repeater Alarms Opens the Alarm Manager view described in SPECTRUM

Views.

Repeater Performance Opens the Performance view described in SPECTRUM

Views.

Repeater Frame & Error

Breakdown

Opens the Repeater Frame & Error Breakdown View

described later in this chapter.

Repeater Frame Size &

Protocols

Opens the Repeater Frame Size & Protocols View described

later in this chapter.


Opens the Repeater Configuration View described in

Chapter 3, Configuration Views.

Repeater Model

Information

Opens the Repeater Model Information view described in

SPECTRUM Views.

Repeater Redundancy Opens the Repeater Redundancy view described in the


the EMME User’s Guide or the SPECTRUM Portable


Guide.

Repeater Source

Address

Opens the Repeater Source Address view described in the


the EMME User’s Guide or the SPECTRUM Portable


Guide.

Repeater Security

Configuration

Opens the Repeater Security view described in the




Guide.


2-11


Repeater Frame & Error Breakdown View

This view displays statistics for a selected port. To access this view do the following:

1.

Within the Chassis Device view, highlight the Repeater label.

2.

From the Icon Subviews menu, select Repeater Frame & Error

Breakdown.

This view is divided into two areas which provide the following separate performance information:

• Frame Breakdown

• Error Breakdown

Each area includes the pie chart providing a visual representation of the numerical statistics. In addition, the Repeater Frame and Error Breakdown view supplies the following presentation modes, affecting the way data is displayed in this view:

Total

Allows you to display the current statistical information for all items contributing to the total value.

Delta

Allows you to display the difference between the previously polled values and the current value of every item contributing to the total

Accum

Allows you to view the accumulated statistical information for all items since the Accum button was last selected.

NOTE

Clear

Select this button to restart the counter. The values will continue to accumulate until clear is selected or another presentation mode is chosen.

Selecting Total, Delta or Accum affects the numerical, as well as graphical representation of every item contributing to the total.

Device Views

2-12

Pie Chart

When Total is selected, the pie chart displays the current statistical information for all items contributing to the total value. When Delta is selected, the pie graph is used to compare the difference between the previously polled value and the current value of all items. When Accum is chosen, the pie chart provides the statistics for all items accumulated since the Accum button was selected.

EMME/EMM-E6


9031111 E7


Frame Breakdown

Displays the breakdown of all the frames transmitted and received through the selected port. The following categories are displayed first as numbers followed by percentages:

• Good Frames

• Collisions

• Errors

• Total

For more information on the individual error types refer to How to Manage

Your Network with SPECTRUM.

Error Breakdown

Displays the number of port traffic errors in an error per second format. The following types of errors are displayed first as numbers followed by percentages:

• Alignment

• CRC

• Runts

• Giants

• OOW Colls

• Total



Repeater Frame Size & Protocols View

This view displays statistics for a selected port. To access this view do the following:

1.

Within the Chassis Device view, highlight the Repeater label.

2.

From the Icon Subviews menu, select Repeater Frame & Protocols.

This view is divided into two areas which provide the following separate performance information:

• Frame Size

• Protocols

Each area includes the pie chart providing a visual representation of the numerical statistics. In addition, the Repeater Frame Size and Protocols view provides the following presentation modes, affecting the way data is displayed in this view:

Device Views

2-13


Total

Allows you to display the current statistical information for all items contributing to the total value.

Delta

Allows you to display the difference between the previously polled value and the current value of every item contributing to the total.

Accum

Allows you to view the accumulated statistical information for all items since the Accum button was last selected.

NOTE

Clear

Select this button to restart the counter. The values for all items will continue to accumulate until clear is selected or another presentation mode is chosen.

Selecting Total, Delta, or Accum affects the numerical, as well as graphical representation of every item contributing to the total.

Device Views

2-14

Pie Chart

When Total is selected, the pie chart displays the current statistical information for all items contributing to the total value. When Delta is selected, the pie graph is used to compare the difference between the previously polled value and the current value of all items. When Accum is chosen, the pie chart provides the accumulated statistics for all items accumulated since the Accum button was selected.

Frame Size

Displays a number signifying how many frames from a selected port are of a certain size. This number is displayed as a numerical value and as percentage of the total frames transmitted and received. The view provides the following frame size categories:

• Runts

• 64 -127 Bytes

• 128 - 255 Bytes

• 256 - 511 Bytes

• 512 - 1023 Bytes

• Giants



EMME/EMM-E6


Table 2-7.


Protocols

Display a number of particular protocol types generated for a selected port.

The following protocols are displayed first as numbers followed by percentages:

• IP

• OSI

• DECnet

• XNS

• Novel

• AppleTalk

• Banyan

• Ctron

• Other

Repeater Port Label

This label represents the bridging channel connecting the EMME/EMM-E6 to a MIM located in the hub.

Repeater Port Channel

This label identifies one of the bridging channels this repeater is connected to

(refer to Figure 2-2 and Figure 2-3). Letters “A”, “B”, and “C” signify the three

internal bridging channels. The background for the Repeater Port Type label is color coded to associate the port with its currently selected channel.

Table 2-7 lists the colors assigned to the repeater ports.

Repeater Port Channel Label & Background Colors

Background Color Repeater Channel

Channel A

Channel B

Channel C

Light orange

Light blue

Light violet

Double-click this label to access the Repeater Configuration View described in



2-15


Repeater Port Status

This label indicates the port activity status. Double-click the Repeater Port

Status label to access the Performance view described in SPECTRUM Views.

BRIM Label (exclusive to EMM-E6)

This label represents the interface to which EMM-E6 provides bridging or routing capabilities through the additional BRIM connections on the front panel of the device. Depending on the BRIMs connected to the device, the

EMM-E6 can supply one additional interface (channel “E”) configured to provide bridging or routing to Ethernet, FDDI, or ATM networks. An EMM-E6 equipped with an Ethernet BRIM will not display a separate Ethernet label.

Table 2-8.

FDDI Label

This label represents the FDDI application and signifies that the EMM-E6 is configured to provide additional bridging or Feeder Node Routing on FDDI.

The FDDI label provides access to the FDDI application-specific Icon

Subviews menu. Table 2-8 describes all menu selections accessible from this

label. See chapter 1, Introduction, for information on Accessing Device-Specific

Subviews.

FDDI Label Icon Subviews Menu

Menu Selection

FDDI Performance

FDDI Configuration

FDDI Station List

FDDI Model

Information

Hub Detail

Description

Opens the Performance view described in SPECTRUM

Views.

Opens the SMT Device Configuration View described in


Opens the FDDI Station view described in MIB II

Applications, Bridging Applications,

andMiscellaneous Applications.

Opens the SMT Model Information view described in

SPECTRUM Views.

Opens the FddiSMT Detail view described in MIB II

Applications, Bridging Applications, and

Miscellaneous Applications.

Double-click this label to open the Performance view described in

SPECTRUM Views.

Device Views

2-16

EMME/EMM-E6


Table 2-9.


ATM Label

This label represents the ATM application and signifies that the EMM-E6 is configured to provide additional bridging or Feeder Node Routing on ATM. the

ATM label provides access to the ATM Application specific Icon Subviews

menu. Table 2-9 describes all menu selections accessible from this label. See

chapter 1, Introduction, for information on Accessing Icon-Specific Subviews.

ATM Label Icon Subviews Menu

Menu Selection

Configuration

VCL Table

Model Information

Description

Opens the ATM Client Application Configuration View

described in Chapter 3, Configuration Views.

Opens the ATM Client Application Virtual Channel Link

View described in Chapter 5, Application View.

Opens the ATM Application Model Information View described in SPECTRUM Views.

Double-click this label to open the Performance view described in

SPECTRUM Views.


2-17


BRIM Port Label

Table 2-10.

This label identifies the port on the front panel of the BRIM. BRIMs with a single front panel port do not display BRIM Port labels (e.g., ATM) therefore their BRIM Channel represents the entire BRIM connection (refer to

Figure 2-3).

The BRIM Port label provides access to the Icon Subviews Menu described in

Table 2-10. See chapter 1, Introduction, for information on Accessing


BRIM Port Label Subviews Menu


Port Notes

Enable/Disable Port


Opens a dialog box which allows you to enable or disable a selected port.

Port Configuration View Opens the Port Configuration view described in Chapter 3,

Configuration Views.

BRIM Port Type Label

This label consists of two fields: the number field and the letter field. The number field displays the number assigned to this BRIM port. The letter field displays the type of this port.

Double-click the number field of the BRIM Port Type label to access the Notes view described in SPECTRUM Views.

Table 2-11.

BRIM Port Status Label

This label indicates the port activity status. All possible states and their color

definitions are described in Table 2-11.

BRIM Port Status Descriptions

State Description

Green

Blue

Yellow

Red

Color

ACT

DIS

CON

SBY active disabled connecting standby

Device Views

2-18

EMME/EMM-E6



MIM Icon

MIM Icon

NOTES

This icon represents a Media Interface Module (MIM). There are two basic types of MIMs that can be managed by the EMME/EMM-E6: Repeater MIMs

(RMIMs) and non-repeater MIMs.

The EMME/EMM-E6 manages the RMIMs located in the MMAC chassis through Ethernet channels B, and C. RMIMs can repeat packets autonomously without channeling them through the EMME/EMM-E6. The members of the RMIM family designed to work with the EMME/EMM-E6 are:

FORMIM, CXRMIM, TPRMIM, and TPXMIM. Figure 2-4 shows an example

of a Repeater MIM icon.

The EMME/EMME-6 uses channel A on the MMAC backplane to transmit and receive data from non-repeater MIMs (i.e., TRMIMs, FOMIMs,

THN-MIMs). The EMME/EMM-E6 provides repeater functionality for these

MIMs.

The callouts in the illustration below identify the labels and, when applicable, the view to which they provides double-click access. Example: Slot

Number/Notes View - displays the slot number and provides double-click access to the Notes view.



2-19


MIM Icon

Figure 2-4.

MIM Icon

MIM

Identification

Labels

Slot Number/

Notes View

Module Channel or Isolation Station/

Performance View

Module Type/

Module Config. View

Repeater

Port Label

Port Number/

Notes View

Port Status/

Port Config. View

Port Statistics/

Performance View

2 Network B

FORMIM-22

1 SEG

2 LNK

3

LNK

4

LNK

5

SEG

6

ON

7

LNK

8

LNK

9 SEG

10

SEG

11 ON

12 SEG 0

0

0

0

0

147

0

0

0

0

0

487

Close

Navigate

Alarms

Performance

Notes...

Utilities

Zoom

Module Notes

Serial Number

Module Configuration

Module Performance

Module Dev Top View

Repeater

Ctrl +c

Module Frame & Error Breakdown

Module Frame Size & Protocols

Enable All Ports

Change Module Channel

Close

Navigate

Alarms

Performance

Notes...

Utilities

Ctrl +c

Zoom

Port Notes

Port Configuration

Port Performance

Port Frame and Error Breakdown

Port Frame Size & Protocols

Port Redundancy

Port Source Address

Port Security Configuration

Enable/Disable Port

MIM Identification Labels

These labels provide the following information (refer to Figure 2-4):

Slot Number

Displays the number of the MMAC FNB slot that the module is connected to.


Views.

Device Views

2-20

EMME/EMM-E6



MIM Icon

Module Channel or Isolation Station

Displays the network/channel that the module is connected to. If the module is in the stand-alone mode, “StandAlone” is displayed. If more than one channel is in use by the module, “StandAloneX” or “NetworkX” is displayed.

Double-click this area to access the Performance view described in

SPECTRUM Views.

Module Type

Displays the type of module in this MMAC FNB slot (e.g., FOM-22).

Double-click this area to access the Module Configuration view described in


MIM Icon Subviews Menu

Table 2-12.

Table 2-12 describes each of the module-specific Icon Subviews menu

selections available for the Repeater module. Table 2-13 describes a submenu

accessible by clicking the Repeater option of the Icon Subviews menu. See

Chapter 1, Introduction, for information on Accessing Device-Specific

Subviews.

MIM Icon Subviews Menu

Menu Selection

Module Notes

Serial Number


Module Performance

Module DevTop View

Repeater

Description


Opens the dialog box allowing you to enter or alter the serial number for the selected module.

Opens the Module Configuration view described in Chapter

3, Configuration Views.


Views.

Opens the Device Topology view described in SPECTRUM

Views.

Opens a submenu described in Table 2-13.


2-21


MIM Icon

Table 2-13.

MIM Module Icon Subviews (Repeater option)


Module Frame & Error

Breakdown


described earlier in this chapter.

Module Frame Size &

Protocols

Enable All Ports


earlier in this chapter.

Opens a dialog box which allows you to enable or disable all ports on a selected module.


(RMIM only)

Opens the Change Module Channel View (RMIMs only)

described later in this chapter.

NOTES

Change Module Channel View (RMIMs only)

This view allows you to change the FNB channel used by a port to communicate with the EMME/EMM-E6. It also allows you to reconfigure the module to a stand-alone mode if it provides its own repeater functionality. To access this view do the following:

1.

Within the Chassis Device view, highlight the Repeater MIM.

2.

From the Icon Subviews menu, select Repeater -> Change Module

Channel.

When configured to operate on channels B or C, the Repeater MIM provides its own repeating; when operating on channel A, its ports depend on the

EMME/EMM-E6 for repeater functionality. Change Module Channel view provides the following information and fields:

Module Number

Displays the slot number where the selected RMIM is located. The RMIM located in this slot will be the only one affected by the configuration changes.

Module Connection

Allows you to chose the appropriate backplane channel or mode. The possible selections are: Channel B, Channel C, Stand_Alone, and Channel_X.

The Stand_Alone option can be applied to all ports configured to use Channels

B or C. Any ports that are configured to operate on Channel A cannot be

switched to the Stand_Alone mode. For more information, see Creating an

Isolated Repeater in Chapter 5, Application View.

Board-level settings will override the any individual port-level settings.

Refer to Release Notes that were shipped with your EMME/EMM-E6 firmware for more information about the implication of operating your

TPXMIM in a Stand_Alone mode.

Device Views

2-22

EMME/EMM-E6



MIM Icon

Repeater Port Labels

Table 2-14.

These labels represent repeaters located on the front panel of the RMIM which supply outside chassis network connectivity.

Repeater Port labels provide access to the port-specific Icon Subviews Menu

described in Table 2-14. See Chapter 1, Introduction, for information on


Repeater Port Icon Subviews Menu

Menu Selection

Port Notes

Port Configuration

Port Performance

Port Frame & Error

Breakdown

Port Frame Size &

Protocols

Port Redundancy

Port Source Address

Port Security

Configuration

Enable/Disable Port

Description

Opens the Notes view described in SPECTRUM Views.

Opens the Port Configuration view described in Chapter 3,

Configuration Views.


Views.

Opens the Port Frame & Error Breakdown view. For

description of fields in this view, refer to the Repeater

Frame & Error Breakdown View described earlier in this

chapter.

Opens the Port Frame Size & Protocols view. For

description of fields in this view, refer to the Repeater

Frame Size & Protocols View described earlier in this

chapter.

Opens the Repeater Redundancy view described in the




Guide.

Opens the Port Source Address view described in the




Guide.

Opens the port Security Configuration view described in the




Guide.



2-23


MIM Icon

Port Number

Identifies the port’s location within the module. The background for this label is color coded to associate the port with its currently selected channel.

Double-click this label to open the Notes view described in SPECTRUM

Views.

Port Status

Describes the port activity status.

Port Statistics

Displays the number of frames (packets) transmitted or received by this port.

Device Views

2-24

EMME/EMM-E6



TPXMIM

TPXMIM

NOTES

The EMME/ EMM-E6 also supports Cabletron’s family of Twisted Pair

Switching Media Interface Modules (TPXMIMs). The TPXMIM-20, -22, -33 and -34 are a series of port assignment modules designed specifically for

Cabletron’s MMAC FNB hubs equipped with the EMME/EMM-E6. TPXMIM permits the entire board (bank switching) or each individual port (the port assignment) to be assigned to any of the three Ethernet channels A, B, and C on the MMAC FNB backplane. This way the unnecessary traffic across the bridge can be eliminated. The TPXMIM gives you an option of reassigning ports to different channels right at the management station without having to move the cable.

Figure 2-5 displays the TPXMIM icon as seen in the Chassis Device View.

The callouts in the illustration below identify the label and, when applicable, the view to which they provide double-click access. Example: Port

Number/Notes View - displays the sport number and provides double-click access to the Notes view.



2-25


TPXMIM

Figure 2-5.

TPXMIM Icon

Module

Identification

Labels

Slot Number

Module Channel or Isolation Station

Module Type

EPIM Port

Close

Navigate

Alarms

Performance

Notes...

Utilities

Ctrl +c

Zoom

Module Notes

Serial Number

Enable All Ports


Module Segment Details

TPXMIM

Port Labels

Port Number/

Notes View

Port Status/

Port Config. View

Port Statistics/

Performance View

5 Network B

TPXMIM22

0

2

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

2 LNK

3

LNK

4

LNK

5 LNK

6

LNK

7 LNK

8

LNK

9 LNK

10 ON

11 LNK

12

LNK

13

LNK

14 LNK

15 LNK

16 LNK

Network A

Network B

Network C


Module Performance

Module Frame & Error Breakdown

Module Frame Size & Protocols

Module Devtop View

Close

Navigate

Alarms

Performance

Notes...

Ctrl +c

Utilities

Zoom

Port Notes

Port Configuration

Port Performance

Port Frame and Error Breakdown

Port Frame Size & Protocols

Port Redundancy

Port Source Address

Port Security Configuration

Enable/Disable Port

Change Port Channel

Device Views

2-26

EMME/EMM-E6



TPXMIM

TPXMIM Identification Labels

These labels provide the following information (refer to Figure 2-5):

Slot Number

Displays the number of the MMAC-FNB slot that the module is connected to.


Views.

Module Channel or Isolation Station

Displays the channel that the module is connected to. If the module is in the stand-alone mode, “StandAlone” is displayed. If more than one channel is in use by the module, “StandAloneX” or “NetworkX” is displayed.

Module Type

Displays the type of module in this MMAC FNB slot (e.g.,TXMIM 22).

TPXMIM Icon Subviews Menu

Table 2-15.

Table 2-15 describes each of the module-specific Icon Subviews menu

selections available for the TPXMIM. Table 2-16 describes the submenu

accessible for each channel listed under the Module Segment Detail option.

See Chapter 1, Introduction, for information on Accessing Device-Specific

Subviews.

TPXMIM Icon Subviews Menu


Module Notes

Serial Number


Opens a dialog box allowing you to enter or alter the serial number for the selected module.

Enable All Ports Opens a dialog box allowing you to enable or disable all ports located on a selected module.


(Channel B & C only)

Opens the Change Module Channel View (RMIMs only)

described earlier in this in this chapter.

Module Segment Details Allows you to access a submenu for each channel (A, B, and

C) being used. Table 2-16 lists the menu selections for these

channels.


2-27


TPXMIM

Table 2-16.

TPXMIM Icon Subviews Menu (Module Segment Details option)



Module Performance

Module Devtop View

Opens the Module Configuration view described in Chapter

3, Configuration Views.


Views.

Module Frame & Error

Breakdown

Opens the Module Frame & Error Breakdown view. For

description of fields in this view refer to the Repeater Frame

& Error Breakdown View described earlier in this chapter.

Module Frame Size &

Protocols

Opens the Module Frame Size & Protocols view. For

description of fields in this view refer to the Repeater Frame

Size & Protocols View described earlier in this chapter.


Views.

TPXMIM Port Labels

Table 2-17.

These labels represent TPXMIM ports situated on the front panel of the module. Port number 1 represents the EPIM port. If an EPIM is not installed in the device, the Port label will not display the port status. The function of repeater ports is to supply the module with connectivity to external networks.

The TPXMIM port management differs from the management of the ordinary

MIM ports because every TPXMIM port can be assigned to any of the three

Ethernet channels on the MMAC FNB backplane.

TPXMIM Port labels provide access to the port-specific Icon Subviews menu

described in Table 2-17. See Chapter 1, Introduction, on Accessing


TPXMIM Port Icon Subviews Menu

Menu Selection

Port Notes

Port Configuration

Port Performance

Port Frame & Error

Breakdown

Description

Opens the Notes view described in the SPECTRUM Views.

Opens the Port Configuration view described in Chapter 3,

Configuration Views.


Views.

Opens the Port Frame & Error Breakdown view. For

description of fields in this view, see the Repeater Frame &

Error Breakdown View described earlier in this chapter.

Device Views

2-28

EMME/EMM-E6


Table 2-17.


TPXMIM

TPXMIM Port Icon Subviews Menu (Continued)

Menu Selection

Port Frame Size &

Protocols

Port Redundancy

Port Source Address

Port Security

Configuration

Enable/Disable

Change Port Channel

Description

Opens the Port Frame Size & Protocols view. For

description of fields in this view, see the Repeater Frame

Size & Protocols View described earlier in this chapter.

Opens the Repeater Redundancy view described in the




Guide.

Opens the Port Source Address view described in the




Guide.

Opens the Port Security Configuration view described in the SPECTRUM Portable Management Application

for the EMME User’s Guide or the SPECTRUM

Portable Management Application for the EMM-E6

User’s Guide.


Opens the Change Port Channel View described later in this

chapter.

Change Port Channel View

This view allows you to reassign the FNB channel used by a selected port to communicate within the MMAC FNB chassis. It also allows you to reconfigure a port to a stand-alone mode. To access this view do the following:

1.

Within the Chassis Device view, highlight the TPXMIM icon.

2.

From the Icon Subviews menu, select Change Port Channel.

When configured to operate on channels B or C, the TPXMIM provides its own repeating, when operating on channel A, TPXMIM ports depend on the

EMME/EMM-E6 for repeater functionality. All TPXMIM ports default to channel B when first installed. Change Port Channel view provides the following fields:

Module Number

Displays the slot number where the TPXMIM containing a selected port is located.


2-29


NOTE

Port Number

Displays the number of a selected port that will be affected by the configuration changes.

Port Connection

Allows you to chose the appropriate backplane channel from the pull-down menu. The pull-down menu includes the following selections: Channel A,

Channel B, and Channel C. Individual ports cannot be placed in stand-alone mode via this menu.

To place only selected ports in stand-alone mode, configure all other ports so that they are connected to Channel A: those ports will remain connected to

Channel A when stand-alone mode is implemented, and only those ports connected to channels B or C will be put in stand-alone mode.

Port Number

This label identifies the port location within the module. The background for this label is color coded to associate the port with its currently selected channel. Double-click this label to open the Notes view described in

SPECTRUM Views.

Port Status

This label describes the port activity status. Double-click this label to access the Port Configuration view described in Chapter 3, Configuration Views.

Port Statistics

Displays the number of frames (packets) transmitted or received by this port.

Double-click this label to access the Performance view described in

SPECTRUM Views.

Interface Device View

This section describes the Interface icons and the Interface Options panel displayed in the Interface Device view. The Interface Device view provides dynamic configuration and performance information for each interface on this device. If the configuration changes, SPECTRUM modifies the Device view after the next polling cycle to reflect the new configuration. This view also provides a Device icon which allows you to monitor device operation and to

access other device-specific views. Figure 2-6 provides an example of the

Interface Device View.

Device Views

2-30

EMME/EMM-E6



Figure 2-6.

EMME/EMM-E6 Interface Device View

EMM-E6 of type HubCSIEMME of Landscape golem: Primary

* File View

Model Name

Contact

Description

Location

Net Addr

Primary Application Bridging

System Up Time

Manufacturer

Device Type

Serial Number

Model Name

Filter Physical

Interface Description

EMM-E6

Device Icon

A ON

ETHERNET

0:0:1D:17:2F:3C

0

B OFF

ETHERNET

0:0:1D:17:2F:3C

0

C OFF

ETHERNET

0:0:1D:17:2F:3C

0

D ON

ETHERNET

0:0:1D:17:2F:3C

0

E OFF

ATM

0:0:1D:17:2F:3C

0

Interface Options Panel

Interface Icons

Help?


2-31


Interface Icons

Interface Icons

These interface icons represent the interfaces and ports of the device. The icons identify the type of interface or port and provide statistical information.

Figure 2-7 shows an example of an interface icon, its Icon Subviews menu,

and its labels/double-click zones.

NOTES

The callouts (a through f) in the illustration below identify the labels and the views to which they provide double-click access. Example: Administrative

Status Label/Port Configuration-BRIMIfATM view displays the interface status and provides double-click access to the Port Configuration-CSIIfPort view.

The menu displayed in the illustration is the icon subviews menu for that interface icon.

Figure 2-7.

(c)

(d)

(e)

(f)

Interface Icon

(a) (b)

A

0:0:1D:17:2F:3C

134.141.56.167

0

ON

ATM

Icon Subviews Menu:

Close

Navigate

Alarms

Performance

Notes...

Utilities

Configuration

Ctrl +c

Secondary Address Panel

Protocols

Model Information

(ATM only)

CtAtProtoApp

CtIpxRipApp

CtIpxSapApp

CtDecProtoApp

Configuration

Performance a. Interface Label b. Administrative Status Label/Port Configuration-BRIMIfATM View c. Interface Type Label d. MAC Address Label/CSI Interface Port Model Information View e. Network Address Label/Secondary Address Panel f.

Gauge Label/Performance - CSIIfPort View

Device Views

2-32

EMME/EMM-E6



Interface Icons

Interface Icon Subviews Menu

Table 2-18.

Table 2-18 describes each of the device-specific Icon Subviews menu selections

available from the Interface icon. See Chapter 1, Introduction, for information

on Accessing Device-Specific Subviews.

Interface Icon Subviews Menu

Menu Selection

Configuration

Secondary Address

Panel

Protocols

(ATM only)

Model Information

Description

Opens an Interface Configuration view for the specific interface type (e.g., Ethernet, FDDI) of the selected

Interface icon. These configuration views are described in

Chapter 3,Configuration Views.

Opens the Secondary Address Panel described later in this

chapter.

Allows you to access protocols submenu. The

ATMClientApp menu selection provides access to the ATM

Client Application Configuration View described in Chapter

3, Configuration Views and the Performance view described in SPECTRUM Views. For other menu selections refer to the Routing Services Management Module Guide as applicable.

Opens the Model Information view described in

SPECTRUM Views.

Interface Label

This label displays the name of the interface. Letters A, B, and C represent the

FNB/backplane channels. Letter D represents the front panel EPIM connection, and the letter E represents EMM-E6’s BRIM interface.

Administrative Status Label

This label displays the status of this interface. The default application for this

view is Bridging. Table 2-19 and Table 2-20 list all possible states and their

corresponding colors for Physical and Bridging Application. To select the application to be displayed (Physical, Bridging) click the Filter button in the

Interface Options Panel. See the Interface Options panel description later on in this chapter for more information on the Filter button.


2-33


Interface Icons

Table 2-19.

Administrative Status for the Physical or MIB II Application

Color

Green

Blue

Yellow

ON

OFF

TST


Port is operational.

Port is off.

Port is in the test mode.

Table 2-20.

Administrative Status for the Bridging Application

Color

Green

Blue

Magenta

Magenta

Orange

Red

Blue

FWD

DIS

LST

LRN

BLK

BRK


Bridge port is forwarding.

Port is disabled.

Bridge is in the listening mode.

Bridge is in the learning mode.

Bridge port is in the blocking mode.

Bridge port is broken.

The status is unknown.

Double-click this label to access the configuration view specific to the interface type of the Interface icon selected. See Chapter 3, Configuration Views, for the description of this view.

Interface Type Label

Table 2-21.

This label displays the type of EMME/EMM-E6 interface. Table 2-21 lists all

possible interface types.

Interface Types

Interface Type

Other

Reg1822

HDH1822

DDNX25 rfc877X25

Ethernet iso88023

Description

None of the following

Regular 1822

HDLC Distant Host protocol

Defense Data Network X.25

RFC877 X.25

Ethernet CSMA/CD

ISO CSMA/CD

Device Views

2-34

EMME/EMM-E6


Table 2-21.


Interface Icons

Interface Types (Continued)

Interface Type iso88024 iso88025 iso88026 starLan

Prot10MB

Prot80MB

HyChan

FDDI

LAPB

SDLC

T1

CEPT

BasicISDN

PrimISDN

PPSerial

PPP

SFTWARLPBK

CLNPoverIP

Enet3MB

XNSoverIP

SLIP

ULTRA

T-3

SMDS

FrameRelay

ATM

Description

ISO token bus

ISO token ring

ISO man

StarLAN IEEE 802.3

ProNET 10 Mbps

ProNET 80 Mbps

Hyperchannel

Fiber Distributed Data Interface

X.25 Line Access Procedure, Balanced

IBM Synchronous Data Link Control protocol

T1 link (USA and Japan)

T1 link (Europe)

Basic Integrated Services Digital Network

Proprietary Integrated Services Digital Network

Proprietary Point to Point Serial

Point to Point Protocol

Software Loopback

Connectionless Network Protocol over IP

Ethernet 3 Mbps

Xerox Network Service Protocol over IP

Generic Serial Line IP

ULTRA Technologies

T3 link

Switched Multimegabit Data Service

T1 Frame relay

Asynchronous Transfer Mode


2-35


MAC Address Label

This label displays the MAC address of the EMME/EMM-E6 interface.

Double-click this label to open the CSI Interface Port Model Information view described in SPECTRUM Views.

Network Address Label

This label displays the current IP address of the interface. To select a different

IP address for this interface, do the following:

1. Double-click the Network Address label to open the Secondary Address panel.

2. From the Address/Mask table, select the desired IP address entry to replace the correct IP address.

3. Click Update.

Secondary Address Panel

This panel allows you to view and change the current IP Address and Mask for this device. The Secondary Address Panel includes a table with different IP

Addresses and Masks. Information displayed in this table is obtained from the

Address Translation table within the device’s firmware. The Secondary

Address Panel provides the following fields and buttons:

IP Address

Displays the current IP address for this interface.

Update

This button allows you to save changes made to the current IP address of the interface.

See Network Address Label for instructions on how to change the current IP

address for the selected interface.

Gauge Label

This label displays the performance statistic determined by the Gauge Control

Panel for this interface. (Refer to the Gauge Control Panel later in this chapter for more information.) Double-click on this label to open the

Performance-CSIIfPort view described in SPECTRUM Views.

Device Views

2-36

EMME/EMM-E6



Interface Options Panel

Interface Options Panel

This area of the Interface Device view allows you to modify the presentation of a highlighted Logical Interface icon. Double-click a non-text area of this panel

to open the Gauge Control Panel, described later in this section. The Interface

Options panel provides the following information:

Filter

This menu button allows you to select the application to be displayed by the interface icons. You can leave the application currently running or you can select other applications such as IP routing if the SPECTRUM Routing

Services Management Module is loaded. For more information, refer to the

Routing Services Management Module Guide.

Interface Description

This field provides a description of the highlighted interface. If no interface is highlighted, this field is empty.

Gauge Control Panel

This panel (Figure 2-8) allows you to change the type of statistical information

displayed on the Gauge label of the Interface icon. To access the Gauge

Control Panel, either double-click the background of the Interface Options panel, or do the following:

1.

Within the Interface Device view, highlight the Interface Options panel.

2.

From the Icon Subviews menu, select Gauge Control Panel.

or

1.

Within the Chassis Device view, highlight the EMME/EMM-E6 module icon.

2.

From the Icon Subviews Menu, select Gauge Control Panel.


2-37


Gauge Control Panel

Figure 2-8.


Gauge Mode

Rates

Totals

Percentages

Gauge Type

Numeric

Linear


Selected Attribute

Load

Load In

Load Out

Packet Rate

In Packet Rate

Out Packet Rate

% Discard

% Filtered

Apply

Reset

Default

Keep Settings

Close

Gauge

Buttons

The Gauge Control Panel provides the following:

• Gauge Mode

• Selected Attribute

• Gauge Type

• Gauge Buttons

Gauge Mode

This area allows you to select the type of information shown on the Gauge

Label of the interface icon: Rates, Totals, or Percentages. The Percentages selection displays the percentage of the selected interface compared to the rest of the interfaces.

The color displayed on the Gauge Label depends on the particular mode and

statistical attribute selected. Table 2-22 and Table 2-23 provide a list of

attributes and their corresponding colors for the Totals mode and Rates mode respectively.

Device Views

2-38

EMME/EMM-E6


Table 2-22.

Table 2-23.


Gauge Control Panel

Rates Gauge Mode: Attributes and Corresponding Colors

Selected Attribute Color

Load

Load In

Load Out

Packet Rate

In Packet Rate

Out Packet Rate

% Discard

% Filtered

% Forwarded

% Host Bound

% Error

% Transmitted

Green

Green

Green

Blue

Blue

Blue

Tan

Gray

Violet

Yellow

Orange

White

Totals Gauge Mode: Attributes and Corresponding Colors

Selected

Attribute

Errors

In Packets

Out Packets

In Octets

Out Octets

Discards

Forwarded

Host Bound

Transmitted

Filtered

Color

Orange

Blue

Blue

Green

Green

Tan

Purple

Yellow

White

Gray

Selected Attribute

This area allows you to select the statistical attribute displayed on the

Interface icon’s Gauge label. The label changes color to reflect the attribute selected.


2-39


Gauge Type

This area allows you to select either a numeric or linear display on the Gauge label.

Gauge Buttons

The following describes the Gauge buttons:

Apply

Applies the current settings to the Gauge label temporarily, but does not save the settings.

Reset

Returns the settings to the previously saved values.

Keep Settings

Saves the current settings while SpectroGRAPH is running. Settings return to the default while you restart SpectroGRAPH.

Close

Closes the Gauge Control Panel.

Default

Returns the settings to the SPECTRUM default.

Device Views

2-40

EMME/EMM-E6



Physical Device View

This view shows a static image of all slots in the MMAC FNB Chassis and

devices placed in them, including EMME/EMM-E6. Figure 2-9 shows an

example of the Physical Device view.

Figure 2-9.

Physical Device View

EMME of type HubCSIEMME of Landscape castle: Primary

* File View Options

Net Addr Model Name

Contact

Description

Location

Primary App.

Sys Up Time

Manufacturer

Device Type

Serial Number

Help?

TPXMIM-20

A B C

ETHERNET

SN

7

8

9

CLN

RCV LNK

6

10

RCV LNK

1

2

3

4

5

RCV LNK

TX

7

RX

RCV LNK

E

P

I

M

TX

RX

8

RCV LNK

B C

CL

RCV LNK

1

RCV LNK

2

RCV LNK

TX

2

X

3

X

4

X

RX

9 3

RCV LNK RCV LNK

SN

5

X

6

X

7

X

8

X

9

X

10

X

TX

10

RX

RCV LNK

4

RCV LNK

TX

11

RX

RCV LNK

5

RCV LNK

TX

RX

12 6

10 BASE - T

ETHERNET

FDIAL/10BASE - FF

ETHERNET

TPRMIM-36

SN

ETHERNET

B C

EMME

SN

RESET

CLN

14

AUI POK

21

22

23

24

25

26

15

16

17

18

19

20

8

9

6

7

4

5

2

3

10

11

12

13

CLN

1

AUI POK

DK

SA

SB

RA

RB

RC

RD

DM FM

ER

SC

SD

CA

CB

CC

CD

DM FM

26 13

15

10 BASE - T

ETHERNET

2

O

L

E

C

O

N

S

M

O

D

E

M

ETHERNET


2-41


Device Views

2-42

EMME/EMM-E6


Configuration Views

Chapter 3


This chapter provides descriptions of the configuration views available for the

EMME/EMM-E6 and the modules it manages. These views allow you to access device-specific configuration information.

The following Configuration views are available for the EMME/EMM-E6 and for the other modules managed by this device:

• EMME/EMM-E6 Device Configuration View

• Chassis Configuration View (EMME only)

• Module and Port Configuration Views

• Repeater Configuration View

• CSI Isolated Repeater Configuration View

• Interface Configuration Views

- Port Configuration - CSIIfPort View

- Port Configuration - BRIMIfEnet

- BRIM - FD Interface Configuration View

- Port Configuration - BRIMIfATM View

• Port Configuration View (for FDDI)

• SMT Device Configuration View

• ATM Client Application Configuration View

Refer to Chapter 1, Introduction, for information on Accessing SPECTRUM

Views from the Device Icon and Accessing Device-Specific Subviews.

9031111 E7

3-1

EMME/EMM-E6 Device Configuration View

EMME/EMM-E6 Device Configuration View

The EMME/EMM-E6 Device Configuration view provides information on the configuration and operating status of the EMME/EMM-E6. In addition, it allows you to change the network connection of the MIMs. The Device

Configuration view provides the following information:

Contact Status

Indicates whether a connection with the device has been established. Possible status messages displayed in this field include: Established, Lost and Initial.

Firmware Revision

Displays the firmware revision for this device (e.g., 3.11.02).

Hardware Revision

Displays the hardware revision for this device.

This view also provides the following buttons, which allow you to configure this device:

Component Table

Opens the Community Name view. This is an SPMA view and is described in the SPECTRUM Portable Management Application Tools Guide.

DownLoad Application

Opens the TFTP Download view. This is an SPMA view and is described in the

SPECTRUM Portable Management Application Tools Guide.

Trap Table

Opens the Trap Table view. This is an SPMA view and is described in the

SPECTRUM Portable Management Application Tools Guide.

Front Panel Redundancy

Opens the Front Panel Redundancy view. This is an SPMA view and is described in the SPECTRUM Portable Management Application for the

EMME User’s Guide or the SPECTRUM Portable Management

Application for the EMM-E6 User’s Guide.

Date/Time

Opens the Device Date/Time view which provides the following fields:

Date: (MM/DD/YY)

Allows you to set up and update the date taken from the device’s internal clock. The date is displayed in the following format: MMDDYY.


3-2

EMME/EMM-E6


Chassis Configuration View (EMME only)

Interface Configuration Table

Time: (HH:MM:SS)

Allows you to set up and update the time taken from the device’s internal clock. The time is displayed in the following format: HHMMSS.

Interface Configuration Table

This table within the EMME/EMM-E6 Device Configuration view provides the following configuration information for the device and each interface or port:

Number of Interfaces

Displays the number of interfaces or ports available from this device.

Index

Displays the number for a given interface or port.

Type

Displays the type of hardware interface for the port. See Table 2-21 for a full

list of possible interface types.

Phy Address

Displays the physical (MAC) address of the port.

Max Frame Size

Displays the maximum frame size for the EMME/EMM-E6 interfaces.

Oper Status

Displays the current operational state of this port (Up, Down, or Testing).

Chassis Configuration View (EMME only)

This view allows you to view and modify the configuration information for the chassis.

To access the Chassis Configuration view do the following:

1.

Within the Chassis Device view, highlight the module icon.

2.

From the Icon Subviews menu, select Chassis Configuration.

This view provides the following information and fields:

Chassis Type

Displays the chassis type. This field can be updated.

Hardware Rev

Displays the revision number of the hardware running on this device.

9031111 E7 Configuration Views

3-3

Module and Port Configuration Views

Time

Allows you to view and update the time taken from the device’s internal clock.

The time is displayed in the following format: HHMMSS.

Date

Allows you to set up and update the time taken from the device’s internal clock. The date is displayed in the following format: MMDDYY.

Chassis Alarm

This menu button allows you to enable or disable chassis alarm. Possible menu selections are: Enable and Disable.

Alarm Condition

This menu button allows you to configure the condition of the alarm. This field can be updated.

Sounding Alarm

This button allows you to reset the sounding alarm.

Module and Port Configuration Views

Both Module Configuration view and Port Configuration view provide information on the configuration and operating status of other modules (in addition to EMME/EMM-E6) installed in the MMAC FNB chassis and on selected individual ports on those modules.

To access the Module Configuration view do the following:

1.

Within the Chassis Device view, highlight the module icon.

2.

From the Icon Subviews menu, select Module Configuration (for

TPXMIM: Module Segment Details > Network X > Module

Configuration)

To access the Port Configuration view do the following:

1.

Within the Chassis Device view highlight the port icon.

2.

From the Icon Subviews menu select Port Configuration.

The Configuration views are divided into four sections:

• Module Management / Port Management

• Trap configuration

• Alarm Configuration

• Error Source

Module Management and Port Management are the only sections that include fields exclusive to the Module Configuration view and the Port Configuration view, therefore they are described separately.


3-4

EMME/EMM-E6



Module Management (Module Configuration View Only)

Module Management (Module Configuration View Only)

This area of the Module Configuration view provides the following information for the selected module:

Port Count

Displays the total number of ports on this module.

Ports On

Displays the total number of ports currently in the ON state on this module.

Ports Operational

Displays the number of operational ports on this module.

Module Ports

This menu button allows you to enable or disable all the ports on this module.

Possible states are: Enable and Disable. You can also enable or disable individual ports by selecting Enable/Disable Port from the port’s Icon

Subviews menu.

Port Management (Port Configuration View Only)

This area of the Port Configuration view provides the following information for the selected port:

Port ID

Displays the number of the port identifying its location within the module.

Administrative Status

This menu button allows you to select the desired operational state of the port.

Possible selections are: Enable and Disable.

Operational Status

Displays the current operational state of the port. Possible states are:

Not-Operational and Operational.

Segmentation Status

Displays the current segmentation state of the port. Possible states are:

Not-Segmented and Segmented.

Link Status

Displays the current link state of the port. Possible states are: Not-Linked,

Linked, and Not-Applicable.

Topological State

Displays the current port topological state. Possible states are: Station and

Trunk.

Set Topological State

This menu button allows you to select the desired topological state for the port. Possible selections are: Not_Forced or Forced_Trunk.


3-5


Trap Configuration

Trap Configuration

This area of the Module or Port Configuration view allows you to enable or disable any of the following types of traps:

Link Traps

This menu button, when enabled, allows all packets indicating a change in link status to be reported within the trap database. Possible menu selections are: Disable, Enable, and other.

Segmentation Traps

This menu button, when enabled, allows all packets indicating a change in segmentation status to be reported within the trap database. Possible menu selections are: Disable, Enable, and other.

Source Address Traps

This button, when enabled, allows all packets indicating a change in source address to be reported within the trap database. Possible menu selections are:

Disable, Enable, and other.

Alarm Configuration

This area of the Module or Port Configuration view provides configuration and status information for generation of alarms by the selected module. The Alarm

Configuration section provides the following information:

Timebase (Port Configuration view only)

Displays the time interval within which the specified number of errors needs to occur before the alarm is generated. This number can only be altered in the

Repeater Configuration view described later in this chapter.

Traffic Alarms

This menu button allows you to enable or disable detection of Traffic Alarms.

Possible menu selections are: Disable and Enable.

Traffic Threshold

Displays the threshold value within the alarm timebase which, once that number of packets is exceeded, generates a traffic alarm. You can alter this name. Allowable values are 1 to ~4 billion.

Traffic Alarm Condition

This menu button allows you to disable the module or port if the traffic alarm threshold is exceeded and an alarm for the module is generated. This feature allows you to prevent excessive network traffic generated by alarm messages that are transmitted by the module. It also aids in module troubleshooting.

Possible menu selections are: Don’t_Disable_Port and Dissable_Port.

Collision Alarms

This menu button allows you to Enable or Disable detection of Collision

Alarms. Possible menu selections are: Disable and Enable.


3-6

EMME/EMM-E6


9031111 E7


Alarm Configuration

Collision Threshold

Displays the threshold value within the alarm timebase which, once that number of collisions per good packet is exceeded, generates a collision alarm.

You can alter this number. Allowable values are: 1 to 15 collisions per good packet.

Collision Alarm Condition

This menu button allows you to disable the module or port if the collision alarm threshold is exceeded and an alarm for the module is generated. This feature allows you to prevent excessive network traffic generated by alarm messages that are transmitted by the module. It also aids in module troubleshooting. Possible menu selections are: Don’t_Disable_Port and

Dissable_Port.

Broadcast Alarms

This menu button allows you to Enable or Disable detection of Broadcast

Alarms. Possible menu selections are: Disable and Enable.

Broadcast Threshold

Displays the threshold value within the alarm timebase which, once that number of broadcasts received is exceeded, generates a broadcast alarm.

Allowable values are 1 to ~4 billion.

Broadcast Alarm Condition

This menu button allows you to disable the module or port if the broadcast alarm threshold is exceeded and an alarm for the module is generated. This feature allows you to prevent excessive network traffic generated by alarm messages that are transmitted by the module. It also aids in module troubleshooting. Possible menu selections are: Don’t_Disable_Port and

Dissable_Port.

Error Alarms

This menu button allows you to Enable or Disable detection of Error Alarms.

Possible menu selections are: Disable and Enable.

Error Threshold

Displays the threshold value within the alarm timebase which, once the percentage of errors per good packet is exceeded, generates an error alarm.

Allowable values are 1 to 100.

Error Alarm Condition

This menu button allows you to disable the module or port if the error alarm threshold is exceeded and an alarm for the module is generated. This feature allows you to prevent excessive network traffic generated by alarm messages that are transmitted by the module. It also aids in module troubleshooting.

Possible menu selections are: Don’t_Disable_Port and Dissable_Port.


3-7


Error Source

Error Source

This area of the Module or Port Configuration view provides a series of buttons allowing you to select error types to include in the error sum. The selectable error types are as follows:

CRC

Describes the number of packets received by the module with bad Cyclical

Redundancy Checks (CRCs).

Runts

Describes the number of runt packets received by the module. A runt packet is one byte less than the standard Ethernet frame of 64 bytes (not including preamble).

OOW_Colls

Describes the number of collisions out of the standard window (51.2

µ s) due to a network problem.

Alignment

Describes the number of misaligned packets detected by the module.

No_Resource

Describes the number of times the module ran out of resources (i.e., lack of buffer space) and could not accept packets.

Giants

Describes the number of giant packets received by the module. A giant packet exceeds 1518 bytes (not including preamble).

Repeater Configuration View

The Repeater Configuration view provides information on the configuration and operating status of the repeater.

To access the Repeater Configuration view do the following:

1.

Within the Chassis Device view, highlight the Repeater Port label on the

EMME/EMM-E6 module icon.

2.

From the Icon Subviews menu, select Repeater Configuration.

or

1.

Within the DevTop or Application view for the EMME/EMM-E6, highlight the CSIRptr Icon.

2.

From the Icon Subviews menu, select Configuration.


3-8

EMME/EMM-E6



Repeater Management

Repeater Management

This area of the Repeater Configuration view provides the following port information:

Port Count

Displays the total number of ports on this LAN segment.

Ports On

Displays the total number of ports currently in the ON state on this network.

Ports Operational

Displays the number of operational ports on this network.

Network Ports

This menu button allows you to enable the network ports on this network segment. Possible states are: NoEnable and Enable.

Network Port Security

This menu button allows you to lock or unlock repeater ports. Possible states are: Locked and Unlocked.

Source Address Management

This section of the Repeater Configuration view allows you to configure the

Aging time.

Aging Interval

Displays the minimum time, in seconds, that an inactive source address will remain in the database before being selected for removal. The source address timer runs continuously beginning at the time the device is turned on; source addresses that are added to the database during one timer cycle will remain in the database for the rest of the current cycle and at least through the next complete cycle. If no packets have been received from that address during one complete cycle, the address will be removed. Aging Interval is user-configurable. Allowable range is 0 to 4320 (three days).


3-9


Trap Configuration

Trap Configuration

This area of the Repeater Configuration view allows you to enable or disable any of the following types of traps:

Link Traps

This menu button, when enabled, allows all packets indicating a change in link status to be reported within the trap database. Possible menu selections are: Disable, Enable, and other.

Segmentation Traps

This menu button, when enabled, allows all packets indicating a change in segmentation status to be reported within the trap database. Possible menu selections are: Disable, Enable, and other.

Source Address Traps

This menu button, when enabled, allows all packets indicating a change in source address to be reported within the trap database. Possible menu selections are: Disable, Enable, and other.

Alarm Configuration

This area of the Repeater Configuration view provides configuration information on generating alarms for the selected module. This section contains the following fields:

Timebase

Displays the time interval, in seconds, within which the specified number of errors needs to occur before the alarm is generated. This time interval is user-configurable. The lowest allowable value is 10.

Traffic Alarms

This menu button allows you to enable or disable detection of Traffic Alarms.

Possible menu selections are: Enable and Disable.

Traffic Threshold

Displays the threshold value within the alarm timebase which, once that number of packets is exceeded, generates a traffic alarm. This field is user-configurable. The allowable range is 1 to ~4 billion.

Collision Alarms

This menu button allows you to enable or disable detection of Collision

Alarms. Possible menu selections are Enable and Disable.

Collision Threshold

Displays the threshold value within the alarm timebase which, once that number of collisions per good packet is exceeded, generates a collision alarm.

This value is user-configurable. Allowable range is 1 to 15 collisions per good packet.


3-10

EMME/EMM-E6



Error Source

Broadcast Alarms

This menu button allows you to Enable or Disable detection of Broadcast

Alarms.

Broadcast Threshold

Displays the threshold value within the alarm timebase which, once that number of broadcasts received is exceeded, generates a broadcast alarm. This value is user-configurable. Allowable range is 1 to ~4 billion.

Error Alarms

This menu button allows you to enable or disable detection of Error Alarms.

Possible menu selections are: Enable and Disable.

Error Threshold

Displays the threshold value within the alarm timebase which, once the percentage of errors per good packet is exceeded, generates an error alarm.

This value is user-configurable. Allowable range is 1 to 100.

Error Source

This area of the Repeater Configuration view provides a series of buttons allowing you to select the types of errors to include in the error sum. The selectable error types are as follows:

CRC

Describes the number of packets received by the module with bad CRC

(Cyclical Redundancy Checks).

Runts

Describes the number of runt packets received by the module. A runt packet is one byte less than the standard Ethernet frame of 64 bytes (not including preamble).

OOW_Colls

Describes the number of collisions out of the standard window (51.2

µ s) due to a network problem.

Alignment

Describes the number of misaligned packets detected by the module.

No_Resource

Describes the number of times the module ran out of resources (i.e., lack of buffer space) and could not accept packets.

Giants

Describes the number of giant packets received by the module. A giant packet exceeds 1518 bytes (not including preamble).


3-11

CSI Isolated Repeater Configuration View

Board Map

Board Map

This area of the Repeater Configuration view provides a series of read-only indicator buttons displaying which slots in the MMAC FNB chassis this repeater resides in.

Manages

This area of the Repeater Configuration view displays the model name of the device managing this repeater. This section also allows you to access the

Device Configuration view by double-clicking on the model name of the managing device, or highlighting it and clicking OK.

CSI Isolated Repeater Configuration View

This view provides information on the configuration and operating status of the network segment that the isolated repeater is monitoring.

To access the CSI Isolated Repeater Configuration view do the following:

1.

Within the Application view, highlight the CSIIsoRptr icon.

2.


In addition to the Model Name and the Network Address, the CSI Isolated

Repeater Configuration view provides the following information:

Repeater Management

This section of the CSI Isolated Repeater Configuration view displays the Port

Group Management table, which provides the following information:

Mgmt. Name

Displays the slot number where this repeater is located in the chassis.

Group ID

Identifies a repeater in a system where a single agent manages multiple repeaters.

Port Count

Displays the total number of ports on this LAN segment.

Ports Enab

Displays the number of ports enabled.


3-12

EMME/EMM-E6


Interface Configuration Views (EMM-E6 only)

Manages

Ports On

Displays the total number of ports in the ON state on this network.

Ports Oper

Displays the number of operational ports on this network.

Manages

This section of the CSI Isolated Repeater Configuration view displays the model name of the device managing this repeater. This section also allows you to access the Device Configuration view by double-clicking on the model name, or highlighting the address and clicking OK.

Interface Configuration Views (EMM-E6 only)

Table 3-1.

These views provide information on the configuration and operating status of the interfaces provided by the device and the attached EPIMs and BRIMs .

Table 3-1 lists the configuration views for the specific types of interfaces.

Interface Configuration Views

Interface Configuration View

Ethernet (Channels A,

B, C, and D)

Ethernet (BRIM)

FDDI

ATM

Port Configuration - BRIMIfEnet View

Port Configuration - CSIIfPort View

BRIM - FD Interface Configuration View

Port Configuration - BRIMIfATM View

To access these views do the following:

1.

Within the Interface Device view, highlight the BRIM’s interface icon.

2.

From the Icon Subviews menu, select Configuration.

All the interface configuration views display the following information and fields:

Interface Index

Displays the numerical value identifying the interface or port.

Interface Type

Displays the type of interface (e.g., FDDI, ATM).


3-13


Operation Status

Displays the current operating status of the interface or port. Possible values are: On, Off, or Test.

Admin Status

This menu button allows you to enable or disable the current administrative state of the port. Possible values are: On (enabled), Off (disabled), or Test.

IF Description

Provides a description of the interface or port (e.g., Ctron FDDI Port Channel

E).

Port Configuration View (for FDDI)

This view provides information concerning the configuration and management of the port located on the front panel of the FDDI BRIM. To access the Port

Configuration view, do the following:

1.

Within the Chassis Device view, highlight the FDDI port label.

2.

From the Icon Subviews menu, select Port Configuration View.

NOTE

The FDDI Port Configuration view is only accessible for the EMM-E6 with a

FDDI BRIM attached to it.

The Port Configuration view provides the following information concerning the port management:

Port Action

Provides a menu button that allows you to enable/disable the port. Possible menu selections are: Other, Enable_Port, and Disable_Port. The state returns to Other once the port is Enabled/Disabled.

Port State

Displays the status of this port. Possible states are: Disabled, Connecting,

Standby, or Active.

Port Type

Displays the type of port. Possible port types are: A_Port or B_Port, Slave or

Master.


3-14

EMME/EMM-E6



Link Error Rate Estimate

Displays a cumulative long-term average of the bit error rate, which represents the quality of the physical link. The link error rate estimate is computed when the port is connected and every 10 seconds thereafter. It ranges from 10 -4 to 10 -15 and is reported as a whole integer. For example, if the port’s link error rate estimate is computed to be 10 -5 , the value reported in this field would be 5, which represents an actual rate of 1,250 bit errors per second. A lower link error rate estimate indicates a higher bit error rate, as

shown in Figure 3-1.

Figure 3-1.

Link Error Rate Estimate

Bit Errors per Second

.

000000125

.00000125

.0000125

.000125

.00125

.0125

.125

1.25

12.5

125

1250

12500

4 5 6 7 8 9 10 11 12 13 14 15

Reported Link Error Rate Estimate (n)

Link Error Monitor Count

Displays the aggregate link error monitor count. This count is set to zero on station power up and increments each time the port’s link error monitor detects an error. An increasing link error monitor count usually indicates a problem with the connectors or the cable between this port and the node.

Link Error Rate Cutoff

Displays the link error rate threshold at which a link connection is flagged as faulty and the port disabled by SMT. The default link error rate cutoff threshold is 7, which represents 12.5 bit errors per second (refer to

Figure 3-1).

Link Error Rate Alarm

Displays the link error rate threshold that, if exceeded, generates an alarm for the port. The default link error rate alarm threshold is 8, which represents

1.25 bit errors per second (refer to Figure 3-1).

Link Error Monitor Reject Count

Displays the link error monitor count of the times the link has been rejected.


3-15


SMT Device Configuration View

This view provides information on the configuration and operating status of the FDDI Station and FDDI SMT.

To access this view do the following:

1.

Within the Device Topology (Dev Top) or Application view, highlight the

FddiSMT Application icon.

2.

From the Icon Subviews menu, select Configuration or

1.

Within the Chassis Device view, highlight the FDDI BRIM label.

2.

From the Icon Subviews menu, select FDDI Configuration.

The SMT Device Configuration view is divided into two tables: Station

Configuration and SMT Information described below.

NOTE

The SMT Device Configuration view is only accessible for the EMM-E6 with a

FDDI BRIM attached to it.

Station Configuration View

Table 3-2.

This section of the SMT Device Configuration view provides the following configuration information on the FDDI station:

Ring State

Indicates the current state of the FDDI Ring. Table 3-2 provides the possible

states and their descriptions.

FDDI Ring States

Ring

States

Isolated

Non-Op

Ring-Op

Detect

Description

The concentrator is not attached to the ring.

The concentrator is attempting to enter the ring.

The ring is operational.

The claim/beacon process of the FDDI ring protocol has exceeded 1 second. This indicates a potential problem.


3-16

EMME/EMM-E6


Table 3-2.

Table 3-3.


Station Configuration View

FDDI Ring States (Continued)

Non-Op-Dup The ring failed to complete the claim/beacon process because a duplicate FDDI address has been detected.

Ring-Op-Dup The ring is operational but a duplicate FDDI address has been detected.

MAC Configuration

Displays the actual configuration of the station. Table 3-3 shows all possible

configurations and their descriptions.

SMT MAC Configurations

Ring

States

Description

Isolated

Local_A

Local_B

Local_AB

The port is not inserted into any path.

The A port is inserted into a local path and the B port is not.

The B port is inserted into a local path and the A port is not.

Both A and B are inserted into a local path.

Local_S

Wrap_A

The S port is inserted into a local path.

The secondary path is wrapped to the A port.

Wrap_B

Wrap_AB

The secondary path is wrapped to the B port.

The primary path is wrapped to the B port and the secondary path is wrapped to the A port.

The primary port is wrapped to the S port.

Wrap_S

C_Wrap_A The primary and secondary paths are joined internally in the station and wrapped to the A port. Regarding the token flow, all of the resources on the secondary path precede those of the primary path.

C_Wrap_B The primary and secondary paths are joined internally in the station and wrapped to the B port. Regarding the token flow, all of the resources on the secondary path precede those of the primary path.

C_Wrap_S The primary and secondary paths are joined internally in the station and wrapped to the S port. Regarding the token flow, all of the resources on the secondary path precede those of the primary path.

Thru The primary path enters the A port and emerges from the B port. The secondary path enters the B port and emerges from the A port.

MAC Path

Displays the current path into which this MAC is inserted. Possible paths are:

Isolated, Local, Secondary, Primary, Concatenated, and Thru.


3-17


SMT Information

MAC Address

Displays the MAC (physical) address of this station.

MAC Count

Displays the number of MACs supported by this station.

Non Master Ports

Displays the number of non-master ports on this station.

Master Ports

Displays the number of master ports on this station.

SMT Information

This section of the SMT Device Configuration view provides the following configuration information on the FDDI Station Management (SMT):

SMT Version

Displays the version of SMT running on this FDDI BRIM.

OBS Present

Indicates whether an Optical Bypass Switch (OBS) connects to this FDDI

BRIM.

T-Notify (sec)

Allows you to view and alter the timer value, in seconds, used in Neighbor

Notification Protocol. The allowed range is 2-30 seconds.

T-Req (milli sec)

Displays the Target Token Rotation Time (TTRT) bid, in milliseconds, made by this FDDI BRIM.

T-Neg (milli sec)

Displays the winning TTRT bid, in milliseconds, on the ring.

TVX (milli sec)

Displays the valid transmission time, in milliseconds.


3-18

EMME/EMM-E6


ATM Client Application Configuration View

ATM Client Application Configuration View

This view provides configuration information on the ATM Client Application.

To access the ATM Client Configuration view do the following:

1.

Within the Chassis Device view, highlight the ATM BRIM label.

2.


or

1.

Within the Interface Device view, highlight the ATM Interface.

2.

From the Icon Subviews menu, select Protocols -> ATMClientApp ->

Configuration.

NOTE

The ATM Client Application Configuration view is only accessible for the

EMM-E6 with an ATM BRIM attached to it.

9031111 E7

The Configuration view includes the Configuration table which provides the following information:

Max VPCs

Indicates the maximum number of VPCs (Virtual Path Connections) supported at this ATM interface. At the User Network Interface (UNI), the maximum number of VPCs ranges from 0 to 256.

Max VCCs

Indicates the maximum number of VCCs (Virtual Channel Connections) supported at this ATM interface.

Conf VPCs

Indicates the number of VPCs configured for use at this ATM interface. At the

User Network Interface (UNI), the configured number of VPCs ranges from 0 to 256.

Conf VCCs

Indicates the number of VCCs configured for use at this ATM interface.

Max VPI Bits

Indicates the maximum number of active VPI (Virtual Path Identifier) bits configured for use at this ATM interface. At the UNI (User Network

Interface), the maximum number of active VPI bits configured for use ranges from 0 to 8.

Max VCI Bits

Indicates the maximum number of active VCI (Virtual Channel Identifier) bits configured for use at this ATM interface.


3-19


ILMI VPI

Indicates the VPI (Interim Local Management Interface) value of the VCC supporting the ILMI at this ATM interface. If the values of both ILMI VPI and

ILMI VCI equal 0, then the ILMI is not supported for this ATM interface.

ILMI VCI

Indicates the VCI value of the VCC supporting the ILMI at this ATM interface. If the values of both ILMI VPI and ILMI VCI equal 0, then the ILMI is not supported for this ATM interface.

Address Type

Indicates the type of primary ATM address configured for use at this ATM interface.

Admin Address

Indicates the address assigned for administrative purposes. If this interface has no assigned administrative address or if the address used for administrative purposes is the same as that used for the physical address, then this is an octet string of zero length.

Neighbor Address

Indicates the IP address of the neighbor system connected to the far end of this interface to which a Network Management Station can send SNMP messages as IP datagrams to UDP port 161 in order to access network management information concerning the operation of that system.

Neighbor If Name

Indicates the name of the interface on the neighbor system at the far end of this interface, and to which this interface connects. If the neighbor system is manageable through SNMP and supports the object ifName, the value of this object must be identical to that of the ifName for the ifEntry of the lowest level physical interface for this port. If this interface does not have a name, the value of this object is a zero length string.

The ATM Client Application Configuration view Configuration table can be sorted, searched, and updated using the following buttons located within this table:

Sort

This button allows you to sort the table based on the column heading you select. To use the Sort feature, select a column heading and click the Sort button. The table is rearranged according to the chosen column.

Find

This button allows you to search the table for a specific entry. To use the Find feature, select a column heading, click the Find button, and enter a search string in the dialog box.


3-20

EMME/EMM-E6



Update

This button allows you to update information in the table.


3-21



3-22

EMME/EMM-E6


Chapter 4

Event and Alarm Messages


This chapter lists the types of events and alarms generated by the

EMME/EMM-E6 and provides any probable cause messages corresponding to these alarms.

Device Events and Alarms

Table 4-1.

Table 4-1 lists the SPECTRUM database directory paths (in bold) and the

messages displayed for the Event Log and Alarm Manager when applicable.

EMME/EMM-E6 Events and Alarms

Message in the Event Log

CsEvFormat/Event00010203

{d “%w- %d %m-, %Y - %T”} - The model created is not the same type as the device. Model type = {t},

Name = {m}, User = {u}. (event [{e}])


{d “%w- %d %m-, %Y - %T”} - Device

{m} of type {t} has been contacted.

(event [{e}])

Alarm View Probable Cause

Message

CsPCause/Prob00010203

The model created is not the same type as the device.

No Probable Cause Message

9031111 E7

4-1

Device Events and Alarms

Table 4-1.

EMME/EMM-E6 Events and Alarms (Continued)

Message in the Event Log Alarm View Probable Cause

Message


{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has been cold started. (event [{e}])


{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m} has been warm started. (event [{e}])


{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has detected a communication Link Down. (event

[{e}])


{d “%w- %d %m-, %Y - %T”} - A(n)

{t} device, named {m}, has detected a communication Link Up. (event

[{e}])

CsEvFormat/Event0001030a

{d “%w- %d %m-, %Y - %T”} - A(n) {t} device, named {m}, has detected an

Authentication Failure. (event [{e}])

CsEvFormat/Event0001030b

{d “%w- %d %m-, %Y - %T”} -

A(n) {t} device, named {m}, has detected an EGP Neighbor Loss.

EGP Neighbor IP address is {0 1}.

(event [{e}])


{d “%w- %d %m-, %Y - %T”} - Device

{m} of type {t} is created with an IP address already used by another model. (event [{e}])




Communication link is down.


CsPCause/Prob0001030a

Authorization failure. Other user is trying to connect to device with an invalid community string.

CsPCause/Prob0001030b

Lost contact with EGP neighbor.


DUPLICATE IP ADDRESS

The model has the same IP address as that of some other model.


4-2

EMME/EMM-E6


Table 4-1.





{d “%w- %d %m-, %Y - %T”} - Device

{m} of type {t} is created with a physical (Mac) address already used by another model. (event [{e}])


{d “%w- %d %m-, %Y - %T”} - Alarm number {I 0x700} cleared for device

{m} of type {t}. (event [{e}])

CsEvFormat/Event000d0001

{d “%w- %d %m-, %Y - %T”} - Bridge

{m} of type (t) has reported a root change. (event [{e}])


{d “%w- %d %m-, %Y - %T”} - Bridge

{m} of type (t) has reported a network topology change. (event

[{e}])


{d “%w- %d %m-, %Y - %T”} - Port {I

3} on module in slot {I 1} of {m} ({t}), has segmented.


{d “%w- %d %m-, %Y - %T”} - Port {I

3} on module in slot {I 1} of {m} ({t}), has unsegmented.


Message


DUPLICATE PHYSICAL ADDRESS

The model has the same Physical address (Mac address) as that of some other model.


CsPCause/Prob000d0001

This bridge has become the new root of the Spanning Tree.


A port has transitioned from the

Learning state to the Forwarding state, or from the Forwarding state to the

Blocking state.


The port has made 32 consecutive attempts to transmit which resulted in a collision each time or the port collision detector was turned on for longer than

2.4 milliseconds. Each of these collision occurrences are caused by a cabling problem of extremely high rates of traffic on the segment the port is attached to.


The port has transmitted or received a valid packet. This can occur when a cabling or termination fault has been corrected. Unsegmenting can also occur on a port that previously was not in use.

9031111 E7 Event and Alarm Messages

4-3


Table 4-1.




{d “%w- %d %m-, %Y - %T”} -

Network configuration change reported by {m} ({t}). Device is linked to port {I 3} on module in slot

{I 1}.


{d “%w- %d %m-, %Y - %T”} -

Network configuration change reported by {m} ({t}). Device previously linked to port {I 3} on module in slot {I 1} has ceased to transmit link integrity pulse.


{d “%w- %d %m-, %Y - %T”} - New source address {X 5}, is detected on

{m} ({t}), port {I 3} of module in slot

{I 1}.


Message


A device supporting link integrity, fiber optic, or twisted pair has made a valid connection (link) to this port.


A device previously linked to this port has been removed, powered down, or the cable segment has a fault.


{d “%w- %d %m-, %Y - %T”} - Source address {X 5}, has timed out on port

{I 3} of the module in slot {I 1} of {m}

({t}).


{d “%w- %d %m-, %Y - %T”} - Device configuration change reported by

{m} ({t}). The module in slot {I 1} has been removed.


{d “%w- %d %m-, %Y - %T”} - Device configuration change reported by

{m} ({t}). A module has been inserted into {I 1} of the MMAC.


A device, previously linked or not, has transmitted a packet that was received on this port. The device is either new or has been powered up but has not transmitted a packet during the aging time period.


A device linked or not linked to this port has not transmitted a packet during the aging time period, and has been removed from the source address table of the device.


A module within this hub has been removed or has failed.


A module has been inserted into this hub.


4-4

EMME/EMM-E6


Table 4-1.





{d “%w- %d %m-, %Y - %T”} -

Network configuration change reported by {m} ({t}). Port {I 3} in slot {I 1} has failed redundancy polling and has switched to a backup port.

CsEvFormat/Event000d010a

{d “%w- %d %m-, %Y - %T”} -

Network configuration change reported by {m} ({t}). Port {I 3} in slot {I 1} has now become active as the result of a redundancy polling failure.

CsEvFormat/Event000d010b

{d “%w- %d %m-, %Y - %T”} -

Redundancy diagnostics of {m} ({t}), indicate that the redundant link for module {I 1}, port {I 3} has failed.

CsEvFormat/Event000d010f

{d “%w- %d %m-, %Y - %T”} - User defined traffic threshold -

{I 1} packets within {I 3} seconds, exceeded on module {I 5} of {m} ({t}).


Message


The polled device(s) in the redundant circuit polling list has failed to respond.

The device(s) has failed, been powered down, or a cable fault from the active port to the polled device has occurred.

Check the retry count as it may need to be adjusted on a busy network segment.

Normal collision occurrences may occur causing the poll packet to not reach its destination.

CsPCause/Prob000d010a

The polled device has been communicated with via a backup port and the port is now active. The other ports in this redundant circuit are now designated as backup and are turned off to prevent data loops on the network.

CsPCause/Prob000d010b

The cable segment connected to the port has a cable fault and should be checked for continuity as soon as possible in the event the other ports in this redundant circuit fail and this port is needed.

CsPCause/Prob000d010f

The packet rate on this module has exceeded user defined limits. The device(s) attached to this module may have an application which requires a large amount of network bandwidth. If the application required a large amount of network bandwidth, then a bridge or router could be used to logically separate various network segments.

Use port level thresholds to further troubleshoot to a device level.


4-5


Table 4-1.




{d “%w- %d %m-, %Y - %T”} -

Error threshold exceeded. An error threshold of {I 1}% good packets in

{I 5} seconds, exceeded on module in slot {I 7}.


{d “%w- %d %m-, %Y - %T”} -

Collision threshold exceeded.

Collisions exceeded {I 1}% of good packets in {I 3} seconds on the module in slot {I 5} of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Traffic threshold, packets per

{I 3} seconds, exceeded on port {I 7} on module in slot {I 5} of {m} ({t}).


Message


This threshold will indicate that a malfunctioning device is present on this module or that a cable fault exists. A port level threshold should be set to further troubleshoot to the offending node.


Collisions are caused by many nodes contending for the network of cabling faults. Use port level thresholds to further troubleshoot to a device level.


{d “%w- %d %m-, %Y - %T”} -

Error threshold exceeded. An error threshold of {I 1}% good packets in

{I 5} seconds, exceeded on port {I 9} on module in slot

{I 7} of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -


Collisions exceeded {I 1}% of good packets in {I 3} seconds on port

{I 7} on module in slot {I 5} of {m}

({t}).


The device(s) attached to this port may have an application which requires a large amount of network bandwidth. If the application requires a large amount of network bandwidth, then a bridge or router could be used to logically separate various network segments.


The device(s) attached to this port could have a hardware failure where it transmits invalid packets or the cable segment attached to this port may have a problem. Check cable for loose connection or continuity problems.


The device(s) attached to this port may have an adapter card problem which causes them to transmit without regarding network availability or a cable problem may exist. Check adapter card and cable for loose connections, termination problems, or improper pinouts.


4-6

EMME/EMM-E6


Table 4-1.





{d “%w- %d %m-, %Y - %T”} -

Port type changed. Port {I 3} of module in slot {I 1} has changed types of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Port security violation has occurred on port {I 3} of module in slot {I 1} has changed types of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Port violation reset, port {I 3} of module in slot {I 1} of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Environment Temperature Warm condition for module in slot {I 1} reported by {m} ({t}).


Message


The number of addresses in the source address table has changed. If more than one address is learned on a port for one aging time period, the port is designated as a trunk port. A port connecting two hubs or a coax segment with multiple taps are examples of trunk ports. If a port has one address in the source address table for two aging times, the port is designated as a station port. An example of a station port would be a twisted pair “home run” to a PC.


This event is only generated when the hub has port locking enabled. When a hub is locked, the source MAC addresses are learned on each port.

When a port detects an attached device has changed its address, the device will note that the new address is not in the source address table. This will disable and lock the port which then transmits this trap. This trap would be generated if an adapter were replaced or if an intruder attempts to access the network.


The network administrator has located the offending device that caused the port violation and has re-enabled the port for use by the original network address for that port.


The module may be defective or a fan has failed in the chassis. Check the alarm log for this device for any fan alarms.


4-7


Table 4-1.



CsEvFormat/Event000d011a

{d “%w- %d %m-, %Y - %T”} -

Environment Temperature Hot condition for module in slot {I 1} reported by {m} ({t}).

CsEvFormat/Event000d011b

{d “%w- %d %m-, %Y - %T”} -

Environment Voltage Low condition has been detected by power supply in slot {I 1} of {m} ({t}).


Message

CsPCause/Prob000d011a

The module may be defective or a fan has failed in the chassis. This alarm indicates a serious heat condition and should be addressed immediately.

CsPCause/Prob000d011b

The internal voltage of the power supply module is low. The voltage condition indicates that either the supply itself is defective or an AC power failure has occurred in the power supply module.

CsPCause/Prob000d011c

A chassis or cooling system problem at this device location has been corrected.

CsEvFormat/Event000d011c

{d “%w- %d %m-, %Y - %T”} -

Environment Temperature Normal condition for module in slot {I 1} reported by {m} ({t}).

CsEvFormat/Event000d011d

{d “%w- %d %m-, %Y - %T”} -

Environment Voltage Normal condition has been detected by power supply in slot {I 1} of {m} ({t}).

CsEvFormat/Event000d011e

{d “%w- %d %m-, %Y - %T”} -

A fan in the system’s chassis has failed or is operating at an abnormal RPM rate, has been detected by {m} ({t}).

CsEvFormat/Event000d011f

{d “%w- %d %m-, %Y - %T”} -

A fan in the system’s chassis has resumed normal operation, has been detected by {m} ({t}).

CsPCause/Prob000d011d

The problem with the power supply module or AC power feed has been corrected and the unit is now functioning normally.

CsPCause/Prob000d011e

A fan(s) in the fan tray assembly has failed or the fan tray has been removed.

The situation is not critical but temperature warm or temperature hot traps may follow. If the temperature traps have appeared in the alarm log, then the failure should be addressed before overheating damages the device.

CsPCause/Prob000d011f

The problem previously detected with the fan assembly has been corrected and the unit is now functioning normally.


4-8

EMME/EMM-E6


Table 4-1.





{d “%w- %d %m-, %Y - %T”} - Board

Broadcast Threshold Exceeded.


{d “%w- %d %m-, %Y - %T”} - Port

Broadcast Threshold Exceeded.


{d “%w- %d %m-, %Y - %T”} -

System Voltage Low condition has been detected by {m} ({t}).


Message


This trap will be generated when the broadcast (packets per time interval) has been exceeded for the given module.


This trap will be generated when the broadcast (packets per time interval) has been exceeded for the given port.


The internal 5 volt line of the system is low. The voltage low condition indicates that either the power supplies are failing or there is not enough power available to the host modules. This is a serious condition and should be addressed immediately.


{d “%w- %d %m-, %Y - %T”} -

System Voltage Normal condition has been detected by {m} ({t}).

CsEvFormat/Event000d0127 d “%w- %d %m-, %Y - %T”} -

An EPIM has been removed from port {I 3} on module in slot {I 1} of

{m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

An {T EPIMType 5} has been inserted into port {I 3} on module in slot {I 1} of {m} ({t}).



An Ethernet Port Interface Module

(EPIM) has been physically removed.



4-9


Table 4-1.




{d “%w- %d %m-, %Y - %T”} -

Traffic threshold, {I 1} packets per

{I 3} second exceeded on the repeater network {I 5} of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Error threshold exceeded. An error threshold of, {I 1}% good packets in

{I 5} seconds, exceeded on repeater network {I 7} of {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -


Collisions exceeded {I 1}% good packets in {I 3} seconds on repeater network {I 5} of {m} ({t}).


Message


The device(s) attached to this channel may have an application level problem.

The attached devices may be operating properly but the application requires a large amount of network bandwidth. If the application requires a large amount of network bandwidth, then a bridge or router may be used to logically separate various network segments. This trap indicates that module or port level thresholds on this repeater channel are needed to pinpoint high bandwidth users.


A user defined threshold has been exceeded on this channel. This threshold could indicate that a malfunctioning device is present on this channel or that a cable fault exists. A module or port level threshold should be set to further troubleshoot to the offending node.


A user-defined threshold has been exceeded on this channel. This threshold could indicate that a malfunctioning device is present on this channel or that a cable fault exists.

Collisions are usually caused by many nodes contending for the network. As traffic rates increase, the collision rate usually follows. Thus, if this channel has a high bandwidth utilization, a high collision rate is not unlikely. Use module and port level thresholds to further troubleshoot to a device level.


4-10

EMME/EMM-E6


Table 4-1.





{d “%w- %d %m-, %Y - %T”} -

Network port security lock has been

{I 1} on repeater network

{I 3} on {m} ({t}).


{d “%w- %d %m-, %Y - %T”} -

Repeater Broadcast Threshold

Exceeded.


{d “%w- %d %m-, %Y - %T”} -

ChBoard Insertion. A module has been inserted into slot {I 1}.


Message


The network administrator has changed the status of port locking for this repeater channel. The security feature locks all ports on this repeater channel so that only a valid user already in the source address table can access the network.


This trap will be generated when the broadcast (packets per time interval) has been exceeded for the repeater.


A module has been inserted into this hub.

CsEvFormat/Event000d01a0

{d "%w- %d %m-, %Y - %T"} - A Port

Interface Module has been inserted into port {I 3} of interface {I 1} on

{m} ({t}).


{d "%w- %d %m-, %Y - %T"} - A Port

Interface Module has been removed from port {I 3} of interface {I 1} on

{m} ({t}).


{d "%w- %d %m-, %Y - %T"} -

Network configuration change reported by {m} ({t}). Device linked to port {I 3} on interface {I 1}.

CsPCause/Prob000d01a0

A Port Interface Module has been physically inserted.


A Port Interface Module has been physically removed.


A device supporting link integrity, fiber optic or twisted pair, has made a valid connection (link) to this port.


4-11


Table 4-1.




{d “%w- %d %m-, %Y - %T} - Port

{I 3} on interface {I 1} of {m} {t} has unsegmented.


{d "%w- %d %m-, %Y - %T"} - Front panel redundant port {I 1} has been activated by device {m} of type {t}.


Message


A device previously linked with this port has been removed, powered down, or the cable segment has a fault.


A new port has been activated for the front panel redundant circuit. This does

NOT indicate this port is usable, but is being tested.


4-12

EMME/EMM-E6


Chapter 5

Application View


This chapter describes the following device-specific applications for the

EMME/EMM-E6:

• Network (A,B. or C) Application (CSIRptrApp)

• Download Application (CtDownloadApp)

• Isolated Repeater Application (CSIIsolRptrApp)

In addition, this chapter describes the following BRIM-specific applications for the EMM-E6:

• ATM Client Application

• FddiSMT Application

9031111 E7

5-1

Applications Not Covered in This Chapter

Applications Not Covered in This Chapter

This device supports the following common applications described inMIB II

Applications, Bridging Applications, and Miscellaneous Applications.

• Bridging (CSIBridge)

- Spanning Tree (Ct_Stp_App)

- Transparent (Transparnt_App)

- Static (Static_App)

• MIB-II (SNMP2_Agent)

- IP (IP2_App)

- System (System2_App)

- ICMP (ICMP_App)

- UDP (UDP2_App)

The following major applications are available if you purchase the associated services. These applications are described in their management module guides.

• Routing Services (CtRouter)

• DLM (DLM_Agent)

• Standard RMON (RMONApp)

Device Application View

This view shows the common and device-specific applications supported by this device and provides access to application-specific information.

Refer to Chapter 1, Introduction, for information on Accessing SPECTRUM

Views from the Device Icon and Accessing Device-Specific Subviews.

Figure 5-1 provides an example of an Application view in the icon mode.

Figure 5-2 provides an example of an Application view in the list mode.

To change the display mode, select View -> Mode -> List or Icon.

Application View

5-2

EMME/EMM-E6


Device Application View

Figure 5-1.

Device Application View Icon Mode)

ATM type BRtrCSIEMM_E6 of Landscape castle: Primary

* File View

Net Addr Model Name

Contact

Description

Location

Prime-App

Sys Up Time

Manufacturer

Device Type

Serial Number

Model Name

EMM-E6

Bridging

CSIBridge

Enet SDB

CT_BdgEnet_Ap

Spanning Tree

CT_Stp_App

Network A

CSIRpt

MIB-II

SNMP2_Agent

SNMP2_Agent

ICMP

ICMP_App

ICMP_App

IP

IP2_App

IP2_App

DLM App

DLM_Agent

SNMP2_Agent

Help?

9031111 E7 Application View

5-3

Device Application View

Figure 5-2.

Device Application View (List Mode)

ATM of type BrtrCSIEMM_E6 of Landscape castle: Primary

* File View

Model Name

Contact

Description

Location

Net Addr

Prime-App

Sys Up Time

Manufacturer

Device Type

Serial Number

BRtrCSIEMM_E6

CSIBridge

CT_BdgEnet_App

CT_Stp_App

Static_App

Transparnt_App

CSIRptr

SNMP2_Agent

ICMP_App

IP2_App

System2_App

UDP2_App

DLM_Agent

CtDownLoadApp

FddiSMT

RMONApp

Help?

Application View

5-4

EMME/EMM-E6


Network (A, B, or C) Application

Network (A, B, or C) Application

Table 5-1.

This section describes the Network (A, B, or C) application supported by this

device. The model type for this application is CSIRptr. Table 5-1 lists all the

application-specific subviews available from the Icon Subviews menu for the

Network (A, B, or C) Application. Table 5-2 describes a submenu accessible by

clicking the Performance option of the Icon Subviews menu. See Chapter 1,

Introduction, for information on Accessing Device-Specific Subviews.

Network (A, B, or C) Application Subviews Menu


Device

Dev Top

Performance

Configuration

Opens the Chassis Device View described in Chapter 2,

Device Views.


Views.

Opens the submenu described in Table 5-2.

Opens the Repeater Configuration View described in


Repeater Redundancy Opens the Repeater Redundancy view described in the




Guide.

Repeater Source

Address

Opens the repeater Source Address view described in the

Portable Management Application for the EMME

SPECTRUM User’s Guide or the SPECTRUM Portable


Guide.

Repeater Security

Configuration

Model Information

Opens the Repeater Security view described in the




Guide.

Opens the Repeater Model Information view described in

SPECTRUM Views.


5-5


Table 5-2.

Network (A, B, or C) Application Subviews Menu (Performance

Option)


Performance Opens the Performance view described in SPECTRUM

Views.

Frame & Error

Breakdown


described in Chapter 2, Device Views.

Frame Size & Protocols


in Chapter 2, Device Views.

Isolated Repeater Application

Table 5-3.

This section describes the Isolated Repeater application supported by this

device. The model type for this application is CSIIsolRptr. Table 5-3 lists all

the application-specific subviews available from the Icon subviews menu for the Isolated Repeater application.

Isolated Repeater Application Subviews Menu

Menu Selection

Device

DevTop

Configuration

Model Information

Description

Opens the Chassis Device View described in Chapter 2,

Device Views.

Opens the Device Topology view described SPECTRUM

Views.

Opens the CSI Isolated Repeater Configuration View

described in Chapter 3, Configuration Views.

Opens the CSI Repeater Model Information view described in SPECTRUM Views.

Application View

5-6

EMME/EMM-E6



Creating an Isolated Repeater

Creating an Isolated Repeater

To reconfigure a selected repeater to a stand _alone mode (isolated), follow these steps:

1.

Within the Chassis Device view, select a desired Repeater MIM icon

(network B or C only).

2.

From the Icon Subviews menu, select:

• For TPXMIM - Change Module Channel

• For other Repeater MIMs- Repeater -> Change Module Channel to open the Change Module Channel view described in Chapter 2, Device

Views.

3.

Within the Change Module Channel view, select Stand_Alone from the

Module Connection menu button.

4.

From the File menu, choose Save All Changes.

To reconfigure the Application view to recognize the new repeater, follow these steps:

1.

Within the Application view, select Edit from the File menu to enter the edit mode.

2.

From the Edit menu, select Reconfigure.

3.

Within the Rediscover Applications dialog box, click OK.

4.

From the File menu, select Save & Close.

The Application view refreshes and the new CSIIsolRptr Icon appears.

NOTE

SPECTRUM also creates isolated repeaters when you insert a MIM into an

MMAC FNB non-shunting chassis, where a non-MIM module or empty slot is to the right of the MIM module.


5-7

DownLoad Application

DownLoad Application

Table 5-4.

This application provides download functionality for the EMME/EMM-E6.

The model type for this application is CtDownLoadApp.Table 5-4 lists all the

application-specific subviews available from the Icon subviews menu for the

DownLoad Application. See Chapter 1, Introduction, for information on


Download Application Subviews Menu


DownLoad Application Opens the DownLoad Application view. This is an SPMA view and is described in the SPECTRUM Portable

Management Application Tools Guide.

Model Information Opens the DownLoad Application Model Information view described in SPECTRUM Views.

ATM Client Application

Table 5-5.

This section describes the ATM Client Application supported by this device.

The model type for this application is ATMClientApp. Table lists all the application-specific subviews available from the Icon Subviews menu for the

ATM Client Application. Table describes a submenu accessible by clicking on the Interfaces option of the Icon Subviews menu. See Chapter 1, Introduction,

for information on Accessing Device-Specific Subviews.

ATM Client Application Subviews Menu

Menu Selection

ATMConfig

Model Information

VCL Table

Interfaces

Description

Opens the ATM Client Application Configuration view described in Chapter 3, Configuration Views.

Opens the ATM Application Model Information view described in SPECTRUM Views.

Opens the ATM Client Application Virtual Channel Link

View described in this chapter.

Allows you to access a submenu for the ATM interface on

this module. Table 5-6 lists the menu selections for this

interface.

Application View

5-8

EMME/EMM-E6


Table 5-6.


ATM Client Application Virtual Channel Link View

ATM Client Application Subviews Menu (Interfaces option)

Menu Selection

Performance

Configuration

Description


Views.

Opens the Port Configuration - BRIMIfATM view described in Chapter 3, Configuration Views.

ATM Client Application Virtual Channel Link View

This view provides the Virtual Channel Link (VCL) table containing detailed information about the virtual channels passing through this ATM Client

Application. In addition, the Row Status Procedure area allows you to create or remove a selected channel from the VCL table. The Virtual Channel Link table provides the following information:

If Index

Displays the interface index for this VPI and VCI.

VPI

Displays the Virtual Path Identifier (VPI) value. This value is a part of the five-byte ATM header and is used to determine the correct input or output path for the ATM cell.

VCI

Displays the Virtual Circuit Identifier (VCI) value. This value is a part of the five-byte ATM header and is used to determine the correct input or output channel for the ATM cell.

Admin Status

Specifies the desired administrative state of the VCL. Possible states are: up and down, indicating that the traffic flow for this VCL is enabled or disabled respectively. Administrative status is implemented only for a VCL which terminates a VCC (i.e., one which is not cross-connected to other VCLs). To change the Admin Status for a specific channel, do the following:

1.

Within the Virtual Channel Link table, double-click the selected channel’s entry to open the ATM Switch Application Virtual Channel Link view.

2.

Select the desired status from the Admin Status menu button.

3.

From the File menu, select Save All Changes.

Oper Status

Indicates the current operational status of the VCL. Possible states are: up, down, and unknown. Up and down states indicate that the VCL is currently operational, or not operational, respectively. The unknown state indicates that the status of this VCL cannot be determined.


5-9



Last Change

Indicates the value of MIB II’s sysUpTime object at the time this VCL entered its current operational state. If the current state was entered prior to the last re-initialization of the agent, this object contains a zero value.

Rcv Descr Index

Indicates a row in the ATM Traffic Descriptor table that applies to the receive direction of this VCL. To change the Rcv Descr Index for a specific channel, do the following:

1.


2.

Within the Xmit Descr Index field, type the new index number.

3.


Xmit Description Index

Identifies the row of the ATM Traffic Descriptor table which applies the transmit direction of this VCL. To change the Xmit Descr Index for a specific channel, do the following:

1.


2.

Within the Xmit Descr Index field, type the new index number.

3.


AAL Type

Indicates the type of the ATM Adaptation Layer (AAL) type used on this VCC.

Possible AAL types are: AAL1, AAL34, and AAL5, other, and unknown. This list may also include a user-defined AAL type. The unknown type indicates that the AAL type cannot be determined. AAL type is implemented when the local VCL endpoint is also the VCC endpoint, and AAL is in use. To change the

AAL Type for a specific channel, do the following:

1.


2.

Select the desired type from the AAL Type menu button.

3.


Application View

5-10

EMME/EMM-E6


9031111 E7



Transmit Size

Displays the maximum AAL5 CPCS SDU size in octets that is supported on the transmit direction of this VCC. Transmit Size is implemented when the local VCL endpoint is also the VCC endpoint, and AAL5 is in use. The

Transmit Size can be altered. The maximum allowable value is 155 Mbs displayed in octets. To change the Transmit Size for a specific channel, do the following:

1.


2.

Within the Transmit Size field, type the new Transmit Size number.

3.


Receive Size

Displays the maximum AAL5 CPCS SDU size in octets that is supported on the receive direction of this VCC. Receive Size is implemented when the local

VCL endpoint is also the VCC endpoint, and AAL5 is in use. The Receive Size can be altered. The maximum allowable value is 155 Mbs displayed in octets.

To change the Receive Size for a specific channel, do the following:

1.


2.

Within the Receive Size field, type the new Receive Size number.

3.


Encaps Type

Displays the type of data encapsulation used over the AAL5 SSCS layer.

Possible Encaps types are: Routed, Bridged_8023, Bridged_8025,

Bridged_8026, LAN_emulation_8023, LAN_emulation_8025,

LLC_Encapsulation, Frame_Relay_Sscs, other, and unknown. Encaps type is implemented when the local VCL endpoint is also the VCC endpoint, and

AAL5 is in use. To change the Encaps Type for a specific channel, do the following:

1.


2.

Select the desired type from the Encaps Type menu button.

3.


Cross Connect Id

Displays an Id for all associated VCLs and their cross-connections that are identified by entries in the Cross Connect table. The Cross Connect Id is initialized by the agent after the associated entries in the Cross Connect Table have been created. The Cross Connect Id is implemented only for a VCL which is cross-connected to other VCLs that belong to the same VCC.

Application View

5-11


Row Status

Displays the row status used while creating, deleting or modifying a row in this table. Possible menu selections are: active, not_in _service, not_ready, create_and_go, create_and_wait, and destroy. To change the Row Status for a specific channel, do the following:

1.


2.

Select the desired status from the Row Status menu button.

3.


The Row Status Procedure area of the ATM Client Application Virtual

Channel Link view provides the following information and fields that allow you to create or remove a virtual channel link from the Virtual Channel Link table.

Channel Information

Allows you to type If Index number, VPI number, and the VCU number for the channel you wish to create or remove.

Create Channel

Allows you to add a new virtual channel to the Virtual Channel Link table.

Remove Channel

Allows you to remove an existing virtual channel from the Virtual Channel

Link table.

To create or remove a virtual channels from the Virtual Channel Link table, follow these steps:

1.

Set channel information by typing the If Index number, the VPI number, and the VCI number of the channel you want to add or remove in the

Channel Information field. The numbers should be separated by periods.

2.

Perform the view update by pressing enter or ctrl+s.

3.

Select Create Channel or Remove Channel.

4.

Within the Virtual Channel Link table, select Update.

Application View

5-12

EMME/EMM-E6



FddiSMT Application

Table 5-7.

This section describes the FddiSMT application supported by this device. The model type for this application is FddiSMT. Table lists all the application-specific subviews available from the Icon Subviews menu for the

FddiSMT application.

FddiSMT Application Icon Subviews Menu

Menu Selection

DevTop

Station List

Configuration

Model Information

Hub Detail

Description

Opens the Device Topology (DevTop) view described in

SPECTRUM Views.

Opens the FDDI Station view described in MIB II



Opens the SMT Device Configuration View described in


Opens the SMT Model Information view described in

SPECTRUM Views.

Opens the FddiSMT Detail view described in MIB II




5-13


Application View

5-14

EMME/EMM-E6


A

A_Port

3-14

AAL Type

5-10

Accessing

Device-Specific Subviews

1-6

SPECTRUM Views

1-4

Accum

2-12 ,

2-14

Address Type

3-20

Admin

Address

3-20

Status

3-14

,

5-9

Administrative

Status

3-5

Label

2-33

Aging Interval

3-9

Alarm

Condition

3-4

Configuration

3-6

,

3-10

Manager

4-1

Alignment

3-8 ,

3-11

Application

Label

2-8

View

5-1

(icon mode)

5-2

(list mode)

5-2

Apply button

2-40

ATM

Client Application

5-8

Configuration View

3-19

Label

2-17

Switch Application Virtual Channel Link

View

5-9

AUI Port

1-2

AutoDiscovery

1-3

B

B_Port

3-14

Board Map

3-12

Bridge

Detail

2-8

Model Information

2-8

9031111 E7

Index

Performance

2-8

Ports

1-2

BRIM

1-2

- FD Interface Configuration View

3-13

Label

2-16

Port

1-2 ,

2-10

Label

2-18

Status Label

2-18

Type Label

2-18

Broadcast

Alarm Condition

3-7

Alarms

3-7 ,

3-11

Threshold

3-11

BRtrCSIEMM_E6

1-3

C

Change

Module Channel View

2-22

Port Channel View

2-29

Channel

1-2

Chassis

Alarm

3-4

Configuration View

3-3

Device View

2-2

Type

3-3

Close button

2-40

Collision Threshold

3-10

Component Table

3-2

Conf VCCs

3-19

Conf VPCs

3-19

Configuration Views

3-1

Contact Status

3-2

CRC

3-8 ,

3-11

Creating an Isolated Repeater

5-7

Cross Connect Id

5-11

CSI Isolated Repeater

3-12

Configuration

3-12

CSIBridge

5-2

Ct_Stp_App

5-2

CtRouter

5-2

Cyclical Redundancy Checks

3-8 ,

3-11

1

D

Date

3-4

Date/Time

3-2

Default button

2-40

Delta

2-12

, 2-14

Device

Application View

5-2

Configuration View

3-2

View

2-1

DLM

5-2

DLM_Agent

5-2

DownLoad Application

3-2 ,

5-8

E

EMME/EMM-E6

1-2

Chassis Module Icon Subviews

2-7

Device Configuration View

3-2


2-7

Model Information

2-7

Module

Icon

2-4

Identification Labels

2-7

Enable All Ports

2-22

Enable/Disable

2-29

Port

2-23

Encaps Type

5-11

EPIM Ports

2-10

Error

Alarms

3-7

Breakdown

2-13

Source

3-8 ,

3-11

Ethernet

802.3 Subnetworks

1-2

Backbone Network

1-2

Port Interface Module (EPIM)

1-2

Event and Alarm Messages

4-1

Log

4-1

F

FDDI Label

2-16

FddiSMT Application

5-13

Filter

2-37

Find

3-20

Firmware Revision

3-2

Frame

Breakdown

2-13

Index

2

Size

2-14


3-2

G

Gauge

Buttons

2-40

Control Panel

2-37

Label

2-36

Mode

2-38

Type

2-40

Getting Help

xiii

Giant Packets

3-8

Giants

3-8 ,

3-11

Group ID

3-12

H

Hardware

Rev

3-3

Revision

3-2

Hub Detail

5-13

HubCSIEMME

1-3

HubCSIEMM-E6

1-3

I

ICMP

5-2

ICMP_App

5-2

IF

Description

3-14

Index

5-9

ILMI

VCI

3-20

VPI

3-20

Index

3-3

Interface

Channel

2-9

Configuration

Table

3-3

Views

3-13

Description

2-37

Device View

2-30

Icon

2-32

Subviews Menu

2-33

Index

3-13

Label

2-33

Labels

2-9

Options Panel

2-37

EMME/EMM-E6


Status

2-9

Type

3-13

Label

2-34

IP Application

5-2

IP2_App

5-2

Isolated Repeater Application

5-6

Isolation Station

2-27

K

Keep Settings button

2-40

L

Last Change

5-10

Link

Error

Monitor

Count

3-15

Reject Count

3-15

Rate

Alarm

3-15

Cutoff

3-15

Estimate

3-15

Graph

3-15

Status

3-5

M

MAC

Address

3-18

Address Label

2-36

Configuration

3-17

Count

3-18

Path

3-17

Manages

3-12

, 3-13

Master

3-14

Max

Ports

3-18

Frame Size

3-3

VCCs

3-19

VCI Bits

3-19

VPCs

3-19

VPI Bits

3-19

Menu Bar Access

2-1

Mgmt. Name

3-12

MIB-II

5-2

MIM

Icon

2-19

9031111 E7

Icon Subviews Menu

2-21


2-20

Misaligned Packets

3-8

MMAC FNB Chassis

1-2

Model

Information

2-33

Type

2-7

Modeling Instructions

1-3

Module

Channel or Isolation Station

2-21

Configuration View

3-4

Connection

2-22

DevTop View

2-21

Management

3-5

Notes

2-7

,

2-21

Number

2-22

Performance

2-21

Ports

3-5

Type

2-21

N

Neighbor

Address

3-20

If Name

3-20

Notification Protocol

3-18

Network

(A, B, or C) Application

5-5

Information Label

2-36

No_Resource

3-8 ,

3-11

Non Master Ports

3-18

Non-Repeater MIM

2-19

Notice

i

Number of Interfaces

3-3

O

OBS Present

3-18

OOW_Colls

3-11

Oper Status

3-3 ,

5-9

Operation Status

3-14

P

Phy Address

3-3

Physical Device View

2-41

Pie Chart

2-12

,

2-14

Port

Action

3-14

Index

3

Configuration

View

3-4

, 3-14

View (for FDDI)

3-14

Count

3-5 ,

3-9 ,

3-12

Frame

& Error Breakdown

2-23

,

2-28

Size & Protocols

2-23 ,

2-29

Management

3-5

, 3-16

Notes

2-23

Number

2-24

,

2-30

Performance

2-23

Redundancy

2-23

, 2-29


2-23 ,

2-29

Source Address

2-23 ,

2-29

State

3-14

Statistics

2-24

Status

2-24

,

2-30

Type

3-14

Port Configuration

- BRIMIfATM View

3-13

- BRIMIfEnet View

3-13

- CSIIfPort View

3-13

Ports

Enab

3-12

On

3-5

,

3-9

, 3-13

Oper

3-13

Operational

3-5 ,

3-9

Probable Cause Messages

4-1

Protocols

2-15

,

2-33

R

Rcv Descr Index

5-10

Receive Size

5-11

Related Reading

xii

Repeater
