Administering Agilent 3070 Systems

MS Windows® NT® and 2000®

January 2004

Contents Administering Agilent 3070 Systems (MS Windows NT and 2000)

1

Introduction

About This Manual ................................................................................................................ 1-1

Who Should Use This Manual............................................................................................... 1-1

Summary of System Administration Tasks ................................................................................. 1-2

How Many Administrators are Necessary? ........................................................................... 1-2

Required Knowledge ............................................................................................................. 1-2

Responsibilities...................................................................................................................... 1-2

3070 Software Overview ............................................................................................................. 1-3

Introduction............................................................................................................................ 1-3

Capabilities of the MS Windows® 2000 Professional Operating System ............................ 1-3

The Agilent 3070 Directory Structure .................................................................................. 1-4

Advantages of a LAN ............................................................................................................ 1-5

3070 Program Software ......................................................................................................... 1-5

3070 Hardware Overview............................................................................................................ 1-8

Testhead ................................................................................................................................. 1-8

Testhead Controller................................................................................................................ 1-8

2

Starting and Shutting Down the System

Starting the System ...................................................................................................................... 2-2

Prerequisites........................................................................................................................... 2-2

Required Tools and Materials................................................................................................ 2-2

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) i

Table of Contents

Booting a 3070 Controller ..................................................................................................... 2-2

Logging In.............................................................................................................................. 2-3

Booting the Testhead ............................................................................................................. 2-3

Shutting Down the System .......................................................................................................... 2-4

Introduction............................................................................................................................ 2-4

Unboot the Testhead .............................................................................................................. 2-4

Shut Down the Controller ...................................................................................................... 2-4

Disconnecting Power to the Controller.................................................................................. 2-4

3

Setting Up and Configuring New Systems

Objectives .............................................................................................................................. 3-1

Prerequisites........................................................................................................................... 3-1

Preparing to Set Up a System ...................................................................................................... 3-2

Information for Windows 2000 Setup ......................................................................................... 3-3

Setup Wizard Tasks ............................................................................................................... 3-3

Setting Up Windows 2000 Professional ...................................................................................... 3-5

Additional Setup Tasks................................................................................................................ 3-6

Gathering Network Configuration Information........................................................................... 3-8

Gather the Network Configuration Information .................................................................... 3-8

Network Components ................................................................................................................ 3-12

Agilent Software License Activation......................................................................................... 3-13

Codeword and License Management................................................................................... 3-13

Required Tools and Materials.............................................................................................. 3-13

Redeeming your Software License ...................................................................................... 3-15

Software License Activation................................................................................................ 3-16

Validate Software License Key ........................................................................................... 3-16

Software License Activation Troubleshooting .......................................................................... 3-17

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) ii

Table of Contents

Configuring a Network Adapter Card (Local Area Connection) .............................................. 3-18

4

Backing Up and Restoring System Software

Introduction............................................................................................................................ 4-1

Objectives .............................................................................................................................. 4-1

Prerequisites........................................................................................................................... 4-1

Required Tools and Materials................................................................................................ 4-2

Planning a Backup Strategy......................................................................................................... 4-3

Preparing for Disaster Recovery.................................................................................................. 4-4

Disaster Recovery for an Industrial PC Controller...................................................................... 4-5

Backup vs. Disaster Recovery ............................................................................................... 4-5

Disaster Recovery Solution ................................................................................................... 4-5

Creating Boot Recovery Diskettes............................................................................................... 4-6

Introduction............................................................................................................................ 4-6

When to Create Boot Recovery Diskettes. ............................................................................ 4-6

Required Tools and Material ................................................................................................. 4-6

How to Create Boot Recovery Diskettes ............................................................................... 4-7

Making a Full Backup Tape......................................................................................................... 4-9

Overview................................................................................................................................ 4-9

Prerequisites........................................................................................................................... 4-9

Required Tools and Materials................................................................................................ 4-9

How to Make a Full Backup Tape ....................................................................................... 4-10

Restoring Selected Data from a Backup Tape ........................................................................... 4-14

Restoring Specific Data ....................................................................................................... 4-14

Restoring a 3070 System from a Full Backup Tape .................................................................. 4-19

Introduction.......................................................................................................................... 4-19

Prerequisites......................................................................................................................... 4-19

Required Tools and Materials.............................................................................................. 4-20

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) iii

Table of Contents

Disaster Recovery Procedure............................................................................................... 4-20

How to Restore a System From a Full Backup Tape........................................................... 4-22

Restoring a 3070 System from the System Recovery DVD...................................................... 4-28

Introduction.......................................................................................................................... 4-28

Required Materials............................................................................................................... 4-28

System Recovery Procedure ................................................................................................ 4-29

IO Configuration Procedure................................................................................................. 4-29

5

Administration Tasks

Objectives .............................................................................................................................. 5-1

Prerequisites........................................................................................................................... 5-1

Overview of Administration Tasks.............................................................................................. 5-2

Maintaining the File System ........................................................................................................ 5-3

Required Tools and Materials................................................................................................ 5-3

File System Maintenance Tasks ............................................................................................ 5-3

Creating User Accounts ............................................................................................................... 5-4

Required Tools and Materials................................................................................................ 5-4

About User Accounts............................................................................................................. 5-5

Group Accounts ..................................................................................................................... 5-5

User Rights ............................................................................................................................ 5-6

Adding a User Account.......................................................................................................... 5-6

Adding a Group Account....................................................................................................... 5-7

Administering Datalogging........................................................................................................ 5-10

Installing Patches ....................................................................................................................... 5-11

6

Understanding the File System

The Root Directory Environment Variable ................................................................................. 6-2

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) iv

Table of Contents

Introduction............................................................................................................................ 6-2

The $AGILENT3070_ROOT Environment Variable ........................................................... 6-2

$AGILENT3070_ROOT on UNIX............................................................................................. 6-2

$AGILENT3070_ROOT on MS Windows................................................................................. 6-5

File Path Usage in a MS Windows Korn Shell Window....................................................... 6-5

The

.hp3070

File ......................................................................................................................... 6-7

Some Descriptions of .hp3070 File Keywords ...................................................................... 6-7

Installing Software Packages ..................................................................................................... 6-11

Introduction.......................................................................................................................... 6-11

Install a Software Package................................................................................................... 6-11

7

Additional Information for Networking

Introduction.................................................................................................................................. 7-2

3070 Networking Facilities.................................................................................................... 7-2

To Configure Networking...................................................................................................... 7-2

Testhead IP Addresses ................................................................................................................. 7-3

3070 System IP Addresses..................................................................................................... 7-3

Implications for Custom Applications................................................................................... 7-3

The Private LAN.......................................................................................................................... 7-5

3070 Private LAN IP Addresses............................................................................................ 7-5

The Public LAN........................................................................................................................... 7-7

Introduction............................................................................................................................ 7-7

A User-Access Example ....................................................................................................... 7-7

Bridges, Routers, and Gateways .................................................................................................. 7-9

Clients and Servers .................................................................................................................... 7-10

Network ............................................................................................................................... 7-10

Hosts and Nodes .................................................................................................................. 7-10

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) v

Table of Contents

Client.................................................................................................................................... 7-10

Server ................................................................................................................................... 7-10

Client/Server ........................................................................................................................ 7-10

The MS Windows Controller as Server............................................................................... 7-10

Domain Names .......................................................................................................................... 7-11

Network Services ....................................................................................................................... 7-12

Useful Commands...................................................................................................................... 7-13

8

Reference

Referenced Manuals .............................................................................................................. 8-1

Introduction............................................................................................................................ 8-1

Logging-On as service3070 ......................................................................................................... 8-2

Display the Logon Status from a Current Login.................................................................... 8-2

Logon as service3070.....................................................8-2

The Root Directory Environment Variable ................................................................................. 8-3

Introduction............................................................................................................................ 8-3

Determine the Value of the Root Directory Environment Variable ...................................... 8-3

Use of the Root Directory Environment Variable in a BT-BASIC Window ........................ 8-3

Use of the Root Directory Environment Variable in a Korn Shell Window ......................... 8-4

Use of the Root Directory Environment Variable in a MS-DOS Command Prompt Window8-5

Directory Descriptions................................................................................................................. 8-6

Editing Files................................................................................................................................. 8-8

Forward-Slashes versus Back-Slashes in Command Lines Containing File Paths ............... 8-8

Use BT-BASIC ...................................................................................................................... 8-8

How to Edit the System Config File to Match the Testhead Configuration.......................... 8-9

How to Resolve the Standard Config File from the System Config File ............................ 8-10

MS Windows Quick-Reference ................................................................................................. 8-16

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) vi

Table of Contents

BT-BASIC Quick-Reference..................................................................................................... 8-17

NT Korn Shell Quick Reference................................................................................................ 8-18

vi and viw Editor Quick Reference............................................................................................ 8-21

Codewords ................................................................................................................................. 8-25

Introduction.......................................................................................................................... 8-25

Install Codewords ................................................................................................................ 8-25

Verify Installed Codewords ................................................................................................. 8-25

Compile the Two Config Files............................................................................................. 8-25

System Config File Specifics..................................................................................................... 8-26

The "Official" and "Actual" System Config Files ............................................................... 8-26

If the System Config File is Corrupt.................................................................................... 8-26

Descriptions of Some Statements in the System Config File .............................................. 8-27

Standard Config File Specifics .................................................................................................. 8-29

Introduction.......................................................................................................................... 8-29

The Board Config File ......................................................................................................... 8-29

Standard Config File Syntax Similarities to and Differences from the System Config File8-29

Statements Allowed in the Standard, System, and Board Config Files............................... 8-30

Statements Not Allowed in either the Standard or Board Config Files, but Are Allowed in the System Config

File .................................................................................................................................... 8-30

Descriptions of Some Statements in the Standard Config File............................................ 8-30

Compiling the System and Standard Config Files..................................................................... 8-35

The bootptab

File ..................................................................................................................... 8-36

Hardware Addresses ............................................................................................................ 8-36

IP Addresses ........................................................................................................................ 8-37

The hosts

File ........................................................................................................................... 8-38

Test Device Communication ............................................................................................... 8-38

Device Files ............................................................................................................................... 8-40

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) vii

Table of Contents

Introduction.......................................................................................................................... 8-40

Location of Device Files...................................................................................................... 8-40

If a DUT Power Supply is Replaced.................................................................................... 8-40

DUT Power Supply Device Files......................................................................................... 8-41

Vacuum Control......................................................................................................................... 8-42

Location of Vacuum Control Statements............................................................................. 8-42

Vacuum Control Specifics ................................................................................................... 8-42

Rotating the Testhead ................................................................................................................ 8-43

Testhead Cards........................................................................................................................... 8-44

If Replacing the ControlXT Card ........................................................................................ 8-44

System Card / Control Card LAN Information ................................................................... 8-44

DUT Power Supplies ................................................................................................................. 8-47

Voltage Ranges .................................................................................................................... 8-47

DUT Power Supplies Allowed ............................................................................................ 8-47

Module Mappings ................................................................................................................ 8-47

Controller Cables and Devices .................................................................................................. 8-52

For the Kayak XU700, use .................................................................................................. 8-52

For the Visualize P600, use ................................................................................................. 8-52

Testhead LAN and Serial Port MUX......................................................................................... 8-59

Testhead LAN IP Address ................................................................................................... 8-59

Serial Port MUX .................................................................................................................. 8-59

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows® NT and 2000) viii

1111

Introduction

In this Chapter...

■

Summary of System Administration Tasks , 1-2

■

3070 Software Overview , 1-3

■

3070 Hardware Overview , 1-8

About This Manual

Welcome to Administering Agilent 3070 Systems (MS

Windows NT and 2000) This manual contains information for administering 3070 board test systems running on MS Windows® 2000 Professional and NT operating systems.

Use this manual as a guide for performing general 3070 system administration tasks. This manual does not describe general NT system administration.

Who Should Use This Manual

This manual is intended for anyone who performs system administration for 3070 MS Windows® systems.

To perform the tasks described in this manual, you must have Administrator log in privileges on the systems you administer.

You should also have a basic working knowledge of MS

Windows® NT or 2000 operating systems and experience in system administration.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-1

Chapter 1: Introduction

Summary of System

Administration

Tasks

How Many Administrators are Necessary?

Ideally, a system should have one system administrator and a backup. It could be necessary to have one system administrator per shift.

Avoid maintenance conflicts by keeping as few system administrators as necessary.

Required Knowledge

Day-to-day tasks are required to keep a system running efficiently. Depending on the number of 3070 systems and the level of support needed, system administration can be either a part- or full-time job.

A 3070 system administrator should acquire basic knowledge of:

■ the 3070 system hardware.

■

■

■

■

■ the Agilent3070 directory structure and file system.

the 3070 program software.

the MS Windows® operating system.

the Windows directory structure and file system.

utilities for performing administration tasks, such as System Tools, Administrative Tools, and

Backup and Recovery Tools.

Responsibilities

The system administrator’s responsibilities include managing system installation, setup, configuration, networking, and security.

Be prepared to allow time for the training required to administer 3070 systems. Without adequate training, a system administrator has both the potential to solve problems and to make a system inoperable!

Administration Tasks

The system administrator routinely performs the following tasks:

■

■

■

■

Installs and configures computer systems.

Installs, configures, and connects computers to a network.

Manages users and user accounts.

Manages the file system and access permissions.

■

■

■

■

Performs incremental and full system backups.

Creates system recovery tapes (after installing software packages or changing the system’s configuration).

Recovers files from backups.

Installs and manages peripheral devices.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-2

Chapter 1: Introduction

3070 Software

Overview

This section contains:

■

Introduction , 1-3

■

Capabilities of the MS Windows® 2000 Professional

Operating System , 1-3

■

The Agilent 3070 Directory Structure , 1-4

■

Advantages of a LAN , 1-5

■

3070 Program Software , 1-5

Introduction

XU700 testhead controllers are shipped with:

■

■

The MS Windows® 2000 Professional operating system.

LAN networking software.

■

3070 applications and programming software that includes languages for board test development and quality reporting.

Optional software features are available. For more information, contact your Agilent sales representative.

Capabilities of the MS Windows® 2000

Professional Operating System

■

File and resource sharing – With a LAN, you can share files, disk resources, applications,

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000)

■

■ computer systems, and peripheral devices over a network.

Multi-tasking – Several programs, processes, and tasks can be performed at the same time.

System Administration Utilities – MS

Windows® 2000 Professional provides a set of

System Tools and Administrative Tools to simplify system administration tasks.

NOTE

The 3070 MS Windows® system permits only single-user log on access to a testhead. Concurrent multi-user log ons are not supported by the operating system.

1-3

Chapter 1: Introduction

The Agilent 3070 Directory Structure

Table 1-1 describes the Agilent 3070 directories located

under the <value in

$AGILENT3070_ROOT

>.

Table 1-1 Agilent3070 directories

Directory: autofile bin boards contrib dev diagnostics documentation etc help home lib library log qm

Directory Contents or Use

System autofiles

3070 system executable programs

Location for customer board directories.

User-contributed software (redistributed by Agilent)

Device files and drivers used by the 3070 software

Test head configuration information and diagnostic programs

3070 user and service documentation

Miscellaneous files

Help information

Default location for the user's home directories

3070 executable libraries

Device libraries for board development

Log data

Quality statistics and files used by Agilent Pushbutton Q-Stats

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-4

Chapter 1: Introduction

Table 1-1 Agilent3070 directories (continued)

Directory: standard tmp util

$NUTCROOT\usr\lib\X11\ app-defaults\3070

Directory Contents or Use

Standard 3070 templates used throughout the system.

Where 3070 software stores temporary files/logs.

Utility files

The directory containing X resource files for X applications.

$NUTCROOT is a system variable set during installation of the NutCracker runtime environment. It contains the MKS Toolkit and Korn shell.

CAUTION

✸ NO NOT edit any files in these directories; they are not customer-editable.

Advantages of a LAN

Connecting 3070 systems together on a common LAN allows users to share peripherals and access files remotely. Programmers can edit testplans remotely from their local system without physically transporting the data. Without networking, a testplan file might have to be transferred via tape, then loaded onto the local system for editing.

Centralized storage of applications, testplans, and board data can reduce software maintenance costs and can maximize the integrity of the 3070 software. It can also simplify the process of revision and backup control.

3070 Program Software

Files and Directories

3070 systems come with directories, files, and utilities that are not a part of the MS Windows® operating system.

Test Programming Languages

The 3070 supports several test programming languages to develop board tests, including:

■

Board Test BASIC (BT-BASIC) is a set of fundamental BASIC statements with many

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-5

Chapter 1: Introduction

■

■ additional test-oriented statements. BT-BASIC testplans are used to control and manipulate the board test system and to run tests on the circuit boards.

Analog Test Language (ATL) is a set of special statements used to make in-circuit measurements on analog devices.

Vector Control Language (VCL) is a set of statements used to write tests for individual digital devices (in-circuit testing).

Quality Reporting Software

The 3070 program software includes a datalogging feature and Pushbutton Q-STATS Quality Management

Software for reporting board test results.

Datalogging automatically gathers test data on circuit boards, including board identification, failing component information, and measurement data on selected components. The logged information is stored in files used by Pushbutton Q-STATS, that generates informative reports which can be used to analyze board production processes.

Table 1-2 Standard 3070 Programs

Program

BT-BASIC

Board Consultant

Fixture Consultant

Use

Programming environment for editing and manipulating test programs.

Data entry tool for defining, viewing, and editing board, device, and topology information.

Graphical interface for viewing and editing fixture attributes such as wiring, probe locations, board placement, and fixture electronics.

IPG Test Consultant

Part Description Editor Graphical interface for defining electrical parts internal to higher level packages such as MCMs or resistor packs.

Pushbutton Debug

Pushbutton Q-Stats

Tool to develop and generate board test programs. Automatically generates test programs and files based on board description and attributes.

Graphical interface for debugging and modifying test programs.

Quality management software for analyzing and evaluating test quality. Provides failure pareto charts, histograms, and production summaries.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-6

Chapter 1: Introduction

Table 1-2 Standard 3070 Programs (continued)

Program

Boundary-Scan

Conversion Tool

Use

Graphical interface for testing digital devices that comply with IEEE Standard 1149.1.

Korn Shell

SetUp Editor

Adobe Acrobat

BootP Server NT

Tool for converting board test programs and directories for cross-platform compatibility between

HP-UX and MS Windows operating systems.

Shell environment for executing UNIX commands on MS Windows operating systems.

Graphical interface for setting up and creating library tests.

Program for viewing, navigating, and printing PDF documents, including 3070 Documentation.

Program for controlling the allocation of IP addresses on the Windows NT platform.

SCO XVision X windows environment.

TapeWare Administrator Utility for backing up, restoring, and recovering files and system.

Internet Explorer

WinZip

Internet browser.

Utility for compressing and extracting files in ZIP format.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-7

Chapter 1: Introduction

3070 Hardware

Overview

This section provides an overview of 3070 test system hardware.

A complete test system includes a testhead and a testhead controller.

Testhead

The testhead contains hardware required to execute board tests.

Testhead Controller

The testhead controller is a computer that controls the testhead. It is located in a testhead pod.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 1-8

2222

Starting and Shutting Down the System

In this Chapter...

■

Starting the System , 2-2

■

Shutting Down the System , 2-4

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 2-1

Chapter 2: Starting and Shutting Down the System

Starting the System

This section describes how to start and boot a 3070 MS

Windows® controller and testhead.

■

Booting a 3070 Controller , 2-2

■

Logging In , 2-3

■

Booting the Testhead , 2-3

Prerequisites

Before beginning, your Agilent 3070 system must be installed and set up correctly by an Agilent CE or SE.

Required Tools and Materials

■

■

Windows® 2000 Professional Quick Start Guide

A 3070 Testhead with Windows® 2000

Professional and software revision 3070 04.00pb

0501 WN or later.

Booting a 3070 Controller

1 Turn on the video display and any other peripherals.

2 Turn on power to the controller.

3 Allow the controller to boot.

During the boot process, the system:

■ tests and initializes hardware components.

■

■ loads the operating system.

starts log on and other system services.

Read the messages displayed on the video monitor.

These messages could be important in solving system administration problems.

The controller boot process is complete when the Log on

to Windows screen appears.

ADVICE

The first time you start your system, you will need to enter information in the Windows 2000 Setup

Wizard. Follow the on-screen instructions and refer to the Windows® 2000 Professional Quick

Start Guide.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 2-2

Chapter 2: Starting and Shutting Down the System

Logging In

Several types of logins exist for the 3070. Some logins can be created or changed by the system administrator

(see

Adding a User Account in Chapter 5) and some

are for specialized use and cannot be changed.

Logins that cannot be changed include:

■ operator

— For standard operator use.

■

■ oil

— For operators using a localized operator interface which is converted to another language

(“oil” stands for “operator interface localization).

service3070

— For troubleshooting hardware problems.

Booting the Testhead

1 Log in as operator

2 Boot the testhead using the Testhead Power On softkey.

Booting takes about 2 to 5 minutes, depending on the number of testhead modules in your 3070 system.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 2-3

Chapter 2: Starting and Shutting Down the System

Shutting Down the

System

This section contains:

■

Introduction , 2-4

■

Unboot the Testhead , 2-4

■

Shut Down the Controller , 2-4

■

Disconnecting Power to the Controller , 2-4

CAUTION

✸ Unboot the testhead before shutting down the controller to prevent damage to the software.

Introduction

Shutdown a system before:

■

Removing power to perform tasks such as installing a new disk or interface card.

Unboot the Testhead

■

At the prompt in the BT-BASIC window controlling the testhead, enter: testhead power off

Shut Down the Controller

CAUTION

✸ Always shut down the computer before turning off the power. It is not safe to turn off the power until

Windows displays the following message: It is

now safe to turn off your computer. Interrupting the power without shutting down can damage the software or hard disk.

Use one of the following methods to shut down:

■

Select Shut Down from the Start menu.

■

Press CTRL-ALT-DELETE, click Shut Down, then select Shut Down in the What do you want the

computer to do? list, and click OK.

Disconnecting Power to the Controller

CAUTION

✸ Perform this step only after following the above instructions to shut down the controller.

Otherwise, software damage can occur.

■

Push the power switch on the controller.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 2-4

3333

In this Chapter...

Setting Up and Configuring New Systems

■

Preparing to Set Up a System , 3-2

■

Information for Windows 2000 Setup , 3-3

■

Setting Up Windows 2000 Professional , 3-5

■

Additional Setup Tasks , 3-6

■

Gathering Network Configuration Information , 3-8

■

Network Components , 3-12

■

Agilent Software License Activation , 3-13

■

Software License Activation Troubleshooting , 3-17

■

Configuring a Network Adapter Card (Local Area

Connection) , 3-18

Objectives

After completing this chapter, you should be able to:

■

Set up your system for Windows® 2000

Professional

■

■

Gather information for network configuration.

Connect and configure a 3070 MS Windows® system to a LAN.

Prerequisites

■

Experience administering NT® or MS Windows® operating systems.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000)

E9970-90000 Rev. G 06/2003

3-1

Chapter 3: Setting Up and Configuring New Systems

Preparing to Set Up a System

Setting up a system involves establishing a computer name, user account, and both Administrator and user passwords. Use the Windows 2000 Setup Wizard to set up your system.

If you plan to connect your computer to a network, you must configure the appropriate Local Area Connections in Network and Dial-up Connections before connecting to your network.

After configuring Network and Dial-up Connections, use the Network Identification Wizard and follow the on-screen instructions to ensure that your system is recognized by your network.

Use this chapter to gather configuration information from the network administrator. Then, use this information to complete the tasks in the Setup and

Network Identification Wizards.

NOTE

If you have a new test system that includes a testhead, an Agilent customer engineer (CE) or system engineer (SE) should be involved in the set-up.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-2

Chapter 3: Setting Up and Configuring New Systems

Information for

Windows 2000

Setup

The first time you start your system, the Windows 2000

Setup Wizard requests information to set up your computer.

Table 3-1 summarizes the information you

may need to complete the Setup Wizard.

Table 3-1 Setup Information

Information

Product Key

Description

A 25-character key that uniquely identifies your copy of Windows 2000

Professional.

NOTE

Agilent sets up product key information when you purchase a complete 3070 system.

Computer Name A unique name that identifies your computer system on a network.

Administrator Password A password that provides access to the Administrator account for your computer with full permissions and control.

Setup Wizard Tasks

The Setup Wizard helps you complete these tasks:

■

■

■

■

Accept or customize Regional Settings.

Enter your Name and Organization.

Enter your Computer name and Administrator password.

Change the Date/Time settings and time zone.

Table 3-2 on page 3-5 describes how to set up MS

Windows® 2000 Professional using the Setup Wizard.

NOTE

For instructions on setting up your system, logging on, and setting up user accounts, see the

Windows® 2000 Professional Quick Start Guide.

CAUTION

✸ Some customers change Regional Options on the controller to set Your locale to their geographic location. Is is alright to do this as long as you don’t change Decimal symbol. The Decimal symbol must remain a period (.); it cannot be changed to a comma (,) or Board Consultant will break testplans.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-3

Chapter 3: Setting Up and Configuring New Systems

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-4

Chapter 3: Setting Up and Configuring New Systems

Setting Up Windows

2000 Professional

Follow the procedure in

Table 3-2

to setup your

Controller for Windows® 2000 Professional.

Table 3-2 Setup Windows® 2000 Professional

Task

1 Verify:

2 Turn on power to the controller.

3 Complete the Windows

2000 Setup Wizard tasks.

ADVICE

To change the

Administrator password: Point to

Settings > Control

Panel > Users and

Passwords, choose

Administrator from the

User Name list, then press Ctrl+Alt+Del and select Change

Password.

Step

• All cable connections to the controller.

a Read the Welcome screen, then click Next.

b Accept or customize Regional Settings, then click Next.

c You can change the Regional Settings for numbers, currency, time, date, locale, and keyboard layout.

d Type your Name and the name of your Organization, then click Next.

e Type your Computer name and Administrator password, then click Next.

This Administrator password is associated with the Administrator account that is local to your computer. This account and password provide full control of your computer. Do not forget this password.

f Set the correct Date & Time and Time Zone, then click Next.

g Click Finish.

The Setup Wizard will restart your computer and apply the new settings.

Congratulations! You have configured the Windows controller for startup.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-5

Chapter 3: Setting Up and Configuring New Systems

Additional Setup

Tasks

The tasks in

Table 3-3 should be completed before the

system is ready for users.

Table 3-3 Additional setup tasks

Task

1 Enter codewords to enable optional software features if necessary:

Step

Agilent 3070 test development systems support standard and optional software features that are licensed with Software Certificates. Optional software features are enabled by entering unique codewords found on Software Certificates.

CAUTION

✸ You must have a license to add codewords that enable optional software features.

Instructions for installing codewords are included with the software license included with the shipment or the optional software. Enter the codeword(s) exactly as appearing on the license.

Also see the document Installing Codewords on a 3070 (E1040-90000).

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-6

Chapter 3: Setting Up and Configuring New Systems

Table 3-3 Additional setup tasks

Task

2 Create a system recovery tape.

Step

It is very important to make a full back up tape that can be used to recover your system in case of a disaster such as a disk crash. For instructions, see

Making a Full

Backup Tape on page 4-9.

Re-establish the bootptab

and system config

files from backup files. If these files were not backed up, contact your Agilent systems engineer.

3 Ensure that the

Administrator password is not lost or forgotten.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-7

Chapter 3: Setting Up and Configuring New Systems

Gathering Network

Configuration

Information

Use this section to gather the information needed to configure your computer for a LAN.

Gather the Network Configuration Information

Complete the information in Table 3-4

with the assistance of the network administrator or LAN manager.

Table 3-4 Windows NT LAN configuration information

Task (Network Parameter)

1 Network Identification

■

Computer Name, or

■

Hostname

2 Network Identification

■

Workgroup or Domain?

Write System Information Here Description

Domain Computer Name or

Hostname:

A unique name that identifies your computer controller.

Member of (select one):

[ ] Workgroup

[ ] Domain

The Workgroup name is the name of a computer or group of computers on a peer-to-peer network.

Workgroup or Domain name

The Domain name is the identifier for the server that controls and manages a group of computers on a client/server network.

3 Network Identification

■

Create a Computer Account in the

Domain

Domain User Name:

Domain Password:

This is the name by which your computer is recognized by the network domain.

See your network administrator to establish or verify domain account information.

4 Will a DHCP Server be Used?

[ ] Yes [ ] No If yes, go to

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000)

Task 16 ( Will Other Network Protocols Be Configured?

).

3-8

Chapter 3: Setting Up and Configuring New Systems

Table 3-4 Windows NT LAN configuration information (continued)

Task (Network Parameter)

5 IP Address

Write System Information Here Description

IP Address: The IP address for this workstation.

.

.

Subnet Mask:

.

.

.

Default Gateway:

.

.

.

.

This number masks (ignores) information that is not specific to your local network.

IP address of the system that is used to route network traffic to other networks.

6 Advanced IP Addressing

■

Gateways

.

.

.

.

.

.

[ ] Yes [ ] No

Gateway(s) for any backup routers of network traffic.

If no, go to

Task 12 ( Will WINS Be Used?

).

7 Will DNS be Used?

(Domain Name System)

8 DNS

■

Hostname

9 DNS

■

Domain

The name by which this system will be known under DNS is the same as the

Computer Name, or in Task 1 .

The domain in which this machine will operate. This domain is associated with your TCP/IP address.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-9

Chapter 3: Setting Up and Configuring New Systems

Table 3-4 Windows NT LAN configuration information (continued)

Task (Network Parameter)

10 DNS

■

DNS Service Search Order

Write System Information Here Description

.

.

.

IP Addresses (in order) of DNS servers that this system uses for resolving host names.

.

.

.

11 DNS

■

Domain Suffix Search Order

Ordered domain suffix list used when searching for a host.

12 Will WINS Be Used?

(Windows Internet Name Services)

13 WINS Address

■

■

Primary WINS Server

Secondary WINS Server

14 WINS Address

■

Checkboxes

[ ] Yes [ ] No If no, go to

Task 16 ( Will Other Network Protocols Be Configured?

).

.

.

.

.

.

.

[ ] Enable DNS for Windows

Resolution

[ ] Enable LMHOSTS Lookup

Check or uncheck either of these boxes as applicable.

CAUTION

✸ If configuring for DNS, check Enable DNS for Windows

Resolution.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-10

Chapter 3: Setting Up and Configuring New Systems

Table 3-4 Windows NT LAN configuration information (continued)

Task (Network Parameter)

15 WINS Address

■

Scope ID

16 Will Other Network Protocols Be

Configured?

Write System Information Here Description

[ ] AppleTalk Protocol This list is not exhaustive; other protocols can be configured. Use this space to document other network protocol information.

[ ] DLC Protocol

[ ] NetBEUI Protocol

[ ] NWLink IPX/SPX Compatible

Transport

[ ] Point To Point Tunneling

Protocol

[ ] Streams Environment

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-11

Chapter 3: Setting Up and Configuring New Systems

Network

Components

Making a network requires the following basic hardware, software, and connections:

■

Network interface cards (NICs), or adapter cards - used to connect a computer to a file servers or workstations.

■

■

Cables - used to connect the nodes on a LAN.

Physical topology - the physical location of all computers on the network and the cabling system that connects them.

■

■

■

Servers - the computer that manages and controls network resources.

Network Operating System - Windows® 2000

Professional is the supported operating system for your 3070 MS Windows® system.

Network-based software - programs that are accessed over the network. May include e-mail programs or standard software applications.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-12

Chapter 3: Setting Up and Configuring New Systems

Agilent Software

License Activation

Codeword and License Management

Agilent will begin issuing license keys to replace the current codeword scheme for new 3070 features starting with software release 05.20p. At present, only new features will require the license key. This is the first step in a process that will eventually replace all Agilent 3070 codewords with license keys in future software releases.

Required Tools and Materials

Before you contact Agilent to activate your software license key, you will need the following:

■

■

■

■

■

Agilent 3070 software revision 05.20p or newer, entitlement certificate which contains the order number and certificate number, hardware (MAC) address of the target controller or test development station which will utilize the software activation key,

Agilent serial number from your controller (if the controller was not supplied by Agilent, use the controller manufacturer's serial number), internet connection

*

.

You will receive an Entitlement Certificate with a new system or when new features are purchased. You will need the information on the Entitlement Certificate to redeem your license activation key on upgrades, new features, or for recovery.

NOTE

New systems shipped from the factory will have the software license keys installed and activated.

The Software Entitlement Certificate evidences Agilent

Technologies' grant of the right to use the software products listed on the certificate. Please refer to your

Software License and Software License Redemption

Certificate for information regarding Agilent’s Software

Terms and Conditions of Use.

Each license redeemed from this certificate authorizes the use of the software product on one system controller or one test development system.

NOTE

The Entitlement Certificate is an important document - you will need to keep it for your records. You will need it to activate or recover your software licenses.

* If you cannot access the internet, call the Agilent Customer Support Center at 1.800.447.8378 for assistance.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-13

Chapter 3: Setting Up and Configuring New Systems

Figure 3-1 Software License Activation Process Flow Diagram

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-14

Chapter 3: Setting Up and Configuring New Systems

Redeeming your Software License

To redeem your software license, perform these steps:

1 Acquire the target controller or test development system’s hardware (MAC) address.

a Login to the 3070 controller or test development system as administrator. This must be the system where you intend to activate the license,

b Open a korn shell window and type lmhostid

-ether

. Hit Return,

c This command will return the hardware or MAC address for the targeted system. Write down and save the 12-character string that is displayed after

The FLEXlm host ID of this machine is:

You will need this string in step 2e.

NOTE

The MAC Address (Media Access Control) is a hardware address that uniquely identifies each node of a network. Agilent Software Licensing takes the MAC address and locks the Software

License Key to the targeted system controller or test development system.

2 Redeem the software entitlement certificate and receive your license activation key.

a From any computer with internet access, log onto the Agilent Software Licensing website at www.agilent.com/find/softwarelicense

.

Follow the instructions on the website to redeem your license. This website has excellent online help to assist you with redemption of your software license.

NOTE

If you do not have Internet access or cannot contact Agilent through this website, contact the

Agilent Customer Support Center at

1.800.447.8378 for assistance.

b In the space provided, enter the Order Number from the Entitlement Certificate,

c In the space provided, enter the Entitlement

Certificate number. Hit Enter or select

Search

.

d The next window will provide you with three options. Select option

I. Request license(s) for one or more software products on one instrument or host computer

. The next window will display your order number and software certificate at the top of the page.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-15

Chapter 3: Setting Up and Configuring New Systems

e Follow the instructions listed below the certification number. Where it says

Enter Node

ID

, type the 12-character hardware (MAC) address for the target system which you recorded in Step 1c.

f Enter the Agilent serial number from your controller (if the controller was not supplied by

Agilent, use the controller manufacturer's serial number

g In the space provided, enter an email address where you can retrieve the license file. You will receive the license file via this email address from [email protected]. The email will contain a message with instructions for installing the license file onto the 3070.

You may also view the license with your internet browser. Return to the main screen and select option

III: Get previously issued licenses for this order.

Software License Activation

3 Activate your Software License Key

a Open the email and save the attachment license key in the $AGILENT3070_ROOT/lib directory on your 3070 controller or test development computer.

b Rename the license file attachment using a unique name. For example you could use a date-name format like agilent3070_

<date>.lic

, where

<date>

is the

YYYYMMDDHHMM

(YYYY is the year,

MM is the month; DD is the day and HHMM is the current time. Change the file extension to

.lic

.

NOTE

Ensure the License File ends with a

.lic

file name extension. If the file does not have a

.lic

extension, manually change it to

.lic

.

Validate Software License Key

1 Run the 3070 Software License Validation

Application by typing licenseValidation.ksh in a korn shell window. Hit return.

2 Select the Test License button. License file entries that have valid data are shown in green font. Invalid license file entries are highlighted in red font.

3 Select the

Close

button or select to exit the 3070

Software License Validation application.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-16

Chapter 3: Setting Up and Configuring New Systems

Software License

Activation

Troubleshooting

If for some reason you can no longer use the license key after activation, use the following recovery process.

Loss of the software key may be due to:

■

■ hardware modification or replacement including controller, hard drive, LAN card, etc.

inadvertent license file deletion,

1 Locate your software entitlement certificate and reconfirm your license activation key.

a From any computer with internet access, log onto the Agilent Software Licensing website at www.agilent.com/find/softwarelicense

.

Follow the instructions on the website to redeem your license.

NOTE

If you do not have Internet access or cannot contact Agilent through this website, call your local Agilent representative or call the Agilent

Customer Support Center at 1.800.447.8378 for assistance.

b In the space provided, enter the Order Number from the Entitlement Certificate for the feature you wish to reactivate.

NOTE

If you do not have the entitlement certificate and order number, you will not be able to retrieve your software activation key through the Agilent

Software Licensing website. You will need to call the Agilent Customer Support Center at

1.800.447.8378 for assistance.

c Enter the Entitlement Certificate number in the space provided. Hit Enter or select

Search

.

d Select option III Get previously-issued licenses for this order number

.

e Right click on the file listed and choose

Save

Target As to retrieve the license file,

f save the license key file in the

$AGILENT3070_ROOT/lib directory on your

3070 controller or test development computer.

NOTE

This process will only work for the same MAC address to which the original license was submitted. If no license history is found or you cannot locate your entitlement certificate, contact your local Agilent representative or call the

Agilent Customer Support Center at

1.800.447.8378 for assistance.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-17

Chapter 3: Setting Up and Configuring New Systems

Configuring a

Network Adapter

Card (Local Area

Connection)

A 3070 MS Windows® system includes two network adapter cards: a 3Com Etherlink XL 10/100 PCI and a

Realtek RTL8139(A)-based Fast Ethernet Adapter.

Agilent configures the Local Area Connection for the

3Com Etherlink XL 10/100 PCI to connect only to the testhead. Never change these settings.

The Local Area Connection for the Realtek

RTL8139(A)-based Fast Ethernet Adapter can be configured and connected to your site network. Contact your network administrator for assistance in configuring adapter cards and connecting to a site network.

Table 3-5

describes how to configure a network adapter card (Local Area Connection 2).

ADVICE

Gather the networking configuration information

in Table 3-4 before performing the procedure in

Table 3-5 .

Table 3-5 Configuring and Connecting a Local Area Connection

Task

1 Open the Network and Dial-up

Connections window.

2 Display the Local

Area Connection 2

Properties.

Step

a On the Desktop, right-click My Network Places.

b Click Properties.

a Right-click Local Area Connection 2,

b Click Properties.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-18

Chapter 3: Setting Up and Configuring New Systems

Table 3-5 Configuring and Connecting a Local Area Connection (continued)

Task

3 Verify that the list of

Components checked are used by this connection: includes:

Step

• Client for Microsoft Networks

• File and Printer Sharing for Microsoft Networks

• NetBEUI Protocol (optional)

• Internet Protocol (TCP/IP)

NOTE

The Internet Protocol (TCP/IP) is required by the testhead controller.

4 Specify IP

Addresses.

5 Specify DNS server addresses.

a Select Internet Protocol (TCP/IP), then click Properties.

b Click Obtain an IP address automatically. Use this step if your domain server supports

DHCP.

If DHCP is not supported, manually enter IP address information:

Click Use the following IP address, then type the IP address, Subnet mask, and

Default gateway numbers.

a Select Obtain DNS server address automatically, or

b Click Use the following DNS server addresses: and type the Preferred DNS server and an Alternate DNS server.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-19

Chapter 3: Setting Up and Configuring New Systems

Table 3-5 Configuring and Connecting a Local Area Connection (continued)

Task

6 Add or edit configuration information.

ADVICE

Contact your IT department for configuration information and assistance.

Step

Click Advanced to add or edit:

• IP addresses

• Gateways

• DNS server addresses

• WINS addresses

• or to specify security options.

7 Accept the configuration.

8 Connect the LAN cable.

• Click OK.

• Agilent provides an RJ45 LAN cable. Physically connect the LAN cable to your network connection.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-20

Chapter 3: Setting Up and Configuring New Systems

Table 3-5 Configuring and Connecting a Local Area Connection (continued)

Task

9 Run the Network

Identification

Wizard.

Step

a Right-click My Computer, then click Properties.

b Click the Network Identification tab in the System Properties dialog box, then click

Network ID.

c Enter the appropriate information in the Network Identification Wizard. This wizard identifies your computer to the network. Be prepared to enter the following information, as needed:

■

■

Is this computer part of a network?

What kind of network? (domain or workgroup?)

■

■

■

User name

Password

User account domain

Computer name

■

■

Computer domain

Workgroup name

■

10 Reboot the system.

After rebooting, verify the network connection. Contact your network administrator if you experience problems.

© Agilent Technologies 2002, 2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 3-21

4444

Backing Up and Restoring System Software

In this Chapter...

■

Planning a Backup Strategy , 4-3

■

Preparing for Disaster Recovery , 4-4

■

Creating Boot Recovery Diskettes , 4-6

■

Making a Full Backup Tape , 4-9

■

Restoring Selected Data from a Backup Tape , 4-14

■

Restoring a 3070 System from a Full Backup Tape ,

4-19

■

Restoring a 3070 System from the System Recovery

DVD , 4-28

NOTE

If you need to recover data and already have boot recovery diskettes, and a full backup tape go to:

•

Restoring Selected Data from a Backup

Tape on page 4-14 or

•

Restoring a 3070 System from a Full Backup

Tape on page 4-19

Introduction

A disaster recovery plan, and backup disks and tape(s) are necessary to protect your system and data against hardware failures, corrupted data, or accidental deletion of files. Your 3070 system includes TapeWare software with Backup, Restore, and Disaster Recovery tools.

Objectives

After reading this chapter, you should be able to:

■

■

■

■

■

Create a backup strategy.

Create boot Recovery Diskettes.

Create a Full backup tape.

Restore selected data from a backup tape.

Boot your system from Recovery Diskettes and use a full backup tape to restore system software and data.

Prerequisites

■

■

Experience administering Windows systems.

Administrator log on privileges.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-1

Chapter 4: Backing Up and Restoring System Software

Required Tools and Materials

■

■

■

TapeWare software with Disaster Recovery.

An HP SureStore DAT 24 tape drive or compatible DDS storage device.

Four (4) blank 3.5” diskettes and 24Gb blank tape

(Included with the system.)

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-2

Chapter 4: Backing Up and Restoring System Software

Planning a Backup

Strategy

Data is sometimes lost when a user accidentally deletes or overwrites a file, or misuses a command. Also, a power failure or hard disk crash can result in lost or corrupted data. Data can be restored if you use effective backup procedures.

One of the most important responsibilities of the system administrator is to implement an effective backup strategy. The backup strategy you use to protect from data loss depends on a number of variables:

■

■

How frequently is the system used?

How often does the data change?

■

How critical is it that files can be restored quickly?

One typical three-tiered backup strategy follows:

1 Make a new set of boot Recovery Diskettes for booting your system periodically, as magnetic media can deteriorate. Also, create a new set every time you:

■

■

■

■ install new software or update existing software or operating system. add or remove users.

change logical volumes in any way.

change the Windows Administrator password.

For instructions, see

Diskettes on page 4-6.

2 Create a full system backup once each week.

NOTE

Creating Boot Recovery

You can recover individual files from a full or partial backup tape.

For instructions, see

Making a Full Backup Tape on page 4-9.

3 Create an incremental backup once each day.

Incremental backups are faster to create than full backups, and they require less backup media.

However, recovering a system may require several backup tapes: the full backup, in addition to multiple incremental backups.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-3

Chapter 4: Backing Up and Restoring System Software

Preparing for

Disaster Recovery

If you have an Industrial PC, see

Disaster Recovery for an Industrial PC Controller

If your system fails, it is important to be prepared for disaster recovery. To recover your 3070 operating system, application software, and files, you need:

■

■

A DDS tape drive connected to your 3070 controller.

TapeWare software with Disaster Recovery.

■

■

The boot diskettes you will create or have created by following procedure described in

Creating

Boot Recovery Diskettes on page 4-6.

A full backup tape, preferably very recently

created. See Making a Full Backup Tape on page 4-9.

WARNING

✸ You must create full backup tapes regularly to prepare for disaster recovery. If you do not have a recent full backup tape, you may lose important data in the event of a disk failure.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-4

Chapter 4: Backing Up and Restoring System Software

Disaster Recovery for an Industrial PC

Controller

This information applies to 3070 systems with Industrial

PC (IPC) controllers with DVD drives.

Backup vs. Disaster Recovery

Backup is the copying of files (board directories) to a removable media or network. Disaster recovery is the process of restoring the system to operational readiness after a major catastrophe like a hard disk failure.

For backup you can use File Explorer for copying to a network device, or HP RECORD NOW to copy the files to a removable media like CD or DVD. These files can then be copied back to the hard drive as needed.

Disaster Recovery Solution

Provided for your 3070 system, is a separate software package called PowerQuest Drive Image. This software allows you to:

■

■

Backup without leaving Windows

Backup to the DVD drive

■

Restore your entire system or individual files

Schedule automatic backups

■

Agilent recommends that you install this software and use it to make full backups of your hard drive.

This software is provided as a third-party software solution. Agilent is not responsible for support of this product. Refer to the support information in the documentation accompanying the PowerQuest product.

IN NO EVENT WILL AGILENT OR ITS SUPPLIERS BE

LIABLE FOR LOSS OF DATA OR FOR DIRECT,

SPECIAL, INCIDENTAL, CONSEQUENTIAL

(INCLUDING LOST PROFIT OR DATA), OR OTHER

DAMAGE WHETHER BASED IN CONTRACT, TORT,

OR OTHERWISE.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-5

Chapter 4: Backing Up and Restoring System Software

Creating Boot

Recovery Diskettes

Introduction

■

Your 3070 system includes a set of blank diskettes that should be used at the initial system setup to create boot disk Disaster Recovery diskettes.

When to Create Boot Recovery Diskettes.

Create a new set of boot Recovery Diskettes when you:

■ initially setup your 3070 controller.

■

■ update your operating system or software.

install new service packs.

■

■

■ add or remove hardware.

change the configuration of your disk drives.

add or remove disk drive volumes or partitions.

ADVICE

Always create two or more sets of boot Recovery

Diskettes, in case one set of disks becomes corrupted or unreadable.

Required Tools and Material

■

TapeWare- a program for backing up recovering, and restoring system data and files.

■

■

Disaster Recovery Wizard - a TapeWare application.

At least four blank formatted 3.5” floppy diskettes, depending on your system configuration.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-6

Chapter 4: Backing Up and Restoring System Software

How to Create Boot Recovery Diskettes

Table 4-1

describes how to create a set of boot

Recovery Diskettes.

Table 4-1 How to create boot Recovery Diskettes

Task

1 Log on as Windows

Administrator.

2 Start TapeWare.

3 Log on to TapeWare as

ADMIN.

4 Create new boot disk Recovery

Diskettes for booting and recovering your system.

Step

a Press Ctrl-Alt-Del to log on.

b The default User Name is Administrator. Click OK.

No password is necessary when you receive your 3070 system. After you establish an Administrator account, you must enter the password.

• Double-click the TapeWare Administrator icon on your desktop, or

• from the Start menu, point to Programs > TapeWare > TapeWare Adminis- trator.

a The default User Name is ADMIN.

b No password is necessary when you receive your 3070 system. After you establish ADMIN accounts, you must enter the Password, then click OK.

a Click Disaster Recovery from the TapeWare Wizard tab.

b Click Make Diskettes, then click OK in the Disaster Recovery window.

c Insert a formatted 3.5” inch disk into the floppy disk drive. The program copies data and prompts you to Insert new disk Recovery Diskette 2.

d Insert new disks, as prompted until you have created a complete set of

Recovery Diskettes.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-7

Chapter 4: Backing Up and Restoring System Software

Table 4-1 How to create boot Recovery Diskettes (continued)

Task

5 Label each boot Recovery

Diskettes.

Step

Include:

• A disk name and number (example: boot disk Recovery Diskette 1 of 4)

• The date created.

• The operating system revision.

• The computer system name.

6 Write protect each boot

Recovery Diskette and store in a secure location.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-8

Chapter 4: Backing Up and Restoring System Software

Making a Full

Backup Tape

Overview

Your 3070 system includes an HP SureStore DAT 24 tape device and TapeWare software for performing data backups. This section describes how to perform full data backups using the TapeWare Wizard and a system compatible DDS tape drive.

A full backup tape can be used to recover your operating system, application software, and data files. An effective disaster recovery policy involves creating full backup tapes on a regular basis.

Prerequisites

Before performing data backups, determine:

■

■ the device file of the storage device on which to create your backup. the disk drives, folders, and files to backup.

■

■ when the backup should occur.

the type of backup. Options include:

• Full - backup all selected drives, folders, and files.

• Incremental - backup only files that have changed since the last backup of any type: Full,

Incremental, Differential, or Snapshot.

• Differential - backup only files that have changed since the last Full backup.

• Snapshot - backup all selected drives, folders, and files without updating archive flags.

Required Tools and Materials

To perform the backup procedures described in this section, you need:

■

■

■

TapeWare software.

An HP SureStore DAT 24 tape drive or system compatible tape device.

A DDS tape with enough capacity to perform a full backup. 24 Gb or more is recommended.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-9

Chapter 4: Backing Up and Restoring System Software

How to Make a Full Backup Tape

Table 4-2

describes how to make a full backup tape using the TapeWare Wizard, which may be used for disaster recovery or restoring selected data.

Table 4-2 How to make a full backup tape

Task

1 Log on as Windows

Administrator.

2 Start TapeWare.

3 Log on to TapeWare as ADMIN.

4 Start and name backup job.

Step

a Press Ctrl-Alt-Del to log on.

b The default User Name is Administrator. Click OK.

No password is necessary when you receive your 3070 system. After you establish an Administrator account, you must enter the password.

• Double-click the TapeWare Administrator icon on your desktop, or

• From the Start menu, point to Programs > TapeWare > TapeWare Administrator.

a The default User Name is ADMIN.

No password is necessary when you receive your 3070 system. After you establish

ADMIN accounts, you must enter the Password, then click OK.

a Click Backup Local Machine in the TapeWare Wizard tab.

b Type a job name in the Wizard - Welcome window, then click Next.

ADVICE

Create a job name that is easy to identify, such as the computer or device name and the backup date.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-10

Chapter 4: Backing Up and Restoring System Software

Table 4-2 How to make a full backup tape (continued)

Task

5 Select a backup tape device.

Step

a Insert a blank DDS tape into a tape device that is connected to your system.

b Select a backup tape device in the Wizard - Where window, then click Next.

TapeWare will copy selected data to the tape in the selected device.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-11

Chapter 4: Backing Up and Restoring System Software

Table 4-2 How to make a full backup tape (continued)

Task

6 Select the type of backup to perform.

7 Select how data will be written to tape.

Step

• Click Full in the Wizard - How to Backup window, then click Next.

• Select Overwrite all tapes that are accessible in the Wizard - How to Write window.

NOTE

The default option is Append to any tapes that are accessible. If you are creating a backup tape to be used for disaster recovery, select the Overwrite option.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-12

Chapter 4: Backing Up and Restoring System Software

Table 4-2 How to make a full backup tape (continued)

Task

8 Choose a data verification option.

Step

• Select a verification option in the Wizard - How to Verify window. Full verify is recommended for a full backup. Then click Next. Options include:

No verify - Do not verify data.

Full verify - Verify data on tape matches exactly data on hard drive.

Quick verify - Verify data on tape is readable.

9 Specify when to run the backup job.

NOTE

Full verify compares all files on the backup media to the files on the server or workstation and ensures that they are identical. Any files that are not identical will be reported in error messages.

• Select Now in the Wizard - When to Run window, and then click Finish.

You can also save the job or schedule it to run later by selecting Save the job, but

don’t run it now or Later.

NOTE

It may take one hour or more to complete a full backup job. A Status of Backup

Local Machine window displays the job’s progress.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-13

Chapter 4: Backing Up and Restoring System Software

Restoring Selected

Data from a Backup

Tape

This section describes the procedures for restoring selected data from a backup tape using TapeWare’s

Restore Specific Wizard. Use this wizard to selectively restore data from individual drives, folders, or files.

For instructions on restoring an entire system, see

Restoring a 3070 System from a Full Backup Tape on page 4-19.

Restoring Specific Data

You can use a full or partial backup tape to selectively

restore data to your system. Table 4-3 on page 4-14

describes how to restore specific data from a backup tape.

Table 4-3 How to recover specific data from a backup tape

Task

1 Log on as Windows

Administrator.

2 Start TapeWare.

3 Log on to TapeWare as ADMIN.

Step

a Press Ctrl-Alt-Del to log on.

b The default User Name is Administrator. Click OK.

No password is necessary when you receive your 3070 system. After you establish an Administrator account, you must enter the password.

a Insert the backup tape into the tape drive. Use either a full or partial backup tape that contains the data you want to recover.

b Double-click the TapeWare Administrator icon on your desktop, or from the Start menu, point to Programs > TapeWare > TapeWare Administrator.

a The default User Name is ADMIN.

No password is necessary when you receive your 3070 system. After you establish

ADMIN accounts, you must enter the Password, then click OK.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-14

Chapter 4: Backing Up and Restoring System Software

Table 4-3 How to recover specific data from a backup tape (continued)

Task

4 Start the Restore

Specific program and name the job.

Step

a Select the TapeWare Wizard tab and click Restore Specific.

b Type a job name, then click Next.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-15

Chapter 4: Backing Up and Restoring System Software

Table 4-3 How to recover specific data from a backup tape (continued)

Task

5 Select what to restore.

Step

• Select the computer, drives, folders, or files that you want to restore in the Wizard-What to Restore window. Click in the checkboxes next to the device or folder names you want to select. Then click Next.

You can expand or collapse devices and folders to view the structure. A folder with a plus sign indicates it can be expanded to view more folders. A folder with a minus sign can be collapsed.

A check mark indicates an item has been selected. Selected data will be restored to its original location.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-16

Chapter 4: Backing Up and Restoring System Software

Table 4-3 How to recover specific data from a backup tape (continued)

Task

6 Choose a tape device from which to restore data.

Step

a Select the device or folder name that represents a tape device connected to your system. If necessary, expand or collapse devices and folders until you can view and select the desired device.

b Click Next.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-17

Chapter 4: Backing Up and Restoring System Software

Table 4-3 How to recover specific data from a backup tape (continued)

Task

7 Specify when to run the restore job.

Step

a Click Now, if you want to run the job immediately.

Click Save job, but don’t run it now to save the job to a file.

Click Later if you want to schedule the job to run later, and follow the onscreen instructions to specify when the job should run.

b Click Finish.

NOTE

TapeWare displays the status of the job in the Status of Restore Specific window.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-18

Chapter 4: Backing Up and Restoring System Software

Restoring a 3070

System from a Full

Backup Tape

Introduction

For instructions on restoring selected data, see

Restoring Selected Data from a Backup Tape on page 4-14.

Restore from full backup or a disaster recovery tape only if:

■

■

■ the operating system will not boot.

the main system disk drive fails.

the entire file structure is corrupted or lost.

CAUTION

✸ If you are restoring a system from a disaster recovery or full backup tape, TapeWare erases and reformats all disk drives, reinstalls the operating system, and overwrites the hard disk drives with data from the backup or disaster recovery tape.

NOTE

When you received your system you should have made recovery media by following the procedures in sections

Creating Boot Recovery Diskettes on page 4-6 and

Making a Full Backup Tape on page 4-9. If you did not do so, contact your

Agilent board test representative.

Prerequisites

The disaster recovery process requires:

■

■

Administrator log on privileges for your 3070

Windows system.

ADMIN log on privileges for TapeWare

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-19

Chapter 4: Backing Up and Restoring System Software

Required Tools and Materials

To restore your system after a system failure or disk crash, you will need:

■

■

■

■

TapeWare software with Disaster Recovery.

An HP SureStore DAT 24 tape drive or system compatible tape device.

A set of boot Recovery Diskettes created at system installation or later.

A full backup tape created at system installation or later or very recently.

Disaster Recovery Procedure

If the hard drive becomes corrupted so that the controller will not boot, you must boot from a set of boot Recovery Diskettes. Booting from Recovery

Diskettes starts TapeWare’s disaster recovery program.

The disaster recovery process involves using the boot

Recovery Diskettes:

■

■ to boot the MS Windows 2000 operating system. to start TapeWare’s disaster recovery program.

■ with a full backup tape to restore your system.

Use the boot Recovery Diskettes and a full backup tape to recover your 3070’s operating system, software applications, and files.

The boot Recovery Diskettes enable you to boot your system and run TapeWare’s disaster recovery program,

Recover.exe. This option should be used only as an emergency measure because it:

■

■

■ removes all the files from the hard drive.

reformats the hard drive.

re-installs MS Windows 2000 and 3070 software applications.

CAUTION

✸ All files on the drive to be recovered will be overwritten!

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-20

Chapter 4: Backing Up and Restoring System Software

You can use TapeWare to recover a boot disk or to recover all disk volumes and partitions.

Table 4-4

describes the disaster recovery options you can select when you boot your system from the boot Recovery

Diskettes. You must use both the boot recovery diskettes and a full backup tape to restore your system.

Table 4-4 TapeWare Disaster Recovery Options

Available Options

Recover Boot Disk

Description

Recover main boot disk. Recover all volumes and partitions from the boot disk.

Recover Entire System Recover entire system, including all volumes and disks.

Exit From Disaster

Recovery

Exit from disaster recovery procedure without recovering system or overwriting data on tape.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-21

Chapter 4: Backing Up and Restoring System Software

How to Restore a System From a Full Backup

Tape

Table 4-5

describes how to restore a 3070 system from boot recovery diskettes and a full backup tape.

NOTE

Use only a complete and recent full backup tape as a disaster recovery tape.

You can make other types of backups, such as

Incremental, Differential, or Snapshot. These types of backups can be used to a recover a partial system or individual files, but cannot be used to restore an entire system.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-22

Chapter 4: Backing Up and Restoring System Software

Table 4-5 How to restore a system from a disaster using boot recovery diskettes and full backup tape

Task

1 Boot from Recovery Diskette 1 and begin TapeWare Disaster Recovery

(Phase 2)

Recovery Diskette 1 contains

Recover.exe, the TapeWare application that initiates the Disaster Recovery process.

2 Insert the most recent full backup tape in the tape drive.

Step

a Insert Recovery Diskette 1 in your floppy drive.

b From the Start menu, choose Shutdown, select Restart and Click

Yes.

NOTE

If a full backup exists on multiple tapes, you must have all backup tapes to fully restore your system. NOTE

TapeWare restores your system by copying data from the disaster recovery tape to your system. The data is restored in its original location on the hard drive.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-23

Chapter 4: Backing Up and Restoring System Software

Table 4-5 How to restore a system from a disaster using boot recovery diskettes and full backup tape (continued)

Task

3 Choose a recovery option. Available options include:

■

■

■

Recover Boot Disk

Recover Entire System

Exit from Disaster Recovery

Step

WARNING

✸ Use this option to recover all hard disks on your system.

NOTE: All data on the drives to be recovered will be overwritten.

a Press the DOWN ARROW key to select Recover Entire System from the Available Options box, then press Enter.

NOTE

If you have placed board files on another disk drive, and you suspect that only your boot disk is corrupted or you have had to replace the boot disk, you may attempt to recover the boot disk only. This will leave all data on other disks intact.

However, this may cause data to be overwritten on other disks as well. It is recommended that you select Recover Entire

System.

b Several messages appear on screen. Read each screen and press

Enter to continue.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-24

Chapter 4: Backing Up and Restoring System Software

Table 4-5 How to restore a system from a disaster using boot recovery diskettes and full backup tape (continued)

Task

4 Overwrite existing partitions on the hard disk drive.

WARNING

✸ This option overwrites all disk volumes and partitions with the data from the disaster recovery tape or backup tape.

Step

a Press F10 to overwrite existing partitions, or

Press ESC to return to the main menu without recovering the system or its volumes.

b Press the UP ARROW key to choose Yes, Recover the Entire

System and press Enter.

To return to the main menu, use the arrow keys to select No, go

back and press Enter.

c This message appears: THIS IS YOUR LAST CHANCE, ARE YOU

SURE? If you want to recover your entire system and all its volumes, select Yes, Perform the Recovery, then press Enter.

To exit and return to the main menu, select No, go back and press

Enter.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-25

Chapter 4: Backing Up and Restoring System Software

Table 4-5 How to restore a system from a disaster using boot recovery diskettes and full backup tape (continued)

Task

5 Insert the remaining Recovery Diskettes when prompted.

Step

NOTE

Your system may automatically reboot several times after the restart process.

NOTE

After completing these steps, it takes approximately 30 minutes to one hour to restore your system.

a Insert Recovery Diskette 2, then press F10.

b When prompted, remove Recovery Diskette 2 and insert

Recovery Diskette 3, then press F10.

c When prompted, remove Recovery Diskette 3 and insert

Recovery Diskette 4, then press F10.

d Remove Recovery Diskette 4.

e Press F10 to reboot (restart) your system.

NOTE

When the system reboots, the disaster recovery software should initialize and the recovery tape should begin to load.

The system may stop responding while displaying the message

Deinitializing System Support

. If this occurs, press the reset button to reboot the system. After the system reboots, the disaster recovery process will continue and the tape should begin to load.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-26

Chapter 4: Backing Up and Restoring System Software

Table 4-5 How to restore a system from a disaster using boot recovery diskettes and full backup tape (continued)

Task Step

f If your backup data spans multiple tapes, click Yes in the Do you have any more tapes that you would like TapeWare to restore to

your system? window and insert additional backup tapes.

Otherwise, click No.

g Click Restart in the Recovery Complete window to restart your system.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-27

Chapter 4: Backing Up and Restoring System Software

Restoring a 3070

System from the

System Recovery

DVD

Introduction

This procedure describes how to install system recovery software on your Agilent 3070 system controller (MS

Windows®

*

system only).

Restore from the System Recovery DVD only if:

■

■

■

■ the operating system will not boot, and the main system disk drive fails, and the file structure is corrupted or lost, and the backup tape was never created or is corrupt.

Restoration takes about 10 minutes.

Required Materials

■

The System Recovery DVD (E9970-19415) that was shipped with your system.

CAUTION

✸ The System Recovery DVD is unique to each computer. The DVD case is labeled with the serial number of the computer for which it was created.

Using the wrong DVD for recovery may result in a defective system.

CAUTION

✸ Restoration from the System Recovery DVD will format the C: drive and reload it to a factory default state. You will not be able to boot the testhead because certain files which are unique to your system are not restored by this process.

Before doing this procedure, verify that you have a backup copy of these unique files:

■

■

■

■

\Agilent3070\diagnostics\th1\config

\Agilent3070\diagnostics\th1\config.o

\Agilent3070\lib\.enable

\Winnt\System32\drivers\etc\bootptab.

To restore these files after the recovery procedure, see Administering Agilent 3070 Systems (MS

Windows®). For restoring codewords, see

Installing Codewords on a 3070. For help, consult your Agilent systems engineer.

After system restoration, you must also reconfigure the IO for the GPIB Card. Follow the

System Recovery Procedure and IO Configuration

Procedure on page 29.

* Window®s and MS Windows® are U.S. registered trademarks of Microsoft Corporation.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-28

Chapter 4: Backing Up and Restoring System Software

System Recovery Procedure

6 Load the System Recovery DVD in your DVD-ROM drive.

7 Restart the computer. If necessary, press the reset button on the front of the computer.

8 At the Agilent 3070: prompt, type restore system

.

9 Press any key to scroll through the license agreement.

10 In the Power Quest screen, click Continue.

11 In the Warning message window, click Yes.

12 When the restoration is completed and you see the

Agilent 3070: prompt, remove the DVD from the drive.

13 Press CTRL-ALT-DEL to restart the computer.

IO Configuration Procedure

1 Log in as administrator

.

2 Right-click the blue IO icon on the right side of the

Taskbar and select Run IO Config.

3 In the Available Interface Types field, select 82350 PCI

GPIB (older controllers) or 82357 USB to GPIB (newer controllers) and click Configure.

4 In the SICL Interface Name field, ensure that hpib7 is selected, and click OK.

5 In the IO Config window, click OK.

6 In the Restart message window, click OK.

7 Restart the computer: click Start > Shutdown > select

Restart > click OK.

This concludes the recovery procedure. Now restore the

unique files listed on page 28.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 4-29

5555

Administration Tasks

In this chapter...

■

Overview of Administration Tasks , 5-2

■

Maintaining the File System , 5-3

■

Creating User Accounts , 5-4

■

About User Accounts , 5-5

■

User Rights , 5-6

■

Adding a User Account , 5-6

■

Adding a Group Account , 5-7

■

Administering Datalogging , 5-10

■

Installing Patches , 5-11

Objectives

When you finish reading this chapter, you should be able to:

■

■

■

Mantain the file system

Add users and groups

Know the 3070 users and groups shipped with the system.

Prerequisites

Before you begin using this chapter, you should already:

■

Know how to administer an MS Windows®

Workstation.

■

■

Know the MS Windows® Administrator login and password.

Have the 3070 hardware and software installed and configured.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000)

E9970-90000 Rev. G 06/2003

5-1

Chapter 5: Adminstration Tasks

Overview of

Administration

Tasks

This chapter describes system administration tasks as they relate to the 3070 applications. It does not describe general MS Windows® system administration. For information on any other MS Windows® administration tasks, refer to the MS Windows® documentation shipped with the system, both on line and hardcopy.

If you do not see a task listed in this section, you can assume that you do not need to have any 3070-specific information to perform the task.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-2

Chapter 5: Adminstration Tasks

Maintaining the File

System

Required Tools and Materials

To accomplish the tasks in this section, you will need:

■

■

Windows 2000 System Tools, such Disk

Defragmenter and Disk Cleanup.

Administrative Tools for other file management tasks.

File System Maintenance Tasks

The 3070 system uses the NTFS file system. NTFS is a

32-bit file system that supports security features and has the capability to address very large files.

Tasks you may need to perform regularly to maintain the file system are:

■

Check the disk for errors. Use Check Disk to fix file system errors and scan for and recover bad sectors.

To run Check Disk:

• From the Desktop, double-click My Computer.

Right-click the local disk you want to check and click Properties.

• Select the Tools tab. Click Check Now from the

Error checking box.

■

Periodically remove files from the following directories:

■

■

■

• C:\temp

• D:\temp

Use Disk Cleanup to delete temporary files,

Internet cache files, and unnecessary program files.

To run Disk Cleanup:

• From the Start menu, point to Programs >

Accessories > System Tools > Disk Cleanup.

Defragment the hard disk. Use Disk Defragmenter to ensure efficient file storage on your hard drive.

To run Disk Defragmenter:

• From the Start menu, point to Programs >

Accessories > System Tools > Disk

Defragmenter.

Use an antivirus program to detect and eliminate viruses.

Help

Windows 2000 provides extensive online help. To use

Help:

■

■

Choose Help from the Start menu, or

Press F1.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-3

Chapter 5: Adminstration Tasks

Creating User

Accounts

Authorized users gain access to an 3070 system by supplying a valid user name (login name) and

(optionally) a password.

File access permissions and group permissions determine who can access a given file on MS

Windows® systems.

Required Tools and Materials

To accomplish the tasks in this chapter, you will need:

■

Standard MS Windows® administration tools.

■

Standard 3070 Group and User Accounts

Groups

Groups are useful because files have permissions at the group level. If your users all belong to the same group, you can have several users, but still share restricted files. Always use one of the predefined 3070 groups when adding new users. You should not need additional groups to use the 3070 functionality. As shipped, your

3070 system is set up with the 3070 groups shown in

Table 5-1

.

Table 5-1 3070 group accounts

Group Name

Agilent3070Operators

Agilent3070Users

Definition and Permissions

The members of this group have access restricted to using BT-Basic. All 3070 operator accounts should be members of this group.

The members of this group have the same privileges as any other user account on the system.

Users

Users accounts are useful if you or your users need to know who creates and owns particular files. Also, you can restrict the environment of a particular user. As shipped, your 3070 system is set up with the 3070 users shown in

Table 5-2 .

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-4

Chapter 5: Adminstration Tasks

Table 5-2 3070 users

User Name operator oil user service3070 calibrate std3070

Definition and Permissions

The operator account, member of the

Agilent3070Operators

group. This user can run

BT-BASIC in operator mode, or you can create a localizable operator interface ( oil

). See the

3070 Online Help System for more information.

A generic user account, member of the

Agilent3070Users

group.

Member of the

Agilent3070Users

group. Use this account to run DGN and troubleshoot the testhead.

Member of the

Agilent3070Users

group. Use this account to calibrate the testhead.

This account is used only by Agilent. It is a member of the

Administrator

group, which is a standard NT group.

About User Accounts

Windows 2000 requires a valid user account to log on to a local computer system. A user account consists of a unique user name and password. The first time you start your computer, you must establish a user account using the Setup Wizard. User accounts can be added as needed.

On a client-server network, there are two types of user accounts: domain accounts and local accounts.

■

■

Domain accounts provide access to the network and its resources, based on defined user permissions.

Local accounts are valid only on a local computer system.

Group Accounts

Group accounts can be used to assign user rights and permissions to many users. You can create groups and assign users to one or more groups. Members of a group have all rights and permissions assigned to the group.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-5

Chapter 5: Adminstration Tasks

User Rights

User rights define the actions a user can perform on a computer. Rights can be assigned to both users and groups. By carefully planning and assigning user and group rights, you can provide secure access to files.

Adding a User Account

Win 2000 System

1 Login as

Administrator

.

2 Click Start > Settings > Control Panel >

Administrative Tools > Computer Management.

3 In the left pane, double-click Local Users and Groups and click Users.

4 In the right pane, right-click and select New User...

5 Enter the User name:, Full name:, Description:,

Password: and Confirm Password: of the <new user> and click Create.

6 Close the New User window.

7 In the Computer Management window, right-click

the <new user> created in step 5

and select

Properties.

8 Click the Profile tab. Verify that Local Path is selected. In the Local path: field, enter:

<drive>:\Agilent3070\home\<new user>

and click OK.

9 If you are on a testhead controller, click the Member

Of tab and click Add. Select Agilent3070Users and click Add > OK. If you are on a test development workstation, this step is not applicable.

10 Close the Computer Management and Administrative

Tools windows.

11 Determine your home folder:

a Click Start > Settings > Control Panel > System >

Advanced > Environment Variables...

b Note the value of the variable

HOME

and close the

Environment Variables, System Properties, and

Control Panel windows.

12 Open Explore, navigate to the home folder, and copy the following files ...

■

■

■

■

.

hp3070

.motifbind

ex.rc

profile.ksh

... to the <new user> folder created in

step 5

.

13 Close Explore.

Win NT System

Only test development workstations are supported on

Windows NT systems; testhead controllers are not supported.

1 Login as

Administrator

.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-6

Chapter 5: Adminstration Tasks

2 Click Start > Programs > Administrative Tools

(Common) > User Manager > User > New User.

3 Enter the Username:, Full Name:, Description:,

Password:, and Confirm Password: of the <new user> and click OK.

4 In the User Manager window, click <new user> >

User > Properties > Profile.

5 Verify that Local Path is selected, and in the Local

path: field, enter:

<drive>:\Agilent3070\home\<new user>.

OK

.

Click

6 Close the User Manager windows.

7 Determine your home folder:

a Click Start > Settings > Control Panel > System >

Environment.

b Note the value of the variable

HOME

and close the

System Properties dialog box.

8 Open Explore, navigate to the home folder, and copy the following files ...

■

■

■

■

.

hp3070

.motifbind

ex.rc

profile.ksh

... to the <new user> folder created in step 3

.

9 Close Explore.

Adding a Group Account

To add a group account, login as

Administrator

and:

1 Click Start > Settings > Control Panel >

Administrative Tools > Computer Management.

2 Double-click Local Users and Groups under System

Tools.

3 Right-click Groups and select New Group.

4 Type a Group name and Description.

5 Click Add to open the Select Users or Groups dialog box.

6 Select the local computer from the Look in list box.

7 Choose a name or group to add, and click Add for each user that you want to add to the group.

8 Click OK, and then click Create.

9 Click Close.

When you add a new 3070 user, keep in mind the following 3070-specific items:

■

When selecting the group the user belongs to, use one of the following predefined 3070 groups:

• Agilent3070Operators

• Agilent3070Users

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-7

Chapter 5: Adminstration Tasks

■

■

Make sure the user belongs to one or more of these groups to ensure proper access and security to 3070 features, applications, and files.

We recommend all users have a password for added system security.

The $AGILENT3070_ROOT system variable is set in system properties, so you do not need to set it for each user account.

Using the 3070 User Accounts Across a Domain

If you are logging into the 3070 using a domain user account, there are no differences EXCEPT if you are logging in as the operator

. Before anyone can use the operator

account across a domain successfully, you must copy the operator policy file to the Primary

Domain Controller (PDC). To do so:

1 Copy the operator’s policy file to the Primary

Domain Controller (PDC), which is the computer that authenticates user logins:

Copy:

%AGILENT3070_ROOT%\etc\OperatorProfile\Policy

\oper.pol

(on the 3070 Controller) to:

%SystemRoot%\System32\Repl\Import\Scripts\ope r.pol

(on the PDC)

The new directory location is also known as the

Netlogon share directory.

2 Merge the oper.pol

file into

Ntconfig.pol

.

3 Use regedit to modify the registry of the 3070 controller as follows: change the

HKEY_LOCAL_MACHINE\SYSTEM\

CurrentControlSet\Control\Update\

UpdateMode DWORD value from a hex 2 to a hex 1 remove

HKEY_LOCAL_MACHINE\SYSTEM\

CurrentControlSet\Control\Update\Networ kPath

string value

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-8

Chapter 5: Adminstration Tasks

4 Transfer the operator account from the 3070 controller to the PDC:

a View the Agilent3070Operators group information on the 3070.

b Replicate this group account on the PDC.

c View the operator user account information on the

3070.

d Replicate this user account on the PDC.

e Remove the operator user account information from the 3070.

5 Optional: Enable replication on all domain controllers so that the

Ntconfig.pol

file is replicated to the same directory on all backup domain controllers.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-9

Chapter 5: Adminstration Tasks

Administering

Datalogging

This section describes several datalogging tasks.

Datalogging is described in Information Management,

Chapter 2; see “Structure of the Datalogging Files.”

Occasionally, the datalogging process may require your attention. If a 3070 system fails to log data, do the following:

■

■

Verify that the translogd

process, which automatically transfers log data from source queues to destination queues, is running. To do this, use the Processes tab in the Windows Task

Manager. If datalogging files are present in the source queues, translogd

transfers them to the destination queues for processing by quality management software.

Verify that the tld.conf

configuration file used by translogd

is present and is not corrupt.

Locate the file in the directory:

$AGILENT3070_ROOT/qm/logdata/

■

Unless you have modified this file, it should be exactly like the original in the directory

$AGILENT3070_ROOT/standard

.

Use an ASCII editor, such as Notepad or Wordpad to examine the translogd

error file to see if any error messages were logged there. The error file is:

$AGILENT3070_ROOT/qm/logdata/tld.log

After you have corrected a datalogging problem, you can delete the error messages, but do not delete the file.

CAUTION

✸ You must never delete the tld.log

error file.

■

■

■

■

■

A repetitive error will cause the

$AGILENT3070_ROOT/qm/logdata/tld.log

error file to grow without bounds. If the size of the file exceeds 2.5 Megabytes, the following message will be printed on a DOS window which will pop up:

WARNING -- TRANSLOGD IS

EXPERIENCING ERRORS. LOG FILE IS

'<path>'

LOG FILE SIZE TOO LARGE

(LIMIT=<number> SIZE=<number>)

PLEASE EXAMINE (THEN TRUNCATE) THIS

FILE!

You may need to clear out the directories where datalogging information is stored (the board subdirectories beneath the testerq

directory or the log data files beneath the pbqmq directory).

Under normal circumstances, these files are removed automatically once they have been processed.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-10

Chapter 5: Adminstration Tasks

Installing Patches

If you receive notification of a patch release for 3070 software, you will also receive instructions on how to download and install the patch.

When you install the patch software, it will find the current software, verify that all patch prerequisites are met, and load the patch. This will typically happen with no interaction required.

CAUTION

✸ Do not install any Microsoft® Service Pack unless specifically recommended by Agilent.

© Agilent Technologies 2001–2003 Administering Agilent 3070 Systems (MS Windows NT and 2000) 5-11

6666

In this Chapter...

Understanding the File System

■

The Root Directory Environment Variable , 6-2

■

The .hp3070 File , 6-7

■

Installing Software Packages , 6-11

3070 Reference

3070 User and Service manuals are located on 3070 system controllers and on factory-supplied updates.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-1

Chapter 6: Understanding the File System

The Root Directory

Environment

Variable

This section contains:

■

Introduction , 6-2

■

The $AGILENT3070_ROOT Environment Variable , 6-2

■

$AGILENT3070_ROOT on UNIX , 6-2

■

$AGILENT3070_ROOT on MS Windows , 6-5

Introduction

3070 systems are now available with a choice of these two operating systems:

■

HP-UX

■

MS Windows®

3070 application file path usage is different between the two operating systems.

The $AGILENT3070_ROOT Environment Variable

Beginning with software revision 3070 04.00pb 0501

WN, an environment variable is used to allow 3070 board files to be easily transferred between 3070 systems running either MS Windows or UNIX.

The environment variable is $AGILENT3070_ROOT. It replaces the root directory path (upper path names) on both operating systems.

All subdirectories under

/opt/hp3070/../..

will exist on UNIX systems for the forseeable future.

NOTE

/opt/hp3070

is replaced by

$AGILENT3070_ROOT on all MS Windows systems.

$AGILENT3070_ROOT

on UNIX

On UNIX systems, the value of $AGILENT3070_ROOT is

/var/hp3070

Identify the Value of $AGILENT3070_ROOT

To identify the value of $AGILENT3070_ROOT on a

UNIX or Windows system, at a shell window prompt enter:

■ echo $AGILENT3070_ROOT

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-2

Chapter 6: Understanding the File System

New File Path Usage in a UNIX terminal Window

Table 6-1

illustrates new path equivalents using the system config file when working in a UNIX terminal window.

Table 6-1 New file path usage in a UNIX shell window

Before Software Release 3070 04.00 pa

/var/hp3070/diagnostics/th1/config

/hp3070/diagnostics/th1/config

At and After Software Release 3070 04.00 pa

$AGILENT3070_ROOT/diagnostics/th1/config

$AGILENT3070_ROOT/diagnostics/th1/config

File Path Usage in BT-BASIC Window

Table 6-2

illustrates new path equivalents using the system config file when working in a BT-BASIC window.

NOTE

BT-BASIC usage is the same in both UNIX and

MS Windows.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-3

Chapter 6: Understanding the File System

Table 6-2 File path usage in a BT-BASIC window

Pre 3070 Software Release 3070 04.00pa

3070 Software Release 3070 05.00p At and After 3070 Software Release 3070 04.00pa

msi

“D:/Agilent3070/diagnostics/th1” msi

“C:/Agilent3070/diagnostics

/th1” msi btgetenv$ (“AGILENT3070_ROOT”) &

“/diagnostics/th1” get

“D:/Agilent3070/diagnostics/th1/ config” get

“C:/Agilent3070/diagnostics

/th1/config” get btgetenv$ (“AGILENT3070_ROOT”) &

“/diagnostics/th1/config”

NOTE

The btgetenv$ (“AGILENT3070_ROOT”) &

is only required for BT-BASIC commands which are referenced to the root.

If the text does a BT-BASIC msi btgetenv$ (“AGILENT3070_ROOT”) & <command>

prior to the next BT-BASIC command (for example compile

or faon

), then using the environment variable which defines the path from the root is unnecessary. BT-BASIC commands which normally contain paths ( msi

, load

, copy

, save

, get

, store

, unlink

, rcall

) for example, will require btgetenv$

(“AGILENT3070_ROOT”) & <rest of path>

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-4

Chapter 6: Understanding the File System

$AGILENT3070_ROOT

on MS Windows

On MS Windows systems, the factory default value of

$AGILENT3070_ROOT is

C:/Agilent3070

Identify the Value of $AGILENT3070_ROOT

To identify the value of $AGILENT3070_ROOT on a MS

Windows system, at a shell window prompt enter:

■ echo $AGILENT3070_ROOT

File Path Usage in a MS Windows Korn Shell

Window

■

When working in a Korn shell window, follow the

UNIX syntax by:

Using

$variable

(instead of

%variable%

).

■

Using the correct case.

Using

/

(forward slash) instead of

\

(backslash)

■

Table 6-3

illustrates new path equivalents when working in a MS Windows Korn shell window.

Table 6-3 New file path usage in a MS Windows Korn shell window

Pre 3070 Software Release 3070 04.00pa 3070 Software Release 3070 05.00p

D:/Agilent3070/diagnostics/th1 C:/Agilent3070/diagnostics/th1

At and After 3070 Software Release 3070 04.00pb 0501 WN

$AGILENT3070_ROOT/diagnostics/th1

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-5

Chapter 6: Understanding the File System

New File Path Usage in a MS-DOS Command Prompt

Window

When working in a Command Prompt window:

■

Use

%variable%

(instead of

$variable

).

■

Use

\

(backslash) instead of

/

(forward slash).

Table 6-4 on page 6-6 illustrates new path equivalents

using the dev

directory when working in a Command

Prompt window.

Table 6-4 New file path usage in a MS-DOS Command Prompt window

Pre 3070 Software Release 3070 04.00pa

At and After 3070 Software Release3070 04.00pb 0501

WN

D:\Agilent3070\dev %AGILENT3070_ROOT%\dev

NOTE

In MS Windows® 2000 Professional, the MS-DOS window is now the Command Prompt window. To open the Command Prompt: point to Start, then

Programs, then Accessories, and choose

Command Prompt.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-6

Chapter 6: Understanding the File System

The

.hp3070

File

The system first searches the current working directory for a

.hp3070

file. If one is not found, the user’s home directory is searched. This method allows a

.hp3070

file for each board.

The

.hp3070

file can affect system behavior in many ways.

Some Descriptions of

.hp3070

File Keywords

Some descriptions of

.hp3070

file keywords are given

in Table 6-5 . This is not a complete description of this

file. Other options are described beneath appropriate topics throughout the 3070 User documentation.

Table 6-5 Some descriptions of

.hp3070

file keywords keyword

.

BackupLevel

Description

The value of this option sets the global backup style for this user and determines whether the system compilers keep an unchanged copy (a backup) of files before modifying them, and how the backup is stored. The backup style can be:

none – No file backup is made.

numbered – Multiple backups are made as files change. To identify a numbered backup file, its name has a period, a tilde (

~

), and a unique number from 1 to 9 appended to its name; for example, file.1~

. Number 1 is the most recent backup, and number 9 is the oldest. When more than 9 backups occur, the oldest backup file in the set is discarded and those remaining are renumbered.

unnumbered – A single backup is made as files change. Each new backup file overwrites the contents of the previous backup file. To identify an unnumbered backup file, a tilde (

~

) is appended to its name; for example, file~

. For example,

.BackupLevel: unnumbered

Besides the global value for backup style, you can individually specify a backup style for some of the software modules in your system. For example,

Mpa.BackupLevel: numbered overrides the global default and sets the backup style for the pin assignment software to numbered.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-7

Chapter 6: Understanding the File System

Table 6-5 Some descriptions of

.hp3070

file keywords (continued) keyword

.

ProgramAction

Debug.Source

FXT.WIRECOLORS

Operator.ForceWidgets

Description

The value of this option determines whether a new window is automatically opened when some commands are executed

(such as execute – see Syntax Reference .

.ProgramAction

can be either window

(a new window is automatically opened) or nowindow

(a new window is not automatically opened). For example,

.ProgramAction: nowindow

The value of this option determines whether the Agilent Pushbutton Debug environment is automatically invoked when a debug

statement is executed on the BT-BASIC command line. The value of this option can be:

Debug.Source: no – Use the standard debug environment by default.

Debug.Source: yes – Use the Agilent Pushbutton Debug environment by default.

For more information, see Test Methods: Digital .

This option lets you specify user-defined wire colors for fixturing. The values following this variable are the colors that are requested in fixture building reports. This lets you customize wiring reports so they ask for colors (in any language) matching the colors of the wires being used.

The first color is used for all non-ground wiring (positive and negative) and should be the local word for red. The second color is used for all ground wiring and should be the local word for black. The remaining colors are used in sequence, one per node. The sequence of colors repeat after the last color has been used. For example,

FXT.WIRECOLORS: "red black blue green yellow aqua white"

In the example, red

is used for all non-ground wires, and black

is used for all ground wires. The color of wires specified for wiring nodes cycle through the list from blue

to white

. After white

has been used, the sequence starts over with blue

.

For more information, see Test and Fixture Development .

This option lets you specify whether the operator keypad appears on the screen for operator logins. Specify

Yes

to have the keypad automatically appear, or

No

to have it not appear. For example,

Operator.ForceWidgets: Yes

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-8

Chapter 6: Understanding the File System

Table 6-5 Some descriptions of

.hp3070

file keywords (continued) keyword

Operator.Footswitch

Description

This option lets you specify whether the foot switch on the Agilent 3070 is enabled. Specify

Yes

to have the foot switch enabled, or

No

to have it disabled. For example,

Operator.footswitch: Yes

The majority of the

.hp3070

file contains definitions for the operator keypad, which are invoked by an operator statement if the

Operator.ForceWidgets

option is set to

Yes

(see Syntax Reference ). When a set of labels is specified in the operator

statement — for example, operator waitforstart

invokes the set of labels and functions defined as waitforstart

— that set of label definitions becomes active. The boxes in the operator keypad are labeled with those definitions, and selecting a box (with the mouse or the touchscreen) invokes the function associated with the label in that box.

If no label specifier is included in an operator statement, the default label definition is determined by the value of either of two variables in this file. The

Operator.Default

variable sets the default for a user who is not using a board handler with the system, and the

Operator.ABH_Default

variable sets the default for a user who is. The values of both of these variables are typically defined as standard

.

The label and function definitions are arranged into groups that each contain three specifications:

■

■

■

A physical description of the operator keypad, including the X and Y coordinates and how many boxes should appear in the keypad.

What label (text) should appear in each box.

Labels can contain any combination of upper or lowercase letters and are treated as lowercase when invoked in an operator

statement.

Which function is invoked by selecting a particular box. Function names are case-sensitive.

For example, standard

, which is the default definition for the operator keypad, might look like the following:

Standard.Boxes:

Standard.X:

Standard.Y:

Standard.Columns:

4

8

8

10

Standard.Label1:

Standard.Label2:

Standard.Label3:

Standard.Label4:

Standard.Label5:

Standard.Label6: start yes no

.

faon faoff

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-9

Chapter 6: Understanding the File System

Standard.Label7:

Standard.Label8: stop exit

Standard.Command1:

Standard.Command2:

Standard.Command3:

Standard.Command4:

Standard.Command5:

Standard.Command6:

Standard.Command7:

Standard.Command8:

CHAR_START

CHAR_YES

CHAR_NO

CHAR_NULL

CHAR_FAON

CHAR_FAOFF

CHAR_STOP

CHAR_EXIT

This example defines the keypad boxes which are arranged in eight columns. When the operator keypad is invoked by an operator

statement that specifies this definition, the boxes are labeled start

, stop

, yes

, no

, faonn

, faoff

, and exit

. When box #1 (

Label1

or start

) is selected, the characters

START

are executed on the command line; start

is the function passed to

BT-BASIC.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-10

Chapter 6: Understanding the File System

Installing Software

Packages

Introduction

The factory routinely releases new software packages that improve and add capabilities.

Some software packages depend on a previous software package being installed.

Always notify system users when a new software package is installed.

Install a Software Package

Installation instructions accompany software packages.

Follow the instructions carefully.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 6-11

7777

In this Chapter...

Additional Information for Networking

■

Introduction , 7-2

■

Testhead IP Addresses , 7-3

■

The Private LAN , 7-5

■

The Public LAN , 7-7

■

Bridges, Routers, and Gateways , 7-9

■

Clients and Servers , 7-10

■

Domain Names , 7-11

■

Network Services , 7-12

■

Useful Commands , 7-13

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-1

Chapter 7: Additional Information for Networking

Introduction

A network is a collection of computers that communicate with each other using a set of agreed upon protocols.

3070 Networking Facilities

3070s contain networking software for:

■

LANs (local area networks).

■

■

Internet services.

File sharing.

Additional facilities include software to enable:

■ remote log ons.

■

■ file transfers.

remote execution.

■

■ network printer servers.

a full range of Internet services.

To Configure Networking

The first time a 3070 is booted, system configuration information will need to entered. This includes

networking information. See Chapter 3, Setting Up and Configuring New Systems for the procedure.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-2

Chapter 7: Additional Information for Networking

Testhead IP

Addresses

This section contains:

■

3070 System IP Addresses , 7-3

■

Implications for Custom Applications , 7-3

All 3070 MS Windows systems are configured with

Agilent IP addresses in the 10.3.112.XX series.

To avoid network conflicts, including the inability to boot a testhead, all 3070 systems on the same network must share the same IP address series.

3070 System IP Addresses

The following Agilent board test systems have IP addresses in the 10.3.112.XX series:

■

3070 MS Windows systems.

■

■

3070 UNIX systems shipped with B.03.80 software.

3070 UNIX systems updated or ignited with

B.03.80 software.

Because of the Hewlett-Packard / Agilent Technologies split, 3070 Board Test systems are no longer shipped with LAN IP addresses in the 15.3.112.XX series.

This should not cause any networking problems because the systems are configured to use local hosts for testhead IP address resolution.

Using a Nameserver for Existing Systems

If you are using a nameserver for name resolution, we recommend, but do not require, that all IP addresses match. This means they should all use the 10.3.112.XX

IP address convention.

NOTE

Only 3070 IP addresses in the 10.3.112.XX format are supported by Agilent.

Implications for Custom Applications

If there are any custom applications that are hard-coded to look for a 15.3.112.XX address, they must be modified to look for a 10.3.112.XX address.

NOTE

If you have existing devices on your public LAN using addresses in the 10.3.112.XX range or if you experience conflicts, contact your Agilent support representative.

Find your Agilent support representative on the

Internet at http://www.agilent.com

a Click Contact Us at the top of the page.

b Click Test & Measurement

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-3

Chapter 7: Additional Information for Networking

c Select your country and click go

d Scroll down to Technical & Professional Services

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-4

Chapter 7: Additional Information for Networking

The Private LAN

This section contains:

■

3070 Private LAN IP Addresses , 7-5

3070 Private LAN IP Addresses

Your 3070 MS Windows system includes two network adapter cards for connecting to local area networks.

(LANs). The first network adapter card is configured and reserved for the private LAN. It is represented as

Local Area Connection in Network and Dial-up

Connections. Local Area Connection communicates directly from the controller to the testhead. Do not change these settings. There should not be other devices attached to this LAN other than shown in

Figure 7-1 on page 7-6.

The private LAN IP addresses are standard for every test system.

Table 7-1

shows the IP addresses reserved for the 3070 private LAN.

Table 7-1 3070 Private LAN IP Addresses

IP Address

10.3.112.10

10.3.112.2

10.3.112.4

10.3.112.5

10.3.112.6

10.3.112.7

Address Reserved for:

The 3070 MS Windows controller. (Local Area Network)

The testhead system card.

Module 0 of the ControlXT card.

Module 1 of the ControlXT card.

Module 2 of the ControlXT card.

Module 3 of the ControlXT card

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-5

Chapter 7: Additional Information for Networking

Figure 7-1 3070 Private LAN IP Addresses

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-6

Chapter 7: Additional Information for Networking

The Public LAN

This section contains:

■

Introduction , 7-7

■

A User-Access Example , 7-7

Introduction

Local Area Connection 2 is the public LAN interface used for connecting to your site network. This LAN interface can be connected to your network with an

RJ45 cable that is compatible with 10Base-T or

100Base-T.

A 3070 MS Windows system includes an RJ45 LAN

cable located at the base of the controller. Figure 7-2

shows the location of the LAN cable and coupler on the back of a 3070 MS Windows controller. Use this cable to connect to your site network.

A User-Access Example

3070 systems are now available with either a Windows

or a UNIX controller. Figure 7-3 on page 7-8 shows an

example of a user-access scheme when both Windows and UNIX systems exist.

Figure 7-2 LAN cable and coupler

RJ45 LAN cable Coupler

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-7

Chapter 7: Additional Information for Networking

Figure 7-3 User-access example for UNIX and MS Windows test development systems and testheads

MS WINDOWS

Single-user (No Concurrent Access) access to MS Windows Test

Development Workstation

Single-user (No Concurrent

Access) access to MS Windows

Testhead

Direct OR

Via Networked

MS Windows

OR Direct

MS Windows

Test Development

Workstation

MS Windows

Testhead

Controller

HUB or Switch, etc.

Connect to public LAN / backbone through router / gateway as needed.

UNIX

Test Development

Server

Direct AND

Multiple-user (Concurrent Access

Available) access to

UNIX Test Development Server

Via Networked

UNIX

Workstation(s)

AND

UNIX

Testhead

Controller

Direct

Multiple-user (Concurrent Access

Available) access to

UNIX Testhead

UNIX

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-8

Chapter 7: Additional Information for Networking

Bridges, Routers, and Gateways

Bridges, routers, and gateways are used to connect multiple segments of a network into a unified, larger network.

Typically, you will not have to worry about these devices. If installing systems onto an existing network, you may have to configure the 3070 to take advantage of the facilities that your network provides.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-9

Chapter 7: Additional Information for Networking

Clients and Servers

Network

A network is a group of computers that are connected and used for sharing resources such as files, software, and peripheral devices.

Hosts and Nodes

Each computer or device on the network is host (also known as a node). A host can be a client, server, or both.

In most cases, each host functions as both a client and a server.

Client

A client is a computer or program that requests the services of another computer or program.

Server

A server is a centralized computer that manages requests and controls access to shared network resources.

Client/Server

In a Client/Server network, a central computer, the server, manages access to shared network resources.

The computers that connect to the server and request services are called clients and are considered to be part of the domain.

The MS Windows Controller as Server

The terms client and server relate to communication from the computer’s point of view. An example of this is the use of a personal computer (MS Windows) as an

X-Terminal to communicate with an 3070 controller.

From the user’s point of view, the 3070 is the server and the MS Windows controller is the client. But from a networking point of view, the MS Windows controller is the server because it is running a program called

X-Server. The 3070 requests services from the MS

Windows controller, such as displaying a window or drawing board graphics. The MS Windows controller does not request services from the 3070.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-10

Chapter 7: Additional Information for Networking

Domain Names

A domain name is a unique combination of a hostname and a network domain name. A hostname is a unique name assigned to node within the network domain to which the node is connected. It is not valid to have two nodes with the same name in the same domain.

TCP/IP protocols provide a number of mechanisms for mapping domain names to IP addresses.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-11

Chapter 7: Additional Information for Networking

Network Services

A 3070 MS Windows system comes bundled with a variety of basic and advanced network services.

These services may require configuration.

Table 7-2 Network services

Network Service

FTP

Telnet

Internet Explorer

Outlook Express

The primary network services available on the 3070 are

described in Table 7-2

.

Description

Transfer files to and from a computer running an FTP server service.

To start FTP:

a From the Start menu, click Run

b Type ftp, then click OK.

Connect or login to a remote server or computer over a network. To use Telnet, you need:

• the TCP/IP protocol installed and configured on your computer.

• a user account on the remote host

To start Telnet:

a From the Start menu, click Run

b Type telnet, then click OK.

Connect to the internet, search for and view information on the World Wide Web.

Use the Internet Connection Wizard to configure settings.

Send and receive e-mail messages.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-12

Chapter 7: Additional Information for Networking

Useful Commands

The commands in

Table 7-3

can be executed in a

Command Prompt window. In Windows 2000, the

Command Prompt replaces the MS-DOS prompt.

More detailed information on these and others commands is available in Windows 2000 Professional

Help.

To Execute a Command in a Command Prompt Window

1 Point to Start > Programs > Accessories and click

Command Prompt.

2 Type the command at the C:\> prompt.

Table 7-3 Command Reference

Command arp finger ftp hostname ipconfig nbstat netstat nslookup ping route rsh

Description

Display or modify IP-to-ethernet physical address translation tables.

Display information about a user on a specified system.

Transfer files to and from a computer running an FTP service.

Display the hostname of the computer.

Display TCP/IP network configuration information.

Display protocol statistics and TCP/IP connections using NetBIOS.

Display protocol statistics and TCP/IP connections.

Display information about DNS servers.

Verify connections to remote computers.

Maintain network routing tables.

Run commands on remote computers running the RSH service.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 7-13

8888

Reference

In this Chapter...

■

Logging-On as service3070 , 8-2

■

The Root Directory Environment Variable , 8-3

■

Directory Descriptions , 8-6

■

Editing Files , 8-8

■

MS Windows Quick-Reference , 8-16

■

BT-BASIC Quick-Reference , 8-17

■

NT Korn Shell Quick Reference , 8-18

■

vi and viw Editor Quick Reference , 8-21

■

Codewords , 8-25

■

System Config File Specifics , 8-26

■

Standard Config File Specifics , 8-29

■

Compiling the System and Standard Config Files , 8-35

■

The bootptab File , 8-36

■

The hosts File , 8-38

■

Device Files , 8-40

■

Vacuum Control , 8-42

■

Rotating the Testhead , 8-43

■

Testhead Cards , 8-44

■

DUT Power Supplies , 8-47

■

Controller Cables and Devices , 8-52

■

Testhead LAN and Serial Port MUX , 8-59

Referenced Manuals

The following manuals are referenced within this chapter:

■

Administering Agilent 3070 MS Windows Systems

E9970-90000.

■

■

■

Agilent 3070 / 79000 Family Site Preparation

Manual 03066-90114.

Agilent 3070 / 79000 Repair I Manual

E4000-90160.

Agilent 3070 Family Users' Manual.

Introduction

The information in this chapter may be helpful when installing an Agilent 3070 system that uses a MS

Windows controller.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-1

Chapter 8: Reference

Logging-On as service3070

The service3070 logon allows system configuration and testing.

Display the Logon Status from a Current Login

1 Press the <Ctrl><Alt><Delete> keyboard keys at the same time.

2 If logged-on as service3070

, click Cancel.

Otherwise, click Logoff....

Logon as

service3070

1 Click Start > Shut Down....

2 Select Close all programs and log on as a different user?

3 Enter the logon information:

■

Logon Name = service3070

■

Default Password = service

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-2

Chapter 8: Reference

The Root Directory

Environment

Variable

This section contains:

■

Introduction , 8-3

■

Determine the Value of the Root Directory

Environment Variable , 8-3

■

Use of the Root Directory Environment Variable in a BT-BASIC Window , 8-3

■

Use of the Root Directory Environment Variable in a Korn Shell Window , 8-4

■

Use of the Root Directory Environment Variable in a MS-DOS Command Prompt Window , 8-5

Introduction

3070 systems now establish a root directory environment variable.

Beginning with software revision 3070 04.00pa, an environment variable is used to allow 3070 board files to be easily transferred between 3070 systems running either MS Windows or UNIX.

The environment variable is named

$AGILENT3070_ROOT. It replaces the root directory path

(upper path names) on both operating systems.

The directories,

/var/hp3070 and

/opt/hp3070, are replaced by $AGILENT3070_ROOT on all MS Windows systems.

The root directory environment variable is usually set to

D:\Agilent3070

, but could change.

Determine the Value of the Root Directory

Environment Variable

1 Open a Korn shell window:

■

Double-click the desktop Korn Shell icon OR

■

Click Start > Programs > Agilent 3070 > Korn

Shell.

2 At the prompt, enter: echo $AGILENT3070_ROOT

The string returned is usually:

D:\Agilent3070

Use of the Root Directory Environment Variable in a BT-BASIC Window

Table 8-1

illustrates new path equivalents using the system config file in a BT-BASIC window.

NOTE

BT-BASIC usage is the same in both UNIX and

MS Windows.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-3

Chapter 8: Reference

Table 8-1 New file path usage in a BT-BASIC window

Pre 3070 Software Release 3070 04.00pa

3070 Software Release 3070 05.00p

msi

"D:/Agilent3070/diagnostics/th1

/config" msi

"C:/Agilent3070/diagnostics/th1

/config" get

"D:/Agilent3070/diagnostics/th1

/config" get

"C:/Agilent3070/diagnostics/th1

/config"

At and After 3070 Software Release 3070 04.00pa

msi btgetenv$ ("AGILENT3070_ROOT") &

"/diagnostics/th1/config" get btgetenv$ ("AGILENT3070_ROOT") &

"/diagnostics/th1/config"

NOTE

The btgetenv$ ("AGILENT3070_ROOT") &

is only required for BT-BASIC commands which are referenced to the root.

If the BT-BASIC msi btgetenv$ ("AGILENT3070_ROOT") &

< command

> is typed prior to the next BT-BASIC command (for example compile

or faon

), then using the environment variable which defines the path from the root is unnecessary. BT-BASIC commands which normally contain paths ( msi

, load

, copy

, save

, get

, store

, unlink

, rcall

) for example, will require: btgetenv$ ("AGILENT3070_ROOT") &

< rest of path

>

Use of the Root Directory Environment Variable in a Korn Shell Window

In a Korn shell window, follow the UNIX syntax:

■

■

■

Use

$<variable>

(instead of

%<variable>%

).

Use the correct case.

Use

/

(forward slash) instead of

\

(backslash).

Table 8-2

illustrates new path usage when working in a

Korn shell window.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-4

Chapter 8: Reference

Table 8-2 New file path usage in a Korn shell window

Pre 3070 Software Release 3070 04.00pa

D:\Agilent3070\diagnostics\th1

\opt\hp3070\help\C\SERVICE

At and After 3070 Software Release 3070 04.00pa

$AGILENT3070_ROOT\diagnostics\th1

$AGILENT3070_ROOT\Documentation\SERVICE

Use of the Root Directory Environment Variable in a MS-DOS Command Prompt Window

In a MS-DOS Command Prompt window:

■

Use

%<variable>%

(instead of

$<variable>

).

■

Use

\

(backslash) instead of

/

(forward slash).

Table 8-3 on page 8-5 illustrates new path usage using

the dev

directory as an example when working in a

MS-DOS Command Prompt window.

Table 8-3 New file path usage in a MS-DOS Command Prompt window

Before Software Release 3070 04.00pa

At and After Software Release 3070 04.00pa

D:\Agilent3070\dev %AGILENT3070_ROOT%\dev

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-5

Chapter 8: Reference

Directory

Descriptions

Table 8-4

lists descriptions of some 3070 MS Windows system directories.

Table 8-4 Descriptions of various 3070 MS Windows system directories

$AGILENT3070_ROOT\

$AGILENT3070_ROOT\autofile

$AGILENT3070_ROOT\bin

$AGILENT3070_ROOT\boards

$AGILENT3070_ROOT\contrib

$AGILENT3070_ROOT\dev

$AGILENT3070_ROOT\diagnostics

$AGILENT3070_ROOT\etc

$AGILENT3070_ROOT\help

$AGILENT3070_ROOT\home

$AGILENT3070_ROOT\lib

$AGILENT3070_ROOT\library

$AGILENT3070_ROOT\qm

$AGILENT3070_ROOT\standard

The directory beneath which the vast majority of the 3070 system software resides.

The directory that contains all the autofiles for the system.

The directory that contains most of the executable programs for the 3070 system.

The directory that should contain customer board directories.

The directory where user-contributed software that may be of use to 3070 customers is redistributed by Agilent.

A directory that contains pseudo device files for use by the 3070 software.

A directory that contains testhead configuration and diagnostic information / programs.

A directory that contains miscellaneous files.

A directory that contains help information.

The directory that contains the MS Windows user's home directories.

The directory that contains digital libraries and other executables.

The directory that contains device libraries provided by Agilent for board development.

The directory to which statistics are logged.

A directory that contains templates used throughout the system.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-6

Chapter 8: Reference

Table 8-4 Descriptions of various 3070 MS Windows system directories (continued)

$AGILENT3070_ROOT\tmp

$AGILENT3070_ROOT\util

A directory that is used by the 3070 software for storing temporary files and logs.

A directory that is used for storing a few utility files.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-7

Chapter 8: Reference

Editing Files

This section contains:

■

Forward-Slashes versus Back-Slashes in

Command Lines Containing File Paths , 8-8

■

Use BT-BASIC , 8-8

■

How to Edit the System Config File to Match the

Testhead Configuration , 8-9

■

How to Resolve the Standard Config File from the

System Config File , 8-10

Forward-Slashes versus Back-Slashes in

Command Lines Containing File Paths

A general rule for commands using a path to a directory or file is to use a forward-slash (/) for commands tied to a 3070 application, and use a back-slash (\) for operating system-related commands.

If a command line containing a file path fails to execute, it may be because the slash used is of the wrong type.

Reversing the slash(es) may resolve the issue.

This is because:

■

Many Korn shell commands are used in the MS

Windows environment, and require forward-slashes (/) in command lines containing file paths.

■

■

In MS Windows, when opening a file from the

Start > Run... menu, both forward-slashes (/) and back-slashes (\) are recognized.

A command may be performed in or with some relationship to the MS-DOS environment, which can require back-slashes in command lines containing file paths.

Use BT-BASIC

BT-BASIC is the designated file-editing tool. Unless otherwise specified, editing described in this chapter is performed using BT-BASIC.

Korn shell, vi, and viw editors can also be used to edit files.

Reference information for all these tools:

■

■

■

BT-BASIC Quick-Reference on page 8-17.

NT Korn Shell Quick Reference on page 8-18.

vi and viw Editor Quick Reference on page 8-21.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-8

Chapter 8: Reference

Open BT-BASIC

• Double-click the desktop BT-BASIC icon OR

Click Start > Programs > Agilent 3070 > BT-BASIC.

BT-BASIC will open with the cursor on the command line.

Open a File in BT-BASIC

• From the command line, enter: get btgetenv$ ("AGILENT3070_ROOT") &

"

< path to the file

>

"

For more information about this command, see

Use of the Root Directory Environment Variable in a

BT-BASIC Window on page 8-3.

Edit in BT-BASIC

• Press F1 on the keyboard, if necessary, to toggle to the workspace.

To move the cursor, use the keyboard arrow keys, and the Insert Char, and Delete Char keys.

Save in BT-BASIC

1 Press F1 on the keyboard, if necessary, to toggle to the command line.

2 Enter: re-save

Exit BT-BASIC

1 Press F1 on the keyboard, if necessary, to toggle to the command line.

2 Enter: exit

How to Edit the System Config File to Match the

Testhead Configuration

If the testhead configuration has changed, the system config file MUST be updated to reflect the change.

Table 8-5

describes the process.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-9

Chapter 8: Reference

Table 8-5 Edit the system config file to match the testhead configuration

Task

1 Open the system config file in a BT-BASIC window.

Step

a Open a BT-BASIC window by double-clicking the desktop icon.

b From the BT-BASIC command line, enter:

2 Arrange or modify statements to reflect the actual testhead configuration.

3 Save and exit the system config file.

4 Compile the system config file.

get btgetenv$ ("AGILENT3070_ROOT") & "/diagnostics/th1/config"

Do this as required.

See

Table 8-8 on page 8-17 for commonly used BT-BASIC commands.

• Enter:

1) re-save

2) exit

See

Compiling the System and Standard Config Files on page 8-35.

How to Resolve the Standard Config File from the

System Config File

If the system config file has changed it is good practice to edit the standard config file to reflect the changes.

This is a service to board test development programmers.

See

Table 8-6 to resolve the standard config file from

the system config file.

Figure 8-1 on page 8-15 illustrates the concept.

The desired end result is to copy the cards ...

, serial ports

..., supplies ...

and ports ...

statements from the system config file to the standard config file.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-10

Chapter 8: Reference

No changes to the system config file are made.

Table 8-6 Resolve the standard config file from the system config file

Task

1 Make a backup copy of the standard config file:

Step

a Open a BT-BASIC window by double-clicking the desktop icon.

b At the prompt, type: msi btgetenv$ ("AGILENT3070_ROOT") & "/standard" c copy "config" over "config.temp"

a Type: 2 Open the standard config file:

3 Open the system config file in a new BT-BASIC window: get "config"

• At the new BT-BASIC window command line, enter: get btgetenv$ ("AGILENT3070_ROOT") & "/diagnostics/th1/config"

4 Arrange the two BT-BASIC windows so that each can be readily accessed.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-11

Chapter 8: Reference

Table 8-6 Resolve the standard config file from the system config file (continued)

Task

5 Copy the appropriate statements from the system config file to the clipboard buffer:

Step

In the BT-BASIC window containing the system config file:

a Press F1 on the keyboard to enter the workspace.

b Locate the module <number>

that contains un-commented cards 1 ...

statements using the arrow keys or the Prev and Next keys.

c Scroll the text up until the end module

statement is visible.

d Click and drag with the mouse to highlight the text including the ports ...

statement

The highlighted text is now copied in the clipboard buffer.

NOTE

Do not include probe

, debug port

, bank

, or end bank

statements.

These statements are not valid in the standard config file.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-12

Chapter 8: Reference

Table 8-6 Resolve the standard config file from the system config file (continued)

Task

6 Paste the copied text in the standard config file:

Step

CAUTION

✸ Do not delete the

! Specify instrument ...

through

! connect ...

statements.

7 Verify that each un-commented module

<number> and end module statement in the system config file is un-commented in the standard config file.

a Activate the window containing the standard config file by clicking on the window border.

b Press F1 on the keyboard to enter the workspace.

c Move the cursor immediately below the module <number>

statement that corresponds to the module <number>

statement copied in the previous task.

■

Take care not to overwrite other lines.

d Click the right mouse button.

The text from the buffer will be inserted into the standard config file.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-13

Chapter 8: Reference

Table 8-6 Resolve the standard config file from the system config file (continued)

Task

8 Save , then exit the standard config file:

9 Exit the system config file without saving it:

Step

a In the window containing the standard config file, press F1 to return to the command line.

b Enter:

1) re-save

2) exit

a In the window containing the system config file, press F1 to return to the command line.

b Enter:

10 Compile the standard config file.

exit

Instructions are given in

Compiling the System and Standard Config Files on page 8-35.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-14

Chapter 8: Reference

Figure 8-1 Copying configuration information

$AGILENT3070_ROOT/standard/config

! CONFIGURATION FOR DEVELOPING BOARD TESTS

!

target . . . enable . . . module . .

command

Status: xxx lines in workspace

! relay 1 controls vacuum . . .

bank . .

module . . cards 1 . . .

ports . . ., . . .

end module module . .

cards 1 asru . . .

ports . . ., . . .

command

BASIC

$AGILENT3070_ROOT/diagnostics/th1/config

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-15

Chapter 8: Reference

MS Windows

Quick-Reference

See

Table 8-7 for a MS Windows quick-reference.

Table 8-7 MS Windows quick-reference

To Do This...

• Kill processes and applications

• Monitor CPU and memory usage

• View error logs

• Perform diagnostics

• Use other various administrative tools

Enter This...

Open the MS Windows Task Manager:

a Hold down the <Ctrl><Alt><Delete> keys at the same time (or right-click on the toolbar).

b Click Task Manager...

Open the MS Windows Event Viewer:

a Click Start > Settings > Control Panel.

b Double-click Administrative Tools, then select the appropriate application.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-16

Chapter 8: Reference

BT-BASIC

Quick-Reference

Table 8-8

lists some commonly used BT-BASIC statements.

Additional BT-BASIC information is given in Editing

Files on page 8-8.

NOTE

If uncertain whether to use forward-slashes or back-slashes, see

Forward-Slashes versus

Back-Slashes in Command Lines Containing

File Paths on page 8-8.

Table 8-8 Commonly used BT-BASIC statements

BT-BASIC Statement msi btgetenv$ ("AGILENT3070_ROOT") & "

< path to the file

>

" get btgetenv$ ("AGILENT3070_ROOT") & "

< path to the file

>

" save "

< filename

>

" re-save compile "

< filename

>

" compile "

< filename

>

";testhead findn "

< string expression

>

" exit

NOTE

For a more complete list of BT-BASIC statements, see the Agilent 3070 Family Users'

Manual Quick Reference Guide available in the online User manuals or on paper as part number

E9900-13602.

Statement Function

Change to file location

Retrieve an existing file

Create a new file

Save an existing file

Compile a file

Compile a testhead file

Find the next occurrence of a string expression

Quit BT-BASIC

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-17

Chapter 8: Reference

NT Korn Shell Quick

Reference

Although the operating system is MS Windows, a number of 3070 UNIX commands are valid in the Korn shell.

See

Table 8-9 for a Korn shell quick reference.

Keyboard keys are in { }.

For complete information about a command, at a Korn shell window prompt, enter: man <command_name>

Table 8-9 Korn shell quick reference

To Do This . . .

Working with directories

Show current working directory

Change directory

Change to home directory

Create a directory

Remove and (empty) directory

Display permissions for a directory

Working with files

List files and directories in current directory

List all files or directories, including hidden (“dot”) files pwd cd

NOTE

If uncertain whether to use forward-slashes or back-slashes, see

Enter This . . .

cd <pathnames>

Forward-Slashes versus

Back-Slashes in Command Lines Containing

File Paths on page 8-8.

mkdir <directoryname> rmdir <directoryname> ls -ld <directoryname> ls ls-a

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-18

Chapter 8: Reference

Table 8-9 Korn shell quick reference (continued)

To Do This . . .

Enter This . . .

List files, and show directories with / and executables with * ls -F

Display permissions for a file ls -l <filename>

Create or edit a file

Display file contents

Copy a file with permissions and owners

Move a file to a new filename vi <filename>

or viw <filename> more <filename>

( q

to quit) ( v

to vi) cp -p <file1> <file2> mv <old_file> <new_file>

Append file1 onto the end of file2

Remove a file cat <file1> >> <file2> rm <filename>

Finding and organizing

Find file(s) beginning with x in the current and sub-directories find . -name ‘x*’ -print

Find all occurrences of word in all files in the current directory grep word *

Display date and time date

Display manual page for

<command name>

Find name of current host system man <commandname> hostname

Find current system information

System operations

Clear screen uname -a clean

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-19

Chapter 8: Reference

Table 8-9 Korn shell quick reference (continued)

To Do This . . .

Exit / close Korn shell window

Set Korn shell for vi

Edit the command line (in Korn shell set for vi)

Recall previous command line (in Korn shell set for vi)

Execute previous command line (in Korn shell set for vi)

List current process status and PIDs

Redirect input from a file to a command

Connect two processes with a “pipe”

Network operations

Invoke ftp and connect to remote host

Set transfer mode to ASCII

Set transfer mode to binary

Copy a file using ftp from remote_hostname

Copy a file using ftp from the local current directory to current directory on the remote_hostname.

Exit ftp

Enter This . . .

exit set -o vi

{ESC}

(use vi commands)

{ESC}k

(back) or j

(forward)

{Return}

(when line is displayed) ps -ef command < infile command1 | command2 ftp <remove_hostname> ascii bin get <remote)file> put <local_file> bye

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-20

Chapter 8: Reference

vi and viw Editor

Quick Reference

See

Table 8-10 for a vi and viw editor quick reference.

Keyboard keys are in { }.

NOTE

If uncertain whether to use forward-slashes or back-slashes, see

Forward-Slashes versus

Back-Slashes in Command Lines Containing

File Paths on page 8-8.

Table 8-10 vi and viw editor quick reference

To Do This . . .

Getting started with vi

Create or edit a file in a Korn shell window

Create or edit a file in a vi window

Make sure you are in command mode

Show if you are in command or insert mode

Find out what file you are in

Moving within a file

Move the cursor left or right

Move the cursor up or down

Cursor to end of line

Cursor to beginning of line

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000)

Enter This in Command Mode . . .

vi

< filename

> viw

< filename

>

{ESC}

:set showmode

{CTRL}g h or l or arrow keys k or j or arrow keys

$

0

(Zero) or

^

8-21

Chapter 8: Reference

Table 8-10 vi and viw editor quick reference (continued)

To Do This . . .

Cursor to end of file

Cursor to line < n

>

Inserting text

Insert text at the cursor position

Insert a new line after the current line

Insert (Append) text after the cursor position

Backspace to overwrite previous character (in Insert Mode)

Replace single character

Replace until {ESC} is pressed

Deleting text

Delete characters at cursor

Delete word (cursor at beginning of word)

Delete the entire line at the cursor position

Delete from cursor to end of the current line

Delete from cursor to end of the file x dw dd

D dG

Enter This in Command Mode . . .

G

< n

>

G i

O

(capital) a

{CTRL}h or

{Backspace} r

< character

>

R

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-22

Chapter 8: Reference

Table 8-10 vi and viw editor quick reference (continued)

To Do This . . .

Moving text

Join lines of text

Copy a line into a buffer

Put copied or deleted text line from buffer after cursor line

Read in another file after cursor line

Searching text

Search forward for <words>

Search backward for <words>

Repeat the previous search for words

Saving and printing files

Save file in same filename

Save file to a new filename

Exit from file without saving changes

Overwrite another existing file with this file

Save and exit from the vi editor

Enter This in Command Mode . . .

J yy p

:r

< filename

>

/

< words

>

?

< words

> n (next) or N (previous)

:w

:w

< new_filename

>

:q!

:w!

or wq!

:wq

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-23

Chapter 8: Reference

Table 8-10 vi and viw editor quick reference (continued)

To Do This . . .

Repairing mistakes

Undo the previous action

Restore a line to its previous state

Restore ("put") last delete

Restore current file to last saved text and disregard changes

Undo last edit

Recover a file after a system interruption (from the Korn shell)

Enter This in Command Mode . . .

u

U p

:e!

u

(repeat to toggle) vi -r

< filename

>

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-24

Chapter 8: Reference

Codewords

Codewords are pre-installed at the factory and normally do not require adjustment.

Introduction

The capabilities of a 3070 system are based on the codewords installed.

Codeword information is used by the system config file compiler and allows confirmation that the hardware and the supported software features are compatible.

Install Codewords

Instructions for installing codewords are included with the software license(s).

Verify Installed Codewords

To verify the codewords:

a Click Start > Programs > Accessories.

b At a command window prompt, enter: codeword -l

(el, not one)

Compile the Two Config Files

CAUTION

✸ If the codewords have changed in any way, it will be necessary to compile both the system and standard config files. Instructions are given in

Compiling the System and Standard Config

Files on page 8-35.

CAUTION

✸ Incorrectly entered codewords, blank lines or spaces before or after a codeword may cause errors when compiling the config files.

User

and

Operator

logins may not boot if the

$AGILENT3070_ROOT/lib/.enable

file contains invalid information. Codeword order does not make any difference.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-25

Chapter 8: Reference

System Config File

Specifics

The path to the system config file is:

$AGILENT3070_ROOT/diagnostics/th1/config

It must match the actual testhead card configuration.

It will be necessary to edit the system config file if the testhead cards or locations of the testhead cards have changed.

To edit the system config file:

1 Login as service3070

(default password is service

).

2 At a BT-BASIC window prompt, enter: msi btgetenv$ ("AGILENT3070_ROOT") &

"/diagnostics/th1"

3 Enter: get "config"

4 Edit the file to match the actual testhead card configuration.

5 Enter: re-save

6 Compile the changed system config file. See

Compiling the System and Standard Config Files on page 8-35

The "Official" and "Actual" System Config Files

The "official" system config file is the system config file as when the system was shipped.

It is contained on a printout shipped with the system, and can be used as a model if it should be necessary to customize the system config file.

The "actual" system config file is the system config file in use which reflects the actual cards and card locations in the testhead.

If the System Config File is Corrupt

One of the sys.config.xxx

templates can be copied from the

$AGILENT3070_ROOT/diagnostics

directory and edited to match the actual system configuration.

NOTE

Changes to the system config file should be reflected in the standard config file. See

Standard

Config File Specifics on page 8-29.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-26

Chapter 8: Reference

Descriptions of Some Statements in the System

Config File

The testhead name Statement

The testhead name

statement in the system config file identifies, via the hosts

file, the block in the bootptab file that contains the hardware and internet protocol addresses for the System Card and ControlXT Card.

The testhead name

statement in the system config file includes only the modules that are present; for a four-module system it looks like: testhead name "testhead1" "module3" "module2"

"module1" "module0"

The System Card is represented by testhead1

The ControlXT Card in each module is represented by module<n>

Modules are mapped in the hosts

file. Using this information, specific hardware addresses (HAs) can be determined in the bootptab

file.

The line frequency Statement

In this statement, the unused frequency is commented.

For example, if the system power is connected to 60 hertz,

50

is commented.

NOTE

"Commented" means that the comment character, an exclamation mark (!), has been placed at the beginning of a line.

"Un-commented" means the "!" has been deleted from the beginning of the line.

The relay Statement

See Vacuum Control on page 8-42.

The cards <keywords> Statements

These statements identify to the system which cards are installed and where they are installed.

See

Table 8-15 on page 8-44 for available 3070 testhead

cards with diagnostics names, cards

< keywords

> statements, pattern applications rates and part numbers.

The cards

< keywords

> statements can be delimited by commas (,); a range can be separated by the word "to."

Valid examples are:

• cards 2, 3, 4, 5 hybrid standard double density

• cards 2 to 5 hybrid standard double density

• cards 2, 4, 7 to 11 hybrid standard double density

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-27

Chapter 8: Reference

NOTE

Single-density Hybrid Pin Cards cannot be used.

The supplies <keywords> Statements

Numbering of the supplies in the supplies

<keywords>

statements is arbitrary.

The software will accept any mapping of supply numbers to modules.

If the customer plans to share board test fixtures with other systems, it is possible they may have modified the default power supply setting.

If so, reconcile the supplies numbering with existing systems.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-28

Chapter 8: Reference

Standard Config

File Specifics

This section contains:

■

Introduction , 8-29

■

The Board Config File , 8-29

■

Standard Config File Syntax Similarities to and

Differences from the System Config File , 8-29

■

Statements Allowed in the Standard, System, and

Board Config Files , 8-30

■

Statements Not Allowed in either the Standard or

Board Config Files, but Are Allowed in the System

Config File , 8-30

■

Descriptions of Some Statements in the Standard

Config File , 8-30

Introduction

The path to the standard config file is:

$AGILENT3070_ROOT/standard/config

It should reflect the complete testhead resources available for the board test developer.

The standard config file as when the system was shipped:

■

■

Has the correct target

< keywords

> statement.

Includes commented enable

< keywords

> statements for optional components.

The Board Config File

The board test developer can use the standard config file as a template when developing a board config file.

The board config file is located in each board's subdirectory, and is a copy or subset of the standard config file.

The board config file can describe the resources in any one system or system subset.

Standard Config File Syntax Similarities to and

Differences from the System Config File

The cards

< keywords

> syntax is the same for the system config file and the standard config file.

However, some of the syntax for the standard config file is different from that of the system config file.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-29

Chapter 8: Reference

Statements Allowed in the Standard, System, and

Board Config Files

• target

• enable

• module

• end module

• access ports

• boards wired in parallel

• cards

• supplies

• ports

• boards

• connect

NOTE connect

statements allow programmers to name and define the use of external ports.

Usually these can remain as-shipped until the customer decides how to use these ports.

Descriptions of Some Statements in the Standard

Config File

The target <keywords> Statements

A target

< keywords

> statement is needed in each board config file

.

See

Table 8-11 for factory default

target

< keywords

> statements.

NOTE

The target

< keywords

> statement should be the first un-commented statement in the file and must exist before the cards

< keywords

> statements.

Statements Not Allowed in either the Standard or

Board Config Files, but Are Allowed in the

System Config File

• testhead name

• line frequency

• board handler

• relay

< x

> controls vacuum

< y

>

• bank

• end bank

• probe

• debug port

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-30

Chapter 8: Reference

Table 8-11 Factory default target

< keywords

> statements

Pattern Application Rate

6 MP/s (megapatterns-per-second)

12 MP/s

20 MP/s target

<keyword> Statement target hp3073 standard target hp3070 advanced target high accuracy

See

Table 8-12 for 3X72 process test system default

target

< keywords

> statements.

Table 8-12 3X72 process test system default target

< keywords

> statements

Product Description

Agilent 3172-U Unpowered Test (up to 2modules)

Agilent 3072-U Unpowered Test (up to 4 modules)

Agilent 3172-P Powered Test (up to 2 modules) target

<keyword> Statement target unpowered target unpowered target unpowered enable powered testing

Agilent 3072-P Powered Test (up to 4 modules) target unpowered enable powered testing

The enable <keywords> Statements

These statements are used in combination with codewords to selectively enable software functionality.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-31

Chapter 8: Reference

CAUTION

✸ enable

< keywords

> statements should exist after the target

< keywords

> statements, and must be outside of a module block.

NOTE

Codewords must be installed to enable optional software features. For more information, see

Codewords on page 8-25.

The programmer will un-comment the correct enable

< keywords

> statements which correspond to standard or optional software features as the board config file is developed.

Table 8-13

contains some enable < keywords statements in the standard config file.

>

Table 8-13 Some enable

< keywords

> statements in the standard config file enable

<keywords> advanced boundary scan

Functional Description:

Allows more advanced techniques in boundary scan testing, such as powered shorts testing.

all high accuracy resources combo test common delimiter connect check dual well shared wiring

For double density, high accuracy HybridPlus Cards, this option enables channel resources to pins that would otherwise be used for extended grounding on XG-50 fixtures. Because the resource assignments change, this option cannot be used with XG-50 fixtures.

Enables both in-circuit and functional testing.

Enables Interoperability between UNIX and MS Windows.

Enables Agilent Connect Check.

Enables Dual-Well Shared Wiring.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-32

Chapter 8: Reference

Table 8-13 Some enable

< keywords

> statements in the standard config file enable

<keywords> drivethru express fixturing flash70 flash isp incircuit test magic multiple board versions

Functional Description:

Enables the testing of digital devices through series resistors using Agilent TestJet technology. Use the Agilent Drive Thru Test in combination with the Agilent Access

Consultant to identify and selectively remove nonessential probing locations.

Allows Agilent SimPlate Express or cassette fixtures for your board test. If this option is not enabled, only an Agilent SimPlate Fixture can be used.

Enables flash memory programming mode.

Enables flash isp software, which supports new data formats. Test system must have

ControlXTP cards installed to utilize this feature.

Enables automatic in-circuit test generation for systems which do not have it.

Enables Agilent MagicTest circuit analysis mode.

Enables Agilent Multiple Board Versions.

paneltest pld isp polarity check powered testing silicon nails

Enables software that helps you develop tests for multiple-board panels on one fixture.

Enables native PLD programming on the 3070 and supports CPLD programming with

STAPL, SVF, Jam and JBC file types.

Enables Polarity Check testing.

Allows limited powered testing on an Agilent 3072 system (a maximum of two HybridPlus

Cards, one HybridPlus and one ChannelPlus Card, or one HybridPlus and one AccessPlus

Card per module).

Enables automatic generation of silicon nails ITL test files.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-33

Chapter 8: Reference

Table 8-13 Some enable

< keywords

> statements in the standard config file enable

<keywords> testjet throughput multiplier

Functional Description:

Enables the TestJet testing technique on your board. This option is automatically enabled on the Agilent 3072 system.

Allows testing up to four boards simultaneously (one per module), which increases board throughput. It can only be used with the paneltest

option.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-34

Chapter 8: Reference

Compiling the

System and

Standard Config

Files

For changes to the system config file and the standard config file to be enabled, they must be compiled.

NOTE

If codewords have been modified in any way, both the system config and the standard config files must be compiled.

To compile the config files:

1 Login as service3070

(default password is service

)

2 Open BT-BASIC.

3 Compile the system config file. At the command line, enter: a msi btgetenv$ ("AGILENT3070_ROOT") &

"/diagnostics/th1" b compile "config"; testhead

4 Compile the standard config file. At the command line, enter: a msi btgetenv$ ("AGILENT3070_ROOT") &

"/standard" b compile "config"

5 When the config files have compiled without errors, exit BT-BASIC.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-35

Chapter 8: Reference

The

bootptab

File

This section contains:

■

Hardware Addresses , 8-36

■

IP Addresses , 8-37

Hardware Addresses

Each control card has a unique hardware address.

If a control card in the testhead is changed, the bootptab

file must be edited to reflect a changed hardware address.

CAUTION

✸ Changes made to the bootptab

file MUST be done through the Bootp Server program.

Given below is a method to edit the bootptab

file:

1 Login as service3070

(password is service

).

2 Make a backup copy. One example:

NOTE

The environment variable $SystemRoot is usually set to c:\winnt\

a Open Windows Explorer:

• For Windows NT, click Start > Programs >

Windows NT Explorer.

• For Windows 2000, click Start > Programs >

Accessories > Windows Explorer.

b Navigate to: c:\winnt\system32\drivers\etc\

Right-click on the bootptab

file then select copy.

c Navigate to:

C:\Temp

d Right-click and select paste.

An unchanged copy is now in

C:\Temp

3 Open Bootp Server:

a Click Start > Settings > Control Panel.

b Double-click BOOTP Server NT.

4 In the BOOTP Server properties window, click the

Clients tab.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-36

Chapter 8: Reference

5 If a ControlXT Card was removed, delete its hardware address:

a Pull down the Hardware Address menu and select the address of the card you removed.

b Click Delete.

6 Add the hardware address of the ControlXT Card you are installing:

a Click New.

b Enter the hardware address of the ControlXT

Card. The complete hardware address is typically

0060B0B2xxxx

(xxxx = the number on the card).

7 Configure the card’s address:

a In the Available options menu, select the following three options one at a time and click >> to move them to the Configured options menu:

• IP address >>

• Merit dump file >>

• Subnet mask >>

b In the Configured options menu, select each option and click Edit.

Enter:

• IP Address =

10.3.112.4

for module 0

10.3.112.5

for module 1

10.3.112.6

for module 2

10.3.112.7

for module 3

• Merit dump file = This is a comment; enter the module number (e.g., module 2

).

• Subnet mask =

255.255.255.0

8 In the BOOTP Server properties window, click Close.

9 Restart the BOOTP Server:

a From Control Panel click Administrative Tools, then Services.

b Double-click Weird Solutions BOOTP Server.

c Click Stop > Start (wait).

10 Close the Services and Administrative Tools windows.

This completes the procedure.

IP Addresses

The bootptab

file, in conjunction with the hosts file, manages IP addresses for the modules in the testhead.

See

The hosts File on page 8-38 to view IP addresses

for the testhead modules.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-37

Chapter 8: Reference

The

hosts

File

The path to the hosts

file is:

•

$SystemRoot/system32/drivers/etc/hosts

NOTE

$SystemRoot is an environment variable that is usually set to: c:/winnt

The hosts

file must include these IP addresses:

10.3.112.2 testhead1

(System Card)

10.3.112.7 module3

10.3.112.6 module2

10.3.112.5 module1

10.3.112.4 module0

Example 8-1 on page 8-39 shows a sample

hosts

file.

Test Device Communication

To verify connection to each of the devices listed in the hosts

file:

1 Boot the testhead.

2 From a DOS window prompt, enter: ping

< system name

> OR ping

<

IP address

>

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-38

Chapter 8: Reference

Example 8-1 A sample hosts

file

#

# This is a sample HOSTS file used by Microsoft TCP/IP for MS Windows.

#

# This file contains the mappings of IP addresses to host names. Each

# entry should be kept on an individual line. The IP address should

# be placed in the first column followed by the corresponding host name.

# The IP address and the host name should be separated by at least one

# space.

#

# Additionally, comments (such as these) may be inserted on individual

# lines or following the machine name denoted by a '#' symbol.

#

#

#

# For example:

#

102.54.94.97

38.25.63.10

rhino.acme.com

x.acme.com

# source server

# x client host

127.0.0.1

localhost

# 10.3.112.1

UNIX Controller uses this

# 10.3.112.10

MS Windows Controller uses this

10.3.112.2

testhead1

10.3.112.3

hpibgw

10.3.112.4

module0

10.3.112.5

module1

10.3.112.6

module2

10.3.112.7

module3

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-39

Chapter 8: Reference

Device Files

This section contains:

■

Introduction , 8-40

■

Location of Device Files , 8-40

■

If a DUT Power Supply is Replaced , 8-40

■

DUT Power Supply Device Files , 8-41

Introduction

Management of devices on MS Windows controllers are very different than on UNIX controllers.

On MS Windows controllers, most devices are managed invisibly by the operating system. A small number of devices (primarily GPIB) are mirrored in the

$AGILENT3070_ROOT/dev

directory so that the 3070 software will execute properly.

Location of Device Files

Device files can be found in the directory:

$AGILENT3070_ROOT/dev

and are listed in Table 8-14

.

Table 8-14

Device Files in $AGILENT3070_ROOT/dev gpio1 hpib1 dmm null ps0. . . ps11 scope hp3488 dmm_ref synth

If a DUT Power Supply is Replaced

Change the appropriate ps

< x

> file if the GPIB address of any power supply changes.

Example 2 shows the contents of the default ps0

file. In the line:

7,22

22

represents the GPIB address.

Example 8-2 Contents of the default ps0 file

!!!!

26 0 1 664499475 0000 hpib7,22

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-40

Chapter 8: Reference

DUT Power Supply Device Files

See

Table 8-18 on page 8-49 for DUT power supply

GPIB addresses and device files.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-41

Chapter 8: Reference

Vacuum Control

Location of Vacuum Control Statements

These are contained in the system config file:

$AGILENT3070_ROOT/diagnostics/th1/config

Vacuum Control Specifics

The relay <x> controls vacuum <y>

statements need to match the actual hardware configuration after the customer decides how to implement vacuum control.

For testheads without internal vacuum valves, the default statements are: relay 1 controls vacuum 2,3 relay 2 controls vacuum 0,1

For testheads with the Agilent E9945A two-module internal vacuum system, the default statements are: relay 1 controls vacuum 3 relay 2 controls vacuum 2

For testheads with the Agilent E9946A four-module internal vacuum system, the default statements are: relay 1 controls vacuum 3 relay 2 controls vacuum 2 relay 3 controls vacuum 1 relay 4 controls vacuum 0

There is nothing special about the defaults except that each matches a configuration shown in the site preparation manual.

See the Agilent 3070 / 79000 Family Site Preparation

Manual 03066-90114 for a drawing of this default vacuum hookup.

Modify the relay statements so they will work with your customer's hardware.

For example, to turn on all four vacuum ports with a single relay, the following statement might be used in the system config file: relay 1 controls vacuum 0,1,2,3

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-42

Chapter 8: Reference

Rotating the

Testhead

CAUTION

✸ Remove all objects, including the monitor / keyboard support arms, from the rotational path of the testhead.

During rotation, should the testhead hit anything, damage could result.

CAUTION

✸ Remove the shipping bolts before attempting to rotate the testhead. Otherwise, damage can result.

1 Open the pod door.

2 Press and hold the testhead rotation switch inside the pod until the testhead rotates to the desired position.

There is also sometimes a testhead rotation switch on the rear of the pod.

NOTE

The PDU must be turned on for the testhead rotation switch to be active.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-43

Chapter 8: Reference

Testhead Cards

See

Table 8-15 for available testhead cards with

diagnostics names, cards <keywords>

statements, pattern applications rates and part numbers.

If Replacing the ControlXT Card

■

■

The ROM from the old card must be removed and installed on the new card.

Its hardware address in the system software must be changed.

NOTE

DO NOT change the hardware address of the

System Card.

System Card / Control Card LAN Information

See

Testhead LAN and Serial Port MUX on page 8-59.

Table 8-15 For MS Windows systems – supported testhead cards with diagnostics names, cards <keywords>

statements, pattern applications rates and part numbers

Card Type

Access

Analog

ASRU

Control

Hybrid

DGN

Config

Screen

Name

Access

Analog cards <keywords>

Config File access analog

Statement in the System

Ana_DD analog double density

ASRU_C asru c revision

Ctl_Xt control xt

H_StdDD hybrid standard double density

Pattern

Application

Rate (MP/s)

6/12/20

6/12/20

6/12/20

Part Number of the Card

E1061-66501

E1121-66526

E4000-66542

6/12/20 03066-66532

6/12/20 E4000-66512

6 E4000-66540

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-44

Chapter 8: Reference

Table 8-15 For MS Windows systems – supported testhead cards with diagnostics names, cards <keywords>

statements, pattern applications rates and part numbers (continued)

H_StdDD2 hybrid standard double density

H_PpuDD hybrid standard double density

HPpuDD2 hybrid standard double density

H_AdvDD hybrid advanced double density

HAdvDD2 hybrid advanced double density

H_HA_DD hybrid high accuracy double density

6 E4000-66550

6 E4000-66546

6 E4000-66550

12 E4000-66544

12 E4000-66550

20 E4000-66545

HHADD2 hybrid high accuracy double density

20 E4000-66550

HStd_32 hybrid standard double density 32

6 E9900-66502

HAdv_32 hybrid advanced double density 32

12 E9900-66502

H_HA_32 hybrid high accuracy double density 32

20 E9900-66502

HPpu_32 hybrid high accuracy double density 32

20 E9900-66502

CAUTION

✸ If a serial

keyword exists in the system config. file, then serial ports

statements MUST be defined in the standard config file

/var/hp3070/diagnostics/th1/config

for each STC Plus Card. Also the serial test codeword MUST be in the

/var/hp3070/bin/.enable

file.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-45

Chapter 8: Reference

Table 8-15 For MS Windows systems – supported testhead cards with diagnostics names, cards <keywords>

statements, pattern applications rates and part numbers (continued)

STC_B

STC_B serial b revision serial b revision with cables

6/12/20 E1085-66502

6/12/20 E1085-66502 with

E1093-61601

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-46

Chapter 8: Reference

DUT Power

Supplies

Voltage Ranges

DUT power supplies are set at the factory to one of two configurations:

• Option 220 for line voltages of 200–220 volts.

• Option 240 for line voltages of 230–240 volts.

DUT Power Supplies Allowed

See

Table 8-16 for the DUT power supplies allowed.

Table 8-16 DUT power supplies allowed

Product No.

44940A

44941A

E4034A

E3784A

Model No.

6624A

6621A

6634A

6642A

Description

4 outputs: 2 @ 0-7 V, 0-5 A or 0-20 V, 0-2 A and 2 @ 0-20 V, 0-2 A or 0-50 V, 0-0.8 A

2 outputs: 0-7 V, 0-10 A and 0-20 V, 0-4 A

1 output: 1-100 V, 0-1 A

1 output: 0-20 V, 0-10 A

Module Mappings

See

Table 8-17

for default DUT power supply mappings for each module.

Table 8-17 Default DUT power supply mappings for each module (rear view of testhead)

Module 0 supplies hp6624 13 to 16 asru channels 1 to 4

! supplies hp6621 13 to 14 asru channels 1 to 4

Module 2

! supplies hp6624 5 to 8 asru channels 1 to 4 supplies hp6621 5 to 6 asru channels 1 to 4

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-47

Chapter 8: Reference

Table 8-17 Default DUT power supply mappings for each module (rear view of testhead) (continued)

! supplies hp6624 23 to 24 asru channels 5 to 6 supplies hp6621 23 asru channels 5 to 6

! supplies hp6634 23 asru channels 5

! supplies hp6634 24 asru channels 6

! supplies hp6642 23 asru channels 5 to 6

Module 1 supplies hp6624 9 to 12 asru channels 1 to 4

! supplies hp6621 9 to 10 asru channels 1 to 4

! supplies hp6624 21 to 22 asru channels 5 to 6

! supplies hp6621 21 asru channels 5 to 6 supplies hp6634 21 asru channels 5 supplies hp6634 22 asru channels 6

! supplies hp6642 21 asru channels 5 to 6

! supplies hp6624 19 to 20 asru channels 5 to 6

! supplies hp6621 19 asru channels 5 to 6 supplies hp6634 19 asru channels 5 supplies hp6634 20 asru channels 6

! supplies hp6642 19 asru channels 5 to 6

Module 3 supplies hp6624 1 to 4 asru channels 1 to 4

! supplies hp6621 1 to 2 asru channels 1 to 4 supplies hp6624 17 to 18 asru channels 5 to 6

! supplies hp6621 17 asru channels 5 to 6

! supplies hp6634 17 asru channels 5

! supplies hp6634 18 asru channels 6

! supplies hp6642 17 asru channels 5 to 6

The commented ("!") statements illustrate that you cannot assign a power supply number (1 through 24) more than once in a testhead, and you cannot assign a channel number (1 through 6) more than once in a module.

For 307X systems with a support bay, if it is necessary to determine which DUT power supply is wired to which module, the DUT/ASRU cables E4000-61602 are labeled on both ends with the module numbers to which they are routed.

Agilent 317X systems use cable numbers E4000-61606 and E1170-61607.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-48

Chapter 8: Reference

GPIB Addresses and Device Files

If the DUT power supplies are functional, a supply’s

GPIB address can be determined by tracing the cabling to determine which supply is connected to the module.

If the supply has a front panel and is accessible, the

GPIB address can be read from the front panel of the supply.

Table 8-18 lists DUT power supply GPIB addresses and

device files. See If a DUT Power Supply is Replaced

Table 8-18 DUT power supply GPIB addresses and device files

Power Supply Connection

Module 0, asru channels 1-4

Module 1, asru channels 1-4

Module 2, asru channels 1-4

Module 3, asru channels 1-4

Module 0, asru channel 5 or 5-6

Module 0, asru channel 6

Module 1, asru channel 5 or 5-6

Module 1, asru channel 6

Module 2, asru channel 5 or 5-6

Module 2, asru channel 6

29

1

2

27

28

25

26

23

24

GPIB Address

22

on page 8-40 for more information about DUT power

supply GPIB addresses.

NOTE

The customer has the flexibility to modify the

DUT power supply GPIB addressing.

Device File

$AGILENT3070_ROOT/dev/ps0

$AGILENT3070_ROOT/dev/ps1

$AGILENT3070_ROOT/dev/ps2

$AGILENT3070_ROOT/dev/ps3

$AGILENT3070_ROOT/dev/ps4

$AGILENT3070_ROOT/dev/ps5

$AGILENT3070_ROOT/dev/ps6

$AGILENT3070_ROOT/dev/ps7

$AGILENT3070_ROOT/dev/ps8

$AGILENT3070_ROOT/dev/ps9

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-49

Chapter 8: Reference

Table 8-18 DUT power supply GPIB addresses and device files (continued)

Module 3, asru channel 5 or 5-6

Module 3, asru channel 6

3

4

$AGILENT3070_ROOT/dev/ps10

$AGILENT3070_ROOT/dev/ps11

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-50

Chapter 8: Reference

To Change DUT Power Supply GPIB Addresses

For 307X systems only where the power supplies are mounted in a support bay:

• Open the support bay and find the correct power supply.

Systems without support bays have the power supplies mounted in the testhead:

• Panels must be removed from the testhead in order to access the front panel of the power supplies.

To change the GPIB address, press ADDR (beside the display), enter the desired address on the ENTRY keypad, and then press ENTER on the ENTRY keypad.

NOTE

If a power supply is split between two modules, the default GPIB address (and device file) is the one for the lower-numbered module.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-51

Chapter 8: Reference

Controller Cables and Devices

There are two supported MS Windows testhead controllers:

For the Kayak XU700, use

Figure 8-2 on page 8-53 with

Table 8-19 on page 8-54.

For the Visualize P600, use

Figure 8-3 on page 8-56 with

Table 8-20 on page 8-57.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-52

Chapter 8: Reference

Figure 8-2 Kayak XU700 cabling diagram

N

A

6

Optional

Bar Code Scanner

Keyboard

3

G

7, K

Mouse

M

1

L

B

2

5

Digi MUX for

Optional

Serial Devices

8

Optional

Modem

F

Strip

Printer

C

E

D

Private LAN

GPIB

Optional SCSI

Optional Site LAN

Not

Used

Optional

Parallel

Printer

I J

Video

4

Monitor

Power

Supply

O

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-53

Chapter 8: Reference

Table 8-19 Kayak XU700 cables and devices

K

L

I

J

G

H

E

F

C

D

A

B

Cables

Figure 8-2

Reference

M

Part Number

E4000-61628

8120-6713

8120-8728

E9927-61607

8120-3445

03066-61629

8120-6751

Not Used

03066-61640

D2800-80006

8120-6794

8120-5371 or . . .

8120-3543

E4000-61630

Description

Control Cable

Footswitch Extension Cable, RJ-11

LAN Cable, RJ-45 to RJ-45

4-meter GPIB Cable (for TAMS 70488-10 card)

1-meter GPIB Cable

Strip Printer Cable, RS-232, DB9(f) to DB25(m) cross-conn., 3-m

Bar Code Scanner Cable

Not Used

Video Extension Cable (1 for 327X / 79000, 2 for 307X / 317X)

Video Cable

Keyboard / Mouse Extension Cable

6-meter LAN Cable, BNC to BNC (for 307X and 317X) or . . .

2-meter LAN Cable, BNC to BNC (for 327X)

LAN Cable, BNC to SMB for ControlXT Cards

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-54

Chapter 8: Reference

Table 8-19 Kayak XU700 cables and devices (continued)

N

O

E4000-61629 LAN Cable, SMB to SMB for ControlXT Cards

8120-1763 2 ea. (327X) or 8120-1763 + 8120-4188 (307X and 317X) power cords

7

8

5

6

3

4

1

2

Devices

Figure 8-2

Reference

Part Number

44902-60000

E4000-62102

0950-2946

E9900-69301

1250-0207

1250-2076

A4030E

1250-3154

1250-3156

Description

Footswitch with Cable

Footswitch Adapter

Bar Code Scanner Wedge (optional) (p/o E3786A)

NEC MultiSync LCD Flat Panel Display

50-ohm BNC Load / Termination

50-ohm SMB Load / Termination

Keyboard and Mouse

Digi 77000707 EIA-232 AccelePort 8p controller PCI card

Digi 76000527 EIA-232 AccelePort 8p interface box

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-55

Chapter 8: Reference

Figure 8-3 Visualize P600C cabling diagram

7

K

Mouse

Keyboard

3

Bar Code

Scanner (Opt)

Testhead - ControlXT Cards

G

M

Mod 3 Mod 2 Mod 1 Mod 0

N

6

A

E

System Card

03066-66581

A B C D E F

1

Footswitch

2

L

B 5

Hub

10

C

Serial A

To Optional

External Modem

To Mouse

To Keyboard

DUT P.S.

(Opt)

DUT P.S.

(Opt)

DUT P.S.

D

To Optional

External LAN

(GPIB) To DUT

Power Supply

To Testhead LAN

(Empty)

(Empty)

P8

9

8

P1

Serial B

To Strip Printer

To Optional

Parallel Printer

These connectors not used

F

4

Video

Monitor

To Video Monitor

To Optional

SCSI/RS-232 MUX

Strip

Printer

Power O

Supply

I

J

Serial Devices

Visualize P600C

Workstation

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-56

Chapter 8: Reference

Table 8-20 Visualize P600C cables and devices

K

L

I

J

G

H

E

F

C

D

A

B

Cables

Figure 8-3

Reference

M

Part Number

E4000-61628

8120-6713

8120-8728

E9927-61607

8120-3445

03066-61629

8120-6751

Not Used

03066-61640

D2800-80006

8120-6794

8120-5371 or . . .

8120-3543

E4000-61630

Description

Control Cable

Footswitch Extension Cable, RJ-11

LAN Cable, RJ-45 to RJ-45

4-meter GPIB Cable (for TAMS 70488-10 card)

1-meter GPIB Cable

Strip Printer Cable, RS-232, DB9(f) to DB25(m) cross-conn., 3-m

Bar Code Scanner Cable

Not Used

Video Extension Cable (1 for 327X / 79000, 2 for 307X / 317X)

Video Cable

Keyboard / Mouse Extension Cable

6-meter LAN Cable, BNC to BNC (for 307X and 317X) or . . .

2-meter LAN Cable, BNC to BNC (for 327X)

LAN Cable, BNC to SMB for ControlXT Cards

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-57

Chapter 8: Reference

Table 8-20 Visualize P600C cables and devices (continued)

N

O

E4000-61629 LAN Cable, SMB to SMB for ControlXT Cards

8120-1763 2 ea. (327X) or 8120-1763 + 8120-4188 (307XPC and 317XPC) power cords

7

8

5

6

9

10

3

4

1

2

Devices

Figure 8-3

Reference

Part Number

44902-60000

E4000-62102

0950-2946

E9900-69301

1250-0207

1250-2076

A4030E

E4000-37900

A1658-62016

J3128A

Description

Footswitch with Cable

Footswitch Adapter

Bar Code Scanner Wedge (optional) (p/o E3786A)

NEC MultiSync LCD Flat Panel Display

50-ohm BNC Load / Termination

50-ohm SMB Load / Termination

Keyboard and Mouse

SCSI/RS-232 w/E4000-37911 pwr sup, SCSI-2 cable (p/o E3788A)

SCSI Terminator

Agilent AdvanceStack 10Base-T Hub-8E with 0950-3612 power supply

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-58

Chapter 8: Reference

Testhead LAN and

Serial Port MUX

Testhead LAN IP Address

The testhead LAN IP address is

10.3.112.10

with a subnet mask of

255.255.255.0

System Card / Control Card LAN Information

The System Card and the ControlXT Cards communicate via a private LAN.

Because the System Card and ControlXT Card IP addresses are local to each system, their assigned addresses are the same from one system to the next.

However, their hardware addresses ( ha

) are unique in each system.

The hardware address of the System Card is printed on its sheet-metal panel.

The last four digits of the ControlXT Card's hardware address are printed on one of its ROMs; it's the last line

(hexadecimal number) on the label.

To verify communication to the testhead (system card), use the ping

command.

1 Power-on the testhead.

2 From a DOS prompt, enter: ping 10.3.112.2

If the communication test fails, check that the LAN ports in the testhead are terminated properly.

See

Controller Cables and Devices on page 8-52 for

the locations of the LAN terminations.

Serial Port MUX

The Kayak 700 controller contains a Digi AccelePort

Xp serial port MUX as standard equipment.

This 8-port EIA-232 serial MUX adapter provides eight

8-pin RJ-45 EIA-232 ports for supporting PPU, JOT, and other optional serial-controlled devices.

CAUTION

✸ Many SCSI adapters use the same HD-68 connector type as the AccelePort Xp. DO NOT plug SCSI devices into the Digi connector, and

DO NOT plug Digi peripheral cables into SCSI adapters. Damage can result.

Connect cabling for serial devices as listed in

Table 8-21 or communication errors can result.

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-59

Chapter 8: Reference

Table 8-21 Connector box MUX assignments

Serial Port

1

2

3—4

5—8

Reserved For

Pay-Per-Use (PPU)

JOT Board Handler

JOT Bar Code Readers

Other EIA-232 Devices

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows NT and 2000) 8-60

Numerics

Index

A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z

Symbols

$AGILENT3070_ROOT

,

8-3

$AGILENT3070_ROOT Environment Variable

,

6-2

$AGILENT3070_ROOT on MS Windows

,

6-5

Numerics

3070 booting a controller

,

2-2

directory structure

,

1-4

hardware overview

,

1-8

Program Software

,

1-5

quality reporting software

,

1-6

restoring from a full backup tape

,

4-19

software

,

1-5

Starting the system

,

2-2

test programming languages

,

1-5

3070 directory structure

,

1-4

3070 Networking Facilities

,

7-2

3070 Private LAN IP Addresses

,

7-5

3070 programs

,

1-6

3070 System IP Addresses

,

7-3

3070 User account

,

5-5

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows® NT and 2000)

A

Adding a group account

,

5-7

Adding a user account

,

5-6

additional system setup tasks

,

3-6

Administering Agilent 3070 MS Windows Systems

,

8-1

Administering Datalogging

,

5-10

administration tasks

,

1-2

Administrators

How many are necessary?

,

1-2

Agilent Software License Activation

,

3-13

Flow Diagram

,

3-14

License Activation

,

3-16

License Management

,

3-13

License Redemption

,

3-15

Troubleshooting

,

3-17

Validation

,

3-16

Agilent3070 Operators (group name)

,

5-4

Agilent3070 Users (group name)

,

5-4

AGILENT3070_ROOT system variable

,

5-8

Analog Test Language

,

1-6

ATL

,

1-6

1-1

Index

Numerics

B

A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z backing up the system creating a backup strategy

,

4-3

back-slash

,

8-8

Backup Strategy planning

,

4-3

Backup tape making

,

4-9

,

4-10

restoring from

,

4-14

board configuration file

,

8-29

Boot disks creating

,

4-6

Boot Recovery Diskettes creating

,

4-7

when to create

,

4-6

Booting a 3070 Controller

,

2-2

Booting the Testhead

,

2-3

bootptab file

,

8-36

,

8-37

Bridges, Routers, and Gateways

,

7-9

BT-BASIC

,

1-5

edit with

,

8-9

exit

,

8-9

open

,

8-9

open a file

,

8-9

save in

,

8-9

BT-BASIC Quick-Reference

,

8-17

BT-BASIC statements

,

8-17

C calibrate (User account)

,

5-5

cards Statements

,

8-27

Change DUT Power Supply GPIB Addresses

,

8-51

Client

,

7-10

Client/Server

,

7-10

Clients

,

7-10

codewords

,

8-25

,

8-31

Commands

,

7-13

compile

,

8-35

Compile the Two Config Files

,

8-25

configuration file tld.conf

,

5-10

Configure Networking

,

7-2

Configuring local area connection

,

3-18

network adapter card

,

3-18

connect statements

,

8-30

Connector box MUX assignments

,

8-60

Controller disconnecting power

,

2-4

Controller Cables and Devices

,

8-52

ControlXT Card

,

8-37

,

8-59

Copying configuration information

,

8-15

Creating Boot Disks

,

4-6

Creating boot Recovery Diskettes

,

4-7

Creating Boot Recovery Disks

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows® NT and 2000) 1-2

Index

Numerics A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z tools and material

,

4-6

E

D

Determine the Value of the Root Directory Environment

Variable

,

8-3

device files

,

8-40

Device Files in $AGILENT3070_ROOT/dev

,

8-40

directories

,

8-6

directory structure

,

1-4

Disaster recovery making a full backup tape

,

4-10

options

,

4-20

preparing for

,

4-4

Disconnecting power

,

2-4

Display the Logon Status from a Current Login

,

8-2

domain

,

5-8

Domain Names

,

7-11

domain, with operator user

,

5-8

DUT power supplies

,

8-47

,

8-48

DUT Power Supply Device Files

,

8-41

DUT power supply GPIB addresses and device files

,

8-49

DUT power supply GPIB addressing

,

8-49

DUT power supply mappings

,

8-47

Edit in BT-BASIC

,

8-9

Edit the System Config File

,

8-9

Editing Files

,

8-8

enable

,

8-32

enable statements

,

8-32

environment variable

,

8-3

F file path usage in a MS Windows Korn shell window

,

6-5

File Path Usage in a MS-DOS Command Prompt Window

,

6-6

File Path Usage in a UNIX BT-BASIC (or MS Windows

BT-BASIC) Window

,

6-3

File Path Usage in a UNIX terminal Window

,

6-3

File system maintaining

,

5-3

maintenance tasks

,

5-3

file system management

,

5-3

files tld.log

,

5-10

forward-slash

,

8-8

G

GPIB Addresses

,

8-49

Group Account

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows® NT and 2000) 1-3

Index

Numerics

adding

,

5-7

groups

,

5-4

A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z

Korn shell quick reference

,

8-18

Group accounts

,

5-5

L

I

H hardware address

,

8-36

Hardware Addresses

,

8-36

Help

,

5-3

Hosts and Nodes

,

7-10

hosts file

,

8-38

,

8-39

How to Restore a System From a Full Backup Tape

,

4-22

incremental backup

,

4-3

Install codewords

,

8-25

Installing Patches

,

5-11

installing patches

,

5-11

IP Address

,

8-37

IP address

,

8-59

IP Addresses

,

8-37

K

Kayak XU700 cables and devices

,

8-54

LAN advantages

,

1-5

LAN Cable and Coupler

,

7-7

LAN networking software

,

1-5

line frequency Statement

,

8-27

Local Area Connection

,

3-18

configuring and connecting

,

3-18

Local Area Connection 2

,

7-7

Location of Device Files

,

8-40

Location of Vacuum Control Statements

,

8-42

Logging-On as service3070

,

8-2

logon

,

8-2

Logon as service3070

,

8-2

M

Maintaining the File System

,

5-3

Making a backup tape tools and materials

,

4-9

Making a disaster recovery full backup tape

,

4-10

Making a Full Backup Tape

,

4-9

Merit dump file

,

8-37

MS Windows Quick-Reference

,

8-16

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows® NT and 2000) 1-4

Index

Numerics A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z

MS Windows systems – supported testhead cards

,

8-44

prerequisites

,

5-1

N

Network

,

7-10

Network Components

,

3-12

Network configuration information gathering

,

3-8

Network services

,

7-12

new software

,

5-11

NT Korn Shell Quick Reference

,

8-18

NUTCROOT alias

,

1-5

O objectives

,

4-1

,

5-1

oil (User account)

,

5-5

oil login

,

2-3

Open a File in BT-BASIC

,

8-9

operator (User account)

,

5-5

,

5-8

operator logging in across a domain

,

5-8

operator login

,

2-3

P patches

,

5-11

Preparing for disaster recovery

,

4-4

© Agilent Technologies 2001–2002 Administering Agilent 3070 Systems (MS Windows® NT and 2000)

Q quality reporting software

,

1-6

R relay controls vacuum statements

,

8-42

relay Statement

,

8-27

Replacing the ControlXT Card

,

8-44

Resolve the Standard Config File

,

8-10

Restoring a 3070 System from a full backup tape

,

4-19

Restoring Specific Data

,

4-14

Restoring Specific Data from a Backup Tape

,

4-14

Restoring specific data from a backup tape

,

4-14

Root Directory Environment Variable

,

6-2

Rotating the Testhead

,

8-43

S

Serial Port MUX

,

8-59

Server

,

7-10

service3070 (User account)

,

5-5

setting up Windows 2000

,

3-3

setting up Windows 2000 Professional

,

3-5

1-5

Index

Numerics A B

C D

E F G H

I J K L M N

O P Q R S T

U V

W X

Y Z setup wizard tasks

,

3-3

Shut Down the Controller

Controller shut down

,

2-4

Shutting Down the System

,

2-4

Site Preparation documentation

,

8-1

software overview

,

1-3

Windows 2000 operating system capabilities

,

1-3

standard config file

,

8-10

,

8-29

standard config file syntax

,

8-29

Statements in the System Config File

,

8-27

std3070 (User account)

,

5-5

Subnet mask

,

8-37

supplies Statements

,

8-28

system preparing to set up

,

3-2

System Administration tasks

,

1-2
