For users and contractors
Thank you for purchasing this instantaneous water heater from AEG Haustechnik. You have chosen a
high-grade device made in Germany.
Even during the development and manufacture, AEG Haustechnik recognises the high value of manufacturing
processes that are environmentally responsible and treat resources with care. Thanks to many product
innovations, devices made by AEG Haustechnik are amongst the most energy-efficient in their class.
1.
Operating instructions
1.1
Equipment description
The instantaneous water heater DDLE Basis heats water as it flows through the equipment. You can adjust
the DHW outlet temperature anywhere between approx. 30 °C and approx. 60 °C via a temperature selector.
From a flow rate of approx. 3 l/min onwards, the control regulates the correct heating output, subject to the
temperature selection and the cold water temperature.
1.2
Vital facts in brief
s4EMPERATURESELECTOR
Turning the selector lets you freely choose the required temperature.
Wash basin ( 35 °C )
Shower ( 40 °C)
Bath ( 45 °C )
Sink ( 55 °C )
Should the outlet temperature fail to reach the required level, when the tap is fully opened, and the
temperature selector has been set to maximum (temperature selector turned fully clockwise), then more water
flows through the equipment than can be heated by the internal heater cartridge (output limit 11;13,5; 18;
21; 24 or 27 kW). In such cases, reduce the flow rate at the tap accordingly.
s4EMPERATURELIMIT
A contractor can set the temperature limit to 43 °C at the device. You can still adjust the temperature selector
across its entire range. The outlet temperature will be permanently limited to 43 °C.
A temperature range 30 °C to 43 °C can be selected.
1.3
!
1.4
!
Safety information
4HEREISARISKOFSCALDINGATOUTLETTEMPERATURESINEXCESSOFª#
Where children or persons with limited physical, sensory or mental capabilities are to be allowed to control
this equipment ensure that this will only happen under supervision or after appropriate instructions by a
person responsible for their safety. Children should be supervised to ensure that they do not play with the
equipment - risk of scalding.
Important information
)FTHEWATERSUPPLYTOTHEINSTANTANEOUSWATERHEATERHASBEENINTERRUPTEDEGBECAUSEOFARISKOFFROST
ORWORKONTHEWATERSYSTEMTAKETHEFOLLOWINGMEASURESPRIORTOTAKINGTHEEQUIPMENTBACKINTOUSE
1. Remove fuses or trip the appropriate MCBs.
2. Open a tap downstream of the equipment long enough, until all air has been vented from the equipment
and its cold water supply pipe.
3. Replace the fuses or reset the relevant MCBs.
22
For users and contractors
1.5
DHW output
Subject to season, the following maximum mixed water or draw-off capacities result for different cold water
temperatures (see Table 1):
ϑ1 = Cold water inlet temperature
ϑ2 = Mixed water temperature
ϑ3 = Outlet temperature.
!VAILABLETEMPERATUREEGFOR
Shower, washing hands, filling a bath, etc.
Kitchen sink and when using thermostatic valves.
ϑ2 = 38 °C
11
13.5
l/min *
5.0
6.0
5.6
6.9
6.6
8.1
ϑ3 = 60 °C
11
13.5
l/min *
3.6
3.1
3.8
3.4
4.2
kW
18
21
24
27
kW
18
21
24
27
ϑ1
ϑ1
6 °C
8.0
9.4
10.7 12.1
6 °C
4.8
5.6
6.4
7.2
10 °C
9.2
10.7 12.3 13.8
10 °C
5.2
6.0
6.9
7.7
14 °C
10.7 12.5 14.5 16.1
14 °C
5.6
6.5
7.5
8.4
Table 1
* Table values relative to a rated voltage of 400 V. The outlet volume is subject to the available supply pressure
and the available mains voltage.
1.6
Recommended settings when using a thermostatic valve
To safeguard the function of the thermostatic valves, set the instantaneous water heater to its maximum
temperature (temperature selector to the right end stop).
1.7
First aid in case of faults
s Check all fuses.
s Check taps/valves and shower heads for scaling or contamination (see also "6. Troubleshooting").
Where a contractor is required, he can better and more speedily remedy the fault if you provide him with
some of the details from the type plate ( A 20):
DDLE Basis . .
1.8
!
1.9
!
No.: . . . . . . - . . . .
-. . . . .
Maintenance and care
-AINTENANCEWORKEGCHECKINGTHEELECTRICALSAFETYMUSTONLYBECARRIEDOUTBYAQUALIlEDCONTRACTOR
A damp cloth is sufficient for cleaning the casing. Do not use abrasive or corrosive cleaning agents.
Operating and installation instructions
+EEPTHESEINSTRUCTIONSSAFELYANDPASSTHEMONTOANYNEWUSERSHOULDTHEEQUIPMENTCHANGEHANDS
,ETYOURCONTRACTORCHECKTHEIRCONTENTINCONJUNCTIONWITHANYMAINTENANCEORREPAIRWORK
23
For contractors
2.
Installation instructions
Only trained and authorised experts must install the device and make the electrical connection under full
observance of these installation instructions.
2.1
Equipment layout
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2.2
A
-
O
Temperature selector
Equipment cap
Base, back panel
DHW compression fitting
Cold water compression fitting
Top, back panel
Electronics
Coding card for output selection for
the DDLE Basis 18/21/24
LED diagnostic “traffic light” for operating
and fault indications
Plug-in position from the temperature
selector cable
Safety pressure limiter (AP 3) with reset
button
Mains terminal
Knock-out for power connection from above
Fixing toggle
High limit safety cut-out (STB) with reset
button
Heating system
17
18
19
20
21
22
23
24
Flow sensor
Temperature selector plug “set T”
Type plate
Mounting bracket
Stud for mounting bracket
Cable grommet (power cable from above/below)
Twin nipple (cold water with shut off valve)
Flat packing
25 Screws/rawl plugs for fixing the back panel in
case of water connection on finished walls
26 Second flow limiter, only for the DDLE Basis
18/21/24 (secured to the cold water pipe)
27 Installation and operating instructions
28
29
30
31
Installation template
Sieve
Flow limiter
Profile washer
Brief description
This electronically regulated instantaneous water heater is a pressure device for the heating of cold water to
DIN 1988 that can supply one or several draw-off points.
The bare wire heating system is suitable for hard and soft water areas (for application range, see
“5.2 Application areas”).
2.3
!
2.4
Important information
s !IRINTHECOLDWATERSUPPLYCANDESTROYTHEBAREWIREHEATINGSYSTEMINSIDETHEEQUIPMENTORCANTRIP
THESAFETYSYSTEM)FTHEWATERSUPPLYTOTHEINSTANTANEOUSWATERHEATERHASBEENINTERRUPTEDEG
BECAUSEOFARISKOFFROSTORWORKONTHEWATERSYSTEMTAKETHEFOLLOWINGMEASURESPRIORTOTAKINGTHE
EQUIPMENTBACKINTOUSE
2EMOVEFUSESORTRIPTHEAPPROPRIATE-#"S
/PENANDCLOSEATAPDOWNSTREAMOFTHEEQUIPMENTSEVERALTIMESUNTILALLAIRHASBEENVENTED
FROMTHECOLDWATERSUPPLYLINEUPSTREAMANDTHEEQUIPMENT
2EPLACETHEFUSESORRESETTHERELEVANT-#"S
4HEINSTANTANEOUSWATERHEATERISEQUIPPEDWITHANAIRDETECTORWHICHTOTHEGREATESTEXTENT
PREVENTSDAMAGETOTHEHEATINGSYSTEM
)FDURINGOPERATIONAIRISDRAWNINTOTHEINSTANTANEOUSWATERHEATERTHEEQUIPMENTSHUTSDOWN
THEHEATINGLOADFORONEMINUTETHEREBYPROTECTINGTHEEQUIPMENT
s 4APS
n $IRECTDRAWOFFTAPFORINSTANTANEOUSWATERHEATER!$%O7$MONOLEVERMIXERWITH
BATHHANDSHOWERCHANGEOVERPARTNO
4HEINSTALLATIONMAYBECARRIEDOUTUSINGCOMMERCIALLYAVAILABLEPRESSURETESTEDTAPS
&ORTHERMOSTATICPRESSURETESTEDVALVESSEEINFORMATION2ECOMMENDEDADJUSTMENT
s !LWAYSCAREFULLYOBSERVEALLINFORMATIONINTHESEOPERATINGANDINSTALLATIONINSTRUCTIONS
4HESECONTAINIMPORTANTINFORMATIONREGARDINGSAFETYOPERATIONINSTALLATIONANDMAINTENANCEOFTHIS
EQUIPMENT
Instructions and regulations
s 4HEINSTALLATIONWATERANDELECTRICALWORKANDCOMMISSIONINGASWELLASTHEMAINTENANCEOFTHIS
equipment, must only be carried out by a qualified contractor in accordance with these instructions.
s 0ERFECTFUNCTIONANDSAFEOPERATIONCANONLYBEASSUREDWHENUSINGORIGINALACCESSORIESANDSPAREPARTS
intended for this equipment.
s /BSERVEALLLOCALLYAPPLICABLEINSTRUCTIONSANDREGULATIONSREGARDINGWATERANDELECTRICALCONNECTIONSSUCH
as DIN VDE 0100, DIN 1988, EN 806, DIN 4109, DIN 44851.
24
For contractors
!
s /BSERVEALLREGULATIONSOFYOURLOCALWATERANDELECTRICITYSUPPLYCOMPANIES
s /BSERVETHETYPEPLATE ( A 19).
s 3EE3PECIlCATION
4HESPECIlCELECTRICALRESISTANTOFTHEWATERUSEDMUSTNOTFALLBELOWTHATSTATEDONTHETYPEPLATE)NA
LINKEDWATERNETWORKOBSERVETHELOWESTELECTRICALWATERRESISTANCESEE!PPLICATIONAREAS9OUR
WATERSUPPLYCOMPANYWILLADVISEYOUOFTHESPECIlCELECTRICALWATERRESISTANCEORCONDUCTIVITY
s )NSTALLTHEDEVICEONLYINANENCLOSEDROOMFREEFROMTHERISKOFFROST3TORETHEDEVICEINAROOMFREEFROM
the risk of frost, as water residues remain inside the device.
s 4HEPROTECTION)0HOSEPROOFCANONLYBEENSUREDWITHACORRECTLYlTTEDCABLEGROMMET
s Water installation:
n -ATERIALOFTHECOLDWATERLINE
Steel, copper or plastic pipework.
n -ATERIALOFTHE$(7LINE
Copper or plastic pipework*.
* The instantaneous water heater can reach operating temperatures up to 60°C. In case of faults, loads
up to 95 °C / 1.2 MPa can occur temporarily in the installation. The plastic pipework used must be suitable
for such temperatures/pressure.
s !SAFETYVALVEINTHEHOTWATERPIPEISNOTPERMISSIBLE
s .EVEROPERATEWITHPREHEATEDWATER
s .EVERUSETAPSVALVESFOROPENVENTEDEQUIPMENT
s &ORTHERMOSTATICVALVESSEE2ECOMMENDEDADJUSTMENT
s Electrical installation:
s 5SEONLYPERMANENTLYWIREDPOWERCABLES
s 4HEEQUIPMENTMUSTBEABLETOBESEPARATEDFROMTHEPOWERSUPPLYFOREXAMPLEBYFUSESTHATDISCONNECT
all poles with at least 3 mm contact separation.
25
For contractors
3.
Standard installation for contractors
Power: Unfinished walls - top; Water: Unfinished walls
3.1
General installation information
At the factory, the device is prepared for a power connection from the top from an installation below
the plaster (see Fig. C - I ):
s 4HEDEVICEISSUITABLEFORABOVEORUNDERSINKINSTALLATION C .
s 7ATERCONNECTIONTHREADEDlTTINGSBELOWTHEPLASTER
s 0OWERCONNECTIONBELOWTHEPLASTERINTHEUPPERDEVICEAREA
Important information regarding the DDLE Basis 18/21/24 with connected load changeover
In its delivered condition the device is set to 21 kW. When changing to a different output, carry out the
following steps:
s Re-plug the coding card
Re-plug the coding card ( A 8) according to the selected output; for selectable output and fuse protection
see “Specification“.
Mark the connected load on the type plate ( A 19), with a permanent marker.
s Replace the flow limiter
If 24 kW connected load has been selected, replace the fitted flow limiter ( O 30, white) with the flow limiter
supplied ( orange, fixed to the cold water pipe).
3.2
Installation site
Install the instantaneous water heater according to the figure C (a-oversink or b-undersink) vertically, flush
with the wall and in a room free from the risk of frost.
3.3
Preparing the device installation
s /PENTHEDEVICE D :
a Disengage the locking device with a screwdriver.
b Open and remove the device cap.
s 2EMOVETHELOWERPARTOFTHEBACKPANEL E :
a Push in both locking hooks.
b Remove the lower part of the back panel towards the front.
s "REAKOUTTHECABLEGROMMETKNOCKOUTINTHEBACKPANEL ( F a). If, by mistake, the wrong knock-out has
been opened, use a new back panel.
s 4RIMTHEPOWERCABLETOSIZE ( F b).
s 2EMOVETHEPROTECTIVETRANSPORTPLUGSFROMTHEWATERCONNECTIONS.
3.4
Fitting the mounting bracket
G
s -ARKOUTTHEHOLESTOBEDRILLEDUSINGTHEINSTALLATIONTEMPLATESUPPLIEDEXISTINGSUITABLE!%'MOUNTING
bracket can be used).
s 3ECURETHEMOUNTINGBRACKETWITHSCREWSANDRAWLPLUGSNOTPARTOFTHESTANDARDDELIVERYSELECTIN
accordance with the material of the fixing wall).
s )NSERTTHESTUDSSUPPLIEDINTOTHEMOUNTINGBRACKET
3.5
Equipment installation
G
s Seal in and insert the twin nipples.
s 0USHTHECABLEGROMMETOVERTHEPOWERCABLE
s 3LIDETHEBACKPANELOVERTHESTUDSANDTHECABLEGROMMETPULLTHECABLEGROMMETWITHAPAIROFPLIERS
against the locking hooks and let both hooks audibly click into place.
s 0USHTHEBACKPANELlRMLYANDmUSHAGAINSTTHEWALLANDLOCKWITHTHElXINGTOGGLE!TTHEBOTTOM
the device can be secure with 2 additional screws ( M 25).
3.6
Water connection
H
s Position the threaded connections with flat packing onto the twin nipples; for this observe the correct
seating of the connections (never twist the bayonet closures inside the device).
Important information:
s 4HOROUGHLYmUSHTHECOLDWATERSUPPLYLINE
s )FTHECORRECTFUNCTIONCANNOTBEASSUREDDUETOINADEQUATEmOWPRESSUREEG-0ABARREPLACE
the flow limiter ( O 30) and reinsert the profile washer ( O 31). If necessary, increase the pressure in the
water installation.
26
For contractors
s Never replace the pressure limiter when using a thermostatic valve.
s Never use the shut-off valve in the cold water supply (23) to reduce the flow rate.
3.7
Power supply
s #ONNECTTHEPOWERCABLETOTHETERMINALSTRIPSEEWIRINGDIAGRAM I ).
1 heating system
2 High limit safety cut-out
3 Safety pressure limiter
Important information:
s The protection level IP 25 (hoseproof) is only assured if the cable grommet is fitted correctly ( G or K )
and if the cable sheath is sealed correctly.
s Connect the equipment to earth.
s For supply cables > 6 mm², increase the hole in the cable grommet.
3.8
Completing the installation
Click the lower part of the back panel ( E 3) into place.
(only by a qualified contractor)
1
MV
NT C
2
T- soll
3
L3’
4
18
L2’
1
L1’
3
21
24
kW
X1 1
1 &ILLANDVENTTHEDEVICE0LEASENOTE"OILDRYRISK
Open and close all connected taps several times, until all air
has been vented from the pipework and the equipment.
Air - see "2.3 Important information".
2 !CTIVATETHESAFETYPRESSURELIMITER!0
The instantaneous water heater is delivered with the safety
pressure limiter triggered (press the reset button).
3 0USHTHETEMPERATURESELECTORCABLEPLUGONTOTHE
ELECTRONIC0#"
4 &ITANDAUDIBLYLETTHEDEVICECAPCLICKINTOPLACE
Check the firm seat of the device cap on the back panel.
5 3WITCHONTHEMAINSPOWER
6 4URNTHETEMPERATURESELECTORASFARASPOSSIBLECLOCKWISE
ANDANTICLOCKWISEWHICHCALIBRATESTHETEMPERATURE
7 #HECKTHEINSTANTANEOUSWATERHEATERFUNCTION
Optional displays of the “traffic light” indicators ( A 9), see also
“7. Troubleshooting”):
L
Commissioning
L
2
4
red
illuminates in case of faults
yellow illuminates when the equipment is heating water
green flashing - equipment is supplied with mains power
%QUIPMENTHANDOVER
Explain the equipment function to the user and familiarise the user
with its operation.
)MPORTANTINFORMATION
s )NFORMTHEUSEROFPOTENTIALHAZARDSSCALDING
s (ANDOVERTHESEINSTRUCTIONSTOTHEUSERFORSAFEKEEPING
5
6
1.
2.
C26_02_02_0769
3.9
27
For contractors
4.
Alternative installation methods for contractors
Power supply: unfinished walls - below, maximum demand relay; undersink installation, water
connections - top; water: finished walls
!LTERNATIVEINSTALLATIONMETHODSARESHOWNINlGURES J O 4.1
Power supply – unfinished walls - below
K
a Push the cable grommet (4) over the power cable.
b Break out the cable grommet knock-out in the back panel.
c Move the terminal strip from the top to the bottom; for this, undo the screw and refit it into the terminal
strip moved to the bottom.
d Slide the back panel over the studs and the cable grommet, pull the cable grommet with a pair of pliers
against the locking hooks and let both hooks audibly click into place.
e Push the back panel firmly and flush against the wall and lock with the fixing toggle (11).
4.2
Power supply – finished walls
s #UTBREAKAHOLEINTOTHEBACKPANELSUITABLEFORTHEPOWERCABLEFORPOSSIBLEKNOCKOUTSSEE J ).
s 7ITHPOWERSUPPLYONlNISHEDWALLSTHEPROTECTIONRATINGISREDUCEDTO)0SPLASHPROOF
0LEASENOTE
Mark the type plate with a permanent marker:
Cross out IP 25 and tick the IP 24 box.
4.3
Priority control
L
When used in conjunction with other electrical equipment, e.g. electric storage heaters, use the maximum
demand relay:
a Maximum demand relay (see “8. Special accessories”).
b Control cable to the contactor of the second device (e.g. electric storage heater).
c Control contact, opens when switching the instantaneous water heater on.
4HERELAYTRIPSASSOONASTHEINSTANTANEOUSWATERHEATERSTARTS
/NLYCONNECTTHEAUTOMATICMAXIMUMDEMANDCONTROLLERTOTHECENTRALPHASEOFTHEEQUIPMENTTERMINALS
MAINSPOWER
4.4
Undersink installation, water connections from the top
Undersink installation with water connections from the top can be achieved with the additional pipe assembly
for undersink devices (part no. 18 44 21). Cleanly break out the water pipe knock-outs in the back panel and
fit the pipe set.
If the maximum temperature is to be limited to 43 °C, this is done on the inside of the
device cap. For this, replug the temperature selector cable in the device cap from 60 °C
to 43 °C. You can still adjust the temperature selector across its entire range. The outlet
temperature will be permanently limited to 43 °C. A temperature range 30 °C to 43 °C
can be selected.
4.6
Temperature limit
4.5
Taps for finished walls
!%'(AUSTECHNIKPRESSURETESTEDTAPFORlNISHEDWALLS
!$%O7$ N (part no. 18 39 34):
s &ITPLUG'žWITHGASKETSA
(part of the standard delivery of the pressure tested tap ADEo 70 WD).
s &ITTHETAP
s 0USHTHEOPENENDOFTHEPIPESINTOTHEVALVE
s #LICKTHELOWERPARTOFTHEBACKPANELINTOTHEUPPERPARTOFTHEBACKPANEL
s 3ECURETHECONNECTIONPIPESONTHEDEVICE
4HEDEVICECAPNEEDSTOTHEPREPAREDTORTHISINSTALLATION
Cleanly break out the knock-outs in the device cap ( M a), use a file, if necessary.
$EVICElXING
Secure the back panel in the lower part of the device with two additional screws ( M 25).
#APINSTALLATION
Hook the device cap at the top and pivot it down onto the back panel, then make it audibly click into
place. Check the firm seat of the device cap on the back panel.
28
For contractors
5.
Specification and application areas for contractors
5.1
Specification
(The details on the type plate apply)
Type
DDLE Basis 11 DDLE Basis 13 DDLE Basis 18 DDLE Basis 18/21/24
DDLE Basis 27
with selectable output
Part number
Rated output
kW
Rated current
A
Fuses
A
Selectable output
Pressure drop *
with DMB
MPa (bar) / l/min
without DMB
MPa (bar) / l/min
Throughput limit
l/min
(DMB)
Colour
Nominal capacity
Type
Rated operating
pressure
Weight
Protection class to EN 60335
Protection level to EN 60529
Test symbols
Water connection
Power supply
Bare wire heating system
Cold water inlet temperature
Application area
Throughput “ON”
16
16
nein
19.5
20
nein
0.07 / 3.1
0.11 / 3.9
0.02 / 3.1
0.03 / 3.9
4.0
4.0
pink
pink
0.4 l
sealed/unvented
1 MPa (10 bar)
26
25
nein
29
32
ja
31
32
ja
35
35
ja
39
40
nein
0.08 / 5.2
0.06 / 5.2
8.0
white
0.08 / 5.2
0.06 / 5.2
8.0
white
0.1 / 6.0
0.08 / 6.0
8.0
white
0.13 / 6.9
0.10 / 6.9
9.0
orange
0.16 / 7.7
0.12 / 7.7
9.0
orange
3.6 kg
1
IP 25
see type plate
G ½” (male thread)
3/PE ~ 400 V - 50 Hz
see application areas
max. 25 °C
water with low lime-scale levels and those with lime-scale content
≥ 3.0 l/min
Table 3
5.2
Application areas
Specific electrical resistance and specific electrical conductivity
Details as
Resistance
Conductivity
Conductivity
application ranges for different reference temperatures
Ωcm
mS/m
μS/cm
standard details
at 15 °C
at 20 °C
at 25 °C
≥ 900
≤ 111
≤ 1110
≥ 800
≤ 125
≤ 1250
≥ 735
≤ 136
≤ 1360
Table 4
29
For users and contractors
6.
Troubleshooting by the user
Fault
Cause
The heating system inside the
No voltage.
instantaneous water heater will not
start in spite of the tap being fully open.
The start-up volume required to start the
heater has not been reached.
Contamination or scaling of perlators in
water taps or shower heads.
Heating system faulty.
Remedy
User / Contractor:
Check the fuses in your fuse board.
User / Contractor:
Clean and / or descale.
Call service / contractor:
Test heater and replace, if required.
The air sensor detects the presence of air Device starts again after one minute.
in water and briefly switches the heater
off.
Intermittent cold water
Table 5
7.
Troubleshooting by the contractor
Display options LED diagnostic “traffic lights”
red
illuminates in case of faults
yellow
illuminates when the equipment is heating water
green
flashing: the device is supplied with power
Fault / Diagnostic
“traffic light” display*
Cause
Remedy
Flow rate too low
Shower head/perlators scaled up
Descale and replace, if required.
Contamination
Clean sieve ( H 28)
Set temperature is not achieved
One phase down
Check fuse/MCB (fuse box).
Heater does not switch on / no hot
water
The air sensor detects the presence of air Device starts again after one minute.
in water and briefly switches the heater
off.
No hot water
Fuse/MCB blown/tripped
Check fuse/MCB (fuse box).
No “traffic light” display
Safety pressure limiter AP 3 has tripped
Remove the cause for the fault (e.g. faulty
pressure washer).
Open downstream tap for 1 minute.
This depressurises and cools down the
heating system, protecting it against
overheating.
Press the pushbutton on the safety
pressure limiter (push A 11).
Faulty electronics
Test the electronics PCB ( A 7) and
replace, if required.
No hot water; throughput> 3 l/min Faulty electronics
Traffic light display:
green flashing or constantly ON
Flow sensor DFE not plugged int
Flow sensor DFE faulty
30
Test the electronics PCB ( A 7) and
replace, if required.
Refit the plug of the electronics PCB.
Check and replace the flow switch, if
required.
For contractors
High limit safety cut-out triggered or
cable break
Check high limit safety cut-out and
activate, if required ( A 15).
Heating system faulty
Test the heating system resistor ( A 16)
and replace, if required.
Faulty electronics
Test the electronics PCB ( A 7) and
replace, if required.
No hot water
Cold water inlet temperature > 35 °C
Reduce the temperature of the cold water
supply to the device.
Traffic light display:
constant red illumination
green flashing
Flow rate > 25 l/min
Reduce the device throughput.
Cold water sensor faulty
Test the electronics PCB ( A 7) and
replace, if required.
No hot water; throughput
> 3 l/min
Traffic light display:
constant yellow indication
green flashing
Table 6
8.
Special accessories
s $IRECTTAPINSTANTANEOUSWATERHEATERS
ADEo 70 WD - mono-lever mixer tap with changeover bath/hand shower
Part no. 18 39 34
s )NSTALLATIONACCESSORIES
Pipe assembly undersink installation UT 104
Part no. 18 44 21
Water connections with 12 mm compression fittings
s 5NIVERSALMOUNTINGFRAME
Part no. 22 77 01
Comprising:
– Mounting frame with
– electrical wiring.
This assembly creates a gap of 30 mm between the device back panel and the installation wall.
This enables the power supply to be routed over unfinished walls at any point behind the device. This
increases the equipment depth by 30 mm. This set reduces the protection to IP 24 (splash-proof).
s /FFSETINSTALLATIONSETFORUNlNISHEDWALLS
Part no. 22 77 02
Comprising:
– Universal mounting frame (for technical description, see part no. 22 77 01).
– Pipe bends for a vertical offset of the device relative to the water connection by 90 mm downwards.
s 0IPEASSEMBLYREPLACEMENTOFAGASlREDWATERHEATER
Part no. 22 77 03
Comprising:
– Universal mounting frame (for a technical description see part no. 22 77 01)
– Pipe bends for the installation with existing gas water heater connections
(cold water on the left and DHW on the right).
s -AXIMUMDEMANDRELAY,2!
Part no. 00 17 86
Priority control of the instantaneous water heater when operating, for example, electric storage heaters
simultaneously. For connection of the LR 1-A, see L .
31
Customer service and warranty
9.
Guarantee
For guarantees please refer to the respective terms and conditions of supply for your country.
32
!
The installation, electrical connection and first operation of this appliance should be carried out by a qualified
installer.
!
The company does not accept liability for failure of any goods supplied which have not been installed and
operated inaccordance with the manufacturer‘s instructions.
Environment and recycling
10.
Environment and recycling
Recycling of obselete appliances
Appliances with this label must not be disposed off with the general waste. They must be collected separately and disposed off
according to local regulations.
33
Adressen und Kontakte
Vertriebszentrale
Deutschland
International
EHT Haustechnik GmbH
AEG Kundendienst
Austria
Markenvertrieb AEG
Gutenstetter Straße 10
90449 Nürnberg
info@eht-haustechnik.de
www.aeg-haustechnik.de
Tel.
0 18 03 / 91 13 23
Fax
09 11 / 96 56 - 44 4
Dortmund
Kundendienstzentrale
Oespel (Indupark)
Brennaborstr. 19
44149 Dortmund
Postfach 76 02 47
44064 Dortmund
Tel.
02 31 / 96 50 22 - 11
Fax
02 31 / 96 50 22 - 77
Holzminden
Hamburg
Fürstenberger Str. 77
37603 Holzminden
Briefanschrift
37601 Holzminden
Georg-Heyken-Str. 4a
21147 Hamburg
Tel.
0 40 / 75 20 18 - 11
Fax
0 40 / 75 20 18 - 77
Der Kundendienst und
Ersatzteilverkauf ist in der Zeit
von Montag bis Donnerstag von
7.15 bis 18.00 Uhr und Freitag
von 7.15 bis 17.00 Uhr, auch unter
den nachfolgenden Telefon- bzw.
Telefaxnummern erreichbar:
Kundendienst
Tel.
Fax
0 18 03 / 70 20 20
0 18 03 / 70 20 25
Ersatzteilverkauf
Tel.
Fax
0 18 03 / 70 20 40
0 18 03 / 70 20 45
Holzminden
Fürstenberger Str. 77
37603 Holzminden
Tel.
0 18 03 / 70 20 20
Fax
0 18 03 / 70 20 25
Leipzig
Airport Gewerbepark-Glesien
Ikarusstr. 10
04435 Schkeuditz
Tel.
03 42 07 / 7 55 - 11
Fax
03 42 07 / 7 55 - 77
Stuttgart
Weilimdorf
Motorstr. 39
70499 Stuttgart
Tel.
07 11 / 9 88 67 - 11
Fax
07 11 / 9 88 67 - 77
Stiebel Eltron Ges. m.b.H.
Eferdinger Str. 73
4600 Wels
Tel.
0 72 42 - 4 73 67 - 0
Fax
0 72 42 - 4 73 67 - 42
Belgium
EHT Belgium BVBA
Avenue du Port 104
1000 Brussel – Bruxelles
Tel.
02 - 4 22 25 34
Fax
02 - 4 22 25 21
Czech Republic
AEG Home Comfort
K Hájům 946
15500 Praha 5 - Stodulky
Tel.
2 - 51 11 61 11
Fax
2 - 51 11 61 53
Hungary
Stiebel Eltron KFT
Pacsirtamező u. 41
1036 Budapest
Tel.
01 - 250 60 55
Fax
01 - 368 80 97
Nederland
Stiebel Eltron Nederland b.v.
Divisie AEG Home Comfort
Daviottenweg 36, Postbus 2020
5222 BH‘s Hertogenbosch
Tel.
0 73 - 6 23 00 00
Fax
0 73 - 6 23 11 41
Polska
AEG Oddzial Stiebel Eltron Polska Sp. z.o.o.
Ul. Instalatorów 9
02-237 Warszawa
Tel.
0 22 - 8 46 48 20
Fax
0 22 - 8 46 67 03
Russia
OOO EHT-Haustechnik LLC
125190, Russia, Moscow,
Baltijskaya str., 15
Tel.
+7 495 788 9168
Fax
+7 495 788 9168
Switzerland
www.aeg-haustechnik.de
© EHT Haustechnik
Irrtum und technische Änderungen vorbehalten · Subject to errors and technical changes! · Sous réserve d‘erreurs et de modifications techniques!
Onder voorbehoud van vergissingen en technische wijzigingen! · Correzioni riservati · Salvo error o modificación técnica! · Rätt till misstag och
tekniska ändringar förbehålls! · Excepto erro ou alteração técnica · Zastrzeżone zmiany techniczne i ewentualne błędy! · Omyly a technické změny
jsou vyhrazeny! · A muszaki változtatások és tévedések jogát fenntartjuk! · Boэможность неточностей и технических изменений не исключается!
A 281474-35066-0901
info@eht-haustechnik.de
EHT Haustechnik AG
Industriestrasse 10
5506 Mägenwill
Tel.
0 62 - 8 89 92 14
Fax
0 62 - 8 89 91 26
