EverFocus Electronics Corp. is a leading manufacturer and integrated system solution provider of CCTV cameras, DVRs, IP
surveillance solutions, access control systems and further CCTV and access control peripherals.
Focused on You!
“Focused on You!” is a true description of EverFocus and our employees. We are constantly trying to rede ne our role in the
marketplace and the World. Our goal is for every product that we manufacture to be easily installed with minimal
maintenance. Our extensive warranty is a testimony to the quality that we achieve on all of our products. Here at EverFocus
we take one word to heart when describing our company as a whole: Focused. We are focused on your needs, on providing
the industry with great products, and on innovation. When it comes to security equipment, go with the name you trust; go
with the name that is Focused on your company.
Thank you for your continued support. We look forward to serving all of your security needs for many years to come.
EverFocus Product Series:
Series
Series
Notice:
© 2011 EverFocus Electronics Corp. The EverFocus trademark is registered by EverFocus Corp.
All rights reserved. Product features and speci cations are subject to change without notice. No parts or contents of this
datasheet may be reproduced or transmitted in any form or by any means without permission from EverFocus.
• Not all models featured are available in all countries. For accessories and other products information,
Please visit www.everfocus.uk.com
• Safety precaution: carefully read the operating instructions and installation manual before using this product
• EverFocus can not be responsible for network performance and/or other manufacturer products that
resident on the network
• These products may be subject to export control regulations
• The above all photographs were taken for the purpose of explanation; actual images may differ
• Models vary in different countries, Please visit EverFocus regional websites for detailed ordering information.
Quality Management System
ISO9001 certi cations
Quality Management System
ISO14001 certi cations
* All product speci cations are subject to change without notice
Table of Contents
HD CCTV
HD Digital Video Recorders
PARAGON HD ........................................................................................................................................ 4
ENDEAVOR HD ...................................................................................................................................... 6
HD Cameras
2 Megapixel Cameras ............................................................................................................................. 9
HD CCTV Accessories
HD-SDI Converter/Repeater/ Splitter .....................................................................................................12
Analog CCTV
Digital Video Recorders .................................................................................................................. 13
PARAGON264 Series ................................................................................................................................14
ENDEAVOR264 L4 ................................................................................................................................16
ECOR264X1 Series ...............................................................................................................................18
ECOR264D2 Series ...............................................................................................................................20
H.264 ELR Series ..................................................................................................................................22
DVR Accessories ...................................................................................................................................24
Моbile Video Surveillance ..................................................................................................................26
Mobile Cameras ....................................................................................................................................27
Mobile DVRs ........................................................................................................................................34
PTZ Cameras ....................................................................................................................................... 41
EPTZ Series .........................................................................................................................................42
PTZ Accessories ...................................................................................................................................51
Colour Cameras .................................................................................................................................. 52
Indoor IR Dome Cameras .....................................................................................................................53
Indoor Colour Dome Cameras ...............................................................................................................59
Outdoor Dome Cameras .......................................................................................................................65
Bullet Cameras (with IR) .......................................................................................................................70
Bullet Cameras (non-IR) .......................................................................................................................79
Box Cameras ........................................................................................................................................81
Covert Cameras.....................................................................................................................................86
IP Surveillance
2 Megapixel HD IP Cameras ........................................................................................................... 90
Nevio Series IP Products
1.3 Megapixel IP Cameras .....................................................................................................................96
Super HAD CCD IP Cameras ..................................................................................................................97
EPN Series IP PTZ Cameras .................................................................................................................102
NVR Software .....................................................................................................................................103
IP Accessories ....................................................................................................................................106
Accessories
Control Keyboards .............................................................................................................................110
DVR Storage Expansion .....................................................................................................................112
Hard Drive Reader .............................................................................................................................112
CCTV Lenses .......................................................................................................................................113
LED Monitors ......................................................................................................................................114
LCD Monitors .....................................................................................................................................115
Mounting Brackets ............................................................................................................................121
Camera Housings ...............................................................................................................................121
IR Illuminators ..................................................................................................................................122
Accessories ........................................................................................................................................126
2
* All product specifications are subject to change without notice
HD CCTV
* All product specifications are subject to change without notice
3
HD CCTV DVR PARAGON HD Series
PARAGON HD
NEW
8 Channels HD Real-Time
Recording & Playback Megapixel Video Over Coax
HD CCTV DVR
Features
• Choice of 1080i or 720p HD CCTV camera support
for superlative image clarity
• H.264 Compression format for ef cient recording
• HD real time recording and playback rate for all
cameras (at 720p)
• HDMI 1080p and VGA multiplex view main monitor
outputs
• Simultaneous high resolution recording
(1080p/720p) with reduced bandwidth remote view
streaming
• MobileView support: check your home or business
on-the-go from your PDA or SmartPhone
• Pentaplex operation (simultaneous live, recording,
playback, archiving and remote viewing)
• Free EverFocus DDNS service–static IP address is
not required for reliable remote access
• User friendly GUI with graphical icons and visual
indicators
• Support for 4 xed internal HDD plus and eSATA
external HDD
• Multiple control inputs: mouse/front panel/IR
remote controller/EKB500 keyboard
• Express setup: a unique menu option for quick &
easy installation
• Express archive: archive video instantly (to USB)
while playing back
• Express playback: simple point, click and drag the
playback bar to view desired recordings
• Express search: use the intuitive playback bar with
simple drag & drop operations
• Smart Search: Quickly identify motion in areas of
interest from recorded video
• Snapshot search: Extract images from recorded
video at speci c intervals to quickly locate events
• Remote con guration support from the built-in web
interface
• Gigabit Ethernet interface for remote network
viewing and control
• On-screen PTZ control via mouse or front panel
• Per channel audio recording capabilities
• Built-in DVD burner
• 3 USB 2.0 ports for video archive and mouse usage
• Multi–language support
• 19" rack mountable (rack ears included)
4
* All product speci cations are subject to change without notice
Specifications
HD-SDI Camera Video Inputs
Recording
8 BNC connectors
120/100fps@1080p; 15/12.5 per channel
Rate/Resolution
Playback
240/200fps@720p; 30/25 per channel
15/12.5fps@1080p; 120/100fps@480x256
Rate/Resolution
Compression Format
Dual Streaming
Mobile Viewing on PDA/
Smartphone
Pentaplex Operation
30/25fps@720p; 240/200fps@320x176
H.264
Yes
Yes ; various platforms and browsers supported
Simultaneous Live, Recording, Playback, Archive and
Remote Viewing
Video Output
Audio Input/Output (RCA)
Main Monitor 1080p HDMI+VGA
8 Inputs/1 Output
Recording Mode
Manual, Schedule and Event
Playback Search
Date/Time Search, Event Search, Smart Search,
Snapshot Search
Alarm In
8 Alarm Inputs
Alarm Out
2 Alarm Outputs–Form “C” rated at 30VDC, 1A
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Internal HDD
External HDD
Built-in DVD Burner
User Interface
Yes
4 Internal HDD
1 eSATA
Slim Type DVD Burner
GUI (Graphical User Interface – easy mouse or front panel
navigation)
OS
Embedded Linux
Network/Protocol
Gigabit Ethernet ; TCP-IP/DHCP/PPPoE/DDNS/UDP/SMTP/SSL/
RTP/RTSP/NTP
USB
3 USB 2.0 port (2 on Front Panel, 1 on Back Panel)
Schedule Setting
User Access
Supports Express and Advanced Schedule Setting
3 Levels of User Access Support
RS-232
9-pin D-Sub socket (male)
RS-485
1 RS485 (3 Terminal connector)
Power Source
Power Consumption
100VAC~240VAC
180W
Dimensions (L x W x H)
410 x 430 x 88 mm/16.2" x 16.9" x 3.5"
Operating Temperature
0°C~40°C/32°F~104°F (20~80% humidity)
Certi cates
CE, FCC, UL
Supported PTZ Protocols
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
HD CCTV DVR PARAGON HD Series
Major Operating Controls
1
2
3
4
5
6
7
Main Power Plug
Audio In (8)
eSATA
Network Connector
USB Slot
RS232 Connector
HDMI Monitor Output
8
9
10
11
12
13
VGA Monitor Out
Audio Out
RS-485 Connector
HD-SDI Video Input (8)
Alarm Out (2)
Alarm In (8)
Rear View
Rear
View
2
1
3
4
5
6
7
8
9
10
11
12
13
HD CCTV DVR
• Front & back panel controls
vary depending on models
Advantages
Real-time High Definition Resolution Recording over COAX
Deliver and record High De nition image quality using traditional coaxial cable*! Retain plug-and-play ease of installation: select leading edge EverFocus
HD CCTV cameras that use the advanced HD-SDI transfer format to send full HD, megapixel resolution digital video over the same coax* that once carried
only standard de nition video. The Paragon HD DVR makes a tremendous leap forward in image quality by providing more than 6 times higher resolution
than SD DVRs to record and playback HD image quality at 240/200 FPS that were carried over COAX. The Paragon HD DVR also provides HD quality still
image recording in response to event noti cations.
H.264 Compression Technology
H.264 compression technology is considered to be approximately 1.5 times
more ef cient in compression ratio than MPEG4. Another bene t from H.264
compression is the remote viewing of high quality images with lower
LAN/WAN bandwidth utilization.
Pentaplex operation plus Dual streaming
For optimized system performance, the Paragon HD DVR can simultaneously record HD resolution on all 8 cameras at 30/25 FPS. It also automatically
employs dual streaming for remote multiplex displays, reducing the image size in the DVR to ef ciently deliver 30/25 FPS on all cameras for full motion
simultaneous remote viewing of up to 8 cameras. Thus it can achieve HD real time recording and playback locally, and still deliver smooth remote motion
reproduction during network playback in low bandwidth environments.
Convenient Monitoring with web-viewer
The Paragon HD DVR has a built-in web server that enables users to monitor live and playback DVR images without special software, through a web
browser from any supported PC.
Video Streaming to Mobile Devices
The Paragon HD DVR supports http streaming for MAC and PDA/SmartPhone
monitoring on a variety of PC’s and mobile devices, allowing you the capability to
check your home or business on-the-go directly from a variety of mobile devices
– FREE! No additional servers or purchased programs required.
Mobile Device
HDMI and VGA multiplex monitor outputs
Full HD 1920x1080 provides superior picture performance on a massive scale, with two entire megapixels of resolution allocated to monitor display. HDMI
and VGA digital outputs render stunning images from any resolution, and enhances motion reproduction to deliver smoother and crisper looking video.
Dimensions
Front View
Side View
410 mm / 16.2”
88 mm / 3.5”
430 mm / 16.9”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product speci cations are subject to change without notice
5
HD CCTV DVR ENDEAVOR HD+SD DVR (EDR HD – 2H14 / EDR HD – 4H4)
ENDEAVOR HD+SD DVR
NEW
HD+SD CCTV Hybrid Real Time
Megapixel and Standard Video over Coax
p
HD-CCTV
SMPTE292m
main monitor
HYBRID
HD+SD
HD CCTV DVR
SMART
SEARCH
Features
• Both HD-CCTV Megapixel Video Inputs and Analog Video
Inputs
• Choose 720p or 1080p HD resolution recording for HDCCTV Video Inputs up to 30
• FPS/camera
• H.264 Compression format to minimize optimize disk space
consumption
• Dual streaming to optimize remote viewing bandwidth
utilization
• Real time recording rate and playback rate - up to
30fps@D1 on analog and 30fps@HD on
• HD-CCTV
• Recording resolution and rate can be set independently for
each camera, and changed via
• user defined schedule
• Multiple Main Monitors : HDMI 1080p / VGA (1920x1080)
output for stunning image clarity
• Pentaplex Operation (Simultaneous live, recording,
playback, archiving and remote viewing)
• User friendly GUI with graphical icons and visual indicators
• Free EverFocus DDNS Service static IP address is not
required for reliable remote access
• Supports eSATA external HDD array (EDA450)
• Supports remote/mobile monitoring via PC browsers,
SmartPhones and iPhone/Android apps
• Multiple Control Inputs: mouse/front panel/ IR remote
control/EKB500 keyboard
• Express Setup: A unique menu option for quick & easy
installation and setup
• Express Playback: Simply point, click and drag the playback
bar to view desired recordings
• Express Archive: Archive video instantly (to USB) while
playing back
• Express Search: Use the intuitive playback bar with simple
drag & drop operations
• Smart Search: Review recorded video to identify motion in
area(s) of interest
• Snapshot search: choose an interval and direction, view a
series of snapshots to quickly
• isolate incidents
• Remote configuration support from built-in web interface
• Gigabit Ethernet interface for remote network viewing and
control
• Audio recording capabilities
• Up to 4 internal HDDs
• Built-in DVD burner
• 2 USB 2.0 ports for video archive and mouse usage
• Multi-language support
• Watermark capabilities to identify intentional modifications
of recorded data
• Compatible with FREE EverFocus Central Management
Software
• USB Mouse and IR remote control included
• 19” Rack mountable – rack ears included
6
* All product specifications are subject to change without notice
Specifications
HD-CCTV Camera Inputs
Analog Camera Inputs
Looping Analog Camera
Outputs
Compression Format
Dual Streaming
HD Recording Rate/Resolution
Choose one resolution for both channels
Analog Recording Rate/
Resolution
EDR HD-2H14
2 BNC SMPTE292m compliant
14 BNC
14 BNC
EDR HD-4H4
4 BNC SMPTE292m compliant
4 BNC
4 BNC
H.264
Yes (Configurable)
30fps NTSC / 25ps PAL(1080p)
60fps NTSC / 50ps PAL(720p)
420fps NTSC / 350ps PAL(D1)
60fps NTSC / 50ps PAL(1080p)
120fps NTSC / 100ps PAL (720p)
120fps NTSC / 100ps PAL(D1)
Resolution and rate can be set independently
per camera up to the total D1 recording
capacity
HD Playback Rate/Resolution
Up to 30fps NTSC / 25fps PAL
Up to 45fps NTSC / 37.5fps PAL
Up to 60fps NTSC / 50fps PAL
Up to 90fps NTSC / 75fps PAL
Analog Playback Rate/
Up to 420fps NTSC / 350fps
Up to 120fps NTSC / 100fps
Resolution
PAL(D1)
PA(D1)
Mobile View
Live view on PDA or Smart Phones (MobleFocus FREE app for
iPhone® and Android™) plus various web browsers
Pentaplex Operation
Simultaneous Live, Recording, Playback, Archive and Remote
Viewing
Main Monitor
1080p HDMI (socket Type A 19 pin female) andVGA 1920 x 1080 @
Outputs(simultaneous display)
60 Hz (D-Sub socket 15 pin female)
Audio Inputs
16 Inputs (RCA, line level)
8 Inputs (RCA, line level)
Audio Outputs
2 Outputs (RCA, line level)
Recording Modes
Manual, Schedule and Event
Playback Search
Date/Time, Event, Tex, Smart, Snapshot
Alarm Inputs
16
8
Alarm Outputs
4 Alarm Outputs – Form “C” rated at 30VDC, 1A
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Yes
Internal HDD Support
4 Internal HDD (up to 8Tb max at time of printing)
External HDD Support
1 eSATA
DVD Drive
DVD RW Built In
User Interface
Colour GUI (Graphical User Interface)
OS
Embedded Linux
Network/Protocol
Gigabit Ethernet; TCP-IP / DHCP/ PPPoE / DDNS / UDP / SMTP /
SSL / HTTP / NTP/ ICMP / ARP
Control PTZ via OSD
Local and via web interface
USB
2 Front Panel USB 2.0 port
Schedule Setting
Support Express and Advanced Schedule Setting
User Access
3 Levels of User Access Support
RS-232
9-pin D-Sub socket (male)
RS-485
1 RS485 (2 RJ45 connector)
Power Source
100VAC~240VAC
Power Consumption
110W max. with 4 x HDD
Dimensions (L x W x H)
423 x 430 x 79.5 mm / 16.6" x 16.9" x 3.2"
Temperature
0°C~40°C / 32°F~104°F (20~80% humidity)
Certificates
CE, FCC, UL (pending)
Supported PTZ Protocols
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
HD CCTV DVR ENDEAVOR HD+SD DVR (EDR HD – 2H14 / EDR HD – 4H4)
Major Operating Controls
22
21
20
19
18
17
16
15 14
15
4
1
2
5
6
7
8
9
10
11
12
13
1
14 13
2
12 11
3
4
5
6
7
10
9
8
3
1 Remote Control Receiver
9
17 FF / Next Step
1 Main Power Plug
2 Channel Key (1~16 CH) (2H14 CH only)
10 Menu Navigation Keys
18 Play / Pause
2 Network Connector
10 Audio Out
3 Channel Key (1~8 CH) (4H4 CH only)
11 Copy
19 Stop
3 RS232 Connector
11 HD-CCTV Video In (CH 15~16)(2H14 only)
4 DVD Eject
12 Jog/Shuttle Dials
20 Pause / Reverse Play
4 RS485 Connectors
12 HD-CCTV Video In (CH 5~8)(4H4 only)
5 View
13 System LEDs
21 Prev Step / FR
5 VGA Main Monitor Out
13 Analog Video Input and Looping (CH 1~14)(2H14 only)
6 Sequence
14 Search
22 USB Ports
6 HDMI Main Monitor Out
14 Analog Video Input and Looping (CH 1~4) (4H4 only)
7 Display
15 Menu/ESC
7 Alarm In (one per camera)
15 eSATA
8 Monitor Control
16 DVD Burner
8 Alarm Out
Zoom
9 Audio In 4x RCA; others on DIN connector
HD CCTV DVR
Advantages
Hybrid Real-Time High & Standard Definition
Resolution Recording over COAX
Deliver and record both High & Standard Definition image
quality using traditional coaxial cable*! Retain plug-and-play
ease of installation: select leading edge EverFocus HD-CCTV
cameras that use the advanced HD-CCTV transfer format to
send full HD, megapixel resolution digital video over the same
coax* that once carried only standard definition video. The
ENDEAVOR HD+SD DVR delivers “hybrid” recording that allows
SMPTE292m complaint HD-CCTV cameras and conventional
analog cameras to be recorded on the same DVR. This unique
platform provides a gradual migration path to High Definition
video recording while still supporting the use of existing analog
equipment.
*Up to 500 feet, longer distances with extenders
HDMI and VGA Multiplex Monitor Outputs
Full HD 1920x1080 provides superior picture performance
on a massive scale, with two entire megapixels of resolution
allocated to monitor display. HDMI and VGA digital outputs
render stunning images from any resolution, and enhance
motion reproduction to deliver smoother and crisper looking
video.
System Configuration
HD-CCTV Camera
Max.4
Camera
HD-SDI in
VGA
Analog in
Max.4
Camera
Standard CCD Camera
HD-CCTV Camera
Max.2
Camera
VGA
HD-SDI in
Analog in
Max.14
Camera
Standard CCD Camera
Amplifiers
High Definition (HD) CCTV
Dimensions
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
7
HD CCTV Cameras 2 Megapixel Full HD CCTV Cameras
EQH5200
NEW
2 Megapixel, HD-SDI, Indoor
Full HD CCTV Box Camera
Dual Output
HD-SDI/
TV Out
AWB
OSD
BLC
OSD Setting
ON/OFF
HD CCTV Cameras
AGC
True Day/Night
ON/OFF
Features
• HD-CCTV 2 Megapixel real time 1080i HD video
over coax
• 2 megapixel progressive scan CMOS sensor
• Supports video outputs of 720p and 1080i
• Lens Types: supports DC and manual iris lenses,
CS mount (C mount adapter ring included)
• True day/night mode selectable with automatic
ICR module
• Easy to use OSD setup menu
• Dual Video Output: Megapixel HD-SDI (BNC) plus
SD TV Out (RCA) for installation
• Dual Power Source 12VDC/24VAC dual voltage
Specifications
Pickup Device
Sensitivity
1/2.5" 2 megapixel CMOS sensor
0.02lux/F=1.2 (AGC ON)
S/N Ratio
38.1dB
Video Format Main Output
HD-SDI/HD-CCTV
Resolution Main Output
1920x1080@50i or 60i; 1280x720@50p or 60p
Video Mode Main Output
Field select 1080i or 720p
Main Output Connector
Video Format Test Output
BNC-F
NTSC/PAL selectable 1Vp-p
Test Output Connector
Electronic Shutter
RCA-F
1/60 (1/50)~1/8000
Lens Type
CS mount
(Adapter included for C-mount ; lens sold separately)
Back Light Comp.
On/Off selectable
Auto Gain Control
High/Middle/Low/Off selectable
Auto White Balance
Gamma Correction
AWB/One Push WB/Manual WB/Indoor/Outdoor
PC / TV Selectable
Iris Control
Auto, -2.0EV~2.0EV
OSD Menu
Yes (controlled from rear 5-axis joystick control)
True Day/Night Control
Mirror
Yes (Auto IR cut lter removal)
H_MIR/ V_MIR
Power Source
Power Consumption
Dimensions (incl. BNC)
(W x H x D)
Dimensions
12VDC/24VAC
24VAC: 6W max. ; 12VDC: 6W max.
68mm x 56mm x 146mm/2.7" x 2.2" x 5.7"
Weight
0.4kg/0.9 lbs
Operating Temperature
0°C~45°C/32°F~113°F (20%~80% Humidity)
Certi cates
8
* All product speci cations are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
HD CCTV Camera 2 Megapixel Full HD CCTV Cameras
EDH5240
2 Megapixel, HD-SDI, Indoor
Full HD CCTV IR Dome Camera
Dual Output
HD-SDI/
TV Out
AWB
OSD
OSD Setting
ON/OFF
ON/OFF
IR
HD CCTV Camera
AGC
True Day/Night
BLC
20m
Features
Specifications
• HD-CCTV 2 Megapixel real time 1080i HD video
over coax
• 2 megapixel progressive scan CMOS sensor
• Supports video outputs of 720p and 1080i
• Lens Types: supports DC and manual iris lenses,
CS mount (C mount adapter ring included)
• True day/night mode selectable with automatic
ICR module
• Easy to use OSD setup menu
• Dual Video Output: Megapixel HD-SDI (BNC) plus
SD TV Out (RCA) for installation
• Dual Power Source 12VDC/24VAC dual voltage
• May be attached to wall or ceiling; ush or
surface mounted
• Equipped with 34 IR LEDs for day and night
environments
• IR distance up to 66 fee (20m; depending on
surface re ectivity)
Pickup Device
Sensitivity
S/N Ratio
Video Format Main Output
0.5lux/F=1.4
45dB
HD-SDI/HD-CCTV
Resolution Main Output
1920x1080/2 Megapixel/1080i or 1280x720/1 Megapixel/720p
Video Mode Main Output
Field select 1080i or 720p
Main Output Connector
Video Format Test Output
Test Output Connector
Electronic Shutter
Lens Type
Back Light Comp.
Auto Gain Control
Auto White Balance
Gamma Correction
BNC-F
NTSC/PAL selectable 1V p-p
RCA-F
1/60(1/50)~1/8000
"Vari-focal lens, Auto Iris
f=3.3~12mm"
On/Off selectable
High/Middle/Low/Off selectable
AWB/One Push WB/Manual WB/Indoor/Outdoor
PC/TV
Iris Control
Auto, -2.0EV~2.0EV
OSD Menu
Yes (controlled from rear 5-axis joystick control)
True Day/Night Control
Mirror
IR Distance
IR Wavelength
Yes (Auto IR cut lter removal)
H_MIR, V_MIR
20M
850nm
IR LED Lifespan
20,000 hours
Power Source
12VDC/24VAC
Power Consumption
Dimensions
1/3" 2 megapixel CMOS sensor
Dimensions (incl. BNC)
Weight
Operating Temperature
Certi cations
24VAC: 6W max.
12VDC: 6W max.
140 mm (O.D.) x 128 mm (H)/ 5.5” (O.D.) x 5.1 “(H)
660g/1.45lbs
0°C~45°C ; 32°F~113°F (20%~80% Humidity)
FCC/CE
140mm / 5.5”
128mm / 5.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product speci cations are subject to change without notice
9
HD CCTV Camera 2 Megapixel Full HD CCTV Cameras
EHH5200
2 Megapixel, HD-SDI, Outdoor
Full HD CCTV Dome Camera
Dual Output
HD-SDI/
TV Out
AWB
BLC
OSD
OSD Setting
ON/OFF
HD CCTV Camera
AGC
ON/OFF
True Day/Night
Vandal proof
Features
Specifications
• HD-CCTV 2 Megapixel real time 1080i HD video
over coax
• 2 megapixel progressive scan CMOS sensor
• Supports video outputs of 720p and 1080i
• Lens Types: supports DC and manual iris lenses,
CS mount (C mount adapter ring included)
• True day/night mode selectable with automatic
ICR module
• Easy to use OSD setup menu
• Dual Video Output: Megapixel HD-SDI (BNC) plus
SD TV Out (RCA) for installation
• Dual Power Source 12VDC/24VAC dual voltage
• Vandal Resistant & Weatherproof IP66 rated
Pickup Device
1/3" 2 megapixel CMOS sensor
Sensitivity
0.5lux/F=1.4
S/N Ratio
45dB
Video Format Main Output
HD-SDI/HD-CCTV
Resolution Main Output
1920x1080/2 Megapixel/1080i or 1280x720/1 Megapixel/720p
Video Mode Main Output
Field select 1080i or 720p
Main Output Connector
Video Format Test Output
BNC-F
NTSC/PAL selectable 1V p-p
Test Output Connector
Electronic Shutter
Lens Type
Back Light Comp.
Auto Gain Control
Auto White Balance
RCA-F
1/60(1/50)~1/8000
"Vari-focal lens, Auto Iris
f=3.3~12mm"
On/Off selectable
High/Middle/Low/Off selectable
AWB/One Push WB/Manual WB/Indoor/Outdoor
Gamma Correction
PC/TV
Iris Control
Auto, -2.0EV~2.0EV
OSD Menu
Yes (controlled from rear 5-axis joystick control)
True Day/Night Control
Mirror
Yes (Auto IR cut lter removal)
H_MIR, V_MIR
WeatherProof
IP66 rated
Vandal Resistant
Power Source
Power Consumption
Dimensions (incl. BNC)
Dimensions
Yes
12VDC/24VAC
24VAC: 6W max.
12VDC: 6W max.
140 mm (O.D.) x 128 mm (H)/ 5.5” (O.D.) x 5.1 “(H)
Weight
740g/1.6lbs
Operating Temperature
-10°C~50°C ; 14°F~122°F (20%~80% Humidity)
Certi cations
FCC/CE
123 mm / 4.8”
Ø
5.
14
-3
107.8 mm / 4.2”
Ø
10
94
.7
* All product speci cations are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
HD CCTV Camera 2 Megapixel Full HD CCTV Cameras
EZH5240
2 Megapixel, HD-SDI, Outdoor
Full HD IR Bullet Camera
Specifications
• HD-CCTV 2 Megapixel real time 1080p/1080i/720p
HD video over coax
• 2 megapixel progressive scan CMOS sensor
• True day/night mode selectable with automatic ICR
module
• Easy to use OSD setup menu
• Dual Video Output : Megapixel HD-SDI (BNC) plus
SD TV Out (RCA) for installation
• Dual Power Source 12VDC/24VAC dual voltage
• Extended IR range of up to 40M with 36 LEDs and
variable output IR control to manage illumination
and conserve energy
• Split glad to prevent internal IR re ections
• Flexible mounting and positioning – speed – mount
ring ts 4” round electrical box; or remove base to
mate with 1” conduit
• E-Z lock ring at the base is designed with easy to
grip tabs for rmly clamp the camera in place, plus
a set screw for added security.
• Easy bottom access to video test point and lens
control inside weatherproof cover plus Remote
Zoom & Focus adjustment by web browser
• IP66 and vandal resistant
Image Sensor
Dimensions
Image Sensor
1920x1080
Sensitivity
0.5Lux/F=1.2
S/N Ratio
45dB
Lens
Lens Type
Aperture (F/No.)
Focus Length
View Angle(Diagonal)
Auto Iris
Ø75.0mm
1/1.2
3.3~12mm
125°~36°
DC-Iris support
Night vision function
Built-in removable IR cut lter
Image Processing
Video Format Main Output
Image Resolution and Frame
rate
Video Mode Main Output
Auto Exposure Control
Electronic Shutter
HD-SDI
1080i60/1080i50/1080p30/1080p25/720p60/720p50
Field select 1080i, 1080p or 720p
Yes
1/60(1/50)~1/8000
Back Light Comp.
On/Off selectable
Auto Gain Control
High/Middle/Low/Off selectable
Auto White Balance
Mirror
NEG_IMAGE
AWB/One Push WB/Manual WB/Indoor/Outdoor
H_MIR, V_MIR
On/Off
System
OSD Menu & Lens zoom
control
IR Distance
Ø83.0mm
Board type Lens
Night vision
Test Output Connector
Ø88.5mm
1/3" 2 megapixel CMOS sensor
Resolution
Main Output Connector
R44.0mm
HD CCTV Camera
Features
BNC-F
RCA-F
Yes (controlled from rear 5-axis joystick control)
60M (TBD)
IR Wavelength
850nm
IR LED Lifespan
20,000 hours
Power
Power Consumption
Environment
Approvals
DC12V /AC24V
8 watts max.
Operation: Temp: -10°C~50°C ; 14°F~122°F (20%~80% Humidity)
Storage: Temp: -15°C ~ 60°C Humidity: 0% ~ 90% non-condensing
FCC/CE class A
316.2
81.5
Ø106.5
184.2
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product speci cations are subject to change without notice
11
HD CCTV Accessories Converter & Repeater
EHA-SRX
HD-SDI to HDMI Converter
NEW
EHA-RPT
HD-SDI Repeater
EHA-FTX/FRX
HD-SDI to Fiber Converter
HD CCTV Accessories
Features
• Accepts HD-CCTV high-definition HD-SDI digital video at 720p/60, 1080i/60
• Provides standard HDMI output for HD TV monitor display (EHA-SRX)
and 1080p/30 formats/ frame rates
• Capable of receiving HD-CCTV digital video over 75Ω coaxial cable at distances
• Processes HD-SDI standard at 1.485Gb/s data rate
up to 400 feet/120m (EHA-SRX)
• Integrated cable equalizer for long distance video transmission without loss of
• Capable of receiving HD-CCTV digital video over 75Ω coaxial cable at distances
quality
over 100M (depending on cable type) (EHA-RPT)
• High quality digital video and audio transmission with near zero latency
• Capable of transmitting and receiving HD-CCTV digital video over fiber optics
(EHA-FTX/FRT)
Specifications
Model
EHA-SRX
EHA-RPT
EHA-FTX/FRX
TECHNICAL
SDI Standards
HD-SDI
Video Bandwidth
1.485Gbps
Video Support
Input Signal
Output Signal
Cable Equalization
Input Connector
Output Connector
720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30Hz
HD-SDI: SMPTE 292M, 296M
HD-SDI: SMPTE 292M, 296M
---
HDMI
HD-SDI: SMPTE 292M / 296M
---
up to 120m/400ft
up to 200m / 665ft ( by cable R11 and R6 )
---
1x BNC [HD-SDI] 3G 75Ω inter-locked socket
1 x BNC [HD-SDI] 3G 75Ω inter-locked socket
1x HDMI Type A [19-pin female]
2 x BNC [HD-SDI] 3G 75Ω inter-locked socket
FTX: 1x BNC [HD-SDI] 3G 75Ω inter-locked socket
FRX: 1 X Simplex LC SFP (Hot Pluggable)
FTX: 1 X Simplex LC SFP (Hot Pluggable)
FRX : 1 X BNC [HD-SDI]
3G 75Ω inter-locked socket
MECHANICAL
Housing
Metal case
Dimensions (W x H x D)
77.4 (W) x 38.4 (H) x 117 (D) mm / 3” (W) x 1.5” (H) x 4.6” (D)
Weight
200g / 0.45lbs
Power Supply
Power Consumption
Operating Temperature
12VDC
2W max.
3 W max.
3 W max.
0°C~50°C /32°F~122°F
0°C~50°C /32°F~104°F
0°C~50°C /32°F~104°F
Humidity
20%~80%
Dimensions
:4/8nn04/8#
EHA-SRX
EHA-RPT
49/5nn02/6#
49/5nn02/6#
Power
Link
228nn05/7#
257/3nn06/9#
12
* All product specifications are subject to change without notice
88/5nn04#
81/3nn03/9#
88/5nn04#
81/3nn03/9#
HD-SDI IN
84/8nn03/:#
74nn03/6#
74nn03/6#
EHA-RPT
12VDC
:4/8nn04/8#
EHA-FTX
84/8nn03/:#
EHA-FTX
HD-SDI IN
12VDC
Power
Link
228nn05/7#
246/8nn06/4#
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders
* All product specifications are subject to change without notice
13
Digital Video Recorders Paragon264 Series with HDMI Output
Digital Video Recorders
PARAGON 264 Series
16 Channels, H.264, HDMI Output with 1080i
H.264
compression
1080i
FREE
DDNS
Dual
Stream
D1
Real-Time
Mobile Device
Features
Specifications
• H.264 Compression format
• D1 real time recording rate and playback rate for all
cameras (Paragon 264X4)
• HDMI video output (1080i)
• Multiple Main Monitors: Separately configured HDMI 1080i
and VGA/BNC Main monitor outputs
• Call monitor: additional composite BNC output with
multiplex and/or sequenced views
• Simultaneous high bandwidth recording (400 PAL/480 NTSC
(D1)) with reduced bandwidth remote view streaming (up
to 400 PAL/480 NTSC (CIF)) (Paragon264 x 4 only)
• Pentaplex Operation (Simultaneous live, recording,
playback, archiving and remote viewing)
• Free EverFocus DDNS Service - static IP address is not
required for reliable remote access
• User friendly GUI with graphical icons and visual indicators
• Supports eSATA external HDD
• Supports video streaming for mobile monitoring
• Multiple Control Inputs: mouse/front panel/remote
controller/EKB500 keyboard
• Built-in record time calculator for fast recording estimation
• Express Setup: A unique menu option for quick & easy
installation
• Express Archive: Archive video instantly(to USB) while
playing back
• Express Playback: Simply point, click and drag the playback
bar to view desired recordings
• Express Search: Use the intuitive playback bar with simple
drag & drop operations
• Remote configuration support from the built-in web
interface
• Gigabit Ethernet interface for remote network viewing and
control
• On-screen PTZ control via mouse or front panel
• Audio recording capabilities
• Support for up to 2 Hot Swappable HDD or 4 fixed internal
HDD
• Built-in DVD burner (Optional)
• 3 USB 2.0 ports (2 located on front panel, 1 located on back
panel) for video archive and mouse usage
• Multi-language support
• Watermark capabilities to identify intentional modifications
to exported data
• 19” Rack mountable – rack ears included
Model No.
PARAGON 264X4
16 CH
Compression Format
H.264
HDMI Output
Yes
Recording Rate/
Resolution
Playback Rate/
Resolution
Mobile Device
Pentaplex Operation
Video Input
240 NTSC / 200 PAL (D1:704x480)
480 NTSC / 400 PAL
(Half D1:704x240)"
480 NTSC / 400 PAL
240 NTSC / 200 PAL (D1:704x480)
(D1:704x480)
480 NTSC / 400 PAL
(Half D1:704x240)
®
Live view on PDA or Smart Phones (MobleFocus FREE app for iPhone
and Android™) plus various web browsers
Simultaneous Live, Recording, Playback, Archive and Remote Viewing
16 BNC
Main: BNC&VGA&HDMI; Call: BNC(up to 16-up); Looping: 16 BNC
Recording Mode
Manual, Schedule and Event
Playback Search
Date/Time, Event, Motion in Recorded Video
Audio Input
16
Audio Output
1
Alarm In
16
Alarm Out
4
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Yes
Internal HDD
4
Hot-Swappable HDD
eSATA
2(optional)
1 eSATA (Hot Swappable model doesn't support eSATA)
Built-in DVD Burner
User Interface
OS
Slim Type DVD Burner(Optional)
GUI(Graphical User Interface)
Embedded Linux
Network/Protocol
Control PTZ via OSD
Dual Streaming
USB
100/1000Mbps Ethernet; TCP-IP / DHCP/ PPPoE /
Everfocus DDNS/RTSP/RTP/HTTP/SMTP/POP3/SSL
Yes
Yes
3 USB 2.0 ports (2 on Front Panel, 1 on Back Panel)
Schedule Setting
User Access
Express and Advanced Schedule Setting Tools
3 Levels of User Access Supported
RS-232
9-pin D-Sub socket (male)
RS-485
1 RS485 (3 Terminal connector)
Power Source
Dimensions(L x W x H)
100VAC~240VAC
410 x 430 x 88 mm / 16.2" x 16.9" x 3.5"
0°C~40°C / 32°F~104°F (20~80% humidity)
Certifications
CE, FCC, UL
Support PTZ Protocal
* All product specifications are subject to change without notice
480 NTSC / 400 PAL
(D1:704x480)
16 BNC
Video Output
Temperature
14
PARAGON 264X2
Channel Number
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders Paragon264 Series with HDMI Output
1
2
3
4
5
6
7
Main Power Plug
Мatrix Output x4
(Optional)
Video Input and Looping
eSATA
Network Connector
USB Slot
RS232 Connector
HDMI Output
VGA
Main Monitor Out
Call Monitor Out
RS-485 Connector
Alarm Out
Alarm In
Audio In/Out
8
9
10
11
12
13
14
15
Digital Video Recorders
Major Operating Controls
Rear View
2
1
3
15
4
5
6
7
8
9
10 11
12
13
14
• Front & back panel controls
vary depending on models
Advantages
Тriplex function for D1 Real time
Best performance triplex operation, in D1 resolution you can still have real time recording for 16 cameras at 30 fps, and playback
all 16 cameras with D1 30 fps. It also supports dual streaming for CIF 30FPS compression for 16 cameras to do remote control. It
can achieve best recording quality locally and get smooth image in low bandwidth environment.
+
16CH
480FPS (D1)
recording
+
16CH
480FPS (D1)
playback
16CH
480FPS (D1)
second stream
Full HD Video Output
H.264 Compression Technology
Full HD 1080p brings superior picture performance on a
massive scale, it can provide 1:1 output for mega pixel
camera. Digital output renders stunning images from any
resolution which enhances motion to deliver a smoother and
clearer Viewing.
H.264 compression technology is
considered 1.5 times better
compression ratio than MPEG4.
Benefiting from H.264 Paragon
DVR delivers the crystal clear
images as long with the low
bandwidth consumption.
Comparison
Disk Saving
EverFocus
H.264
DVR
MPEG4
Dimensions
Front View
Side View
410 mm / 16.2”
88 mm / 3.5”
430 mm / 16.9”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
15
Digital Video Recorders ENDEAVOR264 Series with HDMI Output
Digital Video Recorders
ENDEAVOR264L4
16 Channels D1 real-time recording,
8 Channels D1 real-time playback,
Full HD 1080P output
H.264
compression
1080p
FREE
DDNS
Dual
Stream
NEW
D1
Real-Time
Mobile Device
Features
Specifications
• Compatible with FREE Everfocus Central Management
Software
• D1 real time recording rate for 16 cameras
• D1 real time playback rate for 8 cameras
• HDMI video output (1080p)
• Simultaneous main streaming (400 PAL/480 NTSC (D1))
and second streaming
• H.264 Compression format for efficient disk utilization and
network bandwidth conservation
• Normal and event recording frame rate can be set
independently for each camera
• Recording at CIF for remote web viewing to conserve
bandwidth
• Matrix output x 4
• Support eSATA (Future use)
• Gigabit Ethernet interface for remote network viewing and
controlling
• Audio recording capabilities
• Support up to 4 fixed internal HDD
• Pentaplex Operation (Simultaneous live, recording,
playback, archiving and remote viewing)
• Free EverFocus DDNS Service - static IP address is not
required for reliable remote access
• User friendly GUI with graphical icons and visual indicators
• Supports mobile monitoring of live video from PDA and
Smart Phones
• Multiple Control Inputs: mouse/front panel/remote
controller/EKB500 keyboard
• Built-in record time calculator for fast recording estimation
• Express Setup: A unique menu option for quick & easy
installation
• Express Archive: Archive video instantly (to USB) while
playing back
• Express Playback: Simply point, click and drag the playback
bar to view desired recordings
• Express Search: Use the intuitive playback bar with simple
drag & drop operations
• Smart Search: Directly catch the movement in the specified
area
• Snapshot search: Show snapshots of the specified interval,
help quickly find the interested scene
• Remote configuration support from the built-in web
interface
• On-screen PTZ control via mouse or front panel
• Built-in DVD burner (Optional)
• 2 USB 2.0 ports (1 located on front panel, 1 located on back
panel) for video archive and mouse usage
• Multi-language support
• Watermark capabilities to identify intentional modifications
to exported data
• USB Mouse and IR remote control included
Channel Number
Compression Format
HDMI Output
Yes
Recording Rate/Resolution
Playback Rate/Resolution
Mobile Device
Pentaplex Operation
Video Input
Recording Mode
Main: HDMI (1080p), VGA (1280x1024)
Call: BNC(up to 16-up)
Looping: 16 BNC
Matrix x4"
Manual, Schedule and Event; or, choose Number of Days
Playback Search
Date/Time, Event, Motion in Recorded Video, snapshot by Interval
Audio Input
16
Audio Output
2
Alarm In
16
Alarm Out
4
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Yes
Internal HDD
4
eSATA
Yes
Built-in DVD Burner
User Interface
OS
Yes(Optional)
GUI(Graphical User Interface)
Embedded Linux
Network/Protocol
Control PTZ via OSD
Dual Streaming
USB
Gigabit Ethernet; TCP-IP / DHCP/ PPPoE / DDNS
Yes (via both local and remote interfaces)
480 NTSC / 400 PAL (CIF)
2 USB 2.0 port (on Front Panel)
Schedule Setting
User Access
Express and Advanced Schedule Setting Tools
3 Levels of User Access Supported
RS-232
Yes
RS-485
RJ45x2
Power Source
100~240VAC ,110W max
Dimensions(L x W x H)
430 x 423 x 72 mm / 16.93" x 16.65" x 3.13"
Temperature
0°C~40°C / 32°F~104°F (20~80% humidity)
CE, FCC, UL
Support PTZ Protocal
* All product specifications are subject to change without notice
480 NTSC / 400 PAL (D1:704x480)
480 NTSC / 400 PAL (Half D1:704x240)
480 NTSC / 400 PAL (CIF:352x240)
D1 8CH
240 NTSC / 200 PAL (D1:704x480)
240 NTSC / 200 PAL (Half D1:704x240)
240 NTSC / 200 PAL (CIF:352x240)
®
Live view on PDA or Smart Phones (MobleFocus FREE app for iPhone
and Android™) plus various web browsers
Simultaneous Live, Recording, Playback, Archive and Remote Viewing
16 BNC
Video Output
Certifications
16
16
H.264
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders ENDEAVOR264L4 Series with HDMI Output
1
2
3
4
5
6
7
Main Power Plug
Network Connector
RS232 Connector
RS485 Connector
Main VGA
HDMI Output
Call Monitor Out
8
9
10
11
12
13
14
Alarm In
Alarm Out
eSATA
Audio In
Audio Out
Video Input and Looping
Matrix
Digital Video Recorders
Major Operating Controls
Rear View
• Front & back panel controls
vary depending on models
Advantages
Real-time High-resolution Recording
Applying high speed data processing technology across all channels with H.264 full-frame compression, the ENDEAVOR achieves
the ability to record and play real time video on all channels on all models. Frame rate can be independently set over the channels
to fit the different recording speed requests in different scenes. The ENDEAVOR264L4 series also provides the simultaneous full
speed playback over all channels while recording.
Video Streaming to Mobile Devices
H.264 Compression Technology
The ENDEAVOR264 series supports streaming for and mobile
monitoring, allowing you the capability to check your home
or business on-the-go directly from a variety of RTSP capable
mobile devices – FREE! No additional servers or purchased
programs required.
H.264 compression technology is
considered 1.5 times better
compression ratio than MPEG4.
Benefiting from H.264 Paragon
DVR delivers the crystal clear
images as long with the low
bandwidth consumption.
Comparison
Disk Saving
EverFocus
H.264
DVR
MPEG4
Dimensions
Front View
Side View
395mm
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
430mm
72mm
430mm
* All product specifications are subject to change without notice
17
Digital Video Recorders ECOR264 Series Network H.264 with GUI
Digital Video Recorders
ECOR264X1 Series DVR
4, 9 or 16 Channels Network H.264 with Graphical User Interface
PDA/
Smart Phone
18
Features
Specifications
• H.264 Compression format for efficient disk utilization and network
bandwidth conservation
• Real time recording rate and playback rate for all cameras
• Normal and event recording frame rate can be set independently for
each camera
• Multiple Main Monitors: VGA (800x600, 1280X1024*)/BNC Main
monitor outputs
• Call monitor: additional composite BNC output with multiplex and/or
sequenced views
• Simultaneous recording at D1 or 2CIF with real time streaming at CIF
for remote web viewing to conserve bandwidth
• Pentaplex Operation (Simultaneous live, recording, playback, archiving
and remote viewing)
• Free EverFocus DDNS Service - static IP address is not required for
reliable remote access
• User friendly GUI with graphical icons and visual indicators
• Supports eSATA (Future use, hot-swappable model does not support
eSATA)
• Supports 3GPP for mobile monitoring
• Multiple Control Inputs: mouse/front panel/remote controller/EKB500
keyboard
• Built-in record time calculator for fast recording estimation
• Express Setup: A unique menu option for quick & easy installation
• Express Archive: Archive video instantly (to USB) while playing back
• Express Playback: Simply point, click and drag the playback bar to
view desired recordings
• Express Search: Use the intuitive playback bar with simple drag & drop
operations
• Smart Search: Directly catch the movement in the specified area
• Snapshot search: Show snapshots of the specified interval, help
quickly find the interested scene
• Remote configuration support from the built-in web interface
• Gigabit Ethernet interface for remote network viewing and control
• On-screen PTZ control via mouse or front panel
• Support for up to 1 Hot Swappable HDD or 2 fixed internal HDD
• Built-in DVD burner (Optional)
• 2 USB 2.0 ports (1 located on front panel, 1 located on back panel) for
video archive and mouse usage
• Multi-language support
• Watermark capabilities to identify intentional modifications to exported
data
• 19” Rack mountable
• USB Mouse and IR remote control included
Model No.
Channel Number
Compression Format
Recording Rate/
Resolution
* All product specifications are subject to change without notice
Playback Rate/
Resolution
Mobile Device
Pentaplex Operation
Video Input
Video Output
Recording Mode
Playback Search
Audio Input
Audio Output
Alarm In
Alarm Out
Video Pause
Video Loss Detection
Motion Detection
Event Log
Watch Dog Timer
Internal HDD
Hot-Swappable HDD
eSATA
Built-in DVD Burner
User Interface
OS
Network/Protocol
Control PTZ via OSD
Dual Streaming
USB
Schedule Setting
User Access
RS-232
RS-485
Power Source
Dimensions(L x W x H)
Temperature
Certifications
Support PTZ Protocal
ECOR264x1
9
4
H.264
120 NTSC / 100 PAL
120 NTSC / 100 PAL
120 NTSC / 100 PAL
(D1:704x480)
(D1:704x480)
(D1:704x480)
120 NTSC / 100 PAL
240 NTSC / 200 PAL
240 NTSC / 200 PAL
(Half D1:704x240)
(Half D1:704x240)
(Half D1:704x240)
480 NTSC / 400 PAL
270 NTSC / 225 PAL
120 NTSC / 100 PAL
(CIF:352x240)
(CIF:352x240)
(CIF:352x240)
120 NTSC / 100 PAL
120 NTSC / 100 PAL
120 NTSC / 100 PAL
(D1:704x480)
(D1:704x480)
(D1:704x480)
240 NTSC / 200 PAL
120 NTSC / 100 PAL
240 NTSC / 200 PAL
(Half D1:704x240)
(Half D1:704x240)
(Half D1:704x240)
270 NTSC / 225 PAL
120 NTSC / 100 PAL
480 NTSC / 400 PAL
(CIF:352x240)
(CIF:352x240)
(CIF:352x240)
Live view on PDA or Smart Phones (MobleFocus FREE app for iPhone®
and Android™) plus various web browsers
Simultaneous Live, Recording, Playback, Archive and Remote Viewing
16 BNC
9 BNC
4 BNC
Main: VGA&BNC
Main: VGA&BNC
Main: VGA&BNC
Call: BNC(up to 16-up)
Call: BNC(up to 9-up)
Call: BNC(up to 4-up)
Looping: 16 BNC
Looping: 9 BNC
Looping: 4 BNC
Manual, Schedule and Event
Time search, Event search, Smart search, Snapshot search
4
1
16
9
4
4
2
1
Yes
Yes
Yes
Yes
Yes
2
1(optional)
1 eSATA (Hot Swappable model doesn't support eSATA)
Yes(Optional)
GUI(Graphical User Interface)
Embedded Linux
Gigabit Ethernet; TCP-IP / DHCP/ PPPoE / Everfocus DDNS/RTSP/RTP/
HTTP/SMTP/POP3/SSL
Yes
Yes
2 USB 2.0 ports (1 on Front Panel, 1 on Back Panel)
Express and Advanced Schedule Setting Tools
3 Levels of User Access Supported
Yes
1 RS485 (3 Terminal connector)
DC12V (from included 110/220VAC power supply)
353.0 x 354.8 x 70.60 mm / 13.89" x 13.96" x 3.055"
0°C~40°C / 32°F~104°F (20~80% humidity)
CE, FCC, UL
EverFocus, Pelco D, Pelco P, Samsung, Transparent
16
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders ECOR264 Series Network H.264 with GUI
1
2
3
4
5
6
Main Power Plug
Ethernet
USB
RS-232 Connector
RS-485 Connector
Main Monitor Out
7
8
9
10
11
12
VGA Connector
Alarm lnput
Alarm Output
Аudio In/Out
Video In/Out
eSATA
Digital Video Recorders
Major Operating Controls
Rear View
• Front & back panel controls
vary depending on models
Advantages
H.264 Compression Technology
Comparison
H.264 compression technology is considered 1.5
times better compression ratio than MPEG4.
Benefiting from H.264, ECOR series DVR delivers
the crystal clear images along with low bandwidth consumption.
Disk Saving
EverFocus
H.264
DVR
MPEG4
GUI
With Graphical User Interface (GUI), users can command specific actions on the ECOR Series DVR through graphical icons and
visual indicators. Simply click the screen to do live or playback on the selected channel.
Dimensions
Front View
Side View
70 mm / 2.75”
355 mm / 13.97”
355 mm / 13.97”
11 mm/0.4”
2.4 mm/0.09”
4.3 mm/0.2”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
19
Digital Video Recorders ECOR264 Series Network H.264 with GUI
Digital Video Recorders
ECOR264 D2 Series DVR
NEW
4 or 8 Channels Network H.264 with Graphical User Interface
Dual
Stream
H.264
compression
FREE
DDNS
Features
Specifications
• Compatible with FREE EverFocus Central Management Software
• H.264 Compression format for efficient disk utilization and network
bandwidth conservation
• Recording resolution and rate can be set independently for each
camera, and changed via user defined schedule
• Streaming at CIF for remote web viewing to conserve bandwidth
• Pentaplex Operation (Simultaneous live, recording, playback, archiving
and remote viewing)
• Free EverFocus DDNS Service - static IP address is not required for
reliable remote access
• User friendly colour GUI with graphical icons and visual indicators
• Supports mobile monitoring of live video from PDA and Smart Phones
• Multiple Control Inputs: mouse/front panel/IR remote controller/
EKB500 keyboard
• Built-in record time calculator for fast recording estimation
• Express Setup: A unique menu option for quick & easy installation and
setup
• Express Archive: Archive video instantly (to USB) while playing back
• Express Playback: Simply point, click and drag the playback bar to
view desired recordings
• Express Search: Use the intuitive playback bar with simple drag &
drop operations
• Smart Search: Review recorded video to identify motion in area(s) of
interest
• Snapshot search: choose an interval and direction, view a series of
snapshots to quickly isolate incidents
• Remote viewing of live and recorded video, plus configuration support
from the built-in web interface
• On-screen PTZ control via mouse or front panel
• Built-in DVD burner (Optional)
• 2 USB 2.0 ports (1 located on front panel, 1 located on back panel) for
video archive and mouse usage
• Multi-language support
• USB Mouse and IR remote control included
Model No.
ECOR264-8D2
Channel Number
Recording Rate/
Resolution
Playback Rate/
Resolution
Mobile Device
Pentaplex Operation
Video Input
Video Output
H.264
60 NTSC / 50 PAL (D1:704x480)
60 NTSC / 50 PAL (D1:704x480)
120 NTSC / 100 PAL
120 NTSC / 100 PAL
(Half D1:704x240)
(Half D1:704x240)
240 NTSC / 200 PAL (CIF:352x240) 120 NTSC / 100 PAL (CIF:352x240)
60 NTSC / 50 PAL (D1:704x480)
60 NTSC / 50 PAL (D1:704x480)
120 NTSC / 100 PAL
120 NTSC / 100 PAL
(Half D1:704x240)
(Half D1:704x240)
240 NTSC / 200 PAL (CIF:352x240) 120 NTSC / 100 PAL (CIF:352x240)
®
Live view on PDA or Smart Phones (MobleFocus FREE app for iPhone
and Android™) plus various web browsers
Simultaneous Live, Recording, Playback, Archive and Remote Viewing
8 BNC
4 BNC
Main: VGA or BNC(up to 9-up)
Main: VGA or BNC(up to 4-up)
Recording Mode
Manual, Schedule and Event
Playback Search
Date/Time, Event, Motion in Recorded Video, Snapshot by Interval
Audio Input
1
Audio Output
1
Alarm In
8
Alarm Out
4
1
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Yes
Internal HDD
1
Built-in DVD Burner
Slim Type DVD Burner(Optional)
User Interface
GUI(Graphical User Interface)
Embedded Linux
Network/Protocol
Control PTZ via OSD
Dual Streaming
USB
10/100Mbps Ethernet; TCP-IP / DHCP/ PPPoE / Everfocus DDNS/RTSP/RTP/
HTTP/SMTP/POP3/SSL
Yes
Yes
No
2 USB 2.0 ports (1 on Front Panel, 1 on Back Panel)
Schedule Setting
User Access
Express and Advanced Schedule Setting Tools
3 Levels of User Access Supported
RS-232
Yes
RS-485
1 RS485 (3 Terminal connector)
Power Source
DC12V (from included 110/220VAC power supply)
Dimensions(L x W x H)
320 x 208.9 x 54.3 mm / 12.6" x 8.2" x 2.1"
Temperature
0°C~40°C / 32°F~104°F (20~80% humidity)
Certifications
CE, FCC, UL
Support PTZ Protocal
* All product specifications are subject to change without notice
4
Compression Format
OS
20
ECOR264-4D2
8
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders ECOR264 Series Network H.264 with GUI
1
2
3
4
5
6
Main Power Plug
Alarm In
RS-485 Connector
Аudio In/Out
Video In
Main Monitor Out
7
8
9
10
11
VGA
USB Port
Network Connector
RS232 Connector
Alarm Out
Digital Video Recorders
Major Operating Controls
Rear View
Rear View
• Front & back panel controls
vary depending on models
Advantages
H.264 Compression Technology
Comparison
H.264 compression technology is considered 1.5
times better compression ratio than MPEG4.
Benefiting from H.264, ECOR series DVR delivers
crystal clear images along with low bandwidth consumption.
Disk Saving
EverFocus
H.264
DVR
MPEG4
GUI
With Graphical User Interface (GUI), users can command specific actions on the ECOR Series DVR through graphical icons and
visual indicators. Simply click the screen to do live or playback on the selected channel.
Dimensions
Front View
Side View
320mm
208.9mm
11mm
50.2mm
54.3mm
2.7mm
4.3mm
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
21
Digital Video Recorders ELR Series Network H.264 with GUI
Digital Video Recorders
ELR Series DVR
4 or 8 Channels Network H.264 with Graphical User Interface
H.264
compression
FREE
DDNS
Features
Specifications
• H.264 Compression format
• Pentaplex Operation (Simultaneous live, recording,
playback, archiving and remote viewing)
• User friendly GUI with graphical icons and visual
indicators
• Free EverFocus DDNS Service
• Multiple Control Inputs: mouse/front panel/remote
control
• Built-in DVR calculator for fast recording estimation
• Express Setup: Located in menu option for quick &
easy installation
• Remote configuration support from built-in web
interface
• Audio recording capabilities
• Support 1 internal SATA HDD
• USB 2.0 ports on front panel for video archive and
mouse usage
• Multi-language support
Channel Number
Recording Rate/
Resolution
Playback Rate/Resolution
Mobile Device
Pentaplex Operation
Video Input
Video Output
30 NTSC / 25 PAL (D1:704x480)
60 NTSC / 50 PAL (Half D1:704x240)
120 NTSC / 100 PAL (CIF:352x240)
30 NTSC / 25 PAL (D1:704x480)
60 NTSC / 50 PAL (Half D1:704x240)
120 NTSC / 100 PAL (CIF:352x240)
®
Live view on PDA or Smart Phones (MobleFocus FREE app for iPhone
and Android™) plus various web browsers
Simultaneous Live, Recording, Playback, Archive and Remote Viewing
8 BNC
4 BNC
Main: VGA or BNC(up to 9-up)
Main: VGA or BNC(up to 4-up)
Manual, Schedule and Event
Playback Search
Date/Time, Event
Audio Input
1
Audio Output
1
Alarm In
8
Alarm Out
4
1
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Event Log
Yes
Watch Dog Timer
Yes
1
Built-in DVD Burner
User Interface
OS
Slim Type DVD Burner(Optional)
GUI(Graphical User Interface)
Embedded Linux
Network/Protocol
Control PTZ via OSD
Dual streaming
USB
10/100Mbps Ethernet; TCP-IP / DHCP/ PPPoE / Everfocus DDNS/RTSP/
RTP/HTTP/SMTP/POP3/SSL
Yes
Yes
2 USB 2.0 ports (1 on Front Panel, 1 on Back Panel)
Schedule Setting
User Access
Express and Advanced Schedule Setting Tools
3 Levels of User Access Supported
RS-485
1 RS485 (3 Terminal connector)
Power Source
DC12V (from included 110/220VAC power supply)
Dimensions(L x W x H)
320 x 208.9 x 54.3 mm / 12.6" x 8.2" x 2.1"
Temperature
0°C~40°C / 32°F~104°F (20~80% humidity)
Certifications
CE, FCC, UL
Support PTZ Protocal
* All product specifications are subject to change without notice
4
H.264
Recording Mode
Internal HDD
22
8
Compression Format
EverFocus, Pelco D, Pelco P, Samsung, Transparent
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Digital Video Recorders ELR Series Network H.264 with GUI
1
2
3
4
5
Main Power Plug
Alarm Input
Alarm Output
RS485 Connector
Audio In/Out
6
7
8
9
10
Video In
Video Out
VGA Connector
USB
Network Connector
Digital Video Recorders
Major Operating Controls
Rear View
Rear View
• Front & back panel controls
vary depending on models
Advantages
H.264 Compression Technology
Comparison
H.264 compression technology is considered 1.5
Times better compression ratio than MPEG4.
Benefiting from H.264, ELR series DVR delivers
the crystal clear images as long with low bandwidth consumption.
Disk Saving
EverFocus
H.264
DVR
MPEG4
GUI
With Graphical User Interface (GUI), users can command specific actions on the ELR Series DVR through graphical icons and visual
indicators. Simply click the screen to do live or playback on the selected channel.
Dimensions
Front View
Side View
50.2 mm / 2”
54.3 mm / 2.1”
320 mm / 12.6”
208.9 mm / 8.2”
2.4 mm/0.09”
11 mm/0.4”
4.3 mm/0.2”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
23
DVR Accessories Manageement Software
DVR Accessories
PowerCon 4.3
Network Management Software
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Unlimited number of managed systems (DVRS, Megapixel/network cameras, video servers, 3rd party applications)
Live and playback view of DVR
Live view and recording of EverFocus NEVIO network cameras
Local storage and printout of video data or single pictures on client PC
Multi-window design with scalable video windows
Freely definable multiviews with up to 16 DVR systems or network cameras, also mixed display of different DVRs (max. 256
cameras in 1 multiview with 16 × 16-channel DVR)
Mapview: visualization of CCTV system in areas or buildings with freely scalable maps, graphics (BMP or JPG format) or active
symbols
Remote DVR configuaration
Remote configuration of EverFocus network cameras and video servers
EKB 200 joystick control supported
Network alarm reception and management
Multi-monitor support (depending on PC configuration)
Advanced access rights management with individual user rights for functions and system access
Network monitor for visualization of network traffic
System checker: integrated background port checker with alarm function for availability of DVRs, cameras and video servers in
network
Support of external program starts
Basic feature support for browser-based 3rd party application
System Requirements
Processor:
Operating System:
VGA Card:
USB:
Memory:
Mediaplayer:
Further:
Supported DVRs:
Supported Network Cameras:
Supported Megapixel Cameras:
Further Supported Devices:
PC Pentium IV (1.6 or higher) / AMD Athlon (1.8 or higher)
Windows XP, service pack 2, .NET Framework 2.0, service pack 1,
Windows Vista
32 MB min., 16,7 million colours, with DirectX 9.0C support
2.0 interface
512 MB RAM
30 MB free HD space for installation
min. 10 GB free HD space for storage
Microsoft mediaplayer version 8.x or higher
DirectX 9.0C
EDR 400 / 1600*
EDSR 400 H / M / EDSR 100 / 600 / 900 / 1600*
EDR 410/810 H/M / EDR 410 D / 910 A/D / 1610 A/D / 920/1640,
EDVR series**
ECOR4 / ECOR 8 (FW1.0.10b2 or higher)
EDR-16 Paragon series (FW 1.0.13 or higher)
* latest DVR firmware version
** firmware 1.7 or higher!
EAN 600 / 800 / 850 A / EZN 850 / EDN 800 T / EDN850H
EAN 1350 / EAN 900
Video servers EVS 400 / EVS 100
Network multi I/O controller EPS 100
*Performance varies depending on equipments used and subject to actual test result
24
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
DVR Accessories EverFocus Network DVR Manager
DVR Accessories
ECMS-DVR
EverFocus Network DVR Manager
Overview
1. Support MPEG-4 and H.264
2. Support Paragon, Paragon 264, ECOR, ELR and EDR/EDVR DVR
3. Support Google-Map (Geographic map) and E-Map function
Specifications
Support Device
Max. Client Access
Max. Device Access
Max. DVR per screen
Operation UI
Authorization
Live Video Monitoring
1. Support configurable view layout and display presets for custom split
screens with assigned DVR
2. Support remote viewing
3. Multi-monitor support Video TV Wall via display terminal setting
4. User grouping tree, device tree and map tree with filtered views
5. Support PTZ control, including control of presets and patterns, tours
6. Support device drag and drop function on layout setting and device
configuration
7. Support multiple monitors to display separate information
8. View real-time alarms and alarm history
Map
Video Compression
Live view
Playback and Search
1. Support multiple concurrent video and audio playback from DVR
2. Searching can be queried based on channel; date and time and event type
3. Support several playback speeds in fast forward and fast reverse playback.
4. Support multiple video and audio archive
Live Monitor
User Management
1. User database with login, password and contact details
2. Support user authentication and permission
3. Support user grouping. One user can be assigned to one group and inherit
the privileges of the group
4. User privileges can be assigned per DVR, per E-map and per virtually any
function
Playback & Search
PTZ Control Panel
Paragon, Paragon 264, ECOR, ELR and EDR/EDVR series
DVR
unlimited
unlimited
4
Browser based
Basic User profile
Restrict user access by Camera, user view by map,
access to live view, PTZ, playback, setup
E-Map, Google Map
Edit Map-Link Region
Insert DVR
Max. 4 Map level
Unlimited Map
MPEG4, H.264
30 fps
1x1, 2x2 views and single screen, quad,
9 up and 16up view for each DVR
Support Drag-and-Drop
Unlimited Display Terminal
Support TV Wall with unlimited Display Terminal
Search by Date/Time, Event Archive
Max. 16ch playback at the same time
Preset, Pattern, Tour, Auto Pan, Patrolling
Multiple Patrolling Schemes
Recommended System Requirements
Minimum System Requirements
a) When more than 4 DVRs or IP devices are enabled in live view and playback
mode together, it is recommended that the client PC meets below system
requirements for optimal performance.
•
Intel Core2 Duo E7400 2.8 GHz or higher, 3 MB Cache,
1066 MHz FSB
•
2.0 GB of RAM
•
Graphics card with 512 MB memory or better
•
10 GB of free hard disk space or more
•
1024 x 768 or higher screen resolution
•
10/100/1000 Ethernet Network adapter
•
•
•
•
•
•
Intel Pentium4 531 3.0 GHz, 1 MB Cache, 800 MHz FSB
1.0 GB of RAM
Graphics card with 256 MB memory or better
10 GB of free hard disk space or more
1024 x 768 or higher screen resolution
10/100/1000 Ethernet Network adapter
b) When more than 16 DVRs or IP devices are enabled in live view and
playback mode together, it is recommended that the client PC meets below
system requirements for optimal performance.
•
Intel Core2 Quad Q9400 2.66 GHz or higher, 6 MB Cache,
1333 MHz FSB
•
4.0 GB of RAM
•
Graphics card with 1 GB memory or better
•
10 GB of free hard disk space or more
•
1024 x 768 or higher screen resolution
•
10/100/1000 Ethernet Network adapter
*Performance varies depending on equipments used and subject to actual test result
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
25
Mobile Video Surveillance
26
* All product specifications are subject to change without notice
Mobile Cameras EMW Series
EMW330/EMW330T
Mobile Cameras
Vandal Resistant Mobile Camera with IR,
IP67, Side/Rear/Wall/Ceiling Mounting
Visual
Light Senor
Features
•
•
•
•
•
•
•
•
•
•
•
Specifications
1/3” Sony Super HAD CCD
Resolution 520TVL
Streamline wedge type chassis
Vari-focal lens model with ICR feature (EMW330T)
Fixed lens model with dual-position lens and IR
illuminator (EMW330)
Dual-position lens
Dual-position IR illuminators provide clear images
up to 50 feet away
Vandal resistant, IP67 housing
Side/Rear/Wall/Ceiling mounting options, no bracket
required
Built-in heater
Visible light sensor provides IR illumination only
when needed
Model
EMW330
Pickup Device
EMW330T
1/3'' SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768x494/PAL: 752x582
Horizontal Resolution
Sensitivity
520TVL
0.4 Lux / F=1.2 (IR OFF) ; 0 Lux (IR ON)
S/N Ratio
Over 48dB (AGC Off)
Electronic Shutter
1/50 (1/60)~1/100,000
Video Output
BNC 1.0Vp-p , 75ohm
Gamma Correction
Lens Type
0.45
Fixed lens options: f=3.6/8/16mm
Back Light Comp.
Auto Gain Control
Yes
Auto White Balance
Yes (2500K~9000K)
Sync. Mode
Day/Night
Day/Night Detection
Internal sync
Electronic
Auto IR Cut Removable
Visible light sensor
Built-in Heater
IR LEDs
IR LED Lifespan
Dimensions
Bottom View
50 feet
850nm
Weather Proof
IP67
Vandal Proof
Yes
Power Source
12VDC minimum ; 13.8VDC nominal
Mounting Options
Viewing Direction
Dimensions (W x D x H)
67mm/2.6”
20,000 hours nominal
IE Wavelength
IR LEDs Direction
Operating Temperature
140mm/5.5”
Yes
40 emitters in two arrays
IR Distance
Power Consumption
Top View
Vari-Focal Lens, f=2.9~10mm/F=1.2,
f=9~22mm/F=1.6
Yes
Weight
Certifications
8.4W max at 12VDC (Heater ON & IR LED ON)
Side/Rear/Wall/Ceiling mounting options, no bracket required
Dual-Position (forward/downward)
Single-Position (forward)
-40°C~60°C/-40°F~140°F
105mm x 140mm x 65mm / 4.2” x 5.6” x 2.6”
600g
CE, FCC
70mm/2.8”
Front View
Side View
64.5mm/25”
105mm/4.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
27
Mobile Cameras EMD Series
EMD302
NEW
Mobile Cameras
1/3” Colour DSP, Indoor
Small Vandal-Proof Dome
AGC
540
Vandal proof
Yes
AWB
Yes
BLC
Yes
Features
Specifications
• Colour camera PCB module with 1/3” High
Resolution Sensor in mini Dome
• Employs Digital Signal Processor (DSP) chip-set for
image control
• Pixel number: NTSC=380K / PAL=440K. (High
Resolution)
• High sensitivity, low smear, high anti-blooming, and
high S/N ratio
• Support functions: Auto Electronic Shutter (AES),
Auto Gain Control (AGC), Auto White Balance (AWB)
• Economical, furnished with mini lens
• Built-in anti-aliasing and IR-cut optical filter
• Furnished with DC power cable and video cable
• DC type, low power consumption
• Easy to install, easy to use
Image Pick-up Device
1/3” High Resolution Sensor
Effective Picture
Elements
Horizontal Resolution
NTSC: 768 x 494 (H x V)
PAL: 752 x 582 (H x V)
540 TVL
Minimum Illumination
0.02Lux / F=1.2
S/N Ratio
More than 48 dB
Auto Electronic
Shutter
Gamma Characteristic
Lens Furnished
Auto Gain Control
NTSC:1/60s ~ 1/100,000s
PAL:1/50s ~ 1/110,000s
0.45
Board lens f 2.5mm / F 2.0
(optional: f =3.6 / 4.3 / 6.0 / 8.0 / 12 / 16 mm)
Yes
Auto White Balance
Yes
Synchronous System
Negative sync. Internal.
Video Output
Power Supply
Power Consumption
Operating Temp.
Dimensions
1 Vp-p / 75 Ohms. BNC or F connector
DC 12V
75mA max
-10°C to 50°C (14°F to 122°F)
87.5 mm (W) × 56.5 mm (H)
Dimensions
68 mm
93mm
28
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Mobile Cameras EMD Series
EMD300
380 IR
10~12m
AWB
Yes
BLC
Yes
Mobile Cameras
Compact Weather & Vandal Proof
Mobile/Fixed Day/Night Mini-Dome Camera
AGC
Yes
Features
Specifications
• Super HAD II sensor at .05 lux has superlative
native light sensitivity
• High resolution 550TVL
• Day/Night operation
• Vandal resistant
• Weather resistant
• Compact size
• Choice of black or white housing colour
• Low current draw
Pickup Device
Video Format
Picture Elements
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Day & Night
Power Source
Power Consumption
Operating Temperature
Humidity
Dimensions
Weight
Certifications
1/3" SONY Super HAD II CCD
NTSC
768 x 494(NTSC)
550 TVL
0.05Lux/F=1.2(AGC ON)
Over 45dB (AGC off)
1/60 ~1/100,000
BNC 1.0V p-p 75Ω,
0.45
3.6mm board type
Switches to B/W in low light
12VDC nominal. +/- 10%.
100mA @ 12VDC
-10°C~+50°C ; 14°F~122°F
IP66
81mm(D) x 63mm (H) ; 3.19 ”(D) x 2.48”(H)
0.25 kg / 0.55 lbs
CE / FCC
Dimensions
63mm / 2.5”
33.5mm / 1.3”
59.5mm / 2.3”
51mm / 2”
360° Pan
51mm / 2”
81mm / 3.2”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
29
Mobile Cameras Vehicle Camera
AVM-950H
Mobile Cameras
Internal Vehicle Camera,
Can be used on the windscreen
Mirror
1/3” CCD
LENS 4mm
NEW
DC 12V
Features
Specifications
• 1/3” CCD Image Sensor
• 520 TVL
• Mirroring, Clear Image for Back-Draft.
MODE
NTSC
PAL
PICK UP ELEMENT
1/3 Inch CCD Image Sensor
IMAGE SIGNAL
PROCESS
NUMBER OF PIXEL
Digital Signal Processing System
PICTURE ELEMENTS
HORIZONTAL
RESOLUTION
POWER SUPPLY
768 (H) × 494 (V)
752 (H) × 582 (V)
Approximately 380K
Approximately 440K
Approximately 520 TV Lines
DC +12V
CURRENT
CONSUMPTION
SYNCHRONIZATION
80 mA
Internal
SCANNING SYSTEM
2 : 1 Interlace
SENSITIVITY
0.09 LUX
S/N RATIO
Max 48 dB
AUTO ELECTRONIC
IRIS
BACK LIGHT
COMPENSATION
AUTO GAIN CONTROL
ELECTRONIC
SHUTTER
OUTPUT
Automatically
Automatically
Automatically
NTSC: AUTO: 1/60S TO 1/100,000 S
PAL: AUTO: 1/50 S TO 1/100,000 S
1 Vp-p Composite Video Output, 75 Ohms
LENS MOUNT
LENS
OPERATING
TEMPERATURE
DIMENSIONS
- 5°C ~ +40°C
59mmx32mmx52mm
WEIGHT
About 54.5g (N.W)
52
Dimensions
30
r
29
54.8
32
59
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Mobile Cameras Vechicle View IR Camera
AVM-930BV
Mirror
1/3” CCD
Mobile Cameras
NEW
Vechicle View IR Camera
DC 12V
Features
Specifications
• 1/3” SONY CCD
• Waterproof.
• 13PCS LEDS, Good Night Time Image, IR Distance
10M
• Adjustable Two Axis bracket, Tilt: 100º & Pan: 30º.
• Mirroring, Clear Image for Back-Draft.
• Diagonal: 128º
• Horizontal: 96º
• Vertical: 69º
VIDEO SYSTEM
PICK UP ELEMENT
IMAGE SIGNAL
PROCESS
LENS MOUNT
NUMBER OF PIXEL
PICTURE ELEMENTS
HORIZONTAL
RESOLUTION
POWER SUPPLY
NTSC
PAL
1/3 INCH CCD IMAGE SENSOR ( INTER LINE )
DIGITAL SIGNAL PROCESSING SYSTEM
2.9 mm
510 (H) x 492 (V)
500 (H) x 582 (V)
APPROXIMATELY 250K
APPROXIMATELY 290K
MAX. 420 TV LINES
DC 12 ± 1V (at IR_ON 240 mA)
SYNCHRONIZATION
INTERNAL
SCANNING SYSTEM
2 : 1 INTERLACE
SENSITIVITY
0 LUX -IR ON
SENSITIVITY
0.01Lux
S/N RATIO
Max 48 dB
MIRRORING
YES
AUTO GAIN CONTROL
YES
WHITE BALANCE
ELECTRONIC
SHUTTER
OUTPUT
AUTO
AUTO: 1/60S TO 1/10000S AUTO: 1/50S TO 1/10000S
1 Vp-p COMPOSITE VIDEO OUTPUT, 75 OHMS
IR RANGE
850 nm
OPERATING
TEMPERATURE
TILT(1)
-5° C ~ +60° C
Max : 100°
PAN(2)
Dimensions
77
10 M
WAVELENGTH
Max : 30°
DIMENSIONS
(H × W × D)
WEIGHT
69 × 77 × 76 mm
About 320g
69
76
2
3
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
31
Mobile Cameras Vehicle view Camera
AVM-730A/AVM-730BV
Mobile Cameras
Vehicle view Camera for internal or external use
NEW
Mirror
1/4” CCD
Features
Specifications
• 1/4” Inter Line Transfer CCD
• 420 TVL
• Adjustable Three Axis bracket, Tilt: 80º, Rotation:
360º, & Pan: 60º.
• Mirroring, Clear Image for Back-Draft.
• Diagonal: 136º
• Horizontal: 110º
• Vertical: 80º
Model
AVM730A
Type
NTSC
AVM730A-BV
PAL
Pick Up
NTSC
Image Signal Process
Number Of Pixel
Digital Signal Processing System
510(H)×492(V)
512(H)×582(V)
Picture Elements
Sync System
2 : 1 Interlace
Sensitivity
0.12 LUX
S/n Ratio
Max 48 dB
Mirroring
Yes
N/A
Yes
White Balance
Electronic Shutter
Video Output Signal
Auto
NTSC:AUTO: 1/60 S TO 1/100,000 S
PAL:AUTO: 1/50 S TO 1/100,000 S
1 Vp-p Composite Video Output, 75 Ohms
Power Supply
Power Consumption
DC 5.5V ~14.5V
120mA / 5.5v~50mA / 14.5V
Lens
Operating
Temperature
Dimensions
512(H)×582(V)
Internal
Scanning System
Auto Gain Control
1.92mm
H : 110° V : 80° Diagonal :136
-30° C ~ +75°C
Diameter : 28mm L : 38mm
Tilt(1)
Dimensions
510(H)×492(V)
NTSC:Approximately 250K
PAL:Approximately 290K
Max 420 TV Lines
Horizontal Resolution
View Angle
PAL
1/4 Inch Inter Line Transfer CCD
Max : 80°
Rotation(2)
360°
Pan(3)
Max : 60°
Weight
About : 66g
3
1
37.8
42
2
32
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Mobile Cameras Vehicle view Camera
AVM-730C/AVM-730BV
Mobile Cameras
Vehicle view Camera for internal or external use
NEW
Mirror
1/4” CCD
Features
Specifications
• 1/4” Inter Line Transfer CCD
• 420 TVL
• Adjustable Three Axis bracket, Tilt: 80º, Rotation:
360º, & Pan: 60º.
• Mirroring, Clear Image for Back-Draft.
• Diagonal: 160º
• Horizontal: 128º
• Vertical: 97º
Model
Type
AVM730C
NTSC
Pick Up
NTSC
Digital Signal Processing System
510(H)×492(V)
512(H)×582(V)
Picture Elements
Sync System
2 : 1 Interlace
Sensitivity
0.12 LUX
S/n Ratio
Max 48 dB
Yes
N/A
Yes
White Balance
Electronic Shutter
Video Output Signal
Power Supply
Power Consumption
Auto
NTSC:AUTO: 1/60 S TO 1/100,000 S
PAL:AUTO: 1/50 S TO 1/100,000 S
1 Vp-p Composite Video Output, 75 Ohms
DC 5.5V~14.5V
120mA / 5.5V~50mA / 14.5V
Lens
View Angle
Operating
Temperature
Dimensions
512(H)×582(V)
Internal
Scanning System
Auto Gain Control
1.59mm
H : 128° V : 97° Diagonal :160°
-30° C ~ +75°C
Diameter : 23mm L : 36mm
Tilt(1)
Max : 80°
Rotation(2)
Dimensions
510(H)×492(V)
NTSC:Approximately 250K
PAL:Approximately 290K
Max 420 TV Lines
Horizontal Resolution
Mirroring
PAL
1/4 Inch Inter Line Transfer CCD
Image Signal Process
Number Of Pixel
AVM730C-BV
PAL
360°
Pan(3)
Max : 60°
Weight
About : 66g
3
26
26
42
31.8
Ø23
36
1
2
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
33
Mobile Digital Video Recorders EMV Series
EMV1200
Mobile Digital Video Recorders
Compact 12 Channels H.264 Mobile DVR
NEW
(Wi-Fi optional)
H.264
compression
Features
• 12 Channels of video and audio recording
• Recording Rate: 120fps @ D1 resolution/240fps@
2CIF/480fps@CIF resolution (with global settings;
record rate, resolution and quality can be set
independently per-camera up to the maximum of
480CIF-equivalent FPS)
• H.264 compression format for efficient disk and
network utilization
• Front and rear panel video/audio outputs for easy
connection and configuration
• Special Graphical User Interface design for use with
mobile small-sized monitors
• Molex connectors for shock & vibration resistance;
interface cables to BNC, RCA and power jacks
supplied
• Alarm Inputs & Outputs: 12 & 2 (alarm outputs are
form “C”)
• Embedded 3-axis g-sensor function with separate
programmable alarm levels for X/Y and Z axis
• Removable video storage hard disk ; easy playback
on PC (using EPR110 purchased separately)
• Supports single 3.5" or 2.5" SATA hard disk
• Supports multiple interfaces: 3xUSB, RS-485, RS232, GPS port, wired Ethernet, IR Remote Control
• Optional wireless 802.11 b/g with diversity antennas
• Provides camera power for 12 cameras ; interface
cables to power jacks supplied
• Optional External EDGE/GPRS/CDMA/WI-FI Modules
for cellular/specialized wireless Transmission
• GPS function tracks speed and geographic limits
(optional external GPS receiver)
• Explosion-proof ‘Explosion-proof storage’ interface
(option)
• Power Supply: 10V~36VDC with Surge Protection,
Voltage Regulator, programmable Delay on/off
• Temperature: -40ºC~55ºC (Operating), -40ºC~85ºC
(Non-Operating)
Specifications
Video Format
NTSC/PAL (auto detected by system)
Operating System
Video Input
12 channels (vibration resistant locking Molex connectors – Interface cables to BNC-F
supplied: 3X groups of 4 cameras each)
Video Output
Main monitor: 1 composite BNC rear panel/1 front panel RCA output
Call monitor: 1 composite BNC rear panel
Video Compression
Video Display
Recording Resolutions (set
independently per camera)
Audio Inputs
NTSC: 720 x 480/720 x 240/360 x 240 ;PAL: 704 x 576/704 x 288/352 x 288
12 line in (vibration resistant locking Molex connectors - Interface cables to RCA-F supplied:
3X groups of 4 cameras each)
Audio Outputs
1 front panel RCA line out, 1 rear panel RCA line out
Alarm Inputs
12 alarm inputs (vibration resistant locking Molex connectors - Interface cables supplied)
Alarm Outputs
2 alarm outputs (form “C”; contacts rated at 30V AC/DC @ 1 amp – interface cables
supplied)
Storage
3.5" HDD x 1 (up to 2TB) or 2.5" HDD x 1 (up to 1TB)
Recording Rate
NTSC: D1 120fps, 2CIF 240fps & CIF 480fps (duplex) if set globally
PAL: D1 100fps, 2CIF 200fps & CIF 400fps (duplex) if set globally
Per camera resolutions and record rates can be set individually per camera through the OSD
menus up to the maximum record capacity of 480 (400) CIF FPS
Recording Mode
Continuous recording, event recording, continuous + event recording
(Rate and resolution in each mode set independently per camera)
Record Quality
Adjustable in five levels per camera per Record Mode
Pre Alarm Recording
Playback Rate
Optional; 5 second interval
NTSC: D1 120fps, 2CIF 240fps & CIF 480fps (duplex)
PAL: D1 100fps, 2CIF 200fps & CIF 400fps (duplex)
Camera resolutions and record rates can be set individually per camera through OSD menus
up to the maximum total record capacity of 480 (400) CIF FPS
Playback Search
Video Loss Detection
Time/date, event search
Yes
Event Alarm
Fan failure, hard disk temperature, hard disk failure, hard disk full, hard disk removed,
power loss (after power is restored), network loss, GPS loss, GPS speed, GPS fencing, G
sensor limits
Email Alert
Multiple email notifications in response to alarms and events. (Requires real time network
connectivity though cellular or WiFi service).
G Sensor
Optional External GPS Sensor for speed and geographic limit alarms (rectangular or circular
fencing)
GPS Function
Optional External GPS Sensor for speed and geographic limit alarms (rectangular or circular
fencing)
Configuration Method
Control/Setup
On screen menu with ‘portable monitor friendly’ graphical user interface
IR remote control, USB mouse, network I/F
Real Time Clock
Can be synchronized to GPS/NTP time source; flexible DST settings
Watchdog Function
Networking
Reboots DVR automatically if required
RJ45 socket, 10/100Mbps; 802.11b/g WiFi, diversity antennas
TCP-IP/DHCP/PPPoE/DDNS/SMTP/SSL/POP3/HTTP/NTP
System Warnings
System fail LED : HDD full, HDD/Sys Temp, Fan fail,
HDD fail LED : HDD power off, HDD failure
File Export
USB 2.0 interface
Interfaces
RS-232 x 2, RS-485, USB x 3, GPS port
Explosion-proof Storage
Power Source
4GB device (option)
10V~36VDC (Built in surge protection, voltage regulation, programmable Delay On/Off
relative to ignition or other switched voltage)
With 12ch x 300mA cameras
Camera Power Outputs
Total current 4.8 amps @ 12VDC (vibration resistant locking Molex connectors – interface
cable provided to coaxial power plugs: 3 X groups of 4 cameras); 1.2A for camera 1~4 and
3.6A for camera 5~12
Dimensions (W x D x H)
DVR alone: 210 x 260 x 70mm/8.27" x 10.22" x 2.76"‫‏‬
DVR in mount with antennas: 312 x 298 x 164mm/12.29" x 11.75" x 6.47"
DVR without mount 3.2kg/7.05 lbs.
DVR with mount 3.65kg/8.05 lbs
Operating Temperature
* All product specifications are subject to change without notice
H.264
Full, 4/9/12, Sequence
Weight
34
Embedded Linux with special small monitor friendly GUI
Working Temperature: -40ºC~55ºC/-40F~131ºF
Storage Temperature: -40º~85ºC/-40F~185ºF
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Mobile Digital Video Recorders EMV Series
Major Operating Controls
Rear View
Mobile Digital Video Recorders
Front View
13
1 USB Port
1 Main Monitor Out
6 GPS Data Input
11 Serial Port (Future Used)
2 Audio Out
2 Audio Out
7 USB Port
12 Control Port (Future Used)
3 Main Monitor
3 Alarm Input (12)
8 Power Input / Ignition Control
13 Call Monitor Out
4 Network Connector
4 Alarm Output
14 802.11 b / g WiFi
5 System Status LEDs
(2 x form ’C’)
5 RS232 / RS485
In / Switched Power Out
9 Video & Audio Inputs (12)
10 Camera Power Outputs (12)
• Front & back panel controls vary depending on models
Dimensions
Rear View
Side View
313.5mm/12.35"
260mm/10.24”
210mm/8.27”
313.5mm/12.35"
260mm/10.24”
210mm/8.27”
˦˸̅˼˴˿ʳ̃̂̅̇
70mm / 2.76”
˖̂́̇̅̂˿ʳ̃̂̅̇
260mm / 10.24”
97.8mm / 3.85”
Front View
* All product specifications are subject to change without notice
35
Mobile Digital Video Recorders EMV Series
EMV800
NEW
Mobile Digital Video Recorders
Compact 8 Channels H.264
Mobile Digital Video Recorder
(Wi-Fi optional)
H.264
Removable
hard disk
G Sensor
Camera power
provided
Supports
multiple
interfaces
Explosion-proof
storage
Working
Temperature
-40°C~55°C
Supply
10V~36VDC
Shock and Vibration
resistant
Features
• 8 Channels of video and audio recording
• Recording Rate : 240fps @ D1 resolution/480fps @
2CIF/960fps @ CIF resolution (with global settings
; record rate, resolution and quality can be set
independently per-camera up to the maximum of
960 CIF-equivalent FPS)
• H.264 compression format for efficient disk and
network utilization
• Front and rear panel video/audio outputs for easy
connection and configuration
• Special Graphical User Interface design for use with
mobile small-sized monitors
• Molex connectors for shock & vibration resistance
; interface cables to BNC, RCA and power jacks
supplied
• Alarm Inputs & Outputs : 8 & 2 (alarm outputs are
form “C”)
• Embedded 3-axis g-sensor function with separate
programmable alarm levels for X/Y and Z axis
• Removable video storage hard disk; easy playback
on PC (using EPR110 purchased separately)
• Supports single 3.5” SATA hard disk standard (up to
2TB), 2.5” SATA hard disk standard (up to 1TB)
• Supports multiple interfaces: 3xUSB, RS-485, RS232, GPS port, wired Ethernet, IR Remote Control
• Built in wireless 802.11 b/g with diversity antennas
• Provides camera power for 8 cameras ; interface
cables to power jacks supplied
• Optional External EDGE/GPRS/CDMA/WI-FI Modules
for cellular/specialized wireless Transmission
• GPS function tracks speed and geographic limits
(optional external GPS receiver)
• Explosion-proof ‘Explosion-proof storage’ interface
(option)
• Power Supply : 10V~36VDC with Surge Protection,
Voltage Regulator, programmable Delay on/off
• Temperature : -40ºC~55ºC (Operating),
-40ºC~85ºC (Non-Operating)‫‏‬
Specifications
Video Format
NTSC/PAL (auto detected by system)
Operating System
Video Input
8 channels (vibration resistant locking Molex connectors – Interface cables to BNC-F
supplied: 2X groups of 4 cameras each)
Video Output
Main monitor: 1 composite BNC rear panel/1 front panel RCA output
Call monitor: 1 composite BNC rear panel
Video Compression
Video Display
* All product specifications are subject to change without notice
H.264
Full, 4/9/12, Sequence
Recording Resolutions (set
independently per camera)
Audio Inputs
NTSC: 720 x 480/720 x 240/360 x 240 ;
PAL: 704 x 576/704 x 288/352 x 288
8 line in (vibration resistant locking Molex connectors - Interface cables to RCA-F supplied:
2X groups of 4 cameras each)
Audio Outputs
1 front panel RCA line out, 1 rear panel RCA line out
Alarm Inputs
8 alarm inputs (vibration resistant locking Molex connectors - Interface cables supplied)
Alarm Outputs
2 alarm outputs (form “C”; contacts rated at 30V AC/DC @ 1 amp – interface cables
supplied)
Storage
3.5" HDD x 1 (up to 2TB) or 2.5" HDD x 1 (up to 1TB)
Recording Rate
NTSC: D1 240fps, 2CIF 480fps & CIF 960fps
PAL: D1 200fps, 2CIF 400fps & CIF 800fps
(Per camera resolutions and record rates can be set individually per camera through the
OSD menus up to the maximum record capacity of 960 NTSC (800 PAL) CIF equivalent FPS)
Recording Mode
Continuous recording, event recording, continuous + event recording
(Rate and resolution in each mode set independently per camera)
Record Quality
Adjustable in five levels per camera per Record Mode
Pre Alarm Recording
Playback Rate
Optional; 5 second interval
NTSC: D1 240fps, 2CIF 480fps & CIF 960fps
PAL: D1 200fps, 2CIF 400fps & CIF 800fps
Playback Search
Video Loss Detection
Time/date, event search
Yes
Event Alarm
Fan failure, hard disk temperature, hard disk failure, hard disk full, hard disk removed,
power loss (after power is restored), network loss, GPS loss, GPS speed, GPS fencing,
G sensor limits
Email Alert
Multiple email notifications in response to alarms and events. (Requires real time network
connectivity though cellular or WiFi service).
G Sensor
Embedded 3-axis G Sensor; data recorded; alarm if separate user limits for X/Y or Z axis
exceeded
GPS Function
Optional External GPS Sensor for speed and geographic limit alarms (rectangular or circular
fencing)
Configuration Method
Control/Setup
On screen menu with ‘portable monitor friendly’ graphical user interface
IR remote control, USB mouse, network I/F
Real Time Clock
Can be synchronized to GPS/NTP time source; flexible DST settings
Watchdog Function
Networking
Reboots DVR automatically if required
RJ45 socket, 10/100Mbps; 802.11b/g WiFi, diversity antennas
TCP-IP/DHCP/PPPoE/DDNS/SMTP/SSL/POP3/HTTP/NTP
System Warnings
System fail LED : HDD full, HDD/Sys Temp, Fan fail,
HDD fail LED : HDD power off, HDD failure
File Export
USB 2.0 interface
Interfaces
RS-232 x 2, RS-485, USB x 3, GPS port
Explosion-proof Storage
Power Source
4GB device (option)
10V~36VDC (Built in surge protection, voltage regulation, programmable Delay On/Off
relative to ignition or other switched voltage)
With 8ch x 300mA cameras
Camera Power Outputs
Total current 4.8 amps @ 12VDC (vibration resistant locking Molex connectors – interface
cable provided to coaxial power plugs: 3 X groups of 4 cameras); 1.2A for camera 1~4 and
3.6A for camera 5~12
Dimensions (W x D x H)
DVR alone: 210 x 260 x 70mm/8.27" x 10.22" x 2.76"‫‏‬
DVR in mount with antennas: 312 x 298 x 164mm/12.29" x 11.75" x 6.47"
Weight
DVR without mount 3.2kg/7.05 lbs.
DVR with mount 3.65kg/8.05 lbs
Operating Temperature
36
Embedded Linux with special small monitor friendly GUI
Working Temperature: -40ºC~55ºC/-40F~131ºF
Storage Temperature: -40º~85ºC/-40F~185ºF
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Mobile Digital Video Recorders EMV Series
Major Operating Controls
Rear View
Mobile Digital Video Recorders
Front View
13
1 USB Port
1 Main Monitor Out
6 GPS Data Input
11 Serial Port (Future Used)
2 Audio Out
2 Audio Out
7 USB Port
12 Control Port (Future Used)
3 Main Monitor
3 Alarm Input (8)
8 Power Input / Ignition Control
13 Call Monitor Out
4 Network Connector
4 Alarm Output
14 802.11 b / g WiFi
5 System Status LEDs
(2 x form ’C’)
5 RS232 / RS485
In / Switched Power Out
9 Video & Audio Inputs (8)
10 Camera Power Outputs (8)
• Front & back panel controls vary depending on models
Dimensions
Rear View
Side View
312mm/12.29"
260mm/10.24”
210mm/8.27”
312mm/12.29"
260mm/10.24”
210mm/8.27”
˦˸̅˼˴˿ʳ̃̂̅̇
70mm / 2.76”
˖̂́̇̅̂˿ʳ̃̂̅̇
260mm / 10.22”
96mm / 3.8”
Front View
* All product specifications are subject to change without notice
37
Mobile Digital Video Recorders EMV Series
EMV400
NEW
Mobile Digital Video Recorders
Compact 4 Channels H.264 Mobile DVR
(Wi-Fi optional)
H.264
compression
Shock and Vibration
resistant
38
Removable
hard disk
Support
10V~36VDC
Camera power
provided
Features
Specifications
• 4 Channels of video and audio recording
• 1-DIN car audio size
• Recording Rate: 60fps@D1
resolution/120fps@2CIF/ 240fps@CIF resolution
(with global settings; record rate, resolution and
quality can be set independently per-camera up to
the maximum of 240 CIF-equivalent FPS)
• H.264 compression format for efficient disk and
network utilization
• Front and rear panel video outputs for easy
connection and configuration
• Special Graphical User Interface design for use
with mobile small-sized monitors
• Molex connectors for shock & vibration resistance;
interface cables to BNC, RCA and power jacks
supplied
• Alarm Inputs & Outputs: 6 & 2 (alarm outputs are
form “C”)
• Embedded 3-axis g-sensor function with separate
programmable alarm levels for X/Y and Z axis
• Supports single 2.5” SATA hard disk standard (up
to 1TB)
• Supports multiple interfaces: 3x USB, RS-485, RS232, GPS port, wired Ethernet, IR Remote Control
• Optional wireless 802.11 b/g with diversity
antennas
• Provides camera power for 4 cameras ; interface
cables to power jacks supplied
• Optional External EDGE/GPRS/CDMA/WIFI Modules for cellular/specialized wireless
Transmission
• GPS function tracks speed and geographic limits
(optional external GPS receiver)
• Power Supply: 10V~36VDC with Surge Protection,
Voltage Regulator, programmable Delay on/off
• Temperature: -40ºC~55ºC (Operating),
-40ºC~85ºC (Non-Operating)
Video Format
* All product specifications are subject to change without notice
NTSC/PAL (auto detected by system)
Operating System
Video Input
Embedded Linux with special small monitor friendly GUI
4 channels (vibration resistant locking Molex connectors – Interface cables to BNC-F
supplied: two groups of 2 cameras each)
Video Output
Main monitor: 1 composite BNC rear panel/1 front panel RCA output
Video Compression
Video Display
H.264
Full, 4/9/12, Sequence
Recording Resolutions (set
independently per camera)
Audio Inputs
NTSC: 720 x 480/720 x 240/360 x 240
PAL: 720 x 576/720 x 288/360 x 288
4 line in (vibration resistant locking Molex connectors - Interface cables to RCA-F supplied:
two groups of 2 cameras each)
Audio Outputs
1 front panel RCA line out
Alarm Inputs
6 alarm inputs (vibration resistant locking Molex connectors - Interface cables supplied)
Alarm Outputs
2 alarm outputs (form “C”; contacts rated at 30V AC/DC @ 1 amp –
interface cables supplied)
Storage
2.5" HDD x 1 (up to 1TB)
Recording Rate
NTSC: D1 60FPS, 2CIF 120 FPS, CIF 240 FPS
PAL: D1 50 FPS, 2CIF 100 FPS, CIF 200 FPS
(Per camera resolutions and record rates can be set individually per camera through the
OSD menus up to the maximum record capacity of 240 NTSC (200 PAL) CIF equivalent FPS)
Recording Mode
Continuous recording, event recording, continuous + event recording
(Rate and resolution in each mode set independently per camera)
Record Quality
Adjustable in five levels per camera per Record Mode
Pre Alarm Recording
Playback Rate
Optional ; 5 second interval
NTSC: D1 60 FPS, 2CIF 120 FPS, CIF 240 FPS
PAL: D1 50 FPS, 2CIF 100 FPS, CIF 200 FPS
Playback Search
Time/date, event search
Video Loss Detection
Yes
Event Alarm
Fan failure, hard disk temperature, hard disk failure, hard disk full, hard disk removed,
power loss (after power is restored), network loss, GPS loss, GPS speed, GPS fencing, G
sensor limits
Email Alert
Multiple email notifications in response to alarms and events. (Requires real time network
connectivity though cellular or WiFi service).
G Sensor
Optional External GPS Sensor for speed and geographic limit alarms (rectangular or circular
fencing)
GPS Function
Optional External GPS Sensor for speed and geographic limit alarms (rectangular or circular
fencing)
Configuration Method
Control/Setup
On screen menu with ‘portable monitor friendly’ graphical user interface
IR remote control, USB mouse, network I/F
Real Time Clock
Can be synchronized to GPS/NTP time source; flexible DST settings
Watchdog Function
Networking
Reboots DVR automatically if required
RJ45 socket, 10/100Mbps; 802.11b/g WiFi, diversity antennas
TCP-IP/DHCP/PPPoE/DDNS/SMTP/SSL/POP3/HTTP/NTP
System Warnings
System fail LED : HDD full, HDD/Sys Temp, Fan fail,
HDD fail LED : HDD power off, HDD failure
File Export
USB 2.0 interface
Interfaces
RS-232 x 2, RS-485, USB x 3, GPS port
Power Source
10V~36VDC (Built in surge protection, voltage regulation, programmable Delay On/Off
relative to ignition or other switched voltage)
Total current 5.5 amps @ 12VDC with 4ch x 450mA cameras
Camera Power Outputs
900mA for camera 1~2 and 900mA for camera 3~4. Vibration resistant locking Molex
connectors – interface cable provided to coaxial power plugs: 2 x groups of 2 cameras
Dimensions (W x D x H)
DVR alone: 178 x 50 x 199mm/7” x 2” x 7.8” (1-DIN size)
DVR in mount with antennas 272 x 145 x 224mm/10.7” x 5.7” x 8.8”
Weight
DVR without mount 1.7kg/3.75lbs.
DVR with mount 2.15kg/4.74lbs
Operating Temperature
Working Temperature: -40ºC~55ºC/-40F~131ºF
Storage Temperature: -40º~85ºC/-40F~185ºF
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Mobile Digital Video Recorders EMV Series
Major Operating Controls
Rear View
Mobile Digital Video Recorders
Front View
13
1
2
3
4
USB Port
Audio Out
Main Monitor
System Status LEDs
Power Input
Video & Audio Input (4)
3 Camera Power Output (4)
4 GPS Data Input
5 Network Connector
1
6 USB Port
11 Alarm Output (2 x Form ‘C’)
2
7 GPS Data Input
12 Event Input
8 RS232
13 RS485 Input
9 Main Monitor Out
10 Alarm Input (6)
14 802.11 b/g WiFi
• Front & back panel controls vary depending on models
Dimensions
Rear View
224mm / 8.803”
272mm / 10.709”
199mm / 7.835”
145mm / 5.697”
50mm / 1.969”
178mm / 7”
Side View
73mm / 2.866”
122mm / 4.793”
Front View
184mm / 7.248”
* All product specifications are subject to change without notice
39
Mobile Digital Video Recorders EMV Series
EMV200
Mobile Digital Video Recorders
2 Channels Extra Compact SD Card Mobile DVR
NEW
H.264
compression
Shock and Vibration
resistant
Camera power
provided
Support
10V~36VDC
Features
Specifications
• 2Channels of video and audio recording
• Recording Rate : 60fps @ D1 resolution (with global
settings; record rate, resolution and quality can be set
independently)
• H.264 compression format for efficient storage and network
utilization
• Special Graphical User Interface design for use with mobile
small-sized monitors
• Molex connectors for shock & vibration resistance; interface
cables to BNC, RCA and power jacks supplied
• Alarm Inputs & Outputs : 2 & 1
• Plug-and-play SD card recording, bumpy road proof
• Supports multiple interfaces: RS-232, USB 2.0, wired
Ethernet, IR Remote Control
• Provides camera power for 2 cameras; interface cables to
power jacks supplied
• Optional External EDGE/GPRS/CDMA/WI-FI Modules for
cellular/specialized wireless Transmission
• GPS function tracks speed and geographic limits (optional
external GPS receiver)
• Power Supply : 10V~36VDC with Surge Protection, Voltage
Regulator, programmable Delay on/off
• Temperature : -40ºC ~ 55ºC (Operating), -40ºC ~ 85ºC
(Non-Operating)‫‏‬
Video Format
Operating System
Video Input
Video Output
Video Compression
Recording Resolutions
Audio Inputs
Audio Outputs
Alarm Inputs
Alarm Outputs
Storage
Recording Rate
Recording Mode
Record Quality
Pre Alarm Recording
Playback Rate
Playback Search
Video Loss Detection
Event Alarm
Email Alert
GPS Function
Configuration Method
Control/Setup
Real Time Clock
Watchdog Function
Networking
Dimensions
Front View
Rear View
Interface
Power Source
Dimensions
Weight
Operating Temp.
NTSC/PAL (auto detected by system)
Embedded Linux with special small monitor friendly GUI
2 channels (vibration resistant locking Molex connectors –
Interface cables to BNC
Main monitor: 1 composite BNC RCA output
H.264, support 2nd streaming
NTSC: 720x480/720x240/360x240PAL: 720x576/720x288/360x288
2 line in (vibration resistant locking Molex connectors Interface cables to RCA
1 RCA line out
2 alarm inputs (vibration resistant locking Molex connectors - Interface
cables supplied)
1 alarm outputs ( interface cables supplied)
1 SD card storage medium with anti-shock cover
NTSC: D1 60fps, PAL: D1 50fps
Continuous recording, event recording, continuous + event recording
(Rate and resolution in each mode set independently per camera)
Adjustable in five levels per camera per Record Mode
Optional; 5 second interval
NTSC: D1 60fps, PAL: D1 50fps
Time/date, event search
Yes
SD card error, SD card temperature, SD card Full, SD card Off, Power
Loss, Network Loss, GPS loss, GPS speed, GPS fencing
Multiple email notifications in response to alarms and events. (Requires
real time network connectivity though cellular or WiFi service).
Optional External GPS Sensor for speed and geographic limit alarms
(rectangular or circular fencing)
On screen menu with ‘portable monitor friendly’ graphical user interface
IR remote control, USB mouse, network I/F
Can be synchronized to GPS/NTP time source; flexible DST settings
Reboots DVR automatically if required
RJ45 socket, 10/100Mbps
TCP-IP/DHCP/PPPoE/DDNS/SMTP/SSL/POP3/HTTP/NTP
RS-232, USB 2.0
13.8VDC nominal; 10V~36VDC range (Built in surge protection, voltage
regulation, programmable Delay On/Off relative to ignition or other
switched voltage)
117 x 63 x 38.4mm / 4.6”x 2.5”x 1.5”
300g / 0.66lbs.
Working Temperature: -10º~55º
Storage Temperature: -40º~85º
(Unit: mm/inch)
40
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras
* All product specifications are subject to change without notice
41
PTZ Cameras 36x Optical Zoom, 530TVL Auto Tracking True Day/Night & WDR
EPTZ3650/3650i
PTZ Cameras
530TVL Outdoor/Indoor Speed Dome
with Auto Tracking, WDR & True Day/Night
(36x Optical Zoom)
530
36x
BLC
AWB
Optical Zoom
Yes
Day/Night
Vandal proof
Outdoor
OSD
WDR
AI
Auto Iris
Slow
Shutter
Protocol
auto
detection
AGC
Yes
BLC
Yes
Auto
Tracking
Features
Outdoor
Indoor
Specifications
• Support smart auto tracking functions such as
exclusive masking, pan/tilt limits, various lost
modes, tracking on patrol and various resume
functions.
• One-click easy installation
• True Day/Night function with removable IR cut filter
• Wide Dynamic Range (WDR)
• Digital Slow Shutter (DSS)
• Privacy Zone Masking
• From super low [0.01°/sec] to high fast [360°/sec]
pan/tilt speed
• IP66 rated housing for any-weather outdoor use
• Maximum 192 preset positions available
• Programmable autopan/16 tours/4 patterns
• 4 priority alarm inputs & 2 alarm outputs
• Smart alarm reaction & resume after alarm
• Enhanced auto-resume & power-up function
• Digital Flip function
• Power consumption: 30W max
Product Model
EPTZ3650 (outdoor)
Pickup Device
EPTZ3650i (indoor)
1/4” Sony Ex-View HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Min. Illumination
530TVL
Normal: 1.4 lux/ 1/60 (1/50)sec ; Night Mode: 0.01 lux/ 1/4 (1/3) sec (ICR ON)
S/N Ratio (AGC OFF)
Electronic Shutter
Digital Slow Shutter
Shutter Selection
Lens Type
50dB
1 ~ 1/10,000 (s)
60x (50x for PAL)
AUTO ; A.FLK ; Manual 1~1/10,000 selectable
36x optical zoom, f=3.4 mm (wide) to 122.4mm (tele), F1.6 to F4.5
Zoom Ratio
432x max (36x Optical and 12x Digital Zoom)
True Day & Night
Yes, (Auto/Day/Night)
Auto Gain Control
Yes, (Auto;Manual)
Backlight Comp.
Wide Dynamic Range
Yes, (OFF ; ON)
Yes, (OFF ; ON)
White Balance
Auto ; Indoor ; Outdoor
Auto Tracking
Exclusive Mask, Pan/Tilt Limits, Lost Mode, Manual Target Tracking
Motion Detection
Yes, (4 zone)
Privacy Zone Masking
Yes, (8 zone)
Video Output
1Vp-p/75ohm
Sync. Mode
Internal
Focus Control
One Push/Auto/Manual
Horizontal Rotation Speed
0.01°/s-360°/s (1-255 grade shift gears)
Manual Pan/Tilt Speed
Pan: 0.01°~180°/s ; Tilt: 0.01°~180°/s
Position Accuracy
Horizontal Rotation Range
±0.1°
360° unlimited rotation
Tilt Rotation Range
180° pendulum motion
Auto Speed Control
Control speed auto-adjusted according to zoom length changing
Auto Pan, 2 Points Scanning
Dimensions
Auto Pan Speed
Can set freely
1-255 grade available,0.01º/s – 360º/s
Dwell Time (2 points)
1-99 second available
Preset Positions
192 positions
Running to Position Speed
Dwell Time at Preset Position
Indoor Model
Outdoor Model
159 mm / 6.3”
1-255 grade available,0.01º/s - 360º/s
1-99 second available
Tour
16 groups
Tour Point per Group
Pattern
16 preset positions
4 patterns with 90 sec long each
Alarm
4 in 2 out with tour/position auto triggering
Fan
Auto starts
230 mm / 9.1”
280 mm / 11”
Built-in Menu for Functions
Yes
Communication
RS-485
Communication Speed
1200/2400/4800/9600bps
Built-in Protocols
AUTO ; EVF ; Pelco-P ; Pelco-D/Plus-D ; A-Type ; Panasonic
Address Editable
Yes (through DIP switch)
Speed Dome ID Address
0-255
Power Source
24VAC
Power Consumption
Operating Temperature
180 mm / 7.1”
Environmental Rating
Dimensions (W x H)
Weight
30W Max
-40°C~50°C ≤ 95%/-40°F~122°F ≤ 95%(EPTZ3650)
-10°C~50°C ≤ 85%/14°F~122°F ≤ 85%(EPTZ3650i)
IP66 for outdoor EPTZ3650
180mm x 280mm ; 7.1" x 11" (EPTZ3650)
159mm x 230mm ; 6.3" x 9.1" (EPTZ3650i)
Approx. 3.0kg/6.62lbs
Certifications
42
* All product specifications are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras 30x Optical Zoom, 520TVL True Day/Night & WDR
EPTZ3150/3150i
BLC
AWB
Yes
Yes
Outdoor
OSD
Day/Night
PTZ Cameras
520TVL, Outdoor/Indoor Speed Dome
with WDR & True Day/Night
(30x Optical Zoom)
WDR
AI
Auto Iris
Vandal proof
Slow
Shutter
Protocol
auto
detection
AGC
Yes
30x
Optical Zoom
DNR
Yes
Features
Indoor
Specifications
• Support smart auto tracking functions such as
exclusive masking, pan/tilt limits, various lost
modes, tracking on patrol and various resume
functions
• One-click easy installation
• True Day/Night function with removable IR cut filter
• Wide Dynamic Range (WDR)
• Digital Slow Shutter (DSS)
• Built-in Dynamic Noise Reduction (DNR)
• Privacy Zone Masking
• From super low [0.01°/sec] to high fast [360°/sec]
pan/tilt speed
• IP66 rated housing for any-weather outdoor use
• Maximum 192 preset positions available
• Programmable autopan/16 tours/4 patterns
• 4 priority alarm inputs & 2 alarm outputs
• Smart alarm reaction & resume after alarm
• Enhanced auto-resume & power-up function
• Digital Flip function
• Power consumption:30W max
Dimensions
Indoor Model
Outdoor Model
159 mm / 6.3”
230 mm / 9.1”
280 mm / 11”
Outdoor
Product Model
Pickup Device
Video Format
Scanning System
Horizontal Resolution
Min. Illumination
S/N Ratio (AGC OFF)
Electronic Shutter
Digital Slow Shutter
Shutter Selection
Lens Type
Zoom Ratio
True Day & Night
Auto Gain Control
Backlight Comp.
Wide Dynamic Range
Dynamic Noise Reduction
White Balance
Auto Tracking
Motion Detection
Privacy Zone Masking
Video Output
Sync. Mode
Focus Control
Horizontal Rotation Speed
Manual Pan/Tilt Speed
Position Accuracy
Horizontal Rotation Range
Tilt Rotation Range
Auto Speed Control
Auto Pan, 2 Points Scanning
Auto Pan Speed
Dwell Time (2 points)
Preset Positions
Running to Position Speed
Dwell Time at Preset
Position
Tour
Tour Point per Group
Pattern
Alarm
Fan
Built-in Menu for Functions
Communication
Communication Speed
Built-in Protocols
Address Editable
Speed Dome ID Address
Power Source
Power Consumption
Operating Temperature
Environmental Rating
Dimensions (W x H)
Weight
Certifications
EPTZ3150 (outdoor)
EPTZ3150i (indoor)
1/4" Sony CCD
NTSC/PAL
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
768 x 494 (NTSC) ; 752 x 582 (PAL)
520TVL
Normal: 0.4 Lux/F1.6 ; Night Mode: 0.08 Lux/F1.6 (ICR ON)
50dB
128x~ 1/60(1/50) ~ 1/120,000(s)(NTSC)
128x
AUTO ; A.FLK ; Manual 128x~1/60 (1/50)~1/120,000 selectable
30x optical zoom, f=3.3 mm (wide) to 99mm (tele), F1.6 to F3.2
240x max (30x Optical and 8x Digital zoom)
Yes, (Auto/Day/Night)
Yes, (OFF; Low ; Mid ; Hi)
Yes, (OFF; LOW ; MIDDLE ; HIGH)
Yes, (OFF ; Auto ; ON)
Yes,(OFF; Low ; Mid ; Hi)
Indoor / Outdoor/MAN5100K/MAN3200K/MAN2000K/ONE PUSH
Exclusive Mask, Pan/Tilt Limits, Lost Mode, Manual Target Tracking
Yes, (OFF ; ON )
Yes, (8 zone)
1Vp-p/75ohm
Internal
One Push/Auto/Manual
0.01°/s-360°/s (1-255 grade shift gears)
Pan: 0.01°~180°/s ; Tilt: 0.01°~180°/s
±0.1°
360° unlimited rotation
180° pendulum motion
Control speed auto-adjusted according to zoom length changing
Can set freely
1-255 grade available,0.01º/s – 360º/s
1-99 second available
192 positions
1-255 grade available,0.01º/s - 360º/s
1-99 second available
16 groups
16 preset positions
4 patterns with 90 sec long each
4 in 2 out with tour/position auto triggering
Auto starts
Yes
RS-485
1200/2400/4800/9600bps
AUTO ; EVF ; Pelco-P ; Pelco-D/Plus-D ; A-Type ; Panasonic
Yes (through DIP switch)
0-255
24VAC
30W Max
-40°C~50°C ≤ 95%/-40°F~122°F ≤ 95%(EPTZ3150)
-10°C~50°C ≤ 85%/14°F~122°F ≤ 85%(EPTZ3150i)
IP66 for outdoor EPTZ3150
180mm x 280mm ; 7.1" x 11" (EPTZ3150)
159mm x 230mm ; 6.3" x 9.1" (EPTZ3150i)
Approx. 3.0kg/6.62lbs
CE, FCC
180 mm / 7.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
43
PTZ Cameras Outdoor 37x Optical Zoom, 540TVL, WDR & Day/Night
EPTZ870
NEW
540TVL, Outdoor Speed Dome with WDR & Day/Night
ht
(37x Optical Zoom)
PTZ Cameras
540
AWB
OSD Setting
DSS
WDR 3DNR
Outdoor
PZM
AI
BLC
Auto Iris
ON/OFF
37x
Optical Zoom
Features
Specifications
• EPTZ870 outdoor housing with wall mount bracket/power/
heater/fan
• 1/4 SONY Ex-View CCD with a Digital Slow Shutter (DSS) and
Day/Night mode
• 540 TV lines; PAL/NTSC image formats support
• Auto and fast focus increases the searching speed and
precision
• Auto iris adjusts the monitoring image to the best brightness
• White balance function makes the shades of colour more
natural in different light conditions
• Colour / B&W images auto switching to enhance the
sensitivity in a low light condition or at night
• Wide Dynamic Range (WDR) allows dark portions of a bright
image to be shown clear, enhancing details in scenes and
removing noise(option)
• 3D Noise Reduction (3DNR) produces clear picture quality
even under low light condition and efficiently reduces HDD
consumption
• Support Privacy Zone Masking (PZM) up to 8 zones
• Excellent position accuracy to ±0.1 degree
• From super low [0.01°/sec] to high fast [360°/sec] pan/tilt
speed
• Support digital flip
• 192 preset positions are available
• 16 cruise tours and each tour contains up to 16 positions
• 1 pattern with up to 60 second recording space
• Up to 256 speed domes can be supported on a RS-485 bus
when all speed domes are controlled by EverFocus EKB500
keyboard controller
• Built-in 4 alarm inputs and 1 alarm output
• Auto heater and fan to fit all kinds of temperature
• Weatherproof IP66 rated
Dimensions
Image Sensor
Zoom Ratio
1/4" SONY Ex-View CCD
37x Optical Zoom
Lens
37x Optical Zoom (F1.56 Wide End, F4.09 Tele End, f=3.5~129mm)
Horizontal Resolution
Min. Illumination
Electronic Shutter Speed
540 TVL
Colour: 0.6 (0.003) Lux (Sens-up ON)
B/W: 0.1 (0.0001) Lux (Sens-up ON)
Auto/Off/A.FLK/Manual 1/60s(50s) ~ 1/90,000s
Digital Slow Shutter (DSS)
Up to 128x
Day/Night Mode
S/N Ratio
Auto/Day/Night
more than 50dB (AGC Off)
Iris
Auto/Manual
Focus
Auto/Manual/One Push
White Balance
Auto/Indoor/Outdoor/Manual
Backlight Comp
High/Middle/Low/Off
Auto Gain Control (AGC)
High/Middle/Low/Off
Wide Dynamic Range (WDR)
High/Middle/Low/Off
Privacy Zone Masking (PZM)
Noise Reduction
Preset Point
On (8 Zones)/Off
High/Middle/Low/Off
Up to 192 Preset Points
Built-In Protocols
Horizontal Rotation Range
Tilt Rotation Range
Running to Position Speed
Dwell Time at Preset Position
EVF-1, PELCO-D, PELCO-P, AUTO, HKVI, BSH
360° unlimited rotation
180° pendulum rotation, support digital flip
1-239 grade available, 0.01°/s~360°/s
1-239s available
Position Accuracy
±0.1°
Manual Pan/Tilt Speed
0.01°/s~180°/s
Proportional Pan Speed
Control speed auto-adjusted according to zoom length changing
Auto Pan (2 points scanning)
Auto Pan Speed
Dwell Tome (2 points)
Can set freely
1-239 grade available
1-239s available
Tour
16 groups
Tour Points per Group
Pattern
16 preset positions
1 pattern with up to 60 secound
Alarm
4 in 1 out with tour/position auto triggering
Address Editable
Yes (through DIP switch)
ID Address
0-255
267.35mm / 10.5”
Communication
Communication Speed
Fan / Heater
Standard RS-485
1200/2400/4800/9600bps
Fan/heater auto starts
Operating Temperature
-40°C ~ 60°C / -40°F ~ 140°F
Operating Moisture
±95%
Power Supply
24VAC
Power Consumption
Dimensions
18W max without heater; 70W max with heater
Approx. 218.5 (W) x 267.35 (H) mm / 8.6" (W) x 10.5" (H)
Weight
Approx. 4.2 kg / 9.25lb
Certifications
218.5mm / 8.6”
44
* All product specifications are subject to change without notice
CE, FCC
Weather Resistant
IP66
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras Indoor 37x Optical Zoom, 540TVL, WDR & Day/Night
EPTZ470
NEW
540TVL, Indoor Speed Dome with WDR & Day/Night
ght
(37x Optical Zoom)
DSS
AWB
AI
BLC
OSD Setting
Auto Iris
ON/OFF
WDR 3DNR
PZM
PTZ Cameras
540
37x
Optical Zoom
Features
Specifications
• EPTZ470 indoor recessed mount
• 1/4 SONY Ex-View CCD with a Digital Slow Shutter (DSS)
and Day/Night mode
• 540 TV lines; PAL/NTSC image formats support
• Auto and fast focus increases the searching speed and
precision
• Auto iris adjusts the monitoring image to the best
brightness
• White balance function makes the shades of colour more
natural in different light conditions
• Colour / B&W images auto switching to enhance the
sensitivity in a low light condition or at night
• Wide Dynamic Range (WDR) allows dark portions of a
bright image to be shown clear, enhancing details in scenes
and removing noise(option)
• 3D Noise Reduction (3DNR) produces clear picture quality
even under low light condition and efficiently reduces HDD
consumption
• Support Privacy Zone Masking (PZM) up to 8 zones
• Excellent position accuracy to ±0.1 degree
• From super low [0.01°/sec] to high fast [360°/sec] pan/tilt
speed
• Support digital flip
• 192 preset positions are available
• 16 cruise tours and each tour contains up to 16 positions
• 1 pattern with up to 60 second recording space
• Up to 256 speed domes can be supported on a RS-485 bus
when all speed domes are controlled by EverFocus EKB500
keyboard controller
• Built-in 4 alarm inputs and 1 alarm output
Image Sensor
Dimensions
Auto Pan (2 points scanning)
Zoom Ratio
Lens
Horizontal Resolution
Min. Illumination
Electronic Shutter Speed
Digital Slow Shutter (DSS)
Day/Night Mode
S/N Ratio
Iris
Focus
37x Optical Zoom
37x Optical Zoom (F1.56 Wide End, F4.09 Tele End, f=3.5~129mm)
540 TVL
Colour: 0.6 (0.003) Lux (Sens-up ON)
B/W: 0.1 (0.0001) Lux (Sens-up ON)
Auto/Off/A.FLK/Manual 1/60s(50s) ~ 1/90,000s
Up to 128x
Auto/Day/Night
more than 50dB (AGC Off)
Auto/Manual
Auto/Manual/One Push
White Balance
Auto/Indoor/Outdoor/Manual
Backlight Comp
High/Middle/Low/Off
Auto Gain Control (AGC)
High/Middle/Low/Off
Wide Dynamic Range (WDR)
High/Middle/Low/Off
Privacy Zone Masking (PZM)
Noise Reduction
Preset Point
Built-In Protocols
Horizontal Rotation Range
Tilt Rotation Range
Running to Position Speed
Dwell Time at Preset Position
Position Accuracy
On (8 Zones)/Off
High/Middle/Low/Off
Up to 192 Preset Points
EVF-1, PELCO-D, PELCO-P, AUTO, HKVI, BSH
360° unlimited rotation
180° pendulum rotation, support digital flip
1-239 grade available, 0.01°/s~360°/s
1-239s available
±0.1°
Manual Pan/Tilt Speed
0.01°/s~180°/s
Proportional Pan Speed
Control speed auto-adjusted according to zoom length changing
Auto Pan Speed
Dwell Tome (2 points)
Tour
Tour Points per Group
Pattern
Alarm
Address Editable
ID Address
Communication
Can set freely
1-239 grade available
1-239s available
16 groups
16 preset positions
1 pattern with up to 60 secound
4 in 1 out with tour/position auto triggering
Yes (through DIP switch)
0-255
Standard RS-485
Communication Speed
1200/2400/4800/9600bps
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Operating Moisture
±95%
Power Supply
24VAC
Power Consumption
Dimensions
Weight
Certifications
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
1/4" SONY Ex-View CCD
18W max without heater; 70W max with heater
Approx. 208.5 (W) x 221.6 (H) / 8.2" (W) x 8.7" (H))
Approx. 3.2 kg / 7.05 lb
CE, FCC
* All product specifications are subject to change without notice
45
PTZ Cameras Outdoor 22x Optical Zoom, 540TVL, Day/Night
EPTZ830
NEW
540TVL, Outdoor Speed Dome with Day/Night
(22x Optical Zoom)
PTZ Cameras
540
AWB
OSD Setting
DSS
3DNR
Outdoor
PZM
AI
BLC
Auto Iris
ON/OFF
22x
Optical Zoom
Features
Specifications
• EPTZ830 outdoor housing with wall mount bracket/power/
heater/fan
• 1/4 SONY Super HAD CCD II with a Digital Slow Shutter (DSS)
and Day/Night mode
• 540 TV lines; PAL/NTSC image formats support
• Auto and fast focus increases the searching speed and
precision
• Auto iris adjusts the monitoring image to the best brightness
• White balance function makes the shades of colour more
natural in different light conditions
• Colour / B&W images auto switching to enhance the
sensitivity in a low light condition or at night
• 3D Noise Reduction (3DNR) produces clear picture quality
even under low light condition and efficiently reduces HDD
consumption
• Support Privacy Zone Masking (PZM) up to 8 zones
• Excellent position accuracy to ±0.1 degree
• From super low [0.01°/sec] to high fast [360°/sec] pan/tilt
speed
• Support digital flip
• 192 preset positions are available
• 16 cruise tours and each tour contains up to 16 positions
• 1 pattern with up to 60 second recording space
• Up to 256 speed domes can be supported on a RS-485 bus
when all speed domes are controlled by EverFocus EKB500
keyboard controller
• Built-in 4 alarm inputs and 1 alarm output
• Auto heater and fan to fit all kinds of temperature
• Weatherproof IP66 rated
Image Sensor
Zoom Ratio
1/4" SONY Super HAD CCD II
22x Optical Zoom
Lens
22x Optical Zoom (F1.5 Wide End, F3.0 Tele End, f=3.3~73mm)
Horizontal Resolution
Min. Illumination
Electronic Shutter Speed
540 TVL
Colour: 0.001(0.3) Lux (Sens-up OFF)
B/W: 0.00005(0.05) Lux (Sens-up OFF)
Auto/Off/A.FLK/Manual 1/60s(50s) ~ 1/90000s
Digital Slow Shutter (DSS)
Up to 128x
Day/Night Mode
S/N Ratio
Auto/Day/Night
more than 50dB (AGC Off)
Iris
Auto/Manual
Focus
Auto/Manual/One Push
White Balance
Auto/Indoor/Outdoor/Manual
Backlight Comp
High/Middle/Low/Off
Auto Gain Control (AGC)
High/Middle/Low/Off
Privacy Zone Masking (PZM)
Noise Reduction
Preset Point
On (8 Zones)/Off
High/Middle/Low/Off
Up to 192 Preset Points
Built-In Protocols
Horizontal Rotation Range
Tilt Rotation Range
Running to Position Speed
Dwell Time at Preset Position
Everfocus, Pelco-D, Pelco-P, Samsung
360° unlimited rotation
180° pendulum rotation, support digital flip
1-239 grade available, 0.01°/s~360°/s
1-239s available
Position Accuracy
±0.1°
Manual Pan/Tilt Speed
0.01°/s~180°/s
Proportional Pan Speed
Control speed auto-adjusted according to zoom length changing
Auto Pan (2 points scanning)
Auto Pan Speed
Dimensions
Dwell Tome (2 points)
Can set freely
1-239 grade available
1-239s available
Tour
16 groups
Tour Points per Group
Pattern
16 preset positions
1 pattern with up to 60 secound
Alarm
4 in 1 out with tour/position auto triggering
Address Editable
Yes (through DIP switch)
ID Address
0-255
Communication
267.35mm / 10.5”
Communication Speed
Fan / Heater
Standard RS-485
1200/2400/4800/9600bps
Fan/heater auto starts
Operating Temperature
-40°C ~ 60°C / -40°F ~ 140°F
Operating Moisture
±95%
Power Supply
24VAC
Power Consumption
Dimensions
18W max without heater; 70W max with heater
Approx. 218.5 (W) x 267.35 (H) mm / 8.6" (W) x 10.5" (H)
Weight
Approx. 4.2 kg / 9.25lb
Certifications
CE, FCC
Weather Resistant
IP66
218.5mm / 8.6”
46
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras Indoor 22x Optical Zoom, 540TVL, Day/Night
EPTZ430
NEW
540TVL, Indoor Speed Dome with Day/Night
(22x Optical Zoom)
DSS
3DNR
AWB
AI
BLC
OSD Setting
Auto Iris
ON/OFF
PZM
PTZ Cameras
540
22x
Optical Zoom
Features
Specifications
• EPTZ430 indoor recessed mount
• 1/4 SONY Super HAD CCD II with a Digital Slow Shutter
(DSS) and Day/Night mode
• 540 TV lines; PAL/NTSC image formats support
• Auto and fast focus increases the searching speed and
precision
• Auto iris adjusts the monitoring image to the best
brightness
• White balance function makes the shades of colour more
natural in different light conditions
• Colour / B&W images auto switching to enhance the
sensitivity in a low light condition or at night
• 3D Noise Reduction (3DNR) produces clear picture quality
even under low light condition and efficiently reduces HDD
consumption
• Support Privacy Zone Masking (PZM) up to 8 zones
• Excellent position accuracy to ±0.1 degree
• From super low [0.01°/sec] to high fast [360°/sec] pan/tilt
speed
• Support digital flip
• 192 preset positions are available
• 16 cruise tours and each tour contains up to 16 positions
• 1 pattern with up to 60 second recording space
• Up to 256 speed domes can be supported on a RS-485 bus
when all speed domes are controlled by EverFocus EKB500
keyboard controller
• Built-in 4 alarm inputs and 1 alarm output
Image Sensor
Zoom Ratio
Lens
Horizontal Resolution
Min. Illumination
Electronic Shutter Speed
Digital Slow Shutter (DSS)
Day/Night Mode
S/N Ratio
Iris
Focus
540 TVL
Colour: 0.001(0.3) Lux (Sens-up OFF)
B/W: 0.00005(0.05) Lux (Sens-up OFF)
Auto/Off/A.FLK/Manual 1/60s(50s) ~ 1/90000s
Up to 128x
Auto/Day/Night
more than 50dB (AGC Off)
Auto/Manual
Auto/Manual/One Push
Auto/Indoor/Outdoor/Manual
Backlight Comp
High/Middle/Low/Off
Auto Gain Control (AGC)
High/Middle/Low/Off
Privacy Zone Masking (PZM)
Noise Reduction
Preset Point
Built-In Protocols
Horizontal Rotation Range
Tilt Rotation Range
Running to Position Speed
Dwell Time at Preset Position
Position Accuracy
On (8 Zones)/Off
High/Middle/Low/Off
Up to 192 Preset Points
Everfocus, Pelco-D, Pelco-P, Samsung
360° unlimited rotation
180° pendulum rotation, support digital flip
1-239 grade available, 0.01°/s~360°/s
1-239s available
±0.1°
Manual Pan/Tilt Speed
0.01°/s~180°/s
Proportional Pan Speed
Control speed auto-adjusted according to zoom length changing
Auto Pan Speed
Dwell Tome (2 points)
Tour
Tour Points per Group
Pattern
Alarm
Address Editable
ID Address
Communication
Can set freely
1-239 grade available
1-239s available
16 groups
16 preset positions
1 pattern with up to 60 secound
4 in 1 out with tour/position auto triggering
Yes (through DIP switch)
0-255
Standard RS-485
Communication Speed
1200/2400/4800/9600bps
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Operating Moisture
±95%
Power Supply
24VAC
Power Consumption
Dimensions
Weight
Certifications
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
22x Optical Zoom
22x Optical Zoom (F1.5 Wide End, F3.0 Tele End, f=3.3~73mm)
White Balance
Auto Pan (2 points scanning)
Dimensions
1/4" SONY Super HAD CCD II
18W max without heater; 70W max with heater
Approx. 208.5 (W) x 221.6 (H) / 8.2" (W) x 8.7" (H))
Approx. 3.2 kg / 7.05 lb
CE, FCC
* All product specifications are subject to change without notice
47
PTZ Cameras Outdoor 30x Optical Zoom, 520TVL, Day/Night & WDR
EPTZ3000
520TVL, Outdoor Speed Dome with WDR & Day/Night
(30x Optical Zoom)
PTZ Cameras
30x
Optical Zoom
Features
Specifications
• 520TVL (Colour)/570TVL (Black and White)
• Day/Night function
• Wide Dynamic Range for surveillance with extreme
lighting conditions
• Improve image quality in scenes consisting of bright
and dark area
• White balance function creates natural shades of
colour
• Auto switch colour to black & white to enhance light
sensitivity at night or in low light conditions
• Auto flip 180˚ rotation for continuous viewing
• Auto iris adjusts the monitoring image to the best
brightness
• Integrated privacy zone masking feature
• Built-in heater and fan to tolerate low temperature
• Weatherproof IP66 rated to endure all weather
conditions
Pickup Device
1/4" Vertical double density interline CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
520TVL: Colour ; 570TVL: B/W
0.3 Lux/F1.6 Colour ; 0.05 Lux/F1.6 B/W
S/N Ratio (AGC OFF)
Electronic Shutter
Digital Slow Shutter
Shutter Selection
Lens Type
Over 52dB
128x~ 1/60 (1/50) ~ 1/120,000 (s)(NTSC)
OFF: 4x, 8x, 12x, 16x, 32x,64x,128x selectable
Auto ; A.FLK ; Manual (x8 ~ 1/120,000) selectable
30x optical, f=3.3 mm (wide) tо 99mm (tele), F1.6 to F3.2
Zoom Ratio
240x max (30x Optical and 8x Digital Zoom)
True Day/Night
Auto/Manual ICR
Auto Gain Control
Auto/Manual
White Balance
Auto Indoor/Auto Outdoor/One push/
Video Output
Man 2000k, 3200k, 5100k selectable
BNC, 1Vp-p/75ohm
Sync. Mode
Line Lock/Internal sync
Focus Control
One push/Auto/Manual
Horizontal Rotation Speed
0.01°/s~360°/s (1-239 grade shift gears)
Horizontal Rotation Range
360° unlimited rotation
Tilt Rotation Range
Auto Zoom Speed Control
Auto Pan, 2 Points Scanning
180° pendulum motion
Control speed auto-adjusted according to zoom length changing
Can set freely
Auto Pan Speed
1~239 grades available
Dwell Time (2 points)
1~239 second available
Preset Positions
Dimensions
Running to Position Speed
192 positions
1~239 grade available, 0.01º/s – 360º/s
Tour
16 groups
Tour Point per Group
16 preset positions
Fan & Heater
Auto starts
Position Accuracy
Alarm
±0.1°
4 inputs/1 output with tour/position auto triggering
Built-in Menu for Functions
Yes
Communication
Communication Speed
RS-485
1200/2400/4800/9600 bps
267.35mm / 10.5”
Built-in Protocols
EVF-1, Pelco-P, Pelco-D, Plus-D, A-Type, Plus-D
Address Editable
Yes (through DIP switch)
Speed Dome ID Address
Manual Pan/tilt speed
0-255
Pan: 0.01° ~ 180°/s ; Tilt: 0.01° ~ 180°/s
Power Source
24VAC
Power Consumption
Operating Temperature
18W ; 70W with heater
-40°C~50°C/-40°F ~ 122°F
Weatherproof Ratings
Dimensions (W x H)
218.5mm / 8.6”
48
* All product specifications are subject to change without notice
Weight
IP66
218.5mm x 267.5mm/8.6" x 10.5"
4.2kg/9.25lbs
Certifications
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras Outdoor 18x Optical Zoom, 460TVL
EPTZ1000
460TVL, Outdoor Weatherproof Speed Dome
with 18x Optical Zoom
AWB
OSD Setting
Outdoor
AI
BLC
18x
Auto Iris
ON/OFF
Optical Zoom
Features
Specifications
• 1/4" SONY Interline Transfer Super HAD CCD with
460TVL of horizontal resolution
• Auto Pan/Tilt/Zoom function
• 192 preset positions available
• 16 cruise tours can be set (each tour contains up
to 16 positions)
• Up to 256 speed domes can be supported on the
RS-485 bus
• 4 alarm inputs, 1 alarm output
• Auto iris adjusts the monitoring image to the best
brightness
• Integrated privaccy zone masking feature
• Built-in heater and fan to tolerate low temperatures
• Weatherproof IP66 rated to withstand all weather
conditions
Pickup Device
Video Format
Scanning System
Picture Elements
Horizontal Resolution
Sensitivity
S/N Ratio (AGC OFF)
Electronic Shutter
Digital Slow Shutter
Shutter Selection
Lens Type
Zoom Ratio
Auto ICR
Back Light Comp.
Auto Gain Control
White Balance
Video Output
Sync. Mode
Focus Control
Horizontal Rotation Speed
Horizontal Rotation Range
Tilt Rotation Range
Auto Flip
Auto Speed Speed Control
Auto Pan, 2 Points Scanning
Auto Pan Speed
Dwell Time (2 points)
Preset Positions
Running to Position Speed
Dwell TIme at Preset
Position
Tour
Tour Point per Group
Fan & Heater
Position Accuracy
Alarm
Built-in Menu for Functions
Communication
Communication Speed
Built-in Protocols
Address Editable
Speed Dome Address
Manual Pan/Tilt Speed
Power Source
Power Consumption
Operating Temperature
Weatherproof Ratings
Dimensions (W x H)
Weight
Certifications
Dimensions
267.35mm / 10.5”
218.5mm / 8.6”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Cameras
460
1/4" Sony Type Exview HAD CCD
NTSC/PAL
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
768 x 494 (NTSC) ; 752 x 582 (PAL)
460TVL
0.7 Lux/F1.4
Over 50dB
1~ 1/10,000 (s)
Yes
Yes
18x optical zoom, f=4.1 mm (wide)~73.8mm (tele), F=1.4~3.0
216x max (18x Optical and 12x Digital Zoom)
Yes
On/Off
Auto
Auto/Indoor/Outdoor
BNC, 1Vp-p/75ohm
Line Lock/Internal sync
One push/Auto/Manual
0.01°/s~360°/s (1-239 grade shift gears)
360° unlimited rotation
90° pendulum motion
Rotates 180° when camera tilts to the vertical postion
Control speed auto-adjusted according to zoom length changing
Can set freely
1~239 grades available
1~239 second available
192 positions
1~239 grade available, 0.01º/s~360º/s
1~239 second available
16 groups
16 preset positions
Auto starts
±0.1°
4 inputs/1 output with tour/position auto triggering
Yes
RS-485
1200/2400/4800/9600 bps
EVF-1, Pelco-P, Pelco-D, Plus-D, A-Type, Plus-D
Yes (through DIP switch)
0-255
Pan: 0.01°~180°/s ; Tilt: 0.01°~180°/s
24VAC
18W; 70W with heater
-40°C~50°C/-40°F~122°F
IP66
218.5mm x 267.5mm/8.6" x 10.5"
4.2kg/9.25lbs
CE, FCC
* All product specifications are subject to change without notice
49
PTZ Cameras 18x Optical Zoom, 460TVL
EPTZ500
460TVL, Indoor Recessed Speed Dome
with 18x Optical Zoom
PTZ Cameras
460
AWB
AI
BLC
18x
Digital
Auto Iris
ON/OFF
Optical Zoom
Features
• 1/4" SONY Interline Transfer Super HAD CCD with
460TVL of horizontal resolution
• Auto Pan/Tilt/Zoom function
• 192 preset positions are available
• 16 cruise tours can be set (each tour contains up to
16 positions)
• Up to 256 speed domes can be supported on the
RS-485 bus
• Auto iris adjusts the monitoring image to the best
brightness
• Integrated privacy zone masking feature
• Supports EverFocus, Pelco-D, Pelco-P & Samsung
Protocols
• Suitable for any indoor application
Dimensions
50
* All product specifications are subject to change without notice
Specifications
Pickup Device
Video Formate
Scanning System
Picture Elements
Horizontal Resolution
Sensitivity
S/N Ratio (AGC OFF)
Electronic Shutter
Digital Slow Shutter
Shutter Selection
Lens Type
Zoom Ratio
Auto ICR
Black Light Comp.
Auto Gain Control
White Balance
Video Output
Sync. Mode
Focus Control
Horizontal Rotation Speed
Horizontal Rotation Range
Tilt Rotation Range
Auto Flip
Auto Zoom Speed Control
Auto Pan, 2 Points Scanning
Auto Pan Speed
Dwell Time (2 points)
Preset Positions
Running to Position Speed
Dwell Time at Preset Position
Tour
Tour Point per Group
Position Accuracy
Alarm
Built-In Menu for Functions
Communication
Communication Speed
Built-in Protocols
Address Editable
Speed Dome Address
Manual Pan/Tilt Speed
Power Source
Power Consumption
Operating Temperature
Weatherproof Ratings
Dimensions (W x H)
Weight
Certifications
1/4 SONY Type Exview HAD CCD
NTSC/PAL
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec
768 x 494 (NTSC), 752 x 582 (PAL)
460TVL
0.7 Lux/F=1.4
Over 50dB
1~1/10,000 (s)
Yes
Yes
18x optical zoom, f=4.1mm (wide)~73.8mm (tele), f=1.4~3.0
216x max (18x Optical and 12x Digital Zoom)
Yes
ON/OFF
Auto
Auto/Indoor/Outdoor
BNC 1.0Vp-p, 75ohm
Line Lock/Internal Sync
One push/Auto/Manual
0.1°/s~360°/s (1-239 grade shift gears)
360° unlimited rotation
90° pendulum rotation
Rotates 180° when camera tilts to the vertical position
Control speed auto-adjusted according to zoom length changing
Can set freely
1-239 grade availabe
1-239 second avaliable
192 positions
1-239 grade available, 0.1°/s~360°/s
1-239 second avaliable
16 groups
16 preset positions
±0.1°
4 inputs/1 output with tour/position auto triggering
Yes
RS-485
1200/2400/4800/9600bps
EVF-1, Pelco-D, Pelco-P, A-type, Plus-D
Yes (through DIP switch)
0-255
Pan: 0.1°~180°/s ; Tilt: 0.1°~180°/s
24VAC
18W
0°C~50°C ; 32°F~122°F
Indoor
208.5mm x 221.6mm/8.2" x 8.7"
2.15kg/4.8lbs
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
PTZ Accessories Housings & Brackets
EPTZ3150/3650 Standard Outdoor
Housing (with sun shield)
EPTZ3150/3650 Standard Outdoor
Housing (without sun shield)
Multi-Function Conjunction Box
(For all EPTZ models)
• Compatible with EPTZ-SSM (outdoor sun shield),
EPTZ-WMB (wall mount bracket), EPTZ-CNM (corner
mount adapter), EPTZ-PLM (pole mount adapter),
EPTZ-PBOX (mult-function conjunction box) for
diverse ceiling and wall mounts
• IP66 Rating
• Polycarbonate dome cover (clear/smoked/mirror)
• Aluminum die-cast housing
• Compatible with EPTZ-SSM (outdoor sun shield),
EPTZ-WMB (wall mount bracket), EPTZ-CNM (corner
mount adapter), EPTZ-PLM (pole mount adapter),
EPTZ-PBOX (multi-function conjunction box) for
diverse ceiling and wall mounts
• IP66 Rating
• Polycarbonate dome cover (clear/smoked/mirrored)
• Aluminum die-cast housing
EPTZ3150i/3650i
Standard Indoor Housing
EPTZ-PLMN Pole Mount Adapter
(For all EPTZ models)
PTZ Accessories
EPTZ-PBOX
Outdoor
Steel.
Vandal proof
Power
Coated
• Compatible with EPTZ-CMB (concrete ceiling mount
adapter), EPTZ-CLM (ceiling pendent mount bracket),
EPTZ-ICMB (in-ceiling flush mount bracket) for
diverse ceiling and wall mounts
• Polycarbonate dome cover
• Aluminum die-cast housing
Features
• Compatible with EPTZ-WMB and EPTZ3150/3650
• Stainless steel
• Multi-function conjunction power box for PTZs and cameras
• Vandal resistant and weatherproof IP66 rated
• Optional built-in video encoder for analog to IP network
conversion and network capabilities with web browser
• Compatible with PTZ corner mount (optional EPTZCNM) and
pole mount (optional EPTZPLEM) adaptor
EPTZ-CMB Indoor Concrete Ceiling
Mount Adapter (EPTZ3150i/3650i only)
EverFocus EPTZ-PBOX supports a wide variety of EPTZ indoor
and outdoor mounting accessories. EPTZ-PBOX provides enhanced
durability and eliminates complicated cabling in any location.
=
Compatible with PTZ
pole mount
+
EPTZ series Speed Dome
with EPTZ-PBOX
=
Compatible with PTZ
Corner mount
=
Compatible with PTZ
wall mount
EPTZ -PBM
EPTZ-PLM
EPTZ-CLM Indoor Ceiling Pendent Pole
Mount Bracket
EPTZ-BKAGR Wall Mount Bracket Adapter
(EPTZ3150i/3650i only)
+
EPTZ -PBM
EPTZ-CNM
EPTZ series Speed Dome
10mm x 1pcs, 7mm x 3pcs
2 types: 100V~120VAC/220V ~ 240VAC
Power Output
24VAC
Dimensions (W x D x H)
Weight
Certifications
• Compatible with EPTZ-WMB and EPTZ3150/3650
• Stainless steel
EPTZ -PBOX
Power Source
Power Consumption
• Shall be together with top housing adapter to mount
standard indoor housing on ceiling
• Aluminum die-cast housing
EPTZ-CNMN Corner Mount Adapter
(For all EPTZ models)
+
Specifications
Waterproof Conduit
• Compatible with EPTZ3150/3650
• Waterproof with aluminum die-cast housing
+
+
EPTZ series Speed Dome
with EPTZ-PBOX
• Ceiling mount adapter for indoor EPTZ
• Aluminum die-cast housing
EPTZ-WMB Wall Mount Bracket
(For all EPTZ models)
EPTZ-ICMB Indoor In-Ceiling Mount Bracket
(EPTZ3150i/3650i only)
• Can be installed as flush & recessed ceiling mounting
• Aluminum die-cast housing
• Plastic decorative flange
3.5 amps
250 x 260 x 85 mm/9.8" x 10.2" x 3.3"
4.08 kg/9 lbs ; 4.54 kg/10 lbs (with 1 ch. encoder)
CE, FCC, LVD
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
51
Colour Cameras
52
* All product specifications are subject to change without notice
Colour Cameras Indoor IR Dome Cameras
ED335
520TVL, 1/3" CCD, Indoor, 3-Axis, IR Dome Camera,
Surface or Flush Mount Capabilities
IR
20m
AWB
Yes
BLC
Yes
AGC
Yes
Features
Specifications
• Designed with advanced digital signal processing
circuitry for high image quality
• 520TVL of excellent high resolution technology
• Designed with IR LEDs for day and night
environment
• IR distance up to 20m
• Provides Ceiling (surface) mount and In-ceiling
(flush) mount
• 3-Axis rotation for any view angle
• Built-in vari-focal type, auto Iris lens
• 12VDC/24VAC Dual Voltage support
• High Light IR LED, lifespan up to 20,000 hours
Pickup Device
Video Format
1/3” SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
520TVL
0 Lux (IR LED ON) 0.4 Lux/F=1.2 (AGC ON)
Over 48dB (AGC off)
1/50 (1/60) ~ 1/100,000
Lens Type
Vari-focal lens, Auto Iris f=2.8~10mm/f=9~22mm
Iris Level
Adjustable
Auto Gain Control
On
Back Light Comp.
Yes
White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
IR Distance
IR Wavelength
2 Video Outputs: 1. BNC 1.0 Vp-p ,75ohm
2. Additional testing video output 1.0Vp-p, 75ohm
Internal sync
20m
850nm
IR LED Lifespan
20,000 hours
Power Source
12VDC/24VAC
Power Consumption
Operating Temperature
Dimensions (Φ x H)
Dimensions
Indoor IR Dome Cameras
520
Weight
Certifications
12VDC: 6W max. ; 24VAC: 6.5W max.
0°C~40°C/32°F~104°F (20%~80% Humidity)
Surface Type: 140mm x 128mm/5.5"x 5.1" ;
Ceiling Type: 140mm x 69mm/5.5" x 2.77"
0.66 kg/1.45lbs
CE, FCC
140mm / 5.5”
128mm / 5.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
53
Colour Cameras Indoor IR Dome Cameras
EBD330I
520TVL, 1/3" CCD High Res., 3-Axis,
Indoor, Vari-Frequency, IR Dome Camera
Indoor IR Dome Cameras
IR
520
10~15m
AWB
Yes
BLC
Yes
AGC
Yes
Features
Specifications
• Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3” Super HAD
CCD.
• High Resolution 520TVL
• 3-Axis facilitates easy angle adjustment
• Intelligent Vari-frequency of IR control to save
electricity and make brightness balance
• Easy installation
• Individual lens glass to avoid remaining image from
light reflection
• View angle 50~78 degree-range, IR distance 10~15
meters
• Lifespan of IR LED is 20,000 hours
Pickup Device
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
520TVL
0 Lux (IR LED on) 0.4 Lux/F=1.2 (AGC ON)
S/N Ratio
Over 48dB (AGC OFF)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
BNC 1.0Vp-p , 75ohm
Gamma Correction
Lens Type
0.45
4.3mm, 6.0mm, 8mm
Back Light Comp.
Yes
Auto Gain Control
Yes
White Balance
Yes
Sync. Mode
Internal sync
IR Control
Vari-frequency
IR LED
14pcs
IR LED Lifespan
IR Distance
20,000 hours
4.3mm Lens Type: 10m
6mm Lens Type: 12m
IR Wavelength
8mm Lens Type: 15m
850nm
Power Source
12VDC
Power Consumption
Operating Temperature
Dimensions
Dimensions (Φ x H)
Weight
3W max.
0°C~40°C/32°F~104°F (20%~80% Humidity)
95mm x 90 mm/3.74" x 3.54"
0.17 kg ; 0.37lbs
Certifications
CE, FCC
95mm/3.7”
90mm/3.5”
54
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Indoor IR Dome Cameras
ED330E
520TVL, 1/3" CCD High Res., Indoor, IR Dome Camera
IR
10~12m
AWB
BLC
Yes
Yes
AGC
Yes
Features
Specifications
• Low light sensitivity 0.4 Lux/F=1.2 is achieved by
using the advanced 1/3" SONY Super HAD CCD
• 520TVL of horizontal resolution
• The sensitivity is 0 Lux when IR LED is ON
• Easy installation
• Auto Electronic Shutter function
• Automatic Gain Control function
• Auto White Balance function
• IR distance: 10m/33ft.
• IR LED lifespan is 20,000 hours
Pickup Device
Video Format
1/3” SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Back Light Comp.
520TVL
0.4 Lux/F=1.2 (AGC ON) ; 0 Lux (IR LED on)
Over 48dB (AGC off)
1/50 (1/60)~1/100000s
BNC 1.0Vp-p, 75 ohm
0.45
4.3mm
Yes
Auto Gain Control
Yes
White Balance
Yes
Sync. Mode
IR LED
IR LED Lifespan
IR Distance
IR Wavelength
Power Source
Power Consumption
Operating Temperature
Dimensions (Φ x H)
Weight
Certifications
Dimensions
Indoor IR Dome Cameras
520
Internal Sync.
14pcs
20,000 hours
10m/33feet
850nm
12VDC
4W max.
0°C~50°C/32°F~122°F (20%~80% humidity)
108mm x 80mm/4.3" x 3.2"
0.21 kg/0.46 lbs
CE, FCC
108 mm / 4.3”
80 mm / 3.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
55
Colour Cameras Indoor IR Dome Cameras
EBD255
NEW
420TVL, 1/3" CCD, Indoor, IR Mini Colour
Dome Camera
Indoor IR Dome Cameras
420
IR
10~15m
AWB
Yes
AGC
Yes
Features
Specifications
• IR Dome colour camera with SHARP 1/3" Super
HAD CCD sensor
• Employs Digital Signal Processor (DSP) chip-set for
image control
• Pixel number: NTSC=270K/PAL=320K
• High sensitivity, low smear, high anti-blooming and
high S/N ratio
• Build-in functions: Auto Electronic Shutter (AES),
Auto Gain Control (AGC), Auto White Balance (AWB)
• Built-in anti-aliasing and IR-pass (850nm) optical
filter
• Built-in IR-LED X 12
Image Pick-up Device
Effective Picture Elements
SHARP 1/3" Colour CCD
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
420TVL
Minimum Illumination
0 LUX with built-in IR-LED
S/N Ratio
More than 48 dB
Auto Electronic Shutter
Gain Control
NTSC: 1/60s~1/100,000s ; PAL:1/50s~1/110,000s
Automatically
White Balance
Automatically (2500K~9500K)
Gamma Characteristic
Lens Furnished
Synchronous System
Video Output
0.45
Board Lens 3.6 mm/F2.0 (optional: 4.3 mm, 6mm)
Internal, Negative sync.
1 Vp-p Composite Video/75 Ohms.
Power Supply
Operating Temp.
IR LED
12VDC/250 mA
-10°C~50°C (140°F~122°F)
12 Units of 850nm IR LED
IR Distance
10~15m
Dimensions (Φ x L)
94mm x 82 mm
Dimensions
82mm
94mm
56
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Indoor IR Dome Cameras
EBD230I
420TVL, 1/3" CCD Standard Res., 3-Axis,
Indoor, Vari-Frequency, IR Dome Camera
Yes
BLC
Yes
AGC
Yes
Indoor IR Dome Cameras
AWB
420
380
IR
10~15m
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3” Super HAD
CCD
• High Resolution 420TVL
• 3-Axis facilitates easy angle adjustment
• Intelligent Vari-frequency of IR control to save
electricity and make brightness balance
• Easy installation
• Individual lens glass to avoid remaining image from
light reflection
• View angle 50~78 degree-range, IR distance 10~15
meters
• Lifespan of IR LED is 20,000 hours
Pickup Device
Video Format
1/3” SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
Horizontal Resolution
Sensitivity
420TVL
0 Lux (IR LED on) 0.3 Lux/F=1.2 (AGC ON)
S/N Ratio
Over 48dB (AGC OFF)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
Gamma Correction
Lens Type
Back Light Comp.
BNC 1.0Vp-p, 75ohm
0.45
4.3mm, 6.0mm, 8mm
Yes
Auto Gain Control
Yes
White Balance
Yes
Sync. Mode
Internal sync
IR Control
Vari-frequency
IR LED
IR LED Lifespan
IR Distance
14pcs
20,000 hours
4.3mm Lens Type: 10m
6mm Lens Type: 12m
IR Wavelength
Power Source
Power Consumption
Operating Temperature
Dimensions
Dimensions (Φ x H)
Weight
Certifications
8mm Lens Type: 15m
850nm
12VDC
3W max.
0°C~40°C/32°F~104°F (20%~80% Humidity)
95mm x 90 mm/3.74" x 3.54"
0.17kg ; 0.37 lbs
CE, FCC
95mm/3.7”
90mm/3.5”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
57
Colour Cameras Indoor IR Dome Cameras
ED230E
420TVL, 1/3" CCD Standard Res., IR Dome Camera
Indoor IR Dome Cameras
380 IR
420
BLC
AWB
Yes
Yes
10~12m
Features
AGC
Yes
Specifications
• Low light sensitivity 0.3 Lux/F=1.2 is achieved by
using the advanced 1/3" SONY Super HAD CCD
• 420TVL of horizontal resolution
• The sensitivity is 0 Lux when IR LED is ON
• Easy installation
• Auto Electronic Shutter function
• Automatic Gain Control function
• Auto White Balance function
• IR distance: 10m/33ft.
• IR LED lifespan is 20,000 hours
Pickup Device
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525 TVL, 60 fields/sec ; PAL: 625 TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
Horizontal Resolution
Sensitivity
420TVL
0.3 Lux/F=1.2 (AGC ON) ; 0 Lux (IR LED on)
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Video Output
1/50 (1/60)~1/100000s
BNC 1.0Vp-p, 75 ohm
Gamma Correction
0.45
Lens Type
4.3mm
Back Light Comp.
Yes
Auto Gain Control
Yes
White Balance
Yes
Sync. Mode
Internal Sync.
IR LED
14pcs
IR LED Lifespan
20,000 hours
IR Distance
10m/33 feet
IR Wavelength
850nm
Power Source
12VDC
Power Consumption
Operating Temperature
Dimensions (Φ x H)
Weight
4W max.
0°C~50°C/32°F~122°F (20%~80% humidity)
108mm x 80mm /4.3" x 3.2"
0.21kg/0.46 lbs
Certifications
Dimensions
CE, FCC
108 mm / 4.3”
80 mm / 3.1”
58
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Indoor Dome Cameras
ED350
560TVL, Indoor Mini Colour Dome Camera
BLC
Yes
Indoor Dome Cameras
AWB
560
Yes
AI
AGC
Yes
Auto Iris
Features
Specifications
• Low light sensitivity 0.5 Lux/F=1.2(AGC ON) is
achieved
by using the advanced 1/3" SONY Super HAD CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor(DSP) delivers sharp colour images and
excellent picture quality
• Wide-range automatic electronic shutter: up to
1/100,000
• Manual zoom lens with adjustable viewing range
• Pure Vision Technology
Pickup Device
Video Format
1/3'' SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525 TVL, 60 fields/sec ; PAL: 625 TVL, 50 fields/sec
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
S/N Ratio
560TVL
0.5Lux/F=1.2
Over 48dB (AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Lens Type
Vari-focal lens, Auto Iris
f=2.9~10mm, F=1.2
f=3.8~9.5mm, F=1.2
f=9~22mm, F=1.6
*Lens models and availability vary in different regions
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
On/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
2 Video outputs
BNC 1.0Vp-p, 75ohm
Additional testing video output 1.0Vp-p, 75ohm
Dimensions
Sync. Mode
Internal sync
Power Source
12VDC/24VAC
Power Consumption
24VAC: 5VA max./12VDC: 3.5W max.
Dimensions (Φ x H)
108mm x 80mm/4.3" x 3.2"
Weight
Operating Temperature
Certifications
0.3 kg/0.7lbs
0°C~40°C/32°F~104°F (20%~80% Humidity)
CE, FCC
108 mm / 4.2”
80 mm / 3.1”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
59
Colour Cameras Indoor Dome Cameras
ED300E
520TVL, Indoor Mini Colour Dome Camera
Indoor Dome Cameras
520
BLC
Yes
AWB
AGC
Yes
Yes
Features
Specifications
• Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 520TVL of horizontal resolution
• Designed with advanced digital signal processing
circuitry for high image quality
• Built-in vari-focal lens or fixed lens
• Able to adjust the viewing range with manual zoom
lens (for vari-focal lens only)
• With manual Pan/Tilt mechanism
• Day/Night function (for vari-focal lens only)
• Compact size: 108mm (O.D.) x 80mm (H)/
4.3" (O.D.) x 3.2" (H)
• System available for NTSC or PAL
• BLC, AGC and FL On/Off switchable (for vari-fical
lens only)
Pickup Device
1/3" SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
520TVL
Sensitivity
0.4 Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
1/50 (1/60)~1/100,000
Video Output
BNC1.0Vp-p, 75ohm
Gamma Corvection
Lens Type
0.45
Fixed Lens,
Vari-focal lens,
f=3.6mm/f=4.3mm/
Auto Iris/f=2.6~6mm/
f=6mm/f=8mm
f=3.7~12mm/f=9~22mm
*Lens models and availability vary
*Lens models and availability vary
in different regions
in different regions
Back Light Comp.
Auto Gain Control
Yes
Auto
Yes
Sync. Mode
Internal Sync
Day/Night
Auto
On/Off switch
Flickerless
No
On/Off switch
H-Mirror
No
On/Off switch
Iris Level
Auto
Adjustable
Power Source
Power Consumption
Dimensions
On/Off switch
Auto White Balance
Operating Temperature
Dimensions (Φ x H)
Weight
2 types: 12VDC only & 12VDC/24VAC
12VDC: 2.5W max. 24VAC: 4.5VA max.
0°C~50°C/32°F~122°F (20%~80% Humidity)
108mm x 80mm/4.3" x 3.2"
0.3 kg/0.7lbs
Certifications
CE, FCC
108 mm / 4.2”
80 mm / 3.1”
60
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Indoor Dome Cameras
EFD300E
520TVL, Indoor Mini Colour Flush Dome Camera
BLC
Yes
Indoor Dome Cameras
AWB
520
Yes
AGC
ON/OFF
Features
• Low light sensitivity 0.4 Lux/F=1.2(AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 520TVL of horizontal resolution
• The electronic shutter and AGC allow the camera to
be used in environment with varying light levels
• Built-in Vari-Focal lens
• FL, BNC, AGC and D/N On/Off switchable
• Compact size: 135mm (O.D.) x 112mm (H)
• System available for NTSC or PAL
Specifications
Pickup Device
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
520TVL
0.4Lux/F=1.2
Over 48dB (AGC off)
1/50 (1/60)~1/100,000
2 Video Output BNC 1.0Vp-p, 75ohm
Additional testing video output 1.0Vp-p, 75ohm
Gamma Correction
Lens Type
0.45
Vari-focal lens, Auto Iris f=3.7~12mm, F=1.2mm
Back Light Comp.
Auto
Auto Gain Control
On/Off switch
White Balance
Yes
Sync. Mode
Internal sync
Day & Night Mode
On/Off switch
Flickerless
On/Off switch
H-Mirror
On/Off switch
Vandal Resistant
Power Source
Power Consumption
Operating Temperature(Φ x H)
Dimensions
Weight
Certifications
Yes
12VDC/24VAC
12VDC: 2W max/24VAC: 1.5W max
0°C~50°C/32°F~122°F (20%~80% Humidity)
135mm x 112mm/5.4" x 4.41"
0.7 kg/1.6lbs
CE, FCC
112 mm / 4.4”
Dimensions
1/3'' SONY Super HAD CCD
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
61
Colour Cameras Indoor Dome Cameras
ED200E
420TVL, Indoor Mini Colour Dome Camera
Indoor Dome Cameras
380
420
AWB
Yes
BLC
Yes
AGC
ON/OFF
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 420TVL of horizontal resolution
• Designed with advanced digital signal processing
circuitry for high image quality
• Built-in fixed lens type, mechanical auto iris lens
• Able to adjust the viewing range with manual zoom
lens (for vari-focal lens only)
• Back Light Comp., Auto Gain Control and Auto White
Balance functions
• Compact size: 108mm (O.D.) x 80mm (H)/
4.3" (O.D.) x 3.2" (H)
• System available for NTSC or PAL
Pickup Device
1/3" SONY Super HAD CCD
NTSC/PAL
Video Format
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
420TVL
Horizontal Resolution
0.3 Lux/F=1.2
Sensitivity
Over 48dB (AGC off)
S/N Ratio
Electronic Shutter
Video Output
1/50 (1/60)~1/100,000
BNC 1.0Vp-p, 75ohm
0.45
Gamma Correction
f=2.5mm/f=3.6mm/f=4.3mm/
Lens Type
f=6mm/f=8mm/f=12mm/f=16mm
*Lens models and availability vary in different regions
Back Light Comp.
Yes
Auto Gain Control
Yes
Yes
Auto White Balance
Internal Sync
Sync. Mode
12VDC
Power Source
Power Consumption
Operating Temperature
Dimensions (Φ x H)
12VDC: 1.5W max
0°C~50°C/32°F~122°F (20%~80% Humidity)
108mm x 80mm/4.3" x 3.2"
0.3 kg/0.7lbs
Weight
Certifications
CE, FCC
Dimensions
108 mm / 4.2”
80 mm / 3.1”
62
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Indoor Dome Cameras
ECD250/255/260
420TVL, 1/3” CCD, Colour DSP
Dome Camera
AWB
Yes
Indoor Dome Cameras
380
420
NEW
AGC
ON/OFF
Features
Specifications
• Colour dome camera with SONY 1/3" CCD sensor
(ECD260), with SHARP 1/3" CCD sensor (ECD255),
1/3" CCD sensor (ECD250).
• Employs Digital Signal Processor (DSP) chip-set for
image control.
• Pixel number: NTSC=270K/PAL=320K.
• High sensitivity, low smear, high anti-blooming, and
high S/N ratio.
• Build-in functions: Auto Electronic Shutter (AES),
Auto Gain Control (AGC), Auto White Balance (AWB).
• Furnished with DC power cable and video cable.
• Built-in anti-aliasing optical filter.
Product Model
Image Pick-up Device
Effective Picture Elements
ECD260
ECD255
ECD250
SONY 1/3“ Colour
SHARP 1/3“ Colour
1/3“ CCD Normal
CCD
CCD
Resolution
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
420TVL
Minimum Illumination
0.1 LUX @ F2.0
S/N Ratio
Auto Electronic Shutter
Gamma Characteristic
Lens Furnished
Gain Control
White Balance
Sync. Mode
Video Output
Power Source
Operating Temperature
Dimensions (Φ x H)
Over 48dB
NTSC: 1/60s~1/100,000s ; PAL: 1/50s~1/110,000s
0.45
Board lens 3.6mm/F2.0 (optional: 4.3/6.0/8.0/12/16mm)
Automatically
Automatically (2500K~9500K)
Internal Sync.
1 Vp-p Composite Video/75 Ohms.
12VDC/100mA
-10°C~50°C/14°F~122°F
100mm x 60mm
Dimensions
60mm
22mm
100mm
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
63
Colour Cameras Indoor Dome Cameras
ECD230
420TVL, Micro Mini Indoor Colour Dome Camera
Indoor Dome Cameras
380
420
AWB
Yes
AGC
ON/OFF
BLC
ON/OFF
Features
• Low light senstivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 420TVL of horizontal resolution
• The elecctronic shutter and AGC functions allow the
camera to be used in environment with varying light
levels
• Built-in anti-aliasing and IR-cut optical filter
• Compact size: 87mm (O.D) x 58mm (H)/3.48" (O.D)
x 2.31" (H)
• System available for NTSC or PAL
Specifications
Pickup Device
1/3'' SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
Horizontal Resolution
Sensitivity
420TVL
0.3Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
1/50 (1/60)~1/100,000
Gamma Correction
Video Output
Lens Type
0.45
BNC 1.0Vp-p, 75ohm
f=3.6mm/f=4.3mm/f=6.0mm/f=8.0mm
*Lens models and availability vary in different regions
Back Light Comp.
Yes
Auto Gain Control
Yes
White Balance
Yes
Sync. Mode
Internal sync
Power Source
Power Consumption
Dimensions (O.D. x H)
Weight
12VDC
12VDC: 1.5W max
8mm x 58mm/3.48" x 2.31"
0.1 kg/0.22lbs
Operating Temperature
0°C~50°C/32°F~122°F (20%~80% Humidity)
Certifications
CE, FCC
Dimensions
64
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Outdoor IR Dome Cameras
EBD430
520TVL, 1/3" CCD, 3-Axis, Outdoor IR Dome Camera with
Vari-focal Lens & True Day/Night
AWB
Yes
IR
BLC
ON/OFF
Outdoor IR Dome Cameras
520
Vandal proof
30m
AGC
Yes
Features
Specifications
• Low light sensitivity 0.08 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD II
• 520TVL of excellent high resolution technology
• Up to 30m/98ft. or IR range
• Vari-focal lens to offer you a wide variety of angle
viewing
• True Day/Night function with removable IR cut filter
• External control of lens zoom & focus
• 3-Axis rotation for flexible view angle
• Intelligent vari-frequency of IR control to save
electricity and make brightness balance
• Split glass design to avoid LED light reflection
• Up to 20,000 hours of high IR LED lifespan
• Vandal resistant design to avoid intentional
destruction
• Weatherproof and IP66 rate
PPickup Device
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
520TVL
0.08 Lux / F=1.2 (IR OFF) ; 0 Lux (IR ON)
S/N Ratio
Over 48 dB (AGC Off )
Electronic Shutter
1/50 (1/60)~1/100,000
Video Output
Gamma Correction
Lens Type
BNC 1.0Vp-p, 75ohm
0.45
Vair-focal lens, f=2.9~10mm , f=9~22mm
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Sync. Mode
Yes
Internal sync.
True Day & Night
Yes
IR LED Lifespan
35 pcs
IR LED Lifespan
20,000 hours
IR Distance
30m/98ft.
IR Wavelength
850nm
Weatherproof
IP66
Vandal Resistant
Heater
Power Source
Power Consumption
Dimensions
1/3” SONY Super HAD CCD II
Yes
Yes, built-in
12VDC/24VAC
12VDC:9W max. (Heater On & IR LED On)
24VAC:9.5W max. (Heater On & IR LED On)
Operating Temperature
Dimensions
Weight (W x D x H)
116.97mm x 138.9mm x 144.07mm ; 4.6” x 5.5” x 5.7 ”
1.3kg ; 2.54lbs
CE, FCC
144.07mm/5.7”
Certifications
-40˚C~50˚C ; -40˚F~122˚F (20%~80% humidity)
116.97mm/4.6”
138.9mm/5.5”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
65
Colour Cameras Outdoor PolestarII Dome Cameras
ED610
560TVL, 1/3" CCD, WDR & True Day/Night
Outdoor Vandal Dome Camera
Outdoor Dome Cameras
Super
Low
Lux
560
Outdoor
WDR
3DNR
OSD
Vandal proof
Features
Specifications
• 560TVL of horizontal resolution
• Advanced Digital Signal Processor (DSP) delivers
excellent picture quality and performance
• True Day/Night function with ICR module
• Support 3D-Noise Reduce for noise reduction while
increasing disk storage capacity
• Low light sensitivity 0.05 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3” SONY Super
HAD CCD II
• The starlight Super-high sensitivity of 0.0002Lux/
F=1.2 is achieved by setting SENS-UP Shutter 256x
• OSD setting menu
• Support motion detection function for 4 zones
• Support privacy mask function for 8 zones
• Support Digital Wide Dynamic Range expansion
• Support Digital-Zoom
• Support line lock external synchronization
• Vandal resistant
• Weatherproof IP66 rated
• 3-Axis rotation
Dimensions
Pickup Device
1/3" SONY Super HAD CCD II
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
560TVL
0.05Lux/F=1.2 (AGC ON) ; 0.0002Lux/F=1.2 (Sens-up 256x)
S/N Ratio
Over 52dB (Auto off)
Electronic Shutter
Video Output
1/50 (1/60)~1/100,000
2 Video Outputs: 1. BNC 1.0 Vp-p ,75ohm
2. Additional testing video output 1.0 Vp-p, 75ohm
Gamma Correction
Lens Type
0.45
Vari-focal lens, Auto Iris, 2.8-10mm, 9-22mm
Back Light Comp.
Auto Gain Control
White Balance
BLC, OFF, HS BLC Selectable
Low/Middle/High Selectable
ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode
Internal/Line lock external sync.
Day & Night
Yes, (Auto, Colour, B/W, EXT)
OSD menu
Yes
3DNR
On/Off switch
D-WDR
Outdoor, Indoor
Digital Slow Shutter
Mirror
Sens-Up~256x
Off/Mirror/V-Flip/Rotate Selectable
Digital Zoom
On/Off switch
Motion Detection
On/Off for 4 Zones
Privacy Mask
On/Off for 8 Zones
Weatherproof
IP66
Vandal Resistant
Power Source
123 mm / 4.8”
Power Consumption
Operating Temperature
Dimensions (Φ x H)
Weight
Yes
12VDC/24VAC
12VDC: 3W max./24VAC: 3W max.
-10˚C~50˚C/14˚F~122˚F (20%~80% humidity)
123mm x 107.8mm/4.8" x 4.2"
0.74kg/1.6lbs
CE, FCC
Ø
5.
14
-3
107.8 mm / 4.2”
Certifications
Ø
66
94
.7
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Outdoor Dome Cameras
EHD525EX
560TVL, 1/3" Sony ExView CCD, True Day/Night
Vandal Colour Dome Camera
Yes
Outdoor
Outdoor Dome Cameras
AWB
560
BLC
ON/OFF
AGC
ON/OFF
Vandal proof
Features
Specifications
• Low light sensitivity 0.1 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" Sony Exview
CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
PProcessor (DSP) delivers excellent picture quality
and sharp colour images
• Designed with polycarbonate shell to withstand the
impact of a 10lbs sledgehammer
• Aluminum base with smoke colour shell
• Day/Night with IR cut removable module
• Dual voltage: 24VAC or 12VDC
Pickup Device
Video Format
1/3” SONY EXView CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625 TVL, 50 fields/sec
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Lens Type
560TVL
0.1 Lux/F=1.2
Over 50dB (AGC off)
1/50 (1/60)~1/100,000
Vari-focal lens, Auto Iris
f=2.9~10mm, F=1.2/f=3.6~ 9mm/f=9~22mm, F=1.6
*Lens models and availability vary in different regions
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
On/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
Weatherproof
Vandal Resistant
Heater
Power Source
Power Consumption
BNC 1.0Vp-p, 75 ohm
Line Lock/Internal Sync.
IP66
Yes
Yes, built-in
12VDC/24VAC
12VDC: 11.5W max. (Heater ON)
12VDC: 4W max. (Heater OFF)
24VDC: 6VA max. (Heater OFF)
Dimensions
24VDC: 20.5VA max. (Heater ON)
Dimensions (W x H x D)
Weight
Operating Temperature
1.7kg/3.7lbs
-40°C~50°C/-40°F~122°F (20%~80% humidity)
CE, FCC
130 mm / 5.1”
Certifications
130mm x 98.8mm x 130mm/5.1" x 3.9" x 5.1"
130 mm / 5.1”
98.8 mm / 3.9”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
67
Colour Cameras Outdoor Dome Cameras
EHD350HQ
560TVL, High Resolution, Colour Vandal Dome Camera
Outdoor Dome Cameras
AWB
560
Yes
Outdoor
BLC
ON/OFF
AGC
ON/OFF
Vandal proof
Features
Specifications
• Low light sensitivity 0.5 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor (DSP) delivers excellent picture quality
and sharp colour images
• Designed with polycarbonate shell to withstand the
impact of a 10 lbs sledgehammer
• Rugged dome is designed with 3-Axis for angle-view
flexibility
• Heater triggers when temperature falls below
10˚C/50˚F
• Built-in micro switch for alarm trigger
• Aluminum base with smoke colour shell
• Weatherproof IP66 rated
Pickup Device
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
560TVL
0.5 Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Lens Type
1/50 (1/60)~1/100,000
Vari-focal lens, Auto Iris
f = 2.9~10mm , F=1.2/f = 3,8~ 9.5mm/f = 9~22mm , F=1.6
*Lens models and availability vary in different regions
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
On/Off switch
White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
BNC 1.0Vp-p, 75ohm
Line Lock/Internal Sync
Heater
Yes, built-in
Weatherproof
IP66
Vandal Resistant
Power Source
Power Consumption
Yes
12VDC/24VAC
24VAC: 6VA max. (Heater OFF)
24VAC: 20.5VA max. (Heater ON)
12VDC: 3.5W max. (Heater OFF)
Dimensions
12VDC: 11W max. (Heater ON)
Dimensions (W x H x D)
Weight
130mm x 98.8mm x 130mm ; 5.1" x 3.9" x 5.1"
1.7kg ; 3.7lbs
Operating Temperature
-40°C~50°C ; -40°F~122°F (20%-80% humidity)
Certifications
130 mm / 5.1”
CE, FCC
130 mm / 5.1”
68
98.8 mm / 3.9”
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Outdoor Dome Cameras
EHD300
480TVL, Outdoor Colour Vandal Dome Camera
Yes
Outdoor
BLC
Vandal proof
Outdoor Dome Cameras
AWB
480
ON/OFF
AGC
ON/OFF
Features
Specifications
• Low light sensitivity 0.4 Lux/F=1.6 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 480TVL of horizontal resolution
• The electronic shutter and AGC allow the camera to
be used in environment with varying light levels
• 24VAC/12VDC Dual power ready
• Built-in Vari-Focal lens
• BLC, AGC and Flickerless function on/off switchable
• With manual Pan/Tilt mechanism
• Rugged Dome for vandal proof
• Rugged Dome designed with 3-axis which provides
the best installation for ceiling and wall mounted
• IP66 weatherproof rating
Pickup Device
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
480TVL
0.4 Lux/F=1.2
Over 48dB (AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
BNC 1.0 Vp-p, 75ohm
Gamma Correction
Lens Type
0.45
Vari-focal lens, Auto Iris
f = 2.9~ 10mm, F=1.2/f=3.7~12mm/f=9~22mm, F=16
*Lens models and availability vary in different regions
Back Light Comp.
ON/OFF Switch
Auto Gain Control
ON/OFF Switch
Auto White Balance
Sync. Mode
Flickerless
Weatherproof Ratings
Vandal Resistant
Power Source
Power Consumption
Yes
Internal sync
ON/OFF Switch
IP66
Yes
12VDC/24VAC
12VDC: 2W max. /24VAC: 4VAW max.
Operating Temperature
-10°C~50°C/14°F~122°F (20%~80% humidity)
Dimensions (W x H x D)
130mm x 98.9mm x 130mm/5.1" x 3.87" x 5.1"
Weight
Dimensions
1/3" SONY SUPER HAD CCD
0.8kg/1.8lbs
CE, FCC
130 mm / 5.1”
Certifications
130 mm / 5.1”
98.8 mm / 3.9”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
69
Colour Cameras Bullet IR Cameras
EZ650
560TVL, IR Day/Night plus Wide Dynamic Range,
IP66 Bullet Camera
NEW
Bullet IR Cameras
24VAC
100~240VAC
IR
80m
Features
Specifications
• Super HAD II sensor at 0.05 Lux has 5X better native light
sensitivity before DSP low light boost
• Starlight super high sensitivity of 0.0002 Lux/F=1.2 is
achieved through a sensitivity increase setting of up to
256x
• Extended IR range of up to 80m with 42 LEDs and variable
output IR control to manage illumination and conserve
energy
• Split glass to prevent internal IR reflections
• Full motion true day/night images even with no ambient
light without ghosting
• True Day/Night with ICR module
• Motorized varifocal auto iris lens – 6-50mm focal range
• Digital Wide Dynamic Range expansion to deliver properly
exposed images despite bright light sources, deep shadows
and/or unbalanced lighting in the same scene
• Provides 3D-Noise Reduction to improve picture clarity while
enabling DVRs to improve disk storage utilization
• Easy to use OSD setup menu with local controls or RS-485
remote control
• Motion detection for 4 configurable zones
• Privacy mask function for 8 configurable zones
• Provides digital zoom up to 32x
• Easy bottom access to video test point and lens/OSD menu
controls inside weatherproof cover
• IP66 weather resistant
• Vandal resistant
Pickup Device
Picture Elements
0.05Lux/F=1.2(AGC ON) ; 0.0002Lux/F=1.2 (Sens-up 256x) ;
S/N Ratio
Over 52dB (AGC off)
0 Lux IR on.
Electronic Shutter
Video Output
Lens Type
OFF/BLC/HS BLC Selectable
Auto Gain Control
Low/Middle/High Selectable
White Balance
ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode
Internal/Line lock
Day & Night
Auto/Colour/BW/EXT (True Day/Night with ICR control module)
OSD menu
Multiple functions
IR Emitters
42 long life LEDs
IR Configuration
Split glass isolation prevents internal reflections
IR Wavelength
IR LED Minimum Lifespan
850nm
20,000 hours of operation
IR Range
Up to 80m (AGC ON)
IR Output
Intelligent Variable Intensity Illumination/Energy Management
Off/On switchable
Digital WDR
Outdoor, Indoor
Digital Slow Shutter
Sens-Up to 256X
Off/Mirror/V-Flip/Rotate Selectable
Off/On selectable up to 32X
Off/On for 4 selectable zones
Off/On for 8 selectable zones
RS-485
Control input for menu/configuration
Power Source
Power Consumption
Operating Temperature
115mm/4.5”
* All product specifications are subject to change without notice
0.45
Back Light Compensation
Privacy Mask
70
BNC 1.0V p-p 75Ω,
DC Iris Varifocal: 6-50mm focal length
Motion Detection
.5
1/60 (1/50)~1/100,000
Gamma Correction
Digital Zoom
57
560TVL
Sensitivity
Mirror
275mm/10.8”
NTSC/PAL
768 x 494 (NTSC)/752 x 582 (PAL)
Horizontal Resolution
3D-DNR
Dimensions
1/3" SONY Super HAD II CCD
Video Format
2 types: 24VAC ; 100~240VAC
24VAC: 20W ; 100~240VAC: 18W
-40°C~50°C ; -40°F~122°F (built-in heater) (20% ~ 80% humidity)
Weatherproof
IP66 rated
Heater
Yes, built-in
Vandal Resistant
Dimensions (W x D)
Yes
275mm x 115mm/10.8" x 4.5"
Certifications
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Bullet IR Cameras
EZ630
560TVL, IR Day/Night plus
Wide Dynamic Range, IP66 Bullet Camera
Outdoor
Speedy
Mount Ring
4” Electrical Box
Compatibility
Motorized
VF/AI
Lens
AWB
1” Conduit
Compatibility
BLC
Yes
AGC
OSD
Super
Low
Lux
WDR 3DNR
Vandal proof
RS485
Yes
True Day/Night
Yes
Bullet IR Cameras
560
NEW
IR
60m
Heater
Features
Specifications
• Super HAD II sensor at 0.05 Lux has 5X better native light sensitivity
before DSP low light boost
• Starlight super high sensitivity of 0.0002 Lux/F=1.2 is achieved
through a sensitivity increase setting of up to 256x
• Extended IR range of up to 60M(196ft) with 36 LEDs and variable
output
• IR control to manage illumination and conserve energy
• Split glass to prevent internal IR reflections
• Full motion true day/night images even with no ambient light without
ghosting
• True Day/Night with ICR module
• Motorized varifocal auto iris lens – choose 2.8-10mm or 9-22mm focal
range
• Digital Wide Dynamic Range expansion to deliver properly exposed
images despite bright light sources, deep shadows and/or unbalanced
lighting in the same scene
• Provides 3D-Noise Reduction to improve picture clarity while enabling
DVRs to improve disk storage utilization
• Flexible mounting and positioning – speedy-mount ring fits 4” round
electrical box; or remove base to mate with 1” conduit
• E-Z Lock ring at the base is designed with easy to grip tabs to firmly
clamp the camera in place, plus a set screw for added security.
• Easy to use OSD setup menu with local controls or RS-485 remote
control
• Motion detection for 4 configurable zones
• Privacy mask function for 8 configurable zones
• Provides digital zoom up to 32x
• Easy bottom access to video test point and lens/OSD menu controls
inside weatherproof cover
• IP66 weather resistant
• Vandal resistant
• Dual voltage (12VDC/24VAC) with line lock to AC supply
Pickup Device
Video Format
Picture Elements
Horizontal Resolution
S/N Ratio
Over 52dB (AGC off)
0 Lux IR on.
Electronic Shutter
Video Output
Gamma Correction
Lens Type
OFF/BLC/HS BLC Selectable
Low/Middle/High Selectable
White Balance
Internal/Line lock
Day & Night
Auto/Colour/BW/EXT (True Day/Night with ICR control module)
OSD menu
Multiple functions
IR Emitters
IR Configuration
IR Wavelength
IR LED Minimum Lifespan
up to 60m (196ft)
Intelligent Variable Intensity Illumination/Energy Management
3D-DNR
Power Source
Power Consumption
Operating Temperature
Outdoor, Indoor
Sens-Up 256X
Off/Mirror/V-Flip/Rotate Selectable
Off/On selectable up to 32X
Off/On for 4 selectable zones
Off/On for 8 selectable zones
Control input for menu/configuration
12VDC/24VAC
12VDC:8W max. /24VAC: 9W max.
-40°C~50°C/-40°F~122°F (built-in heater)
IP66 rated
Heater
Yes, built-in
Vandal Resistant
Dimensions (L x H x W)
Weight
81.5
Ø106.5
Off/On switchable
Weatherproof
Mounting Pattern
Yes
316.2mm x 82.5mm x 105.5mm ; 12.49" x 3.24" x 4.15"
1250 g/2.275 lbs.
Speedy-Mount Ring mates with 4” round electrical box; base swivel is 1”
NPT – remove base plate for coupling to standard conduit fittings.
Certifications
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
850nm
20,000 hours of operation
IR Output
RS-485
184.2
36 long life LEDs
Split glass isolation prevents internal reflections
IR Range
Privacy Mask
316.2
ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode
Motion Detection
Ø75.0mm
0.45
DC Iris Varifocal: 2.8-10mm (MVB) or 9-22mm (MV2) focal length
Auto Gain Control
Digital Zoom
Ø83.0mm
1/60 (1/50)~1/100,000
Main Output BNC 1.0V p-p 75Ω, Local test output, cable provided.
Back Light Compensation
Mirror
Ø88.5mm
560TVL
0.05Lux/F=1.2(AGC ON) ; 0.0002Lux/F=1.2(Sens-up 256x) ;
Digital Slow Shutter
R44.0mm
NTSC, PAL
768 x 494 (NTSC)/752 x 582 (PAL)
Sensitivity
Digital WDR
Dimensions
1/3" SONY Super HAD CCD II
CE, FCC
* All product specifications are subject to change without notice
71
Colour Cameras Bullet IR Cameras
EZ330E/335E
520TVL, Outdoor, Weatherproof,
Long Range IR Bullet Camera
Bullet IR Cameras
AWB
520
Yes
BLC
Yes
IR
AGC
Yes
Vandal proof
Outdoor
60m
Features
Specifications
• Low light sensitivity 0.4 Lux/F=1.2(AGC ON) is
achieved by using the advanced 1/3” SONY Super
HAD CCD
• 520TVL of horizontal resolution
• Vari-frequency IR control
• Long IR distance: 30 meters/98 feet for EZ330E and
50 meters/164 feet for EZ335E
• Lifespan of High Light IR LED is 20,000 hours
• IP66 weatherproof rated
• Built-in heater for camera to work in low
temperature environment
• Cables covered by the bracket, to prevent from
intentional destruction
• Internal cable connection provides installation
without additional waterproof connection box
• Vandal Resistant design
Product Model
Pickup Device
EZ335E
EZ330E
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525 TVL, 60 fields/sec ; PAL: 625 TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
520TVL
0.4 Lux/F=1.2 (AGC ON); 0 Lux (IR On)
S/N Ratio
Over 48 dB (AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
BNC 1.0Vp-p, 75ohm
Gamma Correction
*Lens Type
0.45
8mm, 16mm, 25mm
6mm, 8mm
Black Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Yes
Sync. Mode
Internal Sync.
IR LED
35 pcs
IR LED Lifespan
IR Distance
20,000 hours
850nm
Weatherproof
IP66
Vandal Resistant
Power Source
Power Consumption
Dimensions
50m/164feet
30m/98feet
IR Wavelength
Yes
2 types: 24VAC ; 100VAC~240VAC
24VAC/100VAC~240VAC: 16W max.
Operating Temperature
-40°C ~50°C/-40°F~122°F (20%~80% humidity)
Dimensions (W x H x D)
115mm x 115mm x 275mm ; 4.5" x 4.5" x 10.8"
Weight
2.5 kg ; 5.5 lbs (with bracket)
Certifications
275mm / 10.8”
CE, FCC
115 mm / 4.5”
72
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Bullet IR Cameras
EZL32/33/35
NEW
520TVL, Weatherproof,
Long Range IR Bullet Camera
AWB
Yes
Bullet IR Cameras
520
IR
AGC
Yes
Vandal proof
Features
20~50m
Specifications
• The electronic shutter and AGC functions allow the
camera to be used in environment with varying light
levels
• The advanced 1/3” SONY Super HAD colour CCD
provides low light sensitivity 0.4 Lux/F=1.2 (AGC ON)
• Vari-frequency IR control
• Long IR distance: 20m/65ft for EZL32 ; 30m/98ft for
EZL33 and 50m/164ft for EZL35
• Lifespan of High Light IR LED is 20,000 hours
• IP66 weatherproof rated
• Vandal proof design
Model No.
EZL32
Pickup Device
Picture Elements
520TVL
Video Output
BNC 1.0Vp-p, 75ohm
4.3mm
Sensitivity
6mm, 3.8~9.5mm
0.45
S/N Ratio
Over 48 dB (AGC off)
Auto White Balance
Yes
Black Light Comp.
Yes
Auto Gain Control
Yes
Sync. Mode
Internal Sync.
20m/65ft
30m/98ft
IR Wavelength
850mm
IR LED Lifespan
20,000 hours
Weatherproof
IP66
Power Source
12VDC
Power Consumption
8mm, 25mm
0.4 Lux/F=1.2 (AGC ON) ; 0 Lux (IR On)
Gamma Correction
IR Distance
EZL35
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Lens Type
EZL33
1/3” SONY Super HAD CCD
50m/164ft
12VDC: 2W max.
Dimensions
115mm x 115mm x 275mm ; 4.5" x 4.5" x 10.8"
Operating Temperature
-40°C~50°C/-40°F~122°F (20%~80% Humidity)
Weight
1.75kg/3.8 lbs
Dimensions
275mm/10.8”
R5
5
7.
115mm/4.5”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
73
Colour Cameras Bullet IR Cameras
EZ430
520 TVL, Weatherproof, Colour IR Bullet Camera
Bullet IR Cameras
AWB
520
Yes
BLC
Yes
Vandal proof
AGC
Yes
Outdoor
IR
30m
Features
• Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD II
• 520TVL of excellent high resolution technology
• Up to 30 meters/98 ft. of IR range
• Vari-focal lens to offer you a wide variety of angle
viewing
• True Day/Night function with removable IR cut filter
• Motorized lens controller for easy zoom and focus
adjustment
• IRIS level adjustment
• Cable wires are placed inside camera bracket to
eliminate messy wiring and damage
• Intelligent Vari-Frequency of IR control to save
electricity and make brightness balance
• Split glass design to avoid LED light reflection
• Up to 20,000 hours of hign IR LED lifespan
• Vandal resistant for intentional destruction
• Weatherproof and IP66 rated
Specifications
Pickup Device
1/3" SONY Super HAD CCD II
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
520TVL
0.4 Lux/F=1.2 (IR OFF) ; 0 Lux (IR ON)
S/N Ratio
Over 48 dB (AGC off)
Electronic Shutter
Video Output
1/50 (1/60)~1/100,000
BNC 1.0Vp-p, 75ohm
Gamma Correction
Lens Type
0.45
Vair-focal lens, f=2.9~10mm/F=1.2, f=9~22mm/F=1.6
Back Light Comp.
Yes
Auto Gain Control
Yes
White Balance
Sync. Mode
Yes
Internal sync
True Day & Night
Yes
IR LED
35 pcs
IR LED Lifespan
20,000 hours
IR Distance
30m/98ft
IR Wavelength
850nm
Weatherproof
IP66
Vandal Resistant
Yes
Heater
Yes, built-in
Power Source
Dimensions
Power Consumption
12VDC/24VAC
12VDC: 12W max. (Heater ON & IR LED ON) ;
24VAC: 15W max. (Heater ON & IR LED ON)
Operating Temperature
-40˚C~50˚C/-40˚F~122˚F (20%~80% humidity)
Dimensions (W x D x H)
88mm x 235.3mm x 174.2mm/3.46" x 9.26" x 6.86"
Weight
1.15kg/2.53lbs
Certifications
74
* All product specifications are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Bullet IR Cameras
ECZ330E
520TVL, Weatherproof, IR Mini Bullet Camera
Yes
IR
30m
BLC
Yes
AGC
Yes
Features
•
•
•
•
•
•
•
•
•
Bullet IR Cameras
AWB
520
Specifications
520TVL of horizontal resolution
0 Lux when IR LED is ON
Easy installation
Auto Electronic Shutter function
Automatic Gain Control function
Auto White Balance function
IR distance 10~12m/33~39ft
Lifespan of IR LED is 20,000 hours
Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
Pickup Device
Video Format
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Lens Type
Over 48dB (AGC off)
1/50 (1/60)~1/100,000
4.3mm/F=2.0, 6.0mm/F=2.0
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Yes
Gamma Correction
0.45
BNC 1.0Vp-p, 75ohm
Sync. Mode
Internal sync
IR Distance
4.3mm Lens Type: 10m/6mm Lens Type: 12m
IR Wavelength
850nm
IR LED Lifespan
20,000 hours
IR Control
Vari-frequency
IR Wavelength
Power Source
Power Consumption
Dimensions (W x H x D)
IP66
850nm
12VDC
3W max.
With sun shield: 60.5mm x 59.4 mm x 82mm ; 2.4" x 2.3" x 3.2"
Without sun shield: 55mm (O.D.) x 60 mm (H) ; 2.2" (O.D.) x 2.4" (H)
Weight
Operating Temperature
Certifications
0.3 kg
-10°C~50°C/14°F~122°F (20%~80% humidity)
CE, FCC
60 mm / 2.4”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
520TVL
0.4 Lux/F=1.2 (AGC ON)/0 Lux (IR LED on)
*Lens models and availability vary in different regions
Weatherproof Ratings
55 mm / 2.2”
NTSC/PAL
Scanning System
Video Output
Dimensions
1/3” SONY Super HAD CCD
* All product specifications are subject to change without notice
75
Colour Cameras Bullet IR Cameras
ECZ255
420TVL, 1/3” Colour CCD, Weatherproof,
IR Mini Bullet Camera
Bullet IR Cameras
AWB
420
BLC
Yes
Yes
IR
30m
NEW
AGC
Yes
Features
Specifications
• Mini bullet colour camera with SHARP 1/3” CCD
sensor
• Employs Digital Signal Processor (DSP) chip-set for
image control
• Pixel number: NTSC=270K/PAL=320K
• High sensitivity, low smear, high anti-blooming, and
high S/N ratio
• Build-in functions: Auto Electronic Shutter (AES),
Auto Gain Control (AGC), Auto White Balance(AWB)
• Built-in anti-aliasing optical filter
• Built-in Hi-power IR-LED x 6 for low light
environments
Pickup Device
Picture Elements
SHARP 1/3" Colour CCD
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
420TVL
Minimum Illumination
0 LUX with built-in IR-LED
S/N Ratio
Over 48dB
Electronic Shutter
NTSC: 1/60s~1/100,000s ; PAL: 1/50s~1/110,000s
Gain Control
Auto
White Balance
Auto (2500K~9500K)
Gamma Correction
Lens Type
0.45
Board Lens 3.6 mm/F2.0
Sync Mode
Internal, Negative sync.
IR LED
6 Units of 850nm Hi-power IR LED
IR Distance
10~15m
Video Output
Power Source
Operating Temp.
1 Vp-p Composite Video/75 Ohms.
12VDC/180mA
-10°C~50°C/14°F~122°F
Weatherproof Ratings
IP66
Dimensions
54mm
80mm
64mm
76
13mm
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Bullet IR Cameras
EZ230E/235E
420TVL, Outdoor, Weatherproof,
Long Range IR Bullet Camera
AWB
Yes
30-50m
Bullet IR Cameras
420 IR
380
BLC
Yes
AGC
Yes
Vandal proof
Outdoor
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 420TVL of horizontal resolution
• Vari-frequency IR control
• Long IR distance: 30m/98ft for EZ230E and 50
m/164ft for EZ235E
• Lifespan of High Light IR LED is 20,000 hours
• IP66 weatherproof rated
• Internal cable connection provides installation
without additional waterproof connection box
• Vandal Resistant design
• Built-in heater for camera to work in low
temperature environment
• Cables covered by the bracket, to prevent from
intentional destruction
Model No.
Pickup Device
EZ235E
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
Horizontal Resolution
Sensitivity
420TVL
0.3 Lux/F=1.2 (AGC ON); 0 Lux (IR On)
S/N Ratio
Over 48 dB (AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
BNC 1.0Vp-p, 75ohm
Gamma Correction
Lens Type
0.45
6mm, 8mm
8mm, 16mm, 25mm
Black Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Yes
Sync. Mode
Internal Sync.
IR LED
35 pcs
IR LED Lifespan
IR Distance
20,000 hours
30m/98feet
50m/164feet
IR Wavelength
850nm
Weatherproof
IP66
Vandal Resistant
Power Source
Power Consumption
Dimensions
EZ230E
Yes
2 types: 24VAC ; 100VAC~240VAC
24VAC/100VAC~240VAC: 16W max.
Operating Temperature
-40°C ~50°C/-40°F~122°F (20%~80% humidity)
Dimensions (W x H x D)
115mm x 115mm x 275mm ; 4.5" x 4.5" x 10.8"
Weight
Certifications
275mm / 10.8”
2.5 kg ; 5.5 lbs (with bracket)
CE, FCC
115 mm / 4.5”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
77
Colour Cameras Bullet IR Cameras
ECZ230E
420TVL, Weatherproof, IR Mini Bullet Camera
Bullet IR Cameras
420 IR
380
AWB
BLC
Yes
10-12m
Yes
AGC
Vandal proof
Yes
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2(AGC ON)
is achieved by using the advanced 1/3” SONY
Super HAD CCD
• 420TVL of horizontal resolution
• 0 Lux when IR LED is ON
• Easy installation
• Auto Electronic Shutter function
• Automatic Gain Control function
• Auto White Balance function
• IR distance 10~12m/33~39ft
• Lifespan of IR LED is 20,000 hours
Pickup Device
1/3'' SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) ; 500 x 582 (PAL)
Horizontal Resolution
Sensitivity
420TVL
0.3 Lux/F=1.2 (AGC ON) 0 Lux (IR LED on)
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Video Output
BNC 1.0Vp-p , 75ohm
Gamma Correction
Lens Type
0.45
4.3mm/F=2.0, 6.0mm/F=2.0
*Lens models and availability vary in different regions
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Sync. Mode
Yes
Internal sync
IR LED
14pcs
IR LED Lifespan
IR Distance
20,000 hours
4.3mm lens: 10m/6mm lens: 12m
IR Wavelength
IP66
Power Source
12VDC
Power Consumption
Operating Temperature
Dimensions (W x H x D)
Dimensions
850nm
Weatherproof
12VDC: 3W max.
-10°C~50°C ; 14°F~122°F (20%~80% humidity)
With sun shield: 60.5mm x 59.4 mm x 82mm ; 2.4" x 2.3" x 3.2"
Without sun shield: 55mm (O.D.) x 60 mm (H) ; 2.2" (O.D) x 2.4"(H)
Weight
0.3 kg ; 0.7 lbs
Certifications
55 mm / 2.2”
78
CE, FCC
60 mm / 2.4”
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Bullet Cameras
EZ610
NEW
560TVL, Colour Day/Night plus WDR,
IP66 Bullet Camera
Outdoor
Speedy
Mount Ring
4” Electrical Box
Compatibility
Motorized
VF/AI
Lens
AWB
1” Conduit
Compatibility
BLC
Yes
OSD
True Day/Night
AGC
Yes
Yes
Bullet Cameras
560
Super
Low
Lux
WDR 3DNR
Vandal proof
RS485
Heater
Features
Specifications
• Super HAD II sensor at 0.05 Lux has 5X better native light
sensitivity before DSP low light boost
• Colour without compromise: your choice of full motion
colour or true day/night images in low light without
ghosting
• True Day/Night with ICR module
• Starlight super high sensitivity of 0.0002 Lux/F=1.2 is
achieved through a sensitivity increase setting of up to
256x
• Motorized varifocal auto iris lens – choose 2.8-10mm or
9-22mm focal range
• Digital Wide Dynamic Range expansion to deliver properly
exposed images despite bright light sources, deep shadows
and/or unbalanced lighting in the same scene
• Provides 3D-Noise Reduction to improve picture clarity while
enabling DVRs to improve disk storage utilization
• Flexible mounting and positioning – speedy-mount plate fits
4” electrical box; or remove base to mate with 1” conduit
• E-Z Lock ring at the base is designed with easy to grip tabs
to reliably hold the camera in place, plus a set screw for
added security
• Easy to use OSD setup menu with local or RS-485 remote
control (DVR or keyboard)
• Motion detection for 4 configurable zones and local alarm
output
• Privacy mask function for 8 configurable zones
• Provides digital zoom up to 32x
• Easy bottom access to video test point and lens/ODS menu
controls
• IP66 weather resistant
• Vandal resistant
• Dual voltage (12VDC/24VAC) with line lock to AC supply
Pickup Device
Dimensions
Power Consumption
Video Format
Picture Elements
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Over 52dB (AGC off)
1/50 (1/60) ~1/100,000
BNC 1.0Vp-p 75Ω, Local test output, cable provided.
0.45
DC Iris Varifocal: 2.8-10mm (MVB) or 9-22mm (MV2) focal length
OFF/BLC/HS BLC Selectable
Low/Middle/High Selectable
White Balance
ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode
Internal/Line lock
Day & Night
Auto/Colour/BW/EXT
OSD menu
Multiple functions
3D-DNR
Off/On switchable
Digital WDR
Outdoor, Indoor
Digital Slow Shutter
Sens-Up to 256X
Mirror
Digital Zoom
Motion Detection
Privacy Mask
RS-485
Power Source
Dimensions (L x H x W)
Weight
Mounting Pattern
Ø88.5
560TVL
0.05Lux/F=1.2 (AGC ON) ; 0.0002Lux/F=1.2 (Sens-up 256x)
Auto Gain Control
Weatherproof
Ø75.0
NTSC/PAL
NTSC: 768 x 494/PAL: 752 x 582
Back Light Compensation
Operating Temperature
R44.0
1/3" SONY Super HAD II CCD
Off/Mirror/V-Flip/Rotate Selectable
Off/On selectable up to 32X
Off/On for 4 selectable zones
Off/On for 8 selectable zones
Control input for menu/configuration
12VDC/24VAC
12VDC:3W max./24VAC: 3W max.
-40°C~50°C/-40°F~122°F (20%~80% humidity)
IP66 rated
316.2mm x 82.5mm x 105.5mm/12.49" x 3.24" x 4.15"
1250g/2.275lbs
Speedy-Mount Ring mates with 4” round electrical box; base swivel is
1” NPT – remove base plate for coupling to standard conduit fittings.
Ø83.0
Certifications
CE, FCC
316.2
Ø105.5
Ø82.5
184.2
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
79
Colour Cameras Bullet Cameras
EZ350HQ
560TVL, Weatherproof, Colour Bullet Camera
Bullet Cameras
AI
560
Outdoor
AGC
ON/OFF
BLC
Yes
Auto Iris
AWB
Yes
Features
Specifications
• Low light sensitivity 0.5 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3” SONY Super
HAD CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor (DSP) delivers excellent picture quality
and sharp colour images
• Intelligent backlight compensation with On/Off
switch
• Camera can be operated in extreme low
temperature -40°C/-40°F
• Removable sun shield
• IP66 Weatherproof rated
Pickup Device
1/3” SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
560TVL
0.5Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Lens Type
1/50 (1/60)~1/100,000
Vari-focal lens, Auto Iris f=3.8~9.5mm/F=1.2,
f=9~22mm/F=1.6
*Lens models and availability vary in different regions
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
On/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
BNC 1.0Vp-p, 75ohm
Sync. Mode
Line Lock/Internal sync
Heater
Yes, built-in
Weatherproof
IP66
Power Source
12VDC/24VAC
Power Consumption
24VAC: 6VA max. (Heater OFF)
24VAC: 12.5VA max. (Heater ON)
12VDC: 4W max. (Heater OFF)
12VDC: 7.5W max. (Heater ON)
Dimensions
Dimensions (W x H x D)
With sun shield: 90.7mm x 70mm x 172mm /3.57" x 2.8" x 6.8"
Without sun shield: 132mm (D) x 57mm (O.D)/5.2" (D) x 2.2" (O.D)
Weight
80
-40°C~50°C/-40°F~122°F (20%~80% humidity)
Heater Activation Temp
Yes, 10°C On/20°C Off
Certifications
172 mm / 6.8”
132 mm / 5.2”
0.71kg/1.6lbs/0.91kg ; 2lbs (with bracket)
Operating Temperature
CE, FCC
156 mm / 6.14”
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras PolestarII Box Cameras
EQ610
560TVL, Super Low Lux, WDR & True Day/Night Box Camera
RS485 3DNR
Box Cameras
Super
Low
Lux
560
WDR
OSD
Features
Specifications
• Super HAD II sensor at .05 lux has 5X better native
light sensitivity before DSP low light boost
• Colour without compromise: your choice of full
motion colour or true day/night images in low light
without ghosting
• True Day/Night with ICR control (Optional)
• Starlight super high sensitivity of 0.0002 Lux/F=1.2
is achieved through a sensitivity increase setting of
up to 256x
• Digital Wide Dynamic Range expansion to deliver
properly exposed images despite bright light
sources, deep shadows and/or unbalanced lighting
in the same scene
• Provides 3D-Noise Reduction to improve picture
clarity while enabling DVRs to
• improve disk storage utilization
• Accepts C/CS mount manual or DC iris lenses
• Easy to use OSD setup menu with local or RS-485
remote control (DVR or keyboard)
• Motion detection for 4 configurable zones and local
alarm output
• Privacy mask function for 8 configurable zones
• Provides digital zoom up to 32x
• Dual voltage (12VDC/24VAC) or universal power
(100-240VAC) with line lock to AC supply
Pickup Device
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ;PAL: 625TVL, 50 fields/sec.
Picture Elements
768 x 494 (NTSC) ; 752 x 582 (PAL)
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Back Light Compensation
Auto Gain Control
White Balance
560TVL
0.05Lux/F=1.2 (AGC ON) ; 0.0002Lux/F=1.2 (Sens-up 256x)
Over 52dB (AGC off)
1/50 (1/60)~1/100,000
BNC 1.0 Vp-p ,75ohm
0.45
Manual or DC (DD) type C/CS Mount (Lens sold separately)
BLC, OFF, HS BLC Selectable
Off/Low/Middle/High Selectable
ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode
Internal/Line lock external sync.
Day & Night
Yes, (Auto, Colour, B/W, EXT)
OSD menu
3DNR
D-WDR
Digital Slow Shutter
Mirror
Digital Zoom
Yes
Off/On switchable
Outdoor, Indoor
Sens-Up~256x
Off/Mirror/V-Flip/Rotate Selectable
Off/On switchable
Motion Detection
Off/On for 4 selectable zones
Privacy Mask
Off/On for 8 selectable zones
Alarm
Dimensions
1/3" SONY Super HAD CCD II
RS-485
Power Source
Power Consumption
1 output (3.3VDC)
Yes, Built-in
12VDC/24VAC ; 100~240VAC; 12VDC only
12VDC:3W max. ; 24VAC:3W max. ;
100VAC: 4W max. ; 240VAC: 5W max.
Operating Temperature
0°C~50°C/32°F~122°F (20%~80% humidity)
Dimensions (W x H x D)
68mm x 56mm x120mm ; 4.8” x 4.2” x 4.7"
Weight
56 mm / 4.2”
Certifications
0.4 kg ; 0.9 lbs
CE, FCC
120 mm / 4.7
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
81
Colour Cameras Box Cameras
EQ350HQ
560TVL, Aluminum Box Camera
Box Cameras
BLC
AWB
560
Yes
Yes
AI
AGC
ON/OFF
Auto Iris
FL
ON/OFF
Features
Specifications
• Low light sensitivity 0.5 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor (DSP) delivers sharp colour images and
excellent picture quality
• Wide range automatic electronic shutter:
1/60 (1/50)~1/100,000
• Auto line lock with external phase adjustment
• C/mount or CS-mount adjustable with easy backfocus adjustment wheel on the camera
• Smart FL mode for fluorescent light or 1/100sec
(NTSC)
• Utilizing innovative Pure Vision Technology
Pickup Device
Picture Elements
1/3” SONY Super HAD CCD
NTSC: 768 x 494 ; PAL: 752 x 582
Video Format
Scanning System
NTSC/PAL
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Horizontal Resolution
Sensitivity
560TVL
0.5 Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Lens Type
1/50 (1/60)~1/100,000
С/CS mount, Video Drive/Direct Drive (Lens sold separately)
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Fluorescent Light
On/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
BNC 1.0Vp-p,75 ohm
Line Lock/Internal sync
Phase Control
V-Phase +/-90
Power Source
2 types: 100VAC~240VAC ; 12VDC/24VAC
Power Consumption
100VAC~240VAC: 12VA max. ;
24VAC: 7VA max. ; 12VDC: 4.5W max.
Dimensions (W x H x D)
Weight
57mm x 51mm x 140.2mm/2.25" x 2" x 5.52"
0.5kg/1.1lbs
Operating Temperature
0°C~50°С/32°F~122°F (20%-80% humidity)
Certifications
CE, FCC
Dimensions
57 mm / 2.25”
140.2 mm / 5.52”
82
51 mm / 2”
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Box Cameras
EI350HQ
560TVL, Pure Vision Lens, Integrated Colour Camera
Box Cameras
AWB
560
Yes
BLC
AI
ON/OFF
Auto Iris
AGC
ON/OFF
Features
Specifications
• Low light sensitivity 0.5 Lux/F=1.2(AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 560TVL of horizontal resolution
• Revolutionary integrated 10-bit Digital Signal
Processor (DSP) delivers excellent picture quality an
sharp colour images
• Intelligent backlight compensation
• Utilizes Pure Vision Technology
Pickup Device
Video Format
1/3” SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Lens Type
560TVL
0.5 Lux/F=1.2
Over 48dB (AGC off)
1/50 (1/60)~1/100,000
Vari-focal lens, Auto Iris f=3.8~ 9.5mm, F=1.2
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
Power Source
Power Consumption
Dimensions (W x H x D)
Weight
Mounting Bracket (H x Φ )
BNC 1.0Vp-p, 75 ohm
Line Lock/Internal Sync
12VDC/24VAC
24VAC: 7.5VA max. ; 12VDC: 4.5W max.
66mm x 59mm x 146mm/2.56" x 2.3" x 5.7"
0.4kg/0.9lbs
Aluminum, 145mm x 56.5mm/
5.7" x 2.2" ; Max Load 3kgs
Operating Temperature
Certifications
0°C~50°C/32°F~122°F (20%-80% humidity)
CE, FCC
Dimensions
59 mm / 2.3”
146 mm / 5.7”
66 mm / 2.56”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
83
Colour Cameras Box Cameras
EQ300E
520TVL, Aluminum Box Camera with Simple Day/Night
Box Cameras
AWB
520
Yes
BLC
ON/OFF
AGC
ON/OFF
Features
• 520TVL of horizontal resolution
• Support video drive and DC drive auto IRIS lens
• Designed with advance digital signal processing
circuitry for high image quality
• Day/Night Auto/Off switchable
• ES, BLC, AGC and FL On/Off switchable
• Compatible with both C-mount and CS-mount lens
(adapter ring included)
• System available for NTSC or PAL
• Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
Specifications
Pickup Device
1/3" SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
Horizontal Resolution
Sensitivity
520TVL
0.4 Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Auto Iris
1/50 (1/60)~1/100,000
Video Drive/Direct Drive switch
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
On/Off switch
Day & Night Mode
Auto/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
BNC 1.0Vp-p, 75 ohm
Internal sync
Lens Type
C/CS mount (Lens sold separately)
Audio
Optional
Power Source
Power Consumption
3 types: 12VDC only ; 12VDC/24VAC ; 100VAC~240VAC
12VDC: 1.6W max. ; 24VAC: 2.2W max.
100VAC~240VAC: 1.6W max.
Dimensions (W x H x D)
Weight
Dimensions
0.25kg/0.55lbs
Operating Temperature
Lens
58mm x 55mm x 125mm/2.3" x 2.2" x 4.9"
0°C~50°C/32°F~122°F (20%~80% humidity)
Lens sold separately
Certifications
84
* All product specifications are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Box Cameras
EQ200E
420TVL, Aluminum Box Camera with Simple Day/Night
Box Cameras
AWB
380
420
Yes
BLC
ON/OFF
AGC
ON/OFF
Features
Specifications
• 420TVL of horizontal resolution
• Support video drive and DC drive auto IRIS lens
• Designed with advance digital signal processing
circuitry for high image quality
• Day/Night Auto/Off switchable
• ES, BLC, AGC and FL On/Off switchable
• Compatible with both C-mount and CS-mount lens
(adapter ring included)
• System available for NTSC or PAL
• Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
Pickup Device
Video Format
1/3" SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Auto Iris
420TVL
0.3 Lux/F=1.2
Over 48dB (AGC off)
1/50 (1/60)~1/100,000
Video Drive/Direct Drive switch
Back Light Comp.
On/Off switch
Auto Gain Control
On/Off switch
Flickerless
Day & Night Mode
On/Off switch
Auto/Off switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
Lens Type
Audio
Power Source
Power Consumption
BNC 1.0Vp-p, 75 ohm
Internal sync
C/CS mount (Lens sold separately)
Optional
3 types: 12VDC only ; 12VDC/24VAC ; 100VAC~240VAC
12VDC: 1.6W max. ; 24VAC: 2.2W max.
100VAC~240VAC: 1.6W max.
Dimensions (W x H x D)
Weight
Dimensions
Operating Temperature
Certifications
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
58mm x 55mm x 125mm/2.3" x 2.2" x 4.9"
0.25kg/0.55lbs
0°C~50°C/32°F~122°F (20%~80% humidity)
CE, FCC
* All product specifications are subject to change without notice
85
Colour Cameras Covert Cameras
ESD2512/ESD2583
1/3" Covert Camera in PIR Housing
Covert Cameras
Features
Specifications
• Sony Super HAD II high sensitivity CCD sensor
• Built-in Cone Lens
• Option PIR senor board for motion detection
Model No.
Image Device
Picture Elements (HxV)
Resolution
Min. Illumination
ESD2512
ESD2583
1/3" Colour Sony Super HAD II
1/3" Colour Sony Super HAD II
NTSC: 510x492,
PAL: 500x582
420 TVL
NTSC: 768x494,
PAL: 752x582
0.01 Lux/ F1.2
S/N Ratio
0.02 Lux/ F1.2
More than 48dB
Electronic Shutter
NTSC: 1/60~100,000,
PAL: 1/50~1/110,000
0.45
Gamma
Lens Furnished
Cone Lens 3.7mm/ F2.0
White Balance
Auto
Gain Control
Auto
PIR N.C/N.O Relay Output
3A/120 VAC, 3A/24 VAC
PIR N.C/N.O Relay Alarm Time
2 to 40 sec. (adjustable)
PIR Detection Angle
Hor.=100˚ / Ver.=45˚
PIR Max. Detection Range
Up to 15M
Sync. System
Internal
Video Output
1 Vp-p / 75 Ohms
Audio Output
2 Vp-p / 50 Ohms
Power Supply
DC12V±10%
Power Consumption
200mA max.
Operation Temp.
145mA max.
-10°C~50°C
Dimensions
86
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Covert Cameras
ESD200
420TVL, Covert (Fake Smoke Detector) Colour Camera,
available with 1,2,3 or 4 cameras built in
Covert Cameras
AWB
420
380
Yes
BLC
ON/OFF
AGC
ON/OFF
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is
achieved by using the advanced 1/3" SONY
Super HAD CCD
• 420TVL of horizontal resolution
• Designed with advance digital signal processing
circuitry for high image quality
• Built-in fixed lens
• User can simultaneously install up to 4 cameras for
a complete 360˚ surveillance
• Back Light Comp., Auto Gain Control and Auto White
Balance functions
• Compact size: 150mm x 50mm ; 5.9" x 2"
• System available for NTSC or PAL
Pickup Device
Video Format
1/3" SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Lens Type
420TVL
0.3 Lux/F=1.2
Over 48dB (AGC off)
1/50 (1/60)~1/100,000
f=4.3mm ; f=6.0mm ; f=8.0mm
*Lens models and availability vary in different regions
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
Sync. Mode
Power Source
BNC 1.0Vp-p, 75 ohm
Internal sync
12VDC
Power Consumption
3W max.
Dimensions (Φ x H)
150 mm x 50 mm/5.9" x 2"
Weight
Operating Temperature
Certifications
0.32kg/0.7lbs
0°C~50°C/32°F~122°F (20%~80% humidity)
CE, FCC
Dimensions
150 mm / 5.9”
50 mm / 2”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
87
Colour Cameras Covert Cameras
EM200
420TVL, Metal Case Colour Camera
Covert Cameras
420
380
BLC
AWB
Yes
ON/OFF
AGC
12VDC
Yes
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2(AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 420TVL of horizontal resolution
• The electronic shutter and AGC allow the camera to
be used in environment with varying light levels
• Built-in anti-alasing and IR cut optial filter, except
pinhole modules
• System available for NTSC and PAL
Pickup Device
1/3" SONY Super HAD CCD
Video Format
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625 TVL, 50 fields/sec
Picture Elements
NTSC: 510 x 492 ; PAL: 500 x 582
Horizontal Resolution
Sensitivity
420TVL
0.3 Lux/F=1.2
S/N Ratio
Over 48dB (AGC off)
Electronic Shutter
Video Output
1/50 (1/60)~1/100,000
BNC 1.0Vp-p,75 ohm
Gamma Correction
Lens Type
0.45
f=3.6mm ; f=4.3mm ; f=6.0mm ; f=8.0mm
*Lens models and availability vary in different regions
Lens Mount
M12 x P0.5
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Sync. Mode
Yes
Internal Sync.
Power Source
12VDC
Power Consumption
3W max.
Operating Temperature
0°C~50°C/32°F~122°F (20%~80% humidity)
Dimensions (W x D x H)
36mm x 36mm x 31mm/1.42" x 1.42" x 1.22"
Weight
0.09kg/0.20lbs
Certifications
CE, FCC
Dimensions
43 mm / 1.7”
59 mm / 2.3”
88
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Colour Cameras Covert Cameras
EB200
420TVL, Colour Camera Module
BLC
Covert Cameras
380
420
AWB
Yes
ON/OFF
AGC
ON/OFF
Features
Specifications
• Low light sensitivity 0.3 Lux/F=1.2(AGC ON) is
achieved by using the advanced 1/3" SONY Super
HAD CCD
• 420TVL of horizontal resolution
• The electronic shutter and AGC allow the camera to
be used in environment with varying light levels
• Built-in audio function
• Shipped with complete assemblage, easy camera
position adjustments
• System available for NTSC and PAL
Pickup Device
Dimensions
1/3" SONY Super HAD CCD
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec
Picture Elements
NTSC: 510 x 492 ; PAL: 500 x 580
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
420TVL
0.3 Lux/F=1.2
Over 48dB (Auto off)
1/50 (1/60)~1/100,000
BNC 1.0Vp-p, 75 ohm
0.45
f=3.6mm ; f=4.3mm ; f=6.0mm ; f=8.0mm
*Lens models and availability vary in different regions
Lens Mount
M12 x P0.5
Back Light Comp.
Yes
Auto Gain Control
Yes
Auto White Balance
Sync. Mode
Power Soure
Power Consumption
Operating Temperature
Dimensions
Weight
Certifications
Yes
Internal sync
12VDC
3W max.
0°C~50°C/32°F~122°F (20%~80% humidity)
32mm x 32mm/1.28" x 1.28"
0.02kg/0.04lbs
CE, FCC
Dimensions
1 mm / 0.04”
32 mm / 1.28”
32 mm / 1.28”
17.7 mm / 0.71”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
89
IP Surveillance
90
* All product specifications are subject to change without notice
IP Surveillance 2 Megapixel HD IP Cameras
EQN2200/2201
H.264, 2 Megapixel, HD Network Camera
(Q-Cam Network Camera)
NEW
Series
2 Megapixel HD IP Cameras
Features
Specifications
• 2 Megapixel image capture (Max. Resolution: 1600
x 1200)
• Built in H.264 and M-JPEG dual stream output at
720p image size with up to 30fps
• Integrated fix focus wide angle lens (4.3mm),
adjustable focus
• Full screen monitoring
• Two-way audio capability
• Built-in microphone & speaker
• Image transfer by motion detection, digital I/O
• Smart wizard event management
• Plug-and-play installation
• Image date and time stamp
• Built-in 802.11g/b wireless (EQN2201)
Product Model
EQN2200: wired interface
EQN2201: wired and wireless interface
CAMERA
Pickup Device
1/3" progressive scan CMOS sensor, 2 Megapixel
Lens
4.3mm/F=1.8
Sensitivity
0.5Lux /F=1.8
VIDEO STREAMING
Video Compression
Video Resolution
Frame Rate
H.264/M-JPEG
1600 x 1200~160 x 120
1600 x 1200@10fps, 1280 x 960@15fps, 720p lower@ 30fps
AUDIO (Optional)
Microphone & Speaker
Operation Mode
Built-in
Two-way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Support MDI/MDI-X auto crossover function
Built-in IEEE 802.11b/g WLAN (for EQN2201)
Supported Protocols
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP,
ONVIF, PSIA
TERMINAL I/O
Alarm Input/Output
1/1
EVENT MANAGEMENT
Event Trigger
Notification
Alarm Input, Manual Trigger, Motion Detection
Trigger alarm output, Send mail notification,
Upload video to FTP and Network alarm
Dimensions
POWER
Power Supply
Power Consumption
5VDC
EQN2200: 3.5W max.
EQN2201: 4.0W max.
PHYSICAL
Weight
Dimension (H x W x D)
ENVIRONMENTAL
13. 5
54. 5
41
48. 5
0°C~40°C/32°F~104°F
Humidity
< 90% not condensing
Certificates
CE, FCC
34
103
78
4. 2
Operating Temp.
96. 5
62
118. 5
45
66
140g/0.31lbs
97 x 66 x 55mm/3.8” x 2.6” x 2.2”
75. 5
(Unit:mm)
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
91
IP Surveillance 2 Megapixel HD IP Dome Cameras
EDN3240
NEW
2 Megapixel, H.264, Full HD,
IR Network Dome Camera
Series
2 Megapixel HD IP Cameras
IR
H.264/MJPEG
20m
True Day/Night
SDHC
slot
Features
16:9
HDTV
Specifications
• 1/3” 1080p/720p HD colour CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
• Supports both H.264 and Motion JPEG in full 30 fps
frame rate
• High performance noise filter improves image
quality and conserves disk storage
• Provides NTSC/PAL TV signal output for local aim
and focus or display on an analog monitor.
• Dual codec for H.264 and MJPEG allows choice of
stream formats to fit the application
• Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
• Provides true day/night functionality with automatic
IR filter operation
• Two Way Audio transport (line level input/output)
• ONVIF / PSIA compliance interoperates with a broad
range of systems
• Dual power capability PoE or 12VDC for flexible
installation
• Local alarm inputs and outputs
Dimensions
CAMERA
Camera Type
2MP Full HD Network Dome Camera
Pickup Device
1/3" Progressive Scan CMOS
Pixel Effective
Sensitivity
1920 x 1080
0.4 Lux / F=1.2 (IR Off)/0 Lux (IR On)
Day & Night
True Day/Night with IR cut filter
Electronic Shutter
Lens
Rolling
Vari-Focal Lens (3.3~10mm/F=1.2)
Video Output
Yes
IR Distance
20m
IR Wavelength
850nm
VIDEO STREAMING
Video Compression
Video Resolution
Frame Rate
H.264/MJPEG
Max. 1920x1080
30fps@1920x1080p
AUDIO
Audio I/O
1/1
Operation Mode
Two-way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket ; Support MDI/
MDI-X auto crossover function
Supported Protocols
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP,
uPnP, PSIA, ONVIF
TERMINAL I/O
RS-485
Yes
Alarm Input/Output
2/1
EVENT MANAGEMENT
Event Triggered by
Notification
128mm / 5.1”
Alarm input, Manual trigger, Motion detection
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Send HTTP notification and Network alarm
LOCAL STORAGE
SD Card
SD/SDHC memory card slot (card is not included)
POWER
Power Supply
Power Consumption
12VDC
6 max. (12VDC)
140mm / 5.5”
PHYSICAL
Weight
660g/1.45 lbs
Dimension (Φ x H)
Surface Type: 140mm x 128mm/5.5" x 5.1"
Flush Type: 140mm x 68mm/5.5" x 2.8"
ENVIRONMENTAL
Operation Temperature
0°C~40°C/32°F~104°F (20%~80% humidity)
Certificates
92
* All product specifications are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Dome Cameras
EHN3200
NEW
2 Megapixel, H.264, Full HD,
Outdoor Network Dome Camera
Series
True Day/Night
SDHC
slot
2 Megapixel HD IP Cameras
H.264/MJPEG
16:9
Vandal proof
Features
HDTV
Specifications
• 1/3” 1080p/720p HD colour CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
• Supports both H.264 and Motion JPEG in full 30 fps
frame rate.
• High Performance Noise Filter improves image
quality and conserves disk storage
• Provides NTSC/PAL TV signal output for local aim
and focus or display on an analog monitor.
• Dual Codec for H.264 and MJPEG allows choice of
stream formats to fit the application
• Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
• Provides true day/night functionality with automatic
IR filter operation
• Two Way Audio transport (line level input/output)
• ONVIF / PSIA compliance interoperates with a broad
range of systems
• Dual power capability PoE or 12VDC for flexible
installation
• Local alarm inputs and outputs
CAMERA
Camera Type
2MP Full HD Network Outdoor Network Dome Camera
Pickup Device
1/3" Progressive Scan CMOS
Pixel Effective
Sensitivity
Day & Night
Electronic Shutter
Lens
Video Output
True Day/Night with IR cut filter
Rolling
Vari-Focal Lens (3.3~10mm/F=1.2)
Yes
VIDEO STREAMING
Video Compression
Video Resolution
Frame Rate
H.264/MJPEG
Max. 1920 x 1080
30fps@1920 x 1080p
AUDIO
Audio I/O
Operation Mode
1/1
Two-way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket ; Support MDI/
MDI-X auto crossover function
Supported Protocols
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP,
uPnP, PSIA, ONVIF
TERMINAL I/O
Alarm Input/Output
1/1
EVENT MANAGEMENT
Event Triggered by
Dimensions
1920 x 1080
0.4 Lux/F=1.2
Notification
Alarm input, Manual trigger, Motion detection
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Send HTTP notification and Network alarm
LOCAL STORAGE
SD Card
SD/SDHC memory card slot (card is not included)
POWER
Power Supply
127mm /5.0”
12VDC & PoE
Power over Ethernet
Yes (PoE 802.3af 48VDC)
Power Consumption
5W max. (12VDC)
PHYSICAL
Weight
Dimension (Φ x H)
740g/1.6 lbs
123mm x 107.8mm/4.8" x 4.2"
ENVIRONMENTAL
Operation Temperature
112.8mm/4.44”
Weatherproof Ratings
Vandal Resistant
Certificates
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
-10°C~50°C/14°F~122°F (20%~80% humidity)
OTHERS
IP66
Yes
CE, FCC
* All product specifications are subject to change without notice
93
IP Surveillance 2 Megapixel HD IP Bullet Cameras
EZN3240
NEW
2 Megapixel, H.264, Full HD, Outdoor,
IR Network Bullet Camera
Series
2 Megapixel HD IP Cameras
Features
Specifications
• 1/3” 1080p/720p HD colour CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
• Supports both H.264 and Motion JPEG in full 30 fps
frame rate.
• High Performance Noise Filter improves image
quality and conserves disk storage
• Provides NTSC/PAL TV signal output for local aim
and focus or display on an analog monitor.
• Dual Codec for H.264 and MJPEG allows choice of
stream formats to fit the application
• Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
• Provides true day/night functionality with automatic
IR filter operation
• Two Way Audio transport (line level input/output)
• ONVIF / PSIA compliance interoperates with a broad
range of systems
• Dual power capability PoE or 12VDC for flexible
installation
• Local alarm inputs and outputs
• Remote Zoom & Focus adjustment by web browser
Dimensions
CAMERA
Camera Type
2MP Full HD Network Outdoor IR Bullet Network Camera
Pickup Device
1/3" Progressive Scan CMOS
Pixel Effective
Sensitivity
1920 x 1080
0.4 Lux/F=1.2 (IR Off)/0 Lux (IR On)
Day & Night
True Day/Night with IR cut filter
Electronic Shutter
Lens
Rolling
Vari-Focal Lens (2.8~10mm/F=1.2) w/stepping motor
Video Output
Yes
IR Distance
60m
IR Wavelength
850nm
VIDEO STREAMING
Video Compression
Video Resolution
Frame Rate
H.264/MJPEG
Max. 1920 x 1080
30fps@1920 x 1080p
AUDIO
Audio I/O
1/1
Operation Mode
Two-way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket ; Support MDI/
MDI-X auto crossover function
Supported Protocols
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP,
uPnP, PSIA, ONVIF
TERMINAL I/O
RS-485
Yes
Alarm Input/Output
1/1
EVENT MANAGEMENT
Event Triggered by
Notification
Alarm input, Manual trigger, Motion detection
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Send HTTP notification and Network alarm
R44.0mm
Ø88.5mm
Ø83.0mm
LOCAL STORAGE
SD Card
Ø75.0mm
SD/SDHC memory card slot (card is not included)
POWER
Power Supply
Power Consumption
12VDC
12 max. (12VDC, IR LED/ON)
PHYSICAL
Weight
184.2
88mm x 235.3mm x 174.2mm/3.46" x 9.26" x 6.86"
ENVIRONMENTAL
Operation Temperature
81.5
Ø106.5
1.15kg/2.53lbs
Dimension (W x D x H)
316.2
-40°C~50°C/-40°F~122°F (20%~80% humidity)
OTHERS
Weatherproof Ratings
Vandal Resistant
Certificates
94
* All product specifications are subject to change without notice
IP66
Yes
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance 2 Megapixel HD IP Box Cameras
EAN3200
2 Megapixel, H.264, Full HD Network Box Camera
NEW
Series
Specifications
• 1/3” 1080p/720p HD colour CMOS image sensor
delivers HDTV video quality in 16:9 aspect ratio
• Supports both H.264 and Motion JPEG in full 30 fps
frame rate.
• High Performance Noise Filter improves image
quality and conserves disk storage
• Provides NTSC/PAL TV signal output for local aim
and focus or display on an analog monitor.
• Dual Codec for H.264 and MJPEG allows choice of
stream formats to fit the application
• Built-in slot for an SDHC card enables local event
or backup recording in the event of network
interruptions
• Provides true day/night functionality with automatic
IR filter operation
• Two Way Audio transport (line level input/output)
• ONVIF / PSIA compliance interoperates with a broad
range of systems
• Dual power capability PoE or 12VDC for flexible
installation
• Local alarm inputs and outputs
CAMERA
Camera Type
Pickup Device
Lens Type
Sensitivity
Day/Night
Electronic Shutter Speed
SENSE-UP
Auto Gain Control
White Balance mode
Noise Filter
Other settings
Video Output
VIDEO STREAMING
Video Compression
Video Resolution
Video Quality
Frame Rate
AUDIO
Audio Compression
Audio Input
Audio Output
Operation Mode
NETWORK
Interface
Supported Protocols
Dimensions
TERMINAL I/O
Alarm Input / Output
RS485
EVENT MANAGEMENT
Event Trigger
Notifications
136mm/5.4”
13mm/0.5”
10mm/0.4”
57mm/2.2”
Megapixel Network Camera
68mm/2.7”
49mm/1.9”
LOCAL STORAGE
Pre-and Post-alarm buffer
SD Card
POWER
Power Supply
Power over Ethernet
Power Consumption
PHYSICAL
Weight
Dimension
ENVIRONMENTAL
Operating Temp.
Humidity
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
2 Megapixel HD IP Cameras
Features
Indoor, traditional style megapixel network camera
1/3" Full HD progressive scan CMOS sensor
Optional C/CS mount, manual / DD control support
0.5Lux / F=1.2
True Day/Night with IR cut filter
1/10000 s to 1/7.5 s
OFF/x2/x4
OFF/Low/Middle/High selectable
Auto, Custom
Auto/Low/High
Brightness, Contrast, Saturation, Sharpness, Hue, Auto Exposure,
Backlight Compensation, Mirror, Flip, Day/Night, Anti-Flicker
BNC socket, composite 1 Vp-p / 75Ω in local test mode only
H.264/M-JPEG
1920x1080 to 160x120
VBR: 5 level adjustable, CBR: 30Kbps~6Mbps
All resolutions @ 25/30fps
G.726 ADPCM 8 kHz
1 Vrms ; 3.5mm phone jack; Mono
1 Vrms ; 3.5mm phone jack; Mono
Two-way audio
10Base-T/100Base-TX auto-negotiation, RJ-45 socket,
Support MDI/MDI-X auto
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP, uPnP,
ONVIF/PSIA
1/1
Yes (function reserved)
Alarm Input, Manual Trigger, Motion Detection, Schedule Recording
Trigger alarm output, Send mail notification, Upload video to FTP, Record
video to PC, Record to SD card and Network alarm
Up to 120 sec.
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
12 VDC & PoE
Yes (PoE 802.3af)
4 W max. (12VDC)
550g / 1.102 lbs.
68 (W) x 57 (H) x 135 (D) mm / 2.72” (W) x 2.28” (H) x 5.4” (D)
0°C ~ 40°C / 32°F ~ 104°F
< 90% not condensing
* All product specifications are subject to change without notice
95
IP Surveillance 1.3 Megapixel IP Box Cameras
EAN900
1.3 Megapixel, H.264, Box Network Camera
Series
Software Partners:
Nevio Series IP Cameras
Features
Specifications
• 1.3 Megapixel, 1/3” progressive scan CMOS sensor
with high sensitivity
• Built-in H.264, MPEG-4 and MJPEG digital signal
output at 1280x1024 image size with up to 15fps
• H.264/MPEG4/MJPEG multi stream output for
simultaneous live monitoring and high resolution
recording
• Power over Ethernet (PoE) IEEE 802.3af
• True Day/Night function with removable IR cut
filter User-friendly Smart Event Wizard for Event/
Schedule/Alarm recording to PC or SD Card
• Triggered Alarm when motion is detected
• Email notification or FTP video upload upon motion
detection and alarm
• Built-in SD memory card slot for local storage and
support SDHC
CAMERA
Pickup Device
Picture Elements
Sensitivity
1/3” Progressive scan CMOS 1.3 Megapixel
1280 x 1024
0.5 Lux/F=1.2
Day & Night
True Day/Night with ICR module
Lens Type
Optional C/CS mount, manual/DD control supported
Video Output
BNC socket, composite 1Vp-p/75Ω
VIDEO STREAMING
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
H.264/MPEG-4/M-JPEG
1280 x 1024
8 levels adjustable
Up to 15fps in 1280x1024
AUDIO
Microphone
Built-in *
Operation Mode
Two-way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Supported Protocols
Support MDI/MDI-X auto crossover function HTTP, TCP / IP, UDP, RTP,
RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Bandwidth Control
Min. 64 kbps adjustable
Max. Client Limit
32 simultaneous clients
TERMINAL I/O
Alarm Input/Output
RS-485
1/1
RS-485 interface half-duplex
EVENT MANAGEMENT
Dimensions
Event Trigger
Notification
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
48MB RAM reserved for pre-alarm record up to 120 sec.
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Support SDHC Host Specification
POWER
136mm/5.4”
13mm/0.5”
10mm/0.4”
57mm/2.2”
Megapixel Network Camera
68mm/2.7”
Power Source
12VDC & PoE
Power over Ethernet
Yes (PoE 802.3af 48VDC)
Power Consumption
4.5W max. (12VDC)
PHYSICAL
Weight
550g/1.102LBS
Dimensions (W x H x D)
49mm/1.9”
68 x 57 x 136mm /2.7" x 2.2" x 5.4"
with BNC socket: 68 x 57 x 146mm /2.7" x 2.2" x 5.7"
ENVIRONMENTAL
Operating Temperature
0°C~40°C/32°F~104°F
Humidity
< 90% not condensing
Certificates
96
* All product specifications are subject to change without notice
CE, FCC, UL
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance Nevio Series IP Dome Cameras
EDN850H
560TVL, IP66, True Day/Night,
Outdoor Network Dome Camera
Series
Features
Nevio Series IP Cameras
Software Partners:
560
Specifications
• Multi stream output at 4 CIF resolution @ 30fps
• H.264/MPEG4/MJPEG multi stream output for
simultaneous live monitoringand high resolution
recording
• True Day/Night function with ICR module
• Built-in DNR (Dynamic Noise Reduction) for noise
reduction and a 70% saving of Disk storage
• The starlight Super-high sensitivity of 0.002 Lux/
F=1.2 is achieved by setting
• SENS-UP Slow Shutter 128x max.
• Built-in Vari-Focal lens
• Power over Ethernet (PoE) IEEE 802.3af
• Support MDI/MDI-X auto crossover
• Smart Wizard settings for varied Event and schedule
recording
• Built-in SD memory card slot for local storage and
support SDHC
• Two-way Audio
• Easy wall or ceiling installation
• Vandal Resistant & Weatherproof IP66 rating
CAMERA
Pickup Device
Picture Elements
Sensitivity
Day & Night
Lens Type
Video Output
Video Output Resolution
1/3” Sony Super HAD Interlaced CCD
NTSC: 768 x 494 ; PAL: 752 x 582
0.002 Lux (SENS-UP 128x) ; 0.25 Lux/F=1.2
Yes (with IR cut filter)
Vari-Focal Lens with Auto Iris (2.8~10mm)
BNC socket, composite 1Vp-p/75Ω
560TVL
VIDEO STREAMING
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
H.264/MPEG-4/M-JPEG
4CIF, VGA, CIF, QVGA, QCIF
8 levels adjustable
Up to 30fps
AUDIO
Audio Input
3.5mm stereo socket, sensitivity 1 Vrms
Audio Output
3.5mm stereo socket, sensitivity 1 Vrms
Compression
Method IMA ADPCM (Pulse Code Modulation)
Operation
Mode Two-way audio
NETWORK
Interface
Support
Supported Protocols
Bandwidth Control
Max. Client
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
MDI/MDI-X auto crossover function
HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Min. 64 kbps adjustable
Limit 32 simultaneous clients
TERMINAL I/O
Dimensions
Alarm Input
Alarm Output
1 x input for dry contacts, Normal Open/Normal Closed adjustable
1 x dry relay contact, Normal Open/Normal Closed adjustable,
70 VDC/200 mA max
EVENT MANAGEMENT
Event Trigger by
Notification
127mm /5.0”
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
48MB RAM reserved for pre-alarm record up to 120 sec
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
POWER
Power Source
112.8mm/4.44”
12VDC & PoE
PoE
Yes (PoE 802.3af)
Power Consumption
5W max. (12VDC)
OTHER
Weatherproof Ratings
Certificates
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP66
CE, FCC
* All product specifications are subject to change without notice
97
IP Surveillance Nevio Series IP Dome Cameras
EDN800
520TVL, True Day/Night, Vandalproof,
Network Dome Camera
Series
Nevio Series IP Cameras
Software Partners:
520
Features
Specifications
• Built-in H.264, MPEG-4 and MJPEG digital signal
output at 4CIF image size with up to 30fps
• H.264/MPEG4/MJPEG multi stream output for
simultaneous live monitoring and high resolution
recording
• Support 4 independent video streams that can
provide different compression formats and
resolutions
• The high sensitivity of 0.4Lux/F=1.2 is achieved by
using the advanced 1/3" Sony Super HAD CCD
• Built-in Vari=focal Lens
• Power over Ethernet (PoE) IEEE 802.3af
• Support MDI/MDI-X auto crossover function
• Bandwidth control:64k/128k/256k/1m/2m/4m/8m
bps and unlimited
• Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
• Smart Wizard settings for various event and
schedule recording conditions
• Built-in SD memory card slot for local storage and
support SD High Capacity (SDHC)
• Built-in digital motion detection
CAMERA
Pickup Device
Picture Elements
Sensitivity
1/3” Sony Super HAD CCD
NTSC: 768 x 494 ; PAL: 752 x 582
0.4 Lux/F=1.2
Day & Night
Yes
Lens Type
Vari-Focal Lens (3.7~12mm)
Video Output
BNC socket, composite 1 Vp-p/75Ω
Video Output Resolution
520TVL
VIDEO STREAMING
Compression Format
Max. Video Resolution
Video Quality
H.264/MPEG-4/M-JPEG
4CIF, VGAL, CIF, QVGA, QCIF
8 levels adjustable
Frame Rate
Up to 30fps
NETWORK
Interface
10Base-T100Base-TX auto-negotiation, RJ-45 socket Support MDI/
Supported Protocols
HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
MDI-X auto crossover function
Bandwidth Control
Min. 64 kbps adjustable
Max. Client
32 simultaneous clients
TERMINAL I/O
Alarm Input/Output
1x1
EVENT MANAGEMENT
Event Trigger
Alarm input, manual trigger,
Motion detection and Schedule recording
Notification
Dimensions
Trigger alarm output, Send mail notification, Upload, Video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
48MB RAM reserved for pre-alarm record up to 120 sec.
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
POWER
127mm /5.0”
Power Source
12 VDC & PoE
Power over Ethernet
Yes (PoE 802.3af)
Power Consumption
5W max. (12VDC)
PHYSICAL
Weight
550g/1.213 lbs.
Dimensions (O.D x H)
113mm/4.5”
127 x 113mm/5.0" x 4.5"
ENVIRONMENTAL
Operating Temperature
0°C~40°C/32°F~104°
Humidity
<90%, not condensing
Vandal Resistant
Certificates
98
* All product specifications are subject to change without notice
Yes
CE, FCC, UL
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance Nevio Series IP IR Bullet Cameras
EZN850
560TVL, True Day/Night, Weatherproof,
IR Network Bullet Camera
Series
Nevio Series IP Cameras
Software Partners:
560
Outdoor
Features
Specifications
• Built-in H.264, MPEG-4 and MJPEG multi stream
outputs at 4CIF image size with up to 30 fps
• SENS-UP shutter technology 128x
• Support 4 independent video streams that can
provide different compression formats and
resolutions for simultaneous live monitoring and
high resolution recording
• Built-in external adjuster control for 6~50mm auto
iris lens (zoom and focus). Lens control is available
through web browser
• True Day/Night function with removable IR cut filter
• IR distance up to 50 meters (about 164ft.) with
Vari-Frequency IR control
• Smart Wizard settings for various event
management and schedule recording
• Built-in SD memory card slot for local storage and
support SD High Capacity
• Motion detection and privacy area function
• Vandal proof and IP66 weatherproof
CAMERA
Pickup Device
Picture Elements
Sensitivity
1/3” Sony Super HAD CCD
NTSC: 768 x 494 ; PAL: 752 x 582
0.002 Lux/F=1.2 (IR Off, SENS-UP 128x) ; 0 Lux (IR On)
Day & Night
True Day/Night with removable IR cut filter
Lens Type
Vari-focal 6~50mm lens (9x optical zoom)
Video Output
Video Output Resolution
IR Distance
BNC socket, composite 1Vp-p/75Ω
560TVL
50m/164 feet
IR Wavelength
850nm
IR LED Lifespan
20,000 hours
VIDEO STREAMING
Video Compression
H.264/MPEG-4/M-JPEG
Video Resolution
4CIF, VGA, QVGA, QCIF
Video Quality
Frame Rate
8 level adjustable
Up to 30fps
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket Support MDI/
Supported Protocols
HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, FHCP, DNS, DDNS, NTP
MDI-X auto crossover function
Bandwidth Control
Min. 64 kbps adjustable
Max. Client
32 simultaneous clients
TERMINAL I/O
RS-485
Alarm Input/Output
Dimensions
Power Output
RS-485 interface half-duplex
1x1
DC12V for external IR illuminator
EVENT MANAGEMENT
Event Trigger
Alarm input, Manual trigger, Motion detection and Schedule recording
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
POWER
Power Source
295 mm / 11.8”
Power
Consumption
100VAC~240VAC: 8W max. (Heater/ON & IR LED/ON)
115 mm / 4.5”
PHYSICAL
Weight
Dimensions (W x H)
2.5kg/5.5lbs (3.0kg/6.6lbs with bracket)
295 x 115 mm/11.8" x 4.5"
ENVIRONMENTAL
Operating Temperature
Humidity
-40°C~50°C/-40°F~122°F
<90%, not condensing
Heater
Yes
Weatherproof Ratings
IP66
Vandal Resistant
Certificates
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
2 types: 24VAC ; 100~240VCA
24VAC: 28W max. (Heater/ON & IR LED/ON) ;
Yes
CE, FCC, UL
* All product specifications are subject to change without notice
99
IP Surveillance Nevio Series IP Box Cameras
EAN850A
560TVL, Super Low Lux Network Camera
Series
Nevio Series IP Cameras
Software Partners:
560
Features
Specifications
• Built-in H.264, MPEG-4 and MJPEG digital signal
output at 4CIF image size with up to 30fps
• H.264/MPEG4/MJEG multi stream output for
simultaneous live monitoring and high resolution
recording
• Support 4 independent video streams that can
provide different compression formats and
resolutions
• Power over Ethernet (PoE) IEEE 802.3af
• Built-in DNR (Dynamic Noise Reduction) for noise
reduction and a 70% saving of Disk storage
• The starlight Super-high sensitivity of 0.002 Lux/
F=1.2 is achieved by setting SENS-UP Shutter X128
• Bandwidth control:64k/128k/256k/1M/2M/4M/8M
bps and unlimited
• Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
• Support MDI/MDI-X auto crossover function
• Smart Wizard settings for varied Event and schedule
recording conditions
• Built-in SD memory card slot for local storage and
support SD High Capacity
• Two way audio
Dimensions
CAMERA
Pickup Device
Picture Elements
Sensitivity
1/3” Sony Super HAD Interlaced CCD
NTSC: 768 x 494/PAL: 752 x 582
0.002 Lux (SENS-UP X128) ; 0.25 Lux/F=1.2
Day & Night
True Day/Night with ICR module
Lens Type
Optional C/CS mount, manual/DD control supported
Video Output
BNC socket, composite 1 Vp-p/75Ω
Video Output Resolution
560TVL
VIDEO STREAMING
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
H.264/MPEG-4/M-JPEG
4CIF, VGA, CIF, QVGA, QCIF
8 level adjustable
Up to 30fps
AUDIO
Microphone
Built-in
Operation Mode
Two-way audio
EVENT MANAGEMENT
Event Trigger
Notification
Alarm input, Manual trigger, Motion detection and Schedule recording
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
48MB RAM reserved for pre-alarm to 120 sec.
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, Rj-45 socket Support MDI/
Supported Protocols
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
MEI-X auto crossover function
Bandwidth Control
Max. Client Limit
Min. 64 k Byte/sec adjustable
32 simultaneous clients
TERMINAL I/O
Alarm Input/Output
RS-485
1/1
RS-485 interface half-duplex
LOCAL STORAGE
SD Card
13mm/0.5”
68mm/2.7”
57mm/2.2”
Megapixel Network Camera
Secure Disk physical layer specification version 2.0 Supports SDHC Host
Specification
136mm/5.4”
POWER
Power Source
PoE
Power Consumption
49mm/1.9”
5W max. (12VDC)
PHYSICAL
Weight
10mm/0.4”
12 VDC & PoE
Yes (PoE 802.3af 48VDC)
500g/1.102 LBS
Dimensions (W x H x D)
68 x 57 x 136mm/2.7" x 2.2" x 5.4"
with BNC socket: 68 x 57 x 146mm/2.7" x 2.2" x 5.7"
ENVIRONMENTAL
Operating Temperature
Humidity
Certificates
100
* All product specifications are subject to change without notice
0°C~40°C/32~°F~104°F
< 90% not condensing
CE, FCC, UL
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Surveillance Nevio Series IP Box Cameras
EAN800A/EAN800AW
520TVL, H.264, True Day/Night Advanced Network Camera
Series
Features
Nevio Series IP Cameras
Software Partners:
520
Specifications
• Built-in H.264, MPEG-4 and MJPEG digital signal
output with up to 30 EPS at 4CIF (704 x 480)
• Support H.264/MPEG4/MJPEG triple stream for
simultaneous live, monitoring and high resolution
recording
• Power over Ethernet (PoE) IEEE 802.3AF.
• Support MDI/MDI-X auto crossover function
• Equipped with Smart Event Wizard for Motion
Detection, Schedule, and Alarm recording to PC or
SD Card
• Email notification or FTP video upload upon motion
detection and alarm
• Built-in SD memory card slot for local storage and
support SD High Capacity
• Manage AGC, BLC, FL, ES, H-Mirror, IRIS Level and
Day/Night via web browser
• Two way audio
• Built-in IEEE 802.11b/g for wireless module
(EAN800AW)
CAMERA
Pickup Device
Picture Elements
Sensitivity
Day & Night
Lens Type
Video Output
Video Output Resolution
1/3” Sony Super HAD Interlaced CCD
NTSC: 768 x 494/PAL: 752 x 582
0.4Lux/F=1.2
Yes
Optional C/CS mount, manual/DD control supported
BNC socket, composite 1Vp-p/75Ω
520TVL
VIDEO STREAMING
Compression Format
Max. Video Resolution
Video Quality
Frame Rate
H.264/MPEG-4/M-JPEG
4CIF, VGA, CIF, QVGA, QCIF
8 levels (adjustable)
Up to 30fps
AUDIO
Microphone
Operation Mode
Built-in*
Two-way audio
NETWORK
Interface
10Base-TX auto-negotiation, RJ-45 socket Support MDI/MDI-X auto
Supported Protocols
Built-in IEEE 802.11b/g WLAN (EAN800AW) HTTP, TCP/IP, UDP, RTP,
crossover function
RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Bandwidth Control
Max. Client Limit
Min. 64 kbps adjustable
32 clients simultaneously (max).
TERMINAL I/O
Alarm Input/Output
RS-485
1/1
Rs-485 interface half-duplex
EVENT MANAGEMENT
Dimensions
Event Trigger
Alarm Input, Manual Trigger,
Motion Detection and Schedule Recording
Notification
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre-and Post-alarm Buffer
48MB RAM reserved for pre-alarm record up to 120 sec.
LOCAL STORAGE
68mm/2.7”
SD Card
21mm/0.8”
136mm/5.4”
Supports SDHC Host Specification
Power Source
10mm/0.4”
57mm/2.2”
PoE
1.3 Megapixel Network Camera
Power Consumption
12VDC & PoE
Yes (PoE 802.3af 48 VDC)
EAN800A: 5W max. (12VDC) EAN800AW: 6.5W max. (12VDC)
PHYSICAL
Weight
Dimensions (W x H x D)
550g/1.102 lbs.
68 x 57 x 136mm 2.7" x 2.2" x 5.4"
with BNC socket: 68 x 57 x 146mm/2.7" x 2.2" x 5.7"
with Antenna: 68 x 125 x 167mm/2.7" x 4.9" x 6.6"
ENVIRONMENTAL
Operating Temperature
0°C~40°C/32°F~104°F
Humidity
< 90% not condensing
Certificates
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Secure Disk physical layer specification version 2.0
POWER
13mm/0.5”
7mm/0.3”
82mm/3.2”
124.7mm/4.9”
167mm/6.6”
CE, FCC, UL
* All product specifications are subject to change without notice
101
IP Surveillance EPN Series IP Speed Dome Cameras
EPN IP Speed Dome Series
520TVL/530TVL, 30x/36x Optical Zoom,
Auto Tracking, High Speed Pan & Tilt,
Network Speed Dome Camera
Series
Nevio Series IP PTZ Cameras
Outdoor
Features
Indoor
Specifications
• Support smart auto tracking functions
• Built-in H.264/MPEG-4/MJPEG digital signal output
at 4 CIF image size with up to 30fps
• H.264/MPEG-4/MJPEG multi stream output for
simultaneous live monitoring and high resolution
recording
• Support 3 independent video streams that can
provide different compression formats and
resolutions
• Support MDI/MDI-X auto crossover function
• Bandwidth control: 64k/128k/256k/1M/2M/4M/8M
bps and unlimited
• Built-in network interface (10Base-T/100Base-TX)
for remote monitoring by PC
• Smart Wizard settings for various event and
schedule recording conditions
• One-click easy installation
• Built-in 30x/36x optical AF zoom camera
• True Day/Night function with removable IR cut filter
• Low luminance for better image quality at night
• Smart alarm reaction & resume after alarm
• Enhanced auto-resume & power-up function
• Digital Flip function
Product Model
EPN3100
EPN3100i
EPN3600
EPN3600i
(Outdoor)
(Indoor)
(Outdoor)
(Indoor)
CAMERA
1/4" Sony CCD
Pickup Device
NTSC/PAL
Scanning System
NTSC: 525TVL, 60 fields/sec ; PAL: 625TVL, 50 fields/sec.
Picture Elements
NTSC: 768 x 494 ; PAL: 752 x 582
520TVL
530TVL
Normal: 0.4 Lux/F1.6
Normal: 1.4 Lux/1/60(1/50)seс
Horizontal Resolution
Min. Illumination
Night Mode: 0.08 Lux/F1.6
Night Mode: 0.01 Lux/1/4 (1/3)seс
(ICR ON)
(ICR ON)
50dB
50dB
128x~1/60 (1/50)~
1~ 1/10,000 (s)
S/N Ratio (AGC OFF)
Electronic Shutter
1/120,000 (s) (NTSC)
128x
Digital Slow Shutter
Shutter Selection
60x (50x for PAL)
AUTO ; A.FLK ; Manual
AUTO ; A.FLK ;
128x~1/60 (1/50)~1/120,000
Manual 1~1/10,000 selectable
selectable
Lens Type
30x optical zoom, f=3.3mm
36x optical zoom, f=3.4mm
(wide)~99mm (tele), F1.6~F3.2
(wide)~122.4mm (tele), F1.6~F4.5
240x max
432x max
(30x Optical and 8x Digital zoom)
(36x Optical and 12x Digital zoom)
Zoom Ratio
VIDEO
Picture Compression
H.264/MPEG-4/M-JPEG
Picture Resolution
Dimensions
1/4" Sony Ex-View HAD CCD
Video Format
4CIF, VGA, CIF, QVGA, QCIF
NTSC: 720 x 480, 640 x 480, 352 x 40, 320 x 240, 176 x 144 ;
PAL: 720 x 576, 640 x 480, 352 x 288, 352 x 288, 176 x 144
Streaming Frame Rate
Focus Control
Indoor Model
Outdoor Model
230 mm / 9.1”
280 mm / 11”
159 mm / 6.3”
Iris Control
1~30 IPS (NTSC), 1~25 IPS (PAL) adjustable
One Push/Auto/Manual
Auto/Manual
True Day & Night
Certificates
Yes (Auto/DAY/NIGHT)
CE, FCC, UL
Software Partners:
180 mm / 7.1”
102
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
NVR Software Integrated Network & DVR Management Software
ENVR-F16S/F32S
EverFocus Integrated Network Managing &
Recording Solution
NEW
Embedded with all EverFocus IP & DVR series!
• Support Everfocus full series IP devices (video server, IP camera, IP
speed dome) and DVR
• Support Mega-Pixel camera
• Support MJPEG, MPEG-4 and H.264
• Open standard IP camera protocol PSIA and ONVIF
• Max. 256 Client Access
• Web browser based
• Support Window XP, Window Vista and Window 7
• Support OS: Microsoft Windows XP Professional SP2 and Microsoft
Windows Vista SP2
• Support web browser: Internet Explorer 6, Internet Explorer 7 and
Internet Explorer 8
• Support multiple HDD/Partition storage
• Device management–Auto discovery support (uPnP, ZeroConf)
• Flexible live view control–Streaming: HTTP push+RTSP
• Standards-based, open-architecture technology, running on nonproprietary hardware Integration
• User, device, event setting and emergency contact lists support sort
ascending and descending
Live Video View
• Support 16ch devices live view
• User selectable system predefined split screen modes: 1, 2x2, 1+5, 3+4,
1+7, 3x3, 2+8, 4x4, 1+21, 5x5, 6x6, sequence 12, sequence 20 (ENVRF32S)
• User selectable system predefined split screen modes: 1, 2x2, 1+5, 3+4,
1+7, 3x3, 2+8, 4x4, sequence 13 (ENVR-F16S)
• Map Layout shows the map and video of devices on the map at the same
layout
• Configurable view layout and display presets for custom split screens with
assigned channels
• Device tree and layout view tree with filtered live videos
• PTZ control with EKB200 joystick/keyboard, including control of presets,
auto-pan, patterns, tours and auto-tracking
• Device drag and drop function on layout setting
• Full screen, instant snapshot and instant recording
• Support two-way audio
• Support remote viewing
• Video title bar and device tree with instant device status icon show device
recording, motion and event
NVR Software
Overview
Live Monitor and Virtual Matrix
•
•
•
•
•
•
Multi-monitor support video virtual matrix via display terminal setting
Unlimited number of display terminal
Multiple monitors to display separate live video
View real-time alarms and alarm history
Click real-time alarms list show recording playback
Click IP device to show live view
Accounts
•
•
•
•
Basic user profile with login, password and contact details
Unlimited number of user accounts
Support user authentication and permission
Support user grouping. One user can be assigned to one group and
inherit the privileges of the group
• User privileges can be restricted by device, E-map and virtually any
function
• Forgot password protection
E-Map
•
•
•
•
•
•
•
Google map support (Geographic map)
Unlimited number of E-map
Drag and drop DVR and IP devices
Child-map region and Home
Camera direction, shoot angle and shoot distance configuration
Bring out Max. 7 x live view with adjustable window size
Max. 4 map Level (including google map)
Events and Event Handler
•
•
•
•
•
•
•
•
•
•
Event logging within the database
Support for automatic execution of actions in response to events
Configurable device triggers-digital input, motion etc
Configurable pre-alarm, post-alarm and retrigger interval
Play sound and trigger output
Events can be sent to multiple recipients
Flexible emergency contacts setting in charge of multiple devices
Send E-mail notification with snapshot
Send snapshot to FTP server
PTZ Automation: configure actions execution upon events
*Performance varies depending on equipments used and subject to actual test result.
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
103
NVR Software Integrated Network & DVR Management Software
ENVR-F16S/F32S
EverFocus Integrated Network Managing &
Recording Solution
NEW
Embedded with all EverFocus IP & DVR series!
NVR Software
Schedule
• Recording by daily, weekly, special date
• Express schedule, apply to date and schedule copy
• Support multiple recording modes: manual, continues, motion-based
and event-based
• Recording, Tour, Alert trigger and Motion Scheduling
• Advanced schedule setting with 10 types of days and 10 timezones
per day
Minimum System requirements
•
•
•
•
•
•
Intel Pentium4 531 3.0 GHz, 1 MB Cache, 800 MHz FSB
1.0 GB of RAM
Graphics card with 256 MB memory or better
10 GB of free hard disk space or more
1024 x 768 or higher screen resolution
10/100/1000 Ethernet Network adapter
Playback and Search
Recommended System requirements
• Max. 32 channel concurrent video and audio playback Support
synchronized playback
• Searching can be queried based on channel ; date/time ; event type
and navigation search
• Several playback speeds in fast forward and fast reverse playback
• The graphic time-bar provides a visual indication of the current
frame’s time and position
• The graphic time-bar provides video jump-to-time navigation
capabilities
• Support video archive
a) When more than 4 DVRs or IP devices are enabled in live view and
playback mode together, it is recommended that the client PC meets below
system requirements for optimal performance.
•
Intel Core2 Duo E7400 2.8 GHz or higher, 3 MB Cache,
1066 MHz FSB
•
2.0 GB of RAM
•
Graphics card with 512 MB memory or better
•
10 GB of free hard disk space or more
•
1024 x 768 or higher screen resolution
•
10/100/1000 Ethernet Network adapter
PTZ Control Panel
b) When more than 16 DVRs or IP devices are enabled in live view and
playback mode together, it is recommended that the client PC meets below
system requirements for optimal performance.
•
Intel Core2 Quad Q9400 2.66 GHz or higher, 6 MB Cache,
1333 MHz FSB
•
4.0 GB of RAM
•
Graphics card with 1 GB memory or better
•
10 GB of free hard disk space or more
•
1024 x 768 or higher screen resolution
•
10/100/1000 Ethernet Network adapter
•
•
•
•
Basic PTZ, Iris and Focus function
Navigation and Click-and-Go
Pattern/Tour/Auto Pan/Preset
Auto-tracking/Tour-and-Tracking/AutoPan-and-Tracking
Maintenance
• Support database backup and restore
• Scheduling remote replication by date, week and month
Log Information
• Support system log searching by time and log type
• Show system Information
*Performance varies depending on equipments used and subject to actual test result.
104
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
NVR Software Network Management Software
NVR Software
NVR Surveillance Management Software
NVR Software
Web Live View/
Remote
Features
• Support EverFocus NeVio series IP cameras, megapixel
cameras, 3rd party video encoders/IP cameras and more
• Accepts MPEG4/MJPEG/H.264 video formats
• Remote PTZ operation and supports PTZ reaction presets
• Multiple monitor display with up to 64 cameras in Live View
and up to 16 cameras in Playback View
• Local view with 1 or (optional) 2 monitors for Live View plus
(optional) 1 monitor dedicated for simultaneous Playback
View
• Remote Live View with 1 or (optional) 2 monitors (or 1
monitor for Playback View only)
• Smart detection of many types of camera, input, POS and
system events, with 10 potential instant alarm responses
(example, email alert and E-map popup)
• Complete I/O device integration
• Intelligent playback system with 5 video analytic searches
• Remote client live viewer, playback, backup, I/O control and
remote desktop operation
• Joystick support on PTZ cameras and software enabled
digital PTZ function are both available
• Preset points and patrol functions are also available on
many camera models
• User friendly graphical user interface (GUI) with camera
drag and drop for setup and recording, familiar to all users
with basic PC knowledge
• Audio and video recording synchronization
• Watermark capability
• Resource Management tool can monitor system resources
and trigger instant alarm notifications
• DDNS functionality
• 3 GPP/PDA/Mobile Handy Viewer support
• Remote I/O control
• Video enhancement tools t fine tune the image’s visibility,
sharpness, brightness, contrast or even grey scale
• Export to AVI or ASF file format
• Take a snapshot of the recording in BMP or JPEG format to
print or file
• Back up video images to USB drives, CD/DVD or hard disk
drives
• Schedule recording can be set by day, week or repeating
interval
• Intelligent Search recognizes 5 different special events
(general motion, missing object, foreign object, camera
occlusion and signal lost) in recorded files, in addition to
searches by date, time and log file
• Counting application with direction for certain objects or
areas
• Bit rate display for overall usage and per camera stream
helps manage bandwidth utilization
• Unusual events are recorded to the system log, and
counting application results can be exported to an Excel or
text for analysis
Specifications
IP Camera Inputs*
Up to 64 (depending on licenses purchased)
*Models vary. Contact EverFocus for exact list of supported models
IP Cameras Supported
EverFocus NeVio and other IP cameras in addition to 3rd party video
encoders and IP cameras
Digital PTZ
Supported in live view and playback
Multiple View
Zoom function preserves live view by duplicating the same video feed
onto multiple channels in different areas
Triple Monitor
Up to 64 love camera views each on two monitors in addition to
displaying playback video on a separate monitor
Audio Recording
Synchronized with video on each channel
Screen Layout
Single, 6,10 &13 plus NxN up to 64 cameras (16 on playback)
Compression Format
H.264/MPEG4/M-JPEG SUPPORTED
Recording Type
Continuous, digital input trigger, on motion detection, on event manual
and per schedule
Playback Channels
Up to 16 channels max. displayed
Playback Control
Forward/reverse step and play fast (to 16x) and slow (to 1/16x)
Auto Overwrite
Oldest recordings recycled when disk is full
Additional I/O Functions
Optional expansion module
POP Input
Optional POS interface serial data to Ethernet
Supported Language
Chinese (Simplified & Traditional), Czech, Danish, English, Farsi,
Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese,
Korean, Portuguese (Brazil), Portuguese (Portugal), Russian, Slovak,
Spanish
*Performance varies depending on equipments used and subject to actual test result.
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
105
IP Accessories H.264 Video Encoder
EVS200A/EVS200AW
2 Channels H.264 Video Encoder
Series
IP Accessories
Software Partners:
Features
Specifications
• High quality H.264, MPEG-4 and MJPEG multi
stream output at 4CIF resolution @60fps
• H.264/MPEG4/MJPEG dual stream output per
channel for simultaneous live monitoring and high
resolution recording
• Smart wizard settings for varied event and schedule
recording
• Support PTZ control
• Built-in SD memory card slot for local storage and
support SDHC
• Two-way audio
• Power over Ethernet (PoE) IEEE 802.3af.
• Ultra-compact size for space-saving applications
Specifications
Video Compression
Video Reslolution
Video Quality
H.264/MPEG-4/M-JPEG
4CIF, VGA, CIF, QVGA, QCIF
8 levels adjustable
Frame Rate
Up to 30fps
Video Source
2 BNC composite, 1Vp-p/75ohm NTSC/PAL auto-sense
AUDIO
Compression Method
Operation Mode
IMA ADPCM (Pulse Code Modulation)
2 way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation,
Supported Protocols
RJ-45 socket Support MDI/MDI-X auto crossover function
HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS, NTP
Bandwidth Control
Min. 64 kbps adjustable,
Max. Client Limit
32 simultaneous clients
WIRELESS (EVS200AW)
Standard
IEEE 802.11b/g
Antenna Gain
2 dBi
TERMINAL I/O
Alarm I/O
2/2
Serial Connector
RS485
EVENT MANAGEMENT
Event Triggered
Dimensions
Alarm input, Manual trigger, Motion detection and Schedule recording
Notification
Trigger alarm output, Send mail notification, Upload video to FTP,
Pre-and Post-Alarm Butter
Record video to SD card, Record video to PC and Network alarm
48MB RAM reserved for pre-alarm record up to 120 sec
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
POWER
Power Supply
12 VDC
Power over Ethernet
Yes (PoE 802.3af)
Power Consumption
4.5w max. (12VDC)
Certificates
106
* All product specifications are subject to change without notice
CE, FCC
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
IP Accessories H.264 Video Server
ERS-4
4 Channels H.264 Video Server with
Recording Capability
IP Accessories
FREE
DDNS
Features
Specifications
• H.264 Compression technology
• Real-time recording and streaming at 2CIF
resolution for all cameras and total 50 IPS (PAL)/60
IPS (NTSC) under D1 resolution
• Dual stream for 3GPP mobile phones
• Integrated free EverFocus DDNS service, no DDNS
setup PC required
• Bidirectional audio channel with recording
• Support 1 internal 3.5" SATA HDD
• Express Setup-configuration of major parameters on
a single menu page
• Complete setup can be accomplished via network
• Easy remote IP configuration with EverFocus IP
Utility tool
• Alternative setup option with local monitor and USB
mouse
• RS-485 interface for PTZ control
• 4 alarm inputs, 1 alarm output relay
• Local monitor output for live view (full screen, 4x
screen, sequence) and setup
PHYSICAL
Recording Rate/Resolution
704 x 576: 50 IPS PAL/60 IPS NTSC
Playback and Streaming
352 x 288: up to 100 IPS PAL/120 IPS NTSC
Rate/Resolution
704 x 288: up to 100 IPS PAL/120 IPS NTSC
704 x 576: up to 50 IPS PAL/60 IPS NTSC
depending on network conditions
Video Input
Monitor Output
4 x 1 Vpp FBAS, BNC, 75ohm termination
1 x 1 Vpp FBAS, BNC at 75 Ohm
1 x VGA ( resolution 800x600@60 Hz)
Audio Input/Output
Input: 1 x Line In, 1V max. /1Kohm, RCA socket
Output: 1 x Line Out 1V max. 1Kohm, RCA socket
Alarm In
Alarm Out
RS-485
Network Interface
USB
4 x N.O./N.C., screw terminal connector
1 x relay out N.O./N.C., screw terminal connector
1x, screw terminal connector
100 BASE-T, 8P8C/RJ45 socket
1x USB 2.0 on Back Panel (for USB-Mouse)
1x USB 2.0 on Front Panel (for service purpose)
Status LED
Clock
Power Source
Power, Alarm, HDD activity, Network traffic
Internal Real Time Clock, NTP synchronisation option
12VDC with external power supply 100~240 VAC ; 50/60 Hz
Dimensions (W x D x H)
320 x 208.9 x 54.3 mm/12.6" x 8.2" x 2.1"
Temperature
0°C~40°C/32°F~104°F (20~80% humidity)
FUNCTIONAL
Dimensions
OS
Video Compression
User Interface
Operation
Front View
50.2 mm / 2”
320 mm / 12.6”
54.3 mm / 2.1”
352 x 288: 100 IPS PAL/120 IPS NTSC
704 x 288: 100 IPS PAL/120 IPS NTSC
Simultaneous network live/playback operation and local recording
Manual, Schedule and Event
Playback Search
By Date/Time or Event
Video Pause
Yes
Video Loss Detection
Yes
Motion Detection
Yes
Schedule Setting
User Access
208.9 mm / 8.2”
2.4 mm/0.09”
H.264
GUI (Graphical User Interface)
Recording Mode
Event Log
PTZ Protocols
Side View
Embedded Linux
Certificates
Yes
Support Express and Advanced Schedule Setting
3 Levels of User Access Support
EverFocus, Pelco-D, Pelco-P, Samsung El., Transparent
CE, FCC
11 mm/0.4”
4.3 mm/0.2”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
* All product specifications are subject to change without notice
107
IP Accessories Network Video Recorder Server
NVR Pro
NEW
Professional Network Video Recorder Server
IP Accessories
Working
Temperature
0°C~45°C
3-Years
RAID5
warranty
Features
Specifications
• Support ENVR-F16S, ECMS-DVR, PowerCon 4 series
and NVR Software
• Industrial grade NVR designed
• Gigabit LAN
• Dual-monitor support with one VGA, one DVI-I, one
D-SUB and one HDMI port
• HDA with two-way audio
• 4 x USB2.0, 1 x RS232
• Internal 5 x 3.5" SATA HDD with RAID 0, RAID 1,
RAID 0+1 and RAID 5
• 2U Height Rackmount Chassis
• Windows XP embedded
• 3-years warranty
Video Compression
H.264, MPEG4, MJPEG
Supported Number
64 channels
of Channels
Storage Capacity
Ethernet
10TB
Two Gigabit Ethernet
Display
1x VGA port
1x DVI-I / 1x D-SUB / 1x HDMI port
4* USB2.0
USB
Serial Port
1* RS232
Audio
HDA with Mic-in/Line in/Line out port
Storage
Internal 3.5” *5pcs
Power Input
AC110V~264V
Chassis Construction
Indicators
Heavy duty metal
Power, HDD, LAN
OS
Windows XP embedded
Operating Temperature
0ºC to 45ºC (10%~90% humidity)
Storage Temperature
-20ºC to 70ºC (5%~95% humidity)
Dimension (DxWxH)
483x88x501 (mm)
Colour
Black
Weight
12.0kg / 26.5 lbs
Mounting
EMC/Safety
Rack mount
FCC class B, CE
Dimensions
Right View
Front in-side View
108
Rear out-side View
Front out-side View
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* Lens models and availability vary in different regions
Accessories
* All product specifications are subject to change without notice
109
Accessories Control Keyboards
EKB500
Multi-Function Control Keyboard
RS232
Yes
RS485
Yes
DVR
Device
Control
PTZ
ACS
Device
Control
Cascade
Device
Control
Up to 8
Keyboards
Accessories
Features
LCD
Display
20x2
characters
Specifications
• Capable of controlling speed dome cameras, DVRs,
and monitors
• Centralized control of up to 999 cameras from a
single controller
• Password protected to prevent unauthorized users
• 3-D Joystick for PTZ control functions and Jog
Shuttle for DVR control
• Two independent communication prots with
selectble baud rate and protocol
• Customized, upgradeable firmware for specific
applications
• Auto tracking by external signal processor unit
• Preset position and pattern control ; full
programmable preset tour
• Matrix control (EverFocus DVR series products)
12VDC
Power Source
10W
Power Consumption
PTZ Speed Domes, DVRs and Monitors
Device Control
Pelco-D, Pelco-P, EverFocus Enhanced Protocols
Protocols
Remote Control
RS-232/RS-485
Baud Rate
1200-38400 dps
LCD Display
20 x 2 Characters
Integration
Up to 8 keyboard cascading connection
Position, Tour, Auto Pan
Auto Surveillance
Yes
Wiring Box
Approx. 356 x 203 x 108mm/14" x 8" x 4.25"
Dimensions (L x W x H)
Approx. 1.5kg/3.3lb
Weight
System Examples
1
2
EPTZ
EPTZ
Camera
EKB500
RS485
EverFocus DVR Series
RS485
85
5
EverFocus
s DV
D
DVR
VR Series
Se
Serie
ries
ri
ie
ies
ie
es
s
110
* All product specifications are subject to change without notice
Color Monitor
EKB500
Color Monitor
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories Control Keyboards
EKB200
USB Control Keyboard with 3-Axis
USB
3-Axis
Interface
Joystick
Plug & Play
PTZ
Control
USB Power
HID
Standard
HID Class
4 PTZ
Keys
Iris +/Focus +/-
12
Free Keys
JoyMap
Programmable
Switches
Keymapper
Software
Specifications
• “Plug and play” USB interface
• 3-axis joystick for PTZ control function
• Support standard HID class device with high
compatibility
• Industrial ID design
• Long working life of industrial grade 3-axis joystick
• 4 pre-defined PTZ function keys: Iris+/-, Focus+/• 12 free assignable function keys
• Panel mount kit available
• No external power supply required
• Suitable for right or left-handed users
• Dedicated EverFocus JoyMap keymapper software
for standard Windows operation
• Support standard HID class device, easy for 3rd
party integration
• Supported by EverFocus PowerCon central
management software for easy PTZ operation
Interface
USB 1.1
PTZ Function Key
4 keys, Iris+, Iris-, Focus+, Focus-
Assignable key
12 keys
Default Protocol
USB HID class
Keymapper Support
EverFocus JoyMap
USB Cable (Length)
1.8m/6ft
USB Cable (Colour)
Black
Dimension (W × D × H)
200.5 × 200.5 × 111.3mm/7.9” ×7.9” x 4.4” (with Joystick)
Weight
800g/1.94 lbs
Operating Temperature
0˚C~50˚C/32˚F~122˚F
Mounting Method
Desktop, Panel
Power Source
USB Bus Power
Power Consumption
80mA max.
Certification
CE, FCC class A
System Examples
111.3mm/4.4”
58mm/2.3”
3mm/0.1”
Dimensions
7.9mm/0.3”
Accessories
Features
USB
EKB200
Industrial USB Controller
Keyboard with 3-Axis Joystick
PowerCon
130.6mm/5.2”
135.9mm/5.4”
200.5mm/7.9”
EVS100/400
Video Server
200.5mm/7.9”
200.5mm/7.9”
DVR
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
IP Cameras
Analog Cameras
EKB200 Control Line: USB
Internet Cable
Video Line
RS485
EQ550 Speed Dome
Camera
* All product specifications are subject to change without notice
111
Accessories Storage Expansion & Hard Drive Reader
Accessories
EDA450
EPR110
EverFocus SATA Bay Storage Expansion
EverFocus Hard Drive Reader
Features
Features
• 1U 19" form factor
• Supports SATA I and SATA II hard drive, with up to
2TB per hard drive
• Power and each HDD status LED
• Configure as individual SATA drive
• Four 3.5" drive bays
• SATA II compliant, 1.5 Gb/s and 3 Gb/s
• Platform independent—works with Windows or
Linux computers with compatible SATA controller
Operations
1/4/9/16 multi-channel playback
Playback forward/backward at 0.1~16x speed
Audio playback for 1~60FPS recordings (MPEG4 4CH/8CH/16CH
will not support audio function)
Pause
Step forward/backward
Jump to beginning or end of a segment
Search
Search video by segment list, date/time and alarm list
Slide bar to move video pointer
Display current video date/time
Save still image to BMP or JPEG file
Print still image
Archive
Save video to Motion JPEG AVI file up to 4GB
Save disk raw data into proprietary file
Save meta-data to text or binary file
Length limitation depends on various PC hardware, disk and OS
configurations
Specifications
Specifications
Form Factor
1U 19’’
Supported Products
HDD Bays
4 x 3.5"
Light Indication
Maximum Capacity
Host Interface & Transfer Rate
Drive Interface
Cooling Fan
Power Supply
Status Indicators
Dimensions (W x D x H)
Weight
Certifications
8TB
eSATA (3Gb/s)
SATA I & SATA II
x2
150W x 1 (AC100~240V)
Lock
Power Switch
Interface Connector
Power Connector
Operations
Paragon and Paragon264 Series DVRs
2 LEDs for power and disk activity
HDD tray lock
Power On/Off
USB type B connector
6 pin 5V/12VDC
1, 4, 6, 9, or 16 multi-channel playback
4 LEDs for HDD, Power LED
Playback forward/backward at 0.1~16x speed ;
19" x 15" x 1.7"
Pause ; Step forward/backward ; Jump to beginning or
12 lbs
CE, FCC
end of entire drive
Search
Search video by segment list, date/time, alarm list
Slide bar to move video pointer, display current
video date/time
Archive
Save still image to BMP or JPEG file, save video to
AVI file, save disk raw data into proprietary file,
save meta-data to text or binary file
Power Consumption
Dimension (L x W x H)
Weight
112
* All product specifications are subject to change without notice
1.5 amp
276.9 x 154.9 x 45.7 mm/10.9” x 6.1” x 1.8”
2.3 kg/5 lbs
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories CCTV Lenses
CCTV Lens
Specifications
EFV-0616DC
Auto Iris & Vari-focal Lens
Product Model
EFV-2814DC
EFV-358
EFV-358DC
EFV-416
EFV-416DC
EFV-550
EFV-550DC
EFV-0614DC
Description
Vari-focal 2.8~12mm auto iris
Vari-focal 3.8~8mm auto iris
Vari-focal 3.8~8mm auto iris
Vari-focal 4~16mm manual iris
Vari-focal 4~16mm auto iris
Vari-focal 5~50mm manual iris
Vari-focal 5~50mm auto iris
EFV-3010DC
FL-3620
Fixed Iris & Mini Board Lens
Product Model
FL-2520
FL3620
FL-4320
FL-6020
FL-8020
FL-1220
FL-1620
FL-4320
FL-8020
Description
2.5mm Lens
3.6mm Lens
4.3mm Lens
6mm Lens
8mm Lens
12mm Lens
16mm Lens
Accessories
Lens Term & Features
C-mount:
Standard for CCTV lens screw mounting. It is defined with the thread of 1" (25.4mm) in diameter and 32 threads/inch, and the back
flange-to CCD distance of 17.526mm (0.69") The C-mount description applies to both lenses and cameras. C-mount lenses can be put
on both C-mount and CS-mount cameras, an adaptor is required for the latter version only.
CS-mount:
Newer standard for lens mounting. It uses the same physical thread as the C-mount, but the back flange-to-CCD distance is reduced to
12.5mm, in order to have the lenses made smaller, more compact and less expensive, CS-mount lenses can only be used on CS-mount
cameras.
CS-to C-mount Adaptor:
An adaptor used to convert a CS-mount camera to C-mount to accommodate a C-mount lens. The EQ-120/150/250/350 Series Cameras
are equipped with a wide range backfocal mechanism, the adaptor ring is not required.
DC Iris Control:
The lens iris mechanism is controlled by a DC voltage, which is generated depending on the video signal level in the camera.
Sensor Format:
Physical size of the camera CCD chip. The most common chip sizes in CCTV industry are 1/3" abd 1/4" cameras, but not for 1/2"
cameras.
Horizontal Field of View for 1/3" Cameras
f (mm)
2.8
3.5
3.6
4.3
5
8
10
15
50
Hor. angle of view (°)
81
69
67
58
51
33
27
18
5.5
2
3.4
2.7
2.7
2.2
1.9
1.2
1.0
0.6
0.2
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
5
8.6
6.9
67
5.6
4.8
3.0
2.4
1.6
0.5
Horizontal Field of View (m)
Object Distance (m)
10
17.1
13.7
13.3
11.2
9.6
6.0
4.8
3.2
1.0
20
34.3
27.4
26.7
22.3
19.2
12.0
9.6
6.4
1.9
* All product specifications are subject to change without notice
113
Accessories LED Monitors
FH17LED/FH19LED
NEW
17", 19" Professional LED CCTV Monitors
Accessories
Features:
•
•
•
•
Longer Lifetime
Higher Contrast and Black Level
More Balanced Colour Saturation
Lower Failure Rate
• Lower Temperature
• Better Operation Efficiency - 40%
Less Power Consumption
• Environmental Friendly
Specifications
Model No.
FH17LED
FH19LED
Display
Screen Size
17"
19"
Max Resolution
1280x1024
Brightness
300cd/m²
Pixel Type
Active Matrix TFT
Pixel Pitch
0.264(H) x 0.264(V)
Display Colour
0.294(H) x 0.294(V)
16.7 Million
Backlit
LED
Contrast Ratio
10000:1
Aspect Ratio
4:3
Viewing Angle (H/V)
170º/ 160º
Response Time
5ms
Video System
NTSC/PAL
Interface
Video In/Out (BNC Type)
2/2
VGA In/Out (15Pin D-Sub)
1
HDMI In
1
Audio In/Out (RCA Type)
1/1
PC Stereo In
1
Audio
Built In speaker
Yes (2.5W x 2 )
Special Features
3D Comb Filter
YES
3D De-Interlace
YES
Multi-Language
English, German, French, Italian, Spanish, Russia, Turkish, Japanese, Polish
Key Lock Function
Optional
Dimension
Net (WxHxD)
375x420x190(mm)
420x420x190(mm)
Packing(WxHxD)(1pcs/Box)
Weight
500x160x570(mm)
N.W.: 3.17kgs G.W.: 4.7kgs
N.W.: 3.22kgs G.W.: 4.74kgs
Cabinet
Finish/Tilt Stand
Black/Yes
Mount
Visa Mounts Size
75mm/100mm compatible
Wall
Optional
Ceiling
Optional
Rack
Optional
Power
Electrical Ratings
Consumption < On
Regulations
114
* All product specifications are subject to change without notice
DC12V ( AC100~240 [50 / 60])
20W Max
25W Max
UL/CUL, FCC-DOC, CE, RoHS
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories LCD Monitors
FH-7515E
FH-7517E
FH-7519E
15", 17", 19" Professional LCD CCTV Monitors
Accessories
Features
• 2 x BNC Composite Video Input
• Integrated 3D noise reduction filter
• 2 x BNC Composite Video Output
• Easy multi-language OSD setup
• 1 x HDMI Input
• Picture size and - position setup also for all video
• 1 x VGA Input
input types
• 2 x Audio Input, build in speakers
• Newest power management technology
• Newest 4D-Comb-Filter with De-Interlace technology for
• VESA compatible mount (75mm)
clear colour transitions and suppression of cross colours
Specifications
Model
Diagonal Size
Active Area (mm)
Display Resolution
Pixel Pitch (mm)
Brightness
Contrast Ratio
Response Time (Tr/Tf)
FH-7515E
FH-7517E
15"
17"
19"
304.1(H) x 228.1(V)
337.9(H) x 270.3(V)
376.3(H) x 301.06(V)
1024 x 760
1280 x 1204
1280 x 1024
0.297 x 0.297
0.264 x 0.264
0.294 x 0.294
260 cd/m²
300 cd/m²
300 cd/m²
700:1
800:1
800:1
8ms
5ms
5ms
Resolution
SXGA
System
PAL/NTSC
Display Mode
Video1/ Video2/ PC/ HDMI
Viewing Angle
Vertical: -80º~80º,
Temperature
Horizontal: -80º~80º
Operation: 5ºC~40ºC,
Composite Input
Storage: -10ºC~60ºC
BNC x 2, RCA x 2, VGA x 1, PC Audio x 1, HDMI x 1
Composite Output
BNC x 2
Voltage Input
100~240 V, 50/60 Hz
Power Consumption
40W
Standby Power Consumption
3.4W
AC power
Dimension (W x H x D)
Net Weight
FH-7519E
AC 100~240V, 50/60 Hz
370 x 355 x 170mm
420 x 420 x 220mm
430 x 415 x 220mm
3 KG
5.5 KG
6 KG
Cerficates
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
FCC, CE, RoHS
* All product specifications are subject to change without notice
115
Accessories LCD Monitors
FH-7522E
22" Professional Widescreen LCD CCTV Monitors
NEW
Accessories
Features
• 2 x BNC Composite Video Input
• Integrated 3D noise reduction filter
• 2 x BNC Composite Video Output
• Easy multi-language OSD setup
• 1 x HDMI Input
• Picture size and - position setup also for all video
• 1 x VGA Input
input types
• 2 x Audio Input, build in speakers
• Newest power management technology
• Newest 4D-Comb-Filter with De-Interlace technology for
• VESA compatible mount (75mm)
clear colour transitions and suppression of crosscolours
Specifications
Diagonal Size
Active Area (mm)
Display Resolution
Pixel Pitch (mm)
Brightness
Contrast Ratio
1680 x 1050
0.282 x 0.282
300 cd/m²
1000:1
Response Time (Tr/Tf)
5 ms
Resolution
WXGA
System
Display Mode
Viewing Angle
Temperature Operation
Composite Input
Composite Output
Voltage Input
Power Consumption
Standby Power Consumption
AC Power
Dimension (W x H x D)
116
22"
437.6(H) x 296.1(V)
PAL/NTSC
Video1/ Video2/ PC/ HDMI
Vertical: -80º~80º,
Operation: 5ºC~40ºC,
Horizontal: -85º~85º
Storage: -10ºC~60ºC
BNC x 2, RCA x 2, VGA x 1, PC Audio x 1, HDMI x 1
BNC x 2
100~240 V, 50/60 Hz
40W Max. in "ON" Mode
2.5W x 2
AC 100~240V, 50/60 Hz
510 x 420 x 190 mm
Net Weight
7.0 kg
Certificates
FCC-DDC, UL/CUL, CE, ROHS
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories LCD Monitors
FH1080P42
42" Professional LCD CCTV Monitor
NEW
Accessories
Features
• 42" Professional Industrial Metal Case Design
• 1920 x 1080 Full HD High Resolution
• 3D Comb Filter High Quality Motion Adaptive
• 4H Comb Filter Adaptive for Best image Quality
Specifications
Diagonal Size
42"
Active Area (mm)
930.24(H) x 523.26(V)
Display Resolution
1920 x 1080 (Full HD)
Pixel Pitch (mm)
0.4845 x 0.4845
Brightness
500 cd/m²
Contrast Ratio
2500:1
Response Time (Tr/Tf)
6 ms
Viewing Angle
V: 178º,
Colour Depth
H: 178º
16.7 M colours
System
PAL/NTSC
Display Mode
Video1/ Video2/ PC/ HDMI
Temperature
Operation: 0ºC~40ºC, Storage: -10ºC~60ºC
Humidity
10%~90%
Horizontal Frequency
60KHz~73KHz
Veritcal Frequency
47Hz~63Hz
Power Consumption
240 W
Speaker
1.5 W x 2
AC Power
OSD Control
OSD Languages
AC 100~240V 50/60 Hz
Picture Mode, Contrast, Brightness, Colour, Tint, Sharpness, Colour Temp., DNR
English, German, French, Italian, Spanish, Russian, Turkish, Japanese, Polish
Remote Control
Wall Mount
Wall Mount Size
Dimension (W x H x D)
Yes
Yes (Optional)
300 x 200 mm
990 x 592 x 103 mm
Net Weight
28 KG
Accessories
Power code, Manual, VGA Cable, Remote control
Certificates
FCC, UL, CE, RoHS
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
117
Accessories LCD Monitors
EN7517HDMI
EN7519HDMI
17” and 19” HDMI CCTV Monitors
NEW
Accessories
Features
• High Resolution LCD Monitors (over 500 TVL)
• Multi-Language OSD and Built-In Speakers
• 1280 x 1024 Resolution (SXGA) panels
• UL Listed with FCC, CE, and CB, RoHS
• 3D Comb Filter, De-Interlace, Noise Reduction
• 50,000 Hour Rated Lifespan
• NTSC/PAL/SECAM Auto Detection
• Black Plastic Bezel with Metal Base
• Digital (HDMI) & Analog (RGB) Inputs
• Remote Control Included
• Looping BNC Input
• HDMI and VGA Cables Included
Specifications
Model No.
EN7517HDMI
EN7519HDMI
Resolution
1280 x 1024 (SXGA)
1280 x 1024 (SXGA)
Screen Scale
4:3 (HD)
4:3 (HD)
Active Area (mm² )
337.92 x 270.336
376.32 x 301.056
Viewing Lines
>500 lines (TVL)
>500 lines (TVL)
Pixel Pitch
0.264mm
0.294mm
Brightness
300 cd/m²
300 cd/m²
Contrast Ratio
800:1
Response Time
5ms
Viewing Angles
H: 170º V: 170º
3D Comb Filter
Yes
De-interlace
Yes
OSD
2 out of 9 language options
Display Colours
16.7 Million
Speakers
2 each (3 watts)
Video Inputs
HDMI, VGA, BNC, S-Video, RCA
Video Outputs
BNC (1 each)
Audio Inputs
RCA, PC
Audio Outputs
RCA
Mounting
75mm Vesa
Power Input
AC100-240V, 60/50Hz
Power Use
<45W, <2W (standby)
Desk Stand
Removable-Metal
Options
Accessories
118
Rack and wall mounts
VGA cord, Power Cord, and HDMI Cable
Packaging
580x515x165 (LxWxD)
518x465x165 (LxWxD)
Weight
7 kg net(9 kg in carton)
6 kg net(7.5 kg in carton)
Operating Temperature
5 ̊ C - 40 ̊ C
Certificates
CE, FCC, CB
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories LCD Monitors
EN1080P22
22" Full HD Widescreen CCTV Monitors
NEW
Accessories
Features
• High Resolution LCD Monitors (over 500 TVL)
• Multi-Language OSD and Built-In Speakers
• 1920x1080 (Full HD) Resolution on K10S22
• Digital (HDMI) & Analog (RGB) Inputs
• 1366x768 (720P) Resolution on K10S19
• CE Listed with FCC, and CB, RoHS
• 3D Comb Filter, De-Interlace, Noise Reduction
• 50,000 Hour Rated Lifespan
• NTSC/PAL Auto Detection
• Black Plastic Bezel with Removable Base
• Looping BNC Input
• HDMI and VGA Cables Included
Specifications
Resolution
Screen Scale
Active Area (mm² )
Viewing Lines
1920x1080
16:9 (HD)
476.64x268.11
>500 lines (TVL)
Pixel Pitch
0.264mm
Brightness
300cd/m²
Contrast Ratio
1000:1
Response Time
5 ms
Viewing Angles
H: 170º V: 160º
3D Comb Filter
Yes
De-interlace
OSD
Display Colours
Speakers
Video Inputs
Video Outputs
Audio Inputs
Mounting
Yes
2 out of 6 language options
16.7 Million
2 each (3 watts)
HDMI, VGA, BNC Looping, RCA
BNC (1 each)
RCA, PC
75mm Vesa
Power Input
AC100-240V, 60/50Hz
Power Use
<45W, <2W (standby)
Desk Stand
Options
Accessories
Packaging
Weight
Removable-Plastic
Rack and Wall Mounts
VGA Cord, Power Cord, and HDMI Cable
581x115x405 (LxDxW)
4.5 kg net(5.5 kg in carton)
Operating Temperature
5 ̊ C - 40 ̊ C
Certificates
CE, FCC, CB
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
119
Accessories LCD Monitors
EN768P26/EN768P32/EN1080P42
26”/ 32"/ 42” Full HD Widescreen CCTV Monitor
NEW
NEW
NEW
26"
32"
42"
Accessories
Features
• High Resolution (over 500 TVL)
• Multi-Language OSD and Built-In Speakers
• 1920x1080 (Full HD) Resolution (SVD420)
• Digital (HDMI) & Analog (RGB) Inputs
• 1366x768 (720P) Resolution (SVD260 & SVD320)
• Super Slim Design
• 3D Comb Filter, De-Interlace, Noise Reduction
• FCC, CE, and RoHs
• NTSC/PAL Auto Detection
• 50,000 Hour Rated Lifespan
• 2 Looping BNC Inputs
• Metal Case
• Remote Control Included
Specifications
Model No.
EN768P26
EN768P32
26”
32”
42”
1366x768
1366x768
1920x1080
Size
Resolution
Colours
16.7M
16.7M
16.7M
Viewing Angle
H: 170º V: 160º
H: 170º V: 170º
H: 170º V: 170º
Viewing Lines
600 TVL
600 TVL
600 TVL
Contrast Ratio
1000:1
1000:1
1000:1
Response Time
8ms
8ms
6ms
3D Comb Filter
Yes
Yes
Yes
3D Noise Reduction
Yes
Yes
Yes
450cd/m²
450cd/m²
550cd/m²
Brightness
PIP / POP
Yes
Yes
Yes
Speakers
2 each (5 watts)
2 each (5 watts)
2 each (8 watts)
Composite Inputs
BNC x 2, VGA, S-video x 1, HDMI x 1
Composite Outputs
BNC x 2
Audio
Input and Output
Auto Adjustment
Yes
Wall Hanging
VESA Standard
OSD Language
Power Use
English, Spanish, French, German, Italian, and Simplified Chinese
<120W AC100V~240V
<180W AC100V~240V
OSD Control
Yes
Yes
Yes
Remote Control
Yes
Yes
Yes
Accessories
Operating Temperature
Certificates
120
EN1080P42
* All product specifications are subject to change without notice
<220W AC100V~240V
Power Supply, VGA Cable, Remote Control, User’s Guide, and Audio Cable
5 ̊ C - 40 ̊ C
FCC-DOC, CE, RoHS
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories LCD Monitors, Housings and Brackets
EN200/EN220
Mounting Brackets
5.6" Colour TFT LCD Test Monitor &
Server Kit
BA01
BA10
BA11
BA-EHD
BA-ED
Specifications
Accessories
Dome Brackets
Product Model Description
BA-ED
EN200
Features
•
•
•
•
•
•
BA11
Ceiling mount bracket for EPD200 (300mm/12" long)
BA-EHD
5.6” LCD CCTV monitor
Small & compact for portability
Audio & Video Inputs
Built in speaker & Earphone Output
Input voltage 9-20VDC
12VDC adaptor included
BA-EDMS
Box Camera Brackets
EN220
Features
•
•
•
•
•
•
•
•
BA10
Plastic “L”style mounting bracket for ED series mini domes.
146.7 x 121 x 66mm/5.75" x 4.75" x 2.6" (L x W x H)
Aluminum “L” style mounting bracket for EHD series vandal
Domes. 169 x 146 x 110 mm/6.7" x 5.7" x 4.3" (L x W x H)
Aluminum “L” style mounting bracket for ED550, ED560,
EDN800. 169 × 146 × 110 mm/6.7" × 5.7" × 4.3" (L × W × H)
Ceiling mount bracket for EPD200 (624mm/24.6" long)
5.6” LCD CCTV Test monitor
Small & compact for portability
Full colour LCD to check for Audio & Video signal
Built in speaker & Earphone Output
Rechargeable batteries & service Leads included
DC adaptor & Rechargeable adaptor included
Supplied in a portable zip bag with strap
Input voltage 9-20VDC
Product Model Description
BA-01
Mounting bracket. Aluminum. Max. load: 3 kg/6.6 lbs
57 x 165 mm/2.2" x 6.5" (W x H)
BA-03
Mounting bracket. Plastic. Max load: 35kg/7.7 lbs
80 × 160 mm/3.1" × 6.3" (W x H)
BA-05
Mounting bracket. Aluminum. Max. Load: 10kg/22 lbs
84 × 294 mm/3.3" × 11.6" (W × H)
Camera Housing
Specifications
Screen Size (H x V)
5.6"/116 x 87 mm
Active Area (H x V)
111.36mm x 83.52mm
Pixel Type
A-Si Active Matrix TFT
Screen Colour
Full colour
Dot Matrix (H x V)
320 x 240 RGB
Dot Pitch
0.116 x 0.348
Contrast Ratio
Brightness
Sound Input
Terminal Input
85:1
270 cd/m2
200mW (built-in 4cm specker)
Power, Video & Audio Input
Video Input
0.75 Vp-p~1Vp-p, 3.5 pin
Audio Input
50mV min., Stereo In, 3.5 pin
Stereo Output
Ear phone, 3.5 pin
Screen Display
Reverse/normal switchable (R->N)
Power Consumption
Power Source
12VDC, 600mA (8W max.)
Specifications
Product Model
FH-7153
FH-7153H
FH-7153HB
Description
Outdoor camera housing with top cover and lock. Aluminum.
352 × 113 × 106mm/13.9" × 4.5" × 4.2" (L × W × H)
Outdoor camera housing with top cover, lock and heater.
24VAC, 17W power consumption. Aluminum.
352 × 113 × 106mm/13.9" × 4.5" × 4.2" (L × W × H)
Outdoor camera housing with top cover, lock, heater and
blower. 24VAC, 18.7W power consumption. Aluminum.
373 × 140 × 115mm/14.7" × 5.5" × 4.5" (L × W × H)
9VDC~20VDC, 2.0 pin
Dimensions (W x H x D)
162 x 133 x 54 mm/6.4" x 5.2" x 2.1"
Operating Temperature
0 C~60 C/32 F~140 F
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product speci cations are subject to change without notice
121
Accessories IR Illuminators
Accessories
EIR20/50
EIR100
20m/50m IR Illuminator
70m IR Illuminator for use w/EZ550
Features
Features
•
•
•
•
•
•
Up to 50m/164ft. of IR range (EIR50)
Up to 20m/66ft. of IR range (EIR20)
Compact size for discreet surveillance
Compact Standalone design for flexible application
Up to 20,000 houre of LED lifespan
Improve image quality in complete darkness and/or
in low-light conditions
• Built-in sensor will automatically turn on illuminator
at night and off during the daytime
• Weatherproof design and IP66 rated
• Up to 70m/230ft. of IR range
• Up to 20,000 hours of LED lifespan
• Improve image quality in complete darkness and/or
in low-light conditions
• Built-in with EZ550, will automatically turn on
illuminator at night and off during the daytime
• Weatherproof design and IP66 rated
• Designed to enhance low light performance for
EZ550 only
Specifications
Specifications
Model No.
IR Distance
EIR50
EIR20
50m/164ft.
20m/66ft.
IR Wavelength
850nm
IR LED Lifespan
Up to 20,000 hours
12VDC
Power Source
Power Consumption
6W max.
Dimensions (D × H)
80mm × 88.5mm/3.15" × 3.48" (w/out backet)
80mm × 148mm/3.6" × 5.83" (with bracket)
Weight
Operating Temperature
0.33kg/0.73 lbs (with bracket)
IR Distance
70m/230ft.
IR Wavelength
850nm
IR LED Lifespan
Up to 20,000 hours
Power Source
12VDC
Power Consumption
12W max.
Dimensions (L×W×H)
200mm × 290mm × 100mm/7.87" × 11.41" × 3.93"
0.76kg/1.67lbs
Weight
Operating Temperature
-10˚C~50˚C/140˚F~122˚F (20%~80% humidity)
Weatherproof Ratings
IP66
-10˚C~50˚C/140˚F~122˚F (20%~80% humidity)
IP66
Weatherproof Ratings
Dimensions
Dimensions
122
* All product specifications are subject to change without notice
100mm/3.93”
80mm/3.15”
290mm/11.41”
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories INFRA RED AND WHITE LIGHT LED ILLUMINATION
INFRA RED FIXED ANGLE LED ILLUMINATION c/w integrated Photocell
LOW VOLTAGE INTEGRATED INFRA RED ILLUMINATION
IR 30i/120
IR 30 120 degree, fixed panel 850nm IR Illuminator
Integrated Photo cell 12Vdc/24Vac input up to 10m
VARI FOCAL INFRA RED DUAL PANEL LED ILLUMINATION LAMPS (850nM) complete with PSU
LONG DISTANCE IR ILLUMINATION
IR 750 50-180 degree triple panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input wide angle/
ultra long distance up to 150m
IR 500/1020
IR 500, 10-20 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input ultra long
distance up to 250m
Accessories
IR750/50180
MEDIUM TO LONG DISTANCE IR ILLUMINATION
IR 500/2060
IR 500 20-60 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 160m
IR 500/50100
IR 500 50-100 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 110m
IR 500/120180
IR 500 120-180 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 60m
IR 300/2060
IR 300 20-60 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 80m
IR 300/50100
IR 300 50-100 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 50m
IR 300/120180
IR 300 120-180 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 30m
MEDIUM DISTANCE IR ILLUMINATION
SHORT TO MEDIUM DISTANCE IR ILLUMINATION
IR 100/2060
IR 100 20-60 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 40m
IR 100/50100
IR 100 50-100 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 25m
IR 100/120180
IR 100 120-180 degree dual panel vari-focal 850nm IR
Illuminator c/w Ext Boxed PSU 230Vac input up to 15m
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
123
Accessories
INFRA RED AND WHITE LIGHT LED ILLUMINATION
INFRA RED FIXED ANGLE LED ILLUMINATION (850nM)
IR 50/30
IR 50 30 degree fixed panel 850nm IR Illuminator c/w Ext
Boxed Power supply 230Vac input
IR 50/50
IR 50 50 degree fixed panel 850nm IR Illuminator c/w Ext
Boxed Power supply 230Vacinput
IR 50/120
IR 50 120 degree fixed panel 850nm IR Illuminator c/w Ext
Boxed Power supply 230Vac input
INFRA RED FIXED ANGLE LED ILLUMINATION POE (850nm)
Accessories
IR 50/30-POE
IR 50 30 degree fixed panel 850nm IR Illuminator POE input
IR 50/50-POE
IR 50 50 degree fixed panel 850nm IR Illuminator POE input
IR 50/120-POE
IR 50 120 degree fixed panel 850nm IR Illuminator POE
input
* Please note all IR50 POE Lamps are INTERNAL ONLY
FIXED PANEL INFRA RED LED ILLUMINATION LAMPS (940Nm)
IR 50/30-940
IR 50 30 degree fixed panel 940nm IR Illuminator c/w Ext
Boxed Power supply 230Vac input
IR 50/50-940
IR 50 50 degree fixed panel 940nm IR Illuminator c/w Ext
Boxed Power supply 230Vac input
IR 50/120-940
IR 50 120 degree fixed panel 940nm IR Illuminator c/w Ext
Boxed Power supply 230Vac input
VARI FOCAL INFRA RED DUAL PANEL LED ILLUMINATION LAMPS (940Nm)
124
* All product specifications are subject to change without notice
IR 100/2060-940
IR 100 20-60 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 100/50100-940
IR 100 50-100 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 100/120180-940
IR 100 120-180 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 300/2060-940
IR 300 20-60 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 300/50100-940
IR 300 50-100 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 300/120180-940
IR 300 120-180 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 500/2060-940
IR 500 20-60 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 500/50100-940
IR 500 50-100 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU 230Vac input
IR 500/120180-940
IR 500 120-180 degree dual panel vari-focal 940nm IR
Illuminator c/w Ext Boxed PSU230Vac input
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories WHITE LIGHT FIXED ANGLE LED ILLUMINATION
WHITE LIGHT LED LAMPS INCLUDING PSU’s
WL 50 30 degree fixed panel White light LED Illuminator
c/w Ext Boxed Power supply 230Vac input
WL50/50
WL 50 50 degree fixed panel White light LED Illuminator
c/w Ext Boxed Power supply 230Vac input
WL 50/120
WL 50 120 degree fixed panel White light LED Illuminator
c/w Ext Boxed Power supply 230Vac input
WL100/2060
WL 100 20-60 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL100/50100
WL 100 50-100 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL100/120180
WL 100 120-180 degree dual panel vari-focal White light
LED Illuminator c/w Ext Boxed PSU 230Vac input
WL300/2060
WL 300 20-60 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL300/50100
WL 300 50-100 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL300/120180
WL 300 120-180 degree dual panel vari-focal White light
LED Illuminator c/w Ext Boxed PSU 230Vac input
WL500/2060
WL 500 20-60 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL500/50100
WL 500 50-100 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
WL 500/120180
WL 500 120-80 degree dual panel vari-focal White light LED
Illuminator c/w Ext Boxed PSU 230Vac input
Accessories
WL50/30
* Please note all lamps are supplied with a standard PSU incorporating adjustable power output, photo cell adjustment and a
telemetry input (except IR30i range)
Premium PSU include all of the features of Standard plus following on contact and 12Vdc output. Prices available on request
FIXING BRACKETS FOR IR & WHITE LIGHT LED ILLUMINATORS
SB1
Single bracket for Top Pan/Tilt mount
DB2
Dual mounting bracket for Top Pan/Tilt mount
PB180
Pole bracket for IR 750 for use with C-Allview & C-Dome
PB360
Pole bracket for IR 750 for use with C-Allview & C-Dome
PBC-1
Pole clamp mount
WB1
Wall Bracket - L Bracket
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
* All product specifications are subject to change without notice
125
Accessories
PS-201C
1-port Gigabit IEEE 802.3at PoE+ Injector
PD-2024
1-port Gigabit IEEE 802.3at PoE+ Splitter
•
•
Accessories
•
•
1 Ethernet Input Port (Data Only) + 1
Ethernet Output Port (Data + Power)
Compliant with IEEE 802.3at , Output
Power up to 25W
Smart Plug and Play
DC Lead
Multiple output DC Lead
single input 4 outputs
Power Adaptors
TP12.5 12vdc 500ma
TP12.10 12vdc 1amp
BB012 Patch Lead
Ready made 1.2mtr
BNC to BNC patch lead
Power Adaptors
TP12.30 12vdc 3amp
TP12.50 12vdc 5amp
Mini Coax & DC Lead
20mtr & 40mtr Composite Cable
126
•
•
•
1 LAN-In Port (Data + Power) + 1 LANOut Port (Data Only)
Power Detection and Classi cation
Compliant with IEEE 802.3at
Suppors 24V output voltage
* All product speci cations are subject to change without notice
Power Centre
PW101 4 x 1.5 amp
PW102 8 x 1.0 amp
PW103 16 x 0.5 amp
PW104 16 x 1.0 amp
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
Accessories
BNCCRIMP
RG59 BNC Crimp
BNCTO
RG59 Twist on BNC
PPBNC
BNC plug to phono
Accessories
BNCSS
Back to back BNC
PSBNC
BNC to phono
BNCTP
BNC T piece
CABSTRIPPER
BNC Cable Stripper
CRIMPT
Coax Cable Crimp Tool
RG59 Cable
RG59.1 100 mtr roll
RG59.2 200 mtr roll
RG59 DC Cable
RG59DC.1 100 mtr roll
RG59DC.2 250 mtr roll
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
BNCPP
BNC connector
* All product specifications are subject to change without notice
127
Accessories
TTP111VEL
TTP111VL
TTP111VPD
MinI Video Transceiver BNC Male
to screw terminal
MinI Video Transceiver with Pigtail
Video Transceiver With
25cm Mini Coax Cable
Video,Power,Data Transceiver
(Terminal connection)
TPP016
TP111VE
Accessories
IP01
EP01
TTP111VGA
16 Port Passive Transceiver Hub In
1U Rack Mounting Panel
IP01 is a low cost and easy, speedy
solution to allow you use existing
coax cable to send IP camera signal
The EP01 Easy Passive POE
(Power Over Ethernet), uses
unused pairs of 100baseT network
cable to transmit power to remote
Features:
VGA connector to shielding RJ45
female*2pcs.
Passive, no power need
SP001
SP001VPD
CD104 108
GL001
Video, Power, Data Surge Protector
1 Input 4 -8 Output Video Distributor
Video Ground Loop Isolator
Coaxial Video Surge Protector
BNC Connector
128
TTP111VK
TTP414V
TTA111VT+TTA111VR
Video Balun DIY KIT ( TTP111VT + TTP111VL)
4 Channel Video Transceiver
Active Video Twisted Pair Transmission
TTA111AVT + TTA111AVR
TPA008 - TPA016
TTA414VR
Active Video & Audio & Data
Twisted Pair Transmission
8 - 16 Port Active Receiver Hub
In 1U Rack Mounting Panel
Built in 4 port active receivers.
* All product specifications are subject to change without notice
* Models vary in different countries. Please visit EverFocus regional websites for detailed ordering information
