Low and High Voltage Power
Supplies
ISO 9001: 2008
We work according to
Since 1994 Fug works according to the quality assurance system ISO 9001. All shipped units are checked and documented in our testing department with calibrated measuring devices for compliance to the guaranteed characteristics.
All our products are
marked.
So we guarantee compliance with all relevant European standards and regulations.
Our power supplies are manufactured and tested in accordance with the following provisions:
EMC:
EN61000-6-1 and EN61000-6-3 (for single-phase mains)
EN61000-6-2 and EN61000-6-4 (for two- and tree-phase mains)
Safety:
EN 61010-1
This catalogue contains over 600 models,
more than 100 of them available with short term delivery.
2
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Content
Page
Product overview
4
Standard type ranges of power supplies
6
Low voltage power supplies double stabilized/ Series NTN from 6,5 V to 350 V / 35 W tos 100 kW
6
Low voltage power supplies thyristor regulated/ Series NYN from 12,5 V to 350 V / 7 kW to 100 kW
10
Autoranging power supplies/ Series NCA / MCA from 55 V to 3000 V / 750 W to 9000 W
12
Medium voltage power supplies/ Series MCP from 125 V to 2000 V / 14 W to 15 kW
14
Medium voltage power supplies thyristor regulated/ Series MYN from 650 V to 2000 V / 7 kW to 70 kW
17
High voltage power supplies/ Series HCP from 3,5 kV to 300 kV / 14 W to 15 kW
19
High voltage power supplies high power/ Series HCH from 650 V to 300 kV / 10 kW to 50 kW
22
High voltage power supplies thyristor regulated/ Series HYN from 3,5 kV to 20 kV / 10 kW to 50 kW
25
High voltage cassette power supplies EURO-size/ Series HCE from 125 V to 35 kV / 7 W to 350 W
27
Capacitor charging power supplies/ Series HCK from 2 kV to 65 kV / 100 J/s to 20 kJ/s
30
Power supplies for superconducting coils/ Series NTS to 65 V / to 10000 A
33
Linear regulated power supplies unipolar/ Series NLN from 6,5 V to 500 V / 35 W to 1400 W
35
Linear regulated power supplies bipolar/ Series NLB from ±6,5 V to ±500 V / 35 W to 1400 W
38
Bipolar high voltage power supplies/ Series HCB from ±1250 V to ±20000 V / 1,4 W to 200 W
41
Technical appendix, mains fuses, efficiency
43
Options and modifications
44
Analogue programming
44
Probus V (digital interface system)
46
Further possibilities
48
Accessories
49
Isolating transformers
49
Mechanical components
50
High voltage cables
51
High voltage connectors
52
Definitions and terms
54
Examples for customer specific power supplies
56
Imprint
60
3
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Product overview
Power supply family
Function
Type range
Low voltage power supplies
linear regulated with thyristor pre-regulation
NTN
thyristor regulated
NYN
Autoranging power supplies
switched
NCA/ MCA
Medium voltage power supplies
switched
MCP
thyristor regulated
MYN
switched
HCP
switched
HCH
thyristor regulated
HYN
High voltage cassette power supplies
switched
HCE
High voltage capacitor charger
switched
HCK
Power supplies for superconductors
linear regulated with thyristor pre-regulation
NTS
Linear and bipolar power supplies
linear regulated
NLN
linear regulated bipolar
NLB
switched bipolar
HCB
High voltage power supplies
Options / interfaces
For the most FuG power supplies
Customer specific power supplies
Typical examples
4
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Product overview
Upper and lower limits of the maximum output values of each type range
Vmin
Volts
Vmax
Volts
Imin
Amps
Imax
Amps
Page
Pmin
Watts
Pmax
Watts
Emin
J/s
Emax
J/s
6,5
350
0,5
4.000
35
100.000
6
12,5
350
60
4.000
7.000
100.000
10
55
3.000
0,75
180
750
9.000
12
125
2.000
0,006
120
14
15.000
14
650
2.000
10
100
7.000
70.000
17
3.500
300.000
0,0003
4,5
14
15.000
19
650
300.000
0,008
75
2.800
50.000
22
3.500
20.000
0.3
20
7.000
70.000
25
125
35.000
0.0002
2,5
7
350
27
2.000
65.000
0.003
20
65
100
10.000
20.000
30
33
6,5
500
0,06
120
35
1.400
35
± 6.5
± 350
± 0.1
± 120
35
1.400
38
± 1250
± 20.000
± 0.001
± 0.01
1,4
200
41
a variety of options and modifications is available, including a number of interfaces.
We manufacture according to customer specification. Please send us the detailed specification of your application.
44
56
5
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Low voltage power supplies double stabilized
Series NTN from 6,5 V to 350 V / 35 W to 100 kW
 Cooling is carried out via
 Recovery time:
convection or built-in fans,
with the air being exhausted
(depending upon type) either
via the rear or the top. For
high power units water cooling can also be used.
Design Example
Features:
 Simple construction
 Short circuit proof and unlim







ited operation with full current
in short circuit condition
Voltage and current regulation
with automatic and sharp
transition;
control
modes
indicated by LEDs
Voltage and current setting
via 10-turn potentiometers
with precision scale; the adjusting knob can be locked
4½ digit DVM for voltage and
current (for table-top models)
Sense terminals for the compensation of voltage drop on
the load lines. The nominal
voltage always refers to the
output terminals
Parallel and series connection
possible
Suitable also for inductive and
capacitive loads
Safety interlock loop and
internal interlock is standard
on three-phase units
Elapsed-hour meter as a
standard on three-phase units
NTN 700 - 125
125V / 5A
Function:
The mains voltage is transformed to the appropriate level. On
the secondary side of the transformer is a thyristor controlled
rectifier stage (phase cutting
circuit), the output of which is
used to charge a capacitor
bank. This capacitor bank is
also connected to the final series regulating transistor output
stage. By controlling the conduction angle of the thyristors
after each zero-crossing of the
sinusoidal voltage, the flow of
energy is regulated in such a
way as to have a defined voltage drop across the final series
transistor stage (pre-regulation).
The performance of the final
series transistor stage defines
the final stability of the output
voltage (main regulation).
Design:
 Up to 140W nominal power
½19" table-top case
 For 350W nominal power or
higher 19" table-top case
 19" Rack-adapters for mounting into a 19" rack are available as accessory
 For 7kW nominal power or
higher 19" cabinet. Height
depending on type. The side
covers are detachable and the
rear door is lockable.
 All cabinets are equipped with
fork-lift-compatible plinths and
removable crane-eyes.
 Single cabinets up to 38U are
easily transportable by forklift.
Output:
 Output isolation:
The output is floating, maximum operating voltage with
respect to earth: ±500V. Either the positive or the negative terminal may be connected to earth. For units
equipped with the analog
programming: the "0V" of the
analog programming is connected to the positive output.
 Output terminals:
Up to 20A output current,
4mm safety connectors are
used on the rear side. For
currents up to 300A - clamps
are fitted whilst for higher
currents we use copper bars.
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 53Hz
For 2800W and higher:
400V ±10% 47Hz to 53Hz;
two-phase

For 7000W and higher:
400V ±10% 47Hz to 53Hz;
three-phase
Ambient temperature: 0°C to
+40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:


from approx. 0,1% to 100%
Setting resolution:
±1 x 10-4
Residual ripple (0 - 10MHz):
<1 x 10-4pp + 10mVpp
6
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Voltage control:
<50µs for load changes from
10% to 100% or from 100% to
10%.
Current control:
<500ms for load changes
causing an output change of
less than 10% of the rated
voltage.



Units with output voltage
>65V, will switch off for a
short time at high and fast
load changes.
Setting time at nominal load:
100ms to 500ms for changes
of the output voltage from
10% to 90% or 90% to 10%
Discharge time constant for
output without load:
approx. 2sec. to 60sec., depending on type
Deviation:
For ±10% mains voltage variation:
<± 1 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-4
Within the temperature range:
<±1 x 10-4/K
Possible Options:
 Coarse/fine-potentiometers
(99% / 1%) for more accurate
adjustment of voltage and / or
current
 Analog programming (The
positive output has to be
earthed; see also page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Roller blades for cabinet units
 Higher stability (see page 48)
 Power limitation (see page
48)
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
Low voltage power supplies double stabilized
Series NTN from 6,5 V to 350 V / 35 W to 100 kW
Type
Voltage
Current
Width
Height
Depth
Weight
NTN
35 - 6,5
0 -
6,5 V
0 -
5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NTN
140 - 6,5
0 -
6,5 V
0 -
10 A
½19" / 222 mm
3 U / 133 mm
350 mm
8 kg
NTN
350 - 6,5
0 -
6,5 V
0 -
30 A
19" / 443 mm
3 U / 133 mm
450 mm
18 kg
NTN
700 - 6,5
0 -
6,5 V
0 -
60 A
19" / 443 mm
4 U / 177 mm
450 mm
30 kg
NTN
1400 - 6,5
0 -
6,5 V
0 -
120 A
19" / 443 mm
7 U / 310 mm
550 mm
70 kg
NTN
2800 - 6,5
2)
0 -
6,5 V
0 -
250 A
19" / 443 mm
9 U / 399 mm
650 mm
120 kg
NTN
4200 - 6,5
3)
0 -
6,5 V
0 -
400 A
19" / 600 mm
29 U / 1500 mm
600 mm
300 kg
NTN
7000 - 6,5
3)
0 -
6,5 V
0 -
600 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
NTN
10500 - 6,5
3)
0 -
6,5 V
0 -
1000 A
19" / 600 mm
38 U / 2000 mm
800 mm
500 kg
NTN
14000 - 6,5
3)
0 -
6,5 V
0 -
1500 A
19" / 600 mm
38 U / 2000 mm
800 mm
550 kg
NTN
21000 - 6,5
3)
0 -
6,5 V
0 -
2000 A
19" / 600 mm
38 U / 2000 mm
800 mm
650 kg
NTN
28000 - 6,5
3)
0 -
6,5 V
0 -
2500 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1000 kg
NTN
35000 - 6,5
3)
0 -
6,5 V
0 -
3000 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1300 kg
2,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NTN
35 - 12,5
0 -
12,5 V
0 -
NTN
140 - 12,5
0 -
12,5 V
0 -
8 A
½19" / 222 mm
3 U / 133 mm
350 mm
8 kg
NTN
350 - 12,5
0 -
12,5 V
0 -
20 A
19" / 443 mm
3 U / 133 mm
350 mm
17 kg
NTN
700 - 12,5
0 -
12,5 V
0 -
50 A
19" / 443
mm
4 U / 177 mm
450 mm
29 kg
NTN
1400 - 12,5
0 -
12,5 V
0 -
80 A
19" / 443 mm
4 U / 177 mm
550 mm
50 kg
NTN
2800 - 12,5
2)
0 -
12,5 V
0 -
150 A
19" / 443 mm
7 U / 310 mm
650 mm
110 kg
NTN
4200 - 12,5
2)
0 -
12,5 V
0 -
250 A
19" / 443
mm
9 U / 399 mm
650 mm
150 kg
NTN
7000 - 12,5
3)
0 -
12,5 V
0 -
500 A
19" / 600 mm
38 U / 2000 mm
800 mm
340 kg
NTN
10500 - 12,5
3)
0 -
12,5 V
0 -
800 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
NTN
14000 - 12,5
3)
0 -
12,5 V
0 -
1000 A
19" / 600 mm
38 U / 2000 mm
800 mm
520 kg
NTN
21000 - 12,5
3)
0 -
12,5 V
0 -
1500 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
NTN
28000 - 12,5
3)
0 -
12,5 V
0 -
2000 A
19" / 600
mm
38 U / 2000 mm
800 mm
900 kg
NTN
35000 - 12,5
3)
0 -
12,5 V
0 -
2500 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1300 kg
NTN
50000 - 12,5
3)
0 -
12,5 V
0 -
4000 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1500 kg
1,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
½19" / 222 mm
NTN
35 - 20
0 -
20 V
0 -
NTN
140 - 20
0 -
20 V
0 -
6 A
3 U / 133 mm
350 mm
8 kg
NTN
350 - 20
0 -
20 V
0 -
15 A
19" / 443
mm
3 U / 133 mm
350 mm
17 kg
NTN
700 - 20
0 -
20 V
0 -
30 A
19" / 443 mm
4 U / 177 mm
450 mm
26 kg
NTN
1400 - 20
0 -
20 V
0 -
60 A
19" / 443 mm
4 U / 177 mm
550 mm
50 kg
NTN
2800 - 20
2)
0 -
20 V
0 -
120 A
19" / 443
7 U / 310 mm
550 mm
80 kg
NTN
4200 - 20
2)
0 -
20 V
0 -
200 A
19" / 443 mm
9 U / 399 mm
550 mm
110 kg
NTN
7000 - 20
3)
0 -
20 V
0 -
300 A
19" / 600 mm
29 U / 1500 mm
600 mm
300 kg
NTN
10500 - 20
3)
0 -
20 V
0 -
500 A
19" / 600 mm
38 U / 2000 mm
800 mm
440 kg
NTN
14000 - 20
3)
0 -
20 V
0 -
600 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
NTN
21000 - 20
3)
0 -
20 V
0 -
800 A
19" / 600
mm
38 U / 2000 mm
800 mm
580 kg
NTN
28000 - 20
3)
0 -
20 V
0 -
1200 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
NTN
35000 - 20
3)
0 -
20 V
0 -
1500 A
19" / 600 mm
38 U / 2000 mm
800 mm
1200 kg
NTN
50000 - 20
3)
0 -
20 V
0 -
2500 A
2 x 19" /1200 mm
38 U / 2000 mm
800 mm
1400 kg
mm
2) Two phase mains connection
3) Three phase mains connection
7
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Low voltage power supplies double stabilized
Series NTN from 6,5 V to 350 V / 35 W to 100 kW
Type
Voltage
Current
Width
Height
Depth
Weight
NTN
NTN
NTN
35 - 35
140 - 35
350 - 35
000-
35 V
35 V
35 V
000-
1A
4A
10 A
½19" / 222 mm
½19" / 222 mm
19" / 443 mm
3 U / 133 mm
3 U / 133 mm
3 U / 133 mm
350 mm
350 mm
350 mm
5 kg
8 kg
17 kg
NTN
NTN
NTN
700 - 35
1400 - 35
2800 - 35
2)
000-
35 V
35 V
35 V
000-
20 A
40 A
80 A
19" / 443 mm
19" / 443 mm
19" / 443 mm
4 U / 177 mm
4 U / 177 mm
7 U / 310 mm
450 mm
550 mm
550 mm
27 kg
47 kg
70 kg
NTN
NTN
NTN
4200 - 35
7000 - 35
10500 - 35
2)
3)
3)
000-
35 V
35 V
35 V
000-
120 A
200 A
300 A
19" / 443 mm
19" / 600 mm
19" / 600 mm
9 U / 399 mm
20 U / 1100 mm
29 U / 1500 mm
550 mm
600 mm
600 mm
110 kg
280 kg
420 kg
NTN
NTN
NTN
14000 - 35
21000 - 35
28000 - 35
3)
3)
3)
000-
35 V
35 V
35 V
000-
400 A
600 A
800 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
460 kg
530 kg
750 kg
NTN
NTN
35000 - 35
70000 - 35
3)
3)
00-
35 V
35 V
00-
1000 A
2000 A
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
950 kg
1500 kg
NTN
NTN
NTN
35 - 65
140 - 65
350 - 65
000-
65 V
65 V
65 V
000-
500 mA
2A
5A
½19" / 222 mm
½19" / 222 mm
19" / 443 mm
3 U / 133 mm
3 U / 133 mm
3 U / 133 mm
350 mm
350 mm
350 mm
5 kg
8 kg
15 kg
NTN
NTN
NTN
700 - 65
1400 - 65
2800 - 65
2)
000-
65 V
65 V
65 V
000-
10 A
20 A
40 A
19" / 443 mm
19" / 443 mm
19" / 443 mm
4 U / 177 mm
4 U / 177 mm
5 U / 221 mm
350 mm
450 mm
550 mm
24 kg
42 kg
55 kg
NTN
NTN
NTN
4200 - 65
7000 - 65
10500 - 65
2)
3)
3)
000-
65 V
65 V
65 V
000-
60 A
100 A
150 A
19" / 443 mm
19" / 600 mm
19" / 600 mm
9 U / 399 mm
20 U / 1100 mm
29 U / 1500 mm
550 mm
600 mm
600 mm
110 kg
280 kg
390 kg
NTN
NTN
NTN
NTN
14000
21000
28000
35000
65
65
65
65
3)
3)
3)
3)
0
0
0
0
65
65
65
65
0
0
0
0
200
300
400
500
19" /
19" /
19" /
19" /
38 U / 2000
38 U / 2000
38 U / 2000
38 U / 2000
800
800
800
800
mm
mm
mm
mm
440 kg
510 kg
720 kg
900 kg
NTN
70000 - 65
3)
0-
65 V
0-
-
-
V
V
V
V
-
A
A
A
A
600
600
600
600
mm
mm
mm
mm
mm
mm
mm
mm
1000 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1400 kg
NTN
700 - 125
0-
125 V
0-
5A
19" / 443 mm
4 U / 177 mm
350 mm
24 kg
NTN
NTN
NTN
1400 - 125
2800 - 125
4200 - 125
2)
2)
000-
125 V
125 V
125 V
000-
10 A
20 A
30 A
19" / 443 mm
19" / 443 mm
19" / 443 mm
4 U / 177 mm
5 U / 221 mm
9 U / 399 mm
450 mm
550 mm
550 mm
42 kg
55 kg
110 kg
NTN
NTN
NTN
7000 - 125
10500 - 125
14000 - 125
3)
3)
3)
000-
125 V
125 V
125 V
000-
50 A
80 A
100 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
20 U / 1100 mm
29 U / 1500 mm
29 U / 1500 mm
600 mm
600 mm
600 mm
250 kg
300 kg
400 kg
NTN
NTN
NTN
21000 - 125
28000 - 125
35000 - 125
3)
3)
3)
000-
125 V
125 V
125 V
000-
150 A
200 A
250 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
490 kg
680 kg
850 kg
NTN
NTN
50000 - 125
100000 - 125
3)
3)
00-
125 V
125 V
00-
400 A
800 A
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
1200 kg
1700 kg
2) Two phase mains connection
3) Three phase mains connection
8
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Low voltage power supplies double stabilized
Series NTN from 6,5 V to 350 V / 35 W to 100 kW
Type
Voltage
Current
Width
Height
Depth
Weight
NTN
700 - 200
0 -
200 V
0 -
3 A
19" / 443 mm
4 U / 177 mm
350 mm
24 kg
NTN
1400 - 200
0 -
200 V
0 -
6 A
19" / 443 mm
4 U / 177 mm
450 mm
42 kg
NTN
2800 - 200
2)
0 -
200 V
0 -
12 A
19" / 443 mm
5 U / 221 mm
550 mm
55 kg
NTN
4200 - 200
2)
0 -
200 V
0 -
20 A
19" / 443 mm
9 U / 399 mm
550 mm
90 kg
NTN
7000 - 200
3)
0 -
200 V
0 -
30 A
19" / 600 mm
20 U / 1100 mm
600 mm
240 kg
NTN
10500 - 200
3)
0 -
200 V
0 -
50 A
19" / 600 mm
29 U / 1500 mm
600 mm
360 kg
NTN
14000 - 200
3)
0 -
200 V
0 -
60 A
19" / 600 mm
29 U / 1500 mm
600 mm
400 kg
NTN
21000 - 200
3)
0 -
200 V
0 -
100 A
19" / 600 mm
38 U / 2000 mm
800 mm
490 kg
NTN
28000 - 200
3)
0 -
200 V
0 -
120 A
19" / 600 mm
38 U / 2000 mm
800 mm
650 kg
NTN
35000 - 200
3)
0 -
200 V
0 -
150 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
NTN
50000 - 200
3)
0 -
200 V
0 -
250 A
19" / 600 mm
38 U / 2000 mm
800 mm
1200 kg
NTN 100000 - 200
3)
0 -
200 V
0 -
500 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1600 kg
0 -
350 V
0 -
2 A
19" / 443
mm
4 U / 177 mm
350 mm
24 kg
NTN
700 - 350
NTN
1400 - 350
0 -
350 V
0 -
4 A
19" / 443 mm
4 U / 177 mm
450 mm
42 kg
NTN
2800 - 350
2)
0 -
350 V
0 -
8 A
19" / 443 mm
5 U / 221 mm
550 mm
55 kg
NTN
4200 - 350
2)
0 -
350 V
0 -
12 A
19" / 443
mm
9 U / 399 mm
550 mm
90 kg
NTN
7000 - 350
3)
0 -
350 V
0 -
20 A
19" / 600 mm
20 U / 1100 mm
600 mm
240 kg
NTN
10500 - 350
3)
0 -
350 V
0 -
30 A
19" / 600 mm
29 U / 1500 mm
600 mm
275 kg
NTN
14000 - 350
3)
0 -
350 V
0 -
40 A
19" / 600 mm
29 U / 1500 mm
600 mm
400 kg
NTN
21000 - 350
3)
0 -
350 V
0 -
60 A
19" / 600 mm
38 U / 2000 mm
800 mm
490 kg
NTN
28000 - 350
3)
0 -
350 V
0 -
80 A
19" / 600
mm
38 U / 2000 mm
800 mm
650 kg
NTN
35000 - 350
3)
0 -
350 V
0 -
100 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
NTN
70000 - 350
3)
0 -
350 V
0 -
200 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1350 kg
NTN 100000 - 350
3)
0 -
350 V
0 -
300 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1600 kg
2) Two phase mains connection
3) Three phase mains connection
Design Example
NTN 4200M - 200
200V / 20A
Customised version
with polarity reversal
NTN 10500 - 200
200V / 50A
9
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Low voltage power supplies thyristor regulated
Series NYN from 12,5 V to 350 V / 7 kW to 100 kW
Design Example
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:
from approx. 1% to 100%
 Setting resolution:



NYN 70000 - 35
35V / 2000A
Features:
 Simple construction
 Extremely robust
 High efficiency
 Short circuit proof and unlim






ited operation with full current
in short circuit condition
Voltage and current regulation
with automatic and sharp
transition; control modes indicated by LEDs
Voltage and current setting
with 10-turn potentiometers
with precision scale; the adjusting knob can be locked
Sense terminals for the compensation of voltage drop on
the load lines. The nominal
voltage always refers to the
output terminals
Limitation of inrush current on
switching on
Suitable also for inductive and
capacitive loads
Interlock loop to monitor the
external load and internal loop
as a standard
Elapsed-hour meter as a
standard
NYN 42000M - 84
84V / 500A
customer specific design with
current consumption unit
(Side covers removed)
Function:
The mains voltage is first transformed to the appropriate level.
On the secondary side of the
transformer is a thyristor controlled rectifier stage (phase
cutting circuit). The rectified
voltage is smoothed by a LC filter.
Design:
 Depending on voltage and
power the units are built as
single or double 19" cabinets
of various height. The side
covers are detachable, the
rear door is lockable.
 All cabinets are equipped with
fork-lift-compatible plinths and
removable crane-eyes.
 Single 19"- cabinets up to
38U are easily transportable
by fork-lift.
 Cooling is carried out via convection or built-in fans, with
the air being exhausted
(depending upon type) either
via the rear or the top.
Output:
 Output isolation:
The output is floating. The
maximum operating voltage
with respect to earth: ±500V.
Either the positive or the
negative terminal may be
connected to earth.
 Output terminals:
All output terminals are located at the rear side of the
cabinet. For Output current
up to 300A feed though terminals are used; for higher
currents the output is via
copper bars.
Technical Data:
 Mains connection:
400V ±10% 47Hz to 53Hz;
three-phase
 Ambient temperature:
0°C to +40°C
10
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de


±1 x 10-4
Residual ripple (0 - 10MHz):
<1 x 10-2pp + 100mVpp
Recovery time:
<100ms to 500ms (depending
on type) for load variations of
±10%
Setting time at nominal load:
<100ms to 2sec (depending
on type) for changes of the
output voltage from 10% to
90% or 90% to 10%
Discharge time constant
for output without load:
approx. 5sec. to 60sec., depending on type
Deviation:
For ±10% mains voltage variation:
<±1 x 10-4
For no load / full load:
<±1 x 10-3
Over 8 hours under constant
conditions:
<±3 x 10-4
Within the temperature range:
<±3 x 10-4/K
Possible Options:
 Analog programming (One of
the outputs on “0V” - potential; see also page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Internal resistance setting and
regulation (see page 48)
 Power regulation with display
(see page 48)
 Roller blades for cabinet units
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
Low voltage power supplies thyristor regulated
Series NYN from 12,5 V to 350 V / 7kW to 100 kW
Type
Voltage
Current
Width
Height
Depth
Weight
NYN
NYN
NYN
7000 - 12,5
10500 - 12,5
14000 - 12,5
000-
12,5 V
12,5 V
12,5 V
000-
500 A
800 A
1000 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
20 U / 1100 mm
38 U / 2000 mm
38 U / 2000 mm
600 mm
800 mm
800 mm
300 kg
440 kg
480 kg
NYN
NYN
NYN
21000 - 12,5
28000 - 12,5
35000 - 12,5
000-
12,5 V
12,5 V
12,5 V
000-
1500 A
2000 A
2500 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
550 kg
820 kg
1200 kg
NYN
50000 - 12,5
0-
12,5 V
0-
4000 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1300 kg
NYN
7000 - 20
0-
20 V
0-
300 A
19" / 600 mm
20 U / 1100 mm
600 mm
280 kg
NYN
NYN
NYN
10500 - 20
14000 - 20
21000 - 20
000-
20 V
20 V
20 V
000-
500 A
600 A
800 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
400 kg
440 kg
530 kg
NYN
NYN
NYN
28000 - 20
35000 - 20
50000 - 20
000-
20 V
20 V
20 V
000-
1200 A
1500 A
2500 A
19" / 600 mm
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
750 kg
1100 kg
1250 kg
NYN
NYN
7000 - 35
10500 - 35
00-
35 V
35 V
00-
200 A
300 A
19" / 600 mm
19" / 600 mm
20 U / 1100 mm
29 U / 1500 mm
600 mm
600 mm
260 kg
380 kg
NYN
NYN
NYN
14000 - 35
21000 - 35
28000 - 35
000-
35 V
35 V
35 V
000-
400 A
600 A
800 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
420 kg
500 kg
700 kg
NYN
NYN
35000 - 35
70000 - 35
00-
35 V
35 V
00-
1000 A
2000 A
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
900 kg
1070 kg
NYN
NYN
NYN
NYN
7000
10500
14000
21000
0
0
0
0
65
65
65
65
0
0
0
0
19" /
19" /
19" /
19" /
20 U / 1100
29 U / 1500
29 U / 1500
38 U / 2000
600
600
600
800
NYN
NYN
NYN
28000 - 65
35000 - 65
70000 - 65
000-
65 V
65 V
65 V
000-
400 A
500 A
1000 A
19" / 600 mm
19" / 600 mm
19" / 600 mm
NYN
NYN
21000 - 125
28000 - 125
00-
125 V
125 V
00-
150 A
200 A
NYN
NYN
NYN
35000 - 125
50000 - 125
100000 - 125
000-
125 V
125 V
125 V
000-
NYN
NYN
21000 - 200
28000 - 200
00-
200 V
200 V
NYN
NYN
NYN
35000 - 200
50000 - 200
100000 - 200
000-
NYN
NYN
21000 - 350
28000 - 350
NYN
NYN
NYN
35000 - 350
70000 - 350
100000 - 350
-
65
65
65
65
-
V
V
V
V
-
100
150
200
300
A
A
A
A
600
600
600
600
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
260 kg
360 kg
400 kg
480 kg
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
680 kg
850 kg
1070 kg
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
450 kg
650 kg
250 A
400 A
800 A
19" / 600 mm
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
800 kg
1100 kg
1600 kg
00-
100 A
120 A
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
450 kg
630 kg
200 V
200 V
200 V
000-
150 A
250 A
500 A
19" / 600 mm
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
750 kg
1100 kg
1500 kg
00-
350 V
350 V
00-
60 A
80 A
19" / 600 mm
19" / 600 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
450 kg
630 kg
000-
350 V
350 V
350 V
000-
100 A
200 A
300 A
19" / 600 mm
19" / 600 mm
2 x 19" / 1200 mm
38 U / 2000 mm
38 U / 2000 mm
38 U / 2000 mm
800 mm
800 mm
800 mm
750 kg
1200 kg
1500 kg
11
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Autoranging power supplies
Series NCA / MCA from 55 V to 3000 V / 750 W to 9000 W
Design Example
MCA 9000 - 1500
1500V / 18A, max. 9000W
Features:
 Auto ranging characteristic
with constant power limitation
 5 power classes and 6 Voltage classes: 55V to 3000V
 Up to 1500V with floating
output
 Compact size (19" case) ,
Light-weight and High efficiency
 Short-circuit & flashover proof
 Unlimited operation with nom








inal power (even in shortcircuit conditions)
Voltage and current regulation
with automatic, sharp transition and additional power
limitation
Control mode indicated by
LED
4½ digit DVM for voltage and
current for all power classes
Voltage and current setting
with10-turn
potentiometers
with precision scale; the adjusting knob can be locked
Indication of set point values
by means of button for switchover of the displays
Set point adjustment possible
with locked output, release of
output voltage by means of an
"ON" / "OFF" switch
Suitable also for capacitive
loads
Sense connections to compensate voltage drop at the
load cables for NCA
Active down control for NCA
Function:
The NCA/MCA series is an auto
ranging power supply design in
which the power supplies operate over the full range of their
output voltage & current - up to
the units maximum rated output
power. This results in an operating range which is up to 3-times
wider than that of a more conventional power supply. When
fitted with the optional computer
interface, the MCA/NCA series
become versatile programmable
power supplies. In principle, the
rectified line voltage drives a
square wave generator, whose
AC voltage is transformed, rectified and filtered, producing the
output voltage. For regulation,
the square wave voltage is
pulse width modulated.
Design:
19" table-top case (19" rack
adapters available)
Output:
 Output isolation:
Up to 1500V nominal voltage
and 3000W power, the output
is floating. Either the positive
or the negative pole may be
connected to earth.
(Not valid with the option analog programming. If the floating function should remain,
the floating analog programming must be chosen).
Maximum isolation voltage:
Up to 400V nominal voltage:
±500V.
At 750V nominal voltage:
±1000V.
At 1500V nominal voltage:
±2000V.
At 3000V nominal voltage
and for 1500V in the power
classes 6000W and 9000W
one pole is earthed, the polarity must be indicated when
ordering.
 Output terminals:
Units up to 750V nominal
voltage have 4mm safety
connectors. For units with
output current >10A have
output clamps. For units with
nominal voltage greater than
1500V and rated current up
to 10A SHV connectors are
provided, suitable HV-cable
connectors are included.
.
Technical Data:
 Mains connection:
Up to 1500W nominal power:
230V ±10% 47Hz to 63Hz;

For nominal power 3000W
and higher:
400V ±10% 47Hz to 63Hz;
three-phase
Ambient temperature:
0°C to +40°C
12
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:
from approx. 0,1% to 100%
 Setting resolution:

±1 x 10-4
Residual ripple (0 - 10MHz):
<2 x 10-4pp + 200mVpp
 Recovery time:
Voltage control:
<1ms for load changes from
10% to 100% or from 100% to
10%.
Current control:
<10ms for load changes
causing an output change of
less than 10% of the rated
voltage
 Setting time at nominal load:
<300ms for changes of the
output voltage from 10% to
90% or 90% to 10%
 Discharge time constant for
output without load:
approx. 10sec for MCA
NCA have active down regulation.
 Deviation:
For ±10% mains voltage variation:
± 1 x 10-5
For no load / full load:
<5 x 10-4
Over 8 hours under constant
conditions:
<±2 x 10-4
Within the temperature range:
<±1 x 10-4/K
Autoranging power supplies
Series NCA / MCA from 55 V to 3000 V / 750 W to 9000 W
Type
Voltage
Current
Width
Height
Depth
Weight
NCA
750 - 55
750 W
0 -
55 V
0 -
40 A
19" / 443 mm
3 U / 133 mm
350 mm
12 kg
NCA
1500 - 55
1500 W
0 -
55 V
0 -
80 A
19" / 443 mm
3 U / 133 mm
550 mm
20 kg
NCA
3000 - 55
3000 W
0 -
55 V
0 -
160 A
19" / 443 mm
3 U / 133 mm
650 mm
25 kg
750 W
0 -
150 V
0 -
15 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
3)
MCA
750 - 150
MCA
1500 - 150
1500 W
0 -
150 V
0 -
30 A
19" / 443 mm
4 U / 177 mm
450 mm
17 kg
MCA
3000 - 150
3)
3000 W
0 -
150 V
0 -
60 A
19" / 443 mm
4 U / 177 mm
650 mm
37 kg
MCA
6000 - 150
3)
6000 W
0 -
150 V
0 -
120 A
19" / 443 mm
8 U / 355 mm
650 mm
61 kg
MCA
9000 - 150
3)
9000 W
0 -
150 V
0 -
180 A
19" / 443 mm
12 U / 535 mm
650 mm
90 kg
MCA
750 - 400
750 W
0 -
400 V
0 -
6 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
MCA
1500 - 400
1500 W
0 -
400 V
0 -
12 A
19" / 443 mm
4 U / 177 mm
450 mm
17 kg
MCA
3000 - 400
3)
3000 W
0 -
400 V
0 -
24 A
19" / 443 mm
4 U / 177 mm
650 mm
35 kg
MCA
6000 - 400
3)
6000 W
0 -
400 V
0 -
48 A
19" / 443 mm
8 U / 355 mm
650 mm
61 kg
MCA
9000 - 400
3)
9000 W
0 -
400 V
0 -
72 A
19" / 443 mm
12 U / 535 mm
650 mm
90 kg
MCA
750 - 750
MCA
1500 - 750
MCA
3000 - 750
MCA
6000 - 750
MCA
9000 - 750
MCA
750 - 1500
MCA
1500 - 1500
MCA
3000 - 1500
MCA
6000 - 1500
MCA
9000 - 1500
MCA
750 - 3000
MCA
1500 - 3000
MCA
3000 - 3000
MCA
MCA


750 W
0 -
750 V
0 -
3 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
1500 W
0 -
750 V
0 -
6 A
19" / 443 mm
4 U / 177 mm
450 mm
16 kg
3)
3000 W
0 -
750 V
0 -
12 A
19" / 443 mm
4 U / 177 mm
650 mm
33 kg
3)
6000 W
0 -
750 V
0 -
24 A
19" / 443 mm
8 U / 355 mm
650 mm
61 kg
3)
9000 W
0 -
750 V
0 -
36 A
19" / 443 mm
12 U / 535 mm
650 mm
90 kg

750 W
0 -
1500 V
0 -
1,5 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
1500 W
0 -
1500 V
0 -
3 A
19" / 443 mm
4 U / 177 mm
450 mm
17 kg
3)
3000 W
0 -
1500 V
0 -
6 A
19" / 443 mm
4 U / 177 mm
650 mm
32 kg
3)
6000 W*
0 -
1500 V
0 -
12 A
19" / 443 mm
8 U / 355 mm
650 mm
61 kg
3)
9000 W*
0 -
1500 V
0 -
18 A
19" / 443 mm
12 U / 535 mm
650 mm
90 kg

750 W*
0 -
3000 V
0 -
750 mA
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
1500 W*
0 -
3000 V
0 -
1,5 A
19" / 443 mm
4 U / 177 mm
450 mm
17 kg
3)
3000 W*
0 -
3000 V
0 -
3 A
19" / 443 mm
4 U / 177 mm
650 mm
32 kg
6000 - 3000
3)
6000 W*
0 -
3000 V
0 -
6 A
19" / 443 mm
8 U / 355 mm
650 mm
61 kg
9000 - 3000
3)
9000 W*
0 -
3000 V
0 -
9 A
19" / 443 mm
12 U / 535 mm
650 mm
90 kg

3) Three phase mains connection
 short term delivery (components on stock)
*Fields marked with * power supply types do not have a floating output.
For orders of power supplies with 3000V nominal voltage please state the required output polarity.
For 1500V and higher, the mating high voltage connectors are included in the scope of delivery. Mating high voltage cables you‘ll find beginning
with page 51.
Possible Options:
 Analog programming (One of the outputs on “0V” - potential; see also page 44)
 Analog programming, floating (see page 44)
 Computer interfaces - IEEE 488, RS 232, RS 422, Profibus DP, USB, LAN (more on request) (see page 46)
More options and special solutions on request. Some options may involve changes to the description of the unit - especially concerning the mechanical design.
13
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Medium voltage power supplies
Series MCP from 125 V to 2000 V / 14 W to 15000 W
Floating output
(rear side)
Design example
MCP 15000 - 2000
2000V / 7A
MCP 140 - 1250
1250V / 100mA
Features:
 Compact size and light weight
 Efficiency approx. 90%
 Short-circuit & flashover proof
 Unlimited operation with rated







current in a short-circuit condition
Unlimited operation with rated
power
Voltage and current regulation
with automatic sharp transition, control modes indicated
by LEDs
Adjustable overvoltage protection (limitation of set value)
4½ digit DVM's for voltage
and current for all models
Voltage and current setting by
means of 10-turn potentiometers with precision scale; the
adjusting knob can be locked
Indication of set point values
by means of button for switchover of the displays
Set point adjustment possible
with locked output, release of
output voltage by means of an
"ON" / "OFF" switch
 Suitable for inductive and
capacitive loads
 Suitable for photomultipliers
Function:
In principle, the rectified line
voltage drives a square wave
generator of fixed frequency,
whose AC voltage is transformed, rectified and filtered,
producing the output voltage.
For regulation, the square wave
voltage is pulse width modulated.
A low residual ripple of the output voltage, together with a high
stability, high regulation speed
and a low stored energy are all
achieved by virtue of the high
switching frequency.
Design:
 ½19" or 19" table-top case
(depending on output voltage
and power).
 19" Rack-adapters for mounting into a 19" rack are available as accessory.
Output:
 Output isolation:
The output is floating. Either
the positive or the negative
terminal may be connected to
earth. Units with nominal
voltage up to 350V are isolated for ±500V. Units with nominal voltage from 650V up to
2000V are isolated for
±2000V. (Not valid with the
option analog programming.
If the floating function should
remain, the floating analog
programming must be chosen).
 Output terminals:
All output terminals are located at the rear side of the unit.
Units up to 350V nominal
voltage are equipped with
4mm safety connectors. For
nominal voltage of 650V and
higher, high voltage connectors with the appropriate dielectric strength are delivered
with the power supply.
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 63Hz

For 2800W and higher:
400V ±10% 47Hz to 63Hz,
three-phase
Ambient temperature:
0°C to +40°C
(continued on next page)
14
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Medium voltage power supplies
Series MCP from 125 V to 2000 V / 14 W to 15000 W
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:
from approx. 0,1% to 100%
 Setting resolution:
±1 x 10-4
 Residual ripple (0-10MHz):
Up to 350W nominal power:
<5 x 10-5pp + 50mVpp

Current control:
<10ms for load changes
causing an output change of
less than 10% of the rated
voltage
 Setting time at nominal load:
<300ms for changes of the
output voltage from 10% to
90% or 90% to 10%
 Discharge time constant for

For 700W and higher:
<2 x 10-4pp + 200mVpp
Recovery time:
Voltage control:
<1ms for load changes from
10% to 100% or from 100% to
10%
Type
output without load: approx.
2sec. to 10sec., depending
on type
Deviation:
For ±10% mains voltage
variation:
<± 1 x 10-5
For no load / full load:
<1 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-4
Voltage
Current
Within the temperature range:
<±1 x 10-4 /K
Possible Options:
 Coarse/fine-potentiometers
(99% / 1%) for more accurate
adjustment of voltage and / or
current
 Analog programming (One of
the outputs on “0V” - potential;
see also page 44)
 Analog programming, floating
(see page 44)
 DVM with better resolution
Width
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
Lower ripple (see page 48)

 Higher stability (see page 48)
 Lower stored energy (see
page 48)
 Power limitation (see page
48)
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
Height
Depth
Weight
MCP
35 - 125

0 -
125 V
0 -
250 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
MCP
140 - 125

0 -
125 V
0 -
1 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
MCP
350 - 125

0 -
125 V
0 -
2,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
MCP
700 - 125

0 -
125 V
0 -
5 A
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
MCP
1400 - 125

0 -
125 V
0 -
10 A
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
2800 - 125
3)
0 -
125 V
0 -
20 A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 125
3)
0 -
125 V
0 -
40 A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 125
3)
0 -
125 V
0 -
80 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 125
3)
0 -
125 V
0 -
120 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
MCP
35 - 200

0 -
200 V
0 -
150 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
MCP
140 - 200

0 -
200 V
0 -
600 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
MCP
350 - 200

0 -
200 V
0 -
1,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
MCP
700 - 200

0 -
200 V
0 -
3 A
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
MCP
1400 - 200

0 -
200 V
0 -
6 A
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
2800 - 200
3)
0 -
200 V
0 -
12 A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 200
3)
0 -
200 V
0 -
25 A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 200
3)
0 -
200 V
0 -
50 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 200
3)
0 -
200 V
0 -
75 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
MCP
35 - 350

0 -
350 V
0 -
100 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
MCP
140 - 350

0 -
350 V
0 -
400 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
MCP
350 - 350

0 -
350 V
0 -
1 A
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
MCP
700 - 350

0 -
350 V
0 -
2 A
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
MCP
1400 - 350

0 -
350 V
0 -
4 A
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
2800 - 350
3)
0 -
350 V
0 -
8 A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 350
3)
0 -
350 V
0 -
14 A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 350
3)
0 -
350 V
0 -
28 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 350
3)
0 -
350 V
0 -
42 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
15
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Medium voltage power supplies
Series MCP from 125 V to 2000 V / 14 W to 15000 W
Type
MCP
Voltage
14 - 650
MCP
35 - 650
MCP
140 - 650
Current
 0 0 0-
650 V
0-
650 V
650 V
 0 0 0-
Width
Height
Depth
Weight
20 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
0-
50 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
0-
200 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
650 V
0-
500 mA
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
650 V
0-
1A
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
650 V
0-
2A
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
350 - 650
MCP
700 - 650
MCP
1400 - 650
MCP
2800 - 650
3)
0-
650 V
0-
4A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 650
3)
0-
650 V
0-
7A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 650
3)
0-
650 V
0-
15 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 650
3)
0-
650 V
0-
22,5 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
 0 0 0-
1250 V
0-
10 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
1250 V
0-
25 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
1250 V
0-
100 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
 0 0 0-
1250 V
0-
250 mA
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
1250 V
0-
500 mA
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
MCP
14 - 1250
MCP
35 - 1250
MCP
140 - 1250
MCP
350 - 1250
MCP
700 - 1250
MCP
1400 - 1250
1250 V
0-
1A
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
2800 - 1250
3)
0-
1250 V
0-
2A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 1250
3)
0-
1250 V
0-
4A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 1250
3)
0-
1250 V
0-
8A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 1250
3)
0-
1250 V
0-
12 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
MCP
14 - 2000
2000 V
0-
6 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
MCP
35 - 2000
2000 V
0-
15 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
MCP
140 - 2000
 0 0 0-
2000 V
0-
60 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
MCP
350 - 2000
 0 0 0-
2000 V
0-
150 mA
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
2000 V
0-
300 mA
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
2000 V
0-
600 mA
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
MCP
700 - 2000
MCP
1400 - 2000
MCP
2800 - 2000
3)
0-
2000 V
0-
1,2 A
19" / 443 mm
3 U / 133 mm
550 mm
23 kg
MCP
5000 - 2000
3)
0-
2000 V
0-
2,5 A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
MCP
10000 - 2000
3)
0-
2000 V
0-
5A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
MCP
15000 - 2000
3)
0-
2000 V
0-
7A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
3) Three phase mains connection
 short term delivery (components on stock)
For 650V and higher units, the mating high voltage connectors are included in the scope of delivery. Mating high voltage cables you‘ll find beginning with page 51.
16
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Medium voltage power supplies thyristor regulated
Series MYN from 650 V to 2000 V / 7kW to 70 kW
Design examples
MYN 14000 - 650
650V / 20A
Features:
 Simple construction
 Extremely robust
 High efficiency
 Short circuit proof and unlim





ited operation with full current
in short circuit condition
Voltage and current regulation
with automatic and sharp
transition; control mode indicated by LEDs
Voltage and current setting
with 10-turn potentiometers
with precision scale; the adjusting knob can be locked
Limitation of inrush current on
switching on
Suitable also for inductive and
capacitive loads
Interlock loop to monitor the
external load and internal loop
as a standard
Elapsed-hour meter as a
standard
Function:
A transformer is used to transform the mains supply to high
voltage. Either on the primary
side or on the secondary side of
this transformer a phase controlled thyristor rectifier circuit is
fitted. A series LC filter is used
to smooth the resulting rectified
voltage.
MYN 105000 - 1500
1500V / 70A
Design:
 Depending on voltage and
power, the units are built as
single or double 19" cabinets
of various height. The side
covers are detachable, the
rear door is lockable.
 All cabinets are equipped
with
fork-lift-compatible
plinths and removable craneeyes.
 Single 19"- cabinets up to
38U are easily transportable
by fork-lift.
 Cooling is carried out via
convection or built-in fans,
with the air being exhausted
(depending upon type) either
via the rear or the top.
Technical Data:
 Mains connection:
Output:
 Output isolation:
The output is floating with
isolation voltage ±2000V
against earth. Either the positive or the negative terminal
may be connected to earth.
(Not valid with the option
analog programming)
 Output terminals:
All output terminals are located at the rear side of the
cabinet. For Output current
up to 10A high voltage connectors with the appropriate
dielectric strength are installed. Mating connectors
are delivered with the power
supply. For higher current
feed through terminals or bus
bars.


400V ±10% 47Hz to 53Hz,
three-phase
Ambient temperature:
0°C to +40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer to
Definitions and Terms on page
54.)
 Setting range:
from approx. 1% to 100%
 Setting resolution:



±1 x 10-4
Residual ripple (0 - 10MHz):
<1 x 10-2pp + 100mVpp
Recovery time:
<100ms to 500ms (depending
on type) for load variations of
±10%
Setting time at nominal load:
<100ms to 2sec (depending
on type) for changes of the
output voltage from 10% to
90% or 90% to 10%
Discharge time constant
for output without load:
approx. 5sec. to 60sec., depending on type
 Deviation:
For ±10% mains voltage variation:
<±1 x 10-4
For no load / full load:
<±1 x 10-3
Over 8 hours under constant
conditions:
<±3 x 10-4
Within the temperature range:
<±3 x 10-4/K
Possible Options:
 Analog programming (One of
the outputs on “0V” - potential; see also page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Internal resistance setting and
regulation (see page 48)
 Power regulation with display
(see page 48)
 Roller blades for cabinet units
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
17
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Medium voltage power supplies thyristor regulated
Series MYN from 650 V to 2000 V / 7kW to 70 kW
Type
Voltage
Current
Width
Height
Depth
Weight
MYN
21000 - 650
0 -
650 V
0 -
30 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
MYN
28000 - 650
0 -
650 V
0 -
40 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
MYN
35000 - 650
0 -
650 V
0 -
50 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
MYN
70000 - 650
0 -
650 V
0 -
100 A
19" / 600 mm
38 U / 2000 mm
800 mm
1400 kg
MYN
21000 - 1250
0 -
1250 V
0 -
15 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
MYN
28000 - 1250
0 -
1250 V
0 -
20 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
MYN
35000 - 1250
0 -
1250 V
0 -
25 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
MYN
70000 - 1250
0 -
1250 V
0 -
50 A
19" / 600 mm
38 U / 2000 mm
800 mm
1400 kg
MYN
21000 - 2000
0 -
2000 V
0 -
10 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
MYN
28000 - 2000
0 -
2000 V
0 -
12 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
MYN
35000 - 2000
0 -
2000 V
0 -
15 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
MYN
50000 - 2000
0 -
2000 V
0 -
25 A
19" / 600 mm
38 U / 2000 mm
800 mm
1200 kg
Mating high voltage connectors for units with up to 10A output current are included in the scope of delivery. Mating high voltage cables you‘ll find
beginning with page 51.
For units with higher output currents, the output will be carried out according to your wishes so that your load can be optimally connected.
18
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
High voltage power supplies
Series HCP from 3,5 kV to 300 kV / 14 W to 15000 W
 Output terminals:
All output terminals are located at the rear side of the unit.
High voltage connectors with
the
appropriate
dielectric
strength are delivered with the
power supply. For nominal
voltage of 65kV and higher the
HV- plug will be delivered
ready mounted to 3m cable.
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 63Hz
Design example
HCP 140 - 12500
12500V / 10mA
Features:
 Compact size and light weight
 Efficiency approx. 90%
 For units from 12.5kV nominal
voltage on, all HV components
are
moulded
in
(removable) silicon
Short-circuit & flashover proof

 Unlimited operation with rated









current in a short-circuit condition
Unlimited operation with rated
power
Voltage and current regulation
with automatic sharp transition, control modes indicated
by LEDs
Adjustable overvoltage protection (limitation of set value)
4½ digit DVM's for voltage
and current for all models
Voltage and current setting by
means of 10-turn potentiometers with precision scale; the
adjusting knob can be locked
Indication of set point values
by means of button for switchover of the displays
Set point adjustment possible
with locked output, release of
output voltage by means of
"ON" / "OFF" switch
Suitable also for inductive and
capacitive loads
Suitable for photomultipliers
Function:
In principle, the rectified line
voltage drives a square wave
generator of fixed frequency,
whose AC voltage is transformed, rectified and filtered,
producing the output voltage.
For regulation, the square wave
voltage is pulse width modulated.
A low residual ripple of the
output voltage, together with a
high stability, high regulation
speed and a low stored energy
are all achieved by virtue of the
high switching frequency.
Design:
 ½19" or 19" table-top case
(depending on output voltage
and power).
 19" Rack-adapters for mounting into a 19" rack are available as accessory.
Output:
 Output isolation:
The required output polarity
must be stated with the order.
The requested output polarity
will then be available at the
HV connector and the “0V”
terminal will be firmly connected to earth. If required,
the "0V" terminal can be
made floating against earth
up to ± 300V. A polarity reversal switch is optionally
available.

For 2800W and higher:
400V ±10% 47Hz to 63Hz,
three-phase
Ambient temperature:
0°C to +40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer to
Definitions and Terms on page
54.)
 Setting range:
from approx. 0,1% to 100%
 Setting resolution:
±1 x 10-4
 Residual ripple (0 - 10MHz):

<1 x 10-4pp + 50mVpp,
typ. 5 x 10-5pp
Recovery time:
Voltage control:
<1ms for load changes from
10% to 100% or from 100% to
10%


Current control:
<10ms for load changes causing an output change of less
than 10% of the rated voltage
Setting time at nominal load:
<500ms for changes of the
output voltage from 10% to
90% or 90% to 10%
Discharge time constant for
output without load:
approx. 2sec. to 10sec., depending on type
 Deviation:
For ±10% mains voltage variation:
<± 1 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-4
Within the temperature range:
<±1,5 x 10-4/K
Possible Options:
 Coarse/fine-potentiometers
(99% / 1%) for more accurate
adjustment of voltage and / or
current
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Electronically controlled polarity reversal switch (Up to
35kV remotely controllable
when ordered with a programming or interface, for higher
voltages, please ask us).
Please specify the output
polarity, when ordering without polarity reversal switch.
(see page 48)
 Lower ripple (see page 48)
 Higher stability (see page 48)
 Lower stored energy (see
page 48)
 Power limitation (see page
48)
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
19
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
High voltage power supplies
Series HCP from 3,5 kV to 300 kV / 14 W to 15000 W
Type
HCP
Voltage
Current
Width
Height
Depth
Weight
14 - 3500
 0 -
3500 V
0 -
4 mA
½19" / 222 mm
3 U / 133 mm
350 mm
3 kg
HCP
35 - 3500
 0 -
3500 V
0 -
10 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
HCP
140 - 3500
 0 -
3500 V
0 -
40 mA
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
HCP
350 - 3500
 0 -
3500 V
0 -
100 mA
½19" / 222 mm
3 U / 133 mm
450 mm
7 kg
HCP
700 - 3500
 0 -
3500 V
0 -
200 mA
19" / 443 mm
3 U / 133 mm
350 mm
11 kg
HCP
1400 - 3500
 0 -
3500 V
0 -
400 mA
19" / 443 mm
3 U / 133 mm
450 mm
13 kg
HCP
2800 - 3500
3)
0 -
3500 V
0 -
800 mA
19" / 443 mm
3 U / 133 mm*
550 mm**
25 kg
HCP
5000 - 3500
3)
0 -
3500 V
0 -
1,5 A
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCP
10000 - 3500
3)
0 -
3500 V
0 -
3 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
HCP
15000 - 3500
3)
0 -
3500 V
0 -
4,5 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
HCP
14 - 6500
 0 -
6500 V
0 -
2 mA
½19" / 222 mm
3 U / 133 mm
350 mm
3 kg
HCP
35 - 6500
 0 -
6500 V
0 -
5 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
HCP
140 - 6500
 0 -
6500 V
0 -
20 mA
½19" / 222 mm
3 U / 133 mm
350 mm
6 kg
HCP
350 - 6500
 0 -
6500 V
0 -
50 mA
½19" / 222 mm
3 U / 133 mm
450 mm
7 kg
HCP
700 - 6500
 0 -
6500 V
0 -
100 mA
19" / 443 mm
3 U / 133 mm
350 mm
11 kg
HCP
1400 - 6500
 0 -
6500 V
0 -
200 mA
19" / 443 mm
3 U / 133 mm
450 mm
13 kg
HCP
2800 - 6500
3)
0 -
6500 V
0 -
400 mA
19" / 443 mm
3 U / 133 mm*
650 mm
25 kg
HCP
5000 - 6500
3)
0 -
6500 V
0 -
750 mA
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCP
10000 - 6500
3)
0 -
6500 V
0 -
1,5 A
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
HCP
15000 - 6500
3)
0 -
6500 V
0 -
2,3 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
14 - 12500
 0 -
12500 V
0 -
1 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
HCP
35 - 12500
 0 -
12500 V
0 -
2,5 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
HCP
140 - 12500
 0 -
12500 V
0 -
10 mA
½19" / 222 mm
3 U / 133 mm
350 mm
7 kg
HCP
350 - 12500
 0 -
12500 V
0 -
25 mA
19" / 443 mm
3 U / 133 mm
450 mm
11 kg
HCP
700 - 12500
 0 -
12500 V
0 -
50 mA
19" / 443 mm
3 U / 133 mm
550 mm
16 kg
HCP
1400 - 12500
 0 -
12500 V
0 -
100 mA
19" / 443 mm
3 U / 133 mm
650 mm
21 kg
HCP
2800 - 12500
3)
0 -
12500 V
0 -
200 mA
19" / 443 mm
6 U / 266 mm
550 mm
35 kg
HCP
5000 - 12500
3)
0 -
12500 V
0 -
400 mA
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCP
10000 - 12500
3)
0 -
12500 V
0 -
800 mA
19" / 443 mm
9 U / 399 mm
650 mm
75 kg
HCP
15000 - 12500
3)
0 -
12500 V
0 -
1,2 A
19" / 443 mm
12 U / 535 mm
650 mm
110 kg
HCP
14 - 20000
 0 -
20000 V
0 -
0,6 mA
½19" / 222 mm
3 U / 133 mm
350 mm
4 kg
HCP
35 - 20000
 0 -
20000 V
0 -
1,5 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
HCP
140 - 20000
 0 -
20000 V
0 -
6 mA
½19" / 222 mm
3 U / 133 mm
350 mm
7 kg
HCP
350 - 20000
 0 -
20000 V
0 -
15 mA
19" / 443 mm
3 U / 133 mm
450 mm
11 kg
HCP
700 - 20000
 0 -
20000 V
0 -
30 mA
19" / 443 mm
3 U / 133 mm
550 mm
16 kg
HCP
1400 - 20000
0 -
20000 V
0 -
60 mA
19" / 443 mm
3 U / 133 mm
650 mm
21 kg
HCP
2800 - 20000
3)
0 -
20000 V
0 -
120 mA
19" / 443 mm
6 U / 266 mm
650 mm
35 kg
HCP
4200 - 20000
3)
0 -
20000 V
0 -
200 mA
19" / 443 mm
6 U / 266 mm
650 mm
45 kg
HCP
3) Three phase mains connection
Mating high voltage connectors are included in the scope of delivery. Other mating high voltage
cables you‘ll find beginning with page 51.
 short term delivery (components on stock)
All units up to 35kV optionally available with electronically controlled polarity reversal switch and
for 65kV with manually operated polarity reversal switch. For orders without polarity switch
please state the required output polarity.
20
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
High voltage power supplies
Series HCP from 3,5 kV to 300 kV / 14 W to 15000 W
Design example
HCP 15000 - 12500
12500V / 1,2A
Type
Voltage
Current
HCP
35 - 35000

0-
35000 V
0-
HCP
140 - 35000

0-
35000 V
HCP
350 - 35000

0-
35000 V
HCP
700 - 35000

0-
HCP
1400 - 35000
HCP
2800 - 35000
3)
HCP
4200 - 35000
3)
HCP
Width
Height
Depth
Weight
1 mA
19" / 443 mm
3 U / 133 mm
450 mm
10 kg
0-
4 mA
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
0-
10 mA
19" / 443 mm
3 U / 133 mm
450 mm
17 kg
35000 V
0-
20 mA
19" / 443 mm
3 U / 133 mm
550 mm
20 kg
0-
35000 V
0-
40 mA
19" / 443 mm
3 U / 133 mm
650 mm
25 kg
0-
35000 V
0-
80 mA
19" / 443 mm
6 U / 266 mm
650 mm
45 kg
0-
35000 V
0-
120 mA
19" / 443 mm
7 U / 310 mm
650 mm
50 kg
35 - 65000
0-
65000 V
0-
0,5 mA
19" / 443 mm
3 U / 133 mm*
450 mm**
17 kg
HCP
140 - 65000
0-
65000 V
0-
2 mA
19" / 443 mm
3 U / 133 mm*
450 mm**
21 kg
HCP
350 - 65000
0-
65000 V
0-
5 mA
19" / 443 mm
6 U / 266 mm
450 mm**
45 kg
HCP
700 - 65000
0-
65000 V
0-
10 mA
19" / 443 mm
8 U / 355 mm*
550 mm**
55 kg
HCP
1400 - 65000
0-
65000 V
0-
20 mA
19" / 443 mm
8 U / 355 mm*
650 mm
70 kg
HCP
2800 - 65000
0-
65000 V
0-
40 mA
19" / 443 mm
8 U / 355 mm*
650 mm
80 kg
3)
HCP
140 - 100000
0-
100000 V
0-
1 mA
19" / 443 mm
5 U / 221 mm
550 mm
50 kg
HCP
350 - 100000
0-
100000 V
0-
3 mA
19" / 443 mm
5 U / 221 mm
550 mm
55 kg
HCP
700 - 100000
0-
100000 V
0-
6 mA
19" / 443 mm
8 U / 355 mm
550 mm
73 kg
HCP
1400 - 100000
0-
100000 V
0-
12 mA
19" / 443 mm
9 U / 399 mm
550 mm
90 kg
HCP
140 - 150000
0-
150000 V
0-
0,5 mA
19" / 443 mm
10 U /433 mm
750 mm
110 kg
HCP
350 - 150000
0-
150000 V
0-
2 mA
19" / 443 mm
10 U /433 mm
750 mm
130 kg
HCP
700 - 150000
0-
150000 V
0-
4 mA
19" / 443 mm
10 U /433 mm
750 mm
140 kg
HCP
1400 - 150000
0-
150000 V
0-
8 mA
19" / 443 mm
12 U /535 mm
750 mm
160 kg
HCP
140 - 200000
0-
200000 V
0-
0,4 mA
19" / 443 mm
12 U /535 mm
750 mm
160 kg
HCP
350 - 200000
0-
200000 V
0-
1,5 mA
19" / 600 mm
29 U /1500 mm
600 mm
180 kg
HCP
700 - 200000
0-
200000 V
0-
3 mA
19" / 600 mm
38 U /2000 mm
800 mm
200 kg
HCP
1400 - 200000
0-
200000 V
0-
6 mA
19" / 600 mm
38 U /2000 mm
800 mm
220 kg
HCP
140 - 300000
0-
300000 V
0-
0,3 mA
19" / 600 mm
29 U /1500 mm
750 mm
180 kg
HCP
350 - 300000
0-
300000 V
0-
1 mA
19" / 600 mm
38 U /1500 mm
600 mm
200 kg
HCP
700 - 300000
0-
300000 V
0-
2 mA
19" / 600 mm
38 U /2000 mm
800 mm
220 kg
HCP
1400 - 300000
0-
300000 V
0-
4 mA
19" / 600 mm
38 U /2000 mm
800 mm
250 kg
*) With polarity reversal switch
these units will be 2U higher.
**) With polarity reversal switch
these units will be 100mm deeper.
21
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
High voltage power supplies, high power
Series HCH from 650 V to 300 kV / to 50 kW
Design example
 Recovery time:
Voltage control:
<1ms for load changes from
10% to 100% or from 100% to
10%
HCH 50000 - 20000
20kV / 2,5A

 Output terminals:
All output terminals are located at the rear side of the
cabinet or at the top of the HV
container. High voltage connectors with the appropriate
dielectric strength are delivered with the power supply
for units with output current
up to 10A. For units with
higher output currents, the
output will be carried out
according to your wishes so
that your load can be optimally connected.
For nominal voltage of 65kV
and higher the HV- plug will be
delivered ready mounted to
10m cable.
Features:
 Efficiency up to 90%
 Short-circuit & flashover proof
 In units up to 20kV nominal






voltage, the HV-components
are isolated in air. From 35kV
on the isolation is with oil.
Unlimited operation with rated
current in a short-circuit condition
Unlimited operation with rated
power
Voltage and current regulation
with automatic sharp transition, control modes indicated
by LEDs
Limitation of inrush current on
switching on
Voltage and current setting by
means of 10-turn potentiometers with precision scale; the
adjusting knob can be locked
Interlock loop to monitor the
external load and internal loop
as a standard
Function:
In principle, the rectified line
voltage drives a square wave
generator of fixed frequency,
whose AC voltage is transformed, rectified and filtered,
producing the output voltage.
For regulation, the square wave
voltage is pulse width modulated.
Design:
 Depending on Voltage and
Power the units are built as
single or double 19" cabinets,
or as a oil- filled HV container
with the power electronics on
the top or in a separate rack.
Output:
 Output isolation:
The required output polarity
must be stated with the order.
The requested output polarity
will then be available at the
HV connector and the “0V”
terminal will be firmly connected to earth. If required, the
"0V" terminal can be made
floating against earth up to ±
50V. A polarity reversal switch
is optionally available.
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 63Hz

For 2800W and higher:
400V ±10% 47Hz to 63Hz,
three-phase
Ambient temperature:
0°C to +40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:


from approx. 0,1% to 100%
Setting resolution:
±1 x 10-4
Residual ripple (0 - 10 MHz):
<2 x 10-3pp + 50mVpp
22
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de


Current control:
<10ms for load changes causing an output change of less
than 10% of the rated voltage
Setting time at nominal load:
<500ms for changes of the
output voltage from 10% to
90% or 90% to 10%
Discharge time constant
for output without load:
approx. 1sec. to 10sec., depending on type
Deviation:
For ±10% mains voltage variation:
<± 1 x 10-4
For no load / full load:
<5 x 10-4
Over 8 hours under constant
conditions:
<±2 x 10-4
Within the temperature range:
<±1,5 x 10-4 /K
Possible Options:
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 44)
 Polarity reversal switch.
Please specify the output
polarity, when ordering without polarity reversal switch.
(see page 48)
 Lower ripple (see page 48)
 Higher stability (see page 48)
 Shorter setting time (see page
48)
 Roller blades for cabinet units
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
High voltage power supplies, high power
Series HCH from 650 V to 300 kV / to 50 kW
Type
Voltage
Current
Width
Height
Depth
Weight
HCH
20000 - 650
3)
0 -
650 V
0 -
30 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 650
3)
0 -
650 V
0 -
45 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 650
3)
0 -
650 V
0 -
60 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 650
3)
0 -
650 V
0 -
75 A
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 1250
3)
0 -
1250 V
0 -
16 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 1250
3)
0 -
1250 V
0 -
24 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 1250
3)
0 -
1250 V
0 -
32 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 1250
3)
0 -
1250 V
0 -
40 A
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 2000
3)
0 -
2000 V
0 -
10 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 2000
3)
0 -
2000 V
0 -
15 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 2000
3)
0 -
2000 V
0 -
20 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 2000
3)
0 -
2000 V
0 -
25 A
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 3500
3)
0 -
3500 V
0 -
6 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 3500
3)
0 -
3500 V
0 -
8 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 3500
3)
0 -
3500 V
0 -
12 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 3500
3)
0 -
3500 V
0 -
15 A
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 6500
3)
0 -
6500 V
0 -
3 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 6500
3)
0 -
6500 V
0 -
4 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 6500
3)
0 -
6500 V
0 -
6 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 6500
3)
0 -
6500 V
0 -
7,5 A
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 12500
3)
0 -
12500 V
0 -
1,6 A
19" / 600 mm
29 U / 1500 mm
600 mm
240 kg
HCH
30000 - 12500
3)
0 -
12500 V
0 -
2,4 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 12500
3)
0 -
12500 V
0 -
3,2 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 12500
3)
0 -
12500 V
0 -
4 A
2x 19" / 1200 mm
38 U / 2000 mm
800 mm
480 kg
HCH
10000 - 20000
3)
0 -
20000 V
0 -
500 mA
19" / 600 mm
29 U / 1500 mm
600 mm
120 kg
HCH
15000 - 20000
3)
0 -
20000 V
0 -
750 mA
19" / 600 mm
29 U / 1500 mm
600 mm
170 kg
HCH
20000 - 20000
3)
0 -
20000 V
0 -
1 A
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCH
30000 - 20000
3)
0 -
20000 V
0 -
1,5 A
19" / 600 mm
38 U / 2000 mm
800 mm
300 kg
HCH
40000 - 20000
3)
0 -
20000 V
0 -
2 A
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCH
50000 - 20000
3)
0 -
20000 V
0 -
2,5 A
2x 19" / 1200 mm
38 U / 2000 mm
800 mm
480 kg
HCH
10000 - 35000
3)
0 -
35000 V
0 -
300 mA
19" / 600 mm
38 U / 2000 mm
800 mm
390 kg
HCH
15000 - 35000
3)
0 -
35000 V
0 -
400 mA
19" / 600 mm
38 U / 2000 mm
800 mm
420 kg
HCH
20000 - 35000
3)
0 -
35000 V
0 -
600 mA
19" / 600 mm
38 U / 2000 mm
800 mm
450 kg
HCH
30000 - 35000
3)
0 -
35000 V
0 -
800 mA
2x 19" / 1200 mm
38 U / 2000 mm
800 mm
640 kg
HCH
40000 - 35000
3)
0 -
35000 V
0 -
1,2 A
2x 19" / 1200 mm
38 U / 2000 mm
800 mm
720 kg
HCH
50000 - 35000
3)
0 -
35000 V
0 -
1,5 A
2x 19" / 1200 mm
38 U / 2000 mm
800 mm
790 kg
3) Three phase mains connection
Mating high voltage connectors for units with up to 10A output current are included in the scope of delivery. Mating high voltage cables you‘ll find
beginning with page 51. For units with higher output currents, the output will be carried out according to your wishes so that your load can be
optimally connected.
23
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
High voltage power supplies, high power
Series HCH from 650 V to 300 kV / to 50 kW
Type
Voltage
Current
Width
Height
HCH
4200 - 65000
3)
0-
65000 V
0-
60 mA
HCH
10000 - 65000
3)
0-
65000 V
0-
150 mA
19" / 600 mm
HCH
15000 - 65000
3)
0-
65000 V
0-
200 mA
19" / 600 mm
HCH
20000 - 65000
3)
0-
65000 V
0-
300 mA
HCH
30000 - 65000
3)
0-
65000 V
0-
400 mA
HCH
40000 - 65000
3)
0-
65000 V
0-
HCH
50000 - 65000
3)
0-
65000 V
HCH
2800 - 100000 3)
0-
HCH
4200 - 100000 3)
0-
HCH
10000 - 100000 3)
HCH
HCH
750 mm*
Weight
630 mm*
240 kg
38 U / 2000 mm
800 mm
460 kg
38 U / 2000 mm
800 mm
480 kg
19" / 600 mm
38 U / 2000 mm
800 mm
500 kg
19" / 600 mm
29 U / 1500 mm
600 mm** 170/430 kg
600 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 200/470 kg
0-
750 mA
19" / 600 mm
38 U / 2000 mm
800 mm** 250/500 kg
100000 V
0-
25 mA
800 mm*
1200 mm*
760 mm*
550 kg
100000 V
0-
40 mA
800 mm*
1200 mm*
760 mm*
550 kg
0-
100000 V
0-
100 mA
19" / 600 mm
38 U / 2000 mm
800 mm
500 kg
15000 - 100000 3)
0-
100000 V
0-
150 mA
19" / 600 mm
38 U / 2000 mm
800 mm
520 kg
20000 - 100000 3)
0-
100000 V
0-
200 mA
19" / 600 mm
38 U / 2000 mm
800 mm
545 kg
HCH
30000 - 100000 3)
0-
100000 V
0-
300 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 170/500 kg
HCH
40000 - 100000 3)
0-
100000 V
0-
400 mA
19" / 600 mm
31 U / 2000 mm
600 mm** 200/550 kg
HCH
50000 - 100000 3)
0-
100000 V
0-
500 mA
19" / 600 mm
38 U /2000 mm
800 mm** 250/600 kg
HCH
2800 - 150000 3)
0-
150000 V
0-
15 mA
HCH
4200 - 150000 3)
0-
150000 V
0-
25 mA
HCH
10000 - 150000 3)
0-
150000 V
0-
60 mA
19" / 600 mm
20 U / 1100 mm
600 mm** 100/600 kg
HCH
15000 - 150000 3)
0-
150000 V
0-
100 mA
19" / 600 mm
20 U / 1100 mm
600 mm** 115/600 kg
HCH
20000 - 150000 3)
0-
150000 V
0-
130 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 150/680 kg
HCH
30000 - 150000 3)
0-
150000 V
0-
200 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 170/680 kg
HCH
40000 - 150000 3)
0-
150000 V
0-
250 mA
19" / 600 mm
29 U / 1500 mm
800 mm** 200/680 kg
HCH
50000 - 150000 3)
0-
150000 V
0-
300 mA
19" / 600 mm
38 U / 2000 mm
800 mm** 250/680 kg
HCH
2800 - 200000 3)
0-
200000 V
0-
12 mA
955 mm*
1650 mm*
850 mm*
960 kg
HCH
4200 - 200000 3)
0-
200000 V
0-
20 mA
955 mm*
1830 mm*
850 mm*
1000 kg
HCH
10000 - 200000 3)
0-
200000 V
0-
50 mA
19" / 600 mm
20 U / 1100 mm
600 mm** 100/650 kg
HCH
15000 - 200000 3)
0-
200000 V
0-
75 mA
19" / 600 mm
20 U / 1100 mm
600 mm** 115/650 kg
HCH
20000 - 200000 3)
0-
200000 V
0-
100 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 150/750 kg
HCH
30000 - 200000 3)
0-
200000 V
0-
150 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 170/750 kg
HCH
40000 - 200000 3)
0-
200000 V
0-
200 mA
19" / 600 mm
29 U / 1500 mm
600 mm** 200/850 kg
HCH
50000 - 200000 3)
0-
200000 V
0-
250 mA
19" / 600 mm
38 U / 2000 mm
800 mm** 250/850 kg
HCH
2800 - 300000 3)
0-
300000 V
0-
8 mA
1500 mm*
1000 mm*
1500 mm*
1700 kg
HCH
4200 - 300000 3)
0-
300000 V
0-
12 mA
1500 mm*
1000 mm*
1500 mm*
1700 kg
HCH
10000 - 300000 3)
0-
300000 V
0-
30 mA
Dimensions and weight on request
HCH
15000 - 300000 3)
0-
300000 V
0-
50 mA
Dimensions and weight on request
HCH
20000 - 300000 3)
0-
300000 V
0-
65 mA
Dimensions and weight on request
HCH
30000 - 300000 3)
0-
300000 V
0-
100 mA
Dimensions and weight on request
HCH
40000 - 300000 3)
0-
300000 V
0-
130 mA
Dimensions and weight on request
HCH
50000 - 300000 3)
0-
300000 V
0-
160 mA
Dimensions and weight on request
Mating high voltage connectors for these units are in scope of delivery.
Mating high voltage cables you‘ll find beginning with page 51. For units
with higher output currents, the output will be carried out according to
your wishes so that your load can be optimally connected.
HCH power supplies, over 65kV, are provided along with 10m output
cable.
700 mm*
Depth
800 mm*
800 mm*
V 0913
760 mm*
760 kg
1400 mm*
760 mm*
760 kg
*) The dimensions are valid for the high voltage part with power part.
on top. They are non-binding guidelines.
**) The dimensions are valid for the power part. The high voltage part
is housed in a separate oil filled container. Weight is stated: Power
part / High voltage container
24
©
1400 mm*
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
High voltage power supplies thyristor regulated
Series HYN from 3,5 kV to 20 kV / 21kW to 50 kW
Design example
HYN 35000 - 3500
3,5kV / 10A
Features:
 Simple construction
 Extremely robust
 High efficiency
 Short circuit proof and unlim





ited operation with full current
in short circuit condition
Voltage and current regulation
with automatic and sharp
transition;
control
modes
indicated by LEDs
Voltage and current setting
with 10-turn potentiometers
with precision scale; the adjusting knob can be locked
Limitation of inrush current on
switching on
Suitable also for inductive and
capacitive loads
Interlock loop to monitor the
external load and internal loop
as a standard
Elapsed-hour meter as a
standard
Function:
The mains voltage is transformed to high voltage potential.
Either on the primary side or on
the secondary side, a phase
cutting circuit with thyristors is
installed. The rectified voltage is
smoothed by a LC - filter.
Design:
 Depending on voltage and
power the units are built as
single or double 19" cabinets
of various height. The side
covers are detachable, the
rear door is lockable.
 All cabinets are equipped
with
fork-lift-compatible
plinths and removable craneeyes.
 Single 19"- cabinets up to
38U are easily transportable
by fork-lift.
 Cooling is carried out via
convection or built-in fans,
with the air being exhausted
(depending upon type) either
via the rear or the top.
Technical Data:
 Mains connection:
400V ±10% 47Hz to 53Hz,
three-phase
 Ambient temperature:
Output:
 Output isolation:
The required output polarity
must be stated with the order.
The requested output polarity
will then be available at the
HV connector and the “0V”
terminal will be firmly connected to earth. A polarity
reversal switch is optionally
available.
 Output terminals:
All output terminals are located at the rear side of the
cabinet. For Output current
up to 10A high voltage connectors with the appropriate
dielectric strength are installed. Mating connectors
are delivered with the power
supply.
 Residual ripple:
0°C to +40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer to
Definitions and Terms on page
54.)
 Setting range:
from approx. 1% to 100%
 Setting resolution:
±1 x 10-4



<1 x 10-2pp + 100mVpp
Recovery time:
<100ms to 500ms (depending
on type) for load variations of
±10%
Setting time at nominal load:
<100ms to 2sec (depending
on type) for changes of the
output voltage from 10% to
90% or 90% to 10%
Discharge time constant
for output without load:
approx. 5sec. to 60sec., depending on type
 Deviation:
For ±10% mains voltage variation:
<±1 x 10-4
For no load / full load:
<±1 x 10-3
Over 8 hours under constant
conditions:
<±3 x 10-4
Within the temperature range:
<±3 x 10-4 / K
Possible Options:
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, LAN,USB (more on
request) (see page 46)
 Polarity reversal switch.
Please specify the output
polarity, when ordering without polarity reversal switch.
(see page 48)
 Internal resistance setting and
regulation (see page 48)
 Power regulation with display
(see page 48)
 Roller blades for cabinet units
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
25
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
High voltage power supplies thyristor regulated
Series HYN from 3,5 kV to 20 kV / 21 kW to 50 kW
Design example
HYN 200000 - 20000
20kV / 10A
special version,
customised design,
with 20A load capacity
Type
Voltage
Current
Width
Height
Depth
Weight
HYN
21000 - 3500
0 -
3500 V
0 -
6 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
HYN
28000 - 3500
0 -
3500 V
0 -
8 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
HYN
35000 - 3500
0 -
3500 V
0 -
10 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
HYN
70000 - 3500
0 -
3500 V
0 -
20 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1400 kg
HYN
21000 - 6500
0 -
6500 V
0 -
3 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
HYN
28000 - 6500
0 -
6500 V
0 -
4 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
HYN
35000 - 6500
0 -
6500 V
0 -
5 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
HYN
70000 - 6500
0 -
6500 V
0 -
10 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1400 kg
HYN
21000 - 12500
0 -
12500 V
0 -
1,5 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
HYN
28000 - 12500
0 -
12500 V
0 -
2 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
HYN
35000 - 12500
0 -
12500 V
0 -
2,5 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
HYN
50000 - 12500
0 -
12500 V
0 -
4 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1200 kg
HYN
7000 - 20000
0 -
20000 V
0 -
300 mA
19" / 600 mm
29 U / 1500 mm
600 mm
230 kg
HYN
10500 - 20000
0 -
20000 V
0 -
500 mA
19" / 600 mm
29 U / 1500 mm
600 mm
340 kg
HYN
14000 - 20000
0 -
20000 V
0 -
600 mA
19" / 600 mm
38 U / 2000 mm
800 mm
400 kg
HYN
21000 - 20000
0 -
20000 V
0 -
1 A
19" / 600 mm
38 U / 2000 mm
800 mm
480 kg
HYN
28000 - 20000
0 -
20000 V
0 -
1,2 A
19" / 600 mm
38 U / 2000 mm
800 mm
600 kg
HYN
35000 - 20000
0 -
20000 V
0 -
1,5 A
19" / 600 mm
38 U / 2000 mm
800 mm
800 kg
HYN
50000 - 20000
0 -
20000 V
0 -
2,5 A
2 x 19" / 1200 mm
38 U / 2000 mm
800 mm
1200 kg
Mating high voltage connectors for units with up to 10A output current are included in the scope of delivery. Mating high voltage cables you‘ll find
beginning with page 51.
26
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
High voltage cassette power supplies EURO-size
Series HCE from 125 V to 35 kV / 7 W to 350 W
Design example
HCE 7 - 12500
12,5kV / 0,5mA
positive
HCE 35 - 35000
35kV / 1mA
negative
HCE 7 - 3500
3,5kV / 2mA
positive (2 units)
HCE 350 - 2000
2kV / 150mA
positive
Features:
 Compact size
 Light-weight
 For units from 6.5kV nominal










voltage on, all HV components are moulded in (removable) silicon
Short circuit and flashover
proof
Unlimited operation with rated
current in a short-circuit condition
Unlimited operation with rated
power
Voltage or current regulation
with automatic transition.
Control mode indicated by
LEDs
Screwdriver adjustment of
voltage and current on the
front panel
Standard analog programming plus HV ON/OFF input
and monitor outputs
Measuring terminals for voltage and current monitors on
the front panel
Suitable for use with capacitive loads
Suitable for use with photomultipliers
Option:
 Ten turn potentiometer for
voltage on the front panel.
Function:
In principle, the rectified line
voltage drives a square wave
generator of fixed frequency,
whose AC voltage is transformed, rectified and filtered,
producing the output voltage.
For regulation, the square wave
voltage is pulse width modulated.
Design:
 EURO-cassette
design.
Width depending on type.
 19" frames are available as
an option.
Technical Data:
 Mains connection:
230V ±10% 47Hz to 63Hz
 Ambient temperature:
0°C to +40°C
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer to
Definitions and Terms on page
54.)
 Setting range:
from approx. 0,1% to 100%
Output:
 Output isolation:
The polarity is positive or
negative and has to be indicated with the order. The
"0V" - terminal of the output is
connected to earth but may
be disconnected as needed.
When
disconnected,
the
"0V" (earthy) terminal may
float with respect to earth up
to ±125V.
 Output terminals:
Outputs are located on the
rear of the units. For units up
to 650V nominal voltage, the
output is on 4mm safety connectors.
From 1250V nominal voltage
on, HV-connectors are provided. The mating HVconnectors are delivered with
the unit.
 Setting resolution:


±1 x 10-4
Residual ripple (0-10MHZ):
In CV mode:
<1 x 10-4pp + 50mVpp,
typ. 5 x 10-5pp
In CC mode:
<5 x 10-4pp + 50mVpp
Recovery time:
Voltage control:
<1ms for load changes from
10% to 100% or from 100% to
10%

Current control:
<10ms for load changes causing an output change of less
than 10% of the rated voltage
Setting time at nominal load:
<200ms for changes of the
output voltage from 10% to
90% or 90% to 10%
 Discharge time constant
for output without load:
approx. 0,5sec. to 5sec.,
depending on type
 Deviation:
For ±10% mains voltage variation:
<± 1 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-4
Within the temperature range:
<±1,5 x 10-4 /K
Voltage and current adjustment
by screwdriver or via analog
programming.
27
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
High voltage cassette power supplies EURO-size
Series HCE from 125 V to 35 kV / 7 W to 350 W
Optionally, the front
plane
can
be
equipped with a ten
turn potentiometer
for voltage adjustment.
Rear side with mains connection, high voltage output and
analog programming as a
standard
Type
Voltage
Current
Width
Height
Depth
Weight
HCE
7 - 125
 0 -
125 V
0 -
50 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 125
 0 -
125 V
0 -
250 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 125
0 -
125 V
0 -
1 A
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 125
0 -
125 V
0 -
2,5 A
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 200
 0 -
200 V
0 -
30 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 200
 0 -
200 V
0 -
150 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 200
0 -
200 V
0 -
600 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 200
0 -
200 V
0 -
1,5 A
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 350
 0 -
350 V
0 -
20 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 350
 0 -
350 V
0 -
100 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 350
0 -
350 V
0 -
400 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 350
0 -
350 V
0 -
1 A
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 650
 0 -
650 V
0 -
10 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 650
 0 -
650 V
0 -
50 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 650
0 -
650 V
0 -
200 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 650
0 -
650 V
0 -
500 mA
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 1250
 0 -
1250 V
0 -
5 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 1250
 0 -
1250 V
0 -
25 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 1250
0 -
1250 V
0 -
100 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 1250
0 -
1250 V
0 -
250 mA
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 2000
 0 -
2000 V
0 -
3 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 2000
 0 -
2000 V
0 -
15 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 2000
0 -
2000 V
0 -
60 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 2000
0 -
2000 V
0 -
150 mA
21 U / 107 mm
6 U / 262 mm
230 mm
4,0 kg
 short term delivery (components on stock)
For 1250V and higher, mating high voltage connectors are included in the scope of delivery. Mating high voltage cables you‘ll find beginning with
page 51.
28
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
High voltage cassette power supplies EURO-size
Series HCE from 125 V to 35 kV / 7 W to 350 W
19“-(84U) frames are
available as accessory
Type
Voltage
Current
Width
Height
Depth
Weight
HCE
7 - 3500
 0 -
3500 V
0 -
2 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,2 kg
HCE
35 - 3500
 0 -
3500 V
0 -
10 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 3500
0 -
3500 V
0 -
40 mA
21 U / 107 mm
6 U / 262 mm
230 mm
3,0 kg
HCE
350 - 3500
0 -
3500 V
0 -
100 mA
28 U / 142 mm
6 U / 262 mm
230 mm
4,0 kg
HCE
7 - 6500
 0 -
6500 V
0 -
1 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,3 kg
HCE
35 - 6500
 0 -
6500 V
0 -
5 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,5 kg
HCE
140 - 6500
0 -
6500 V
0 -
20 mA
21 U / 107 mm
6 U / 262 mm
230 mm
5,0 kg
HCE
350 - 6500
0 -
6500 V
0 -
50 mA
28 U / 142 mm
6 U / 262 mm
230 mm
6,0 kg
HCE
7 - 12500
 0 -
12500 V
0 -
0,5 mA
14 U / 71 mm
3 U / 133 mm
170 mm
1,3 kg
HCE
35 - 12500
 0 -
12500 V
0 -
2,5 mA
21 U / 107 mm
3 U / 133 mm
170 mm
1,8 kg
HCE
140 - 12500
0 -
12500 V
0 -
10 mA
28 U / 142 mm
6 U / 262 mm
230 mm
5,0 kg
HCE
350 - 12500
0 -
12500 V
0 -
25 mA
28 U / 142 mm
6 U / 262 mm
230 mm
6,0 kg
HCE
7 - 20000
 0 -
20000 V
0 -
0,3 mA
21 U / 107 mm
3 U / 133 mm
170 mm
2,3 kg
HCE
35 - 20000
 0 -
20000 V
0 -
1,5 mA
21 U / 107 mm
3 U / 133 mm
170 mm
2,5 kg
HCE
140 - 20000
0 -
20000 V
0 -
6 mA
28 U / 142 mm
6 U / 262 mm
230 mm
5,0 kg
HCE
350 - 20000
0 -
20000 V
0 -
15 mA
28 U / 142 mm
6 U / 262 mm
230 mm
6,0 kg
HCE
7 - 35000
 0 -
35000 V
0 -
0,2 mA
28 U / 142 mm
3 U / 133 mm
170 mm
2,5 kg
HCE
35 - 35000
 0 -
35000 V
0 -
1 mA
28 U / 142 mm
3 U / 133 mm
170 mm
2,8 kg
HCE
140 - 35000
0 -
35000 V
0 -
4 mA
28 U / 142 mm
6 U / 262 mm
230 mm
5,0 kg
HCE
350 - 35000
0 -
35000 V
0 -
10 mA
28 U / 142 mm
6 U / 262 mm
230 mm
6,0 kg
 short term delivery (components on stock)
For 1250V and higher, mating high voltage connectors are included in the scope of delivery. Mating high voltage cables you‘ll find beginning with
page 51.
29
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Capacitor charging power supplies
Series HCK from 2 kV to 65 kV / 100 J/s to 20 kJ/s
 Setting range for the charging


Design example
HCK 200 - 12500
12500V / 30mA


Features:
 Efficiency approx. 90%
 In units of 20kV and higher,





the
HV-components
are
moulded in (removable) silicon resin. From 35kV / 5000J/
s on, the HV-components are
isolated in oil
Continuous charging or triggered charging via potential
free external trigger input
selectable (opto-coupler input
for 12 - 24V).
Charging
with
adjustable
constant current without overshoot.
Voltage and current setting by
10-turn potentiometers with
precision scale; the adjusting
knob can be locked
Suitable for continuous or
compensation charging
No external protection resistor
is required
Permanent short-circuit proof

 4½ digit DVM for charging



current and output voltage (for
table-top models)
Pre-selection of the output
voltage with display
End of charge signal, when
the final voltage is reached,
via front panel LED and a
potential-free interface for
signalling to an external control system (opto-coupler
output)
Suitable for capacitive loads
with resistive elements
 The nominal current can be
permanently supplied at maximum output voltage
Function:
The capacitor charging high
voltage DC power supplies are
designed specifically to the
requirements of capacitor charging or capacitor conditioning, i.e.
they have a more heavily designed output resistor to withstand a pulsed load and a regulating circuit, optimized for fast
switching over between current
and voltage regulation and vice
versa.
In principle, the rectified line
voltage drives a square wave
generator of fixed frequency,
whose AC voltage is transformed, rectified and filtered,
producing the output voltage.
For regulation, the square wave
voltage is pulse width modulated.
Design:
Up to 2500J/s nominal power
19" table-top case, higher power
in 19" cabinets (depending on
type) with oil isolated external
HV-container.
Output:
 Output isolation:
The polarity is positive or
negative and has to be indicated with the order.
The "0V"- terminal of the
output is connected to earth
but may be disconnected as
needed. When disconnected,
the "0V" (earthy) terminal
may float with respect to
earth up to ±300V.
 Output terminals:
For all HCK units the output
is on the rear side of the unit
or on a separate HVcontainer.
Mating
HVconnectors are included, from
35kV on, assembled with 3m
cable, from 65kV >5000J/s on
with 10m cable.
Technical Data:
 Mains connection:
Up to 800J/s nominal power:
230V ±10% 47Hz to 63Hz;
From nominal power 1600J/s
400V ±10% 47Hz to 63Hz,
three-phase
 Ambient temperature:
0°C to +40°C
 Charging power:
The specified max. charging
power (see table) will be
supplied for charging between "0" and the rated voltage. For charging of a partially discharged capacitor a
considerably higher charging
power, up to the double, can
be supplied.
30
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
voltage:
from approx. 1% to 100%
Setting resolution:
±1 x 10-4
Reproducibility of the charging voltage with respect to the
rated value:
For ±10% mains voltage variation:
<±1 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-3
Within the temperature range:
<±2 x 10-4 /K
For a repetition frequency of
<10Hz:
<±1 x 10-3
For a repetition frequency of
>10Hz:
<±1 x 10-2
Repetition frequency:
max. 100Hz
Residual ripple of the charging current:
approx. 10%pp 20kHz/40kHz)
Possible Options:
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, LAN, USB (more on
request) (see page 46)
 Polarity reversal switch available up to 1600J/s (by request for higher powers)
Please specify the output
polarity, when ordering without polarity reversal switch.
(see page 48)
 Dump switch for the output &
the load
 Higher repetition frequency
 Built-in or external discharge
circuit for pulse operation
 Higher stability and better
reproducibility (see page 48)
 Roller blades for cabinet units
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
Capacitor charging power supplies
Series HCK from 2 kV to 65 kV / 100 J/s to 20 kJ/s
Type
Voltage
Current
Charg. pow.
Width
Height
Depth
Weight
6 kg
HCK
100 - 2000
0-
2000 V
0-
100 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm
HCK
200 - 2000
0-
2000 V
0-
200 mA
200 J/s
19" / 443 mm
3 U / 133 mm
350 mm
7 kg
HCK
400 - 2000
0-
2000 V
0-
400 mA
400 J/s
19" / 443 mm
3 U / 133 mm
350 mm
11 kg
HCK
800 - 2000
0-
2000 V
0-
800 mA
800 J/s
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
HCK
1600 - 2000
3)
0-
2000 V
0-
1,6 A
1600 J/s
19" / 443 mm
6 U / 266 mm
650 mm
25 kg
HCK
2500 - 2000
3)
0-
2000 V
0-
2,5 A
2500 J/s
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCK
5000 - 2000
3)
0-
2000 V
0-
5A
5000 J/s
19" / 600 mm
9 U / 399 mm
650 mm
75 kg
HCK
7500 - 2000
3)
0-
2000 V
0-
7,5 A
7500 J/s
19" / 600 mm
12 U / 535 mm
650 mm
110 kg
HCK
10000 - 2000
3)
0-
2000 V
0-
10 A
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCK
20000 - 2000
3)
0-
2000 V
0-
20 A
20000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCK
100 - 3500
0-
3500 V
0-
50 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm
6 kg
HCK
200 - 3500
0-
3500 V
0-
100 mA
200 J/s
19" / 443 mm
3 U / 133 mm
350 mm
7 kg
HCK
400 - 3500
0-
3500 V
0-
200 mA
400 J/s
19" / 443 mm
3 U / 133 mm
350 mm
11 kg
HCK
800 - 3500
0-
3500 V
0-
400 mA
800 J/s
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
HCK
1600 - 3500
3)
0-
3500 V
0-
800 mA
1600 J/s
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCK
2500 - 3500
3)
0-
3500 V
0-
1,4 A
2500 J/s
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCK
5000 - 3500
3)
0-
3500 V
0-
2,8 A
5000 J/s
19" / 600 mm
9 U / 399 mm
650 mm
75 kg
HCK
7500 - 3500
3)
0-
3500 V
0-
4,2 A
7500 J/s
19" / 600 mm
12 U / 535 mm
650 mm
110 kg
HCK
10000 - 3500
3)
0-
3500 V
0-
5,7 A
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCK
20000 - 3500
3)
0-
3500 V
0-
11 A
20000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCK
100 - 6500
0-
6500 V
0-
30 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm
6 kg
HCK
200 - 6500
0-
6500 V
0-
60 mA
200 J/s
19" / 443 mm
3 U / 133 mm
350 mm
7 kg
HCK
400 - 6500
0-
6500 V
0-
120 mA
400 J/s
19" / 443 mm
3 U / 133 mm
350 mm
11 kg
HCK
800 - 6500
0-
6500 V
0-
250 mA
800 J/s
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
HCK
1600 - 6500
3)
0-
6500 V
0-
500 mA
1600 J/s
19" / 443 mm
6 U / 266 mm
650 mm
35 kg
HCK
2500 - 6500
3)
0-
6500 V
0-
750 mA
2500 J/s
19" / 443 mm
6 U / 266 mm
550 mm
40 kg
HCK
5000 - 6500
3)
0-
6500 V
0-
1,5 A
5000 J/s
19" / 600 mm
9 U / 399 mm
650 mm
75 kg
HCK
7500 - 6500
3)
0-
6500 V
0-
2,3 A
7500 J/s
19" / 600 mm
12 U / 535 mm
650 mm
110 kg
HCK
10000 - 6500
3)
0-
6500 V
0-
3A
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCK
20000 - 6500
3)
0-
6500 V
0-
6A
20000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
6 kg
HCK
100 - 12500
0-
12500 V
0-
15 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm
HCK
200 - 12500
0-
12500 V
0-
30 mA
200 J/s
19" / 443 mm
3 U / 133 mm
450 mm
7 kg
HCK
400 - 12500
0-
12500 V
0-
60 mA
400 J/s
19" / 443 mm
3 U / 133 mm
450 mm
11 kg
HCK
800 - 12500
0-
12500 V
0-
120 mA
800 J/s
19" / 443 mm
3 U / 133 mm
450 mm
21 kg
HCK
1600 - 12500
3)
0-
12500 V
0-
250 mA
1600 J/s
19" / 443 mm
6 U / 266 mm
550 mm
35 kg
HCK
2500 - 12500
3)
0-
12500 V
0-
400 mA
2500 J/s
19" / 443 mm
6 U / 266 mm
650 mm
40 kg
HCK
5000 - 12500
3)
0-
12500 V
0-
800 mA
5000 J/s
19" / 600 mm
9 U / 399 mm
650 mm
75 kg
HCK
7500 - 12500
3)
0-
12500 V
0-
1,2 A
7500 J/s
19" / 600 mm
12 U / 535 mm
650 mm
110 kg
HCK
10000 - 12500
3)
0-
12500 V
0-
1,5 A
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCK
20000 - 12500
3)
0-
12500 V
0-
3A
20000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
3) Three phase mains connection
All units are available with polarity reversal
switch. For orders without polarity switch
please state the required output polarity.
Mating high voltage connectors (from 35kV complete with 3m cable, from 65kV >5000J/s with
10m cable) are included in the scope of delivery. Mating high voltage cables you‘ll find beginning
with page 51. Capacitor chargers with different from the type range voltage or power are available on request. . (From approx.100V and till approx. 200kV)
31
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Capacitor charging power supplies
Series HCK from 2 kV to 65 kV / 100 J/s to 20 kJ/s
HCK 5000 - 12500
12,5kV / 800mA
HCK 6750M - 30000
(side cover removed)
30kV / 450mA
(650mA up to 15kV)
HCK 150000M - 12000
12kV / to 35A
customer specific design,
4-fould 19“ cabinet, cubical
Design examples
Type
Voltage
Current
Charg. pow.
Width
Height
Depth
Weight
HCK
100 - 20000
0-
20000 V
0-
10 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm**
11 kg
HCK
200 - 20000
0-
20000 V
0-
20 mA
200 J/s
19" / 443 mm
3 U / 133 mm
350 mm**
12 kg
HCK
400 - 20000
0-
20000 V
0-
40 mA
400 J/s
19" / 433 mm
3 U / 133 mm
450 mm
14 kg
HCK
800 - 20000
0-
20000 V
0-
80 mA
800 J/s
19" / 443 mm
4 U / 177 mm
550 mm
25 kg
HCK
1600 - 20000
3)
0-
20000 V
0-
160 mA
1600 J/s
19" / 443 mm
6 U / 266 mm
650 mm
35 kg
HCK
2500 - 20000
3)
0-
20000 V
0-
250 mA
2500 J/s
19" / 443 mm
7 U / 310 mm
550 mm
40 kg
HCK
5000 - 20000
3)
0-
20000 V
0-
500 mA
5000 J/s
19" / 600 mm
29 U / 1500 mm
600 mm
120 kg
HCK
10000 - 20000
3)
0-
20000 V
0-
1A
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
240 kg
HCK
20000 - 20000
3)
0-
20000 V
0-
2A
20000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
360 kg
HCK
100 - 35000
0-
35000 V
0-
5 mA
100 J/s
19" / 443 mm
3 U / 133 mm
350 mm**
12 kg
HCK
200 - 35000
0-
35000 V
0-
10 mA
200 J/s
19" / 443 mm
3 U / 133 mm
450 mm
12 kg
HCK
400 - 35000
0-
35000 V
0-
20 mA
400 J/s
19" / 433 mm
3 U / 133 mm
550 mm
30 kg
HCK
800 - 35000
0-
35000 V
0-
40 mA
800 J/s
19" / 443 mm
4 U / 177 mm
550 mm
30 kg
HCK
1600 - 35000
3)
0-
35000 V
0-
80 mA
1600 J/s
19" / 443 mm
6 U / 266 mm
650 mm
50 kg
HCK
2500 - 35000
3)
0-
35000 V
0-
140 mA
2500 J/s
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
HCK
5000 - 35000
3)
0-
35000 V
0-
280 mA
5000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
390 kg
HCK
10000 - 35000
3)
0-
35000 V
0-
570 mA
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
450 kg
HCK
20000 - 35000
3)
0-
35000 V
0-
1,1 A
20000 J/s
2x19" / 1200 mm
38 U / 2000 mm
800 mm
720 kg
HCK
100 - 65000
0-
65000 V
0-
3 mA
100 J/s
19" / 443 mm
3 U / 133 mm*
450 mm**
20 kg
HCK
200 - 65000
0-
65000 V
0-
6 mA
200 J/s
19" / 443 mm
5 U / 221 mm*
450 mm**
30 kg
HCK
400 - 65000
0-
65000 V
0-
12 mA
400 J/s
19" / 433 mm
7 U / 310 mm*
550 mm
55 kg
HCK
800 - 65000
0-
65000 V
0-
25 mA
800 J/s
19" / 443 mm
7 U / 310 mm*
550 mm
60 kg
HCK
1600 - 65000
3)
0-
65000 V
0-
50 mA
1600 J/s
19" / 443 mm
8 U / 355 mm*
550 mm
80 kg
HCK
2500 - 65000
3)
0-
65000 V
0-
75 mA
2500 J/s
19" / 443 mm
10 U / 443 mm*
650 mm
120 kg
HCK
5000 - 65000
3)
0-
65000 V
0-
150 mA
5000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
460 kg
HCK
10000 - 65000
3)
0-
65000 V
0-
300 mA
10000 J/s
19" / 600 mm
38 U / 2000 mm
800 mm
HCK
20000 - 65000
3)
0-
65000 V
0-
600 mA
20000 J/s
19" / 600 mm
29 U / 1500 mm
600 mm***
500 kg
200/470
kg
3) Three phase mains connection
All units are available with polarity reversal switch. For orders without
polarity switch please state the required output polarity.
For the final dimensioning of the capacitor charging power supplies, details regarding the load and the operating conditions are
necessary.
*) With polarity reversal switch these units will be 2 units higher.
**) With polarity reversal switch these units will be 100mm deep.
***) The dimensions are valid for the power part. The high voltage part
is housed in a separate oil filled container. Weight is stated: Power
part / High voltage container
32
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Power supplies for superconducting coils
Series NTS to 65 V / to 10000 A
Design:
 Up to 200A (or approx. 2.5
kW) in 19’’ table-top cases or
plug-in units.
 Units with higher current or
power are supplied as 19"
cabinets on roller blades. The
side panels can be removed,
the rear door can be locked.
 All cabinets have removable
crane-eyes.
Output:
 Output isolation:

The output is floating. Operating voltage with respect to
earth: for air cooled units max.
±300V DC, for water cooled
units max. ±100V DC.
Output terminals:
Up to 100A, clamps on the
rear. For higher currents we
use copper bars.
Design examples
Features:
 High efficiency
 Short circuit proof and with





unlimited operation at full
current in short-circuit condition
Sense terminals for the compensation of the voltage drop
on the power lines. By presetting the voltage, a linear
current ramp can be generated
Energizing and de-energizing
voltage can be preset with a
single potentiometer
Constant voltage operation for
linear up and down control
Linear de-energization, with
reverse voltage permitted up
to the nominal value of the
output voltage (2-quadrant
operation)
Interlock loop to monitor the
external load and internal loop
as a standard
NTS 250000M - 50
Front plate
Function:
Designed specifically for superconducting coil applications.
This power supply family is
series regulated, via a set of
parallel transistors, which are
driven from a pre-regulation
stage which utilises phase
controlled thyristors. In this
manner, the power lost across
the output transistors is kept to
minimum. Thus, the final control element always has a low
power dissipation in energizing
and static constant current
mode.
In de-energizing mode, the
transistor stage is working as a
current sink and the power is
dissipated by means of either
air or water cooling.
Cooling:
Up to approx. 1000A (or approx. 5kW de-energizing power), air cooling. For higher currents, or higher powers, water
cooling.
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 53Hz
For 2800W and higher:
400V ±10% 47Hz to 53Hz,
two-phase

For 700W and higher:
400V ±10% 47Hz to 53Hz,
three-phase
Ambient temperature:
0°C to +40°C
 Run up time:
from 1sec. to 100 hours
 Deviation:
For ±10% mains voltage variation:
<± 1 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±1 x 10-4 to ±1 x 10-5
Within the temperature range:
<±1 x 10-4 to ±5 x 10-6 /K
Possible Options:
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 DVM with higher resolution
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
Higher stability

 Current control by electronic




All following data are guide
values and will be modified
according to the specification.
(For explanations please refer to
Definitions and Terms )
 Setting range for current:
from approx. 0,1% to 100%
 Setting range for voltage:



from -100% to +100%
Setting resolution:
±1 x 10-4 to ±1 x 10-6
Residual ripple (Voltage 020MHz):
approx. 1 x 10-3pp
Residual ripple (Current 020MHz):
±1 x 10-4pp to ±1 x 10-6pp
depending on inductivity of the
load


ramp with digital control; rise
and fall times are adjustable
manually or via computer
interface
Current limit setting either
manually or via computer
interface. Resolution up to 1 x
10-5 for external setting
High speed turn-off input with
adjustable threshold
Quench detector to monitor
the magnet
Fast de-energizing in the
event of quench or mains
failure: A DC circuit breaker or
a semiconductor switch disconnects the power supply
from
the
magnet.
Deenergization takes place with
a power resistor, actuated at
quench, or via an external
circuit
Short circuit switch (Current
source 100mA for heating a
sector of the superconducting
circuit)
Water cooling
More options and special solutions on request.
For this type of power supplies we don't indicate a range of standard types since it is
meaningful to adapt the power and equipment of the units for each single application.
33
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Power supplies for superconducting coils
Series NTS to 65 V / to 10000 A
Design examples
NTS 720 - 8 mod.
8V / 90A
customer specific design for
high temperature super
conductor
NTS 20000M - 10
10V / 2000A
NTS 250000M - 50
50V / 5000A
34
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Linear regulated power supplies unipolar
Series NLN from 6,5 V to 500 V / 35 W to 1400 W
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms from
page 54.)
 Setting range:
from approx. 0,1% to 100%
 Setting resolution:




Design examples
Features:
 Voltage and current setting
with 10-turn potentiometers
with precision scale; the adjusting knob can be locked
 Output voltage and output
current are fast programmable
 No output capacitor
 All units are short circuit proof





and allow unlimited operation
with full current in short circuit
condition
Voltage and current regulation
with automatic and sharp
transition; control mode indicated by LEDs
4½ digit DVM for voltage and
current (for table-top models)
Sense terminals for the compensation of voltage drop on
the load lines, for units up to
350V nominal voltage. The
rated voltage always refers to
the output terminals
Suitable also for inductive and
capacitive loads
Standard starting current
limitation from 700W nominal
power onwards
NLN 1400 - 20
20V / 60A
Function:
The mains voltage is transformed to the appropriate level
and rectified. The rectified voltage charges a bank of capacitors of the intermediate circuit
to a constant voltage, which it is
given via a set of power transistors to the output. The series
transistor defines the final stability of the output voltage and
the regulation speed.
Optionally a set of power transistors parallel to the output can
act as a current sink to provide
active pull down ability. The design of linear regulated power
supplies is optimized for fast
programming speed.
Design:
 For 35W nominal power ½19" table-top case,
 other models - 19" table-top
case (19" rack adaptors available)
 Cooling: Convection or builtin fan with air outlet on the
rear
±1 x 10-4
Residual ripple (0 - 10MHz):
<5 x 10-4pp + 10mVpp
Recovery time:
<50µs for load changes from
10% to 100% or from 100% to
10%
Setting time at nominal load:
<1ms for full range
Deviation:
For ±10% mains voltage variation:
<± 2 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±2 x 10-4
Within the temperature range:
<±2 x 10-4 /K
Output:
 Output isolation:
The output is floating. Operating voltage with respect to
earth: max. ±500V.
Each of the output terminals
may be connected to earth.
 4mm safety connectors up to
20A on the rear panel. For
higher currents clamps installed on the rear.
Possible Options:
 Analog programming (The
positive output has to be
earthed; see also page 44)
 Analog programming, floating
(see page 44)
 DVM with higher resolution
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 63Hz
For 2800W and higher:
400V ±10% 47Hz to 63Hz,
three-phase
 Ambient temperature:
0°C to +40°C
 Power loss:
At nominal load approx. 25%,
during short circuit at nominal
current approx 125% of the
nominal power.

 Computer interfaces - IEEE

488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
Active pull-down control. Parallel to the output is a set of
power transistors operating as
a current sink. (see page 48)
Higher programming speed
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
35
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Linear regulated power supplies unipolar
Series NLN from 6,5 V to 500 V / 35 W to 1400 W
Design example
NLN 700 - 250
250V / 2,8A
Customised design
(Non standard voltage/ current
prepared for 19“ build-in)
Type
Voltage
Current
Width
Height
Depth
Weight
NLN
35 - 6,5
0 -
6,5 V
0 -
5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
140 - 6,5
0 -
6,5 V
0 -
10 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 6,5
0 -
6,5 V
0 -
30 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 6,5
0 -
6,5 V
0 -
60 A
19" / 443 mm
4 U / 177 mm
550 mm
38 kg
NLN
1400 - 6,5
0 -
6,5 V
0 -
120 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
2,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
35 - 12,5
0 -
12,5 V
0 -
NLN
140 - 12,5
0 -
12,5 V
0 -
8 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 12,5
0 -
12,5 V
0 -
20 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 12,5
0 -
12,5 V
0 -
50 A
19" / 443 mm
4 U / 177 mm
550 mm
38 kg
NLN
1400 - 12,5
0 -
12,5 V
0 -
80 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
NLN
35 - 20
0 -
20 V
0 -
1,5 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
140 - 20
0 -
20 V
0 -
6 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 20
0 -
20 V
0 -
15 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 20
0 -
20 V
0 -
30 A
19" / 443 mm
4 U / 177 mm
550 mm
35 kg
NLN
1400 - 20
0 -
20 V
0 -
60 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
NLN
35 - 35
0 -
35 V
0 -
1 A
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
140 - 35
0 -
35 V
0 -
4 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 35
0 -
35 V
0 -
10 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 35
0 -
35 V
0 -
20 A
19" / 443 mm
4 U / 177 mm
550 mm
35 kg
NLN
1400 - 35
0 -
35 V
0 -
40 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
NLN
35 - 65
0 -
65 V
0 -
500 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
140 - 65
0 -
65 V
0 -
2 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 65
0 -
65 V
0 -
5 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 65
0 -
65 V
0 -
10 A
19" / 443 mm
4 U / 177 mm
550 mm
35 kg
NLN
1400 - 65
0 -
65 V
0 -
20 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
On request we deliver power supplies of this type also with higher power.
36
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Linear regulated power supplies unipolar
Series NLN from 6,5 V to 500 V / 35 W to 1400 W
Design example
Customer specific
special versions
NLN 3000M - 10
10V / 300A
In rel. Duty cycle 10%
NLN 22500M - 15
15V / 1500A for 0,5s
Special design:
Intermediate storage of energy
Adjustable internal resistance
Type
Voltage
Current
NLN
35 - 125
0 -
125 V
0 -
NLN
140 - 125
0 -
125 V
0 -
NLN
350 - 125
0 -
125 V
0 -
NLN
700 - 125
0 -
125 V
0 -
NLN
1400 - 125
0 -
125 V
NLN
35 - 200
0 -
NLN
140 - 200
NLN
350 - 200
NLN
NLN
NLN
NLN
NLN
250 mA
Width
Height
Depth
Weight
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
1 A
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
2,5 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
5 A
19" / 443 mm
4 U / 177 mm
550 mm
30 kg
0 -
10 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
200 V
0 -
150 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
0 -
200 V
0 -
600 mA
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
0 -
200 V
0 -
1,5 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
700 - 200
0 -
200 V
0 -
3 A
19" / 443 mm
4 U / 177 mm
550 mm
30 kg
1400 - 200
0 -
200 V
0 -
6 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
35 - 350
0 -
350 V
0 -
100 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
140 - 350
0 -
350 V
0 -
400 mA
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
350 - 350
0 -
350 V
0 -
1 A
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 350
0 -
350 V
0 -
2 A
19" / 443 mm
4 U / 177 mm
550 mm
25 kg
NLN
1400 - 350
0 -
350 V
0 -
4 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
NLN
35 - 500
0 -
500 V
0 -
60 mA
½19" / 222 mm
3 U / 133 mm
350 mm
5 kg
NLN
140 - 500
0 -
500 V
0 -
250 mA
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
NLN
350 - 500
0 -
500 V
0 -
600 mA
19" / 443 mm
4 U / 177 mm
450 mm
19 kg
NLN
700 - 500
0 -
500 V
0 -
1,2 A
19" / 443 mm
4 U / 177 mm
550 mm
25 kg
NLN
1400 - 500
0 -
500 V
0 -
2,5 A
19" / 443 mm
7 U / 310 mm
550 mm
50 kg
On request we deliver power supplies of this type also with higher power.
37
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Linear regulated power supplies bipolar
Series NLB from ±6,5 V to ±350 V / 35 W to 1400 W
Design example
NLB 350 - 20
± 20V / ± 15A
The following data applies for
voltage and current regulation,
and refers to the rated value
(unless otherwise stated):
(For explanations please refer
to Definitions and Terms on
page 54.)
 Setting range:
from -100% to +100%
 Setting resolution:


Features:
 Single output power supply
with adjustable bipolar output
voltage and current. Instantaneous change of polarity.
 Voltage and current setting
with 10-turn potentiometers
with precision scale; the adjusting knob can be locked
 When equipped with an interface or with the analog programming, fast programmable
including change of polarity
 Short circuit proof and allow
unlimited operation with full
current in short circuit condition
 One of the potentiometers is
used for set point adjustment
(selectable for voltage or
current). The second potentiometer is for
limiting the
respective other value.
 4½ digit DVM for voltage and
current (for table-top models)
 Sense terminals for the compensation of voltage drop on
the load lines, for units up to
350V nominal voltage.
 4-quadrant operation is possible for passive loads (when
the stored energy is low, optionally also for active loads or
higher energy with reverse
current)
 Suitable also for inductive and
capacitive loads
 Standard starting current
limitation from 700W nominal
power onwards
Function:
Bipolar linear regulated power
supplies supply one output voltage, where the value and polarity is adjustable. The mains voltage is transformed to the appropriate level and rectified. The
rectified voltage charges a bank
of capacitors of the intermediate
circuit to a constant voltage,
which it is fed, via a set of serial
power transistors, to the output.
The output stages of the positive
and the negative circuits are
switched together in a push-pull
manner. The regulation transistors define the final stability of
the output voltage and the regulation speed. Bipolar power
supplies are able to operate as
4-quadrant power amplifier.
(optionally also for active loads).
Technical Data:
 Mains connection:
Up to 1400W nominal power:
230V ±10% 47Hz to 63Hz

For 2800W and higher:
400V ±10% 47Hz to 63Hz,
three-phase
Ambient temperature:
0°C to +40°C
 Power loss:
at nominal load approx. 35%,
during short circuit at nominal
current approx 140% and at
no load approx. 15% of the
nominal power.
Design:
 19" table-top case (19" rack
adaptors available)
 Cooling:
Convection or built-in fan with
air outlet on the rear
Output:
 Output isolation:
The output is floating. Operating voltage with respect to
earth: max. ±500V.
 Output terminals:
4mm safety connectors up to
20A on the rear panel. For
higher currents clamps installed on the rear
38
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de


±2 x 10-4
Residual ripple (0 - 10MHz):
<5 x 10-4pp + 10mVpp
Recovery time:
Voltage regulation
<50µs for load changes from
10% to 100% or from 100% to
10%
Current regulation: <1ms
Setting time at nominal load:
<1ms for full range
Deviation:
For ±10% mains voltage variation:
<± 2 x 10-5
For no load / full load:
<2 x 10-4
Over 8 hours under constant
conditions:
<±2 x 10-4
Within the temperature range:
<±2 x 10-4 /K
Possible Options:
 Analog programming (Output
“A0” on “0V” potential, see
page 44)
 Analog programming, floating
(page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Full 4-quadrant operation,
even with active loads
 Higher programming speed
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
Linear regulated power supplies bipolar
Series NLB from ±6,5 V to ±350 V / 35 W to 1400 W
Type
Voltage
Current
Width
Height
Depth
Weight
NLB
35 - 6,5
0 -
±6,5 V
0 -
±5 A
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 6,5
0 -
±6,5 V
0 -
±10 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 6,5
0 -
±6,5 V
0 -
±30 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 6,5
0 -
±6,5 V
0 -
±60 A
19" / 443 mm
8 U / 355 mm
550 mm
35 kg
NLB
1400 - 6,5
0 -
±6,5 V
0 -
±120 A
19" / 443 mm
10 U / 443 mm
550 mm
55 kg
NLB
35 - 12,5
0 -
±12,5 V
0 -
±2,5 A
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 12,5
0 -
±12,5 V
0 -
±8 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 12,5
0 -
±12,5 V
0 -
±20 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 12,5
0 -
±12,5 V
0 -
±50 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
NLB
1400 - 12,5
0 -
±12,5 V
0 -
±80 A
19" / 443 mm
8 U / 355 mm
550 mm
55 kg
NLB
35 - 20
0 -
±20 V
0 -
±1,5 A
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 20
0 -
±20 V
0 -
±6 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 20
0 -
±20 V
0 -
±15 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 20
0 -
±20 V
0 -
±30 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
NLB
1400 - 20
0 -
±20 V
0 -
±60 A
19" / 443 mm
8 U / 355 mm
550 mm
55 kg
NLB
35 - 35
0 -
±35 V
0 -
±1 A
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 35
0 -
±35 V
0 -
±4 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 35
0 -
±35 V
0 -
±10 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 35
0 -
±35 V
0 -
±20 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
NLB
1400 - 35
0 -
±35 V
0 -
±40 A
19" / 443 mm
7 U / 310 mm
550 mm
55 kg
NLB
35 - 65
0 -
±65 V
0 -
±500 mA
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 65
0 -
±65 V
0 -
±2 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 65
0 -
±65 V
0 -
±5 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 65
0 -
±65 V
0 -
±10 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
NLB
1400 - 65
0 -
±65 V
0 -
±20 A
19" / 443 mm
7 U / 310 mm
550 mm
55 kg
39
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Linear regulated power supplies bipolar
Series NLB from ±6,5 V to ±350 V / 35 W to 1400 W
Type
Voltage
Current
NLB
35 - 125
0 -
±125 V
0 -
NLB
140 - 125
0 -
±125 V
NLB
350 - 125
0 -
±125 V
NLB
700 - 125
0 -
±125 V
NLB
1400 - 125
0 -
±125 V
NLB
35 - 200
0 -
NLB
140 - 200
0 -
NLB
350 - 200
NLB
700 - 200
NLB
Width
Height
Depth
Weight
±250 mA
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
0 -
±1 A
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
0 -
±2,5 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
0 -
±5 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
0 -
±10 A
19" / 443 mm
7 U / 310 mm
550 mm
55 kg
±200 V
0 -
±150 mA
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
±200 V
0 -
±600 mA
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
0 -
±200 V
0 -
±1,5 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
0 -
±200 V
0 -
±3 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
1400 - 200
0 -
±200 V
0 -
±6 A
19" / 443 mm
7 U / 310 mm
550 mm
55 kg
NLB
35 - 350
0 -
±350 V
0 -
±100 mA
19" / 443 mm
4 U / 177 mm
450 mm
9 kg
NLB
140 - 350
0 -
±350 V
0 -
±400 mA
19" / 443 mm
4 U / 177 mm
450 mm
12 kg
NLB
350 - 350
0 -
±350 V
0 -
±1 A
19" / 443 mm
4 U / 177 mm
550 mm
22 kg
NLB
700 - 350
0 -
±350 V
0 -
±2 A
19" / 443 mm
5 U / 221 mm
550 mm
35 kg
NLB
1400 - 350
0 -
±350 V
0 -
±4 A
19" / 443 mm
7 U / 310 mm
550 mm
55 kg
On request we deliver power supplies of this type also with higher power.
40
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Bipolar high voltage power supplies
Series HCB from ±1250 V to ±20000 V / 1,4 W to 200 W
Design example
HCB 7 - 6500
± 6500V / ± 1mA
Features:
 Light-weight
 In units with 6,5kV and higher








the
HV-components
are
moulded in (removable) silicon resin
Short-circuit and flash over
proof.
Unlimited operation with rated
current in a short-circuit condition
Voltage regulation and current
limitation
with
automatic,
sharp
transition,
control
modes indicated by LEDs
Voltage adjustment with 10turn potentiometers with precision scale; the adjusting
knob can be locked
4½ digit DVM for voltage and
current (for table-top models)
Set point adjustment possible
with locked output, release of
output voltage by means of an
"ON" / "OFF" switch
4- quadrant operation possible also for active loads and
unlimited power sinking
Suitable for capacitive and
resistive loads
Function:
Bipolar HV power supplies
consist of 2 switch-mode controlled HV sources which are
connected to the output. In
principle, the rectified line voltage in each source drives a
square wave generator of fixed
frequency, whose AC voltage is
transformed, rectified and filtered, producing the positive or
negative output voltage. For
regulation, the square wave
voltage is pulse width modulated. The operation is contramoving, and the output can be
adjusted with continuous zero
crossing.
Design:
 19" table-top case (19" rack
adaptors available)
Output:
 Output isolation:
One output terminal each
leads the high voltage, the
"0V" terminal is connected
firmly to earth. If required, the
"0V" terminal can be made
floating against earth up to
±300V.
 Output terminals:
All output terminals are located at the rear plate of the
unit. High voltage connectors
with the appropriate dielectric
strength are delivered with
the power supply
Technical Data:
 Mains connection:
Up to 700W nominal power:
230V ±10% 47Hz to 63Hz

For 1400W nominal power
and more:
400V±10% 47Hz to 63Hz,
three phase
Ambient temperature:
0°C to +40°C
The following data applies for
voltage regulation, and refers to
the rated value (unless otherwise stated). (For explanations
please refer to Definitions and
Terms on page 54.)
 Setting range:
from -100% to +100%
 Setting resolution:


±1 x 10-4
Residual ripple (0 - 10 MHz):
<3 x 10-4pp + 50mVpp,
typ. 2 x 10-4pp
Recovery time for voltage
control:
<1ms for load changes from
10% to 90% or from 90% to
10%
 Setting time at nominal load:
<200ms
 Deviation:
For ±10% mains voltage variation:
<± 2 x 10-5
For no load / full load:
<2 x 10-4
over 8 hours under constant
conditions:
<±2 x 10-4
within the temperature range:
<±2 x 10-4 /K
Possible Options:
 Analog programming (see
page 44)
 Analog programming, floating
(see page 44)
 Computer interfaces - IEEE
488, RS 232, RS 422, Profibus DP, USB, LAN (more on
request) (see page 46)
 Lower ripple (see page 48)
 Higher stability (see page 48)
 Lower stored energy and
shorter recovery time (see
page 48)
More options and special solutions on request. Some options
may involve changes to the
description of the unit - especially concerning the mechanical design.
41
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Bipolar high voltage power supplies
Series HCB from ±1250 V to ±20000 V / 1,4 W to 200 W
Type
Voltage
Current
Width
Height
Depth
Weight
HCB
1,4 - 1250
0 -
±1250 V
0 -
±1 mA
19" / 443 mm
3 U / 133 mm
350 mm
6 kg
HCB
14 - 1250
0 -
±1250 V
0 -
±10 mA
19" / 443 mm
3 U / 133 mm
350 mm
7 kg
HCB
2 - 2000
0 -
±2000 V
0 -
±1 mA
19" / 443 mm
3 U / 133 mm
350 mm
6 kg
HCB
20 - 2000
0 -
±2000 V
0 -
±10 mA
19" / 443 mm
3 U / 133 mm
350 mm
9 kg
HCB
3,5 - 3500
0 -
±3500 V
0 -
±1 mA
19" / 443 mm
3 U / 133 mm
350 mm
7 kg
HCB
35 - 3500
0 -
±3500 V
0 -
±10 mA
19" / 443 mm
3 U / 133 mm
450 mm
10 kg
HCB
7 - 6500
0 -
±6500 V
0 -
±1 mA
19" / 443 mm
3 U / 133 mm
350 mm
10 kg
HCB
70 - 6500
0 -
±6500 V
0 -
±10 mA
19" / 443 mm
3 U / 133 mm
550 mm
15 kg
HCB
14 - 12500
0 - ±12500 V
0 -
±1 mA
19" / 443 mm
3 U / 133 mm
350 mm
30 kg
HCB
140 - 12500
0 - ±12500 V
0 -
±10 mA
19" / 443 mm
6 U / 266 mm
550 mm
42 kg
HCB
20 - 20000
0 - ±20000 V
0 -
±1 mA
19" / 443 mm
6 U / 266 mm
550 mm
35 kg
HCB
200 - 20000
0 - ±20000 V
0 -
±10 mA
19" / 443 mm
6 U / 266 mm
550 mm
45 kg
On request, we deliver power supplies of this type with different voltage or power ranges.
Mating high voltage connectors for units are included in the scope of delivery. Mating high voltage cables you‘ll find beginning with page 51.
42
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Technical Appendix
Mains Fuses, Connected Wattage
Type Range
Power Class [W]
Voltage Range
Efficiency
Mains Fuse
(Automaten)
NTN
NYN / MYN / HYN
NCA / MCA
MCP
HCP
HCH
HCK
4.200
6,5V upto20V
25A
7.000
6,5V upto 20V
25A
10.500
6,5V upto20V
32A
14.000
6,5V upto 20V
21.000
6,5V upto20V
28.000
6,5V upto 20V
typ. 70-80%
32A
For design of your electricity
supply please provide the next
higher rated value of the main
fuses used inside the unit. For
external fuses use such with
delayed action. When circuit
breakers are used, we recommend “G” or ”K” characteristic.
50A
80A
35.000
6,5V upto20V
80A
50.000
6,5V upto 20V
160A
4.200
35V upto 350V
25A
7.000
35V upto 350V
25A
10.500
35V upto 350V
32A
14.000
35V upto 350V
21.000
35V upto 350V
28.000
35V upto 350V
100A
35.000
50.000
35V upto 350V
35V upto 350V
80A
160A
typ. 90%
32A
63A
7.000
All
20A
10.500
All
25A
14.000
All
50A
21.000
All
28.000
All
35.000
All
80A
50.000
All
100A
70.000
All
160A
100.000
All
200A
3.000
All
10A
6.000
All
9.000
All
20A
2.800
All
6A
4.200
All
5.000
All
10.000
All
25A
15.000
All
35A
2.800
All
6A
4.200
All
10A
50A
typ. 86-93%
typ. 85%
63A
16A
10A
typ. 90%
typ. 90%
16A
5.000
All
10.000
All
25A
15.000
All
35A
10.000
All
32A
15.000
All
50A
20.000
All
30.000
All
40.000
All
125A
50.000
All
160A
1.600
All
10A
2.500
All
5.000
All
10.000
All
63A
20.000
All
125A
typ 85%
16A
63A
100A
16A
typ 85%
32A
43
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Options and modifications:
Analog programming
Many FuG- power supplies are
available which differ from the
standard design or equipment.
On this pages we highlight
some of the most common
options and modifications. Other customer-specific units having different technical data,
different mechanical construction, alternative customer defined interfaces or with extended features are available even
for single piece orders.
Analog programming:
With this option the output voltage and current of the power
supply can be set via analog
voltages (0-10V) or by external
potentiometers. Monitor signals
of voltage and current (0-10V)
available on the programming
terminal. An external "ON"command enables the regulation loop.
Selection of manual operation
or external programming is possible by a switch on the front
panel. This option is also availa-
Pin Configuration: SUB-D 15 pin
ble as a retrofit set for later up
gradation of your unit.
Usually the "0V" of the programming voltage is connected
to one of the outputs of the unit.
If this is not wanted, the unit
may be equipped with floating
analog programming.
For this version:
 Isolation max. 2kV DC with
respect to the unit output,
30V DC with respect to
ground.
a fibre optic option with isolation
capabilities up to 200kV and
more.
For most models, the floating
analog programming can be
installed later at our site.
On request we can also supply
(Solder side of the plug )
Pin
Description
Comment
1
Status report: current regulation
regulation activ e ≙ approx . +15V v ia 10kW
2
Status report: v oltage regulation
regulation activ e ≙ approx . +15V v ia 10kW
3
Monitor-signal current
0…nominal v alue ≙ 0...+10V; Ri = 10kW
(alw ay s positiv e, independent of output polarity )
4
Slider front plate v oltage potentiometer
0...+10V depending from position of potentiomer knob
(not used w ith isolated analogue programming)
5
Slider front plate current potentiometer
0...+10V depending from position of potentiomer knob
(not used w ith isolated analogue programming)
6
0V for digital signals
7
Polarity change for units w ith electronic polarity rev ersal
open = positiv e
(otherw ise not used)
connected to 6) = negativ e
8
Set v alue v oltage
0...+10V ≙ 0…nominal v alue
9
0Vfor analogue signals
10
+ 10 V reference
w ith reference to pin 9; load up to approx . 2mA
11
Monitor-signal v oltage
0…nominal v alue ≙ 0...+10V; Ri = 10kW
(alw ay s positiv e, independent of output polarity )
12
Command: „output ON / OFF“
open = OFF
connected to pin 6 = ON
no mains interruption!
13
Polarity signalization for units w ith electronic polarity rev ersal
+12V = positiv e
(otherw ise not used)
0V = negativ e
14
not used
15
Set v alue current
0...+10V ≙ 0…nominal v alue
For single types of equipments, deviations from this configuration are possible (especially for HCN7E, HCB, NLB and custom-designed equipment). In these cases the equipment description is valid.
For proper function of the analog programming at least pin 12 (Output ON/OFF - link to 0V) and both pins 8 and 15 (set values ≠ 0) have to be
connected. Using external set value signals, the "0V" line also has to be connected.
On request we also deliver a complete remote control with indicating instruments and set-point potentiometers in a separate case (cable length to
10m), matching to the analog programming.
44
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Options and modifications:
Analog programming
Application notes for the analog programming:
 Only external ON / OFF, front side potentiometers stay active:
12
 Read signals in local mode:
6
5
15
4
g ood
1
A Link from pin 12 to pin 6
releases the output, a disconnection between these pins
locks it. The link can be made
by switch, relay contact, wire
link, transistor or opto-coupler
output (care for correct polarity
in the last two cases).
Links between pins 15 and 5
and also between 8 and 4 forward the signals of the front
plate potentiometers.
fai l
2
6
3
11
8
( 0 - 10V)
I
( 0 - 10V)
U
9
 Output always ON, external input of set values for voltage and
These signals can be read out
also when the unit is set to local
mode by the mode switch at the
front plate (switch in position
“local”), so that the values are
set by the front plate control
elements. By analyzing the
status signals (pins 1 and 2) via
threshold switches for example
a good / fail recognising for
isolation tests can be created.
The indication of monitor values
by
appropriately
calibrated
measuring instruments with 0 10V is also always possible,
independently of the mode of
control.
 Master slave circuit 1:
current:
Link between pins 12 and 6 to
release the output.
12
M as ter
Sl ave
4
8
5
15
9
9
6
8
I
U
10k
15
10k
10
9
0 - 10V set value input at pins 8
(voltage) and 15 (current). The
graphic shows the generation
of set values by voltage divider
potentiometers, using the internal reference at pin 10. External generation of set values is
also possible by digital analog
converters or other signal
sources.
 Output always ON, only set value for voltage is with external
12
6
Wipers of the front plate potentiometers (pins 4 and 5) of the
master unit are connected to
the set value inputs of the slave
unit (pins 8 and 15). This allows
a symmetrical control of two
power supplies.
Link between pins 12 and 6 is
necessary to release the output
for the slave unit. (For the master unit this depends on the
mode of control.)
 Master slave circuit 2:
input, current limited to maximum value.
Link between pins 12 and 6 to
release the output.
12
6
M as ter
Sl ave
3
15
9
9
12
Input of set value only for voltage, pin 15 (set value current)
connected to +10V reference,
limiting the current to the maximum value by this.
10
8
U
10k
15
6
10
8
9
The current monitor output (pin
3) of the master is connected to
the current set value input (pin
15) of the slave, while the voltage value of the slave is limited
to the maximum value (link
between pins 10 and 8). This
circuit ensures an equal distribution of current with two parallel switched power supplies.
The voltage setting is carried
out at the master power supply
(„local“ - or „remote“- control
possible.)
Link between pins 12 and 6 is
necessary to release the output
for the slave unit. (For the master unit this depends on the
mode of control.)
45
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Options and modifications:
Probus V (digital interface system)
Design example
Interface converter
Profibus DP
ADDA - module
General:
The modular interface system
PROBUS V allows to connect
FuG- power supplies with various
interfaces
and
bussystems.
The PROBUS V system consist
of two assemblies, the ADDA
module and an interface converter respectively.
The ADDA module is an intelligent analog-digital and digitalanalog converter for controlling
the power supply. This part is
always in the power supply and
communicates by a serial ASCII
protocol via optical fibres with
the interface converter. It evaluates the programmed commands, controls the power supply by reference voltages and
makes available serially the
feed back data of the power
supply .
The ADDA module stores also
all calibration data and all unit
specific data.
All commands and read-backdata are transmitted between
these both modules as readable
ASCII characters.
For customer specific multichannel-units up to 256 ADDAs
can be used parallel by optical
fiber hub or can be used serial
by a optical fiber chain. Every
single ADDA-module of the
group can be addressed by sub
-addressing. (Not for Profibus
DP)
Connection to the customer is
made by the Interface Converter, which converts the signals of the respective bus system or interface standard to the
serial data stream of the optical
transfer line.
Available versions:
 IEEE 488
 RS 232 electrical or optical
 RS 422
 USB
 Profibus DP
 LAN (Ethernet)
 More on request
Every version can be integrated
completely into the power supply or delivered with an external
interface converter. In the last
case the connection is via optical fibre cables. The external
interface converters are Euro
Cassettes of 61mm width (12U),
133mm (3U) high and 170mm
deep. The fibre optic cable from
the external interface converter
to the power supply can be up to
30m long (plastic optical fibre) or
in special design more than
1000m (glass fibre).
Furthermore, an external version with electrical connections
to the power supply via the analog programming is also possible.
Features:
 Easy programming with
SCPI-like syntax; Standard
set of commands compatible
to previous version PROBUS
IV.
 Extended set of commands
for special functions.
 Most modern RISC-Microcontroller techniques with SMD.
 Completely digitally adjusted
for highest precision.
 Isolation between interface
converter and ADDA component via optical fibre, though
extremely immune against
interferences.
 More than one ADDA components addressable in one
optical fibre chain.
Technical data:
 Instruction processing time
approx. 300µs (without serial
data transfer time)
 At 625kBd at least 1000 settings per second programmable (typ. 2000/sec)
 Up to 100 measurements per
second
 Two outputs 0..+/-10V, effective resolution 14 to 20 bit
incl. sign (depending on integration time), theoretical resolution 24 bit.
 Setting time of outputs
<500us
 Tc < 1x10-5/K, typ. 3ppm/K
 Two inputs 0..+/-10V, pro-



grammable resolution, max.
22 bit incl. sign, input impedance >1GΩ
Several digital I/Os for control
of the power supply
Optical connectors: Standard
Agilent (HP) HFBR-0500
series. Optionally HFBR-0400
series.
When several ADDA modules
are connected to a fibre optic
chain, then an additional time
delay depending on the selected baud rate and the
string length is necessary.
For 625kBd approx. 1ms
delay per ADDA module must
be added.
46
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
IEEE 488:
 Delay time of the data transfer: <100us.
 Baud rates on the serial side
of the optical link: 38400Bd or
625kBd selectable.
 SRQ (Service Request) programmable.
 LED indicators for "addressed" und "SRQ" conditions.
 Together with ADDA commonly compatible to the IEEE
-488 mode of the predecessor PROBUS IV.
 IEEE-488 address selectable
by switch near the IEEE-488
connector (outside the unit).
RS 232 electrical (active):
 Own power supply, 3-wire
connection sufficient (Rx, Tx,
GND).
 Baud rates up to 115200Bd
possible.
 Connector: 9-pol. Sub-D.
 Together with ADDA com-

monly compatible to the RS232 mode of the predecessor
PROBUS IV.
Optical connectors: Standard
Agilent
(HP)
HFBR-0500
series. Optionally HFBR-0400
series.
RS 232 optical (passive):
 Equal to RS 232 active, but:
 Optical



connectors: Direct
sticking connection for standard 1mm POF optical link.
Includes 5m fibre optic cable
to connect the power supply
to the computer.
Fibre optic cables up to 30m
on request. (Longer version
available as special cables,
glass fibre up to 1000m)
The complete interface converter is housed in a Sub-Dconnector-like case.
Options and modifications:
Probus V (digital interface system)
RS 422:
 Baud rates up to 625kBd possible.
 Optical connectors: Standard
Agilent
(HP)
HFBR-0500
series. Optionally HFBR-0400
series.
USB:
 Control via virtual COM-Port
or directly via USB-driver.
(Virtual Com-Port driver for
the most common operation
systems available, very simple programming, no USBprogramming knowledge necessary.)
 Delay time typical approx.1ms
due to USB principle.
LAN (Ethernet):
 Control via virtual COM-Port
or
directly
by
TCP/IPprogramming.
(Virtual Com-Port driver for
the most common operation
systems available, very simple programming, no profound knowledge of TCP/IPprogramming necessary.)
 Delay time approx. 20ms.
.
Profibus DP:
 An initial data block is made
available on the Profibus-DP
side. Into this the primary SPS
writes the required set points
and control commands.
 This initial data block is transferred cyclically by the converter via optical link to the
ADDA part.
 The feedback data (e.g.
measurements) of the ADDA
part is questioned cyclically
and provided n the exit data
block of the converter to the
primary SPS.
 Cycle time 40ms.
 Mode indication for optical
link.
 The Profibus-DP
interface
does not support the interconnection of several ADDA
modules
 Profibus address selectable

by code-switch outside the
unit.
Mode indication for Profibus
connection (red Error-LED).
Possible analog and digital interface alternatives for
FuG - Power supplies (Overview)
47
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Options and modifications:
Further possibilities
Polarity reversal:
By this switch the output voltage
polarity of a high voltage power
supply (Nearly all of the HCP,
HCK or HYN types) can be
changed.
With HCP up to 35kV it is possible to remote control the polarity
change if the units are equipped
additionally with an analog programming or with digital interface. For the most models the
polarity reversal can be installed
later at our site. On request
please ask us!
Higher stability:
Voltage and/or current regulation with better long-term stability and lower temperature coefficient. With a lot of models, using components with a better
specification and lower temperature coefficient the following
data can be reached:
 Stability over 8 hours under
constant conditions:
<±1 x 10-5
 Temperature coefficient:
<±1 x 10-5 /K within the specified temperature range
On request we can achieve for
certain units even a higher stability.
These options can be incorporated only in new units. A later
modification is not possible.
These options are not available
for cassette power supplies.
Lower output ripple:
On several series a lower ripple
can be achieved by better
smoothing. This option can be
supplied only with new units. A
later modification is not possible. The following data will be
achieved:
 For MCP / HCP up to 35W:
<1 x 10-5 + 10mV p-p
 For MCP / HCP 140W to
700W:
<1 x 10-5 + 20mV p-p
 For MCP / HCP of 1400W
and higher power:
<1 x 10-5 + 100mV p-p
This option is not available for
cassette power supplies and for
power supplies of the NTN
series.
Lower stored energy:
Especially for the operation of
gas discharge processes, arcs
or similar loads with a negative
dynamic resistance characteristic, the quantity of stored energy
can be decreased by smaller
output capacitors. Those units
will have than a higher ripple up
to 1%. This option is available
for units of the series MCP, HCP
or HCH.
Digital meters with higher
resolution:
For units, which are equipped
with 3½ digit DVM in the standard version (Units in cabinet
case: display of max."1999"),
instead of the standard DVM, a
DVM with higher resolution (4½
digit) can be offered. This replacement is also possible later
at our site.
For customer specific units even
higher display resolutions are
possible (Only for new units in
combination with a higher stability).
Standard table top units are
equipped with 4½ digit meters.
Higher adjustment resolution:
By an additional ten-turn potentiometer for fine adjustment of
current and/or voltage the resolution will be increased by a
factor of 100. Adjustment range
0 - 99% and a window of approx. 1%.
Power regulation with display
and adjustment:
Besides the standard voltage
regulation and current regulation, the units may be equipped
with an additional regulation
loop for constant power.
Preset indication:
The preset values can be displayed by a button besides the
appropriate meter. (For tabletop units standard.)
Electronical sweep of nominal value:
Ramp function especially for
superconductor power supplies.
Flashover sensor:
Supervising on over-current/
high voltage flashover with
signalization, shut down or
spark counter.
Interlock loop for supervising of the connected load
(e.g. door contacts):
At interrupting the interlock
loop, the unit will be shut down
by disconnecting the mains.
Only
after
pressing
the
"RESET"- button, the unit can
be put into operation again.
Fast discharge of the output:
When the unit is shut down,
e.g. together with the interlock
loop, additionally the output
capacitor will be discharged
within a distinct time. To offer
this, we need additional information on the desired discharge time, frequency of such
discharges and any existing
external capacitance which
needs to be discharged.
On request please ask us!
Active down regulation:
For fast controlled decrease of
the output voltage.
Internal impedance:
For electronic simulation of a
changing internal impedance of
the unit (e.g. battery characteristic). The technical design is
similar to the power regulation.
48
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Different mains voltage and
frequency:
As a standard, our units are
designed for a 230V, 50Hz or
400V, 50Hz three phase mains
input. But most of our units can
be modified for other mains
values, like they are used in
other countries.
Higher isolation of the output
and/or the mains input:
For special applications (e.g.
the operation at a high voltage
platform), the standard isolation
of the unit may be not sufficient.
We can deliver units with isolations up to > 200kV.
Customer specific design of
the power output:
For several types of our units
the output, as a standard, is at
the front or at the rear plate.
Optionally on request it can be
moved to any other place.
Temperature regulated fan:
Switch on of the fans of a
cooled by forced air unit only at
higher power request. This
option can be delivered for
some models only if there are
no strong requests for the stability of the current regulation.
Please take into account that
many of the options and modifications mentioned here
require a further technical
specification.
Furthermore,
we will gladly offer you more
special equipments and modifications on request.
Accessories:
Isolating transformers
Design examples
HTS 200 - 50
Function:
Technical data:
 Input voltage:
230V 47 - 63Hz
 Output voltage:
230V 47 - 63Hz
 Isolation:
primary / secondary: 50kV
DC
 Test voltage:
75kV DC for 1 min.
 Test voltage between primary
winding, primary screen and
core: 7.5kV DC
 Test voltage between secondary winding and secondary screen: 7,5kV DC
High voltage isolating transformers are used to provide
mains supply to loads located
on a high voltage potential. The
primary winding is earthy.
Features:
 Compact size
 Moulded in artificial resin
 Low capacity
 Double screened
Ty pe
HTS
Nominal pow er
HTS 3000 - 50 3p
Three phase version
Design:
 Mechanical design:
Core and windings are completely moulded in artificial
resin with isolating crosspieces between the connections. Attachment at the bottom with 4 x M8 female
thread.
 Connections:
Primary and secondary side
by threaded bolts, M6, to top,
screen connections on free
wire endings.
Special designs:
 Different voltages
 Different isolation voltages
 Higher power
 Three phase versions (see
picture above)
Width
Hight
Depth
Weight
100 VA
165 mm
220 mm
160 mm
15 kg
100 -
50
HTS
500 -
50
500 VA
210 mm
230 mm
200 mm
21 kg
HTS
1000 -
50
1000 VA
210 mm
200 mm
200 mm
25 kg
HTS
2000 -
50
2000 VA
252 mm
260 mm
252 mm
40 kg
HTS
3000 -
50
3000 VA
252 mm
270 mm
250 mm
43 kg
49
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Accessories:
Mechanical components
Rack adapters
We offer rack adapters for the
installation of all FuG- tabletop
models into 19" systems. They
are available for mounting
heights from 2U to 9U and both
for 19” and for ½ 19" units.
Rack adapter for a 19"- unit
Detail:
For retrofitting of 19" rack
adapters please state the height
of the front panel!
Rack adapter for a ½19" unit
with ½19" blind panel
Rack adapter for two ½19"
units
19“ frames and tabletop cases
For our cassette power supplies
of the HCE series, we offer 19“
frames (on the left) or tabletop
cases (on the right).
Empty cases and milled front plates according to your specification
We are pleased to offer to you on request.
50
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Accessories:
High voltage cables
Type
Design
(Diameter in mm)
RG 58
Mat.- Nr.: 0502030100
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
101pF
50W
-50°C … +80°C
10cm (repeated)
2,5cm (once)
max. 10A
130660
Mat.- Nr.: 0502030130
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
82,7pF
20W
-5°C … +85°C
20cm (repeated)
3cm (once)
max.4A
RG 11
Mat.- Nr.: 0502030200
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
68pF
75W
-50°C … +80°C
20cm (repeated)
5 cm (once)
max. 6A
C 2124
Mat.- Nr.: 0502032124
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
99pF
61W
-50°C … +60°C
15,2cm
max. 27A
C 2121
Mat.- Nr.: 0502032121
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
95pF
51W
-50°C … +60°C
21,6cm
max. 30A
C2134
Mat.- Nr.: 0502032134
Capacitance/m:
Impedance:
Ambient temperature:
Bending radius:
Max. current:
102pF
64W
-50°C … +60°C
25,4cm
max. 55A
Max. Cable operating voltage
Mating connector
10kV DC
SHV
6,5kV
30kV DC
HS21
F3415
20kV
50kV DC
F3430
35kV
100kV DC
(Operating voltage connector)
HVS 65
65kV
HVS 100
100kV
150kV DC
Special plug, available only complete
with cable
200kV DC
Special plug, available only complete
with cable
51
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Accessories:
High voltage sockets
SHV– panel connector
RA 3415
HB 21
RA 3430
B 150
52
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Accessories:
High voltage connectors
Provided plugs and matching cables for FuG power
supplies
For all medium and high voltage power supplies, the appropriate output connectors , as mentioned in the table (excluding banana plugs)
are included in the delivery of the unit . Additional connectors (as
shown in page 51) can be delivered on request.
SHV- cable jack
For power supply types, not listed in the below table, the output will be
designed with special high voltage sockets, chopper bars or clamps.
As far as necessary the mating plugs will be also included in the delivery.
F 3415
Type
Connector type
Quantity
included
Stock number
matching
cable
MCA 750-1500
to MCA 3000-1500
SHV cable jack
2
03 01 04 11 05
RG 58
MCA 750-3000
to MCA 9000-3000
SHV cable jack
1
03 01 04 11 05
RG 58
MCP 14-650
to MCP 5000-650
SHV cable jack
2
03 01 04 11 05
RG 58
MCP 14-1250
to MCP 10000-1250
SHV cable jack
2
03 01 04 11 05
RG 58
MCP 14-2000
to MCP 15000-2000
SHV cable jack
2
03 01 04 11 05
RG 58
SHV cable jack
2
03 01 04 11 05
RG 58
MYN 21000-2000
HS 21
HCP 14-3500
to HCP 15000-3500
SHV cable jack
1
03 01 04 11 05
HCP 14-6500
to HCP 15000-6500
SHV cable jack
1
03 01 04 11 05
RG 58
HCP 14-12500
HCP 14-20000
to HCP 2800-12500
to HCP 140-20000
HS21
HS21
1
1
03 01 04 04 25
03 01 04 04 25
130 660
130 660
HCP 350-20000
to HCP 4200-20000
F 3430 AG 10,2
1
03 01 04 04 55
HCP 35-35000
to HCP 4200-35000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCP 35-65000
to HCP 2800-65000
HVS 65
1
03 01 04 05 70
C 2124
inclusive 3m cable
HCP 140-100000
to HCP 1400-100000
HVS 100
1
03 01 04 06 05
C 2124
inclusive 3m cable
HCP 140-150000
to HCP 700-150000
HVS 150
1
03 01 04 06 55
C 2121
inclusive 3m cable
HCH 10000-1250
F 3430
RG 58
RG 11
SHV cable jack
1
03 01 04 11 05
RG 58
HCH 10000-2000
HCH 10000-3500
and HCH 15000-2000
to HCH 30000-3500
SHV cable jack
SHV cable jack
1
1
03 01 04 11 05
03 01 04 11 05
RG 58
RG 58
HCH 10000-6500
to HCH 50000-6500
SHV cable jack
1
03 01 04 11 05
RG 58
HCH 10000-12500
to HCH 50000-12500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCH 10000-20000
to HCH 50000-20000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCH 10000-35000
to HCH 50000-35000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCH 4200-65000
to HCH 50000-65000
HVS 65
1
03 01 04 05 70
C 2124
inclusive 10m cable
HCH 2800-100000
to HCH 50000-100000
HVS 100
1
03 01 04 06 05
C 2124
inclusive 10m cable
HYN 21000-3500
to HYN 35000-3500
SHV cable jack
1
03 01 04 11 05
RG 58
HYN 70000-3500
Copper busbar
HYN 21000-6500
to HYN 70000-6500
SHV cable jack
1
03 01 04 11 05
RG 58
HYN 21000-12500
to HYN 50000-12500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HYN 7000-20000
to HYN 50000-20000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCE 7-1250
to HCE 350-1250
SHV cable jack
1
03 01 04 11 05
RG 58
HCE 7-2000
to HCE 350-2000
SHV cable jack
1
03 01 04 11 05
RG 58
HCE 7-3500
to HCE 350-3500
SHV cable jack
1
03 01 04 11 05
HCE 7-6500
to HCE 350-6500
SHV cable jack
1
03 01 04 11 05
RG 58
HCE 7-12500
to HCE 350-12500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCE 7-20000
to HCE 350-20000
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCE 7-35000
to HCE 350-35000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCK 100-2000
to HCK 10000-2000
SHV cable jack
1
03 01 04 11 05
HCK 100-3500
to HCK 10000-3500
SHV cable jack
1
03 01 04 11 05
RG 58
HCK 100-6500
to HCK 10000-6500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCK 20000-6500
S 150, HVS 65, HVS 100, HVS 150 (Difference only in length)
Comment
RG 58
RG 58
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCK 100-12500
to HCK 20000-12500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCK 100-20000
to HCK 20000-20000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
HCK 100-35000
to HCK 20000-35000
S 150 Teflon
1
03 01 04 05 56
C 2032 SNJ
HCK 100-65000
to HCK 20000-65000
HVS 65 Teflon
1
03 01 04 05 69
C 2184
HCB 1,4-1250
to HCB 70-6500
SHV cable jack
1
03 01 04 11 05
RG 58
HCB 14-12500
to HCB 140-12500
F 3415 AG 6,2
1
03 01 04 03 56
130 660
HCB 20-20000
to HCB 200-20000
F 3430 AG 10,2
1
03 01 04 04 55
RG 11
incl. cable
53
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Definitions and Terms
Absolute accuracy
The stated figure refers to the
absolute deviation of the DVM,
or of the monitors of the analog
programming. They are independent of the stability data of
the individual series.
For all families with standard
data the following absolute
accuracy values apply:
 for all nominal voltages:



< ± 0,2% of the nominal value
for all nominal currents within
the range > 5mA up to <
200A:
< ± 0,2% of the nominal value
without this range:
< ± 0,5% of the nominal value
additional error of the DVM:
< ± 2 Digits
Active pull-down control
Available on demand especially
for the NLN series: Power transistors parallel to the output
acting as a current sink.
Autoranging power supply
Power supply with automatic
ranging of the operating point.
without steps. These power
supplies can provide any combination of the rated current and
voltage - limited only by the
rated maximum available output
power.
Bipolar power supply
A bipolar power supply can be
adjusted from positive output
voltage and current to negative
with continuous zero crossing.
All bipolar power supply units of
FuG Elektronik GmbH are designed for restricted 4-quadrant
operation. The electrical power
stored within the load can be
subsequently reabsorbed by the
power supply. On request the
units can be equipped for full 4quadrant capability.
CE mark
All FuG- power supplies have a
CE label - a guarantee of compliance with the current EMC
and safety standards.
Certificate of calibration
All FuG- power supplies can be
calibrated at the factory. The
certificate of calibration, which
can be supplied on request,
confirms the compliance of the
output data with the catalogue
data:
 Indication on the DVM
 Monitor voltages*)
 Computer output data*)
 Reference voltage*)
 Linear coherence between
control voltage and output
value*)
*) Options
Charging current
FuG- capacitor charging power
supplies operate with constant
current. It is adjustable to every
value up to the nominal value.
On request, units are available
with enhanced charging current
at low voltage.
Charging power
Power specification for capacitor
charging power supplies. The
data is in J/s, and is valid for
charging from "0" to the nominal
voltage. For charging of a partially discharged capacitor a
considerably higher charging
power, up to double, can be
supplied.
Chopper controlled
See Switch mode power supply.
Deviation (Stability data)
This term is always referred to
the nominal parameter value
and is valid for operation under
constant operating conditions.
Constant operating conditions
means that, in each case, all
other conditions such as the
load, ambient temperature and
mains voltage are constant:
a) Deviation of the output voltage (or output current when
specified) for ±10% variation
of the line voltage.
b) Deviation of the output voltage (or output current when
specified) over a period of 8
hours, after an appropriate
warm up time.
c) Deviation of the output voltage at load changes from
full load to no load.
stage. The high efficiency of the
thyristor pre-regulator stage is
combined with the high regulation characteristics of a linear
regulator.
Dump switch
Rapid discharge switch for the
controlled discharging of internal and external capacitors.
(see also Interlock)
Efficiency
The efficiency of the units depends on the respective operating point. At full load a figure of
85 -95% will be reached with
switched and thyristor regulated
power supplies ,whilst 70 -90%
is achievable with linear regulated power supplies with thyristor pre-regulation.
Electronic load
A unit, which has the behaviour
of an adjustable load resistor.
Usually, it is used for testing
power supplies. Depending on
the design, it is possible to
adjust and regulate the resistance, the load power or the
load current. FuG offers customized electronic loads on
request.
EMC
Electro Magnetic Compatibility.
See Regulations and Standards.
EURO-size
19" cassette system cases, 3U
Fast de-energizing
Option for super conductor
supplies for controlled deenergization of super conducting coils/magnets at quench.
Final charging voltage
Preset voltage for capacitor
charging power supplies up to
which the capacitor shall be
charged.
Discharge time constant
This data always relates to the
unconnected output. It is the
time taken for the output voltage
to decay to approx. 37% of the
adjusted voltage after the output
has been switched off.
Double stabilized power supply
Such units are equipped with a
thyristor pre-regulator followed
by a linear transistor regulator
54
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Floating output
The specified output terminals
have no DC connection to other
parts of the unit or to ground.
The maximum potential difference (isolation voltage) is indicated.
IMS-size
Older size of plug-in cases, 4U
Interlock
Loop for switching off the output
voltage when disconnected.
Mains disconnection of the
power stage, but without any
forced discharging of the output
or load. (see also dump switch)
ISO 9001
Since 1994 FuG has maintained
this quality assurance system.
All supplied units are tested
(using calibrated measuring
instruments) and the results are
recorded in our test department,
so as to ensure that all units
shipped are fully in accordance
with their specification.
Linear regulation
Control of energy flow by one or
more of bipolar or field effect
transistors which are switched
in series to the load and operated with the linear part of their
characteristic.
Mains connection
Stated is the mains voltage, the
permissible tolerance (±10%),
the line frequency range and
the type of mains connection,
e.g. single phase, two-phase or
three-phase. Connection of N
(neutral) and PE (protective
earth) are always necessary.
Nominal current
Maximum available current.
Nominal power
Maximum available power from
the power supply. No higher
power is available - even for a
short time. For FuG- power supplies the first number in the type
name is the power class or the
main component of the power
supply. This value is approximately (but may be not exactly)
the nominal power.
Definitions and Terms
Nominal voltage
Maximum adjustable voltage.
For FuG- power supplies the
second number in the type
name is usually the nominal
voltage of the power supply.
Operational conditions
As far as not otherwise stated in
the manual, for Fug power supplies the following conditions
are valid:
Temperature: 0 to +40 °C
Humidity:
0 to 85% not
condensing
Height over sea level:
max. 2000m
Output isolation
On units where the "0V" terminal is not firmly connected to
earth (or may be optionally
disconnected from earth), it is
always shown up to which maximum voltage the terminal may
be allowed to float with respect
to earth.
For units with floating output (all
low and medium voltage power
supplies up to 2kV - except
cassettes) this value is valid for
either of the output terminals.
PROBUS
FuG name for our system of
computer interfaces.
PWM-Regulator
Regulator utilising Pulse Width
Modulation. Such regulators are
used in switch mode power
supplies and in drives.
Quench
The transition of a super conducting coil / magnet from super
conducting to normally conducting condition. If no special
measures are taken, the energy, stored in the magnetic field,
will be converted into thermal
energy, within a short time,
when quench occurs.
Quench detector
Circuit to detect a quench.
Recovery time
This characteristic is stated
independently for voltage and
current:
For voltage control, it is the
time which the power supply
requires to return to the adjusted voltage after a load variation
from 10% to 100%, or from
100% to 10%.
For current control, it is the
time which the power supply
requires to return to the adjusted current after a load variation
where the output voltage does
not change by more than 10%
of the nominal voltage.
Regulation mode
Standard power supplies can
be operated in constant voltage
mode or constant current
mode. Switching over takes
place automatically with sharp
transition. For FuG power supplies the regulation mode is
displayed on the front plate by
LEDs.
Regulations and standards
The design and production of
our power supplies is in accordance with the latest standards
for EMC and safety. Depending
on the type of the respective
unit, different standards are
valid:
EMC:
EN61000-6-1 and EN61000-6-3
(single-phase mains connection)
EN61000-6-2 and EN61000-6-4
(two- and three-phase mains
connection)
Safety:
EN 61010
Repetition frequency
This frequency corresponds to
the repetitive charge and discharge of a capacitor by a capacitor charging power supply.
The reproducibility of the end-of
-charge voltage depends on the
repetition frequency.
Reproducibility
Repeatability of setting of a
desired output value under
constant conditions - it is always referred to the nominal
value of the supply.
Residual Ripple
If not otherwise stated the residual voltage ripple is the referredto parameter. It is always referred to the nominal value independent of the set value. The
frequency of the ripple is the
frequency of the mains rectifier
and its harmonics. For chopper
controlled units there is also a
component of the switching
frequency (usually 20kHz/40
kHz). For capacitor charging
power supplies the value of the
charging current is the referredto parameter.
For FuG- power supplies the
residual ripple usually is stated
as “Peak to peak”. (“p-p”) value.
It is different to the “RMS” value
since this measurement also
takes into account the short
term voltage peaks on full scale.
RMS
The energetically equivalent DC
value (also effective value) to an
alternating voltage. It corresponds to the square root of the
integral of squares (Root Mean
Square). For a purely sinusoidal
voltage the rms value corresponds to about 36% (1/(2x√2))
of the "peak-to-peak" value. At a
pulse range consisting of narrow
peaks (which is typically the
case for the residual ripple of a
switched mode power supply)
the difference can be considerably larger.
Safety
See Regulations and Standards.
Sense terminals
For low voltage power supplies,
sense lines can be connected to
these terminals to measure the
voltage immediately at the load
and by this to compensate for
any voltage drop on the loadlines. The nominal output voltage always refers to the actual
output terminals and does not
take account of any voltage
drop on the load-lines. The compensation of the voltage drop on
the load-lines is restricted to a
maximum of 5% of the nominal
voltage (minimum of 1V) and
has to be considered when
choosing a supply.
Setting resolution
Smallest possible steps for the
adjustment of voltage or current
- always referred to the nominal
value.
Setting time
The time required before the
output value of a power supply
reaches the set value in the
limits of the stated tolerance.
Stability
See deviation.
Standards
See Regulations and Standards.
Switch mode power supply
Power supply where the transmission of energy is performed
by high frequently alternating
voltage.
Temperature coefficient (Tc)
In addition to the value for longterm stability (see deviation), we
also refer to the 'drift' of an
output value as a function of the
variation in the ambient temperature whilst the supply is operating under otherwise constant
conditions. The data is specified
as 'per Kelvin' and is only valid
within the stated operating temperature range. The Tc is always referred to the nominal
value. When the option "higher
stability" is integrated, then the
Tc figure improves.
Thyristor regulation
Control of energy flow by a
phase cutting circuit with thyristors, operating at the frequency
of the mains input.
Unipolar power supply
Units with only one polarity and
with no regulation through zero.
Warm-up time
Stability data is only valid after a
warm-up time of min. 30
minutes.
2-quadrant operation
The unit operates as a current
source and also as current sink
(electronic load) with only one
polarity of the output voltage.
(See active pull-down.)
4-quadrant operation
The unit operates as a current
source and also as current sink
(electronic load) with both polarities of the output voltage. (See
also bipolar power supply.)
55
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Examples for customer specific power supplies:
We design and manufacture according to your requests!
MCP 140 - 2000
Medium voltage precision power supply
Equipped with the options: coarse/fine potentiometers for voltage and current, digital interface, analog programming and power limitation.
HCV 3,1M - 12000
Power supply for VUVSpectrometer
3 outputs in series:
0 - ±100V; 0 - 1mA
0 - +2000V; 0 - 1mA
0 - +10000V; max. 0,1mA
HCV 57M - 20000
Multiple output high voltage supply
19 voltage sources with 11 output voltages
from 6kV to 20kV
NLV 27M - 400
Power supply for beam deflection
5 double outputs with counter moving voltages:
0 - ±400V; max. 1mA
56
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
Examples for customer specific power supplies:
We design and manufacture according to your requests!
MCP 1100 - 1100
Power supply for undersea applications
0 - 1,1kV, 0 - 1A
With two separate switchable outputs, isolated and monitored, Wide input range 85V - 265V
HCV 349M - 6500
High voltage supply for backward wave tube
0 - 6,5kV, 0 - 50mA
With floating heater supply
Special design for airborne use (vibration hard)
HCE 2,4M - 12000
Customer specific high voltage module
0 - 12kV, max. 200µA
For picture tube testing
HCN7E - 7000
Customer specific test equipment
0 - 7kV, max. 1mA
With test pistol
NTN 100M - 12,5
Isolated low voltage power supply
0 - 12,5V, 0 - 8A
Designed for floating operation up to 20kV
HCM 7,5 - 30000
Customer specific high voltage module
Bipolar
0 - ± 30kV, 0 - ±0,25mA
For mass spectrometers
HCN 35M - 70000
Insultation Tester
0 - 70kV, 0 - 0,5mA
Two high-resolution current measurement circuits.
57
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
Examples for customer specific power supplies:
We design and manufacture according to your requests!
HCK 800M - 13000
Cable Tester
13kV / 120mA
Many special functions
HCN 12900M - 300000
High voltage power supply
300kV, 60mA (Fold back to 35mA at full voltage)
Two additional 12.5kV supplies installed for clearing electrodes
For the operation of an electrostatic septum for particle accelerators
HCK 50000M - 50000
14 pieces of Capacitor charging power supplies
50kV, 2A
Very high reproducibility (10ppm) for klystron supply of a free electron laser
58
©
V 0913
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
HCK 150M - 100000
Capacitor charging power supply
For lightning-arrestor test bench
100kV / 3mA
Special version: Output via brass ball
Examples for customer specific power supplies:
We design and manufacture according to your requests!
HCV 4200M - 400000
Double High voltage power
supply for X-Ray tube
Two symmetrical outputs: 0 to
+200kV und 0 to -200kV.
Additional output for anode
heater, floating on negative
output potential.
Regulation loops for voltage
control, current control and
emission
current
control.
(Regulation loop is closed via
filament current .)
For the calibration of the power
supply two high precision voltage dividers are included (right
and left)
HCV 141510M - 40000
Power supply for IOT (Inductive Output Tube)
Anode voltage 40kV with max. 3,4A
Additionally, all auxiliary supplies necessary for the operation of the tube, such as heating, grid bias voltage
and focusing, are provided.
The electromagnetic field generated by the IOT is used to accelerate electrons for a synchrotron radiation
standard to a accurate defined distinct energy.
59
©
FuG Elektronik GmbH, D-83135 Schechen, Am Eschengrund 11
http://www.fug-elektronik.de, E-Mail: info@fug-elektronik.de
V 0913
