ENGLISH
Quick Install Guide
ShareCenter® Cloud Storage 2000
Minimum System Requirements
• One or two 3.5” SATA Hard Drive(s)
• Computer with: 1GHz processor/512MB RAM/200MB available disk
space/CD ROM drive
• Internet Explorer version 7.0 or Mozilla Firefox 3.0 or above
• Windows® 7, Vista®, or XP (with Service Pack 2); Mac OS® X (10.5 or
above)
Installation - Windows® Only
The Setup Wizard on the CD-ROM will give you step-by-step instructions
how to connect, install, and configure your DNS-320L.
Thank you for purchasing the ShareCenter® Cloud Storage 2000. Follow the easy
steps in this guide to properly set up your storage device. Please verify that all the
package contents listed below are available.
Package Contents
DNS-320L ShareCenter® Cloud Storage 2000
CAT5 Ethernet Cable
Step 1:
Insert the supplied CD-ROM into your computer. When the autorun screen
appears, click Install.
Step 2:
Follow the on-screen instructions. Once completed you can log into the
DNS-320L for advanced configuration.
Installation - Mac OS® X Only
The Setup Wizard on the CD-ROM will give you step-by-step instructions
how to connect, install, and configure your DNS-320L.
Hard Drive Mounting Kit (2 straps, 4 screws)
Power Cord and Adapter
CD-ROM with Manual and Software
If any of the above items are missing, please contact your reseller.
DNS-320L
Step 1:
Insert the supplied CD-ROM into your computer and navigate to the Setup
Wizard > Mac folder. Launch the setup wizard file.
Step 2:
Follow the on-screen instructions. Once completed you can log into the
DNS-320L for advanced configuration.
Manual Installation
For Linux users or for manual installation, follow the steps below:
Step 1:
Remove the top cover of your device by pressing the push button in and
then lift the cover up.
Step 7:
Select System Administrator and click the Login button (leave the
password blank by default). Once you are logged in, click Management
and then click Setup Wizard. Follow the on-screen instructions to
configure your device.
Step 2:
Attach the strap to your hard drive(s) with the supplied screws.
Step 3:
Insert one or two 3.5” SATA hard drive(s) into the drive bay until they are
firmly seated. Then, re-attach the top cover.
DNS-320L
Router
Step 4:
Plug an Ethernet cable to the Ethernet port on the back of the device and
plug the other end to your network via a router or switch, or directly to a
computer for configuration.
Step 5:
Connect the power adapter to the device and then connect the other end
into a power outlet or surge protector. Press the power button on the front
of the device to turn the device on.
Step 6:
Open a web browser and enter the IP address of the DNS-320L to access
the Web UI. If you have a DHCP-enabled router on your network, you may
need to check the DHCP table to see what IP address the DNS-320L was
assigned.
Note: The computer used to access the ShareCenter® web-based
configuration manager must be on the same subnet as the ShareCenter®.
If your network is using a DHCP server and the computer receives IP
settings from the DHCP server, the ShareCenter® will automatically be in
the same subnet.
Modem
RESET
DC-IN
LAN
USB
1
2
LAN
3
4
INTERNET
USB
5V - - - 3A
LAN
Note: Please refer to the manual for more information.
Technical Support
Having trouble installing your new product? D-Link’s website contains the latest
user documentation and software updates for D-Link products. U.S. and Canadian
customers can contact D-Link Technical Support through our website or by phone.
United States
Canada
Telephone: (877) 453-5465
Internet: http://support.dlink.com
Telephone: (800) 361-5265
Internet: http://support.dlink.ca
