Samsung UN40B7000WF Service manual

液晶显示器-电视
底板:N74A
型号 : UA46B8000XF
UA55B8000XF
维 修
手 册
薄膜液晶显示器电视
目录
1.注意事项
2.产品规格
3.拆卸和重新组装
4.故障排除
5.分解图和零件清单
6. 接线图
UA46B8000XF/UA55B8000XF
参阅 GSPN 维修手册(翻阅封底)获取更多信息。
目录表
1.注意事项 ........................................................................................................................................ 1-1
1-1 安全注意事项 ........................................................................................................................... 1-1
1-2 维修注意事项 ........................................................................................................................... 1-2
1-3 静电敏感器件(ESD)注意事项 .............................................................................................. 1-2
1-4 安装注意事项 ........................................................................................................................... 1-3
2.产品规格 .........................................................................................................................................2-1
2-1 特点与规格 ..............................................................................................................................2-1
2-2 MJC:运动加帧处理引擎(FRC) ............................................................................................ 2-7
2-3 电视网络 .................................................................................................................................2-8
2-4 使用内容库 ..........................................................................................................................2-17
2-5 使用电视存储目录 .................................................................................................................2-18
2-6 使用内容管理器 ...................................................................................................................2-29
2-7 媒体播放器 ............................................................................................................................2-20
2-8 与老型号的规格比较 ...............................................................................................................2-22
2-9 附件 ....................................................................................................................................... 2-23
3.拆卸和重新组装.............................................................................................................................. .3-1
3-1 拆卸和重新组装 ..................................................................................................................... 3-1
4.故障排除 ......................................................................................................................................... 4-1
4-1 故障排除 ............................................................................................................................... 4-1
4-2 调整和调节 ............................................................................................................................ 4-25
4-3 工厂模式调节 ......................................................................................................................... .4-26
4-4 白平衡-校准 ...................................................................................................................... ...4-36
4-5 维修信息 ................................................................................................................................. 4-38
5.分解图和零件清单 ........................................................................................................................... 5-1
5-1. UA46B8000XF 分解图 .......................................................................................................…..5-1
5-2. UA55B8000XF 分解图 ....................................................................................... ……………...5-3
5-3. UA46B8000XF 零件清单...........................................................................................................5-5
5-4. UA55B8000XF 零件清单....................................................................................................... 5-37
6.接线图 ............................................................................................................................................. 6-1
6-1 接线图 46/55”......................................................................................................................... ...6-1
6-2 连接器功能................................................................................................................................6-4
6-3 接线.............................................................................................................................. ………... 6-4
GSPN (全球维修合作网络)
国家
北美
拉丁美洲
CIS
欧洲
中国
亚洲
中东&非洲
网站
service.samsungportal.com
latin.samsungportal.com
cis.samsungportal.com
europe.samsungportal.com
china.samsungportal.com
asia.samsungportal.com
mea.samsungportal.com
本维修手册归三星电子有限公司所有。 未经授权使用该
手册可能受到适用的国际和/或国内法律 的惩罚。
© 2008三星电子有限公司。
版权所有
中国印刷
P/N: BN82-00632A-00
3 拆卸和重新组装
3.拆卸和重新组装
维修手册的这一章叙述UA40B8000XF液晶显示电视的拆卸和重新组装步骤。
警告:本显示器包含静电敏感器件,处理这些部件时应小心。
3-1.拆卸
小心:1. 拆卸显示器前,请断开电源。
2. 小心按如下步骤进行;除所提供的工具外不得使用其它金属工具。
说明
1.
图片说明
螺钉
将显示屏面朝下放置在垫有软垫
的 桌面上。
拆卸底座上的螺钉。
拆卸底座。
3-1
3 拆卸和重新组装
说明
2.拆卸后盖螺钉。
2-1.拉出交流电源线。
3.提起后盖。
3-2
图片说明
螺钉
3 拆卸和重新组装
说明
图片说明
螺钉
4.拆卸 SMPS、主板和低音器及架座上
的接线和螺钉。
40”
46”/55” 低音扩音器2个
3-3
3 拆卸和重新组装
说明
5.拆卸屏板架上的螺钉。
※
3-4
重新组装步骤与拆卸步骤相反。
图片说明
螺钉
4. 故障排除
4.故障排除
4-1.故障排除
1. 首先检查各电缆连接情况。
·检查是否有烧坏或损坏的接线。
·检查接线是否断开,或连接处太松。
·检查是否依据连接图连接接线。
2. 检查主板的电源输入。
3. 检查 FRC 和 FBE3 选项的内部图案。
FRC:工厂模式(静音 1-8-2,当电视处于待机模式时开启)->控制->测试模式->FRC PATT->DDR 前
/DDR 后。
*FRCM 图案由 FRCM IC(T-con)产生
FBE3:工厂模式(静音 1-8-2,当电视处于待机模式时开启)->控制->测试模式->FBE Pattem Sel。
*主图案由主电路产生(Chelsea)
情况 1:FBE3 正常,FRC 不正常:更换 T-con 板。
情况 2:FBE3 不正常,FRC 不正常:更换主板。
<46 英寸型号>
*FRCQ:Micronas FRC 芯片
4-1
4. 故障排除
„ 简单的故障流程图
是
电视是否打开?
否
屏幕是否有显示?
是
否
显示屏上是否有在
屏显示调节菜单?
是
否
检查连接到主板上的
LVCD 接线,必要时更换
主板。
检查电源线
是否可以看到数字
信道广播。
否
是
射频信号被连接时,
电视是否有声音?
更换主板
是
检查 LVDS 接线的
连接,必要时更换
T-con 板。
否
CN1001 的管脚 27
上的电压是否为
5V?
否
检查 30p 接线,必要时
更换 SMPS 板。
是
CN1001 的管脚 9
是否出现电压
B13V?
是
请联系技术支持部门。
4-2
否
更换主板
否
更换主板。
4. 故障排除
■新功能故障排除
我设法在 Wiselink 中设置 BGM。
Media 的说明
只有当“音乐 DB”配置完成时,才可使用 BGM 慢移和“语
气”设置。进入音乐类型,并首先完成“音乐 DB”配置。
我可以选择文件,但不能配置“语气”
设置。
在运行 Wiselink 后,我不能进入“照
Media 的说明
检查 USB 存储器是否包括 MP3 或 JPEG 文件。
Media 的说明
当电视机不支持照片格式,或者 JPEG 文件未包括缩略图
片”或“音乐”
在照片类型中未显示照片缩略图。
时,可能出现这种情况。
在电影类型中,未显示视频缩略图。 Media 的说明
只有当至少播放视频一次时,才显示视频缩略图。
USB 存储器中的 JPEG 文件不在列
Media 的说明
不显示路径长于 256 个字符的文件。
Media 的说明
当在 PTP 模式下连接设备时,不支持浏览文件夹。
我不能播放当前加亮选中的文件。
Media 的说明
检查是否选择了另一个文件(检查)。将播放选定的文件。
我想了解支持的照片颜色格式。
Media 的说明
支持 RGB、YUV、YcbCr、CMYK、YCCK、GRAY 格式。
我想了解支持的照片最大分辨率。
Media 的说明
最大分辨率是 15360x8640 像素。
我想了解支持和音乐采样频率。
Media 的说明
支持的频率为 8、11.025、12、16、22.05、24、32、44.1、
表上。
我连接了数码相机,但是不能浏览文
件夹。
48 Khz
我不能播放从网站下载的 MP3 文
Media 的说明
不支持播放 DRM 文件(用于保护内容)。
Media 的说明
电视机只支持不支持大容量存储类型或 PTP 类型的设备。
件 。( 向 MP3 下 载 网 站 付费 , 如
Melon)
我想了解知道的 USB 设备。
当通过 USB 集线器将设备连接到电视机上时,不支持设
备。不保证支持需要外部电源的 USB 设备,如外部 HDD。
不保证支持需要安装附加设备驱动程序的 USB 设备
支持的照片播放速度慢。
Media 的说明
因为电视机不使用缓冲,与计算机不同,可能需要花一些
时间显示高分辨率照片。
我不能播放付费 MP3 文件。
Media 的说明
如果 MP3 文件有 DRM(保护副本)文件,则不会播放文
件。
我不能播放支持 PTP 的数码相机。
Media 的说明
检查数码相机的 PTP 模式。它在打印机连接模式下不会
工作。
我不能使用支持 PTP 的数码相机的
Media 的说明
对 PTP 设备,不能设置早晨叫醒功能。
早晨叫醒功能。
在连接 PTP 后或在运行期间,我将
Media 的说明
不支持在连接以后或运行期间在 MSC 和 PTP 之间切换连
设备设置改为 MSC 连接模式,但未
接模式。只可在断开数码相机以后改变数码相机连接模
识别设备。
式。
WLAN 不工作。
Media 的说明
由三星电子(附送)提供的 WLAN USB 棒以外的设备不
会工作。共享程序必须支持 IEEE 801.11 g/b。不支持 IEEE
801.11n。
4-3
4. 故障排除
我在 WLAN 设置菜单中找不到互联
网共享程序。
WISELINK 的说明
只支持共享程序的 InfraStructure。不支持 Ad-Hoc 模式。
如果使用多个共享程序,配置这些程序,使这些程序不使用
同一通道。将共享程序设置为未控制 ICMP,以便此程序回
应 Ping 测试。
WLAN 数据速率慢。
WISELINK 的说明
如果距共享程序的距离太远,操作可能慢或者可能找不到共
享程序。如果在电视机和共享程序之间有障碍、墙壁或电子
设备,则操作可能慢或者因通信困难,可能找不到共享程序。
我在电视机上可以看到的 DLNA 服
务器突然消失了。我应该怎么办?
PC 共享管理器搜索
1. 检查是否关闭计算机。
2. 检查是否在三星计算机共享管理器的访问控制菜单中
是否将三星电视机设置为拒接连接。若果真如此,改变
设置,以便连接。
3. 检查是否将 LAN 接线接到计算机和电视机上。
尽管三星计算机服务器开着,弹出信
息,告知三星服务器关闭。
PC 共享管理器搜索
当重新配置服务器的共享文件夹时,DLNA 服务器功能暂时
停止,然后在重新配置完成后继续运行。当改变服务器名称
时,DLNA 服务器功能也暂时停止,然后继续运行。
我在三星计算机共享管理器中注册
了文件,以便在电视机上观看,但我
在电视机上找不到文件。我该怎么
办?
内容共享
1. 并未对每个文件提供共享功能。采用 DLNA 不支持的
格式的文件,即使在计算机上显示,也不会在电视机上
显示。请接受我们的道歉,我们正在研究这个问题。
2. 检查在三星计算机共享管理器上注册了文件的文件夹
是否共享。文件夹也应共享。
3. 检查在共享包括文件的文件夹后是否点击应用按钮。如
果您不能确定,请再次点击此按钮,并且在片刻之后重
新检查是否显示文件。
我可以通过共享管理器看到共享文
件夹,但我看不到文件。
内容共享
因为只显示与图像、音乐和电影类型对应的文件,所以可能
不显示与这些类型不相符的文件。
连接到网络上的计算机上的 2x 和 3x
快进视频功能不起作用。
DLNA 视频播放
支持在通过网络连接的计算机上播放视频的功能不支持 2x
和 3x 快进功能。
间歇播放视频。
DLNA 视频播放
检查网络是否稳定。检查是否正确连接网络接线以及网络是
否过载。如果在服务器和 DTV 之间的无线网络部分,通信
环境可能不稳定。
可能不支持暂停功能,这取决于 DLNA 服务器或服务器提
供的内容。也不支持搜索功能。
在播放视频或音乐文件时,按下暂停 DLNA 视频播放
键不起作用。搜索功能也不起作用。
我不能在计算机共享管理器程序中
通过拖放文件夹或文件,来移动文件
夹和文件,也不能复制文件夹或文
件。
我更换了 L750 Ruby DTV,更换了
旧的。但是,在更换 DTV 后,尽管
我使用与以前使用的相同的 IP 地址,
但我找不到计算机服务器。
我不能播放视频文件。
计算机共享管理器功
能
计算机共享管理器程序提供与计算机和电视机共享的文件,
并未提供那些功能。
访问控制功能只依据
目标设备的 MAC 地
址运行。
应在计算机共享管理器菜单->共享->设置设备策略中将新
DTV 设置为“接受”。
DLNA 视频播放
只可播放由三星摄录一体机和数码相机录制的视频。其他视
频可能能播放或不能播放,这取决于分辨率和格式。
在播放视频时,我可以看到画面,但
听不到声音。
DLNA 视频播放
如果不支持声音格式,或者文件为非隔行扫描文件,则只播
放视频。
4-4
4. 故障排除
我不能播放具有 wmv 或 flv 扩展名的
文件。
我在按 2x 快进播放时,不能使用 20
秒搜索功能。
尽管我可播放一些文件,但我不能播
放其他文件,即使文件有相同的分辨
率和格式,也是如此。
我可以使用 USB 设备运行特技和搜
索功能,但我不能用 DLNA 运行特
技和搜索功能。
如何可以显示字幕?
当我进入电视网络时,显示“连接服
务……”警告信息框,在此可以选择
“重试”或“取消”,并且不能进入
电视网络。(未显示面板条。)
尽管我可以进入电视网络,但我不能
连接到服务上。
当连接网络时,我不能连接到一些信
息上。
在详细新闻视图中未显示或间歇显
示照片。
新闻模式信息变化。(例如,新闻模
式列表中有“娱乐”,但从列表删除
了此项。)
显示的股票价格与当前价格不同。
DLNA 视频播放
对于具有这些扩展名的文件,不支持视频播放功能。
DLNA 视频播放
如欲在按 2x 快进播放时使用搜索功能,按下播放按钮,可
首先使播放速度正常。此后,则可以使用搜索功能。
对于未支持的视频,可以播放某些分辨率和格式的一些视
频。
DLNA 视频播放
DLNA 视频播放
对于 DNLA,不支持特技功能。对于 PS 和 TS,只支持搜索
功能。
DLNA 视频播放
电视网络的说明
只显示 smi 字幕文件的第一个语言。
当在购买电视机后,未从电视网络收到正常信息时,会出现
这种情况。在这种情况下,连接互联网接线,然后再试。
电视网络的说明
当至少正确电视网络一次但是当前未连接互联网时,会出现
这种情况。在这种情况下,连接互联网接线,再试。
当 CP 发送不完整的信息时,会出现这种情况。在这种情况
下,重新连接到互联网上,并再试。
因互联网速度慢,可能出现这种情况。重试,并就数据速率
低的问题咨询互联网服务提供商。
只按 CP 提供的样子显示新闻模式信息,与电视机无关。
电视网络的说明
电视网络的说明
电视网络的说明
电视网络的说明
由 CP 提供相应信息,与电视机无关。CP 提供的信息为延
迟信息,在服务中显示告知观看人员信息为延迟信息的声
明。
4-5
4. 故障排除
我想知道如何进入主屏。
内容库的说明
按下[菜单]按钮,移到[应用],并从子菜单选择[内容库],可
进入主屏。另外,从遥控器热键中按下[内容]按钮,可进入
相应服务的主屏。
我想知道如何删除、复制或将电视机
上存储的内容移动到外部设备。
内容库的说明
未支持删除、复制和移动默认内置内容。
我听说电视机有内置 2GB 闪存。怎
么访问闪存?
内容库的说明
我想使用画廊功能以幻灯片形式播
放个人照片,我如何做?
内容库的说明
电视机内安装的内置闪存只用于支持各种电视功能,不用于
用户保存内容。但是,可以将外部 USB 存储设备连接到电
视机上,并播放 USB 存储器上的内容。
在[内容库]中未播放 Samsung.com 或与 Samsung.com 链接
的第三方内容提供商提供的图像。但是,可以使用 WiseLink
Pro 的幻灯片功能。
当第二次玩游戏时,我想从以前运行
的最后一个画面开始继续,我如何
做?
[内容库]中内置游戏是不支持游戏保存功能的非正式的基本
游戏。
在播放内容时按下遥控按钮,会终止
当前的服务,并显示电视信号源屏。
按下遥控器上与频道相关的按钮,可显示电视信号源屏。小
心不要误按频道增加/频道减小、频道列表、指导、Pre. Ch
和 Fav. Ch 按钮。
[内容库]不支持播放三星电子批准播放的文件或三星电子授
权的第三方内容提供商正式提供的文件以外的文件。
我听说由 Adobe flash player 播放默
认内置内容。因此,我从互联网下载
了 Flash 内容,并试图从 USB 存储
设备播放,但是未播放。是什么问
题?
我想知道如何下载和播放默认内置 内容库的说明
内容以外的新内容。
我将内容下载到了 USB 存储设备 内容库的说明
上,并将 USB 存储器插入电视机来
播放内容,但是电视机根本不工作。
通过 Samsung.com 提供新内容。由相应内容提供商负责提
供由第三方内容提供商提供的内容。
检查是否正确连接 USB 设备。如果即使正确连接,屏幕上
也无显示,则进入内容库主屏,并按下“红色”按钮,移到
USB 内容搜索屏。如果电视机未识别 USB 设备,关闭电视
机,然后再打开,重新插入 USB 存储器,并重复上述步骤。
当播放外部 USB 存储设备上的内容
时,不能播放。
内容库的说明
检查 USB 连接,并再试。
当我靠近看产品边缘时,可以看到微
量异物。
外观的说明
在设计本产品时,用透明物质涂敷空边边缘,使颜色显示暗
淡。看到的物质是因设计引起的,不属于产品缺陷。
4-6
4. 故障排除
4-1-1.未通电
征兆
主要检查点
小心
-当连接电源线时,PD 板继电器未工作。
-本机似乎损坏。
如果接线连接不当或主板或 PD 板有故障,当连接电源线时,PD 板继电器不工作。
在这种情况下,检查下列各项:
-检查本机内部接线连接状态。
-检查各零件的保险丝。
-检查 PD 板的输出电压。
-更换主板。
在 IP 板上工作之前,必须断电。
电源开启时,检查继电器是否
有声音发出?
是
在CN1001的管脚27上是否出
现合适的待机DC A5V?
否
否
检查电源线的连接。
P/N:BN96-09872A
更换主电源组件
40” / 46”:BN44-00269A
55” :BN44-00271A
是
诊断
在 CN1001 的管脚 23,管脚 15
和管脚 9 上是否出现合适的主
DC B12VS,B5V,B13V?
否
是
IC1002的管脚5上是否出
现合适的DC A3.3V?
否
更换IC1002或主板组件
是
IC1005的管脚1和IC1008上是
否出现合适的DCB3.3V及
IC1003的管脚3是否出现
B9V?
否
更换IC1005、 IC1008、
IC1003或主板组件
BN94-02706A。
是
在C1032,C1033上chelsea
核磁是否出现合适的1.2V,
1.8V?
否
是
供应到屏板上的电源是否可
以在C7136上显现。
否
更换 IC1007,IC1008 或更换
主板组件。
检查其它功能(无图片部分)
更换液晶显示屏
40” :BN07-00700B
46”:BN07-00701B
55”:BN07-00702B
4-7
4. 故障排除
4-8
4. 故障排除
4-1-2.无图像(模拟 PC 信号)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查 PC 信号源
-检查IC7001(chelsea)
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 IP 板上工作之前,必须断电。
无视频
是
诊断
检查 PC 源并检查 DSUB 的
连接是否正常?
否
输入模拟 PC 信号,检查
接线的连接。
否
PC 接线
更换 PC 接线,变更主印刷
电路板组件。
否
更换 IC6001 或主印刷电
路板组件
是
X
在 CN3011 的管脚 1、2、3、
13、14(R,G,B,H,V)是否有信号
出现?
是
Y
IC6001 的输出是否有数字数
据出现?
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-9
4. 故障排除
波形
XY
Z
4-10
PC 输入(竖直同步,水平同步)
LVDS 输出 (CLK + / -)
4. 故障排除
4-1-3. 无图像(HDMI-数字信号)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查 HDMI 信号源
-检查 IC7001(chelsea)
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 IP 板上工作之前,必须断电。
无视频
是
检查 HDMI 源并检查 HDMI
接线的连接是否正常?
否
输入 HDMI 信号
检查接线的连接。
否
检查 CN3013、 3016、3015、
3010
(HDMI1,2,3,4),更换 HDMI 接
线,更换主印刷电路板组件。
否
更换 IC3013 或主印刷电
路板组件
否
检查 IC7001
更换主印刷电路板组件
是
诊断
[
信号是否出现在 IC3013
管脚 2~12(HDMI1),管脚
14~24(HDMI2),
管脚 27~37(HDMI3),管脚
39~49(HDMI4)上?
是
\
IC3013 的管脚 89-99(HDMI)
的输出是否有数字数据出现?
是
^
CN7005 的管脚 14-42 的输出
是否有数字数据出现?
是
检查 LVDS 接线是否正确?
检查 T-con 板是否正确?是
否需要更换液晶显示屏?
否
请联系技术支持。
4-11
4. 故障排除
波形
[\
4-12
HDMI 输入 (CLK + / -)
]
Tuner CVBS 输出 (模式: 灰色栏)
^
TS 数据输出(Clk, 数据 [0])
4. 故障排除
4-1-4.无图像(Tuner_CVBS)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查 Tuner CVBS 信号源
-检查Chelsea
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 IP 板上工作之前,必须断电。
无视频
是
检查射频源并检查射频接线
的连接是否正常?
诊断
否
输入射频信号
检查接线的连接。
是
]
TU5001 的管脚 8 是否有
信号出现?
否
检查 TU5001,并更换主印
刷电路板组件。
是
否
\
CN7005 的管脚 14-42 的输出
是否有数字数据出现?
更换 IC7001 或主印刷电
路板组件
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-13
4. 故障排除
波形
4-14
\
Tuner CVBS 输出 (模式: 灰色栏)
]
Eagle+ 输出 (Clk, 水平-同步)
4. 故障排除
4-1-5.无图像(Tuner DTV)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查 DTV 信号源
-检查 Chelsea
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 PD 板上工作之前,必须断电。
无视频
是
检查射频源并检查射频接线
的连接是否正常?
否
输入射频信号
检查接线的连接。
是
诊断
^
TU5001 的管脚 15、16 是
否有信号出现?
否
检查 TU5001,并更换主印
刷电路板组件。
是
否
\
CN7005 的管脚 14-42 的输出
是否有数字数据出现?
更换 IC7001 或主印刷电
路板组件
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-15
4. 故障排除
波形
4-16
\
Tuner CVBS 输出 (模式: 灰色栏)
^
TS DATA 输出 (Clk, 数据 [0])
4. 故障排除
4-1-6.无图像(Viedo CVBS 1)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查 DTV 信号源
-检查 Chelsea
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 PD 板上工作之前,必须断电。
无视频
是
检查视频源并检查视频接线
的连接是否正常?
否
输入视频信号
检查接线的连接。
是
诊断
\
R3070 上是否有信号出现?
否
检查 CN3005,并更换主印
刷电路板组件。
是
否
\
CN7005 的管脚 14-42 的输出
是否有数字数据出现?
更换 IC7001 或主印刷电
路板组件
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-17
4. 故障排除
波形
\
4-18
Tuner CVBS 输出 (模式: 灰色栏)
4. 故障排除
4-1-7.无图像(分量 1)
征兆
主要检查点
小心
-声音正常,但屏幕上未显示画面。
-检查分量信号源
-检查 Chelsea
-当断开连接主板和显示屏的 LVDS 接线时,可能出现这种情况。
在 PD 板上工作之前,必须断电。
无视频
是
检查视频源并检查视频接线
的连接是否正常?
否
输入视频信号
检查接线的连接。
是
`
诊断
否
R3065、R3064、R3066(Y,
Pb, Pr)上是否有信号出现?
检查 CN3004,并更换主印
刷电路板组件。
是
RA6004、 RA6005、RA6006
(Rout)
RA6007、RA6008、RA6009
(Gout)
RA6001、 RA6002、RA6003
(Bout)
的输出是否有数字数据出现?
否
更换 IC6001 或主印刷电
路板组件
是
\
CN7005 的管脚 14~42 的输
出是否有数字数据出现?
否
检查 IC7001
更换主印刷电路板组件
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-19
4. 故障排除
波形
4-20
_
Tuner CVBS 输出 (模式: 灰色栏)
_
分量输入(Y/Pb)
4. 故障排除
4-1-8.无声音
征兆
-视频正常,但无声音。
主要检查点
-当扬声器连接断开或损坏时
-当主板的声音处理部分失去功能时
-扬声器损坏。
小心
在 PD 板上工作之前,必须断电。
无声音
是
检查声音源并检查声音接线
的连接是否正常?
否
输入声音信号
检查接线的连接。
是
诊断
a
否
检查 CN3005,并更换主印
刷电路板组件。
否
更换 IC2001 或主印刷电
路板组件
否
检查 IC2002
更换主印刷电路板组件
R3069、R3071 上是否有信号
出现?
是
IC2002的管脚27、28、29
的输出是否有数字数据出现?
是
CN2001 的管脚 1~4 的输出
是否有数字数据出现?
是
检查 LVDS 接线是否正确?
是否需要更换液晶显示屏?
否
请联系技术支持。
4-21
4. 故障排除
波形
a
音频输入 (信号波)
12S 输入 (Clk, 数据)
音频放大输出 (信号波)
4-22
4. 故障排除
4-1-10. 参考
输出运行Edge Led的CNT。
(与左右的变更不相干)
当你看到TV前部的显示屏时,
如果左侧(a)发生故障,连接Y在位置X的接线,如过
为正常图片,更换LED显示屏。
如果出现异常图片,检查电源板。
如果左侧(b) 发生故障,
连接Y在位置X的接线,如过为正常图片,更换LED
显示屏。
如果出现异常图片,检查电源板。
参看符合每个LED连接器部分的图片。
然而,在外拉连接器中的对管脚时,这里有很大的区
别,所有我们推荐变更(X)或(Y)本身。
4-23
4. 故障排除
连接计算机
使用 D-sub 接线
1. 连接在电视机上的 PC 输入[PC]连接器和 PC 输出连接
器间的接线。
2. 连接电视上 PC 输入[音频]插口和计算机上声卡的音频
输出插口间的接线。
使用HDMI/DVI接线
1. 连接电视HDMI1/DVI插孔和计算机PC输出插孔间的
HDMI/DVI 线。
2. 连接电视上PC输入[音频]插口和计算机的声卡音频输
出插口间的PC音频接线。
连接DVI线
1.连接电视HDMI1/DVI插孔和设备PC输出插孔间的
HDMI/DVI 线。
2.连接电视上DVI输入[音频]插口和设备声卡音频输出
插口间的DVI音频接线。
* 每个计算机都有着不同的底板配置。
* 在连接计算机时,计算机声卡的PC声音接线需要匹配
与连接终端色彩一致的接线。
* 在使用HDMI/DVI 接线连接时,必须使用设备上的
HDMI IN 1终端和DVI声音接线。
4-24
4. 故障排除
4-2.调整和调节
4-2-1 一般维修说明
1. 通常,彩色液晶电视只需在安装时稍加调节。检查基本特性,如高度、水平和竖直同步。
2. 使用规定的测试设备或等效品。
3. 需要正确的匹配阻抗。
4. 避免过载。扫描振荡器发出的过多信号可能使电视的前端过载。当插入标志信号时,不可使标志信
号发生器干扰测试结果。
5. 只可把电视连接到具有后盖铭牌上标定的电压和频率的交流电源上。
6. 当电视机处于开机状态时,不可试图连接或断开接线。必须保证在更换任何零件时拔下电源线。
7. 为了防止电击危险,应使用隔离变压器。
4-25
4 故障排除
4-3.工厂模式调节
4-3-1 进入工厂模式
如欲进入“维修模式”,可按下列顺序按下遥控键:
-如果无工厂遥控器
Power OFF
INFO
MENU
MUTE
Power On
4-3-2 如何进入维修模式使用客户遥控
1.关机,并设置为待机模式。
2.按此顺序,按下遥控按钮:INFO - MENU - MUTE - POWER ON,打开本机。
3.本机开机,并进入服务模式。这可能花费大约 20 秒。
4.按下电源按钮退出,并将数据储存在存储器里。
-如果没能进入服务模式,重复上述第 1、2 步。
5.初始化维修模式显示状态。
模式:CDTV.RES:480I
6.维修模式下的操作按钮
Menu
Direction Keys
c/ d
Item Selection by Moving the Cursor
Direction Keys
e/ f
Data Increase / Decrease for the Selected Item
Source
4-26
Full Menu Display/Move to Parent Menu
Cycles through the active input source that are connected to the unit
4 故障排除
4-3-3 工厂数据
„ 选项
主:选项
模式:CDTV,RES:480I
„ADC/WB
ADC
AV Calibration
Success
Comp Calibration
Success
PC Calibration
Success
HDMI Calibration
Success
4-27
4 故障排除
4-28
4 故障排除
„控制
子选项
等离子选项
4-29
4 故障排除
4-30
4 故障排除
„高级(在高级选项中按下 0 按钮 4 次进入隐藏菜单)
4-31
4 故障排除
4-32
4 故障排除
4-33
4 故障排除
4-34
4 故障排除
4-35
4 故障排除
4-36
4 故障排除
4-4.白平衡-校准
4-4-1 白平衡-校准
AV Calibration
ADC/WB
ADC
Comp Calibration
PC Calibration
HDMI Calibration
4-4-2 维修调节-在调节白平衡之前,必须使用方格图进行校准
„颜色校准
调节规格
1. 信号源:HDMI
2. 设置模式:1280*720@60Hz
3. 图案:图案#24(方格图)
方格图
4. 使用设备:CA210 和主 MSPG925 发生器
-只有与主设备的结果比较结果后,才可使用其他设备。
Input mode
Calibration
Pattern
CVBS IN (Model_#1)
Perform in NTSC B&W Pattern #24
Lattice
Component IN (Model_#6)
Perform in 720p B&W Pattern #24
Lattice
Perform in VESA XGA (1024x768)
Lattice
PC Analog IN (Model_#21)
HDMI IN
B&W Pattern #24
Perform in 720p B&W Pattern #24
Lattice
<表1>
4-37
4 故障排除
„ 颜色校准方法(AV)
1) 向 AV IN1 端口发送 NTSC 方格 (第 2 号)图信号。
2) 按下信号源键,可切换到“AV1”模式。
3) 进入维修模式。
4) 选择“ADC/WB”和“ADB”菜单。
5) 选择“AV Calibration”菜单。
6) 在“AV Calibration Failure”状态下,按下“ f ”键进行校准。
7) 校准完成时,返回上一级菜单。
8) 可以看到“AV Calibration”状态从失败变为成功。
„ 颜色校准方法(分量)
1) 向分量 IN1 端口发送 720p 方格 (第 6 号)图信号。
2) 按下信号源键,可切换到“分量 1”模式。
3) 进入维修模式。
4) 选择“ADC/WB”和“ADB”菜单。
5) 选择“Comp Calibration”菜单。
6) 在“Comp DTV Calibration”状态下,按下“f ”键进行校准。
7) 校准完成时,返回上一级菜单。
8) 可以看到“Comp Calibration”状态从失败变为成功。
„ 颜色校准方法(PC)
1) 向 PC IN1 端口发送 VESA XGA (第 21 号)图信号。
2) 按下信号源键,可切换到“PC”模式。
3) 进入维修模式。
4) 选择“ADC/WB”和“ADB”菜单。
5) 选择“PC Calibration”菜单。
6) 在“PC Calibration Failure”状态下,按下“f ”键进行校准。
7) 校准完成时,返回上一级菜单。
8) 可以看到“PC Calibration”状态从失败变为成功。
„ 颜色校准方法(HDMI)
1) 向 HDM1/DVI IN 端口发送 720p 方格 (第 6 号)图信号。
2) 按下信号源键,可切换到“HDMI1”模式。
3) 进入维修模式。
4) 选择“ADC/WB”和“ADB”菜单。
5) 选择“HDMI Calibration”菜单。
6) 在“HDMI Calibration Failure”状态下,按下“ f ”键进行校准。
7) 校准完成时,返回上一级菜单。
8) 可以看到“HDMI Calibration”状态从失败变为成功。
4-38
4 故障排除
4-4-3 白平衡-调节
ADC/WB
白平衡
(弱光)
(强光)
次亮度
红色偏移
绿色偏移
蓝色偏移
次对比度
红色增益
绿色增益
蓝色增益
(白平衡调节状况,请参照下页)
4-5.维修信息
4-5-1 软件升级
三星公司在将来可能会提供电视固件的升级。请联系三星访问中心1-800-SAMSUNG (726-7864)接收关于
下载升级的信息并使用USB驱动器。升级将会通过连接USB驱动器到安置在电视背后的USB端口上。
1. 插入包含固件升级的 USB 驱动器到电视侧部的智能连接
端口上。
2. 如果弹出小窗口,按下退出或按下否按钮。(如果按下是
按钮,显示屏将会变更到智能连接菜单)。
3. 按下菜单按钮显示菜单。
按下 S 或 T 按钮可选择“设置”,然后按下确认按钮。
4. 按下 S 或 T 可选择“软件升级”,然后按下确认按钮。
5. 按下确认按钮。
出现信息 “扫描 USB,可能需要大约 30 秒的时间”
6. 出现信息 “版本升级 XXXX 到版本 XXXX ?系统在升级
后将会被重新设置”。
按下 W 或 X 按钮选择“确认”。
请注意在进行升级的过程中,不要断开电源或取下 USB 驱
动。在完成固件升级后,电视将会关闭。升级完成后请检查
固件版本。软件升级后,视频和音频设置将会返回到默认(工
厂)设置。我们推荐您写下您的设置,那样在升级后将会很
容易复位。
4-39
4 故障排除
4-5-2 自诊断功能
此种简单的测试功能用于判别电视机是否发生故障。
这里有 2 种自检,图片和声音。
1. 按下 “菜单 -> 支持 -> 自诊断”
显示信息 “图片检测 / 声音检测”。
2.图片检测
1) 显示信息“这种检测模式故障仍然存在?
”
2) 按下“是“,此为电视机故障,显示信息“联系三星公司
呼叫中心1-800-SAMSUNG 求助”。
3) 按下“否”。
这不是电视机故障。
显示信息“如果自诊断图片正常,则可能是由外部设备引
起的图片扭曲变形。请检查连接,如果故障仍然存在,请
参看外部设备用户手册“。
4-40
4 故障排除
3.声音检测
1) 显示信息“使用此声音测试故障仍然存在?”
2) 按下“是“,此为电视机故障,显示信息“联系三星公司
呼叫中心1-800-SAMSUNG 求助”。
3) 按下“否”。
这不是电视机故障。
显示信息“如果自诊断图片正常,则可能是由外部设备引起的
图片扭曲变形。请检查连接,如果故障仍然存在,请参看外部
设备用户手册“。
4-41
5. Exploded View & Part List
5. Exploded View & Part List
M0027
T0003
M0215
M0115
M0014
M0013
T0175
5-1. UA46B8000XF Exploded View
5-1
5. Exploded View & Part List
5-1-1. UA46B8000XF Parts List
Location No.
Code No.
T0003
BN96-11067H
M0215
Q’ty
S.A/S.N.A
ASSY COVER P-FRONT;46 B8000,PC(CLR)+PC(D
1
S.A
BN07-00699A
LCD-PANEL;LTF460HG02
1
S.A
T0175
BN96-09470B
ASSY SPEAKER P;8ohm,4pin,15W,R:850 / L:5
1
S.N.A
M0115
BN61-05536A
BRACKET-STAND LINK;UB7000 46inch,HGI,T3.
1
S.N.A
M0014
BN94-03008A
ASSY PCB MAIN-SQE;UA46B8000XFX*
1
S.A
M0013
BN96-11072H
ASSY COVER P-REAR;46 B8000,PCM T0.5,BKN-
1
S.A
M0027
BN96-11089A
ASSY STAND P-BASE;46 B8000,SUS304 T0.6,P
1
S.A
5-2
Description & Specification
Remark
5. Exploded View & Part List
M0027
T0003
M0215
M0115
M0014
M0013
T0175
5-2. UA55B8000XF Exploded View
5-3
5. Exploded View & Part List
5-2-1. UA55B8000XF Parts List
Location No.
Code No.
T0003
BN96-11068F
M0215
Q’ty
S.A/S.N.A
ASSY COVER P-FRONT;55 B8000,PC(CLR)+PC(D
1
S.A
BN07-00717A
LCD-PANEL;LTF550HH01
1
S.A
T0175
BN96-09470C
ASSY SPEAKER P;8ohm,4pin,15W,R:950 / L:6
1
S.A
M0115
BN61-05536A
BRACKET-STAND LINK;UB7000 46inch,HGI,T3.
1
S.N.A
M0014
BN94-03008B
ASSY PCB MAIN-SQE;UA55B8000XFX*
1
S.A
M0013
BN96-11073H
ASSY COVER P-REAR;55 B8000,PCM T0.5,BKN-
1
S.A
M0027
BN96-11091A
ASSY STAND P-BASE;55 B8000,SUS304 T0.6,P
1
S.A
5-4
Description & Specification
Remark
5. Exploded View & Part List
5-3. UA46B8000XF Parts List
Level
Location No.
Code No.
Description & Specification
UA46B8000XFXXY
UA46B8000XF,N74A/46BX1-G8X,46,LCD-TV,AUS
Q’ty
SA/SNA
0.1
M0001
BN90-02047G
ASSY COVER FRONT;46 B8000
1
S.N.A
..2
T0003
BN96-11067H
ASSY COVER P-FRONT;46 B8000,PC(CLR)+PC(D
1
S.N.A
...3
ZIGBEE+H/B
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
1
S.N.A
...3
T0069
AA60-00171V
SPACER-FELT;BE46PS,FELT,500,T0.35,10
4
S.N.A
...3
T0069
AA60-00172J
SPACER-FELT;42C7,FELT,544,BLK,0.35,10
2
S.N.A
...3
T0069
BN60-00120A
SPACER-FELT;UB7000 46inch,FELT,L16,T0.5,
4
S.N.A
BN61-04661A
BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H
4
S.N.A
...3
CCM1
BN63-02183H
COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2
0.9
S.N.A
...3
CCM1
BN63-05199B
COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL
2.8
S.N.A
...3
...3
CCM1
BN63-05199F
COVER-SHEET;AMBER,PE,T0.08,W95mm,200M,CL
1.3
S.N.A
...3
M0112
BN63-05587E
COVER-FRONT;LB8000 46,PC+PC,V0
1
S.A
BN64-01042A
DECORATION-BOTTOM;UB8000,PC,clear
1
S.N.A
T0175
BN96-09470B
ASSY SPEAKER P;8ohm,4pin,15W,R:850 / L:5
1
S.N.A
BN96-10736J
ASSY BOARD P-TOUCH FUNCTION&PO;UN46B8000
1
S.N.A
....4
M2893
BN39-01180B
LEAD CONNECTOR;UE40B7000WWXXC,UL2835#30,
1
S.A
....4
M2893
BN39-01181C
LEAD CONNECTOR;UE40B7000WWXXC,UL1061#28,
1
S.A
BN96-10735A
ASSY BOARD P-TOUCH POWER&IR;LN46B7000WFX
1
S.N.A
S.N.A
...3
...3
...3
....4
....4
M0175
BN96-10736A
ASSY BOARD P-TOUCH FUNCTION;LN46B7000WFX
1
....4
M0102
BN96-10940A
ASSY BLU P;UE40B8000VWXXC,MB-M0809-BLUE,
1
S.A
BN96-10737C
ASSY BOARD P-RF MODULE ASSY;RF MODULE AS
1
S.N.A
...3
....4
M2893
....4
BN39-01183A
LEAD CONNECTOR;UN40B7000WF,UL1571#30,6 T
1
S.A
BN96-10737A
ASSY BOARD P-RF MODULE;RF Module,DS-ST10
1
S.N.A
...3
T0852
BN96-11069B
ASSY COVER P-MIDDLE;46 B8000,ABS,HB,BLK
1
S.N.A
....4
T0069
AA60-00091E
SPACER-FELT;-,FELT,100X10,-,-,BLK,T0.5,-
1
S.N.A
....4
BN61-03261A
BOSS-TAPE;Tulip,ACRYL,T1.1,W12mm,GRAY,TA
3.3
S.N.A
....4
BN61-04692A
BOSS-PRIMER;#94,clear,35cps
1.3
S.N.A
....4
BN63-05652B
COVER-FRONT MIDDLE;B8000 46,ABS,HB,BLK
1
S.N.A
...3
T0382
BP61-00495C
HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm
0.16
S.N.A
0.1
M0002
BN90-02137G
ASSY COVER REAR;46 B8000
1
S.N.A
..2
T0081
6001-000799
SCREW-MACHINE;BH,+,M3,L5,ZPC(BLK),SWRCH1
3
S.N.A
..2
T0081
6001-000799
SCREW-MACHINE;BH,+,M3,L5,ZPC(BLK),SWRCH1
1
S.N.A
..2
C/REAR+PAN
6003-000133
SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW
2
S.N.A
..2
H/CORD+PAN
6003-000337
SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR
1
S.N.A
..2
C/REAR+C/F
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
12
S.N.A
..2
C/REAR+PAN
..2
..2
M0013
...3
6011-001815
BOLT-ETC;M8,L12,ZPC(Black),SWRCH18A,WSP,
4
S.A
BN61-04922A
HOLDER-CORD;LB7000 46,ABS,V0,BLK
1
S.N.A
BN96-11072H
ASSY COVER P-REAR;46 B8000,PCM T0.5,BKN-
1
S.N.A
AA60-00091A
SPACER;-,FELT,150X10,-,-,BLK,T0.35,-,-
1
S.N.A
...3
T0069
AA60-00091H
SPACER-FELT;-,FELT,150X10,-,-,BLK,T1.0,-
2
S.N.A
...3
M0279
BN63-00870A
FELT;AS17UO,FELT,0.3,10,287
1
S.N.A
...3
M0006
...3
BN63-05588B
COVER-REAR;LB8000 46,PCM,T0.5
1
S.A
BN96-10996C
ASSY MISC P-INSULATOR;LEDTV,55 8000
1
S.N.A
....4
T0278
BN60-00122B
SPACER-SPONGE;UB7000,CR,L140,T2.0,W10
3
S.N.A
0.1
M0216
BN90-02246A
ASSY STAND;46 B8000
1
S.N.A
..2
M0027
BN96-11089A
ASSY STAND P-BASE;46 B8000,SUS304 T0.6,P
1
S.A
Remark
5-5
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
...3
G/STAND+C/
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
4
S.N.A
...3
B/S/BOT+G/
6003-001374
SCREW-TAPTYPE;FH,+,B,M4,L12,NI PLT,SWRCH
6
S.N.A
...3
BN61-04248C
BOSS-TAPE;#4920,acryl,0.45mm,12mm,3M,whi
1.6
S.N.A
...3
BN61-04692A
BOSS-PRIMER;#94,clear,35cps
3.5
S.N.A
BN61-04731B
BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE
1
S.N.A
BN61-04927A
GUIDE-STAND;LB700 46,PC,G/F20%
1
S.N.A
...3
BN61-05382A
BRACKET-STAND BOTTOM;UB8000 46inch,HGI,T
1
S.N.A
...3
BN61-05383A
BRACKET-SWIVEL BOTTOM;UB8000 46inch,HGI,
1
S.N.A
...3
...3
T0920
SA/SNA
...3
BN61-05384A
GUIDE-STAND NECK;UB8000,PC insert,Clear
1
S.N.A
....4
BN61-05565A
HOLDER-INSERT;UB8000 46inch,PC, Extrusio
1
S.N.A
...3
BN61-05460A
HOLDER-SWIVEL RING BOTTOM;UB8000 46inch,
1
S.N.A
...3
BN61-05461A
HOLDER-SWIVEL RING TOP;UB8000 46inch,Ace
1
S.N.A
...3
CCM1
BN63-04755A
COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6
0.6
S.N.A
...3
M0111
BN63-05593A
COVER-STAND;UB8000 46inch,SUS,T0.6
1
S.A
BN63-05673A
COVER-STAND GLASS;UB8000 46inch,Glass,27
1
S.A
...3
...3
M0126
BN73-00203A
RUBBER-FOOT;LB7000 46inch,CR RUBBER,T7.0
4
S.N.A
...3
M0126
BN73-00204A
RUBBER-FOOT;42LB650,RUBBER,16*33,60,2.0
4
S.N.A
BN91-04038B
ASSY LCD-AMLCD;BN07-00699A,SPVA 82%
1
S.N.A
BN07-00699A
LCD-PANEL;LTF460HG02
1
S.A
BN81-02361A
A/S-T CON LTF460HG02;LTF460HG02
1
S.N.A
0.1
..2
M0215
...3
0.1
BN91-04263A
ASSY SHIELD-SQE;UA46B8000XFXXY
1
S.N.A
..2
T0081
6001-002283
SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1
7
S.A
..2
T0081
6001-002283
SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1
5
S.A
..2
T0081
6001-002289
SCREW-MACHINE;BH,+,WT,M4,L6,ZPC(WHT),SWR
1
S.A
..2
B/LINK+PAN
6003-000133
SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW
4
S.N.A
..2
PANEL+C/FR
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
4
S.N.A
6003-001748
SCREW-TAPTYPE;BH,+,WP,S,M4,L10,ZPC(BLK),
8
S.A
..2
M2893
BN39-01099L
LEAD CONNECTOR;UN40B7000WF,UL1007#26,30
1
S.A
..2
M2893
S.A
..2
..2
BN39-01184B
LEAD CONNECTOR;UN40B7000WF,UL20276#30,51
1
BN44-00270A
SMPS-PD;PSLF251B01A,PD4612F2,AC/DC,211W,
1
S.A
..2
T0069
BN60-00130A
SPACER-FELT;46UB7000,L1000mm,BLK,T0.30mm
1
S.N.A
..2
CCMM1
BN73-00210A
SILICON/RUBBER;UE40B7000WWXXC,SILICON+PO
2
S.N.A
BN73-00211A
SILICON/RUBBER-GAPPAD;UE40B7000WWXXC,SIL
2
S.N.A
..2
..2
BN73-00212A
RUBBER-SPACER;UB7000 46inch,CR Rubber,25
6
S.N.A
..2
T0175
BN96-09468B
ASSY SPEAKER P;8ohm,4pin,Diameter: 120mm
1
S.N.A
..2
T0066
BN96-10604A
ASSY POWER CORD;250/10A,LP-23A,GFC-3R,PK
1
S.N.A
..2
T0444
BN96-11322B
ASSY BRACKET P-STAND LINK;UB7000 46,HGI,
1
S.N.A
...3
M0115
BN61-05536A
BRACKET-STAND LINK;UB7000 46inch,HGI,T3.
1
S.N.A
...3
M0131
BN63-02722A
GASKET;LS40BHT,Conductive Fabric,2 mm,8
1
S.N.A
0.1
M0017
BN91-04265A
ASSY CHASSIS;UA46B8000XFX*
1
S.N.A
..2
M0014
BN94-03008A
ASSY PCB MAIN-SQE;UA46B8000XFX*
1
S.N.A
...3
T0245
0202-001521
SOLDER-WIRE FLUX;ECO SOLDER RMA98 SUP,D1
0.25
S.N.A
...3
CN3011
3701-001571
CONNECTOR-DSUB;15P,3ROW,FEMALE,ANGLE,TIN
1
S.A
...3
CN906
3707-001090
CONNECTOR-OPTICAL;angle(ULTRA SLIM),SPDI
1
S.A
...3
CN330
3711-003847
HEADER-BOARD TO CABLE;BOX,12P,1R,2mm,ANG
1
S.A
...3
CN1001
3711-005884
HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG
1
S.A
...3
CN330
3711-006715
HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN
1
S.N.A
...3
CN330
3711-006715
HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN
1
S.N.A
5-6
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
...3
CN7002_USB
3722-001051
JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE
1
S.A
...3
CN7006
3722-001051
JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE
1
S.A
...3
JA330
3722-002844
JACK-PHONE;1/7P,NI,LAUREL-GREEN,ANGLE
1
S.A
...3
JA330
3722-002845
JACK-PHONE;1/7P,NI,YELLOW,ANGLE
1
S.A
...3
JA330
3722-002846
JACK-PHONE;1/6,NI,BLACK,ANGLE
1
S.A
...3
JA330
3722-002846
JACK-PHONE;1/6,NI,BLACK,ANGLE
1
S.A
...3
CN9001_LAN
3722-002849
JACK-MODULAR;8P/8C(ULTRA SLIM),YES,ANGLE
1
S.A
...3
T0562
6046-001015
STAND OFF;#4-40,L5,Ni PLT,C3601,M3
2
S.N.A
...3
CIS3
BN40-00145B
TUNER;TDHG6-K13A,TDHG6-K13A,DVB TC,164CH
1
S.A
...3
SUB09
BN61-04924B
BRACKET-AV;UB7000/8000,PCM,T0.5,BKN-P824
1
S.N.A
...3
T0066
BN62-00042A
HEAT SINK-ES;30*30*5,Ceramic,T1.5,TAPE
1
S.A
...3
T0066
BN62-00043A
HEAT SINK-ES;40*40*5,Ceramic,T1.5,TAPE
1
S.A
...3
T0174
BN97-03573A
ASSY SMD;UA46B8000XFX*,BN94-03008A
1
S.N.A
....4
SUB05
0202-001477
SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A
0.384
S.N.A
....4
D2001
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4003
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4004
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4100
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4101
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4102
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4228
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4229
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D3001
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3002
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3051
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3054
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3061
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3062
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3063
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3076
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3077
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3079
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3080
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D4008
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D4010
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9001_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9002_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9003_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9004_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D5001
0401-001099
DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3
1
S.N.A
....4
D4001
0403-000002
DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD
1
S.A
....4
D5011
0403-000002
DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD
1
S.A
....4
D3003
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3004
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3005
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3006
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3007
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3008
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3009
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3011
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3015
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
Remark
5-7
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
D3016
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3018
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3019
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3020
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3021
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3023
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3024
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3028
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3029
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3039
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3045
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3056
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3057
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3058
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3060
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3065
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3066
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3067
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3068
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3069
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3073
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3074
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3075
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3776
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3779
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D7001_USB
0406-001200
DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70
1
S.A
....4
D7002
0406-001200
DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70
1
S.A
....4
D3901
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3902
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3903
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3904
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3905
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3906
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3907
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3908
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D7999
0407-000123
DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
1
S.N.A
....4
Q4003
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q4005
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q4020
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q1002_LCD
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q3007
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q3008
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4004
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4009
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4011
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q9001_LAN
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q7601_LCD
0501-002080
TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59
1
S.A
5-8
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
Q7602_LCD
0501-002080
TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59
1
S.A
....4
Q409
0505-000110
FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0.
1
S.A
....4
Q409
0505-001916
FET-SILICON;Si4800BDY,N,30V,9A,0.03ohm,2
1
S.A
....4
IC104
0801-002095
IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP
1
S.A
....4
IC104
0801-002172
IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI
1
S.A
....4
IC104
0801-002172
IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI
1
S.A
....4
IC104
0801-002630
IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT
1
S.A
....4
IC104
0801-002780
IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER
1
S.N.A
....4
IC7008
1001-000164
IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16
1
S.A
....4
IC9003_LAN
1001-001109
IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C
1
S.A
....4
IC106
1001-001177
IC-VIDEO SWITCH;TEA6425D,VIDEO SWITCH,SO
1
S.A
....4
IC106
1001-001573
IC-VIDEO SWITCH;SiI9287ACNUTR,QFN,72P,10
1
S.A
....4
IC107
1002-001482
IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI
1
S.A
....4
IC3001
1006-001266
IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P,
1
S.A
....4
IC112
1103-000129
IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm
1
S.A
....4
IC112
1103-000129
IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm
1
S.A
....4
IC112
1103-001385
IC-EEPROM;AT24C256,256Kbit,32Kx8,SOP,8P,
1
S.A
....4
IC112
1103-001415
IC-EEPROM;AT93C46D,1Kbit,128x8/64x16,SOP
1
S.N.A
....4
IC7003
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7004
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7005
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7006
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7999
1107-001740
IC-NAND FLASH;KFH8GH6U4M-DIB6,8Gbit,512M
1
S.A
....4
T0124
1201-002796
IC-POWER AMP;STA339BWS,PSSO,36P,10.3x7.5
1
S.A
....4
T0124
1201-002796
IC-POWER AMP;STA339BWS,PSSO,36P,10.3x7.5
1
S.A
....4
T0087
1203-001816
IC-POSI.FIXED REG.;78M08,TO-252,3P,-,PLA
1
S.A
....4
T0087
1203-002519
IC-POSI.FIXED REG.;KIA7809AF,DPAK,3P,240
1
S.A
....4
T0087
1203-002842
IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P
1
S.A
....4
T0087
1203-002842
IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P
1
S.A
....4
T0087
1203-002898
IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6.
1
S.A
....4
IC012
1203-002995
IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P,
1
S.A
....4
IC012
1203-002995
IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P,
1
S.A
....4
IC4005
1203-004363
IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P,
1
S.A
....4
IC4004
1203-004364
IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P,
1
S.A
....4
IC1007
1203-004879
IC-DC/DC CONVERTER;MP8668DL,QFN,14P,3x4m
1
S.A
....4
T0087
1203-005134
IC-POSI.FIXED REG.;RT9167A-33PB,SOT-23-5
1
S.A
....4
IC1006
1203-005538
IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4.
1
S.A
....4
IC5006
1203-005559
IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2
1
S.A
....4
T0087
1203-005713
IC-POSI.FIXED REG.;S-1172B33-E6T1G,HSOP,
1
S.A
....4
T0087
1203-005713
IC-POSI.FIXED REG.;S-1172B33-E6T1G,HSOP,
1
S.A
....4
IC118
1204-003010
IC-VIDEO PROCESS;SDP84,PBGA,324P,23x23mm
1
S.A
....4
IC7001
1204-003011
IC-DECODER;SDP83,PBGA,729P,34x34mm,PLAST
1
S.A
....4
IC9002_LAN
1205-002941
IC-ETHERNET CONTROLLER;RTL8100CSL-LF,LQF
1
S.N.A
....4
IC3011
1205-003201
IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm
1
S.A
....4
IC2001
1205-003352
IC-CODEC;WM8593SEFT/V,TQFP,64P,10x10mm,P
1
S.A
....4
IC8006
1205-003479
IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6
1
S.A
....4
IC7007
1205-003733
IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9
1
S.A
....4
IC7010_USB
1205-003735
IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm,
1
S.A
....4
IC5010
1209-001830
IC-PLL;IDT6V10012PGG,TSSOP,20P,6.5x4.4mm
1
S.A
....4
D4110
1405-001185
VARISTOR;24Vdc,1.6x0.8x0.36mm,TP
1
S.A
....4
D3010
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
Remark
5-9
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
D3012
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3013
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3014
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3017
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3025
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3026
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3027
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3041
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3059
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3064
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3070
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3071
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3072
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3078
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3081
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4011
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4012
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4014
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4016
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4017
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4018
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D7003_USB
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D7004
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D9005_LAN
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D9006_LAN
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
R7120
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7121
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7122
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7123
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7152
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7153
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7154
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7155
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7162
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7163
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7164
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7165
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7169
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7170
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7171
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7172
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5034
2007-000060
R-CHIP;100Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R5038
2007-000060
R-CHIP;100Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R1801
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5101
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2058
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2059
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2060
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2061
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2086_WF
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2087_WF
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
5-10
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R5112
....4
R2085_WF
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
1
S.A
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
1
S.A
....4
....4
R7050
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
R7053
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7056
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7058
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7062
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7066
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7069
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7070
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2001
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2002
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2025
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2026
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3007
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3034
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3036
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3046_AU
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3062
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3068
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3070
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3120
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3205
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3206
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3207
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3243
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4042
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4049
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4050
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4079
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4080
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4087
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4097
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4155
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7114
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7605_LCD
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8311
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1031_LCD
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1072
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1172
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3010
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3021
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3022
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3035
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3037
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3069
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3071
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3227
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3228
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4081
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6028
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-11
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R6064
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6065
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6066
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7045
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7072
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7195
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7196
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7602_LCD
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7999
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9007_LAN
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2054
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2081_WF
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4019
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4085
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5030
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1030_LCD
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1060
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1070
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1170
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2062
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2063
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3159
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3272
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3273
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3274
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4016
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4018
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4020
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4057
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4059
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4066
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4074
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4077
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4500_AU
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4501_AU
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4771
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4772
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4773
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4774
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5017
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6015
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6021
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6023
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6038
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6039
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6040
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6048
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6053
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6100
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6101
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6102
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
5-12
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7010
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7011
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7012
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7013
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7017
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7033
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7034
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7036
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7037
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7060
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7063
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7064
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7065
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7067
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7068
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7131
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7136
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7137
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7148_USB
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7149_USB
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7156
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7174
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7239
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7240
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7400
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7401
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7800
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3044
2007-000146
R-CHIP;6.8Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1013
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1015
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2027
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3168
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3252
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3253
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3310
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3311
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4017
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4027
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4078
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4150
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5111
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6847
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7103
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7351
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7411_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7600_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7601_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7603_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7604_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-13
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R8012
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8014
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8015
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8020
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8022
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9028_LAN
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4021
2007-000155
R-CHIP;27Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4061
2007-000155
R-CHIP;27Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1011
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2007
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2008
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2009
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2010
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2019
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2020
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2021
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2022
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3003
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3040
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3041_AU
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3042
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3043_AU
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3053
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3055
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3182
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3201
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3204
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3275
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3276
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3820
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4151
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9029_LAN
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2046
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2082_WF
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3103
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3125
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3160
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3161
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3162
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3163
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3164
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3165
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3166
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3167
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3169
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3170
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3199
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3200
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3202
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3203
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
5-14
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3220
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3250
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3251
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3258
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3259
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3284
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3285
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3289
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3290
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3400
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3500
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3860
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4041
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4200
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4250
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5006
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5007
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5011
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5033
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5035
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6013
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6061
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6068
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6084
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6848
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7002
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7003
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7004
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7007
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7014
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7015
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7018
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7035
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7038
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7047
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7048
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7073
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7074
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7075
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7076
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7077
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7078
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7079
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7080
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7081
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7082
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7083
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7084
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7089
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7090
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7091
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-15
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7092
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7093
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7094
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7095
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7096
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7097
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7098
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7099
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7101
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7102
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7104
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7118
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7119
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7128
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7129
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7130
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7132
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7133
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7134
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7141
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7143
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7144
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7150_USB
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7151_USB
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7161
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7167
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7168
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7177
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7201
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7202
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7204_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7230_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7234
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7236
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7237
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7238
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7244_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7245_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7246_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7284_LCD
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7294_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7295_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7997
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7998
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8016
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9020_LAN
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9021_LAN
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3288
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3300
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3301
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3302
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
5-16
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3303
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4038
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5042
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5043
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2048
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2049
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2050
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2051
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2077_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2078_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2079_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2080_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3240
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3244
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4036
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5008
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5009
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5010
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6031
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6042
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6043
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6069
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6070
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6075
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6076
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6184
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7115
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7124
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7126
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7127
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7159
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7175
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7200
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7650
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7651
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7652
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7653
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7654
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7655
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8021
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3008
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3256
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3257
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4039
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4040
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7217
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1018
2007-000239
R-CHIP;1.5Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R6089
2007-000259
R-CHIP;1.6Kohm,5%,1/10W,TP,1608
1
S.A
....4
R3254
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R3255
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R5022
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
Remark
5-17
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7105
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R7147
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R2064
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2065
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2066
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2067
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2068
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2069
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2070
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2071
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2088_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2089_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2090_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2091_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R5001
2007-000402
R-CHIP;150ohm,5%,1/10W,TP,1608
1
S.A
....4
R5031
2007-000563
R-CHIP;220Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5026
2007-000591
R-CHIP;22ohm,1%,1/10W,TP,1608
1
S.A
....4
R1800
2007-000608
R-CHIP;240ohm,5%,1/10W,TP,1608
1
S.A
....4
R5045
2007-000669
R-CHIP;2Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R7160
2007-000729
R-CHIP;300ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R7176
2007-000729
R-CHIP;300ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5044
2007-000755
R-CHIP;330Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5039
2007-000758
R-CHIP;330Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5037
2007-000763
R-CHIP;330ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R1021
2007-000779
R-CHIP;33ohm,1%,1/10W,TP,1608
1
S.A
....4
R1012
2007-000803
R-CHIP;36Kohm,1%,1/10W,TP,1608
1
S.A
....4
R2072
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2073
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4015
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6067
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9031_LAN
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9032_LAN
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9018_LAN
2007-000982
R-CHIP;5.6Kohm,5%,1/16W,TP,1005
1
S.A
....4
R9030_LAN
2007-000982
R-CHIP;5.6Kohm,5%,1/16W,TP,1005
1
S.A
....4
R5048
2007-001038
R-CHIP;56Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5041
2007-001044
R-CHIP;56ohm,5%,1/10W,TP,1608
1
S.A
....4
R1014
2007-001179
R-CHIP;8.2Kohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2047
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2052
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2053
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2074_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2075_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2076_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3246
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5046
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5047
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8028
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9022_LAN
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3245
2007-001305
R-CHIP;120ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3247
2007-001305
R-CHIP;120ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7194
2007-001308
R-CHIP;200ohm,5%,1/16W,TP,1005
1
S.N.A
5-18
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3111
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3112
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3113
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3114
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4152
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7410_LCD
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1004
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1007
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1008
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1009
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5056
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5102
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R9001_LAN
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1017
2007-002900
R-CHIP;11Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5070
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5210
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5211
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5213
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5214
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5215
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6846
2007-007095
R-CHIP;390ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1010
2007-007107
R-CHIP;100Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9008_LAN
2007-007132
R-CHIP;15Kohm,1%,1/16W,TP,1005
1
S.A
....4
R2057
2007-007136
R-CHIP;4.7Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R8013
2007-007136
R-CHIP;4.7Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R1019
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R1023_LCD
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4028
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4030
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4052
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4053
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4089
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4156
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4775_ZIG
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R2055
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2056
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2083_WF
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2084_WF
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7193
2007-007222
R-CHIP;6.04Kohm,1%,1/10W,TP,1608
1
S.A
....4
R1016
2007-007312
R-CHIP;20Kohm,1%,1/16W,TP,1005
1
S.A
....4
R1022
2007-007312
R-CHIP;20Kohm,1%,1/16W,TP,1005
1
S.A
....4
R5036
2007-007469
R-CHIP;110ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7190
2007-007698
R-CHIP;5.1Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7191
2007-007698
R-CHIP;5.1Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7116
2007-007797
R-CHIP;44.2ohm,1%,1/10W,TP,1608
1
S.A
....4
R7117
2007-007797
R-CHIP;44.2ohm,1%,1/10W,TP,1608
1
S.A
....4
R3009
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3011
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3012
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3029
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3030
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
Remark
5-19
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3031
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3045
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3047
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3050
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3051
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3052
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3054
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3064
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3065
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3066
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3208
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3209
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3210
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3241
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3242
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R5032
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9100_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9101_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9102_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9103_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9014_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9015_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9016_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9017_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R1020
2007-008593
R-CHIP;750ohm,1%,1/16W,TP,1005
1
S.A
....4
RA7061
2011-001001
R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2
1
S.A
....4
RA5003
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA7056
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA7057
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA5005
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA5006
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8006
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8007
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8008
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4044
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4045
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4046
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4047
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4048
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4051
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6004
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6005
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6006
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6007
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
5-20
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
RA6008
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6009
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6010
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6011
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6012
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6013
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6015
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7004
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7005
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7006
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7007
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7008
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7009
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7010
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7011
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7012
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7041
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7042
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7043
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7044
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7045
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7046
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7047
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7048
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7049
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7050
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7051
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7052
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7500
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7501
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8017
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8018
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8019
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA9001_LAN
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2005
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA2006
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA6019
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA8010
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA6018
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7013
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7014
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7015
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7020
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7053
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7054
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7502
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7503
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7600
2011-001427
R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,2.0
1
S.N.A
....4
RA3006
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
Remark
5-21
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
RA3007
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA3008
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA3009
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA4010
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA4075
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA7060
2011-001589
R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1
1
S.A
....4
C6856
2203-000041
C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608
1
S.N.A
....4
C2080
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2081
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2082
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2083
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2114_WF
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2115_WF
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2040
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C2091_WF
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3002
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3013
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3015
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3021
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3023
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3066
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3250
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3251
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C2036
2203-000280
C-CER,CHIP;0.01nF,0.5pF,50V,C0G,1608
1
S.A
....4
C2089_WF
2203-000330
C-CER,CHIP;0.012nF,5%,50V,C0G,1005
1
S.A
....4
C6857
2203-000357
C-CER,CHIP;0.15nF,5%,50V,C0G,1608
1
S.N.A
....4
C7137
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C9017_LAN
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C9019_LAN
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C1001
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1029
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1041_LCD
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1768
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4003
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4012
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4025
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4035
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C6090
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1027
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C3014
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C3016
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C5001
2203-000550
C-CER,CHIP;0.02nF,5%,50V,C0G,1005
1
S.N.A
....4
C5002
2203-000550
C-CER,CHIP;0.02nF,5%,50V,C0G,1005
1
S.N.A
....4
C2070
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2071
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2072
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2073
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2074
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2075
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C5037
2203-000595
C-CER,CHIP;0.22nF,5%,50V,C0G,2012
1
S.N.A
....4
C4009
2203-000679
C-CER,CHIP;0.027nF,5%,50V,C0G,1005
1
S.A
5-22
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C4010
....4
C5003
2203-000679
C-CER,CHIP;0.027nF,5%,50V,C0G,1005
1
S.A
2203-000697
C-CER,CHIP;0.002NF,0.25PF,50V,C0G,TP,160
1
S.A
....4
....4
C5004
2203-000697
C-CER,CHIP;0.002NF,0.25PF,50V,C0G,TP,160
1
S.A
C7048
2203-000761
C-CER,CHIP;330nF,10%,16V,X7R,TP,2012,-
1
S.N.A
....4
C2107_WF
2203-000783
C-CER,CHIP;0.33nF,5%,50V,C0G,1608
1
S.A
....4
C3006
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3007
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3008
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3018
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3019
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3020
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3022
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C2111_WF
2203-000925
C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1120
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C3017
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C4018
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C4020
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C2038
2203-001126
C-CER,CHIP;0.68nF,10%,50V,X7R,1608
1
S.N.A
....4
C2090_WF
2203-001126
C-CER,CHIP;0.68nF,10%,50V,X7R,1608
1
S.N.A
....4
C5031
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5135
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5136
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5137
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C1013
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1016
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1113
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1116
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1005
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C1007
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C1008
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C2006
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C2007
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4008
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4011
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4019
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4021
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4022
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4024
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4100
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4902_ZIG
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C5023
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6061
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6077
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6099
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7018
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7136
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7139_LCD
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C5010
2203-002494
C-CER,CHIP;470nF,10%,16V,X7R,2012
1
S.N.A
....4
C7050
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
....4
C7051
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
....4
C7052
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
Remark
5-23
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C1004
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1022
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1024
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1048_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1148_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1149_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1150_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2047
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2048
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2049
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2050
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2051
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2052
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2060
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2061
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2062
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2063
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2066
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2067
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2068
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2069
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2076
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2077
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2078
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2079
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2101_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2102_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2103_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2105_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2106_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2108_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2109_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2110_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2112_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2113_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2116_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2147_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C5021
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C5121
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6056
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6057
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6058
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6059
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6062
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6063
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6073
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6074
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6075
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6078
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6094
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6095
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
5-24
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C6096
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6100
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7011
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7017
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7049
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7109_USB
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7114
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7115
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7121
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7122
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7997
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7998
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7009
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7016
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7025
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7029
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7059
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7063
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7065
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7073
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7088
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7105
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7106
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7148
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7157
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7173
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7205
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7210
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7770
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C3063
2203-005393
C-CER,CHIP;0.005nF,0.1pF,50V,NP0,TP,1005
1
S.N.A
....4
C2093_WF
2203-005437
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
1
S.N.A
....4
C2099_WF
2203-005437
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
1
S.N.A
....4
C6044
2203-005493
C-CER,CHIP;220nF,+80-20%,16V,Y5V,1005
1
S.A
....4
C6045
2203-005493
C-CER,CHIP;220nF,+80-20%,16V,Y5V,1005
1
S.A
....4
C7053
2203-005659
C-CER,CHIP;0.18nF,5%,50V,NP0,1005
1
S.N.A
....4
C1032
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C1035
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C1036
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C5025
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C2041
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C2092_WF
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C6091
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C9108_LAN
2203-006039
C-CER,CHIP;1nF,10%,2000V,X7R,3216
1
S.A
....4
C9109_LAN
2203-006039
C-CER,CHIP;1nF,10%,2000V,X7R,3216
1
S.A
....4
C5040
2203-006104
C-CER,CHIP;1000nF,10%,50V,X7R,3225
1
S.A
....4
C6098
2203-006126
C-CER,CHIP;47NF,10%,16V,X7R,TP,1005
1
S.N.A
....4
C1019
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1025
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1028
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1060
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C7084
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
Remark
5-25
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7178
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C7601_LCD
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1003
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1006
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1030
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1034
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1091
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1092
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1191
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1192
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1639
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1801
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2028
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2037
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2039
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2042
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2044
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2045
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2088_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2094_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2095_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2096_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2097_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2098_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3046
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3054
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3055
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3056
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3057
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3065
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3071
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3072
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3100
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3101
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3102
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4006
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4016
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4023
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4026
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4036
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4050
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
5-26
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C4103
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4901_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4903_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4904_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5011
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5024
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5071
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5072
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5073
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6021
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6028
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6033
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6042
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6048
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6052
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6053
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6064
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6065
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6066
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6067
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6068
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6069
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6079
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6081
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6082
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6083
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6084
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6085
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6086
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6087
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6088
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6089
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6101
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6102
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6103
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6104
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6105
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6106
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6107
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6109
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6110
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6111
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
Remark
5-27
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C6112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6113
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6114
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6115
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6116
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6150
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6151
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6152
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6153
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7019
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7034
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7038
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7054
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7055
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7056
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7062
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7064
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7068
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7069
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7074
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7075
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7076
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7077
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7078
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7081
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7082
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7083
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7086
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7087
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7094
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7095
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7096
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7098
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7099
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7100_USB
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7107
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7113
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7116
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7117
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7134
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7140
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7142
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7143
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7146
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7147
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
5-28
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7149
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7152
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7160
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7161
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7164
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7165
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7168
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7169
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7172
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7176
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7177
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7180
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7181
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7185
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7200
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7201
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7202
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7203
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7206
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7211
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7220
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7221
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7222
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7223
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7224
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7225
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7226
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7227
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7228
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7400
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7402
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7403
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7404
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7405
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7406
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7407
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7408
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7409
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7410
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7411
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7412
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7413
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7414
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7417
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7418
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7419
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7420
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7423
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7750
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7751
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7752
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
Remark
5-29
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7753
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7754
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7755
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7756
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7757
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7758
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7759
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7760
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7761
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7771
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7772
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7773
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8001
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8003
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8004
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8007
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8011
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8015
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8016
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8017
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8018
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8019
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9001_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9005_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9007_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9008_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9010_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9011_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9012_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9013_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9014_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9015_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9016_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9018_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9023_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9024_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9104_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9105_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9106_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9107_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2104_WF
2203-006336
C-CER,CHIP;10000nF,10%,25V,X5R,3216
1
S.A
....4
C5012
2203-006336
C-CER,CHIP;10000nF,10%,25V,X5R,3216
1
S.A
....4
C1017
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1020
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1021
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1023
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1031
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
5-30
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C1033
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1050
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2003
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2011
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2014
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2035
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2046
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2055
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2064
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2065
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3037
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3043
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3051
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3067
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3068
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3069
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3073
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3810
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C4001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C4015
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5018
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5028
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5032
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5034
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5035
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5036
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5111
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6011
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6022
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6029
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6030
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6031
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6032
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6046
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6049
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6050
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6054
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6055
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6071
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6072
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6092
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6093
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7004
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7006
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7007
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
Remark
5-31
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7008
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7021
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7085_USB
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7108
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7110
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7130
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7132
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7133
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7999
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C8010
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9002_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9022_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9100_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9101_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9102_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9103_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2084
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2085
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2086
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2087
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2185_WF
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2186_WF
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C1040_LCD
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C1042_LCD
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2023
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2024
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2025
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2026
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2029
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2030
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3901
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3902
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3903
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3904
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C4004
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6040
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6041
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6060
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6076
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6097
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6851
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6852
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6853
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7003
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7028
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7030
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7037
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7039
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7040
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7072
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7089
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
5-32
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7097
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7141
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7156
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7204
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7209
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2004
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2008
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2009
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2010
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2056
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2057
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2059
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C3077
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C4005
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C5016
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2053
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C2054
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C3058
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C3062
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C1015
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C1018
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C2002
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C2058
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C5022
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C6047
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C5019
2402-001210
C-POLYMER AL CHIP;100uF,20%,10V,WT,TP,7.
1
S.A
....4
C6005
2409-001118
C-POLYMER ,CHIP;47uF,-+20,10V,WT,REEL,3.
1
S.A
....4
C6014
2409-001118
C-POLYMER ,CHIP;47uF,-+20,10V,WT,REEL,3.
1
S.A
....4
CA2001
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA2002
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6003
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6004
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6005
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA7600
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA7601
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA9001_LAN
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
T9001_LAN
2601-001056
TRANS-SMD,PULSE;350UH,-,1:1,1:1,12.7X6.7
1
S.A
....4
T0052
2703-000380
INDUCTOR-SMD;18uH,5%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-003391
INDUCTOR-SMD;15uH,20%,8080
1
S.A
....4
T0052
2703-003391
INDUCTOR-SMD;15uH,20%,8080
1
S.A
....4
T0052
2703-003559
INDUCTOR-SMD;4.7uH,20%,8080
1
S.A
....4
T0052
2703-003628
INDUCTOR-SMD;1.5uH,20%,2020
1
S.A
....4
L2001
2704-000018
INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh
1
S.N.A
....4
L2002
2704-000018
INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh
1
S.N.A
....4
X202
2801-003326
CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH
1
S.A
....4
X202
2801-003773
CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh
1
S.A
Remark
5-33
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
X202
....4
X202
2801-004629
CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP
1
S.A
2801-004734
CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12
1
S.A
....4
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
T0568
3301-000314
BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,-
1
S.N.A
....4
T0568
3301-000314
BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,-
1
S.N.A
....4
T0568
3301-001145
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
5-34
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0313
3404-001207
SWITCH-TACT;12V,50mA,160gf,6.2X6.2,SPST
1
S.A
....4
CN3010
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3013
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3015
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3016
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3002
3710-002276
SOCKET-INTERFACE;24P,1R,0.5mm,SMD-A,AU,B
1
S.A
....4
CN330
3711-005292
HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,SMD-
1
S.N.A
....4
CN330
3711-005292
HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,SMD-
1
S.N.A
....4
CN330
3711-005477
HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,SMD-
1
S.A
....4
CN330
3711-005499
HEADER-BOARD TO CABLE;BOX,8P,1R,1.25mm,S
1
S.N.A
....4
CN330
3711-005543
HEADER-BOARD TO CABLE;BOX,6P,1R,1.25mm,S
1
S.N.A
....4
CN330
3711-005925
HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S
1
S.N.A
....4
T0077
BN41-01190A
PCB MAIN;ultra slim eu,FR-4,4,1.2T,200*2
1
S.N.A
....4
M0018
BN97-03532A
ASSY MICOM;SEC,N74A,2009-02-25,T-CHL7DAU
1
S.N.A
.....5
IC7002
1107-001740
IC-NAND FLASH;KFH8GH6U4M-DIB6,8Gbit,512M
1
S.A
....4
CCMM1
BN97-03541A
ASSY MICOM-SUB;N74A,2009-02-27,T-CHLDEUS
1
S.N.A
.....5
IC520
0903-001590
IC-MICROCONTROLLER;61P8E-RG480WT,LQFP,48
1
S.A
....4
T0010
BP27-00002A
COIL CHOKE;SLF6028T-220MR77,22uF,20%,,,,
1
S.A
0.1
M0045
BN92-04948G
ASSY ACCESSORY;UA46B8000XFXXY
1
S.N.A
..2
M0045
BN96-10939C
ASSY ACCESSORY-CABEL;UA46B8000XFXXY
1
S.A
...3
T0685
4301-000103
BATTERY-ALKALINE;1.5V,750mAH,AAA[ LR03],
2
S.N.A
Remark
5-35
5. Exploded View & Part List
Level
Location No.
...3
T0524
...3
T0074
Description & Specification
Q’ty
SA/SNA
6902-000009
BAG PE;HDPE,T0.03,W240,L400,TRP,8,2,-,5.
1
S.N.A
BN59-00858A
REMOCON;LED9000,8000,7000,TM990,EUROPE,5
1
S.A
...3
M9889
BN61-05596A
HOLDER-WIRE CABLE;LED TV,LDPE,T1.1,L150,
1
S.N.A
BN63-01798B
CLOTH-CLEAN;cloth,180,200,sea blue,ToC
1
S.N.A
...3
T0531
BN63-05654B
COVER-BOTTOM;LB7000 46,HIPS,HB
1
S.A
BN96-10276B
ASSY HOLDER P-RING;09 LEDTV ALL MODEL,AB
1
S.N.A
....4
6902-000683
BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M
1
S.N.A
....4
BN61-05280A
HOLDER-RING;LB7000 46inch,ABS, HB,gray
4
S.N.A
...3
...3
Code No.
...3
M0045
BN96-10579A
ASSY ACCESSORY;09 LEDTV,ALL
1
S.A
....4
STAND+SET
6003-000337
SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR
5
S.N.A
6902-000683
BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M
1
S.N.A
BN96-10810A
ASSY HOLDER P;09 LEDTV MODEL,NYRON
1
S.N.A
6902-000031
BAG ZIPPER;LDPE,T0.05,W80,L160,TRP,0,0,4
1
S.N.A
BN61-05373A
HOLDER-WIRE;LB7000 46,NYRON
3
S.N.A
BN61-05491A
HOLDER-WIRE STAND;UB7000 46inch,NYRON
1
S.N.A
....4
...3
T0010
....4
....4
M0114
....4
..2
M0045
BN96-10939G
ASSY ACCESSORY-MANUAL;UA46B8000XFXXY, 55
1
S.A
...3
T0524
6902-000009
BAG PE;HDPE,T0.03,W240,L400,TRP,8,2,-,5.
1
S.N.A
...3
AA68-03242M
MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun
1
S.N.A
...3
BN59-00726D
S/W DRIVER-CD;LN40B650T1F,DLNA,WorldWide
1
S.N.A
...3
T0511
BN68-02227A
MANUAL USERS;B8000,SAMSUNG,ENG,AUSTRALIA
1
S.N.A
...3
T0238
BP68-00274D
MANUAL FLYER-WARRANTY CARD;comm,Samsung,
1
S.N.A
0.1
M0003
BN92-05058C
ASSY BOX;46 B8000
1
S.N.A
..2
M0521
BN69-03515A
BOX-SET,IN;46UB7000,CB,C-01,DW1,ECT50,YE
1
S.N.A
BN69-03719C
BOX-SET,OUT;46UB8000-S,CB,C-03,DW3,YEL,W
1
S.N.A
..2
0.1
M0113
BN92-05061A
ASSY P/MATERIAL;46 B8000
1
S.N.A
..2
T0376
6902-000061
BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000
0.058
S.N.A
..2
T0376
6902-000379
BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0
0.015
S.N.A
..2
T0524
6902-000958
BAG PE;NITRON,T0.015/T0.5,W1300,L800,TRP
1
S.N.A
..2
T0214
AA61-20285C
HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g
4
S.N.A
..2
T0214
BN74-00008A
TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M,
1.56
S.N.A
0.1
M0019
BN92-05153A
ASSY LABEL;UA46B8000XFX*,46
1
S.N.A
5-36
Remark
5. Exploded View & Part List
5-4. UA55B8000XF Parts List
Level
Location No.
Code No.
Description & Specification
UA55B8000XFXXY
UA55B8000XF,N74A/55BX1-G8X,55,LCD-TV,AUS
Q’ty
SA/SNA
0.1
M0001
BN90-02071G
ASSY COVER FRONT;55 B8000
1
S.N.A
..2
T0003
BN96-11068F
ASSY COVER P-FRONT;55 B8000,PC(CLR)+PC(D
1
S.A
...3
ZIGBEE+H/B
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
1
S.N.A
...3
T0069
AA60-00091T
SPACER-FELT;W7,L635,BLK,T0.35,W10
2
S.N.A
...3
T0069
AA60-00172J
SPACER-FELT;42C7,FELT,544,BLK,0.35,10
4
S.N.A
...3
T0069
BN60-00120A
SPACER-FELT;UB7000 46inch,FELT,L16,T0.5,
4
S.N.A
BN61-04661A
BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H
4
S.N.A
...3
CCM1
BN63-02183H
COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2
1.5
S.N.A
...3
CCM1
BN63-05199B
COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL
3.5
S.N.A
...3
...3
CCM1
BN63-05199F
COVER-SHEET;AMBER,PE,T0.08,W95mm,200M,CL
1.5
S.N.A
...3
M0112
BN63-05589E
COVER-FRONT;LB8000 55,PC+PC,V0
1
S.A
BN64-01042A
DECORATION-BOTTOM;UB8000,PC,clear
1
S.N.A
T0175
BN96-09470C
ASSY SPEAKER P;8ohm,4pin,15W,R:950 / L:6
1
S.N.A
BN96-10736K
ASSY BOARD P-TOUCH FUNCTION&PO;UN55B8000
1
S.N.A
BN39-01179A
LEAD CONNECTOR;UE40B7000WWXXC,UL1061#28,
1
S.A
...3
...3
...3
....4
M2893
....4
M2893
....4
BN39-01180A
LEAD CONNECTOR;UE40B7000WWXXC,UL2835#30,
1
S.A
BN96-10735A
ASSY BOARD P-TOUCH POWER&IR;LN46B7000WFX
1
S.N.A
S.N.A
....4
M0175
BN96-10736A
ASSY BOARD P-TOUCH FUNCTION;LN46B7000WFX
1
....4
M0102
BN96-10940A
ASSY BLU P;UE40B8000VWXXC,MB-M0809-BLUE,
1
S.A
BN96-10737D
ASSY BOARD P-RF MODULE;RF MODULE ASSY,SW
1
S.N.A
...3
....4
M2893
....4
BN39-01183B
LEAD CONNECTOR;UN55B7000WF,UL1571#30,6 T
1
S.A
BN96-10737A
ASSY BOARD P-RF MODULE;RF Module,DS-ST10
1
S.N.A
...3
T0852
BN96-11070B
ASSY COVER P-MIDDLE;55 B8000,ABS,HB,BLK
1
S.N.A
....4
T0069
AA60-00091E
SPACER-FELT;-,FELT,100X10,-,-,BLK,T0.5,-
1
S.N.A
....4
BN61-03261A
BOSS-TAPE;Tulip,ACRYL,T1.1,W12mm,GRAY,TA
3.3
S.N.A
....4
BN61-04692A
BOSS-PRIMER;#94,clear,35cps
1.3
S.N.A
....4
BN63-05653B
COVER-FRONT MIDDLE;LB8000 55,ABS,HB,BLK
1
S.A
...3
T0382
BP61-00495C
HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm
0.16
S.N.A
0.1
M0002
BN90-02138G
ASSY COVER REAR;55 B8000
1
S.N.A
..2
T0081
6001-000799
SCREW-MACHINE;BH,+,M3,L5,ZPC(BLK),SWRCH1
3
S.N.A
..2
T0081
6001-000799
SCREW-MACHINE;BH,+,M3,L5,ZPC(BLK),SWRCH1
1
S.N.A
..2
C/REAR+PAN
6003-000133
SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW
2
S.N.A
..2
H/CORD+PAN
6003-000337
SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR
1
S.N.A
..2
C/REAR+C/F
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
12
S.N.A
..2
C/REAR+PAN
..2
..2
M0013
...3
6011-001815
BOLT-ETC;M8,L12,ZPC(Black),SWRCH18A,WSP,
4
S.A
BN61-04922A
HOLDER-CORD;LB7000 46,ABS,V0,BLK
1
S.N.A
BN96-11073H
ASSY COVER P-REAR;55 B8000,PCM T0.5,BKN-
1
S.N.A
AA60-00091A
SPACER;-,FELT,150X10,-,-,BLK,T0.35,-,-
1
S.N.A
...3
T0069
AA60-00091H
SPACER-FELT;-,FELT,150X10,-,-,BLK,T1.0,-
2
S.N.A
...3
M0279
BN63-00870A
FELT;AS17UO,FELT,0.3,10,287
1
S.N.A
...3
M0006
...3
BN63-05591B
COVER-REAR;LB8000 55,PCM,T0.5
1
S.A
BN96-10996C
ASSY MISC P-INSULATOR;LEDTV,55 8000
1
S.N.A
....4
T0278
BN60-00122B
SPACER-SPONGE;UB7000,CR,L140,T2.0,W10
3
S.N.A
0.1
M0216
BN90-02247A
ASSY STAND;55 B8000
1
S.N.A
..2
STAND+SET
6003-000133
SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW
5
S.N.A
Remark
5-37
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
..2
M0027
BN96-11091A
ASSY STAND P-BASE;55 B8000,SUS304 T0.6,P
1
S.A
...3
G/STAND+G/
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
4
S.N.A
...3
B/S/BOT+G/
6003-001374
SCREW-TAPTYPE;FH,+,B,M4,L12,NI PLT,SWRCH
6
S.N.A
BN61-04248C
BOSS-TAPE;#4920,acryl,0.45mm,12mm,3M,whi
1.6
S.N.A
...3
...3
BN61-04692A
BOSS-PRIMER;#94,clear,35cps
0.004
S.N.A
...3
BN61-04731B
BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE
1
S.N.A
...3
BN61-04927A
GUIDE-STAND;LB700 46,PC,G/F20%
1
S.N.A
...3
T0920
BN61-05382A
BRACKET-STAND BOTTOM;UB8000 46inch,HGI,T
1
S.N.A
...3
BN61-05383A
BRACKET-SWIVEL BOTTOM;UB8000 46inch,HGI,
1
S.N.A
...3
BN61-05384A
GUIDE-STAND NECK;UB8000,PC insert,Clear
1
S.N.A
....4
BN61-05565A
HOLDER-INSERT;UB8000 46inch,PC, Extrusio
1
S.N.A
...3
BN61-05460A
HOLDER-SWIVEL RING BOTTOM;UB8000 46inch,
1
S.N.A
...3
BN61-05461A
HOLDER-SWIVEL RING TOP;UB8000 46inch,Ace
1
S.N.A
...3
CCM1
BN63-04755A
COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6
0.6
S.N.A
...3
M0111
BN63-05594A
COVER-STAND;UB8000 55inch,SUS,T0.6
1
S.A
...3
BN63-05674A
COVER-STAND GLASS;UB8000 55inch,Glass,30
1
S.A
...3
M0126
BN73-00203A
RUBBER-FOOT;LB7000 46inch,CR RUBBER,T7.0
4
S.N.A
...3
M0126
BN73-00204A
RUBBER-FOOT;42LB650,RUBBER,16*33,60,2.0
4
S.N.A
BN91-04038C
ASSY LCD-AMLCD;BN07-00717A,SPVA 72% ZBD
1
S.N.A
BN07-00717A
LCD-PANEL;LTF550HH01
1
S.A
...3
BN81-02444A
A/S-T CON LTF550HH01;LTF550HH01
1
S.N.A
0.1
BN91-04264A
ASSY SHIELD-SQE;UA55B8000XFXXY
1
S.N.A
0.1
..2
M0215
..2
T0081
6001-002283
SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1
7
S.A
..2
T0081
6001-002283
SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1
5
S.A
..2
T0081
6001-002289
SCREW-MACHINE;BH,+,WT,M4,L6,ZPC(WHT),SWR
1
S.A
..2
B/LINK+PAN
6003-000133
SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW
4
S.N.A
..2
PANEL+C/FR
6003-001003
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR
4
S.N.A
6003-001748
SCREW-TAPTYPE;BH,+,WP,S,M4,L10,ZPC(BLK),
8
S.A
..2
..2
M2893
BN39-01099L
LEAD CONNECTOR;UN40B7000WF,UL1007#26,30
1
S.A
..2
M2893
BN39-01184C
LEAD CONNECTOR;UN46B7000WF,UL20276#30,51
1
S.A
BN44-00272A
SMPS-PD;PSLF311B01A,PD5512F2,AC/DC,339W,
1
S.A
..2
..2
T0069
BN60-00131A
SPACER-FELT;55UB7000,L1200mm,BLK,T0.30mm
1
S.N.A
..2
CCMM1
BN73-00210A
SILICON/RUBBER;UE40B7000WWXXC,SILICON+PO
2
S.N.A
..2
BN73-00211A
SILICON/RUBBER-GAPPAD;UE40B7000WWXXC,SIL
2
S.N.A
..2
BN73-00212A
RUBBER-SPACER;UB7000 46inch,CR Rubber,25
6
S.N.A
..2
T0175
BN96-09468C
ASSY SPEAKER P;8ohm,4pin,Diameter: 120mm
1
S.N.A
..2
T0066
BN96-10604A
ASSY POWER CORD;250/10A,LP-23A,GFC-3R,PK
1
S.N.A
..2
T0444
BN96-11322B
ASSY BRACKET P-STAND LINK;UB7000 46,HGI,
1
S.N.A
...3
M0115
BN61-05536A
BRACKET-STAND LINK;UB7000 46inch,HGI,T3.
1
S.N.A
...3
M0131
BN63-02722A
GASKET;LS40BHT,Conductive Fabric,2 mm,8
1
S.N.A
0.1
M0017
BN91-04265B
ASSY CHASSIS;UA55B8000XFX*
1
S.N.A
..2
M0014
BN94-03008B
ASSY PCB MAIN-SQE;UA55B8000XFX*
1
S.N.A
...3
T0245
0202-001521
SOLDER-WIRE FLUX;ECO SOLDER RMA98 SUP,D1
0.25
S.N.A
...3
CN3011
3701-001571
CONNECTOR-DSUB;15P,3ROW,FEMALE,ANGLE,TIN
1
S.A
...3
CN906
3707-001090
CONNECTOR-OPTICAL;angle(ULTRA SLIM),SPDI
1
S.A
...3
CN330
3711-003847
HEADER-BOARD TO CABLE;BOX,12P,1R,2mm,ANG
1
S.A
...3
CN1001
3711-005884
HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG
1
S.A
...3
CN330
3711-006715
HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN
1
S.N.A
5-38
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
...3
CN330
3711-006715
HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN
1
S.N.A
...3
CN7002_USB
3722-001051
JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE
1
S.A
...3
CN7006
3722-001051
JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE
1
S.A
...3
JA330
3722-002844
JACK-PHONE;1/7P,NI,LAUREL-GREEN,ANGLE
1
S.A
...3
JA330
3722-002845
JACK-PHONE;1/7P,NI,YELLOW,ANGLE
1
S.A
...3
JA330
3722-002846
JACK-PHONE;1/6,NI,BLACK,ANGLE
1
S.A
...3
JA330
3722-002846
JACK-PHONE;1/6,NI,BLACK,ANGLE
1
S.A
...3
CN9001_LAN
3722-002849
JACK-MODULAR;8P/8C(ULTRA SLIM),YES,ANGLE
1
S.A
...3
T0562
6046-001015
STAND OFF;#4-40,L5,Ni PLT,C3601,M3
2
S.N.A
...3
CIS3
BN40-00145B
TUNER;TDHG6-K13A,TDHG6-K13A,DVB TC,164CH
1
S.A
...3
SUB09
BN61-04924B
BRACKET-AV;UB7000/8000,PCM,T0.5,BKN-P824
1
S.N.A
...3
T0066
BN62-00042A
HEAT SINK-ES;30*30*5,Ceramic,T1.5,TAPE
1
S.A
...3
T0066
BN62-00043A
HEAT SINK-ES;40*40*5,Ceramic,T1.5,TAPE
1
S.A
...3
T0174
BN97-03573B
ASSY SMD;UA55B8000XFX*,BN94-03008B
1
S.N.A
....4
SUB05
0202-001477
SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A
0.384
S.N.A
....4
D2001
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4003
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4004
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4100
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4101
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4102
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4228
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D4229
0401-001049
DIODE-SWITCHING;LS4148,75V,150mA,SOD-80,
1
S.A
....4
D3001
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3002
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3051
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3054
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3061
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3062
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3063
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3076
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3077
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3079
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D3080
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D4008
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D4010
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9001_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9002_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9003_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D9004_LAN
0401-001056
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
1
S.A
....4
D5001
0401-001099
DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3
1
S.N.A
....4
D4001
0403-000002
DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD
1
S.A
....4
D5011
0403-000002
DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD
1
S.A
....4
D3003
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3004
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3005
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3006
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3007
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3008
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3009
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3011
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
Remark
5-39
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
D3015
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3016
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3018
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3019
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3020
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3021
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3023
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3024
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3028
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3029
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3039
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3045
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3056
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3057
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3058
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3060
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3065
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3066
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3067
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3068
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3069
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3073
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3074
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3075
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3776
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D3779
0403-001180
DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D0254
0404-001404
DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23,
1
S.A
....4
D7001_USB
0406-001200
DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70
1
S.A
....4
D7002
0406-001200
DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70
1
S.A
....4
D3901
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3902
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3903
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3904
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3905
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3906
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3907
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D3908
0406-001271
DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251
1
S.A
....4
D7999
0407-000123
DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
1
S.N.A
....4
Q4003
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q4005
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q4020
0501-000280
TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23
1
S.A
....4
Q1002_LCD
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q3007
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q3008
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4004
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4009
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q4011
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
....4
Q9001_LAN
0501-000445
TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT
1
S.A
5-40
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
Q7601_LCD
0501-002080
TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59
1
S.A
....4
Q7602_LCD
0501-002080
TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59
1
S.A
....4
Q409
0505-000110
FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0.
1
S.A
....4
Q409
0505-001916
FET-SILICON;Si4800BDY,N,30V,9A,0.03ohm,2
1
S.A
....4
IC104
0801-002095
IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP
1
S.A
....4
IC104
0801-002172
IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI
1
S.A
....4
IC104
0801-002172
IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI
1
S.A
....4
IC104
0801-002630
IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT
1
S.A
....4
IC104
0801-002780
IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER
1
S.N.A
....4
IC7008
1001-000164
IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16
1
S.A
....4
IC9003_LAN
1001-001109
IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C
1
S.A
....4
IC106
1001-001177
IC-VIDEO SWITCH;TEA6425D,VIDEO SWITCH,SO
1
S.A
....4
IC106
1001-001573
IC-VIDEO SWITCH;SiI9287ACNUTR,QFN,72P,10
1
S.A
....4
IC107
1002-001482
IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI
1
S.A
....4
IC3001
1006-001266
IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P,
1
S.A
....4
IC112
1103-000129
IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm
1
S.A
....4
IC112
1103-000129
IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm
1
S.A
....4
IC112
1103-001385
IC-EEPROM;AT24C256,256Kbit,32Kx8,SOP,8P,
1
S.A
....4
IC112
1103-001415
IC-EEPROM;AT93C46D,1Kbit,128x8/64x16,SOP
1
S.N.A
....4
IC7003
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7004
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7005
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7006
1105-001859
IC-DDR2 SDRAM;K4T1G164QD-ZCE7,DDR2,1Gbit
1
S.A
....4
IC7999
1107-001740
IC-NAND FLASH;KFH8GH6U4M-DIB6,8Gbit,512M
1
S.A
....4
T0124
1201-002796
IC-POWER AMP;STA339BWS,PSSO,36P,10.3x7.5
1
S.A
....4
T0124
1201-002796
IC-POWER AMP;STA339BWS,PSSO,36P,10.3x7.5
1
S.A
....4
T0087
1203-001816
IC-POSI.FIXED REG.;78M08,TO-252,3P,-,PLA
1
S.A
....4
T0087
1203-002519
IC-POSI.FIXED REG.;KIA7809AF,DPAK,3P,240
1
S.A
....4
T0087
1203-002842
IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P
1
S.A
....4
T0087
1203-002842
IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P
1
S.A
....4
T0087
1203-002898
IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6.
1
S.A
....4
IC012
1203-002995
IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P,
1
S.A
....4
IC012
1203-002995
IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P,
1
S.A
....4
IC4005
1203-004363
IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P,
1
S.A
....4
IC4004
1203-004364
IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P,
1
S.A
....4
IC1007
1203-004879
IC-DC/DC CONVERTER;MP8668DL,QFN,14P,3x4m
1
S.A
....4
T0087
1203-005134
IC-POSI.FIXED REG.;RT9167A-33PB,SOT-23-5
1
S.A
....4
IC1006
1203-005538
IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4.
1
S.A
....4
IC5006
1203-005559
IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2
1
S.A
....4
T0087
1203-005713
IC-POSI.FIXED REG.;S-1172B33-E6T1G,HSOP,
1
S.A
....4
T0087
1203-005713
IC-POSI.FIXED REG.;S-1172B33-E6T1G,HSOP,
1
S.A
....4
IC118
1204-003010
IC-VIDEO PROCESS;SDP84,PBGA,324P,23x23mm
1
S.A
....4
IC7001
1204-003011
IC-DECODER;SDP83,PBGA,729P,34x34mm,PLAST
1
S.A
....4
IC9002_LAN
1205-002941
IC-ETHERNET CONTROLLER;RTL8100CSL-LF,LQF
1
S.N.A
....4
IC3011
1205-003201
IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm
1
S.A
....4
IC2001
1205-003352
IC-CODEC;WM8593SEFT/V,TQFP,64P,10x10mm,P
1
S.A
....4
IC8006
1205-003479
IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6
1
S.A
....4
IC7007
1205-003733
IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9
1
S.A
....4
IC7010_USB
1205-003735
IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm,
1
S.A
....4
IC5010
1209-001830
IC-PLL;IDT6V10012PGG,TSSOP,20P,6.5x4.4mm
1
S.A
....4
D4110
1405-001185
VARISTOR;24Vdc,1.6x0.8x0.36mm,TP
1
S.A
Remark
5-41
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
D3010
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3012
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3013
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3014
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3017
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3025
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3026
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3027
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3041
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3059
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3064
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3070
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3071
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3072
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3078
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D3081
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4011
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4012
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4014
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4016
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4017
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D4018
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D7003_USB
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D7004
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D9005_LAN
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
D9006_LAN
1405-001233
VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP
1
S.A
....4
R7120
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7121
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7122
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7123
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7152
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7153
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7154
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7155
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7162
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7163
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7164
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7165
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7169
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7170
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7171
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R7172
2007-000043
R-CHIP;1Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5034
2007-000060
R-CHIP;100Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R5038
2007-000060
R-CHIP;100Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R1801
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5101
2007-000070
R-CHIP;0ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2058
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2059
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2060
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2061
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2086_WF
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
5-42
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R2087_WF
....4
R5112
2007-000072
R-CHIP;47ohm,5%,1/10W,TP,1608
1
S.N.A
2007-000074
R-CHIP;100ohm,5%,1/10W,TP,1608
1
S.A
....4
....4
R2085_WF
2007-000090
R-CHIP;10Kohm,5%,1/10W,TP,1608
1
S.A
R7050
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7053
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7056
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7058
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7062
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7066
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7069
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7070
2007-000137
R-CHIP;2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2001
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2002
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2025
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2026
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3007
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3034
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3036
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3046_AU
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3062
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3068
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3070
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3120
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3205
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3206
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3207
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3243
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4042
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4049
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4050
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4079
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4080
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4087
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4097
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4155
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7114
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7605_LCD
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8311
2007-000138
R-CHIP;100ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1031_LCD
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1072
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1172
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3010
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3021
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3022
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3035
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3037
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3069
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3071
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3227
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3228
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4081
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-43
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R6028
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6064
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6065
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6066
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7045
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7072
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7195
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7196
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7602_LCD
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7999
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9007_LAN
2007-000140
R-CHIP;1Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2054
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2081_WF
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4019
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4085
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5030
2007-000141
R-CHIP;2.2Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1030_LCD
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1060
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1070
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1170
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2062
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2063
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3159
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3272
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3273
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3274
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4016
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4018
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4020
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4057
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4059
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4066
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4074
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4077
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4500_AU
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4501_AU
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4771
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4772
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4773
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4774
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5017
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6015
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6021
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6023
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6038
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6039
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6040
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6048
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6053
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6100
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6101
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
5-44
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R6102
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7010
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7011
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7012
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7013
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7017
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7033
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7034
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7036
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7037
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7060
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7063
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7064
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7065
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7067
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7068
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7131
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7136
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7137
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7148_USB
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7149_USB
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7156
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7174
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7239
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7240
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7400
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7401
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7800
2007-000143
R-CHIP;4.7Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3044
2007-000146
R-CHIP;6.8Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1013
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1015
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2027
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3168
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3252
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3253
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3310
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3311
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4017
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4027
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4078
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4150
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5111
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6847
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7103
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7351
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7411_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7600_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7601_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7603_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-45
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7604_LCD
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8012
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8014
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8015
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8020
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8022
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8023
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9028_LAN
2007-000148
R-CHIP;10Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4021
2007-000155
R-CHIP;27Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4061
2007-000155
R-CHIP;27Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1011
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2007
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2008
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2009
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2010
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2019
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2020
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2021
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2022
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3003
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3040
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3041_AU
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3042
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3043_AU
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3053
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3055
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3182
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3201
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3204
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3275
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3276
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3820
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4151
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9029_LAN
2007-000157
R-CHIP;47Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2046
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2082_WF
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3103
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3125
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3160
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3161
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3162
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3163
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3164
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3165
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3166
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3167
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3169
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3170
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3199
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3200
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3202
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
5-46
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3203
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3220
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3250
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3251
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3258
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3259
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3284
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3285
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3289
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3290
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3400
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3500
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3860
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4041
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4200
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4250
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5006
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5007
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5011
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5033
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5035
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6013
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6061
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6068
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6084
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6848
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7002
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7003
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7004
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7007
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7014
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7015
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7018
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7035
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7038
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7047
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7048
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7073
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7074
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7075
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7076
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7077
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7078
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7079
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7080
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7081
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7082
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7083
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7084
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7089
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7090
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
Remark
5-47
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7091
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7092
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7093
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7094
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7095
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7096
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7097
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7098
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7099
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7101
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7102
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7104
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7118
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7119
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7128
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7129
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7130
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7132
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7133
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7134
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7141
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7143
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7144
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7150_USB
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7151_USB
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7161
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7167
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7168
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7177
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7201
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7202
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7204_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7230_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7234
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7236
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7237
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7238
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7244_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7245_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7246_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7284_LCD
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7294_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7295_120H
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7997
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7998
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8016
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9020_LAN
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9021_LAN
2007-000171
R-CHIP;0ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3288
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3300
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3301
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
5-48
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3302
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3303
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4038
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5042
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5043
2007-000172
R-CHIP;10ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2048
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2049
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2050
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2051
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2077_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2078_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2079_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2080_WF
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3240
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3244
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4036
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5008
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5009
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5010
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6031
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6042
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6043
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6069
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6070
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6075
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6076
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6184
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7115
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7124
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7126
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7127
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7159
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7175
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7200
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7650
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7651
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7652
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7653
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7654
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7655
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8021
2007-000173
R-CHIP;22ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3008
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3256
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3257
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4039
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4040
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7217
2007-000174
R-CHIP;47ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1018
2007-000239
R-CHIP;1.5Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R6089
2007-000259
R-CHIP;1.6Kohm,5%,1/10W,TP,1608
1
S.A
....4
R3254
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R3255
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
Remark
5-49
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R5022
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R7105
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R7147
2007-000287
R-CHIP;100ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R2064
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2065
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2066
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2067
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2068
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2069
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2070
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2071
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2088_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2089_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2090_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R2091_WF
2007-000362
R-CHIP;12ohm,5%,1/10W,TP,1608
1
S.A
....4
R5001
2007-000402
R-CHIP;150ohm,5%,1/10W,TP,1608
1
S.A
....4
R5031
2007-000563
R-CHIP;220Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5026
2007-000591
R-CHIP;22ohm,1%,1/10W,TP,1608
1
S.A
....4
R1800
2007-000608
R-CHIP;240ohm,5%,1/10W,TP,1608
1
S.A
....4
R5045
2007-000669
R-CHIP;2Kohm,1%,1/10W,TP,1608
1
S.N.A
....4
R7160
2007-000729
R-CHIP;300ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R7176
2007-000729
R-CHIP;300ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5044
2007-000755
R-CHIP;330Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5039
2007-000758
R-CHIP;330Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5037
2007-000763
R-CHIP;330ohm,1%,1/10W,TP,1608
1
S.N.A
....4
R1021
2007-000779
R-CHIP;33ohm,1%,1/10W,TP,1608
1
S.A
....4
R1012
2007-000803
R-CHIP;36Kohm,1%,1/10W,TP,1608
1
S.A
....4
R2072
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2073
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4015
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6067
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9031_LAN
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9032_LAN
2007-000932
R-CHIP;470ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9018_LAN
2007-000982
R-CHIP;5.6Kohm,5%,1/16W,TP,1005
1
S.A
....4
R9030_LAN
2007-000982
R-CHIP;5.6Kohm,5%,1/16W,TP,1005
1
S.A
....4
R5048
2007-001038
R-CHIP;56Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5041
2007-001044
R-CHIP;56ohm,5%,1/10W,TP,1608
1
S.A
....4
R1014
2007-001179
R-CHIP;8.2Kohm,5%,1/10W,TP,1608
1
S.N.A
....4
R2047
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2052
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2053
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2074_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2075_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2076_WF
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3246
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5046
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5047
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R8028
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R9022_LAN
2007-001292
R-CHIP;33ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3245
2007-001305
R-CHIP;120ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3247
2007-001305
R-CHIP;120ohm,5%,1/16W,TP,1005
1
S.N.A
5-50
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R7194
....4
R3111
2007-001308
R-CHIP;200ohm,5%,1/16W,TP,1005
1
S.N.A
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
....4
R3112
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
R3113
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R3114
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R4152
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7410_LCD
2007-001325
R-CHIP;3.3Kohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1004
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1007
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1008
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1009
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5056
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R5102
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R9001_LAN
2007-002425
R-CHIP;1ohm,5%,1/10W,TP,1608
1
S.N.A
....4
R1017
2007-002900
R-CHIP;11Kohm,1%,1/10W,TP,1608
1
S.A
....4
R5070
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5210
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5211
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5213
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5214
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R5215
2007-007009
R-CHIP;75ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R6846
2007-007095
R-CHIP;390ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R1010
2007-007107
R-CHIP;100Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9008_LAN
2007-007132
R-CHIP;15Kohm,1%,1/16W,TP,1005
1
S.A
....4
R2057
2007-007136
R-CHIP;4.7Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R8013
2007-007136
R-CHIP;4.7Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R1019
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R1023_LCD
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4028
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4030
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4052
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4053
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4089
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4156
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R4775_ZIG
2007-007142
R-CHIP;10Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R2055
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2056
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2083_WF
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R2084_WF
2007-007197
R-CHIP;3.3ohm,5%,1/16W,TP,1005
1
S.N.A
....4
R7193
2007-007222
R-CHIP;6.04Kohm,1%,1/10W,TP,1608
1
S.A
....4
R1016
2007-007312
R-CHIP;20Kohm,1%,1/16W,TP,1005
1
S.A
....4
R1022
2007-007312
R-CHIP;20Kohm,1%,1/16W,TP,1005
1
S.A
....4
R5036
2007-007469
R-CHIP;110ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7190
2007-007698
R-CHIP;5.1Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7191
2007-007698
R-CHIP;5.1Kohm,1%,1/16W,TP,1005
1
S.N.A
....4
R7116
2007-007797
R-CHIP;44.2ohm,1%,1/10W,TP,1608
1
S.A
....4
R7117
2007-007797
R-CHIP;44.2ohm,1%,1/10W,TP,1608
1
S.A
....4
R3009
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3011
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3012
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3029
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
Remark
5-51
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
R3030
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3031
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3045
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3047
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3050
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3051
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3052
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3054
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3064
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3065
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3066
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3208
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3209
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3210
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3241
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R3242
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R5032
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9100_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9101_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9102_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9103_LAN
2007-008015
R-CHIP;75ohm,1%,1/16W,TP,1005
1
S.N.A
....4
R9014_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9015_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9016_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R9017_LAN
2007-008298
R-CHIP;49.9ohm,1%,1/16W,TP,1005
1
S.A
....4
R1020
2007-008593
R-CHIP;750ohm,1%,1/16W,TP,1005
1
S.A
....4
RA7061
2011-001001
R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2
1
S.A
....4
RA5003
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA7056
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA7057
2011-001093
R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3
1
S.A
....4
RA5005
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA5006
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8006
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8007
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8008
2011-001261
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4044
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4045
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4046
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4047
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4048
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA4051
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6001
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6004
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6005
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6006
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
5-52
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
RA6007
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6008
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6009
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6010
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6011
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6012
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6013
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA6015
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7002
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7003
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7004
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7005
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7006
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7007
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7008
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7009
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7010
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7011
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7012
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7041
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7042
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7043
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7044
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7045
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7046
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7047
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7048
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7049
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7050
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7051
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7052
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7500
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA7501
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8017
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8018
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA8019
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA9001_LAN
2011-001262
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
1
S.A
....4
RA2005
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA2006
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA6019
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA8010
2011-001345
R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2
1
S.N.A
....4
RA6018
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7013
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7014
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7015
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7020
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7053
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7054
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7502
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7503
2011-001396
R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP,
1
S.N.A
....4
RA7600
2011-001427
R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,2.0
1
S.N.A
Remark
5-53
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
RA3006
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA3007
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA3008
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA3009
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA4010
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA4075
2011-001449
R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010
1
S.N.A
....4
RA7060
2011-001589
R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1
1
S.A
....4
C6856
2203-000041
C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608
1
S.N.A
....4
C2080
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2081
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2082
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2083
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2114_WF
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2115_WF
2203-000125
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
1
S.A
....4
C2040
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C2091_WF
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3002
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3013
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3015
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3021
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3023
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3066
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3250
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C3251
2203-000233
C-CER,CHIP;0.1nF,5%,50V,C0G,1005
1
S.A
....4
C2036
2203-000280
C-CER,CHIP;0.01nF,0.5pF,50V,C0G,1608
1
S.A
....4
C2089_WF
2203-000330
C-CER,CHIP;0.012nF,5%,50V,C0G,1005
1
S.A
....4
C6857
2203-000357
C-CER,CHIP;0.15nF,5%,50V,C0G,1608
1
S.N.A
....4
C7137
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C9017_LAN
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C9019_LAN
2203-000384
C-CER,CHIP;0.015nF,5%,50V,C0G,1608
1
S.N.A
....4
C1001
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1029
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1041_LCD
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1768
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4003
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4012
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4025
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C4035
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C6090
2203-000438
C-CER,CHIP;1nF,10%,50V,X7R,1005
1
S.A
....4
C1027
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C3014
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C3016
2203-000489
C-CER,CHIP;2.2nF,10%,50V,X7R,1005
1
S.A
....4
C5001
2203-000550
C-CER,CHIP;0.02nF,5%,50V,C0G,1005
1
S.N.A
....4
C5002
2203-000550
C-CER,CHIP;0.02nF,5%,50V,C0G,1005
1
S.N.A
....4
C2070
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2071
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2072
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2073
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2074
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C2075
2203-000575
C-CER,CHIP;220nF,10%,25V,X7R,TP,2012
1
S.N.A
....4
C5037
2203-000595
C-CER,CHIP;0.22nF,5%,50V,C0G,2012
1
S.N.A
5-54
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C4009
2203-000679
C-CER,CHIP;0.027nF,5%,50V,C0G,1005
1
S.A
....4
C4010
2203-000679
C-CER,CHIP;0.027nF,5%,50V,C0G,1005
1
S.A
....4
C5003
2203-000697
C-CER,CHIP;0.002NF,0.25PF,50V,C0G,TP,160
1
S.A
....4
C5004
2203-000697
C-CER,CHIP;0.002NF,0.25PF,50V,C0G,TP,160
1
S.A
....4
C7048
2203-000761
C-CER,CHIP;330nF,10%,16V,X7R,TP,2012,-
1
S.N.A
....4
C2107_WF
2203-000783
C-CER,CHIP;0.33nF,5%,50V,C0G,1608
1
S.A
....4
C3006
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3007
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3008
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3018
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3019
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3020
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C3022
2203-000812
C-CER,CHIP;.033nF,5%,50V,C0G,-,1005
1
S.A
....4
C2111_WF
2203-000925
C-CER,CHIP;470nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1120
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C3017
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C4018
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C4020
2203-000995
C-CER,CHIP;0.047nF,5%,50V,C0G,1005
1
S.A
....4
C2038
2203-001126
C-CER,CHIP;0.68nF,10%,50V,X7R,1608
1
S.N.A
....4
C2090_WF
2203-001126
C-CER,CHIP;0.68nF,10%,50V,X7R,1608
1
S.N.A
....4
C5031
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5135
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5136
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C5137
2203-001412
C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005
1
S.N.A
....4
C1013
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1016
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1113
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1116
2203-001596
C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012
1
S.A
....4
C1005
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C1007
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C1008
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C2006
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C2007
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4008
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4011
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4019
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4021
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4022
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4024
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4100
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C4902_ZIG
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C5023
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6061
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6077
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C6099
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7018
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7136
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C7139_LCD
2203-002285
C-CER,CHIP;10nF,10%,50V,X7R,1005
1
S.N.A
....4
C5010
2203-002494
C-CER,CHIP;470nF,10%,16V,X7R,2012
1
S.N.A
....4
C7050
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
....4
C7051
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
Remark
5-55
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
....4
C7052
....4
C1004
....4
....4
2203-005138
C-CER,CHIP;1.8nF,10%,50V,X7R,1005
1
S.A
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
C1022
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
C1024
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1048_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1148_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1149_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C1150_LCD
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2047
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2048
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2049
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2050
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2051
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2052
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2060
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2061
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2062
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2063
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2066
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2067
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2068
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2069
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2076
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2077
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2078
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2079
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2101_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2102_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2103_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2105_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2106_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2108_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2109_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2110_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2112_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2113_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2116_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C2147_WF
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C5021
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C5121
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6056
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6057
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6058
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6059
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6062
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6063
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6073
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6074
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6075
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6078
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6094
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
5-56
SA/SNA
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C6095
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6096
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C6100
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7011
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7017
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7049
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7109_USB
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7114
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7115
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7121
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7122
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7997
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7998
2203-005249
C-CER,CHIP;100nF,10%,50V,X7R,TP,1608
1
S.N.A
....4
C7009
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7016
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7025
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7029
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7059
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7063
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7065
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7073
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7088
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7105
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7106
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7148
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7157
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7173
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7205
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7210
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C7770
2203-005344
C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,-
1
S.N.A
....4
C3063
2203-005393
C-CER,CHIP;0.005nF,0.1pF,50V,NP0,TP,1005
1
S.N.A
....4
C2093_WF
2203-005437
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
1
S.N.A
....4
C2099_WF
2203-005437
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
1
S.N.A
....4
C6044
2203-005493
C-CER,CHIP;220nF,+80-20%,16V,Y5V,1005
1
S.A
....4
C6045
2203-005493
C-CER,CHIP;220nF,+80-20%,16V,Y5V,1005
1
S.A
....4
C7053
2203-005659
C-CER,CHIP;0.18nF,5%,50V,NP0,1005
1
S.N.A
....4
C1032
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C1035
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C1036
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C5025
2203-005834
C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216
1
S.A
....4
C2041
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C2092_WF
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C6091
2203-005968
C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005
1
S.N.A
....4
C9108_LAN
2203-006039
C-CER,CHIP;1nF,10%,2000V,X7R,3216
1
S.A
....4
C9109_LAN
2203-006039
C-CER,CHIP;1nF,10%,2000V,X7R,3216
1
S.A
....4
C5040
2203-006104
C-CER,CHIP;1000nF,10%,50V,X7R,3225
1
S.A
....4
C6098
2203-006126
C-CER,CHIP;47NF,10%,16V,X7R,TP,1005
1
S.N.A
....4
C1019
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1025
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1028
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1060
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
Remark
5-57
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7084
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C7178
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C7601_LCD
2203-006141
C-CER,CHIP;1000nF,10%,16V,X5R,1608
1
S.N.A
....4
C1002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1003
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1006
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1030
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1034
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1091
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1092
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1191
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1192
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1639
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C1801
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2028
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2037
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2039
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2042
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2044
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2045
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2088_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2094_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2095_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2096_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2097_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2098_WF
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3046
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3054
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3055
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3056
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3057
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3065
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3071
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3072
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3100
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3101
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C3102
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4006
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4016
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4023
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4026
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4036
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
5-58
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C4050
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4103
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4901_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4903_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C4904_ZIG
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5011
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5024
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5071
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5072
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5073
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C5112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6021
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6027
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6028
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6033
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6042
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6048
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6052
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6053
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6064
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6065
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6066
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6067
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6068
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6069
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6070
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6079
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6081
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6082
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6083
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6084
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6085
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6086
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6087
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6088
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6089
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6101
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6102
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6103
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6104
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6105
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6106
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6107
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6109
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6110
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
Remark
5-59
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C6111
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6113
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6114
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6115
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6116
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6150
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6151
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6152
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C6153
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7019
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7020
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7034
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7038
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7043
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7054
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7055
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7056
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7062
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7064
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7068
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7069
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7074
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7075
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7076
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7077
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7078
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7080
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7081
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7082
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7083
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7086
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7087
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7094
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7095
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7096
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7098
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7099
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7100_USB
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7107
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7112
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7113
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7116
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7117
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7134
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7140
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7142
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7143
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7146
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
5-60
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7147
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7149
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7152
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7160
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7161
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7164
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7165
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7168
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7169
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7172
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7176
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7177
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7180
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7181
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7185
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7200
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7201
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7202
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7203
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7206
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7211
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7220
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7221
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7222
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7223
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7224
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7225
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7226
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7227
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7228
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7400
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7402
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7403
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7404
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7405
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7406
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7407
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7408
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7409
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7410
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7411
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7412
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7413
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7414
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7417
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7418
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7419
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7420
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7423
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7750
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7751
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
Remark
5-61
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7752
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7753
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7754
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7755
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7756
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7757
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7758
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7759
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7760
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7761
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7771
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7772
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C7773
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8001
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8002
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8003
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8004
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8007
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8011
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8012
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8013
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8014
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8015
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8016
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8017
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8018
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C8019
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9001_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9005_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9007_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9008_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9010_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9011_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9012_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9013_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9014_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9015_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9016_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9018_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9023_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9024_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9104_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9105_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9106_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C9107_LAN
2203-006158
C-CER,CHIP;100nF,10%,16V,X7R,1005
1
S.N.A
....4
C2104_WF
2203-006336
C-CER,CHIP;10000nF,10%,25V,X5R,3216
1
S.A
....4
C5012
2203-006336
C-CER,CHIP;10000nF,10%,25V,X5R,3216
1
S.A
....4
C1017
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1020
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1021
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1023
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
5-62
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C1031
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1033
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C1050
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2003
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2011
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2014
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2035
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2046
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2055
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2064
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2065
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3037
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3043
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3051
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3067
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3068
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3069
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3073
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C3810
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C4001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C4015
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5018
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5028
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5032
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5034
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5035
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5036
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C5111
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6011
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6022
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6029
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6030
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6031
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6032
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6046
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6049
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6050
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6054
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6055
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6071
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6072
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6092
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C6093
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7001
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7004
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7005
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7006
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
Remark
5-63
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7007
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7008
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7021
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7085_USB
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7108
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7110
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7130
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7132
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7133
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C7999
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C8010
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9002_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9022_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9100_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9101_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9102_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C9103_LAN
2203-006361
C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012
1
S.A
....4
C2084
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2085
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2086
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2087
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2185_WF
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C2186_WF
2203-006382
C-CER,CHIP;10000nF,10%,25V,X7R,TP,3225
1
S.N.A
....4
C1040_LCD
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C1042_LCD
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2023
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2024
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2025
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2026
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2029
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2030
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3901
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3902
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3903
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C3904
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C4004
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6040
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6041
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6060
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6076
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6097
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6851
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6852
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C6853
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7003
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7028
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7030
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7037
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7039
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7040
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7072
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
5-64
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
C7089
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7097
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7141
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7156
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7204
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C7209
2203-006562
C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005
1
S.N.A
....4
C2004
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2008
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2009
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2010
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2056
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2057
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2059
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C3077
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C4005
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C5016
2203-006681
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1005
1
S.N.A
....4
C2053
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C2054
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C3058
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C3062
2203-006992
C-CER,CHIP;0.33nF,5%,50V,C0G,1005
1
S.N.A
....4
C1015
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C1018
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C2002
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C2058
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C5022
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C6047
2203-007176
C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 (
1
S.N.A
....4
C5019
2402-001210
C-POLYMER AL CHIP;100uF,20%,10V,WT,TP,7.
1
S.A
....4
C6005
2409-001118
C-POLYMER ,CHIP;47uF,-+20,10V,WT,REEL,3.
1
S.A
....4
C6014
2409-001118
C-POLYMER ,CHIP;47uF,-+20,10V,WT,REEL,3.
1
S.A
....4
CA2001
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA2002
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6003
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6004
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA6005
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA7600
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA7601
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
CA9001_LAN
2503-001051
C-NETWORK;100nFx4,20%,16V,2012
1
S.A
....4
T9001_LAN
2601-001056
TRANS-SMD,PULSE;350UH,-,1:1,1:1,12.7X6.7
1
S.A
....4
T0052
2703-000380
INDUCTOR-SMD;18uH,5%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-000398
INDUCTOR-SMD;10uH,10%,3225
1
S.A
....4
T0052
2703-003391
INDUCTOR-SMD;15uH,20%,8080
1
S.A
....4
T0052
2703-003391
INDUCTOR-SMD;15uH,20%,8080
1
S.A
....4
T0052
2703-003559
INDUCTOR-SMD;4.7uH,20%,8080
1
S.A
....4
T0052
2703-003628
INDUCTOR-SMD;1.5uH,20%,2020
1
S.A
....4
L2001
2704-000018
INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh
1
S.N.A
....4
L2002
2704-000018
INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh
1
S.N.A
....4
X202
2801-003326
CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH
1
S.A
Remark
5-65
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
X202
2801-003773
CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh
1
S.A
....4
X202
2801-004629
CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP
1
S.A
....4
X202
2801-004734
CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12
1
S.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
F103
2901-001302
FILTER-EMI SMD;20V,0.3A,0pF,2.0x1.2x1.3m
1
S.N.A
....4
T0568
3301-000314
BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,-
1
S.N.A
....4
T0568
3301-000314
BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,-
1
S.N.A
....4
T0568
3301-001145
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001236
BEAD-SMD;60ohm,1608
1
S.N.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
5-66
Remark
5. Exploded View & Part List
Level
Location No.
Code No.
Description & Specification
Q’ty
SA/SNA
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0568
3301-001404
BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz
1
S.A
....4
T0313
3404-001207
SWITCH-TACT;12V,50mA,160gf,6.2X6.2,SPST
1
S.A
....4
CN3010
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3013
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3015
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3016
3701-001293
CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU
1
S.A
....4
CN3002
3710-002276
SOCKET-INTERFACE;24P,1R,0.5mm,SMD-A,AU,B
1
S.A
....4
CN330
3711-005292
HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,SMD-
1
S.N.A
....4
CN330
3711-005292
HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,SMD-
1
S.N.A
....4
CN330
3711-005477
HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,SMD-
1
S.A
....4
CN330
3711-005499
HEADER-BOARD TO CABLE;BOX,8P,1R,1.25mm,S
1
S.N.A
....4
CN330
3711-005543
HEADER-BOARD TO CABLE;BOX,6P,1R,1.25mm,S
1
S.N.A
....4
CN330
3711-005925
HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S
1
S.N.A
....4
T0077
BN41-01190A
PCB MAIN;ultra slim eu,FR-4,4,1.2T,200*2
1
S.N.A
S.N.A
....4
M0018
BN97-03532A
ASSY MICOM;SEC,N74A,2009-02-25,T-CHL7DAU
1
.....5
IC7002
1107-001740
IC-NAND FLASH;KFH8GH6U4M-DIB6,8Gbit,512M
1
S.A
....4
CCMM1
BN97-03541A
ASSY MICOM-SUB;N74A,2009-02-27,T-CHLDEUS
1
S.N.A
.....5
IC520
0903-001590
IC-MICROCONTROLLER;61P8E-RG480WT,LQFP,48
1
S.A
....4
T0010
BP27-00002A
COIL CHOKE;SLF6028T-220MR77,22uF,20%,,,,
1
S.A
0.1
M0045
BN92-04948H
ASSY ACCESSORY;UA55B8000XFXXY
1
S.N.A
..2
M0045
BN96-10939G
ASSY ACCESSORY-MANUAL;UA46B8000XFXXY, 55
1
S.A
Remark
5-67
5. Exploded View & Part List
Level
Location No.
...3
T0524
...3
...3
Code No.
Description & Specification
Q’ty
SA/SNA
6902-000009
BAG PE;HDPE,T0.03,W240,L400,TRP,8,2,-,5.
1
S.N.A
AA68-03242M
MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun
1
S.N.A
BN59-00726D
S/W DRIVER-CD;LN40B650T1F,DLNA,WorldWide
1
S.N.A
T0511
BN68-02227A
MANUAL USERS;B8000,SAMSUNG,ENG,AUSTRALIA
1
S.N.A
...3
T0238
BP68-00274D
MANUAL FLYER-WARRANTY CARD;comm,Samsung,
1
S.N.A
..2
M0045
BN96-10939J
ASSY ACCESSORY-CABLE;UA55B8000XFXXY
1
S.A
...3
T0685
4301-000103
BATTERY-ALKALINE;1.5V,750mAH,AAA[ LR03],
2
S.N.A
...3
T0524
6902-000009
BAG PE;HDPE,T0.03,W240,L400,TRP,8,2,-,5.
1
S.N.A
...3
T0074
BN59-00858A
REMOCON;LED9000,8000,7000,TM990,EUROPE,5
1
S.A
BN61-05596A
HOLDER-WIRE CABLE;LED TV,LDPE,T1.1,L150,
1
S.N.A
CLOTH-CLEAN;cloth,180,200,sea blue,ToC
1
S.N.A
...3
...3
...3
M9889
BN63-01798B
...3
T0531
BN63-05654B
COVER-BOTTOM;LB7000 46,HIPS,HB
1
S.A
BN96-10276B
ASSY HOLDER P-RING;09 LEDTV ALL MODEL,AB
1
S.N.A
....4
6902-000683
BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M
1
S.N.A
....4
BN61-05280A
HOLDER-RING;LB7000 46inch,ABS, HB,gray
4
S.N.A
BN96-10810A
ASSY HOLDER P;09 LEDTV MODEL,NYRON
1
S.N.A
6902-000031
BAG ZIPPER;LDPE,T0.05,W80,L160,TRP,0,0,4
1
S.N.A
BN61-05373A
HOLDER-WIRE;LB7000 46,NYRON
3
S.N.A
BN61-05491A
HOLDER-WIRE STAND;UB7000 46inch,NYRON
1
S.N.A
...3
...3
T0010
....4
....4
M0114
....4
0.1
M0003
BN92-05059C
ASSY BOX;55 B8000
1
S.N.A
..2
M0521
BN69-03542A
BOX-SET,IN;55UB7000,CB,C-01,DW1(DY-01),E
1
S.N.A
BN69-03732B
BOX-SET,OUT;55UB8000,CB,C-03, DW3,ECT 60
1
S.N.A
..2
0.1
M0113
BN92-05062A
ASSY P/MATERIAL;55 B8000
1
S.N.A
..2
T0376
6902-000061
BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000
0.09
S.N.A
..2
T0376
6902-000379
BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0
0.02
S.N.A
..2
T0524
6902-000426
BAG PE;HDPE/NITRON,T0.015/T0.5,W1600,L14
1
S.N.A
..2
T0214
AA61-20285C
HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g
4
S.N.A
..2
T0214
BN74-00008A
TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M,
1.59
S.N.A
0.1
M0019
BN92-05153B
ASSY LABEL;UA46B8000XMXRD, 46
1
S.N.A
5-68
Remark
1. Precautions
1. Precautions
1-1. Safety Precautions
Follow these safety, servicing, and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
1. For continued safety, do not attempt to modify any circuitry.
1-1-2. Servicing the LCD TV
1. When servicing the LCD TV, Disconnect the AC line cord from the AC outlet.
2. It is essential that service technicians have an accurate voltage meter available at all times.
Check the calibration of this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the LCD TV to the user, perform the following safety checks:
1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the LCD TV.
2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers or shields, isolation resistor capacitor networks, mechanical insulators, etc.
3. Leakage Current Hot Check (Figure 1-1):
WARNING : Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI
C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).
4. With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch
(READING SHOULD)
NOT BE ABOVE 0.5mA
LEAKAGE
CURRENT
TESTER
DEVICE
UNDER
TEST
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
*ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
Figure 1-1. Leakage Current Test Circuit
first in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safety related characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identified by
on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.
1-1
1. Precautions
1-2. Servicing Precautions
WARNING: An electrolytic capacitor installed with the wrong polarity might explode.
Caution:
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
If unforeseen circumstances create conflict between the following servicing precautions and any of the
Note:
safety precautions, always follow the safety precautions.
1-2-1 General Servicing Precautions
1. Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before
attempting to:
(a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
2. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes
used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to their original position.
3. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels,
input terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON.
Connect an insulation resistance meter (500 V) to the blades of the AC plug.
The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be
greater than 1 mega ohm.
6. Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument’s ground lead last.
1-3. Electrostatically Sensitive Devices (ESD) Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the LCD TV.
2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESDs.
4. Use only a grounded-tip soldering iron to solder or desolder ESDs.
5. Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static” can generate
electrical charges sufficient to damage ESDs.
6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution: Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together,
or lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD.
1-2
1. Precautions
1-4. Installation Precautions
1. For safety reasons, more than two people are required for carrying the product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal
temperature may cause fire.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a fire or electric shock.
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric
shock.
6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the highvoltage cable or the
antenna falling over may cause fire or electric shock.
7. When installing the product, leave enough space (0.4inches) between the product and the wall for ventilation
purposes. A rise in temperature within the product may cause fire.
1-3
1. Precautions
Memo
1-4
2. 产品规格
2.产品规格
2-1.功能与规格
UA46B8000XF
型号
功能
数字电视、RF、4-HDMI、1-分量、1-AV、USB1、USB2(HDD 仅在 USB1 中可用)、D-SUB、网络@
电视
亮度:500cd/m2
对比度:3000000:1
反应时间:3ms
动态对比度,Super-PVA
画中画(HDMI1、2、3、4、分量 1、PC 模式和电视模拟和数字模式下的可用子图)
规格
项目
说明
LCD 屏板
TFT-LCD板、 RGB 竖条、 SPVA 模式、 普通黑色
46英寸可视、0.53025(H) × 0.53025(W) mm 像素
浏览频率
水平:67.5KHz (typ)
竖直: 60Hz (typ)
显示色彩
10.7亿色彩
最大分辨率
水平:1920 Pixels
竖直:1080 Pixels
输入信号
模拟0.7 Vp-p ± 5% 极端 75Ω,内置终端
输入同步信号
H/V分离, TTL, P.或N.
最大像素时钟频率
148.5MHz
启用显示屏
水平/竖直
40.083 × 22.547 英寸 (1018.08 (H) × 572.67(V) mm)
AC 电源电压和频率
AC 110V ~ 220V, 60 Hz
电源消耗
< 160W (< 0.1W, stand by)
尺寸
本机(宽x深x高)
44.53 x 10.9 x 29.8 英寸 (1131 x 277 x 757 mm)带底座
Set (W x D x H) 44.53 x 1.18 x 27.09英寸 (1131 x 29.9 x 688 mm)不带底座
重量(本机)
50.16 lbs(22.8kg) 带底座
39.6 lbs(18kg) 不带底座
TV 制式
调谐
同步频率(参看频率表详情)
制式
DVB-T/C、PAL、 SECAM、 NT4.43
声音
BG、DK、 NICAM、 MPEG1
环境因素
运行温度:50˚F ~ 104˚F (10˚C ~ 40˚C)
运行湿度:10% ~ 80%,非凝固
保藏温度:-13˚F ~ 113˚F (-25˚C ~ 45˚C)
保藏湿度:5% ~ 95%, 非凝固
音频规格
- 最大内置扬声器输出:右=> 10W, 左 => 10W
- BASS 控制范围:-10dB ~ + 10dB
- TREBLE 控制范围: -10dB ~ +10dB
- 输出频率:RF : ~ 15 kHz
A/V : ~ 20 kHz
备注:Anynet+、 媒体播放、网络电视
2-1
2. 产品规格
UA55B8000XF
型号
功能
数字电视、RF、4-HDMI、1-分量、1-AV、USB1、USB2(HDD 仅在 USB1 中可用)、D-SUB、网络@
电视
亮度:500cd/m2
对比度:3000000:1
反应时间:3ms
动态对比度,Super-PVA
画中画(HDMI1、2、3、4、分量 1、PC 模式和电视模拟和数字模式下的可用子图)
规格
项目
说明
LCD 屏板
TFT-LCD板、 RGB 竖条、 SPVA 模式、 普通黑色
52英寸可视、0.63(H) × 0.63(W) mm 像素
浏览频率
水平:67.5KHz (typ)
竖直: 60Hz (typ)
显示色彩
10.7亿色彩
最大分辨率
水平:1920 Pixels
竖直:1080 Pixels
输入信号
模拟0.7 Vp-p ± 5% 极端 75Ω,内置终端
输入同步信号
H/V分离, TTL, P.或N.
最大像素时钟频率
148.5MHz
启用显示屏
水平/竖直
47.624×26.788 英寸 (1209.6 (H) × 680.4 (V) mm)
AC 电源电压和频率
AC 110V ~ 220V, 60 Hz
电源消耗
< 160W (< 0.1W, 待机)
尺寸
本机(宽x深x高)
52.05 x 12.09 x 33.86 英寸(1322 x 307 x 860 mm)带底座
52.05 x 1.18 x 31.38 英寸 (1322 x 29.9 x 797 mm)不带底座
重量(本机)
63.8 lbs(29 kg) 带底座
51.04lbs(23.2 kg) 不带底座
TV 制式
调谐
同步频率(参看频率表详情)
制式
DVB-T/C、PAL、 SECAM、 NT4.43
声音
BG、DK、 NICAM、 MPEG1
环境因素
运行温度:50˚F ~ 104˚F (10˚C ~ 40˚C)
运行湿度:10% ~ 80%, non-condensing
保藏温度:-13˚F ~ 113˚F (-25˚C ~ 45˚C)
保藏湿度:5% ~ 95%, non-condensing
音频规格
- 最大内置扬声器输出:右=> 15W, 左 => 15W
- BASS 控制范围:-10dB ~ + 10dB
- TREBLE 控制范围: -10dB ~ +10dB
- 输出频率:RF : ~ 15 kHz
A/V : ~ 20 kHz
备注:Anynet+、 媒体播放、网络电视
2-2
2. 产品规格
PAL 在空气中的信道频率表
2-3
2. 产品规格
2-4
2. 产品规格
PAL CATV 信道频率表
2-5
2. 产品规格
2-6
2. 产品规格
2-2. MJC : 运动加帧处理引擎(FRC)
举例
技术
y高品质影片映象运动加桢消除。
y适应性递归搜索法(ARS)
-同时执行IPC/MJC
-搜索范围
-水平:± 72 像素,竖直:± 12 行
<运动加桢>
<运动加桢消除>
框图
关
DTV 信号
ME
(ARS)
影片检测
开
IPC
MJC
<运动加桢>
<运动加桢消除>
2-7
2. 产品规格
2-3. 网络电视
- 是否支持此功能取决于你所在的国家。
- 如果你在使用导向功能时遇到一些问题,请联系服务商。
在导向操作中,按下绿色按钮并获取信息或参看辅助网站获取服务商信息。
- 根据所在地区,导向服务中可能仅支持英语。
- 不适用于所有地区。
2-3-1. 开始网络电视
网络电视通过网络连接提供三星导向服务。网络电视的内容的变更取决于提供商。你可以通过网络电视服
务获取各种信息,例如YouTube。
- 配置导向及他们所提供的服务会按照所选择的国家而不同。
变更国家后,关闭并开启电视,然后可以通过导向服务变更所支持的国家。如果国家被设置为其它,电
视将不能识别你的国家,在这种情况下,请直接选择服务国家列表。
- If a certain content’s font provided by contents provider is not supported on TV, It may not be viewed
normally.
- 可获取如何设置国家的更多信息。
- You may experience slow operation or hesitation when using this function due to network conditions.
- Before using Internet@TV, set up the network first. For more information on how to configure your
network.
When running Internet@TV for the first time, the basic settings proceed automatically. It may take few
minutes to update.
1. Press the MENU button. Press the ▲ or ▼ button to select Application, then press the ENTERE
button.
2. Press the ▲ or ▼ button to select Internet@TV, then press the ENTERE button.
Press the Internet@ button on the remote control to display the Internet@TV menu.
3.The ‘User Agreement’ is displayed. Select Agree to accept the agreement.
4.The ‘Statistics & Analysis’ is displayed. Select Agree to accept the agreement.
2-3-2. 设置网络电视
You can check and use the menus regarding Single Sign On (SSO), system management and
properties.
按下▲ 或 ▼ 按钮可选择设置,然后按下回车键。
„单独登录
在创建时可以使用此菜单,删除账号。
使用独立登录,你可以掌控包含网站内容的账号信息。
你不需要进行其它的登录。
- 账号仅供网络电视使用。
创建账号
你可以创建一个账号并连接到所需的网站。
- 账号要小于10位数字。
- 账号的字符限制应当为10。
- 如果没有需要登录的服务,你不能建立账号。
账户管理
服务网站:你可以注册登录服务网站信息。(例如: YouTube).
变更密码:可变更你的账号密码。
删除:可删除账号。
- 如果忘记了账号密码,按照如下顺序按下遥控按钮,可复位网络电视: 电源(关闭) →静音 → 9 → 4 →
8 → 电源 (开启)。
如果使用此功能,所有账号将会被删除。
2-8
2. 产品规格
„制式设置
Ticker自动运行,Ticker的间隔取决于你所在的国家。
变更服务锁密码
新电视的默认密码为0-0-0-0。
如果你忘记密码,按照如下顺序按下遥控按钮,可将密码复位为0-0-0-0
:电源 (关闭) →静音 → 8 → 2 → 4 → 电源 (开启)。
选择服务时段
在屏保出现前,选择并设置服务间隔时段。
Ticker自动运行→ 关 / 开
选择设置ticker为自动运行或当开启电视时运行。
Ticker间期
在屏保出现前选择设置服务间隔时段。
„属性
显示网络电视信息。
可以使用网络电视服务中的速度测试可测试网络电视的速度。
2-3-3. 使用网络电视服务
在导向多选项菜单中,你可以浏览选项菜单中的内容。
使用 e 和 f 按钮。
账号登陆
1. 按下红色按钮。
2. 选择所需的用户账号,然后按下回车按钮。
3. 输入密码。
- 登录成功后,用户的账号将会显示在屏幕上。
- 在登录前,至少一个或更多的账号注册。如果你想创建账号,请使用导向专栏。
You can use Run Service, Lock, Install Service at the existing widget and you can see description of the
widget service that isn’t installed. On the Internet@TV, you can add and use various widgets provided
by service provider.
服务提供商的不同可能会有所不同。
- 运行服务:运行导向服务。
- 锁:设定服务锁。
- 安装服务 (或删除服务):安装或删除导向服务。
2-9
2. 产品规格
使用YouTube工具栏
可以收看由YouTube提供的电影。
如果你拥有YouTube的账号,可通过账户管理注册账户信
息。
然后,你可以使用我的收藏夹。
- 菜单可以通过网络服务进行变更。
- 这里可能有一些不适合孩子看的内容。这种情况下,在
Widget Gallery中使用锁定功能。
2-3-4. 网络电视的故障排除
故障
可能存在的解决方法
一些导向服务不能运行
检查是否符合服务商要求。
在导向指示中,按下绿色按钮并获取联系信息或参看辅助网站
获取服务商信息。
参看辅助网站页面
单独登录的优点是什么?
如果创建账号并注册所需服务的登录信息,就可在不进行其它
登录的情况下浏览个人信息。
当网络故障发生时,我不能使用除设置
菜单外的其它菜单选项。
如果网络连接不运行,你的服务可能受限。因为除了设置菜单
外的所有功能都需要连接至网络。
在 YouTube 网站上可以收看成人电影
吗?
事实上,在菜单的列表中已经被过滤掉。但是通过使用搜索功
能,可以显示收看。在这种情况下,使用Widget Gallery锁定导
向服务。
2-3-5. 辅助网站
2-10
2. 产品规格
2-4. 使用内容库
The Content Library allows you to enjoy various content on your TV. You can use the default content
stored in the TV memory or you can enjoy new content using a USB device or via the Internet.
Using the Content Library Menu
1.Press the MENU button. Press the ▲ or ▼ button to
select Application, then press the ENTER button.
2.Press the ▲ or ▼ button to select Content Library, then
press theENTER button.
- The Content Library main menu is displayed.
3.Press the or button to select an icon (Gallery, Cooking,
Game, Children, Wellness, Other, Content Management),
then press the ENTER button.
使用内容库菜单中的遥控按钮。
2-11
2. 产品规格
2-5.使用电视存储目录
You can use the default content stored in the TV memory.
You can add/delete the content of the TV memory. To delete/add content, select Content Management.
- To return to Content Library main menu, press the EXIT button
图库
This function plays a SlideShow with high resolution images and
background music and produces various atmospheres. Using the
Gallery function of the TV, you can change your home
atmosphere.
- The copyrights of the Gallery contents and all issues related to
them are reserved by Gallery Player, Inc.
- Press the ENTERE button to pause the SlideShow, and also
press the ENTERE button to resume the SlideShow.
- Press the INFO button to display the information on the selected
photo. (This is not displayed if the photo has no information.)
烹饪
You can view various recipes that you can then easily follow step by step. Enjoy thesecontents which
give you great ideas for meals.
- The recipes introduced in the Cooking contents on the Samsung TV are based on recipes published by
Anness Publishing.
- The copyrights of the Cooking contents and all issues related to them are reserved by Practical
Pictures.
游戏
This category provides entertainment games for the whole family.
- For the buttons used in the games, refer to the directions on the screen.
- Color Buttons for Games
儿童
This is educational and interactive content that children can watch repeatedly.
- The copyrights of the Children contents and issues related to them reserved by UpToTen.
保健
This is beneficial health management content that provides stretching and massage exercises that can
be enjoyed by the whole family.
- The Basic Stretches contents are automatically played so that you can easily follow the movements on
the screen.
To move to the previous or next operation, press the e or f button to view the required step. The
selected item is displayed on the screen.
其它
The default content is not saved in the TV memory.
- You can copy new content to the TV memory using the Content Management screen.
2-12
2. 产品规格
2-6. 使用目录管理
Content Management
You can select multiple content items by selecting content
items repeatedly and pressing the Yellow button.
My Contents
You can check the content saved in the TV memory for each
subitem of the Content Library.
- Select a content item and press the ENTER button.
You can play or delete the selected content item.
USB
You can check the content saved on the USB device for each
subitem of the Content Library.
Select a content item and press the ENTER button.
You can play the selected content item or copy it to the TV
memory.
- “Content Library only supports USB Mass Storage Class
devices (MSC). MSC is a Mass Storage Class Bulk-Only
Transport device.
Examples of MSC are Thumb drives and Flash Card
Readers (Both USB HDD and HUB are not supported.)
- Playing a game using an external USB memory device will
allow you to save your game (depending on the game). Take
care as removing the USB memory device while saving data
to the USB memory device may cause the data to be lost.
- Downloading New Contents
New content other than the built-in contents will be provided
via the Samsung.com website with or without charge.
Downloading Content
1. Visit the www.samsung.com website and open the Content
Library page.
2. Enter the product number (UDN, Unique Device Number).
3. Select a content item in the Contents Download page.
4. Download the contents onto the USB memory device.
5. Go to Content Library main menu by pressing Contents
button or choosing Content Library (Menu → Application
→ Content Library).
6. Plug the USB memory into USB port on the side of the TV.
Finding a product number (Unique Device Number, UDN)
1. Insert the USB memory into the USB port on the side of the
TV.
2. In the USB Browser main screen, press the Green button
(Show UDN).
3. The 18-digit number on the screen is the product code.
Provided Content
Additional contents are available on www.samsung.com
设置
- 屏保运行时间:设置屏保的运行时间。
- 保存UDN:保存UDN编号到USB设备中。
2-13
2. 产品规格
2-7.媒体播放
2-7-1 使用媒体播放功能
此功能可以让您浏览并收听存储在USB大容量存储器设备(MSC)中图片(JPEG),音频文件(MP3)
和电影(MPEG)。
1. 按下遥控器上的电源按钮或前部显示板。
- 电视被开启。
2. Connect a USB device containing JPEG and/or MP3 and
or/MPEG files to the usb jack (USB jack) on the side of the
TV.
- (If you enter the Media Play mode with no USB device
connected the message “No external storage device found.
Check the connection status.” will appear. In this case, insert
the USB device, exit the screen by pressing the MEDIA.P
button on the remote control and enter the MEDIA.P screen
again.
- MTP (Media Transfer Protocol) is not supported.
- The file system only supports FAT16/32 (The NTFS file system
is supported).
- Certain types of USB Digital camera and audio devices may
not be compatible with this TV.
- Media Play only supports USB Mass Storage Class devices
(MSC). MSC is a Mass Storage Class Bulk-Only Transport
device. Examples of MSC are Thumb drives and Flash Card
Readers (Both USB HDD and HUB are not supported.)
- Please connect directly to the USB port of your TV. If you are
using a separate cable connection, there may be a USB
Compatibility problem.
- Before connecting your device to the TV, please back up your
files to prevent them from damage or loss of data.SAMSUNG
is not responsible for any data file damage or data loss.
- Do not disconnect the USB device while it is loading.
- MSC supports MP3 and JPEG files, while a PTP device
supports JPEG files only.
- The sequential jpeg format is supported.
- Photo and audio files must be named in English, French or
Spanish. If not, the files can not be played. Change the file
names to English, French or Spanish if necessary.
- The higher the resolution of the image, the longer it takes to
display on the screen.
- 最大支持JPEG的分辨率为15360 x 8640像素。
- 对于不被支持或损坏的文件,显示“文件格式不支持”信息。
2-14
2. 产品规格
- 电影格式
支持MPEG4 GMC 1 Wrapping Point
支持 H.264 Level 4.0
支持 MP4的HE-AAC, DVB的3GPP和TS及ISDB-T型号。
2-15
2. 产品规格
2-8. 与老型号的规格比较
UB8X
(UA46B8000XF/UA55B8000XF)
SAPPHIRE
(LA46A850S1F/LA52A850S1F)
LCD TV
LCD TV
1920 x 1080
1920 x 1080
TFT LCD Panel 200Hz
TFT LCD Panel 100Hz
屏幕尺寸
46” / 55”
46” / 52”
图片比率
16 : 9
16 : 9
型号
设计
显示屏类别
分辨率
液晶显示屏
体积(宽X高X
深)
46
44.53 x 10.9 x 29.8英寸_带底座
44.53 x 1.18 x 27.09英寸_不带底座
46
44.05 x 11.14 x 29.33英寸_带底座
44.05 x 1.74 x 27.26英寸_不带底座
55
52.05 x 12.09 x 33.86英寸_带底座
52.05 x 1.18 x 31.3英寸_不带底座
52
49.72 x 12.36 x 32.74英寸_带底座
49.72 x 1.74 x 30.68英寸_不带底座
46
46 50.16lbs(22.8kg)_带底座
39.6 lbs(18kg)_ 不带底座
46
54.01 lbs(24.5kg)_ 带底座
45.19 lbs(20.5kg)_ 不带底座
55
63.8 lbs(29kg)_ 带底座
51.04 lbs(23.2kg)_不带底座
52
68.78 lbs (31.2kg)_ 带底座
59.08 lbs (26.8kg)_ 不带底座
重量
亮度
对比度
图片增强
均衡器
自动运动加桢
120Hz
环绕音
扬声器输出
天线
2-16
500 nit
500 nit
3000000:1
50000:1
DNIe+(FBE3)
DNIe+(FBE3)
5 Band
5 Band
是
是
2 Way SRS TruSurround Dolby Digital
2 Way SRS TruSurround Dolby Digital
10W + 10W (46”) 15W + 15W (55”)
10W + 10W
1 (Cable/Air)
1 (Cable/Air)
2. 产品规格
2-9.附件
产品
说明
代码编号
遥控和电池(AAA X 2)
BN59-00858A
简易遥控
BN59-00788B
底盖
BN63-00514E
保修卡/注册卡/安全指导手册
(不是所有地区都可通用)
BP68-00263D
干净的布
BN63-01798B
程序光盘
BN59-00726D
USB
BN96-10365A
底座螺钉(M4*L10)
6003-00337
(UN40B7000,
UN46B7000)
支撑环(4个)
BN61-05280A
支撑线缆
BN61-05596A
电视固定器和螺钉(M8*L19)
BN96-10788B
备注
所提供附件
2-17
2. 产品规格
产品
2-18
说明
代码编号
交叉线缆(分量)
BN39-01154C
交叉线缆(AV)
BN39-01154B
交叉线缆(声音)
BN39-01154D
备注
所提供附件
6. Wiring Diagram
6. Wiring Diagram
6-1. Wiring Diagram 46”/55”
WOOFER
POWER CORD
Function
Speaker
PANEL
CNM802
CNM9401 CNM9402
SMPS
CN801S
T- CON
IR
Main Board
WOOFER
CN1001
CN2002
CN7005
CN2001
CN4001
CN4901
RF module
Speaker
6-1
6. Wiring Diagram
CN2001(to Speaker)
CN7005(to T-CON)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
GND
GND
SW_PVCC
FRC_RESET
SDA
SCL
LVDS opt
H-Sync Out
Panel_WP
T_Con Check
NC
NC
GND
RE[4]+
RE[4]RE[3]+
RE[3]GND
RECLK+
RECLKGND
RE[2]+
RE[2]RE[1]+
RE[1]RE[0]+
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
CN3013(to HDMI1)
1
2
3
4
5
6
7
8
9
10
6-2
HDMI1_RX2+
DGND
HDMI1_RX2HDMI1_RX1+
DGND
HDMI1_RX1HDMI1_RX0+
DGND
HDMI1_RX0HDMI1_RXCLK+
1
2
3
4
RE[0]GND
RO[4]+
RO[4]RO[3]+
RO[3]GND
ROCLK+
ROCLKGND
RO[2]+
RO[2]RO[1]+
RO[1]RO[0]+
RO[0]GND
GND
GND
NC
Panel_VCC
Panel_VCC
Panel_VCC
Panel_VCC
Panel_VCC
R+
RL+
L-
CN2002(to Speaker)
1
2
3
4
SW+
SWSW+
SW-
CN4001(to Function)
1
2
3
4
5
6
IR
GND
A3.3V
LED_INDICAT
BUZZER
KEY1
7
8
9
10
11
12
CN4901(to RF Module)
1
2
3
4
5
6
A3.3V
ZIGBEE_RESET
RDB_HOTEL
GND
TDB_HOTEL
POWER_DET
CN3011(to PC_IN)
11
12
13
14
15
16
17
18
19
DGND
HDMI1_RXCLKHDMI_CEC
DGND
HDMI1_DDC_SCL
HDMI1_DDC_SDA
DGND
HDMI1_5V
HDMI1_HPD
KEKY2
NCL
A5V
NC
LED_CTRL
B5V
1
2
3
4
5
6
7
8
PC_RED
PC_GREEN
PC_BLUE
DGND
DGND
DGND
DGND
DGND
9
10
11
12
13
14
15
CN7006 (to USB1)
PC_5V
PC_IDENT
DGND
SDA_DOWN
PC_H_SYNC
PC_V_SYNC
SCL_DOWN
1
2
3
4
USB0_VCC
USB0_DM
USB0_DP
DGND
CN7002 (to USB2)
1
2
3
4
USB1_VCC
USB1_DM
USB1_DP
DGND
6. Wiring Diagram
CN3016(to HDMI2)
1
2
3
4
5
6
7
8
9
10
HDMI2_RX2+
DGND
HDMI2_RX2HDMI2_RX1+
DGND
HDMI2_RX1HDMI2_RX0+
DGND
HDMI2_RX0HDMI2_RXCLK+
11
12
13
14
15
16
17
18
19
DGND
HDMI2_RXCLKHDMI_CEC
DGND
HDMI2_DDC_SCL
HDMI2_DDC_SDA
DGND
HDMI2_5V
HDMI2_HPD
11
12
13
14
15
16
17
18
19
DGND
HDMI3_RXCLKHDMI_CEC
DGND
HDMI3_DDC_SCL
HDMI3_DDC_SDA
DGND
HDMI3_5V
HDMI3_HPD
11
12
13
14
15
16
17
18
19
DGND
HDMI4_RXCLKHDMI_CEC
DGND
HDMI4_DDC_SCL
HDMI4_DDC_SDA
DGND
HDMI4_5V
HDMI4_HPD
CN3015(to HDMI3)
1
2
3
4
5
6
7
8
9
10
HDMI3_RX2+
DGND
HDMI3_RX2HDMI3_RX1+
DGND
HDMI3_RX1HDMI3_RX0+
DGND
HDMI3_RX0HDMI3_RXCLK+
CN3010(to HDMI4)
1
2
3
4
5
6
7
8
9
10
HDMI4_RX2+
DGND
HDMI4_RX2HDMI4_RX1+
DGND
HDMI4_RX1HDMI4_RX0+
DGND
HDMI4_RX0HDMI4_RXCLK+
6-3
6. Wiring Diagram
6-2. Connector Functions
Connector
Functions
CNM802<->CN1001
Supply power from SMPS to Main Board.
CN7005<->T-CON
The LVDS signal transfered from Main Board to Panel.
6-3. Cables
Use
Code
6-4
Main-SMPS
Main-Tcon
Function Assy
46,55” :
46” : BN39-01184B(51P 250mm)
46” : BN96-10736J
BN39-01099L(30P 100mm)
55” : BN39-01184C(51P 300mm)
55” : BN96-10736K
