0100DVD-E600_EB_cover.fm Page 1 Monday, August 23, 2004 4:58 PM
DVD-E600
DVD PLAYER
LECTEUR DE DVD
EB
©2004
YAMAHA ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.
YAMAHA CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA
YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, F.R. OF GERMANY
YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE
YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND
YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN
YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA
All rights reserved.
Printed in Malaysia WD90090
Downloaded From Disc-Player.com Yamaha Manuals
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
Important Note
DK
Advarsel:
Laserrudstråling ved åbning når sikkerhesafbrydere er ude af funktion. Undgå u tsættelse for stråling.
SF
Luokan 1 laserlaite + Klass 1 laserapparat
Varoitus!
Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan
1 ylittävälle lasersäleilille.
Bemærk:
Netafbryderen STANDBY/ON er sekundært indkoblet og afbryder ikke strømmen fra nette. Den indbyggede netdel er derfor tilsluttet til lysnettet så længe netstikket sidder i stikkontakten.
Huom.
Toiminnanvalitsin STANDBY/ON on kytketty toisiopuolelle, eikä se kytke laitetta irti sähköverkosta. Sisäänrakennettu verkko-osa on kytkettynä sähköverkkoon aina silloin, kun pistoke on pistorasiassa.
N
Observer:
Nettbryteren STANDBY/ON er sekundert innkoplet. Den innebygdenetdelen er derfor ikke frakoplet nettet så lenge apparatet er tilsluttet nettkontakten.
VARO!
AVATTAESSA JA SUOJALUKITUS OHITETTAESSA
OLET ALTTIINA NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.
S
Klass 1 laserapparat
Varning!
Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kann användaren utsättas för laserstrålning, som översjruder gränsen för läserklass 1.
VARNING!
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD.
BETRAKTA EJ STRÅLEN.
Observera!
Strömbrytaren STANDBY/ON är sekundärt kopplad och inte bryter strömmen fråan nätet Den inbyggda nätdelen är därför ansluten till elnätet så länge stickproppen sitter i v
ägguttaget.
Important Note for Users in the UK
Mains plug
This apparatus is fitted with an approved 13 Amp plug.To change a fuse in this type of plug proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of
5 Amp. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5 Amp.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue = neutral (N), brown = live (L).
As these colours may not correspond with the colour markings identifying the terminals in your plug, proceed as follows:
● Connect the blue wire to the terminal marked N or coloured black.
● Connect the brown wire to the terminal marked L or coloured red.
● Do not connect either wire to the earth terminal in the plug, marked E (or e) or coloured green (or green and yellow).
Note:The severed plug must be disposed of to avoid a possible shock hazard should it be inserted into a 13
Amp socket elsewhere.
Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent.
See Copyright Act 1956 and The Performer’s Protection
Acts 1958 to 1972.
General information
CAUTION
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
ATTENTION
L’emploi de commandes, de réglages ou un choix de procédures différents des spécifications de cette brochure peut entraîner une exposition à d’éventuelles radiations pouvant être dangereses.
ACHTUNG
Die Verwendung von Bedienungselementen oder
Einstellungen oder die Durchführung von
Bedienungsvorgängen, die nicht in dieser Anleitung aufgeführt sind, kann zu einem Kontakt mit gefährlichen
Laserstrahlen führen.
OBSERVERA
Användning av kontroller och justeringar eller genomförande av procedurer andra än de som specificeras i denna bok kan resultera i att du utsätter dig för farlig strålning.
ATTENZIONE
Uso di controlli o regolazioni o procedure non specificamente descritte può causare l’esposizione a radiazioni di livello pericoloso.
PRECAUCIÓN
El uso de los controles o los procedimientos de ajuste o utilización diferentes de los especificados en este manual pueden causar una exposición peligrosa a la radiación.
VOORZICHTIG
Gebruik van bedieningsorganen of instellingen, of uitvoeren van handelingen anders dan staan beschreven in deze handleiding kunnen leiden tot blootstelling aan gevaarlijke stralen.
The unit is not disconnected from the AC power source as long as it is connected to the wall outlet,even if this unit itself is turned off.This state is called the standby mode.In this state,this unit is designed to consume a very small quantity of power.
L ’appareil n ’est pas isolé de la source d ’alimentation aussi longtemps qu ’il reste branché sur une prise murale,même lorsqu ’il est éteint.Il est alors dit en mode
«Veille ».Dans ce mode, l ’appareil consomme très peu de courant.
Das Gerät ist nicht vom Netz getrennt, solange der
Netzstecker noch mit der Wandsteckdose verbunden ist, selbst wenn das Gerät ausgeschaltet wurde. Dieser
Betriebszustand wird als Bereitschaftsmodus bezeichnet.
In diesem Zustand nimmt das Gerät eine sehr geringe
Menge Strom auf.
Enheten är inte urkopplad från nätet så länge som den är ansluten till vägguttaget även om enheten i sig självt är avstängd. Detta kallas för beredskapsläge och i detta tillstånd konsumerar apparaten minimalt med ström.
L’unità non è scollegata dall’impianto elettrico di casa sintanto che rimane collegata ad una presa di corrente anche se è spenta. Questo modo viene chiamato “modo di attesa”. In esso, l’unità consuma una quantità molto bassa di energia per mantenere in memoria le impostazioni da voi fatte.
Aunque el propio aparato se encuentre apagado, éste no se desconectará de la fuente de CA siempre que se mantenga enchufado a la toma de corriente. Este estado recibe el nombre de “modo de espera”. En este estado, este aparato ha sido diseñado para consumir una cantidad muy pequeña de energía.
De stroomtoevoer naar het toestel is niet afgesloten zolang de stekker nog in het stopcontact zit, zelfs niet als het toestel zelf uitgeschakeld is. Deze toestand wordt
“standby” (waak- of paraatstand) genoemd. Het toestel is ontworpen om in deze toestand.
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
PRODUIT LASER DE CLASSE 1
SYSTEM
CONNECTOR
RECEIVER
COMPONENT VIDEO OUT AV
P
R
P
B
Y
DIGITAL
OUT
S VIDEO
VIDEO OUT
VIDEO
COAXIAL OPTICAL
E
AUDIO
OUT
L
R
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
PRODUIT LASER DE CLASSE 1
CAUTION VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID EXPOSURE TO BEAM.
ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING VED
ÅBNING. UNDGÅ UDSÆTTELSE FOR STRÅLING.
ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING NÅR
DEKSEL ÅPNES. UNNGÅ EKSPONERING FOR STRÅLEN.
VARNING SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR
DENNA DEL ÄR ÖPPNAD. BETRAKTA EJ STRÅLEN.
VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA
NÄKYMÄTTÖMÄLLE LASER SÄTEILYLLE. ÄLÄ KATSO
SÄTEESEEN.
VORSICHT SICHTBARE UND UNSICHTBARE
LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET.
NICHT DEM STRAHL AUSSETSEN.
DANGER VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.
ATTENTION RAYONNEMENT LASER VISIBLE ET
INVISIBLE EN CAS D’OUVERTURE. EXPOSITION
DANGEREUSE AU FAISCEAU.
ii
Downloaded From Disc-Player.com Yamaha Manuals
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
1 To assure the finest performance, please read this manual carefully. Keep it in a safe place for future reference.
2 Install this sound system in a well ventilated, cool, dry, clean place — away from direct sunlight, heat sources, vibration, dust, moisture, or cold. In a cabinet, allow about 2.5cm (1 inch) of free space all around this unit for adequate ventilation.
3 Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds.
4 Do not expose this unit to sudden temperature changes from cold to hot, nor locate this unit in an environment with high humidity (i.e., a room with a humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.
5 Avoid installing this unit in a location where foreign objects may fall onto this unit or where this unit may be exposed to liquid dripping or splashing. On the top of this unit, do not place:
– Other components, as they may cause damage and/ or discoloration on the surface of this unit.
– Burning objects (i.e., candles), as they may cause fire, damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall, spilling the liquid and causing an electrical shock to the user and/or damage to this unit.
6 Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation. If the temperature inside this unit rises, it may cause fire, damage to this unit, and/or personal injury.
7 Do not plug in this unit to a wall outlet until all connections are complete.
8 Do not operate this unit upside-down. It may overheat, possibly causing damage.
9 Do not use excessive force on switches, knobs and/or cords.
10 When disconnecting the power cord from the wall outlet, grasp the plug; do not pull the cord.
11 Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth.
12 Use only the voltage specified on this unit. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than as specified.
13 To prevent damage by lightning, disconnect the power cord from the wall outlet during an electrical storm.
14 Do not attempt to modify or fix this unit. Contact qualified
YAMAHA service personnel when any service is needed.
The cabinet should never be opened for any reason.
15 When not planning to use this unit for long periods of time
(i.e., vacation), disconnect the AC power plug from the wall outlet.
16 Be sure to read the “TROUBLESHOOTING” section on common operating errors before concluding that this unit is faulty.
17 Before moving this unit, press STANDBY/ON to set the unit in standby mode, then disconnect the AC power plug from the wall outlet.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
NOTE:
Pictures shown maybe different between countries.
Never make or change connections with the power switched on.
LASER SAFETY
This unit employs a laser. Due to possible eye injury, only a qualified service person should remove the cover or attempt to service this device.
CAUTION
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM (WARNING LOCATION:
INSIDE ON LASER COVERSHIELD OR THE BACKPLATE OF
SET)
LASER
Type
DANGER
This unit emits visible laser radiation when open. Avoid direct eye exposure to beam.
When this unit is plugged into a wall outlet, do not place your eyes close to the opening of the disc tray and other openings or look inside.
Semiconductor laser GaAlAs
Wave length 650 nm (DVD)
780 nm (VCD/CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degree
Contents
Introduction
Environmental Information ............................ 2
Supplied accessories .................................... 2
Notes about discs.......................................... 2
Cleaning discs .................................................... 2
Symbols Used in this Manual ........................ 2
Functional Overview
Front and Rear Panels .................................. 3
Remote Control ............................................. 4
Preparation
General Notes on connections...................... 5
Digital Connections ....................................... 5
Analog Connections ...................................... 5
Video Connections ........................................ 6
S-Video terminal <A>.......................................... 6
Composite Video terminal <B>........................... 6
Component Video terminal <C> ......................... 6
SCART Connection <D> ..................................... 6
Inserting batteries into the Remote Control... 7
Using the Remote Control ................................... 7
PAL/NTSC Conversion ................................. 7
Turning on the power .................................... 7
Smart Power On/Off...................................... 7
Operation
Basic Playback .............................................. 8
General Operation......................................... 8
Video control during playback ............................ 8
Audio control during playback............................ 8
Repeat and Shuffle.............................................. 9
Repeat A-B.......................................................... 9
Disc Resume ....................................................... 9
OSD (On-Screen Display) ................................... 9
Zoom ................................................................. 10
Special DVD Features................................. 10
Playing a Title .................................................... 10
Playing a Chapter.............................................. 10
Camera Angle ................................................... 10
Changing the Audio Language and/or format .. 10
Subtitles............................................................. 10
Special VCD & SVCD Features .................. 10
Playback Control (PBC) .................................... 10
Preview Function ............................................... 11
Picture CD & MP3 Playback
General Operation....................................... 12
MP3 & JPEG Navigator ..................................... 12
Play Mode ......................................................... 12
Special JPEG Features............................... 13
Function Introduction ........................................ 13
Preview Function............................................... 13
Zoom picture..................................................... 13
Playback with multi-angles ............................... 13
Wipe Effect........................................................ 13
Special MP3 Features................................. 13
Function Introduction ........................................ 13
JPEG and MP3 simultaneous playback ...... 13
Setup Menu
Basic Operation........................................... 14
General Setup menu ................................... 14
DISC LOCK ....................................................... 14
PROGRAM (not for Picture CD/MP3) ................ 14
OSD LANGUAGE.............................................. 15
SCREEN SAVER................................................ 15
Audio Setup menu....................................... 15
SPEAKER SETUP .............................................. 15
DIGITAL AUDIO SETUP.................................... 16
EQUALIZER (Sound Mode) .............................. 16
3D (REVERB MODE)......................................... 16
Video Setup menu....................................... 17
TV TYPE ............................................................ 17
TV DISPLAY ...................................................... 17
CLOSED CAPTION ........................................... 18
COMPONENT ................................................... 18
PROGRESSIVE.................................................. 18
PICTURE SETTING ........................................... 19
PASSWORD SETUP .................................. 19
Preference Setup menu .............................. 20
AUDIO language............................................... 20
SUBTITLE language.......................................... 20
DISC MENU language ...................................... 20
PARENTAL Control ........................................... 21
DEFAULT Setup ................................................ 21
MP3/JPEG NAV................................................. 21
Troubleshooting............................ 22
Specifications................................ 23
Maintenance .................................. 23
Language Code ............................. 24
1
Downloaded From Disc-Player.com Yamaha Manuals
Introduction
Thank you for purchasing this unit. This Owner’s Manual explains the basic operation of this unit.
The region code for this set is 2.
Since it is usual for DVD movies to be released at different times in different regions
2 of the world, all players have region codes and discs can have an optional region code. This unit can play discs containing the identical region code, or mentioned as region “ALL”. If you load a disc of a different region code to this unit, you will see the region code notice on the screen. The disc will not play, and should be unloaded.
Cleaning discs
● When a disc becomes dirty, clean it with a cleaning cloth.
Wipe the disc from the centre out. Do not wipe in a circular motion.
● Do not use solvents such as benzine, thinner, commercially available cleaners, or antistatic spray intended for analog records.
Symbols Used in this Manual
The below symbols appear in some headings and notes with the following meanings:
Environmental Information
This unit consists of materials which can be recycled and reused if disassembled by a specialised company.
Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
Supplied accessories
– Remote control
– Batteries (two AA size) for remote control
– Audio pin cable
– Video pin cable
– System control cable (green)
– Owner’s Manual
DVD
VCD
CD
– Description refers to playback of
DVD-video discs
– Description refers to playback of
Video CDs
– Description refers to playback of
Audio CDs
– Description refers to playback of
Super VCDs
● Some DVD video discs require specific functions or allow only limited functions during playback.
● “ ✕ ” may appears on the TV screen which means that the function is not available on that specific DVD video disc.
Notes about discs
– This unit is designed for use with DVD video, Video CD,
Super video CD, Audio CD, CD-R, CD-RW (MP3 Supported),
DVD+RW, DVD+R, DVD-R and DVD-RW.
– CD-R and CD-RW cannot be played unless finalized.
– Some discs cannot be played depending on the recording conditions such as PC environment and application software.
The characteristics and condition of the discs; materials, scratches, curvature, and etc, may result in failure.
– Be sure to use only CD-R and CD-RW discs made by reliable manufacturers.
– Do not use any non standard shaped discs (heart, etc.)
– Do not use disc with tape, scals, or paste on it, damage to the unit may result.
– Do not use a disc printed on its surface by a commercially available label printer.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Functional Overview
Front and Rear Panels
STANDBY/ON
– to turn this unit to standby mode or ON
Disc Tray
/ OPEN/CLOSE
– to open/close the disc tray
9 STOP
– to stop playback
R/ T
– search forward* / go to the next chapter or track
S /Q
– search backward* / go to a previous chapter or track
B/ ; PLAY/PAUSE
– to start/interrupt playback
NATURAL SOUND DVD PLAYER DVD–E600
STANDBY/ON
/ /
* Press button for about two seconds.
COAXIAL
– connect to DIGITAL INPUT of your AV reciver
S-VIDEO
– connect to S-Video input of your TV
SYSTEM CONNECTOR
– connect to the SYSTEM CONNECTOR
(DVD) of the RX-E600
AUDIO OUT (Left/Right)
– connect to AUDIO inputs of your
AV receiver or stereo system
COMPONENT VIDEO
– connect to component video inputs of your TV
AC Power Cord
– connect to the AC outlet of the RX-E600
OPTICAL
– connect to DIGITAL INPUT of your
AV receiver
AV
– connect to a TV with SCART
VIDEO
– connect to Video inputs
of your TV
SYSTEM
CONNECTOR
RECEIVER
COMPONENT VIDEO OUT AV
P
R
P
B
Y
S VIDEO
VIDEO OUT
VIDEO
DIGITAL
OUT
COAXIAL OPTICAL
E
AUDIO
OUT
L
R
Caution: Do not touch the inner pins of the jacks on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
Downloaded From Disc-Player.com Yamaha Manuals
3
Functional Overview
Remote Control
TOP MENU/RETURN
– display the top-level disc menu (DVD) / go back to previous menu (VCD)
MENU
– access menu of a disc (DVD) / switch PBC on/off (VCD)
1 2 3 4
– (left/right/up/down) select an item in the menu
ENTER/OK
– acknowledge menu selection
S
– search backward* / go to a previous chapter or track
STOP ( 9 )
– stop playback
PLAY ( B )
– start playback
PAUSE ( ; )
– pause playback temporarily / frame-by-frame playback
REPEAT
– repeat chapter, track, title, disc / shuffle chapter, track
A-B
– repeat a specific segment
SCAN
– preview the content of a track or whole disc (VCD) / play the first 6 seconds or less of each track (CD)
MUTE
– disable or enable sound output
1
4
7
TOP MENU RETURN
8
0
MENU
2
5
3
6
9
ON SCREEN
SETUP
ENTER
OK
STOP PLAY PAUSE
SUBTITLE ANGLE ZOOM AUDIO
REPEAT A B SCAN MUTE
DVD
– turn this unit ON or go to standby-on mode
0-9 numeric buttons
– select numbered items in a menu
ON SCREEN
– access or remove player’s
On Screen Display menu
SETUP
– access or remove player’s setup menu
T
– search forward* / next chapter or track
SUBTITLE
– subtitle language selector
ANGLE
– select DVD camera angle
ZOOM
– enlarge video image
AUDIO
– audio language and format selector
* Press and hold button for about two seconds.
Preparation
Please refer to the RX-E600 manual for instructions on connecting this unit to the RX-E600 receiver.
General Notes on connections
Never make or change connections with the power switched on.
● Depending on the equipment you wish to connect, there are various ways you could connect this unit. Possible connections are shown in the following drawings.
● Please refer to the manuals of other equipment as necessary to make the best connections.
● Do not connect this unit via your VCR. The video quality could be distorted by the copy protection system.
● Do not connect this unit’s audio out jack to the phono in jack of your audio system.
Digital Connections
This unit has COAXIAL and OPTICAL digital out jacks.
Connect one or both of them to your AV receiver equipped with Dolby digital or MPEG decoder using each specific cable (separate purchase).
S VIDEO
VIDEO OUT
VIDEO
DIGITAL
OUT
COAXIAL OPTICAL
E
AUDIO
OUT
L
R
C O
AV receiver
COAXIAL
IN
OPTICAL
IN
Analog Connections
Use audio/video cable supplied with this unit to connect
AUDIO OUT L (left) and R (right) jacks of this unit to corresponding input jacks of your audio equipment such as Stereo amplifier.
S VIDEO
VIDEO OUT
VIDEO
DIGITAL
OUT
COAXIAL OPTICAL
E
R
AUDIO
OUT
L
R
L
(supplied)
Stereo amplifier
Left speaker
Right speaker
R
1 CD/DVD
L
R L
Left main speaker
Center speaker
Right main speaker
Subwoofer
Left rear speaker
Right rear speaker
You will need to set this unit’s digital output to All (see
‘DIGITAL OUTPUT’).
Note:
– If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all. Make sure to select the appropriate audio format at menu screen included on the disc.
Pressing AUDIO once or more may change not only audio languages but also audio formats, and the selected format appears for several seconds on the status window.
5
Downloaded From Disc-Player.com Yamaha Manuals
Preparation
Video Connections
The player has three types of video output jacks. Use one of them in accordance with the input jacks of the equipment to be connected.
Note:
– If your AV receiver has video output jacks, connect your receiver (and then to your TV) so that you can use one TV for several different video sources (LD, VCR etc.) by simply switching the input source selector of your receiver.
COMPONENT VIDEO OUT AV
P
R
P
B
Y
S VIDEO
VIDEO OUT
VIDEO
DIGITAL
OUT
COAXIAL OPTICAL
E
AUDIO
OUT
L
R
(supplied)
<A>
S
V <B> <C>
<D>
S-Video terminal <A>
S (separate) video connection achieves a clearer picture than composite video connection by separating color and luminance when transmitting signals. Use commercially available S-video cable.
Composite Video terminal <B>
Use audio/video cable supplied with this unit when connecting the player to a TV.
Component Video terminal <C>
Component video connection achieves high fidelity in reproducing colors (better performance than S-video connection), separating video signal into luminance (Y, terminal color-coded as green), and color difference (Pb, blue/Pr, red). Use commercially available coaxial cables.
Receiver (and TV) with component input is required.
Observe the color of each jack when connecting.
SCART Connection <D>
Use a SCART cable to connect this unit’s AV terminal to a SCART terminal on your TV.
Note:
– Ensure that the “TV” indication on SCART cable is connected to the TV set and “DVD” indication on SCART cable is connected to this unit.
Preparation
Inserting batteries into the
Remote Control
1 Open the battery cover by pressing in the tab, then lift off the cover.
2 Insert batteries with the correct polarity as indicated by the + and - symbols inside the battery compartment.
3 Close the cover.
–
+
+
–
PAL/NTSC Conversion
This player is equipped with a PAL/NTSC conversion feature to convert the video output of the disc to match your TV system. The conversions supported are as below. To activate the conversion, refer to “TV TYPE”:
Type
DVD
VCD
Disc
Format
PAL
NTSC
PAL
NTSC
PAL
PAL
Output format
Selected mode
NTSC MULTI
NTSC PAL
PAL
PAL
NTSC
NTSC
NTSC
PAL
PAL NTSC NTSC
Notes:
– “MULTI” can only be selected when using a TV that has both the PAL and NTSC systems.
– Slight picture distortions may occur due to this conversion. This is normal. Thus, the “MULTI” is most suitable for the best picture quality.
CAUTION!
– Remove batteries if they are exhausted or not to be used for a long time.
– Do not use old and new or different types of batteries in combination.
– Batteries contain chemical substances, so they should be disposed off properly and kept away from children.
Using the Remote Control
● Direct the remote control at the remote sensor of the DVD player.
● Do not drop or give the remote control a shock.
● Do not leave the remote control in extremely hot or humid places.
● Do not spill water or put anything wet on the remote control.
Turning on the power
1 Connect the AC power cord to the power outlet.
2 Turn on the TV and your receiver.
3 Select the appropriate input source at the receiver that was used to connect to this unit. Refer to the equipment owner’s manual for detail.
4 Turn this unit on.
5 Set the TV to the correct Video IN channel. (eg. EXT1,
EXT2, AV1, AV2, AUDIO/VIDEO, etc. (Refer to your TV owner’s manual for detail)
➜ The front display lights up and the default screen appears on the TV.
Smart Power On/Off
When in STOP mode, the DVD player will switch to standby mode after 15 minutes without any operations for saving energy. It is easily reactivated by pressing the
POWER or PLAY on the remote control or the STANDBY/
ON button on the front panel.
7
Downloaded From Disc-Player.com Yamaha Manuals
Operation
Basic Playback
1 Press STANDBY/ON on the front panel to turn on the DVD player.
2 Press / (OPEN/CLOSE) on the front panel to open disc loading tray.
3 Place the chosen disc in the tray, with the label facing up.
4 Press / (OPEN/CLOSE) again to close the tray.
➜ After recognizing this disc, the player begin to playback automatically.
➜ If you press PLAY when the tray is open, this unit closes the tray and starts playback.
SEARCH DVD VCD CD SVCD
1 To search the contents in fast speed, press 2 or 1 for fast forward/backward searching.
2 Press 2 or 1 again to increase the speed for searching.
3 Press PLAY to return to normal playback.
Slow Motion
1 To get a slow motion effect during playback, press 3 or
4.
2 Press 3 or 4 again, you can get different playback forward/backward speeds.
3 Press PLAY to return to normal play back.
VCD SVCD
1 To get a slow motion effect during playback, press 4.
2 Press 4 again, you can get different playback forward speeds.
3 Press PLAY to return to normal play back.
Note: The SLOW BACKWARD function is not available for
VCD/Super VCD discs.
Notes:
– DVDs may have a region code. Your player will not play discs that have a region code different from the region code of your player.
– If ‘DISC LOCK’ is set to LOCK and the disc inserted is not authorized, the 6-digit code must be entered and/or the disc must be authorized (see ‘DISC LOCK’).
General Operation
Note: All instructions set out below refer to the remote control, unless otherwise stated.
Video control during playback
STOP DVD VCD CD SVCD
1 You can resume the play from the point at which you stopped last time, if you just press STOP once. It will start from the beginning if you press STOP twice to stop playback.
PAUSE/STEP DVD VCD CD SVCD
1 To get a still picture, press PAUSE during playback.
2 To step forward to the next frame picture, press PAUSE again.
➜ It resumes to the normal playback for CD.
3 To resume normal playback, press PLAY.
SKIP DVD VCD CD SVCD
1 Press !
1 or 2@ briefly during playback to go to the next chapter/track or to return to the beginning of the currect chapter/track respectively.
2 Press !
1 twice briefly to step back to the previous chapter/track.
3 To go directly to any chapter/track, enter the chapter/ track number using the numeric buttons and press
ENTER/OK.
Note: Long press of the !
1
or
2@
till switch on backward or forward search.
Audio control during playback
MUTE DVD VCD CD SVCD
1 Press MUTE to disable the sound output.
2 Press MUTE again to deactivate the mute.
Audio channel selection
VCD CD SVCD
1 Super VCD has two stereo audio channels which are used for playing karaoke or the audio language selection. (for instance, you can choose one channel for only the music background of the song while you play the karaoke.)
2 Press AUDIO to select the audio channels you want.
3 VCD has only one stereo audio channel, you can select
STEREO, MONO LEFT, MONO RIGHT or MIX-MONO by pressing AUDIO.
➜ STEREO: Output the left and right audio channels of the disc through the left and right audio jacks accordingly.
➜ MONO LEFT: Output the left audio channels of the disc through the left and right audio jacks.
➜ MONO RIGHT: Output the right audio channels of the disc through the left and right audio jacks.
➜ MIX-MONO: each of the audio jacks can output the same audio effect as stereo.
Operation
Repeat and Shuffle
● Each time you press REPEAT, the Repeat/Shuffle mode changes as follows;
Chapter Repeat* Title Repeat
Repeat/Shuffle Off Shuffle Repeat Shuffle
* This feature may not be available with some discs.
VCD CD
With PBC OFF,
● Each time you press REPEAT, the Repeat/Shuffle mode changes as follows;
Track Repeat
Repeat/Shuffle Off
Disc Repeat
Shuffle Repeat Shuffle
Repeat A-B
DVD VCD SVCD CD
DVD-Video Discs: repeat a sequence in a title
Video and Audio CDs: repeat a sequence in a track
1 Press Repeat A-B at your chosen starting point.
2 Press Repeat A-B again at your chosen end point.
➜ The repeat sequence begins.
3 To exit the sequence, press Repeat A-B.
Disc Resume
DVD VCD CD SVCD
This player can resume playback of the last 5 discs, even if the disc was ejected or the power switched off.
1 Load one disc, which is one of the last 5 discs.
2 Press PLAY when DVD player is recognizing the disc. If the information of this disc has been stored in the memory of DVD player, it will be played back from the stop point last time.
OSD (On-Screen Display)
This function will provide some information about your playing disc and a rough transferring speed of the video data on the screen.
● Press ON SCREEN.
The Status window appears on the TV.
Title/Chapter/Track selection DVD VCD
1 Press 34 to select “TITLE” or “CHAPTER” (DVD) or
“TRACK” (VCD).
2 Press ENTER/OK.
3 Select a title, chapter or track number using the numeric buttons.
Time Search DVD VCD
1 Press 34 to select “TT TIME” or “CH TIME”(DVD) or
“TRACK TIME” or “DISC TIME”(VCD).
➜ “TT TIME” refers to the total time of the current title, and the “CH TIME” refers to the total time of the current chapter.
2 Press ENTER/OK.
3 Enter hours, minutes and seconds from left to right using the numeric buttons. (e.g. 0:34:27)
Audio/Subtitle/Angle
You can change “AUDIO”, “SUBTITLE” or “ANGLE” if available on the disc you are playing.
1 Press 34 to select “AUDIO”, “SUBTITLE” or “ANGLE”.
2 Press ENTER/OK.
3 For Audio and Subtitle,
Press 34 to highlight your selection and press ENTER/
OK.
or
For Angle,
Select an angle using the numeric buttons.
Repeat/Time Display DVD VCD
1 Press 34 to select “REPEAT” or “TIME DISP.”.
2 Press ENTER/OK.
3 Press 34 to highlight your selection and press ENTER/
OK.
Time display
Each time you press ON SCREEN, the time display changes as follows;
Total Elapsed
Single Remain
Total Remain
Single Elapsed
9
Downloaded From Disc-Player.com Yamaha Manuals
Operation
Zoom
DVD VCD SVCD
The Zoom function allows you to change the image size.
1 Press ZOOM to activate the function.
➜ Use 341 2 to view other parts of the zoomed picture.
➜ Playback will continue.
➜ Zoom function is also effective when the playback is paused.
2 Press ZOOM repeatedly to return to the original size.
Special DVD Features
Playing a Title
A DVD disc may have one or more titles. This depends on the content (a movie, video clips, a drama series, etc.) on the disc.
● After you load a disc, information about the content shows on the screen waiting for your selection. You can also press TOP MENU to turn back to the title menu during playback.
➜ Press the appropriate numeric buttons or 341 2 to highlight your selection.
➜ Press ENTER/OK to confirm.
Playing a Chapter
When you have selected a title, it may include one or more chapters.
● Any time you want to watch another chapter during playback, press MENU to turn back to the chapter menu
(If disc has chapter menu).
➜ Press the appropriate numeric buttons or 341 2 on the remote control to highlight your selection.
➜ Press ENTER/OK.
➜ After a chapter has been selected, you also can press
¡!1 or 2@ to make a change.
Camera Angle
Some discs contain scenes which have been shot simultaneously from various angles.
This DVD player allows you to select the desired camera angle.
● Press ANGLE on your remote control.
Note: The function is available only for the DVD discs which have several angles recorded.
Changing the Audio Language and/or format
● Press AUDIO repeatedly to select the different languages.
Note: The function will be activated only if the DVD is recorded with multi-language audio tracks.
Subtitles
DVD SVCD
● Press SUBTITLE repeatedly to select the different subtitles.
Note: The function will be activated, only if the DVD or Super
VCD is recorded with multi-subtitles.
Special VCD & SVCD Features
Playback Control (PBC)
PBC function allows you to enter the index menu which is used to select a track after loading the VCD & SVCD disc.
If you want to activate the function during the playback or after pressing STOP twice,
1 Press MENU to set the PBC On.
➜ Pay attention to the hint on the screen.
2 Use !
1 or 2@ to select the page you like.
➜ If the items of the index menus are numbered, press the appropriate numeric buttons.
➜ Press ENTER/OK.
3 Press RETURN to enter the index menu during the playback.
Notes:
– The content of the index menu depends on the disc. Please refer to the disc’s instructions for details.
– If the disc doesn’t include the PBC information, this function will have no effect.
If you want to skip the index menu and playback directly from the beginning,
1 Press MENU to switch off the function.
Preview Function
● Press SCAN to enter previewing menu.
● Press 34 to highlight “TRACK DIGEST”, “DISC
INTERVAL” or “TRACK INTERVAL”.
● Press ENTER/OK to open one option.
SELECT DIGEST TYPE:
TRACK DIGEST
DISK INTERVAL
TRACK INTERVAL
Operation
2
DISC INTERVAL
This function is used to divide a disc into six parts by regular intervals and display them on one page to help you preview the whole disc.
● After you enter the menu of any digest type,
➜ To quit preview function: Press 341 2 to highlight
EXIT and press ENTER/OK.
➜ To return to the previewing menu for selecting the other digest type: Press 341 2 to highlight MENU and press ENTER/OK.
Note: You can select “TRACK INTERVAL” only during playback, with PBC Off.
1
TRACK DIGEST
This function will minimize the picture of every track in order to display every six of these tracks on the screen to help you know the content of every track on the disc.
- To choose the desired track, press 341 2 to highlight the second line and input your numerical selection next to
“SELECT” and press ENTER/OK.
- You can also select a track by highlighting the preview screen using 341 2 and pressing ENTER/OK.
3
TRACK INTERVAL
This function is used to divide a single track into six parts by regular intervals and display them on one page to help you preview the selected track.
- To choose the desired track, press 341 2 to highlight the second line and input your selected track number next to
“SELECT”.
➜ Select the others from the current six by pressing the
!
1 or 2@ to open the previous or next page and press
ENTER/OK.
- You can also select a track by highlighting the preview screen using 341 2 and pressing ENTER/OK.
- To choose the desired track, please press 341 2 to highlight the second line and input your numerical selection next to “SELECT” and press ENTER/OK.
- You can also select a track by highlighting the preview screen using 341 2 and pressing ENTER/OK.
11
Downloaded From Disc-Player.com Yamaha Manuals
Picture CD & MP3 Playback
This player can playback JPEG format pictures and MP3 files on a personally recorded CD-R/RW disc or commercial CD, and is compatible with Kodak Picture
CD. This player does not support PROGRESSIVE JPEG.
● Playback pictures or songs one by one automatically.
● Album and track selection.
● Repeat (disc / album / track / picture).
● Select any music or pictures from the disc to playback them together.
● Maximum numbers of files in one folder are 500.
● Maximum number of folders in one layer are 500.
● Maximum nested directory is eight levels.
● Maximum 13 characters are supported.
● The file names, MP3, JPG, JPE, and JPEG, are supported.
● Maximum files Programmable is 100.
MP3 & JPEG Navigator
To select a different playback method, follow the steps below.
1 At STOP mode, press SETUP to open the setup menu.
2 Press 1 2 to highlight PREFERENCE icon.
3 Press 4 to open the PREFERENCE menu.
4 Press 34 to highlight the MP3/JPEG NAV menu.
5 Press 2 to enter the menu.
6 Press 34 to highlight the WITHOUT MENU or WITH
MENU item.
➜ WITHOUT MENU: automatically playback all files in according date sequence (MP3 only).
➜ WITH MENU: playback files in the selected folder.
7 Press ENTER/OK to confirm your selection.
General Operation
● If you choose WITH MENU in the Setup Menu (Please refer to the MP3 & JPEG navigator below), the Picture
CD/MP3 CD menu will be shown on the screen before playback.
● At any time during JPEG playback, press MENU to return to the menu.
● To open the selected folder, press ENTER/OK.
● The menu shows six files or folders at a time. To move to the next (or previous) page, press 2@ (or !1 ).
● You cannot record the MP3 audio output from digital audio output jacks.
Play Mode
Auto Playback
If you choose WITHOUT MENU, the DVD player will automatically play MP3 CD in sequence when it is loaded.
Repeat / Shuffle
● When the Picture CD/MP3 CD menu is shown on the screen, Press REPEAT repeatedly, the button beside
PLAY MODE will display different option,
➜ Repeat One: One file will be replayed time after time.
➜ Repeat Folder: All files in this folder will be replayed time after time.
➜ Shuffle: All files in this folder will be played at random without any repeat.
➜ Folder: All files in this folder will be played.
● If you press REPEAT during playback, the option will be displayed on the screen accordingly.
● During Shuffle mode, you can skip tracks by pressing !1 or 2@.
Picture CD & MP3 Playback
Special JPEG Features
Function Introduction
Picture CD is a disc with a collection of JPEG format pictures, and all extension filenames should end with
‘.JPG’. The CD can be recorded on any computer, and pictures may be from digital camera or scanner. If the customers prefer, they can make this CD become a
Digital Album.
You can choose any general function introduced in
General Operation, besides, you also can,
● Display the thumbnails of 12 pictures.
● Zoom the picture.
● Rotate the picture.
● Flip the picture vertically or horizontally.
● Scan pictures by different effects.
Playback with multi-angles
When displaying one picture on TV screen
● Press 341 2 to get different effects.
3: Flip the picture vertically.
4: Flip the picture horizontally.
1: rotate the picture anti-clockwise.
2: rotate the picture clockwise.
Wipe Effect
● Press ANGLE repeatedly to choose different wipe effects.
Preview Function
This function shows the content of the current folder or the whole disc.
1 Press STOP during playback of JPEG pictures. You will see the thumbnails of 12 pictures on the screen.
Special MP3 Features
Function Introduction
“MP3” stands for “MPEG Audio Layer-3”. and is a part of the MPEG standard. A CD can store up to 10 hours of
MP3 audio, which is nearly 10 times as much as an Audio
CD. Each song is recorded as a file. You can choose any general function introduced in General Operation. You can also choose different playback speeds.
2 Press !
1 or 2@ to display the other pictures on the next or the previous page.
3 Press 341 2 to highlight one of them and press ENTER/
OK to playback, or,
Move the cursor to highlight on the bottom of the page to start playback from the first picture on the current page.
4 Press MENU to go to the Picture CD/MP3 CD menu.
JPEG and MP3 simultaneous playback
1 Firstly playback MP3 music according to the instructions introduced in playback Selection.
2 Then select a picture to playback. Refer to the instructions introduced in playback Selection.
➜ Now the pictures will be played back in sequence together with MP3 music.
3 To quit simultaneous playback, press MENU to return to the Picture CD/MP3 CD menu, then pictures will be stopped. After that, press STOP, then MP3 music will be stopped as well.
Note: In the function of JPEG and MP3 Simultaneous
Playback, !
1
and
2@
are invalid for MP3.
Zoom picture
● During playback or pause, press ZOOM to display the picture with different scales.
● Press 341 2 to view the rest of the zoomed picture.
13
Downloaded From Disc-Player.com Yamaha Manuals
Setup Menu
Basic Operation
1 Press SETUP in the STOP mode to enter the Setup Menu.
2 Press ENTER/OK to go to the next level submenu or confirm your selection.
3 Press 1 2 to enter the submenu or return to the previous menu.
4 Press 34 to highlight the desired menu.
5 Press SETUP to quit the setup menu.
➜ When you quit the setup menu, the settings will be stored in the player’s memory even if the player is switched to power off.
PROGRAM (not for Picture CD/MP3)
1 press 34 to choose “PROGRAM”.
2 Press 2 to move the cursor to the field of the submenu to choose the item Input menu.
➜ Input menu: Enter the Program item.
3 Press ENTER/OK to enter the program page.
General Setup menu
Some settings need to be made in this menu. They are:
“DISC LOCK”, “PROGRAM”, “OSD LANGUAGE” and
“SCREEN SAVER”.
Follow the steps below:
GENERAL SETUP PAGE
DISK LOCK
PROGRAM
OSD LANGUAGE
SCREEN SAVER
1 Press SETUP to enter the setup menu.
2 Press 1 2 to choose the GENERAL SETUP icon .
DISC LOCK
When the disc is locked, the player will store its specific code into the memory for future identification. For the next playback, the DVD player will prompt you to enter the password. Then, press ENTER/OK to load the disc.
1 Press 34 to highlight “DISC LOCK”.
2 Enter its submenu by pressing 2.
➜ Lock: Lock the disc being played.
➜ Unlock: unlock the disc.
3 Press 1 to return to the General Setup Page.
Input your favorite track
1 Input valid track number by pressing the numeric buttons.
2 Press 341 2 to move the cursor to the next selected position.
➜ If the track number is more than ten, press 2@ to open the next page and go on programing, or press 341 2 to highlight NEXT button, and then press ENTER/OK.
3 Repeat this steps to input another track number until the whole program is completed.
Remove a track
1 Press 341 2 to move the cursor to the track you want to remove.
2 Press ENTER/OK or PLAY to remove this track from the program menu.
Playback tracks
When programing is completed,
1 Press 341 2 to move the cursor to the START button.
2 Press ENTER/OK.
➜ DVD player will playback the selected tracks under the programed sequence.
Quit the program playback
In the Program menu,
1 Press 341 2 to move the cursor to the EXIT button.
2 Press ENTER/OK to quit this menu.
Stop the program playback
● During playback of the programmed tracks, press STOP once. Then after you press PLAY, the DVD player will start resume-playback.
● Press STOP twice to cancel the resume-function.
Repeat the program playback
● During playback of the programmed tracks, press
REPEAT. The programed tracks can be played again.
Note: If you select Shuffle mode by pressing REPEAT several times, the DVD player cancels program playback.
Setup Menu
OSD LANGUAGE
This option is to select a language for information displayed on TV screen.
1 Press 34 to highlight “OSD LANGUAGE” in the General
Setup menu.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected language.
4 Press ENTER/OK to confirm.
5 Press 1 to return to the General Setup Page.
Audio Setup menu
There are items included in Audio Setup Page such as
“SPEAKER SETUP”, “DIGITAL AUDIO SETUP”,
“EQUALIZER” and “3D”.
AUDIO SETUP PAGE
SPEAKER SETUP
DIGITAL AUDIO SETUP
EQUALIZER
3D
SCREEN SAVER
This function is used to turn the screen saver on or off.
1 Press 34 to highlight “SCREEN SAVER” in the General
Setup menu.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected item.
➜ On: In STOP or No DISC mode, if no actions are performed within 5~6 minutes, the screen saver will be activated.
➜ Off: Screen saver is disabled.
4 Press ENTER/OK.
5 Press 1 to return to the General Setup Page.
1 Press SETUP to enter the setup menu.
2 Press 1 2 to choose the AUDIO SETUP icon .
SPEAKER SETUP
This menu contains setup options for your analog audio output, such as “DOWNMIX”, “DRC” (Dynamic Range
Compression) etc. which makes the setup system reproduce high quality surround sound.
DOWNMIX
1 Press 34 to highlight the “DOWNMIX”.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected item.
● LT/RT
➜ This option should be used only if your DVD player is connected to a Dolby Prologic decoder.
● STEREO
➜ This option will downmix Dolby Digital signals directly into analogue stereo from L/R jacks.
● VIRTUAL SURROUND
➜ This option will reproduce the surround channels virtually.
4 Press ENTER/OK.
5 Press 1 to return to the Audio Setup Page.
DRC (Dynamic Range Compression)
The DVD player will compress the dynamic range of its sound output for late-night listening.
1 Press 34 to highlight “DRC”.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected item.
➜ ON: Enable DRC.
➜ OFF: Disable DRC.
4 Press ENTER/OK.
5 Press 1 to return to the Audio Setup Page.
15
Downloaded From Disc-Player.com Yamaha Manuals
Setup Menu
DIGITAL AUDIO SETUP
In this menu, you can set up the digital audio output signal from the digital jacks, such as coaxial etc.
DIGITAL OUTPUT
1 Press 34 to highlight DIGITAL OUTPUT.
2 Enter its submenu by pressing 2.
3 Press 34 to highlight the selected item.
➜ All: Original digital signals output.
➜ PCM Only: If your receiver is PCM-compatible, or your receiver can not decode MPEG-2 or Dolby Digital, choose this option.
4 Press ENTER/OK.
5 Press 1 and return to the Audio Setup Page.
Note: If DIGITAL OUTPUT is set to “ALL”, all audio settings except MUTE are invalid.
LPCM OUTPUT
In this menu, you can select PCM digital output between
48kHz and 96kHz.
1 Press 34 to highlight the “LPCM OUTPUT”.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected item.
➜ 48K: 96kHz (if available on disc) PCM data stream will be converted to 48kHz.
➜ 96K: If the 96kHz disc is copy protected, the digital output will be muted to comply with the standards.
4 Press ENTER/OK.
5 Press 1 to return to the Audio Setup Page.
EQUALIZER (Sound Mode)
The “EQUALIZER” allows you to select from various preset modes that control the frequency bands of sound to optimize certain musical styles.
It greatly enhances the excitement and enjoyment of your favourite music.
1 Press 34 to highlight the “EQUALIZER”.
2 Enter its submenu “SOUND MODE” by pressing 2.
3 Press 2.
4 Move the cursor by pressing 34 to highlight the selected item.
➜ NONE: Play the disc under the original sound effect.
5 Press ENTER/OK.
6 Press 1 to return to the Audio Setup Page.
Note: The sound may be distorted if the selected sound mode is incompatible with the disc contents.
In that case, select another sound mode or “NONE”.
3D (REVERB MODE)
The “3D” can simulate the echoes and frequency response of some particular places so as to make you feel like personally on the place. The choices are OFF,
CONCERT, LIVING ROOM, HALL, ARENA, and
CHURCH.
1 Press 34 to highlight the “3D”.
2 Enter its submenu “REVERB MODE” by pressing 2.
3 Press 2.
4 Move the cursor by pressing 34 to highlight the selected item.
➜ OFF: Play the disc under the original sound effect.
5 Press ENTER/OK.
6 Press 1 to return to the Audio Setup Page.
Setup Menu
Video Setup menu
There are items included in Video Setup menu such as
“TV TYPE”, “TV DISPLAY”, “CLOSED CAPTION”,
“COMPONENT”, “PROGRESSIVE” and “PICTURE
SETTING”.
VIDEO SETUP PAGE
TV TYPE
TV DISPLAY
CLOSED CAPTIONS
COMPONENT
PROGRESSIVE
PICTURE SETTING
TV DISPLAY
4:3
PANSCAN
4:3
LETTERBOX
16:9
1 Press SETUP to enter the setup menu.
2 Press 1 2 to choose the VIDEO SETUP icon .
TV TYPE
Before viewing the DVD or VCD, ensure that the PAL or
NTSC setting of the system matches your TV set.
1 Press 34 to highlight “TV TYPE” in the Video Setup menu.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight one option.
4 Press ENTER/OK.
5 Press 1 to return to the Video Setup Page.
Note: Choosing “NTSC” item indicates that the player will output NTSC signals, Similarly, you can get PAL signals by choosing the “PAL” option. The option “MULTI” means video output depends on the format of the DVD or VCD discs.
Select the aspect ratio of the TV to be connected.
4:3 PANSCAN
➜ when you connect a normal TV to the
DVD player. Displays the wide picture on the whole TV screen with a portion automatically cut off.
4:3 LETTERBOX
➜ when you connect a normal TV to the
DVD player. Displays a wide picture with bands displayed on the upper and lower portions of the TV screen.
16:9
➜ when you connect a wide-screen TV to the DVD player.
Setup the item as follows,
1 Press 34 to highlight the “TV DISPLAY” option in the
Video Setup menu.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight the selected item.
4 Press ENTER/OK.
5 Press 1 to return to the Video Setup Page.
Downloaded From Disc-Player.com Yamaha Manuals
17
Setup Menu
CLOSED CAPTION
Closed Captions are data that are hidden in the video signal on specific discs, invisible without a special decoder. The difference between subtitles and captions is that subtitles are intended for hearing persons and captions are for the hearing impaired. Subtitles rarely show all of the audio. For example, captions show sound effects (e.g., “phone ringing” and “footsteps”), while subtitles don’t.
Before you select this function, please ensure that the disc contains closed captions information and your TV set also has this function.
1 Press 34 to highlight “CLOSED CAPTION” in the Video
Setup menu.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight one option.
➜ ON: Enable Closed Caption.
➜ OFF: Disable Closed Caption.
4 Press ENTER/OK.
5 Press 1 to return to the Video Setup Page.
COMPONENT
In this menu, you can select whether to output YUV signals from the COMPONENT jacks or to output RGB signals from the AV jack (SCART).
1 Press 34 to highlight “COMPONENT”.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight one option.
➜ YUV: Output YUV signals from the COMPONENT jacks.
➜ RGB: Output RGB signals from the AV jack (SCART).
4 Press ENTER/OK.
5 Press 1 to return to the Video Setup Page.
PROGRESSIVE
This player’s COMPONENT video jack can output progressive signals to a progressive signal compatible
TV for an extra high-quality picture.
1 Press 34 to highlight “PROGRESSIVE”.
2 Enter its submenu by pressing 2.
3 Move the cursor by pressing 34 to highlight one option.
➜ ON: Enable Progressive.
➜ OFF: Disable Progressive.
If you select “ON”, the player prompt you to comfirm your selection.
4 Press ENTER/OK.
5 Press 1 to return to the Video Setup Page.
Notes on activating Progressive:
● Ensure that your TV has progressive scan.
● Connect with YPbPr video cable.
● When the Progressive is active, the VIDEO (CVBS) and S
VIDEO jacks do not output video signals.
● If there is no picture, wait 15 seconds for auto recover or disactivate Progressive manually.
1 Open the disc tray by pressing / (OPEN/CLOSE)on the front panel.
2 Press 1.
3 Press MUTE.
● You cannot activate Progressive when “COMPONENT” is set to “RGB”.
CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE
WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE
DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625
PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE CONNECTION
TO THE “STANDARD DEFINITION” OUTPUT. IF THERE ARE
QUESTIONS REGARDING OUR VIDEO MONITOR
COMPATIBILITY WITH THIS MODEL 525P AND 625P DVD
PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE
CENTER.
This unit is compatible with the complete line of YAMAHA products, including the projectors DPX-1000, LPX-510 and the plasma monitor PDM-4210E.
Setup Menu
PICTURE SETTING
In this menu, you can personalize your picture color by adjusting brightness, contrast, tint and color (saturation).
1 Press 34 to highlight “PICTURE SETTING” in the Video
Setup menu.
2 Press 2 to open its submenu.
BRIGHTNESS
1 Press 34 to highlight “BRIGHTNESS”.
2 Press 2 to open the level bar.
PASSWORD SETUP
This item is used for the parental control and disc lock.
Enter your six digit password when a hint is displayed on the screen.
PASSWORD SETUP PAGE
PASSWORD
BRIGHTNESS - 1
3 Press 1 2 to increase and decrease the brightness level.
4 Press ENTER/OK to return to the PICTURE SETTING menu.
CONTRAST
1 Press 34 to highlight “CONTRAST”.
2 Press 2 to open the level bar.
3 Press 1 2 to increase and decrease the contrast level.
4 Press ENTER/OK to return to the PICTURE SETTING menu.
TINT
1 Press 34 to highlight “TINT”.
2 Press 2 to open the level bar.
3 Press 1 2 to increase and decrease the tint level.
4 Press ENTER/OK to return to the PICTURE SETTING menu.
COLOR (saturation)
1 Press 34 to highlight “COLOR”.
2 Press 2 to open the level bar.
3 Press 1 2 to increase and decrease the color level.
4 Press ENTER/OK to return to the PICTURE SETTING menu.
1 Press SETUP to enter the setup menu.
2 Press 1 2 to choose the PASSWORD icon .
3 Press 4 to highlight “PASSWORD”.
4 Press 2 to highlight “CHANGE”.
5 Press ENTER/OK to open the Password Change Page.
OLD PASSWORD
NEW PASSWORD
CONFIRM PWD
6 Press 4 to repeatedly until the player prompt you to enter the old password.
7 Enter the current 6 digit code.
8 If successful, the player will prompt for a new one.
9 After that, enter the new password again to reconfirm.
10 Press ENTER/OK to return to the Password Setup Page.
Notes:
– You can change the setup of parental control and load a locked disc with a valid password being entered.
– If you forget your password, you can enter the default password 842100, then you can input your password after logging on.
Downloaded From Disc-Player.com Yamaha Manuals
19
