Yamaha YST-SW45 Owner`s manual

UCA
YST-SW45
Active Servo Processing Subwoofer System
Caisson de grave avec asservissement actif
OWNER’S MANUAL
MODE D’EMPLOI
SAFETY INSTRUCTIONS
9
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Heat – The unit should be situated away from heat
sources such as radiators, stoves, or other appliances
that produce heat.
10 Power Sources – The unit should be connected to a
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
power supply only of the type described in the operating
instructions or as marked on the unit.
11 Power-Cord Protection – Power-supply cords should be
• Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert you to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the unit.
12 Cleaning – The unit should be cleaned only as
recommended by the manufacturer.
13 Nonuse Periods – The power cord of the unit should be
The exclamation point within an equilateral triangle
is intended to alert you to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
1
2
Read Instructions – All the safety and operating
instructions should be read before the unit is operated.
unplugged from the outlet when left unused for a long
period of time.
14 Object and Liquid Entry – Care should be taken so that
objects do not fall into and liquids are not spilled into the
inside of the unit.
15 Damage Requiring Service – The unit should be serviced
by qualified service personnel when:
Retain Instructions – The safety and operating
instructions should be retained for future reference.
A. The power-supply cord or the plug has been
3
Heed Warnings – All warnings on the unit and in the
operating instructions should be adhered to.
B. Objects have fallen, or liquid has been spilled into the
4
Follow Instructions – All operating and other instructions
should be followed.
5
Water and Moisture – The unit should not be used near
water – for example, near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming
pool, etc.
damaged; or
unit; or
C. The unit has been exposed to rain; or
D. The unit does not appear to operate normally or
exhibits a marked change in performance; or
6
Carts and Stands – The unit should be used only with a
cart or stand that is recommended by
the manufacturer.
6A A unit and cart combination should be
moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the unit and cart
combination to overturn.
7
Wall or Ceiling Mounting – The unit should be mounted to
a wall or ceiling only as recommended by the
manufacturer.
8
Ventilation – The unit should be situated so that its
location or position does not interfere with its proper
ventilation. For example, the unit should not be situated
on a bed, sofa, rug, or similar surface, that may block the
ventilation openings; or placed in a built-in installation,
such as a bookcase or cabinet that may impede the flow
of air through the ventilation openings.
2
E. The unit has been dropped, or the cabinet damaged.
16 Servicing – The user should not attempt to service the
unit beyond those means described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
17 Power Lines – An outdoor antenna should be located
away from power lines.
18 Grounding or Polarization – Precautions should be taken
so that the grounding or polarization is not defeated.
English
FCC INFORMATION
1. IMPORTANT NOTICE : DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC,
to use the product.
2. IMPORTANT : When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable/s supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3. NOTE : This product has been tested and found to
comply with the requirements listed in FCC
Regulations, Part 15 for Class “B” digital devices.
Compliance with these requirements provides a
reasonable level of assurance that your use of this
product in a residential environment will not result in
harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and,
if not installed and used according to the instructions
found in the users manual, may cause interference
harmful to the operation of other electronic devices.
Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product
is found to be the source of interference, which can be
determined by turning the unit “OFF” and “ON”, please try
to eliminate the problem by using one of the following
measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead,
change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory
results, please contact the local retailer authorized to
distribute this type of product. If you can not locate the
appropriate retailer, please contact Yamaha Electronics
Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA
90620.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
We Want You Listening For A Lifetime
YAMAHA and the Electronic Industries Association’s
Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the
sound come through loud and clear without annoying blaring
or distortion – and, most importantly, without affecting your
sensitive hearing.
Since hearing damage from loud sounds is often
undetectable until it is too late, YAMAHA and the
Electronic Industries Association’s Consumer
Electronics Group recommend you to avoid
prolonged exposure from excessive volume levels.
3
Thank you for selecting this YAMAHA subwoofer system.
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
1. To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2. Install this unit in a cool, dry, clean place, away from
windows, heat sources, sources of excessive vibration,
dust, moisture and cold. Avoid sources of humming
(transformers, motors). To prevent fire or electrical shock,
do not expose the unit to rain or water.
3. Never open the cabinet. If something drops into the set,
contact your dealer.
4. Do not use force on switches, controls or connection wires.
When moving the unit, first disconnect the power plug and
the wires connected to other equipment. Never pull the
wire itself.
5. Do not attempt to clean the unit with chemical solvents;
this might damage the finish. Use a clean, dry cloth.
6. Be sure to read the “TROUBLESHOOTING” section
regarding common operating errors before concluding that
the unit is faulty.
7. When not planning to use this unit for long periods of time
(i.e., vacation, etc.), disconnect the AC power plug from
the wall outlet.
8. To prevent lightning damage, disconnect the AC power
plug when there is an electrical storm.
9. Since this unit has a built-in power amplifier, heat will
radiate from the rear panel. Therefore, place the unit apart
from the walls, allowing enough space above, behind and
on the both sides of the unit to prevent fire and damage.
Also, do not position with the rear panel facing down on
the floor or other surface.
<For U.K. and Europe models only >
Be sure to allow a space of at least 20 cm above, behind
and on the both sides of the unit.
10. Super-bass frequencies reproduced by this unit may cause
a turntable to generate a howling sound. In such a case,
move this unit away from the turntable.
11. Vibration generated by super-bass frequencies may cause
images on a TV to be distorted. In such a case, move this
unit away from the TV set.
12. This unit features a magnetically shielded design, but there
is still a chance that placing it too close to a TV set might
impair picture color. Should this happen, move this unit
away from the TV set.
13. If you hear distortion (i.e., unnatural, intermittent “rapping”
or “hammering” sounds) coming from this unit, reduce the
volume level. Extremely loud playing of a movie
soundtrack’s low frequency, bass-heavy sounds or
similarly loud popular music passages can damage this
speaker system.
14. Voltage Selector (General and China Models only)
The voltage selector on the rear panel of this unit must
be set for your local main voltage BEFORE plugging
into the AC main supply.
Voltages are AC 110/120/220/240V, 50/60 Hz.
4
15. Secure placement or installation is the owner’s
responsibility.
YAMAHA shall not be liable for any accident caused
by improper placement or installation of speakers.
IMPORTANT
Please record the serial number of this unit in the space
below.
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
FOR CANADIAN CUSTOMERS
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT AND FULLY INSERT.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH
CANADIAN ICES-003.
For U.K. customers
If the socket outlets in the home are not suitable for the plug
supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the
instructions described below.
Note: The plug severed from the mains lead must be
destroyed, as a plug with bared flexible cord is hazardous if
engaged in a live socket outlet.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT
THE WIRES IN THE MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
Blue: NEUTRAL
Brown: LIVE
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter N or coloured
BLACK. The wire which is coloured BROWN must be
connected to the terminal which is marked with the letter L or
coloured RED. Making sure that neither core is connected to
the earth terminal of the three pin plug.
Caution ....................................................................... 4
Features ..................................................................... 5
Placement .................................................................. 5
Connections ............................................................... 6
Controls and their functions ....................................... 9
English
CONTENTS
Adjusting volume ...................................................... 10
Advanced YAMAHA Active Servo Technology ......... 12
Troubleshooting ....................................................... 13
Specifications ........................................................... 13
FEATURES
• This subwoofer system employs Advanced YAMAHA Active
Servo Technology which YAMAHA has developed for
reproducing higher quality super-bass sound. (Refer to page
12 for details on Advanced YAMAHA Active Servo Technology.) This super-bass sound adds a more realistic, theaterin-the-home effect to your stereo system.
• This unit can be added easily to your existing audio system
by connecting to either the speaker terminals or the line
output (pin jack) terminals of the amplifier.
• For the effective use of this unit, this unit’s super-bass
sound must be matched to the sounds of your main speakers. You can create the best sound quality for various
listening conditions by using the HIGH CUT control.
• The Automatic Standby function saves you the trouble of
pressing the STANDBY/ON button to turn the power on and
off.
PLACEMENT
ı
Å
(
: subwoofer,
Ç
: main speaker)
One subwoofer will have a good effect on your audio system,
however, the use of two subwoofers is recommended to obtain
more presence.
Use the rubber pads
Put the provided rubber pads at the four corners on the bottom
of the subwoofer unit to prevent the subwoofer unit moving due
to vibrations etc.
If using one subwoofer, it is recommended to place it on the
outside of either the right or the left main speaker. (See fig. Å.)
If using two subwoofers, it is recommended to place them on
the outside of each main speaker. (See fig. ı.) The placement
shown in fig. Ç is also possible, however, if the subwoofer
system is placed directly facing the wall, the bass effect may
die because the sound from it and the sound reflected by the
wall may cancel. To prevent this, face the subwoofer system
obliquely to the wall as in fig. Å or ı.
Note
There may be a case that you cannot obtain enough superbass sounds from this unit when listening at the middle of the
room. This is because “standing waves” have developed
between two parallel walls and the bass sounds are canceled.
In such a case, face the unit obliquely to the wall. It also may
be necessary to break up the parallel surfaces by placing
bookshelves etc. along the walls.
5
CONNECTIONS
Never plug in the subwoofer and other audio/video components until all connections are completed.
• When making connections between this unit and other components, be sure all connections are made firmly and correctly; L (left)
to L, R (right) to R, + to + and – to –.
• This unit can be connected to either the speaker terminals or the line output (pin jack) terminals of the amplifier. Choose one of
the connections shown below according to your audio system. Refer also to the owner’s manuals supplied for your audio system.
CONNECTING TO SPEAKER TERMINALS OF THE AMPLIFIER
Using one unit
When your amplifier has one set of speaker terminals
• Disconnect your main speakers from the amplifier if connected, and connect them
to the speaker terminals of this unit.
Right speaker
OUTPUT
TO SPEAKERS
INPUT2
Left speaker
AUTO
STANDBY
LOW HIGH
This unit
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
OFF
FROM AMPLIFIER
INPUT1
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
Amplifier
POWER
ON
OFF
To AC outlet
Speaker terminals
When your amplifier has two sets of speaker terminals
This unit
OUTPUT
TO SPEAKERS
INPUT2
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
AUTO
STANDBY
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
POWER
ON
OFF
Left speaker
Right speaker
To AC outlet
Amplifier
Speaker terminals
A
B
(Both A and B speaker outputs
must be ON.)
6
English
Using two units
Disconnect your main speakers from the amplifier if connected, and connect them to the speaker terminals of this unit.
Right speaker
Left speaker
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
This unit
This unit
LOW HIGH
LOW HIGH
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
OFF
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
FROM AMPLIFIER
INPUT1
LOW HIGH
OFF
OFF
FROM AMPLIFIER
INPUT1
FROM AMPLIFIER
INPUT1
Amplifier
POWER
POWER
ON
ON
OFF
OFF
To AC outlet
To AC outlet
Speaker terminals
Connecting to this unit’s OUTPUT/INPUT terminals
For connections, keep the speaker wires as short as possible.
(Cut the excessive wire, if necessary.) If the connections are faulty,
no sound will be heard from the speakers. Make sure that the
polarity of the speaker wires is correct, by observing + and –
markings. If these wires are reversed, the sound will be unnatural
and will lack bass.
Do not let the core of the speaker wires touch each other
and do not let them touch the metal parts of this unit as this
could damage this unit, your amplifier and/or speakers.
* Banana Plug connections are also possible (except for U.K.
and Europe models). Simply insert the Banana Plug connector into the corresponding terminal.
How to Connect:
Red: positive (+)
Black: negative (–)
1 Unscrew the knob.
2 Insert the core of the
wire. [Remove
approx. 5 mm (1/4”)
insulation from the
speaker wires.]
3 Tighten the knob to
secure the wire firmly.
7
CONNECTING TO LINE OUTPUT (PIN JACK) TERMINALS OF THE AMPLIFIER
• Connect the main speakers to the speaker output terminals of the amplifier.
• Amplifier line output terminals are generally labeled PRE OUT or SUBWOOFER OUT.
• To connect with a YAMAHA DSP amplifier, connect the SUBWOOFER (or LOW PASS etc.) terminal on the rear of the DSP
amplifier to either the left (L) or right (R) INPUT 2 terminal.
Using one unit
Left speaker
This unit
Right speaker
OUTPUT
TO SPEAKERS
OUTPUT
TO SPEAKERS
INPUT2
INPUT2
AUTO
STANDBY
AUTO
STANDBY
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
POWER
ON
OFF
To AC outlet
‹YAMAHA DSP amplifier›
Pin plug
cords
SUBWOOFER
Amplifier
‹Amplifier›
PRE OUT
Using two units
Right speaker
Left speaker
OUTPUT
TO SPEAKERS
INPUT2
OUTPUT
TO SPEAKERS
AUTO
STANDBY
INPUT2
LOW HIGH
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
This unit
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
OFF
FROM AMPLIFIER
INPUT1
Pin plug
cords
This unit
AUTO
STANDBY
OUTPUT
TO SPEAKERS
INPUT2
AUTO
STANDBY
LOW HIGH
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
OFF
FROM AMPLIFIER
INPUT1
Amplifier
POWER
POWER
ON
ON
OFF
OFF
To AC outlet
To AC outlet
Notes on the above connections
• When connected to line output terminals of the amplifier, other speakers should not be connected to the OUTPUT terminals on
the rear panel of the subwoofer. If connected, they will not produce sound.
• When connecting this unit to a monaural line output terminal of the amplifier, connect to either the left or right INPUT 2 terminal.
• For using a power amplifier and a preamplifier, the preamplifier must have two sets of PRE OUT terminals. If your preamplifier
has only one set of PRE OUT, connect this unit to the speaker terminals. (See page 6.)
8
English
CONTROLS AND THEIR FUNCTIONS
Front panel
STANDBY/ON
HIGH CUT
40 Hz
140 Hz
VOLUME
0
10
STANDBY/ON
HIGH CUT
50 Hz
~
Ÿ
150 Hz
!
VOLUME
0
10
⁄
Rear panel
OUTPUT
TO SPEAKERS
POWER
OUTPUT
TO SPEAKERS
INPUT2
ON
INPUT2
AUTO
STANDBY
AUTO
STANDBY
LOW HIGH
OFF
FROM AMPLIFIER
INPUT1
OFF
LOW HIGH
@
POWER
ON
OFF
OFF
FROM AMPLIFIER
INPUT1
¤
~ Power indicator
Lights up while this unit is ON.
* If the AUTO STANDBY switch on the rear panel is set
to the LOW or HIGH position, this indicator is illuminated dimly when no signal is input to this unit.
Ÿ STANDBY/ON button
Each press of this button turns the unit on and off (on
standby). A small amount of power is always consumed
even while this unit is on standby.
! HIGH CUT control
Adjusts the high frequency cut off point.
Frequencies higher than the frequency selected with this
control are all cut off (and not output).
⁄ VOLUME control
Adjusts the volume level.
@ Main POWER switch
Normally, leave this switch to the ON position. When you
will not use this unit for a long period, set this switch to the
OFF position.
Automatic Standby function
When you play a source, the power of this unit turns on
automatically by sensing audio signals input to this unit. This
unit turns into the standby mode automatically if the source
being played is stopped or the low frequency input signal is
cut off for several minutes.
This function will operate by sensing a certain level of low
frequency input signal. Its sensitivity is high in the HIGH
position and low in the LOW position of the AUTO STANDBY
switch. In the HIGH position, the power will turn on even with
a low level of input signal, but on the other hand this unit may
not turn into the standby mode when there is an input signal
even if its level is extremely low.
* There may be a case that the power turns on unexpectedly
by sensing noise from other appliances. If it occurs, set the
AUTO STANDBY switch to the OFF or LOW position.
* The level of low frequency input signal differs with each
source, and each different part on the same source. So,
this function may not operate properly depending on some
sources.
This function is available only when the power of this
unit is on (by setting the STANDBY/ON button Ÿ to ON).
¤ AUTO STANDBY switch
With this switch, you can activate the Automatic Standby
function. Normally, set the switch to the LOW position.
To cancel this function, set the switch to the OFF position.
* Change the setting of this switch only when the power of
this unit is on standby (by setting the STANDBY/ON
button to OFF).
9
ADJUSTING VOLUME
Adjustment of the HIGH CUT control and the VOLUME control needs to be changed according to the main speakers, listening
condition, source, etc.
Front panel
STANDBY/ON
HIGH CUT
50 Hz
3
1
2
3
4
5
VOLUME
150 Hz
5
0
10
1,6
Set the VOLUME control to minimum (0).
Turn on the other components.
Press the STANDBY/ON button to turn on this unit.
Play any source and adjust the amplifier’s volume control to the desired listening level.
Adjust the HIGH CUT control according to the main speakers connected.
Normally, set the control to the main speaker’s rated minimum reproducible frequency*. If the desired response
cannot be obtained, adjust the control again to your preference.
* The main speaker’s rated minimum reproducible frequency can be looked up in the speakers’ catalog or
owner’s manual.
6
Turn up the VOLUME control gradually to adjust the volume balance between this unit and the
main speakers.
Normally, set the control to the level where you can obtain a little more bass effect than when this unit is not used.
If the desired response cannot be obtained, adjust the control again to your preference.
Once the volume balance between this unit and the main speakers is adjusted, you can adjust the volume of your
whole sound system by using only the amplifier’s volume control.
FREQUENCY RESPONSE
This unit’s frequency response
dB
HIGH CUT 100 Hz
90
HIGH CUT 150 Hz
80
70
HIGH CUT 50 Hz
60
50
40
20
10
50
100
200
500Hz
English
The figures below show the optimum adjustment of each control and the frequency characteristics when this unit is
combined with a typical main speaker system.
EX.1 When combined with a 3” or 4” (8cm or 10cm)
acoustic suspension, 2 way system main speakers
dB
HIGH CUT
Combined frequency response
VOLUME
90
80
50 Hz
150 Hz
0
10
70
YST-SW45
* One graduation of this
control represents 10 Hz.
60
Main
speaker’s
response
50
40
20
50
100
200
500Hz
EX.2 When combined with a 5” (13 cm )
acoustic suspension, 2 way system main speakers
dB
HIGH CUT
Combined frequency response
VOLUME
90
80
YST-SW45
50 Hz
150 Hz
0
10
* One graduation of this
control represents 10 Hz.
70
Main
speaker’s
response
60
50
40
20
50
100
200
500Hz
11
ADVANCED YAMAHA ACTIVE SERVO TECHNOLOGY
The theory of Yamaha Active Servo Technology has been
based upon two major factors, the Helmholtz resonator and
negative-impedance drive. Active Servo Processing
speakers reproduce the bass frequencies through an “air
woofer”, which is a port or opening in the speaker’s cabinet.
This opening is used instead of, and performs the functions
of, a woofer in a conventionally designed speaker system.
Thus, signals of low amplitude within the cabinet can,
according to the Helmholtz resonance theory, be output from
this opening as waves of great amplitude if the design is
such that the size of the opening and the volume of the
cabinet are in the correct proportion to satisfy a certain ratio.
In order to accomplish this, moreover, the amplitudes within
the cabinet must be both precise and of sufficient power
because these amplitudes must overcome the “load”
presented by the air that exists within the cabinet.
Thus it is this problem that is resolved through the
employment of a design in which the amplifier functions to
supply special signals. If the electrical resistance of the voice
coil could be reduced to zero, the movement of the speaker
unit would become linear with respect to signal voltage, and,
to accomplish this, a special negative-impedance outputdrive amplifier for subtracting output impedance of the
amplifier is used.
By employing negative-impedance drive circuits, the
amplifier is able to generate precise, low-amplitude lowfrequency waves with superior damping characteristics, and
these waves are then radiated from the cabinet opening as
high-amplitude signals. The system can, therefore, by
employing the negative-impedance output drive amplifier and
a speaker cabinet with the Helmholtz resonator, reproduce
an extremely wide range of frequencies with amazing sound
quality and less distortion.
The features described above, then, are combined to be the
fundamental structure of the conventional Yamaha Active
Servo Technology.
Our new Active Servo Technology — Advanced Yamaha
Active Servo Technology — adopted Advanced Negative
Impedance Converter (ANIC) circuits, which allows the
conventional negative impedance converter to dynamically
vary in order to select an optimum value for speaker
impedance variation. With this new ANIC circuits, Advanced
Yamaha Active Servo Technology can provide more stable
performance and improved maximum sound pressure
compared with the conventional Yamaha Active Servo
Technology, resulting in more natural and energetic bass
reproduction.
Air woofer
(Helmholtz resonator)
Cabinet
High-amplitude
bass sound
Port
Advanced Negativeimpedance Converter
Active
Servo
Processing
Amplifier
Signals of low amplitude
12
Signals
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact
your authorized YAMAHA dealer or service center for help.
SYMPTOM
CAUSE
REMEDY
The power cannot be turned on.
The power cord is not plugged in, or the Main
POWER switch is set to the OFF position.
Plug the power cord into an AC outlet and/or set the
Main POWER switch to the ON position.
No sound.
The VOLUME control is set to 0.
Turn the VOLUME control to right.
Speaker wires are not connected securely.
Connect them securely.
Speaker wires are connected incorrectly.
Connect them correctly; L (left) to L, R (right) to R, + to
+ and – to –.
A source sound with few bass frequencies is
played.
Play a source sound with bass frequencies.
Set the HIGH CUT control to a higher position.
It is influenced by standing waves.
Reposition the subwoofer or break up the parallel
surface by placing bookshelves etc. along the walls.
The Main POWER switch is set to the OFF
position.
Set the Main POWER switch to the ON position.
The STANDBY/ON button is set to OFF.
Set the STANDBY/ON button to ON.
The AUTO STANDBY switch is set to the OFF
position.
Set the AUTO STANDBY switch to the HIGH or LOW
position.
The level of input signal is too low.
Set the AUTO STANDBY switch to the HIGH
position.
The unit turns off (on standby)
unexpectedly.
The level of input signal is too low.
Set the AUTO STANDBY switch to the HIGH
position.
The unit turns on unexpectedly.
An influence of noise generated from external
equipment etc.
Move the unit farther away from such equipment and/
or change the position of connected speaker wires.
Otherwise, set the AUTO STANDBY switch to the
OFF position.
Sound level is too low.
The unit does not turn on
automatically.
SPECIFICATIONS
YST-SW45
Type ................ Active Servo Processing Subwoofer System
Speaker Unit .................... 20 cm (8”) cone woofer (JA2162)
magnetic shielding type x 1
Amplifier Output ............................................. 70 W/5 ohms
High-Cut Filter ......................... 50 Hz–150 Hz (–24 dB/oct.)
Frequency Response ..................... 30 Hz–200 Hz (–10 dB)
Power Supply
U.S.A. and Canada models .................. AC 120 V, 60 Hz
Australia model ..................................... AC 240 V, 50 Hz
U.K. and Europe models ...................... AC 230 V, 50 Hz
General and China models
................... AC 110/120/220/240 V, 50/60 Hz
.................. (Adjustable with Voltage Selector)
Power Consumption ...................................................... 55 W
Dimensions (W × H × D) ........... 235 mm × 365 mm × 318 mm
(9-5/16” × 14-7/20” × 12-1/2”)
Weight ...................................................... 9 kg (19 lbs. 13 oz.)
Supplied Accessory .......................................... Rubber Pads
* Design and specifications are subject to change without notice.
