Projectors
CONSTANT
BRILLIANCE
5 YEAR
10,000
HOUR
*
WARRANTY
MERCURY
FREE
LIGHT SOURCE
casio.co.uk/projectors
2
At a glance
CONSTANT BRILLIANCE
The Casio projector range combines the extremely long life of Laser and LED
technology to create an outstanding performance of up to 4,000 ANSI lumens.
While the performance of a conventional projector lamp declines considerably with
age, Casio projectors deliver consistantly brilliant, bright images throughout their
20,000 hour life.
Innovative Light Source Technology
Casio’s revolutionary lamp-free Laser & LED
hybrid light source technology improves
environmental credentials AND reduces
power consumption ensuring budgets
go further.
Intelligence Brightness Control
Integrated light sensors detect the levels of
ambient light and adjust brgihtness output to
ensure optimum performance for the light conditions
and further reduces energy consumption.
PC-free presenation
Selected models offer
er mobile
ay your
presenting. Display
presentations / images / video’s
directly from a USB drive.
Flexible installations
Advanced Connectivity
All models have standard
ndard vga and
composite video, as well as an HDMI port
for connection to high definition sources.
A powerful integrated optical zoom
feature allows the user to adjust the screen
size projected without actually moving the
projector.*
* On selected models. Short throw series do not have zoom function
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Eco Features
Eco Features
Intelligent Brightness Control
Special integrated light sensors in all Casio projectors
detect the levels of ambient light, and adjust brightness
output to ensure optimum performance for the light
conditions in the classroom. This means that the
class will always be able to see the screen clearly
and because power consumption is further reduced when
the projectors operate below full brightness, the school
will save money too!
05;,330.,5;
)90./;5,::*65;963
AUTOMATIC
CONTROL
High power consumption
Low power consumption
Low-maintenance solution
With no lamps to check and replace, the user will
save considerable time and money in comparison to
conventional lamp-based projectors. Casio projectors are
also filter-free, so users won’t be spending any time or
money on cleaning or replacing projector filters.
Conventional projectors after 2,000 hours
CASIO projectors with innovative laser and LED hybrid
technology after 3,000 hours
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
3
4
Innovative light source technology
Casio offer a complete range of lamp-free projectors, which sets Casio apart from
all others. Offering users a greener, more cost effective projection solution the Laser
& LED hybrid light source delivers top performance for the life of the projector, with
unparalleled low total cost of ownership.
Casio’s revolutionary lamp-free Laser & LED hybrid light
source technology offers the user the opportunity to improve
their environmental credentials AND make their budgets
go further. By eliminating lamps, Casio projectors eliminate
mercury from the classroom and give users the peace of
mind that their AV equipment is free from environmentally
hazardous substances. The innovative light source also
demands less power than conventional lamps to achieve a
comparable brightness, which will help to keep businesses
and education establishments’ carbon footprint to a
minimum, and running costs down.
A new lamp can cost upwards of £400 and
requires replacement in some cases after
only 2000 hours. The Casio Laser & LED
hybrid light source will last up to 20,000
hours.
The diagram shown illustrates the
fundamentals of how the Laser & LED hybrid
light source works.
Projection screen
Projection optical system
DLP® chip
Condenser lenses
Phosphor
Blue laser unit
Red LED
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Innovative Light Source Technology
If you’re looking for top performance from your
projectors, with the Casio Laser & LED hybrid light
source there’s no need to compromise. Conventional
lamps decline in brightness over time, reaching just 50%
of their original brightness at the end of their stated lifetime.
This means that lamp-based projectors only perform to
their maximum technical specification for a fraction of their
product lifecycle. More importantly, it means that users
may struggle to view the projected display as it becomes
dimmer over time.
5
Key features
• Lamp-free Laser & LED Hybrid Light Source
• Mercury-free
• 20,000 hours life expectancy
• Eliminates the need for expensive replacement lamps
• Delivers consistent light output for the life of the projector
The Casio Laser & LED light source delivers
consistent light output for the life of the
projector, so users will view the same bright
image over the lifetime of the projector.
Discover how much can be saved using Casio Projectors.
Our cost saving calculator will enable you to discover how much on average a year you could save by switching your
projectors to Casio. Find out more today by visiting www.casio.co.uk/projectorsTCO
CASIO projectors
2,000 AL
(dust, etc.)
1,000 AL
Conventional projectors
3,000 hrs
‘end of life’
20,000 hrs
‘end of life’
15 years
Constant brightness level
220 days/year at 6 hrs
5 years
No lamp replacements
10 years
15 years
No follow-up costs
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
6
Remote projector management
Crestron Roomview Express® software provides a custom
configurable interface to monitor, manage and control
every device in every room remotely from any computer.
Use the free network management software (Crestron
Roomview Express®) to automatically switch ON/OFF up
to 250 projectors from a single location. The easy-to-use
interface allows you to manage all the units connected to
the network in one place.
• Manage up to 250 projectors at the same time
(via master PC).
• Alter the projector settings using a simple web browser
page including OSD menu control.
• Set up email alerts for warning messages.
• Ideal for large installations in both educational and
business environments.
Available on Signature, Short Throw,
Pro series Wireless / LAN models.
Laptop
Download Crestron RoomView® Express
software from:
www.crestron.com/getroomview
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Centralised
Management
PC
Casio Projector Range
Projector Management
7
Flexible installations
To enable flexible installs within a host of applications,
many of our projectors have integrated optical zoom.
This enables users to adjust the screen size projected
without actually moving the projector. It is particularly
useful for meeting room upgrade programmes, where
the Casio projector will be replacing an existing unit. The
optical zoom feature means that the Casio projector could
directly replace the old projector
– without moving the brackets – and deliver exactly the
same screen size as before. This will save a significant
amount of time, money and disruption.
Interested in how Casio projectors
would fit your room requirements?
Ed
re
isu
uc
ati
Le
on
ate
r
po
r
Co
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
8
Advanced Connectivity
Whatever your connection requirements you can achieve
them with a Casio projector. All models have standard
VGA and composite video connections, as well as an
HDMI port ensuring your projector is HD Ready. Many
models also offer S-Video connectivity, audio input / output
and USB / wireless connectivity for PC free presentation.
Selected models can be connected to a network enabling
them to be managed from a remote location, ensuring fleet
management is effortless.
Teaching in the Third Dimension
Equipped with a 3D ready DLP chip, many Casio
projectors can display 3D content for rich, lifelike
presentations.** Imagine how much easier it would be
to understand complex scientific diagrams, or bring to
life three-dimensional models and spatial visualisations.
3D technology allows presenters to showcase realistic,
engaging images and movies to maximise the impact of
their presentation.
** 3D content and Active-shutter glasses required.
Impressive colour rendition
Casio projectors deliver a brilliant colour rendition across
a massive range of colours that is further enhanced by the
‘Helmholtz–Kohlrausch effect’. This optical phenomenon
causes an increase in the subjective perception of
brightness proportional to the degree of colour saturation.
The greyscale rendition of the new projectors is also
almost perfect: black appears as black, and not as a
dark grey. Such superb colour performance will give
you the confidence to deliver truly memorable, impactful
presentations.
?1TVKLSZ
The colour spectrum recognised by the human eye
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Subhead here
9
ONLY
FIVE YEAR
THE
*
,000 HOUR
10
ON-SITE HARDWARE
& LIGHT SOURCE WARRANTY
We are pleased to offer you additional peace
of mind with our most comprehensive and
quibble-free warranty which is available on
ALL of our projectors.
5 YEAR
10,000
HOUR
*
WARRANTY
020 8208 9510 | projectors@casio.co.uk | casio.co.uk/projectors
MERCURY
FREE
LIGHT SOURCE
CONSTANT BRILLIANCE
* Whichever comes first. Terms and conditions apply.
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
10
Casio Projector Range
Green Slim Series
The ideal replacement projector
The Green Slim series uses the cost-effective,
environmentally friendly Casio Laser & LED Hybrid light
source and is the perfect choice for those looking to upgrade
their existing installed projectors. An industry-leading 2x
optical zoom means that a Green Slim model will replace
almost any installed projector seamlessly, without having
to change the ceiling brackets. This helps to keep budgets
under control and disruption to a minimum.
• Lamp-free Laser & LED Hybrid Light Source
– Mercury-free
– 20,000 hours life expectancy
– Eliminates the need for expensive
replacement lamps
– Delivers consistent light output for
the life of the projector
The Green Slim series offers brightness levels up to
3,000 ANSI lumens – more than enough for even a large,
bright meeting room – and a choice of XGA and WXGA
resolution. All models have HDMI connectivity, enabling the
presentation of HD content and they’re light and portable,
so can easily be moved between rooms if required.
Models
ANSI lumens
Resolution
USB/WLAN
XJ-A131
XJ-A141 /
XJ-A146
XJ-A241 /
XJ-A246
XJ-A251 /
XJ-A256
2,000
2,500
XGA (4:3)
XGA (4:3)
–
XJ-A146 only
2,500
WXGA (16:10)
XJ-A246 only
3,000
WXGA (16:10)
XJ-A256 only
• Up to 3,000 ANSI lumens
5 YEAR
WARRANTY
• XGA and WXGA resolution
• 2x optical zoom
• Extensive connectivity options,
including HDMI, LAN, WLAN and USB
(selected models)
2
• Quick start and stop
• Mobi Show functionality for connection to
smartphones and iPads (selected models)
Full 5 year
or
10,000 hour
warranty
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Green Slim Series
11
Case Study – Yates’s
Bedford’s top nightspot transforms its entertainment experience
with Casio XJ-A projectors.
Yates’s Bedford is a bar, nightclub
and restaurant with a capacity of 500,
making it one of the town’s busiest
nightspots.
Visitors are drawn to the pub’s
vibrant welcoming atmosphere and
live televised sporting events. To
provide the best-possible viewing
experience of sports and music
channels, Yates’s Bedford had
previously used four traditional
lamp-based projectors, each areas
hosting non-stop entertainment.
Gary Voysey is the General
Manager of Yates’s Bedford and has
overall responsibility for providing
his customers with a great pub
experience. He takes up the story:
“Our continued use of projectors
in Yates’s Bedford goes far
beyond providing background
entertainment. Regulars and
visitors alike are nothing short of
passionate about our screened
events, so our ongoing schedule
of live events is, and will continue
to be, a key attraction.”
Gary asked sound and visual media
provider PlayNetwork to suggest
new, more cost-efficient and greener
projector technologies — and that’s
where Casio comes in. Casio’s
XJ-A145 models, with Casio’s own
proprietary Laser & LED Hybrid
technology, eliminate maintenance
costs by using a solid-state lampfree light source, providing a crisp,
high quality image regardless of
ambient lighting conditions.
“We are open from 10am till 3am
each day, so the demands on
our AV are intensive. Projectors
are running all day, every day. We
absolutely needed to install reliable,
low-maintenance projectors that
deliver crystal sharp images, day
and night.”
With the new Casio XJ-A145, no
lamp changes are required and its
laser and LED technology does
not suffer from degradation in light
power or image quality. The intense
2,500 lumen brightness of the Casio
models will continue for its usable
life. This also eliminates the need
for Yates’s Bedford to replace each
projector’s lamp every six months —
a cost saving of around £200 each,
plus an external call out charge. As a
result, Gary will save around £2,000
per annum.
Installation of the projectors
commenced in May 2011 and
operating time has already
surpassed 12,000 hours.
As with all of the Yates’s chain,
Yates’s Bedford is keen to provide
a safe operating atmosphere for
both staff and public. Gary
elaborates: “The Casio XJ-A
projectors are so easy to operate
that we can now do the projector
maintenance in-house. This is readily
achieved with the Casio XJ-As as
these projectors are filter-free and
require minimal cleaning, and are
also mercury-free.”
Eliminating mercury within each
lamp is in line with the more open,
greener, family pub environment
Yates’s Bedford encourages. In
addition, the pub is driving down its
carbon footprint; cutting electricity
consumption by switching to
alternative cleaner devices without
affecting the customer experience.
The four Casio projectors are ceiling
mounted, weigh-in at a lightweight
2Kg and have a discreet A4-sized
footprint. Using the Casio XJ-As,
the pub can be flexible about room
layouts — Gary can elect to project
directly onto walls, or on to a pulldown screen.
Gary summarises the Casio Laser
& LED Hybrid projector experience:
“It has been a total win-win, in
fact the difference between the
old projectors and the new Casio
models has been like going from
black and white television to colour.
From a visitor point of view, the
Casio projectors have provided
total ‘wow’ feedback, with no haze,
and crystal-clear images. From a
management perspective, they’ve
been brilliant: they’ve driven down
costs and power consumption and
reduced maintenance time.”
“From a visitor point of view, the Casio projectors have
provided total ‘wow’ feedback, with no haze, and crystalclear images. From a management perspective, they’ve
been brilliant: they’ve driven down costs and power
consumption and reduced maintenance time.”
”
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
12
Signature Series
A versatile range of projectors for classrooms and meeting rooms
The Signature series offers versatile projection solutions
using the cost-effective, environmentally friendly Casio Laser
& LED Hybrid light source. Thanks to Intelligent Brightness
Control, the light output is automatically adjusted according
to the levels of ambient light. This minimises power
consumption – and running costs – by ensuring that the
brightness delivered is no more than actually required. The
projectors also deliver all of the key benefits associated with
• Lamp-free Laser & LED Hybrid Light Source
– Mercury-free
– 20,000 hours life expectancy
– Eliminates the need for expensive
replacement lamps
– Delivers consistent light output for
the life of the projector
the unique Casio Laser & LED Hybrid light source: excellent
colour performance with no deterioration of brightness, a
20,000 hour life expectancy, quick start & stop, and the
elimination of expensive replacement lamps. The nine
models in the Signature series offer a range of connectivity
options, including RGB, HDMI, LAN, WLAN & USB and can
be used in any orientation offering complete flexibility for
more bespoke applications.
Models
ANSI lumens
Resolution
USB/LAN/WLAN
XJ-M130
XJ-M140 /
XJ-M145
XJ-M150 /
XJ-M155
XJ-M240 /
XJ-M245
XJ-M250 /
XJ-M255
2,000
2,500
XGA (4:3)
XGA (4:3)
–
XJ-M145 only
3,000
XGA (4:3)
XJ-M155 only
2,500
WXGA (16:10)
XJ-M245 only
3,000
WXGA (16:10)
XJ-M255 only
• Up to 3,000 ANSI lumens
• XGA and WXGA resolution
5 YEAR
1.5
• Intelligent Brightness Control
WARRANTY
• 3D Ready
• Extensive connectivity options,
including HDMI, LAN, WLAN, USB
and S-Video (selected models)
46)0:/6>
05;,330.,5;
46)0:/6> )90./;5,::*65;963
05;,330.,5;
)90./;5,::*65;963
• Mobi Show functionality for connection to
smartphones and iPads (selected models)
Full 5
year or
10,000 hour
warranty
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Signature Series
13
Case Study – St Georges Academy
Leading Maths and Computing Academy, St Georges, adopts
hybrid Laser/LED Projectors throughout the Academy:
“One of the very few products that I
would happily endorse:” Jamie Hirst
– ICT Services Director, St George’s
Academy.
New Casio XJ-M Signature range
provides enlightened learning
experience whist dramatically
decreasing costs:
St George’s Academy is a thriving,
specialist academy in the heart of
Lincolnshire excelling in the provision
of Maths and Computing to over
2,200 students across two sites in
Sleaford and Ruskington.
In the classroom, modern and
emerging technologies take a key
role in teaching methods with useful
innovation being key to life at the
Academy.
Jamie Hirst is the ICT Services
Director for the Academy operating
in a team of seven and is responsible
for recommending and procuring
integrated ICT to positively enrich the
classroom experience. As such, when
a Casio model of a new hybrid Laser/
LED projector appeared back in the
summer of 2010, and having worked
with lasers previously, Jamie knew
that what had been announced was
nothing short of revolutionary enabling
the move away from the resource
draining conventional lamp-based
projectors. He elaborates. “The minute
you switch on a conventional bulb
based projector, degradation in the
brightness of lumens starts.
Prior to the new Casio projectors
being deployed, we not only had
to factor in the high cost of new
bulbs every 3 years, at the cost of
£200 each, we also had to consider
the ongoing maintenance cost of
cleaning out filters on a monthly
basis, which is no longer required
with the Casio projectors.”
Jamie contacted Casio and the
first GreenSlim Casio XJ-A model
was dispatched. Such was the
positive response when in operation,
that an order for the remaining five
rooms in the Language Centre
followed immediately.
It made sound financial and
teaching sense to deploy LED/
Lasers throughout the Academy and
the decision was made to replace all
the projectors. Casio had enhanced
the model range further with the
arrival of the new Casio XJ-M140.
Each Casio XJ-M140 arrived with
a no quibble 5 year or 10,000 hour
hardware and light source warranty,
which Jamie envisages will last the
Academy many, many years before
each projector needs replacing.
The remaining units were installed
in all the Academy’s classrooms
throughout the summer vacation
and their lightweight frame slotted
seamlessly into the existing ceiling
mounted brackets.
When the Academy returned in the
Autumn term, staff instantly reported
a marked difference in their teaching
experience. Lectures were no
longer interrupted with staff fiddling
with blinds and adjusting projector
settings in order that the whole class
could see the lesson properly.
As you would expect in such a
forward thinking environment,
the Academy has a strong Green
Policy and strives wherever possible
to reduce energy and carbon
overheads, demonstrating
efficiencies. Part of the Signature
Range, the Casio XJ-M140 boasts
75% reduction in energy costs,
using less than 1 watt of electricity
in standby mode and contains no
mercury for disposal considerations.
Jamie concludes. “We stand proud
of our heritage of deploying really
useful technology that produces an
enhanced learning experience for
the children and staff and give us
significant reductions in the cost of
ownership deploying a far superior
product. As a technology Academy,
we stand extremely proud of this
installation and technology choice
and it is a solution I am happy to
put my name against.”
“We stand proud of our heritage of deploying really
useful technology that produces an enhanced learning
experience for the children and staff and give us
significant reductions in the cost of ownership
deploying a far superior product.”
”
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
14
Short Throw Series
Big screen performance in small spaces
The XJ-ST145 & XJ-ST155 deliver a short throw projection
solution using the cost-effective, environmentally friendly
Casio Laser & LED Hybrid light source. Perfect for use with
whiteboards in classrooms or in meeting rooms where
space is limited, the Short Throw models can achieve a
60” screen from just 80cm away from the display surface.
The optional interactive pointer enables interactive lessons
and presentations without the need for a special interactive
• Lamp-free Laser & LED Hybrid Light Source
– Mercury-free
– 20,000 hours life expectancy
– Eliminates the need for expensive
replacement lamps
whiteboard, and 3D technology makes presentations
even more lifelike and engaging.
Both models are easily re-fitted to existing short throw
systems where projector replacement is required. Their
ability to be connected to a network means that they
can be monitored and controlled from a remote location,
allowing users to centralise the management of their
projector fleet.
Models
ANSI lumens
Resolution
USB/LAN/WLAN
XJ-ST145
XJ-ST155
2,500
3,000
XGA (4:3)
XGA (4:3)
Yes
Yes
– Delivers consistent light output for
the life of the projector
05;,9(*;0=,
7605;05.
-<5*;065
5 YEAR
• 60” screen from just 80cm
WARRANTY
• Intelligent Brightness Control
46)0:/6>
05;,330.,5;
)90./;5,::*65;963
• 3D Ready
• Interactive functionality (with optional pointer)
• Extensive connectivity options, including HDMI,
LAN, WLAN and USB
• Mobi Show functionality for connection
to smartphones and iPads
• Short throw series can be retrofitted to existing
interactive solutions.
Contact your reseller or distribution partner for
bespoke bracket options
Full 5 year
or 10,000
hour
warranty
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Short Throw Series
15
Case Study – United Learning
United Learning, nationwide advisor for 30,000 children across UK Academies’
& Independent Schools, recommends Casio’s Revolutionary LED Projector range:
New Casio LED lampless
technology re-invigorates classroom
learning and dramatically reduces
cost of ownership for education.
United Learning offers best advice
on provision of a quality infrastructure
to 30,000 schoolchildren across
the UK. To this end, United
Learning Technologies group ethos
is to train and facilitate their 2,500
teachers to enable the most out of
new technology to positively enrich
the classroom experience.
Learning Technoloiges Team Leader
Geoff Gould has been an ongoing
advocate of deployment of worthy
audio visual equipment technology to
education establishments for over ten
years. He takes up the story. “Since
1999 we have had a policy of having
LCD projectors to accompany our
Interactive Whiteboards. However,
whilst LCD projectors were still a mile
ahead of the previous OHP projection
technology, distinct quality issues
were becoming apparent after just a
year or so of use.”
In the classroom, lamp lumen
degradation was the first to go;
with lamps starting to significantly
dim after 15-18 months of use.
In addition, ongoing maintenance
was required with filter cleaning
recommended on a monthly basis.
Ongoing lamp replenishment was
another constant drain. With most
schools holding a variety of LCD
projectors all with varying lamp
types, academies were required to
keep a rolling stock of replacement
lamps on premises.
Environmental factors within the
classroom itself also needed to be
considered when using the LCD
projectors. Blinds to divert natural
daylight often needed to be darkout
or even blackout quality and lights had
to be switched off to stop incumbent
light pollution. Teachers were also
concerned that these conditions were
less than ideal for those pupils who
may have been susceptible to eye
strain.
Teachers, school AV Teams and
IT departments turned to the
experts at United Learning for
advice, despondent that even
after just the second year of use
the LCD projectors were becoming
sub-optimal.
United Learning contacted their AV
partner, IDNS, who suggested that
lampfree LED technology should be
evaluated as an alternative technology.
Casio’s new XJ range was suggested
and following a demonstration, Geoff
and the Team at United Learning were
impressed by the immediate light
vibrancy on offer.
Communications to all of the United
Learning’s Network Managers followed
containing recommendations as to
why individual establishments would
benefit, with proof points provided by
Swindon Academy.
A year down the line, the Casio
XJ LED projector ranges are
firmly entrenched across the UK’s
classrooms, with over 10 of United
Learning’s establishments running
the transforming Casio LED
projectors. That’s over 700 units,
with more being installed as budget
allow each week; their compact
size slotting into the existing ceiling
mounts and their inbuilt auto
configuration quickly finding the
optimum viewing experience.
In terms of ROI vs. initial capital outlay
per unit, Geoff has conducted some
interesting findings with a five year cost
of ownership (TCO) plan for traditional
LCD vs. Casio’s LED projectors.
He comments on his findings: “A
traditional lamp based LCD projectors’
TCO over 5 years equates to around
£1200 (including projector, sourcing
& installing 1 replacement lamp,
arranging 1 offsite specialist deep clean
& ongoing onsite maintenance 6 times
a year); vs. Casio’s XJ unit that retails at
under £700 and simply has no further
overhead. It’s not just the financial
considerations that stand out here.
It’s the fact that there is no downtime
or hassle factor with the Casio XJ
LED projectors.”
For total peace of mind, Geoff
notes that Casio uniquely back each
unit with a 5 year, 10,000 hour noquibble guarantee.
“It’s not just the financial considerations that stand
out here. It’s the fact that there is no downtime or
hassle factor with the Casio XJ LED projectors.”
”
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
16
Pro Series
High brightness projectors for installation
The Pro series offers high brightness projection solutions
using the cost-effective, environmentally friendly Casio
Laser & LED Hybrid light source. Perfect for large meeting
rooms and school halls, models in the Pro series deliver
up to 4000 ANSI lumens with consistent brightness and a
20,000 hour life expectancy. Intelligent Brightness Control
adjusts the light output according to the levels of ambient
light, which minimises power consumption – and running
• Lamp-free Laser & LED Hybrid Light Source
– Mercury-free
– 20,000 hours life expectancy
– Eliminates the need for expensive
replacement lamps
costs – by ensuring that the brightness delivered is no
more than actually required. All models are 3D ready, and
selected models can be used with a Casio interactive
pointer to enable interaction with presentations for a rich,
dynamic projection experience. Selected models can also
be connected to a network, which means that it can be
monitored and controlled from a remote location, allowing
users to centralise the management of their projector fleet.
Models
ANSI lumens
Resolution
USB/LAN/WLAN
XJ-H1600 /
XJ-H1650
XJ-H1700 /
XJ-H1750
XJ-H2600/
XJ-H2650
3,500
XGA (4:3)
XJ-H1650 only
4,000
XGA (4:3)
XJ-H1750 only
3,5000
WXGA
XJ-H2650 only
– Delivers consistent light output for
the life of the projector
• Bright up to 4,000 ANSI lumens performance
05;,9(*;0=,
7605;05.
• Intelligent Brightness Control
-<5*;065
• XGA and WXGA resolution
• 3D Ready
5 YEAR
46)0:/6>
05;,330.,5;
WARRANTY
)90./;5,::*65;963
• Interactive functionality (with optional pointer)
• Extensive connectivity options, including HDMI,
LAN, WLAN and USB (XJ-H1650)
• Mobi Show functionality for connection
to smartphones and iPads (XJ-H1650)
Full 5 year
or 10,000
hour
warranty
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
Casio Projector Range
Market opportunities
Market opportunities
The Casio range of projectors have been designed to ensure all users get the
following from their projectors:
• Ease of use
• Cost savings
• Low maintenance
• Peace of mind
Casio projectors have many applications, examples of which are below.
Leisure and hospitality
The requirement for projectors within leisure and
hospitality applications varies depending on location and
type of application. However all of these environments
require a product that is easy to install, can replace
existing models and will save them both time and
money. For example the Casio Green Slim series
has great success within bars and restaurants as it
eliminates maintenance costs and provides crisp high
quality images regardless of ambient light conditions.
Corporate
Within large corporations projectors and AV equipment
are now common place, often the requirement for
projectors is within boardrooms, meeting rooms and
training facilities.
The Casio Signature and Pro Series are designed to suit
these applications.
With their multiple inputs, quick start-up mode and
unique lamp-free light source, they offer a low TCO
compared to all standard LCD projectors, saving
businesses time and money.
Education
From primary school classrooms through to higher
education seminar rooms there is a Casio projector
that will suit.
The Casio projector range offer a wide choice of options
to fulfil the requirements of any education environment,
ranging from 2000 to 4000 ANSI lumens brightness,
available in XGA and WXGA resolution and with a choice
of connectivity and functionality these easy to install
projectors are a natural fit for education.
The Casio range of projectors will not only save money
over time, but also reduce maintenance and downtime,
and enhance any learning environment with their ability to
deliver bright images and movies even in well-lit rooms.
The entire range of Casio projectors come with a quibble-free 5 year/10,000 hour on-site
hardware and light source warranty ensuring peace of mind, whatever the application.
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
17
18
GREEN SLIM SERIES
Model
XJ-A131
S
XGA 0.55”
DLP® chip
Laser - LED Hybrid
20,000 Hours
2000
XJ-A141
XJ-A146
XGA 0.55”
DLP® chip
Laser - LED Hybrid
20,000 Hours
2500
XJ-A241
XJ-A246
WXGA 0.65”
DLP® chip
Laser - LED Hybrid
20,000 Hours
2500
XJ-A251
XJ-A256
WXGA 0.65”
DLP® chip
Laser - LED Hybrid
20,000 Hours
3000
XGA 0.55”
DLP® chip
Laser - LED hybrid
20,000 Hours
2000
XJ-M140
XJ-M145
XGA 0.55”
DLP® chip
Laser - LED hybrid
20,000 Hours
2500
Available
(Auto / Manual)
1800:1
Available
(Auto / Manual)
1800:1
Available
(Auto / Manual)
1800:1
Available
(Auto / Manual)
1800:1
Available
(Auto / Manual)
1800 : 1 (tele mode)
Available
(Auto / Manual)
1800 : 1 (tele mode)
XGA
(1024x768 pixels)
UXGA / WSXGA+
XGA
(1024x768 pixels)
UXGA / WSXGA+
WXGA
(1280x800 pixels)
UXGA / WSXGA+
WXGA
(1280x800 pixels)
UXGA / WSXGA+
XGA (1024x768
pixels)
UXGA / WSXGA+
XGA (1024x768
pixels)
UXGA / WSXGA+
2x optical zoom
(electronic)
Electronic
100%
f15.9-30.8/
F2.29-3.09
35dB (Eco 1)
2x optical zoom
(electronic)
Electronic
100%
f15.9-30.8/
F2.29-3.09
35dB (Eco 1)
2x optical zoom
(electronic)
Electronic
84%
f15.9-30.8/
F2.29-3.09
35dB (Eco 1)
2x optical zoom
(electronic)
Electronic
84%
f15.9-30.8/
F2.29-3.09
35dB (Eco 1)
Keystone Correction (Vertical)
Screen Size (diagonally)
+/- 30° (Auto)
15 - 300 inch
+/- 30° (Auto)
15 - 300 inch
+/- 30° (Auto)
18 - 300 inch
+/- 30° (Auto)
18 - 300 inch
1.5x optical zoom
(manual)
Manual
100%
f18.9-27.2/
F2.31-2.73
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
30 - 300 inch
1.5x optical zoom
(manual)
Manual
100%
f18.9-27.2/
F2.31-2.73
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
30 - 300 inch
Throwing Distance
1.7m - 3.4m
2.8 - 5.6
1.4 - 2.8
1.7m - 3.4m
2.8 - 5.6
1.4 - 2.8
1.4m - 2.8m
2.4 - 4.8
1.15 - 2.3
1.4m - 2.8m
2.4 - 4.8
1.15 - 2.3
2.0m to 3.0m
3.4m to 4.9m
1.64 - 2.46 : 1
2.0m to 3.0m
3.4m to 4.9m
1.64 - 2.46 : 1
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x HDMI type A
(480p–1,080p)
1 x RCA composite
(via supplied
AV cable)
Via D Sub 15-pin
1 x HDMI type A
(480p–1,080p)
1 x RCA composite
(via supplied
AV cable)
Via D Sub 15-pin
1 x HDMI type A
(480p–1,080p)
1 x RCA composite
(via supplied
AV cable)
Via D Sub 15-pin
1 x HDMI type A
(480p–1,080p)
1 x RCA composite
(via supplied
AV cable)
Via D Sub 15-pin
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
-
-
-
-
-
-
-
-
From HDMI
input only
YK-5
(optional accessory)
-
From HDMI
input only
YK-5
(optional accessory)
XJ-A146 only
-
From HDMI
input only
YK-5
(optional accessory)
XJ-A246 only
-
From HDMI
input only
YK-5
(optional accessory)
XJ-A256 only
-
1 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
1 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
-
USB
-
Interactive pointing
-
1 x USB type A (XJA146 only)
-
1 x USB type A
(XJ-A246 only)
-
1 x USB type A
(XJ-A256 only)
-
XJ-M145 only
1 x RJ45
(XJ-M145 only)
1 x USB type A
(XJ-M145 only)
-
Technology
Light Source
Life Expectancy
Brightness (ANSI Lumens)
Intelligent Brightness Control
Contrast Ratio
Native Resolution
Max Signal Resolution
Lens
Standard zoom
Focus
Offset
Projection Ratio
Fan Noise
60” screen
100” screen
Throw Ratio
Inputs
Computer
Input
Output
Digital input
Video
Component video
Audio
Input
Output
RS-232C serial
WLAN
LAN terminal
Speaker
Instant Off
Time To Full Brightness
Power Consumption
Colour
Dimensions (wxhxd) mm
Weight
Box Contents
XJ-M130
-
1W
1W
1W
1W
5W
5W
Max
Yes
8 secs
Yes
8 secs
Yes
8 secs
Yes
8 secs
Yes
5 secs
Yes
5 secs
Eco Off
210W
210W
210W
210W
190W
190W
Eco On Level 1
170W
170W
170W
170W
150W
150W
Standby
0.6W
0.6W
0.6W
0.6W
0.4W
0.4W
White
297x43x210
White
297x43x210
White
297x43x210
White
297x43x210
White
311 x 244 x 82
White
311 x 244 x 82
2.3kg
2.3kg
2.3kg
2.3kg
Remote Control (YT-110), Composite Cable, RGB Cable, Wireless Adapter
(USB models only), Power Cable, Soft Carrying Case, User Manual, CD-ROM
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
3.9kg
3.9kg
Remote Control (YT-120),
Power Cable, So
19
SIGNATURE SERIES
SHORT THROW SERIES
XJ-M150
XJ-M155
XGA 0.55”
DLP® chip
Laser - LED hybrid
20,000 Hours
3000
XJ-M240
XJ-M245
WXGA 0.65”
DLP® chip
Laser - LED hybrid
20,000 Hours
2500
XJ-M250
XJ-M255
WXGA 0.65”
DLP® chip
Laser - LED hybrid
20,000 Hours
3000
XJ-ST145
XJ-ST155
XGA 0.7”
DLP® chip
Laser - LED hybrid
20,000 Hours
2500
XGA 0.7”
DLP® chip
Laser - LED hybrid
20,000 Hours
3000
Available
(Auto / Manual)
1800 : 1 (tele mode)
Available
(Auto / Manual)
1800 : 1 (tele mode)
Available
(Auto / Manual)
1800 : 1 (tele mode)
Available
(Auto / Manual)
1,800 : 1 (tele mode)
XGA (1024x768
pixels)
UXGA / WSXGA+
WXGA (1280x800
pixels)
UXGA / WSXGA+
WXGA
(1280x800 pixels)
UXGA / WSXGA+
XGA
(1024x768 pixels)
UXGA / WSXGA+
Available
(Auto / Manual)
1,800 : 1 (tele
mode)
XGA
(1024x768 pixels)
UXGA / WSXGA+
1.5x optical zoom
(manual)
Manual
100%
f18.9-27.2/
F2.31-2.73
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
30 - 300 inch
1.5x optical zoom
(manual)
Manual
83%
f18.9-27.2/
F2.31-2.73
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
35 - 300 inch
1.5x optical zoom
(manual)
Manual
83%
f18.9-27.2/
F2.31-2.73
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
35 - 300 inch
-
-
Manual
109%
f9.78/F2.5
2.0m to 3.0m
3.4m to 4.9m
1.64 - 2.46 : 1
1.7 to 2.5m
2.9 to 4.9m
1.32 - 1.93 : 1
1 x 15-pin RGB mini
D-sub (VGA)
-
PRO SERIES
XJ-H1600
XJ-H1650
XGA 0.7”
DLP® chip
Laser - LED hybrid
20,000 Hours
3500
XJ-H1700
XJ-H1750
XGA 0.7”
DLP® chip
Laser - LED hybrid
20,000 Hours
4000
XJ-H2600
XJ-H2650
WXGA 0.65”
DLP® chip
Laser & LED hybrid
20,000 Hours
3500
Available
(Auto / Manual)
1400 : 1
Available
(Auto / Manual)
1400 : 1
Available
(Auto / Manual)
1400 : 1
XGA
(1024x768 pixels)
UXGA / WSXGA+
XGA
(1024x768 pixels)
UXGA / WSXGA+
WXGA
(1280x800 pixels)
UXGA / WSXGA+
Manual
109%
f9.78/F2.5
1.2x optical zoom
(manual)
Manual
100%
f23.2-27.7/F2-2.15
1.2x optical zoom
(manual)
Manual
100%
f23.2-27.7/F2-2.15
1.2x optical zoom
(manual)
Manual
111%
f23.2-27.7/F2-2.15
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
45 - 142 inches
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
45 - 142 inches
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
27 - 300 inches
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
27 - 300 inches
33 dB (default) /
28 dB (safe)
+/- 30° (Auto)
30 - 300 inches
1.7 to 2.5m
2.9 to 4.9m
1.32 - 1.93 : 1
0.8m
1.4m
0.68 : 1
0.8m
1.4m
0.68 : 1
1.9m - 2.3m
3.3m - 3.9m
1.60 - 1.91 : 1
1.9m - 2.3m
3.3 - 3.9m
1.60 - 1.91 : 1
2.1 - 2.5m
3.5 - 4.2m
1.62 - 1.95
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x 15-pin RGB mini
D-sub (VGA)
-
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
2 x 15-pin RGB mini
D-sub (VGA)
1 x 15-pin RGB mini
D-sub (VGA)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
2 x 15-pin RGB
mini D-sub (VGA)
1 x 15-pin RGB mini
D-sub (VGA)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
2 x 15-pin RGB mini
D-sub (VGA)
1 x 15-pin RGB mini
D-sub (VGA)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
2 x 15-pin RGB mini
D-sub (VGA)
1 x 15-pin RGB mini
D-sub (VGA)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
2 x 15 pin RGB mini
D-sub (VGA)
1 x 15 pin RGB mini
D-sub (VGA)
1 x HDMI type A
(480p–1,080p)
1 x RCA (composite)
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D Sub 15-pin
1 x S-Video
Via D-Sub 15 pin
1 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
1 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
1 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
2 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
2 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
2 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini D-sub
2 x 3.5mm stereo
mini jack
RCA pin terminal
(L/R) x 1
1 x 3.5mm stereo
mini jack
1 x 9-pin mini D-sub
XJ-M155 only
1 x RJ45
(XJ-M155 only)
1 x USB type A
(XJ-M155 only)
-
XJ-M245 only
1 x RJ45
(XJ-M245 only)
1 x USB type A
(XJ-M245 only)
-
XJ-M255 only
1 x RJ45
(XJ-M255 only)
1 x USB type A
(XJ-M255 only)
-
Yes
1 x RJ45
2 x 3.5 mm stereo
mini jack
RCA pin terminal
(L/R) x1
1 x 3.5 mm stereo
mini jack
1 x 9-pin mini
D-sub
Yes
1 x RJ45
1 x USB type A
1 x USB type A
1 x USB type B
1 x USB type B
XJ-H1750 only
1 x RJ45
(XJ-H1750 only)
1 x USB type A
(XJ-H1750 only)
1 x USB type B
(XJ-H1750 only)
10W
XJ-H2650 only
1 x RJ45
(XJ-H2650 only)
1 x USB type A
(XJ-H2650 only)
1 x USB type B
(XJ-H2650 only)
10W
5W
5W
5W
10W
10W
XJ-H1650 only
1 x RJ45
(XJ-H1650 only)
1 x USB type A
(XJ-H1650 only)
1 x USB type B
(XJ-H1650 only)
10W
Yes
5 secs
Yes
5 secs
Yes
5 secs
Yes
5 secs
Yes
5 secs
Yes
5 secs
Yes
5 secs
Yes
5 secs
190W
190W
190W
330W
330W
330W
350W
330W
150W
150W
150W
260W
260W
250W
270W
250W
0.4W
0.4W
0.4W
0.4W
0.4W
0.4W
0.4W
0.4W
White
311 x 244 x 82
White
311 x 244 x 82
White
311 x 244 x 82
White
420 x 323 x 106
White
420 x 323 x 106
White
400 x 323 x 106
White
400 x 323 x 106
White
400 x 323 x 106mm
3.9kg
3.9kg
RGB Cable, Wireless Adapter (USB models only)
oft Carrying Case, User Manual, CD-ROM
3.9kg
7.1kg
7.1kg
Remote Control (YT-120), RGB Cable,
Wireless Adapter (USB models only)
Power Cable, Soft Carrying Case,
User Manual, CD-ROM
7.1kg
7.1kg
7.1kg
Remote Control (Y-120), RGB Cable, Wireless Adapter
(USB models only) Power Cable, Soft Carrying Case,
User Manual, CD-ROM
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
5 years/10,000 hour warranty
CONSTANT BRILLIANCE
5 YEAR
10,000
HOUR
*
WARRANTY
MERCURY
FREE
LIGHT SOURCE
The unique lamp-free light source in Casio projectors delivers up to 20,000 hours of
superb performance at up to 4,000 ANSI lumens for bright, engaging presentations.
With four product groups, including a Short Throw series for the education market,
the Casio projector range has a model to suit every customer.
PRO PROJECTORS
High brightness projectors for installation
allation
SHORT THROW PROJECTORS
All you need for dynamic,
engaging lessons
Full 5 year
or 10,000
hour
warranty
SIGNATURE PROJECTORS
A versatile range of projectors
for classrooms, meeting rooms
and even digital signage
GREEN SLIM PROJECTORS
The ideal replacement projectors
ECOLOGICALLY SOUND,
ENERGY SAVING
POWERFUL AND INNOVATIVE
ECONOMICAL AND EFFICIENT
• Mercury-free light source
• HDMI port
• Power consumption less than
1 watt in standby mode
• Quick start-up and stop
• Lamp-free technology with up to
20,000 hours continuous performance
• Intelligent Brightness Control
• USB 2.0 for PC-free presentations
(selected models)
• Minimal maintenance requirements
• LAN and WLAN capability
(selected models)
• Incredible 5 year/10,000 hour warranty
on projector AND light source
• Significant reduction of follow-up costs
• WXGA resolution (selected models)
• MobiShow functionality, for connection
to smart phones and tablets
(selected models)
For more information on Casio projectors visit www.casio.co.uk/projectors or call 0208 2089510
