Canon VB-M40 Installation guide

YT1-1632-001
Note
This symbol indicates important or restricted items. Be sure to read
this section.
Contains reference information for operation or additional
explanations.
Safety Precautions
This section explains precautions that must be observed when using the camera. If they
are not observed, injury, death and/or property damage may occur. Read the following
information carefully and be sure to observe the precautions.
This product comes with the following items. If any item is missing, contact the dealer where you
purchased the product.
1. VB-H41/VB-H41B or VB-M40/VB-M40B 4. Installation Guide (This document)
2. Power connector
5. Warranty card
3. Setup CD-ROM
6. Notice
Write the serial number and MAC address of the camera (printed on the seal at the bottom of
the camera) in the field below before storing this Installation Guide in a safe location.
Serial number
MAC Address
_________________________________
_________________________________
© CANON INC. 2012
Printed in Taiwan
Notes on Privacy and Publicity Rights Regarding the Use of
Video/Audio
When using the camera (for video or audio recording), it is the full responsibility of the user to
protect privacy and avoid any violation of publicity rights. For example, obtain consent to install
the camera in advance if specific buildings or rooms are to be monitored. Canon shall have no
liability whatsoever in this regard.
Legal Notice
In some cases, camera monitoring may be prohibited by law or regulation, the details of which
differ by country or region. Before using the camera, check the laws or regulations of the country
or region where the camera is used.
European Union (and EEA) only.
These symbols indicate that this product is not to be disposed of with your
household waste, according to the WEEE Directive (2002/96/EC), the Battery
Directive (2006/66/EC) and/or national legislation implementing those
Directives.
If a chemical symbol is printed beneath the symbol shown above, in
accordance with the Battery Directive, this indicates that a heavy metal
(Hg = Mercury, Cd = Cadmium, Pb = Lead) is present in this battery or accumulator at a
concentration above an applicable threshold specified in the Battery Directive.
This product should be handed over to a designated collection point, e.g., on an authorized onefor-one basis when you buy a new similar product or to an authorized collection site for recycling
waste electrical and electronic equipment (EEE) and batteries and accumulators.
Improper handling of this type of waste could have a possible impact on the environment and
human health due to potentially hazardous substances that are generally associated with EEE.
Your cooperation in the correct disposal of this product will contribute to the effective usage of
natural resources.
For more information about the recycling of this product, please contact your local city office,
waste authority, approved scheme or your household waste disposal service or visit
www.canon-europe.com/weee.
(EEA: Norway, Iceland and Liechtenstein)
The contents of this guide are subject to change without any prior notice.
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON EUROPA N.V.
Bovenkerkerweg 59-61, P.O. Box 2262, 1185 XB Amstelveen, The Netherlands
14- 4.5 ( 0.18)
(Junction box fixing holes)
90
°
47
47
(1.85) (1.85)
Audio File Playback*3
15 (0.59) 15 (0.59)
Privacy Mask
View Restriction
Preset
Intelligent Function
Ceiling Mount Cover
Event Trigger Type
66
(2.60)
180 (7.09)
Fire or electric shock may result.
Caution
For installation or inspection of this camera, consult the dealer where you purchased the
product.
•This installation should be made by a qualified service person and should conform to all
local codes.
•When installing on a ceiling, make sure the surface is capable of withstanding the
total weight of the ceiling mount cover and the camera, and is sufficiently reinforced if
necessary.
•Periodically check the parts and screws for rust and to see if they have loosened, in
order to prevent injuries and equipment damage due to falling items.
Image Upload
140 (5.51)
116 (4.57)
4- 3.4 ( 0.13)
(camera mounting holes)
4- 4.5 ( 0.18)
(ceiling mount holes)
144 (5.67)
4- 3.4 ( 0.13)
(Junction Box Plate
mounting holes)
Unit: mm (in.)
User Manuals
•Installation Guide (This document)
This guide provides notes on the camera installation and explains the procedures to install the
camera using a ceiling mount cover (sold separately), as well as the main camera specifications.
•Operation Guide (Included in the Setup CD-ROM)
This document explains the initial camera settings, Admin Tools settings, viewer operations
and troubleshooting, etc.
•Do not install in unstable places, places subject to significant vibration or impact, or
places subject to salt damage or corrosive gas.
•The camera cannot be installed on vertical surfaces such as walls.
•Be sure to attach the safety wire when installing the camera.
Failure to do so may result in the camera falling or other accidents.
Symbols Indicating Camera Model
•Do not touch the edges of metal parts with bare hands.
•Be careful not to trap your fingers during installation of the camera.
Injury may result.
Main Specifications
Camera specific functions will be listed using the icons below.
: VB-H41
: VB-M40
Camera
Caution
•Do not carry the camera by the camera head.
•Do not turn the camera rotator by hand.
•Do not install the camera on an unstable or inclined surface.
Malfunction may result.
•Take care not to damage wiring or pipes in the room.
Damage to peripheral items may result.
Precautions for Use
Warning
•If you discover defective conditions such as smoke, strange sounds, heat or strange
odors, immediately stop using the camera and contact your nearest dealer.
Fire or electric shock may result from continued use of the product.
•Do not disassemble or modify the camera.
•Do not damage the connecting cable.
•Do not spill water or other liquid inside the camera, spray the camera with water, or
otherwise make it wet.
•Do not insert foreign objects into the camera.
•Do not use flammable sprays near the camera.
•Do not leave LAN cables, external power supplies or AC adapter (sold separately)
power connectors connected when the camera is not in use for long periods.
•Do not use flammable solvents such as alcohol, paint thinner or benzine when cleaning
the camera.
Fire or electric shock may result.
AutoIP
Audio Compression Method
Audio Communication Method
Do not install in the following places:
•Places in strong direct sunlight, near heat-generating objects, or subject to high
temperatures
•Places near fire sources or flammable solvents (alcohol, thinner, fuel, etc.)
•Humid or dusty places
•Places subject to oily smoke or steam
•Places subject to sea air
•Confined or enclosed places
Iframe Interval
Simultaneous Client Access
Access Control
Encrypted Communications
Protocol
85.7 (3-3/8)
65
(2.56)
Check Included Items
46 (1-13/16)
83.5 (3-9/32)
20
(0.79)
try to install the camera yourself. Doing so may result in unforeseen
accidents such as dropping the camera or electric shock.
Warning
Max. Frame Rate
Camera Control
22 (0.87)
CautionRequest a professional installer for all camera installation work. Never
4-M3
(mounting
screw holes)
Installation Precautions
to rain or moisture.
46 (1-13/16)
83.5 (3-9/32)
85.7 (3-3/8)
Inappropriate handling against the instruction accompanied by
this sign may result in property damage. Be sure to observe these
precautions.
161 (6.34)
(when lens is fully vertical)
Important
13
10°
Caution
Video Quality
Frame Rate*2
0)
20
(0.79)
WARNINGTo reduce a risk of fire or electric shock, do not expose this product
Caution
Inappropriate handling against the instruction accompanied by this
sign may result in injury. Be sure to observe these precautions to
ensure safety.
5.2
2(
45
(1.77)
* For the latest information (firmware and included software, user manuals, operating
environment, etc.), please refer to the Canon Web Site.
Warning
Inappropriate handling against the instruction accompanied by this
sign may result in death or serious injury. Be sure to observe these
warnings to ensure safety.
Junction Box Plate
e
Thank you for purchasing Canon Network Camera VB-H41/VB-H41B/VB-M40/VB-M40B (hereafter
referred to as the camera).
The only difference between VB-H41/VB-M40 and VB-H41B/VB-M40B is the exterior color.
Be sure to read “Installation Guide” (this document) and “Operation Guide” (included in the Setup
CD-ROM) before use.
This “Installation Guide” explains the installation method of the camera using the ceiling mount
cover (sold separately). Be sure to read the “Safety Precautions” section for correct use. After
reading this Installation Guide, keep it in a readily accessible location for future reference.
For the installation method of this camera using the indoor dome housing (sold separately),
please read the “Installation Guide” included with the indoor dome housing.
The detailed procedures for using this camera are explained in the “Operation Guide”. Read
these guides carefully before using the camera to ensure correct use.
VB-H41/VB-H41B/VB-M40/VB-M40B
) g
17 an
2. r
(R le )
5 sib ion
R5 pos ot
( fm
o
Installation Guide
This Installation Guide uses the following marks to indicate important information the
user should know in order to use the product safely. Be sure to observe these items.
Video Compression Method
Video Size
160 (6.30)
/
External Dimensions
18
48
(0.71) (1.89)
Network Camera
Server
Symbols Indicating Safety Precautions
155 (6.10)
112.5 (4.43)
(when lens is horizontal)
ENGLISH
Image Sensor
Number of Effective Pixels
Scanning Method
Lens
Focal Length*1
F-number
Viewing Angle
Day/Night Switch
Min. Subject Illumination
Day Mode (color)
1/3 type CMOS (primary color filter)
Approx. 2.1 million pixels
Approx. 1.3 million pixels
Progressive
20x optical (12x digital) zoom lens with auto focus
20x optical (4x digital) zoom lens with auto focus
4.7 (W) – 94 mm (T)
F1.6 (W) – F3.5 (T)
Horizontal: 60.4° (W) – 3.2° (T), Vertical: 35.1° (W) – 1.8° (T)
Horizontal: 55.4° (W) – 2.8° (T), Vertical: 42.3° (W) – 2.2° (T)
Auto/Manual
.4 lux (F1.6, shutter speed 1/30 sec., when smart shade control is off, 50IRE)
0
0.03 lux (F1.6, shutter speed 1/2 sec., when smart shade control is off, 50IRE)
0.01 lux (F1.6, shutter speed 1/2 sec., when smart shade control is on, 50IRE)
0
.4 lux (F1.6, shutter speed 1/30 sec., when smart shade control is off)
0.1 lux (F1.6, shutter speed 1/8 sec., when smart shade control is off)
0.03 lux (F1.6, shutter speed 1/8 sec., when smart shade control is on)
Night Mode (monochrome)
0.02 lux (F1.6, shutter speed 1/30 sec., when smart shade control is off, 50IRE)
0.002 lux (F1.6, shutter speed 1/2 sec., when smart shade control is off, 50IRE)
0.001 lux (F1.6, shutter speed 1/2 sec., when smart shade control is on, 50IRE)
0
.01 lux (F1.6, shutter speed 1/30 sec., when smart shade control is off)
0.002 lux (F1.6, shutter speed 1/8 sec., when smart shade control is off)
0.001 lux (F1.6, shutter speed 1/8 sec., when smart shade control is on)
Focus
Auto/One-shot AF/Manual/Fixed at infinity
Shooting Distance Day Mode: 0.3 m (12 in.) – infinity (W), 1.0 m (3.3 ft.) – infinity (T)
(from front of lens)Night Mode: 1.0 m (3.3 ft.) – infinity (W), 1.5 m (4.9 ft.) – infinity (T)
When [Use] is selected for [Dome]:
Day Mode: 2.0 m (6.6 ft.) – infinity (W, T)
Night Mode: 1.0 m (3.3 ft.) – infinity (W), 2.2 m (7.2 ft.) – infinity (T)
1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000,
Shutter Speed
1/4000, 1/8000, 1/16000*4 sec.
Exposure
Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/Manual (Shutter Speed, Aperture,
Gain)
White Balance
Auto/Light Source (Daylight Fluorescent/White Fluorescent/Warm Fluorescent/
Mercury Lamp/Sodium Lamp/Halogen Lamp)/Lock (One-shot WB)/Manual
Metering Mode
Center-Weighted/Average/Spot
Exposure Compensation
9 levels
7 levels
Smart Shade Control
7 levels (increases the brightness of shaded subjects in a video)
5 levels
AGC Limit
Image Stabilizer
2 levels (digital)
Pan Angle Range
340° (±170°)
Tilt Angle Range
100º (ceiling-mounted position: -90º – +10º) When the horizontal direction of the
camera is 0°
Moving Speed
Pan: Max. 150º/sec. Tilt: Max. 150º/sec.
Event Notification
On-Screen Display
Daylight Saving Time
Language
JPEG, H.264
JPEG: 1920 x 1080, 960 x 540, 480 x 270, 320 x 240
H.264: 1920 x 1080, 960 x 540, 480 x 270
JPEG: 1280 x 960, 640 x 480, 320 x 240, 160 x 120
H.264: 1280 x 960, 640 x 480, 320 x 240
JPEG, H.264: 5 levels
JPEG: 0.1 – 30 fps
H.264: 1/2/3/5/6/10/15/30 fps
H.264: 10/15/30 fps
1920 x 1080 (when streaming): 30 fps
1280 x 960 (when streaming): 30 fps
0.5/1/1.5/2/3/4/5 sec.
Max. 30 Clients + 1 Admin Client
H.264: Max. 10 Clients
Administrator, Authorized user, Guest user (level of control varies depending on
user)
Max. 50 user names and passwords registered for authorized users.
User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
SSL/TLS, IPsec (Auto Key Exchange/Manual)
IPv4:TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client),
DNS (Client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP,
WV-HTTP (Canon proprietary), ONVIF
IPv6:TCP/IP, UDP, HTTP, FTP, SMTP (Client), DHCPv6 (Client) *4, DNS (Client),
ICMPv6, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon
proprietary), ONVIF
Available
G.711 μ-law (64 kbps)
Full-duplex (two-way) Echo cancellation function compliant
Sound Transfer Protocol by Canon
Available (audio files can be played back when an event is triggered by the
intelligent function or external device input.)
Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9
colors)
Available
Max. 20 positions (Preset Tour capable)
<Video>
Detection Types: moving object detection, abandoned object detection, removed
object detection, camera tampering detection, and passing detection*4
Detection Settings: Max. 15
<Volume>
Volume Detection
External Device Input, Intelligent Function (Video), Intelligent Function (Volume),
Timer
FTP/HTTP/SMTP (e-mail)
Temporary storage memory in camera: Max. approx. 5MB
Max. approx. 4MB
Frame Rate: Max. 10 fps
HTTP/SMTP (e-mail)
Available
Available
English/German/French/Italian/Spanish/Japanese
“ONVIF” is trademarks of ONVIF Inc.
Interface
Network Terminal
LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex))
3.5 mm ( 0.14 in.) mini-jack connector (monaural)
Audio Input Terminal
(common for LINE IN & MIC IN) Switch LINE IN/MIC IN in the setting page.
LINE IN x 1 (connect to an amplifier microphone) or
MIC IN x 1 (connect to a microphone w/o amplifier)
Audio Output Terminal
3.5 mm ( 0.14 in.) mini-jack connector (monaural)
(LINE OUT)
LINE OUT x 1 (connect to an amplifier speaker)
Input x 2, Output x 2
External device I/O Terminal
Memory Card
SD Memory Card, SDHC Memory Card, SDXC Memory Card*4 compatible.
Max. approx. 32 GB
Capacity:
Frame Rate: Max. 1 fps
Others
Operating Environment
Power Supply
Power Consumption
Dimensions
Weight
Temperature: -10°C – +50°C (+14°F – +122°F), Humidity: 5% – 85% (without
condensation)
PoE: PoE power supply via LAN connector (IEEE802.3af compliant)
AC adapter: PA-V17 (100 – 240 V AC) (sold separately)
External power source: 24 V AC/12 V DC
When using PoE:
Max. approx. 9.2 W
Max. approx. 9.8 W
When using AC Adapter PA-V17:
Max. approx. 10.7 W
Max. approx. 12.5 W
Max. approx. 10.6 W
When using DC:
Max. approx. 8.6 W
Max. approx. 9.8 W
When using AC:
Max. approx. 8.8 W
( x H) 132 x 155 mm ( 5.20 x 6.10 in.)
Camera only (height when camera is placed horizontally, excluding Ceiling Bracket)
Approx. 1150 g (2.535 lb.) (Camera only)
Approx. 1140 g (2.514 lb.)
Approx. 270 g (9.6 oz.) (Ceiling Plate, Ceiling Mount Cover)
Approx. 108 g (3.9 oz.) (Junction Box Plate)
*1 (W): maximum wide angle, (T): maximum telephoto
*2 The frame rate may be reduced due to Viewer PC’s specs, the number of clients accessing at the same time,
network loads, image quality setting, type or movement of the subject or other reasons.
*3 A third-party amplifier speaker is necessary.
*4 VB-H41 specific function
3
Installing the Camera
The following explains the procedures to install the camera on a ceiling using the Ceiling Mount
Cover SS40-S-VB/SS40-B-VB (sold separately).
Before installing the camera, set the IP address and other network information on the camera
using the “VB Initial Setting Tool” on the Setup CD-ROM.
For details on how to operate the “VB Initial Setting Tool”, see “Operation Guide”.
Fixing screw
M3 × 4
(included)
Recommended Power Cables [Reference]
Part Names
Cable (AWG)
Front
LED
The blue LED light comes on.
• On: when powered on, during reboot, during normal use
• Off: when [Turn Off] is selected (see “Operation Guide” > “Setting
Page” > “Installation Conditions”)
1 Determine an installation position for the camera and drill holes in the ceiling
* When [Turn Off] is selected, the LED light will come on for several seconds
when the camera is powered on and during reboot.
Use the template included with the ceiling mount cover (sold separately) to determine the
positions of the fixing screw holes and wiring hole (43 x 84 mm (1.7 x 3.3 in.)) according to the
camera orientation. Next, cut out the wiring hole, and drill the fixing screw holes in the ceiling.
Rear
Power connection terminal
Audio input terminal (dual LINE IN and MIC IN)
External Device I/O Terminals
Important
Audio output terminal (LINE OUT)
Reset Switch
If a wiring hole cannot be opened in a concrete ceiling, etc., secure the wiring to a comparable location.
Turn on the power while pushing this switch using a sharp object.
Continue to push the switch for 5 seconds or more to restore all
factory settings except for the date and time.
4 Fix the ceiling plate to the ceiling
Junction box plate
Fixing screw
M3 x 4
(included)
Ceiling Plate
Fixing screw
M3 x 4
(included)
Bottom
Fix the ceiling plate to the ceiling at four points using the appropriate screws. The ceiling plate
has four diameter 4.5 mm ( 0.18 in.) screw holes. Use the appropriate screws for ceiling
mounting in accordance with the condition and material of the installation site.
Using an SD Memory Card
SD card slot
MAC address
Push the SD memory card as far as possible into the SD card slot.
Removing the card
Push the SD memory card in all the way until the card slightly pops out. Pinch the card and
remove.
Important
•Insert the SD memory card before installing the camera.
•Make sure the SD memory card is not write-protected.
•When using an SD memory card with the camera for the first time, it is recommended to format the card
after inserting it into the camera (see “Operation Guide” > “Setting Page” > “Memory Card”).
Accessories
Accessories can be purchased separately as necessary. A ceiling mount cover or indoor dome
housing is necessary to install the camera on a ceiling.
Ceiling Mount Cover SS40-S-VB/SS40-B-VB
This dedicated accessory is used to install the camera on a ceiling. The ceiling mount cover is
available in two colors: silver (SS40-S-VB) and black (SS40-B-VB).
Indoor Dome Housing DR41-C-VB/DR41-S-VB/DR40-C-VB/DR40-S-VB
This dedicated accessory lets you embed the camera into the ceiling. The dome is available in
two colors: clear (DR41-C-VB/DR40-C-VB) and smoked (DR41-S-VB/DR40-S-VB).
AC Adapter PA-V17
A dedicated AC adapter for this camera.
The camera's unique address. Write the address on the front of this
Installation Guide before installing the camera.
If AC Adapter PA-V17 (sold separately) or an external power supply is used, connect the
power connector to the camera.
Connect cables to external device I/O terminals and audio input/output terminals as
necessary.
Safety wire attachment
When installing the camera on a ceiling using the separately sold
ceiling mount cover or indoor dome housing, attach the safety wire
that comes with the separately sold product.
6 Install the ceiling mount cover
Serial number
Align the (O) mark on the ceiling mount cover with the (I) mark on the rear of the camera, and
turn the cover clockwise to the (I) position.
Check that the ceiling mount cover is securely attached.
Cutout section
If the cables cannot be stored above a ceiling made of concrete, etc., or if the cables
do not fit within the ceiling mount cover, bend the cutout section of the ceiling mount
cover using diagonal pliers, etc., to create a cutout through which to guide the cables.
The camera position is initiated (see “Operation Guide” > “Setting Page” > “Maintenance”).
Important
Inserting the card
1.03
( 0.041)
1.30
( 0.051)
12 V DC maximum cable length
m
(ft.)
5
(16.4)
9
(29.5)
14
(45.9)
23
(75.5)
32
(105.0)
24 V AC maximum cable length
m
(ft.)
11
(36.1)
18
(59.1)
29
( 95.1)
46
(150.9)
64
(210.0)
Use UL cable (UL-1015 or equivalent) for 12 V DC or 24 V AC wiring.
 AC Adapter
Use the dedicated PA-V17 AC adapter (sold separately).
•The camera does not have a power switch. Connecting and disconnecting the LAN cable (PoE power
supply), AC adapter, or external power supply plug turns the power ON and OFF, respectively.
•When the camera needs to be rebooted, perform the reboot operation from the camera setting page
(see “Operation Guide” > “Setting Page” > “Maintenance”).
External device I/O terminals consist of two input and output systems each. Viewer can be used
to check external device input status and control ouput to an external device (see “Operation
Guide” > “Selecting the External Device Output” and “Displaying Event Status”).
 External Device Input Terminals (IN1, IN2)
External device input terminals consist of two sets (IN1, IN2) of two terminals, with the negative
terminals connected to the camera interior GND. Connecting cables to the positive and negative
terminals and opening or closing the circuit notifies the Viewer.
Important
•When connecting sensors and switches, connect terminals that are electrically isolated from the
respective power and GND.
•Do not push the external device I/O terminal button with too much force. Doing so may cause the button
to remain pushed-in.
 External Device Output Terminals (OUT1, OUT2)
7 Reboot the camera when the installation is complete
SD card cover
Fixing screw hole for tripod
5 Connect the LAN cable to the camera through the wiring hole
Note
Place your fingers on the left and right holds of the SD card cover and pull to remove. To return the
SD card cover to the camera, use the same procedure in reverse.
16
0.82
( 0.032)
External Device I/O Terminals
Securely attach the safety wire to an anchor or structure. After securing one end of the safety
wire to the ceiling, secure the other end to the camera using the screw that is fastened to the
camera.
Use the junction box plate (included with
the ceiling mount cover (sold separately)) to
mount the camera to the junction box.
Attach the junction box plate to the
junction box with screws that match the
screw holes in the junction box.
Mount the ceiling plate to the camera
using the four included fixing screws
(M3).
Attach the ceiling plate to the junction
box plate using four included fixing
screws (M3).
Turn the ceiling mount cover over the
ceiling plate to fix it in place.
18
0.65
( 0.026)
100BT LAN connector
3 Secure the safety wire
Attaching to a Junction Box
20
0.52
( 0.020)
Note
Lens
Camera head
Fix the ceiling plate to the camera with the four screws (M3) included with the ceiling mount cover
(sold separately).
6
22
mm
(in.)
SD card cover
2 Attach the ceiling plate to the camera
4
24
Conductor size
The camera can be installed in the upright position. Attach commercial anti-slip guards to the base of the
camera and set on a flat, stable surface without inclination, or fix the camera to a tripod, etc. Be sure to use
a tripod with mounting screws shorter than 5.5 mm (0.22 in.). Using a tripod with mounting screws 5.5 mm
(0.22 in.) or longer may damage the camera. Also, use a tripod with a base diameter of 30 mm (1.18 in.) or
more.
Notes on Power Supply
Warning
•Only use the dedicated AC Adapter PA-V17 (sold separately) for AC power.
•Do not set any heavy objects on the power cable.
•Do not pull, forcibly bend, scratch, or modify the power cable.
•Do not cover or wrap the AC adapter (sold separately) with cloth or blankets.
Fire or electric shock may result.
Be sure to read the user manual for the PA-V17 (sold separately) before use.
Caution
•Never touch the camera head during initialization. Initialization failure or malfunction
may result.
•After turning off the power, wait for at least five seconds before turning the power on
again. If the power is turned on again too quickly, the camera may operate poorly.
The camera's serial number. Write the number on the front of this
Installation Guide before installing the camera.
Connecting the Camera
Power Connection
Power can be supplied to the camera in the three ways described as follows.
 PoE (Power over Ethernet)
The camera supports PoE functions. Power can be supplied to the camera by using a LAN cable
to connect it to a PoE HUB that conforms to the IEEE 802.3af standard.
Important
•Check with your dealer for more information about PoE HUB and Midspan technology.
•Some PoE HUBs allow current limits for each port, but applying limits may interfere with performance. If
using this type of PoE HUB, do not limit the operating current.
•Some PoE HUBs have total consumption current limits for ports, which can interfere with performance
when multiple ports are in use. For more information, check the instruction guide for your PoE HUB.
•Use a category 5 or higher cable 100 m (328 ft.) or less in length for the LAN cable that connects the
camera and the PoE HUB.
•When the camera is connected to a switching HUB, changing the connection while the camera is
operating may cause the HUB learning function to interfere with communication. Do not change the
connection when the camera is operating.
•The camera can also be connected to an AC adapter (sold separately) while receiving power from
a PoE HUB. In such cases, the PoE power supply is given priority, and the camera does not use the
power supply from the AC adapter (sold separately). When the PoE power supply is disconnected,
power is supplied automatically from the AC adapter (sold separately). Midspan (a LAN cable power
supply device) is a device that, like a PoE HUB, supplies power to the camera via a LAN cable.
External device output terminals consist of two sets (OUT1, OUT2) of two terminals. The sets
have no polarity. Controls from the viewer can be used to open and close the circuit between the
terminals. Using optical couplers, the output terminals are isolated from the camera's internal
circuit.
The load connected to the output terminals should be within the following rating range.
Rating between output terminals:
Internal Connection Diagram
Maximum voltage 50 V DC
+3.3 V
Continuous load current at or below 100 mA
1 kΩ
10 kΩ
10 kΩ
On resistance: Max. 30 Ω
Note
Adaptive wiring for external device cables
Solid conductor AWG: No. 28 – 22
Conductor size: 0.32 – 0.65 mm ( 0.013 – 0.026 in.)
Cable strip should be approx. 8 – 9 mm (0.315 – 0.354
in.)
Internal controller
2
External device
0.1 µF
Input terminal
IN1, IN2
External device
Output terminal
OUT1, OUT2
Audio Input/Output Terminals
Each audio input/output terminal has one input system and one output system.
Connecting the camera to an audio input/output device such as a microphone or a speaker with
an amplifier allows you to send/receive audio through the viewer.
 Audio Input Dual LINE IN/MIC IN (monaural input)
Although the camera has a single audio input system, it supports two types of microphone input:
LINE IN and MIC IN. Before using the audio input, change [Audio Input] on the Setting Page (see
“Operation Guide” > “Audio Input”). LINE IN is selected by default.
Input terminal: 3.5 mm ( 0.14 in.) mini jack (monaural)
•Dynamic MIC IN
Input impedence: 1.75 kΩ ±20%
* Supported microphones: Output impedence: 400 Ω – 600 Ω
•Condenser MIC IN
Input impedence (microphone bias resistance): 2.2 kΩ ±20%
Microphone power supply: plug-in power (voltage: 1.8 V)
* Supported microphones: Condenser microphones with plug-in power support
•LINE IN
Input level: up to 1 Vp-p
* Use a microphone with an amplifier.
 External Power Supply
 Audio Output Terminal LINE OUT (monaural output)
12 V DC or 24 V AC input can be used.
Connect the included power connector as shown below.
Connect the camera to a speaker with an amplifier. Audio can be sent to the speaker from Viewer.
Output terminal: 3.5 mm ( 0.14 in.) mini jack (monaural)
Output level: up to 1 Vp-p
* Use a speaker with an amplifier.
Screwdriver
Tightening torque: 0.2 N·m
(max.)
For 12 V DC and 24 V AC input, use a power supply insulated
from 100 V AC.
12 V DC can be connected in a non-polar configuration.
Strip
Important
Approx. 4 – 6 mm
(0.16 – 0.24 in.)
Power connector
(included)
•The power supply should be within the following voltage range.
•24 V AC: Voltage fluctuation within ±10% of 24 V AC (50 Hz or
60 Hz ±0.5 Hz or less)
Current supply capacity of at least 1.0 A per camera
•12 V DC: Voltage fluctuation within ±10% of 12 V DC
Current supply capacity of at least 1.5 A per camera
•When using a 12 V DC battery power supply, be sure to connect
resistors of at least 0.5 – 1.0 Ω/20 W in series to the power line.
•For an external power supply, use a double-insulated device.
Important
•Using incorrect settings for [Audio Input] may damage the camera and/or microphone. Be sure to
configure the settings correctly.
•Microphone characteristics may affect volume and sound quality.
•Images and audio do not always synchronize properly.
•Audio may be interrupted depending on PC characteristics and network environment.
•Video and audio can be streamed to up to 30 clients. However, audio may be interrupted when
streaming to many clients or using SSL.
•Audio may be interrupted when using antivirus software.
•Connecting and disconnecting the LAN cable interrupts the audio. Use the viewer to reconnect.
