A7V8X-LA specification summary
CPU
Socket A for AMD Athlon™/Athlon™XP 3000+ processor
Barton core support
Chipset
VIA KM400
VIA VT8237
Front Side Bus (FSB)
333/266MHz
Memory
2 x 184-pin DDR DIMM sockets support up to maximum 2GB
unbuffered PC2700/2100/1600 non-ECC DDR SDRAM
memory
Expansion slots
3 x PCI
1 x AGP 8X/4X (1.5V)
Storage
2 x UltraDMA100 IDE connectors
2 x Serial ATA connectors
Integrated Graphics
Integrated VIA UniChrome™ Graphics
Audio
Realtek ALC658 6-channel AUDIO CODEC
Digital audio via an S/PDIF out interface
LAN
Southbridge integrated 10/100 Mbps LAN controller and
VT6103 LAN PHY
IEEE 1394
VIA VT6307 supports two IEEE 1394 ports
Hardware Monitoring
Super I/O integrated monitoring of CPU/chassis fan and
MB/CPU temperature
Rear Panel I/O Ports
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x RJ45 port
1 x Audio I/O
1 x VGA port
1 x IEEE 1394 port
4 x USB 2.0/1.1
Internal I/O
Connectors
2 x USB connectors support additional 4 USB 2.0 ports
1 x IEEE 1394 connector for an additional IEEE 1394 port
CPU/chassis fan connectors
20-pin ATX power connector
Front panel connector
CD/AUX connectors
Front panel audio connector
S/PDIF out connector
(Continued next page)
iii
A7V8X-LA specification summary
BIOS features
4Mb Flash ROM, Award BIOS, Enhanced ACPI, DMI2.0,
Green, PnP features
Industry standard
PCI 2.2, USB 2.0/1.1
Manageability
WOL, WOR, Wake on KB, Wake on PS/2 mouse
Support CD contents
Device drivers
ASUS PC Probe
ASUS Screensaver
Award BIOS Flash Utility
Microsoft® Direct X
Adobe Acrobat Reader
Trend Micro™ PC-cillin 2002
Accessories
User Guide
ASUS A7V8X-LA support CD
UltraDMA cable
FDD cable
I/O shield
Form Factor
Micro-ATX form factor: 9.6 in x 9.6 in
* Specifications are subject to change without notice
iv
1. Motherboard layout
24.5cm (9.6in)
PS/2KBMS
T: Mouse
B: Keyboard
CPU_FAN
Socket 462
VIA
VT6307
24.5cm (9.6in)
FLOPPY
FRONT_1394
Top:Line In
Center:Line Out
Below:Mic In
SECONDARY_IDE
USB2.0
Top:
T: USB3 RJ-45
B: USB4
PRIMARY_IDE
VIA
KM400
CHA_FAN
ATX Power Connector
ATX12V
Bottom:
T:USB1 Top:
B:USB2 1394
DDR DIMM2 (64 bit,184-pin module)
VGA
DDR DIMM1 (64 bit,184-pin module)
PARALLEL PORT
COM1
Accelerated Graphics Port (AGP1)
SATA2
PCI1
SATA1
SPDI/F
VIA
VT8237
PCI2
Super
I/O
AUX-IN
CD-IN
ALC658
PCI3
FRONT_AUDIO
CLPWD
FRONT_USB1
FRONT_USB2
ASUS A7V8X-LA Motherboard
BAT1
CLRTC
BUZZER
FRONT_PANEL
A7V8X-LA (KAMET2)
4MB
Flash
ROM
VIA
VT6103
1
2. Central Processing Unit (CPU)
The motherboard comes with a Socket A (462) for the AMD processor. AMD
processors offer gigahertz speeds to support all latest computing platforms and
applications. The A7V8X-LA supports AMD Athlon™/Athlon XP™ 3000+
processors. This motherboard also supports 333/266MHz front side bus (FSB),
and allows data transfers of up to 2.7GB/s with PC2700 DDR.
Each AMD CPU has a “marked” corner. This corner is usually indicated with a
notch and/or a golden square or triangle. Refer to this indicator while orienting the
CPU. A fan and a heatsink should be attached to the CPU to prevent overheating.
CPU NOTCH
TO INNER
CORNER
LOCK
LEVER
A7V8X-LA (KAMET2)
AMD™ CPU
CPU NOTCH
A7V8X-LA (KAMET2) Socket 462
Installing the CPU
Follow these steps to install a CPU.
1. Locate the Socket 462 and open it by
pulling the lever gently sideways
away from the socket. Then lift the
lever upwards. The socket lever
must be fully opened (90 to 100
degrees).
2. Insert the CPU with the correct
orientation. The notched or golden
corner of the CPU must be oriented
toward the inner corner of the socket
base nearest to the lever hinge.
The CPU fits only in one correct orientation. DO NOT force the CPU into the
socket to prevent bending the pins and damaging the CPU!
2
ASUS A7V8X-LA Motherboard
3. System memory
The motherboard comes with two Double Data Rate (DDR) Dual Inline Memory
Module (DIMM) sockets. These sockets support up to 2GB system memory using
184-pin unbuffered non-ECC PC2700/PC2100/PC1600 double-sided DDR DIMMs.
DIMM2
A7V8X-LA (KAMET2)
DIMM1
80 Pins
104 Pins
The following figure illustrates the location of the DDR DIMM sockets.
A7V8X-LA (KAMET2) 184-Pin DDR DIMM Sockets
CAUTION: DIMMs are keyed to fit with only one direction. DO NOT force a
DIMM into a socket to avoid damaging the DIMM.
Installing a DIMM
You may install 64MB, 128MB, 256MB, 512MB, and 1GB DDR DIMMs into the
DIMM sockets using the memory configurations in this section.
Make sure to unplug the power supply before adding or removing DIMMs or
other system components. Failure to do so may cause severe damage to both
the motherboard and the components.
Follow these steps to install a DIMM.
DDR DIMM notch
1. Unlock a DIMM socket by pressing
the retaining clips outward.
2. Align a DIMM on the socket such
that the notch on the DIMM
matches the break on the socket.
3. Firmly insert the DIMM into the
socket until the retaining clips
snap back in place and the DIMM
is properly seated.
Unlocked Retaining Clip
ASUS A7V8X-LA Motherboard
3
4. Expansion slots
The motherboard has three PCI slots and one Accelerated Graphics Port (AGP) slot.
To install and configure an expansion card:
1. Install an expansion card following the instructions that came with the chassis.
2. Turn on the system and change the necessary BIOS settings, if any.
3. Assign an IRQ to the card. Refer to the tables below.
4. Install the drivers and/or software applications for the expansion card
according to the card documentation.
Standard interrupt assignments
*
IRQ
Priority
Standard Function
0
1
System Timer
1
2
Keyboard Controller
2
N/A
Programmable Interrupt
3*
11
Communications Port (COM2)
4*
12
Communications Port (COM1)
5*
13
Sound Card (sometimes LPT2)
6
14
Floppy Disk Controller
7*
15
Printer Port (LPT1)
8
3
System CMOS/Real Time Clock
9*
4
ACPI Mode when used
10*
5
IRQ holder for PCI steering
11*
6
IRQ holder for PCI steering
12*
7
PS/2 Compatible Mouse Port
13
8
Numeric Data Processor
14*
9
Primary IDE Channel
15*
10
Secondary IDE Channel
These IRQs are usually available for ISA or PCI devices.
IRQ assignments for this motherboard
PCI slot 1
PCI slot 2
PCI slot 3
AGP slot
Onboard 1394 controller
4
A
shared
––
––
shared
––
B
––
shared
––
––
––
C
––
––
shared
––
––
ASUS A7V8X-LA Motherboard
D
––
––
––
––
shared
PCI slots
There are three (3) 32-bit PCI slots on this motherboard. The slots support PCI
cards such as a LAN card, SCSI card, USB card, and other cards that comply with
PCI specifications. The figure below shows a typical PCI card installed into a slot.
AGP slot
This motherboard has an Accelerated Graphics Port (AGP) slot that supports
AGP 8X/4X cards. When you buy an AGP card, make sure that you ask for one
with +1.5V specification.
Note the notches on the card golden fingers to ensure that they fit the AGP slot on
your motherboard.
Install only +1.5V AGP cards on this motherboard!
A7V8X-LA (KAMET2)
Keyed for 1.5v
A7V8X-LA (KAMET2)
Accelerated Graphics Port (AGP)
ASUS A7V8X-LA Motherboard
5
5. Jumpers
1. Clear CMOS (3-pin CLRTC)
This jumper allows you to clear the RAM data in CMOS, except the system
date and time. The RAM data in CMOS, is powered by the onboard button cell
battery.
To erase the CMOS RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 2-3 (Default) to pins 1-2 (Clear CMOS).
Keep the cap on pins 1-2 for about 5~10 seconds, then move the cap back
to pins 2-3.
3. Plug the power cord and turn ON the computer.
4. Hold down the <F1> key during the boot process and enter the BIOS setup
to re-enter data.
Except when clearing the CMOS RAM, never remove the jumper cap on CLRTC
jumper default position. Removing the cap will cause system boot failure!
CLRTC
1 2
A7V8X-LA (KAMET2)
Clear CMOS
2 3
Normal
(Default)
A7V8X-LA (KAMET2) Clear RTC RAM
6
ASUS A7V8X-LA Motherboard
2. Clear Password (3-pin CLPWD)
This jumper allows you to clear the BIOS setup password.
To erase the BIOS setup password:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 2-3 (Default) to pins 1-2 (Clear Password).
Keep the cap on pins 1-2 for about 5~10 seconds, then move the cap back
to pins 2-3.
3. Plug the power cord and turn ON the computer.
4. Hold down the <F1> key during the boot process and enter the BIOS setup
to set a new password.
CLPWD
A7V8X-LA (KAMET2)
1 2
Clear Password
2 3
Normal
(Default)
A7V8X-LA (KAMET2) Clear Password Setting
ASUS A7V8X-LA Motherboard
7
6. Connectors
This section describes and illustrates the internal connectors on the motherboard.
1. Floppy disk drive connector (34-1 pin FLOPPY)
This connector supports the provided floppy drive ribbon cable. After
connecting one end to the motherboard, connect the other end to the floppy
drive. (Pin 5 is removed to prevent incorrect insertion when using ribbon cables
with pin 5 plug.)
FLOPPY
NOTE: Orient the red markings on
the floppy ribbon cable to PIN 1.
A7V8X-LA (KAMET2)
PIN 1
A7V8X-LA (KAMET2) Floppy Disk Drive Connector
2. ATX power connectors (20-pin ATXPWR; 4-pin ATX12V)
These connectors connect to an ATX 12V power supply. The plugs from the
power supply are designed to fit these connectors in only one orientation. Find
the proper orientation and push down firmly until the connectors completely fit.
Make sure that your ATX 12V power supply can provide 8A on the +12V lead
and at least 1A on the +5-volt standby lead (+5VSB). The minimum
recommended wattage is 230W, or 300W for a fully configured system. The
system may become unstable and may experience difficulty powering up if the
power supply is inadequate.
ATXPWR
A7V8X-LA (KAMET2)
+12.0VDC
+5VSB
PWR_OK
COM
+5.0VDC
COM
+5.0VDC
COM
+3.3VDC
+3.3VDC
+5.0VDC+12V DC
GND
+5.0VDC
-5.0VDC
COM
COM
COM
PS_ON#
COM
-12.0VDC
+3.3VDC
A7V8X-LA (KAMET2) ATX Power Connectors
8
ATX12V
ASUS A7V8X-LA Motherboard
+12V DC
GND
3. IDE connectors (40-1 pin PRIMARY_IDE, SECONDARY_IDE)
This connector supports the provided UltraDMA IDE hard disk ribbon cable.
Connect the cable’s blue connector to the primary (recommended) or secondary
IDE connector, then connect the gray connector to the UltraDMA100 device
(hard disk drive) and the black connector to the UltraDMA100 master device. It is
recommended that you connect non-UltraDMA100 devices to the secondary IDE
connector. If you install two hard disks, you must configure the second drive as a
slave device by setting its jumper accordingly. Refer to the hard disk
documentation for the jumper settings. BIOS supports specific device bootup. If
you have more than two UltraDMA100 devices, purchase another UltraDMA
cable. You may configure two hard disks to be both master devices with two
ribbon cables – one for the primary IDE connector and another for the secondary
IDE connector.
Pin 20 on each IDE connector is removed to match the covered hole on the
UltraDMA cable connector. This prevents incorrect orientation when you
connect the cables.
2.
The hole near the blue connector on the UltraDMA cable is intentional.
PRIMARY_IDE
A7V8X-LA (KAMET2)
SECONDARY_IDE
1.
A7V8X-LA (KAMET2) IDE Connectors
NOTE: Orient the red markings
(usually zigzag) on the IDE
ribbon cable to PIN 1.
PIN 1
ASUS A7V8X-LA Motherboard
9
4. CPU and Chassis Fan Connectors (3-pin CPU_FAN, CHA_FAN)
The fan connectors support cooling fans of 350mA~740mA (8.88W max.) or a
total of 1A~2.22A (26.64W max.) at +12V. Connect the fan cables to the fan
connectors on the motherboard, making sure that the black wire of each cable
matches the ground pin of the connector.
Do not forget to connect the fan cables to the fan connectors. Lack of sufficient
air flow within the system may damage the motherboard components. These
are not jumpers! DO NOT place jumper caps on the fan connectors!
Rotation
+12V
GND
CPU_FAN
CHA_FAN
A7V8X-LA (KAMET2)
GND
+12V
Rotation
A7V8X-LA (KAMET2) Fan Connectors
5. Internal audio connectors (4-pin AUX-IN, CD-IN)
Aux-L Audio
Jack detect
AGND
Aux-R Audio
These connectors allow you to receive stereo audio input from sound sources
such as a CD-ROM, TV tuner, or MPEG card.
AUX-IN (White)
A7V8X-LA (KAMET2)
CD-IN (Black)
A7V8X-LA (KAMET2) Internal Audio Connectors
10
ASUS A7V8X-LA Motherboard
6. USB headers (10-1 pin FRONT_USB1)
If the USB ports on the rear panel are inadequate, a USB header is available
for additional USB ports. The USB header complies with USB 2.0 specification
that supports up to 480 Mbps connection speed. This speed advantage over
the conventional 12 Mbps on USB 1.1 allows faster Internet connection,
interactive gaming, and simultaneous running of high-speed peripherals. You
may connect a USB module to the USB header.
USB+5V
USB_P6USB_P6+
GND
NC
FRONT_USB2
USB+5V
USB_P6USB_P6+
GND
NC
FRONT_USB1
A7V8X-LA (KAMET2) USB Connectors
1
USB+5V
USB_P5USB_P5+
GND
1
USB+5V
USB_P5USB_P5+
GND
A7V8X-LA (KAMET2)
7. S/PDIF out connector (3-pin SPDI/F)
This connector is for an S/PDIF audio module that allows digital instead of
analog sound output. Connect one end of the audio cable to this connector and
the other end to the S/PDIF module.
Ground
SPDIFOUT
+5V
SPDI/F
A7V8X-LA (KAMET2)
A7V8X-LA (KAMET2) S/PDIF Connector
ASUS A7V8X-LA Motherboard
11
8. IEEE 1394 connector (10-1 pin FRONT_1394)
This connector is for a 10-to-6-pin 1394 serial connector cable that connects to
a 1394 module. Attach the 10-1 pin cable plug to this connector, and the 6-pin
cable plug to the 1394 module. You may also connect a 1394-compliant
internal hard disk to this connector.
NEVER connect a USB cable to any of the IEEE 1394 connectors. Doing so
will damage the motherboard!
1
A7V8X-LA (KAMET2)
TPA+
GND
TPB+
+12V
FRONT_1394
TPAGND
TPB+12V
GND
A7V8X-LA (KAMET2) IEEE 1394 Connector
The IEEE 1394 module is purchased separately.
9. Front audio connector (10-1 pin FRONT_AUDIO)
AUD_RET_L
AUD_GND
AUD_VCC
AUD_RET_R
This connector is for a chassis-mounted front panel headphone and MIC-IN
jack.
1
A7V8X-LA (KAMET2)
A7V8X-LA (KAMET2)
Front HeadPhone and MIC-IN Connector
12
AUD_MIC1
AUD_MIC2
AUD_FPOUT_R
AUD_MIC_JD
AUD_FPOUT_L
FRONT_AUDIO
ASUS A7V8X-LA Motherboard
10. Serial ATA connectors (7-pin SATA2, SATA1)
These next generation connectors support the thin Serial ATA cables for Serial ATA
hard disks. The current Serial ATA interface allows up to 150 MB/s data transfer
rate, faster than the standard parallel ATA with 133MB/s (Ultra ATA133).
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXP2
RSATA_RXN2
GND
SATA2
SATA1
A7V8X-LA (KAMET2) SATA Connectors
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXP1
RSATA_RXN1
GND
A7V8X-LA (KAMET2)
Important notes on Serial ATA
•
The Serial ATA cable is smaller and more flexible allowing easier
routing inside the chassis. The lower pin count of the Serial ATA
cable eliminates the problem caused by the wide, flat ribbon cables
of the Parallel ATA interface.
•
Hot plug support for Serial ATA drive and connections are not available in
this motherboard.
•
Adjust the necessary BIOS settings when using the Serial ATA interface.
•
Install Windows® XP™ Service Pack 1 when using Serial ATA.
ASUS A7V8X-LA Motherboard
13
11. System panel connector (10-1 pin FRONT_PANEL)
This connector accommodates several system front panel functions.
Power Button
PLED+
PLEDPWR
GND
Power LED
HDLED+
HDLEDGround
Reset
NC
FRONT_PANEL
A7V8X-LA (KAMET2)
HD LED
Reset
A7V8X-LA (KAMET2) Front Panel Connector
•
System Power LED Lead (2-pin PLED)
This 3-1 pin connector connects to the system power LED. The LED lights
up when you turn on the system power, and blinks when the system is in
sleep mode.
•
Hard Disk Activity LED Lead (2-pin HDLED)
This 2-pin connector is for the HDD LED cable. The read or write activities of the
device connected to the any of IDE connectors cause the IDE LED to light up.
•
ATX Power Switch / Soft-Off Switch Lead (2-pin PWRBTN)
This connector connects a switch that controls the system power. Pressing the
power switch turns the system between ON and SLEEP, or ON and SOFT
OFF, depending on the BIOS or OS settings. Pressing the power switch while
in the ON mode for more than 4 seconds turns the system OFF.
•
Reset Switch Lead (2-pin RESET)
This 2-pin connector connects to the case-mounted reset switch for rebooting
the system without turning off the system power.
14
ASUS A7V8X-LA Motherboard
