LEAK DETECTION
INDUSTRY LEADING SENSITIVITY
Pg 01
Visit us Online at www.cpsproducts.com
Leak Detection
LEAK-SEEKER®
Electronic Leak Detectors
LS1 & LS2 are PATENTED
CPS® PRODUCTS
8,555,701
LS2 (Featuring E_Mos Sensor Technology)
KEY FEATURES:
Specifications
LS1
LS2
Detector Type
Patented E_MOS
Detection Technology
Patented E_MOS
Detection Technology
Sensitivity
Better than a 0.1 oz / year
(3g / year)
Better than a 0.1 oz / year
(3g / year)
Operation Selection
Manaul Operation
Fully Automatic
Visual Display
Visual Tachometer-like bar
graph display w/ Eight High
Intensity LEDs
Visual Tachometer-like bar
graph display w/ Eight High
Intensity LEDs
Flex Probe
15.5” flexible probe for hard
to reach areas
15.5” flexible probe for hard
to reach areas
Operating Temp
-18 to 60˚C
(0 to 140˚F)
-18 to 60˚C
(0 to 140˚F)
Power
50 hour battery life
(3 C batteries)
50 hour battery life
(3 C batteries)
Weight
1 lb 2 oz (500 g)
1 lb 2 oz (500 g)
Warranty
1 years
2 years
LS1 & LS2 SPECIFICATIONS
• Microprocessor controlled sensor electronics
utilizing a multi channel signal detection method,
improves sensitivity while reducing false alarms.
• Patented E_MOS detection technology
incorporates a proprietary pulse modulation
design to increase both battery and sensor life.
• Software managed sensor rejuvenation mode,
automatically initiated at each start up ensures the
highest level of sensitivity every use, for up to 500
hours of detecting leaks of less than .1 oz per year.
• The LS2 is the world’s only leak detector with
fully automatic sensitivity selection and control.
• Meets or exceeds all US and International
standards for both automotive and
commercial use
• Superior sensitivity to R410A and new
HFO refrigerants
• Sensitivity to 35 parts per million
(less than .1 oz per year)
• Detects 5% Hydrogen Trace Gas Mixture.
• 50 hour battery life (3 C batteries)
• 500 hours sensor life
CPS® ELECTRONIC LEAK-SEEKER® LS1 & LS2
Spare Parts for E_Mos™ Sensors
Item
Description
EMOS2
Replacement Sensor for LS1 & LS2
LS2XF
Replacement Sensor Filters for LS1 & LS2
(10-Pk)
LS2XVF
Replacement Vapor Filter Sensing Tip for
LS1 & LS2
LS2XVF
EMOS2
CPS Products has raised the bar for leak detectors. The revolutionary
new E_MOS technology developed by CPS is more sensitive, stable and
accurate than any other detection method on the market, including
heated diode, corona, ultrasonic and halide torches. Introducing the
Leak Seeker II, simply turn it on and pinpoint the leak.
LS1 (Featuring E_Mos Sensor Technology)
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 02
Leak Detection
CPS® ELECTRONIC LEAK-SEEKER® LS790B
Combines the most advanced microcomputer circuitry with field
proven Ion-pump sensor technology creating a highly sensitive,
accurate electronic refrigerant leak detector. Over 100 computer
generated tones and a high intensity bar graph display quickly
alerts the user to varying halogen concentrations. Patented
automatic calibration design eliminates the need for manual
balance or tick rate adjustments while the user selectable 10
sensitivity ranges enables the LS790B to detect leaks of all
refrigerants.
LS790B
Visual Alarm Indicators
Patented Ion-Pump® Sensor
LS790B SPECIFICATIONS
LSXS3
Pg 03
Specifications
LS790B
Detector Type
Patented Ion-Pump sensor with built-in selective
filter housing
Sensitivity
Better than 0.25oz/yr (7g/yr) leak rate of HFC
Audible Alarms
128 computer generated tones to precisely guide
the user to the source of the leak.
Operation Selection
6 button keypad
Visual Display
High Intensity Bar Graph Display
Flex Probe
18” / 45.7cm long metal flex probe
Operating Temp
-18 to 60C (0 to 140˚F)
Power
40 hours batter life using
4 “AA” alkaline batteries.
Weight
1lb 2oz / 500g
Warranty
2 years
LSXBMK
LSXS
Spare Parts for LEAK-SEEKERS®
1= LS780A 2 = LS780B 3=LS790A 4=LS790B 5 = LS1&LS2
Item
Product
Description
LSXB
1,2,3,4
Battery compartment cover
LSXBMK
2,4
Maintenance Kit: (1)LSXS + (1)LSXSF
LSXC
1,2,3,4
Leather carrying case
LSXC3
5
Storage case LS1 & LS2
LSXE
1,2,3,4
Earphone
1,3
Maintenance kit
2 pcs/St. LSXS + 2 pcs/St. LSXVF
LSXS3
5
Sensor for LS1 & LS2
LSXS
1,2,3,4
Ion-pump sensor
LSXMK
LSXSF
2,4
Selective filter/housing
LSXSH
1,3
Aluminum Sensor housing
LSXVF
1,3
Water vapor filter
Visit us Online at www.cpsproducts.com
Item No.
Refrigerant Type
Replacement Sensor
RM12
R-12
RMX12
RM134
R-134
RMX12
RMX11
R-22
RMX12
RM404
R-404A
RMX12
RM407
R-407
RMX12
RM410
R-410A
RMX12
RM502
R-502
RMX12
RM507
R-507
RMX12
Item No.
Refrigerant Type
Replacement Sensor
RMX11
R-12
RMX12
RMX12
R-134
RMX12
100 to 1,000 ppm
ACCURACY
± 3% of the setting or ± 25 ppm
VISUAL ALARMS
High intensity LED display
AUDIBLE ALARM
85 db at 1 foot
OPERATING
TEMPERATURE
-20 to 150 F /-28 to 65 C
SENSOR MODULE
Relative Humidity 10 to 95% non-condensing
CONTROL MODULE
32 to 150 F / 0 to 65 C
POWER
AC or DC control voltages.
SENSOR FAILURE
INDICATOR
LED constantly illuminates
WEIGHT
1lb 2oz / 500g
WARRANTY
1 year
RM SPECIFICATIONS
RM
SENSITIVITY
Refrigerant Monitors
Compact, highly reliable, yet economical refrigerant leak monitoring
systems. Designed to monitor a single refrigerant in a single zone
providing early warning of costly and environmentally damaging
refrigerant leakage. Adjustable sensitivity settings between 100 to
1000PPM with an auxiliary 1⁄2 HP N.O. and N.C dry contact control
function for operating an additional alarm or other safety device.
Replacement sensors are interchangeable enabling the replacement
of a failed sensor directly in the field without recalibration,
minimizing “downtime.”
GAS-SEEKER® GS40 - Portable Combustible Gas Detector
The GS40 is a low maintenance, easy-to-use portable combustible gas leak detector
engineered to pinpoint leaks in residential, commercial and industrial appliances. Advanced
semiconductor sensor and electronic control package enables detection of gases commonly
found in service applications including; Carbon Monoxide, Natural Gas, Propane, Ammonia,
Methane, Acetone, Hydrogen and Iso-Butane, with a virtually instantaneous alarm response
period. Applications include the inspection of furnaces, valves, regulators, pipelines, meters
and other devices associated with combustible gases.
Detecting Range
0 - 100% LEL referenced to Methane.
Alarm Indication
Both visual and audible (>40db) alarm indicators
Low Level Alarm
Preset at 10% LEL
High Level Alarm
Preset at 30% LEL
Operating Conditions
0°F to 104°F / -20°C to +40°C at less than 98% RH (non-condensing)
Power
Working voltage is 3VDC using two 1.5V AA batteries.
Battery Life/Indicator
5 hrs continuous use. Orange LED constantly illuminates when battery is low
Sampling
Natural diffusion
Dimensions
7.2 x 0.71in / 183 x 18mm
Weight
5.3oz / 150g (including battery)
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
GS40
Pg 04
UV LEAK DETECTION
VISUAL LEAK INSPECTION
Pg 05
Visit us Online at www.cpsproducts.com
UVPRO UV Flashlight & Enhancing Glasses
The new and improved UVPRO light is the most compact
and efficient UV light we have ever designed. The nine
high intensity true UV LED’s are specifically engineered
to maximize the fluorescing capabilities of today’s most
commonly used dyes while greatly reducing the amount
of “nuisance” background blue light emitted. Its rugged
anodized aluminum body and o-ring sealed battery
compartment allows it to handle harsh field conditions
while small enough to conveniently fit in your pocket.
• 9 True UV emitting LED technology
• Rugged anodized aluminum body
• Works with all common dye additives
• Ultra Compact and lightweight
• Instant “ON” with no heat produced
• Operates on (3) AAA batteries (included)
UVPRO
Why BLUE is NOT Necessarily Cool?
CLEAR LENS
UV LED
TRUE UV LIGHT RAYS
UV LED’s produce only true and efficient UV Light.The CPS
UVPRO provides UV-A (Long wave UV)
325-375nm. Instant on LED provides the fastest leak
inspection of any light available.
*Light spectrum wavelengths in nanometers
UV LED TECHNOLOGY
A correctly tuned Ultra Violet (UV) lamp should
predominantly emit invisible UV light waves with only a
trace of visible “purple” or “blue” light. The small amount
of visible light is required to direct the user’s eyes to the
leak search area, while the invisible UV light rays actually
illuminate the leaking dye. Lamps that emit large amounts
of visible blue light have been marketed heavily as being
more powerful and more effective at fluorescing leaks,
backed by the obvious high output of visible light. Knowing
that UV dye additives requires invisible true UV light rays
to effectively fluoresce dispels this claim altogether. In
fact, special “blue blocking” glasses are required for use
with these high output blue lamps in order to remove the
nuisance blue light from the vision of the user during the
leak search process. Otherwise, the high output of light
will mask the actual leak or illuminating dye additive.
UV55 LED Refrigerant Leak Detection Kit
• UVPRO True UV emitting LED light technology
• Compact & Rugged anodized aluminum body
• Mess-free and easy to use Squeeze Gun™ injector
• 1 UVS2 universal OEM approved dye cartridge
• Includes 90° low side snap coupler
• Operates 8 continuous hours on
(3) AAA batteries (included)
UV55
UV55 Includes: UVPRO LED flashlight, squeeze gun injector
w/ hose, R-134a 90° low coupler, safety glasses, UVS2 dye
cartridge and carrying case.
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 06
COMPUTE-A-CHARGE
CHARGING SCALES
®
WORTH THEIR WEIGHT IN COLD
Pg 07
Visit us Online at www.cpsproducts.com
Charging Scales
Born in the USA:
CPS designs and manufactures its own products in
the United States, resulting in engineering excellence,
as well as consistent, industry leading quality and
reliability.
CC240RF
KEY FEATURES:
CC240RF
CC840RF
Working load capacity
240 lbs (110kg)
240 lbs (110kg)
Operating Temperature
14°F to +122°F / -10°C to +50°C
14°F to +122°F / -10°C to +50°C
Accuracy
0.05% of reading or ± 0.25oz / (±
10g) whichever is greater
0.05% of reading or +/- 0.25oz /
(+/-10g)
whichever is greater
Resolution
±0.25oz / ±10 grams
±0.25oz / ±10 grams
Overload Protection
Electronic and mechanical
Electronic and mechanical
Platform Dimensions
10.0” x 10.0” / 25.4cm x 25.4cm
10.0” x 10.0” / 25.4cm x 25.4cm
Weight
8 lbs 15 oz. (4.00 kg) with batteries
9.8lb / 4.5kg
Power
One 9V alkaline (ANSI 1604AC-IEC
6LR61) (display unit)Four AA alkaline
(ANSI 15A-IEC LR6) (scale platform)
One 9V alkaline (ANSI 1604AC-IEC
6LR61) (display unit)Four AA alkaline
(ANSI 15A-IEC LR6) (scale platform)
Battery Life
32 hours of continuous use
32 hours of continuous use
Battery Indicator
Battery symbol with 3 segment
display
Battery symbol with 3 segment
display
RF frequency range
2.4 GHz, ISM band, can be used
worldwide
2.4 GHz, ISM band, can be used
worldwide
RF Transmission range
30ft / 9m
30ft / 9m
Readout
Imperial / Metric
Imperial / Metric
Warranty:
1 year
1 year
Made in the USA
Yes
Yes
Progamable
No
Yes
CC240RF & CC840RF SPECIFICATIONS
• Operates in the international ISM band
for worldwide use.
• Advanced communication software
ensures uninterrupted connectivity
between hand-held display unit and
scale platform.
• Calibrated to strict NIST Standards at
our manufacturing facility in Hialeah, Fl.
• Accuracy specification exceeds all OEM
requirements for charging accuracy and
is twice as good as any competitive unit
on the market.
• Temperature compensated over the
entire operating temperature range
to maintain charging accuracy under
all ambient conditions.
• Selectable measurements in Imperial
or Metric units.
• Designed to withstand overloads
of 150%.
• High contrast wide angle LCD Display
for ease of viewing.
• Designed and manufactured in the USA
Specifications
CPS® PROGRAMMABLE WIRELESS
REFRIGERANT CHARGING SCALES :
CPS Products proudly introduces its new line
of cordless RF charging scales including the
world’s first fully automatic programmable RF
controlled unit featuring set it and forget it
software. For over 27 years Compute-A-Charge
has been the brand you can trust for performance accuracy and reliability.
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
CC840RF
Pg 08
Charging Scales
CPS® REFRIGERANT CHARGING SCALES :
With specifications exceeding all OEM requirements for charging
accuracy, Compute-A-Charge Scales are twice as good as any
competitive unit on the market. The Standard Series of
Compute-A-Charge scales are performance leaders in
accuracy, reliability and the Standard by which all others are
measured. The competition simply doesn’t measure up!
HIGH CAPACITY CHARGING SCALES :
CC220 & CC110 SPECIFICATIONS
High capacity 220lb/100kg Compute-A-Charge refrigerant
charging/recovery scale, calibrated to strict NIST standards. Fully
enclosed and removable metal scale platform enables use of
product in or out of the protective case. Large, highly visible 1
1⁄2” x 2”/37mm x 48mm high resolution LCD readout displays
either Imperial or Metric measurements in .25oz / 10g
increments. The ergonomic hand held remote incorporates 6ft
coil cord, a hanging hook and is backed with a magnet for
attaching to metal surfaces. Full mechanical and visual overload
protection. Operates 60 continuous hours on two 9V alkaline
batteries. Includes automatic off feature.
CC220
Specifications
CC220
CC800A
Working load
capacity
220 lbs (100kg)
220LB /100Kg
Operating Temp
14°F to +122°F / -10°C to +50°C
14ºF - 122ºF / -10ºC to 50ºC
Accuracy
0.05% of reading or +/- 0.25oz /
(+/- 10g)whichever is greater
0.05% of reading or +/- 0.25oz /
(+/- 10g) whichever is greater
Resolution
±0.25oz / ±10 grams
±0.25oz / ±10 grams
Overload Protection
Electronic and mechanical
Electronic and mechanical
Platform Dimensions
8 ¾” x 8 ¾” / 22.23cm x 22.23cm
8 3/4” x 8 3/4” 223 x 223mm
Weight
5.6lb / 2.55kg
8.5 lb/3.9 kg
Power
Two 9V batteries, included
Two 9V batteries, included
Battery Life
60 hours of continuous use
30 hours of continuous. Solenoid valve
lasts for 10,000 actuations.
Battery Indicator
Battery symbol with 3 segment display
Battery symbol with 3 segment display
Readout
Imperial / Metric
Imperial / Metric
Warranty
1 year
1 year
Made in the USA
Yes
Yes
Pg 09
Visit us Online at www.cpsproducts.com
Removable Platform
Robust
Handheld Remote
Rugged
Carrying Case
CPS® REFRIGERANT CHARGING SCALES :
With accuracy specifications exceeding all OEM
requirements for charging accuracy, that is twice as
good as any competitive unit on the market, the Standard
Series of Compute-A-Charge scales are Performance
Leaders in accuracy and reliability and the Standard by
which all others are measured. The competition simply
doesn’t measure up!
THE ONLY CHARGING SCALE
WITH 1G RESOLUTION
CC50
KEY FEATURES:
CC110 & CC50 SPECIFICATIONS
• Accuracy specification exceeds all
Specifications
CC50
OEM requirements for charging
accuracy and is twice as good as
55 lbs (25kg)
Working load
capacity
any competitive unit on the
market.
14°F to +122°F / -10°C to +50°C
Operating Temp
• Temperature compensated over
0.05% of reading or ± 0.05oz /
the entire operating temperature
Accuracy
(± 1g) whichever is greater
range to maintain charging
±0.05oz / ±1 gram
Resolution
accuracy under all ambient
conditions.
Electronic and mechanical
Overload Protection
• Environmentally sealed strain
8 ¾” x 8 ¾” / 22.23cm x 22.23cm
Platform Dimensions
gage beam load cell technology
5.6lb / 2.55kg
Weight
first introduced by CPS in 1985.
• Designed to withstand overloads
Two 9V batteries, included
Power
of 150%.
60 hours of continuous use
Battery Life
• High contrast wide angle LCD
Display for ease of viewing.
Battery symbol with 3 segment display
Battery Indicator
• Platform can be removed from
Imperial / Metric
Readout
carrying case.
1 year
Warranty
• Magnetic back on handheld unit.
• Hanging hook.
Yes
Made in the USA
• User selectable automatic power
off to conserve batteries.
• Designed and manufactured
in the USA
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 10
CHARGING STATIONS
COMPACT, FULLY EQUIPPED & READY-TO-GO
Pg 11
Visit us Online at www.cpsproducts.com
Charging Stations
PRO-SET® PORTABLE VACUUM / CHARGING STATIONS
PRO-SET charging stations combine all the necessary tools required
to perform a full system evacuation and subsequent charging in a single,
compact, mobile unit. Each station includes a Vortech or BlackMax
service manifold, a PRO-SET vacuum pump, a Compute-A-Charge
refrigerant scale and premium charging hoses. The lightweight tubular
steel frame incorporates rear wheels for easy transport to and from the
job site with integrated storage areas for all components.
• Unsurpassed Charging Accuracy of ± 0.05% of reading
• Hanging ports and hooks for hose storage
• Rear wheels on Frame for Ease of Mobility
• Contains all Tools Needed for Charging / Evacuation
• All Components Store Easily on Cart
Hard Mounted Manifolds
CS16DMV5D2P5E
Application
Manifold
Type
Refrig. Scales
Appliance / Light
Refrigeration
BlackMax 2 valve
Manifold (MBD)
R22, R134a, R404A
(2.5” / 68mm)
PSI / °F
CS12SMBDS5E
Air Conditioning
BlackMax 2 valve
Manifold (MBH)
R410A, R22, R404A
(2.5” / 68mm)
CS12DMV4H2P5E
Air Conditioning /
Refrigeration
Vortech 4 valve
Manifold (MV4H2)
CS16DMV4H2P5E
Air Conditioning /
Refrigeration
Vacuum
Pump
Scale
3-pk of 5ft / 150cm
Std. BV Hoses
Single Stage
2 CFM Pump
(50 microns)
220lb
Compute-A-Charge
Scale
PSI / °F
3-pk of 5ft / 150cm
Prem. BV Hoses
Single Stage
2 CFM Pump
(50 microns)
220lb
Compute-A-Charge
Scale
R22, R410A, R404A,
R134a (3.5” / 80mm)
PSI / °F
3-pk of 5ft / 150cm
Prem. BV Hoses
Two Stage
2 CFM Pump
(10 microns)
220lb
Compute-A-Charge
Scale
Vortech 4 valve
Manifold (MV4H2)
R22, R410A, R404A,
R134a (3.5” / 80mm)
PSI / °F
3-pk of 5ft / 150cm
Prem. BV Hoses
Two Stage
6 CFM Pump
(10 microns)
220lb
Compute-A-Charge
Scale
Refrigeration
Vortech 5 valve
Manifold (MV5D2)
R22, R134a, R404A
(3.5” / 80mm)
PSI / °F
3-pk of 5ft / 150cm
Prem. BV Hoses
Two Stage
6 CFM Pump
(10 microns)
220lb
Compute-A-Charge
Scale
Air Conditioning /
Refrigeration
Vortech 4 valve
Manifold (MV4T)
R22, R134a, R404A
(2.5” / 68mm)
kPa / PSI
/ °C
3-pk of 6ft / 180cm
Prem. Hoses & Cplrs.
Two Stage
2 CFM Pump
(10 microns)
100kg
Compute-A-Charge
Scale
CS12SMBHP5E
CS16DMV5D2P5E
CS12DMV4TP6Q
All Components Store
Easily on Cart
Hoses
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
CHARGING STATIONS SPECIFICATIONS
Press./
Temp.
Scales
Item
Rear wheels on Frame for
Ease of Mobility
Pg 12
ELECTRICAL
& SPECIALTY
METERS
MEASURE WITH CONFIDENCE
Pg 13
Visit us Online at www.cpsproducts.com
Captures the True
Motor InRush
Current
AC750 Probes
Includes
Built in
Data Logging
w/ Software
Electrical &
Specialty Meters
AC750 DIGITAL CLAMP METER
The AC750 is a Multi-Functional AC/DC Clamp Meter. The
AC750 hosts an array of enhanced features such as the
ability to capture True Inrush measurements, Non-Contact
Voltage Detection and Data Logging your output readings
to a PC (USB Connection cable included).
Description
Display:
6000 count dual display
Range Control
Auto range mode
Battery
9V battery one piece
Dimensions
225(W) x 86(H) x 33(D) mm
Weight
Approx. 320g
SPECIFICATIONS
AC750 Front
Specifications
AC750 KEY FEATURES:
• Versatile for testing AC/DC voltage, AC/DC current,
resistance and frequency
• True RMS AC measurement
• Max./Min. value measurement
• Audible continuity and diode test
• Non contact voltage detection
• Integrated clamp light and LCD backlight
• Auto zero key for DCA measurement
• Auto/Manual range, auto power off
• Secondary injection molded case, safety as
per IEC1010 1000V CAT III
AC750 Back
USB Data Connection
Built in Flashlight
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Extra Strength Grip Clamp
Pg 14
Electrical &
Specialty Meters
AM50 AIR VELOCITY METER
Precision vane type anemometer provides fast,
accurate air velocity measurements for use in
balancing HVAC systems or determining CFM
calculations. A convenient TYPE K thermocouple is
built-in to the remote vane providing quick
measurement of grille/duct outflow temperatures from
32 to 122 F / 0 to 50 C. Included, is an easy-to-read
laminated conversion chart that allows the user to
quickly convert air velocity measurements into CFM
calculations at a glance. Shipped with a rugged
carrying case and is CE approved.
SM150
SPECIFICATIONS
SM150 SOUND LEVEL METER
Pg 15
UNITS
RANGE
ACCURACY
Ft/Min
0-8800
±3% or 0.1
M/S
0-45
±3% or 0.1
km/Hr
0-140
±3% or 0.1
knots
0-88
±3% or 0.1
AM50
Professional grade sound level indicator designed to measure noise
levels from 35 to 130dB. The unit incorporates a large LCD,
maximum hold function, Over and Under range indicator, peak and
average response settings and A-C weighing for checking
compliance with standard safety regulations. Applications include
the monitoring of HVAC/R compressors, blowers, health and safety
requirements, environmental quality issues, offices, factory
machinery, airports, auditoriums and studio acoustics. Unit is CE
approved and includes carrying case.
EXAMPLES
SOUND
PRESSURE
LEVEL dBSPL
SOUND
PRESSURE
N/m2 = Pa
SOUND
INTENSITY
watts/m2
Jet aircraft, 50 m away
140
200
100
Threshold of pain
130
63.2
10
Threshold of discomfort
120
20
1
Chainsaw, 1m distance
110
6.3
0.1
Disco, 1 m from speaker
100
2
0.01
Diesel truck, 10m away
90
0.63
0.001
Curbside of busy road, 5m
80
0.2
0.0001
Vacuum cleaner, distance 1m
70
0.063
0.00001
Conversational speech, 1m
60
0.02
0.000001
Average home
50
0.0063
0.0000001
Quiet library
40
0.002
0.00000001
Quiet bedroom at night
30
0.00063
0.000000001
Background in TV studio
20
0.0002
0.0000000001
Rustling leaf
10
0.000063
0.00000000001
Threshold of hearing
0
0.00002
0.000000000001
TEMPERATURE &
SYSTEM MEASUREMENT
TOOLS THAT MEASURE UP
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 16
TempERATURE & System
Measurement
SH450 THERMOMETER / ANALYZER
The SH450 Total Systems Analyzer is quite possibly the most
versatile tool you will ever own. Measure pressure from -14.7
to 725 PSI, automatically calculate and display superheat, sub
cooling, relative humidity, wet bulb, dry bulb and dew point readings
in seconds. Display temperature differential between any 2 of 4
independent temperature channels. Record and display min/max
readings for any channel at the touch of a button. Scan all 4
temperature channels simultaneously. The SH450 is self contained
in a rugged polyethylene case with plenty of room to fit all your
accessory probes.
SH450 Superheat / Subcool Specifications
-14.7 PSIG to 725.0 PSIG (-100 kPa to 5000 kPa)
Pressure Accuracy
±1% of reading or ± 0.5 PSIG (± 3.5 kPa),
whichever is greater
Pressure Units
PSIG, kPa, BAR, Hg, kg/cm2
Proof Pressure
1000 PSI (7000 KPa)
Temperature
Accuracy
±0.4˚F / ±0.2˚C from 14.0˚F to 158˚F / -10.0˚C to 70˚C;
0.6˚F / 0.3˚C elsewhere in the range
Dew or Bubble
Saturation Temperature
±1.8˚F (±1.0˚C)
SH450 SPECIFICATIONS
Pressure Range
SH450 Thermo-Psychrometer Specifications
Measurement
Temperature Range
-40˚F to +300˚F (-40˚C to +150˚C). Actual temp range
depends on the probe being used.
Temperature
Resolution
±0.1˚F or ˚C
Temperature
Accuracy
±0.4˚F / ±0.2˚C from 14.0˚F to 158˚F / -10.0˚F to 70˚C;
0.6˚F / 0.3˚C elsewhere in the range
RH Range
0 to 100%RH
RH Accuracy
(TMX3RH)
±1.8%RH from 10 to 90%RH;
± 3% elsewhere in the range
DB Accuracy
(TMX3RH)
±1.2% of reading ± 1.0˚F from -40˚F to 200˚F
(± 1.2% of reading ± 0.5˚C from -40˚C to 90˚C)
SH450 General Specifications
Power Source
9V alkaline battery or optional TMX3PS AC adapter for
100 to 240VAC (40 to 60 Hz) - USA Plug
Battery Life
30hrs. continuous use
Automatic Power Off
After 10 minutes of inactivity (no key press)
Dimensions
12” x 10” x 3” (30.5cm x 25.4cm x 7.6cm)
Weight
3lb (1.4 kg) with probes
Warranty
1 year
SH450
SH450 KEY FEATURES:
•90+ refrigerant PT table built-in
•Four discrete temperature channels
•Superheat and subcool measuring functions
•Direct relative humidity and wet bulb measurements
•Temperature differential with min / max memory
•Stainless steel pressure-vacuum sensor with a
range of -14.7 PSI to 725 PSI
•Reads in PSIG, KPa, BAR, Hg, kg / cm2
•High accuracy silicon humidity transducer
probe port
•Operates on 9V battery or optional
wall transformer
•Auto-off or continuous on mode
•Large, 4-digit backlit display
•Calibrated to NIST traceable standards
• Displays bubble and vapor
saturation temperatures
Rugged Clamp-On Probe
Pg 17
Visit us Online at www.cpsproducts.com
Premium Build Pressure Port
TM360 THERMOMETER / ANALYZER
The TM360 is a professional grade thermo-psychrometer adaptable to
accommodate all your temperature, humidity, dry/wet bulb and dew
point measurements.The unit incorporates 4 discrete temperature ports
all capable of min/max and memory functions including temperature
differential between any 2 of the 4 available ports. Press the SCAN key
and the display will alternate between all 4 ports in three second
intervals providing continuous monitoring of multiple probe points
during critical system diagnosis. A dedicated special purpose port
accommodates an optional state of the art silicon humidity transducer
probe for fast and accurate measurements during superheat
calculations. Designed in a rugged polyethylene case the TM360 is
engineered to provide laboratory accuracy in rough field conditions. A
generous probe storage area is provided for housing all your job
specific probes directly in the unit itself.
TM360 Thermo-Psychrometer Specifications
TM360
TM360 KEY FEATURES:
TM360
Available with the following
accessory probes: 1-TMX2A,
1-TMX2S, 1-TMX2G
TM360C
TM360 Accessory Probe
(Included)
Available with the following accessory probes: 1-TMX3C, 1-TMX2S,
1-TMX2A
±0.1˚F or ˚C
Temperature
Accuracy
±0.4˚F / ±0.2˚C from 14.0 to 158˚F / -10.0 to 70˚C; 0.6˚F /
0.3˚C elsewhere in the range
RH Range
0 to 100%RH
RH Accuracy
(TMX3RH)
±1.8%RH from 10 to 90%RH;
± 3% elsewhere in the range
DB Accuracy
(TMX3RH)
±1.2% of reading ± 1.0˚F from -40˚F to 200˚F
(± 1.2% of reading ± 0.5˚C from -40˚C to 90˚C)
TM360 General Specifications
Power Source
9V alkaline battery or optional TMX3PS AC adapter for
100 to 240VAC (40 to 60 Hz)
Battery Life
30hrs. continuous use
Automatic
Power
Off After 10 minutes of non-use or user
selectable continuous ON mode
Backlight
15 seconds
Dimensions
12” X 10” X 3” (30.5cm x 25.4cm x 7.6cm)
Weight
3lb (1.4 kg) with probes
Warranty
1 year
Accessory Probes
TMX2A
Air Probe
-40 to 221° F / -40 to 105° C
TMX2C
Pipe Clamp-On Probe
-40 to 221° F / -40 to 105° C
TMX2G
General Purpose Probe
-40 to 257° F / -40 to 125° C
TMX2P
Puncture Probe
-40 to 257° F / -40 to 125° C
TMX2RH
RH / DP Probe
-40 to 194° F / -40 to 90° C
RH / WB / DP Probe
-40 to 194° F / -40 to 90° C
RH range: 0 to 100%
Velcro Strap Pipe Probe
-40 to 257° F / -40 to 125° C
TMX2FP
Flexible Touch Probe
-40 to 221° F / -40 to 105° C
TMX2GA
General Purpose Air Probe
-40 to 257° F / -40 to 125° C
TMX3RH
TMX2S
TM360 SPECIFICATIONS & ACCESSORY PROBES
• Four discrete temperature channels
• High accuracy silicon humidity transducer
probe port
• Large, 4-digit, easy-to-read, backlit display
• Min / Max and memory functions
• Temperature differential between any 2 of the
4 temperature ports
• Direct relative humidity and wet bulb
measurements
• Calibrated to NIST traceable standards
• Auto-off after 10 minutes of non-use or
continuous ON mode
• Operates 30 continuous hours on 1 9V
alkaline battery
• Integrated battery eliminator jack
• Rugged polyethylene carrying case
• Large probe storage area
• Switchable ˚C / ˚F
Temperature
Resolution
TempERATURE & System
Measurement
Built in LED Light
TMINI12
K-Type Input
4 Digit Backlit LCD
TMINI12 NON-CONTACT THERMOMETER
TMINI12 SPECIFICATIONS
TMINI12 THERMOMETER SPECIFICATIONS
Temperature Range
-76°F to 932°F or -60°C to 500°C
D:S
(Distance to Spot Size)
12:1
Emissivity
Emmisivity pre-set at 0.95 - adjustable
Accuracy
±2ºC (±4ºF) or ±2% of reading
Display
Digital Backlit LCD
Resolution
1ºC/Fº
Batteries / Life
(2) AAA batteries and auto power off
DIGITAL AND ANALOG POCKET THERMOMETERS
Item No.
Description
TMDP
Digital pocket thermometer with stainless steel
probe and pocket clip.
Range: -58° to 302°F / -50° to 150°C
TMAP
Analog pocket thermometer with 1” dial and
Stainless steel probe and pocket clip.
Range: 0° to 220°F
TMAPC
Analog pocket thermometer with 1” dial and
Stainless steel probe and pocket clip.
Range: -40° to 80°C
TMAP
Pg 19
The TMINI12 infrared thermometer provides instant
temperature measurement over a wide range of
applications. The unit offers simple one-handed
operation, laser point sighting,a backlit display, °C/°F
select ability and an automatic power off feature.Use the
TMINI12 to quickly measure temperatures of registers,
ductwork, furnaces,evaporators,condensers,compresso
rs, relays, manifolds, radiators,exhaust systems,
thermostats, bearings and more.Leather carrying case
and 9V alkaline battery are included.
TM50 ANALOG POCKET THERMOMETER
A step above the standard pocket thermometer the
TM50 is packed full of features, including a user
selectable temperature alarm, a countdown timer,
Min/Max, °F/°C selectable and memory functions.
The unit incorporates a highly accurate stainless
steel 96mm puncture probe with a 4ft/122cm
cord. Temperature range is -58° to 500°F / -50° to
260°C. The TM50 operates on a single AAA alkaline
battery with 25 hours of battery life and a low
battery indicator.
TMDP
TM50
TMXSK90
TMXSK90 TEMPERATURE PROBE
Ribbed Handle
The TMXSK90 is the fastest and most accurate handheld K-type surface
probe providing accurate readings in less than 5 seconds. The sensor is
made from flat-spring ribbons of thermocouple material for contact on
uneven surfaces. An angled head for measuring hard to reach surfaces
and a 3 foot coiled lead for durability and long reach. The exposed
junction provides for fast response and is compatible with any other
instrument with a K-Type input.
TMXSK TEMPERATURE PROBE
The TMXSK is the fastest and most accurate handheld
K-type surface probe providing accurate readings in
less than 5 seconds. The sensor is made from
flat-spring ribbons of thermocouple material for
contact on uneven surfaces. A ribbed handle for grip
and a 3 foot coiled lead for durability and long reach.
The exposed junction provides for fast response and
is compatible with any other instrument with a K-Type
input.
Coiled Lead
Flat-Spring Ribbons
K-Type Accessory Probe
TMXSK
TMXKBEAD TEMPERATURE PROBE
SPECIFICATIONS
The TMXKBEAD is a standard K-type bead probe
ideally suited for getting fast results when measuring
temperature in a variety of media. This 36” long
(1 meter) probe provides accurate readings in less
than 5 seconds over the range of -58ºF to 400 ºF
(-50 ºC to 204 ºC).
THERMOMETER SPECIFICATIONS
TMXSK90
Max Temp: 752°F (400°C)
TMXSK
Max Temp: 752°F (400°C)
TMXKBEAD
Max Temp: 400°F (204°C)
Min Temp: -58°F (-50°C)
TMXKBEAD
Used as seen above on the CPS TMINI12 and
is compatible with any other instrument with
a K Type input.
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 20
VACUUM GAUGES
VALUE THAT CAN’T BE MEASURED
Pg 21
Visit us Online at www.cpsproducts.com
VACROMETER™ DIGITAL VACUUM GAUGE
Advanced measurement instrument providing continual
digital readout of evacuation process on large 5 digit
LCD. Measurement units are user selectable to read in
Microns,Torr, in/hg or mBar at the touch of a key.
Advanced surface mount technology automatically
compensates for ambient changes in the environment
ensuring accuracy and consistency in performance.
Advanced field-cleanable sensor is able to withstand
400 PSI of positive pressure. Unit operates 30 hours on
9V alkaline battery with low battery indicator and auto
off feature. Includes carrying case, hanging hook, AVT45,
9V battery and is CE approved.
VG200
AVT45
VG200 VACROMETER DIGITAL VACUUM GAUGE SPECIFICATIONS
Self - heated thermistor bridge with integral temperature compensation from
0 to 50 °C (32 to 122 °F).
Operating Pressure Range
Atmospheric pressure to 0 microns Maximum Working pressure: 400 PSIG
Burst Pressure
400 PSIG
Operating Range
VG200- Atmospheric to 0 microns / VG100A- Atomospheric to 25 Microns
Accuracy
+/- 10% of Reading.
Operating Temp Range
Compensated (accuracy as stated): 0°C TO 50°C (32°F TO 122°F)
Non-compensated (add +/- 0.5% error for every °C outside compensated range):
0 to 50°C (-22 to 158°F)
Operating & Storage
Humidity
VG201
Add vacuum
measurement to your
manifold with a VG201A
0-95%, non-condensing.
Storage Temperature
- 40 to 185°F / - 40 to 85°C
Power Source
One 9 volt alkaline battery (ANSI 1604AC – IEC 6LR61)
Battery Life
20 hours of continuous use. Instrument shuts itself off after 5 minutes of operation.
Weight
5.5 oz. / 153 g. excluding the battery.
Dimensions
68 mm. diameter by 40 mm. deep by 124 mm. overall height
(2.7” dia. by 1.6” deep by 5” overall height).
Mechanical Connection
Standard 1/4” female SAE refrigerant hose type with core depressor.
Battery Indicator
Battery symbol with 3 segment Power Level Bar Graph. (VG200).
LED Low Battery Indicator (VG100)
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
VG200 VACUUM GAUGE SPECIFICATIONS
Type
Pg 22
Vacuum Gauges
VACROMETER™ DIGITAL VACUUM GAUGE
Compact self-contained instrument designed to provide
constant indication and monitoring of the evacuation
process from start to finish. Nine discrete high intensity
LED’s are preset to illuminate upon achieving industry
standards for proper system evacuations. Advanced
surface mount technology automatically compensates for
ambient changes in the environment ensuring accuracy
and consistency in performance. Advanced field-cleanable
sensor is able to withstand 400 PSI of positive pressure.
Unit operates 25 hours on 9V alkaline battery with low
battery indicator and auto-off feature.
Includes carrying case.
GAUGE ACCESSORIES
VG100A
VACUUM GAUGE SPARE PARTS & ACCESSORIES
VGXC
Carrying case VG100A/ VG200
VGXH
Hanging Hook
AVT87
Adapter for VG100A/VG200. 1/4” SAE male to
1/2”-20 male to 1/2” -20 swivel female tee
AVT48
Adapter for VG100A/VG200. 1/4” SAE male to
1/2” ACME male to 1/4” SAE swivel female tee
AVT45
Adapter for VG100A/VG200. 1/4” SAE male to
1/4” SAE male to 1/4” SAE swivel female tee
Add vacuum
measurement to your
manifold with a VG101A
VG201
AVT45
AVT45 VACUUM GAUGE ADAPTER
The AVT45 is premium built brass adapter for the VG100A /
VG200 and comes with a 1/4” SAE male to 1/4” SAE male
to 1/4” SAE swivel female tee.
Pg 23
Visit us Online at www.cpsproducts.com
VACUUM PUMPS
LIGHT WEIGHT DESIGN
HEAVY WEIGHT PERFORMANCE
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 24
Vacuum Pumps
Pro-Set® PREMIUM VACUUM PUMPS
Pro-Set Premium Series vacuum pumps are offered in
single and dual stage units with versatile voltage and HP
motor options. Pro-Set pumps boast the same high
quality, high value features engineered into all of our
Pro-Set products providing performance excellence
and years of reliable service.
VP12D
DUAL STAGE SPECIFICATIONS
Universal IEC Socket
w/ Dual Voltage Selector Switch
Specifications
VP2D
VP4D
VP6D
VP8D
VP10D
VP12D
Motor Size
(HP) RPM @ 50/60Hz
1/3 (HP)
1440/1720
1/2 (HP)
2880/3440
1 / 2 (HP)
2880 / 3440
2/3 (HP)
2880 / 3440
3/4 (HP)
2880 / 3440
1 (HP)
2880 / 3440
Dimensions (Inches)
12.2” x 5” x 9.6”
13.1” x 5.5” x 10”
13.1” x 5.5” x 10”
14.9” x 5.7” x 10.6”
14.9” x 5.7” x 10.6”
14.9” x 5.7” x 10.6”
Weight
17.7lb / 8.0kg
22.1 lb / 10.0 kg
22.5 lb / 10.2 kg
29.8 lb / 13.5 kg
30.3 lb / 13.7kg
30.9 lb / 14.0 kg
Operating
Temperature Range
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
Power Source
Dual Voltage: 110-120V / 220-240V 50/60Hz Single Voltage: 220-240V 50/60Hz
Oil Capacity
11.5oz/330ml
15.5 oz / 450 ml
14 oz / 400 ml
29 oz / 860 ml
28 oz / 830 ml
27 oz / 800 ml
Free Air
Displacement
2 CFM @ 60Hz,
48 l/m @ 50Hz
4 CFM @ 60Hz,
96l/m @ 50Hz
6 CFM @ 60 Hz,
144 l / m @ 50 Hz
8 CFM @ 60 Hz,
192 l / m @ 50 Hz
10 CFM @ 60Hz,
240l/m @ 50Hz
12 CFM @ 60Hz,
288l/m @ 50Hz
Intake Fittings
1/4” SAE, 3/8” SAE,
and 1/2”ACME
1/4” SAE, 3/8” SAE,
and 1/2”ACME
1/4” SAE, 3/8” SAE,
and 1/2”ACME
1/4” SAE, 3/8” SAE,
and 1/2” SAE
1/4” SAE, 3/8” SAE,
and 1/2” SAE
1/4” SAE, 3/8” SAE,
and 1/2” SAE
PREMIUM VACUUM PUMP KEY FEATURES:
• Dual voltage operation
• 2 Stages
• Exceptional ultimate vacuum ratings, 10 microns
• Advanced air cooled motor design for operation in high
ambient temperatures
• Proprietary oil mist free exhaust port cap for clean, safe
job environment
• Gas ballast valve speeds achievement of deep vacuum
• Also Available in 220-240V 50/60Hz
Pg 25
• On-Off Power Switch
• Single Stage Models also available VP2S, VP4S, VP6S
• Multiple inlet port connections
• Easy maintenance with large oil sight glass and fill port
with easily accessible oil drain port
• Heavy Gauge Aluminum Chasis with rubber lined
steel handle and heavy duty rubber base
• Built in inlet check valve
• Includes 2 year warranty
Visit us Online at www.cpsproducts.com
Pro-Set® PREMIUM VACUUM PUMPS
The VP6S Pro-Set Premium Series is a 6 CFM, single stage unit with
a versatile dual voltage ½ HP motor. It boasts the same high-quality,
high-value features engineered into all of our Pro-Set vacuum pumps,
delivering excellent performance and years of reliable service.
VG200 DIGITAL VACUUM GAUGE
The VG200 is our digital vacuum
gauge designed to monitor the
entire evacuation process. It uses
two keys—one to turn the unit on
and off, and a second key to change
between MICRONS, MILLIBAR, TORR
and INCHES HG VAC any time during
operation.
VP6S
Check out unit variations that bring
Pro-Set engineering to your specific
requirements. You’ll find features such
as ultimate vacuum ratings as low as 50
microns, an air-cooled motor design for
operation in high ambient temperatures
and a proprietary mist free exhaust port
cap for a clean, safe job environment.
VG200 (For use with all Vacuum Pump Models)
Oil Mist Port Cap
Oil mist preventer exhaust port.
Specifications
VP2S
VP4S
VP6S
Motor Size (HP) RPM @ 50/60Hz
1/4 (HP) 1440/1720
1/3 (HP) 2880/3440
1 / 2 (HP) 2880 / 3440
Dimensions (Inches)
12.2” X 5” X 9.6”
12.2” x 5” x 9.6”
13.1” x 5.5” x 10”
Weight
13.7 lb/ 6.2 kg
15.0 lb/ 6.8 kg
18.3 lb/8.3 kg
Operating Temperature Range
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
0°C (32°F) to
52°C (125°F)
Power Source
VPXJ220 PORT CAP
220 VAC jumper power cord for locations
where 110 voltage is not available.
Large Oil Sight Glass
Single Voltage: 220-240V 50/60Hz
*Dual Voltage: 110-120V / 220-240V 50/60Hz
Oil Capacity
16 oz/ 470ml
16oz/ 470ml
19 oz/ 540ml
Free Air Displacement
2 CFM @ 60Hz,
48 l/m @ 50Hz
4 CFM @ 60Hz,
96l/m @ 50Hz
6 CFM @ 60 Hz,
144 l / m @ 50 Hz
Intake Fittings
1/4” SAE,
3/8” SAE,
and 1/2”ACME
1/4” SAE,
3/8” SAE,
and 1/2”ACME
1/4” SAE,
3/8” SAE,
and 1/2”ACME
SINGLE STAGE SPECIFICATIONS
VPXOMP PORT CAP
Brass T-Valve Adapter
Vacuum Pumps
PREMIUM COMPACT SIZE PUMP
Single Stage VPC2SE
STANDARD SIZE PUMP
PREMIUM COMPACT SIZE PUMP
Dual Stage VP12D
Dual Stage VPC2DU
PREMIUM COMPACT VACUUM PUMPS
SMALL SIZE, BIG PERFORMANCE
KEY FEATURES:
• Single or Dual Stage Models
• Thermally protected motor for overload protection
• Innovative compact and lightweight design
• Easy maintenance with large oil sight glass and fill port with
• Exceptional ultimate vacuum rating
easily accessible oil drain port
• Advanced air cooled motor design for operation in high
ambient temperatures
• Sure grip handle ergonomically designed for superior
comfort and portability
• Proprietary oil mist free exhaust port cap for clean,
safe job environment
• Extremely compact and portable design
• Operating tempature range of 0 °C (32 °F) to 52 °C (125 °F)
• On-Off power switch for the Control System
• Gas Ballast Valve
• Intake Fitting size of 1/4” SAE and 1/2”ACME
• Also inquire about our 12VDC battery operated models
• Heavy gauge aluminum chasis with impact resistant
• Includes 1 year warranty
plastic base
Pg 27
Visit us Online at www.cpsproducts.com
Pro-Set® PREMIUM COMPACT
VACUUM PUMPS
The VPC2S Premium Compact Pro-Set
Vacuum Pump incorporates professional
level features with extreme portability. This
innovative 2 CFM, single-stage unit is
certified to achieve an ultimate vacuum
rating as low as 100 microns. With a
weight of just 9.3 lbs (4.2 kg), it helps you
get more done without weighing you down.
Delivering the same performance to
portability, the VPC2D is a 2 CFM, dual
stage unit that is factory-tested to deliver
an ultimate vacuum rating as low as 15
microns, while weighing a mere 12.1 lb
(5.5 kg). You’ll find advanced air-cooling,
easy maintenance and high impact plastic
base for added shock resistance.
VPC2SE
VPC2DU
VPC2SU
VPC4SU
Stage
2
1
1
Motor Size
(HP) RPM @ 50/60Hz
1/4 (HP)
2880 / 3440 RPM
1/5 (HP)
2880 / 3440 RPM
1/4 (HP)
2880 / 3440 RPM
Dimensions (Inches)
11.3” x 4.5” x 8.0”
9.1” x 4.5” x 8.0”
11.3” x 4.5” x 8.0”
Weight
12.1 lb / 5.5 kg
9.3 lb / 4.2 kg
11.0 lb / 5 kg
Power Source
115V 60 Hz
115V 60 Hz
115V 60 Hz
15 Microns
as low as
100 Microns
as low as
100 Microns
Oil Capacity
9 oz / 250 ml
9 oz / 250 ml
10 oz / 300 ml
Free Air
Displacement
2 CFM @ 60hz,
48l/m @ 50Hz
2 CFM @ 60 Hz,
48 l / m @ 50 Hz
4 CFM @ 60 Hz,
96 l / m @ 50 Hz
Specifications
VPC2DE
VPC2SE
VPC4SE
Stage
2
1
1
Motor Size
(HP) RPM @ 50/60Hz
1/4 (HP)
2880 / 3440 RPM
1/5 (HP)
2880 / 3440 RPM
1/4 (HP)
2880 / 3440 RPM
Dimensions (Inches)
11.3” x 4.5” x 8.0”
9.1” x 4.5” x 8.0”
11.3” x 4.5” x 8.0”
Weight
12.1 lb / 5.5 kg
9.3 lb / 4.2 kg
11.0 lb / 5 kg
Power Source
220-240V
50/60 Hz
220-240V
50/60 Hz
220-240V
50/60 Hz
15 Microns
as low as
100 Microns
as low as
100 Microns
Oil Capacity
9 oz / 250 ml
9 oz / 250 ml
10 oz / 300 ml
Free Air
Displacement
2 CFM @ 60hz,
48l/m @ 50Hz
2 CFM @ 60hz,
48l/m @ 50Hz
4 CFM @ 60Hz,
96l/m @ 50Hz
Ultimate Vacuum
Intake Port Brass Adapter
Ultimate Vacuum
Rugged & Durable Power Cable
COMPACT VACUUM PUMP SPECIFICATIONS
Large Oil Sight Glass
Specifications
Vacuum Pumps
ANTI-SIPHON VALVE KITS
The CPS anti-siphon valve is an essential accessory to any
vacuum pump application. The anti-siphon valve prevents the
cross-contamination of vacuum pump oil and the compressor
oil in the A/C or refrigeration system being serviced. Mixing of
vacuum pump oil and compressor oil can cause premature failure
in the A/C or refrigeration system. CPS makes three models that fit
all CPS and other brands of vacuum pumps.
Add these kits to any brand of vacuum pump to prevent the
cross-contamination of vacuum pump oil and the compressor oil
of the system being serviced.
VPASU
VPAS4 - 1/4” SAE Female Knurl Nut
VPAS8 - 3/8” SAE Female Knurl Nut
VPASU - 1/4” SAE, 3/8” SAE, 1/2”-20
UNF Female Knurl Nut
ACCESSORIES
VPAS8
ITEM
DESCRIPTION
VPAS4
1/4” SAE Female Knurl Nut
VPAS8
3/8” SAE Female Knurl Nut
VPASU
1/4” SAE, 3/8” SAE, 1/2”-20 (UNF Female Knurl Nut)
AVCVAC
Vacuum pump cap kit with chains
PREMIUM VACUUM PUMP OILS
VPOG6
(6) one gallon bottles
PREMIUM VACUUM PUMP OILS
VPOQ12
(12) one quart bottles
VPOP12
(12) one pint bottles
PRO-SET Premium Vacuum Pump Oil is an extremely high quality,
severely hydrotreated vacuum pump oil. The oil is compatible for
use in pumps made by most manufacturers. PRO-SET Premium
Vacuum Pump Oil should always be clean and free of contaminants
such as moisture, acids, vapors, dirt etc. It is strongly
recommended that the vacuum pump oil be changed after each
use to improve service and the life of the pump.
Vacuum pump cap kit with chains
on one common ring
AVCVAC
VPOP12
1/2” ACME
1/4” SAE
Pg 29
3/8” SAE
1/2” SAE
VPOQ12
VPOG6
RECOVERY EQUIPMENT
RECOVER REFRIGERANTS QUICKLY & EFFICIENTLY
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 30
Recovery Equipment
RECOVER LOST TIME
The Smallest, Lightest, Fastest
and Most Reliable Recovery Machine
found anywhere in the world
TR21
Premium Brass Fittings
Pro-Set
Manual HP Reset Button (TR21E only)
®
The Workingman’s Choice™
TR21 SPECIFICATIONS
BUILT FOR PERFORMANCE:
Compressor Type
2 Cylinder Oil-less Reciprocating Compressor
Dimensions
15cm (6”) Wide x 30cm (12”) Long x 23cm (9”)
High
Weight
24.5 lb
Operating Temperature
Range
0˚C (32˚F) to 49˚C (120˚F)
Power Source
115 V 50/60 Hz
Power Consumption
R410A
VAPOR @75
R410A
DIRECT
LIQUID
R410A
PUSH PULL
LBS
KG
LBS
KG
LBS
KG
PRO-SET® TR21
.703
.319
11.95
5.42
31.70
14.38
850 W
APPION G5
.396
.180
3.48
1.58
10.21
4.63
Filtration
Cleanable 100 - mesh screen integrated into
Suction Port
APPION G1
.264
.120
4.32
1.96
12.17
5.52
Overload Protection
Motor Thermally Protected
ATP RG5410EX
.443
.201
5.14
2.33
14.13
6.41
High Pressure
Shut-Off
550 psig
RITCHIE XLT95760
.490
.220
1.68
O.76
12.21
5.54
REFTEC DIABLO-115
.220
.100
4.98
2.26
15.00
6.80
INFICON VORTEX AC
.287
.130
3.46
1.57
11.35
5.15
BACHARACH STINGER
.310
.140
3.26
1.48
16.29
7.39
Refrigerants
Pg 31
5 years of intensive product research and development have
produced the Pro-Set® TR21, the smallest, lightest, fastest and
most reliable recovery machine found anywhere in the world.
That means you can get the job done more effectively, with less
effort, in half the time.
R-12, R-134a, R-401C, R-406A, R-500,
R-401A, R-409A, R-401B, R-412A, R-411A,
R-407D, R-22, R-411B, R-502, R-407C,
R-402B, R408A, R-509, R-407A, R-404A,
R-402A, R-507, R-407B, R-410A
* Chart data was obtained from published UL/ARI test results per ARI
740-98 Standards for Recovery Equipment
Visit us Online at www.cpsproducts.com
TIME IS MONEY
ADDITIONAL MODELS
TR21C
Features
Same as TR21 except: 450 psig high pressure shut-off.
Automatic reset 115V 50/60 Hz
TR21E
Features
Same as TR21 except: 525 psig high pressure shut-off.
Manual reset 220-240V 50 Hz
TR21J
Features
Same as TR21 except: 550 psig high pressure shut-off.
Automatic reset Tank overfill sensor cord 100V 50/60 Hz
TR21S
Features
Same as TR21 except: 550 psig high pressure shut-off.
Automatic reset 220-240V 50/60 Hz
TR22
Features
Same as TR21, but with Tank overfill sensor cord
Dimensions
4” D x 12” H
TR22S
Features
Same as TR21S, but with Tank overfill sensor cord
Weight
5 lbs
Maximum
Operation Pressure
550 psig
Discharge
Pressure Gauge
0 to 600 PSIG
Inlet/Outlet
Connections
1/4” SAE Male
Performance
up to 9000 Btu’s
Transform your Bottom line
with the MT69 Molecular
Transformator.
LBS / MIN
KG / MIN
Vapor
High
Temp
Vapor
(104˚)
Push
Pull
Liquid
Vapor
High
Temp
Vapor
(104˚)
8.86
0.597
0.860
14.30
4.02
0.271
0.390
25.66
7.80
0.503
N/A
11.64
3.54
0.228
N/A
R407C
29.14
9.50
0.536
N/A
13.22
4.31
0.243
N/A
R410A
31.70
11.95
0.703
0.816
14.38
5.42
0.319
0.370
Push
Pull
Liquid
R22
31.53
R134a
Type
MT69 SPECIFICATIONS
TR21 RECOVERY RATES PER ARI - 740 - 98
ENHANCE THE PERFORMANCE
OF YOUR RECOVERY MACHINE
COMPARATIVE DATA
Test results show time to recover 15 lbs of
R22 at 120˚ F:
With MT69 = 17 minutes
Without MT69 = 32 minutes
THIS IS WHAT IT DOES:
• Up to 95% increase in recovery speed
• Actual time to recover 15 lbs. of R22 at
120 °F is 17 minutes with MT69 vs. 32
minutes without MT69
• The hotter it gets, the better it works
• Eliminates the need to change tanks when recovering R410A
• Eliminates annoying shutdown due to high pressure switch limit
• Dramatically improves the performance of any recovery machine
• Essential for recovering R410A on hot days
• Essential for recovering liquid refrigerant on cold days
• Eliminates liquid slugging at colder temperatures
• Patented and Patents Pending
MT69
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 32
PRO-SET® OIL-LESS REFRIGERANT
RECOVERY MACHINES
• Powerful 1HP oil-less reciprocating recovery compressor
• Exceptional compressor, condensing & cooling systems
allow fast recovery in high temperature environments
• Automatic Low Pressure shut-off feature turns unit
off when recovery is completed
• Rugged high density double walled plastic housing
with easy view top mounted controls
• R-410a ready with 550psi high pressure
shut-off switch
• Ergonomic well balanced design for easy transport
including shoulder strap - weighs 36 lbs / 16.2 kg
• Built-in suction filter located under suction port
• Worlwide patents pending.
SUCTION PORT DESIGN
CR700
Outgoing refrigerant flow (Discharge Valve)
Low pressure expansion chamber
Incoming refrigerant flow (Suction Port)
• Compact design with easy 4 bolt access
• Compressor can be rebuilt in minutes
• Externally serviceable valves and gauges
• Integrated component moorings for quiet operation
• Fewer components equals more reliablity
Unique suction port design eliminates
suction valve & precisely meters
incoming refrigerant.
UL CERTIFIED
meets or exceed EPA Regulations per ARI Standard 740-98
CR700 Series
ITEM:
VOLTAGE
GAUGES
CR700
115V
psig/kgcm2
CR700E
220-240V
BAR/kPa
CR700S
230V
psig/kgcm2
CR700J
100V
MPa
• Powerful 1HP oil-less reciprocating recovery
compressor
• Oversized piston head & cylinder combined with a
larger discharge port
• No suction valve eliminates failures caused by
liquid slugs
• Heavy duty components with special long-lasting
composite seals
Pg 33
Visit us Online at www.cpsproducts.com
Test Conditions at 75 F Degrees
Brand Models
CPS CR700
104 F Degrees
Refrigerant
Liquid (kg/m)
Push / Pull (kg/m)
Vapor (kg/m)
R410a
2.95
6.97
0.23
High Temp Vapor
(kg/m)
NRTL Ratings
(UL) QVBC SA12068
R410a
1.58
4.63
0.30
(UL) QVBC SA13136
R410a
0.76
5.54
0.22
(UL) QVBC SA12038
Promax RG5410EX
R410a
2.33
6.39
0.20
(UL) QVBC SA12994
Promax RG5410A
R410a
1.85
4.91
0.16
(UL) QVBC SA12994
Inficon Vortex AC
R410a
1.66
5.15
0.08
(UL) QVBC SA12798
Stinger 2000-3300
R410a
1.37
6.63
0.10
(AR) RRRE-05040-1Q
CPS CR700
R22
3.11
7.17
0.22
0.242
(UL) QVBC SA12068
Appion G5
R22
2.82
7.54
0.28
0.19
(UL) QVBC SA13136
Yellow Jkt 95760
R22
0.90
6.12
0.15
0.15
(UL) QVBC SA12038
Promax RG5410EX
R22
1.90
6.58
0.18
0.14
(UL) QVBC SA12994
Promax RG5410A
R22
1.81
4.32
0.15
0.13
(UL) QVBC SA12994
Inficon Vortex AC
R22
1.35
2.50
0.11
0.13
(UL) QVBC SA12798
Stinger 2000-3300
R22
1.60
5.58
0.13
0.13
(AR) RRRE-05040-1Q
CPS CR700
R134
2.15
6.30
0.15
(UL) QVBC SA12068
Appion G5
R134
1.97
5.03
0.19
(UL) QVBC SA13136
Yellow Jkt 95760
R134
1.13
6.12
0.10
(UL) QVBC SA12038
Promax RG5410EX
R134
1.09
5.30
0.14
(UL) QVBC SA12994
Promax RG5410A
R134
1.57
3.63
0.11
(UL) QVBC SA12994
Inficon Vortex AC
R134
1.13
3.44
0.10
(UL) QVBC SA12798
Stinger 2000-3300
R134
1.21
4.98
0.10
(AR) RRRE-05040-1Q
CR700
CR700J
CR700E
Compressor Type
1 HP oil-less reciprocating compressor
Dimensions
20cm (8”) wide x 37cm (14.5”) long x 30.5cm (12”) high
Weight
15.3kg (34lbs.)
Oprtg. Temp. Range
0°C (32°F) to 49°C (120°)
Power Source
115V 50/60Hz 1 HP
100V 50/60Hz 1 HP
850 W
Filtration
Cleanable 100-mesh screen integrated into Suction Port
Shut-off valves
Both Suction and Discharge piston manifold valves
Overload Protection
CR700S
220-240V 50/60 Hz 1 HP
Power Consumption
15 amp
COMPETITIVE COMPARISON RECOVERY RATES
Appion G5
Yellow Jkt 95760
230V 50/60 Hz 1 HP
8 amp
Replacement Parts
CRXCR1
Compressor Rebuild Kit for CR600 (all)
CRXCR2
Compressor Rebuild Kit for CR500 (115V)
CRXCR3
Compressor Rebuild Kit for CR500 (230V)
CRXCR8
Compressor Rebuild Kit for CR700 (all)
CRXTOS2
CR Overfill Sensor Cord Kit 115V
CRXTOS2
CR Overfill Sensor Cord Kit 230V
CRXF2
(6) Suction Filters for CR300, 400, 500, 600
CRXF3
(6) Suction Filters for CR700
CR700S
Pg 34
Recovery Equipment
REFRIGERANT RECOVERY TANKS
TANK SPECIFICATIONS
PRO-SET Premium Vacuum Pump Oil is an extremely high quality, severely hydrotreated vacuum pump oil. The oil is compatible for
use in pumps made by most manufacturers. PRO-SET Premium Vacuum Pump Oil should always be clean and free of contaminants
such as moisture, acids, vapors, dirt etc. It is strongly recommended that the vacuum pump oil be changed after each use to improve
service and the life of the pump.
ITEM
DESCRIPTION
WATER
CAPACITY
DOT
SPECIFICATION
SERVICE
PRESSURE
ARX134T
Automotive 50lb tank with 1/2” ACME M fitting
47.7lb / 21.7kg
DOT04BA-400
400 PSIG
ARX134TS
Automotive 50lb tank with 1/2” ACME M fitting
and overfill sensor
47.7lb / 21.7kg
DOT04BA-400
400 PSIG
CRX390T
90lb tank with 1/4” SAE M fitting on tank. 1/4” SAE FM x 1/2”
ACME M adapter fitting included
92 lb / 41.7kg
DOT04BW-400
400 PSIG
CRX390TS
90lb tank with 1/4” SAE M fitting on tank and overfill sensor.
1/4” SAE FM x 1/2” ACME M adapter fitting included
92 lb / 41.7kg
DOT04BW-400
400 PSIG
CRX400T
50lb tank with 1/4” SAE M fitting
47.7lb / 21.7kg
DOT04BA-400
400 PSIG
CRX400TS
50lb tank with 1/4” SAE M fitting and overfill sensor
47.7lb / 21.7kg
DOT04BA-400
400 PSIG
CRX430T
30lb tank with 1/4” SAE M fitting
26.2lb / 11.9kg
DOT04BA-400
400 PSIG
CRX430TS
30lb tank with 1/4” SAE M fitting and overfill sensor
26.2lb / 11.9kg
DOT04BA-400
400 PSIG
CRX390T
1/4” SAE & 1/2” ACME
Tank Adapter
CRX390TS
1/4” SAE with float
CRX430T
1/4” SAE Tank
CRX430T
1/4” SAE Tank with float
00
Pg 35
ARX134T
1/2” ACME (AR300/400)
U.S. Automotive
ARX134TS
1/2” ACME with float (AR500)
CRX400T
1/4” SAE Tank
CRX400TS
1/4” SAE Tank with float
Visit us Online at www.cpsproducts.com
SERVICE MANIFOLDS
& GAUGES
MECHANICAL & DIGITAL MANIFOLD SOLUTIONS
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 36
BLACKMAX MANIFOLDS
®
INDUSTRY LEADING ACCURACY
Pg 37
Manifolds & Gauges
BLACKMAX® DIGITAL MANIFOLD SERIES
BLACKMAX digital manifolds from CPS Products, Inc.
combine the latest manifold design and electronic
measurement features into one easy-to-use, accurate
and water resistant product in a rugged nylon plastic
housing, incorporating a durable elastomeric keypad
and large backlighted LCD display.
MD100
Rugged Design
• Water Resistant High Strength Glass Filled Nylon Housing
• Precision Machined Anodized Aluminum Manifold Body
• Proprietary Vortech Valve Systems (certified to 10 microns)
• High-impact polycarbonate LCD Window
• Advanced sight glass design
Simplicity & Versatility
• One key ON/OFF and function select
• Preloaded with over 90 of the most common Refrigerants
• Compatible with R744 subcritical CO2 Refrigerants
• One-touch access to your 5 favorite refrigerants
• Performs pressure decay and vacuum rise tests
• 25 hours of continuous use with full backlight illumination
Best-in-Class Accuracy
Full System Measurement
• 2 Pressures, 2 Temperatures & Vacuum
(using MDXVG accessory)
• Vacuum Rise and Pressure Decay Test Functions
• Simultaneously Displays:
HI & LO Pressures, Superheat & Subcooling
HI & LO Pressures, T1 & T2
HI & LO Pressures, Saturation T1 & Saturation T2
HI & LO Pressures, Displays T1, T2 & Delta T
ITEM
NORTH AMERICA
SOUTH AMERICA
AUSTRALIA
MD50
2V Digital Manifold with (2) Clamp Probes
MD50HE
2V Digital Manifold with (2) Clamp Probes and 5’ Hoses
MD50VHE
2V Digital Manifold with (2) Clamp Probes and
5’ BV Hoses & Vac accessory
MD100
4V Digital Manifold with (2) Clamp Probes
MD100HE
4V Digital Manifold with (2) Clamp Probes and 5’ Hose
MD100VHE
4V Digital Manifold with (2) Clamp Probes,
a 5’ BV Hose & Vac accessory
MDXVG
MD50/100 Vacrometer Accessory
MDXBK
MD50/100 Rechargeable Battery Kit
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
MANIFOLD CONFIGURATIONS
• Pressure: 1% of reading Pressure
• Temperature: Superior Thermistor Sensors for
+/- 0.2°C (+/- 0.4°F) Accuracy
• Vacuum: Direct System Attachment achieves
+/- 10 microns from 0 to 25,000 microns
Pg 38
BLACKMAX MANIFOLDS
®
ENGINEERED FOR PERFORMANCE & RELIABILITY
Pg 39
Manifolds & Gauges
BLACKMAX® MANIFOLDS
BLACK & CHROME SERIES
BlackMax Black & Chrome series anodized
aluminum block body with three 1/4” SAE and
one 3/8” SAE vacuum port (4 Valve Manifold only),
Vortech Deep Vacuum Valves, extra large sight
glass, easy-to-read Class 1.0 accuracy gauges,
protective gauge boots and hanging hook.
MADE IN USA
MV4H4P5EZ
BLACKMAX® BLACK & CHROME VORTECH VALVE MANIFOLDS
SPECIFICATIONS
SOUTH AMERICA
R134a, R22,
R404a, R410a
R410a, R22, R407c
* Gauges built with Internal Silicon Dampening
Cup for Flutter-Free operation
3 1/8”
(80mm)
Class 1.0
Accuracy
3 1/8”
(80mm)
Class 1.0
Accuracy
Pressure Scales
PSI
BAR / PSI
Temperature Scales
°F
˚C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
FITTINGS
GAUGE
DESCRIPTION
Refrigerant Scales
REPLACEMENT
GAUGES
FOUR VALVE
MANIFOLDS
TWO VALVE
MANIFOLDS
MV2H4Z
Gauge Size / Type
Manifold & Gauges Only
MV2H4Z
MV2O4Z
3 Premium 5ft (150cm ) Pro-Set
Black & Chrome Hoses
MV2H4P5Z
MV2O4P5Z
3 Premium 5ft (150cm ) Pro-Set
Black & Chrome BV Hoses
MV2H4P5EZ
MV2O4P5EZ
Manifold & Gauges Only
MV4H4Z
MV4O4Z
3 Premium 5ft (150cm ) Pro-Set
Black & Chrome Hoses
MV4H4P5Z
MV4O4P5Z
3 Premium 5ft (150cm ) Pro-Set
Black & Chrome BV Hoses
MV4H4P5EZ
MV4O4P5EZ
Low Side Gauge
RGH4L
RGO4L
High Side Gauge
RGH4H
RGO4H
BLACKMAX® MANIFOLD CONFIGURATIONS
NORTH AMERICA
MV4H4Z
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 40
Manifolds & Gauges
BLACKMAX® MANIFOLDS
BLACK & CHROME SERIES
BlackMax Black & Chrome series 2 valve anodized
aluminum block body with ¼" SAE 45° fittings,
Triple Seal piston valves, easy-to-read 3 1/8"
(80mm) Class 1.0 accuracy gauges, protective
gauge boots, extra access port in center with
Schrader valve, premium 5ft Pro-Set Black &
Chrome hoses with 45° anti blowback valves on
end and hanging hook. MADE IN USA
MBH4P5EZ
BLACKMAX® BLACK & CHROME TRIPLE SEAL VALVE MANIFOLDS
NORTH AMERICA
SPECIFICATIONS
NORTH AMERICA
NORTH AMERICA
SOUTH AMERICA
SOUTH AMERICA
HP5BKZ
AUSTRALIA
R134a, R22,
R404a, R410a
R134a, R22,
R404a, R410a
R410a
R410A, R22,
R407C
* Gauges built with
Internal Silicon
Dampening Cup
3 1/8"
(80mm)
Class 1.0
Accuracy
2 1/2"
(68mm)
Class 1.6
Accuracy
2 1/2"
(68mm)
Class 1.6
Accuracy
3 1/8"
(80mm)
Class 1.0
Accuracy
Pressure Scales
PSI
PSI
PSI / kPa
BAR / PSI
Temperature Scales
°F
°F
°F / °C
°C
Manifold and
Hose Fittings
1/4" SAE
45° Fittings
1/4" SAE
45° Fittings
1/4" SAE
45° Fittings
1/4" SAE
45° Fittings
Manifold &
Gauges Only
MBH4Z
MBH5Z
MBB5Z
MBO4Z
3 5ft (150cm ) Pro-Set
Black & Chrome
Premium Hoses
MBH4P5Z
MBH5P5Z
MBB5P5Z
MBO4P5Z
3 5ft (150cm ) Pro-Set
Black & Chrome
Premium BV Hoses
MBH4P5EZ
MBH5P5EZ
MBB5P5EZ
MBO4P5EZ
Low Side Gauge
RGH4L
RGH5L
RGB5L
RGO4L
High Side Gauge
RGH4H
RGH5H
RGB5H
RGO4H
GAUGE
DESCRIPTION
FITTINGS
TWO VALVE
MANIFOLDS
REPLACEMENT
GAUGES
BLACKMAX® MANIFOLD CONFIGURATIONS
Refrigerant Scales
Pg 41
Gauge Size / Type
5' Black Premium Chrome
Charging Hoses
HP5BKEZ
5' Black Premium Anti-Blowback
Chrome Charging Hoses
HV5Z
Visit us Online at www.cpsproducts.com
5' Black 3/8” Premium
Chrome Hose
BLACKMAX® MANIFOLDS BLACK & CHROME SERIES
BlackMax Black & Chrome series 2 valve anodized aluminum block body with ¼" SAE 45°
fittings, Triple Seal piston valves, easy-to-read 3 1/8" (80mm) Class 1.0 accuracy gauges,
protective gauge boots, extra access port in center with Schrader valve, premium 5ft Pro-Set
Black & Chrome hoses with 45° anti blowback valves on end and hanging hook. MADE IN USA
RGH4L
RGX80IB
RGH4H
MBH5P5EZ
PRO-SET® BLACK & CHROME PRESSURE GAUGES
3 1/8" /80mm Pressure Gauges
2 1/2" /68mm Pressure Gauges
NORTH AMERICA
RGH5L
SOUTH
AMERICA
NORTH AMERICA
SOUTH AMERICA
RUBBER BOOT
RGH5H
GAUGE ONLY
GAUGE DESCRIPTION
AUSTRALIA
RGX68IB
Refrigerant Scales
Gauge Size / Type
* Gauges built with Internal
Silicon Dampening Cup
R134a, R22,
R404a, R410a
R410A, R22,
R407C
R134a, R22,
R404a, R410a
R410a
3 1/8" (80mm)
Class 1.0
3 1/8" (80mm)
Class 1.0
2 1/2"
(68mm)
Class 1.6
2 1/2"
(68mm)
Class 1.6
Pressure Scales
PSI
BAR / PSI
PSI
PSI / kPa
Temperature Scales
°F
°C
°F
°F / °C
Low Side Gauge
RGH4L
RGO4L
RGH5L
RGB5L
High Side Gauge
RGH4H
RGO4H
RGH5H
RGB5H
Item Number
RGX80IB
RGX80IB
RGX68SB
RGX68IB
Description
Ribbed Design
Ribbe Design
Spider Design
Spider Design
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
BLACKMAX® GAUGE CONFIGURATIONS
ITEM SPECIFICATIONS
NORTH
AMERICA
Pg 42
PREMIUM PISTON SERIES
PROPRIETARY TRIPLE SEAL VALVES
BEST IN CLASS 1% MEASUREMENT ACCURACY
Pg 43
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
PRO-SET® MANIFOLDS WORKINGMAN SERIES
The Workingman’s Choice series 2 valve anodized aluminum
block body with 1/4” SAE 45° fittings, Triple Seal piston valves,
sure grip rubber over metal valve handles, easy-to-read 3-1/8”
(80mm) Class 1.0 accuracy gauges, protective gauge boots,
extra access port in center with Schrader valve and
hanging hook.
MT2H7P5E
PRO-SET® WORKINGMAN’S CHOICE 2 VALVE MANIFOLDS
SPECIFICATIONS
SOUTH AMERICA
R134a, R22,
R404a, R410a
R410a, R22,
R407c
3 1/8” (80mm)
Class 1.0
Accuracy
3 1/8” (80mm)
Class 1.0
Accuracy
Pressure Scales
PSI
BAR / PSI
Temperature Scales
°F
˚C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
Manifold & Gauges Only
MT2H7
MT2O7
REPLACEMENT
GAUGES
TWO VALVE
MANIFOLDS
FITTINGS
GAUGE
DESCRIPTION
Refrigerant Scales
Gauge Size / Type
* Gauges built with Internal Silicon Dampening
Cup for Flutter-Free operation
3 Premium 5ft (150cm ) Pro-Set Hoses
MT2H7P5
MT2O7P5
3 Premium 5ft (150cm ) Pro-Set AB Hoses
MT2H7P5A
MT2O7P5A
3 Premium 5ft (150cm ) Pro-Set BV Hoses
MT2H7P5E
MT2O7P5E
Low Side Gauge
RGH7L
RGO7L
High Side Gauge
RGH7H
RGO7H
Replacement Gauge Boot
RGXBW
RGXBW
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
PRO-SET® MANIFOLD CONFIGURATIONS
NORTH AMERICA
Pg 44
PISTON SERIES - BLACK BODY
PROPRIETARY TRIPLE SEAL VALVES
Pg 45
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
PISTON BLACK BODY MANIFOLD SERIES
Piston series 2 valve anodized aluminum block body with ¼” SAE
45° fittings, Triple Seal piston valves, 2 ½” (68mm) Class 1.6
accuracy gauges, extra access port in center with Schrader valve
and hanging hook. MADE IN USA
MBDP5E
MBH
MBC
MBD
TRIPLE SEAL™ PISTON 2 VALVE BLACK BODY MANIFOLDS
S. AMERICA
S. AMERICA
ASIA
AUSTRALIA
R22, R404a,
R410a,
R12, R134a,
R22
R134a, R22,
R404a
R410a, R22,
R407c
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
PSI
PSI
PSI
PSI / kPa
PSI / kPa
BAR / PSI
Temperature Scales
°F
°F
°F
°F / °C
°C
°C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
Manifold & Gauges Only
MBC
MBD
MBH
MBZ
MBT
MBO
Three 3ft (150cm ) Pro-Set Hoses
MBCS3
MBDP3
MBHP3
MBZS3
MBTP3
MBOP3
Three 5ft (150cm ) Pro-Set Hoses
MBCS5
MBDP5
MBHP5
MBZS5
MBTP5
MBOP5
Three 5ft (150cm ) Pro-Set AB Hoses
NA
MBDP5A
MBHP5A
NA
MBTP5A
MBOP5A
Three 5ft (150cm ) Pro-Set BV Hoses
NA
MBDP5E
MBHP5E
NA
MBTP5E
MBOP5E
Low Side Gauge
RGCL
RGDL
RGHL
RGZL
RGTL
RGOL
High Side Gauge
RGCH
RGDH
RGHH
RGZH
RGTH
RGOH
SPECIFICATIONS
N. AMERICA
N. AMERICA
R12, R22,
R502
R134a, R22,
R404a
* Gauges built with Internal Silicon Dampening
Cup for Flutter-Free operation
2 1/2”
(68mm)
Class 1.6
Accuracy
Pressure Scales
REPLACEMENT
GAUGES
TWO VALVE
MANIFOLDS
FITTINGS
GAUGE
DESCRIPTION
Refrigerant Scales
Gauge Size / Type
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
S. AMERICA
PISTON BLACK BODY MANIFOLD CONFIGURATIONS
N. AMERICA
Pg 46
PISTON SERIES - PINK BODY
PROPRIETARY TRIPLE SEAL VALVES
Pg 47
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
PISTON PINK BODY MANIFOLD SERIES
Piston series 2 valve anodized aluminum block body with ¼” SAE
45° fittings, Triple Seal piston valves, 2 ½” (68mm) Class 1.6
accuracy gauges, extra access port in center with Schrader valve
and hanging hook. MADE IN USA
MEBP5E
MEB
MEH
NON-FLUTTER GAUGE
Design with Rugged Metal Housing
TRIPLE SEAL™ PISTON 2 VALVE PINK BODY MANIFOLDS
FRONT CALIBRATION
SPECIFICATIONS
N. AMERICA
Refrigerant Scales
R410a
R410a, R22,
R404a
R410a
Gauge Size / Type
*Gauges built with Internal Silicon
Dampening Cup for Flutter-Free operation
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
Pressure Scales
PSI / kPa
PSI
PSI / kPa
Temperature Scales
°F / °C
°F
°F / °C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/2” - 20
UNF
Manifold & Gauges Only
MEB
MEH
MCB
3 Premium 3ft (150cm ) Pro-Set Hoses
MEBP3
MEHP3
MCBJ3
3 Premium 5ft (150cm ) Pro-Set Hoses
MEBP5
MEHP5
MCBJ5
3 Premium 5ft (150cm ) Pro-Set AB Hoses
MEBP5A
MEHP5A
MCBJ5A
3 Premium 5ft (150cm ) Pro-Set BV Hoses
MEBP5E
MEHP5E
MCBJ5E
Low Side Gauge
RGBL
RGHL
RGBL
High Side Gauge
RGBH
RGHH
RGBH
EASY-TO-GRAB
Large Knob
• Three Super Neoprene o-ring design
• Back-seating o-ring seals valve nut
when fully open
• Floating nylon sealing disk
• Valve stems retract fully to provide
maximum flow
• Mirror-like port finish for smooth
valve movement
REPLACEMENT
GAUGES
TWO VALVE
MANIFOLDS
Triple Seal™ VALVES
FITTINGS
GAUGE
DESCRIPTION
Block Body
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
AUSTRALIA
PISTON PINK BODY MANIFOLD CONFIGURATIONS
Access Port
ANODIZED ALUMINUM
S. AMERICA
N. AMERICA
Pg 48
DEEP VACUUM
MULTI-VALVE SERIES
PROPRIETARY VORTECH VALVE SYSTEMS
Pg 49
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
VORTECH® DEEP VACUUM MANIFOLD SERIES
Deep Vacuum series 2 valve pink anodized aluminum block body
with ¼” SAE 45° fittings, Vortech Deep Vacuum Valves, extra
large sight glass, easy-to-read 3 1/8” (80mm) Class 1.6 accuracy
gauges, protective gauge boots, extra access port in center with
Schrader valve and hanging hook. MADE IN USA
MV3H2
MV3H2P5E
MV3H3
MV13H2
MV13H3
VORTECH DEEP VACUUM VALVE MANIFOLDS
SPECIFICATIONS
N. AMERICA
S. AMERICA
R410a. R22, R404a,
R134a
R410a, R22,
R404a, R143a
R410a, R22,
R407c
R410a
3 1/8” (80mm)
Class 1.6
Accuracy
3 1/8” (80mm)
Class 1.6
Accuracy
*Oil-Filled
3 1/8” (80mm)
Class 1.6
Accuracy
3 1/8” (80mm)
Class 1.6
Accuracy
*Oil-Filled
Pressure Scales
PSI
PSI
PSI / bar
PSI / kPa
Temperature Scales
°F
°F
°C
°F / °C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
Manifold & Gauges Only
MV3H2
MV3H3
MV3O2
MV3B3
3 Premium 5ft (150cm ) Pro-Set Hoses
MV3H2P5
MV3H3P5
MV3O2P5
MV3B3P5
3 Premium 5ft (150cm ) Pro-Set AB Hoses
MV3H2P5A
MV3H3P5A
MV3O2P5A
MV3B3P5A
3 Premium 5ft (150cm ) Pro-Set BV Hoses
MV3H2P5E
MV3H3P5E
MV3O2P5E
MV3B3P5E
Manifold & Gauges Only
MV13H2
MV13H3
MV13O2
MV13B3
3 Premium 5ft (150cm ) Pro-Set Hoses
MV13H2P5
MV13H3P5
MV13O2P5
MV13B3P5
3 Premium 5ft (150cm ) Pro-Set AB Hoses
MV13H2P5A
MV13H3P5A
MV13O2P5A
MV13B3P5A
3 Premium 5ft (150cm ) Pro-Set BV Hoses
MV13H2P5E
MV13H3P5E
MV13O2P5E
MV13B3P5E
Low Side Gauge
RGH2LB
RGH3L
RGO2LB
RGB3L
High Side Gauge
RGH2HB
RGH3H
RGO2HB
RGB3H
GAUGE
DESCRIPTION
FITTINGS
TWO VALVE
MANIFOLDS
FOUR VALVE
MANIFOLDS
Gauge Size / Type
* Gauges built with Internal Silicon Dampening
Cup for Flutter-Free operation
AUSTRALIA
VORTECH® DEEP VACUUM MANIFOLD CONFIGURATIONS
Refrigerant Scales
REPLACEMENT
GAUGES
S. AMERICA
N. AMERICA
Manifolds & Gauges
VORTECH™ DEEP VACUUM
MANIFOLD SERIES
Deep Vacuum series 5 valve anodized aluminum
block body with four ¼” SAE ports, one 3/8” SAE
vacuum port, Vortech Deep Vacuum Valves, VG200
electronic vacuum gauge, extra large sight glass,
easy-to-read 3 3/8” (80mm) Class 1.6
accuracy gauges, protective gauge boots, two
hanging hooks and plastic carrying case.
MADE IN USA
MV5H2D
VORTECH™ DEEP VACUUM 5 VALVE BLACK BODY MANIFOLDS
N. AMERICA
S. AMERICA
R410a, R22,
R404a, R134a
R410a, R22,
R404a, R134a
R410a, R22,
R407c
R410a
*Gauges built with Internal Silicon
Dampening Cup for Flutter-Free operation
3 1/8”
(80mm)
Class 1.6
Accuracy
3 1/8”
(80mm)
Class 1.6
Accuracy
*Oil-Filled
3 1/8”
(80mm)
Class 1.6
Accuracy
3 1/8”
(80mm)
Class 1.6
Accuracy
*Oil-Filled
Pressure Scales
PSI
PSI
BAR / PSI
PSI / kpa
Temperature Scales
°F
°F
°C
°F / °C
FITTINGS
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
FIVE
VALVE
S. AMERICA
N. AMERICA
Manifold & Gauges Only
MV5H2D
MV5H3D
MV5O2D
MV5B3D
Low Side Gauge
RGH2LB
RGH3L
RGO2LB
RGB3L
High Side Gauge
RGH2HB
RGH3H
RGO2HB
RGB3H
GAUGE
DESCRIPTION
Refrigerant Scales
REPLACEMENT
GAUGES
DEEP VACUUM MANIFOLD CONFIGURATIONS
SPECIFICATIONS
Gauge Size / Type
AUSTRALIA
RGH2L
RGH2H
Pg 51
Visit us Online at www.cpsproducts.com
VORTECH™ DEEP VACUUM
MANIFOLD SERIES
Deep Vacuum series 5 valve anodized aluminum block
body with four ¼” SAE ports, one 3/8” SAE vacuum port,
Vortech Deep Vacuum Valves, VG200 electronic vacuum
gauge, extra large sight glass, oil-filled 3 3/8” (80mm)
Class 1.6 accuracy gauges, two hanging hooks and
plastic carrying case. MADE IN USA
RGB3L
MV5H3D
PRO-SET® 3 1/8' / 80mm PREMIUM PRESSURE GAUGES
RGB3H
NORTH
AMERICA
SOUTH AMERICA
R410a, R22,
R404a, R134a
R410a, R22,
R404a, R134a
R410a, R22,
R407c
R410a
* Gauges built with Internal
Silicon Dampening Cup
3 1/8” (80mm)
Class 1.6
Accuracy
3 1/8” (80mm)
Class 1.6
Accuracy
*Oil-Filled
3 1/8” (80mm)
Class 1.6
Accuracy
3 1/8” (80mm)
Class 1.6
Accuracy
*Oil-Filled
Pressure Scales
PSI
PSI
BAR / PSI
PSI / kpa
Temperature Scales
°F
°F
°C
°F / °C
Low Side Gauge
RGH2L
RGH3L
RGO2L
RGB3L
High Side Gauge
RGH2H
RGH3H
RGO2H
RGB3H
Low Side Gauge
RGX80BB
NA
RGX80BB
NA
High Side Gauge
RGX80RB
NA
RGX80RB
NA
GAUGE DESCRIPTION
GAUGE ONLY
RUBBER BOOT
Refrigerant Scales
Gauge Size / Type
AUSTRALIA
PRESSURE GAUGE CONFIGURATIONS
RGO2L
SOUTH AMERICA
NORTH
AMERICA
ITEM SPECIFICATIONS
RGO2H
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 52
BALL VALVE SERIES
1/4 TURN, FULL OPEN/CLOSE VALVES
Pg 53
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
BALL VALVE BODY MANIFOLD SERIES
Ball Valve series 2 valve anodized aluminum block body with
¼” SAE fittings, full flow ball valve design, 2 ½” (68mm)
Class 1.6 accuracy gauges, and hanging hook.
MADE IN USA
MGH
MGO
VORTECH™ DEEP VACUUM VALVE MANIFOLDS
REPLACEMENT
GAUGES
TWO VALVE
MANIFOLDS
FITTINGS
GAUGE
DESCRIPTION
SPECIFICATIONS
N. AMERICA
S. AMERICA
Refrigerant Scales
R410a, R22, R404a
R410a, R22, R407c
Gauge Size / Type
2 1/2” (68mm)
Class 1.6
Accuracy
2 1/2” (68mm)
Class 1.6
Accuracy
* Gauges built with Internal Silicon Dampening Cup
for Flutter-Free operation
Pressure Scales
PSI
BAR / PSI
Temperature Scales
°F
°C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
Manifold & Gauges Only
MGH
MGO
3 Premium 5ft (150cm ) Premium Barrier Hoses
MGHP5
MGOP5
3 Premium 5ft (150cm ) Premium Barrier AB Hoses
MGHP5A
MGOP5A
3 Premium 5ft (150cm ) Premium Barrier BV Hoses
MGHP5E
MGOP5E
Low Side Gauge
RGHL
RGOL
High Side Gauge
RGHH
RGOH
MGHP5E
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 54
BRASS BODY SERIES
THE ORIGINAL MANIFOLD DESIGN
Pg 55
Visit us Online at www.cpsproducts.com
Manifolds & Gauges
BRASS BODY MANIFOLD SERIES
Brass series 2 valve forged brass body with ¼” SAE 45°
fittings, piston valves, 2 ½” (68mm) Class 1.6 accuracy
gauges and hanging hook.
• Quality forged brass body
• Sliding double o-ring piston valve system
• Full sized porting for maximum flow
• No flutter gauges with rugged Metal housings
• Large easy-to-grip knobs
M6DP5
PREMIUM BRASS BODY 2 VALVE MANIFOLDS
FITTINGS
TWO VALVE
MANIFOLDS
REPLACEMENT
GAUGES
N. AMERICA
S. AMERICA
Refrigerant Scales
R134a, R22, R404a
R12, R22, R134a
Gauge Size / Type
* Gauges built with Internal Silicon Dampening Cup
for Flutter-Free operation
2 1/2”
(68mm)
Class 1.6
Accuracy
2 1/2”
(68mm)
Class 1.6
Accuracy
Pressure Scales
PSI
PSI / kPa
Temperature Scales
°F
°F / °C
Manifold and Hose Fittings
1/4” SAE
45° Fittings
1/4” SAE
45° Fittings
Manifold & Gauges Only
M6D
M6Z
3 Premium 3ft (150cm ) Pro-Set Hoses
M6DP3
M6ZP3
3 Premium 5ft (150cm ) Pro-Set Hoses
M6DP5
M6ZP5
Low Side Gauge
RGDL
RGZL
High Side Gauge
RGDH
RGZH
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
BRASS BODY MANIFOLD CONFIGURATIONS
GAUGE
DESCRIPTION
SPECIFICATIONS
Pg 56
Manifolds & Gauges
MANIFOLD & GAUGE
ACCESSORIES
A complete line of repair kits, parts
and accessories to keep your
manifold tuned up and in top shape!
MX2C
MXMH
MXPV
M2XHA
MANIFOLD & GAUGE ACCESSORIES
ITEM
MXC
DESCRIPTION
M2XHA
2-way hose anchor bracket for Vortech & diaphragm
M2XRK
Diaphragm valve repair kit: sevices 2 valves
M4XHA
4-way hose anchor bracket for Vortech & diaphragm
M4XRK
Diaphragm valve repair kit: sevices 4 valves
M5XRK
Diaphragm valve repair kit: sevices 5 valves
MV2XRK
Vortech valve repair kit: services 2 valves
MV4XRK
Vortech valve repair kit: services 4 valves
MV5XRK
Vortech valve repair kit: services 5 valves
MVXK
Replacement valve handle w/ plugs for Vortech manifolds
MXBK
Replacement valve handle for brass manifold
MXC
Plastic carrying case for manifolds
MX2C
Rugged canvas carrying case for manifolds
MXK
Replacement valve handle w/ labels for diaphragm manifolds
MXMH
Hanging hook for all manifolds
MXPK
Replacement valve handle w/ labels for BLACKMAX manifolds
MXPV
Complete BLACKMAX piston valve assembly
MXPVO
BLACKMAX piston valve seals repair kit: services 2 valves
MVXK
M2XRK
MVXKC
MXPK
MXK
Pg 57
Visit us Online at www.cpsproducts.com
MXPVO
GAS PRESSURE TEST ASSEMBLIES
The GT1 and GT2 are designed to test the
integrity of new installations for pressure leaks.
Available with either a 3/4” or 1” FPT brass bell.
Simply connect the test assembly, pressurize
the system using the supplied access port and
monitor the easy-to-read 3 1/2” / 80mm gauge
for potential pressure drops that would indicate
a leak.
GT1
GT2
GT4
GT1 GAS TEST GAUGE
GT2 GAS TEST GAUGE
• Large 3 1/8” gauge - easy to read
• 0-30 PSIG (0-2 BAR) pressure scale
• 1 PSIG increments
• 3/4” FPT hex style brass bell
• Access valve
• Large 3 1/8” gauge - easy to read
• 0-30 PSIG (0-2 BAR) pressure scale
• 1 PSIG increments
• 3/4” FPT hex style brass bell
• Access valve
GT3 FUEL OIL TEST KIT
INCLUDES:
The GT3 is a comprehensive test kit
which includes the components
necessary to test oil fuel pump
performance while diagnosing
related burner efficiency issues such
as cleaner light-offs and coasting
stops.
• 2 1/2” gauge, scale 30”, 0-150 lbs
• 2 1/2” gauge, scale 30”, 0-300 lbs
• 12” hose 1/4” Fem swivel x 1/4”
Fem 45° swivel
• 1/8 NPT x 1/4 Male SAE adapter
• 1/8 NPT x 1/4 Male SAE 90° adapter
• 1/4 NPT x 1/4 Male SAE adapter
• 1/4 NPT x 1/4 Male SAE 90° adapter
• Carrying Case
GT3
Pg 58
VACUUM / CHARGING HOSES
OUR OFFERING IS AS FLEXIBLE AS OUR HOSES
Pg 59
Visit us Online at www.cpsproducts.com
Vacuum /
Charging Hoses
PRO-SET® PREMIUM BARRIER CHARGING HOSES
• R-410A Compatible
• 800 psi working pressure; 4000 psi burst
• Environment friendly Nylon Permeation Barrier meets SAE J2196
• Compatible with CFC, HCFC and HFC refrigerants & blends
• Available with MicroSeal or ball valve fittings
HP3E
PREMIUM CHARGING HOSES
LENGTH
YELLOW
BLUE
RED
3-PACK
1/4” Premium Hoses For All Refrigerants
HP3
3’ - 90cm
HP3Y
HP3B
HP3R
HP3
5’ - 150cm
HP5Y
HP5B
HP5R
HP5
6’ - 180cm
HP6Y
HP6B
HP6R
HP6
HP3YE
HP3BE
HP3RE
HP3E
5’ - 150cm
HP5YE
HP5BE
HP5RE
HP5E
6’ - 180cm
HP6YE
HP6BE
HP6RE
HP6E
1/4” Premium Hoses With MICROSEAL™ Anti-Blowback Valve On One End
HP3A
3’ - 90cm
HP3YA
HP3BA
HP3RA
HP3A
5’ - 150cm
HP5YA
HP5BA
HP5RA
HP5A
HP6YA
HP6BA
HP6RA
HP6A
6’ - 180cm
1/4” Premium In-Line Ball Valve Hoses
3’ - 90cm
HP3YL
HP3BL
HP3RL
HP3L
5’ - 150cm
HP5YL
HP5BL
HP5RL
HP5L
6’ - 180cm
HP6YL
HP6BL
HP6RL
HP6L
R-410A Premium Hose w/ Special 1/2”-20 UNF Fittings
HP3L
3’ - 90cm
HJ3Y
HJ3B
HJ3R
HJ3
5’ - 150cm
HJ5Y
HJ5B
HJ5R
HJ5
WITH 45° BALL VALVE FITTING IN ONE END
3’ - 90cm
HJ3YE
HJ3BE
HJ3RE
HJ3E
5’ - 150cm
HJ5YE
HJ5BE
HJ5RE
HJ5E
PRO-SET® PREMIUM HOSE CONFIGURATIONS
1/4” Premium Hoses With 45° Ball Valve On End
3’ - 90cm
6” - 12” Ball Valve Hose Extensions
HJ3
HTE
6”
1/4 SAE
HTYE
HTBE
HTRE
HTE
12”
1/4 SAE
HT1YE
HT1BE
HT1RE
HT1E
6”
1/2-20 UNF
HT410YEJ
HT410BEJ
HT410REJ
HT410EJ
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 60
Vacuum /
Charging Hoses
STANDARD CHARGING HOSES
•All-weather flexibility and strength
•Extra deep knurling on nuts for easy grip
•750 psi working pressure; 3000 psi burst
•1/4” SAE fittings with 45° bend on one end
•Available with MicroSeal™ or ball valve fittings
•Leak-proof eight-sided crimp
•Blow-off grooves channel refrigerant to prevent spray back
HS3
Integral adjustable valve core depressor can open all
types of Schraeder valves.
HS3E
STANDARD CHARGING HOSES
LENGTH
YELLOW
BLUE
RED
3-PACK
STANDARD HOSE CONFIGURATIONS
1/4” Standard Hoses
3’ - 90cm
HS3Y
HS3B
HS3R
HS3
4’ - 120cm
HS4Y
HS4B
HS4R
HS4
5’ - 150cm
HS5Y
HS5B
HS5R
HS5
6’ - 180cm
HS6Y
HS6B
HS6R
HS6
8’ - 240cm
HS8Y
HS8B
HS8R
HS8
10’ - 300cm
HS10Y
HS10B
HS10R
HS10
1/4” Standard Hoses With 45° Ball Valve On End
3’ - 90cm
HS3YE
HS3BE
HS3RE
HS3E
5’ - 150cm
HS5YE
HS5BE
HS5RE
HS5E
6’ - 180cm
HS6YE
HS6BE
HS6RE
HS6E
8’ - 240cm
HS8YE
HS8BE
HS8RE
HS8E
HS3A
1/4” Standard Hoses With MICROSEAL™ Anti-Blowback Valve On One End
3’ - 90cm
HS3YA
HS3BA
HS3RA
HS3A
5’ - 150cm
HS5YA
HS5BA
HS5RA
HS5A
6’ - 180cm
HS6YA
HS6BA
HS6RA
HS6A
8’ - 240cm
HS8YA
HS8BA
HS8RA
HS8A
1/4” Standard In-Line Ball Valve Hoses
Pg 61
3’ - 90cm
HS3YL
HS3BL
HS3RL
HS3L
5’ - 150cm
HS5YL
HS5BL
HS5RL
HS5L
6’ - 180cm
HS6YL
HS6BL
HS6RL
HS6L
8’ - 240cm
HS8YL
HS8BL
HS8RL
HS8L
Visit us Online at www.cpsproducts.com
HS3L
Premium 3/8” Vacuum /
Charging Hoses
• 5/16” I.D. heavy-duty hose
• Permeation resistant barrier
• 460 psi working pressure;
2300 psi burst
Premium Pressure Control Hoses
• Replaces Standard Copper Capillary Tubing
• 1/4” SAE Hex Style Fittings
HV3
ITEM
PARTS DESCRIPTION
HXGD2
1/2”-20 UNF &1/2” ACME Hose Gaskets
HX3G
3/16” Hose Gasket (10)
HX14R
14mm Hose Rings (10)
HX38G
3/8” Hose Gaskets (10)
J-TYPE CHARGING HOSES
HXG2
1/2” UNF &1/2” ACME Hose Gaskets (10),core depressors (10)
HXGA
Microseal Antiblowback gaskets (10)
HXGA410
1/2”-20 UNF Microseal Antiblowback gaskets (10)
HXTG
1/4” SAE Teflon hose gasket (10)
HXTG2
1/2”-20 UNF & 1/2” ACME Teflon hose gasket (10)
HHC2S
Premium Pressure Control Hoses
LENGTH
90° x 90°
Straight x 90°
2’ - 60cm
HHC2
HHC2S
3’ - 90cm
HHC3
HHC3S
4’ - 120cm
HHC4
HHC4S
Premium 3/8” Vacuum/Charging Hoses
HOSE P/N
HXTG2
HX14R
LENGTH
WITHOUT BALL VALVE
HV3
3’ - 90cm
HV5
5’ - 150cm
HV6
6’ - 180cm
HV8
8’ - 240cm
WITH IN-LINE BALL VALVE
HV5E
HXGD2
5’ - 150cm
REPLACEMENT PARTS & ACCESSORIES
Replacement Hose Gaskets,
Depressors & O-Rings
HXG2
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 62
CHARGING HOSE VALVES
PRECISION MACHINED, SOLID BRASS
Pg 63
Visit us Online at www.cpsproducts.com
Charging Hose Valves
Premium PRO-SET® Ball Valves
• Add to existing hose to eliminate refrigerant loss and comply with
EPA regulations
• Easy 1/4 turn open/close with rugged plastic composite
color-coded handles
• Oversized chrome ball for smooth operation and non-restrictive flow
• Individual valves include all three color-coded handle inserts
BV
BV45
PRO-SET® Ball Valve Specifications
BV90
Qty / Pk
Female
male
Other
BV
1
1/4” SAE
1/4” SAE
Straight
BV3
3
1/4” SAE
1/4” SAE
Straight
BV38
1
3/8” SAE
3/8” SAE
Straight
1/2” - 20 UNF
BV410
1
BV41018
1
1/2” - 20 UNF
Straight
1/2” 20 UNF x 1/8” MNPT
Straight
BV4103
3
1/2” - 20 UNF
1/2” - 20 UNF
Straight
BV41090A
1
1/2” - 20 UNF 90°
1/4” SAE
90° FM
BV410A
1
1/2” - 20 UNF
1/4” SAE
Straight
BV45
1
1/4” SAE 45°
1/4” SAE
45° FM
BV453
3
1/4” SAE 45°
1/4” SAE
45° FM
BV90
1
1/4” SAE 90°
1/4” SAE
90° FM
BV903
3
1/4” SAE 90°
1/4” SAE
90° FM
BVAD38
1
3/8” SAE
1/4” SAE
Straight
BVBH
1
1/4” SAE x 1/16” MNPT
Bulkhead
BVM
1
1/4” SAE x 1/4” SAE
Straight
BVM3
3
1/4” SAE x 1/4” SAE
Straight
BVXH
3
Replacement Ball Valve Handle w/1 ea (Yellow, Blue, Red) inserts
MICROSEAL™ Anti-Blowback Valve Specifications
AB12
AB3
ABG18
AB
1
1/4” SAE
1/4” SAE
Straight
AB12
1
1/2” ACME
1/2” ACME
Straight
AB3
3
1/4” SAE
1/4” SAE
Straight
AB410
1
1/2” - 20 UNF
1/2” - 20 UNF
Straight
AB4103
3
1/2” - 20 UNF
1/2” - 20 UNF
Straight
AB41090A
1
1/2” - 20 UNF
1/4” SAE
90° FM
AB410A
1
1/2” - 20 UNF
1/4” SAE
Straight
AB90
1
1/4” SAE 90°
1/4” SAE
90° FM
AB903
3
1/4” SAE 90°
1/4” SAE
ABG18
1
1/4” SAE x 1/8”FNPT
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
CHARGING HOSE VALVE SPECIFICATIONS
BVM
ITEM
90° FM
1/8” FNPT is not an AB
Pg 64
BRASS ADAPTERS, FITTINGS
& VALVE CORE TOOLS
MANUFACTURED TO STRINGENT INDUSTRY STANDARDS
Pg 65
Visit us Online at www.cpsproducts.com
brass adapters
ITEM
Qty / Pk
Female
male
Other
APPLICATION
AD12
1
1/2" ACME
LO-side R-134a
-
R-134a automotive tanks
AD12B
100
1/2" ACME
LO-side R-134a
Bulk
R-134a automotive tanks
AD14
1
-
14mm x 1/4" SAE
-
R-134a automotive couplers
AD14B
100
-
14mm x 1/4" SAE
Bulk
R-134a automotive couplers
AD18C
1
1/4" SAE
1/8" SAE
w/ valve core
Manifolds, Compressors
AD24
6
-
1/4" SAE x 1/8" MNPT
w/ valve core
Manifolds, Compressors
AD24B
100
-
1/4" SAE x 1/8" MNPT
Bulk
1/4” Service Manifolds
AD36
1
3/16" SAE
1/4" SAE
no valve core
TLVC Valve Core Tool for R-12 Auto. HI-side
AD36C
1
3/16" SAE
1/4" SAE
w/ valve core
Automotive Adapter
AD41
1
3/4" -14
1/4" SAE
w/ gasket
Large 125 lb cylinders
AD41B
100
3/4" -14
1/4" SAE
Bulk
Large 125 lb cylinders
1
3/4" -14
3/8" SAE
w/ gasket
Large 125 lb cylinders
100
3/4" -14
3/8" SAE
Bulk
Large 125 lb cylinders
AD44
6
-
1/4" SAE x 1/4" MNPT
w/ valve core & cap
Vacuum Pumps, Compressors
AD44B
100
-
1/4" SAE x 1/4" MNPT
Bulk
Vacuum Pumps, Compressors
AD47
1
-
1/4" SAE X 1/4" SAE
-
1/4” Hose Union
AD47B
100
-
1/4" SAE X 1/4" SAE
Bulk
1/4” Hose Union
AD48
3
1/4" SAE
1/2" ACME
w/ valve core
Vacuum Pumps/Manifolds/Recovery/Tanks
AD48B
50
1/4" SAE
1/2" ACME
w/ valve core
Vacuum Pumps/Manifolds/Recovery/Tanks
AD48C
300
1/4" SAE
1/2" ACME
no valve core
Vacuum Pumps/Manifolds/Recovery/Tanks
AD68
3
1/4" SAE
3/8" SAE
w/core & Depressor
Vacuum Pumps
AD68V
1
1/2" ACME
3/8" SAE
w/core & Depressor Bulk
Vacuum Pumps
AD78
1
1/4" SAE
1/2"-20 UNF
w/ valve core
R-410A International
AD78B
100
1/4" SAE
1/2"-20 UNF
Bulk
R-410A International
AD81
1
3/4" -14
1/2" ACME
w/ gasket
Large 125 lb cylinder
AD81B
100
3/4" -14
1/2" ACME
Bulk
Large 125 lb cylinder
AD84
3
1/2" ACME
1/4" SAE
no valve core
Vacuum Pumps/Manifolds/Recovery/Tanks
AD84B
100
1/2" ACME
1/4" SAE
Bulk
Vacuum Pumps/Manifolds/Recovery/Tanks
AD84C
3
1/2" ACME
1/4" SAE
w/ valve core
Vacuum Pumps/Manifolds/Recovery/Tanks
AD84CB
100
1/2” ACME
1/4” SAE
Bulk
Vacuum Pumps/Manifolds/Recovery/Tanks
AD87
1
1/2"-20 UNF
1/4" SAE
w/ valve core
R-410A International
AD87S
1
1/2"-20 UNF SWVL
1/4" SAE 55D
w/ valve core
R-410A International
AD149C
1
1/4" SAE
1/4" SAE 90D
w/ valve core
Automotive Adapter
AD369C
1
3/16" SAE
1/4" SAE 90D
w/ valve core
Automotive Adapter
AD849C
3
1/2" ACME 90°
1/4" SAE 90D
w/ valve core
Automotive Adapter
AD51B
100
5/8 BPS
1/4” SAE
Bulk
Large Cylinder Adapter
AD64
1
1/4” SAE
3/8” SAE
adapter
-
AD91
1
21.8 Whitworth
3/8” SAE
w/ gasket
Large Cylinder Adapter
AD91B
100
21.8 Whitworth
1/4” SAE
Bulk
Large Cylinder Adapter
AD91C
1
21.8 Whitworth
-
Cap w/ Gasket
-
AD91CB
100
21.8 Whitworth
-
Bulk
-
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
HVAC/R ADAPTER SPECIFICATIONS
AD61
AD61B
Pg 66
Adapters / Fittings
& Valve Core Tools
Quick Seal O-Ring Caps & Valve Cores
RING CAP & VALVE CORE SPECIFICATIONS
ITEM
Qty / Pk
AVC4
AVC4R
AVS1
DESCRIPTION
AVC134C
2
1/2" ACME Brass Caps w/Chain
AVC134CB
100
1/2" ACME Brass Caps w/Chain (BULK)
AVC134H
10
R-134a HI Side Caps
AVC134HB
100
R-134a HI Side Caps
AVC134L
10
R-134a LO Side Caps
AVC134LB
100
R-134a LO Side Caps
AVC134PS
2
1/2" ACME Plastic Cap w/ Straps
AVC134PSB
100
1/2" ACME Plastic Cap w/ Straps
AVC2
10
1/4" Aluminum Term Caps
AVC3
10
3/16" Aluminum Term Caps
AVC3P
10
3/16" Plastic Caps
TLVC
1/4" SAE Remover & Installer
1/4" SAE valve core remover & installer w/side port
AVC8C
AVC6C
AVC134C
AVC4C
AVC410C
Valve Core Tool Accessories
ITEM
DESCRIPTION
AVC3PB
10
3/16" Plastic Caps
TLVCS
AVC410
10
1/2"-20 UNF SAE Brass Caps
TLVC1
Standard Valve Core w/3 cores
AVC410B
100
1/2"-20 UNF SAE Brass Caps
TLVC2
Dual Valve Core Standard & Large Bore Remover/Installer
Dual valve core tool (Bulk 100pk)
AVC410C
2
1/2" -20 UNF SAE Brass Caps w/ Chain
TLVC2B
AVC410CB
100
1/2" -20 UNF SAE Brass Caps w/ Chain (BULK)
TLVC4
Valve Core Remover/Installer with Port Rethreader
JRA 6mm Valve Core Remover/Installer
R-134a Valve Core Remover & Installer
AVC4
10
1/4" SAE Brass Caps
TLVC6
AVC425
25
1/4" SAE Brass Caps
TLVC134
AVC4B
100
1/4" SAE Brass Caps Bulk
TLVC410
1/2"-20 UNF Remover/Installer
AVC4C
2
1/4" SAE Brass Caps w/ Chain
TLVCS410
1/2"-20 UNF Valve Core Remover/Installer w/side port
AVC4CB
100
1/4" SAE Brass Caps w/ Chain (BULK)
TLVC810
EATON 8 & 10mm Valve Core Remover/Installer
Broken Schrader Extractor Tool for TLVC/TLVCS
AVC4P
6
1/4" SAE Plastic Caps
TLXVCBC
AVC4PB
100
1/4" SAE Plastic Caps
TLXVCRT
Schrader Rethreading Tool for TLVC/TLVCS
Digital Thermometer Accessory for TLVC/TLVCS
AVC6C
2
3/8" SAE Brass Caps w/ Chain
TLXVCT
AVC6CB
100
3/8" SAE Brass Caps w/ Chain (BULK)
TLXVC410BC
Broken Schrader Extractor Tool for TLVC410/TLVCS410
AVC8C
2
1/2" SAE Brass Caps w/ Chain
TLXVC410RT
Schrader Rethreading Tool for TLVC410/TLVCS410
AVC8BC
100
1/2" SAE Brass Caps w/ Chain (BULK)
AVC4PS
6
1/4" SAE Plastic Caps w/ Straps
AVC4R
6
1/4" SAE Brass Caps w/ Core Remover
AVC4RB
100
1/4" SAE Brass Caps w/ Core Remover Bulk
AVC6P
3
3/8" SAE Plastic Caps
AVLP
1
Univ. Line Tap Valve 3/16" - 3/8" O.D.
AVS1
10
Valve Cores
AVS125
25
Valve Cores
AVS1B
100
Valve Cores Bulk
AVS1BC
1000
Valve Cores Bulk
AVS2
10
GM Large Bore Valve Core
AVS3
10vv
JRA 6mm Valve Cores
TLVC
TLXVCT
TLXVCBC
AVB34 - 6PK
AVB34B - 100PK
3/16” ID x 1/4” OD
AVB346 - 6PK
AVB346B - 100PK
AVB346BU - 100PK unassbld
AVB346RB - 100PK cap w/core tool
3/16” ID x 1/4” OD x 3/8” OD
AVB46 - 6PK
AVB46B - 100PK
1/4” ID x 3/8” OD
AVT4P
AVT2P
AVT44
AVB456 - 6PK
AVB456B - 100PK
1/8” ID x 3/16”, 1/4”, 5/16”
AVB6 - 6PK
AVB6B - 100PK
AVB6BC -100PK w/o caps
6-8-10mm OD Solder
ITEM
HVAC/R Access Fittings
6pk
100pk
Description
AVT4
Wrench Cap
6pk
100pk
AV2PB
1/8” MPT x 1/4” I.D.
N/A
N/A
AV3
AV3B
3/16” O.D. x 1/8” I.D.
AV3R
AV3RB
AV4
AV4B
1/4” O.D. x 3/16” I.D.
AV4R
AV4RB
AVT44
AV4BU
1/4” O.D. x 3/16” I.D.
UNASSMBLD
N/A
N/A
AVT45
AV4L
AV4LB
1/4” O.D. x 3/16” I.D.
W/4” COP-TB EXT
AV4LR
AV4LRB
AVT48
AV4P
AV4PB
1/4” MPT x 1/4” I.D. SOL
N/A
N/A
AV5
AV5B
5/16” O.D. x 1/4” I.D.
AV5R
AV5RB
AV6
AV6B
3/8” O.D. x 5/16” I.D.
AV6R
AV6RB
AV6MM
AV6MB
6mm O.D. x 5mm I.D.
AV6MR
AV6MRB
AV4410
AV4410B
1/2-20 ACCES,1/4” O.D.
X 3/16” I.D.
N/A
N/A
AV46M
AV46MB
6mm O.D. x 1/4” O.D.
N/A
N/A
AVCT4
AV2
• Includes Wrench Cap
• Extension length approx. 2”
• For Use with all Refrigerants
• Valves Meet ARI Standard 720-97
• Material is CDA 360 Brass & Standard
Refrigeration Tubing
AVT4M
AVT64
AVT64B
AVT87
Qty/Pk
DESCRIPTION
3
1/4” Male w/Cap & Valve Core x
1/4” Male x 1/8” MNPT
3
1/4” Male w/Cap & Valve Core x
1/8” MNPT x 1/4” Male
100
1/4” Male w/Cap & Valve Core x
1/8” MNPT x 1/4” Male
3
1/4” Male w/Cap & Valve Core x
1/4” Male x 1/4” MNPT
3
1/4” Male x 1/8” MNPT x
1/4” Male w/Core
3
1/4” Female Hex x 1/4” SAE male x
1/4” male w/Cap & Valve Core
3
1/4” Male x 1/4” Female Knurl
x 1/4” Male
1
1/4” Male x 1/4” Female Knurl
x 1/2” Acme Male
3
1/4” Male w/Cap & Valve Core
x 1/4” Male x 1/4” Female Hex
100
1/4” Male w/Cap & Valve Core
x 1/4” Malex 1/4” Female Hex
1
1/4” Male x 1/2”-20 UNF Female
x 1/2”-20 UNF Male (R-410A)
1/4” SAE Access Valve With
Copper Tube On Branch
ITEM
Qty/Pk
DESCRIPTION
AVCT4
3
1/4” SAE x 1/4” O.D.F
AVCT4B
100
1/4” SAE x 1/4” O.D.F
AVCT5
3
1/4” SAE x 5/16” O.D.F
AVCT6
3
1/4” SAE x 3/8” O.D.F
AVCT8
3
1/4” SAE x 1/2” O.D.F
AVCT10
1
1/4” SAE x 5/8” O.D.F
AVCT12
1
1/4” SAE x 3/4” O.D.F
AVCT14
1
1/4” SAE x 7/8” O.D.F
AVCT18
1
1/4” SAE x 1-1/8” O.D.F
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
ACCESS VALVE & CONNECTOR SPECIFICATIONS
AV2P
AVS44
AV2RB
AVT4P
AV2B
AVCT8
AV2R
AVT4B
AV2
AVCT10
1/8” O.D.x 1/16” I.D.
AVT64
1/4”SAE Tee Connectors
AVT2P
Standard Cap
AVT4M
Pg 68
TUBING TOOLS
ERGONOMIC TOOLS FOR CUTTING, FORMING & BENDING
Pg 69
Visit us Online at www.cpsproducts.com
Tubing Tools
TCT206
TCT174
TCT274
PRO-SET® HEAVY DUTY TITANIUM
TUBE CUTTERS
You need tools that work as hard as you do and nothing
outperforms like the power of the Pro-Set Titanium HD
series. Put them to work for you on your next job.
TCT127
PERFORMANCE THAT
REALLY MAKES THE CUT
• All cutter wheels are precision machined from high grade
chromium steel and plated with Titanium Nitride to
increase life up to 5 times longer
• Precision machined rollers feature cut-off groove to
reduce tube loss in damaged flare removal
• Durable metal handle with industrial grade rubber boot
provides sure comfortable grip
ITEM
Cutting Range
(inches)
Cutting Range
(millimeters)
TCPVC
1/4” - 2 5/8”
6 to 68mm
TCT174
1/8” - 1 1/8
3 to 30mm
TCT206
1/4” - 2 5/8”
6 to 68mm
TCT127
1/8” - 5/8”
3 to 16mm
TCT274
1/8” - 1 3/8”
3 to 35mm
TCT312
1/8” - 1 3/4”
3 to 45mm
TCT SPECIFICATIONS
KEY FEATURES:
TITANIUM TUBE CUTTERS
• Integrated retractable and replaceable rotary reamer
tool for ease in deburring pipe
• Enclosed hardened steel, thrust bearing feed mechanism
for smooth cutting action and trouble free operation
• Available in 5 popular configurations to accommodate
cutting of 1/8” (4mm) up to 2 5/8” (66mm) O.D. tubing
• Produces clean right angle cuts every time
Integrated retractable
and replaceable
reamer tool
TCPVC
Ratcheting PVC Tube Cutter:
•Ratcheting PVC tube cutter
•Heavy duty all metal construction
•Capacity up to 5/8”
•Cuts CPVC, PVC, plastic & rubber tubing
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 70
Tubing Tools
TC174
Big mini tube cutter
Capacity: 3/8” to 1-1/8”
(9.5mm to 28mm)
* Wide Flare Cut-off Groove
to accommodate flares on
large size tubing.
TC206
Premium ratchet
feed tube cutter
TC312
Heavy duty
tube cutter
Capacity: 3/8” to 2-5/8” O.D.
Capacity: 1/4” to 1-5/8”
PRO-SET® TUBE CUTTER SPECIFICATIONS
* Ratchet feed mechanism speeds
up cutting operation.
Capacity: 1/8” to 5/8”
(4mm to 15mm)
(7mm to 41mm)
* Spare Cutting Wheel Located under
retractable locking reamer.
ITEM
DESCRIPTION
TC174
Big Mini Tube Cutter 3/8" - 1 1/8", 9.5 - 28 mm
TCX7C
TC127 Cutting Wheel- (10 PK)
TCX7S
TC127 Cutting Wheel Screw- (10 PK)
TC312
Heavy Duty Tube Cutter 1/4" to 1 5/8", 7 to 41 mm
TCX4C
TC274 / 312 Cutting Wheel- (10 PK)
TCX4R
TC274 / TC312 Reamer Blade
TCX4RS
TC274 / TC312 Reamer Blade Screw
TCX4S
TC274 / TC312 Cutting Wheel Screw- (10 PK)
TCSET
TC127 / TC274 Tubing Cutter Set
TC100
Tube Cutter - 1/4" - 7/8". 6 - 23mm
TCX4CS
Cutting Wheel and Screw for TC274 / TC312
TCX7CS
Cutting Wheel and Screw for TC127
TCX100CS
Cutting Wheel and Screw for TC100
TCX4CTS
Titanium Cutting Wheel and Screw for
TCTC174/274/312
TCX6CTS
Titanium Cutting Wheel and Screw for TC206
TCX7CTS
Titanium Cutting Wheel and Screw for TC127
TC274
Premium tube cutter
Capacity: 1/8” to 1-1/8”
(4mm to 28mm)
TCX4S
TCX4R
Pg 71
TC127
Mini tube cutter
Visit us Online at www.cpsproducts.com
TCX4C
TB10MM
PRO-SET® TUBE BENDERS
You need tools that work as hard as you do
and nothing outperforms like the power of the
Pro-Set Tube Bender series. Put them to work
for you on your next job.
TB12MM
TB250
Universal ratchet tube bender for soft
copper, aluminum, and light wall hydraulic
tubing from 3/8” to 7/8”
TB15MM
TB250
TB16MM
TB04
TB08
TB06
TB05
TB10
ITEM
DESCRIPTION
TB04
1/4" Tube Bender
TB05
5/16" - 8 mm Tube Bender
TB06
3/8" Tube Bender
TB08
1/2" Tube Bender
TB10
3/4" Tube Bender
TB12
5/8" Tube Bender
TB14
7/8" Tube Bender
TB250
Universal Tube Bender, TC274, Reamer
TB368
Universal Tube Bender 1/4"-5/16"-3/8"
6-8-10 mm
TB6MM
6 mm Tube Bender
TB10MM
10 mm Tube Bender
TB12MM
12 mm Tube Bender
TB15MM
15 mm Tube Bender
TB16MM
16 mm Tube Bender
TB10XH
Replacement Hook with Screw
TB12XH
TB12 Replacement Hook with Screw
TBXB1
Small Bending Bar
TBX2
Large Bending Bar
TBXM10
Mandrel 3/8" / 10MM
TBXM14
Mandrel 1/2" / 14MM
TBXM16
Mandrel 5/8" / 16MM
TBXM19
Mandrel 3/4" / 19MM
TBXM22
Mandrel 7/8" / 22MM
TBXM6
Mandrel 1/4" / 6MM
TBXM8
Mandrel 5/16" / 8MM
TBXR
Ratchet Mechanism
LEVER TUBE BENDER SPECIFICATIONS
TB12MM
Sizes: 1/4”, 3/8”, 1/2”, 5/8”, 3/4”, 7/8”
(6, 8,10, 12, 16, 19, 22mm)
TB16MM
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 72
Reason
PRO-SET® Flaring & Swaging Tools
Effeciently connect gas pipes and copper tubing with premium
Pro-Set branded flaring and swaging tools.
PRO-SET® Flaring Tools, Kits, Replacement Part SPECIFICATIONS
ITEM
DESCRIPTION
FS226
Tube Cutting/Double Flaring Set 1/8" - 3/4"
FS226M
Metric Tube Cutting/Double Flaring Set 4.75, 6, 8,
10mm
FS275
45° Flaring & Swaging Kit 1/8" - 3/4"
FS275M
45° Flaring & Swaging Kit Metric
FSX501
FS275 Bar 7/16", 1/4", 1/8", 3/16", 5/16", 3/8"
FSX502
FS275 Short Bar 1/2", 5/8", 3/4" O.D
FSX503
FS275 5/16" Swaging Adapter
FSX504
FS275 3/16" Swaging Adapter
FSX505
FS275 1/2" Swaging Adapter
FSX506
FS275 5/8" Swaging Adapter
FSX507
FS275M 8, 12, 14, 16, 22 MM Swaging Adapter
FSX508
FS275 3/4" Swaging Adapter
FSX509
FS275 Yoke Assembly
FSX511
FS275M 15, 16mm Flaring Bar Metric
FSX512
FS275M 4, 18, 22mm Flaring Bar Metric
FSX513
FS275 Compressor Cone
FT195
45° Flaring Tool 3/16" to 5/8"
FT500
45° Flaring/Burning Tool Metric 3/16" TO 5/8"
FT500M
45°Flaring/Burning Tool Metric 6mm to 16mm
FT525
Adjustable Flaring Tool 3/16" to 5/8"/ 5 to 16mm
FT800FN
R-410A Imperial Concentric Flaring Tool w/Ratchet
3/16",1/4", 5/16" 3/8”, 1/2", 5/8", 3/4"
FT806A
Imperial Eccentric Flaring Tool w/Ratchet
3/16",1/4", 5/16", 3/8", 1/2", 5/8", 3/4"
FT806M
Metric Eccentric Flaring Tool w/Ratchet
6, 8, 10, 12, 15, 16, 18mm
FTX500
FT195 Yoke Assembly
FTX501
FT195 Flaring Bar 5/16", 3/8", 7/16"
FTX509
FT195 Compressor Cone
FTX510
FT195 Wing Nut
FTX513
FT500 Yoke Assembly
FTX514
FT500 Die Holder Assembly
FTX515
FT500M Die Holder Assembly
FTX516
FT525 Yoke Assembly
FTX517
FT525 Tube Holding Assembly
FTX518
FS275 Yoke Assembly
FTX800B410
FT800FN R410A Imperial Flaring Bar
FTX800BA
FT806A Imperial Flaring Bar
FTX800BM
FT806M Metric Flaring Bar
FTX800R
Ratchet for FT800FN/FT806A/FT806M
FTX800Y
Yoke Assembly FT800FN/FT806A/FT806M
FT800FN
• Engineered specifically to create stronger flare joints
for higher pressure R-410A systems.
• Unique clutch driven feed screw and eccentrically
mounted cone produces uniform, clean flare walls
without galling.
• Exclusive 3/8”sq drive incorporated directly in yoke
handle for use with ratchet (included).
• Rugged polyethylene storage case included.
FT525
Universal/Adjustable
Flaring Tool
3/16” to 5/8”
(5mm to 16mm)
FT195
45° Flaring Tool
3/16” to 5/8”
FT203
Flaring Tool
5/8”, 3/4”, 7/8”,
& 1 1/8” O.D
FEATURES OF THE FT500
• Slot in yoke is used for tube
height gauge.
• Sliding dies with lever
clamping action.
• Yoke slips over top of bar, then
locks into position with slight turn.
FS275
45° Flaring
& Swaging Kit
1/8” - 3/4”
*All flaring tools listed are recommended for softer thin-walled materials such
as copper, aluminum, and brass
PRO-SET® Tube Expander / Swaging Set
TLE6/TLE6M (metric)
• Create professional grade one seam pipe unions in the field.
• Multi-faceted interchangeable heads ensure equal linear
expansion of tubing and uniformed wall thickness.
• Extended handle length provides added leverage for
ease of operation.
• Re-round deformed tubing and fabricate couplings.
• Components are heat treated for durability.
• Ideal for copper, aluminum and soft steel tubing.
• Includes storage case for long-term protection.
• Components are heat treated for durability.
• Ideal for copper, aluminum and soft steel tubing.
• Includes storage case for long-term protection.
TLE6/TLE6M (metric)
PRO-SET® Metric Torque Wrench Set
TLTWSM
Deburring Tools /Universal Reamer Tool
TLRM
Pocket Deburring Tool
TLDB2
Pocket Deburring Tool
ITEM
DESCRIPTION
TLE6
Tube expander set with 6 heads 3/8", 1/2", 5/8",
3/4", 7/8", 1 1/8"
TLE6M
Tube expander set with case includes: 10, 12, 15, 18,
22, 28mm
TLE601
Expander tool only
TLH06
3/8" Expander Head (Standard in TLE6)
TLH08
1/2" Expander Head (Standard in TLE6)
TLH10
5/8" Expander Head (Standard in TLE6)
TLH12
3/4" Expander Head (Standard in TLE6)
TLH14
7/8" Expander Head (Standard in TLE6)
TLH16
1" Expander Head
TLH18
1 1/8" Expander Head (Standard in TLE6)
TLH22
1 3/8" Expander Head
TLH26
1 5/8" Expander Head
TLHM10
10mm Expander Head (Standard in TLE6M)
TLHM12
12mm Expander Head (Standard in TLE6M)
TLHM15
15mm Expander Head (Standard in TLE6M)
TLHM16
16mm Expander Head
TLHM18
18mm Expander Head (Standard in TLE6M)
TLHM20
20mm Expander Head
TLHM22
22mm Expander Head (Standard in TLE6M)
TLHM28
28mm Expander Head (Standard in TLE6M)
TLHM35
35mm Expander Head
TLHM42
42mm Expander Head
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Accessory Head SPECIFICATIONS
Professional interchangeable jaw torque wrench set ensures
compliance with OEM torque settings for high pressure systems.
• Interchangeable 17, 22, 24, 26, 27 & 29mm jaw sizes.
• Corresponding settings clearly marked on torque wrench in
Newton Meters (10-75Nm).
• Provides consistently accurate readings and rugged,
trouble free performance.
• Includes storage case for
long-term protection.
Pg 74
Tubing Tools
BLACKMAX® PREMIUM TUBING Tools
Introducing BlackMAX hand tools- a new line of premium
grade, good-looking and hard-working hand tools from CPS.
For cutting, deburing, flaring, expanding and bending soft
copper and aluminum tubing. BlackMAX hand tools also
include a line of 2 and 3 jaw gear pullers. Premium form,
function and ergonomics at affordable prices. Try them
today and see the difference!
BTC300
BTC200
Patented “Set and Cut”
technology provides easy
tube cutting with little or no
readjustment required.
Quick release pin for fast
replacement of cutting wheels
BTC200R
SPECIFICATIONS
TUBE CUTTERS
ITEM
SPECIFICATIONS
DESCRIPTION
BTC200
1/8”-7/8”OD
TUBE CUTTER
BTC200R
1/8”-7/8”OD
RATCHET TUBE CUTTER
BTC300
3/16” - 1-1/4” OD
TUBE CUTTER
GEAR PULLERS
BTLGP4
4” 3
JAW GEAR PULLER
BTLGP7
7” 3
JAW GEAR PULLER
Patented design enables fast configuration of two
or three puller arms for inward or outward gripping
positions.
BTLGP4
Pg 75
Visit us Online at www.cpsproducts.com
TUBE EXPANDER KIT
RATCHET TUBE BENDER
BTLE9
BTB300
Includes 1/4” + 5/16” Expander Heads
• Easy to Use
• Color Code System
• Solid Aluminum Mandrels
• Reverse Bend Mechanism
Patented 2 position handle
BTB12
FLARING TOOLS
SPECIFICATIONS
DESCRIPTION
BFT850FN
3/16, 1/4, 5/16, 3,8,
1/2, 5/8, 3/4” OD
LIGHT WEIGHT
CONCENTRIC FLARING TOOL
BTLE9
1/4, 5/16, 3/8, 1/2, 5/8,
3/4, 7/8, 1, 1-1/8” OD
BTB300
1/4, 5/16, 3/8, 1/2, 5/8,
3/4, 7/8” OD
TUBE EXPANDER
PREMIUM TUBE
EXPANDING KIT
TUBE BENDER
RATCHET TUBE BENDER W/
REVERSE OPTION
LEVER TUBE BENDERS
Lightweight Design
R410A Capable
BFT850FN
BTB06
3/8 OD
PREMIUM LEVER
TUBE BENDER
BTB08
1/2 OD
PREMIUM LEVER
TUBE BENDER
BTB10
5/8 OD
PREMIUM LEVER
TUBE BENDER
BTB12
3/4 OD
PREMIUM LEVER
TUBE BENDER
BTB14
7/8 OD
PREMIUM LEVER
TUBE BENDER
BLACKMAX® TUBING TOOL SPECIFICATIONS
ITEM
DEBUR TOOL
BTLDB3
PREMIUM BUILT DEBURING TOOL
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 76
SPECIALTY HAND TOOLS
COMPLETE TOOL KITS FOR FAST, CONVENIENT REPAIRS
Pg 77
Visit us Online at www.cpsproducts.com
TLB410A TOOL KIT
R-410A Ductless mini-split
tool kit with Triple-Seal 2 valve
manifold (MEHP5E )
and metric torque
wrench set
Specialty Hand Tools
CPS® EXTRA DURABLE TOOL BAGS
Organize your tools with care with this extra strong, premium
built series of tool bags from CPS.
TLBAG1
TLBAG2
TLBAG3
TLB410AC2 TOOL KIT
ITEM
DESCRIPTION
TLB410A
Universal R-410A Service Tool Kit 1/4” & 5/16” (1/2”-20 UNF)
Triple-Seal MEHP5E manifold, metric torque set
TLB410AC
Universal R-410A Service Tool Kit 1/4” & 5/16” (1/2”-20 UNF)
BlackMax MBH5P5Z manifold
TLB410AC2
Universal R-410A Service Tool Kit 1/4” & 5/16” (1/2”-20 UNF)
BlackMax MBH4P5EZ manifold
TLB410SAE
Universal R-410A Service Tool Kit 1/4” & 5/16” (1/2”-20 UNF)
Triple-Seal MEHP5E manifold, SAE torque set
CPS® TOOL BAGS
TLBAG1
Square Tool Organizer
TLBAG2
16” Rubber Bottom Tool Organizer
TLBAG3
Tool Belt Tool Organizer
TLB410AC TOOL KIT
TLB410SAE TOOL KIT
R-410A Ductless mini-split
tool kit with BlackMax Black &
Chrome 2 valve
manifold
(MBH5P5Z)
and metric
torque
wrench
set
R-410A Ductless mini-split tool
kit with Triple-Seal
2 valve manifold
(MEHP5E ) and SAE
torque wrench set
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
SPECIFICATIONS
R-410A Ductless mini-split
tool kit with BlackMax Black &
Chrome 2 valve manifold
(MBH4P5EZ) and
metric torque
wrench set
Pg 78
Specialty
Hand Tools
PRO-SET® 6-in-1 Auto-Loading Screwdriver
• Patented auto loading bit design
• 6 replaceable industrial grade 1/4” hex bits
• Includes standard valve core tool bit
• Magnetic head holds fastener in place
• Ergonomic high impact housing design
• Standard 1/4” hex drive
TLSD1
PRO-SET® Specialty Hex Key Wrench Sets
TLSWH
Inch Hex Key Set:
3/32”,7/64”, 1/8”,
9/64”, 5/32”, 3/16”,
7/32” and 1/4” (Nickel Plated Finish)
TLSWHM
Metric Hex Key Set:
1.5, 2, 2.5, 3, 4,
5, 6, 8mm
(Nickel Plated Finish)
PRO-SET® Swaging / Pinch-Off Tools
TLPORR
TLSWT
Torx Wrench Set:
(Nickel Plated Finish)
PRO-SET® TLPP Service Plier
TLPP
Pinch-Off tool & rerounds tubing on
1/4”, 5/16”, 3/8”, and 1/2”
Copper and tubing
Tube Piercing Pliers 1/4”
PRO-SET® TLSWL
TLPK
TLSWL
1/2”
5/8”
3/8” 5/16”
1/4”
Swage Punch Tool
Pg 79
124 Service Wrench
1/4” - 3/16” SQ x 9/16”
1/2” HEX
Visit us Online at www.cpsproducts.com
Specialty
Hand Tools
TLFC6
TLFC6 Universal 6 Sided ALL PURPOSE
Fin Straightening Tool
Repair bent condenser fins with the TLFC6 Universal
6 sided fin comb straightening tool.
TLFC2 Fin Straightening Tool
TLFC2
Fin Straightener with large durable, easy grip handle.
PRO-SET® Inspection Mirrors
TLMIR3
TLMIR4
DESCRIPTION
TLMIR2
Circular Telescoping Mirror ø 2.24"
TLMIR3
Rectangular Telescoping Mirror 3.5 x 2.12"
TLMIR4
Oval Pocket Mirror 2 x .98"
TLXMIR2
Replacement Mirror Head for TLMIR2
TLXMIR3
Replacement Mirror Head for TLMIR3
TLXMIR4
Replacement Mirror Head for TLMIR4
SPECIFICATIONS
ITEM
TLMIR2
Solenoid Magnet
Compact Magnetizer/Demagnetizer
The TLMKC18 is designed to manually open solenoid valves by
magnetically lifting the stem assembly and plunger. Simply slide
the TLMKC18 over the valve’s enclosing tube and the industrial
grade magnets incorporated inside the rugged ABS plastic housing does the rest. It is an ideal tool for trouble shooting/servicing
both direct connected or pilot operated 2-way solenoid, 3-way
reclaim or 4-way reversing valves.
Use the TLMAG1 to magnetize tools in order to keep small
screws and nuts in position, especially helpful when working
in confined spaces, or demagnetize tools when working on or
near electronic circuit boards. Simply insert a screwdriver or
nut driver into the (+) opening, slowly draw it out and it’s magnetized. Leave the magnetizer on the tool for extra strength. To
demagnetize, slowly draw the tool through the smallest area of
the (-) opening. The TLMAG1 is an essential tool for the professional and do-it-yourselfer alike.
* 0.75”/18mm opening fits all common manufactured valves
TLMKC18
• Instantly Magnetize or Demagnetize Steel Tools & Parts
• Incorporates Two C5 Industrial Strength Magnets
• Impact Resistant ABS Molded Plastic
• No Batteries or Electricity Required
• Compact Design: 2” x 2” x 1”
TLMAG1
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 80
Specialty
Hand Tools
Super-strong
tool that exceeds
ANSI specifications
providing years of service!
Adjustable Handle Wrench
TLWA06
Size: 6”
Jaw Capacity:
15/16” / 24mm
TLWA08
Size: 8”
Jaw Capacity:
1 1/8” / 29mm
TLWA10
Size: 10”
Jaw Capacity:
1 5/16” / 33mm
TLWA12
Size: 12”
Jaw Capacity:
1 1/2” / 38mm
• Patented Light Weight Composite Handle Design
• Ergonomic, Comfortable Grip Reduces Fatigue
• Wide Jaw Opening With 45% More Torque
• Precision Machined for Smooth Operation
• Durable and Environment-Resistant
• One Year Warranty
Duct Knives
Used to fabricate fiberglass duct board. Stainless steel double edge resharpenable blade facilitates easy piercing for inside cuts. The
double edge is also ideal for tapping into and trimming flex duct. Available with either ergonomic cushioned or a comfortable walnut
wooden handle.
TLDKRH
6” (152 mm.)
TLDKWH - 6” (152 mm.)
Net Weight:5 oz. (142 g.)
Rechargeable Anodized Aluminum LED Work Light
Simply the best work light you will ever own, the TLWL53A is precision machined from aircraft grade
aluminum and anodized for long life. Fifty three proprietary high output LEDs are incorporated in the
work light segment with a 1W Luxeon LED integrated in the top. A powerful 2500mAh Ni-Mh
rechargeable battery keeps the lights burning for hours; 7-8 hours for Luxeon spot, 4-5 hours for
53 white LEDs. The professional quality and intense output of the TLWL53A outperforms many
competitive units incorporating 70 or more standard LEDs. Ideal for air conditioning contractors
municipalities, law enforcement, fire fighters, automotive technicians, and wherever else a high
performance, professional, durable work light is needed.
Pg 81
• Rugged Anodized Aluminum Body
• Super Bright 1W Luxeon Spot
• 53 Proprietary High Lumen Output LEDs
• Integrated 2500mAh 3.5V Rechargeable Battery
• Strong magnetic base for attaching to metal surfaces
• Universal UL/CUL Electronic Wall and Car Chargers Included
• Superior Durability and Shock Resistance
• High Quality Reflector Lens
• Wall and Car charger Included
• One Year Warranty
BRAZING & SOLDERING
JOIN COPPER, BRASS & STEEL WITH CONFIDENCE
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 82
Brazing & Soldering
PREMIUM
OXY-ACETYLENE
BRAZING OUTFIT
Complete Soldering &
Brazing full Workstation
Tool Kit
BRHVACR1
BRHVACR1 PRO-SET® OXY-ACETYLENE BRAZING KIT:
Brazes up to 1” copper tubing and welds up to 1/8” steel. The PRO-SET BRHVACR1
OxyAcetylene Welding/Brazing Kit (UL Listed) comes with oxy regulator, acetylene
regulator, torch handle, torch tips, goggles, hoses, plastic tote and check valves.
Includes:
• Torch handle
• Oxygen regulator
• Acetylene regulator
• Brazing tips
• Check valves
• Striker
• Goggles
• 12.5’ twin hose
• Carrying tote
• Circular storage case
Pg 83
Visit us Online at www.cpsproducts.com
PREMIUM
INTERCHANGEABLE TIPS
Be Brazen, with our new Pro-Set®
Workingman’s Choice Torch...
BRHT2 PRO-SET® HAND TORCH:
Auto-Ignite Hand Torch for MAPP,
PROPANE or PROPYLENE and
3 changeable tips with
plastic case
BRHT2
BRHT1
BRHT2
BRHT5
BRHTS1A
BRHTPKIT
Flame Control
Adjustable
Adjustable
Adjustable
Adjustable
Adjustable
For use with
MAPP , Propane or
Propylene
MAPP , Propane or
Propylene
MAPP , Propane or
Propylene
MAPP , Propane or
Propylene
MAPP ®, Propane or
Propylene
Inlet Connection
CGA600
Inlet Connection
CGA600
Inlet Connection
CGA600
Inlet Connection
CGA600
Inlet Connection
CGA600
Inlet Connection
Construction
Cast Aluminum &
stainless steel
burn tube
Reinforced Plastic &
stainless steel
burn tube
Brass regulator,
composite handle & stainless steel burn tube
Brass regulator & stainless steel
burn tube
All brass
construction
Other
Flame lock Precise flame
adjustment, flame
lock button
tips & storage case with
space for
2 cylinders
New brass regulator and
5ft hose length.
Torch tube swivels 360
degrees, operates in any
position.
Pencil flame torch,
general heating and
round tip included
BRHT1
®
®
®
®
BRHT1 HAND TORCH:
BRHT5 HAND TORCH:
Auto-Ignite Hand Torch (Cast Aluminum) for disposable 1lbs bottles) For
MAPP, PROPANE
or PROPALYNE
Auto-Ignite Hand Torch Kit w/5ft.
Hose & Valve For MAPP, PROPANE
or PROPALYNE
TORCH SPECIFICATIONS
Specifications
BRHT5
Call and Speak to a Sales Rep: 305-687-4121 / 1-800-277-3808
Pg 84
