Bosch Commercial Public Address Solutions
Amplifiers, Microphones and Speakers

Bosch PA Speakers
BOSCH PA LOUDSPEAKER RANGE
Without compromising on quality, Bosch
loudspeakers provide an overall lower cost of
ownership. All of its acoustical products meet, or
exceed, international standards. They are robust,
require minimal power and are easy to install and
maintain. And while proud of its technical proficiency,
Bosch strives always to match the highest audio
quality with great looking design.
•High quality
•Excellent sound reproduction
•Easy to install and maintain
BOSCH PANEL LOUDSPEAKERS
The Bosch panel loudspeakers and matching mounting boxes are
ideal for built-in sound installations in shops, department stores,
schools, offices, hotels and restaurants. They are manufactured
and finished to the same exacting standards as all Bosch public
address systems and components, guaranteeing high quality, and
compatibility throughout the range.
Ø
Ø
OPTIONAL VOLUME CONTROL
Watt
Taps
Size
SPL
dBi
Details
Code
9W
0.75/1.5/6/6W
284x165x65mm
88dB
96dB
Without Volume
LBC3011/41
Ø
~
With Volume
LBC3011/51
BOSCH PA CEILING SPEAKERS BCS-CS RANGE
The BCS-CS Series of Ceiling Loudspeakers
are part of the latest ‘EasyFit’ range. BCS-CS
Loudspeakers are lightweight, quick and easy to
install, and are finished in unobtrusive white with
an attractive metal grille. Their wide frequency
range and dispersion ensure good quality music
reproduction and excellent speech intelligibility.
•Wide bandwidth for music reproduction
•Wide dispersion for speech intelligibility
•Simple output-level selection
•Easily flush-mounted in ceilings or bulkheads
•Dependable rota-clamp fixing system
•Blends in with virtually all interiors
Details
Watt
Taps
Size
SPL
dBi
Code
4” Easy-Fit
8W max
0.33, 0.5, 1, 2.5, 5W
110x170mmØ
89dB
94dB
BCS-CS4BW
BOSCH-2
5” Easy-Fit
8W max
0.33, 0.5, 1, 2.5, 5W
90x200mmØ
90dB
97dB max
BCS-CS5BW
6.5” Easy-Fit
15W max
1.25, 2.5, 10W
115x220mmØ
91dB
101dB max
BCS-CS6E
8” Easy-Fit
22W max
1.25, 2.5, 5, 10, 15W
103x273mmØ
93dB
105dB max
BCS-CS8BW
March 2013
8” Easy-Fit
45W max
3.75, 7.5, 15, 30W
115x273mmØ
93dB
108dB max
BCS-CS830E
Prices Ex. GST
BOSCH PA CEILING 6” LBC
BOSCH PA CEILING 6” LBC SAFETY
DUAL CONE METAL GRILLE
Voice alarm loudspeakers are specifically designed for use in buildings
where performance of systems for verbal evacuation announcements
is governed by regulations. The LBC 3086/41 is designed for use in
voice alarm systems.
DUAL CONE METAL GRILLE FIRE SAFETY RATED
Voice alarm loudspeakers are specifically designed for use in buildings
where performance of systems for verbal evacuation announcements
is governed by regulations. Designed for use in voice alarm systems.
•Suitable for speech and music reproduction
•Flush-mounting in ceiling cavity
•Easy to install
•Simple power setting
•Optional certified fire dome
Details
Watt
Taps
Size
SPL
dBi
Code
Safety ratings
EN 60065
BS 5839‑8
EN 60849
EN 60529‑IP32
*EN 54‑24
(*With fire dome)
6”
6Wrms 9Wmax
0.75/1.5/3/6W
90x216mmØ
90dB
98dB
LBC3090/31
Details
Watt
Taps
Size
SPL
dBi
Code
FIREDOME
Steel. Red.
Size
Code
•Suitable for speech and music reproduction
•Flush-mounting in ceiling cavity
•Easy to install
•Simple power setting
•Optional certified fire dome
87x147mmØ
LBC3080/01
6” Dual Cone
9W
0.75/1.5/3/6W
90x216mmØ
90dB
98dB
LBC3086/41
90
3.54
FIREDOME
Steel. Red.
Size
Code
100x157mmØ
LBC3081/02
BOSCH PA CEILING 6” LBC POLY
BOSCH PA CEILING 8”
POLY COVER FIRE SAFE
Flush-mounting ceiling loudspeaker for applications where extra power
is required, such as rooms with high ceilings. It delivers a high sound
pressure level and has a wide frequency range to ensure excellent
speech intelligibility and good quality music reproduction. It is used
in applications like shops, department stores, schools, offices, sports
halls, hotels and restaurants.
The LBC 3090/01 is an economic flush-mounting ceiling loudspeaker
for general purpose applications. It is a full range loudspeaker for
speech and music reproduction in shops, department stores, schools,
offices, sports halls, hotels and restaurants.
•Suitable for speech and music
•Increased sensitivity
•Flush-mounting in ceiling cavity
•Easy to install
•Protective dust cover
Safety
EN 60065
Details
Watt
Taps
Size
SPL
dBi
Code
6” polly Grill
6Wrms 9Wpeak
1.5/3/6W
88x210mmØ
91dB
103dB
LBC3090/01
SURFACE MOUNT
Adaptor. Off-white.
Size 93x210mmØ
Code LBC3091/01
•Excellent speech and music reproduction
•High sound pressure level
•Ideal for high-ceiling applications
•Flush mounted in ceilings
•Clamp mounting
Details
Watt
Taps
Size
SPL
dBi
Code
8” Dual Cone
36W
6/12/24W
89x265mmØ
92dB
106dB
LBC3099/41
FIREDOME
Steel. Red.
Size 100x182mmØ
Code LBC3082/00
0°
30°
0
0°
30°
-20
60°
60°
-40
90°
FIREDOME
Steel. Red.
120°
120°
-20
150°
180°
250 Hz
500 Hz
1000 Hz
0
150°
180°
2000 Hz
4000 Hz
8000 Hz
0
Size 87x147mmØ
Code LBC3080/01
Prices Ex. GST
90°
-40
24W
12W
6W
March 2013
8
BOSCH-3
BOSCH PA HORN SPEAKER 6 ½”
BOSCH PA HORN 7½”
Horn Loudspeaker is specifically designed for excellent sound
reproduction in marine applications and other industrial environments.
It is rugged, water and dust protected, and resistant to the corrosive
effects of seawater and most industrial atmospheres. Suitable for
both stationary and mobile systems, its strength and good acoustic
performance also makes it ideal for general commercial applications.
The LBC 3470/00 is a 15 W high‑efficiency
circular horn loudspeaker, provide excellent
speech reproduction and sound distribution
for a wide scope of indoor and outdoor
applications. It is ideal for sports grounds,
parks, exhibition areas, factories and
swimming pools. The horn is made from
ABS and finished in light gray.
•Suitable for marine and industrial applications
•Glass reinforced polyester with strong, fire retardant qualities
•Corrosion and chemical resistant
•Reduced maintenance costs
•IP 67
Details
Watt
Taps
Size
SPL
dBi
Code
•High‑efficiency driver
•Excellent speech reproduction
•Versatile mounting bracket
•Water-and dust protected to IP 65
•Complies with international
installation and safety regulations
6.5” White IP67
15W (22Wmax)
0.8, 2, 4, 5, 7.5, 15w
245x163mmØ
102dB
114dB
LBC3428/00
Details
Watt
Taps
Size
SPL
dBi
Code
ABS Horn
22.5W
3.75/7.5/15W
225x190mmØ
103dB
115dB
LBC3470/00
225
8.9
190
7.5
BOSCH PA HORN SPEAKER 8” & 9½”
POPULAR RECTANGULAR SHAPE
Bosch high-efficiency horn
loudspeakers provide excellent
speech reproduction and sound
distribution for a wide scope of
outdoor applications. They are
ideal for sports grounds, parks,
exhibitions, factories, pools, etc.
•High efficiency driver
•Up to 45 W (max. power)
•Wide opening angle
•Excellent speech reproduction
•Simple power setting
High-efficiency horn
loudspeakers provide
excellent speech
reproduction and sound
distribution for a wide scope
of paging and emergency
evacuation applications.
Details
Watt
Taps
Size
SPL
dBi
Code
Details
Size
Watt
Taps
SPL
dBi
Code
8” White IP66
230x200mmØ
10W
1.25, 2.5, 5, 10W
108dB
119dB max
BCS-HS10E
9.5” White IP66
292x246mmØ
20W
5, 7.5, 10, 15, 20W
110dB
124dB max
BCS-HS20E
BOSCH PA HORN SPEAKER HIFI
BOSCH PA HORN SPEAKER 14”
2-WAY MUSIC QUALITY
The Bosch LH1-UC30E Music Horn Loudspeaker features a two‑way
system, resulting in an extended frequency range and high sensitivity
which makes it ideal for high quality speech and music reproduction.
LARGE AREA BROADCAST
Bosch high-efficiency horn loudspeakers
provide excellent speech reproduction
and sound distribution for a wide scope
of outdoor applications.
They are ideal for
sports grounds, parks,
exhibitions, factories,
swimming pools, etc.
•Excellent speech and
music reproduction
•Two‑way system
•Wide opening angle
•Attractive ABS housing
•Provisions for internal
mounting of the optional
line / loudspeaker
supervision board
BOSCH-4
71.5
2.81
83
3.27
•10W & 20W Models available
•IP66 Rated outdoor use
•Emergency Evacuation System ready
•Wide dispersion for speech intelligibility
•Screwdriver adjustable power tapping
•Loop in / Loop out wiring
Rectangular Horn
15W
2.5/5/10W
267x171x276mm
108dB
121dB
LBC3491/12
Two Way HiFi
45W
3.75/7.5/15/30W
370x255x291mm
100dB
115dB
LH1-UC30E
155
6.10
5.3 x 4
0.21 x 0.16
BOSCH PA HORN SPEAKER SQUARE
Details
Watt
Taps
Size
SPL
dBi
Code
90
3.54
110
4.33
•High efficiency driver
•Up to 45 W (max. power)
•Wide opening angle
•Excellent speech reproduction
•Simple power setting
291
11.46
63
2.48
369.67
14.55
254.46
10.2
mm
in
10
0.39
120
4.72
Details
Watt
Taps
Size
SPL
dBi
Code
14” ABS Horn
30W
5/10/20W
332x354mmØ
110dB
125dB
LBC3493/12
March 2013
Prices Ex. GST
BOSCH 20” HORN LOUDSPEAKER 50W
Highly accurate speech reproduction and powerful sound distribution
is ideal for outdoor use such as sporting events, exhibits, swimming
pools, etc. The durable aluminum construction is protected against
impact by a PVC rim around the edges. Designed for use in voice
alarm systems and is compliant with emergency standards.
0
1
16 Ω
1/2
•High efficiency driver
•Excellent speech reproduction
•Provision for inside mounting of the optional
line/loudspeaker supervision board
•Water-and dust protected to IP65
•BS 5839‑8 and EN 60849 compliant
1/4
20k
1k
20” Horn 50W
Details Aluminium
52.5W
Watt
9/18/36W
Taps
500x490mmØ
Size
111dB
SPL
117dB
dBi
Code LBC3483/00
37
1.45
mm
in
BOSCH 20” HORN LOUDSPEAKER 75W
Bosch high-efficiency horn loudspeakers provide excellent speech
reproduction and sound distribution for a wide scope of outdoor
applications. They are ideal for sports grounds, parks, exhibitions,
factories and swimming pools. This 50 W horn loudspeaker,
measuring 490 mm (19.6 in) in diameter is made from aluminum.
The edges of the horns are covered with a PVC profile for
protection against impact damage. They are light grey
(RAL 7035), and are water and dust protected.
0
1
1/2
1/4
•High efficiency driver
•Excellent speech reproduction
•Provision for inside mounting of the optional
line/loudspeaker supervision board
•Water and dust protected to IP 65
•BS 5839-8 and EN 60849 compliant
Details
Watt
Taps
Size
SPL
dBi
Code
16 Ω
20k
1k
20” Horn 75W Aluminium
75W
12.5/25/50W
500x490mmØ
110dB
127dB
LBC3484/00
mm
in
37
1.45
BOSCH HORN DRIVER - LBN SERIES
BOSCH DRIVER HORN FLARES - LBN SERIES
REQUIRES HORN 1 3/8”
The Bosch professional horn loudspeaker system comprises a range
of three high-efficiency driver units that can be installed into one of the
compatible circular and rectangular horns (supplied separately without
drivers). A standard 1 3/8” screw thread is used for mounting the
drivers into horns. All models are treated against corrosion.
Flame-retardant, high-impact plastic for high strength and low weight,
and are finished in light grey. A steel mounted bracket is also supplied.
Details 10” Round
255mmØ
Size
Code LBC3403/16
15” Round
380mmØ
LBC3404/16
20” Round
510mmØ
LBC3405/16
9x15” x Square
380x235mm
LBC3406/16
•High efficiency
•30W or 50W versions
•1 3/8” screw thread
•Simple power setting
•Complies with international
installation and safety regulations
162 (6.38)
Details
Watt
Taps
Size
SPL
dBi
Code
Driver Only
30W
10/15/20/30W
134x104mmØ
114dB
129dB
LBN9001/00
Driver Only
50W
30/35/40/50W
162x118mmØ
114dB
131dB
LBN9003/00
Prices Ex. GST
dia. 118 (4.65)
1 3/8”-18 UNEF-2A
March 2013
BOSCH-5
BOSCH CABINET SPEAKER
General-purpose, cost effective loudspeaker for indoor use. Two brackets, fixed
to the rear panel, are provided for quick and easy mounting on a wall or ceiling.
The cabinet is available in the colours black or white. Sold as singles.
•Good speech intelligibility and background music reproduction
•Complies with international installation and safety regulations
•Mounting brackets for wall or ceiling mounting
•Finished in white or black
•MDF construction
Watt
Taps
Size
SPL
dBi
Details
Colour
Code
9W
1.5/3/6W
264x151x139mm
91dB
99dB
No Volume
No Volume
White
Black
LB1-UW06-L
LB1-UW06-D
With Volume
White
LB1-UW06V-L
Ø
~
4
With Volume
Black
LB1-UW06V-D
BOSCH CABINET SPEAKER
CORNER MOUNT
The LB1-CW06-x is a 6 W, general-purpose cost-effective
loudspeaker for indoor use. Two brackets with keyholes,
fixed on one side provide quick and easy mounting in
corners between two walls, or between a wall and
ceiling. The cabinet is available in black or white.
•Good speech intelligibility and
background music reproduction
•Special shape for mounting in corners
•Available in black or white
•MDF construction
•Compliancy with international
installation and safety regulation
Details
Watt
Size
SPL
dBi
Taps
Colour
Code
Ø
~
Wedge
9W
240x151x138mm
91dB
99dB
1.5/3/6W
Light
Dark
LB1-CW06-L LB1-CW06-D
BOSCH PA HIFI SPEAKER
Premium sound cabinet loudspeakers are intended for clear reproduction of speech,
foreground and background music to be used in general indoor and outdoor applications.
Range consists of a 15 W and 30 W model, available in a light or dark colour.
The loudspeakers have selectable 8 ohm, 70 V and 100 V inputs. Singles.
Details
Watt
Taps
Size
SPL
dBi
Colour
Code
4” Woofer ½” Tweeter
22.5W
1.9, 3.75, 7.5, 15W
205x136x117mm
86dB
98dB max
White
Charcoal
LB2-UC15-L LB2-UC15-D
5” Woofer ½” Tweeter
45W
3.75, 7.5, 15, 30W
250x160x140mm
90dB
105dB max
White
Charcoal
LB2-UC30-L LB2-UC30-D
165.9
F
8 ohms
E
1.9W
D
3.75W 1.9W
C
7.5W
B
15W
7.5W
100V
70.7V
225.4
208
2.2uf
3.75W
15W
A
0
F'
C
E'
D'
1
C'
B'
A'
117.8
BOSCH-6
March 2013
Prices Ex. GST
BOSCH XLA LINE-ARRAY LOUDSPEAKERS
LESS SPEAKERS FOR BETTER SOUND
Conventional Column loudspeaker
The XLA 3200 range incorporates a unique technology angle.
An ingenious new approach of positioning the loudspeaker
drivers in the array, coupled with filtering techniques so each
-6dB 500Hz
-6dB 1kHz
-6dB 4kHz
0ºaxis
driver emits a dedicated frequency range, results in unique
Listening Area 500Hz
and advanced acoustical characteristics.
Listening Area 1kHz
Listening Area 4kHz
•Ideal combination of advanced acoustics and easy application
•Uniform distribution of natural sound throughout the room
XLA 3200 Line Array Loudspeaker
•Extremely slim for unobtrusive, elegant, easy installation
•Excellent intelligibility of speech and music
•Suppressed side lobes reduces echos
-6dB 500Hz -6dB 1kHz -6dB 4kHz
0ºaxis
•Suitable for both indoor and outdoor use
Listening Area 500Hz
•Voice evacuation compliant as standard
Listening Area 1kHz
Listening Area 4kHz
•EN 54‑24 and EN 60849 compliant
1200mm ARRAY FOCUSED
This loudspeaker, with its excellent directivity and high
power output, can handle large (reverberant) indoor
environments or outdoor use. Its full frequency range
makes it ideal for music as well as speech reproduction.
Conventional column loudspeakers produce a main
lobe of sound, which is directed at listeners, and a
number of unwanted side lobes. The LBC 3210/00
has highly suppressed side lobes in the vertical plane,
resulting in a much clearer, less ‘coloured’ sound, even
when close to the loudspeakers. This gives the line
array loudspeaker superb intelligibility of both speech
and music. 120cm high, 16 cm wide. 190Hz - 18KHz.
Includes wall bracket. Optional floor stand.
Angle 1 kHz / 4 kHz (-6 dB)
Horizontal 170° / 90°
Vertical 55° / 18°
Details
Watt
Taps
Size
SPL
dBi
Code
Double Array
90W
15/30/60W
1200x160x90mm
97dB
115dB
LBC3210/00
1200mm ARRAY
Offers extremely accurate directivity of sound. Ideal
for medium and large (reverberant) environments as
well as more acoustically demanding situations like
buildings with pillars or exhibition halls full of stands.
Gives excellent quality reproduction of speech and
background music. Excellent directivity and side lobe
suppression. 120 cm high, 8 cm wide. Includes wall
bracket. Optional floor stand.
Angle 1 kHz / 4 kHz (-6 dB)
Horizontal 210° / 132°
Vertical 50° / 22°
Details
Watt
Taps
Size
SPL
dBi
Code
Full Array
90W
15/30/60W
1200x80x90mm
92dB
110dB
LBC3201/00
600mm ARRAY
A very compact loudspeaker that provides
superb, clear sound in small- and medium-sized
indoor venues like showrooms, canteens and
meeting rooms. A really good performer with a
superb size/performance ratio. Surprisingly clear
and natural speech and music. 190Hz - 18KHz
Includes wall bracket. Optional floor stand.
Angle 1 kHz / 4 kHz (-6 dB)
Horizontal 220° / 130°
Vertical 70° / 18°
FLOOR STAND
This universal floorstand provides an effective mounting
solution. They are manufactured and finished to the same
high standards as all Bosch products, assuring excellent
quality and guaranteed compatibility throughout the range.
Details
Watt
Taps
Size
SPL
dBi
Code
Details Optional Stand
1.4-2.2M
Size
Code LBC1259/00
Compact
45W
7.5/15/30W
600x80mm
91dB
106dB
LBC3200/00
The LBC 1259/00 floorstand is hand-adjustable using a
spring-loaded locking screw for heights between 1.4M-2.2M
An extra safety bolt on the support can be tightened to
ensure the stand remains extended. This lightweight stand
has a double-braced folding base for extra strength, and a
wide leg span to ensure stability.
STAND CARRY BAG
For storage and ease of transport with two inside compartments with
separate zippers for holding two universal floorstands (LBC 1259/00).
Made from sturdy black weather-proof nylon.
Details Suit LBC1259/00
Code LM1-CB
Prices Ex. GST
March 2013
BOSCH-7
BOSCH PENDENT SPEAKER
Sound spheres are pendent sound projectors designed to be suspended from the
ceiling by their connecting cables. Their excellent sound spread makes them
ideal for use in buildings with high ceilings, such as markets and superstores.
The LS1-UC20E-1 is a powerful 20 W pendent sphere loudspeaker, intended
for high quality speech and music reproduction. The state‑of‑the‑art design
is matched to both modern and traditional style environments. The
loudspeaker is suitable for use in voice evacuation systems.
•Superb speech and music reproduction
•5 m connection cable
•Provision for optional safety cord
•Water and dust protected to IP 65
•BS 5839‑8 and EN 60849 compliant
Details
Watt
Taps
Size
SPL
dBi
Code
0
20W
10W
8
5W
2.5W
Omnidirectional
30W
2.5/5/10/20W
254x185mmØ
86dB
99dB
LS1-UC20E-1
(7.28)
Ø 185
(2.20)
56
(10.00)
254
BOSCH SOUND PROJECTOR
The LP1-BC10E-1 is a powerful 10 W bidirectional sound projector intended for high quality speech and music reproduction
in indoor and outdoor applications. The two Loudspeakers facing in opposite directions are ideally suited to applications such
as tunnels, long corridors and shopping arcades. The state‑of‑the‑art design is matched to both modern and traditional style
environments. The sound projector is suitable for use in voice alarm systems.
•Superb speech and music reproduction
•Integrated connection cable
•Ceiling or wall mounting
•Water and dust protected to IP 65
•BS 5839‑8 and EN 60849 compliant
(7.28)
Ø185
(11.81)
300
0
Bidirectional
15W
1.25/2.5/5/10W
300x185mmØ
80dB
90dB
LP1-BC10E-1
10W
(5.67)
Ø144
(5.67)
Ø144
(1.61)
41
(4.65)
118
5W
(1.34)
34
2.5W
(11.93)
303
(7.28)
Ø185
Details
Watt
Taps
Size
SPL
dBi
Code
1.25W
(11.81)
300
BOSCH SOUND PROJECTOR
(4.29)
109
6 (0.24)
5W
2.5W
120°
(5.43)1.25W
138
27 (1.06)
(1.57) 40
(5.67)
Ø144
30W
2.5/10/20W
87dB
100dB
LP1-UC20E-1
(5.67)
Ø144
41 (1.61)
(1.34) 34
(3.03) 77
(11.81)
300
BOSCH-8
0
10W
(11.93)
303
Unidirectional
15W
1.25/2.5/5/10W
86dB
96dB
LP1-UC10E-1
23 (0.90)
14 (0.55)
(7.28)
Ø185
Details
Watt
Size
SPL
dBi
Code
(0.43) 11
(7.28)
Ø185
The LP1-UC10E-1 is a powerful, 10 W sound projector intended for high quality speech and music reproduction
in indoor and outdoor applications. The state‑of‑the‑art design is matched to both modern and traditional style
environments. The sound projector is suitable for use in voice alarm systems.
•Superb speech and music reproduction
•Integrated connection cable
•Ceiling or wall mounting
•Water and dust protected to IP 65
(13.43)
341
•BS 5839‑8 and EN 60849 compliant
March 2013
(7.28)
Ø185
Prices Ex. GST
BOSCH PENDENT SPEAKER
The LBC 3095/15 is a pendant sphere designed to be
suspended from the ceiling via its connecting cable. The
pleasing shape and neutral colour make the pendant sphere
models interesting architectural features in their own right.
•Suitable for speech and music reproduction
•Simple power setting
•5 m fixed connection cable
•Splash-waterproof type
•Robust self-extinguishing ABS enclosure to UL 94 V0
Details
Watt
Taps
Size
SPL
dBi
Code
Omni-Dirrectional
15W
2.5/5/10W
157x185mmØ
89dB
99dB
LBC3095/15
BOSCH SOUND PROJECTOR
UNI-DIRECTIONAL
The LBC 3432/02 is a powerful 20 W sound projector intended for speech and music reproduction in indoor and outdoor applications.
The sturdy, aluminum enclosure is finished in the colour off-white. It has provisions for cable loop through connection and mounting of
a line or loudspeaker supervision board. The sound projector is suitable for use in voice alarm systems.
•Excellent speech and music reproduction
•Provision for supervision board mounting
•(Suspended) ceiling and/or wall mounting
•Water and dust protected to IP 66
•EN 54‑24 certified
0
20W
146
5.75
Unidirectional
30W
200x146mmØ
92dB
105dB
LBC3432/02
10W
8
132
5.20
5W
7
0.28
2.5W
30.5 30.5
1.20 1.20
mm
in
154
6.06
0˚
30˚
10dB
0˚
0
30˚
-10
60˚
60˚
-20
90
90˚
90˚
-20
SPL(dB)
Details
Watt
Size
SPL
dBi
Code
200
7.87
120˚
150˚
31.5 63
125
250
500 1k
2k
Frequency (Hz)
8k
4k
120˚
-10
16k
180˚
0
150˚
180˚
2000 Hz
4000 Hz
8000 Hz
250 Hz
500 Hz
1000 Hz
BOSCH SOUND PROJECTOR
BI-DIRECTIONAL
The LBC 3430/02 is a 12 W bidirectional sound projector intended for
speech and music reproduction in indoor and outdoor applications.
The two loudspeakers facing in opposite directions are ideally suited
to applications such as subway tunnels, long corridors and shopping
arcades. The sturdy, aluminum enclosure is finished in the colour offwhite. The sound projector is suitable for use in voice alarm systems.
•Excellent speech and music reproduction
•Ceiling and/or wall mounting
•Robust aluminum extrusion enclosure
•Water and dust protected to IP 55
•BS 5839‑8 and EN 60849 compliant
Bidirectional
18W
1.5/3/6/12W
186x146mmØ
91dB
102dB
LBC3430/02
Prices Ex. GST
0˚
0
30˚
-10
60˚
60˚
-20
90˚
90˚
-20
SPL(dB)
120˚
150˚
31.5 63
125
250
500 1k
2k
Frequency (Hz)
146
5.75
4k
8k
186
7.32
16k
120˚
-10
180˚
0
150˚
180˚
2000 Hz
4000 Hz
8000 Hz
250 Hz
500 Hz
1000 Hz
5.5
0.22
0
12W
157
6.18
166
6.54
Details
Watt
Taps
Size
SPL
dBi
Code
0˚
30˚
10dB
90
6W
3W
1.5W
175
6.89
March 2013
mm
In
100
3.94
mm
In
BOSCH-9

Electro-Voice
EVID CEILING SPEAKERS
EVID C12.2
The Electro-Voice EVID Ceiling loudspeaker system is a complete
package consisting of a bezel assembly, grille, rear enclosure, coax
mounted two-way loudspeaker and internal line-matching transformer.
Features a waveguide coupled titanium coated dome tweeter, 2nd
order crossover network at 3.3kHz, protection circuit to protect the
network, woofer, and tweeter drivers from excessive power levels.
Transformer with 70V or 100V lines, or 8Ω bypass. Selection is
via a convenient switch on the front baffle. The perforated grille is
finished in semi-gloss white powder coated enamel. The baffle and
bezel are constructed from UL94V-0 rated ABS. The EVID line of
ceiling speakers has been designed to provide wide dispersion, high
efficiency, high-maximum
output, ease of installation,
and wide-range reproduction
of music or voice.
•Full-range power, ample HiFi sound for high ceilings in large spaces
•High 100 dB sensitivity and high 100Wrms power-handling 12”
•Front-panel mode/wattage selector. White gloss perforated grille
•Safe, easy installation with included tile bridge and mounting ring
•Integrated transformer with automatic saturation compensation for
distortion free 70 V, 100 V, or 8 Ω use
•Heavy-gauge steel enclosure
•Pendant Mount Rigging Points for use
in Open Ceiling Installations
•Tile Bridge and Mounting Ring for
Easy Installation into Tile Ceilings
Watt
Taps
Size
SPL
dBi
Freq.
Code
100W(400Wmax)
8Ω/4/8/16/32/64W
333x414mmØ
100dB
126dB
65Hz-20KHz
C12.2
EVID C4.2
EVID C8.2
4” TWO-WAY HI-FI 8” BEZEL PAIR
8” TWO-WAY HI-FI PAIR
Perfect for conventional rooms. It has excellent bandwidth in
an esthetically very unobtrusive installation profile. Its compact
design fits in tight areas. Its 4-inch woofer and waveguide coupled,
titanium-coated dome tweeter give smooth, wide frequency
response. The enclosure is ported and tuned to provide surprising
bass response in such a compact package. Features an easy
3-point mounting system for quick installations.
100mm Polypropylene Woofer
20mm Titanium Mylar Tweeter
70V: 1.88/3.75/7.5/15/30W
100V: 3.75/7.5/15/30W
Bypass: 8Ω (Front switch)
65Hz-20KHz -10dB 130°
UL1480, UL2043, UL94V-O
Tuned enclosure 8-inch woofer to provide amazing bass response.
The 1-inch waveguide-coupled tweeter give smooth controlled
coverage out to 20 kHz. Perfect for installations where a flush-mount
design is desired but demand for high-quality audio exists. Features
a 4-point mounting system to make installations fast and easy.
Available in a low-profile version, ideal for tight ceiling spaces.
200mm Polypropylene Woofer
25mm Titanium Mylar Tweeter
70V: 1.88/3.75/7.5/15/30W
100V: 3.75/7.5/15/30W
Bypass: 8Ω (Front switch)
50Hz-20KHz -10dB 110°
UL1480, UL2043, UL94V-O
Watt
Taps
Size
SPL
dBi
Freq.
Code
50W(200Wmax)
8Ω/1.88/3.75/7.5/15/30W
176x181mmØ
85dB
109dB
65Hz-20KHz
C4.2
Ø7.1"
[181mm]
Ø8.3"
[210mm]
7.9"
[201mm]
6.9"
[176mm]
8.3"
[212mm]
Watt
Taps
SPL
dBi
Details
Freq.
Size
Code
75W(300Wmax)
8Ω/1.88/3.75/7.5/15/30W
91dB
116dB
Extended LF Low Profile
50Hz-20KHz 55Hz-20KHz
255x270mmØ 178x270mmØ
C8.2
C8.2LP
Sold in pairs
EVID C10.1 SUB-WOOFER
EVID C8.2 HIGH CEILING
45Hz to 180Hz CEILING MOUNT
The C10.1 packs a 10-inch subwoofer in a tuned high performance
enclosure to give amazing low frequency performance down to 45Hz!
It is one of the few quick-mount ceiling TRUE subwoofers available.
Flexible installation and powerful low-end performance make it the
ideal mate to any EVID ceiling model.
•10” High-Excursion sub
•Low Pass Network with
Overload Protection
•Integrated low loss
matching transformer
allows for either
70v/100v or 8-ohm
•Tile bridge & mounting
ring for easy installation
8” TWO-WAY FOR HIGH CEILINGS
The EVID C8.2HC is ideal for high ceilings and reverberant
“problem”rooms. Its exclusive ported, waveguide-coupled, 8” driver
provides excellent intelligibility and definition. The 8.2HC’s patentpending design provides great coverage control throughout the voice
range and above. No other ceiling speaker system provides the
combination of excellent pattern control, wide bandwidth, high power
handling, and compact design like the C8.2HC.
Watt
Taps
Size
SPL
dBi
Freq.
Code
Watt
Taps
Size
SPL
dBi
Freq.
Code
150W(600Wmax)
8Ω/7.5/15/30/60W
303x320mmØ
94dB
120dB
45Hz-180Hz
C10.1
Frequency Response:
200mm Polypropylene Woofer
25mm Titanium Mylar Tweeter
70V: 7.5/15/30/60W
100V: 7.5/15/30/60W
Bypass: 8Ω (Front switch)
50Hz-20KHz -10dB 70°
UL1480, UL2043, UL94V-O
75W(300Wmax)
8Ω/7.5/15/30/60W
303x320mmØ
93dB
118dB
50Hz-20KHz
C8.2HC
Sold in singles
BOSCH-10
Sold in pairs
March 2013
Prices Ex. GST

Electro-Voice
EVID SURFACE MOUNT SPEAKERS
EVID is not just another speaker. From the unique aesthetic design to the innovative acoustic integrity, EVID delivers value, performance and
ease-of-use to the contractor and end listener alike. EVID is something attractive and superior sounding in a world of plain black boxes.
EV have achieved a comprehensive background/foreground speaker line with the characteristics installers need and the features users want.
•1” titanium diaphragm HF driver with neodymium magnetic structure
•Coherent Coverage Waveguide
•Full-bandwidth overload protection (LF and HF)
•Elliptical weather-resistant ABS enclosure
•Oval shaped. Metal grilled. Modern styling.
•Paintable black or white finish
•Strong-Arm Mount™ for easy, flexible aiming
•“T” version for 70 or 100 V distributed systems
•Screw terminal inputs. Daisy-chain option
•Premium build quality and excellence in sound
EVID 3.2
Woofer
Power
Size
Freq.
SPL
dBi
Taps
Colour
Code
3½”
75Wrms (300Wmax)
135x130x165mm (1.5Kg)
85-20KHz
87dB
104dB
8 Ohm
8Ω/70V/100V
Black
White
Black
White
EVID3.2
EVID3.2W EVID3.2T EVID3.2TW
Includes wall stand. Sold in pairs.
Coverage -6dB Horz. 140° Vert. 100°
Screw terminal back panel.
0.75” Titanium tweeter
Taps* 70V:5W, 100V:10W
EVID 4.2
Includes wall stand. Sold in pairs.
Coverage -6dB Horz. 120° Vert. 80°
Screw terminal back panel.
1” Titanium tweeter Coax mounted
8 Ohm input with optional: Taps* 70V:7W, 100V:15W
Woofer 4”
310x175x216mm (4Kg)
Size
65-20KHz
Freq.
Power 100Wrms(400Wmax)
89dB
SPL
115dB
dBi
8 Ohm
8Ω/70V/100V
Taps
White
Black
White
Colour Black
EVID4.2
EVID4.2W EVID4.2T EVID4.2TW
Code
EVID 6.2
Includes wall stand. Sold in pairs.
Coverage -6dB Horz. 100° Vert. 80°
Screw terminal back panel.
1” Titanium tweeter Coaxial Mounted
8 Ohm input with optional: Taps* 70V, 100V:15/30/60W
Woofer
Size
Freq.
Power
SPL
dBi
Taps
Colour
Code
6”
420x230x300mm (5.3Kg)
62-20KHz
150Wrms(600Wmax)
94dB
122dB
8 Ohm
8Ω/70V/100V
Black
White
Black
White
EVID6.2
EVID6.2W EVID6.2T EVID6.2TW
EVID ACCESSORIES
Optional extras available: See overleaf...
Description
Horizontal Mount Desk Stand
Mic Stand Adaptor Mount Kit
Weatherised Terminal Cover
Weatherised Terminal Cover
Weatherised Terminal Cover
Weatherised Terminal Cover
Prices Ex. GST
Code
HS-3
MA-3
TC-4B
TC-4W
TC-6B
TC-6W
http://data.wescomponents.com/Speakers/EV/
http://data.wescomponents.com/Speakers/EV/EVID.pdf
March 2013
BOSCH-11

Electro-Voice
EVID 12.1
12” SUBWOOFER ADD-ON
•Supplemental 12” bass system for indoor speakers
•Satellite system type - No additional amp required
•High-excursion woofer with dual voice coil for L/R channels
•High sensitivity, high power-handling as with other EVID
•Crossed-over pass-thru for up to four satellite speakers
•Trapezoidal shape for corner enhanced horn efficiency
•Eyebolts for optional ceiling hang mounting by rigging
•Steel-reinforced cabinet with mounting hardware included
•Paintable black or white finish decor attractive
Woofer
Power
Size
Freq.
SPL
dBi
Taps
Colour
Code
12”
175Wrms(700Wmax)
412x594x305mm (18Kg)
40-140Hz
100dB
128dB
8 Ohm x2
Black
White
EVID12.1 EVID12.1W
Safety line
attachment
eyebolt
Input/output
connector
panel
Bracket clip
mounting
points
EVID FM SERIES
2-WAY FLUSH MOUNT LOUDSPEAKER
•Shallow profile, ideal for tight wall or ceiling spaces
•Tuned passive radiator extends bass, enhances performance
•High quality 1-inch titanium dome tweeter
•Full-bandwidth overload protection
•70 V, 100 V, and 8 ohms operation
•Front-panel mode/wattage switch
•Fully-sealed enclosure provides superior isolation to protect adjacent rooms
•Secure Phoenix-style pass-through connectors for easy wiring and installation.
•Four point “quick mounting” tabs for fast attachment in any wall cavity
•Can-mounted transformer for enhanced rigidity
•Ribbed back can eliminates flexing
Woofer
Power
Size
Freq.
SPL
dBi
Taps
Colour
Code
4” + 4” PR
50Wrms(200Wmax)
350x200x95mm (3Kg)
52-20,000KHz
97dB
110dB
8Ω/1.75/3.75/7.5/15/30
White
FM4.2
6” + 6” PR
75Wrms(300Wmax)
465x256x100mm (6Kg)
52-20,000Hz
90dB
115dB
8Ω/7.5/15/30/60
White
FM6.2
EVID MIC STANDING
EVID DESK STAND
EVID BACK COVERS
MICROPHONE STAND KIT
HORIZONTAL MOUNT
WEATHER PROOF PLATE
Clever system that attaches EVID
speakers in between microphone holder
and microphone stand (not included).
Angle adjustable.
Suits all EVID Surface mount speaker boxes.
Horizontal table-top mounting. Metal stand
with rubber feet. Sold in pairs.
Rugged terminal cover with cable grommet.
Protects rear of EVID from the elements.
Code
HS-3
Code
MA-3
Suits EVID4.2B EVID4.2W EVID6.2B EVID6.2W
White
Black
White
Colour Black
TC-4W
TC-6B
TC-6W
Code TC-4B
Boom
(Not Included)
EVID
(Not Included)
BOSCH-12
March 2013
Prices Ex. GST

EV Wireless Mic R300
R300 WIRELESS MICROPHONE SYSTEM
Designed for the entry-level professional, the Electro-Voice R300 makes the benefits of
professional wireless microphone performance accessible to a new category of users. With
features like one-touch ClearScan and EZsync transmitter update, the R300 offers professionalclass capabilities but is as easy to setup and use as any entry-level wireless microphone system.
•ClearScan™ – find the clearest channel available with the touch of one button
•EZsync™ – infrared channel transfer from receiver to transmitter for easy and error-free setup
•PL22 cardioid dynamic microphone element for crisp, clear vocals in any application
•Rugged metal transmitters with backlit LCD display and battery gauge
•Bodypack with TA4 connector – Compatible with lapel and head-worn microphones
•14-hour battery life from two AA alkaline batteries
•32 preset channels, with compatible groups of 8 channels for simultaneous use
•Detachable half-wave TNC antennas enable use with APD4+ antenna distribution system
•Metal receiver chassis with optional rack-mount ears and front-mount antenna cables
R300 HANDHELD SYSTEM
R300 LAPEL SYSTEM
MIC & RECEIVER KIT
MIC & RECEIVER KIT
The HT-300 metal handheld transmitter is made to withstand the
rigors of daily use but still be comfortable in your hand. The PL22
dynamic microphone is the perfect all-around microphone for speaking
engagements, singing and emcees. The cardioid pickup pattern
rejects noises from the surroundings, helps control audio feedback,
and still allows an experienced vocalist to work the microphone.
The R300-L system includes the metal BP-300 bodypack transmitter,
which uses two AA batteries. With ClearScan and EZsync, the R300-L
is the easiest wireless system you will ever use for presentations and
worship services. The directional ULM18 helps to reject noise from the
surroundings and control audio feedback.
•ClearScan automatically finds the clearest channel
•EZsync one-step channel setup
•PL22 cardioid dynamic microphone element
•14 hour battery life from two AA alkaline
•Rugged metal transmitter
•Metal receiver chassis
•ClearScan automatically finds the clearest channel
•EZsync one-step channel setup
•ULM18 directional lapel microphone
•14 hour battery life from two AA alkaline
•Rugged metal transmitter
•Metal receiver chassis
Code
Code
R300-L-B
R300-HD-B
R300 HEADSET SYSTEM
R300 ACCESSORIES
MIC & RECEIVER KIT
Replacement microphones.
HANDHELD MIC
Code
The R300-E system includes the metal BP-300 body pack transmitter,
which uses two AA batteries. The HM3 microphone is comfortable for
extensive daily use, including long presentations. Using a headwork
microphone helps to control audio feedback and provides consistent
audio while the speaker moves naturally around the stage.
•ClearScan automatically finds the clearest channel
•EZsync one-step channel setup
•HM3 omni-directional microphone
•14 hour battery life from two AA alkaline
•Rugged metal transmitter
Code
R300-E-B
HT-300-B
LAPEL MIC
Code
ULM18
HEADSET MIC
Code
HM3
BODY PACK
Belt pack transmitter (only).
Code
BP-300-B
BODY PACK SYSTEM
Kit includes the receiver unit
and a belt body transmitter unit
(TA4). No microphone.
Code
R300-BP-B
RECEIVER
Base station only.
Code
R300-RX-B
Prices Ex. GST
March 2013
BOSCH-13

Bosch Plena Easy Commercial PA
BOSCH PLENA-EASY MIXER AMP
SINGLE ZONE WITH 100V LINE + 8Ω OUTPUT
High performance, professional public address units with modern state
of the art features. They are easy to use, taking the complexity away
from the user and putting it where it belongs, inside the equipment.
Providing a crisp call or clear music is as easy as turning on the radio.
The amplifier is also surprisingly affordable, without sacrificing features
such as ducking, priority and flexibility.
•4 microphone/line inputs, plus 3 music source inputs
•Telephone input with priority & VOX
•Announcement only output, 3-wire volume override
•Voice-activated emergency override
•Wide range of power (30, 60 and 120 Watts)
•70 V / 100 V and 8 ohm outputs
•2-tone chime (more with PLE4TM)
•Outputs for line out and music only out
•Unique easy-to-use intuitive tone controls
MIC. Inputs Zone Insert Output
4
4
4
3xRCA 1
3xRCA 1
3xRCA 1
No
No
No
Code
30Wrms PLE-1MA030
60Wrms PLE-1MA060
120Wrms PLE-1MA120
http://data.wescomponents.com/bosch/PLE-1MA.pdf
BOSCH PLENA-EASY MIXER AMP 2 ZONE
TWO ZONE WITH 100V LINE + 8Ω OUTPUT
The music can be switched on and off in the zones via the front
panel and optional wall panel. Announcements from the PLE-2CS
two-zone call station can be routed to zone 1 or zone 2, or both.
Announcements from the tel/100 V input or inputs 1 & 2 are routed
to both zones. Input 1 can be used for a PLE-1CS all-call call
station or any other microphone or call station with a PTT contact.
•6 microphone/line inputs plus 3 music source inputs
•Telephone and a call station input with priority & VOX
•2 zones and announcement only output
•Voice activated emergency override
•High output power 120 and 240 Watts
•70 V / 100 V and 8 ohm outputs
•2-tone chime built in (7 more chimes optional with call station)
•Outputs for line out, music only out and insert point
•24 V backup input with built in 24 V charger
•Separate tone controls for microphones and music sources
MIC. Input
6
6
Zone Insert Output
3xRCA 2
3xRCA 2
Yes
yes
Code
120Wrms PLE-2MA120
240Wrms PLE-2MA240
http://data.wescomponents.com/bosch/PLE-2MA.pdf
BOSCH PLENA-EASY MIXER PRE-AMP
AMPS TO SUIT - NEXT PAGE....
The Plena mixer is a high performance, professional public address
mixer with modern state of the art features. Combined with a power
amplifier for an easy-to-operate powerful flexible public address system.
•6 microphone/line inputs, plus 3 music source inputs
•Telephone and a call station input with priority & VOX
•2 zones and 2-channel operation
•Voice-activated emergency override
•2-tone chime built in, 7 more chimes optional with call station
•Outputs for line out, music-only out, and insert point
•24 V backup input with built in 24 V charger
•Separate tone controls for microphones and music sources
MIC. Input
6
Zone Insert Output Code
3xRCA 2
Yes
Line
PLE-10M2
http://data.wescomponents.com/bosch/PLE-10M2.pdf
BOSCH-14
August 2013
Prices Ex. GST

Bosch Plena Easy Commercial PA
BOSCH PLENA-EASY POWER AMPLIFIER
POWER AMP ONLY WITH 100V LINE + 8Ω OUTPUT
High-power plug-and-play cost effective power amplifiers that
deliver 120 and 240 Watts to constant voltage or 8 ohm loads. Built
with premium quality and protections, they offer basic functionality
at a budget price. The amplifiers offer straight 1 V and 100 V line in,
and 70 V, 100 V and 8 ohms out. They can extend the power of the
PLE- series mixer amplifiers or be combined with the PLE-10M2-EU
mixer, or work anywhere where more power on an existing 100 V
line is needed or when a line level signal is provided.
•120 and 240 W power amplifier in a compact housing
•1 V line level balanced (XLR Loop-Through) input or...
•100 V input for slave operation on 100 V speaker line
•70 V, 100 V and 8 ohm outputs screw wire connect
•Forced front to back ventilation (directly stackable)
•24 VDC backup power input with built in charger
Input Output
1
1
Code
120Wrms PLE-1P120
240Wrms PLE-1P240
http://data.wescomponents.com/bosch/bosch/PLE-1P.pdf
BOSCH PLENA-EASY eWALL-PLATE
BOSCH PLENA-EASY eTONE GENERATOR
Wall Panel is used to remotely select a music source and activate or
deactivate zones of a Plena PLE audio mixer or mixer amplifier.
The Plena Tone Module is an extension to the Plena line of equipment,
offering the user four different signals to use in an installation. The
first two chimes are specifically made to comply with ISO 8201, which
is mandatory in areas where installations are required to meet the
AS2220.1.2 standard.
•Can be used for all Plena Easyline (PLE) mixer amplifiers
•Remote selection of three music source inputs
•Remote zone selection
•Perfect companion to Bosch volume controls
•Daisy‑ chain of multiple wall panels
•Powered through the Plena system
•Plena-Easy Evacuation,
Alert, Time Signal, and
Chime signal generation
•Microphone pre-amplifier
connection with PTT
•Stereo line input with
priority switchover
•Australian Standard
AS2220.1.2 and ISO 8201
•Signal generation and line
input without sacrificing an
input of the mixer
Code
PLE-WP3S2Z
Code
PLE-4TM
http://data.wescomponents.com/bosch/PLE-4TM.pdf
http://data.wescomponents.com/bosch/PLE-WP3S2Z.pdf
eDESK-MIC HEAVY DUTY
eDESK-TOP MIC
eDESK-TOP MIC 2 ZONE
•Sturdy desk top microphone for
demanding applications
•PTT-key for calls for activation
•Momentary or toggle
•Green LED, indicating microphone active
•Stable metal base design
•2 m cable
•Lockable Euro style connector
•Phantom powered by amplifier
•PTT-key for calls for activation
•Momentary or toggle
•Green LED, indicating microphone active
•Stable metal base design
•2 m cable
•Lockable Euro style connector
•Phantom powered by amplifier
•Modern two-zone call station for the PLE
series
•Selectable gain
•Speech filter and limiter
•Output level control
•Loop-through option for up to 8 call
stations
•LED indications for zone selection, busy,
and power on
Code
PLE-1CS
Code
Code
PLE-2CS
PLE-1SCS
Plena
1 2 3 4 5
ZONE
3
LED
5
4
na
PTT
S2
na
http://data.wescomponents.com/bosch/PLE-1SCS.pdf
Prices Ex. GST
http://data.wescomponents.com/bosch/PLE-1CS.pdf
August 2013
P le
S3
2
1
P le
S1
http://data.wescomponents.com/bosch/PLE-2CS.pdf
BOSCH-15

Bosch Plena PA
PLENA PUBLIC ADDRESS SOLUTIONS
Plena Solutions can be used to tailor the public address system to the
precise needs of small-to-mid-sized locations. Plena offers facilities for
background music, paging and playing pre-recorded commercials and
additional power for applications such as hotels, offices and shopping malls.
•High quality sound and construction
•Ideal for small-to-midsized applications
•Easy expandability and function
•Easy to install and maintain
http://products.boschsecurity.com.au
PLENA MIXER AMP ALL-IN-ONE
DVD/CD/MP3/AM/FM/MIC MIXER AMP WITH 100V LINE + 8Ω OUTPUT
Versatile all-in-one solution to cover all needs for background music
(BGM), making announcements and paging people. This high
performance yet affordable unit is very easy to install and operate. It
is typically used in shops, supermarkets, restaurants, bars, schools,
canteens, gyms, garages and other places where BGM creates the
right atmosphere, and also amplified speech needs to be heard clearly.
•All-in-one solution for background music and paging
•DVD/CD-player for video and audio
•Supports MP3, JPEG, and multi-format video outputs
•FM/AM tuner with 10 presets and digital control
•Dual-zone 120 W mixer amplifier with volume control per zone
•70V / 100V and 8 ohm outputs
•Selectable priority and VOX switching on microphone input 1
•Optional 2-tone chime to precede announcements
•Remote control
MIC. Input
3
Zone Insert Output
2xRCA 2
No
Details
Code
120Wrms DVD + AM/FM PLN-2AIO120
http://data.wescomponents.com/bosch/PLN-2AIO120.pdf
Video output
Plena BGM/Paging System
Mode
AM/FM
Eject
Scan
0 dB
-6 dB
-20 dB
M1/6
M2/7
M3/8
M4/9
M5/0
Shift
C all Only Zone 1 C all/B G M
Memory
FM
AM
0
100V 0 100V 0
1
2
Select
Z o ne 1
8
Yc
R -Y
C VBS
B -Y
Zone 2 C all/B G M C all Active
100 V 0
0
S DDIF
8
Y /C
Z o ne 2
DVD/Tuner
14
-2
5
L
Aux
Power
0
0
3
-1 2
-1 5
-9
-6
-1 2
-3
0d B
-1 5
-9
-6
-3
R
0d B
1234567
0
0
C himen
Ducking
1
2
3
Aux In
0
PLENA INDUCTIVE LOOP AMP
The Plena Loop Amplifier is a cost-effective amplifier designed to drive a wire loop installed in the floor or ceiling, covering an area of up
to 600M² per amplifier. This solution enables hearing-aid users in the area enclosed by the wire loop to hear all announcements, or music.
Hearing-aid users can set their devices to the Tmode setting to receive the signal coming from the loop. They receive announcements in
excellent audio-quality, without the background noise or reverberations that normally impair intelligibility for people with hearing disabilities.
•High power, current driven amplifier
•Two microphone/line inputs, one priority input (100 V)
•Selectable frequency range and tone controls
•Limiter and automatic gain control (AGC)
•Integrates in an EN 54‑16 and EN 60849 compliant system
Code
PLN-1LA10
INDUCTION LOOP TESTER
The Plena inductive loop receiver is a compact, portable
device intended to receive the field from an inductive
loop for assistive listening device users. It can be used to
monitor the field strength and quality of the inductive loop
system such as from the Bosch Plena PLN1LA10.
•Monitoring of an inductive loop system
•Quick check of field strength
•Neck cord included for use by assistive hearing
device users without “T”setting.
•Earphones included
•For two AAA rechargeable or alkaline batteries
Slave
in Slave
0º
Line Out
Out
90º
out
Fault
input
Supervis
1
ion
NO
C
5K 10K
115V
NC
On
2
0
Vox
Off
Line fuse:
Off
Phantom
Mic
Line
On
Line fu
se
230V
Apparatu
Connect s delivered
ed for
230V
Phantom
Mix
On
Off
230V
115V 3A
6A
Loop
Out
Com
Mic
Line
: 230V
115V 3A
6A
Loop
Out
Co
m
d St
ren
00
MAX O.K
gth
er
iv
100 400
LOOP NOT INCLUDED
Field Strength
http://data.wescomponents.com/bosch/PLN-ILR.pdf
BOSCH-16
Master
Limiter
100V
m
O.K
In
Priority
AGC
he
PLN-ILR
Master
Metal
loss
compensa
tion
l
ve
le ils
ar deta
/e for
ye l
t e anua
Code
http://data.wescomponents.com/bosch/PLN-1LA10.pdf
August 2013
Prices Ex. GST
Bosch Plena PA

PLENA MIXER AMPS
100V LINE + 8Ω OUTPUT
The Plena mixer amplifier is a versatile, high-performance unit with four mono microphone inputs and a music input.
It fulfills a wide variety of public address requirements at a surprisingly low cost.
•Range of single zone mixer amplifiers from 30W to 120W
•70V / 100V and 8 ohm outputs
•Four low-noise balanced inputs for microphone or line
•Selectable priority & VOX switching on microphone input 1
•Optional 2-tone chime to precede announcements
•VOX activated emergency override
•Outputs for normal, call-only and mix-only zones
•Select switch for CD, tuner or auxiliary music inputs
MIC. Inputs Zone Insert Output
4
4
4
3xRCA 1
3xRCA 1
3xRCA 1
Yes
Yes
Yes
Code
30Wrms LBB1903/10
60Wrms LBB1906/10
120Wrms LBB1912/10
http://data.wescomponents.com/bosch/LBB19xxMA.pdf
L
Tel/Emer.
Plena Mixer Amplifier
Out
0
R
0 dB
-6 dB
-20 dB
In
CD
Aux
Inc
Line Out 1V
0 2
Mic/Line
Mic/Line
100V 0
70V
0
8
Power
0 100/70V 0 100/70V 0
1 3
4 5
1
2
3
2
Select
CD
AUX
Master
Call Only Mix Only24VDCIn
Call/Mix
Chime
1
3
4
Line
4
PLENA MIXER 6 ZONE PRE-AMP
PRE-AMPLIFIER ONLY - REQUIRES AMP
The Plena system pre-amplifier is a versatile, high performance unit with call and mono BGM (background music).
It fulfills a wide variety of public address requirements at a surprisingly low cost. It can provide dual channel
operation for simultaneous calls and BGM for up to six different zones, using two Plena amplifiers.
•Six-zone system pre-amplifier, with single
or dual channel operation
•Two input channels for call stations
•Universal input for microphone/line, with
speech optimized tone control
•Three inputs for BGM selection and music
optimized tone control
•Front panel zone selection for BGM and
call station zone selection for calls
•PC and trigger inputs for automated calls,
alarm tones and chimes to selected zones
LBB1941-00 / LBB1946-00
MIC. Input
2
Microphone Not Included
Zone Insert Output Code
3xRCA 6
No
Line
LBB1925/10
http://data.wescomponents.com/bosch/LBB1925-10.pdf
Tel/EMG
115V
Trigger 1 Trigger 2
230V
Plena System Pre-amplifier
Select
0 dB
1. Audio+
2.0V
3.Audio4.24Vd.c.
/Line
5. Allcall
6.DataPCAudoln
7.Data+
8.Chs.GND
RS232
CD
2
GND
-
3
R
3
5
7
3
5
1
2
3
5
4
8
2
1
1
GND
1
-
MasterOut
Z2
Z3
100V 0
100V 0
100V 0
+24V-
+24V-
/Line
Z4
Z5
Z6
+
2
3
100V 0
6
4
100V 0
Power
+
Z1
AUX
-20 dB
Aux
L
/Line
14
CD
-6 dB
0
100V 0
100V 0
100V 0
0
Out
0
PLENA POWER AMPS
POWER AMPLIFIER ONLY WITH 100V LINE + 8Ω OUTPUT
A powerful range of power amplifiers in a 2U high 19” case for rack
mounting or tabletop use. LEDs on the front panel show the status
of the amplifier: power, audio output level, and supervised functions.
This high-performance unit fulfills a wide range of public address
requirements at a surprisingly low cost.
1
1
1
1
120Wrms
240Wrms
480Wrms
1000Wrms
Pilot-tone
Detector
OffOn
Power
Input Battery Main Power
Battery
Detection
NO COM NC
NO COM NC
OffOn
NO COM NC
Direct O utput
2..24V GND 2..24V GND 100V
Default Off Default On
Input 1-Priority
0
100V
0
70V
0
8
Input 2-Progr am
Priority Controlled Output
100V
Input
0V
100V
24V DC In
0V
Input
Priority Only
Input
•High power amplifier in a compact housing
•70V / 100V and 8 ohm outputs
•Dual inputs with priority switching
•100 V input for slave operation on 100 V speaker line
•Temperature controlled forced front to back ventilation,
directly stackable.
Input Output
Fault Relays' Output
Input 1 Input 2 Slave Input
Priority Enable 100V
No Priority
Output
Code
LBB1930/20
LBB1935/20
LBB1938/20
PLN-1P1000
http://data.wescomponents.com/bosch/LBB1930-20.pdf
Prices Ex. GST
August 2013
BOSCH-17

Bosch Source Accessories
PLENA EASY BGM
Plena Easy Line SD Tuner BGM source is the ideal high‑quality source for background music (BGM) in public address systems.
It provides hours of uninterrupted music for professional systems. Designed without moving parts, it can be used in systems
that are on for long periods. It is designed to be used with non-volatile steady state flash memory.
•MP3 playback from SD card and USB inputs
•FM tuner with RDS, presets and digital control
•Simultaneous operation of SD/USB-player and FM tuner
•Separate outputs for digital source and FM tuner
Code
PLE-SDT
Insert only one USB stick at the time.
If a USB stick is inserted in the front,
this socket cannot be used, and vice versa
ANTENNA
WEEKLY TIMER
OUTPUT LEVEL
TUNER
COMBINED
USB/SD
OUTPUTS
R
L
TUNER
R
L
COMBINED
230V~50Hz 50W or 115V~60Hz 50W
R
L
USB/SD
USE ONLY WITH 250V FUSE
230V~FUSE T0.63A/250V or
115V~FUSE T1.25A/250V
http://data.wescomponents.com/bosch/PLE-SDT.pdf
The Plena Weekly Timer is an accurate timer for use in public address systems. It is ideally suited for schools,
shopping malls and all other venues that need regularly timed messages, signals or other controls. It is ideally
suited for connection to the Plena Message Manager and Voice Alarm System.
•Two weekly programs
•14 Chimes
•Six contact outputs
•Automatic daylight/standard time
•BGM level control
•Hold and pause function
•Programming on the unit and via the supplied PC program
•Ideal partner complement to the Plena Message Manager
and Voice Alarm Controller for timed messages
Code
PLN-6TMW
DIGITAL MESSAGE ANNOUNCER
http://data.wescomponents.com/bosch/PLN-6TMW.pdf
The Plena message manager is a high performance, highly versatile
stand-alone digital message player. Applications range from spot
announcements in supermarkets and theme parks to warning and
evacuation messages in emergency situations.
•Highly flexible stand‑alone digital message player
•Up to 12 messages and 12 trigger inputs
•Downloads messages from a PC in WAV format
•Compliant with standards for emergency sound systems
•Zone control for Plena system preamplifier LBB 1925/10
•Front panel control and remote control
Code
LBB1965/00
FEEDBACK ELIMINATOR
http://data.wescomponents.com/bosch/LBB1965-00.pdf
The Plena feedback suppressor uses a powerful DSP with a
patented algorithm to suppress acoustic feedback. It actively filters
out unwanted room reverberations using an echo-cancellation and
de-reverberation algorithm. By adding masked (inaudible) noise
to the output signal or by shifting the frequency of the output
signal by five hertz, the Plena feedback suppressor is able to
detect the reverb component of the signal and remove it before
feedback occurs. This leaves the original signal intact.
•Patented feedback suppression algorithm
•Suppresses feedback before it occurs
•Automatically adapts to the acoustical situation
•Up to 12 dB additional gain before feedback occurs
•Balanced line or microphone input with phantom supply
•Second microphone input with automatic mixer
Code
LBB1968/00
BOSCH-18
http://data.wescomponents.com/bosch/LBB1968-00.pdf
August 2013
Prices Ex. GST

Bosch Microphones
PLENA ALL-CALL STATION MIC
PLENA CALL STATION
The Plena Call Station is a stylish, high-quality call station with
a stable metal base design, a flexible microphone stem, and a
unidirectional condenser microphone. Its purpose is to make calls to
all zones (all-call) in a public address system built around the LBB
1925/10 system preamplifier. In addition to tabletop use, the special
design enables the unit to be neatly flush-mounted in desktops.
DESK MIC 6 ZONE
•Stylish all-call call station,
intended for LBB 1925/10
system pre-amplifier
•Unidirectional condenser
microphone on flexible stem
•Momentary PTT‑key for calls
•Selectable gain, speech
filter, and limiter for improved
intelligibility
•Stable metal base design
•Fixed 5 m cable and
loop-through connector for
additional call stations
Six-zone Call Station is a stylish, high-quality call station with a stable
metal base design, a flexible microphone stem, and a unidirectional
condenser microphone. It can make calls to selected zones (one to six
and all-call) in a public address system built around the LBB 1925/10
system pre-amplifier. In addition to tabletop use, the special design
enables the unit to be neatly flush-mounted in desktops.
•Stylish six-zone call station, intended
for LBB 1925/10 system pre-amplifier
•Unidirectional condenser microphone
on flexible stem
•Six zone selection keys, all-call key,
and momentary PTT-key for calls
•Selectable gain, speech filter, and
limiter for improved intelligibility
•Selectable priority levels and different
pre and postcall chimes
•LED indications for zone selection,
system activity, and call station status
Code
Code
LBB1941/00
LBB1946/00
http://data.wescomponents.com/bosch/LBB1941-00.pdf
http://data.wescomponents.com/bosch/LBB1946-00.pdf
UNIVERSAL TABLE TOP MIC
UNIVERSAL HAND-HELD MIC
The Plena tabletop microphone is a stylish, high quality tabletop
unidirectional condenser microphone, mainly intended for making
calls in a public address system. Its heavy metal base and rubber feet
ensure stability on any flat surface. The special design also allows the
unit to be neatly flush-mounted in desktops.
This unidirectional handheld microphone
provides some motion freedom. It is based
on a dynamic transducer element in a sturdy
housing with shielding against wind and wind
bursts (pops). The microphone has excellent
cardioid directivity, greatly reducing acoustic
feedback. The microphone is intended for
public address and sound reinforcement
applications such as in leisure centres,
assembly halls, and shops. Includes wall
mount clip. 221x53mm 420g. Bosch branded.
•Stylish tabletop unidirectional
condenser microphone on a
flexible stem
•Phantom powered by amplifier
•Momentary or toggle PTT-key
for calls with priority contact
•Green LED, indicating
microphone active
•Stable metal base design with
fixed 2 m cable
•Lockable DIN connector
•XLR Adaptor
•Dynamic transducer 600 ohm 2mV/Pa
•Unidirectional handheld microphone
•High speech intelligibility 100Hz-13KHz
•Rugged construction - Dark grey finish
•Inbuilt mute I/O switch with PTT contacts
•0.5M coiled / 1.2M uncoiled to 5 Pin Din
Code
5 Pin
DIN
Code
LBB1950/10
LBB9099/10
http://data.wescomponents.com/bosch/LBB1950-10.pdf
http://data.wescomponents.com/bosch/LBB9099-10.pdf
UNIVERSAL GOOSENECK MIC
UNIVERSAL HEAVY-DUTY MIC
UNIVERSAL PTT HAND MIC
The gooseneck microphone is a stylish
high quality unidirectional condenser
microphone, mainly intended for
public address applications.
Professional Gooseneck
Paging Microphone suitable for
applications where ruggedness,
dependability and durability are
required - perfect for supermarkets!
Dynamic passive handheld microphone
push-to-talk is designed for close talking
applications, and is ideal for short
announcements.
•Unidirectional condenser
microphone
•Flexible stem
•Phantom powered by
amplifier
•On/off sliding switch
with priority contact
•Supplied with fixed
2 m (78 in) cable
and lockable DIN
connector
Code
LBB1949/00
•Durable single-zone
gooseneck paging
microphone with normallyclosed preconfiguration
•Omnidirectional pickup
pattern, speech-optimized
frequency response
•Flexible 16” steel
gooseneck arm
•Excellent speech reproduction
•Rugged construction
•Easy to handle
•Remote switching contact
•Close talking applications
•Matt black finish
Code
LBB9080/00
Code
SR785LN/O
10dB
50 Hz 100
http://data.wescomponents.com/bosch/LBB1949-00.pdf
Prices Ex. GST
http://data.wescomponents.com/bosch/SR785LN-O.pdf
August 2013
200
500
1 kHz 2
5
10
20
http://data.wescomponents.com/bosch/LBB9080-00.pdf
BOSCH-19

Bosch Plena Matrix
PLENA MATRIX DIGITAL SOUND SYSTEM
HIGH PERFORMANCE DSP WITH MULTIPLE CONTROL OPTIONS
The PLENA matrix system combines superior audio performance and product quality in an easy
to install and use package. Ideal for recorded or live music and speech distribution, PLENA matrix
will produce outstanding sound in small to medium applications requiring up to 8 zones.
•Complete DSP 8-zone matrix mixer and loudspeaker processor featuring powerful control
•4 microphone/line inputs, call station input, 3 RCA music inputs and up to 8 mixed outputs
•4-channel power amplifiers (100 V / 70 V / 8 Ω / 4 Ω output) with DSP processing and input mixing
•Standby mode engaged manually, or automatically with motion sensors in each zone
•Control via Windows PC GUI, Apple iOS App and Wall Control Panels
•8-zone call station with capacitive touch buttons and programmable zone selection
•Three year warranty
www.wescomponents.com/bosch
INTELLIGENT FEATURES & SUPERB PERFORMANCE
As expected from Bosch, audio performance is premium and with their new PLENA matrix series,
PA is now in the digital age of convenience with DSP and touch control.
•8-Zone DSP Matrix Mixer delivers a full-featured DSP zone matrix with
4 microphone/line, 3 music source, call station and emergency inputs, all
output via parametric EQ to 8 zones.
•4-Channel DSP Power Amplifiers (125 or 220 W/channel models) Class D
power amplifier, 100 V/70 V/8 Ω/4 Ω outputs. Built-in DSP with input mixing
controls via iOS app or PC GUI. 8-band parametric EQ for each zone.
•Call Station with up to 8 Zones for paging.
•Wall Control Panels for simple volume and source select
•Ethernet for integration of computer and tablet devices for access to
advanced signal administration and DSP audio control.
EASY CAT5 CONNECTIONS SOLUTIONS
Utilising CAT5 cabling dramatically reducing cable runs and installation time while simplify wiring chaos
making setup and trouble shooting intuitive. Bosch recommend using CAT5e-SFTP Shielded Patch cables.
•Amp Link CAT5e connections link the DSP mixer with the amplifiers.
4CH per CAT5-SFTP Digital streaming up to 500 metres.
•Call Station CAT5 connection can be Daisy-chained to expand to
further call stations, audio, control and powered over a single CAT5.
•RS485 CAT5 connection to Wall Controllers. Daisy-chain to expand
to up to 16 wall controllers, all powered over CAT5.
•Ethernet CAT5 to up to 5x PC Control and/or a wireless hub for WiFi
control by up to 8 iPad/iPhone Apps for hand-held touch control.
•Multiple systems CAT5 Ethernet hub can connect further PLM-8M8
Matrix Mixers for easy central control of complex installations.
CAT5 Cable
SAVE ON RUNNING COSTS
Class D Amplifiers are the most efficient form of amplification saving on long term power use.
Amplifiers automatically drop into low power consumption mode when zones are not used.
With the aid of optional PIR motion detectors, zones can automatically switch on and off.
Reduce running costs and extending product life without depending on venue staff.
ADVANCED DIGITAL CONTROL
Taking advantage of the latest in GUI control of Digital Signal Processing makes
advanced intricate control easy for even the novice. 3 Levels of operator are
available. From simple venue employee to manager to advanced system with full DSP
adjustments. Modern interfaces make operation intuitive and a joy to use.
•Wall Control Panels enable input source and volume control within each zone.
•Call Stations provide paging capability to up to 8 zones with optional ducking.
•PC GUI provides extensive controls for audio professionals and system admins with
password protected access. Modern software is highly graphical and easy to use.
•iOS App for iPhone and iPad allows wireless control of input source and acoustic
variables over multiple zones. Up to 8 users simultaneously can have portable access.
BOSCH-20
August 2013
Prices Ex. GST

Bosch Plena Matrix
PLENA MATRIX DSP MIXER
8 ZONE CONTROLLER WITH 4 MIC & 3 BGM INPUTS + CALL STATION & CONTROL PANEL INPUTS
Multi-zone control centre for low-level mixing and routing of various sources.
Required to integrate call stations, control panels, amplifiers, ethernet control.
Inputs include 4x mic/aux, 3x RCA, 1x Call station, Phoenix EVAC terminal.
Outputs to “Amp-link” RJ45 (x2) or (8x) 3-Pole Phoenix line level connectors.
•Independent zone selection (up to 8 zones)
•Independent mixing of 4 x mic/line inputs (per zone)
•Independent 3 BGM source selection (per zone)
•Paging level control per zone. Ducking facility
•Input gain, HPF, PEQ (5 filters mic/line)
•Dynamic range compressor. Dynamic bass.
•Crossover (HPF, LPF, up to 8th order)
•Output PEQ (7 filters per output)
•Output delay (up to 120 ms)
•Output level control with phase inversion
•Call station, override and tones facility
Contact closures for activation of
emergency tones and override input
Power switch
and connector
Code
Line outputs
8x (-/c/+)
Amp Link outputs
2x RJ45 (1-4+5-8)
PLM-8M8
3 x BGM line
inputs via RCA
4 x Mic/ line input via
XLR/TRS combo
Ethernet
control port
Balanced line input
for active override
Wall Control Panel
connection
Call Station
connection
PLENA MATRIX DSP AMPLIFIERS
QUAD CHANNEL CLASS-D AMPLIFIERS WITH 4 LOCAL INPUTS
Can operate as a 4 zone amplifier or bridge to operate as a single
zone high power stereo amplifier. 4CH inputs accept line-level or
microphone, ¼” or XLR or hard wired connections, level trimming.
Sensor trigger inputs for auto stand-by power up/down. Use as part of
an expanded system or stand-alone with full featured IP control.
•Highly efficient Class D amplifiers with low standby power
•Bridgeable outputs (1-2/3-4) for quad or stereo output
•Separate dedicated 4Ω / 8Ω / 70V / 100V on each output
•Level control of amplifier output channels via IP controlled
•Built-in DSP feature set and full 4-channel mixer. Dynamic bass.
•Standby on/off (Auto Standby with optional motion detectors)
•Crossover Filters and EQ Filters (PEQ, HPF, LPF, Shelf)
•Delay control up to 120 ms delay per channel with distance
•Dynamic range compressor/limiting with advanced controls
•Local OVERRIDE connection for emergency, EVAC, etc.
4 x line inputs via XLR/TRS combo or
Euro-Phoenix connection
Outputs Bridged Code
4x 125W 2x 250W PLM-4P125
4x 220W 2x 445W PLM-4P220
Power switch
and connector
www.wescomponents.com/bosch
Amplifier
channel outputs
Movement sensor/contact closure for
Auto standby and 12VDC power output
Amp Link
input
Channel
attenuation
Active override input
and contact closure
DIP Switch to control input
sensitivity and bridging
PLENA MATRIX CALL STATION
PLENA MATRIX WALL CONTROL PANEL
8 ZONE ANNOUNCING MICROPHONE
IN-ZONE CONTROLLER
•Paging any combination of 8 zones
•Capacitive touch buttons
•Status LED indicators
•Label inserts printed from PC GUI
•Powered via CAT5 from PLM-8M8
•Daisy chained using CAT5 RJ45
•Individual local zone controller
•Volume & input source selection
•Status LEDs & Volume level
•Label inserts printed from PC GUI
•Powered via CAT5 from PLM-8M8
•Daisy chain more units with CAT5
Capacitive touch
buttons
Paper label
inserts
Code
Ethernet
control port
Paper label inserts can
be printed off from GUI
Code
PLM-8CS
PLM-WCP
Mechanical
PTT button
Powered over CAT5 cable
from PLM-8M8
Capacitive
touch buttons
CAT5 Cable
CAT5
Cable
www.wescomponents.com/bosch
Prices Ex. GST
August 2013
Powered by CAT5 cable
from the PLM-8M8
BOSCH-21

Bosch Commercial Electronics
A PRACTICAL SOLUTION FOR ALL TYPES OF APPLICATIONS
With more than 60 years of experience in the design and development of electroacoustic technology, Bosch is an established leader in the field. Their guiding principle
is to create products that are superior in terms of technology, design and ease of use.
From waveguide to array technology, and 3-D simulation to cutting edge design, Bosch’s
acoustical expertise is as extensive as it is innovative. Turning comprehensive experience
into world-class acoustical solutions – that’s how Bosch continues to lead the way.
Enabling optimal acoustics
At Bosch, our expertise is in developing superior technology for an optimal acoustical
environment. Sometimes this means high quality background music with a consistent
sound level everywhere in the listening area. Other times, as in the case of an
emergency, it means messages which are received clearly, with high speech intelligibility
– even when there is considerable background noise. It’s all made possible through the
technologies developed by Bosch: cardioid column loudspeakers, feedback suppression,
reverberation technology, and many others. And Bosch continues to innovate, creating
today’s technologies which will become tomorrow’s industry standards.
Investment in R&D
Bosch’s reputation for producing state of the art technologies is largely due to the
extensive research that it invests in. Its commitment to innovation is huge: Bosch owns
and operates one of Europe’s largest acoustical test and measurement facilities. This
test centre has 5 fully equipped anechoic rooms, allowing Bosch to accurately and
automatically measure microphones and loudspeakers. Extensive testing, all done
according to internationally recognised industry standards, ensures that customers can
be confident about the high quality of every Bosch acoustical product.
Horn Speaker
Cabinet
Loudspeakers
Sphere Speakers
Paging
Microphone
Feedback
Suppressor
Plena
Message
Manager
Microphone
Plena Mixer
Aux iPod Dock
DVD Player
& Tuner
Plena Matrix Digital Sound System
Code
PLM-8M8
PLM-4P125
PLM-4P220
PLM-8CS
PLM-WCP
Description
PLENA matrix 8CH DSP Matrix Mixer
PLENA matrix DSP Quad Power Amplifier 125W
PLENA matrix DSP Quad Power Amplifier 220W
PLENA matrix 8 Zone Call Station
PLENA matrix Wall Control Panel
Plena Matrix
Software:
Windows & iOS
Plena Easy Amplifiers
Loop Amps
Code
Code
PLE-1CS
PLE-1MA030
PLE-1MA060
PLE-1MA120
PLE-1P120
PLE-1P240
PLE-1SCS
PLE-2CS
PLE-2MA120
PLE-2MA240
PLE-4TM
PLE-10M2
PLE-WP3S2Z
Description
PLN-1LA10
Plena e desk mic gooseneck - all call
Plena easy 30w mixer amp 4x inputs
Plena easy 60w mixer amp 4x inputs
Plena easy 120w mixer amp 4x inputs
Plena easy power amp 120w
Plena easy power amp 240w
Plena e heavy duty desk mic gooseneck - all call
Plena e desk mic gooseneck - 2 zone
Plena easy 120w 2 z mixer amp 6x inputs
Plena easy 240w 2 z mixer amp 6x inputs
Plena e tone generator module
Plena easy mixer 2 channel 6x input
Plena e wall panel source selector
PLN-ILR
Mixers
Code
LBB1903/10
LBB1906/10
LBB1912/10
PLN2AIO120
Description
Microphones
Code
30 watt mixer amp, 100v line, includes rack ears
60 watt mixer amp, 100v line, includes rack ears
120 watt mixer amp, 100v line, includes rack ears
“All in One” 2 zone 120 watt mixer amplifier with built in CD/MP3
/DVD player and AM/FM tuner. This
Plena Power Amps
Code
LBB1930/20
LBB1935/20
LBB1938/20
PLN-1P1000
Description
120 watt power amplifier, includes rack ears
240 watt power amplifier, includes rack ears
480 watt power amplifier, includes rack ears
1000 watt power amplifier, includes rack ears
BOSCH-22
Description
LBB1925/10 “Plena” system preamp / mixer, 6 zone paging system, includes
rack ears
Plena Mixer Amps
Code
Description
Loop amplifier, delivers 10 amps into the loop making it suitable
for covering up to 600 square metre
Plena Inductive Loop Receiver / basic test set including
headphones
Description
LBB1941/00 “Plena” all-call desktop condenser microphone / call station for
LBB1925/10
LBB1946/00 “Plena” 6 zone desktop condenser microphone / call station for
LBB1925/10
LBB1949/00 Permanently installed gooseneck microphone, 395mm, dynamic
LBB1950/10 Universal desktop condenser paging microphone with PTT
switch
LBB9080/00 Handheld dynamic fist microphone (CB style) with 1.2m coiled
cable
LBB9099/10 Uni-directional handheld dynamic mic with 1.2m coiled cord
terminated with 5-pin DIN plug
SR785LN/O Dynamic, Normally open PTT, Low Z, Gooseneck paging mic,
Rugged Stainless Steel Construction. Ideal
August 2013
Prices Ex. GST

Bosch Commercial Electronics
Wireless Microphone Systems
Ceiling Loudspeakers BCS-CS
Code
Code
MW1-RX-F1
MW1-HTX-F1
MW1-LTX-F1
MW1-LMC
MW1-RMB
Description
Bosch UHF diversity receiver 193 channel with LCD
Bosch handheld microphone transmitter 193 channel
Bosch bodypack transmitter 193 channel
Lavalier microphone (requires beltpack tx 010389)
Rack mount brackets & antenna adapter set to suit MW1RX-F1 receiver
Description
BCS-CS4BW 4” Easyfit ceiling speaker with 100V line tx with taps at 5,2.5,0.6
& 0.3W. 94dB SPL 1W/1m, 140mm cut out
BCS-CS4EM 4” Easyfit ceiling speaker with 100V line tx with taps at 5,2.5,0.6
& 0.3W. 94dB SPL 1W/1m, 140mm cut out
BCS-CS5BW 5” Easyfit ceiling speaker with 100v line tx with taps at 5, 2.5, 1,
0.6, 0.33W. 90dB SPL 1W/1m, 170mm cut out
BCS-CS6E
6.5” Easyfit ceiling speaker with 100v line tx with taps at 10, 5,
2.5, 1.25W. 91dB SPL 1W/1m, 195mm cut out
BCS-CS8BW 8” Easyfit ceiling speaker with 100v line tx with taps at 15, 10, 5,
2.5,1.25W. 93dB SPL 1W/1m, 238mm cut out
BCS-CS830E 8” Easyfit ceiling speaker with 100v line tx with taps at 30, 15,
7.5, 3.75W. 93dB SPL 1W/1m, 238mm cut out
Ceiling Loudspeaker Spring Mount - 6 Inch
Music Sources
Code
Code
Description
PLN-DVDT CD / MP3 / DVD player and AM/FM tuner, background music
source, separate audio outputs, video output
PLN-SDT SD/USB player and AM/FM Tuner background music source,
independent audio outputs for each source, in
Volume Controls and Source Selector Panels
Code
LBC1402/10
LBC1402/20
LBC1412/10
LBC1412/20
LBC1420/10
LBC1420/20
LBC1434/00
Description
Volume Control, 12 watts with Relay
Emergency Failsafe Volume Control, 12 Watts with relay
Volume Control, 36 watts with Relay
Emergency Failsafe Volume Control, 36 Watts with relay
Volume Control, 100 watts with Relay
Emergency Failsafe Volume Control, 100 Watts with relay
Source Selector, 5 channels plus off
Weekly Timer
Code
Description
PLN-6TMW Weekly timer featuring 2 separate programs, 14 chimes, 6 contact
outputs, automatic daylight savings
Digital Message Announcer
Code
Description
LBB1965/00 Digital message announcer, 12 message capacity at CD quality,
167s capacity at 24kHz sample rate, fu
Feedback Eliminator
Code
Description
MTS ION - Cobranet Audio Patching Solutions
ION0.2-O/P
ION2.0-I/P
ION4.4
ION8.8
Description
ION0.2 Wall Mount 2 Channel CNET Output I/F
ION2.0 Wall Mount 2 Channel CNET Input I/F
ION4.4 4x Channel Mic/Line:Output Line, CNET I/F
ION8.8: 8x Channel Mic/Line:Output Line, CNET I/F
Plena VAS Combined PA and Emergency Sound
Code
Description
LBB1956/00 Plena VAS Call Station - Six Zone Paging Buttons & All Call
button
LBB1957/00 Plena VAS Call Station Keypad - expands Call Station by 6x
programmable buttons
LBB1990/00 Plena VAS System Controller featuring six zones with individual
vol. control, built-in message manag
LBB1992/00 Plena VAS Router - expands Plena VAS by 6 Zones
LBB1995/00 Plena voice alarm fireman’s panel
LBB1996/00 Plena voice alarm remote control
LBB1997/00 Plena voice alarm remote control ext
LBB1998/00 Plena voice alarm remote control kit
LBB1999/00 Plena voice alarm remote control extension kit
PLN-1EOL Plena vas eol board - pack of 6
PLN-DMY60 Plena vas dummy load board - pack of 12
Prices Ex. GST
Ceiling Loudspeaker Spring Mount - 8 Inch
Code
Description
LBC3082/00 Steel firedome for LBC 3099/41 ceiling speaker
LBC3099/41 Spring mount 8” dual cone ceiling speaker with metal grille, 24
watts, 100v line with taps at 24, 12
Ceiling Loudspeaker High Performance
Code
C4.2
C8.2
C8.2HC
C8.2LP
C10.1
C12.2
Description
Recessed Ceiling Prosound Lsp 30W 4” (2PCS)
Recessed Ceiling Prosound Lsp 30W 8” (2PCS)
Recessed Ceiling Prosound Lsp 60W 8” high ceiling (2PCS)
Recessed Ceiling Prosound Lsp 30W 8” Low Profile (2PCS)
Recessed Ceiling Prosound Lsp 60W 10” Sub (2PCS)
Recessed Ceiling Prosound Lsp 60W 12” Full range (1 PC)
Horn Speakers General Horn Range
LBB1968/00 Feedback Suppressor, 1RU, includes rack ears,
1RUx430x270mm, 3kg
Code
Description
LBC3080/01 Steel firedome for LBC 3090/31 & LBC 3090/01 loudspeakers,
Colour: Flame red (RAL 3000)
LBC3081/02 Steel firedome to suit the LBC3086/41 ceiling speaker, (red flame
colour RAL3000)
LBC3086/41 Spring mount voice alarm ceiling speaker, 6” dual cone, integral
metal grille, 6 watts 100v line wit
LBC3090/01 Spring mount 6” dual cone ceiling speaker, integral plastic grille,
6 watts, 100v line with taps at
LBC3090/31 Spring mount 6” dual cone ceiling speaker with terminal block for
cable connection, integral metal g
LBC3091/01 Surface mounting box for LBC 3090/01 ceiling speaker, Colour:
Off white (RAL 9010)
Code
Description
BCS-HS10E Round horn speaker, grey colour, 10w with taps at 10, 5, 2.5,
1.25 watts, comes with metal U mount
BCS-HS20E Round horn speaker 245mm diam, grey, 20w with taps at 20, 10,
5, 2.5 watts, comes with metal U-mount
LBC3470/00 Round horn speaker, light grey ABS, 15w 100v line with taps at
15, 7.5 & 3.75 watts
LBC3491/12 Rectangular horn, 267x171mm opening, light grey ABS, 10 watts
100v line with taps at 10, 5 & 2.5 watt
LBC3493/12 Round horn, 400mm opening, light grey aluminium/ABS, 30
watts 100v line with taps at 30, 15 & 7.5 watt
LBC3483/00 Round horn speaker, 490mm diam. Aluminium. 50W
LBC3484/00 Round horn speaker, 490mm diam. Aluminium. 75W
Horn Speakers Marine Grade
Code
Description
LBC3428/00 Marine horn protected to IEC60529 - IP66 and IP67, 163mm
opening, 15 watts 100v line taps
Horn Speakers Music Quality
Code
Description
LH1-UC30E 2 way CD horn, rectangular, light grey ABS, 30 watts 100v line
with taps at 30, 15, 7.5 & 3.75 watts
August 2013
BOSCH-23

Bosch Commercial Electronics
Horn Drivers - 9000 Series
Column Loudspeakers External Metal Weatherproof
Code
Code
Description
LBN9000/00 15w horn driver, 100v line with taps at 15, 7.5, 3.75 W
LBN9001/00 30w horn driver, 100v line with taps at 30, 15, 7.5 W
LBN9003/00 50w horn driver, 100v line with taps at 50, 25, 12.5 W
Horn Flares - 9000 Series
Code
LBC3403/16
LBC3404/16
LBC3405/16
LBC3406/16
XL3200 Line Array XLA “Xtended Line Array”
Description
Round Horn Flare without driver - 10” Suits 9000 series
Round Horn Flare without driver - 15” Suits 9000 series
Round Horn Flare without driver - 20” Suits 9000 series
Rectangular Horn Flare without driver - 15”x 8” Suits 9000 series
Drivers
Intrinsically Safe Horns - Explosion & Flame Proof
Code
Description
LBC3437/00 Explosion flameproof horn, 15 watts, 100v line with taps at 15,
7.5, 5, 4, 2, & 0.8 watts, black col
LBC3438/00 Explosion flameproof horn, 25 watts, 100v line with taps at 25,
12.5, 6, 4, 2 and 1 watt, 100dB SPL
Cabinet Loudspeakers Panel Loudspeakers - ABS
Code
Description
LBC3011/41 Panel loudspeaker designed for flush or surface mounting, 6
watts 100v line, taps at 6, 3, 1.5 and 0
LBC3011/51 Panel loudspeaker designed for flush or surface mounting, 6
watts 100v line, taps at 6, 3, 1.5 and 0
LBC3012/01 Surface mounting box for speaker LBC 3011/41 or 51
LBC3013/01 Flush mounting box for speaker LBC 3011/41 or 51
Description
Cabinet Loudspeakers - MDF
LB1-CW06-L
LB1-UW06-D
LB1-UW06-L
LB1-UW06V-D
LB1-UW06V-L
Description
LB2-UC15-D 2 way music cabinet 4” woofer & 0.5” HF. 15W 100v line (22.5W
at 8 ohms) taps at 15, 7.5,3.75 & 1.9
LB2-UC15-L 2 way music cabinet 4” woofer & 0.5” HF. 15W 100v line (22.5W
at 8 ohms) taps at 15, 7.5,3.75 & 1.9
LB2-UC30-D 2 way music cabinet 5” woofer & 0.5” HF. 30W 100v line (45W at
8 ohms) taps at 30, 15, 7.5 & 3.75 Wa
LB2-UC30-L 2 way music cabinet 5” woofer & 0.5” HF. 30W 100v line (45W at
8 ohms) taps at 30, 15, 7.5 & 3.75 Wa
Cabinet Loudspeakers - Metal Weatherproof
Code
LB1-UM20E-D
LB1-UM20E-L
LB1-UM50E-D
LB1-UM50E-L
Description
Sound Projectors Pendant Speakers (Spheres)
LB3-PC250 250W 100V line moulded plastic cabinet loudspeaker - 12” mid/
low, 1” HF
LB3-PC350 350W 100V line moulded plastic cabinet loudspeaker - 15” mid/
low, 1” HF
Sound Projectors
Description
12 watt bi-directional metal housing sound projector, IP55 rated,
ceiling or wall mounted. 100v line
LBC3432/02 20 watt uni-directional metal housing sound projector, IP66
rated, ceiling or wall mounted. 100v line
LP1-BC10E-1 10 watt bi-directional ABS sound projector, modern styling, IP65
rated, ceiling or wall mounted. 100 line
LP1-UC10E-1 10 watt uni-directional ABS sound projector, modern styling with
an omni style bracket, IP65 rated
LP1-UC20E-1 20 watt uni-directional ABS sound projector, modern styling with
an omni style bracket, IP65 rated
Hemi-Directional Loudspeaker
Code
LM1-MSB
Description
Hemi-directional suspension bracket for fixed mounting to
eradicate swinging.
LS1-OC100E-1 Hemi-directional loudspeaker - 100V line with taps at 100, 50
& 25W. Maximum 600m floor coverage.
CCS-CML900
CCS-CMS900
CCS-CU900
CCS-CUD900
CCS-CURD900
CCS-DL900
CCS-DS900
CCS-SC6900
CCS-SC10900
LBB3311/00
LBB3316/00
LBB3316/05
LBB3316/10
BOSCH-24
Description
10W pendent sphere, 100V line tx taps at 10, 5 & 2.5W, 89dB
SPL 1W/1m, 130Hz - 20kHz, off white
LS1-UC20E-1 20W pendent sphere, modern state-of-the-art styling, IP65
rated, 100v line with taps
Code
20W Aluminium Cabinet Loudspeaker, IP65 Charcoal
20W Aluminium Cabinet Loudspeaker, IP65 White
50W Aluminium Cabinet Loudspeaker, IP65 Charcoal
50W Aluminium Cabinet Loudspeaker, IP65 White
Description
Description
LA3-VARI-B
VARI-DIRECTIONAL BASE UNIT
LA3-VARI-BH VARI-DIRECTIONAL BASE UNIT WITH EXTENDED HIGH
FREQUENCY
LA3-VARI-CM VARI-DIRECTIONAL COBRANET MODULE
LA3-VARI-CS VARI-DIRECTIONAL CONFIGURATION SET
LA3-VARI-E
VARI-DIRECTIONAL EXTENSION UNIT
Conferencing and Discussion Systems - CCS 900
Cabinet Loudspeakers - Premium High Output
Code
Code
LBC3430/02
6 watt corner cabinet loudspeaker, MDF, 90dB
6 watt cabinet loudspeaker, MDF, 91dB SPL 1w/1m
6 watt cabinet loudspeaker, MDF, 91dB SPL 1w/1m
6 watt cabinet loudspeaker with volume control, 91dB
6 watt cabinet loudspeaker with volume control, 91dB
Cabinet Loudspeakers - Moulded ABS
Code
VARI-DIRECTIONAL - Digital Steerable Line Array
Code
Description
Description
LBC1259/00 Loudspeaker floorstand for XLA3200 range
LBC3200/00 XLA line array column, 30 watts, 100v line, taps at 30, 15 & 7.5
watts, 93dB SPL 1w/1m, silver colour
LBC3201/00 XLA line array column, 60 watts with taps at 60, 30 and 15 watts,
92dB SPL 1w/1m, silver colour
LBC3210/00 XLA line array column, 60 watts with taps at 60, 30 and 15 watts,
92dB SPL 1w/1m, 9kg, silver colour
LM1-CB
XLA carry bag for two floor stands
LBC3095/15
LBC3018/00 Metal cabinet loudspeaker. Surface or recess mounted, 6 watts
100v line with taps at 6, 3, 1.5 and 0
Code
Code
Code
Cabinet Loudspeaker - Metal Vandal resistant
Code
Description
LA1-UM20E Metal column loudspeaker IP65 rated, 100V line with taps at 20,
10, 5, 2. 5W as well as a 35W, 8 ohm
LA1-UM40E Metal column loudspeaker IP65 rated, 100V line with taps at 40,
20, 10, 5W as well as a 60W, 8 ohm s
August 2013
Description
Chairman’s microphone unit, long microphone
Chairman’s microphone unit, short microphone
Master control unit
Master control unit - Digital Anti Feedback
Master control unit - Digital Anti-Feedback & Rec.
Delegate’s unit, long microphone
Delegate’s unit, short microphone
Portable case for 1x control unit, 6x delegate units
Portable suitcase for 10 x discussion units
19” mounting brackets
System installation pack, (100 metres of CCS900 cable + 5
male + 5 female connectors)
Extension cable assembly, 5 metres
Extension cable assembly, 10 metres
Prices Ex. GST
