Control Panels
B5512/B4512
en
Owner's Manual
Control Panels
Table of Contents | en
3
Table of contents
1
Introduction
1.1
About documentation
2
Keypads overview
11
3
Points
14
3.1
What is a point?
14
3.2
Controlled points
14
3.3
24-hour points
15
4
Areas
16
4.1
What is an area?
16
5
Warning displays and tones
17
5.1
Keypad quiets for keystrokes
17
5.2
Silence the alarm tone
17
5.3
Entry delay tone and display
18
5.4
Exit delay tone and display
18
5.5
Keypress tones
19
6
How the system reports events
20
8
9
7
Alarm events
22
7.1
Priority of events
22
7.2
Fire alarms
22
7.3
Gas alarms
24
7.4
User and burglarly alarms
25
8
Trouble events
27
8.1
Fire trouble events
27
8.2
Gas trouble events
27
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
4
en | Table of Contents
Control Panels
8.3
User and burglary trouble events
28
8.4
System trouble events
28
9
Cleared events are not lost
29
10
View faulted or bypassed points
30
11
B930 keypad operation
31
11.1
B930 keys overview
32
11.2
B930 display overview
34
11.3
B930 status LEDs overview
35
12
B930 Menu tree
37
13
B930 On/Off menu
41
13.1
All On menu
41
13.2
Part On menu
46
13.3
Off menu
49
13.4
Extend Closing
52
13.5
Bypass
54
14
B930 Status menu
56
14.1
View Area Status
56
14.2
View Point Status
57
14.3
Send Status Report
58
15
B930 Actions menu
59
15.1
Reset
59
15.2
Outputs
61
15.3
Test
62
15.4
RPS
67
15.5
Go to area
71
15.6
Firmware
72
15.7
Service bypass
73
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Table of Contents | en
5
16
B930 Users menu
74
16.1
Change Passcode
74
16.2
Add User
76
16.3
Edit User
82
16.4
Delete User
85
87
17
B930 Settings menu
17.1
Watch Mode
87
17.2
Date/Time
89
17.3
Schedule (SKEDs)
91
17.4
Keypad
93
18
B930 Shortcuts menu
96
19
B930 Events menu
97
19.1
View Event Memory
97
19.2
Clear Event Memory
98
19.3
View Log
99
20
B920 keypad operation
100
20.1
B920 keys overview
101
20.2
B920 display overview
103
20.3
B920 status LEDs overview
104
21
B920 Menu tree
106
22
B920 On/Off menu
110
22.1
All On menu
110
22.2
Part On menu
115
22.3
Off menu
118
22.4
Extend Closing
120
22.5
Bypass menu
122
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
6
en | Table of Contents
Control Panels
23
B920 Status menu
124
23.1
View Area Status
124
23.2
View Point Status
125
23.3
Send Status Report
126
24
B920 Actions menu
127
24.1
Reset
127
24.2
Outputs
129
24.3
Test
130
24.4
RPS
136
24.5
Go to Area
139
24.6
Firmware
140
24.7
Service Bypass
141
25
B920 Users menu
142
25.1
Change Passcode
142
25.2
Add User
144
25.3
Edit User
150
25.4
Delete User
154
26
B920 Settings menu
155
26.1
Watch Mode
155
26.2
Date/Time
157
26.3
Schedule (SKEDs)
159
26.4
Keypad
161
27
B920 Shortcuts menu
164
28
B920 Events menu
165
28.1
View Event Memory
165
28.2
Clear Event Memory
166
28.3
View Log
167
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Table of Contents | en
7
29
Options
168
29.1
Two-man Rule
168
29.2
Early Ambush
169
29.3
Security system limitations
171
29.4
Cross points
173
29.5
Fire safety and evacuation
174
29.6
Multiple area systems
176
Glossary
184
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
8
1
en | Introduction
Control Panels
Introduction
Security systems help to secure life, property, and
investments against fire, theft, and bodily harm. The
keypad is an advanced digital device that offers a variety
of features not available with other systems. Its highly
visible, back-lit display and built-in sounder alert you to
a number of system events. Stylish design and ease-ofuse make it ideal for property protection.
Your security company can program the system to meet
your individual needs. Your property is given its own
English language description that appears in the display.
Contact your security company should problems be
encountered during testing of the system.
Your alarm company is:
Call before test:
______________________________________________________
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
1.1
Introduction | en
9
About documentation
This owner’s manual covers basic and advanced
functions. This manual is designed to be an everyday
type of reference for system users. The functions
described in this manual are programmed by your
security company. Some of them might not be included
in your system. Some of the functions covered require
you to enter your personal passcode.
This manual offers instructions for both the B930 and
B920 keypads.
Manual organization
–
Sections 2 through 10. Discuss security system
basics, including how to identify which keypad
model(s) you own.
–
Sections 11 through 19. Cover how to use the B930
keypad.
–
Sections 20 through 28. Cover how to use the B920
keypad.
–
Section 29. Explains optional features and security
system recommendations and limitations.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
10
en | Introduction
Control Panels
Manual conventions
Throughout this manual the # symbol refers to a variable
numerical quantity, such as the number of points to test
or exit delay time.
Text that shows on the keypad’s display appears in this
manual in italics, unless it is referring to a softkey. Keys
to press appear in this manual in brackets [ ]. When
keys are softkeys, the softkey name appears in bold in
brackets [ ].
Copyright
This document is the intellectual property of Bosch
Security Systems, Inc. and is protected by copyright. All
rights reserved.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
2
Keypads overview | en
11
Keypads overview
The B930 ATM Style Alphanumeric Keypad (SDI2)
features a bright five-line display with four ATM style
softkeys on either side of the display.
The B920 Two-line Alphanumeric Keypad (SDI2)
features a bright two line display and 8 function keys.
Both keypad models have user-adjustable volume and
display brightness, and a [HELP] key that opens ondisplay instructions.
The overview figure shows the B930 keypad in the top
half, and the B920 keypad in the bottom half. Take note
of which keypad you own so that you can read the
appropriate instructions.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
12
en | Keypads overview
Control Panels
1
2
Area 1
Off
A1 Lobby
Ready to turn on
7
<Shortcuts
3
PREV
HELP
1
2
GAS
GHI
GHI
3
DEF
DEF
6
MNO
MNO
5
JKL
JKL
8
TUV
TUV
ESC
ESC
0
PQRS
PQRS
3
NEXT
ABC
ABC
7
4
4
7
Menu>
WXYZ
WXYZ
9
CMD
CMD
5
6
1
3
10
A1 Lobby
Ready to turn on
4
GAS
9
8
2
2012.12 | 03 | F.01U.265.453
5
Owner's Manual
6
11
Bosch Security Systems, Inc.
Control Panels
Keypads overview | en
13
Descriptions of callouts for B930 and B920 overview
figure (previous page)
Callout
Description
Number
1
Alphanumeric display
2
HELP key
3
PREV and NEXT keys
4
Status LEDs
5
ESC key (Escape)
6
CMD key (Command)
7
Softkeys (B930 only)
8
Programmable function keys (B920 only)
9
ALL, PART, and BYPASS keys (B920 only)
10
ENTER key (B920 only)
11
MENU key (B920 only)
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
14
en | Points
Control Panels
3
Points
3.1
What is a point?
The term point refers to a detection device, or group of
devices connected to your security system. Points show
individually at the keypad with name. The point name
can describe a single door, motion sensor, smoke
detector, or an area such as Upstairs or Garage. There
are two basic types of points, controlled and 24-hour.
3.2
Controlled points
Controlled points respond to alarm conditions
depending upon whether the system is turned on
(armed) or turned off (disarmed). Controlled points are
programmed to respond instantly to alarm conditions or
to provide a delay for you to reach the keypad and turn
your system off. There are two types of controlled
points, part points and interior points.
3.2.1
Part points
Part points often include the exterior doors and
windows of the building (the perimeter of the building).
When you turn your system Part On, you only turn on
(arm) the part points.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
3.2.2
Points | en
15
Interior points
These points often include interior forms of burglary
detection devices, such as motion sensors or interior
doors, for example. When you turn your system All On,
you turn on (arm) both part points and interior points.
3.3
24-hour points
24-hour points are always on (armed), even when your
security system is turned off (disarmed). There are two
types of 24-hour points, fire points and non-fire points.
3.3.1
Fire points
Fire points exclusively monitor fire detection devices.
They are always on (armed) and cannot be turned off
(disarmed). You can clearly distinguish fire points from
other non-fire points at the keypad.
3.3.2
Non-Fire points
Non-fire 24-hour points are always on (armed) and you
cannot turn them off (disarm). Panic buttons, hold up
buttons, low temperature sensors, and water sensors
are examples of devices that are typically monitored by
non-fire 24-hour points.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
16
en | Areas
Control Panels
4
Areas
4.1
What is an area?
An area is a number of points that are grouped together
so that you can control them together as one unit. For
example, if a security system protected a building with
three sections – an office, a laboratory, and a cafeteria –
the points in each of those sections could be grouped
together as an area. With each section being its own
area in your security system, you can turn them on
(arm) and off (disarm) individually, in groups (office and
laboratory, for example), or all together.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
5
Warning displays and tones | en
17
Warning displays and tones
The keypads emit several distinct tones and shows text
to alert you to system events. Additional bells or sirens
may also be connected to your system. Bells or sirens
mounted on the exterior of the premises alert neighbors
to emergencies and provide an audible guide for police
and fire fighters.
The keypads have five status LEDs that indicate the
status of the system and some alarms. For more
information, refer to the status LED overview section for
your keypad.
5.1
Keypad quiets for keystrokes
Pressing any key on the keypad lights the keys and
quiets any warning tones. If you do not press another
key within 20 seconds, the keypad lights go out and the
warning tones resume.
5.2
Silence the alarm tone
The audible alarm sounds for a specific period of time
before it automatically shuts off. To silence the siren
before the time expires, simply enter your personal
passcode and press [Enter] or [ENTER].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
18
5.3
en | Warning displays and tones
Control Panels
Entry delay tone and display
When you enter a system that is on (armed) through a
point programmed for entry delay, the keypad emits the
entry delay tone as a reminder to turn off the security
system.
Failure to turn off your security system before the entry
delay time expires might sound the burglary tone and
could result in an alarm report being sent to your
security company.
Your security company programmed the entry delay
times for you:
My entry delay time is: _______________________________
5.4
Exit delay tone and display
When you first turn on (arm) your system (using your
keypad or keyfob), the keypad emits the exit delay tone,
shows Exit Now!, and counts down the exit delay time.
The tone pulsing rate increases during the last 10 sec of
exit time.
If you exit and re-enter before exit time expires, the exit
delay timer restarts the countdown. The restart only
applies once.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Warning displays and tones | en
19
Your security company programmed the exit delay times
for you:
My exit delay time is: _______________________________
5.5
Keypress tones
The keypad sounds the keypress tone (a short beep)
when you press any key. Use the Settings menu to
enable/disable the keypress tone.
5.5.1
Invalid entry (error tone)
The invalid entry tone follows the keypress tone when
the keypress completes a invalid entry.
Sometimes an entry is one keypress. Other times it is a
series of two or more keypresses.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
20
6
en | How the system reports events
Control Panels
How the system reports
events
Your security system makes repeated attempts to send
reports to your security company. In the event your
security system fails to communicate, the keypad
sounds the trouble tone and the keypad shows a
communication failed message. Notify your security
company of the communications failure.
If your telephone, internet, or cellular service is
interrupted, your security system cannot send reports
to the security company unless an alternate means of
transmitting the reports exists.
For telephone communication, your security company
can program your security system to automatically
disconnect the telephones when sending reports to the
security company. Once the report finishes, the security
system returns the telephones to normal operation
(check with your security company).
Consult with your installer to determine if your security
system is configured with a communicator delay. A
communicator delay aborts reports to the central
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
How the system reports events | en
21
station if the control panel is disarmed within 30 to 45
seconds after an burglary alarm is triggered. Note that
fire-type alarms are normally reported without a delay.
Consult with your installer to determine if your security
system is configured with a cancel feature. If you silence
a non-fire alarm before the alarm sound timer expires,
your security systems sends a cancel report to your
security company.
Consult with your installer to determine if your security
system is configured with a swinger shutdown feature
for non-fire alarms and trouble events. After a
programmable number of alarm or trouble events your
security system will automatically bypass points.
If your telephone service includes the call waiting
feature, your security company can configure your
security system so that call waiting does not interfere
with alarm reporting. Be sure to notify your security
company if you enable call waiting. A system that is
configured for call waiting cannot report alarms
correctly when call waiting is disabled. If you disable
call waiting after your system has been configured for it,
be sure to notify your security company.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
22
7
en | Alarm events
Control Panels
Alarm events
The system produces several types of events.
7.1
Priority of events
If more than one event occurs, the system sorts them
into one of six groups. The groups are (highest priority
first): Fire Alarms, Gas Alarms, User Alarms, Burglary
Alarms, Fire Troubles, and Non-Fire Troubles. The group
with the highest priority scrolls first. The descriptions
and instructions that follow describe the tones and
displays for each group, and explain how to silence the
tones.
7.2
Fire alarms
Fire alarms are the highest priority events. When a fire
point activates, the keypad emits a unique pulsating fire
tone (━━━ ━━━ ━━━).
Evacuate all occupants and investigate for smoke or fire.
Ensure that all occupants know the difference between
the steady burglary tone (━━━━━━━━━━━), the pulsating
gas tone (━ ━ ━ ━
━━━━
━ ━ ━ ━), and the pulsating
fire tone (━━━ ━━━ ━━━). The tone sounds for the
duration set by your security company.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Alarm events | en
23
The display shows the point text of the first point that
went into fire alarm. Press [NEXT] to manually show
additional points (if any) that went into alarm. Events
scroll from the oldest to the newest.
7.2.1
Silence fire alarms
Enter your passcode to silence fire alarms. If the system
is on (armed), silencing the fire alarm also turns the
system off. The system now shows Alarm Silenced and
then the number of points in alarm and the name of all
the points in alarm, in the order of occurrence.
Your security company can program your system so that
users cannot silence some fire alarms until the fire
event clears. Your security company can program the
system so that users cannot silence some fire alarms
until the fire point has restored to normal. The Alarm
Silenced message continues to scroll as a reminder that
you can still view the points in alarm by using the View
Event Memory menu option.
If the fire point is still in alarm (faulted) then the point
goes to trouble after silencing. Some fire points need to
be reset. You cannot clear fire troubles from the display.
When fire points return to normal (trouble conditions
are corrected), the security system automatically clears
the fire troubles from the display.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
24
en | Alarm events
7.3
Control Panels
Gas alarms
Gas alarms are the second highest priority events. When
a gas point activates, the keypad emits a unique
pulsating gas alarm (━ ━ ━ ━
━━━━
━ ━ ━ ━).
Evacuate all occupants and investigate for gas. . Ensure
that all occupants know the difference between the
burglary tone (━━━━━━━━━━━), the pulsating gas tone
(━ ━ ━ ━
━━━━
━ ━ ━ ━), and the pulsating fire tone
(━━━ ━━━ ━━━). The tone sounds for the duration set by
your security company.
The display shows the point text of the first point that
went into gas alarm. Press [NEXT] to manually show
additional points (if any) that went into alarm. Events
scroll from the oldest to the newest.
7.3.1
Silence gas alarms
Enter your passcode to silence gas alarms. If the system
is on (armed), silencing the gas alarm also turns the
security system off (disarms the system). The system
now shows Alarm Silenced and then the number of
points in alarm and the name of all the points in alarm,
in the order of occurrence.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Alarm events | en
25
Your security company can program the system so that
users cannot silence some gas alarms until the gas
event clears. Enter your passcode to clear the scrolling
point text from the display. The Alarm Silenced message
continues to scroll as a reminder that you can still view
the text of the points in alarm by using the View Event
Memory menu option.
If the gas point is still in alarm (faulted) then the point
goes to trouble after silencing. Some gas points need to
be reset. You cannot clear gas troubles from the display.
When gas points return to normal (trouble conditions
are corrected), the security system automatically clears
the fire trouble from the display.
7.4
User and burglarly alarms
User alarms have the third priority. User alarms are user
initiated alarms that include hold-up, panic, and medical
alarms, for example. Medical alarms are not available on
UL listed systems. A steady tone (━━━━━━━━━━━) sounds
for the time set by your security company.
Burglary alarms are the forth priority. When a burglary
point activates while the system is on (armed), the
keypad emits a steady burglary tone (━━━━━━━━━━━).
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
26
en | Alarm events
Control Panels
Ensure that all occupants know the difference between
the steady user or burglary tone (━━━━━━━━━━━), the
pulsating gas tone (━ ━ ━ ━
━━━━
━ ━ ━ ━), and the
pulsating fire tone (━━━ ━━━ ━━━). The tone sounds for
the time set by your security company.
7.4.1
Silence user and burglar alarms
The audible alarm sounds for a specific period of time
before it automatically shuts off. To silence user and
burglary alarms before the time expires, simply enter
your personal passcode and press [Enter] or [ENTER].
Notice!
i
For silent alarms, such as hold up alarms, no audible
alarm sounds.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Trouble events | en
8
Trouble events
8.1
Fire trouble events
27
When a fire trouble occurs, the keypad emits the
trouble tone (three tones followed by a pause
repeated). The system shows the number of fire points
with troubles and the name for each point in trouble.
8.1.1
Silence fire troubles
Press [Silence] or [ENTER] to silence the trouble tone.
After you silence the trouble, the text of the fire point in
trouble continues to show on the display. Press [NEXT]
to scroll through the trouble text. Events scroll from
oldest to newest. You cannot clear fire troubles from
the display until the trouble condition is cleared (the
point is normal).
8.2
Gas trouble events
When a gas trouble occurs, the keypad emits the
trouble tone (three tones followed by a pause
repeated). The system shows the number of gas points
with troubles and the name for each point in trouble.
8.2.1
Silence gas troubles
Press [Silence] or [ENTER] to silence the trouble tone.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
28
en | Trouble events
8.3
Control Panels
User and burglary trouble events
The security company can program a keypad to emit the
trouble tone (three tones followed by a pause
repeated), when a user or burglary trouble event occurs.
If the system is on, the display shows the number of
points with troubles and the name for each point.
8.3.1
Silence user and burglary trouble events
Press [Silence] or [ENTER] to silence the trouble tone.
8.3.2
View user and burglary trouble events
After a user enters a passcode, the name of the point in
trouble continues to scroll through the display. Press
[NEXT] to scroll text manually. Events scroll from oldest
to newest.
8.4
System trouble events
Examples of system trouble displays include Service AC
Failure and Service Battery Low. These displays appear
on all keypads in the system. All system trouble displays
begin with SERV or Service. Press [Silence] or [ENTER]
to silence the trouble tone. but the Service text clears
only after the faulted condition is corrected.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
9
Cleared events are not lost | en
29
Cleared events are not lost
If you clear the alarms and troubles from the display,
you can still view all the events.
Using the events menu you can:
–
Select the Event Memory menu to view the alarm
and trouble events that occurred since the last time
the system was turned on (armed). Turning the
system on (arming) clears event memory.
–
Select the View Log menu to view all events in your
system’s event log.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
30
en | View faulted or bypassed points
10
Control Panels
View faulted or bypassed
points
To turn on (arm) the system, all the doors and windows
in the system must be in the normal (not faulted)
condition. Viewing the faulted points helps you find
faulted points and correct them so arming is possible.
The keypad offers two ways of displaying faulted and
bypassed point information. The first causes the faulted
or bypassed point information to scroll automatically
through the display. The second allows you to manually
scroll through each individual point description.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
11
B930 keypad operation | en
31
B930 keypad operation
Your security system provides quick access to functions
through the keypad menus.
To access menus using a B930, press [Menu]. Functions
programmed by your security company show on the
display as menu items, each with its own softkey. To
exit a menu and return to the previous level, press
[ESC]. To exit and return to idle text from any level of
the menu structure, press and hold [ESC].
The keypad has a Shortcuts menu to quickly access
functions you use most. Your security company
programmed these Shortcuts for you. To access
Shortcuts using a B930, press [Shortcuts].
You can also initiate a select number of functions by
pressing [CMD] key and one or two additional keys.
Refer to the section on the Command menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
32
en | B930 keypad operation
Control Panels
11.1 B930 keys overview
Each B930 keypad has 10 numeric keys, one function
[CMD] key, keys for previous, next, escape, and help,
and eight softkeys. When pressed, keys enable keypad
backlighting and emit a muted beep. Use the eight
softkeys to select a menu and associated functions.
11.1.1 B930 keys descriptions
Softkeys
Use softkeys to make a selection when the display
shows an arrow pointing from a menu option to the
softkey. The idle text display shows the Menu and
Shortcuts softkeys. The Shortcuts menu is the quickest
way to access the functions you use most.
ESC
The [ESC] (Escape) key has two uses. First, use the
[ESC] (Escape) key to exit from menus and functions.
Also, use the key as a Backspace when you enter names
and numbers.
HELP
Use the [HELP] key to open the keypad’s on-display
Help. Press [ESC] to exit help when you finish viewing.
PREV and NEXT
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 keypad operation | en
33
Use the [PREV] and [NEXT] keys to scroll through
menus or menu selections.
CMD
Use the [CMD] key in combination with one or two
number keys to perform select functions.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
34
en | B930 keypad operation
Control Panels
11.2 B930 display overview
The B930 keypad uses words, numbers, and symbols to
show the status of the security system. When several
events occur, the keypad shows each event in order of
priority. The display shows five lines, 21 characters per
line.
The keypad has a bright two-line by 20-character liquid
crystal display (LCD). When names are more than 18
characters, the text scrolls horizontally, similar to the
way a stock ticker scrolls.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 keypad operation | en
35
11.3 B930 status LEDs overview
The status LEDs on keypads provide a quick visual
reference for you to see how your system is operating.
Ready to arm: The green checkmark LED indicates
whether the system is ready to turn on (arm).
–
ON Steady. All points are normal and the system is
ready to turn on.
–
OFF. One or more points are faulted, and the system
is not ready to turn on.
On (armed): The red lock LED indicates whether the
system is on (armed).
–
–
ON Steady. All areas are on with no alarms.
Flashing. All areas are armed, and there is an active
alarm.
–
OFF. One or more areas is off.
Trouble. The yellow caution LED lights when a trouble
condition exists.
–
ON Steady. There is a system, device, or point
trouble.
–
OFF. There are no system, device, or point troubles.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
36
en | B930 keypad operation
Control Panels
GAS: The blue GAS LED indicates a gas alarm.
–
Flashing. An area has a gas alarm. You should leave
the premises immediately when there is a gas alarm.
–
OFF. A gas alarm does not exist within the keypad’s
scope.
Power: The blue power plug LED indicates whether the
control panel has AC power.
–
ON Steady. The AC (mains) power to the control
panel is present.
–
Flashing. AC (mains) power to the control panel is
not present and the control panel is operating from
the battery.
–
OFF. There is no power to the control panel.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
12
B930 Menu tree | en
37
B930 Menu tree
The B930 offers an easy-to-use menu tree structure. To
access the Menu tree, press [Menu]. The Main menu
shows first. Each menu selection has its own softkey.
Press the softkey to choose that option.
At each Menu tree level, the menu options are
associated with a number based upon the order in
which the menu option is shown. You can type the
number for the desired menu, if you know it.
The Menu tree figure on the next page shows the Menu
structure and the numbers associated for each menu.
With associated numbers, you can press a number key
instead of using the softkeys.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
38
en | B930 Menu tree
Control Panels
B930 Menu tree
Main Menu
Menu>
[1]
[2]
[3]
[4]
[1]
[2]
[3]
[4]
Actions Menu
<Reset
Go to Area> [5]
<Outputs Firmware> [6]
<Test
Srv Bypass> [7]
<RPS
[1]
[2]
[3]
[4]
Users Menu
<Change Passcode
<Add User
<Edit User
<Delete User
[1]
[2]
[3]
[4]
Settings> [5]
Shortcuts> [6] *
Events>
[7]
Events Menu
[1] <View Event Memory
[2] <Clear Event Memory
[3] <View Log
[1]
[2]
[3]
[4]
Edit User Menu
<Passcode Language> [5]
<Name
<Level
<Keyfob
[1]
[2]
[3]
[4]
Add User Menu
<Passcode Language> [5]
<Name
<Level
<Keyfob
RPS Menu
[1] <Answer
[2] <Network Originate
[3] <Call via Phone
<On/Off
<Status
<Actions
<Users
Test Menu
<Walk Test
<Test Report
<Revisions
<Notification Test
[1]
[2]
[3]
[4]
Settings Menu
<Watch Mode
<Date/Time
<Schedule
<Keypad
Keypad Menu
[1] <Brightness
[2] <Volume
[3] <Keypress
Date/Time Menu
[1] <Set Date
[2] <Set Time
[3] <Show Time
Status Menu
[1] <View Area Status
[2] <View Point Status
[3] <Send Status Report
[1]
[2]
[3]
[4]
On/Off Menu
<All On
Bypass> [5]
<Part On
<Off
<Extend Close
Off Menu
[1] <Turn Off
[2] <Turn Off Select Area
Part On Menu
[1] <Part On Delay
[2] <Part On Instant
[3] <Part On Select Area
All On Menu
[1] <All On Delay
[2] <All On Instant
[3] <All On Select Area
* Your security company programmed the Shortcuts for you.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Menu tree | en
39
Commands
Commands resides outside of the Menu tree. You can
initiate a limited number of functions with the [CMD]
key plus the one or two digit command.
If you know the command number, press [CMD] and
then the one or two digit command.
Review the available commands in the table on the next
page
Notice!
i
With B920 and B930 keypads, you can use [PREV] or
[NEXT] to move through the list of commands, and
press [Enter] or [ENTER] when viewing the desired
command.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
40
en | B930 Menu tree
Control Panels
Function
Command
All on
CMD 1
All On, Instant
CMD 1 1
Part On, Instant
CMD 2
Part On
CMD 3
Watch
CMD 6
See Alarms
CMD 4 0
Reset Sensors
CMD 4 7
Extend Close
CMD 5 1
Bypass
CMD 0
Unbypass
CMD 0 0
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
13
B930 On/Off menu | en
41
B930 On/Off menu
Use the On/Off menu to turn areas All or Part On, to
turn areas off, to extend closing time, or to bypass
points.
When you turn on (arm) your security system, there is
an exit delay that gives you time to leave the area
without sounding the burlary tone. When you enter a
security system that is turned on (armed), there is an
entry delay that gives you time to turn off (disarm) the
system.
13.1 All On menu
Use the On/Off menu to turn areas All or Part On, to
turn areas off, to extend closing time, or to bypass
points.
When you turn on (arm) your security system, there is
an exit delay that gives you time to leave the area
without sounding the burlary tone. When you enter a
security system that is turned on (armed), there is an
entry delay that gives you time to turn off (disarm) the
system.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
42
en | B930 On/Off menu
Control Panels
13.1.1 All On
Turning an area All On turns on all points in the area and
provides entry and exit delay. For example, you can turn
on the area and leave through a door (within exit delay
time) without creating an alarm event. When you turn
the area All On, the display shows how many seconds of
exit delay time remain to exit the protected area. Leave
before the exit delay time expires.
Leaving after exit delay expires causes entry delay to
start. It may also cause an alarm on an interior device.
Enter your passcode to turn off the system.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
43
Turning areas All On:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [All On] to open the All On menu option.
4. Press [All On Delay] to open the All On Delay menu
option.
5. Enter your passcode and press [Enter]. The keypad
shows Exit Now! and sounds during the exit delay.
6. Exit the area or enter your passcode again to stop
the system from turning on. If you turn your system
All On and don't exit, the system automatically
switches to Part On.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
44
en | B930 On/Off menu
Control Panels
13.1.2 All On Instant
Turning an area All On Instant turns on all points with
no entry or exit delay. When areas are All On Instant,
faulting any point (opening a door for example) creates
an alarm event immediately.
Turning areas All On Instant:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [All On] to open the All On menu option.
4. Press [All On Instant] to open the All On Instant
menu option.
5. Enter your passcode and press [Enter]. The keypad
shows All On.
6. To turn off the security system, enter your passcode
and press [Enter].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
45
13.1.3 Select Area
Use All On Select to choose individual areas to turn All
On or All On Instant. You choose areas from a list of the
areas in which you have authority.
Turning on a specific area:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [All On] to open the All On menu option.
4. Press [All On Select] to open the All On Select
menu option.
5. Enter your passcode and press [Enter].
6. Press either [On Delay] or [Instant]. The keypad
responds based upon your selection.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
46
en | B930 On/Off menu
Control Panels
13.2 Part On menu
Use the Part On menu to turn areas Part On. Turning an
area Part On means to turn on only some of the points,
and thus part of the system. For example, your security
company might configure your system so that when you
use the Part On function, only the exterior doors and
windows turn on, whereas interior motion sensors do
not turn on.
13.2.1 Part On
Turning an area Part On turns on some points, or part of
the system, in the area and provides entry and exit
delay. For example, you can turn on the area and leave
through a door (within exit delay time) without creating
an alarm event.
Turning the perimeter on with an exit delay:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Part On] to open the Part On menu option.
4. Press [Part On Delay] to open the Part On Delay
menu option.
5. Enter your passcode and press [Enter]. The keypad
shows Part On Delay.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
47
13.2.2 Part On Instant
Turning an area Part On turns on some points, or part of
the system, in the area with no entry or exit delay. When
the area is Part On Instant, faulting a Part On point
(opening a door for example) creates an alarm event
immediately.
Turning the system Part On without delay:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Part On] to open the Part On menu option.
4. Press [Part On Instant] to open the Part On Instant
menu option.
5. Enter your passcode and press [Enter]. The keypad
shows Part On Instant.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
48
en | B930 On/Off menu
Control Panels
13.2.3 Select Area
Use Part On Select to choose individual areas to turn
Part On or Part On Instant. You choose areas from a list
of the areas in which you have authority.
Turning individual areas Part On:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Part On] to open the Part On menu option.
4. Press [Part On Select] to open the Part On Select
menu option.
5. Enter your passcode and press [Enter].
6. Press either [On Delay] or [On Instant]. The keypad
responds based upon your selection.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
49
13.3 Off menu
You can turn areas off simply by entering your passcode
or by using the Off menu. With either option, you turn
off all areas in which you have authority.
You must enter your personal passcode and enter
through a designated entry door to prevent an instant
alarm condition. Opening the door starts entry delay
time and the keypad emits a pulsing “beep” tone to
remind you to turn the system off. Enter your passcode
before the entry delay time expires.
If you enter through the wrong door or fail to turn off
(disarm) before the entry delay time expires, an alarm
occurs. If this happens, silence the alarm (by entering
your personal passcode and pressing [Enter]) and call
your security company to notify them that you do not
have an emergency situation.
Turning off the security system (disarm) with your
passcode:
1. Enter your personal passcode.
2. Press [Enter] within 8 sec of entering your
passcode. The display returns to idle text.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
50
en | B930 On/Off menu
Control Panels
13.3.1 Turn Off
You can use the Turn Off menu to turn off all areas in
which you have authority.
Turning off areas:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Off] to open the Off menu option.
4. Press [Turn Off] to turn off.
5. Enter your passcode and press [Enter]. The display
returns to idle text.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
51
13.3.2 Turn Off Select
Use Turn Off Select to choose individual areas to turn
off. You choose areas from a list of the areas in which
you have authority.
Turning off a specific area:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Off] to open the Off menu option.
4. Press [Turn Off Select Area] to open the Turn Off
Select menu option.
5. Press either [Off Delay] or [Off Instant]. The
keypad responds based upon your selection.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
52
en | B930 On/Off menu
Control Panels
13.4 Extend Closing
Your security company might program your system to
expect you to turn on (arm) within a closing window. A
closing window is a duration of time programmed by
your security company. Your security company sets a
fixed length of time for the closing window. Additionally,
your security company might program your system to
automatically turn on (arm) at the end of the window.
Use the Extend Close Time option when you need to
stay later than the scheduled close time. If you do not
extend the Close Time and do not turn the system on
before the scheduled time, the system creates a Late to
Close event.
At the beginning of the closing window, the keypad
beeps and shows Please Close Now to remind you to
turn on (arm) your system. It remains in the display until
you turn on the system, the close window ends, or you
extend closing. Alarm or trouble messages replace this
message in the event of an alarm or trouble condition. If
the alarm or trouble condition clears before the end of
the close window Please Close Now returns to the
keypad display.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
53
Pressing [ESC] silences the beep and clears the
message for 10 minutes. If you have not turned your
system on (armed) or extended closing, the Please Close
Now message and beep reappear after 10 minutes. To
extend the window, enter the new time at which you
would like the reminder tone to begin. This time is the
new beginning of the closing window.
When you hear the warning, you can:
–
Leave before the end of the closing window by
pressing [ESC] to silence the signal, turning on the
system, and leaving.
–
Stay past the scheduled end of the closing window,
by using this function to extend the closing window.
To extend closing:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Extend Close] to open the Extend Close
menu option.
4. Enter your passcode and press [Enter].
Notice!
i
You cannot extend the window across the midnight
boundary. The system cannot arm if points are off-normal.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
54
en | B930 On/Off menu
Control Panels
13.5 Bypass
Use the Bypass menu to temporarily take points out of
the security system, and enter them back into the
system. Bypassed points do not create alarm or trouble
events, do not detect intruders, and cannot send any
reports. For example, to leave a window open and turn
the system on, you bypass the window point and then
turn the system on.
13.5.1 Bypass Points
You can bypass points when an area is turned off
(disarmed). Points remain bypassed until you unbypass
them or some points return when the area is turned off
(disarmed). Use point bypassing with discretion:
bypassing a point reduces the level of security.
Bypassing a point:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Bypass] to open the Bypass menu option.
4. Press [Bypass Points] to open the Bypass Points
menu option.
5. Select a point to bypass.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 On/Off menu | en
55
13.5.2 Unbypass Points
Unbypassing a point returns a bypassed point to the
security system so that it can once again respond to
trouble and alarm conditions.
Unbypassing a point:
1. Press [Menu] to open the Main menu.
2. Press [On/Off] to open the On/Off menu option.
3. Press [Bypass] to open the Bypass menu option.
4. Press [Unbypass Points] to open the Unbypass
Points menu option.
5. Select a point to unbypass.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
56
en | B930 Status menu
14
Control Panels
B930 Status menu
Use the Status menu to see area or point status, or to
send a status report.
14.1 View Area Status
Area Status shows the on/off status for areas in which
you have authority.
Viewing area status:
1. Press [Menu] to open the Main menu.
2. Press [Status] to open the Status menu option.
3. Press [View Area Status] to open the View Area
Status menu option.
4. Enter your passcode and press [Enter]. The display
shows the status of each area. For example A-1: Off.
5. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Status menu | en
57
14.2 View Point Status
The View Point Status feature shows the status (normal,
open, or short) for all points in the areas in which you
have authority.
Viewing point status:
1. Press [Menu] to open the Main menu.
2. Press [Status] to open the Status menu option.
3. Press [View Point Status] to open the View Point
Status menu option.
4. Enter your passcode and press [Enter].
5. The display shows the number of points in the
system. Use [PREV] or [NEXT] to scroll through the
list of points and each point’s status.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
58
en | B930 Status menu
Control Panels
14.3 Send Status Report
The Send Status Report feature sends a complete
system status report to your security monitoring
company. Status reports can alert them to potential
problems.
Sending a status report:
1. Press [Menu] to open the Main menu.
2. Press [Status] to open the Status menu option.
3. Press [Send Status Report] to open the Send
Status Report menu option.
4. Enter your passcode and press [Enter]. The control
panel sends a report to your security company.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
15
B930 Actions menu | en
59
B930 Actions menu
Use the Actions menu to reset sensors, change outputs,
see the test menu, see the RPS menu, go to an area,
update system firmware, or to view service bypassed
points.
15.1 Reset
Detection devices, such as smoke detectors and shock
sensors, might require a reset action before they return
to normal operation. This function momentarily removes
power from these devices to reset them.
Resetting sensors:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Reset] to open the Reset menu option.
4. Enter your passcode and press [Enter]. The display
shows Sensors resetting for approximately 3 seconds
and then goes blank before returning to idle
disarmed text.
If you enter this function and the detector or sensor
resets momentarily, but then returns to a faulted
condition, the conditions causing the activation may still
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
60
en | B930 Actions menu
Control Panels
be present or the detector may be faulty. Check to be
certain that there is no smoke, fire, or other danger
present.
If you cannot reset the detector or sensor, contact your
security company.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
61
15.2 Outputs
Your security company programs outputs for automatic
control and/or keypad control of devices such as
premises lighting or entry gates. An output is a device
that is controlled by the security system. Contact your
security company for further information regarding the
use of outputs in your security system.
Use this function to select outputs to turn on or off.
Outputs on your security system can control other
systems, lighting for example.
Your security system is not UL listed for access control.
Turning outputs on and off:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Outputs] to open the Outputs menu option.
4. Enter your passcode and press [Enter].
5. Use [NEXT] to select the desired output value, or
use the number keys to enter the value.
6. Press [Turn On] or [Turn Off].
7. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
62
en | B930 Actions menu
Control Panels
15.3 Test
Use the Test menu to walk test your system, send test
reports, or to review system revision information on the
keypad display.
15.3.1 Walk Test
A walk test allows you to test the sensors, keypads,
sounders, and other devices in your system without
creating alarm events. You can review untested points
at the keypad to help pinpoint any problems.
You cannot turn on the security system while in the walk
test mode. Also, the security system does not create
alarm events for points included in the walk test. Points
not included create alarm events. For example, faulting
a fire point during an intrusion walk test creates a fire
alarm event.
Beginning the walk test activates the burglary tone for 2
seconds. A battery test also begins. A successful battery
test ends in four minutes (the walk test continues). If
the security system determines there is a low battery, it
generates a low battery event and continues the test. If
the battery is determined to be very low, the system
creates a missing battery event and ends the battery
test immediately.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
B930 Actions menu | en
Control Panels
63
To test individual detection devices, simply activate
sensors and open protected doors and windows one-ata-time. As you fault each detection device, the keypad
from which you initiated the test emits a brief tone, and
for 60 seconds the display indicates that the point was
tested. The tone and display verify that each detection
device is working properly. Keypads within the area’s
scope from which you did not initiate the walk test
show Walk test in progress during the testing.
Performing a walk test:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Test] to open the Test menu option.
4. Press [Walk Test] to open the Walk Test menu
option.
5. Press [Fire], [Intrusion], [Service], or [Invisible]
based upon the type of walk test you wish to
perform.
6. The keypad shows the number of points remaining
to test. Press [View Untested Points].
7. Use [NEXT] to go through your desired point and
view the status of that point.
8. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
64
en | B930 Actions menu
Control Panels
Automatic termination
The Walk Test automatically ends after 20 minutes of no
test activity. The keypad sounds during the last 5
minutes of the test.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
65
15.3.2 Send Test Report
This function tests the communication link between
your security system and your security company. It is an
important part of maintaining a high level of security for
your property.
Sending a test report:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Test] to open the Test menu option.
4. Press [Send Test Report] to open the Send Test
Report menu option.
5. Enter your passcode and press [Enter]. The system
sends a test report.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
66
en | B930 Actions menu
Control Panels
15.3.3 Revisions
Use this function to view the current reversion of your
control panel firmware.
Viewing the current revision of your system (control
panel):
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Test] to open the Test menu option.
4. Press [Revisions] to open the Revisions menu
option.
5. Enter your passcode and press [Enter]. The current
revision information shows on the display.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
67
15.3.4 Notification Test
Use this menu to test the security system’s ability to
send personal notification messages to the destination
path designated by your security company.
Testing notifications:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Test] to open the Test menu option.
4. Press [Notification Test] to open the Notification
Test menu option.
5. The keypad shows the first properly configured
notification path. Use [NEXT] to go to the desired
notification path, and then press [Enter]. The
control panel sends a test notification, and then
returns to idle text.
15.4 RPS
Use the RPS menu for connection to Remote
Programming Software (RPS). Your security company
uses RPS to configure and service your security system.
RPS is intended for use by professional or licensed
installers only.
15.4.1 Answer
Use the Answer option to answer the phone (pick up
the phone line) to connect to RPS.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
68
en | B930 Actions menu
Control Panels
Using the Answer menu option to answer an incoming
call from RPS:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [RPS] to open the RPS menu option.
4. Press [Answer] to open the Answer menu option.
5. Enter your passcode and press [Enter].
The keypad shows RPS is connecting…. and then returns
to idle text.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
69
15.4.2 Network Originate
Use this function to originate an RPS session using an IP
(internet) connection.
Connecting to RPS using an internet connection:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [RPS] to open the RPS menu option.
4. Press [Network Originate] to open the Network
Originate menu option.
5. To use the programmed port number, press
[Configured Port]. The connection progress begins.
6. If you wish to change the port number before
connecting, press [Change Port]. The [ESC] key
acts as a backspace key. Press [ESC] to delete the
characters, and then enter the new characters.
Press [Enter]. The connection progress begins.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
70
en | B930 Actions menu
Control Panels
15.4.3 Call Via Phone
Use this function to call RPS using the phone line.
Connecting to RPS via the phone line:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [RPS] to open the RPS menu option.
4. Press [Call Via Phone] to open the Call Via phone
menu option.
5. Enter your passcode, press [Enter].The connection
progress begins.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
71
15.5 Go to area
With the Go to Area function you can perform tasks in
an area other than the one you’re in without having to
physically go to that area. For example, using the
keypad in the office area, you could 'go' to the loading
area. You select the area from a list of areas in which
you have authority.
Once you 'go’ to an area, you can perform tasks you
have authority for in that area. To 'leave' an area press
[ESC].
Using Go to Area:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Go to Area] to open the Go to Area menu
option.
4. Enter your passcode and press [Enter].
5. Use [NEXT] to go to the area you wish to enter, and
then press [Go to Area].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
72
en | B930 Actions menu
Control Panels
15.6 Firmware
Your security company might have configured your
security system to require your authorization before
system firmware can be updated. Use this action to
provide authorization at the request of your security
company. Local authorization is required for UL listed
systems.
Authorizing a firmware update:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Firmware] to open the Firmware menu
option.
4. Enter your passcode and press [Enter].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Actions menu | en
73
15.7 Service bypass
To facilitate system maintenance for service personnel,
your security system comes with a special point bypass
option to remove any point from service. Bypassed
points are not protected. Use this menu to view
bypassed points.
Viewing points in Service Bypass:
1. Press [Menu] to open the Main menu.
2. Press [Actions] to open the Actions menu option.
3. Press [Srv Bypass] to open the Service Bypass
menu option. The keypad shows any points in
service bypass.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
74
en | B930 Users menu
16
Control Panels
B930 Users menu
Use the Users menu to change your own passcode, add
new users, edit existing users, or to delete users.
16.1 Change Passcode
Use the Change Passcode function to change your
personal passcode.
Before you begin, consider the following:
–
Choose a new passcode three to six digits long. If
you choose a passcode with the same digit in
consecutive order (for example “33” in 334697),
take care when entering it.
–
To avoid conflicting with other passcodes and
duress codes, your security system does not let you
change to existing passcodes or passcodes that are
within plus or minus 2 of an existing passcode. For
example, if 1234 were an existing code, your
security system would not let you change your code
to 1232, 1233, 1234, 1235, or 1236.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Users menu | en
75
Changing your passcode:
1. Press [Menu] to open the Main menu.
2. Press [User] to open the Users menu option.
3. Press [Change Passcode] to open the Change
Passcode menu option.
4. Enter your current passcode and press [Enter].
5. Enter your new passcode and press [Enter].
6. Enter your new passcode again and press [Enter].
7. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
76
en | B930 Users menu
Control Panels
16.2 Add User
Use the Add User function to add a passcode to your
security system. Before you add the user, you need to
know which user numbers are available, the authority
level you want to assign to the new passcode, and the
areas in which it will be valid.
The two-digit user numbers identify users in reports
transmitted from your security system. The authority
level determines what system functions the passcode
can access. The area number identifies which parts of
your security system the passcode can access. Contact
your security company if you don’t know what user
numbers, authority levels, or areas are available.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Users menu | en
77
Before you begin:
–
Do not try to add passcodes without knowing the
available user numbers. These are two-digit
numbers, not to be confused with passcodes, that
identify users at your security company.
–
Choose a new passcode three to six digits long. If
you choose a passcode with the same digit in
consecutive order (for example “33” in 334697),
take care when entering it.
–
To avoid conflicting with other passcodes and
duress codes, your security system does not let you
add passcodes that are within plus or minus 2 of an
existing passcode. For example, if 1234 were an
existing code, your system would not let you change
your code to 1232, 1233, 1235, or 1236.
–
Choose an authority level for each area. Leaving the
authority level for an area blank by pressing [Enter]
or [ENTER] without making an entry, denies the
passcode access to that area.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
78
en | B930 Users menu
Control Panels
Adding a user:
1. Press [Menu] to open the Main menu.
2. Press [User] to open the Users menu option.
3. Press [Add User] to open the Add User menu
option.
4. Enter your passcode and press [Enter].
5. Enter the number (1 – 50) for the user you wish to
add, and press [Enter].
Configuring the user’s passcode:
1. Press [Passcode] to set the passcode.
2. Press [Enter] to continue.
3. Enter the user’s passcode and press [Enter].
4. Enter the passcode again and press [Enter]. The
keypad shows Passcode changed and then returns to
the previous menu.
Configuring the user’s name:
1. Press [Name] to configure the user’s name.
2. The [ESC] key acts as a backspace key. Press [ESC]
to delete the characters. Press a number key
repeatedly to scroll through the number and letters
shown on the key. To enter a space, press [0][0]. To
capitalize a letter, press [CMD] before you enter the
letter. For caps lock, press [CMD][CMD]. To remove
caps lock, press [CMD][CMD][CMD].
3. Press [Enter] to save the name. The keypad returns
to the previous menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Users menu | en
79
Configuring the user’s level:
1. Press [Level] to assign an authority level.
2. Press [Enter] to continue.
3. Press [Yes] to change the default authority level for
area 1.
4. Enter the authority level number (1 – 14) you wish
to apply to the user and press [Enter]. The keypad
shows Level configured and returns to the previous
menu.
5. If your security system has more than one area, use
[NEXT] and the previous two steps to set the levels
for the additional areas.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
80
en | B930 Users menu
Control Panels
Configuring a RADION keyfob* or an Inovonics
Transmitter for the user:
1. Press [Keyfob] to assign a RADION keyfob* or an
Inovonics Transmitter to the user.
2. To manually enter the RFID, if desired, press [Enter
RFID] to add the RFID. Otherwise, the keypad
automatically learns the RFID into the security
system when you add a RADION keyfob* or an
Inovonics Transmitter.
3. Press [Enter] to continue.
4. Enter the RFID.
5. Press [Save] to save the RFID and return to the
previous menu.
6. Press [Add] to add a RADION keyfob* or an
Inovonics Transmitter.
7. Press [Add] to continue.
8. On a RADION keyfob*, press any button on the
keyfob. On an Inovonics Transmitter, open the
transmitter and press the RESET button, per the
manufacturer’s instructions. The keypad shows
Keyfob enrolled.
9. If you need to replace the keyfob or transmitter you
just added (for example, you accidentally added the
wrong one), press [Replace] and then [Replace],
and follow the previous step.
10. You can remove the added keyfob or transmitter by
pressing [Remove].
11. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Users menu | en
81
*Not applicable to UL listed systems.
Selecting a keypad display language for the user:
1. Press [Language] to select the user’s language.
2. Press [Enter] to continue.
3. Press the softkey for the desired language. The
keypad shows Language configured, and then returns
to the previous menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
82
en | B930 Users menu
Control Panels
16.3 Edit User
Use the Edit User function to edit a user of your security
system. You need to know the user number for the user
you want to edit.
Editing an existing user:
1. Press [Menu] to open the Main menu.
2. Press [User] to open the Users menu option.
3. Press [Edit User] to open the Edit User menu
option.
4. Enter your passcode and press [Enter].
5. Enter the number (1 – 50) for the user you wish to
edit, and press [Enter].
6. The keypad shows the name for the user number
you entered. Press [Continue].
Configuring the user’s passcode:
1. Press [Passcode] to set the passcode.
2. Press [Enter] to continue.
3. Enter the user’s passcode and press [Enter].
4. Enter the passcode again and press [Enter]. The
keypad shows Passcode changed and then returns to
the previous menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
B930 Users menu | en
Control Panels
83
Configuring the user’s name:
1. Press [Name] to configure the user’s name.
2. The [ESC] key acts as a backspace key. Press [ESC]
to delete the characters. Press a number key
repeatedly to scroll through the number and letters
shown on the key. To enter a space, press [0][0]. To
capitalize a letter, press [CMD] before you enter the
letter. For caps lock, press [CMD][CMD]. To remove
caps lock, press [CMD][CMD][CMD].
3. Press [Enter] to save the name. The keypad returns
to the previous menu.
Configuring the user’s level:
1. Press [Level] to assign an authority level.
2. Press [Enter] to continue.
3. Press [Yes] to change the default authority level for
area 1.
4. Enter the authority level number (1 – 14) you wish
to apply to the user and press [Enter]. The keypad
shows Level configured and returns to the previous
menu.
5. If your security system has more than one area, use
[NEXT] and the previous two steps to set the levels
for the additional areas.
Configuring a RADION keyfob* or an Inovonics
Transmitter for the user:
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
84
en | B930 Users menu
Control Panels
1. Press [Keyfob] to assign a RADION keyfob* or an
Inovonics Transmitter to the user.
2. To remove a previously added keyfob or transmitter,
press [Remove].
3. To replace a previously added keyfob or transmitter,
press [Replace] and then [Replace], and follow the
next step.
4. On a RADION keyfob*, press any button. On an
Inovonics Transmitter, open the transmitter and
press the RESET button, per the manufacturer’s
instructions. The keypad shows Keyfob enrolled.
5. To add a RADION keyfob* or an Inovonics
Transmitter, press [Add] Press [Add] to continue,
and follow the previous step.
6. To manually enter the RFID, if desired, press [Enter
RFID] to add the RFID. Otherwise, the keypad
automatically learns the RFID into the security
system when you add a RADION keyfob* or an
Inovonics Transmitter.
7. Press [Enter] to continue.
8. Enter the RFID.
9. Press [Save] to save the RFID and return to the
previous menu.
*Not applicable to UL listed systems.
Selecting a keypad display language for the user:
1. Press [Language] to select the user’s language.
2. Press [Enter] to continue.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Users menu | en
85
3. Press the softkey for the desired language. The
keypad shows Language configured, and then returns
to the previous menu.
16.4 Delete User
Use the Delete User function to delete a user.
Use this function to remove users from the system. All
user data (name, passcode, keyfob) is deleted and
cannot be recovered. Use Edit User if you only wish to
remove a user's authority (disable the user), but retain
the user’s data. You need to know the user number for
the passcode you want to delete. The user numbers
identify users in reports transmitted from your system.
Deleting a user:
1. Press [Menu] to open the Main menu.
2. Press [User] to open the Users menu option.
3. Press [Delete User] to open the Delete User menu
option.
4. Enter your passcode and press [Enter].
5. Enter the number (1 – 50) for the user you wish to
delete, and press [Enter]. The keypad shows the
name for the user number you entered.
6. Press [Continue].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
86
en | B930 Users menu
Control Panels
7. Press [Yes] to confirm you wish to delete the
selected user. The keypad shows User ## deleted,
and then returns to the previous menu.
8. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
17
B930 Settings menu | en
87
B930 Settings menu
Use the Settings menu to turn Watch mode on or off,
set the system date and time, view and change
schedules, set keypad brightness and volume, and show
the time in the keypad display.
17.1 Watch Mode
You can use Watch Mode to monitor select points with
the security system turned off. Each time points are
faulted (door or window is opened), the keypad chimes
once and shows the point text for 60 seconds. The
control panel does not generate alarms in this mode
except 24-hour alarms (fire, panic, etc.).
Use this function in residential systems to monitor
entries or exits in your home. In commercial systems it
can serve as a door chime to alert you when a customer
or delivery person enters your business.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
88
en | B930 Settings menu
Control Panels
Entering and exiting Watch Mode:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Watch Mode] to open the Watch Mode menu
option.
4. Enter your passcode and press [Enter].
5. Press [Turn On] or [Turn Off]. The keypad indicates
that you enabled or disabled Watch Mode
successfully.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Settings menu | en
89
17.2 Date/Time
Your security system must have the correct time and
date for scheduled events to occur at the correct times.
Use the Date/Time function to set both the time and
date. The security system uses a 12-hour AM/PM format.
If your security system is configured for automatic date/
time updates, the update might overwrite your changes.
Setting the date and time:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Date/Time] to open the Date/Time menu
option.
4. Press [Set Date] to open the Set Date menu option.
5. Enter your passcode and press [Enter].
6. Enter the new date in MM/DD/YY format. If you
make a mistake, the [ESC] key acts as a backspace
key. Press [ESC] to delete the characters and then
enter the new numbers.
7. Press [Enter] to save the date. The keypad shows
Change complete and then returns to the previous
menu.
8. Press [Set Time] to open the Set Time menu option.
9. Press [Enter] to continue.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
90
en | B930 Settings menu
Control Panels
10. Enter the new time in HH:MM format. If you make a
mistake, the [ESC] key acts as a backspace key.
Press [ESC] to delete the characters and then enter
the new numbers.
11. Press [Enter] to save the change.
12. Press [AM] or [PM]. The keypad shows Change
complete and then returns to the previous menu.
13. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Settings menu | en
91
17.3 Schedule (SKEDs)
A SKED is a function programmed to be performed
automatically at a scheduled time by your security
system. You can change the scheduled time for SKEDs,
disable a SKED to prevent it from automatically
happening, or restart a previously disabled SKED.
Contact your security company to determine what
SKEDs they programmed for your system.
Selecting a SKED to change:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Schedule] to open the Schedule menu
option.
4. Enter your passcode and press [Enter].
5. Use [PREV] or [NEXT] to scroll through the list of
SKEDs. The keypad indicates whether a SKED is
enabled, disabled, or not yet programmed.
6. Continue to Enabling a disabled SKED or Disabling a
enabled SKED.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
92
en | B930 Settings menu
Control Panels
Enabling a disabled SKED:
1. With the SKED you wish to enable showing, press
[Enable the sked].
2. Press [Exclude holidays] or [Include holidays].
3. Enter the new time in HH:MM format. If you make a
mistake, the [ESC] key acts as a backspace key.
Press [ESC] to delete the characters and then enter
the new numbers.
4. Press [Enter] to save the time and choose AM or
PM.
5. Press [AM] or [PM]. The keypad shows Schedule
update complete and then returns to the previous
menu.
6. Press [ESC] to exit the menu.
Disabling an enabled SKED:
1. With the SKED you wish to disable showing, press
[Disable the sked].
2. Press [Enter] to disable the SKED. The keypad
display indicates that the SKED is disabled.
3. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Settings menu | en
93
17.4 Keypad
Use the Keypad menu to adjust the brightness of the
keypad display, the keypress volume, and enable or
disable the keypress tone.
17.4.1 Brightness
Use the Brightness function to adjust the brightness
level for the keypad display.
Adjusting the keypad display brightness:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Keypad] to open the Keypad menu option.
4. Press [Brightness] to open the Brightness menu
option.
5. Press [PREV] or [NEXT] to adjust the brightness
level. The changes apply immediately.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
94
en | B930 Settings menu
Control Panels
17.4.2 Volume
Use the Volume function to adjust the keypress volume
level for the keypad.
Adjusting the keypress volume:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Keypad] to open the Keypad menu option.
4. Press [Volume] to open the Volume menu option.
5. Press [PREV] or [NEXT] to adjust the volume level.
The changes apply immediately.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Settings menu | en
95
17.4.3 Keypress
Use the Keypress function to activate or deactivate the
keypress tone.
Activating and deactivating the keypress tone:
1. Press [Menu] to open the Main menu.
2. Press [Settings] to open the Settings menu option.
3. Press [Keypad] to open the Keypad menu option.
4. Press [Keypress] to open the Keypress menu
option.
5. Press [Turn On] or [Turn Off].
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
96
en | B930 Shortcuts menu
18
Control Panels
B930 Shortcuts menu
Use shortcuts to quickly access common functions.
Using a shortcut:
1. Press [Menu] to open the Main menu, and then
press [Shortcuts] to open the Shortcuts menu
option, or simply press [Shortcuts] while viewing
idle text.
2. Press the softkey for the desired Shortcut. If more
than four Shortcuts are available, the [NEXT] key
lights, and you can use the key to view additional
Shortcuts.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
19
B930 Events menu | en
97
B930 Events menu
Use the Events menu to view event memory, clear event
memory, or view the event log.
19.1 View Event Memory
Your security system stores events that occurred since
the last time memory was cleared. Use View Event
Memory to view the events not previously cleared. Each
time you turn the security system on, the event memory
is erased.
Viewing event memory:
1. Press [Menu] to open the Main menu.
2. Press [Events] to open the Events menu option.
3. Press [View Event Memory] to open the View Event
Memory menu option.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
98
en | B930 Events menu
Control Panels
19.2 Clear Event Memory
Use the Clear Event Memory function to clear out event
memory without turning your security system off and on
again.
Clearing event memory:
1. Press [Menu] to open the Main menu.
2. Press [Events] to open the Events menu option.
3. Press [Clear Event Memory] to open the Clear
Event Memory menu option.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B930 Events menu | en
99
19.3 View Log
Use the View Log function to review events stored in
your security system. Reviewing past events might help
you identify problems. Events are stored in the control
panel’s memory in order of occurrence, and tagged with
the date and time.
Viewing the log:
1. Press [Menu] to open the Main menu.
2. Press [Events] to open the Events menu option.
3. Press [View Log] to open the View Log menu option.
The keypad shows Enter Start Date.
To view part of the log, enter the date (MM/DD/YY)
at which you wish to start the review. Press [Enter].
To view the entire log from the newest event, press
[Go to last event] without entering a start date. The
date and time of the newest event shows. Use
[PREV] or [NEXT] to move through the events.
4. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
100 en | B920 keypad operation
20
Control Panels
B920 keypad operation
Your security system provides quick access to functions
through the keypad menus.
To access menus using a B920, press [MENU]. Press
[PREV] or [NEXT] to scroll through the list of functions
programmed by your security company. To initiate the
function shown on the display, press [ENTER] or press
the corresponding number key, as indicated in the ondisplay instructions (for example, Press 2 for Status
menu). To exit a specific menu and return to the
previous level, press [ESC]. To exit and return to idle
text from any level of the menu structure, press and
hold [ESC].
The keypad has a Shortcuts menu to quickly access
functions you use most. Your security company
programmed these Shortcuts for you. To access
Shortcuts, press [MENU], and then press [6].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 keypad operation | en 101
20.1 B920 keys overview
Each B920 keypad has 10 number keys and seven
function keys. When pressed, keys turn on keypad
backlighting and emit the keypress tone (short beep).
The function keys include programmable function keys
and keys to initiate arming and bypassing with one
keypress.
20.1.1 B920 keys descriptions
MENU
Use the [MENU] key to open the keypad’s Main menu.
Press [MENU] + [6] to access the Shortcuts menu,
which is the quickest way to access the functions you
use most.
ALL, PART, and BYPASS
Use the [ALL] key to turn your system All On. Use the
[PART] key to turn your system Part On. Use the
[BYPASS] key to access the menu to bypass points.
ENTER
Use the [ENTER] key to complete the entry of your
passcode other numbers, or to answer Yes to a keypad
request.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
102 en | B920 keypad operation
Control Panels
ESC
The [ESC] (Escape) key has two uses. First, use the
[ESC] (Escape) key to exit from menus and functions.
Also, use the key as a Backspace when you enter names
and numbers.
HELP
Use the [HELP] key to open the keypad’s on-display
Help. Press [ESC] to exit help when you finish viewing.
PREV and NEXT
Use the [PREV] and [NEXT] keys to scroll through
menus or menu selections.
CMD
Use the [CMD] key in combination with one or two
number keys to perform select functions.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 keypad operation | en 103
20.2 B920 display overview
The B920 keypad uses words, numbers, and symbols to
show the status of the security system. When several
events occur, the keypad shows each event in order of
priority. The display shows two lines, 18 characters per
line.
The keypad has a bright two-line by 20-character liquid
crystal display (LCD).
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
104 en | B920 keypad operation
Control Panels
20.3 B920 status LEDs overview
The status LEDs on keypads provide a quick visual
reference for you to see how your system is operating.
Ready to arm: The green checkmark LED indicates
whether the system is ready to turn on (arm).
–
ON Steady. All points are normal and the system is
ready to turn on.
–
OFF. One or more points are faulted, and the system
is not ready to turn on.
On (armed): The red lock LED indicates whether the
system is on (armed).
–
–
ON Steady. All areas are on with no alarms.
Flashing. All areas are armed, and there is an active
alarm.
–
OFF. One or more areas is off.
Trouble. The yellow caution LED lights when a trouble
condition exists.
–
ON Steady. There is a system, device, or point
trouble.
–
OFF. There are no system, device, or point troubles.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 keypad operation | en 105
GAS: The blue GAS LED indicates a gas alarm.
–
Flashing. An area has a gas alarm. You should leave
the premises immediately when there is a gas alarm.
–
OFF. A gas alarm does not exist within the keypad’s
scope.
Power: The blue power plug LED indicates whether the
control panel has AC power.
–
ON Steady. The AC (mains) power to the control
panel is present.
–
Flashing. AC (mains) power to the control panel is
not present and the control panel is operating from
the battery.
–
OFF. There is no power to the control panel.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
106 en | B920 Menu tree
21
Control Panels
B920 Menu tree
The B920 offers an easy-to-use menu tree structure. To
access the Menu tree, press [MENU]. Each menu option
has a number. At each level, you can press the number
for the desired menu, if you know it. Otherwise, use
[PREV] or [NEXT] to review your options at that level,
and then press [ENTER] when you see the desired menu
option.
The Menu tree figure on the next page shows the Menu
structure and the numbers associated for each menu
option.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Menu tree | en 107
B920 Menu tree
Press 1 for
All On menu.
Press 1 for
All On Delay.
Press 1 for
Part On Delay.
Press 1 for
On/Off menu.
Press 2 for
Part On menu.
Press 2 for
Part On Instant.
Press 3 for
Off menu.
Press 3 for
Part On Select.
Press 2 for
Status menu.
Press 4 for
Extend Close time.
Press 3 for
Actions menu.
Press 4 for
Users menu.
Press 5 for
Bypass menu.
Press 3 for
All On Select.
Press 1 to
Turn Off.
Press 1 to
reset sensors.
Press 2 to
Turn Off Select.
Press 2 to
change output.
Press 1 to
Turn Off.
Press 1 to
View Area Status.
Press 2 to
View Point Status.
Press 2 for
All On Instant.
Press 3 for
Test menu.
Press 2 to
Turn Off Select.
Press 4 for
RPS menu.
Press 5 for
Settings menu.
Press 3 to Send
Status Report.
Press 6 for
Shortcuts menu. *
Press 5 to
go to area.
Press 1 to
change passcode.
Press 1 to
configure
Press 2 to
add user.
Press 2 to
configure name.
Press 3 to
edit user.
Press 3 to
configure level.
Press 4 to
delete user.
Press 4 to
configure keyfob.
Press 6 to
update firmware.
Press 7 for
Events menu.
Press 1 for
Walk Test menu.
Press 2 to
Send Test report.
Press 3 to
display revisions.
Press 4 to
test notification.
Press 1 to
answer.
Press 2 for
Originate menu.
Press 3 to
call via phone.
Press 7 to
view serv
Press 1 to
view event
Press 2 to
clear event
Press 3 to
view log.
Press 1 to
change Watch mode.
Press 5 to
configure
Press 2 for
Date/Time
Press 1 to
set panel date.
Press 1 to
adjust brightness.
Press 3 to
change schedule.
Press 2 to
set panel time.
Press 2 to
adjust volume.
Press 4 for
keypad config.
Press 3 to
show date/time.
Press 3 to
silence keytone.
* Your security company programmed the Shortcuts for you.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
108 en | B920 Menu tree
Control Panels
Commands
Commands resides outside of the Menu tree. You can
initiate a limited number of functions with the [CMD]
key plus the one or two digit command.
If you know the command number, press [CMD] and
then the one or two digit command.
Review the available commands in the table on the next
page
Notice!
i
With B920 and B930 keypads, you can use [PREV] or
[NEXT] to move through the list of commands, and
press [Enter] or [ENTER] when viewing the desired
command.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Menu tree | en 109
Function
Command
All on
CMD 1
All On, Instant
CMD 1 1
Part On, Instant
CMD 2
Part On
CMD 3
Watch
CMD 6
See Alarms
CMD 4 0
Reset Sensors
CMD 4 7
Extend Close
CMD 5 1
Bypass
CMD 0
Unbypass
CMD 0 0
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
110 en | B920 On/Off menu
22
Control Panels
B920 On/Off menu
Use the On/Off menu to turn areas All or Part On, to
turn areas off, to extend closing time, or to bypass
points.
When you turn on (arm) your security system, there is
an exit delay that gives you time to leave the area
without sounding the burlary tone. When you enter a
security system that is turned on (armed), there is an
entry delay that gives you time to turn off (disarm) the
system.
22.1 All On menu
Use the All On menu to turn areas All On. Turning an
area All On means to turn on all the points. All doors
and windows and all motion sensors, for example.
22.1.1 All On
Turning an area All On turns on all points in the area and
provides entry and exit delay. For example, you can turn
on the area and leave through a door (within exit delay
time) without creating an alarm event. When you turn
the area All On, the display shows how many seconds of
exit delay time remain to exit the protected area. Leave
before the exit delay time expires.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 111
Leaving after exit delay expires causes entry delay to
start. It may also cause an alarm on an interior device.
Enter your passcode to turn off the system.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
112 en | B920 On/Off menu
Control Panels
Turning areas All On:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Press [1] or [ENTER] to open the All On menu.
4. Press [1] or [ENTER] to select All On Delay.
5. Enter your passcode and press [ENTER]. The keypad
shows Exit Now! and sounds during the exit delay.
6. Exit the area or enter your passcode to stop the
system from turning on. If you turn your system All
On and don't exit, the system automatically switches
to Part On.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 113
22.1.2 All On Instant
Turning an area All On Instant turns on all points with
no entry or exit delay. When areas are All On Instant,
faulting any point (opening a door for example) creates
an alarm event immediately.
Turning areas All On Instant:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Press [1] or [ENTER] to open the All On menu.
4. Use [NEXT] to go to the All On Instant option, and
press [ENTER], or simply press [2]. The keypad
shows All On.
5. To turn off the security system, enter your passcode
and press [ENTER].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
114 en | B920 On/Off menu
Control Panels
22.1.3 Select Area (All On menu)
Use All On Select to choose individual areas to turn All
On or All On Instant. You choose areas from a list of the
areas in which you have authority.
Turning on a specific area:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Press [1] or [ENTER] to open the All On menu.
4. Use [NEXT] to go to the All On Select menu, and
press [ENTER], or simply press [3].
5. Use [NEXT] and [ENTER] to select either the On
Instant or On Delay option. The keypad responds
based upon your selection.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 115
22.2 Part On menu
Use the Part On menu to turn areas Part On. Turning an
area Part On means to turn on only some of the points,
and thus part of the system. For example, your security
company might configure your system so that when you
use the Part On function, only the exterior doors and
windows turn on, whereas interior motion sensors do
not turn on.
22.2.1 Part On
Turning an area Part On turns on some points, or part of
the system, in the area and provides entry and exit
delay. For example, you can turn on the area and leave
through a door (within exit delay time) without creating
an alarm event.
Turning the perimeter on with an exit delay:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Part On option, and press
[ENTER], or simply press [2].
4. Press [1] or [ENTER] to open the Part On Delay
option. The keypad shows Part On Dly.
5. To turn off the system, enter your passcode and
press [ENTER].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
116 en | B920 On/Off menu
Control Panels
22.2.2 Part On Instant
Turning an area Part On turns on some points, or part of
the system, in the area with no entry or exit delay. When
the area is Part On Instant, faulting a Part On point
(opening a door for example) creates an alarm event
immediately.
Turning the system Part On without delay:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Part On option, and press
[ENTER], or simply press [2].
4. Use [NEXT] to go to the Part On Instant option, and
press [ENTER], or press [2].
5. Enter your passcode and press [ENTER]. The keypad
shows Part On Inst.
6. To turn off the system, enter your passcode and
press [ENTER].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 117
22.2.3 Select Area (Part On menu)
Use Part On Select to choose individual areas to turn
Part On or Part On Instant. You choose areas from a list
of the areas in which you have authority.
Turning individual areas Part On:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Part On option, and press
[ENTER], or simply press [2].
4. Use [NEXT] to go to the menu Part On Select menu,
and press [ENTER], or press [3].
5. Use [NEXT] and [ENTER]to select either the On
Instant or On Delay option. The keypad responds
based upon your selection.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
118 en | B920 On/Off menu
Control Panels
22.3 Off menu
You can turn areas off simply by entering your passcode
or by using the Off menu. With either option, you turn
off all areas in which you have authority.
You must enter your personal passcode and enter
through a designated entry door to prevent an instant
alarm condition. Opening the door starts entry delay
time and the keypad emits a pulsing “beep” tone to
remind you to turn the system off. Enter your passcode
before the entry delay time expires.
If you enter through the wrong door or fail to turn off
(disarm) before the entry delay time expires, an alarm
occurs. If this happens, silence the alarm (by entering
your personal passcode and pressing [ENTER]) and call
your security company to notify them that you do not
have an emergency situation.
Turning off the security system (disarm) with your
passcode:
1. Enter your personal passcode.
2. Press [ENTER] within 8 sec of entering your
passcode. The display returns to idle text.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 119
22.3.1 Turn Off
You can use the Turn Off menu to turn off all areas in
which you have authority.
Turning off areas:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the menu Off menu, and press
[ENTER], or simply press [3].
4. Press [1] or [ENTER] to open the Off menu.
5. Enter your passcode and press [ENTER]. The display
returns to idle text.
22.3.2 Turn Off Select
Use Turn Off Select to choose individual areas to turn
off. You choose areas from a list of the areas in which
you have authority.
Turning off a specific area:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the menu Off menu, and press
[ENTER], or simply press [3].
4. Use [NEXT] to go to the menu Turn Off Select menu,
and p[ENTER], or simply press [2].
5. Use [NEXT] and [ENTER] to select an area.
6. Press [ENTER] to turn off your selected area.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
120 en | B920 On/Off menu
Control Panels
22.4 Extend Closing
Your security company might program your system to
expect you to turn on (arm) within a closing window. A
closing window is a duration of time programmed by
your security company. Your security company sets a
fixed length of time for the closing window. Additionally,
your security company might program your system to
automatically turn on (arm) at the end of the window.
Use the Extend Close Time option when you need to
stay later than the scheduled close time. If you do not
extend the Close Time and do not turn the system on
before the scheduled time, the system creates a Late to
Close event.
At the beginning of the closing window, the keypad
beeps and shows Please Close Now to remind you to
turn on (arm) your system. It remains in the display until
you turn on the system, the close window ends, or you
extend closing. Alarm or trouble messages replace this
message in the event of an alarm or trouble condition. If
the alarm or trouble condition clears before the end of
the close window Please Close Now returns to the
keypad display.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 121
Pressing [ESC] silences the beep and clears the
message for 10 minutes. If you have not turned your
system on (armed) or extended closing, the Please Close
Now message and beep reappear after 10 minutes. To
extend the window, enter the new time at which you
would like the reminder tone to begin. This time is the
new beginning of the closing window.
When you hear the warning, you can:
–
Leave before the end of the closing window by
pressing [ESC] to silence the signal, turning on the
system, and leaving.
–
Stay past the scheduled end of the closing window,
by using this function to extend the closing window.
To extend closing:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Extend Closing menu, and
press [ENTER], or simply press [4].
4. Enter your passcode and press [ENTER].
Notice!
i
You cannot extend the window across the midnight
boundary. The system cannot arm if points are off-normal.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
122 en | B920 On/Off menu
Control Panels
22.5 Bypass menu
Use the Bypass menu to temporarily take points out of
the security system, and enter them back into the
system. Bypassed points do not create alarm or trouble
events, do not detect intruders, and cannot send any
reports. For example, to leave a window open and turn
the system on, you bypass the window point and then
turn the system on.
22.5.1 Bypass
You can bypass points when an area is turned off
(disarmed). Points remain bypassed until you unbypass
them or some points return when the area is turned off
(disarmed). Use point bypassing with discretion:
bypassing a point reduces the level of security.
Bypassing a point:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Bypass menu, and press
[ENTER], or simply press [5].
4. Press [1] or [ENTER] to open the Bypass Points
menu.
5. Select a point to bypass.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 On/Off menu | en 123
22.5.2 Unbypass
Unbypassing a point returns a bypassed point to the
security system so that it can once again respond to
trouble and alarm conditions.
Unbypassing a point:
1. Press [MENU] to open the Main menu.
2. Press [1] or [ENTER] to open the On/Off menu.
3. Use [NEXT] to go to the Bypass menu, and press
[ENTER], or simply press [5].
4. Use [NEXT] to go to the Unbypass menu, and press
[ENTER], or simply press [2].
5. Enter your passcode and press [ENTER].
6. Select a point to bypass.
7. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
124 en | B920 Status menu
23
Control Panels
B920 Status menu
Use the Status menu to see area or point status, or to
send a status report.
23.1 View Area Status
Area Status shows the on/off status for areas in which
you have authority.
Viewing area status:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Status menu option, and
press [ENTER], or simply press [2].
3. Press [1] or [ENTER] to open the View Area Status
menu.
4. Enter your passcode and press [ENTER]. The display
shows the status of each area. For example A1: Off.
5. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Status menu | en 125
23.2 View Point Status
The View Point Status feature shows the status (normal,
open, or short) for all points in the areas in which you
have authority.
Viewing point status:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Status menu option, and
press [ENTER], or simply press [2].
3. Use [NEXT] to go to the View Point Status menu
option, and press [ENTER], or simply press [2].
4. The display shows the number of points in the
system. Use [PREV] or [NEXT] to scroll through the
list of points and each point’s status.
5. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
126 en | B920 Status menu
Control Panels
23.3 Send Status Report
The Send Status Report feature sends a complete
system status report to your security monitoring
company. Status reports can alert them to potential
problems.
Sending a status report:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Status menu option, and
press [ENTER], or simply press [2].
3. Use [NEXT] to go to the Send Status Report menu
option, and press [ENTER], or simply press [3].
4. Enter your passcode and press [ENTER]. The control
panel sends a status report to your security
company.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
24
B920 Actions menu | en 127
B920 Actions menu
Use the Actions menu to reset sensors, change outputs,
see the test menu, see the RPS menu, go to an area,
update system firmware, or to view service bypassed
points.
24.1 Reset
Detection devices, such as smoke detectors and shock
sensors, might require a reset action before they return
to normal operation. This function momentarily removes
power from these devices to reset them.
Resetting sensors:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Press [1] or [ENTER] to reset the sensors with the
Reset option.
4. Enter your passcode and press [ENTER]. The display
shows Sensors resetting for approximately 3 seconds
and then goes blank before returning to idle
disarmed text.
If you enter this function and the detector or sensor
resets momentarily, but then returns to a faulted
condition, the conditions causing the activation may still
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
128 en | B920 Actions menu
Control Panels
be present or the detector may be faulty. Check to be
certain that there is no smoke, fire, or other danger
present.
If you cannot reset the detector or sensor, contact your
security company.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 129
24.2 Outputs
Your security company programs outputs for automatic
control and/or keypad control of devices such as
premises lighting or entry gates. An output is a device
that is controlled by the security system. Contact your
security company for further information regarding the
use of outputs in your security system.
Use this function to select outputs to turn on or off.
Outputs on your security system can control other
systems, lighting for example.
Your security system is not UL listed for access control.
Turning outputs on and off:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Outputs menu option, and
press [ENTER], or simply press [2].
4. Enter your passcode and press [ENTER].
5. Use [NEXT] to select the desired output value, or
use the number keys to enter the value.
6. Press [ENTER]. The current state of the output
shows.
7. Use [ENTER] to toggle between Off and On.
8. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
130 en | B920 Actions menu
Control Panels
24.3 Test
Use the Test menu to walk test your system, send test
reports, or to review system revision information on the
keypad display.
24.3.1 Walk Test
A walk test allows you to test the sensors, keypads,
sounders, and other devices in your system without
creating alarm events. You can review untested points
at the keypad to help pinpoint any problems.
You cannot turn on the security system while in the walk
test mode. Also, the security system does not create
alarm events for points included in the walk test. Points
not included create alarm events. For example, faulting
a fire point during an intrusion walk test creates a fire
alarm event.
Beginning the walk test activates the burglary tone for 2
seconds. A battery test also begins. A successful battery
test ends in four minutes (the walk test continues). If
the security system determines there is a low battery, it
generates a low battery event and continues the test. If
the battery is determined to be very low, the system
creates a missing battery event and ends the battery
test immediately.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
B920 Actions menu | en 131
Control Panels
To test individual detection devices, simply activate
sensors and open protected doors and windows one-ata-time. As you fault each detection device, the keypad
from which you initiated the test emits a brief tone, and
for 60 seconds the display indicates that the point was
tested. The tone and display verify that each detection
device is working properly. Keypads within the area’s
scope from which you did not initiate the walk test
show Walk test in progress during the testing.
Performing a walk test:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Test menu option, and press
[ENTER], or simply press [3].
4. Press [1] or [ENTER] to open the Walk Test menu.
5. Enter your passcode and press [ENTER].
6. Use [NEXT] to go to the desired walk test, and press
[ENTER], or simply press the number key for the
desired walk test: [1] for Fire, [2] for Intrusion, [3]
for Service, or [4] for Invisible.
7. Press [ENTER] to view the points.
8. Use [NEXT] to toggle through your desired point and
view the status of that point.
9. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
132 en | B920 Actions menu
Control Panels
Automatic termination
The Walk Test automatically ends after 20 minutes of no
test activity. The keypad sounds during the last 5
minutes of the test.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 133
24.3.2 Send Test Report
This function tests the communication link between
your security system and your security company. It is an
important part of maintaining a high level of security for
your property.
Sending a test report:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Test menu option, and press
[ENTER], or simply press [3].
4. Use [NEXT] to go to the Send Test Report menu
option, and press [ENTER], or simply press [2].
5. Enter your passcode and press [ENTER]. The system
sends a test report.
6. Press [ESC] to exit the menu
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
134 en | B920 Actions menu
Control Panels
24.3.3 Revisions
Use this function to view the current reversion of your
control panel firmware.
Viewing the current revision of your system (control
panel):
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Test menu option, and press
[ENTER], or simply press [3].
4. Use [NEXT] to go to the Revisions menu option, and
press [ENTER], or simply press [3]. The current
control panel revision information shows on the
display.
5. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 135
24.3.4 Notification Test
Use this menu to test the security system’s ability to
send personal notification messages to the destination
path designated by your security company.
Testing notifications:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Test menu option, and
[ENTER], or simply press [3].
4. Use [NEXT] to go to the Notification Test Report
option, and press [ENTER], or simply press [4]. The
keypad shows the first destination.
5. Use [NEXT] to go to the desired destination, and
then press [ENTER]. The control panel sends a test
notification, and then returns to idle text.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
136 en | B920 Actions menu
Control Panels
24.4 RPS
Use the RPS menu for connection to Remote
Programming Software (RPS). Your security company
uses RPS to configure and service your security system.
RPS is intended for use by professional or licensed
installers only.
24.4.1 Answer
Use the Answer option to answer the phone (pick up
the phone line) to connect to RPS.
Using the Answer menu option to answer an incoming
call from RPS:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the RPS menu option, and press
[ENTER], or simply press [4].
4. Press [1] or [ENTER] to reset the sensors with the
Answer option.
5. Enter your passcode and press [ENTER]. The keypad
shows RPS is connecting…. and then returns to idle
text.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 137
24.4.2 Network Originate
Use this function to originate an RPS session using an IP
(internet) connection.
Connecting to RPS using an internet connection:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the RPS menu option, and press
[ENTER], or simply press [4].
4. Use [NEXT] to go to the Network Originate menu
option, and press [ENTER], or simply press [2].
5. Enter your passcode and press [ENTER].
6. To use the programmed port number, press [1] or
press [ENTER]. The connection progress begins.
7. If you wish to change the port number before
connecting, press [NEXT] and then [ENTER], or
simply press [2]. The [ESC] key acts as a backspace
key. Press [ESC] to delete the characters, and then
enter the new characters. Press [ENTER]. The
connection process begins.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
138 en | B920 Actions menu
Control Panels
24.4.3 Call Via Phone
Use this function to call RPS using the phone line.
Connecting to RPS via the phone line:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the RPS menu option, and press
[ENTER], or simply press [4].
4. Use [NEXT] to go to the Call Via Phone menu option,
and press [ENTER], or simply press [3].
5. Enter your passcode and press [ENTER]. The
connection process begins.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 139
24.5 Go to Area
With the Go to Area function you can perform tasks in
an area other than the one you’re in without having to
physically go to that area. For example, using the
keypad in the office area, you could 'go' to the loading
area. You select the area from a list of areas in which
you have authority.
Once you 'go’ to an area, you can perform tasks you
have authority for in that area. To 'leave' an area press
[ESC].
Using Go to Area:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Go to Area menu option,
and press [ENTER], or simply press [5].
4. Enter your passcode and press [ENTER].
5. Use [NEXT] to go to the area you wish to enter, and
then press [ENTER].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
140 en | B920 Actions menu
Control Panels
24.6 Firmware
Your security company might have configured your
security system to require your authorization before
system firmware can be updated. Use this action to
provide authorization at the request of your security
company. Local authorization is required for UL listed
systems.
Authorizing a firmware update:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Firmware menu option, and
[ENTER], or simply press [6].
4. Enter your passcode and press [ENTER].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Actions menu | en 141
24.7 Service Bypass
To facilitate system maintenance for service personnel,
your security system comes with a special point bypass
option to remove any point from service. Bypassed
points are not protected. Use this menu to view
bypassed points.
Viewing points in Service Bypass:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Actions menu option, and
press [ENTER], or simply press [3].
3. Use [NEXT] to go to the Service Bypass menu
option, and press [ENTER], or simply press [6].
4. Enter your passcode and press [ENTER]. The keypad
shows any points in service bypass.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
142 en | B920 Users menu
25
Control Panels
B920 Users menu
Use the Users menu to change your own passcode, add
new users, edit existing users, or to delete users.
25.1 Change Passcode
Use the Change Passcode function to change your
personal passcode.
Before you begin, consider the following:
–
Choose a new passcode three to six digits long. If
you choose a passcode with the same digit in
consecutive order (for example “33” in 334697),
take care when entering it.
–
To avoid conflicting with other passcodes and
duress codes, your security system does not let you
change to existing passcodes or passcodes that are
within plus or minus 2 of an existing passcode. For
example, if 1234 were an existing code, your
security system would not let you change your code
to 1232, 1233, 1234, 1235, or 1236.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Users menu | en 143
Changing your passcode:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go the Users menu option, and press
[ENTER], or simply press [4].
3. Press [1] or [ENTER] to open the Change Passcode
option.
4. Enter your current passcode and press [ENTER].
5. Enter your new passcode and press [ENTER].
6. Enter your new passcode again and press [ENTER].
The keypad shows Passcode changed and then
returns to the Change Passcode option.
7. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
144 en | B920 Users menu
Control Panels
25.2 Add User
Use the Add User function to add a passcode to your
security system. Before you add the user, you need to
know which user numbers are available, the authority
level you want to assign to the new passcode, and the
areas in which it will be valid.
The two-digit user numbers identify users in reports
transmitted from your security system. The authority
level determines what system functions the passcode
can access. The area number identifies which parts of
your security system the passcode can access. Contact
your security company if you don’t know what user
numbers, authority levels, or areas are available.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Users menu | en 145
Before you begin:
–
Do not try to add passcodes without knowing the
available user numbers. These are two-digit
numbers, not to be confused with passcodes, that
identify users at your security company.
–
Choose a new passcode three to six digits long. If
you choose a passcode with the same digit in
consecutive order (for example “33” in 334697),
take care when entering it.
–
To avoid conflicting with other passcodes and
duress codes, your security system does not let you
add passcodes that are within plus or minus 2 of an
existing passcode. For example, if 1234 were an
existing code, your system would not let you change
your code to 1232, 1233, 1235, or 1236.
–
Choose an authority level for each area. Leaving the
authority level for an area blank by pressing [Enter]
or [ENTER] without making an entry, denies the
passcode access to that area.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
146 en | B920 Users menu
Control Panels
Adding a user:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go the Users menu option, and press
[ENTER], or simply press [4].
3. Use [NEXT] to go to the Add User menu option, and
press [ENTER], or simply press [2].
4. Enter your passcode and press [ENTER].
5. Enter the number (1 – 50) for the user you wish to
add, and press [ENTER].
Configuring the user’s passcode:
1. Press [1] or [ENTER] to open the Configure
Passcode menu.
2. Press [ENTER] to configure the user’s passcode.
3. Enter the user’s passcode and press [ENTER].
4. Enter the passcode again and press [ENTER]. The
keypad shows Passcode changed and then returns to
the previous menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
B920 Users menu | en 147
Control Panels
Configuring the user’s name:
1. Use [NEXT] to go to the Configure Name option, and
press [ENTER], or simply press [2].
2. Press [ENTER] to configure the user’s name.
3. The [ESC] key acts as a backspace key. Press [ESC]
to delete the characters. Press a number key
repeatedly to scroll through the number and letters
shown on the key. To enter a space, press [0][0]. To
enter a space, press [0][0]. To capitalize a letter,
press [CMD] before you enter the letter. For caps
lock, press [CMD][CMD]. To remove caps lock,
press [CMD][CMD][CMD].
4. Press [ENTER] to save the new name. The keypad
returns to the previous menu.
Configuring the user’s level:
1. Use [NEXT] to go to the Configure Level option, and
press [ENTER], or simply press [3].
2. Press [ENTER] to change the default authority level
for area 1.
3. Enter the authority level number (1 – 14) you wish
to apply to the user and press [ENTER]. The keypad
shows Level configured and returns to the previous
menu.
4. If your security system has more than one area, use
[NEXT] and the previous two steps to set the levels
for the additional areas.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
148 en | B920 Users menu
Control Panels
Configuring a RADION keyfob* or an Inovonics
Transmitter for the user:
1. Use [NEXT] to go to the Configure Keyfob option,
and press [ENTER], or simply press [4].
2. Press [ENTER] to continue.
3. To manually enter the RFID, if desired, press [1] or
[ENTER] to open the RFID option. Otherwise, the
keypad automatically learns the RFID into the
security system when you add a RADION keyfob* or
an Inovonics Transmitter.
4. Press [ENTER] to continue.
5. Enter the RFID.
6. Press [ENTER] to save the RFID and return to the
previous menu.
7. Use [NEXT] to go to the Add a Keyfob option, and
press [ENTER] or simply press [2].
8. Press [ENTER] to continue.
9. On a RADION keyfob*, press any button on the
keyfob. On an Inovonics Transmitter, open the
transmitter and press the RESET button, per the
manufacturer’s instructions. The keypad shows
Keyfob enrolled and returns to the previous menu.
10. If you need to replace the keyfob or transmitter you
just added (for example, you accidentally added the
wrong one), use [NEXT] to go to the Replace a
Keyfob option, and press [ENTER],or simply press
[3], and then follow the previous step.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Users menu | en 149
11. To remove the added keyfob or transmitter, use
[NEXT] to go to the Remove a Keyfob option, and
press [ENTER] or simply press [4].
12. Press [ESC] to exit the menu.
*Not applicable to UL listed systems.
Selecting a keypad display language for the user:
1. Use [NEXT] to go to the Configure Keyfob option,
and press [ENTER], or simply press [4].
2. Press [ENTER] to continue.
3. Press [ENTER] to change the language. The keypad
shows Language configured, and then returns to the
previous menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
150 en | B920 Users menu
Control Panels
25.3 Edit User
Use the Edit User function to edit a user of your security
system. You need to know the user number for the user
you want to edit.
Editing an existing user:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go the Users menu option, and press
[ENTER], or simply press [4].
3. Use [NEXT] to go to the Edit User menu option, and
press [ENTER], or simply press [3].
4. Enter your passcode and press [ENTER].
5. Enter the number (1 – 50) for the user you wish to
edit, and press [ENTER].
6. The keypad shows the name for the user number
you entered. Press [ENTER].
Configuring the user’s passcode:
1. Press [1] or [ENTER] to open the Configure
Passcode menu.
2. Press [ENTER] to configure the user’s passcode.
3. Enter the user’s passcode and press [ENTER].
4. Enter the passcode again and press [ENTER]. The
keypad shows Passcode changed and then returns to
the previous menu.
Configuring the user’s name:
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
B920 Users menu | en 151
Control Panels
1. Use [NEXT] to go to the Configure Name option, and
press [ENTER], or simply press [2].
2. Press [ENTER] to configure the user’s name.
3. The [ESC] key acts as a backspace key. Press [ESC]
to delete the characters. Press a number key
repeatedly to scroll through the number and letters
shown on the key. To enter a space, press [0][0]. To
enter a space, press [0][0]. To capitalize a letter,
press [CMD] before you enter the letter. For caps
lock, press [CMD][CMD]. To remove caps lock,
press [CMD][CMD][CMD].
4. Press [ENTER] to save the new name. The keypad
returns to the previous menu.
Configuring the user’s level:
1. Use [NEXT] to go to the Configure Level option, and
press [ENTER], or simply press [3].
2. Press [ENTER] to change the default authority level
for area 1.
3. Enter the authority level number (1 – 14) you wish
to apply to the user and press [ENTER]. The keypad
shows Level configured and returns to the previous
menu.
4. If your security system has more than one area, use
[NEXT] and the previous two steps to set the levels
for the additional areas.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
152 en | B920 Users menu
Control Panels
Configuring a RADION keyfob* or an Inovonics
Transmitter for the user:
1. Use [NEXT] to go to the Configure Keyfob option,
and press [ENTER], or simply press [4].
2. Press [ENTER] to continue.
3. To manually enter the RFID, if desired, press [1] or
[ENTER] to open the RFID option. Otherwise, the
keypad automatically learns the RFID into the
security system when you add a RADION keyfob* or
an Inovonics Transmitter.
4. Press [ENTER] to continue.
5. Enter the RFID.
6. Press [ENTER] to save the RFID and return to the
previous menu.
7. Use [NEXT] to go to the Add a Keyfob option, and
press [ENTER] or simply press [2].
8. Press [ENTER] to continue.
9. On a RADION keyfob*, press any button on the
keyfob. On an Inovonics Transmitter, open the
transmitter and press the RESET button, per the
manufacturer’s instructions. The keypad shows
Keyfob enrolled and returns to the previous menu.
10. If you need to replace the keyfob or transmitter you
just added (for example, you accidentally added the
wrong one), use [NEXT] to go to the Replace a
Keyfob option, and press [ENTER],or simply press
[3], and then follow the previous step.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Users menu | en 153
11. To remove the added keyfob or transmitter, use
[NEXT] to go to the Remove a Keyfob option, and
press [ENTER] or simply press [4].
12. Press [ESC] to exit the menu.
*Not applicable to UL listed systems.
Selecting a keypad display language for the user:
1. Use [NEXT] to go to the Configure Keyfob option,
and press [ENTER], or simply press [4].
2. Press [ENTER] to continue.
3. Press [ENTER] to change the language. The keypad
shows Language configured, and then returns to the
previous menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
154 en | B920 Users menu
Control Panels
25.4 Delete User
Use the Delete User function to delete a user.
Use this function to remove users from the system. All
user data (name, passcode, keyfob) is deleted and
cannot be recovered. Use Edit User if you only wish to
remove a user's authority (disable the user), but retain
the user’s data. You need to know the user number for
the passcode you want to delete. The user numbers
identify users in reports transmitted from your system.
Deleting a user:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go the Users menu option, and press
[ENTER], or simply press [4].
3. Use [NEXT] to go to the Delete User menu option,
and press [ENTER], or simply press [4].
4. Enter your passcode and press [ENTER].
5. Enter the number for the user you wish to delete,
and press [ENTER].
6. Press [ENTER] to continue.
7. Press [ENTER] to confirm you wish to delete the
selected user. The keypad shows User ## deleted,
and then returns to the previous menu.
8. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
26
B920 Settings menu | en 155
B920 Settings menu
Use the Settings menu to turn Watch mode on or off,
set the system date and time, view and change
schedules, set keypad brightness and volume, and show
the time in the keypad display.
26.1 Watch Mode
You can use Watch Mode to monitor select points with
the security system turned off. Each time points are
faulted (door or window is opened), the keypad chimes
once and shows the point text for 60 seconds. The
control panel does not generate alarms in this mode
except 24-hour alarms (fire, panic, etc.).
Use this function in residential systems to monitor
entries or exits in your home. In commercial systems it
can serve as a door chime to alert you when a customer
or delivery person enters your business.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
156 en | B920 Settings menu
Control Panels
Entering and exiting Watch Mode:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Press [1] or [ENTER] to open the Watch Mode
option.
4. Enter your passcode and press [ENTER].
5. Press [ENTER] to turn Watch Mode on if it is off, or
off if it is on. The keypad display indicates that you
enabled or disabled Watch Mode successfully.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Settings menu | en 157
26.2 Date/Time
Your security system must have the correct time and
date for scheduled events to occur at the correct times.
Use the Date/Time function to set both the time and
date. The security system uses a 12-hour AM/PM format.
If your security system is configured for automatic date/
time updates, the update might overwrite your changes.
Setting the date and time:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Use [NEXT] to go to the Date/Time menu option,
and press [ENTER], or simply press [2].
4. Enter your passcode and press [ENTER].
5. Press [1] or [ENTER] to set the control panel’s date.
6. Enter the new date in MM/DD/YY format. If you
make a mistake, the [ESC] key acts as a backspace
key. Press [ESC] to delete the characters and then
enter the new numbers.
7. Press [ENTER]. The keypad shows Change complete
and then returns to the previous menu.
8. Use [NEXT] to go to the option to change the time,
and press [ENTER], or simply press [2].
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
158 en | B920 Settings menu
Control Panels
9. Enter the new time in HH:MM format. If you make a
mistake, the [ESC] key acts as a backspace key.
Press [ESC] to delete the characters and then enter
the new numbers.
10. Press [ENTER] to save the time and to go to the AM
or PM selection option.
11. Press [ENTER] to select AM, or press [NEXT] and
then [ENTER] to select PM. The keypad shows
Change complete and then returns to the previous
menu.
12. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Settings menu | en 159
26.3 Schedule (SKEDs)
A SKED is a function programmed to be performed
automatically at a scheduled time by your security
system. You can change the scheduled time for SKEDs,
disable a SKED to prevent it from automatically
happening, or restart a previously disabled SKED.
Contact your security company to determine what
SKEDs they programmed for your system.
Selecting a SKED to change:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Use [NEXT] to go to the Schedule menu option, and
[ENTER], or simply press [3].
4. Enter your passcode and press [ENTER].
5. Use [PREV] or [NEXT] to scroll through the list of
SKEDs. The keypad indicates whether a SKED is
enabled, disabled, or not yet programmed.
6. With the SKED you wish to enable showing, press
[ENTER].
7. Continue to Enabling a disabled SKED or Disabling a
enabled SKED.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
160 en | B920 Settings menu
Control Panels
Enabling a disabled SKED:
1. With the SKED you wish to enable showing, press
[ENTER].
2. Press [ENTER] to continue.
3. Enter the new time in HH:MM format. If you make a
mistake the [ESC] key acts as a backspace key.
Press [ESC] to delete the characters and then enter
the new numbers.
4. Press [ENTER] to save the time and choose AM or
PM.
5. Press [ENTER] to select AM, or press [NEXT] and
then [ENTER] to select PM. The keypad shows
Schedule update complete and then returns to the
previous menu.
6. Press [ESC] to exit the menu.
Disabling an enabled SKED:
1. With the SKED you wish to enable showing, press
[ENTER].
2. Press [ENTER].to continue disable it. The keypad
display indicates that the SKED is disabled.
3. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Settings menu | en 161
26.4 Keypad
Use the Keypad menu to adjust the brightness of the
keypad display, the keypress volume, and enable or
disable the keypress tone.
26.4.1 Brightness
Use the Brightness function to adjust the brightness
level for the keypad display.
Adjusting the keypad display brightness:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Use [NEXT] to go to the Keypad menu option, and
press [ENTER], or simply press [4].
4. Press [1] or [ENTER] to adjust the brightness.
5. Press [PREV] or [NEXT] to adjust the brightness
level. The changes apply immediately.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
162 en | B920 Settings menu
Control Panels
26.4.2 Volume
Use the Volume function to adjust the keypress volume
level for the keypad.
Adjusting the keypress volume:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Use [NEXT] to go to the Keypad menu option, and
press [ENTER], or simply press [4].
4. Use [NEXT] to go to the Volume menu option, and
press [ENTER], or simply press [2].
5. Press [PREV] or [NEXT] to adjust the volume level.
The changes apply immediately.
6. Press [ESC] to exit the menu.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Settings menu | en 163
26.4.3 Keypress
Use the Keypress function to activate or deactivate the
keypress tone.
Activating and deactivating the keypress tone:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Settings menu option, and
press [ENTER], or simply press [5].
3. Use [NEXT] to go to the Keypad menu option, and
press [ENTER], or simply press [4].
4. Use [NEXT] to go to the Keypress menu option, and
press [ENTER], or simply press [3].
5. Press [ENTER] to toggle between the On and Off
options.
6. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
164 en | B920 Shortcuts menu
27
Control Panels
B920 Shortcuts menu
Use shortcuts to quickly access common functions.
Using a shortcut:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Shortcuts menu option, and
press [ENTER], or simply press [6].
3. Use [PREV] or [NEXT] to go to the Shortcut you wish
to run, and then press [ENTER]. The shortcut runs.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
28
B920 Events menu | en 165
B920 Events menu
Use the Events menu to view event memory, clear event
memory, or view the event log.
28.1 View Event Memory
Your security system stores events that occurred since
the last time memory was cleared. Use View Event
Memory to view the events not previously cleared. Each
time you turn the security system on, the event memory
is erased.
Viewing event memory:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Events menu option, and
press [ENTER], or simply press [7].
3. Press [1] or [ENTER] to open the view event
memory.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
166 en | B920 Events menu
Control Panels
28.2 Clear Event Memory
Use the Clear Event Memory function to clear out event
memory without turning your security system off and on
again.
Clearing event memory:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Events menu option, and
press [ENTER], or simply press [7].
3. Use [NEXT] to go to the Clear Event Memory menu
option, and press [ENTER], or simply press [2].
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
B920 Events menu | en 167
28.3 View Log
Use the View Log function to review events stored in
your security system. Reviewing past events might help
you identify problems. Events are stored in the control
panel’s memory in order of occurrence, and tagged with
the date and time.
Viewing the log:
1. Press [MENU] to open the Main menu.
2. Use [NEXT] to go to the Events menu option, and
press [ENTER], or simply press [7].
3. Use [NEXT] to go to the View Log menu option, and
press [ENTER], or simply press [3]. The keypad
shows Enter Start Date.
To view part of the log, enter the date (MM/DD) at
which you wish to start the review. Press [ENTER].
To view the entire log from the newest event, press
[ENTER] without entering a start date. The date and
time of the newest event shows. Use [PREV] or
[NEXT] to move through the events. If an event
description is longer than the display, the event
description scrolls horizontally.
4. Press [ESC] to exit the menu.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
168 en | Options
29
Control Panels
Options
This section describes optional features that your
security company might have programmed for you.
29.1 Two-man Rule
The Two-man Rule adds an extra step to the process of
turning off your security system by requiring two unique
passcodes entered on the same keypad to turn off an
area. Two-man Rule is disabled for SIA compliant
systems.
Two-man Rule is:
enabled on my system.
disabled on my system.
Turning off with Two-man Rule enabled:
1. Enter the first passcode and press [Enter] or
[ENTER]. The keypad shows a request for the
second passcode.
2. Enter a second passcode and press [Enter] or
[ENTER]. The second passcode must be different
from the first passcode. The area turns off.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 169
29.2 Early Ambush
When the Early ambush feature is enabled, the security
system, requires two passcodes to turn off the area.
Entering the first passcode turns the area off and begins
counting down Early Ambush Time (__ minutes). A user
must enter the second passcode before Early Ambush
time expires. Early Ambush is disabled for SIA compliant
systems.
If Early Ambush time expires before a user enters the
second passcode, the system creates a duress event.
You can enter the first passcode a second time as the
second passcode.
You can enter the passcodes at the same keypad, or at
different keypads (if keypads are assigned to the same
area).
Early Ambush is:
enabled on my system.
disabled on my system.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
170 en | Options
Control Panels
Turning off with Early Ambush enabled:
1. Enter the first passcode and press [Enter] or
[ENTER]. The keypad shows the system is turned
off. Early ambush time begin counting down. The
keypad does not indicate that early ambush time is
counting down.
2. You must enter the second passcode before the
Early Ambush time expires. Warning! Failure to
cancel will result in alarm transmission and law
enforcement may be dispatched.
3. Enter a second passcode and press [Enter] or
[ENTER]. The keypad shows Code 2 Validated to
confirm that the security system accepted the
second passcode and stopped the Early Ambush
time countdown. The system does not create a
duress event.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 171
29.3 Security system limitations
Not even the most advanced security system can
guarantee protection against burglary, fire, or
environmental threats. All security systems are subject
to possible compromise or failure-to-warn for a variety
of reasons including, but not limited to, the following:
–
Sirens or horns placed outside the hearing range of
people in remote areas of the building or in areas
that are frequently closed off do not provide the
intended protection.
–
If intruders gain access through unprotected points
of entry, the security system does not detect the
intruders.
–
If intruders have the technical means of bypassing,
jamming, or disconnecting all or part of the security
system, the security system cannot detect the
intruders.
–
If the AC power supply is OFF and the back-up
battery is either missing or dead, the security
system does not detect intrusion.
–
Smoke detectors cannot detect smoke in chimneys,
walls, or roofs, or smoke blocked by a closed door.
They might not detect smoke or fire on a level of the
building different from the one on which they are
located. Smoke detectors might not be able to warn
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
172 en | Options
Control Panels
in time about fires started by explosions, improper
storage of flammables, overloaded electrical circuits,
or other types of hazardous conditions.
–
If your security system’s method of communication
is down (phone line, cellular, or internet problems),
reports from the security system to the security
company cannot send. Communication methods are
vulnerable to compromise by several means.
Inadequate maintenance and failure to test are the most
common causes of alarm failure. Testing the system
once a week is strongly recommended to ensure all
system components are working properly.
Although having a security system might make you
eligible for reduced insurance premiums, the security
system is no substitute for insurance. Warning devices
cannot compensate you for loss of life or property.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 173
29.4 Cross points
Points can be assigned to cross point groups. When a
point in a cross point group detects an alarm, the
control panel starts the cross point timer. If a second
point in the same cross point group detects an alarm
while the cross point timer is active, the control panel
sends alarm reports for both points.
If a single cross point detects an alarm and stays in
alarm throughout the cross point timer, the control
panel sends an alarm report only for that point. If a
single point in a cross point group detects an alarm and
restores while the timer is still active, the system sends
an unverified event for that point. A second alarm on the
first point does not create an alarm event, but rather an
unverified event.
Cross points are:
enabled on my system.
disabled on my system.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
174 en | Options
Control Panels
29.5 Fire safety and evacuation
Residential fire is a leading cause of accidental death.
Most fire related deaths occur at night when occupants
suffocate in their sleep from smoke and toxic gases,
rather than from burns. To help reduce this risk,
implement the following program:
–
Make a home escape plan. Draw a map of your home
showing all doors and windows. Discuss the plan
with everyone in your home.
–
Know at least two ways out of every room, if
possible. Make sure all foors and windows leading
outside open easily.
–
Have an outside meeting place (like a tree, light pole
or mailbox), a safe distance from the home where
everyone should meet.
–
Practice your home fire drill at night and during the
–
Practice using different ways out.
–
Teach children how to esape on their own in case
–
Close doors behhind you as you leave.
day with everyone in your home, twice each year.
you can’t help them.
If the alarm sounds:
–
If the smoke alarm sounds, get out and stay out.
Never go back inside for people or pets.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
–
Options | en 175
If you have to escape through smoke, get low and
go under the smoke to your way out.
–
Call the fire department from outside your home.
Dining Room
Kitchen
Bedroom
Family Room
Living Room
Bedroom
Meeting
Place
Bedroom
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
176 en | Options
Control Panels
29.6 Multiple area systems
29.6.1 Keypad scope
Your security company can configure your security
system so that keypads allow you view the status of and
control only one area, a group of areas, or all of the
areas in your system. The areas you can view and the
area functions (actions) you can use at a keypad
constitute the keypad’s scope.
29.6.2 Authority levels
Each of your security system users is assigned an
authority level. An authority level determines how much
control the user has for any function that requires a
passcode (turning an area on, for example). The
authority level is set for each area in a multiple area
system so that a user can have different levels in each
area, if desired.
29.6.3 Scope and authority levels combined
The functions you can use at a keypad (turning All On,
for example) are limited to the areas you have authority
in, and the areas that are within a keypad’s scope.
Example
Your security system protects a business configured for
three areas (the office, the warehouse, and shipping),
and three users (1, 2, and 3).
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 177
Keypads details:
–
The keypad in the office area has scope for all areas.
(Users can view the status of all areas – office,
warehouse, and shipping.)
–
The keypad in the warehouse has scope for the
warehouse only.
–
The keypad in shipping has scope for the warehouse
and shipping.
Users details:
–
User 1 has authority to turn the office area on and
off, but no authority in the warehouse or shipping
areas.
–
User 2 has authority in the warehouse and shipping.
–
User 3 has authority in all three areas.
When a user enters his or her passcode into a keypad,
the security system allows the user to perform functions
limited to both the user’s authority level and the
keypad’s scope. What does this mean for the three
users in the example? Specifically, which areas turn on
when the user turns the system All On from each
keypad?
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
178 en | Options
Control Panels
User 1 at the office keypad
Action
Area
Reason
affected
View status?
All three
Keypad’s scope includes
all three areas
Perform
Office
User’s authority is
passcode-
limited to the office
protected
area
functions?
Result of turning the system All On? Only the office area
turns on.
User 1 at the warehouse keypad
Action
Area
Reason
affected
View status?
Warehouse
Keypad’s scope includes
only the warehouse area
Perform
None
User’s authority is
passcode-
limited to the office
protected
area, which is not within
functions?
the warehouse keypad’s
scope
Result of turning the system All On? No area turns on.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 179
User 1 at the shipping keypad
Action
Area
Reason
affected
View status?
Perform
Warehouse
Keypad’s scope includes
and
both the warehouse and
shipping
shipping areas
None
User’s authority is
passcode-
limited to the office
protected
area, which is not within
functions?
the warehouse or
shipping keypad’s scope
Result of turning the system All On? No area turns on.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
180 en | Options
Control Panels
User 2 at the office keypad
Action
Area
Reason
affected
View status?
All three
Keypad’s scope includes
all three areas
Perform
Warehouse
User’s authority is
passcode-
and
limited to the
protected
shipping
warehouse and shipping
functions?
areas
Result of turning the system All On? Only the warehouse
and shipping areas turn on.
User 2 at the warehouse keypad
Action
Area
Reason
affected
View status?
Warehouse
Keypad’s scope includes
only the warehouse area
Perform
Warehouse
User’s authority
passcode-
includes the warehouse
protected
which is in the keypad’s
functions?
scope
Result of turning the system All On? Only the warehouse
area turns on.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 181
User 2 at the shipping keypad
Action
Area
Reason
affected
View status?
Warehouse
Keypad’s scope includes
and
both the warehouse and
shipping
shipping areas
Perform
Warehouse
User’s authority level
passcode-
and
and the keypad’s scope
protected
shipping
include both the
functions?
warehouse and shipping
Result of turning the system All On? Only the warehouse
and shipping areas turn on.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
182 en | Options
Control Panels
User 3 at the office keypad
Action
Area
Reason
affected
View status?
All three
Keypad’s scope includes
all three areas
Perform
All three
passcode-
User’s authority
includes all three areas
protected
functions?
Result of turning the system All On? All three areas turn
on.
User 3 at the warehouse keypad
Action
Area
Reason
affected
View status?
Warehouse
Keypad’s scope includes
only the warehouse area
Perform
Warehouse
User’s authority
passcode-
includes the warehouse
protected
which is in the keypad’s
functions?
scope
Result of turning the system All On? Only the warehouse
area turns on.
2012.12 | 03 | F.01U.265.453
Owner's Manual
Bosch Security Systems, Inc.
Control Panels
Options | en 183
User 3 at the shipping keypad
Action
Area
Reason
affected
View status?
Warehouse
Keypad’s scope includes
and
both the warehouse and
shipping
shipping areas
Perform
Warehouse
User’s authority level
passcode-
and
and the keypad’s scope
protected
shipping
include both the
functions?
warehouse and shipping
Result of turning the system All On? Only the warehouse
and shipping areas turn on.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
184 en | Glossary
Control Panels
Glossary
through the correct
All On
To turn on (arm) both
point and disarm the
interior points and
area. If not disarmed
perimeter points.
before the delay time
expires, the system
bypass
begins an alarm
Selectively remove
points from the security
system. A point may be
bypassed in order to
arm the perimeter with
include reports to the
central station.
exit delay
A programmed delay of
a window open.
system alarm response
closing window
allowing exit after
A duration of time
programmed by your
security company. You
security company can
program the system to
turn on at the end of
the window.
arming an area. Failure
to exit before the delay
time expires, causes
entry delay to begin.
The system must then
be disarmed. If not
disarmed before the
entry delay
A programmed delay of
system alarm response
allowing an individual to
enter an armed area
2012.12 | 03 | F.01U.265.453
response which may
Owner's Manual
delay time expires, the
system begins an alarm
response which may
include reports to the
central station.
Bosch Security Systems, Inc.
Control Panels
faulted points
Glossary | en 185
point
Point that are not
A detection device, or
normal (a door or
group of devices
window is open).
connected to the
security system. Points
keypress tone
display individually at
The beep you hear each
the command
time you press a key.
centerwith custom text.
output
The text can describe a
The system may have
single door, motion
outputs programmed to
sensor, smoke detector,
provide control of
or an area such as
devices such as
premises lighting or
entry gates. The
UPSTAIRS or GARAGE.
trouble
A service condition that
security company
needs to be corrected,
programs outputs for
such as a broken wire.
automatic control
and/or control from the
keypad.
Part On
An arming command
that arms only the
perimeter points.
Bosch Security Systems, Inc.
Owner's Manual
2012.12 | 03 | F.01U.265.453
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450
USA
www.boschsecurity.com
© Bosch Security Systems, Inc., 2012
