PRECAUTIONS
1. Setting up
- Refer to the identification label located on
the rear of your player for its proper operating voltage.
- Install your player in a cabinet with adequate ventilation holes. (7~10cm) Do not
block ventilation holes on any of the components for air circulation.
- Do not push the disc tray in by hand.
- Do not stack components.
- Be sure to turn all components off before
moving the player.
- Before connecting other components to this
player, be sure to turn them off.
- Be sure to remove the disc and turn off the
player after use, especially if you don’t use
it for a long time.
- The mains plug is used as a disconnect
device and shall readily operable at any
time.
2. For your safety
- This product utilizes a laser. Use of controls
or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
- Do not open covers and do not repair yourself. Refer servicing to qualified personal.
3. Caution
- Your player is not intended for industrial use
but for domestic purposes. Use of this product is for personal use only.
- Apparatus shall not be expossed to dripping
or splashing and no objects filled with liquids, such as vases, shall be placed on the
apparatus.
- Exterior influences such as lightning and
static electricity can affect normal operation
of this player. If this occurs, turn the player
off and on again with the POWER button, or
disconnect and then reconnect the AC
power cord to the AC power outlet. The
player will operate normally.
2
- When condensation forms inside the player
due to sharp changes in temperature, the
player may not operate
correctly. If this occurs, leave the player at
room temperature until the inside of the
player becomes dry and operational.
4. Disc
- Do not clean record-cleaning sprays, benzene, thinner, or other volatile solvents that
may cause damage to the disc surface.
- Do not touch the disc’s signal surface. Hold
by the edges or by one edge and the hole
in the center.
- Wipe the dirt away gently; never wipe a
cloth back and forth over the disc.
5. Environmental info
- The battery used in this product contains
chemicals that are harmful to the environ
ment.
- So, dispose of batteries in the proper man
ner, according to federal, state, and local
regulations.
The product unit accompanying this user manual is
licensed under certain intellectual property rights of
certain third parties. This license is limited to private
non-commercial use by end-user consumers for
licensed contents. No rights are granted for
commercial use. The license does not cover any
product unit other than this product unit and the
license does not extend to any unlicensed product
unit or process conforming to ISO/OUR 11172-3 or
ISO/OUR 13818-3 used or sold in combination with
this product unit. The license only covers the use of
this product unit to encode and/or decode audio files
conforming to the ISO/OUR 11172-3 or ISO/OUR
13818-3. No rights are granted under this license for
product features or functions that do not conform to
the ISO/OUR 11172-3 or ISO/OUR 13818-3.
CAUTION: USE OF ANY CONTROLS,
ADJUSTMENTS, OR PROCEDURES OTHER
THAN SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
Remote Control
Batteries for Remote
Control (AAA Size)
User’s Manual
Video/Audio
Cable
Install Batteries in the Remote control
1. Open the battery cover on the back of the remote
control.
2. Insert two AAA batteries.
Make sure that the
polarities (+ and -) are aligned correctly.
3. Replace the battery cover.
s
If remote control doesn’t operate
properly:
- Check the polarity + - of the batteries (Dry-Cell)
- Check if the batteries are drained.
- Check if remote control sensor is blocked by
obstacles.
- Check if there is any fluorescent lighting nearby.
TABLE OF
CONTENT
Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Before you start . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setup
General Features . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Disc Type and Characteristics . . . . . . . . . . . . . . . . 5
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tour of the Remote Control . . . . . . . . . . . . . . . . . . 8
Connections
Choosing a Connection . . . . . . . . . . . . . . . . . . . . . 9
Basic Functions
Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using the Search and Skip Functions . . . . . . . . . 16
Using the Display Function . . . . . . . . . . . . . . . . . 16
Using the Disc and Title Menu . . . . . . . . . . . . . . 16
Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Slow Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Advanced Functions
Adjusting the Aspect Ratio (EZ View) . . . . . . . . . 18
Selecting the Audio Language . . . . . . . . . . . . . . . 18
Selecting the Subtitle Language. . . . . . . . . . . . . . 19
Changing the Camera Angle . . . . . . . . . . . . . . . . 19
Using the Bookmark Function . . . . . . . . . . . . . . . 20
Using the Zoom Function . . . . . . . . . . . . . . . . . . . 20
Clips Menu for MP3/WMA/JPEG/
CD Audio/MPEG4. . . . . . . . . . . . . . . . . . . . . . . . . 21
Folder Selection . . . . . . . . . . . . . . . . . . . . . . . . . . 21
MP3/WMA/CD Audio Playback. . . . . . . . . . . . . . . 21
MPEG4 Playback . . . . . . . . . . . . . . . . . . . . . . . . . 22
Playing Media files Using the USB
Host feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CD Ripping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Picture CD Playback. . . . . . . . . . . . . . . . . . . . . . . 24
Changing Setup Menu
Using the Setup Menu . . . . . . . . . . . . . . . . . . . . . 25
Setting Up the Language Features . . . . . . . . . . . 26
Setting Up the Audio Options . . . . . . . . . . . . . . . . 27
Setting Up the Display Options . . . . . . . . . . . . . . 28
Setting Up the Parental Control . . . . . . . . . . . . . . 29
Reference
Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . 31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 32
USB Host feature supported products . . . . . . . . . 33
Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3
English
BEFORE YOU
STAR T
SETUP
General Features
Excellent Sound
Dolby Digital, a technology developed by Dolby
Laboratories, provides crystal clear sound reproduction.
Screen
Both regular and widescreen(16:9) pictures can be
viewed.
Slow Motion
An important scene can be viewed in slow motion.
Parental Control (DVD)
The parental control allows users to set the level
necessary to prohibit children from viewing harmful
movies such as those with violence, adult subject
matter, etc.
Various On-Screen Menu Functions
You can select various languages (Audio/Subtitle)
and screen angles while enjoying movies.
Progressive Scan
Progressive scanning creates an improved picture
with double the scan lines of a conventional interlaced picture.
EZ VIEW (DVD)
Easy View enables picture adjustment to match
your TV's screen size (16:9 or 4:3).
Digital Photo Viewer (JPEG)
You can view Digital Photos on your TV.
Repeat
You can repeat a song or movie simply by pressing
the REPEAT button.
MP3/WMA
This unit can play discs created from MP3/WMA
files.
MPEG4
This unit can play MPEG4 formats within an avi file.
CD Ripping
This feature lets you to copy audio files from disc to
USB device into MP3 format (only audio CD
(CD DA)).
4
Note
- Discs which cannot be played with this
player.
• DVD-ROM
• DVD-RAM
• CD-ROM
• CDV
• CDI
• CVD
• CDGs play audio only, not graphics.
- Ability to play back may depend on recording
conditions.
• DVD-R, +R
• CD-RW
• DVD+RW, -RW (V mode)
- The unit may not play certain CD-R, CD-RW
and DVD-R due to the disc type or recording
conditions.
COPY PROTECTION
Many DVD discs are encoded with copy protection.
Because of this, you should only connect your DVD
player directly to your TV, not to a VCR. Connecting
to a VCR results in a distorted picture from copyprotected DVD discs.
This product incorporates copyright protection
technology that is protected by methods claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection technology must be auzthorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
PROGRESSIVE SCAN OUTPUTS
(525p)
“CONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE, IN CASE OF 525 PROGRESSIVE
SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING YOUR TV SET COMPATIBILITY
WITH THIS MODEL 525p DVD PLAYER, PLEASE
CONTACT SAMSUNG'S CUSTOMER SERVICE
CENTER.”
Disc Type and Characteristics
Disc Types (Logos)
Recording Types
DVD
Audio
+
Video
VIDEO-CD
Audio
+
Video
AUDIO-CD
Disc Size
Max. Playing Time
Characteristics
12 Cm
Single-sided 240 min.
Double-sided 480 min.
8 Cm
Single-sided 80 min.
Double-sided 160 min.
- DVD contains excellent sound
and video due to Dolby Digital
and MPEG-2 system.
- Various screen and audio functions can be easily selected
through the on-screen menu.
12 Cm
74 min.
8 Cm
20 min.
12 Cm
74 min.
8 Cm
20 min.
Audio
Disc Markings
~
PAL
Play Region Number
PAL broadcast system in
U.K, France, Germany, etc.
Dolby Digital disc
STEREO
DIGITAL
SOUND
Stereo disc
- Video with CD sound, VHS quality & MPEG-1 compression technology.
- CD is recorded as a Digital
Signal with better audio quality,
less distortion and less deterioration of audio quality over time.
Region Number
Both the DVD player and the discs are coded
by region. These regional codes must match in
order for the disc to play. If the codes do not
match, the disc will not play.
The Region Number for this player is
described on the rear panel of the player.
Digital Audio disc
DivX Certification
DTS disc
DivX, DivX Certified, and associated logos are trademarks of
DivXNetworks, Inc and are used
under license.
MP3 disc
You must only insert one DVD disc at a
time. Inserting two or more discs will not
allow to play them back and it may cause
damage to the DVD player.
5
English
This DVD player is capable of playing the following types of discs with the corresponding logos:
Description
Front Panel Controls
9
1 2
1.
2.
3.
4.
4
3
STANDBY/ON (
)
When STANDBY/ON is pressed on, the indicator
goes out and the player is turned on.
STANDBY indicator
When the unit is first plugged in, this indicator
lights.
DISC TRAY
Place the disc here.
USB HOST
Connect digital still camera, MP3 player, memory
stick, Card reader other removable storage
devices.
5.
6.
7.
8.
9.
5
6
7
8
6
OPEN/CLOSE (
)
Press to open and close the disc tray.
SKIP (
/
) SEARCH
Allow you to search forward/backward through
a disc. Use to skip the title, chapter or track.
STOP (
)
Stops disc play.
PLAY/PAUSE (
)
Begin or pause disc play.
DISPLAY
Operation indicators are displayed here.
Front Panel Display
Total playing time/Displays various messages concerning operations such as PLAY,
STOP, LOAD ...
nodSC: No disc loaded.
OPEn: The disc tray is open.
LOAd: Player is loading disc information.
6
Rear Panel
2
English
1
4
3
1.
2.
5.1CH ANALOG AUDIO OUT
JACKS
- Connect to an amplifier with 5.1ch analog input
jacks.
DIGITAL AUDIO OUT JACKS
- Use a coaxial digital cable to connect to a
compatible Dolby Digital receiver.
- Use a coaxial digital cable to connect to an A/V
Amplifier that contains a Dolby Digital, MPEG2
or DTS decoder.
3.
4.
COMPONENT VIDEO OUT
JACKS
- Use these jacks if you have a TV with
Component Video in jacks. These jacks provide PR, PB and Y video.
- If Component(P-SCAN) Video Output is selected in Setup Menu, progressive scan mode will
work.
- If Component(I-SCAN) Video Output is selected in Setup Menu, interlaced scan mode will
work.
VIDEO OUT JACK
- Use a video cable to connect to the Video
input jack on your television.
- The Video Output in Setup Menu must be set
to Component(I-SCAN).
Note
- Consult your TV User’s Manual to find out if your TV supports Progressive Scan.
If Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan
settings in the TV’s menu system.
- See pages 27 ~ 29 to get more information on how to use the setup menu.
7
Tour of the Remote Control
6.
TV VOL (+, -) Buttons
Control volume.
15
16
1
2
17
3
4
5
6
7
8
9
18
7.
SKIP Buttons (
)
/
Use to skip the title, chapter or track.
8.
STOP Button (
9.
MENU Button
)
Brings up the DVD player’s menu.
œ/ƒ,¦/‹ Buttons
10. ENTER/œ
This button functions as a toggle switch.
11. EZ VIEW Button
The aspect ratio of a picture can easily be adjusted
19
20
21
22
according to the screen size of your TV (16:9 or 4:3).
12. DISC MENU Button
Brings up the Disc menu.
13. OPEN/CLOSE (
) Button
To open and close the disc tray.
14. AUDIO Button
10
Use this button to access various audio functions on a disc.
15. DVD Button
11
12
23
24
25
26
13
14
Press this when you use a DVD player.
16. TV Button
Press this to operate TV.
17. REPEAT A-B Button
Allows you to repeat A-B disc.
18. STEP Button/TV Source
Advances play one frame at a time.
Press to select an available TV source (mode TV).
19. SUBTITLE Button
20. TV CH (
,
) Buttons
Channel selection.
21. PLAY/PAUSE Button (
1.
DVD POWER Button
Turns the power on or off.
2.
3.
NUMBER Buttons
ZOOM / (-/--) Button
Enlarge DVD Picture.
Use this to select the channel of TV program by inserted
the channel number (TV mode).
4.
SEARCH Buttons (
)
/
Allow you to search forward/backward through a disc.
5.
VIDEO SEL. Button
Selects video output formats.
8
)
Begin/Pause disc play.
22. RETURN Button
Returns to a previous menu.
23. INFO Button
Displays the current disc mode.
24. CANCEL Button
Use to remove menus or status displays from the
screen.
25. USB Button
26. REPEAT Button
Allows you to repeat play a title, chapter, track, or disc.
CONNECTIONS
The following shows examples of connections commonly used to connect the DVD player with a TV and
other components.
Before Connecting the DVD Player
- Always turn off the DVD player, TV, and other components before you connect or disconnect any cables.
- Refer to the user’s manual of the additional components you are connecting for more information on those
particular components.
Connection to a TV (For Video)
1
Using video/audio cables, connect the VIDEO
(yellow)/AUDIO (red and white) OUT terminals of 5.1 CH
(front L-R) on the rear of the DVD player to the VIDEO
(yellow)/AUDIO (red and white) IN terminals of TV.
2
Turn on the DVD player and TV.
RED
WHITE
YELLOW
Audio Cable
Video Cable
RED
WHITE
YELLOW
3
Press the TV/VIDEO button on the TV's remote
control to select Video.
Note
- Noise may be generated if the audio cable is too close to the power cable.
- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 12 to 14)
- The number and position of terminals can vary depending on your TV set. Please refer to the user's manual of the TV.
- If there is one audio input terminal on the TV, connect it to the [AUDIO OUT][left] (white) terminal of the
DVD player.
- If you press the VIDEO SEL. button when DVD Player is in stop mode or no disc is inserted, the Video
Output mode changes in the following sequence: (COMPONENT (I-SCAN) ➝ COMPONENT(P-SCAN))
9
English
Choosing a Connection
Connection to a TV (Interlace)
- Connecting to your TV using Component video cables.
- You will enjoy high quality and accurate color reproduction images. Component video separates the picture element into black and white(Y), blue(PB), red(PR) signals to present clear and clean images. (Audio
signals are delivered through the audio output.)
1
Using component video cables (not included), connect the
COMPONENT VIDEO OUT terminal on the rear of the
DVD player to the COMPONENT IN terminal of TV.
2
Using the audio cables, connect the AUDIO (red and
white) OUT terminals of 5.1 CH (Front L-R)on the rear of
the DVD player to the AUDIO (red and white) IN terminals
of TV. Turn on the DVD player and TV.
BLUE
GREEN
RED
RED
WHITE
3
Press the TV/VIDEO button on the TV's remote control to
select Component or DVD.
Audio Cable
RED
WHITE
RED
BLUE
GREEN
Component cable
(not included)
4
Set the Video Output to Component (I-SCAN) in the
Display Setup menu. (See pages 28 to 29)
Note
- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 12 to 14)
- The component terminal of TV can be marked by “R-Y, B-Y, Y” or “Cr, Cb, Y” instead of “PR, PB, Y”
depending on the manufacturer. The number and position of terminals can vary depending on the TV set.
Please refer to the user's manual of the TV.
10
Connection to a TV (Progressive)
1
2
BLUE
English
Using component video cables (not included), connect the
COMPONENT VIDEO OUT terminal on the rear of the
DVD player to the COMPONENT IN terminal of TV.
GREEN
Using the audio cables, connect the AUDIO (red and
white) OUT terminals 5.1 CH (Front L-R) on the rear of the
DVD player to the AUDIO (red and white) IN terminals of
TV. Turn on the DVD player and TV.
RED
RED
3
Press the input selector on your TV remote control until the
Component signal from the DVD player appears on the TV
screen.
WHITE
Audio Cable
RED
WHITE
RED
BLUE
GREEN
Component cable
(not included)
4
Set the Video Output to Component (P-SCAN) in the
Display Setup menu. (See pages 28 to 29)
To see the progressive video output,
-You
Consult
TVsupporting
User’s Manual
to find out
need ayour
TV set
the progressive
scanif your TV supports Progressive Scan. If Progressive
Scan isfunction.
supported,
follow
TV up
User’s
Manual regarding Progressive Scan settings in the TV’s
input
And you
havethe
to set
the TV
menu system.
- Depending on your TV, the connection method may differ from the illustration above.
Note
- What is "Progressive Scan"?
Progressive scan has twice as many scanning lines as the interlace output method has. Progressive
scanning method can provide better and clearer picture quality.
11
Connection to an Audio System (2 Channel Amplifier)
1
Using the audio cables, connect the AUDIO (red and
white) OUT terminals of 5.1 CH (Front L-R)on the rear of
the DVD player to the AUDIO (red and white) IN terminals of the Amplifier.
2
Using the video signal cable(s), connect the VIDEO or
COMPONENT OUT terminals on the rear of the DVD player to the VIDEO or COMPONENT IN terminal of your TV.
RED
3
WHITE
Audio Cable
Turn on the DVD player, TV, and Amplifier.
RED
WHITE
2-channel amplifier
4
Press the input select button of the Amplifier to select external input in order to hear sound from the DVD player.
Note
- Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause
damage to the speakers and your ears.
- Please set the audio in the menu screen according to the Amplifier. (See pages 27 to 28)
- The position of terminals can vary depending on the Amplifier.
Please refer to the user's manual of the Amplifier.
12
Connection to an Audio System (Dolby digital, MPEG2 or DTS Amplifier)
1
English
If using a coaxial cable (not included), connect the DIGITAL AUDIO OUT (COAXIAL) terminal on the rear of the
DVD player to the DIGITAL AUDIO IN (COAXIAL) terminal of the Amplifier.
2
Using the video signal cable(s), connect the VIDEO or
COMPONENT OUT terminals on the rear of the DVD player to the VIDEO or COMPONENT IN terminal of TV.
Coaxial Cable
(not included)
3
Turn on the DVD player, TV, and Amplifier.
4
Press the input select button of the Amplifier to select
external input in order to hear sound from the DVD player.
Note
- Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause
damage to the speakers and your ears.
- Please set the audio in the menu screen according to the Amplifier. (See pages 27 to 28)
- The position of terminals can vary depending on the Amplifier.
Please refer to the user's manual of the Amplifier.
13
Connection to a 5.1CH Analog Amplifier
1
If using audio cables for 5.1 CH Analog Amplifier (not
included) connect the 5.1CH ANALOG AUDIO OUT terminals on the rear of the DVD player to the 5.1CH ANALOG
AUDIO IN terminals of the 5.1CH Analog Amplifier.
2
Using the video signal cable(s), connect the VIDEO or
COMPONENT terminals on the rear of the DVD player to
the VIDEO or COMPONENT terminals of your TV as
described on pages 9 to 11.
RED
3
RED
WHITE
WHITE
BLACK
BLACK
Turn on the DVD player, TV, and Amplifier.
5.1ch Analog
Amplifier
4
Press the input select button of the Amplifier to select external input in order to hear sound from the DVD player.
Note
- Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause
damage to the speakers and your ears.
- Please set the audio in the menu screen according to the Amplifier. (See pages 27 to 28)
- The position of terminals may vary depending on the Amplifier.
Please refer to the user's manual of the Amplifier.
14
Playing a Disc
Before Play
- Turn on your TV and set it to the correct Video
Input by pressing TV/VIDEO button on the TV
remote control.
- If you connected an external Audio System, turn
on your Audio System and set it to the correct
Audio Input.
After plugging in the player, the first time you press the DVD
POWER button, this screen comes up: If you want to select
a language, press a NUMBER button. (This screen will only
appear when you plug in the player for the first time.)
If the language for the startup screen is not set, the settings
may change whenever you turn the power on or off.
Therefore, make sure that you select the language you want
to use.
Once you select a menu language, you can change it by
pressing the
button on the front panel of the unit for
more than 5 seconds with no disc in the unit. Then the
SELECT MENU LANGUAGE window appears again where
you can reset your preferred language.
Playback
1. Press the OPEN/CLOSE ( ) button. The STANDBY
indicator light goes out and the tray opens.
2. Place a disc gently into the tray with the disc’s label facing
up.
- You must only insert one DVD disc at a time.
Inserting two or more discs will not allow to play
them back and it may cause damage to the DVD
player.
3. Press the PLAY/PAUSE ( ) button or OPEN/ CLOSE
( ) button to close the disc tray.
- When you stop disc play, the player remembers
where you stopped, so when you press
PLAY/PAUSE ( ) button again, it will pick up where
you left off. (unless the disc is removed or the player
is unplugged, or if you press the STOP ( ) button
twice.)
4. Stopping Play
Press the STOP ( ) button during play.
5. Removing Disc
Press the OPEN/CLOSE ( ) button.
6. Pausing Play
Press the PLAY/PAUSE ( ) or STEP button on the
remote control during play.
- Screen stops, no sound.
To resume, press the PLAY/PAUSE ( )
button once again.
7. Step Motion Play (Except CD)
Press the STEP button on the remote control during play.
- Each time the button is pressed, a new frame will
appear.
- No sound is heard during STEP mode.
- Press the PLAY/PAUSE ( ) button to resume
normal play.
- You can only perform step motion play in the
forward direction.
8. Slow Motion Play
Press and hold the SEARCH ( / ) button to choose
the play speed between 1/8, 1/4 and 1/2 of normal during
PAUSE or STEP mode.
- No sound is heard during slow mode.
- Press the PLAY/PAUSE ( ) button to resume
normal play.
Note
- If the player is left in the stop mode for more
than one minute without any user interaction, a
screen saver will be activated. Press the
PLAY/PAUSE ( ) button to resume normal play.
- If the player is left in the stop mode for more than
about 30 minutes, the power will automatically
shut off except when the MIC is connected.
(Automatic Power-Off Function)
- If the player is left for about 5 minutes in pause
mode, it will stop.
- This (
) icon indicates an invalid button press.
15
English
BASIC FUNCTIONS
Using the Search and Skip
Functions
During play, you can search quickly through a chapter or track, and use the skip function to jump to the
next selection.
Searching through a Chapter or
Track
During play, press the SEARCH ( or
) button on
the remote control for more than 1 second.
DVD
2X, 4X, 64X, 128X
VCD
4X, 8X
CD
2X, 4X, 8X
2. Press the œ/ƒbuttons to select the desired item.
- Only Menu Off is available for VCD2.0. Each press of
the DISC MENU button toggles between Menu On and
Menu Off.
3. Press the ¦/‹ buttons to make the desired setup and then
press the ENTER button.
- You may use the number buttons of the remote control
to directly access a title, chapter or to start the
playback from the desired time.
4. To make the screen disappear, press the CANCEL button.
Note
To access the desired title when there is
more than one in the disc. For example, if
there is more than one movie on a DVD,
each movie will be identified.
Note
- The speed marked in this function may be different from
the actual speed of playback.
- No sound is hearing during search mode (Except CD).
Chapter
Allows playback of the film from a desired
time. You must enter the starting time as a
reference.The time search function does not
operate on some disc.
Skipping Tracks
During play, press the SKIP (
or
) button.
- When playing a DVD, if you press the SKIP (
) button, it
moves to the next chapter. If you press the SKIP (
)
button, it moves to the beginning of the chapter. One more
press makes it move to the beginning of the previous
chapter.
- When playing a VCD 2.0 in Menu Off mode, or a VCD 1.1
or a CD, if you press the SKIP (
) button, it moves to
the next track. If you press the SKIP (
) button, it moves
to the beginning of the track. One more press makes it
move to the beginning of the previous track.
- If a track exceeds 15 minutes when playing a VCD and
you press the
If you press the
button, it moves forward 5minutes.
button, it moves backward 5 minutes.
Note
Only Menu Off is available for VCD2.0. Each press of the
DISC MENU button toggles between Menu On and Menu
Off.
Most DVD discs are recorded in chapters so
that you can quickly find a specific passage
(similar to tracks on an VCD).
Audio
Refers to the language of the film soundtrack.
In the example, the soundtrack is played in
English 5.1CH. A DVD disc can have up to
eight different soundtracks.
Refers to the subtitle languages available in
the disc. You will be able to choose the
subtitle languages or, if you prefer, turn them
off from the screen. A DVD disc can have up
to 32 different subtitles.
To access the desired Bookmark or Angle
function.
Some DVD discs are have more angle function from any picture.
Bookmark function make you easily and
quickly to find a track or chapter from DVD
or VCD ( Menu Off).
The EZ View function is use for changing the
aspect ratio in DVD.
Using the Disc and Title
Menu
Using the Disc Menu
1. During Stop mode, press the MENU button on the remote
control.
Using the Display Function
When Playing a DVD/VCD/MPEG4
1. During play, press the INFO button on the remote control.
16
2. Press the œ/ƒ buttons to select Disc Menu, then press the
‹ or ENTER button.
Press ENTER key
for Disc Menu
Using the A-B Repeat function
- Depending on a disc, the Disc Menu may not work.
- You can also use the Disc Menu, using the DISC
MENU button on the remote control.
- Only Menu Off is available for VCD2.0. Each press of
the DISC MENU button toggles between Menu On and
Menu Off.
1. Press the REPEAT button on the remote control.
2. Press the ¦/‹ buttons to Select A-B button.
3. Press the ENTER button at the point where you want
repeat play to start (A). B is automatically highligh ted.
4. Press the ENTER button at the point where you want the
repeat play to stop (B).
- To return to normal play, press the CANCEL button.
Using the Title Menu
1. During stop mode, press the MENU button on the remote
control.
5. To return to normal play, press REPEAT button again, then
press the ¦/‹ buttons to select Off and press ENTER
button.
DVD
2. Press the œ/ƒ buttons to select Title Menu, then press
the ‹ or ENTER button.
Off
Off
Note
- Depending on a disc, the Title Menu may not
work.
- Title Menu will only be displayed if there are at
least two titles in the disc.
Repeat Play
Repeat the current track, chapter, title, a chosen
section (A-B), or all of the disc.
When playing a DVD/VCD
1. Press the REPEAT button on the remote control.
Repeat screen appears.
2. Press the ¦/‹ buttons to select Chapter, Title or A-B,
then press the ENTER button.
- DVD repeats play by chapter or title, VCD
repeat play by disc or track.
- Chapter ( ): repeats the chapter that is playing.
- Title ( ): repeats the title that is playing.
- Disc ( ): repeats the disc that is playing.
- Track ( ): repeats the track that is playing.
- A-B: repeats a segment of the disc that you select.
T
01 A - B
T
ENTER REPEAT
VCD
Press ENTER key
for Title Menu
.
01
T
01
D
01 A - B
ENTER REPEAT
Note
- A-B REPEAT does not allow you to set point (B)
until at least 5 seconds of playback time has
elapsed after point (A) has been set.
- Depending on a disc, the Repeat function may
not work.
- Only Menu Off is available for VCD2.0. Each
press of the DISC MENU button toggles
between Menu On and Menu Off.
Slow Play
This feature allows you slowly to repeat scenes containing sports, dancing, musical instruments being
played etc., so you can study them more closely.
When playing a DVD
1. During play, press the PLAY/PAUSE (
) button.
2. Press and hold the SEARCH ( / ) button to choose the
play speed between 1/8, 1/4 and 1/2 of normal during
PAUSE or STEP mode.
DVD
Off
01
01 A - B
VCD
Off
T
01
D
01 A - B
ENTER REPEAT
17
English
Note
If you are using a 4:3 TV
ADVANCED
FUNCTIONS
For 16:9 aspect ratio discs
Adjusting the Aspect Ratio
(EZ View)
To play back using aspect ratio
(DVD)
1. During play, press the INFO button on the remote control.
2. Press the œ/ƒ buttons to select Shortcut.
3. Press the ¦/‹ buttons to select EZ View, then press
ENTER button.
4:3 Letter Box
- 4:3 Letter Box
Displays the content of the DVD title in 16:9 aspect ratio. The
black bars will appear at the top and bottom of the screen.
- 4:3 Pan&Scan
The left and right portions of the screen are cut off and the
central portion of the 16:9 screen is displayed.
- SCREEN FIT
The top and bottom portions of the screen are cut off and a
full screen appears. The picture will look vertically stretched.
- ZOOM FIT
The top, bottom, left and right of the screen are cut off and
the central portion of the screen is enlarged.
EZ VIEW
For 4:3 aspect ratio discs
- The screen size changes when the ‹button is pressed
repeatedly.
- The screen zoom mode operates differently depending on the
screen setting in the Display Setup menu.
- To ensure correct operation of the EZ VIEW button, you
should set the correct aspect ratio in the Display Setup
menu. (See pages 28 to 29).
If you are using a 16:9 TV
For 16:9 aspect ratio discs
- WIDE SCREEN
Displays the content of the DVD title in 16:9 aspect ratio.
- SCREEN FIT
The top and bottom portions of the screen are cut off.
When playing a 2.35:1 aspect ratio disc, the black bars at
the top and bottom of the screen will disappear. The picture
will look vertically stretched. (Depending on a type of disc,
the black bars may not disappear completely.)
- ZOOM FIT
The top, bottom, left and right of the screen are cut off and
the central portion of the screen is enlarge
For 4:3 aspect ratio discs
- Normal Wide
Displays the content of the DVD title in 16:9 aspect ratio.
The picture will look horizontally stretched.
- SCREEN FIT
The top and bottom portions of the screen are cut off and
the full screen appears.
The picture will look vertically stretched.
- ZOOM FIT
The top, bottom, left and right portions of the screen are
cut off and the central portion of the screen is enlarged.
- Vertical Fit
When a 4:3 DVD is viewed on a 16:9 TV, black bars will
appear at the left and right of the screen in order to prevent
the picture from looking horizontally stretched.
- Normal Screen
Displays the content of the DVD title in 4:3 aspect ratio.
- SCREEN FIT
The top and bottom portions of the screen are cut off and the
full screen appears. The picture will look vertically stretched.
- ZOOM FIT
The top, bottom, left and right portions of the screen are cut
off and the central portion of the screen is enlarged.
Note
This function may behave differently depending on
the type of disc.
Selecting the Audio
Language
You can select a desired audio language quickly and
easily with the AUDIO button.
Using the AUDIO button
1. Press the AUDIO button. The Audio changes when the
button is pressed repeatedly.
The audio languages are represented by
abbreviations.
DVD
ENG DOLBY DIGITAL 5.1CH
AUDIO
VCD
When playing a VCD, you
can select among Stereo,
Left or Right.
Stereo
AUDIO
Press Audio button at remote control repeatly to select the
desired audio on MPEG4 then press the ENTER.
18
PCM 1/2
2. To remove the AUDIO icon, press the CANCEL or RETURN button.
Note
- This function depends on audio languages are
encoded on the disc and may not work.
- A DVD disc can contain up to 8 audio languages.
- To have the same audio language come up
whenever you play a DVD;
Refer to “Using the Audio Language” on page
26.
Note
- You have to change the desired subtitle in the
Disc Menu, according to discs. Press the DISC
MENU button.
- This function depends on what subtitles are
encoded on the disc and may not work on all
DVDs.
- A DVD disc can contain up to 32 subtitle
languages.
- To have the same subtitle language come up
whenever you play a DVD; Refer to “Using the
Subtitle Language” on page 26.
Changing the Camera
Angle
When a DVD contains multiple angles of a particular
scene, you can use the ANGLE function.
Selecting the Subtitle
Language
You can select a desired subtitle quickly and easily
with the SUBTITLE button.
Using the SUBTITLE button (DVD)
1. Press the SUBTITLE button. The subtitle languages are
represented by abbreviations. The subtitle changes when
the button is pressed repeatedly.
Using the ANGLE Function (DVD).
If the disc contains multiple angles, the ANGLE
appears on the screen.
1. During play, press the INFO button on the remote control.
2. Press the œ/ƒ buttons to select Shortcut.
3. Press the ¦/‹ buttons to select Angle, then press ENTER
button.
DVD
Off
SUBTITLE
4. Press the ¦/‹ buttons on the remote control to select the
desired angle.
MPEG4
Subtitle Selection
External Subtitle option
will appear, depends on
the DivX disc.
External Subtitle Off
4/6
readme.TXT
Non-standard fonts are not supported
Enter
Return
Menu
Press SUBTITLE button at remocon repeatly to select the
disired subtitle language on MPEG4 then press the ENTER.
MPEG4
Off
SUBTITLE
2. To remove the SUBTITLE icon, press the CANCEL or
RETURN button.
19
English
MPEG4
Using the Bookmark
Function
5. Press the PLAY/PAUSE (
scene.
) button to skip to the marked
This feature lets you bookmark sections of a DVD or
VCD (Menu Off mode) so you can quickly find them
at a later time.
Using the Bookmark Function
(DVD/VCD)
Clearing a Bookmark
1. During play, press the INFO button on the remote control.
2. Press the œ/ƒ buttons to select Shortcut.
5. Press the CANCEL button to delete a bookmark number.
1~3. The first 1~3 steps are the same as those for “Using the
Bookmark Function” on page 20.
4. Press the ¦/‹ buttons to select the bookmark number you
want to delete.
1 2 3
DVD
Using the Zoom Function
VCD
Using the Zoom Function
(DVD/VCD)
3. Press the ¦/‹ buttons to select Bookmark(except VCD),
then press the ENTER button.
4. When you reach the scene you want to mark, press the
ENTER button. Up to three scenes may be marked at a time.
1 - -
Note
- Only Menu Off is available for VCD2.0. Each
press of the DISC MENU button toggles
between Menu On and Menu Off.
- Depending on a disc, the Bookmark function
may not work.
Recalling a Marked Scene
1~3. The first 1~3 steps are the same as those for “Using the
Bookmark Function” on page 20.
4. Press the ¦/‹ buttons to select a marked scene.
1 2 3
20
1. During play or pause mode, press the ZOOM button on the
remote control, press the ENTER button.
2. Press the œƒ¦‹ buttons to select the part of the
screen you want to zoom in on.
- During DVD play, press ENTER to zoom in
2X/4X/2X/Normal in order.
- During VCD play, press ENTER to zoom in
2X/4X/2X/Normal in order.
Clips Menu for
MP3/WMA/JPEG/CD
Audio/MPEG4
- To select the Sub-Folder
Press the ¦/‹ buttons to highlight right window.
ƒ buttons to select the desired folder,
Press the œ/ƒ
then press ENTER.
Open the disc tray.
Place the disc on the tray.
Close the tray.
The tray closes and this
screen displays.
Stop
Off
R oot
W MA
JPEG
English
CD Audio or discs with MP3/WMA/JPEG/MPEG4
contain individual songs and/or pictures that can be
organized into folders as shown below. They are similar to how you use your computer to put files into different folders.
P arent Fol der
MP 3
MU S IC
C urrent Fol der
1s t
S ub-Fol ders
2nd
S ON G FILE 1
P eer Fol ders
S ON G FILE 2
S ON G FILE 3
MP E G4 FILE S
-
: Name of currently playing file.
-
: Current Playback Time.
-
MP3 /WMA /CD Audio
Playback
: Current Playback Mode : There are four
modes. They can be selected in order by
pressing the REPEAT button.
- Off: Normal Playback
- Track: Repeats the current track.
- Folder: Repeats the current folder.
- Random: Files in the disc will be played
in random order.
-
: MP3 file icon. -
: Folder icon.
-
: WMA file icon. -
: Current Folder icon.
-
: JPEG file icon.
-
: AVI file icon.
-
: CD Audio file icon.
Folder Selection
The folder can be selected in Stop or Play mode.
- To select the Parent Folder
Press the RETURN button to go to parent folder, or press the
œ/ƒ
ƒ buttons to select “..” and press ENTER to go to the
parent folder.
- To select the Peer Folder
Press the ¦/‹ buttons to highlight left window. Press the
œ/ƒ
ƒ buttons to select the desired folder, then press
ENTER.
1. Open the disc tray. Place the disc on the tray. Close the tray.
- Only one kind of file is played back when a disc or a
folder contains both MP3 and WMA files.
ƒ or ¦/‹
‹ buttons to select a song file.
2. Press the œ/ƒ
Press ENTER to begin playback of the song file.
Play
Off
Repeat/Random playback
Press the REPEAT button to change the playback mode. There
are four modes, such as Off, Track, Folder and Random.
- Off: Normal Playback
- Track: Repeats the current song file.
- Folder: Repeats the song files which have the same
extension in the current folder.
- Random: Song files which have the same extension will be
played in random order.
To resume normal play, press the CANCEL button.
CD-R MP3/WMA file
When you record MP3 or WMA files on CD-R, please refer
to the following.
- Your MP3 or WMA files should be ISO 9660 or JOLIET
format.
21
ISO 9660 format and Joliet MP3 or WMA files are
compatible with Microsoft's DOS and Windows, and with
Apple's Mac. This format is the most widely used.
- When naming your MP3 or WMA files, do not exceed 8
characters, and enter “.mp3, .wma” as the file extension.
General name format : Title.mp3. or Title.wma. When
composing your title, make sure that you use 8 characters or
less, have no spaces in the name, and avoid the use of
special characters including: (.,/,\,=,+).
- Use a decompression transfer rate of at least 128 Kbps
when recording MP3 files.
Sound quality with MP3 files basically depends on the rate of
compression/decompression you choose. Getting CD audio
sound requires an analog/digital sampling rate, that is
conversion to MP3 format, of at least 128 Kbps and up to 160
Kbps. However, choosing higher rates, like 192 Kbps or more,
only rarely give better sound quality. Conversely, files with
decompression rates below 128 Kbps will not be played
properly.
- Use a decompression transfer rate of at least 64Kbps
when recording WMA files.
Sound quality with WMA files basically depends on the rate of
compression/decompression you choose.
Getting CD audio sound requires an analog/digital sampling
rate, that is conversion to WMA format, of at least 64Kbps
and up to 192Kbps. Conversely, files with decompression
rates below 64Kbps or over 192Kbps will not be played
properly.
- Do not try recording copyright protected MP3 files.
Certain "secured" files are encrypted and code protected to
prevent illegal copying. These files are of the following types:
TM
Windows Media (registered trade mark of Microsoft Inc) and
TM
SDMI (registered trade mark of The SDMI Foundation). You
cannot copy such files.
- Important:
The above recommendations cannot be taken as a
guarantee that the DVD player will play MP3 recordings, or as
an assurance of sound quality. You should note that certain
technologies and methods for MP3 file recording on CD-Rs
prevent optimal playback of these files on your DVD player
(degraded sound quality and in some cases, inability of the
player to read the files).
- This unit can play a maximum of 500 files and 500 folders
per disc.
MPEG4 Playback
MPEG4 Play Function
AVI files are used to contain the audio and video
data. Only AVI format files with the “.avi” extensions
can be played.
22
1. Open the disc tray. Place the disc on the tray.
Close the tray.
ƒ or ¦/‹
‹ buttons to select an avi file
2. Press the œ/ƒ
(DivX/XviD), then press the ENTER button.
Stop
Off
Repeat Playback
Press the REPEAT button to change playback mode. There
are 3 modes, such as Off, Folder and Title.
- Folder : Repeats the AVI files which have the same extension in the current folder.
- Title : repeats the title that is playing.
MPEG4 Function Description
(
(
Function
Description
Reference page
Skip
or
During play, press the
or
button, it moves forward or
backward 5 minutes.
During play, press the SEARCH (
or
) button and press again to
search at a faster speed. Allows you
to search at a faster speed in an
AVI file. (2X, 4X, 8X)
Allows you to search at a slower
speed in an AVI file. (1/8X, 1/4X,
1/2X)
Each time the STEP button is
pressed, a new frame will
appear.
-
)
Search
or
)
Slow Motion
Play
Step Motion
Play
ZOOM
2X/4X/2X/Normal in order
-
P 15
P 15
P 20
- These functions may not work depending on MPEG4 file.
CD-R AVI file
This unit can play the following video compression formats
within the AVI file format:
- DivX 3.11 contents
- DivX 4 contents (Based on MPEG4 Simple Profile)
- DivX 5 contents (MPEG4 simple profile plus additional features such as bi-directional frames. Qpel and GMC are also
supported.)
- XviD MPEG4 compliant Contents.
This unit supports all resolutions up to maximum below.
DivX3.11 & DivX4 & XviD
DivX5
Bitrate may fluctuate:
720 x 480 @30fps
Device may skip decoding the
720 x 576 @25fps
high bitrate portions and begin
: Maximum bitrate : 4Mbps
decoding again when Bitrate
returns to
normal.
- This unit supports CD-R/RW written in MPEG4 in
accordance with the “ISO9660 format”.
Skip Forward/Back
During playback, press the (
/
) button.
• When there is more than one file, when you press the
button, the next file is selected.
• When there is more than one file, when you press the
button, the previous file is selected.
Fast playback
Playing Media Files Using
the USB Host feature
To play back the disc at a faster speed, press
(
/
) during playback.
You can enjoy the media files such as pictures, movies and
• Each time you press either button, the playback speed will
change as follows:
2x ➞ 4x ➞ 8x.
tunes saved in an MP3 player, USB memory or digital cam-
Compatible Devices
era in high audio by connecting the storage device to the
USB port of the DVD Player.
Using the USB HOST feature
1. Connect the USB device to the USB host on the front of the
player.
ƒ button to
2. If the USB have any partition, press the œ/ƒ
select part of partition from USB which you want to play,
then press the ENTER button.
Disc
USB
ƒ or ¦/‹
‹ buttons to select a file in the
3. Press the œ/ƒ
USB. then press ENTER to open or playing the file.
STOP
Off
00:00:00
1. USB devices that support USB Mass Storage v1.0.
(USB devices that operate as a removable disk in Windows
(2000 or later) without additional driver installation.)
2. MP3 Player: HDD and flash type MP3 player.
3. Digital camera: Cameras that support USB Mass Storage
v1.0.
• Cameras that operate as a removable disk in Windows
(2000 or later) without additional driver installation.
4. USB HDD and USB Flash Drive: Devices that support
USB2.0 or USB1.1.
• You may experience a difference in playback quality when
you connect a USB1.1 device.
• For a USB HDD, make sure to connect an auxiliary power
cord to the USB HDD for proper operation.
5. USB card Reader: One slot USB card reader and Multi slot
USB card reader
• Depending on the manufacturer. the USB card reader
may not be supported.
• If you install multiple memory devices into a multi card
reader, you may experience problems.
6. If you use a USB extension cable, the USB device might not
be recognized.
• Supported Formats
File Name
Note
• Each time the USB button on the remote control is
pressed, a frame of the USB device selection will appear.
• “USB” appears on the display screen.
• USB MENU screen appears on the TV screen and the
saved file is played.
Still Picture
Music
Movie
File Extension
Bit Rate
Version
Pixel
Sampling
Frequency
JPG
JPG .JPEG
—
—
640*480
—
MP3
.MP3
80~384kbps
—
—
44.1kHz
WMA
.WMA
56~128kbps
V8
—
44.1kHz
VCD
.MPG.MPEG
1.5Mbps
VCD1.1,VCD2.0
320*480
44.1KHz
DivX
.AVI,.ASF
4Mbps
DivX3.11~DivX5.1,Xvid 720*480 44.1KHz~48KHz
Safe USB Removal
To prevent damage to the memory stored in the USB device,
perform safe removal before disconnecting the USB cable.
- Press the STOP (
) button.
- Remove the USB cable.
23
English
Note
- Some MPEG4 files created on a personal computer may not be play back.
That is why Codec Type, Version and Higher resolution over specification is not supported.
• CBI (Control/Bulk/Interrupt) is not supported.
• Digital Cameras that use PTP protocol or require additional
program installation when connected to a PC are not supported.
• A device using NTFS file system is not supported.
(Only FAT 16/32 (File Allocation Table 16/32) file system is
supported.)
• Some MP3 players, when connected to this product,may not
operate depending on the sector size of their file system.
• The USB HOST function is not supported if a product that
transfers media files by its manufacturer-specific program is
connected.
• Does not operate with Janus enabled MTP(Media Transfer
Protocol) devices.
• The USB host function of this product does not support
all USB devices.
For information on the supported devices, see page 34.
ƒ buttons to select START, then press the
3. Press the œ/ƒ
ENTER button.
File copy begins.
- To cancel the copying in progress, press the CANCEL
button.
PLAY
00:03:15
Track 02
Track 03
DEV : USB 1
UNSELECT
START
Track 04
Track
05
CD
Ripping
START...
Track 06
Track 07
CANCEL
Cancel Ripping
Enter
REPEAT
Repeat
Note
- When the CD ripping is being processed the
player will atoumatic in play mode.
- Only Audio CD (CD DA) discs that can be ripping.
Picture CD Playback
This feature lets you to copy audio files from disc to
USB device into MP3 format.
STOP
Off
Track 01
T
1. Select the desired folder.
ƒ buttons to select a Picture file in the clips
2. Press the œ/ƒ
menu and then press the ENTER button.
3. Press the INFO button on the remote control to select the
menu you want to view and then press the ENTER button.
00:00:00
Track 01
Track 02
DEV : SELECT
START
Track 03
Connect the USB device to the
USB host on the front of the
player.
This screen will displayed.
T
Track 01
CD Ripping
Open the disc tray.
Place a Audio CD (CD DA) on
the tray, then close the tray.
Off
Track 01
Track 04
Track 05
ENTER RETURN
Track 06
Track 07
Track 08
Enter
Menu
1. To Select DISC
ƒ buttons to select
With the unit in Stop mode, press the œ/ƒ
DISC.
To Select DEV (storage media device)
Press the ‹button to select DEV (storage media device)
menu, then press the ENTER button.
ƒbuttons to select USB, then press the ENTER
Press the œ/ƒ
button.
STOP
Note
- If no buttons on the remote control are pressed for
10 seconds, the menu will disappear.
- Press the STOP button to return to the clips menu.
- When playing a Kodak Picture CD, the unit displays
the Photo directly, not the clips menu.
Rotation
Off
Track 01
Disc
T
: Each time the ENTER button is pressed, the
picture rotates 90 degrees clockwise.
00:00:00
USB
Track 01
Track 02
DEV : USB 1
UNSELECT
START
Track 03
Track 04
Track 05
Track 06
Zoom
Track 07
Track 08
Enter
ƒ buttons to select SELECT, then press the
2. Press the œ/ƒ
ENTER button to marked all files to be copying.
- To unmarked copying all files, press the ENTER button
once again (UNSELECT Menu).
- If you want to marked several files to be copying, press
the ¦ button, then press the ENTER button on the
selected file.
24
ƒ buttons to select the part of the
: Press the œ/ƒ
screen you want to zoom in on.
Press the ENTER button. Each time the ENTER button is pressed, the picture is enlarged up to 2X.
Menu
Slide Show
•
: The unit enters slide show mode.
• Before beginning the Slide Show, the picture interval must
be set.
: When this icon is selected and ENTER is
pressed, the pictures change automatically
with about a 6 second interval.
•
: The pictures change automatically with
about a 12 second interval.
•
: The pictures change automatically with
about a 18 second interval.
TIMER:
CHANGING SETUP
MENU
Using the Setup Menu
ENTER RETURN
The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have.
1. With the unit in Stop mode, press the MENU button on the
ƒ buttons to select Setup, then
remote control. Use the œ/ƒ
press the ‹ or ENTER button.
Note
- Depending on a file size, the amount of time
between each picture may be different from the
manual.
- If you don’t press any button, the slide show will
start automatically in about 10 seconds by default.
CD-R JPEG Discs
- Only files with the “.jpg” and “.JPG” extensions can be played.
- If the disc is not closed, it will take longer to start playing and
not all of the recorded files may be played.
- Only CD-R discs with JPEG files in ISO 9660 or Joliet format
can be played.
- The name of the JPEG file may not be longer than 8
characters and should contain no blank spaces or special
characters (. / = +).
- Only a consecutively written multi-session disc can be played.
If there is a blank segment in the multi-session disc, the disc
can be played only up to the blank segment.
- A maximum of 500 images can be stored on a single CD.
- Kodak Picture CDs are recommended.
- When playing a Kodak Picture CD, only the JPEG files in the
pictures folder can be played.
- When playing a Kodak Picture CD, only the JPEG files in the
pictures folder can be played.
- Kodak Picture CD: The JPEG files in the pictures folder can
be played automatically.
- Konica Picture CD: If you want to see the Picture, select the
JPEG files in the clips menu.
- Fuji Picture CD: If you want to see the Picture, select the
JPEG files in the clips menu.
- QSS Picture CD: The unit may not play QSS Picture CD.
- If the number of files in 1 Disc is over 500, only 500 JPEG
files can be played.
- If the number of folders in 1 Disc is over 500, only JPEG
files in 500 folders can be played
Language Setup
‹
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
❶ Language Setup: Setup of the Language.
❷ Audio Setup : Setup of the Audio Options.
❸ Display Setup : Setup of the Display Options. Use to
select which type of screen you want to watch and sever
al display options.
❹ Parental Setup : Setup of the Parental Level. Allows
users to set the level necessary to prevent children from
viewing unsuitable movies such as those with violence,
adult subject matter, etc.
❺ DivX(R) Registration : Please use the Registration code
to register this player with the DivX(R) Video On
Demand format. To learn more go to www.divx.com/vod.
ƒ buttons to access the different features.
2. Press the œ/ƒ
Press the ‹ or ENTER button to access the sub features.
3. To make the setup screen disappear after setting up, press
the MENU button again.
Note
Depending on the disc, some Setup Menu selections may not work.
25
English
•
Setting Up the Language
Features
If you set the player menu, disc menu, audio and
subtitle language in advance, they will come up
automatically every time you watch a movie.
Using the Player Menu Language
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Language Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
ƒ buttons to select Player Menu, then press
4. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select the desired language,
5. Press the œ/ƒ
then press the ‹ or ENTER button.
- The language is selected and the screen
returns to Language Setup menu.
- To make the setup menu disappear, press the MENU
button.
Using the Audio Language
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Language Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
ƒ buttons to select Audio, then press the ‹
4. Press the œ/ƒ
or ENTER button.
ƒ buttons to select the desired language, then
5. Press the œ/ƒ
press the ‹ or ENTER button.
- Select “Original” if you want the default soundtrack
language to be the original language the disc is
recorded in.
- If the selected language is not recorded on the disc, the
original pre-recorded language is selected.
- The language is selected and the screen returns to
Language Setup menu.
- To make the setup menu disappear, press the MENU
button.
LANGUAGE SETUP
Player Menu
: English
Original
: English
English
: English
Deutsch
: English
: English
Italiano
Disc Menu
Audio
Subtitle
DivX Subtitle
Enter
Return
Menu
Using the Subtitle Language
Using the Disc Menu Language
This function changes the text language only on the
disc menu screens.
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Language Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
ƒ buttons to select Disc Menu, then press
4. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select the desired language,
5. Press the œ/ƒ
then press the ‹ or ENTER button.
- If the selected language is not recorded on the disc,
the original pre-recorded language is selected.
- The language is selected and the screen returns to
Language Setup menu.
- To make the setup menu disappear, press the MENU
button.
LANGUAGE SETUP
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Language Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
ƒ buttons to select Subtitle, then press the ‹
4. Press the œ/ƒ
or ENTER button.
ƒ buttons to select the desired language,
5. Press the œ/ƒ
then press the ‹ or ENTER button.
- Select “Automatic” if you want the subtitle language to
be the same as the language selected as the audio
language.
- Some discs may not contain the language you select as
your initial language; in that case the disc will use its
original language setting.
- The language is selected and the screen returns to
setup menu.
- To make the setup menu disappear, press the MENU
button.
LANGUAGE SETUP
Player Menu
Disc Menu
: English
√ Automatic
: English
English
Audio
Subtitle
: English
Deutsch
: English
DivX Subtitle
Italiano
: English
Enter
26
Return
Menu
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Language Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
ƒ buttons to select DivX Subtitle, then press
4. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select the desired language,
5. Press the œ/ƒ
then press the ‹ or ENTER button.
- The language is selected and the screen returns to
Language Setup menu.
e
- To make the setup menu disappear, press the
MENU button.
LANGUAGE SETUP
Player Menu
: English
Disc Menu
: English
Audio
√ Unicode
Turkish
Central
Subtitle
DivX Subtitle
❶ Dolby Digital Out
- PCM : Converts to PCM(2CH) audio.
- Bitstream : Outputs Dolby Digital via the digital output.
Select Bitstream when connecting to a
Dolby Digital Decoder.
❷ MPEG-2 Digital Out
- PCM : Converts to PCM(2CH) audio.
- Bitstream : Converts to MPEG-2 Digital Bitstream
(5.1CH or 8CH). Select Bitstream when using the
Digital Audio Output.
❸ Dynamic Compression
- On : To select dynamic compression.
- Off : To select the standard range.
❹ PCM Down Sampling
- On : Select this when the Amplifier connected to the
player is not 96KHz compatible. In this case, the
96KHz signals will be down converted to 48KHZ.
- Off : Select this when the Amplifier connected to the
player is 96KHz compatible. In this case, all signals
will be output without any changes.
Note
Even when PCM Down sampling is Off
• Some discs will only output down sampled
audio through the digital outputs.
Setting Up the Audio
Options
❺ Output Channel
- 2Ch : Select this when using 2 channel connection only.
- 5.1 Ch : Select this when using 5.1 Channel connection.
Audio Options allows you to setup the audio device
and sound status settings depending on the audio
system in use.
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Audio Setup, then press
3. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select the desired item, then
4. Press the œ/ƒ
press the ‹ or ENTER button.
Language Setup
Audio Setup
Display Setup
Parental Setup :
DivX(R) Registration
‹
‹
‹
‹
‹
Note
To make The Speaker Setup menu appear, select output
channel to 5.1 Ch.
To make the Setup menu disappear, press the MENU
button.
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
“DTS” and “DTS Digital Out” are trademarks of
Digital Theater Systems, Inc.
Surround Sound Speaker Setup
AUDIO SETUP
Dolby Digital Out
:PCM
MPEG-2 Digital Out
:PCM
Dynamic Compression :On
PCM Down Sampling
:On
Output Channel
: 5.1 CH
Speaker Setup
‹
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Audio Setup, then press
3. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select Speaker Setup, then
4. Press the œ/ƒ
press the ‹ or ENTER button.
5. Press the œ/ƒ/¦/‹ buttons to select the desired item,
then press the ENTER button to set the speaker.
27
English
Using the DivX Subtitle Language
AUDIO SETUP
Dolby Digital Out
:PCM
MPEG-2 Digital Out
:PCM
Dynamic Compression :On
PCM Down Sampling
:On
Output Channel
:5.1CH
‹
Speaker Setup
Enter
Return
Menu
SPEAKER SETUP
Small
Test
Small
On
Small
To make the Setup menu disappear or return to
menu screen during set up, press RETURN button.
• The subwoofer test output signal is lower
than the other speakers.
• The MPEG Multichannel logo is a trademark
registered by PHILIPS Corporation.
• If you set Front (L, R) “Small”, LFE
(Subwoofer) is set “On” automatically.
User
Small
Small
Note
To make the setup menu disappear, press the MENU
button.
The default settings : FRONT L, R (Small),
CENTER (Small), SURROUND (Small).
Select the size of the speakers to be connected.
❶ Front (FL, FR)
- Large: Normally select this.
- Small: When the sound distorts or the suround
sound effects are difficult to hear, select this.
This activates the Dolby Digital bass redirec
tion circuitry and outputs the bass frequencies
of the speaker from the subwoofer.
❷ Center
- None: If you do not connect a center speaker,
select this.
- Large: Normally select this.
- Small: When the sound distorts, select this.
This activates the Dolby Digital bass redirection circuitry and outputs the bass frequencies
of the center speaker from other speakers.
❸ Surround (SL, SR)
- None: If you do not connect a center speaker,
select this.
- Large (Rear/Side): Normally select either of
these according to the rear speaker’s position.
- Small (Rear/Side): When the sound ditorts or
the surround sound effects are dificult to hear,
select either of these according to the rear
speaker’s position.
This activates the Dolby Digital bass rediretion
circuitry and outputs the bass frequencies of
the rear speaker from other speakers.
Setting up Test
The test output signals come clockwise starting
from the Front Speaker(L).
Adjust Channel Balance so that speakers output
equally in your room.
FRONT(L) ➝ CENTER ➝ SUBWOOFER ➝
FRONT(R) ➝ SURROUND(R) ➝ SURROUND(L)
28
Note
Setting Up the Display
Options
Display options enable you to set various video
functions of the player.
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
ƒ buttons to select Display Setup, then press
3. Press the œ/ƒ
the ‹ or ENTER button.
ƒ buttons to select the desired item, then
4. Press the œ/ƒ
press the ‹ or ENTER button.
‹
Language Setup
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
Enter
Return
Menu
❶ TV Aspect
Depending on a type of television you have, you
may want to adjust the screen setting (aspect
ratio).
- 4:3 Letter Box : Select when you want to see
the total 16:9 ratio screen DVD
supplies, even though you have a TV with a 4:3
ratio screen. Black bars will appear at the top
and bottom of the screen.
- 4:3 Pan&Scan : Select this for conventional
size TVs when you want to see the central portion of the 16:9 screen. (Extreme left and right
side of movie picture will be cut off.)
- 16:9 Wide : You can view the full 16:9
picture on your wide screen TV.
DISPLAY SETUP
TV Aspect
Still Mode
Screen Messa
Black Level
TV System
Video Output
: PAL
: I-SCAN
These options will help prevent picture shake in
still mode and display small text clearer.
- Auto : When selecting Auto, Field/Frame mode
will be automatically converted.
DISPLAY SETUP
TV Aspect
- Field : Select this feature when the screen
shakes in the Auto mode.
Still Mode
- Frame : Select this feature when you want to
see small letters more clearly in the Auto
mode.
TV System
❸ Screen Messages
Use to turn on-screen messages On or Off.
❹
• If the Yes/No selection in the Display Setup
sub Menu is not made within 10 seconds,
the screen returns to the previous menu.
Black Level
Adjusts the brightness of the screen.(On or Off)
It does not function in Progressive mode.
➎ TV System
- NTSC : In case of using NTSC disc
• If your TV system only has PAL-Video input,
you must choose “PAL”. When you choose
“PAL”, Interlace output format is PAL 60 Hz
output.
• If your TV system only has NTSC, input you
must choose “NTSC ”.
- PAL : In case of using PAL disc
• If your TV system only has NTSC-Video input,
you must choose “NTSC”.
• If your TV system only has PAL input, you
must choose “PAL ”.
DISPLAY SETUP
TV Aspect
Still Mode
Screen Messages
Black Level
TV System
Video Output
:
:
:
:
4:3 L-Box
Auto
On
Off
➏ Video Output
Select Video Output.
- COMPONENT(I-SCAN) : Select when you
want to use Component Interlace (525i) Out.
- COMPONENT(P-SCAN) : Select when you
want to use Component Progressive (525p)
Out.
• If you press the VIDEO SEL. button, Video
output mode is changed in regular sequence
in no disc mode.
(COMPONENT (I-SCAN) ➝ COMPONENT(PSCAN))
: 4:3 L-Box
: Auto
Screen Messages : On
Black Level
: Off
Video Output
• Consult your TV User’s Manual to find
out if your TV supports Progressive Scan. If
Progressive Scan is supported, follow the TV
User’s Manual regarding Progressive Scan
settings in the TV’s menu system.
• If Video Output is set incorrectly, the screen
may be blocked.
• When the resolution is changed during playback, it may take a few seconds for a normal
image to appear.
Setting Up the Parental
Control
The Parental Control function works in conjunction
with DVDs that have been assigned a rating, which
helps you control the types of DVDs that your family
watches. There are up to 8 rating levels on a disc.
Setting Up the Rating Level
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
Language Setup
‹
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
ƒ buttons to select Parental Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button.
Language Setup
‹
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
ƒ buttons to select Rating Level, then press
4. Press the œ/ƒ
the ‹ or ENTER button.
29
English
❷ Still Mode
PARENTAL SETUP
Rating level
: Kids Safe
Change Password
ƒ button to select Change Password, then
4. Press the œ/ƒ
press the ‹ or ENTER button. Enter your password (default
password). Enter the new password again.
PARENTAL SETUP
Rating Level
:Kids Safe
Change Password
5. Enter your password.
- By default, password is set to 0000.
- Please change password to other than 0000 to
activate parental control function.
PARENTAL SETUP
Rating Level
: Kids Safe
Change Password
PARENTAL SETUP
Rating Level
Enter Password
Enter
Return
Enter Password
Menu
Enter
ƒ buttons to select the Rating Level you want,
6. Press the œ/ƒ
then press the ‹ or ENTER button.
e.g) Setting up in Kids Safe.
PARENTAL SETUP
Rating
RatingLevel
Level
Return
Level
Level
Level
Level
Level
2
3
4
5
6
Rating Level
Menu
:Kids Safe
Change Password
Enter New Password
Enter
Menu
MENU button. For example, if you select up to
Level 6, discs that contain Level 7,8 will not play.
Changing the Password
1. With the unit in Stop mode, press the MENU button.
ƒ buttons to select Setup, then press the ‹
2. Press the œ/ƒ
or ENTER button.
Language Setup
Return
Menu
Note
If you have forgotten your password, see
“Forgot Password” in the Troubleshooting Guide.
Note
• To make the setup menu disappear, press the
‹
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
ƒ buttons to select Parental Setup, then
3. Press the œ/ƒ
press the ‹ or ENTER button. The Enter Password screen
appears. Enter your password.
30
Return
PARENTAL SETUP
KidsSafe
Safe
√ : Kids
Change Passwor
Enter
:Kids Safe
Change Password
Language Setup
‹
Audio Setup
‹
Display Setup
‹
Parental Setup :
‹
DivX(R) Registration
‹
REFERENCE
English
Firmware upgrade
Introduction
Samsung will often support the software upgrade to
improve the performance of this unit to the latest
status, through Samsung Internet Site
(www.samsung.com).
Because the specially new MPEG4 codec continues
and it is appearing. What improvements are made
depends on the upgrade software you are using as well
as the software that your DVD-player contained before
the upgrade.
How to make an upgrade disc
Write the downloaded file onto a blank CD-R or CDRW disc, using the following settings:
- In the middle of the writing, the tray will open
automatically. After taking out the disc, please wait for
about 2 minutes.
- If the unit was succesfully updated, the unit will turn off
and on after closing the tray automatically. When the
unit turns on, this screen will display.
3. Press the number buttons to select the desired
language
1. You have to download a new file through Download Center
of Samsung Internet Site (www.samsung.com).
2. Write the file to Disc using CD-RW of your computer.
Note
- File System CD-ROM ISO Level
- Character set ISO 9660
- Finalized, single session
- Write speed low
Upgrade procedure
1. Open the disc tray. Place the disc on the tray. Close the
tray. The Firmware upgrade screen appears.
Note
- If the “Select Menu Language” doesn’t appear,
please contact to “Samsung Service Center”.
- Do not press any button and unplug the power
code during upgrade.
- The upgrade procedure may change, refer to
the web site (www.samsung.com).
Firware upgrade
appears on the display
2. Press the ¦/‹ buttons to select Total, then press the
ENTER button.
31
Troubleshooting
Before requesting service (troubleshooting), please check the following.
Action
Problem
Page
No operations can be
performed with the
remote control.
• Check the batteries in the remote control.
They may need replacing.
• Operate the remote control at a distance of no more than 20 feet.
• Remove batteries and hold down one or more buttons for several minutes to drain
the microprocessor inside the remote control to reset it. Reinstall batteries and try
to operate the remote control again.
P3
Disc does not play.
• Ensure that the disc is installed with the label side facing up.
• Check the region number of the DVD.
P5
5.1 channel sound is
not being reproduced.
The
icon appears
on screen.
• 5.1 channel sound is reproduced only when the following conditions are met. :
1) The DVD player is connected with the proper Amplifier
2) The disc is recorded with 5.1 channel sound.
• Check whether the disc being played has the “5.1 ch” mark on the outside.
• Check if your audio system is connected and working properly.
• In a SETUP Menu, is the Audio Output set to Bitstream?
• The features or action cannot be completed at this time because:
1. The DVD’s software restricts it.
2. The DVD’s software doesn’t support the feature (e.g., angles).
3. The feature is not available at the moment.
4. You’ve requested a title or chapter number or search time that is out of range.
P12-14
P27-28
Disc Menu doesn’t appear. • Check if the disc has a Menu.
Play mode differs from the
Setup Menu selection.
• Some of the functions selected in the Setup Menu may not work properly if the
disc is not encoded with the corresponding function.
P25-30
The screen ratio
cannot be changed.
• The Screen Ratio is fixed on your DVDs.
P28-29
No audio.
• Make sure you have selected the correct Digital Output in the Audio Options
Menu.
P27-28
The screen is blocked
• Press the
button for more than 5 seconds under no disc inside.
All settings will revert to the factory settings.
Forgot password
• Press the
button for more than 5 seconds under no disc inside.
All settings including the password will revert to the factory settings. Don't
use this unless absolutely necessary.
If you experience
other problems.
The picture is noisy or
distorted
32
P15
P29
• Go to the contents and find the section of the instruction book that contains the
explanations regarding the current problem, and follow the procedure once again.
• If the problem still cannot be solved, please contact your nearest authorized service center.
• Make sure that the disc is not dirty or scratched.
• Clean the disc.
P2
USB HOST Feature
Supported Products
USB Flash Disk
Product
Finepix-A340
Finepix-F810
Finepix-F610
Finepix-f450
Finepix S7000
Finepix A310
KD-310Z
Finecam SL300R
Finecam SL400R
Finecam S5R
Finecam Xt
Dimage-Z1
Dimage Z1
Dimage X21
Coolpix4200
Coolpix4300
Coolpix 2200
Coolpix 3500
Coolpix 3700
Coolpix 4100
Coolpix 5200
Stylus 410 digital
300-digital
U300
X-350
C-760
C-5060
X1
U-mini
Lumix-FZ20
DMC-FX7GD
Lumix LC33
LUMIX DMC-F1
Optio-S40
Optio-S50
Optio 33LF
Optio MX
Digimax-420
Digimax-400
Sora PDR-T30
Coolpix 5900
Coolpix S1
Coolpix 7600
DMC-FX7
Dimage Xt
AZ-1
Company
Fuji
Fuji
Fuji
Fuji
Fuji
Fuji
Konica
Kyocera
Kyocera
Kyocera
Kyocera
Minolta
Minolta
Minolta
Nikon
Nikon
Nikon
Nikon
Nikon
Nikon
Nikon
Olympus
Olympus
Olympus
Olympus
Olympus
Olympus
Olympus
Olympus
Panasonic
Panasonic
Panasonic
Panasonic
Pentax
Pentax
Pentax
Pentax
Samsung
Samsung
Toshiba
Nikon
Nikon
Nikon
Panasonic
Minolta
Olympus
Type
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Digital Camera
Company
Sandisk
Cruzer Mini
Cruzer Mini
SONY Micro Vault
FLEX DRIVE
AnyDrive
XTICK
Micro Mini
iFlash
LG
RiDATA
Type
USB 2.0 USB Flash
Drive 128M
USB 2.0 128M
USB 2.0 256M
USB 2.0 64MB
USB 2.0 32MB
USB 2.0 128MB
USB 2.0 128M
USB 2.0 128M
USB 2.0 64M
USB 2.0 64M
USB 2.0 64M
Sandisk
Sandisk
Sony
Serotech
A.L tech
LG
Iomega
Imation
XTICK(M)
EZDrive
MP3 Player
Product
Company
Creative MuVo NX128M
Iriver H320
YH-920
YP-T7
YP-MT6
YP-T6
YP-53
YP-ST5
YP-T5
YP-60
YP-780
YP-35
YP-55
iAUDIO U2
iAUDIO G3
iAudio M3
SI-M500L
H10
YP-T5 VB
YP-53
Type
Creative
Iriver
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Samsung
Cowon
Cowon
Cowon
Sharp
Iriver
Samsung
Samsung
128 MB MP3 Player
20G HDD MP3 Player
20G HDD MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
MP3 Player
HDD MP3 Player
256MB MP3 Player
MP3 Player
MP3 Player
256MB MP3 Player
Multi Card Reader
Product
UNICORN
USB 2.0 Card Reader
Company
Type
Unicorn
Billionton(Taiwan)
USB 2.0 7 IN 1 CARD
READER UC-601R
USB 2.0 Card Reader for
SD/MMC/RS-MMC(3-in-1)
USB External HDD
Product
CUTIE
MOMOBAY UX-2
Company
Serotech
Dvico
Type
POCKET HARD DISK DRIVE
USB 2.0
33
English
Digital Camera
Product
Cruzer Micro
Specification
General
Power Requirements
AC 110-240 V ~ 50/60 Hz
Power Consumption
9W
1.5 Kg
Weight
430mm (W) X 207mm (D) X 37mm (H)
Dimensions
+5°C to +35°C
Operating Temperature Range
Operating Humidity Range
10 % to 75 %
DVD
(DIGITAL VERSATILE DISC)
Disc
Reading Speed : 3.49 ~ 4.06 m/sec.
Approx. Play Time
(Single Sided, Single Layer Disc) : 135 min.
CD : 12Cm
(COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
CD : 8Cm
(COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 20 min.
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min. (Video + Audio)
VCD : 12Cm
Video
Output
Composite Video
1 channel : 1.0 Vp-p (75 Ω load)
Component Video
Y : 1.0 Vp-p (75 Ω load)
Pr : 0.70 Vp-p (75 Ω load)
Pb : 0.70 Vp-p (75 Ω load)
2 Channel
F/L,F/R
F/L,F/R,R/L,R/R,CT,S/W
5.1 Channel
Audio
Output
48 kHz Sampling : 4 Hz to 22 kHz
96 kHz Sampling : 4 Hz to 44 kHz
*Frequency Response
*S/N Ratio
*Dynamic Range
110 dB
*Total Harmonic Distortion
0.004 %
100 dB
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications with out
notice.
- Weight and dimensions are approximate.
34
