MC45
USER GUIDE
b
MC45
User Guide
72E-164159-01
Rev. A
December 2012
ii
MC45 User Guide
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from Motorola. This includes electronic or mechanical means, such as
photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to
change without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on
a licensed basis. Motorola grants to the user a non-transferable and non-exclusive license to use each
software or firmware program delivered hereunder (licensed program). Except as noted below, such license
may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of
Motorola. No right to copy a licensed program in whole or in part is granted, except as permitted under
copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with
other program material, create a derivative work from a licensed program, or use a licensed program in a
network without written permission from Motorola. The user agrees to maintain Motorola’s copyright notice on
the licensed programs delivered hereunder, and to include the same on any authorized copies it makes, in
whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed
program delivered to the user or any portion thereof.
Motorola reserves the right to make changes to any software or product to improve reliability, function, or
design.
Motorola does not assume any product liability arising out of, or in connection with, the application or use of
any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any Motorola, Inc.,
intellectual property rights. An implied license only exists for equipment, circuits, and subsystems contained in
Motorola products.
Motorola Solutions, Inc.
1301 E. Algonquin Rd.
Schaumburg, IL 60196-1078, U.S.A.
http://www.motorolasolutions.com
iii
Revision History
Changes to the original manual are listed below:
Change
-01 Rev. A
Date
12/2012
Description
Initial release.
iv
MC45 User Guide
Table of Contents
Revision History.................................................................................................................................... iii
About This Guide
Introduction ...........................................................................................................................................
Documentation Set .........................................................................................................................
Configurations ............................................................................................................................................
Software Versions...........................................................................................................................
Chapter Descriptions ............................................................................................................................
Notational Conventions ..............................................................................................................................
Related Documents ..............................................................................................................................
Service Information ....................................................................................................................................
xi
xi
xii
xii
xiv
xv
xv
xvi
Chapter 1: Getting Started
Introduction ..........................................................................................................................................
Unpacking ............................................................................................................................................
Getting Started .....................................................................................................................................
Installing the Micro Secure Digital (microSD) Card ........................................................................
Installing the mini-SIM Card ...........................................................................................................
Installing the Battery ......................................................................................................................
Charging the Battery ......................................................................................................................
Charging the Battery ................................................................................................................
Charging Spare Batteries .........................................................................................................
Charging Temperature .............................................................................................................
Powering On the MC45 ..................................................................................................................
Calibrating the Screen ...................................................................................................................
Checking Battery Status ................................................................................................................
Replacing the Battery .........................................................................................................................
First-time Network Activation ...............................................................................................................
GSM/UMTS Activation ...................................................................................................................
Network Activation ...................................................................................................................
Battery Management ...........................................................................................................................
Changing the Power Settings ........................................................................................................
Changing the Backlight & Keylight Settings ...................................................................................
1-1
1-2
1-2
1-3
1-4
1-5
1-6
1-6
1-7
1-7
1-8
1-8
1-8
1-8
1-9
1-9
1-9
1-10
1-10
1-10
Table of Contents
vi
Turning Off the Radios ................................................................................................................... 1-10
Chapter 2: Using the MC45
Introduction ..........................................................................................................................................
Home Screen .......................................................................................................................................
Status Bar ......................................................................................................................................
Icon Bar ..........................................................................................................................................
Today Screen .................................................................................................................................
Classic Today Screen ....................................................................................................................
Soft Keys Bar .................................................................................................................................
Start Screen ...................................................................................................................................
Settings Folder ...............................................................................................................................
Adjusting Volume .......................................................................................................................................
Battery Status Indications ..........................................................................................................................
LED Indicators ...........................................................................................................................................
Resetting the MC45 ...................................................................................................................................
Waking the MC45 ................................................................................................................................
Locking the MC45 ................................................................................................................................
Password Locking ..........................................................................................................................
Function Buttons ........................................................................................................................................
Stylus .........................................................................................................................................................
Entering Data .......................................................................................................................................
Display Orientation ....................................................................................................................................
Taking Photos ............................................................................................................................................
Recording Video ..................................................................................................................................
Viewing Photos and Videos .................................................................................................................
2-1
2-1
2-2
2-4
2-5
2-6
2-8
2-8
2-11
2-14
2-15
2-16
2-17
2-17
2-17
2-18
2-20
2-21
2-21
2-22
2-23
2-23
2-23
Chapter 3: Data Capture
Introduction ..........................................................................................................................................
Laser Scanning ....................................................................................................................................
Scanning Considerations ...............................................................................................................
Bar Code Scanning ........................................................................................................................
Adaptive Scanning ...............................................................................................................................
Color Digital Camera ...........................................................................................................................
Digital Camera Scanning ...............................................................................................................
DataWedge ..........................................................................................................................................
3-1
3-1
3-1
3-2
3-2
3-3
3-3
3-4
Chapter 4: Using the Phone
Introduction ..........................................................................................................................................
Accessing the Phone Dialer .................................................................................................................
Turning the Phone On and Off .............................................................................................................
Using a Bluetooth Headset ............................................................................................................
Adjusting Audio Volume .................................................................................................................
Using the Phone Keypad ...............................................................................................................
Using Contacts ...............................................................................................................................
Using Call Log ................................................................................................................................
Making a Speed Dial Call ...............................................................................................................
Making an Emergency Call ..................................................................................................................
4-1
4-1
4-2
4-3
4-4
4-5
4-5
4-6
4-7
4-7
Table of Contents
Answering a Call ..................................................................................................................................
Incoming Call Features ..................................................................................................................
Smart Dialing .......................................................................................................................................
Muting a Call ........................................................................................................................................
Using Speed Dial .................................................................................................................................
Adding a Speed Dial Entry .............................................................................................................
Editing a Speed Dial Entry .............................................................................................................
Deleting a Speed Dial Entry ...........................................................................................................
Using Call Log .....................................................................................................................................
Managing Call Log .........................................................................................................................
Changing the Call Log View .....................................................................................................
Deleting All Call Log Items .......................................................................................................
Viewing Call Status ..................................................................................................................
Using the Call Log Options ......................................................................................................
SMS Messaging ...................................................................................................................................
Sending a Text Message ...............................................................................................................
Viewing Text Messages .................................................................................................................
Replying to a Text Message ..........................................................................................................
MMS Messaging ..................................................................................................................................
Creating and Sending MMS Messages .........................................................................................
Viewing an MMS Message ............................................................................................................
Replying to an MMS Message .......................................................................................................
Blocking Incoming MMS Messages ...............................................................................................
Voice Commander ...............................................................................................................................
Call .................................................................................................................................................
Find ................................................................................................................................................
Redial .............................................................................................................................................
Callback .........................................................................................................................................
Start ...............................................................................................................................................
Appointments .................................................................................................................................
Read ..............................................................................................................................................
What time is it ................................................................................................................................
Call History .....................................................................................................................................
Voice Play Music ............................................................................................................................
What can I say ...............................................................................................................................
Goodbye ........................................................................................................................................
Chapter 5: Using WLAN
Introduction ..........................................................................................................................................
Fusion Overview ..................................................................................................................................
Connecting to the Internet ..............................................................................................................
Wireless Zero Config Overview ...........................................................................................................
Switching Between Fusion and WZC ..................................................................................................
Supported Applications ........................................................................................................................
Wireless Zero Config Setup .................................................................................................................
More Information on WZC ..............................................................................................................
vii
4-7
4-8
4-8
4-9
4-10
4-10
4-12
4-12
4-13
4-13
4-13
4-14
4-15
4-16
4-20
4-20
4-21
4-22
4-22
4-23
4-23
4-24
4-24
4-24
4-25
4-26
4-26
4-26
4-27
4-27
4-27
4-27
4-27
4-27
4-28
4-28
5-1
5-1
5-2
5-2
5-2
5-3
5-6
5-8
Chapter 6: Using GPS Navigation
Introduction .......................................................................................................................................... 6-1
Table of Contents
Software Installation ............................................................................................................................
MC45 GPS Setup ................................................................................................................................
Operation .............................................................................................................................................
GPS Maps on microSD Cards .......................................................................................................
Answering a Phone Call While Using GPS ....................................................................................
Losing the GPS Signal While in a Vehicle .....................................................................................
GPS Reset .....................................................................................................................................
viii
6-1
6-1
6-2
6-2
6-2
6-2
6-3
Chapter 7: Using Bluetooth
Introduction ..........................................................................................................................................
Adaptive Frequency Hopping ..............................................................................................................
Security ................................................................................................................................................
Bluetooth Power States .......................................................................................................................
Suspend ...................................................................................................................................
Resume ....................................................................................................................................
Turning Bluetooth On and Off ..............................................................................................................
Enabling Bluetooth ...................................................................................................................
Discovering Bluetooth Device(s) ....................................................................................................
Available Services ..........................................................................................................................
Object Push Services via Beam ...............................................................................................
Internet Sharing .......................................................................................................................
Hands-free Services ................................................................................................................
Serial Port Services .................................................................................................................
ActiveSync Using Serial Port Services ....................................................................................
Phone Book Access Profile Services .......................................................................................
Dial-Up Networking Services ...................................................................................................
Connect to a HID Device .........................................................................................................
A2DP/AVRCP Services ...........................................................................................................
7-1
7-1
7-2
7-3
7-3
7-3
7-4
7-4
7-5
7-8
7-8
7-9
7-10
7-11
7-11
7-13
7-13
7-14
7-14
Chapter 8: Accessories
Introduction ..........................................................................................................................................
Communication with Host Computer .............................................................................................
Charging the MC45 Battery ...........................................................................................................
Charging Temperature .............................................................................................................
Vehicle Charge Cradle .........................................................................................................................
Windshield Installation ...................................................................................................................
Install the MC45 .............................................................................................................................
Connect Power ..............................................................................................................................
Remove the MC45 .........................................................................................................................
Battery Charging Indicators ...........................................................................................................
Charging Temperature .............................................................................................................
micro USB Adapter ..............................................................................................................................
Handstrap ............................................................................................................................................
Installing ActiveSync ......................................................................................................................
MC45 Setup ...................................................................................................................................
Setting Up an ActiveSync Connection on the Host Computer .......................................................
Synchronization with the MC45 .....................................................................................................
8-1
8-3
8-4
8-5
8-6
8-6
8-7
8-8
8-9
8-10
8-10
8-11
8-12
8-13
8-13
8-14
8-14
Table of Contents
ix
Chapter 9: Maintenance & Troubleshooting
Introduction ..........................................................................................................................................
Maintaining the MC45 ..........................................................................................................................
Removing the Screen Protector ...........................................................................................................
Battery Safety Guidelines ....................................................................................................................
Cleaning ...............................................................................................................................................
Materials Required .........................................................................................................................
Cleaning the MC45 ........................................................................................................................
Housing ....................................................................................................................................
Display .....................................................................................................................................
Scanner Exit Window ...............................................................................................................
Connector ................................................................................................................................
Cleaning Cradle Connectors ..........................................................................................................
Cleaning Frequency .......................................................................................................................
Troubleshooting ...................................................................................................................................
MC45 .............................................................................................................................................
Single Slot Charge Cradle .............................................................................................................
Multi Slot Universal Charge Only Cradle .......................................................................................
Vehicle Charge Cradle ...................................................................................................................
Four Slot Battery Charger ..............................................................................................................
Cables ............................................................................................................................................
9-1
9-1
9-2
9-3
9-3
9-3
9-4
9-4
9-4
9-4
9-4
9-4
9-5
9-5
9-5
9-8
9-9
9-9
9-10
9-11
Appendix A: Technical Specifications
MC45 Technical Specifications ............................................................................................................
MC45 Accessory Specifications ..........................................................................................................
Single Slot Charge Cradle .............................................................................................................
Multi Slot Universal Charge Only Cradle .......................................................................................
Four Slot Battery Charger ..............................................................................................................
A-1
A-4
A-4
A-5
A-6
Appendix B: Keypads
Numeric Keypad Configuration ............................................................................................................ B-1
Special Character Key ......................................................................................................................... B-4
Glossary
Index
x
MC45 User Guide
About This Guide
Introduction
This guide provides information about using the MC45 and accessories.
NOTE
Screens and windows pictured in this guide are samples and can differ from actual screens.
Documentation Set
The documentation set for the MC45 provides information for specific user needs, and includes:
• MC45 Quick Start Guide - describes how to get the MC45 up and running.
• MC45 User Guide - describes how to use the MC45.
• MC45 Integrator Guide - describes how to set up the MC45 and accessories.
• MC45 Regulatory Guide - provides all regulatory, service and EULA information for the MC45.
• Enterprise Mobility Developer Kit (EMDK) Help File - provides API information for writing applications.
xii
MC45 User Guide
Configurations
This guide covers the following configurations:
Configuration
Radios
Display
Memory
Data
Capture
Operating
System
Keypads
MC4587
WWAN:
GSM/HSDPA
3.2”
QVGA16 Bit
Color
256 MB RAM/
1 GB Flash
Camera
Microsoft
Windows
Embedded
Handheld
6.5.3,
Professional
Edition
Numeric
MC4597
WLAN: 802.11a/b/g
WWAN:
GSM/HSDPA
3.2”
QVGA16 Bit
Color
256 MB RAM/
1 GB Flash
1-D laser
scanner or
camera
Microsoft
Windows
Embedded
Handheld
6.5.3,
Professional
Edition
Numeric
Software Versions
This guide covers various software configurations and references are made to operating system or software
versions for:
• Adaptation Kit Update (AKU) version
• OEM version
• Phone version
• Fusion version
AKU Version
To determine the Adaptation Kit Update (AKU) version:
Tap Start > Settings > System folder > About icon > Version tab.
The second line lists the operating system version and the build number. The last part of the build number
represents the AKU number. Build 29102.5.3.12.13 indicates that the device is running AKU version 5.3.12.13.
About This Guide
OEM Version
To determine the OEM software version:
Tap Start > Settings > System folder > System Info icon > System tab.
Fusion Software
To determine the Fusion software version:
Tap Start > Wireless Companion icon > Wireless Status icon > Versions.
xiii
xiv
MC45 User Guide
Phone Software
To determine the Phone software version:
Tap Start > Phone >
> Phone information.
Chapter Descriptions
Topics covered in this guide are as follows:
• Chapter 1, Getting Started provides information on getting the MC45 up and running for the first time.
• Chapter 2, Using the MC45 provides basic instructions for using the MC45, including powering on and
resetting the MC45, and entering and capturing data.
• Chapter 3, Data Capture provides information for using the MC45 to capture data using the laser scanner or
camera.
• Chapter 4, Using the Phone provides basic instructions for using the MC45 phone.
• Chapter 5, Using WLAN explains the WLAN functionality on the MC45.
• Chapter 6, Using GPS Navigation provides information about GPS navigation with the MC45.
• Chapter 7, Using Bluetooth explains Bluetooth functionality on the MC45.
• Chapter 8, Accessories describes the available accessories and how to use them with the MC45.
• Chapter 9, Maintenance & Troubleshooting includes instructions on cleaning and storing the MC45, and
provides troubleshooting solutions for potential problems during MC45 operation.
• Appendix A, Technical Specifications provides the technical specifications for the MC45.
• Appendix B, Keypads provides keypad layouts and operation.
About This Guide
Notational Conventions
The following conventions are used in this document:
• “Mobile Computer” refers to the Motorola MC45 series of handheld computers.
• Italics are used to highlight the following:
• Chapters and sections in this and related documents
• Icons on a screen.
• Bold text is used to highlight the following:
• Dialog box, window, and screen names
• Drop-down list and list box names
• Check box and radio button names
• Key names on a keypad
• Button names on a screen.
• Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential
• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
Related Documents
• MC45 Quick Start Guide, p/n 72-164157-xx.
• MC45 Regulatory Guide, p/n 72-164158-xx.
• MC45 Integrator Guide, p/n 72E-164160-xx.
• Enterprise Mobility Developer Kits (EMDKs), available at: http://supportcentral.motorola.com.
• Latest ActiveSync software, available at: http://www.microsoft.com.
For the latest version of this guide and all guides, go to: http://supportcentral.motorola.com.
xv
xvi
MC45 User Guide
Service Information
If you have a problem with your equipment, contact Motorola Solutions Global Customer Support for your region.
Contact information is available at: http://www.motorolasolutions.com/support.
When contacting Motorola Solutions Global Customer Support, please have the following information available:
• Serial number of the unit
• Model number or product name
• Software type and version number
Motorola responds to calls by email, telephone or fax within the time limits set forth in support agreements.
If your problem cannot be solved by Motorola Solutions Global Customer Support, you may need to return your
equipment for servicing and will be given specific directions. Motorola is not responsible for any damages incurred
during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the
warranty.
If you purchased your Motorola business product from a Motorola business partner, contact that business partner
for support.
Chapter 1 Getting Started
Introduction
This chapter lists the parts for the MC45 and explains how to install and charge the batteries, replace the strap, and
power on the MC45 for the first time.
Receiver
Ambient Light
Sensor
Charging/Battery
Status LED
Proximity
Sensor
Programmable
Button (Scan)
Touch Screen
with Screen
Protective Film
Micro USB port
Scan Button
Power Button
Up/Down Button
Keypad
Microphone
Charging Connector
Figure 1-1
MC45 Front View
1 - 2 MC45 User Guide
Battery Cover Latch
Battery Cover
Handstrap Mount
Programmable
Button (Camera)
Stylus
Volume Buttons
Scan Window
Camera Flash
Camera
Tether Point
Figure 1-2
MC45 Rear View
Unpacking
Carefully remove all protective material from the MC45 and save the shipping container for later storage and
shipping.
Verify that you received the following:
• MC45
• Lithium-ion battery
• Battery cover
• Tethered stylus
• Screen Protector
• Regulatory Guide
• Quick Start Guide.
Inspect the equipment for damage. If any equipment is missing or damaged, contact the Motorola Solutions Global
Customer Support center immediately. See page xvi for contact information.
Getting Started
To start using the MC45 for the first time:
• Install microSD card (optional)
Getting Started 1 - 3
• Install the mini-SIM card
• Install the battery.
• Charge the MC45
• Power on the MC45
• Configure the MC45.
Installing the Micro Secure Digital (microSD) Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the battery (see Figure
1-3). Refer to the documentation provided with the card for more information, and follow the manufacturer’s
recommendations for use.
CAUTION Follow proper ESD precautions to avoid damaging the microSD card. Proper ESD precautions include,
but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.
To install the microSD card:
1.
Slide the mini-SIM card holder to the right to unlock.
2.
Lift the mini-SIM card holder.
Figure 1-3
microSD Card Installation
3.
Slide the microSD card holder down to unlock.
4.
Lift up the microSD card holder.
5.
Insert the card with the card contacts facing down and lower the microSD card holder.
6.
Slide the microSD card holder up to lock.
7.
Lower the mini-SIM card holder.
8.
Slide the mini-SIM card holder to the left to lock.
1 - 4 MC45 User Guide
To remove the microSD card:
1.
Slide the microSD card holder down to unlock.
2.
Lift the microSD card holder.
Figure 1-4
Card Removal
3.
Remove the card from the card holder.
4.
Lower the microSD card holder.
5.
Slide the microSD card holder up to lock.
Installing the mini-SIM Card
NOTE The MC45 does not support copying multiple contacts to some SIM cards. If an error message appears, see
Chapter 9, Maintenance & Troubleshooting for more information.
GSM phone service requires a Subscriber Identification Module (SIM) card, or smart card. Obtain this card from the
your service provider. The card fits into the MC45 and can contain the following information:
• Mobile phone service provider account details.
• Information regarding service access and preferences.
• Contact information, which can be moved to Contacts on the MC45.
• Any additional services to which you have subscribed.
NOTE For more information about SIM cards, refer to the service provider's documentation.
To install the mini-SIM card:
1.
Slide the mini-SIM card holder to the right to unlock.
2.
Lift the mini-SIM card holder.
Figure 1-5
Lifting the mini-SIM Card Cover
Getting Started 1 - 5
3.
Insert the mini-SIM card, as shown in Figure 1-6, with the cut edge of the card facing out and the contacts
facing down.
Figure 1-6
Inserting the mini-SIM Card
4.
Lower the mini-SIM card holder and slide it to the left to lock.
5.
Install the battery. See Installing the Battery on page 1-5 for more information.
6.
After completing initial MC45 setup or after replacing a mini-SIM card:
a.
Press the red Power button.
b.
Ensure Phone is on.
c.
Make a call to verify cellular connection.
NOTE For detailed information about WWAN activation and settings, refer to the MC45 Integrator Guide.
Installing the Battery
NOTE When installing the battery for the first time out of the box, the back cover and battery are not installed.
To install the battery:
1.
Insert the battery, bottom first, into the battery compartment in the back of the MC45.
NOTE Position the battery correctly, with the battery gold charging contacts positioned on top of the gold charging
pins in the MC45 battery compartment.
2.
Press the battery down into the battery compartment.
1 - 6 MC45 User Guide
Figure 1-7
Inserting the Battery
3.
With the battery cover latch open, insert the cover, top first, then press down on the bottom of the cover.
4.
Slide the battery cover latch to the right until the red dot is not visible.
Figure 1-8
5.
Locking the Battery Cover Latch
Power up the MC45 by pressing the red Power button.
Charging the Battery
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 9-3.
Charging the Battery
Before using the MC45 for the first time, charge the main battery until the green Charging/Battery Status LED
remains lit (see Table 1-1 on page 1-7 for charge status indications). To charge the MC45, use the USB Rapid
Charge Cable or a cradle with the appropriate power supply. For information about the accessories available for
the MC45, see Chapter 8, Accessories.
To charge the battery, use either a USB Rapid Charge Cable or a cradle. For USB Rapid Charge Cable or cradle
setup and charging procedures refer to the MC45 Integrator Guide.
• Single Slot Charge Cradle
• Multi Slot Universal Charge Only Cradle
• Vehicle Charge Cradle.
To charge the battery:
Getting Started 1 - 7
1.
Connect the charging accessory to the appropriate power source.
2.
Insert the MC45 into a cradle or attach to the USB Rapid Charge Cable and Power Supply. The MC45 begins
charging. The Charging/Battery Status LED blinks green while charging, then turns solid green when fully
charged. See Table 1-1 for charging indications.
3.
The 3080mAh battery fully charges in less than six hours at room temperature of approximately 25 °C (77°F).
Charging time may vary at different temperatures.
NOTE The MC45 Battery Cover must be in place and closed properly for the MC45 to power on and charge the
battery.
Charging/Battery
Status LED
LED Indicators
Figure 1-9
Table 1-1
LED Charge Indications
Charging/Battery
Status LED
Indication
Off
MC45 is not charging.
MC45 is not inserted correctly in the cradle or connected to a power source.
Cradle is not powered.
Slow Blinking Green
(1 blink every 2 seconds)
MC45 is charging.
Solid Green
Charging complete.
Fast Blinking Red
(2 blinks / second)
Charging error, e.g.:
• Temperature is too low or too high.
• Charging has gone on too long without completion (typically eight hours).
Charging Spare Batteries
See Chapter 8, Accessories for information on using accessories to charge spare batteries.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC45.
To accomplish this, for small periods of time, the MC45 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC45 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-1.
1 - 8 MC45 User Guide
Powering On the MC45
Press the Power button to turn on the MC45. If the MC45 does not power on perform a reset. See Resetting the
MC45 on page 2-17.
When turning the MC45 on for the first time, the splash screen displays for about a minute as the MC45 initializes
its flash file system, then the calibration window appears. Note that these windows also appear upon reset.
Calibrating the Screen
NOTE The Calibration screen can be accessed by pressing Blue key - BKSP key or tapping Start > Settings >
System > Screen > General > Align Screen button.
To calibrate the screen so the cursor on the touch screen aligns with the tip of the stylus:
1.
Remove the stylus from its holder on the back of the MC45.
2.
Tap the screen to begin calibration.
3.
Carefully press and briefly hold the tip of stylus on the center of each target that appears on the screen.
4.
Repeat as the target moves around the screen.
Checking Battery Status
To check the charge status of the main battery or backup battery in the MC45, tap Start > Settings > Power icon
to display the Power window.
Replacing the Battery
To replace the battery:
1.
Press the red Power button to wake the device.
2.
Hold down the red Power button for 3 seconds and release. A screen appears. Tap the Power Off to turn off
the MC45.
3.
Slide the battery cover latch to the left until the green indicators align with the eject icon and the red dot is
visible. The battery cover ejects slightly.
Eject icon
Green indicators
Red dot
Figure 1-10
Unlocking the Battery Cover Latch
4.
Lift the bottom of the battery cover and remove.
5.
Lift the battery, top first, out of the well.
Getting Started 1 - 9
CAUTION Do not attempt to remove the battery using a screwdriver or sharp instrument.
6.
Insert the replacement battery, bottom first, into the battery compartment in the back of the MC45.
NOTE Position the battery correctly, with the battery gold charging contacts positioned on top of the gold charging
pins in the MC45 battery compartment.
7.
With the battery cover latch open, insert the cover, top first, then press down on the bottom of the cover.
Battery Cover
Battery
Figure 1-11
Replacing the Battery
8.
Slide the battery cover latch to the right until the red dot is not visible.
9.
Press the red Power button to power on the MC45.
First-time Network Activation
GSM/UMTS Activation
Network Activation
To activate on a GSM/UMTS network:
1.
If an active SIM card was installed in the MC45, the MC45 performs the activation process.
2.
The Phone Network - GSM/UMTS Setup dialog box displays.
3.
Tap Yes and then OK. For some carriers, the MC45 resets.
4.
If during start-up, no update connection settings message appears, tap Start > Settings > Connections >
Phone Network Setup and tap Update Connection Settings button.
5.
If the network is unsupported, a message appears with links for manually setting the data connection and MMS
settings.
1 - 10 MC45 User Guide
For detailed information for configuring the phone and activating on a different network, refer to the MC45
Integrator Guide.
Battery Management
Observe the following battery saving tips:
NOTE The MC45 factory default settings for the WLAN radio is set to OFF.
• Leave the MC45 connected to AC power at all times when not in use.
• Set the MC45 to turn off after a short period of non-use.
• Set the backlight to turn off after a short period of non-use.
• Turn off all wireless activities when not in use.
• Power off the MC45 when charging to charge at a faster rate.
Changing the Power Settings
To set the MC45 to turn off after a short period of non-use:
1.
Tap Start > Settings > Power icon > Advanced tab.
2.
Select the On battery power: Turn off screen if not used for check box and select a value from the
drop-down list.
3.
Select ok.
Changing the Backlight & Keylight Settings
To change the backlight settings in order to conserve more battery power:
1.
Tap Start > Settings > System tab > Backlight & Keylight icon > Battery Power tab.
2.
Select the Disable backlight if device is not used for check box and select a value from the drop-down list.
3.
Select the Brightness tab.
4.
Tap the Disable backlight check box to turn off the display backlight, or use the slider to set a low value for the
backlight.
5.
Select ok.
Turning Off the Radios
Windows Embedded Handheld 6.5 devices include Wireless Manager, which provides a simple method of
enabling, disabling, and configuring all the device’s wireless capabilities in one place.
To open Wireless Manager, tap Status Bar > Connectivity icon > Wireless Manager on the Today screen.
Getting Started 1 - 11
Status bar
Figure 1-12
Tapping the Connectivity Icon
Figure 1-13
Opening Wireless Manager
Select Wireless Manager.
1 - 12 MC45 User Guide
Figure 1-14
Wireless Manager Window
NOTE Wireless connection options vary depending upon configurations.
To enable or disable a wireless connection, tap the specific button.
To enable or disable all wireless connections, tap the All button.
To configure settings for a connection, tap Menu.
Figure 1-15
Wireless Manager Menu
Chapter 2 Using the MC45
Introduction
NOTE The WLAN feature is only applicable for the MC4597.
This chapter explains the buttons, status icons, and controls on the MC45, and provides basic instructions for using
the MC45, including powering on and resetting the MC45, and entering and capturing data.
The MC45 factory default radio states are:
• WLAN - OFF
• Bluetooth - OFF
• Phone - ON.
Home Screen
The Home contains the Status Bar at the top of the screen, the Today screen in the center and the Soft Keys at the
bottom of the screen.
Each of these are described below.
2 - 2 MC45 User Guide
Status Bar
Today Screen
Applications
Soft Key Bar
Figure 2-1
Home Screen
Status Bar
The Status Bar at the top of the screen can contain the status icons listed in Table 2-1.
Notifications
Connectivity
WAN
Audio
Battery
Clock
Table 2-1
Status Icons
Icon
Description
Notifications
Notification that one or more instant messages were received.
Notification that one or more e-mail/text messages were received.
Notification that one or more voice messages were received.
Speakerphone is on.
There are more notification icons than can be displayed. Tap to display remaining icons.
Indicates a reminder of an upcoming calendar event.
One or more Email messages were received.
Receiving MMS message.
Sending MMS message.
MMS message sent successfully.
Using the MC45 2 - 3
Table 2-1
Status Icons (Continued)
Icon
Description
MMS message received sucessfully.
Bluetooth is on.
TTY Headset enabled.
TTY HCO enabled.
TTY VCO enabled.
Microsoft customer feedback alert.
Connectivity
Connection is active.
Connection is not active.
Synchronization is occurring.
WLAN available.
WLAN in use.
HSDPA available.
3G available.
GPRS available.
EGPRS available.
Call missed.
WAN
Dialing while no SIM card is installed.
Voice call in progress.
Calls are forwarded.
Call on hold.
Antenna/signal icon: wireless on/good signal.
Antenna/signal icon: wireless off.
Antenna/signal icon: no service or searching.
HSDPA connecting.
HSDPA in use.
3G connecting.
3G in use.
GPRS connecting.
GPRS in use.
2 - 4 MC45 User Guide
Table 2-1
Status Icons (Continued)
Icon
Description
EGPRS connecting.
EGPRS in use.
Roaming.
SIM Card not installed.
Audio
All sounds are on.
All sounds are off.
Vibrate is on.
Battery
Battery is charging.
Battery has a full charge.
Battery has a high charge.
Battery has a medium charge.
Battery has a low charge.
Battery has a very low charge.
Icon Bar
Tap the Status Bar to display the icon bar. Tap an icon to get additional notification or status information.
Figure 2-2
Icon Bar
Using the MC45 2 - 5
Table 2-2
Icon
Bar Icons
Name
Description
Magnify
Enlarges the screen.
Bluetooth
Displays the Bluetooth dialog box.
WLAN
Displays the Network Detection dialog box.
Voicemail
Dials Voicemail.
Notifications
Indicates that notifications are available.
Headset
Indicates that a wireless stereo headset is connected to the MC45.
Connectivity
Displays the Connectivity dialog box.
Phone Data
Displays the Phone dialog box.
Volume
Displays the Volume dialog box.
Power
Displays the Power window.
Clock & Alarms
Opens the Clock & Alarms window.
Today Screen
The Today screen is scrollable and contains a list of applications and an Information Status bar. The Information
Status bar highlights the application that is under it and provides additional information.
Touch and hold the screen with your finger and move the Today screen up and down. As the application names
move under the Information Status bar, information relevant to that application appears in the bar.
Figure 2-3
Moving Today Screen
You can also touch and hold the Information Status bar and move it up and down over an application name.
Remove your finger and the Information Status bar and application name center in the screen.
2 - 6 MC45 User Guide
Figure 2-4
Moving Information Status Bar
Application Icon
Application Information
Figure 2-5
Information Bar Example
To customize the Today screen, tap Start > Settings > Today icon. Use the Appearance tab to customize the
background and the Items tab to change the display format.
Classic Today Screen
The user can change the Today screen to the classic layout that is used in Windows Mobile 6.5.3.
Using the MC45 2 - 7
Status Bar
Today Screen
Task Tray
Soft Key Bar
Figure 2-6
Classic Today Screen
To change to the classic view tap Start > Settings > Home icon > Items tab.
Figure 2-7
Today Screen Settings
Deselect the Windows Default checkbox and select any of the other checkboxes.
Tap OK.
NOTE The task bar is only visible in the classic view.
The task bar at the bottom of the screen can contain the task tray icons listed in Table 2-3.
Table 2-3
Icon
Task Tray Icons
Name
Description
Wireless connection
status
Indicates WLAN signal strength.
ActiveSync
Active serial connection between the MC45 and the host computer.
DataWedge
Provides access to the DataWedge interface.
2 - 8 MC45 User Guide
Soft Keys Bar
The Soft Key bar is located at the bottom of the screen and contains two soft key buttons. These buttons display an
action and a menu to the user that are context sensitive and can be changed dynamically by an application. For
example, in the Contacts list view, the soft keys are New and Menu. As the user begins creating a new contact in
edit view, the soft keys change to Done and Menu.
Start Screen
The Start screen lists applications and folders available to the user. Table 2-4 lists the default programs and folders
listed on the Start screen.
Figure 2-8
Table 2-4
Icon
Start Screen
Programs and Folders on the Start Screen
Name
Description
Icon
Name
Description
Today
Close the Start menu and
display the Today screen.
E-mail
Send an Email.
Text
Send an SMS text message.
Contacts
Keep track of friends and
colleagues.
Calendar
Keep track of appointments
and create meeting
requests.
Internet
Explorer
Browse Web and WAP sites
as well as download new
programs and files from the
Internet.
Settings
Open the Settings folder.
See Settings Folder on page
2-11.
Pictures &
Videos
View and manage pictures,
animated GIFs, and video
files.
Getting
Started
Launch the Getting Started
application.
Windows
Media
Play back audio and video
files.
Using the MC45 2 - 9
Table 2-4
Icon
Programs and Folders on the Start Screen (Continued)
Name
Description
Icon
Name
Description
Messenger
Use this mobile version of
Windows Live Messenger.
Marketplace
Purchase applications from
the Marketplace.
Phone
Make and receive calls,
switch between calls, and
set up conference calling.
MSN
Weather
Check the local weather.
Windows Live
Use this mobile version of
Windows Live™ to find
information on the web.
MSN Money
Keep track of your finances.
Games
Play games.
Remote
Desktop
Log onto Windows NT server
type computers and use all of
the programs that are
available on that computer
from the MC45.
Notes
Create handwritten or typed
notes, drawings, and voice
recordings.
Calculator
Perform basic arithmetic and
calculations, such as
addition, subtraction,
multiplication, and division.
Tasks
Keep track of your tasks.
File Explorer
Organize and manage files
on your device.
ActiveSync
Synchronize information
between the MC45 and a
host computer or the
Exchange Server.
Office Mobile
Use the complete suite of
Microsoft® Office
applications for your mobile
device.
Excel Mobile
OneNote Mobile
PowerPoint Mobile
Word Mobile
Internet
Sharing
Connect a notebook
computer to the Internet
using the MC45's data
connection.
Task
Manager
Enables viewing of memory
and CPU allocations and
stops running processes.
Refer to the Microsoft
Applications for Windows
Embedded Handheld 6.5.3
User Guide for more
information.
Search
Phone
Search contacts, data, and
other information on the
MC45. Refer to the Microsoft
Applications for Windows
Embedded Handheld 6.5.3
User Guide for more
information.
Wireless
Companion
Open the Wireless
Companion folder.
2 - 10 MC45 User Guide
Table 2-4
Icon
Programs and Folders on the Start Screen (Continued)
Name
Description
Icon
Name
Description
Help
See Help topics for the
current screen or program.
AirBEAM
Client
Allows specially designed
software packages to be
transferred between a host
server and the MC45. Refer
to the MC45 Integrator
Guide for more information.
SMS Staging
Intercepts SMS Staging
messages and reassembles
them into the original
Staging Profile.
MSP Agent
Interacts with MSP agents to
collect monitoring and asset
information to enable the
configuration, provisioning,
monitoring and
troubleshooting of the
MC45. Refer to the MC45
Integrator Guide for more
information.
Rapid
Deployment
Client
Facilitates software
downloads from a Mobility
Services Platform Console
FTP server to the MC45.
Refer to the MC45 Integrator
Guide for more information.
DEMO
Launches the DEMO
applications. This icon
appears after the DEMO
applications have been
installed.
Alarms
Sets the clock to the date and
time of your locale. Alarms
can also be set at specified
days and times of a week.
Toolbox
Contains the Adobe
Reader, Streaming Player
and Voice Commander
applications.
Debug
Contains the RIL Logger and
RTLogExport applications.
Use when instructed to by
Motorola support personnel.
Using the MC45 2 - 11
Settings Folder
Table 2-5 lists the setting applications pre-installed on the MC45. Tap Start > Settings to open the Settings folder.
Table 2-5
Icon
Setting Applications in the Setting Folder
Name
Description
Icon
Name
Description
Clock &
Alarms
Set the device clock to the
date and time of your locale
or to a visiting time zone
when you’re traveling.
Alarms can also be set at
specified days and times of
a week.
Power
Check battery power and set
the time-out for turning off
the display to conserve
battery power.
Lock
Set a password for the
MC45.
Sounds &
Notifications
Enable sounds for events,
notifications, and more, and
set the type of notification for
different events.
Connections
Folder
Contains connection
applications (see below).
Home
Customize the appearance
of the Today screen and the
information to display on it.
Personal
Folder
Contains personal
applications (see below).
Bluetooth
Open the Bluetooth
application, set the MC45 to
visible mode and scan for
other Bluetooth devices in
the area.
System
Folder
Contains system
applications (see below).
Connections Folder
Beam
Set the MC45 to receive
incoming IrDA beams.
Connections
Set up one or more types of
modem connections for your
device, such as phone
dial-up, GPRS, Bluetooth,
and more, so that your
device can connect to the
Internet or a private local
network.
Domain
Enroll
Make your device an AD
domain member for device
management and security.
Refer to the Microsoft
Applications for Windows
Mobile 6 User Guide for
more information.
GPS Assist
Helps to find your MC45
location faster.
Phone
Network
Setup
Activate the phone and
setup the network.
USB Connect
Enables or disables the
enhanced network
connectivity.
2 - 12 MC45 User Guide
Table 2-5
Icon
Setting Applications in the Setting Folder (Continued)
Name
WLAN
Description
Icon
Name
Description
Setup wireless network
connection and customize
settings.
Wireless
Manager
Enables or disables the
MC45’s wireless radios and
customizes WLAN, and
Bluetooth settings.
Buttons
Assign a program to a
button.
Owner
Information
Enter personal information
on the MC45.
Input
Set options for each of the
input methods.
Phone
Configure phone settings.
KeyRemap
Remap the keys in the hard
keypad.
Voice
Commander
Settings
Enable user to use speech
commands on the MC45.
About
View basic information such
as the Windows Mobile®
version and type of
processor used on the
MC45.
Certificates
See information about
certificates installed on the
MC45.
Backlight &
Keylight
Set the display backlight and
keylight time-out and adjust
brightness.
Customer
Feedback
Submit feedback on the
Windows Mobile 6 software.
Error
Reporting
Enable or disable the
device's error reporting
function. When this function
is enabled and a program
error occurs, technical data
about the state of the
program and your computer
is logged in a text file and
delivered to Microsoft's
technical support if you
choose to send it.
Encryption
Allow files on a storage card
to be encrypted. Encrypted
files are readable only on
your device.
DataWedge
Enable or disable the
barcode scanning function.
Device
Information
Display the MC45 hardware
information.
Personal Folder
System Folder
Using the MC45 2 - 13
Table 2-5
Icon
Setting Applications in the Setting Folder (Continued)
Name
Description
Icon
Name
Description
External GPS
Set the appropriate GPS
communication ports, if
required. You may need to
do this when there are
programs on the device that
access GPS data or you
have connected a GPS
receiver to the device.
Managed
Programs
Displays the programs that
were installed on the MC45
using Mobile Device
Manager.
Task
Manager
Stop running programs.
Memory
Check the device memory
allocation status and
memory card information
and stop currently running
programs.
Regional
Settings
Set the regional
configuration to use,
including the format for
displaying numbers,
currency, date, and time on
the MC45.
Remove
Programs
Remove programs that you
installed on the MC45.
System Info
Displays the MC45’s
software and hardware
information.
Screen
Change the screen
orientation, re-calibrate the
screen, and change the
screen text size.
2 - 14 MC45 User Guide
Adjusting Volume
To adjust the system volume using the Speaker icon in the navigation bar:
1.
Tap the Speaker icon. The Volume dialog box appears.
Figure 2-9
Volume Dialog Box
2.
Tap and move the slide bar to adjust the volume.
3.
Select the On or Off radio button to turn the volume on or off.
You can also adjust the system volume using the Sounds & Notifications window, or use the Up/Down button on
the side of the MC45.
Using the MC45 2 - 15
Battery Status Indications
Battery icons appear on the navigation bar indicating the battery power level. When the battery power falls below a
predetermined level the icon indicates the status and a battery dialog box appears indicating the status of the
battery.
The Battery icon always appears in the navigation bar when the Today screen is visible. The icon indicates the
battery power level. The message displays until the Dismiss button is pressed.
Figure 2-10
Battery Icon on the Title Bar
Also view the battery status using the Power window.
Figure 2-11
Battery Status.
2 - 16 MC45 User Guide
LED Indicators
The MC45 has one LED indicator. The Charging/Battery Status LED indicates battery charging and status.
Charging/Battery
Status LED
LED Indicators
Figure 2-12
Table 2-6
LED Indications
LED State
Indication
Charging/Battery Status LED
Slow Blinking Green
Battery in MC45 is charging.
Solid Green
Battery in MC45 is fully charged.
Fast Blinking Red
Charging error.
Off
Not charging.
Single Blink Green (when Power button pressed)
Start-up commenced.
NOTE During an over temperature error condition, the Charging Error indication will only appear if the condition
exists for more than 30 minutes.
NOTE For information about scanning/decoding, see Chapter 3, Data Capture. For information about WAN radio
status and settings, see Chapter 4, Using the Phone, or refer to the MC45 Integrator Guide.
Using the MC45 2 - 17
Resetting the MC45
To perform a reset simultaneously press the Power button and the 1 and 9 keys.
Waking the MC45
The wake-up conditions define what actions wake up the mobile computer after it has gone into suspend mode.
The mobile computer can go into suspend mode by either pressing the Power button or automatically by Control
Panel time-out settings. These settings are configurable and the factory default settings are shown in are subject to
change/update. To change the wake-up conditions, tap Start > Settings > Power > Wakeup.
Figure 2-13
Wake-up Device Window
Locking the MC45
NOTE You can make emergency calls even when the MC45 is locked.
Use the Device Lock feature to prevent use of the device. Note that when locked, the MC45 does not respond to
screen or keypad input.
To lock the MC45, tap Start > Lock or press the Power button for three seconds and then tap Lock Device. The
Lock screen appears.
To unlock the MC45, side the Lock button to the left or right.
2 - 18 MC45 User Guide
Figure 2-14
Unlock Device Window
If the MC45 was locked with a password, a prompt appears for the password.
Password Locking
Use the Password window to set a password to disable unauthorized access to the MC45.
NOTE If the device is configured to connect to a network, use a strong (difficult to figure out) password
to help protect network security. Password cracking tools continue to improve and the
computers used to crack passwords are more powerful than ever.
1.
Tap Start > Settings > Lock icon > Password tab.
Figure 2-15
Password Window - Password Tab
2.
Select Prompt if device unused for check box to enable password protection.
3.
From the drop-down list, select a time value for the protection to take affect after non-use.
4.
From the Password type: drop-down list, select either Simple PIN or Strong alphanumeric.
5.
For a simple password, enter a four-digit password in the Password field.
For a stronger password:
Using the MC45 2 - 19
a.
Enter a seven character password in the Password: field. A strong password must contain at least seven
characters and contain at least three of the following: uppercase and lowercase letters, numerals, and
punctuation.
b.
Re-enter the password in the Confirm: field.
6.
Tap OK.
7.
To set a hint to remember the password, tap the Hint tab.
8.
In the text box, enter a hint for a password reminder.
9.
Tap OK.
NOTE You can make emergency calls even when the MC45 is password locked.
When the MC45 is not used for a period of time and the user tries to access the device, the Password window
appears. This also appears when the MC45 is connected to a host computer with either a cradle or communication
cable.
Figure 2-16
Enter Password Windows
Enter the password to un-lock the device.
Tap the Unlock button to unlock the device and go to the Today screen, or tap the Contact button to unlock the
device and go to the Contacts window or tap the Email button to unlock the device and go to the Messaging
window.
2 - 20 MC45 User Guide
Function Buttons
The MC45’s buttons perform certain functions.
Programmable
Button (Scan)
Volume Buttons
Scan Button
Up/Down Button
Programmable
Button (Camera)
Power Button
Figure 2-17
Function Buttons
• Power: Press the red Power button to turn the MC45 screen on and off. The MC45 is in suspend mode when
the screen is off. For more information, see Powering On the MC45 on page 1-8. Also use the Power button
to reset the MC45 by performing a warm or cold boot. See Resetting the MC45 on page 2-17.
• Scan: Press to scan bar codes or capture images. See Chapter 3, Data Capture.
Or, press to open an application or perform a function. See the Microsoft® Applications for Windows
Embedded Handheld 6.5 User Guide to set an application to open.
• Up/Down: Press to increase or decrease the MC45’s volume.
Using the MC45 2 - 21
Stylus
Use the MC45 stylus to select items and enter information. The stylus functions as a mouse.
• Tap: Touch the screen once with the stylus to press option buttons and open menu items.
• Tap and Hold: Tap and hold the stylus on an item to see a list of actions available for that item. On the pop-up
menu that appears, tap the action to perform.
• Drag: Hold the stylus on the screen and drag across the screen to select text and images. Drag in a list to
select multiple items.
CAUTION To prevent damage to the screen, do not use any device other than the Motorola-provided stylus.
Entering Data
When entering data on the keypad, use either the single-hand method or the two-hand method as shown in Figure
2-18.
Single-hand Method
Figure 2-18
Entering Data on the Keypad
Two-hand Method
2 - 22 MC45 User Guide
Display Orientation
The screen can be rotated between portrait and landscape modes manually. To change the orientation of the
screen, tap Start > Settings > System > Screen > General tab and select between three different types of
orientations:
• Potrait
• Landscape (right-handed)
• Landscape (left-handed).
Figure 2-19
Display Orientation Window
Using the MC45 2 - 23
Taking Photos
To take a photo:
1.
Press the side Camera button or tap Start > Pictures & Videos and then tap Camera on the Command bar.
2.
Check the image on the view finder, adjust if necessary.
3.
Press the side Camera button or the ENTER key to take the picture. Hold the MC45 still until the camera flash
occurs or the shutter sound is heard.
Recording Video
To record a video clip:
1.
Press the side Camera button or tap Start > Pictures & Videos and then tap Camera on the Command bar.
2.
Tap Camera on the command bar.
3.
Tap Menu > Video to set shooting mode to video.
The available recording time displays on the screen.
NOTE By default, the time limit for recording videos is set to 30 seconds.
4.
Press the OK key or the side Camera Button to begin recording.
Recording stops when you press the OK key or the side Camera Button again.
Viewing Photos and Videos
To view photos and video clips:
1.
Tap Start > Pictures & Videos icon.
2.
Tap the picture or video clip to view.
2 - 24 MC45 User Guide
Chapter 3 Data Capture
Introduction
The MC45 offers two types of data capture options:
• Laser scanning
• Color digital camera.
The MC45 contains the DataWedge application that allows user to enable the camera, decode the bar code data
and display the bar code content. To enable DataWedge, see DataWedge on page 3-4.
Laser Scanning
An MC45 with an integrated laser scanner has the following features:
• Reading of a variety of bar code symbologies, including the most popular 1-D code types.
• Intuitive aiming for easy point-and-shoot operation.
• Adaptive Scanning.
Scanning Considerations
Typically, scanning is a simple matter of aim, scan, and decode and a few quick trial efforts master it. However,
consider the following to optimize scanning performance:
• Range
Any scanning device decodes well over a particular working range — minimum and maximum distances from
the bar code. This range varies according to bar code density and scanning device optics.
Scanning within range brings quick and dependable decodes; scanning too close or too far away prevents
decodes. Move the scanner closer or further away to find the right working range for the bar codes being
scanned.
• Angle
Scanning angle is important for promoting quick decodes.
3 - 2 MC45 User Guide
• Hold the MC45 farther away for larger symbols.
• Move the MC45 closer for symbols with bars that are close together.
NOTE Scanning procedures depend on the application and MC45 configuration. An application may use different
scanning procedures from the one listed above.
Bar Code Scanning
CAUTION Do not aim the scan beam at your eyes and others.
1.
Ensure that a scan-enabled application is loaded on the MC45.
Figure 3-1
2.
Linear Scanning
Press and hold the scan button. The laser beam exits from the end of the MC45. Ensure the red scan beam
covers the entire bar code. The Scan/Decode LED lights red to indicate that scanning is in process, then lights
green and a beep sounds, by default, to indicate the bar code was decoded successfully.
Correct
Figure 3-2
3.
Incorrect
Linear Scanner Aiming Pattern
Release the scan button.
Adaptive Scanning
The MC45 contains the adaptive scanning feature that automatically adjusts the scan beam width for rapid and
easy scanning of bar codes from near contact to more than 200 inches away.
By default the MC45 is set to wide scan beam width. When the user presses the scan button, the MC45 determines
the distance from the bar code. For close bar codes the MC45 sets a wide beam width and for far bar codes it sets
a narrow beam width. The MC45 uses distance, bar code type and material to determine the correct scan beam
width.
Data Capture 3 - 3
Figure 3-3
Adaptive Scanning
Color Digital Camera
MC45 with an integrated color digital camera have the following features:
• Omnidirectional reading of a variety of bar code symbologies, including the most popular linear, postal,
PDF417, and 2D matrix code types.
• Advanced intuitive aiming for easy point-and-shoot operation.
Digital Camera Scanning
1.
Ensure that a scan-enabled application is loaded on the MC45.
2.
Aim the camera lens on the back of the MC45 at a bar code.
3.
Press and hold the scan button. In the image window, align the camera over the barcode.
Figure 3-4
4.
Digital Camera Scanning
The Scan/Decode LED lights green and a beep sounds, by default, to indicate the bar code was decoded
successfully. Release the scan button.
3 - 4 MC45 User Guide
NOTE The camera decode feature is set by default to automatically decode the bar code when read. This feature
can be programmed to display a red aiming reticle that turns green upon good decode indicating that the bar
code has been successfully decoded and to that the scan button may be released.
DataWedge
DataWedge allows the user to input captured bar code data into a text field of an application.
To enable DataWedge:
1.
Tap Start > Settings > System > DataWedge.
2.
Tap Basic Configuration.
3.
Tap 1. Barcode input.
4.
Select one of the following
a.
Tap 1. SSI Scanner Driver for the laser scanner.
b.
Tap 2. Camera Scanner Driver for the camera.
5.
Tap 1. Enabled.
6.
Tap 0. Back.
7.
Tap 0. Back.
8.
Tap 0. Exit.
9.
Tap OK.
10. Tap the Running option to start the DataWedge prcoess. The DataWedge Status changes to Ready.
11. Tap OK.
To disable DataWedge:
1.
Tap Start > Settings > System > DataWedge.
2.
Tap the Running option to end the DataWedge process. The DataWedge Status changes to Stopped.
3.
Tap OK.
Chapter 4 Using the Phone
Introduction
Use the MC45 to make phone calls, set up speed dials, keep track of calls, and send text messages. Your wireless
service provider may also provide other services such as voice mail, call forwarding, and caller ID.
Also use the integrated phone to connect to an ISP or work network in order to browse the Web and read e-mail.
Connect to the Internet or work network over High-Speed Downlink Packet Access (HSDPA) using Cellular Line, or
using the modem specified by the mobile operator. For more information, or to customize the MC45 phone by
changing phone settings, see the MC45 Integrator Guide.
Accessing the Phone Dialer
NOTE Dialers vary depending on the carrier, services and the state of the phone. For example, place calls on hold
and use
to create conference calls. (See Conference Calling on an MC45 on page 4-17.)
Access the dialer regardless of the program in use. Applications on the MC45 can be in use during a call.
Antenna Signal
Call Line
Figure 4-1
Phone Dialer
4 - 2 MC45 User Guide
To access the phone dialer tap Start > Phone or press
.
To receive calls when the MC45 is suspended, leave the phone radio turned on and ensure the MC45 is set to
wake with any key.
Turning the Phone On and Off
Windows Embedded Handheld 6.5 devices include Wireless Manager, which provides a simple method of
enabling and disabling the phone.
To open Wireless Manager, tap the Connectivity icon.
Figure 4-2
Opening Wireless Manager
Select Wireless Manager. The Wireless Manager window appears.
To toggle on or off the phone, tap blue Phone bar.
To configure settings for a connection, tap Menu > Phone Settings.
Using the Phone 4 - 3
Audio Modes
The MC45 offers three audio modes for use during phone calls:
• Handset Mode: Switches audio to the speaker at the top front of the MC45, so you can use the MC45 as a
handset. This is the default mode.
• Speaker Mode: Use the MC45 as if on speaker phone. Tap the Speaker On button to activate this mode.
Tap the Speaker Off button to switch back to handset mode.
• Headset Mode: Connect a Bluetooth headset to automatically switch audio to the headset.
The MC45 defaults to handset mode. When a Bluetooth headset is configured for use with the MC45, the earpiece
and speakerphone are muted and audio is heard through the headset.
NOTE While using a Bluetooth headset during a call, the mobile computer will not go into suspend mode.
Handset Mode
Figure 4-3
Speaker Mode
Headset Mode
Audio Modes
Using a Bluetooth Headset
You can use a Bluetooth headset for audio communication when using an audio-enabled application. See Chapter
7, Using Bluetooth for information on connecting a Bluetooth headset to the MC45. Set the MC45’s volume
appropriately before putting the headset on. When a Bluetooth headset is connected the speakerphone is muted.
It is recommended for phone conversations to use the Bluetooth Hands-free profile instead of the Headset profile.
See Chapter 7, Using Bluetooth for more information.
NOTE When using a Bluetooth headset during a call, the MC45 power button is disabled and the MC45 will not go
into suspend mode. Once the call is completed, the power button functionality is enabled.
The following dialog box displays when a Bluetooth headset connection is established.
4 - 4 MC45 User Guide
Figure 4-4
WWAN Bluetooth Audio Notification Dialog Box
Adjusting Audio Volume
Use the Volume Control Slider or the keypad keys to adjust the volume of the ringer when not in a call and the
audio volume when in a call.
Phone Volume Slider
Ringer Volume Slider
Figure 4-5
Phone Volume Slider
To adjust the volume tap the Speaker icon in the Title bar. Move the slider up or down to adjust the volume.
NOTE Adjust the conversation phone volume during a call. Adjusting the volume while not in a call affects the ring
and notification sound levels.
Using the Phone 4 - 5
Making a Call
NOTE You can make emergency calls even when the MC45 is locked or when a SIM card is not installed. See
Making an Emergency Call on page 4-7 for more information.
With the MC45, you can make a call from the phone dialer, contacts, speed dial and call history.
Using the Phone Keypad
To make a call using the phone keypad:
1.
Tap Start > Phone or press
2.
Enter the phone number on the dialer or keypad. The number appears in the Call Line.
3.
Tap the green Call Line or press
4.
Tap
5.
When the call connects, the name or number appears in the Call Line. To place the call on hold, press
to cancel the call or tap
To return to the call, press
.
.
to place the MC45 in speakerphone mode.
again.
NOTE Placing a call on hold using the Call Line can be enabled. To enable, press
The toggle icon changes to On.
6.
Tap
or press
to end the call.
Using Contacts
Use Contacts to make a call without looking up or entering the phone number.
To make a call from Contacts:
1.
Tap Start > Contacts.
2.
From the contact list, tap and hold the contact name.
>
> Enable Hold.
.
4 - 6 MC45 User Guide
Figure 4-6
3.
Contacts Menu
Tap Call Work, Call Home or Call Mobile.
NOTE To make a call from an open contact, tap the number to call. See On-Device Help for more information about
Contacts.
Using Call Log
To make a call using Call Log:
1.
Tap Start > Phone or press
2.
From the Phone dialer, tap
.
.
Call Log
Figure 4-7
Call Log Window
3.
Tap on the desired Contacts name to begin dialing and return to the phone dialer.
4.
Press
to stop dialing or end the call.
Using the Phone 4 - 7
Making a Speed Dial Call
Use Speed Dial to call someone saved in the speed dial directory.
To make a speed dial call:
1.
Tap Start > Phone or press
.
2.
From the Phone keypad, tap the speed dial location number assigned to a contact.
Speed Dial
Location Number
Figure 4-8
3.
Press
Speed Dial Contact List
to stop dialing or end the call.
Making an Emergency Call
Your service provider programs one or more emergency phone numbers, such as 911, 999 or 112 that you can call
under any circumstances, even when your phone is locked or the SIM card is not inserted. Your service provider
can program additional emergency numbers into your SIM card. However, your SIM card must be inserted in your
phone in order to use the numbers stored on it. See your service provider for additional information. See Installing
the mini-SIM Card on page 1-4 for SIM card installation procedures.
When the alpha-numeric keypad phone is locked, press the Orange key twice to set the keypad to numeric mode
and then enter the emergency number.
NOTE Emergency numbers vary by country. Your phone’s pre-programmed emergency number(s) may not work in
all locations, and sometimes an emergency call cannot be placed due to network, environmental, or
interference issues.
Answering a Call
A dialog box appears on the MC45 when it receives an incoming call. If the phone is set to ring, a ring tone sounds.
Answer or ignore the incoming call.
To answer an incoming call tap
on the Phone - Incoming dialog or press
.
4 - 8 MC45 User Guide
Figure 4-9
Incoming Call
To ignore the incoming call tap
or press
. This may send the caller to voice mail, depending on the
service provider. Otherwise, this presents busy signal to the calling party.
Press
to stop dialing or end the call..
Incoming Call Features
• You can use other programs on the MC45 during a call. To switch back to Phone, press
or tap Start
> Phone. Tap End to end the call.
• If a caller isn't in your contact list, create a contact during the call or from Call History by tapping Menu >
Save to Contacts.
• To hold the current call and answer a waiting call, tap
on the Phone - Incoming dialog or press
.to place the current call on hold and answer the incoming call.
• To put a call on hold to call another number, press
• To move from one call to another, press
or tap the green Call Line.
on the MC45 or tap the green Call Line.
Smart Dialing
Smart Dialing makes it easy to dial a phone number. When you start entering numbers or characters, Smart Dialing
automatically searches and sorts the contact entries on the SIM card, in Contacts, and the phone numbers in Call
History (including incoming, outgoing, and missed calls). You can then select the desired number or contact from
the filtered list to dial.
Open the Phone screen, then tap the keys on the Phone keypad that correspond to the phone number or contact to
call. The contact panel lists contacts that match the sequence that you entered.
Smart Dialing starts looking for numbers or contacts that match the sequence entered.
To find a phone number:
• Enter the first one or two digits to find a phone number in Call History.
Using the Phone 4 - 9
• Enter the first three digits or more to find a phone number from the saved Contacts and SIM card.
To find a contact name:
• Enter the first letter of a contact’s first name or last name. Smart Dialing searches for the letter starting
from the first character of a contact name as well as from the character that appears after a space, dash,
or underscore in a contact name. For example, if you tap number “2” which is associated with [a, b, c] on
the Phone keypad, contact names such as the following will be considered matches: “Smith, Bernard”,
“Adams, John”, “Carlson, Eileen”, “Dillon, Albert”, “Childs, Larry”, “Cooper, Robert” and “Parks, Celine”.
• If the matching list is long narrow down the search further by entering another letter. Using the same
example above, tap “3” which is associated with (d, e, f), the matching list is narrowed down to the
following names: “Smith, Bernard”, “Adams, John”, and “Parks, Celine”.
Figure 4-10
Finding a Contact
To make a call or send a text message using Smart Dialing:
1.
Begin entering the first few numbers or characters.
2.
In the Smart Dialing panel, use the up and down arrows on the keypad to navigate to the desired contact or
phone number.
3.
When the correct contact is selected, press
4.
To send a text message to the selected contact, tap Menu > Send Text Message.
5.
To call a different phone number associated with the selected contact, tap the contact name and select the
phone number to call.
to make a voice call.
Muting a Call
During a call, you can mute the microphone so you can hear the person on the line but he or she cannot hear
conversation from the microphone. This is useful when there is conversation or background noise on your end.
To mute or unmute a call:
1.
Tap Start > Phone or press
2.
Make a call.
.
4 - 10 MC45 User Guide
3.
Tap
on the display to mute the audio. The Mute button becomes yellow.
Using Speed Dial
Create speed dial numbers to dial frequently called numbers with a single tap. Before creating a speed dial entry,
ensure the phone number exists in Contacts.
Adding a Speed Dial Entry
To add a speed dial entry from the phone keypad:
1.
Ensure the contact and phone number are in the Contacts list.
2.
Tap Start > Phone or press
3.
Tap
Figure 4-11
.
.
Contacts
4.
Tap the desired contact name and number in the list.
5.
Tap
> Add to Speed Dial.
Using the Phone 4 - 11
Figure 4-12
Speed Dial Contact Location
6.
In the Location field, tap the up/down arrows to select an available location to assign as the new speed dial
entry. The first speed dial location is reserved for voice mail.
7.
Tap OK to add the contact to the speed dial list.
To add a speed dial entry from the Contacts window:
1.
Tap Start > Contacts.
Figure 4-13
Contacts
2.
Tap a contact name.
3.
Tap Menu > Add to Speed Dial.
4 - 12 MC45 User Guide
Speed Dial Contact Location
Figure 4-14
4.
In the Location drop-down list, select a different available location to assign as the new speed dial entry. The
first speed dial location is reserved for voice mail.
5.
Tap OK.
Editing a Speed Dial Entry
To change a speed dial entry:
1.
Tap Start > Phone or press
.
2.
Tap
3.
Tap the desired contact name in the list.
4.
Tap
5.
In the Location drop-down list, select a different available location to assign as the new speed dial entry. The
first speed dial location is reserved for voice mail.
6.
Tap OK to change the speed dial list.
7.
Tap OK to exit the Edit Contacts window.
8.
Tap X to exit the Contacts window.
.
> Edit Speed Dial.
Deleting a Speed Dial Entry
To delete a speed dial entry:
1.
Tap Start > Phone or press
.
2.
Tap
3.
Tap the desired contact name in the list.
.
Using the Phone 4 - 13
4.
Tap
> Edit Speed Dial.
5.
Tap
.
6.
Tap Yes to confirm permanently deleting the speed dial entry.
NOTE Deleting names and phone numbers in Speed Dial does not delete the contact information in Contacts (Start
> Contacts).
7.
Tap OK to exit the Edit Contacts window.
8.
Tap X to exit the Contacts window.
Using Call Log
Use Call Log to call someone who was recently called, or recently called in. Call Log provides the time and duration
of all incoming, outgoing, and missed calls. It also provides a summary of total calls and easy access to notes
taken during a call. Table 4-1 lists the call history icons that appear in the Call Log window.
Tap Start > Phone or press
Table 4-1
and then tap
to open the Call Log window
Call Log Icons
Icon
Description
This icon appears next to the contact information for all outgoing calls.
This icon appears next to the contact information for all incoming calls.
This icon appears next to the contact information for all unconnected outgoing calls.
This icon appears next to the contact information for all missed calls.
Managing Call Log
Change views, reset the call timer, and delete calls to manage the calls stored in Call Log.
Changing the Call Log View
1.
Tap Start > Phone or press
and then tap
to open the Call Log window.
2.
Tap
3.
Tap Filters and select a view type from the menu to display only received calls, outgoing calls, incomplete calls
or missed calls.
on the top right corner to show the Call Log menu.
4 - 14 MC45 User Guide
Call Log
Figure 4-15
4.
Tap
Call Log Window
to exit the Call Log window.
Deleting All Call Log Items
1.
Tap Start > Phone or press
2.
From the Phone dialer, tap
3.
Tap
Figure 4-16
4.
to display the Phone dialer.
.
> Delete call logs.
Call Log - Delete Call Logs Menu
Select All call logs.
Using the Phone 4 - 15
Figure 4-17
Call Log - Deleting all call logs
5.
Tap Delete.
6.
Tap OK to exit the Call History window.
Viewing Call Status
1.
Tap Start > Phone or press
2.
From the Phone dialer, tap
3.
Tap an item to call the number or tap
window appears.
Figure 4-18
to display the Phone dialer.
.
Viewing Call Status
4.
Select an applicable option from the list.
5.
Tap
6.
Tap
to exit the Options window.
to close the Call Log window.
to open the Options window for that item. The Call Log Options
4 - 16 MC45 User Guide
NOTE When more than one call is on the phone line, only the duration of the first call is recorded.
Using the Call Log Options
Use the Call Log Options to dial voice mail, save to contacts, view a note, delete a listing, send a text message,
and make a call.
1.
Tap Start > Phone or press
to display the Phone dialer.
2.
From the Phone dialer, tap
3.
Tap an item to call the number or tap
window appears.
.
to open the Options window for that item. The Call Log Options
Send text message
icon
Figure 4-19
Call Log Option
4.
Select an applicable item from the menu, as needed.
5.
Depending on the item selected, the appropriate window displays. For example, select Send Text Message to
display the Inbox window.
6.
Tap
7.
Tap
to exit the Options window.
to close the Call Log window.
Using the Phone 4 - 17
Conference Calling on an MC45
NOTE Conference Calling and the number of conference calls allowed may not be available on all services. Please
check with your service provider for Conference Calling availability.
To create a conference phone session with multiple people:
1.
Tap Start > Phone or press
2.
Enter the first phone number and tap the Call Line area or press
or number appears in the Call Line
3.
Tap
.
4.
Tap
. The dialer re-appears.
5.
Enter the second number and tap Send.
6.
When the call connects, the first call is placed on hold and the second call is active.
Figure 4-20
to display the Phone dialer.
Creating a Conference Call
7.
Tap call Line 1 to make that call active. The second call goes on hold.
8.
Tap
to create a conference call (three callers).
. When the call connects, the name
4 - 18 MC45 User Guide
Figure 4-21
9.
Two Merged Calls
To add a third caller, tap
conference is on hold.
Figure 4-22
. The dialer appers. When the call connects, the new call is active and the
Adding a Third Call
10. To add the new caller to the conference, tap
.
Using the Phone 4 - 19
Figure 4-23
11. Tap
Three Merged Calls
to view all callers.
Figure 4-24
Un-Merge Calls
12. To remove a caller from the conference, tap the caller and then tap
13. To end the conference call, tap
next to the Call Line or press
Call Completed screen appears and then the dialer displays.
NOTE To speak privately with one party during a conference call, tap
include all parties again, tap
.
next to the caller or press
.
.
and then tap
next to the caller. To
4 - 20 MC45 User Guide
SMS Messaging
Text messages allow the user to send and receive short text messages (SMS) to and from other mobile devices.
The text can contain words, numbers or an alphanumberic combination no longer than 160 characters.
Sending a Text Message
To send a text message:
1.
Tap Start > Text.
2.
Tap
> New > SMS.
Address Area
Message Area
Figure 4-25
Create Text Message
3.
Tap To to select a recipient from Contacts.
4.
Compose your message.
• The auto-correct feature automatically fixes common spelling errors as you type so your messages are
more accurate.
• The character counter lets you see and control the size of the message as you compose.
• If you want to know if your text message was received, tap
Request message delivery notification check box.
5.
Tap
> Message Options, then select the
to send the message.
If the phone is turned on, your text message is sent. If it’s off, you are prompted to turn on the phone. If you do
so, the message is sent; otherwise when you tap OK, the message is saved in the Drafts folder and sent when
the phone is turned on.
If you are out of coverage area, the message is saved in the Drafts folder and sent when you return to a
coverage area.
NOTE On MC45 devices, the message remains in the Drafts folder and has to be manually re-sent when you return
to a coverage area.
Using the Phone 4 - 21
Viewing Text Messages
To view a text message:
You can view a text message whether the phone is on or off. When the phone is on, you can view a text message
from its notification callout. Tap the text message notification icon on the navigation bar to display the message.
Text Message Notification Icon
Figure 4-26
New Text Message Notification
The Caller Identification feature matches incoming text message numbers with those stored in Contacts so you
know who is sending you a message. Furthermore, the New Text Message dialog box gives you the option to call
the sender or save, dismiss, or delete the message.
Figure 4-27
New Text Message Options
When the phone function is off, you can still view received text message in Messaging:
1.
Tap Start > Text or on the Today screen, tap the text message on the Information Bar.
4 - 22 MC45 User Guide
Tap to View Text Messages.
Figure 4-28
Text Messaging on Today Screen
2.
The Text Messages window appears.
3.
In the message list, tap the text message.
Enter reply here.
Figure 4-29
Text Messages List
Replying to a Text Message
To reply to a text message:
1.
Tap Start > Text.
2.
In the message list, tap a text message. The window displays previous text conversations.
3.
Enter text in the reply field.
4.
Tap
to send the reply.
MMS Messaging
MMS Messaging allows the user to send a pictures, videos, audio files and other file types to another mobile
computer.
Using the Phone 4 - 23
Creating and Sending MMS Messages
To send an MMS message:
1.
Tap Start > Text.
2.
Tap
> New > MMS.
Figure 4-30
MMS Window
3.
To add a contact, tap
Done.
. A window appears with a list of contacts. Select one or more contacts and then tap
4.
Tap
5.
Tap in the text window to enter a text message. A window appears allowing you to add a text message plus
emoticons, favorite web addresses, pre-defined text, contact information and calendar information. Tap Done
after adding information.
6.
Tap
to attach a picture or video stored on the MC45 to the message.
7.
Tap
to attach a sound file stored on the MC45 to the message.
8.
Tap
to take a picture and attach it to the message.
9.
Tap
to capture video and attach it to the message.
to add a subject for the message. Enter the subject text in the window and then tap Done.
10. Tap
to record a message and attach it to the message.
11. Tap
to add a file stored on the MC45 to the message.
12. After all of the items are attached to the message, tap Send.
Viewing an MMS Message
To view an MMS message:
1.
Tap Start > Text.
2.
Tap the MMS message.
3.
In the threaded message, tap the MMS icon to view the message.
4 - 24 MC45 User Guide
4.
Tap Contents to view a list of files included in the message.
On the Message Contents screen:
1.
Tap Menu > Save to save a file.
2.
Tap Menu > Save into My Text to save the contents of a text file to the My Text list.
3.
Tap Menu > Assign to Contact to associate a photo to a contact.
4.
Tap Menu > Set as Ringtone to associate a audio file as a ringtone.
Replying to an MMS Message
To reply to an MMS message
1.
Tap Start > Text.
2.
Tap the MMS message.
3.
In the threaded message, tap the MMS message to open and view an MMS message.
4.
After viewing the MMS message, tap Menu > Reply > via MMS to reply with an MMS message or tap Menu >
Reply > via SMS to reply with a text message.
Blocking Incoming MMS Messages
To block incoming MMS messages from a specific sender:
1. Open and view the MMS message.
2. Tap Menu > Show > Contact Details.
3. Tap Menu > Save to Blacklist.
4. Tap Done.
To unblock a sender:
1.
Tap Start > Text.
2.
Tap Menu > MMS Options > Blacklist.
3.
Tap and hold the phone number.
4.
Select Delete from the pop up menu.
5.
Tap OK.
Voice Commander
Voice Commander is a speech dialog system that provides natural human interface for users to communicate
seamlessly with the MC45. Users can make phone calls, look up contact information, launch programs or check
calendars. Voice Commander contains the following features:
• Eyes-free and hands-free voice command and control.
• Speaker-independent speech recognition technology, no training is required.
Using the Phone 4 - 25
• Ease of use conversational user interface.
• Personal Voice Tag and Digit Model Adaptation to enhance the usability.
To initiate Voice Commander tap Start > Toolbox > Voice Commander or press the call button on a Bluetooth
headset. The system says, “Say a Command.” The user says one of the following commands:
• Call
• Find
• Redial / Callback
• Play Music
• Play
• Next / Previous
• Start
• Appointments
• Read / Call History
• What time is it?
• What can I say?
• Goodbye
Call
To call a person by name:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Call Michael Archer.” System responds with “Call Michael Archer work, is it correct?”
3.
Say “Yes.” MC45 responds with “Dialing.”
To call a person at a location:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Call Mary Smith at home.” The MC45 responds with “Call Mary Smith home, is it correct?”
3.
Say “Yes.” The MC45 responds with “Dialing.”
To call a person with more that one phone number:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Call Alex Jordan.” The MC45 responds with “Call Alex Jordan, home, work, mobile or cancel?”
3.
Say “Home.” The MC45 responds with “Dialing.”
If two people have similar names:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Call Halley Johnson.” The MC45 responds with “More than one Halley Johnson, please select.”
3.
Select the contact intended to call.
4 - 26 MC45 User Guide
NOTE Voice Commander automatically maintains a maximum of 2000 contacts in the recognition database.
If the command can not be recognized, Voice Commander prompts “Please say again.” This situation
could happen under the noisy environment, or when user says command before Voice Commander
starts recording. After hearing the prompt “Say Command”, user should wait one to two seconds to speak
the command.
The recognizable contact length is 48 characters. Contacts exceeding 48 characters will be ignored.
Find
To look up contact information:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Find Mary Smith.” The MC45 responds with “Mary Smith home 5555551212."
To look up a specific number:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Find Michael Archer at work.” The MC45 responds with “Michael Archer, work, 5555551212."
If two contacts have similar names:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Find Haley Johnson at work.” The MC45 responds with “More than one Haley Johnson, please select.”
Voice Commander displays a window with the two contacts. (System will show both Halley Johnson and Haley
Johnson for user to select.)
If a contact is not found:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Find Michael Archer at home.”
3.
MC45 responds with “Michael Archer has no home number.”
Redial
To redial a previous number:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Redial.” The MC45 responds with “Call Mary Smith at home, is it correct?”
3.
Say “Yes.” The MC45 responds with “Dialing.”
Callback
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Callback.” The MC45 responds with “Call Mary Smith at home, is it correct?”
3.
Say “Yes.” The MC45 responds with “Dialing.”
Using the Phone 4 - 27
Start
To launch an application:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Start calendar.” The MC45 responds with “Go to Calendar.” The Calendar application launches.
Appointments
To read today’s, tomorrow’s or this week’s appointments:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Today's appointment.” The MC45 responds with “You have 3 appointments” and reads the appointments.
NOTE User can say Previous, Next, Repeat, or Abort to control calendar reading. Voice Commander only plays the
new appointments. Older appointments are ignored.
Read
To read a text message or an email message:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Read SMS.” The MC45 responds with “You have 3 SMS” and reads the SMS messages.
What time is it
To find out the time of day:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “What time is it?” The MC45 responds with “The time is 3 p.m.”
Call History
To view the call history window:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Call History.” The MC45 responds with “Call history.”
3.
The Call History page displays.
Voice Play Music
To play a specific music file:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Play The Moment.” The MC45 responds with “The Moment.”
3.
Windows Media starts to play “The Moment.”
To play all music files:
4 - 28 MC45 User Guide
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Play music.” The MC45 responds with “Play music.”
3.
Windows Media starts to play all music files.
To play a different music file during playing of another:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Next.” The MC45 responds with “Next.”
3.
Windows Media starts to play next music file.
To pause or resume a playing music file:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “Pause” or “Resume.” The MC45 pauses or resumes the playing music.
NOTE User can say “Pause” or “Resume” to control music playing. The command “Resume” only works when
Windows Media is running. The commands “Previous” and “Next” only work when playing all music files.
Voice Commander only supports media files with .mp3 and .wma format. Voice Commander supports the
music files in Playlists or Media files synched by Active Sync, in My Documents and its subfolder or on the
microSD card and its subfolders.
What can I say
To view the help information:
1.
Initiate Voice Commander. The MC45 responds with “Say command.”
2.
Say “What can I say.” The help file displays.
Alternatively tap Menu > Help to open the help file.
Goodbye
To exit the Voice Commander application, Say “Goodbye.” The MC45 responds with “Goodbye” and the
application terminates.
Voice Commander can be also terminated manually by tapping Menu > Exit. Note that goodbye will not be
accepted during voice digit dialing operation.
NOTE Voice Commander automatically terminates after 10 seconds of silence.
CHAPTER 5 USING WLAN
Introduction
NOTE The WLAN feature is only applicable for the MC4597.
The WLAN feature supports the 802.11 a/b/g networking mode.
WLANs allow the MC45 to communicate wirelessly inside a building. Before using the MC45 on a WLAN, the
facility must be set up with the required hardware to run the WLAN (sometimes known as infrastructure). The
infrastructure and the MC45 must both be properly configured to enable this communication.
Refer to the documentation provided with the infrastructure (access points (APs), access ports, switches,
Radius servers, etc.) for instructions on how to set up the infrastructure.
Once you have set up the infrastructure to enforce your chosen WLAN security scheme, use the Fusion or
Wireless Zero Config (WZC) software to configure the MC45 to match.
Fusion Overview
The Fusion software contains applications with which to create wireless profiles. Each profile specifies the
security parameters to use for connecting to a particular WLAN as identified by its ESSID. The Fusion software
also allows the user to control which profile out of a set of profiles is used to connect. Other Fusion applications
allow the user to monitor the status of the current WLAN connection and to invoke diagnostic tools for
troubleshooting.
To access Fusion, tap the Start >
> Wireless Launcher.
5 - 2 MC45 User Guide
Figure 5-1
Fusion Launcher Window
Refer to the Wireless Fusion Enterprise Mobility Suite User Guide for Version 3.xx for detailed information on
using and configuring Fusion.
To access the on-device Fusion Help tap Start >
> Fusion Help.
Connecting to the Internet
To connect to the Internet on a WLAN when using Fusion, ensure that the network card settings is set to
Internet:
1.
Ensure Fusion is enabled and a profile is configured.
2.
Tap Start > Settings > Connections > WLAN.
3.
In the My network card Connects to drop-down list, select The Internet.
4.
Tap OK.
Wireless Zero Config Overview
WZC is a Microsoft wireless connection management utility that dynamically selects a wireless network to
connect to based on a user's preferences and various default settings.
Switching Between Fusion and WZC
To switch from Fusion to WZC:
1.
Tap the Start >
> Wireless Launcher > Options.
2.
Select WLAN Management from the drop-down list.
3.
Select Microsoft Manages WLAN radio button.
4.
Tap Save.
5.
Tap OK.
6.
Perform a reset.
Using WLAN 5 - 3
To switch from WZC to Fusion:
1.
Tap the Start >
> Wireless Launcher > Options.
2.
Select WLAN Management from the drop-down list.
3.
Select Fusion Manages WLAN radio button.
4.
Tap Save.
5.
Tap OK.
6.
Perform a reset.
Supported Applications
The Fusion menu items and their corresponding applications are summarized in Table 5-1.
Table 5-1
Supported Applications
Application
Fusion
Support
Description
WZC
Support
Find WLANs
Invokes the Find WLANs application which
displays a list of the WLANs active in your area.
Yes
No
Manage Profiles
Invokes the Manage Profiles application
(which includes the Profile Editor Wizard) to
manage and edit your list of WLAN profiles.
Yes
No
Wireless Zero Config
Invokes the Wireless Zero Config application to
configure the WLAN.
No
Yes
Manage Certs
Invokes the Certificate Manager application
which allows you to manage certificates used
for authentication.
Yes
Yes
Manage PACs
Invokes the PAC Manager application which
helps you manage the list of Protected Access
Credentials used with EAP-FAST
authentication.
Yes
No
Options
Invokes the Options application which allows
you to configure the Fusion option settings.
Yes
Yes
Wireless Status
Invokes the Wireless Status application which
allows you to view the status of the current
wireless connection.
Yes
Yes
Wireless Diagnostics
Invokes the Wireless Diagnostics application
which provides tools with which to diagnose
problems with the wireless connection.
Yes
Yes
Log On/Off
Invokes the Network Login dialog which
allows you to log on to a particular profile or to
log off from the currently active profile
Yes
No
Fusion Help
Invokes the Fusion Help application which
provides detailed explanations on all the
available Fusion applications
Yes
No
5 - 4 MC45 User Guide
Fusion Setup
To setup WLAN using Fusion refer to the Wireless Fusion Enterprise Mobility Suite User Guide for Version
H3.40 for detailed information on using and configuring Fusion.
To setup WLAN using Fusion:
NOTE Obtain the proper WLAN configuration information from your system administrator prior to performing the
Fusion setup procedures.
The following setup procedure example shows setup of a WLAN using WEP encryption.
1.
Tap the Start >
appears.
2.
Tap and hold in the window and select Add from the pop-up menu. The Wireless LAN Profile Entry
window appears.
3.
In the Profile Name text box enter a name for the profile.
4.
In the ESSID text box enter the ESSID.
Figure 5-2
> Wireless Configuration Editor > Manage Profiles. The Manage Profiles window
Profile ID Dialog Box
5.
Tap Next. The Operating Mode dialog box displays.
6.
In the Operating Mode drop-down list, select Infrastructure or Ad-hoc.
Figure 5-3
Operating Mode Dialog Box
7.
Tap Next. The Security Mode dialog box displays.
8.
In the Security Mode drop-down list, select Legacy (Pre-WPA).
Using WLAN 5 - 5
Figure 5-4
9.
Security/Authentication Dialog Box
In the Authentication drop-down list, select None.
10. Tap Next. The Encryption dialog box displays.
11. In the Encryption Type drop-down list, select WEP-40 (40/24).
Figure 5-5
Encryption Dialog Box
12. Select the Pass-phrase or Hexadecimal Keys radio button to indicate whether a pass-phrase or
hexadecimal keys will be entered on the next page.
13. Select the For added security - Mask characters entered check box to hide characters entered.
Deselect this to show characters entered.
14. Tap Next.
Figure 5-6
WEP-40 WEP Keys Dialog Box
15. In the Edit Key drop-down list, select the key to enter.
16. In the Key field, enter 10 hexadecimal characters.
17. In the Confirm field, re-enter the key. When the keys match, a message appears indicating that the keys
match.
18. Repeat for each WEP key.
5 - 6 MC45 User Guide
19. In the Transmit Key drop-down list, select the key to transmit.
20. Tap Next. The IPv4 Address Entry dialog box displays.
Figure 5-7
IP Address Entry Dialog Box
21. Ensure that all three check boxes are selected.
22. Tap Next. The Battery Usage dialog box appears.
23. In the Battery Usage Mode dialog box select a power consumption option.
Figure 5-8
Battery Usage Dialog Box
24. Tap Save.
Wireless Zero Config Setup
To setup WLAN using WZC:
NOTE Obtain the proper WLAN configuration information from your system administrator prior to performing the
WZC setup procedures.
The following setup procedure example shows setup of a WLAN using WEP encryption.
1.
Tap Start >
> Wireless Launcher > Wireless Zero Config.
Using WLAN 5 - 7
Figure 5-9
Wireless Zero Config Window
2.
The MC45 searches for wireless networks in the area and displays them in the window.
3.
Tap a network name.
Figure 5-10
Configure Wireless Network Window
4.
In the Connects to drop-own list, select either The Internet or Work.
5.
Check the This is a hidden network checkbox if the network is a hidden network.
6.
Tap Next.
5 - 8 MC45 User Guide
Figure 5-11
Configure Network Authentication Window
7.
In the Authentication drop-down list, select the authentication type.
8.
In the Data Encryption drop-down list, select the data encryption type.
9.
If WEP encryption is selected, enter an encryption key in the Network key text box.
10. Tap Next.
Figure 5-12
Configure Network Authentication Window
11. If required, select Use IEEE 802.1x network access control check box.
12. In the EAP type drop-down list box, select the EAP type.
13. Tap Finish.
More Information on WZC
For more information on Microsoft Wireless Zero Config, see the Microsoft Software Developer Network
(MSDN) at http://msdn.microsoft.com.
Chapter 6 Using GPS Navigation
Introduction
The MC45 includes Global Positioning System (GPS) technology using the QC Modem Solution chipset. GPS
technology is based on a worldwide system of GPS satellites orbiting the earth that continuously transmit digital
radio signals. These radio signals contain data on the satellites’ locations and their exact clock time and are used
to determine your location on the earth.
WARNING! When using the MC45 in a vehicle, it is the user’s responsibility to place, secure and use in a
manner that will not cause accidents, personal injury or property damage or obstruct their view. It
is the responsibility of the driver to operate the vehicle in a safe manner, maintain observation of
all driving conditions at all times, and not become distracted by the device to the exclusion of safe
driving practices. It is unsafe to operate the controls of the device while driving.
Software Installation
Third-party GPS navigation software is required. Evaluation software is available from various suppliers. For
example; VisualGPS, visit: http://www.visualgps.net/VisualGPSce/
If interested in purchasing GPS navigation software check with the GPS software vendor (before purchasing,
downloading, or installing any software) to determine that the application is compatible with the MC45. Refer to the
application’s user guide for application installation and setup information.
MC45 GPS Setup
By default, the MC45 has the following settings:
1. Tap Start > Settings > System > External GPS icon.
2. In the Programs tab, the GPS program port is set to COM6.
3. In the Hardware tab, the GPS hardware port is set to None.
Multiple programs can simultaneously access GPS data. Each program must use Microsoft GPS API or COM8 to
access the GPS data.
6 - 2 MC45 User Guide
Operation
Acquiring satellite signals may take several seconds to a few minutes. It is best to be outside and have a clear,
unobstructed view of the sky. Without a clear view, acquisition takes much longer and could result in the MC45
being unable to compute the initial position quickly. When operating the device indoors access to the GPS signals
may be limited or unavailable.
NOTE When using a GPS navigation application, ensure that the MC45 does not go into suspend mode. If the MC45
suspends then the power to the GPS radio is removed. Upon resume the GPS receiver must reacquire a valid GPS
signal, resulting in a a delay of positional information.
GPS Maps on microSD Cards
GPS navigation software vendors may sell maps on microSD cards. If using a microSD card with the GPS
navigation software:
1.
Slide the mini-SIM card holder to the right to unlock.
2.
Lift the mini-SIM card holder.
3.
Slide the microSD card holder down to unlock.
4.
Lift up the microSD card holder.
5.
Insert the card with the card contacts facing down and lower the microSD card holder.
6.
Slide the microSD card holder up to lock.
7.
Lower the mini-SIM card holder.
8.
Slide the mini-SIM card holder to the left to lock.
Answering a Phone Call While Using GPS
If you receive a phone call while using your GPS navigation software:
1.
Answer the phone call by pressing the Answer button.
2.
Once you end the phone call, press the End Call button to resume the audio on the GPS software.
NOTE Anytime you are using GPS on the MC45 and you receive a phone call, the audio on the GPS navigation software
is muted until you finish the call.
Losing the GPS Signal While in a Vehicle
GPS performance on the MC45 may be affected if the vehicle has thermal glass windows and windshields, which
can block the MC45 from receiving a GPS signal from satellites. To improve GPS signal strength, place the MC45
where there is a clear view of the sky. A direct line of sight is required between the MC45 and the GPS satellites to
access information from the satellites.
Using GPS Navigation 6 - 3
Assisted GPS
GPS can be used in stand-alone or Assisted GPS (A-GPS) modes. A Stand-alone GPS receiver downloads data
from GPS satellites. It can take several minutes to get a fix. By using GPS Location servers, A-GPS dramatically
improves the performance of the Time To First Fix (TTFF) of GPS receivers by providing them with data that they
would ordinarily have to download from the GPS satellites and other aiding data that helps the acquisition. With the
A-GPS data, GPS receivers can operate faster and more reliably.
The GPS Assist application provides the ability to modify the settings associated with obtaining GPS data.
Tap Start > Connections > GPS Assist icon.
Figure 6-1
GPS Assistance Window
To set the source of the data tap Source and select one of the options: Any (default), None.
To set the frequency of updating the data tap Update Frequency and select one of the options: On Demand
(default), 1 Day, 2 Days, 4 Days, 7 Days.
To manually update the data tap the Update Now button.
GPS Reset
To perform a factory reset of the GPS function:
1.
Close all applications that are using GPS.
2.
Tap the Reset GPS Hardware button. The Reset GPS Hardware dialog box appears indicating that the GPS
chip has been reset.
3.
Tap OK.
6 - 4 MC45 User Guide
Chapter 7 Using Bluetooth
Introduction
Bluetooth-equipped devices can communicate without wires, using frequency-hopping spread spectrum (FHSS)
radio frequency (RF) to transmit and receive data in the 2.4 GHz Industry Scientific and Medical (ISM) band
(802.15.4). Bluetooth wireless technology is specifically designed for short-range (30 feet/10 meters)
communication and low power consumption.
MC45 with Bluetooth capabilities can exchange information (e.g., files, appointments, and tasks) with other
Bluetooth enabled devices such as phones, printers, access points, and other mobile computers. To use the MC45
as a modem, create a dial-up modem connection between a computer and MC45.
The MC45 with Bluetooth technology uses the Microsoft Bluetooth stack. To write an application that uses the
Microsoft Bluetooth stack APIs, refer to the Enterprise Mobility Developer Kit (EMDK) Help.
Adaptive Frequency Hopping
Adaptive Frequency Hopping (AFH) is a method of avoiding fixed frequency interferers, and can be used with
Bluetooth voice. All devices in the piconet (Bluetooth network) must be AFH-capable in order for AFH to work.
There is no AFH when connecting and discovering devices. Avoid making Bluetooth connections and discoveries
during critical 802.11b communications. AFH for Bluetooth consists of four main sections:
• Channel Classification - A method of detecting an interference on a channel-by-channel basis, or pre-defined
channel mask.
• Link Management - Coordinates and distributes the AFH information to the rest of the Bluetooth network.
• Hop Sequence Modification - Avoids interference by selectively reducing the number of hopping channels.
• Channel Maintenance - A method for periodically re-evaluating the channels.
When AFH is enabled, the Bluetooth radio “hops around” (instead of through) the 802.11b high-rate channels. AFH
coexistence allows Motorola mobile computers to operate in any infrastructure.
7 - 2 MC45 User Guide
The Bluetooth radio in this MC45 operates as a Class 2 device power class. The maximum output power is 2.5mW
and the expected range is 32.8 feet (10 meters). A definition of ranges based on power class is difficult to obtain
due to power and device differences, and whether one measures open space or closed office space.
NOTE It is not recommended to perform Bluetooth wireless technology inquiry when high rate 802.11b operation is
required.
Security
The current Bluetooth specification defines security at the link level. Application-level security is not specified. This
allows application developers to define security mechanisms tailored to their specific need. Link-level security
occurs between devices, not users, while application-level security can be implemented on a per-user basis. The
Bluetooth specification defines security algorithms and procedures needed to authenticate devices, and if needed,
encrypt the data flowing on the link between the devices. Device authentication is a mandatory feature of Bluetooth
while link encryption is optional.
Pairing of Bluetooth devices is accomplished by creating an initialization key that is used to authenticate the
devices and create a link key for them. Entering a common PIN number in the devices being paired generates the
initialization key. The PIN number is never sent over the air. By default, the Bluetooth stack responds with no key
when a key is requested (it is up to user to respond to the key request event). Authentication of Bluetooth devices
is based-upon a challenge-response transaction. Bluetooth allows for a PIN number or passkey that is used to
create other 128-bit keys used for security and encryption. The encryption key is derived from the link key used to
authenticate the pairing devices. Also worthy of note is the limited range and fast frequency hopping of the
Bluetooth radios that makes long-distance eavesdropping difficult.
Recommendations are:
• Perform pairing in a secure environment
• Keep PIN codes private and don't store the PIN codes in the mobile computer
• Implement application-level security.
The Microsoft stack supports Smart-pairing. For detailed information, refer to the Microsoft MSDN.
Using Bluetooth 7 - 3
Bluetooth Configuration
The following services are supported
• A2DP/AVRCP Services
• Dial-Up Networking Services
• File Transfer profile
• General Audio/Video Distribution Profile
• Generic Access Profile
• Generic Object Exchange Profile
• Hands-Free Audio Gateway Services
• Headset Profile
• HID Client Services
• PBAP Services
• Personal Area Networking Services
• Serial Port Services
• Service Discovery Access profile
• SIM Access Profile.
COM2 through COM4 and COM8 are available unless being used by another service.
Bluetooth Power States
Suspend
When there is an active Bluetooth connection, the Bluetooth radio goes into low power mode maintaining the active
connection. When there is no active connection, the Bluetooth radio turns off.
NOTE If there is an active Bluetooth connection between the MC45 and another Bluetooth device and there is no
data activity, the MC45 will timeout. However, if the user presses the Power button on the MC45, the MC45
will suspend (except when on a call) and upon receiving data from a remote Bluetooth device, the MC45 will
wake from suspend mode. For example, headset redial or Bluetooth scanner sending data to the MC45.
Resume
When the MC45 resumes, Bluetooth turns on if it was on prior to suspend.
7 - 4 MC45 User Guide
Turning Bluetooth On and Off
Turn off the Bluetooth radio to save power or if entering an area with radio restrictions (e.g., an airplane). When the
radio is off, other Bluetooth devices cannot see or connect to the MC45. Turn on the Bluetooth radio to exchange
information with other Bluetooth devices (within range). Communicate only with Bluetooth radios in close proximity.
NOTE To achieve the best battery life turn off radios not in use.
Enabling Bluetooth
To enable Bluetooth:
1.
Tap Wireless Manager and then tap the Bluetooth bar or
Tap Start > Settings > Connections > Wireless Manager > Bluetooth bar.
Figure 7-1
2.
Wireless Manager Window
Tap on the Bluetooth bar to turn on Bluetooth.
Using Bluetooth 7 - 5
Disabling Bluetooth
To disable Bluetooth:
1.
Tap Wireless Manager and then tap the Bluetooth bar or
Tap Start > Settings > Connections > Wireless Manager > Bluetooth bar.
2.
Tap on the Bluetooth bar to turn off Bluetooth.
Discovering Bluetooth Device(s)
The MC45 can receive information from discovered devices without bonding. However, once bonded, the MC45
and a bonded device exchange information automatically when you turn the Bluetooth radio on. To find Bluetooth
devices in the area:
1.
Ensure that Bluetooth is enabled on both devices.
2.
Ensure that the Bluetooth device to discover is in discoverable and connectable modes.
3.
Ensure that the two devices are within 30 feet (10 meters) of one another.
4.
Tap Start > Settings > Connections > Wireless Manager >Menu > Bluetooth Settings > Devices.
Figure 7-2
5.
Bluetooth - Devices Tab
Tap Add new device. The MC45 begins searching for discoverable Bluetooth devices in the area.
7 - 6 MC45 User Guide
Figure 7-3
6.
Select a device from the list.
Figure 7-4
7.
Searching for Bluetooth Devices
Select a Bluetooth Device
Tap Next. The Enter Passcode window appears.
NOTE If Smart-pairing is configured and the device is requesting one of the pre-defined PINs, the Enter
Passcode window does not appear.
Using Bluetooth 7 - 7
Figure 7-5
8.
Enter Passcode
Enter the Passcode on the other device. The device is added to the Bluetooth list.
Figure 7-6
Bluetooth Connection Confirmation
You are prompted to enter a passcode. If the device has a specific passcode, enter it in the Passcode field and
tap Next. If the device does not have a specific passcode, enter a passcode in the Passcode field and tap
Next. The Bluetooth radio tries to connect with the device.
9.
If you created a passcode, you will be prompted by the other device to enter the same passcode. Enter the
created passcode to establish a paired connection. (If you entered a passcode from the device, you shouldn’t
have to do anything on the other device.)
10. When the connection is complete, a list of matching and supported services on the device appears.
11. Select the services you want to use and tap Finish. The services on the new devices have to be selected or
else the pairing won’t include those services, even though the devices are paired. If services are not selected,
you will be continually reprompted for the passcode from the device.
12. The device appears in the list on the main window.
After the passcodes have been accepted on both sides, you have a trusted (“paired”) connection.
7 - 8 MC45 User Guide
Available Services
NOTE Some devices might not require a PIN. This depends upon the device’s authentication.
See the following sections for information on available services.
Object Push Services via Beam
NOTE You can only send files to a remote device using the Beam function.
Use the OBEX Push Service to send files and contacts to another Bluetooth device. To transfer files between the
MC45 and another Bluetooth enabled device:
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
Tap Start > File Explorer.
4.
Navigate to the file to transfer.
5.
Tap and hold on the filename until the pop-up menu appears.
Figure 7-7
File Explorer Window
6.
Select Beam File. The MC45 searches for Bluetooth devices in the area.
7.
Tap Tap to send next to the Bluetooth device to send the file to. The MC45 communicates with the device and
send the file. When completed, Tap to send changes to Done.
Using Bluetooth 7 - 9
Figure 7-8
Beam File Window
To transfer a contact between the MC45 and another Bluetooth enabled device:
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
Tap Start > Contacts
4.
Navigate to the contact to transfer.
5.
Tap and hold on the contact until the pop-up menu appears.
Figure 7-9
Contact Window
6.
Select Send Contact > Beam. The MC45 searches for Bluetooth devices in the area.
7.
Tap Tap to send next to the Bluetooth device to send the file to. The MC45 communicates with the device and
send the contact. When completed, Tap to send changes to Done.
Internet Sharing
Internet Sharing allows the user to connect a computer or laptop to the MC45 and use the MC45 as a modem to
connect to an office network or ISP.
To use MC45 as a modem using Bluetooth:
7 - 10 MC45 User Guide
1.
Ensure that the device is not connected to the computer or laptop.
2.
On the MC45, ensure that the Phone is on and a data connection is configured.
3.
Tap Start > Internet Sharing.
4.
In the PC Connection list, select Bluetooth PAN.
5.
In the Network Connection list, select the connection type.
Select the network connection that the device should use to connect to the Internet.
6.
Tap Connect.
7.
On the computer or laptop, setup a Bluetooth PAN with your device.
a.
Select Start > Control Panel > Network Connections.
b.
Under Personal Area Network, select Bluetooth Network Connection.
c.
Right-click on Bluetooth Network Connection and select View Bluetooth network devices.
d.
In the Bluetooth Personal Area Network Devices window select your device.
e.
Click Connect. The computer connects to the device via Bluetooth.
NOTE If your computer is Bluetooth-enabled and you select Bluetooth as the PC connection, you must initiate and
complete the Bluetooth PAN partnership before Internet Sharing will work. For more information, refer to
Windows Help and Support.
8.
To verify, on the PC or laptop, launch Internet Explorer and open a web site.
9.
To end dial-up networking, on the MC45 tap Disconnect.
Hands-free Services
To connect to a Bluetooth headset:
NOTE Newer Bluetooth headsets are device dependant and remember the last device they connected to. If problems
occur while connecting to the headset, place the headset in discovery mode. Refer to the headset user manual
for more information.
Only WAN audio is routed to the headset. System audio is still emitted through the MC45 speaker.
You can accept calls and re-dial using the Hands-free profile.
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
Tap Start > Settings > Connections > Wireless Manager >Menu > Bluetooth Settings > Devices.
4.
Tap New device. The MC45 searches for Bluetooth devices in the area.
5.
Select the headset name and tap Next. The Passcode window appears.
6.
Enter the headset’s passcode.
7.
Tap Next. The MC45 connects to the headset. Refer to the headset user manual for instructions on
communicating with a Bluetooth device.
Using Bluetooth 7 - 11
Serial Port Services
Use the wireless Bluetooth serial port connection as you would a physical serial cable connection. Configure the
application that will use the connection to the correct serial port.
To establish a serial port connection:
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
Tap Start > Settings > Bluetooth > Devices.
4.
Tap Add new device. The MC45 begins searching for discoverable Bluetooth devices in the area.
5.
Select a device from the list.
6.
Tap Next. The Enter Passcode window appears.
7.
Enter the Passcode and the tap Next. The device is added to the Bluetooth list.
8.
In the device list, tap the serial device. The Partnership Settings window displays.
9.
Select the Serial Port checkbox.
10. Tap Save.
11. Tap COM Ports tab.
12. Tap New Outgoing Port. The add device window appears.
13. Select the serial device in the list and then tap Next.
14. Select a COM port from the drop-down list.
15. Tap Finish.
NOTE No connection is made at this point. An application must open the selected COM port to trigger Microsoft
Bluetooth stack to open the connection.
ActiveSync Using Serial Port Services
Use the wireless Bluetooth serial port connection for ActiveSync just as you would a physical serial cable
connection. You must configure the application that will use the connection to the correct serial port.
To set up a Bluetooth ActiveSync connection:
Before setting up a Bluetooth ActiveSync connection, configure the Bluetooth function of your device.
NOTE For additional security, disable network bridging on the computer (specifically, bridging to a Remote NDIS
adapter) before connecting to the computer to pass though to the Internet or a network. For more information
on network bridging, see Windows Help on your computer.
The instructions below are for computers that support the Windows XP SP2 or later version operating system.
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
On the computer, click Start > Settings > Control Panel.
7 - 12 MC45 User Guide
4.
Double-click Bluetooth Devices.
5.
On the Options tab, select the Turn discovery on and Allow Bluetooth devices to connect to this
computer checkboxes.
Figure 7-10
Computer Bluetooth Devices Window
6.
On the COM Ports tab, click Add.
7.
Select the Incoming (device initiates the connection) option, then click OK.
Note the number of the COM port that was added.
8.
Click OK.
9.
Click Start > All Programs > Microsoft ActiveSync.
10. Click File > Connection Settings.
Figure 7-11
ActiveSync Connection Settings
11. On the Allow connections to one of the following drop-down list, select the COM port with the number you
noted earlier.
12. On the MC45, tap Start > ActiveSync.
Using Bluetooth 7 - 13
13. Tap Menu > Connect via Bluetooth.
Synchronization is automatically initiated. The ActiveSync icon appears on the lower right corner of the Today
screen.
If an Authentication is required, the Enter Passcode screen appears, type an alphanumeric passkey (PIN
code), then tap Next; enter the same passkey on the other device.
The passkey is recommended for enhanced security. Your passkey must be between 1 to 16 alphanumeric
characters.
If you do not want to use a passkey, tap Next.
14. To disconnect the ActiveSync connection, tap My Apps > Active Sync.
15. Tap Disconnect.
Phone Book Access Profile Services
Phone Book Access profile (PBAP) is used to synchronize contacts between a remote device and the MC45. To
establish an PBAP synchronization:
1.
Ensure that Bluetooth is enabled and discoverable on both devices.
2.
Ensure that the two devices are within 30 feet (10 meters) of one another.
3.
Tap Start > Settings > Bluetooth > Devices.
4.
Tap Add New Device.The MC45 searches for a Bluetooth device, such as a Car Kit.
5.
Select a device from the list.
6.
Tap Next. The Enter Passcode window appears.
7.
Enter the Passcode and the tap Next. The device is added to the Bluetooth list.
8.
A dialog box appears requesting if you want to transfer contacts to the car kit.
9.
Select Yes or No.
10. If Yes is selected, contacts from the MC45 are transferred to the car kit.
Dial-Up Networking Services
Dial-up networking allows the user to connect a PC or laptop to the MC45 and use the MC45 as a modem to
connect to an office network or ISP.
Before setting up dial-up networking, obtain dial-up information and other necessary settings (username, password
and domain name, if required) for the office network or ISP. To create a new Bluetooth connection:
1.
Ensure the MC45 is discoverable and connectable.
2.
On the PC or laptop, set up Bluetooth according to the manufacturer’s instructions.
3.
On the PC or laptop Bluetooth software, search for the MC45 and select the Dial-up Networking service.
4.
Using dial-up software on the PC or laptop, connect to the MC45.
5.
The MC45 phone function dials the ISP number and connects to the ISP.
6.
To verify, on the PC or laptop, launch Internet Explorer and open a web site.
7 - 14 MC45 User Guide
Connect to a HID Device
The MC45 can connect to an Human Interface Device (HID) device such as a Bluetooth keyboard or mouse:
1.
Ensure that Bluetooth is enabled on both devices.
2.
Ensure that the Bluetooth device to discover is in discoverable and connectable modes.
3.
Ensure that the two devices are within 30 feet (10 meters) of one another.
4.
Tap Start > Settings > Bluetooth > Devices.
5.
Tap Add new device. The MC45 begins searching for discoverable Bluetooth devices in the area.
6.
Select a HID device from the list.
7.
Tap Next. The Enter Passcode window appears. Refer to the device’s User Manuals for more information.
8.
Tap Connect. The MC45 connects to the HID device.
A2DP/AVRCP Services
A2DP/AVRCP is used to connect to a high-quality stereo headset:
1.
Ensure that Bluetooth is enabled on both devices.
2.
Ensure that the Bluetooth device to discover is in discoverable and connectable modes.
3.
Ensure that the two devices are within 30 feet (10 meters) of one another.
4.
Tap Start > Settings > Bluetooth > Devices.
5.
Tap Add new device. The MC45 begins searching for discoverable Bluetooth devices in the area.
6.
Select a stereo headset from the list.
7.
Tap Next. The Enter Passcode window appears. Refer to the device’s User Manuals for more information.
8.
Tap Connect. The MC45 connects to the stereo headset.
For stereo headsets that can use hands-free services, connect to the hands-free service after connecting to the
A2DP service:
1.
Tap Start > Settings > Bluetooth > Devices.
2.
Tap Add new device. The MC45 begins searching for discoverable Bluetooth devices in the area.
3.
Select a stereo headset from the list.
4.
Tap Next. The Enter Passcode window appears. Refer to the device’s User Manuals for more information.
NOTE If Smart-pairing is configured and the device is requesting one of the pre-defined PINs, the Enter
Passcode window does not appear.
5.
Tap Connect. The MC45 connects to the stereo headset.
Chapter 9 Maintenance &
Troubleshooting
Introduction
This chapter includes instructions on cleaning and storing the MC45, and provides troubleshooting solutions for
potential problems during MC45 operation.
Maintaining the MC45
For trouble-free service, observe the following tips when using the MC45:
• Do not scratch the screen of the MC45. When working with the MC45, use the supplied stylus or
plastic-tipped pens intended for use with a touch-sensitive screen. Never use an actual pen or pencil or other
sharp object on the surface of the MC45 screen.
• A screen protector, p/n KT-MC45-SCRNP-10R, is applied to the MC45. Motorola recommends using this to
minimize wear and tear. Screen protectors enhance the usability and durability of touch screen displays.
Benefits include:
• Protection from scratches and gouges
• Durable writing and touch surface with tactile feel
• Abrasion and chemical resistance
• Glare reduction
• Keeping the device’s screen looking new
• Quick and easy installation.
• The touch-sensitive screen of the MC45 is polycarbonate. Do not to drop the MC45 or subject it to strong
impact.
• Protect the MC45 from temperature extremes. Do not leave it on the dashboard of a car on a hot day, and
keep it away from heat sources.
• Do not store or use the MC45 in any location that is dusty, damp, or wet.
• Use a soft lens cloth to clean the MC45. If the surface of the MC45 screen becomes soiled, clean it with a soft
cloth moistened with a diluted window-cleaning solution.
9 - 2 MC45 User Guide
• Periodically replace the rechargeable battery to ensure maximum battery life and product performance.
Battery life depends on individual usage patterns.
Removing the Screen Protector
A screen protector is applied to the MC45. Motorola recommends using this to minimize wear and tear. Screen
protectors enhance the usability and durability of touch screen displays.
To remove the screen protector, lift the corner using a thin plastic card, such as a credit card, then carefully lift it off
the display.
Lift Screen
Protector
Corner
Figure 9-1
Removing the Screen Protector
CAUTION Do not use a sharp object to remove the protector. Doing so can damage the display.
NOTE Not using a screen protector can affect warranty coverage. To purchase replacement protectors, contact your
local account manager or Motorola, Inc. These include screen protector installation instructions. Part number:
KT-MC45-SCRNP-10R Screen Protector 10/pk.
Maintenance & Troubleshooting 9 - 3
Battery Safety Guidelines
• The area in which the units are charged should be clear of debris and combustible materials or chemicals.
Particular care should be taken where the device is charged in a non commercial environment.
• Follow battery usage, storage, and charging guidelines found in the user's guide.
• Improper battery use may result in a fire, explosion, or other hazard.
• To charge the mobile device battery, the battery and charger temperatures must be between +32 ºF and
+104 ºF (0 ºC and +40 ºC)
• Do not use incompatible batteries and chargers. Use of an incompatible battery or charger may present a risk
•
•
•
•
•
•
•
•
•
•
•
•
•
of fire, explosion, leakage, or other hazard. If you have any questions about the compatibility of a battery or a
charger, contact Motorola Solutions Global Customer Support.
For devices that utilize a USB port as a charging source, the device shall only be connected to products that
bear the USB-IF logo or have completed the USB-IF compliance program.
To enable authentication of an approved battery, as required by IEEE1725 clause 10.2.1, all batteries will
carry a Motorola hologram. Do not fit any battery without checking it has the Motorola authentication
hologram.
Do not disassemble or open, crush, bend or deform, puncture, or shred.
Severe impact from dropping any battery-operated device on a hard surface could cause the battery to
overheat.
Do not short circuit a battery or allow metallic or conductive objects to contact the battery terminals.
Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water
or other liquids, or expose to fire, explosion, or other hazard.
Do not leave or store the equipment in or near areas that might get very hot, such as in a parked vehicle or
near a radiator or other heat source. Do not place battery into a microwave oven or dryer.
Battery usage by children should be supervised.
Please follow local regulations to promptly dispose of used
re-chargeable batteries.
Do not dispose of batteries in fire.
Seek medical advice immediately if a battery has been swallowed.
In the event of a battery leak, do not allow the liquid to come in contact with the skin or eyes. If contact has
been made, wash the affected area with large amounts of water and seek medical advice.
If you suspect damage to your equipment or battery, contact Motorola Solutions Global Customer Support to
arrange for inspection.
Cleaning
WARNING! Avoid exposing this product to contact with hot oil or other flammable liquids. If such exposure
occurs, unplug the device and clean the product immediately in accordance with these guidelines.
CAUTION Always wear eye protection.
Read warning label on compressed air and alcohol product before using.
If you have to use any other solution for medical reasons please contact Motorola for more information.
Materials Required
• Alcohol wipes
9 - 4 MC45 User Guide
• Lens tissue
• Cotton tipped applicators
• Isopropyl alcohol
• Can of compressed air with a tube.
Cleaning the MC45
Housing
Using the alcohol wipes, wipe the housing including keys and in-between keys.
Display
The display can be wiped down with the alcohol wipes, but care should be taken not to allow any pooling of liquid
around the edges of the display. Immediately dried the display with a soft, non-abrasive cloth to prevent streaking.
Scanner Exit Window
Wipe the scanner exit window periodically with a lens tissue or other material suitable for cleaning optical material
such as eyeglasses.
Connector
1.
Remove the main battery from mobile computer. See Replacing the Battery on page 1-8.
2.
Close battery door.
3.
Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
4.
Rub the cotton portion of the cotton tipped applicator back-and-forth across the connector on the bottom of the
MC45. Do not leave any cotton residue on the connector.
5.
Repeat at least three times.
6.
Use the cotton tipped applicator dipped in alcohol to remove any grease and dirt near the connector area.
7.
Use a dry cotton tipped applicator and repeat steps 4 through 6.
CAUTION Do not point nozzle at yourself and others, ensure the nozzle or tube is away from your face.
8.
Spray compressed air on the connector area by pointing the tube/nozzle about ½ inch away from the surface.
9.
Inspect the area for any grease or dirt, repeat if required.
Cleaning Cradle Connectors
To clean the connectors on a cradle:
1.
Remove the DC power cable from the cradle.
2.
Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
Maintenance & Troubleshooting 9 - 5
3.
Rub the cotton portion of the cotton tipped applicator along the pins of the connector. Slowly move the
applicator back-and-forth from one side of the connector to the other. Do not let any cotton residue on the
connector.
4.
All sides of the connector should also be rubbed with the cotton tipped applicator.
CAUTION Do not point nozzle at yourself and others, ensure the nozzle or tube is away from your face.
5.
Spray compressed air in the connector area by pointing the tube/nozzle about ½ inch away from the surface.
6.
Ensure that there is no lint left by the cotton tipped applicator, remove lint if found.
7.
If grease and other dirt can be found on other areas of the cradle, use lint free cloth and alcohol to remove.
8.
Allow at least 10 to 30 minutes (depending on ambient temperature and humidity) for the alcohol to air dry
before applying power to cradle.
If the temperature is low and humidity is high, longer drying time is required. Warm temperature and dry
humidity requires less drying time.
Cleaning Frequency
The cleaning frequency is up to the customer’s discretion due to the varied environments in which the mobile
devices are used. They may be cleaned as frequently as required. However when used in dirty environments it
may be advisable to periodically clean the scanner exit window to ensure optimum scanning performance.
Troubleshooting
MC45
Table 9-1
Troubleshooting the MC45
Problem
MC45 does not turn
on.
Rechargeable battery
did not charge.
Cause
Solution
Battery not charged.
Charge or replace the battery.
Battery not installed
properly.
Install the battery properly. See Installing the Battery on page 1-5.
System crash.
Perform a warm boot. If the MC45 still does not turn on, perform a
cold boot. See Resetting the MC45 on page 2-17.
Battery failed.
Replace battery. If the MC45 still does not operate, perform a warm
boot, then a cold boot. See Resetting the MC45 on page 2-17.
MC45 removed
from cradle while
battery was
charging.
Insert MC45 in cradle and allow to charge.
Extreme battery
temperature.
Battery does not charge if ambient temperature is below 0°C (32°F)
or above 40°C (104°F).
9 - 6 MC45 User Guide
Table 9-1
Troubleshooting the MC45 (Continued)
Problem
Cause
Cannot see characters
on display.
MC45 not powered
on.
Press the red Power button.
During data
communication, no
data transmitted, or
transmitted data was
incomplete.
MC45 removed
from cradle or
disconnected from
host computer
during
communication.
Replace the MC45 in the cradle, or reattach the communication
cable and re-transmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software was
incorrectly installed
or configured.
Perform setup. Refer to the MC45 Integrator Guide for details.
No sound.
Volume setting is
low or turned off.
Adjust the volume. See Adjusting Volume on page 2-14.
MC45 shuts off.
MC45 is inactive.
The MC45 turns off after a period of inactivity. If the MC45 is
running on battery power, set this period from 1 to 5 minutes, in
one-minute intervals. If the MC45 is running on external power, set
this period to 1, 2, 5, 10, 15, or 30 minutes.
Check the Power window by selecting Start > Settings > Power
icon. Select the Advanced tab and change the setting for a longer
delay before the automatic shutoff feature activates.
Battery is depleted.
Recharge or replace the battery.
Battery is not
inserted properly.
Insert the battery properly. See Installing the Battery on page 1-5.
Screen is not
calibrated correctly.
Re-calibrate the screen. See Calibrating the Screen on page 1-8.
The system is not
responding.
Warm boot the system. See Resetting the MC45 on page 2-17.
Too many files
stored on the MC45.
Delete unused memos and records. If necessary, save these
records on the host computer (or use a microSD card for additional
memory).
Too many
applications
installed on the
MC45.
Remove user-installed applications on the MC45 to recover
memory. Select Start > Settings > System and tap the Remove
Programs icon. Select the unused program and tap Remove.
The MC45’s battery
is low.
Recharge or replace the battery. Configure the MC45 to conserve
power. Refer to Battery Management on page 1-10 for more
information.
Tapping the window
buttons or icons does
not activate the
corresponding feature.
A message appears
stating that the MC45
memory is full.
MC45 keeps powering
down to protect
memory contents.
Solution
Maintenance & Troubleshooting 9 - 7
Table 9-1
Troubleshooting the MC45 (Continued)
Problem
The MC45 does not
accept data capture
input.
Cause
Solution
Scanning
application is not
loaded.
Load a scanning application on the MC45. See the system
administrator.
Unreadable bar
code.
Ensure the symbol is not defaced.
Distance between
exit window and bar
code is incorrect.
Place the MC45 within proper scanning range.
MC45 is not
programmed for the
bar code.
Program the MC45 to accept the type of bar code being scanned.
MC45 is not
programmed to
generate a beep.
If the MC45 does not beep on a good decode, set the application to
generate a beep on good decode.
Battery is low.
If the scanner stops emitting a laser beam upon a trigger press,
check the battery level. When the battery is low, the scanner shuts
off before the MC45 low battery condition notification. Note: If the
scanner is still not reading symbols, contact the distributor or
Motorola.
Phone service is not
available with SIM
card installed.
SIM card might not
be installed
properly.
Re-install SIM card and ensure that it is seated properly. See
Installing the mini-SIM Card on page 1-4.
Error message “SIM
Error. Cannot save
info to SIM” appears
when copying contacts
to a SIM card.
Feature not
supported on some
SIM cards.
If error appears while creating a new contact, add at least one
number (e.g. 0) to the Work Phone field.
If error appears while copying one contact, reboot the MC45. The
contact appears on the SIM card after rebooting.
If error appears while copying multiple contacts, copy one contact at
a time and follow the above solution.
Use Microsoft Outlook Exchange and ActiveSync to synchronize
contacts with Microsoft Outlook on host computer.
MC45 cannot find any
Bluetooth devices
nearby.
Too far from other
Bluetooth devices.
Move closer to the other Bluetooth device(s), within a range of 10
meters.
The Bluetooth
device(s) nearby
are not turned on.
Turn on the Bluetooth device(s).
The Bluetooth
device(s) are not in
discoverable mode.
Set the Bluetooth device(s) to discoverable mode. If needed, refer
to the device’s user documentation for help.
9 - 8 MC45 User Guide
Single Slot Charge Cradle
Table 9-2
Troubleshooting the Single Slot Charge Cradle
Symptom
Possible
Cause
Action
LEDs do not light
when MC45 is
inserted.
Cradle is not
receiving power.
Ensure the power cable is connected securely to both the cradle
and to AC power.
MC45 is not seated
firmly in the cradle.
Remove and re-insert the MC45 into the cradle, ensuring it is firmly
seated.
MC45 battery is not
charging.
MC45 was removed
from cradle or
cradle was
unplugged from AC
power too soon.
Ensure cradle is receiving power. Ensure MC45 is seated correctly.
Confirm battery is charging under Start > Settings > Power.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the faulty
battery.
The MC45 is not
fully seated in the
cradle.
Remove and re-insert the MC45 into the cradle, ensuring it is firmly
seated.
Ambient
temperature of the
cradle is too warm.
Move the cradle to an area where the ambient temperature is
between 0°C (32°F) and 35°C (95°F).
Extreme battery
temperature.
Battery does not charge if ambient temperature is below 0°C (32°F)
or above 40°C (104°F).
MC45 removed
from cradle during
communications.
Replace MC45 in cradle and retransmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software is not
installed or
configured properly.
Perform setup as described in the MC45 Integrator Guide.
During data
communication, no
data transmits, or
transmitted data was
incomplete.
Maintenance & Troubleshooting 9 - 9
Multi Slot Universal Charge Only Cradle
Table 9-3
Troubleshooting the Multi Slot Universal Charge Only Cradle
Symptom
Possible
Cause
Action
LEDs do not light
when MC45 is
inserted.
Cradle is not
receiving power.
Ensure the power cable is connected securely to both the cradle
and to AC power.
MC45 is not seated
firmly in the cradle.
Remove and re-insert the MC45 into the cradle, ensuring it is firmly
seated.
MC45 battery is not
charging.
MC45 was removed
from cradle or
cradle was
unplugged from AC
power too soon.
Ensure cradle is receiving power. Ensure MC45 is seated correctly.
Confirm battery is charging under Start > Settings > Power.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the faulty
battery.
The MC45 is not
fully seated in the
cradle.
Remove and re-insert the MC45 into the cradle, ensuring it is firmly
seated.
Ambient
temperature of the
cradle is too warm.
Move the cradle to an area where the ambient temperature is
between 0°C (32°F) and 35°C (95°F).
Extreme battery
temperature.
Battery does not charge if ambient temperature is below 0°C (32°F)
or above 40°C (104°F).
Vehicle Charge Cradle
Table 9-4
Troubleshooting the Vehicle Charge Cradle
Symptom
Possible
Cause
Action
LEDs do not light up
when MC45 is inserted
Cradle is not
receiving power.
Ensure the power input cable is securely connected to the cradle’s
power port.
MC45 battery is not
charging.
MC45 was removed
from the cradle too
soon.
Replace the MC45 in the cradle.
Battery is faulty.
Replace the battery.
9 - 10 MC45 User Guide
Table 9-4
Troubleshooting the Vehicle Charge Cradle (Continued)
Symptom
Possible
Cause
Action
MC45 is not placed
correctly in the
cradle.
Remove the MC45 from the cradle, and re-insert correctly. If the
battery still does not charge, contact customer support.
The MC45 battery charging LED slowly blinks amber when the
MC45 is correctly inserted and charging.
Ambient
temperature of the
cradle is too warm.
Move the cradle to an area where the ambient temperature is
between 0°C (32°F) and 35°C (95°F).
MC45 removed
from cradle during
communication.
Replace MC45 in cradle and retransmit.
Four Slot Battery Charger
r
Table 9-5
Troubleshooting the Four Slot Battery Charger
Symptom
Possible
Cause
Action
LEDs do not light
when MC45 is
inserted.
Charger is not
receiving power.
Ensure the power cable is connected securely to both the charger
and to AC power.
MC45 battery is not
seated firmly in the
charger.
Remove and re-insert the MC45 battery into the charging well,
ensuring it is firmly seated.
MC45 battery is not
charging.
Battery was
removed from the
charger or charger
was unplugged from
AC power too soon.
Re-insert the battery in the charger or re-connect the charger’s
power supply.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the faulty
battery.
Battery contacts not
connected to
charger.
Verify that the battery is seated in the charging well correctly with
the contacts facing down.
Ambient
temperature of the
cradle is too warm.
Move the charger to an area where the ambient temperature is
between 0°C (32°F) and 35°C (95°F).
Maintenance & Troubleshooting 9 - 11
Cables
Table 9-6
Troubleshooting the Cables
Symptom
MC45 battery is not
charging.
During data
communication, no
data transmits, or
transmitted data was
incomplete.
Possible
Cause
Action
MC45 was
disconnected from
AC power too soon.
Connect the power cable correctly. Confirm main battery is charging
under Start > Settings > Power.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the faulty
battery.
The MC45 is not
fully attached to
power.
Detach and re-attach the power cable to the MC45, ensuring it is
firmly connected.
Cable was
disconnected from
MC45 during
communications.
Re-attach the cable and retransmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software is not
installed or
configured properly.
Perform setup as described in the MC45 Integrator Guide.
9 - 12 MC45 User Guide
Chapter 8 Accessories
Introduction
MC45 accessories, listed below, provide a variety of product support capabilities.
Table 8-1
MC45 Accessories
Accessory
Part Number
Description
Cradles
Single Slot Charge Cradle
CRDMC45-1000CR
Charges the MC45 device.
Multi Slot Universal
Charge Only Cradle
CRDUNIV-XX-5000R
Charges five MC45 devices simultaneously or four MC45
devices when configured with a Four Slot Battery Charger.
Charger Cups and Power Supplies sold separately.
Multi Slot Universal
Charge Only Cradle with
five MC45 cups installed
CRDUNIV-45-5000R
Charges five MC45 devices simultaneously or four MC45
devices when configured with a Four Slot Battery Charger.
Includes 5 Charger Cups. Power Supply sold separately.
Vehicle Charge Cradle
VCD45XX-1000R
Installs in a vehicle and charges the MC45 battery.
SAC45XX-4000CR
Charges four MC45 batteries simultaneously.
Auto Charge Cable
VCA400-01R
Charges the MC45 using a vehicle’s cigarette lighter.
DEX Cable
25-45793-01R
For use with electronic data exchange. For example,
connecting MC45 to a vending machine.
USB Rapid Charge Cable
25-128458-01R
Charges the MC45 and provides USB communication with
a host computer.
PWRS-124306-01R
Provides power to the MC45 or Single Slot Charge Cradle
using the USB Rapid Charge Cable.
Chargers
Four Slot Battery Charger
Cables
Miscellaneous
Power Supply
8 - 2 MC45 User Guide
Table 8-1
MC45 Accessories (Continued)
Accessory
Part Number
Description
Power Supply
PWRS-14000-148C
Provides power to the Multi Slot Universal Charge Only
Cradle or the Four Slot Battery Charger.
Spare 3080 mAh
lithium-ion battery
BTRY-MCXX-3080-01R
Replacement 3080 mAh battery.
BTRY-MCXX-3080-10R
Package of 10 replacement 3080 mAh batteries
BTRY-MCBR-3080-01R
Replacement 3080 mAh battery for Brazil only.
MC45 Battery Door
KT-MC45-BTRYD-01R
Replacement battery door.
Mount Bracket
KT-UNIVLBRKT-01R
Mount bracket for rack or wall mounting of the Multi Slot
Universal Charge Only Cradle.
Charger Cup
CUPMC45XX-1000R
Charger cup for the Multi Slot Universal Charge Only
Cradle.
Blank Slot Cover
CUPUNICVR-5000R
Package of 5 blank slot covers for the Multi Slot Universal
Charge Only Cradle charge slot.
Four Slot Battery Charger
Cup Adapter
CUPUNIBTRY-1000R
Mounts the Four Slot Battery Charger onto the Multi Slot
Universal Charge Only Cradle.
Handstrap
SG-MC45-STRAP-01R
Single pivot handstrap.
Soft Holster
SG-MC45-HLSTR-01R
Soft case holder for added protection.
Stylus with Tether Kit
KT-MC45-STYTH-10R
Replacement Stylus and Tether (10-pack)
micro USB adapter
ADP45XX-100R
Rugged micro USB adapter that connects to the MC45
micro USB port.
Screen Protector
KT-MC45-SCRNP-10R
Package of 10 screen protectors.
Accessories
8-3
USB Rapid Charge Cable
Use the USB Rapid Charge cable to connect the MC45 to the power supply for charging or to a host computer for
communication.
Figure 8-1
USB Rapid Charge Cable
Communication with Host Computer
To communicate with a host computer:
1.
Ensure ActiveSync is installed and configured on the host computer. See ActiveSync on page 8-13 for more
information.
2.
Connect USB Rapid Charge cable to the micro USB port on the side of the MC45.
3.
Connect the USB connector of the USB Rapid Charge Cable to the USB Port on the host computer .
4.
The USB Connect dialog box appears.
5.
Tap ActiveSync RNDIS or ActiveSync Serial.
6.
Tap Connect.
8 - 4 MC45 User Guide
Single Slot Charge Cradle
Charging the MC45 Battery
To charge the MC45 battery:
Figure 8-2
1.
Charging the MC45 Using the Single Slot Charge Cradle
Place the MC45 into the cradle.
The MC45’s LED indicates the status of the battery charging in the MC45. See Table 1-1 on page 1-7 for charging
status indications. The 3080mAh battery fully charges in less than six hours at room temperature of approximately
25 °C (77°F). Charging time may vary at different temperatures.
Accessories
8-5
Multi Slot Universal Charge Only Cradle
NOTE The Multi Slot Universal Charge Only Cradle charges five MC45 devices simultaneously or four MC45 devices
when configured with a Four Slot Battery Charger.
To charge the MC45 batteries:
1.
Place the MC45 into the cradle.
Figure 8-3
Multi Slot Universal Charge Only Cradle
NOTE The Four Slot Battery Charger can be attached to the Multi Slot Universal Charge Only Cradle using a Battery
Charger Cup Adapter. The cup adapter angles the Battery Charger so that the user can see the LED
indicators easily.
The Four Slot Battery Charger requires a separate power supply. See Four Slot Battery Charger on page 8-10
for more information
The MC45’s LED indicates the status of the battery charging in the MC45. See Table 1-1 on page 1-7 for charging
status indications. The 3080mAh battery fully charges in less than six hours at room temperature of approximately
25 °C (77°F). Charging time may vary at different temperatures.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC45.
To accomplish this, for small periods of time, the MC45 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC45 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-1 on page 1-7.
8 - 6 MC45 User Guide
Vehicle Charge Cradle
WARNING! Some countries prohibit the mounting of any electronic device in any location on the vehicle
dashboard. Be sure to check with local laws acceptable mounting areas before installing the
auto mounting kit.
Install the vehicle mount on the surface of the vehicle that is reasonably flat and free of dirt and oil. Clean the
mounting surface with a glass cleaner and a clean cotton cloth. Install the vehicle mount on the windshield or other
flat car surface using the supplied mounting disc.
Windshield Installation
1.
Fix the suction cup mount to the selected area with the suction lever facing up.
Figure 8-4
2.
Install on Windshield
Flip the lever down to create a vacuum between the suction cup and the mounting surface.
Accessories
Figure 8-5
3.
Move lever Toward Windshield
Make sure that the suction bond is strong enough before proceeding to the next step.
Install the MC45
To install the MC45 into the Vehicle Charge Cradle:
1.
Place the MC45 bottom first into the cradle.
2.
Push the MC45 back until it snaps into place.
Figure 8-6
Insert MC45 into Vehicle Charge Cradle
3.
Position the MC45 for best viewing.
4.
Tighten the nuts to lock the cradle in place.
8-7
8 - 8 MC45 User Guide
Figure 8-7
Tighten Nut
Connect Power
To connect power to the Vehicle Charge Cradle:
1.
If required, connect the micro USB connector of the auto charger to the input power connector in the Vehicle
Charge Cradle.
Figure 8-8
Commercial Grade Auto Charger
Accessories
Figure 8-9
2.
8-9
Connect Auto Charge Cable to Vehicle Charge Cradle
Connect the other end to the cigarette lighter socket.
The LED indicator flashes green indicating the MC45 is charging.
Remove the MC45
To remove the MC45 from the Vehicle Charge Cradle lift the MC45 up and then remove from the bottom of the
cradle.
Figure 8-10
Remove MC45 from Vehicle Charge Cradle
8 - 10 MC45 User Guide
Four Slot Battery Charger
To charge the MC45 batteries:
1.
Connect the charger to a power source.
2.
Insert the spare battery into a spare battery charging well and gently press down on the battery to ensure the
battery is safely locked under the latch.
Spare Battery
Charging LEDs (4)
Figure 8-11
Four Slot Battery Charger
To remove the spare battery from the Four Slot Battery Charger:
1.
Gently push the battery located in the spare battery charging well towards the back of the charger. The latch
unlocks.
2.
Remove the battery by pulling it upwards from the spare battery charging well.
NOTE The Four Slot Battery Charger is compatible and charges the 3080 mAh lithium-ion battery (p/n
BTRY-MCXX-3080-01R, BTRY-MCXX-3080-10R and BTRY-MCBR-3080-01R).
Battery Charging Indicators
The charger has a green LED for each battery charging well. See Table 8-2 for charging status indications. The
3080 mAh battery fully charges in less than six hours at room temperature of approximately 25 °C (77°F). Charging
time may vary at different temperatures.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the Four
Slot Battery Charger.
To accomplish this, for small periods of time, the charger alternately enables and disables battery charging to keep
the battery at acceptable temperatures. The charger indicates when charging is disabled due to abnormal
temperatures via its LED. See Table 1-1 on page 1-7.
Accessories 8 - 11
Table 8-2
Spare Battery LED Charging Indicators
LED
Indication
Off
No spare battery in slot; battery is not charging; battery is not inserted correctly in
the charger; charger is not powered.
Slow Blinking Green
Spare battery is charging.
Solid Green
Charging complete.
Fast Blinking Red
Charging error.
micro USB Adapter
Use the micro USB Adapter to connect accessory devices (such as printers or USB flash drives) to the MC45. The
micro USB Adapter connects the DEX cable to the MC45.
Figure 8-12
micro USB Adapter Connection
NOTE The micro USB Adapter can only be connected to the MC45 and not the Single Slot Charge Cradle.
The micro USB Adapter is intended to provide extension of the MC45 micro USB port. Use the micro USB
Adapter to minimize mechanical wear and failures of the MC45.
CAUTION Do not connect a USB device that draws more than 100 mA. If a device that draws more than 100mA is
connected, the MC45 displays a Warning dialog box. Remove the USB device from the micro USB
Adapter.
Connect an accessory device’s USB connector to the micro USB Adapter.
NOTE When connecting a USB Flash drive to the micro USB Adapter, the USB Flash Drive appears in File Explorer
as Hard Drive under My Device folder.
8 - 12 MC45 User Guide
Handstrap
The handstrap allows the MC45 to be worn safely around the palm of your hand. To install the handstrap:
1.
Remove the 2 screws securing the existing tether plate from the MC45.
2.
Untie the tether from the tether plate.
3.
Tie the tether to the handstrap plate.
4.
Install the handstrap plate to the MC45.
1
2
4
3
Figure 8-13
Installing the Handstrap
Accessories 8 - 13
ActiveSync
To communicate with various host devices, install Microsoft ActiveSync (version 4.5 or higher) on the host
computer. Use ActiveSync to synchronize information on the MC45 with information on the host computer.
Changes made on the MC45 or host computer appear in both places after synchronization.
NOTE When the MC45 is connected to a host computer and an ActiveSync connection is made, the WLAN radio is
disabled. This is a Microsoft security feature to prevent connection to two networks at the same time.
ActiveSync software:
• Allows working with mobile computer-compatible host applications on the host computer. ActiveSync
replicates data from the mobile computer so the host application can view, enter, and modify data on the
mobile computer.
• Synchronizes files between the mobile computer and host computer, converting the files to the correct
format.
• Backs up the data stored on the mobile computer. Synchronization is a one-step procedure that ensures the
data is always safe and up-to-date.
• Copies (rather than synchronizes) files between the mobile computer and host computer.
• Controls when synchronization occurs by selecting a synchronization mode, e.g., set to synchronize
continually while the mobile computer is connected to the host computer, or set to only synchronize on
command.
• Selects the types of information to synchronize and control how much data is synchronized.
Installing ActiveSync
To install ActiveSync on the host computer, download version 4.5 or higher from the Microsoft web site at
http://www.microsoft.com. Refer to the installation procedures included with the ActiveSync software.
MC45 Setup
NOTE Microsoft recommends installing ActiveSync on the host computer before connecting the MC45.
The MC45 can be set up to communicate with a USB connection. The MC45 communication settings must be set
to match the communication settings used with ActiveSync.
1.
On the MC45 tap Start > ActiveSync.
2.
Tap Menu > Connections.
3.
Select the connection type from the drop-down list.
4.
Tap OK to exit the Connections window
5.
Tap OK to exit the ActiveSync window.
6.
Proceed with setting up a partnership with a host computer with ActiveSync installed.
8 - 14 MC45 User Guide
Setting Up an ActiveSync Connection on the Host Computer
To start ActiveSync:
1.
Select Start > Programs > Microsoft ActiveSync on the host computer.
NOTE Assign each MC45 a unique device name. Do not try to synchronize more than one MC45 to the same name.
2.
In the ActiveSync window, select File > Connection Settings. The Connection Settings window appears.
3.
Select Allow USB connections check box.
4.
Select the Show status icon in Taskbar check box.
5.
Select OK to save any changes made.
Synchronization with the MC45
NOTE When the MC45 is connected to a host computer and an ActiveSync connection is made, the WLAN radio
(if applicable) is disabled. This is a Microsoft security feature to prevent connection to two networks at the
same time.
To synchronize with the MC45:
1.
If the Get Connected window does not appear on the host computer, select Start > Active Sync and then
click Next.
2.
Select the check box to synchronize with a server running Microsoft Exchange if applicable and then click
Next.
3.
Select the appropriate settings and click Next and then click Finish.
During the first synchronization, information stored on the MC45 is copied to the host computer. When the copy is
complete and all data is synchronized, the MC45 can be disconnected from the host computer.
NOTE The first ActiveSync operation must be performed with a local, direct connection. Windows Mobile retains
partnerships information after a cold boot.
For more information about using ActiveSync, start ActiveSync on the host computer, then see ActiveSync Help.
Appendix A Technical Specifications
MC45 Technical Specifications
The following tables summarize the MC45’s intended operating environment and technical hardware
specifications.
Table A-1
MC45 Technical Specifications
Item
Description
Physical Characteristics
Dimensions
Length: 14.2 cm (5.6 in.)
Width: 6.6 cm (2.6 in.)
Depth: 2.5 cm (1.0 in.)
Weight
247.4 g (8.73 oz)
Display
16 bit color 3.2” QVGA with backlight, TFT-LCD, 65K colors,
240 W x 320 L (QVGA size)
Touch Panel
Polycarbonate analog resistive touch
Backlight
LED backlight
Battery
Rechargeable Lithium Ion 3.7V, 3080 mAh battery
Expansion Slot
User accessible microSD slot with UHS-I SDHC support up to 32GB
Network Connections
USB 2.0 High Speed (host and client), WLAN, WWAN and Bluetooth
Notification
Vibrator and audible tone plus multi-color LED
Keypad Options
Numeric
Audio
VoWWAN: handset mode with active noise reduction, speaker phone mode,
Bluetooth wireless headset mode
Performance Characteristics
CPU
600 MHz, ARM 11 processor, MSM 7627
A - 2 MC45 User Guide
Table A-1
MC45 Technical Specifications (Continued)
Item
Description
Operating System
Microsoft® Windows Embedded Handheld™ 6.5.3 Professional Edition
Memory
256 MB RAM / 1GB Flash
Interface/Communications
USB 2.0
Output Power
USB: 5 VDC @ 300mA max.
User Environment
Operating Temperature
-10°C to 50°C (14°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
32°F to 104°F / 0° C to 40° C
Humidity
5% to 95% non-condensing
Drop Specification
Multiple 1.5 m (5 ft.) drop per MIL-STD 810G
Multiple 0.9 m (3 ft.) drop to concrete, over operating temperature range
Tumble
250, 0.5 m (1.5 ft.) tumbles with standard batteries installed; per applicable IEC
tumble specifications
Electrostatic Discharge (ESD)
+/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing
IP64 per applicable IEC sealing specifications
Vibration
.04g2/Hz Random, Non-Operating, 1 hour duration per axis
Termal Shock
-40°C to 70°C rapid transition
Wireless WAN Data and Voice Communications
Radio
GSM and UMTS/HSDPA
Frequency Band
GSM – All Models Quad Band : 850 / 900 / 1800 / 1900 MHz
UMTS/HSDPA – MC4597-A and MC4587-A : 2100 MHz
UMTS/HSDPA – MC4597-B: 850 / 1900 MHz
GPS
Integrated, Autonomous and Assisted-GPS (A-GPS)
Wireless LAN Data and Voice Communications
Radio
MC4597-A and MC4597-B: Tri-mode IEEE® 802.11a/b/g
Data Rates Supported
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
Operating Channels
Chan 8-169 (5040 – 5845 MHz)
Chan 1-13 (2412-2472 MHz) Chan 14 (2484 MHz) Japan only
Actual operating frequencies depend on regulatory rules and certification
agency
Technical Specifications A - 3
Table A-1
MC45 Technical Specifications (Continued)
Item
Description
Security
WPA2, WEP (40 or 128 bit), TKIP, TLS, TTLS (MS-CHAP), TTLS (MS-CHAP
v2), TTLS (CHAP), TTLS-MD5, TTLS-PAP, PEAP-TLS, PEAP (MS-CHAP v2),
AES, LEAP, CCXv4 certified; FIPS 140-2 certified
Spreading Technique
Direct Sequence Spread Spectrum (DSSS) and Orthogonal Frequency Division
Multiplexing (OFDM)
Antenna
Internal
Wireless PAN Data and Voice Communications
Bluetooth
Class II, V2.0 with EDR
Data Capture Specifications
Options
1D laser, color camera
Laser 1D Scanner (SE965) Specifications
Optical Resolution
0.005 in. minimum element width
Roll
+/- 30° from vertical
Pitch Angle
+/- 65° from normal
Skew Tolerance
+/- 40° from normal
Ambient Light
Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting
conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED :
450 Ft Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux)
Shock
2,000 +/- 5% G
Scan Rate
50 (+/- 6) scans/sec (bidirectional)
Scan Angle
46.5° (typical)
Laser Power
1.0 mW nominal
Camera Specifications
Resolution
3.2 Mega pixel with auto focus and flash
A - 4 MC45 User Guide
Table A-2
Data Capture Options
Item
Camera Decode Capability
Description
1-D Bar Codes
Codabar
Code 93
Coupon Code
EAN 13
Korean 3 of 5
RSS 14
Trioptic Code 29
UPCE
2-D Bar Codes
Australian Postal
Composite C
Macro Micro PRF
PDF
UK Postal
US Postnet
Code 11
Code 128
Discrete 2 of 5
Interleaved 2 of 5
MSI
RSS Limited
UCC / EAN 128
UPCE1
Code 39
Chinese 2 of 5
EAN 8
ISBT 128
RSS
RSS Expanded
UPCA
Web Code
Aztec
Data Matrix
Japan Postal
Micro PDF
QR Code
UK Intellimail
Composite AB
Dutch Postal
Linked Aztec
Micro QR
Signature
US Planet
MC45 Accessory Specifications
Single Slot Charge Cradle
Table A-3
Single Slot Charge Cradle Technical Specifications
Feature
Description
Dimensions
Length: 9.6 cm (3.8 in.)
Width: 8.30 cm (3.3 in.)
Height: 6.8 cm (2.7 in.)
Weight
245 g (8.6 oz)
Input Power
5 VDC
Power Consumption
6 watts
Interface
USB
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Technical Specifications A - 5
Table A-3
Single Slot Charge Cradle Technical Specifications (Continued)
Feature
Description
Humidity
5% to 95% non-condensing
Drop
76 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Multi Slot Universal Charge Only Cradle
Table A-4
Multi Slot Universal Charge Only Cradle Technical Specifications
Feature
Description
Dimensions (Base only)
Length: 12.0 cm (4.7 in.)
Width: 45.0 cm (17.7 in.)
Height: 3.8 cm (1.5 in.)
Height: 4.4 cm (1.7 in.) with 5 rubber caps
Dimensions (Base with 5 Charger
Cups)
Length: 12.0 cm (4.7 in.)
Width: 45.0 cm (17.7 in.)
Height: 7.7 cm (3.0 in.)
Dimensions (Base with 4 Charger Cups
and 1 Four Slot Battery Charger Cup
Adapter)
Length: 12.0 cm (4.7 in.)
Width: 45.0 cm (17.7 in.)
Height: 7.7 cm (3.0 in.)
Weight (Base only)
910 g (32.10 oz)
930 g (32.80 oz) with 5 rubber caps
Weight (Base with 5 Charger Cups)
1190 g (41.98 oz)
Weight (Base with 4 Charger Cups and
1 Four Slot Battery Charger Cup
Adapter)
1670 g (58.91 oz)
Input Power
12 VDC
Power Consumption (with 5 MC45s)
37.5 watts
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
A - 6 MC45 User Guide
Four Slot Battery Charger
Table A-5
Four Slot Battery Charger Technical Specifications
Feature
Description
Dimensions
Length: 11.9 cm (4.7 in.)
Width: 8.7 cm (3.4 in.)
Height: 9.4 cm (3.7 in.)
Weight
366 g (12.91 oz)
Input Power
12 VDC
Power Consumption
25.1 watts
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Appendix B Keypads
Numeric Keypad Configuration
The numeric keypad contains application keys, scroll keys, and function keys. The keypad is color-coded to
indicate the alternate function key (blue) values. Note that an application can change keypad functions so the
MC45’s keypad may not function exactly as described. See Table B-1 for key and button descriptions and Table
B-2 on page B-4 for the keypad’s special functions.
Figure B-1
MC45 Numeric Keypad
B - 2 MC45 User Guide
Table B-1
MC45 Numeric Keypad Descriptions
Key
Blue Key (left)
Description
Use this key to access function keys shown on the keypad in blue.
Press the Blue key once to activate this mode, followed by another key.
A single press illuminates the key and displays the following icon
at the bottom of the
screen until a second key is pressed:
Press the Blue key twice to lock the keypad in the blue keys mode. This displays the
following icon
at the bottom of the screen.
Press the Blue key again to return to the normal state.
Orange Key
Use this key to access the secondary layer of characters and actions shown on the keypad
in orange.
Press the Orange key once to activate this mode, followed by another key.
A single press illuminates the key and displays the following icon
at the bottom of the
screen until a second key is pressed:
Press the Orange key twice to lock the keypad in the orange keys mode.This displays the
following icon
at the bottom of the screen.
Press the Orang key twice, then press the Shift key to add a permanent shift (that applies
until the Shift is pressed again). This displays the following icon
screen.
Press the Orange key again to return to the normal state.
at the bottom of the
Talk / Start Menu
Talk (Green Phone): press to display the phone keypad window or to dial a phone number
(from the phone keypad window).
When on a phone call, press to place the call on hold.
Use this key in conjunction with the Blue key to instantly display the Start menu from any
application without tapping the screen. This function is user programmable.
End / OK
End (Red Phone) : press when the phone keypad window displays to stop dialing or end a
call.
Use this key in conjunction with the Blue Key as an OK or close button. This function is user
programmable.
Scan (yellow)
Activates the scanner in a scan enabled application.
Scroll Up and Down
/ Scroll Left and
Right
Moves up one item.
Moves left one item when pressed with the Orange key.
Moves down one item.
Moves right one item when pressed with the Orange key.
Keypads B - 3
Table B-1
MC45 Numeric Keypad Descriptions (Continued)
Key
Description
Star / Backlight
Produces a dash in default state.
Produces an asterisk when pressed with the Orange key.
Use this key in conjunction with the Blue Key to toggle the backlight on or off.
Alphanumeric
In default state, produces the numeric value on the key.
When pressed with the Orange key, produces the lower case alphabetic characters on the
key. Each key press produces the next alphabetic character in sequence. For example,
press and release the Orange key and then press the ‘4’ key once to produce the letter ‘g’;
press and release the Orange key and then press the ‘4’ key three times to produce the
letter ‘i’.
Press the SHIFT key in Alpha state to produce the upper case alphabetic characters on the
key. For example, press and release the Orange key, press and release the SHIFT key, and
then press the ‘4’ key once to produce the letter ‘G’; press and release the Orange key,
press and release the SHIFT key and then press the ‘4’ key three times to produce the letter
‘I’.
Pound / SPACE
Produces a pound / number in default state.
Produces a space when pressed with the Orange key.
BACKSPACE
Produces a backspace.
SHIFT
Press and release the SHIFT key to activate the keypad alternate SHIFT functions.
A single press displays the following icon
at the bottom of the screen, until a second
key is pressed:
Press the Shift key twice to lock the keypad in the Shift mode.This displays the following icon
at the bottom of the screen.
Press the Orang key twice, then press the Shift key to add a permanent shift (that applies
until the Shift is pressed again). This displays the following icon
screen.
ENT (Enter)
Executes a selected item or function.
at the bottom of the
B - 4 MC45 User Guide
Numeric Keypad Input Modes
Table B-2
Orange Key
(Alpha Lowercase Mode)
Numeric Mode
Key
Blue+
Key
SHIFT
+ Key
1st
Press
2nd
Press
3rd
Press
4th
Press
Orange + Shift Keys
(Alpha Uppercase Mode)
1st
Press
2nd
Press
3rd
Press
1
1
F1
!
2
2
F2
@
a
b
c
A
B
C
3
3
F3
#
d
e
f
D
E
F
4
4
F4
$
g
h
i
G
H
I
5
5
F5
%
j
k
l
J
K
L
6
6
F6
^
m
n
o
M
N
O
7
7
F7
&
p
q
r
P
Q
R
8
8
F8
*
t
u
v
T
U
V
9
9
F9
(
w
x
y
W
X
Y
0
0
F10
)
.
>
Up
Up
Up
Hilight
Up
Left
Left
Down
Down
Down
Hilight
Down
Right
Right
Enter
Action
Action
Action
Action
Action
s
z
4th
Press
S
Z
Note: An application can change the key functions. The keypad may not function exactly as described.
Special Character Key
To add special characters using the MC45 áü key, press the Orange key twice first then type the related character
followed by the áü (P) key. Continue pressing the áü key until the special character displays. To modify an existing
character, move the cursor to the right of the character then press the Orange key twice and then press the áü key
until the special character replaces the original character. Table B-3 lists the special characters you can generate.
Table B-3
Key
Special Characters
Special Characters
Key
a
A
c
C
d
D
e
E
i
I
Special Characters
Keypads B - 5
Table B-3
Key
Special Characters (Continued)
Special Characters
Key
l
L
n
N
o
O
p
P
r
R
s
S
t
T
u
U
y
Y
z
Z
$
/
“
(
)
+
!
.
*
@
%
,
#
&
_
‘
?
:
-
Special Characters
B - 6 MC45 User Guide
Glossary
A
API. An interface by means of which one software component communicates with or controls another. Usually used to refer
to services provided by one software component to another, usually via software interrupts or function calls
Application Programming Interface. See API.
AKU. (Adaptation Kit Update) Updates to the Windows Mobile operating system.
AFH. Adaptive Frequency Hopping.
ActiveSync. ActiveSync is a data synchronization program developed by Microsfot for use with Windows Mobile operating
systems.
B
Bar. The dark element in a printed bar code symbol.
Bar Code. A pattern of variable-width bars and spaces which represents numeric or alphanumeric data in machine-readable
form. The general format of a bar code symbol consists of a leading margin, start character, data or message character,
check character (if any), stop character, and trailing margin. Within this framework, each recognizable symbology uses
its own unique format. See Symbology.
Bar Code Density. The number of characters represented per unit of measurement (e.g., characters per inch).
Bit. Binary digit. One bit is the basic unit of binary information. Generally, eight consecutive bits compose one byte of data.
The pattern of 0 and 1 values within the byte determines its meaning.
Bits per Second (bps). Bits transmitted or received.
boot or boot-up. The process a computer goes through when it starts. During boot-up, the computer can run self-diagnostic
tests and configure hardware and software.
Glossary - 2 MC45 User Guide
bps. See Bits Per Second.
Byte. On an addressable boundary, eight adjacent binary digits (0 and 1) combined in a pattern to represent a specific
character or numeric value. Bits are numbered from the right, 0 through 7, with bit 0 the low-order bit. One byte in
memory is used to store one ASCII character.
C
Codabar. A discrete self-checking code with a character set consisting of digits 0 to 0 and six additional characters (“-”, ”$”,
”:”, ”/”, ”,” and “+”).
Code 128. A high density symbology which allows the controller to encode all 128 ASCII characters without adding extra
symbol elements.
Code 3 of 9 (Code 39). A versatile and widely used alphanumeric bar code symbology with a set of 43 character
types,including all uppercase letters, numerals from 0 to 9 and 7 special characters (“-”, “.”, “/”, “+”, “%”, “$” and space).
The code name is derived from the fact that 3 of 9 elements representing a character are wide, while the remaining 6
are narrow.
Code 93. An industrial symbology compatible with Code 39 but offering a full character ASCII set and a higher coding
density than Code 39.
COM port. Communication port; ports are identified by number, e.g., COM1, COM2.
Cradle. A cradle is used for charging the terminal battery and for communicating with a host computer, and provides a
storage place for the terminal when not in use.
D
Decode. To recognize a bar code symbology (e.g., UPC/EAN) and then analyze the content of the specific bar code
scanned.
Discrete 2 of 5. A binary bar caode symbology representing each character by a group of five bars, two of which are wide.
The location of wide bars in the group determines which character is encoded; spaces are insignificant. Only numberic
characters (0 to 9) and START/STOP characters may be encoded.
E
EAN. European Article Number. This European/International version of the UPC provides its own coding format and
symbology standards. Element dimensions are specified metrically. EAN is used primarily in retail.
EMDK. Enterprise Mobility Developer’s Kit.
ESD. Electro-Static Discharge
Glossary - 3
F
File Transfer Protocol (FTP). A TCP/IP application protocol governing file transfer via network or telephone lines. See
TCP/IP.
FTP. See File Transfer Protocol.
G
GPS (Global Positioning System). A satellite-based navigation system made up of a network of 24 satellites. GPS
satellites circle the earth and transmit signal information to earth. GPS receivers take this information and use
triangulation to calculate the user's exact location.
H
Hz. Hertz; A unit of frequency equal to one cycle per second.
Host Computer. A computer that serves other terminals in a network, providing such services as computation, database
access, supervisory programs and network control.
High-Speed Downlink Packet Access (HSDPA). A 3G (third generation) mobile telephony communications protocol in the
High-Speed Packet Access (HSPA) family, which allows networks based on Universal Mobile Telecommunications
System (UMTS) to have higher data transfer speeds and capacity.
I
Interleaved 2 of 5. A binary bar code symbology representing character pairs in groups of five bars and five interleaved
spaces. Interleaving provides for greater information density. The location of wide elements (bar/spaces) within each
group determines which characters are encoded. This continuous code type uses no intercharacter spaces. Only
numeric (0 to 9) and START/STOP characters may be encoded.
Internet Protocol Address. See IP.
IP. Internet Protocol. The IP part of the TCP/IP communications protocol. IP implements the network layer (layer 3) of the
protocol, which contains a network address and is used to route a message to a different network or subnetwork. IP
accepts “packets” from the layer 4 transport protocol (TCP or UDP), adds its own header to it and delivers a “datagram”
to the layer 2 data link protocol. It may also break the packet into fragments to support the maximum transmission unit
(MTU) of the network.
IP Address. (Internet Protocol address) The address of a computer attached to an IP network. Every client and server
station must have a unique IP address. A 32-bit address used by a computer on a IP network. Client workstations have
either a permanent address or one that is dynamically assigned to them each session. IP addresses are written as four
sets of numbers separated by periods; for example, 204.171.64.2.
Glossary - 4 MC45 User Guide
L
LASER. Light Amplification by Stimulated Emission of Radiation.The laser is an intense light source. Light from a laser is
all the same frequency, unlike the output of an incandescent bulb. Laser light is typically coherent and has a high energy
density.
laser scanner. A type of bar code reader that uses a beam of laser light.
LCD. See Liquid Crystal Display.
LED Indicator. A semiconductor diode (LED - Light Emitting Diode) used as an indicator, often in digital displays. The
semiconductor uses applied voltage to produce light of a certain frequency determined by the semiconductor's particular
chemical composition.
Light Emitting Diode. See LED.
Liquid Crystal Display (LCD). A display that uses liquid crystal sealed between two glass plates. The crystals are excited
by precise electrical charges, causing them to reflect light outside according to their bias. They use little electricity and
react relatively quickly. They require external light to reflect their information to the user.
M
MC. Mobile Computer.
MDN. Mobile Directory Number. The directory listing telephone number that is dialed (generally using POTS) to reach a
mobile unit. The MDN is usually associated with a MIN in a cellular telephone -- in the US and Canada, the MDN and
MIN are the same value for voice cellular users. International roaming considerations often result in the MDN being
different from the MIN.
Mobile Computer. In this text, mobile computer refers to the MC45. It can be set up to run as a stand-alone device, or it can
be set up to communicate with a network, using wireless radio technology.
N
Nominal. The exact (or ideal) intended value for a specified parameter. Tolerances are specified as positive and negative
deviations from this value.
Nominal Size. Standard size for a bar code symbol. Most UPC/EAN codes are used over a range of magnifications (e.g.,
from 0.80 to 2.00 of nominal).
NVM. Non-Volatile Memory.
Glossary - 5
P
PAN . Personal area network. Using Bluetooth wireless technology, PANs enable devices to communicate wirelessly.
Generally, a wireless PAN consists of a dynamic group of less than 255 devices that communicate within about a 33-foot
range. Only devices within this limited area typically participate in the network.
Parameter. A variable that can have different values assigned to it.
PING. (Packet Internet Groper) An Internet utility used to determine whether a particular IP address is online. It is used to
test and debug a network by sending out a packet and waiting for a response.
R
RAM. Random Access Memory. Data in RAM can be accessed in random order, and quickly written and read.
Reset. Restarts the mobile computer by closing all running programs. All data that is not saved to flash memory is lost.
Resolution. The narrowest element dimension which is distinguished by a particular reading device or printed with a
particular device or method.
RF. Radio Frequency.
ROM. Read-Only Memory. Data stored in ROM cannot be changed or removed.
Router. A device that connects networks and supports the required protocols for packet filtering. Routers are typically used
to extend the range of cabling and to organize the topology of a network into subnets. See Subnet.
S
Scanner. An electronic device used to scan bar code symbols and produce a digitized pattern that corresponds to the bars
and spaces of the symbol. Its three main components are: 1) Light source (laser or photoelectric cell) - illuminates a bar
code,; 2) Photodetector - registers the difference in reflected light (more light reflected from spaces); 3) Signal
conditioning circuit - transforms optical detector output into a digitized bar pattern.
Shared Key. Shared Key authentication is an algorithm where both the AP and the MU share an authentication key.
Subnet. A subset of nodes on a network that are serviced by the same router. See Router.
Subnet Mask. A 32-bit number used to separate the network and host sections of an IP address. A custom subnet mask
subdivides an IP network into smaller subsections. The mask is a binary pattern that is matched up with the IP address
to turn part of the host ID address field into a field for subnets. Default is often 255.255.255.0.
Symbology. The structural rules and conventions for representing data within a particular bar code type (e.g. UPC/EAN,
Code 39, PDF417, etc.).
Glossary - 6 MC45 User Guide
T
TCP/IP. (Transmission Control Protocol/Internet Protocol) A communications protocol used to internetwork dissimilar
systems. This standard is the protocol of the Internet and has become the global standard for communications. TCP
provides transport functions, which ensures that the total amount of bytes sent is received correctly at the other end.
UDP is an alternate transport that does not guarantee delivery. It is widely used for real-time voice and video
transmissions where erroneous packets are not retransmitted. IP provides the routing mechanism. TCP/IP is a routable
protocol, which means that all messages contain not only the address of the destination station, but the address of a
destination network. This allows TCP/IP messages to be sent to multiple networks within an organization or around the
world, hence its use in the worldwide Internet. Every client and server in a TCP/IP network requires an IP address, which
is either permanently assigned or dynamically assigned at startup.
Terminal. See Mobile Computer.
Tolerance. Allowable deviation from the nominal bar or space width.
Transmission Control Protocol/Internet Protocol. See TCP/IP.
U
UDP. User Datagram Protocol. A protocol within the IP protocol suite that is used in place of TCP when a reliable delivery
is not required. For example, UDP is used for real-time audio and video traffic where lost packets are simply ignored,
because there is no time to retransmit. If UDP is used and a reliable delivery is required, packet sequence checking and
error notification must be written into the applications.
UPC. Universal Product Code. A relatively complex numeric symbology. Each character consists of two bars and two
spaces, each of which is any of four widths. The standard symbology for retail food packages in the United States.
Index
Numerics
1-D bar codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
1-D laser scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
A
A2DP/AVRCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
accessories
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . 8-1
battery door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
blank slot cover . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
charger cup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
four slot battery charger . . . . . . . . . . . . . . .8-1, 8-10
four slot battery charger cup adapter . . . . . . . . . 8-2
handstrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
micro USB adapter . . . . . . . . . . . . . . . . . . .8-2, 8-11
microSD card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
multi slot universal charge only cradle . 1-6, 8-1, 8-5
multi slot universal charge only cradle with five MC45
cups installed . . . . . . . . . . . . . . . . . . . . . 8-1
power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
screen protector . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
single slot charge cradle . . . . . . . . . . . . 1-6, 8-1, 8-4
soft holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
spare battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
stylus with tether kit . . . . . . . . . . . . . . . . . . . . . . . 8-2
USB rapid charge cable . . . . . . . . . . . . 1-6, 8-1, 8-3
vehicle charge cradle . . . . . . . . . . . . . . 1-6, 8-1, 8-6
ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9, 8-13
icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
setting up a connection . . . . . . . . . . . . . . . . . . . 8-14
synchronization . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
adaptive frequency hopping . . . . . . . . . . . . . . . . . . . 7-1
adaptive scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
adjusting audio volume . . . . . . . . . . . . . . . . . . . . . . . 4-4
adjusting volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Adobe Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
AFH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
AirBEAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
assisted GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
audio icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
B
bar codes
one dimensional . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6, 8-4
check status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
management . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
battery charger
charging indicators . . . . . . . . . . . . . . . . . . . . . . 8-10
charging temperature . . . . . . . . . . . . . . . . . . . . 8-10
battery charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
using single slot charge cradle . . . . . . . . . . . . . . 8-4
battery cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
battery door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
battery icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4, 2-15
battery status indications . . . . . . . . . . . . . . . . . . . . . 2-15
blank slot cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Index - 2 MC45 User Guide
adaptive frequency hopping . . . . . . . . . . . . . . . . 7-1
configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
discovering devices . . . . . . . . . . . . . . . . . . . . . . . 7-5
power states . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
suspend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
turning off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
turning on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
bluetooth
turning on and off . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
bullets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
buttons
function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
power . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8, 2-20
scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
up and down . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
C
cables
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . 8-1
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
USB rapid charge cable . . . . . . . . . . . . 1-6, 8-1, 8-3
calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
calibrating the screen . . . . . . . . . . . . . . . . . . . . . . . . 1-8
call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6, 4-13
camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
charger cup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
chargers
four slot battery charger . . . . . . . . . . . . . . .8-1, 8-10
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
spare batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
using single slot charge cradle . . . . . . . . . . . . . . 8-4
charging indicators
four slot battery charger . . . . . . . . . . . . . . . . . . 8-10
charging temperature . . . . . . . . . . . . . . . . . . . . .1-7, 8-5
four slot battery charger . . . . . . . . . . . . . . . . . . 8-10
Classic Today Screen . . . . . . . . . . . . . . . . . . . . . . . . 2-6
cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
command bar
icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5, 2-7
conference call . . . . . . . . . . . . . . . . . . . . . . . .4-17, 4-19
configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
connectivity icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
contacts application . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
conventions
notational . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
cradles
multi slot universal charge only cradle . 1-6, 8-1, 8-5
multi slot universal charge only cradle with five MC45
cups installed . . . . . . . . . . . . . . . . . . . . . 8-1
single slot charge cradle . . . . . . . . . . . . 1-6, 8-1, 8-4
vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6, 8-1, 8-6
D
data capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
adaptive scanning . . . . . . . . . . . . . . . . . . . . . . . . 3-2
camera scanning . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
linear scanning . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
one dimensional bar codes . . . . . . . . . . . . . . . . . 3-1
scan angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
scan button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
scan range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
DataWedge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
debug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Device Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
dialer
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
display orientation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
E
e-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
emergency calls . . . . . . . . . . . . . . . . . . . . 2-17, 2-19, 4-7
entering data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
ESD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
F
file explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
four slot battery charger . . . . . . . . . . . . . . . . . . 8-1, 8-10
charging indicators . . . . . . . . . . . . . . . . . . . . . . 8-10
charging temperature . . . . . . . . . . . . . . . . . . . . 8-10
four slot battery charger cup adapter . . . . . . . . . . . . . 8-2
function buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Fusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
G
games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Index - 3
pound/space . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
SHIFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
special character key . . . . . . . . . . . . . . . . . . . . . . B-4
star / backlight key . . . . . . . . . . . . . . . . . . . . . . . . B-3
talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
global positioning system . . . . . . . . . . . . . . . . . . . . . 6-1
GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
GPS assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
H
handset mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
handstrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
headset mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
hexadecimal keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
High-Speed Downlink Packet Access . . . . . . . . . . . . 4-1
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Human Interface Device (HID) . . . . . . . . . . . . . . . . 7-14
I
icons
ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4, 2-15
connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
DataWedge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
task tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
WAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
wireless connection status . . . . . . . . . . . . . . . . . 2-7
indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
radio status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
information, service . . . . . . . . . . . . . . . . . . . . . . . . . . .xvi
Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2, 1-3
Internet Explorer Mobile . . . . . . . . . . . . . . . . . . . . . . 2-8
internet sharing . . . . . . . . . . . . . . . . . . . . . . . . . .2-9, 7-9
IrDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
K
key descriptions
numeric keypad . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
keypads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
alphanumeric . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
backspace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
blue key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
Enter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
input modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
key descriptions . . . . . . . . . . . . . . . . . . . . . . . . . B-2
numeric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
orange key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
L
laser scanning
See data capture . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
LEDs
battery status . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
charging . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16, 8-10
indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
scan and decode . . . . . . . . . . . . . . . . . . . . . 3-2, 3-3
left and right key . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
lithium-ion battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
locking MC45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
password locking . . . . . . . . . . . . . . . . . . . . . . . . 2-18
M
maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
marketplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
masked characters . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
MC4587 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
MC4597 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Windows Live Messenger . . . . . . . . . . . . . . . . . . 2-9
micro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
micro USB adapter . . . . . . . . . . . . . . . . . . . . . . 8-2, 8-11
microSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
MSN Money . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
MSN Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
MSP Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
multi slot universal charge only cradle . . . . . 1-6, 8-1, 8-5
multi slot universal charge only cradle with five MC45
cups installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
muting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
N
navigation bar
icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
network activation . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
GSM/UMTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . xv
notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Index - 4 MC45 User Guide
notifications icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
numeric keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
input modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
key descriptions . . . . . . . . . . . . . . . . . . . . . . . . . B-2
O
Object Push Services . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Office Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
operating environment . . . . . . . . . . . . . . . . . . . . . . . . A-1
operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
P
pass-phrase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
hint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
answering a call . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
conference call . . . . . . . . . . . . . . . . . . . . .4-17, 4-19
contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
dialer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
MMS messaging . . . . . . . . . . . . . . . . . . . . . . . . 4-22
muting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
SMS messaging . . . . . . . . . . . . . . . . . . . . . . . . 4-20
speed dial
adding entry . . . . . . . . . . . . . . . . . . . . . . . . 4-10
calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
deleting entry . . . . . . . . . . . . . . . . . . . . . . . 4-12
editing entry . . . . . . . . . . . . . . . . . . . . . . . . 4-12
three-way call . . . . . . . . . . . . . . . . . . . . . .4-17, 4-19
turning on and off . . . . . . . . . . . . . . . . . . . . . . . . 4-2
using call log . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
using keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Voice Commander . . . . . . . . . . . . . . . . . . . . . . 4-24
Phone Book Access profile . . . . . . . . . . . . . . . . . . . 7-13
pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
power button . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8, 2-20
power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
R
radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
rapid deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
recording video . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
remote desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
replacing battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
resetting the MC45 . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
S
scan button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
scan/decode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
scanning
button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
See data capture . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
calibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
screen protector . . . . . . . . . . . . . . . . . . . . . . . . . 8-2, 9-2
search phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
security
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
service information . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8, 2-11
about . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
clock & alarms . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
connections folder . . . . . . . . . . . . . . . . . . . . . . . 2-11
customer feedback . . . . . . . . . . . . . . . . . . . . . . 2-12
DataWedge . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
device information . . . . . . . . . . . . . . . . . . . . . . . 2-12
domain enroll . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
error reporting . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
external GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
GPS assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
keylight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
KeyRemap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
managed programs . . . . . . . . . . . . . . . . . . . . . . 2-13
memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
owner information . . . . . . . . . . . . . . . . . . . . . . . 2-12
personal folder . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
phone network setup . . . . . . . . . . . . . . . . . . . . . 2-11
power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
regional settings . . . . . . . . . . . . . . . . . . . . . . . . 2-13
remove programs . . . . . . . . . . . . . . . . . . . . . . . 2-13
screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
sounds & notifications . . . . . . . . . . . . . . . . . . . . 2-11
system folder . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
system info . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
task manager . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
USB connect . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Voice Commander settings . . . . . . . . . . . . . . . . 2-12
Index - 5
wireless manager . . . . . . . . . . . . . . . . . . . . . . . 2-12
WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
SIM card
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
single slot charge cradle . . . . . . . . . . . . . . . 1-6, 8-1, 8-4
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
smart dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
SMS Staging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
soft holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
soft keys bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
spare battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
speaker icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
speaker mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
special character key . . . . . . . . . . . . . . . . . . . . . . . . . B-4
speed dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7, 4-10
start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
AirBEAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
contactsl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
debug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
e-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
file explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Internet Explorer Mobile . . . . . . . . . . . . . . . . . . . 2-8
internet sharing . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
marketplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
MSN Money . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
MSN Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
MSP Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Office Mobile . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
rapid deployment . . . . . . . . . . . . . . . . . . . . . . . 2-10
remote desktop . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
search phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
SMS Staging . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
task manager . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
today . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
toolbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Windows Live . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
wireless companion . . . . . . . . . . . . . . . . . . . . . . . 2-9
starting the MC45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
status icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4, 2-15
connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
WAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Streaming Player . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2, 2-21
stylus with tether kit . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
subscriber identification module . . . . . . . . . . . . . . . . . 1-4
suspend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20, 7-3
synchronize with PC
using Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
T
taking photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
task manager . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9, 2-13
task tray icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
technical specifications . . . . . . . . . . . . . . . . . . . . . . . A-1
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
charging . . . . . . . . . . . . . . . . . . . . . . . . 1-7, 8-5, 8-10
text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
three-way call . . . . . . . . . . . . . . . . . . . . . . . . . 4-17, 4-19
Time To First Fix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
today . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Today Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
toolbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Adobe Reader . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Streaming Player . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Voice Commander . . . . . . . . . . . . . . . . . . . . . . . 2-10
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
U
unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
up and down button . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
up and down key . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
USB rapid charge cable . . . . . . . . . . . . . . . . . . . 8-1, 8-3
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
using Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . 4-3
using stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
V
vehicle charge cradle . . . . . . . . . . . . . . . . . . 1-6, 8-1, 8-6
Index - 6 MC45 User Guide
videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
viewing photos and videos . . . . . . . . . . . . . . . . . . . 2-23
Voice Commander . . . . . . . . . . . . . . . . . . . . . .2-10, 4-24
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
W
wakeup conditions . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
waking the MC45 . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
WAN icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Windows Live . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Windows Live Messenger . . . . . . . . . . . . . . . . . . . . . 2-9
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-10, 4-2
wireless companion . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
wireless connection status
icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Wireless Manager . . . . . . . . . . . . . . . . . . . . . . .1-10, 4-2
wireless manager . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Wireless Zero Config . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
802.11a/b/g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
WWAN
GSM/HSDPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
