ANCHOR AUDIO
662
SOUND REINFORCEMENT
XTREME & LIBERTY SOUND SYSTEMS
AC- and DC-Powered
Portable Sound Systems
With a built-in CD player and up to three built-in Anchor Wireless UHF
Receivers, the Xtreme and Liberty expands their capabilities beyond any other
system in the industry.
An AC-powered sound system, the 130-watt Xtreme delivers a powerful 123dB
of crystal clear speech projection—enough to reach crowds of up to 2,500 people.
The 50-watt Liberty is a DC-powered system that delivers 117dB of clear sound
to crowds of 1000 or more.
With the convenience of a built-in CD player and a wireless microphone, the
Xtreme is great for large indoor and outdoor events such as press conferences,
sports events, graduation ceremonies, musical productions or any other settings
needing powerful and clear voice or music amplification. Rugged, reliable and
crystal clear, Liberty is used at the White House for Presidential press conferences,
at thousands of schools around the world, at corporate training centers and on many U.S. aircraft carriers.
Xtreme
◆
Clear and powerful sound, thanks to an 8˝ woofer and
constant-directivity horn inside a ported enclosure.
◆
Delivers up to 123 dB of clear sound
◆
Handles crowds of 2,500 or more.
◆
Biamplified; separate high and low frequency amplifiers for enhanced
performance.
Liberty
◆
Comes with a hassle-free 6-year warranty.
◆
Tough, injection-molded case is remarkably durable
◆
8˝ woofer and titanium dome compression driver in tuned enclosure
◆
Features lead-acid batteries and a built-in charger
◆
Handles crowds of 1,000 people or more
External speaker output powers optional companion speaker
◆
Active limiter—keeps sound clean even when driven hard.
◆
◆
The XLR input allows the use of line level or microphone sources,
with or without condenser mic power
◆
Integrated circuit amplifier with short circuit and thermal overload
protection
◆
Line-level, balanced output supplies signal to additional sound system
◆
◆
Neutrik Speakon connector for use with XTR-6001
Speech projection mode (on/off selectable) provides crystal-clear
voice projection
◆
Bass and treble controls
◆
Speech projection mode provides crystal-clear voice projection
◆
Comes with a hassle-free 6-year warranty
XBP-6000 Xtreme Basic Package:
Includes Xtreme XTR-6000CU1 sound system, built-in CD player and
built-in Anchor Wireless UHF with16-user selectable channels, speaker
stand (SS-550) and choice of wireless mic: handheld mic (WH-3000) or
body-pack transmitter (WB-3000) and headband mic (HBM-3000) or
lapel mic (LM-3000) or collar mic (CM-3000)
XDP-6000 Xtreme Deluxe 2-Speaker Package:
Includes Xtreme XTR-6000CU1 sound system, built-in CD player and
built-in Anchor Wireless UHF with16-user selectable channels,
unpowered companion speaker (XTR-6001) two speaker stands (SS550), 50’ cable connection (SC-50NL) and choice of wireless mic: handheld mic (WH-3000) or body-pack transmitter (WB-3000) and headband mic (HBM-3000) or lapel mic (LM-3000) or collar mic (CM-3000)
PHOTO - VIDEO - PRO AUDIO
www.bhphotovideo.com
XDP-6000
Xtreme Deluxe
2-Speaker Package
ANCHOR AUDIO
EXPLORER SOUND SYSTEMS
Explorer is a favorite of audio rental companies and hotels for a quick setup in a
conference room. Weighing 20 lbs. this sound system has also traveled the world
with missionaries and aboard cruise ships. Delivers a great balance of speech clarity and music fidelity. (A battery-powered model is also available.)
Heavy-duty amp and full-range speaker
system deliver fidelity sound
◆ 6.5˝ woofer coupled with a high-output
horn tweeter
◆ Simple to set up and operate
◆
Durable injection-molded polypropylene case
Short circuit and thermal overload protection
◆ Weighs less than 20 pounds
◆ Speaker output to power companion speakers
◆ Comes with a 6-year warranty
◆
◆
EBP-2500 Explorer Basic Package:
Includes Explorer PA-2500W sound system, (SS-550) speaker stand
and choice of wireless mic: (WH-58) Shure handheld mic or (WB-II)
body-pack transmitter and (HBM-60) headband mic or lapel mic
(LM-60) or collar mic (CM-1000).
EDP-2500 Explorer Deluxe Package:
Includes Explorer PA-2500W sound system, Explorer P-2501 companion
speaker, two (SS-550) speaker stands and choice of wireless mic:
(WH-58) Shure handheld mic or (WB-II) body-pack transmitter and
(HBM-60) headband or lapel mic (LM-60) or collar mic (CM-1000).
Injection-molded case
High-efficiency re-entrant
horn driver
◆ Speaker output powers
optional companion speaker
◆ Built-in wireless
microphone receiver
◆
◆
Powerful amplifier and horn
driver combine for 126 db output
◆ Runs up to 10 hours on a charge
◆ Speaker stand receptacle molded
into bottom
◆ 6-year warranty
◆
MEGA-BP MegaVox Basic Package: Includes MegaVox with built-in
2-channel selectable wireless receiver, (SS-550) speaker stand and
choice of wireless mic: (WH-1000) handheld mic or (WL-1000) bodypack transmitter and (HBM-40) headband mic
MEGA-DP MegaVox Deluxe Package: Includes MegaVox with built-in
2-channel selectable wireless receiver, MegaVox P-351 unpowered
companion speaker, (SC-50) 50" cable connector and two (SS-550)
speaker stands and choice of wireless mic: (WH-1000) handheld mic
or (WL-1000) body-pack transmitter and (HBM-40) headband mic.
AN-100 packages are
the perfect choice for
classrooms small
conference rooms and
corporate road
warriors who rely on
their sound systems
to command the
audience. Plus, it’s the
perfect companion
for a video projector.
The AN-100 produces
such accurate sound that it is used by movie studios to hear their mix
on the master sound tracks. Weighing in at just 8.5 lbs. this powerful
sound system is designed for audiences up to 100 people.
25 watt amplifier
◆ Durable injection-molded case
provides lots of sound.
◆ 6 year warranty
◆ 2-way speaker system
◆ Magnetically shielded speaker.
combines 4.5˝ woofer
◆ Has mic, instrument & 2 line inputs
and dome tweeter
◆ Built-in two selectable channels RF wireless receiver
◆
AN-100:
AN-100 all by itself with nothing else. Just plug in a microphone or
the video projector cables, and you’re ready to go.
AN-100BP AN-100 Basic Package:
Includes AN-100 Wireless VHF Receiver and choice of wireless mic:
(WH-1000) handheld mic or (WL-1000) body-pack transmitter and
(HBM-40) headband mic
