D C T 2 0 0 0
D i g i t a l C o n s u m e r T e r m i n a l
I n s t a l l a t i o n M a n u a l
GUIDE
CURSOR MESSAGES
A/B
INFO
MENU SELECT
REMOTE
POWER
A/B
CHANNEL
POWER
Graphical symbols and supplement warning marking locations on the bottom of the appliance.
This symbol indicates that dangerous voltage levels are present within the equipment. These voltages are not insulated and may be of sufficient strength to cause serious bodily injury when touched. The symbol may also appear on schematics.
This symbol calls attention to a critical procedure, or means refer to the instruction manual for opening or service information. Only qualified service personnel are to install or service the equipment. The symbol may also appear in text and on schematics.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRICAL SHOCK, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
FCC Compliance: Federal Communications Commission Radio and Television Interface Statement for a Class ‘B’ Device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in the residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:
Increase the separation between the equipment and the affected receiver
Connect the equipment on a circuit different from the one the receiver is on
Ensure that the cover plate for the security card is secured and tight
You may find the following booklet, prepared by the Federal Communication Commission, helpful: How to Identify and Resolve Radio-TV
Interference Problems, Stock No. 004-000-0342-4, U.S. Government Printing Office, Washington, DC 20402.
Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Declaration of Conformity: According to 47 CFR, Parts 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and
Power Supplies used with Class B Personal Computers, Motorola, Inc., 6450 Sequence Drive, San Diego, CA 92121, 1-800-225-9446, declares under sole responsibility that the product identifies with 47 CFR Part 2 and 15 of the FCC Rules as a Class B digital device. Each product marketed is identical to the representative unit tested and founded to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47 CFR 2.909. Operation is subject to the following condition: This device must accept any interference received, including interference that may cause undesired operation. The above named party is responsible for ensuring that the equipment complies with the standards of 47 CFR, Paragraphs 15.107 to 15.109
FCC Part 68 Statement: This equipment complies with part 68 of the FCC rules. On the rear panel of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for the equipment. If requested, this information must be provided to the telephone company.
The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the maximum REN for the calling area.
This equipment uses the following USOC jack: RJC. An FCC-compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected to the telephone network or premises wiring using a compatible modular jack that is Part 68 compliant. This equipment cannot be used on telephone company-provided coin services. Connection to Party Line Service is subject to state tariffs.
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that the temporary discontinuance of services may be required. If advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a compliant with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order to maintain uninterrupted service.
If the trouble is causing harm to the telephone system, the telephone company may request that you remove the equipment from the network until the problem is resolved.
It is recommended that the customer install an AC surge arrestor in the AC outlet to which this device is connected. This is to avoid damaging the equipment by local lightning strikes and other electrical surges.
Canadian Compliance: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respects toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Industry Canada CS-03 Statement: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The department does not guarantee that the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions might not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier. Repairs or alterations made by the user to this equipment, or equipment malfunctions may give the telecommunication company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
The Ringer Equivalence Number (REN) of this device is 0.4. The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all devices does not exceed 5. The telephone connection arrangement is a CA11A.
Repairs: If repair is necessary, call the Motorola Repair Facility at 1-800-227-0450 for a Return for Service Authorization (RSA) number before sending the unit. The RSA number must be prominently displayed on all equipment cartons. Pack the unit securely; enclose a note describing the exact problem, and a copy of the invoice that verifies the warranty status. Ship the unit PRE-PAID to the following address:
Motorola, Inc.
Attn: RSA #___________ c/o Rudolph Miles and Sons
2500 Courage Boulevard
Brownsville, TX 78521
NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close as possible to the point of cable entry as practical.
Copyright © 2001 by Motorola, Inc.
All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc.
Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Motorola may make improvements or changes in the product(s) described in this manual at any time.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. STARVUE and STARFONE are registered trademarks of Motorola, Inc.
C o n t e n t s
Section 1
I n t r o d u c t i o n
Features, Options, and Interfaces................................................................................................................1-1
Using This Manual .......................................................................................................................................1-2
Related Documentation................................................................................................................................1-3
Document Conventions................................................................................................................................1-3
If You Need Help ..........................................................................................................................................1-4
Calling for Repairs.......................................................................................................................................1-4
Section 2
O v e r v i e w
Front Panel ..................................................................................................................................................2-1
Rear Panel ...................................................................................................................................................2-3
Options ........................................................................................................................................................2-5
Remote Controls ..........................................................................................................................................2-7
DRC 400 Remote Control........................................................................................................................2-7
Installing Batteries in Remote Control .....................................................................................................2-9
Section 3
I n s t a l l a t i o n
Before You Begin .........................................................................................................................................3-1
Installing the DCT2000 .................................................................................................................................3-1
Standard Cabling Diagram ...........................................................................................................................3-2
STARFONE module cabling diagram............................................................................................................3-3
Standard VCR Cabling Diagram ...................................................................................................................3-4
RF Bypass Switch VCR Cabling Diagrams ...................................................................................................3-5
A/B In Module Cabling Diagrams .................................................................................................................3-7
Dual A/B-RF Bypass Module Cabling Diagrams ...........................................................................................3-9
Composite Baseband and S-Video Cabling Diagrams ................................................................................3-11
Stereo Cabling Diagram (Baseband) ..........................................................................................................3-13
Dolby Digital Cabling Diagrams .................................................................................................................3-16
Operational Check .....................................................................................................................................3-19
DCT 20 0 0 In s ta ll at io n Man u al
i i C o n t e n t s
Section 4
A d d i n g t h e I R B l a s t e r O p t i o n
Locating the IR Receiver on the VCR...........................................................................................................4-1
Installing the IR Blaster ...............................................................................................................................4-2
Checking the Installation.............................................................................................................................4-2
Section 5
T r o u b l e s h o o t i n g
Appendi x A
S p e c i f i c a t i o n s
Appendi x B
D i a g n o s t i c s
Accessing Diagnostics ............................................................................................................................... B-1
Navigating the Diagnostics......................................................................................................................... B-2 d 01: DCT2000 General Status .............................................................................................................. B-4 d 02: Out-Of-Band (OOB) Status ............................................................................................................ B-7
Data Activity and EMM Data Activity Indicators ................................................................ B-8
Selecting the OOB Frequency ........................................................................................... B-8
Agile Enabled DCT2000 Operation Notes ......................................................................... B-9 d 03: In-Band Status.............................................................................................................................B-10
Data Activity Indicator − LED and OSD ........................................................................... B-11
EMM Data Activity Indicator − LED and OSD................................................................... B-11
Carrier Lock − LED and OSD........................................................................................... B-11
Program-Clock-Reference (PCR) Lock − OSD Only........................................................... B-11
Signal-To-Noise Ratio (SNR) − OSD Only......................................................................... B-12
Modulation Mode ........................................................................................................... B-12
Short Term Error Count .................................................................................................. B-12
Long Term Error Count ................................................................................................... B-12
Tuned Frequency ........................................................................................................... B-12 d 04: Audio/Video Status ......................................................................................................................B-13 d 05: Unit Address................................................................................................................................B-15 d 06: Firmware Version.........................................................................................................................B-17 d 07: Current Channel Status ................................................................................................................B-18
LED Channel Types ........................................................................................................ B-18
Acquisition State ........................................................................................................... B-19
Purchasable Indicator − LED and OSD ........................................................................... B-19
Preview Indicator − LED and OSD................................................................................... B-19
DCT 20 0 0 In s ta ll at io n Man u al
C o n t e n t s i i i
Parental Control - LED and OSD .....................................................................................B-20
Mute Status ...................................................................................................................B-20
Current Channel Status - OSD ........................................................................................B-20
Current Channel Status − OSD fields ..............................................................................B-22 d 08: Renewable Security System ........................................................................................................ B-23
TVPC Required − LED and OSD .......................................................................................B-24
Crypto Mode...................................................................................................................B-24
Status ............................................................................................................................B-24
Version ..........................................................................................................................B-24 d 09: Upstream Modem Status ............................................................................................................. B-25
STARVUE II (RF) Diagnostics ...........................................................................................B-25
STARFONE Diagnostics ...................................................................................................B-27 d 10: Application (APP) Code Modules ................................................................................................. B-31
Status Modes .................................................................................................................B-32 d 11: Memory Config ........................................................................................................................... B-33 d 12: Interactive Info ........................................................................................................................... B-34
State ..............................................................................................................................B-34
Socket Port State ...........................................................................................................B-35 d 13: MAC Frequency Table ................................................................................................................. B-35 d 14: Message Types........................................................................................................................... B-35 d 15: In Band Program Association Table (PAT).................................................................................... B-36 d 16: In Band Program Map Table (PMT) .............................................................................................. B-36 d 17: Task Status ................................................................................................................................ B-36 d 18: Keyboard/LED ............................................................................................................................ B-37
A b b r e v i a t i o n s a n d A c r o n y m s
F i g u r e s
Figure 1-1 DCT2000 advanced set-top terminal ..........................................................................................1-2
Figure 2-1 DCT2000 front panel ..................................................................................................................2-1
Figure 2-2 DCT2000 rear panel....................................................................................................................2-3
Figure 2-3 DCT2000 options........................................................................................................................2-5
Figure 2-4 DRC 400 remote control .............................................................................................................2-7
Figure 2-5 Back view of remote control ......................................................................................................2-9
Figure 3-1 Standard cabling........................................................................................................................3-2
Figure 3-2 Standard wiring with a STARFONE module................................................................................3-3
Figure 3-3 Standard VCR cabling................................................................................................................3-4
Figure 3-4 RF Bypass switch with VCR (STARFONE return module installed) ............................................3-5
Figure 3-5 Cabling with RF Bypass module (using RF return) ....................................................................3-6
Figure 3-6 A/B In module with a STARFONE module ..................................................................................3-7
DCT 20 0 0 In s ta ll at io n Man u al
i v C o n t e n t s
Figure 3-7 A/B In module with return on Cable A .......................................................................................3-7
Figure 3-8 A/B In module with return on Cable B .......................................................................................3-8
Figure 3-9 Return on STARFONE module ...................................................................................................3-9
Figure 3-10 Return on Cable A.................................................................................................................. 3-10
Figure 3-11 Return on Cable B.................................................................................................................. 3-10
Figure 3-12 Standard baseband cabling ................................................................................................... 3-11
Figure 3-13 Composite VCR cabling ......................................................................................................... 3-12
Figure 3-14 Audio on the VCR .................................................................................................................. 3-13
Figure 3-15 Audio on VCR/audio output on TV ......................................................................................... 3-14
Figure 3-16 CD player cabling .................................................................................................................. 3-15
Figure 3-17 Audio through Stereo Receiver.............................................................................................. 3-17
Figure 3-18 Dolby 5.1 optical output......................................................................................................... 3-18
Figure 4-1 IR transmitter installed in mounting bracket .............................................................................4-1
Figure 4-2 IR Blaster installed ....................................................................................................................4-2
Figure B-1 Diagnostics main menu −−−− OSD................................................................................................. B-2
Figure B-2 DCT2000 General Status −−−− LED ................................................................................................ B-4
Figure B-3 DCT2000 Status −−−− OSD............................................................................................................. B-5
Figure B-4 Out-Of-Band Status −−−− LED ....................................................................................................... B-7
Figure B-5 OOB Diagnostic Status −−−− OSD ................................................................................................. B-7
Figure B-6 In-Band Status −−−− LED............................................................................................................. B-10
Figure B-7 In-Band Diagnostic −−−− OSD ..................................................................................................... B-10
Figure B-8 Audio/Video Status - OSD ...................................................................................................... B-13
Figure B-9 Unit address - LED ................................................................................................................. B-15
Figure B-10 Unit Address - OSD .............................................................................................................. B-16
Figure B-11 Dena firmware version - LED ................................................................................................ B-17
Figure B-12 Firmware Version - OSD ....................................................................................................... B-17
Figure B-13 Current Channel Status - LED .............................................................................................. B-18
Figure B-14 Current Channel Status - OSD .............................................................................................. B-21
Figure B-15 Renewable Security Status - LED ......................................................................................... B-23
Figure B-16 Renewable Security −−−− OSD................................................................................................... B-23
Figure B-17 STARVUE II diagnostics LED................................................................................................ B-25
Figure B-18 STARVUE II Diagnostic - OSD .............................................................................................. B-25
Figure B-19 STARFONE diagnostics - LED .............................................................................................. B-27
Figure B-20 STARFONE Diagnostic - OSD ............................................................................................... B-28
Figure B-21 Application code module - LED ............................................................................................ B-31
Figure B-22 APP Code Modules – OSDs .................................................................................................. B-32
Figure B-23 Memory Status OSD ............................................................................................................. B-33
Figure B-24 Interactive Info menu - OSD ................................................................................................. B-34
DCT 20 0 0 In s ta ll at io n Man u al
C o n t e n t s v
Figure B-25 Mac Frequency Table - OSD ................................................................................................. B-36
Figure B-26 Message Types - OSD ........................................................................................................... B-36
Figure B-27 In Band PAT - OSD ............................................................................................................... B-36
Figure B-28 In Band PMT – OSD .............................................................................................................. B-37
Figure B-29 Task Status - OSD ................................................................................................................ B-37
Figure B-30 Keyboard diagnostic −−−− OSD ................................................................................................. B-37
DCT 20 0 0 In s ta ll at io n Man u al
v i C o n t e n t s
T a b l e s
Table 2-1 Front panel ..................................................................................................................................2-2
Table 2-2 Rear panel ...................................................................................................................................2-3
Table 2-3 Options .......................................................................................................................................2-5
Table 2-4 Remote control keys ...................................................................................................................2-8
Table 3-1 Audio port functionality ............................................................................................................ 3-16
Table 3-2 Operational check ..................................................................................................................... 3-19
Table 5-1 Troubleshooting guidelines ........................................................................................................5-1
Table B-1 Operational keys using the diagnostics main menu or submenus ............................................ B-2
Table B-2 Diagnostic ................................................................................................................................. B-3
Table B-3 Error codes ................................................................................................................................ B-5
Table B-4 LED and OSD indicators for out-of-band control channel ......................................................... B-8
Table B-5 Out-of-band EMM data activity indicator −−−− LED and OSD .......................................................... B-8
Table B-6 Data activity indicator −−−− LED and OSD .................................................................................... B-11
Table B-7 EMM data activity indicator −−−− LED and OSD ............................................................................ B-11
Table B-8 In-band carrier lock −−−− LED and OSD........................................................................................ B-11
Table B-9 SNR indicators −−−− OSD only...................................................................................................... B-12
Table B-10 Modulation Mode ................................................................................................................... B-12
Table B-11 Audio Video Status ................................................................................................................ B-13
Table B-12 Channel Types −−−− LED and OSD.............................................................................................. B-18
Table B-13 Acquisition state.................................................................................................................... B-19
Table B-14 Purchasable status −−−− LED and OSD....................................................................................... B-19
Table B-15 Preview status −−−− LED and OSD .............................................................................................. B-19
Table B-16 Parental Control –LED and OSD ............................................................................................ B-20
Table B-17 Mute –LED and OSD ............................................................................................................... B-20
Table B-18 Current channel status −−−− OSD fields ..................................................................................... B-22
Table B-19 TVPC required........................................................................................................................ B-24
Table B-20 Crypto mode .......................................................................................................................... B-24
Table B-21 TVPC status ........................................................................................................................... B-24
Table B-22 STARVUE II transmitter status ............................................................................................... B-26
Table B-23 STARVUE II IPPV status ......................................................................................................... B-26
Table B-24 STARFONE fourth-digit parameter status .............................................................................. B-28
Table B-25 STARFONE third-digit baud rate ............................................................................................ B-29
Table B-26 STARFONE transmitter status................................................................................................ B-29
Table B-27 STARFONE hang-up code ...................................................................................................... B-30
Table B-28 First LED indicating current status of download ................................................................... B-31
DCT 20 0 0 In s ta ll at io n Man u al
Section 1
I n t r o d u c t i o n
The Motorola DCT2000 is an analog/digital terminal designed to support 64 and 256 QAM digital signal formats, and it can be configured to support analog descrambling.
The DCT2000 is compatible with existing Motorola analog and digital set-top terminal products.
Existing set-top terminals are not affected by the new data flowing from the system to the
DCT2000s.
This manual provides instructions to install the DCT2000.
F e a t u r e s , O p t i o n s , a n d I n t e r f a c e s
The Motorola DCT2000 offers the following standard features:
54 through 860 MHz integrated tuner
Integrated RF return (using built-in STARVUE II module)
RF and baseband audio/ video ports
Single IR Blaster port (replaces two connectors on DCT 1000/1200 series)
Auxiliary audio input
Switched accessory outlet
RS 232 serial data port (provides a high speed serial data interface)
Optional features include:
STARFONE II (14.4 kbps) Telco return
A/B In switch
RF Bypass switch
Dual A/B-RF Bypass switch
IR Blaster cable
S-Video output
Dolby
AC-3
audio output (SPDIF Interface)
Optical Dolby
AC-3
audio output
DCT 2000 Installation Manual
1 - 2 I n t r o d u c t i o n
Figure 1-1 illustrates front and rear views of the DCT2000:
Figure 1-1
DCT2000 advanced set-top terminal
GUIDE
CURSOR
MESSAGES
A/B
INFO
MENU SELECT
REMOTE
POWER
A/B
CHANNEL
POWER
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN COAX
Digital Audio
Optical
R L
AUDIO OU T
VIDEO
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
U s i n g T h i s M a n u a l
This manual provides instructions to install and configure a DCT2000:
Section 1
Section 2
Section 3
Section 4
Section 5
Appendix A
Appendix B
Abbreviations and Acronyms
Introduction provides a product description, a list of related documentation, the technical helpline telephone number, and the repair/return procedure.
Overview describes the DCT2000 terminal and provides an overview of its use. This section also identifies the front-panel displays and switches and describes the rear-panel features.
Installation provides instructions on how to install the DCT2000 in a subscriber location and perform operational tests.
Adding the IR Blaster Option provides instructions on how to install the IR Blaster option for controlling VCR recording through the DCT2000.
Troubleshooting provides guidelines for troubleshooting the equipment.
Specifications provide the technical specifications for the DCT2000.
Diagnostics provide instructions on accessing and interpreting the built-in diagnostics.
The Abbreviations and Acronyms list contains the full spelling of the short forms used in this manual.
DCT 2000 Installation Manual
R e l a t e d D o c u m e n t a t i o n
Separate instruction manuals are available for associated components. Although these may be useful, they are not necessary to install or operate the basic DCT2000:
DCT2000 User Guide
DCT 1000 Cable Terminal Installation Manual
DRC 425 Remote Control User Guide
DRC 400 Remote Control User Guide
DCT External Add-On Modules Installation Sheet
STARFONE 2 Installation Sheet
D o c u m e n t C o n v e n t i o n s
Before you begin working with this manual and using the DCT2000, familiarize yourself with the stylistic conventions used in this manual:
SMALL CAPS
*
(asterisk)
Denotes silk screening on the equipment, typically representing front- and rear-panel controls, input/output (I/O) connections, and LEDs
Indicates that several versions of the same model number exist and the information applies to all models; when the information applies to a specific model, the complete model number is given
Italic type Used for emphasis
Courier font
Displayed text
DCT 2000 Installation Manual
1 - 4 I n t r o d u c t i o n
I f Y o u N e e d H e l p
If you need assistance while working with the DCT2000, contact the Motorola Technical
Response Center (TRC):
Inside the U.S.: 1-888-944-HELP (1-888-944-4357)
Outside the U.S.: 215-323-0044
Online: http://www.motorola.com/broadband , click HTML/Modem Version, click
Customer Support, then click Web Support.
The TRC is open from 8:00 AM to 7:00 PM Eastern Time, Monday through Friday and 10 AM to
6 PM Eastern Time, Saturday. When the TRC is closed, emergency service only is available on a call-back basis. Web Support offers a searchable solutions database, technical documentation, and low priority issue creation/tracking 24 hours per day, 7 days per week. Web Support is available after registering.
C a l l i n g f o r R e p a i r s
If repair is necessary, call the Motorola Repair Facility at 1-800-227-0450 for a Return for
Service Authorization (RSA) number before sending the unit. The RSA number must be prominently displayed on all equipment cartons. The Repair Facility is open from 8:00 AM to
5:00 PM Central Time, Monday through Friday.
When calling from outside the United States, use the appropriate international access code and then call 956-541-0600 to contact the Repair Facility.
When shipping equipment for repair, follow these steps:
1
2
Pack the unit securely.
Enclose a note describing the exact problem. Complete and enclose the checklist provided with the unit.
3 Enclose a copy of the invoice that verifies the warranty status.
Ship the unit PREPAID to the following address:
Motorola, Inc.
Broadband Communications Sector
Attn: RSA #___________ c/o Rudolph Miles and Sons
25 00 Courage Boulevard
Brownsville, TX 78521
DCT 2000 Installation Manual
Section 2
O v e r v i e w
The DCT2000 uses state-of-the-art digital compression technology to provide new revenue generating services. The DCT2000 can be configured to support real time reverse path communications, providing a gateway to interactive services such as Video on Demand (VOD),
Internet access, Email, home shopping, and more.
This section provides illustrations and tables showing the DCT2000 controls, displays and connectors. Before you begin to install the DCT2000, familiarize yourself with the various controls and displays.
F r o n t P a n e l
Figure 2-1 illustrates the front panel, which contains selection keys, tuning keys, various displays, and the power switch:
Figure 2-1
DCT2000 front panel
1 2 3 4 5
GUIDE
CURSOR
MESSAGES
A/B
INFO
MENU SELECT
REMOTE
POWER
A/B
CHANNEL
POWER
6 7 8 9 10 11 12 13
These controls provide minimum, yet functional capability in the event the remote control is lost or temporarily out of service. Functions requiring a numeric entry are not available without a remote control.
DCT 2000 Installation Manual
2 - 2 O v e r v i e w
8
9
10
11
12
Table 2-1 describes the front-panel controls and LEDs:
Table 2-1
Front panel
Key Feature Function
4
5
6
1
2
3
A/B
MESSAGES
GUIDE
REMOTE
POWER
Lights if optional switch is activated
Lights to indicate that a message is present
Normally displays current channel number or time of day; in the diagnostic mode, displays diagnostic codes
Flashes when an error-free signal is received from the remote control
Lights when the unit is on
Displays the electronic program guide (EPG)
7 CURSOR Moves the cursor in menu and program guide screens
INFO
MENU
SELEC T
A/B
CHANNEL
Displays current channel and program information
Displays the Main menu
Selects function options and Pay-Per-View (PPV) events and tunes channels from the electronic program guide
When enabled, this switches an add-on module from one function to another function
Changes channel up and down
13
POW ER
Turns DCT2000 on/off
DCT 2000 Installation Manual
O v e r v i e w 2 - 3
R e a r P a n e l
Figure 2-2 illustrates the rear panel of the DCT2000, which contains a switched power outlet; connectors for video, audio, and RF cabling; data output connectors; and IR Blaster output connector:
Figure 2-2
DCT2000 rear panel
1 2 3 4 5 6
5
6
7
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN COAX
Digital Audio
Optical
R L
AUDIO OUT
VIDEO
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
7 8 9 10 11 12 13 14 15
A protective plate covers the rear panel opening when the optional Telco return is not installed.
Do not remove the protective plate unless you are installing new hardware in the opening.
Table 2-2 describes each of the rear-panel features:
Table 2-2
Rear panel
Key Item Function
1 TO
TV/VCR
F-type connector used to connect the DCT2000 to a standard TV or
VCR
2 F-type connector used for DCT2000 input from the TO RF IN connector
RF
IN
3
4
TO RF IN
F-type connector used to connect the
TO RF IN
port to the
RF IN
port
(output from integrated RF return)
Covers slot used for STARFONE option
AUX AUDIO IN
SPDIF
CABLE IN
RCA jacks for looping through audio from auxiliary audio equipment
Option to enhance your DCT2000; see, “Options” for more information
F-type connector used for the coaxial cable input port from plant (input to integrated RF return)
DCT 2000 Installation Manual
2 - 4 O v e r v i e w
Key Item Function
8 Left and right audio RCA jacks used for stereo audio output
9
10
R L
AUDIO OUT
VIDEO
TV Pass Card
RCA jack used to connect the DCT2000 to a composite (baseband) video TV or a monitor; in some configurations this jack connects to a
VCR
Cover for an area reserved for future use
11 Optical An optional optical connector that provides Dolby Digital or PCM audio.
12
13
14
S-VIDEO
IR
Data connector to interface serial data and access the high speed serial interface for high definition decoding
Option to enhance your DCT2000; see, “Options” for more information
Mini-phone jack for connecting an optional IR Blaster
15 AC power outlet that can be configured as a switched or unswitched outlet and the two-pronged plug is for attaching a power cord
DCT 2000 Installation Manual
O v e r v i e w 2 - 5
O p t i o n s
The DCT2000 supports a variety of options enabling your company to offer a system tailored to the individual needs of your subscribers. Figure 2-3 illustrates the options available for the
DCT2000:
Figure 2-3
DCT2000 options
1 2
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN COAX
Digital Audio
Optical
R L
AUDIO OUT
VIDEO
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
A
CABLE IN
A
B
3
RF
OUT
4
CONV
IN
RF OUT
5
B
PHONE
6 7
Table 2-3 describes the function of each of the options shown in Figure 2-3:
Table 2-3
Options
Key Option Name Function
1
2
SPDIF SPDIF Used to deliver Dolby Digital 5.1, Dolby AC3 audio, or
PCM audio (digital audio recording)
Used for high quality video to external devices such as high-end VCRs or TVs
S-VIDEO
S-VIDEO
3
CABLE IN
A
A/B In Used in a dual cable system to receive both cables; verify the location of the A and B connectors on your particular A/B In module
B
4
RF
OUT
RF
IN
CONV
IN
RF Bypass Enables the cable signal to bypass the DCT2000 and go directly to a TV or VCR
DCT 2000 Installation Manual
2 - 6 O v e r v i e w
Key Option Name Function
5
RF OUT
A
Dual A/B
RF Bypass
Used in a dual cable system; enables the cable signal on the current side (A or B) to go directly to a TV or
VCR
B
6 STARFONE
7
PHONE
Optical Optical
Used in a two-way addressable system to send
Impulse Pay-Per-View (IPPV) information to the
DAC 6000 or other controller through the subscriber’s telephone hookup
Used to deliver Dolby Digital or PCM audio through an optical connector to an A/V receiver.
DCT 2000 Installation Manual
O v e r v i e w 2 - 7
R e m o t e C o n t r o l s
The basic DCT2000 uses the DRC 400 remote control. If your system offers optional interactive applications, such as an interactive program guide, a different remote control may be required.
The application provider should supply user instructions for each interactive application.
DRC 400 Remote Control
Figure 2-4 illustrates the DRC 400:
Figure 2-4
DRC 400 remote control
1
2
3
4
5
6
7
8
9
10
11
12
13
AUX
VCR CABLE
TV
HELP
PAGE
POWER
LOCK PAGE
EXIT INFO
OK
MENU
VOLUME LAST CHANNEL
FAVORITE
A
1
B
2
C
3
4 5 6
7
TV/VCR
DAY
STOP
REW
8
0
PAUSE
RECORD
9
ENTER
DAY
PLAY
F.FWD
15
16
17
18
19
20
21
22
14
DCT 2000 Installation Manual
2 - 8 O v e r v i e w
Table 2-4 describes the remote control keys:
Table 2-4
Remote control keys
Key Item Description
1 AUX, VCR, CABLE, or
TV
Selects a desired device to control. The selected mode will remain active until you press another device key.
6
9
10
VOLUME + or
VOLUME -
A, B, or C
▼ Pages through menu screens and the program guide.
Moves the cursor around the program guide and menu screens. program guide. Your remote may only have OK; this key still performs the same functions.
Increases or decreases the volume of the currently selected device.
Functionality is determined from services offered by the service provider.
13
14
BYPASS
◄ Day
Day ►
STOP, PAUSE, PLAY,
REW,
RECORD, F.FWD function to operate.
Moves the program guide ahead or back 24 hours.
Controls the VCR.
Pay-Per-View menu. Your remote may have only LOCK; this key still performs the same functions. all applications).
20 CHANNEL + or - Changes the channels by moving up or down. enter channels.
DCT 2000 Installation Manual
O v e r v i e w 2 - 9
Installing Batteries in Remote Control
Before using the remote control, you must install two AA (1.5 V) alkaline batteries. Figure 2-5 illustrates battery access on the back of the remote control.
2
3
To install batteries in an DRC 400:
1 Press and slide the battery compartment cover off.
Place the batteries in the compartment; be careful to observe the correct polarity.
Slide the battery compartment cover back into place.
Battery installation will vary with each style of remote control. Refer to the instructions included with your remote control for installing batteries.
Figure 2-5
Back view of remote control
+
+
DCT 2000 Installation Manual
Section 3
I n s t a l l a t i o n
This section provides instructions for installing and cabling the DCT2000. To complete the installation, you must:
Connect the cables
Supply power to equipment
Download configuration information and software
Run operational check and diagnostics
B e f o r e Y o u B e g i n
Before you begin, review the installation instructions, gather the required items, and complete the tasks listed below:
Determine if the subscriber’s system requirements include an A/B In, RF Bypass, Dual
A/B-RF Bypass module, or a STARFONE module. These options can be installed before leaving the office. Installation instructions are provided with these modules.
Verify that you have 75-ohm coaxial cables with F-type connectors and RCA baseband phono-type cables.
Determine if you are connecting the DCT2000 to a standard TV or a composite (baseband) monitor.
Place the DCT2000 on a smooth, flat surface and remove any obstructions that could interfere with the free flow of air over, under, or around it. Advise the subscriber not to place anything on top of the unit.
I n s t a l l i n g t h e D C T 2 0 0 0
3
4
5
To install the DCT2000:
1 If an add-on module is required and it was not previously installed, do that now. When installed, verify that the appropriate configuration information has been downloaded via the access control system.
2 Determine if you are connecting the DCT2000 to a conventional TV or to a monitor. To install the video connection:
For a conventional TV, use a 75-ohm coaxial cable with F-type connectors.
For a monitor, use an RCA phono cable to connect the
VIDEO connector to the monitor.
Locate the cabling diagram that matches the subscriber’s configuration requirement.
Connect the cables as illustrated in the diagram.
Perform the basic operational check in this section after the DCT2000 is installed.
DCT 2000 Installation Manual
3 - 2 I n s t a l l a t i o n
S t a n d a r d C a b l i n g D i a g r a m
The DCT2000 will output on either channel 3 or 4 depending on the configuration message from the control system. Figure 3-1 illustrates a standard diagram connecting the DCT2000 to a TV using RF connectors:
Figure 3-1
Standard cabling
DCT2000
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
From cable outlet
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
The remodulated channel, 3 or 4, does not carry stereo for digital channels. Connect the
DCT2000 using RCA baseband connectors to receive stereo on digital channels. These connections are illustrated later in this section.
DCT 2000 Installation Manual
S T A R F O N E m o d u l e c a b l i n g d i a g r a m
Figure 3-2 illustrates the RF wiring diagram for the DCT2000 when it has a telephone return modem:
Figure 3-2
Standard wiring with a STARFONE module
DCT2000
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN SPDIF
Optical
PHONE
R L
AUDIO OUT
VIDEO
Subscriber telephone hookup
From cable outlet
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
For service providers planning to implement RF return capabilities, it is recommended the
DCT2000 be wired for both the STARFONE telephone return and the integrated STARVUE
RF return. This enables the operator to move the DCT2000 into a two-way RF return without rewiring the DCT2000 later.
DCT 2000 Installation Manual
3 - 4 I n s t a l l a t i o n
S t a n d a r d V C R C a b l i n g D i a g r a m
Figure 3-3 illustrates the basic cabling diagram that enables you to record the channel being viewed:
Figure 3-3
Standard VCR cabling
DCT2000
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
R L
AUDIO OUT
VIDEO
From cable source
CABLE IN R
AUDIO
IN L VIDEO IN SVIDEO IN
VCR
CABLE OUT R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
The remodulated channel, 3 or 4 does not carry stereo for digital channels. Connect the DCT2000 using RCA baseband connectors to receive stereo on digital channels. These connections are illustrated later in this section.
DCT 2000 Installation Manual
R F B y p a s s S w i t c h V C R C a b l i n g D i a g r a m s
Proper operation of the RF Bypass feature requires special configuration in the control system and in the EPG settings.
The STARFONE return module is used in a one-way addressable system to send information to the controller through the subscriber’s telephone hookup. Figure 3-4 illustrates the cabling diagram that enables viewing an unscrambled analog channel on TV while recording another channel through the DCT2000:
Figure 3-4
RF Bypass switch with VCR (STARFONE return module installed)
From cable source
DCT2000
TO
TV/VCR
RF
OUT
RF
IN
RF
IN
TO RF IN
CABLE IN
PHONE
AUX AUDIO IN SPDIF
Optical
R L
AUDIO OUT
VIDEO
Subscriber telephone hookup
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
CABLE IN R
AUDIO
IN L VIDEO IN SVIDEO IN
VCR
CABLE OUT R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
If the operator plans to implement two-way RF return functionality in the future, the installer should use the integrated STARVUE RF return.
DCT 2000 Installation Manual
3 - 6 I n s t a l l a t i o n
Figure 3-5 illustrates the cabling diagram that uses the RF return and enables viewing of an unscrambled analog channel on TV while recording another channel through the DCT2000:
Figure 3-5
Cabling with RF Bypass module (using RF return)
DCT2000
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
OUT
RF
IN
RF
IN
CONV
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
From cable source
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
CABLE IN R
AUDIO
IN L VIDEO IN SVIDEO IN
VCR
CABLE OUT R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
DCT 2000 Installation Manual
A / B I n M o d u l e C a b l i n g D i a g r a m s
The A/B In module is commonly used in dual-cable systems. Figure 3-6 illustrates a DCT2000 that is equipped with a STARFONE module:
Figure 3-6
A/B In module with a STARFONE module
DCT2000 Cable A
TO
TV/VCR
A
CABLE IN
IN
B
TO RF IN
CABLE IN
Cable B
PHONE
AUX AUDIO IN SPDIF
Optical
R L
AUDIO OUT
VIDEO
Subscriber telephone hookup
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
Figure 3-7 illustrates a DCT2000 with the return on Cable A:
Figure 3-7
A/B In module with return on Cable A
DCT2000
RF OUT
TO
TV/VCR
A
RF
IN
B
AUX AUDIO IN SPDIF
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Cable A (Return)
Cable B
Optical
CABLE IN
TV
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
DCT 2000 Installation Manual
3 - 8 I n s t a l l a t i o n
Figure 3-8 illustrates a DCT2000 when the return is on Cable B:
Figure 3-8
A/B In module with return on Cable B
Cable A
DCT2000
AUX AUDIO IN SPDIF
TO
TV/VCR
A
CABLE IN
IN
B
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
Cable B (Return)
DCT 2000 Installation Manual
D u a l A / B - R F B y p a s s M o d u l e C a b l i n g D i a g r a m s
The Dual A/B-RF Bypass module is commonly used in dual-cable systems. Both Cable A and
Cable B are cable signals coming from the service provider. The service provider determines which source will be the return cable. Choose the cabling diagram that matches the return configuration you need.
The Dual A/B cable system using a STARFONE module utilizes the telephone modem as the return path to the service provider. Figure 3-9 illustrates a DCT2000 with a STARFONE module:
Figure 3-9
Return on STARFONE module
Cable A
DCT2000
RF OUT
TO
TV/VCR
A
RF
IN
B
TO RF IN
CABLE IN
Cable B
PHONE
AUX AUDIO IN SPDIF
Optical
R L
AUDIO OUT
VIDEO
Subscriber telephone hookup
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
TV
DCT 2000 Installation Manual
3 - 1 0 I n s t a l l a t i o n
Figure 3-10 illustrates a DCT2000 with the Dual A/B RF Bypass module when the return is on
Cable A:
Figure 3-10
Return on Cable A
DCT2000
RF OUT
TO
TV/VCR
A
RF
IN
B
TO RF IN
CABLE IN
AUX AUDIO IN SPDIF
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Cable A
Cable B
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
TV
Figure 3-11 illustrates a DCT2000 with a Dual A/B RF Bypass module when the return is on
Cable B:
Figure 3-11
Return on Cable B
Cable A
DCT2000
RF OUT
TO
TV/VCR
A
RF
IN
B
TO RF IN
CABLE IN
AUX AUDIO IN SPDIF
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Cable B (Return)
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
TV
VIDEO
IN
SVIDEO
IN
DCT 2000 Installation Manual
C o m p o s i t e B a s e b a n d a n d S - V i d e o C a b l i n g D i a g r a m s
Connecting the DCT2000 using the baseband RCA type outputs enables the subscriber to experience stereo and Dolby Surround
sound on digital channels when available.
Figure 3-12 illustrates the standard baseband audio and video outputs of the DCT2000:
Figure 3-12
Standard baseband cabling
DCT2000
See appropriate cable diagram
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
TV
VIDEO
IN
SVIDEO
IN
The S-Video connector is part of the Home Theatre option and is not included on all DCT2000s.
When connecting the video path, connect either the baseband composite video or S-video to the input device you plan to use. Do not connect both the baseband composite video and S-video.
Certain types of electronics equipment will not support both video inputs simultaneously.
DCT 2000 Installation Manual
3 - 1 2 I n s t a l l a t i o n
Figure 3-13 illustrates the baseband audio and video outputs of the DCT2000 that are available to connect to a VCR:
Figure 3-13
Composite VCR cabling
DCT2000
See appropriate cable diagram
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
CABLE IN
CABLE OUT
VCR
R
AUDIO
IN L VIDEO IN SVIDEO IN
R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
Either / or
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
When connecting the video path, connect either the baseband composite video or S-video to the input device you plan to use. Do not connect both the baseband composite video and S-video.
Certain types of electronics equipment will not support both video inputs simultaneously.
DCT 2000 Installation Manual
S t e r e o C a b l i n g D i a g r a m ( B a s e b a n d )
This audio configuration does not provide for a TV playing through the stereo. Figure 3-14 illustrates how to connect the DCT2000 to a stereo using the audio connectors on the VCR:
Figure 3-14
Audio on the VCR
DCT2000
See appropriate cable diagram
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
CABLE IN
CABLE OUT
VCR
R
AUDIO
IN L VIDEO IN SVIDEO IN
R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
Either / or
R
AUDIO
IN L
STEREO
R
AUDIO
OUT L
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
TV
VIDEO
IN
SVIDEO
IN
When connecting the video path, connect either the baseband composite video or S-video to the input device you plan to use. Do not connect both the baseband composite video and S-video.
Certain types of electronics equipment will not support both video inputs simultaneously.
DCT 2000 Installation Manual
3 - 1 4 I n s t a l l a t i o n
This audio configuration enables the TV to play through the stereo. Figure 3-15 shows how to connect the DCT2000 to a stereo using the audio loop-through connectors on the VCR and the audio output ports on the TV monitor:
Figure 3-15
Audio on VCR/audio output on TV
DCT2000
See appropriate cable diagram
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
CABLE IN
CABLE OUT
VCR
R
AUDIO
IN L VIDEO IN SVIDEO IN
R
AUDIO
OUT L VIDEO OUT SVIDEO OUT
Either / or
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
STEREO
AUDIO
IN
R
AUDIO
OUT
L
R L
When connecting the video path, connect either the baseband composite video or S-video to the input device you plan to use. Do not connect both the baseband composite video and S-video.
Certain types of electronics equipment will not support both video inputs simultaneously.
DCT 2000 Installation Manual
When all of the RCA audio connectors on the back of the stereo receiver are used, the DCT2000 enables audio to pass through an external device such as a CD player. In this configuration, a subscriber’s CD player can be played through the DCT2000 to a stereo receiver. Figure 3-16 illustrates how to connect the RCA baseband auxiliary audio input/output on the DCT2000:
Figure 3-16
CD player cabling
DCT2000
CD PLAYER
R
AUDIO
OUT R
See appropriate cable diagram
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
STEREO
AUDIO
IN
R
AUDIO
OUT
L
R L
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
L
R L
VIDEO
IN
SVIDEO
IN
The DCT2000 must be turned off from the front panel to enable audio loop-through signals to pass through. When the DCT2000 is powered on, the audio outputs correspond with the currently tuned channel on the DCT2000.
DCT 2000 Installation Manual
3 - 1 6 I n s t a l l a t i o n
D o l b y D i g i t a l C a b l i n g D i a g r a m s
The DCT2000 can deliver Dolby AC-3 audio to a Dolby Digital stereo receiver using the SPDIF
RCA or optical cable with a TOSLINK connector. Because the SPDIF does not carry audio for analog channels, use both the baseband L/R audio and the SPDIF connectors when connecting the DCT2000 to a digital receiver. The optical connector carries Dolby digital for both analog and digital channels.
PCM audio and AC-3 are the operation modes for the SPDIF connector. PCM audio mode is the default setting from the factory. Use the Electronic Program Guide (EPG) to select an alternative operating mode for the DCT2000. If the EPG does not provide a PCM or AC-3 option, then the SPDIF port will default to PCM audio.
Table 3-1 describes the functionality of the audio ports based on the digital audio mode selected:
Table 3-1
Audio port functionality
Baseband Audio
Left/Right
Audio Mode (selected in application setup screen)
PCM
Analog channels: Passthrough of transmitted signal (mono, stereo, or
Dolby Surround).
Digital channels: Mono, stereo, or Dolby
Surround down mix of Dolby Digital as selected by user. Default is stereo.
Dolby Digital
Analog channels: Passthrough of transmitted signal (mono, stereo, or
Dolby Surround).
Digital channels (option L): Mono, stereo, or Dolby Surround down mix of Dolby Digital as selected by user.
Default is stereo.
Digital Channels (option K): No output.
Digital channels (not option K or L):
Mono, stereo, or Dolby Surround down mix of Dolby Digital as selected by user. Default is stereo.
Analog channels: No output.
Digital channels: Dolby Digital.
SPDIF – Option K Analog channels: No output.
Digital channels: Mono, stereo, or Dolby
Surround down mix of Dolby Digital as selected by user. Default is stereo.
Coax/Optical – Option L Analog channels: Passthrough of transmitted signal (mono, stereo, or
Dolby Surround) in PCM format.
Digital channels: Mono, stereo, or Dolby
Surround down mix of Dolby Digital as selected by user. In PCM format.
Analog channels: Passthrough of transmitted signal (mono, stereo, or
Dolby Surround) in PCM format.
Digital channels: Dolby Digital.
For normal viewing with the SPDIF connection:
1
2
Set the DCT2000 to PCM audio mode using the Electronic Program Guide.
Adjust the Dolby Digital receiver input audio settings for the DCT2000 to baseband L/R inputs (refer to stereo receiver instructions for more information). This prevents audio loss while channel surfing through analog channels.
3 When a digital program has been selected for viewing, set the DCT2000 to AC-3 mode using the EPG. Set the stereo receiver to digital audio input to experience AC-3 audio.
DCT 2000 Installation Manual
Many Dolby Digital receivers are designed with A/V output ports that feed external devices such as a VCR. The AV output content is based on the selected input device. When the DCT2000 is selected as the input device for VCR recording, an alternate device cannot simultaneously use the Dolby Digital receiver, or the VCR will then record the secondary device. (Reference the
Dolby Digital receiver installation manual for information on selecting and configuring A/V interfaces on the receiver).
For normal viewing with the optical connector set the audio in the EPG to:
Mono for one channel
Stereo for two channels
Matrix stereo for 5.1 (digital AC-3)
DCT 2000 Installation Manual
3 - 1 8 I n s t a l l a t i o n
Using this configuration the audio/video signals are passed through the digital receiver to enable the VCR record and playback features. Figure 3-17 illustrates audio/video connections for a Dolby Digital receiver:
Figure 3-17
Audio through A/V Receiver
DCT2000
See appropriate cable diagram
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN SPDIF
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
Either / or
A/V
RECEIVER
S-Video
Video
In
Out
In
Video 2
Video 1
Coaxial
Optical
Either / or
VCR
CABLE IN
CABLE OUT
AUDIO
IN R
AUDIO
OUT R
L
L
VIDEO
IN
SVIDEO
IN
VIDEO
OUT
SVIDEO
OUT
S-Video or
Baseband Video
TV
CABLE IN
AUDIO
IN
R
AUDIO
OUT
R
L
L
VIDEO
IN
SVIDEO
IN
DCT 2000 Installation Manual
When using the Dolby
5.1 optical output, the SPDIF and left/right baseband audio connections to the A/V receiver are not used. Figure 3-18 illustrates the Dolby 5.1 optical output connections:
Figure 3-18
Dolby 5.1 optical output
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
AUX AUDIO IN SPDIF
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
DCT2000
Cable in
CABLE/
ANTENNA IN
To TV
Stereo VCR
INPUT
AUDIO VIDEO
OUTPUT
AUDIO VIDEO
R L R L
CABLE/
ANTENNA IN
Stereo TV
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
DVD
CABLE/TV
VIDEO 2
R
AUDIO
L
IN
VCR
OUT
VIDEO
VIDEO S-VIDEO
DIGITAL INPUT
COAX
A/V Receiver
OPTICAL
TV/MONITOR
OUTPUT
VIDEO S-VIDEO
SPEAKER
CONNECTORS
DCT 2000 Installation Manual
3 - 2 0 I n s t a l l a t i o n
O p e r a t i o n a l C h e c k
The operational check tests the communication link between the remote control and the
DCT2000. The procedures verify the DCT2000 response to remote control commands.
Table 3-2 lists the operational check procedures:
Table 3-2
Operational check
Power on
Channel Selection
Volume Control
Press
POWER
to turn on the DCT2000.
Turn on the TV and tune it to the output channel of the DCT2000 (channel 3 or
4).
Scan through the channels using the
CHANNEL
56 keys on the DCT2000 and the
CHANNEL
+ - keys on the remote control.
Tune to several channels by entering the channel number with the numeric keys on the remote control.
Use the TV volume control to adjust the sound volume to a moderate level.
Press
VOLUME
+ - on the remote control to increase the volume to its upper limit, lowest level, and to a comfortable level.
Press
MUTE
to turn the sound completely off. Press
MUTE
again to restore the sound.
If the DCT2000 does not operate properly, refer to Section 5, ‘‘Troubleshooting.’’
DCT 2000 Installation Manual
Section 4
A d d i n g t h e I R B l a s t e r O p t i o n
The IR Blaster provides control of the subscriber’s VCR from the DCT2000. It consists of a low-power infrared transmitter attached to a six-foot cord and a mounting bracket. The mounting bracket is a clear plastic holder with a pad of adhesive tape for installing the
IR Blaster near the VCR IR receiver. A mini-pin connector at the end of the cord connects the
IR Blaster to the DCT2000.
The IR Blaster functionality is controlled by the interactive program application that is resident on the DCT2000. Not all applications support the optional IR Blaster.
Figure 4-1 illustrates the IR transmitter installed in the mounting bracket:
Figure 4-1
IR transmitter installed in mounting bracket
Adhesive tape Mounting bracket
Transmitter
The IR Blaster is automatically activated through the electronic program guide. Individual VCR codes are broadcast through the out-of-band data channel and are updated periodically as new codes are added.
The procedure for installing the IR Blaster is described in the following paragraphs.
L o c a t i n g t h e I R R e c e i v e r o n t h e V C R
1
2
The IR receiver is not visible on some VCRs. You can locate the receiver using the following procedure:
Obtain a piece of opaque material, such as a 3- by 5-inch index card.
Use the card to block areas of the VCR where the receiver might be located. Turn the VCR on and off, while pointing the remote control at the card blocking the VCR. Be sure the remote control is close to the VCR to reduce reflections the receiver may pick up.
3 Note the area where the VCR is unresponsive to the remote control. This region contains the receiver and can be marked by loosely taping the index card to the area.
Because the IR Blaster radiates an area approximately 40 degrees wide, it is not necessary to be precisely on target with the remote control. Offset the location of the IR Blaster transmitters from the VCR receiver to reduce interference with operation of the VCR remote control.
DCT 2000 Installation Manual
4 - 2 A d d i n g t h e I R B l a s t e r O p t i o n
I n s t a l l i n g t h e I R B l a s t e r
To install the IR Blaster:
1
2
Fit the transmitter into the mounting bracket (refer to Figure 4-1).
Plug the mini-pin connector into the
(refer to Figure 4-2).
IR jack on the rear panel of the DCT2000 rear panel
Figure 4-2
IR Blaster installed
DCT2000
AUX AUDIO IN SPDIF
TO
TV/VCR
RF
IN
TO RF IN
CABLE IN
R L
AUDIO OUT
VIDEO
Optical
S-VIDEO
IR
SWITCHED
105-125V
60Hz
4A MAX
500W MAX
VCR
3
4
Remove the adhesive tape cover from the mounting bracket.
Position the IR receiver off center of the VCR receiver and then press firmly attaching the mounting bracket on the VCR. Be careful to route the wire so that it does not prevent loading videotapes.
C h e c k i n g t h e I n s t a l l a t i o n
The IR Blaster is now located near the receiver and the VCR can be controlled through the
DCT2000. As a final check, operate the VCR using the remote control from various positions in the room. If the IR Blaster is obstructing the IR receiver on the VCR, move it slightly.
DCT2000 Installation Manual
Section 5
Tr o u b l e s h o o t i n g
This section provides information to assist you in quickly detecting, isolating, and resolving error conditions that might occur when using the DCT2000. If you need assistance, call TRC:
Inside the U.S.: 1-888-944-HELP (1-888-944-4357)
Outside the U.S.: 215-323-0044
Table 5-1 is a list of possible problems and solutions:
Table 5-1
Troubleshooting guidelines
No power to the
DCT2000
Remote control is not responding
The DCT2000 is not receiving a cable signal
Guide has no data
VCR did not record
Check the power outlet for AC power.
Be sure the TV is tuned to the output channel of the DCT2000 (channel 3 or 4).
Verify that cable connections are correct from the TV set or monitor to the
DCT2000.
Check that the power cord is properly plugged into the outlet and DCT2000.
Check for an obstruction between the remote control and the DCT2000. Aim the remote control directly at the DCT2000, not the TV or VCR.
Be sure you firmly and deliberately press and release operation keys one at a time.
Verify that channels can be changed using the keys on the front panel and then check that the batteries have been installed properly. Replace with new batteries if necessary.
Check that the DCT2000 has been initialized correctly; refer to Diagnostics.
Check the cable connections and hand-tighten if necessary.
Verify that the cable connections are correct.
Verify the TV is working and has a clear picture.
Unplug the power to the DCT2000 and plug in the unit again. Wait for the DCT2000 to collect the data.
Turn the VCR off when you are not using it.
Be sure the IR Blaster is correctly placed.
Check the Scheduled Events list to be sure programs are scheduled for recording.
DCT2000 Installation Manual
Appendix A
S p e c i f i c a t i o n s
Input frequency
HRC/IRC frequency assignments
Number of channels:
Analog
Digital
Dual A/B cable switching
Input analog video level
Input analog sound level
Average digital input level
Data carrier:
Frequency
Bandwidth
Level
Video s/n
Output frequency accuracy
Return loss:
Input
Output
Spurious output
Cross-modulation distortion
Composite second order distortion
Second order distortion
Composite triple beat distortion
Set-top input beats (with all input signals)
Hum modulation distortion
Output level
Isolation (input/output)
Differential phase
Analog descrambling method (optional)
On-screen display (OSD):
Screen size
Message/barker capacity
Mechanical security
54 through 860 MHz (excluding data carrier frequency)
Downloadable
136 carriers per cable, 1 or 2 cables
1 channel per carrier
More than 1 channel per carrier, content dependent
Optional A/B (field upgradeable)
0 dBmV through +15 dBmV
–17 dBmV through +2 dBmV
–10 dBmV through +5 dBmV
QPSK-modulated carrier
75.250 MHz or 72.75 MHz or 104.2 MHz
1.5 MHz
–10 dBmV through +5 dBmV
49 dB @ 0 dBmV input level
±150 kHz
6 dB minimum
8 dB minimum
–57 dBc maximum, in band
–56 dB (136 channels, each @ +15 dBmV)
–57 dB (136 channels, each @ +15 dBmV)
–60 dB (136 channels, each @ +15 dBmV)
–57 dB (136 channels, each @ +15 dBmV)
–25 dB (136 channels, each @ +15 dBmV)
3 IRE
10 through 15 dBmV
70 dB minimum
10 degrees (maximum)
Gated sync suppression or dynamic gated sync suppression, video inversion, audio privacy, and Hamlin compatibility
352 x 480 pixels (configuration dependent)
Up to 40 pages (configuration dependent)
Standard: security screws, unichassis construction
DCT2000 Installation Manual
A - 2 S p e c i f i c a t i o n s
Operating environment range:
Temperature
Humidity ac voltage
Power dissipation
Surge protection
Size
Weight
0 ° through 40°C (32° through 104°F)
5 through 95% (noncondensing)
105 through 125, 60 Hz
35 W at 115 Vac
Provided on power supply and RF ports
17.13 × 13.25 × 2.75 inches
8.6 pounds
DCT2000 Installation Manual
Appendix B
D i a g n o s t i c s
This section describes the diagnostics designed to confirm proper installation of the DCT2000.
The diagnostics include checking error states and signal integrity, as well as provisions to identify the DCT2000 on the network and to verify communications with the headend. The diagnostic information is displayed on the front-panel LED and the On-Screen-Display.
For diagnostics provided in this appendix:
All indicators are in decimal notation unless otherwise noted.
All signal-level and quality indicators are based on a 0 to 100% scale, unless otherwise noted.
All screens self-refresh at a minimum rate of once every five seconds.
All sample displays are illustrative; actual data will differ from the examples.
The diagnostic screens are available for DCT 7.54 code and beyond. Previous versions of
DCT code are subsets.
For diagnostics information on other DCT models, reference the installation manual for each model.
A c c e s s i n g D i a g n o s t i c s
4
5
When accessing the DCT2000 diagnostic mode the following commands are helpful:
1
2
Press POWER to turn on the DCT2000
Wait five seconds and then press POWER again to turn off the DCT2000
3 Press SELECT within two seconds after powering off. The DIAGNOSTICS Main menu
(Figure B-1) is displayed on the OSD and d 01 is displayed on the front-panel LED. The
DCT2000 is now in diagnostic mode.
Use the
Press
CHANNEL
CURSOR <,
keys to select the desired diagnostic.
CURSOR >, SELECT , or ENTER to execute the selected diagnostic.
6 To exit the diagnostic mode, press powers off.
POWER . The DCT2000 exits the diagnostic mode and
DCT 2000 Installation Manual
B - 2 D i a g n o s t i c s
N a v i g a t i n g t h e D i a g n o s t i c s
Figure B-1 illustrates the OSD Diagnostics main menu:
Figure B-1
Diagnostics main menu −−−− OSD
13
14
15
16
17
18
06
07
08
09
10
11
12
DIAGNOSTICS
01 GENERAL STATUS
02 OOB STATUS
03
04
05
IN BAND STATUS
AUDIO/VIDEO STATUS
UNIT ADDRESS
FIRMWARE VERSION
CURRENT CHANNEL STATUS
RENEWABLE SECURITY
UPSTREAM MODEM
APP CODE MODULES
MEMORY CONFIG
INTERACTIVE INFO
MAC FREQUENCY TABLE
MESSAGE TYPES
IN BAND PAT
IN BAND PMT
TASK STATUS
KEYBOARD/LED
Table B-1 provides a list of keys and key functions for selecting diagnostics:
Table B-1
Operational keys using the diagnostics main menu or submenus
Key Key function using a diagnostic
POWER
Key function using the diagnostics main menu
DCT2000 exits the diagnostic mode and enters the OFF state
Moves the cursor up
DCT2000 exits the diagnostic mode and enters the Off state
Displays the DIAGNOSTICS Main menu CH/CUR +,
CURSOR UP
CH/CUR - ,
CURSOR
DOWN
Moves the cursor down Displays the DIAGNOSTICS Main menu
DCT 2000 Installation Manual
Key
CURSOR
RIGHT,
CURSOR LEFT,
SELECT,
ENTER
GUIDE
MENU
INFO
Key function using the diagnostics main menu
The DCT2000 executes the selected diagnostic
No function
No function
No function
Key function using a diagnostic
Displays the DIAGNOSTICS Main menu
No function
No function
No function
Table B-2 lists the LED and provides a description of each diagnostic. It also indicates whether the diagnostic provides information on the LED/OSD:
Table B-2
Diagnostic
LED Diagnostic d 01 General status of the DCT2000 d 02 QPSK out-of-band control channel d 03 In-band receiver status d 04 Audio/Video status d 05 Unit address d 06 Firmware version d 07 Current channel status d 08 Renewable security system d 09 Upstream modem status d 10 Application code modules d 11 Memory configuration d 12 Interactive info d-13 MAC frequency table d 14 Message types
d 15 In Band PAT
d 16 In Band PMT
d 17 Task Status
d 18 Keyboard and LED diagnostic
LED
X
X X
X
X
X
X
X
X
X
X
OSD
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
DCT 2000 Installation Manual
B - 4 D i a g n o s t i c s
d 01: DCT2000 General Status
This diagnostic indicates the general status of the DCT2000. Figure B-2 illustrates the LED that alternates between the error code and the purchases count:
Figure B-2
DCT2000 General Status −−−− LED
Error display alternating with purchases count and IPPV status indicator
IPPV status indicator
The purchases count is used by Customer Service Representatives (CSRs) to check returned
DCT2000 for uncollected purchases that are used to close out a subscriber’s account. The largest error code takes priority.
DCT 2000 Installation Manual
Figure B-3 illustrates the DCT2000 Status OSD, which displays the error code, a short description of the error, the purchases count, and specific model information:
Figure B-3
DCT2000 Status −−−− OSD
01 DCT2000 STATUS
ERROR
NO ERROR
PURCHASES
Platform ID:
Family ID
Model ID
TUNER
Remod Channel
Table B-3 lists error codes:
:
:
:
:
:
:
:
E 00
0
0x0008
0x0000
0x008F
V860DL
3
Table B-3
Error codes
Initialization status errors
Error Code OSD
E 00*
E 01*
E 02
Cause
NO ERROR Indicates normal condition after initialization
NOT CONNECTED DCT2000 did not receive a connect message
PWR CYCLE Init Error
E 03
E 04
E 07
E 08
DRAM
DPSRAM
ROM
RAM
DRAM error
DP-SRAM error
ROM verification failure
Faulty RAM, ROM, EEPROM, or
POST failure (this is a hardware failure)
Remedy
Not applicable
Restore out-of-band signal
Send a connect message
Box needs a Power Cycle to recover
Not used at this time
Not used at this time
Power cycle box; if repetitive, return for repair
Return DCT2000 for repair
DCT 2000 Installation Manual
B - 6 D i a g n o s t i c s
Error Code
E 09
OSD
BATTERY
Cause
Dead battery or memory has not been initialized; occurs if battery fails to keep the RAM alive during power-down; causes DCT2000 to be disconnected
Invalid serial number
Invalid unit address
Remedy
Return DCT2000 for repair; requires factory initialization message
E 10
E 11
E 12
E 13
E 14
E 15
SERIALNO
INVALID UNIT
ADDRESS
POST ERROR
BOOT
STARTUP
TSI INVALID
POST failed
Sys_boot initialization failure
DCT2000 system startup failure
TSI structure is corrupted
Not used at this time
Return DCT2000 for repair; requires a unit creation message
Not used at this time
Power cycle box; if repetitive, return for repair
Power cycle box; if repetitive, return for repair
Power cycle box; if repetitive, return for repair
Error logged, ignore E 16 FLASH BAD
NUMBER
BAD PLATVAL
Bad flash number specified for Initiate
Flash Platform
Bad platform validation step number E 17 Error logged, ignore
*E 00 and E 01 cannot be displayed while the DCT2000 is off. The other errors will display on the LED display when the DCT2000 is off.
There are five different tuners that could appear on the OSD display:
V1000D2
V1000D3C
V860
V860D
V860DL
DCT 2000 Installation Manual
d 02: Out-Of-Band (OOB) Status
This diagnostic indicates the status of the out-of-band control channel. Figure B-4 illustrates the
Out-Of-Band Status LED display:
Figure B-4
Out-Of-Band Status −−−− LED
Data activity
EMM data activity
P
Out-of-band diagnostic indicator
Indicates no data
Carrier lock
Figure B-5 illustrates the OOB Diagnostic OSD:
Figure B-5
OOB Diagnostic Status −−−− OSD
02 OOB DIAGNOSTIC
DATA
EMM DATA
CARRIER LOCK
HUNT MODE
CUR FREQ
LKC
EMM PRVDR ID
MAN FREQ
*
*
YES
None
SNR 23 dB GOOD
COUNT 1
(For AGILE OOB DCTs only)
(For AGILE OOB DCTs only)
(For AGILE OOB DCTs only)
0x0001 (For AGILE OOB DCTs only)
(For AGILE OOB DCTs only)
The CARRIER LOCK COUNT is reset to ‘‘1’’ after an initialize from the DAC or a power cycle.
DCT 2000 Installation Manual
B - 8 D i a g n o s t i c s
Table B-4 lists the LED and OSD indications of whether the out-of-band control channel is locked to the carrier (this indicator can falsely indicate locked):
Table B-4
LED and OSD indicators for out-of-band control channel
LED OSD State
L
U
Data Activity and EMM Data Activity Indicators
The LED EMM Data Activity indicator is lit when a message is present and the Data Activity indicator shows receipt of a message. The OSD indicates with a *, that data has been received.
The indicators cover all packet processors regardless of which stream they are monitoring and are cleared when you enter the diagnostic.
Table B-5 lists how the EMM data activity indicator shows when the DCT2000 is receiving a message on the EMM stream:
Table B-5
Out-of-band EMM data activity indicator −−−− LED and OSD
LED OSD Status off Blank No data received on
The DCT2000 can receive only six PIDs at one time. Data on PIDs can be present on the out-of-band multiplex that the DCT2000 is not receiving.
Selecting the OOB Frequency
To select the OOB Frequency go to 02 OOB STATUS diagnostic and begin:
1 Press the MENU button to enter the frequency selection mode. The frequency of the last known carrier (LKC) displays on the LED. The OSD displays a new MANUAL FREQ line at the bottom of the screen, indicating the LKC frequency.
2 Press the MENU key a second time to exit the frequency change mode.
Or
Press the UP/DOWN channel or cursor keys to scroll through the frequencies to locate the desired OOB frequency. The frequency selection appears on the LED and on the MANUAL
FREQ line of the OSD. When you select the last known frequency, a DOT appears in the upper-middle portion of the LED.
DCT 2000 Installation Manual
3
4
5
6
The first frequency to display is 75.25. The system scrolls through each frequency until it reaches the last, 103.75, and then scrolls back to the beginning. This diagnostic scrolls through the OOB frequencies in the following order:
75.25 MHz
104.20 MHz
72.75 MHz
92.25 MHz
98.25 MHz
107.25 MHz
107.40 MHz
110.25 MHz
116.25 MHz
103.75 MHz
Press SELECT to begin searching for the OOB frequency. While the DCT2000 searches for a frequency, the LED flashes. On the OSD the MANUAL FREQ line of text clears, the
HUNT MODE displays FIX to indicate the fixed frequency search, and the CUR FREQ field changes to the frequency selected to search.
If the frequency is found with the proper EMM Provider ID, the LED displays the normal
OOB receiver status as shown in Figure B-4. The OSD LKC field changes to display the new frequency.
If after 40 seconds the frequency search is not successful, the DCT2000 performs a warm reset and returns to the last known carrier frequency.
To abort a search without waiting the 40 seconds, press POWER to cause a warm reset.
Agile Enabled DCT2000 Operation Notes
The DCT2000 LED displays hunt:
After a cold reset from the front panel. This indicates that the DCT2000 is in a round robin hunt mode. The hunt message continues to display until the proper stream (EMM provider of 0x0000 or 0x001) is detected.
After receiving an OOB_processor_config message with EMM_provider_ID that is not equal to the one it is currently using. Receiving this message puts the DCT2000 into the EMM ID
Hunt Mode. The hunt message continues to display until the proper stream is detected.
DCT 2000 Installation Manual
B - 1 0 D i a g n o s t i c s
d 03: In-Band Status
The DCT2000 displays the in-band diagnostics for the last attempted channel tune. If a digital carrier is not present, the diagnostics indicate the carrier lock is analog. When the carrier lock is analog, all fields for digital (other than a carrier lock channel) are blank.
Figure B-6 illustrates the In-Band Status as shown on the LED:
Figure B-6
In-Band Status −−−− LED
Data activity
EMM data activity
IB diagnostic indicator
Figure B-7 illustrates the In-Band Diagnostic OSD:
Figure B-7
In-Band Diagnostic −−−− OSD
Carrier lock
03 IN BAND DIAGNOSTIC
DATA
EMM DATA
CARRIER LOCK
PCR LOCK
SNR
MODULATION MODE
SHORT TERM ERROR COUNT
LONG TERM ERROR COUNT
TUNED FREQ
36 dB
*
*
YES
YES ssss
QAM 64
0000
9999
543.000
DCT 2000 Installation Manual
Data Activity Indicator −−−− LED and OSD
The data activity indicator lights when the DCT2000 is receiving a message. The indicator is blank when you enter this diagnostic and three seconds after receiving the last message. The indicator covers all packet processors regardless of which stream they are monitoring.
Table B-6 lists the LED and OSD indications:
Table B-6
Data activity indicator −−−− LED and OSD
LED OSD Status off blank No data received on
EMM Data Activity Indicator −−−− LED and OSD
Table B-7 lists the LED and OSD indicator lights when the DCT2000 is receiving a message on the EMM stream. The indicator is clear when entering this diagnostic.
Table B-7
EMM data activity indicator −−−− LED and OSD
LED OSD Status off on blank No data received
Carrier Lock −−−− LED and OSD
This diagnostic indicates that the digital in-band receiver is locked to the carrier. Table B-8 lists the LED and OSD indications:
Table B-8
In-band carrier lock −−−− LED and OSD
LED OSD Status
L
U
A
Program-Clock-Reference (PCR) Lock −−−− OSD Only
The PCR lock indicates a program-clock-reference lock with the current digital datastream.
DCT 2000 Installation Manual
B - 1 2 D i a g n o s t i c s
Signal-To-Noise Ratio (SNR) −−−− OSD Only
The SNR displayed on the OSD is a rough estimate of the carrier signal-to-noise ratio. The SNR displayed is a measure of the QAM cluster variance, which is proportional to the signal-to-noise ratio.
Analog channels display analog for carrier lock. The SNR display a number for the numeric value and blank for the ssss value.
A blank display indicates that the digital section of the DCT2000 is still in the initial state. If this occurs, check diagnostic d07.
Table B-9 lists the SNR indicators for the OSD:
Table B-9
SNR indicators −−−− OSD only
ssss value
GOOD
FAIR
POOR
Meaning
Good value
Marginal signal level − check the signal
Unusable signal
Modulation Mode
The modulation mode for analog and digital channels are illustrated in table B-10:
Table B-10
Modulation Mode
Analog channels
Analog
Digital channels QAM 64
QAM 256
Short Term Error Count
The Short Term Error Count polls the FEC errors (maximum count of 65535) at 5-second intervals. The Short Term Error Count is cleared after polling.
Long Term Error Count
The Long Term Error Count is the accumulation of the Short Term Error Count (maximum count of 65535). The Long Term Error Count is cleared every 24 hours.
Tuned Frequency
Tuned Frequency (Carrier Definition Frequency + 1.75 MHz) is the actual frequency the tuner is programmed.
DCT 2000 Installation Manual
d 04: Audio/Video Status
This diagnostic displays the audio and video information for the current tuned channel. The audio and video status OSD is illustrated in Figure B-8:
Figure B-8
Audio/Video Status - OSD
04 AUDIO/VIDEO STATUS
ADP Lock
Audio Mode
Audio SPDIF
SAP
YES
STEREO
IEC958PCM
N/A
LFE 0
VP Lock
MPEG Method
YES
MUTE BLACK
A list of the audio video status information is illustrated in Table B-11:
Table B-11
Audio Video Status
Status Description
ADP Lock
Audio Mode
The ADP Lock is the Audio Processor locked status. The ADP Lock displays either
YES or NO.
The audio modes of the DCT2000 are:
Audio SPDIF
N/A
Mono
Stereo
Surround
The audio SPDIF displays SPDIF modes valid for the DCT2000. The mode is set by the software application that runs on the DCT. The two modes for a non-SPIDIF DCT are:
N/A
IEC958PCM – AC3
The following are SPIDIF configuration modes (K and L DCT models options):
1/0 – Right or left front
2/0 – Right front, left front
3/0 - Right front, left front, center
2/1 - Right front, left front / right or left rear
3/1 - Right front, left front, center / right or left rear
2/2 – Right front, left front / right rear, left rear
3/2 - Right front, left front, center / right rear, left rear
LFE - Low frequency effect if “1” signifies Dolby 5.1
DCT 2000 Installation Manual
B - 1 4 D i a g n o s t i c s
Status Description
SAP
VP Lock
SAP is the Second Audio Program availability. It displays:
N/A (for digital channel)
YES (for analog channel)
NO (for analog channel)
The VP Lock is the Video Processor locked status. The VP Lock displays either YES or
NO.
MPEG Method The MPEG Method selected. The MPEG Methods are:
Unmuted
Mute Still
Mute Black
DCT 2000 Installation Manual
d 05: Unit Address
This diagnostic displays the 16-digit (40-bit) unit address of the DCT2000. It displays in five parts on the four-section LED. The address display stays on each section for five seconds. The location of the dash in each of the five displays is unique. Figure B-9 shows the LED for unit address 123-45678-90123-456:
Figure B-9
Unit address - LED
MUTE
On the unit address OSD, the unit, network, and TV PassCard (TVPC) addresses are in decimal form (13 address digits and three check digits). The multicast 16-bit address is in TCP/IP decimal byte form.
DCT 2000 Installation Manual
B - 1 6 D i a g n o s t i c s
Figure B-10 illustrates the Unit Address OSD:
Figure B-10
Unit Address - OSD
05 DCT2000 Unit Address:
000-02831-99902-038
Network Address:
085-14316-55765-159
TVPC:
000-00000-00000-000
Multicast 16 Address:
085.085
102.102
119.119
DATA
136.136
068.068
034.034
051.051
017.017
Seed Health 0xFF
The Multicast 16 address numbers change to display the values for each datastream. The following is a list of Multicast 16 addresses:
NET
EMM
SCC
DWLD
DATA
VCN
POLL
Seed Health --- This value respresents the health of the DCT and should be 0xFF.
DCT 2000 Installation Manual
d 06: Firmware Version
This diagnostic displays the Dena firmware version. Figure B-11 illustrates that the LED alternates between displaying the firmware version number and the characters Dena:
Figure B-11
Dena firmware version - LED
P
MUTE MUTE
Alternating with
P
MUTE MUTE
Major revision number
Minor revision number
The Firmware Version OSD displays:
Dena firmware version or revision number
The build date and time
TSODA firmware version number
CAMEL (CMLBK) firmware version number
The BOOT is the lowest level of firmware code that can be used on the DCT2000
Figure B-12 illustrates the Dena Firmware Version OSD:
Figure B-12
Firmware Version - OSD
06 FIRMWARE VERSION
07.44
April 12, 2001
09:31:05
BOOT 07.41
TSODA t16 (or t14)
CMLBK 8404
DCT 2000 Installation Manual
B - 1 8 D i a g n o s t i c s
d 07: Current Channel Status
This diagnostic gives the instantaneous status of the last attempted channel tune on the in-band tuner. The status shows channel type (analog/digital), acquisition state, purchasable indicator, preview indicator, parental control status, and mute status. Figure B-13 illustrates a current channel status display on the LED:
Figure B-13
Current Channel Status - LED
LED Channel Types
Table B-12 lists the possible channel types:
Table B-12
Channel Types −−−− LED and OSD
Meaning 1 s t LED OSD
A d
DCT 2000 Installation Manual
Acquisition State
Table B-13 lists the acquisition state:
2 n d LED n
I
C
A d
S
E
U
Table B-13
Acquisition state
State
Not connected
Initialized to acquire the program
Configured to acquire the program
Acquiring the program
Not authorized for the program
Authorized for analog program
Authorized for encrypted digital program
Unencrypted digital program
Purchasable Indicator −−−− LED and OSD
Table B-14 lists the purchases indicator:
Table B-14
Purchasable status −−−− LED and OSD
LED OSD Meaning
off NO Channel is not purchasable at present
on YES Channel is purchasable at present
Preview Indicator −−−− LED and OSD
Table B-15 lists the preview indicator:
Table B-15
Preview status −−−− LED and OSD
LED OSD Meaning
off NO Channel is not in preview
on YES Channel is in preview
DCT 2000 Installation Manual
B - 2 0 D i a g n o s t i c s
Parental Control - LED and OSD
Table B-16 lists the parental control indicator:
Table B-16
Parental Control –LED and OSD
OSD Meaning
NO
YES
Parental Control is not active
Parental Control is active
There is no indicator on the LED for Parental Control.
Mute Status
Table B-17 lists the mute indicator:
Table B-17
Mute –LED and OSD
OSD Meaning
NO Mute is not active
YES Mute is active
There is no indicator on the LED for Mute status.
Current Channel Status - OSD
The Current Channel Status OSD has the following fields:
The TYPE field indicates whether the current channel is analog or digital.
The STATUS field indicates the channel type. The types of status are:
- Authorized
- Unauthorized
- Encrypted
- Unencrypted
The CONNECTED field indicates whether the DCT2000 is connected or disconnected. If the value is connected, the program is viewable.
The PREVIEW field indicates that the program is in the free preview state. The field displays
YES or NO.
The PURCHASABLE field indicates if the current or next program can be purchased. The field displays YES or NO.
The PURCHASED field indicates if the current or next program has been bought. The field displays YES or NO.
The EPOCH NUM field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE
PROTOCOL document #DCII-093-052, Service Status Reply for description of current_program_epoch_number and next_program_epoch_number].
DCT 2000 Installation Manual
The EPOCH TYPE field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE
PROTOCOL document #DCII-093-052, Service Status Reply for description of current_epoch_status and next_epoch_status].
The AUTH field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE PROTOCOL document #DCII-093-052, Service Status Reply for description of current_epoch_auth_reason and next_epoch_auth_reason].
The SERVICE field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE
PROTOCOL document #DCII-093-052, Service Status Reply for description of service_number ].
The STATUS field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE
PROTOCOL document #DCII-093-052, Service Status Reply for description of service_status ].
The ID field is for Motorola use only [refer to TSODA GATEKEEPER INTERFACE PROTOCOL document #DCII-093-052, Service Status Reply for description of service_ID].
The CH indicates the channel currently tuned when the OSD screen displayed.
The TUNED FREQ (Carrier Definition Frequency + 1.75 MHz) is the actual frequency the tuner is programmed.
Figure B-14 illustrates the current channel status display on the OSD:
Figure B-14
Current Channel Status - OSD
07 CURRENT CHANNEL STATUS
TYPE DIGITAL
STATUS
CONNECTED
PREVIEW aaa bb ccccc dddd
NO
PURCHASABLE
PURCHASED
EPOCH NUM
EPOCH TYPE
AUTH
CURR
NO
NO
0X0
0x0
0X0
SERVICE 0 STATUS 1 ID 0X0004 0X00
CH 204 TUNED FREQ 543.000
NEXT
--
--
1
0x0
0X0
DCT 2000 Installation Manual
B - 2 2 D i a g n o s t i c s
Current Channel Status −−−− OSD fields
Table B-18 lists the Current Channel Status OSD fields:
Table B-18
Current channel status −−−− OSD fields
State OSD variables aaa bb ccccc ddd
Analog − blank
For digital only:
ENC − encrypted
UNE − unencrypted current epoch authorization reason in the current_epoch_auth_reason field. This is displayed in hex:
00 – missing program re-key
01 – missing working key epoch message
02 – missing event blackout message
03 – missing category rekey
04 – old category sequence in program, rekey message
10 – program bought
11 – program bought without taping
12 – subscribed with taping
13 – subscribed without taping
14 - subscribed with taping purchasable
15 – IPPV with taping
16 – IPPV without taping
20 – bad seed checksum
21 – bad debit buffer checksum
30 – IPPV not enabled
31 – insufficient credit to purchase
32 – show count limit exceeded
33 – debit register will overflow
34 – no AFP records available
36 – maximum package cost exceeded
37 – no IPPV overlay in message
40 – not subscribed
41 – regional blackout
42 – event blackout
INIT − Initialized state
CONFI − Configured
ACQUI − Acquiring the program
AUTH − Authorized for the program
Not A − Not authorized for the program blank − Connected
NOT − Not connected
DCT 2000 Installation Manual
d 08: Renewable Security System
The renewable security system includes a TVPC card that returns the security status to current.
The status LED includes whether the TVPC is required, the mode, status, and version.
Figure B-15 illustrates the Renewable Security Status LED:
Figure B-15
Renewable Security Status - LED
TvPC
Crypto mode
TvPC status
TvPC status
Alternating with
P
TvPC
Revision
Figure B-16 illustrates the Renewable Security OSD:
Figure B-16
Renewable Security −−−− OSD
08 RENEWABLE SECURITY
TVPC NOT REQUIRED
CRYPTO
STATUS
VERSION
NOT MATED
00
00
DCT 2000 Installation Manual
B - 2 4 D i a g n o s t i c s
TVPC Required −−−− LED and OSD
Table B-19 shows how the LED and OSD indicate whether further operation of the DCT2000 requires the TVPC:
Table B-19
TVPC required
LED OSD n NOT
REQUIRED
Y
Status
TVPC not required
IS REQUIRED TVPC is required
Crypto Mode
Table B-20 lists the current mode as displayed on the LED and the OSD:
Table B-20
Crypto mode
LED OSD
A
S n
Status
STAND ALONE Stand alone
SUPPORT Support
NOT MATED Not mated
Status
Table B-21 shows the TVPC status as displayed on the LED and the OSD:
Table B-21
TVPC status
04
05
0a
0b
LED and
OSD
00
01
02
03
0C
0d
Status
OK
TVPC communication problem
TVPC required
Validator does not match between GK and
TVPC
Invalid unit key number
Old TVPC unit address
TVPC not mated
TVPC /base module unit address mismatch
New TVPC, but wrong version number
TVPC unit address mismatch
DCT 2000 Installation Manual
Version
The version of renewable security being used is displayed in this field.
d 09: Upstream Modem Status
These diagnostics display the appropriate set of STARVUE II (RF) and STARFONE (telephone) modem information based on the module installed in the DCT2000.
STARVUE II (RF) Diagnostics
This diagnostic shows the status and operating parameters for the STARVUE II RF return.
Figures B-17 and B-18 illustrate the parameters for testing. Figure B-17 illustrates the
STARVUE II diagnostics LED:
Figure B-17
STARVUE II diagnostics LED
IPPV status
P
STARVUE frequency
STARVUE power level
Transmitter status
Alternating with
Transmitter status
Figure B-18 illustrates the STARVUE II Diagnostics OSD:
Figure B-18
STARVUE II Diagnostic - OSD
09 STARVUE II DIAGNOSTICS
STATUS:
FREQUENCY:
LEVEL:
IPPV:
LAST POLL REQ:
6-15-2001 20:49:33
DISABLED
23.000 MHz
39
DISABLED
170
DCT 2000 Installation Manual
B - 2 6 D i a g n o s t i c s
LAST POLL ACK:
6-15-2001 20:49:33
170
Table B-22 lists the STARVUE II transmitter status:
Table B-22
STARVUE II transmitter status
LED and
OSD
- t
Indicator
Idle
Transmitting
The FREQUENCY field indicates the transmitting frequency.
The LEVEL field indicates the approximate power value of the STARVUE II transmitter in dBmV. The difference between the power value on the diagnostic screen and the actual power of the STARVUE II module may be
± 5 dBmV.
Table B-23 shows how the LED and OSD indicate the IPPV status:
Table B-23
STARVUE II IPPV status
LED OSD Mode on flashing UNSENT − ## The DCT2000 contains unsent IPPV transactions off
The variable
−
## is the number of unsent transactions.
The LAST POLL REQ field contains the sequence number of the last poll request received by the
DCT2000. The time stamp of the last poll request will be displayed immediately below LAST
POLL REQ . If no poll request has been received by the DCT2000, the sequence number field will display N/A and the time stamp field will display N/A. If a poll request has been received by the
DCT2000 but the system time of the DCT2000 has not yet been initialized, the time stamp field will display NOT AVAILABLE.
The LAST POLL ACK field contains the sequence number of the last poll acknowledge received by the DCT2000. The time stamp of the last poll acknowledge will be displayed immediately below
LAST POLL ACK . If no poll acknowledge has been received by the DCT2000, the sequence number field will display N/A and the time stamp field will display N/A. If a poll acknowledge has been received by the DCT2000 but the system time of the DCT2000 has not yet been initialized, the
time stamp field will display NOT AVAILABLE.
DCT 2000 Installation Manual
STARFONE Diagnostics
This diagnostic shows the status and operating parameters for the STARFONE module.
Figure B-19 illustrate the STARFONE diagnostics LED:
Figure B-19
STARFONE diagnostics - LED
Hang-up code
Transmitter status
Baud rate indicator
Parameter status
STARFONE
Status
Parental control
Carrier present
DCT 2000 Installation Manual
B - 2 8 D i a g n o s t i c s
Figure B-20 illustrates the STARFONE Diagnostics OSD:
Figure B-20
STARFONE Diagnostic - OSD
09 TELEPHONE MODEM
TYPE:
PARAMETERS
BAUD RATE
DATA FRMT
STARFONE 14.4K
: Not Verified
: 300
: 8, EVEN
PHONE NUMBERS
#1
#2
: 3435556666
: 3435556667
LAST POLL REQ
6-15-2001 20:49:33
LAST POLL ACK
6-15-2001 20:49:33
: 170
: 170
BUSY COUNT
NO ANSWER COUNT
LOST CARRIER COUNT
: 0
: 0
: 0
CARRIER :
STATUS:
HANGUP-NORMAL
The TYPE field describes the type of modem and the speed.
Table B-24 lists the STARFONE fourth-digit telephone parameters:
Table B-24
STARFONE fourth-digit parameter status
LED OSD Mode
P (flashing)
P (solid)
NOT VALID
SET
Telephone parameters not valid
Telephone parameters OK
DCT 2000 Installation Manual
Table B-25 lists the STARFONE third-digit baud rate:
Table B-25
STARFONE third-digit baud rate
LED OSD Mode
DATA FORMAT is the modem protocol.
PHONE NUMBERS are the numbers that the modem will dial.
Table B-26 lists the STARFONE transmitter status:
Table B-26
STARFONE transmitter status
1 s t Digit 2 n d Digit Meaning
h * On hook (* = hang-up code)
t – Test for line available
d – Dialing
A – Waiting for answer
c R Communicating, receiving
c T Communicating, transmitting
c – Communicating, idle
r * Waiting for retry (* = hang-up code)
The LAST POLL REQ field contains the sequence number of the last poll request received by the
DCT2000. The time stamp of the last poll request will be displayed immediately below LAST
POLL REQ . If no poll request has been received by the DCT2000, the sequence number field will display N/A and the time stamp field will display N/A. If a poll request has been received by the
DCT2000 but the system time of the DCT2000 has not yet been initialized, the time stamp field will display ‘‘Not available.’’
DCT 2000 Installation Manual
B - 3 0 D i a g n o s t i c s
The LAST POLL ACK field contains the sequence number of the last poll acknowledge received by the DCT2000. The time stamp of the last poll acknowledge will be displayed immediately below LAST POLL ACK. If no poll acknowledge has been received by the DCT2000, the sequence number field will display ‘‘N/A’’ and the time stamp field will display ‘‘N/A.’’ If a poll acknowledge has been received by the DCT2000 but the system time of the DCT2000 has not yet been initialized, the time stamp field will display NOT AVAILABLE. Table B-25 lists the STARFONE hang-up code:
Table B-27
STARFONE hang-up code
P t
C r c
L
E
U
Mode Status
–
A
Normal hang-up
Answer time-out
Phone ringing
Carrier loss
Line in use
Errors (data)
User line request
Parameters invalid
Data timeout
Communication protocol fault
DCT 2000 Installation Manual
d 10: Application (APP) Code Modules
This diagnostic displays the currently downloaded code modules. This can be a multi-page display. Press SELECT to display additional pages. The LED shows the downloaded status.
The LED diagnostic indicates the current download status. The data received indicator lights when downloaded data is received. The download packet counter counts down toward zero, indicating the remaining packets of the current module to be received. This counter will initially be blank, and after segment zero is received it shows the remaining packets. The data received indicator can be lit even if no additional packets are stored.
Figures B-21 and B-22 illustrate the application code module for LED and OSD:
Figure B-21
Application code module - LED
Table B-28 lists the mode for the first LED that indicates the current status of the download:
Table B-28
First LED indicating current status of download
First LED Mode
I
C d
Idle − no download in progress
Connected to download PID − awaiting data
Download in progress
Figure B-22 is an example of an OSD screen for a DCT2000 that contains ROM.
Figure B-22
APP Code Modules – OSDs
10 APP CODE MODULES
MODULE VER STATUS ID
DCT_ROM
Dct_plat
05.88
07.44
DISABLD 0000
ENABLED 0001
DCT 2000 Installation Manual
B - 3 2 D i a g n o s t i c s
Appl_____ 02.00
DOWNLD 07DA
Or
10 APP CODE MODULES
MODULE VER STATUS ID
Dct_plat
Appl_____
07.44
02.00
ENABLED
DOWNLD
0001
07DA
The DCT2000 model version indicates if a DCT_ROM module is installed. All DCT2000s with module version 6.X and below have a DCT_ROM module installed. All DCT2000s with module versions 7.X and higher are ROMLESS.
Status Modes
The STATUS modes available are:
LOADING
DELETED
ENABLING
ENABLED
DSABLNG
DISABLD
DELETNG
POSTPND
ENNORUN
DISNORUN
DCT 2000 Installation Manual
d 11: Memory Config
There is no LED for this diagnostic. The format of the OSD depends on the installed memory types. The PLATFORM shows sizes of memory types allocated to platform code. The
APPLICATION shows sizes of memory types allocated to application code. The SYSTEM HEAP shows breakdown of DRAM allocations.
Figure B-23 illustrates the Memory Status OSD:
Figure B-23
Memory Status OSD
11 MEMORY STATUS
EEPROM VER.NO.
NVMEM
DRAM
FLASH
ROM
PLATFORM
256k
512k
1M
1M
00.00
APPLICATION
20k
1.5M
1M n/a
Fail
0
0
0
0
0
0
DCT 2000 Installation Manual
B - 3 4 D i a g n o s t i c s
d 12: Interactive Info
The Interactive Info menu is a diagnostic tool used to gather information about your system.
Figure B-24 illustrates the OSD of the Interactive Info menu. There is no LED for the
Interactive Info menu.
Figure B-24
Interactive Info menu - OSD
12 INTERACTIVE INFO
IP
UPM
UPSTREAM ID
DOWNSTREAM ID
STATE
MAC ABORT CNTR
: 0.0.0.0
: 0X000021
: 0X0000
: 0X0000
: UNCONFIG
: 0000
GOOD PACKETS:
ERROR PACKETS:
2
3
4
SOCKET PORT STATE
0
1
UNUSED
UNUSED
UNUSED
UNUSED
UNUSED
State
The different modes for the STATE are:
MAC CONNECT
UNCONFIG
INIT_WAIT_DC_OR_
WAIT_LM_ACK
WAIT_SO_ACK
WAIT_LA_OR_SO
INIT_STOPPED
RUN_WAIT-DC-OR-C
RUNNING
RUN_STOPPED
INVALID
DCT 2000 Installation Manual
Socket Port State
The different modes for the SOCKET PORT STATE are:
UNUSED
OPENED
READY
RECVING
SENDING
DCT 2000 Installation Manual
B - 3 6 D i a g n o s t i c s
d 13: MAC Frequency Table
The DCT2000 uses a range of frequencies set by the host for upstream communications.
Figure B-25 is an example of the Mac Frequency Table OSD that will display your frequency and signal power:
Figure B-25
Mac Frequency Table - OSD
13 MAC FREQUENCY TABLE
FREQ POWER
d 14: Message Types
This diagnostic displays a listing of PIDs and counts. In addition the message types with IDs and counts are shown.
Figure B-26
Message Types - OSD
14 MESSAGE TYPES (hex data)
OOB:
PID
0000
0000
0
1
__
Msg Id
-
2
Cnt
0
0
INB:
PID Cnt
0000 4
0000 2
__
Cnt
216
89
Msg
9A
A0
Id
E
15
Lost DRAM
0 0
0 0
Cnt
0
0
d 15: In Band Program Association Table (PAT)
This diagnostic displays the Program Association Table Information. (For Motorola use only).
Figure B-27
In Band PAT - OSD
15 IN BAND PAT (hex data)
PAT
001
SN
0001
PID
0029
DCT 2000 Installation Manual
d 16: In Band Program Map Table (PMT)
This diagnostic displays the Program Map Table information. (For Motorola use only).
Figure B-28
In Band PMT – OSD
16 IN BAND PMT (hex data)
PAT
001
SN
0080
PID
0210
d 17: Task Status
This diagnostic displays a listing of tasks. (For Motorola use only).
Figure B-29
Task Status - OSD
17 TASK STATUS (hex data)
TID
64
63
…
0
RID PRI STARTS RUNTIME STK%
00 2 21553 47441 26
d 18: Keyboard/LED
This diagnostic is used to verify the functionality of the LED and front-panel keys. The LED diagnostic indicates the currently pressed key. One segment on each row is lit corresponding to the front-panel key. Each character is highlighted while the front panel key is held.
Figure B-30 illustrates the keyboard diagnostic OSD:
Figure B-30
Keyboard diagnostic −−−− OSD
KEYBOARD/LED DIAG
G < > V ^ I M S B + P
Press power button to exit OSD screen and return DCT to off state.
Press any key on the remote control to exit the keyboard diagnostic and display the Main menus.
DCT 2000 Installation Manual
NVOD
NVRAM
OSD
PCR
PID
PPV
QAM
QPSK
RSA
TCP/IP
CSR
DCT2000
EMM
HRC
IPG
IPPV
IR Blaster
IRC
MPAA
TRC
TvPC
VOD
A b b r e v i a t i o n s a n d A c r o n y m s
Customer Service Representative
Digital Consumer Terminal 2000 entitlement management message(s) harmonically related carriers interactive program guide
Impulse Pay-Per-View
Infrared Blaster incrementally related carriers
Motion Picture Advisory Association
Near Video on Demand
Non-volatile random-access memory on-screen display program clock reference packet identifier
Pay-Per-View quadrature amplitude modulation quadrature phase shift keying
Return for Service Authorization
Transmission Control Protocol/Internet Protocol
Technical Response Center
TV PassCard
Video on Demand
DCT2000 Installation Manual
484288-001
12/01 MGBI
advertisement
