Owner’s Instructions
HL-R4266W
Register your product at www.samsung.com/global/register
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 2
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 3
A Guide to Digital TV
• What is Digital Television?
Digital television (DTV) is a new way of transmitting high quality video and audio to your TV set.
Using DTV, broadcasters can transmit high definition TV (HDTV) images, Dolby digital surround
audio, and new services such as multicasting (transmitting more than one program on the same
TV channel) and datacasting. Several of these services can be combined into a single digital
broadcast.
Digital Television Services
• Digital Picture Quality
DTV programs are transmitted in two different formats. The first is Standard Definition Television
(SDTV) and the second is High Definition Television (HDTV).
• SDTV program formats include 480-line interlaced (480i) and 480-line progressive (480p) video.
480i programs are essentially a digital version of our current analog TV programs, while the 480p
format offers improved image detail over 480i. Some 480p programs are broadcast in widescreen
and are comparable to progressive-scan DVD movies in image quality.
• HDTV program formats include 1080-line interlaced (1080i) and 720-line progressive (720p).
Both HDTV formats are always broadcast in widescreen, and offer much higher picture quality than
SDTV.
• Dolby Surround Sound
With DTV, you can listen to a variety of Dolby digital audio formats from Dolby Surround 2.0 to
Dolby Digital 5.1 surround, using your home audio system. Many HDTV programs are now
broadcast with DD 5.1 soundtracks.
U.S.A Only
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third
parties. In particular, this product is licensed under the following US patents:
5,991,715, 5,740,317, 4,972,484, 5,214,678, 5,323,396, 5,539,829, 5,606,618, 5,530,655, 5,777,992,
6,289,308, 5,610,985, 5,481,643, 5,544,247, 5,960,037, 6,023,490, 5,878,080, and under US Published
Patent Application No. 2001-44713-A1.
This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are
granted for commercial use. The license does not cover any product unit other than this product unit and the license
does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used
or sold in combination with this product unit. The license only covers the use of this product unit to encode and/or
decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this license
for product features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC 13818-3.
Other countries
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain
third parties. This license is limited to private non-commercial use by end-user consumers for licensed contents.
No rights are granted for commercial use. The license does not cover any product unit other than this product unit
and the license does not extend to any unlicensed product unit or process conforming to ISO/IEC 11172-3 or
ISO/IEC 13818-3 used or sold in combination with this product unit. The license only covers the use of this
product unit to encode and/or decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3.
No rights are granted under this license for product features or functions that do not conform to the ISO/IEC
11172-3 or ISO/IEC 13818-3.
English - 3
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 4
CableCARD and Digital Cable Ready TVs
CableCARD and Digital Cable Ready TVs are the products of a new digital cable standard.
This new standard is called OpenCable and it is a concerted effort to standardize the digital cable
service network interface in North America. For more information, please refer to www.cablelabs.com.
Digital Cable Ready TVs are equipped with a proper digital cable tuner to receive digital cable signals
from your local cable service provider. They are also designed to work with digital cable card modules
(PCMCIA card modules called CableCARDs). These PCMCIA card modules or CableCARDs will be
provided by your local cable service provider after a proper subscription process.
The provided CableCARD from your local cable service provider needs to be inserted into the
CableCARD slot of a Digital Cable Ready TV. Please refer to page 22 for how to insert the CableCARD.
A digital set-top box which used to be provided by the cable service provider is no longer needed with
Digital Cable Ready TVs and CableCARDs.
When CableCARD is inserted into the slot, the TV screen will show the message that CableCARD is
inserted and tries to download necessary data such as channel information or subscription information
from your digital cable service provider. When you insert CableCARD for the first time, this process
could take few minutes depending on the amount of data your cable provider needs to send.
During this process the digital cable service provider or CableCARD may display messages on the TV
screen to help or give you further information.
Please contact your local cable provider for more information on service availability and how to
acquire a CableCARD.
NOTE
• This television receiver supports the copy protection system regulated by DTLA (Digital Transmission
Licensing Administrator). It should be noted that copy protected content may not be viewable
depending on your particular connections.
English - 4
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 5
Q&A
1. Is the antenna I use for existing TV reception good enough for DTV?
Over-the-air (OTA) digital TV broadcasting uses the same channels as analog TV and works well
with many existing TV antennas. However, DTV broadcast channel assignments are different than
analog channels. You should find out whether your local DTV broadcasts are on VHF (channels
2-13) or UHF (channels 14-69) to see if you need a different antenna.
If your DTV channels are on UHF and you already get good UHF reception, your present antenna
may work fine. The same holds true for VHF DTV reception. Note that in some markets, both VHF
and UHF channels are used for DTV broadcasts.
You can find out the latest DTV channel assignments for your area by browsing selected Internet
web sites such as www.titantv.com, www.10000watts.com, and www.fcc.gov.
2. How difficult is it to receive DTV signals indoors?
This depends on whether your local DTV stations are running full power or not and how close your
location is to the transmission tower. DTV receivers do not require as much signal as analog TV
receivers to produce high-quality images and sound.
Once the DTV signal level exceeds a certain threshold at the receiver, the digital video and audio
data is decoded at the same quality it was originally encoded for broadcast.
This is a big advantage for DTV over analog TV - there is no noise, ghosting, static, or scratchy
audio.
3. How can I connect an antenna in my townhouse, co-operative apartment,
condominium, or apartment?
The Federal Communications Commission’s OTARD Rule (part of the Telecommunications Act of
1996) allows residents of condominiums, townhouse, or members of neighborhood associations to
put up outside antennas for reception of broadcast TV signals as long as those antennas are not
located in common areas and are no more than 12’ in height.
Residents of rental units (apartments, etc.) are not covered by the OTARD rules and will have to use
indoor antennas to receive DTV broadcasts. It is possible that the landlord of an apartment complex
can provide broadcast DTV signals via a master TV antenna system to each apartment.
4. Can I connect my DTV set-top receiver to my cable TV service?
Cable TV systems use a different method for transmitting digital TV programs that is currently
incompatible with broadcast DTV set-top receivers. So you will still need to use an outdoor or
indoor antenna to receive OTA broadcast DTV programs.
The good news is that you won’t have to pay a monthly or per-program charge to watch OTA DTV
and HDTV programs. They’re free, unlike subscription satellite TV or premium cable TV. All you
need is an antenna and a DTV set-top receiver to enjoy clear, sharp widescreen images and
high-quality audio.
English - 5
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 6
Table of Contents
Your New Wide TV.................................................................................10
Viewing Position ....................................................................................................10
List of Features.......................................................................................................11
Accessories ...........................................................................................................11
Right side buttons...................................................................................................12
Side Panel Jacks ................................................................................................... 12
Front Panel LED Indicators.......................................................................................13
Rear Panel Jacks ....................................................................................................14
Remote Control......................................................................................................15
Connections ...........................................................................................18
Connecting VHF and UHF Antennas ........................................................................18
Antennas with 75-ohm Round Leads ..............................................................18
Connecting Cable TV .............................................................................................19
Cable without a Cable Box...........................................................................19
Cable with a Cable Box that Descrambles All Channels...................................19
Cable with a Cable Box that Descrambles Some (But Not All) Channels ............20
Connecting a VCR .................................................................................................21
Connecting a VCR to the Video or S-Video/Audio jack....................................21
Connecting CableCARD .........................................................................................22
Connecting a Camcorder .......................................................................................23
Connecting a DVD Player .......................................................................................24
Connecting to Y, PB, PR .................................................................................24
Connecting to Audio and Video Jacks............................................................24
Connecting a DTV Set-Top Box ................................................................................25
Connecting to Y, PB, PR .................................................................................25
Connecting to DVI (Digital Visual Interface) ....................................................25
Connecting to HDMI (High Definition Multimedia Interface) ..............................26
Connecting a Digital Audio System..........................................................................27
Connecting to an Analog Amplifier..........................................................................27
Operation ..............................................................................................30
Turning the TV On and Off .....................................................................................30
Viewing the Menus and On-Screen Displays .............................................................30
Selecting a Menu Language....................................................................................31
Memorizing the Channels .......................................................................................32
Adding and Erasing Channels.................................................................................34
Changing Channels ...............................................................................................35
Customizing Your Remote Control ............................................................................36
Remote Control Codes............................................................................................37
Setting the Clock....................................................................................................38
Setting the On/Off Timer ........................................................................................40
Setting the Sleep Timer ...........................................................................................41
Viewing an External Signal Source ..........................................................................42
Assigning Names to External Input Mode .................................................................43
English - 6
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 7
Channel Control .....................................................................................46
Selecting Your Favorite Channels .............................................................................46
Labeling the Channels ............................................................................................47
Fine Tuning Analog Channels Analog ........................................................................48
Checking the Digital-Signal Strength Digital ..............................................................49
LNA (Low Noise Amplifier) .....................................................................................50
Picture Control ........................................................................................52
Picture Control.......................................................................................................52
Changing the Picture Size.......................................................................................55
Digital Noise Reduction ..........................................................................................56
Viewing the DNIe Demonstration .............................................................................57
Setting the My Color Control Mode .........................................................................58
Using the Color Weakness Enhancement Feature.......................................................60
Setting the Film Mode ............................................................................................61
Viewing Picture-In-Picture.........................................................................................62
Freezing the Picture................................................................................................69
Setting the Blue Screen Mode..................................................................................70
Sound Control ........................................................................................72
Sound Control .......................................................................................................72
Auto Volume..........................................................................................................74
Choosing a Multi-Channel Sound (MTS) track Digital .................................................75
Choosing a Multi-Channel Sound (MTS) track Analog .................................................76
Choosing a Digital Sound Format Digital ..................................................................77
Selecting the Internal Mute......................................................................................78
Setting the On/Off Melody.....................................................................................79
Special Features .....................................................................................82
Setting the Function Help ........................................................................................82
Menu Transparency Level........................................................................................83
Using the V-Chip....................................................................................................84
Viewing Closed Captions (On-Screen Text Messages) Analog ......................................94
Viewing Closed Captions (On-Screen Text Messages) Digital ......................................96
Using the CableCARD ............................................................................................98
Using the CableCARD Setup Function ......................................................................99
Using the Guide ..................................................................................................101
Appendix ............................................................................................104
PIP Settings .........................................................................................................104
Replacing the Lamp..............................................................................................104
Troubleshooting ...................................................................................................106
Cleaning and Maintaining Your TV ........................................................................107
Using Your TV in Another Country .........................................................................107
Specifications ......................................................................................................107
English - 7
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 8
SAMSUNG
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 9
Your New Wide TV
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 10
Your New Wide TV
Viewing Position
To optimize your viewing comfort, please follow the guidelines below for viewing distance.
If viewing for an extended period of time, sit as far back from the screen as possible.
When installing the product, make sure to keep
it away from the wall (more than 10cm/4inches)
for ventilation purposes.
• Poor ventilation may cause an increase in the
internal temperature of the product, resulting
in a shortened component life and degraded
performance.
English - 10
BP68-00496A-01(002~017)
3/9/05
2:24 PM
Page 11
List of Features
Your TV was designed and engineered using the latest technology. It is a full-featured, high-performance
unit that exceeds industry standards. In addition, it has these special features:
• Easy-to-operate remote control
• Easy-to-use on-screen menu system you can access from right side buttons or remote control
• Automatic timer to turn the TV on and off at any time you choose
• Adjustable picture and sound settings and the ability to memorize your favorite settings
• Automatic channel tuning for up to 181 channels
• A special filter to reduce or eliminate reception problems
• Fine tuning control for the sharpest picture possible
• A built-in multi-channel sound decoder for stereo and bilingual listening
• Built-in, dual channel speakers
• A special sleep timer
• Picture-in-Picture capability that let you watch two channels at once
• Widescreen TV with adjustable image size
• Life-like clear images provided by DNle technology
• My Color Control Mode for corresponding with your color style
• Color weakness Mode
• Digital Input (HDMI/DVI IN) jack
• Digital Audio Output (OPTICAL) jack
• AV network system (Anynet) that enables you to easily control Samsung audio-video(AV) devices from
this TV.
• CableCARD slot
Accessories
Once you have unpacked your TV, check to make sure that you have all the parts shown here.
If any piece is missing or broken, call your dealer.
Remote Control
(BP59-00084A)/
AAA Batteries
Owner’s Instructions
Anynet Cable
(BN39-00518B)
Power Cord
(3903-000144)
English - 11
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 12
Your New Wide TV
Right side buttons
The buttons on the right side panel control your TV’s basic features, including the on-screen menu system.
To use the more advanced features, you must use the remote control.
Press to switch between viewing TV programs and signals from connected components.
Press to see the on-screen menu.
Press to raise or lower the volume and to select items when using the on-screen menu.
Press to change channels and move between items on the on-screen menu.
Press to activate (or change) a particular item.
Side Panel Jacks
Use the right side panel jacks to connect a component that is used only occasionally (a camcorder or
video game, for example).
Connect the video signal from a camcorder or video game.
Connect the audio signal from a camcorder or video game.
Connect an S-Video signal from a camcorder or video game.
(S-Video 3 jack and Audio L/R input 3 are used in conjunction.)
English - 12
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 13
Front Panel LED Indicators
The three lights on the front panel indicate the status of your TV.
POWER
Press to turn the TV on and off.
Remote Control Sensor
Aim the remote control towards this spot on the TV.
Indicator Light Key
: Light is On
: Light is Blinking
: Light is Off
TIMER LAMP STAND BY/TEMP
Indication
Standby state.
The picture will automatically appear in about 15 seconds.
Auto Timer ON/OFF has been set and the set will automatically be
turned on in about 25 seconds.
A cooling fan inside the set is not operating normally.
Lamp cover on the rear of the set is not properly shut.
Check if the ventilation hole on the rear of the set is blocked, because
if the inner temperature is too high, the power will shut off.
Lamp may be defective. Please contact a certified technician.
• It takes about 30 seconds for the TV to warm up, so normal brightness may not appear immediately.
• The TV has a fan to keep the inside lamp from overheating. You’ll occasionally hear it working.
English - 13
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 14
Your New Wide TV
Rear Panel Jacks
Use the rear panel jacks to connect components such as a VCR. You can connect different components
such as VCRs, Set-Top Box and a DVD player etc., because there are two sets of video input jacks and
two sets of component video input jacks on the rear panel of your TV. For more information, see
“Connections”.
ΠANTENNA terminals
Two independent cables or antennas can be connected to
these terminals. Use “ANT 1 IN (CABLE)” and “ANT 2 IN (AIR)”
terminals to receive a signal from VHF/UHF antennas or your
cable system. (Refer to pages 18~20)
´ SERVICE
This jack is for software upgrades.
ˇ S-VIDEO INPUT jacks
Connects an S-Video signal from an S-VHS VCR or DVD player.
(Refer to page 23)
¨ DVI (Digital Video Interface) AUDIO INPUT jacks
Connect to the digital audio output jacks of a device with DVI
output. (Refer to page 25)
ˆ VIDEO/AUDIO INPUT jacks
Connect video/audio signals from external sources, such as VCR
or DVD players. (Refer to page 24)
Ø VIDEO/AUDIO OUTPUT jacks
Sends video/audio signals from the TV to an external source,
such as a VCR. These jacks are available only in RF, Video and
S-Video modes.
English - 14
∏ COMPONENT1, 2 jacks (Y, PB, PR, L, R)
Use these jacks to connect the component video/audio signals
from a DVD player or a Set-Top Box. (Refer to pages 24~25)
” DIGITAL AUDIO OUT (OPTICAL) jack
Connect to a Digital Audio Component. (Refer to page 27)
’ Anynet
Please refer to the Anynet Owner’s Instruction.
˝ HDMI (High Definition Multimedia Interface)/
DVI INPUT jack
Connect to the HDMI jack of a device with HDMI output.
These inputs can also be used as a DVI connection with separate
analog audio inputs. An optional HDMI/DVI cable will be
necessary to make this connection. When using the optional
HDMI/DVI adapter, the DVI analog audio inputs on your TV
allow you to receive left and right audio from your DVI device.
(Refer to pages 25~26)
Ô CableCARDTM
Insert the CableCARD into the slot. (Refer to page 22)
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 15
Remote Control
You can use the remote control up to about 23 feet from the TV. When using the remote control,
always point it directly at the TV. You can also use your remote control to operate your VCR,
Cable box, DVD player or Samsung Set-Top Box. See pages 36~37 for details.
1. POWER
Turns the TV on and off.
2. P.MODE
Adjust the TV picture by selecting one of
the preset factory settings (or select your
personal, customized picture settings.)
3. ANTENNA
Press to select “AIR” or “CABLE”.
4. CHANNEL NUMBER
Press to directly tune to a particular channel.
5. Press to select additional channels (digital
and analog) being broadcast by the same
station. For example, to select channel
“54-3”, press “54”, then press “-” and “3”.
6. VOL +, VOL Press to increase or decrease the volume.
7. MUTE
Press to mute the TV sound.
8. Anynet
Runs the Anynet view functions and sets up
Anynet devices.
9. MENU
Displays the main on-screen menu.
10. CH.LIST
Displays the channel list.
11. FAV.CH (Favorite Channel)
Press to switch between your favorite
channels.
12. MODE
Selects a target device to be controlled by
the Samsung remote control (i.e., TV, STB,
VCR, CABLE, or DVD).
13. PRE-CH
Tunes to the previous channel.
14. SOURCE
Press to display all of the available video
sources (i.e., TV, Set-Top Box, VCR, DVD,
DTV).
15. CH
/
Press to change channels.
Moves from one set of screen information to
the next in TV Guide menu.
16. INFO
Press to display information on the TV
screen.
18. ▲, ▼, œ, √, ENTER
Press to select highlight up, down, left, or
right. While using the on-screen menus,
press ENTER to activate (or change) a
particular item.
19. MTS (Multichannel Television
Stereo)
Press to choose Stereo, Mono or SAP
(Secondary Audio Program).
20. PIP (Picture In Picture)
Displays the available channels in sequence.
(These buttons change channels in the PIP
window only.)
21. STILL
Press to pause the current screen.
22. P.SIZE
Press to change the screen size.
23. DNSe
DNSe enhances the sound quality for a more
vibrant reality, automatically controls output,
and prevents sound distortion.
Press this button to set it On or Off.
24. DNIe (Digital Natural Image
engine)
Activates DNIe Demo mode.
25. SET
Used during set up of this remote control,
so that it will work compatibly with other
devices (Set-Top Box, VCR, Cable box, DVD,
etc.)
26. SLEEP
Press to select a preset time interval for
automatic shut off.
27. PIP Controls
CH / : Press to display the available
channels in sequence. (These buttons change
channels in the PIP window only.)
28. CAPTION
Controls the caption decoder.
29. VCR/DVD Controls
Controls VCR or DVD functions: Rewind, Stop,
Play/Pause, Fast Forward.
30. RESET
If your remote control is not functioning
properly, take out the batteries and press
the reset button for about 2~3 seconds.
Re-insert the batteries and try using the
remote control again.
17. EXIT
Press to exit the menu.
English - 15
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 16
Your New Wide TV
Installing Batteries in the Remote Control
With normal use, the batteries in the remote control should last about a year. If you notice a performance
degradation while using the remote, the batteries may need to be replaced. Make sure you replace both
batteries and do not mix old and new batteries in the remote control. If you won’t be using the remote
control for a long time, remove the batteries and store them in a cool dry place.
1
Slide the back cover all the way out to open
the battery compartment of the remote control.
2
Install two AAA size batteries. Make sure to
match the “+” and “–” ends of the batteries
with the diagram inside the compartment.
3
Slide the cover back into place.
NOTE
• Do not mix battery types, i.e, alkaline and manganese.
English - 16
BP68-00496A-01(002~017)
3/8/05
2:59 PM
Page 17
Connections
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 18
Connections
Connecting VHF and UHF Antennas
If you do not have a cable system, you will need to connect an antenna to your TV.
Antennas with 75-ohm Round Leads
If your antenna looks like this:
1
Plug the antenna lead into
the ANT 2 IN (AIR) on the
rear panel of your TV.
English - 18
it has 75-ohm round leads.
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 19
Connecting Cable TV
You can connect different cable systems to your TV, including cable without a Cable box,
and cable with a Cable box that descrambles some or all channels.
Cable without a Cable Box
1
Plug the incoming cable into
the ANT 1 IN (CABLE) on the
rear panel of your TV.
Cable with a Cable Box that Descrambles All Channels
1
Find the cable connected to
the ANTENNA OUT
terminal on your Cable box.
This terminal might be
labeled “ANT OUT”, “VHF
OUT” or simply “OUT”.
2
Connect the other end of
the cable to the “ANT 1 IN
(CABLE)” terminal on the
rear panel of your TV.
English - 19
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 20
Connections
Cable with a Cable Box that Descrambles Some (But Not All) Channels
To complete this connection you will need a two-way splitter, an RF (A/B) switch, and four coaxial
cables (which you can buy from your Samsung dealer or any electronics store).
1
Find and disconnect the
cable that is connected to
the ANTENNA IN terminal
of your Cable box.
This terminal might be
labeled “ANT IN”, “VHF IN”
or simply, “IN”. Connect this
cable to a two-way splitter.
2
Connect a coaxial cable
between an OUT terminal
of the splitter and the IN
terminal of the Cable box.
3
Connect a coaxial cable
between the ANTENNA OUT
terminal of the Cable box
and the B-IN terminal of the
RF (A/B) switch.
4
Connect a coaxial cable
between the other OUT
terminal of the Cable box
and the A-IN terminal of the
RF (A/B) switch.
5
Connect the last coaxial
cable between the OUT
terminal of the RF (A/B)
switch and the ANT 1 IN
(CABLE) on the TV.
After you’ve made this connection, set the A/B switch to the “A” position for normal viewing.
Set the A/B switch to the “B” position to view scrambled channels. (When you set the A/B switch
to “B”, you will need to tune your Set-Top Box to the Cable box's output channel, which is usually
channel 3 or 4.)
English - 20
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 21
Connecting a VCR
Connecting a VCR to the Video or S-Video/Audio jack
1
Connect the Video/Audio
cables between the VIDEO
or S-VIDEO/AUDIO input
jacks on the TV and VIDEO
or S-VIDEO/AUDIO output
jacks on the VCR.
2
Connect a coaxial cable
between the Antenna out
terminal (i.e., “OUT to TV”)
on the VCR and the ANT 1
IN (CABLE) on the TV.
3
Connect a video cable
between the S-VIDEO IN
jack on the TV and the
S-VIDEO OUT jack on the
VCR.
NOTES
TV Rear Panel
2
1
3
Incoming
Cable or
Antenna
Stereo VCR
• For better video, use an
S-Video cable.
• Please be sure to match the
color coded input terminals
and cable jacks.
English - 21
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 22
Connections
Connecting CableCARD
You must obtain a CableCARD from a local cable service provider.
1
2
Insert the CableCARD into
the “CableCARD” slot and
the message “CableCARDTM
Inserted” is displayed on
the screen. If the channel
information does not
already exist, the message
“Updating Channel List” is
displayed during channel
information configuration.
TV Rear Panel
Incoming
Cable or
Antenna
When channel information
configuration is finished,
the message “Updating
Completed” is displayed.
It indicates that the channel
list is now updated.
Please insert the
card as shown.
English - 22
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 23
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a Camcorder to your TV.
You can use your camcorder to view tapes without using a VCR.
1
2
3
Locate the A/V output jacks
on the camcorder. They are
usually found on the side or
back of the camcorder.
Connect a set of audio
cables between the AUDIO
IN jacks on the TV and the
AUDIO OUT jacks on the
camcorder. If you have a
mono Camcorder, connect
L(mono) to the Camcorder
audio out using only one
audio cable.
Connect a video cable
between the VIDEO IN (or
S-VIDEO IN) jack on the TV
and the VIDEO OUT jack
on the Camcorder. The
audio-video cables shown
here are usually included
with a Camcorder. (If not,
check your local electronics
store.) If your Camcorder is
stereo, you need to connect
a set of two cables.
1
Camcorder
Output Jacks
TV Rear of right side
Camcorder
2
3
or
English - 23
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 24
Connections
Connecting a DVD Player
The rear panel jacks on your TV make it easy to connect a DVD player to your TV.
Connecting to Y, PB, PR
1
2
Connect a set of audio
cables between the
COMPONENT (1 or 2)
AUDIO (L, R) IN jacks on
the TV and the AUDIO OUT
jacks on the DVD player.
TV Rear Panel
Incoming
Cable or
Antenna
To enable Component video
viewing, connect a set of
video cables between the
COMPONENT (1 or 2)
VIDEO (Y, PB, PR) IN jacks
on the TV and VIDEO
(Y/PB/PR or Y/CB/CR) OUT
jacks on the DVD player.
2
1
DVD Player
Connecting to Audio and Video Jacks
1
Connect a set of audio
cables between the AUDIO
IN (1 or 2) jacks on the TV
and the AUDIO OUT jacks
on the DVD player.
2
Connect a video cable
between the VIDEO IN (1
or 2) jack on the TV and the
VIDEO OUT jack on the
DVD player.
TV Rear Panel
Incoming
Cable or
Antenna
2
NOTE
• For an explanation of
Component video, see your
DVD player’s owner’s
manual.
English - 24
DVD Player
1
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 25
Connecting a DTV Set-Top Box
Connecting to Y, PB, PR
1
Connect a set of audio
cables between the
COMPONENT (1 or 2)
AUDIO (L, R) IN jacks on
the TV and the AUDIO OUT
jacks on the Set-Top Box.
2
Connect a set of video
cables between the
COMPONENT (1 or 2)
VIDEO (Y, PB, PR) IN jacks
on the TV and VIDEO
(Y/PB/PR or Y/CB/CR) OUT
jacks on the Set-Top Box.
TV Rear Panel
2
1
Incoming
Cable or
Antenna
DTV Set-Top Box
Connecting to DVI (Digital Visual Interface)
1
Connect a set of audio
cables between the DVI
AUDIO (L, R) IN jacks on the
TV and the AUDIO OUT
jacks on the Set-Top Box.
2
Connect an HDMI/DVI
video cable between the
HDMI/DVI IN jack on the
TV and the DVI OUT jack
on the Set-Top Box.
TV Rear Panel
2
NOTES
• For an explanation
of Component video, see
your Set-Top Box owner’s
manual.
• Requires a Cable Converter.
1
Incoming
Cable or
Antenna
DTV Set-Top Box
English - 25
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 26
Connections
Connecting to HDMI (High Definition Multimedia Interface)
1
Connect an HDMI cable
between the HDMI/DVI IN
jack on the TV and the HDMI
OUT jack on the Set-Top Box.
TV Rear Panel
NOTE
• Make sure the HDMI/DVI
source’s power is on, or you
will be unable to select it in the
TV menu’s source list.
Incoming
Cable or
Antenna
DTV Set-Top Box
English - 26
BP68-00496A-01(018~029)
3/10/05
3:29 PM
Page 27
Connecting a Digital Audio System
There are many types of digital audio systems on the market today.
A simplified illustration of an audio system is shown below. For more information, see your
audio system owner’s manual.
1
If your audio system has an
optical digital audio input,
connect to the “DIGITAL
AUDIO OUT (OPTICAL)” jack
on the TV.
TV Rear Panel
NOTE
• OPTICAL: converts the electric
signal into an optical light
signal, and transmits it through
glass fibers. A transmission
system of digital audio in the
form of a light wave, S/PDIF
format using a glass conductor.
See page 77 to set the digital
output format (Dolby Digital or
PCM) appropriate to your
digital audio component.
Audio System
Connecting to an Analog Amplifier
1
The “AUDIO OUT” terminals
cannot be used for external
speakers. You must hook
them up to an amplifier.
When an audio amplifier is
connected to the “AUDIO
OUT” terminals: Decrease
the gain (volume) of the
audio amplifier, make the
internal mute on and adjust
the volume level with the
volume control of the
amplifier.
TV Rear Panel
NOTE
• In case the input is HDMI or
Component, the audio monitor
output signal is available only
when Internal Mute is On.
(Refer to page 78)
Amplifier
English - 27
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 28
SAMSUNG
BP68-00496A-01(018~029)
3/8/05
3:00 PM
Page 29
Operation
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 30
Operation
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the POWER button on the front panel.
Viewing the Menus and On-Screen Displays
The on-screen menu system allows you to control the settings of your TV. Access the on-screen menu
system by pressing the MENU button on the remote control. Once the on-screen menu appears, use
the …/†/œ/√/ENTER buttons on your remote control to select menu items and make adjustments.
You can also view the on-screen menu system and make some adjustments using the TV’s side panel
buttons.
Viewing the Menus
1
2
3
Press the MENU button.
The main menu is displayed.
There are six menu groups:
“Input”, “Picture”, “Sound”,
“Channel”, “Setup”, and
“Guide”.
Press the … or † button to
select an item you want
in the menu.
Press the œ, √ or ENTER
button to display, change,
or use the selected items.
Use the ENTER button to
enter items in the menu.
Input
Input
Source List
Edit Name
Anynet
Sound
Channel
Setup
Guide
Move
Enter
Sound
Channel
Setup
Guide
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Viewing the Display
English - 30
Exit
Input
Press the EXIT button to exit.
Press the INFO button on the
remote control.
The TV displays the current
channel, the status of certain
picture and sound settings and
the current time.
The information displayed varies
according to the selected source.
√
√
: TV
Cable 3
Picture Mode
Standard
Sound Mode
Custom
MTS
Stereo
Caption
Off
V-Chip
Off
No Time Information
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 31
Selecting a Menu Language
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press the
ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the ENTER button to
select “Language”.
Press the … or † button to
select “English”, “Español”
or “Français”, then press the
ENTER button.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Setup
Input
Sound
Channel
Setup
Guide
Language
: English
English
Español
Time
Français
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Press the EXIT button to exit.
English - 31
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 32
Operation
Memorizing the Channels
Your TV can memorize and store all of the available channels for both “off-air” (antenna) and cable
channels. After the available channels are memorized, use the CH
and CH
buttons to scan
through the channels. This eliminates the need to change channels by entering the channel digits.
There are three steps for memorizing channels: selecting a broadcast source, memorizing the channels
(automatic) and adding and deleting channels (manual).
Selecting the Video Signal Source
Before your television can begin memorizing the available channels,
you must specify the type of signal source that is connected to the TV
(i.e., an antenna or cable system).
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the ENTER button to
select “Antenna”.
Press the … or † button to
select “Air” or “Cable”, then
press the ENTER button.
3
Move
Enter
Return
Channel
Input
Sound
Channel
Setup
Guide
Press the … or † button to
select “Auto Program”, then
press the ENTER button.
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Antenna
:Air
Cable
Cable
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: Off
Move
Enter
Return
Channel
Input
Sound
Channel
Setup
Guide
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Move
Enter
Return
NOTE
• All available DTV and analog channels are automatically stored
in memory.
English - 32
BP68-00496A-00(030~051)
4
3/3/05
1:07 PM
Page 33
Press the … or † button to select the
Antenna connection, then press the
ENTER button.
• Air : “Air” antenna signal
Cable : “Cable” antenna signal
Air+Cable : “Air” and “Cable”
antenna signals
• If the CableCARD is inserted into the
“CableCARD” slot on the rear panel,
“Cable” and “Air+Cable” are not
available.
When selecting Cable TV system:
Press the ENTER button to start the auto
program. By default, the cable TV system
is set to “STD”.
If you want to select another type of
cable system, press the œ button and
use the … or † button to select
Analog or Digital “STD”, “HRC” or
“IRC”. Press the ENTER button.
Auto Program
Input
Select the antennas to memorize.
Air
Start
Sound
Cable
Start
Air+Cable
Start
Channel
Setup
Guide
Move
Enter
Return
Auto Program
Input
Sound
Channel
Setup
Select the cable system.
Analog
✔
STD
HRC
IRC
Start
Digital
✔
STD
HRC
IRC
Guide
Move
Enter
Return
• STD, HRC and IRC identify various types of cable TV systems.
Contact your local cable company to identify the type of cable system
that exists in your particular area.
At this point the signal source has been selected.
5
Press the √ button to select “Start”, then
press the ENTER button to start the auto
program. The TV begins memorizing all
available stations. Press the ENTER button
at any time to interrupt the memorization
process.
Auto Program
Input
Sound
Channel
Setup
Guide
Select the cable system.
Analog
✔
STD
HRC
IRC
Start
Digital
✔
STD
HRC
IRC
Move
Enter
Return
Press the EXIT button to exit.
Auto Program
• The TV must be connected to an
antenna in order to receive digital TV
signals. Even if a particular channel
is deleted from the memory, you can
always tune to that channel directly
by using the number buttons on the
remote control.
Auto Program in progress
Cable Channel 26
Stop
Enter
Return
English - 33
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 34
Operation
Adding and Erasing Channels
You can add channels that were not memorized (or delete unwanted channels from memory).
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Add/Delete”, then
press the ENTER button.
Sound
Setup
Guide
3
Enter
Return
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Move
Enter
Return
Add/Delete
Cable 26
Not In Memory
Press ENTER to add the channel.
Add
Move
Enter
Return
Add/Delete
Cable 26
In Memory
Press ENTER to delete the channel.
Press the EXIT button to exit.
Delete
Move
English - 34
Move
Channel
Input
Channel
Repeatedly pressing the
ENTER button will alternate
between add channel and
delete channel.
Press the CH
or CH
button to switch to the
appropriate channel, then
repeat above.
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Enter
Return
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 35
Changing Channels
Using the Channel Buttons
Press the CH
or CH
button to change channels.
When you press the CH
or CH
button, the TV changes channels in sequence.
You will see all the channels that the TV has memorized.
(The TV must have memorized at least three channels.)
You will not see channels that were either erased or not memorized.
Using the Number Buttons
Use the number buttons to quickly switch to any channel.
Press the number buttons to go directly to a channel. For example, to select channel 27, press
“2,” then “7.” The TV will change channels when you press the second number.
Using the “-” Button
The “-” button is used to select stations that broadcast both a digital and analog signal.
For example, for channel 7-1
(digital), press “7”, then “-”,
then “1”.
DTV Air
7-1
English
Picture Mode
Sound Mode
MTS
Caption
V-Chip
12:00 am
For channel 7-2 (analog), press
“7”, then “-”, then “2”.
Standard
Standard
English
On
Off
Air 7-2
Mono
Picture Mode
Sound Mode
MTS
Caption
V-Chip
12:00 am
NOTE
• HD indicates the TV is
receiving a Digital High
Definition signal.
SD indicates the TV is
receiving a Analog
standard definition
signal.
Standard
Standard
Stereo
On
Off
Using the Previous Channel
Press the PRE-CH button.
The TV changes to the last channel you were watching.
English - 35
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 36
Operation
Customizing Your Remote Control
Your TV comes equipped with a universal remote control. In addition to controlling the TV, the universal
remote control can also operate a VCR, Cable box, DVD, and Samsung Set-Top Box (even if your
VCR, Cable box and DVD are made by manufacturers other than Samsung).
NOTE
• The remote control might not be compatible with all VCRs, DVD players and Cable boxes.
Setting Up Your Remote Control to Operate Your VCR (Cable box or
DVD player)
1
2
Turn off your VCR (Cable box or DVD player).
3
4
On your Samsung remote control, press the SET button.
5
Press the POWER button. Your VCR (Cable box or DVD player)
should turn on. If your VCR (Cable box or DVD player) turns on,
your remote control is now set correctly.
If your VCR (Cable box or DVD player) does not turn on, repeat
steps 2, 3, and 4, but try one of the other codes listed for the
brand of your particular VCR (Cable box or DVD player).
6
Once your remote control is set up, press the MODE button any
time you want to use the remote to operate your VCR (Cable box
or DVD player).
Press the MODE button to switch the remote control to the VCR
(CABLE or DVD) mode.
The remote control has five modes: TV, STB, VCR, CABLE, and
DVD.
Enter 3 digits of the VCR (Cable box or DVD player) code listed
on next page for your brand of VCR (Cable box or DVD player).
Make sure you enter 3 digits of the code, even if the first digit is
a “0”. (If more than one code listed, try the first one.)
NOTES
• When your remote is in the TV mode, the VCR (or DVD player)
control buttons (REW, STOP, PLAY/PAUSE, and FF) will still operate
your VCR (or DVD player).
• When your remote control is in the STB, VCR, CABLE, or DVD mode,
the volume buttons still control your TV’s volume.
English - 36
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 37
Remote Control Codes
VCR Codes
Cable Box Codes
DVD Codes
English - 37
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 38
Operation
Setting the Clock
Setting the clock is necessary in order to use the various timer features of the TV.
Also, you can check the time while watching the TV. (Just press the INFO button.)
Option 1: Setting the Clock Manually
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Time”, then press the
ENTER button.
Press the ENTER button to
select “Clock”.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Time
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock
Sleep Timer
On Timer
Off Timer
√
√
√
√
: Off
: Inactivated
: Inactivated
Setup
Guide
3
Press the ENTER button to
select “Clock Mode”.
Press the … or † button to
select “Manual”, then press
the ENTER button.
Move
Enter
Return
Clock
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock Mode
Clock Set
Time Zone
DST
: Manual
Auto
Auto
: No
Setup
Guide
4
Press the … or † button to
select “Clock Set”, then
press the ENTER button.
Move
Enter
Return
Clock
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock Mode
Clock Set
Time Zone
DST
√
√
√
√
: Manual
: No
Setup
Guide
5
Press the œ or √ button to
move to “Month”, “Day”,
“Year”, “Hour”, “Minute”,
or “am/pm”. Set the clock
you want by pressing the
… or † button, then press
the ENTER button.
Move
Enter
Return
Clock Set
Input
Enter the current date and time.
Month
Sound
--
Day
Year
--
----
Hour
Minute
am/pm
--
--
--
▲
Channel
Setup
Guide
▼
Move
Adjust
Return
• You can set the month,
day, year, hour and minute
directly by pressing the number
buttons on the remote control.
Press the EXIT button to exit.
NOTE
English - 38
• The current time will appear every time you press the INFO button.
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 39
Option 2: Setting the Clock Automatically
The Clock can be set automatically if you are receiving a digital signal.
1
Press the MENU button.
Press the … or † button to select “Setup”,
then press the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to select “Time”,
then press the ENTER button.
Press the ENTER button to select “Clock”.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Time
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock
Sleep Timer
On Timer
Off Timer
√
√
√
√
: Off
: Inactivated
: Inactivated
Setup
Guide
3
Press the ENTER button to select “Clock
Mode”.
Press the … or † button to select “Auto”,
then press the ENTER button.
Move
Enter
Return
Clock
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock Mode
Clock Set
Time Zone
DST
:Manual
Auto
Auto
: No
Setup
Guide
4
Press the … or † button to select “Time
Zone”, then press the ENTER button.
Press the … or † button to highlight the
time zone for your local area (and to
move the highlight to the appropriate time
zone on the map of the United States),
then press the ENTER button.
Move
Enter
Return
Time Zone
Input
Sound
Channel
Setup
Guide
Select the time zone where you locate.
Atlantic
Eastern
Central
Mountain
Pacific
Alaska
Hawaii
Move
Enter
Return
• When you set up Auto Time, the set time may
not be correct depending on the broadcasting
station and signal. If there is a difference
between the real time and set time, please set
the time manually.
5
Press the … or † button to select
“DST”(Daylight Saving Time), then press
the ENTER button.
Press the … or † button to select “Yes” or
“No”, then press the ENTER button.
Press the EXIT button to exit.
Clock
Input
Sound
Channel
--/ --/ ----/ -- : -- -Clock Mode
Clock Set
Time Zone
DST
: Yes
No
No
Setup
Guide
: Auto
Move
Enter
Return
English - 39
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 40
Operation
Setting the On/Off Timer
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Time”, then press the
ENTER button.
Press the … or † button
to select “On Timer”, then
press the ENTER button.
Press the … or † button to
adjust “Hour”, then press
the √ button to move to the
next step.
Set other items using the
same method as above.
Move
Enter
Return
Time
Input
Sound
Channel
1/ 1/ 2005/ 12 : 00 am
Clock
Sleep Timer
On Timer
Off Timer
√
√
√
√
: Off
: Inactivated
: Inactivated
Setup
Guide
Move
Enter
Return
On Timer
Input
Sound
To activate On Timer with
the setting entered, set
Activation to “Yes” by
pressing … or † button.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Channel
Enter the On Timer options.
Hour Minute am/pm Antenna
▲
12
00
am
Air
▼
Channel
Volume Activation
3
Setup
Guide
10
Move
No
Adjust
Return
• You can set the hour, minute, channel, and volume directly
by pressing the number buttons on the remote control.
When finished, press the MENU button to return.
NOTE
• Auto Power Off
When you set the timer
“On”, the television will
eventually turn off, if no
controls are operated for
3 hours after the TV was
turned on by the timer.
This function is only
available in timer “On”
mode and prevents
overheating or leakage,
which may occur if a TV
is on for too long (when
you are on vacation, for
example).
English - 40
3
Press the … or † button to
select “Off Timer”, then
press the ENTER button.
Press the … or † button to
adjust “Hour”, then press
the √ button to move to the
next step. Set other items
using the same method as
above.
Off Timer
Input
Sound
Enter the Off Timer options.
Hour Minute am/pm Activation
▲
12
00
am
No
▼
Channel
Setup
Guide
Move
Adjust
Return
To activate Off Timer with the setting entered, set Activation to
“Yes” by pressing … or † button.
When finished, press the EXIT button to exit.
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 41
Setting the Sleep Timer
The sleep timer automatically shuts off the TV after a preset time (from 30 to 180 minutes).
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Time”, then press the
ENTER button.
Press the … or † button to
select “Sleep Timer”, then
press the ENTER button.
3
Move
Enter
√
√
√
√
√
√
√
Return
Time
Input
Sound
Channel
1/ 1/ 2005/ 12 : 00 am
Clock
Sleep Timer
On Timer
Off Timer
: Off
: Inactivated
: Inactivated
√
√
√
√
Setup
Guide
Press the … or † button to
adjust “Minute”.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Sleep Timer
Input
Set sleep timer.
Minute
Sound
---
Activation
▲
No
▼
Channel
Setup
Guide
4
Setting the Timer sets the
Activation to “Yes”
automatically.
Press the EXIT button to exit.
Move
Adjust
Return
Sleep Timer
Input
Set sleep timer.
Minute
Activation
Sound
30
Yes
▲
▼
Channel
Setup
Guide
Move
Adjust
Return
Alternate method
Press the SLEEP button on the
remote control repeatedly until the
appropriate time interval appears
(any of the preset values from
“30 min” to “180 min”).
Sleep Timer : 90 min
English - 41
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 42
Operation
Viewing an External Signal Source
Use the remote control to switch between viewing signals from connected equipment,
such as a VCR, DVD, Set-Top Box or the TV source (broadcast or cable).
Setting the Signal Source
1
Press the MENU button.
Press the ENTER button to
select “Input”.
Input
Input
Source List
Edit Name
Anynet
: TV
√
√
Sound
Channel
Setup
Guide
2
Press the ENTER button to
select “Source List”.
Press the … or † button to
select a signal source, then
press the ENTER button.
Move
Enter
Return
Source List
Input
Sound
Channel
Setup
TV
AV1
AV2
AV3
S-Video1
S-Video2
S-Video3
▼ More
-------------------
• When you connect
Guide
Move
Enter
Return
equipment to the TV,
you can choose
between the following sets of jacks: “AV1”, “AV2”,
“S-VIDEO1”, “S-VIDEO2”, “COMPONENT1”,
“COMPONENT2”, or “HDMI/DVI” on the TV’s rear
panel and “AV3” or “S-VIDEO3” on the TV’s side panel.
• HDMI input can be selected only when the external device
is turned on and connected to the TV.
Alternate method
Press the SOURCE button on the
remote control repeatedly to
select an external signal source.
English - 42
AV1
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 43
Assigning Names to External Input Mode
This feature enables you to name the input source you have connected.
1
Press the MENU button.
Press the ENTER button to
select “Input”.
Input
Input
Source List
Edit Name
Anynet
√
√
: TV
Sound
Channel
Setup
Guide
2
Press the … or † button to
to select “Edit Name”, then
press the ENTER button.
Move
Enter
Return
Input
Input
Source List
Edit Name
Anynet
√
√
: TV
Sound
Channel
Setup
Guide
3
Press the … or † button to
select a signal source to
edit, then press the ENTER
button.
Enter
Return
Edit Name
Input
Sound
Channel
Setup
Guide
4
Move
Press the … or † button to
Input
select the external device :
VCR, DVD, D-VHS, Cable
Sound
STB, HD STB, Satellite STB,
Channel
PVR STB, AV Receiver,
Setup
DVD Receiver, GAME,
Guide
Camcorder, DVD Combo,
DVD HDD Recorder, Internet
TV Recv., Interactive TV Recv.,
VOD (Video On Demand) STB, TV.
AV1
AV2
AV3
S-Video1
S-Video2
S-Video3
Component1
▼ More
Move
:
:
:
:
:
:
:
√
√
√
√
√
√
√
---------------------Enter
Return
Edit Name
AV1
AV2
AV3
S-Video1
S-Video2
S-Video3
Component1
▼ More
Move
---: --VCR
: --DVD
: --D-VHS
:
--Cable STB
: --HD
STB
: --- STB
Satellite
PVR
: ----STB
▼
Enter
Return
Press the ENTER button.
Set other signal sources
(AV2, AV3, S-Video1,
S-Video2, S-Video3,
Component1, Component2,
HDMI) using the same
method as listed above.
Press the EXIT button to exit.
English - 43
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 44
SAMSUNG
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 45
Channel Control
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 46
Channel Control
Selecting Your Favorite Channels
You can store your favorite channels for each available input source (such as TV and CATV).
This allows you to quickly and easily find frequently watched channels by pressing the FAV.CH button on
the remote control.
To Store Your Favorite Channels:
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Favorite Channels”,
then press the ENTER button.
Press the … or † button to
select a channel, then press
the ENTER button and a
check mark will appear.
Press the ENTER button
again to deselect the
selected channel and the
check mark will disappear.
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Move
Enter
Return
Favorite Channels
Input
Air 2
Air 3
✔
Sound
Channel
Setup
Guide
Select All
Clear All
Air 4
Air 5
Air 6
Air 7
Air 8
▼
Move
Enter
Return
Press the EXIT button to exit.
NOTES
• Only memorized channels can be set as Favorite channels.
• Select All : Press to select all channels.
• Clear All : Press to clear all channels.
To View Your Favorite Channels:
Press the FAV.CH button repeatedly to jump from one favorite channel
to another.
English - 46
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 47
Labeling the Channels
Use this feature to assign an easy-to-remember label to analog channels (i.e., “CBS”, “ESPN”,
“PBS2”, CNN02”, etc.) A label consists of five fields, where each field is a letter, a number or a
blank. When the INFO button is pressed, the channel label will appear below to the channel number.
1
Press the CH
or CH
will be labeled.
2
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Press the … or † button to
select “Name”, then press
the ENTER button.
3
4
NOTE
• If you add or delete a
TV channel, the
labeled channels will
also be added or
deleted.
button to tune to the channel that
Press the … or † button to
move to the channel to be
assigned to a new name,
then press the ENTER button.
Press the … or † button to
select a letter, a number or a
blank. (Results in this
sequence: A...Z, 0...9, +, -,
✽, /, blank).
Press the √ button to switch
to the next field, which will
be selected.
Select a second letter or digit
pressing … or † button, as
above.
Repeat the process to select
the last three digits.
When you have finished,
press the ENTER button.
To erase the assigned new
name, select “Clear” by
pressing the œ or √ button,
then press the ENTER button.
Channel
Input
Sound
Channel
Setup
√
√
√
√
√
√
√
√
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Guide
Move
Enter
Return
Name
Input
▲
Air
2 A
Air
3
Clear
Sound
Air
4
Clear
Channel
Air
5
Clear
Air
6
Setup
Clear
▼
OK
Clear
▼
Guide
Move
Adjust
Return
Name
Input
▲
Air
2 CNN02
Air
3
Clear
Sound
Air
4
Clear
Channel
Air
5
Clear
Air
6
Setup
▼
Clear
OK
Clear
▼
Guide
Move
Adjust
Return
Press the EXIT button to exit.
English - 47
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 48
Channel Control
Fine Tuning Analog Channels
Analog
Use fine tuning to manually adjust a particular channel for optimal reception.
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Fine Tune”, then press
the ENTER button.
Move
Sound
Setup
Return
√
√
√
√
√
√
√
√
Antenna
: Cable
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: Off
Guide
3
Enter
Channel
Input
Channel
Press the œ or √ button to
adjust the fine tuning.
√
√
√
√
√
√
√
√
Antenna
: Cable
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: Off
Move
Enter
Return
Fine Tune
Cable 26
Not Fine Tuned
3
Reset
Adjust
4
NOTE
• Only analog TV
channels can be fine
tuned.
5
To store the fine tuning
setting in the TV’s memory,
press the ENTER button.
To reset the fine tuning
setting, press the † button to
select “Reset”, then press the
ENTER button.
Save
Return
Fine Tune
Cable 26
Fine Tuned
3
Reset
Adjust
Save
Return
Fine Tune
Press the EXIT button to exit.
Cable 26
Not Fine Tuned
0
Reset
Move
English - 48
Enter
Return
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 49
Checking the Digital-Signal Strength
Digital
Unlike analog channels, which can vary in reception quality from “snowy” to clear, digital (HDTV)
channels have either perfect reception quality or you will not receive them at all. So, unlike analog
channels, you cannot fine tune a digital channel.
You can, however, adjust your antenna to improve the reception of available digital channels.
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Signal Strength”, then
press the ENTER button.
Move
Enter
√
√
√
√
√
√
√
√
Return
Channel
Input
Sound
Channel
Setup
Guide
If the signal strength meter
indicates that the signal is
weak, physically adjust your
antenna to increase the
signal strength. Continue to
adjust the antenna until you
find the best position with
the strongest signal.
Antenna
: Cable
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: Off
Antenna
: Cable
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: Off
Move
Enter
√
√
√
√
√
√
√
√
Return
Signal Strength
Input
Sound
Channel
OK
Setup
Guide
Enter
Return
Press the EXIT button to exit.
English - 49
BP68-00496A-00(030~051)
3/3/05
1:07 PM
Page 50
Channel Control
LNA (Low Noise Amplifier)
If the TV is operating in a weak-signal area, sometimes the LNA function can improve
the reception (a low-noise preamplifier boosts the incoming signal).
1
Press the MENU button.
Press the … or † button to
select “Channel”, then press
the ENTER button.
Channel
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “LNA”, then press the
ENTER button.
Sound
Setup
Guide
3
Sound
Setup
Guide
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Move
Return
Enter
√
√
√
√
√
√
√
√
Return
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength Off
LNA
: On
On
Move
Press the EXIT button to exit.
NOTE
• LNA functions only when antenna is set to Air.
The settings will be stored separately in each channel.
English - 50
Enter
Channel
Input
Channel
4
Move
√
√
√
√
√
√
√
√
Channel
Input
Channel
Press the … or † button to
select “On” or “Off”, then
press the ENTER button.
Antenna
: Air
Auto Program
Add/Delete
Favorite Channels
Name
Fine Tune
Signal Strength
LNA
: On
Enter
Return
BP68-00496A-00(030~051)
3/3/05
1:08 PM
Page 51
Picture Control
BP68-00496A-00(052~071)
3/3/05
1:09 PM
Page 52
Picture Control
Picture Control
You can select the type of picture which best corresponds to your viewing requirements.
Changing the Picture Standard
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the ENTER button
again to select “Mode”.
Sound
Setup
Guide
3
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Mode
Input
Channel
Press the ENTER button.
Press the … or † button to
select the desired picture
mode (Dynamic, Standard,
Movie, Custom), then press
the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
: Warm1
√
90
50
65
60
R 50
√
Enter
Return
: Standard
Mode
Input
Sound
Channel
Setup
Guide
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
:Dynamic
Standard
Standard
Movie
Custom
90
50
65
60
R 50
: Warm1
Enter
Return
Press the EXIT button to exit.
• Choose “Dynamic” for viewing the TV during the day or when
there is a bright light in the room.
• Choose “Standard” for the standard factory settings.
• Choose Movie when viewing the movie.
• Choose Custom if you want to adjust the settings according to
personal preference (see “Customizing the Picture Settings”,
page 53).
English - 52
BP68-00496A-00(052~071)
3/3/05
1:09 PM
Page 53
Customizing the Picture Settings
You can use the on-screen menus to change the “Contrast”, “Brightness”, “Sharpness”, “Color”,
“Tint”, and “Color Tone” according to personal preference. You can select “Standard” which
automatically recalls your personalized picture settings.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press the
ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the ENTER button to
select “Mode”.
Sound
Setup
Guide
3
4
Press the œ or √ button to
decrease or increase the value
of a particular item.
Off
Enter
Return
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
: Warm1
√
90
50
65
60
R 50
√
Enter
Return
: Standard
Mode
Input
Sound
Channel
Setup
Guide
Press the … or † button to
select a particular option
(Contrast, Brightness,
Sharpness, Color, or Tint),
then press the ENTER button.
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Mode
Input
Channel
Press the ENTER button.
Press the … or † button to
select the desired picture mode
(Dynamic, Standard, Movie,
Custom), then press the ENTER
button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
:Dynamic
Standard
Standard
100
45
75
65
R 50
Movie
Custom
: Cool1
Enter
Return
Mode
Input
Sound
Channel
Setup
Guide
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
: Cool1
√
100
45
75
65
R 50
√
Enter
Return
: Dynamic
▲
• You can also select these
options (Contrast, Brightness,
Sharpness, Color, or Tint) by
pressing the … or † button.
Contrast
90
▼
NOTES
• “Tint” doesn’t operate in HDMI or 480p Component or higher modes.
• The Tint cannot be adjusted while watching Digital TV.
Continued...
English - 53
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 54
Picture Control
5
Press the ENTER button to return to
“Mode”.
Press the … or † button to select
“Color Tone”, then press the ENTER
button.
Mode
Input
Sound
Channel
Setup
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Guide
6
Press the … or † button to select a
particular option (Cool2, Cool1, Normal,
Warm1, or Warm2), then press the
ENTER button.
Enter
Return
Mode
Input
Sound
Channel
Press the EXIT button to exit.
Move
: Cool1
√
100
45
75
65
R 50
√
: Dynamic
Setup
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Guide
Move
: Dynamic
Cool2
Cool1
Normal
:Warm1
Warm1
Warm2
Enter
100
45
75
65
R 50
Return
NOTE
• Color tone is not available in the “Movie” picture mode.
Resetting the Picture Settings to the Factory Defaults
7
To return the factory defaults, select
“Reset” by pressing the … or † button.
Press the ENTER button.
Mode
Input
Sound
• The previously adjusted settings will
be reset to the factory defaults.
Channel
Setup
Guide
English - 54
Mode
Contrast
Brightness
Sharpness
Color
Tint
G 50
Color Tone
Reset
Move
: Cool1
√
100
45
75
65
R 50
√
Enter
Return
: Dynamic
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 55
Changing the Picture Size
You can select the picture size which best corresponds to your viewing requirements.
1
2
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Press the … or † button to
select “Size”, then press the
ENTER button.
Press the œ or √ button to
select the screen format you
want, then press the ENTER
button.
Press the EXIT button to exit.
Input
Sound
Channel
Setup
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Guide
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Size
Input
Sound
Channel
16:9
Panorama Zoom1
Zoom2
4:3
Setup
Guide
Move
Enter
Return
Alternate method
Press the P.SIZE button on the remote control repeatedly to select one
of the picture size settings.
• “16:9”: Sets the picture to 16:9 wide mode.
• “Panorama”: Use this mode for the wide aspect ratio of a
panoramic picture.
• “Zoom1”: Magnifies the size of the picture on screen.
• “Zoom2”: Magnifies the size of the picture more than “Zoom1”.
• “4:3”: Sets the picture to 4:3 normal mode.
This is a standard TV screen size.
NOTES
• You can select only the 16:9 and 4:3 screen sizes in the DTV or Component (720p, 1080i) mode.
• When Double (
,
) mode has been set in PIP, the Picture Size cannot be set.
English - 55
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 56
Picture Control
Digital Noise Reduction
If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction
feature to help reduce any static and ghosting that may appear on the screen.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Digital NR”, then
press the ENTER button.
Sound
Setup
Guide
3
Press the EXIT button to exit.
Off
Enter
√
√
√
√
√
√
√
Return
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Sound
Channel
Setup
Guide
English - 56
Move
Standard
16:9
On
Off
Input
Channel
Press the … or † button to
select “Off” or “On”, then
press the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
: Standard
Size
: 16:9
Digital NR
: Off
On
DNIe Demo
: On
Off
My Color Control
Film Mode
: Off
PIP
Move
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 57
Viewing the DNIe Demonstration
This TV includes the DNIe function so as to provide a high visual quality.
If you set DNIe Demo to On, you can view an applied DNIe and a normal picture on the screen,
for demonstration purposes. Using this function, you can view the difference in the visual quality.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “DNIe Demo”, then
press the ENTER button.
Sound
Setup
Guide
3
Press the EXIT button to exit.
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Input
Channel
Press the … or † button to
select “Off” or “On”, then
press the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Input
Sound
Channel
Setup
Guide
Mode
: Standard
Size
: 16:9
Digital NR
: On
DNIe Demo
: Off
Off
My Color Control On
Film Mode
: Off
PIP
Move
Enter
Return
Alternate method
Press the DNIe button on the remote control repeatedly to select one
of the settings.
• On: Switches on the DNIe Demo mode.
• Off: Switches off the DNIe Demo mode.
DNIe Demo
DNIe On
DNIe Off
NOTE
• DNIeTM (Digital Natural Image engine)
This feature brings you more detailed image with 3D noise
reduction, detail enhancement, contrast enhancement and
white enhancement.
English - 57
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 58
Picture Control
Setting the My Color Control Mode
My Color Control allows you to adjust colors according to your preference, by adjusting skin, sky,
and grass tones using the predefined settings (“Blue”, “Green”, “Pink”, “Standard”, and “Custom”)
without affecting other colors on the screen.
Using the Easy Control Menu
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Guide
2
Move
Input
Sound
Channel
Setup
Move
• Changing the settings
in the “Detail Control”
menu (see next page)
will automatically set
the My Color Control
mode to “Custom”.
English - 58
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Easy Control
Detail Control
√
√
: Custom
Sound
Channel
Setup
Guide
Move
Original
Enter
Return
Custom
Easy Control
œ
Standard
Press the EXIT button to exit.
• “Blue”: Emphasizes Clear Blues.
• “Green”: Emphasizes Mild Greens.
• “Pink”: Emphasizes Warm Skin Colors.
• “Standard”: Standard Picture.
Return
My Color Control
Input
Press the ENTER button to
accept the selected mode.
NOTE
Enter
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Guide
3
Off
Press the … or † button to
select “My Color Control”,
then press the ENTER button.
Press the ENTER button to
select “Easy Control”.
Press the œ or √ button to
select one of the picture
settings you want.
The original picture (before
adjustment) is shown
on the left side, while the
selected mode is shown
on the right side.
√
√
√
√
√
√
√
Standard
16:9
On
Off
Move
√
Custom
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 59
Custom Settings
1
2
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Press the … or † button to
select “My Color Control”,
then press the ENTER button.
Press the … or † button to
select “Detail Control”, then
press the ENTER button.
Input
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Sound
Channel
Setup
Guide
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
My Color Control
Input
Easy Control
Detail Control
√
√
: Custom
Sound
Channel
Setup
Guide
3
Press the … or † button to
select the desired My Color
Control, then press the
ENTER button.
There are three colors:
“Pink”, “Green” and “Blue”.
Move
Enter
Return
Detail Control
Input
Pink
Green
Blue
Reset
Sound
50
50
50
Channel
Setup
Guide
Press the œ or √ button to
adjust the value of a color
selected.
Changing the adjustment
value will refresh the
adjusted screen.
Move
Original
Enter
Return
Adjusted
Detail Control
▲
50
Pink
▼
Move
Return
Adjust
Resetting the My Color Control Colors to the Factory Defaults
You can return to the factory default settings for My Color Control
colors.
4
Press the MENU button to
display the “Detail Control”
menu.
Press the … or † button to
select “Reset”, then press the
ENTER button.
The previously adjusted My
Color Control colors will be
reset to the factory defaults.
Detail Control
Input
Sound
Pink
Green
Blue
Reset
50
50
50
Channel
Setup
Guide
Move
Enter
Return
English - 59
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 60
Picture Control
Using the Color Weakness Enhancement Feature
This feature adjusts the Red, Green or Blue color to enhance the picture according to the user’s
particular color weakness.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Color Weakness”,
then press the ENTER button.
Sound
Setup
Guide
3
4
Press the œ or √ button to
adjust the value of a color
selected.
• You can also select these
options (Red, Green or
Blue) by pressing the …
or † button.
Press the EXIT button to exit.
English - 60
Enter
Return
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Color Weakness
Input
Sound
Color Weakness
Red
Green
Blue
Off
On
0
0
0
Channel
Setup
Guide
Press the … or † button to
select a color to be adjusted,
then press the ENTER button.
Move
Setup
Input
Channel
Press the ENTER button to
select “Color Weakness”.
Press the … or † button to
select “On”, then press the
ENTER button.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Color Weakness
Input
Sound
Color Weakness
Red
Green
Blue
: On
√
0
0
0
Channel
Setup
Guide
Move
Enter
Return
Color Weakness
▲
0
Red
▼
Move
Adjust
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 61
Setting the Film Mode
You can automatically sense and process film signals from all sources and adjust the picture for
optimum quality.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Film Mode”, then
press the ENTER button.
Sound
Setup
Guide
3
Press the EXIT button to exit.
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Off” or “On”, then
press the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Sound
Channel
Setup
Guide
Mode
: Standard
Size
: 16:9
Digital NR
: On
DNIe Demo
: Off
My Color Control
Film Mode
: Off
Off
On
PIP
Move
Enter
Return
NOTE
• Film mode is supported in 480i only.
English - 61
BP68-00496A-01(052~071)
3/8/05
4:05 PM
Page 62
Picture Control
Viewing Picture-In-Picture
One of the best features of your TV is the Picture-In-Picture (PIP) feature. The advanced PIP system
allows you to watch two different pictures at once, even if you don’t have a VCR or DVD connected
to your TV.
Activating the PIP
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
Input
Channel
Press the ENTER button to
select “PIP”.
Press the … or † button to
select “On”, then press the
ENTER button.
The sub picture appears in
the corner of the screen.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
√
√
√
√
√
√
√
Standard
16:9
On
Off
Off
Enter
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: Off
Off
On
: TV
: Cable
: Cable 3
Setup
Guide
Move
Enter
Return
Press the EXIT button to exit.
Alternate method
Press the PIP button on the remote control repeatedly to activate or
deactivate the PIP.
NOTES
• This feature doesn’t function when the “V-Chip” is active.
• If you turn the TV off while watching and turn it on again, then the mode will return to normal
video.
• Digital channels cannot be viewed in the PIP window.
• PIP is supported when the video source for the main picture is digital and the source for the
sub picture is analog.
English - 62
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 63
Selecting an External Source
You can use PIP to view a signal from an external source, such as a VCR.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Source”, then press
the ENTER button.
If you have not connected
any equipment to the TV’s
input jacks, the signal from
these inputs will not appear.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
Setup
Guide
: TV
Off
AV1
: TV
AV2
AV3
S-Video1
: Air
S-Video2
: AIR 3
S-Video3
Component1
▼
Move
Enter
Return
Press the … or † button to
select an external signal,
then press the ENTER button.
Press the EXIT button to exit.
NOTE
• For more information about external signals, see “Viewing an External Signal Source” (See page 42)
and the “PIP Settings” (See page 104).
English - 63
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 64
Picture Control
Changing the Size of the Sub (PIP) Picture
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Press the … or † button to
select a size you want, then
press the ENTER button.
Press the EXIT button to exit.
English - 64
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Size”, then press the
ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: On
: TV
: Air
: Air 3
Setup
Guide
Move
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 65
Changing the Location of the Sub (PIP) Picture
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Press the … or † button to
select a position you want,
then press the ENTER button.
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Position”, then press
the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: On
: TV
: Air
: AIR 3
Setup
Guide
Move
Enter
Return
Press the EXIT button to exit.
NOTE
• The Double (
,
) mode cannot be selected in Position.
English - 65
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 66
Picture Control
Selecting a Signal Source (Antenna or Cable) for PIP
If the PIP source is TV while PIP is On, you can select a different broadcasting source
for the PIP picture from the main picture.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Air/CATV”, then
press the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: On
: TV
: Air
Air
: Cable
Air 3
Setup
Guide
4
Press the … or † button to
select “Air” or “Cable”, then
press the ENTER button.
Press the EXIT button to exit.
Enter
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: On
: TV
: Air
Air
: Cable
Air 3
Setup
Guide
English - 66
Move
Move
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 67
Changing the Channel of the Sub (PIP) Picture
After you set the signal source (antenna or cable) of the sub picture, it is easy to change channels.
1
Press the MENU button.
Press the … or † button to
select “Picture”, then press
the ENTER button.
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “PIP”, then press the
ENTER button.
Sound
Setup
Guide
3
Press the … or † button to
select a channel you want,
then press the ENTER button.
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
Input
Channel
Press the … or † button to
select “Channel”, then press
the ENTER button.
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Mode
:
Size
:
Digital NR
:
DNIe Demo
:
My Color Control
Film Mode
:
PIP
Move
Standard
16:9
On
Off
Off
Enter
√
√
√
√
√
√
√
Return
PIP
Input
Sound
Channel
PIP
Source
Size
Position
Air/CATV
Channel
: Cable▲
Cable311
: Cable
▼
Setup
Guide
: On
: TV
Move
Enter
Return
Press the EXIT button to exit.
• Air : “Air” antenna signal
Cable : “Cable” antenna signal
Alternate method
Press the CH
or CH
button under the cover of the remote
control to change the sub picture channels while PIP is on.
English - 67
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 68
Picture Control
Selecting the Sound Source
You can use this feature to hear sound from the main or sub (PIP) picture.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Sound Select”, then
press the ENTER button.
Press the … or † button to
select “Main” or “Sub”, then
press the ENTER button.
English - 68
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Setup
Guide
Press the EXIT button to exit.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
: Off
: Off
: Dolby Digital
:Main
Main
:Sub
On
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 69
Freezing the Picture
Press the STILL button to freeze a moving picture. (Normal sound will
still be heard.)
Press again to cancel.
NOTE
• In the PIP mode, the main and sub pictures are stilled at the same
time.
English - 69
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 70
Picture Control
Setting the Blue Screen Mode
If no signal is being received or the signal is very weak, a blue screen automatically replaces the
noisy picture background. If you wish to continue viewing the poor picture, you must set the “Blue
Screen” mode to “Off”.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Blue Screen”, then
press the ENTER button.
Sound
Setup
Guide
3
Press the EXIT button to exit.
Enter
Return
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Setup
Input
Sound
Channel
Setup
Guide
English - 70
Move
√
√
√
√
√
√
√
Setup
Input
Channel
Press the … or † button to
select “On” or “Off”, then
press the ENTER button.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Language
Time
V-Chip
Caption
Menu Transparency
Blue Screen
Color Weakness
▼ More
Move
: English
: Medium
: Off
Off
On
Enter
Return
BP68-00496A-01(052~071)
3/8/05
3:21 PM
Page 71
Sound Control
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 72
Sound Control
Sound Control
You can control and customize the sound levels and settings of the TV with the remote control.
Adjusting the Volume
Press the VOL+ or VOL– button to increase or decrease the volume.
Using the MUTE Button
At any time, you can temporarily
cut off the sound.
Press the MUTE button on the
remote control.
The message “Mute” is displayed
and the sound cuts off.
Mute
To turn mute off, press the MUTE
button again or press either the
VOL+ or VOL– button.
Customizing the Sound
The sound settings can be adjusted to suit your personal preference.
(Alternatively, you can use one of the automatic settings. See next
page.)
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Equalizer”, then
press the ENTER button.
Sound
Setup
Guide
English - 72
: Custom
:
:
:
:
:
Move
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Channel
Continued...
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
BP68-00496A-00(072~081)
3
3/3/05
1:13 PM
Page 73
Press the œ or √ button to select a
particular item to be changed.
Press the … or † button to increase or
decrease the selected frequency.
Equalizer
Input
Channel
Press the EXIT button to exit.
R
Sound
+
0
L
Setup
-
100 300 1K 3K 10K
Guide
Move
Adjust
Return
Using Automatic Sound Settings
Your TV has automatic sound settings (“Standard”, “Music”, “Movie”, and “Speech”) that are preset
at the factory. You can select “Custom”, which automatically recalls your personalized sound settings.
1
Press the MENU button.
Press the … or † button to select
“Sound”, then press the ENTER button.
Sound
Input
Sound
Channel
Setup
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Guide
2
Press the ENTER button to select “Mode”.
Press the … or † button to select a
particular item, then press the ENTER
button.
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Press the EXIT button to exit.
Move
: Custom
Setup
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Guide
Move
: Standard
Custom
Music
Movie
: Speech
Off
: Custom
Off
: Dolby Digital
: Main
: On
Enter
Return
• Choose “Standard” for the standard factory settings.
• Choose “Music” when watching music videos or concerts.
• Choose “Movie” when watching movies.
• Choose “Speech” when watching a show that is mostly dialog (i.e., news).
• Choose “Custom” to recall your personalized settings.
English - 73
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 74
Sound Control
Auto Volume
Each broadcasting station has its own signal conditions, and it is inconvenient to adjust the volume
every time the channel is changed. “Auto Volume” automatically adjusts the volume of the desired
channel by lowering the sound output when the modulation signal is high or by raising the sound
output when the modulation signal is low.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Auto Volume”, then
press the ENTER button.
Sound
Setup
Guide
3
Press the EXIT button to exit.
:
:
:
:
:
Move
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Setup
Guide
English - 74
: Custom
Sound
Input
Channel
Press the … or † button to
select “Off” or “On”, then
press the ENTER button.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
: Off
Off
: On
Off
: Dolby Digital
: Main
: On
Enter
Return
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 75
Choosing a Multi-Channel Sound (MTS) track
Digital
The digital-TV transmission system is capable of simultaneous transmission of many audio tracks
(for example, simultaneous translations of the program into foreign languages).
The availability of these additional “multitracks” depends upon the program.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Multi-Track Options”,
then press the ENTER button.
Sound
Setup
Guide
3
: Custom
:
:
:
:
:
Move
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Channel
Press the ENTER button to
select “Preferred Language”.
Press the … or † button to
choose the language
(English, Spanish or French)
you want, then press the
ENTER button.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Multi-Track Options
Input
Preferred Language
Multi-Track Sound
: English
English
: Spanish
Stereo
French
Sound
Channel
Setup
Guide
Move
Enter
Return
Press the EXIT button to exit.
Alternate method
Press the MTS button on the
remote control.
You can listen in a language
other than the favorite language
by pressing the MTS button.
1. English
English - 75
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 76
Sound Control
Choosing a Multi-Channel Sound (MTS) track
Analog
Depending on the particular program being broadcast, you can listen to Mono, Stereo or SAP.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Multi-Track Options”,
then press the ENTER button.
Sound
Setup
Guide
Press the … or † button to
select “Multi-Track Sound”,
then press the ENTER button.
Press the … or † button to
select a setting you want,
then press the ENTER button.
: Custom
:
:
:
:
:
Move
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Channel
3
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Multi-Track Options
Input
Preferred Language
Multi-Track Sound
: English
: Mono
Stereo
Stereo
SAP
Sound
Channel
Setup
Press the EXIT button to exit.
Guide
Move
Enter
Return
Alternate method
Press the MTS button on the
remote control repeatedly to select
an external signal source.
Stereo
NOTES
• Choose “Mono” for channels that are broadcasting in mono, or
if you are having difficulty receiving a stereo signal.
• Choose “Stereo” for channels that are broadcasting in stereo.
• Choose “SAP” to listen to the Separate Audio Program, which is
usually a foreign-language translation.
English - 76
BP68-00496A-01(072~081)
3/14/05
5:03 PM
Page 77
Choosing a Digital Sound Format
Digital
Digital sound can be output from the rear-panel connector on your TV. The digital sound
output is an optical connector labeled “Optical Out”. After connecting an optical digital-audio
component, you must specify the transmission format (Dolby or PCM, as appropriate to your
digital audio component). See the owner's manual of your Digital Audio component for further
information.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Digital Output”, then
press the ENTER button.
Press the … or † button to
select “Dolby Digital” or
“PCM”, then press the
ENTER button.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Setup
Guide
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
: Off
: Off
: Dolby
PCM Digital
: PCM
Main
: On
Enter
Return
Press the EXIT button to exit.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
English - 77
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 78
Sound Control
Selecting the Internal Mute
When using a device such as a Home Theater or Amplifier with external speakers, you can set
Internal Mute to On to cut off sound from the TV’s internal speakers.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Internal Mute”, then
press the ENTER button.
Sound
Setup
Guide
3
: Custom
:
:
:
:
:
Move
Off
Off
Dolby Digital
Main
On
Enter
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Return
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Setup
Guide
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
: Off
: Off
Off
: On
PCM
: Main
: On
Enter
Press the EXIT button to exit.
NOTES
• The VOL +, VOL - and Mute buttons do not operate when the
Internal Mute is set to On.
• When Internal Mute is on, only the Multi-Track Options and
Melody menu are available.
English - 78
√
√
√
√
√
√
√
√
Sound
Input
Channel
Press the … or † button to
select “On”, then press the
ENTER button.
Pressing the … or † button
will alternate between “On”
and “Off”.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Return
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 79
Setting the On/Off Melody
A melody sound can be set to come on when the TV is powered On or Off.
1
Press the MENU button.
Press the … or † button to
select “Sound”, then press
the ENTER button.
Sound
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Melody”, then press
the ENTER button.
Press the … or † button to
select “On” or “Off”, then
press the ENTER button.
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
:
:
:
:
:
Off
Off
Dolby Digital
Main
On
Enter
√
√
√
√
√
√
√
√
Return
Sound
Input
Sound
Channel
Setup
Guide
Mode
Equalizer
Multi-Track Options
Auto Volume
Internal Mute
Digital Output
Sound Select
Melody
Move
: Custom
: Off
: Off
: Dolby Digital
: Off
Main
: On
On
Enter
Return
Press the EXIT button to exit.
English - 79
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 80
SAMSUNG
BP68-00496A-00(072~081)
3/3/05
1:13 PM
Page 81
Special Features
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 82
Special Features
Setting the Function Help
Displays Help on the menu functions.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Function Help”, then
press the ENTER button.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Setup
Input
Sound
▲ More
Function Help
: Off
CableCARDTM
TM
CableCARD Setup
√
√
√
Channel
Setup
Guide
3
Press the … or † button to
select “On”, then press the
ENTER button.
Press the EXIT button to exit.
Move
Enter
Return
Setup
Input
Sound
▲ More
Function Help
: Off
Off
On
CableCARDTM
TM
CableCARD Setup
Channel
Setup
Guide
Move
Enter
Switches the Function Help on.
English - 82
Return
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 83
Menu Transparency Level
Adjusts the transparency of the menu screen.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Menu Transparency”,
then press the ENTER button.
Press the … or † button to
select level, then press the
ENTER button.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Setup
Input
Sound
Channel
Setup
Guide
Language
Time
V-Chip
Caption
Menu Transparency
Blue Screen
Color Weakness
▼ More
Move
: English
: High
Medium
: Medium
Off
Low
Opaque
Enter
Return
Press the EXIT button to exit.
English - 83
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 84
Special Features
Using the V-Chip
Access to channels and programs is controlled by a password (i.e., a 4-digit secret code that is
defined by the user). The on-screen menu will instruct you to assign a password (you can change it
later, if necessary).
How to Change Your Password
1
2
3
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
Press the … or † button to
select “Change PIN”, then
press the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
V-Chip Lock
: Off
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
√
√
√
√
√
√
Setup
Guide
4
Press the number buttons to
enter your new 4-digit pin
number.
Re-enter your new pin
number to confirm.
Press the EXIT button to exit.
Move
Enter
Return
Change PIN
Input
Enter New PIN
Sound
Confirm New PIN
Channel
Setup
Guide
0~9 Enter PIN
Return
NOTES
• The PIP doesn’t function when the V-Chip is active.
• If you forget the pin number, press the remote control buttons in the
following sequence, which resets the pin to 0-0-0-0: POWER (Off),
MUTE, 8, 2, 4, POWER (On).
• The V-Chip function only works in RF, AV mode and S-Video mode.
English - 84
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 85
How to Enable/Disable the Rating Controls
1
2
3
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
The “V-Chip” screen will
appear. To enable the
V-Chip feature, press the
ENTER button so that the
“V-Chip Lock” field is “On”.
(Pressing the … or † button
will alternate between “On”
and “Off”.)
Press the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
V-Chip Lock
:Off
Off
On
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
Setup
Guide
Move
Enter
Return
Press the EXIT button to exit.
English - 85
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 86
Special Features
How to Set up Restrictions Using the “TV Parental Guidelines”
The parental restrictions can be set up using either of two methods: The “TV Parental Guidelines” or
“MPAA Rating”.
1
2
3
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
Press the … or † button
to select “TV Parental
Guidelines”, then press the
ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
V-Chip Lock
: Off
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
√
√
√
√
√
√
Setup
Guide
English - 86
Move
Enter
Return
BP68-00496A-00(082~103)
4
3/3/05
1:15 PM
Page 87
You can independently lock the TV
ratings. The locked TV (FCC) ratings are
indicated by the symbol “ ”.
Press the …/†/œ/√ buttons and the
ENTER button to activate the appropriate
restrictions for TV (FCC) rating system.
TV Parental Guidelines
Input
Sound
Channel
Setup
Guide
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
:
:
:
:
:
:
Young children
Children 7 and over
General audience
Parent Guidance
Viewers 14 and over
Mature Audience
ALL FV
V
S
L
TV-Y
TV-Y7
D
Allow All
Block All
TV-G
TV-PG
TV-14
TV-MA
Move
Enter
Return
NOTE
• Allow All : Press to unlock
all TV ratings.
Block All : Press to lock all
TV ratings.
Press the EXIT button to exit.
NOTES
• These categories consist of two separate groups: “TV-Y” and “TV-Y7” (young children
through age 7), and “TV-G” through “TV-MA” (everybody else).
• The restrictions for these two groups work independently: If a household includes
very young children as well as young adults, the TV parental guidelines must be
set up separately for each age group. (See page 89.)
English - 87
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 88
Special Features
How to Set up Restrictions Using the “MPAA Rating”
The Movie rating system uses the “MPAA” (Motion Picture Association of America) system, and its
main application is for movies.
When the rating control is on, the TV will automatically block any programs that are coded with
objectionable ratings (either “MPAA Rating” or “TV Parental Guidelines”).
1
2
3
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
Press the … or † button to
select “MPAA Rating”, then
press the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
√
√
√
√
√
√
V-Chip Lock
: Off
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
Setup
Guide
4
You can independently lock
the movie ratings. The locked
movie ratings are indicated
by the symbol “ ”.
Press the …/†/ENTER
buttons to activate the
appropriate restrictions for
movie rating system.
Enter
Return
MPAA Rating
Input
Sound
Channel
Setup
Guide
Press the EXIT button.
NOTE
• Allow All : Press to unlock all movie ratings.
Block All : Press to lock all movie ratings.
English - 88
Move
Block
Allow All
G
PG
PG-13
R
NC-17
X
Block All
NR
Move
Enter
Return
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 89
Important Notes About Parental Locks
Explanation of the MPAA and TV (FCC) Rating Systems:
TV (FCC) Age-Based Ratings
TV-MA
Mature audiences only. This program may
contain mature themes, profane language,
graphic violence and explicit sexual content.
TV-14
Parents strongly cautioned. This program may
contain sophisticated themes, sexual content,
strong language and more intense violence.
TV-PG
Parental guidance suggested. The program
may contain infrequent coarse language,
limited violence, some suggestive sexual
dialog and situations.
TV (FCC) Content Category
V
S
L
D
FV
Violence.
Sexual content.
Offensive language.
Dialog sexual innuendo.
Fantasy or cartoon violence.
TV-G
General audience. It contains little or no
violence, no strong language, and little or no
sexual dialog or situations.
TV-Y7
Directed to older children. Themes and
elements in this program may include mild
physical or comedic violence, or may frighten
children under the age of seven.
TV-Y
All children. The themes and elements in this
program are specifically designed for a very
young audience, including children from ages
two – six.
MPAA Rating System (Movies)
G
General audience. No restriction.
PG
Children under 13 should be accompanied
by an adult.
PG-13
Parental guidance suggested. Children
under 13 should be accompanied by an
adult.
R
Restricted. Viewers should be 17 or older.
NC-17
Not classified. Viewers should be 17 or
older.
X
Adults only.
NR
Not rated.
• TV (FCC) ratings : The particular rating that you have selected will be locked (and indicated as
a red “L” on a blue background). Also, all of the age-based ratings will be locked within the
particular group (i.e., “group 1” or “group 2”). Suppose that the TV-G rating and all of its
contents (V, S, L, and D) are locked. In that case, more restrictive ratings (TV-PG, TV-14, and
TV-MA) and all of their contents (V, S, L, and D) are automatically locked as well.
• MPAA ratings : The particular rating that you have selected will be locked. In addition, more
restrictive ratings will be locked as well.
• Neither TV (FCC) ratings nor MPAA ratings apply to news programs.
English - 89
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 90
Special Features
How to Set up Restrictions Using Canadian English
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
2
3
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
Press the … or † button to
select “Canadian English”,
then press the ENTER button.
Setup
Guide
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
V-Chip Lock
: Off
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
√
√
√
√
√
√
Setup
Guide
English - 90
Move
Enter
Return
BP68-00496A-00(082~103)
4
3/3/05
1:15 PM
Page 91
Press the … or † button to select a
appropriate restriction.
Canadian English
Input
Press the ENTER button to activate the
restriction selected.
The “ ” symbol is indicated.
Press the EXIT button.
Sound
Channel
Setup
Guide
Block
E
Allow All
C
C8+
G
PG
14+
18+
Block All
Move
Enter
Return
NOTE
• Allow All : Press to unlock
all TV ratings.
Block All : Press to lock all
TV ratings.
E
Exempt programming includes...news, sports,
documentaries and other information programming,
talk shows, music videos, and variety programming.
C
Programming intended for children under age 8.
C8+
Programming generally considered acceptable for
children 8 years and over to watch on their own.
G
General programming, suitable for all audiences.
PG
Parental Guidance.
14+
Programming contains themes or content which may
not be suitable for viewers under the age of 14.
18+
Adult programming.
English - 91
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 92
Special Features
How to Set up Restrictions Using Canadian French
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Press the … or † button to
select “V-Chip”, then press
the ENTER button.
2
3
Press the number buttons to
enter your current 4-digit pin
number.
(The default pin number for
a new TV set is “0000”.)
The “V-Chip” menu is
displayed.
Press the … or † button to
select “Canadian French”,
then press the ENTER button.
Setup
Guide
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
V-Chip
Input
Enter PIN
*
Sound
Channel
Setup
Guide
0~9 Enter PIN
Return
V-Chip
Input
Sound
Channel
V-Chip Lock
: Off
TV Parental Guidelines
MPAA Rating
Canadian English
Canadian French
Change PIN
√
√
√
√
√
√
Setup
Guide
English - 92
Move
Enter
Return
BP68-00496A-00(082~103)
4
3/3/05
1:15 PM
Page 93
Press the … or † button to select a
appropriate restriction.
Press the ENTER button to activate the
restriction selected.
The “ ” symbol is indicated.
Press the EXIT button.
Canadian French
Input
Block
E
Allow All
Sound
G
8 ans+
13 ans+
16 ans+
18 ans+
Block All
Channel
Setup
Guide
Move
Enter
Return
NOTE
• Allow All : Press to unlock
all TV ratings.
Block All : Press to lock all
TV ratings.
E
Exempt programming includes...news, sports,
documentaries and other information programming,
talk shows, music videos, and variety programming.
G
General.
8
ans+ 8+ General-Not recommended for young children.
13 ans+ Programming may not be suitable for children under the
age of 13.
16 ans+ Programming is not suitable for children under the age of
16.
18 ans+ Programming restricted to adults.
English - 93
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 94
Special Features
Viewing Closed Captions (On-Screen Text Messages)
Analog
The Analog Caption function operates in either analog RF channel mode or external signal mode.
(Depending on the broadcasting signal, the Analog Caption function may operate on digital
channels.)
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Caption”, then press
the ENTER button.
Sound
Setup
Guide
3
Press the … or † button to
select “On”, then press the
ENTER button.
Enter
Return
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Caption
Input
Caption
Mode
Caption Options
:Off
On
:On
Default
Sound
Channel
Setup
Guide
English - 94
Move
√
√
√
√
√
√
√
Setup
Input
Channel
Press the ENTER button to
select “Caption”.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
BP68-00496A-00(082~103)
4
3/3/05
1:15 PM
Page 95
Press the … or † button to select “Mode”,
then press the ENTER button.
Press the … or † button to select submenu
(CC1~CC4 or Text1~Text4) you want,
then press the ENTER button.
Caption
Input
Caption
Mode
Caption Options
Sound
Channel
Setup
Press the EXIT button to exit.
:Default
On
:CC1
Default
CC2
CC3
CC4
Text1
Text2
Text3
†
Guide
Move
Enter
Return
NOTES
• The default is “CC1”.
CC1 : The Primary Synchronous Caption Service. These are captions in the
primary language that must be in sync with the sound, preferably
matched to a specific frame.
CC2 : The Special NonSynchronous Use Captions. This channel carries data
that is intended to augment information carried in the program.
CC3 : Secondary Synchronous Caption Service. Alternate program-related
caption data, typically second language captions.
CC4 : Special Non-Synchronous Use Captions. Similar to CC2.
Text1 : First Text Service. This may be various non-program related data.
Text2 : Second Text Service. Additional data, usually not program related.
Text3/Text4 : Third and Fourth Text Services. These data channels should be
used only if Text1 and Text2 are not sufficient.
• The Caption feature only works in RF, AV and S-Video mode.
• The availability of captions depends on the program being broadcast.
English - 95
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 96
Special Features
Viewing Closed Captions (On-Screen Text Messages)
Digital
The Digital Captions function operates on digital channels.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Caption”, then press
the ENTER button.
Sound
Setup
Guide
3
Press the … or † button to
select “On”, then press the
ENTER button.
4
NOTE
• “Caption Options” are
available only when
“Service1~ Service6” can
be selected in “Mode”.
English - 96
5
Press the … or † button to
select “Caption Options”,
then press the ENTER button.
Enter
Return
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Caption
Input
Caption
: Off
On
Mode
: On
Default
Caption Options
Sound
Channel
Setup
Guide
Press the … or † button to
select “Mode”, then press
the ENTER button.
Press the … or † button to
select submenu (Service 1
~Service 6, CC1~CC4 or
Text1~Text4) you want, then
press the ENTER button.
Move
√
√
√
√
√
√
√
Setup
Input
Channel
Press the ENTER button to
select “Caption”.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Caption
Input
Caption
Mode
Caption Options
Sound
Channel
Setup
Default
: On
Service
1
: Default
Service 2
Service 3
Service 4
Service 5
Service 6
CC1
†
Guide
Move
Enter
Return
Caption
Input
Caption
: On
Mode
: Default
Caption Options
√
√
√
Sound
Channel
Setup
Guide
Move
Enter
Return
BP68-00496A-00(082~103)
6
3/3/05
1:15 PM
Page 97
Press the … or † button to select “Size”,
then press the ENTER button.
Press the … or † button to select one you
want, then press the ENTER button.
Set other listed options below using the
same method as above.
Press the EXIT button to exit.
Caption Options
Input
Sound
Channel
Setup
Guide
Size
Font Style
Foreground Color
Background Color
Foreground Opacity
Background Opacity
Return to Default
Move
:
:
:
:
:
:
√
√
√
√
√
√
Default
Default
Default
Default
Default
Default
Enter
Return
NOTE
• The availability of captions depends on the program being broadcast.
Size
This option consists of “Default”, “Small”, “Standard”, and “Large”.
The default is “Standard”.
Font Style
This option consists of “Default”, “Style0 ~ Style 7”.
You can change the font you want. The default is “Style 0”.
Foreground Color
This option consists of “Default”, “White”, “Black”, “Red”, “Green”,
“Blue”, “Yellow”, “Magenta”, and “Cyan”.
You can change the color of the letter. The default is “White”.
Background Color
This option consists of “Default”, “White”, “Black”, “Red”, “Green”,
“Blue”, “Yellow”, “Magenta”, and “Cyan”. You can change the
background color of the caption. The default is “Black”.
Foreground Opacity
This option consists of “Default”, “Transparent”, “Translucent”,
“Solid”, and “Flashing”. You can change the opacity of the letter.
Background Opacity
This option consists of “Default”, “Transparent”, “Translucent”,
“Solid”, and “Flashing”. You can change the background opacity of
the caption.
Return to Default
This option sets each of “Size”, “Font Style”, “Foreground Color”,
“Background Color”, “Foreground Opacity”, and “Background
Opacity” Color to its default.
Alternate method
Press the CAPTION button on the remote
control repeatedly to select “On” or “Off”.
Caption : On
English - 97
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 98
Special Features
Using the CableCARD
This menu works with a CableCARD provided by a local cable service provider.
Prior to accessing this menu, a CableCARD should be connected to the rear panel of the TV.
For detailed connection instructions refer to the “Connecting CableCARD” section on page 22 of this
manual.
Displaying CableCARD related information
To access information on Status, Pairing, Network Setup of the CableCARD provided by the service
provider in CableCARD menu.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “CableCARDTM”, then
press the ENTER button.
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
√
√
√
√
√
√
√
Return
Setup
Input
Sound
▲ More
Function Help : Off
CableCARDTM
CableCARDTM Setup
√
√
√
Channel
Setup
Guide
3
English - 98
Press the EXIT button to exit.
Move
Enter
Return
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 99
Using the CableCARD Setup Function
Sets up relevant CableCARD options.
CableCARD Reset
Resets CableCARD when the channels provided by CableCARD are not available.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “CableCARDTM Setup”,
then press the ENTER button.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Setup
Input
Sound
▲ More
Function Help : Off
CableCARDTM
CableCARDTM Setup
√
√
√
Channel
Setup
Guide
3
Press the ENTER button to
select “CableCARDTM Reset”.
Move
Enter
Return
CableCARDTM Setup
Input
CableCARDTM Reset
Channel List Reorganization
Sound
Channel
Setup
Guide
Move
Enter
Return
English - 99
BP68-00496A-00(082~103)
3/3/05
1:15 PM
Page 100
Special Features
Channel List Reorganization
Deletes and reorganizes the channel list provided by CableCARD.
This feature should be used if you change or upgrade your CableCARD service.
1
Press the MENU button.
Press the … or † button to
select “Setup”, then press
the ENTER button.
Setup
Input
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “CableCARDTM Setup”,
then press the ENTER button.
√
√
√
√
√
√
√
Language
: English
Time
V-Chip
Caption
Menu Transparency : Medium
Blue Screen
: Off
Color Weakness
▼ More
Move
Enter
Return
Setup
Input
Sound
▲ More
Function Help : Off
CableCARDTM
CableCARDTM Setup
√
√
√
Channel
Setup
Guide
3
Press the ENTER button to
select “Channel List
Reorganization”.
Move
Enter
Return
CableCARDTM Setup
Input
CableCARDTM Reset
Channel List Reorganization
Sound
Channel
Setup
Guide
English - 100
Move
Enter
Return
BP68-00496A-01(082~103)
3/8/05
3:06 PM
Page 101
Using the Guide
You can display a list of all channels or your favorite channels.
1
Guide
Press the MENU button.
Press the … or † button to
select “Guide”, then press
the ENTER button.
Input
√
√
√
Channel List
Edit Channel List
Favorite Channel List
Sound
Channel
Setup
Guide
2
Press the … or † button to
select “Channel List” or
“Favorite Channel List”, then
press the ENTER button.
Press the CH
or CH
button to display the previous
or next channel list page.
Move
Enter
Return
Channel List
All
▲ More
29
30
31
32
33
34
35
36
2/3
37
38
39
40
41
42
43
44
Page
Favorite
Move
45
46
47
48
49
50
51
52
Edit
Exit
Watch
▼ More
Return
• Yellow button : Press to edit channels.
The edit channel menu is displayed.
(See next page for details.)
Green button : Press to toggle between your all or favorite
channels.
Blue or EXIT button : Press to exit.
Alternate method
Press the CH.LIST button
on the remote control to
display a list of channels.
Channel List
All
2
3
4
5
6
7
8
9
1/3
10
11
12
13
14
15
17
19
Page
Favorite
Move
20
21
22
24
25
26
27
28
Edit
Exit
Watch
▼ More
Return
English - 101
BP68-00496A-01(082~103)
3/8/05
3:06 PM
Page 102
Special Features
Adding and Erasing Channels
1
Guide
Press the MENU button.
Press the … or † button to
select “Guide”, then press
the ENTER button.
Input
√
√
√
Channel List
Edit Channel List
Favorite Channel List
Sound
Channel
Setup
Guide
2
Move
Enter
Return
Guide
Press the … or † button to
select “Edit Channel List”,
then press the ENTER button.
Input
√
√
√
Channel List
Edit Channel List
Favorite Channel List
Sound
Channel
Setup
Guide
3
Press the … or † button to
change channels you want
to add or delete.
Repeatedly pressing ENTER
button will alternate between
“Add” and “Delete”.
Move
Enter
Return
Channel List
Edit
▲ More
29
30
31
32
33
34
35
36
2/3
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
Add All Delete All
Favorite
Exit
Page
Move
Delete
▼ More
Return
Press the … or † button to select favorite channel you want
to add, then press the yellow button.
The check ( ✔ ) mark will appear.
Press the yellow button again to deselect the selected channel
and the check ( ✔ ) mark will disappear.
Press the CH
or CH
next channel list page.
button to display the previous or
• Red button : Press to add all channels of the channel list.
Green button : Press to delete all channels of the channel list.
Yellow button : Press to add favorite channels.
Blue or EXIT button : Press to exit.
English - 102
BP68-00496A-00(082~103)
3/3/05
1:16 PM
Page 103
Appendix
BP68-00496A-01(104~107)
3/8/05
3:07 PM
Page 104
Appendix
PIP Settings
▲ : PIP operates
X : PIP doesn’t operate
Sub
Main
ATSC
QAM
NTSC
AV1
AV2
AV3
S-Video1
S-Video2
S-Video3
Component1
Component2
ATSC QAM NTSC AV1 AV2 AV3 S-Video1 S-Video2 S-Video3 Component1 Component2 HDMI
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
▲
▲
X
X
X
X
X
X
X
X
X
X
Replacing the Lamp
• Why do I need to replace the lamp?
The lamp used in a DLP TV has a limited lifespan. For the best screen quality it needs to be
replaced periodically. After replacing the lamp, the screen quality will be bright and clear as new.
• When do I need to replace it?
It should be replaced when the screen becomes darker, less clear or when all three LEDs on the
front (TIMER, LAMP, & STAND BY/TEMP) are flashing.
• Check before lamp replacement
1. The lamp must be the same code number and type.
2. The lamp type is indicated on the right side of the TV. It is also indicated on the lamp case.
3. After checking the code number for the lamp, give the code number to the store where you
purchased the TV or to a Samsung Service center.
• Caution
1. Replace with the correct code numbered lamp to avoid damage to the TV.
2. Turn the power off and wait for 30 minutes before replacing the lamp as it will be hot.
3. Do not touch the glass part of the lamp with your bare hands nor insert any foreign object
inside the cover as it may cause poor screen quality, electric shock or fire.
4. Do not place the old lamp near flammable objects or within the reach of children.
5. Be sure to connect this TV directly to an AC wall outlet. If the TV’s AC plug is connected to a
cable box or other source, it will not allow for proper cool down time.
English - 104
BP68-00496A-00(104~107)
3/3/05
1:17 PM
Page 105
• For replacement, you will need a 5.91-Inch screwdriver and a pair of gloves.
1
Unplug TV, then use a
screwdriver to remove the
screws.
2
Remove the Lamp cover.
3
Remove the screw securing
the Lamp by using a
screwdriver.
4
Separate the Lamp from the
engine by holding the handle
and pulling it out.
5
To reinstall the Lamp, follow
these steps in reverse order.
NOTES
• Be sure the replacement Lamp is the same type.
• After replacing the lamp, align the lamp cover with the groove and secure the screws.
• The TV will not turn on if the lamp cover is not correctly closed (as this will activate the protective
circuit).
English - 105
BP68-00496A-00(104~107)
3/3/05
1:17 PM
Page 106
Appendix
Troubleshooting
If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these
troubleshooting tips apply, then call your nearest Samsung authorized service center.
Problem
Possible Solution
Poor picture quality.
Try another channel.
Adjust the antenna.
Check all wire connections.
Poor sound quality.
Try another channel.
Adjust the antenna.
Make sure the MUTE button is off.
No picture or sound.
Try another channel.
Press the SOURCE button.
Make sure the TV is plugged in.
Check the antenna connections.
No color, wrong colors or tints.
Make sure the program is broadcasted in color.
Adjust the picture settings.
Picture rolls vertically.
Adjust the antenna.
Check all wire connections.
If you are using a VCR, check the tracking.
The TV operates erratically.
Unplug the TV for 30 seconds, then try operating it
again.
Your remote control does not
operate your TV.
Press the MODE button to put your remote control
into TV mode.
Make sure the remote has batteries.
The TV won’t switch on.
Make sure the wall outlet is working.
Make sure the TV is plugged in.
Make sure the remote has batteries.
Digital broadcasting screen
problem.
Please check the digital signal strength and input
antenna.
• The display panel used for the DLP TV is composed of many tiny pixels.
These pixels may occasionally appear on the screen.
English - 106
BP68-00496A-00(104~107)
3/3/05
1:17 PM
Page 107
Cleaning and Maintaining Your TV
With proper care, your TV will give you many years of service. Please follow these guidelines to
get the maximum performance from your TV.
Placement
• Do not put the TV near extremely hot, cold, humid or dusty places.
• Do not place the TV near appliances with electric motors that create magnetic fields, such as
vacuum cleaners.
• Keep the ventilation openings clear; do not place the TV on a soft surface, such as cloth or
paper.
• Place the TV in a vertical position only.
Liquids
• Do not handle liquids near or on the TV. Liquids that spill into it can cause serious damage.
Cabinet
• Never open the cabinet or touch the parts inside.
• Wipe your TV with a clean, dry cloth. Never use water, cleaning fluids, wax, or chemicals.
• Do not put heavy objects on top of the cabinet.
• This DLP TV projects the image onto a large screen by applying an optical system.
If you place the TV set face down, it might cause a problem because dirt, or some other
contaminant may become attached to the inside of the TV set.
Temperature
• If your TV is suddenly moved from a cold to a warm place, unplug the power cord, and allow
at least two hours for moisture that may have formed inside the unit to dry completely.
Using Your TV in Another Country
If you plan to take your TV with you to a foreign country, please be aware of the different
television systems that are in use around the world. A TV designed for one system may not work
properly with another system due to differences in the TV channel frequencies.
Specifications
Model
HL-R4266W
Voltage
AC 110-120V~
Frequency of Operation
Power Consumption
Dimensions
(W x D x H)
Weight
60Hz
230 watts
39.33 x 13.03 x 30.53 inches
999 x 331 x 755.5 mm
28 Kg / 61.72 lbs
English - 107
BP68-00496A-01(cover)
3/8/05
2:59 PM
Page 2
1-800-SAMSUNG (1-800-726-7864)
Samsung Electronics America
Service Division
400 Valley Road, Suite 201
Mount Arlington, NJ 07856
www.samsung.com
Samsung Electronics Canada Inc.
Samsung Customer Care
7037 Financial Drive
Mississauga, Ontario
L5N 6R3
www.samsung.ca
BP68-00496A-01
