important safety instructions
Read and follow all instructions before using your oven to prevent the
risk of fire, electric shock, personal injury, or damage when using the
range. This guide does not cover all possible conditions that may occur. Always
contact your service agent or manufacturer about problems that you do not
understand.
What you need to know about safety
instructions
Warnings and Important Safety Instructions in this manual do not cover all
possible conditions and situations that may occur. It is your responsibility to use
common sense, caution, and care when installing, maintaining, and operating
your oven.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
What the icons and symbols in this user manual mean:
WARNING
CAUTION
CAUTION
Hazards or unsafe practices that may result in severe
personal injury or death.
Hazards or unsafe practices that may result in minor
personal injury or property damage.
To reduce the risk of fire, explosion, electric shock, or
personal injury when using your oven, follow these basic
safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
These warning icons and symbols are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
1_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 1
2013-04-25 �� 5:25:33
ANTI-TIP DEVICE
WARNING
WARNING - To reduce the risk of tipping the range, the range must be
secured by a properly installed Anti-Tip device. AFTER THE RANGE
HAS BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE
HAS BEEN PROPERLY INSTALLED AND VERIFY THAT THE ANTITIP DEVICE IS PROPERLY ENGAGED. Refer to the installation manual
for instructions.
a)If the anti-tip device is not installed, a child or adult can tip the range
and be killed.
b)Verify the anti-tip device has been properly installed and engaged at
rear right (or rear left) of the range bottom.
c)If you move the range and then move it back into place, ensure the
anti-tip device is re-engaged at the right or left rear of the range bottom.
d)Do not operate the range without the anti-tip device in place and engaged.
e)Failure to do so can result in death or serious burns to children or adults.
WARNING
WARNING
Do not step, lean, or sit on the oven door or warming drawer of the
range. You can cause the range to tip, resulting in burns or serious injuries.
Confirm that the Anti-Tip device is installed properly. Then, to verify that
the Anti-Tip device is engaged, grasp the top rear edge of the range and
carefully attempt to tilt it forward. The Anti-Tip device should prevent the
range from tilting forward more than a few inches.
If you pull the range out from the wall for any reason, make sure the antitip device is properly engaged when you push the range back against the
wall. If it is not, there is a risk of the range tipping over and causing injury
if you or a child stand, sit or lean on an open door.
Never completely remove the leveling legs. If you remove the leveling legs,
the range will not be secured to the anti-tip device properly.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
Use this appliance only for its intended purpose as described in this
Owner’s Manual.
Potentially hot surfaces include the cooktop, areas facing the cooktop, oven
vent opening, surfaces near the opening, and crevices around the oven door.
important safety instructions _2
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 2
2013-04-25 �� 5:25:33
Be sure your appliance is properly installed and grounded by a qualified
technician.
User servicing - Do not repair or replace any part of the appliance
unless specifically recommended in the manual. All other servicing should
be referred to a qualified technician.
Always disconnect the power to the appliance before servicing by
removing the fuse or switching off the circuit breaker.
Do not enter the oven.
Do not store items of interest to children in cabinets above a
range or on the back guard of a range. Children climbing on the range
to reach items could be seriously injured.
Do not leave children alone. Never leave children alone or unattended
in an area where this appliance is in use. They should never be allowed to
sit or stand on any part of the appliance.
Never use your appliance for warming or heating the room.
Do not use water on grease fires. Turn off the oven to avoid spreading
the flame. Smother the fire or flame by closing the door or use a dry
chemical, baking soda, or foam-type extinguisher.
Avoid scratching or impacting glass doors, cooktops or control panels.
Doing so may lead to glass breakage. Do not cook on a product with
broken glass. Shock, fire or cuts may occur.
If there is a fire in the oven during baking, smother the fire by closing
the oven door and turning the oven off or by using a multi-purpose dry
chemical or foam-type fire extinguisher.
If there is a fire in the oven during self-clean, turn the oven off and wait
for the fire to go out. Do not force the door open. Introduction of fresh
air at self-clean temperatures may lead to a burst of flame from the oven.
Failure to follow this instruction may result in severe burns.
If the oven is heavily soiled with oil, self clean the oven before using the
oven again. Leaving the oil in place creates a risk of fire.
Wipe up heavy soil on the oven bottom with a paper tower or rag before
self cleaning. Self cleaning the oven when there is heavy soil on the oven
bottom requires longer cleaning cycles and produces more smoke.
Storage in or on appliance. Do not store flammable materials in the
oven or near the surface units. Be sure all packing materials are removed
from the appliance before operating it. Keep plastics, clothes, and paper
away from parts of the appliance that may become hot.
Wear proper apparel. Never wear loose-fitting or hanging garments
while using the appliance.
3_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 3
2013-04-25 �� 5:25:33
Use only dry potholders. Placing moist or damp potholders on hot
surfaces may result in burns from steam. Do not let the potholder touch
hot heating elements. Do not use a towel or other bulky cloth on or near
the range.
Teach children not to play with the controls or any other part of the range.
For your safety, do not use high-pressure water cleaners or steam jet cleaners
to clean the any part of the range.
If the power cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons to avoid creating a hazard.
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Surface cooking units
Never leave surface units unattended at high heat settings.
Boilovers cause smoking and greasy spillovers that may ignite.
To avoid oil spillover and fire, use a minimum amount of oil when shallow
pan-frying and avoid cooking frozen foods with excessive amounts of ice.
Do not lift the cooktop. Lifting the cooktop can damage the range and
cause the range to malfunction.
Do not operate the cooktop without cookware. If you operate the
cooktop without cookware, the control knobs will become hot.
Never use the glass cooktop surface as a cutting board.
Use care when touching the cooktop. The glass surface of the
cooktop will retain heat after the controls have been turned off.
Be careful when placing spoons or other stirring utensils on the
glass cooktop surface when it is in use. They may become hot and
could cause burns.
Use proper pan sizes. This appliance is equipped with surface units of
different sizes. Select pots and pans that have flat bottoms large enough
to cover the surface area of the heating element. Using undersized
cookware will expose a portion of the heating element to direct contact
and may result in the ignition of clothing. Matching the size of the pot or
pan to the burner will also improve efficiency.
important safety instructions _4
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 4
2013-04-25 �� 5:25:33
Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Units – To reduce the risk of burns, ignition of
flammable materials, and spillage due to unintentional contact with
utensils, position utensil handles so that they are turned inward, and do
not extend over adjacent surface units.
Glazed cooking utensils. Only certain types of glass, glass/ceramic,
ceramic,earthenware, or other glazed cookware are suitable for range-top
service without breaking due to sudden change in temperature.
Cookware handles should be turned outward and not extend
over adjacent surface units. To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact with
cookware, position cookware handles so that they are turned outward,
and do not extend over adjacent surface units.
Cleaning. Read and follow all instructions and warnings on the cleaning
cream labels.
Be sure you know which control knob operates each surface unit. Always
make sure you have turned on the correct surface unit.
Always turn the surface units off before removing cookware.
When preparing flaming foods under the hood, turn the fan on.
Keep an eye on foods being fried at high or medium high heat settings.
DO NOT store heavy items above the cooktop surface that could
fall and damage it.
Do Not Use Decorative Surface Element Covers – If an element is
accidentally turned on, the decorative cover will become hot and possibly
melt. Burns will occur if the hot covers are touched. Damage may also be
done to the cooktop.
Electrical safety
Proper Installation- Be sure your appliance is properly installed and
grounded by a qualified technician.
The appliance should be serviced only by qualified service personnel.
Repairs carried out by unqualified individuals may cause injury or a
serious malfunction. If your appliance is in need of repair, contact a
Samsung authorized service center. Failure to follow these instructions
may result in damage and void the warranty.
5_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 5
2013-04-25 �� 5:25:33
Flush - mounted appliances may be operated only after they have been
installed in cabinets and workplaces that conform to the relevant electrical
and building codes. This ensures that the appliances are installed in
compliance with the appropriate safety standards.
If your appliance malfunctions or if fractures, cracks or splits appear:
- switch off all cooking zones.
- unplug the range from the AC wall outlet.
- contact your local service center.
WARNING
WARNING
WARNING- If the surface is cracked, switch off and unplug the appliance
to avoid the possibility of electrical shock. Do not use your cooktop until
the glass surface has been replaced.
WARNING- Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
The range should not be placed on a base.
Child safety
WARNING
WARNING- This appliance is not intended for use by young children or
infirm persons without the adequate supervision of a responsible adult.
Young children should be supervised to ensure that they do not play with
the appliance.
Keep children away from the oven when you open or close the door.
They could be struck by the door when you open it or catch their fingers
in the door when you close it.
The cooking zones will become hot when you cook. To keep small
children from being burned, always keep them away from the appliance
while you are cooking.
During self-cleaning, the range’s surfaces may get hotter than usual. To
prevent children from being burned, make sure that you keep them away
from the range when it is in the self-cleaning mode.
WARNING
WARNING- Accessible parts may become hot during use. To avoid
burns, young children should be kept away.
important safety instructions _6
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 6
2013-04-25 �� 5:25:33
OVEN
DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot even though
they are dark in color. Interior surfaces of an oven become hot enough to
cause burns. During and after use, do not touch or let clothing or other
flammable materials contact the heating elements or interior surfaces
of the oven until they have had sufficient time to cool. Other surfaces of
the appliance may become hot enough to cause burns. Among these
surfaces are oven vent openings and surfaces near these openings, the
oven door, and the window of the oven door.
Do not heat unopened food containers. The build-up of pressure may
cause the container to burst and result in injury.
Do not use the oven to dry newspapers. If overheated, newspapers
can catch on fire.
Do not use the oven for a storage area. Items stored in an oven can
ignite.
Use care when opening the door. Let hot air or steam escape before
you remove food from or put food into the oven.
Protective liners. Do not use aluminum foil to line the oven bottoms,
except as suggested in the manual. Improper installation of these liners
may result in a risk of electric shock or fire.
Keep oven vent ducts unobstructed. The oven vent is located below
the control box. This area could become hot during oven use. Never
block this vent or place plastic or heat-sensitive items on it.
Placement of oven racks. Always place oven racks in the desired
location while the oven is cool. If the rack must be moved while the oven
is hot, use potholders. Do not let the potholders come in contact with the
hot heating element in the oven.
Do not allow aluminum foil or a temp probe to contact the heating elements.
During use, the appliance becomes hot. Care should be taken to
avoid touching heating elements inside the oven.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass. They can scratch the surface which may result in the
glass shattering.
If there is a fire in the oven during baking, smother the fire by closing
the oven door and turning the oven off or by using a multi-purpose dry
chemical or foam-type fire extinguisher.
7_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 7
2013-04-25 �� 5:25:33
CAUTION
Do not attempt to operate the oven during a power failure. If the
power fails, always turn the oven off. If the oven is not turned off and
the power resumes, the oven may begin to operate again. Food left
unattended could catch fire or spoil.
WARMING DRAWER
DO NOT TOUCH THE HEATING ELEMENT OR THE INTERIOR
SURFACE OF THE DRAWER. These surfaces may be hot enough to
burn.
REMEMBER: The inside surface of the drawer may be hot when you
open the drawer.
The purpose of the warming drawer is to hold hot cooked foods at
serving temperature. Always start with hot food. Cold food cannot be
heated or cooked in the warming drawer.
Use care when opening the drawer. Open the drawer a crack and
let hot air or steam escape before removing or replacing food. Hot air or
steam which escapes can cause burns to hands, face and/or eyes.
Do not use the drawer to dry newspapers. If overheated, newspapers
can catch on fire.
Do not use aluminum foil to line the drawer. Foil is an excellent heat
insulator and will trap heat beneath it. This will upset the performance of
the drawer and it could damage the interior finish.
Do not leave paper products, plastics, canned food or combustible
materials in the drawer.
Never leave jars or cans of fat drippings in or near your drawer.
Do not warm food in the drawer for more than three hours.
SELF-CLEANING OVENS
Do not clean the door gasket. The door gasket is essential for a good
seal. Care should be taken not to rub, damage, or move the gasket.
Never keep pet birds in the kitchen. Birds are extremely sensitive
to the fumes released during an oven self-clean cycle. Fumes may be
harmful or fatal to birds. Move birds to a well-ventilated room.
Clean only the parts listed in this manual in the self-clean cycle.
Before self-cleaning the oven, remove the partition, rack, utensils, and
food.
important safety instructions _8
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 8
2013-04-25 �� 5:25:33
Before operating the self-clean cycle, wipe grease and food soils from the
oven. Excessive amount of grease may ignite, leading to smoke damage
to your home.
Do not use any commercial oven cleaner or oven liner protective coating
of any kind in or on the outside of the oven. Use only a ceramic cooktop
cleaner.
Remove the nickel oven shelves from the oven before you begin the selfcleaning cycle, or they may discolor.
If the self-clean mode malfunctions, turn the oven off and disconnect the
power supply. Have it serviced by a qualified technician.
Excess spillage must be removed before cleaning.
VENTILATING HOOD
Clean ventilating hoods frequently. Do not let grease accumulate on
the hood or filter.
When flaming foods under the hood, turn the fan on.
GLASS/CERAMIC COOKING SURFACES
DO NOT TOUCH SURFACE UNITS OR AREAS NEAR THE UNITS.
Surface units may be hot even though they are dark in color. Areas near
surface units may become hot enough to cause burns. During and after
use, do not touch, or let clothing or other flammable materials contact the
surface units or areas near the units until they have had sufficient time to
cool. Among these areas are the cook-top and the facing of the cook-top.
Do not cook on a broken cooktop. If the cooktop should break,
cleaning solutions and spillovers may penetrate the broken cook-top and
create a risk of electric shock. Contact a qualified technician immediately.
Clean the cooktop with caution. If you use a wet sponge or cloth to
wipe up spills on a hot cooking area, be careful to avoid steam burns.
Some cleaners can produce noxious fumes if applied to a hot surface.
9_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 9
2013-04-25 �� 5:25:33
WARNING
CRITICAL INSTALLATION WARNINGS
This appliance must be installed by a qualified technician or service company.
- Failing to have a qualified technician install the range may result in electric
shock, fire, an explosion, problems with the product, or injury.
Unpack the oven. remove all packaging material and examine the oven for
any damage such as dents on the interior or exterior of the oven, broken door
latches, cracks in the door, or a door that is not lined up correctly. If there is any
damage, do not install or operate the oven and notify your dealer immediately.
Plug the power cord into a properly grounded outlet with the proper
configuration. Your oven should be the only item connected to this circuit.
Keep all packaging materials out of the reach of children. Children may use them
for play and injure themselves.
Install your appliance on a hard, level floor that can support its weight.
- Failing to do so may result in abnormal vibrations, noise, or problems with the
product.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
- This may result in electric shock, fire, an explosion, or problems with the
product.
Do not cut or remove the ground prong from the power cord under any
circumstances.
Connect the oven to a circuit that provides the correct amperage.
Do not install this appliance in a humid, oily or dusty location, or in a location
exposed to direct sunlight or water (rain drops).
- This may result in electric shock or fire.
Do not use a damaged power cord or loose wall socket.
- This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the
power cord, or insert the power cord between objects.
- This may result in electric shock or fire.
If the power cord is damaged, contact your nearest service center.
important safety instructions _10
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 10
2013-04-25 �� 5:25:33
CAUTION
CRITICAL USAGE WARNINGS
If the appliance is flooded by any liquid, please contact your nearest service
center. Failing to do so may result in electric shock or fire.
If the appliance produces a strange noise, a burning smell, or smoke, unplug the
power plug immediately and contact your nearest service center.
- Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area
immediately. Do not touch the power cord. Do not touch the appliance.
- A spark can cause an explosion or fire.
Take care not to contact the oven door, heating elements, or any of the other
hot parts with your body while cooking or just after cooking.
- Failing to do so may result in burns.
If materials inside the oven should ignite, keep the oven door closed, turn the
oven off and disconnect the power cord, or shut off power at the fuse or circuit
breaker panel. If the door is opened, the fire may spread.
Always observe safety precautions when using your oven. Never try to repair the
oven on your own - there is dangerous voltage inside. If the oven needs to be
repaired, contact an authorized service center near you.
If you use the appliance when it is contaminated by foreign substances such as
food waste, it may result in a problem with the appliance.
Take care when removing the wrapping from food taken out of the appliance.
- If the food is hot, hot steam may be emitted abruptly when you remove the
wrapping and this may result in burns.
Do not attempt to repair, disassemble, or modify the appliance yourself.
- Since a high voltage current enters the product chassis, it may result in
electric shock or fire.
- When a repair is needed, contact your nearest service center.
If any foreign substance such as water has entered the appliance, contact your
nearest service center.
- Failing to do so may result in electric shock or fire.
Do not touch the power cord with wet hands.
- This may result in electric shock.
Do not turn the appliance off while an operation is in progress.
- This may cause a spark and result in electric shock or fire.
Keep all packaging materials well out of the reach of children, as packaging
materials can be dangerous to children.
- If a child places a plastic bag over its head, the child can suffocate.
Do not let children or any person with reduced physical, sensory or mental
capabilities use this appliance unsupervised.
11_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 11
2013-04-25 �� 5:25:33
Make sure that the appliance’s controls and cooking areas are out of the reach
of children.
- Failing to do so may result in electric shock, burns or injury.
Do not touch the inside of the appliance immediately after cooking. The inside of
the appliance will be hot.
- Failing to do so may result in burns.
Do not use or place flammable sprays or objects near the oven.
- Flammable items or sprays can cause fires or an explosion.
Do not insert fingers, foreign substances, or metal objects such as pins or
needles into inlets, outlets, or holes. If foreign substances are inserted into any
of these holes, contact your product provider or nearest service center.
Do not tamper with or make any adjustments or repairs to the door. Under no
circumstances should you remove the door or outer shell of the oven.
Do not store or use the oven outdoors.
Never use this appliance for purposes other than cooking.
- Using the appliance for any purpose other than cooking may result in fire.
Open the cap or stopper of sealed containers (herb tonic tea bottles, baby
bottles, milk bottles, etc.) before heating them. Make a hole in food items that
have shells (eggs, chestnuts, etc.) with a knife before cooking them.
- Failing to do so may result in burns or injury.
Never heat plastic or paper containers and do not use them for cooking.
- Failing to do so may result in fire.
Do not heat food wrapped in paper from magazines, newspapers, etc.
- This may result in fire.
Do not open the door if food in the oven is burning.
- If you open the door, it causes an inflow of oxygen and may cause the food
to ignite.
Do not apply excessive pressure to the door or the inside of the appliance. Do
not strike the door or the inside or the appliance.
- Hanging on to the door may result in the product falling and cause serious
injury.
- If the door is damaged, do not use the appliance. Contact a service center.
Do not hold food in your bare hands during or immediately after cooking.
- Use cooking gloves. The food may be very hot and you could burn yourself.
- Use cooking glove or gloves, Handle and oven surfaces may be hot enough
to cause burns after cooking.
important safety instructions _12
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 12
2013-04-25 �� 5:25:33
CAUTION
USAGE CAUTIONS
If the surface is cracked, turn the appliance off.
- Failing to do so may result in electric shock.
Dishes and containers can become hot. Handle with care.
Hot foods and steam can cause burns. Carefully remove container coverings,
directing the steam away from hands and face.
Remove lids from baby food jars before heating. After heating baby food, stir
well to distribute the heat evenly. Always test the temperature by tasting before
feeding the baby. The glass jar or the surface of the food may appear to be
cooler than the interior, which can be hot enough to burn an infant’s mouth.
Take care as beverages or food may be very hot after heating.
- Especially when feeding a child. Check that it has cooled sufficiently.
Take care when heating liquids such as water or other beverages.
- Make sure to stir during or after cooking.
- Avoid using a slippery container with a narrow neck.
- Wait at least 30 seconds after heating before removing the heated liquid.
- Failing to do so may result in an abrupt overflow of the contents and cause
burns.
Do not stand on top of the appliance or place objects (such as laundry, an oven
cover, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.)
on the appliance.
- Items, such as a cloth, may be caught in the door.
- This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
- This may result in electric shock.
Do not spray volatile substances such as insecticide onto the surface of the
appliance.
- As well as being harmful to humans, it may also result in electric shock, fire or
problems with the product.
Do not put your face or body close to the appliance while cooking or when
opening the oven door just after cooking.
- Take care that children do not come too close to the appliance.
- Failing to do so may result in children burning themselves.
Do not place food or heavy objects over the edge of the oven door.
- If you open the door, the food or object may fall and this may result in burns
or injury.
Do not abruptly cool the door, the inside of the appliance, or a dish by pouring
water over it during or just after cooking.
- This may result in damage to the appliance. The steam or water spray may
result in burns or injury.
13_ important safety instructions
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 13
2013-04-25 �� 5:25:33
Do not operate while empty except for self-cleaning.
Do not use the oven or cooktop to defrost frozen beverages in narrow-necked
bottles. The containers can break.
Do not scratch the glass of the oven door with a sharp object.
- This may result in the glass being damaged or broken.
Do not store anything directly on top of the appliance when it is in operation.
Do not use sealed containers. Remove seals and lids before cooking. Sealed
containers can explode due to buildup of pressure even after the oven has been
turned off.
Take care that food you are cooking in the oven does not come into contact
with the heating element.
- This may result in fire.
Do not over-heat food.
- Overheating food may result in fire.
CAUTION
CRITICAL CLEANING WARNINGS
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner or alcohol to clean the appliance.
- This may result in discoloration, deformation, damage, electric shock or fire.
Take care not to hurt yourself when cleaning the appliance (external/internal).
- You may hurt yourself on the sharp edges of the appliance.
Do not clean the appliance with a steam cleaner.
- This may result in corrosion.
Keep the inside of the oven clean. Food particles or spattered oils stuck to the
oven walls or floor can cause paint damage and reduce the efficiency of the oven.
CAUTION
St
ate of california proposition
65 warnings:
The California Safe Drinking Water and Toxic Enforcement Act requires the
Governor of California to publish a list of substances known to the State of
California to cause cancer, birth defects, or other reproductive harm, and
requires businesses to warn of potential exposure to such substances.
This product contains a chemical known to the State of California to cause
cancer, birth defects, or other reproductive harm. This appliance can cause
low-level exposure to some of the substances listed, including benzene,
formaldehyde, carbon monoxide, and toluene.
important safety instructions _14
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 14
2013-04-25 �� 5:25:34
contents
installing the oven
17
preparing to install the range
18
connecting the power
20
installing the range
26
introducing your new range
29
before you begin
30
getting started
30
17 About this section
17 For your safety
18 Remove packaging
18 Prepare tools & Parts
19 Checking the installation site
20 Step 1.Meeting electrical connection
requirements
21 Step 2.Accessing the power cord
connection
22 Step 3. Installing the power cord
24 Step 4. Installing the conduit
25 Step 5. Replacing the access cover
26 Installing the anti-tip device
27 Finalizing the installation
28 Optional rear filler kit
29 Overview
29 What’s included with your range
30 Before you begin
30
30
31
31
31
Setting the clock
Control panel display modes
Turning the oven light on and off
Control lockout
Setting the kitchen timer
15_ contents
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 15
2013-04-25 �� 5:25:34
contents
surface cooking
32
34
36
36
37
About surface cooking
How to set the appliance for surface cooking
Using the proper cookware
Choosing the proper cookware
Protecting the cooktop surface
operating the oven
38
39
41
42
43
The oven control panel
Using the oven racks
Using the gliding rack
Using the partition
Twin cooking mode temperature setting
ranges
Minimum and maximum settings
Baking
Convection baking
Convection roasting
Timed cooking
Delay start
Broiling
Using the favorite cook feature
Using the healthy cook feature
Using the keep warm function
Using the bread proof function
Using the options function
Using the temp probe
Setting the sabbath feature
32
38
44
44
45
47
48
49
50
51
52
55
55
55
58
60
using the warming drawer
61
62
maintaining your appliance
troubleshooting
72
76
warranty
61 About the warming drawer
61 Turning the warming drawer on or off
62
64
65
66
69
70
71
Self-cleaning
Steam-cleaning
Care and cleaning of the oven
Care and cleaning of the glass cooktop
Removing and replacing the oven door
Removing and replacing the warming drawer
Changing the oven light
72 Troubleshooting
76 Warranty (U.S)
77 Warranty (CANADA)
contents _16
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 16
2013-04-25 �� 5:25:34
installing the oven
About this section
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY.
Important note to the installer
• Read all instructions contained in these installation instructions before installing the range.
• Remove all packing materials from the oven compartments before connecting the electrical
supply to the range.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
Important note to the consumer
Keep these instructions for the local electrical inspector’s use.
• As when using any appliance generating heat, there are certain safety precautions you should
follow.
• Be sure your range is installed and grounded properly by a qualified installer or service
technician.
• Make sure the wall coverings around the range can withstand the heat generated by the range.
• To eliminate the need to reach over the surface elements, avoid having cabinet storage space
above the cooktop.
• The range should not be placed on a base.
For your safety
WARNING
WARNING
If the information in this manual is not followed exactly, a fire or electrical
shock may result causing property damage, personal injury or death.
WARNING
WARNING
Before beginning the installation, switch the power off at the service panel and
lock the service disconnecting switch to prevent power from being switched on accidentally. When the
service disconnecting switch cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
WARNING
WARNING This appliance must be properly grounded.
17_ installing the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 17
2013-04-25 �� 5:25:34
preparing to install the range
Remove packaging
Remove packaging materials. Failure to remove packaging materials could result in damage to the
appliance.
Prepare tools & Parts
Drill
Adjustable Wrench
Pliers
1/4˝
Nut Driver
Phillips Screwdriver
Flat Screwdriver
Pencil
Level
Screws (short:2 ea,
long:2 ea)
Filler Kit & Screws (3 ea)
PREPARING TO INSTALL THE RANGE
The tools you will need
What’s included with your range
Template
Anti-Tip Bracket
What’s not included
4-Wire Cord or 3-Wire Cord
(UL Approved 40 or 50 AMP)
Strain Relief
(For Conduit Installation Only)
preparing to install the range _18
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 18
2013-04-25 �� 5:25:35
Checking the installation site
Clearances and dimensions
To install the range, refer to the following figure.
CAUTION
CAUTION
This range has been designed to comply with the maximum allowable wood
cabinet temperatures of 194 °F. Make sure the wall covering, countertops and cabinets around the
range can withstand the heat (up to 194 °F) generated by the range. If not, discoloration, delamination
or melting may occur.
3”
24”
Hatched Faces should be
flat and leveled.
1/2” min.
1” min.
3”
23-3/16”
35-7/8”
31”
25”
B
36”~36-4/5”
A
29-4/5”
25-1/2” (26-3/10”)
6”
A : Cabinet opening
29-15/16”~30-1/16”
(76.04 - 76.28 cm)
B : Acceptable electrical
outlet area
Minimum dimensions
IMPORTANT
To eliminate the risk of burns or fire caused by reaching over heated surface
units, avoid having cabinet storage space located above the surface units. If you have cabinet storage
space over the heating elements, you can reduce the risk by installing a range hood that projects
horizontally a minimum of 5 inches beyond the bottom of the cabinets.
30”
* 30”
** 15”
* 30” minimum clearance between the top of
the cooking surface and the bottom of an
unprotected wood or metal cabinet; or 24”
minimum when the bottom of the wood or
metal cabinet is protected by not less than
1/4” of flame retardant millboard covered
with not less than no.28 MSG sheet steel,
0.015” stainless steel, 0.024” aluminum, or
0.020” copper.
** 15” minimum between the countertop and
the adjacent cabinet bottom.
19_ preparing to install the range
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 19
2013-04-25 �� 5:25:36
connecting the power
Step 1. Meeting electrical connection requirements
CAUTION
CAUTION
For personal safety, do not use an extension cord with this appliance.
Remove house fuse or open circuit breaker before beginning installation.
CONNECTING THE POWER
This appliance must be supplied with the proper voltage and frequency, and
be connected to an individual, properly grounded branch circuit, protected by
a circuit breaker or fuse having amperage as specified on the rating plate. The
rating plate is located above the drawer on the oven frame. (Fig. 1 or Fig. 2)
We recommend you have the electrical wiring and hookup of your range
connected by a qualified electrician. After installation, have the electrician
show you where your main range disconnect is located.
Check with your local utilities for electrical codes which apply in your area.
Failure to wire your oven according to governing codes could result in a
hazardous condition. If there are no local codes, your range must be wired and
fused to meet the requirements of the National Electrical Code, ANSI/NFPA No.
70–Latest Edition. You can get a copy by writing:
(Fig. 1)
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
(Fig. 2)
Effective January 1, 1996, the National Electrical Code requires that new construction
(not existing) utilize a 4-conductor connection to an electric range.
When installing an electric range in new construction, follow Steps 2 and 3 for 4-wire
connection.
You must use a 3-wire or 4-wire, single-phase A.C. 208Y/120 Volt or 240/120 Volt, 60 hertz
electrical system.
If the electrical service provided does not meet the above specifications, have a licensed
electrician install an approved outlet.
Use only a 3-conductor or a 4-conductor UL-listed range cord. These cords may be provided with
ring terminals on the wire and a strain relief device.
A range cord rated at 40 amps with 125/250 minimum volt range is required. A 50 amp range
cord is not recommended but if used, it should be marked for use with nominal 13⁄8” diameter
connection openings. Care should be taken to center the cable and strain relief within the
knockout hole to keep the edge from damaging the cable.
• Because range terminals are not accessible after the range is in position, a flexible service conduit or
cord must be used.
NOTE If conduit is being used, go to Step 4 on page 24.
ALL NEW BRANCH-CIRCUIT CONSTRUCTIONS, MOBILE HOMES,
RECREATIONAL VEHICLES AND INSTALLATIONS WHERE LOCAL CODES DO
NOT ALLOW GROUNDING THROUGH NEUTRAL, REQUIRE A 4-CONDUCTOR ULLISTED RANGE CORD.
connecting the power _20
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 20
2013-04-25 �� 5:25:37
Step 2.Accessing the power cord connection
Loosen and then remove the rear access cover screw with a screwdriver. Remove the rear access
cover by lifting it up and then out. The terminal block will then be accessible.
Terminal block
Access cover
Specified power-supply-cord kit rating
Range rating, watts
120/240 volts
3-wire
120/208 volts
3-wire
8,750 - 16,500
7,801 - 12,500
Diameter (inches) of range
connection opening
Specified rating of
power-supply-cord kit,
amperes
Power cord
Conduit
40 or 50 A
13/8”
11/8”
For power cord installations, go to page 22. For conduit installations, go to page 24.
21_ connecting the power
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 21
2013-04-25 �� 5:25:37
Step 3.Installing the power cord
For power cord installations, hook the strain relief over the power cord hole (13/8”) located below
the rear of the drawer body. Insert the power cord through the strain relief and tighten the device.
Conduit connection plate
CONNECTING THE POWER
Power cord
Strain relief
• You must install the power cord with a strain relief.
• Attach the strain relief to the 13/8” opening in the conduit connection plate.
Installing a 3-wire power cord
WARNING
WARNING
The neutral or ground wire of the power cord must be connected to the
neutral terminal located in the center of the terminal block. The power leads must be connected to the
lower left and the lower right terminals of the terminal block.
1. Remove the 3 lower terminal screws from the
terminal block.
2. Insert the 3 terminal screws through each
power cord terminal ring and into the lower
terminals of the terminal block. Be certain that
the center wire (white/neutral) is connected to
the center lower position of the terminal block.
Ground strap
Neutral
terminal
White
Black
Red
3. Tighten screws securely to the terminal
block. DO NOT remove the ground strap
connection.
4. Go to step 5 on page 25 to continue with the
installation.
Black
White
Red
connecting the power _22
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 22
2013-04-25 �� 5:25:38
Installing a 4-wire power cord
WARNING
WARNING
The neutral wire of the supply circuit must be connected to the neutral terminal
located in the lower center of the terminal block. The power leads must be connected to the lower left
and the lower right terminals of the terminal block. The 4th grounding lead must be connected to the
frame of the range with the ground plate and the ground screw.
1. Remove the 3 lower terminal screws from the terminal block. Remove the ground screw and
ground plate and retain them.
2. Cut and discard the ground strap. Do not discard any screws.
3. Insert the ground screw into the power cord ground wire terminal ring, through the ground plate,
and into the frame of the range.
4. Insert the 3 terminal screws (removed earlier) through each power cord terminal ring and into the
lower terminals of the terminal block. Be certain that the center wire (white/neutral) is connected to
the center lower position of the terminal block. Tighten screws securely to the terminal black.
5. Go to step 5 on page 25 to continue with the installation.
Neutral
terminal
White
Black
Red
Ground strap
Ground plate
Black
Ground
screw
White
Red
Ground
wire (Green)
23_ connecting the power
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 23
2013-04-25 �� 5:25:38
Step 4.Installing the conduit
Remove the conduit connection plate and rotate it as shown below.
The conduit hole (11/8”) must be used.
11/8”
13/8”
11/8”
1. Prepare the conduit cord as shown in Figure 1.
2. Install the conduit cord as shown in Figure 2.
Figure 1
3/8”
1”
Figure 2
1”
31/2”
3 wire
3/8”
Ring
Body
31/2”
CONNECTING THE POWER
13/8”
4 wire
Knockout surface
Strain relief
Conduit connection plate
For conduit installations, insert the strain relief (not included) into the conduit hole (11/8”). Then thread
the conduit cord through the body of the strain relief and fasten the ring. Reinstall the bracket.
Installing a 3-wire conduit
• Aluminum building wire may be used but it must be rated for the correct amperage and voltage.
Connect the wires as described below.
• The wire you use, the location and enclosure of splices, etc., must conform to good wiring
practices and local codes.
1. Loosen the 3 lower terminal screws from the
terminal block.
2. Insert the center bare wire (white/neutral) tip
through the bottom center terminal block opening.
On certain models, the wire will need to be
inserted through the ground strap opening and
then into the bottom center block opening.
Neutral
terminal
White
Black
Ground
strap
Red
3. Insert the two side bare wire tips into the lower left
and the lower right terminal block openings.
4. Tighten the screws until the wire is firmly secured
(35 to 50 inch-lbs.). Do not over-tighten the
screws since it could damage the wires.
5. Go to step 5 on page 25 to continue with the
installation.
Black
White
Red
Wire tips
connecting the power _24
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 24
2013-04-25 �� 5:25:39
Installing a 4-wire conduit
• Aluminum building wire may be used but it must be rated for the correct amperage and voltage to
make the connection. Connect the wires as described below.
• The wire you use, the location and enclosure of splices, etc., must conform to good wiring
practices and local codes.
1. Loosen the 3 lower terminal screws from the terminal block. Remove the ground screw and
ground plate and retain them.
2. Cut and discard the ground strap. Do not discard any screws.
3. Insert the ground bare wire tip between the range frame and the ground plate (removed
earlier) and secure it in place with the ground screw (removed earlier).
4. Insert the bare wire (white/neutral) tip through the bottom center of the terminal block opening.
5. Insert the two side bare wire tips into the lower left and the lower right terminal block
openings.
6. Tighten the screws until the wire is firmly secured (35 to 50 inch-lbs.). Do not over-tighten
the screws since it could damage the wires.
7. Go to step 5 below to continue with the installation.
Black
White
Red
Neutral
terminal
Ground strap
Ground plate
Wire tips
White
Black
Red
Ground
wire (Green)
Step 5.Replacing the access cover
To replace the rear access cover on the range back. insert the double projections on the bottom
of the cover into the pockets located below the opening, and then insert and tighten the rear
access cover screw.
25_ connecting the power
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 25
2013-04-25 �� 5:25:40
installing the range
Installing the anti-tip device
WARNING
WARNING
To reduce the risk of tipping, you must secure the appliance by properly
installing the Anti-Tip device packed with the appliance.
• Refer to the installation instructions supplied with the bracket.
Anti-Tip
bracket
*approximately
21/32” (16.5 mm)
Screw must enter
wood or concrete
*NOTE: To install the Anti-Tip
bracket, release the leveling
leg. A minimum clearance of
21/32” (16.5 mm) is required
between the range bottom and
the kitchen floor.
INSTALLING THE RANGE
• If the anti-tip device is not installed properly, an adult or child stepping on or sitting on the range
door could tip the range and suffer serious injuries caused by spilled hot liquids or by the range itself.
1.Install the bracket using the template
The Anti-Tip bracket is packaged with a template. The instructions include information necessary
to complete the installation. Read and follow the instructions on the sheet (template) for range
installation.
2.Level the range
Level the range by adjusting the leveling legs with a wrench.
Raise range
Lower range
Leveling leg
installing the range _26
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 26
2013-04-25 �� 5:25:41
3.Check your adjustments
Use a spirit level to check your adjustments. Place the level diagonally on the oven rack or surface
cooktop, and confirm the range is level in the two directions shown below.
1. Check direction 1.
2. Check direction 2.
If the spirit level indicates that the range is not
level, adjust the leveling legs with a wrench.
Finalizing the installation
• Move range close enough to the opening to plug into the receptacle.
• Slide the range into position insuring that the rear left (or rear right) leg slides under the Anti-Tip
bracket.
• Carefully tip the range forward to insure that the Anti-Tip bracket engages the back brace and
prevents tip-over.
• Turn on the electrical power. Check the range for proper operation as described in the user manual.
Anti-Tip bracket
Leveling leg
27_ installing the range
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 27
2013-04-25 �� 5:25:41
Optional rear filler kit
If you are replacing a free-standing range with a slide-in range, you can use a Filler Kit to cover the
gap between the slide-In range and the back wall.
If the countertop depth is greater than 25”, there will be a gap between the filler kit and the
back wall.
INSTALLING THE RANGE
installing the range _28
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 28
2013-04-25 �� 5:25:42
introducing your new range
Overview
Surface control knobs
See page 34 for more information
Oven control panel
See page 38 for more information
Glass surface
Automatic oven light switch
Temp probe socket
Self/steam clean latch
Oven light
Oven door
Convection fan
Gasket
Shelf position
Partition insert position
What’s included with your range
* Wire rack (1)
* Gliding rack (1)
* Recessed rack (1)
* Partition (1)
* Temp probe (1)
If you need an accessory marked with a *, you can buy it from the Samsung
Contact Center (1-800-726-7864).
29_ introducing your new range
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 29
2013-04-25 �� 5:25:43
before you begin
Clean the oven thoroughly before using it for the first time. Remove the accessories, set the oven to bake,
and then run the oven at 400 °F for 1 hour before using. There will be a distinctive odor. This is normal.
Ensure your kitchen is well ventilated during this conditioning period.
Setting the clock
The clock must be set to the correct time of day for the automatic oven timing functions to work properly.
• The time of day cannot be changed during a timed cooking, a delay-timed cooking, or a selfcleaning cycle.
• You can choose between a 12-hour or 24-hour display. The default is 12-hour.
BEFORE YOU BEGIN
getting started
How to set the clock
1. Start the set up.
Press CLOCK.
2. Press CLOCK to select AM or PM.
(Skip this step on 24 hour display setting)
3. Enter the current time in hours and minutes on the number pad.
eg. 1,3,0 for 1:30
4. Press CLOCK or OVEN START/SET to save the changes.
Control panel display modes
Sleep Mode
Your control panel will remain in a sleep mode when not in use. Only the clock will display. You will
need to wake the control panel to begin any function.
Wake Mode
To wake the control panel, touch the wake-up key. After 2 minutes without activity (or one minute
when the oven is operating in standby mode), the control panel will return to Sleep mode. User
preferences are available in this mode as well as timers, the oven light, and the control lock.
before you begin _30
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 30
2013-04-25 �� 5:25:44
Turning the oven light on and off
• The oven light turns on automatically when the door is opened.
• The oven light turns off automatically when the door is closed.
• You can turn the oven light on and off manually by pressing OVEN LIGHT.
Control lockout
Control lockout lets you lock the buttons on the touch pad so they cannot be activated accidentally.
Control lockout is only activated in standby mode.
How to activate the control lockout feature
1. Press Control Lock Hold 3 Sec. for 3 seconds.
The display will show “Loc” and Lock icon continuously, as well as the current time.
All functions must be cancelled before Control lockout is activated.
This function is available only when the oven temperature is under 400 °F.
How to unlock the controls
1. Press Control Lock Hold 3 Sec. for 3 seconds.
“Loc” and the Lock icon will disappear from the display.
Setting the kitchen timer
The timer counts down elapsed time and will beep when the time you set has elapsed. It does not
start or stop cooking functions. You can use the kitchen timer with any of the other oven functions.
How to set the timer
1. Turn the timer on.
Press TIMER1 ON/OFF (TIMER2 ON/OFF).
2. Enter the amount of time you want.
Enter the amount of time you want using the number pad, eg. 1, 5. The timer can be set for
any amount of time from 1 minute to 9 hours and 99 minutes. If you make a mistake, press
CLEAR and enter the amount of time again.
3. Start the timer.
Press TIMER1 ON/OFF (TIMER2 ON/OFF) or OVEN START/SET.
4. When the set time has elapsed, the oven will beep and the display will show End until you
press the pad. You can cancel the timer at any time by pressing TIMER1 ON/OFF (TIMER2
ON/OFF).
31_ getting started
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 31
2013-04-25 �� 5:25:44
surface cooking
About surface cooking
BEFORE COOKING
CAUTION
• Do not use the glass cooktop surface as a cutting board.
• Turn the surface units on only after placing the cookware on them.
• Do not store heavy items above the cooktop surface. They could fall and damage it.
DURING COOKING
CAUTION
• Do not place aluminum foil or plastic items such as salt and pepper shakers, spoon
holders, or plastic wrappings on the range when it is in use. The hot air from the vent
could melt plastics or ignite flammable items.
surface cooking
• Do not place or store items that can melt or catch fire on the glass cooktop, even
when it is not being used.
• Make sure the correct surface unit is turned on.
• Never cook food directly on the glass. Always use cookware.
• Always place the pan in the center of the surface unit you are cooking on.
• Never leave surface units unattended while using a high heat setting. Boilovers cause
smoking and greasy spillovers that may catch on fire.
• Turn the surface units off before removing cookware.
• Do not use plastic wrap to cover food. Plastic may melt onto the surface and be very
difficult to remove.
AFTER COOKING
CAUTION
• Do not touch the surface units until they have cooled down.
• The surface may be still be hot and burns may occur if the glass surface is touched
before it has cooled down sufficiently.
• Immediately clean spills on the cooking area to prevent a tough cleaning chore later.
• If you have a cabinet directly above the cooking surface, make sure that the items
in it are infrequently used and can be safely stored in an area subjected to heat.
Temperatures in the cabinet may be unsafe for items such as volatile liquids, cleaners.
and aerosol sprays.
About the radiant surface elements
The temperature of radiant surface elements rises gradually and evenly. As the temperature rises,
the radiant element will glow red. To maintain the selected setting, the element will cycle on and
off. The heating element retains enough heat to provide a uniform and consistent heat during the
off cycle. For efficient cooking, turn off the element several minutes before cooking is complete.
This will allow residual heat to complete the cooking process.
Radiant elements have a limiter that allows the element to cycle ON and OFF, even at the
HI setting. This helps to prevent damage to the ceramic cooktop. Cycling at the HI setting
is normal. It can also occur if the cookware is too small for the radiant element or if the
cookware bottom is not flat.
surface cooking _32
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 32
2013-04-25 �� 5:25:44
Location of the radiant surface elements and controls
The radiant control knobs operate the radiant surface elements on the cooktop as shown below.
5
2
4
1. Left Front: 7”, 1,800 W (Bridge)
2. Left Rear: 7”, 1,800 W
1
3
6
3. Right Front: 6”/9”/12”, 3,000 W
4. Right Rear: 6”, 1,200 W
5. Warming Center: 100 W
6. Hot surface indicator
Hot surface indicator
• Comes on when the unit is turned on or hot to the touch.
• Stays on even after the unit is turned off.
• Glows until the unit is cooled to approximately 150 °F.
Cooking areas
• The cooking areas on your range are identified by permanent circles on the glass cooking
surface. For the most efficient cooking, fit the pan size to the element size.
• Pans should not extend more than ½˝ to 1˝ beyond the cooking area.
• When a control is turned on, you can see a glow through the glass cooking surface. The
element will cycle on and off to maintain the preset heat setting, even at high settings.
• For more information on selecting proper types of cookware, refer to the section “Using the
proper cookware” on page 36.
33_ surface cooking
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 33
2013-04-25 �� 5:25:44
How to set the appliance for surface cooking
CAUTION
• The surface elements may be hot even when off and burns can occur. Do not touch
the surface elements until they have cooled down sufficiently.
• At high or medium-high settings, never leave food unattended. Boilovers cause
smoking and greasy spillovers may catch on fire.
• Be sure you turn the control knob to OFF when you finish cooking.
Single surface unit control knob (left rear, right rear)
surface cooking
1. Push the knob in.
2. Turn in either direction to the setting you want.
• At both the off and high settings, the knob clicks into
position.
Bridge surface unit control knob (left front)
1. Push the knob in.
2. Turn in either direction to the setting you want.
• To use the single surface unit, turn the control knob
to the single burner setting.
• To use the bridge surface unit, turn the control knob
to the bridge burner setting.
Triple surface unit control knob (right front)
The triple surface unit has 3 cooking sizes to select from
so you can match the size of the cooking area to the size
of the cookware you are using.
1. Push the knob in.
2. Turn in either direction to the setting you want.
• To use the large surface unit, turn the control knob
to the large burner (A) settings.
• To use the middle surface unit, turn the control knob
to the middle burner (B) settings.
• To use the small surface unit, turn the control knob
to the small burner (C) settings.
If you removed knob for cleaning, insert it after check to direction. (refer to above figure)
surface cooking _34
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 34
2013-04-25 �� 5:25:45
The area on the knob between the high and off settings is not appropriate for cooking.
CAUTION
Recommended settings
SETTING
TYPE OF COOKING
HIGH
Starting most foods, bringing water to a boil, pan broiling
MEDIUM HIGH
Continuing a rapid boil, frying, deep fat frying
MEDIUM
Maintaining a slow boil, thickening sauces and gravies, steaming vegetables
MEDIUM LOW
Keeping foods cooking, poaching, stewing
LOW
Keeping foods warm, melting, simmering
Using the warming center
The warming center, located in the back center of the glass surface, will keep hot, cooked food
at serving temperature.
• The surface warmer will not glow red like the cooking elements.
• Do not warm food on the warming center for more than two hours.
• Use only cookware and dishes recommended as safe for oven and cooktop use.
• Always use potholders or oven mitts when removing food from the warming center as
cookware and plates will be hot.
• When warming pastries and breads, use covers that have an opening to allow
moisture to escape.
• Do not use plastic wrap to cover foods. Plastic may melt onto the surface and be very
difficult to clean off.
• Food should be kept in its container and covered with a lid or aluminum foil to
maintain food quality.
• Always start with hot food. Eating uncooked or cold food placed on the warming
center could result in illness.
CAUTION
1. Turn the warming center on.
Press WARMING CENTER ON/OFF.
2. Select the power setting you want.
Press WARMING CENTER LEVEL once to set it to the Level 1 setting. Press the pad twice
for the Level 2 setting, 3 times for Level 3.
3. Turn the warming center off.
Press WARMING CENTER ON/OFF.
• Pressing OVEN OFF does not turn the warming center off.
• For best results, all foods on the warming center should be covered with a lid or aluminum foil.
When warming pastries or breads, the lid or foil should be vented to allow moisture to escape.
Recommended settings
LEVEL
1
2
3
TYPE OF FOOD
Breads/pastries, casseroles, gravies, eggs
Dinner plate with foods, soups (cream), vegetables, sauces, stews, meats
Fried foods, soups (liquid), hot beverages
35_ surface cooking
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 35
2013-04-25 �� 5:25:45
Using the proper cookware
Using the right cookware can prevent many problems, such as uneven cooking or extended
cooking times. Using the proper pans will reduce cooking times and cook food more evenly.
CORRECT
Flat bottom and straight sides.
Check for flatness by
rotating a ruler across the
bottom of the cookware.
Curved and warped pan
bottoms.
• Weight of handle does not tilt
pan.
• Pan is well balanced.
• Pan size matches the amount
of food to be prepared
and the size of the surface
element.
• Made of a material that
conducts heat well.
• Always match pot diameter to
element surface diameter.
Pan overhangs element by more
than one-half inch.
surface cooking
• Tight fitting lids.
INCORRECT
Pan is smaller than element.
Heavy handle tilts pan.
Choosing the proper cookware
What your cookware is made of determines how evenly and quickly heat is transferred from the
surface element to the pan bottom.
• ALUMINUM - Excellent heat conductor. Some types of food will cause the aluminum to
darken. (Anodized aluminum cookware resists staining and pitting.) If aluminum pans are slid
across the ceramic cooktop, they may leave metal marks that resemble scratches. Remove
these marks as soon as the cooktop cools down.
• COPPER - Excellent heat conductor but discolors easily. May leave metal marks on ceramic
glass (see above).
• STAINLESS STEEL - Slow heat conductor with uneven cooking results. Is durable, easy to
clean and resists staining.
• CAST IRON - A poor conductor, but retains heat very well. Cooks evenly once cooking
temperature is reached. Not recommended for use on ceramic cooktops.
• ENAMELWARE - Heating characteristics will vary depending on base material. Porcelainenamel coating must be smooth to avoid scratching ceramic cooktops.
• GLASS - Slow heat conductor. Not recommended for ceramic cooktop surfaces because it
may scratch the glass.
surface cooking _36
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 36
2013-04-25 �� 5:25:46
Protecting the cooktop surface
Cleaning
• Clean the cooktop before using it for the first time.
• Clean your cooktop daily or after each use. This will keep your cooktop looking good and can
prevent damage.
• If a spillover occurs while you are cooking, immediately clean the spill from the cooking area
while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe the spill with a
clean dry towel.
• Do not allow spills to remain on the cooking area or the cooktop trim for a long period of time.
• Do not use abrasive cleansing powders or scouring pads, which will scratch the cooktop.
• Do not use chlorine bleach, ammonia, or other cleansers not specifically recommended for use
on a glass-ceramic surface.
Preventing marks and scratches
• Do not use glass cookware. It may scratch the cooktop.
• Do not place a trivet or wok ring between the cooktop and the pan. These items can mark or
scratch the cooktop.
• Make sure the cooktop and the pan bottom are clean.
• Do not slide metal pans across the cooktop.
Preventing stains
• Do not use a soiled dish cloth or sponge to clean the cooktop surface. A film will remain, which
may cause stains on the cooking surface after the area is heated.
• Continuously cooking on a soiled surface can result in a permanent stain.
Preventing other damage
• Do not allow plastic, sugar, or foods with high sugar content to melt onto the hot cooktop.
Should this happen, clean immediately.
• Do not let a pan boil dry. This will damage the cooktop and the pan.
• Do not use the cooktop as a work surface or cutting board.
• Do not cook food directly on the cooktop. Always use the proper cookware.
37_ surface cooking
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 37
2013-04-25 �� 5:25:46
operating the oven
The oven control panel
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For the best results,
familiarize yourself with the various features and functions of the oven as described below.
Detailed instructions for each feature and function follow later in this user manual.
2
1
3
5
4
6
7
8
9
26
27
10
11
13
14
12
15 19
16
20
17 21 18 22
23
24
OPERATING THE OVEN
25
1. DISPLAY: Shows the time of day, oven temperature, whether the oven is in the bake, broil or
self-cleaning mode, and the time set for the timer or automatic oven operations.
2. UPPER/LOWER: Use to activate the upper or lower oven for cooking operation.
3. TIMER ON/OFF: Use to set or cancel the minute timer. The minute timer does not start or
stop cooking.
4. COOKING TIME: Press and then use the number pad to set the amount of time you want
your food to cook. The oven will shut off when the cooking time has run out.
5. DELAY START: Press to set the oven to start and stop automatically at a time you set. (Bake,
Conv.bake/Roast, Cooking Time, and self clean only.)
6. CLOCK: Use to set the time of day.
7. OPTIONS: Use to bring up the user preference menu in the display.
8. LAMP: Press to turn the oven light on or off.
9. OVEN OFF: Press to cancel all oven operations except the clock and timer.
10.WARMING DRAWER: Press to turn the warming drawer on or off. (Low, Mid, Hi)
11.CONVECTION BAKE: Use to select the Convection bake function of the oven.
12.CONVECTION ROAST: Use to select the Convection roast function of the single or upper oven.
13.BAKE: Use to select the bake function of the single or lower oven.
14.BROIL: Use to select the broil function of the single or upper oven.
15.FAVORITE COOK: Use to save or recall a favorite cooking mode.
16.TEMP PROBE: Use to activate the temp probe mode.
17.KEEP WARM: Use to select the keep warm function of the single oven to keep cooked foods warm.
18.SELF CLEAN: Use to select the Self-cleaning function of the single oven.
19.HEALTHY COOK: Press to recall the healthy cook recipe setting of the oven.
20.BREAD PROOF: Use to select the Bread proof function.
21.STEAM CLEAN: Use to select the steam cleaning function of the single oven.
22.HI+/LO-: Use to raise or lower the temperature and increase or decrease times.
23.NUMBER PAD: Use to set any function requiring numbers such as the time of day on the
clock, the timer, the oven temperature, the start time and length of operation for timed baking.
24.CLEAR: Use to cancel previously entered temperature or times.
25.OVEN START/SET: Use to start any cooking or cleaning function in the oven.
26.CONTROL LOCKOUT: Use to disable all oven functions.
27.TOUCH TO WAKE-UP: Press to activate buttons and functions on the display.
operating the oven _38
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 38
2013-04-25 �� 5:25:46
Using the oven racks
Oven rack positions (single mode)
The single oven has 7 rack positions (1~7).
7
6
5
4
3
2
1
TYPE OF FOOD
RACK POSITION
Muffins, Browines, Cookies,
Cupcakes, Layer cakes, Pies,
Biscuits
4
Frozen pies
4
Casserole
4
Bundt or pound cakes
3
Angel food cakes
2
Small roast, hams
2
Turkey, Large roast
1
• This table is for reference only.
Oven rack positions with partition (twin mode)
The upper oven has 2 rack positions (A, B).
B
The lower oven has 4 rack positions (1~4).
A
4
3
2
1
TYPE OF FOOD
RACK POSITION
Upper
Lower
Frozen pies
A
2
Angel food cakes
-
2
Bundt or pound cakes
-
2
Muffins, Browines, Cookies,
Cupcakes, Layer cakes, Pies,
Biscuits
A
2
Casserole
A
2
Small roast, hams
A
2
Small turkey, Medium roast
-
1
• This table is for reference only.
Recessed rack position
If you use Recessed rack, the recessed ends must be
placed in the rack position above the desired position of
the food. See the following figure.
3
2
These rack positions are for flat racks. If recessed
rack is used, the rack position must be adjusted
as shown in the previous figure.
39_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 39
2013-04-25 �� 5:25:47
Rack and Pan Placement
Centering the baking pans in the oven as much as possible will produce better results. If baking
with more than one pan, place the pans so each has at least 1˝ to 1½˝ of air space around it.
If baking on two racks, place the oven racks in positions 2 and 4 or 2 and 5 when using a single
cavity.
For the best performance, place the oven racks in positions 2 and 4 when baking cakes on
multiple racks in a single cavity.
When baking cookies on multiple racks, place the oven racks in positions 2 and 5.
Place the pans or cookware as show in the figures below.
When baking on single oven rack, place the oven rack in position 3 or 4.
• If you use the gliding rack, place the gliding rack below the flat rack.
Type of Baking
OPERATING THE OVEN
Using Multiple Oven Racks
Rack positions
Cakes
2 and 4
Cookies
2 and 5
Single Oven Rack
Multiple Oven Rack
Before using the racks
The oven has three racks.
Each rack has stoppers that need to be placed correctly on the supports. These stoppers will
keep the rack from coming completely out.
CAUTION
• Do not cover a rack with aluminum foil or place on the oven bottom. This will hamper
the heat circulation, resulting in poor baking, and may damage the oven bottom.
• Arrange the oven racks only when the oven is cool.
operating the oven _40
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 40
2013-04-25 �� 5:25:48
Using the gliding rack
The fully extendable Gliding Rack makes food preparation easier, especially when preparing
heavier dishes. The Gliding Rack has 2 glide tracks that allow you to extend the rack well out of
the oven without touching the sides of the oven walls.
Installing the Gliding rack
• With the Gliding rack in the “Closed” position and the oven off, carefully insert the Gliding Rack
between the guides until the rack reaches the back.
• When using the Gliding Rack in the oven, be sure to pull on the handle of the rack only to
slide it in and out. If you grasp the frame while using the rack, the entire Gliding Rack will be
removed.
Rack
Guides
Removing the Gliding rack
• With the Sliding rack in the “Closed” position and the oven off and cool, grasp the rack and
frame and pull both forward to remove.
Do not install the Gliding rack directly above the Flat rack and Recessed rack.
CAUTION
You will not be able to install it properly and the rack could fall.
You can install the Gliding rack in any rack positions except the highest (level 7) and lowest
(level 1) rack position in the oven.
41_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 41
2013-04-25 �� 5:25:49
Using the partition
• To use twin mode operation, insert the partition.
• You cannot use the Self-Clean or Steam-Clean functions when the partition is installed in the
oven cavity.
• Handle the partition with both hands.
• Use oven gloves when inserting or removing the partition.
To Install the Partition into the Oven Cavity
1. Insert the partition into the 5th rack position of the cavity.
OPERATING THE OVEN
2. Push the partition in until its back end rests against the back of the cavity.
3. If the partition is installed correctly, the “-” icon appears on the display.
Range displays “E-0C”
CAUTION
• Check the partition to see if it is installed correctly.
To Insert the Partition into the Partition Storage Location
1. Open the warming drawer.
2. Tilt the partition up slightly and rest it on the slides on either side of the storage location.
3. Tip the partition down and push it in.
operating the oven _42
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 42
2013-04-25 �� 5:25:51
Twin cooking mode temperature setting ranges
When you use the upper and lower ovens at the same time, each oven has a minimum and
maximum amount of power available and consequently a minimum and maximum temperature
setting. Oven temperatures in the lower oven also limit broil settings in the upper oven. The
temperature and broil setting limitations are shown in the table below.
(O - Available, X - Not available)
LOWER OVEN
Available setting function and temp.
UPPER OVEN
Mode
Broil
Convection
Bake &
Convection
Roast
Set Temp
BAKE
MIN
Bake
Convection
Bake
MAX
MIN
MAX
Hi
350 °F
480 °F
350 °F
480 °F
Low
325 °F
480 °F
325 °F
480 °F
480 °F
400 °F
480 °F
400 °F
480 °F
450 °F
350 °F
480 °F
350 °F
480 °F
300 °F
250 °F
375 °F
250 °F
400 °F
250 °F
225 °F
300 °F
225 °F
325 °F
175 °F
175 °F
200 °F
175 °F
200 °F
UPPER OVEN
Available setting function and temp.
LOWER OVEN
Mode
Convection BAKE
Set Temp
BROIL
Convection BAKE & ROAST
LOW
HI
MIN
MAX
480 °F
O
O
400 °F
480 °F
450 °F
O
O
350 °F
480 °F
350 °F
O
X
275 °F
450 °F
325 °F
O
X
275 °F
400 °F
250 °F
X
X
225 °F
300 °F
175 °F
X
X
175 °F
200 °F
480 °F
O
O
400 °F
480 °F
450 °F
O
O
350 °F
480 °F
350 °F
O
X
275 °F
450 °F
325 °F
O
X
275 °F
400 °F
250 °F
X
X
225 °F
300 °F
175 °F
X
X
175 °F
200 °F
The twin cooking mode lets you use different settings for the upper and lower
compartments, such as different switch off times, cooking times and temperatures settings.
To apply or modify settings in either compartment, press the respective touch pad.
43_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 43
2013-04-25 �� 5:25:51
Minimum and maximum settings
All of the features listed in the table below have minimum and maximum time or temperature
settings.
A beep will sound each time you press a pad on the control panel and the entry is accepted. An
error tone will sound in the form of a long beep if the temperature or time you entered is below the
minimum or above the maximum setting for the feature.
FEATURE
MINIMUM
MAXIMUM
Bake
175 °F (80 °C)
550 °F (287 °C)
Broil
LO
HI
Convection Bake
175 °F (80 °C)
550 °F (287 °C)
Convection Roast
175 °F (80 °C)
550 °F (287 °C)
3 Hr.
5 Hr.
20 Min.
20 Min.
Warming Drawer
-
3 Hr.
Keep Warm
-
3 Hr.
Bake
175 °F (80 °C)
480 °F (250 °C)
Broil
LO
HI
Convection Bake
175 °F (80 °C)
480 °F (250 °C)
Convection Roast
175 °F (80 °C)
480 °F (250 °C)
Single Oven
Steam Clean
OPERATING THE OVEN
Self Clean
Twin Oven ( With partition)
Baking
The oven can be programmed to bake at any temperature from 175 °F to 550 °F.
Baking temperature and time will vary depending on the ingredients, size and shaped of the
baking pan used.
Dark or nonstick coatings may be cooked food faster with more browning.
How to set the temperature (Single mode)
1. Start the set up.
Press BAKE. The default temperature is 350 °F.
2. Enter the temperature you want on the number pad, eg. 3, 7, 5.
3. Start the bake function.
Press OVEN START/SET. The temperature display will start to change once the oven
temperature reaches 175 °F.
4. If you want to cancel baking or if you have finished, press OVEN OFF.
Place food in the oven after preheating if the recipe calls for it. Preheating is very important
for good results when baking cakes, cookies, pastry, and breads. After the oven has
reached the desired temperature, a long beep will sound 6 times.
operating the oven _44
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 44
2013-04-25 �� 5:25:51
How to set the temperature (Twin mode)
1. Insert the Partition.
2. Start the set up.
Press LOWER. (You can’t use this mode on the UPPER oven).
3. Press BAKE. The default temperature is 350 °F.
4. Enter the temperature you want to on the number pad eg. 3, 7, 5.
5. Start the bake function.
Press OVEN START/SET. The temperature display will start to change once the oven
temperature reaches 175 °F.
6. If you want to cancel baking or if you have finished, press LOWER OVEN OFF.
Place food in the oven after preheating if the recipe calls for it. Preheating is very important
for good results when baking cakes, cookies, pastry, and breads. After the oven has
reached the desired temperature, a long beep will sound 6 times.
How to adjust the temperature while cooking
1. Start the set up.
Press BAKE. The display will show the present temperature, eg. 375 °F.
2. Enter the temperature you want, eg. 425 °F, using the number pad.
3. Complete the entry by pressing OVEN START/SET.
The process is the same in twin mode.
If you leave the oven door open for more than 2 minutes when the oven is on, all heating
elements will shut off automatically.
When you have finished cooking, the cooling fan will continue to run until the oven has
cooled down.
Convection baking
7
7
6
6
5
5
4
4
3
3
2
2
1
1
By using the convection bake feature, you will be able to cook faster. You can program the oven
for convection baking at any temperature between 175 °F and 550 °F.
When operating in twin mode, you can program the oven for convection baking at any
temperature between 175 °F and 480 °F. This improved heat distribution allows for even cooking
and excellent results using multiple racks at the same time. Foods cooked on a single oven rack
will generally cook faster and more evenly with convection baking. Multiple oven rack cooking
may slightly increase cook times for some foods, but the overall result is time saved. Breads and
pastries brown more evenly.
45_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 45
2013-04-25 �� 5:25:52
Tip for convection baking (single mode)
The amount of time you save will vary depending on the amount and type of food you are
cooking. When baking cookies or biscuits, you should use pans with no sides or very low sides
to allow the heated air to circulate around the food. Using a pan with a dark finish will allow faster
cooking times.
When using convection baking with a single rack, place the oven rack in position 4. If cooking on
multiple racks, place the oven racks in positions 2 and 5 (when baking cookies) or 2 and 4 (when
baking cakes).
How to set the oven for convection baking (single mode)
Press
Bake. The default temperature is 350 °F.
2. Enter the temperature you want, eg. 400 °F, using the number pad. Set the temperature that is
called for in the recipe.
3. Press OVEN START/SET to begin convection baking.
The Conv.Bake icon and the adjusted oven temperature, eg. 400 °F, will appear in the display
for 2 seconds.
The temperature display will start to change once the oven temperature reaches 175 °F.
A beep will sound 6 times when the oven reaches the adjusted oven temperature.
OPERATING THE OVEN
1. Start the convection baking mode.
4. To turn off or cancel convection baking, press OVEN OFF.
How to set the oven for convection baking (twin mode)
Insert the partition into the cavity.
1. Start the Convection baking mode.
Press UPPER or LOWER to select the partition in which you intend to cook.
2. Press
Bake. The default temperature is 350 °F.
3. Enter the temperature you want, eg. 400 °F, using number pads.
You can select a temperature from 175 °F to 480 °F.
4. Press OVEN START/SET to begin convection baking.
The Conv.Bake icon and the adjusted oven temperature, eg. 400 °F, will appear in the display
for 2 seconds.
The temperature display will start to change once the oven temperature reaches 175 °F.
A beep will sound 6 times when the oven reaches the adjusted oven temperature.
5. To turn off or cancel convection baking, press UPPER OVEN OFF or LOWER OVEN OFF
depending on the partition you want to turn OFF.
The convection oven fan shuts off when the oven door is opened.
DO NOT leave the door open for long periods of time while using convection cooking or you
may shorten the life of the convection heating element.
If you leave the oven door open for more than 2 minutes when the oven is on, all heating
elements will shut off automatically.
When you have finished cooking, the cooling fan will continue to run until the oven has
cooled down.
operating the oven _46
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 46
2013-04-25 �� 5:25:52
Convection roasting
Convection roasting is good for cooking large tender cuts of meat, uncovered.
Heat comes from the top heating element. The convection fan circulates the heated air evenly
over and around the food. Meat and poultry are browned on all sides as if they were cooked on a
rotisserie. The heated air seals in juices quickly for a moist and tender product while, at the same
time, creating a rich golden brown exterior.
How to set the oven for convection roasting (single mode)
1. Start the convection roasting mode.
Press
Roast. The default temperature is 350 °F.
2. Enter the temperature you want, eg. 400 °F, using the number pads.
3. Press OVEN START/SET to begin convection roasting.
The Conv.Roast icon and the adjusted oven temperature, eg. 400 °F, will appear in the display
for 2 seconds.
The temperature display will start to change once the oven temperature reaches 175 °F.
A beep will sound 6 times when the oven reaches the adjusted oven temperature.
4. Turn off or cancel convection roasting by pressing OVEN OFF.
How to set the oven for convection roasting (twin mode)
1. Insert the partition in the cavity.
2. Start the convection roasting mode.
Press UPPER.
3. Press
Roast.
The default temperature is 350 °F.
4. Press OVEN START/SET to begin convection roasting.
5. To turn off or cancel convection roasting, press UPPER OVEN OFF.
The convection oven fan shuts off when the oven door is opened.
DO NOT leave the door open for long periods of time while using convection cooking or you
may shorten the life of the convection heating element.
If you leave the oven door open for more than 2 minutes when the oven is on, all heating
elements will shut off automatically.
When you have finished cooking, the cooling fan will continue to run until the oven has
cooled down.
47_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 47
2013-04-25 �� 5:25:52
Timed cooking
In timed cooking, the oven turns on immediately and cooks for the length of time you select. At
the end of the cooking time, the oven turns off automatically.
• You can use the cooking time feature only with another cooking operation (bake, convection
bake, convection roast, Healthy Cook, or Favorite Cook).
How to set the oven for timed cooking (single mode)
1. Enter the set up.
2. Enter the temperature you want, eg. 375 °F, using the number pad.
3. Press COOKING TIME.
4. Enter the cooking time you want, eg. 45 min, using the number pad.
You can set the cooking time for any amount of time from 1 minute to 9 hours and 99 minutes.
5. Press OVEN START/SET to begin cooking.
The temperature display will start to change once the oven temperature reaches 175 °F.
The oven will continue to cook until the set amount of time has elapsed, then turn off
automatically unless the keep warm feature was set. (Refer to the section on the keep warm
function on page 55.)
OPERATING THE OVEN
Press the pad for the cooking operation you want, eg. CONV.BAKE. The default temperature
is 350 °F.
6. You can cancel a cook time at any time by pressing OVEN OFF.
How to set the oven for timed cooking (twin mode)
Insert the partition into the cavity.
1. Enter the set up.
Press UPPER or LOWER for the cooking mode you want.
2. Press pad for the cooking operation you want, eg. CONV.BAKE. The default temperature is
350 °F.
3. Enter the temperature you want, eg. 375 °F, using the number pad.
4. Press COOKING TIME.
5. Enter the cooking time you want, eg. 45 minutes, using the number pad.
You can set the cooking time for any amount from 1 minute to 9 hours and 99 minutes.
6. Press OVEN START/SET to begin cooking.
7. You can cancel a timed cooking at any time by pressing OVEN OFF.
Place food in the oven after preheating if the recipe calls for it. Preheating is important for
good results when baking cakes, cookies, pastry, and breads. After the oven has reached
the desired temperature, a long beep will sound 6 times.
CAUTION
Use caution with the cooking time or delay start features. Use these features when
cooking cured or frozen meats and most fruits and vegetables. Foods that can easily
spoil, such as milk, eggs, fish, meat, or poultry, should be chilled in the refrigerator
first. Even when chilled, they should not stand in the oven for more than 1 hour before
cooking begins, and should be removed promptly when cooking is completed. Eating
spoiled food can result in sickness from food poisoning.
operating the oven _48
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 48
2013-04-25 �� 5:25:53
Delay start
In a delay timed cooking, the oven’s timer turns the oven on and off at times you select in
advance.
• You can use the delay start feature only with another cooking operation (bake, convection bake,
convection roast, Healthy Cook, or Favorite Cook).
• You can set the oven for a delay start before setting other cooking operations.
• The clock must be set to the current time.
How to set the oven for delay start (single mode)
1. Position the oven rack(s) and place the food in the oven.
2. Enter the set up.
Press the pad for the cooking operation you want, eg. CONV.BAKE. The default temperature is 350 °F.
3. Use the number pad to enter the temperature you want, eg. 375 °F.
4. Press COOKING TIME.
5. Enter the cooking time you want, eg. 45 minutes, using the number pad.
You can set the cooking time for any amount of time from 1 minute to 9 hours and 99 minutes.
6. Press DELAY START.
7. Enter the time you want the oven to turn on, eg. 4:30, using the number pad.
8. Press OVEN START/SET.
At the set time, a short beep will sound. The oven will begin to bake. When the oven has
reached the desired temperature, a long beep will sound 6 times.
How to set the oven for delay start (twin mode)
Insert the partition into the cavity.
1. Position the oven rack(s) and place the food in the oven.
2. Enter the set up.
Press UPPER or LOWER for the cooking mode you want.
3. Press the pad for the cooking operation you want, eg. CONV.BAKE. The default temperature is 350 °F.
4. Use the number pads to enter the temperature you want, eg. 375 °F.
5. Press COOKING TIME.
6. Enter the cooking time you want, eg. 45 minutes, using the number pad.
You can set the cooking time for any amount of time from 1 minute to 9 hours and 99 minutes.
7. Press DELAY START.
8. Enter the time you want the oven to turn on, eg. 4:30, using the number pads.
9. Press OVEN START/SET.
At the set time, a short beep will sound. The oven will begin to bake. When the oven has
reached the desired temperature, a long beep will sound 6 times.
Place food in the oven after preheating if the recipe calls for it. Preheating is important for
good results when baking cakes, cookies, pastry, and breads. After the oven has reached
the desired temperature, a long beep will sound 6 times.
49_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 49
2013-04-25 �� 5:25:53
Broiling
Broil mode is best for meats, fish, and poultry up to 1” thick. Broiling is a method of cooking
tender cuts of meat by direct heat under the broil element of the oven. The high heat cooks
quickly and gives a rich, brown outer appearance. Temp probe cannot be used with this mode.
How to set the oven for broiling (single mode)
1. Select the broil setting you want.
Press BROIL.
You can select Hi or Lo by pressing HI+ or LO-.
Use Lo to cook foods such as poultry or thick cuts of meat thoroughly without over-browning them.
2. Start the broiling function.
Press OVEN START/SET.
Broil one side until the food is browned. Turn over and broil the other side.
3. Press OVEN OFF once you have finished cooking or if you want to cancel broiling.
How to set the oven for broiling (twin mode)
Insert the partition into the cavity.
OPERATING THE OVEN
1. Press UPPER.
Press BROIL.
You can select Hi or Lo by pressing HI+ or LO-.
Use Lo to cook foods such as poultry or thick cuts of meat thoroughly without over-browning them.
2. Start the broiling function.
Press OVEN START/SET.
Broil one side until the food is browned. Turn over and broil the other side.
3. Press UPPER OVEN OFF once you have finished cooking or if you want to cancel broiling.
This oven is designed for CLOSE DOOR broiling.
The oven door must be closed during broiling.
If you leave the oven door open for more than 2 minutes when the oven is on, all heating
elements will shut off automatically.
When you have finished cooking, the cooling fan will continue to run until the oven has
cooled down.
CAUTION
Always use this cooking mode with the oven door
closed.
CAUTION
Use care when opening the door. Let hot air or steam escape before you remove food
from or put food into the oven.
operating the oven _50
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 50
2013-04-25 �� 5:25:53
Broiling Recommendation Guide
The size, weight, thickness, starting temperature, and your doneness preference will affect broiling times.
This guide is based on meats at refrigerator temperature.
Always use a broiler pan and its grid when broiling.
Always preheat the oven for 5 minutes before broiling.
Food
Hamburgers
Toasts
Beef steaks
Chicken pieces
Pork chops
Lamb chops
Fish fillets
Ham slices
(precooked)
Doneness
Size
Thickness
Medium
9 patties
Medium
16 patties
Medium
9 patties
Rack position
Cooking time
Single
Upper
1st side
2nd side
3/4”
7
B
2:50
2:00
3/4”
6
A
4:00
3:00
3/4”
6
A
3:30
3:00
-
9 toasts
-
5
A
0:50
0:35
Rare
-
1”
5
A
5:00
3:30-4:00
Medium
-
1-1½”
5
A
7:00
5:00-6:00
Well done
-
1½”
5
A
8:00
6:00-7:00
Well done
4.5 lbs.
1/2-3/4”
2
A
18:00-20:00 11:00-15:00
Well done
2-2½ lbs.
1/2-3/4”
2
A
13:00-15:00 8:00-11:00
Well done
1 lb.
1/2”
3 or 2
A
9:00-10:00
7:00-9:00
Medium
10-12 oz.
1”
3 or 2
A
5:00
4:00-5:00
Well done
1 lb.
1½”
3 or 2
A
7:00
6:00-8:00
Well done
-
1/4-1/2”
3 or 2
A
5:00-9:00
3:00-4:00
-
-
1/2”
3 or 2
A
5:00
4:00
Using the favorite cook feature
The favorite cook feature lets you record up to 3 different recipe settings. You can use the favorite
cook feature for baking, convection baking, or convection roasting. It will not work with any other
function, including the delay start feature.
How to record a recipe setting
1. Press the pad for the cooking operation you want to store, eg. BAKE. The default temperature
is 350 °F.
2. Use the number pad to enter the temperature you want, eg. 375 °F.
3. Press COOKING TIME.
4. Enter the cooking time you want, eg. 45 min, using the number pad.
5. You can store a recipe setting in one of three favorite cook positions. Press FAVORITE COOK
the number of times that corresponds to the position in which you want to store the setting.
eg. for FAVORITE COOK position 2, press FAVORITE COOK twice.
Recipe settings can be stored at position 1, 2, or 3.
6. Press OVEN START/SET.
How to recall a setting
1. Press FAVORITE COOK the number of times that corresponds to the position in which the
recipe setting is stored, eg. for Favorite Cook position 2, press FAVORITE COOK twice.
2. Start the stored cooking operation.
Press OVEN START/SET.
51_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 51
2013-04-25 �� 5:25:53
Using the healthy cook feature
You can use the Healthy Cook feature in both the single and twin cooking modes. To use the
Healthy Cook feature in the single cooking mode, follow the directions below. To use the Healthy
Cook feature in the twin cooking mode, insert the partition, select the cavity you want to use by
pressing upper or lower, and then follow the directions below.
Rice casserole
The Rice casserole feature provides a healthier cooking method for cooking rice casseroles
containing vegetables, herbs, chicken breasts, etc.
How to set the Rice casserole function
1. Press HEALTHY COOK. The default temperature is 375 °F.
2. Press 1 (Rice casserole) on the number pad.
Enter the temperature you want on the number pad.
3. Press OVEN START/SET to begin rice casserole cooking.
For the best results, cook rice casseroles with toppings uncovered, and stews and braised
meats covered to prevent evaporation.
OPERATING THE OVEN
When using this function, you do not need to preheat the oven prior to cooking. The cooking
temperature and cooking time depends on the quantity and material.
Baked potato
Baked potato mode is specially designed to bake potatoes or sweet potatoes.
When using this function, you do not need to preheat the oven prior to cooking.
How to set the Baked potato function
1. Press HEALTHY COOK. The default temperature is 375 °F.
2. Press 2 (Baked potato) on the number pad.
Enter the temperature you want on the number pad.
3. Press OVEN START/SET.
Grilled chicken
Grilled chicken mode is specially designed to cook chicken pieces or chicken breasts.
When using this function, you do not need to preheat the oven prior to cooking.
If you want to prevent over browning and drying of the skin, cover the breast with foil.
How to set the Grilled chicken function
1. Press HEALTHY COOK. The default temperature is 350 °F.
2. Press 3 (Grilled chicken) on the number pad.
Enter the temperature you want on the number pad.
operating the oven _52
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 52
2013-04-25 �� 5:25:53
Salmon steak
This feature is specially designed to cook Salmon steaks.
When using this function, you do not need to preheat the oven prior to cooking.
The temperature and cooking time depend on the quantity and thickness.
How to set the Salmon steak function
1. Press HEALTHY COOK. The default temperature is 350 °F.
2. Press 4 (Salmon steak) on the number pad.
Enter the temperature you want on the number pad.
3. Press OVEN START/SET.
White fish fillet
This feature is specially designed to cook white fish fillets.
When using this function, you do not need to preheat the oven prior to cooking.
The temperature and cooking time depend on the quantity and thickness.
How to set the White fish fillet function
1. Press HEALTHY COOK. The default temperature is 375 °F.
2. Press 5 (White fish fillet) on the number pad.
Enter the temperature you want on the number pad.
3. Press OVEN START/SET.
Healthy Cook Recommendation Guide
The guide below contains recommendations for using the Healthy Cook feature. This chart is for
reference only.
When using this function, you do not need to preheat the oven prior to cooking.
Food
Quantity
Rack Position
Default
Temp.
Single Upper Lower
(°F)
Oven
Temp.
(°F)
Cooking
Time
Recommendations
(min)
Put a cup of
instant rice, some
vegetables (carrot,
onion, zucchini,
eggplant, etc.) and
chicken breasts into
a baking dish.
Rice
casserole
17.5 oz
(500 g)
4
A
2
375
375 to
425
40-50
Pour a cup of hot
consomme into the
baking dish and
cover it with a lid
or foil.
To prevent the
bottom from over
cooking, do not use
an enamel or iron
baking dish.
53_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 53
2013-04-25 �� 5:25:53
Food
Quantity
Rack Position
Default
Temp.
Single Upper Lower
(°F)
Oven
Temp.
(°F)
Cooking
Time
Recommendations
(min)
Put 6 potatoes on a
tray or baking dish.
Baked
potato
6 ea
3
A
1
375
375 to
425
30-40
Do not cut the
potatoes in half.
Season the
potatoes after
cooking if desired.
3 pieces
19.5 oz
(550 g)
Chicken
Pieces
1~1.2 kg
5
2
A
A
1
1
350
350
350 to
425
350 to
425
30-40
30-40
Season the salmon
after cooking if
desired.
Put the chicken
pieces on a tray or
baking dish.
OPERATING THE OVEN
Salmon
steak
Put the salmon
steaks on a tray or
baking dish.
Season the chicken
after cooking if
desired.
Put the chicken
breasts (thickness
1/8 to 4/10 inch)
on a broiler pan or
baking dish.
Grilled
chicken
Chicken
Breast
4~6 pieces
2
A
1
350
350 to
425
30-40
Season the chicken
after cooking if
desired.
To prevent the
chicken from
over browning or
drying out, cover
the chicken with
aluminum foil.
Put the fish fillets
on a broiler pan or
baking dish.
White
fish fillet
4 fillets
(550 g)
5
A
1
375
350 to
425
20-30
Season the fish
after cooking if
desired.
To prevent the fish
from over browning
or drying out,
cover the fish with
aluminum foil.
operating the oven _54
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 54
2013-04-25 �� 5:25:53
Using the keep warm function
The keep warm feature maintains an oven temperature of 170 °F and will keep cooked food warm
for serving up to 3 hours after cooking has finished.
After 3 hours, the feature will shut the oven off automatically. The feature may be used without any
other cooking operations or may be set to activate after a timed or delay timed cooking operation.
You should not use this feature to reheat cold foods.
How to use the Keep Warm function
1. Press KEEP WARM.
2. Press OVEN START/SET.
3. Press OVEN OFF at any time to turn the feature off.
How to set the oven to activate the keep warm mode after a timed cooking
1. Set up the oven for TIMED COOKING.
(Refer to the section on Timed Cooking on page 48.)
2. Press KEEP WARM before pressing OVEN START/SET to begin cooking.
3. Press OVEN OFF at any time to turn the feature off.
Using the bread proof function
The Bread Proof function automatically provides the optimum temperature for the bread proof
process, and therefore does not have a temperature adjustment.
If you press BREAD PROOF when the oven temperature is above 100 °F, Hot will appear in the
display. Because these functions produce the best results when started while the oven is cool, we
recommend that you wait until the oven has cooled down and Hot disappears from the display.
1. Press BREAD PROOF.
2. Press START/SET.
3. Press OVEN OFF at any time to turn off the Bread Proof feature.
Using the options function
This function enables you to control various electronic control options. These options include temp
adjust, temp unit, auto conversion, 12 hour time of day or 24 hour time of day, 12 hour energy
saving, language, sound on/off, and demo mode.
The option menu is only available when the oven is not being used (not cooking).
Feature
Options
1. Temp Adjust
Lets you correct the temperature in the oven.
2. Temp Unit
Lets you program the oven control to display temperatures in Fahrenheit
or Centigrade.
3. Auto Conversion
The convection auto conversion feature automatically converts entered
regular baking temperatures to convection baking temperatures.
4. Time of Day
Lets you set the clock to display the time of day in the 12 hour or 24 hour
mode.
5.12 hour energy
saving
This feature automatically turns off the oven after 12 hours during baking
functions or after 3 hours during a broil function.
55_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 55
2013-04-25 �� 5:25:53
Feature
Options
6. Language
Lets you select English, French, or Spanish.
7. Sound On/Off
Lets you set the oven controls to operate silently.
8. Demo mode
This option is for use by retail establishments for display purposes only.
Temp Adjust
The oven temperature can be adjusted ±35 °F (±19 °C ).
How to correct the oven temperature
1. Press OPTIONS and 1 on the number pad.
2. Press Hi+ or Lo- to select higher or lower than the recommended temperature.
3. Enter the adjustment you want using the number pad. (0~35)
4. Press OVEN START/SET to save the changes.
OPERATING THE OVEN
The temperature in the oven has been calibrated at the factory. When first using the oven, be
sure to follow recipe times and temperatures. If you think the oven is too hot or too cool, you can
correct the temperature in the oven. Before correcting, test a recipe by using a temperature setting
that is higher or lower than the recommended temperature. The baking results should help you to
decide how much of an adjustment is needed.
This adjustment will not affect the broiling or the self-cleaning temperatures. The adjustment
will be retained in memory after a power failure.
Temp Unit (Fahrenheit or Celsius temperature selection)
You can program the oven control to display temperatures in Fahrenheit or Centigrade. The oven
has been preset at the factory to display in Fahrenheit.
How to change the display from Fahrenheit to Celsius or Celsius to Fahrenheit
1. Press OPTIONS and 2 on the number pad.
2. Press 1 (Fahrenheit) or 2 (Celsius) on the number pad.
3. Press OVEN START/SET to save the changes.
Auto Conversion
When you use the auto conversion feature, the convection auto conversion feature will
automatically convert entered regular baking temperatures to convection baking temperatures.
If this feature is activated, the display will show the actual converted (reduced) temperature. For
example, if you enter a regular recipe temperature of 350 °F and press Oven Start/Set, the display
will show the converted temperature of 325 °F.
(Default setting : off)
How to enable or disable the auto conversion feature
1. Press OPTIONS and 3 on the number pad.
2. Press 1 (Off) or 2 (On) on the number pad.
3. Press OVEN START/SET to save the changes.
operating the oven _56
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 56
2013-04-25 �� 5:25:53
Time of Day (12hr/24hr)
The oven control can be programmed to display time of day in the 12 hour or 24 hour mode.
The oven has been preset at the factory to display in the 12 hour mode.
How to change between the 12 and 24 hour time of day display
1. Press OPTIONS and 4 on the number pad.
2. Press 1 (12hr) or 2 (24hr) on the number pad.
3. Press OVEN START/SET to save the changes.
12 hour energy saving
If you accidently leave the oven on, this feature will automatically turn off the oven after 12 hours
during baking functions or after 3 hours during a broil function.
How to turn the 12 hour energy saving feature on or off
1. Press OPTIONS and 5 on the number pad.
2. Press 1 (Off) or 2 (On) on the number pad.
3. Press OVEN START/SET to save the changes.
Language
You can select English, French, or Spanish. The default setting is English.
How to change the language on the display
1. Press OPTIONS and 6 on the number pad.
2. Press 1 (EN), 2 (FR) or 3 (SP) on the number pad.
3. Press OVEN START/SET to save the changes.
Sound On/Off
Using Sound On/OFF, you can set the oven controls to operate silently.
How to turn the sound on or off
1. Press OPTIONS and 7 on the number pad.
2. Press 1 (Off) or 2 (On) on the number pad.
3. Press OVEN START/SET to save the changes.
Demo mode
This option is for use by retail establishments for display purposes only. (The heating element does
not operate.)
How to enable or disable the demo mode
1. Press OPTIONS and 8 on the number pad.
2. Press 1 (Off) or 2 (On) on the number pad.
3. Press OVEN START/SET to save the changes.
57_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 57
2013-04-25 �� 5:25:53
Using the temp probe
For many foods, especially roasts and poultry (beef, chicken, turkey, pork, lamb etc), measuring
the internal temperature is the best way to determine if the food is properly cooked.
The temp probe lets you cook meat to the exact internal temperature you want, taking the guess
work out of determining whether a piece of meat is done or not.
This function can be used with Bake, Convection Bake, or Convection Roast in Single mode.
After the internal temperature of the food reaches 100 °F, the increasing internal temperature will
be shown in the display.
How to use the Temp probe
• Insert the probe completely into the meat as shown
in the illustrations. It should not touch bone, fat, or
gristle.
• If you do not fully insert the probe into the meat, the
Temp Probe function will not work correctly because
the probe will sense the oven temperature, not the
temperature of the meat.
• For bone-in meats, insert the probe into the center of
the lowest and thickest portion of the piece.
OPERATING THE OVEN
1. Push the tip of the temp probe into the meat as fully as possible, so that the tip is in the center
of the meat.
• For whole poultry (turkey, large chickens, etc.), insert
the probe into the thickest part of the inner thigh,
parallel to the leg.
• If you activate the Keep Warm function to keep the
meat warm after you have cooked it using the Temp
Probe function, the meat’s internal temperature will
exceed the temperature you want.
2. Insert the temp probe plug into the socket on the top side wall of the oven as far as it will go.
3. Select the desired cooking function (Conv.Bake, Conv.Roast, Bake) and temperature.
4. Press TEMP PROBE to set the desired internal temperature.
5. Set the desired internal temperature by pressing the number pad.
Available temperatures
100 °F to 200 °F
6. If you want to use the Cook time, Delay start, or Keep warm function, set each function.
7. Press OVEN START/SET.
8. When the desired internal temperature is reached, the function automatically stops and an alarm
sounds.
CAUTION
To protect the temp probe’s tip, be careful not to insert the probe so that the tip
protrudes through the surface of the meat. Make sure that the tip is in or near the center
of the meat.
operating the oven _58
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 58
2013-04-25 �� 5:25:54
• Do not store the probe in the oven.
CAUTION
• Do not leave the probe inside the oven during a Self-Cleaing or Broiling cycle. You can
permanently damage the probe and it will no longer work.
• To avoid breaking the probe’s tip, defrost your food completely.
• Do not use tongs when inserting or removing the probe. Tongs can damage the probe.
• Use the temp probe for Temp probe function cooking only. Do not use the temp
probe for any other purpose.
If you remove the temp probe while the Temp probe function is operating or insert the temp
probe while baking or cooking normally, cooking will stop after 1 minute.
Temp probe table
Type of Food
Beef / Lamb
Internal temperature
Rare
140-150 °F
Medium
160-170 °F
Well done
175-185 °F
Pork
175-185 °F
Poultry
185-195 °F
If you cover the meat with aluminum foil and allow it to stand for 10 minutes after cooking,
the Internal temperature will rise 5-10 degrees.
Removing the Temp probe
Remove the temp probe plug from the socket.
After cooking, the temp probe is hot enough to cause burns.
CAUTION
59_ operating the oven
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 59
2013-04-25 �� 5:25:54
Setting the sabbath feature
(For use on the Jewish Sabbath & Holidays)
K
For further assiistance, guidelines for proper usage and a complete list of
models with the Sabbath feature, please visit the web at http:\\www.star-k.org.
How to use the Sabbath feature
1. Press BAKE.
The default temperature is 350 °F.
2. Enter the temperature you want, eg. 375 °F, by using the number pad.
3. Press OVEN START/SET.
OPERATING THE OVEN
You can use the Sabbath feature for baking only. The oven temperature may be set higher or
lower after you have set the Sabbath feature (the oven temperature adjustment feature should be
used only during Jewish holidays). The display, however, will not change and tones will not sound
when a change occurs. Once the oven is properly set for baking with the Sabbath feature active,
the oven will remain continuously on until the Sabbath feature is cancelled. This will override the
factory preset 12 hour energy saving feature. If the oven light is needed during the Sabbath, press
OVEN LIGHT before activating the Sabbath feature. Once the oven light is turned on and the
Sabbath feature is active, the oven light will remain on until the Sabbath feature is turned off. If the
oven light needs to be off, be sure to turn the oven light off before activating the Sabbath feature.
The temperature display will start to change once the oven temperature reaches 150 °F.
4. Press BAKE and TOUCH TO WAKE-UP at the same time for 3 seconds.
The display will show SAb.
Once SAb appears in the display, the oven control will no longer beep or display any further changes.
You may change the oven temperature once baking has started. Remember that the oven
control will no longer beep or display any further changes once the Sabbath feature is active.
5. You can turn the oven off at any time by pressing OVEN OFF. This will turn only the oven off. If
you want to deactivate the Sabbath feature, hold down BAKE and TOUCH TO WAKE-UP at
the same time for 3 seconds. Sab will disappear from the display.
Do not attempt to activate any other program feature except BAKE while the Sabbath
feature is active. ONLY the following key pads will function correctly with the Sabbath
feature: NUMBER PAD, BAKE, OVEN START/SET and OVEN OFF. ALL OTHER
KEYPADS should not be used once the Sabbath feature is activated.
You can change the oven temperature, but the display will not change and tones will not
sound when a change occurs. (the oven temperature adjustment feature should be used
only Jewish holidays) After changing the temperature while the unit is in Sabbath mode
there is a 15 seconds delay before the unit will recognize the change.
You can set the Cook time function before activating the Sabbath feature.
Should you experience a power failure or interruption, the oven will shut off. When power
is returned the oven will not turn back on automatically. SAb will be displayed in the oven
control display, but the oven will not operate. The food may be safely removed from the
oven while the oven is still in the Sabbath mode, however the oven cannot be turned back
on until after the Sabbath/Holidays. After the Sabbath observance turn OFF the Sabbath
mode. Press and hold both BAKE and TOUCH TO WAKE-UP for at least 3 seconds
simultaneously to turn the Sabbath mode off. The oven may be used normally.
Do not open the oven door or change the oven temperature for about 30 minutes after you
have started Sabbath mode to allow the oven to reach the set temperature. Note that, for
best performance, the oven fan operates only when the oven temperature is rising.
Do not use the cooktop when the range is in the Sabbath MODE.
operating the oven _60
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 60
2013-04-25 �� 5:25:54
using the warming drawer
About the warming drawer
The warming drawer will keep hot,
cooked foods warm. Always start with hot
food. Do not use to warm cold food other
than bread, crackers, chips or dry cereal.
Allow approximately 25 minutes for the
warming drawer to preheat.
• Do not line the warming drawer or pan with aluminum foil. Foil is an excellent heat
insulator and will trap heat beneath it. This will impede the performance of the drawer
and could damage the interior finish.
• Do not put liquid or water in the warming drawer.
• All foods placed in the warming drawer should be covered with a lid. When warming pastries or
breads, the cover should be vented to allow moisture to escape.
• Remove serving spoons, etc. before placing containers in the warming drawer.
• Food should be kept hot in its cooking container or transferred to a heat-safe serving dish.
CAUTION
Plastic containers or plastic wrap will melt if in direct contact with the drawer, pan or a
hot utensil. Melted plastic may not be removable and is not covered under your warranty.
Turning the warming drawer on or off
1. Set the warming drawer to the heat level you want.
Press WARMING DRAWER once for low, twice for medium, or 3 times for high, or 4 times for off.
The warming drawer starts automatically once you have finished selecting the level you want.
2. To turn the warming drawer off, press WARMING DRAWER until the warming drawer turns off.
• Pressing OVEN OFF does not turn the warming drawer off.
• The warming drawer cannot be used during a self-cleaning cycle.
Recommended settings
LEVELS
Low
Medium
High
TYPE OF FOOD
Rolls (soft), empty dinner plates
Gravies, eggs, biscuits, pastries, casseroles, vegetables, rolls (hard),
roasts (beef, pork, lamb)
Bacon, poultry, pizza, hamburger patties, pork chops, fried foods
• Different types of food may be placed in the warming drawer at the same time. For best
results, do not leave foods in the warming drawer for longer than 1 hour. Do not leave
smaller quantities or heat-sensitive foods, such as eggs, for longer than 30 minutes.
• The warming drawer will shut off automatically after 3 hours.
61_ using the warming drawer
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 61
2013-04-25 �� 5:25:54
maintaining your appliance
Self-cleaning
This self-cleaning oven uses high temperatures (well above cooking temperatures) to burn off
leftover grease and residue completely or reduce them to a finely powdered ash that you can wipe
away with a damp cloth.
• During the self-cleaning cycle, the outside of the range will become very hot to the
touch. Do not leave small children unattended near the appliance.
• Some birds can be sickened by the fumes given off during the self-cleaning cycle of
any range. Move birds to another well-ventilated room.
• Do not line the oven walls, racks, bottom, or any other part of the range with
aluminum foil. Doing so will result in poor heat distribution, produce poor baking
results, and cause permanent damage to the oven interior. Aluminum foil will melt and
adhere to the interior surface of the oven.
• Do not force the oven door open. This can damage the automatic door locking
system. Use care when opening the oven door after the self-cleaning cycle is
complete. Stand to the side of the oven when opening the door to allow hot air or
steam to escape. The oven may still be VERY HOT.
Before a self-cleaning cycle
MAINTAINING YOUR APPLIANCE
CAUTION
• We recommend venting your kitchen by opening a window
or using a ventilation fan or hood during the self-cleaning
cycle.
Fig. 1
• Remove the wire rack, broil pan, broil pan insert, all
cookware, and any aluminum foil from the oven.
• Wipe up debris from the oven bottom. (Fig. 1)
• The silver-colored oven racks can be self-cleaned, but they
will darken, lose their luster, and become hard to slide.
Fig. 2
Don’t hand
clean the
oven door
gasket.
You may
hand clean
the door.
• Residue on the front frame of the range and outside the
gasket on the door will need to be cleaned by hand. Clean
these areas with hot water, soap-filled steel-wool pads, or
cleansers such as Soft Scrub. Rinse well with clean water
and dry.
• Do not clean the gasket. The fiberglass material of the oven
door gasket cannot withstand abrasion. It is essential for
the gasket to remain intact. If you notice it becoming worn
or frayed, replace it. (Fig. 2)
• Make sure the oven light bulb cover is in place and the
oven light is off.
Remove oven racks and accessories before starting the self-clean mode.
maintaining your appliance _62
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 62
2013-04-25 �� 5:25:55
How to run a self-cleaning cycle
1. Select the length of time for the self-cleaning operation, eg. 3 hours.
Press SELF CLEAN once for a 3 hour clean time, twice for a 4 hour clean time, or 3 times for
a 5 hour clean time.
The default setting is 3 hours.
2. Start the self-cleaning cycle.
Press OVEN START/SET. The motor-driven door lock will engage automatically.
3. When the self-cleaning cycle is done, End will show in the display and a beep will sound 6 times.
• You will not be able to start a self-cleaning cycle if the control lockout feature is activated
or if the oven’s temperature is too hot.
• The oven door locks automatically. The display will show the cleaning time remaining.
It is not be possible to open the oven door until the temperature drops to a safe/cool
temperature.
• The self-cleaning feature will not operate when the warming drawer is on.
How to delay the start of self-cleaning
1. Press SELF CLEAN.
Select the desired self-clean time by pressing SELF CLEAN.
2. Press DELAY START.
3. Enter the time you want the clean cycle to start.
4. Press OVEN START/SET.
The display will show delay start, self clean, and the Lock icon. The motor-driven door lock
will engage automatically.
5. The Self-Cleaning cycle will turn on automatically at the set time.
How to turn off the self-cleaning feature
You may find it necessary to stop or interrupt a self-cleaning cycle due to smoke in the oven.
1. Press OVEN OFF.
2. You will be able to open the oven door once the oven has cooled down for approximately
1 hour.
After a self-cleaning cycle
• You may notice some white ash in the oven. Wipe it up with a damp cloth after the oven cools.
(If white spots remain, remove them with a soap-filled steel wool pad and rinse thoroughly with
a vinegar and water mixture.)
• If the oven is not clean after one cycle, repeat the cycle.
• You cannot set the oven for cooking until the oven is cool enough for the door to unlock.
63_ maintaining your appliance
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 63
2013-04-25 �� 5:25:55
Steam-cleaning
How to set the oven for steam-cleaning
For light cleaning, the Steam-cleaning function saves time and energy. For heavier-duty cleaning of
debris and grease, use the self-cleaning function.
1. Remove all accessories from the oven.
2. Pour approximately 10 oz. (300 ml) of water onto the bottom of the
empty oven and close the oven door.
Use normal water only, not distilled water.
MAINTAINING YOUR APPLIANCE
3. Press STEAM CLEAN.
4. Press OVEN START/SET.
When the operation is complete, the display will blink and a beep will sound.
5. Press OVEN OFF.
6. Clean the oven’s interior.
There will be a significant amount of water remaining on the
bottom of the oven after a steam-cleaning cycle. Remove the
residual water with a sponge or soft dry cloth.
When steam-cleaning, use exactly 10 oz. of water since this produces the best results.
If you press STEAM CLEAN when the oven temperature is above 100 ˚F, Hot will appear in
the display. Because these functions produce the best results when started while the oven
is cool, we recommend that you wait until the oven has cooled down and Hot disappears
from the display.
After a steam-cleaning cycle
• Take care when opening the door after a steam-cleaning procedure has ended. The water on
the bottom is hot.
• Open the oven door and remove the remaining water with a sponge. Do not leave the residual
water in the oven for any length of time. Wipe the oven clean and dry with a soft cloth. Do not
forget to wipe under the oven door seal.
• Use a detergent-soaked sponge, a soft brush, or a nylon scrubber to wipe the oven interior.
Remove stubborn residue with a nylon scourer. You can remove lime deposits with a cloth
soaked in vinegar.
• If the oven remains dirty, you can repeat the procedure once the oven has cooled.
• For heavy residue, such as grease left over from roasting, we recommend that you rub
detergent into the residue before activating the steam-cleaning function.
• After cleaning, leave the oven door ajar at a 15 ° angle to allow the interior enamel surface to
dry thoroughly.
maintaining your appliance _64
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 64
2013-04-25 �� 5:25:55
Care and cleaning of the oven
WARNING
• Be sure all controls are OFF and all surfaces are COOL before cleaning any
part of the range.
• If your range is removed for cleaning, servicing, or
any reason, be sure the Anti-Tip device is re-engaged
properly when the range is replaced. If you fail to reengage the Anti-Tip device, the range could tip and
cause serous injury.
Oven vent
Oven vent
• The oven vent is located below
the control box.
• This area could become hot
during oven use.
• It is normal for steam to come
out of the vent.
• The vent is important for proper
air circulation. Never block this
vent.
Cleaning painted parts and decorative trim
• For general cleaning, use a cloth with hot and soapy water.
• For more difficult residue and built-up grease, apply a liquid detergent directly onto the area and
leave for 30 to 60 minutes. Wipe with a damp cloth and dry. Do not use abrasive cleaners on
any of these surfaces. They can scratch.
Cleaning stainless steel surfaces
1. Shake the bottle of Stainless Steel Appliance Cleaner or polish well.
2. Place a small amount of stainless steel appliance cleaner or polish on a damp cloth or damp
paper towel.
3. Clean a small area, rubbing with the grain of the stainless steel if applicable.
4. Dry and buff with a clean, dry paper towel or soft cloth.
5. Repeat as necessary.
• Do not use a steel-wool pad. It will scratch the surface.
• If a mineral oil-based stainless steel appliance cleaner has been used before to clean
the appliance, wash the surface with dishwashing liquid and water prior to using the
Stainless Steel Appliance Cleaner or polish.
65_ maintaining your appliance
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 65
2013-04-25 �� 5:25:56
Oven racks
• If the racks are left in the oven during a self-cleaning cycle, their color will turn slightly blue and
the finish will be dull. After the self-cleaning cycle is complete and the oven has cooled, rub the
sides of the racks with wax paper or a cloth containing a small amount of oil. This will help the
racks glide more easily into their tracks.
• Gliding racks may be cleaned by hand with an abrasive cleaner or steel wool. During cleaning,
be careful not to allow water or cleaner to enter the slides on the sides of rack.
• Do not clean in a dishwasher.
• If the rack becomes hard to remove or replace, lightly wipe the oven rack guides with
cooking oil. Do not wipe cooking oil on the slides.
Don’t hand
clean the
oven door
gasket.
You may
hand clean
the oven
door.
• Use soap and water to thoroughly clean the top, sides,
and front of the oven door. Rinse well. You may use a
glass cleaner on the outside glass of the oven door.
DO NOT immerse the door in water. DO NOT spray or
allow water or the glass cleaner to enter the door
vents. DO NOT use oven cleaners, cleaning powders,
or any harsh abrasive cleaning materials on the outside
of the oven door.
• DO NOT clean the oven door gasket. The oven
door gasket is made of a woven material which is
essential for a good seal. Care should be taken not to
rub, damage, or remove this gasket.
MAINTAINING YOUR APPLIANCE
Oven door
Care and cleaning of the glass cooktop
Normal daily use cleaning
Use only a ceramic cooktop cleaner. Other creams may not be as effective.
By following these steps, you can maintain and protect the surface of your glass cooktop.
1. Before using the cooktop for the first time, clean it with a ceramic cooktop cleaner. This helps
protect the top and makes cleanup easier.
2. Daily use of a ceramic cooktop cleaner will help keep the cooktop looking new.
3. Shake the cleaning cream well. Apply a few drops of cleaner directly to the cooktop.
4. Use a paper towel or a cleaning pad for ceramic cooktops to clean the entire cooktop surface.
5. Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse.
WARNING
DAMAGE to your glass surface may occur if you use scrub pads other than those
recommended.
maintaining your appliance _66
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 66
2013-04-25 �� 5:25:56
Removing burned-on residue
1. Allow the cooktop to cool.
2. Spread a few drops of ceramic cooktop cleaner
on the entire burned residue area.
3. Using the cleaning pad for ceramic cooktops, rub
the residue area, applying pressure as needed.
4. If any residue remains, repeat the steps listed
above as needed.
5. For additional protection, after all residue has been
removed, polish the entire surface with ceramic
cooktop cleaner and a paper towel.
Removing heavy, burned-on residue
1. Allow the cooktop to cool.
2. Use a single-edge razor-blade scraper at
approximately a 45 ° angle against the glass
surface and scrape the soil. It will be necessary to
apply pressure in order to remove the residue.
3. After scraping with the razor scraper, spread a few
drops of ceramic cooktop cleaner on the entire
burned residue area. Use the cleaning pad to
remove any remaining residue. (Do not scrape the
seal.)
4. For additional protection, after all residue has
been removed, polish the entire surface with the
cooktop cleaner and a paper towel.
Removing metal marks and scratches
1. Be careful not to slide pots and pans across your cooktop. It will leave marks on the cooktop
surface. You can remove these marks by applying ceramic cooktop cleaner with a cleaning
pad for ceramic cooktops.
2. If pots with a thin overlay of aluminum or copper are allowed to boil dry, the overlay may leave
black discoloration on the cooktop. You should remove this discoloration immediately or it may
become permanent.
WARNING
Carefully check the bottoms of pans for roughness that may scratch the cooktop.
67_ maintaining your appliance
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 67
2013-04-25 �� 5:25:56
Cleaning the cooktop seal
To clean the seal around the edges of the glass, lay a
wet cloth on it for a few minutes, then wipe clean with
a nonabrasive cleaner.
• Sugary spillovers (such as jellies, fudge, candy, syrups) or melted plastics can cause pitting of the
surface of your cooktop. This is not covered under the warranty. You should clean the spill while it
is still hot. Take special care when removing hot substances. Refer to the following section.
• When using a scraper, be sure it is new and the razor blade is still sharp. Do not use a dull or
nicked blade.
Cleaning sugary spills and melted plastic
1. Turn off all surface units. Remove hot pans.
MAINTAINING YOUR APPLIANCE
Potential for permanent damage to the glass surface
2. Wearing an oven mitt, use a single-edge razor-blade scraper to move the spill to a cool area of
the cooktop. Remove the spill with paper towels.
3. Any remaining spillover should be left until the surface of the cooktop has cooled.
4. Don’t use the surface units again until all of the residue has been completely removed.
If pitting or indentations in the glass surface have already occurred, the cooktop glass will
have to be replaced. In this case, service will be necessary.
maintaining your appliance _68
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 68
2013-04-25 �� 5:25:57
Removing and replacing the oven door
How to remove the door
CAUTION
• The door is very heavy. Be careful when removing and lifting the door. Do not lift the
door by the handle.
• Turn the power OFF before removing the door.
1. Open the door completely.
2. Pull the hinge locks down toward the door frame to the unlocked position.
Hinge lock
Locked position
Unlocked position
3. Firmly grasp both sides of the door at the top.
4. Close the door to the door removal position, which is approximately 5 degrees from vertical
(Fig. 1).
5. Lift door up and out until the hinge arm is clear of the slot (Fig. 2).
about 5 °
Fig. 1
Fig. 2
How to replace the door
1. Firmly grasp both sides of the door at the top.
2. With the door at the same angle as the removal position, slide the indentation of the hinge arm
into the bottom edge of the hinge slot. The notch in the hinge arm must be fully inserted into
the bottom of the slot.
Hinge arm
Bottom
edge of slot
Indentation
69_ maintaining your appliance
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 69
2013-04-25 �� 5:25:58
3. Open the door fully. If the door will not open fully, the indentation is not inserted correctly in the
bottom edge of the slot.
4. Push the hinge locks up against the front frame of the oven cavity to the locked position.
Hinge lock
Unlocked position
Locked position
MAINTAINING YOUR APPLIANCE
5. Close the oven door.
Removing and replacing the warming drawer
CAUTION
Turn the power OFF before removing the warming drawer.
How to remove the warming drawer
1. Pull out the drawer until it stops.
2. Locate the locking clips near the back of each full-extension roller guide rail. Using two hands,
push down on the left clip and lift up on the right clip to release the clips. Pull the drawer the
rest of the way out.
Lever
Lever
Push down on the left guide
Pull up on the right guide
3. Pull the warming drawer away from the range.
How to replace the warming drawer
1. Position the ends of the full-extension roller guide rails in
the side rails of the drawer opening.
Right roller guide rail
2. Push in the drawer to close it and snap the locking clips into place.
maintaining your appliance _70
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 70
2013-04-25 �� 5:25:59
Changing the oven light
The oven light is a standard 40-watt appliance bulb. It will come on when the oven door is open.
When the oven door is closed, press OVEN LIGHT to turn it on or off. It will not work during a
self-cleaning cycle.
1. Make sure the oven and the bulb are cool.
2. Unplug the range or disconnect the power.
3. Turn the glass bulb cover in the back of the oven counterclockwise to remove.
4. Turn the bulb counterclockwise to remove it from its socket.
Remove Replace
Glass bulb cover
Bulb
5. Replace the light bulb and glass bulb cover by turning them clockwise.
6. Plug in the range or reconnect power.
CAUTION
Before changing your oven light bulb, disconnect the electrical power to the range at the
main fuse or circuit breaker panel. Make sure the oven and the bulb are cool.
71_ maintaining your appliance
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 71
2013-04-25 �� 5:26:00
troubleshooting
Troubleshooting
Samsung works hard to ensure that you don’t have problems with your new electric range. If you run into
unexpected trouble, look first for a solution in the table below. If, after trying the suggested solution, you’re
still having trouble, call Samsung at 1-800-SAMSUNG (1-800-726-7864).
POSSIBLE CAUSE
The appliance has been installed
improperly.
SOLUTION
• Place the oven rack in the center of the
oven. Place a level on the oven rack.
Adjust the leveling legs at the base of the
range until the oven rack is level.
• Insure the floor is level and strong and
stable enough to adequately support the
range.
• Contact a carpenter to correct the situation.
• Insure the cabinets are square and provide
sufficient room for installation.
The appliance
must be accessed
for servicing and
cannot be moved
easily.
The oven control
beeps and displays
an error code.
The surface units
will not maintain
a rolling boil or
will not cook fast
enough.
The surface units
will not turn on.
The surface unit
stops glowing when
changed to a lower
setting.
The floor is sagging or sloping.
The kitchen cabinets are not
properly aligned and make the
range appear to be not level.
The kitchen cabinets are not
• Contact a builder or installer to make the
square and built too tightly in to the
appliance accessible.
appliance.
Carpet is interfering with
• Provide sufficient space so the range can
movement of the range.
be lifted over the carpet.
• Press OVEN OFF and restart the oven.
You have a function error code.
If the problem persists, disconnect all
CODE
CAUSE
power to the range for at least 30 seconds
E-21 Oven sensor opened
and then reconnect the power. If this does
E-22 Oven sensor shorted
not solve the problem, call for service.
E-24 Oven heating over
E-2E Temp probe error
E-0E Door locking error
E-83 Communication error
-tE- Communication error
(Touch)
-dE- Divider error
TROUBLESHOOTING
PROBLEM
The range is not
level.
You may be using inappropriate
• Use pans which are flat and match the
cookware.
diameter of the surface unit selected.
In some areas, the power (voltage) • Cover the pan with a lid until the desired
may be low.
heat is obtained.
A fuse in your home may be blown • Replace the fuse or reset the circuit
or the circuit breaker tripped.
breaker.
The cooktop controls are set
• Check to see the correct control is set for
improperly.
the surface unit you are using.
This is normal. The unit is still on and hot.
troubleshooting _72
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 72
2013-04-25 �� 5:26:00
PROBLEM
POSSIBLE CAUSE
Areas of
Food spillover was not cleaned.
discoloration on the
cooktop.
The surface is hot and the model
features a light-colored cooktop.
The surface unit
This is normal.
frequently cycles on
and off.
The oven will not
The range is not completely
turn on.
plugged into the electrical outlet.
A fuse in your home may be blown
or the circuit breaker tripped.
The oven controls have been set
improperly.
The oven is too hot.
The appliance will
The appliance is not completely
not turn on.
plugged into the electrical outlet or
a fuse in your home may be blown
or the circuit breaker tripped.
Incomplete service wiring.
Power outage.
The oven light will
not turn on.
Oven smokes
excessively during
broiling.
SOLUTION
• Refer to the section on care and cleaning
of the glass cooktop on page 66.
• This is normal. The surface may appear
discolored when it is hot. This is temporary
and will disappear as the glass cools.
• The element will cycle on and off to
maintain the power setting.
• Make sure the electrical plug is inserted
into a live, properly grounded outlet.
• Replace the fuse or reset the circuit
breaker.
• See the chapter on operating the oven.
• Allow the oven to cool.
• Make sure the power cord is plugged into
a live, properly grounded outlet. Check the
fuse and circuit breakers.
• Call for service.
• Check to see if the house lights will turn
on. If required, call your local electric
company for service.
The light bulb is loose or defective. • Tighten or replace the bulb.
The switch operating light is
• Call for service.
broken.
The control has not been set
• Refer to the section on setting oven
properly.
controls.
The meat has been placed too
close to the element.
The meat has not been properly
prepared.
• Make sure the oven door is opened to the
broil stop position.
• Reposition the rack to provide proper
clearance between the meat and the
element. Preheat the broil element for
searing.
• Remove the excess fat from the meat. Cut
away fatty edges that may curl, leaving the
lean intact.
• Regular cleaning is necessary when
broiling frequently.
• See the chapter on operating the oven.
Grease has built up on oven
surfaces.
Food does not bake The oven controls have not been
or roast properly.
set correctly.
The oven rack has been positioned • See the section on using the oven racks
incorrectly or is not level.
on page 39.
Incorrect cookware or cookware of
improper size is being used.
The oven sensor needs to be
• See the section on adjusting the
adjusted.
thermostat on page 56.
73_ troubleshooting
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 73
2013-04-25 �� 5:26:00
PROBLEM
Food does not broil
properly.
Brown streaks or
specks.
Areas of
discoloration with
metallic sheen.
The oven will not
self-clean.
“Crackling” or
“popping” sound.
Excessive smoking
during a selfcleaning cycle.
The oven sensor needs to be
adjusted.
SOLUTION
• Press BROIL.
• See the Recommended broiling guide on
page 51.
• Use suitable cookware.
• Preheat the broil element for 10 minutes.
• See the Recommended broiling guide on
page 51.
• See the section on adjusting the
thermostat on page 56.
The cooktop is being cleaned
improperly.
• Scratches are not removable. Tiny
scratches will become less visible in time
as a result of cleaning.
Cookware with rough bottoms was • To avoid scratches, use the recommended
cleaning procedures. Make sure cookware
used on the cooktop or there were
coarse particles (eg. salt or sand)
bottoms are clean before use, and use
cookware with smooth bottoms.
present between the cookware
and the surface of the cooktop.
Cookware has been slid across the
cooktop surface.
Boilovers have been cooked onto • Use the blade scraper to remove soil.
the surface.
• See the section on care and cleaning of
the glass cooktop on page 66.
Mineral deposits from water and
• Remove using a ceramic-glass cooktop
food have been left on the surface
cleaning cream.
of the cooktop.
• Use cookware with clean, dry bottoms.
The oven temperature is too high
• Allow the range to cool and reset the
to set a self-clean operation.
controls.
The oven controls have been set
• See the section on self-cleaning on page
incorrectly.
62.
A self-cleaning cycle cannot be started if the oven lockout feature has been
activated or if a induction surface element is on.
This is the sound of the metal
• This is normal.
heating and cooling during
both the cooking and cleaning
functions.
There is excessive soiling in the
• Press OVEN OFF. Open the windows
oven.
to rid the room of smoke. Wait until the
self-cleaning cycle is cancelled. Wipe up
the excessive soil and reset the oven for
self-cleaning.
The oven is too hot.
• Allow the oven to cool.
The oven door will
not open after a
self-cleaning cycle.
Oven not clean
The oven controls were not set
after a self-cleaning correctly.
cycle.
The oven was heavily soiled.
TROUBLESHOOTING
The oven
temperature is too
hot or too cold.
Scratches or
abrasions on
cooktop surface.
POSSIBLE CAUSE
The oven controls have been set
incorrectly.
The rack has not been properly
positioned.
Cookware not suited for broiling.
In some areas the power (voltage)
may be low.
• See the section on self-cleaning on page
62.
• Wipe up heavy spillovers before starting
the self-cleaning cycle. Heavily soiled
ovens may need to be self-cleaned again
or for a longer period of time.
troubleshooting _74
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 74
2013-04-25 �� 5:26:00
PROBLEM
Steam from the
vent.
POSSIBLE CAUSE
When using the convection
feature, it is normal to see steam
coming out of the oven vent.
As the number of racks or amount
of food being cooked increases,
the amount of visible steam will
increase.
Burning or oily odor This is normal in a new oven and
emitting from the
will disappear in time.
vent.
SOLUTION
• This is normal.
• To speed the process, set a self-cleaning
cycle for a minimum of 3 hours.
• See the section on self-cleaning on page
62.
Strong odor.
An odor from the insulation around • This is temporary.
the inside of the oven is normal
for the first few times the oven is
used.
Fan noise.
A convection fan may automatically • This is normal.
turn on and off.
Oven racks are
The shiny, silver-colored racks
• Apply a small amount of vegetable oil to
difficult to slide.
were cleaned in a self-cleaning
a paper towel and wipe the edges of the
cycle.
oven racks with the paper towel.
Display goes blank. A fuse in your home may be blown • Replace the fuse or reset the circuit
or the circuit breaker tripped.
breaker.
Display flashes.
There was a power failure.
• Reset the clock.
Drawer does not
The drawer is out of alignment.
• Fully extend the drawer and push it all the
slide smoothly or
way in. See the page 70.
drags.
The drawer is over-loaded or the
• Reduce weight. Redistribute drawer
load is unbalanced.
contents.
Warming drawer will A fuse in your home may be blown • Replace the fuse or reset the circuit
not work.
or circuit breaker tripped.
breaker.
The controls are not set correctly. • See the chapter on using the warming
drawer on page 61.
Excessive
There is liquid present in the
• Remove the liquid.
condensation in the drawer.
drawer.
Uncovered foods.
• Cover food with a lid.
The temperature is set too high.
• Adjust the temperature to a lower setting.
Food dries out in
Moisture is escaping.
• Cover food with a lid.
the warming drawer. The drawer is not fully closed.
• Push the drawer in until the latch engages.
75_ troubleshooting
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 75
2013-04-25 �� 5:26:00
warranty (U.S)
PLEASE DO NOT DISCARD THIS REPLACES THE WARRANTY PAGE IN THE USE & CARE GUIDE
SAMSUNG ELECTRIC RANGE
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered
new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials
and workmanship for a limited warranty period of:
During this limited additional four-year warranty, you will responsible for any labor or in-home service.
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service
can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as
proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. Samsung will provide in-home service during the warranty
period at no charge subject to availability within the contiguous United States. In home service is not available in all areas. To receive in
home service product must be unobstructed and accessible to the service agent. If service is not available Samsung may elect to provide
transportation of the product to and from an authorized service center.
WARRANTY
One (1) Year Parts and Labor, Five (5) Years Parts Warranty
For Glass Cooktop and Heater Radiant
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or
products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property
of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety
(90) days, whichever is longer.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this
product and shall not apply to the following: damage which occurs in shipment; delivery and installation; applications and uses for which
this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire,
water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications,
installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result
in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating
instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal and
reinstallation; problems caused by pest infestations, and overheating or overcooking by user. This limited warranty shall not cover cases
of incorrect electric current, voltage or supply, light bulbs, house fuses, house wiring, cost of a service call for instructions, or fixing
installation errors. Furthermore, damage to the glass cooktop caused by the use of cleaners other than the recommended cleaners and
pads, damage to the glass cook top caused by hardened spills of sugary materials or melted plastic that are not cleaned according to the
directions in the use and care guide are not covered. SAMSUNG does not warrant uninterrupted or error-free operation of the product.
EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED AND
SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY,
INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING,
PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S
PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT.
THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS
NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics America Inc.,
85 Challenger Road, Ridgefield Park, NJ 07660-0511
1-800-SAMSUNG (726-7864) and www.samsung.com
warranty _76
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 76
2013-04-25 �� 5:26:00
warranty (CANADA)
PLEASE DO NOT DISCARD THIS REPLACES THE WARRANTY PAGE IN THE USE & CARE GUIDE
SAMSUNG ELECTRIC RANGE
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC. (SAMSUNG) and delivered
new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials
and workmanship for a limited warranty period of:
One (1) Year Parts and Labor, Five (5) Years Parts Warranty
For Glass Cooktop and Heater Radiant
During this limited additional four-year warranty, you will responsible for any labor or in-home service.
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service
can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as
proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. Samsung will provide in-home service during the warranty
period at no charge subject to availability within the contiguous United States. In home service is not available in all areas. To receive in
home service product must be unobstructed and accessible to the service agent. If service is not available Samsung may elect to provide
transportation of the product to and from an authorized service center.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or
products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property
of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety
(90) days, whichever is longer.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this
product and shall not apply to the following: damage which occurs in shipment; delivery and installation; applications and uses for which
this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire,
water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications,
installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result
in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating
instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal and
reinstallation; problems caused by pest infestations, and overheating or overcooking by user. This limited warranty shall not cover cases
of incorrect electric current, voltage or supply, light bulbs, house fuses, house wiring, cost of a service call for instructions, or fixing
installation errors. Furthermore, damage to the glass cooktop caused by the use of cleaners other than the recommended cleaners and
pads, damage to the glass cook top caused by hardened spills of sugary materials or melted plastic that are not cleaned according to the
directions in the use and care guide are not covered. SAMSUNG does not warrant uninterrupted or error-free operation of the product.
EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED AND
SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY,
INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING,
PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S
PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT.
THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS
NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics Canada Inc.,
Customer Service 55 Standish Court, Mississauga, Ontario L5R 4B2 Canada
1-800-SAMSUNG (726-7864) and www.samsung.com
77_ warranty
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 77
2013-04-25 �� 5:26:00
memo
(IB_Best)NE58F9710WS_AA_DG68-00506A_EN_130425-1.indd 78
2013-04-25 �� 5:26:00
Please be advised that the Samsung warranty does NOT cover service calls to explain product
operation, correct improper installation, or perform normal cleaning or maintenance.
CANADA
1-800-SAMSUNG (726-7864)
MEXICO
01-800-SAMSUNG (726-7864)
U.S.A
Consumer Electronics
1-800-SAMSUNG (726-7864)
www.samsung.com/ca (English)
www.samsung.com/ca_fr (French)
www.samsung.com
Code No. : DG68-00506A
