CXl09HL1W
CXl12HL1W
CXl18HL1W
EN SPLIT INVERTER
AIR CONDITIONER
USER MANUAL
2 www.electroluxaircomfort.com
TABLE OF CONTENTS
Congratulations .............................................................................................................................2
Safety Precautions .........................................................................................................................3
Product Description .......................................................................................................................6
Indoor Unit Display ........................................................................................................................7
Remote Control .............................................................................................................................7
Quick Start Guide ..........................................................................................................................8
Remote Control Description ...........................................................................................................8
Remote Control Display Indicators ...............................................................................................11
First Use ......................................................................................................................................12
How to use the Remote Control ..................................................................................................12
How to use the Indoor Unit ..........................................................................................................17
Emergency Operation ..................................................................................................................19
Optimal Operation .......................................................................................................................19
Cleaning and Maintenance ..........................................................................................................20
Operation Tips .............................................................................................................................23
Troubleshooting ...........................................................................................................................25
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.
Welcome to Electrolux.
Electrolux Central Vacuum Systems
5855 Terry Fox Way
Mississauga, ON, L5V 3E4
Canada
Visit our website:
Get usage advice, brochures, trouble shooter, service information:
www.electroluxaircomfort.com
Important Reminder
•
•
•
•
•
Keep the remote control where its signal can reach the receiver of the indoor unit.
When operate the air conditioner, make sure the remote control is pointing to the signal receiver
of the indoor unit.
When the remote control sends out a signal, the symbol will blink for about 1 second on the
display of the remote control.
The indoor unit will acknowledge the signal with a beep when it receives the signal from the
remote control.
Please press the button of the remote control and resend the signal if you did not hear a beep
from the indoor unit.
www.electroluxaircomfort.com 3
CONGRATULATIONS!
Congratulations and thank you for choosing a
split-type air conditioner. We are sure you will
find your new air conditioner a pleasure to use.
Before you use the air conditioner, we
recommend that you read through the entire
user manual, which provides the description of
the air conditioner and its functions.
To avoid the risks that are always present when
you use an electrical appliance, it is important
that the air conditioner is installed correctly and
that you read the safety instructions carefully to
avoid misuse and hazards.
We recommend that you keep this instruction
booklet for future reference and pass it on to any
future owners.
After unpacking the air conditioner please check
it is not damaged. If in doubt, do not use the air
conditioner but contact your local authorised
service centre.
Environmental Tip
Information on disposal for users
• Most of the packing materials are recyclable.
Please dispose of those materials through
your local recycling depot or by placing them
in appropriate collection containers.
• If you wish to discard this air conditioner,
please contact your local authorities and ask
for the correct method of disposal.
•
•
•
•
•
•
Caution
The air conditioner is not intended for use by
young children or infirmed persons without
supervision.
Young children should be supervised to
ensure that they do not play with the air
conditioner.
Contact an authorised installer for installation
of this air conditioner.
Contact an authorised service technician for
repair or maintenance of this unit.
If the power cord is to be replaced,
replacement work shall be performed by
authorised personnel only.
Installation work must be performed
in accordance with the national wiring
Standards by authorised personnel only.
Conditions of Use
This appliance is intended to be used in
household and similar applications such as:
• Staff kitchen areas in shops, offices and
other working environments.
• Farm houses.
• By clients in hotels, motels, and other
residential type environments.
• Bed and breakfast type environments.
Important Notes
Contact an authorised installer for installation of
this unit.
Contact an authorised service technician for
repair or maintenance of this unit.
• The socket outlet required to supply power
must be connected and commissioned by a
licenced contractor.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Young children should be supervised to
ensure that they do not play with the air
conditioner.
• If the power cord is to be replaced,
replacement work shall be performed by
authorised personnel only.
• Installation work must be performed
in accordance with the national wiring
standards and the electricity suppliers
service rules by authorised personnel only.
• If the unit is to be moved to another location
or disposed of, only a suitably qualified
person is permitted to undertake such work.
• Take care not to catch fingers on the fan
blade when adjusting vertical louvres.
• This air conditioner uses R410A refrigerant
(Confirm before installation).
4 www.electroluxaircomfort.com
SAFETY PRECAUTIONS
Inside this manual you will find many helpful
hints on how to use and maintain your air
conditioner properly.
Just a little preventive care on your part can
save you a great deal of time and money over
the life of your air conditioner. You’ll find many
answers to common problems in the chart
of troubleshooting tips on page 20-21. If you
review the chart of troubleshooting tips first, you
may not need to call for service.
Meanings of symbols used in this manual are
shown below:
This indicates information concerning
your personal safety and how to avoid
damaging the appliance.
This symbol indicates tips and information
about use of the appliance.
This symbol indicates tips and information
about economical and ecological use of
the appliance.
This symbol indicates never to do this.
Do not damage or cut off the power cord
or other wires. If this occurs, please have
it repaired or replaced by an accredited
technician
Do not connect this air conditioner to a
multi- outlet power boards.
Please switch off the power supply to
the air conditioner if it is not to be used
for an extended period. Otherwise, it will
accumulate dust and may cause a fire.
Before cleaning the air conditioner, please
disconnect the power supply in order to
eliminate the possibility of electric shock.
The power supply should be matched
with the air conditioner according to
the installation manual. Air conditioners
provided with a supply cord should be
connected directly to a power outlet with a
suitable safety switch.
Air conditioners that are hard wired must
be connected to a suitable safety circuit
breaker according to the installation
manual.
Always do this.
Important Notes:
• Do not operate unit with horizontal louvre
inclosed position.
• Do not operate unit without the air filter.16
Drain connector
Warning
If you notice an unusual situation, such
as a burning smell, please switch off the
power to the air conditioner and contact an
authorised service agent. If this abnormal
status continues the air conditioner may be
damaged or even cause electric shock or
fire.
Do not operate the air conditioner with wet
hands. This may cause electric shock.
Please ensure that the power supply to
the air conditioner is stable and meets
the requirements set out in the installation
manual.
Always ensure the product is installed with
appropriate earthing/grounding.
For safety, be sure to turn off the
circuit breaker before performing any
maintenance or cleaning or when the
product is not used for an extended period
of time. Accumulated dust may cause fire
or electric shock.
www.electroluxaircomfort.com 5
SAFETY PRECAUTIONS
Caution
Select the most appropriate temperature.
It can save electricity.
Usage
•
Do not keep windows and doors open for •
a long time during operation. It will result in
insufficient performance.
Exposure to direct airflow from the air
conditioner for an extended period of time
could be hazardous to your health.
Do not expose people, pets or plants to the
direct airflow for an extended period.
Cleaning and Maintenance
Do not block the air inlet or outlet. It will
result in insufficient performance and
cause malfunctions.
1. When cleaning the unit, first make sure that
the power and circuit breaker are turned off.
2. Do not touch the metal parts of the unit
Keep combustible materials away from the
when removing the filters. Injuries can occur
units at least 1m. It may cause fire.
when handling sharp metal edges.
3. Do not use water to clean inside the air
Do not step on the top of the outdoor unit
conditioner. Exposure to water may lead to
or place heavy things on it. It may cause
possible electric shock.
damage or injury.
Service
Do not attempt to repair the air conditioner
by yourself. Incorrect repairs may cause
For repair and maintenance, contact your
electric shock or fire. Please contact your
authorised service dealer.
local authorised service centre.
Do not insert your hands or objects into
the air inlet or outlet. It may cause injury.
Do not expose animals or plants directly to
the air flow.
Do not use the unit for any other purpose,
such as preserving food or drying clothes.
Do not splash water on the air conditioner.
It may cause electric shock or malfunction.
Prior to Operation
1. Contact an installation qualified for
installation.
2. Plug in the power plug properly.
3. Do not use a damaged or non-standard
power cord.
4. Do not share the same outlet with other
appliances.
5. Do not use an extension cord.
6. Do not start/stop operation by plugging /
unplugging the power cord.
6 www.electroluxaircomfort.com
PRODUCT DESCRIPTION
1.
2.
3.
4.
Display indicator
Mounting plate
Front panel
Healthy air filter (behind the
dust filter)
5. Dust filter
6. Horizontal air louvre
7. Vertical air louvre (Behind
the horizontal air louvre)
8. Manual control button
9. Cold plasma generator
10. Plasma dust collector
11. Remote control
12. Remote control holder
13. Power cable
14. Wall pipe
15. Binding tape
16. Refrigerant pipe
17. Drain hose
18. Connecting cable
19. Drain connector
Note
The above drawings are for explanation purpose only. Your air conditioner may be slightly different.
The actual shape shall prevail.
www.electroluxaircomfort.com 7
INDOOR UNIT DISPLAY
1. HEAT operation indicator - It lights when the
operation mode is HEAT.
2. COOL operation indicator - It lights when the
operation mode is COOL.
3. Temperature indicator - Displays the
temperature settings when the air conditioner
is in operation.
•
4. Power ON/OFF indicator - It lights when the
unit connected with power supply.
5. DEHUMIDIFY operation indicator - It lights
•
when the operation mode is DEHUMIDIFY.
•
REMOTE CONTROL
How to use the Remote Control
•
Point the remote control to the signal
receiver of indoor unit.
• When the remote control sends out a signal,
the symbol will blink for about 1 second on
the display of the remote control. The indoor
unit will acknowledge the signal with a beep
when it receives an effective signal.
• Make sure there is no obstacle that may
interfere with the signal.
Location of the remote control
•
Keep the remote control where its signal
can reach the receiver of the indoor unit (a
maximum distance of 8m is allowed).
• When you select the timer operation, the
remote control automatically transmits a
signal to the indoor unit at the specified time.
• If you keep the remote control in a position
that hinders proper signal transmission, a
time lag of up to 15 minutes may occur.
•
Caution
The air conditioner will not operate if curtains,
doors or other materials block the signals
from the remote control to the indoor unit.
Prevent any liquid from falling into the remote
control. Do not expose the remote control to
direct sunlight or heat.
If the infrared signal receiver on the indoor
unit is exposed to direct sunlight, the air
conditioner may not function properly. Use
curtains to prevent the sunlight from falling
on the receiver.
If other electrical appliances react to the
remote control, either move these appliances
or consult your local dealer.
Reminder
When I FEEL operation is activated, the remote
control sends the temperature information at
its location to the indoor unit every ten (10)
minutes. If the indoor unit does not receive such
temperature information for successive eleven
(11) minutes, the air conditioner will quit I FEEL
operation and revert to normal operation.
8 www.electroluxaircomfort.com
QUICK START GUIDE
the high speed to allow for rapid cooling or
heating.
Special functions
X-FAN
After the unit is turned off the indoor fan will
continue operation for 10 minutes to remove the
moisture of the indoor unit to avoid the growth of
mould and bacteria.
About AUTO run
In this mode the set temperature will not be
displayed on the remote control, and the unit
will automatically judge and select the suitable
operation method to make ambient comfortable.
Remote lock
Press Swing-V and ION-Filter buttons
simultaneously to lock or unlock the keyboard. If
the remote control is locked, the
icon will be
displayed on it, in which case, press any button,
the mark will flicker three times. If the keyboard
is unlocked, the mark will disappear.
Switch between Centigrade and Fahrenheit
With the air conditioner switched off, press the
Swing-H and ION-Filter buttons simultaneously
to switch between °C and °F.
1. ON/OFF Button - Press this button to turn
the air conditioner ON or OFF.
2. Mode Button - Press this button to select
the desired operation mode, AUTO, COOL,
DEHUMIDIFY, FAN, and HEAT.
3. Control Button:
and
- Press these two
buttons to set the desired temperature.
4. Fan Button - Press this button to set the fan
speed at Auto, Low, Medium-low, Medium,
Medium -high, and High.
5. Swing -V and Swing -H Buttons - The swing
buttons will allow you to select horizontal (H)
or vertical (V) swing of the air guiding louvres.
6. Sleep Button - Pressing this button to select
sleep mode.
7. Timer On/Timer Off Buttons - Press to set
automatic start and stop of the conditioner.
8. Light Button - Press to switch the indicating
lights of the indoor unit on or off.
9. Turbo Button - Press to put the fan into
Energy saving
In COOL mode, press ION-Filter and Clock
buttons simultaneously to start or stop energy
saving function. The remote control display will
show “SE” in temperature display area when it is
active.
Low heat mode
In HEAT mode, pressing ION-Filter and
Clock buttons simultaneously will put the air
conditioner into a low heat mode that will
operate to a temperature of 8°C. Repeat the
operation to quit.
www.electroluxaircomfort.com 9
3. Control Button: Forward - Press the
button to increase the temperature setting.
Holding this button down for 2 seconds and
more will increase the temperature setting
more quickly. Maximum setting is 30°C. In
Timer On/Off or Clock functions, use this
button to set the clock or timer adjustment.
4. Control Button: Backward - Press the
button to decrease the temperature setting.
Holding this button down for 2 seconds and
more will decrease the temperature setting
more quickly. Maximum setting is 16°C. In
Timer On/Off or Clock functions, use this
button to set the clock or timer adjustment.
5. Fan Button - By pressing this button, Auto,
Low, Medium-low, Medium, Mediumhigh, and High speed can be progressively
selected. When the unit is turned on, Auto
fan speed is the default. In DEHUMIDIFY
mode, the fan speed is fixed at Low speed.
6. Turbo Button - Press this button in COOL
or HEAT mode to put the fan into the high
speed Turbo mode and the air conditioner
will work at maximum power. The Turbo
1. ON/OFF Button - Press this button to turn
symbol will be displayed on the remote
the air conditioner ON or OFF. Sleep function
control. Turbo function will be cancelled if
will be cancelled while the unit is switched
the Turbo button is pressed again, or if the
off.
mode or fan speed is changed.
2. Mode Button - By pressing this button,
7. Swing-V Button - Press this button, the
AUTO, COOL, DEHUMIDIFY, FAN, and HEAT
horizontal louvre will swing up and down
(COOL only model has no HEAT feature)
automatically, and will be displayed on the
mode can be selected progressively. AUTO
remote control. Press again to cancel it and
mode is default while power on. Under
the louvre will stay at its last position.
AUTO mode, the temperature will not be
8. Swing-H Button - Press this button,
displayed; Under HEAT mode, the initial
the vertical louvre will swing left to right
value is 28°C; Under other modes, the initial
automatically, and will be displayed on the
value is 25°C.
remote control. Press again to cancel it and
10 www.electroluxaircomfort.com
the louvre will stay at its last position.
9. Quiet Button - Press this button the indoor
fan operates at ultra-low speed, the indoor
noise is low.
symbol will be displayed on •
the remote control once the Quiet function is
activated. Quiet function and Turbo function
can not be activated at the same time. Quiet
function will be cancelled if the Quiet button
is pressed again, or if the mode or fan speed
is changed.
10. Sleep Button - Pressing this button to select •
sleep mode , sleep mode , sleep
mode
and cancel the Sleep mode.
•
Sleep mode
In COOL or DEHUMIDIFY mode, the set
temperature will increase 1°C after an hour,
and increase another 1°C after 2 hours, then
continue to run at this setting.
In HEAT mode, the set temperature will
decrease 1°C after an hour, and decrease
another 1°C after 2 hours, then continue to run
at this setting.
after 7 hours, the temperature will be
decreased a further 1°C, after that the unit
will keep running at this temperature;
When setting the initial temperature between
24-27°C, after turning on the Sleep function,
the temperature will increase 1°C every hour,
after 2°C the temperature will be maintained,
after 7 hours, the temperature will be
decreased a further 1°C, after that the unit
will keep running at this temperature;
When setting the initial temperature between
28-29°C, after turning on the Sleep function,
the temperature will increase 1°C in the first
hour, after 7 hours, the temperature will be
decreased a further 1°C, after that the unit
will keep running at this temperature;
When setting the initial temperature to
30°C, after 7 hours the temperature will be
decreased 1°C, after that the unit will keep
running at this temperature.
In COOL or DEHUMIDIFY mode
• When the initial temperature is 16°C, the air
conditioner will continue to run at this setting;
• When the initial temperature is set between
17-20°C, the set temperature will decrease
1°C after the first hour and continue to run at
this setting;
• When the initial temperature is set between
21-27°C, the set temperature will decrease
1°C in every hour, after two hours the air
conditioner will continue to run at this setting;
• When the initial temperature is set between
28-30°C, the set temperature will decrease
1°C in every hour, after three hours the air
conditioner will continue to run at this setting
Sleep mode
In this mode the sleep temperature curve is
manually set.
Sleep mode
In this mode, the air conditioner will run
according to a preset sleep temperature curve.
In COOL mode
• When setting the initial temperature between
16-23°C, after turning on the Sleep function,
the temperature will increase 1°C every hour,
after 3°C the temperature will be maintained,
1. After selecting Sleep mode , press and
hold the Turbo button until the remote
control enters into user defined sleep setting
status. The remote control will display “1”
hour, temperature display will show the
corresponding temperature of last setting
sleep curve and blink (the original factory
setting will display for the first use.)
2. Adjust the control buttons and to change the
set temperature for the first hour of sleep.
After setting the temperature, press the
Turbo button for confirmation
www.electroluxaircomfort.com 11
3. The hour of sleep mode will be automatically
increased on the remote control, to the 2nd,
3rd hour of sleep mode and so on with each
press of the Turbo button;
4. Repeat the above step (2)-(3) operation
until 8 hours of sleep temperature setting is
finished. The remote control will resume the
original timer display and the temperature
display will return to the original setting.
The sleep program can be checked by
selecting sleep mode , pressing and holding
the Turbo button and then repeat pressing
the turbo button to review the sleep program
temperatures without pressing the control
button
or
.
Press this button again to cancel the Timer
On function, and
symbol will disappear.
Confirm the Timer On settings by pressing
Timer On button, or wait for 5 seconds after
selecting the desired time and the
symbol
will display permanently. Default time for
timer on is 8:00AM.
17. Timer Off Button - Press this button to enter
into Time Off setup, in which case the
symbol will blink. The method of setting
is the same as for Time On. Default time for
timer off is 5:00PM.
REMOTE CONTROL DISPLAY
INDICATOR
In this mode, if no button is pressed for 10
seconds, the display will revert to normal
operation.
11. ION-Filter Button - Press this button to turn
on and off the Cold Plasma function and
Plasma Dust Collector function.
symbol
will be displayed on the remote control if
Cold Plasma function and Plasma Dust
Collector function are selected.
12. I Feel Button - Press this button to turn on
the I Feel function and the
symbol will be
displayed on the remote control. The remote
control will send the temperature information
to the indoor unit every ten (10) minutes. The
air conditioner will operate to reach the set
temperature at the location of the remote
control. Press again to cancel this function.
13. X-Fan Button - Press this button in COOL or
DEHUMIDIFY mode to active X-Fan function.
After the unit is turned off the indoor fan will
continue operation at low fan speed for 10
minutes to dry the indoor unit prevent from
bacteria and mildew growing. Press again to
cancel this function.
14. Clock Button - Press this button and the
Clock symbol will blink. You can press
Control buttons and to set the time you
want.
15. Light Button - Press this button to switch the
indicating lights of the indoor unit on or off.
The normal condition at start up is on.
16. Timer On Button - Press the Timer On
button to set the Timer On or start time,
symbol will flash on the display. Press
the control button or to adjust the start time.
1. Transmission Indicator: Displays for 1 second
when the remote control transmits signals to
the indoor unit.
2. Quiet Function Display - Displays when Quiet
function is selected.
3. Turbo Function Display - Displays when
Turbo function is selected.
4. Fan Speed Display - Displays the selected
fan speed in the following sequence:
In Auto speed, only
symbol displays.
12 www.electroluxaircomfort.com
5. Mode Display - Displays the current
operation mode in the following sequence:
and press ON/OFF button to turn the unit
on. The default operating mode is AUTO.
Once you select the operating mode with
remote control, the operating conditions will
be saved in the indoor unit’s microcomputer
memory. The next time the air conditioner will
start operating under the same conditions
when you simply push the ON/OFF button of
the remote control.
6. Ion-Filter Function Display - Displayed by
pressing the ION-Filter button. Press the
ION-Filter button again to remove it.
7. Sleep Function Display - Displays the three
Tips and Information
sleep modes in the following sequence when
• In case of energy cut off or product shut
Sleep function is selected by pressing the
down when removing the power cord, or
Sleep button.
even when changing the remote control
batteries the microprocessor will return back
to the AUTO mode.
8. Horizontal Swing Display - Displays when the
Horizontal Swing function is selected.
9. Light Status Display - Displays when the
HOW TO USE THE REMOTE
indicating lights of indoor unit is switched on.
CONTROL
The normal condition at start up is on.
10. X-Fan Function Display - Displays when the
X-Fan function is activated.
Automatic Operation
11. 8°C Heating Indicator - Displays when
ION-Filter and Clock buttons are pressed
When the AUTO mode is selected, the air
simultaneously to enter low heat operation in conditioner will automatically select COOL,
HEAT mode.
HEAT (if applicable), or FAN only operation,
12. Remote Lock Indicator - Displays when the
depending on the programmed and/or the room
remote control is locked.
temperature.
13. Vertical Swing Display - Displays when the
Vertical Swing function is selected.
14. I Feel Function Display - Displays when I Feel
function is activated.
15. Timer On/Off Display symbol will display
when the Timer On function is selected
symbol will display when the Timer Off
function is selected
16. Time Display - Displays the Clock time (must
be set) and/or the on/off time of the timer.
17. Temperature Display - Displays the set
temperature in °C or °F.
FIRST USE
1. Ensure the unit is plugged in and power is
available.
2. Be sure the batteries are inserted correctly in
the remote control (the lights on the remote
control will be on).
3. Set the time by Control buttons and confirm
by pressing the Clock button.
4. Point the remote control to the indoor unit
www.electroluxaircomfort.com 13
Start
1. ON/OFF Button - Press this button to turn
the air conditioner on. The temperature
indicator on the indoor unit display lights on.
2. Mode Button - Press to select AUTO.
Stop
1. ON/OFF Button - Press this button again to
turn the air conditioner off. The horizontal
louvre returns back to the position upon shut
down.
If the AUTO mode is uncomfortable, you can
select the desired conditions manually.
Tips and Information
• In AUTO mode the temperature can not be
set.
Dehumidifying Operation
The DEHUMIDIFY mode works based on the
difference between the set temperature and the
actual room temperature.
The temperature is regulated while
dehumidifying through repeatedly turning on/
off of the COOLING operation or FAN only
operation.
Stop
1 ON/OFF Button
Press this button again to turn the air conditioner
off. The horizontal louvre returns back to the
position upon shut down.
Tips and Information
In DEHUMIDIFY mode the fan speed is fixed
at Low, and Turbo function cannot be used.
• In DEHUMIDIFY mode, Sleep model 2 and
Sleep mode 3 can not be activated.
•
Fan Operation
When you select the FAN operating mode the air
conditioner will just vent the indoor air.
Start
1 ON/OFF Button
Press this button to turn the air conditioner on.
The temperature indicator on the indoor unit
display lights on.
2 Mode Button
Press to select DEHUMIDIFY.
3 Control Buttons
Set the desired temperature.
Normally, set between 21ºC to 28ºC.
Start
1. ON/OFF Button - Press this button to turn
the air conditioner on. The temperature
indicator on the indoor unit display lights on.
2. Mode Button - Press to select FAN.
3. Fan Button - Press to select the desired fan
speed at: Auto, Low, Medium and High. The
default fan speed is Auto.
14 www.electroluxaircomfort.com
Stop
1. ON/OFF Button - Press this button again to
turn the air conditioner off. The horizontal
louvre returns back to the position upon shut
down.
Stop
1. ON/OFF Button - Press this button again to
turn the air conditioner off. The horizontal
louvre returns back to the position upon shut
down.
Tips and Information
• The temperature can not be set through the
remote control in FAN operating mode.
• No fan speed indication displays on the
remote control if Auto fan speed is selected.
Tips and Information
• No fan speed indication displays on the
remote control if Auto fan speed is selected.
Timer Settings
Cooling and Heating Operation
Start
1. ON/OFF Button - Press this button to turn
the air conditioner on. The temperature
indicator on the indoor unit display lights on.
2. Mode Button - Press to select COOL or
HEAT (for Heat Pump model only) mode.
3. Control Buttons - Set the desired
temperature. Normally, set between 21ºC to
28ºC.
4. Fan Button - Press to select the desired fan
speed at: Auto, Low, Medium-low, Medium,
Medium high and High. The default fan
speed is Auto.
5. Swing-V and Swing-H Buttons - Press to
select the airflow direction.
Timer On Operation
1. Press the Timer-On button,
will
flash on the display of the remote control in
case of the first use of Timer-On operation.
Otherwise, the last set time will flash.
2. Set the desired time by pressing the Control
buttons:
Forward
Backward. Each
time you press the buttons, the time will
moves forward or backward by 1 minute.
Holding the button down will scroll more
rapidly through the time display.
3. Point the remote control to the indoor unit,
confirm the set time by pressing the TimerOn button.
symbol will stay on the
remote control’s display.
www.electroluxaircomfort.com 15
Cancelling the Settings
Point the remote control to the indoor unit and
press again the Timer-On button. Make sure the
symbol
on the remote control is turned off.
Timer Off Operation
1. Press the Timer-Off button,
(for the
first use) or the previous set time will flash on
the display of the remote control.
2. Set the desired time by pressing the Control
buttons: Forward
Backward. Each
time you press the buttons, the time will
moves forward or backward by 1 minute.
Holding the button down will scroll more
rapidly through the time display.
3. Point the remote control to the indoor unit,
confirm the set time by pressing the TimerOff button.
symbol will stay on the
remote control’s display.
Cancelling the Settings
Point the remote control to the indoor unit and
press again the Timer-Off button. Make sure the
symbol
on the remote control is turned off.
Tips and Information
The working time of the timer function set
by the remote control depends on the Clock
time. Check that the Clock on the remote
control is set correctly in order to prevent
malfunctioning.
• The effective operation time set by the
remote control is limited in 24 hours
•
Examples of Timer Settings
Timer On Operation (Timer Start Operation)
This function is recommended when you
want the unit to be turned on automatically
before returning home. The air conditioner will
automatically start operating at the set time.
Example: It is 8:00 AM and you want the air
conditioner to start working at 6:00 PM.
1. Press the Timer-On button.
2. Set the desired time by pressing repeatedly
or holding down the Control buttons until
6:00PM shows in the display of the remote
control.
3. Confirm the set time by pointing the remote
control to the indoor unit and pressing again
the Timer On button.
symbol will stay
on the remote control’s display.
Timer Off Operation (Timer Stop Operation)
This function is recommended when you want
the unit to be turned off automatically for bed
time. The air conditioner will automatically stop
operating at the set time.
Example: It is 6:00 PM and you want the Air
Conditioner to turn off at 11:55 FM.
1. Press the Timer-Off button.
2. Set the desired time by pressing repeatedly
or holding down the Control buttons until
11:55PM shows in the display of the remote
control.
3. Confirm the set time by pointing the remote
control to the indoor unit and pressing again
the Timer Off button.
symbol will stay
on the remote control’s display.
Combined Timer
Timer On
Timer Off (Off-Start-Stop
operation)
This function is recommended when you want
to turn the air conditioner on before waking up
and turn it off after leaving the house.
Example: It is 10:00 PM and you want to
start the air conditioner at 6:30 AM and
stop it at 9:30 AM.
1. Press the Timer On button.
2. Set the desired time by pressing repeatedly
or holding down the Control buttons until
6:30AM shows in the display of the remote
control.
16 www.electroluxaircomfort.com
3. Confirm the set time by pointing the remote
control to the indoor unit and pressing again
the Timer On button.
4. Press the Timer Off button.
5. Set the desired time by pressing repeatedly
or holding down the Control buttons until
9:30AM shows in the display of the remote
control.
function is activated.
Setting the Clock
6. Confirm the set time by pointing the remote
control to the indoor unit and pressing
again the Timer Off button.
symbol is
displayed on the remote control and the
function is activated.
Timer Off
Timer On (On-Stop-Start
operation)
This function is recommended when you want
to turn the air conditioner off after going to
bed and start it again before waking up in the
morning or returning back home.
Example: It is 8:00 AM and you want to stop
the air conditioner at 9:30AM and restart at
6:00PM
1. Press the Timer Off button.
2. Set the desired time by pressing repeatedly
or holding down the Control buttons until
9:30AM shows in the display of the remote
control.
Timer On Operation (Timer Start Operation)
Before you start operating the air conditioner,
set the clock of the remote control using the
procedure given in this section. The clock panel
on the remote control will display the time
regardless of whether the air conditioner is in
operation or not.
After batteries are inserted in the remote control,
will display and begin to flash.
3. Confirm the set time by pointing the remote
control to the indoor unit and pressing again
the Timer-Off button.
4. Press the Timer On button.
5. Set the desired time by pressing repeatedly
or holding down the Control buttons until
6:00PM shows in the display of the remote
control.
6. Confirm the set time by pointing the remote
control to the indoor unit and pressing
again the Timer On button.
symbol
is displayed on the remote control and the
1. Control Buttons - Press the Control
buttons to set the desired time. Forward
Backward. Each time you press the
buttons the time will moves forward or
backward by 1 minute. Holding the button
down will scroll more rapidly through the time
display.
2. Clock Button - When the desired time is
achieved, press the Clock button again or
after 5 seconds with no operation, the clock
time stops flashing and the clock is set.
3. Re-set the Clock Press the Clock button
and the clock symbol will start to flash.
Follow step 1 and 2 to set the new time.
www.electroluxaircomfort.com 17
Tips and Information
• The clock timer uses a 12 hour clock mode.
• The default time for remote control is
12:00PM and it will revert to this when the
batteries are changed.
Tips and Information
• The default setting for remote control is ON
when the remote control is turned on.
• It is not necessary to use this function when
the room air quality is good.
• Clean the Plasma dust Collector every three
to six months depending on the condition.
I Feel Operation
The remote control works as a remote
thermostat, providing an accurate temperature
control and maximum comfort.
HOW TO USE THE INDOOR
UNIT
Point the remote control to the indoor unit and
press I Feel button, a beep from the indoor
unit is to confirm that this function is activated.
The I Feel symbol will stay on the display of the
remote control until I Feel button is pressed
again.
Additional Options
Press the ION-Filter button to active the Cold
Plasma and Plasma Dust Collector functions.
The
symbol will stay on the display of the
remote control until the ION-Filter button is
pressed again.
Both horizontal louvre and vertical louvre can be
adjusted with the remote control.
1. Smart Restart Function - The air conditioner
resumes automatically with the previous
settings after a possible power failure.
2. Removable Panel - The front panel of indoor
unit can be easily removed for cleaning and
The air conditioner will operate to reach the
maintenance.
set temperature at the location of the remote
3. Self Diagnose and Auto Protection - This
control.
air conditioner can detect the malfunctions,
showing the diagnosis on the display of
The remote control sends the temperature
the indoor unit by means of an error code.
information at its location to the indoor unit every
The air conditioner will change operation
ten (10) minutes. The air conditioner will quit I
automatically for self-protection.
FEEL operation and revert to normal operation
if no temperature information is received from
the remote control for successive eleven (11)
Airflow Direction Control
minutes.
Adjust the airflow direction properly, otherwise,
it might cause discomfort or uneven room
ION-Filter Operation
temperatures.
The Cold Plasma generator releases plasma
which can help to eliminate bacteria, viruses,
dusts and other harmful agents in the air.
The Plasma Dust Collector can trap various fine
particulate matter such as dust, smoke and
pollen from the air stream so as to keep the
room air clean.
This function is recommended when the indoor
air quality is poor.
To set the vertical (up/down) airflow
direction automatically
1. Perform this function while the unit is in
operation.
2. Press the Swing-V button on the remote
control, the horizontal louvre will swing up
and down automatically.
3. When the louvre moves to the desired
direction, press the Swing-V button again and
the louvre will stay at where it is.
18 www.electroluxaircomfort.com
3. When the louvre moves to the desired
direction, press the Swing button again and
the louvre will stay at where it is.
4. Press the Swing button again and the louvre
will start swing up and down automatically.
4. Press the Swing-V button again and the
louvre will start swinging up and down
automatically.
•
To set the vertical (up/down) airflow
direction automatically
1. Perform this function while the unit is in
operation.
2. Press the Swing-H button on the remote
control, the vertical louvre will swing left and
right automatically.
•
•
•
•
•
Caution
The Swing-V and Swing-H buttons will be
disabled when the air conditioner is not in
operation (even if the Timer On is set).
Do not operate the air conditioner for long
time with the airflow direction set downward
in COOL or DEHUMIDIFY mode. Otherwise,
condensate may occur on the surface of the
horizontal louvre and drop onto the floor or
furnishings.
Do not move the horizontal louvre and
vertical louvre manually. Always use the
Swing-V and Swing-H buttons. Moving the
louvres manually may cause malfunction
during operation. If the louvre malfunctions,
stop the air conditioner and restart it.
Open angle of the horizontal louvre should
not be set too small, as cooling or heating
performance may be impaired due to too
restricted airflow area.
Do not operate the air conditioner with
horizontal louvre in closed position.
When the air conditioner is connected to
power (initial operation), the horizontal louvre
may generate a sound for 10 seconds, this is
a normal operation.
www.electroluxaircomfort.com 19
EMERGENCY OPERATION
OPERATING TEMPERATURE
When the remote control is lost or fails to
operate, please use the manual switch on the
indoor unit. The air conditioner will operate in
AUTO mode and the temperature setting or fan
speed can not be changed.
The operation temperature range is as below:
1. Open the front panel.
Indoor Side
DB/WB(°C)
Outdoor Side
DB/WB(°C)
Maximum Cooling
32/23
43/26
Minimum Cooling
21/15
21/–
Maximum Heating
27/–
24/18
Minimum Heating
20/–
-5/-6
The operation temperature range (outdoor
temperature) for cooling only model is
16ºC~48ºC, for heat pump model is
-15ºC~48ºC. If the air conditioner is used
outside of the above conditions, certain safety
2. Press the Manual Control button to enter
protection features may come into operation
AUTO mode. The air conditioner will select
the mode of COOL, HEAT (heat pump model and cause the unit to function abnormally.
only) and FAN automatically according to
the room temperature for reaching the best
comfort.
OPTIMAL OPERATION
3. Press the Manual Control button again to
turn the air conditioner off. The operation
mode is seen in the following table.
Mode
Model
Temperature setting
Fan Speed
AUTO
Cooling
25°C (COOL, FAN)
AUTO
AUTO
Heat
pump
25°C (COOL, FAN)
AUTO
AUTO
Heat
pump
20°C (HEAT)
AUTO
To achieve optimal performance, please note:
• Adjust the airflow direction correctly so that it
is not directed on people.
• Adjust the temperature to achieve the
highest comfort level. Do not adjust the unit
to excessive temperature levels.
• Close doors and windows in the operation
of COOL or HEAT mode, otherwise, product
performance will be impaired.
• Use the Timer On and Timer Off buttons on
the remote control to select the desired time
for startup and shut-down.
• Do not place any object close to the air inlets
or outlets, as the product efficiency may be
reduced and the air conditioner may stop
running.
• Clean the air filters frequently, otherwise
cooling or heating performance may be
reduced.
20 www.electroluxaircomfort.com
CLEANING AND
MAINTENANCE
Items
Maintenance
operations
Recommended
frequency
Dust filter
Clean
Every month or more
often if necessary
Battery Installation/Replacement
Plasma dust
collector
Clean
Every 3 months
or more often if
necessary
Healthy air
filters
Replace or
clean
Every 3 months
or more often if
necessary
Unit casing
Clean
Every month or more
often if necessary
1. Push the back cover of the remote control.
2. Take out the old batteries.
3. Insert two new AAA1.5V dry batteries, and
pay attention to the polarity.
4. Attach the back cover of the remote control.
Water tray and Clean and
evacuation
check for
piping
obstructions
Each season before
start up*
Indoor and
outdoor coils
Each season before
start up*
Clean
* The operation must be performed by qualified
personnel only.
•
Warning
Stop the air conditioner and disconnect the
power supply before cleaning. Otherwise, it
may cause electric shock or fire.
Indoor Unit and Remote
Control Cleaning
•
•
Tips and Information
When changing batteries, do not use old
or varied ones, otherwise, it may cause
problems with the remote control.
• If the remote control is not used for a long
time, remove the batteries as old batteries
may leak or corrode and damage the remote
control.
• The battery life during normal use is about
six months.
• If the remote control does not operate
normally, please remove and refit the
batteries. If abnormal operation continues,
replace with new batteries..
•
•
•
•
•
•
Use a dry cloth to wipe the indoor unit and
remote control.
A cloth dampened with cold water may be
used on the indoor unit if it is too dirty.
The front panel of the indoor unit cant be
removed and cleaned with water. Then wipe
with a dry cloth.
Do not use brushes, emery paper or
burnishes to clean the unit because it may
cause damages.
Do not use a chemically treated cloth or
duster to clean the unit.
Do not use benzine, thinner, polishing
powder or similar solvents for cleaning.
These may cause the plastic surface to crack
or deform.
Never use warm water over 40ºC to clean
the front panel, it may cause deformation or
discolouration.
Maintenance
Cleaning the Filters
The following maintenance operations must be
performed regularly.
Note: Supply power must be disconnected
before cleaning.
www.electroluxaircomfort.com 21
A clogged dust filter reduces the cooling/heating
efficiency of this unit. Please clean the filter every
month or more often if necessary.
1. Lift the indoor unit front panel up to an angle
until it stops with a full support from the
frame.
6. Install the healthy air freshening filters back in
position.
2. Then pull the dust filter downwards out of
the indoor unit.
7. Install the upper portion of dust filers back
into the unit, taking care that the left and right
edges line up correctly and place dust filters
into position.
3. Hold the dust filter handle and lift it up slightly
to take it out from the filter holder.
Cleaning the Plasma Dust Collector
4. Clean the Dust filter with a vacuum cleaner
or water, then dry it up in cool place.
•
Warning
Stop the air conditioner and disconnect the
power supply for at least 60 seconds before
cleaning. Otherwise, it may cause electric
shock or fire.
1. Pull the Dust filters out of the indoor unit.
5. The healthy air freshening filters (if applicable)
like Active carbon filter / BIO filter / Vitamin C
filter / HEPA filter, Silver ion filter are fixed on
the support frame of the dust filter. Remove
the healthy filters from the support frame
of the dust filter. Clean the healthy filters
2. Hold the dust filter handle and lift it up slightly
at least every three (3) months and replace
to take it out from the filter holder.
every 6 months. Clean with vacuum cleaner
if possible.
22 www.electroluxaircomfort.com
before install it back to the indoor unit to
avoid electricity leakage.
Cleaning the Cold Plasma Generator
Do not touch or try to clean the Cold Plasma
Generator by yourself, and it may cause electric
shock.
Please contact qualified personnel or Electrolux
service centre for clean or replacement if
necessary.
3. Carefully lift the dust box up, then pull it out
of the frame of the Dust Collector.
General Maintenance
4. Put the dust box into the warm water with
a small amount of neutral detergent for ten
minutes or longer, then clean it with a soft
brush. Rinse with clean water after make
sure the box is clean, dry it completely, then
install back to the frame of dust collector.
5. Make sure the dust box is correctly fixed into
the frame and the two clips of dust box are
securely fixed in place.
6. Put the filters back and install the front panel.
•
•
•
•
•
•
If the air conditioner is not going to be used for a
long period of time:
• Operate in FAN only mode for 1~2 hours to
allow the unit to completely dry out.
• Switch off the unit and pull out the power
plug. Remove the batteries from the remote
control.
• The outdoor unit requires periodic
maintenance and cleaning. Do not attempt
to do this yourself. Contact your dealer or
service technician.
Checks before operation
• Check that the wiring is not broken or
disconnected
• Check that the dust filter is installed.
• Check if the air outlet or inlet is blocked if the
air conditioner has not been used for a long
time
Warning
When cleaning the unit, firstly make sure that •
the power and circuit breaker are turned off
for at least 60 seconds.
Do not use high pressure air to blow plasma •
dust collector so as to avoid accidental injury
and damage to the eyes and the collector.
Do not expose the collector directly under
the sunshine or put it close to the fire, which •
may cause deformation and damage.
Be careful not to break the tungsten filament
during the operation, and avoid vigorously
scrubbing the dust collector.
Do not use strong corrosive detergents to
clean the dust collector.
Ensure the dust collector is completely dried
Warning
Do not touch the metal parts of the unit
when removing the filter. Injuries can occur
when handling sharp metal edges.
Do not use water to clean inside the air
conditioner. Exposure to water can destroy
the insulation, leading to possible electric
shock.
When cleaning the unit, first make sure that
the power and circuit breaker are turned off.
www.electroluxaircomfort.com 23
OPERATION TIPS
The following events may occur during normal
operation:
Protection of the air conditioner.
• Compressor protection - The compressor
can’t restart for 3 minutes after it stops
• Anti-freezing - If the unit is operating
in COOL mode and in low ambient
temperature, frost may be formed on
the heat exchanger. When indoor heat
exchanger temperature decreases below
0ºC, the compressor will stop operation to
protect the unit.
• Defrosting - Frost may form on the outdoor
unit in heating operation when the outdoor
temperature is low but humidity is high,
resulting in low heating efficiency. During this
condition the air conditioner will stop heating
operation and start defrosting automatically.
The time to defrost may vary from 3 to 12
minutes. During defrosting, the fan motors
of indoor unit and outdoor unit will stop,
the indoor indicator flashes “H1” and the
outdoor unit may emit vapour. This is not
malfunction. After defrosting is finished, the
heating operation will recover automatically.
• Anti-cold air - In HEAT mode, the indoor fan
will not operate in order to prevent cold air
being blown into the room (within 5 minutes),
if the indoor heat exchanger does not reach
a minimum temperature under the following
states:
1. Heating operation just start.
2. After auto defrosting is just finished.
3. Heating at low temperature.
A white mist coming out from the indoor
unit
• A white mist may generate due to a large
temperature difference between air inlet
and air outlet in COOL mode in an indoor
environment that has a high relative humidity.
• A white mist may generate due to moisture
generated from defrosting process when
the air conditioner restarts in HEAT mode
operation after defrosting.
Low noise of the air conditioner
• You may hear a low hissing sound when
the compressor is running or has just stop
running. This is the sound of the refrigerant
flowing or coming to a stop.
• You also may hear a low “squeak” sound
when the compressor is running or just
stopped running. This is caused by heat
expansion and cold contraction of the plastic
parts in the unit when the temperature is
changing.
• A noise may be heard due to louvre restoring
to its original position when power is first
turned on.
Dust is blown out from the indoor unit
This is a normal condition when the air
conditioner has not been used for a long time or
during first use of the unit.
A peculiar smell comes out from the indoor
unit
This is caused by the indoor unit giving off
Gentle breeze
The indoor unit may still run to blow out the rest smells permeated from building material,
heat of the indoor unit in the following situations: furniture or smoke.
1. In HEAT mode, the temperature reaches the
setting value, the compressor stops and the The air conditioner turns to FAN only mode
from COOL or HEAT mode
indoor fan still runs for 60 seconds.
When the indoor temperature reaches the
2. In HEAT mode, the unit is turned off, the
setting value, the compressor will stop
compressor stops and the indoor fan still
automatically, and the air conditioner turns to
runs for 10 seconds.
FAN mode.
The compressor will start again when the indoor
temperature rises in COOL mode or falls in
HEAT mode to the set point.
24 www.electroluxaircomfort.com
Condensation
Condensate water is likely to form at the air
outlet if cooling or drying for a long time when
the relative humidity is more than 80% (with
doors and windows open).
Set the vertical louvre to its maximum angle (to
the floor) and High fan speed. Close the doors
and windows.
Lighting or a car wireless telephone
operating nearby may cause the unit to
malfunction.
Disconnect the unit with power and then reconnect the unit with power again. Push ON/
OFF button on the remote control to restart
operation.
X-Fan function
The indoor unit may keep running after you
switch off the unit by pressing ON/OFF button.
Please check whether the X-Fan function is
switched off.
www.electroluxaircomfort.com 25
TROUBLESHOOTING
The air conditioner is not user serviceable. Incorrect repair may cause electric shock or fire.
Please contact an authorised service centre for professional repair.
Warning
If one of the following situations occur, immediately stop the air conditioner, disconnect the power,
and contact the authorised service centre.
•
•
•
•
•
•
•
•
•
If error code appear on the display window of indoor unit.
Power indicator or other indicator flash rapidly and this flashing can not be stopped by
disconnecting the power and then connecting it again.
Fuse blows frequently or circuit breaker often trips.
Water or other liquid is splashed into the unit.
Water is leaking from the unit.
There is a harsh sound during operation.
Strong odours are emitted during operation.
Power cord and power plug are overheating.
Other abnormal situations.
The pressure in the refrigeration system is low and could result in the unit breaking down. Ask a
certified installer to control it.
Malfunctions
Cause
What should be done
The unit does not start
Power failure
Wait for power to be restored.
The unit may have become
unplugged.
Check that plug is securely in wall
receptacle.
Fuse may have blown.
Replace the fuse.
Voltage is too high or too low.
Test the voltage by professionals.
Batteries in remote control may have
been exhausted.
Replace the batteries.
The time you have set with timer is
incorrect.
Wait or cancel timer setting.
Inappropriate temperature setting.
Set the temperature correctly. For
details please refer to “Using Remote
Control” section
Air filter is blocked.
Clean the air filter.
Doors or windows are open.
Close the doors or windows.
Air inlet or outlet of indoor or outdoor
unit has been blocked.
Clear the obstructions away first,
then restart the unit.
Compressor 3 minutes protection
has been activated.
Wait for 3 minutes.
The unit does not cool or heat (if
applicable) the room very well while
air flows out from the air conditioner
If the trouble has not been corrected, please contact a local dealer or the nearest customer service centre.
Be sure to inform them of the detailed malfunctions and unit model.
26 www.electroluxaircomfort.com
The following checks prior to contact may save you time and money.
Malfunctions
Cause
The unit does not operate
The unit does not operate if it is turned on immediately after it is turned off. This is
to protect the unit. Please wait about 3 minutes.
Odours are emitted
•
•
Some odours may be emitted from the indoor unit. This is the result of room
smells (such as furniture, tobacco, etc.) which have been taken into the unit.
Consult authorised service centre for cleaning if the odours persist.
“Water flowing” noise
The swishing noise like water flowing is the refrigerant flowing inside the unit.
Mist is emitted in COOL mode
During cooling operation, a thin mist may be seen emitted from the indoor unit
due to high room temperature and humidity. After a period of time, the mist will
disappear as the decrease of room temperature and humidity.
Cracking noise
This is the sound of friction caused by expansion and/or contraction of panel or
other parts due to the change of temperature.
The unit can not be started up
•
•
•
•
•
•
Is the power cut off?
Is the power plug loose? (if applicable)
Is the circuit protection device tripped off?
Is voltage higher or lower? (tested by professionals)
Is the TIMER correctly used?
Are the batteries exhausted?
Cooling /Heating effect is poor
•
•
•
•
•
•
Is the temperature setting appropriate?
Is the air inlet/outlet blocked?
Is the filter dirty?
Is the door or window open?
Is low fan speed set?
Are there heat sources in the room?
Water leakage of indoor unit
•
•
•
The humidity is high.
Condensing water overflows.
Drain hose is loose or obstructed.
Water leakage of outdoor unit
•
During cooling operation, water condensates around the pipes and
connection joints.
During defrosting operation, thawed water flows out.
During heating operation, water on the heat exchanger drips out.
•
•
Noise from indoor unit
•
•
The noise emitted when the fan or compressor relay is switched on or off.
When the defrosting operation is started or stopped, there is a sound of
refrigerant flowing in the reverse direction.
Indoor unit can not blow air
•
In HEAT mode, when the temperature of indoor heat exchanger is very low,
airflow is stopped in order to prevent cold air. (within 2 minutes)
In HEAT mode, when the outdoor temperature is low or humidity is high,
frost will be formed on the outdoor heat exchanger. The unit will defrost
automatically and indoor unit will stop blowing air for 2-3 minutes.
During defrosting operation, water or vapour may be emitted.
In DEHUMIDIFY mode, the indoor fan will stop blowing air for 3-12 minutes in
order to avoid condensing water being vaporised again.
•
•
•
Moisture on air outlet
If the unit operates at high humidity for a long time, moisture may be generated on
air outlet grill and then drip off.
H1 error code: defrosting
It is normal. The unit is in defrosting operation and heating will recommence soon.
www.electroluxaircomfort.com 27
28 www.electroluxaircomfort.com
Distributed by:
