Instructions
Getting to Know your camera
Use this camera in the following order.
Thank you for buying a Samsung Digital Camera.
Setting up the application
software
Take a picture
Insert the USB cable
To use this camera with a PC,
install the application software
first. After this has been done, the
stored images in the camera can be
moved to the PC and can be edited
by an image editing program.
Take a picture. (p.22)
Insert the supplied USB cable
into the PC’s USB port and the
camera’s USB connection
terminal. (p.108)
Check the camera's power
Check the camera’s power. If the
power is turned off, preset the
camera button to turn it on.
Check [Removable Disk]
Open Windows’s EXPLORER
and search for [Removable Disk].
(p.109)
Downloaded from ManualsCamera.com Manuals
Prior to using this camera, please read the user manual thoroughly.
If you require After Sales service, please bring the camera and the cause of
the camera malfunction (such as battery, Memory card etc.) to the A/S center.
Please check that the camera is operating properly prior to when
you intend to use it (e.g. for a trip or an important event) to avoid
disappointment. Samsung takes no responsibility for any loss or
damage that may result from camera malfunction.
Keep this manual in a safe place.
If you use a card reader to copy the images on the memory card to
your PC, the images could be damaged. When transferring the
images taken with the camera to your PC, be sure to use the
supplied USB cable to connect the camera to your PC. Please note
that the manufacturer holds no responsibility for loss or damage of
images on the memory card due to the use of a card reader.
The contents and illustrations of this manual are subject to change
without prior notice for upgrading the camera functions.
Ä Microsoft, Windows and Windows logo are registered trademarks
of Microsoft Corporation incorporated in the United States and/or
other countries.
Ä Adobe and Reader are either trademarks or registered
trademarks in the United States and/or other countries.
Ä All brand and product names appearing in this manual are
registered trademarks of their respective companies.
Ä For Open Source License information, refer to the “OpenSourceInfo.pdf”
in the provided CD-ROM.
Ä HDMI, the HDMI logo and the term
“High Definition Multimedia Interface”
are trademarks or registered trademarks
of HDMI Licencing LLC.
001
Danger
Warning
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Do not attempt to modify this camera in any way. To do so may
result in fire, injury, electric shock or severe damage to you or your
camera. internal inspection, maintenance and repairs should only
be carried out by your dealer or Samsung Camera Service center.
Please do not use this product in close proximity to flammable or
explosive gases, as this could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do
not use it. Switch off the camera, and then disconnect the power
source. You must contact your dealer or Samsung Camera Service
center. Do not continue to use the camera as this may cause a fire
or electric shock.
Do not insert or drop metallic or inflammable foreign objects into
the camera through access points e.g. the memory card slot and
battery chamber. This may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk
of electric shock.
Do not use the flash in close proximity to people or animals.
Positioning the flash too close to your subject’s eyes may cause
eyesight damage.
For safety reasons keep this product and accessories out of reach
of children or animals to prevent accidents e.g.:
- Swallowing battery or small camera accessories. If an accident
should occur, please consult a doctor immediately.
- There is the possibility of injury from the camera’s moving parts.
Battery and camera may become hot during prolonged use and it
may result in camera malfunction. Should this be the case, allow
the camera to sit idle for a few minutes to allow it time to cool.
Do not leave this camera in places subject to extremely high temperatures, such as a sealed vehicle, direct sunlight or other places
of extremes in temperature. Exposure to extreme
temperatures may adversely affect the camera’s internal
components and could cause a fire.
When in use, do not cover the camera or Charger. This may cause
heat to build up and distort the camera body or cause a fire. Always
use the camera and its accessories in a well-ventilated area.
002
Downloaded from ManualsCamera.com Manuals
Caution
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in a minor or moderate injury.
Leaking, overheating, or damaged battery could result in fire or injury.
- Use battery with the correct specification for the camera.
- Do not short circuit, heat or dispose of battery in fire.
- Do not insert the battery with the polarities reversed.
Remove the battery when not planning to use the camera for a
long period of time. Otherwise the battery may leak corrosive
electrolyte and permanently damage the camera’s components.
Do not fire the flash while it is in contact with hands or objects. Do
not touch the flash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using
the AC adapter. After use, always switch off the camera before
unplugging the cable from the wall socket. Then make sure that
any connector cords or cables to other devices are disconnected
before moving the camera. Failure to do so may damage the cords
or cables and cause a fire or electric shock.
Take care not to touch the lens or lens cover to avoid taking an
unclear image and possibly causing camera malfunction.
Avoid obstructing the lens or the flash when you capture an image.
When using this camera in low temperatures, you may experience
the following. These are not camera malfunctions and usually
recover at normal temperature.
- It takes longer to turn on the LCD monitor and the color may differ
from the subject.
- When changing the composition, there may be an after image on
the LCD monitor.
Credit cards may be demagnetized if left near case. Avoid leaving
magnetic strip cards near the case.
Never connect the 20 pin connector to the USB port of a PC. This
carries
a high risk offrom
computer
malfunction.
Downloaded
ManualsCamera.com
Manuals
Contents
READY
007
Package Contents
Sold Separately
008
Identification of features
008
009
011
011
012
012
012
Front & Top
Back
Bottom
Smart dial
Self-timer lamp
Camera Status Lamp
Mode icon
013
016
017
RECORDING
System chart
007
007
019
020
021
Connecting to a Power Source
Inserting the memory card
Instructions on how to use the memory
card
When using the camera for the first time
LCD monitor indicator
How to use the menu
022
Starting the recording mode
022
023
024
024
025
025
026
026
027
Selecting modes
How to use the Smart Auto mode
How to use the Program mode
How to use the Aperture. Shutter Priority
mode
How to use the Manual mode
How to use the User Setting shooting
mode
How to use the Nightscene modes
How to use the Beauty Shot mode
How to use the Scene modes
003
Contents
028
029
029
How to use the Movie clip mode
Recording HD (High Definition) movie clips
Recording the movie clip without sound
030
Things to Watch Out for When Taking
Pictures
Focus lock
Using the camera buttons to set the camera
POWER button
SHUTTER button
Zoom W/T Lever
Diopter adjustment lever
AEL/Image protection button
Flash pop-up button
Exposure compensation button
EVF/LCD button
MENU button
OK/AF point button
Info (DISP) / Up button
Macro / Down button
Flash / Left button
Self-timer / Right button
Shooting
031
031
031
032
032
034
034
034
035
035
036
037
037
038
041
043
044
045
046
048
048
049
004
How to Enable Functions Using the MENU
Button
White balance
Fine-tuning the white balance
ISO
Face Detection
Downloaded from ManualsCamera.com Manuals
052
053
053
053
054
054
055
055
056
056
057
057
058
059
060
061
061
062
063
063
064
064
064
SETUP
065
065
065
065
065
065
065
066
Smart FR Edit
Face Tone
Face Retouch
Photo Size / Movie Size
Quality / Frame rate
Smart Range
Metering
Drive mode
Setting AEB area
Auto Focus type
Flash Intensity
Photo Style Selector
Smart Filter
Image Adjust
Image Stabilization
Key mapping
Voice Memo
Voice Recording
Setting movie recording
Setting user mode
Distortion compensation
Movie clip frame stabiliser
Smart Scene Detection
Sound menu
Sound
Volume
Beep Sound
Shutter sound
Start up sound
AF sound
Setup menu
Contents
066
066
066
066
067
067
067
068
068
068
068
069
069
069
070
070
071
071
072
073
073
PLAY
074
074
074
075
075
075
075
076
077
Display
Setting the Grid Line
Function Description
Start up image
Display Bright
Quick view
Display Save
Settings
Formatting a memory
Initialization
Language
Setting up the Date / Time / Date type
Time Zone
File name
Imprinting the recording date
Auto power off
Auto Focus lamp
Anynet+ (HDMI-CEC)
HDMI Size
Selecting Video out type
Setting the USB
Starting play mode
Playing back a still image
Playing back a movie clip
Movie clip capture function
On camera movie trimming
Playing back a recorded voice
Playing back a voice memo
LCD monitor Indicator
Using the camera buttons to set the camera
Downloaded from ManualsCamera.com Manuals
077
077
077
080
080
081
081
082
084
084
085
085
086
087
089
089
089
090
090
091
091
091
091
092
093
093
094
096
097
Play mode button
Thumbnail / Digital Zoom Lever
Smart Album
Info (DISP) / Up button
Play & Pause / OK button
Left / Right / Down / MENU button
Delete button
Setting up the play back function using the
LCD monitor
Edit
Resize
Rotating an image
Photo Style Selector
Smart Filter
Image Adjust
View
Starting the Multi Slide Show
Start the Multi Slide Show
Selecting Images
Setting play interval
Setting Background Music
Configure Multi Slide show effects
File Options
Deleting images
Protecting images
Face List Edit
Voice memo
DPOF
Copy To Card
PictBridge
005
Contents
098
098
099
099
101
102
104
PictBridge : Picture Selection
PictBridge : Print Setting
PictBridge : Reset
Important notes
Warning indicator
Before contacting a service center
Specifications
SOFTWARE 107
Transferring files to your computer
(for Windows)
107
111
111
113
114
115
115
116
006
For Windows users
Transferring files to your computer
(for Mac)
For Mac users
Using the Samsung RAW Converter
Correcting the exposure
Handling the JPEG/TIFF files as you edit
RAW files
Saving the RAW files into JPEG or TIFF
format
FAQ
Downloaded from ManualsCamera.com Manuals
System chart
Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the
optional equipment, contact your nearest Samsung dealer or Samsung service center. Parts and accessories illustrated below may differ from
exact appearance.
Package Contents
Camera
Rechargeable battery
AC adapter / USB cable
Lens cap / Lens cap strap
(see p.10)
Software CD
(User manual included)
Quick Start Manual
AV cable
Battery charger
Neck strap (see p.10)
Sold Separately
SD/SDHC memory card
(see p.16)
Downloaded from ManualsCamera.com Manuals
HDMI cable
007
Identification of features
Front & Top
Zoom T Lever
(Digital zoom)
Shutter button
Zoom W Lever (Thumbnail)
Built-in flash (p.34)
AF Lamp/
Self-timer lamp
Microphone
Flash pop-up button
(p.34)
Diopter adjustment lever (p.34)
Hook for neck strap (p.10)
Speaker
HDMI port
Lens
008
Downloaded from ManualsCamera.com Manuals
USB and A/V port
Identification of features
Back
Mode Dial
POWER button
Electronic Viewfinder (EVF)
(p.36)
LCD monitor
Video shooting button
EVF/LCD button
(p.35)
MENU button
Play mode button
Smart dial (p.11)
Downloaded from ManualsCamera.com Manuals
Hook for neck strap
AE lock/image protection
button (p.34)
Exposure compensation
button (p.35)
OK/AF point button
(p.37)
Fn / Delete button
009
Identification of features
Ŷ Attaching the neck strap
Attach the neck strap as shown below.
Ŷ Attaching a lens cap to the camera
1. Insert the lens cap string into the
hole in the lens cap.
2. Attach the lens cap to the neck
strap.
Ensure that the neck strap is attached correctly, or the camera may
fall.
3. Attach the lens cap as shown in
the image.
010
Downloaded from ManualsCamera.com Manuals
Identification of features
Bottom
Smart dial
Ŷ When pressing the Smart Dial
• Move UP/DOWN /LEFT/RIGHT
• Execute options in the shooting mode:
c Change the display
d Change the timer option
e Change the close-up shooting option
f Change the flash option
Battery chamber
cover lever
Tripod socket
Push the battery chamber cover lever in the direction of the arrow to
open the battery chamber cover.
Battery chamber
Memory card slot
Battery chamber cover
Ŷ When turning the Smart Dial
• Move option or menu
• Adjust the shutter speed, aperture value,
exposure value and set the automatic exposure bracketing (AEB) area in the shooting
mode.
• Search files in the playback mode.
Battery holder
Downloaded from ManualsCamera.com Manuals
011
Identification of features
Self-timer lamp
Icon
Mode icon
Status
Description
- For the first 8 seconds, the lamp blinks at 1 second
intervals.
Blinking
- For the final 2 seconds, the lamp blinks quickly at
0.25-second intervals.
Blinking
For the 2 seconds, the lamp blinks quickly at
0.25-second intervals.
A picture will be taken after about 10 seconds and 2
Blinking
seconds later a second picture will be taken.
Status
After taking a picture
MODE
Description
The lamp turns on and off when the camera
is ready to take a picture
The lamp blinks while saving the image data and
turns off when the camera is ready to take a picture
MODE
The lamp lights up
(LCD monitor turns off after initializing the device)
MODE
MODE
ICON
When the AF activates
012
The lamp turns on
(The camera focus on the subject)
The lamp blinks
(The camera doesn’t focus on the subject)
Downloaded from ManualsCamera.com Manuals
Manual
User
Night
Beauty Shot
Scene
Movie
SCENE
Frame Guide
Portrait
Children
Landscape
Close Up
Text
Sunset
Dawn
Backlight
Fireworks
Beach & Snow
ICON
Transmitting Data with a PC The lamp blinks (LCD monitor turns off)
When the printer is printing The lamp blinks
Aperture. Shutter
Priority
ICON
When the USB cable is
inserted into a printer
The lamp blinks
Program
ICON
When flash battery is charging The lamp blinks
When the USB cable is
inserted to a PC
Smart Auto
ICON
MODE
Camera Status Lamp
Power on
Refer to page 22 for more information about the camera mode setting.
MODE
ICON
Connecting to a Power Source
You should use the rechargeable battery SLB-11A supplied with the
camera. Be sure to charge the battery before using the camera.
SLB-11A rechargeable battery Specification
Model
SLB-11A
Type
Lithium lon
Capacity
1130mAh
Voltage
3.8V
Charging time
Approximately 200 Minutes
Number of images and battery life: Using the SLB-11A
Battery life /
Number of images
Conditions
Using the fully charged battery,
Default settings, Program mode,
Shot to shot interval: 30Sec.
Approx. 120 MIN / Changing the zoom position between
Still image
Approx. 240 shots the Wide and the Tele after every shot.
Using the flash on every second shot.
Using the camera for 5 minutes and
then powering it off for 1 minute.
Movie
Using the fully charged battery
Approx. 120 MIN 640x480 image size
30fps frame rate
Important information about battery usage.
When camera is not in use, turn off the power.
Please remove the battery if the camera will not be used
for long periods. Batteries can lose power over time and are
prone to leaking if kept inside the camera.
Low temperatures (below 0°C) can affect the performance of
the battery and you may experience reduced battery life.
Batteries will usually recover at normal temperatures.
During extended use of the camera, the camera body may
become warm. This is perfectly normal.
Ŷ Connecting the AC adapter with the USB cable can be used as an
AC cable, and you can charge the rechargeable battery with the
AC cable.
- Using an AC cable:
Connect the AC adapter to the USB
cable. It can be used as a power
cable.
- Using a USB cable:
Remove the AC adapter.
You can download stored images to
your PC (p.108) or supply the power to
your camera through the USB cable.
Ä These figures are measured under Samsung’s standard conditions
and shooting conditions and may vary depending on the user’s
methods.
Downloaded from ManualsCamera.com Manuals
013
Connecting to a Power Source
Important information about USB cable usage.
Use a USB cable with the correct specification.
If the camera is connected to the PC through a USB hub :
connect the camera directly to the PC.
If the camera and other devices are connected to the PC at
the same time : remove other device.
Camera can not be detected using the front side USB port
of computer. In this case, use the back side USB port of
computer.
If the USB port of the PC doesn’t meet the Power output standard
(5V, 500mA), the battery may not be charged.
Before inserting any cables or AC adapter, check the directions
and do not insert by force. It may cause breakage of cable or
camera.
If the charging LED of the AC Charger does not turn on or blink
after inserting the rechargeable battery, please check whether
the battery is inserted correctly.
If you charge the battery with the camera power on, the battery
won’t be fully charged. Turn the camera off while charging the
battery.
Charging LED of the AC charger
Charging LED
How to charge the rechargeable battery
Being Charged
Red LED is on
Charging is complete
Green LED is on
Charging error
Orange LED is off or blinking
If you insert the fully discharged battery to charge it, do not turn on
the camera at the same time. The camera may not be turned on
because of the low battery capacity. Charge the battery for more
than 10 minutes before using the camera.
Do not use the flash frequently or take a movie clip with the fully
discharged battery charged for a short time. Even if the charger
is inserted, the camera power may be turned off because the
rechargeable battery is discharged again.
014
Downloaded from ManualsCamera.com Manuals
Connecting to a Power Source
When using the battery, please keep the following guidelines.
Failure to do so may cause the generation of heat, fire, or
explosion.
Ɣ If you find the battery shape distorted in size, try to contact a
service center. It may present physical dangers.
Ɣ Use only the recommended battery charger.
Ɣ Do not place the product close to the fire device.
Ɣ Do not insert the product into the microwave oven.
Ɣ Do not place the product inside a car during the summer.
Ɣ Do not place the product in a space with hot temperature and
high humidity range.
Ɣ Do not use the product for long time in the carpet, comforter, or
electronic mattress.
Ɣ Do not leave the product turned on where the air cannot be circulated.
Ɣ Be careful about the battery slot not to be connected with
accessories like necklace, coin, key, watch, and so on.
Ɣ Use the 2nd Advanced Lithium Batteries with the guarantee
under the manufacturing company.
Ɣ Do not try to disassemble or perforate the product by using the
sharp pin.
Ɣ Do not give a hard pressure on the product.
Ɣ Do not let the product fall down from the height, or do not give a
shock to the product.
Ɣ Do not exposure the product to the high temperature over 60°C
(140°F) degree.
Ɣ Do not exposure the product to the water or humidity.
Ɣ Battery shall not be exposed to excessive heat such as sunshine,
fire or the like.
Downloaded from ManualsCamera.com Manuals
Guidelines of disposal
Ɣ Do not throw away the over used battery.
Ɣ Destruction by fire is not allowed for disposal of battery.
Ɣ The disposal instruction may differ depending on the nation or
the specific region. Please follow the given method of disposal.
Guideline of recharging the battery
Ɣ Do not recharge the battery by using the different method other
than the user manual indicates. Failure to following the right
instruction may cause the fire or the explosion.
015
Connecting to a Power Source
Inserting the memory card
Insert the battery as shown
Insert the memory card as shown.
- If the camera does not turn on after you have inserted battery,
please check whether the battery (+ / -) direction is right.
- When the battery chamber cover is opened, do not force it. This
may cause damage to the battery chamber cover.
- Turn off the camera’s power before inserting the memory card.
- Have the front label of the memory card facing toward the front
of the camera (Lens) and the card pins toward the back of the
camera (LCD monitor).
- Do not insert the memory card the wrong way round.
Doing so may damage the memory card slot.
There are 4 indicators for battery condition that are displayed on
the LCD monitor.
Battery
indicator
Battery
status
The battery is
fully charged
Low battery
Low battery
Battery empty.
capacity
capacity
(Recharge or
(Prepare to
(Prepare to
use spare batrecharge or use recharge or use
tery)
spare battery) spare battery)
Ä When using the camera and the battery in a place that is excessively cold or hot,
the battery status on the LCD may be different from the actual battery status.
016
Downloaded from ManualsCamera.com Manuals
Instructions on how to use the memory card
Be sure to format the memory card (see p.68) if you are using a
newly purchased memory card for the first time, if it contains data
that the camera cannot recognize, or if it contains images captured
with a different camera.
Turn off the camera power whenever the memory card is being
inserted or removed.
Repeated use of the memory card will eventually reduce the
memory card’s performance. Should this be the case, you will need
to purchase a new memory card. Wear and tear on the memory
card is not covered by the Samsung warranty.
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy
impact.
Do not store the memory card in an environment with strong
electronic or magnetic fields, e.g. near loud speakers or TV receivers.
Please do not use or store in an environment where there are
extremes in temperature.
Do not allow the memory card to become dirty or to come into
contact with any liquid. Should this happen, clean the memory card
with a soft cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the
memory card is warm. This is perfectly normal.
Do not use a memory card that is used in another digital camera.
To use the memory card in this camera, format the memory card
using this camera.
Do not use a memory card formatted by another digital camera or
memory card reader.
Downloaded from ManualsCamera.com Manuals
If the memory card is subjected to any of the following, the recorded
data may become corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while
recording, deleting (formatting) or reading.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up
e.g. hard disks, CD etc.
If there is insufficient memory available :
A [Memory Full] message will appear and the camera will not
operate. To optimize the amount of memory in the camera, replace
the memory card or delete unnecessary images stored on the
memory card.
Don't remove the memory card when the camera status lamp is
blinking as this may cause damage to data in the memory card.
017
Instructions on how to use the memory card
The camera can use SD/SDHC Memory Cards.
Card pins
When using a 1GB SD memory, the specified shooting capacity will be
as follows. These figures are approximate as image capacities can be
affected by variables such as subject matter and memory card type.
Recorded
image size
Write protect switch
Label
Still
[SD (Secure Digital) memory card]
The SD/SDHC memory card has a write protect switch that
prevents image files from being deleted or formatted. By sliding
the switch to the bottom of the SD/SDHC memory card, the data
will be protected. By sliding the switch to the top of the SD/SDHC
memory card, the data protection will be cancelled.
Slide the switch to the top of the SD/SDHC memory card before
taking a picture.
29
33
116
191
285
-
-
131
215
321
-
-
154
252
375
-
-
199
324
479
-
-
311
502
733
-
-
487
779
1113
-
-
716
1113
1558
-
-
1640
2397
3116
Recorded
image size
-
12'58''
25'18''
-
41'31''
01:38'30''
01:29'48''
02:38'14''
03:23'03''
Movie
clip
The recording times can be changed by the zoom operation.
The Zoom W/T lever doesn’t function during the movie recording.
Several videos were recorded in succession to determine the total
recording time.
018
Downloaded from ManualsCamera.com Manuals
When using the camera for the first time
Charge the rechargeable battery fully before using the camera for
the first time.
When the camera is turned on for the first time, a menu will be
displayed on the LCD monitor to set date, time, time zone and
language. This menu will not be displayed again after setting up
the date, time, time zone and language. Set up the date, time,
time zone and language before using this camera.
2. Select the desired sub menu by
pressing the Up/Down button and press
the OK button.
1. Select the [Date&Time] menu by
pressing the Up/Down button and press
the Right button.
2. Select the desired sub menu by
pressing the Up/Down/Left/Right
button and press the OK button.
Language
:English
Time Zone
:London
Date & Time
:2010/03/01
yyyy mm dd
2010/ 03 / 01
Back
13:00
Off
Set
Left/Right button : Selects world time/year/month/day/hour/
zminute/date type.
Up/Down button : Changes the value of each item.
Setting up the language
1. Select the [Language] menu by
pressing the Up/Down button and press
the Right button.
Setting up the date, time and date type
Language
:English
English
:London
한국어
:08/12/01
Français
Time Zone
Date & Time
Deutsch
Español
Italiano
Back
Set
Setting up the Time Zone
1. Select the [Time Zone] menu by
pressing the Up/Down button and press
the Right button.
2. Press the Left/Right button to select the
desired mode.
Time Zone
London
[GMT +00:00]
Back
2010/03/01
01:00 PM
DST
Ä For more information about the World Time, refer to the page 69.
Downloaded from ManualsCamera.com Manuals
019
LCD monitor indicator
No.
6
7
8
9
10
11
The LCD monitor displays information about the shooting
functions and selections.
Description
Icons
Page
Battery
p. 16
Flash
p. 41
Self-timer
p. 43
Macro
p. 38
Smart Range
p. 54
Photo Style Selector
p. 57
12 Face Detection / Smart Filter
[Image & Full Status]
No.
Description
1
Recording mode
p. 22
2
Optical / Digital Zoom bar
/ Digital Zoom rate
p. 33
3
Voice Memo
p. 61
Number of available shots
remaining
Remaining time
Memory card icon /
5
Internal memory icon
4
020
Icons
Page
13
Camera shake compensation /
Without Sound
14
15
16
17
18
19
Date / Time
p. 69
p. 30
Auto Focus Frame
Auto Focus type
p. 56
Drive mode
p. 55
Metering
p. 55
20
Image Quality /
Frame Rate
p. 54
21
Photo Size / Movie Size
22
p. 56
p. 53
/
ISO / Face Retouch
23 White Balance / Face Tone
24
00:00:00
p. 18
Flash EVC
25
26 Locking the Exposure/Locking the Focus
Histogram
27
p. 48/53
p. 46/53
/
p. 24-25/
35
p. 57
Aperture Value/Shutter Speed/
Exposure compensation
p. 18
Downloaded from ManualsCamera.com Manuals
p. 60/63
2010/03/01 PM 01:00
Camera shake Warning
00001
-
p. 49/58
/
p. 61
p. 38
How to use the menu
1. Turn on the camera and press the MENU button. A menu for each camera mode appears.
White Balance
Shooting
WB Fine-tuning
ISO
Sound
Display
Settings
Face Detection
Smart FR Edit
Photo Size
Quality
Exit
Change
2. Use the up or down button to navigate through the menus.
White Balance
Shooting
WB Fine-tuning
ISO
Sound
Display
Settings
Face Detection
Press the
Up or Down
button.
Volume
Shooting
Sound
Display
Smart FR Edit
Beep Sound
Shutter Sound
Start Sound
Press the
Up or Down
button.
Sound
Display
AF Sound
Settings
Settings
Photo Size
Grid Line
Shooting
Function Description
Start Image
Display Brightness
Quick View
Power Save
Voice
Quality
Exit
Exit
Change
Exit
Change
Change
3. Use the left or right button to select a sub menu.
Volume
Shooting
Sound
Display
Beep Sound
Shutter Sound
Start Sound
AF Sound
Press the
Left or Right
button.
Volume
:Medium
Beep Sound
:1
Shutter Sound
:1
Start Sound
:Off
AF Sound
:On
Press the
Left or Right
button.
Volume
Off :Medium
Beep Sound
Low:1
Shutter Sound
Medium
:1
Start Sound
High
:Off
AF Sound
:On
Settings
Exit
Change
Exit
Back
Back
Set
4. Select a submenu and click the OK button to save settings and return to the previous window.
Downloaded from ManualsCamera.com Manuals
021
Starting the recording mode
Selecting modes
Ŷ Shooting modes
You can select the shooting modes by using the mode dial on the upper
of your camera.
How to use the mode dial
Select the shooting mode by turning the mode dial to the selection
point.
Manual
Aperture. Shutter Priority
User1
Program
Select point
Smart Auto
The appropriate option can be set
automatically for a shooting scene by
recognizing shooting scenes.
Program
Various shooting options can be set
manually.
Aperture. Shutter
Priority
Aperture values or shutter speed
can be set manually.
Manual
Various shooting options, including
the shutter speed and the aperture
values, can be set manually.
User
Frequently used shooting options
can be preset.
Night
This mode can be used at night or
in poor lighting conditions.
Beauty Shot
The skin tone of a subject can be
corrected.
Scene
The appropriate options for shooting scenes are preset per scene.
Movie
Movies can be recorded.
Smart Auto
User2
Movie
Night
Beauty Shot
022
Scene
Downloaded from ManualsCamera.com Manuals
Starting the recording mode
How to use the Smart Auto mode (
)
The camera automatically chooses the appropriate camera settings
based on a detected type of scene. It will be helpful if you are not
familiar with the camera settings for various scenes.
1. Select Smart Auto mode by using the
Mode dial. (p.22)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the Shutter button to capture an
image.
If the camera does not recognize a proper scene mode, the
default settings will be used.
Even if there is a face detected, the camera may not select a
portrait mode depending on the subject’s position or lighting.
Each scene is recognized in the following conditions;
[Landscape]
(
) : When shooting outdoor scenes
[White]
(
) : When shooting a white background
[Nights]
(
) : When shooting the nighttime scenes
[Night Portrait]
(
) : When shooting people in a dark outdoor
place
[Backlight]
(
) : When shooting a backlit scenery without
a portrait
[Backlight Portrait] (
) : When shooting a backlit portrait
[Portrait]
(
) : When shooting a portrait
[Macro]
(
) : When shooting close-ups
[Macro Text]
(
) : When shooting texts in a close focus
[Tripod]
(
) : When shooting a subject that doesn’t
move for a certain time after the camera
is mounted on the tripod (available only
when the camera recognizes it as nighttime)
[Action]
(
) : When shooting a subject making
frequent movements
[Sunset]
(
) : When shooting sunset
[Blue Sky]
(
) : When shooting blue sky
The camera may not select the correct scene depending on
shooting environments, such as camera shake, lighting, and
distance to the subject.
The [Night] mode recognizes scenes only when the flash is set
to off. The camera operates the [Tripod] mode after checking the
shooting condition on the tripod for a certain time.
Despite using a tripod, the camera may not select a tripod mode
depending on the subject’s movement.
Downloaded from ManualsCamera.com Manuals
023
Starting the recording mode
[Natural Green]
(
) : When shooting nature such as forest
and leaves
[Macro Color]
(
) : When shooting close-up shot for the
subject with various colors
[Macro Portrait]
(
) : When shooting close-up portrait shot
How to use the Program mode (
)
Selecting the Smart Auto mode will configure the camera with
optimal settings. You can still manually configure all functions.
1. Select the Program mode by using the
Mode dial. (p.22)
2. Press the Menu button to configure
advanced functions.
024
Downloaded from ManualsCamera.com Manuals
How to use the Aperture. Shutter Priority mode (
)
When the user configures the aperture value or shutter speed, an appropriate aperture value or shutter speed is configured automatically.
When the user configures an aperture value, the camera adjusts the
shutter speed automatically. When the user selects the shutter speed,
the camera selects an aperture value for optimal exposure.
1. Select the Aperture. Shutter Priority
mode by using the Mode dial. (p.22)
2. Select an aperture value or shutter
speed by turning the Smart Dial.
An " " icon will appear on the
selected item.
3. Select the aperture value or shutter
speed by pressing the left or right
button and then adjust a desired value
by turning the Smart Dial.
4. Point the camera towards the subject
and compose the image by using the
LCD monitor.
5. Press the Shutter button to capture an
image.
Starting the recording mode
How to use the Manual mode (
)
The user can manually set both the aperture value and the shutter
speed.
1. Select the Manual mode by using the
Mode dial. (p.22)
2. Select an aperture value or shutter
speed by turning the Smart Dial.
An " " icon will appear on the selected item.
3. Select the aperture value or shutter
speed by pressing the left or right
button and then adjust a desired value
by turning the Smart Dial.
4. Point the camera towards the subject
and compose the image by using the
LCD monitor.
How to use the User Setting shooting mode (
)
The user’s own shooting mode can be used by saving the shooting
options which are configured in the [Program], [Aperture. Shutter
Priority] and [Manual] modes.
See page 63 to see how to set the User mode.
1. Set a User setting mode (User 1,
User 2) by turning the Mode Dial.
(p.22)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the Shutter button to capture
an image.
5. Press the Shutter button to capture
an image.
Downloaded from ManualsCamera.com Manuals
025
Starting the recording mode
How to use the Nightscene modes (
)
Select this mode at night or in low light conditions.
1. Select the Nightscene mode by using
the Mode dial. (p.22)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the Shutter button to capture an
image.
How to use the Beauty Shot mode (
1. Select the Beauty Shot mode by using
the Mode dial. (p.22)
2. Press the Up/Down button in
[Shooting] menu to select [Face Tone]
or [Face Retouch].
3. Press the Left/Right button to select a
desired level of [Face Tone] or [Face
Retouch] features. And then press the
OK button.
4. Press the Shutter button to capture
images.
026
Downloaded from ManualsCamera.com Manuals
)
Take a photo of portraits by setting options to clear facial
imperfections.
Starting the recording mode
How to use the Scene modes (
The scene modes are listed below.
)
Use the menu to easily configure optimal settings for a variety of
shooting situations.
1. Select the Scene mode by using the
Mode dial. (p.22)
Frame Guide
2. Press the Left/Right button to select
the desired mode.
3. Point the camera towards the subject
and compose the image by using the
LCD monitor.
This mode is appropriate for taking pictures with
pre-composed scenes.
4. Press the shutter button to capture an
image.
Ä To change the Scene mode,
press the MENU button and select
a desired scene menu.
Frame Guide
Scene
Children
Sound
Landscape
Display
Exit
) : Use this mode when you want someone
else to take a picture for you from the
angle you choose.
[Portrait]
(
) : To take a picture of a person.
[Children]
(
) : To take a picture of fast moving
objects, for example, children.
[Landscape]
(
) : To take pictures of distant scenery.
[Close Up]
(
) : Close-up shooting for small objects such
as plants and insects.
[Text]
(
) : Use this mode to shoot a document.
[Sunset]
(
) : For taking pictures of sunsets.
[Dawn]
(
) : Daybreak scenes.
[Backlight]
(
) : Portrait without shadows caused by backlight.
[Fireworks]
(
) : Firework scenes.
Portrait
Shooting
Settings
[Frame Guide] (
Close Up
Text
Sunset
Change
Downloaded from ManualsCamera.com Manuals
[Beach & Snow] (
) : For ocean, lake, beach and snowscape
scenes.
027
Starting the recording mode
How to use the [Frame Guide] mode
How to use the Movie clip mode (
Set [Frame Guide] mode when you want someone else to take a
picture for you from the angle you choose.
A movie clip can be recorded for as long as the available recording
time (maximum 20 minutes at once) of the memory capacity allows.
1. Take a picture from the angle you
choose.
- A guide appears around the sides
of the picture.
Guide
Cancel Frame : OK
2. Then another person can take the
picture by aligning the edge of the
picture to be taken with the guide
framing the sides of the window.
Cancel Frame : OK
Cancel Frame : OK
)
1. Select the Movie clip mode by using
the Mode dial. (p.22)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the shutter button once and
movie clips are recorded for as long
as the available recording time allows. Movie clips will still be
recorded if the shutter button is released. If you wish to stop
recording, press the shutter button again.
Ä The user can shoot movies when
pressing the movie shooting button
in the shooting mode. When the user
presses the movie shooting button once
more, the function for shooting a movie
is disabled.
Ä Movie clip size and type are listed below.
– Movie clip size: 1280X720HQ, 640x480, 320x240
(1280X720HQ are the settings for recording
high-quality videos.)
– Movie clip file type: H.264(MPEG4.AVC)
– Frame Rate: 60FPS, 30FPS, 15FPS
Select [Zoom Mute] from the recording menu during video recording
to disable the recording of zoom sound.
028
Downloaded from ManualsCamera.com Manuals
Starting the recording mode
Recording HD (High Definition) movie clips
Recording the movie clip without sound
You can record HD (High Definition) movie clips. (1280X720HQ, 30 fps)
H.264(MPEG4.AVC) is a standard for the digital video codec.
It supports a high quality movie clip in a small file size.
You can record the movie clip without sound.
1. Select the Movie clip mode by using
the Mode dial. (p.22)
2. Press the Fn button to set the
resolution to [1280x720 HQ].
3. Press the Shutter button to record
video for the available recording time.
1280x720 HQ
Exit
Move
What is H.264(MPEG4 part10/AVC)?
Steps from 1 -3 are the same as those for
MOVIE mode.
4. Press the Menu button.
5. Press the Up / Down button to select
the [Movie] menu and press the Right
button.
6. Select the [Voice] menu by pressing the
Up / Down button and press the OK button.
7. Select the [Off] menu by pressing the Left / Right button.
8. Press the OK bu tton. You can record a movie without sound.
Ä See p.63 for further details.
With its high-compression rate and the small file size, it is a
standard for the digital video codec. It supports the recording
functions in a high resolution.
Downloaded from ManualsCamera.com Manuals
029
Things to Watch Out for When Taking Pictures
Pressing the shutter button down half way.
Lightly press the shutter button to confirm focus and flash battery
charge. Press the shutter button all way down to take the picture.
[Lightly press the shutter button]
[Press the shutter button]
The available memory capacity may vary depending on shooting
conditions and camera settings.
When shooting a low lighting conditions, the camera shake
warning indicator ( Ã ) may appear on the LCD monitor. In
this case, use a tripod, support the camera on a solid surface or
change to flash shot mode.
Shooting against the light : It is best to take pictures with the sun in the
background. Taking pictures against the
sun may make the picture come out dark.
To take a picture against the light, please
use the [Backlight] in scene shooting mode
(see page 23), fill-in flash (see page 42),
spot metering (see page 55), exposure
compensation (see page 35) or ACB (see
page 87) function.
030
Downloaded from ManualsCamera.com Manuals
Avoid obstructing the lens or the flash when you capture an image.
Compose the image by using the LCD monitor.
Under certain conditions the auto focus system may not perform
as expected.
- When photographing a subject that has little contrast.
- If the subject is highly reflective or shiny.
- If the subject is moving at high speed.
- When there is strong reflected light, or when the background is
very bright.
- When the subject matter has only horizontal lines or the subject
is very narrow (such as a stick or flagpole).
- When the surroundings are dark.
Focus lock
Using the camera buttons to set the camera
To focus on a subject not positioned in the center of the picture, use
the focus lock function.
The recording mode function can be set up by using the camera buttons.
Using the Focus Lock
1. Ensure the subject is in the center of the autofocus frame.
2. Press the shutter button halfway. When the green auto focus
frame lights up, it means the camera is focused on the subject.
Be careful not to press the shutter button all the way down to
avoid taking an unwanted picture.
3. With the shutter button still pressed down only halfway, move the
camera to recompose your picture as desired, and then press
the shutter button completely to take the picture. If you release
your finger from the shutter button, the focus lock function will be
cancelled.
1. The image to be
captured.
2. Press the shutter
button halfway and
focus on the subject.
POWER button
Used for turning the camera’s power
on / off. If there is no operation during
the specified time, the camera's power
will be turned off automatically to save
battery life. Refer to page 70 for more
information about the auto power off
function.
3. Recompose the picture
and fully depress the
shutter button.
Downloaded from ManualsCamera.com Manuals
031
SHUTTER button
Zoom W/T Lever
Used for taking an image or recording voice in the Recording mode.
If the menu is not displayed, this lever
works as the OPTICAL ZOOM or
DIGITAL ZOOM lever.
This camera has a 26X optical zoom
and a 5X digital zoom function. Using
both will offer a total zoom ratio of 130X.
In Movie clip mode
Pressing the shutter button down
fully starts the process for recording a movie clip. Press the shutter
button once and the movie clip is
recorded for as long as the available recording time in the memory
allows. If you wish to stop recording,
press the shutter button again.
In Still image mode
Pressing the shutter button down halfway activates the autofocus
and checks the condition of the flash. Pressing the shutter button
down fully takes and stores the image. If you select voice memo
recording, the recording will start after the camera has finished
storing the image data.
TELE Zoom
Optical zoom TELE : Move the Zoom W/T lever to the right to see
the subject closer.
Digital zoom TELE : Move the Zoom W/T lever to the right once
again in optical 26x zoom mode to enable
digital zoom (software tele). Stop moving
the Zoom W/T lever to stop the operation of
digital zoom (tele). In digital 5x zoom mode,
digital zoom is disabled even if you operate
the Zoom W/T lever.
[WIDE zoom]
032
Downloaded from ManualsCamera.com Manuals
[TELE zoom]
[Digital zoom 5.0X]
Zoom W/T Lever
WIDE Zoom
Optical zoom WIDE : Move the Zoom W/T lever to the left in
optical zoom mode to see subjects in the
distance. Continue to move the Zoom W/T
lever to the left to disable optical zoom.
If the Zoom W/T lever is fully turned, the zoom adjusts quickly.
If the Zoom W/T lever is turned a little, the zoom adjusts slowly.
Images taken using the digital zoom may take a little longer for
the camera to process. Allow time for this to take place.
Zooming during video recording may record operation sound of
the Zoom W/T lever.
Select [Zoom Mute] from the recording menu during video
recording to disable the recording of zoom sound.
You may notice a decrease in image quality when using the digital
zoom.
To view a clearer digital zoom image, press the shutter button
[TELE zoom]
Digital zoom WIDE
Optical zoom
Digital zoom
[Digital zoom 5.0X]
[Optical zoom 2X]
[WIDE zoom]
: Move the Zoom W/T lever to the left in
digital zoom mode to enable digital zoom
(software wide). Stop moving the Zoom
W/T lever to stop the operation of digital
zoom. Continue to move the Zoom W/T
lever to the left when digital zoom is
disabled to disable optical zoom (optical
tele).
[TELE zoom]
halfway at the maximum optical zoom position and move the
Zoom W/T lever to the right again.
The digital zoom can’t be activated in the [Face Detection], [Beauty
Shot], [Smart Auto], [Movie] and some Scene modes.
Take care not to touch the lens to avoid taking an unclear image
and possibly causing camera malfunction. If the image is dim, turn
the camera power off and on again to modify the lens position.
Take care not to press the lens as this may cause a camera
malfunction.
When the camera is turned on, take care not to touch the camera’s
moving lens parts as this may cause the resulting image to be dim
and unclear.
Take care not to touch the lens while operating the Zoom W/T
lever.
[WIDE zoom]
Downloaded from ManualsCamera.com Manuals
033
Diopter adjustment lever
Flash pop-up button
When the electronic viewfinder is out
of focus, the user can achieve the
clearest focus by turning the diopter
adjustment lever. (p.36)
When a background is brighter than a
subject, or when intentionally turning
on the flash, e.g. backlight shooting or
shooting in poor lighting conditions, the
user must pop up the flash by pressing
the flash pop-up button.
See page 41 to set the desired flash
mode for a shooting situation when
using the flash.
AEL/Image protection button (
)
An exposure value can be saved prior
to shooting when the AEL button is
pressed. When a subject is too small
to obtain the appropriate exposure or
for backlight shots, this button can be
used.
The AEL button can be used for AFL,
AEL/AFL, and AF (see page 61 for setting procedure).
In the playback mode, this button can be used as an image protection button ( ) (p. 92).
034
Downloaded from ManualsCamera.com Manuals
Precautions when using built-in flash
Ɣ Do not attempt to open the built-in flash forcibly, as it may damage
the camera.
Ɣ Ensure that the flash is always closed when it is not used.
If the flash is pushed backwards, it may damage the flash.
Exposure compensation button
EVF/LCD button
This camera adjusts the appropriate
amount of exposure automatically for
a shooting situation. The user can use
the exposure compensation button to
shoot with excessive exposure (bright
images) or insufficient exposure (dark
images). The range of exposure compensation is -2 to +2 (EV), and can be set with intervals of 1/3 EV.
The user can shoot with the electronic
viewfinder when it is difficult for the user
to see the LCD display due to bright
lighting.
The user can switch between EVF and
LCD by pressing the EVF/LCD button.
How to set exposure compensation
1. Press the exposure compensation
button in the shooting mode.
[Press the
EVF/LCD button.]
2. Set a desired exposure compensation
value by using the LEFT/RIGHT buttons or the Smart Dial.
3. Press the OK button to save a configured value and the setting
for exposure compensation is complete. The exposure compensation icon ( ) appears on the LCD monitor after setting
the exposure compensation, if the exposure compensation
value is not 0.0EV.
[LCD monitor]
[Electronic viewfinder]
Ä Note that the LCD monitor looks blurry or good images can’t
be obtained if [+] exposure compensation is made. If [-] exposure compensation is made, exposure becomes insufficient.
Exposure compensation setting is available in the [Program],
[Aperture. Shutter Priority] and [Movie] modes.
Downloaded from ManualsCamera.com Manuals
035
EVF/LCD button
MENU button
Using the electronic viewfinder (EVF)
The electronic viewfinder shows the same display as the LCD
monitor, and is used when it is difficult for the user to see the
LCD monitor due to bright lighting. Pressing the EVF/LCD button
will switch between the electronic viewfinder and the LCD monitor. The display remains the same when the camera is turned off
or when the user selects another mode with the Mode Dial.
- When you press the MENU button, a menu related to each
camera mode will be displayed on the LCD monitor. Pressing it
again will return the LCD to the initial display.
- The menu screen is available in the [Smart Auto], [Program],
[Aperture. Shutter Priority], [Manual], [Night], [Beauty Shot],
[Scene] and [Movie] modes, but it is not available in the voice
recording function.
When the electronic viewfinder is out of focus, turn the diopter
adjustment lever to obtain the clearest image.
White Balance
WB Fine-tuning
Shooting
ISO
Sound
Diopter adjustment lever
Face Detection
Display
Smart FR Edit
Settings
Photo Size
[Pressing the MENU button]
Electronic viewfinder (EVF)
Exit
[Menu off]
EVF/LCD button
036
Downloaded from ManualsCamera.com Manuals
Quality
Change
[Menu on]
OK/AF point button (
)
Info (DISP) / Up button
When the menu is displayed on the LCD
monitor, this button is used for shifting the cursor to the sub menu or for
confirming data.
This button is used when moving to or
saving the changed data on the menu
screen.
Press the UP/DOWN/LEFT/RIGHT buttons to shift the AF points.
White Balance
Shooting
Sound
Display
Settings
Face Detection
[Pressing the OK button]
Face Detection
Smart FR Edit
Smart FR Edit
Photo Size
Change
[Histogram/Grid Window]
WB Fine-tuning
ISO
Photo Size
Quality
Quality
Exit
[Filming screen]
White Balance
WB Fine-tuning
ISO
While the menu is showing, the Up button operates as a direction button.
In the recording modes or playback mode, pressing this button will display
the image information.
Exit
Back
[Information screen]
Histogram is not displayed when setting the [Face Detection]
function.
Downloaded from ManualsCamera.com Manuals
037
Info (DISP) / Up button
Histogram/Grid Window (
Macro (
While the menu is showing, the DOWN button operates as a direction
button.
When the menu is not showing, you can use the Macro ( ) / Down
button to take macro pictures.
The focus ranges are shown on the next page.
Press the Macro button until the desired macro mode indicator
appears on the LCD monitor.
)
Pixel
Histogram
Histogram shows you the distribution
of brightness in recorded images. If
the bars in the histogram are higher
towards the right, the image may be too
bright. If the bars are higher on the left,
the image may be too dark. If the lighting conditions are too bright to check
the subject by using the LCD, checking
the histogram will enable more precise
exposure control for the shots.
) / Down button
Distribution of brightness
Dark
Bright
Grid
[Auto Focus]
[Macro (
)]
If you focus on the subject using a variety of horizontal or vertical
grids, you will be able to take pictures at better angles, checking
size, horizontality, or proportions. For information on types of grid
and how to set them, refer to Page 66.
[Auto Macro (
[Manual Focus(
038
Downloaded from ManualsCamera.com Manuals
)]
)]
[Super Macro (
)]
Macro (
) / Down button
How to Set Focus Manually
Types of focus mode and focus range
If it is difficult to get the automatic focus to work (for example in
low light), you can manually control the focus.
Program(
Mode
1. Press the Macro button to enable
manual focus.
- Then the control bar for manual focus
will appear.
Focus
Type
2. Press the Left/Right button to control
the focus as you want.
Control Bar for Manual
Focus
Ä Set the manual focus to expand the center of the window to
the entire window. Press the shutter button halfway down to
return to the initial state.
(Unit: cm)
)/Aperture. Shutter Priority(
)
Manual(
Normal
Auto Macro
Wide
Wide
Macro
)/
Super
Macro
Manual
Focus
1 ~ 10
10 ~ Infinity
Wide
Focus 80 ~ Infinity 10 ~ Infinity
range
Tele
Tele
10 ~ 80
170 ~ Infinity 170 ~ Infinity
80 ~ 150
Tele
When the macro mode is selected, be particularly careful to
avoid camera shake.
When using the Super Macro function, you cannot operate the
zoom and adjust the zoom magnification rate.
The zoom is limited in Macro shooting.
Note that the picture may be blurred if manual focusing is not
performed properly.
Downloaded from ManualsCamera.com Manuals
039
Macro (
) / Down button
Available focusing method, by recording mode
( o : Selectable, : Infinity focus range)
Mode
Macro
Super
Macro
Manual
Focus
o
o
o
o
o
o
o
o
o
o
o
o
Normal
Auto Macro
SCENE
Mode
Normal
Auto Macro
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
Focus range is automatically selected in [Smart Auto] mode.
o
o
’
o
040
Macro
Downloaded from ManualsCamera.com Manuals
Super
Macro
Manual
Focus
Flash (
) / Left button
When the menu is displayed on the LCD monitor, pressing the Left
button makes the cursor shift to the left tab.
When the menu is not displayed on the LCD monitor, the flash ( )
/Left button operates as the flash ( ) button.
Selecting the flash mode
1. Press the Flash pop-up button to pop up the flash.
2. Select the desired Recording mode, except for the [Movie]
mode. (p.22)
3. Press the Flash button until the desired flash mode indicator is
displayed on the LCD monitor.
4. A flash mode indicator will be displayed on the LCD monitor.
Use the correct flash to suit the environment.
Ä You can control the flash intensity in the [Shooting] menu. (p.57)
Flash range
flash fires to check the shooting condition (Flash range and Power
ratio of flash). Do not move the camera until the second flash
fires.
Using the flash frequently will reduce the life of the battery.
Under normal operating conditions the re-charging time for the
flash is usually within 5 seconds. If the battery is weak, the charging time will be longer.
The camera flash does not operate in the [Movie] and some
Scene modes.
Take photographs within the flash range.
The image quality is not guaranteed if the subject is too close or
highly reflective.
When taking an image in poorly lit conditions with the flash, there
may be a white speck in the captured image. The speck is caused
by the flash light reflecting off atmospheric dust.
If flash doesn’t pop up, can not use the flash.
(Unit: m)
Shooting range
Wide
Tele
Normal
0.3 ~ 6.0
Auto macro
0.3 ~ 6.0
1.7 ~ 3.0
Macro
0.3 ~ 0.8
0.8 ~ 1.5
Super Macro
Manual Focus
If you press the shutter button after selecting the flash, the first
ISO
1.7 ~ 3.0
AUTO
0.3 ~ 6.0
1.7 ~ 3.0
Downloaded from ManualsCamera.com Manuals
041
Flash (
) / Left button
Flash mode indicator
Icon
Flash mode
Auto flash
Red-eye
Available flash mode, by recording mode
If the subject or background is dark, the
camera flash will operate automatically.
The flash fires regardless of the available light.
The intensity of the flash will be automatically
controlled to suit the prevailing conditions.
Slow synchro
The flash operates with a slow shutter speed
to obtain a balanced correct exposure. In poor
lighting conditions the camera shake warning
indicator ( Ã ) will display on the LCD monitor.
When a shot with "red eye" is detected,
Red-eye reduction this mode will reduce the red-eye effect
automatically.
042
Mode
o
o
If a subject or background is dark, the
camera flash will work automatically and will
reduce the red-eye effect by using the redeye reduction function.
Fill in flash
Flash off
( o : Selectable)
Description
The flash does not fire.
Select this mode when capturing images in
a place or situation where flash photography
is prohibited. When you capture an image in
poorly lit conditions, the camera shake warning indicator ( Ã ) will appear on the LCD
monitor.
Downloaded from ManualsCamera.com Manuals
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
o
Smart Auto Flash (
) icon will appear in [Smart Auto] mode.
Flash (
Self-timer (
) / Left button
SCENE
Mode
o
o
o
o
o
o
o
o
o
o
) / Right button
When the menu is displayed on the LCD monitor, pressing the Right
button makes the cursor shift to the right tab.
When the menu is not displayed on the LCD monitor, the Right
button operates as the Self-timer ( ) button. This function is used
when the photographer would also like to be in the image.
If you operate the Self-timer button during the self-timer
operation, the self-timer function is cancelled.
Use a tripod to prevent the camera from shaking.
In [Smart Auto], [Frame Guide], [Movie] mode, only the
10SEC self-timer will work.
o
o
o
o
o
o
Downloaded from ManualsCamera.com Manuals
043
Self-timer (
) / Right button
Selecting the self-timer
1. Select a Recording mode with the
exception of Voice recording mode. (p.22)
2. Press the Self-timer / Right ( )
button until the desired mode indicator
displays on the LCD monitor.
A 10 second, 2 second or Double Selftimer icon appears on the LCD monitor.
3. When you press the shutter button, the
picture will be taken after the specified
time has elapsed.
Shooting (
Use the menu that enables the functions, or the Fn button, to bring up the
menus below:
Mode
Description
10SEC Pressing the shutter button will allow an interval of
self-timer 10 seconds before the image is taken.
2SEC Pressing the shutter button will allow an interval of
self-timer 2 seconds before the image is taken.
A picture will be taken after about 10 seconds and
2 seconds later a second picture will be taken.
Double
When using the flash, the 2-second
self-timer
self-timer may be delayed for longer than 2 seconds depending on the flash charging time.
044
Downloaded from ManualsCamera.com Manuals
Available mode
Page
p.46
WB Fine-tuning
p.48
ISO
p.48
Face Detection
p.49-51
Smart FR Edit
p.52
Face Retouch
Self-timer mode indicator
Mode
Menu
White Balance
Face Tone
[Selecting the 10 SEC
self-timer]
Icon
)
p.53
Photo Size / Movie Size
p.53
Quality / Frame Rate
p.54
Smart Range
p.54
Metering
p.55
Drive
p.55
AEB Area
p.56
Focus Area
p.56
(Shooting)
Flash EVC
p.57
Photo Style Selector
p.57
Smart Filter
p.58
Image Adjust
p.59
Shooting (
Mode
(Shooting)
)
Menu
Available mode
Page
Image Stabiliser
p.60
Key mapping
p.61
Voice
p.61-63
How to Enable Functions Using the MENU Button
1. Press the MENU button in an available mode.
2. Press the Up / Down button to select the [Shooting] menu and
press the Right/OK button.
White Balance
Shooting
User Mode Set
p.63
Distortion Control
p.64
Stabilizer
p.64
Smart Scene Detection
p.64
Sound
Display
Settings
White Balance
WB Fine-tuning
WB Fine-tuning
ISO
ISO
Face Detection
Smart FR Edit
Photo Size
Face Detection
Right/OK
button
Smart FR Edit
Photo Size
Quality
Quality
Exit
Change
Exit
Back
3. Select a desired menu by pressing the Up / Down button and
then press the OK button.
White Balance
White Balance
WB Fine-tuning
WB Fine-tuning
ISO
ISO
Up / Down
button
Face Detection
Smart FR Edit
Photo Size
Face Detection
Smart FR Edit
Photo Size
Quality
Exit
Downloaded from ManualsCamera.com Manuals
Quality
Back
Exit
Back
045
Shooting (
)
4. Select a desired menu by pressing the Left / Right button and
then press the OK button.
ISO
ISO 80
Left / Right
button
Back
Move
Back
Move
Use the Fn button on the rear of the camera to bring up the menus
that enable frequently used functions faster.
White balance
The white balance is a function that makes
adjustments in accordance with the lighting
conditions and colors of a scene so that the
white in the photograph appears white.
The white balance control allows you to
adjust the colors to appear more natural
depending on the lighting conditions.
Mode
046
Back
Move
Description
Auto WB
The camera automatically selects the appropriate white balance settings, depending on the
prevailing lighting conditions.
Daylight
For taking images outside.
Cloudy
For taking images under a cloudy and overcast
sky.
Fluorescent_H
For shooting under daylight fluorescent types
of three-way fluorescent lighting.
Fluorescent_L
Shooting under white fluorescent lighting.
Tungsten
Downloaded from ManualsCamera.com Manuals
Icon
White Balance
For shooting under tungsten (standard light
bulb) lighting.
Custom Set
Allows the user to set the white balance
according to the shooting condition.
Color
Temperature
Allows the user to set the desired color
temperature according to the shooting condition.
Ä Different lighting conditions may cause a color cast on your images.
Shooting (
)
Using the Custom White Balance
What is color temperature?
White balance settings may vary slightly depending on the
shooting environment. You can select the most appropriate
white balance setting for a given shooting environment by setting
up the custom white balance.
1. Select the Custom (
) menu of the
White Balance and place a sheet of
white paper in front of the camera
so that the LCD monitor shows only
white.
Red light
Clear sky
Shade
Cool-white (Fluorescent)
Downloaded from ManualsCamera.com Manuals
Blue light
Cloudy
Flash
Daylight
Neutral-white (Fluorescent)
Warm-white (Fluorescent)
- The custom white balance value will be applied, starting with the
next picture you take.
- The user configured white balance will be remain effective until
it is overwritten.
Halogen
White paper
Incandescent
2. OK button
Candle flame
: selects previous
custom white balance.
Shutter button : saves new custom white
balance.
The color of the light changes to blue when the color temperature
goes up, but it changes to red when the color temperature goes
down. The change in the color of the light is indicated in kelvins (K)
and is called the color temperature. This camera allows the user
to set the white balance settings to shoot with natural colors in the
variety of lighting conditions.
047
Shooting (
)
Fine-tuning the white balance
ISO
Press the UP/DOWN/LEFT/RIGHT buttons
to adjust the desired white balance.
Seven levels (196 patterns) are available on
the G-M and B-A axis.
You can select the ISO sensitivity when
taking pictures.The speed or specific
light-sensitivity of a camera is rated by
ISO numbers.
• G: Green
• A: Amber
• M: Magenta
• B: Blue
Back
Move
ISO
Back
Move
[Auto] : The camera's sensitivity is automatically changed by
variables such as lighting value or subject brightness.
[ISO 80, 100, 200, 400, 800, 1600, 3200, 6400] :
You can increase the shutter speed while the same amount of light
is present, by increasing the ISO sensitivity. However, the image
may be saturated in high luminance.
The higher the ISO value, the higher the camera’s sensitivity to light
and therefore the greater its capacity to take pictures in dark conditions. However, the noise level in the image will increase as the ISO
value increases, making the image appear coarse.
Ä When [Motion Capture] is set, ISO speed will be set to Auto.
Ä ISO setting is available in the [Program], [Aperture. Shutter
Priority] and [Manual] modes.
Ä When you set the ISO speed to 6400, you can select only 3M or
lower resolution.
048
Downloaded from ManualsCamera.com Manuals
Shooting (
)
Face Detection
If you use face detection options, your
camera can detect a human face. When
focusing on a human face, the brightness
of the face is also adjusted. You can also
capture natural facial expressions by using
self portrait.
Face Detection
Back
Move
Ä Selectable modes: Program, Aperture. Shutter Priority, Manual,
Beauty Shot, Portrait, Children, Beach & Snow
Normal
This mode detects the face position of the subject automatically and
then sets the focus and exposure. Select this mode for quick and
easy face picture.
1. The size and position of the auto focus
frame is set at the face of the subject
automatically.
This function can detect up to 10 persons.
When the camera recognizes many people at the same time,
it will focus on the nearest person.
The Digital zoom is not activated in this mode.
When the camera detects a target face, the white color focus
frame will be displayed over the target face and the grey
color focus frame appears over the remaining faces.
Press the shutter button halfway down to focus on the face
and the white focus frame turns green.
Return to previous AF mode if face detection was failure.
In some conditions this function cannot work properly.
- When a person wears dark glasses or some part of the face
is hidden.
- When the person being taken does not look at the camera.
- Camera doesn't detect a face as the brightness is too dark
or too bright.
- The distance between the camera and object are far.
The maximum available Face Detection range is 2m (Wide).
The nearer the subject, the faster the camera can recognize
the subject.
In [Beauty Shot], [Portrait], and [Children] mode, the [Face
Detection] function setting is set to its default value.
2. Press the shutter button halfway.
The focus frame turns to green when
the focus is activated.
3. Press the shutter button fully to take a
picture.
Downloaded from ManualsCamera.com Manuals
049
Shooting (
)
Self Portrait
Smile Shot
When taking pictures of yourself, the area of your face is automatically
detected so that you can take self pictures more easily and quickly.
The camera automatically takes a picture by
detecting the face of the subject although
you don’t press the shutter button. If you
press the Shutter button, the picture is taken
in the normal way. When taking a picture of
smile shot, showing teethes or keeping the
smiley face of your subject helps detecting
the smile face of the subject.
1. For self-filming, set the camera lens
towards the face of the object.
It automatically detects the face of the
object, and emits a guiding sound.
2. Start filming by pressing the shutter
button.
When locating the face in the center of the screen, it repeatedly
emits a faster sound unlike the sounds that are emitted when
the face is not in the center.
Blink Detection
If the eyes of the subject are closed when
the shutter button is pressed, the camera
takes 2 continuous shots and then the
images are saved. The camera takes only
one picture if the eyes of the subject are
open when the Shutter button is pressed.
Detecting the smiling face or the blinking eyes may not be
available if any of the following situations occurs:
- If the subject is wearing sunglasses.
- When the subject is not facing directly to the camera.
- If the environmental light is too bright or too dark to detect the
face of the subject.
- When the camera is far from the subject. (Orange colored
focusing mark)
- If there is refl ection of the light or the back light that are too
bright.
050
Downloaded from ManualsCamera.com Manuals
Shooting (
)
Smart Face Recognition
The camera automatically registers
faces that you frequently photograph.
This feature will automatically prioritize
the focus on those faces and favorite
faces. This feature is available only
when you use a memory card.
The same person can be recognized as a different person and
vice versa depending on glasses, brightness, extreme change
of pose or facial expressions.
If you register a new face when 12 faces are already registered,
the 12th face with the lowest priority is switched with the newly
added face.
A maximum of 10 people can be registered in a scene.
Categorizing pictures is available in the playback mode according
to the priority of faces (p. 93).
Even though a face is recognized, it may not be categorized in
the Smart Album according to the priority.
The nearest face appears in a white
focus frame and the rest of the faces
appear in gray focus frames.
-
: Indicate favorite faces (To register
favorite faces, see page 52).
: Indicate faces that the camera
automatically registers.
Downloaded from ManualsCamera.com Manuals
051
Shooting (
)
You can register up to 8 favorite faces.
The flash option will be set to Off.
If you register the same face twice, you can delete one of the
faces in the face list.
Smart FR Edit
You can register frequently shot faces
or edit the registered face list prior to
shooting. This feature is available only
when you use a memory card.
Smart FR Edit
Face List
Back
Move
My Star
You can change the ranking of your favorite faces or delete them.
1. Press the Fn button.
Face List
You can register your favorite faces to prioritize the focus and
exposure on those faces.
1. Align your subject’s face with the
oval guideline and press [Shutter] to
register the face.
- If the subject’s face is not aligned
with the oval guideline, the white
frame will not appear.
Back
Set
- You can take photos of a subject’s
face directly from the front, to the left side, to the right side,
from above, or from below.
- Take photos of one person at a time when registering faces.
2. Press the OK button to save after taking photos of the face.
3. Press the MENU button when the registered face list appears.
- Your favorite faces are indicated with a (
) on the face list.
052
Downloaded from ManualsCamera.com Manuals
Back
2. Select a desired menu by pressing
the Up / Down button and then press
the OK button.
Edit
Face List
Edit Ranking
Delete My Star
Cancel
Back
[Edit Ranking]
Set
: Change the rankings of people registered as
My Star.
[Delete My Star] : Delete people from My Star.
Shooting (
)
Photo Size / Movie Size
Face Tone
This menu allows you to control the skin tone in images in beauty shot
mode. The higher the level you select, the brighter the skin tone.
1. Select [Face Tone] by pressing the
Up/Down button.
2. Select a desired face tone by pressing
the Left / Right button and then press
the OK button.
3. Press the Shutter button to take an
image.
You can select the photo size / movie size appropriate for your application.
(Unit: pixel)
Still image mode
Face Tone
Icon
Size
Back
4288x
3216
4288x
2848
4288x
2416
Move
3264x
2448
2592x
1944
2048x
1536
1920x
1080
1024x
768
Movie clip mode
Icon
Size
Face Retouch
1280x720HQ
This menu allows you to make skin appear clear and beautiful before
recording in beauty shot mode. The higher the level selected, the
more effective the control.
1. Select [Face Retouch] by pressing the
Up/Down button.
2. Select a desired face retouch by
pressing the Left / Right button and
then press the OK button.
3. Press the Shutter button to take an
image.
640x480
320x240
Movie Size
Photo Size
Back
Face Retouch
Move
[ Still image mode ]
Back
Move
Downloaded from ManualsCamera.com Manuals
Back
Move
[ Movie clip mode ]
The higher the resolution, the lower the number of shots
available because high resolution images require more memory.
053
Shooting (
)
Quality / Frame rate
This file format complies with the DCF (Design rule for Camera
You can select the compression ratio appropriate for your application
of the captured images. The higher the compression ratio, the lower
the picture quality.
JPEG (Joint Photographic Experts Group) :
Mode
Still image mode
File system).
JPEG is the image compression standard developed by the Joint
Photographic Experts Group. This type of compression is most
commonly used for compressing photos and graphics because it
can compress the files efficiently.
Icon
Sub menu RAW + S.Fine RAW + Fine Super Fine
File Format DNG+JPEG DNG+JPEG
Mode
JPEG
Fine
Normal
JPEG
JPEG
Movie clip mode
Icon
Sub menu
60 FPS
30 FPS
15 FPS
File Format
H.264
H.264
H.264
Smart Range
The smart range can be set to an image for
shooting. When you use the smart range,
detailed expressions of dark areas and bright
areas can be achieved. The level of brightness adjustment of [Smart Range 2] is set
higher than [Smart Range 1].
Smart Range
Back
Ɣ If the smart range is set too high, a noise may occur.
Frame Rate
Quality
Back
Move
[ Still image mode ]
054
Back
Move
[ Movie clip mode ]
Downloaded from ManualsCamera.com Manuals
Move
Shooting (
)
Metering
Drive mode
If you cannot obtain suitable exposure conditions, you can change
the metering method to take brighter pictures.
You can select continuous shot, and AEB (Auto Exposure Bracketing).
[Multi] (
) : Exposure will be calculated
based on an average of
Metering
the available light in the
image area. However, the
calculation will be biased
towards the center of the
Back
Move
image area. This is suitable
for general use.
[Spot] ( ) : Only the rectangular area in the center of the LCD monitor
will be metered for light. This is suitable when the subject
in the center is exposed correctly, regardless of the back
lighting.
[Center-weighted] ( )
: Exposure will be calculated based on an average of the
available light in the image area. However, the calculation
will be biased towards the center of the image area. This
is suitable for taking a picture of small object like a flower
or insects.
[Single] (
)
[Continuous] (
[High-speed] (
[Motion Capture] (
[AEB] (
)
: Take one picture only.
) : Images will be taken
continuously until the
Drive
shutter button is released.
) : Continuous shooting is
Back
Move
available while pressing
and holding the Shutter button (About 6.5 frames
per second). The shooting speed may get slower
depending on the shooting environment or the
number of shots. (Up to 3M Size)
) : This takes 10 shots per second, when the shutter
is pressed and held down. After completing the
continuous shooting, images are saved and the
images play back on the Rear LCD. The maximum
number of shots is 30 and the image size is fixed
as 1024X768.
: Take three consecutive photos with varying
exposure values. Use this mode if it is hard to
decide exposure of the object.
Ä If the subject is not the center of the focus area, do not use the
spot metering as this may result in an exposure error. In this
circumstance, it is better to use exposure compensation.
Downloaded from ManualsCamera.com Manuals
055
Shooting (
)
High resolution and picture quality increases file saving time,
which increases stand-by time.
If the [Continuous], [High-speed], [Motion Capture], [AEB] sub
menu is selected, the flash will be off automatically.
If less than 3 pictures are available in the memory, the AEB
shooting is not available.
It is best to use a tripod for the AEB shooting as the time to save
each image file is longer and blurring caused by camera shake
may occur.
Setting AEB area
The ranges and intervals of three photos can be set during AEB shooting.
- Set a standard for the exposure bracket
by pressing the LEFT/RIGHT buttons.
- Set a range for the left and right exposure
bracket by using the Smart Dial.
-2
0
+1
You can select your preferred Focus Area according to the shooting
conditions.
[Center AF] (
[Multi AF] (
) : The rectangular area in the
center of the LCD monitor
will be focused
) : This camera selects all of
available AF point from the 9
AF points.
Focus Area
Back
Move
[Selection AF] (
) : Focus on the desired position of the LCD monitor.
[Tracking AF] (
) : The focus moves along with the movements of a
subject.
Ä When the camera focuses on the subject, the auto focus frame
turns to green. When the camera doesn't focus on the subject, the
auto focus frame turns to red.
+2
AEB Area
Ŷ How to Enable Selection AF
Back
056
-1
Auto Focus type
Move
Downloaded from ManualsCamera.com Manuals
After setting [Selection AF], press the OK
button and then the screen for setting the
location of a focus frame will appear.
Press the Up/Down/Left/Right button to
move the focus mark to the desired position.
Press the shutter button to enable Selection
AF. Once setting is complete, the focus mark
will be fixed at the position set.
Move
Set
Focus Mark
Shooting (
)
Press the OK button once again to change the location of the focus
frame and the focus frame will appear again.
Ä Even if you turn off the power and turn on it again, the previous setting will be maintained.
Ä [Selection AF] is not available when operating the [Face Detection]
function.
Photo Style Selector
You can add various effects to the image
without using image editing software.
Photo Style Selector
Back
Move
1. Select the desired Photo style selector by pressing the Left/Right
button and press the OK button.
Flash Intensity
2. Press the Shutter button to take an image.
You can control flash intensity. (You can set flash intensity within the
range of +/- 2EV in intervals of 1EV.)
Style mode
Normal
[-2], [-1], [0], [+1], [+2]
Flash EVC
-2
Back
-1
0
+1
+2
Move
Ɣ The [Flash EVC] function is not available in the [Smart Auto],
[Beauty Shot], [Scene] and [Movie], [Night] modes.
Ɣ If the subject is too close or the sensitivity is too high, changing
the value to a negative value (-) may not have any effect.
Ɣ If the flash intensity is out of the control range because the
exposure value is too high or low, the camera may not operate
properly.
Downloaded from ManualsCamera.com Manuals
Icon
Description
No style effect is applied.
Soft
Soft style is applied.
Vivid
Vivid style is applied.
Forest
Forest style is applied.
Retro
Sepia style is applied.
Cool
Cool style is applied.
Calm
Calm style is applied.
Classic
Negative
Custom RGB
Black & white effect is applied.
Negative effect is applied.
Define an RGB tone to create your own photo
style.
057
Shooting (
)
Custom color : You can change the R
(Red), G (Green) and
B (Blue) values of the
image.
Smart Filter
Apply various filter effects to your photos
to create unique images.
Back
Smart Filter
Move
- Up/Down button : Selects R, G, B
- Left/Right button : Changes the values
Back
Move
1. Select the desired Smart Filter by pressing the Left/Right button
and press the OK button.
Back
Move
When picture style is set, face detection is not available.
When Soft or Vivid in photo style is set, saturation is not
available.
When Negative in photo style is set, contrast is not available.
2. Press the Shutter button to take an image.
Smart Filter
Normal
Icon
Description
No effect
Vignetting
Apply the retro-looking colors, high contrast, and
strong vignette effect
Fish-eye
Distort close objects to imitate the visual effect
of a fisheye lens.
Defog
Distinct style is applied.
When you apply a smart filter effect while recording a video, the
video will be automatically resized to (640x320) or smaller.
(Frame rate : 15 Fps)
If you use this function, you cannot set the photo style and image
adjustment options.
058
Downloaded from ManualsCamera.com Manuals
Shooting (
)
Image Adjust
Sharpness
You can adjust the sharpness of the
picture you are about to take.
You cannot check the sharpness effect
on the LCD monitor before you take a
picture, because this function is applied
only when the captured image is stored
on the memory.
Saturation
You can change the saturation of the image.
Image Adjust
-2
-1
0
+1
+2
Contrast
-2
-1
0
+1
+2
Saturation
-2
-1
0
+1
+2
Sharpness
Back
Move
1. Select [Saturation] by pressing the
Up/Down button.
2. Change the saturation by pressing the
Left/Right button.
3. Press the Shutter button to take an
image.
Image Adjust
-2
-1
0
+1
+2
Contrast
-2
-1
0
+1
+2
Saturation
-2
-1
0
+1
+2
Sharpness
Back
Move
When Image Adjust is set, Photo Style Selector function is not
1. Select [Sharpness] by pressing the Up/Down button.
2. Change the Sharpness by pressing the Left/Right button.
3. Press the Shutter button to take an image.
available.
When Image Adjust is set, Face Detection mode is not available.
Contrast
You can change the contrast of the image.
1. Select [Contrast] by pressing the
Up/Down button.
2. Change the contrast by pressing the
Left/Right button.
3. Press the Shutter button to take an
image.
Image Adjust
-2
-1
0
+1
+2
Contrast
-2
-1
0
+1
+2
Saturation
-2
-1
0
+1
+2
Sharpness
Back
Move
Downloaded from ManualsCamera.com Manuals
059
Shooting (
)
Image Stabilization
This feature allows you to minimize camera
shake while taking a picture.
Image Stabiliser
Back
[OIS] (
Move
) : Performs optical image stabilization.
[DUAL IS] (
) : Performs optical image stabilization and digital image
stabilization simultaneously.
Ŷ Things to watch out for using the DUAL IS mode
– The digital zoom will not operate in the DUAL IS mode.
– If the lighting conditions are brighter than fluorescent lighting conditions, the DUAL IS will not activate.
– If the lighting conditions are darker than fluorescent lighting conditions,
camera shake warning indicator ( ) will be displayed. For best results
only take pictures in situations where the camera shake warning
indicator ( ) is not displayed.
– If the subject is moving, the captured image may be blurred.
– As the DUAL IS uses the camera’s digital signal processor, it may take
a little longer for the camera to process and save the images.
060
Downloaded from ManualsCamera.com Manuals
OIS function may not work sufficiently in the following cases.
- To take pictures of a moving subject.
- To take pictures with higher zoom values.
- When camera shake is beyond the camera-shake correction
range.
- When the shutter speed is slow.
- When the battery is low.
If you operate OIS function using a tripod, the image can be
blurred by the vibration of the sensor of the OIS. Turn off the OIS
function when you use a tripod.
If the camera is subjected to an impact, the LCD monitor can be
affected. To make the camera function properly again, turn it on
and off.
Shooting (
)
Key mapping
Voice Memo
A desired AEL button can be set.
You can add your voice-over to a stored
still image. (Max. 10 sec.)
[AEL]: Shooting is available while the exposure is being locked.
Key mapping
[AFL]: Shooting is available while the focus
is being locked.
Back
Move
[AEL + AFL]: Shooting is available while the
exposure and the focus are locked.
[AF-On]: This function is a replacement for pressing the shutter halfway
down (metering and autofocus).
Memo
Back
Move
- If the voice memo indicator is displayed
on the LCD monitor, the setting is
completed.
- Press the shutter button and take a
picture. The picture is stored on the
memory card.
- Voice memo will be recorded for ten
seconds from the moment the picture
is stored. In the middle of the sound
recording, pressing the shutter button
will stop the voice memo.
Stop
Downloaded from ManualsCamera.com Manuals
061
Shooting (
)
Voice Recording
Pausing while recording a voice
Using this function, you can record
your favorite voice clips into a voice
recording file without having to create
multiple voice recording files.
A voice can be recorded for as long as
the available recording time (maximum 5
hours at once) allows.
Record
Stop
Back
1. Press the OK button to pause recording.
2. Press the OK button again to resume the recording.
3. If you wish to stop recording, press the shutter button again.
Press the shutter button to record a voice.
- Press the shutter button once and voice
is recorded for as long as the available
recording time (maximum 5 hours at
once) allows.
The recording time will be displayed
on the LCD monitor. Voice will still be
recorded if the shutter button is released.
A distance of 40cm between you and the camera (microphone) is
the best distance to record sound.
Record
Exit
[Voice recording mode]
- If you wish to stop recording, press the
shutter button again.
- File type : *.wav
062
Record
[Voice recording mode]
Move
Downloaded from ManualsCamera.com Manuals
If the camera power is turned off while the voice recording is
paused, the voice recording is cancelled.
Shooting (
)
Setting movie recording
Setting user mode
You can set the desired voice recording
mode in Movie mode.
You can use your own shooting mode by
saving the shooting options which are set
in the [Program], [Aperture. Shutter Priority]
and [Manual] modes.
Set a desired option and save the setting
information.
Voice
Back
Move
- [Voice] sub menus
[Off]
: Record a video without sound.
(
) icon will appear on the LCD monitor.
[On]
: Record a video with sound.
[Zoom Mute] : Record a video without sound while zooming.
Downloaded from ManualsCamera.com Manuals
User Mode Set
Back
Move
Ŷ How to set the user mode
1. Select a mode from [Program], [Aperture. Shutter Priority] or [Manual]
modes.
2. Select the desired mode.
3. Select [User Mode Set] in the [Shooting] menu.
4. Select [User Mode 1] or [User Mode 2] by pressing the LEFT/RIGHT
buttons and press the OK button to save the setting information.
063
Shooting (
)
Distortion compensation
Smart Scene Detection
Distortion of the center of an image due to
a wide-angle lens can be compensated for.
If you use the distortion compensation function, the size of the photo will be smaller than
one taken with normal shooting.
You can set the smart scene detection during
movie recording.
[Off]: Distortion is not compensated for.
Smart Scene Detection
Distortion Control
Back
Move
[On]: Distortion is compensated for.
Stabilizer
Back
Move
[Off]: Movie clip frame stabilizer function is disabled.
[On]: Minimises camera shake during movie recording.
Ä The recording frame range becomes narrow when you select this menu.
064
[Off](
) : Disable scene detection function.
[On](
) : Enable scene detection function.
Move
Select [Off] for normal movie recording.
When you set [Smart Scene Detection], you cannot set the
[Photo Style Selector] and [Smart Filter] options.
Movie clip frame stabiliser
This function helps stabilize images captured
during movie recording. You can select this
menu only in the Movie clip mode.
Back
Downloaded from ManualsCamera.com Manuals
Sound menu
In this mode, you can set up sound settings. You can use the setup
menu in all camera modes, except Voice Recording mode.
The items indicated by * are default settings.
Ä Menus are subject to change without prior notice.
Shutter sound
You can select the shutter sound.
- Shutter sound : [Off], [1]*, [2], [3]
Sound (  )
:Medium
Beep Sound
:1
Shutter Sound
Off :1
Start Sound
1
:Off
AF Sound
2
:On
3
Start up sound
Volume
You can select a volume of start up sound, shutter sound, beep
sound and AF sound.
- [Volume] sub menus : [Off], [Low],
[Medium]*, [High]
Volume
Volume
Off :Medium
Beep Sound
Low :1
Shutter Sound
Medium
:1
High
:Off
Start Sound
AF Sound
:On
Back
Set
You can select the sound that is activated whenever the camera is
turned on.
- Start up sound : [Off]*, [1], [2], [3]
- If the start up image is set to [Off], the
start up sound will not activate, even
though you may have set these to on.
Volume
:Medium
Beep Sound
:1
Shutter Sound
:1
Start Sound
Off :Off
AF Sound
1
:On
2
3
Back
Back
Set
Set
AF sound
Beep Sound
If you set sound to ON, a beep will sound when buttons are pressed,
letting you know the camera operation status.
If you set AF sound to on, AF sound will be activated when the Shutter
button is pressed down half way so that you can be aware of the
camera operation status.
- [Beep Sound] sub menus : [Off], [1]*, [2], [3]
- [AF sound] sub menus : [Off], [On]*
Volume
Beep Sound
Shutter Sound
:Medium
Off
1
:1
:1
Start Sound
2
:Off
AF Sound
3
:On
Volume
:Medium
Beep Sound
:1
Shutter Sound
:1
Start Sound
:Off
AF Sound
Off :On
On
Back
Set
Downloaded from ManualsCamera.com Manuals
Back
Set
065
Setup menu
Display (
In this mode, you can set up basic settings. You can use the setup
menu in all camera modes, except Voice Recording mode.
The items indicated by * are default settings.
Ä Menus are subject to change without prior notice.
Function Description
Display (
You can set the type of grid displayed on
the histogram/grid window. (p.37)
– [Grid Line] sub menus:
[+]:
Grid Line
Start Image
:2 X 2
+
:On
3X3
X :Off
Display Brightness
2 X :Auto
2
Function Description
Quick View
:0.5sec
Power Save
:Off
Back
066
You can select whether the function
description can be displayed on the window
in recording mode.
- Function Description sub menus
[Off] : The function description
function can’t be activated.
[On]* : The name and description of the
option is displayed.
)
Setting the Grid Line
[3 X 3]:
)
[X]:
Set
[2 X 2]*:
Downloaded from ManualsCamera.com Manuals
Grid Line
Function Description
Start Image
Display Brightness
:2 X 2
Off
On
:On
:Off
:Auto
Quick View
:0.5sec
Power Save
:Off
Back
Set
Start up image
You can select the image that is first displayed on the LCD monitor
whenever the camera is turned on.
- Sub menus : [Off]*, [Logo], [User Image]
- Use a saved image for the start-up image
with the [Start Image] in the [Resize]
menu in the play mode.
- The start-up image will not be deleted by
[Delete] or [Format] menu.
- The User images will be deleted by
[Reset] menu.
Grid Line
:2 X 2
Function Description
:On
:Off
Start Image
Display Brightness
Quick View
:Auto
OFF
:0.5sec
Power Save
:Off
Back
Set
Display (
)
Display Bright
Display Save
You can adjust the LCD brightness.
- Sub menus : [Auto]*, [Dark],
[Normal], [Bright]
Grid Line
:2 X 2
Function Description
:On
Start Image
:Off
Display Brightness
Auto:Auto
Quick View
Dark:0.5sec
Normal
:Off
Power Save
Bright
Back
Set
Quick view
If you set the [Power Save] to On and the camera isn't operated
during the specified time, the LCD monitor will be turned off
automatically.
- Sub menus
[Off]* : The LCD monitor will not be turned off.
[On] : If the camera isn't operated
during the specified time (about 30
SEC.), the camera power will be
idle (Camera status lamp:Blinking)
automatically.
Grid Line
:2 X 2
Function Description
:On
Start Image
:Off
Display Brightness
:Auto
Quick View
:0.5sec
Power Save
Off
:Off
On
Back
Set
Ä You can’t set the [Power Save] menu of Playback Mode.
If you enable Quick View before capturing an image, you can view
the image you just captured on the LCD monitor for the duration
set in the [Quick View] setup. Quick view is possible only with still
images.
- Sub menus
[Off]
: The quick view function can’t
be activated.
[0.5 sec]*, [1 sec], [3 sec]
: The captured image is briefly
displayed during the selected
time.
Grid Line
:2 X 2
Function Description
:On
Start Image
:Off
Display Brightness
Off :Auto
Quick View
0.5sec
:0.5sec
1sec:Off
Power Save
3sec
Back
Set
Downloaded from ManualsCamera.com Manuals
067
Settings (
)
Formatting a memory
Initialization
This is used for formatting the memory. If you run [Format] on the
memory, all images, including the protected images, will be deleted.
Be sure to download important images to your PC before formatting
the memory.
All camera menu and function settings will be restored to their
default values. However, values for Date & Time, Language, and
Video Out will not be changed.
- Sub menus
[Yes] : A window for confirming the
selection displays. Select the
[Yes] menu. A [Formatting]
message appears and the
memory will be formatted.
If you run FORMAT in Play mode,
a [Format is completed] message
will appear.
[No]* : The memory will not be formatted.
Format
Reset
Yes
No
Language
:English
Date & Time
:2010/03/01
Time Zone
:London
File No.
:Series
Imprint
:Off
Back
Set
Be sure to run [Format] on the following types of memory card.
- A new memory card, or an unformatted memory card.
- A memory card that has a file this camera can't recognize or one
that has been taken from another camera.
- Always format the memory card using this camera. If you insert a
memory card that has been formatted using other cameras,
memory card readers, or PCs, you will get a [Card Error]
message.
068
Downloaded from ManualsCamera.com Manuals
- Sub menus
[Yes] : A window to confirm the
selection will be displayed.
Select the [Yes] menu and
all settings will be restored
to their defaults.
[No]* : Settings will not be restored to
their defaults.
Format
Reset
Language
Yes
No
:English
Date & Time
:Off
Time Zone
:London
File No.
:Series
Imprint
Back
:Off
Set
Language
There is a choice of language that can be
displayed on the LCD monitor. Even if the
battery is removed and inserted again, the
language setting will be preserved.
Format
Reset
English
Language
한국어
:English
Français
:Off
Deutsch
:London
Español
Date & Time
Time Zone
File No.
Imprint
Back
:Series
Italiano
:Off
Set
Settings (
)
Setting up the Date / Time / Date type
File name
You can change the date and time that will be displayed on the
captured images and set up the date type. Setting [Time Zone]
enables you to display the local date and time on the LCD monitor
when travelling overseas.
This function allows the user to select the file naming format.
- Date type : [yyyy/mm/dd], [mm/dd/yyyy],
[dd/mm/yyyy], [Off]*
Format
Reset
Language
:English
Date & Time
:2010/03/01
yyyy
dd
Timemm
Zone
2010
/ 03 / 01
File No.
:London
13:00
Off
Imprint
Back
:Series
:Off
Set
Time Zone
Available cities:
London, Cape Verde, Mid-Atlantic,
Time Zone
Buenos Aires, Sao Paulo, Newfoundland,
Caracas, La Paz, NewYork, Miami,
Chicago, Dallas, Denver, Phoenix, LA,
San Francisco, Alaska, Honolulu, Hawaii,
London
[GMT +00:00] 2010/03/01 01:00 PM
Samoa, Midway, Wellington, Auckland,
Back
DST
Okhotsk, Guam, Sydney, Darwin, Adelaide,
Seoul, Tokyo, Beijing, Hong Kong, Bankok, Jakarta, Yangon, Almaty,
Kathmandu, Mumbai, New Delhi, Tashkent, Kabul, Abu Dhabi,
Teheran, Moscow, Athens, Helsinki, Rome, Paris, Berlin
[Reset] : After using the reset function, the
next file name will be set from
0001 even after formatting,
deleting all or inserting a new
memory card.
Format
Reset
Language
Date & Time
Time Zone
File No.
Imprint
:English
:2009/01/01
:London
Reset
:Series
Series
:Off
Back
Set
[Series]* : New files are named using
numbers that follow the previous sequence, even when
a new memory card is used, or after formatting, or after
deleting all pictures.
- The first stored folder name is 100PHOTO, and the first file name
is SAM_0001.
- File names are assigned sequentially from SAM_0001 SAM_0002 ~ SAM_9999.
- The folder number is assigned sequentially from 100 to 999 as
follows: 100PHOTO 101PHOTO ~ 999PHOTO.
- Maximum numbers of files in a folder are 9999.
- The files used with the memory card conform to the DCF (Design
rule for Camera File systems) format. If you change the image file
name, the image may not play back.
Ä DST : Daylight Saving Time
Downloaded from ManualsCamera.com Manuals
069
Settings (
)
Imprinting the recording date
Auto power off
There is an option to include DATE / TIME on still images.
This function switches the camera off after a set amount of time in
order to prevent unnecessary battery drainage.
- Sub menus
[Off]*
: The DATE & TIME will not be
imprinted on the image file.
[Date]
: Only the DATE will be
imprinted on the image file.
[Date & Time] : The DATE & TIME will be
imprinted on the image file.
Format
Reset
Language
:English
Date & Time
:2009/01/01
Time Zone
File No.
Imprint
Back
Off
:London
Date
:Series
Date & Time
:Off
Set
- Sub menus
[Off] : The power off function will not
operate.
[1 min], [3 min]*, [5 min], [10 min] :
The power will turn off automatically if
not used for the period of time specified.
Auto Power Off
:3 min
Off
1 min:On
Anynet+ (HDMI-CEC) 3 min:On
AF Lamp
HDMI Size
5 min:1080i
Video Out
10 min
:NTSC
USB
Back
Ä The Date & Time are imprinted at the bottom right side of the still
image.
Ä The imprint function is applied only to still images.
Ä Depending on the manufacturer and print mode, the date printed
on an image may not be printed correctly.
070
Downloaded from ManualsCamera.com Manuals
:Auto
Set
- After replacing the battery, the power off
setting will be preserved.
- Note that the automatic power off function will not operate if the
camera is in the PC / Printer mode, slide show, playing back a
voice recording and playing back a movie clip.
Settings (
)
Auto Focus lamp
You can turn on and off the Auto Focus lamp.
- Sub menus
[Off] : The AF lamp will not light up in
low light conditions.
[On]* : The AF lamp will light up in low
light conditions.
Auto Power Off
AF Lamp
Anynet+ (HDMI-CEC)
:3 min
Off :On
On :On
HDMI Size
:1080i
Video Out
:NTSC
USB
Back
4. When you select the camera menu of Anynet+ using the TV remote,
a play menu screen appears on the TV.
- The playback menu appearing on TV screen operates the same
function of the camera.
:Auto
Set
Anynet+ (HDMI-CEC)
Anynet+ (HDMI-CEC) is an AV network system which controls all your
connected SAMSUNG AV devices when using the TV remote control
that supports Anynet+. When connected to the SAMSUNG HDTV, you
can operate the playback functions by using the TV remote control.
5. Select the desired playback function by using the remote control of
the TV.
- To select the sub menus, move to the desired playback menu and
then press the Enter button.
Ŷ How to use the Anynet+ (HDMI-CEC)
1. Connect your camera to your HDTV using an optional HDMI cable.
(p.72)
2. TV turns on as soon as the power button is pressed on the camera.
3. If there is no picture after turning on the TV, press the source button
on the TV remote control to change to the HDMI mode.
- Depending on the TV, it might not change to the HDMI mode
although you press the source button.
Downloaded from ManualsCamera.com Manuals
Ɣ Only available when using the TV that supports Anynet+ (HDMI-CEC).
(Not available by using TV that supports Anynet)
Ɣ For more detailed information of the HDTV connection, see the
user manual of HDTV.
071
Settings (
)
HDMI Size
When the camera is connected with the
HDTV, you can select image size that is
compatible with the HDTV. The image sizes
are [1080i], [720p], [480p] and [576p]. Only
when [480p] is set to [NTSC] and [576p]
is set to [PAL], those resolutions will be
displayed in the menu.
Auto Power Off
:3 min
AF Lamp
:On
Anynet+ (HDMI-CEC)
:On
HDMI Size
Video Out
USB
Back
:1080i
1080i
:NTSC
720p
480p:Auto
Set
Ŷ How to connect the camera with the HDTV
Connect your camera to your HDTV using an optional HDMI cable.
HDMI cable
072
Downloaded from ManualsCamera.com Manuals
Ɣ HDMI (High Definition Multimedia Interface) is a function that
allows transferring the recorded images without compression by
using the HDMI cable. You can see the images in a high resolution
in the HDTV.
Ɣ When Anynet+ (HDMI-CEC) is used and HDMI resolution is set
to [480p] (NTSC) or [576p] (PAL), it is only available to play back
the image, movie clip, voice.
Ɣ If the selected HDMI resolution is not supported by HDTV, the
clear image can not be shown in the screen.
Ɣ If you try to select the HDMI resolution that is not supported by
HDTV, the resolution is adjusted to the maximum resolution of the
HDTV. For example, if you select “1080i” when the HDTV supports
the “720p” by the maximum resolution, it is adjusted to “720p.”
Ɣ You can playback the normal resolution of the movie clip as well.
Ɣ You can not connect HDMI to HDTV which is not supported.
Please check up the specification of HDTV before connecting it.
Ɣ For more information of the HDTV connection, see the user
manual of the HDTV.
Settings (
)
Selecting Video out type
The Video output signal from the camera can be NTSC or PAL.
Your choice of output will be governed by the type of device
(monitor or TV, etc.) to which the camera is connected. PAL
mode can support only BDGHI.
Connecting to an external monitor
When the camera is connected to an
external monitor, the image and menus
on the LCD monitor will be visible on the
external monitor.
Auto Power Off
:3 min
AF Lamp
:On
Anynet+ (HDMI-CEC)
:On
HDMI Size
:1080i
Video Out
:NTSC
NTSC
USB
PAL :Auto
Back
Set
- NTSC : U.S.A, Canada, Japan, South Korea, Taiwan, Mexico etc. .
- PAL : Australia, Austria, Belgium, China, Denmark, Finland, Germany,
U.K., Holland, Italy, Kuwait, Malaysia, New Zealand, Singapore,
Spain, Sweden, Switzerland, Thailand, Norway etc. .
- When using a TV as an external monitor, you will need to select the
external or AV channel of the TV.
- There will be a digital noise on the external monitor, but it is not a
malfunction.
- If the image is not in the center of the screen, use the TV controls
to center it.
- When the camera is connected to an external monitor, some parts
of the image may not be displayed.
- When the camera is connected to an external monitor, the menu
will be visible on the external monitor and the menu functions are
the same as those indicated on the LCD monitor.
Setting the USB
If the camera is set to connect automatically to a PC or a printer using
a USB cable, you can manually set [Computer] or [Printer].
Yellow - Video
White - Sound
Downloaded from ManualsCamera.com Manuals
-[USB] sub menus:
[Auto]*
: Automatically enables an
Auto Power Off
:3 min
external device connected with
AF Lamp
:On
Anynet+ (HDMI-CEC)
:On
a USB cable.
HDMI Size
:1080i
Auto
[Computer] : Sets computer connection
Video Out
:NTSC
Computer
USB
:Auto
mode if the connected external
Printer
device cannot be recognized
Back
Set
automatically.
[Printer]
: Sets printer connection mode if the connected external
device cannot be recognized automatically.
073
Starting play mode
Turn the camera on and select Play mode by pressing the play mode
button ( Î ). The camera can now play back the images stored in
the memory. If the memory card is inserted in the camera, all the
camera functions apply only to the memory card.
If the memory card is not inserted in the camera, all the camera
functions apply only to the internal memory.
Playing back a movie clip
1. Select the recorded movie clip that
you want to play back by using the
Left/Right button.
2. Press the OK button to play back a movie
clip file.
Play
Playing back a still image
1. Select the Play mode by pressing
the play mode button ( Î ).
2. The last image stored on the
memory is displayed on the
LCD monitor.
3. Select an image that you want to
view by pressing the Left/ Right
button.
Ä Press and hold the Left or Right
button to play back the images
quickly.
Video files (H.264 (MPEG4.AVC)) recorded with another
camera cannot be played back.
How to Control Volume While Playing Back Movie clip
While a movie clip is playing, if you turn the Zoom
W/T lever to the left, the volume turns down.
If you turn the Zoom W/T lever to the right, the
volume turns up.
Ä Even though voice memo, movie clip,voice
recording is playing, you can control the volume.
074
Downloaded from ManualsCamera.com Manuals
Capture
- To pause a movie clip file while playing
it back, press the OK button again.
- Pressing the OK button again will cause the movie clip file to
restart.
- To rewind the movie clip while it is playing, press the Left button.
To fast forward the movie clip, press the Right button.
- To stop playback of the movie clip, press the OK button, and
then press the Left or Right button.
Starting play mode
Movie clip capture function
Playing back a recorded voice
You can capture still images from the movie clip.
1. Select the recorded voice that you want to
play back by using the Left/Right button.
2. Press the OK button to play back a
recorded voice file.
- To pause a recorded voice file, while
Play
playing it back, press the OK button
again.
- To resume playback of the voice file, press the OK button.
- To rewind the voice file while it is playing, press the Left button.
To fast forward the voice file, press the Right button.
- To stop playback of the voice memo, press the Down button.
How to capture the movie clip
1. Press the OK button while playing the
movie clip. Then press the Down button.
2. The paused movie clip is saved as a
new file name.
Ä The captured movie clip file is the
Play
Capture
same size as the original movie clip
[Paused]
(1280x720HQ, 640x480, 320x240).
Ä When you press the down button at the beginning of the movie
clip, the first frame of the movie clip will be saved as a still image.
On camera movie trimming
Playing back a voice memo
You can extract desired frames of movie clip during the movie clip
play back.
1. Select a still image that has the voice
memo.
2. Press the OK button to play back the
voice memo.
- To pause the voice memo, while
playing it back, press the OK button
again.
- To resume playback of the voice memo,
press the OK button.
1. Press the OK button at the point of the
movie clip that you want to start extracting,
Trimming?
and turn the lever to the right.
Yes
No
2. Press the OK button at the point of the
movie clip that you want to stop extracting,
and turn the lever to the right.
Play
Capture
3. A confirmation window will be displayed.
4. Press the Up / Down button to select a desired sub menu.
[Yes] : The extracted frames are saved as a new file name.
[No] : The movie trimming will be cancelled.
Ä If the running time is under 10 seconds, the movie clip can’t be
Downloaded
from ManualsCamera.com Manuals
trimmed.
Play
Pause
075
LCD monitor Indicator
The LCD monitor displays shooting information about the displayed image.
076
Downloaded from ManualsCamera.com Manuals
No.
Description
Icon
1
Playback mode
p.74
2
Voice Memo
p.93
3
DPOF
p.94
4
Protect
p.92
5
Smart Face Recognition
p.51
6
Folder name & File name
7
Memory indicator
-
8
Battery
p.16
9
Histogram
p.38
100-0010
Page
p.69
10
ISO
80 ~ 6400
p.48
11
Aperture value
F2.8 ~ F8.0
-
12
Shutter speed
16 ~ 1/2,000
-
13
Flash
On/Off
p.41
14
Image size
4288x3216 ~ 320x240
p.53
15
Recording date
2010/03/01
p.69
Using the camera buttons to set the camera
Thumbnail ( º ) / Digital Zoom ( í ) Lever
In Play mode, you can use the buttons on the camera to conveniently
set up the Play mode functions.
Smart Album
Play mode button
If you have turned on the camera by
pressing the POWER button, you can
press the Play mode button once to
switch to Play mode and press it again to
switch to Recording mode.
You can view multiple pictures, enlarge a selected picture, and crop
and save a selected area of an image.
1. Turn the lever to the left to enter the Smart
Album mode when a picture is displayed.
2. Move to the desired picture by using the
Left/Right buttons.
3. Move to the normal playback screen by
turning the digital zoom lever to the right.
You can turn the power on with the Play
mode button. The camera is turned on in play mode. Press the
Play mode button again to turn off the camera.
Manner mode: To select the Manner mode, press the Play mode
button for more than 3 seconds. In the Manner
mode, Operating sound, Effect sound, Start-up
sound and Shutter sound will not be generated. To
cancel the Manner mode, turn on the camera by
pressing the POWER button.
Downloaded from ManualsCamera.com Manuals
11
12
Filter
[Highlighted image]
1
3
5
2010/03/01
[Smart Album Window]
077
Thumbnail ( º ) / Digital Zoom ( í ) Lever
Searching or Deleting Files
Smart Album Filter
1. Turn the lever to the left when the Smart
Album screen is displayed.
2. Whenever you turn the lever, categories
and files are displayed on the Smart
Album screen.
3. Select the file by pressing the Up/Down/Left/Right buttons.
4. Press the Delete(Õ) button to delete the selected file.
1. Press the MENU button in Smart
Album mode.
2. Selecting the desired category enables
to categorize and search the files by
using the Up/Down button.
Type
Date
Color
Week
Face
11
12
Back
1
2010/03/01
3
5
Set
Details of Each Category
Category
11
12
Filter
1
2010/03/01
3
5
11
12
Filter
1
3
5
2010/03/01
[9-Thumbnail Window]
11
12
Filter
1
3
Description
File Format
5
Type
Categorized depending on the file type
(e.g., picture, video, or voice)
Date
Categorized depending on the sequence
of recorded dates.
Color
Categorized depending on the main color.
Week
Categorized depending on the sequence
of recorded weeks.
Face
Categorized depending on the faces
photographed in the Face Detection mode.
2010/03/01
[20-Thumbnail Window]
When Smart Album feature runs or a category is selected, it
may take few seconds depends on recorded data volume.
However, it is not a malfunction please wait until Smart Album
screen appears.
Pictures,
Videos, Voice
Ɣ The [Face] category appears only if there are faces that
were photographed in the Face Detection mode.
078
Downloaded from ManualsCamera.com Manuals
Thumbnail ( º ) / Digital Zoom ( í ) Lever
Image enlargement
1. Select an image that you want to enlarge
and turn the lever to the right.
2. Different parts of the image can be
viewed by pressing the 5 function button.
3. Turning the lever to the left will zoom
back to the original full sized image.
- You can tell whether the image
displayed is an enlarged view by
checking the image enlargement
indicator shown at the top left of the
LCD monitor. (If the image is not an
enlarged view, the indicator will not
Trim
be displayed.) You can also check the
area of enlargement.
- Movie clips and WAV files can’t be enlarged.
- If an image is enlarged, a loss of quality may occur.
The maximum enlargement rate in proportion to the image size
Image size
Maximum
enlargement X13.4 X11.2 X11.2 X10.2 X8.1
rate
X6.4
X5.0
X3.2
Trimming : You can extract part of the image that you want and
save it separately.
1. Select an image that you want to enlarge and press the enlargement button.
Trimming?
Press the OK button and a message will
Yes
be displayed.
No
2. Select a desired sub menu by
pressing the Up / Down button
Confirm
and press the OK button.
- [Yes] : The trimmed image will be saved as a new file name,
and appear on the LCD monitor.
- [No] : The trimming menu will disappear.
Ä If there is not enough memory space to save the trimmed
image, the image can’t be trimmed.
Downloaded from ManualsCamera.com Manuals
079
Info (DISP) / Up button
Play & Pause / OK button
When the menu is displayed on the LCD monitor, the Up button
operates as a direction button.
When the menu is not displayed on the LCD monitor, pressing the
Info button will display image information on the LCD monitor.
In Play mode, the play & pause/ OK button works as follows:
Info (DISP) button
Info (DISP) button
- When the menu is displayed on the LCD monitor, the OK button
is used for confirming data that is changed by using the 5 function
button.
- If a still image with a voice memo, a voice file, or a movie clip is
playing
·In Stop mode
: Plays a still image with a voice memo, a voice
file, or a movie clip.
·During playback : Temporarily stops playback.
·In Pause mode : Resumes playback
Info (DISP) button
Play
[ Voice recording is stopped ]
080
Downloaded from ManualsCamera.com Manuals
Pause
Stop
[ Voice recording is playing ]
Play
Stop
[ Voice recording is paused ]
Left / Right / Down / MENU button
Delete ( Õ ) button
Left / Right / Down / MENU buttons activate the following.
This deletes images stored on the memory.
- Left button
: While the menu is showing, the Left button
operates as a direction button. While the menu is
not showing, press the Left button to select the
previous image.
- Right button : While the menu is showing, the Right button
operates as a direction button. While the menu is
not showing, press the Right button to select the
next image.
- Down button : While the menu is showing, the Down button
operates as a direction button.
- MENU button : When you press the MENU button, the play mode
menu will be displayed on the LCD monitor. Pressing
it again will return the LCD to the initial display.
1. Select an image that you want to delete by pressing the
Left / Right button and press the Delete ( Õ ) button.
Delete File?
Delete File?
Yes
No
Multiple Delete
Yes
No
Multiple Delete
11
Select
[Single Image]
12
1
3
5
Select
[Thumbnail Image]
2. To add images to delete, select the [Multiple Delete] menu.
- Left/Right button : Selects images
- OK button
: checks for deletion
- Fn button
: deletes the
selected images.
Prev
Select
Next
Delete
3. Select the submenu values by pressing the Up / Down button
and then press the OK button.
- If [Yes] is selected : deletes the selected images.
- If [No] is selected : cancels "Delete Image".
Downloaded from ManualsCamera.com Manuals
081
Setting up the play back function using the LCD monitor
Play mode functions can be changed by using the LCD monitor.
In the Play mode, pressing the MENU button displays the menu on
the LCD monitor. The menus you can set up in Play mode are as follows. To capture an image after setting up the play menu, press the
Play mode button or shutter button.
Menu Tab
Main Menu
Resize
Rotate
Edit
)
(
Photo Style
Selector
Smart Filter
Image Adjust
View
(
082
)
Sub Menu
2592x1944
2048x1536
1024X768
2592X1728
1800X1200
2592X1456
1920X1080
Start Image
Right 90˚
Left 90˚
180˚
Horizontal
Vertical
Normal
Soft
Vivid
Forest
Retro
Cool
Calm
Classic
Negative
Custom RGB
Off
Miniature
Vignetting
Fish-eye
Sketch
Defog
Off
ACB
Red-eye Fix
Face Retouch
Brightness
Contrast
Saturation
Add Noise
Single, 9, 20
Menu Tab
Sub Menu
Start
Play / Repeat
Images
Page
p.84
Main Menu
Multi Slide
Show
)
(
Interval
Music
Effect
p.85
Delete
p.85
p.86
Protect
File
Options
(
)
Face List Edit
Voice memo
All
Date
-
Select
-
-
1, 3, 5, 10 sec
-
Off
Mist
-
Drops
Muse
-
Trip
Fall
-
Off
Calm
-
Shine
Relax
-
Lively
Sweet
-
Select
-
All
Yes / No
Select
-
All
Lock / Unlock
Edit Ranking
-
Delete My Star
-
Off
-
On
-
Standard
p.87
DPOF
Index
Size
p.89
Downloaded from ManualsCamera.com Manuals
Copy to Card
Secondary
Menu
-
Page
p.89
p.90
p.90
p.91
p.91
p.91
p.92
p.93
p.93
Select / All / Reset p.94
Yes / No
~
Select / All / Reset p.95
Yes
-
No
-
p.96
Setting up the play back function using the LCD monitor
This menu is available while the camera is connected to a PictBridge
supporting printer (direct connection to the camera, sold separately)
with a USB cable.
Menu Tab
Main Menu
Images
Paper
❹
Layout
Sub Menu
Menu Tab
Secondary Menu Page
One Photo
-
All Photos
-
Auto
-
PostCard
-
Card
-
4X6
-
L
-
2L
-
Letter
-
A4
-
A3
-
Auto
-
Full
-
1
-
2
-
4
-
8
-
9
-
16
-
Index
-
Main Menu
Type
p.98
Quality
❹
Date
File Name
p.98
Downloaded from ManualsCamera.com Manuals
Reset
Sub Menu
Secondary Menu Page
Auto
-
Plain
-
-
Fast Photo
-
Auto
-
Draft
-
Normal
-
Fine
-
Auto
-
Off
-
On
-
Auto
-
Off
-
On
-
No
-
Yes
-
p.98
p.99
Ä Menus are subject to change without prior notice.
083
Edit (
)
Resize
Change the resolution (size) of pictures taken. Select [Start image]
to save an image to be the start-up image.
1. Press the play mode button and press
the MENU button.
2. Click the Up/Down button from the
)
Edit menu to select [Resize] (
menu tab and press the OK button.
3. Select a desired sub menu by
pressing the Left / Right button and
press the OK button.
Resize
Back
Image Resize Types
Move
( o : Selectable)
o
o
o
o
o
o
o
o
o
o
o
o
o
o
084
Downloaded from ManualsCamera.com Manuals
o
o
o
o
- A large sized image can be resized to a smaller sized image,
but not vice versa.
- Only JPEG images can be resized. Movie clip (H.264), Voice
recording (WAV) files can’t be resized.
- You can change the resolution of only those files compressed in
the JPEG 4:2:2 format.
- The resized image will have a new file name. The [Start
Image] image is stored not on the memory card but on the
internal memory.
- If a new user image is saved, the original user image will be
deleted.
- If the memory capacity is insufficient to store the resized image,
a [Memory Full] message will appear on the LCD monitor and the
resized image can't be stored.
Edit (
)
After using [Edit] feature, the edited image will be saved at a smaller
size than original image.
Rotating an image
You can rotate the stored images by various degrees.
1. Press the play mode button and press
the MENU button.
2. Click the Up/Down button from the Edit
menu to select [Rotate] (
) menu tab
and press the OK button.
3. Select a desired sub menu by pressing
the Left / Right button and press the
OK button.
Right 90˚
Back
Left 90˚
Move
[ ô : Right 90˚]
: Rotate picture in a
clock-wise direction
Back
Rotate
Back
Move
1. Press the play mode button and press
the MENU button.
2. Click the Up/Down button from the Edit
menu to select [Photo Style Selector]
(
) menu tab and press the OK
button.
3. Select a desired sub menu by
pressing the Left / Right button and
press the OK button.
Normal
Back
Move
[ ó : Left 90˚]
[ õ : 180˚]
: Rotate picture in a
: Rotate picture 180
counter-clock-wise direction degrees
Horizontal
It is possible to add various effects to your images by using this function.
Style mode
180˚
Move
Photo Style Selector
Vertical
Back
Move
Back
Move
Description
Soft style is applied.
Vivid
Vivid style is applied.
Forest
Forest style is applied.
Retro
Sepia style is applied.
Cool
Cool style is applied.
Calm
Calm style is applied.
Negative
Back
No style effect is applied.
Soft
Classic
[
: Horizontal]
: Rotate picture horizontally
Icon
Photo Style Selector
Black & white effect is applied.
Negative effect is applied.
Move
[ ® : Vertical]
: Rotate picture vertically
If you display the rotated image on the LCD monitor, empty
spaces
may appearfrom
to theManualsCamera.com
left and right of the image. Manuals
Downloaded
Custom RGB
Define an RGB tone to create your own photo style.
4. The changed image is saved as a new file name.
085
Edit (
)
Custom color
Smart Filter
You can change the R (Red), G (Green)
and B (Blue) values of the image.
- OK button : Select / setup the Custom
Color
- Up / Down button : Selects R, G, B
- Left / Right button : Change the values
Apply various filter effects to your photos to create unique images.
Back
Back
Move
1. Press the play mode button and press
the MENU button.
2. Click the Up/Down button from the
Edit menu to select [Smart Filter]
) menu tab and press the OK
(
button.
3. Select a desired sub menu by pressing
the Left / Right button and press the
OK button.
Back
Move
Move
Smart Filter
Off
086
Smart Filter
Downloaded from ManualsCamera.com Manuals
Icon
Description
No effect
Miniature
Make a photo of a life-size location or object
look like a photo of a miniature scale model.
Blurring parts of the photo makes the scene
seem much smaller than it actually is.
Vignetting
Apply the retro-looking colors, high contrast, and
strong vignette effect
Fish-eye
Distort close objects to imitate the visual effect
of a fisheye lens.
Sketch
Sketchy style is applied.
Defog
Distinct style is applied.
Edit (
)
Image Adjust
Face Retouch
You can make the skin in an image appear clear and beautiful.
1. Press the play back button and press the MENU button.
2. Click the Up/Down button from the Edit menu to select
[Image Adjust] (
) menu tab and press the OK button.
ACB
You can automatically adjust the brightness of the dark area,
caused by under exposure to the light source.
1. Select ( ) by pressing the Left/Right
button and press the OK button.
2. The [Making New Image] message is
displayed and the image is saved as a
new file name.
Face Retouch
Back
Move
ACB
Brightness control
Back
Move
Red eye effect can be removed from the captured image.
Red-eye Fix
Back
You can change the brightness of the image.
1. Select (
) by pressing the
Left/Right button and press the OK
button. Then a bar for selecting the
brightness will be displayed.
2. Change the brightness by pressing the
Left/Right button.
3. Press the OK button and the image will
be saved as a new file name.
Red eye Removal
1. Select ( ) by pressing the Left/Right
button and press the OK button.
2. The [Making New Image] message is
displayed and the image is saved as a
new file name.
1. Select (
) by pressing the Left/
Right button and press the OK button. Then a bar for selecting the face
retouch will be displayed.
2. Change the face retouch by pressing the
Left/Right button.
3. Press the OK button and the image will
be saved as a new file name.
Brightness
Back
Move
Move
Downloaded from ManualsCamera.com Manuals
087
Edit (
)
Contrast control
Noise effect
You can change the contrast of the image.
1. Select ( ) by pressing the Left/Right
button and press the OK button. Then
a bar for selecting the contrast will be
displayed.
2. Change the contrast by pressing the
Left/Right button.
3. Press the OK button and the image will be
saved as a new file name.
You can add noise to an image to add a more classic feel to your
photo.
1. Select (
) by pressing the Left/Right
button and press the OK button.
2 The [Making New Image] message is
displayed and the image is saved as a
new file name.
Contrast
Back
Move
Back
Saturation control
You can change the saturation of the image.
1. Select (
) by pressing the Left/Right
button and press the OK button. Then
a bar for selecting the saturation will be
displayed.
2. Change the saturation by pressing the
Left/Right button.
3. Press the OK button and the image will be
saved as a new file name.
088
Add Noise
Saturation
Back
Move
Downloaded from ManualsCamera.com Manuals
Move
View (
)
Starting the Multi Slide Show (
You can view the thumbnails and easily categorize or search a large
amount of content such as pictures and videos.
1. Press the MENU button in playback
mode.
2. Press the Up/Down button to select the
desired menu.
3. Press the OK button and selected
thumbnail screen will appear.
Single
Images can be displayed continuously at pre-set intervals.
You can view the Multi Slide Show by connecting the camera to an
external monitor.
1. Press the play mode button and press the menu button.
2. Press the Up / Down button and select the [Multi Slide Show]
menu tab and press the OK button.
9
20
Exit
)
Back
Start the Multi Slide Show
The Multi Slide Show can start only in the [Start] menu.
1. Use the Up / Down button to select the [Start] menu and press
the Right button.
2. Select a desired sub menu by pressing
the Up / Down button.
[Play] : The Multi Slide Show is
closed after one cycle.
[Repeat] : The Slide show is repeated
until cancelled.
Start
Images
Interval
Play
Repeat:All
:1 sec
Music
:Off
Effect
:Off
Back
Set
3. Press the OK button and the slide show will be started.
- To pause the slide show while playing it back, press the OK
button again.
- Pressing the OK button again will cause the Multi Slide Show
restart.
- To stop playback of the Multi Slide Show, press the OK button,
and then press the Left or Right button.
Downloaded from ManualsCamera.com Manuals
089
Starting the Multi Slide Show (
)
Selecting Images
Setting play interval
Set the Multi Slide Show play interval.
You can select image to view
1. Use the Up / Down button to select the
[Images] menu and press the Right button.
Start
Images
Interval
All
:All
:1 sec
Date
:Off
Select
Music
2. Select a desired sub menu by pressing
Effect
:Off
the Up / Down button.
[All]
: All images saved in the
Back
Set
Memory are played back.
Press the OK button and the settings are saved.
[Date] : Images taken in a specified date are played back.
Press the OK button and the settings are saved.
[Select] : Play only the selected images. If you press the Up /
Down button, you can select the desired images to play
back. The selected image can be saved as [Select1],
[Select2] and [Select3]. If you save the selected image
with the [New Select] command, it will be saved as
[Select1]. But when a new image is saved again using
[New Select], the former image which had been saved
as [Select1] will be saved as [Select2] automatically.
You can change and cancel the images which were
saved as [Select1], [Select2] and [Select3]. Press the
Fn button and the settings are saved.
3. Select [Play] or [Repeat] in the [Start] menu to start the multi
slide show.
090
Downloaded from ManualsCamera.com Manuals
1. Select the [Interval] sub menu by
pressing the Up / Down button and
press the Right button.
2. Use the Up / Down button to select
the desired interval.
3. Press the OK button to save the
configuration.
Start
Images
:All
Interval
:1 sec
1 sec
Music
3 sec:Off
5 sec:Off
Effect
10 sec
Back
Set
The loading time depends on the image size and quality.
While the Multi Slide Show is playing, only the first frame
of a Movie file is displayed.
While the Multi Slide Show is playing, the voice recording file
will not display.
The interval menu functions in the [Off] menu only.
Starting the Multi Slide Show (
File Options (
)
Setting Background Music
1. Press the play mode button and press the menu button.
2. Press the Up / Down button and select the [File Options] menu tab
and press the OK button.
Set the Multi Slide Show music.
1. Select the [Music] sub menu by
pressing the Up / Down button and
press the Right button.
2. Use the Up / Down button to select the
desired Music.
3. Press the OK button to save the
configuration.
Start
Images
Interval
Music
Effect
Back
Off
Mist :All
:1 sec
Drops
Muse:Off
Trip :Off
Set
Unique screen effects can be used for the Multi Slide Show.
Start
Interval
Off
:All
Calm
:1 sec
Shine
Music
:Off
Relax
Effect
Lively
:Off
Sweet
Images
Back
Deleting images
This deletes images stored on the memory.
Fall
Configure Multi Slide show effects
1. Select the [Effect] sub menu by
pressing the Up / Down button and
press the RIGHT button.
2. Use the Up / Down button to select
the type of effect.
3. Press the OK button to confirm the
setting.
)
Set
Downloaded from ManualsCamera.com Manuals
1. Press the Up / Down button and select
Delete
Select
Protect
the [Delete] menu tab. And then press
All
Face List Edit
the Right button.
Voice memo
:Off
2. Select a desired sub menu by pressing the
DPOF
Copy
to
Card
Up / Down button and press the OK button.
[Select] : Selection window for an image
Back
Set
to delete is displayed.
- Up/ Down/ Left/ Right : Select an image
- OK button : Select the image for
deletion. ( Ë mark)
- Fn Button : Press the Fn button to display
the confirmation message.
Select
Delete
Select the [Yes] menu and
press the OK button to delete
marked images.
Delete
[All] : Displays confirmation window.
Protect
Select the [Yes] menu and press the
Face List Edit
Delete All File(s)?
OK button to delete all unprotected
Voice memo
:Off
Yes
DPOF
No
images. If there aren’t protected
Copy to Card
images, all the images are deleted
Back
Set
and a [No Image File] message will
appear.
3. After deletion, the screen will be changed to the play mode screen.
11
12
1
3
5
091
File Options (
)
Of all the files stored on the memory, the unprotected files
in the DCIM subfolder will be deleted. Remember that this
will permanently delete unprotected images. Important shots
should be stored on a computer before deletion takes place.
The startup image is stored on the camera’s internal memory
(i.e., not on the memory card) and it will not be deleted even if
you delete all files on the memory.
[All] : Protect / release all saved images
- If you protect an image, the protect
icon will be displayed on the LCD
monitor. (An unprotected image has
no indicator)
- An image in LOCK mode will be
protected from the delete function
or [Delete] function, but will NOT be
protected from the [Format] function.
Delete
Protect
Face List Edit
Protect All?
Recycle Bin
Lock
Voice memo Unlock
DPOF
:Edit Ranking
:Off
:Off
Copy to Card
Back
Set
Protecting images
This is used to protect specific shots from being accidentally erased (Lock).
It also unprotects images that have been previously protected (Unlock).
1. Press the Up / Down button and select
the [Protect] menu tab. And then press
the Right button.
2. Select a desired sub menu by pressing the
Up / Down button and press the OK button.
[Select ] : Selection window for an
image to be protected /
released is displayed.
- Up / Down / Left / Right : Select an image
- OK button : Protect / release the
- Fn button : Your changes will be
saved and the menu will
disappear.
092
Delete
Protect
Select
Face List Edit
All
Voice memo
:Off
DPOF
Copy to Card
Back
11
12
Select
Set
1
3
5
Set
Downloaded from ManualsCamera.com Manuals
Image protection is enabled when selecting an image in playback
mode and pressing the image protection button. ( )
File Options (
)
Face List Edit
Voice memo
Portrait images can be classified or deleted in the smart album
according to their ranking. This feature is available only when you
use a memory card.
You can add your voice to a stored still image.
1. Press the Up / Down button to select
the [Face List Edit] menu and press the
Right/OK button.
2. Select a desired menu by pressing the
Up / Down button and then press the
OK button.
[Edit Ranking] : The ranking of the
registered images
can be changed.
[Delete My Star] : Selected images can
be deleted from the
list.
3. Press the MENU button to switch to the
Playback mode.
Delete
Protect
Face List Edit
Delete
Voice memo
Protect
Face List Edit
Voice memo
Edit Ranking
Delete:Off
My Star
DPOF
Back
Copy to Card
Back
Off
:Off
On
Set
[Voice memo menu]
Start
[Ready for recording]
Stop
[Voice is recording]
Set
- Once you press the shutter button, the voice will record for 10
seconds.
- To stop the recording, press the shutter button.
Face List Edit
Back
DPOF
Copy to Card
Set
Downloaded from ManualsCamera.com Manuals
093
File Options (
)
DPOF
DPOF(Digital Print Order Format) allows you to embed printing
information on your memory card’s MISC folder. Select the
pictures to be printed and how many prints to make.
The DPOF indicator will display on the LCD monitor when an image
that has DPOF information plays back. Images can then be printed
on DPOF printers, or at an increasing number of photo labs.
This function is not available for Movie clips and Voice recording files.
When the wide angle image is printed as a wide angle print, 8%
of the left and right side of the image may not be printed. Check
that your printer can support the wide angle image when you print
the image. When you print the image at a photo lab, request that
the image is printed as a wide angle image. (Some photo labs
may not support the wide angle size print.)
Depending on the printer, the image saved in portrait orientation
may not be printed in portrait orientation.
Standard
This function allows you to embed printing quantity information on
a stored image.
1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.
Delete
Protect
Select
Face List
EditImage
Voice memo Select
All
DPOF
Reset
Copy to Card
2. Press the Right button again and
[Standard] sub menu will display.
3. Select a desired sub menu by pressing
the Up / Down button and press the OK
button.
[Select] : Selection window for an
image to print is displayed.
- Up / Down / Left / Right : Select an
image to print.
- Zoom W/T Lever : Select the number of
prints.
[All] : Configure number of prints for all
pictures except movie and voice
files.
- Up / Down button : Select a number of
prints
[Reset] : Cancel the print setup.
Back
11
Set
00
00
00
02
12
:Off
1
01
3
Quantity
5
Set
0
Quantity
Set
4. Press the OK button to confirm the setting. If an image carries
) will show.
DPOF instruction, the DPOF indicator (
094
Downloaded from ManualsCamera.com Manuals
File Options (
)
Index
Images (except for movie clips and voice files) are printed as index
type.
1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.
2. Select the [Index] menu and press the
Right button again. Sub menu will
display.
Print size
You can specify the print size when printing images stored on the
memory card. The [Size] menu is available only for DPOF 1.1
compatible printers.
Delete
Protect
Face List Edit
Setting Index?
Voice memo Yes
DPOF
:Off
No
Copy to Card
Back
Set
3. Select a desired sub menu by pressing the Up / Down button.
If [Yes] is selected : The image will be printed in index format.
If [No] is selected : Cancel the index print setting.
4. Press the OK button to confirm the setting.
1. Press the Up / Down button and select
the [DPOF] menu tab. And then press
the Right button.
Delete
Protect
Select Image
Face List Edit
Select
Voice memo
All
DPOF
Reset
2. Select the [Size] menu and press the
Right button again. Sub menu will
display.
3. Select a desired sub menu by pressing
the Up / Down button and press the
OK button.
[Select] : Selection window to change
the printed size of the image
is displayed.
- Up / Down / Left / Right : Select an image.
- Zoom W/T Lever : Change the print size.
- Fn button : Your changes will be
saved and the menu will
disappear.
[All] : Change print size of all saved
images.
- Up / Down button : Select a print size
- OK button : Confirm the changed setting.
[Reset] : Cancel all of the print size settings.
:Off
Copy to Card
Back
11
Set
Cancel
Cancel
Cancel
Cancel
12
1
Cancel
3
Size
5
Set
3X5
Size
Set
Ä DPOF [Size] secondary menu : Cancel, 3X5, 4X6, 5X7, 8X10
Depending on the manufacturer and print model, cancelling the
Downloaded from ManualsCamera.com Manuals
printing may take a little longer for the printer to process.
095
File Options (
)
Copy To Card
If there is not enough space available in the memory card to
This enables you to copy image files, movie clips and voice recording
files to the memory card.
1. Select the [Copy to Card] menu tab by
pressing the Up / Down button. And
then press the Right button.
2. Select a desired sub menu by pressing
the UP/ DOWN button and press the
OK button.
Delete
Protect
Face List Edit
Voice memo
:Off
DPOF
Copy to Card
Yes
No
Back
Set
- [No] : Cancels "Copy to Card".
- [Yes] : All images, movie clips and voice recording files saved in
the internal memory are copied to the memory card after
the [Copying] message is displayed. After copying has
been completed, the screen will return to play mode.
096
Downloaded from ManualsCamera.com Manuals
copy saved images on the internal memory (About 8MB), the
[Copy to Card] command will copy only some of the images and
display [Memory Full] message. Then the system will return to
the playback mode. Please be sure to delete any unnecessary
files to free up space before inserting the memory card into the
camera.
When you move the images that are stored on the internal
memory by doing [Copy to Card] to the card, the next number of
file names will be created on the card to avoid duplication of the
file name.
- When the [Reset] of the [File No.] setup menu is set : The copied file names start from after the last stored file name.
- When the [Series] of the [File No.] setup menu is set : The copied
file names start from after the last captured file name. After
completing [Copy to Card], the last stored image of the last copied
folder is displayed on the LCD monitor.
PictBridge
You can use the USB cable to connect this camera to a printer that
supports PictBridge (sold separately) and print the stored images
directly. Movie clips and voice files cannot be printed.
Setting up the camera for connection to the printer
1. Connect the camera and printer with USB cable.
2. Once the camera is turned on, the camera automatically recognizes
the printer and is connected to it.
Easy printing
When you connect the camera to printer
in the Play back mode, you can print a
picture easily.
- Pressing the Left / Right button :
Selects a previous / next image.
- Pressing the OK button :
Currently displayed image will be
printed with the printer’s default settings.
Print
Menu
Ä If automatic connection fails, set the [USB] menu to [Printer]. (p.73)
Ä For a printer that can enable removable disk, set the [USB] menu to
[Printer].
Connecting the Camera to a Printer
Downloaded from ManualsCamera.com Manuals
097
PictBridge : Picture Selection
PictBridge : Print Setting
You can select images you want to print.
You can select the Paper Size, Print Format, Paper Type, Print Quality, Date Print, and File Name Print menus for printed pictures.
Setting the Number of Copies to Print
Images
:One Photo
One Photo
Paper
1. Press the Menu button and the
All:Auto
Photos
Layout
:Auto
PictBridge menu will display.
Type
:Auto
2. Use the Up / Down button to
Quality
:Auto
select the [Images] menu and
Back
Set
press the Right button.
3. Use the Up / Down button to select a desired sub menu and
press the OK button.
- Select [One Photo] or [All Photos]. A screen where you can
set the number of copies to print will appear as shown below.
1. Press the Menu button and the
PictBridge menu will display.
2. Use the Up / Down button to select
the desired menu, and then press the
Right button.
3. Use the Up / Down button to select
the desired sub menu value, and then
press the OK button.
Menu
0
Quantity
Set
Quantity
Card
:Auto
4x6
L :Auto
Layout
Type
2L
:Auto
Quality
Back
Set
Sub menu
Set the size of the printing
paper
Auto, PostCard, Card, 4X6, L,
2L, Letter, A4, A3
Layout
Set the number of pictures to
be printed on a sheet of paper
Auto, Full, 1, 2, 4, 8, 9, 16,
Index
Type
Set the quality of the printing
paper
Auto, Plain, Photo,
Fast Photo
Quality
Set the quality of the picture
to be printed
Auto, Draft, Normal, Fine
Date
Set whether to print the date
Auto, Off, On
File Name
Set whether to print the file name
Auto, Off, On
Set
[When [All Photos] is selected]
- Press the Up / Down button to select the number of prints.
- When [One Photo] is selected : Use the Left / Right button to
select another picture. After
selecting another picture, select
the number of prints for another
picture.
- After setting the number of prints, press the OK button to save.
- Press the Shutter button to return to the menu without setting
the number of prints.
4. Press the play mode button ( Î ) and images will be printed.
098
:One Photo
Auto
:Auto
Postcard
Paper
Paper
1
[When [One Photo] is selected]
Function
Images
Downloaded from ManualsCamera.com Manuals
Ä Some menu options are not supported on all printers.
If not supported, the menus are still displayed on the LCD, but are not
selectable.
PictBridge : Reset
Important notes
Initialises user-changed configurations.
Be sure to observe the following precautions!
1. Use the Up / Down button to select
the [Reset] menu tab. And then press
the Right button.
2. Use the Up / Down button to select
the desired sub menu, and then press
the OK button.
Date
:Auto
File Name
Reset
:Auto
No
No
Yes
Back
Set
If [No] is selected : Settings will not be reset.
If [Yes] is selected : All print and image settings will be reset.
Ä Default print setting varies depending on the printer manufacturer.
For your printer’s default setting, refer to the user’s guide that
came with your printer.
This unit contains precision electronic components. Do not
use or store this unit in the following locations.
- Areas exposed to severe changes in temperature and humidity.
- Areas exposed to dust and dirt.
- Areas exposed to direct sunlight or the inside of a vehicle in hot
weather.
- Environments where there is high magnetism or excessive vibration.
- Areas with high explosives or highly flammable materials.
Do not leave this camera in places subject to dust, chemicals
(like naphthalene and mothballs), high temperature and high
humidity. Keep this camera with silica gel in a hermetically
sealed box when not planning to use the camera for a long
period of time.
Sand can be particularly troublesome to cameras.
- Do not let sand get inside the camera when using it on beaches,
coastal dunes, or other areas where there is lots of sand.
- Doing so may result in failure or may permanently render the
camera unusable.
Handling the camera
- Never drop the camera or subject it to severe shocks or vibrations.
- Protect the large size LCD monitor from an impact. When this
camera is not used, keep it in the camera case.
- Avoid obstructing the lens or the flash when you capture an image.
- This camera is not waterproof.
To avoid dangerous electrical shocks, never hold or operate the
camera with wet hands.
- If you use this camera in wet places, such as beach or pool, do
not let water or sand get inside the camera. Doing so may result
in failure or may permanently damage the unit.
Downloaded from ManualsCamera.com Manuals
099
Important notes
Extremes in temperature may cause problems.
- If the camera is transferred from a cold to a warm and humid
environment, condensation can form on the delicate electronic
circuitry. If this occurs, turn the camera off and wait for at least
1 hour until all moisture is dispersed. Moisture built up can also
occur on the memory card. If this happens, turn off the
camera and remove the memory card. Wait until the moisture
has dispersed.
Caution on Using the Lens
- If the lens is subjected to direct sunlight, it could result in the
discoloration and deterioration of the image sensor.
- Take care not to get fingerprints or foreign substances on the
surface of the lens.
If the digital camera is not used for a long period, an electric
discharge can occur. It is a good idea to remove the battery
and the memory card if you do not intend using the camera
for an extended period of time.
If the camera is exposed to an electronic interference, it will
turn itself off to protect the memory card.
Camera Maintenance
- Use a soft brush (available from photo stores) to gently clean the
lens and LCD assemblies. If this does not work, lens-cleaning
paper with lens cleaning fluid can be used.
Clean the camera body with a soft cloth. Do not allow this
camera to come into contact with solvent materials such as
benzol, insecticide, thinners etc. This may damage the body shell
of the camera and also affect its performance. Rough handling
can damage the LCD monitor. Take care to avoid
damage and keep the camera in its protective carry case at all
times when not in use.
Do not attempt to disassemble or modify the camera.
Under certain conditions, static electricity can cause the flash
unit to fire. This is not harmful to the camera and is not a
malfunction.
When images are uploaded or downloaded, the data transfer
may be affected by static electricity. In this case, disconnect
and re-connect the USB cable before trying the transfer again.
Before an important event or going on a trip, you should
check the camera condition.
- Take a picture for testing the camera condition and prepare extra battery.
- Samsung cannot be held responsible for camera malfunctions.
If the digital camera is not used for a long period, the date and
time may adopt the default settings by automatical battery
discharged. In this case, reset the date and time correctly before
the recording.
100
Downloaded from ManualsCamera.com Manuals
Warning indicator
There are several warnings that may appear on the LCD display.
[Card Error]
Memory card error
Turn off the camera power and turn it on again
Insert the memory card again
Insert and format the memory card (p.68)
[Card Locked]
The memory card is locked
SD/SDHC memory card : Slide the write protect switch to the
top of the memory card
[Memory Full]
The memory card or internal memory is full.
Insert new memory card.
Delete the unnecessary image files
[File Error]
File error
Delete the file.
Memory card error
Contact a camera service center.
[Low Battery]
There is low battery capacity
Insert a charged battery or recharge the battery.
[Power turns off automatically to prevent malfunction due to
high temperatures. Wait a minute before use.]
The power is automatically tuned off at a high temperature above
60˚C.
If the camera is turned off because of the temperature
increase in the product, cool off the heat and turn it on again.
If the camera is turned off because of high temperature in the
surrounding air, turn on the power at less warm area.
[No Image File]
There are no images stored on the memory
Take images
Insert a memory card that is holding some images
Downloaded from ManualsCamera.com Manuals
101
Before contacting a service center
Please check the following
The camera doesn’t switch on
There is low battery capacity
Insert a charged battery or recharge the battery. (p.16)
Battery is inserted incorrectly with the polarities reversed
Insert the battery according to the polarity marks (+, -).
The camera power ceases while in use
The battery is exhausted
Insert a charged battery or recharge the battery.
The Camera is turned off automatically
Turn on the camera power again.
Operation has ceased in a low temperature outside of the camera
usage temperature range
Make the camera and battery warm by placing them in your
pocket, etc. and then immediately before shooting, place the
battery in the camera and then shoot.
Camera does not take images when pressing the Shutter button
There is insufficient memory capacity
Delete unnecessary image files
The memory card has not been formatted
Format the memory card (p.68)
The memory card is exhausted
Insert a new memory card
The memory card is locked
Refer to [Card Locked] error message
The camera's power is off
Turn the camera power on
The battery is exhausted
Insert a charged battery or recharge the battery (p.16)
Battery is inserted incorrectly with the polarities reversed.
Insert the battery according to the polarity marks (+, -)
The camera suddenly stops working while in use
The camera stopped due to a malfunction
Remove /re-insert battery and switch the camera on
The images are unclear
A picture was taken of the subject without setting an appropriate
macro mode
Select an appropriate macro mode to take a clear image.
Taking a picture beyond the flash range
Take a picture within the flash range
The lens is smudged or dirty
Clean the lens
102
Downloaded from ManualsCamera.com Manuals
Before contacting a service center
The flash does not fire
Flash off mode has been selected
Dis-engage flash off mode
The camera mode can't use the flash
Refer to the FLASH instruction (p.41)
Incorrect date and time is displayed
The date and time have been set incorrectly or the camera has
adopted the default settings
Reset the date and time correctly
The camera buttons do not operate
Camera malfunction
Remove/re-insert battery and switch the camera on
A card error has occurred while the memory card is in the camera.
Incorrect memory card format
Re-format the memory card
The images don't play back
Incorrect file name (Violation of DCF format)
Do not change the image file name
Color of image is different to the original scene
White balance or effect setting is incorrect
Select appropriate White balance and effect
Images are too bright
Exposure is excessive
Reset exposure compensation
Downloaded from ManualsCamera.com Manuals
No image on external monitor
The external monitor has not been connected properly with the
camera
Check the connection cables
There are incorrect files on the memory card
Insert a memory card that has correct files
When using the PC’s explorer, the [Removable Disk] file does not show
Cable connection is incorrect
Check the connection
The camera is off
Turn the camera on
The operating system is not Windows XP, Vista, 7 / Mac OS 10.4.
Alternatively the PC does not support USB
Install Windows XP, Vista, 7 / Mac OS 10.4 to PC that
supports USB
A part of the LCD screen does not occasionally turn on or a spot appears.
Although the LCD screen is manufactured with high precision
technology, the precision pixels are not occasionally lighted or the
red, white and blue spots appear.
ĺ This phenomenon does not affect the quality of the recorded
image and it is not a malfunction.
A vertical line appears on the LCD screen when taking a picture
of a bright object.
If a subject is exposing bright lights, a gray, black, red or purple
vertical line may appear.
ĺ This is a phenomenon called smear and it does not affect the
quality of the recorded image. This is not a malfunction.
103
Specifications
Image Sensor
- Type : 1/2.33" CCD
- Effective Pixel : Approx. 13.8 Mega-pixel
- Total Pixel : Approx. 14.5 Mega-pixel
Lens
- Focal Length : Schneider-Kreuznach Lens
f = 4.6 ~ 119.6mm (35mm film
equivalent : 26 ~ 676mm), 26X Zoom
- F No. : F2.8(W) ~ F5.0(T)
- Digital Zoom : · Still Image mode :1.0X ~ 5.0X
· Play mode : 1.0X ~ 13.4X
(depends on image size)
Image Stabilization - Dual IS (OIS + DIS)
Ä OIS (Optical Image Stabilization),
DIS (Digital Image Stabilization)
LCD Monitor
- 3.0"(7.62cm) color TFT LCD (230,000 dots)
Viewfinder (EVF) : 0.24" color TFT LCD
(230,000 dot)
Focusing
- Type : TTL auto focus
(Multi AF, Center AF, Selection AF,
Tracking AF, Face Detection AF)
- Range
Focus
range
Shutter
104
Normal
Auto Macro
Macro
Wide
Wide
Wide
80cm ~ Infinity
10cm ~ Infinity
10cm ~ 80cm
Tele
Tele
Tele
170cm ~ Infinity
170cm ~ Infinity
80cm ~ 150cm
Super Macro Manual Focus
1cm ~ 10cm
10cm ~
Infinity
- Program : 1/2 ~ 1/2,000 sec.,
A·S/Manual/User : 16 ~ 1/2,000 sec.
(Continuous, AEB : 1/4 ~ 1/2,000 sec.)
Downloaded from ManualsCamera.com Manuals
Exposure
- Control : Program AE
- Metering : Multi, Spot, Center-weighted,
Face Detection AE
- Compensation : ±2EV (1/3EV steps)
- ISO : Auto, 80, 100, 200, 400, 800, 1600, 3200,
6400 (Up to 3M Size)
Flash
- Modes : Auto, Auto & Red-eye reduction, Fill-in
flash, Slow sync, Flash off, Red Eye Fix
- Range : Wide: 0.3 ~ 6.0 m, Tele: 0.8 ~3.0 m
(ISO Auto)
- Recharging Time : Approx. 5 sec
Sharpness
- Soft+, Soft, Normal, Vivid, Vivid+
White Balance
Auto, Daylight, Cloudy, Fluorescent_H,
Fluorescent_L, Tungsten, Custom
Voice Recording - Voice Recording (maximum 5 hours at once)
- Voice Memo in Still Image (max. 10 sec.)
Date Imprinting
- Date, Date & Time, Off (user selectable)
Shooting
- Still Image
·Mode : Smart Auto, Program, A·S, Manual, Night,
Beauty Shot, Scene, User1, User2
·Scene : Frame Guide, Portrait, Children,
Landscape, Close Up, Text, Sunset, Dawn,
Backlight, Fireworks, Beach & Snow
·Smart Auto : Portrait, Night Portrait, Night, Backlight
Portrait, Backlight, Landscape, White,
Macro, Macro Text, Tripod, Action,
Sunset, Blue Sky, Natural Green,
Macro Color, Macro Portrait
Specifications
·Shooting : Single, Continuous, High Speed,
Motion Capture, AEB
·Self-timer : 10 sec., 2 sec., Double
- Movie Clip
·With Audio or without Audio
(user selectable, recording time : max 20min)
·Size : 1280x720HQ(30FPS & 15FPS),
640x480(30FPS & 15FPS),
320x240(60FPS & 30FPS & 15FPS)
·Movie Editing (Embedded):
Pause during recording, Still Image Capture,
Time Trimming
Storage
4288x
3216
- Media
·Internal memory : About 8MB flash memory
·External memory (Optional) :
SD card (Up to 2GB guaranteed)
SDHC card (Up to 32GB guaranteed)
- File Format
·Still Image : RAW (DNG1.1), JPEG (DCF),
EXIF 2.21, DPOF 1.1, PictBridge 1.0
·Movie Clip : MP4 (H.264(MPEG4.AVC))
·Audio : WAV
- Image Size
4288x
2848
4288x
2416
3264x
2448
2592x
1944
2048x
1536
1920x
1080
- Capacity (1GB Size)
29
-
-
-
-
-
-
33
-
-
-
-
-
-
-
116
131
154
199
311
487
716
1640
191
215
252
324
502
779
1113
2397
285
321
375
479
733
1113
1558
3116
Ä These figures are measured under Samsung standard conditions and
may vary depending on shooting conditions and camera settings.
Effect
- Effect : Photo Style Selector, Smart Filter, Image
Adjust (Sharpness, Contrast, Saturation)
- Editing : Resize, Rotate, Photo Style Selector,
Smart Filter, Image Adjust (ACB, Face
Retouch, Red Eye Fix, Brightness,
Contrast, Saturation, Add Noise)
Image Play
- Type : Single image, Thumbnails, Smart Album,
Multi slide show, Movie Clip
Ä Multi slide show : Slide show with Effect & Music
1024x
768
Downloaded from ManualsCamera.com Manuals
105
Specifications
Interface
- Digital output connector : USB 2.0
- Audio : Microphone: Stereo,
Internal Speaker: Mono
- Video output :
AV : NTSC, PAL (user selectable)
HDMI (Built-in, D-type Standard)
- DC power input connector : 4.4 V
Power Source
- Rechargeable battery : SLB-11A, 3.8V
(1130mAh)
Ä Included battery may vary depending on
sales region.
Dimensions
(WxHxD)
- 116.1×82.8×91.1mm
(excluding protrusions)
Weight
- Approx. 396g (without battery and card)
Operating
Temperature
- 0 ~ 40°C
Operating Humidity - 5 ~ 85%
Software
- Intelli-studio, Adobe Reader, Samsung RAW
Converter
Specifications are subject to change without prior notice.
All trademarks are the property of their respective owners.
106
Downloaded from ManualsCamera.com Manuals
Transferring files to your computer (for Windows)
For Windows users
Transfer files by connecting your camera to your PC.
Installing programs
Hardware and software requirements
Item
Requirements
CPU
Intel® Pentium®4 3.2 GHz or higher
AMD Athlon™ FX 2.6 GHz or higher
RAM
512 MB or more (1 GB or more recommended)
OS
Others
Using a self-assembled PC or a PC and OS that are not supported
may void your warranty.
The programs may not work properly on 64-bit Edition of Windows
XP, Vista and 7.
Intelli-studio may not perform correctly on some computers, even
when the computer meets the requirements.
If your computer does not meet the requirements, videos may not
play correctly or it may take longer to edit videos.
Install DirectX 9.0c or above before you use the program.
Windows XP/Vista/7
- USB port
- CD-ROM drive
- nVIDIA Geforce 7600GT or higher
Ati X1600 series or higher
- 1024 X 768 pixels, 16-bit color display compatible
monitor (1280 X 1024 pixels, 32-bit color display
recommended)
- Microsoft DirectX 9.0c or later
Downloaded from ManualsCamera.com Manuals
107
Transferring files to your computer (for Windows)
1. Insert the installation CD in a compatible CD-ROM drive.
2. When the setup screen is displayed, click Samsung Digital Camera
Installer to start installation.
Transferring files to your PC
Once you connect the camera to your PC, the camera will be
recognized as a removable drive.
The battery will be charged while the camera is connected to a
PC with the USB cable.
1. Connect your camera to your PC with the USB cable.
3. Select programs to install and follow the onscreen instructions.
4. Click Exit to complete the installation and restart your computer.
108
Downloaded from ManualsCamera.com Manuals
You must plug the end of the cable with the indicator light (Ÿ)
into your camera. If the cable is reversed, it may damage your
files. The manufacturer is not responsible for any loss of data.
Transferring files to your computer (for Windows)
2. Turn on the camera.
- The computer recognizes the camera automatically.
If the camera fails to connect, a pop-up window will appear.
Select Computer.
3. On your PC, select [My Computer ĺ Removable Disk ĺ DCIM
ĺ 100PHOTO].
Disconnecting the camera (for Windows XP)
The way to disconnect the USB cable for Windows Vista / 7 is
similar.
1. If the status lamp on your camera is blinking, wait until it stops.
2. Click (
screen.
) on the tool bar at the bottom right of your PC
4. Select the files you want and drag or save them to your PC.
3. Click the pop-up message.
4. Remove the USB cable.
Downloaded from ManualsCamera.com Manuals
109
Transferring files to your computer (for Windows)
Using Intelli-studio
Once you have installed the Intelli-studio on your PC, the Intelli-studio starts automatically when a camera is connected with your PC.
If the Intelli-studio does not start after you have connected the camera to your PC, double-click the Intelli-studio icon on your Windows
desktop. The Intelli-studio allows you to play back and edit files. You can also upload files to websites, such as Flickr or YouTube. For
details, select [Menu ĺ Help] in the program.
You cannot edit files directly on the camera. Transfer files to a folder on your computer before editing.
You cannot copy files in your computer to the camera.
Intelli-studio supports the following formats
- Videos: AVI(MJPEG), MP4 (Video: H.264, Audio: AAC), WMV (WMV 7/8/9)
- Photos: JPG, GIF, BMP, PNG, TIFF
110
Downloaded from ManualsCamera.com Manuals
Transferring files to your computer
(for Windows)
Icon
Description
Transferring files to your computer
(for Mac)
For Mac users
When you connect the camera to a Macintosh computer, the
computer will recognize the device automatically. You can transfer
files directly from the camera to the computer without installing any
programs.
1
Open menus
2
Display files in the selected folder
3
Change to the Photo edit mode
4
Change to the Video edit mode
5
Change to the Sharing mode (You can send files by email or
upload files to websites, such as Flickr or YouTube.)
6
Enlarge or reduce the thumbnails in the list
7
Select a file type
CPU
Power Mac G3 or later
8
View files of the selected folder on your computer
RAM
Minimum 256MB RAM
9
Show or hide files of the connected camera
10
View files of the selected folder on the camera
11
View files as thumbnails, in Smart Album, or on a map
12
Browse folders in the connected device
13
Browse folders in your computer
14
Move to the previous or next folder
15
Print files, view files on a map, store files in My Folder, or
register faces
Downloaded from ManualsCamera.com Manuals
Installing programs
Hardware and software requirements
Item
OS
Others
Requirements
Mac OS 10.4 or higher
- USB port
- CD-ROM drive
111
Transferring files to your computer (for Mac)
1. Connect your camera to a Macintosh computer with the USB
cable.
You must plug the end of the cable with the indicator light (Ÿ)
into your camera. If the cable is reversed, it may damage your
files. The manufacturer is not responsible for any loss of data.
2. Turn on the camera.
- The computer recognizes the camera automatically and a
removable disk icon will be displayed.
3. Double-click the removable disk icon.
4. Transfer photos or videos to the computer.
112
Downloaded from ManualsCamera.com Manuals
Using the Samsung RAW Converter
Using the Samsung RAW Converter, you can develop RAW files
after editing them as you like. You can also edit JPEG or TIFF files
in the same way you edit the RAW files. This software is only
compatible with Windows OS. This software is only compatible with
Windows XP and Vista.
To start the program, click [Start ĺ All Programs ĺ Samsung RAW
Converter ĺ Samsung RAW Converter]
Developing the RAW files
- Image edit functions are listed below.
Ì Menu bar
Í Image editing tools
[Exposure bias] : Compensates the exposure value.
[White balance] : Adjusts the white balance value.
[Tone]
: Adjusts the contrast.
[Color]
: Changes the color.
[Sharpness]
: Adjusts the sharpness.
[Development] : Previewing is available for the final output.
Highlight controller
Adjusts the saturation and highlights of the selected image.
Histogram
Displays the color layers of the selected image.
Preview window
Displays the selected image.
Ä Refer to the [Help] menu in Samsung RAW Converter for further
information.
You can download the Samsung RAW Converter program for
Macintosh from the Samsung website.
Downloaded from ManualsCamera.com Manuals
113
Using the Samsung RAW Converter
Correcting the exposure
The main feature of the Samsung RAW Converter is that you can
keep the best quality of the images as you make changes to the
RAW files while editing.
After making changes to the brightness or contrast, you can still
obtain the same result whichever you change first. The following
images show how you can change the exposure to the image using
the Samsung RAW Converter.
Ÿ Original image
P Mode, Aperture: f = 2.8,
Shutter Speed: 1/30 sec, ISO = 80
Ÿ Changed image after
correcting the exposure.
You can adjust the exposure by using the menu option as shown in
the picture.
You can see the changed results in the histogram windows as shown
images:
Menu option for
adjusting the
exposure.
Ÿ Original image
114
Downloaded from ManualsCamera.com Manuals
Ÿ Changed image after
correcting the exposure.
Using the Samsung RAW Converter
Handling the JPEG/TIFF files as you edit RAW files
Saving the RAW files into JPEG or TIFF format
Using the Samsung RAW Converter, you can handle the JPEG/TIFF
files as you edit RAW files. You can adjust the white balance, sharpness, and reducing the noise is also available. The following images
show how the contrast was changed on the TIFF image using the
Samsung RAW Converter.
You can save the RAW files into JPEG or TIFF format using the
Samsung RAW Converter.
You can adjust the
contrast by using
the menu option
as shown in the
picture.
Menu option for
adjusting the
contrast
Ÿ Original image
P Mode, Aperture: f = 2.8,
Shutter Speed: 1/30 sec, ISO = 80
1. Choose the image
you want to edit and
then select [File(F)] ĺ
[Development...].
2. Select the type of file as
JPEG or TIFF and then
click [Save(S)].
- The selected file is
saved as JPEG or
TIFF format.
Ÿ Changed image after
correcting the contrast.
Downloaded from ManualsCamera.com Manuals
115
FAQ
Please check the following if the USB connection malfunctions.
Case 1
USB cable is not connected or it is not the supplied USB
cable.
Connect the supplied USB cable.
Case 2
The camera is not recognized by your PC.
Sometimes, the camera may appear under [Unknown
Devices] in Device Manager.
Turn off the camera, remove the USB cable, plug in the
USB cable again, and then turn on the camera.
Case 3
There is an unexpected error during file transfer.
Turn the camera power off and on again. Transfer the file
again.
Case 4
When using the USB hub.
There may be a problem in connecting the camera to the
PC through the USB hub if the PC and the hub are not
compatible. Wherever possible, connect the camera to
the PC directly.
Case 5
116
Are other USB cables connected to the PC?
The camera may malfunction when it is connected to the
PC at the same time as another USB cable. In this case,
disconnect the other USB cable, and connect only one
USB cable to the camera.
Downloaded from ManualsCamera.com Manuals
Case 6
When I open the Device Manager (by clicking Start
(Settings) Control Panel (Performance and Maintenance) System (Hardware) Device Manager),
there are Unknown Devices or Other Devices entries
with a yellow question mark(?) beside them or devices
with an exclamation mark(!) beside them.
Right-click on the entry with the question (?) or exclamation
(!) mark and select "Remove". Restart the PC and connect
the camera again.
Case 7
In some security programs (Norton Anti Virus, V3, etc.),
the computer may not recognize the camera as a removable disk.
Stop the security programs and connect the camera to
the computer. Refer to the security program instructions
about how to temporarily disable the program.
Case 8
The camera is connected to the USB port located on
the front of the computer.
When the camera is connected to the USB port located
on the front of the computer, the computer may not
recognize the camera. Connect the camera to the USB
port located on the back of the computer.
FAQ
When the DirectX 9.0c or later is not installed
Install the DirectX 9.0c or later
1) Insert the CD provided with the camera
2) Run the windows explorer and select the [CD-ROM drive:\
DirectX] folder and click the DXSETUP.exe file.
The DirectX will be installed. Visit the Microsoft website for
downloading the DirectX.
If a PC connected with the camera stops responding while
Windows is starting.
In this case, disconnect the PC and the camera and Windows
will start. If the problem happens continuously, set the Legacy
USB Support to disable and re-start the PC. The Legacy USB
Support is in the BIOS setup menu. (The BIOS setup menu
differs from the PC manufacturers and some BIOS menus don’t
have Legacy USB Support) If you can’t change the menu by
yourself, contact to the PC manufacturer or BIOS manufacturer.
Downloaded from ManualsCamera.com Manuals
117
Correct disposal of batteries in this product
Correct disposal of batteries in this product
Applicable in the European Union and other European
countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that
the batteries in this product should not be disposed of with other
household waste at the end of their working life. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the battery contains
mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances
can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them
through your local, free battery return system.
Correct Disposal of This Product
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment) (Applicable in the European Union
and other European countries with separate collection
systems)
This marking on the product, accessories or literature indicates that
the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the
end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for details of
where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
This Class [B] digital apparatus complies with Canadian ICES-003.
Samsung Eco-mark
118
Downloaded from ManualsCamera.com Manuals
It is Samsung’s own symbol mark is used to effectively
communicate Samsung’s environmental friendly product
activities to the consumers. The mark represents
Samsung’s continuous effort on development of
environmental conscious products.
Downloaded from ManualsCamera.com Manuals
