BROWN RIDE-ON BLOWER-VAC Operator`s manual

®
ULTRA-VAC
OPERATOR’S MANUAL

Dear Customer,
Thank you for choosing WALINGA TRANSPORTATION EQUIPMENT. For your convenience, should you
require any information related to Parts, Service or Technical Engineering, please contact one of the following
Walinga Personnel in Guelph at 1-888 925-4642 unless noted*
TECHNICAL - ENGINEERING:
Anthony Vis (ext: 239) ajv@walinga.com
Ken Swaving *519 787-8227 (ext:100) cms@walinga.com
WARRANTY CLAIMS:
For Customers in Canada:
Gary Nijenhuis (ext:258) gary.nijenhuis@walinga.com
For Customers in USA:
Jonathan Medemblik * (800) 466-1197 (ext 8) jtm@walinga.com
SERVICE MANAGER:
Chris Ecclestone *(519) 787-8227 (ext:106) chris.ecclestone@walinga.com
ORIGINAL PARTS SALES:
For Customers in Canada:
Jack Lodder (ext: 224) jel@walinga.com
Parts Department Fax: (519) 824-0367
For Customers in USA:
John VanMiddlekoop * (800) 466-1197 (ext 3) jvm@walinga.com
________________________________________

























 
SERIAL NUMBER LOCATION
Always give your dealer the Serial Number of your
Walinga Ultra-Vac® when ordering parts or requesting
service or other information.
The Serial Number plates are located where
indicated. Please mark the number in the space
provided for easy reference.
Machine Serial Number
______________________________________
Blower Serial Number
______________________________________
Airlock Serial Number
______________________________________



















  
















































 
 
 
 
 























WALINGA INC.
ULTRA-VAC WARRANTY
♦ For Farm Use Only , The Seller warrants to the Buyer that the Equipment manufactured
by the Seller will be free from defect in material, workmanship and title for a period of one
(1) year from the date of delivery to the Buyer. This warranty is subject to the following:
♦ For Commercial Use, The Seller warrants to the Buyer that the Equipment manufactured
by the Seller will be free from defect in material, workmanship and title for a period of 90
days from the date of delivery to the Buyer. This warranty is subject to the following:
a)The Seller’s obligation under said warranty shall be limited to repairing or replacing (at the Seller’s option)
EXW (ExWorks) Guelph, Ontario, Canada, any part of the Equipment which, if properly installed, used and
maintained, proves defective in material or workmanship, provided that notice of any such defect and
satisfactory proof thereof is promptly given by the Buyer to the Seller;
b)All costs of the installation or transportation pursuant to this warranty are for the account of the Buyer;
c) The obligations set forth in this clause are conditional upon:
i.
Proper storage, installation (except where installation is supervised by or performed by the Seller), use,
maintenance and compliance with any applicable recommendations of the Seller; and,
ii.
The Buyer promptly notifying the Seller of any defect and obtaining authorization prior to proceeding
with repairs, and if required, promptly making the goods available for correction;
d)In respect of any Equipment or part thereof supplied hereunder which are manufactured by others, the
Seller gives no warranty whatsoever, and the warranty given by the manufacturer, if any, shall apply;
e)The Seller shall not be liable for any cargo loss, loss of equipment, use or any other incidental or
consequential damages resulting from any defective part or parts, the Seller’s liability and the Buyer’s
exclusive remedy being expressly limited to the replacement of defective parts as provided herein;
f) The warranty set out within this paragraph does not apply to:
i.
tires, accessories, and other items including the items, if any listed on the face hereof as “Buyers
Specified Items”, manufactured by others and the Buyer shall rely solely on the warranty, if any, of the
manufacturer of such tires, accessories and other items; nor
ii.
to any equipment, otherwise subject to this warranty, which shall have been repaired, modified or
altered in any way by anyone other than the Seller or one of its duly authorized service representatives.
g)With respect to used equipment sold hereunder, regardless of manufacture, the Seller makes no warranty
whatever, and all warranties, express or implied are hereby excluded. With respect to such used
equipment, the Buyer agrees to accept such used equipment on an “as is” basis.
h)
WARRANTY VOID IF NOT REGISTERED
TABLE OF CONTENTS
Serial Number Location......................................................................................................4
Warranty Registration Form & Inspection Report......................................................5
1 Introduction .....................................................................................................................8
2
Safety .............................................................................................................................9
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
General Safety .......................................................................................................10
Operating Safety ....................................................................................................11
Maintenance Safety ...............................................................................................12
Hydraulic Safety .....................................................................................................12
Storage Safety .......................................................................................................12
Transport Safety.....................................................................................................13
Tire Safety..............................................................................................................13
Safety Signs ...........................................................................................................13
Sign-Off Form.........................................................................................................14
3 Safety Decal Locations................................................................................................15
4 Operation ......................................................................................................................19
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
4.10
5
To The New Operator Or Owner ...........................................................................19
Machine Components ..........................................................................................20
Break-In................................................................................................................21
Pre-Operation Checklist .......................................................................................21
Controls................................................................................................................22
Attaching/Unhooking ............................................................................................23
Machine Preparation ............................................................................................24
Operating .............................................................................................................25
Transporting .........................................................................................................29
Storage ................................................................................................................31
Service And Maintenance..........................................................................................32
5.1.1 Fluids And Lubricants.......................................................................................32
5.1.2 Greasing...........................................................................................................32
5.2 Maintenance..............................................................................................................37
5.2.1 Belt Tension And Alignment .............................................................................37
5.2.2 Blower Oil Changing And Breather Cleaning ...................................................40
5.2.3 Airlock ..............................................................................................................42
5.2.4 Air System Relief Valves..................................................................................44
6
Trouble Shooting .......................................................................................................45
6.1
6.3
6.4
7
Mobile Transfer Unit............................................................................................45
Blower .................................................................................................................48
V-Belt Drive .........................................................................................................49
Specifications..............................................................................................................50
7.1
7.2
Mechanical ..........................................................................................................50
Bolt Torque..........................................................................................................51
7
1 INTRODUCTION
®
Congratulations on your choice of a Walinga Ultra-Vac to complement your farming operation. This
equipment has been designed and manufactured to meet the needs of the discriminating buyer for the
efficient moving of grain.
®
Safe, efficient and trouble free operation of your Ultra-Vac requires that you and anyone else who will be
operating or maintaining the machine, read and understand the Safety, Operation, Maintenance and Trouble
Shooting information contained within the Operator’s Manual.
This manual covers Models 4510D, 5614D,6614D,7614D,8614D made by Walinga Inc. Differences are
explained where appropriate.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Walinga
dealer if you need assistance, information or additional copies of the manual. Contact your dealer for a
complete listing of parts.
OPERATOR ORIENTATION - The directions left, right, front (hitch) and rear (receiver tank) , as mentioned
throughout this manual, are as seen from the driver’s seat of the towing vehicle.
2
SAFETY
SAFETY ALERT SYMBOL
This Safety Alert symbol means
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert symbol
identifies important safety
messages on the Walinga
Ultra-Vac® and in the manual.
When you see this symbol, be
alert to the possibility of
personal injury or death. Follow
the instructions in the safety
message.
Why is SAFETY important to you?
Accidents Disable and Kill
Accidents Cost
Accidents Can Be Avoided
3 Big Reasons
DANGER -
Indicates an imminently
hazardous situation that, if not
avoided, will result in death or
serious injury. This signal
word is to be limited to the most
extreme situations, typically for
machine components that, for
functional purposes, cannot be
guarded.
WARNING -
Indicates a potentially
hazardous situation, that if not
avoided, could result in death or
serious injury, and includes
hazards that are exposed when
guards are removed. It may
also be used to alert against
unsafe practices.
CAUTION -
Indicates a potentially
hazardous situation that, if not
avoided, may result in minor or
moderate injury. It may also be
used to alert against unsafe
practices.
SIGNAL WORDS:
Note the use of the signal words
DANGER, WARNING and CAUTION
with the safety messages. The
appropriate signal word for each
message has been selected using the
following guidelines:
9
SAFETY
YOU are responsible for the SAFE operation
and maintenance of your Walinga Ultra-Vac®.
YOU must ensure that you and anyone else
who is going to operate, maintain or work
around the Ultra-Vac® be familiar with the
operating and maintenance procedures and
related SAFETY information contained in this
manual. This manual will take you step-by-step
through your working day and alerts you to all
good safety practices that should be adhered to
while operating the Ultra-Vac®.
2.1
GENERAL SAFETY
1. Read and understand the
Operators Manual and all safety
signs before operating,
maintaining, adjusting or
unplugging the Ultra-Vac®.
2. Only trained competent persons
shall operate the Ultra-Vac®. An
untrained operator is not qualified
to operate the machine.
3. Have a first-aid kit available
for use should the need
arise and know how to use it.
Remember, YOU are the key to safety. Good
safety practices not only protect you but also
the people around you. Make these practices a
working part of your safety program. Be certain
that EVERYONE operating this equipment is
familiar with the recommended procedures and
follows all the safety precautions. Remember,
most accidents can be prevented. Do not risk
injury or death.
•
Ultra-Vac® owners must give operating
instructions to operators or employees
before allowing them to operate the
equipment, and at least annually thereafter.
•
The most important safety feature on this
equipment is a SAFE operator. It is the
operator’s responsibility to read and
understand ALL Safety and Operating
instructions in the manual and to follow
these. All accidents can be avoided.
•
•
Walinga feels that a person who has not
read, understood and been trained to
follow all operating and safety instructions
is not qualified to operate the equipment.
An untrained operator exposes himself and
bystanders to possible serious injury or
death.
Do not modify the equipment in any way.
Unauthorized modification may impair the
function and/or safety of the equipment and
affect the life of the machine.
Think SAFETY! Work SAFELY!
Have a fire extinguisher available
and know how to use it.
5. Do not allow riders.
6. Wear appropriate protective gear.
Remember to be an efficient operator. An
efficient operator is a very safe, cost
efficient and professional person.
•
•
4.
This list includes but is not
limited to:
- A hard hat
- Protective
shoes with slip
resistant soles
- Protective goggles
- Heavy Gloves
- Wet weather gear
- Hearing protection
7.
Before servicing, adjusting,
repairing or maintaining unit,
ensure that unit power source is
completely shut down and can
not start up.
8. Wear appropriate hearing
protection when operating for
long periods of time.
9. Know where overhead electrical
lines are located and stay away
from them. Electrocution can
occur without direct contact.
10. Review safety related items
annually with all personnel who
will be operating or maintaining
the Ultra-Vac®.
2.2 OPERATING SAFETY
1. Read and understand the Operator’s
Manual and all safety signs before using.
13. Wear appropriate ear protection when operating
or long periods of time.
2. Place all controls in neutral, stop the
engine, remove ignition key and wait for all
moving parts to stop before servicing,
adjusting, repairing or unplugging.
3. Do not operate when any guards are
damaged or removed. Install and secure
guards before starting.
4. Keep hands, feet, clothing and hair away
from all moving and/or rotating parts.
11. Do not place intake nozzle near feet when
standing on the top of grain.
5. Do not allow riders on the Ultra-Vac® or
towing vehicle during operation or
transporting.
12. Before applying pressure to the hydraulic
system, make sure all components are tight and
that steel lines, hoses and couplings are in good
condition.
6. Clear the area of all bystanders, especially
small children, before starting.
13. Review safety items with all personnel annually.
7. Stay away from overhead obstructions and
power lines when extending boom and
during operation and transporting.
Electrocution can occur without direct
contact.
8. Keep away from unloading boom when
moving, adjusting or setting. Keep others
away.
9. Clean reflectors, signs, and lights before
transporting.
10. Do not operate with leaks in the hydraulic
system.
11
2.3 MAINTENANCE SAFETY
2.4 HYDRAULIC SAFETY
1. Follow ALL the operating, maintenance and
safety information in the manual.
1. Make sure that all components in the hydraulic
system are kept in good condition and are
clean.
2. Support the machine with blocks or safety
stands when changing tires or working
beneath.
3. Follow good shop
practices:
-Keep service area
clean and dry.
-Be sure electrical
outlets and tools are
properly grounded.
-Use adequate
light for the job at hand.
4. Use only tools, jacks and hoists of sufficient
capacity for the job.
5. Before servicing, adjusting, repairing or
maintaining unit, ensure that unit power
source is completely shut down and can not
start up. Make sure all guards are in place
and properly secured when maintenance
work is completed.
6. Keep hands, feet, hair and clothing away
from all moving and/or rotating parts.
7. Clear the area of bystanders, especially
small children, when carrying out any
maintenance and repairs or making any
adjustments.
2. Replace any worn, cut, abraded, flattened or
kinked hoses or metal lines immediately.
3. Relieve pressure before working on hydraulic
system.
4. Do not attempt any makeshift repairs to the
hydraulic fittings or hoses by using tape, clamps
or cements. The hydraulic system operates
under extremely high-pressure. Such repairs
will fail suddenly and create a hazardous and
unsafe condition.
5. Wear proper hand
and eye protection
when searching for a
high-pressure
hydraulic leak. Use
a piece of wood or
cardboard as a
backstop instead of
hands to isolate and
identify a leak.
6. If injured by a concentrated high-pressure
stream of hydraulic fluid, seek medical attention
immediately. Serious infection or toxic reaction
can develop from hydraulic fluid piercing the
skin surface.
7. Before applying pressure to the system, make
sure all components are tight and that lines,
hoses and couplings are not damaged.
2.5
STORAGE SAFETY
2. Do not permit children to play on or around the
stored machine.
3. Store the unit in a dry, level area. Support the
base with planks if required.
2.6
TRANSPORT SAFETY
1. Make sure you are in compliance with all
local regulations regarding transporting
equipment on public roads and highways.
2. Make sure that all the lights and reflectors
that are required by local highway and
transport authorities are in place, are clean
and can be seen clearly by all overtaking
and oncoming traffic.
3. Attach securely to the towing vehicle using
a retainer on the drawbar pin and a safety
chain.
2.8
SAFETY SIGNS
1. Keep safety signs clean and legible at all times.
2. Replace safety signs that are missing or have
become illegible.
3. Replaced parts that displayed a safety sign
should also display the current sign.
4. Safety signs are available from your Distributor
or the factory.
How to Install Safety Signs:
4. Do not allow anyone to ride on the UltraVac® or towing vehicle during transport.
•
Be sure that the installation area is clean and
dry.
5. Reduce speed on rough roads and
surfaces.
•
Be sure temperature is above 50°F (10°C).
•
Decide on the exact position before you remove
the backing paper.
•
Remove the smallest portion of the split backing
paper.
7. Always use hazard warning flashers on
towing vehicle when transporting unless
prohibited by law.
•
Align the sign over the specified area and
carefully press the small portion with the
exposed sticky backing in place.
8. Add extra lights or use pilot vehicles when
transporting during times of limited
visibility.
•
Slowly peel back the remaining paper and
carefully smooth the remaining portion of the
sign in place.
2.7
•
Small air pockets can be pierced with a pin and
smoothed out using the piece of sign backing
paper.
6. Stay away from overhead obstructions and
power lines. Electrocution can occur
without direct contact.
TIRE SAFETY
1. Failure to follow proper procedures when
mounting a tire on a wheel or rim can
produce an explosion which may result in
serious injury or death.
2. Do not attempt to mount a tire unless you
have the proper equipment and experience
to do the job.
3. Have a qualified tire dealer or repair
service perform required tire maintenance.
How to Reorder Your Safety Signs:
1. Call you local dealer, or the factory branch
nearest you.
- HEAD OFFICE; GUELPH, ON. ,CANADA.
PHONE
(519) 824-8520
FAX
(519) 824-5651
CARMAN, MANITOBA, CANADA
PHONE
(204) 745-2951
FAX
(204) 745-6309
WAYLAND, MICHIGAN, U.S.A..
PHONE
(800) 466-1197
FAX
(616) 877-3474
DAVIDSON, SASKATCHEWAN
CANADA.
PHONE (306) 567-3031
FAX
(306) 567-3039
13
2.9 SIGN-OFF FORM
Walinga Inc. follows the general Safety Standards specified by the American Society of Agricultural Engineers
(ASAE) and the Occupational Safety and Health Administration (OSHA). Anyone who will be operating
and/or maintaining the Ultra-Vac® must read and clearly understand ALL Safety, Operating and Maintenance
information presented in this manual.
Do not operate or allow anyone else to operate this equipment until such information has been reviewed.
Annually review this information with personnel.
Make these periodic reviews of SAFETY and OPERATION a standard practice for all of your equipment. We
feel that an untrained operator is unqualified to operate this machine.
A sign-off sheet is provided for your record keeping to show that all personnel who will be working with the
equipment have read and understand the information in the Operator’s Manual and have been instructed in
the operation of the equipment.
SIGN-OFF FORM
DATE
EMPLOYEE’S SIGNATURE
EMPLOYER’S SIGNATURE
3 SAFETY DECAL LOCATIONS
The types of safety signs and locations on the equipment are shown on the following pages. Good safety
requires that you familiarize yourself with the various safety signs, the type of warning and the area, of
particular function related to that area, that requires your SAFETY AWARENESS.
• Think SAFETY! Work SAFELY!
Fig. 3-1 Right Hand Side
Decal B
Decal A
REMEMBER - If safety signs have been damaged, removed, become illegible or parts are replaced without
signs, new signs must be applied. New signs are available from your authorized dealer or factory direct.
15
3 SAFETY DECAL LOCATIONS (Cont’d)
The types of safety signs and locations on the equipment are shown on the following pages. Good safety
requires that you familiarize yourself with the various safety signs, the type of warning and the area, of
particular function related to that area, that requires your SAFETY AWARENESS.
• Think SAFETY! Work SAFELY!
Decal D
Decal C
Decal F
(See Fig 3-4)
Decal E
REMEMBER - If safety signs have been damaged, removed, become illegible or parts are replaced without
signs, new signs must be applied. New signs are available from your authorized dealer or factory direct.
3 SAFETY DECAL LOCATIONS (Cont’d)
The types of safety signs and locations on the equipment are shown on the following pages. Good safety
requires that you familiarize yourself with the various safety signs, the type of warning and the area, of
particular function related to that area, that requires your SAFETY AWARENESS.
• Think SAFETY! Work SAFELY!
Fig. 3-2 Rear
Fig. 3-3 Belt Cover
Fig. 3-4 Belt Cover Removed
for Servicing
REMEMBER - If safety signs have been damaged, removed, become illegible or parts are replaced without
signs, new signs must be applied. New signs are available from your authorized dealer or factory direct.
17
3 SAFETY DECAL LOCATIONS (Cont’d)
The types of safety signs and locations on the equipment are shown on the following pages. Good safety
requires that you familiarize yourself with the various safety signs, the type of warning and the area, of
particular function related to that area, that requires your SAFETY AWARENESS.
• Think SAFETY! Work SAFELY!
Decal G
Fig 3-5 Typical Decals on Sweep and
Suction Nozzle
Decal H
REMEMBER - If safety signs have been damaged, removed, become illegible or parts are replaced without
signs, new signs must be applied. New signs are available from your authorized dealer or factory direct.
4 OPERATION
4.1
TO THE NEW OPERATOR OR OWNER
The Walinga Ultra-Vac® is specifically
designed to vacuum up grain and move it in a
stream of pressurized air. A high capacity air
pump moves the air through the machine
creating a vacuum on the intake side and
pressure on the outlet side. Be familiar with all
operating and safety procedures before
starting.
Many features incorporated into this machine
are the result of suggestions made by
customers like you. Read this manual carefully
to learn how to operate the machine safely and
how to set it to provide maximum efficiency. By
following the operating instructions in
conjunction with a good maintenance program,
your Ultra-Vac® will provide many years of
trouble-free service.
It is the responsibility of the owner and operator
to read this manual and to train all other
operators before they start working with the
machine. Follow all safety instructions exactly.
Safety is everyone’s business. By following
recommended procedures, a safe working
environment is provided for the operator,
bystanders, and the area around the worksite.
Untrained operators are not qualified to operate
the machine.
19
4.2
MACHINE COMPONENTS
The air pump or blower is the key component in the
Ultra-Vac® and is driven by the diesel engine
through a belt drive system. The blower moves air
through the machine. On the intake side, the
blower creates a vacuum in the receiver tank and
intake lines for picking up grain. Grain is separated
from the stream of air in the receiver tank.
On the discharge side of the blower, the
pressurized air flows through the airlock where it
picks up a metered quantity of grain and moves it
out the lines to the discharge cyclone.
The airlock is rotated by the same power source
as the blower.
Fig. 4-1 Machine Components
Some items shown may be optional
4.3
BREAK-IN
Although there are no operational restrictions on
the Ultra-Vac® when used for the first time, it is
recommended that the following mechanical items
be checked:
A. After operating for 1/2 hour:
1. Retorque all the wheel bolts.
2. Retorque all other fasteners and
hardware.
3. Check that the blower turns freely.
4. Open and clean the pre-cleaner door and
tank.
5. Check that no hoses are pinched, rubbing
or being crimped. Re-align as required.
6. Check for oil leaks. Stop leaks before
continuing.
7. Check oil level in reservoirs. Add as
required.
8. Lubricate all grease fittings.
B. After operating for 5 hours and 10 hours:
1. Retorque all wheel bolts, fasteners and
hardware.
2. Check hose routing.
3. Check that blower turns freely.
4. Open and clean the pre-cleaner door and
tank.
5. Check oil level in reservoirs.
6. Then go to the normal servicing and
maintenance schedule as defined in the
Maintenance Section 5
4.4
PRE-OPERATION
CHECKLIST
Efficient and safe operation of the Walinga UltraVac® requires that each operator reads and
understands the operating procedures and all
related safety precautions outlined in this section.
A pre-operation checklist is provided for the
operator. It is important for both the personal
safety and maintaining the good mechanical
condition of the Ultra-Vac® that this checklist is
followed.
Before operating the Ultra-Vac® and each time
thereafter, the following areas should be checked
off:
1. Lubricate the machine per the schedule
outlined in Section 5 Service and
Maintenance.
2. Ensure that the machine is properly attached
to the towing vehicle. Be sure that the retainer
is installed in the drawbar pin and the safety
chain is attached.
3. Check the hydraulic system.
4. Check the oil level in the blower reservoirs.
5. Inspect all hydraulic lines, hoses, fittings and
couplers for tightness.
6. Check the tires and ensure that they are
inflated to the specified pressure.
7. Check that the blower turns freely.
8. Open and clean the pre-cleaner door and
tank.
9. Check for and remove entangled material.
10. Close and secure all guards.
21
4.5
CONTROLS
All controls on the Ultra-Vac® are located on the
rear of the machine. Review this section
carefully to familiarize yourself with the function
and movement of each control before starting.
1. Airlock Control:
The right valve controls the operation of the
airlock. Pull on the control to operate the
airlock in the forward direction and push to
operate in the reverse direction. Stop the
airlock by placing the lever in the center
neutral position.
Do not operate for long periods of time in the
reverse direction. The rotor is not designed
to operate in the reverse direction. Reverse
rotation may be used to free jammed object in
rotor only.
Watch and count the arrow revolutions on the
airlock indicator wheel to determine airlock
speed and direction.
2. Boom Rotation Control:
This spring-loaded-to-neutral-centre lever
controls the direction of the boom rotation.
Push on the lever and hold to swing the boom
to the right. (clockwise) Release to return to
centered position to stop rotation. Pull and
hold to swing to the left. (counter-clockwise)
3. Boom Lift Control:
The valve controls the boom position. Push on
the lever to raise the boom and pull to lower.
Place in the center position for no boom
movement.
Fig. 4-2 Controls
5. Flow Divider:
A flow divider in the airlock circuit is used to
control the airlock speed. Normal operation
should start at a setting of 5. Move in small
increments toward 0 to decrease the speed.
Move toward 10 to increase the speed. Watch
and count the arrow revolutions on the airlock
wheel to determine the speed.
Use Table 1 as a guide to setting the airlock
speed.
Experiment a little to determine the best
setting.
Airlock Speed vs Grain (rpm)
4510D 5614D 6614D
7614D
IMPORTANT
Do not attempt to raise boom while airlock is
in operation.
4. Boom Lock Valve:
This valve is located in the boom lift circuit to
control the oil flowing through the lines. Move
the lever parallel to the line to open the valve
when positioning the boom. Move at right
angles to the line to stop oil flow and maintain
boom position.
Grain
50-70
50-70
55-70
65-70
Barley
50-70
50-70
55-70
65-70
Wheat
50-70
50-70
55-70
65-70
Corn
50-70
50-70
55-70
65-70
Table 1
4.6 ATTACHING/UNHOOKING
The Ultra-Vac® should always be parked on a
level, dry area that is free of debris and foreign
objects.
Follow this procedure when attaching.
1. Clear the area of bystanders and remove
foreign objects from the machine and working
area.
2. Make sure there is enough room to back the
towing vehicle up to the hitch point.
3. Start the towing vehicle and slowly back it up
to the hitch point.
Fig. 4-3 Unhooked
4. Stop the towing vehicle, place all controls in
neutral, set park brake and remove ignition
key before dismounting.
5. Use the tongue jack to raise or lower the UltraVac to align to towing vehicle.
6. Install a safety chain between the towing
vehicle drawbar and the machine tongue.
7. Raise the tongue jack and rotate it 90° to
place in its stowed position.
8. When unhooking from the towing vehicle,
reverse the above procedure.
23
4.7 MACHINE PREPARATION
Before the Ultra-Vac® can be used it must be set
up and prepared for operation.
When setting-up, follow this procedure:
1. Clear the area of bystanders, especially small
children.
2. Be sure you select a spot that has sufficient
space to locate the machine and enough
clearance to allow trucks to drive under the
discharge cyclone.
3. Position the machine approximately 12 feet (4
meters) from the storage facility.
Fig. 4-4 12ft Bin Clearance
4. Place all other controls in neutral and set park
brake before dismounting.
5. Remove the plug from the receiver tank inlet.
6
Remove the intake nozzle from its storage
position on the frame and install on the end of
the steel flex tube. Secure in position using
the bolts on the coupler.
7
Connect the 12 foot steel flex tube to the inlet.
Tighten the bolts on the coupler to lock the
tube securely in place.
Fig. 4-5 Intake Installation
8. Starting Engine:
a. Place all controls (including Clutch) in their
neutral or off position and lock-off the
hydraulic oil supply valve to the boom-lift
cylinder.
b. Start the engine using the procedure
outlined in the engine manufacturers
handbook. Run the engine at low idle.
c.
Fig. 4-6 Flex Tube Installation
Slowly engage the PTO/Clutch control to
the drive system
9. Use the boom lift control to raise the boom out
of the boom saddle. Use the boom rotation
control to swing boom around until it is in a
working position that will allow a truck to drive
under the discharge cyclone.
10. Reverse the above procedure when finished
working and placing into the storage or
transport configuration.
Stay away from overhead electrical wires to
prevent electrocution.
Fig. 4-7
Positioned
4.8 OPERATING
When operating the Ultra-Vac®, follow this
procedure:
1. Clear the area of bystanders, especially small
children, before starting.
2. Review and follow the Pre-Operation Checklist
(See Section 4.4).
3. Be sure the machine is correctly positioned
and set-up per Section 4.7. The trucks should
have ample space and clearance to drive
under the discharge cyclone.
Fig. 4-8
Working Position
4. Place chocks in front and behind unit tires to
prevent moving.
5. Starting Machine:
a. Place all controls (including Clutch) in their
neutral or off position and lock-off the
hydraulic oil supply valve to the boom-lift
cylinder.
b. Start the engine using the procedure
outlined in the engine manufacturers
handbook. Run the engine at low idle.
c.
Fig. 4-9
PTO/Clutch Control
Slowly engage the PTO/Clutch control to
the drive system. (Fig. 4-9 )
d. Preliminary airlock setting:
i
Engage airlock hydraulics.
ii.
Check arrow on indicator to be sure
airlock is turning in the correct
direction.
iii. Increase engine speed to 1500 RPM
and use the flow divider to set the
airlock speed to approximately 60
RPM.
Fig. 4-10 Airlock Flow Divider
iv. Return engine speed to low idle and
stop airlock.
Fig. 4-11 Airlock Flow Divider
25
4.8
OPERATING (cont'd)
Airlock Speed vs Grain (rpm)
4510D 5614D 6614D
7614D
5. Starting Machine (cont’d)
e.
Slowly engage the PTO/Clutch control to
the drive system. (Fig. 4-8 )
f.
Increase engine speed until it is at
3/4 throttle.
g. Engage airlock hydraulics. Be sure airlock
is turning in the forward direction.
Grain
50-70
50-70
55-70
65-70
Barley
50-70
50-70
55-70
65-70
Wheat
50-70
50-70
55-70
65-70
Corn
50-70
50-70
55-70
65-70
Table 2
h. Operate machine at 3/4 speed for 10
minutes to warm system before putting
under full load.
IMPORTANT
It is important to warm the hydraulic
system and blower reservoirs before going
to rated speed. The blower will not "warm
up" unless product is being conveyed.
i. Open airslide approximately 2 inches and
insert into the grain. Operate at this
setting until the machine is warm (10
minutes).
j.
After warm up period, bring machine to
capacity.
Fig. 4-12
Open Airslide
i. Increase engine speed to rated RPM.
ii. Close airslide until the intake line
starts to pulsate. Open slightly to stop
pulsing.
iii. Watch glass door in receiver tank to
determine how the product is moving
through the machine. The glass can
be covered but it should not be
stationary. If more product is being
drawn in than discharged, the product
will lay stationary against the window.
6.
Airlock Speed:
Refer to the Table 2 as a guide
for setting the airlock speed. Use the
flow control to adjust the speed and
count the revolutions using the arrow on
the wheel. It may be necessary to
experiment to determine the best
speed.
Fig. 4-13 Sight Glass in Receiver Tank
7. Maximum Capacity:
a. The nozzle should be placed into the grain
with the inlet below the surface of the
grain but not below the airslide. It is
recommended that some air be allowed to
enter with the grain to obtain the best
capacity.
b. Open the airslide about 2 inches to start.
Close the airslide until the machine starts
to pulsate. Then open it until the pulsing
stops. This will give a balanced grain and
airflow condition.
c.
Fig. 4-14 Nozzle Positioned
Watch the amount of grain on the window
in the receiver tank. Keep the window full
yet keep the product moving.
There are several ways to control the
amount of grain on the window:
i.
Decrease the amount of grain entering
nozzle.
ii.
Increase airflow by opening airslide.
iii. Increase airlock speed.
iv. Decrease airlock speed.
The airlock acts as a seal between the
vacuum and pressure sides of the circuit.
Increasing the airlock speed normally will
remove product from the receiver faster.
Refer to Airlock Speed Chart as a guide.
8. Use the regular nozzle until there is
approximately 12 inches of grain left in the bin.
Then switch to the clean-up nozzle to pick up
the last of the grain.
Fig. 4-15 Sight Glass
9. When using the clean-up nozzle, it is
recommended that the rubber intake hose be
installed to allow you to move around to pick
up the grain from the corners more easily.
10. Stopping Machine:
a. Remove the intake nozzle from the grain.
b. Allow the unit to run until the grain has
stopped coming out the cyclone.
c.
Stop the airlock.
d. Slow the engine speed down to low idle.
27
4.8
OPERATING (cont'd)
10. Stopping Machine Cont’d:
e.
Disengage hydraulic circuit and slowly
disengage PTO clutch.
f.
Stop engine by turning ignition key to OFF
and REMOVE.
11. Pre-Cleaner:
The machine is designed with a cleaner
between the blower and the receiver tank to
remove dust and dirt from the air stream.
Clean every 1000 bushels during normal
operating conditions. Clean or empty precleaner canister more frequently in dirty or
dusty conditions.
Fig. 4-16
Pre-Cleaner Canister
12. Specialty Crops:
Operating:
When handling specialty products such as
sunflower seeds, lentils etc, it is recommended
that the PTO speed be reduced by 1/4 to ½
rated RPM. This gives a gentler action through
the machine.
Run the airlock at a slower speed to allow
More time for the product to fill the pockets.
13. Operating Hints:
a. Try to keep the hoses full as possible to
have maximum capacity.
Fig. 4-17 Inside Bin
b. Pull the intake nozzle out of the grain and
empty the machine before changing
trucks.
c.
Maximum efficiency is obtained with large
airflow lines. Use the smaller rubber lines
only for final clean-up.
e. Route the lines to minimize bends and
corners. If a corner is necessary, use a
large radius elbow.
f.
Keep lines as short as possible to
minimize friction loses.
g. If long distance moving is required, push
the grain rather than pull.
h. If long distance moving is required, use
solid metal tubing whenever and wherever
possible.
Fig. 4-18 Loading Truck
4.8
OPERATING (cont'd)
i. If the airlock becomes jammed, use the
hydraulics to reverse the direction of airlock
rotation and clear the obstruction.
j. When on top of grain, do not push
the nozzle into the pile next to the feet.
The suction will pull the nozzle and
the operator into the pile. If the pile is deep
enough, the operator can be submerged
under the grain and suffocated.
4.9 TRANSPORTING
29
4.9
TRANSPORTING
Walinga Ultra-Vacs® are designed to be easily
and conveniently moved from location to location.
When transporting, follow this procedure:
1. Be sure all bystanders are clear of the
machine.
2. Be sure that the Ultra-Vac® is hitched
positively to the towing vehicle. Always use a
retainer in the drawbar pin and a safety chain
between the machine and the towing vehicle.
3. Keep to the right and yield the right-of-way to
allow faster traffic to pass. Drive on the road
shoulder, if permitted by law.
4. Make sure the the lights and reflectors that are
required by the local highway and transport
authorities are in place, are clean and can be
seen clearly by all overtaking and oncoming
traffic.
4.9
TRANSPORTING (cont’d)
5. Lower cyclone, and swing around into the
boom saddle.
6. Do not allow riders on the machine or towing
vehicle.
7. During periods of limited visibility, use pilot
vehicles or add extra lights to the Ultra-Vac®.
8. Always use hazard flashers on the towing
vehicle when transporting unless prohibited by
law.
9. Secure all components and accessories
before transporting.
10. Stay away from overhead power lines
Electrocution can occur without direct contact.
4.10 STORAGE
At the end of the season, the machine should be
thoroughly inspected and prepared for storage.
Repair or replace any worn or damaged
components to prevent any unnecessary down
time at the start of next season.
When storing, follow this procedure:
1. Wash the entire machine thoroughly using a
water hose or pressure washer to remove all
dirt, mud, debris or residue.
2. Retract and secure all accessories and
components.
3. Lubricate all grease points. Make sure all
grease cavities have been filled with grease to
remove any water residue from the washing.
4. Inspect all hydraulic hoses, fittings, lines,
couplers and valves. Tighten any loose
fittings. Replace any hose that is badly cut,
nicked or abraded or is separating from the
crimped end of the fitting.
5. Check the oil level in the blower reservoirs.
Bring to the recommended level.
6. Install the plugs into the receiver tank inlet.
7. Empty pre-cleaner tank.
8. Touch up all paint nicks and scratches to
prevent rusting.
9. All hoses should be stored inside or under a
shelter.
10. Move the machine to its storage position.
Storage:
To prepare the machine for storage,
remove the inlet pipe and spray the blower
clean with water, then run at idle for 5
minutes to dry the inside of the tank,
piping, blower and airlock. This will
prevent any residue from caking on the
internal components.
11. Select an area that is dry, level and free of
debris.
12. Place planks under the jack for added support.
13. Unhook the machine from the towing vehicle
(Refer to Section 4.6).
31
5
SERVICE AND
MAINTENANCE
5.1
5.1.1
SERVICE
FLUIDS AND LUBRICANTS
1. Grease:
Use an SAE multi-purpose high temperature
grease with extreme pressure (EP)
characteristics. Also acceptable is an SAE
multi-purpose lithium based grease.
2. Blower Oil:
Use Walinga Blower oil (part# 98-13813-6)
Imperial 80W 140 GX Extra gear oil
or equivalent.
Reservoir Capacity: +1 1/4 quarts











3. Storing Lubricants:
Your unit can operate at top efficiency only if
clean lubricants are used. Use clean
containers to handle all lubricants. Store them
in an area protected from dust, moisture and
other contaminants.
5.1.2
GREASING
Refer to Section 5.1.1 for recommended grease.
Use the Service Record checklist provided to
keep a record of all scheduled servicing.
1. Use a hand-held grease gun for all greasing.
2. Wipe grease fitting with a clean cloth before
greasing, to avoid injecting dirt and grit.
3. Replace and repair broken fittings
immediately.
4. If fittings will not take grease, remove and
clean thoroughly. Also clean lubricant
passageway. Replace fitting if necessary.
5.1.3
SERVICING INTERVALS
8 Hours or Daily
1. Check the tension and alignment of the input
drive belts. (fig. 5-3)
See Maintenance Section.
2. Check the oil level in the blower reservoirs (2
locations).
Fig. 5-1 Blower End Views
Fig. 5-2 Gear End
40 Hours
1. Lubricate the exposed rod end of the boom lift
cylinder with "never seize" (1 location).
2. Lubricate the splined input shaft and bearings
(2 locations)
Fig 5-3 Drive End
33
5.1.3
SERVICING INTERVALS (cont’d)
20 Hours
1. Check the condition of the wear liner in the
discharge cyclone.(fig. 5-4)
Replace as required.
Fig. 5-4 Discharge Cyclone
& Boom Cylinder
40 Hours
1. Lubricate the exposed rod end of the boom lift
cylinder (fig. 5-4) with “never seize” (1
location)
Fig. 5-5 Boom Swivel
2. Lubricate the boom swivel.
5.1.3
SERVICING INTERVALS (cont’d)
100 Hours or Annually
1. Change the oil in the blower reservoirs (2
reservoirs).
Fig. 5-6 Blower Reservoirs
Fig 5-7 Vacuum Relief Valve
2. Check the function of the vacuum and
pressure relief valves.
Fig 5-8 Pressure Relief Valve
3. Check condition of air line seals.
Fig. 5-9 Air Line Seal at Flex Hose
35
5.1.4
SERVICE RECORD
See Lubrication and Maintenance sections for details of service. Copy this page to continue record.
ACTION CODE:
L LUBRICATE
Hours
Serviced By
Maintenance
8 Hours or Daily
Tens & align input drive belts
Oil level in blower reservoirs
20 Hours
Wear liner in discharge cyclone
L
L
L
L
40 Hours
Rod end of boom lift cylinder
Splined Input Shaft & Bearings
Boom Swivel
Blower outboard bearing
100 Hours or Annually
C Oil in Blower Reservoirs (2)
Vacuum & Press Relief Valves
Air Line Seals
C
CHANGE
CHECK
5.2 MAINTENANCE
Follow this procedure when checking and
adjusting belt tension and pulley alignment.
By following a careful service and maintenance
program for your machine, you will enjoy many
years of trouble-free service.
1. Clear the area of bystanders, especially small
children.
5.2.1 BELT TENSION AND
ALIGNMENT
Rotational power from the engine is transmitted to
the blower through the belt drive. To obtain
efficient transmission of power and good belt life,
the belts must be properly tensioned and the
pulleys aligned.
Belts that are too tight will stretch and wear quickly
or overload the bearings on the input shaft or
blower; Belts that are too loose will not transmit
the required, power and will slip, overheat and
wear quickly. Pulleys that are not aligned will result
In rapid belt wear.
MODEL
BELT TENSION
2.
Place all controls in neutral, stop the engine,
remove ignition key and wait for all moving
parts to stop before dismounting.
3.
Unlatch and remove the belt cover. Lay to the
side.
DEFLECTION
New
Belt
Old Belt
15
14 lbs
(6.3kg)
½ in (12.7mm)
15
14 lbs
(6.3kg)
½ in (12.7mm)
14
12 lbs
(5.4kg)
3/8 in (9.5mm)
14
12 lbs
(5.4kg)
3/8 in (9.5mm)
4510D
5614D
6614D
7614D
Table 4 Belt Deflection
37
5.2.1 BELT TENSION AND
ALIGNMENT (cont'd)
4. Use a 10 pound weight to determine the belt
deflection in a static condition.
5.
Adjusting Tension:
a. Loosen the jam nuts on the adjusting
bolts. Loosen bearing bolts slightly.
Fig. 5-10 Deflection
b. Turn the adjusting bolt to set the tension.
Turn both bolts the same amount to
maintain pulley alignment.
c.
Check the tension again. Over
tightening will cause belt stretching and
overload the bearing. Belts that
are too loose will slip, tear and
wear rapidly. Check alignment,
see next section.
d. Tighten jam nuts. Tighten bearing
bolts.
e. Install and secure belt covers.
Fig. 5-11 Tension Adjustment
6. Pulley Alignment:
a. Lay a straight-edge across the faces of the
two pulleys.
e.
b. If the gap between the pulley and the
straight-edge exceeds 1/16 inch (1.5 mm),
the pulleys must be realigned.
f.
c.
Review the types of alignment before
starting.
Use the bearing housing assembly anchor
bolts to align the blower pulley. Tighten
anchor bolts to their specified torque.
Set the belt tension.
g. Install and latch belt cover.
7.
Be sure all guards are installed and secure
before resuming work.
d. Use the adjusting bolts on the input shaft
to align the input pulley. Tighten jam nuts
when alignment has been completed.
Fig. 5-12 Misalignment
39
5.2.2
BLOWER OIL CHANGING AND
BREATHER CLEANING
The gears that drive and time the blower lobes run
in an oil bath for lubrication. Maintaining the
correct level in the reservoirs and changing every
100 hours will insure proper lubrication.
When maintaining the blower, follow this
procedure:
1. Clear the area of bystanders, especially small
children.
Fig. 5-13 Blower
2. Place all controls in neutral, stop engine and
remove ignition key or disconnect PTO
driveline before starting.
3. Unlatch and remove the belt drive covers.
4. Checking Oil Level:
a. Remove the level plug in each reservoir or
check the sight glass.
IMPORTANT
Check the level only when the oil is cold
and the machine is level.
b. Oil in the reservoir should just fill the
threads of the level plug hole.
c.
Add oil if low or allow the reservoir to drain
if overfilled.
IMPORTANT
It is necessary to maintain the recommended oil
level in the reservoir. A low level causes heating
from lack of lubrication and rapid gear and bearing
wear. Too much oil causes heating from oil
churning and can cause seal and breather leaks.
d. Install and tighten the level plug.
e. Install and secure the belt covers.
Fig. 5-14 Blower
5.2.2 BLOWER OIL CHANGING AND
BREATHER CLEANING (cont'd)
5. Changing Oil:
a. Place a collection pan or pail under each
drain plug.
b. Remove each drain plug.
c.
Flush each case and allow several
minutes to drain.
d. Dispose of the oil in an approved manner.
Do not contaminate the worksite with used
oil.
e. Install and tighten the drain plugs.
f.
Remove fill and level plugs.
Fig. 5-15 Blower
IMPORTANT
Condensation forms and collects inside
the reservoirs during machine operation.
Changing oil removes this water and
prevents it from damaging the gears and
bearings.
g.
Install and tighten the level and fill plugs.
h. Install and secure the belt drive covers.
6. Cleaning Breathers:
a. Remove breathers and blow out with an
air hose.
b. If dirt has caked up in the breather, soak in
good solvent and then blow out. It may be
necessary to use a probe to loosen the
dirt.
c.
Install and tighten the breather.
Fig. 5-16 Breathers
d. Install and secure the belt drive covers.
e. Clean vents in end plates located under
the blower on either side of the drain plug.
41
5.2.3
AIRLOCK
The airlock acts as a seal between the vacuum
and pressure sides of the machine and is located
at the bottom of the receiver tank. As the rotor
turns, a pocket is filled with material when it points
upward. As the pocket rotates, it is moved to the
bottom and is moved into the pressure side of the
system. The grain is picked up by the stream of
pressurized air and moved out the discharge
piping.
Efficient operation of the airlock requires a close fit
between the tips of the rotor and the case to
maintain a seal between vacuum and pressure
sides.
When checking or maintaining the airlock, follow
this procedure:
1. Clear the area of bystanders, especially small
children.
2. Disconnect the hydraulic lines from the tractor
to prevent airlock operation.
Fig. 5-17 Airlock Typical Location
Below Receiver Tank
5.2.3
AIRLOCK (cont'd)
3. Checking Tip Clearance:
a. Checking the airlock can be done through
the inspection door.
b. Use a feeler gauge to check the clearance
between the tip and the case. Inspect
each tip over its entire width.
c.
The clearance of the tips must be
maintained at 0.004 to 0.006* inches at all
times. Adjust or replace tips as required
to insure system sealing. (*614 units .007
to .009).
d. Replace any tips that are bent, chipped or
broken.
e. File the ends of each replacement blade
so there is approximately 0.006 inches of
clearance between the ends and the
housing.
f.
g. Rotate airlock rotor slightly to set the
clearance between the blade and the
case. Be sure to set it at 0.004 inches of
clearance. Use a feeler gauge.
h. Tighten the center bolt first. Then the
others.
i.
Rotate the airlock and listen if it touches
the housing anywhere. A slight touch is
alright.
j.
Repeat mounting procedure with the other
blades.
k.
Turn the rotor after each blade is installed
to be sure it does not contact the case.
l.
Mount the new wiper blade. Be sure the
wiper contacts each tip slightly as the
airlock turns.
NOTE
Blades are reversible if not
excessively damaged.
Mount the blades to their respective vane
and tighten bolts finger tight.
m. Install and secure the airlock.
Fig.
5-18 Tip Clearance
4. Wiper Blade:
A wiper blade is located at the top of the
airlock to clean the tips as the airlock turns.
To check the wiper blade, follow this
procedure:
a. Open the access door on receiver tank.
n. Connect hydraulic lines and close access
door.
o. Pour 1/2 gallon Varsol in to the airlock.
Run the airlock at operating speed.
p. Clean thoroughly.
b. Reach into the top of the airlock and feel
the condition of the wiper blade.
c.
Replace it if it is damaged in any way.
5. Blade Replacement:
a. Disconnect hydraulic hoses from the
tractor.
b. Remove the quick connect plugs from
hydraulic lines.
c.
Lift the receiver tank off the airlock.
d. Remove the tips from the rotor and the
wiper blade from the housing.
43
5.2.4
AIR SYSTEM RELIEF VALVES
The air in this system is moved by the blower. It
draws air into the intake side and creates a
vacuum that can pick up and draw material into
the system. As the air moves through the blower,
it becomes pressurized and flows through the
airlock to move material out of the system and to
its destination. As the flow into the intake is
restricted, the vacuum will build until it exceeds the
setting of the intake relief valve. The valve opens
to supply a flow of air to the blower to prevent
overheating. A relief valve on the pressure side
will also open to allow air flow if the airlock (outlet
pressure side of the circuit) is restricted or
plugged.
Fig. 5-19 Vacuum Relief Valves
The vacuum side relief valve is set to open at 15
in. Hg vacuum and the pressure side at 15 psi.
Both must function at very close to these specified
levels to insure optimum capacity and
performance. After prolonged use, the springs in
these valves can weaken causing the valve to
open prematurely and affect machine
performance. Dirt and debris can get caught in the
valve seat allowing air leakage that affects system
performance.
To maintain air system relief valves, follow this
procedure:
1. Listen for the valves opening during operation.
They will sound like a popping or a whistle if
they are opening.
2. Install gauges on the vacuum and pressure
sides of the air system.
3. Watch the gauges to monitor the pressure in
the vacuum and pressure sides of the air
circuit.
4. Restrict the flow into the intake side of the air
system until you hear the valve open. The
vacuum gauge should read 15 in. Hg. If it
does not, replace valve.
5. Restrict the output side until you hear the
valve open. The pressure gauge should read
15 psi. If it does not, replace the valve.
6. Place all controls in neutral or OFF, stop
engine, remove ignition key and wait for all
moving parts to stop.
7. Remove old valve and replace it with a new
one.
8. Tighten valve into fitting to secure.
Fig. 5-20 Pressure Relief Valve
6
TROUBLE SHOOTING
The Walinga Ultra-Vac® is a high capacity air pump that creates a vacuum for picking up grain and supplies
pressurized air for moving the grain. It is a simple and reliable system that requires minimum maintenance.
In the following section, we have listed many of the problems, causes and solutions to the problems that you
may encounter.
If you encounter a problem that is difficult to solve, even after having read through this trouble shooting
section, please call your Walinga dealer. Before you call, please have this Operator’s Manual and the serial
number from your Ultra-Vac® ready.
6.1
MOBILE TRANSFER UNIT
PROBLEM
CAUSE
SOLUTION
Slow pick up of grain.
Air leaks.
Tighten all vacuum connections.
Be sure seals are in good
condition.
Tighten receiver cyclone to base.
Check seal on pre-cleaner bottom
door. Close and secure.
Inspection door must be closed
and sealed.
Check vacuum relief valve.
Replace if defective. Clear
obstruction.
Check pressure relief valve.
Clean or replace as required.
Slow discharge of grain.
Defective blower.
Check clearance between lobes
and case. Excessive clearance
will decrease air flow. Consult
your dealer.
Defective airlock.
Check that tip clearance is 0.004
inches. Adjust or replace tips as
required.
Improper setting of air slide.
Reset airslide.
Air leaks.
Tighten all pressure connections.
Be sure seals are in good
condition.
Check pressure relief valve.
Clean or replace as required.
45
PROBLEM
CAUSE
SOLUTION
Slow discharge of grain (cont'd).
Defective blower.
Check clearance between lobes
and case. Excessive clearance
will decrease air flow. Consult
your dealer.
Defective airlock.
Check that tip clearance is 0.004
inches. Adjust or replace tips as
required.
Improper setting of flow control
valve.
Reset flow control.
Not enough air flow.
Open air slide on nozzle to
provide more air.
Pulsation.
Increase blower speed or
decrease size of intake piping.
Blower overheating.
Product damage.
Too many bends.
Straighten out intake line.
Not enough air flow.
Open air slide on nozzle to
provide more air.
Low oil level.
Add oil as required.
Liners worn out.
Replace wear liners in discharge
cyclone.
Poor connections.
Tighten and seal all connections.
Lines wearing.
Eliminate elbows. Keep lines
straight as possible and provide a
large radius for bends.
Excessive RPM speed.
Decrease air flow by slowing
blower or increasing size of the
lines.
Increase grain quantity by closing
air slide.
Blower bogging down.
Dirt from pre-cleaner going
through blower.
Clean pre-cleaner tank. Clean
more frequently in dirty conditions.
Hydraulics overheating.
Low oil level.
Check engine oil level. Add as
required.
PROBLEM
CAUSE
SOLUTION
Hydraulics overheating (cont’d)
Poor oil quality.
Replace with oil of required
specifications.
Defective hose or tube.
Check hoses, lines and couplers.
Repair or replace as required.
Improper circuit.
Check for proper system setting.
i.e. open or close.
Wrong airlock speed.
Check for speed control valve. If
oil flow continues at 0 setting,
repair or replace valve.
Too much flow.
If flow from engine is set at 30
gpm, reduce to 15 gpm.
Airlock too tight.
Adjust airlock tips.
PROBLEM
CAUSE
SOLUTION
Noisy airlock.
Tips hitting case.
Readjust tips where applicable
Airlock stalls.
Airlock jammed.
Reverse airlock direction to clear.
6.2
AIRLOCK
Remove obstruction from airlock
by opening inspection door or
discharge elbow. Disconnect
hydraulic hoses.
Insufficient oil flow.
Check couplings or lines.
Defective engine hydraulics.
Repair engine.
Airlock operated in reverse too
long.
Rotor damaged. Repair or
replace rotor.
Blades too tight.
Loosen bolts. Refer to airlock
maintenance.
Faulty airlock motor.
Replace motor.
Faulty flow divider.
Replace flow divider.
Faulty pressure relief valve.
Replace pressure relief valve.
Air loss through airlock.
Tip clearance too large.
Adjust tips to decrease clearance
to 0.006 inches.
Breaking rotor blades.
Airlock running in reverse.
Set for forward rotation. Repair or
replace blades.
47
6.3
BLOWER
PROBLEM
CAUSE
SOLUTION
Low air volume.
Slow speed.
Check blower speed with tach.
Increase speed.
Check for slipping belts. Adjust
belt tension as required.
Piping blocked.
Check inlet and outlet piping.
Remove obstruction.
Check relief valves. Clean, repair
or replace as required.
Overheating.
Engine overloading.
Excessive pressure rise.
Check inlet vacuum and discharge
pressure and compare with
recommended conditions.
Determine cause before
continuing.
Worn components.
Check clearance and replace
defective components. Refer to
Blower Manual.
Inadequate lubrication.
Check oil level in reservoirs. Add
as required.
Excessive lubrication.
Check oil level. Correct as
required.
Excessive pressure rise.
Adjust operating conditions to
reduce pressure rise to below 10
psi.
Coupling misalignment.
Check and realign.
Speed too high.
Check and decrease speed to
recommended RPM.
Pressure too high.
Adjust operating conditions to set
rise to below 10 psi. Add more
air.
Impellers rubbing.
Consult your nearest dealer.
6.4
V-BELT DRIVE
PROBLEM
CAUSE
SOLUTION
Loss in drive speed.
Belts slipping.
Tighten belts as required.
Localized belt wear.
Check cross-section dimension.
a. If narrow, pulley spinning.
b. If swollen, belt failing
internally.
Unequal stretch on belts.
Defective belts. Replace with
matched set.
Belts overloaded.
Belts failed or worn out. Replace
belts with matched set.
Belt separation.
Belts too tight. Replace belts and
set correctly.
Envelope seams opening.
Check for oil or rubber solvent.
Eliminate contamination and
replace belts.
Abnormal envelope wear.
Check for worn sheave,
misalignment or slip. Replace
defective parts, adjust properly
and replace belt.
Belt softening or swelling.
Eliminate oil or rubber solvent.
Replace belt.
Belt hardening or cracking.
Eliminate heat or chemical
contamination. Replace belt.
49
7
SPECIFICATIONS
7.1 MECHANICAL
MODEL
CAPACITY*
Bu/Hr (tones/hr)
4510D
5614D
6614D
7614D
CORN &
BARLEY
WHEAT
BEANS
LINE SIZE
1200
(30)
2500
(64)
3600
(92)
5000
(127)
1000
(27)
2200
(58)
3200
(84)
4500
(119)
900
(24)
1900
(51)
2800
(75)
4000
(107)
4 in (100mm)
5 in (125mm)
5 & 6 in
(125mm & 150mm)
6 & 7 in
(150mm & 175mm)
DISCHARGE
HEIGHT
13ft-4in min
(4.06m)
14 ft min
(4.26m)
14ft min
(4.26m)
14ft min
(4.26m)
*Capacities based on using 12ft (3.65m) suction line and truck loading kit.
Capacity will vary with condition of product.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
7.2 BOLT TORQUE
CHECKING BOLT TORQUE
The tables shown below give correct torque values for various bolts and capscrews. Tighten all bolts to the
torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque
chart as a guide. Replace hardware with the same strength bolt.
ENGLISH TORQUE SPECIFICATIONS
Bolt
Diameter
"A"
1/4"
5/16"
3/8"
7/16"
1/2"
9/16"
5/8"
3/4"
7/8"
1"
SAE 2
Bolt Torque
SAE 5
SAE 8
(N.m) (lb-ft)
8
6
13
10
27
20
41
30
61
45
95
60
128
95
165
225
230
170
345
225
(N.m) (lb-ft)
9
12
25
19
45
33
72
53
110
80
115
155
215
160
390
290
570
420
850
630
(N.m) (lb-ft)
17
12
36
27
63
45
75
100
155
115
220
165
220
305
400
540
880
650
1320
970
METRIC TORQUE SPECIFICATIONS
Bolt
Diameter
"A"
M3
M4
M5
M6
M8
M10
M12
M14
M16
M20
M24
M30
M36
Bolt Torque
8.8
10.9
(N.m) (lb-ft)
(N.m) (lb-ft)
.5
3
6
10
25
50
90
140
225
435
750
1495
2600
.4
2.2
4
7
18
37
66
103
166
321
553
1103
1917
1.8
4.5
9
15
35
70
125
200
310
610
1050
2100
3675
1.3
3.3
7
11
26
52
92
148
229
450
774
1550
2710
Torque figures indicated above are valid for non-greased or non-oiled threads and heads unless otherwise
specified. Therefore, do not grease or oil bolts or capscrews unless otherwise specified in this manual. When
using locking elements, increase torque values by 5%.
* Torque value for bolts and capscrews are identified by their head markings.
51

























 



