LASER CLASS 700 Series Specifications
WHAT IS INTERNET FAXING?
WHAT ARE TRANSFER AND TX ARCHIVE
MODES?
Internet-enabled fax machines plug into your existing data network.
They convert scanned documents into file formats that are easily
transported over the Internet or your company intranet, sending
data to e-mail address destinations or other I-fax-capable machines.
Internet faxing bypasses the public switched telephone network and
offers many advantages for your business:
• Lowers communication costs by eliminating per-call charges for each
transmission—especially for long-distance and international calls.
• Allows for simultaneous and instantaneous distribution of information to all recipients. Data is transmitted to everyone at once, at the
maximum speed of your network, eliminating delays associated
with sequential broadcast technology.
• Maintains image quality and document integrity throughout digital
transmission. Your faxes are impervious to distortion from static
and line noise, so resolution is not compromised.
• Increases productivity by eliminating busy signals and rescanning
tasks—so fax transmissions get through the first time, every time.
And since the Canon LASER CLASS 700 Series devices offer both
I-fax and Super G3 sending, total communications flexibility is at
your fingertips, allowing you to:
Transfer and TX Archive modes allow LASER CLASS 700 Series users
to archive both incoming and outgoing data to a file server, e-mail
address, fax machine, or I-fax device. Transfer Mode automatically
transmits incoming documents to other destinations for storing, while
TX Archiving automatically transmits outgoing data to other destinations.
These features offer many benefits to your business:
• Automates and simplifies the process of storing incoming and
outgoing data, eliminating the burdens associated with copying
or scanning these documents and helping to avoid manual
operation errors.
• Facilitates records retention for sent information by automatically
transmitting this information to a designated e-mail address, database, or file server.
• Ensures the security and confidentiality of customer records and
information by routing incoming faxes to a designated e-mail
address, database, or file server.
• Helps satisfy security regulations and guidelines such as those
defined by the Gramm-Leach-Bliley Act and the Sarbanes-Oxley Act.*
* Statements made in this document are the opinions of Canon U.S.A. None of these statements should be
construed to customers or Canon U.S.A.’s dealers as legal advice, as Canon U.S.A. does not provide legal counsel
or compliance consultancy, including without limitation, Sarbanes-Oxley, HIPAA, GLBA, Check 21, or the USA
Patriot Act. Each customer must have its own qualified counsel determine the advisability of a particular solution
as it relates to regulatory and statutory compliance
• Receive an I-fax and forward it to a G3 fax
• Scan images to e-mail
INTERNET
Mail Server
I-Fax
I-Fax
PC
LAN
Effective Scanning Width
LASER CLASS 710/730i:
InstaScan:
Data Compression System:
Modem Speed:
Transmission Speed:
Printing Method:
Printing Speed:
Halftone:
TX/RX Resolution
Ultra Fine Mode:
Super Fine Mode:
Fine Mode:
Standard Mode:
Effective Recording Width:
Recording Paper Supply
LASER CLASS 710/730i:
Receiving Paper Tray:
Recording Paper Size:
Enhanced Imaging Quality:
Enhanced Printing Quality:
Printing Resolution:
Printer Cartridge:
Cartridge Yield:
Power Consumption
Standby:
Max.:
Energy Saver:
Dimensions (H x W x D)
LASER CLASS 710/730i
Without Handset:
3 Options:
• I-Fax to I-Fax
• I-Fax to PC
• PC to I-Fax
Desktop Transceiver
Public Switched Telephone Network
G3
Up to 70 Sheets (Letter)*
Up to 30 Sheets (Legal)*
Up to 30 Sheets (Ledger)*
Contact Image Sensor
Maximum: 11" x 39.4" (279mm x 1000mm)
Minimum: 5.9" x 5" (148mm x 128mm)
10" (254mm)
Approx. 1.1 Sec./Page (Letter, Standard Mode)
Approx. 35 Scans/Min.(Letter, Standard Mode)
MH, MR, MMR, JBIG†††
33.6/31.2/28.8/26.4/24/21.6/19.2/16.8/
14.4/12/9.6/7.2/4.8/2.4 Kbps
Automatic Fallback
Approx. 3 Sec./Page*** (V.34/33.6 Kbps + JBIG)
Laser Dry Electrostatic Transfer
Up to 19 Pages/Min. (Letter)
256 Shades of Gray
Horizontal
Vertical
406 pels/in.
x
391 lines/in.
16 pels/mm
x
15.4 lines/mm
203 pels/in.
x
391 lines/in.
8 pels/mm
x
15.4 lines/mm
203 pels/in.
x
196 lines/in.
8 pels/mm
x
7.7 lines/mm
203 pels/in.
x
98 lines/in.
8 pels/mm
x
3.85 lines/mm
8.2" (210mm)
600 Sheets: 2 x 250-Sheet, Adjustable
Cassette; 100-Sheet MP Tray; Optional
500-Sheet Cassette (Letter)
Face-Down, Print-In-Order: 250 Sheets
Letter/Legal/A4
UHQ (Ultra High Quality)
1200-dpi Smoothing for Incoming Faxes
1200 dpi x 1200 dpi
FX7 Cartridge
Approx. 4,500 Pages††
Approx. 15W (710)
Approx. 20W (730i)
Approx. 980W
5W (710), 15W (730i)
18-1/8" x 19-3/4" x 19-3/4"
(459mm x 499mm x 499mm)
18-1/8" x 22-1/2" x 19-3/4"
(459mm x 569mm x 499mm)
Weight (Excluding Handset Option)
LASER CLASS 710:
Approx. 52 lb. 15 oz. (24kg)
LASER CLASS 730i:
Approx. 55 lb. 2 oz. (25kg)
Environmental Conditions
Temperature:
50˚F - 90.5˚F (10˚C - 32.5˚C)
Humidity:
20% - 80% RH
Dialing:
Automatic Dialing
One-Touch Speed-Dialing: 72 Locations
Coded Speed-Dialing: 128 Locations
Group-Dialing: 199 Groups
Each Group Can Accommodate up to
199 Locations
Maximum Dial Digits: 120
Error Re-Dialing
Manual Re-Dialing
Dial Search
Energy Saver Key
Programmable Key
Send Feature
LASER CLASS 730i:
LASER CLASS 710:
Sending Methods:
Number of Addresses:
File Format:
Sending Resolution
Simple Mode:
E-mail Mode:
Protocol:
Mail Address:
Send Settings:
Network Scanning:
Networking
Delayed Transmission:
Memory Polling Transmission
Polling Reception
Multi-Polling:
Delayed Polling:
Sequential Broadcast:
Options:
Standard
Optional
Super G3 is Standard on Both Models
E-mail, I-Fax, Super G3 Fax, File Server (FTP)
210
M-TIFF (MH/MR/MMR), PDF
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 400 dpi, 400 dpi x 400 dpi
SMTP; POP3
5 Destinations
Document Name
Subject
Text
Signature
Priority
RX Confirmation
Message
Yes**
Up to 210 Destinations and up to
70 Reservations
Up to 210 Locations
Up to 200 Locations
Up to 5 Designated Times per Speed-Dial
Up to 210 Locations
(200 Pre-Programmed Speed-Dials)
Up to 200 Locations
Up to 50
Up to 5 Designated Times per Speed-Dial
Relay Broadcast:
Relay Boxes:
Delayed Relay Broadcast:
Relay Broadcast Command
Transmission to Confidential Mail Box
Confidential Mail Box:
Up to 50 Boxes
Memory Transmission/Reception:
LASER CLASS 710:
(8MB) Up to 510 Pages (Standard)▲
One Open Slot, Optional 32MB for
Total Capacity
LASER CLASS 730i:
(40MB) Up to 1,500 Pages▲
Receiving Restriction
Password and Sub-Address (ITU-T STD)
Convenience:
Auto Receive Reduction (70% ~ 100%)
Dual Access
TX Reservation During RX
TX Reservation During Memory TX
Memory RX During Copy
Memory TX During Copy
Scan During Printing
Transmission Reservation:
Up to 70 Reservations
LCD (Liquid Crystal Display):
20-Digits x 2-Line
Department Access Code:
Up to 99 Codes
Local Copy Function:
Multiple Copy up to 99 Pages
Program Buttons:
Up to 72
Memory Lock Reception
Battery Backup:
Up to 12 Hours† (710)
Up to 3 hours (730i)
RX Document Multiple Printout: Up to 99 Pages
RX Page Footer:
Yes
Transfer Mode:
Yes
Soft Counter:
Yes
Report/Reference:
Activity Report (up to 40 Transactions)
Non-Delivery Report
Management Report
List of Phone Numbers for One-Touch
and Coded Speed-Dialing
List of Transaction Schedule
User Data List
File Reference
TTI (Transmitter Terminal Identification)
TTI Selector: Up to 99 Identifications
RTI (Remote Terminal Identification)
33.6 Kbps Dual Line
Printer Kit III (for 710 Only)
Network Kit III (for 710 Only)
500-Sheet Cassette (Letter)
Stamp
Stamp Refill
Braille Kit D-1
Telephone Handset Kit 8
Pedestal▲▲ (H x W x D):
17-3/4" x 18-7/8" x 17-1/2"
(450mm x 478mm x 444mm)
Provided by Third-Party:
Facsimile Memory: 32MB (710 Only)
Printer Memory: 32MB, 64MB
Printer Kit III (Optional for 710; Standard for 730i)
Type:
Embedded Print Controller
Processor:
Power PC405 200MHz RISC Processor
Memory:
Standard 8MB (72MB Max.)
PDL Support:
PCL 5e, PCL 6, PJL
Internal Fonts:
PCL 5e/6: 45 Roman Fonts,
32 Bar Code Fonts
Interface Connections:
Parallel (IEEE 1284)
USB Optional RJ-45 (10/100Base-T)
(Compatibility: Nibble, Byte, and ECP Mode)
Memory:
8MB (72MB Max.)
Paper Sizes:
A4/A/B5/Executive/Legal/Letter/Postcard/
Double Postcard/C5/COM10/Monarch/DL
Media Type:
Plain Paper/Heavy Paper/Recycled Paper/
Colored Paper/Bond Paper/Plain Paper 2
Notification Job Completion:
Yes (E-Mail) n
Toner Saver:
Yes
Duplex Printing (Print Jobs):
Yes
Network Kit III (Optional for 710nn; Standard for 730i)
CPU:
ETRAX 100LX (32-Bit RISC CPU 100MHz)
Memory (RAM):
4MB
Storage (ROM):
2MB (Flash™)
SDRAM:
128 Kbps
Network I/F:
10Base-T, 100Base-TX (RJ-45)
Printer I/F:
EPS10 v. 1.00
Network OS:
Novell® NetWare® v.3.2, 4.1, 4.11, 4.2,
5.0, 5.1 (IPX/SPX™)
Windows® 95/98/Me/Windows NT ® 4.0/
Windows 2000/XP (TCP/IP)
Solaris™ 1.1x, 2.5 or Later (TCP/IP)
Protocol Stacks:
IPX/SPX: 802.2, 802.3, Ethernet II,
802.2 SNAP (Ethernet SNAP)
TCP/IP: Ethernet II
NetBEUI (NetBIOS): 802.2
Other Features:
Remote UI Supported
imageWARE Enterprise Management Console
Limited Warranty:
90 Days
* 15-27.5˚ C; 20-80% RH; 20 lb., < 120 µm
** Scan-to-E-mail functionality
*** Approximate 3-second-per-page fax transmission time based on ITU-T
No. 1 Chart (JBIG, Standard Mode) at 33.6 Kbps modem speed when
transmitting to another V.34 machine. The Public Switched Telephone
Network (PSTN) currently supports 28.8 Kbps modem speeds or lower,
depending on telephone line conditions.
† When the system is configured with 40MB memory, battery backup is
reduced to three hours maximum (see page 3).
†† Based on 4% Original, 5% Coverage.
††† Actual Compression Ratio may vary with image.
▲ Based on ITU-T No. 1 Chart (Standard Mode).
▲▲ Requires 500-Sheet letter-sized cassette.
n Requires Network Kit III.
nn Requires Printer Kit III.
Mail Server acts like
a Post Office
Mail Server
E-Mail
Scanning Method:
Document Sizes:
With Handset:
• Send a fax to an e-mail address
• Receive a G3 fax and forward it to e-mail
Type:
Applicable Line:
Compatibility:
Automatic Document Feeder:
PC
LAN
E-Mail
©2005 Canon U.S.A., Inc. All rights reserved.
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY
STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S.
marks. Windows and Windows NT are registered trademarks of Microsoft Corporation in the United
States and/or other countries. Novell and NetWare are registered trademarks of Novell, Inc. in the
United States and other countries. IPX/SPX is a trademark of Novell, Inc. Solaris is a trademark of Sun
Microsystems, Inc. in the United States and other countries. Flash is a trademark of Macromedia, Inc.
in the United States and/or other countries. CANON and LASER CLASS are registered trademarks, and
the SUPER G3 logo is a trademark of Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries. IMAGEWARE is a registered trademark of Canon U.S.A., Inc.
in the United States and is a trademark of Canon Inc. in certain other countries. IMAGEANYWARE is a
trademark of Canon. All referenced product names and other marks are trademarks of their respective owners.
Specifications and availability subject to change without notice.
©2007 Canon U.S.A., Inc. All rights reserved.
0113W836
0807R-LC700-2.2M-L
printed on recycled
paper in the u.s.a.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Workgroup
Systems
WORKGROUP SYSTEMS
Comparison
Chart
LASER CLASS 710
A STANDARD IN
FACSIMILE COMMUNICATIONS
Canon’s LASER CLASS® 700 Series. Two costeffective, compact, high-quality Internet facsimile
systems that bridge the gap between your
telephone and data network lines. The LASER
CLASS 700 Series devices, with Canon state-of-theart technology, provide true multifunctionality for a
totally integrated communications solution.
The LASER CLASS 710 device is a high-performance, high-speed
Super G3 fax. Featuring a 3-second-per-page transmission speed,**
70-sheet* document feeder with 1.1-second/page scanning and
19-ppm, 1200-dpi laser output, the LASER CLASS 710 device gives you
all the faxing power you need today, with the opportunity to easily
upgrade your capabilities tomorrow.
The LASER CLASS 730i device also delivers:
• Support for M-TIFF and PDF formats for sending Internet faxes
and network scan files†
• Automatic inbound routing of faxes to PCs by sub-address,
telephone number, and e-mail
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Support for Canon Remote UI (User-Interface)—access and control the unit using a standard Web browser
• Support for Canon imageWARE™—create and manage digital
document databases
• Support for Canon device management utilities—easy device
installation, status monitoring, and network management
LASER CLASS 730i
The flagship of the Canon LASER CLASS 700 Series Internet
facsimile systems, the LASER CLASS 730i device does it all. Offering
a powerful combination of Internet faxing, Super G3 faxing, PC
faxing, local and network duplex printing, network scanning, and
convenience copying capabilities as standard, it’s the one multifunction device that can handle your every need. Easy to connect
and use, the LASER CLASS 730i device provides Parallel and USB
ports for local printing, and a 10/100Base-TX Ethernet interface.
The LASER CLASS 710
device, shown here
with standard 250sheet front-loading,
user-adjustable paper
cassettes, is complemented by a 100-sheet
MultiPurpose Tray. Add
an optional 500-sheet
cassette for maximum
printing productivity.
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
* Based on ITU-T No.1 Chart (Standard Mode)
** 15-27.5˚C, 20-80% RH, 20 lb., < 120 µm
† Scan-to-E-mail functionality
Leverage your investment in industry-leading Canon fax technology by
enabling optional local Parallel and USB printing capabilities with the
Printer Kit III. Or raise the bar to full multifunctionality with the ability
to print, scan, and fax right from one’s desktop with the optional
Network Kit III. Even add optional memory and paper capacity as
needed, and design the configuration that offers the most value for
your office. The LASER CLASS 710 device provides:
L A S E R C L A SS ® 7 3 0 i
L A S E R C L A SS ® 7 1 0
Modem Speed
Super G3 33.6 Kbps*
Super G3 33.6 Kbps*
Automatic Document Feeder
70 Sheets,** Face-Up
70 Sheets,** Face-Up
35 Scans/Min. (1.1 Sec./Pg.)
35 Scans/Min. (1.1 Sec./Pg.)
Up to 1,500 Pages (40MB) / Up to 1,500 Pages†† (40MB)
Up to 510 Pages (8MB) / Up to 1,500 Pages†† (40MB)
250 + 250 + 100 / 1,100 Sheets
250 + 250 + 100 / 1,100 Sheets
Original Scanning Speed
Standard/Maximum Fax Memory
Standard/Maximum Paper Capacity
Dual Line Fax
Print Speed
Output Resolution
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
1200 dpi
Optional (Print Jobs)
Local Printing
Standard
Optional
Network Printing
Standard
Optional
PC Faxing
Standard
Optional
Internet Faxing
Standard
Optional
M-TIFF, PDF
M-TIFF, PDF
Collated Output
Cartridge
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Optional Dual Line Kit for twice the faxing capability—send or
receive two faxes at once, or send and receive faxes at the
same time
imageWARE
The installation of Printer
Kit III and Network Kit III
enable the Internet Fax
function. These boards
are standard on the
LASER CLASS 730i model
and optional on the
LASER CLASS 710 model.
19 Pages per Minute
1200 dpi
Network Scanning***
• Automatic inbound routing of faxes to the PC by sub-address,
telephone number, and e-mail (when configured with the optional
Printer Kit III and Network Kit III)
Optional
19 Pages per Minute
Standard (Print Jobs)
Duplex Printing
I-Fax Sending File Formats
• Up to 510 pages of 8MB standard page memory, expandable to
40MB (1,500 pages) †
Optional
Standard
Optional
Yes, Face-Down
Yes, Face-Down
Full Yield FX7 Cartridge
Full Yield FX7 Cartridge
Optional
Optional
Notes: The Printer Kit III is standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables local printing via IEEE 1284 Parallel and USB interfaces, plus duplex printing capability. The Network Kit III is
standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables Internet faxing, network printing, and Scan-to-E-mail capabilities via a 10/100Base-TX interface. Installation of the Printer Kit III is
required for installation of the Network Kit III.
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at 33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network (PSTN)
currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
** 15-27.5˚C, 20-80% RH, 20 lb., <120 µm
***Scan-to-E-mail functionality
† When the system is configured with 40MB memory, battery backup is reduced to three hours, maximum.
†† Based on ITU-T No. 1 Chart (Standard Mode)
Printer Kit III
Network Kit III
• Full Dual Access
• Support for Canon imageWARE software, Remote UI (User-Interface),
and device management utilities (when connected to the network)
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
The LASER CLASS 730i device features up to 1,500 pages* (40MB) of
standard page memory, 35 scans per minute, a 70-page** face-up
document feeder, and full Dual Access, so you can put the most
robust communication tool to work in your office, right out of the
box. Add a 500-sheet Paper Cassette to the standard three-way,
600-sheet paper supply (1,100 sheets maximum) and optional Dual
Line faxing, and raise your office productivity to new heights.
* 15-27.5˚C, 20-80% RH, 20 lb. < 120 µm
** Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at
33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network
(PSTN) currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
† Based on ITU-T No. 1 Chart (Standard Mode)
The LASER CLASS 700 Series, shown with maximum
paper capacity of 1,100 sheets.
The FX7 Cartridge produces up to 4,500 prints at 5%
image coverage, and makes maintenance a snap.
The user-friendly control
panel makes all functions
easily accessible.
WORKGROUP SYSTEMS
Comparison
Chart
LASER CLASS 710
A STANDARD IN
FACSIMILE COMMUNICATIONS
Canon’s LASER CLASS® 700 Series. Two costeffective, compact, high-quality Internet facsimile
systems that bridge the gap between your
telephone and data network lines. The LASER
CLASS 700 Series devices; with Canon state-of-theart technology, provide true multifunctionality for a
totally integrated communications solution.
The LASER CLASS 710 device is a high-performance, high-speed
Super G3 fax. Featuring a 3-second-per-page transmission speed,**
70-sheet* document feeder with 1.1-second/page scanning and
19-ppm, 1200-dpi laser output, the LASER CLASS 710 device gives you
all the faxing power you need today, with the opportunity to easily
upgrade your capabilities tomorrow.
The LASER CLASS 730i device also delivers:
• Support for M-TIFF and PDF formats for sending Internet faxes
and network scan files†
• Automatic inbound routing of faxes to PCs by sub-address,
telephone number, and e-mail
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Support for Canon Remote UI (User-Interface)—access and control the unit using a standard Web browser
• Support for Canon imageWARE™—create and manage digital
document databases
• Support for Canon device management utilities—easy device
installation, status monitoring, and network management
LASER CLASS 730i
The flagship of the Canon LASER CLASS 700 Series Internet
facsimile systems, the LASER CLASS 730i device does it all. Offering
a powerful combination of Internet faxing, Super G3 faxing, PC
faxing, local and network duplex printing, network scanning, and
convenience copying capabilities as standard, it’s the one multifunction device that can handle your every need. Easy to connect
and use, the LASER CLASS 730i device provides Parallel and USB
ports for local printing, and a 10/100Base-TX Ethernet interface.
The LASER CLASS 710
device, shown here
with standard 250sheet front-loading,
user-adjustable paper
cassettes, is complemented by a 100-sheet
MultiPurpose Tray. Add
an optional 500-sheet
cassette for maximum
printing productivity.
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
* Based on ITU-T No.1 Chart (Standard Mode)
** 15-27.5˚C, 20-80% RH, 20 lb., < 120 µm
† Scan-to-E-mail functionality
Leverage your investment in industry-leading Canon fax technology by
enabling optional local Parallel and USB printing capabilities with the
Printer Kit III. Or raise the bar to full multifunctionality with the ability
to print, scan, and fax right from one’s desktop with the optional
Network Kit III. Even add optional memory and paper capacity as
needed, and design the configuration that offers the most value for
your office. The LASER CLASS 710 device provides:
L A S E R C L A SS ® 7 3 0 i
L A S E R C L A SS ® 7 1 0
Modem Speed
Super G3 33.6 Kbps*
Super G3 33.6 Kbps*
Automatic Document Feeder
70 Sheets,** Face-Up
70 Sheets,** Face-Up
35 Scans/Min. (1.1 Sec./Pg.)
35 Scans/Min. (1.1 Sec./Pg.)
Up to 1,500 Pages (40MB) / Up to 1,500 Pages†† (40MB)
Up to 510 Pages (8MB) / Up to 1,500 Pages†† (40MB)
250 + 250 + 100 / 1,100 Sheets
250 + 250 + 100 / 1,100 Sheets
Original Scanning Speed
Standard/Maximum Fax Memory
Standard/Maximum Paper Capacity
Dual Line Fax
Print Speed
Output Resolution
1200 dpi
Optional (Print Jobs)
Local Printing
Standard
Optional
Network Printing
Standard
Optional
PC Faxing
Standard
Optional
Internet Faxing
Standard
Optional
M-TIFF, PDF
M-TIFF, PDF
Network Scanning***
• Automatic inbound routing of faxes to the PC by sub-address,
telephone number, and e-mail (when configured with the optional
Printer Kit III and Network Kit III)
Cartridge
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Optional Dual Line Kit for twice the faxing capability—send or
receive two faxes at once, or send and receive faxes at the
same time
19 Pages per Minute
1200 dpi
• Up to 510 pages of 8MB standard page memory, expandable to
40MB (1,500 pages) †
Collated Output
imageWARE
The installation of Printer
Kit III and Network Kit III
enable the Internet Fax
function. These boards
are standard on the
LASER CLASS 730i model
and optional on the
LASER CLASS 710 model.
Optional
19 Pages per Minute
Standard (Print Jobs)
Duplex Printing
I-Fax Sending File Formats
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
Optional
Standard
Optional
Yes, Face-Down
Yes, Face-Down
Full Yield FX7 Cartridge
Full Yield FX7 Cartridge
Optional
Optional
Notes: The Printer Kit III is standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables local printing via IEEE 1284 Parallel and USB interfaces, plus duplex printing capability. The Network Kit III is
standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables Internet faxing, network printing, and Scan-to-E-mail capabilities via a 10/100Base-TX interface. Installation of the Printer Kit III is
required for installation of the Network Kit III.
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at 33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network (PSTN)
currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
** 15-27.5˚C, 20-80% RH, 20 lb., <120 µm
***Scan-to-E-mail functionality
† When the system is configured with 40MB memory, battery backup is reduced to three hours, maximum.
†† Based on ITU-T No. 1 Chart (Standard Mode)
Printer Kit III
Network Kit III
• Full Dual Access
• Support for Canon imageWARE software, Remote UI (User-Interface),
and device management utilities (when connected to the network)
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
The LASER CLASS 730i device features up to 1,500 pages* (40MB) of
standard page memory, 35 scans per minute, a 70-page** face-up
document feeder, and full Dual Access, so you can put the most
robust communication tool to work in your office, right out of the
box. Add a 500-sheet Paper Cassette to the standard three-way,
600-sheet paper supply (1,100 sheets maximum) and optional Dual
Line faxing, and raise your office productivity to new heights.
* 15-27.5˚C, 20-80% RH, 20 lb. < 120 µm
** Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at
33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network
(PSTN) currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
† Based on ITU-T No. 1 Chart (Standard Mode)
The LASER CLASS 700 Series, shown with maximum
paper capacity of 1,100 sheets.
The FX7 Cartridge produces up to 4,500 prints at 5%
image coverage, and makes maintenance a snap.
The user-friendly control
panel makes all functions
easily accessible.
WORKGROUP SYSTEMS
Comparison
Chart
LASER CLASS 710
A STANDARD IN
FACSIMILE COMMUNICATIONS
Canon’s LASER CLASS® 700 Series. Two costeffective, compact, high-quality Internet facsimile
systems that bridge the gap between your
telephone and data network lines. The LASER
CLASS 700 Series devices; with Canon state-of-theart technology, provide true multifunctionality for a
totally integrated communications solution.
The LASER CLASS 710 device is a high-performance, high-speed
Super G3 fax. Featuring a 3-second-per-page transmission speed,**
70-sheet* document feeder with 1.1-second/page scanning and
19-ppm, 1200-dpi laser output, the LASER CLASS 710 device gives you
all the faxing power you need today, with the opportunity to easily
upgrade your capabilities tomorrow.
The LASER CLASS 730i device also delivers:
• Support for M-TIFF and PDF formats for sending Internet faxes
and network scan files†
• Automatic inbound routing of faxes to PCs by sub-address,
telephone number, and e-mail
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Support for Canon Remote UI (User-Interface)—access and control the unit using a standard Web browser
• Support for Canon imageWARE™—create and manage digital
document databases
• Support for Canon device management utilities—easy device
installation, status monitoring, and network management
LASER CLASS 730i
The flagship of the Canon LASER CLASS 700 Series Internet
facsimile systems, the LASER CLASS 730i device does it all. Offering
a powerful combination of Internet faxing, Super G3 faxing, PC
faxing, local and network duplex printing, network scanning, and
convenience copying capabilities as standard, it’s the one multifunction device that can handle your every need. Easy to connect
and use, the LASER CLASS 730i device provides Parallel and USB
ports for local printing, and a 10/100Base-TX Ethernet interface.
The LASER CLASS 710
device, shown here
with standard 250sheet front-loading,
user-adjustable paper
cassettes, is complemented by a 100-sheet
MultiPurpose Tray. Add
an optional 500-sheet
cassette for maximum
printing productivity.
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
* Based on ITU-T No.1 Chart (Standard Mode)
** 15-27.5˚C, 20-80% RH, 20 lb., < 120 µm
† Scan-to-E-mail functionality
Leverage your investment in industry-leading Canon fax technology by
enabling optional local Parallel and USB printing capabilities with the
Printer Kit III. Or raise the bar to full multifunctionality with the ability
to print, scan, and fax right from one’s desktop with the optional
Network Kit III. Even add optional memory and paper capacity as
needed, and design the configuration that offers the most value for
your office. The LASER CLASS 710 device provides:
L A S E R C L A SS ® 7 3 0 i
L A S E R C L A SS ® 7 1 0
Modem Speed
Super G3 33.6 Kbps*
Super G3 33.6 Kbps*
Automatic Document Feeder
70 Sheets,** Face-Up
70 Sheets,** Face-Up
35 Scans/Min. (1.1 Sec./Pg.)
35 Scans/Min. (1.1 Sec./Pg.)
Up to 1,500 Pages (40MB) / Up to 1,500 Pages†† (40MB)
Up to 510 Pages (8MB) / Up to 1,500 Pages†† (40MB)
250 + 250 + 100 / 1,100 Sheets
250 + 250 + 100 / 1,100 Sheets
Original Scanning Speed
Standard/Maximum Fax Memory
Standard/Maximum Paper Capacity
Dual Line Fax
Print Speed
Output Resolution
1200 dpi
Optional (Print Jobs)
Local Printing
Standard
Optional
Network Printing
Standard
Optional
PC Faxing
Standard
Optional
Internet Faxing
Standard
Optional
M-TIFF, PDF
M-TIFF, PDF
Network Scanning***
• Automatic inbound routing of faxes to the PC by sub-address,
telephone number, and e-mail (when configured with the optional
Printer Kit III and Network Kit III)
Cartridge
• 200 Speed-/Group-dials, Soft Counter, Confidential Mail Box,
Broadcasting, and more
• 10"-wide effective scanning width for faxing 11" x 17" documents
• Optional Dual Line Kit for twice the faxing capability—send or
receive two faxes at once, or send and receive faxes at the
same time
19 Pages per Minute
1200 dpi
• Up to 510 pages of 8MB standard page memory, expandable to
40MB (1,500 pages) †
Collated Output
imageWARE
The installation of Printer
Kit III and Network Kit III
enable the Internet Fax
function. These boards
are standard on the
LASER CLASS 730i model
and optional on the
LASER CLASS 710 model.
Optional
19 Pages per Minute
Standard (Print Jobs)
Duplex Printing
I-Fax Sending File Formats
• Support for storing both incoming and outgoing data through
Transfer and TX Archive modes
Optional
Standard
Optional
Yes, Face-Down
Yes, Face-Down
Full Yield FX7 Cartridge
Full Yield FX7 Cartridge
Optional
Optional
Notes: The Printer Kit III is standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables local printing via IEEE 1284 Parallel and USB interfaces, plus duplex printing capability. The Network Kit III is
standard on the LASER CLASS 730i model and optional on the LASER CLASS 710 model; enables Internet faxing, network printing, and Scan-to-E-mail capabilities via a 10/100Base-TX interface. Installation of the Printer Kit III is
required for installation of the Network Kit III.
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at 33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network (PSTN)
currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
** 15-27.5˚C, 20-80% RH, 20 lb., <120 µm
***Scan-to-E-mail functionality
† When the system is configured with 40MB memory, battery backup is reduced to three hours, maximum.
†† Based on ITU-T No. 1 Chart (Standard Mode)
Printer Kit III
Network Kit III
• Full Dual Access
• Support for Canon imageWARE software, Remote UI (User-Interface),
and device management utilities (when connected to the network)
• 20,000-impression-per-month duty cycle to keep pace with
busy environments
The LASER CLASS 730i device features up to 1,500 pages* (40MB) of
standard page memory, 35 scans per minute, a 70-page** face-up
document feeder, and full Dual Access, so you can put the most
robust communication tool to work in your office, right out of the
box. Add a 500-sheet Paper Cassette to the standard three-way,
600-sheet paper supply (1,100 sheets maximum) and optional Dual
Line faxing, and raise your office productivity to new heights.
* 15-27.5˚C, 20-80% RH, 20 lb. < 120 µm
** Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart ( JBIG, Standard Mode) at
33.6 Kbps modem speed when transmitting to another V.34 machine. The Public Switched Telephone Network
(PSTN) currently supports 28.8 Kbps modem speeds or lower, depending on telephone line conditions.
† Based on ITU-T No. 1 Chart (Standard Mode)
The LASER CLASS 700 Series, shown with maximum
paper capacity of 1,100 sheets.
The FX7 Cartridge produces up to 4,500 prints at 5%
image coverage, and makes maintenance a snap.
The user-friendly control
panel makes all functions
easily accessible.
LASER CLASS 700 Series Specifications
WHAT IS INTERNET FAXING?
WHAT ARE TRANSFER AND TX ARCHIVE
MODES?
Internet-enabled fax machines plug into your existing data network.
They convert scanned documents into file formats that are easily
transported over the Internet or your company intranet, sending
data to e-mail address destinations or other I-fax-capable machines.
Internet faxing bypasses the public switched telephone network and
offers many advantages for your business:
• Lowers communication costs by eliminating per-call charges for each
transmission—especially for long-distance and international calls.
• Allows for simultaneous and instantaneous distribution of information to all recipients. Data is transmitted to everyone at once, at the
maximum speed of your network, eliminating delays associated
with sequential broadcast technology.
• Maintains image quality and document integrity throughout digital
transmission. Your faxes are impervious to distortion from static
and line noise, so resolution is not compromised.
• Increases productivity by eliminating busy signals and rescanning
tasks—so fax transmissions get through the first time, every time.
And since the Canon LASER CLASS 700 Series devices offer both
I-fax and Super G3 sending, total communications flexibility is at
your fingertips, allowing you to:
Transfer and TX Archive modes allow LASER CLASS 700 Series users
to archive both incoming and outgoing data to a file server, e-mail
address, fax machine, or I-fax device. Transfer Mode automatically
transmits incoming documents to other destinations for storing, while
TX Archiving automatically transmits outgoing data to other destinations.
These features offer many benefits to your business:
• Automates and simplifies the process of storing incoming and
outgoing data, eliminating the burdens associated with copying
or scanning these documents and helping to avoid manual
operation errors.
• Facilitates records retention for sent information by automatically
transmitting this information to a designated e-mail address, database, or file server.
• Ensures the security and confidentiality of customer records and
information by routing incoming faxes to a designated e-mail
address, database, or file server.
• Helps satisfy security regulations and guidelines such as those
defined by the Gramm-Leach-Bliley Act and the Sarbanes-Oxley Act.*
* Statements made in this document are the opinions of Canon U.S.A. None of these statements should be
construed to customers or Canon U.S.A.’s dealers as legal advice, as Canon U.S.A. does not provide legal counsel
or compliance consultancy, including without limitation, Sarbanes-Oxley, HIPAA, GLBA, Check 21, or the USA
Patriot Act. Each customer must have its own qualified counsel determine the advisability of a particular solution
as it relates to regulatory and statutory compliance
• Receive an I-fax and forward it to a G3 fax
• Scan images to e-mail
INTERNET
Mail Server
I-Fax
I-Fax
PC
LAN
Effective Scanning Width
LASER CLASS 710/730i:
InstaScan:
Data Compression System:
Modem Speed:
Transmission Speed:
Printing Method:
Printing Speed:
Halftone:
TX/RX Resolution
Ultra Fine Mode:
Super Fine Mode:
Fine Mode:
Standard Mode:
Effective Recording Width:
Recording Paper Supply
LASER CLASS 710/730i:
Receiving Paper Tray:
Recording Paper Size:
Enhanced Imaging Quality:
Enhanced Printing Quality:
Printing Resolution:
Printer Cartridge:
Cartridge Yield:
Power Consumption
Standby:
Max.:
Energy Saver:
Dimensions (H x W x D)
LASER CLASS 710/730i
Without Handset:
3 Options:
• I-Fax to I-Fax
• I-Fax to PC
• PC to I-Fax
Desktop Transceiver
Public Switched Telephone Network
G3
Up to 70 Sheets (Letter)*
Up to 30 Sheets (Legal)*
Up to 30 Sheets (Ledger)*
Contact Image Sensor
Maximum: 11" x 39.4" (279mm x 1000mm)
Minimum: 5.9" x 5" (148mm x 128mm)
10" (254mm)
Approx. 1.1 Sec./Page (Letter, Standard Mode)
Approx. 35 Scans/Min.(Letter, Standard Mode)
MH, MR, MMR, JBIG†††
33.6/31.2/28.8/26.4/24/21.6/19.2/16.8/
14.4/12/9.6/7.2/4.8/2.4 Kbps
Automatic Fallback
Approx. 3 Sec./Page*** (V.34/33.6 Kbps + JBIG)
Laser Dry Electrostatic Transfer
Up to 19 Pages/Min. (Letter)
256 Shades of Gray
Horizontal
Vertical
406 pels/in.
x
391 lines/in.
16 pels/mm
x
15.4 lines/mm
203 pels/in.
x
391 lines/in.
8 pels/mm
x
15.4 lines/mm
203 pels/in.
x
196 lines/in.
8 pels/mm
x
7.7 lines/mm
203 pels/in.
x
98 lines/in.
8 pels/mm
x
3.85 lines/mm
8.2" (210mm)
600 Sheets: 2 x 250-Sheet, Adjustable
Cassette; 100-Sheet MP Tray; Optional
500-Sheet Cassette (Letter)
Face-Down, Print-In-Order: 250 Sheets
Letter/Legal/A4
UHQ (Ultra High Quality)
1200-dpi Smoothing for Incoming Faxes
1200 dpi x 1200 dpi
FX7 Cartridge
Approx. 4,500 Pages††
Approx. 15W (710)
Approx. 20W (730i)
Approx. 980W
5W (710), 15W (730i)
18-1/8" x 19-3/4" x 19-3/4"
(459mm x 499mm x 499mm)
18-1/8" x 22-1/2" x 19-3/4"
(459mm x 569mm x 499mm)
Weight (Excluding Handset Option)
LASER CLASS 710:
Approx. 52 lb. 15 oz. (24kg)
LASER CLASS 730i:
Approx. 55 lb. 2 oz. (25kg)
Environmental Conditions
Temperature:
50˚F - 90.5˚F (10˚C - 32.5˚C)
Humidity:
20% - 80% RH
Dialing:
Automatic Dialing
One-Touch Speed-Dialing: 72 Locations
Coded Speed-Dialing: 128 Locations
Group-Dialing: 199 Groups
Each Group Can Accommodate up to
199 Locations
Maximum Dial Digits: 120
Error Re-Dialing
Manual Re-Dialing
Dial Search
Energy Saver Key
Programmable Key
Send Feature
LASER CLASS 730i:
LASER CLASS 710:
Sending Methods:
Number of Addresses:
File Format:
Sending Resolution
Simple Mode:
E-mail Mode:
Protocol:
Mail Address:
Send Settings:
Network Scanning:
Networking
Delayed Transmission:
Memory Polling Transmission
Polling Reception
Multi-Polling:
Delayed Polling:
Sequential Broadcast:
Options:
Standard
Optional
Super G3 is Standard on Both Models
E-mail, I-Fax, Super G3 Fax, File Server (FTP)
210
M-TIFF (MH/MR/MMR), PDF
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 400 dpi, 400 dpi x 400 dpi
SMTP; POP3
5 Destinations
Document Name
Subject
Text
Signature
Priority
RX Confirmation
Message
Yes**
Up to 210 Destinations and up to
70 Reservations
Up to 210 Locations
Up to 200 Locations
Up to 5 Designated Times per Speed-Dial
Up to 210 Locations
(200 Pre-Programmed Speed-Dials)
Up to 200 Locations
Up to 50
Up to 5 Designated Times per Speed-Dial
Relay Broadcast:
Relay Boxes:
Delayed Relay Broadcast:
Relay Broadcast Command
Transmission to Confidential Mail Box
Confidential Mail Box:
Up to 50 Boxes
Memory Transmission/Reception:
LASER CLASS 710:
(8MB) Up to 510 Pages (Standard)▲
One Open Slot, Optional 32MB for
Total Capacity
LASER CLASS 730i:
(40MB) Up to 1,500 Pages▲
Receiving Restriction
Password and Sub-Address (ITU-T STD)
Convenience:
Auto Receive Reduction (70% ~ 100%)
Dual Access
TX Reservation During RX
TX Reservation During Memory TX
Memory RX During Copy
Memory TX During Copy
Scan During Printing
Transmission Reservation:
Up to 70 Reservations
LCD (Liquid Crystal Display):
20-Digits x 2-Line
Department Access Code:
Up to 99 Codes
Local Copy Function:
Multiple Copy up to 99 Pages
Program Buttons:
Up to 72
Memory Lock Reception
Battery Backup:
Up to 12 Hours† (710)
Up to 3 hours (730i)
RX Document Multiple Printout: Up to 99 Pages
RX Page Footer:
Yes
Transfer Mode:
Yes
Soft Counter:
Yes
Report/Reference:
Activity Report (up to 40 Transactions)
Non-Delivery Report
Management Report
List of Phone Numbers for One-Touch
and Coded Speed-Dialing
List of Transaction Schedule
User Data List
File Reference
TTI (Transmitter Terminal Identification)
TTI Selector: Up to 99 Identifications
RTI (Remote Terminal Identification)
33.6 Kbps Dual Line
Printer Kit III (for 710 Only)
Network Kit III (for 710 Only)
500-Sheet Cassette (Letter)
Stamp
Stamp Refill
Braille Kit D-1
Telephone Handset Kit 8
Pedestal▲▲ (H x W x D):
17-3/4" x 18-7/8" x 17-1/2"
(450mm x 478mm x 444mm)
Provided by Third-Party:
Facsimile Memory: 32MB (710 Only)
Printer Memory: 32MB, 64MB
Printer Kit III (Optional for 710; Standard for 730i)
Type:
Embedded Print Controller
Processor:
Power PC405 200MHz RISC Processor
Memory:
Standard 8MB (72MB Max.)
PDL Support:
PCL 5e, PCL 6, PJL
Internal Fonts:
PCL 5e/6: 45 Roman Fonts,
32 Bar Code Fonts
Interface Connections:
Parallel (IEEE 1284)
USB Optional RJ-45 (10/100Base-T)
(Compatibility: Nibble, Byte, and ECP Mode)
Memory:
8MB (72MB Max.)
Paper Sizes:
A4/A/B5/Executive/Legal/Letter/Postcard/
Double Postcard/C5/COM10/Monarch/DL
Media Type:
Plain Paper/Heavy Paper/Recycled Paper/
Colored Paper/Bond Paper/Plain Paper 2
Notification Job Completion:
Yes (E-Mail) n
Toner Saver:
Yes
Duplex Printing (Print Jobs):
Yes
Network Kit III (Optional for 710nn; Standard for 730i)
CPU:
ETRAX 100LX (32-Bit RISC CPU 100MHz)
Memory (RAM):
4MB
Storage (ROM):
2MB (Flash™)
SDRAM:
128 Kbps
Network I/F:
10Base-T, 100Base-TX (RJ-45)
Printer I/F:
EPS10 v. 1.00
Network OS:
Novell® NetWare® v.3.2, 4.1, 4.11, 4.2,
5.0, 5.1 (IPX/SPX™)
Windows® 95/98/Me/Windows NT ® 4.0/
Windows 2000/XP (TCP/IP)
Solaris™ 1.1x, 2.5 or Later (TCP/IP)
Protocol Stacks:
IPX/SPX: 802.2, 802.3, Ethernet II,
802.2 SNAP (Ethernet SNAP)
TCP/IP: Ethernet II
NetBEUI (NetBIOS): 802.2
Other Features:
Remote UI Supported
imageWARE Enterprise Management Console
Limited Warranty:
90 Days
* 15-27.5˚ C; 20-80% RH; 20 lb., < 120 µm
** Scan-to-E-mail functionality
*** Approximate 3-second-per-page fax transmission time based on ITU-T
No. 1 Chart (JBIG, Standard Mode) at 33.6 Kbps modem speed when
transmitting to another V.34 machine. The Public Switched Telephone
Network (PSTN) currently supports 28.8 Kbps modem speeds or lower,
depending on telephone line conditions.
† When the system is configured with 40MB memory, battery backup is
reduced to three hours maximum (see page 3).
†† Based on 4% Original, 5% Coverage.
††† Actual Compression Ratio may vary with image.
▲ Based on ITU-T No. 1 Chart (Standard Mode).
▲▲ Requires 500-Sheet letter-sized cassette.
n Requires Network Kit III.
nn Requires Printer Kit III.
Mail Server acts like
a Post Office
Mail Server
E-Mail
Scanning Method:
Document Sizes:
With Handset:
• Send a fax to an e-mail address
• Receive a G3 fax and forward it to e-mail
Type:
Applicable Line:
Compatibility:
Automatic Document Feeder:
PC
LAN
E-Mail
©2005 Canon U.S.A., Inc. All rights reserved.
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY
STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S.
marks. Windows and Windows NT are registered trademarks of Microsoft Corporation in the United
States and/or other countries. Novell and NetWare are registered trademarks of Novell, Inc. in the
United States and other countries. IPX/SPX is a trademark of Novell, Inc. Solaris is a trademark of Sun
Microsystems, Inc. in the United States and other countries. Flash is a trademark of Macromedia, Inc.
in the United States and/or other countries. CANON and LASER CLASS are registered trademarks, and
the SUPER G3 logo is a trademark of Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries. IMAGEWARE is a registered trademark of Canon U.S.A., Inc.
in the United States and is a trademark of Canon Inc. in certain other countries. IMAGEANYWARE is a
trademark of Canon. All referenced product names and other marks are trademarks of their respective owners.
Specifications and availability subject to change without notice.
©2007 Canon U.S.A., Inc. All rights reserved.
0113W836
0807R-LC700-2.2M-L
printed on recycled
paper in the u.s.a.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Workgroup
Systems
LASER CLASS 700 Series Specifications
WHAT IS INTERNET FAXING?
WHAT ARE TRANSFER AND TX ARCHIVE
MODES?
Internet-enabled fax machines plug into your existing data network.
They convert scanned documents into file formats that are easily
transported over the Internet or your company intranet, sending
data to e-mail address destinations or other I-fax-capable machines.
Internet faxing bypasses the public switched telephone network and
offers many advantages for your business:
• Lowers communication costs by eliminating per-call charges for each
transmission—especially for long-distance and international calls.
• Allows for simultaneous and instantaneous distribution of information to all recipients. Data is transmitted to everyone at once, at the
maximum speed of your network, eliminating delays associated
with sequential broadcast technology.
• Maintains image quality and document integrity throughout digital
transmission. Your faxes are impervious to distortion from static
and line noise, so resolution is not compromised.
• Increases productivity by eliminating busy signals and rescanning
tasks—so fax transmissions get through the first time, every time.
And since the Canon LASER CLASS 700 Series devices offer both
I-fax and Super G3 sending, total communications flexibility is at
your fingertips, allowing you to:
Transfer and TX Archive modes allow LASER CLASS 700 Series users
to archive both incoming and outgoing data to a file server, e-mail
address, fax machine, or I-fax device. Transfer Mode automatically
transmits incoming documents to other destinations for storing, while
TX Archiving automatically transmits outgoing data to other destinations.
These features offer many benefits to your business:
• Automates and simplifies the process of storing incoming and
outgoing data, eliminating the burdens associated with copying
or scanning these documents and helping to avoid manual
operation errors.
• Facilitates records retention for sent information by automatically
transmitting this information to a designated e-mail address, database, or file server.
• Ensures the security and confidentiality of customer records and
information by routing incoming faxes to a designated e-mail
address, database, or file server.
• Helps satisfy security regulations and guidelines such as those
defined by the Gramm-Leach-Bliley Act and the Sarbanes-Oxley Act.*
* Statements made in this document are the opinions of Canon U.S.A. None of these statements should be
construed to customers or Canon U.S.A.’s dealers as legal advice, as Canon U.S.A. does not provide legal counsel
or compliance consultancy, including without limitation, Sarbanes-Oxley, HIPAA, GLBA, Check 21, or the USA
Patriot Act. Each customer must have its own qualified counsel determine the advisability of a particular solution
as it relates to regulatory and statutory compliance
• Receive an I-fax and forward it to a G3 fax
• Scan images to e-mail
INTERNET
Mail Server
I-Fax
I-Fax
PC
LAN
Effective Scanning Width
LASER CLASS 710/730i:
InstaScan:
Data Compression System:
Modem Speed:
Transmission Speed:
Printing Method:
Printing Speed:
Halftone:
TX/RX Resolution
Ultra Fine Mode:
Super Fine Mode:
Fine Mode:
Standard Mode:
Effective Recording Width:
Recording Paper Supply
LASER CLASS 710/730i:
Receiving Paper Tray:
Recording Paper Size:
Enhanced Imaging Quality:
Enhanced Printing Quality:
Printing Resolution:
Printer Cartridge:
Cartridge Yield:
Power Consumption
Standby:
Max.:
Energy Saver:
Dimensions (H x W x D)
LASER CLASS 710/730i
Without Handset:
3 Options:
• I-Fax to I-Fax
• I-Fax to PC
• PC to I-Fax
Desktop Transceiver
Public Switched Telephone Network
G3
Up to 70 Sheets (Letter)*
Up to 30 Sheets (Legal)*
Up to 30 Sheets (Ledger)*
Contact Image Sensor
Maximum: 11" x 39.4" (279mm x 1000mm)
Minimum: 5.9" x 5" (148mm x 128mm)
10" (254mm)
Approx. 1.1 Sec./Page (Letter, Standard Mode)
Approx. 35 Scans/Min.(Letter, Standard Mode)
MH, MR, MMR, JBIG†††
33.6/31.2/28.8/26.4/24/21.6/19.2/16.8/
14.4/12/9.6/7.2/4.8/2.4 Kbps
Automatic Fallback
Approx. 3 Sec./Page*** (V.34/33.6 Kbps + JBIG)
Laser Dry Electrostatic Transfer
Up to 19 Pages/Min. (Letter)
256 Shades of Gray
Horizontal
Vertical
406 pels/in.
x
391 lines/in.
16 pels/mm
x
15.4 lines/mm
203 pels/in.
x
391 lines/in.
8 pels/mm
x
15.4 lines/mm
203 pels/in.
x
196 lines/in.
8 pels/mm
x
7.7 lines/mm
203 pels/in.
x
98 lines/in.
8 pels/mm
x
3.85 lines/mm
8.2" (210mm)
600 Sheets: 2 x 250-Sheet, Adjustable
Cassette; 100-Sheet MP Tray; Optional
500-Sheet Cassette (Letter)
Face-Down, Print-In-Order: 250 Sheets
Letter/Legal/A4
UHQ (Ultra High Quality)
1200-dpi Smoothing for Incoming Faxes
1200 dpi x 1200 dpi
FX7 Cartridge
Approx. 4,500 Pages††
Approx. 15W (710)
Approx. 20W (730i)
Approx. 980W
5W (710), 15W (730i)
18-1/8" x 19-3/4" x 19-3/4"
(459mm x 499mm x 499mm)
18-1/8" x 22-1/2" x 19-3/4"
(459mm x 569mm x 499mm)
Weight (Excluding Handset Option)
LASER CLASS 710:
Approx. 52 lb. 15 oz. (24kg)
LASER CLASS 730i:
Approx. 55 lb. 2 oz. (25kg)
Environmental Conditions
Temperature:
50˚F - 90.5˚F (10˚C - 32.5˚C)
Humidity:
20% - 80% RH
Dialing:
Automatic Dialing
One-Touch Speed-Dialing: 72 Locations
Coded Speed-Dialing: 128 Locations
Group-Dialing: 199 Groups
Each Group Can Accommodate up to
199 Locations
Maximum Dial Digits: 120
Error Re-Dialing
Manual Re-Dialing
Dial Search
Energy Saver Key
Programmable Key
Send Feature
LASER CLASS 730i:
LASER CLASS 710:
Sending Methods:
Number of Addresses:
File Format:
Sending Resolution
Simple Mode:
E-mail Mode:
Protocol:
Mail Address:
Send Settings:
Network Scanning:
Networking
Delayed Transmission:
Memory Polling Transmission
Polling Reception
Multi-Polling:
Delayed Polling:
Sequential Broadcast:
Options:
Standard
Optional
Super G3 is Standard on Both Models
E-mail, I-Fax, Super G3 Fax, File Server (FTP)
210
M-TIFF (MH/MR/MMR), PDF
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 100 dpi, 200 dpi x 200 dpi
200 dpi x 400 dpi, 400 dpi x 400 dpi
SMTP; POP3
5 Destinations
Document Name
Subject
Text
Signature
Priority
RX Confirmation
Message
Yes**
Up to 210 Destinations and up to
70 Reservations
Up to 210 Locations
Up to 200 Locations
Up to 5 Designated Times per Speed-Dial
Up to 210 Locations
(200 Pre-Programmed Speed-Dials)
Up to 200 Locations
Up to 50
Up to 5 Designated Times per Speed-Dial
Relay Broadcast:
Relay Boxes:
Delayed Relay Broadcast:
Relay Broadcast Command
Transmission to Confidential Mail Box
Confidential Mail Box:
Up to 50 Boxes
Memory Transmission/Reception:
LASER CLASS 710:
(8MB) Up to 510 Pages (Standard)▲
One Open Slot, Optional 32MB for
Total Capacity
LASER CLASS 730i:
(40MB) Up to 1,500 Pages▲
Receiving Restriction
Password and Sub-Address (ITU-T STD)
Convenience:
Auto Receive Reduction (70% ~ 100%)
Dual Access
TX Reservation During RX
TX Reservation During Memory TX
Memory RX During Copy
Memory TX During Copy
Scan During Printing
Transmission Reservation:
Up to 70 Reservations
LCD (Liquid Crystal Display):
20-Digits x 2-Line
Department Access Code:
Up to 99 Codes
Local Copy Function:
Multiple Copy up to 99 Pages
Program Buttons:
Up to 72
Memory Lock Reception
Battery Backup:
Up to 12 Hours† (710)
Up to 3 hours (730i)
RX Document Multiple Printout: Up to 99 Pages
RX Page Footer:
Yes
Transfer Mode:
Yes
Soft Counter:
Yes
Report/Reference:
Activity Report (up to 40 Transactions)
Non-Delivery Report
Management Report
List of Phone Numbers for One-Touch
and Coded Speed-Dialing
List of Transaction Schedule
User Data List
File Reference
TTI (Transmitter Terminal Identification)
TTI Selector: Up to 99 Identifications
RTI (Remote Terminal Identification)
33.6 Kbps Dual Line
Printer Kit III (for 710 Only)
Network Kit III (for 710 Only)
500-Sheet Cassette (Letter)
Stamp
Stamp Refill
Braille Kit D-1
Telephone Handset Kit 8
Pedestal▲▲ (H x W x D):
17-3/4" x 18-7/8" x 17-1/2"
(450mm x 478mm x 444mm)
Provided by Third-Party:
Facsimile Memory: 32MB (710 Only)
Printer Memory: 32MB, 64MB
Printer Kit III (Optional for 710; Standard for 730i)
Type:
Embedded Print Controller
Processor:
Power PC405 200MHz RISC Processor
Memory:
Standard 8MB (72MB Max.)
PDL Support:
PCL 5e, PCL 6, PJL
Internal Fonts:
PCL 5e/6: 45 Roman Fonts,
32 Bar Code Fonts
Interface Connections:
Parallel (IEEE 1284)
USB Optional RJ-45 (10/100Base-T)
(Compatibility: Nibble, Byte, and ECP Mode)
Memory:
8MB (72MB Max.)
Paper Sizes:
A4/A/B5/Executive/Legal/Letter/Postcard/
Double Postcard/C5/COM10/Monarch/DL
Media Type:
Plain Paper/Heavy Paper/Recycled Paper/
Colored Paper/Bond Paper/Plain Paper 2
Notification Job Completion:
Yes (E-Mail) n
Toner Saver:
Yes
Duplex Printing (Print Jobs):
Yes
Network Kit III (Optional for 710nn; Standard for 730i)
CPU:
ETRAX 100LX (32-Bit RISC CPU 100MHz)
Memory (RAM):
4MB
Storage (ROM):
2MB (Flash™)
SDRAM:
128 Kbps
Network I/F:
10Base-T, 100Base-TX (RJ-45)
Printer I/F:
EPS10 v. 1.00
Network OS:
Novell® NetWare® v.3.2, 4.1, 4.11, 4.2,
5.0, 5.1 (IPX/SPX™)
Windows® 95/98/Me/Windows NT ® 4.0/
Windows 2000/XP (TCP/IP)
Solaris™ 1.1x, 2.5 or Later (TCP/IP)
Protocol Stacks:
IPX/SPX: 802.2, 802.3, Ethernet II,
802.2 SNAP (Ethernet SNAP)
TCP/IP: Ethernet II
NetBEUI (NetBIOS): 802.2
Other Features:
Remote UI Supported
imageWARE Enterprise Management Console
Limited Warranty:
90 Days
* 15-27.5˚ C; 20-80% RH; 20 lb., < 120 µm
** Scan-to-E-mail functionality
*** Approximate 3-second-per-page fax transmission time based on ITU-T
No. 1 Chart (JBIG, Standard Mode) at 33.6 Kbps modem speed when
transmitting to another V.34 machine. The Public Switched Telephone
Network (PSTN) currently supports 28.8 Kbps modem speeds or lower,
depending on telephone line conditions.
† When the system is configured with 40MB memory, battery backup is
reduced to three hours maximum (see page 3).
†† Based on 4% Original, 5% Coverage.
††† Actual Compression Ratio may vary with image.
▲ Based on ITU-T No. 1 Chart (Standard Mode).
▲▲ Requires 500-Sheet letter-sized cassette.
n Requires Network Kit III.
nn Requires Printer Kit III.
Mail Server acts like
a Post Office
Mail Server
E-Mail
Scanning Method:
Document Sizes:
With Handset:
• Send a fax to an e-mail address
• Receive a G3 fax and forward it to e-mail
Type:
Applicable Line:
Compatibility:
Automatic Document Feeder:
PC
LAN
E-Mail
©2005 Canon U.S.A., Inc. All rights reserved.
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY
STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S.
marks. Windows and Windows NT are registered trademarks of Microsoft Corporation in the United
States and/or other countries. Novell and NetWare are registered trademarks of Novell, Inc. in the
United States and other countries. IPX/SPX is a trademark of Novell, Inc. Solaris is a trademark of Sun
Microsystems, Inc. in the United States and other countries. Flash is a trademark of Macromedia, Inc.
in the United States and/or other countries. CANON and LASER CLASS are registered trademarks, and
the SUPER G3 logo is a trademark of Canon Inc. in the United States and may also be registered trademarks or trademarks in other countries. IMAGEWARE is a registered trademark of Canon U.S.A., Inc.
in the United States and is a trademark of Canon Inc. in certain other countries. IMAGEANYWARE is a
trademark of Canon. All referenced product names and other marks are trademarks of their respective owners.
Specifications and availability subject to change without notice.
©2007 Canon U.S.A., Inc. All rights reserved.
0113W836
0807R-LC700-2.2M-L
printed on recycled
paper in the u.s.a.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Workgroup
Systems
