Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/global/regist
er
The HD camcorder is capable of recording and playing back both High Definition (HD: 1280x720p) and Standard
Definition (SD: 720x480p) image quality, Select the recording image quality, HD (high definition) or SD (standard definition),
before recording,
ENJOYING
IMAGES
WITH
HIGH
DEFINITION
You can view record video with HD (high definition)
,,
,,
,,
(HD)
QUALITY
image quality.
This HD camcorder offers 720p resolution with a sharper image than previous SD camcorders (480i).
It also supports widescreen recording with an aspect ratio of 16:9.
Recordings made in HD (high definition) image quality will fit widescreen (16:9) HDTVs.
If your TV is not a high definition T_, movies with HD (high definition) image quality will be displayed with SD
(standard definition) image quality.
To enjoy HD quality images, you need a TV supporting 1280x720p input.
(Refer to the user manual of your T_)
To enjoy the HD quality images, use an HDMI or Component cable.
The multi AV cable does not support HD quality images so it down converts them to SD quality images.
The image is recorded in 720x480p when the quality is set to SD in the HD camcorder.
Videos recorded at SD (standard definition) image quality cannot be converted to HD (high definition).
72O
72O
48O
<720p/16:9
high definmon camcoraer>
image resolution: about 5 times that of orevious SD camcorders
ii
Engii:sh
<4_:)_/ normal dJ__a_camooraer>
'480i
FEATURES OF YOUR NEW HD CAMCORDER
1.61 Mega pixel (Gross) CMOS sensor
1/4.5" CMOS sensor provides stunning detail and clarity with exceptional video (1280 lines of resolution HD mode
or 720 lines of horizontal resolution SD mode) and still image performance (3.0 mega pixels). Unlike traditional CCD
imagers, CMOS sensors require less power, providing better battery performance.
High-capacity
embedded flash memory (SC-HMXl 0A/HMXl 0C only)
The HD camcorder has built-in high capacity flash memory that allows you to record movie or photo images.
H.264 (MPEG4 partl0/AVC)
encoding
The latest video compression technology, H.264 uses a high compression
time for the same size storage.
rate to sharply increase the recordable
HDMI interface (Anynet+ supported)
,, If you have an HDTV with an HDMI jack, you can enjoy a clearer and
sharper image when compared to a standard definition TV
,, This HD camcorder supports Anynet+.
Anynet+ is an AV network system that enables you to control all connected
Samsung AV devices with an Anynet+ supported Samsung TV remote
control. Refer to the corresponding TV's user manual for more details.
2.7" wide (16:9) touch panel LCD screen (230K pixels)
The 2.7" wide (16:9) LCD screen provides excellent viewing clarity with improved
resolution. The 230K pixel LCD screen rotates up to 270 degrees for multiple viewing
angles providing sharp, detailed images for monitoring or playback, and the widescreen
format makes shooting in 16:9 mode and composing shots even easier.
Touch panel adopted
You can play recorded images and set functions by simply tapping on the LCD screen.
Swivel handle for free style shooting
You can adjust the swivel handle's angle up to 150 ° to suit the recording situation.
English
iii
J
What the icons and signs in this user manual mean;
Z_
Means that death or serious personal injury is a risk.
WANNING
Z_
Means that there is a potential risk for personal injury or material damage.
CAUTION
CAUTION
[]
To reduce the risk of fire, explosion, electric shock, or personal injury when using your HD
camcorder, follow these basic safety precautions:
Means hints or referential pages that may be helpful when operating the HD camcorder.
These warning signs are here to prevent injury to you and others.
Please follow them explicitly. After reading this section, keep it in a safe place for future reference.
rnr or snt ssf tv nstnA<;tons
I
J
This symbol indicates that dangerous voltage consisting a risk of
electric shock is present within this unit.
OAUTION: TO REDUCETHE RISKOF ELECTRICSHOCK,
DONOT REMOVEOOVER DR RACK)
NO USER SERVICEABLEPARTSINSIDE
REFERSERVICINGTO QUALIFIEDSERVICEPERSONNEL
Warning
To Reduce
The Risk Of Fire Or Electric
Shock,
English
J
This symbol indicates that there are important operating and
/
maintenance instructions in the literature accompanying this unit.
J
Do Not Expose
This Apparatus
To Rain Or Moisture."
Caution
Apparatus
shall not be exposed
to dripping
or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
To disconnect
the apparatus
from the mains, the plug must be pulled out from the mains socket, therefore the mains
plug shall be readily operable.
iv
/
|
rnoor nt
I
n tr Aot
J
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachmentJaccessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the carVapparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power_supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
16. VENTILATION:
Slots and openings in the cabinet are provided
for ventilation to ensure reliable operation of the
CAMCORDER and to protect it from overheating.
These openings must not be blocked or covered.
Never place your CAMCORDER on a bed, sofa, rug,
or other similar surface: on or near a radiator or heat
register. This CAMCORDER should not be placed in a
built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer's
instructions have been adhered to.
English v
