BLUE POWER
World quality leader in independent electric power
ABOUT VICTRON ENERGY
With over 30 years’ experience, Victron Energy enjoys an unrivalled reputation for technical innovation,
reliability and quality, and is a world leader in the supply of self-supporting electric power. Our products
have been designed to meet the most demanding situations faced by a diversity of craft, recreational
and commercial alike, whilst we also cater for many other industrial and commercial applications. Our
product range includes sine wave inverters and inverter/chargers, battery chargers, DC/DC converters,
transfer switches, Gel and AGM batteries, alternators, battery monitors, complete network solutions and many other
innovative solutions.
[ Appliance ]
[ Products range ]
[ Applications ]
Victron pure sine wave inverters can
be used for: computer, TV, stereo audio
system, microwave, refrigerator, coffee
maker, radar and navigation system,
lighting, power tools and other electric
household equipment.
•
•
•
•
•
•
•
•
•
•
•
•
•
• Solar and wind power systems
• Yachts and commercial vessels
• Special vehicles such as live
broadcasting vehicles,
ambulances, service vans, trains,
caravans etc
• Industrial
• Emergency power supply
• Remote areas where there is no
continuous supply of 230V AC
Sinewave Inverters
Combined Inverter/chargers
Automatic Battery Chargers
DC DC Converters
Transfer Switches
Deep Cycle Gel and AGM batteries
High Power Alternators
Battery Monitors
DC Distribution Units
Control and Distribution Panels
Battery Isolators
Shore Power Connection Kits
System Monitoring and Control
[ World-wide service and support ]
Having served both the commercial and
leisure marine sectors as well as vehicle and
industrial markets for over 30 years, Victron has an
established network of dealers and distributors
covering the whole world. Our customer base
is such that providing prompt and competent
local service is essential and this is reflected in the
capabilities of our support network. Our flexible approach to service support and our
commitment to quick turnaround for repairs
is market-leading. There are countless examples of Victron products that have provided
decades of reliable service in the most demanding applications. This level of reliability
combined with the highest level of technical
know-how means that Victron Energy power
systems offer the very best value available.
PHOENIX INVERTER
230VAC/50HZ
[ 12V: 180-5000 VA ]
[ 24V: 180-5000 VA ]
[ 48V: 180-5000 VA ]
CHARACTERISTICS
• SinusMax - Superior engineering
True sine wave inverter with optimised efficiency but without compromise in performance.
Employing hybrid HF technology, the result is a top quality product with compact
dimensions, light in weight and capable of supplying power, problem-free, to any load.
• Extra start-up power
A unique feature of the SinusMax technology is very high start-up power. Phoenix inverters,
however, are well suited to power up difficult loads such as refrigeration compressors,
electric motors and similar appliances.
• Virtually unlimited power thanks to parallel and 3-phase operation capability
Up to 6 units Phoenix 24/3000 can operate in parallel to achieve
Operation in 3-phase configuration is also possible.
18KVA
power
output.
• To transfer the load to another AC source: the automatic transfer switch
If an automatic transfer switch is required on models rated at 1200 VA or more, we recommend using the Phoenix Multiplus instead. The switch is included in these products
and the charger function of the Multi can be disabled. For our lower power models we
recommend the use of our Filax Automatic Transfer Switch. Computers and other electronic
equipment will continue to operate without disruption because both the Filax and the
Phoenix Multi feature a very short switchover times (less than 20 milliseconds).
• Computer interface
All models rated at 1200 VA or more have a RS-485 computer interface. Together with the
VEConfigure software, all parameters of the inverters can be customised. The inverters can
also be connected to VEnet, the new power control network of Victron Energy.
ACCESSORIES
BMV-600
Battery Monitor
Phoenix 12 Volt
inverter 14 Volt
48 Volt
12/180
24/180
48/180
12/350
24/350
48/350
12/750
24/750
48/750
C12/1200
C24/1200
C12/1600
C24/1600
C12/2000
C24/2000
12/3000
24/3000
48/3000
12/5000
24/5000
48/5000
Input voltage range (VCD)
10.5 - 15.5
21.0 - 31.0
42.0 - 62.0
10.5 - 15.5
21.0 - 31.0
42.0 - 62.0
10.5 - 15.5
21.0 - 31.0
42.0 - 62.0
9.5 - 16
19.5 - 32.2
9.5 - 16
19.5 - 33
9.5 - 16
19.5 - 33
9.5 - 16
19.5 - 33
38 - 66
9.5 - 16
19.5 - 33
38 - 66
Cont. output power at 25 ˚C (VA)
180
350
750
1200
1600
2000
3000
5000
Cont. power at 25 ˚C / 40 ˚C (W)
175 / 150
300 / 250
700 / 650
1000 / 900 (4)
1300 / 1200 (4)
1600 / 1450 (4)
2500 / 2000 (4)
4250 / 3350 (4)
Peak power (W)
(W)
200
500
1400
2200
2300
3000
4000
6000
7500
Max. Efficiency 12/24/48 V (%)
91 / 92 / 92
90 / 91 / 92
91 / 93 / 94
93 / 94
93 / 94
93 / 94
93 / 94 / 95
92 / 94 / 95
Zero-load power 12/24/48V (w)
2.2 / 3.0 / 4.0
3.0 / 3.5 / 4.0
12 / 12 / 12
8 / 11
8 / 11
10 / 10
15 / 15 / 16
25 / 30 / 30
Zero-load power in AES mode
n.a.
n.a.
3/4/5
Muti purpose relay
driver or relay
a,b,d,h
a,b,d,h
5/8
5/8
8/10
10/10/12
15/20/20
relay driver (2)
relay driver (2)
relay driver (2)
relay (3)
relay (3)
a,b,d,c,d,f,g,h
a,b,d,c,d,f,g,h
a,b,d,c,d,f,g,h
a-h
a-h
Protection (5)
a,b,d,h
Common Characteristics
Output: 230 V ± 2% /50/60 Hz ± 0,2% (switch selectable) Operating temperature range: -20 to +50˚C Humidity: max 95%
ENCLOSURE
Phoenix Inverter
Control (PIV)
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
1)
1)
1)
M8 Studs
M8 Studs
230 V AC-connection
IEC-320 (IEC-320 plug included) or Schuko
G-ST18i
G-ST18i
Spring-clamp
Screw-clamp
Protection category
IP20
IP20
IP20
IP21
IP21
IP21
IP21
Weight (kg)
2.7
3.5
2.7
10
10
12
18
30
Dimensions (hxwxd in mm)
72x132x200
72x155x237
72x180x295
375x214x110
375x214x110
520x255x125
362x258x218
444x328x240
√ (PIV)
√ (PIV)
√ (PIV)
√ (PIV)
√ (PIV)
Remote on-off switch
√
√
√
√
√
√
√
Automatic transfer switch
FILAX
FILAX
FILAX
Phoenix Multi
Safety
EN 60950
EN 60950
EN 60950
EN 60335-1
Emission / Imunnity
EN 55014-1 / EN55014-2
Automotive Directive
95/54/EC and 2004/104/EC
1)
Screw conn.
4 M8 bolts
IP21
ACCESSORIES
Remote panel (RS485)
Computer controlled
operation and
monitoring (Victron
Interface Mk2)
Battery Alarm An
excessively high
or low battery
voltage is indicated
by an audible and
visual alarm, and a
relay for remote
signailing.
√
Quattro
STANDARDS
1) Battery cables of 1.5 meter
genset starts signal function
a. Output short circuit
e. Battery reverse polarity detection
2) Relay driver: open Collector 66V
4) Suitable for parallel and 3-phase
b. Overload
f. 230 V AC on inverter output
EN 60335-1
EN 60335-1
EN 60335-1
EN 60335-1
3) Multipurpose relay which can be set for general alarm, DC undervoltage or
5) Protection
c. Battery voltage too high
d. Battery voltage too low
g. Input voltage riplle too high
h. Temperature too high
PHOENIX INVERTER
120VAC/60HZ
[ 12V: 180-5000 VA ]
[ 24V: 180-5000 VA ]
CHARACTERISTICS
• SinusMax - Superior engineering
True sine wave inverter with optimised efficiency but without compromise in performance.
Employing hybrid HF technology, the result is a top quality product with compact
dimensions, light in weight and capable of supplying power, problem-free, to any load.
• Extra start-up power
A unique feature of the SinusMax technology is very high start-up power. Phoenix inverters,
however, are well suited to power up difficult loads such as refrigeration compressors,
electric motors and similar appliances.
• Virtually unlimited power thanks to parallel and 3-phase operation capability
Up to 6 units Phoenix 24/3000 can operate in parallel to achieve 18KVA power output.
Operation in 3-phase configuration is also possible.
• To transfer the load to another AC source: the automatic transfer switch
If an automatic transfer switch is required on models rated at 1200 VA or more, we recommend using the Phoenix Multiplus instead. The switch is included in these products
and the charger function of the Multi can be disabled. For our lower power models we
recommend the use of our Filax Automatic Transfer Switch. Computers and other electronic
equipment will continue to operate without disruption because both the Filax and the
Phoenix Multi feature a very short switchover times (less than 20 milliseconds).
ACCESSORIES
BMV-600 Battery Monitor
Phoenix 12 Volt
inverter 24 Volt
12/180
24/180
12/350
24/350
12/750
24/750
C12/2000
C24/2000
12/3000
24/3000
12/5000
24/5000
Input voltage range (VCD)
10.5 - 15.5
21.0 - 31.0
10.5 - 15.5
21.0 - 31.0
10.5 - 15.5
21.0 - 31.0
9.5 - 16
19.5 - 33
9.5 - 16
19.5 - 33
9.5 - 16
19.5 - 33
Cont. output power at 25 ˚C (VA)
180
350
750
2000 (4)
3000 (4)
5000 (4)
Cont. power at 25 ˚C / 40 ˚C (W)
175 / 150
300 / 250
700 / 650
1600 / 1450
2500 / 2000
4250 / 3350
Peak power (W) (W)
200
500
1400
4000
6000
7500
Max. Efficiency 12/24/48 V (%)
91 / 92
90 / 91
91 / 93
93 / 94
93 / 94
92 / 94
Zero-load power 12/24/48V (w)
2.2 / 3.0
3.0 / 3.5
12 / 12
10 / 10
15 / 15
25 / 30
Zero-load power in AES mode
n.a.
n.a.
3/4/5
Muti purpose relay
driver or relay
a,b,d,h
a,b,d,h
8 / 10
10 / 10
15 / 20
relay driver (2)
relay (3)
relay (3)
a,b,d,c,d,f,g,h
a-h
a-h
4M8 botts
Protection (5)
a,b,d,h
Common Characteristics
Output: Output: 120 V ± 2% / 60 Hz ± 0,2% (switch selectable)
Operating temperature range: 0 - 122 ˚F Humidity: max 95%
ENCLOSURE
Phoenix Inverter
Control (PIV)
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
1)
230 V AC-connection
NEMA5-15R
Protection category
IP20
IP20
Weight (kg)
2.7
3.5
Dimensions (hxwxd in mm)
72x132x200
Remote on-off switch
Automatic transfer switch
1)
Screw conn.
M8 Studs
M8 Studs
Spring-clamp
Screw-clamp
IP20
IP21
IP21
2.7
12
18
30
72x155x237
72x180x295
520x255x125
362x258x218
444x328x240
√ (PIV)
√ (PIV)
√ (PIV)
√
√
√
√
√
FILAX
FILAX
FILAX
Phoenix multi
EN 60950
EN 60950
EN 60950
EN 60335-1
IP21
ACCESSORIES
Remote panel (RS485)
Computer controlled
operation and
monitoring (Victron
Interface Mk2)
STANDARDS
Safety
Emission / Imunnity
Automotive Directive
Battery Alarm
An excessively high or
low battery voltage is
indicated by an audible
and visual alarm, and
a relay for remote signailing.
√
Quattro
EN 60335-1
EN 55014-1 / EN55014-2
95/54/EC and 2004/104/EC
1) Battery cables of 1.5 meter
2) Relay driver: open Collector 66V
3) Multipurpose relay which can be set for general alarm, DC undervoltage or genset starts signal function
4) Suitable for parallel and 3-phase
5) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Battery reverse polarity detection
f. 230 V AC on inverter output
g. Input voltage riplle too high
h. Temperature too high
EN 60335-1
PHOENIX MULTIPLUS
230VAC/50HZ
[ 12V: 800-3000 VA ]
[ 24V: 800-3000 VA ]
[ 48V: 3000 VA ]
CHARACTERISTICS
• Multi-functional, with intelligent mains and generator power management
The multi gets its name from the multiple functions it can perform. It is a powerful true sine wave inverter, a sophisticated
battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact
enclosure.
• Uninterrupted AC power (UPS function)
In the event of a grid failure, or mains or generator power being disconnected, the inverter within the Multi is automatically
activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that
computers and other electronic equipment will continue to operate without disruption.
• PowerControl - Dealing with limited generator, shore side or grid power
With the Phoenix Multi Control Panel a maximum generator or shore current can be set. The Multi will then take account of
other AC loads and use whatever is extra for charging, this preventing the generator or mains supply from being
overloaded.
• PowerAssist - Boosting the capacity of grid or generator power, an innovative feature of the MultiPlus
This feature takes the principle of PowerControl to a further dimension allowing the MultiPlus to supplement the capacity
of the alternative source. Where peak power is so often required only for a limited period, the Phoenix MultiPlus will make
sure that insufficient shore or generator power is immediately compensated for by power from the battery.
• Four stage adaptive charger and dual bank battery charging
The main output provides a powerful charge to the battery system by means of advanced ‘adaptive charge’ software that
fine-tunes the three stage automatic process to suit the condition of the battery, and adds a fourth stage for long periods
of float charging. In addition to this, the Multi will charge a second battery using an independent trickle charge output
intended for a main engine or generator starter battery.
ACCESSORIES
Phoenix Multi Control
This is a remote control
and monitoring panel
for the Phoenix Multiplus
Multiplus 12V / 24V / 48V
C12/800/35
C24/800/16
PowerControl
Yes
C12/1200/50
C24/1200/25
PowerAssist
-
Yes (Multiplus)
Transfer switch (A)
16
16
C12/1600/70
C24/1600/40
C12/2000/80
C24/2000/50
16
30
12/3000/120
24/3000/70
48/3000/35
Yes
16 or 50
INVERTER
Input voltage range (VCD)
9.5-17V
Output
230 V ± 2% /50 Hz ± 0,1%
19-33V
38-66V
Cont. output power at 25 ˚C (VA) (5)
800
1200
1600
2000
3000 (4)
Cont. output power at 25/40 ˚C (W)
700/650
1000/900
1300/1200
1600/1450
2500/2000
Peak power (W)
1600
2400
3000
4000
6000
Maximum efficiency (%)
92/94
93/94
93/94
93/94
93/94/95
Zero-load power (W)
5/8
5/8
5/8
10/10
10/10/12
80 / 50
120 / 70 / 40
CHARGER
VVC: VE.Net to VE BUS
Converter
AC input
187-265 VAC, 45-55 HZ, Power factor:1
Charge voltage ‘absorption’ (V DC)
14.4 / 28.8 / 57.6
Charge voltage ‘float’ (V DC)
13.8 / 27.6 / 55.2
Storage mode (V DC)
13.2 / 26.4 / 52.8
Charge current house battery (A)(4)
35 / 16
Charge current starter battery (A)
4
Battery temperature sensor
Yes
50 / 25
70 / 40
GENERAL
Victron Global Remote
Multi purpose relay driver or relay
Relay driver (2)
Relay (3)
Protection (5)
a,b,c,d,f,g,h
a-h
Common Characteristics
Operating temp. range: -20 - 50 ˚C (fan assisted cooling)
Humidity (non condesing) : max 95%
ENCLOSURE
Common Characteristics
Material & Colour: aluminum (blue RAL 5012)
Battery-connection
(1)
M8 Studs
230 V AC-connection
G-ST 18i
Spring-clamp
Scre-clamp
Protection category
IP 21
Weight (kg)
10
12
18
Dimensions (hxwxd in mm)
375x214x110
520x255x125
362x258x218
10
10
STANDARDS
Safety
EN 60335-1,
EN60335-2-29
Emission / Immunity
EN 55014-1,
EN 55014-2 / EN 61000-3-2,
Automotive Directive
95/94/EC and 2004/104/EC
EN 61000-3-3
1) Battery cables of 1.5 meter
2) Relay driver: open Collector 66V
3) Multipurpose relay which can be set for general alarm, DC undervoltage or genset starts signal function
4) Suitable for parallel and 3-phase
5) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Battery reverse polarity detection
f. 230 V AC on inverter output
g. Input voltage riplle too high
h. Temperature too high
QUATTRO 5KVA
230VAC/50HZ
[ 24V: 3000 VA ]
[ 24V: 5000 VA ]
[ 48V: 5000 VA ]
CHARACTERISTICS
• Two AC inputs with integrated transfer switch
• Two AC outputs
The main output has no-break functionality. The second output is live only when AC is available on
one of the inputs of the Quattro.
• Virtually unlimited power thanks to parallel operation
Up to 6 Quattro’s can operate in parallel.
• Three phase capability
Three units can be configured for three-phase output.
• PowerControl - Dealing with limited generator, shore-side or grid power
• PowerAssist - Boosting shore or generator power
• Solar energy: AC power available even during a grid failure
The Quattro can be used in off grid as well as grid connected PV and other alternative
energy systems.
• A grid connected PV system will shit down when the grid fails! Not anymore with a
Quattro and batteries
Quattro
24/3000/70
24/5000/120
48/5000/70
PowerControl / PowerAssist
Yes
Yes
Yes
Integrated Transfer switch
Yes
Yes
Yes
AC inputs (2x)
Input voltage range: 187-265 VAC
Input frequency: 45-55 Hz
Power factor: 1
Maximum feed through current (A)
50
30
30
19-33
38-66
INVERTER
Input voltage range (V DC)
19-33
Output (1)
Output voltage: 230 VAC ± 2%
Frequency: 50 Hz ± 0.1 %
Cont. output power at 25 ˚C (VA) (2)
3000
5000
5000
Cont. output power at 25 ˚C (W)
2500
4250
4250
Cont. output power at 40 ˚C (W)
2000
3350
3350
Peak power (W)
6000
7500
7800
Maximum efficiency (%)
94
94
95
Zero-load power (W)
15
30
30
Load shedding output
25
10 Switches off when no external AC source available
CHARGER
Charge voltage ‘absorption’ (V DC)
28.8
28.8
57.6
Charge voltage ‘float’ (V DC)
27.6
27.6
55.2
Storage mode (V DC)
26.4
26.4
52.8
Charge current house battery (A)
70
120
70
Charge current starter battery (A)
4
Battery temperature sensor
Yes
Yes
Yes
Multi purpose relay (1)
Yes
Yes
Yes
Protection (3)
a-f
Common Characteristics
Operating temp.: -20 to +50 ˚C (fan assisted cooling) Humidity (non condensing) : max 95%
GENERAL
ENCLOSURE
Common Characteristics
Material & Colour: aluminium (blue RAL 5012)
Battery-connection
Four M8 bolts (2 plus and 2 minus connections)
230 V AC-connection
Screw clamp 13 mm² (AWG 6)
Weight (kg)
30
Dimensions (hxwxd in mm)
362x258x218
Protection category: IP 21
444x328x240
STANDARDS
Safety
EN 60335-1, EN 60335-2-29
Emissions / immunity
EN 55014-1, EN 61000-3-2 / EN 55014-2, EN61000-3-3
Automotive Directive
2004/104/EC
1) Multipurpose relay which can be set for general alarm, DC undervoltage or genset starts signal function
2) Suitable for parallel and 3-phase
3) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Battery reverse polarity detection
f. 230 V AC on inverter output
g. Input voltage riplle too high
h. Temperature too high
PHOENIX MULTIPLUS/QUATTRO
120VAC/60HZ
[ 12V: 2000-5000 VA ]
[ 24V: 2000-5000 VA ]
CHARACTERISTICS
• Multi-functional, with intelligent shore and generator power management
The multi gets its name from the multiple functions it can perform. It is a powerful true sine wave inverter, a sophisticated
battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact
enclosure.
• Uninterrupted AC power (UPS function)
In the event of a grid failure, or mains or generator power being disconnected, the inverter within the Multi is automatically
activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that
computers and other electronic equipment will continue to operate without disruption.
• Virtually unlimited power thanks to parallel operation and three phase capability
Up to 6 Multi’s can operate in parallel to achieve higher power output. Three units of the same model can be configured for
three-phase output.
• PowerControl - Dealing with limited generator or grid power
With the Phoenix Multi Control Panel a maximum generator or shore current can be set. The Multi will then take account of
other AC loads and use whatever is extra for charging, this preventing the generator or shore supply from being
overloaded.
• PowerAssist - Boosting the capacity of shore or generator power, an innovative feature of the MultiPlus
This feature takes the principle of PowerControl to a further dimension allowing the MultiPlus to supplement the capacity
of the alternative source. Where peak power is so often required only for a limited period, the Phoenix MultiPlus/Quattro will make
sure that insufficient shore or generator power is immediately compensated for by power from the battery.
• Four stage adaptive charger and dual bank battery charging
The main output provides a powerful charge to the battery system by means of advanced ‘adaptive charge’ software that
fine-tunes the three stage automatic process to suit the condition of the battery, and adds a fourth stage for long periods
of float charging. In addition to this, the Multi will charge a second battery using an independent trickle charge output
intended for a main engine or generator starter battery.
Multiplus
12V / 24V
Input 1
12/2000/80-120/240V
24/2000/50-120/240V
12/3000/120-120V 12/3000/120-120V
24/3000/70-120V 24/3000/70-120V
Quattro 12/5000/200 - 120/240V
Quattro 24/5000/120 - 120/240V
30 A
60 A
120Vac
L1-1
120Vac
PowerControl
Yes
PowerAssist
Yes
Transfer switch (A)
30/50 A
L2-1
Output
N1
GND
L1 ( no break)
120Vac
50 A
120Vac
L2
INVERTER
N
Input 2
Input voltage range (V DC)
9.5-17V
Output
Output voltage: 120 VAC ± 2%
19-33V
Cont. output power at 25 ˚C (VA) (2)
2000
3000
3000
5000
Cont. output power at 25/40 ˚C (W)
1600/1450
2500/2000
2500/2000
4250/3350
Peak power (w)
4100
6000
6000
7500
Maximum efficiency (%)
93/94
93/94
93/94
92/94
Zero-load power (W)
10/10
15/15
15/15
25/30
GND
120Vac
L1-2
Frequency: 60 Hz ± 0,1%
120Vac
L2-2
N2
GND
CHARGER
AC input
120VAC split-phase version
Input 1
230Vac
120V or 120/240V Input voltage range: 95-140 VAC Input frequency: 45 65 Hz Power factor:1
Charge voltage ‘absorption’ (V DC)
14.4/28.8
Charge voltage ‘float’ (V DC)
13.8/27.6
Storage mode (V DC)
13.2/26.4
Charge current house battery (A)
80/50
Charge current starter battery (A)
4
Battery temperature sensor
Yes
120/70
120/70
200/120
L1-1
GENERAL
Output
N1
GND
Input 2
L1 ( no break)
L1-2
N2
GND
Relay
Protection (3)
a-h
Common characteristics
Operating temp. range: 0-120 ˚F (fan assisted cooling)
Humidity (non condensing): max 95%
N
GND
230Vac
Multi purpose relay driver or relay (1)
230Vac
ENCLOSURE
Common Characteristics
Material & Colour: aluminum (blue RAL 5012)
Battery-connection
M8 Studs
230 V AC-connection
Spring-clamp
Protection category: IP 21
Four M8 Blots (2+, 2-)
Screw-clamp
Protection category
IP 21
Weight (kg)
12
18
18
30
Dimensions (hxwxd in mm)
520x255x125
492x258x218
362x258x218
444x328x240
STANDARDS
Safety
EN 60335-1, EN 60335-2-29
Emission / Immunity
EN 55014-1, EN 55014-2/EN61000-3-2, EN 61000-3-3
Automotive Directive
95/54/EC abd 2004/104/EC
230 VAC single-phase version
1) Multipurpose relay which can be set for general alarm, DC undervoltage or genset starts signal function
2) Suitable for parallel and 3-phase
3) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Battery reverse polarity detection
f. 230 V AC on inverter output
g. Input voltage riplle too high
h. Temperature too high
BLUE POWER BATTERY CHARGER IP20
[ 12V: 7-15 A ]
[ 24V: 5-8 A ]
CHARACTERISTICS
• Universal input: 90-265 VAC or 90-350 VDC
The charger will operate on whatever supply is available.
• Adaptive 4-stage charge characteristics: bulk - absorption - float - storage
The Blue Power charger features a microprocessor controlled ‘adaptive’ battery management.
The ‘adaptive’ feature will automatically optimise the charging process relative to the way the
battery is being used.
• Less maintenance and aging when the battery is not in use: the Storage Mode
The storage mode kicks in whenever the battery has not been subjected to discharge during
24 hours. In the storage mode float voltage is reduced to 2,2 V/cell (13,2 V for a 12 V battery) to
minimise gassing and corrosion of the positive plates. Once a week the voltage is raised back to the
absorption level to ‘equalize’ the battery. This feature prevents stratification of the electrolyte and
sulphation, a major cause of early battery failure.
• Protected against overheating and silent fan cooling
Output current will reduce as temperature in creases up to 60˚C but the Blue Power charger will not
fail. The load and temperature controlled fan is practically inaudible.
• Two LED’s for status indication
Yellow LED: bulk charge (blinking fast), absorption (blinking slow). float (solid)
Green LED: power on
Blue power charger IP 20
24/5
24/8
12/7
12/10
12/15
Input voltage range
90-265 VAC, 90-350 VDC
Frequency
45-65 or DC
Charge voltage ‘absorption’ (V DC)
14.4
28.8
Charge voltage ‘float’ (V DC)
14
28
Charge voltage ‘storage’ (V DC)
13.2
26.4
Charge current (A)
7/10/15
5/8
Charge characteristic
4-stage adaptive
Minimum battery capacity (Ah)
24/36/55
Can be used as power supply
Yes
Protection
Battery reverse polarity (fuse in battery cable)
Output short circuit, over temperature
Operating range
-20 tot 60 °C
16/24
Humidity: Max 95%
ENCLOSURE
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
Black and red cable of 1,5 meter
230 V AC-connection
Cable of 1,5 meter with Europe class 1 plug (CE certified)
Protection category
IP20
Weight (kg)
1.3
Dimensions (hxwxd in mm)
50x85x200
STANDARDS
Safety
EN60335-1, EN60335-2-29
Emission
EN55014-1, EN61000-3-2
Immunity
EN55014-2, EN61000-3-3
BLUE POWER BATTERY CHARGER IP67
[ 12V: 7-17 A ]
[ 24V: 3-12 A ]
CHARACTERISTICS
• Completely encapsulated: waterproof, shockproof and ignition protected
Water, oil or dirt will not damage the Blue Power charger. The casing is made of cast aluminium and the
electronics are molded in resin.
• Protected against overheating
Can be used in a hot environment such as a machine room. Output current will reduce as temperature increases
up to 60°C, but the Blue Power charger will not fail.
• Automatic three stage charging
Once the absorption voltage has been reached to a low break point current (see specifications), or after a 20 hour
absorption period. The battery is therefore effectively protected against overcharging and can remain
permanently connected to the charger. The charger will automatically reset and start a new charge cycle after
interruption of the AC supply.
• Two LED’s for status indication
Yellow LED: battery being charged
Green LED: float charge, the battery is charged
Blue Power charger
12/7
Input voltage range (V AC) (1)
200-265
Frequency (Hz)
45-65
12/17
24/3
Charge voltage ‘absorption’ (V DC)
14.4
28.8
Charge voltage ‘float’ (V DC)
13.7
27.2
Charge current (A)
7
Charge characteristic
3 stage with max. 20 hours absorption time
17
24/12
3
12
Minimum battery capacity (Ah)
15
35
6
24
Breakpoint current (A)
0.7
1.7
0.3
1.2
Can be used as power supply
Yes
Protection
Battery reverse polarity (fuse in battery cable) Output short circuit, over temperature
Operating range
-20 to 60 °C,
Humidity Max: 100%
ENCLOSURE
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
Black and red cable of 1,5 meter
230 V AC-connection
Cable of 1,5 meter with Europe class 1 plug (CE-certified)
Protection category
IP 67
Weight (kg)
1.1
1.4
1.1
1.4
Dimensions (hxwxd in mm)
43x80x155
47x99x193
43x80x155
47x99x193
STANDARDS
Safety
EN60335-1, EN 60335-2-29
Emission
EN55014-1, EN61000-3-2
Immunity
EN55014-2, EN61000-3-3
1) 120V / 60 Hz available
PHOENIX BATTERY CHARGER
[ 12V: 30-50 A ]
[ 24V: 16-25 A ]
CHARACTERISTICS
• Adaptive 4-stage charge characteristic: bulk - absorption - float - storage
The Phoenix charger features a microprocessor controlled ‘adaptive’ battery management system that can be preset to suit
different types of batteries. The ‘adaptive’ feature will automatically optimise the process relative to the way the battery is
being used.
• The right-amount of charge: adaptive charge
When only shallow discharges occur (a yacht connected to shore power for example) the absorption time is kept short in order
to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure
that the battery is completely recharged.
• Preventing damage due to excessive gassing: the BatterySafe mode (see fig2. below)
If, in order to quickly charge a battery, a high charge current in combination with a high absorption voltage has been chosen,
the Phoenix charger will prevent damage due to excessive gassing by automatically limiting the rate of voltage increase once
the gassing voltage has been reached (see the charge curve between 14,4 V and 15,0 V in fig.2 below).
• Less maintenance and aging when the battery is not in use: the Storage mode (see fig.1 & 2 below)
The storage mode kicks in whenever the battery has not been subjected to discharge during 24 hours. In the storage mode
float voltage is reduced to 2,2 V/cell (13,2 V for 12 V battery) to minimise gassing and corrosion of the positive plates. Once a
week the voltage is raised back to the absorption level to ‘equalize’ the battery. This feature prevents stratification of the
electrolyte and sulphation, a major cause of early battery failure.
• To increase battery life: temperature compensation
Every Phoenix charger comes with a battery temperature sensor. When connected, charge voltage will automatically
decrease with increasing battery temperature.
• Battery voltage sense
In order to compensate for voltage loss due to cable resistance, Phoenix chargers are provided with a voltage sense facility so
that the battery always receives the correct charge voltage.
• Computer interface
Every Phoenix Charger is ready to communicate with a computer through its RS-485 data port. Together with our VEConfigure
software, all parameters of the chargers can be customised. The chargers can also be connected to VENet, or to other
computerised monitoring control systems.
Fig. 1
Fig. 2
ACCESSORIES
Battery Monitor
Phoenix Charger Control
Phoenix charger
12V/24V
12/30
24/16
Input voltage range
90-265 VAC, 90-400 VDC
Frequency (Hz)
45-65, PF:1
Charge voltage ‘absorption’ (V DC)
14.4 / 28.8
Charge voltage ‘float’ (V DC)
13.8 / 27.6
Storage mode (V DC)
13.2 / 26.4
Battery bank
3
Charge current house batt. (A)(2)
30/16
Charge current starter batt. (A)
4
Charge characteristics
4 stage adaptive
Battery capacity (Ah)
100-400
100-200
Temperature sensor
Yes
12/50
24/25
50/25
200-800
100-400
Can be used as power supply
Yes
Forced cooling
Yes
Protection (1)
a,b,c,d
Common characteristics
Temperature: -20 to 60 °C (0 - 140°F) Max humidity: 95%
ENCLOSURE
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
M6 Studs
230 V AC-connection
Screw-clamp 4mm²
Protection category
IP21
Weight (kg)
3.8
Dimensions (hxwxd in mm)
350x200x108
STANDARDS
Computer controlled
operation and monitoring
(Victron interface Mk2b)
Battery Alarm
Safety
EN60335-2-29
Emission
EN55014, EN61000-3-2, EN61000-3-3
Immunity
EN55014-2
Vibration
IEC68-2-6: 10-150Hz/1.0G
Automotive directive
95/54/EC
1) Protection
a. Output short circuit
c. Battery voltage too high
2) Up to 40 °C ambient
b. Battery reverse polarity detection
d. Temperature too high
SKYLLA TG BATTERY CHARGER
[ 12V: 30-50-80-100 A ]
[ 24V: 25-50 A ]
CHARACTERISTICS
• Perfect chargers for any type of battery
Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system. In particular,
sealed maintenance free batteries must be charged correctly in order to ensure a long service life.
Over voltage will result in excessive gassing and venting of a sealed battery. The battery will dry out
and fail.
• Controlled charging
Every TG charger has a microprocessor, which accurately controls the charging in three steps. The
charging process takes place in accordance with the IUoUo characteristics and charges more rapidly
than other processes.
• Use of TG chargers as a power supply
As a result of the perfectly stabilized output voltage, a TG charger can be used as a power supply if
batteries or large buffer capacitors not available.
• Two outputs to charge 2 battery banks
The TG chargers feature 2 isolated outputs. The second output, limited to approximately 4 A and
with a slightly lower output voltage, is intended to top up a starter battery.
• To increase battery life: temperature compensation
Every Skylla TG charger comes with a battery temperature sensor. When connected, charge
voltage will automatically decrease with increasing battery temperature. This feature is especially
recommended for sealed batteries which otherwise might be overcharged and dry out due to
venting.
• Battery voltage sense
In order to compensate for voltage loss due to cable resistance, TG chargers are provided with
a voltage sense facility so that the battery always receives the correct charge voltage.
Charge curve
Application example
ACCESSORIES
24/50 TG
24/50 GMDSS
24/50 TG
3 phase
24/80 TG
Skylla
24V / 48V
24/30 TG
24/30 GMDSS
Input voltage
185-265VAC, 320-450VAC or 180-400VDC (3)
Frequency (Hz)
45-65
24/100 TG
24/100 TG
3 phase
48/25 TG
48/50 TG
Charge voltage ‘absorption’ (VDC)
28.5
57
Charge voltage ‘float’ (VDC)
26.5
53
Battery capacity (Ah)
150-300
250-500
400-800
500-1000
125-250
250-500
Charge current house batt. (A) (2)
30
50
75
100
25
50
Charge current starter batt. (A)
4
Charge characteristics
IUoUo
Temperature sensor
√
Can be used as power supply
√
Potential free contacts
√
n.a.
Protection (1)
a,b,c,d
Common characteristics
Temperature: -20 to 60 °C (0 - 140 °F) Max humidity: 95%
ENCLOSURE
Battery Monitor
Charger Switch
A remote on-off switch
Skylla Control
Battery Alarm
An excessively high or low
battery voltage is indicated
by an audible and visual
alarm.
Skylla TG GMDSS
Material & Colour
Aluminium (blue RAL 5012)
Battery-connection
M8 Studs
230 V AC-connection
Screw-clamp 2,5 mm² (AWG 6)
Protection category
IP21
Weight (kg)
5.5/6
5.5/13
10
10/23
5.5
10
Dimensions (hxwxd in mm)
365x250x147
365x250x147
365x250x257
365x250x257
365x250x257
515x260x265
365x250x147
365x250x257
STANDARDS
Safety
EN60335-2-29
Emissions
EN55014, EN61000-3-2, EN61000-3-3
Immunity
EN55014-2
Automotive divective
95/54/EC
1) Protection
a. Output short circuit
b. Battery reverse polarity detection
c. Battery voltage too high
d. Temperature too high
2) Up to 40 °C ambient
Wide input voltage 90-265 VAC and GL approval model available
CENTAUR BATTERY CHARGER
[ 12V: 20-30-40-50-60-80-100-200 A ]
[ 24V: 16-30-40-60-80-100 A ]
CHARACTERISTICS
• Quality without compromise
Aluminium epoxy powder coated cases with drip shield and stainless steel fixings withstand the rigors of
adverse environments: heat, humidity and salt air. Circuit boards are protected with an acrylic coating for
maximum corrosion resistance. Temperature sensors ensure that power components will always operate
within specified limits, if needed, by automatic reduction of output current under extreme environmental
conditions.
• Universal 90 to 265 Volt input voltage range
All models will operate without any adjustment needed over a 90 to 265 Volt input voltage range, whether
50 Hz or 60 Hz.
• Three outputs that each can supply the full output current
Three isolated outputs to simultaneously charge 3 battery banks. Each output is capable to supply the full
rated current.
• Three stage charging, with temperature compensation
The Centaur charges at bulk rate until the output has reduced to 70% of the rated Amps, at which a 4 hour
timer begins. After the timed period the charger switches to float rate. An internal temperature sensor is used
to compensate the charge voltage with 2 mV/˚C (1mV/˚F) per cell.
Charging curve
Centaur Charger
Example
12/20
12/30
24/16
12/40
12/50
Common
characteristics
Input voltage: 90 - 265 VAC or 90 - 400 VDC
Charge voltage
‘absorption’ (VDC)
14.3 / 28.5 (1)
Charge voltage
‘float’ (VDC)
13.5/27 (1)
Output banks
3
Recommended
battery capacity
(Ah)
80-200
Charge current
(A)(2)
20
Total output
ammeter
Yes
Charge
characteristics
IUoUo (Three stage charging)
Temperature
sensor
Internal, -2mV / °C (-1mV / °F) per cell
Forced Cooling
Yes, temperature and current controlled fan
120-300
45-150
160-400
30/16
40
12/60
24/30
Input frequency: 45 - 65 Hz
200-500
50
Ignition protected
Yes
Protection
Output short circuit, over temperature
Operating range
Temperature: -20 to 60 °C (0 - 140 °F)
12/80
24/40
12/100
24/60
24/80
12/200
24/100
Power factor: 1
240-600
120-300
320-800
160-400
400-1000
240-600
320-800
800-2000
400-1000
60/30
80/40
100/60
80
200/100
Humidity max: 95%
ENCLOSURE
Material & Colour
ACCESSORIES
Aluminium (blue RAL5012)
AC-connection
Screw-clamp 4mm² (AWG 6)
Batteryconnection
IP21
Protection
category
M6 Studs
M8 Studs
Weight kg (lbs)
3.8
5
12
16
Dimension
(hxwxd in mm)
355x215x110
426x239x135
505x255x130
505x255x230
STANDARDS
Battery Monitor
Battery Alarm
An excessively high or low
battery voltage is indicated
by an audible and visual alarm.
Safety
EN 60335-2-29, UL 1236
Emission
EN 55014, EN61000-3-2, EN 61000-3-3
Immunity
EN 55014-2
1) Standard setting. Optium charge/float voltages for Flooded Lead-acid, Gel-Cell or AGM batteries selectable by dip switch.
2) Up to 40 °C (1oo °F) ambient. Output will reduce to approximately 80% of nominal at 50 °C (120 °F) and 60% of nominal at 60 °C (140 °F)
1. Fasten the separate mounting
plate (A) to the wall where you
want to place the battery charger,
and simply hook up the Centaur.
2. Secure the bottom of the backside
(B) to the wall.
ORION DC/DC CONVERTER
CHARACTERISTICS
Possibly the widest range on the
market!
An ever-increasing is being used on
vehicles and industrial systems.
Because most low-voltage equipment is designed for 12 Volts,
Victron Energy supplies DC/DC converters which deliver a stable 12 Volt
supply from a 24 Volt system.
These products are also distinguished by high efficiency, together
with absolute safety. An inferior
supply can cause irreparable damage to your 12 Volt system, but the
use of an Orion voltage converter
prevents problems of that type.
Next to converters from 24 V to 12 V,
a wide range of other models available.
Battery charger
The Orion 24/12-20 and 24/12-30
can also be used as a 13.8 Volt battery charger for a 12 Volt starter or
accessory battery in an otherwise 24
V system.
To charge a 24 V battery from a 12
V system the Orion 12/27,6-12 can
be used. The output voltage of this
model can be adjusted with a potentiometer.
A super wide input range buckboost regulator:
The Orion 7-35/12-3 is an isolated
converter with a very wide input
range, suitable for both 12 V and 24
V systems, and a fixed 12,6 V output.
Non isolated converters
Orion
24/12-5
Orion
24/12-8
Orion
24/12-12
Orion
24/12-20
Orion
24/12-30
Orion
24/12-60
Orion
12/24-7
Orion
12/24-10
Input voltage range (V)
18-35
18-35
20-35
20-35
20-35
20-35
9-18
9-18
Output voltage (V)
13.2
13.2
13.2
13.8
13.8
13.8
24
24
Max. output current (A)
5.5
8
12
20
30
60
70
10
Fan assisted cooling
(temp. Controlled)
no
no
no
no
yes
yes
no
no
Galvanic isolation
no
no
no
no
no
no
no
no
Off load current
<5mA
<5mA
<5mA
appr. 25mA
appr. 25mA
appr. 50mA
<15mA
<15mA
Temperature increase after
30 minutes at full load (°C)
30
20
30
25
33
33
30
30
Weight (kg)
0.17
0.25
0.26
0.48
0.6
1.2
0.3
0.4
Dimensions (hxwxd in mm)
49x88x68
49x88x98
49x88x98
49x88x126
49x88x151
88x100x180
49x88x98
49x88x126
Note: two units orion 24/12-60 can be connected in parallel to obtain a 120A converter
Isolated converters
Orion xx/yy-100W
Orion xx/yy-200W
Orion xx/yy-360W
Power rating (W)
100 (12,5V/8A or 24V/4A)
200 (12,5V/16A or 24V/8A)
360 (12,5V/30A or 24V/15A)
Galvanic isolation
yes
yes
yes
Temperature increase after
30 minutes at full load (C)
25
30
30
Fan assisted cooling (temp. Controlled)
no
yes
yes
Weight (kg)
0.5
0.6
1.4
Dimensions (hxwxd in mm)
49 x 88 x 152
49 x 88 x 182
64 x 163 x 160
Input voltage (xx)
12 V (9-18V) or 24 V (20-35 V) or 48 V (30-60 V) or 96 V (60-120 V), 110 V
Output voltage (yy)
12,5 V or 24 V
Isolated 24V battery charger:
Orion 12/27,6-12
Input 9 - 18 V, output 27,6 V, current limit 12 A, fan assisted cooling
Output voltage adjustable with potentiometer
Weight 1,4 kg, dimensions 64 x 163 x 160 mm
Isolated buck-boost regulator:
Orion 7-35/12-3
Input 7 - 35 V, output 12,6 V current limit 3 A, derate current linearly from 3 A at 18 V to 1,5 A at 7 V
Weight 1,4 kg, dimensions 64 x 163 x 160 mm
COMMON CHARACTERISTICS
Output voltage stability
2 % (Orion 12/24-7 and Orion 12/24-10: + 0% / -5%)
Output voltage tolerance
3%
Output noise
< 50 mV rms
Off load current
< 25 mA (isolated converters)
Efficiency
Non isolated: appr. 92%
Isolation
> 400 Vrms between input, output and case (isolated products only)
Isolated: appr. 85%
Operating temperature
- 20 to + 30 °C. Derate linearly to 0 A at 70 °C
Humidity
Max 95% non condensing
Casework
Anodised aluminium
Connections
6.3 mm push-on flat blade connectors
PROTECTION
Overcurrent
Short circuit proof
Overheating
Reduction of output voltage
Reverse polarity conn
Fuse and reverse connected diode across input
Overvoltage
Varistor (also protects against load dump)
STANDARDS
Emission
EN 50081-1
Immunity
EN 50082-1
Automotive Directive
95/45/EC
VE SOLARSWITCH
No-break back-up for grid connected solar systems.
Grid inverter
Preventing shut down of the PV system in the event of a power
outage
Solar panel
A rapidly growing number of houses, farms and other buildings are being fitted with grid connected solar installations.
The standard configuration has an important drawback: it is
dependent on the grid. If the grid fails, the grid connected
inverter shuts down and a total blackout is the result, despite the
investment in a solar installation!
VE Solar Switch
Feed -in meter
0196347
,
kWh
The same is true for other grid connected alternative energy
solutions, such as wind, water or micro-heat-and-power.
0196347
,
kWh
Supply meter
Optional
load disconnect
Basically, the solution to this problem is to add an inverter/
charger and batteries.
Unprotected loads
Public grid
In case of a power outage the SolarSwitch will connect the grid
inverter to the output of a MultiPlus (or Quattro). The MultiPlus
effectively replaces the grid and will take over the supply of the
protected loads. High power loads that should not drain the
battery can be connected to a second, load shedding output, of
the MultiPlus.
water heater
Grid present
Battery
During night time or when the load needs more power than
supplied by the solar panels, the MultiPlus will supply extra
power taken from the battery.
Any excess power supplied by the solar panels will be used to
recharge the battery. Once the batteries are fully charged, the
excess power can be redirected to a water heater (relay not
shown), or a dump load (not shown), or the grid inverter can
be stopped by slightly changing the output frequency of the
MultiPlus.
Grid inverter
Solar panel
VE Solar Switch
Feed -in meter
0196347
,
kWh
In order to prevent the batteries from discharging completely
in case of insufficient solar power, some or all loads can be can
be shut down with help of programmable relays available on
the SolarSwitch (not shown).
Protected loads
0196347
,
kWh
Supply meter
Optional
load disconnect
Unprotected loads
Public grid
water heater
No grid, battery mode
Battery
Grid inverter
Solar panel
VE Solar Switch
Feed -in meter
0196347
,
kWh
Protected loads
0196347
,
kWh
Supply meter
Optional
load disconnect
Unprotected loads
Public grid
water heater
Battery
No grid, batteries discharged
BATTERY MONITORING
CHARACTERISTICS
Precision monitoring
The essential function of a battery monitor is to calculate ampere-hours consumed and the state of charge of a battery.
Ampere-hours consumed is calculated by integrating the
current flowing in or out of the battery. In case of a constant
current, this integration is equivalent to current multiplied by
time. A discharge current of 10A during 2 hours, for example, amounts to 20Ah consumed. All our battery monitors are
based on a powerful microprocessor, programmed with the
algorithms needed for precision monitoring.
Standard information and alarms
Battery voltage (V)
Battery charge/discharge current (A)
Ampere-hours consumed (Ah)
State of charge (%)
Time to go at the current rate of discharge
Visual and audible alarm: over- and under voltage,
and/or battery discharged
Programmable alarm or generator start relay.
BMV 600: low cost ultra high resolution monitor
Highest resolution: 10mA (0,01A) with 500A shunt.
Lowest current consumption: 1mA.
Easiest to wire: the BMV 600 comes with stunt, 10 meter
RJ 12 UTP cable and 2 meter battery cable with fuse.
No other components needed.
Easiest to install: separate front bezel for square or round
appearance; ring for rear mounting and screws for front
mounting.
Broadest voltage range: 9-90 VDC without prescaler needed.
Battery Monitoring
BMV 600
BMV 602
BMV 602H
VE.Net
Battery Controller
VE.Net
Battery Controller
48V
Power supply voltage range
9-90 VDC
9-90 VDC
35-150 VDC
9-35 VDC
9-60 VDC
Current draw, back light off
4mA at 12V
3mA at 24V
4mA at 12V
3mA at 24V
3mA
10mA at 12VDC
3mA at 48VDC
Input voltage range (VDC)
9-90 VDC
9-90 VDC
35-150 VDC
9-35 VDC
39-60 VDC
Battery capacity (Ah)
20-9999 Ah
20-60000Ah
Operating temperature range
-20 - 50 °C (0 - 120 °F)
Measures voltage of second battery
No
Yes
Yes
No
Communication port
No
Yes
Yes
Yes (VE.Net)
Potential free contacts
60V/1A (N/O)
RESOLUTION (with 500 A shunt)
Current
± 0.01A
Voltage
± 0.01V
Amp hours
± 0.1Ah
State of charge (0-100%)
± 0.1%
Time to go
± 1 min
Temperature (0-50 °C or 30-120 °F)
n.a.
Accuracy of current measurement
± 0.3%
Accuracy of voltage measurement
± 0.4%
± 0.1A
± 1 °C (± 1°F)
INSTALLATION AND DIMENSIONS
Installation
Flush mount
DIN rail
Front
63 mm diameter
22 x 75 mm (0.9 x 2.9 inch)
Front bezel
69 x 69 mm (2.7 x 2.7 inch)
n.a.
Body diameter
52 mm (2.0 inch)
n.a.
Body depth
31 mm (1.2 inch)
105 mm (4.1 inch)
ACCESSORIES
BMV 602H: 35 to 150VDC voltage range
No prescaler needed.
BMV 602: two batteries and communication port
In addition to all the features of the BMV600, the BMV602 can
measure the voltage of a second battery and has a communication port. (Isolated RS232 interface is needed tot connect
to a computer)
VE.Net Battery Controller: any number of batteries
One VE.Net panel will connect to any number of battery
controllers.
Comes with 500A/50mV shunt and can be programmed for
any other shunt.
With use, abuse and data memory.
Temperature sensor and connection kit included.
Shunt (included)
500 A / 50 mV
500 A / 50 mV
Cables (included)
10 meter 6 core UTP with RJ12 connectors
and cable with fuse for ‘+’ connection
Supplied with 1m cables
Temperature sensor
n.a.
Supplied with 3m cable
Computer interface
n.a.
Optional
Optional
n.a.
VE NET
CHARACTERISTICS
• VE NET stands for VICTRON ENERGY NETWORK, a low power network that will monitor all essential
equipment and alarms, and keep you informed through automatic e-mails, text messages, and even
voice calls. Similarly the wireless connection could be used to access all systems on board remotely. For the
ultimate in monitoring and control of your power system, VE.Net represents the state of the art. As a truly
integrated solution, VE.Net provides the following components:
• 1. Blue power panel - multi character display and interface panel
• 2. Battery Controller - full function battery monitoring module (any number can be connected to the network).
• 3. Generator control - full monitoring and control of your generator including auto start/stop functionality.
• 4. VRM module - enables full access to system status and control remotely through the internet. It also gives a
historical overview with graphs and bars trough our internet website.
VE.Net can also be integrated with any number of other devices including an on board PC, power distribution
systems and or senders and alarms. Your imagination is the only limit to what is possible.
OTHERS
Batteries
•
•
•
•
VRLA AGM: design life 7-10 years
VRLA GEL: design life 12 years
VRLA GEL 2 volt cells: design life 20 years
The AGM range has very low internal resistance making them particulary suitable
for high current discharge and charging.
• The GEL model range offer best deep cycle durability and overall longer life.
• The use of high purity materials and lead calcium grids ensure that for both AGM
and GEL products have particulary low self discharge so that they will not go flat
during long periods without charge.
• Both ranges are supplied with M8 drilled, flat copper terminals ensuring best
possible connection contact and eliminating the need for battery terminals.
Manufactured under ISO 9002 quality standards, they are compliant with both CE
and UL specifications in ABS fireproof containers and come with Victron’s 2 year
world-wide warranty.
FILAX Transfer Switch
• Filax: the ultra fast transfer switch
The Filax has been designed to switch sensitive loads, such as computers or
modern entertainment equipment from one AC source to another.
The priority source typically is the mains, a generator or shore power. The
alternate source typically is an inverter.
PowerMan Transfer Switches
• Ideal to build a no-break power supply with several paralleled Multi’s.
The PowerMan transfer switch enables seamless power transfer from one or more
AC sources to several paralleled Multi’s. In-built AC current monitoring ensures
that the AC power management functionality of the Multi’s remains available.
BatteryProtect (Models: BP-40i, BP-60i, BP-200i)
• The BatteryProtect disconnects the battery from non-essential loads before it
is completely discharged (which would damage the battery) or before it has
insufficient power left to crank the engine.
ESP system panel
• The new ESP panel system provides a contemporary designed range of panels
that cover the core engineering systems. The main system panel is the heart of
the range. This provides AC and DC monitoring, Multi control and backlight
control. Additional panels include AC and DC circuit breaker panels, a general
control panel, a VE Net panel.
Victron Global Remote
• The Global Remote is a modem which sends alarms, warnings and system status reports to cellular phones via
text messages (SMS). It can also log data from Victron Battery Monitors, Multi’s, Quattro’s and Inverters to a website
through a GPRS connection. The usage of this website is free of charge.
The idea is simple: you can use it to get SMS alarms from a Multi, a Battery System, or both. When monitoring the
usage of batteries, it can be extremely helpful to receive under and overvoltage alarms; whenever they occur. For
this purpose, the Global Remote is perfect. A prepaid SIM-card (for example) in combination with the Global Remote
is adequate for remotely monitoring your system.
Taking it one step further, an internet browser and -connection is all you need to view all of the data online. You
can simply create an account on the website and add your modem(s). Subsequently you can configure the GPRS
connection, which will enable you to monitor the historic data of several basic properties such as system voltages,
power levels and status information. All of this data is graphed. These graphs are available in daily, weekly and
monthly timeframes.
Victron Remote Management is the name of the system which consists of the VGR and the monitoring website.
To get a preview: please go to http://www.victronenergy.com, and login at ‘Victron Remote Management’ via the
Login menu on the upper right of the page.
MULTIPLUS PRINCIPLE
INVERTER/CHARGER SYSTEM WITH INTELLIGENT SHORE AND GENERATOR POWER MANAGEMENT
PowerControl: Dealing with limited generator or grid power
All models in the MultiPlus range feature powerful battery chargers. When the largest model is working hard it can draw almost 10A from a 230V supply. Using the
remote panel it is possible to ‘dial-in’ the maximum current that is available from mains or generator. The MultiPlus will then automatically regulate the charger
taking account of other system AC loads and ensuring the charger only uses what is spare. This way it is possible to avoid tripping the mains power or overloading
the generator.
POWER CONTROL ©
Battery charger reduces its output, if required, to avoid overload of supply when system consumption is high.
Multi remote panel
MultiPlus
PHOENIX MULTI CONTROL
inverter on
mains on
overload
12
boost
low battery
equalize
temperature
on
16
AC distribution
20
24
8
28
4
float
0
charger only
30
Water Heater (10A)
shore current limiter
off
16A
mains on
inverter on
bulk
overload
absorption
low battery
float
temperature
Microwave (6A)
Fridge (1A)
phoenix
multi plus 12/3000/120
RCD
www.victronenergy.com
TV / DVD (1A)
Computer (1A)
Kettle (13A)
Battery 12V/300Ahr
Services
Public grid
Hairdryer (8A)
13A
Power Tools (2A)
Reduced charge to battery
PowerAssist: Boosting the power available from mains or generator, an innovative feature of Multiplus.
The feature that most distinguishes the MultiPlus from other inverter / chargers is PowerAssist. This feature takes the principle of PowerControl to a further
dimension by allowing a MultiPlus to supplement the power available from mains or generator to ‘assist’ during periods of high demand. Peak power demand is
almost always sustained only for short periods, either a few minutes (in the case of items like cooking appliances) or just a few seconds (in the case of the burst of
energy needed to start an air-conditioning or refrigeration compressor).
With the capacity of the generator or mains power set on the remote panel, the MultiPlus detects when the load is becoming too much for the supply and will
instantly provide the extra power required. When the demand has reduced, the unit returns to charging the battery. This feature is equally effective in large and
small systems helping to reduce the required generator capacity or to achieve greater things with limited mains power. There is even a special feature to enable the
MultiPlus/Quattro to work perfectly with portable generators.
POWER ASSIST ©
Inverter boosts incoming power, if required, to avoid overload of supply when system consumption exceeds supply.
Multi remote panel
MultiPlus
PHOENIX MULTI CONTROL
inverter on
mains on
overload
boost
low battery
equalize
temperature
float
on
charger only
12
16
AC distribution
20
8
24
28
4
0
30
Water Heater (10A)
shore current limiter
off
16A
mains on
inverter on
bulk
overload
absorption
low battery
float
temperature
Microwave (6A)
Fridge (1A)
phoenix
multi plus 12/3000/120
RCD
www.victronenergy.com
TV / DVD (1A)
Computer (1A)
Kettle (13A)
Battery 12V/300Ahr
Services
Public grid
Battery delivers energy to “Power Assist” incoming
21A
power
Hairdryer (8A)
Power Tools (2A)
SYSTEM APPLICATION
INTRODUCTION
However far you travel, a reliable power source is an essential requirement for providing optimum onboard comfort.
This necessity becomes even greater in remote places where the power supply is less dependable. So now you can
enjoy a hot shower or a cold drink, whenever and wherever you want, without worrying about where your power is
coming from.
Victron Energy offers a complete range of power systems, designed to meet a diversity of requirements. From small
craft to large sailing yacht, mobile homes, utility vehicles or industrial applications, our systems offer the ideal solution to your specific power needs.
MARINE 7
VEBus digital panel
PV system
MultiPlus
BMV-602 Battery Monitor
PHOENIX MULTI CONTROL
BMV-602
battery monitor
inverter on
mains on
overload
boost
low battery
equalize
temperature
float
on
SETUP
charger only
off
shore current limiter
+
-
SELECT
QUATTRO
12
120
AC distribution
Solar converter
Water Heater (10A)
Microwave (6A)
Public grid
Fridge (1A)
32A/30mA
RCD/RCBO
TV / DVD (1A)
Induction Hob
Coffee Maker (8A)
DC Link Box
Hairdryer (8A)
Power Tools (2A)
Genset
230V/50Hz
DC Solar system
Blue Power panel
PV system
2 x Quattro 24/5000/120
VE.NET
cancel
enter
VE.NET
VE.BUS
Converter
QUATTRO
QUATTRO
24
24
5000
120
5000
120
AC distribution
Grid inverter
VE Solar Switch
Water Heater (10A)
Microwave (6A)
Fridge (1A)
TV / DVD (1A)
Public grid
32A/30mA
RCD/RCBO
Computer (1A)
Coffee Maker (8A)
Hairdryer (8A)
Washer/dryer (13A)
VE.NET
Battery
Controller
Genset
230V/50Hz
DC Link Box
Air - Con (Partial)
Induction Hob
AC Solar system
Victron Energy B.V. / De Paal 35
1351 JG Almere / The Netherlands
Phone: +31 (0)36 535 97 00
Fax: +31 (0)36 535 97 40
e-mail: sales@victronenergy.com
www.victronenergy.com
