ClearSounds CS10 Owner`s manual

Introduction
Playing the Piano
Music Menu
CS10
Owner’s Manual
Recorder
Settings
Appendix
Thank you for purchasing this Kawai Classic Series CS10 digital piano.
This owner’s manual contains important information regarding the instrument’s usage and operation.
Please read all sections carefully, keeping this manual handy for future reference.
„ About this Owner’s Manual
Before attempting to play this instrument, please read the Introduction section from page 10 of this owner’s manual. This section
explains the name and function of each part, how to connect the power cable, and how to turn on the power.
The Playing the Piano section (page 16) provides an overview of the instrument’s commonly used functions, allowing the CS10
digital piano to be enjoyed almost immediately after being connected, while the Music Menu section (page 32) includes information
regarding the built-in demonstration songs, Piano Music pieces, Lesson and Finger Exercise features, and Concert Magic function.
The Recorder section (page 44) provides instructions on how to record and play back pieces stored both in the instrument’s internal
memory, and also MP3/WAV audio files saved to a USB memory device. The Settings section (page 59) details the various options
and settings that can be used to adjust the sound and operation of the instrument.
Finally, the Appendix section (page 118) includes lists for all internal sounds, songs, and drum rhythms, MIDI reference information,
and full specification details.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING
CAUTION
TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS : RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the leterature
accompanying the product.
Examples of Picture Symbols
denotes that care should be taken.
The example instructs the user to take care not to allow fingers to be trapped.
denotes a prohibited operation.
The example instructs that disassembly of the product is prohibited.
denotes an operation that should be carried out.
The example instructs the user to remove the power cord plug from the AC outlet.
Read all the instructions before using the product.
$ #3'$2$(-2314"3(.-2
$$/3'$2$(-2314"3(.-2
$$# ++6 1-(-&2
.++.6 ++(-2314"3(.-2
.-.342$3'(2 // 1 342-$ 16 3$1
+$ -.-+86(3'#18"+.3'
.-.3!+."* -85$-3(+ 3(.-./$-(-&2-23 ++(-
"".1# -"$6(3'3'$, -4% "341$1;2(-2314"3(.-2
.-.3(-23 ++-$ 1 -8'$ 32.41"$224"' 21 #( 3.12
'$ 31$&(23$1223.5$2.1.3'$1 // 1 342(-"+4#(-&
,/+(:$123' 3/1.#4"$'$ 3
.-.3#$%$ 33'$2 %$38/41/.2$.%3'$/.+ 1(9$#.1
&1.4-#(-&38/$/+4&/.+ 1(9$#/+4&' 236.
!+ #$26(3'.-$6(#$13' -3'$.3'$1&1.4-#(-&
38/$/+4&' 236.!+ #$2 -# 3'(1#&1.4-#(-&
/1.-&'$6(#$!+ #$.13'$3'(1#/1.-&2 1$
/1.5(#$#%.18.412 %$38%3'$/1.5(#$#/+4&#.$2
-.3:3(-3.8.41.43+$3".-24+3 -$+$"31("( -%.1
1$/+ "$,$-3.%3'$.!2.+$3$.43+$3
1.3$"33'$/.6$1".1#%1.,!$(-&6 +*$#.-.1
/(-"'$#/ 13("4+ 1+8 3/+4&2".-5$-($-"$
1$"$/3 "+$2 -#3'$/.(-36'$1$3'$8$7(3%1.,3'$
// 1 342
-+842$ 33 "',$-32 ""$22.1($22/$"(:$#!83'$
, -4% "341$1
2$.-+86(3'3'$" 1323 -#31(/.#!1 "*$3.13 !+$
2/$"(:$#!83'$, -4% "341$1.1
2.+#6(3'3'$ // 1 342'$- " 13(242$#
42$" 43(.-6'$-,.5(-&3'$" 13 // 1 342
".,!(- 3(.-3. 5.(#(-)418%1.,3(/.5$1
-/+4&3'(2 // 1 342#41(-&+(&'3-(-&23.1,2.1
6'$-4-42$#%.1+.-&/$1(.#2.%3(,$
$%$1 ++2$15("(-&3.04 +(:$#2$15("$/$12.--$+
$15("(-&(21$04(1$#6'$-3'$ // 1 342' 2!$$-
# , &$#(- -86 824"' 2/.6$124//+8".1#.1
/+4&(2# , &$#+(04(#' 2!$$-2/(++$#.1.!)$"3
' 5$% ++$-(-3.3'$ // 1 3423'$ // 1 342' 2
!$$-$7/.2$#3.1 (-.1,.(2341$#.$2-.3./$1 3$
-.1, ++8.1' 2!$$-#1.//$#
WARNING - When using electric products, basic precautions should always be followed, including the following.
WARNING
The product should be connected to
an AC outlet of the specified voltage.
Indicates a potential hazard that could result in death or
serious injury if the product is handled incorrectly.
120V
230V
240V
If you are going to use an AC power cord,
make sure that its has the correct plug shape
and conforms to the specified power voltage.
Failure to do so may result in fire.
Do not insert or disconnect the power
cord plug with wet hands.
Doing so may cause electric shock.
Take care not to allow any foreign
matter to enter the product.
Entry of water, needles or hair pins may result
in breakdown or short-circuit.
The product shall not be exposed to dripping or
splashing. No objects filled with liquids, such as
vases, shall be placed on the product.
The chair must be used properly (it must be
used only when playing the product).
Do not play with it or stand on it.
Only one person is allowed to sit on it.
Do not sit on it when opening the lid.
Re-tighten the bolts occasionally.
Doing so may cause the chair to fall over or your
fingers to be trapped, resulting in injury.
When using the headphones, do not
listen for long periods of
time at high volume levels.
Doing so may result in hearing problems.
Do not lean against the keyboard.
Doing so may cause the product to fall over,
resulting in injury.
Do not disassemble, repair or modify
the product.
Doing so may result in product breakdown, electric
shock or short-circuit.
When disconnecting the AC power cord's
plug, always hold the plug
and pull it to remove it.
Pulling the AC power cord itself may damage
the cord, causing a fire, electric shock or
short-circuit.
The product is not completely disconnected from the
power supply even when the power switch is turned
off. If the product will not be used for a long time,
unplug the AC power cord from the AC outlet.
Failure to do so may cause fire in case of
lightning.
Failure to do so may over-heat the product,
resulting in fire.
This product may be equipped with a polarized line plug (one blade wider
than the other). This is a safety feature.
If you are unable to insert the plug into the outlet, contact an electrician to
replace your obsolete outlet.
Do not defeat the safety purpose of the plug.
This product shall be near the AC outlet and the power cord plug in a position so that it can readily be
disconnected in an emergency because electricity is always charging while the plug is in the AC outlet
even in a power switch off condition.
CAUTION
Indicates a potential hazard that could result in injury or
damage to the product or other property if the product
is handled incorrectly.
Do not use the product in the following areas.
Areas, such as those near windows, where the product is
exposed to direct sunlight
Extremely hot areas, such as near a heater
Extremely cold areas, such as outside
Extremely humid areas
Areas where a large amount of sand or dust is present
Areas where the product is exposed to excessive
vibrations
Using the product in such areas may result in
product breakdown.
Use the product only in moderate climates (not
in tropical climates).
When you close the keyboard cover,
close it gently.
Closing it roughly may trap your fingers,
resulting in injury.
Before connecting cords, make sure
that the power to this product
and other devices is turned
OFF.
OFF
Failure to do so may cause breakdown of this
product and other devices.
Do not drag the product on the floor.
Take care not to drop the product.
Please lift up the product when moving it.
Please note that the product is heavy and must
be carried by more than two persons.
Dropping the product may result in breakdown.
Do not place the product near electrical
appliances such as TVs and radios.
Doing so may cause the product to generate
noise.
If the product generates noise, move the
product sufficiently away from the electrical
appliance or connect it to another AC outlet.
When connecting the AC power cord
and other cords, take care
not to get them tangled.
Failure to do so may damage them, resulting in
fire, electric shock or short-circuit.
Do not wipe the product with benzene
or thinner.
Doing so may result in discoloration or deformation
of the product.
When cleaning the product, put a soft cloth in
lukewarm water, squeeze it well, then wipe the
product.
Do not stand on the product or exert
excessive force.
Doing so may cause the product to become
deformed or fall over, resulting in breakdown
or injury.
Do not place naked flame, such as lighted
candles on the product.
Doing so may cause the illumination to fall over,
resulting in fire.
Ensure that the ventilation is not
impeded by covering the ventilation
openings with items, such as newspaper,
table-cloths, curtains, etc.
Failure to do so may over-heat the product,
resulting in fire.
The product should be located so that its location or position does not interfere with its proper ventilation. Ensure a
minimum distance of 5cm around the product for sufficient ventilation.
+.+
%,*
/
./
.-+
*.
.+
$'
Should an abnormality occur in the product, immediately turn the power OFF, disconnect the power cord plug, and then
contact the shop from which the product was purchased.
)!%$
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
$!%$
Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et
pousser jusqu'au fond.
*.
*
If your product is marked with this recycling symbol it means that, at the end of its life, you must dispose of it
separately by taking it to an appropriate collection point.
You should not mix it with general household waste. Disposing of this product correctly will prevent potential negative
effects on the environment and human health which could otherwise arise due to inappropriate waste handling.
For further details, please contact your local authority.
(European Union only)
!
*)"
!#&%'$
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
BLUE :
NEUTRAL
BROWN : LIVE
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
Do not plug either terminal of the power cord to the the ground od AC outlet on the wall.
'
!*'+
This instrument complies with the limits for a class B digital apparatus, pursuant to the Radio Interference Regulations,
C.R.C., c. 1374.
!*.
)(
)!%$ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
$% This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
Products :
Model Number :
Responsible Party Name :
Address :
Telephone
The nameplate label is located on
the underside of the instrument, as
indicated below.
Electronic Piano
CS10
Kawai America Corporation
2055 East University Drive Rancho
Dominguez, CA 90220
310-631-1771
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This applies only to products distributed by Kawai America Corporation.
Nameplate
Table of Contents
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 4
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Introduction
Recorder
Song Recorder (Internal memory) . . . . . . . . . . . . . . . . . . . .44
1. Recording a song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
2. Playing a song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Welcome to the Classic Series . . . . . . . . . . . . . . . . . . . . . . . 10
3. Internal Player Edit menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1. Feature Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. Erasing a part/song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
2. Owner’s Manual Conventions . . . . . . . . . . . . . . . . . . . . . . . . 11
5. Converting a song to an audio file . . . . . . . . . . . . . . . . . . . . 49
Part Names and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Audio Record/Playback (USB memory) . . . . . . . . . . . . . . . 50
Setting Up the Piano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1. Recording an MP3/WAV audio file . . . . . . . . . . . . . . . . . . . . 50
Adjusting the Volume / Using Headphones . . . . . . . . 15
2. Playing an MP3/WAV audio file . . . . . . . . . . . . . . . . . . . . . . . 52
3. Playing a MIDI song file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Playing the Piano
Using the Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Dual Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Split Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Four Hands Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4. USB Player Edit menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5. Converting a MIDI song to an audio file . . . . . . . . . . . . . . 57
6. Overdubbing a MP3/WAV audio file . . . . . . . . . . . . . . . . . . 58
Settings
Function menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Reverb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
1. Key Transpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2. Song Transpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Metronome / Drum Rhythms . . . . . . . . . . . . . . . . . . . . . . . .28
3. Tone Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Registration Memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Panel Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
User Tone Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
4. Speaker Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5. Phones Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Music Menu
Demo Songs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6. Line In Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7. Line Out Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8. Wall EQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Piano Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
10. Damper Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
1. Selecting a lesson book/song . . . . . . . . . . . . . . . . . . . . . . . . 34
11. Four Hands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
2. Listening to the selected song. . . . . . . . . . . . . . . . . . . . . . . . 35
12. LCD Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
3. Lesson Function settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
13. User Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
4. Repeating sections of a lesson song . . . . . . . . . . . . . . . . . . 37
14. Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5. Recording a lesson song practise . . . . . . . . . . . . . . . . . . . . . 38
6. Finger Exercises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Concert Magic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1. Performing a Concert Magic song . . . . . . . . . . . . . . . . . . . . 40
2. Concert Magic demo mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3. Concert Magic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4. Concert Magic song arrangement types . . . . . . . . . . . . . 43
8
9. Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Lesson Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Settings (cont.)
Settings (cont.)
Virtual Technician Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 76
USB MIDI (USB to Host port) . . . . . . . . . . . . . . . . . . . . . . . . . .105
1. Touch Curve. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
USB Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
User Touch Curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
1. Load Song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
2. Voicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
2. Load Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
3. Damper Resonance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
3. Load User Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
4. Damper Noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4. Save Song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
5. String Resonance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5. Save SMF Song . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
6. Key-off Effect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6. Save Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
7. Fall-back Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
7. Save User Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
8. Hammer Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
8. Rename File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
9. Topboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
9. Delete File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
10. Decay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
10. Format USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
11. Minimum Touch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
12. Stretch Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Power Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Auto Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
User Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
13. Temperament . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
User Temperament . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
14. Temperament Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
15. User Key Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
16. Half-Pedal Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Appendix
Connecting to Other Devices . . . . . . . . . . . . . . . . . . . . . . . 118
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Demo Song List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
17. Soft Pedal Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Sound List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
MIDI Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Program Change Number List . . . . . . . . . . . . . . . . . . . . . . 124
MIDI Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Drum Rhythm List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
1. MIDI Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
2. Send Program Change Number . . . . . . . . . . . . . . . . . . . . 100
3. Local Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
MIDI Exclusive Data Format . . . . . . . . . . . . . . . . . . . . . . . . 128
MIDI Implementation Chart . . . . . . . . . . . . . . . . . . . . . . . . 129
4. Transmit Program Change Numbers . . . . . . . . . . . . . . . .102
5. Multi-timbral Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
User Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
6. Channel Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
9
Welcome to the Classic Series
1 Feature Highlights
Grand Feel wooden-key action with Ivory Touch key surfaces and ‘Let-Off’ mechanism.
The CS10 digital piano utilises Kawai’s latest Grand Feel wooden-key keyboard action, which draws upon 85 years of
acoustic piano craftsmanship to provide an exceptionally realistic playing experience.
Introduction
As with a grand piano, all eighty-eight black and white keys are crafted entirely from long pieces of wood, pivoting on
a central balance pin in a smooth, seesaw-like motion. The new Grand Feel keys are longer than any other digital piano
keyboard action, with the pivot point distance extended to match that of a Kawai grand piano. When the front of a
key is pressed down, the rear rises, throwing a hammer which plays the note. These hammers are graded in size and
weight, replicating the heavier bass and lighter treble notes of an acoustic grand piano, while additional counter-weights
embedded within the lower keys help to lighten their touch during pianissimo passages. The Grand Feel keyboard
action even reproduces the subtle let-off sensation felt when playing the keys of a grand piano very softly, satisfying the
expectations of even the most discerning pianists.
Finally, the Grand Feel keyboard action features Kawai’s Ivory Touch key surfaces as standard. This finely textured material
gently absorbs moisture to assist playing control, and possesses a natural, matte finish that is smooth, but not slippery.
Harmonic Imaging XL (HI-XL) with 88-key piano sampling
The CS10 digital piano captures the beautiful sound of Kawai’s highly acclaimed hand-built EX concert grand piano, with all
88 keys of this exceptional instrument meticulously recorded, analysed and faithfully reproduced using the latest Harmonic
Imaging™ XL sound technology. This unique process accurately recreates the broad dynamic range of the original grand
piano, affording pianists an extraordinary level of expressiveness ranging from the softest pianissimo to the strongest,
boldest fortissimo.
This Classic Series model features a wide range of Concert, Studio, Jazz, Modern, and Pop grand piano sounds, and also
include a full-bodied traditional upright piano sound.
Strong selection of additional instrument sounds
Supplementing the realistic acoustic piano voices, the CS10 digital piano also features an excellent selection of additional
instrument sounds, ranging from electric pianos and drawbar and church organs, to strings, brass, and woodwind
instruments, inviting musicians to add greater variety to their performances.
Furthermore, the Dual playing mode also allows two different sounds, such as grand piano and strings, to be layered
together, while the Split and Four Hands modes divide the keyboard into two independent sections. The volume balances
for each playing mode can also be adjusted quickly and easily using the real-time panel controls.
Virtual Technician adjustments to personalise the instrument’s character
The CS10 digital piano’s Virtual Technician feature allows various characteristics of the selected acoustic piano, electric
piano, or harpsichord sound to be shaped at the touch of a button, with settings to adjust voicing and regulation, string
and damper resonances, and subtle hammer, damper, and key release noises. It is even possible to adjust the precise
tuning and volume of individual notes, before saving one’s personal configuration to an onboard registration memory.
USB to Device functionality, with MP3/WAV file recording and playback
The CS10 digital piano is equipped with USB connectors that not only allow the instrument to be connected to a computer
for MIDI use, but also to load and save data to USB memory devices directly. This ‘USB to Device’ feature allows instrument
settings or recorded songs stored in internal memory to be saved to USB for posterity, or standard MIDI files (SMF)
downloaded from the internet to be conveniently played back without additional hardware.
USB memory devices can also be used to play back MP3 or WAV audio files, allowing musicians to learn the chords or
melody for a new piece, or to simply play along with their favourite songs. It is even possible to save performances as MP3
or WAV files for emailing to friends and family, listening to on the move, or for further editing using an audio workstation.
Wide range of connectivity options
The CS10 digital piano features a variety of connectivity options, with Line-level output jacks that allow the instrument to
be enjoyed in larger settings such as churches and schools. Standard MIDI and ‘USB to Host’ connectors ensure flexibility
when using computers and other electronic instruments, while the Line-in jacks provide a convenient method of mixing
in audio from a laptop, tablet, or other digital device.
10
2 Owner’s Manual Conventions
This owner’s manual utilises a number of illustrative conventions in order to explain the CS10 digital piano’s various
functions. The examples below provide an overview of the button LED indicator states and press types, and the
appearance of difference kinds of text.
Introduction
„ Button LED indicator states
LED indicator off:
Sound/Function is not selected.
LED indicator on:
Sound/Function is selected.
LED indicator flashing:
Sound/Function is selected in a
temporary state.
„ Button press types
×4
×2
Normal press:
Select a sound or function.
Press multiple times:
Cycle through sounds or settings.
ld
ho
ld
ho
Press and hold:
Select a function’s settings, or
store registration memories etc.
Press twice:
Select a sound or function.
Press and hold, then press X:
Combine two sounds.
„ Text appearance
Normal instruction and explanation text
is written in regular type at 9 pt. size.
Captions explaining the LCD display
or button functions, are written in
bold type at 8.5 pt. size.
* Notes about functions are marked with an
asterisk and written in 8 pt. size.
Reminders about previous operations are
written in italic type at 9 pt. size.
Example operations are written in italic type
at 8 pt. size, and enclosed within a grey box.
11
Part Names and Functions
Introduction
c
d
a
e
f
g
h
i
b
j
k
l
m
n
12
o
p
q
a POWER switch
i PLAY/STOP button
This switch is used to turn the instrument on/off. Be sure to turn
off the instrument after playing.
This button is used to start/stop the playback of demonstration
songs, Piano Music pieces, and Lesson and Finger Exercises, and
to start/stop the recording and playback of recorder songs, and
MP3/WAV audio files.
i REC button
b MASTER VOLUME knob
This button is used to record performances to internal memory
or a USB memory device as MP3/WAV audio files.
This knob controls the master volume level of the instrument’s
built-in speakers or headphones, if connected.
j SOUND buttons
* The MASTER VOLUME knob will not affect the volume level of the LINE
OUT connectors.
c LCD display
The LCD display provides useful information such as the
currently selected sound name, settings values, and the status
of other functions when active.
* A protective plastic film is attached to the display during production.
Please remove this film before attempting to play the instrument.
d
FUNCTION button
These buttons are used to select one of three functions/options
shown at the bottom of the LCD display.
Introduction
* The CS10 digital piano features a power saving mode that can turn
off the instrument automatically after a specified period of inactivity.
For more information, please refer to the ‘Auto Power Off’ setting on
page 117.
These buttons are used to select the sound(s) that will be heard
when playing the keyboard of the CS10 digital piano. Multiple
sounds are assigned to each category button, and can be
selected by pressing the same button repeatedly.
These buttons are also used to select Registration memories.
k REGISTRATION button
This button is used to store and recall one of the sixteen different
registration memories. Each registration can store sound, reverb
and effects settings, as well as various other panel options.
l USB to DEVICE port
This port is used to connect a FAT or FAT32 formatted USB
memory device to the instrument in order to load/save recorded
song data, registration memories, and MP3/WAV/SMF files etc.
m PHONES jacks
These jacks are used to connect stereo headphones to the CS10
digital piano. Two pairs of headphones can be connected and
used simultaneously.
n LINE IN jacks
e ARROW buttons
These buttons are used to navigate around the various menus
and screens, adjust values, and answer on-screen prompts.
f EFFECTS button
This button is used to turn effects for the selected sound on/off,
to select the different effect types, and to adjust their settings.
These jacks are used to connect the stereo output from audio
equipment, computers, or other electronic instruments to the
CS10 digital piano’s amplifier and speakers.
When using the Left/Right 1/4” phone jacks, the input level can
be adjusted by using the LEVEL knob.
o LINE OUT jacks
g REVERB button
These jacks are used to connect the stereo output (Left/Right
1/4” phone plug) of the CS10 digital piano to external amplifiers,
mixers, recording devices, and similar equipment.
This button is used to turn reverb for the selected sound on/off,
to select the different reverb types, and to adjust their settings.
p USB to HOST port
h METRONOME button
This port is use to connect the CS10 digital piano to a computer
using a USB ‘B to A’ type cable in order to send and receive MIDI
data.
This button is used to turn the metronome function on/off, and
also to adjust the tempo, time signature (or beat), and volume
settings.
q MIDI IN / OUT jacks
These jacks are used to connect the CS10 digital piano to
external MIDI devices such as other musical instruments or a
computer in order to send and receive MIDI data.
* For more information about the instrument’s connectors and jacks,
please refer to ‘Connecting to Other Devices’ on page 118.
13
Setting Up the Piano
2. Connecting the power cable to an outlet
Connect the included power cable to the ‘AC IN’ inlet located on
the back side of instrument in the bottom left corner.
Connect the instrument’s power cable to an AC outlet.
Introduction
1. Connecting the power cable to the instrument
3. Turning on the power
Press the POWER switch located on the right hand side of the front panel.
The instrument will turn on, and the words ‘Concert Grand’ will
be shown in the LCD display, indicating that the Concert Grand
sound is selected, and the instrument is ready to be played.
* The CS10 digital piano features a power saving mode that can turn
off the instrument automatically after a specified period of inactivity.
For more information, please refer to the ‘Auto Power Off’ setting on
page 117.
„ Adjusting the pedal support bolt
A pedal support bolt is attached at the base of the pedal board
to aid stability when the pedals are pushed.
Turn the bolt anti-clockwise until it makes contact with the floor
and supports the pedals firmly.
Pedal support bolt
14
Adjusting the Volume / Using Headphones
„ Adjusting the volume
The MASTER VOLUME knob controls the volume level of the
instrument’s speakers, or headphones if connected.
Turn the knob clockwise to increase the volume, and anticlockwise to decrease the volume.
* The MASTER VOLUME knob will not affect the volume level of the LINE
OUT connectors.
Decrease
volume
Introduction
Use this knob to set the volume to a comfortable listening level
- the middle is often a good starting point.
Increase
volume
* The LINE OUT level can be reduced by using the ‘Line Out Volume’
setting. Please refer to page 68 for more information.
* The maximum volume level of the speakers can be reduced by
using the ‘Speaker Volume’ setting. Please refer to page 65 for more
information.
„ Using headphones
Use the jacks located beneath the keyboard on the left hand
side, to connect stereo headphones to the CS10 digital piano.
Two pairs of headphones can be connected and used
simultaneously.
When a pair of headphones is connected, sound will not be
produced by the speakers. In addition, the PHONES indicator in
the LCD display will be highlighted.
Headphones connected
* The maximum volume level of the headphones output can be
increased by using the ‘Phones Volume’ setting. Please refer to page
66 for more information.
„ Accessing the Control Panel
Lift the left cheek-block cover to access the control panel.
Please open and close the control panel cover carefully to
prevent damaging the instrument.
15
sectionthe Pedals
Using
As with a grand piano, the CS10 digital piano features three pedals: sustain, sostenuto, and soft.
„ Sustain pedal (right pedal)
Depressing this pedal sustains the sound after one’s hands have
been lifted from the keyboard - greatly enriching the piano
sound, while also assisting smooth ‘legato’ passages.
The sustain pedal is capable of responding to half pedaling.
Soft pedal
Sostenuto pedal
Playing the Piano
Sustain pedal
„ Soft pedal (left pedal)
„ Sostenuto pedal (centre pedal)
Depressing this pedal softens the sound, reducing its volume.
Depressing this pedal after playing the keyboard and before
releasing the keys, sustains the sound of only those notes that
have been played. Any keys that are subsequently played after
the sostenuto pedal is depressed will not be sustained.
When the rotary speaker effect is selected, the soft pedal is also
used to alternate the speed of the rotary simulation between
‘Slow’ and ‘Fast’ effect modes.
„ Pedal support bolt
A pedal support bolt is attached at the base of the pedal board
to aid stability when the pedals are pushed.
Turn the bolt anti-clockwise until it makes contact with the floor
and supports the pedals firmly. If the pedal support bolt does
not make contact with the floor, the pedal board may become
damaged.
Pedal support bolt
When moving the instrument, always adjust or remove the pedal
support bolt, then readjust when the instrument is in its new position.
„ Caring for the pedals
If the surface of the pedals becomes dirty, clean the pedals using a dry dish-washing sponge.
Do not attempt to clean the pedals using rust-removing solvents, abrasives or files.
„ Grand Feel pedal system
The CS10 digital piano features the Grand Feel pedal system, which replicates the sustain, soft, and sostenuto pedal weighting of
Kawai’s EX Concert Grand piano. It is also possible to adjust the sensitivity of the sustain/damper pedal, and the effectiveness of the
soft pedal using the ‘Half-Pedal Adjust’ and ‘Soft Pedal Depth’ settings.
* For more information, please refer to page 95.
16
section Sounds
Selecting
The CS10 digital piano features a wide selection of realistic instrument sounds suitable for various musical styles.
Sounds are arranged into eight categories, with several sounds assigned to each category button. For a complete
listing of available instrument sounds, please refer to page 123 of this owner’s manual.
By default, the ‘Concert Grand’ sound will be selected automatically when the instrument is turned on.
„ Selecting a sound
Press the desired SOUND button.
LED indicator on:
Sound category is selected.
Playing the Piano
The LED indicator for the button will turn on to indicate that this
category has been selected, and the name of the sound will be
shown in the LCD display.
Example: To select the E.PIANO category, press
the E.PIANO button.
„ Changing the sound
Several sounds are assigned to each category button.
Press the selected category button repeatedly to cycle through
the different sound variations.
×3
Example: To select the ‘Studio Grand’ sound,
press the PIANO1 button three times.
The d or c buttons can also be used to select sounds and cycle
through the different sound variations.
17
Dual Mode
The Dual Mode function allows two sounds to be layered together, creating a more complex sound.
For example, a piano sound layered with strings, or a church organ combined with a choir, etc.
1. Entering Dual mode
Press and hold a SOUND button to select the main sound, then
press another SOUND button to select the layered sound.
Playing the Piano
Main
sound
ld
ho
The LED indicators for both SOUND buttons will turn on to
indicate that Dual Mode is in use, and the respective sound
names will be shown in the LCD display.
Layered
sound
2a. Changing the main/layered sounds: Method 1
To select a different variation for the layered sound:
Press and hold the main SOUND button, then press the layered
SOUND button repeatedly to cycle through the different sound
variations.
×2
ld
ho
Example: To change the layered ‘Slow Strings’ sound
to the ‘Warm Strings’ sound, press and hold the PIANO1
button, then press the STRINGS button twice.
To select a different variation for the main sound:
Press and hold the layered SOUND button, then press the main
SOUND button repeatedly to cycle through the different sound
variations.
×3
ld
ho
Example: To change the main ‘Concert Grand’ sound to
the ‘Studio Grand 2’ sound, press and hold the STRINGS
button, then press the PIANO1 button three times.
2b. Changing the main/layered sounds: Method 2
It is also possible to change the main/layered sound without
pressing and holding buttons.
ef buttons:
Change sound variation.
Press the d or c buttons to move the selection cursor over the
main sound or layered sound.
Press the e or f buttons to cycle through the different sound
variations.
dc buttons:
Move selection cursor.
18
Dual Mode settings
The Dual Mode settings menu allows characteristics of the combined sound to be adjusted.
„ Dual Mode settings
Dual Mode setting
Description
Default setting
Balance
Adjust the volume balance between the main and layered sounds.
5:5
Layer Octave Shift
Raise/lower the pitch of the layered sound in octave steps.
0
Dynamics
Adjust the dynamic sensitivity of the layered sound relative to the main sound.
10
„ Entering the Dual Mode settings menu
Press the
Playing the Piano
While the Dual Mode screen is shown in the LCD display:
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Dual Mode settings menu will be shown in the LCD display.
* Preferred Dual Mode settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
„ Adjusting Dual Mode settings
After entering the Dual Mode settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
3. Exiting Dual mode
Press the
FUNCTION button (EXIT) to exit Dual Mode.
19
Split Mode
The Split Mode function divides the keyboard into two sections, allowing each section to be played with a different
sound. For example, a bass sound in the lower section, and a piano sound in the upper section.
1. Entering Split mode
Press the
FUNCTION button (SPLIT).
The LED indicator for the FUNCTION button will turn on, and
the Split Mode screen will be shown in the LCD display.
LED indicator on:
Upper section sound.
* The default split point is set between keys B2 and C3.
Playing the Piano
The upper section and lower section sound names will be
shown in the LCD display. The LED indicator for the upper
section sound button will turn on, and the LED indicator for the
lower section sound button will start to flash.
Upper
section
sound
Lower
section
sound
* By default, the lower section will be set to the ‘Wood Bass’ sound.
LED indicator flashing:
Lower section sound.
2a. Changing the upper/lower section sounds: Method 1
To select a different sound for the upper section:
To select a different sound for the lower section:
Press the desired SOUND button.
Press and hold the
SOUND button.
FUNCTION button, then press the desired
×2
Example: To select the 'Jazz Organ' sound for the
upper section, press the ORGAN button twice.
* Preferred Split Mode upper/lower section sound combinations can be
stored to a Registration memory for convenient recall. Please refer to
page 30 for more information.
Example: To select the 'W. Bass & Ride' sound for the
lower section, press and hold the 1 FUNCTION button,
then press the BASS & GUITAR button four times.
2b. Changing the upper/lower section sounds: Method 2
It is also possible to change the upper/lower section sound without
pressing and holding buttons.
ef buttons:
Change sound variation.
Press the d or c buttons to move the selection cursor over the
upper section or lower section sound.
Press the e or f buttons to cycle through the different sound
variations.
dc buttons:
Move selection cursor.
20
3. Changing the split point
Press and hold the FUNCTION button, then press the desired
split key on the keyboard.
The name of the pressed key will briefly be shown in the LCD
display, and will become the new split point.
ho
ld
Lower section
Upper section
Playing the Piano
New split point
Split Mode settings
The Split Mode settings menu allows characteristics of the Split Mode sound and operation to be adjusted.
„ Split Mode settings
Split Mode setting
Description
Default setting
Balance
Adjust the volume balance between the upper and lower sections.
5-5
Lower Octave Shift
Raise/lower the pitch of the lower section sound in octave steps.
0
Lower Pedal
Enable/disable the sustain pedal for the lower section sound.
Off
„ Entering the Split Mode settings menu
While the Split Mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Split Mode settings menu will be shown in the LCD display.
* Preferred Split Mode settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
„ Adjusting Split Mode settings
After entering the Split Mode settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
21
Four Hands Mode
The Four Hands Mode function divides the keyboard into two sections in a similar way to that of the Split Mode
function. However, with Four Hands Mode enabled, the octave/pitch of each section is automatically adjusted to
create two separate 44-key instruments with the same playing range. Furthermore, the sustain (right) pedal and
soft (left) pedal act as separate sustain pedals for the respective upper and lower sections, allowing two people to
perform piano duets using a single instrument.
1. Entering Four Hands mode
Press the FUNCTION button (SPLIT) once to enter Split Mode,
then press the
FUNCTION button (4HAND) again to select
Four Hands Mode.
* The default four hands mode split point is set between keys E3 and F3.
Playing the Piano
The LED indicator for the FUNCTION button will turn on. The
Four Hands Mode screen and right/left section sound names
will be shown in the LCD display.
Right
section
sound
Left
section
sound
* By default, the right and left sections will both be set to the ‘Concert
Grand’ sound.
2a. Changing the right/left section sounds: Method 1
To select a different sound for the right section:
To select a different sound for the left section:
Press the desired SOUND button.
Press and hold the FUNCTION button (SPLIT), then press the
desired SOUND button.
×2
ld
ho
Example: To select the 'Classic E.P.' sound for the
right section, press the E.PIANO button.
* Preferred Four Hands Mode right/left section sound combinations
can be stored to a Registration memory for convenient recall. Please
refer to page 30 for more information.
Example: To select the 'Pop Piano' sound for the
left section, press and hold the 1 FUNCTION button,
then press the PIANO2 button.
2b. Changing the right/left section sounds: Method 2
It is also possible to change the right/left section sound without
pressing and holding buttons.
ef buttons:
Change sound variation.
Press the d or c buttons to move the selection cursor over the
right section or left section sound.
Press the e or f buttons to cycle through the different sound
variations.
dc buttons:
Move selection cursor.
22
3. Changing the Four Hands mode split point
Press and hold the FUNCTION button, then press the desired
split key on the keyboard.
The name of the pressed key will briefly be shown in the LCD
display, and will become the new split point.
ho
ld
Left section
Right section
Playing the Piano
New split point
Four Hands Mode settings
The Four Hands Mode settings menu allows characteristics of the Four Hands Mode sound to be adjusted.
„ Four Hands Mode settings
Four Hands Mode setting
Description
Default setting
Balance
Adjust the volume balance between the right and left sections.
5-5
Right Octave Shift
Raise/lower the pitch of the right section sound in octave steps.
0
Left Octave Shift
Raise/lower the pitch of the left section sound in octave steps.
+2
„ Entering the Four Hands Mode settings menu
While the Four Hands Mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Four Hands Mode settings menu will be shown in the LCD
display.
* Changes made to the Four Hands Mode settings will not affect the
Split Mode settings, and vice versa.
* Preferred Four Hands Mode settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
„ Adjusting Four Hands Mode settings
After entering the Four Hands Mode settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
23
Reverb
Reverb adds reverberation to the sound, simulating the acoustic environment of a recital room, stage, or concert
hall. Some sound types, such as acoustic piano, enable reverb automatically in order to improve acoustic realism.
The CS10 digital piano features six different reverb types.
Playing the Piano
„ Reverb types
Reverb type
Description
Room
Simulates the ambiance of a small rehearsal room.
Lounge
Simulates the ambience of piano lounge.
Small Hall
Simulates the ambiance of a small hall.
Concert Hall
Simulates the ambiance of a concert hall or theater.
Live Hall
Simulates the ambiance of a live hall or stage.
Cathedral
Simulates the ambiance of a large cathedral.
1. Turning Reverb on/off
Press the REVERB button to turn reverb on/off.
The LED indicator for the REVERB button will turn on to indicate
when reverb is in use, and the current status will briefly be
shown in the LCD display.
Reverb
status
Reverb
type
Reverb settings
The Reverb settings menu allows the type and characteristics of the reverb to be adjusted.
„ Reverb settings
24
Reverb setting
Description
Range
Type
Changes the type of environment.
–
Depth
Adjusts the depth of the environment (i.e. amount of reverberation to apply).
1 - 10
Time
Adjusts the decay length/speed of the reverberation.
1 - 10
„ Entering the Reverb settings menu
Press and hold the REVERB button.
The Reverb settings menu will be shown in the LCD display.
ld
ho
„ Adjusting Reverb settings
After entering the Reverb settings menu:
ef buttons:
Adjust selected setting.
Playing the Piano
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
„ Exiting the Reverb settings menu
Press the
menu.
FUNCTION button (EXIT) to exit the Reverb settings
* Reverb settings are independent for each sound variation.
* Any changes made to the reverb type, settings, or on/off status will
remain until the power is turned off.
* Preferred reverb settings can be stored to a Registration memory for
convenient recall. Please refer to page 30 for more information.
25
Effects
In addition to reverb, various other effects can be applied to the selected sound, altering the tonal character
and feeling of the instrument. As with reverb, some sound types enable certain effects automatically in order to
enhance tonal quality. The CS10 digital piano features 11 different effect types, with 4 combination effects, and 3
additional amplified effects.
Playing the Piano
„ Effect types
Effect type
Description
Stereo Delay
Adds an echo effect to the sound, playing through both speakers (stereo) simultaneously.
Ping Delay
Adds a ‘ping pong’ echo effect to the sound, giving the impression that it is ‘bouncing’ from left to right.
Triple Delay
Similar in principle to Ping Delay, but with an additional centre echo.
Chorus
Layers a slightly detuned version of the sound over the original, thus enriching its tonal character.
Classic Chorus
Similar in principle to Chorus, but intended for vintage electric piano sounds.
Tremolo
Continuously varies the volume at a constant speed, adding a vibrato type effect to the sound.
Classic Tremolo
Similar in principle to Tremolo, but intended for vintage electric piano sounds.
Auto Pan
Alternates the sound output from left to right across the stereo field using a sine wave.
Classic Auto Pan
Similar in principle to Auto Pan, but intended for vintage electric piano sounds.
Phaser
Applies a cyclic phase change to the sound, giving the impression that the sound is moving.
Rotary
Simulates the sound of a rotary speaker commonly used with vintage electronic organs.
There are three different levels of overdrive, with and without a Chorus effect.
* The soft pedal can be used to alternate the speed of the rotary simulation between ‘Slow’ and ‘Fast’ effect modes.
Combination Effects
Amplified Effects
Different combinations of the above effects, applied simultaneously.
* Combination effect types: Phaser+Chorus, Tremolo+Chorus, Phaser+AutoPan, Chorus+Chorus
A selection of the above effects, with a vintage electric piano speaker effect applied.
1. Turning Effects on/off
Press the EFFECTS button to turn effects on/off.
The LED indicator for the EFFECTS button will turn on to indicate
when effects are in use, and the current status will briefly be
shown in the LCD display.
Effect
type
Effect
status
„ Effects settings
Effect type
Effect setting
Description
Stereo Delay / Ping Delay / Triple Delay
Dry / Wet
Adjust the intensity of the delay.
Time
Adjust the interval of time between each delay.
Dry / Wet
Adjust the intensity of the chorus.
Speed
Adjust the speed of the chorus.
Chorus
26
Effect type
Effect setting
Description
Classic Chorus
Mono / Stereo
Toggle between a Mono or Stereo effect.
Speed
Adjust the speed of the chorus.
Dry / Wet
Adjust the intensity of the tremolo.
Speed
Adjust the speed of the tremolo.
Dry / Wet
Adjust the intensity of the pan.
Speed
Adjust the speed of the pan.
Dry / Wet
Adjust the intensity of the phaser.
Speed
Adjust the speed of the phaser.
Accel. Speed
Adjust the acceleration speed between slow and fast modes.
Rotary Speed
Adjust the speed of the rotary speaker.
Dry / Wet
Adjust the intensity of the effects.
Speed
Adjust the speed of the effects.
Tremolo / Classic Tremolo
Auto Pan / Classic Auto Pan
Phaser
Rotary
Combination Effects / Amplified Effects
Playing the Piano
„ Effects settings (cont.)
„ Entering the Effects settings menu
Press and hold the EFFECTS button.
The Effects settings menu will be shown in the LCD display.
ld
ho
„ Adjusting Effects settings
After entering the Effects settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
„ Exiting the Effects settings menu
Press the
menu.
FUNCTION button (EXIT) to exit the Effects settings
* Effects settings are independent for each sound variation.
* Any changes made to the effects type, settings, or on/off status will
remain until the power is turned off.
* Preferred effects settings can be stored to a Registration memory for
convenient recall. Please refer to page 30 for more information.
27
Metronome / Drum Rhythms
The Metronome function provides a steady beat to aid practicing the piano at a consistent tempo. In addition
to regular metronome beats, the CS10 digital piano also features a variety of drum rhythms to accompany most
playing styles and musical genres.
For a complete listing of available drum rhythms, please refer to page 126 of this owner’s manual.
„ Turning the Metronome on/off
Press the METRONOME button.
The LED indicator for the METRONOME button will turn on to
indicate that the metronome function is in use, and a 1/4 beat
will start to count.
Playing the Piano
The current metronome tempo in beats per minute (BPM) and
beat of the bar will also be shown in the LCD display.
Tempo
Beat
Press the METRONOME button again to stop the metronome.
The LED indicator for the METRONOME button will turn off.
Metronome settings
The Metronome settings menu allows the tempo, beat, and volume of the metronome to be adjusted.
„ Metronome settings
Metronome setting
Description
Range
Tempo
Adjust the tempo of the metronome beat / drum rhythm in beats per minute (BPM).
10 - 400 bpm
Beat
Volume
Change the metronome beat (time signature) / drum rhythm.
* There are ten different time signature available: 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, and 12/8.
Adjusts the volume of the metronome beat / drum rhythm.
„ Entering the Metronome settings menu
Press and hold the METRONOME button.
The Metronome settings menu will be shown in the LCD
display.
ld
ho
28
–
1 - 10
„ Adjusting Metronome settings
After entering the Metronome settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
FUNCTION button (RESET).
dc buttons:
Move selection cursor.
„ Drum rhythms
Playing the Piano
As an alternative to the simple metronome count, it is also possible
to select a drum pattern from one of 100 different rhythm styles.
Enter the Metronome settings menu and select the Beat setting.
Press the e or f buttons to cycle through the available beats
until reaching the ‘8 Beat 1’ drum rhythm.
Drum
rhythm
ef buttons:
Select drum rhythm.
Continue to press the e or f buttons to select the desired
drum rhythm.
* For a complete listing of available drum rhythms, please refer to page
126 of this owner’s manual.
„ Exiting the Metronome settings menu
Press the
FUNCTION button (EXIT) to exit the Metronome
settings menu.
* Any changes made to the metronome tempo, beat, or volume
settings will remain until the power is turned off.
* Preferred metronome settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
„Recording with the metronome
It is also possible to record songs with the metronome activated. This is useful when recording parts separately, or wishing to
maintain correct timing throughout complex passages. Note that the standard metronome ‘click’ will not be heard when the song
is played back, however if a drum rhythm is selected, the pattern will be heard.
* For more information about the instrument’s Recorder function, please refer to page 44.
29
Registration Memories
The Registration function allows the current instrument setup (sound selections, split point, reverb and effect
settings, and various other panel options) to be stored to a memory and conveniently recalled at the touch of
a button. There are two banks (‘A’ and ‘B’) for each registration button, allowing up to 16 different registration
memories to be stored.
Registrations can also be loaded from/saved to a USB memory device. Please refer to pages 108/112 for more
information.
Playing the Piano
„ Settings stored in Registration memories
Functions
Settings
Selected sound (including primary sound for each category)
Basic Settings
Dual Mode / Split Mode / Four Hands Mode (including settings)
Virtual Technician Settings
Reverb, Effects (Type, Settings)
MIDI Settings
Transpose (Key Transpose, Song Transpose)
Metronome (Beat, Tempo, Volume)
* Changes made to the Auto Power Off setting will be stored to User
Memory automatically.
„ Entering Registration mode
Press the REGISTRATION button.
The LED indicator for the REGISTRATION button will turn on to
indicate that the registration function is in use.
„ Selecting a Registration memory
When the registration function is in use:
Press the or FUNCTION buttons to select the registration
memory bank ‘A’ or ‘B’.
Press a SOUND button to select the desired registration memory.
The LED indicator for the pressed button will turn on to
indicate that the registration memory is selected.
Example: To select registration memory B-3, press the
FUNCTION button, then press the E.PIANO button.
„ Exiting Registration mode
Press the REGISTRATION button.
The LED indicator for the REGISTRATION button will turn off,
and the button panel will return to normal operation.
30
„ Storing a Registration memory
Press and hold the REGISTRATION button.
The eight registration memory buttons will start to flash.
ld
ho
Press the or FUNCTION buttons to select the registration
memory bank ‘A’ or ‘B’, then press a registration memory
(SOUND) button.
A beep will sound and the current instrument settings will be
stored to the selected registration memory.
Playing the Piano
Example: To store the current instrument setup to memory
A-4, press and hold the REGISTRATION button, then press
the FUNCTION button, and finally the ORGAN button.
„ Resetting all Registration memories
Press and hold the REGISTRATION and REC buttons, then turn the instrument’s power off/on.
All registrations will be reset to the factory default settings.
Panel Lock
The Panel Lock function allows the state of all panel buttons to be temporarily locked, preventing sounds and other
settings from being changed. This function may prove useful in teaching environments, ensuring that students are
not distracted by changing sounds etc.
1. Activating the Panel Lock
Press the d and c buttons simultaneously.
The Panel Lock screen will be shown in the LCD display, and the
instrument will stop responding to panel button presses.
* When activated, the Panel Lock will remain until the power is turned
off.
* While Panel Lock is activated, the LED indicators for all buttons will
turn off.
2. Deactivating the Panel Lock
While the Panel Lock is activated:
Press and hold the
FUNCTION button (UNLOCK).
A message will be shown in the LCD display to indicate that
the Panel Lock has been deactivated, and the instrument will
resume responding to panel button presses as normal.
31
Demo Songs
The Demo function provides an excellent introduction to the varied capabilities of CS10 digital piano. There are
over 30 different demonstration songs available, highlighting the instruments’ rich selection of high quality sounds
and its power speaker system.
For a complete listing of demonstration songs, please refer to page 122 of this owner’s manual.
„ Entering Demo mode
Press the
FUNCTION button (MUSIC).
The LED indicator for the FUNCTION button will start to flash,
and the Music Menu will be shown in the LCD display. Demo
mode will be selected automatically.
Press the
FUNCTION (ENTER) or PLAY/STOP buttons.
or
Music Menu
The LED indicator for the PIANO 1 button will start to flash, and
the ‘Concert Grand’ demo song will start to play.
„ Selecting a demo song
While Demo mode is selected:
Press a SOUND button to select a sound category.
The first demo song of the sound category will start to play.
Press the d or c buttons to cycle through the demo songs in
the selected sound category, and the e or f buttons to cycle
through the different sound categories.
ef buttons:
Select sound category
* When the selected song has finished, the next demo song in the
category will begin to play automatically.
dc buttons:
Select demo song
„ Stopping the demo song and exiting Demo mode
Press the FUNCTION (BACK) or PLAY/STOP buttons while the
song demo is playing.
The LED indicator for the selected SOUND button will stop
flashing, and the song demo will stop playing.
Press the
32
FUNCTION (EXIT) button to exit the Music Menu.
Piano Music
In addition to the sound demonstration songs, the CS10 digital piano also features a selection of popular classical
piano works from the Baroque and Romantic periods. Notated scores are provided in the separate ‘Classical Piano
Collection’ book*, assisting the musical appreciation and study of each piece.
* Depending on market area.
For a complete listing of Piano Music pieces, please refer to the separate ‘Internal Song Lists’ booklet.
„ Entering Piano Music mode
Press the FUNCTION button (MUSIC), then press the d or c
buttons to select Piano Music mode.
Press the
FUNCTION (ENTER) or PLAY/STOP buttons.
The LED indicator for the PIANO 1 button will start to flash, and
the piece ‘Tambourin’ by Rameau will start to play.
Music Menu
„ Selecting a piano music piece
While Piano Musice mode is selected:
Press the d or c buttons to cycle through the different piano
music pieces.
The title and composer of the selected piece will be shown in
the LCD display.
Title
Composer
* The balance of the left hand and right hand parts can be adjusted by
pressing the FUNCTION (EDIT) button, and adjusting the Balance
setting.
„ Replaying the selected piano music piece
When the selected piano music piece has finished:
Press the PLAY/STOP button to replay the piano music piece.
„ Stopping the piano music piece and exiting Piano Music mode
Press the FUNCTION (BACK) or PLAY/STOP buttons while the
piano music piece is playing.
The LED indicator for the PLAY/STOP button will turn off, and
the piano music piece will stop playing.
Press the
FUNCTION (EXIT) button to exit the Music Menu.
33
Lesson Function
The Lesson function allows budding pianists to practice the piano using a selection of built-in song books and
finger exercises. The left and right hand parts of each piece can be practiced separately*, adjusting the tempo to
perfect difficult passages, before being recorded for self-evaluation.
* When finger exercises are selected, the left and right hand part balance cannot be adjusted independently.
„ Built-in lesson mode song books
US, Canada, Australasia
Rest of the World
Alfred’s Premier Piano Course Lesson 1A
Burgmüller 25 (25 Etudes Faciles, Opus 100)
Alfred’s Premier Piano Course Lesson 1B
Czerny 30 (Etudes de Mécanisme, Opus 849)
Alfred’s Basic Piano Library Lesson Book Level 1A
Czerny 100 (Hundert Übungsstücke, Opus 139)
Alfred’s Basic Piano Library Lesson Book Level 1B
Beyer (Vorschule im Klavierspiel, Opus 101)
Alfred’s Basic Adult Piano Course Lesson Book Level 1
J.S. Bach: Inventionen, Sonatinen Album 1
* Lesson books sold separately - please refer to the separate ‘Internal Song Lists’ booklet for more information.
1 Selecting a lesson book/song
Music Menu
1. Entering lesson mode
Press the FUNCTION button (MUSIC), then press the d or c
buttons to select Lesson Mode.
Press the
FUNCTION button (ENTER) to enter lesson mode.
The name of the selected lesson book, song, and current bar
will be shown in the LCD display.
2. Selecting a lesson book/song
Press the d or c buttons to move the selection cursor over the
lesson book name or song title.
ef buttons:
Select lesson book/song.
Press the e or f buttons to cycle through the different lesson
books and song titles.
Book name
Song title
It is also possible to select songs by pressing and holding the
FUNCTION button (EDIT), then pressing the relevant key on
the keyboard.
34
dc buttons:
Move selection cursor.
* Please refer to the separate ‘Internal Song Lists’ booklet for a
complete listing of available lesson books/songs and corresponding
key numbers.
2 Listening to the selected lesson song
This page will explain how to play and stop the selected lesson song, and change the playback position.
1. Playing the lesson song
After selecting a lesson book and song:
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the song starts to play.
* If the first bar of the song begins on an ‘up’ beat (i.e. pickup notes),
the first bar number will be shown as zero in the LCD display.
* The metronome will not continue after the count-in bar, but can be
turned on manually by pressing the METRONOME button.
2. Changing the playback position (Bar)
ef buttons:
Change playback position.
Music Menu
Press the d or c buttons to move the selection cursor over the
third line of the LCD display (Bar).
Press the e or f buttons to rewind or cue the playback position
(Bar) of the current song.
Current bar
dc buttons:
Move selection cursor.
To reset the playback position to the first bar of the song, press
the REVERB and EFFECTS buttons simultaneously.
„ Stopping and resuming the lesson song
While the lesson song is playing:
Press the PLAY/STOP button to stop the lesson song playback.
Press the PLAY/STOP button once again to resume playback
from the stopped position.
3. Exiting lesson mode
Press the
FUNCTION (EXIT) button to exit the Music Menu.
35
Lesson Function
3 Lesson Function settings
The Lesson Function settings menu allows the left and right-hand part volumes of the current lesson song to be
adjusted, allowing each part to be practiced separately. It is also possible to adjust the playback tempo of the
current lesson song, allowing difficult passages to be practised more conveniently.
„ Lesson Function settings
Lesson Function setting
Description
Default setting
Balance
Adjust the volume balance between the left and right-hand parts.
5-5
Tempo
Adjust the playback tempo of the current lesson song in beats per minute (BPM).
Song specific
„ Entering the Lesson Function settings menu
After selecting a lesson book and song:
Press the
FUNCTION button (EDIT).
Music Menu
The Lesson Function settings menu will be shown in the LCD
display.
„ Adjusting the left/right-hand part volume
Press the d or c buttons to move the selection cursor over the
Balance setting, then press the e or f buttons to adjust the
volume of the left/right-hand part volume.
ef buttons:
Adjust left/right-hand volume.
Increasing the volume of the left-hand part will reduce the
volume of the right-hand part, and vice versa.
Example: To practice the right-hand part while listening
to the left-hand part, set the left-hand volume to 9.
* If the Beyer lesson book is selected, increasing the left-hand value will
decrease the volume of the student’s part, while increasing the righthand value will decrease the volume of the teacher’s part.
„ Adjusting the playback tempo of the lesson song
Press the d or c buttons to move the selection cursor over the
Tempo setting, then press the e or f buttons to adjust the
playback tempo of the lesson song.
* To reset the playback tempo of the selected lesson song to the default
value, press the FUNCTION button (RESET).
36
ef buttons:
Adjust playback tempo.
4 Repeating sections of a lesson song
The ‘A-B Loop’ feature of the Lesson Function allows sections of the selected lesson song to be ‘looped’ between
two points in order to practise difficult passages continuously.
1. Playing the lesson song
After selecting a lesson book and song:
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the song starts to play.
2. Specifying the start point (A) of the loop
Press the FUNCTION button (A-B) to specify the start point
of the loop.
Music Menu
The LED indicator for the FUNCTION button will start to flash,
indicating that the start point (A) of the loop has been set.
Point ‘A’ set
3. Specifying the end point (B) of the loop
Press the FUNCTION button (A-B) again to specify the end
point of the loop.
The LED indicator for the
FUNCTION button will turn on,
indicating that the end point of the (B) of the loop has been set.
Point ‘B’ set:
loop active
The defined ‘A-B’ section of the lesson song will repeat (loop),
allowing the passage to be practiced continuously.
* The Balance and Tempo lesson function settings can continue to be
adjusted while the A-B loop is in operation.
4. Cancelling the ‘A-B’ loop
Press the
loop.
FUNCTION button (A-B) once again to cancel the
The LED indicator for the FUNCTION button will turn off, and
the lesson song will resume normal playback.
37
Lesson Function
5 Recording a lesson song practice
The Lesson Function’s Record feature allows the left or right-hand parts of the selected lesson song to be recorded
to internal memory, and then played back for self-evaluation.
1. Starting the lesson song recording
After selecting a lesson book and song:
Press the REC button.
The LED indicators for the REC and PLAY/STOP buttons will turn
on to indicate that recording mode is in use.
* It may be desirable to adjust the Balance and Tempo lesson function
settings before starting the recording.
A one bar count-in will be heard before the lesson song starts
to play and record.
Music Menu
2. Stopping the lesson song recording
Press the PLAY/STOP button.
The LED indicators for the REC and PLAY/STOP buttons will turn
off, and the lesson song recording and playback will stop.
3. Playing back the recorded lesson song
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn on, and a
one bar count-in will be heard before the recorded lesson song
starts to play.
* The Balance and Tempo lesson function settings can continue to be
adjusted while the recorded lesson song practise is playing.
* The ‘A-B’ loop function cannot be used when recording a lesson song
practice.
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn off, and the
recorded lesson song will stop playing.
38
* Press the REC and PLAY/STOP buttons simultaneously to erase the
recorded lesson song practice. The recorded practice will be erased
automatically when a different lesson song is selected.
6 Finger Exercises
The lesson function also includes a selection of finger exercises for practicing major and minor scales, arpeggios,
chords, cadences, and Hanon exercises, with notated scores provided in the separate ‘Finger Exercises’ book.
The CS10 digital piano can also evaluate one’s practice, analysing note accuracy, timing evenness, and note volume
consistency, before displaying results for each category. Using this function, players can objectively review their
performances, and concentrate on improving a particular area of their technique.
1. Selecting and recording a Hanon finger exercise
While Lesson mode is in use:
Select the Hanon lesson book, then select a song number.
* It may be desirable to adjust the Balance and Tempo lesson function
settings before starting the recording.
Press the REC button.
Music Menu
The LED indicators for the REC and PLAY/STOP buttons will turn on to indicate that recording mode is in use.
A one bar count-in will be heard before the finger exercise starts to play and record.
2. Evaluating the recorded finger exercise
Press the PLAY/STOP button
The LED indicators for the REC and PLAY/STOP buttons will turn
off, and the finger exercise recording and playback will stop.
The recorded practice will be evaluated for note accuracy,
timing evenness, and volume consistency, with the results
shown alternately in the LCD display.
* Press the REC and PLAY/STOP buttons simultaneously to erase the
recorded lesson song practice. The recorded practice will be erased
automatically when a different lesson song is selected.
3. Playing back the recorded finger exercise
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn on, and
a one bar count-in will be heard before the recorded finger
exercise starts to play.
Press the PLAY/STOP button once again.
The LED indicator for the PLAY/STOP button will turn off, and the
recorded finger exercise song will stop playing.
* Press d or c buttons to cycle through the evaluation results. The
recorded finger exercise can be replayed even after cancelling the
evaluation result screen.
39
Concert Magic
The Concert Magic function allows complete beginners to enjoy playing the piano by simply selecting one of the
176 pre-programmed songs, then tapping the keyboard with a steady rhythm and tempo.
For a complete listing of available Concert Magic songs, please refer to the separate ‘Internal Song Lists’ booklet.
1 Performing a Concert Magic song
The 176 Concert Magic songs are divided into banks ‘A’ and ‘B’, with each bank containing 88 songs.
1. Entering Concert Magic mode
Press the FUNCTION button (MUSIC), then press the d or c
buttons to select Concert Magic.
Press the
FUNCTION button (ENTER) to enter Concert Magic.
Music Menu
The bank, number, and name of the selected Concert Magic
song will be shown in the LCD display.
2. Selecting a Concert Magic song
While Concert Magic mode is in use:
Press and hold the FUNCTION button (EDIT), then press the
key to which the Concert Magic song (bank ‘A’) is assigned.
* To select a song from bank ‘B’, press the same key again. Repeatedly
pressing the same key will alternate between banks ‘A’ and ‘B’.
3. Performing the selected Concert Magic song
Press a key on the keyboard.
The song will advance with every key that is pressed. Pressing
the keys gently will produce a soft sound, while pressing heavily
will produce a loud sound.
As the song advances, the z symbols shown in the LCD will be
replaced by y symbols. This is called the Note Navigator.
40
ld
ho
A Concert Magic song from bank ‘A’ will be selected, with the
song number and name shown in the LCD display.
4. Changing the Concert Magic playback sound
Press a SOUND button to change the sound used for the Concert
Magic song (melody and accompaniment parts).
It is also possible to select independent sounds for the melody and
accompaniment parts:
Press the FUNCTION button (SPLIT), to enable Concert Magic
split mode.
Press a SOUND button to change the melody sound.
Press and hold the FUNCTION button (SPLIT), then press a
SOUND button to change the accompaniment sound.
ld
ho
5. Exiting Concert Magic mode
Press the
FUNCTION button (BACK), to exit Concert Magic mode.
2 Concert Magic demo mode
Music Menu
This function allows all of the Concert Magic songs to be played back randomly or in designated categories.
„ Random playback
Enter Concert Magic mode and select the desired song.
Press the PLAY/STOP button.
All 176 Concert Magic songs will be played in a random order
until the PLAY/STOP button is pressed again.
„ Category playback
Enter Concert Magic mode and select the desired song.
Press and hold the
PLAY/STOP button.
FUNCTION button (EDIT), then press the
ld
ho
Songs in the same category as the selected song, will be played
in sequential order until the PLAY/STOP button is pressed again.
Example: If the song ‘Row, Row, Row Your Boat’ is selected, all
other songs in the ‘Children’s Songs’ category will be played.
41
Concert Magic
3 Concert Magic settings
The Concert Magic settings menu allows the playback tempo, playing mode, and volume balance to be adjusted.
„ Concert Magic settings
Concert Magic setting
Description
Default setting
Tempo
Adjust the playback tempo of the Concert Magic song in beats per minute (BPM).
Song specific
Mode
Change the Concert Magic playing mode (see below).
Normal
Balance
Adjust the volume balance between the melody and accompaniment parts.
10
„ Entering the Concert Magic settings menu
While Concert Magic mode is in use:
Press the
FUNCTION button (EDIT).
Music Menu
FUNCTION button will turn on,
The LED indicator for the
and the Concert Magic settings menu will be shown in the LCD
display.
„ Adjusting Concert Magic settings
After entering the Concert Magic settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
button (RESET).
FUNCTION
dc buttons:
Move selection cursor.
Steady Beat mode
Steady Beat mode allows all Concert Magic songs to be played by simply tapping any key with a constant steady
beat, regardless of the song arrangement type.
42
4 Concert Magic song arrangement types
Concert Magic songs are divided into three different arrangement types, each requiring a different level of skill to
be performed correctly.
* The Concert Magic arrangement type is for each song is indicated in the ‘Internal Song Lists’ booklet as ‘EB’, ‘MP’, or ‘SK’.
„ Easy Beat
EB
These are the easiest songs to play. To perform them, simply tap out a constant steady beat on any key on the keyboard.
The following example shows the notated score for ‘Für Elise’, indicating that a constant, steady rhythm should be maintained
throughout the song. This is the distinguishing characteristic of an Easy Beat song.
Key on:
X X
X X X X X X
X X X X X X
X X X X
X X
„ Melody Play
Music Menu
MP
These songs are also relatively easy to play, especially if they are familiar to the player. To perform them, tap out the rhythm of the
melody on any key of the keyboard. Singing along as the rhythm is tapped can be helpful.
The following example shows the notated score for ‘Twinkle, Twinkle, Little Star’.
* When performing fast Concert Magic songs, it may be easier to tap different keys with two alternating fingers in order to play at a greater speed.
Key on: X
X
X
X
X
X
X
X
X
X
X
X
X
X
SK
„ Skillful
These songs range in difficulty from moderately difficult to difficult. To perform them, tap out the rhythm of both the melody and the
accompaniment notes on any key of the keyboard. The Note Navigator will be very helpful when playing the Skillful type songs.
The following example shows the notated score for ‘Waltz of the Flowers’.
Key on
X
X
X
X
X
X
X X
X
X
X
X
X
43
Song Recorder (Internal Memory)
The CS10 digital piano allows up to 10 different songs to be recorded, stored in internal memory, and played back
at the touch of a button. Each song consists of two separate tracks - referred to as ‘parts’ - that can be recorded and
played back independently. This allows the left-hand part of a song to be recorded first on one track, and the righthand part to be recorded later on the other track.
1 Recording a song
1. Entering song recorder mode
Press the REC button.
The LED indicator for the REC button will start to flash, and the
Record Internal screen will appear with the currently selected
song and part number shown in the LCD display.
* If a USB memory device is connected, press the
(INT) to select the internal song recorder.
FUNCTION button
2. Selecting the song/part to be recorded
Press the d or c buttons to move the selection cursor over the
song memory or part.
ef buttons:
Select song memory/part.
Press the e or f buttons to change the selected song memory
or part to be recorded.
Recorder
If a part has already been recorded, a * symbol will be shown.
dc buttons:
Move selection cursor.
Part has been recorded
When recording part 1 and part 2 separately, select the song and part number
carefully in order to prevent accidentally overwriting a previously recorded part.
3. Starting the song recorder
Press a key on the keyboard, or the PLAY/STOP button.
The LED indicators for the REC and PLAY/STOP buttons will turn
on, and recording will start.
or
The current bar and beat will also be shown in the LCD display.
Recording
Metronome
tempo/beat
(if enabled)
44
* Pressing the PLAY/STOP button allows a rest period or empty bar to be
inserted at the beginning of the song.
* Press the METRONOME button before or during the recording to
turn on the metronome. The metronome ‘click’ sound will not be
recorded, however drum patterns will be recorded.
4. Stopping the song recorder
Press the PLAY/STOP button.
The LED indicators for the PLAY/STOP and REC buttons will turn
off, the recorder will stop, and the part/song will be stored in
internal memory.
After a few seconds, the Internal Song Player screen will be
shown in the LCD display, indicating that the song is ready for
playback.
Stopped
Seek bar
* The maximum recording capacity is approximately 90,000 notes, with
button and pedal presses also counted as one note.
* If the maximum recording capacity is reached during recording, the
recorder will stop automatically.
* Recorder songs will remain in memory after the power is turned off.
To play back the recorded song, please refer to the ‘Playing a Song’
instructions on page 46.
„Recording a second part
To record a second part, repeat the above instructions, selecting the part that has not been recorded to.
„Recording with the metronome
It is also possible to record songs with the metronome activated. This is useful when recording parts separately, or wishing to
maintain correct timing throughout complex passages. Note that the standard metronome click will not be heard when the song is
played back, however if a drum rhythm is selected, the pattern will be heard.
Recorder
* For more information about the instrument’s Metronome function, please refer to page 28.
„Changing panel settings while recording
In some cases, it may be desirable to make changes to the selected sound or style while recording a song. The tables below list the
various functions which will and will not be remembered during recording.
Panel operations remembered during recording
Panel operations NOT remembered during recording*
Changes made to the sound type. (SOUND buttons etc.)
Changes made to the reverb settings.
Switching between dual/split modes.
Changes made to the effects settings.
Changes made to the tempo.
Changes made to the volume balance in dual/split mode.
Changes made to transpose, tuning, touch, etc.
* Desired effects, reverb, and tempo settings etc. should be prepared
before recording a new song.
5. Exiting song recorder mode
Press the FUNCTION button (EXIT), to exit the Internal Song
Recorder and return to normal operation.
45
Song Recorder (Internal Memory)
2 Playing a song
This function is used to playback recorder songs stored in internal memory. To playback a song/part immediately
after recording, start this process from step 2.
1. Entering song play mode
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP button will turn on, and
the Internal Player screen will be shown in the LCD display.
Stopped
Seek bar
* If a USB memory device is connected, press the
(INT) to select the internal song recorder.
2. Selecting the song/part(s) to be played back
Press the d or c buttons to move the selection cursor over the
song memory or part.
ef buttons:
Select song memory/part.
Press the e or f buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be played back.
If a part has already been recorded, a * symbol will be shown.
Recorder
dc buttons:
Move selection cursor.
Part has been recorded
3. Starting/stopping song playback
Press the PLAY/STOP button.
The LED indicator for the PLAY/STOP buttons will turn on, and
the selected song/parts will start to play.
* The selected part can be changed during song playback.
* To adjust the playback tempo of the recorded song, press and hold
the METRONOME button, then press the e or f buttons.
Press the PLAY/STOP button again.
The LED indicator for the PLAY/STOP button will turn off and the
song will stop playing.
5. Exiting song play mode
Press the FUNCTION button (EXIT), to exit the Internal Song
Player and return to normal operation.
46
FUNCTION button
3 Internal Player Edit menu
The Internal Player Edit menu features transpose settings that allow the pitch of the keyboard or song to be adjusted
in semi-tone steps. This menu also includes functions to delete the song, or convert the song to an audio file.
„ Internal Player menu
Internal Player function Description
Default setting
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
Song Transpose
Raise or lower the pitch of the recorder song in semi-tone steps.
0
Erase
Erase a part of a recorder song from memory (see page 48).
–
Audio Convert
Convert a recorder song to an MP3/WAV audio file (see page 49).
–
„ Entering the Internal Player menu
While the Internal Player screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
Recorder
The LED indicator for the FUNCTION button will turn on, and
the Internal Player menu will be shown in the LCD display.
„ Adjusting the Internal Player settings/functions
After entering the Internal Player menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
button (RESET).
FUNCTION
dc buttons:
Move selection cursor.
„ Exiting the Internal Player menu
Press the FUNCTION button (BACK), to exit the Internal Player
menu and return to normal operation.
47
Song Recorder (Internal Memory)
4 Erasing a part/song
This function is used to erase recorder parts that may have been recorded incorrectly or songs that are no longer
listened to. Once a part/song has been erased from memory it cannot be recovered.
1. Selecting the Erase function
After entering the Internal Player menu (see page 47):
Press the d or c buttons to move the selection cursor over the
Erase function.
dc buttons:
Move selection cursor.
Press the
function.
FUNCTION button (ENTER) to select the Erase
2. Selecting the song/part to be erased
Press the d or c buttons to move the selection cursor over the
song memory or part.
ef buttons:
Select song memory/part.
Press the e or f buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be erased.
Recorder
If a part has already been recorded, a * symbol will be shown.
dc buttons:
Move selection cursor.
3. Erasing the selected song/part
Press the
and part.
FUNCTION button (OK) to Erase the selected song
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the erase operation.
Press the
FUNCTION button (YES) to confirm the erase
operation, or the FUNCTION button (NO) to cancel.
YES: Erase
„ Erasing all recorder songs from memory
Press and hold the PLAY/STOP and REC buttons, then turn the
instrument’s power off/on.
All recorder songs stored in memory will be erased.
ld
ho
ld
ho
48
NO: Cancel
5 Converting a song to an audio file
This function allows recorder songs stored in internal memory to be played back and saved (converted) as an audio
file to a USB device in either MP3 or WAV format.
1. Selecting the Convert to Audio function
After entering the Internal Player menu (see page 47):
Press the d or c buttons to move the selection cursor over the
Convert to Audio function.
dc buttons:
Move selection cursor.
Press the FUNCTION button (ENTER) to select the Convert to
Audio function.
2. Selecting the song/part to be converted
Press the d or c buttons to move the selection cursor over the
song memory or part.
ef buttons:
Select song memory/part.
Press the e or f buttons to change the selected song memory
(1-10) or part (1, 2, or 1&2) to be converted.
If a part has already been recorded, a * symbol will be shown.
FUNCTION button (OK) to continue.
dc buttons:
Move selection cursor.
Recorder
Press the
3. Selecting the audio file format
Press the e or f buttons to select the desired file format for the
converted song.
ef buttons:
Select audio recorder format.
It is also possible to adjust the recording gain at this stage.
* For more information about the instrument’s audio recorder gain
setting, please refer to page 50.
4. Starting the conversion
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will turn
on, the selected song will play, and the convert to audio process
will start.
* Notes played on the keyboard will also be recorded to the audio file.
„ Naming and saving the converted audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 51 from step 4.
49
Audio Record/Playback (USB Memory)
1 Recording a MP3/WAV audio file
The CS10 digital piano is also capable of recording performances as digital audio - saving the data to a USB memory
device in either MP3 or WAV format. This useful function allows professional quality recordings to be produced
directly on the instrument - without the need for additional sound equipment - then emailed to friends and family,
listened to away from the instrument, or edited and remixed further using an audio workstation.
In addition, the CS10 digital piano also supports mixing the LINE IN audio source with the recorded MP3/WAV file.
„ Audio Recorder format specifications
Audio format
Specifications
Bitrate
MP3
44.1 kHz, 16 bit, Stereo
192 kbit/s (fixed)
WAV
44.1 kHz, 16 bit, Stereo
1,411 kbit/s (uncompressed)
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
MP3 codec is Copyright (c) 1995-2007, SPIRIT.
1. Entering USB recorder mode
Connect a USB memory device to the USB port.
Press the REC button.
The LED indicator for the REC button will start to flash, and the
USB Recorder format screen will be shown in the LCD display.
2. Selecting the USB recorder file format
Recorder
Press the e or f buttons to select the desired USB recorder
audio file format (WAV or MP3).
ef buttons:
Select audio recorder format.
* MP3 audio files require less storage space than WAV audio files.
* A 1 GB USB memory device can store over 12 hours of MP3 audio data.
„ Adjusting the recording volume (Gain)
Press the FUNCTION button (GAIN).
The gain adjustment screen and recording level meter will be
shown in the LCD display.
* The gain setting can be adjusted within the range of 0 dB - 15 dB.
Press the e or f buttons to adjust the recorder gain setting.
* To reset the gain setting to the default level, press the
button (RESET).
50
FUNCTION
* Express caution when increasing the gain setting, as higher levels may
result in distorted recordings.
* The gain meter will also display the sound level of the LINE IN audio.
3. Starting the USB recorder
Press a key on the keyboard, or the PLAY/STOP button.
or
The LED indicators for the REC and PLAY/STOP buttons will turn
on, and recording will start.
The current recording time will also be shown in the LCD display.
Recording
Time
* Pressing the PLAY/STOP button allows a rest period or empty bar to be
inserted at the beginning of the song.
* Press the METRONOME button before or during the recording to
turn on the metronome. The metronome ‘click’ sound will not be
recorded, however drum patterns will be recorded.
4. Stopping the USB recorder, saving the file
Press the PLAY/STOP button.
The LED indicators for the PLAY/STOP and REC buttons will turn
off, and recording will stop
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
YES: Save
Recorder
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
NO: Cancel
5. Naming the recorded audio file, confirming save
After confirming the save operation:
ef buttons:
Move selection cursor.
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
dc buttons:
Select character.
Press the
FUNCTION button (OK) to confirm the save
operation, or the FUNCTION button (BACK) to cancel.
The recorded audio file will be saved with the specified name.
After a few seconds, the Play Audio screen will be shown in the
LCD display, indicating that the audio is ready for playback.
To play back the recorded audio file, please refer to the ‘Playing an
MP3/WAV audio File’ instructions on page 52.
OK: Save
BACK: Cancel
* ‘MP3 Song 01’ or ‘WAV Song 01’ will be used as the default name for the
recorded audio files, with the number increasing automatically.
* The recorded audio file will be saved in the root folder of the USB
memory device. It is not possible to save the file in a different folder.
51
Audio Record/Playback (USB Memory)
2 Playing an MP3/WAV audio file
The CS10 digital piano is also capable of playing MP3 and WAV audio files stored on a USB memory device directly
through the instrument’s speaker system. This function is particularly useful when attempting to learn the chords
or melody to a new piece, or to simply play along with one’s favorite song.
„ Audio Player supported format specifications
Audio format
Specifications
Bitrate
MP3
32 kHz/44.1 kHz/48 kHz, Mono/Stereo
8-320 kbit/s (fixed & variable)
WAV
32 kHz/44.1 kHz/48 kHz, Mono/Stereo, 16 bit
-
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
MP3 codec is Copyright (c) 1995-2007, SPIRIT.
„ Preparing the USB memory device
First, prepare a selection of MP3 or WAV audio files, copying the
data to a USB memory device.
* USB devices should be formatted to use the ‘FAT’ or ‘FAT32’ filesystems.
Please refer to page 119 for more information.
1. Entering USB playback mode
Connect a USB memory device to the USB port.
Press the PLAY/STOP button.
Recorder
The LED indicator for the the PLAY/STOP button will turn on,
and the Song Browser screen will be shown in the LCD display.
„ Song Browser screen
The Song Browser screen provides a listing of relevant files and
folders stored on the connected USB device.
The icon is used to represent an audio/song file.
The icon is used to represent a folder.
The icon is used to represent the current/previous folder.
dc buttons:
Move selection cursor.
FUNCTION button:
Select file/enter folder.
An example of a typical file/folder listing screen is shown below.
Please note that the visible screen height has been extended for
the purpose of this illustration.
52
Current/previous folder
* Files and folders will be listed in alphabetical order, with folders shown
at the top of the screen.
Folders
* When the USB Player function is selected, only MP3, WAV, and MID files
will be shown.
Files
* The LCD display is capable of showing filenames with a maximum
length of 12 characters (+3 character suffix). Filenames longer than 12
characters will be truncated automatically.
2. Selecting an audio file
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (SELECT) to select the audio file.
The audio play screen will be shown in the LCD display.
3. Playing the selected audio file
Press the PLAY/STOP button.
The selected audio file will start to play, and information about
the file will be shown in the LCD display.
Audio file,
artist/song
Playback
volume
Playing
position
* If the selected audio file contains embedded metadata (e.g. ID3 tags)
such as artist name and song title, this information will be also be
shown beside the filename.
„ Controlling audio file playback
While the audio file is playing:
ef buttons:
Rewind/advance playing position.
Press the PLAY/STOP button to pause and resume playback.
Press the e or f buttons to rewind or advance the playing
position of the audio file.
* The playback volume can be adjusted within the range of 1 - 128.
Press the FUNCTION button (A-B) twice to set the start and
end points of the A-B loop.
* Pressing the A-B button for a third time will turn off the loop.
dc buttons:
Adjust playback volume.
Recorder
Press the d or c buttons to adjust the playback volume of the
audio file.
* There may be a noticeable difference in volume between audio file
playback and the CS10 keyboard sound. When playing back audio
data, please adjust the volume of the audio file as desired.
„ USB Player Edit menu
The USB Player Edit menu allows the playback mode (Single, 1-Repeat, All-Repeat, Random) to be changed, and the pitch of the keyboard
to be transposed in semi-tone steps. Please refer to page 56 for more information.
„ Overdub function
The Overdub function allows the sound of the CS10 to be recorded (overdubbed) to an existing MP3 or WAV audio file.
Please refer to page 58 for more information.
4. Exiting USB playback mode
Press the
FUNCTION button (BACK) to exit USB playback
mode and return to normal operation.
53
Audio Record/Playback (USB Memory)
3 Playing a MIDI song file
The CS10 digital piano also supports the playback of Standard MIDI File (SMF) files and CS10 recorder songs stored
on a USB memory device, allowing a vast selection of widely accessible music to be heard through the instrument’s
exquisite Harmonic Imaging XL sound engine.
„ Song Player supported format specifications
Song format
Specifications
MID
Format 0, Format 1
KS0
Kawai Song file
„ Preparing the USB memory device
First, prepare a selection of MID (SMF) song files, copying the
data to a USB memory device.
* USB devices should be formatted to use the ‘FAT’ or ‘FAT32’ filesystems.
Please refer to page 119 for more information.
1. Entering USB playback mode
Connect a USB memory device to the USB port.
Press the PLAY/STOP button.
Recorder
The LED indicator for the the PLAY/STOP button will turn on,
and the Song Browser screen will be shown in the LCD display.
„ Song Browser screen
The Song Browser screen provides a listing of relevant files and
folders stored on the connected USB device.
The icon is used to represent an audio/song file.
The icon is used to represent a folder.
The icon is used to represent the current/previous folder.
dc buttons:
Move selection cursor.
FUNCTION button:
Select file/enter folder.
An example of a typical file/folder listing screen is shown below.
Please note that the visible screen height has been extended for
the purpose of this illustration.
Current/previous folder
Folders
Files
54
* Files and folders will be listed in alphabetical order, with folders shown
at the top of the screen.
* When the USB Player function is selected, only MP3, WAV, and MID files
will be shown.
* The LCD display is capable of showing filenames with a maximum
length of 12 characters (+3 character suffix). Filenames longer than 12
characters will be truncated automatically.
2. Selecting a MIDI file
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (SELECT) to select the MIDI file.
The MIDI play screen will be shown in the LCD display.
3. Playing the selected MIDI file
Press the PLAY/STOP button.
The selected MIDI file will start to play, and information about
the file will be shown in the LCD display.
MIDI file,
artist/song
Playback
volume
Playing
position
* The CS10 digital piano does not contain the full General MIDI/GM2
sound bank selection. Consequently, some SMF song files may not be
reproduced entirely accurately when played through the instrument.
„ Controlling MIDI file playback
While the MIDI file is playing:
Press the PLAY/STOP button to pause and resume playback.
ef buttons:
Rewind/advance playing position.
Press the e or f buttons to rewind or advance the playing
position of the MIDI file.
Press the d or c buttons to adjust the playback volume of the
MIDI file.
dc buttons:
Adjust playback volume.
Recorder
* The playback volume can be adjusted within the range of 1 - 128.
Press the FUNCTION button (A-B) twice to set the start and
end points of the A-B loop.
* Pressing the A-B button for a third time will turn off the loop.
„ USB Player Edit menu
The USB Player Edit menu allows the playback mode (Single, 1-Repeat, All-Repeat, Random) to be changed, the tempo of the MIDI song to
be adjusted, and the pitch of the keyboard or song to be transposed in semi-tone steps. Please refer to page 56 for more information.
„ Convert MIDI to Audio function
The Convert MIDI to Audio function allows MIDI files or CS10 recorder songs stored on a USB memory device to be converted to MP3/WAV
audio files. Please refer to page 57 for more information.
„ Exiting USB playback mode
Press the
FUNCTION button (BACK) to exit USB playback
mode and return to normal operation.
55
Audio Record/Playback (USB Memory)
4 USB Player Edit menu
The USB Player Edit menu allows the playback mode of the audio/MIDI file to be changed to one of four types. This
menu also features settings to adjust the MIDI song playback tempo, and to transpose the pitch of the keyboard or
MIDI song in semi-tone steps.
„ USB Player menu
USB Player function
Description
Default setting
Play Mode
Change the audio/MIDI file playback mode (see below).
Single
Tempo
Adjust the playback tempo of the MIDI song in beats per minute (BPM).
–
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
Song Transpose
Raise or lower the pitch of the recorder/MIDI song in semi-tone steps.
0
* Tempo and Song Transpose settings will not be shown when an audio file is selected.
„ Play Mode settings
Play Mode setting
Description
Single
The selected audio/MIDI file will be played once.
1-Repeat
The selected audio/MIDI file will be repeated.
All-Repeat
All audio/MIDI files in the current folder will be played repeatedly.
Random
All audio/MIDI files in the current folder will be played in random order.
„ Entering the USB Player menu
Recorder
While the USB Player screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the USB Player menu will be shown in the LCD display.
„ Adjusting the USB Player settings
After entering the USB Player menu:
Press the d or c buttons to move the selection cursor over the
desired setting.
ef buttons:
Adjust selected setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
button (RESET).
FUNCTION
dc buttons:
Move selection cursor.
56
5 Converting a MIDI song file to an MP3/WAV audio file
This function allows MIDI files or CS10 recorder songs stored on a USB memory device to be played back and saved
(converted) as an audio file (to the USB device) in either MP3 or WAV format.
1. Selecting the MIDI song to be converted
While the Song Browser Player screen is shown in the LCD display:
Press the d or c buttons to move the selection cursor over the
desired MIDI file, then press the REC button.
The LED indicator for the REC button will start to flash, and the
Convert MIDI to Audio screen will be shown in the LCD display.
2. Selecting the audio file format
With the Format setting selected, press the e or f buttons to
select the desired USB recorder audio file format (WAV or MP3).
ef buttons:
Select audio recorder format.
* It is also possible to record a new song directly to the USB device (i.e.
not convert the previously selected song to an audio file) by changing
the Mode setting to ‘New Song’.
Recorder
3. Starting the conversion
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will turn
on, the selected song will play, and the convert to audio process
will start.
* Notes played on the keyboard will also be recorded to the audio file.
When the end of the song is reached, the save confirmation
screen will be shown in the LCD display.
„ Naming and saving the converted audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 50 from step 3.
57
Audio Record/Playback (USB Memory)
6 Overdubbing a MP3/WAV audio file
This function allows the sound of the CS10 to be recorded (overdubbed) to an existing MP3 or WAV audio file. In
addition, the CS10 digital piano also supports mixing the LINE IN audio with the overdubbed MP3/WAV file.
* This function records/overdubs to a copy of the selected file - the original audio file will not be modified.
1. Selecting the audio file to be overdubbed
While the Song Browser Player screen is shown in the LCD display:
Press the d or c buttons to move the selection cursor over the
desired MP3/WAV file, then press the REC button.
The LED indicator for the REC button will start to flash, and the
Overdubbing screen will be shown in the LCD display.
2. Selecting the audio file format
With the Format setting selected, press the e or f buttons to
select the desired USB recorder audio file format (WAV or MP3).
ef buttons:
Select audio recorder format.
Recorder
* It is also possible to record a new audio file directly to the USB device
(i.e. not overdub the previously selected audio file) by changing the
Mode setting to ‘New Song’.
3. Starting the recording/overdubbing
Press the PLAY/STOP button, or a key on the keyboard.
The LED indicator for the PLAY/STOP and REC buttons will
turn on, the selected audio file will play, and the recording/
overdubbing process will start.
Notes played on the keyboard will be recorded to the audio file.
* The playback volume of the selected audio file will automatically be
set to 100, in order to prevent a distorted recording.
When the end of the MP3/WAV is reached, the save confirmation
screen will be shown in the LCD display.
„ Naming and saving the overdubbed audio file
Please follow the ‘Recording a MP3/WAV audio file’ instructions on page 50 from step 3.
58
Function menus
The Function menus contain a variety of options to adjust the CS10 digital piano’s operation and sound. Settings
are grouped by category, providing convenient access to relevant controls. Once adjusted, settings can be stored
to one of the instrument’s 16 registration memories, or selected as the default power-on settings with the User
Memory function (page 74).
„ Entering the Function menus
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the d or c buttons to cycle through the different menus.
Press the
FUNCTION button (ENTER) to enter the selected
Function menu.
dc buttons:
Move selection cursor.
FUNCTION button:
Select function.
„ Exiting the Function menus
Press the FUNCTION button (EXIT) to exit the Function menus
and return to normal operation.
1. Basic Settings
2. Virtual Technician Settings
Key Transpose, Song Transpose, Tone Control, Speaker Volume,
Touch Curve, Voicing, Damper Resonance, Damper Noise,
Phones Volume, Line In Level*, Line Out Volume, Wall EQ*, Tuning,
String Resonance, Key-off Effect, Fallback Noise, Hammer Delay,
Damper Hold, Four Hands, LCD Contrast, User Memory, Factory Reset
Lid Position, Decay Time, Minimum Touch, Stretch Tuning,
Settings
„ Overview of Function menus
Temperament, Key of Temperament, User Temperament,
3. MIDI Settings
User Key Volume, Half-Pedal Adjust, Soft Pedal Depth
MIDI Channel, Send Program Change No., Local Control,
Transmit Program Change No., Multi-timbral Mode, Channel Mute
4. USB Functions
Load Internal Song, Load Registration, Load User Memory,
5. Power Settings
Save Internal Song, Save SMF Song, Save Registration,
Auto Power Off
Save User Memory, Rename File, Delete File, Format USB
59
Basic Settings
The Basic Settings menu contains settings to adjust the pitch, tuning, and general sound of the instrument.
This menu also allows favourite panel settings to be stored, or reset back to the original factory configuration.
„ Basic Settings
No.
Setting
Description
Default setting
1
Key Transpose
Raise or lower the pitch of the keyboard in semi-tone steps.
0 (C)
2
Song Transpose
Raise or lower the pitch of the recorder/MIDI song in semi-tone steps.
0
3
Tone Control
Change the EQ settings of the instrument’s sound.
Off
4
Speaker Volume
Change the maximum volume level of the speaker output.
Normal
5
Phones Volume
Change the maximum volume level of the headphones output.
Normal
6
Line In Level
Adjust the input volume of the Line In connectors.
0 dB.
7
Line Out Volume
Adjust the output volume of the Line Out connectors.
10
8
Wall EQ
Optimise the instrument’s speaker system based on instrument placement.
Off
9
Tuning
Raise or lower the pitch of the instrument in 0.5 Hz steps.
440.0 Hz
10
Damper Hold
Change the effect of pressing the sustain pedal on organ, string, etc. sounds.
Off
11
Four Hands
Enable the ‘Four Hands Mode’ function.
Off
12
LCD Contrast
Adjust the contrast of the instrument’s LCD display.
5
13
User Memory
Store current panel settings as the default (power-on) configuration.
-
14
Factory Reset
Restore all panel settings to the original factory configuration.
-
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
„Entering the Basic Settings menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
Settings
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the FUNCTION button (ENTER) again to enter the Basic
Settings menu.
„Selecting and adjusting the desired setting
After entering the Basic Settings menu:
ef buttons:
Adjust selected setting.
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the
button (RESET).
60
FUNCTION
dc buttons:
Move selection cursor.
1 Key Transpose
The Key Transpose setting allows the pitch of the CS10 digital piano keyboard to be raised or lowered in semi-tone
steps. This is particularly useful when accompanying instruments tuned for different keys, or when a song learned
in one key must be played in another key. When transposed, the song can be played in the original key, yet heard
in a different key.
1. Selecting the Key Transpose setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Key Transpose setting.
2. Adjusting the Key Transpose value
Press the e or f buttons to increase or decrease the value of
the Key Transpose setting.
* The keyboard pitch can be raised or lowered by up to 12 semi-tones.
* To reset the Key Transpose setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Key Transpose setting will remain until the
power is turned off.
* Preferred Key Transpose settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
„Current Transpose state
If the Key Transpose setting is set to a value other than 0 (C),
the TRANSPOSE indicator shown in the normal playing mode
screen will be highlighted.
Transpose
enabled
Settings
3. Exiting the Key Transpose setting
Press the FUNCTION button (BACK) to exit the Key Transpose
setting and return to the Function Menus screen.
61
Basic Settings
2 Song Transpose
The Song Transpose setting allows the pitch of MIDI files or CS10 recorder songs stored on a USB memory device to
be raised or lowered in semi-tone steps when played back.
1. Selecting the Song Transpose setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Song Transpose setting.
2. Adjusting the Song Transpose value
Press the e or f buttons to increase or decrease the value of
the Song Transpose setting.
* The song pitch can be raised or lowered by up to 12 semi-tones.
* To reset the Song Transpose setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Song Transpose setting will remain until the
power is turned off.
* Preferred Song Transpose settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Song Transpose setting
Settings
Press the FUNCTION button (BACK) to exit the Song Transpose
setting and return to the Function Menus screen.
62
3 Tone Control
The Tone Control setting allows the overall sound character of the CS10 digital piano to be adjusted to provide
the best sound quality within the area that the instrument is located. There are five different preset EQ settings
available, with an additional ‘User’ setting allowing finer control over the different frequency bands.
„ Tone Control setting
Tone Control type
Description
Off (default)
Tone control adjustment is not applied.
Loudness
Emphasises frequencies to retain the instrument’s sound character when playing at low volume levels.
Bass Boost
Emphasises low-range frequencies, creating a deeper sound.
Treble Boost
Emphasises high-range frequencies, creating a brighter sound.
Mid Cut
Reduces mid-range frequencies, creating a clearer sound.
User
Allows the low, mid, and high-range frequency bands to be adjusted separately.
1. Selecting the Tone Control setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Tone Control setting.
2. Changing the Tone Control type
Press the e or f buttons to cycle through the different Tone
Control types.
* To reset the Tone Control setting to the default type, press the
FUNCTION button (RESET).
* Any changes made to the Tone Control setting will remain until the
power is turned off.
Settings
* Preferred Tone Control settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Tone Control setting
Press the FUNCTION button (BACK) to exit the Tone Control
setting and return to the Function Menus screen.
63
Basic Settings
User Tone Control
The User Tone Control option allows finer control over the instrument’s sound character, allowing the volume of
four frequency bands to be adjusted individually. It is also possible to adjust the frequency range of the mid-low
and mid-high frequency bands.
„ User Tone Control setting
No. User Tone Control
Description
1
Low
Adjusts the volume of the low range frequency band (20 - 100 Hz).
2
Mid-low dB
Adjusts the volume of the mid-low range frequency band.
Mid-low Frequency
Adjusts the frequency of the mid-low band (355 - 1000 Hz).
Mid-high db
Adjusts the volume of the mid-high range frequency band.
Mid-high Frequency
Adjusts the frequency of the mid-high band (1120 - 3150 Hz).
High
Adjusts the high range frequency band (5000 - 20000 Hz).
3
4
1. Selecting the User Tone Control setting
After selecting the Tone Control setting (page 63):
Press the e or f buttons to select the User Tone Control type,
then press the FUNCTION button (EDIT).
The User Tone Control screen will be shown in the LCD display.
2. Selecting and adjusting the User Tone Control settings
Press the d or c buttons to select the User Tone Control
setting.
Press the e or f buttons to increase or decrease the value of
the selected User Tone Control setting.
* Each User Tone Control band can be adjusted within the range of
–6 dB - +6 dB.
Settings
* To reset the User Tone Control setting to the default type, press the
FUNCTION button (RESET).
* Any changes made to the User Tone Control setting will remain until
the power is turned off.
* Preferred User Tone Control settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the User Tone Control setting
Press the
FUNCTION button (BACK) to exit the User Tone
Control setting and return to the Tone Control setting.
64
4 Speaker Volume
The Speaker Volume setting allows the maximum volume level of the CS10 digital piano’s speaker output to be
reduced, providing finer adjustment control over the master volume. This setting can also function as a volume
limiter, preventing the instrument from being played too loudly in the home or classroom etc.
* This setting does not affect the headphones or Line Out volume.
„ Speaker Volume setting
Speaker Volume
Description
Normal (default)
The instrument’s speakers will output sound at the normal volume level.
Low
The instrument’s speakers will output sound at a reduced volume level.
1. Selecting the Speaker Volume setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Speaker Volume setting.
2. Changing the Speaker Volume type
Press the e or f buttons to alternate between ‘Normal’ and
‘Low’ Speaker Volume settings.
* To reset the Speaker Volume setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Speaker Volume setting will remain until the
power is turned off.
* Preferred Speaker Volume settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
Settings
3. Exiting the Speaker Volume setting
Press the FUNCTION button (BACK) to exit the Speaker Volume
setting and return to the Function Menus screen.
65
Basic Settings
5 Phones Volume
The Phones Volume setting allows the maximum volume level of the headphones output to be increased.
The default setting for Phones Volume is ‘Normal’ in order to protect an individual’s ears from excessive volume
levels. The ‘High’ setting may be selected when using headphones with a high impedance, or in situations where it
is desirable to increase the maximum volume level of the headphones output.
* This setting does not affect the speaker or Line Out volume.
„ Phones Volume setting
Phones Volume
Description
Normal (default)
The instrument’s headphone connectors will output sound at the normal volume level.
High
The instrument’s headphone connectors will output sound at an increased volume level.
1. Selecting the Phones Volume setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Phones Volume setting.
2. Changing the Phones Volume type
Press the e or f buttons to alternate between ‘Normal’ and
‘High’ Phones Volume settings.
* To reset the Phones Volume setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Phones Volume setting will remain until the
power is turned off.
Settings
* Preferred Phones Volume settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Phones Volume setting
Press the FUNCTION button (BACK) to exit the Phones Volume
setting and return to the Function Menus screen.
66
6 Line In Level
The Line In Level setting allows the volume level of the CS10 digital piano’s Line In input jacks to be adjusted. This
setting may be useful when using the USB Recorder function and attempting to balance an external audio source
with the instrument’s sound.
* The Line In Level can also be adjusted by using the LEVEL knob, located on the jack panel. Please refer to page 119 for more information.
1. Selecting the Line In Level setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Line In Level setting.
2. Adjusting the Line In Level value
Press the e or f buttons to increase or decrease the value of
the Line In Level setting.
* The Line In Level can be adjusted within the range of –10 dB - +10 dB.
* To reset the Line In Level setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Line In Level setting will remain until the
power is turned off.
* Preferred Line In Level settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
3. Exiting the Line In Level setting
Settings
Press the FUNCTION button (BACK) to exit the Line In Level
setting and return to the Function Menus screen.
67
Basic Settings
7 Line Out Volume
The Line Out Volume setting allows the level of the instrument’s Line Out output to be adjusted. This setting may
be useful when connecting the CS10 digital piano to mixers and other audio equipment.
* This setting does not affect the speaker or headphone volume.
1. Selecting the Line Out Volume setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Line Out Volume setting.
2. Adjusting the Line Out Volume value
Press the e or f buttons to increase or decrease the value of
the Line Out Volume setting.
* The Line Out Volume can be adjusted within the range of –10 - +10.
* To reset the Line Out Volume setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Line Out Volume setting will remain until
the power is turned off.
* Preferred Line Out Volume settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Line Out Volume setting
Settings
Press the
FUNCTION button (BACK) to exit the Line Out
Volume setting and return to the Function Menus screen.
68
8 Wall EQ
The Wall EQ setting optimises the sound character of the soundboard speaker depending on whether the CS10
digital piano (back) is placed beside a wall, or in an area away from a wall.
* This setting does not affect the headphones or Line Out output.
„ Wall EQ setting
Wall EQ
Description
Off (default)
Optimise the speaker system for placing the CS10 digital piano in an area away from a wall.
On
Optimise the speaker for placing the CS10 digital piano beside a wall.
1. Selecting the Wall EQ setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Wall EQ setting.
2. Changing the Wall EQ setting
Press the e or f buttons to turn the Wall EQ setting on or off.
* To reset the Wall EQ setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Wall EQ setting will remain until the power
is turned off.
* Preferred Wall EQ settings can be stored to a Registration memory for
convenient recall. Please refer to page 30 for more information.
Settings
3. Exiting the Wall EQ setting
Press the FUNCTION button (BACK) to exit the Wall EQ setting
and return to the Function Menus screen.
69
Basic Settings
9 Tuning
The Tuning setting allows the overall pitch of the CS10 digital piano to be raised and lowered in 0.5 Hz steps, and
may therefore prove useful when playing with other instruments.
1. Selecting the Tuning setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Tuning setting.
2. Adjusting the Tuning value
Press the e or f buttons to increase or decrease the value of
the Tuning setting.
* The Tuning value can be adjusted within the range of 427.0 - 453.0 Hz.
* To reset the Tuning setting to the default value, press the
button (RESET).
FUNCTION
* Any changes made to the Tuning setting will remain until the power
is turned off.
* Preferred Tuning settings can be stored to a Registration memory for
convenient recall. Please refer to page 30 for more information.
3. Exiting the Tuning setting
Settings
Press the FUNCTION button (BACK) to exit the Tuning setting
and return to the Function Menus screen.
70
10 Damper Hold
The Damper Hold setting is used to determine whether sounds such as organ or strings should be sustained
continuously when the sustain (damper) pedal is pressed, or whether these sounds should decay, naturally.
„ Damper Hold setting
Damper Hold
Description
Off (default)
Organ, strings, etc. sounds will gradually decay, even while the sustain pedal is pressed.
On
Organ, strings, etc. sounds will be sustained continuously while the sustain pedal is pressed.
1. Selecting the Damper Hold setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Damper Hold setting.
2. Changing the Damper Hold setting
Press the e or f buttons to turn the Damper Hold setting on
or off.
* To reset the Damper Hold setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Damper Hold setting will remain until the
power is turned off.
* Preferred Damper Hold settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Damper Hold setting
Settings
Press the FUNCTION button (BACK) to exit the Damper Hold
setting and return to the Function Menus screen.
71
Basic Settings
11 Four Hands
The Four Hands setting provides an alternative method to enabling the Four Hands Mode function, and may prove
useful in teaching environments or situations where the function should be enabled automatically every time the
CS10 digital piano is turned on.
When enabled, all Four Hands Mode control operations are identical to those explained on page 22.
„ Four Hands setting
Four Hands
Description
Off (default)
Four Hands Mode will be turned off by default.
On
Four Hands Mode will be turned on by default.
1. Selecting the Four Hands setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Four Hands setting.
2. Changing the Four Hands setting
Press the e or f buttons to turn the Four Hands setting on or
off.
* To reset the Four Hands setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Four Hands setting will remain until the
power is turned off.
* Preferred Four Hands settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
Settings
3. Exiting the Four Hands setting
Press the FUNCTION button (BACK) to exit the Four Hands
setting and return to the Function Menus screen.
72
12 LCD Contrast
The LCD Contrast setting is used to adjust the contrast of the LCD display. The contrast of the display becomes
sharper as the value increases.
1. Selecting the LCD Contrast setting
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the LCD Contrast setting.
2. Adjusting the LCD Contrast value
Press the e or f buttons to increase or decrease the value of
the LCD Contrast setting.
* The LCD Contrast value can be adjusted within the range of 0 - 10.
* To reset the LCD Contrast setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the LCD Contrast setting will remain until the
power is turned off.
* Preferred LCD Contrast settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the LCD Contrast setting
Settings
Press the FUNCTION button (BACK) to exit the LCD Contrast
setting and return to the Function Menus screen.
73
Basic Settings
13 User Memory
The User Memory function allows preferred panel functions/settings to be stored in the instrument’s memory, and
automatically recalled as the default settings every time the CS10 digital piano is turned on.
* User Memory settings can also be saved to and loaded from USB memory devices. Please refer to pages 109/113 for more information.
„ Functions/Settings stored in User Memory
Functions
Settings
Selected sound (including primary sound for each category)
Basic Settings
Dual Mode / Split Mode / Four Hands Mode (including settings)
Virtual Technician Settings
Reverb, Effects (Type, Settings)
MIDI Settings
Transpose (Key Transpose, Song Transpose)
Metronome (Beat, Tempo, Volume)
1. Selecting the User Memory function
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the User Memory setting.
2. Storing current settings to User Memory
Press the REC button.
A confirmation message will be shown in the LCD display, and
the current panel settings will be stored to User Memory.
* The Factory Reset function can be used to restore all settings to their
default values. Please refer to page 75 for more information.
3. Exiting the User Memory function
Settings
Press the FUNCTION button (BACK) to exit the User Memory
setting and return to the Function Menus screen.
74
* Changes made to the Auto Power Off setting will be stored to User
Memory automatically.
14 Factory Reset
The Factory Reset function clears any settings stored using the User Memory function, restoring the CS10 digital
piano to its factory default settings.
* This function will not clear registration memories or recorder songs stored in internal memory.
1. Selecting the Factory Reset function
After entering the Basic Settings menu (page 60):
Press the d or c buttons to select the Factory Reset setting.
2. Restoring factory settings
Press the REC button.
A confirmation message will be shown in the LCD display, and
the all settings will be restored to their default values.
3. Exiting the Factory Reset function
Settings
Press the FUNCTION button (BACK) to exit the Factory Reset
setting and return to the Function Menus screen.
75
Virtual Technician Settings
An experienced piano technician is essential to fully realise the potential of a fine acoustic piano. In addition to
meticulously tuning each note, the technician also performs numerous regulation and voicing adjustments that
allow the instrument to truly sing.
The Virtual Technician settings of the CS10 digital piano simulate these refinements digitally, allowing performers
to shape various aspects of the instrument’s character to suit their personal preferences.
* The table below indicates which Virtual Technician settings affect to all sounds, or acoustic piano and electric piano sounds only.
„ Virtual Technician Settings
No.
Setting
Description
All AP
1
Touch Curve
Adjust the touch sensitivity of the keyboard.
z
2
Voicing
Adjust the tonal character of the instrument.
z
3
Damper Resonance
4
EP Default
Normal
Normal
Adjust the resonance that is heard when pressing the damper pedal.
z
5
Damper Noise
Adjust the sound that is heard when pressing the damper pedal.
z
5
5
String Resonance
Adjust the resonance that is heard when notes are held.
z
6
Key-off Effect
Adjust the sound that is heard when keys are released.
z
7
Fall-back Noise
Adjust the sound that is heard when the key action falls back.
z
5
8
Hammer Delay
Adjust the delay of the hammer striking strings when playing pianissimo.
z
Off
9
Topboard
Adjust the position of the grand piano topboard.
z
Open 3
10
Decay Time
Adjust the decay time of the piano sound while the keys are pressed.
11
Minimum Touch
Adjust the minimum key velocity required to produce a sound.
12
Stretch Tuning
13
5
z
5
5
z
z
z
1
Adjust the level of stretch tuning for equal temperaments.
z
Normal
User Tuning
Adjust the individual tuning of each of the 88 keys.
z
–
Temperament
Adjust the tuning system to suit Renaissance and Baroque periods etc.
z
Equal Temp.
–
User Temperament
Create a custom, user-defined tuning system.
z
14
Temperament Key
Adjust the key of the selected tuning system.
z
C
15
User Key Volume
Adjust the individual volume of each of the 88 keys.
z
Off
16
Half-Pedal Adjust
Adjust the point at which the damper pedal begins to sustain the sounds.
z
5
17
Soft Pedal Depth
Adjust the depth/effectiveness of the soft pedal.
z
5
Settings
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
„Entering the Virtual Technician menu
„Selecting and adjusting the desired setting
While the normal playing mode screen is shown in the LCD display:
After entering the Virtual Technician menu:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the e or f buttons to adjust the selected setting.
Press the d or c buttons to select the Virtual Technician menu.
* To reset the current setting to the default value, press the
button (RESET).
Press the FUNCTION button (ENTER) again to enter the Virtual
Technician menu.
76
Press the d or c buttons to move the selection cursor over the
desired setting.
FUNCTION
1 Touch Curve
As with an acoustic piano, the CS10 digital piano produces a louder sound when the keys are struck with force, and
a softer sound when the keys are played gently. The volume and tonal character change in relation to the strength
and speed of playing – on a digital piano this system is referred to as ‘touch sensitivity’.
The Touch Curve setting allows the touch sensitivity of the keyboard to be conveniently adjusted. There are six
different preset touch curve settings available, with two additional ‘User’ settings allowing performers to customise
the instrument’s responsiveness to suit their individual playing style.
* This Virtual Technician setting will affect all sounds.
„ Touch Curve types
Touch Curve
Description
Light +
Requires less striking force to achieve a forte note. For players with a very delicate touch.
A louder volume is produced even when playing with a soft touch. For those still developing finger strength.
Light
* This touch curve is recommended for children and organ players.
Normal (default)
Reproduces the standard touch sensitivity of an acoustic piano.
Heavy
Requires a heavier touch to produce a loud volume. Ideally suited to those with stronger fingers.
Heavy +
Requires considerably more striking force to achieve a loud volume.
A constant volume is produced regardless of how hard the keys are struck.
Off (constant)
* This touch curve intended for playing sounds of instruments that have a fixed dynamic range (e.g. organ and harpsichord).
User 1 / User 2
A custom touch curve, created to suit an individual’s personal playing style.
„Touch Curve graph
a
b
c
d
e
Light +
b
Light
c
Normal (default)
d
Heavy
e
Heavy +
f
Off (constant)
Settings
f
a
Soft
Sound Volume
Loud
The illustration below provides a visual representation of the different Touch Curve settings.
Gentle
Keyboard Pressure
Strong
77
Virtual Technician Settings
1 Touch Curve (cont.)
1. Selecting the Touch Curve setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Touch Curve setting.
2. Changing the Touch Curve type
Press the e or f buttons to cycle through the different Touch
Curve types.
* To reset the Touch Curve setting to the default type, press the
FUNCTION button (RESET).
* Any changes made to the Touch Curve type or User Touch setting will
remain until the power is turned off.
* Preferred Touch Curve settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
3. Exiting the Touch Curve setting
Press the FUNCTION button (BACK) to exit the Touch Curve
setting and return to the Function Menus screen.
User Touch Curve
„Creating a User Touch Curve
After selecting the Touch Curve setting:
Settings
Press the e or f buttons to select the User 1 or User 2 touch
curve, then press the REC button.
A message will be shown, prompting for the keyboard to be
played.
Play the piano dynamically from very soft to very loud, allowing
the instrument to examine the personal playing technique.
* More than one attempt may be required in order to create an accurate
User Touch Curve.
* Reducing the master volume fader to the lowest position before
creating the User Touch Curve may help to reduce user distractions,
thus improving accuracy.
Press the PLAY/STOP button.
The new User Touch Curve will be stored to the ‘User1’ or ‘User2’
touch types, and selected automatically.
78
2 Voicing
The Voicing setting allows the tonal character of the CS10 digital piano to be set to one of six different types.
* This Virtual Technician setting will affect all sounds.
„ Voicing types
Voicing type
Description
Normal (default)
The normal tonal character of an acoustic piano throughout the entire dynamic range.
Mellow 1
A softer, more mellow tonal character throughout the entire dynamic range.
Mellow 2
An even soften tonal character than Mellow 1.
Dynamic
A tonal character that changes dramatically from mellow to bright, depending on the strength of key strike.
Bright 1
A bright tonal character throughout the entire dynamic range.
Bright 2
An even brighter tonal character than Bright 1.
1. Selecting the Voicing setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Voicing setting.
2. Changing the Voicing type
Press the e or f buttons to cycle through the different Voicing
types.
* To reset the Voicing setting to the default type, press the
button (RESET).
FUNCTION
* Any changes made to the Voicing setting will remain until the power
is turned off.
Settings
* Preferred Voicing settings can be stored to a Registration memory for
convenient recall. Please refer to page 30 for more information.
3. Exiting the Voicing setting
Press the FUNCTION button (BACK) to exit the Voicing setting
and return to the Function Menus screen.
79
Virtual Technician Settings
3 Damper Resonance
Pressing the damper pedal of an acoustic piano raises all dampers, allowing the strings to vibrate freely. When a
note or chord is played on the piano with the sustain pedal pressed, not only will the strings of the notes played
vibrate, but also the strings of other notes, vibrating in sympathetic resonance.
The CS10 digital piano recreates this phenomenon, with the Damper Resonance setting allowing the volume of this
resonance sound to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Damper Resonance setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Damper Resonance
setting.
2. Adjusting the Damper Resonance volume
Press the e or f buttons to increase or decrease the volume of
the Damper Resonance setting.
* The Damper Resonance volume be adjusted within the range of
Off, 1 - 10, with higher values resulting in a louder effect.
* To reset the Damper Resonance setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Damper Resonance setting will remain until
the power is turned off.
* Preferred Damper Resonance settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Damper Resonance setting
Settings
Press the
FUNCTION button (BACK) to exit the Damper
Resonance setting and return to the Function Menus screen.
80
4 Damper Noise
When the damper pedal of an acoustic piano is pressed and released, it is often possible to hear the sound of the
damper head touching and releasing the strings.
The CS10 digital piano reproduces this sound, with the Damper Noise setting allowing the volume of this sound to
be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Damper Noise setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Damper Noise setting.
2. Adjusting the Damper Noise volume
Press the e or f buttons to increase or decrease the volume of
the Damper Noise setting.
* The Damper Noise volume be adjusted within the range of
Off, 1 - 10, with higher values resulting in a louder effect.
* To reset the Damper Noise setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Damper Noise setting will remain until the
power is turned off.
* Preferred Damper Noise settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Damper Noise setting
Settings
Press the FUNCTION button (BACK) to exit the Damper Noise
setting and return to the Function Menus screen.
81
Virtual Technician Settings
5 String Resonance
String Resonance refers to a phenomenon that exists in acoustic pianos whereby the strings of held notes resonate
‘sympathetically’ with other notes of the same harmonic series.
The CS10 digital piano recreates this phenomenon, with the String Resonance setting allowing the volume of this
resonance to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
„ Demonstrating String Resonance
To experience the string resonance phenomenon, gently hold down the ‘C’ key as shown in the illustration below, then press any of
the keys marked with a z symbol. In addition to the sound of each note played, it should also be possible to hear the strings of the
first ‘C’ key resonating ‘sympathetically’, thus demonstrating String Resonance.
DA
F G
B
F G
C
ho
ld
C
BA
1. Selecting the String Resonance setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the String Resonance
setting.
2. Adjusting the String Resonance volume
Press the e or f buttons to increase or decrease the volume of
the String Resonance setting.
Settings
* The String Resonance volume be adjusted within the range of
Off, 1 - 10, with higher values resulting in a louder effect.
* To reset the String Resonance setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the String Resonance setting will remain until
the power is turned off.
* Preferred String Resonance settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the String Resonance setting
Press the
FUNCTION button (BACK) to exit the String
Resonance setting and return to the Function Menus screen.
82
G
C
E
G
BA
C D E
G
C
6 Key-off Effect
When playing an acoustic piano – particularly in the bass region of the keyboard – if a key is played with force and
released quickly, it is often possible to hear the faint sound of the damper touching the strings immediately before
the vibrations are stopped.
In addition, the speed at which keys are lifted will also affect the character of the sound. For example, when lifting
the keys quickly (e.g. staccato playing) the ‘release’ portion of the sound will be noticeably shorter than when
lifting the keys slowly (e.g. legato playing).
The CS10 digital piano reproduces both characteristics, with the Key-off Effect setting allowing the volume of the
key-off sound to be adjusted, and the key-off release speed detection to be turned on or off.
* This Virtual Technician setting will affect acoustic piano and electric piano sounds.
1. Selecting the Key-off Effect setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Key-off Effect setting.
2. Adjusting the Key-off Effect volume
Press the e or f buttons to increase or decrease the volume of
the Key-off Effect setting.
* The Key-off Effect volume be adjusted within the range of
Off, 1 - 10, with higher values resulting in a louder effect.
* When the Key-Off Effect setting is set to Off, the key-off release speed
detection will also be disabled, and the speed at which keys are lifted
will not affect the character of the sound.
* To reset the Key-off Effect setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Key-off Effect setting will remain until the
power is turned off.
Settings
* Preferred Key-off Effect settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Key-off Effect setting
Press the FUNCTION button (BACK) to exit the Key-off Effect
setting and return to the Function Menus screen.
83
Virtual Technician Settings
7 Fall-back Noise
When playing an acoustic piano, it is often possible to hear the faint sound of the keyboard action returning (i.e.
‘falling back’) to the neutral position after a key is released.
The CS10 digital piano reproduces this sound, with the Fall-back Noise setting allowing the volume of this sound
to be adjusted.
* This Virtual Technician setting will affect acoustic piano and harpsichord sounds.
1. Selecting the Fall-back Noise setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Fall-back Noise setting.
2. Adjusting the Fall-back Noise volume
Press the e or f buttons to increase or decrease the volume of
the Fall-back Noise setting.
* The Fall-back Noise volume be adjusted within the range of
Off, 1 - 10, with higher values resulting in a louder effect.
* To reset the Fall-back Noise setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Fall-back Noise setting will remain until the
power is turned off.
* Preferred Fall-back Noise settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Fall-back Noise setting
Settings
Press the FUNCTION button (BACK) to exit the Fall-back Noise
setting and return to the Function Menus screen.
84
8 Hammer Delay
When playing pianissimo passages using an acoustic piano, there may be a perceived delay between a key being
pressed and the hammer striking the strings.
If desired, the CS10 digital piano can recreate this delay, with the Hammer Delay setting allowing the delay length
to be adjusted.
* This Virtual Technician setting will affect acoustic piano sounds only.
1. Selecting the Hammer Delay setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Hammer Delay setting.
2. Adjusting the Hammer Delay value
Press the e or f buttons to increase or decrease the value of
the Hammer Delay setting.
* The Hammer Delay value can be adjusted within the range of
Off, 1 - 10, with higher values resulting in an increased delay.
* To reset the Hammer Delay setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Hammer Delay setting will remain until the
power is turned off.
* Preferred Hammer Delay settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Hammer Delay setting
Settings
Press the FUNCTION button (BACK) to exit the Hammer Delay
setting and return to the Function Menus screen.
85
Virtual Technician Settings
9 Topboard
When playing an acoustic grand piano, the position of the instrument’s topboard (lid) affects both the volume and
‘openness’ of the tone produced. A fully open topboard allows sound waves to reflect off the polished lid surface
and project into the room, while a closed lid has the opposite effect, resulting in a darker, more opaque tone.
The CS10 digital piano attempts to simulate these characteristics, with four different topboard positions.
* This Virtual Technician setting will affect acoustic piano sounds only.
„ Topboard positions
Topboard position
Description
Open 3 (default)
Simulates the character of a fully open topboard.
Open 2
Simulates the character of a half open topboard.
Open 1
Simulates the character of a partially open topboard.
Closed
Simulates the character of a closed topboard.
1. Selecting the Topboard setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Topboard setting.
2. Changing the Topboard position
Press the e or f buttons to cycle through the different
Topboard types.
* To reset the Topboard setting to the default position, press the
FUNCTION button (RESET).
* Any changes made to the Topboard setting will remain until the
power is turned off.
Settings
* Preferred Topboard settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
3. Exiting the Topboard setting
Press the
FUNCTION button (BACK) to exit the Topboard
setting and return to the Function Menus screen.
86
10 Decay Time
When playing an acoustic grand piano, the length of the instrument influences the speed at which held notes decay,
with longer grand pianos (i.e. longer strings) characterised by longer decay times.
The CS10 digital piano attempts to simulate this characteristic, with the Decay Time setting allowing the length of
decay while keys are pressed to be adjusted.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Decay Time setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Decay Time setting.
2. Adjusting the Decay Time volume
Press the e or f buttons to increase or decrease the value of
the Decay Time setting.
* The Decay Time value can be adjusted within the range of
1 - 10, with larger values resulting in increased decay times.
* To reset the Decay Time setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Decay Time setting will remain until the
power is turned off.
* Preferred Decay Time settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
3. Exiting the Decay Time setting
Settings
Press the FUNCTION button (BACK) to exit the Decay Time
setting and return to the Function Menus screen.
87
Virtual Technician Settings
11 Minimum Touch
The Minimum Touch setting allows the minimum key velocity required to produce a sound to be adjusted. By
default, this setting attempts to recreate the extremely fine touch sensitivity of a concert grand piano, allowing
a very soft sound to be produced with the slightest of key touches. However, it may be desirable to reduce this
sensitivity, when wishing to recreate the sensitivity of a small grand piano or an upright piano.
* This Virtual Technician setting will affect acoustic piano and electric piano sounds.
1. Selecting the Minimum Touch setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Minimum Touch setting.
2. Adjusting the Minimum Touch value
Press the e or f buttons to increase or decrease the value of
the Minimum Touch setting.
* The Minimum Touch value can be adjusted within the range of
1 - 20, with larger values resulting in a less sensitive key touch.
* To reset the Minimum Touch setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Minimum Touch setting will remain until
the power is turned off.
* Preferred Minimum Touch settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Minimum Touch setting
Settings
Press the
FUNCTION button (BACK) to exit the Minimum
Touch setting and return to the Function Menus screen.
88
12 Stretch Tuning
Stretch tuning is a piano-specific tuning method in which the tuning for the lower notes is slightly lower and the
tuning for the higher notes is slightly higher than the settings made in the Equal temperament.
The Stretch Tuning setting allows the degree of stretch tuning to be adjusted when Equal (piano) or Equal
temperament are selected. It is also possible to create custom tuning methods using one of the four User types.
* This Virtual Technician setting will affect all sounds.
„ Stretch Tuning setting
Stretch Tuning
Description
Normal (default)
Normal stretch tuning.
Wide
Wide stretch tuning.
User 1-4
User defined tuning methods.
1. Selecting the Stretch Tuning setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Stretch Tuning setting.
2. Changing the Stretch Tuning type
Press the e or f buttons to alternate between ‘Normal’ and
‘Wide’ Stretch Tuning settings.
* To reset the Stretch Tuning setting to the default type, press the
FUNCTION button (RESET).
* Any changes made to the Stretch Tuning setting will remain until the
power is turned off.
Settings
* Preferred Stretch Tuning settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Stretch Tuning setting
Press the FUNCTION button (BACK) to exit the Stretch Tuning
setting and return to the Function Menus screen.
89
Virtual Technician Settings
User Tuning
The User Tuning function allows each of the 88-keys to be tuned individually.
1. Selecting the User Tuning memory
After selecting the Stretch Tuning setting (page 89):
Press the e or f buttons to select one of the User Tuning
memories.
* Up to four different User Tuning memories can be created and stored.
Press the
FUNCTION button (EDIT).
The User Tuning screen will be shown in the LCD display.
2. Selecting the note, adjusting the user tuning value
Press the d or c buttons to select the desired note to be
adjusted.
* To select a note directly, press and hold the
(+ KEY) then press the desired key.
FUNCTION button
Press the e or f buttons to adjust the user tuning value for the
selected note.
* The User Tuning value can be adjusted within the range of –50 - +50.
* To reset the User Tuning setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the User Tuning setting will remain until the
power is turned off.
* Preferred User Tuning settings can be stored to a Registration memory
for convenient recall. Please refer to page 30 for more information.
3. Exiting the User Tuning function
Settings
Press the FUNCTION button (BACK) to exit the User Tuning
tuning screen and return to the Stretch Tuning setting.
90
13 Temperament
The Temperament setting allows the tuning system used by the CS10 digital piano to be changed from the modern
‘Equal Temperament’ standard to one of the various temperaments popularised during the Renaissance and
Baroque periods. It is also possible to create customised temperaments using the User Temperaments function.
* This Virtual Technician setting will affect all sounds.
„ Temperament types
Temperament type
Description
Equal Temperament (piano)
This is the default temperament. When a piano sound is selected, the tuning will be stretched like an
acoustic piano (equal temperament).
(Equal P.only)
Pure Temperament
(Pure Major/Pure Minor)
Pythagorean Temperament
(Pythagorean)
Meantone Temperament
(Meantone)
Werckmeister III Temperament
(Werkmeister)
Kirnberger III Temperament
(Kirnberger)
Equal Temperament (flat)
(Equal Flat)
Equal Temperament
(Equal Stretch)
User Temperament
(User)
* If any other type of sound is selected, the tuning will be set to equal temperament (flat).
This temperament, which eliminates dissonances for thirds and fifths, is still popular in choral music
because of its perfect harmony. Any key modulation will result in dissonances.
* The key of the temperament, and major/minor setting must be correctly matched.
This temperament, which uses mathematical ratios to eliminate dissonance for fifths, is very limited for
use with chords, but produces very characteristic melodic lines.
This temperament, which uses a mean between a major and minor whole tone to eliminate dissonance
for thirds, was devised to eliminate the lack of consonances experienced with certain fifths for the
Mersenne pure temperament.
It produces chords that are more beautiful than those played with equal temperament.
These two temperaments are placed in between Meantone and Pythagorean. For music with few
accidentals, this temperament produces the beautiful chords of the mean tone, but as accidentals
increase, the temperament produces the characteristic melodies of the Pythagorean temperament.
It is used primarily for classical music written in the Baroque era to revive the original characteristics.
This is an ‘unstretched’ equal temperament that divides the scale into twelve equal semi-tones. It produces
the same chordal intervals in all twelve keys, and has the advantage of limitless modulation of the key.
However the tonality of each key becomes less characteristic and no chord is in pure consonance.
This is the most popular piano temperament. The hearing ability of a human is uneven and is not as
accurate with high frequency and low frequency as it is with the middle range. This temperament’s
tuning is stretched to compensate for this so the sound will be heard naturally to the ears. This
‘stretched’ equal temperament is a practical variation of the ‘unstretched’ equal temperament which
was invented on a mathematical basis.
A custom, user temperament, created by raising or lowering the pitch for each semi-tone.
Settings
1. Selecting the Temperament setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Temperament setting.
2. Changing the Temperament type
Press the e or f buttons to cycle through the different
Temperament types.
* To reset the Temperament setting to the default type, press the
FUNCTION button (RESET).
* Any changes made to the Temperament setting will remain until the
power is turned off.
* Preferred Temperament settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
91
Virtual Technician Settings
User Temperament
The User Temperament setting allows custom temperaments to be created.
1. Selecting the User Temperament
After selecting the Temperament setting (page 91):
Press the e or f buttons to select the User temperament, then
press the FUNCTION button (EDIT).
The User Temperament screen will be shown in the LCD display.
2. Selecting the note, adjusting the user temperament value
Press the d or c buttons to select the desired note to be
adjusted.
Press the e or f buttons to adjust the cent value for the selected
note.
* The User Temperament value can be adjusted within the range of
–50 - +100.
* To reset the User Temperament setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the User Temperament setting will remain until
the power is turned off.
* Preferred User Temperament settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the User Temperament function
Settings
Press the
FUNCTION button (BACK) to exit the User
Temperament screen and return to the Temperament setting.
92
14 Temperament Key
The Temperament Key setting allows the key of the selected temperament to be specified. When using a
temperament other than Equal temperament, use this setting to specify the key signature of the piece.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Temperament Key setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Temperament Key setting.
2. Adjusting the Temperament Key
After selecting a temperament other than Equal (piano) or Equal
temperament types (page 91):
Press the e or f buttons to change the Temperament Key.
* The Temperament Key can be set within the range of C to B.
* To reset the Temperament Key setting to the default key, press the
FUNCTION button (RESET).
* Any changes made to the Temperament Key setting will remain until
the power is turned off.
* Preferred Temperament Key settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Temperament Key setting
Settings
Press the FUNCTION button (BACK) to exit the Temperament
Key setting and return to the Function Menus screen.
93
Virtual Technician Settings
15 User Key Volume
The User Key Volume settings allows the volume of each of the 88-keys to be adjusted individually.
* This Virtual Technician setting will affect all sounds.
1. Selecting the User Key Volume setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the User Key Volume setting.
2. Selecting the User Key Volume memory
Press the e or f buttons to select one of the User Key Volume
memories.
* Up to four different User Key Volume memories can be created and
stored.
Press the
FUNCTION button (EDIT).
The User Key Volume adjustment screen will be shown in the
LCD display.
2. Selecting the note, adjusting the User Key Volume
Press the d or c buttons to select the desired note to be
adjusted.
* To select a note directly, press and hold the
(+ KEY) then press the desired key.
FUNCTION button
Press the e or f buttons to adjust the User Key Volume for the
selected note.
* The User Key Volume value can be adjusted within the range of
–50 - +50.
Settings
* To reset the User Key Volume setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the User Key Volume setting will remain until
the power is turned off.
* Preferred User Key Volume settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the User Key Volume function
Press the FUNCTION button (BACK) to exit the User Key Volume
adjustment screen and return to the User Key Volume setting.
94
16 Half-Pedal Adjust
The Half-Pedal Adjust setting allows the point at which the damper/sustain pedal becomes effective (i.e. when
the dampers of the piano begin to lift from the strings) to be adjusted. This setting may be useful for pianists that
habitually rest their right foot on the damper/sustain pedal, but do not necessarily wish to sustain the sound.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Half-Pedal Adjust setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Half-Pedal Adjust
setting.
2. Adjusting the Half-Pedal Adjust value
Press the e or f buttons to increase or decrease the value of
the Half-Pedal Adjust setting.
* The Half-Pedal Adjust value can be adjusted within the range of
1 - 10, with higher values resulting in a later damper pedal point.
* To reset the Half-Pedal Adjust setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Half-Pedal Adjust setting will remain until
the power is turned off.
* Preferred Half-Pedal Adjust settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Half-Pedal Adjust setting
Settings
Press the
FUNCTION button (BACK) to exit the Half-pedal
Point setting and return to the Function Menus screen.
95
Virtual Technician Settings
17 Soft Pedal Depth
The Soft Pedal Depth setting adjusts the effectiveness (i.e. depth/strength) of the soft pedal.
* This Virtual Technician setting will affect all sounds.
1. Selecting the Soft Pedal Depth setting
After entering the Virtual Technician menu (page 76):
Press the d or c buttons to select the Soft Pedal Depth setting.
2. Adjusting the Soft Pedal Depth value
Press the e or f buttons to increase or decrease the value of
the Soft Pedal Depth setting.
* The Soft Pedal Depth value can be adjusted within the range of
1 - 10, with higher values resulting in a softer sound.
* To reset the Soft Pedal Depth setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Soft Pedal Depth setting will remain until
the power is turned off.
* Preferred Soft Pedal Depth settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Soft Pedal Depth setting
Settings
Press the
FUNCTION button (BACK) to exit the Soft Pedal
Depth setting and return to the Function Menus screen.
96
MIDI Settings
MIDI Overview
The term MIDI is an acronym for Musical Instrument Digital Interface, an international standard for connecting
musical instruments, computers, and other devices to allow the exchange of performance data.
„ MIDI Terminals
MIDI terminal
Function
MIDI IN
Receiving note, program change, and other data.
MIDI OUT
Sending note, program change, and other data.
„MIDI channels
MIDI uses channels to exchange data back and forth between MIDI devices. There are receive (MIDI IN) and transmit (MIDI OUT)
channels. Most musical instruments or devices with MIDI functions are equipped with both MIDI IN and OUT jacks and are capable of
transmitting and receiving data via MIDI. The receive channels are used to receive data from another MIDI device, and the transmit
channels are used to transmit data to another MIDI device.
The illustration below shows three musical instruments, connected together using MIDI.
Transmitting instrument a
Receiving instrument b
Receiving instrument c
Transmitting instrument a sends transmit channel and keyboard information to receiving instruments b/c.
The information arrives at the receiving instruments b/c.
Receiving instruments b/c will respond to MIDI data that is sent if their receive channel is the same as the transmit channel of the
transmitting instrument a. If the channels do not match, the receiving instruments b/c will not respond to any data that is sent.
For both receiving and transmitting, channels 1-16 can be used.
Settings
„Recording/playing with a sequencer
When connected to a sequencer (or a computer running MIDI
sequencing software), the CS10 digital piano can be used to
record and playback multi-track songs, with separate sounds
playing simultaneously on each channel.
Sequencer
97
MIDI Settings
„MIDI Functions
The CS10 digital piano supports the following MIDI functions:
Transmit/receive note information
Transmit/receive program change information
Transmit/receive note information to/from a MIDI-connected
musical instrument or device.
Transmit/receive program change data to/from a MIDIconnected musical instrument or device.
Transmit/receive channel settings
Transmit/receive pedal data
Specify transmit/receive channels within the range of 1 to 16.
Transmit/receive sustain, sostenuto, and soft pedal data to/
from a MIDI-connected musical instrument or device.
Transmit/receive exclusive data
Receive volume data
Transmit/receive front panel or menu function settings as
exclusive data.
Receive MIDI volume data sent from a MIDI-connected
musical instrument or device.
* Please refer to the ‘MIDI Implementation Chart’ on page 129 for further
information regarding the MIDI capabilities of the CS10 digital piano.
Multi-timbral mode setting
Receive multiple channel MIDI data from a MIDI-connected
musical instrument or device.
„ MIDI Settings
No.
Setting
Description
Default setting
1
MIDI Channel
Specify the channel that is used to transmit/receive MIDI information.
1
2
Send PGM Change # Send a MIDI program change number from 1 to 128.
1
3
Local Control
Specify whether internal sounds will be heard when the keyboard is pressed.
On
4
Trans. PGM Change
Specify whether program change data is sent when sounds are changed.
On
5
Multi-timbral Mode
Specify whether the instrument can receive Multi-timbral MIDI information.
Off
6
Channel Mute
Specify which channels (1-16) are activated to receive MIDI information.
Play All
Settings
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
„Entering the MIDI Settings menu
„Selecting and adjusting the desired setting
While the normal playing mode screen is shown in the LCD display:
After entering the MIDI Settings menu:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the e or f buttons to adjust the selected setting.
Press the d or c buttons to select the MIDI Settings menu.
* To reset the current setting to the default value, press the
button (RESET).
Press the FUNCTION button (ENTER) again to enter the MIDI
Settings menu.
98
Press the d or c buttons to move the selection cursor over the
desired setting.
FUNCTION
1 MIDI Channel
The MIDI Channel setting allows the transmit/receive channel to be specified. The selected channel will function as
both the transmit and receive channel (separate transmit/receive channels cannot be specified).
1. Selecting the MIDI Channel setting
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the MIDI Channel setting.
2. Changing the MIDI Channel value
Press the e or f buttons to increase or decrease the value of
the MIDI Channel setting.
* The MIDI Channel value can be adjusted within the range of 1 - 16.
* To reset the MIDI Channel setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the MIDI Channel setting will remain until the
power is turned off.
* Preferred MIDI Channel settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the MIDI Channel setting
Press the FUNCTION button (BACK) to exit the MIDI Channel
setting and return to the Function Menus screen.
„Omni mode
Settings
When the CS10 digital piano is turned on, the instrument is automatically set to ‘omni mode on’, allowing MIDI information to be
received on all MIDI channels (1-16). When the MIDI Channel setting is used to specify a transmit/receive channel, the instrument
will be set to ‘omni mode off’.
„ Multi-timbral mode and Split/Dual modes
Using Split mode with Multi-timbral mode enabled
Using Dual mode with Multi-timbral mode enabled
Notes played in the lower section of the keyboard will be
transmitted on the channel that is 1 channel higher than the
specified channel. For example, if the MIDI channel is set to
3, notes played in the lower section of the keyboard will be
transmitted on channel 4.
Notes played will be transmitted on two channels: the
specified channel and the channel that is 1 channel higher.
For example, if the MIDI channel is set to 3, notes played on
the keyboard will be transmitted on channels 3 and 4.
* If the specified MIDI channel is 16, the lower section / layered part will be transmitted on channel 1.
99
MIDI Settings
2 Send Program Change Number
The Send Program Change Number function is used to send a Program Change Number (1-128) to the connected
MIDI device.
1. Selecting the Send Program Change Number function
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the Send Program Change
Number function.
2. Specifying and transmitting a Program Change Number
Press the e or f buttons to decrease or increase the Program
Change Number.
* The program change number can be set within the range of 1-128.
Press the
FUNCTION button (SEND) to send the specified
Program Change Number.
3. Exiting the Send Program Change Number function
Settings
Press the FUNCTION button (BACK) to exit the Send Program
Change Number function and return to the Function Menus
screen.
100
3 Local Control
The Local Control setting determines whether the instrument will play an internal sound when the keys are pressed.
This setting may be useful when using the CS10 digital piano to control an external MIDI device that is connected
to the instrument’s amplifier/speakers.
„ Local Control setting
Local Control
Description
Off
The instrument will transmit information to an external MIDI device only.
On (default)
The instrument will play an internal sound and transmit information to an external MIDI device.
1. Selecting the Local Control setting
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the Local Control setting.
2. Changing the Local Control setting
Press the e or f buttons to turn the Local Control setting on
or off.
* To reset the Local Control setting to the default setting, press the
FUNCTION button (RESET).
* Any changes made to the Local Control setting will remain until the
power is turned off.
* Preferred Local Control settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Local Control setting
Settings
Press the FUNCTION button (BACK) to exit the Local Control
setting and return to the Function Menus screen.
101
MIDI Settings
4 Transmit Program Change Numbers
The Transmit Program Change Numbers setting determines whether the CS10 digital piano will transmit program
change information via MIDI when the instrument’s panel buttons are pressed.
„ Transmit Program Change Numbers setting
Transmit PGM#
Multi-timbral setting
Effect of pressing panel buttons
On (default)
Off, On1
SOUND buttons will send PGM# shown in the left column*.
On
On2
SOUND buttons will send PGM# shown in the right column*.
Off
Off
Program Change information will not be transmitted via MIDI.
* Please refer to the ‘Program Change Number List’ on page 124.
1. Selecting the Transmit Program Change Numbers setting
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the Transmit Program Change
Numbers setting.
2. Changing the Transmit Program Change Numbers setting
Press the e or f buttons to turn the Transmit Program Change
Numbers setting on or off.
* To reset the Transmit Program Change Numbers setting to the default
setting, press the FUNCTION button (RESET).
* Any changes made to the Transmit Program Change Numbers setting
will remain until the power is turned off.
Settings
* Preferred Transmit Program Change Numbers settings can be stored
to a Registration memory for convenient recall. Please refer to page
30 for more information.
3. Exiting the Transmit Program Change Numbers setting
Press the
FUNCTION button (BACK) to exit the Transmit
Program Change Numbers setting and return to the Function
Menus screen.
„Omni mode
ƒ When using Dual or Split mode, On/Off information and sound
type settings for are transmitted as exclusive data, however
program change numbers will not be transmitted.
102
ƒ Program change numbers will also be transmitted when
Multi-timbral mode is set to On1 or On2.
5 Multi-timbral Mode
The Multi-timbral Mode setting determines whether or not the CS10 digital piano is able to receive MIDI information
on more than one MIDI channel simultaneously. This allows the instrument to play back multi-track, multi-timbral
performance data sent from an external MIDI device.
„ Multi-timbral Mode setting
Multi-timbral Mode
Selected sound
Off
The sound shown in the left column is selected*.
On1 (default)
The sound shown in the left column is selected*.
On2
The sound shown in the right column is selected*.
* Please refer to the ‘Program Change Number List’ on page 124.
1. Selecting the Multi-timbral Mode setting
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the Multi-timbral Mode
setting.
2. Changing the Multi-timbral Mode setting
Press the e or f buttons to change turn the Multi-timbral
Mode setting.
* To reset the Multi-timbral Mode setting to the default setting, press
the FUNCTION button (RESET).
* Any changes made to the Multi-timbral Mode setting will remain until
the power is turned off.
Settings
* Preferred Multi-timbral Mode settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Multi-timbral Mode setting
Press the FUNCTION button (BACK) to exit the Multi-timbral
Mode setting and return to the Function Menus screen.
103
MIDI Settings
6 Channel Mute
The Channel Mute setting determines which MIDI channels (1-16) are activated to receive MIDI information when
Multi-timbral mode is enabled.
* This setting is only available when the Multi-timbral Mode setting is set to ‘On1’ or ‘On2’.
1. Selecting the Channel Mute setting
After entering the MIDI Settings menu (page 98):
Press the d or c buttons to select the Channel Mute setting.
Press the
FUNCTION button (EDIT).
The Channel Mute selection screen will be shown in the LCD
display.
2. Selecting and playing/muting channels
Press the d or c buttons to select the desired MIDI channel.
Press the e or f buttons to alternate between ‘Play’ and ‘Mute’
states.
* To reset the Channel Mute setting to the default value, press the
FUNCTION button (RESET).
* Any changes made to the Channel Mute setting will remain until the
power is turned off.
* Preferred Channel Mute settings can be stored to a Registration
memory for convenient recall. Please refer to page 30 for more
information.
3. Exiting the Channel Mute function
Settings
Press the FUNCTION button (BACK) to exit the Channel Mute
adjustment screen and return to the MIDI Settings menu.
104
USB MIDI (USB to Host connector)
The CS10 digital piano features a ‘USB to Host’ type connector, allowing the instrument to be connected to a
computer using an inexpensive USB cable and utilised as a MIDI device. Depending on the type of computer and
operating system installed, additional driver software may be required for USB MIDI communication to function
correctly.
„ USB MIDI driver
Operating System
Windows ME
Windows XP (no SP, SP1, SP2, SP3)
Windows XP 64-bit
Windows Vista (SP1, SP2)
Windows Vista 64-bit (SP1, SP2)
Windows 7 (no SP, SP1)
Windows 7 64-bit
Windows 8
Windows 8 64-bit
Windows 98 se
Windows 2000
Windows Vista (no SP)
USB MIDI Driver Support
Additional USB MIDI driver software NOT required.
The standard (built-in) Windows USB MIDI driver will be installed automatically when the
instrument is connected to the computer.
* After driver installation, ensure that the ‘USB Audio Device’ (Windows ME/Windows XP) or ‘USB-MIDI’
(Windows Vista/Windows 7) device is correctly selected in the application software.
Additional USB MIDI driver software required.
Please download the USB MIDI driver from the Kawai Japan website:
’ http://www.kawai.co.jp/english
* After driver installation, ensure that the ‘KAWAI USB MIDI’ device is correctly selected in the application software.
Windows Vista 64-bit (no SP)
USB MIDI is not supported.
Please upgrade to service pack 1 or service pack 2.
Mac OS X
Additional USB MIDI driver software NOT required.
The standard (built-in) Mac OS X USB MIDI driver will be installed automatically when the
instrument is connected to the computer.
Mac OS 9
USB MIDI is not supported.
Please use the standard MIDI IN/OUT connectors.
„ USB MIDI information
ƒ Disconnecting the USB MIDI cable suddenly, or turning the
both connected simultaneously, the USB MIDI port will be
given priority.
instrument on/off while using USB MIDI may cause computer
instability in the following situations:
ƒ Ensure that the instrument is turned OFF before attempting
to connect the USB MIDI cable.
ƒ
When connecting the instrument to a computer using
the USB MIDI port, there may be a short delay before
communications begin.
ƒ If the instrument is connected to a computer via a USB hub
and USB MIDI communication becomes unreliable/unstable,
please connect the USB MIDI cable directly to the one of the
computer’s USB ports.
Settings
ƒ If the instrument’s MIDI IN/OUT jacks and USB MIDI port are
– while installing the USB MIDI driver
– while starting up the computer
– while MIDI applications are performing tasks
– while the computer is in energy saver mode
ƒ If there are any further problems experienced with USB MIDI
communication while the instrument is connected, please
double-check all connections and relevant MIDI settings in
the computer’s operating system.
* ‘MIDI’ is a registered trademark of the Association of Manufacturers of Electronic Instruments (AMEI).
* ‘Windows’ is registered trademark of Microsoft Corporation.
* ‘Macintosh’ is registered trademark of Apple Computer, Inc.
* Other company names and product names mentioned referenced herein may be registered trademarks or trademarks of respective owners.
105
USB Menu
The USB Menu contains functions to load/save registration memories and recorder songs from/to a USB memory
device. This menu also allows files to be renamed and deleted, and for the USB memory device to be formatted.
„ USB Menu functions
No.
Function
Description
1
Load Song
Load a recorder song from a USB memory device into the instrument’s internal memory.
2
Load Registrations
Load registration memories from a USB memory device into the instrument.
3
Load User Memory
Load User Memory settings from a USB memory device into the instrument.
4
Save Internal Song
Save a recorder song stored in internal memory to a USB memory device.
5
Save SMF Song
Save a recorder song stored in internal memory to a USB memory device as an SMF (MIDI) file.
6
Save Registrations
Save registration memories from the instrument to a USB memory device.
7
Save User Memory
Save the instrument’s current User Memory settings to a USB memory device.
8
Rename File
Rename a file stored on a USB memory device.
9
Delete File
Delete a file stored on a USB memory device.
10
Format USB
Format a USB memory device, erasing all stored data.
„Entering the USB Menu menu
While the normal playing mode screen is shown in the LCD display:
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the d or c buttons to select the USB Menu.
Settings
Press the
Menu.
FUNCTION button (ENTER) again to enter the USB
dc buttons:
Move selection cursor.
„Selecting the desired USB Menu function
After entering the USB Menu:
Press the d or c buttons to move the selection cursor over the
desired function.
Press the
106
FUNCTION button (ENTER) to select the function.
dc buttons:
Move selection cursor.
FUNCTION button:
Select function.
1 Load Song
The Load Song function is used to load CS10 recorder songs stored on a USB memory device into the instrument’s
internal memory.
* This function will overwrite any song data stored in the selected song memory.
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 44.
1. Selecting the Load Song function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Load Song function.
2. Selecting the song memory
Press the e or f buttons to select the internal song memory for
the song to be loaded into.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The file selection screen will be shown in the LCD display, listing
CS10 song files stored on the USB memory device.
3. Selecting the song to be loaded
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the song file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
4. Confirming the load operation
Settings
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
5. Exiting the Load Song function
Press the
FUNCTION button (BACK) to exit the Load Song
function and return to the Function Menus screen.
To play back the loaded song file, please refer to the ‘Playing a
Song’ instructions on page 46.
107
USB Menu
2 Load Registrations
The Load Registrations function is used to load a CS10 registration file stored on a USB memory device into the
instrument’s registration memories.
* This function will overwrite all existing Registration memories.
* For more information about the instrument’s Registration feature, please refer to page 30.
1. Selecting the Load Registrations function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Load Registrations
function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
CS10 registration files stored on the USB memory device.
2. Selecting the registration file to be loaded
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the registration
file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
3. Confirming the load operation
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
Settings
4. Exiting the Load Registrations function
Press the
FUNCTION button (BACK) to exit the Load
Registrations function and return to the Function Menus
screen.
To use the loaded registrations, please refer to the Registration
instructions on page 30.
108
3 Load User Memory
The Load User Memory function is used to load a CS10 user memory setting file stored on a USB memory device into
the instrument’s User Memory. The loaded settings will be used as the default settings every time the CS10 digital
piano is turned on.
* This function will overwrite the previously stored User Memory settings.
* For more information about the instrument’s User Memory feature, please refer to page 74.
1. Selecting the Load User Memory function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Load User Memory
function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
CS10 user memory files stored on the USB memory device.
2. Selecting the user memory file to be loaded
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (LOAD) to select the user memory
file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the load operation.
3. Confirming the load operation
Settings
Press the
FUNCTION button (YES) to confirm the load
operation, or the FUNCTION button (NO) to cancel.
4. Exiting the Load User Memory function
Press the
FUNCTION button (BACK) to exit the Load User
Memory function and return to the Function Menus screen.
109
USB Menu
4 Save Song
The Save Song function is used to save CS10 recorder songs stored in the instrument’s internal memory to a USB
memory device in Kawai’s native song format.
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 44.
1. Selecting the Save Song function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Save Song function.
2. Selecting the song memory to be saved
Press the e or f buttons to select the internal song memory
to be saved.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The filename input screen will be shown in the LCD display.
3. Naming the song
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the song, or the
FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
Settings
4. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The song file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
5. Exiting the Save Song function
Press the
FUNCTION button (BACK) to exit the Save Song
function and return to the Function Menus screen.
110
5 Save SMF Song
The Save SMF Song function is used to save CS10 recorder songs stored in the instrument’s internal memory to a
USB memory device as a Standard MIDI File (SMF).
* For more information about the instrument’s ‘Internal Song Recorder’ feature, please refer to page 44.
1. Selecting the Save SMF Song function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Save SMF Song function.
2. Selecting the song memory to be saved
Press the e or f buttons to select the internal song memory
to be saved.
* If a song memory contains song data, a * symbol will be shown.
Press the
FUNCTION button (ENTER).
Song has been recorded
The filename input screen will be shown in the LCD display.
3. Naming the SMF song
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the song, or the
FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
Settings
4. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The SMF song file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
5. Exiting the Save SMF Song function
Press the FUNCTION button (BACK) to exit the Save SMF Song
function and return to the Function Menus screen.
111
USB Menu
6 Save Registrations
The Save Registrations function is used to save CS10 registration memories stored in the instrument to a USB
memory device.
* For more information about the instrument’s ‘Registration’ feature, please refer to page 30.
1. Selecting the Save Registrations function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Save Registrations
function.
Press the
FUNCTION button (ENTER).
The filename input screen will be shown in the LCD display.
2. Naming the Registrations file
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
Press the
file, or the
FUNCTION button (SAVE) to save the registration
FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
3. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
Settings
* The registration file will be saved in the root folder of the USB memory
device. It is not possible to save the file in a different folder.
4. Exiting the Save Registrations function
Press the
FUNCTION button (BACK) to exit the Save
Registrations function and return to the Function Menus
screen.
112
7 Save User Memory
The Save User Memory function is used to save the current CS10 User Memory settings to a USB memory device.
* For more information about the instrument’s ‘User Memory’ feature, please refer to page 74.
1. Selecting the Save User Memory function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Save User Memory
function.
Press the
FUNCTION button (ENTER).
The filename input screen will be shown in the LCD display.
2. Naming the User Memory file
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
Press the FUNCTION button (SAVE) to save the user memory
file, or the FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the save operation.
3. Confirming the save operation
Press the
FUNCTION button (YES) to confirm the save
operation, or the FUNCTION button (NO) to cancel.
* The user memory file will be saved in the root folder of the USB
memory device. It is not possible to save the file in a different folder.
Settings
* The user memory file will not store the settings of the ‘User Touch
Curve’, ‘User Temperament’, ‘User Tuning’, and ‘User Key Volume’
settings.
4. Exiting the Save User Memory function
Press the
FUNCTION button (BACK) to exit the Save User
Memory function and return to the Function Menus screen.
113
USB Menu
8 Rename File
The Rename File function is used to rename song, audio, and registration files stored on a USB memory device.
1. Selecting the Rename File function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Rename File function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
files stored on the USB memory device.
2. Selecting the file to be renamed
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (RENAME) to select the file to be
renamed.
The filename input screen will be shown in the LCD display.
3. Renaming the selected file
Press the d or c buttons to cycle through the alphanumeric
characters, and the e or f buttons to move the cursor.
Press the FUNCTION button (RENAME) to rename the file, or
the FUNCTION button (BACK) to cancel.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the rename operation.
Settings
4. Confirming the rename operation
Press the
FUNCTION button (YES) to confirm the rename
operation, or the FUNCTION button (NO) to cancel.
5. Exiting the Rename File function
Press the FUNCTION button (BACK) to exit the Rename File
function and return to the Function Menus screen.
114
9 Delete File
The Delete File function is used to delete song, audio, and registration files stored on a USB memory device.
Once a file has been deleted from the USB device it cannot be recovered.
1. Selecting the Delete File function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Delete File function.
Press the
FUNCTION button (ENTER).
The file selection screen will be shown in the LCD display, listing
files stored on the USB memory device.
2. Selecting the file to be deleted
Press the d or c buttons to move the selection cursor, then
press the FUNCTION button (OK) to delete the file.
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the delete operation.
3. Confirming the delete operation
Press the
FUNCTION button (YES) to confirm the delete
operation, or the FUNCTION button (NO) to cancel.
4. Exiting the Delete File function
Settings
Press the
FUNCTION button (BACK) to exit the Delete File
function and return to the Function Menus screen.
115
USB Menu
10 Format USB
The Format USB function is used to format the connected USB memory device, erasing all stored data.
The USB Format function will erase all data stored on the connected USB memory device.
Exercise caution when using this function in order to prevent accidental data loss.
1. Selecting the Format USB function
After entering the USB Menu (page 106):
Press the d or c buttons to select the Format USB function.
Press the
FUNCTION button (ENTER).
A confirmation message will be shown in the LCD display,
prompting to confirm or cancel the format operation.
2. Confirming the format operation
Press the
FUNCTION button (YES) to confirm the format
operation, or the FUNCTION button (NO) to cancel.
3. Exiting the Format USB function
Settings
Press the FUNCTION button (BACK) to exit the Format USB
function and return to the Function Menus screen.
116
Power Settings
Auto Power Off
The CS10 digital piano features a power saving function that can be used to automatically turn off the instrument
after a specified period of inactivity.
* This setting will be stored automatically, and recalled every time the instrument is turned on.
„ Auto Power Off settings
Auto Power Off
Description
Off
The Auto Power Off function is disabled.
30 min.
The instrument will turn off automatically after 30 minutes of inactivity.
60 min.
The instrument will turn off automatically after 60 minutes of inactivity.
120 min.
The instrument will turn off automatically after 120 minutes of inactivity.
1. Selecting the Auto Power Off setting
Press the
FUNCTION button (EDIT).
The LED indicator for the FUNCTION button will turn on, and
the Function menus will be shown in the LCD display.
Press the d or c buttons to select the Power Setting menu.
Press the FUNCTION button (ENTER) again to enter the Power
Setting menu.
2. Changing the Auto Power Off setting
Press the e or f buttons to change the Auto Power Off setting.
Settings
* The Auto Power Off setting will be stored automatically, and recalled
every time the instrument is turned on.
3. Exiting the Auto Power Off setting
Press the FUNCTION button (BACK) to exit the Auto Power Off
setting and return to the Function Menus screen.
117
Connecting to Other Devices
The CS10 digital piano features a variety of jacks that allow the instrument to be connected to MIDI devices,
computers, speakers, and mixers. It is also possible to connect external audio sources, such as an MP3 player,
tablet, or a secondary keyboard, to the instrument’s amplifier and speaker system. The illustration below provides
a visual overview of the connectors and their typical applications.
USB type ‘B’
USB type ‘A’
Connect the audio from
other devices to the
instrument’s speakers.
Connect the instrument
to external speakers,
amplifiers, mixers, etc.
Connect the instrument
to a computer to send
or receive MIDI data.
Connect the instrument
to MIDI modules, other
instruments/devices, etc.
Appendix
Before connecting the CS10 digital piano to other devices, ensure that the power to both the instrument and the
other device is turned off. If connections are established while the power is turned on, extraneous noise that can
damage the CS10 digital piano may activate the instrument’s amplifier protection circuit, preventing any sound
from being produced. If this occurs, turn the power off and then on again to reset the amplifier protection circuit.
Do not connect the LINE IN and LINE OUT jacks of the CS10 digital piano together with the same cable. An audio
loop (oscillation sound) will occur, resulting in damage to the unit.
118
Jack Panel
„LINE IN jacks (1/4” phone jack)
„LINE OUT jacks (1/4” phone jack)
These jacks are used to connect a pair of stereo outputs from
other electronic instruments or audio equipment to the CS10
digital piano’s speakers. The input level signal from these jacks
can be adjusted using the LEVEL knob, or by adjusting the
volume of the connected device.
These jacks are used to connect the stereo output of the CS10
digital piano’s sound to external speakers, amplifiers, mixers,
recording devices, and similar equipment.
To connect a device in mono, connect the cable to the L/MONO
jack only. The CS10 digital piano also allows the LINE IN audio to
be mixed with a recorded MP3/WAV file.
* The ‘Line In Level’ setting can also be used to adjust the level of the
LINE IN signal. Please refer to page 67 for more information.
„USB to Host port (‘B’ type)
This USB port is used to connect the CS10 digital piano to a
computer using an inexpensive USB cable. When connected, the
instrument can be used as a standard MIDI device, allowing it to
send a receive MIDI data. Connect a ‘B’ type USB connector to
the instrument, and an ‘A’ type USB connector to the computer.
Mono signals will be output only if a cable is connected to the
L/MONO jack.
The MASTER VOLUME knob does not affect the LINE OUT level.
* The ‘Line Out Volume’ setting can be used to adjust the level of the
LINE OUT signal. Please refer to page 68 for more information.
„MIDI IN/OUT jacks
These jacks are used to connect the CS10 digital piano to external
MIDI devices, and also to a computer with a MIDI interface as an
alternative to the ‘USB to Host’ port.
* Please refer to page 97 for more information about MIDI.
* Please refer to page 105 for more information about USB MIDI.
Headphone Panel
„PHONES jacks (1/4” phone jack)
„USB to Device port (‘A’ type)
These jacks are used to connect stereo headphones to the CS10
digital piano. Two pairs of headphones can be connected and
used simultaneously. When a pair of headphones is connected,
sound will not be produced by the speakers.
This USB port is used to connect a USB memory device to the
CS10 digital piano. This allows MP3/WAV audio files, and SMF
song files to be played directly. It is also possible to record
performances to MP3/WAV audio files, and save recorder songs
stored in internal memory for posterity.
ƒ The ‘USB to Device’ functionality of the CS10 digital piano
ƒ It may be necessary to format the USB memory device before
conforms to USB2.0 Hi-Speed standards. Older USB devices
can still be used, however data transfer speed will be limited
to the maximum transfer speed of the device.
it can be used with the CS10 digital piano. If so, please refer to
the USB Format function instructions on page 116. Formatting
the device will erase all data.
The ‘USB to Device’ port is intended for connecting USB
memory devices, however USB floppy drive devices can also
be used to save recorder songs stored in internal memory, or
play SMF song files.
ƒ Avoid removing the USB memory device while data is being
ƒ
loaded or saved, files are being renamed or deleted, or the
device is being formatted.
ƒ Other USB devices, such as computer mice, keyboards, or
battery chargers etc. cannot be used with this instrument.
119
Appendix
„USB device information
Troubleshooting
The tables below summarise issues that may be experienced with the CS10 digital piano, explaining the typical
cause(s), and recommended solution(s).
„ Power
Issue
Possible Cause and Solution
Page no.
The instrument does not turn on.
Check that the power cable is firmly attached to the instrument, and
connected to an AC outlet.
p. 14
The instrument turns itself off after a period
of inactivity.
Check that the ‘Auto Power Off’ function is not enabled.
p. 117
„ Sound
Issue
The instrument is turned on, however no sound
is produced when the keys are pressed.
The sound distorts when playing at very loud
volume levels.
Possible Cause and Solution
Page no.
Check that the MASTER VOLUME knob is not set to the lowest position.
p. 15
Check that a pair of headphones (or headphone adaptor plug) are not
connected to the PHONES jacks.
p. 15
Check that the ‘Local Control’ setting in the MIDI Settings menu is set to On.
p. 101
Check that the MASTER VOLUME knob is set to an appropriate level,
reducing the volume if excessive distortion is heard.
p. 15
If connecting the instrument to an amplifier/mixer using the Line Out jacks,
reduce the value of the ‘Line Out Volume’ setting in the Basic Settings
menu
Strange sounds or noises are heard when
playing with piano sounds.
The CS10 digital piano attempts to reproduce the rich variety of tones
created by an acoustic grand piano as accurately as possible. This includes
string resonances and damper noises, and other subtle characteristics that
contribute to the overall piano playing experience.
p. 76
While these additional tones are intended to enhance the realism of the
instrument, it is possible to reduce their prominence, or disable the effects
altogether using the settings in the Virtual Technician menu.
The top 18 notes of the keyboard sustain for
longer than neighbouring notes, even when the
damper pedal is not pressed.
This is the correct behaviour, and intended to reproduce the undamped
notes (typically the top two octaves) of an acoustic grand piano.
–
Possible Cause and Solution
Page no.
„ Pedals
Issue
Appendix
When depressing a pedal, the pedal board
flexes and is not firm.
120
Check that the pedal support bolt is fully extended.
p. 16
„ Headphones
Issue
The headphone volume is too low.
Possible Cause and Solution
If the ‘Nominal Impedance’ specification of the headphones is less
than 100 Ω (ohms), set the ‘Phones Volume’ setting in the Basic
Settings menu to High.
Page no.
p. 66
„ USB (memory device)
Issue
Possible Cause and Solution
Page no.
A USB memory device is not detected, cannot be
saved to, or does not appear to function when
connected to the ‘USB to Device’ port.
Check that the USB memory device is formatted to use the FAT/FAT32
filesystem, and not set to ‘Write Protect’ mode.
p. 119
Disconnect the USB memory device, turn the instrument off then on, then
reconnect the USB device. If the USB device still does not function, it may
be damaged or incompatible. Please try using a different USB device.
–
The instrument pauses briefly when connecting
a USB memory device.
This is recognised behaviour when using very large capacity (e.g. 8GB+)
USB memory devices.
–
Possible Cause and Solution
Page no.
„ USB (MIDI)
Issue
The instrument is connected to the computer
using a USB cable, however the software does
not respond to key presses.
Check that a USB MIDI driver is installed on the computer.
p. 105
Check that ‘USB Audio Device’ or ‘KAWAI USB MIDI’ is selected in the
software’s input/output device settings.
p. 105
„ MP3/WAV/SMF files
Possible Cause and Solution
Page no.
No sound can be heard when playing an MP3
or WAV audio file stored on a USB memory
device.
Check that the audio player volume is not set to 0.
p. 53
Check that the format of the audio file is supported and listed in the
‘Audio Player supported format specifications’ table.
p. 52
An MP3/WAV audio file stored on a USB
memory device sounds strange, or does not
play back correctly.
Check that the format of the audio file is supported and listed in the
‘Audio Player supported format specifications’ table.
p. 52
The file transfer speed of the USB memory device may be too slow to
play the audio file. Please try using a different USB memory device,
ensuring that it conforms to USB2.0 Hi-Speed standards.
p. 119
When recording MP3/WAV audio files, the
volume is too low/too high (distorted).
Check the gain setting before recording the audio, and if necessary
adjust to increase/decrease the recording level.
p. 50
An SMF MIDI file stored on a USB memory
device sounds strange when played back.
The CS10 digital piano does not contain the full General MIDI sound
bank selection. Consequently, some SMF song files may not be
reproduced entirely accurately when played through the instrument.
p. 55
Appendix
Issue
121
sectionSong List
Demo
Sound Name
Song Title
Composer
Polonaise-Fantaisie
Chopin
Concert Grand 2
Petit chien
Chopin
Studio Grand
Original
Kawai
Studio Grand 2
Original
Kawai
Mellow Grand
Sonata No.30 Op.109
Beethoven
Mellow Grand 2
La Fille aux Cheveux de lin
Debussy
Pop Piano
Original
Kawai
Upright Piano
Alpenglühen Op.193
Oesten
Modern Piano
Original
Kawai
Rock Piano
Original
Kawai
New Age Piano
Original
Kawai
Classic E.Piano
Original
Kawai
Modern E.P.
Original
Kawai
Modern E.P. 2
Original
Kawai
PIANO 1
Concert Grand
PIANO 2
E. PIANO
ORGAN
Jazz Organ
Original
Kawai
Blues Organ
Original
Kawai
Drawbar Organ
Original
Kawai
Church Organ
Chorale Prelude “Wachet auf, ruft uns die Stimme.”
Bach
Diapason
Wohl mir, daβ ich Jesum have
Bach
Full Ensemble
Original
Kawai
Harpsichord
French Suite No.6
Bach
Harpsichord Oct.
Prelude in Ab
Bach
Vibraphone
Original
Kawai
Clavi
Original
Kawai
Slow Strings
Original
Kawai
String Pad
Original
Kawai
String Ensemble
Le quattro stagioni La primavera
Vivaldi
Choir
Londonderry Air
Irish folk song
Choir 2
Original
Kawai
Jazz Ensemble
Original
Kawai
HARPSI & MALLETS
STRINGS
Appendix
VOCAL & PAD
New Age Pad
Original
Kawai
Atmosphere
Original
Kawai
BASS & GUITAR
122
Wood Bass
Original
Kawai
Fretless Bass
Original
Kawai
W. Bass & Ride
Original
Kawai
Ballad Guitar
Original
Kawai
Pick Nylon Gt.
Original
Kawai
PIANO 1
HARPSI & MALLETS
Concert Grand
Harpsichord
Concert Grand 2
Harpsichord Oct
Studio Grand
Vibraphone
Studio Grand 2
Clavi
Mellow Grand
Marimba
Mellow Grand 2
Celesta
Jazz Grand
Harpsichord 2
Jazz Grand 2
Bell Split
PIANO 2
STRINGS
Pop Piano
Slow Strings
Pop Piano 2
String Pad
Upright Piano
Warm Strings
Modern Piano
String Ensemble
Rock Piano
Soft Orchestra
Honky Tonk
Chamber Strings
New Age Piano
Harp
New Age Piano 2
Pizzicato Str.
E. PIANO
VOCAL & PAD
Classic E. Piano
Choir
60’s E.P.
Pop Ooh
Modern E.P.
Pop Aah
Classic E.P. 2
Choir 2
New Age E.P.
Jazz Ensemble
Crystal E.P.
Pop Ensemble
Modern E.P. 2
Slow Choir
Modern E.P. 3
Breathy Choir
ORGAN
New Age Pad
Jazz Organ
Atmosphere
Blues Organ
Itopia
Ballad Organ
Brightness
Gospel Organ
New Age Pad 2
Drawbar Organ
Brass Pad
Drawbar Organ 2
Bowed Pad
Drawbar Organ 3
Bright Warm Pad
Drawbar Organ 4
BASS & GUITAR
Church Organ
Wood Bass
Diapason
Finger Bass
Full Ensemble
Fretless Bass
Diapason Oct.
W. Bass & Ride
Chiffy Tibia
E. Bass & Ride
Principal Oct.
Ballad Guitar
Principal Choir
Pick Nylon Gt.
Baroque
Finger Nylon Gt
Appendix
sectionList
Sound
123
Program Change Number List
Multi-timbral mode = off/on1
Sound Name
Multi-timbral mode = on2
Bank
Program Number
Program Number
Concert Grand
1
1
121
0
Concert Grand 2
2
1
95
16
Studio Grand
3
1
121
1
Studio Grand 2
4
1
95
17
Mellow Grand
5
1
121
2
Mellow Grand 2
6
1
95
18
Jazz Grand
7
1
95
8
Jazz Grand 2
8
1
95
19
Pop Piano
9
2
95
10
Pop Piano 2
10
2
95
13
Upright Piano
11
1
95
25
Modern Piano
12
2
121
0
Rock Piano
13
2
121
1
Honky Tonk
14
4
121
0
New Age Piano
15
1
95
9
New Age Piano 2
16
1
95
10
Classic E. Piano
17
5
121
0
60’s E.P.
18
5
121
3
Modern E.P.
19
6
121
0
Classic E.P. 2
20
5
121
1
New Age E.P.
21
6
95
2
Crystal E.P.
22
6
95
1
Modern E.P. 2
23
6
121
1
Modern E.P. 3
24
6
121
2
Jazz Organ
25
18
121
0
Blues Organ
26
17
121
0
MSB
LSB
PIANO 1
PIANO 2
E. PIANO
Appendix
ORGAN
124
Ballad Organ
27
17
95
5
Gospel Organ
28
17
95
3
Drawbar Organ
29
17
95
1
Drawbar Organ 2
30
17
95
2
Drawbar Organ 3
31
18
121
2
Drawbar Organ 4
32
17
121
3
Church Organ
33
20
121
0
Diapason
34
20
95
7
Full Ensemble
35
21
95
1
Diapason Oct.
36
20
95
6
Chiffy Tibia
37
20
95
17
Principal Oct.
38
20
95
24
Principal Choir
39
20
95
23
Baroque
40
20
95
19
Multi-timbral mode = off/on1
Sound Name
Program Number
Multi-timbral mode = on2
Program Number
Bank
MSB
LSB
HARPSI & MALLETS
Harpsichord
41
7
121
0
Harpsichord Oct
42
7
121
1
Vibraphone
43
12
121
0
Clavi
44
8
121
0
Marimba
45
13
121
0
Celesta
46
9
95
1
Harpsichord 2
47
7
121
3
Bell Split
48
15
95
5
Slow Strings
49
45
95
1
String Pad
50
49
95
8
STRINGS
Warm Strings
51
49
95
1
String Ensemble
52
49
121
0
Soft Orchestra
53
50
95
1
Chamber Strings
54
49
95
14
Harp
55
47
121
0
Pizzicato Str.
56
46
121
0
CHOIR & PAD
Choir
57
53
121
0
Pop Ooh
58
54
95
39
Pop Aah
59
54
95
40
Choir 2
60
54
95
53
Jazz Ensemble
61
54
95
2
Pop Ensemble
62
54
95
7
Slow Choir
63
53
95
2
Breathy Choir
64
53
95
1
New Age Pad
65
89
121
0
Atmosphere
66
100
121
0
Itopia
67
92
121
1
Brightness
68
101
95
1
New Age Pad 2
69
89
95
2
Brass Pad
70
62
95
2
Bowed Pad
71
93
121
0
Bright Warm Pad
72
90
95
1
73
33
121
0
Finger Bass
74
34
121
0
Fretless Bass
75
36
121
0
W. Bass & Ride
76
33
95
1
E. Bass & Ride
77
34
95
2
Wood Bass
Ballad Guitar
78
26
95
6
Pick Nylon Gt.
79
25
95
3
Finger Nylon Gt
80
25
95
4
Appendix
BASS & GUITAR
125
Drum Rhythm List
Appendix
No.
126
Rhythm Name
No.
Rhythm Name
1
8 Beat 1
51
Hip Hop 3
2
8 Beat 2
52
Hip Hop 4
3
8 Beat 3
53
Techno 1
4
16 Beat 1
54
Techno 2
5
16 Beat 2
55
Techno 3
6
16 Beat 3
56
Heavy Techno
7
16 Beat 4
57
8 Shuffle 1
8
16 Beat 5
58
8 Shuffle 2
9
16 Beat 6
59
8 Shuffle 3
10
Rock Beat 1
60
Boogie
16 Shuffle 1
11
Rock Beat 2
61
12
Rock Beat 3
62
16 Shuffle 2
13
Hard Rock
63
16 Shuffle 3
14
Heavy Beat
64
T Shuffle
15
Surf Rock
65
Triplet 1
16
2nd Line
66
Triplet 2
17
50 Ways
67
Triplet 3
18
Ballad 1
68
Triplet 4
19
Ballad 2
69
Triplet Ballad 1
20
Ballad 3
70
Triplet Ballad 2
21
Ballad 4
71
Triplet Ballad 3
22
Ballad 5
72
Motown 1
23
Light Ride 1
73
Motown 2
24
Light Ride 2
74
Ride Swing
25
Smooth Beat
75
H.H. Swing
Jazz Waltz 1
26
Rim Beat
76
27
Slow Jam
77
Jazz Waltz 2
28
Pop 1
78
5/4 Swing
29
Pop 2
79
Tom Swing
30
Electro Pop 1
80
Fast 4 Beat
31
Electro Pop 2
81
H.H. Bossa Nova
32
Ride Beat 1
82
Ride Bossa Nova
33
Ride Beat 2
83
Beguine
34
Ride Beat 3
84
Mambo
35
Ride Beat 4
85
Cha Cha
36
Slip Beat
86
Samba
37
Jazz Rock
87
Light Samba
38
Funky Beat 1
88
Surdo Samba
39
Funky Beat 2
89
Latin Groove
40
Funky Beat 3
90
Afro Cuban
41
Funk 1
91
Songo
42
Funk 2
92
Bembe
43
Funk 3
93
African Bembe
44
Funk Shuffle 1
94
Merenge
45
Funk Shuffle 2
95
Reggae
46
Buzz Beat
96
Tango
47
Disco 1
97
Habanera
48
Disco 2
98
Waltz
49
Hip Hop 1
99
Ragtime
50
Hip Hop 2
100
Country & Western
section
Specifications
„ Kawai CS10 Digital Piano
Sound Source
Internal Sounds
Polyphony
Keyboard Modes
88 wooden keys with Ivory Touch key surfaces
Grand Feel (GF) action with Let-Off
Harmonic Imaging™ XL (HI-XL), 88-key piano sampling
80 voices
max. 256 notes
Dual Mode, Split Mode, Four Hands Mode (Volume/Balance adjustable)
Reverb
Type:
Parameters:
Effects
Type:
Parameters:
Virtual Technician
Touch Curve:
Voicing:
MP3, WAV, SMF
Record:
MP3, WAV, SMF
Others:
Load Internal Song, Load Registration, Load User Memory, Save Internal Song, Save SMF Song,
Save Registration, Save User Memory, Rename File, Delete File, Format USB.
Convert Song to Audio, Overdub Audio
Tempo:
Piano Music:
Lesson Function:
Concert Magic:
Dimensions
Weight
10 - 400 bpm (20 - 800 bpm for eighth note rhythms)
37 songs
29 or 42 pieces 1
Finger exercises + Alfred or Burgmüller, Czerny, Beyer, and Bach lesson books 1
176 songs (88 x 2 banks)
Key Transpose, Song Transpose, Tone Control (incl. User EQ), Speaker Volume, Phones Volume, Line In Level, Line
Out Volume, Audio Recorder Gain, Wall EQ, Tuning, Damper Hold, Four Hands, LCD Contrast, User Memory, Factory
Reset, Lower Octave Shift, Lower Pedal On/Off, Split Balance, Layer Octave Shift, Layer Dynamics, Dual Balance,
MIDI Channel, Send PGM#, Local Control, Transmit PGM#, Multi-timbral Mode, Channel Mute, Auto Power Off
128 x 64 pixel LCD with backlight
Sustain (with half-pedal support), Soft, Sostenuto
LINE IN (L/MONO, R), LINE IN Level Adjust, LINE OUT (L/MONO, R), Headphones x 2,
MIDI (IN/OUT), USB to Host, USB to Device
Speakers:
Output Power:
(Not including music rack)
1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, 12/8 + 100 drum rhythms
16 memories (8 x 2)
Speaker System
Power Consumption
Stretch Tuning, User Tuning, User Key Volume, Half-Pedal Adjust, Minimum Touch
Playback:
Demo Songs:
Jacks
Normal, Mellow 1, Mellow 2 , Dynamic, Bright 1, Bright 2
10 song, 2 track recorder – approximately 90,000 note memory capacity
Music Menu
Pedals
Light+, Light, Normal, Heavy, Heavy+, Off (Constant), User 1, User 2
Equal (Piano), Pure Major, Pure minor, Pythagorean, Meantone, Werckmeister, Kirnberger,
Equal (Flat), Equal (Stretch), User Temperament, Key of Temperament
Beat:
Display
Dry/Wet, Time, Speed, Mono/Stereo, Accel./Rotary Speed – Parameters dependent on effect.
Temperament
& Tuning:
Metronome
Other Settings
& Functions
Stereo Delay, Ping Delay, Triple Delay, Chorus, Classic Chorus, Tremolo, Classic Tremolo,
Auto Pan, Classic Auto Pan, Phaser, Rotary, Combination effects x 4, Amplified Effects x 3
Damper Resonance, Damper Noise, String Resonance, Key-off Effect (incl. Key-off Release),
Fall-back Noise, Hammer Delay, Topboard, Decay Time, Soft Pedal Depth
USB Functions
Registrations
Reverb Depth, Reverb Time
Resonance,
Noise & Effects:
Others:
Internal Recorder
Room, Lounge, Small Hall, Concert Hall, Live Hall, Cathedral
7 cm x 4 (top speakers)
1.4 cm x 2 (dome tweeters)
Soundboard Speaker System
Appendix
Keyboard
45 W x 2 + 45 W transducer
55 W
1510 (W) x 542 (D) x 1049 (H) mm
60” (W) x 211⁄3 ” (D) x 411⁄3 ” (H)
102.0 Kg / 225 lbs.
Specifications are subject to change without notice. / 1 depending on market location.
127
section
MIDI
Exclusive Data Format
1st byte
2nd byte
3rd byte
4th byte
5th byte
6th byte
7th byte
8th byte
9th byte
10th byte
1
2
3
4
5
6
7
8
9
10
Byte
ID
Description
1 F0
Start code
2 40
Kawai ID number
3 00 - 0F
MIDI channel
4 10, 30
Function code (30 when setting Multi-timbre On/Off)
5 04
Indicates that the instrument is an electric piano
6 02
Indicates that the piano is a CA/ES model
7 data 1
8 data 2
See table below
9 data 3
Appendix
10 F7
128
End code
data 1
data 2
data 3
Function
00
00
-
Multi-timbre Off
00
01
-
Multi-timbre On 1
00
02
-
Multi-timbre On 2
0F
00 - 7F
-
Split Point
14
00 - 7F
-
Dual/Split balance
16
1F - 60
-
Tune, 40: 440 Hz
17
00, 7F
-
00: Program Change Off, 7F: Program Chage On
18
00 - 07
-
00: Light, 01: Normal, 02: Heavy, 03: Off, 04: Light +, 05: Heavy +,
06: User1, 07: User2
19
00 - 03
-
Lower Octave Shift
20
00 - 4F
00 - 4F
Dual, data 2: Main sound, 3: Layer sound
21
00 - 4F
00 - 4F
Split, data 2: Upper sound, data 3: Lower sound
22
00 - 4F
00 - 4F
Four Hands, data 2: Right sound, data 3: Left sound
25
00 - 08
00 - 0B
data 2: Temperament, data 3: Key
26
00, 7F
00 - 0F
Multi-timbre channel mute, data 2: 00 (mute On), 7F (mute Off), data 3: Channel
MIDI Implementation Chart
„ Kawai CS10 digital piano
Date : December 2012 - Version : 1.0
Function
Transmit
Receive
1
1
1 - 16
1 - 16
Mode 3
Mode 1
°
Mode 1, 3
ÄÄÄÄÄÄÄÄÄ
°
21 - 108 **
0 - 127
ÄÄÄÄÄÄÄÄÄ
0 - 127
Note on
{
{
Note off
{
{
Key specific
°
°
Channel specific
°
°
°
°
{
°
°
°
{ (Right pedal)
{ (Middle pedal)
{ (Left pedal)
{
{
{
{
{
{
{
{ 0 - 127
{ 0 - 127 ***
At power-up
Remarks
Basic channel
Settable
At power-up
Mode
Message
Alternative
Note number
Range
* The default for the OMNI
mode is ON.
Specifying MIDI channels
automatically turns it OFF.
** The value depends on
the Transpose setting.
Velocity
After touch
Pitch bend
0, 32
7
10
11
64
66
67
Control change
Program change
True
{
{
Song position
°
°
Song selection
°
°
Tune
°
°
Clock
°
°
Commands
°
°
Local On / Off
°
{
All notes Off
°
{ (123 - 127)
Active sensing
°
{
Reset
°
°
Exclusive
Common
ÄÄÄÄÄÄÄÄ
Bank Select
Volume
Pan Pot
Expression Pedal
Sustain Pedal
Sostenuto Pedal
Soft Pedal
*** Refer to the Program
Change Number List on
page 124.
On/Off Selectable
Real time
Appendix
Other functions
Remarks
Mode 1: omni mode On, Poly
Mode 2: omni mode On, Mono
{ : Yes
Mode 3: omni mode Off, Poly
Mode 4: omni mode Off, Mono
° : No
129
Appendix
User Notes
130
Hello to Jason Isaacs!
CS10 Owner’s Manual
KPSZ-0609
OW1070E-J1302
Printed in Indonesia
Copyright © 2013 Kawai Musical Instruments Mfg. Co., Ltd. All Rights Reserved.
