Product Overview
Chapter 1
Product Overview
Thank you for choosing the IM-945GSE Series (MS9830 v1.X) Mini ITX mainboards from MSI.
Based on the innovative Intel® 945GSE & ICH7M controllers for optimal system efficiency, the IM-945GSE
Series accommodate the latest Intel® AtomTM processor
N270 (1.6GHz single core with HT) and support one
DDR2 533/667/800 SO-DIMM slot to provide the maximum of 1GB memory capacity.
Three options are available for the IM-945GSE Series:
Option A
ATX Power, High Rear I/O, DVI, VGA,
1 RS-232/422/485 Port, 5 RS-232 Ports
DC Power, Low Rear I/O, DVI-I,
Option B
Option C
1 RS-232/422/485 Port, 4 RS-232 Ports
DC Power, Low Rear I/O, VGA, LVDS,
1 RS-232/422/485 Port, 4 RS-232 Ports
DC Power, High Rear I/O, DVI, VGA,
Option D
Option E
1 RS-232/422/485 Port
DC Power, High Rear I/O, VGA, LVDS,
1 RS-232/422/485 Port, 4 RS-232 Ports
1-1
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Mainboard Specifications
Proce ssor
- Intel Atom processor N270 (1.6GHz single core with HT)
FSB
- 533MHz
Chipset
- Northbridge: Intel 945GSE chipset
- Southbridge: Intel ICH7M chipset
M e mo r y
- 1 unbuffered non-ECC DDR2 533/667/800 SO-DIMM slot
- Up to 1GB memory capacity
LAN
- Supports Gigabit Ethernet by Intel 82574L Controller
Audio
- HDA Codec by Realtek ALC888 7.1 channel (compliant with
Azalia 1.0 specs)
- TPA3005D2 am plifier (for Option C, E)
IDE
- 1 IDE port by Intel ICH7M
- Supports Ultra DMA 66/100 mode
- Supports PIO, Bus Master operation mode
SATA
- 2 SATA ports by Intel ICH7M
- Supports 2 SATA devices
- Supports up to 1.5Gb/s data transfer rate
Graphics
- Onboard graphics integrated in Intel 945GSE
1-2
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
Connectors
Option A Back Panel
- 1 double stack DB-9 connector
- 1 stack up VGA and DVI-D connector
- 1 stack up RJ45 and USB connector
- 1 double stack USB connector
- 1 Gigabit LAN jack
- 3 audio jacks
Option B Back Panel
- 1 DB-9 connector
- 1 DVI-I connector
- 2 double stack USB connectors
- 1 Gigabit LAN jack
- 2 audio jacks
Option C Back Panel
- 1 DB-9 connector
- 1 VGA connector
- 2 double stack USB connectors
- 1 Gigabit LAN jack
- 2 audio jacks
Option D Back Panel
- 1 DB-9 connector
- 1 stack up VGA and DVI-D connector
- 2 double stack USB connectors
- 1 Gigabit LAN jack
- 2 audio jacks
Option E Back Panel
- 1 DB-9 connector
- 1 VGA connector
- 1 stack up RJ45 and USB connector
- 1 double stack USB connector
- 1 Gigabit LAN jack
- 2 audio jacks
1-3
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Onboard Connectors
- 1 front audio pinheader
- 1 USB 2.0 pinheader (2 ports)
- 1 parallel port connector
- 4 serial port connectors (for option A, B, C, E only)
- 1 SPI Flash ROM pinheader (for debugging)
- 1 chassis intrusion switch pinheader
- 1 S/PDIF-Out pinheader
- 1 amplifier pinheader (for option C, E only)
- 1 LVDS connector (for option C, E only)
- 1 20-pin ATX power connector (for option A only)
- 1 4-pin DC 12V power connector (for option B, C, D, E only)
- 1 4-pin DC 5V/12V power connector (for option B, C, D, E only)
Slots
- 1 Mini PCI-E slot
- 1 32-bit/33MHz PCI slot
Form Factor
- Mini ITX: 170mm x 170mm
M ounting
- 4 mounting holes
Environmental
Storage Environment
- Temperature: -20oC ~ 80o C
- Humidity: 5% ~ 90% non condensing
Operation Environment
- Temperature: 0o C ~ 60o C
- Humidity: 5% ~ 90% non condensing
1-4
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
Block Diagram
1-5
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Mainboard Layout
CON1
ATX1
JCOMP2 JCOMP1
DIMM1
CPUFAN1
COM Ports
Top: VGA Port
Bottom: DVI Port
Int el
Atom CPU
JFP1
Intel
945GSE
Top: LAN Jack
Bottom: USB Ports
USB Ports
JCI1
JCOMP3
PCI1
COM3
JSPI1
SATA2
JC OMP5
JCO MP4
IDE 1
JAUD1
SATA1
COM2
JUSB1
COM1
JRTC1
JSPDO1
T: Line-In
M: Line-Out ALC888
B: Mic-In
COM4
JLAN1
JLPT1
Intel
ICH7M
JCOMP6
IM-945GSE Series Mini ITX Mainboard - Option A
1-6
PDF created with pdfFactory Pro trial version www.pdffactory.com
CON1
Product Overview
COM5
DIMM1
CPUFAN1
JCOMP1
JPW1
(DC-IN)
JDVI1
Intel 945GSE
JFP1
Intel Atom CPU
USB Ports
JPWR1
(For HDD)
USB Ports
JCI1
JLAN1
JRTC1
JCOMP3
PCI1
COM3
SATA2
JCOMP5
JCOMP4
IDE 1
JAUD1
SATA1
COM4
JUSB1
COM2
ALC888
COM1
JSPI1
JSPDO1
T: Line-Out
B: Mic-In
JLPT1
I ntel ICH7M
JCOMP6
IM-945GSE Series Mini ITX Mainboard - Option B
1-7
PDF created with pdfFactory Pro trial version www.pdffactory.com
CON1
M S-9830 M ainboard
COM5
DIMM1
CPUFAN1
JCOMP1
JPW1
(DC-IN)
JVGA1
Intel 945GSE
JFP1
I ntel Atom CPU
USB Ports
JPWR1
(For HDD)
JVDD1
JLVDS1
JCI1
USB Ports
J1
JLPT1
Intel ICH7M
JLAN1
JRTC1
JSPI1
SATA2
JCOMP3
PCI1
JCOMP5
JCOMP4
IDE 1
JAUD1
SATA1
COM3
JSPDO1
COM4
JUSB1
ALC888
COM1
T: Line-Out
B: Mic-In
COM2
JAMP1
JCOMP6
IM-945GSE Series Mini ITX Mainboard - Option C
1-8
PDF created with pdfFactory Pro trial version www.pdffactory.com
CON1
Product Overview
COM5
DIMM1
CPUFAN1
JCOMP1
JPW1
(DC-IN)
Top: VGA Port
Bottom: DVI Port
Intel 945GSE
JFP1
Int el Atom CPU
USB Ports
JPWR1
(For HDD)
USB Ports
JCI1
JLAN1
JRTC1
JSPI1
ALC888
JUSB1
JAUD1
SATA1
SATA2
JCOMP3
PCI1
JCOMP5
JCOMP4
IDE 1
JSPDO1
T: Line-Out
B: Mic-In
JLPT1
Intel ICH7M
JCOMP 6
IM-945GSE Series Mini ITX Mainboard - Option D
1-9
PDF created with pdfFactory Pro trial version www.pdffactory.com
CON1
M S-9830 M ainboard
COM5
DIMM1
CPUFAN1
JCOMP1
JPW1
(DC-IN)
JVGA1
I ntel 945GSE
JFP1
Intel Atom CPU
Top: LAN Jack
Bottom: USB Ports
JPWR1
(For HDD)
JVDD1
JLVDS1
JCI1
USB Ports
J1
JLPT1
Intel ICH7M
JLAN1
JRTC1
JSPI1
SATA2
JCOMP3
PCI1
JCOMP5
JCOMP4
IDE 1
JAUD1
SATA1
COM3
JSPDO1
COM4
JUSB1
ALC888
COM1
T: Line- Out
B: Mic-In
COM2
JAMP1
JCOMP6
IM-945GSE Series Mini ITX Mainboard - Option E
1-10
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
Board Dimension
1-11
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Back Panel & I/O Shield Drawing
IM-945GSE Series Mini ITX Mainboard - Option A
1-12
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
IM-945GSE Series Mini ITX Mainboard - Option B
1-13
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
IM-945GSE Series Mini ITX Mainboard - Option C
1-14
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
IM-945GSE Series Mini ITX Mainboard - Option D
1-15
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
IM-945GSE Series Mini ITX Mainboard - Option E
1-16
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
Power Consumption
Component
Description
CPU
Intel Atom Processor 200 Series
Memory
Corsair 1G DDR2-800 x1
Add-On VGA
NA
Hard Disk
Western 80G IDE 7200rpm HDD x1
Operating System
Microsoft Windows XP Professional SP2
Total
3.3V input
5V input
12V input
5VSB
Current (A)
Current (A)
Current (A)
Current (A)
Watt
Enter DOS (stable)
0.54
1.03
0.30
0.06
10.83W
Enter BIOS (stable)
0.56
1.03
0.30
0.06
10.90W
Idle
0.54
1.10
0.27
0.05
10.77W
CPU Stress 100%
0.54
1.18
0.31
0.05
11.65W
Windows stress
(3dMARK2006)
0.55
1.11
0.36
0.05
11.94 W
Windows Desktop
Standby S1 without
LAN connected
(stable)
0.48
1.03
0.25
0.05
9.98W
0
0
0
0.22
1.10W
0
0
0
0.13
0.65W
0
0
0
0.15
0.75W
MS-9830-0A (ATX)
Windows Desktop
Standby S3 without
LAN connected
Watt
(stable)
Windows Desktop
Hibernate S4 without
LAN connected
(stable)
Windows Desktop
Soft Off S5 without
LAN connected
(stable)
1-17
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Component
Description
CPU
Intel Atom Processor 200 Series
Memory
TRANSCEND 1G DDR2-800 x1
Add-On VGA
NA
Hard Disk
MAXTOR 40G IDE 7200rpm HDD x1
Operating System
Microsoft Windows XP Professional SP2
12V input
MS-9830-0A (DC)
Current (A)
Watt
Enter DOS (stable)
0.956A
11.47W
Enter BIOS (stable)
0.952 A
11.42W
Idle
0.934 A
11.21W
1.02A
12.24W
1.28 A
15.36W
Windows Desktop
Standby S1 without
LAN connected
(stable)
0.875 A
10.50W
Windows Desktop
Standby S3 without
LAN connected
(stable)
0.119 A
1.43W
0.05A
0.60W
0.05A
0.60W
CPU Stress 100%
Windows stress
(3dMARK2006)
Windows Desktop
Hibernate S4 without
LAN connected
(stable)
Windows Desktop
Soft Off S5 without
LAN connected
(stable)
1-18
PDF created with pdfFactory Pro trial version www.pdffactory.com
Product Overview
Safety Compliance & MTBF
Safety Compliance
Certification Standard number
Title of standard
EN 55022: 2006
CE
RFI
Limits for harmonic current emission
Limitation of voltage fluctuation and
flicker in low-voltage supply system
EN 55024:1998+A1:2001+A2:2003 Product family standard
EN 1995+A1:2001+A2:2005
Immunity
BSMI
CNS 13438 乙類(1995年6月版)
C-Tick
AS/NZS CISPR 22:2006
FCC
VCCI
Product family standard
EN 2006
FCC CFR Title 47 Part 15 Subpart B: 2005 Class B
CISPR 22: 2006
VCCI V-3:2008 Class B
VCCI V-4:2008 Class B
MTBF - Reliability Prediction
Calculation Model
Operation
Temperature (°C)
option A
Telcordia Issue 1
40
option B, D
Telcordia Issue 1
40
option C, E
Telcordia Issue 1
40
9830
Operation
Duty Cycle MTBF (hr.)
Environment
GB, GC Ground Benign, 6,429.899614 155,523
Controlled
GB, GC Ground Benign, 6,311.357614 158,445
Controlled
GB, GC Ground Benign, 6,841.490152 146,167
Controlled
1-19
PDF created with pdfFactory Pro trial version www.pdffactory.com
This page is intentionally left blank.
viii
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Chapter 2
Hardware Setup
This chapter provides you with the information about
hardware setup procedures. While doing the installation,
be careful in holding the components and follow the
installation procedures. For some components, if you
install in the wrong orientation, the components will not
work properly.
Use a grounded wrist strap before handling computer
c om ponen ts . S tatic elec tric ity m ay damage the
components.
2-1
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Quick Components Guide
CON1, p.2-18
JCOMP2, p.2-17
DIMM Slot, p.2-3
ATX1, p.2-4
JCOMP1, p.2-17
Back Panel
I/O, p.2-5
JPW1, p.2-4
CPUFAN1,
p.2-11
JCI1, p.2-10
JFP1, p.2-14
J1, p.2-12
JPWR1, p.2-4
JVDD1, p.2-17
JLVDS1, p.2-16
IDE1, p.2-9
JAMP1, p.2-14
JSPDO1, p.2-15
JLPT1, p.2-13
SATA1~2, p.2-10
JAUD1, p.2-15
JSPI1, p.2-11
COM1~4, p.2-13
JCOMP3~6,
p.2-17
JUSB1, p.2-12
PCI1, p.2-18
2-2
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Memory
The DIMM slots are intended for system memory modules.
DDR2 SO-DIMM Slot
200-pin, 1.8V
Installing Memory Modules
1. Locate the SO-DIMM slots on the mainboard.
2. Align the notch on the DIMM with the key on the slot. Insert the DIMM vertically into
the SO-DIMM slot. Then push it in until the golden finger on the DIMM is deeply
inserted in the SO-DIMM slot.
3. Manually check if the DIMM has been locked in place by the retaining clips at the
sides.
2-3
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Power Supply
System Power Connector: ATX1 (for option A)
This connector allows you to connect a 20-pin power supply. To connect the power
supply, make sure the power supply connector is inserted in the proper orientation
and the pins are aligned. Then push down the power supply firmly into the connector.
Pin Definition
ATX1
20
10
11
1
PIN
SIGNAL
PIN
SIGNAL
1
2
+3.3V
+3.3V
11
12
+3.3V
-12V
3
4
GND
+5V
13
14
GND
PS-ON#
5
6
GND
+5V
15
16
GND
GND
7
8
GND
PWR OK
17
18
GND
Res
9
5VSB
10
+12V
19
20
+5V
+5V
12V System Power Connector: JPW1 (for option B, C, D, E)
This 12V power connector is used to provide power to the system & CPU.
Pin Definition
4
1
JPW1
PIN
SIGNAL
1
2
12V
12V
3
4
GND
GND
5V/12V HDD Power Connector: JPWR1 (for option B, C, D, E)
This connector provides power to the hard disk drives.
Pin Definition
1
4
JPWR1
PIN
SIGNAL
1
5V
2
3
GND
GND
4
12V
2-4
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Back Panel I/O
Option A
COM6
RS-232
Serial Port
Line-In
VGA Port
LAN
Line-Out
LAN
COM5
RS-232/422/485
Serial Port
DVI Port
USB Ports USB Ports
M IC
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
VGA Port
The DB15-pin female connector is provided for monitor.
DVI Port
The DVI (Digital Visual Interface) connector allows you to connect a LCD monitor. It
provides a high-speed digital interconnection between the computer and its display
device. To connect an LCD monitor, simply plug your monitor cable into the DVI
connector, and make sure that the other end of the cable is properly connected to
your monitor (refer to your monitor manual for more information.)
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
2-5
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
Activity Indicator
Left LED
LED Color
10M Cable Plug-in
100M Cable Plug-in
1000M Cable Plug-in
Speed Indicator
Right LED
Active LED
100M/1000M Speed LED
Yellow
Green/Orange
No Transmission
Slow Blinking
OFF
Transition
Swiftly Blinking
OFF
No Transmission
Slow Blinking
Green(Lighting)
Transition
Swiftly Blinking
Green(Lighting)
No Transmission
Slow Blinking
Orange(Lighting)
Transition
Swiftly Blinking
Orange(Lighting)
Green (Lighting)
OFF
In S3/S4/S5 Standby State
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Line-In (Blue) - Line In, is used for external CD player, tapeplayer or other
audio devices.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
2-6
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Line-Out
Option B
COM5
RS-232/422/485
Serial Port
LAN
DVI Port
USB Ports USB Ports
M IC
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
DVI Port
The DVI (Digital Visual Interface) connector allows you to connect a LCD monitor. It
provides a high-speed digital interconnection between the computer and its display
device. To connect an LCD monitor, simply plug your monitor cable into the DVI
connector, and make sure that the other end of the cable is properly connected to
your monitor (refer to your monitor manual for more information.)
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
LED Color
10M Cable Plug-in
100M Cable Plug-in
1000M Cable Plug-in
Activity Indicator
Speed Indicator
Left LED
Right LED
Active LED
100M/1000M Speed LED
Yellow
Green/Orange
No Transmission
Slow Blinking
OFF
Transition
Swiftly Blinking
OFF
No Transmission
Slow Blinking
Green(Lighting)
Transition
Swiftly Blinking
Green(Lighting)
No Transmission
Slow Blinking
Orange(Lighting)
Transition
Swiftly Blinking
Orange(Lighting)
Green (Lighting)
OFF
In S3/S4/S5 Standby State
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
2-7
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Option C
Line-Out
LAN
COM5
RS-232/422/485
Serial Port
VGA Port
USB Ports USB Ports
M IC
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
VGA Port
The DB15-pin female connector is provided for monitor.
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
Activity Indicator
Left LED
LED Color
10M Cable Plug-in
100M Cable Plug-in
1000M Cable Plug-in
Speed Indicator
Right LED
Active LED
100M/1000M Speed LED
Yellow
Green/Orange
No Transmission
Slow Blinking
OFF
Transition
Swiftly Blinking
OFF
No Transmission
Slow Blinking
Green(Lighting)
Transition
Swiftly Blinking
Green(Lighting)
No Transmission
Slow Blinking
Orange(Lighting)
Transition
Swiftly Blinking
Orange(Lighting)
Green (Lighting)
OFF
In S3/S4/S5 Standby State
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
2-8
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
VGA Port
Line-Out
Option D
COM5
RS-232/422/485
Serial Port
LAN
DVI Port
USB Ports USB Ports
M IC
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
VGA Port
The DB15-pin female connector is provided for monitor.
DVI Port
The DVI (Digital Visual Interface) connector allows you to connect a LCD monitor. It
provides a high-speed digital interconnection between the computer and its display
device. To connect an LCD monitor, simply plug your monitor cable into the DVI
connector, and make sure that the other end of the cable is properly connected to
your monitor (refer to your monitor manual for more information.)
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
Activity Indicator
Left LED
LED Color
10M Cable Plug-in
100M Cable Plug-in
1000M Cable Plug-in
Speed Indicator
Right LED
Active LED
100M/1000M Speed LED
Yellow
Green/Orange
No Transmission
Slow Blinking
OFF
Transition
Swiftly Blinking
OFF
No Transmission
Slow Blinking
Green(Lighting)
Transition
Swiftly Blinking
Green(Lighting)
No Transmission
Slow Blinking
Orange(Lighting)
Transition
Swiftly Blinking
Orange(Lighting)
Green (Lighting)
OFF
In S3/S4/S5 Standby State
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
2-9
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
LAN
Option E
Line-Out
LAN
COM5
RS-232/422/485
Serial Port
VGA Port
USB Ports USB Ports
M IC
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16
bytes FIFOs. You can attach a serial mouse or other serial devices directly to the
connector.
VGA Port
The DB15-pin female connector is provided for monitor.
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard,
mouse, or other USB-compatible devices.
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN).
You can connect a network cable to it.
100M Cable Plug-in
1000M Cable Plug-in
Speed Indicator
Left LED
Right LED
Active LED
100M/1000M Speed LED
Yellow
Green/Orange
No Transmission
Slow Blinking
OFF
Transition
Swiftly Blinking
OFF
No Transmission
Slow Blinking
Green(Lighting)
Transition
Swiftly Blinking
Green(Lighting)
No Transmission
Slow Blinking
Orange(Lighting)
Transition
Swiftly Blinking
Orange(Lighting)
Green (Lighting)
OFF
LED Color
10M Cable Plug-in
Activity Indicator
In S3/S4/S5 Standby State
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
2-10
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Connector
IDE Connector: IDE1
This connector supports IDE hard disk drives, optical disk drives and other IDE devices.
IDE1
Important
If you install two IDE devices on the same cable, you must configure the drives
separately to master / slave mode by setting jumpers. Refer to IDE device’s
documentation supplied by the vendors for jumper setting instructions.
2-11
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Chassis Intrusion Connector: JCI1
This connector connects to the chassis intrusion switch cable. If the chassis is
opened, the chassis intrusion mechanism will be activated. The system will record
this status and show a warning message on the screen. To clear the warning, you
must enter the BIOS utility and clear the record.
GND
CINTRU
1
2
JCI1
Serial ATA Connector: SATA1, SATA2
This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device.
SATA1
SATA2
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise,
data loss may occur during transmission.
2-12
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
SPI Flash ROM Pinheader: JSPI1
This pinheader is used to flash SPI flash ROM.
Pin Definition
JSPI1
2
1
10
9
Pin
Description
Pin
Description
1
VCC3_SB
2
VCC3_SB
3
SPI_MISO_F
4
SPI_MOSI_F
5
SPI_CS0_F#
6
SPI_CLK_F
7
GND
8
GND
9
SPI_HOLD#
10
NC
Fan Power Connector: CPUFAN1
The fan power connector supports system cooling fan with +12V. W hen connecting
the wire to the connectors, always note that the red wire is the positive and should
be connected to the +12V; the black wire is Ground and should be connected to GND.
If the mainboard has a System Hardware Monitor chipset onboard, you must use a
specially designed fan with speed sensor to take advantage of the CPU fan control.
GND
+1 2V
SENSOR
CONTROL
CPUFAN1
Important
Please refer to the recommended CPU fans at CPU vendor’s official website
or consult the mainboard vendor for proper CPU cooling fan.
2-13
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Backlight Connector: J1 (for option C, E)
This connector is provided for LCD backlight options.
J1
Pin Definition
1
PIN
SIGNAL
1
12V
2
3
GND
Inverter On
4
5
Backlight Control
5V
Front USB Pinheader: JUSB1
This pinheader, compliant with Intel® I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras,
M P3 players, printers, modems and the like.
Pin Definition
JUSB1
2
1
10
9
PIN
SIGNAL
PIN
SIGNAL
1
VCC
2
VCC
3
USB0-
4
USB1-
5
USB0+
6
USB1+
7
GND
8
GND
9
Key (no pin)
10
USBOC
USB 2.0 Bracket
(Optional)
Important
Note that the pins of VCC and GND must be connected correctly to avoid
possible damage.
2-14
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Serial Port Connector: COM1 ~ COM4 (for option A, B, C, E)
This connector is a 16550A high speed communications port that sends/receives 16
bytes FIFOs. You can attach a serial device to it through the optional serial port
bracket.
Pin Definition
COM1~4
1
2
9
10
PIN
1
2
3
4
5
6
7
8
9
SIGNAL
DESCRIPTION
DCD
SIN
SOUT
DTR
GND
DSR
RTS
CTS
VCC_COM
Data Carry Detect
Serial In or Receive Data
Serial Out or Transmit Data
Data Terminal Ready
Ground
Data Set Ready
Request To Send
Clear To Send
Power Source
Parallel Port Header: JLPT1
The mainboard provides a 26-pin header for connection to an optional parallel port
bracket. The parallel port is a standard printer port that supports Enhanced Parallel
Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.
JLPT1
26
2
25
1
PIN
SIGNAL
PIN
SIGNAL
PIN
SIGNAL
PIN
SIGNAL
1
RSTB#
2
AFD#
15
PRND6
16
GND
3
5
PRND0
PRND1
4
6
ERR#
PINIT#
17
19
PRND7
ACK#
18
20
GND
GND
7
9
PRND2
PRND3
8
10
LPT_SLIN#
GND
21
23
BUSY
PE
22
24
GND
GND
11
13
PRND4
PRND5
12
14
GND
GND
25
SLCT
26
KEY
2-15
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Audio Amplifier Connector: JAMP1 (for option C, E)
The JAMP1 is used to connect audio amplifiers to enhance audio performance.
Pin Definition
JAM P1
1
PIN
SIGNAL
1
AMP_L-
2
AMP_L+
3
4
AMP_RAMP_R+
Front Panel Connector: JFP1
The mainboard provides one front panel connector for electrical connection to the
front panel switches and LEDs. The JFP1 is compliant with Intel® Front Panel I/O
Connectivity Design Guide.
JFP1
HDD +
LED Reset Switch +
1
2
9
10
Power
LED
- Power
+ Switch
Pin Definition
PIN
SIGNAL
DESCRIPTION
1
HD_LED +
Hard disk LED pull-up
2
3
FP PWR/SLP
HD_LED -
MSG LED pull-up
Hard disk active LED
4
5
FP PWR/SLP
RST_SW -
MSG LED pull-up
Reset Switch low reference pull-down to GND
6
7
PWR_SW RST_SW +
Power Switch low reference pull-down to GND
Reset Switch high reference pull-up
8
9
PWR_SW+
RSVD_DNU
Power Switch high reference pull-up
Reserved. Do not use.
2-16
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
S/PDIF-Out Connector: JSPDO1
This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format)
interface for digital audio transmission.
JSPDO1
VCC
GND
SPDIF
S/PDIF Bracket (Optional)
Front Panel Audio Connector: JAUD1
This connector allows you to connect the front panel audio and is compliant with
Intel® Front Panel I/O Connectivity Design Guide.
JAUD1
2
1
10
9
HD Audio Pin Definition
PIN
SIGNAL
DESCRIPTION
1
2
MIC_L
GND
Microphone - Left channel
Ground
3
4
MIC_R
PRESENCE#
Microphone - Right channel
Active low signal-signals BIOS that a High Definition Audio dongle
is connected to the analog header. PRESENCE# = 0 when a
High Definition Audio dongle is connected
5
6
LINE out_R
MIC_JD
Analog Port - Right channel
Jack detection return from front panel microphone JACK1
7
Front_JD
Jack detection sense line from the High Definition Audio CODEC
jack detection resistor network
8
9
NC
LINE out_L
No control
Analog Port - Left channel
10
LINEout_JD
Jack detection return from front panel JACK2
2-17
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
LVDS Flat Panel Connector: JLVDS1 (for option C, E)
The LVDS (Low Voltage Differential Signal) connector provides a digital interface
typically used with flat panels. After connecting an LVDS interfaced flat panel to the
JLVDS1, be sure to check the panel datasheet and set the JVDD1 LVDS Power
Selection Jumper (p. 2-17) to a proper voltage.
JLVDS1
1
39
2
40
SIGNAL
PIN
SIGNAL
+12V
2
1
+12V
+12V
4
3
+12V
GND
6
5
+12V
GND
8
7
VCC3/VCC5
LCD_VDD
10
9
LCD_VDD
LDDC_DATA
12
11
LDDC_CLK
LVDS_VDDEN
14
13
L_BKLTCTL
GND
16
15
L_BKLTEN
LA_DATA0
18
17
LA_DATA0#
LA_DATA1
20
19
LA_DATA1#
LA_DATA2
22
21
LA_DATA2#
LA_CLK
24
23
LA_CLK#
LA_DATA3
26
25
LA_DATA3#
GND
28
27
GND
LB_DATA0
30
29
LB_DATA0#
LB_DATA1
32
31
LB_DATA1#
LB_DATA2
34
33
LB_DATA2#
LB_CLK
36
35
LB_CLK#
LB_DATA3
38
37
LB_DATA3#
GND
40
39
GND
2-18
PDF created with pdfFactory Pro trial version www.pdffactory.com
Hardware Setup
Jumper
LVDS Power Selection Jumper: JVDD1 (for option C, E)
Use this jumper to specify the operation voltage of the LVDS interfaced flat panel.
1
JVDD1
1
1
1
+5V
+3.3V
+12V
COM Port Power Jumper: JCOMP2 (for option A),
JCOMP1, JCOMP3~6 (for option A, B, C, E)
These jumpers specify the operation voltage of the onboard serial ports.
1
JCOMP3~6
(for COM1~4)
1
1
+5V
+12V
1
JCOMP1
(for COM5)
JCOMP2
(for COM6)
1
+5V
1
+12V
2-19
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Slot
PCI (Peripheral Component Interconnect) Express Slot
The CON1 is Mini PCI-E connector for wireless LAN, TV tuner, and Robson NAND
Flash.
Mini PCI-E Slot
PCI (Peripheral Component Interconnect) Slot
The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that
comply with PCI specifications.
32-bit PCI Slot
Important
When adding or removing expansion cards, make sure that you unplug the
power supply first. Meanwhile, read the documentation for the expansion
card to configure any necessary hardware or software settings for the expansion card, such as jumpers, switches or BIOS configuration.
2-20
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Chapter 3
BIOS Setup
This chapter provides information on the BIOS Setup
program and allows you to configure the system for
optimum use.
You may need to run the Setup program when:
² An error message appears on the screen during the
system booting up, and requests you to run SETUP.
² You want to change the default settings for customized features.
3-1
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Entering Setup
Power on the computer and the system will start POST (Power On Self Test) process.
W hen the message below appears on the screen, press <Del> key to enter Setup.
Press Del to enter SETUP
If the message disappears before you respond and you still wish to enter Setup,
restart the system by turning it OFF and On or pressing the RESET button. You may
also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys.
Important
1. The items under each BIOS category described in this chapter are under
continuous update for better system performance. Therefore, the description may be slightly different from the latest BIOS and should be held for
reference only.
2. Upon boot-up, the 1st line appearing after the memory count is the BIOS
version. It is usually in the format:
A9830IMS V1.0 102708 where:
1st digit refers to BIOS maker as A = AMI, W = AWARD, and P =
PHOENIX.
2nd - 5th digit refers to the model number.
6th digit refers to the chipset as I = Intel, N = nVidia, A = ATi , K=AMD
and V = VIA.
7th - 8th digit refers to the customer as MS = all standard customers.
V1.0 refers to the BIOS version.
102708 refers to the date this BIOS was released.
3-2
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Control Keys
< ->
Move to the previous item
< ¯>
Move to the next item
< ¬>
Move to the item in the left hand
< ®>
Move to the item in the right hand
<Enter>
Select the item
<Esc>
Jumps to the Exit menu or returns to the main menu from a
submenu
<+/PU>
Increase the numeric value or make changes
<-/PD>
Decrease the numeric value or make changes
<F6>
Load Optimized Defaults
<F7>
Load Fail-Safe Defaults
<F10>
Save all the CMOS changes and exit
Getting Help
After entering the Setup menu, the first menu you will see is the Main Menu.
M ain M enu
The main menu lists the setup functions you can make changes to. You can use the
arrow keys ( -¯ ) to select the item. The on-line description of the highlighted setup
function is displayed at the bottom of the screen.
Sub-M enu
If you find a right pointer symbol (as shown in the right view)
appears to the left of certain fields that means a sub-menu
can be launched from this field. A sub-menu contains additional options for a field parameter. You can use arrow keys ( -¯ ) to highlight the
field and press <Enter> to call up the sub-menu. Then you can use the control keys
to enter values and move from field to field within a sub-menu. If you want to return
to the main menu, just press the <Esc >.
General Help <F1>
The BIOS setup program provides a General Help screen. You can call up this screen
from any menu by simply pressing <F1>. The Help screen lists the appropriate keys
to use and the possible selections for the highlighted item. Press <Esc> to exit the
Help screen.
3-3
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
The Menu Bar
Main
Use this menu for basic system configurations, such as time, date etc.
Advanced
Use this menu to set up the items of special enhanced features.
Boot
Use this menu to specify the priority of boot devices.
Security
Use this menu to set supervisor and user passwords.
Chipset
This menu controls the advanced features of the onboard Northbridge and Southbridge.
Power
Use this menu to specify your settings for power management.
Exit
This menu allows you to load the BIOS default values or factory default settings into
the BIOS and exit the BIOS setup utility with or without changes.
3-4
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Main
BIOS Information, Processor, System M emory
These items show the firmware and hardware specifications of your system. Read
only.
System Time
The time format is <Hour> <Minute> <Second>.
System Date
The date format is <Day>, <Month> <Date> <Year>.
3-5
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Advanced
CPU Configuration
These items show the advanced specifications of your CPU. Read only.
3-6
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Max CPUID Value Limit
The Max CPUID Value Limit BIOS feature allows you to circumvent problems
with older operating systems that do not support the Intel Pentium 4 processor
with Hyper-Threading Technology. W hen enabled, the processor will limit the
maximum CPUID input value to 03h when queried, even if the processor supports a higher CPUID input value. When disabled, the processor will return the
actual maximum CPUID input value of the processor when queried.
Execute Disable Bit Capability
Intel's Execute Disable Bit functionality can prevent certain classes of malicious
"buffer overflow" attacks when combined with a supporting operating system.
This functionality allows the processor to classify areas in memory by where
application code can execute and where it cannot. W hen a malicious worm
attempts to insert code in the buffer, the processor disables code execution,
preventing damage or worm propagation.
Hyper Threading Technology
The processor uses Hyper Threading technology to increase transaction rates
and reduces end-user response times. The technology treats the two cores
inside the processor as two logical processors that can execute instructions
simultaneously. In this way, the system performance is highly improved. If you
disable the function, the processor will use only one core to execute the
instructions. Please disable this item if your operating system doesn’t
support HT Function, or unreliability and instability may occur.
Intel(R) SpeedStep(tm) Tech
EIST (Enhanced Intel SpeedStep Technology) allows the system to dynamically
adjust processor voltage and core frequency, which can result in decreased
average power consumption and decreased average heat production.
3-7
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
IDE Configuration
ATA/IDE Configuration
This setting specifies the operation mode of the onboard ATA/IDE controller.
Legacy IDE Channels
This setting specifies the IDE channels.
Primary/Secondary IDE Master/Slave
3-8
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
[Type]
Press PgUp/<+> or PgDn/<-> to select
[Manual], [None] or [Auto] type. Note that the
specifications of your drive must match with
the drive table. The hard disk will not work
properly if you enter improper information for
this category. If your hard disk drive type is
not matched or listed, you can use [Manual] to
define your own drive type manually.
[LBA/Large Mode]
Enabling LBA causes Logical Block Addressing to be used in place of Cylinders,
Heads and Sectors
[Block(Multi-Sector Transfer)] Any selection except Disabled determines
the number of sectors transferred per block
[PIO Mode]
Indicates the type of PIO (Programmed Input/
Output)
[DMA Mode]
Indicates the type of Ultra DMA
[S.M.A.R.T.]
This allows you to activate the S.M.A.R.T.
(Self-Monitoring Analysis & Reporting
Technology) capability for the hard disks. S.
M.A.R.T is a utility that monitors your disk sta
tus to predict hard disk failure. This gives you
an opportunity to move data from a hard disk
that is going to fail to a safe place before the
hard disk becomes offline.
[32 Bit Data Transfer]
Enables 32-bit communication between
CPU and IDE device
Hard Disk Write Protect
This option allows users to write protect boot sector on hard disk to protect
against viruses.
IDE Detect Time Out (Sec)
This setting allows you to set the time out value for the BIOS to delay the
initialization of IDE devices.
ATA(PI) 80Pin Cable Detection
This BIOS feature allows you to control whether both IDE controller and IDE
device should be allowed to detect the type of IDE cable used.
3-9
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Super IO Configuration
Option A
Option B
3-10
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Option C, E
Option D
Serial Port 1/2/3/4/5/6 Address, Serial Port 1/2/3/4 IRQ
Select an address and a corresponding interrupt for the serial port.
Serial Port5 M ode
This setting specifies the serial port5 mode.
3-11
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Parallel Port Address
Select an address for the parallel port.
Watch Dog
You can enable the system watch-dog timer, a hardware timer that generates
either an NMI or a reset when the software that it monitors does not respond as
expected each time the watch dog polls it.
Hardware Health Configuration
Chassis Intrusion
The field enables or disables the feature of recording the chassis intrusion
status and issuing a warning message if the chassis is once opened. To clear
the warning message, set the field to [Reset]. The setting of the field will
automatically return to [Enabled] later.
CPU Temperature, System Temperature, Sy stem Speed, VCORE,
5VSB, VCC5, 12V, VBAT
These items display the current status of all of the monitored hardware devices/components such as CPU voltage, temperatures and all fans’ speeds.
System Fan Pin Select
This setting specifies the pin numbers of the system fan power connector.
System Fan Mode Setting
This setting controls the Smart Fan feature. Smart Fan is an excellent feature
which will adjust the CPU/system fan speed automatically depending on the
current CPU temperature to prevent your CPU from overheating.
3-12
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Temperature Limit of Highest, Temperature Limit of Second
You can select a temperature tolerance value here for the specific range of
the Smart Fan function.
ACPI Settings
General ACPI Configuration
Suspend M ode
This item specifies the power saving modes for ACPI function. If your oper-
3-13
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
ating system supports ACPI, such as W indows 98SE, W indows ME and
W indows 2000, you can choose to enter the Standby mode in S1 (POS) or
S3 (STR) fashion through the setting of this field.
USB Device Wakeup From S3
The item allows the activity of the USB device to wake up the system from
S3 (Suspend to RAM) sleep state.
Advanced ACPI Configuration
ACPI Version Features
This setting allows you to select the ACPI version.
ACPI APIC Support
This BIOS feature is used to enable or disable the motherboard's APIC (Advanced
Programmable Interrupt Controller). The APIC provides multiprocessor support,
more IRQs and faster interrupt handling.
3-14
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
USB Configuration
Legacy USB Support
Set to [Enabled] if your need to use any USB device in the operating system that
does not support or have any USB driver installed, such as DOS and SCO Unix.
Set to [Disabled] only if you want to use any USB device other than the USB
mouse.
BIOS EHCI Hand-Off
This setting allows you to enable or disable a workaround for operating systems without EHCI (Enhanced Host Controller Interface) hand-off support. The
Enhanced Host Controller Interface (EHCI) specification describes the registerlevel interface for a Host Controller for the Universal Serial Bus (USB) Revision
2.0.
3-15
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
USB Mass Storage Device Configuration
USB Mass Storage Reset Delay
This setting controls the number of seconds the POST waits for the USB
mass storage device after the start unit command is sent.
Emulation Type
This setting enables you to set the type of device you want the USB mass
storage device to emulate.
3-16
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Boot
Boot Settings Configuration
3-17
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Quick Boot
Enabling this setting will cause the BIOS power-on self test routine to skip some
of its tests during bootup for faster system boot.
Quiet Boot
This BIOS feature determines if the BIOS should hide the normal POST messages with the motherboard or system manufacturer's full-screen logo.
W hen it is enabled, the BIOS will display the full-screen logo during the boot-up
sequence, hiding normal POST messages.
When it is disabled, the BIOS will display the normal POST messages, instead of
the full-screen logo.
Please note that enabling this BIOS feature often adds 2-3 seconds of delay to
the booting sequence. This delay ensures that the logo is displayed for a
sufficient amount of time. Therefore, it is recommended that you disable this
BIOS feature for a faster boot-up time.
Bootup Num-Lock
This setting is to set the Num Lock status when the system is powered on.
Setting to [On] will turn on the Num Lock key when the system is powered on.
Setting to [Off] will allow users to use the arrow keys on the numeric keypad.
Wait For ‘F1’ If Error
W hen this setting is set to [Enabled] and the boot sequence encounters an
error, it asks you to press F1. If disabled, the system continues to boot without
waiting for you to press any keys.
Flash Write Protection
This function protects the BIOS from accidental corruption by unauthorized
users or computer viruses.
Boot Device Priority, Removable Drives
The items allow you to set the sequence of boot devices/removable drives. First
press <Enter> to enter the sub-menu. Then you may use the arrow keys ( -¯ ) to
select the desired device, then press <+>, <-> or <PageUp>, <PageDown> key to
move it up/down in the priority list.
3-18
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Security
Supervisor Password / Change Supervisor Password
Supervisor Password controls access to the BIOS Setup utility. These settings allow
you to set or change the supervisor password.
User Password / Change User Password
User Password controls access to the system at boot. These settings allow you to
set or change the user password.
Boot Sector Virus Protection
This function protects the BIOS from accidental corruption by unauthorized users or
computer viruses. W hen enabled, the BIOS’ data cannot be changed when attempting to update the BIOS with a Flash utility. To successfully update the BIOS, you’ll
need to disable this Flash BIOS Protection function.
You should enable this function at all times. The only time when you need to disable
it is when you want to update the BIOS. After updating the BIOS, you should immediately re-enable it to protect it against viruses.
3-19
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Chipset
North Bridge Configuration
3-20
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Configure DRAM Timing by SPD
Selects whether DRAM timing is controlled by the SPD (Serial Presence Detect)
EEPROM on the DRAM module. Setting to [Auto By SPD] enables DRAM timings
and the following related items to be determined by BIOS based on the configurations on the SPD. Selecting [Manual] allows users to configure the DRAM
timings and the following related items manually.
Boot Graphics Adapter Priority
This item specifies which VGA card is your primary graphics adapter.
Internal Graphics M ode Select
The field specifies the size of system memory allocated for video memory.
3-21
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Video Function Configuration
Option A, D
Option B
3-22
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Option C, E
DVMT Mode Select
Intel's Dynamic Video Memory Technology (DVMT) allows the system to dynamically allocate memory resources according to the demands of the system at any point in time. The key idea in DVMT is to improve the efficiency of
the memory allocated to either system or graphics processor.
It is recommended that you set this BIOS feature to DVMT Mode for maximum
performance. Setting it to DVMT Mode ensures that system memory is dynamically allocated for optimal balance between graphics and system
performance.
Boot Display Device
Use the field to select the type of device you want to use as the display(s)
of the system.
Flat Panel Type
Use the field to select the resolution of the flat panel display.
3-23
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
South Bridge Configuration
USB Functions
This setting specifies the function of the onboard USB controller.
USB 2.0 Controller, Audio Controller, PRO-NIC Controller, SM BUS
Controller
These settings enable/disable the specified onboard controllers.
3-24
PDF created with pdfFactory Pro trial version www.pdffactory.com
BIOS Setup
Power
Restore on AC Power Loss
This setting specifies whether your system will reboot after a power failure or
interrupt occurs. Available settings are:
[Power Off]
Leaves the computer in the power off state.
[Power On]
Leaves the computer in the power on state.
[Last State]
Restores the system to the previous status before power
failure or interrupt occurred.
Resume On LAN
This field specifies whether the system will be awakened from power saving modes
when activity or input signal of onboard LAN is detected.
Resume On PME#
W hen setting to [Enabled], this setting allows your system to be awakened from the
power saving modes through any event on PME (Power Management Event).
Resume On RTC Alarm
W hen [Enabled], your can set the date and time at which the RTC (real-time clock)
alarm awakens the system from Suspend mode.
3-25
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Exit
Save Changes and Exit
Save changes to CMOS and exit the Setup Utility.
Discard Changes and Exit
Abandon all changes and exit the Setup Utility.
Discard Changes
Abandon all changes and continue with the Setup Utility.
Load Optimal Defaults
Use this menu to load the default values set by the mainboard manufacturer specifically for optimal performance of the mainboard.
Load Failsafe Defaults
Use this menu to load the default values set by the BIOS vendor for stable system
performance.
3-26
PDF created with pdfFactory Pro trial version www.pdffactory.com
Sy stem Resources
Chapter 4
System Resources
This chapter provides information on the following
system resources:
1. W atch Dog Timer Setting (p.4-2);
2. AMI POST Code (p.4-3);
3. Resource List (p.4-7).
4-1
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Watch Dog Timer Setting
Software Code
SIO_IDX equ 4EH
SIO_DTAequ 4FH
Timer equ 10; reset after 10 seconds
1. Enter configuration
Mov
mov
out
out
2. Set to LDN 07
Mov
mov
out
mov
mov
out
mode
dx, SIO_IDX
al, 87h
dx, al
dx, al
dx, SIO_IDX
al, 07h
dx, al
dx, SIO_DTA
al, 07h
dx, al
3. Set W atchDog Timer
Mov
dx, SIO_IDX
mov
al, 0f6h
out
dx, al
mov
dx, SIO_DTA
mov
al, Timer
out
dx, al
4. Exit configuration mode
Mov
dx, SIO_IDX
mov
al, 0AAh
out
dx, al
4-2
PDF created with pdfFactory Pro trial version www.pdffactory.com
Sy stem Resources
AMI POST Code
Bootblock Recovery Code Checkpoints
The Bootblock recovery code gets control when the BIOS determines that a BIOS
recovery needs to occur because the user has forced the update or the BIOS
checksum is corrupt. The following table describes the type of checkpoints that may
occur during the Bootblock recovery portion of the BIOS:
4-3
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
POST Code Checkpoints
The POST code checkpoints are the largest set of checkpoints during the BIOS preboot process. The following table describes the type of checkpoints that may occur
during the POST portion of the BIOS:
4-4
PDF created with pdfFactory Pro trial version www.pdffactory.com
Sy stem Resources
4-5
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
4-6
PDF created with pdfFactory Pro trial version www.pdffactory.com
Sy stem Resources
Resource List
ICH7M GPIO
Power
Connect
BM_BUSY#
VCC3
PM_BMBUSY#
I/O
REQ[5]#
VCC5
PREQ#5
I/OD
PIRQE#
VCC5
VCC3
I/OD
PIRQF#
VCC5
VCC3
I/OD
PIRQG#
VCC5
VCC3
GPIO5
I/OD
PIRQH#
VCC5
VCC3
AC21
GPIO6
I/O
Unmultiplexed
VCC3
ATADET0
AC18
GPIO7
I/O
Unmultiplexed
VCC3
SIO_OVT#
E21
GPIO8
I/O
Unmultiplexed
3VSB
3VSB
E20
GPIO9
I/O
Unmultiplexed
3VSB
3VSB
A20
GPIO10
I/O
Unmultiplexed
3VSB
3VSB
B23
GPIO11
I/O
SMBALERT#
3VSB
SMBALERT#
Pin
GPIO
Type
AB18
GPIO0
I/O
C8
GPIO1
G8
GPIO2
F7
GPIO3
F8
GPIO4
G7
Multiplexed with
F19
GPIO12
I/O
Unmultiplexed
3VSB
SPI_HOLD_GPO#
E19
GPIO13
I/O
Unmultiplexed
3VSB
SIO_PME#
R4
GPIO14
I/O
Unmultiplexed
3VSB
3VSB
E22
GPIO15
I/O
Unmultiplexed
3VSB
3VSB
AC22
GPIO16
I/O
DPRSLPVR
VCC3
DPRSLPVR
D8
GPIO17
I/O
GNT5#
VCC3
PGNT#5
AC20
GPIO18
I/O
STPPCI#
VCC3
PM_STPPCI#
AH18
GPIO19
I/O
SATA1GP
VCC3
SATA1GP
AF21
GPIO20
I/O
STPCPU#
VCC3
PM_STPCPU#
AF19
GPIO21
I/O
SATA0GP
VCC3
SATA0GP
A13
GPIO22
I/O
REQ4#
VCC3
PREQ#4
AA51
GPIO23
I/O
LDRQ1#
VCC3
NC
B3
GPIO24
I/O
Unmultiplexed
3VSB
BIOS_WP#
D20
GPIO25
I/O
Unmultiplexed
3VSB
NC
A21
GPIO26
I/O
Unmultiplexed
3VSB
NC
B12
GPIO27
I/O
Unmultiplexed
3VSB
DISABLE_LAN1
E23
GPIO28
I/O
Unmultiplexed
3VSB
DISABLE_LAN2
C3
GPIO29
I/O
OC5#
3VSB
3VSB
4-7
PDF created with pdfFactory Pro trial version www.pdffactory.com
M S-9830 M ainboard
Pin
GPIO
Type
A2
GPIO30
I/O
B3
GPIO31
I/O
AG18
GPIO32
I/O
AC19
GPIO33
U2
GPIO34
AD21
Multiplexed with
Power
Connect
OC6#
3VSB
3VSB
OC7#
3VSB
3VSB
CLKRUN#
VCC3
CLKRUN#
I/O
AZ_DOCK_EN#
VCC3
PRES2
I/O
AZ_DOCK_RST#
VCC3
PRES3
GPIO35
I/O
SATACLKREQ#
VCC3
PRES1
AH19
GPIO36
I/O
SATA2GP
VCC3
SATA2GP
SATA3GP
AE19
GPIO37
I/O
SATA3GP
VCC3
AD20
GPIO38
I/O
Unmultiplexed
VCC3
NC
AE20
GPIO39
I/O
Unmultiplexed
VCC3
WLAN_PWRON
A14
GPIO48
I/O
GNT4#
VCC3
PGNT#4
AG24
GPIO49
I/O
CPUPERGD
VTT
CPU_PWRGD
4-8
PDF created with pdfFactory Pro trial version www.pdffactory.com
Sy stem Resources
SIO GPIO
Pin
GPIO
Multi
Type
Power
Default
Connection
49
GPIO0
I/OOD
VIDOUT0
VSB
VIDOUT0
NC
50
GPIO1
I/OOD
VIDOUT1
VSB
VIDOUT1
NC
51
GPIO2
I/OOD
VIDOUT2
VSB
VIDOUT2
NC
52
GPIO3
I/OOD
VIDOUT3
VSB
VIDOUT3
NC
53
GPIO4
I/OOD
VIDOUT4
VSB
VIDOUT4
NC
54
GPIO5
I/OOD
VIDOUT5 / SIC
VSB
VIDOUT5
NC
55
GPIO6
I/OOD
SLOTOCC#
VSB
SLOTOCC#
SKTOCC#
56
GPIO7
I/OOD
Turbo1#/ WDTRST#
VSB
GPI
WDT#
59
GPIO10
I/OOD
SPI_SLK/FANIN4
VSB
GPI
EN232
60
GPIO11
I/OOD
SPI_CS0#/ FANCTL4
VSB
GPI
#EN485
61
GPIO12
I/OOD
VSB
GPI
#EN422
62
GPIO13
I/OOD
VSB
GPI
BEEP
VSB
GPI
AMP_EN
SPI_MISO/
FANCTL1_1
SPI_MOSI/ BEEP
FWH_DIS/WDTRST#/
63
GPIO14
I/OOD
64
GPIO15
I/OOD
LED_VSB/ ALERT#
VSB
GPI
LED_VSB
65
GPIO16
I/OOD
LED_VCC/ Turbo2#
VSB
GPI
LED_VCC
66
GPIO17
I/OOD
Unmultiplexed
VSB
GPI
FAN_12V_SET#
74
GPIO20
I/OOD
PCIRST1#
VSB
PCIRST1#
PLTRST_BU#1
75
GPIO21
I/OOD
PCIRST2#
VSB
PCIRST2#
PLTRST_BU#2
76
GPIO22
I/OOD
PCIRST3#
VSB
PCIRST3#
PLTRST_BU#3
77
GPIO23
I/OOD
RSTCON#
VSB
GPIO
NC
78
GPIO24
I/OOD
ATXPG_IN
VSB
ATXPG_IN
ATX_PWR_OK
79
GPIO25
I/OOD
PME#
VSB
PME#
SIO_PME#
80
GPIO26
I/OOD
PWSIN#
VSB
PWSIN#
PSIN
81
GPIO27
I/OOD
PWSOUT#
VSB
PWSOUT#
PSOUT#
82
GPIO30
I/OOD
S3#
VSB
S3#
SLP_S3#
83
GPIO31
I/OOD
PSON#
VSB
PSON#
PS_ON#
84
GPIO32
I/OOD
PWROK
VSB
PWROK
NC
85
GPIO33
I/OOD
RSMRST#
VBAT
RSMRST#
RSMRST#
25
GPIO40
I/OOD
FANIN3
VCC
FANIN3
AMP_GAIN0
26
GPIO41
I/OOD
FAN_CTL3
VCC
FAN_CTL3
SYS_FANOUT1
27
GPIO42
I/OOD
IRTX
VCC
IRTX
NC
28
GPIO43
I/OOD
IRRX
VSB
IRRX
AMP_GAIN1
SPI_CS1#
4-9
PDF created with pdfFactory Pro trial version www.pdffactory.com
