Canon VBCollector Specifications

NETWORK
VIDEO
SOLUTIONS
Network Cameras with Built-in Servers
VB-C50i / VB-C50iR / VB-C50Fi/ VB-C50FSi
Analog PTZ Cameras
VC-C50i / VC-C50iR
Network Camera Server
VB150
Network Video Recording Software
VK-64 Ver. 1.1/ VK-16 Ver. 1.1
Monitoring Software
WebView Livescope MV Ver. 2.1
WebView Livescope MV Ver. 2.1 LE
Viewer for Pocket PC
Canon WebView Livescope:
You owe it to your business to find out m
What is
Network Video
Solutions?
Transmit
Network Video Solutions is simply the transmission of high-quality video images through the
Internet or a LAN connection. This may involve
an individual viewing scenes from multiple
locations, many individuals viewing a single
location or a combination of the two.
Record
Anything that’s transmitted can be recorded and
stored to be viewed again at any time, a crucial
factor in safety and security applications.
Why is
Canon superior?
Over 60 Years of Excellence
With over 60 years of industry-leading experience
and a host of groundbreaking technical innovations
to its credit, Canon richly deserves its reputation
as maker of the world’s most advanced cameras
and photographic equipment.
Share
Network Video Solutions can accommodate
multiple viewers and multiple image locations,
linking people in a way no other technology
can offer.
Internet
Legendary Optics
Canon lenses are the choice of professional
photographers all over the world. They feature
proprietary technology
that delivers sharp
resolution, high color
fidelity, crisp, fast
focus and powerful,
seamless zooming.
High-resolution Images
Each camera features a CCD sensor built to
Canon’s exacting specifications, ensuring
high-resolution images in a variety of motion
patterns and lighting conditions.
Close the Distance
Network Video Solutions literally puts you
and/or the information you wish to broadcast
in several places at once. When physical
distance ceases to be a barrier, the possibilities
are limitless.
Flexibility
Canon systems make installation, configuration
and maintenance easy, so you’ll be up and
running quickly and worry-free.
Ethernet
(10/100Mbps)
Save
Putting Canon’s Network Video
Solutions to work for you will boost
the productivity of your business
immediately, for cost and time
savings that go straight to
your bottom line.
Ultimate Performance and Reliability
Canon’s excellent reputation is a direct result
of the high performance and reliability of its
products. Canon’s Network Video Solutions is
designed to perform long term in demanding
situations with minimal maintenance.
One-stop Solution
From network-ready cameras to servers to
software, Canon offers a complete, fully
integrated system that’s ready to go to work.
A Name You Can Trust
Canon is a solid industry leader, earning the
trust of millions for
over 60 years. We
are fully committed
to the needs of our
customers today,
tomorrow and well
into the future.
2
CANON
more.
SYSTEM
How can
NETWORK CAMERAS WITH
B U I LT - I N S E R V E R S
the system work
for you?
Medical Facility
Monitor multiple locations to provide the
highest quality care and security in facilities
where quick reactions are essential.
Teleconferencing
Conduct high-quality meetings with colleagues
and clients all over the world for unmatched
convenience and
substantial cost
savings.
Retail Store
Strategically located cameras can dramatically
improve security and allow employees to
provide more prompt customer service.
VB-C50i
VB-C50iR
VB-C50Fi
VB-C50FSi
A N A LO G PT Z C A M E R A S
VC-C50i
Distance Learning
Broadcast lectures and classroom sessions to
remote students. WebView’s crisp images and
superior camera control make students feel as
if they’re in the
room.
VC-C50iR
NETWORK CAMERA SERVER
VB150
Construction Site
Oversee security, safety practices and project
status wherever you are. Ideal for client
presentations as well.
SOFTWARE
Tourism
Promote destinations and attractions with live
views available to prospective visitors anywhere
in the world.
Museum or Gallery
Constant surveillance in multiple locations
can reduce staffing requirements and give
you greater peace of mind.
Traffic Reports
Newsrooms can monitor key sites to give
accurate, real-time traffic reports.
Network Video
Recording Software
VK-64 Ver. 1.1/
VK-16 Ver. 1.1
WebView Livescope
MV Ver. 2.1
WebView Livescope
MV Ver. 2.1 LE
Viewer for
Pocket PC
Viewer for Java
Viewer for PC
3
NETWORK CAMERAS WITH BUILT-IN SERVERS
The VB-C50 series boasts high-quality images
and a high frame rate. They respond to all of
your monitoring needs with a wide array of
features such as the 26x optical zoom, the most
powerful in the industry, motion detection and
low-light features.
Nomenclature
Compatible viewers
*3
*2
*1
Viewer for
Pocket PC
Free Viewer
Software
*1, *2, *3 Some features cannot be operated.
VB-C50i
VB-C50iR
VB-C50FSi
VB-C50Fi
Rear View of VB-C50iR
Rear View of VB-C50FSi
Rear View of VB-C50i
Rear View of VB-C50Fi
NETWORK CAMERA
VB-C50 Series
DC In Terminal Multi-terminal Input
Ethernet (10/100Mbps Automatic Switching)
PoE (10/100Mbps Automatic Switching)
<Item code: 9781A008>
<Item code: 9782A007>
<Item code: 0220B002>
<Item code: 0777B002>
Features common to the VB-C50 Series
Sample System Configurations
LAN/WAN/Internet Environment
VB-C50FSi
26x Optical Zoom/12x Digital Zoom
1x
(wide-angle end)
The camera’s genuine Canon
26x optical zoom lens offers
the highest optical zoom
magnification in the industry,
making these network cameras
the perfect choice for monitoring
large facilities.
30 fps Image Capture
Shade Correction
You’ll capture and transmit clear, well-focused video with
excellent image quality: 30 fps, 640 x 480 pixels. Viewers
with slower connections or video-enabled cell phones may
not want or be able to receive the camera’s highest-quality
video, given its larger file size. For customization and
flexibility, the camera simultaneously broadcasts in 3 file
sizes from which the viewer can select. The system can
accommodate up to 50 clients.
The Shade Correction feature increases the brightness of
only the shaded areas, leaving lighter areas untouched.
VB-C50i
VB-C50Fi
VB-C50iR
VB-EX50
Microphone
Speaker
Microphone
IP Network
Speaker
Bundled Software Speaker
PC Viewer
Bundled Software
Administrator Viewer
Network Video Recorder VK-64
Recording/Monitoring
Internet Service Provider Environment
Original
captured image
VB-C50Fi
Router
Web Server
Viewer PC
Viewer PC
Backlight Compensation
Shade Correction
VB-C50iR
Schedule-setting Tool
4x
26x (maximum zoom)
Sophisticated Motion Detection
Four areas can be selected for motion detection with the
ability to set sensitivity, area ratio and duration of detected
movement. These settings can be independently set in each
of the four areas.
Excellent Low-light Performance
The camera will capture clear color images in dim lighting all
the way down to a single lux thanks to a highly-sensitive
CCD, bright lens and slow shutter capability. Images are
further enhanced with automatic noise reduction in both
bright and dim light.
The schedule-setting tool automatically provides image
storage, motion detection, or input/output services with
external devices such as an alarm on specified days or
times. Various settings are possible, allowing the numerous
features to be fully utilized.
VB-C50FSi
Router
Broadband
Line, etc.
Internet
Router
Viewer PC
VB-C50 Series Option
Multi-terminal VB-EX50
<Item code: 9783A003>
The optional VB-EX50 greatly expands the camera's flexiblity. An
audio out terminal allows you to connect an external speaker. You
can plug in an existing analog camera or output a signal directly to
a monitor. External devices, such as door sensors and alarms,
can also be connected.
Audio data cannot be input/output on the VB-C50Fi.
Audio/IN
(Microphone)
Video/OUT
(BNC Terminal)
Contact/IN x 2
Audio/OUT
Speaker
Video/IN
(BNC Terminal)
Monitor and Control via a Mobile
Phone
Static images can be viewed and cameras
can be controlled on cell phones featuring
web browser capability.
Motion Detection Setting Tool (VB Administration Tool)
4
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
*Displays may vary depending on the cell phone model.
*Only the preset positions can be controlled in the VB-C50FSi and
VB-C50Fi.
(external camera image input)
Multi-terminal Input
(Connects camera via supplied cable)
Contact/OUT x 3
Audio Playback Function
A pre-selected audio file can be played at a scheduled time or
when triggered by an event. For example, a department store can
alert customers to a special sales promotion every 3 minutes. In a
security monitoring example, you can record your own message,
such as “We will be right with you”, and have it played when
someone approaches the reception desk of an office building.
5
NETWORK CAMERAS WITH BUILT-IN SERVERS
The VB-C50 series boasts high-quality images
and a high frame rate. They respond to all of
your monitoring needs with a wide array of
features such as the 26x optical zoom, the most
powerful in the industry, motion detection and
low-light features.
Nomenclature
Compatible viewers
*3
*2
*1
Viewer for
Pocket PC
Free Viewer
Software
*1, *2, *3 Some features cannot be operated.
VB-C50i
VB-C50iR
VB-C50FSi
VB-C50Fi
Rear View of VB-C50iR
Rear View of VB-C50FSi
Rear View of VB-C50i
Rear View of VB-C50Fi
NETWORK CAMERA
VB-C50 Series
DC In Terminal Multi-terminal Input
Ethernet (10/100Mbps Automatic Switching)
PoE (10/100Mbps Automatic Switching)
<Item code: 9781A008>
<Item code: 9782A007>
<Item code: 0220B002>
<Item code: 0777B002>
Features common to the VB-C50 Series
Sample System Configurations
LAN/WAN/Internet Environment
VB-C50FSi
26x Optical Zoom/12x Digital Zoom
1x
(wide-angle end)
The camera’s genuine Canon
26x optical zoom lens offers
the highest optical zoom
magnification in the industry,
making these network cameras
the perfect choice for monitoring
large facilities.
30 fps Image Capture
Shade Correction
You’ll capture and transmit clear, well-focused video with
excellent image quality: 30 fps, 640 x 480 pixels. Viewers
with slower connections or video-enabled cell phones may
not want or be able to receive the camera’s highest-quality
video, given its larger file size. For customization and
flexibility, the camera simultaneously broadcasts in 3 file
sizes from which the viewer can select. The system can
accommodate up to 50 clients.
The Shade Correction feature increases the brightness of
only the shaded areas, leaving lighter areas untouched.
VB-C50i
VB-C50Fi
VB-C50iR
VB-EX50
Microphone
Speaker
Microphone
IP Network
Speaker
Bundled Software Speaker
PC Viewer
Bundled Software
Administrator Viewer
Network Video Recorder VK-64
Recording/Monitoring
Internet Service Provider Environment
Original
captured image
VB-C50Fi
Router
Web Server
Viewer PC
Viewer PC
Backlight Compensation
Shade Correction
VB-C50iR
Schedule-setting Tool
4x
26x (maximum zoom)
Sophisticated Motion Detection
Four areas can be selected for motion detection with the
ability to set sensitivity, area ratio and duration of detected
movement. These settings can be independently set in each
of the four areas.
Excellent Low-light Performance
The camera will capture clear color images in dim lighting all
the way down to a single lux thanks to a highly-sensitive
CCD, bright lens and slow shutter capability. Images are
further enhanced with automatic noise reduction in both
bright and dim light.
The schedule-setting tool automatically provides image
storage, motion detection, or input/output services with
external devices such as an alarm on specified days or
times. Various settings are possible, allowing the numerous
features to be fully utilized.
VB-C50FSi
Router
Broadband
Line, etc.
Internet
Router
Viewer PC
VB-C50 Series Option
Multi-terminal VB-EX50
<Item code: 9783A003>
The optional VB-EX50 greatly expands the camera's flexiblity. An
audio out terminal allows you to connect an external speaker. You
can plug in an existing analog camera or output a signal directly to
a monitor. External devices, such as door sensors and alarms,
can also be connected.
Audio data cannot be input/output on the VB-C50Fi.
Audio/IN
(Microphone)
Video/OUT
(BNC Terminal)
Contact/IN x 2
Audio/OUT
Speaker
Video/IN
(BNC Terminal)
Monitor and Control via a Mobile
Phone
Static images can be viewed and cameras
can be controlled on cell phones featuring
web browser capability.
Motion Detection Setting Tool (VB Administration Tool)
4
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
*Displays may vary depending on the cell phone model.
*Only the preset positions can be controlled in the VB-C50FSi and
VB-C50Fi.
(external camera image input)
Multi-terminal Input
(Connects camera via supplied cable)
Contact/OUT x 3
Audio Playback Function
A pre-selected audio file can be played at a scheduled time or
when triggered by an event. For example, a department store can
alert customers to a special sales promotion every 3 minutes. In a
security monitoring example, you can record your own message,
such as “We will be right with you”, and have it played when
someone approaches the reception desk of an office building.
5
NETWORK CAMERAS WITH BUILT-IN SERVERS
VB-C50i and VB-C50iR are equipped with sophisticated features such as two-way audio, pan, tilt, zoom and
motion detection, as well as auto tracking and auto touring, resulting in an exceptional monitoring system.
26x Optical Zoom
/12x Digital Zoom
Pan and Tilt
The VB-C50Fi achieves stylish and stable monitoring with a sophisticated, compact casing. The newly
introduced VB-C50FSi is equipped with additional features such as two-way audio and PoE, allowing you to
select the model you want based on your needs.
26x Optical Zoom
/12x Digital Zoom
Two-way Audio
PoE
26x Optical Zoom
/12x Digital Zoom
Two-way Audio
340k Effective Pixels
340k Effective Pixels
Motion Detection
Motion Detection
Low-light Capability
340k Effective Pixels
Motion Detection
Auto Tracking
VB-C50i
VB-C50iR
Low-light Capability
Preset Tour
Highest Pan and Tilt Performance in its Class
PoE (VB-C50FSi)
A “tour” can be programmed so that the VB-C50i or VB-C50iR
automatically moves from one preset viewing angle to
another at specified intervals. A tour can be continuous or
conducted on demand. This can be especially helpful
when monitoring a large area, such as a parking lot or
storage facility.
The VB-C50i is the best compact PTZ (pan/tilt/zoom) camera
in its class with respect to pan angle and speed. With a high
pan speed of 1 to 90 degrees per second and a tilt speed of
1 to 70 degrees per second, the state-of-the-art pan/tilt
mechanism built into its center ensures a quiet and smooth
operating performance.
Power over Ethernet (PoE) allows the VB-C50FSi to receive
both data and power through a single Ethernet cable.
Since a power cable is not required, this allows easier
installation at sites not readily accessible to AC power
outlets. Perfect for hard-to-reach locations (such as ceilings
or rooftops) both indoors and outdoors, PoE eliminates the
cost of running expensive power cabling to each camera,
reducing the overall cost of installation.
Auto Touring
Low-light Capability
<Item code: 9781A008>
<Item code: 9782A007>
VB-C50FSi
<Item code: 0777B002>
VB-C50Fi
<Item code: 0220B002>
Built-in IR Illuminator
Sophisticated features of the VB-C50i /VB-C50iR
Standard Model
Reverse Model
Easy Audio Recording and Playback Feature
Pan 340°
Pan 200°
Image and audio data stored in the camera’s internal
memory can be downloaded to a PC using the VB Collector
3.0 (included software), allowing thumbnail display,
animation display and audio playback. A pre-selected audio
file can be played at a scheduled time or when triggered by
an event. For example, a department store can alert
customers to a special sales promotion every 3 minutes. In
a security monitoring example, you can record your own
message, such as “We will be right with you”, and have it
played when someone approaches the reception desk of an
office building.
Tilt 120°
•Up 90° •Down 30°
Tilt 100°
•Up 10° •Down 90°
Range of Camera Head Movement
Auto Tracking
Improved Monitoring with Two-way Audio
A microphone and speaker can be connected using the
Multi-terminal Module VB-EX50, allowing immediate
action to be taken in emergency situations.
Auto tracking gives the camera
the ability to pan and tilt once
motion is detected and capture
this movement automatically.
*Audio input/output cannot be used with the VB-C50Fi.
*The VB-C50Fi and VB-C50FSi are not equipped with auto tracking.
Audio Reception
Welcome
Welcome
Hello
Hello
MIC
LAN
Internet
VB-EX50
VB-C50i
PC Viewer
Speaker
Audio Transmission
This area is
off-limits.
This area is off-limits.
MIC
6
LAN
Internet
Administrator
Viewer
VB-C50i
VB-EX50 Speaker
*Audio input/output cannot be used with the VB-C50Fi.
Night Imaging with Infrared Light
Easy Installation (VB-C50Fi/VB-C50FSi
A Night Mode with built-in infrared
light allows the camera to capture
clear black and white images even in
complete darkness. An additional
external infrared light can also be
connected.
The VB-C50Fi/VB-C50FSi can be installed in various
locations such as a ceiling, wall or floor. The compact dome
attachment also lets you install the cameras either indoors or
outdoors.
*The built-in infrared light cannot be used with a dome housing.
*The maximum projection of the built-in infrared light is approximately 9.8 ft (3m).
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
0lux
7
NETWORK CAMERAS WITH BUILT-IN SERVERS
VB-C50i and VB-C50iR are equipped with sophisticated features such as two-way audio, pan, tilt, zoom and
motion detection, as well as auto tracking and auto touring, resulting in an exceptional monitoring system.
26x Optical Zoom
/12x Digital Zoom
Pan and Tilt
The VB-C50Fi achieves stylish and stable monitoring with a sophisticated, compact casing. The newly
introduced VB-C50FSi is equipped with additional features such as two-way audio and PoE, allowing you to
select the model you want based on your needs.
26x Optical Zoom
/12x Digital Zoom
Two-way Audio
PoE
26x Optical Zoom
/12x Digital Zoom
Two-way Audio
340k Effective Pixels
340k Effective Pixels
Motion Detection
Motion Detection
Low-light Capability
340k Effective Pixels
Motion Detection
Auto Tracking
VB-C50i
VB-C50iR
Low-light Capability
Preset Tour
Highest Pan and Tilt Performance in its Class
PoE (VB-C50FSi)
A “tour” can be programmed so that the VB-C50i or VB-C50iR
automatically moves from one preset viewing angle to
another at specified intervals. A tour can be continuous or
conducted on demand. This can be especially helpful
when monitoring a large area, such as a parking lot or
storage facility.
The VB-C50i is the best compact PTZ (pan/tilt/zoom) camera
in its class with respect to pan angle and speed. With a high
pan speed of 1 to 90 degrees per second and a tilt speed of
1 to 70 degrees per second, the state-of-the-art pan/tilt
mechanism built into its center ensures a quiet and smooth
operating performance.
Power over Ethernet (PoE) allows the VB-C50FSi to receive
both data and power through a single Ethernet cable.
Since a power cable is not required, this allows easier
installation at sites not readily accessible to AC power
outlets. Perfect for hard-to-reach locations (such as ceilings
or rooftops) both indoors and outdoors, PoE eliminates the
cost of running expensive power cabling to each camera,
reducing the overall cost of installation.
Auto Touring
Low-light Capability
<Item code: 9781A008>
<Item code: 9782A007>
VB-C50FSi
<Item code: 0777B002>
VB-C50Fi
<Item code: 0220B002>
Built-in IR Illuminator
Sophisticated features of the VB-C50i /VB-C50iR
Standard Model
Reverse Model
Easy Audio Recording and Playback Feature
Pan 340°
Pan 200°
Image and audio data stored in the camera’s internal
memory can be downloaded to a PC using the VB Collector
3.0 (included software), allowing thumbnail display,
animation display and audio playback. A pre-selected audio
file can be played at a scheduled time or when triggered by
an event. For example, a department store can alert
customers to a special sales promotion every 3 minutes. In
a security monitoring example, you can record your own
message, such as “We will be right with you”, and have it
played when someone approaches the reception desk of an
office building.
Tilt 120°
•Up 90° •Down 30°
Tilt 100°
•Up 10° •Down 90°
Range of Camera Head Movement
Auto Tracking
Improved Monitoring with Two-way Audio
A microphone and speaker can be connected using the
Multi-terminal Module VB-EX50, allowing immediate
action to be taken in emergency situations.
Auto tracking gives the camera
the ability to pan and tilt once
motion is detected and capture
this movement automatically.
*Audio input/output cannot be used with the VB-C50Fi.
*The VB-C50Fi and VB-C50FSi are not equipped with auto tracking.
Audio Reception
Welcome
Welcome
Hello
Hello
MIC
LAN
Internet
VB-EX50
VB-C50i
PC Viewer
Speaker
Audio Transmission
This area is
off-limits.
This area is off-limits.
MIC
6
LAN
Internet
Administrator
Viewer
VB-C50i
VB-EX50 Speaker
*Audio input/output cannot be used with the VB-C50Fi.
Night Imaging with Infrared Light
Easy Installation (VB-C50Fi/VB-C50FSi
A Night Mode with built-in infrared
light allows the camera to capture
clear black and white images even in
complete darkness. An additional
external infrared light can also be
connected.
The VB-C50Fi/VB-C50FSi can be installed in various
locations such as a ceiling, wall or floor. The compact dome
attachment also lets you install the cameras either indoors or
outdoors.
*The built-in infrared light cannot be used with a dome housing.
*The maximum projection of the built-in infrared light is approximately 9.8 ft (3m).
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
0lux
7
ANALOG PTZ CAMERAS
NETWORK CAMERA SERVER
The VB150 camera server has superior expandability,
and is capable of transmitting live images through
the Internet and Intranet. Images from Canon’s VCC50i/VC-C50iR cameras as well as other cameras can
be transmitted.
Compatible Viewers
*2
*1
*3
Free viewer
software
Viewer for
Pocket PC
VB-C50 Series Bundled Software
These analog PTZ cameras are equipped with high
magnification, high sensitivity and night mode.
They are high-performance cameras that improve
monitoring capability.
*1, *2, *3 Some features cannot be operated.
NETWORK CAMERA SERVER
VB-150
Administrator Viewer with Shade
Correction Feature
The dedicated application with quick startup makes it
possible to take over camera controlling rights from another
user or override visible range limits to control the camera. The
administrator viewer allows you to control contact input/
addition, the shade correction feature makes the darker
image easier to see.
Firmware Version 1.1
<Item Code: 8346A002>
High Image Quality and High Frame Rate
Expandability
The VB150 captures images at a maximum of 30 fps and
uses Motion-JPEG for image compression. The image quality
and capture rate can be set freely on the transmitting side.
A modem card or memory card can be attached via the card
slot. Sensor-triggered images or images captured on
schedule may be stored on the memory card (sensortriggering and scheduling can be used simultaneously).
Furthermore, due to input/output via two external contacts
per unit, external devices can be turned on and off. Abnormalities and access conditions can be stored as log data,
then forwarded by e-mail to specified addresses.
Up to Four Cameras Can Be Connected
Light VC-C50iR
Sensor
Lights On/Off
Can be remotely controlled
power
Unit
VB150
VC-C50i
VC-C50i
VC-C50iR
VC-C50iR
Video Cable
VB150
VC-C50iR
Superior Camera Control
LAN
By setting the visible range, your camera can control the
areas you want to show and display them. By setting the
“home position,” the camera moves to the specified
position when there is no controller, giving you additional
flexibility.
Router
Static Camera
Viewer PC
Low-light
Capability
Built in
IR Illuminator
Image Capture Even in the Dark, Minimum
Illumination of Only 1 Lux (at 1/30 Shutter Speed)
26x Optical Zoom/12x Digital Zoom
Router
VB150
340k Effective
Pixels
*The built-in infrared light cannot be used with a dome housing.
*The maximum projection of the built-in infrared light is approximately 9.8 feet (3 m).
VC-C50i
Static Camera
Pan and Tilt
A Night Mode with built-in infrared light allows the camera
to capture clear black and white images even in complete
darkness. An additional external infrared light can also be
connected.
Sample System Configurations
LAN Environment
*Image signals from each camera are
connected to the VB150.
26x Optical Zoom
/12x Digital Zoom
<Item Code: 0668B001>
Night Mode Feature and Built-in Infrared Light
Ethernet
Example of Coupling with External Devices (Door Sensor and Light)
Control Cable
<Item Code: 0667B001>
With a fast lens and high-sensitivity CCD with 680K pixels,
these cameras improve image-capturing performance in
low-light environments, improving monitoring capability.
Open Door Signal
Sensor
Camera Control
/Imaging
Up to four Canon communication cameras can be
completely controlled by cascading; all other general video
cameras (NTSC) can also be installed. Images from up to
four cameras can be displayed and recorded simultaneously
with the Network Video Recorder VK-64/VK-16.
VC-C50iR
VC-C50i
These cameras are equipped with a 26x optical zoom lens
(9-group, 11-element multi-group configuration), which makes
it possible to capture clear, high-resolution images. In
addition, the large aperture of F1.6 is the fastest in its class.
Viewer PC
Internet Service Provider Environment
VB Collector Version 3.0
Image and audio data stored in
the internal memory of the
network camera are downloaded
based on a specified schedule.
Image thumbnails and animation
can be displayed and audio data
can be played using ImageViewer.
VB Administration Tools
Six tools – the panorama creation tool, view
restriction tool, preset setting tool,
advanced schedule setting tool, log viewer
and administrator viewer – are bundled.
Administrator features can be operated at a
single source.
*The panorama creation tool is only for the VB-C50i and VB-C50iR models.
Panorama Creation Tool
Schedule Setting Tool
View Restriction Setting Tool
Motion Detection Setting Tool
Excellent Server Features
The VB150 contains both a web server and an FTP server.
Access can be limited by user name and password or IP
address. Images can be transmitted simultaneously to up to
50 users. Constant access can be maintained from the
VB150 side by the “network connection feature” and “automatic dialing (PPP transmission) feature,” which transmit
packets at regular intervals.
VB 150 back view
VB150
Nomenclature
Internet
Router
Viewer PC
Broadband, Line, etc
VB150
LAN
VC-C50i
PC Card
PSTN
Viewer PC
DC In Terminal
Video Output (BNC terminal)
Multi-Connector Plug
(RS-232C Input/Output, S Terminal Output,
Contact Input/Output )
LAN+Dial-up Environment
PCMCIA Type II Slot x 2
Power Source (DC 11.0 – 14.0 V)
Contact Input/Output
(IN x 2, OUT x 2)
Ethernet (10M/100M)
Serial I/F for Camera Control
(RS-232C) x 2
Video Input (RCA Terminal) x 2
Video Input (BNC Terminal) x 2
Web Server
VC-C50i
Viewer PC
PC Card *Connection cannot be made with a
different communications network
VC-C50i/ VC-C50iR
Interface Adapter VC-EX3 (Supplied)
The VC-EX3 is an adapter that connects the VC-C50i/VC-C50iR
multi-connector socket with the RS-232C cable. The connecting
terminal is equipped with three terminals: an S-video output, RS232C output and RS-232C input. A BNC-RCA converter connector is attached.
Detection Area
Detection Block
Effective when there is no sensor device
8
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
9
ANALOG PTZ CAMERAS
NETWORK CAMERA SERVER
The VB150 camera server has superior expandability,
and is capable of transmitting live images through
the Internet and Intranet. Images from Canon’s VCC50i/VC-C50iR cameras as well as other cameras can
be transmitted.
Compatible Viewers
*2
*1
*3
Free viewer
software
Viewer for
Pocket PC
VB-C50 Series Bundled Software
These analog PTZ cameras are equipped with high
magnification, high sensitivity and night mode.
They are high-performance cameras that improve
monitoring capability.
*1, *2, *3 Some features cannot be operated.
NETWORK CAMERA SERVER
VB-150
Administrator Viewer with Shade
Correction Feature
The dedicated application with quick startup makes it
possible to take over camera controlling rights from another
user or override visible range limits to control the camera. The
administrator viewer allows you to control contact input/
addition, the shade correction feature makes the darker
image easier to see.
Firmware Version 1.1
<Item Code: 8346A002>
High Image Quality and High Frame Rate
Expandability
The VB150 captures images at a maximum of 30 fps and
uses Motion-JPEG for image compression. The image quality
and capture rate can be set freely on the transmitting side.
A modem card or memory card can be attached via the card
slot. Sensor-triggered images or images captured on
schedule may be stored on the memory card (sensortriggering and scheduling can be used simultaneously).
Furthermore, due to input/output via two external contacts
per unit, external devices can be turned on and off. Abnormalities and access conditions can be stored as log data,
then forwarded by e-mail to specified addresses.
Up to Four Cameras Can Be Connected
Light VC-C50iR
Sensor
Lights On/Off
Can be remotely controlled
power
Unit
VB150
VC-C50i
VC-C50i
VC-C50iR
VC-C50iR
Video Cable
VB150
VC-C50iR
Superior Camera Control
LAN
By setting the visible range, your camera can control the
areas you want to show and display them. By setting the
“home position,” the camera moves to the specified
position when there is no controller, giving you additional
flexibility.
Router
Static Camera
Viewer PC
Low-light
Capability
Built in
IR Illuminator
Image Capture Even in the Dark, Minimum
Illumination of Only 1 Lux (at 1/30 Shutter Speed)
26x Optical Zoom/12x Digital Zoom
Router
VB150
340k Effective
Pixels
*The built-in infrared light cannot be used with a dome housing.
*The maximum projection of the built-in infrared light is approximately 9.8 feet (3 m).
VC-C50i
Static Camera
Pan and Tilt
A Night Mode with built-in infrared light allows the camera
to capture clear black and white images even in complete
darkness. An additional external infrared light can also be
connected.
Sample System Configurations
LAN Environment
*Image signals from each camera are
connected to the VB150.
26x Optical Zoom
/12x Digital Zoom
<Item Code: 0668B001>
Night Mode Feature and Built-in Infrared Light
Ethernet
Example of Coupling with External Devices (Door Sensor and Light)
Control Cable
<Item Code: 0667B001>
With a fast lens and high-sensitivity CCD with 680K pixels,
these cameras improve image-capturing performance in
low-light environments, improving monitoring capability.
Open Door Signal
Sensor
Camera Control
/Imaging
Up to four Canon communication cameras can be
completely controlled by cascading; all other general video
cameras (NTSC) can also be installed. Images from up to
four cameras can be displayed and recorded simultaneously
with the Network Video Recorder VK-64/VK-16.
VC-C50iR
VC-C50i
These cameras are equipped with a 26x optical zoom lens
(9-group, 11-element multi-group configuration), which makes
it possible to capture clear, high-resolution images. In
addition, the large aperture of F1.6 is the fastest in its class.
Viewer PC
Internet Service Provider Environment
VB Collector Version 3.0
Image and audio data stored in
the internal memory of the
network camera are downloaded
based on a specified schedule.
Image thumbnails and animation
can be displayed and audio data
can be played using ImageViewer.
VB Administration Tools
Six tools – the panorama creation tool, view
restriction tool, preset setting tool,
advanced schedule setting tool, log viewer
and administrator viewer – are bundled.
Administrator features can be operated at a
single source.
*The panorama creation tool is only for the VB-C50i and VB-C50iR models.
Panorama Creation Tool
Schedule Setting Tool
View Restriction Setting Tool
Motion Detection Setting Tool
Excellent Server Features
The VB150 contains both a web server and an FTP server.
Access can be limited by user name and password or IP
address. Images can be transmitted simultaneously to up to
50 users. Constant access can be maintained from the
VB150 side by the “network connection feature” and “automatic dialing (PPP transmission) feature,” which transmit
packets at regular intervals.
VB 150 back view
VB150
Nomenclature
Internet
Router
Viewer PC
Broadband, Line, etc
VB150
LAN
VC-C50i
PC Card
PSTN
Viewer PC
DC In Terminal
Video Output (BNC terminal)
Multi-Connector Plug
(RS-232C Input/Output, S Terminal Output,
Contact Input/Output )
LAN+Dial-up Environment
PCMCIA Type II Slot x 2
Power Source (DC 11.0 – 14.0 V)
Contact Input/Output
(IN x 2, OUT x 2)
Ethernet (10M/100M)
Serial I/F for Camera Control
(RS-232C) x 2
Video Input (RCA Terminal) x 2
Video Input (BNC Terminal) x 2
Web Server
VC-C50i
Viewer PC
PC Card *Connection cannot be made with a
different communications network
VC-C50i/ VC-C50iR
Interface Adapter VC-EX3 (Supplied)
The VC-EX3 is an adapter that connects the VC-C50i/VC-C50iR
multi-connector socket with the RS-232C cable. The connecting
terminal is equipped with three terminals: an S-video output, RS232C output and RS-232C input. A BNC-RCA converter connector is attached.
Detection Area
Detection Block
Effective when there is no sensor device
8
Privacy and image rights: Please install and use network cameras responsibly, taking into consideration privacy and image rights (including audio data picked up by microphone) of the party being imaged.
9
MONITORING AND RECORDING SOFTWARE
This highly flexible, easy to run program provides a comprehensive solution for all video monitoring and
recording needs. Ideal for large-scale locations with multiple cameras, multi-site businesses and any
business in need of data custody at remote locations.
•VK Recording server
Stores data of images and events from multiple locations.
•VK Viewer
Monitors data of images and events from multiple locations and plays back the data
recorded by the recording server.
Full Screen Mode
Convert Recorded Video to QuickTime™
Full Screen mode gives you the benefit of showing only the
video windows, resulting in a large, easy to view display. You
have the option of showing or hiding the camera selector and
timeline. Up to 64 cameras (SXGA resolution) or 36 cameras
(XGA resolution) can be displayed in this mode.
The software makes it simple to convert up to an hour of
recorded video into a QuickTime™ file, allowing you to email
a viewable video file to recipients.
Network video recording software
VK-64 v1.1 <Item Code: 9513A011>
[Recording server and viewer (1 client each)]
Supports Low-Light Features
For recording in dark conditions, you can activate the
camera's low-light features through the software by turning
on the infrared (IR) cut filter, built-in IR light, or backlight
compensation.
Network video recording software
VK-16 v1.1 <Item Code: 9513A012>
[Recording server and viewer (1 client each)]
Application/Purpose
Network video recording software
Viewer license <Item Code: 9513A013>
[Additional viewer client]
Support Network Camera & Camera Server
VK- 64 Ver. 1.1
VK- 16 Ver. 1.1
*1 The VB150 can connect up to 4 cameras via the simultaneous signal delivery feature.
Simultaneous Display and Playback of up to 35
Screen Images
Remote Monitoring and Recording
Using an IP network, you can record video captured from a
camera server. This remote data custody can serve as a
crucial back up in the event of fire or other damage in the
server location.
Highly Flexible System Construction
Unlike conventional systems, this network is constructed with
a combination of ethernet cables and a hub. So compared to
conventional monitoring systems in which a single video cable
directly connects the camera to the recording device, new or
additional installation of cameras as well as changing of
installation locations can be achieved with more flexibility.
Customizable Viewing Screen
The number, size and placement of image windows can be
freely set in the image display area, allowing you to freely set
screen formats that are tailored to your needs and easy to use.
Patterned screen layouts can also be stored.
Location
Event Indicator
Records up to 64 Network Cameras
Network video recording software
5 viewer licenses <Item Code: 9513A014>
[5 additional viewer clients]
Network Video Recording Software
Screen Currently
Being Played Back
Remote Recording
Camera Selection Area
When using the SXGA monitor, a maximum of 35 screens of
live and recorded images can be displayed or played back
simultaneously (up to 24 screens for the XGA). You can play
back while recording, as well as simultaneously play back
images recorded at different times. You can compare the
congestion in areas such as stores at each hour.
The VK-64 ver. 1.1 software can record video from up to 64
cameras simultaneously to a single storage server. It can
also manage 3 storage servers with a single viewer, allowing
you to manage recorded video from a total of 192 cameras.
The VK-16 ver. 1.1 software is identical to the VK-64 ver. 1.1,
but permits video recording from up to 16 cameras on a
single storage server.
Remote Monitoring
• XGA 6 screens (grid: medium)
LAN Type
2nd Floor Conference Room
Automatic Layout Switching
Layout Switching automatically switches the video window
layout at a specified interval, such as every 30 seconds. It
allows you the flexibility of showing critical camera images
more frequently. This feature is convenient if you have many
cameras connected and cannot display all of them in a
single layout.
Monitoring
VB-C50Fi
VB150
B1 Floor Parking Lot
WAN Type
Recording
VB-C50i
VB-C50FSi
Store
A
Store
VK-64/VK-16
Viewer
Ethernet
VB-C50Fi
VB-C50FSi
Headquarter
Side
Router
VK-64/VK-16
Viewer
IP
Router
Network
VB-C50iR
VK-64/VK-16
Recording Server
Store
Router
VB-C50iR
C
Router
VB150
VB-C50iR
VB-C50iR
VC-C50iR
Multiple Type
Store
West Region
Store
Mid-West Region
Store
East Region Store
H
G
E
Store
A
C
Store
Store
Store
B
D
F
Store
Sales Division
I
Security Division
Data Center
Zone
Systems Management Division
Camera
Control
Panel
Live Event
Display
Display Area
Event
Search
Shade Correction
The Shade Correction feature increases the brightness of
only the shaded areas, leaving lighter areas untouched.
Extract Video
Return
To Live
Incremental
Time Controls
Playback
Controls
10
VB-C50i
1st Floor Entrance
B
Take control of camera directly from the live video window or
use camera control panel with captured panorama image for
quick and easy control. Presets are also available.
Network Monitoring (LAN and WAN Types)
Installation is easy with network monitoring using a
LAN, resulting in cost reduction.
Sample System Configurations
Versatile Camera Control
• XGA 24 screens (grid: small)
Improve productivity by comparing and analyzing
recorded images. It is also useful in improving teaching
efficiency and work improvement.
Ideal for store management purposes, such
as verifying customer attraction and queuing
conditions.
Various Recording Mode Settings
The software allows unparalleled
flexibility in recording, with a
wide range of options available
to each individual camera. There
is a mode to meet every need,
including continuous recording
triggered by a sensor event at
night, pre- and post-event recording, as well as motion
detection.
Comparative Analysis of Recorded Images
The recorded image will remain even when
the location of the camera is destroyed.
Camera Currently
Selected
Timeline
Timeline Play Head
Recorded data may be lost due to operator error, repair or inspection. Regrettably, we cannot assume any responsibility for losses incurred due to such data loss. Please backup important recorded data regularly.
Original
Backlight Compensation
Shade Correction
Server Capacity/Traffic/Data Size Comparison Table
Number of
Cameras
Image Size
Frame Size
Network Traffic
Frames/Second Traffic Capacity
Storage Volume
1Month
1Day
120kbps
1GB
37GB
1fps
320 x 240
15KB
600kbps
6GB
187GB
5fps
1
420kbps
4GB
122GB
1fps
640 x 480
50KB
2Mbps
20GB
608GB
5fps
1.2Mbps
12GB
373GB
1fps
320 x 240
15KB
6Mbps
62GB
1,866GB
5fps
10
4Mbps
41GB
1,216GB
1fps
640 x 480
50KB
20Mbps
203GB
6,081GB
5fps
*These numbers are strictly for reference purposes. The actual numbers will vary depending on the
environment, such as the server and the network.
11
MONITORING AND RECORDING SOFTWARE
This highly flexible, easy to run program provides a comprehensive solution for all video monitoring and
recording needs. Ideal for large-scale locations with multiple cameras, multi-site businesses and any
business in need of data custody at remote locations.
•VK Recording server
Stores data of images and events from multiple locations.
•VK Viewer
Monitors data of images and events from multiple locations and plays back the data
recorded by the recording server.
Full Screen Mode
Convert Recorded Video to QuickTime™
Full Screen mode gives you the benefit of showing only the
video windows, resulting in a large, easy to view display. You
have the option of showing or hiding the camera selector and
timeline. Up to 64 cameras (SXGA resolution) or 36 cameras
(XGA resolution) can be displayed in this mode.
The software makes it simple to convert up to an hour of
recorded video into a QuickTime™ file, allowing you to email
a viewable video file to recipients.
Network video recording software
VK-64 v1.1 <Item Code: 9513A011>
[Recording server and viewer (1 client each)]
Supports Low-Light Features
For recording in dark conditions, you can activate the
camera's low-light features through the software by turning
on the infrared (IR) cut filter, built-in IR light, or backlight
compensation.
Network video recording software
VK-16 v1.1 <Item Code: 9513A012>
[Recording server and viewer (1 client each)]
Application/Purpose
Network video recording software
Viewer license <Item Code: 9513A013>
[Additional viewer client]
Support Network Camera & Camera Server
VK- 64 Ver. 1.1
VK- 16 Ver. 1.1
*1 The VB150 can connect up to 4 cameras via the simultaneous signal delivery feature.
Simultaneous Display and Playback of up to 35
Screen Images
Remote Monitoring and Recording
Using an IP network, you can record video captured from a
camera server. This remote data custody can serve as a
crucial back up in the event of fire or other damage in the
server location.
Highly Flexible System Construction
Unlike conventional systems, this network is constructed with
a combination of ethernet cables and a hub. So compared to
conventional monitoring systems in which a single video cable
directly connects the camera to the recording device, new or
additional installation of cameras as well as changing of
installation locations can be achieved with more flexibility.
Customizable Viewing Screen
The number, size and placement of image windows can be
freely set in the image display area, allowing you to freely set
screen formats that are tailored to your needs and easy to use.
Patterned screen layouts can also be stored.
Location
Event Indicator
Records up to 64 Network Cameras
Network video recording software
5 viewer licenses <Item Code: 9513A014>
[5 additional viewer clients]
Network Video Recording Software
Screen Currently
Being Played Back
Remote Recording
Camera Selection Area
When using the SXGA monitor, a maximum of 35 screens of
live and recorded images can be displayed or played back
simultaneously (up to 24 screens for the XGA). You can play
back while recording, as well as simultaneously play back
images recorded at different times. You can compare the
congestion in areas such as stores at each hour.
The VK-64 ver. 1.1 software can record video from up to 64
cameras simultaneously to a single storage server. It can
also manage 3 storage servers with a single viewer, allowing
you to manage recorded video from a total of 192 cameras.
The VK-16 ver. 1.1 software is identical to the VK-64 ver. 1.1,
but permits video recording from up to 16 cameras on a
single storage server.
Remote Monitoring
• XGA 6 screens (grid: medium)
LAN Type
2nd Floor Conference Room
Automatic Layout Switching
Layout Switching automatically switches the video window
layout at a specified interval, such as every 30 seconds. It
allows you the flexibility of showing critical camera images
more frequently. This feature is convenient if you have many
cameras connected and cannot display all of them in a
single layout.
Monitoring
VB-C50Fi
VB150
B1 Floor Parking Lot
WAN Type
Recording
VB-C50i
VB-C50FSi
Store
A
Store
VK-64/VK-16
Viewer
Ethernet
VB-C50Fi
VB-C50FSi
Headquarter
Side
Router
VK-64/VK-16
Viewer
IP
Router
Network
VB-C50iR
VK-64/VK-16
Recording Server
Store
Router
VB-C50iR
C
Router
VB150
VB-C50iR
VB-C50iR
VC-C50iR
Multiple Type
Store
West Region
Store
Mid-West Region
Store
East Region Store
H
G
E
Store
A
C
Store
Store
Store
B
D
F
Store
Sales Division
I
Security Division
Data Center
Zone
Systems Management Division
Camera
Control
Panel
Live Event
Display
Display Area
Event
Search
Shade Correction
The Shade Correction feature increases the brightness of
only the shaded areas, leaving lighter areas untouched.
Extract Video
Return
To Live
Incremental
Time Controls
Playback
Controls
10
VB-C50i
1st Floor Entrance
B
Take control of camera directly from the live video window or
use camera control panel with captured panorama image for
quick and easy control. Presets are also available.
Network Monitoring (LAN and WAN Types)
Installation is easy with network monitoring using a
LAN, resulting in cost reduction.
Sample System Configurations
Versatile Camera Control
• XGA 24 screens (grid: small)
Improve productivity by comparing and analyzing
recorded images. It is also useful in improving teaching
efficiency and work improvement.
Ideal for store management purposes, such
as verifying customer attraction and queuing
conditions.
Various Recording Mode Settings
The software allows unparalleled
flexibility in recording, with a
wide range of options available
to each individual camera. There
is a mode to meet every need,
including continuous recording
triggered by a sensor event at
night, pre- and post-event recording, as well as motion
detection.
Comparative Analysis of Recorded Images
The recorded image will remain even when
the location of the camera is destroyed.
Camera Currently
Selected
Timeline
Timeline Play Head
Recorded data may be lost due to operator error, repair or inspection. Regrettably, we cannot assume any responsibility for losses incurred due to such data loss. Please backup important recorded data regularly.
Original
Backlight Compensation
Shade Correction
Server Capacity/Traffic/Data Size Comparison Table
Number of
Cameras
Image Size
Frame Size
Network Traffic
Frames/Second Traffic Capacity
Storage Volume
1Month
1Day
120kbps
1GB
37GB
1fps
320 x 240
15KB
600kbps
6GB
187GB
5fps
1
420kbps
4GB
122GB
1fps
640 x 480
50KB
2Mbps
20GB
608GB
5fps
1.2Mbps
12GB
373GB
1fps
320 x 240
15KB
6Mbps
62GB
1,866GB
5fps
10
4Mbps
41GB
1,216GB
1fps
640 x 480
50KB
20Mbps
203GB
6,081GB
5fps
*These numbers are strictly for reference purposes. The actual numbers will vary depending on the
environment, such as the server and the network.
11
MONITORING SOFTWARE
The WebView Livescope MV Version 2.1 is loaded with optimal features for a variety of business uses, and
lets you construct a sophisticated remote monitoring environment simply and comfortably. Simultaneous
monitoring from multiple locations is also possible with additional licenses.
The WebView Livescope MV Version 2.1 LE is a monitoring software that is simple to operate and costeffective, allowing you to display images from up to four locations simultaneously. You can control the
camera using the panorama window.
Multi-screen Monitoring Software
Simple Monitoring Software
View Window
<Item Code: 6633A024>
•MV Manager
Automatic creation of monitoring screens tailored to your needs
Centralized control of multiple network camera servers
•MV Station
Monitoring of camera images from multiple locations
Management and display of stored images
Camera Source window
Panorama Window
WebView Livescope MV Version 2.1 <Item Code: 6633A022>
[MV Manager and MV Station (per client)]
Camera Control Panel
WebView Livescope MV Version 2.1 license <Item Code: 6633A023>
[MV Station (per additional client)]
Integrated Type A 16-screen Display
(SXGA 1280 x 1024 UXGA 1600 x 1000)
Simultaneously displays images from
up to 16 locations and makes it
possible to register up to 100 camera
servers. Select the optimal screen
from 37 layouts of 1 to 16 screens.
Up to 8 automatic preset tours can be
preset for each camera, allowing you
to monitor a large area with the
minimum number of cameras.
The WebView Livescope MV notifies you
of contact input via alarm display and
flashing icon. You can also turn external
devices such as lights and buzzers
connected to the contact output on and
off on the screen (input notification and
output control of external devices).
Camera servers are searched and
automatically registered. A monitoring
screen tailored to your needs can be
easily created by simply answering
the Wizard questions.
Integrated Type A
The WebView Livescope MV Version 2.1 LE allows you to display up to four images simultaneously. You can select one of the following
three viewers: 4 viewers, 1 viewer (large) and 1 viewer (medium).
A built-in search feature automatically locates camera servers on the same network for quick and easy registration.
The video relay feature switches video images from up to four cameras on the same server in sequence and displays them
simultaneously.
*Some features cannot be used with the VB-C50 series network cameras or VC-C50i/VC-C50iR communication cameras.
Sample System Configurations
The Mapping feature allows you to
place icons of cameras and sensors
on your figure pasted onto the viewer
screen and create your own layout.
VC-C50iR
VB150
VC-C50i
*Presets set up with the MV Manager will be separate from
those set up with the camera server.
Ethernet
(10/100Mbps)
VB-C50iR
VB-C50FSi
Panorama Window
WebView Livescope MV Version
2.1 LE
Camera Control Panel
Distributed Type A
The auto-switching feature allows you
to monitor multiple camera servers
efficiently. You can automatically
switch up to 10 patterns of the same
images that have been set. This
feature can also be coupled with the
automatic preset tour.
Integrated Type B
*Some features cannot be used with the VB-C50 series network cameras or VC-C50i/VC-C50iR
Sample System Configurations
Single Location Monitoring
VB-C50FSi
VC-C50iR
VB-C50FSi
VC-C50iR
VB150
VC-C50i
VB-C50iR
VC-C50iR
VB-C50Fi
VB-C50iR
PocketPC Software
VC-C50i
VB-C50i
VC-C50iR
Access and control your
network cameras right from
your PDA! Supports a wide
variety of Pocket PC based
PDAs. Available in a single
or 5-license pack.
Full Screen Mode
Easy Camera Registration
VB-C50i
Router
Bundled Viewer Software
Viewer for Java
Item Code: 8957A002
8957A004 (5-License Pack)
Multiple Location Monitoring
VC-C50i
• Simultaneously monitor up to 4 locations on a single screen.
• Panoramic Viewing Image Function.
• Add new camera servers quickly and easily.
Allows video from the VB-150, VBC50FSi,
VB-C50Fi, or VB-C50i/R to be displayed on a
standard web browser. This software is
automatically downloaded.
Viewer for PC
Offers faster start-up and a higher
video frame rate. Installable for
frequent viewers.
VB-C50Fi
Ethernet
(10/100Mbps)
Router
Router
Software Development Kit (SDK)
WebView Livescope MV Ver. 2.1
(WebView Livescope MV Manager, MV Station)
This configuration comprises the MV Station, which displays images, and the MV
Manager, which administers the monitoring system. It is flexible and expandable,
allowing you to easily meet future expansion needs such as adding cameras and
changing camera locations.
12
Ethernet
(10/100Mbps)
WebView Livescope MV Station
Version 2.1 License
Create custom applications that take advantage of all Canon's Network Cameras and Network Camera Servers functionality. The
Software Developers kit includes codes for access and control as well as sample applications and checker tools that allow
programming and integration. For more information and to request a copy of the Software Developers kit, visit our website at:
http://www.canondv.com/nvs/sdk
13
MONITORING SOFTWARE
The WebView Livescope MV Version 2.1 is loaded with optimal features for a variety of business uses, and
lets you construct a sophisticated remote monitoring environment simply and comfortably. Simultaneous
monitoring from multiple locations is also possible with additional licenses.
The WebView Livescope MV Version 2.1 LE is a monitoring software that is simple to operate and costeffective, allowing you to display images from up to four locations simultaneously. You can control the
camera using the panorama window.
Multi-screen Monitoring Software
Simple Monitoring Software
View Window
<Item Code: 6633A024>
•MV Manager
Automatic creation of monitoring screens tailored to your needs
Centralized control of multiple network camera servers
•MV Station
Monitoring of camera images from multiple locations
Management and display of stored images
Camera Source window
Panorama Window
WebView Livescope MV Version 2.1 <Item Code: 6633A022>
[MV Manager and MV Station (per client)]
Camera Control Panel
WebView Livescope MV Version 2.1 license <Item Code: 6633A023>
[MV Station (per additional client)]
Integrated Type A 16-screen Display
(SXGA 1280 x 1024 UXGA 1600 x 1000)
Simultaneously displays images from
up to 16 locations and makes it
possible to register up to 100 camera
servers. Select the optimal screen
from 37 layouts of 1 to 16 screens.
Up to 8 automatic preset tours can be
preset for each camera, allowing you
to monitor a large area with the
minimum number of cameras.
The WebView Livescope MV notifies you
of contact input via alarm display and
flashing icon. You can also turn external
devices such as lights and buzzers
connected to the contact output on and
off on the screen (input notification and
output control of external devices).
Camera servers are searched and
automatically registered. A monitoring
screen tailored to your needs can be
easily created by simply answering
the Wizard questions.
Integrated Type A
The WebView Livescope MV Version 2.1 LE allows you to display up to four images simultaneously. You can select one of the following
three viewers: 4 viewers, 1 viewer (large) and 1 viewer (medium).
A built-in search feature automatically locates camera servers on the same network for quick and easy registration.
The video relay feature switches video images from up to four cameras on the same server in sequence and displays them
simultaneously.
*Some features cannot be used with the VB-C50 series network cameras or VC-C50i/VC-C50iR communication cameras.
Sample System Configurations
The Mapping feature allows you to
place icons of cameras and sensors
on your figure pasted onto the viewer
screen and create your own layout.
VC-C50iR
VB150
VC-C50i
*Presets set up with the MV Manager will be separate from
those set up with the camera server.
Ethernet
(10/100Mbps)
VB-C50iR
VB-C50FSi
Panorama Window
WebView Livescope MV Version
2.1 LE
Camera Control Panel
Distributed Type A
The auto-switching feature allows you
to monitor multiple camera servers
efficiently. You can automatically
switch up to 10 patterns of the same
images that have been set. This
feature can also be coupled with the
automatic preset tour.
Integrated Type B
*Some features cannot be used with the VB-C50 series network cameras or VC-C50i/VC-C50iR
Sample System Configurations
Single Location Monitoring
VB-C50FSi
VC-C50iR
VB-C50FSi
VC-C50iR
VB150
VC-C50i
VB-C50iR
VC-C50iR
VB-C50Fi
VB-C50iR
PocketPC Software
VC-C50i
VB-C50i
VC-C50iR
Access and control your
network cameras right from
your PDA! Supports a wide
variety of Pocket PC based
PDAs. Available in a single
or 5-license pack.
Full Screen Mode
Easy Camera Registration
VB-C50i
Router
Bundled Viewer Software
Viewer for Java
Item Code: 8957A002
8957A004 (5-License Pack)
Multiple Location Monitoring
VC-C50i
• Simultaneously monitor up to 4 locations on a single screen.
• Panoramic Viewing Image Function.
• Add new camera servers quickly and easily.
Allows video from the VB-150, VBC50FSi,
VB-C50Fi, or VB-C50i/R to be displayed on a
standard web browser. This software is
automatically downloaded.
Viewer for PC
Offers faster start-up and a higher
video frame rate. Installable for
frequent viewers.
VB-C50Fi
Ethernet
(10/100Mbps)
Router
Router
Software Development Kit (SDK)
WebView Livescope MV Ver. 2.1
(WebView Livescope MV Manager, MV Station)
This configuration comprises the MV Station, which displays images, and the MV
Manager, which administers the monitoring system. It is flexible and expandable,
allowing you to easily meet future expansion needs such as adding cameras and
changing camera locations.
12
Ethernet
(10/100Mbps)
WebView Livescope MV Station
Version 2.1 License
Create custom applications that take advantage of all Canon's Network Cameras and Network Camera Servers functionality. The
Software Developers kit includes codes for access and control as well as sample applications and checker tools that allow
programming and integration. For more information and to request a copy of the Software Developers kit, visit our website at:
http://www.canondv.com/nvs/sdk
13
Specifications
NETWORK VIDEO RECORDER
NETWORK CAMERAS
Product code
Image delivery
features
Camera
performance
Web delivery
features
External device
connection
Unit
specifications
Protocol
Network
Capture frame rate
Capture size
Compression method
Simultaneous client access
Image signal
Image sensor
Pixels
Minimum subject illumination
Image capture mode
Focus
Lens
Infrared-cut filter
Night mode Light projection distance
Lens filter diameter
Pan
Drive mechanism
Tilt
Server functions
Maximum transmission rate
Access security features
Connection limitation
Camera control administration
Preset
Home position feature
Visible range restriction
Image storage capacity
Storage trigger
Contact output method
Display and management
of stored images
Size
Operating environment
Power source
Weight
9781A008
9782A007
0220B002
0777B002
TCP/IP, HTTP, DHCP, FTP, NTP, SMTP
Ethernet x 1 (RJ45, 10/100Mbps auto negotiation)
30 fps (640 x 480)
160 x 120/320 x 240/640 x 480
Motion-JPEG (movie, variable image quality), JPEG (still image)
50(Max.)
NTSC-compatible (image output when connecting to the VB-EX50)
¼ CCD
680K pixels (340K effective)
1 lux (at 1/30 seconds)/0 lux (with infrared light projection)
1 lux (at 1/30 seconds)
Normal mode/Night mode
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
(In night mode, W: 0.78" to ∞ (0.02 m to ∞), T: 90.5" to ∞ (2.3 m to ∞ )
f = .13" to 3.38" (3.5mm to 91.0 mm), F 1.6 to 4.0, 26x power zoom (when capturing images at ∞)
Power on/off
approximately 9.8ft(3 m)
1.45" (37 mm) pitch = .029" (0.75 mm)
+170° /–170° (1°~90°/sec)
+100° /–100° (1°~90°/sec)
+10° /–90° (1°~70°/sec)
+90° /–30° (1°~70°/sec)
www, FTP, Audio, Camera
www, FTP, Camera
www, FTP, Audio, Camera
0.1 to 30 fps (variable)
Password
Access limitation (user/host address), image connection time, service time, simultaneous connections (up to 50)
Yes (exclusion administration, administration permit time, number in queue)
20 positions
10 positions
Yes
Yes
Approximately 15 MB
Scheduled, motion detection, sensor
Manual/operated by sensor input
External PC (via supplied VB Collector 3.0)
4.11"(W) x 5.12"(D) x 4.31"(H)
(104.6 mm x 130.3 mm x 109.7 mm)
5.35"(W) x 5.12"(D) x 4.35"(H)
2.60"(W) x 5.28"(D) x 3.81"(H)
(136.0 mm x 130.3 mm x 110.6 mm)
(66.2 mm x 134.2 mm x 97.0 mm)
Temperature: F: 32-104° (C: 0-40°), humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V)
AC adapter (included), DC 13V (11.5-14.0V)
PoE IEEE802.3 at compliant
Power consumption: 14W or less
Power consumption: 10W or less
AC adapter (option), DC 13V (11.5-14.0V)
Power consumption: 10W or less
approximately 1.37 lbs(620 g)
approximately 1.5 lbs(700 g)
approximately 1.06 lbs(480 g)
approximately 1.17 lbs(530 g)
9513A011
9513A012
Product code
Compatibility camera servers
VB-C50FSi, VB-C50Fe, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150, VB101
Recorded file format
Motion-JPEG
Recording
Images input
64
16
features
Image recording size
160 x 120 to 640 x 480
HDD
Recording medium
Depends on OS specifications and PC’S HDD capacity
Recording time
0.1 to 30 fps
Recording frame rate
Schedule
Yes
Sensor
detection
recording
Yes
Recording
Motion detection recording
Yes
mode
Pre- event recording
Yes (maximum 30 seconds)
Yes (maximum 999 seconds)
Post-event recording
Image screens
Normal: 24 (XGA), 35 (SXGA); Full-screen mode: 36 (SXGA), 64 (SXGA)
Displayed
Simultaneous playback during recording
Yes
Live image monitoring during recording
Yes
playback
Rewind and fast forward speed
x2, x5, x10
Search function
Date, time, event
Motion detection, event detection, control of output to external devices
Live/image playback feature characteristics
Number of viewers connected
Other
5
simultaneously to the recording server
3
Number of operating servers
Pentium 4, 2.2 GHz or faster
CPU
Recording
Windows
Server
2003
Standard
Edition,
Windows
Server
2003
Standard
Edition
(SP1),
Windows
2000 Server (SP4), Windows 2000 Professional (SP4), Windows XP Professional (SP2) *1
OS
server
1024 MB or higher (1.5 GB or higher recommended when using 48 or more camera servers)
(recommended Memory
Hard disk
20 GB or higher available disk space
conditions)
Display
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
CPU
Pentium III, 700 MHz or faster
OS
Windows Server 2003 Standard Edition, Windows Server 2003 Standard Edition (SP1), Windows 2000 Server (SP4), Windows 2000 Professional (SP4), Windows XP Professional (SP2) *1
Operating
Minimum
Memory
256 MB or higher (1 GB recommended when using 16 or more camera servers)
environment
conditions
Hard disk
2 GB or higher available disk space
Display
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
Viewer
CPU
Pentium 4, 2.2 GHz or faster
Windows XP Professional (SP1)
OS
Recommended
1024 MB or higher
Memory
conditions
2 GB or higher available disk space
Hard disk
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
Display
Standard package
VK-64
VK-16
(recording server+ viewer)
Contents
1 additional client (9513A0013)
Additional viewer license
5 additional clients (9513A014)
*When using Windows XP SP2, depending on the OS specifications, if more than 10 of the cameras that are registered with the recording server cannot be connected, startup and various operation of the VB-64 viewer may take time.
NETWORK CAMERA SERVER
WEBVIEW LIVESCOPE
Additional Station License*
Product code
Protocol
Image compression method
Capture frame rate
Capture size
Server functions
Log administration
Camera control
Support camera
Access limitations
Simultaneous client access
Image storage features
Stored image collection
E-mail features
Interface
Image input
Serial
Network
Expansion slots
Contact input/output
Display LEDs
Size
Unit
Operating environment
specifications
Power source
Weight
8346A002
TCP/IP, HTTP, BOOTP, FTP,SMTP
Motion-JPEG (movie, variable image quality from 1 to 99), JPEG (still image)
0.1 to 30 fps (variable)
160 x 120/320 x 240/640 x 240
www, FTP, Camera
Syslog format (capable of e-mail, FTP, flash memory recording)
Pan, tilt, zoom, preset, brightness, shutter speed, focus, ND filter (only with NU-700N), iris (only with NU-700N), wiper (only with NU-700N),
visible range restriction, administration time limitation (up to 60 minutes), maximum number in queue for control right (0 to 50)
VC-C4/VC-C4R, NU-700N, VC-C50i/VC-C50iR
Access control: password (up to 50)/host specification (30 categories), image connection time (1 to 65535 seconds, unlimited)
50 (Max)
Flash memory card, scheduled recording (minimum 1-minute intervals), recording by an external device (minimum 1-minute intervals), recording by motion detection (minimum 1-minute intervals)
Capable of remote operation via LAN or from remote locations (from a minimum of 5 minutes using the VB Collector)
Transmission of static images from recording by an external device, transmission of log code (data, error, warning)
4 inputs (NTSC:RCA x 2, BNC x 2)
RS-232C x 2 (MiniDIN8, for camera control x 2)
Ethernet x 1 (10/100Mbps auto negotiation)
PCMCIA Type II (3.3V/5V) x 2 *Please check PC card model operation before use
Input x 2, output x 2
Power on/off, network status, PCMCIA status display
9.77"(W) x 6.56"(D) x 2.05"(H) (248.3 mm x 166.8 mm x 52.1 mm)
Temperature: F: 32-104° (C: 0-40°), humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V) Power consumption: 17W or less
Approximately 2.6 lbs(1.2 kg)
Product code
Protocol
Registered camera servers
Compatibility camera servers
Screen pattern
Auto-switch
Automatic preset tour
Camera control
Server contact input/output
Motion detection
Map feature
Stored image collection
Search recorded image
CPU
OS
Operating
Memory
environment Hard disk
Display
Browser
6633A022
6633A023
TCP/IP, HTTP, FTP
Up to 100
VB-C50FSi, VB-C50Fi, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150, VB101/VB100 Version 3 or higher
1/2/3/4/5/6/8/9/10/12/16/full screen
Switching between up to 10 screens (same screen pattern)
8 Presets per camera server
Pan, tilt, zoom, backlight correction, preset, panorama operation, focus
Input: alarm display Output: remote control
Detection: alarm display
Input external image (bmp or JPEG)
Set 16 tasks: minimum 1 hour interval
Sort-by-image difference feature
Pentium III, 600 MHz or faster
Windows 2000 (SP4) or XP (SP1)
128 MB or higher
50 MB or higher available disk space
—
XGA or higher, 16 bit color or higher
IE 5.0 or later
6633A024
TCP/IP, HTTP
Up to 4 (however, when multiple cameras are connected to a camera
server, the number of servers serving up to a total of 4 cameras)
VB-C50Fi, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150,
VB101/VB100 Version 3.0 or higher
1/4/full screen
—
—
Pan, tilt, zoom, backlight correction, panorama operation, focus
—
—
—
—
—
20 MB or higher available disk space
XGA or higher, 16 bit color or higher
Features: (Only for MV Version 2.1) • Auto-switch: switches automatically between multiple screens • Automatic preset tour: drives up to 8 preset settings automatically • Motion detection feature: recognizes images within a specified area and notifies, records,
etc. (available only with VB150) • Image collection and administration: collects images stored within the camera server at regular intervals and plays back video • Map feature: places cameras and sensors on desired map data, visually supplementing
monitoring * If you are using the MV Station installed in more than one server, please purchase additional license(s). *Some features are unavailable when using a VB-C50 series network camera and/or VC-C50i/VC-C50iR communication camera. (Only for MV
Version 2.1 LE) • You can control the cameras with up to 4 screen displays • Full-screen display or camera server connection data display *Some features are unavailable when using a VB-C50 series network camera and/or VC-C50i/VC-C50iR communication
camera.
ANALOG CAMERA
Product code
Image signal
Image sensor
Pixels
Synchronizing method
Horizontal resolution
Vertical resolution
SN ratio
Scanning method
Minimum subject illumination
Capture mode
Drive mechanism
Connection
terminal
Cascade control
Focus
Apenture
Lens
Output terminal
Multi-connector
0667B001
Pan
Tilt
Infrared-cut filter
Light projection distance
Minimum subject illumination
Lens filter diameter
White balance
Installation angle
Size
Unit
Operating environment
specifications
Power source
Weight
Night mode
+100° /–100° (1°~90°/sec)
+90° /–30° (1°~70°/sec)
0668B001
NTSC-compatible
¼ CCD
680K pixels (340K effective)
Internal synchronizing
460TV
350TV
50dB
2:1 interlaced
1 lux (at 1/30 seconds)
Normal mode/Night mode
+170° /–170° (1°~90°/sec)
+10° /–90° (1°~70°/sec)
VIDEO OUT: BNC composite video output
S-VIDEO output, RS-232C control (input/output), sensor input, alarm output, external illumination control
Up to 9 units
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
Auto iris servo method
f = .13" to 3.38" (3.5mm to 91.0 mm), F 1.6 to 4.0, 26x power zoom (when capturing images at ∞)
Power on/off
9.8ft (3 m)
0 lux (with Infrared light projection)
1.45" (37 mm) pitch = .029" (0.75 mm)
TTL auto/manual/one-push
Horizontal ±20° (±15° when using the optional wide converter)
3.93"(W) x 4.92"(D) x 3.77"(H) (100 mm x 125 mm x 96 mm
5.11"(W) x 4.92"(D) x 3.77"(H) (130 mm x 125 mm x 98 mm)
Temperature: F: 32-104° (C: 0 to 40°); Humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V) Power consumption: 13 W or less
Approximately 0.93 lbs (420 g)
Approximately 1.08 lbs (490 g)
UNIT: mm (millimeter)
Specifications
NETWORK VIDEO RECORDER
NETWORK CAMERAS
Product code
Image delivery
features
Camera
performance
Web delivery
features
External device
connection
Unit
specifications
Protocol
Network
Capture frame rate
Capture size
Compression method
Simultaneous client access
Image signal
Image sensor
Pixels
Minimum subject illumination
Image capture mode
Focus
Lens
Infrared-cut filter
Night mode Light projection distance
Lens filter diameter
Pan
Drive mechanism
Tilt
Server functions
Maximum transmission rate
Access security features
Connection limitation
Camera control administration
Preset
Home position feature
Visible range restriction
Image storage capacity
Storage trigger
Contact output method
Display and management
of stored images
Size
Operating environment
Power source
Weight
9781A008
9782A007
0220B002
0777B002
TCP/IP, HTTP, DHCP, FTP, NTP, SMTP
Ethernet x 1 (RJ45, 10/100Mbps auto negotiation)
30 fps (640 x 480)
160 x 120/320 x 240/640 x 480
Motion-JPEG (movie, variable image quality), JPEG (still image)
50(Max.)
NTSC-compatible (image output when connecting to the VB-EX50)
¼ CCD
680K pixels (340K effective)
1 lux (at 1/30 seconds)/0 lux (with infrared light projection)
1 lux (at 1/30 seconds)
Normal mode/Night mode
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
(In night mode, W: 0.78" to ∞ (0.02 m to ∞), T: 90.5" to ∞ (2.3 m to ∞ )
f = .13" to 3.38" (3.5mm to 91.0 mm), F 1.6 to 4.0, 26x power zoom (when capturing images at ∞)
Power on/off
approximately 9.8ft(3 m)
1.45" (37 mm) pitch = .029" (0.75 mm)
+170° /–170° (1°~90°/sec)
+100° /–100° (1°~90°/sec)
+10° /–90° (1°~70°/sec)
+90° /–30° (1°~70°/sec)
www, FTP, Audio, Camera
www, FTP, Camera
www, FTP, Audio, Camera
0.1 to 30 fps (variable)
Password
Access limitation (user/host address), image connection time, service time, simultaneous connections (up to 50)
Yes (exclusion administration, administration permit time, number in queue)
20 positions
10 positions
Yes
Yes
Approximately 15 MB
Scheduled, motion detection, sensor
Manual/operated by sensor input
External PC (via supplied VB Collector 3.0)
4.11"(W) x 5.12"(D) x 4.31"(H)
(104.6 mm x 130.3 mm x 109.7 mm)
5.35"(W) x 5.12"(D) x 4.35"(H)
2.60"(W) x 5.28"(D) x 3.81"(H)
(136.0 mm x 130.3 mm x 110.6 mm)
(66.2 mm x 134.2 mm x 97.0 mm)
Temperature: F: 32-104° (C: 0-40°), humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V)
AC adapter (included), DC 13V (11.5-14.0V)
PoE IEEE802.3 at compliant
Power consumption: 14W or less
Power consumption: 10W or less
AC adapter (option), DC 13V (11.5-14.0V)
Power consumption: 10W or less
approximately 1.37 lbs(620 g)
approximately 1.5 lbs(700 g)
approximately 1.06 lbs(480 g)
approximately 1.17 lbs(530 g)
9513A011
9513A012
Product code
Compatibility camera servers
VB-C50FSi, VB-C50Fe, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150, VB101
Recorded file format
Motion-JPEG
Recording
Images input
64
16
features
Image recording size
160 x 120 to 640 x 480
HDD
Recording medium
Depends on OS specifications and PC’S HDD capacity
Recording time
0.1 to 30 fps
Recording frame rate
Schedule
Yes
Sensor
detection
recording
Yes
Recording
Motion detection recording
Yes
mode
Pre- event recording
Yes (maximum 30 seconds)
Yes (maximum 999 seconds)
Post-event recording
Image screens
Normal: 24 (XGA), 35 (SXGA); Full-screen mode: 36 (SXGA), 64 (SXGA)
Displayed
Simultaneous playback during recording
Yes
Live image monitoring during recording
Yes
playback
Rewind and fast forward speed
x2, x5, x10
Search function
Date, time, event
Motion detection, event detection, control of output to external devices
Live/image playback feature characteristics
Number of viewers connected
Other
5
simultaneously to the recording server
3
Number of operating servers
Pentium 4, 2.2 GHz or faster
CPU
Recording
Windows
Server
2003
Standard
Edition,
Windows
Server
2003
Standard
Edition
(SP1),
Windows
2000 Server (SP4), Windows 2000 Professional (SP4), Windows XP Professional (SP2) *1
OS
server
1024 MB or higher (1.5 GB or higher recommended when using 48 or more camera servers)
(recommended Memory
Hard disk
20 GB or higher available disk space
conditions)
Display
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
CPU
Pentium III, 700 MHz or faster
OS
Windows Server 2003 Standard Edition, Windows Server 2003 Standard Edition (SP1), Windows 2000 Server (SP4), Windows 2000 Professional (SP4), Windows XP Professional (SP2) *1
Operating
Minimum
Memory
256 MB or higher (1 GB recommended when using 16 or more camera servers)
environment
conditions
Hard disk
2 GB or higher available disk space
Display
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
Viewer
CPU
Pentium 4, 2.2 GHz or faster
Windows XP Professional (SP1)
OS
Recommended
1024 MB or higher
Memory
conditions
2 GB or higher available disk space
Hard disk
XGA (1024 x 768) or better, high resolution display with 16 bit color or higher
Display
Standard package
VK-64
VK-16
(recording server+ viewer)
Contents
1 additional client (9513A0013)
Additional viewer license
5 additional clients (9513A014)
*When using Windows XP SP2, depending on the OS specifications, if more than 10 of the cameras that are registered with the recording server cannot be connected, startup and various operation of the VB-64 viewer may take time.
NETWORK CAMERA SERVER
WEBVIEW LIVESCOPE
Additional Station License*
Product code
Protocol
Image compression method
Capture frame rate
Capture size
Server functions
Log administration
Camera control
Support camera
Access limitations
Simultaneous client access
Image storage features
Stored image collection
E-mail features
Interface
Image input
Serial
Network
Expansion slots
Contact input/output
Display LEDs
Size
Unit
Operating environment
specifications
Power source
Weight
8346A002
TCP/IP, HTTP, BOOTP, FTP,SMTP
Motion-JPEG (movie, variable image quality from 1 to 99), JPEG (still image)
0.1 to 30 fps (variable)
160 x 120/320 x 240/640 x 240
www, FTP, Camera
Syslog format (capable of e-mail, FTP, flash memory recording)
Pan, tilt, zoom, preset, brightness, shutter speed, focus, ND filter (only with NU-700N), iris (only with NU-700N), wiper (only with NU-700N),
visible range restriction, administration time limitation (up to 60 minutes), maximum number in queue for control right (0 to 50)
VC-C4/VC-C4R, NU-700N, VC-C50i/VC-C50iR
Access control: password (up to 50)/host specification (30 categories), image connection time (1 to 65535 seconds, unlimited)
50 (Max)
Flash memory card, scheduled recording (minimum 1-minute intervals), recording by an external device (minimum 1-minute intervals), recording by motion detection (minimum 1-minute intervals)
Capable of remote operation via LAN or from remote locations (from a minimum of 5 minutes using the VB Collector)
Transmission of static images from recording by an external device, transmission of log code (data, error, warning)
4 inputs (NTSC:RCA x 2, BNC x 2)
RS-232C x 2 (MiniDIN8, for camera control x 2)
Ethernet x 1 (10/100Mbps auto negotiation)
PCMCIA Type II (3.3V/5V) x 2 *Please check PC card model operation before use
Input x 2, output x 2
Power on/off, network status, PCMCIA status display
9.77"(W) x 6.56"(D) x 2.05"(H) (248.3 mm x 166.8 mm x 52.1 mm)
Temperature: F: 32-104° (C: 0-40°), humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V) Power consumption: 17W or less
Approximately 2.6 lbs(1.2 kg)
Product code
Protocol
Registered camera servers
Compatibility camera servers
Screen pattern
Auto-switch
Automatic preset tour
Camera control
Server contact input/output
Motion detection
Map feature
Stored image collection
Search recorded image
CPU
OS
Operating
Memory
environment Hard disk
Display
Browser
6633A022
6633A023
TCP/IP, HTTP, FTP
Up to 100
VB-C50FSi, VB-C50Fi, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150, VB101/VB100 Version 3 or higher
1/2/3/4/5/6/8/9/10/12/16/full screen
Switching between up to 10 screens (same screen pattern)
8 Presets per camera server
Pan, tilt, zoom, backlight correction, preset, panorama operation, focus
Input: alarm display Output: remote control
Detection: alarm display
Input external image (bmp or JPEG)
Set 16 tasks: minimum 1 hour interval
Sort-by-image difference feature
Pentium III, 600 MHz or faster
Windows 2000 (SP4) or XP (SP1)
128 MB or higher
50 MB or higher available disk space
—
XGA or higher, 16 bit color or higher
IE 5.0 or later
6633A024
TCP/IP, HTTP
Up to 4 (however, when multiple cameras are connected to a camera
server, the number of servers serving up to a total of 4 cameras)
VB-C50Fi, VB-C50i/VB-C50iR, VB-C10/VB-C10R, VB150,
VB101/VB100 Version 3.0 or higher
1/4/full screen
—
—
Pan, tilt, zoom, backlight correction, panorama operation, focus
—
—
—
—
—
20 MB or higher available disk space
XGA or higher, 16 bit color or higher
Features: (Only for MV Version 2.1) • Auto-switch: switches automatically between multiple screens • Automatic preset tour: drives up to 8 preset settings automatically • Motion detection feature: recognizes images within a specified area and notifies, records,
etc. (available only with VB150) • Image collection and administration: collects images stored within the camera server at regular intervals and plays back video • Map feature: places cameras and sensors on desired map data, visually supplementing
monitoring * If you are using the MV Station installed in more than one server, please purchase additional license(s). *Some features are unavailable when using a VB-C50 series network camera and/or VC-C50i/VC-C50iR communication camera. (Only for MV
Version 2.1 LE) • You can control the cameras with up to 4 screen displays • Full-screen display or camera server connection data display *Some features are unavailable when using a VB-C50 series network camera and/or VC-C50i/VC-C50iR communication
camera.
ANALOG CAMERA
Product code
Image signal
Image sensor
Pixels
Synchronizing method
Horizontal resolution
Vertical resolution
SN ratio
Scanning method
Minimum subject illumination
Capture mode
Drive mechanism
Connection
terminal
Cascade control
Focus
Apenture
Lens
Output terminal
Multi-connector
0667B001
Pan
Tilt
Infrared-cut filter
Light projection distance
Minimum subject illumination
Lens filter diameter
White balance
Installation angle
Size
Unit
Operating environment
specifications
Power source
Weight
Night mode
+100° /–100° (1°~90°/sec)
+90° /–30° (1°~70°/sec)
0668B001
NTSC-compatible
¼ CCD
680K pixels (340K effective)
Internal synchronizing
460TV
350TV
50dB
2:1 interlaced
1 lux (at 1/30 seconds)
Normal mode/Night mode
+170° /–170° (1°~90°/sec)
+10° /–90° (1°~70°/sec)
VIDEO OUT: BNC composite video output
S-VIDEO output, RS-232C control (input/output), sensor input, alarm output, external illumination control
Up to 9 units
Auto/Manual W: 0.39" to ∞ (0.01 m to ∞), T: 62.9" to ∞ (1.6 m to ∞)
Auto iris servo method
f = .13" to 3.38" (3.5mm to 91.0 mm), F 1.6 to 4.0, 26x power zoom (when capturing images at ∞)
Power on/off
9.8ft (3 m)
0 lux (with Infrared light projection)
1.45" (37 mm) pitch = .029" (0.75 mm)
TTL auto/manual/one-push
Horizontal ±20° (±15° when using the optional wide converter)
3.93"(W) x 4.92"(D) x 3.77"(H) (100 mm x 125 mm x 96 mm
5.11"(W) x 4.92"(D) x 3.77"(H) (130 mm x 125 mm x 98 mm)
Temperature: F: 32-104° (C: 0 to 40°); Humidity: 20 to 85% RH (no condensation)
AC adapter (included), DC 13V (11.5-14.0V) Power consumption: 13 W or less
Approximately 0.93 lbs (420 g)
Approximately 1.08 lbs (490 g)
UNIT: mm (millimeter)
OPTIONS
WIDE CONVERTER
EXPANSION BOX
Wide Converter A wider angle of image capture can be
achieved by attaching the optional Wide
WL-37
Multi Terminal
Module VB-EX50
Converter WL-37 to the VB-C50i/
VB-C50iR/VC-C50i. This option is useful
when the camera is installed too close
to the area that requires monitoring.
For safety reasons, this optional item cannot be
used with ceiling-mounted models.
AC Adapter PA-16 AC Adapter for VB-C50FSi
and AC Cable
Item Code: 6588A001
• Audio Out for speakers
• Video In/Out (BNC) for analog video
cameras already in use
• External Sensor In/Out for sensors
and alarms
• Lens magnification: 0.74x
• Expands field-of-view to 65°
Item Code: 4674A001
AC ADAPTER
The Multi Terminal Module VB-EX50
enables connection of various types of
external devices to the VB-C50i/
VB-C50iR/VB-C50Fi.
• Input: voltage AC 100V-240V 50/60Hz
• Output: voltage13V(11.5-14V), 1.8A(Max.)
• Dimension (W x D x H):
2.28 x 4.65 x 0.95in.(58 x 118 x 25mm)
• Weight: 0.45lbs (205g)
Item Code: 9783A003
DOMES/HOUSINGS for VB-C50i/VB-C50iR
IRC1-P:
Indoor Recessed
Clear Dome
• Plenum rated metal top indoor recessed
ceiling housing
• 7”optically clear lower dome
• White decorative trim ring with quickrelease pressure springs
• 24vac input for longer cable runs
• Power convert inside the housing to
provide 12vdc to the camera
• Right angle power plug
• Feed through wiring for power and Ethernet
• 40va plug-in 110vac to 24vac wall
transformer included
IWC1-P:
Indoor Wall
Clear Dome
• Outdoor dome housing that is UV
protected, and a 94VO flame rating
• Wall mount to allow the housing to attach
to most vertical surfaces
• Heater and Blower to maintain an operating
environment of (-20°F to +120°F)
• 24vac input for longer cable runs
• Power convert inside the housing to
provide 12vdc to the camera
• Right angle power plug
• Feed through wiring for power and Ethernet
• 40va plug-in 110vac to 24vac wall
transformers included
OPC1-P:
Outdoor
Pendant
Clear Dome
Item Code: 9958A001
OWC1-P:
Outdoor Wall
Clear Dome
• Indoor dome housing that is UV
protected, and a 94VO flame rating
• Wall mount to allow the housing to
attach to most vertical surfaces
• 24vac input for longer cable runs
• Power convert inside the housing to
provide 12vdc to the camera
• Right angle power plug
• Feed through wiring for power and Ethernet
• 40va plug-in 110vac to 24vac wall
transformer included
• Indoor dome housing that is UV protected
IPC1-P:
Indoor Pendant and a 94VO flame rating
• Pendant mount, 1 1/2" pipe thread
Clear Dome
• 24vac input for longer cable runs
• Outdoor dome housing that is UV
protected and a 94VO flame rating
• Pendant mount, 1 1/2" pipe thread
• Heater and Blower to maintain an operating
environment of (-20°F to +120°F)
• 24vac input for longer cable runs
• Power convert inside the housing to
provide 12vdc to the camera
• Right angle power plug
• Feed through wiring for power and Ethernet
• 40va plug-in 110vac to 24vac wall
transformers included
OPCP1-P:
Outdoor
Pendant Clear
Pressurized
Dome
Item Code: 9958A003
Item Code: 9958A002
Item Code: 9958A004
Item Code: 9958A005
• Wall mounting bracket for pendant domes
IPC2:
Indoor Pendant • Decorative gooseneck style bracket
• 1 1/2" pipe thread on end for quick and
Clear Dome
easy dome mounting
WMB1:
Wall Mount
Bracket
• Durable powder coat finish
• All aluminum construction
• 50 lb load rating
Item Code: 0693V579
• Power convert inside the housing to
provide 12vdc to the camera
• Right angle power plug
• Feed through wiring for power and Ethernet
• 40va plug-in 110vac to 24vac wall
transformer included
• Outdoor pressurized dome housing that
is UV protected and a 945VA flame rating
• Schrader Valve for nitrogen input
• 5-7psi pressure relief valve to protect
against pressurization
• Pendant mount, 1 1/2" pipe thread
• Heater and Blower to maintain an operating
environment of (-40°F to +120°F)
• 24vac input for longer cable runs
• Power convert inside the housing to
provide 12vdc to the camera
• 100va plug-in 110vac to 24vac transformer
included
Item Code: 9958A006
• Wall mounting bracket for pendant domes
• Decorative gooseneck style bracket
• 1 1/2" pipe thread on end for quick and
easy dome mounting
• Durable powder coat finish
• All aluminum construction
• 50 lb load rating
Item Code: 0612V934
CMB1:
Ceiling Mount
Bracket
• Ceiling mounting bracket for pendant
domes
• Includes junction box
• Includes 1 1/2" pipe threaded coupling
• Wiring can be run through the ceiling or
through conduit into the junction box
• Durable powder coat finish
• All steel construction
• 30 lb load rating
Item Code: 0648V239
HOUSINGS for VB-C50Fi
IWH1-P:
Indoor Wall/
Pole Housing
• Indoor housing that is UV protected
• Wall mount/Pole mount to allow the housing
to attach to most vertical surfaces
• Side hinges for ease of access when
focusing and adjusting the camera
• 24vac input for longer cable runs
• Feed through wiring for power and Ethernet
• Specifically designed for the VB-C50Fi
Fixed Network Camera
Item Code: 0630V051
OWH1-P:
Outdoor Wall/
Pole Housing
• Indoor housing that is UV protected
• Wall mount/Pole mount to allow the housing
to attach to most vertical surfaces
• Side hinges for ease of access when
focusing and adjusting the camera
• 24vac input for longer cable runs
• Feed through wiring for power and Ethernet
• Specifically designed for the VB-C50Fi
Fixed Network Camera
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042 U.S.A.
Item Code: 0630V050
IWH2:
Indoor Wall/
Pole Housing
• Indoor housing that is UV protected
• Wall mount/Pole mount to allow the housing
to attach to most vertical surfaces
• Side hinges for ease of access when
focusing and adjusting the camera
• 24vac input for longer cable runs
• Feed through wiring for power and Ethernet
• Specifically designed for the VB-C50Fi
Fixed Network Camera
Canon Canada, Inc.
6390 Dixie Road
Mississauga, Ontario L5T 1P7 Canada
Canon Mexicana, S. de R.L. de C.V.
Blvd. Manuel Ávila Camacho
No. 138, Piso 17
Col. Lomas de Chapultepec
C.P. 11000 México, D.F. México
Item Code: 0689V554
Specifications are subject to change without notice. Weight and
dimensions are approximate. Canon and Canon Know How are registered
trademarks of Canon Inc. in the United States and may also be registered
marks in other countries. Microsoft and Windows are either registered
trademarks or trademarks of the Microsoft Corporation in the United States
and/or other countries. Macintosh and Mac OS are trademarks of Apple
Computer, Inc., registered in the United States and other countries. Other
names and products not mentioned above may be registered trademarks or
trademarks of their respective companies.
Warning: Unauthorized recording of copyrighted materials may infringe
on the rights of copyright owners and be contrary to copyright laws.
www.canondv.com/nvs
Canon Latin America, Inc.
703 Waterford Way, Suite 400
Miami, FL 33126 U.S.A.
©2005 CANON U.S.A., INC.
0035W407 10/05
PRINTED IN U.S.A.
