Thank you for purchasing the Canon DR-2050C/DR-2050SP Document
Scanner. Please read this manual thoroughly before using the machine to
familiarize yourself with its capabilities, and to make the most of its many
functions. After reading this manual, store it in a safe place for future reference.
The Canon DR-2050C/DR-2050SP is a compact document scanner with
automatic paper feed.
In addition to the conventional functions of a document scanner, the Canon
DR-2050SP is equipped with a Presentation mode that enables the user to
directly connect the scanner to a liquid crystal projector without using a
computer, and project scanned images onto a screen.
Manuals for the Scanner
The following manuals are provided with the Canon DR-2050C/DR-2050SP
Document Scanner. Make sure to read the manuals before attempting to use the
scanner. If you plan to use the DR-2050SP in Presentation mode, you should
read this manual together with the DR-2050SP User’s Guide Presentation
Mode Edition.
DR-2050C
DR-2050SP
1. DR-2050C/DR-2050SP Easy Start Guide
provided
provided
2. DR-2050C/DR-2050SP User’s Guide (this
manual)
provided
provided
—
provided
3. DR-2050SP User’s Guide Presentation
Mode Edition
The following describes the manuals packaged with the scanner. Before you
start using the scanner, be sure to read this User’s Guide.
Easy Start Guide
This manual describes the procedure for removing the scanner from its box
through to setting up the scanner for scanning.
User’s Guide (this guide)
This manual describes the basic operations for using the scanner, performing
routine maintenance, and troubleshooting, and provides the scanner
specifications.
DR-2050SP User’s Guide Presentation Mode Edition
This manual describes how to use the Canon DR-2050SP Document Scanner
in the Presentation mode. Make sure to read this manual before attempting to
use the presentation mode.
INTRODUCTION
1
Chapter
INTRODUCTION
Symbols Used in This Manual
The following symbols are used in this manual to explain procedures,
restrictions, handling precautions, and instructions that should be observed for
safety.
WARNING
Indicates a warning concerning operations that may lead to death
or injury to persons if not performed correctly. To use the machine
safely, always pay attention to these warnings.
CAUTION
Indicates a caution concerning operations that may lead to injury
to persons, or damage to property if not performed correctly. To
use the machine safely, always pay attention to these cautions.
IMPORTANT
Indicates operational requirements and restrictions. Be sure to read these items
carefully to operate the machine correctly, and avoid damage to the machine.
Note
Indicates a clarification of an operation, or contains additional explanations for
a procedure. Reading these notes is highly recommended.
2
INTRODUCTION
INTRODUCTION ...................................................................... 1
Manuals for the Scanner ............................................................... 1
Symbols Used in This Manual ....................................................... 2
Chapter 1
Before Using the Scanner ................................. 5
1. Important Safety Instructions ..................................................... 6
Installation Location ................................................................ 6
Power ...................................................................................... 7
Moving the Scanner ................................................................ 7
Remote Control (DR-2050SP only) ......................................... 8
Handling .................................................................................. 8
Disposal ................................................................................ 10
2. Features ................................................................................... 11
3. Names and Functions of Parts ................................................ 13
4. Installation Requirements ........................................................ 15
5. About the Setup Disc ............................................................... 17
Chapter 2
Using the Scanner ........................................... 19
1. Documents ...............................................................................
2. Preparing the Trays .................................................................
Setting Up the Document Feed Tray ....................................
Using the Document Guide Adapter .....................................
Using the Feed Extension Plate ............................................
3. Placing a Documents ...............................................................
How to Feed with the Page Separation Mode ......................
How to Feed with the Bypass Mode .....................................
Scanning Folio (Folded Document) ......................................
4. Scanning Documents ...............................................................
Using CapturePerfect 3.0 ......................................................
Using the Job Function .........................................................
Setting the Event Function ....................................................
5. Clearing a Paper Jam ..............................................................
6. Scanning Hints .........................................................................
7. Software Settings .....................................................................
ISIS Driver Settings ...............................................................
TWAIN Driver Settings ..........................................................
Job Registration Tool Settings ..............................................
Chapter 3
20
21
21
22
22
23
23
26
27
28
28
34
37
42
44
49
50
52
54
Appendices ....................................................... 57
1. Regular Maintenance ...............................................................
Cleaning the Scanner ...........................................................
Cleaning Inside the Scanner .................................................
Cleaning the Scanning Glass and the Rollers ......................
Cleaning the Metal Rollers ....................................................
Contents
58
58
58
59
61
3
Chapter
Contents
2. Removing and Attaching the Rollers .......................................
Roller Replacement Cycle ....................................................
Resetting the Counter ...........................................................
Removing and Attaching the Feed Roller .............................
Removing and Attaching the Retard Roller ...........................
3. Troubleshooting .......................................................................
The Scanner Does Not Turn ON ...........................................
The Scanner Is Not Recognized ...........................................
Slow Scanning Speed ...........................................................
Scanning Is Not Performed ...................................................
Documents Are Not Fed Correctly ........................................
Paper Is Not Ejected Correctly ..............................................
Saved Image Files Do Not Open ..........................................
Scanning Results Are Not as Expected ................................
4. Uninstalling Software ...............................................................
Uninstalling the ISIS/TWAIN Driver/Job Registration Tool ....
Uninstalling CapturePerfect 3.0 ............................................
5. Specifications ...........................................................................
Specifications ........................................................................
62
62
63
65
68
72
72
72
73
74
74
75
75
75
78
80
82
84
84
Index ...................................................................................... 87
4
Contents
Chapter 1
Before Using the Scanner
1. Important Safety Instructions .............. 6
Installation Location ..................................... 6
Power .......................................................... 7
Moving the Scanner .................................... 7
Remote Control (DR-2050SP only) ............. 8
Handling ...................................................... 8
Disposal ..................................................... 10
2.
3.
4.
5.
Features ...............................................
Names and Functions of Parts ..........
Installation Requirements ..................
About the Setup Disc .........................
11
13
15
17
1. Important Safety Instructions
To ensure the safe operation of this scanner, be sure to read the safety warnings
and precautions described below.
Installation Location
The performance of this scanner is affected by the environment in which it is
installed. Make sure that the location where the scanner is installed meets the
following environmental requirements.
At least 3.9" (100 mm)
At least 3.9"
(100 mm)
At least 3.9"
(100 mm)
• Provide adequate space around the scanner for operation and maintenance,
and for ventilation.
• Provide adequate space behind the scanner in order to eject scanned
documents to the front of the scanner.
• Avoid installing the machine in direct sunlight. If this is unavoidable, use
curtains to shade the scanner.
• Avoid locations where a considerable amount of dust accumulates.
• Avoid warm or humid locations, such as in the vicinity of a water faucet,
water heater, or humidifier, and avoid locations where the fumes from
ammonia, paint thinner, or other volatile chemicals may be present.
• Avoid locations where ammonia gas is emitted.
• Avoid locations near volatile or flammable materials, such as alcohol or
paint thinner.
• Avoid locations that are subject to vibration.
• Avoid exposing the scanner to rapid changes in temperature. If the room in
which the scanner is installed is cold but rapidly heated, water droplets
(condensation) may form inside the scanner. This may result in a noticeable
degradation in scanning quality.
The following conditions are recommended for optimal scanning quality:
Room temperature: 10 °C to 32.5 °C (50 °F to 90.5 °F)
Humidity:
20% to 80% RH
• Avoid installing the scanner near equipment that generates a magnetic field
(e.g. speakers, televisions, or radios).
6
Before Using the Scanner
• Connect only to a power outlet of the rated voltage and power supply
frequency. (either 120 V, 60 Hz or 220-240 V, 50/60 Hz depending on your
region)
• Do not connect other electrical equipment to the same power outlet to which
the scanner is connected. Also, when using an extension cord, make sure that
the extension cord is rated for the current requirements of the scanner.
• Never try to disassemble the AC adapter or modify it in any way, as this is
extremely dangerous.
• The power cord and AC adapter may become damaged if they are often
stepped on or if heavy objects are placed on them. Continued use of a
damaged power cord and AC adapter can lead to an accident, such as a fire
or electrical shock.
• Do not use the power cord while it is coiled.
• Do not pull directly on the power cord. When disconnecting the power cord,
grasp the plug and remove it from the outlet.
• Keep the area around the power plug clear of objects so that the power cord
can be disconnected easily in an emergency.
• Use only the AC adapter provided with this scanner. Also, do not use the AC
adapter provided with the scanner with any other electrical devices.
Model: MG1-3607
• If you have any questions regarding the power supply, contact your local
authorized Canon dealer or service representative for further information.
Moving the Scanner
• When moving the scanner, always hold it with both hands to avoid dropping
it. The scanner weighs approximately 5.5 lb (2.5 kg).
• Before moving the scanner, make sure to disconnect the interface cables and
AC adapter. If the scanner is transported with these items connected, the
plugs and connectors may be damaged due to excessive force applied to
them during movement.
Before Using the Scanner
7
Chapter 1
Power
Remote Control (DR-2050SP only)
• Do not leave the remote control on the floor, as damage may result if it is
stepped on.
• Do not disassemble the remote control.
• Take care not to misplace the remote control.
• Do not drop or cause physical shock to the remote control.
• Do not use any remote control other than the one provided with the scanner.
Also, do not use the remote control with any other product.
• Remove the batteries from the remote control when it is not in use for
extended periods of time.
• When replacing the remote control batteries, replace both batteries together.
• Insert the positive (+) and negative (-) poles of the batteries correctly.
• Do not combine old and new batteries, or batteries of different types.
• Do not use Ni-Cd or Ni-MH batteries.
• Make sure to comply with local regulations when disposing of batteries used
for the remote control.
Handling
WARNING
Note the following precautions whenever using the scanner.
Failure to do so may result in a fire or electric shock.
• Never use alcohol, benzene, paint thinner, aerosol sprays, or any
other highly flammable substance near the scanner.
• Do not cut, damage, or modify the power cord or AC adapter. Do
not place heavy objects on the power cord or AC adapter, and do
not pull or excessively bend the power cord.
• Never connect the power cord when your hands are wet.
• Do not connect the scanner to a multi plug power strip.
• Do not knot or coil the power cord as this may result in a fire or
electric shock. When connecting the power cord, make sure that
the power plug is securely and completely inserted into the
power outlet.
• Do not use power cords and AC adapters other than the power
cord and AC adapter provided with this scanner.
• Never try to take the scanner apart or modify it in any way.
• Never try to take the AC adapter apart or modify it in any way, as
this is dangerous and may lead to a fire or electric shock.
• Do not use flammable aerosol sprays products near the scanner.
• When cleaning the scanner, turn the power switch OFF and
disconnect the power cord from the power supply.
• Clean the scanner using a slightly dampened cloth which has
been well wrung out. Never use alcohol, benzene, paint thinner,
or any other flammable substances.
8
Before Using the Scanner
CAUTION
• Do not install the scanner on a surface that is unstable or tilted,
or in an area subject to excessive vibrations, as this may cause
the scanner to fall, resulting in personal injury or damage to the
scanner.
• Do not block the ventilation openings. Doing so could cause the
scanner to overheat, creating a risk of fire.
• Never place small metal objects such as staples, paper clips, or
jewelry on the scanner. These items may fall into the scanner,
and cause a fire or electric shock. Should such objects ever fall
inside the scanner, immediately turn the power switch OFF, and
disconnect the power plug from the power outlet. Then, contact
your local authorized Canon dealer or service representative to
have the unit serviced.
• Do not locate the scanner in a humid or dusty location. Doing so
might cause fire or electric shock.
• Do not place objects on top of the scanner. Such objects may tip
or fall over, resulting in personal injury.
• To prevent any risk of fire or electric shock, make sure that the
power source meets the power requirements of the unit.
• When unplugging the power cord, grasp it firmly by its plug. Do
not pull directly on the power cord, as this may damage or
expose the cord’s internal wiring, resulting in a fire or electric
shock.
• Leave sufficient space around the power plug so that it can be
unplugged easily. If objects are placed around the power plug,
you will be unable to unplug it in an emergency.
• Do not allow water or flammable substances (alcohol, paint
thinner, benzene, etc.) to spill into the scanner, as this may
result in a fire or electric shock.
Before Using the Scanner
9
Chapter 1
• If the scanner makes strange noises, or gives off, smoke, heat,
or strange odors, or the scanner does not function or other
abnormalities occur when you use the machine, immediately
turn the power switch OFF, and disconnect the power plug from
the power outlet. Then, contact your local authorized Canon
dealer or the service representative for further information.
• Do not drop the scanner, or subject it to impact or strong shock.
Should the scanner ever become damaged, immediately turn the
power switch OFF, and disconnect the power plug from the
power outlet. Then, contact your local authorized Canon dealer
or service representative to have the unit serviced.
• Before moving the scanner, be sure to turn the power switch
OFF, and disconnect the power plug from the power outlet.
• Turn OFF the power switch for safety when not using the
scanner for a long period of time, such as overnight. Also, turn
OFF the power switch, and disconnect the AC adapter from the
scanner and disconnect the power cord from the power outlet
for safety when the machine will not be used for an extended
period of time, such as during consecutive holidays.
• Do not wear loose clothing or jewelry that may get caught in the
scanner while you are using it. This may result in personal
injury. Be extra careful of neckties and long hair. If anything
becomes caught in the scanner, immediately disconnect the
power cord to stop the scanner.
Disposal
• When disposing of this scanner, be sure to follow all local ordinances and
laws or consult with the retailer who sold you the scanner.
• If you are using the DR-2050SP, make sure to comply with local regulations
when disposing of batteries used for the remote control.
10
Before Using the Scanner
Chapter 1
2. Features
The main features of the DR-2050C/DR-2050SP document scanner are
described below.
„ Compact Configuration
The scanner has a very compact configuration, measuring only 11.7"
(298 mm) (W) × 7.7" (197 mm) (H) × 3.9" (100 mm) (D). The small
footprint of this standup vertical scanner saves space.
„ Fast Document Feeding
The scanner can scan a maximum of 20 documents per minute in a range of
sizes from business cards to LTR/A4 size. (Scanning conditions: Black and
white, LTR/A4 size portrait, two sided, 200 dpi.)
„ USB 2.0 Interface
Connect the scanner to a computer with Hi-Speed USB 2.0 protocol.
„ Color/Grayscale Support
Documents can be scanned in 24-bit color or 256-level grayscale.
„ Supports a Variety of Scanning Modes
The scanner supports the following scanning modes, depending on the
document type:
• Single-sided/double-sided mode
• Single sheet/dual feeding path
„ Paper Size Detection
The size of scanned documents is automatically detected, and images of
non-standard size documents are saved with the unwanted margin around
the document removed.
„ Folio Scan
A folio (folded in half) document can be set for scanning as it is, and the
scanned images of both sides are combined as a single image. (See p. 27.)
„ Deskew
If a document is fed through the scanner as crooked, the scanned image is
corrected so that it is aligned as straight.
„ Text enhancement mode
The “Text Enhanced” mode is used to make text easier to read if the
background of the document is dark or the text is written lightly in pencil.
The “Advanced Text Enhancement II” mode is used to make text easier to
read if the background and text are similar colors are both light colors.
* May not function well depending on the document.
„ Dropout Color
The scanner is equipped with a Dropout Color function that allows you to
specify a color for the scanner to omit from scanned images.
Before Using the Scanner
11
„ Skip Blank Page Function
The scanner is equipped with a Skip Blank Page function that allows it to
scan a document regardless of whether every document is double-sided or
single-sided.
„ Prescan Function
The scanner is equipped with a Prescan function that allows you to adjust
the contrast and brightness of a prescanned image and then send the
adjusted image to the application software, without needing to scan the
document again.
„ Auto Start
The scanner is equipped with an Auto Start function that automatically
initiates scanning when a document is placed in the document feed tray.
„ Compatible with Carbonless Duplicating Paper
The scanner is able to scan carbonless duplicating paper.
„ Energy Saving Mode
This scanner is compatible with the International Energy Star Program, and
is designed to save power by using the energy saving feature except when
scanning is being performed.
„ Presentation mode (DR-2050SP only)
The scanner can project scanned images onto a screen from a projector
directly connected to the scanner without using a computer. For more details
see the DR-2050SP User’s Guide Presentation Mode Edition.
Note
Certain functions may not be available depending on the software you are
using.
12
Before Using the Scanner
This section describes the name and function of each part. Make sure to read
this section and familiarize yourself with the parts of the scanner before using
the scanner. For part names and their functions of the DR-2050SP, see the DR2050SP User’s Guide Presentation Mode Edition.
„ Front/Right Side
Upper Cover
Open when you need to set a document in the scanner.
Power Indicator
Lights green when
the scanner is turned
ON.
Scan Button
Press to start
document scanning.
Document Feed
Tray
Open this tray to
place your
documents into the
feeder. (See p. 21.)
Document Eject
Opening
Scanned documents
are output to the
document eject
opening.
Stop Button
Press to cancel
document scanning.
(Feed Mode:
Panel + Auto)
Feed Indicator
Indicates the Feed
Selection Lever
position.
Feed Selection Lever
Use it to set the way the documents are fed. To feed a multipage document one page at a time, lower the lever (Page
Separation mode). To feed bound documents, such as invoices,
without separating them, raise the lever (Bypass mode).
„ Front (Upper Cover and Document Feed Tray open)
Document Guide Adapter
When documents are
skewed, insert the adapter
into the document guide.
Feed Extension Plate
Pull out this plate if
documents tend to
fall forward.
Front Unit
Open when
clearing a paper
jam or cleaning
inside.
Document Feed Opening
Place the document to be
scanned here.
Document Guide
Adjust them to align with
the width of the document.
OPEN Knob
Use this knob to
open the front unit.
Before Using the Scanner
13
Chapter 1
3. Names and Functions of Parts
„ Back/Left Side
Ventilation
Openings
USB Connector
Connect the included USB
cable or one that supports
Hi-Speed USB 2.0.
Power Connector
Connect the AC adapter that
is provided with the scanner.
Power Switch
Turns the scanner
ON and OFF.
(OFF)
(ON)
Kensington Slot
Used for anti-theft measures.
Theft can be prevented by
attaching a chain, etc.
CAUTION
Make sure that ventilation openings are not blocked. Blocked
openings can cause internal heat build up, creating the risk of fire.
„ Conventions
indicating page-by-page feeding
of document (Page Separation
mode).
indicating multi-page document
alignment.
indicating document setting
method (center position, front/
back, feed direction).
14
Before Using the Scanner
To use the DR-2050C/DR-2050SP, your computer must satisfy the following
system requirements.
• One of the following operating systems:
- Microsoft Windows 98SE
- Microsoft Windows Me
- Microsoft Windows 2000 Professional SP4 or later
- Microsoft Windows XP Professional SP2 or later
- Microsoft Windows XP Home Edition SP2 or later
• Microsoft Windows XP Professional x64 Edition
• Microsoft Windows Vista Home Basic
• Microsoft Windows Vista Home Premium
• Microsoft Windows Vista Business
• Microsoft Windows Vista Ultimate
• Microsoft Windows Vista Enterprise
• A computer that meets the following specifications:
- CPU: Intel Celeron 733 MHz or faster
- Memory: 256 MB or more
- Hard disk: 512 MB or more available space
- CD-ROM drive
- Hi-Speed USB 2.0 interface
- Monitor: Resolution of 1024 × 768 (XGA) or better recommended.
• USB interface connections vary according to the operating system as shown
below.
- Windows 98SE/ME: USB Full-Speed (equal to USB 1.1)
- Windows 2000/XP: Hi-Speed USB 2.0/USB Full-Speed (equal to USB
1.1)
- Windows Vista: Hi-Speed USB 2.0
• An ISIS-compatible application or a TWAIN-compatible application that is
compatible with the above operating systems.
IMPORTANT
• If you do not know the requirements for your computer system, contact the
store where you purchased the computer or the manufacturer of the
computer for more information.
• Use the most recent version of the USB 2.0 driver provided by Microsoft.
Contact your local authorized Canon dealer or service representative for
more detailed information.
• Not all USB interfaces provided as standard with personal computers are
guaranteed. Contact your local authorized Canon dealer for more detailed
information.
Before Using the Scanner
15
Chapter 1
4. Installation Requirements
• Scanning speeds are lower if your computer’s standard USB interface is
USB Full-Speed (equal to USB 1.1).
• Use the USB cable provided with the scanner, or a Hi-Speed USB 2.0
compatible cable.
• If the CPU, memory, interface card, and other specifications do not satisfy
the installation requirements, the scanning speed may be greatly reduced and
transmission may take a long time.
• Even if the computer satisfies the recommended specifications, the scanning
speed may vary, depending on the scan settings.
• The ISIS/TWAIN Drivers provided with the scanner do not necessarily
operate on all ISIS- or TWAIN-compatible applications. For details, contact
your application software retailer.
16
Before Using the Scanner
Chapter 1
5. About the Setup Disc
The Canon DR-2050 series scanner setup disc contains the software listed
below:
• DR-2050C Driver
Scanner driver for use with the DR-2050C/DR-2050SP scanner, and the Job
Registration Tool.
• CapturePerfect 3.0
ISIS-compatible application developed for Canon document scanners.
Note
The following shows how the DR-2050 series setup disc is configured.
For instructions on how to install the software included on the setup disc, see
the Easy Start Guide.
Menu screen
Typical Installation
* All of the indicated software is installed.
Read the manual
Custom Installation
* The “Easy Start Guide”, “User’s Guide”
and “CapturePerfect 3.0 Operation
Guide” provided with the scanner.
* Only the software selected in the
checkboxes is installed.
Before Using the Scanner
17
18
Before Using the Scanner
Chapter 2
Using the Scanner
1. Documents .......................................... 20
2. Preparing the Trays ............................ 21
Setting Up the Document Feed Tray ......... 21
Using the Document Guide Adapter .......... 22
Using the Feed Extension Plate ................ 22
3. Placing a Documents ......................... 23
How to Feed with the Page
Separation Mode ....................................... 23
How to Feed with the Bypass Mode .......... 26
Scanning Folio (Folded Document) ........... 27
4. Scanning Documents ......................... 28
Using CapturePerfect 3.0 .......................... 28
Using the Job Function .............................. 34
Setting the Event Function ........................ 37
5. Clearing a Paper Jam ......................... 42
6. Scanning Hints ................................... 44
7. Software Settings ............................... 49
ISIS Driver Settings ................................... 50
TWAIN Driver Settings .............................. 52
Job Registration Tool Settings .................. 54
1. Documents
This scanner can scan documents ranging in size from business cards and
checks to LTR/A4 size documents. The size of documents that can be scanned
is shown below.
For Page Separation mode (continuous feed) (See “How to Feed with the
Page Separation Mode,” on p. 23.)
Width: 2.16" to 8.5" (55 mm to 216 mm)
Length: 2.75" to 11.6" (70 mm to 297 mm)
Weight: 14 to 32 lb bond (52 to 128 g/m2)
0.0024" to 0.0059" (0.06 mm to 0.15 mm)
For Bypass mode (single-sheet feed) (See “How to Feed with the Bypass
Mode,” on p. 26.)
Width: 2.16" to 8.5" (55 mm to 216 mm)
Length: 2.75" to 13.9" (70 mm to 355 mm)
Weight: 11 to 40 lb bond (42 to 157 g/m2)
0.0020" to 0.0079" (0.05 mm to 0.20 mm)
IMPORTANT
A document must meet the following criteria to be scannable:
• When scanning a multipage document, pages must be grouped together so
that they have the same size, thickness, and weight. Scanning different types
of paper at one time can cause the scanner to jam.
• Always make sure that the ink on a document is dry before scanning it.
Scanning documents with the ink still wet may soil the rollers or scanning
glass, cause lines or smudges to appear on images, or dirty other documents.
• Always clean the rollers or scanning glass after scanning a document written
in pencil. Scanning documents with pencil written on them may soil the
rollers or scanning glass, cause stripes to appear in images, or dirty other
documents.
• When scanning a two-sided document that is printed on thin paper, the image
on the opposite side of each page may show through. Adjust the brightness
in the scanning conditions before scanning the document.
• Scanning the following types of documents can cause a paper jam or
malfunction. To scan such a document, make a photocopy of the document
and then scan the photocopy.
20
Wrinkled or
creased documents
Extremely thin,
translucent paper
Paper with square
holes
Curled paper
Carbon paper
Documents with
paper clips or staples
Torn documents
Coated paper
Using the Scanner
2. Preparing the Trays
Prepare the document feed tray in accordance with the document size and type.
Chapter 2
Setting Up the Document Feed Tray
Pull the document feed tray towards you to open it.
In the case of a short document, open the upper cover.
Using the Scanner
21
Using the Document Guide Adapter
When a document becomes skewed during scanning or when scanning a
document that is folded in half (See p. 27.), install the document guide adapter
on the document guide to keep the document from becoming skewed.
Install the document guide adapter by positioning it as shown in the
illustration. Insert the legs of the document guide adapter as far as they go into
the document guide.
Note
If document skew is not remedied by installing the document guide adapter, set
deskew to on in the ISIS/TWAIN driver settings. (See p. 49.)
Using the Feed Extension Plate
Under the following conditions, install the document guide adapter, set the
document in the scanner, and then pull out the feed extension Plate.
• When the document falls forward
• When the document tends to bend forward because the paper is very thin,
etc.
22
Using the Scanner
There are two methods for paper separation, called the Page Separation mode
and Bypass mode for feeding documents. Feeding documents continuously
from a stack of documents placed in the feed tray is called the Page Separation
mode. Feeding documents one sheet at a time by hand or feeding multiple
sheet documents, such as invoices that are attached at one end, is called the
Bypass mode. The document feed method can be switched by moving the feed
selection lever.
IMPORTANT
• Before you place a document, check to make sure it does not contain paper
clips, staples, or other small metal objects. These objects may damage the
document, or cause a paper jam or scanner malfunction.
• Do not wear loose clothing or jewelry that may get caught in the scanner
while you are using it. This may result in personal injury. Be extra careful of
neckties and long hair. If anything becomes caught in the scanner,
immediately disconnect the power cord to stop scanning.
• Always smooth out any folds or curls in your originals before placing them
into the feeder. If the leading edge of a document is curled, it may cause a
paper jam.
How to Feed with the Page Separation Mode
1. Lower the feed selection lever (Page Separation mode).
Bypass mode
Page Separation
mode
Using the Scanner
23
Chapter 2
3. Placing a Documents
2. Adjust the document guide to the width of the document being scanned.
IMPORTANT
Do not hold the tips of the document guide adaptor when installing it. Doing so
can damage the document tray.
3. Fan the stack of documents to be scanned, and then angle the stack as shown in
the illustration so the top edge of the first page is the lowest. (Set the document
in the scanner with the top edge of the document facing downwards.)
123
123
4
4
ABC
ABC
CAUTION
Handle the document carefully when setting it in the scanner. The
edges of the paper can unexpectedly cut your hands.
24
Using the Scanner
4. Set the document in the scanner with the back of the document facing forward
Chapter 2
and its top edge facing downwards.
IMPORTANT
The document sheet capacity is 50 sheets of non-curled sheets. Note, however,
that the capacity is less when document pages are not being fed correctly.
5. Adjust the document guides so they match the width of the document.
Note
Before scanning, make sure that the document is loaded in the scanner
correctly. Scanning a curled document or a creased document can damage the
document.
6. Start scanning from the application.
IMPORTANT
• If the paper feed operation stops due to a system error or a paper jam while
the scanner is scanning, resolve the problem, make sure that the scanned
image of the last page that was fed has been stored, and then resume the
scanning operation.
• After you finish scanning, close the document feed tray and the upper cover
to prevent damage to the scanner while it is not being used.
Using the Scanner
25
How to Feed with the Bypass Mode
1. Raise the feed selection lever (Bypass mode).
Bypass mode
Page Separation
mode
2. Adjust the document guide to the width of the document being scanned.
3. Start scanning from the application.
4. Set the document in the scanner with the back of the document facing forward
and its top edge facing downwards.
The document is scanned as it is detected.
IMPORTANT
• When scanning documents that are fastened together, such as invoices, set
the edge that is fastened together as the leading edge.
• After you finish scanning, close the document feed tray and the upper cover
to prevent damage to the scanner while it is not being used.
26
Using the Scanner
Scanning Folio (Folded Document)
(Front)
Chapter 2
The scanner uses a folio scanning method to scan documents that are bigger
than LTR/A4 size (maximum A3 size). To do folio scanning, fold the
document in half and place it on the scanner. Both sides of the folded
document are scanned and combined into a single image.
(Back)
(Combined Image)
Note
• When doing folio scan, put the feed selection lever up (a in the figure
above) and attach the document guide adapter to keep the document straight.
(See p. 22.)
• To scan a folio document, place it on the scanner with the fold on the right
side (b in the figure above). The image on the front page of the folded
document appears as a composite image on the right half of the page. (c in
the figure above)
• When scanning a document that is folded in half, set scanning side in the
ISIS/TWAIN driver to [Folio]. (“ISIS Driver Settings g,” on p. 50,
“TWAIN Driver Settings g,” on p. 52)
• Combined images can be a maximum of A3 size. To use folio scan to scan
non-standard size documents, set “Page size” to [Auto-detection].
IMPORTANT
• When folding documents, align the left and right edges and crease the
document at the fold. The way the document is folded may cause paper jams
or misaligned images.
• The part of the document at the fold is not scanned. Take care when scanning
documents that have text or photos that go across the fold.
• Use manual feeding for folio scanning. Load the document one page at a
time.
• Align the paper side guides to the width of the document. If the paper side
guides are too wide the document may skew or images may be misaligned.
• Documents that are folded in half cannot be scanned when using the DR2050SP in the Presentation mode.
Using the Scanner
27
4. Scanning Documents
There are two methods of scanning documents using the DR-2050C/DR2050SP document scanner. You can scan from an application, such as
CapturePerfect 3.0, or you can use the Job function, which allows you to scan
by pressing the scan buttons on the operation panel, without starting up an
application.
This section describes the scanning flow of the CapturePerfect 3.0 application
and the Job Function.
For details on how to install each application and the driver, see the Easy Start
Guide.
Using CapturePerfect 3.0
CapturePerfect 3.0 is an ISIS-compatible application developed for Canon
document scanners.
CapturePerfect 3.0 includes the following modes. Select the desired scan mode
from the scan menu to perform scanning.
• Scan Batch to File
Documents are scanned with the preset scanning conditions, and the image
file is saved to the specified folder.
• Scan Batch to Print
Documents are scanned with the preset scanning conditions, and the scanned
image is printed on the specified printer.
• Scan Batch to Mail
Documents are scanned with the preset scanning conditions, the e-mail
software is started up, and the scanned image is attached to a new e-mail
message.
• Scan 1 Page
One sheet of the document is scanned according to preset scanning
conditions and scanning ends.
• Scan Job
The scanning conditions and scan mode (Scan Batch to File, Scan Batch to
Print, or Scan Batch to Mail) are registered in advance as a job. The scan job
can then be performed by selecting the registered job from the drop-down
list (a) and pressing
(Scan JOB) on the toolbar (b).
b
28
Using the Scanner
a
• Scan to Presentation Mode
This mode is handy when the scanner is used in environments, such as
conference halls, where it can be connected to large displays or projectors.
CapturePerfect 3.0 is switched to full-screen display, the document is
scanned, and the scanned image is displayed at full size on the screen.
Projector
The scanned image is
projected onto the screen.
DR-2050C/
DR-2050SP
Scan to Presentation Mode
Scan to Presentation Mode
Note
For instructions on how to use CapturePerfect 3.0, see the CapturePerfect 3.0
Operation Guide and CapturePerfect Help. Be sure to read the CapturePerfect
3.0 Operation Guide and CapturePerfect Help before you use CapturePerfect
3.0.
CapturePerfect 3.0 Operation Procedure
This section describes how to start up CapturePerfect 3.0, select the scanner,
and the procedure up to scanning with Scan Batch to File.
For details, see the CapturePerfect Operation Guide and CapturePerfect Help.
1. Click the Windows [Start] button, and then click [Programs] ([All Programs]
for Windows XP) Æ [CapturePerfect 3.0] Æ [CapturePerfect 3.0].
Using the Scanner
29
Chapter 2
Note
The following two jobs are already registered as scan jobs.
• Color Document
Document is scanned in 24 bit color, as Simplex 300 dpi and then saved in
[My Pictures] in the My Documents folder.
• Binary Document
Document is scanned in black and white, as Simplex 200 dpi and then saved
in [My Pictures] in the My Documents folder.
CapturePerfect 3.0 starts up.
2. Follow the procedure below to select the Canon DR-2050C document scanner
as the scanner to be used.
1. On the [Scan] menu, click [Select Scanner].
30
Using the Scanner
Note
If [CANON DR-2050C] is not displayed in the list of scanners, re-install the
ISIS/TWAIN driver. (See “Step 3. Installing the Software” in the Easy Start
Guide.)
3. Set the “Default Page Size”.
Note
This dialog box is displayed only when you select [CANON DR-2050C] for
the first time and you click the [OK] button, or when you click [Settings] on
the [Select Scanner].
3. On the [Scan] menu, click [Scanner Setting].
Driver basic setup dialog box opens.
Using the Scanner
31
Chapter 2
2. Select [CANON DR-2050C] Æ click the [OK] button.
4. Set the scan settings.
For details setting the scanning settings, see “ISIS Driver Settings,” on p. 50,
and ISIS/TWAIN Driver Help.
5. Place your document. (See “Placing a Documents,” on p. 23.)
6. On the [Scan] menu, select [Scan Batch to File].
32
Using the Scanner
Chapter 2
The [Scan Batch to File Setting] dialog box opens.
For more details on how to scan documents, see the CapturePerfect Operation
Guide and CapturePerfect Help.
7. Specify the file name and the file type for saving the image data, and click
[Save] to start scanning.
For details on the available settings in the [Scan Batch to File Setting] dialog
box, see the CapturePerfect Operation Guide and CapturePerfect Help.
8. When there are no more document sheets to scan, scanning stops and the
Continue dialog box is displayed. To continue scanning, click [Continue
scanning], and to stop scanning, click [Stop scanning].
9. After scanning is complete, select [Exit] on the [File] menu to quit
CapturePerfect 3.0.
Using the Scanner
33
Using the Job Function
The job function allows you to scan merely by pressing the [Scan] button on
the scanner according to the Windows event function and job tools.
Scanned image data is automatically processed by the function registered to
the [Job] button by the Job Registration Tool.
Select and register one of the following four functions to the [Scan] button.
• Save as file
Scanning is performed according to preset scanning conditions, and image
files are saved to a specified folder.
• Print
Scanning is performed according to preset scanning conditions, and image
files are output on a specified printer.
• Attach to E-mail
Scanning is performed according to preset scanning conditions, e-mail
software is started up, and scanned images are attached to a new e-mail.
• Launcher
The application selected by [Setting the Event Function] (See p. 37.) is
started up.
Save as file
Image files are saved
to a specified folder.
Print
Image files are printed
on a specified printer.
Attach to E-mail
e-mail software is started up
and image files are attached to
a new e-mail massage.
(mail server)
(network)
Scan button
DR-2050C/
DR-2050SP
34
Using the Scanner
Launcher
The specified application is
started up.
The following describes the procedure from starting up Job Registration Tools
through to execution of a job scan. For details on setting up the Job
Registration Tool, refer to “Job Registration Tool Settings” (See p. 54.) and the
Job Registration Tool Help.
When [Launcher] is selected, events must be set. (See “Setting the Event
Function,” on p. 37.)
1. Click the [Start] button, and then click [Programs] ([All Programs] if you are
using Windows XP) Æ [Canon DR-2050C] Æ [Job Registration Tool].
The Job Registration Tool starts up.
Note
• Job Registration Tool is a TWAIN compatible application that is installed
with the ISIS/TWAIN driver.
• You can register jobs for numbers 1 through 10. The job for the icon that is
colored is executed when the scan button is pressed.
Using the Scanner
35
Chapter 2
Job Scan Procedure
2. Set up the Job Registration Tool.
For details on setting up the Job Registration Tool, refer to “Job Registration
Tool Settings” (See p. 54.) and the Job Registration Tool Help.
Note
• You can register jobs for numbers 1 through 10.
• When [Launcher] is selected, set the events. (See “Job Registration Tool
Settings,” on p. 54.)
3. Use the scan button to select the job you want to execute from the registered
jobs, and then click the icon (
) in the No. frame.
When you click the icon of the No. to which a job is registered the icon appears
colored. (
)
Note
The job with the colored icon is executed when the scan button is pressed.
4. Click [Close] to close the [Job Registration Tool].
5. Place the document. (See “Placing a Documents,” on p. 23.)
6. Press the [Scan] button.
Scan button
36
Using the Scanner
Chapter 2
“Monitor for DR2050C” is displayed and the scan is executed.
7. When there are no more document sheets, the image data is transferred
according to the specified conditions.
[Sending complete] is displayed on the “Monitor for DR2050C.”
8. Click [Close] to close the “Monitor for DR2050C.”
Setting the Event Function
By setting [Events], you select the application to be started up when
[Launcher] is selected in Job Registration Tool.
1. Use the following procedure to open the [Event settings] dialog box.
1. Click the [Start] button, and then click [Settings] on the [Start] menu Æ
click [Control Panel]. (For Windows XP, click the [Start] button Æ click
[Control Panel].)
Using the Scanner
37
2. For Windows XP, switch the Control Panel to Classic View, or select
[Printers and Other Hardware] in the working field.
Control Panel (category view)
Control Panel (classic view)
3. Click [Scanners and Cameras].
38
Using the Scanner
Printers and Other Hardware
Chapter 2
4. Select [CANON DR-2050C USB], and then click [Properties].
5. Click the [Events] tab.
Using the Scanner
39
2. Select [Scan] button from the [Scanner events] drop-down list.
3. At [Send to this application] unmark the applications that are not to be started
up, and click [Apply].
4. Click [OK] to close [CANON DR-2050C USB Properties].
5. Restart Windows to enable the new settings for the event function.
40
Using the Scanner
Chapter 2
Note
• When two or more applications are marked at [Send to this application], the
application selection dialog box will be displayed when [Launcher] in the
[Job Tools] dialog box is selected, and the [Scan] button is clicked.
• Certain applications may not run normally when started as an event.
• To disable use of events, mark the [Disable device events] checkbox.
Using the Scanner
41
5. Clearing a Paper Jam
When paper jams occur during scanning, use the following procedure to clear
them.
CAUTION
When removing jammed paper, take care not to cut your hands on
the edges of the paper.
1. Remove any documents from the document feed tray.
2. Pressing the OPEN knob from both sides (a), pull the front unit forward to
open it (b).
3. Remove the jammed document from the feed side or the output side.
42
Using the Scanner
4. Gently press the left and right sides of the top of the Front Unit. Be sure that
the upper unit is completely closed by pushing on both edges with both hands
until you hear a click.
Note
After removing the jammed paper, check to see if the last page of your
document was scanned correctly, and then continue scanning.
Using the Scanner
43
Chapter 2
IMPORTANT
If you are removing the document manually, make sure to remove the
document carefully, by pulling on it steadily and without applying too much
force. Should the paper tear, make sure to remove any torn pieces remaining in
the scanner.
6. Scanning Hints
This section describes helpful hints for setting up and using your scanner.
Refer to these hints when you set up the ISIS/TWAIN driver. For more details
on items not described in this section, see “Software Settings,” on p. 49.
Scanning Double-sided Documents
• I want to scan a double-sided document.
Set Scanning Side to [Duplex].
See “ISIS Driver Settings g,” on p. 50, and “TWAIN Driver Settings g,”
on p. 52.
Scanning Non-standard Size Documents
• I want to scan non-standard size documents
When a non-standard size document is scanned with a standard size
specified, a black margin around the scanned image. If you want to scan
nonstandard size documents, set “Page Size” to [Auto-detection]. The size of
the document is automatically detected.
See “ISIS Driver Settings c,” on p. 50, and “TWAIN Driver Settings c,”
on p. 52.
• I want to register non-standard size documents
A non-standard document size can be registered as a Custom Paper Size.
See “ISIS Driver Settings l,” on p. 50, and “TWAIN Driver Settings l,”
on p. 52.
• I want to scan only part of a document
The scan area can be specified before scanning. Note, however, that the scan
area cannot be specified when “Page Size” is set to [Auto-detection].
See “ISIS Driver Settings m,” on p. 50, and “TWAIN Driver Settings m,”
on p. 52.
44
Using the Scanner
• I want to divide a document that cannot be placed all at once into
multiple stacks and scan them as a single file
Set the “Feeding Option” in the Scanner Settings to [Automatic Feeding].
When the scanner detects a document, scanning starts automatically, and you
can continue scanning batches until your job is complete.
When “Feeding Option” is set to [Panel-Feeding], scanning does not start
until you place your document and press Scan button. This is handy when
you need to align the edges of the document after it has been placed.
See “ISIS Driver Settings h,” on p. 50, and “TWAIN Driver Settings h,”
on p. 52.
• I want to divide up scanned images by individual document
stacks to save as separate files
Set the “Feeding Option” to [Automatic Feeding] or [Panel-Feeding], and set
[Batch Separation] to [Auto]. (ISIS driver only)
See “ISIS Driver Settings h,” on p. 50, and “ISIS Driver Settings i,” on
p. 50.
• I want to scan a document one sheet at a time
Set the “Feeding Option” to [Automatic Feeding] or [Panel-Feeding] to scan
one sheet at a time. Scanning is interrupted after one page of the document is
scanned.
If the “Feeding Option” is set to [Automatic Feeding] and the next document
is loaded, the scanner starts scanning when it detects the next document.
If the “Feeding Option” is set to [Panel-Feeding] and the next document is
loaded, the scanner starts scanning when the Scan button is pressed.
See “ISIS Driver Settings h,” on p. 50, and “TWAIN Driver Settings h,”
on p. 52.
Using the Scanner
45
Chapter 2
Scanning Multiple Documents
Scanning Documents Containing Blank Sheets
• I want to skip blank sheets contained in a document stack.
Set “Scanning Side” to [Skip blank page]. [Double-sided scanning] is not
performed, and blank pages are skipped.
See “ISIS Driver Settings g,” on p. 50, and “TWAIN Driver Settings g,”
on p. 52.
• Blank sheets are not skipped even if [Skip blank page] is set.
Set a higher [Ratio of black pixels] value (adjust the slider towards the right).
If a low [Ratio of black pixels] value is set, blank sheets are sometimes not
skipped due to the background color or dirt on the document.
• Documents full of text are skipped as blank sheets.
Set a lower [Ratio of black pixels] value (adjust the slider towards the left).
If a high [Ratio of black pixels] value is set, even documents full of text are
sometimes skipped as blank sheets.
When a blank sheet is not skipped, adjust the slider to the right.
When a text document is skipped, adjust the slider to the right.
46
Using the Scanner
• I want to enhance text on a document with a dark background
Set “Mode” to [Text Enhancement]. The background of the document is
removed to enhance the text.
See “ISIS Driver Settings b,” on p. 50, and “TWAIN Driver Settings b,”
on p. 52.
• I want to enhance text on a document that has light text on a
light background
Set the scanning mode to [Advanced Text Enhancement II]. The background
is eliminated or processed out of the document and the text is enhanced.
See “ISIS Driver Settings b,” on p. 50, and “TWAIN Driver Settings b,”
on p. 52.
• I want to lessen the moire effect that occurs when color
documents, such as magazine photos, are scanned
Scan at a resolution of 400 dpi or less and at [256 shade grayscale] or [24 bit
smoothing colors]. This averages the image to suppress moire.
See “ISIS Driver Settings b,” on p. 50, and “TWAIN Driver Settings b,”
on p. 52.
• I want to skip specific colors
Specify the color to skip during scanning in [Color drop-out].
See “ISIS Driver Settings o,” on p. 50, and “TWAIN Driver Settings o,”
on p. 52.
• I want to enhance shadows from stamps
Select [Red Enhance] at Dropout Color.
See “ISIS Driver Settings o,” on p. 50, and “TWAIN Driver Settings o,”
on p. 52.
• I want to enhance image contours
Adjust the [Edge emphasis] setting.
See “ISIS Driver Settings q,” on p. 50, and “TWAIN Driver Settings q,”
on p. 52.
• I want to delete black borders around images
Check the [Border Removal] checkbox.
See “ISIS Driver Settings r,” on p. 50, and “TWAIN Driver Settings r,”
on p. 52.
• I want to scan documents in negative image
Mark the [Reverse Image] checkbox. (TWAIN driver only)
See “TWAIN Driver Settings s,” on p. 52.
Using the Scanner
47
Chapter 2
Adjusting Scanned Image
Prescan Function
• I want to preview the image before I scan it
For the ISIS driver, check the [Prescan] checkbox. The Prescan window is
displayed when scanning starts.
See “ISIS Driver Settings k,” on p. 50.
For the TWAIN driver, check the [Prescan] checkbox and click [Preview].
One sheet of the document is scanned, and the Prescan window is displayed.
See “ISIS Driver Settings j,” on p. 50, and “ISIS Driver Settings n,” on
p. 50.
Registering Settings
• I want to use preset scanning conditions again
Assign a name to the scanning conditions and register them as a user
preference. If you select the name of an already registered user preference,
the conditions you set overwrite the settings of the selected user preference.
See “ISIS Driver Settings a,” on p. 50, and “TWAIN Driver Settings a,”
on p. 52.
With CapturePerfect 3.0 Scan JOB function, the scan mode can also be
registered with the scanning conditions as a job, and scanning can be
performed by selecting the job and then executing the scan job.
48
Using the Scanner
7. Software Settings
ISIS Driver Settings.............................................................P. 50
TWAIN Driver Settings........................................................P. 52
Job Registration Tool Settings..........................................P. 54
Note
A “Quick Guide” containing the same content as this section of the PDF file
version of the User’s Guide is available on the setup disc. Print this guide and
keep it near the scanner as a reference.
Using the Scanner
49
Chapter 2
This section describes the setting items when setting the ISIS driver, TWAIN
driver, and Job Registration Tool. For a more detailed description, read the
Help files for each item.
ISIS Driver Settings
Save User Preferences
Basic Setup Dialog Box
a
b
c
d
e
f
Mode
g
Page Size
h
i
j
* [Contrast] is set automatically
when Black and White is
selected, and [Brightness]
and [Contrast] are set
automatically when Text
Enhanced is selected.
* The Smoothing mode options
are not displayed when [600
dpi] Dots per inch is
selected.
k
Batch Separation
Dots per inch
* Batch Separation is not
available when the [Standard
Feeding] Feeding Option is
selected.
Feeding Option
* The Delay setting is available
when the [Automatic Feeding]
Feeding Option is selected.
Scanning Side
Scan Area Dialog Box
* Blank pages for skipping
are determined using the
[Ratio of black pixels] value
selected.
Custom Page Size registration
l
m
n
Unit
* Area setting is not available when the [Auto-detection] Page Size is selected.
* Scanning of the specified area may be shifted when Deskew is enabled.
Advanced Settings Dialog Box
Drop-out color
o
p
Gamma Data
q
r
Select
s
Scanner Adjustment is a function used to adjust the
reference values of the scanner when abnormalities occur
within the scanned images. Do not execute when the
scanner is functioning properly.
50
Using the Scanner
* When the [Custom] Gamma
Data is selected, the [Autodetection] Page Size, [Skip
blank page] Scanning Side,
and Deskew options are not
available, and [Brightness]
and [Contrast] are set
automatically.
a User Preference
Name and save your settings.
) Names can consist of up to 32 characters.
b Mode
Selects the scanning mode.
) [Text Enhanced] and [Advanced Text
Enhancement II] process the
background of a document so the text is
enhanced and easier to read.
) The Smoothing Gray/Color options
used to smooth images and reduce
moiré patterns are available when [400
dpi] Dots per inch or below is selected.
c Page Size
Selects the size of the pages to be scanned.
) Selecting [Auto-detection] causes
automatic page size detection when
scanning.
d Dots per inch
Selects scanning resolution.
e Brightness
Adjusts brightness of scanned images.
[Brightness] is set automatically when the
Text Enhanced mode is selected.
f Contrast
Adjusts contrast of scanned images.
[Contrast] is set automatically when the
Black and White or Text Enhanced mode is
selected.
g Scanning Side
Specifies the side of the document to scan.
) When [Skip blank page] is selected,
images are skipped if they are
determined blank based on the [Ratio of
black pixels] value.
) When [Folio] is selected, both sides of a
document are scanned, and the images
displayed are combined into one image.
For details, refer to the user’s guide.
) When the [Reverse side] check box is
selected, a mirror image of the scanned
document is displayed.
) [Ratio of black pixels] specifies the ratio
of black areas (0 to 20%) when skipping
blank pages.
h Feeding Option
Selects the document feeding method.
) [Standard Feeding] scans loaded
documents after starting scanning from
the application program.
) [Panel-Feeding] scans loaded documents
after pressing the scanner’s scan button.
) [Automatic Feeding] starts scanning
whenever the scanner detects a loaded
document.
i Batch Separation
This setting is enabled when the [PanelFeeding] or [Automatic Feeding] Feeding
Option is selected. Documents can be
scanned as separate batches.
) When [Auto] is selected, batch
separation is performed when scanning
j
k
l
m
n
with [Panel-Feeding] or [Automatic
Feeding] starts.
) When [Panel] is selected, batch
separation is performed when the batch
separation button in the Scan Panel is
clicked.
Deskew
When a document page feeds at a slant,
the scanned image is straightened.
Prescan
When scanning starts, a page of the
document is scanned and its image is
displayed in the Prescan window.
Scan Area Dialog Box
Page Size
Selects the size of the pages to be scanned.
) Click [Custom] to register a non-standard
document size as a custom page size.
Area
Specifies the area to be scanned.
) These settings are disabled when [Autodetection] is selected for the Page Size.
Area Window
The appearance of this window indicates
the current Page Size setting.
) The specified scan area can be
adjusted by dragging the mouse.
Advanced Settings Dialog Box
o Drop-out color
Enabled for all scanning modes except [24bit Color], this function selects skipping
(drop-out) of red, green, or blue or
enhancement of red when scanning the
front or back of documents.
p Gamma
To alter the standard gamma curve, select
[Custom] Gamma Data and change the
gamma curve. For details on this setting,
click the Help button.
q Edge emphasis
Enhances contours in scanned images.
r Border Removal
Removes the black border that may be
created around scanned images.
s Scanner Adjustment
Scanner Adjustment is a function used to
adjust the reference values of the scanner
when abnormalities occur within the
scanned images, and normal maintenance
does not remedy the problem. For details
on Scanner Adjustment, refer to “Scanning
Results Are Not as Expected” (See p. 75.)
in the user’s guide.
This Quick Guide describes the dialog boxes
displayed by CapturePerfect. Depending on
your application program, the basic setup
dialog box may not be displayed. In this case,
the Advanced Settings dialog box, which
includes some of the functions in the basic
setup dialog box, is displayed. Click the Help
button for details.
Using the Scanner
51
Chapter 2
Basic Setup Dialog Box
TWAIN Driver Settings
Save User Preferences
Basic Setup Dialog Box
a
b
c
d
Mode
e
f
g
Page Size
h
i
k
* [Contrast] is set automatically
when Black and White is
selected, and [Brightness]
and [Contrast] are set
automatically when Text
Enhanced is selected.
* The Smoothing mode options
are not displayed when [600
dpi] Dots per inch is selected.
j
Scanning Option
If an application program executes scanning directly
from the basic setup dialog box, the [Scan] button is
displayed instead of the [OK] button, and the [Area
window] is displayed in the Scan Area dialog box.
Scan Area Dialog Box
Dots per inch
Scanning Side
* Blank pages for skipping are
determined using the [Ratio
of black pixels] value
selected.
Feeding Option
l
m
* The Delay setting is available
when the [Automatic Feeding]
Feeding Option is selected.
Custom Page Size registration
n
Unit
* Area setting is not available when the [Auto-detection] Page Size is selected.
* Scanning of the specified area may be shifted when Deskew is enabled.
Advanced Settings Dialog Box
Drop-out color
o
p
Gamma Data
q
r
s
Select
t
Scanner Adjustment is a function used to adjust the reference
values of the scanner when abnormalities occur within
the scanned images. Do not execute when the scanner is
functioning properly.
52
Using the Scanner
* When the [Custom] Gamma
Data is selected, the [Autodetection] Page Size, [Skip
blank page] Scanning Side,
and Deskew options are not
available, and [Brightness]
and [Contrast] are set
automatically.
a User Preference
Name and save your settings.
b Mode
Selects the scanning mode.
) [Text Enhanced] and [Advanced Text
Enhancement II] process the
background of a document so the text is
enhanced and easier to read.
) The Smoothing Gray/Color options
used to smooth images and reduce
moiré patterns are available when [400
dpi] Dots per inch or below is selected.
c Page Size
Selects the size of the pages to be
scanned.
) Selecting [Auto-detection] causes
automatic page size detection when
scanning.
d Dots per inch
Selects scanning resolution.
e Brightness
Adjusts brightness of scanned images.
[Brightness] is set automatically when the
Text Enhanced mode is selected.
f Contrast
Adjusts contrast of scanned images.
[Contrast] is set automatically when the
Black and White or Text Enhanced mode is
selected.
g Scanning Side
Specifies the side of the document to scan.
) When [Skip blank page] is selected,
images are skipped if they are
determined blank based on the [Ratio of
black pixels] value.
) When [Folio] is selected, both sides of a
document are scanned, and the images
displayed are combined into one image.
For details, refer to the user’s guide.
) When the [Reverse side] check box is
selected, the mirror image of the
scanned document is displayed.
) [Ratio of black pixels] specifies the ratio
of black areas (0 to 20%) when skipping
blank pages.
h Feeding Option
Selects the document feeding method.
) [Standard Feeding] scans all loaded
documents when scanning is started
from the application program.
) [Panel-Feeding] scans all loaded
documents when scanning is started by
the scanner’s scan button.
) [Automatic Feeding] starts scanning
when the scanner detects a loaded
document.
i Deskew
When a document page feeds at a slant,
the scanned image is straightened.
j Prescan
When scanning starts, a page of the
document is scanned and its image is
displayed in the Prescan window.
k Scanning Option
Specifies operation during scanning.
) [Standard]:
after one page has been scanned and
ejected, the next page is scanned.
) [Scan Ahead]:
scans document pages continuously.
) [Scan Single Page]:
Scanning Side is set and fixed at
[Simplex], and only one page is scanned.
Scan Area Dialog Box
l Page Size
Selects the size of the pages to be
scanned.
) Click [Custom] to register a nonstandard document size as a custom
page size.
m Area
Specifies the area to be scanned.
) These settings are disabled when [Autodetection] is selected for the Page Size.
n Preview
When [Prescan] is selected, click this
button to display a preview image in the
Prescan window after a page of the
document is scanned.
Advanced Settings Dialog Box
o Drop-out color
Enabled for all scanning modes except [24bit Color], this function selects skipping
(drop-out) of red, green, or blue or
enhancement of red when scanning the
front or back of documents.
p Gamma
To alter the standard gamma curve, select
[Custom] Gamma Data and change the
gamma curve. For details on this setting,
click the Help button.
q Edge emphasis
Enhances contours in scanned images.
r Border Removal
Removes the black border that may be
created around scanned images.
s Reverse Image
When the [Black and White], [Error
Diffusion], or [Text Enhanced] mode is
selected, black and white are reversed in
the scanned image.
t Scanner Adjustment
Scanner Adjustment is a function used to
adjust the reference values of the scanner
when abnormalities occur within the scanned
images, and normal maintenance does not
remedy the problem. For details on Scanner
Adjustment, refer to “Scanning Results Are
Not as Expected” (See p. 75.) in the user’s
guide.
This Quick Guide describes the TWAIN driver
settings. Click the Help button for details.
Using the Scanner
53
Chapter 2
Basic Setup Dialog Box
Job Registration Tool Settings
Job Registration Tool Dialog Box
Admin Dialog Box
v
a
w
x
b
c
d
y
e
z
Copy Dialog Box
New/Editing Dialog Box
Dialog box contents will differ depending
on the selected function.
Save as file
Function
f
g
Language for OCR
h
i
j
k
l
m
PDF/TIFF Settings
r
File type
s
* The [Setting] button
is enabled when [PDF]
or [TIFF] is selected.
Print
t
u
n
Access setting (Windows 2000/XP)
o
Attach to E-mail
q Launcher
p
54
Using the Scanner
a Job list
Shows the registered jobs.
) The job for the icon (
) that is colored is
executed when the scan button is pressed.
b [New/Editing] button
Opens the New/Editing dialog box.
c [Copy] button
Copies a registered job to another Job No.
d [Delete] button
Deletes the selected job from the Job list.
e [Admin] button
Opens the Admin dialog box.
New/Editing Dialog Box
f Job title
Enter the job title to appear on the display
panel.
g Function
Selects the function assigned to the Scan
button.
) The contents of the Editing dialog box
are determined by the selected function.
h Scanner setting
Opens the TWAIN driver’s basic setting
dialog box to configure the scanner.
i Save to My Pictures folder
Saves scanned images in the My Pictures
folder in My Documents.
) When this check box is not checked,
you can specify the destination folder
for saving images.
j File name
Specifies the file name.
) Image file names are created by appending
a time stamp to the specified file name.
k File type
Selects the file format for saved images.
) The [Setting] button is enabled when
PDF or TIFF is selected.
l [Setting] button
This button is enabled when the PDF or
TIFF file type is selected, and opens the
PDF or TIFF Setting dialog box.
) The PDF setting dialog box provides
[Compression] and [OCR] settings.
) The TIFF setting dialog box provides
[Multi-tiff setting] and [Compression]
settings.
m [Access setting] button
Opens the Access setting dialog box.
) Enter the correct User name and Password
to obtain access to a shared network folder.
n Printer
Shows the default printer. Printer settings
can be changed by clicking the [Printer
setting] button.
o Print format
Selects the printing size.
) [Actual size] prints at the same size as
the document.
) [Fit to paper] resizes scanned images to
fit on the printing paper when the
images are larger than the paper. When
the images are smaller than the paper,
they are printed at actual size.
p Save Image
Select this check box to save images scanned
using “Attach to E-mail”.
q Launcher
Starts applications set with the Windows
event function. See the user’s guide for
detailed information.
PDF/TIFF Settings
r Compression rate
Selects [Normal] or [High Compression]
rate.
) [High Compression] reduces the file’s
size, but also reduces the image quality
slightly.
) [High Compression] is useful for
grayscale and color images.
s Language for OCR/Apply OCR
Recognizes printed text in a document as
characters, and adds text data to the
PDF file.
) When the [Apply OCR] check box is
selected, recognized text data is saved
where the printed text is located in the
PDF file.
) When OCR is applied, Deskew is
enabled, regardless of the configured
settings for the TWAIN driver.
t Multi-tiff setting
Selects the saving method for multiple
page images.
) [One page] creates one file for one page
with the number of TIFF files
corresponding to the number of pages.
) [Multi pages] saves the images for all of
the pages as one file.
u Compression
Compresses image files before saving
them.
) Black and white images are
compressed as CCITT Group 4 images,
while grayscale and color images are
compressed as JPEG images.
Admin Dialog Box
v Capacity Warning Settings
Specifies the folder for saved image files,
and the capacity of that folder, in advance.
) After specifying the folder and starting to
scan, a warning message is displayed
when the specified capacity is reached
while scanning.
w Register Folder/Display Warning Dialog
The [Capacity Observed Folder] and
[Warning Size] items are enabled by
specifying a [Register Folder] (number) and
selecting the [Display Warning Dialog]
check box.
) When the capacity warning is displayed,
follow the displayed instructions to
continue scanning.
x Show Monitor Dialog
The Monitor for DR-2050C dialog box
appears when the Scan button is pressed,
and the scan progress is displayed.
y Maximum size of attached file
Specifies a maximum size for image files to
be attached to e-mails.
z Job Backup/Restore
Backs up and restores registered jobs.
) Backup files can be restored on another
DR-2050C document scanner.
Using the Scanner
55
Chapter 2
Job Registration Tool Dialog Box
56
Using the Scanner
Chapter 3
Appendices
1. Regular Maintenance ......................... 58
Cleaning the Scanner ................................
Cleaning Inside the Scanner .....................
Cleaning the Scanning Glass and the
Rollers .......................................................
Cleaning the Metal Rollers ........................
58
58
59
61
2. Removing and Attaching the Rollers 62
Roller Replacement Cycle .........................
Resetting the Counter ...............................
Removing and Attaching the Feed Roller ..
Removing and Attaching the Retard
Roller .........................................................
62
63
65
68
3. Troubleshooting ................................. 72
The Scanner Does Not Turn ON ...............
The Scanner Is Not Recognized ...............
Slow Scanning Speed ...............................
Scanning Is Not Performed .......................
Documents Are Not Fed Correctly ............
Paper Is Not Ejected Correctly ..................
Saved Image Files Do Not Open ...............
Scanning Results Are Not as Expected ....
72
72
73
74
74
75
75
75
4. Uninstalling Software ......................... 78
Uninstalling the ISIS/TWAIN Driver/
Job Registration Tool ................................ 80
Uninstalling CapturePerfect 3.0 ................. 82
5. Specifications ..................................... 84
Specifications ............................................ 84
1. Regular Maintenance
Perform the regular maintenance described below to maintain peak scanning
quality.
CAUTION
• When cleaning the scanner or the inside of the scanner, turn
OFF the power switch and unplug the power cord from the
outlet.
• Do not use spray cleaners to clean the scanner. Precision
mechanisms inside the scanner may get wet and result in
malfunction.
• Never use paint thinner, alcohol, or other organic solvents to
clean the scanner. Such solvents can damage or discolor the
exterior of the scanner, or create a risk of fire or electric shock.
Cleaning the Scanner
Moisten a cloth with plain water, wring out the excess water, and then wipe the
exterior of the scanner to clean it.
Cleaning Inside the Scanner
Dust or paper particles inside the scanner can cause lines in scanned images.
Use a blower for regular cleaning of dust and paper particles from inside the
scanner. After finishing a large scanning job, you should turn OFF the scanner
and then clean any paper particles that are remaining.
58
Appendices
Cleaning the Scanning Glass and the Rollers
If your scanned images contain lines or smudges, or if the scanned documents
are dirty, then the scanning glass or the rollers inside the scanner may be dirty.
Clean them periodically.
1. Open the document feed tray.
2. Pressing the OPEN knob from both sides (a), pull the front unit forward to
Chapter 3
open it (b).
3. Use a blower to keep the interior of the scanner free of dust and paper particles.
4. Use a clean dry cloth to wipe dirt off the scanning glass.
Wipe both the top and bottom scanning glasses.
CAUTION
Do not use spray type cleaners to clean the scanner. Precision
mechanisms, such as the light source, may get wet which will
cause a malfunction.
IMPORTANT
Scratches on the scanning glass may cause marks on the images and could
cause feeding errors. If there are scratches on the scanning glass, contact your
local authorized Canon dealer or service representative.
Appendices
59
5. Rotate the rollers (a) and (b) as you clean them. Moisten a cloth with plain
water, wring out excess water, wipe the rollers and then dry it with a clean dry
cloth.
Feed Roller
Retard Roller
6. Remove the feed roller and retard roller. (See p. 66, p. 69.)
IMPORTANT
After removing the feed roller and retard roller, clean them and then return
them to the scanner.
7. Wipe the removed rollers with a firmly wrung cloth moistened with water.
8. Attach the rollers that were removed. (See p. 67, p. 70.)
9. Gently press the left and right sides of the top of the front unit. Return the unit
fully to its original position until you hear it click into place.
60
Appendices
Cleaning the Metal Rollers
1. Turn on the scanner.
2. Open the document feed tray.
3. Pressing the OPEN knob from both sides (a), pull the front unit forward to
Chapter 3
open it (b).
4. Use a clean dry cloth to wipe the metal rollers (
parts in the illustration).
Press the Scan button and Stop button at the same time to rotate the metal
rollers in small increments.
CAUTION
• There are two metal rollers, one for the Front Unit and one for the
scanner. Be sure to wipe both of them. Do not spray water or
neutral detergent directly on the metal rollers. Doing so can
damage precision mechanisms, such as the light source.
Moisture on the scanner or your hands also creates the risk of
electric shock.
• Scanner power needs to be turned on when cleaning the metal
rollers. Because of this, you need to exercise extra caution when
cleaning them.
Appendices
61
2. Removing and Attaching the Rollers
Follow the relevant procedure to remove and attach the feed roller and retard
roller when you clean or replace them.
IMPORTANT
Feed rollers are consumable parts. When the rollers start to wear out, paper
jams and misfeeds may occur more often. When this happens, buy an exchange
roller kit, and replace the feed roller and the retard roller.
CAUTION
Do not use excessive force when removing or attaching the
rollers. Doing so may damage them.
Roller Replacement Cycle
When the number of pages scanned exceeds 30,000, a roller replacement
message will appear when the computer is started. When you are using the
DR-2050SP in the Presentation mode, a message prompting you to change the
rollers is displayed after the opening screen when the scanner’s power is turned
ON. Buy an exchange roller kit, and replace the feed roller and the retard
roller.
When using the DR-2050SP in Presentation mode
IMPORTANT
• If misfeeds happen often, check the rollers for wear, and replace them if
necessary before the message is displayed.
• Be sure to reset the counter after replacing the rollers. (See “Resetting the
Counter,” on p. 63.)
• Contact your local authorized Canon dealer or service representative for
information about the exchange roller kit (feed roller and retard roller).
62
Appendices
Resetting the Counter
After replacing the feed rollers, open the [Counter setup] dialog box and reset
the counter.
1. Follow the procedure below to open the [Counter setup] dialog box.
Chapter 3
1. Click the [Start] button, Æ click [Settings] on the Start menu Æ click
[Control Panel]. (For Windows XP, click the [Start] button Æ click [Control
Panel].)
2. For Windows XP, switch the Control Panel to Classic View, or select
[Printers and Other Hardware] in the working field.
Control Panel (category view)
Printers and Other Hardware
Control Panel (classic view)
Appendices
63
3. Select [CANON DR-2050C USB], and then click [Properties].
4. Click the [Counter] tab.
64
Appendices
2. Click the [Reset] button, and then make sure that the [Retard and Feed roller]
Chapter 3
has been set to 0.
Removing and Attaching the Feed Roller
Follow the procedure below to remove and attach the feed roller for cleaning
or replacement.
Note
When attaching the feed roller during installation, operate the roller fastening
lever according to the removal procedure and then attach the feed roller.
CAUTION
Do not use excessive force when removing or attaching the feed
roller. Doing so may damage them.
Appendices
65
Removing the Feed Roller
1. Pressing the OPEN knob from both sides (a), pull the front unit forward to
open it (b).
2. Open the roller cover on the scanner side. Insert a finger into the depression in
the cover and open it.
3. Raise the roller lock lever (a), and then slide it to the left (b).
66
Appendices
Attaching the Feed Roller
1. Set the feed roller into the hollow inside the roller cover, and align the notch in
the roller with the scanner shaft.
2. Slide the roller lock lever to the right, and then insert the shaft into the hole on
the left side of the roller.
Appendices
67
Chapter 3
4. Shift the feed roller to the left to separate it from the shaft, and then remove it.
3. Lower the lever to lock the roller shaft.
4. Close the roller cover. Return the cover fully to its original position until you
hear it click into place.
5. Gently press the left and right sides of the top of the Front Unit. Return the unit
fully to its original position until you hear it click into place.
Removing and Attaching the Retard Roller
Follow the procedure below to remove and attach the retard roller for cleaning
or replacement.
Note
When attaching the feed roller during installation, operate the roller fastening
lever according to the removal procedure and then attach the feed roller.
68
Appendices
CAUTION
Do not use excessive force when removing or attaching the
rollers. Doing so may damage them.
Removing the Retard Roller
1. Pressing the OPEN knob from both sides (a), pull the front unit forward to
Chapter 3
open it (b).
2. Holding the edges of the roller cover on the inside of the front unit, open the
cover.
3. Raise the roller lock lever (a), and then slide it to the left (b).
Appendices
69
4. Shift the Retard Roller to the left to separate it from the shaft, and then remove
it.
Attaching the Retard Roller
1. Position the retard roller so the notch in the roller is facing the scanner’s shaft.
2. Slide the roller lock lever to the right, and then insert the shaft into the hole on
the left side of the retard roller.
70
Appendices
3. Push the roller lock lever towards the back of the scanner to lock the retard
roller in place.
Chapter 3
4. Attach the roller cover. Be sure that the upper unit is completely closed by
pushing on both edges with both hands until you hear a click.
5. Gently press the left and right sides of the top of the front unit. Return the unit
fully to its original position until you hear it click into place.
Appendices
71
3. Troubleshooting
This section describes the possible problems that might occur during use of the
scanner and how to solve them.
The Scanner Does Not Turn ON ........................................P. 72
The Scanner Is Not Recognized ........................................P. 72
Slow Scanning Speed.........................................................P. 73
Scanning Is Not Performed................................................P. 74
Documents Are Not Fed Correctly ....................................P. 74
Paper Is Not Ejected Correctly ..........................................P. 75
Saved Image Files Do Not Open........................................P. 75
Scanning Results Are Not as Expected............................P. 75
If, after consulting this section, you still cannot resolve the problem, contact
your local authorized Canon dealer or your service representative.
The Scanner Does Not Turn ON
Check the following if the scanner does not turn on:
• Is the power cord connected correctly?
• Is the power cord connected securely?
• Is the power cord inserted into the power outlet?
For details on connecting the power cord, see “Step 4. Connecting the Scanner
to Your PC,” in the Easy Start Guide.
The Scanner Is Not Recognized
The following are possible causes of the PC failing to recognize the scanner.
Check each possible cause.
72
Problem
The scanner is not correctly connected.
Solution
Make sure that the scanner and the computer are correctly
connected with the USB cable. (See “Step 4. Connecting the
Scanner to Your PC,” in the Easy Start Guide.)
Problem
The scanner power is switched OFF.
Solution
Make sure that the scanner is switched ON. If the scanner is OFF,
turn the scanner ON. (See “Step 4. Connecting the Scanner to
Your PC,” in the Easy Start Guide.)
Appendices
Problem
The scanner does not support your USB interface.
Solution
This product is not guaranteed to operate with all types of USB
interfaces. Contact your local authorized Canon dealer or service
representative for more information. (See p. 15.)
Problem
The scanner does not support the USB cable.
Solution
Use the USB cable provided with the scanner.
Problem
The USB hub is not compatible with the scanner.
Solution
Remove the USB hub.
Chapter 3
Slow Scanning Speed
The following problems might cause the scanning speed to be slow.
Problem
Other applications are running in the background on your
PC.
Solution
Quit all other applications that are running.
Problem
Resident applications, such as anti-virus software, are
draining memory resources.
Solution
Quit all resident applications.
Problem
Temporary files cannot be created in the TEMP folder, as
there is not enough free space on the hard disk.
Solution
Delete unwanted files on the hard disk to increase free space on
the hard disk.
Problem
The USB port you are using does not support Hi-Speed
USB 2.0.
Solution
Scanning speeds are lower if your computer’s standard USB
interface is not compatible with Hi-Speed USB 2.0. (See p. 15.)
Use a computer that is equipped with USB that is compatible with
Hi-Speed USB 2.0 as standard.
Problem
The USB cable does not support Hi-Speed USB 2.0.
Solution
Use the USB cable provided with the scanner.
Problem
The USB hub does not support Hi-Speed USB 2.0.
Solution
Remove the USB hub.
Appendices
73
Scanning Is Not Performed
Check the following if the scanner does not scan an image even though the
scanning operation is performed:
• Is the scanner correctly connected to the computer?
• Has the scanner driver been installed?
• Has the application software been installed correctly? Has the application
software been set up correctly?
• Is there a problem in the PC system?
IMPORTANT
• If documents are not scanned normally even if the scanner setup is OK, a
probable cause is that the scanner driver or application software is not
running correctly. Re-install the scanner driver or application software.
• When system errors result in the scanner not functioning at all, turn OFF the
scanner and wait at least ten seconds before turning it ON again. If the error
continues to occur, restart the computer.
• When scanning continues, make sure that the last document scanned was
scanned correctly.
Documents Are Not Fed Correctly
The following are possible causes when documents are not fed correctly.
Problem
Static electricity, etc., is causing the pages of the document
to stick together, and they cannot be separated correctly by
the scanner.
Solution
Before you place your document, thoroughly fan the stack of
papers. (See “Placing a Documents,” on p. 23.)
Problem
An attempt was made to scan a size, thickness, or type of
paper that cannot be scanned by the scanner.
Solution
Check the document size, thickness, and paper type. (See
“Documents,” on p. 20.)
Problem
The rollers inside the scanner are dirty or worn.
Solution
Refer to p. 59 and clean the rollers. If the rollers are worn, then
they need to be replaced. Contact your local authorized Canon
dealer or service representative to purchase a roller replacement
kit.
For details on how to clear jammed paper, see “Clearing a Paper Jam,” on
p. 42.
74
Appendices
Paper Is Not Ejected Correctly
When you are performing page-by-page scanning while a multi-page
document is set in the scanner, scanning pauses with the trailing edge of the
scanned sheet being engaged by the eject roller.
Problem
Under these conditions, the scanner enters a standby state
and pauses for the next sheet. It does not indicate a paper
jam.
Solution
To scan the next sheet of the document, manually remove the page
that is engaged by the eject roller, or just start the next scan job.
Chapter 3
For details on how to clear jammed paper, see “Clearing a Paper Jam,” on
p. 42.
Saved Image Files Do Not Open
When image files saved by CapturePerfect 3.0 cannot be opened by other
applications, the probable causes are as follows.
Symptoms A multi-page TIFF file saved in CapturePerfect 3.0
cannot be opened by other applications.
Problem
The application you are using to open the TIFF file does not
support multi-page TIFF files.
Solution
Open the file with an application that supports multi-page TIFF
files.
Symptoms A TIFF file saved in CapturePerfect 3.0 cannot be
opened by other applications.
Problem
If the TIFF file saved in CapturePerfect 3.0 has been
compressed, the application you are using to open the TIFF
file does not support the compression type that was used to
save the file in CapturePerfect 3.0.
Solution
Set the compression type for the image file to [None] and save the
file again in CapturePerfect 3.0.
Scanning Results Are Not as Expected
If there is a problem with the scanning result (e.g., the scanned image is not
clear, or the image is striped or dirty), the probable causes are incorrect ISIS/
TWAIN driver settings or a problem with the scanning unit inside the scanner.
Scanning results can also become skewed if the ISIS/TWAIN driver has not
been installed correctly, or the application in use does not support ISIS/
TWAIN driver functions.
Appendices
75
Symptoms The scanned image is too dark (or faint).
Problem
The [Brightness] setting is not set to an appropriate value.
Solution
If the image is dark, set a higher [Brightness] setting, or if the
image is faint, set a lower [Brightness] setting.
(See “Software Settings,” on p. 49.)
Symptoms Text or images on the rear side of your document
appear in the scanned image.
Problem
The [Brightness] setting is too low, or the paper is too thin.
Solution
Set a higher [Brightness] setting. If the paper is too thin, make a
copy of the documents and then scan the copy.
Symptoms Double-sided scanning is not possible.
Problem
“Scanning Side” is set to [Simplex].
Solution
Set “Scanning Side” to [Double-sided].
Symptoms A black margin appears around the scanned document.
Problem
A document smaller than the preset paper size has been
scanned. Or, the loaded document has shifted out of
position.
Solution
Set “Paper size” to [Auto-detection]. Or, set [Border Removal] to
on.
Symptoms The scanned image is skewed.
Problem
The document has been fed at an angle. (skew)
Solution
Use the document guide adapter to prevent document skew, and
set [Deskew] to on. (See p. 22.)
Symptoms Lines, smudges, or dirt appear on the scanned image.
76
Problem
CauseThe scanning glass or rollers inside the scanner are
dirty.
Solution
Clean the scanning glass and rollers.
If lines still appear on the image even after cleaning the scanning
glass and rollers, the scanning glass inside the scanner may be
scratched. Contact your local authorized Canon dealer or service
representative. (See p. 59.)
Appendices
Symptoms The scanned image is abnormal for certain documents.
Problem
Functions such as [Auto-detection], [Deskew], or [Border
Removal] were used when scanning documents containing
text or photos up to their edges. (The scanner cannot
accurately process the edges of documents.)
Solution
Turn off functions such as [Auto-detection], [Deskew], or [Border
Removal] when scanning documents containing text or photos up
to their edges. (See “Software Settings,” on p. 49.)
Problem
A function not supported by the application was used.
Solution
Some applications do not support functions such as auto-detection
of the paper size. Scanning documents with an application such as
this will result in an abnormal scanned image. Try scanning with
auto-detection of the paper size set to “off.”
Adjusting the Scanner
To adjust the scanner, set the supplied Adjustment Sheet (Shading Sheet) in the
scanner. Orient the adjusting sheet in the direction indicated by the arrow when
setting it in the scanner. After setting the Adjustment Sheet in the scanner, click
the Windows [Start] button, and then click [Programs] (All Programs in the
case of Windows XP) Æ [Canon Document Scanner], and then [DR-2050C &
2080C Adjustment Tool], or use the [Scanner Adjustment] function of the ISIS/
TWAIN driver. Follow the instructions on the dialog box that appears on the
screen to adjust the scanner. Refer to Help for the ISIS/TWAIN driver for
information about the ISIS/TWAIN driver [Scanner Adjustment].
Adjustment Sheet
(Shading Sheet)
CAUTION
Before performing scanner adjustment, be sure to clean the
scanning glass (see p. 59). Attempting to perform scanner
adjustment while the scanning glass is dirty can cause vertical
lines in the scanned image. Note that performing scanner
adjustment will cause previous adjustment data to be deleted.
Once deleted, adjustment data cannot be recovered.
Appendices
77
Chapter 3
Symptoms The scanned image is abnormal in some applications.
4. Uninstalling Software
If the ISIS/TWAIN driver, “Job Registration Tool,” and “CapturePerfect 3.0”
are not operating normally, follow the procedure below to uninstall them.
Then, re-install the software from the DR-2050 series setup disc. (See “Step 3.
Installing the Software,” in the Easy Start Guide.)
IMPORTANT
Be sure to log on as an administrator when using Windows 2000 Professional
or Windows XP.
1. Click the [Start] button Æ click [Settings] Æ [Control Panel].
Note
For Windows XP, click the [Start] button Æ click [Control Panel].
The [Control Panel] window appears.
2. Double-click the [Add/Remove Programs].
Note
If you are using Windows XP, double-click the [Add or Remove Programs].
78
Appendices
Chapter 3
The [Add/Remove Programs Properties] dialog box appears.
Note
For Windows XP, the [Add or Remove Programs] dialog box appears.
3. From the list in the dialog box, select the application you want to delete Æ
click [Change/Remove].
For more information on uninstalling each application, see the following:
See “Uninstalling the ISIS/TWAIN Driver/Job Registration Tool,” on p. 80.
See “Uninstalling CapturePerfect 3.0,” on p. 82.
Appendices
79
Uninstalling the ISIS/TWAIN Driver/Job Registration
Tool
1. From the Programs list in the dialog box, select [Canon DR-2050C/2080C
Scanner Driver] (or [DR-2050C Job Tool]) Æ click the [Change/Remove]
button.
2. The [Confirm File Deletion] screen appears. Click the [Yes] button.
The [Remove Shared File ?] dialog box appears.
3. Click the [Yes To All] button.
A confirmation message appears.
80
Appendices
4. Click the [Yes] button to start the uninstallation.
Note
All deleted shared files can be reinstalled by installing the software again.
Chapter 3
5. After uninstall is complete, click the [OK] button to exit the uninstaller.
Appendices
81
Uninstalling CapturePerfect 3.0
1. Select [CapturePerfect 3.0] from the list in the dialog box Æ click the
[Remove] button.
2. The file delete confirmation screen appears. Click the [Yes] button.
Uninstallation starts.
82
Appendices
Chapter 3
3. After uninstallation is complete, click the [Finish] button to exit the uninstaller.
Appendices
83
5. Specifications
Specifications
For DR-2050SP Presentation mode specifications, see the DR-2050SP User’s
Guide Presentation Mode Edition.
Scanner
Type
Desktop sheetfed scanner
Scanning Document Specifications
Width:
2.16" to 8.50" (55 mm to 216 mm)
Length:
(separated documents) 2.75" to 11.6" (70 mm to 297 mm)
(nonseparated documents) 2.75" to 13.9" (70 mm to 355 mm)
Weight:
(separated documents) 14 to 32 lb bond (0.0024" to 0.0059")
(nonseparated documents) 52 to 128 g/m2 (0.06 mm to 0.15 mm)
11 to 40 lb bond (0.0020" to 0.0079")
42 to 157 g/m2 (0.05 mm to 0.20 mm)
Document Feeding Method
Automatic
Scanning Method
Contact image sensor
Light Source
LED
Scanning Side
Simplex/Duplex
Scanning Modes
Black and white, Text Enhanced, Advanced Text
Enhancement II, Error diffusion, 256-level
grayscale, 24 bit color
Scanning Resolution
(Primary Scan Lines ×
Secondary Scan Lines)
100 × 100 dpi, 150 × 150 dpi, 200 × 200 dpi
240 × 240 dpi, 300 × 300 dpi, 400 × 400 dpi
600 × 600 dpi
Scanning Speed
(Conditions: CPU Celeron 733 MHz; 256 MB RAM; Document Size: A4)
Black and White
Simplex
200 × 200 dpi
20 pages/minute
300 × 300 dpi
11 pages/minute
Duplex
200 × 200 dpi
38 images/minute
300 × 300 dpi
20 images/minute
256-level Gray
Simplex
200 × 200 dpi
300 × 300 dpi
20 pages/minute
11 pages/minute
200 × 200 dpi
300 × 300 dpi
38 images/minute
20 images/minute
Duplex
84
Appendices
24-bit Color
Simplex
100 × 100 dpi
200 × 200 dpi
18 pages/minute
7 pages/minute
100 × 100 dpi
200 × 200 dpi
36 images/minute
12 images/minute
Duplex
Hi-Speed USB 2.0
Other Functions
Auto document thickness adjustment, folio scan
Dimensions
11.7" × 7.7" × 3.9" (W × H × D)
298 mm × 197 mm × 100 mm (W × H × D)
Dimensions (with trays open)
11.7" × 12.7" × 5.2" (W × H × D)
298 mm × 323 mm × 132 mm (W × H × D)
Weight
(Excluding the AC adapter)
Approximately 5.5 lb (2.5 kg) (DR-2050C)
Approximately 5.7 lb (2.6 kg) (DR-2050SP)
Power Supply
DC 16 V, 0.8 A (AC adapter used)
Power Consumption
Maximum power: 13 W (DR-2050C)
16 W (DR-2050SP)
Low power mode: 4 W
Power SW OFF: 0.4 W
Noise
66 dB or less
Operating Environment
Temperature: 10°C to 32.5°C (50°F to 90.5°F)
Humidity:
20% to 80% RH
Chapter 3
Interface
AC Adaptor
AC 100-240 V Model
MG1-3607
Input
AC 100-240 V 50/60 Hz 0.65-0.34 A
Output
DC 16 V 1.8 A
Power Supply
0.5 W max. (separate AC adaptor)
Weight
Approx. 0.7 lb (0.3 kg) (including Power Cord)
Replacement Parts
Roller replacement kit (product code: 7982A001)
Kit to replace the feed rollers (feed roller and retard roller).
• For details on replacing the rollers, see “Removing and Attaching the Retard
Roller,” on p. 68.
• Contact your local authorized Canon dealer for detailed information about
replacement parts.
Specifications are subject to change without notice.
Appendices
85
11.7" (298 mm)
86
Appendices
3.9"
(100 mm)
1.3"
(32 mm)
(Document Tray is open)
7.7" (197 mm)
12.7" (323 mm)
External Dimensions
Index
A
J
AC adapter ...................................................7
Job Function .............................................. 34
Job Registration Tool .......................... 35, 49
Bypass Mode .............................................26
C
CapturePerfect 3.0 .........................17, 28, 75
Cleaning .....................................................58
Metal Rollers .........................................61
Rollers ...................................................59
Scanner ..................................................58
Scanning Glass ......................................59
Conventions ...............................................14
Counter ......................................................63
D
Disposal .....................................................10
Document Eject Opening ..........................13
Document Feed Opening ...........................13
Document Feed Tray .................................13
Document Guide ........................................13
Document Guide Adapter ....................13, 22
Documents .................................................20
DR-2050C Driver ......................................17
E
Easy Start Guide ..........................................1
Event Function ..........................................37
External Dimensions .................................86
F
Features .....................................................11
Feed Extension Plate .................................13
Feed Indicator ............................................13
Feed Roller ..........................................60, 65
Attaching ...............................................67
Removing ..............................................66
Feed Selection Lever ...............13, 23, 26, 27
Folio ...........................................................27
Front Unit ..................................................13
H
Handling ......................................................8
I
Installation Location ....................................6
Installation Requirements ..........................15
Introduction .................................................1
ISIS Driver ................................................49
K
Kensington Slot ......................................... 14
M
Manuals for the Scanner ............................. 1
Moving the Scanner .................................... 7
N
Names and Functions of Parts ................... 13
O
OPEN Knob .............................................. 13
operating systems ...................................... 15
P
Page Separation Mode .............................. 23
Paper Jam .................................................. 42
Placing a Documents ................................. 23
Power Connector ....................................... 14
Power Indicator ......................................... 13
Power Switch ............................................ 14
Preparing the Trays ................................... 21
Document Feed Tray ............................ 21
Document Guide Adapter ..................... 22
Feed Extension Plate ............................ 22
R
Regular Maintenance ................................ 58
Retard Roller ....................................... 60, 68
Attaching .............................................. 70
Removing ............................................. 69
S
Scanning Documents ................................ 28
CapturePerfect 3.0 ................................ 28
Scanning Hints .......................................... 44
Setup Disc ................................................. 17
Custom Installation ............................... 17
Read the manual ................................... 17
Typical Installation ............................... 17
Software .............................................. 49, 78
Settings ................................................. 49
Uninstalling .......................................... 78
Specifications ............................................ 84
T
Troubleshooting ........................................ 72
TWAIN Driver .......................................... 49
Index
87
Index
B
U
Upper Cover ..............................................13
USB Connector ..........................................14
V
Ventilation Openings .................................14
88
Index
Nederlands
Italiano
Espanõl
Deutsch
Français
English
Memo
CANON ELECTRONICS INC.
1248, SHIMOKAGEMORI, CHICHIBU-SHI, SAITAMA 369-1892, JAPAN
CANON U.S.A. INC.
ONE CANON PLAZA, LAKE SUCCESS, N.Y. 11042, U.S.A.
CANON CANADA INC.
6390 DIXIE ROAD, MISSISSAUGA, ONTARIO L5T 1P7, CANADA
CANON EUROPA N.V.
BOVENKERKERWEG 59-61, P.O.BOX 2262, 1180 EG AMSTELVEEN, THE NETHERLANDS
CANON LATIN AMERICA, INC.
703 WATERFORD WAY, SUITE 400 MIAMI, FLORIDA 33126, U.S.A.
CANON AUSTRALIA PTY. LTD.
1 THOMAS HOLT DRIVE, NORTH RYDE, SYDNEY. N.S.W, 2113. AUSTRALIA
CANON SINGAPORE PTE. LTD.
1 HARBOUR FRONT AVENUE #04-01, KEPPEL BAY TOWER, SINGAPORE 098632
CANON HONGKONG COMPANY LTD.
19TH FLOOR, THE METROPOLIS TOWER, 10 METROPOLIS DRIVE, HUNGHOM, KOWLOON, HONG KONG.
PUB.CE-IE-549-01
© CANON ELECTRONICS INC. 2007
ISIS Driver Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Save User Preferences
Basic Setup Dialog Box
Mode
Page Size
Batch Separation
* Batch Separation is not
available when the [Standard
Feeding] Feeding Option is
selected.
Feeding Option
* The Delay setting is available
when the [Automatic Feeding]
Feeding Option is selected.
* [Contrast] is set
automatically when Black
and White is selected, and
[Brightness] and [Contrast]
are set automatically when
Text Enhanced is selected.
* The Smoothing mode
options are not displayed
when [600 dpi] Dots per
inch is selected.
Dots per inch
Scanning Side
* Blank pages for skipping
are determined using the
[Ratio of black pixels] value
selected.
Scan Area Dialog Box
Custom Page Size registration
Unit
* Area setting is not available when the [Auto-detection] Page Size is selected.
* Scanning of the specified area may be shifted when Deskew is enabled.
Advanced Settings Dialog Box
Drop-out color
Gamma Data
Select
Scanner Adjustment is a function used to adjust the reference
values of the scanner when abnormalities occur within the
scanned images. Do not execute when the scanner is
functioning properly.
* When the [Custom] Gamma
Data is selected, the [Autodetection] Page Size, [Skip
blank page] Scanning Side,
and Deskew options are not
available, and [Brightness]
and [Contrast] are set
automatically.
ISIS Driver Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Basic Setup Dialog Box
Scan Area Dialog Box
1 User Preference
Name and save your settings.
☞ Names can consist of up to 32 characters.
B Page Size
Selects the size of the pages to be scanned.
☞ Click [Custom] to register a non-standard document
size as a custom page size.
2 Mode
Selects the scanning mode.
☞ [Text Enhanced] and [Advanced Text Enhancement
2] process the background of a document so the
text is enhanced and easier to read.
☞ The Smoothing Gray/Color options used to smooth
images and reduce moiré patterns are available
when [400 dpi] Dots per inch or below is selected.
3 Page Size
Selects the size of the pages to be scanned.
☞ Selecting [Auto-detection] causes automatic page
size detection when scanning.
4 Dots per inch
Selects scanning resolution.
5 Brightness
Adjusts brightness of scanned images.
[Brightness] is set automatically when the Text
Enhanced mode is selected.
6 Contrast
Adjusts contrast of scanned images.
[Contrast] is set automatically when the Black and
White or Text Enhanced mode is selected.
7 Scanning Side
Specifies the side of the document to scan.
☞ When [Skip blank page] is selected, images are
skipped if they are determined blank based on the
[Ratio of black pixels] value.
☞ When [Folio] is selected, both sides of a document
are scanned, and the images displayed are
combined into one image. For details, refer to the
user’s guide.
☞ When the [Reverse side] check box is selected, a
mirror image of the scanned document is
displayed.
☞ [Ratio of black pixels] specifies the ratio of black
areas (0 to 20%) when skipping blank pages.
8 Feeding Option
Selects the document feeding method.
☞ [Standard Feeding] scans loaded documents after
starting scanning from the application program.
☞ [Panel-Feeding] scans loaded documents after
pressing the scanner's scan button.
☞ [Automatic Feeding] starts scanning whenever the
scanner detects a loaded document.
9 Batch Separation
This setting is enabled when the [Panel-Feeding] or
[Automatic Feeding] Feeding Option is selected.
Documents can be scanned as separate batches.
☞ When [Auto] is selected, batch separation is
performed when scanning with [Panel-Feeding] or
[Automatic Feeding] starts.
☞ When [Panel] is selected, batch separation is
performed when the batch separation button in the
Scan Panel is clicked.
0 Deskew
When a document page feeds at a slant, the scanned
image is straightened.
A Prescan
When scanning starts, a page of the document is
scanned and its image is displayed in the Prescan
window.
C Area
Specifies the area to be scanned.
☞ These settings are disabled when [Auto-detection]
is selected for the Page Size.
D Area Window
The appearance of this window indicates the current
Page Size setting.
☞ The specified scan area can be adjusted by
dragging the mouse.
Advanced Settings Dialog Box
E Drop-out color
Enabled for all scanning modes except [24-bit Color],
this function selects skipping (drop-out) of red, green,
or blue or enhancement of red when scanning the front
or back of documents.
F Gamma
To alter the standard gamma curve, select [Custom]
Gamma Data and change the gamma curve. For
details on this setting, click the Help button.
G Edge emphasis
Enhances contours in scanned images.
H Border Removal
Removes the black border that may be created around
scanned images.
I Scanner Adjustment
Scanner Adjustment is a function used to adjust the
reference values of the scanner when abnormalities
occur within the scanned images, and normal
maintenance does not remedy the problem. For details
on Scanner Adjustment, refer to “Adjusting the
Scanner” (see P.75) in the user’s guide.
This Quick Guide describes the dialog boxes displayed
by CapturePerfect. Depending on your application
program, the basic setup dialog box may not be
displayed. In this case, the Advanced Settings dialog
box, which includes some of the functions in the basic
setup dialog box, is displayed. Click the Help button for
details.
TWAIN Driver Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Save User Preferences
Basic Setup Dialog Box
Mode
Page Size
Scanning Option
If an application program executes scanning directly
from the basic setup dialog box, the [Scan] button is
displayed instead of the [OK] button, and the [Area
window] is displayed in the Scan Area dialog box.
Scan Area Dialog Box
* [Contrast] is set automatically
when Black and White is
selected, and [Brightness]
and [Contrast] are set
automatically when Text
Enhanced is selected.
* The Smoothing mode options
are not displayed when [600
dpi] Dots per inch is selected.
Dots per inch
Scanning Side
* Blank pages for skipping are
determined using the [Ratio
of black pixels] value
selected.
Feeding Option
* The Delay setting is available
when the [Automatic Feeding]
Feeding Option is selected.
Custom Page Size registration
Unit
* Area setting is not available when the [Auto-detection] Page Size is selected.
* Scanning of the specified area may be shifted when Deskew is enabled.
Advanced Settings Dialog Box
Drop-out color
Gamma Data
Select
Scanner Adjustment is a function used to adjust the reference
values of the scanner when abnormalities occur within
the scanned images. Do not execute when the scanner is
functioning properly.
* When the [Custom] Gamma
Data is selected, the [Autodetection] Page Size, [Skip
blank page] Scanning Side,
and Deskew options are not
available, and [Brightness]
and [Contrast] are set
automatically.
TWAIN Driver Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Basic Setup Dialog Box
Scan Area Dialog Box
1 User Preference
Name and save your settings.
B Page Size
Selects the size of the pages to be scanned.
☞ Click [Custom] to register a non-standard document
size as a custom page size.
2 Mode
Selects the scanning mode.
☞ [Text Enhanced] and [Advanced Text Enhancement
2] process the background of a document so the
text is enhanced and easier to read.
☞ The Smoothing Gray/Color options used to smooth
images and reduce moiré patterns are available
when [400 dpi] Dots per inch or below is selected.
3 Page Size
Selects the size of the pages to be scanned.
☞ Selecting [Auto-detection] causes automatic page
size detection when scanning.
4 Dots per inch
Selects scanning resolution.
5 Brightness
Adjusts brightness of scanned images.
[Brightness] is set automatically when the Text
Enhanced mode is selected.
6 Contrast
Adjusts contrast of scanned images.
[Contrast] is set automatically when the Black and
White or Text Enhanced mode is selected.
7 Scanning Side
Specifies the side of the document to scan.
☞ When [Skip blank page] is selected, images are
skipped if they are determined blank based on the
[Ratio of black pixels] value.
☞ When [Folio] is selected, both sides of a document
are scanned, and the images displayed are
combined into one image. For details, refer to the
user’s guide.
☞ When the [Reverse side] check box is selected, the
mirror image of the scanned document is
displayed.
☞ [Ratio of black pixels] specifies the ratio of black
areas (0 to 20%) when skipping blank pages.
8 Feeding Option
Selects the document feeding method.
☞ [Standard Feeding] scans all loaded documents
when scanning is started from the application
program.
☞ [Panel-Feeding] scans all loaded documents when
scanning is started by the scanner's scan button.
☞ [Automatic Feeding] starts scanning when the
scanner detects a loaded document.
9 Deskew
When a document page feeds at a slant, the scanned
image is straightened.
0 Prescan
When scanning starts, a page of the document is
scanned and its image is displayed in the Prescan
window.
A Scanning Option
Specifies operation during scanning.
☞ [Standard]:
after one page has been scanned and ejected, the
next page is scanned.
☞ [Scan Ahead]:
scans document pages continuously.
☞ [Scan Single Page]:
Scanning Side is set and fixed at [Simplex], and
only one page is scanned.
C Area
Specifies the area to be scanned.
☞ These settings are disabled when [Auto-detection]
is selected for the Page Size.
D Preview
When [Prescan] is selected, click this button to display
a preview image in the Prescan window after a page of
the document is scanned.
Advanced Settings Dialog Box
E Drop-out color
Enabled for all scanning modes except [24-bit Color],
this function selects skipping (drop-out) of red, green,
or blue or enhancement of red when scanning the front
or back of documents.
F Gamma
To alter the standard gamma curve, select [Custom]
Gamma Data and change the gamma curve. For
details on this setting, click the Help button.
G Edge emphasis
Enhances contours in scanned images.
H Border Removal
Removes the black border that may be created around
scanned images.
I Reverse Image
When the [Black and White], [Error Diffusion], or [Text
Enhanced] mode is selected, black and white are
reversed in the scanned image.
J Scanner Adjustment
Scanner Adjustment is a function used to adjust the
reference values of the scanner when abnormalities
occur within the scanned images, and normal
maintenance does not remedy the problem. For details
on Scanner Adjustment, refer to “Adjusting the
Scanner” (see P.75) in the user’s guide.
This Quick Guide describes the TWAIN driver settings.
Click the Help button for details.
Job Registration Tool Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Job Registration Tool Dialog Box
Admin Dialog Box
Copy Dialog Box
New/Editing Dialog Box
Dialog box contents will differ depending on the
selected function.
Save as file
Function
PDF/TIFF Settings
File type
Print
* The [Setting] button is
enabled when [PDF] or
[TIFF] is selected.
Access setting (Windows 2000/XP)
Attach to E-mai
Launcher
Language for OCR
Job Registration Tool Quick Guide
Keep this Quick Guide near the scanner for ready reference.
Job Registration Tool Dialog Box
1 Job list
Shows the registered jobs.
☞ The job for the icon ( ) that is colored is executed
when the scan button is pressed.
2 [New/Editing] button
Opens the New/Editing dialog box.
3 [Copy] button
Copies a registered job to another Job No.
4 [Delete] button
Deletes the selected job from the Job list.
5 [Admin] button
Opens the Admin dialog box.
New/Editing Dialog Box
6 Job title
Enter the job title to appear on the display panel.
7 Function
Selects the function assigned to the Scan button.
☞ The contents of the Editing dialog box are
determined by the selected function.
8 Scanner setting
Opens the TWAIN driver’s basic setting dialog box to
configure the scanner.
9 Save to My Pictures folder
Saves scanned images in the My Pictures folder in My
Documents.
☞ When this check box is not checked, you can
specify the destination folder for saving images.
0 File name
Specifies the file name.
☞ Image file names are created by appending a time
stamp to the specified file name.
A File type
Selects the file format for saved images.
☞ The [Setting] button is enabled when PDF or TIFF is
selected.
B [Setting] button
This button is enabled when the PDF or TIFF file type is
selected, and opens the PDF or TIFF Setting dialog box.
☞ The PDF setting dialog box provides [Compression]
and [OCR] settings.
☞ The TIFF setting dialog box provides [Multi-tiff setting]
and [Compression] settings.
C [Access setting] button
Opens the Access setting dialog box.
☞ Enter the correct User name and Password to
obtain access to a shared network folder.
D Printer
Shows the default printer. Printer settings can be
changed by clicking the [Printer setting] button.
E Print format
Selects the printing size.
☞ [Actual size] prints at the same size as the
document.
☞ [Fit to paper] resizes scanned images to fit on the
printing paper when the images are larger than the
paper. When the images are smaller than the paper,
they are printed at actual size.
F Save Image
Select this check box to save images scanned using
“Attach to E-mail”.
G Launcher
Starts applications set with the Windows event function.
See the user’s guide for detailed information.
PDF/TIFF Settings
H Compression rate
Selects [Normal] or [High Compression] rate.
☞ [High Compression] reduces the file’s size, but also
reduces the image quality slightly.
☞ [High Compression] is useful for grayscale and
color images.
I Language for OCR/Apply OCR
Recognizes printed text in a document as characters,
and adds text data to the PDF file.
☞ When the [Apply OCR] check box is selected,
recognized text data is saved where the printed text
is located in the PDF file.
☞ When OCR is applied, Deskew is enabled, regardless
of the configured settings for the TWAIN driver.
J Multi-tiff setting
Selects the saving method for multiple page images.
☞ [One page] creates one file for one page with the
number of TIFF files corresponding to the number of
pages.
☞ [Multi pages] saves the images for all of the pages
as one file.
K Compression
Compresses image files before saving them.
☞ Black and white images are compressed as CCITT
Group 4 images, while grayscale and color images
are compressed as JPEG images.
Admin Dialog Box
L Capacity Warning Settings
Specifies the folder for saved image files, and the
capacity of that folder, in advance.
☞ After specifying the folder and starting to scan, a
warning message is displayed when the specified
capacity is reached while scanning.
M Register Folder/Display Warning Dialog
The [Capacity Observed Folder] and [Warning Size]
items are enabled by specifying a [Register Folder]
(number) and selecting the [Display Warning Dialog]
check box.
☞ When the capacity warning is displayed, follow the
displayed instructions to continue scanning.
N Show Monitor Dialog
The Monitor for DR-2050C dialog box appears when
the Scan button is pressed, and the scan progress is
displayed.
O Maximum size of attached file
Specifies a maximum size for image files to be
attached to e-mails.
P Job Backup/Restore
Backs up and restores registered jobs.
☞ Backup files can be restored on another DR-2050C
document scanner.
This Quick Guide describes settings for the Job
Registration Tool. Click the Help button for details.
