Samsung MID462 flat panel floorstand

SAMSUNG Video Wall Kit
Installation Guide
Contents
1.Product Overview
2. Installation
3. Fixing
4. Various Installation Methods
1
2
3
4
4
6
6
10
Product Feature
Package Contents
Part Names
Installation Instructions
Adjusting the Level
Arranging the Stand
Assembling the Monitor
Connecting and Arranging the Cables
11
12
13
Fixing the monitor to the wall
Where and How to Assemble the
BRACKET-PANEL
ASSY COVER P-TOP
13
13
13
13
14
Basic (3x3)
Stair
Pyramid
Circular
Rectangle
5. Product Specifications (Drawing)
i
Matrix_ID-Eng.indd i
2009-04-15
9:54:04
SAMSUNG Video Wall Kit Setup Guide
1. Product Overview
1.Product Overview
Product Feature
● Samsung ID 1 (MID40, MID46) : compatible with 400UX(n), 460UX(n) series
● Samsung ID 2 (MID462) : compatible with 460UT(n) series
● Interlocking Display Solution
● Multi LCD Display Solution
● Free Standing Solution
● Easy Content Management
● 4-Layer stackable
1
Matrix_ID-Eng.indd Sec1:1
2009-04-15
9:54:07
SAMSUNG Video Wall Kit Setup Guide
1. Product Overview
Package Contents
SAMSUNG Video Wall Kit Main Body Front View / Back View
BRACKET-BALLAST
Quantity: 5EA
BRKT-LINK MIDDLE
Quantity: 8EA
BRACKET-LINK TOP
Quantity: 2EA
Screws (M5 x L12)
Quantity: 40EA
Screws (M6 x L15)
Quantity: 5 EA
L-Shape Wrench (4mm)
Quantity: 1EA
HOLDER WIER
Quantity: 10EA
Spanner
Hinge
2
Matrix_ID-Eng.indd Sec1:2
2009-04-15
9:54:07
SAMSUNG Video Wall Kit Setup Guide
1. Product Overview
Part Names
Link hole
Link hole
Vents
Level Adjuster
Level Adjuster
Level Adjuster
Level Adjuster
Fixing Screw Hole
Cable Exit
Link Fixing
Screw Hole
Link Fixing
Screw Hole
Back Cover/
Vents
Cable Entrance
Level Adjuster
Level Adjuster
Fixing Screw Hole
3
Matrix_ID-Eng.indd Sec1:3
2009-04-15
9:54:09
SAMSUNG Video Wall Kit Setup Guide
2. Installation
2. Installation
Installation Instructions
● Install the product maintaining a distance of at least 50 cm from the
wall.
● Make sure to fix the product to the floor with screws.
1
2
3
➣
4
When the assembly is complete, arrange the cables on the back of the stand, close the rear cover and fasten the
screws(M6 X L15).
4
Matrix_ID-Eng.indd Sec1:4
2009-04-15
9:54:10
SAMSUNG Video Wall Kit Setup Guide
2. Installation
Adjusting the Level
1. Place the product on a flat surface (floor).
2. Level the product using the 4 Level Adjusters at the front and back of the product using the L-shape wrench.
3. Level the product by turning the 2 Level Adjusters on both sides of the product.
4. You must the level the product using the level gauge spirit level so that the angles of the sides and the top
are within a range of 89.8~90.2 degrees.
➣
If the vertical angle is not within the 89.8~90.2 degree range, the monitors may fall when they are piledup. Ensure
that the angle is within the range.
5
Matrix_ID-Eng.indd Sec1:5
2009-04-15
9:54:11
SAMSUNG Video Wall Kit Setup Guide
2. Installation
Arranging the Stand
● Arrange the stand in the installation shape.
(Level each of the stands referring to the descriptions in the “Adjusting Level” section.)
➣
If you want the monitor inclined towards you, tilt it as far as you need it to go and fix it on the floor.
Assemble it follwing the same steps described previously.
Assembling the Monitor
N After stacking the necessary monitors on top of each other and fastening all the screws to the connecting
parts.
To stack 3 or more monitors, two or more persons must work together.
1. Insert the Middle Bracket-Links into the connecting pipe.
2. Assemble the Ballast-Brackets.
6
Matrix_ID-Eng.indd Sec1:6
2009-04-15
9:54:12
SAMSUNG Video Wall Kit Setup Guide
2. Installation
3. Assemble the monitors.
4. After assembling the monitors, assemble the Middle Bracket-Links and Ballast-Brackets.
5. After assembling the Middle Bracket-Links and the Ballast-Brackets, assemble the monitors.
7
Matrix_ID-Eng.indd Sec1:7
2009-04-15
9:54:14
SAMSUNG Video Wall Kit Setup Guide
2. Installation
6. Assemble all the monitors (up to 4 monitors in a column) according to the same procedures, install the Top
Bracket-Link, and then fasten all the screws of the connecting parts.
7. When the arrangement is complete, fix it to the floor with the screws.
N The parts used for the product assembly are as follows.
ex) When monitors are constructed in a 2x3 stack.
8
Matrix_ID-Eng.indd Sec1:8
2009-04-15
9:54:20
9
Matrix_ID-Eng.indd Sec1:9
2009-04-15
9:54:26
SAMSUNG Video Wall Kit Setup Guide
2. Installation
Connecting and Arranging the Cables
1. Remove the 6 screws from the back of the product and separate the back cover.
2. Arrange the cables and hubs in the arrangement space and close the cover.
3. Connect the cables with the relevant devices.
4. Tie the cables firmly using the arrangement hook at the back of each monitor.
5. If the number of stacked monitors in a column is equal to or greater than 3, the power cable may be too
short. In this case, connect the power using a power extension cable.
Power Extension Cable (Optional)
10
Matrix_ID-Eng.indd Sec1:10
2009-04-15
9:54:30
SAMSUNG Video Wall Kit Setup Guide
3. Fixing
3. Fixing
Fixing the monitor to the wall
If the monitor is not fixed to the wall, movement of up to ±1degrees at the front and back may occur.
Therefore, make sure to fix the monitor to the wall using the Top-Bracket.
N Create a fixing pipe referring to the specifications of the Top-Bracket on the “Product Specifications” page.
[Required Parts]
● A Wall-Fixing Pipe with a 30mm size (to be created separately.)
● Fixing Screws
1. After installing the product, connect the Top-Bracket to the top part of the Top-Bracket-Link.
2. Insert the prepared fixing pipe into the Top-Bracket.
3. Check the position of the wall and fix the Top-Bracket to the wall using the screws and fix the product to the
wall.
Note: Maintain a distance of at least 50cm from the wall.
11
Matrix_ID-Eng.indd Sec1:11
2009-04-15
9:54:33
SAMSUNG Video Wall Kit Setup Guide
3. Fixing
Where and How to Assemble the BRACKET-PANEL
* Fasten the 16 points using the FH, M4 and L10 screws.
ASSY COVER P-TOP
BRACKET PANEL-TOP BRACKET PANEL-BOTTOM
BRACKET PANEL-L
BRACKET PANEL-R
1. CODE : BN96-1259A
2. This is a material that is included in the separate set of accessories.
3. This is an item to be assembled by the user for maintenance of the product's appearance and quality.
4. The assemby screws and 16 pieces of FH, M4xL10 are provided in the manual and in a PE-bag
respectively.
5. As shown in the attached drawing, it is divided into the top, the bottom, and the left and right sides.
Note: It is supplied with the SAMSUNG ID2 model only.
12
Matrix_ID-Eng.indd Sec1:12
2009-04-15
9:54:34
SAMSUNG Video Wall Kit Setup Guide
4. Various Installation Methods
4. Various Installation Methods
Basic (3x3)
Stair
Pyramid
Circular
Back of the Folding
Front of the Folding
13
Matrix_ID-Eng.indd Sec1:13
2009-04-15
9:54:34
SAMSUNG Video Wall Kit Setup Guide
4. Various Installation Methods
Rectangle
Note: If monitors are assembled in the shape of a rectangle, maintain a space of at least 30cm from the ceiling
as air may become trapped inside and result in overheating.
14
Matrix_ID-Eng.indd Sec1:14
2009-04-15
9:54:36
SAMSUNG Video Wall Kit Setup Guide
5. Product Specifications
5. Product Specifications (Drawing)
For 40 Inch Monitors Samsung ID 1
1. Weight
- Net : 28.4kg
- Gross : 38.4kg
2. Size
Width[mm]
Depth[mm]
Height[mm]
Set
913.7
600
468
Packing Dimension
1030
696
361
15
Matrix_ID-Eng.indd Sec1:15
2009-04-15
9:54:36
SAMSUNG Video Wall Kit Setup Guide
5. Product Specifications
For 46 Inch Monitors Samsung ID 1
1. Weight
- Net : 32.8kg
- Gross : 43.1kg
2. Size
Width[mm]
Depth[mm]
Height[mm]
Set
1049.4
600
468
Packing Dimension
1166
696
361
1009.4
651.7
160.0
100.0 160.0
468.0
269.5
101.5
600.0
229.0
1049.4
571.7
100.0
43.0
120.0
130.0
120.0
134.0
80.0
416.0
13.0
55.5
98.5
600.0
16
Matrix_ID-Eng.indd Sec1:16
2009-04-15
9:54:37
SAMSUNG Video Wall Kit Setup Guide
5. Product Specifications
BRACKET-LINK MIDDLE
170
4-M5TAP, THRU(C1)
M4TAP, THRU(C1)
C3
5.2
45
69.6
45
5.2
BRACKET-TOP
30
7.
21.5
1.5
2
32.4
75
45
6
35
41
127.5
155.5
18
Matrix_ID-Eng.indd Sec1:18
2009-04-15
9:54:39
SAMSUNG Video Wall Kit Setup Guide
5. Product Specifications
BRACKET-LINK
4.
10.5
70
23.5
14.5
34
5
14.5
39.2
45
6.
5
W2-M5 TAP, THRU(C1)
10.4
23.5
84.5
BRACKET-BALLAST
34.2
°
130.1
45.6
15
10
3.9
20
°
48.8
°
80
.3
°
23
19
Matrix_ID-Eng.indd Sec1:19
2009-04-15
9:54:40
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care centre.
