OFFICEJET PRO 8000
User Guide
A809
HP Officejet Pro 8000 (A809) Printer
Series
User Guide
Copyright information
© 2009 Copyright Hewlett-Packard
Development Company, L.P.
Hewlett-Packard Company
notices
The information contained in this
document is subject to change without
notice.
All rights reserved. Reproduction,
adaptation, or translation of this
material is prohibited without prior
written permission of HewlettPackard, except as allowed under
copyright laws.
The only warranties for HP products
and services are set forth in the
express warranty statements
accompanying such products and
services. Nothing herein should be
construed as constituting an
additional warranty. HP shall not be
liable for technical or editorial errors
or omissions contained herein.
Acknowledgements
Windows and Windows XP are U.S.
registered trademarks of Microsoft
Corporation. Windows Vista is either a
registered trademark or trademark of
Microsoft Corporation in the United
States and/or other countries.
Safety information
Always follow basic safety
precautions when using this product
to reduce risk of injury from fire or
electric shock.
1. Read and understand all
instructions in the documentation that
comes with the device.
2. Observe all warnings and
instructions marked on the product.
3. Unplug this product from wall
outlets before cleaning.
4. Do not install or use this product
near water, or when you are wet.
5. Install the product securely on a
stable surface.
6. Install the product in a protected
location where no one can step on or
trip over the line cord, and the line
cord cannot be damaged.
7. If the product does not operate
normally, see Maintain and
troubleshoot.
8. There are no user-serviceable parts
inside. Refer servicing to qualified
service personnel.
9. Use only the external power
adaptor/battery provided with the
device.
Contents
1
Get started
Find other resources for the product .........................................................................................7
Find the device model number .................................................................................................8
Accessibility ..............................................................................................................................9
Understand the device parts .....................................................................................................9
Front view .........................................................................................................................10
Control panel ....................................................................................................................10
Back view .........................................................................................................................11
Connection information ...........................................................................................................11
Turn off the device ..................................................................................................................12
Eco-Tips .................................................................................................................................12
2
Install the accessories
Install the duplexer .................................................................................................................13
Install Tray 2 ...........................................................................................................................13
Turn on accessories in the printer driver .................................................................................14
To turn on accessories on Windows computers ...............................................................14
To turn on accessories on Macintosh computers .............................................................. 14
3
Use the device
Select print media ...................................................................................................................15
Recommended papers for printing .................................................................................... 15
Tips for selecting and using print media ...........................................................................17
Understand specifications for supported media ................................................................18
Understand supported sizes .......................................................................................18
Understand supported media types and weights ........................................................20
Set minimum margins .......................................................................................................21
Load media .............................................................................................................................22
Configure trays .......................................................................................................................23
Change print settings ..............................................................................................................24
To change settings from an application for current jobs (Windows) .................................. 25
To change default settings for all future jobs (Windows) ..................................................25
To change settings (Mac OS X) ........................................................................................25
Print on both sides (duplexing) ...............................................................................................25
Guidelines for printing on both sides of a page .................................................................26
Perform duplexing .............................................................................................................26
Print on special and custom-sized media ...............................................................................27
Print borderless ......................................................................................................................28
To print a borderless document (Windows) ......................................................................28
To print a borderless document (Mac OS X) ....................................................................28
Print a Web page (Windows only) ..........................................................................................29
Cancel a print job ....................................................................................................................29
1
4
Configure and manage
Manage the device .................................................................................................................31
Monitor the device ............................................................................................................32
Administer the device .......................................................................................................33
Use device management tools ...............................................................................................34
Embedded Web server .....................................................................................................34
To open the embedded Web server ...........................................................................34
Embedded Web server pages ....................................................................................35
HP Toolbox (Windows) .....................................................................................................36
Open the HP Toolbox .................................................................................................36
HP Toolbox tabs .........................................................................................................37
Network Toolbox .........................................................................................................38
Use the HP Solution Center (Windows) ............................................................................38
HP Printer Utility (Mac OS X) ............................................................................................38
Open the HP Printer Utility ..........................................................................................38
HP Printer Utility panels ..............................................................................................39
Use the HP Device Manager ......................................................................................40
Understand the self-test diagnostic page ................................................................................40
Understand the network configuration or wireless (some models only) status report .............41
Configure the device (Windows) .............................................................................................43
Direct connection ..............................................................................................................43
To install the software before connecting the device (recommended) ........................43
To connect the device before installing the software ..................................................43
To share the device on a locally shared network ........................................................44
Network connection ..........................................................................................................44
Install the device on a network .................................................................................... 45
Install the device software on client computers ........................................................... 45
Install the printer driver using Add Printer ...................................................................46
Install the device in a pure IPV6 network environment ...............................................46
Configure the device (Mac OS X) ...........................................................................................47
To install the software for network or direct connection ....................................................47
To share the device on a locally shared network ..............................................................47
Set up the device for wireless communication (some models only) ........................................48
Understand 802.11 wireless network settings ..................................................................49
To set up wireless communication using the installer (Windows) .....................................50
To set up the device for wireless communication using the installer (Mac OS X) .............50
Connect the device using an ad hoc wireless network connection ...................................51
To turn off wireless communication ..................................................................................51
Configure your firewall to work with HP devices ...............................................................51
Change the connection method ........................................................................................52
Guidelines for ensuring wireless network security ............................................................53
To add hardware addresses to a wireless access point .............................................53
Other guidelines ..........................................................................................................53
Uninstall and reinstall the software .........................................................................................54
5
Maintain and troubleshoot
Supported ink cartridges .........................................................................................................57
Replace the ink cartridges ......................................................................................................58
2
Contents
Maintain the printheads ..........................................................................................................59
To check printhead health ................................................................................................59
To print the print quality diagnostic page ..........................................................................59
To align the printheads .....................................................................................................61
To clean the printheads ....................................................................................................61
To clean the printhead contacts manually ........................................................................62
To calibrate the linefeed ...................................................................................................64
To replace the printheads .................................................................................................64
Store printing supplies ............................................................................................................66
Store ink cartridges ...........................................................................................................66
Store printheads ...............................................................................................................66
Troubleshooting tips and resources ........................................................................................66
Solve printing problems ..........................................................................................................67
The device shuts down unexpectedly ...............................................................................67
The device is not responding (nothing prints) ...................................................................67
Printer lights are blinking ..................................................................................................68
Device takes a long time to print .......................................................................................68
Placement of the text or graphics is wrong .......................................................................69
The device prints half a page, then ejects the paper ........................................................69
Device is printing from the wrong input tray ......................................................................70
Poor print quality and unexpected printouts ............................................................................70
General print quality troubleshooting ................................................................................70
Meaningless characters print ............................................................................................71
Ink is smearing .................................................................................................................71
Ink is not filling the text or graphics completely .................................................................72
Output is faded or dull colored ..........................................................................................72
Colors are printing as black and white ..............................................................................72
Wrong colors are printing ..................................................................................................72
Printout shows bleeding colors .........................................................................................72
The printout has a horizontal band of distortion near the bottom of a borderless print .....73
Colors do not line up properly ...........................................................................................73
Text or graphics are streaked ...........................................................................................74
Something on the page is missing or incorrect .................................................................74
Solve paper-feed problems .....................................................................................................74
Optional Tray 2 cannot be inserted ...................................................................................74
Media stops halfway .........................................................................................................74
Another paper-feed problem is occurring ..........................................................................74
Solve device management problems ......................................................................................76
Embedded Web server cannot be opened .......................................................................76
Solve network problems .........................................................................................................77
3
Solve wireless problems .........................................................................................................77
Basic wireless troubleshooting .........................................................................................78
Advanced wireless troubleshooting ..................................................................................78
Make sure your computer is connected to your network .............................................79
Make sure that the HP device is connected to your network ......................................80
Check to see if the firewall software is blocking communication .................................81
Make sure the HP device is online and ready .............................................................81
Your wireless router is using a hidden SSID ...............................................................82
Make sure the wireless version of the HP device is set as the default printer
driver (Windows only) .................................................................................................82
Make sure the HP Network Devices Support service is running (Windows only) ........82
Add hardware addresses to a wireless access point (WAP) .......................................83
Troubleshoot installation issues ..............................................................................................83
Hardware installation suggestions ....................................................................................83
Software installation suggestions ...................................................................................... 84
Solve network problems ...................................................................................................84
Clear jams ..............................................................................................................................86
Clear a jam in the device ..................................................................................................86
Tips for avoiding jams .......................................................................................................87
Errors ......................................................................................................................................87
Printhead(s) Missing - The following printhead appears to be missing, not detected,
or incorrectly installed .......................................................................................................88
Incompatible Printhead - The following printhead is not intended for use in this
printer ...............................................................................................................................88
Printhead problem - The following printhead has a problem .............................................88
Device Disconnected ........................................................................................................88
Replace Cartridge(s) Soon - Replace the following cartridge soon ................................... 88
Cartridge Problem - The following cartridge appears to be missing or damaged ..............89
Cartridge Problem - The following cartridge must be replaced .........................................89
Paper Mismatch - Paper detected does not match paper size or type selected ...............89
The cartridge cradle cannot move. Please turn device power off. Check device for
paper jam or other obstruction ..........................................................................................89
Paper Jam - There is a paper jam (or misfeed). Clear the jam and press the
Resume button on the printer ...........................................................................................89
The printer is out of paper. Load more paper and press the Resume button on the
front of the printer .............................................................................................................89
Incompatible Cartridge(s) - The following cartridge is not intended for use in this
printer. ..............................................................................................................................90
Printer Offline - Your printer is currently offline .................................................................90
Printer Paused - Your printer is currently paused .............................................................90
Document failed to print - The job failed to print due to an error in the printing
system ..............................................................................................................................91
General printer error..........................................................................................................91
6
Control-panel lights reference
Interpreting control-panel lights ..............................................................................................92
A HP supplies and accessories
Order printing supplies online .................................................................................................97
Accessories ............................................................................................................................97
4
Contents
Supplies ..................................................................................................................................98
Ink cartridges and printheads ...........................................................................................98
HP media ..........................................................................................................................98
B Support and warranty
Obtain electronic support ........................................................................................................99
Hewlett-Packard limited warranty statement .........................................................................100
Ink cartridge warranty information ......................................................................................... 101
Obtain HP telephone support ...............................................................................................102
Before you call ................................................................................................................102
Support process .............................................................................................................. 102
HP support by phone ......................................................................................................103
Phone support period ...............................................................................................103
Telephone support numbers .....................................................................................104
Placing a call .............................................................................................................105
After the phone support period .................................................................................105
Additional warranty options .............................................................................................105
HP Quick Exchange Service (Japan) ..............................................................................106
HP Korea customer support ...........................................................................................106
Prepare the device for shipment ...........................................................................................107
Remove the ink cartridges and printheads before shipment ...........................................107
Pack the device ....................................................................................................................109
C Device specifications
Physical specifications ..........................................................................................................111
Product features and capacities ...........................................................................................112
Processor and memory specifications ..................................................................................112
System requirements ............................................................................................................112
Network protocol specifications ............................................................................................113
Embedded Web server specifications ................................................................................... 114
Print resolution ......................................................................................................................114
Environmental specifications ................................................................................................114
Electrical specifications .........................................................................................................114
Acoustic emission specifications (print in Draft mode, noise levels per ISO 7779) ...............115
D Regulatory information
FCC statement .....................................................................................................................116
Notice to users in Korea .......................................................................................................117
VCCI (Class B) compliance statement for users in Japan ....................................................117
Notice to users in Japan about the power cord .....................................................................117
Toxic and hazardous substance table ..................................................................................117
Regulatory information for wireless products ........................................................................118
Exposure to radio frequency radiation ............................................................................118
Notice to users in Brazil ..................................................................................................118
Notice to users in Canada ..............................................................................................118
Notice to users in Taiwan ...............................................................................................119
European Union regulatory notice ..................................................................................120
Regulatory model number ....................................................................................................120
Declaration of conformity ......................................................................................................121
5
Environmental product stewardship program .......................................................................123
Paper use .......................................................................................................................123
Plastics ...........................................................................................................................123
Material safety data sheets .............................................................................................123
Recycling program ..........................................................................................................123
HP inkjet supplies recycling program ..............................................................................123
Disposal of waste equipment by users in private households in the European Union ....124
Power consumption ........................................................................................................125
Chemical Substances .....................................................................................................125
Third-party licenses ..............................................................................................................126
Index...........................................................................................................................................131
6
1
Get started
This guide provides details about how to use the device and to resolve problems.
•
•
•
•
•
•
•
Find other resources for the product
Find the device model number
Accessibility
Understand the device parts
Connection information
Turn off the device
Eco-Tips
Find other resources for the product
You can obtain product information and further troubleshooting resources that are not
included in this guide from the following resources:
Resource
Description
Location
Setup poster
Provides illustrated setup
information.
A printed version of this
document is provided with
the device, it is also available
on the HP Web site
www.hp.com/support.
Readme file and release notes
Provide late-breaking
information and
troubleshooting tips.
Included on the Starter CD.
Wireless Getting Started
Guide (some models only)
Provides instructions for
setting up the device’s
wireless function.
A printed version of the
document is provided with
the device.
Device management tools
(network connection)
Allows you to view status
information, change settings,
and manage the device.
Available from a connected
computer.
For more information, see
Embedded Web server.
HP Toolbox (Microsoft®
Windows®)
Provides information about
printhead health and access
to maintenance services.
Typically installed with the
device software.
For more information, see HP
Toolbox (Windows).
HP Printer Utility (Mac OS X)
Contains tools to configure
print settings, calibrate the
device, clean the printheads,
print the configuration page,
and find support information
from the Web site.
Typically installed with the
device software.
For more information, see HP
Printer Utility (Mac OS X).
Get started
7
Chapter 1
(continued)
Resource
Description
Location
Control panel
Provides status, error, and
warning information about
operations.
For more information, see
Control panel.
Logs and reports
Provides information about
events that have occurred.
For more information, see
Monitor the device.
Configuration page
•
For more information, see
Understand the self-test
diagnostic page.
Device information:
◦ Product name
◦
◦
◦
•
•
•
Model number
Serial number
Firmware version
number
Accessories installed (for
example, Tray 2)
Number of pages printed
from the trays and
accessories
Printing supply status
Print quality diagnostic page
Diagnoses issues affecting
print quality and helps you
decide whether to run any
maintenance services to
improve the print quality of
your printouts.
For more information, see To
print the print quality
diagnostic page.
HP Web sites
Provide the latest printer
software, and product and
support information.
www.hp.com/support
HP telephone support
Lists information to contact
HP.
For more information, see
Obtain HP telephone support.
HP Solution Center (Windows)
Allows you to change device
settings, order supplies, start,
and access the onscreen
Help. Depending on the
devices you have installed,
the HP Solution Center
provides additional features,
such as access to the HP
photo and imaging software
and the Fax Setup Wizard.
For more information, see
Use the HP Solution Center
(Windows).
Typically installed with the
device software.
www.hp.com
Find the device model number
In addition to the model name that appears on the front of the device, this device has a
specific model number. You can use this number to help determine which supplies or
accessories are available for your product, as well as when obtaining support.
8
Get started
The model number is printed on a label located inside the device, near the ink
cartridges area.
Accessibility
The device provides a number of features that make it accessible for people with
disabilities.
Visual
The device software is accessible for users with visual impairments or low vision
through the use of your operating-system's accessibility options and features. It also
supports most assistive technology such as screen readers, Braille readers, and voiceto-text applications. For users who are color blind, colored buttons and tabs used in
the software and on the control panel have simple text or icon labels that convey the
appropriate action.
Mobility
For users with mobility impairments, the device software functions can be executed
through keyboard commands. The software also supports Windows accessibility
options such as StickyKeys, ToggleKeys, FilterKeys, and MouseKeys. The device
doors, buttons, paper trays, and paper guides can be operated by users with limited
strength and reach.
Support
For more details about the accessibility of this product and HP's commitment to
product accessibility, visit HP's Web site at www.hp.com/accessibility.
For accessibility information for Mac OS X, visit the Apple Web site at www.apple.com/
accessibility.
Understand the device parts
•
•
•
Front view
Control panel
Back view
Understand the device parts
9
Chapter 1
Front view
1
Control panel
2
Output tray
3
Tray 1
4
Width guides
5
Ink cartridge door
6
Ink cartridges
7
Printhead latch
8
Printheads
9
Tray 2 (Tray 2 is sold as an accessory. For ordering information, see Accessories.)
Control panel
For more information about interpreting control-panel lights, see Control-panel lights
reference.
10
1
Ink cartridge lights
2
Printhead lights
Get started
(continued)
NOTE: The printhead lights are only visible when a printhead needs attention.
3
4
Network button
(available with some models)
Wireless button
(available with some models)
Cancel
button
5
Resume
6
button and light
Power button and light
Back view
1
Power input
2
Ethernet network port
3
Rear universal serial bus (USB) port
4
Automatic two-sided printing accessory (duplexer)
5
Duplex rear access door latch
Connection information
Description
Recommended
number of connected
computers for best
performance
Supported software
features
Setup instructions
USB connection
One computer
connected with a USB
cable to the rear USB
2.0 high-speed port on
the device.
All features are
supported.
Follow the setup poster
guide for detailed
instructions.
Ethernet (wired)
connection
Up to five computers
connected to the device
using a hub or router.
All features are
supported.
Follow the instructions
in the getting started
guide, and then see To
share the device on a
locally shared network
in this guide for further
instructions.
Connection information
11
Chapter 1
(continued)
Description
Recommended
number of connected
computers for best
performance
Supported software
features
Setup instructions
Printer sharing
Up to five computers.
All features resident on
the host computer are
supported. Only print is
supported from the
other computers.
Follow the instructions
in To share the device
on a locally shared
network.
All features are
supported.
Follow the instructions
in Set up the device for
wireless communication
(some models only).
The host computer must
be turned on at all
times, or the other
computers cannot print
to the device.
802.11 wireless (some
models only)
Up to five computers
connected to the device
using a hub or router.
Turn off the device
Turn off the HP product by pressing the Power button located on the product. Wait
until the Power light turns off before unplugging the power cord or turning off a power
source. If you improperly turn off the HP product, the print carriage might not return to
the correct position, which might cause problems with the printheads and print quality
issues.
Eco-Tips
HP is committed to helping customers reduce their environmental footprint. HP has
provided the Eco-Tips below to help you focus on ways to assess and reduce the
impact of your printing choices. In addition to specific features in this product, please
visit the HP Eco Solutions website for more information on HP's environmental
initiatives.
www.hp.com/hpinfo/globalcitizenship/environment/
•
•
•
•
12
Duplex printing: Use Paper-saving Printing to print two-sided documents with
multiple pages on same sheet to reduce paper usage. For more information, see
Print on both sides (duplexing).
Smart Web printing: The HP Smart Web Printing interface includes a Clip Book
and Edit Clips window where you can store, organize, or print clips you have
gathered from the Web. For more information, see Print a Web page (Windows
only).
Energy Savings Information: To determine the ENERGY STAR® qualification
status for this product, see Power consumption.
Recycled Materials: For more information regarding recycling of HP products,
please visit:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/
Get started
2
Install the accessories
This section contains the following topics:
•
•
•
Install the duplexer
Install Tray 2
Turn on accessories in the printer driver
Install the duplexer
You can print on both sides of a sheet of paper automatically. For information on using
the duplexer, see Print on both sides (duplexing).
To install the duplexer
▲ Slide the duplexer into the device until the unit locks into place. Do not press the
buttons on either side of the duplexer when installing the unit; use them only for
removing the unit from the device.
Install Tray 2
NOTE: Tray 2 is sold as an accessory. For ordering information, see Accessories.
Tray 2 can hold up to 250 sheets of plain paper.
To install Tray 2
1. Unpack the tray, remove the packing tapes and materials, and move the tray to the
prepared location. The surface must be sturdy and level.
2. Turn off the device, and disconnect the power cord.
3. Set the device on top of the tray.
CAUTION: Be careful to keep your fingers and hands clear of the bottom of
the device.
4. Connect the power cord and turn on the device.
5. Enable Tray 2 in the printer driver. For more information, see Turn on accessories
in the printer driver.
Install the accessories
13
Chapter 2
Turn on accessories in the printer driver
•
•
To turn on accessories on Windows computers
To turn on accessories on Macintosh computers
To turn on accessories on Windows computers
After you install the device software on Windows computers, Tray 2 must be turned on
in the print driver in order for it to work with the device. (The duplexer does not need to
be turned on.)
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
2. Right-click the icon for the preferred printer driver, and then click Properties.
3. Select one of these tabs: Configure, Device Settings, or Device Options. (The
name of the tab depends on the printer driver and the operating system.)
4. On the selected tab, click the accessory that you want to turn on, click Installed
from the drop-down menu, and then click OK.
To turn on accessories on Macintosh computers
Mac OS X automatically turns on all accessories in the printer driver when you install
the device software. If you add a new accessory later, follow these steps:
Mac OS X (v10.4)
1. Double-click Macintosh HD, double-click Applications, double-click Utilities, and
then double-click Printer Setup Utility.
2. On the Printer List window, click once on the device you want to set up to select it.
3. From the Printers menu, select Show info.
4. Click the Names and Location drop-down menu and select Installable Options.
5. Check the accessory that you want to turn on.
6. Click Apply Changes.
Mac OS X (v10.5)
1. Open the System Preferences and then select Print & Fax.
2. Click Options & Supplies.
3. Click the Driver tab.
4. Select the options you want to install, and then click OK.
14
Install the accessories
3
Use the device
This section contains the following topics:
•
•
•
•
•
•
•
•
•
Select print media
Load media
Configure trays
Change print settings
Print on both sides (duplexing)
Print on special and custom-sized media
Print borderless
Print a Web page (Windows only)
Cancel a print job
Select print media
The device is designed to work well with most types of office media. It is best to test a
variety of print media types before buying large quantities. Use HP media for optimum
print quality. Visit the HP Web site at www.hp.com for more information about HP
media.
HP recommends plain papers with the ColorLok logo for printing
and copying of everyday documents. All papers with the
ColorLok logo are independently tested to meet high standards
of reliability and print quality, and produce documents with crisp,
vivid color, bolder blacks & dry faster than ordinary plain papers.
Look for papers with the ColorLok logo in a variety of weights
and sizes from major paper manufacturers.
This section contains the following topics:
•
•
•
•
Recommended papers for printing
Tips for selecting and using print media
Understand specifications for supported media
Set minimum margins
Recommended papers for printing
If you want the best print quality, HP recommends using HP papers that are
specifically designed for the type of project you are printing.
Use the device
15
Chapter 3
Depending on your country/region, some of these papers might not be available.
HP Brochure Paper
HP Superior Inkjet
Paper
These papers are glossy-coated or matte-coated on both sides for
two-sided use. They are the perfect choice for near-photographic
reproductions and business graphics for report covers, special
presentations, brochures, mailers, and calendars.
HP Bright White Inkjet
Paper
HP Bright White Inkjet Paper delivers high-contrast colors and sharp
text. It is opaque enough for two-sided color usage with no showthrough, which makes it ideal for newsletters, reports, and flyers. It
features ColorLok Technology for less smearing, bolder blacks and
vivid colors.
HP Printing Paper
HP Printing Paper is a high-quality multifunction paper. It produces
documents that look and feel more substantial than documents
printed on standard multipurpose or copy paper. It features ColorLok
Technology for less smearing, bolder blacks and vivid colors. It is
acid-free for longer lasting documents.
HP Office Paper
HP Office Paper is a high-quality multifunction paper. It is suitable for
copies, drafts, memos and other everyday documents. It features
ColorLok Technology for less smearing, bolder blacks and vivid
colors. It is acid-free for longer lasting documents
HP Multipurpose Paper
HP Multipurpose Paper is a high-quality multifunction paper. It
features ColorLok Technology for less smearing, bolder blacks and
vivid colors. It is acid-free for longer lasting documents.
HP Premium
Presentation Paper
These papers are heavy two-sided matte papers perfect for
presentation, proposals, reports and newsletters. They are
heavyweight for an impressive look and feel.
HP Professional Paper
HP Premium Inkjet
Transparency Film
HP Premium Inkjet Transparency Film makes your color
presentations vivid and even more impressive. This film is easy to
use and handle and dries quickly without smudging.
HP Advanced Photo
Paper
This thick photo paper features an instant-dry finish for easy handling
without smudging. It resists water, smears, fingerprints, and humidity.
Your prints have a look and feel comparable to a store processed
photo. It is available in several sizes, including A4, 8.5 x 11 inch, 10 x
15 cm (4 x 6 inch), 13 x 18 cm (5 x 7 inch) and two finishes – glossy
or soft gloss (satin matte). It is acid-free for longer lasting documents.
HP Everyday Photo
Paper
Print colorful, everyday snapshots at a low cost, using paper
designed for casual photo printing. This affordable, photo paper dries
quickly for easy handling. Get sharp, crisp images when you use this
paper with any inkjet printer. Available in matte finish in 8.5 x 11 inch,
A4, and 10 x 15 cm (4 x 6 inch). It is acid-free for longer lasting
documents.
To order HP papers and other supplies, go to www.hp.com/buy/supplies. If prompted,
choose your country/region, follow the prompts to select your product, and then click
one of the shopping links on the page.
NOTE: At this time, some portions of the HP Web site are available in English only.
HP Photo Value Packs:
HP Photo Value Packs conveniently package Original HP ink cartridges and HP
Advanced Photo Paper to save you time and take the guesswork out of printing
16
Use the device
affordable professional photos with your HP printer. Original HP inks and HP
Advanced Photo Paper have been designed to work together so your photos are long
lasting and vivid, print after print. Great for printing out an entire vacation’s worth of
photos or multiple prints to share.
Tips for selecting and using print media
For the best results, observe the following guidelines:
•
•
•
Always use media that conforms to the device specifications. For more
information, see Understand specifications for supported media.
Load only one type of media at a time into a tray. If you place a special media on
top of a plain media, then you may end up with a paper jam or an incorrect print.
For Tray 1 and Tray 2, load media print-side down, aligned against the back of the
tray. Center the media in the input tray, and adjust the paper-width guides. For
more information, see Load media.
NOTE: Tray 2 is sold as an accessory. For ordering information, see
Accessories.
•
•
•
Tray 2 is designed to hold only plain paper.
Do not overload the trays. For more information, see Understand specifications for
supported media. HP recommends loading special media no higher than 2/3 full.
To prevent jams, poor print quality, and other printing problems, avoid the following
media:
◦ Multipart forms
◦ Media that is damaged, curled, or wrinkled
◦ Media with cutouts or perforations
◦ Media that is heavily textured, embossed, or does not accept ink well
◦ Media that is too lightweight or stretches easily
Cards and envelopes
• Avoid envelopes that have a very slick finish, self-stick adhesives, clasps, or
windows. Also, avoid cards and envelopes with thick, irregular, or curled edges, or
areas that are wrinkled, torn, or otherwise damaged.
• Use tightly constructed envelopes, and make sure the folds are sharply creased.
• Load envelopes with the flaps facing up and to the right or the back of the device.
Select print media
17
Chapter 3
Photo media
• Use the Best mode to print photographs. Note that in this mode, printing takes
longer and more memory is required from your computer.
• Remove each sheet as it prints and set it aside to dry. Allowing wet media to stack
up may cause smearing.
Transparencies
• Insert transparencies with the rough side down and the adhesive strip pointing
towards the back of the device.
• Remove each sheet as it prints and set it aside to dry. Allowing wet media to stack
up may cause smearing.
Custom-sized media
• Use only custom-sized media that is supported by the device.
• If your application supports custom-sized media, set the media size in the
application before printing the document. If not, set the size in the printer driver.
You might need to reformat existing documents to print them correctly on customsized media.
Understand specifications for supported media
Use the Understand supported sizes and Understand supported media types and
weights tables to determine the correct media to use with your device, and determine
what features will work with your media.
Always use the correct media-type settings in the printer driver, and configure the trays
for the correct media type. HP recommends testing any paper before buying it in large
quantities.
•
•
Understand supported sizes
Understand supported media types and weights
Understand supported sizes
NOTE: Tray 2 is sold as an accessory. For ordering information, see Accessories.
Media size
Standard media sizes
U.S. Letter (216 x 279 mm; 8.5 x 11 inches)
8.5 x 13 inches (216 x 330 mm)
U.S. Legal (216 x 356 mm; 8.5 x 14 inches)
A4 (210 x 297 mm; 8.3 x 11.7 inches)
U.S. Executive (184 x 267 mm; 7.25 x
10.5 inches)
18
Use the device
Tray 1
Tray 2
Duplexer
(continued)
Media size
Tray 1
Tray 2
Duplexer
U.S. Statement (140 x 216 mm; 5.5 x 8.5
inches)
B5 (JIS) (182 x 257 mm; 7.17 x 10.12
inches)
A5 (148 x 210 mm; 5.8 x 8.3 inches)
Borderless A4 (210 x 297 mm; 8.3 x 11.7
inches)
Borderless A5 (148 x 210 mm; 5.8 x 8.3
inches)
Borderless B5 (JIS) (182 x 257 mm; 7.17
x 10.12 inches)
Envelopes
U.S. #10 Envelope (105 x 241 mm; 4.12 x
9.5 inches)
Monarch Envelope (98 x 191 mm; 3.88 x
7.5 inches)
Card Envelope (111 x 152 mm; 4.4 x 6
inches)
A2 Envelope (111 x 146 mm; 4.37 x 5.75
inches)
DL Envelope (110 x 220 mm; 4.3 x 8.7
inches)
C5 Envelope (162 x 229 mm; 6.4 x 9
inches)
C6 Envelope (114 x 162 mm; 4.5 x 6.4
inches)
Japanese Envelope Chou #3 (120 x 235
mm; 4.7 x 9.3 inches)
Japanese Envelope Chou #4 (90 x 205
mm; 3.5 x 8.1 inches)
Cards
Index card (76.2 x 127 mm; 3 x 5 inches)
Index card (102 x 152 mm; 4 x 6 inches)
Index card (127 x 203 mm; 5 x 8 inches)
Index card (216 x 279 mm; 8.5 x 11 inches)
Hagaki* (100 x 148 mm; 3.9 x 5.8 inches)
Ofuku Hagaki (148 x 200 mm; 5.8 x 7.9
inches) *
Select print media
19
Chapter 3
(continued)
Media size
Tray 1
Tray 2
Duplexer
Photo media
Photo media (76.2 x 127 mm; 3 x 5 inches)
Photo media (102 x 152 mm; 4 x 6 inches)
Photo media with tear-off tab (102 x 152
mm; 4 x 6 inches)
Borderless photo media (102 x 152 mm; 4
x 6 inches)
Borderless photo media (5 x 7 inches)
Borderless photo media (8.5 x 11 inches)
Other media
Custom-sized media between 76.2 to 216
mm wide and 127 to 356 mm long (3 to
8.5 inches wide and 5 to 14 inches long)
* The device is compatible with plain and inkjet hagaki from Japan Post only. It is not
compatible with photo hagaki from Japan Post.
Understand supported media types and weights
NOTE: Tray 2 is sold as an accessory. For ordering information, see Accessories.
Tray
Type
Weight
Capacity
Tray 1
Paper
60 to 105 g/m
2
(16 to 28 lb bond)
Transparencies
Up to 250 sheets of
plain paper
(25 mm or 1 inch
stacked)
Up to 70 sheets
(17 mm or 0.67 inch
stacked)
Photo media
250 g/m2
Up to 100 sheets
(66 lb bond)
(17 mm or 0.67 inch
stacked)
Labels
Up to 100 sheets
(17 mm or 0.67 inch
stacked)
Envelopes
Cards
75 to 90 g/m2
Up to 30 sheets
(20 to 24 lb bond
envelope)
(17 mm or 0.67 inch
stacked)
Up to 200 g/m2
Up to 80 cards
(110 lb index)
20
Use the device
(continued)
Tray
Type
Weight
Capacity
Tray 2
Plain paper only
60 to 105 g/m2
Up to 250 sheets of
plain paper
(16 to 28 lb bond)
Duplexer
Paper
60 to 105 g/m2
(25 mm or 1.0 inch
stacked)
Not applicable
(16 to 28 lb bond)
Output-bin
All supported media
Up to 150 sheets of
plain paper (text
printing)
Set minimum margins
The document margins must match (or exceed) these margin settings in portrait
orientation.
Media
(1) Left
margin
(2) Right
margin
(3) Top
margin
(4) Bottom
margin
U.S. Letter
3.3 mm (0.13
inch)
3.3 mm (0.13
inch)
3.3 mm (0.13
inch)
3.3 mm (0.13
inch)
3.3 mm (0.13
inch)
3.3 mm (0.13
inch)
16.5 mm
(0.65 inch)
16.5 mm
(0.65 inch)
U.S. Legal
A4
U.S. Executive
U.S. Statement
8.5 x 13 inches
B5
A5
Cards
Custom-sized media
Photo media
Envelopes
Select print media
21
Chapter 3
NOTE: If you are using the duplexer to print on both sides of the paper, the
minimum top and bottom margins must match or exceed 12 mm (0.47 inch).
NOTE: For Mac OS X, the minimum bottom margin for all the media (except
envelope, Hagaki, and Ofuku Hagaki) is 12 mm (0.47 inch).
Load media
This section provides instructions for loading media into the device.
NOTE: Tray 2 is sold as an accessory. For ordering information, see Accessories.
To load Tray 1 (main tray)
1. Lift the output tray.
2. Slide the media guides out to the widest setting.
3. Insert the media print-side down in the center of the tray, make sure the media
does not exceed the line marking in the tray. Slide the media guides towards the
center until they touch the left and right sides of the media, and then gently push
the paper stack to the back of the tray.
NOTE: Do not load paper while the device is printing.
22
Use the device
4. Lower the output tray.
5. Pull out the extension on the output tray.
NOTE: For media longer than 11 inches (279 mm), pull the extension out to
the maximum extended position.
To load Tray 2
1. Pull the tray out of the device by grasping the front of the tray.
2. Slide the media guides out to the widest setting.
3. Insert the media print-side down in the center of the tray, make sure the media
does not exceed the line marking in the tray. Slide the media guides towards the
center until they touch the left and right sides of the media, and then gently push
the paper stack to the back of the tray.
NOTE: Do not load paper while the device is printing.
4. Gently reinsert the tray.
5. Pull out the extension on the output tray.
NOTE: For media longer than 11 inches (279 mm), pull the extension out to
the maximum extended position.
Configure trays
NOTE: Tray 2 is sold as an accessory. For ordering information, see Accessories.
To configure trays, you must have Tray 2 installed and turned on in the printer
driver.
Configure trays
23
Chapter 3
By default, the device draws media from Tray 1. If Tray 1 is empty, the device draws
media from Tray 2 (if it is installed and loaded with media). You can change this
default setting by using the following features:
•
•
Tray Lock: Use this feature to protect special media such as letterhead or
preprinted media from accidental use. If the device runs out of media while printing
a document, it will not use media from a locked tray to complete the print job.
Default Tray: Use this feature to determine the first tray from which the device
draws media.
NOTE: To use the Tray Lock and Default Tray settings, you must select the
automatic tray selection option in the device software. If the device is on a network
and you set a Default Tray, the setting will affect all users of the device.
Tray 2 is designed to hold only plain paper.
The following table lists possible ways you can use the tray settings to meet your
printing needs.
I want to...
Follow these steps
Load both trays with the same media, and
have the device pick media from one tray if
the other one is empty.
•
Have both special media (such as
transparencies or letterhead) and plain paper
loaded in the trays.
•
Load media in both trays but have the device
pick media from a specific tray first.
•
•
•
•
•
Load media in Tray 1 and Tray 2. For
more information, see Load media.
Make sure TrayLock is disabled.
Load special media in Tray 1 and plain
paper in Tray 2.
Make sure the default tray is set to Tray 2.
Make sure Tray Lock is set to Tray 1.
Load media in Tray 1 and Tray 2.
Make sure Default Tray is set to the
appropriate tray.
To configure the trays
1. Make sure the device is turned on.
2. Perform one of the following:
• Embedded Web server: Click the Settings, tab and click Paper Handling in
the left panel.
• HP Toolbox (Windows): Click the Services, tab and click Paper Handling.
• HP Printer Utility (Mac OS X): Click Trays Configuration from the Printer
Settings panel.
3. Change the desired tray setting, and then press OK or Apply.
Change print settings
You can change print settings (such as paper size or type) from an application or the
printer driver. Changes made from an application take precedence over changes
made from the printer driver. However, after the application is closed, the settings
return to the defaults configured in the driver.
24
Use the device
NOTE: To set print settings for all print jobs, make the changes in the printer
driver.
For more information about the features of the Windows printer driver, see the
online help for the driver. For more information about printing from a specific
application, see the documentation that came with the application.
•
•
•
To change settings from an application for current jobs (Windows)
To change default settings for all future jobs (Windows)
To change settings (Mac OS X)
To change settings from an application for current jobs (Windows)
1. Open the document that you want to print.
2. On the File menu, click Print, and then click Setup, Properties, or Preferences.
(Specific options may vary depending on the application that you are using.)
3. Choose the printing shortcut that you want, and then click OK, Print, or a similar
command.
To change default settings for all future jobs (Windows)
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
NOTE: If prompted, enter the computer administrator's password.
2. Right-click the printer icon, and then click Properties, Document Defaults, or
Printing Preferences.
3. Change the settings that you want, and then click OK.
To change settings (Mac OS X)
1. On the File menu, click Page Setup.
NOTE: In Mac OS X (v10.5), some applications do not have a Page Setup
menu, it is part of the Print menu.
2. Change the settings that you want (such as paper size), and then click OK.
3. On the File menu, click Print to open the printer driver.
4. Change the settings that you want (such as media type), and then click OK or Print.
Print on both sides (duplexing)
You can print on both sides of a sheet of media, either automatically by using the
automatic two-sided printing accessory (duplexer) or manually by turning the media
over and feeding it into the device again.
•
•
Guidelines for printing on both sides of a page
Perform duplexing
Print on both sides (duplexing)
25
Chapter 3
Guidelines for printing on both sides of a page
•
•
•
•
•
•
Always use media that conforms to the device specifications. For more
information, see Understand specifications for supported media.
Specify duplex options in your application or in the printer driver.
Do not print on both sides of transparencies, envelopes, photo paper, glossy
media, or paper lighter than 16 lb bond (60 g/m2) or heavier than 28 lb bond (105 g/
m2). Jams might occur with these media types.
Several kinds of media require a specific orientation when you print on both sides
of a page, such as letterhead, preprinted paper, and paper with watermarks and
prepunched holes. When you print from a computer running Windows, the device
prints the first side of the media first. When you print from a computer using Mac
OS X, the device prints the second side first. Load the media with the front side
facing down.
For auto-duplexing, when printing finishes on one side of the media, the device
holds the media and pauses while the ink dries. Once the ink dries, the media is
pulled back into the device and the second side is printed. When printing is
complete, the media is dropped onto the output tray. Do not grab it before printing
is complete.
You can print on both sides of supported custom-sized media by turning the media
over and feeding it into the device again. For more information, see Understand
specifications for supported media.
Perform duplexing
NOTE: You can perform manual duplexing by first printing only the odd pages,
flipping the pages over, and then printing only the even pages.
To print automatically on both sides of a page (Windows)
1. Load the appropriate media. For more information, see Guidelines for printing on
both sides of a page and Load media.
2. Make sure the duplexer is properly installed. For more information, see Install the
duplexer.
3. With a document open, click Print on the File menu, and then select a printing
shortcut.
4. Change any other settings, and then click OK.
5. Print your document.
To print automatically on both sides of a page (Mac OS X)
1. Load the appropriate media. For more information, see Guidelines for printing on
both sides of a page and Load media.
2. Make sure the duplexer is properly installed. For more information, see Install the
duplexer.
3. Verify that you are using the correct printer and page size in the Page Setup.
4. On the File menu, click Print.
5. Select Copies and Pages from the drop-down list.
6. Select the Two-sided Printing option.
26
Use the device
7. Select the binding orientation by clicking the appropriate icon.
8. Change any other settings, and then click Print.
Print on special and custom-sized media
To print on special or custom-sized media (Windows)
1. Load the appropriate media. For more information, see Load media.
2. With a document open, click Print on the File menu, and then click Setup,
Properties, or Preferences.
3. Click the Features tab.
4. Select the media size from the Size drop-down list. If you do not see the media
size, create a custom media size.
5.
6.
7.
8.
To set a custom media size
a. Select Custom from the drop-down list.
b. Type a name for the new custom size.
c. In the Width and Height boxes, type the dimensions, and then click Save.
d. Click OK twice to close the properties or preferences dialog box. Open the
dialog box again.
e. Select the new custom size.
Select the paper type in the Paper type drop-down list.
Select the media source from the Paper source drop-down list.
Change any other settings, and then click OK.
Print your document.
To print on special or custom-sized media (Mac OS X)
1. Load the appropriate media. For more information, see Load media.
2. On the File menu, click Page Setup.
NOTE: Some Mac OS X 10.5 applications do not have a Page Setup menu, it
is included in the Print menu.
3. Verify you have selected the HP device.
4. Select the media size.
To set a custom media size:
a. Click Manage Custom Sizes in the Paper Size pull-down menu.
b. Click New, and type a name for the size in the Paper Size Name box.
c. In the Width and Height boxes, type the dimensions and set the margins, if
desired.
d. Click Done or OK, and then click Save.
5. On the File menu, click Page Setup, and then select the new custom size.
NOTE: Some Mac OS X (v10.5) applications do not have a Page Setup
menu, it is included in the Print menu.
Print on special and custom-sized media
27
Chapter 3
6.
7.
8.
9.
Click OK.
On the File menu, click Print.
Open the Paper Handling panel.
Under Destination Paper Size, click the Scale to fit paper size tab, and then
select the customized paper size.
10. Change any other desired settings, and then click OK or Print.
Print borderless
Borderless printing lets you print to the edges of certain photo media types and a
range of standard media sizes.
NOTE: Open the file in a software application and assign the image size. Make
sure the size corresponds to the media size on which you are printing the image.
You can also gain access to this feature from the Printing Shortcuts tab
(Windows only). Open the printer driver, select the Printing Shortcuts tab, and
select the printing shortcut for this print job drop-down list.
•
•
To print a borderless document (Windows)
To print a borderless document (Mac OS X)
To print a borderless document (Windows)
1. Load the appropriate media. For more information, see Load media.
2. Open the file that you want to print.
3. From the application, open the printer driver:
a. Click File, and then click Print.
b. Click Properties, Setup, or Preferences.
4. Select the print settings shortcut you want to use.
5. Change any other print settings, and then click OK.
6. Print the document.
7. If you printed on photo media with a tear-off tab, remove the tab to make the
document completely borderless.
To print a borderless document (Mac OS X)
1. Load the appropriate media. For more information, see Load media.
2. Open the file that you want to print.
3. Click File, and then click Page Setup.
NOTE: Some Mac OS X (v10.5) applications do not have a Page Setup
menu, it is included in the Print menu.
4.
5.
6.
7.
28
Select the borderless media size, and then click OK.
Click File, and then click Print.
Open the Paper Type/Quality panel.
Click the Paper tab, and then select the media type from the Paper type dropdown list.
Use the device
8. Check the Borderless Printing tab and make sure Borderless is selected, and
change the Borderless Expansion if you want.
9. If you are printing photos, select Best from the Quality drop-down list.
Alternatively, select Maximum dpi, which provides up to 4800 x 1200 optimized
dpi*.
*Up to 4800 x 1200 optimized dpi for color printing and 1200 input dpi. This setting
might temporarily use a large amount of hard disk space (400 MB or more) and will
print more slowly.
10. Select the media source.
11. Change any other print settings, and then click Print.
12. If you printed on photo media with a tear-off tab, remove the tab to make the
document completely borderless.
Print a Web page (Windows only)
You can print a Web page from your Web browser on the HP Printer.
If you use Internet Explorer 6.0 or higher for Web browsing, you can use HP Smart
Web Printing to ensure simple, predictable web printing with control over what you
want and how you want it printed. You can access HP Smart Web Printing from the
toolbar in Internet Explorer. For more information about HP Smart Web Printing, see
the help file provided with it.
To print a Web page
1. Make sure you have paper loaded in the main input tray.
2. On the File menu in your Web browser, click Print.
TIP: For best results, select HP Smart Web Printing from the File menu. A
check mark appears when it is selected.
The Print dialog box appears.
3. Make sure the product is the selected printer.
4. If your Web browser supports it, select the items on the Web page that you want to
include in the printout.
For example, in Internet Explorer, click the Options tab to select options such as
As laid out on screen, Only the selected frame, and Print all linked documents.
5. Click Print or OK to print the Web page.
TIP: To print Web pages correctly, you might need to set your print orientation to
Landscape.
Cancel a print job
You can cancel a print job using one of the following methods:
Control panel: Press
Cancel button. This clears the job that the device is currently
processing. It does not affect jobs waiting to be processed.
Windows: Double-click the printer icon that appears in the lower-right corner of the
computer screen. Select the print job, and then press the Delete key on the keyboard.
Cancel a print job
29
Chapter 3
Mac OS X: Click the printer icon in the Dock, select the document, and then click Delete.
30
Use the device
4
Configure and manage
This section is intended for the administrator or individual who is responsible for
managing the device. This section contains information about the following topics:
•
•
•
•
•
•
•
•
Manage the device
Use device management tools
Understand the self-test diagnostic page
Understand the network configuration or wireless (some models only) status report
Configure the device (Windows)
Configure the device (Mac OS X)
Set up the device for wireless communication (some models only)
Uninstall and reinstall the software
Manage the device
The following table lists common tools that you can use to manage the device.
Specific procedures might include other methods. For information about accessing
and using the tools, see Use device management tools.
NOTE: Mac OS X users can use the control panel, the embedded Web server,
and the HP Printer Utility. Windows users can use the control panel, the embedded
Web server, the printer driver, the HP Toolbox, and myPrintMileage.
For more information about myPrintMileage, visit the myPrintMileage Web site.
Windows
• Device control panel
• Printer driver
• HP Toolbox
• Embedded Web server
Mac OS X
• Device control panel
• HP Printer Utility
• Embedded Web server
This section contains the following topics:
•
•
Monitor the device
Administer the device
Configure and manage
31
Chapter 4
Monitor the device
This section provides instructions for monitoring the device.
Use this tool...
to obtain the following information....
Control panel
Press and hold for three seconds the
Cancel button to obtain information about the
status of jobs that are being process, the
operating statys of the device, the status of
ink cartridges and printheads, and the
network configuration page.
Embedded Web server
•
•
•
•
Printer status information: Click the
Information tab, and then click an option
available on the left pane.
Ink cartridge and printhead status:
Click the Information tab, and then click
Ink Supplies in the left pane.*
Accumulated ink and media usage:
Click the Information tab, and then click
Usage Report in the left pane.
The device may display an approximation
of the number of pages that can be
printed with the existing supplies. This is
only an approximation and the actual
number of pages you can print may vary
depending upon the images printed, print
settings, paper type, frequency of use,
temperature, and other factors. The
approximation might change dramatically
from printed page to printed page and is
provided by HP for customer
convenience. The approximation is not a
promise or guarantee of future yield.
Usage tracking: Click Settings, and then
select Usage Tracking
HP Toolbox (Windows)
Ink cartridge information: Click the
Estimated Ink Levels tab to view the inklevel information, and then scroll to display
the Cartridge Details button. Click the
Cartridge Details button to view information
about replacement ink cartridges and
expiration dates.*
Network Toolbox
View network settings. From the Toolbox,
click the Network Settings tab.
HP Printer Utility (Mac OS X)
Ink cartridge information: Open the
Information and Support panel, and click
Supplies Status.*
* Ink level warnings and indicators provide estimates for planning purposes only.
When you receive a low-ink warning message, consider having a replacement
cartridge available to avoid possible printing delays. You do not need to replace
cartridges until prompted to do so.
32
Configure and manage
Administer the device
This section provides information about administering the device and modifying
settings.
Use this tool...
to do the following...
Control panel
Reset the administrator password and network
settings: Press and hold the
press
Power button,
Network button, (on some models, press
the Wireless button
), two times, press the
Cancel button three times, and
press the
release the Power button. For more information,
see Troubleshooting tips and resources.
Embedded Web server
•
•
•
•
•
•
•
•
Toolbox (Windows)
•
•
Set embedded Web server password: Click
the Settings tab, and then click Security in the
left pane.
Change tray settings: Click the Settings tab,
and then click Paper Handling in the left pane.
Perform device maintenance tasks: Click the
Settings tab, and then click Device Services
in the left pane.
Language or country/region: Click the
Settings tab, and then click International in
the left pane.
Configure network settings: Click the
Networking tab, and then click an option in the
left pane.
Order supplies: On any tab, click the Order
Supplies button, and then follow the onscreen
instructions.
Support: On any tab, click the Support button,
and then select a support option.
Configure e-mail alerts: Click the Settings
tab, and then click Alerts in the left pane.
Change tray settings: Click Paper Handling
on the Services tab.
Perform device maintenance tasks: Click the
Services tab.
Network Toolbox
View and change network settings. From the HP
Toolbox, click the Network Settings tab. To
change settings, click the Change Settings button.
HP Printer Utility (Mac OS X)
•
•
Change tray settings: Click Paper Handling
from the Printer Settings panel.
Perform device maintenance tasks: Open
the Information and Support panel, and then
click the option for the task that you want to
perform.
Manage the device
33
Chapter 4
Use device management tools
The following lists common tools that can be used to manage the device.
•
•
•
•
Embedded Web server
HP Toolbox (Windows)
Use the HP Solution Center (Windows)
HP Printer Utility (Mac OS X)
Embedded Web server
When the device is connected to a network, you can use the embedded Web server to
view status information, change settings, and manage it from your computer.
NOTE: For a list of system requirements for the embedded Web server, see
Embedded Web server specifications.
Some settings might be restricted by the requirement for a password.
You can open and use the embedded Web server without being connected to the
Internet; however, some features will not be available.
The embedded Web server (EWS) places a very small text file (cookies) on your hard
drive when you are browsing. These files let the EWS recognize your computer the
next time you visit. For example, if you have configured the EWS language, a cookie
helps remember which language you have selected so that the next time you open the
EWS, the pages are displayed in that language. Though some cookies are cleared at
the end of each session (such as the cookie that stores the selected language), others
(such as the cookie that stores customer-specific preferences) are stored on the
computer until you clear them manually.
You can configure your browser to accept all cookies, or you can configure it to alert
you every time a cookie is offered, which allows you to decide on a cookie-by-cookie
basis which cookies to accept or refuse. You can also use your browser to remove
unwanted cookies.
NOTE: Depending on your device, if you chose to disable cookies, you will
disable one or more of the following features:
•
•
•
•
Remembering the EWS browser language setting
Automatically refreshing the existing page
Starting where you left the application (especially useful when using setup wizards)
Preventing other users from modifying the same settings while you are making
changes
For information about how to change your privacy and cookie settings and how to view
or delete cookies, see the documentation available with your Web browser.
•
•
To open the embedded Web server
Embedded Web server pages
To open the embedded Web server
You can open the embedded Web server by using these methods:
34
Configure and manage
NOTE: To open the embedded Web server from the printer driver (Windows), or
the HP Printer Utility (Mac OS X), the device must be on a network and must have
an IP address.
When you open the embedded Web server, you might receive an invalid certificate
message. Accept the link to enter the EWS.
•
•
•
•
Web browser: In a supported Web browser on your computer, type the IP address
or hostname that has been assigned to the device.
For example, if you are using an IPv4 network environment and the IP address is
123.123.123.123, type the following address into the Web browser:
http://123.123.123.123. If you are using an IPv6-only network environment
and the IP address is FE80::BA:D0FF:FE39:73E7, type the following address into
the Web browser: http://[FE80::BA:D0FF:FE39:73E7].
The IP address and hostname for the device are listed on the network or wireless
(some models only) status report. For more information, see Understand the
network configuration or wireless (some models only) status report.
After opening the embedded Web server, you can bookmark it so that you can
return to it quickly in the future.
Windows taskbar: Right-click the HP Digital Imaging Monitor icon, point to the
device you wish to view, and then click Network Settings (EWS).
Windows Vista: Right-click the printer icon, and then select Device Web Page.
HP Printer Utility (Mac OS X): On the Printer Settings panel, click Additional
Settings, and then click the Open Embedded Web Server button.
Embedded Web server pages
The embedded Web server contains pages that you can use to view product
information and change device settings. The pages also contain links to other eservices.
Pages/buttons
Contents
Information page
Shows status information about the device, its ink
supplies and usage, and a log of device events
(such as errors).
The device might display an approximation of the
number of pages that can be printed with the
existing supplies. This is only an approximation and
the actual number of pages you can print might
vary depending upon the images printed, print
settings, paper type, frequency of use,
temperature, and other factors. The approximation
might change dramatically from printed page to
printed page and is provided by HP for customer
convenience. The approximation is not a promise
or guarantee of future yield.
Settings page
Shows the settings that have been configured for
the device and gives you the ability to change
these settings.
Use device management tools
35
Chapter 4
(continued)
Pages/buttons
Contents
Networking page
Shows network status and the network settings that
have been configured for the device. These pages
only appear if the device is connected to a network.
Support and Order Supplies buttons
Support provides a number of support services.
Order Supplies connects you to online ordering of
supplies.
HP Toolbox (Windows)
The HP Toolbox provides maintenance information about the device.
NOTE: The HP Toolbox can be installed from the Starter CD by selecting the full
installation option if the computer meets the system requirements.
This section contains the following topics:
•
•
•
Open the HP Toolbox
HP Toolbox tabs
Network Toolbox
Open the HP Toolbox
• From the HP Solution Center, click the Settings menu, point to Print Settings,
and then click Printer Toolbox.
• Right-click the HP Digital Imaging Monitor in the taskbar, point to Printer Model
Name, and then click Display Printer Toolbox.
36
Configure and manage
HP Toolbox tabs
The HP Toolbox contains the following tabs.
Tabs
Contents
Estimated Ink Level
•
Ink Level Information: Shows estimated ink
level for each cartridge.
NOTE: Ink level warnings and indicators
provide estimates for planning purposes only.
When you receive a low-ink warning message,
consider having a replacement cartridge
available to avoid possible printing delays. You
do not need to replace cartridges until
prompted to do so.
•
•
•
Information
Services
•
•
•
MyPrintMileage
•
Print Diagnostic Page: Allows you to print the
self-test diagnostic page of the device. This
page contains information about the device
and the supplies. For more information, see
Understand the self-test diagnostic page.
Print a Print Quality Diagnostic Page: Allows
you to print the print-quality diagnostic report of
the device. This page contains information
about the device and ink cartridges.
Align Printheads: Guides you through
aligning the printheads. For more information,
see To align the printheads.
Clean Printheads: Guides you through
cleaning the printheads. For more information,
see To clean the printheads.
Calibrate color: Allows you to calibrate the
colors that are printed.
•
•
•
•
Network Settings
Shop Online: Provides access to a Web site
from which you can order printing supplies for
the device online.
Dial a cartridge: Shows telephone numbers
that you can call to order supplies for the
device. Telephone numbers are not available
for all countries/regions.
Cartridge Details: Shows order numbers of
the installed ink cartridges.
Printhead health
Hardware Info
Gives information on the network settings. Also,
includes a button that allows you to open the
Network Toolbox and change some network
settings.
Use device management tools
37
Chapter 4
Network Toolbox
The Network Toolbox allows you to view and change some network settings. You can
change the IP address, turn the wireless radio on or off (some models only), perform
tests, and print reports.
To open the Network Toolbox
1. Open the HP Toolbox.
2. Click the Network Settings tab.
3. Click the Change Settings... button.
4. Do one of the following:
a. To change wired network settings, click Wired Settings.
b. To change wireless settings, click Wireless Settings (some models only).
c. To print reports or run a diagnostic test, click Utilities.
Use the HP Solution Center (Windows)
Use the HP Solution Center to change print settings, order supplies, and access the
onscreen Help.
The features available in the HP Solution Center vary depending on the devices you
have installed. The HP Solution Center is customized to show icons that are
associated with the selected device. If the selected device is not equipped with a
particular feature, then the icon for that feature does not appear in the HP Solution
Center.
To open the HP Solution Center
▲ Double-click the HP Digital Imaging Monitor in the taskbar.
HP Printer Utility (Mac OS X)
The HP Printer Utility contains tools to configure print settings, calibrate the device,
clean the printheads, print the configuration page, order supplies online, and find Web
site support information.
•
•
•
Open the HP Printer Utility
HP Printer Utility panels
Use the HP Device Manager
Open the HP Printer Utility
To open the HP Printer Utility from the HP Device Manager
1. Click on the HP Device Manager listed in the Dock.
2. Select Maintain printer from the Information and Settings menu.
3. Select the HP device, and click Launch Utility.
38
Configure and manage
HP Printer Utility panels
This section covers the following topics:
•
•
Information and Support panel
Printer Settings panel
Information and Support panel
• Supplies Status: Shows the information about currently installed printheads and
ink cartridges.
• Supply Info: Shows the ink cartridge replacement options.
• Device Information: Displays information about the model and serial number.
Also allows you to print the self-test diagnostic page of the device. This page
contains information about the device and the supplies. For more information, see
Understand the self-test diagnostic page.
• Print Quality Diagnostics: Allows you to diagnose issues affecting the print
quality of the device. For more information, see To print the print quality diagnostic
page.
• Clean: Guides you through cleaning the printheads. For more information, see To
clean the printheads.
• Align: Guides you through aligning the printheads. For more information, see To
align the printheads.
• Calibrate Linefeed: Allows you to perform linefeed calibration. For more
information, see To calibrate the linefeed.
• Control Panel Language: Allows you to set the language used to print reports
such as the configuration page.
• HP Support: Gain access to the HP Web site, where you can find support for the
device, register the device, and find information about returning and recycling used
printing supplies.
Printer Settings panel
• Trays Configuration: Set the default media type and size for a tray, and set the
tray priority. For more information, see Configure trays.
• Additional Settings: Launch the embedded Web server to change network
settings. Configure IP settings for network connectivity.
Use device management tools
39
Chapter 4
Use the HP Device Manager
To open the HP Photosmart Studio software on a Macintosh computer
1. Click the HP Photosmart Studio icon in the Dock.
The HP Photosmart Studio window appears.
2. In the HP Photosmart Studio task bar, click Devices.
The HP Device Manager window appears.
3. Select the device from the Device drop-down menu.
NOTE: On a Macintosh computer, the features available in the
HP Photosmart Studio software vary depending on the selected device.
Ink level warnings and indicators provide estimates for planning purposes only.
When you receive a low-ink warning message, consider having a replacement
cartridge available to avoid possible printing delays. You do not need to
replace cartridges until prompted to do so.
TIP: When the HP Photosmart Studio software is opened, you can gain
access to the Dock menu shortcuts by selecting and holding the mouse button
over the HP Photosmart Studio icon in the Dock.
Understand the self-test diagnostic page
Use the self-test diagnostic page to view current device information, ink cartridge
status, and printhead health status; to help troubleshoot problems; and to verify
installation of optional accessories, such as Tray 2.
If you need to call HP, it is often useful to print the self-test diagnostic page before
calling.
40
Configure and manage
1. Printer Information: Shows device information (such as the product name, model
number, serial number, and firmware version number), the accessories that are
installed (such as the duplexer), and the number of pages printed from the trays
and accessories.
2. Ink Cartridge Status: Shows the estimated ink levels (represented in graphical
form as gauges) and the part numbers and expiration dates of the ink cartridges.
NOTE: Ink level warnings and indicators provide estimates for planning
purposes only. When you receive a low-ink warning message, consider having
a replacement cartridge available to avoid possible printing delays. You do not
need to replace cartridges until prompted to do so.
3. Printhead Status: Shows the status of the printhead health and the part numbers,
first-installation dates, and end-of-warranty dates of the printheads, as well as the
accumulated ink usage. The status options for the printhead are: good, fair, and
replace. If the status is fair, then the print quality must be monitored, but the
printhead does not need to replaced. If the status is replace, then the printhead
should be replaced, as the device will not function until it is.
To print the self-test diagnostic page
• Control panel: Press and hold the
Cancel button for 3 seconds.
NOTE: For models that are connected to a network, the network configuration
or wireless (some models only) configuration page will also be printed.
•
•
•
HP Toolbox (Windows): Click the Services tab, and then click Print Self-Test
Diagnostic Page.
HP Printer Utility (Mac OS X): Click Device Information from the Information
and Support panel, and then click Print Configuration Page.
Embedded Web Server: Click Settings, click Device Services, select Self-Test
Report from the drop-down menu in the Reports section, and then click Print.
Understand the network configuration or wireless (some
models only) status report
The network configuration or wireless (some models only) status report shows the
network or wireless settings for the device.
NOTE: The network configuration or wireless status report is printed when you
print a self-test report. For more information, see Understand the self-test
diagnostic page.
Understand the network configuration or wireless (some models only) status report
41
Chapter 4
1. General Information: Shows information about the current status and connection
type of the network, and other information, such as the URL of the embedded Web
server and the hardware address of the device.
Network Status: This setting can be Ready or Offline. When the setting is Offline,
it implies either that the IP is being assigned or negotiated by the DHCP server, or
that the AutoIP or the network is not available.
2. 802.3 Wired (some models): Shows information about your wired network
connection, such as the hostname, IP address, subnet mask, default gateway, and
server.
Link Configuration: The possible values are 10T/100T HalfDplx/FullDplx, 10T
HalfDplx, 100T FullDplx, and 100T HalfDplx.
3. 802.11 Wireless (some models): Shows information about your wireless network
connection, such as the hostname, IP address, subnet mask, default gateway, and
server.
4. Miscellaneous: Shows information, such as the administrator details.
• mDNS: Shows information about the active Multicast Domain Name System
(mDNS) connection. mDNS services are typically used on small networks for
IP address and name resolution (through UDP port 5353) where a
conventional DNS server is not used.
• SLP: Shows information about the current Service Location Protocol (SLP)
connection. SLP is used by network management applications for device
management. The device supports SNMPv1 protocol on IP networks.
42
Configure and manage
Configure the device (Windows)
You can connect the device directly to a computer, or you can share the device among
other users on a network.
NOTE: Microsoft Internet Explorer 6.0 must be installed on the computer system
to run the installation program.
Also, you must have administrator privileges to install a printer driver on Windows®
2000, Windows® XP, or Windows Vista.
When setting up the device, HP recommends that you connect it after you install the
software, because the installation program is designed to provide you with the easiest
setup experience. However, if you have connected the cable first, see To connect the
device before installing the software.
Direct connection
You can connect the device directly to your computer using a USB cable.
NOTE: If you install the device software and connect the device to a computer
running Windows, you can connect additional devices to the same computer with
USB cables without reinstalling the device software.
When setting up the device, HP recommends that you connect the device when
prompted by the installation software because the installation program is designed to
provide you with the easiest setup experience. However, if you have connected the
cable first, see To connect the device before installing the software.
To install the software before connecting the device (recommended)
1. Close any applications that are running.
2. Insert the Starter CD into the CD drive. The CD menu runs automatically. If the CD
menu does not start automatically, double-click the setup icon on the Starter CD.
3. On the CD menu, click Install USB-connected Device, and follow the onscreen
instructions.
NOTE: You can also share the device with other computers using a simple form
of networking known as locally shared networking. For more information, see To
share the device on a locally shared network.
To connect the device before installing the software
If you connected the device to the computer before installing the device software, the
Found New Hardware wizard displays on the computer screen.
NOTE: If you turned on the device, do not turn it off or unplug the cable from the
device while the installation program is running. If you do so, the installation
program will not finish.
Configure the device (Windows)
43
Chapter 4
1. In the Found New Hardware dialog box that displays methods for locating the
printer driver, select the Advanced option, and then click Next.
NOTE: Do not allow the Found New Hardware wizard to perform an
automatic search for the printer driver.
2. Select the check box for specifying the driver location, and ensure that the other
check boxes are clear.
3. Insert the Starter CD into the CD drive. If the CD menu appears, close it.
4. Browse to locate the root directory on the Starter CD (for example, D), and then
click OK.
5. Click Next, and follow the onscreen instructions.
6. Click Finish to close the Found New Hardware wizard. The wizard automatically
starts the installation program (this might take a short while).
7. Complete the installation process.
NOTE: You can also share the device with other computers using a simple form
of networking known as locally-shared networking. For more information, see To
share the device on a locally shared network.
To share the device on a locally shared network
In a locally shared network, the device is connected directly to the USB connector of a
selected computer (known as the server) and is shared by other computers (clients).
NOTE: When sharing a directly connected device, use the computer with the
newest operating system as the server.
Use this configuration only in small groups or when usage is low. The connected
computer is slowed down when many users print to the device.
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
2. Right-click the device icon, click Properties, and then click the Sharing tab.
3. Click the option to share the device, and give it a share name.
Network connection
If the device has network capability, it can be shared in a network environment by
connecting it directly to the network. This type of connection offers the ability to
manage the device using the embedded Web server from any computer on the
network.
NOTE: Microsoft Internet Explorer 6.0 must be installed on the computer system
to run the installation program.
44
Configure and manage
Choose the installation option for the type of network you have:
•
•
Client/server network: If your network has a computer acting as a dedicated print
server, install the device software on the server, and then install the device
software on the client computers. For more information see Install the device on a
network and Install the device software on client computers. This method does not
allow you to share the full functionality of the device. Client computers can only
print from the device.
Peer-to-peer network: If you have a peer-to-peer network (a network without a
dedicated print server), install the software on the computers that will be using the
device. For more information, see Install the device on a network.
In addition, you can connect to a network printer on both types of networks using the
Add Printer wizard in Windows. For more information, see Install the printer driver
using Add Printer.
Install the device on a network
Use the following steps to install the device software in the following networking
scenarios:
You have a peer-to-peer network (a network without a dedicated print server)
1. Remove the protective cover from the device's network port, and connect the
device to the network.
2. Close any third-party firewall and any applications that are running on the
computer system that are acting as the print server.
3. Insert the Starter CD into the CD drive. The CD menu starts automatically. If the
CD menu does not start automatically, browse to the CD drive of the computer,
and double-click Setup.exe.
4. On the CD menu, click Install Network/Wireless Device, and then follow the
onscreen instructions.
5. On the Connection Type screen, select Network/Wireless Device, and then click
Next.
6. Follow the onscreen instructions to complete the installation.
NOTE: To share the device with Windows client computers, see Install the device
software on client computers and To share the device on a locally shared network.
Install the device software on client computers
After printer drivers are installed on the computer that is acting as the print server, the
printing functionality can be shared. Individual Windows users who want to use the
network device must install the software on their computers (clients).
A client computer can connect to the device in the following ways:
•
•
•
In the Printers folder, double-click the Add Printer icon and follow the instructions
for a network installation. For more information, see Install the printer driver using
Add Printer.
On the network, browse to the device and drag it to your Printers folder.
Add the device and install the software from the INF file on your network. On the
Starter CD, the INF files are stored in the root directory of the CD.
Configure the device (Windows)
45
Chapter 4
Install the printer driver using Add Printer
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
2. Double-click Add Printer, and then click Next.
3. Select Network Printer or Network Printer Server.
4. Click Next.
5. Do one of the following:
Type in the network path or queue name of the shared device, and then click Next.
Click Have Disk when prompted to select the device model.
Click Next and locate the device in the list of shared printers.
6. Click Next, and follow the onscreen instructions to complete the installation.
Install the device in a pure IPV6 network environment
If you are connecting the device to a Windows XP or Windows Vista computer on a
pure IPV6 network, follow these instructions to install the printer driver.
NOTE: If you attempt to install the device software from the Starter CD, you will
not be able to find the device and complete the software setup.
NOTE: In pure IPv6 network environment, only the printer driver is available.
Other device software features such as HP Toolbox and Solution Center will not be
available.
To install the device driver on Windows XP
1. Connect the HP device to your network.
2. Install the HP Standard TCP/IP port monitor from the util\ipv6 folder on the Starter
CD.
NOTE: Click Next, if you see a dialog box stating that the device cannot be
identified.
3. Print a network configuration page from the device to obtain the IP address. For
more information, see Understand the network configuration or wireless (some
models only) status report.
4. In the Windows Add Print Wizard, create a local printer, and select HP Standard
TCP/IP Port.
5. When prompted, type the Stateless IPv6 address of the HP device printed on the
Network configuration page. For example, 2001:DB8:1::4A50:33GFF:FE32:3333.
NOTE: The device status is not available in pure IPv6 network environment
running Windows XP.
To install the printer driver on Windows Vista
1. Click Start, and then Network.
2. Right-click on the device you are installing, and then click Install.
3. When prompted for the printer driver, select the root level of the Starter CD.
46
Configure and manage
Configure the device (Mac OS X)
You can use the device with a single Macintosh computer using a USB cable, or you
can share it among other users on a network.
This section contains the following topics:
•
•
To install the software for network or direct connection
To share the device on a locally shared network
To install the software for network or direct connection
NOTE: If you are installing the device on a wired network, connect the Ethernet
cable before installing the software.
1.
2.
3.
4.
Insert the Starter CD into the CD drive. Double-click the Install HP Software icon.
Click Install Software, and follow the onscreen instructions.
When prompted, connect the device to your computer.
If necessary, share the device with other Macintosh computer users.
• Direct connection: Share the device with the other Macintosh computer
users. For more information, see To share the device on a locally shared
network.
• Network connection: Individual Macintosh computer users who want to use
the device on the network must install the device software on their computers.
To share the device on a locally shared network
When you connect the device directly, you can share it with other computers using a
simple form of networking known as locally shared networking. Use this configuration
only in small groups or when usage is low. The connected computer is slowed down
when many users print to the device.
Basic requirements for sharing in Mac OS X environment include the following items:
•
•
•
The Macintosh computers must be communicating on the network using TCP/IP,
and they must have IP addresses. (AppleTalk is not supported.)
The device that is being shared must be connected to a built-in USB port on the
host Macintosh computer.
Both the host Macintosh computer and the client Macintosh computers that are
using the shared device must have device sharing software installed, and the
driver or PPD for the device that is installed. (You can run the installation program
to install the device sharing software and associated Help files.)
Configure the device (Mac OS X)
47
Chapter 4
For more information about USB device sharing, see the support information on the
Apple Web site (www.apple.com) or the Apple Macintosh Help on the computer.
To share the device among computers
1. Open System Preferences, click Print & Fax, and then do one of the following,
based on the operating system you are using:
a. Mac OS X (v10.4): Click the Sharing tab, check the box next to Share these
printers with other computers, and then select the printer to be shared.
b. Mac OS X (v10.5): Select a printer, and then click Share this printer.
2. To print from the other Macintosh computers (the clients) on the network, do the
following:
a. Click File, and then select Page Setup in the document you want to print.
NOTE: Some Mac OS X (v10.5) applications do not have a Page Setup
menu, it is included in the Print menu.
b. In the drop-down menu next to Format for, select Shared Printers, and then
select your device.
c. Select the Paper Size, and then click OK.
d. In the document, click File, and then select Print.
e. From the drop-down menu next to Printer, select Shared Printers, and then
select your device.
f. Make additional settings, if necessary, and then click Print.
Set up the device for wireless communication (some
models only)
You may set up the device for wireless communication using one of the following ways:
Setup method
Infrastructure
wireless
communication
Ad hoc wireless
communication
USB cable
For more information, see To set up the device for
wireless communication using the installer (Mac
OS X) or To set up wireless communication using
the installer (Windows).
NOTE: If you encounter problems, see Solve wireless problems.
To use the device with any wireless connection, you must run the installation
program at least once from the Starter CD and create a wireless connection.
Make sure the device is not connected to the network using a network cable.
The sending device must have built-in 802.11 capabilities or an 802.11 wireless
card installed.
The device and the computers that use it must be on the same subnet.
48
Configure and manage
Before installing the device software, you may wish to find out the settings of your
network. Obtain the information from your system administrators, or complete the
following tasks:
•
•
•
Obtain your network's network name or Service Set Identifier (SSID) and
communication mode (infrastructure or ad hoc) from the configuration utility for the
network's wireless access point (WAP) or the computer's network card.
Find out the type of encryption your network uses, such as Wired Equivalent
Privacy (WEP).
Find out the security password or encryption key of the wireless device.
This section contains the following topics:
•
•
•
•
•
•
•
•
Understand 802.11 wireless network settings
To set up wireless communication using the installer (Windows)
To set up the device for wireless communication using the installer (Mac OS X)
Connect the device using an ad hoc wireless network connection
To turn off wireless communication
Configure your firewall to work with HP devices
Change the connection method
Guidelines for ensuring wireless network security
Understand 802.11 wireless network settings
Network name (SSID)
By default, the device looks for the wireless network name or SSID named "hpsetup."
Your network may have a different SSID.
Communication mode
There are two communication mode options:
•
•
Ad hoc: On an ad hoc network, the device is set to ad hoc communication mode
and communicates directly with other wireless devices without the use of a WAP.
All devices on the ad hoc network must:
◦ Be 802.11 compatible
◦ Have ad hoc as the communication mode
◦ Have the same network name (SSID)
◦ Be on the same subnet and same channel
◦ Have the same 802.11 security settings
Infrastructure (recommended): On an infrastructure network, the device is set to
infrastructure communication mode and communicates with other devices on the
network, whether the devices are wired or wireless, through a WAP. WAPs
commonly act as routers or gateways on small networks.
Security settings
NOTE: For the available settings for the device, see Understand the network
configuration or wireless (some models only) status report.
For more information on wireless security, visit www.wi-fi.org.
Set up the device for wireless communication (some models only)
49
Chapter 4
•
•
Network authentication: The device's factory default setting is Open' which does
not require security for authorization or encryption. The other possible values are
OpenThenShared, and Shared.
WPA increases the level of over-the-air data protection and access control on
existing and future Wi-Fi networks. It addresses all known weaknesses of Wired
Equivalent Privacy (WEP), the original native security mechanism in the 802.11
standard.
WPA2 is the second generation of WPA security; it provides enterprise and
consumer Wi-Fi users with a high level of assurance that only authorized users
can access their wireless networks.
Data encryption:
◦ WEP provides security by encrypting data sent over radio waves from one
wireless device to another wireless device. Devices on a WEP-enabled
network use WEP keys to encode data. If your network uses WEP, you must
know the WEP key(s) it uses.
◦ WPA uses the Temporal Key Integrity Protocol (TKIP).
◦ WPA2 provides a new encryption scheme, the Advanced Encryption Standard
(AES). AES is defined in counter cipher-block chaining mode (CCM) and
supports the Independent Basic Service Set (IBSS) to enable security between
client workstations operating in ad hoc mode.
To set up wireless communication using the installer (Windows)
NOTE: For this method, you will need to have a wireless network set up and
running. You will also need a USB cable. Do not attach the USB cable until
prompted by the installer.
1. Save any open documents. Close any applications that are running on your
computer.
2. Insert the Starter CD into the CD drive. The CD menu runs automatically. If the CD
menu does not start automatically, double-click the setup icon on the Starter CD.
3. On the CD menu, click Install Network/Wireless Device, and then follow the
onscreen instructions.
NOTE: If the firewall software on your computer displays any messages
during the installation, select the always permit/allow option in the messages.
Selecting this option allows the software to install successfully on your
computer.
4. When prompted, temporarily connect the USB wireless setup cable.
5. Follow the onscreen instructions to complete the installation.
6. Disconnect the USB wireless setup cable when prompted.
To set up the device for wireless communication using the installer (Mac OS X)
1. Connect a USB wireless setup cable to the port on the back of the HP device and
then to any USB port on the computer.
2. Place the Starter CD into the computer.
50
Configure and manage
3. Double-click the HP Installer icon on the Starter CD, and then follow the onscreen
instructions.
4. Disconnect the USB wireless setup cable when prompted.
Connect the device using an ad hoc wireless network connection
Method 1
1. Turn on wireless in your computer and in the device.
2. On your computer, connect to the network named (SSID) “hpsetup.“ (This network
name is the default, ad hoc network created by the HP device.)
NOTE: If your HP device was previously configured for a different network,
you can restore the network defaults to enable the device to use “hpsetup.“ To
restore the network defaults, complete the following steps:
Reset the administrator password and network settings: Press and hold
the
Network button (on some models press the Wireless button), press the
Resume button three times, and release the Network or Wireless button.
For more information, see Troubleshooting tips and resources.
Method 2 (Windows only)
1. Make sure your computer has an ad hoc network profile. For more information, see
the documentation available with your operating system.
2. Install the software on your device, and select the network that corresponds with
the ad hoc network profile for your computer.
To turn off wireless communication
Press and hold the wireless button on the front of the device for three seconds.
Configure your firewall to work with HP devices
A personal firewall, which is security software running on your computer, can block
network communication between your HP device and your computer.
If you are having problems such as:
•
•
•
Printer not found when installing HP software
Unable to print, print job stuck in queue, or printer goes offline
Unable to see printer status on your computer
The firewall might be preventing your HP device from notifying computers on your
network where it can be found. If the HP software cannot find the HP device during
Set up the device for wireless communication (some models only)
51
Chapter 4
installation (and you know the HP device is on the network), or you have already
successfully installed HP software and experience problems, try the following:
1. If you are using a computer running Windows, in the firewall configuration utility,
look for an option to trust computers on the local subnet (sometimes called the
“scope“ or “zone“). By trusting all computers on the local subnet, computers and
devices in your home can communicate with each other while still being protected
from the internet. This is the easiest approach to use.
2. If you do not have the option to trust computers on the local subnet, add incoming
UDP port 427 to your firewall’s list of allowed ports.
NOTE: Not all firewalls require you to differentiate between incoming and
outgoing ports, but some do.
Another common problem is that HP software is not trusted by your firewall to access
the network. This can happen if you answered “block“ to any firewall dialog boxes that
appeared when you installed the HP software.
If this occurs, and if you are using a computer running Windows, check that the
following programs are in your firewall’s list of trusted applications; add any that are
missing.
•
•
•
•
•
•
hpqkygrp.exe, located in C:\program files\HP\digital imaging\bin
hpqscnvw.exe, located in C:\program files\HP\digital imaging\bin
hpqste08.exe, located in C:\program files\HP\digital imaging\bin
hpqtra08.exe, located in C:\program files\HP\digital imaging\bin
hpqdirec.exe, located in C:\program files\HP\digital imaging\bin
hpqthb08.exe, located in C:\program files\HP\digital imaging\bin
NOTE: Refer to your firewall documentation on how to configure the firewall port
settings and how to add HP files to the “trusted“ list.
NOTE: Some firewalls continue to cause interference even after you disable
them. If you continue to have problems after configuring the firewall as described
above and if you are using a computer running Windows, you might need to
uninstall the firewall software in order to use the HP device over the network.
Change the connection method
If you have installed the software and connected your HP device using a USB or
Ethernet cable, you can change to a wireless connection any time you want.
Change from a USB connection to a wireless connection (Windows)
1. Select Start, Programs, HP, select your device, and then select Reconfigure
Network Settings.
2. Press Add a Device.
3. Follow the onscreen instructions, and remove the USB cable when prompted.
52
Configure and manage
Change from a USB connection to a wireless connection (Mac OS X)
1. Click the HP Device Manager icon on the Dock or in the Hewlett Packard folder in
the Applications folder.
2. From the Information and Settings list, select Network Printer Setup Utility.
3. Follow the onscreen instructions to configure the network settings.
Change from an Ethernet connection to a wireless connection
NOTE: For Ethernet-enabled HP devices only.
1. Open the embedded Web server (EWS). For more information, see Embedded
Web server.
2. Click the Networking tab, and then click Wireless (802.11) in the left pane.
3. On the Wireless Setup tab, click Start Wizard.
4. Follow the onscreen instructions to change from an Ethernet connection to a
wireless connection.
5. After you finish changing the settings, disconnect the Ethernet cable.
Guidelines for ensuring wireless network security
This section contains the following topics:
•
•
To add hardware addresses to a wireless access point
Other guidelines
To add hardware addresses to a wireless access point
MAC filtering is a security feature in which a wireless access point, such as a wireless
router or Apple AirPort Base Station is configured with a list of MAC addresses (also
called "hardware addresses") of devices that are allowed to gain access to the network
through the access point.
If the access point does not have the hardware address of a device attempting to
access the network, the access point denies the device access to the network.
If the access point filters MAC addresses, then the device's MAC address must be
added to the access point's list of accepted MAC addresses.
1. Print the wireless status report. For information on the wireless status report, see
Understand the network configuration or wireless (some models only) status report.
2. Open the wireless access point's configuration utility, and add the HP device's
hardware address to the list of accepted MAC addresses.
Other guidelines
To keep the wireless network secure, follow these guidelines:
•
•
Use a password with at least 20 random characters. You can use up to 63
characters in a WPA password.
Avoid any common words or phrases, easy sequences of characters (such as all
1s), and personally-identifiable information for passwords. Always use random
strings composed of uppercase and lowercase letters, numbers, and if allowed,
special characters such as punctuation.
Set up the device for wireless communication (some models only)
53
Chapter 4
•
•
•
•
•
Change the password periodically.
Change the default password provided by the manufacturer for administrator
access to the access point or wireless router. Some routers let you change the
administrator name as well.
Turn off administrative access over wireless, if possible. If you do this, you need to
connect to the router with a wired Ethernet connection when you want to make
configuration changes.
Turn off remote administrative access over the Internet on your router, if possible.
You can use Remote Desktop to make an encrypted connection to a computer
running behind your router and make configuration changes from the local
computer you are accessing over the Internet.
To avoid accidentally connecting to another party's wireless network, turn off the
setting to automatically connect to non-preferred networks. This is disabled by
default in Windows XP.
Uninstall and reinstall the software
If your installation is incomplete, or if you connected the USB cable to the computer
before being prompted by the software installation screen, you might need to uninstall,
and then reinstall the software. Do not simply delete the device application files from
your computer. Make sure to remove them properly using the uninstall utility provided
when you installed the software that came with the device.
There are three methods to uninstall the software on a Windows computer, and two
methods to uninstall on a Macintosh computer.
To uninstall from a Windows computer, method 1
1. Disconnect the device from your computer. Do not connect it to your computer until
after you have reinstalled the software.
2. Press the Power button to turn off the device.
3. Follow the onscreen instructions.
4. If you are asked whether you would like to remove shared files, click No.
Other programs that use these files might not work properly if the files are deleted.
5. Restart your computer.
6. To reinstall the software, insert the device Starter CD into your computer's CDROM drive, follow the onscreen instructions, and also see To install the software
before connecting the device (recommended).
7. After the software is installed, connect the device to your computer.
8. Press the Power button to turn the device on.
After connecting and turning on the device, you might have to wait several minutes
for all of the Plug and Play events to complete.
9. Follow the onscreen instructions.
54
Configure and manage
When the software installation is complete, the HP Digital Imaging Monitor icon
appears in the Windows system tray.
To uninstall from a Windows computer, method 2
NOTE: Use this method if Uninstall is not available in the Windows Start menu.
1. On the Windows taskbar, click Start, select Settings, select Control Panel, and
then click Add/Remove Programs.
- Or Click Start, click Control Panel, and then double-click Programs and Features.
2. Select the device you want to uninstall, and then click Change/Remove or
Uninstall/Change.
3. Disconnect the device from your computer.
4. Restart your computer.
NOTE: It is important that you disconnect the device before restarting your
computer. Do not connect the device to your computer until after you have
reinstalled the software.
5. Insert the device Starter CD into your computer's CD-ROM drive, and then start
the Setup program.
6. Follow the onscreen instructions and also see To install the software before
connecting the device (recommended).
To uninstall from a Windows computer, method 3
NOTE: Use this method if Uninstall is not available in the Windows Start menu.
1. Insert the device Starter CD into your computer's CD-ROM drive, and then start
the Setup program.
2. Disconnect the device from your computer.
3. Select Uninstall, and follow the onscreen directions.
4. Restart your computer.
NOTE: It is important that you disconnect the device before restarting your
computer. Do not connect the device to your computer until after you have
reinstalled the software.
5. Start the Setup program for the device again.
6. Select Install.
7. Follow the onscreen instructions and also see To install the software before
connecting the device (recommended).
To uninstall from a Macintosh computer, method 1
1. Launch HP Device Manager.
2. Click Information and Settings.
3. Select Uninstall HP software from the pull-down menu.
Follow the onscreen instructions.
Uninstall and reinstall the software
55
Chapter 4
4. After the software is uninstalled, restart your computer.
5. To reinstall the software, insert the device Starter CD into your computer's CDROM drive.
6. On the desktop, open the CD-ROM, and then double-click HP Printer Installer.
7. Follow the onscreen instructions and also see To install the software before
connecting the device (recommended).
To uninstall from a Macintosh computer, method 2
1. Open the Finder.
2. Double-click Applications.
3. Double-click Hewlett-Packard.
4. Select your device, and then double-click Uninstall.
56
Configure and manage
5
Maintain and troubleshoot
This section contains the following topics:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Supported ink cartridges
Replace the ink cartridges
Maintain the printheads
Store printing supplies
Troubleshooting tips and resources
Solve printing problems
Poor print quality and unexpected printouts
Solve paper-feed problems
Solve device management problems
Solve network problems
Solve wireless problems
Troubleshoot installation issues
Clear jams
Errors
Supported ink cartridges
Ordering cartridges online is not supported in all countries/regions. However, many
countries have information on ordering by telephone, locating a local store and printing
a shopping list. In addition, you can select the How to Buy option at the top of the
www.hp.com/buy/supplies page to obtain information about purchasing HP products in
your country.
You can find the ink cartridge number in the following places:
•
•
•
•
•
•
On the Information page of the embedded Web server (see Embedded Web
server).
Windows: From the HP Toolbox, if you have bidirectional communication, click
the Estimated Ink Levels tab, scroll to display the Cartridge Details button, and
then click Cartridge Details.
Mac OS X: From the HP Printer Utility, click Supply Info from the Information
and Support panel, and then click Retail Supplies Information.
On the label of the ink cartridge you are replacing.
Solution Center: From the Solution Center you can view supplies information from
the Shopping tab or the estimated ink level screen.
On the configuration page (see Understand the self-test diagnostic page).
NOTE: Ink from the cartridges is used in the printing process in a number of
different ways, including in the initialization process, which prepares the device and
cartridges for printing, and in printhead servicing, which keeps print nozzles clear
and ink flowing smoothly. In addition, some residual ink is left in the cartridge after
it is used. For more information see www.hp.com/go/inkusage.
Maintain and troubleshoot
57
Chapter 5
Replace the ink cartridges
You can check the estimated ink levels from the HP Toolbox (Windows), the HP
Printer Utility (Mac OS X), or the embedded Web server. For information about using
these tools, see Use device management tools. You can also print the configuration
page to view this information (see Understand the self-test diagnostic page).
NOTE: Ink level warnings and indicators provide estimates for planning purposes
only. When you receive a low-ink warning message, consider having a
replacement cartridge available to avoid possible printing delays. You do not need
to replace cartridges until prompted to do so.
After removing a cartridge from its package, install it right away. Do not remove a
cartridge from the device for long periods of time.
To find out which ink cartridges work with your device, see Supplies.
For information on recycling used ink supplies, see HP inkjet supplies recycling
program.
To replace the ink cartridges
1. Gently pull open the ink cartridge cover.
2. Remove the ink cartridge that requires replacement by grasping it between your
thumb and forefinger and pulling it firmly toward you.
3. Remove the new ink cartridge from its package.
4. Align the cartridge with its color-coded slot, and insert the cartridge into the slot.
Press down firmly on the cartridge to ensure proper contact.
5. Close the ink cartridge cover.
58
Maintain and troubleshoot
Maintain the printheads
If printed characters are incomplete, or printouts are streaked, the ink nozzles might be
clogged, and you might need to clean the printheads.
When the quality of printouts deteriorates, follow the steps below:
1. Check the health of the printheads. For more information, see To check printhead
health.
2. Print the print quality diagnostic page on a clean sheet of white paper. Evaluate
any problem areas, and perform the recommended actions. For more information,
see To print the print quality diagnostic page.
3. Clean the printheads. For more information, see To clean the printheads.
4. Replace the printheads if the problems persist after cleaning. For more
information, see To replace the printheads.
This section covers the following printhead maintenance tasks:
•
•
•
•
•
•
•
To check printhead health
To print the print quality diagnostic page
To align the printheads
To clean the printheads
To clean the printhead contacts manually
To calibrate the linefeed
To replace the printheads
To check printhead health
Use one of the following means to check the printhead health. If the status of any
printhead is replace, then perform one or more of the maintenance functions, or clean
or replace the printhead.
•
•
•
Configuration Page: Print the configuration page on a clean sheet of white paper,
and check the printhead health section. For more information, see Understand the
self-test diagnostic page.
Embedded Web server: Open the embedded Web server. For more information,
see To open the embedded Web server. Click the Information tab, and then click
Ink Supplies in the left pane.
HP Toolbox (Windows): Open the HP Toolbox. For more information, see Open
the HP Toolbox. Click the Information tab, and then click Printhead Health.
To print the print quality diagnostic page
Use the print quality diagnostic page to diagnose issues affecting the print quality. This
will help you decide whether to run any maintenance services to improve the print
Maintain the printheads
59
Chapter 5
quality of your printouts. You can also view the ink level information and the printhead
health status on the page.
•
•
•
•
60
Control panel: Press and hold the
Power button, press the
Cancel button
seven times, press the Resume button two times, and release the
Power
button.
Embedded Web server: Click the Settings tab, click Device Services in the left
pane, select Print PQ (print quality) diagnostic page from the drop-down list in
the Print Quality section, and then click Run Diagnostic.
HP Toolbox (Windows): Click the Services tab, and then click Print PQ (print
quality) diagnostic page and follow the onscreen instructions.
HP Printer Utility (Mac OS X): Click Print Quality Diagnostics from the
Information and Support panel.
Maintain and troubleshoot
1
Printer Information: Shows device information (such as the product model number, serial
number, and firmware version number), the number of pages printed from the trays and
duplexer, the ink level information, and the printhead health status.
NOTE: Ink level warnings and indicators provide estimates for planning purposes only.
When you receive a low-ink warning message, consider having a replacement cartridge
available to avoid possible printing delays. You do not need to replace cartridges until
prompted to do so.
2
Test Pattern 1: If the lines are not straight and connected, align the printheads. For more
information, see To align the printheads.
3
Test Pattern 2: If there are thin white lines across any of the colored blocks, clean the
printheads. For more information, see To clean the printheads.
4
Test Pattern 3: If there are dark lines or white gaps where the arrows are pointing,
calibrate the linefeed. For more information, see To calibrate the linefeed.
To align the printheads
Whenever you replace a printhead, the device automatically aligns the printheads to
ensure the best print quality. However, if the appearance of your printed pages
indicates that the printheads are misaligned, you can start the alignment process
manually.
•
•
•
•
Control panel: Press and hold the
Power button, press the
Resume button
three times, and release the
Power button.
Embedded Web server: Click the Settings tab, click Device Services in the left
pane, select Align Printer from the drop-down list in the Print Quality section,
and then click Run Diagnostic.
HP Toolbox (Windows): Click the Services tab, and then click Align Printheads,
and follow the onscreen instructions.
HP Printer Utility (Mac OS X): Click Align from the Information and Support
panel.
To clean the printheads
If printed characters are incomplete, or dots or lines are missing from printouts, ink
nozzles might be clogged, and you might need to clean the printheads.
NOTE: Cleaning uses ink, so clean the printheads only when necessary.
The cleaning process can take several minutes. Some noise might be generated in
the process.
Make sure paper is loaded before you begin to clean the printheads.
•
•
Control panel: Press and hold the
Power button, press the
Cancel button
Resume button one time, and release the
Power button.
two times, press the
Embedded Web server: Click the Device Settings tab, click Device Services in
the left pane, select Clean Printheads from the drop-down list in the Print Quality
section, and then click Run Diagnostic.
Maintain the printheads
61
Chapter 5
•
•
HP Toolbox (Windows): Click the Services tab, click Clean Printheads and
follow the onscreen instructions.
HP Printer Utility (Mac OS X): Click Clean from the Information and Support
panel.
To clean the printhead contacts manually
After the printheads are installed, one or more of the printhead lights might be blinking.
If the printhead lights are blinking, you might need to clean the electrical contacts on
the printheads and in the device.
CAUTION: Electrical contacts contain sensitive electronic components that can
be damaged easily.
1. Make sure paper is loaded in Tray 1.
2. Open the top cover.
3.
If the carriage does not move to the left automatically, press and hold the
Resume button until the carriage moves to the left. Wait for the carriage to stop
moving, and then unplug the power cord from the printer.
4. Lift the printhead latch.
5. Lift the handle of the printhead you want to replace, and then pull the printhead out
of its slot.
62
Maintain and troubleshoot
6. Obtain a clean, dry, soft, and lint-free cleaning material. Suitable materials include
paper coffee filters and eyeglass lens cleaning paper.
CAUTION: Do not use water.
7. Wipe the electrical contacts on the printhead, but do not touch the nozzles.
CAUTION: The electrical contacts are small copper-color squares, grouped
on one face of the printhead.
The nozzles are on a different face of the printhead. Ink will be visible on the
nozzles.
Touching the nozzles can cause permanent nozzle damage. Also, ink can
permanently mark clothing.
8. After cleaning, place the printhead on a sheet of paper or paper towel. Make sure
the nozzles are facing up and are not in contact with the paper.
9. Clean the electrical contacts in the printhead slot inside the device with a clean,
dry, soft, and lint-free cloth.
10. Insert the printhead into its color-coded slot (the label on the printhead must match
the label on the printhead latch). Press down firmly on the printhead to ensure
proper contact.
11. Pull the printhead latch all the way forward, and then press down to ensure that
the latch is properly engaged. You might have to apply some pressure to engage
the latch.
Maintain the printheads
63
Chapter 5
12. Close the cover.
13. If the printhead light is still blinking, repeat the cleaning procedure described above
for the printhead which corresponds to the blinking printhead light.
14. If the printhead light continues to blink, replace the printhead which corresponds to
the blinking printhead light.
15. Wait while the device initializes the printheads and prints the alignment pages. If
the device does not print the pages, start the alignment process manually. For
more information, see To align the printheads.
To calibrate the linefeed
If your printout shows bandings (dark or light lines across colored block) or staggered
lines, calibrate the printer's linefeed.
•
•
•
•
Control panel: Press and hold the
Power button, press the
Cancel button
14 times, press the
Resume button six times, and release the
Power button.
Embedded Web server: Click the Settings tab, click Device Services in the left
pane, select Calibrate Linefeed from the drop-down list in the Print Quality
section, and then click Run Diagnostic.
HP Toolbox (Windows): Click the Services tab, click Calibrate Linefeed and
follow the onscreen instructions.
HP Printer Utility (Mac OS X): Click Calibrate Linefeed from the Information
and Support panel.
To replace the printheads
NOTE: To find out which printheads work with your printer, see Supplies.
1. Open the cover.
2. Make sure paper is loaded in Tray 1.
3.
If the carriage does not move to the left automatically, press and hold the
Resume button until the carriage moves to the left. Wait for the carriage to stop
moving.
4. Lift the printhead latch.
64
Maintain and troubleshoot
5. Lift the handle of a printhead, and use it to pull the printhead out of its slot.
6. Before installing a printhead, shake the printhead up and down at least six times
while the printhead is still in its packaging.
7. Remove the new printhead from its package, and then remove its orange
protective caps.
CAUTION: Do not shake printheads after the caps are removed.
Maintain the printheads
65
Chapter 5
8. Insert the printhead into its color-coded slot (the label on the printhead must match
the label on the printhead latch). Press down firmly on the printhead to ensure
proper contact.
9. Pull the printhead latch all the way forward, and then press down to ensure that
the latch is properly engaged. You might have to apply some pressure to engage
the latch.
10. Close the cover.
11. Wait while the device initializes the printheads and prints the alignment pages. If
the device does not print the pages, start the alignment process manually. For
more information, see To align the printheads.
Store printing supplies
This section covers the following topics:
•
•
Store ink cartridges
Store printheads
Store ink cartridges
Ink cartridges can be left in the device for extended periods of time. If you remove the
ink cartridges, place them in an airtight container, such as a resealable plastic bag.
Store printheads
Printheads can be left in the device for extended periods of time. However, to assure
optimal printhead health, be sure to turn off the device properly. For more information,
see Turn off the device.
Troubleshooting tips and resources
Use the following tips and resources to resolve printing problems:
•
•
•
•
•
•
•
•
•
•
66
For a paper jam, see Clear a jam in the device.
For paper-feed problems, such as the paper skew and paper pick, see Solve
paper-feed problems.
Power light is on and not blinking. When the device is turned on for the first time, it
takes approximately 20 minutes to initialize it after the printheads are installed.
No error messages appear on the computer screen.
Power cord and other cables are working, and are firmly connected to the device.
Make sure the device is connected firmly to a functioning alternating current (AC)
power outlet, and is turned on. For voltage requirements, see Electrical
specifications.
Media is loaded correctly in the tray and is not jammed in the device.
Printheads and ink cartridges are properly installed in their correct color-coded
slots. Press down firmly on each one to ensure proper contact.
Printhead latch and all covers are closed.
The duplexer is locked into place.
All packing tapes and materials are removed.
Maintain and troubleshoot
•
•
•
•
The device can print a configuration page. For more information, see Understand
the self-test diagnostic page.
The device is set as the current or default printer. For Windows, set it as the
default in the Printers folder. For Mac OS X, set it as the default in the Printer
Setup Utility (Mac OS X (v10.4), for Mac OS X (v10.5) open System Preferences,
select Print & Fax, and then select the device from the Default Printer drop-down
list.) See your computer's documentation for more information.
Pause Printing is not selected if you are using a computer running Windows.
You are not running too many programs when you are performing a task. Close
programs that you are not using or restart the computer before attempting the task
again.
To set a static IP address
1. Open the embedded Web server, click the Networking tab, click Wired (802.3) or
Wireless (802.11) in the left pane, and then click the IPv4 Configuration or IPv6
Configuration sub-tab.
2. Select Manual IP, and then type the static IP address in the Manual IP Address
box.
3. Enter the Manual Subnet Mask and the Manual Default Gateway, if necessary,
and then click Apply.
CAUTION: Changing the IP address can disrupt the current connection to the
embedded Web server.
Solve printing problems
•
•
•
•
•
•
•
The device shuts down unexpectedly
The device is not responding (nothing prints)
Printer lights are blinking
Device takes a long time to print
Placement of the text or graphics is wrong
The device prints half a page, then ejects the paper
Device is printing from the wrong input tray
The device shuts down unexpectedly
Check the power and power connections
Make sure the device is connected firmly to a functioning alternating current (AC)
power outlet. For voltage requirements, see Electrical specifications.
The device is not responding (nothing prints)
If the device supports wireless communication, see also Solve wireless problems.
Check the device setup
For more information, see Troubleshooting tips and resources.
Solve printing problems
67
Chapter 5
Check the printhead initialization
When printheads are installed or replaced, the device automatically prints a few
alignment pages to align the printheads. This process takes about 20 minutes. Until
this process is complete, only the automatic alignment pages can be printed.
Check the device software installation
If the device is turned off when printing, an alert message should appear on your
computer screen; otherwise, the device software might not be installed correctly. To
resolve this, uninstall the software completely, and then reinstall the device software.
For more information, see Uninstall and reinstall the software.
Check the cable connections
• Make sure both ends of the network/USB cable are secure.
• If the device is connected to a network, check the following:
◦ Check the Network button on the control panel. If an active network cable is
connected to the device, the light will be green.
◦ Make sure you are not using a phone cord to connect the device.
◦ The network hub, switch, or router is turned on and working properly.
Check the device setup for a network environment
Ensure the correct device driver and printer driver port are being used. For more
information about network connections, see Configure the device (Windows),
Configure the device (Mac OS X), or the documentation provided by your network
vendors.
Check any personal firewall software installed on the computer
The personal software firewall is a security program that protects a computer from
intrusion. However, the firewall might block communication between the computer and
the device. If there is a problem communicating with the device, try temporarily
disabling the firewall. If the problem persists, the firewall is not the source of the
communication problem. Re-enable the firewall. For more information, see Configure
your firewall to work with HP devices.
Printer lights are blinking
Check the error messages. For more information, see Control-panel lights reference.
Use the following steps to try and solve the problem:
•
•
•
Remove and reinstall the printhead
Clean the printhead contacts manually
Replace the printhead
Device takes a long time to print
Check the system configuration
Make sure the computer meets the minimum system requirements for the device. For
more information, see System requirements.
68
Maintain and troubleshoot
Check the device software settings
Print speed is slower when Best or Maximum dpi is selected as the print quality. To
increase the print speed, select different print settings in the device driver. For more
information, see Change print settings.
Check for radio interference
If the device is connected using wireless communication and is printing slowly, then
the radio signal might be weak.
Placement of the text or graphics is wrong
If these solutions do not work, the problem may be caused by the inability of the
application to interpret print settings properly. See the release notes for known
software conflicts, refer to the application's documentation, or contact the software
manufacturer for specific help.
Check how the media is loaded
Make sure the media width and length guides fit snugly against the edges of the stack
of media, and make sure the trays are not overloaded. For more information, see Load
media.
Check the media size
• Content on a page might be cut off if the document size is larger than the media
that you are using. For more information, see Select print media.
• Make sure the media size selected in the printer driver match the size of media
loaded in the tray.
Check the page-orientation setting
Make sure the media size and page orientation selected in the application match the
settings in the printer driver. For more information, see Change print settings.
Check the device location and length of USB cable
It is recommended that you use a USB cable that is less than 3 meters (9.8 feet) long.
You can also try to use a different USB cable to check if the cable has failed.
The device prints half a page, then ejects the paper
Check the ink cartridges
The ink cartridges may have run out of ink, and the print job was cancelled. Replace
the ink cartridges, and then resend the print job to the device. For more information,
see Replace the ink cartridges.
More than one page is being picked
For more information on paper-feed problems, see Solve paper-feed problems.
Solve printing problems
69
Chapter 5
There is a blank page in the file
Check the file to make sure there is no blank page.
Clean the printhead
Complete the printhead cleaning procedure. For more information, see To clean the
printheads.
Check the top cover
If the top cover is left open, the printer will eject the page and then move the
printheads to the home position after a time out period.
Device is printing from the wrong input tray
Check the tray configuration settings
The tray configuration is not set to print from the tray with plain paper. For more
information, see Configure trays.
Poor print quality and unexpected printouts
•
•
•
•
•
•
•
•
•
•
•
•
General print quality troubleshooting
Meaningless characters print
Ink is smearing
Ink is not filling the text or graphics completely
Output is faded or dull colored
Colors are printing as black and white
Wrong colors are printing
Printout shows bleeding colors
The printout has a horizontal band of distortion near the bottom of a borderless print
Colors do not line up properly
Text or graphics are streaked
Something on the page is missing or incorrect
General print quality troubleshooting
Check the printheads and ink cartridges
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Check the paper quality
Make sure the media meets HP specifications, and try to print again. For more
information, see Select print media.
70
Maintain and troubleshoot
Check the type of media loaded in the device
• Make sure the tray supports the type of media you have loaded. For more
information, see Understand specifications for supported media.
• Make sure you have selected the tray in the printer driver that contains the media
that you want to use.
Check the device location and length of USB cable
It is recommended that you use a USB cable that is less than 3 meters (9.8 feet) long.
You can also try a new USB cable to check whether the cable has failed.
Meaningless characters print
If an interruption occurs to a job that is printing, the device might not recognize the rest
of the job.
Cancel the print job and wait for the device to return to the ready state. If the device
does not return to the ready state, cancel all jobs in the printer driver, turn the device
off, let it set for a few seconds, turn the device on, and then print the document.
Check the cable connections
If the device and computer are connected with a USB cable, the problem may be due
to a poor cable connection.
Make sure the cable connections at both ends are secure. If the problem persists, turn
off the device, disconnect the cable from the device, turn on the device without
connecting the cable, and delete any remaining jobs from the print spooler. When the
Power light is on and not flashing, reconnect the cable.
Check the document file
The document file may be damaged. If you can print other documents from the same
application, try printing a backup copy of your document, if available.
Ink is smearing
Check the print settings
Color documents that have rich, blended colors can wrinkle or smear when printed
using the Best print quality. Try using another print mode, such as Normal, to reduce
ink, or use HP Premium Paper designed for printing vivid color documents. For more
information, see Change print settings.
Check the media type
• Some types of media do not accept ink well. For these types of media, ink will dry
more slowly and smearing may occur. For more information, see Select print media.
• Make sure that the media type selected in the printer driver matches the media
type loaded in the device.
Poor print quality and unexpected printouts
71
Chapter 5
Ink is not filling the text or graphics completely
Check the media type
Some media types are not suitable for use with the device. For more information, see
Select print media.
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Output is faded or dull colored
Check the print mode
The Draft or Fast mode in the printer driver allows you to print at a faster rate, which is
good for printing drafts. To get better results, select Normal or Best. For more
information, see Change print settings.
Check the paper type setting
When printing on transparencies or other special media, select the corresponding
media type in the printer driver. For more information, see Print on special and customsized media.
Colors are printing as black and white
Check the print settings
Make sure Print in Grayscale is not selected in the printer driver.
Wrong colors are printing
Check the print settings
Make sure Print in Grayscale is not selected in the printer driver.
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Printout shows bleeding colors
Check the ink cartridges
Make sure you are using genuine HP ink. For ordering information, see HP supplies
and accessories.
72
Maintain and troubleshoot
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
The printout has a horizontal band of distortion near the bottom of a borderless
print
Check the paper type
HP recommends that you use HP papers or any other paper type that is appropriate
for the product. Always make sure the paper you are printing on is flat. Uncurl paper
by bending it in the opposite direction of the curl. For best results when printing
images, use HP Advanced Photo Paper. Store photo media in its original packaging
inside a resealable plastic bag on a flat surface, in a cool place. When you are ready
to print, remove only the paper you plan to use immediately. When you have finished
printing, return any unused photo paper to the original package, and reseal the bag.
This will prevent the photo paper from curling. For more information, see Select print
media.
Use a higher print quality setting
Check the print quality setting and make sure it is not set too low. Print the image with
a high print-quality setting, such as Best or Maximum dpi.
Rotate the image
If the problem persists, use the software you installed with the product or another
software application to rotate your image 180 degrees so that the light blue, gray, or
brown hues in your image do not print at the bottom of the page. The defect is more
noticible in areas of uniform light colors, so rotating the image may help.
Clean the printhead
Manually clean the printhead. For more information, see To clean the printhead
contacts manually.
Colors do not line up properly
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Check the graphics placement
Use the zoom or print preview feature of your software to check for gaps in the
placement of graphics on the page.
Poor print quality and unexpected printouts
73
Chapter 5
Text or graphics are streaked
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Something on the page is missing or incorrect
Check the printheads
Print the print quality diagnostic page on a clean sheet of white paper. Evaluate any
problem areas, and perform the recommended actions. For more information, see To
print the print quality diagnostic page.
Check the color print settings
Make sure Print in Grayscale is not selected in the printer driver.
Check the device location and length of USB cable
It is recommended that you use a USB cable that is less than 3 meters (9.8 feet) long.
Solve paper-feed problems
For information on resolving jams, see Clear a jam in the device.
•
•
•
Optional Tray 2 cannot be inserted
Media stops halfway
Another paper-feed problem is occurring
Optional Tray 2 cannot be inserted
•
•
Reinsert the tray. Make sure it is aligned with the device opening.
Check for a paper jam. For more information, see Clear a jam in the device.
Media stops halfway
If the paper is not correct, the media will not feed fully. Ensure the media selected in
the printer driver matches the media loaded.
Another paper-feed problem is occurring
Media is not supported for the printer or tray
Use only media that is supported for the device and the tray being used. For more
information, see Understand specifications for supported media.
74
Maintain and troubleshoot
Media is not picked up from a tray
• Make sure media is loaded in the tray. For more information, see Load media. Fan
the media before loading.
• Make sure the media guides are snug, but not tight, against the stack.
• Make sure media in the tray is not curled. Uncurl paper by bending it in the
opposite direction of the curl.
• When using thin, special media, make sure that the tray is completely loaded. If
you are using special media that is only available in small quantities, try placing the
special media on top of other paper of the same size to help fill the tray. (Some
media is picked up more easily if the tray is full.)
• If you are using thick, special media (such as brochure paper), load media so that
the tray is between 1/4 and 3/4 full. If necessary, place the media on top
of other paper of the same size so that the stack height is within this range.
• Make sure Tray 2 (optional) is inserted properly.
• If you are printing on the blank side of a page that has been used, the device may
have problems picking up the media.
Media is not coming out correctly
• Make sure the output tray extension is extended; otherwise, printed pages may fall
off the device.
•
Remove excess media from the output tray. There is a limit to the number of
sheets the tray can hold.
Pages are skewing
• Make sure the media loaded in the trays fits snugly between the media guides. If
the tray is removable, pull out the tray from the device, and reload the media
properly, making sure that the media guides are properly aligned.
• Make sure the duplexer is properly installed.
• Load media into the device only when it is not printing.
• When reinserting a removeable tray into the device, do so gently. Forceful
insertion with a full stack of paper may cause sheets to slide up within the device,
causing the device to jam or pick multiple sheets at one time.
Multiple pages are being picked up
• Fan the media before loading.
• Make sure the paper guides are set to the correct markings in the tray for the
media size you are loading. Also make sure the guides are snug, but not tight,
against the stack.
Solve paper-feed problems
75
Chapter 5
•
•
•
•
•
Make sure the tray is not overloaded with paper.
When using thin, special media, make sure that the tray is completely loaded. If
you are using special media that is only available in small quantities, try placing the
special media on top of other paper of the same size to help fill the tray. (Some
media is picked up more easily if the tray is full.)
If you are using thick, special media (such as brochure paper), load media so that
the tray is between 1/4 and 3/4 full. If necessary, place the media on top
of other paper of the same size so that the stack height is within this range.
When reinserting a removeable tray into the device, do so gently. Forceful
insertion with a full stack of paper may cause sheets to slide up within the device,
causing the device to jam or pick multiple sheets at one time.
Use HP media for optimum performance and efficiency. For more information, see
Select print media.
Solve device management problems
This section provide solutions to common problems that involve managing the device.
This section contains the following topic:
•
Embedded Web server cannot be opened
Embedded Web server cannot be opened
Check your network setup
• Make sure you are not using a phone cord or a cross cable to connect the device
to the network. For more information, see Configure the device (Windows) or
Configure the device (Mac OS X).
• Make sure the network cable is securely connected to the device.
• Make sure the network hub, switch, or router is turned on and working properly.
Check the computer
Make sure the computer that you are using is connected to the network.
Check your Web browser
Make sure the Web browser meets the minimum system requirements. For more
information, see System requirements.
Check the device IP address
• To check the IP address of the device from the control panel, print the network
configuration page. For more information, see Understand the network
configuration or wireless (some models only) status report.
• Ping the device using the IP address from the command prompt.
For example, if the IP address is 123.123.123.123, type the following at the MSDOS prompt:
C:\Ping 123.123.123.123
If a reply appears, the IP address is correct. If a time-out response appears, the IP
address is incorrect.
76
Maintain and troubleshoot
Solve network problems
NOTE: After correcting any of the following, run the installation program again.
General network troubleshooting
• If you are unable to install the device software, verify that:
◦ All cable connections to the computer and the device are secure.
◦ The network is operational, and the network hub is turned on.
◦ All applications, including virus protection programs, spyware protection
programs, and firewalls, are closed or disabled for computers running Windows.
◦ Make sure the device is installed on the same subnet as the computers that
will be using the device.
◦ If the installation program cannot discover the device, print the network
configuration page, and enter the IP address manually in the installation
program. For more information, see Understand the network configuration or
wireless (some models only) status report
• If you are using a computer running Windows, make sure that the network ports
created in the device driver match the device IP address.
◦ Print the device’s network configuration page.
◦ Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
◦ Right-click the device icon, click Properties, and then click the Ports tab.
◦ Select the TCP/IP port for the device, and then click Configure Port.
◦ Compare the IP address listed in the dialog box, and make sure it matches the
IP address listed on the network configuration page. If the IP addresses are
different, change the IP address in the dialog box to match the address on the
network configuration page.
◦ Click OK twice to save the settings and close the dialog boxes.
Problems connecting to a wired network
• If the Network light on the control panel does not turn on, make sure that all of the
“General network troubleshooting” conditions are met.
• Though it is not recommended that you assign the device with a static IP address,
you might resolve some installation problems (such as a conflict with a personal
firewall) by doing so.
Solve wireless problems
If the device is unable to communicate with the network after completing the wireless
setup and software installation, perform one or more of the following tasks in the order
shown below.
•
•
Basic wireless troubleshooting
Advanced wireless troubleshooting
Solve wireless problems
77
Chapter 5
Basic wireless troubleshooting
Perform the following steps in the order presented.
NOTE: If this is the first time you are setting up the wireless connection, and you
are using the included software, make sure that the USB cable is connected to the
device and the computer.
Step 1 - Make sure the wireless (802.11) light is turned on
If the blue light near the HP device's wireless button is not lit, the wireless capabilities
might not have been turned on. To turn on wireless, press and hold the Wireless
button for three seconds.
NOTE: If your HP device supports Ethernet networking, make sure that an
Ethernet cable has not been connected to the device. Connecting an Ethernet
cable turns off the HP device's wireless capabilities.
Step 2 - Restart components of the wireless network
Turn off the router and the HP device, and then turn them back on in this order: router
first and then the HP device. If you still are unable to connect, turn off the router, HP
device, and your computer. Sometimes, turning off the power and then turning it back
on will recover a network communication issue.
Step 3 - Run the Wireless Network Test
For wireless networking issues, run the Wireless Network Test. To print a Wireless
Network Test page, press the Wireless button. If a problem is detected, the printed
test report will include recommendations that might help solve the problem.
Advanced wireless troubleshooting
If you have tried the suggestions provided in the Basic troubleshooting section and are
still unable to connect to your HP device to the wireless network, try the following
suggestions in the order presented:
•
•
•
•
•
•
•
•
78
Make sure your computer is connected to your network
Make sure that the HP device is connected to your network
Check to see if the firewall software is blocking communication
Make sure the HP device is online and ready
Your wireless router is using a hidden SSID
Make sure the wireless version of the HP device is set as the default printer driver
(Windows only)
Make sure the HP Network Devices Support service is running (Windows only)
Add hardware addresses to a wireless access point (WAP)
Maintain and troubleshoot
Make sure your computer is connected to your network
To check a wired (Ethernet) connection
▲ Many computers have indicator lights beside the port where the Ethernet cable
from the router connects to your computer. Usually there are two indicator lights,
one that is on and another that blinks. If your computer has indicator lights, check
to see if the indicator lights are on. If the lights are not on, try reconnecting the
Ethernet cable to the computer and the router. If you still do not see lights, there
might be a problem with the router, the Ethernet cable, or your computer.
NOTE: Macintosh computers do not have indicator lights. To check the
Ethernet connection on a Macintosh computer, click System Preferences in
the Dock, and then click Network. If the Ethernet connection is working
correctly, Built-in Ethernet appears in the list of connections, along with the IP
address and other status information. If Built-in Ethernet does not appear in
the list, there might be a problem with the router, the Ethernet cable, or your
computer. For more information, click the Help button in the window.
To check a wireless connection
1. Make sure that your computer's wireless has been turned on. (For more
information, see the documentation that came with your computer.)
2. If you are not using a unique network name (SSID), then it is possible that your
wireless computer could be connected to a nearby network that is not yours.
The following steps can help you determine if your computer is connected to your
network.
Windows
a. Click Start, click Control Panel, point to Network Connections, and then
click View Network Status and Tasks.
Or
Click Start, select Settings, click Control Panel, double-click Network
Connections, click the View menu, and then select Details.
Leave the network dialog box open while you continue to the next step.
b. Disconnect the power cord from the wireless router. The connection status of
your computer should change to Not Connected.
c. Reconnect the power cord to the wireless router. The connection status should
change to Connected.
Mac OS X
▲ Click the AirPort icon in the menu bar at the top of the screen. From the menu
that appears, you can determine if the AirPort is turned on and which wireless
network your computer is connected to.
NOTE: For more detailed information about your AirPort connection, click
System Preferences in the Dock, and then click Network. If the wireless
connection is working correctly, a green dot appears next to AirPort in the
list of connections. For more information, click the Help button in the window.
Solve wireless problems
79
Chapter 5
If you are unable to get your computer connected to your network, contact the person
who set up your network or the router manufacturer as there might be a hardware
issue with either your router or computer.
If you are able to access the Internet and are using a computer running Windows, you
can also access HP Network Assistant at www.hp.com/sbso/wireless/tools-setup.html?
jumpid=reg_R1002_USEN for help in setting up a network. (This Web site is only
available in English.)
Make sure that the HP device is connected to your network
If your device is not connected to the same network as your computer, you will not be
able to use the HP device over the network. Follow the steps described in this section
to find out if your device is actively connected to the correct network.
Make sure the HP device is on the network
1. If the HP device supports Ethernet networking and is connected to an Ethernet
network, make sure an Ethernet cable is not plugged into the back of the device. If
an Ethernet cable is plugged into the back, then wireless connectivity is disabled.
2. If the HP device is connected to a wireless network, print the device's Wireless
Configuration page. For more information, see Understand the network
configuration or wireless (some models only) status report.
▲ After the page has been printed, check the Network Status and URL:
Network Status
•
•
URL
If the Network Status is Ready, the
HP device is actively connected to a
network.
If the Network Status is Offline, the
HP device is not connected to a
network. Run the Wireless Network
Test (using the instructions at the
beginning of this section) and follow
any recommendations.
The URL shown here is the network
address assigned to the HP device by
your router. You will need this to connect
to the embedded Web server.
Check to see if you can access the embedded Web server (EWS)
▲ After you establish that the computer and the HP device both have active
connections to a network, you can verify if they are on the same network by
80
Maintain and troubleshoot
accessing the device's embedded Web server (EWS). For more information, see
Embedded Web server.
To access the EWS
a. On your computer, open the Web browser you normally use to access the
Internet (for example, Internet Explorer or Safari). In the address box, type the
URL of the HP device as it was shown on the Network Configuration Page (for
example, http://192.168.1.101).
NOTE: If you are using a proxy server in your browser, you might need to
disable it to access the EWS.
b. If you can access the EWS, try using the HP device over the network (such as
to print) to see if your network setup was successful.
c. If you cannot access the EWS or are still having problems using the HP device
over the network, continue to the next section regarding firewalls.
Check to see if the firewall software is blocking communication
If you cannot access the EWS and are sure both the computer and HP device have
active connections to the same network, the firewall security software might be
blocking communication. Temporarily turn off any firewall security software running on
your computer and then try to access the EWS again. If you can access the EWS, try
using the HP device (for printing).
If you are able to access the EWS and use your HP device with the firewall turned off,
you will need to reconfigure your firewall settings to allow the computer and HP device
to communicate with each other over the network.
If you are able to access the EWS, but are still unable to use the HP device even with
the firewall turned off, try enabling the firewall software to recognize the HP device.
Make sure the HP device is online and ready
If you have the HP software installed, you can check the HP device’s status from your
computer to see if the device is paused or offline, preventing you from using it.
To check the HP device’s status, complete the following steps:
Windows
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
2. If the printers on your computer are not being displayed in Details view, click the
View menu, and then click Details.
3. Do one of the following, depending on the printer status:
a. If the HP device is Offline, right-click the device, and click Use Printer Online.
b. If the HP device is Paused, right-click the device, and click Resume Printing.
4. Try using the HP device over the network.
Solve wireless problems
81
Chapter 5
Mac OS X
1. Click System Preferences in the Dock, and then click Print & Fax.
2. Select the HP device, and the click Print Queue.
3. If Jobs Stopped appears in the window that appears, click Start Jobs.
If you can use the HP device after performing the steps above but find that the
symptoms persist as you continue to use the device, your firewall might be interfering.
If you still cannot use the HP device over the network, continue to the next section for
additional troubleshooting help.
Your wireless router is using a hidden SSID
If your wireless router or Apple AirPort Base Station is using a hidden SSID, your HP
device will not automatically detect the network.
Make sure the wireless version of the HP device is set as the default printer
driver (Windows only)
If you install the software again, the installer might create a second version of the
printer driver in your Printers or Printers and Faxes folder. If you have difficulties
printing or connecting to the HP device, make sure the correct version of the printer
driver is set as the default.
1. Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
2. Determine if the version of the printer driver in the Printers or Printers and Faxes
folder is connected wirelessly:
a. Right-click the printer icon, and then click Properties, Document Defaults, or
Printing Preferences.
b. On the Ports tab, look for a port in the list with a checkmark. The version of the
printer driver that is connected wirelessly has Standard TCP/IP Port as the
Port description, next to the checkmark.
3. Right-click the printer icon for the version of the printer driver that is connected
wirelessly, and select Set as Default Printer.
NOTE: If there is more than one icon in the folder for the HP device, right-click
the printer icon for the version of the printer driver that is connected wirelessly, and
select Set as Default Printer.
Make sure the HP Network Devices Support service is running (Windows only)
To restart the HP Network Device Support service
1. Delete any print jobs currently in the print queue.
2. On the desktop, right-click My Computer or Computer, and then click Manage.
3. Double-click Services and Applications, and then click Services.
4. Scroll down the list of services, right click HP Network Devices Support, and then
click Restart.
5. After the service restarts, try using the HP device over the network again.
82
Maintain and troubleshoot
If you are able to use the HP device over the network, your network setup was
successful.
If you still cannot use the HP device over the network or if you have to periodically
perform this step in order to use your device over the network, your firewall might be
interfering.
If this still does not work, there might be a problem with your network configuration or
router. Contact the person who set up your network or the router manufacturer for help.
Add hardware addresses to a wireless access point (WAP)
MAC filtering is a security feature in which a wireless access point (WAP) is configured
with a list of MAC addresses (also called “hardware addresses”) of devices that are
allowed to gain access to the network through the WAP. If the WAP does not have the
hardware address of a device attempting to access the network, the WAP denies the
device access to the network. If the WAP filters MAC addresses, then the device’s
MAC address must be added to the WAP’s list of accepted MAC addresses.
•
•
Print the network configuration page. For more information, see Understand the
network configuration or wireless (some models only) status report.
Open the WAP’s configuration utility, and add the device’s hardware address to
the list of accepted MAC addresses.
Troubleshoot installation issues
If the following topics do not help, see Support and warranty for information about HP
support.
•
•
•
Hardware installation suggestions
Software installation suggestions
Solve network problems
Hardware installation suggestions
Check the device
• Make sure that all packing tape and material have been removed from outside and
inside the device.
• Make sure that the device is loaded with paper.
• Make sure that no lights are on or blinking except the Power light, which should be
on. If a light other than the Power light is on or blinking, there is an error. For more
information, see Control-panel lights reference.
• Make sure that the device can print a configuration page.
• Duplexer is locked into place.
Check the hardware connections
• Make sure that any cords and cables that you are using are in good working order.
• Make sure that the power cord is connected securely to both the device and to a
working power outlet.
Troubleshoot installation issues
83
Chapter 5
Check the printheads and ink cartridges
• Make sure that all of the printheads and ink cartridges are firmly installed in their
correct, colorcoded slot. Press down firmly on each one to ensure proper contact.
The device cannot work if they are not all installed.
• Make sure there are no pieces of the orange cap attached to the printhead.
• Make sure that all latches and covers are closed properly.
Software installation suggestions
Check the computer system
• Make sure that your computer is running one of the supported operating systems.
• Make sure that the computer meets at least the minimum system requirements.
• In the Windows device manager, make sure that the USB drivers have not been
disabled.
• If you are using a computer running Windows, and the computer cannot detect the
device, run the uninstallation utility (util\ccc\uninstall.bat on the Starter CD) to
perform a clean uninstallation of the device driver. Restart your computer, and
reinstall the device driver.
Verify installation preliminaries
• Make sure to use the Starter CD that contains the correct installation software for
your operating system.
• Before installing software, make sure that all other programs are closed.
• If the computer does not recognize the path to the CD-ROM drive that you type,
make sure that you are specifying the correct drive letter.
• If the computer cannot recognize the Starter CD in the CD-ROM drive, inspect the
Starter CD for damage. You can download the device driver from the HP Web site
(www.hp.com/support).
NOTE: After correcting any problems, run the installation program again.
Solve network problems
General network troubleshooting
• If you are unable to install the device software, verify that:
◦ All cable connections to the computer and the device are secure.
◦ The network is operational and the network hub is turned on.
◦ All applications, including virus protection programs, spyware protection
programs, and firewalls are closed or disabled for computers running Windows.
84
Maintain and troubleshoot
◦
•
Make sure the device is installed on the same subnet as the computers that
will be using the device.
◦ If the installation program cannot discover the device, print the network
configuration page, and enter the IP address manually in the installation
program. For more information, see Understand the network configuration or
wireless (some models only) status report.
If you are using a computer running Windows, make sure that the network ports
created in the device driver match the device IP address:
◦ Print the device’s network configuration page.
◦ Click Start, point to Settings, and then click Printers or Printers and Faxes.
- Or Click Start, click Control Panel, and then double-click Printers.
◦ Right-click the device icon, click Properties, and then click the Ports tab.
◦ Select the TCP/IP port for the device, and then click Configure Port.
◦ Compare the IP address listed in the dialog box and make sure it matches the
IP address listed on the network configuration page. If the IP addresses are
different, change the IP address in the dialog box to match the address on the
network configuration page.
◦ Click OK twice to save the settings and close the dialog boxes.
Problems connecting to a wired network
• If the Configuration light on the control panel does not turn on, make sure that all
of the “General network troubleshooting” conditions are met.
• Though it is not recommended that you assign the device with a static IP address,
you might resolve some installation problems (such as a conflict with a personal
firewall) by doing so.
To reset the device's network settings
1. Press and hold the
Power button, press
Network button, (on some models,
press the Wireless button
), two times, press the press the
Cancel button
three times, and release the Power button. For more information, see
Troubleshooting tips and resources.
2. Press the
Network button to print the network configuration pag,e and verify
that the network settings have been reset. By default, the network name (SSID) is
"hpsetup," and the communication mode is "ad hoc."
Troubleshoot installation issues
85
Chapter 5
Clear jams
Occasionally, media becomes jammed during a job. Try the following remedies before
you attempt to clear the jam.
•
•
•
•
•
Make sure that you are printing with media that meets specifications. For more
information, see Select print media.
Make sure to print with media that is not wrinkled, folded, or damaged.
Make sure that the input trays are loaded correctly and are not too full. For more
information, see Load media.
Clear a jam in the device
Tips for avoiding jams
Clear a jam in the device
To clear a jam
1. Remove all media from the output tray.
CAUTION: Trying to clear a paper jam from the front of the device can
damage the print mechanism. Always access and clear paper jams through the
duplexer.
2. Check the duplexer.
a. Push the button on either side of the duplexer, and then remove the panel or
unit.
b. Locate any jammed media inside the device, grasp it with both hands, and
then pull it towards you.
c. If the jam is not there, push the latch on the top of the duplexer, and lower its
cover. If the jam is inside, carefully remove it. Close the cover.
86
Maintain and troubleshoot
d. Reinsert the duplexer into the device.
3. Open the top cover and remove any debris.
4. If you have not found the jam and have Tray 2 installed, pull out the tray, and
remove the jammed media, if possible. If not, do the following:
a. Ensure the device is turned off, and disconnect the power cord.
b. Lift the device off Tray 2.
c. Remove the jammed media from the bottom of the device or from Tray 2.
d. Reposition the device on top of Tray 2.
5. Open the cover door. If there is paper remaining inside the device, ensure the
carriage has moved to the right of the device, free any paper scraps or wrinkled
media, and pull the media towards you through the top of the device.
WARNING! Do not reach into the device when it is on and the carriage is
stuck. When you open the top cover, the carriage should return to its position
on the right side of the device. If it does not move to the right, turn off the
device before you remove any jam.
6. After clearing the jam, close all covers, turn on the device (if you turned it off) and
resend the print job.
Tips for avoiding jams
•
•
•
•
•
•
•
•
Make sure that nothing is blocking the paper path.
Do not overload the trays. For more information, see Understand specifications for
supported media.
Load paper properly and when the device is not printing. For more information, see
Load media.
When reinserting Tray 2 (optional) into the device, do so gently. Forceful insertion
with a full stack of paper may cause sheets to slide up within the device, causing it
to jam or pick multiple sheets at one time.
Do not use media that is curled or crumpled.
Always use media that conforms with specifications. For more information, see
Select print media.
Make sure the output tray is not overly full.
Make sure the media length and width guides are adjusted snugly against the
media, but do not crinkle or bend the media.
Errors
This list represents some of the errors you might see on your computer screen
(Windows) and how to fix the errors.
•
•
•
•
Printhead(s) Missing - The following printhead appears to be missing, not
detected, or incorrectly installed
Incompatible Printhead - The following printhead is not intended for use in this
printer
Printhead problem - The following printhead has a problem
Device Disconnected
Errors
87
Chapter 5
•
•
•
•
•
•
•
•
•
•
•
•
Replace Cartridge(s) Soon - Replace the following cartridge soon
Cartridge Problem - The following cartridge appears to be missing or damaged
Cartridge Problem - The following cartridge must be replaced
Paper Mismatch - Paper detected does not match paper size or type selected
The cartridge cradle cannot move. Please turn device power off. Check device for
paper jam or other obstruction
Paper Jam - There is a paper jam (or misfeed). Clear the jam and press the
Resume button on the printer
The printer is out of paper. Load more paper and press the Resume button on the
front of the printer
Incompatible Cartridge(s) - The following cartridge is not intended for use in this
printer.
Printer Offline - Your printer is currently offline
Printer Paused - Your printer is currently paused
Document failed to print - The job failed to print due to an error in the printing system
General printer error
Printhead(s) Missing - The following printhead appears to be missing, not
detected, or incorrectly installed
Use the following to correct the error:
To replace the printheads
Incompatible Printhead - The following printhead is not intended for use in this
printer
Use the following to correct the error:
To replace the printheads
Printhead problem - The following printhead has a problem
Use the following to correct the error:
To replace the printheads
Device Disconnected
Use the following to correct the error:
Hardware installation suggestions
Replace Cartridge(s) Soon - Replace the following cartridge soon
Use the following to correct the error:
Replace the ink cartridges
88
Maintain and troubleshoot
NOTE: Ink level warnings and indicators provide estimates for planning purposes
only. When you receive a low-ink warning message, consider having a
replacement cartridge available to avoid possible printing delays. You do not need
to replace cartridges until prompted to do so.
For information on recycling used ink supplies, see HP inkjet supplies recycling
program.
Cartridge Problem - The following cartridge appears to be missing or damaged
Use the following to correct the error:
•
•
Replace the ink cartridges
HP inkjet supplies recycling program
Cartridge Problem - The following cartridge must be replaced
Use the following to correct the error:
•
•
Replace the ink cartridges
HP inkjet supplies recycling program
Paper Mismatch - Paper detected does not match paper size or type selected
Use the following to correct the error:
•
•
•
Load media
Print on special and custom-sized media
Change print settings
The cartridge cradle cannot move. Please turn device power off. Check device for
paper jam or other obstruction
Use the following to correct the error:
•
•
Clear a jam in the device
Hardware installation suggestions
Paper Jam - There is a paper jam (or misfeed). Clear the jam and press the
Resume button on the printer
Use the following to correct the error:
Clear a jam in the device
The printer is out of paper. Load more paper and press the Resume button on the
front of the printer
Use the following to correct the error:
Load media
Errors
89
Chapter 5
Incompatible Cartridge(s) - The following cartridge is not intended for use in this
printer.
Use the following to correct the error:
•
•
Replace the ink cartridges
HP inkjet supplies recycling program
Printer Offline - Your printer is currently offline
Use the following to correct the error:
To check if the printer is paused or offline (Windows)
1. Depending upon your operating system, do one of the following:
• Windows Vista: On the Windows taskbar, click Start, click Control Panel, and
then click Printers.
• Windows XP: On the Windows taskbar, click Start, click Control Panel, and
then click Printers and Faxes.
2. Double-click the icon for your product to open the print queue.
3. On the Printer menu, make sure there are no check marks next to Pause Printing
or Use Printer Offline.
4. If you made any changes, try to print again.
To check if the printer is paused or offline (Mac OS X)
1. Click System Preferences, click Print & Fax, and then click select the printer you
want to use.
2. Double-click the icon for your product to open the print queue.
3. If Hold is selected, click Resume.
4. If you made any changes, try to print again.
Printer Paused - Your printer is currently paused
Use the following to correct the error:
To check if the printer is paused or offline (Windows)
1. Depending upon your operating system, do one of the following:
• Windows Vista: On the Windows taskbar, click Start, click Control Panel, and
then click Printers.
• Windows XP: On the Windows taskbar, click Start, click Control Panel, and
then click Printers and Faxes.
2. Double-click the icon for your product to open the print queue.
3. On the Printer menu, make sure there are no check marks next to Pause Printing
or Use Printer Offline.
4. If you made any changes, try to print again.
90
Maintain and troubleshoot
To check if the printer is paused or offline (Mac OS X)
1. Click System Preferences, click Print & Fax, and then click select the printer you
want to use.
2. Double-click the icon for your product to open the print queue.
3. If Hold is selected, click Resume.
4. If you made any changes, try to print again.
Document failed to print - The job failed to print due to an error in the printing
system
Use the following to correct the error:
Solve printing problems
General printer error
If you are going to move or transport the product after receiving this message, make
sure you keep it upright and do not tip it on its side to avoid ink leakage. There was a
problem with the product.
Write down the error code provided in the message, and then contact HP support. Go
to:
www.hp.com/support.
If prompted, choose your country/region, and then click Contact HP for information on
calling for technical support.
Errors
91
6
Control-panel lights reference
The control-panel lights indicate status and are useful for diagnosing printing
problems. This section contains information about the lights, what they indicate, and
what action to take if necessary.
•
Interpreting control-panel lights
Interpreting control-panel lights
1
Ink cartridge lights
2
Printhead lights
NOTE: The printhead lights are only visible when a printhead needs attention.
3
4
Network button
(available with some models)
Wireless button
(available with some models)
Cancel
button
5
Resume
6
92
button and light
Power button and light
Control-panel lights reference
For more information, visit the HP Web site (www.hp.com/support) for the latest
troubleshooting information, or product fixes and updates.
Light description/Light pattern
Explanation and
recommended action
All lights are off.
The device is off.
•
•
The Power light is on.
Connect the power
cord.
Press the
Power button.
The device is ready.
No action is required.
The Power light blinks.
The device is turning
on or off, or is
processing a print job.
No action is required.
The device is pausing
for the ink to dry.
Wait for the ink to dry.
The Power light and the Resume light blink.
Print media is jammed
in the device.
Remove all media from
the output tray. Locate
and clear the jam. For
more information, see
Clear a jam in the
device.
The device carriage
has stalled.
•
•
•
Open the top
cover and remove
any obstructions
(such as jammed
media).
Press the
Resume button to
continue printing.
If the error
persists, turn the
device off, and
then on again.
Interpreting control-panel lights
93
Chapter 6
(continued)
Light description/Light pattern
Explanation and
recommended action
The Power light is on, and the Resume light blinks.
The device is out of
paper.
Load paper, and press
the
The Power light and the Resume light are on.
Resume button.
A cover is not closed
completely.
Make sure all covers
are completely closed.
The Power light and the Resume light blink, and one or more of the
ink cartridge lights are on.
One or more of the ink
cartridges have expired.
CAUTION: Product
failure or damage
attributable to the use
of an expired ink
cartridge will not be
covered under
warranty.
• Replace the
indicated ink
cartridge.
• If you choose to
use the expired ink
cartridge, press
and hold the
(Power button),
and press the
Resume button
three times. All
lights except the
Power light go off.
The Power light is on, and one or more of the printhead lights blink.
94
Control-panel lights reference
One or more of the
printheads are missing,
(continued)
Light description/Light pattern
Explanation and
recommended action
damaged, or not
properly installed.
•
•
•
The Power light and one or more of the printhead lights blink.
Install the
indicated
printhead, and
then try to print.
Ensure the
indicated printhead
is properly
installed, and then
try to print.
Remove and
reinsert the
printhead if
necessary.
If the error still
persists, replace
the indicated
printhead.
One or more of the
printheads are
incompatible or need
attention.
The printhead is not
intended for use in this
product. Replace the
indicated printhead.
The Power light is on, and one or more of the ink cartridge lights blink.
One or more of the ink
cartridges are missing,
damaged, or not
properly installed.
•
•
Install the
indicated ink
cartridge, and then
try to print.
Remove and reinsert the ink
cartridge a few
times if necessary.
If the error
persists, replace
the indicated ink
cartridge.
The ink in one of the
cartridges is depleted.
Replace the cartridge
indicated to continue
printing. For ordering
information, see HP
supplies and
accessories.
Interpreting control-panel lights
95
Chapter 6
(continued)
Light description/Light pattern
Explanation and
recommended action
The Power light and one or more of the ink cartridge lights blink.
One or more of the ink
cartridges are
incompatible or need
attention.
The ink cartridge is not
intended for use in this
product. Replace the
indicated ink cartridge.
The Power light is on, and one or more of the ink cartridge lights are
on.
One or more of the ink
cartridges are low on
ink and will need to be
replaced soon.
Get new ink cartridges
and replace the
existing cartridges
when they become
empty.
All lights blink.
A non-recoverable
error has occurred.
Unplug the power cord,
and then plug the
power cord back in,
and try printing.
The Power light, Resume light, and one or more ink cartridge lights
blink.
Non-HP ink has been
detected in one or
more of the cartridges.
CAUTION: Product
failure or damage
attributable to the use
of non-HP ink is not
covered under
warranty.
Replace the cartridge
indicated with an
original HP cartridge or
press
(Resume
button) to use the nonHP ink.
96
Control-panel lights reference
A
HP supplies and accessories
This section provides information on HP supplies and accessories for the device. The information
is subject to changes, visit the HP Web site (www.hpshopping.com) for the latest updates. You
may also make purchases through the Web site.
•
Order printing supplies online
•
Accessories
•
Supplies
Order printing supplies online
To order supplies online or create a printable shopping list, open the HP Solution Center desktop
icon that was installed by your HP printer software, and click the Shopping icon. Select Shop
Online or Print My Shopping List. HP Solution Center uploads, with your permission, printer
information, including model number, serial number, and estimated ink levels. The HP supplies
that work in your printer are pre-selected. You can change quantities, add or remove items, and
then print the list or purchase online at the HP Store or other online retailers (options differ by
country/region). Cartridge information and links to online shopping also appear on ink alert
messages.
You can also order online by visiting www.hp.com/buy/supplies. If prompted, choose your country/
region, follow the prompts to select your product, and then the supplies you need.
NOTE: Ordering cartridges online is not supported in all countries/regions. However, many
countries have information on ordering by telephone, locating a local store, and printing a
shopping list. In addition, you can select the 'How to Buy' option at the top of the www.hp.com/
buy/supplies page to obtain information about purchasing HP products in your country.
Accessories
250-sheet input tray
CB090A
Optional second tray for up to 250
pages of plain paper
HP Jetdirect en1700 External
Print Server
J7988G
External print server
HP Jetdirect en3700 Fast
Ethernet Print Server
J7942G
External print server (USB 2.0)
HP Jetdirect ew2400 802.11b/
g Wireless and Fast Ethernet
External Print Server (USB
2.0, 10/100 Base-TX, 802.11
b/g)
J7951G
Wireless or wired external print server
HP USB Network Print
Adapter
Q6275A
USB 2.0 printer adapter that allows
you to share the device with multiple
computers.
HP Wireless Printing
Upgrade Kit
Q6236A, Q6259A
Upgrade non-wireless devices to
use 802.11g wireless technology
HP Wireless G Print Server
Q6301A, Q6302A
802.11g print server for wireless
communication to a computer
HP supplies and accessories
97
Appendix A
Supplies
This section covers the following topics:
•
Ink cartridges and printheads
•
HP media
Ink cartridges and printheads
Ordering cartridges online is not supported in all countries/regions. However, many countries
have information on ordering by telephone, locating a local store and printing a shopping list. In
addition, you can select the 'How to Buy' option at the top of the www.hp.com/buy/supplies page
to obtain information about purchasing HP products in your country.
You can find the ink cartridge number in the following places:
•
On the Information page of the embedded Web server (see Embedded Web server).
•
Windows: From the HP Toolbox, if you have bidirectional communication, click the
Estimated Ink Levels tab, scroll to display the Cartridge Details button, and then click
Cartridge Details.
•
Mac OS X: From the HP Printer Utility, click Supply Info from the Information and
Support panel, and then click Retail Supplies Information.
•
On the label of the ink cartridge you are replacing.
•
Solution Center: From the Solution Center you can view supplies information from the
Shopping tab or the estimated ink level screen.
•
On the configuration page (see Understand the self-test diagnostic page).
NOTE: Ink level warnings and indicators provide estimates for planning purposes only.
When you receive a low-ink warning message, consider having a replacement cartridge
available to avoid possible printing delays. You do not need to replace cartridges until
prompted to do so.
HP media
To order media such as HP Premium Paper, go to www.hp.com.
HP recommends plain papers with the ColorLok logo for printing
and copying of everyday documents. All papers with the
ColorLok logo are independently tested to meet high standards
of reliability and print quality, and produce documents with crisp,
vivid color, bolder blacks & dry faster than ordinary plain papers.
Look for papers with the ColorLok logo in a variety of weights
and sizes from major paper manufacturers.
98
HP supplies and accessories
B
Support and warranty
The information in Maintain and troubleshoot suggests solutions to common problems. If your
device is not operating correctly and those suggestions did not solve your problem, try using one
of the following support services to obtain assistance.
This section contains the following topics:
•
Obtain electronic support
•
Hewlett-Packard limited warranty statement
•
Ink cartridge warranty information
•
Obtain HP telephone support
•
Prepare the device for shipment
•
Pack the device
Obtain electronic support
To find support and warranty information, go to the HP Web site at www.hp.com/support. If
prompted, choose your country/region, and then click Contact HP for information on calling for
technical support.
This Web site also offers technical support, drivers, supplies, ordering information, and other
options such as:
•
Access online support pages.
•
Send HP an e-mail message for answers to your questions.
•
Connect with an HP technician by using online chat.
•
Check for software updates.
You can also obtain support from HP from the following electronic sources:
•
HP Toolbox (Windows): The HP Toolbox provides easy, step-by-step solutions to common
printing problems. For more information, see HP Toolbox (Windows).
•
Embedded Web server: When the device is connected to a network, you can use the
embedded Web server to view status information, change settings, and manage the device at
your computer. For more information, see Embedded Web server.
Support options and availability vary by product, country/region, and language.
Support and warranty
99
Appendix B
Hewlett-Packard limited warranty statement
HP product
Duration of limited warranty
Software Media
90 days
Printer
1 year
Print or Ink cartridges
Until the HP ink is depleted or the “end of warranty” date printed
on the cartridge has been reached, whichever occurs first. This
warranty does not cover HP ink products that have been refilled,
remanufactured, refurbished, misused, or tampered with.
Printheads (only applies to products with customer
replaceable printheads)
1 year
Accessories
1 year unless otherwise stated
A. Extent of limited warranty
1. Hewlett-Packard (HP) warrants to the end-user customer that the HP products specified above will be free from defects
in materials and workmanship for the duration specified above, which duration begins on the date of purchase by the
customer.
2. For software products, HP’s limited warranty applies only to a failure to execute programming instructions. HP does not
warrant that the operation of any product will be interrupted or error free.
3. HP's limited warranty covers only those defects that arise as a result of normal use of the product, and does not cover
any other problems, including those that arise as a result of:
a. Improper maintenance or modification;
b. Software, media, parts, or supplies not provided or supported by HP;
c. Operation outside the product's specifications;
d. Unauthorized modification or misuse.
4. For HP printer products, the use of a non-HP cartridge or a refilled cartridge does not affect either the warranty to the
customer or any HP support contract with the customer. However, if printer failure or damage is attributable to the use of
a non-HP or refilled cartridge or an expired ink cartridge, HP will charge its standard time and materials charges to
service the printer for the particular failure or damage.
5. If HP receives, during the applicable warranty period, notice of a defect in any product which is covered by HP's
warranty, HP shall either repair or replace the product, at HP's option.
6. If HP is unable to repair or replace, as applicable, a defective product which is covered by HP's warranty, HP shall,
within a reasonable time after being notified of the defect, refund the purchase price for the product.
7. HP shall have no obligation to repair, replace, or refund until the customer returns the defective product to HP.
8. Any replacement product may be either new or like-new, provided that it has functionality at least equal to that of the
product being replaced.
9. HP products may contain remanufactured parts, components, or materials equivalent to new in performance.
10. HP's Limited Warranty Statement is valid in any country where the covered HP product is distributed by HP. Contracts
for additional warranty services, such as on-site service, may be available from any authorized HP service facility in
countries where the product is distributed by HP or by an authorized importer.
B. Limitations of warranty
TO THE EXTENT ALLOWED BY LOCAL LAW, NEITHER HP NOR ITS THIRD PARTY SUPPLIERS MAKES ANY
OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER EXPRESS OR IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
C. Limitations of liability
1. To the extent allowed by local law, the remedies provided in this Warranty Statement are the customer's sole and
exclusive remedies.
2. TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS SPECIFICALLY SET FORTH IN
THIS WARRANTY STATEMENT, IN NO EVENT SHALL HP OR ITS THIRD PARTY SUPPLIERS BE LIABLE FOR
DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON
CONTRACT, TORT, OR ANY OTHER LEGAL THEORY AND WHETHER ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
D. Local law
1. This Warranty Statement gives the customer specific legal rights. The customer may also have other rights which vary
from state to state in the United States, from province to province in Canada, and from country to country elsewhere in
the world.
2. To the extent that this Warranty Statement is inconsistent with local law, this Warranty Statement shall be deemed
modified to be consistent with such local law. Under such local law, certain disclaimers and limitations of this Warranty
Statement may not apply to the customer. For example, some states in the United States, as well as some governments
outside the United States (including provinces in Canada), may:
a. Preclude the disclaimers and limitations in this Warranty Statement from limiting the statutory rights of a consumer
(e.g., the United Kingdom);
b. Otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations; or
c. Grant the customer additional warranty rights, specify the duration of implied warranties which the manufacturer
cannot disclaim, or allow limitations on the duration of implied warranties.
3. THE TERMS IN THIS WARRANTY STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT
EXCLUDE, RESTRICT, OR MODIFY, AND ARE IN ADDITION TO, THE MANDATORY STATUTORY RIGHTS
APPLICABLE TO THE SALE OF THE HP PRODUCTS TO SUCH CUSTOMERS.
HP Limited Warranty
Dear Customer,
You will find below the name and address of the HP entity responsible for the performance of the HP Limited Warranty in your
country.
You may have additional statutory rights against the seller based on your purchase agreement. Those rights are not
in any way affected by this HP Limited Warranty.
Ireland: Hewlett-Packard Ireland Limited, 63-74 Sir John Rogerson's Quay, Dublin 2
United Kingdom: Hewlett-Packard Ltd, Cain Road, Bracknell, GB-Berks RG12 1HN
Malta: Hewlett Packard International Trade BV, Branch 48, Sqaq Nru 2, Triq ix-Xatt, Pieta MSD08, Malta
South Africa: Hewlett-Packard South Africa Ltd, 12 Autumn Street, Rivonia, Sandton, 2128, Republic of South Africa
100
Support and warranty
Ink cartridge warranty information
The HP cartridge warranty is applicable when the product is used in its designated HP printing
device. This warranty does not cover HP ink products that have been refilled, remanufactured,
refurbished, misused, or tampered with.
During the warranty period the product is covered as long as the HP ink is not depleted and the
end of warranty date has not been reached. The end of warranty date, in YYYY-MM format, may
be found on the product as indicated:
Ink cartridge warranty information
101
Appendix B
Obtain HP telephone support
During the warranty period, you may obtain assistance from the HP Customer Care Center.
NOTE: HP does not provide telephone support for Linux printing. All support is provided
online at the following Web site: https://launchpad.net/hplip. Click the Ask a question button
to begin the support process.
The HPLIP Web site does not provide support for Windows or Mac OS X. If you are using
these operating systems, visit www.hp.com/support.
This section contains the following topics:
•
Before you call
•
Support process
•
HP support by phone
•
Additional warranty options
•
HP Quick Exchange Service (Japan)
•
HP Korea customer support
Before you call
Visit the HP Web site (www.hp.com/support) for the latest troubleshooting information, or product
fixes and updates.
Software programs from other companies might be included with the HP device. If you
experience problems with any of those programs, you will receive the best technical assistance
by calling the experts at that company.
NOTE: This information does not apply to customers in Japan. For information on service
options in Japan, see HP Quick Exchange Service (Japan).
To assist our Customer Care Center representatives to serve you better, prepare the following
information if you need to call HP.
1.
Print the self-test diagnostic page of the device. For more information, see Understand the
self-test diagnostic page. If the device does not print, get the following information ready:
•
Device model
2.
•
Model number and serial number (check the back of the device)
Check the operating system that you are using, such as Windows XP.
3.
If the device is connected to the network, check the network operating system.
4.
Note how the device is connected to your system, such as through USB or network
connection.
5.
Obtain the version number of the printer software. (To find the version number of the printer
driver, open the printer settings or properties dialog box, and click the About tab.)
6.
If you have a problem printing from a particular application, note the application and version
number.
Support process
If you have a problem, follow these steps
1. Check the documentation that came with the device.
2.
102
Visit the HP online support Web site at www.hp.com/support. HP online support is available
to all HP customers. It is the fastest source for up-to-date device information and expert
assistance and includes the following features:
•
Fast access to qualified online support specialists
•
Software and driver updates for the HP device
Support and warranty
3.
•
Valuable troubleshooting information for common problems
•
Proactive device updates, support alerts, and HP newsgrams that are available when
you register the HP device
Call HP support. Support options and availability vary by device, country/region, and language.
HP support by phone
The phone support numbers and associated costs listed here are those in effect at time of this
material publication. For the most current HP list of telephone support numbers and call-cost
information, see www.hp.com/support.
This section contains the following topics:
•
Phone support period
•
Telephone support numbers
•
Placing a call
•
After the phone support period
Phone support period
One year of phone support is available in North America, Asia Pacific, and Latin America
(including Mexico).
To determine the duration of phone support in Europe, the Middle East, and Africa, go to
www.hp.com/support. Standard phone company charges apply.
Obtain HP telephone support
103
Appendix B
Telephone support numbers
For the most current list of telephone support numbers, see www.hp.com/support.
www.hp.com/support
$IULFD(QJOLVKVSHDNLQJ
$IULTXHIUDQFRSKRQH
$UJHQWLQD%XHQRV$LUHV
$UJHQWLQD
$XVWUDOLD
$XVWUDOLDRXWRIZDUUDQW\
˜VWHUUHLFK
‫ﺍﻟﺠﺰﺍﺋﺮ‬
೼SP
‫ﺍﻟﺒﺤﺮﻳﻦ‬
%HOJL­
%HOJLTXH
%UDVLO6DR3DXOR
%UDVLO
&DQDGD
&HQWUDO$PHULFD7KH
&DULEEHDQ
&KLOH
Ё೑
Ё೑
೼
೼
KSLQYHQW
ZZZKSFRPVXSSRUW
&RORPELD%RJRW£
&RORPELD
&RVWD5LFD
ÎHVN£UHSXEOLND
'DQPDUN
'..
(FXDGRU$QGLQDWHO
℡
(FXDGRU3DFLILWHO
℡
‫ﻣﺼﺮ‬
(O6DOYDGRU
(VSD³D
೼
)UDQFH
೼
'HXWVFKODQG
೼DXVGHPGHXWVFKHQ
)HVWQHW]EHL$QUXIHQDXV
0RELOIXQNQHW]HQN¸QQHQ
DQGHUH3UHLVHJHOWHQ
˃˨˨˙ˡ˞˞˭˹˱ˬˢ˫˶˱ˢˮ˦˧˹ ˃˨˨˙ˡ˞ˢ˪˱˹˯˃˨˨˙ˡ˞˯
˃˨˨˙ˡ˞˞˭˹̱˺˭ˮˬ
*XDWHPDOD
佭␃⡍߹㸠ᬓऔ
0DJ\DURUV]£J
,QGLD
,QGLD
,QGRQHVLD
‫ﺍﻟﻌﺮﺍﻕ‬
‫ﺍﻟﻜﻮﻳﺖ‬
‫ﻟﺒﻨﺎﻥ‬
‫ﻗﻄﺮ‬
‫ﺍﻟﻴﻤﻦ‬
,UHODQG
೼
‫ישראל‬
,WDOLD
104
Support and warranty
೼
-DPDLFD
㡴㦻
㡴㦻
‫ﺍﻷﺭﺩﻥ‬
뼑霢
/X[HPERXUJ)UDQ©DLV
೼
/X[HPEXUJ'HXWVFK
೼
0DOD\VLD
0DXULWLXV
0«[LFR&LXGDGGH0«[LFR 0«[LFR
0DURF
1HGHUODQG
೼
1HZ=HDODQG
1LJHULD
1RUJH
12.
‫ُﻋﻤﺎﻥ‬
3DQDP£
3DUDJXD\
3HU¼
3KLOLSSLQHV
3ROVND
3RUWXJDO
೼
3XHUWR5LFR
5HS¼EOLFD'RPLQLFDQD
5HXQLRQ
5RP¤QLD
̷͕͘͘͏̳͕͉͇ͦ͑͘
೼
̷͕͘͘͏̸͇͔͙ͦ͑
̶͙͈͚͌͌͗͗͊
೼
‫ﺍﻟﺴﻌﻮﺑﻴﺔ‬
6LQJDSRUH
6ORYHQVNR
6RXWK$IULFD56$
6XRPL
೼
6YHULJH
6(.
6ZLW]HUODQG
&+)
㟎☷
ࡷࡎ࡙
‫ﺗﻮﻧﺲ‬
7ULQLGDG7REDJR
7¾UNL\HòVWDQEXO$QNDUD ò]PLU%XUVD
̺͇͔͇͑͗ͭ
‫ﺍﻹﻣﺎﺭﺍﺕ ﺍﻟﻌﺮﺑﻴﺔ ﺍﻟﻤﺘﺤﺪﺓ‬
8QLWHG.LQJGRP
8QLWHG6WDWHV
8UXJXD\
9HQH]XHOD&DUDFDV
9HQH]XHOD
9L¬W1DP
e
Placing a call
Call HP support while you are in front of the computer and the HP device. Be prepared to provide
the following information:
•
Model number (located on the label on the front of the device)
•
Serial number (located on the back or bottom of the device)
•
Messages that appear when the situation occurs
•
Answers to these questions:
◦
Has this situation happened before?
◦
Can you re-create it?
◦
Did you add any new hardware or software to your computer at about the time that this
situation began?
◦
Did anything else occur prior to this situation (such as a thunderstorm, HP device was
moved, etc.)?
After the phone support period
After the phone support period, help is available from HP at an additional cost. Help may also be
available at the HP online support Web site: www.hp.com/support. Contact your HP dealer or call
the support phone number for your country/region to learn more about support options.
Additional warranty options
Extended service plans are available for the HP device at additional costs. Go to www.hp.com/
support, select your country/region and language, then explore the services and warranty area for
information about the extended service plans.
Obtain HP telephone support
105
Appendix B
HP Quick Exchange Service (Japan)
For instructions on how to pack your product for exchange, see Pack the device.
HP Korea customer support
106
Support and warranty
Prepare the device for shipment
If after contacting HP Customer Support or returning to the point of purchase, you are requested
to send the device in for service, make sure you remove and keep the following items before
returning your device:
•
The ink cartridges and printheads
•
The power cord, USB cable, and any other cable connected to the device
•
Any paper loaded in the input tray
•
Remove any originals you might have loaded in the device
This section contains the following topics:
•
Remove the ink cartridges and printheads before shipment
Remove the ink cartridges and printheads before shipment
Before you return the device, make sure you remove your ink cartridges and printheads.
NOTE: This information does not apply to customers in Japan.
To remove ink cartridges before shipment
1. Turn the device and wait until the print carriage is idle and silent. If the device will not turn on,
skip this step and go to step 2.
2.
Gently pull open the ink cartridge cover.
3.
Remove the ink cartridges from their slots by grasping each between your thumb and
forefinger and pulling it firmly toward you.
4.
Place the ink cartridges in an airtight plastic container so they will not dry out, and put them
aside. Do not send them with the device unless the HP customer support call agent instructs
you to do so. For more information on storing supplies, see Store printing supplies.
5.
Close the ink cartridge door and wait a few minutes for the print carriage to move back to its
home position (on the right side).
6.
Press the Power button to turn off the device.
Prepare the device for shipment
107
Appendix B
To remove printheads before shipment
1. Open the top cover.
2.
If the print carriage does not move to the left automatically, press and hold the
Resume
button until the carriage moves to the left. Wait for the print carriage to stop moving, and then
unplug the power cord from the printer.
NOTE: If the printer cannot be powered on, use a pen to remove the printhead cover.
108
3.
Lift the printhead latch.
4.
Lift the handle of a printhead, and use it to pull the printhead out of its slot.
Support and warranty
5.
Place the printheads in an airtight plastic container--nozzles facing up and not touching each
other or the container--so they will not dry out, and put them aside. Do not send them with the
device unless the HP customer support call agent instructs you to.
6.
Close the top cover.
NOTE: If you have opened the printhead cover, use your thumb to press the catch, and
reinsert the printhead cover.
7.
After the printer is idle and the print carriage has returned to its parked position, press the
Power button to turn off the device.
Pack the device
Complete the following steps after you have prepared the device for shipment:
To pack the device
1. If available, pack the device for shipment by using the original packaging materials, or use
the packaging materials that came with your replacement device.
Pack the device
109
Appendix B
If you do not have the original packaging materials, please use other adequate packaging
materials. Shipping damage caused by improper packaging and/or improper transportation is
not covered under the warranty.
110
2.
Place the return shipping label on the outside of the box.
3.
Include the following items in the box:
•
A complete description of symptoms for service personnel (samples of print quality
problems are helpful).
•
A copy of the sales slip or other proof of purchase to establish the warranty coverage
period.
•
Your name, address, and a phone number where you can be reached during the day.
Support and warranty
C
Device specifications
For media and media-handling specifications, see Understand specifications for supported media.
•
Physical specifications
•
Product features and capacities
•
Processor and memory specifications
•
System requirements
•
Network protocol specifications
•
Embedded Web server specifications
•
Print resolution
•
Environmental specifications
•
Electrical specifications
•
Acoustic emission specifications (print in Draft mode, noise levels per ISO 7779)
Physical specifications
Size (width x height x depth)
Device with duplexer: 494 x 180 x 479 mm (19.5 x 7.1 x 18.9 inches)
With Tray 2: Adds 66 mm (2.6 inches) to the height of the device.
Device weight (does not include printing supplies)
Device with duplexer: 7.2 kg (17.2 lb)
With Tray 2: Adds 2.6 kg (5.7 lb)
Device specifications
111
Appendix C
Product features and capacities
Feature
Capacity
Connectivity
•
•
•
USB 2.0-compliant high speed
Fast Ethernet 10/100Base-TX for wired
network connection (some models only)
Wireless 802.11b/g (some models only)
Print method
Drop-on-demand thermal inkjet printing
Ink cartridges
Four ink cartridges (one each for black, cyan,
magenta, and yellow)
Printheads
Two printheads (one black and yellow, and
one magenta and cyan)
Supply yields
Visit www.hp.com/go/learnaboutsupplies/ for
more information on estimated ink cartridge
yields.
Device languages
HP PCL 3 enhanced
Font support
US fonts: CG Times, CG Times Italic,
Universe, Universe Italic, Courier, Courier
Italic, Letter Gothic, Letter Gothic Italic.
Duty cycle
Up to 15,000 pages per month
Processor and memory specifications
Device processor
384MHz ARM11
Device memory
•
32 MB built-in RAM
•
8 MB built-in MROM + 2 MB built-in Flash ROM
System requirements
NOTE: For the most current information about supported operating systems and system
requirements, visit http://www.hp.com/support/.
Operating system compatibility
•
Windows 2000, Windows XP, Windows XP x64, Windows Vista
NOTE: For Windows 2000 SP4, Windows XP x64 Edition SP 1, Windows XP SP 1
Starter Edition, and Windows Vista Starter Edition only printer drivers and the Toolbox
are available.
112
•
Mac OS X (v10.4, v10.5)
•
Linux (For more information, see www.hp.com/go/linuxprinting).
Device specifications
Minimum requirements
•
Microsoft Windows® 2000 Service Pack 4: Intel® Pentium II or Celeron® processor, 128 MB
RAM, 160 MB free hard disk space, Microsoft Internet Explorer 6.0
•
Microsoft Windows XP (32-bit) Service Pack 1: Intel Pentium II or Celeron processor, 512 MB
RAM, 225 MB free hard disk space, Microsoft Internet Explorer 6.0
•
Microsoft® Windows x64 Service Pack 1: AMD Athlon 64 or AMD Opteron processor, Intel
Xeon or Pentium processor with Intel EM64T support, 512MB RAM, 160 MB free hard disk
space, Microsoft Internet Explorer 6.0
•
Microsoft Windows Vista: 800 MHz 32-bit (x86) or 64-bit (x64) processor, 512 MB RAM, 225
MB free hard disk space, Microsoft Internet Explorer 7.0
•
Mac OS X (v10.4.11, v10.5): PowerPC G3, G4, G5, or Intel Core processor, 256 MB
memory, 500 MB free hard disk space
•
Quick Time 5.0 or later (Mac OS X)
•
Adobe Acrobat Reader 5.0 or later
Recommended requirements
•
Microsoft Windows 2000 Service Pack 4: Intel Pentium III or higher processor, 256 MB RAM,
160 MB free hard disk space, Microsoft Internet Explorer 6.0 or later
•
Microsoft Windows XP (32-bit) Service Pack 1: Intel Pentium III or higher processor, 512MB
RAM, 360 MB free hard disk space, Microsoft Internet Explorer 6.0 or later
•
Microsoft® Windows® XP x64 Service Pack 1: AMD Athlon 64 or AMD Opteron processor,
Intel Xeon processor with Intel EM64T support, or Intel Pentium 4 processor with Intel EM64T
support, 512MB RAM, 160 MB free hard disk space, Microsoft Internet Explorer 6.0 or later
•
Microsoft Windows Vista: 1 GHz 32-bit (x86) or 64-bit (x64) processor, 1 GB RAM, 355 MB
free hard disk space, Microsoft Internet Explorer 7.0 or later
•
Mac OS X (v10.4.11, v10.5): PowerPC G3, G4, G5, or Intel Core processor, 512 MB
memory - 500 MB free hard disk space
•
Microsoft Internet Explorer 6.0 or later (Windows 2000, Windows XP); Internet Explorer
7.0 or later (Windows Vista)
Network protocol specifications
Network operating system compatibility
•
Windows 2000, Windows XP (32-bit), Windows XP x64 (Professional and Home Editions),
Windows Vista
•
Mac OS X (v10.4.x, v10.5)
•
Microsoft Windows 2000 Server Terminal Services with Citrix Metaframe XP with Feature
Release 3
•
Microsoft Windows 2000 Server Terminal Services with Citrix Presentation Server 4.0
•
Microsoft Windows 2000 Server Terminal Services
•
Microsoft Windows 2003 Server Terminal Services
•
Microsoft Windows 2003 Server Terminal Services with Citrix Presentation Server 4.0
•
Microsoft Windows 2003 Server Terminal Services with Citrix Metaframe XP with Feature
Release 3
•
Novell Netware 6, 6.5, Open Enterprise Server 6.5
Compatible network protocols
TCP/IP
Network protocol specifications
113
Appendix C
Network management
Embedded Web server
Features
◦
Ability to remotely configure and manage network devices
◦
myPrintMileage
Embedded Web server specifications
Requirements
•
A TCP/IP-based network (IPX/SPX-based networks are not supported)
•
A Web browser (either Microsoft Internet Explorer 6.0 or higher, Mozilla Firefox 1.0 or higher,
Opera 8.0 or higher, or Safari 1.2, or higher)
•
A network connection (you cannot use the embedded Web server connected directly to a
computer with a USB cable)
•
An Internet connection (required for some features)
NOTE: You can open the embedded Web server without being connected to the
Internet. However, some features will not be available.
•
It must be on the same side of a firewall as the device.
Print resolution
Black
Up to 1200 dpi with pigmented black ink
Color
HP enhanced photo quality (up to 4800 by 1200 dpi Optimized on HP Premium Plus photo
papers with 1200 x 1200 input dpi)
Environmental specifications
Operating environment
Operating temperature: 5° to 40° C (41° to 104° F)
Recommended operating conditions: 15° to 32° C (59° to 90° F)
Recommended relative humidity: 25 to 75% noncondensing
Storage environment
Storage temperature: -40° to 60° C (-40° to 140° F)
Storage relative humidity: Up to 90% noncondensing at a temperature of 65° C (150° F)
Electrical specifications
Power supply
Universal power adapter (external)
Power requirements
Input voltage: 100 to 240 VAC (± 10%), 50 to 60 Hz (± 3Hz)
Output voltage: 32 Vdc, 2000 mA
Power consumption
26 watts (Fast Draft Mode)
114
Device specifications
Acoustic emission specifications (print in Draft mode, noise levels
per ISO 7779)
Sound pressure (bystander position)
LpAd 54 (dBA)
Sound power
LwAd 6.7 (BA)
Acoustic emission specifications (print in Draft mode, noise levels per ISO 7779)
115
D
Regulatory information
This section contains the following topics:
•
FCC statement
•
Notice to users in Korea
•
VCCI (Class B) compliance statement for users in Japan
•
Notice to users in Japan about the power cord
•
Toxic and hazardous substance table
•
Regulatory information for wireless products
•
Regulatory model number
•
Declaration of conformity
•
Environmental product stewardship program
•
Third-party licenses
FCC statement
FCC statement
The United States Federal Communications Commission (in 47 CFR 15.105) has specified
that the following notice be brought to the attention of users of this product.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•
•
•
•
Reorient the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
For further information, contact:
Manager of Corporate Product Regulations
Hewlett-Packard Company
3000 Hanover Street
Palo Alto, Ca 94304
(650) 857-1501
Modifications (part 15.21)
The FCC requires the user to be notified that any changes or modifications made to this
device that are not expressly approved by HP may void the user's authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
116
Regulatory information
Notice to users in Korea
VCCI (Class B) compliance statement for users in Japan
Notice to users in Japan about the power cord
Toxic and hazardous substance table
Toxic and hazardous substance table
117
Appendix D
Regulatory information for wireless products
This section contains the following regulatory information pertaining to wireless products:
Exposure to radio frequency radiation
•
•
Notice to users in Brazil
•
Notice to users in Canada
•
Notice to users in Taiwan
•
European Union regulatory notice
Exposure to radio frequency radiation
Exposure to radio frequency radiation
Caution The radiated output power of this device is far below the FCC radio
frequency exposure limits. Nevertheless, the device shall be used in such a manner
that the potential for human contact during normal operation is minimized. This
product and any attached external antenna, if supported, shall be placed in such
a manner to minimize the potential for human contact during normal operation. In
order to avoid the possibility of exceeding the FCC radio frequency exposure
limits, human proximity to the antenna shall not be less than 20 cm (8 inches)
during normal operation.
Notice to users in Brazil
Aviso aos usuários no Brasil
Este equipamento opera em caráter secundário, isto é, não tem direito à proteção
contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário. (Res.ANATEL 282/2001).
Notice to users in Canada
Notice to users in Canada/Note à l'attention des utilisateurs canadiens
For Indoor Use. This digital apparatus does not exceed the Class B limits for radio noise
emissions from the digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications. The internal wireless radio complies with RSS
210 and RSS GEN of Industry Canada.
Utiliser à l'intérieur. Le présent appareil numérique n'émet pas de bruit radioélectrique
dépassant les limites applicables aux appareils numériques de la classe B prescrites dans
le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications
du Canada. Le composant RF interne est conforme a la norme RSS-210 and RSS GEN
d'Industrie Canada.
118
Regulatory information
Notice to users in Taiwan
Regulatory information for wireless products
119
Appendix D
European Union regulatory notice
European Union Regulatory Notice
Products bearing the CE marking comply with the following EU Directives:
•
•
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
CE compliance of this product is valid only if powered with the correct CE-marked AC
adapter provided by HP.
If this product has telecommunications functionality, it also complies with the essential
requirements of the following EU Directive:
•
R&TTE Directive 1999/5/EC
Compliance with these directives implies conformity to harmonized European standards
(European Norms) that are listed in the EU Declaration of Conformity issued by HP for this
product or product family. This compliance is indicated by the following conformity
marking placed on the product.
The wireless telecommunications functionality of this product may be used in the following
EU and EFTA countries:
Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,
Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania,
Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic,
Slovenia, Spain, Sweden, Switzerland and United Kingdom.
Products with 2.4-GHz wireless LAN devices
France
For 2.4 GHz Wireless LAN operation of this product certain restrictions apply: This
product may be used indoor for the entire 2400-2483.5 MHz frequency band (channels
1-13). For outdoor use, only 2400-2454 MHz frequency band (channels 1-9) may be used.
For the latest requirements, see http://www.art-telecom.fr.
Italy
License required for use. Verify with your dealer or directly with the General Direction for
Frequency Planning and Management (Direzione Generale Pianificazione e Gestione
Frequenze).
Regulatory model number
For regulatory identification purposes, your product is assigned a Regulatory Model Number. The
Regulatory Model Number for your product is SNPRC-0702-01 (HP Officejet Pro 8000 Printer) or
SNPRC-0702-02 (HP Officejet Pro 8000 Wireless Printer). This regulatory number should not be
confused with the marketing name (HP Officejet Pro 8000 Printer) or product number.
120
Regulatory information
Declaration of conformity
DECLARATION OF CONFORMITY
according to ISO/IEC 17050-1 and EN 17050-1
Supplier’s Name:
Hewlett-Packard Company
Supplier’s Address:
60, Alexandra Terrace, # 07-01 The Comtech, Singapore 118502
DoC#: SNPRC-0702-01-A
declares, that the product
Product Name:
HP Officejet Pro 8000 Printer Series
Regulatory Model Number:1)
SNPRC-0702-01
Product Options:
C9101A / Automatic 2-Sided Printing Device
CB090A / 250-sheet Paper Tray
conforms to the following Product Specifications and Regulations:
SAFETY:
IEC 60950-1:2001 / EN60950-1:2001 + A11:2004
EN 60825-1 1994+A1:2002+A2: 2001
EMC:
CISPR 22:2005/ EN 55022: 2006 Class B(4)
EN 55024:1998 +A1:2001 + A2:2003
EN 61000-3-2: 2000 + A2: 2005
EN 61000-3-3:1995 +A1: 2001
FCC CFR 47, Part 15 Class B(4) / ICES-003, Issue 4 Class B(4)
Supplementary Information:
1. This product is assigned a Regulatory Model Number which stays with the regulatory aspects of the design. The Regulatory
Model Number is the main product identifier in the regulatory documentation and test reports, this number should not be
confused with the marketing name or the product numbers.
2. This product complies with the requirements of the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC
and carries the CE-marking accordingly. In addition, it complies with the WEEE Directive 2002/96/EC and RoHS Directive
2002/95/EC.
3. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two Conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
4. The product was tested in a typical configuration
Singapore
April 2008
Wong Soo Min, Director Quality
Imaging & Printing Manufacturing Operations
Local contact for regulatory topics only:
EMEA: Hewlett-Packard GmbH, HQ-TRE, Herrenberger Strasse 140, 71034 Boeblingen, Germany www.hp.com/go/certificates
USA : Hewlett-Packard, 3000 Hanover St., Palo Alto 94304, U.S.A. 650-857-1501
Declaration of conformity
121
Appendix D
DECLARATION OF CONFORMITY
according to ISO/IEC 17050-1 and EN 17050-1
Supplier’s Name:
Hewlett-Packard Company
Supplier’s Address:
60, Alexandra Terrace, # 07-01 The Comtech, Singapore 118502
DoC#: SNPRC-0702-02-A
declares, that the product
Product Name:
HP Officejet Pro 8000 Printer Series
Regulatory Model Number:1)
SNPRC-0702-02
Product Options:
C9101A / Automatic 2-Sided Printing Device
CB090A / 250-sheet Paper Tray
Radio Module Number:
RSVLD-0608
conforms to the following Product Specifications and Regulations:
SAFETY:
IEC 60950-1:2001 / EN60950-1:2001 + A11:2004
EN 60825-1 1994+A1:2002+A2: 2001
EMC:
CISPR 22:2005/ EN 55022: 2006 Class B(4)
EN 55024:1998 +A1:2001 + A2:2003
EN 61000-3-2: 2000 + A2: 2005
EN 61000-3-3:1995 +A1: 2001
FCC CFR 47, Part 15 Class B(4) / ICES-003, Issue 4 Class B(4)
RADIO:
EN 301 489-1 V1.6.1:2005 / EN 301 489-17 V1.2.1:2002
EN 300 328 V1.7.1:2006
Supplementary Information:
1. This product is assigned a Regulatory Model Number which stays with the regulatory aspects of the design. The Regulatory
Model Number is the main product identifier in the regulatory documentation and test reports, this number should not be
confused with the marketing name or the product numbers.
2. This product complies with the requirements of the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC
and the R&TTE Directive 99/5/EC, and carries the CE-marking accordingly. In addition, it complies with the WEEE
Directive 2002/96/EC and RoHS Directive 2002/95/EC.
3. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two Conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
4. The product was tested in a typical configuration
Singapore
April 2008
Wong Soo Min, Director Quality
Imaging & Printing Manufacturing Operations
Local contact for regulatory topics only:
EMEA: Hewlett-Packard GmbH, HQ-TRE, Herrenberger Strasse 140, 71034 Boeblingen, Germany www.hp.com/go/certificates
USA : Hewlett-Packard, 3000 Hanover St., Palo Alto 94304, U.S.A. 650-857-1501
122
Regulatory information
Environmental product stewardship program
Hewlett-Packard is committed to providing quality products in an environmentally sound manner.
Design for recycling has been incorporated into this product. The number of materials has been
kept to a minimum while ensuring proper functionality and reliability. Dissimilar materials have
been designed to separate easily. Fasteners and other connections are easy to locate, access,
and remove using common tools. High priority parts have been designed to access quickly for
efficient disassembly and repair.
For more information, visit HP’s Commitment to the Environment Web site at:
www.hp.com/hpinfo/globalcitizenship/environment/index.html
This section contains the following topics:
Paper use
•
•
Plastics
•
Material safety data sheets
•
Recycling program
•
HP inkjet supplies recycling program
•
Disposal of waste equipment by users in private households in the European Union
•
Power consumption
•
Chemical Substances
Paper use
This product is suited for the use of recycled paper according to DIN 19309 and EN 12281:2002.
Plastics
Plastic parts over 25 grams are marked according to international standards that enhance the
ability to identify plastics for recycling purposes at the end of product life.
Material safety data sheets
Material safety data sheets (MSDS) can be obtained from the HP Web site at:
www.hp.com/go/msds
Recycling program
HP offers an increasing number of product return and recycling programs in many countries/
regions, and partners with some of the largest electronic recycling centers throughout the world.
HP conserves resources by reselling some of its most popular products. For more information
regarding recycling of HP products, please visit:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/
HP inkjet supplies recycling program
HP is committed to protecting the environment. The HP Inkjet Supplies Recycling Program is
available in many countries/regions, and lets you recycle used print cartridges and ink cartridges
free of charge. For more information, go to the following Web site:
www.hp.com/hpinfo/globalcitizenship/environment/recycle/
Environmental product stewardship program
123
Appendix D
English
Français
Deutsch
Italiano
Español
Česky
Likvidace vysloužilého zařízení uživateli v domácnosti v zemích EU
Tato značka na produktu nebo na jeho obalu označuje, že tento produkt nesmí být likvidován prostým vyhozením do běžného domovního odpadu. Odpovídáte za to, že vysloužilé
zařízení bude předáno k likvidaci do stanovených sběrných míst určených k recyklaci vysloužilých elektrických a elektronických zařízení. Likvidace vysloužilého zařízení samostatným
sběrem a recyklací napomáhá zachování přírodních zdrojů a zajišťuje, že recyklace proběhne způsobem chránícím lidské zdraví a životní prostředí. Další informace o tom, kam můžete
vysloužilé zařízení předat k recyklaci, můžete získat od úřadů místní samosprávy, od společnosti provádějící svoz a likvidaci domovního odpadu nebo v obchodě, kde jste produkt
zakoupili.
Dansk
Bortskaffelse af affaldsudstyr for brugere i private husholdninger i EU
Dette symbol på produktet eller på dets emballage indikerer, at produktet ikke må bortskaffes sammen med andet husholdningsaffald. I stedet er det dit ansvar at bortskaffe affaldsudstyr
ved at aflevere det på dertil beregnede indsamlingssteder med henblik på genbrug af elektrisk og elektronisk affaldsudstyr. Den separate indsamling og genbrug af dit affaldsudstyr på
tidspunktet for bortskaffelse er med til at bevare naturlige ressourcer og sikre, at genbrug finder sted på en måde, der beskytter menneskers helbred samt miljøet. Hvis du vil vide mere
om, hvor du kan aflevere dit affaldsudstyr til genbrug, kan du kontakte kommunen, det lokale renovationsvæsen eller den forretning, hvor du købte produktet.
Nederlands
Afvoer van afgedankte apparatuur door gebruikers in particuliere huishoudens in de Europese Unie
Dit symbool op het product of de verpakking geeft aan dat dit product niet mag worden afgevoerd met het huishoudelijk afval. Het is uw verantwoordelijkheid uw afgedankte apparatuur
af te leveren op een aangewezen inzamelpunt voor de verwerking van afgedankte elektrische en elektronische apparatuur. De gescheiden inzameling en verwerking van uw afgedankte
apparatuur draagt bij tot het sparen van natuurlijke bronnen en tot het hergebruik van materiaal op een wijze die de volksgezondheid en het milieu beschermt. Voor meer informatie over
waar u uw afgedankte apparatuur kunt inleveren voor recycling kunt u contact opnemen met het gemeentehuis in uw woonplaats, de reinigingsdienst of de winkel waar u het product
hebt aangeschaft.
Eesti
Eramajapidamistes kasutuselt kõrvaldatavate seadmete käitlemine Euroopa Liidus
Kui tootel või toote pakendil on see sümbol, ei tohi seda toodet visata olmejäätmete hulka. Teie kohus on viia tarbetuks muutunud seade selleks ettenähtud elektri- ja elektroonikaseadmete
utiliseerimiskohta. Utiliseeritavate seadmete eraldi kogumine ja käitlemine aitab säästa loodusvarasid ning tagada, et käitlemine toimub inimeste tervisele ja keskkonnale ohutult.
Lisateavet selle kohta, kuhu saate utiliseeritava seadme käitlemiseks viia, saate küsida kohalikust omavalitsusest, olmejäätmete utiliseerimispunktist või kauplusest, kust te seadme
ostsite.
Suomi
Hävitettävien laitteiden käsittely kotitalouksissa Euroopan unionin alueella
Tämä tuotteessa tai sen pakkauksessa oleva merkintä osoittaa, että tuotetta ei saa hävittää talousjätteiden mukana. Käyttäjän velvollisuus on huolehtia siitä, että hävitettävä laite
toimitetaan sähkö- ja elektroniikkalaiteromun keräyspisteeseen. Hävitettävien laitteiden erillinen keräys ja kierrätys säästää luonnonvaroja. Näin toimimalla varmistetaan myös,
että kierrätys tapahtuu tavalla, joka suojelee ihmisten terveyttä ja ympäristöä. Saat tarvittaessa lisätietoja jätteiden kierrätyspaikoista paikallisilta viranomaisilta, jäteyhtiöiltä tai tuotteen
jälleenmyyjältä.
Ελληνικά
Απόρριψη άχρηστων συσκευών στην Ευρωπαϊκή Ένωση
Το παρόν σύμβολο στον εξοπλισμό ή στη συσκευασία του υποδεικνύει ότι το προϊόν αυτό δεν πρέπει να πεταχτεί μαζί με άλλα οικιακά απορρίμματα. Αντίθετα, ευθύνη σας είναι να
απορρίψετε τις άχρηστες συσκευές σε μια καθορισμένη μονάδα συλλογής απορριμμάτων για την ανακύκλωση άχρηστου ηλεκτρικού και ηλεκτρονικού εξοπλισμού. Η χωριστή συλλογή και
ανακύκλωση των άχρηστων συσκευών θα συμβάλει στη διατήρηση των φυσικών πόρων και στη διασφάλιση ότι θα ανακυκλωθούν με τέτοιον τρόπο, ώστε να προστατεύεται η υγεία των
ανθρώπων και το περιβάλλον. Για περισσότερες πληροφορίες σχετικά με το πού μπορείτε να απορρίψετε τις άχρηστες συσκευές για ανακύκλωση, επικοινωνήστε με τις κατά τόπους αρμόδιες
αρχές ή με το κατάστημα από το οποίο αγοράσατε το προϊόν.
Magyar
A hulladékanyagok kezelése a magánháztartásokban az Európai Unióban
Ez a szimbólum, amely a terméken vagy annak csomagolásán van feltüntetve, azt jelzi, hogy a termék nem kezelhető együtt az egyéb háztartási hulladékkal. Az Ön feladata,
hogy a készülék hulladékanyagait eljuttassa olyan kijelölt gyűjtőhelyre, amely az elektromos hulladékanyagok és az elektronikus berendezések újrahasznosításával foglalkozik.
A hulladékanyagok elkülönített gyűjtése és újrahasznosítása hozzájárul a természeti erőforrások megőrzéséhez, egyúttal azt is biztosítja, hogy a hulladék újrahasznosítása az
egészségre és a környezetre nem ártalmas módon történik. Ha tájékoztatást szeretne kapni azokról a helyekről, ahol leadhatja újrahasznosításra a hulladékanyagokat, forduljon
a helyi önkormányzathoz, a háztartási hulladék begyűjtésével foglalkozó vállalathoz vagy a termék forgalmazójához.
Latviski
Lietotāju atbrīvošanās no nederīgām ierīcēm Eiropas Savienības privātajās mājsaimniecībās
Šis simbols uz ierīces vai tās iepakojuma norāda, ka šo ierīci nedrīkst izmest kopā ar pārējiem mājsaimniecības atkritumiem. Jūs esat atbildīgs par atbrīvošanos no nederīgās ierīces,
to nododot norādītajā savākšanas vietā, lai tiktu veikta nederīgā elektriskā un elektroniskā aprīkojuma otrreizējā pārstrāde. Speciāla nederīgās ierīces savākšana un otrreizējā pārstrāde
palīdz taupīt dabas resursus un nodrošina tādu otrreizējo pārstrādi, kas sargā cilvēku veselību un apkārtējo vidi. Lai iegūtu papildu informāciju par to, kur otrreizējai pārstrādei var
nogādāt nederīgo ierīci, lūdzu, sazinieties ar vietējo pašvaldību, mājsaimniecības atkritumu savākšanas dienestu vai veikalu, kurā iegādājāties šo ierīci.
Lietuviškai
Europos Sąjungos vartotojų ir privačių namų ūkių atliekamos įrangos išmetimas
Šis simbolis ant produkto arba jo pakuotės nurodo, kad produktas negali būti išmestas kartu su kitomis namų ūkio atliekomis. Jūs privalote išmesti savo atliekamą įrangą atiduodami ją
į atliekamos elektronikos ir elektros įrangos perdirbimo punktus. Jei atliekama įranga bus atskirai surenkama ir perdirbama, bus išsaugomi natūralūs ištekliai ir užtikrinama, kad įranga
yra perdirbta žmogaus sveikatą ir gamtą tausojančiu būdu. Dėl informacijos apie tai, kur galite išmesti atliekamą perdirbti skirtą įrangą kreipkitės į atitinkamą vietos tarnybą, namų ūkio
atliekų išvežimo tarnybą arba į parduotuvę, kurioje pirkote produktą.
Utylizacja zużytego sprzętu przez użytkowników domowych w Unii Europejskiej
Symbol ten umieszczony na produkcie lub opakowaniu oznacza, że tego produktu nie należy wyrzucać razem z innymi odpadami domowymi. Użytkownik jest odpowiedzialny za
dostarczenie zużytego sprzętu do wyznaczonego punktu gromadzenia zużytych urządzeń elektrycznych i elektronicznych. Gromadzenie osobno i recykling tego typu odpadów
przyczynia się do ochrony zasobów naturalnych i jest bezpieczny dla zdrowia i środowiska naturalnego. Dalsze informacje na temat sposobu utylizacji zużytych urządzeń można
uzyskać u odpowiednich władz lokalnych, w przedsiębiorstwie zajmującym się usuwaniem odpadów lub w miejscu zakupu produktu.
Descarte de equipamentos por usuários em residências da União Européia
Este símbolo no produto ou na embalagem indica que o produto não pode ser descartado junto com o lixo doméstico. No entanto, é sua responsabilidade levar os equipamentos
a serem descartados a um ponto de coleta designado para a reciclagem de equipamentos eletro-eletrônicos. A coleta separada e a reciclagem dos equipamentos no momento do
descarte ajudam na conservação dos recursos naturais e garantem que os equipamentos serão reciclados de forma a proteger a saúde das pessoas e o meio ambiente. Para obter mais
informações sobre onde descartar equipamentos para reciclagem, entre em contato com o escritório local de sua cidade, o serviço de limpeza pública de seu bairro ou a loja em que
adquiriu o produto.
Postup používateľov v krajinách Európskej únie pri vyhadzovaní zariadenia v domácom používaní do odpadu
Tento symbol na produkte alebo na jeho obale znamená, že nesmie by vyhodený s iným komunálnym odpadom. Namiesto toho máte povinnos odovzda toto zariadenie na zbernom
mieste, kde sa zabezpečuje recyklácia elektrických a elektronických zariadení. Separovaný zber a recyklácia zariadenia určeného na odpad pomôže chráni prírodné zdroje a
zabezpečí taký spôsob recyklácie, ktorý bude chráni ľudské zdravie a životné prostredie. Ďalšie informácie o separovanom zbere a recyklácii získate na miestnom obecnom úrade,
vo firme zabezpečujúcej zber vášho komunálneho odpadu alebo v predajni, kde ste produkt kúpili.
Ravnanje z odpadno opremo v gospodinjstvih znotraj Evropske unije
Ta znak na izdelku ali embalaži izdelka pomeni, da izdelka ne smete odlagati skupaj z drugimi gospodinjskimi odpadki. Odpadno opremo ste dolžni oddati na določenem zbirnem
mestu za recikliranje odpadne električne in elektronske opreme. Z ločenim zbiranjem in recikliranjem odpadne opreme ob odlaganju boste pomagali ohraniti naravne vire in zagotovili,
da bo odpadna oprema reciklirana tako, da se varuje zdravje ljudi in okolje. Več informacij o mestih, kjer lahko oddate odpadno opremo za recikliranje, lahko dobite na občini,
v komunalnem podjetju ali trgovini, kjer ste izdelek kupili.
Kassering av förbrukningsmaterial, för hem- och privatanvändare i EU
Produkter eller produktförpackningar med den här symbolen får inte kasseras med vanligt hushållsavfall. I stället har du ansvar för att produkten lämnas till en behörig återvinningsstation
för hantering av el- och elektronikprodukter. Genom att lämna kasserade produkter till återvinning hjälper du till att bevara våra gemensamma naturresurser. Dessutom skyddas både
människor och miljön när produkter återvinns på rätt sätt. Kommunala myndigheter, sophanteringsföretag eller butiken där varan köptes kan ge mer information om var du lämnar
kasserade produkter för återvinning.
Изхвърляне на оборудване за отпадъци от потребители в частни домакинства в Европейския съюз
Този символ върху продукта или опаковката му показва, че–продуктът не трябва да се изхвърля заедно с домакинските отпадъци. Вие имате отговорността да изхвърлите
оборудването за отпадъци, като го предадете на определен пункт за рециклиране на електрическо или механично оборудване за отпадъци. Отделното събиране и рециклиране
на оборудването за отпадъци при изхвърлянето му помага за запазването на природни ресурси и гарантира рециклиране, извършено така, че–да не застрашава човешкото
здраве и околната среда. За повече информация къде можете да оставите оборудването за отпадъци за рециклиране се свържете със съответния офис в града ви, фирмата за
събиране на отпадъци или с–магазина, от който сте закупили продукта
Română
Português
Eliminación de residuos de aparatos eléctricos y electrónicos por parte de usuarios domésticos en la Unión Europea
Este símbolo en el producto o en el embalaje indica que no se puede desechar el producto junto con los residuos domésticos. Por el contrario, si debe eliminar este tipo de residuo, es
responsabilidad del usuario entregarlo en un punto de recogida designado de reciclado de aparatos electrónicos y eléctricos. El reciclaje y la recogida por separado de estos residuos
en el momento de la eliminación ayudará a preservar recursos naturales y a garantizar que el reciclaje proteja la salud y el medio ambiente. Si desea información adicional sobre los
lugares donde puede dejar estos residuos para su reciclado, póngase en contacto con las autoridades locales de su ciudad, con el servicio de gestión de residuos domésticos o con la
tienda donde adquirió el producto.
Slovenčina
Smaltimento di apparecchiature da rottamare da parte di privati nell'Unione Europea
Questo simbolo che appare sul prodotto o sulla confezione indica che il prodotto non deve essere smaltito assieme agli altri rifiuti domestici. Gli utenti devono provvedere allo
smaltimento delle apparecchiature da rottamare portandole al luogo di raccolta indicato per il riciclaggio delle apparecchiature elettriche ed elettroniche. La raccolta e il riciclaggio
separati delle apparecchiature da rottamare in fase di smaltimento favoriscono la conservazione delle risorse naturali e garantiscono che tali apparecchiature vengano rottamate
nel rispetto dell'ambiente e della tutela della salute. Per ulteriori informazioni sui punti di raccolta delle apparecchiature da rottamare, contattare il proprio comune di residenza,
il servizio di smaltimento dei rifiuti locale o il negozio presso il quale è stato acquistato il prodotto.
Slovenščina
Entsorgung von Elektrogeräten durch Benutzer in privaten Haushalten in der EU
Dieses Symbol auf dem Produkt oder dessen Verpackung gibt an, dass das Produkt nicht zusammen mit dem Restmüll entsorgt werden darf. Es obliegt daher Ihrer Verantwortung, das
Gerät an einer entsprechenden Stelle für die Entsorgung oder Wiederverwertung von Elektrogeräten aller Art abzugeben (z.B. ein Wertstoffhof). Die separate Sammlung und das
Recyceln Ihrer alten Elektrogeräte zum Zeitpunkt ihrer Entsorgung trägt zum Schutz der Umwelt bei und gewährleistet, dass sie auf eine Art und Weise recycelt werden, die keine
Gefährdung für die Gesundheit des Menschen und der Umwelt darstellt. Weitere Informationen darüber, wo Sie alte Elektrogeräte zum Recyceln abgeben können, erhalten Sie bei
den örtlichen Behörden, Wertstoffhöfen oder dort, wo Sie das Gerät erworben haben.
Svenska
Évacuation des équipements usagés par les utilisateurs dans les foyers privés au sein de l'Union européenne
La présence de ce symbole sur le produit ou sur son emballage indique que vous ne pouvez pas vous débarrasser de ce produit de la même façon que vos déchets courants.
Au contraire, vous êtes responsable de l'évacuation de vos équipements usagés et, à cet effet, vous êtes tenu de les remettre à un point de collecte agréé pour le recyclage des
équipements électriques et électroniques usagés. Le tri, l'évacuation et le recyclage séparés de vos équipements usagés permettent de préserver les ressources naturelles et de s'assurer
que ces équipements sont recyclés dans le respect de la santé humaine et de l'environnement. Pour plus d'informations sur les lieux de collecte des équipements usagés, veuillez contacter
votre mairie, votre service de traitement des déchets ménagers ou le magasin où vous avez acheté le produit.
Български
Disposal of Waste Equipment by Users in Private Households in the European Union
This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment
at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where
you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Polski
Disposal of waste equipment by users in private households in the European Union
124
Înlăturarea echipamentelor uzate de către utilizatorii casnici din Uniunea Europeană
Acest simbol de pe produs sau de pe ambalajul produsului indică faptul că acest produs nu trebuie aruncat alături de celelalte deşeuri casnice. În loc să procedaţi astfel, aveţi
responsabilitatea să vă debarasaţi de echipamentul uzat predându-l la un centru de colectare desemnat pentru reciclarea deşeurilor electrice şi a–echipamentelor electronice.
Colectarea şi reciclarea separată a–echipamentului uzat atunci când doriţi să îl aruncaţi ajută la conservarea resurselor naturale şi asigură reciclarea echipamentului într-o manieră care
protejează sănătatea umană şi mediul. Pentru informaţii suplimentare despre locul în care se poate preda echipamentul uzat pentru reciclare, luaţi legătura cu primăria locală, cu
serviciul de salubritate sau cu vânzătorul de la care aţi achiziţionat produsul.
Regulatory information
Power consumption
Power usage drops significantly while in Sleep mode, which saves natural resources and saves
money without affecting the high performance of this product. To determine the ENERGY STAR®
qualification status for this product see the Product Data Sheet or Specifications Sheet. Qualified
products are also listed at www.hp.com/go/energystar.
Chemical Substances
HP is committed to providing our customers with information about the chemical substances in
our products as needed to comply with legal requirements such as REACH (Regulation EC No
1907/2006 of the European Parliament and the Council). A chemical information report for this
product can be found at: www.hp.com/go/reach
Environmental product stewardship program
125
Appendix D
Third-party licenses
Third-party licenses
Expat
Copyright (c) 1998, 1999, 2000 Thai Open Source Software Center Ltd
Permission is hereby granted, free of charge, to any person obtaining a copy of
this software and associated documentation files (the "Software"), to deal in the
Software without restriction, including without limitation the rights to use, copy,
modify, merge, publish, distribute, sublicense, and/or sell copies of the
Software, and to permit persons to whom the Software is furnished to do so,
subject to the following conditions:
The above copyright notice and this permission notice shall be included in all
copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON
INFRINGEMENT.IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT
HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY,
WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE,
ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR
THE USE OR OTHER DEALINGS IN THE SOFTWARE.
126
Regulatory information
OpenSSL
Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com)
All rights reserved.
This package is an SSL implementation written by Eric Young
(eay@cryptsoft.com). The implementation was written so as to conform with
Netscapes SSL.
This library is free for commercial and non-commercial use as long as the
following conditions are aheared to. The following conditions apply to all code
found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the
SSL code. The SSL documentation included with this distribution is covered by the
same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
Copyright remains Eric Young's, and as such any Copyright notices in the code
are not to be removed. If this package is used in a product, Eric Young should be
given attribution as the author of the parts of the library used. This can be in the
form of a textual message at program startup or in documentation (online or
textual) provided with the package.
Redistribution and use in source and binary forms, with or without modification,
are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the copyright notice, this list of
conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this
list of conditions and the following disclaimer in the documentation and/or
other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must
display the following acknowledgement:
"This product includes cryptographic software written by Eric Young
(eay@cryptsoft.com)"
The word 'cryptographic' can be left out if the rouines from the library being
used are not cryptographic related :-).
4. If you include any Windows specific code (or a derivative thereof) from the
apps directory (application code) you must include an acknowledgement:
"This product includes software written by Tim Hudson (tjh@cryptsoft.com)."
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND ANY EXPRESS
OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT
LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED
AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT
LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN
ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
Third-party licenses
127
Appendix D
The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and
put under another distribution licence [including the GNU Public Licence.]
========================================================
Copyright (c) 1998-2001 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification,
are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list
of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this
list of conditions and the following disclaimer in the documentation and/or
other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must
display the following acknowledgment:
"This product includes software developed by the OpenSSL Project for use in
the OpenSSL Toolkit. (http://www.openssl.org/)"
4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to
endorse or promote products derived from this software without prior written
permission. For written permission, please contact openssl-core@openssl.org.
5. Products derived from this software may not be called "OpenSSL" nor may
"OpenSSL" appear in their names without prior written permission of the
OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following acknowledgment:
"This product includes software developed by the OpenSSL Project for use in
the OpenSSL Toolkit (http://www.openssl.org/)"
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY
EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL
PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
128
Regulatory information
This product includes cryptographic software written by Eric Young
(eay@cryptsoft.com). This product includes software written by Tim Hudson
(tjh@cryptsoft.com).
========================================================
Copyright (c) 1998-2006 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification,
are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list
of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this
list of conditions and the following disclaimer in the documentation and/or
other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must
display the following acknowledgment:
"This product includes software developed by the OpenSSL Project for use in
the OpenSSL Toolkit. (http://www.openssl.org/)"
4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to
endorse or promote products derived from this software without prior written
permission. For written permission, please contact openssl-core@openssl.org.
5. Products derived from this software may not be called "OpenSSL" nor may
"OpenSSL" appear in their names without prior written permission of the
OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following
acknowledgment:
"This product includes software developed by the OpenSSL Project for use in
the OpenSSL Toolkit (http://www.openssl.org/)"
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY
EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL
PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
========================================================
Third-party licenses
129
Appendix D
This product includes cryptographic software written by Eric Young
(eay@cryptsoft.com). This product includes software written by Tim Hudson
(tjh@cryptsoft.com).
========================================================
Copyright 2002 Sun Microsystems, Inc. ALL RIGHTS RESERVED.
ECC cipher suite support in OpenSSL originally developed by
SUN MICROSYSTEMS, INC., and contributed to the OpenSSL project.
SHA2
FIPS 180-2 SHA-224/256/384/512 implementation
Last update: 02/02/2007
Issue date: 04/30/2005
Copyright (C) 2005, 2007 Olivier Gay <olivier.gay@a3.epfl.ch>
All rights reserved.
Redistribution and use in source and binary forms, with or without modification,
are permitted provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list
of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this
list of conditions and the following disclaimer in the documentation and/or
other materials provided with the distribution.
3. Neither the name of the project nor the names of its contributors may be used
to endorse or promote products derived from this software without specific
prior written permission.
THIS SOFTWARE IS PROVIDED BY THE PROJECT AND CONTRIBUTORS ``AS
IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE
PROJECT OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF
THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
130
Regulatory information
Index
A
accessibility
mobility 9
support 9
visual 9
accessories
installation 13
ordering 97
part numbers 97
self-test diagnostic page 41
turning on in printer driver 14
warranty 100
acoustic emissions 115
Add Printer installation 46
administrator
management tools 31
settings 33
after the support period 105
C
calibrate linefeed 64
cancel
print job 29
capacity
trays 20
cards
guidelines 17
sizes supported 19
tray supported 20
cartridges. See ink cartridges
colors
bleeding 72
do not line up 73
printing incorrectly 72
specifications 114
troubleshooting 72
connections
changing Ethernet to
wireless 53
changing USB to wireless
(Mac OS X) 53
changing USB to wireless
(Windows) 52
features available 11
connectors, locating 11
control panel
administrator settings 33
illustration 92
lights, understanding 92
locating 10
customer support
electronic 99
phone support 102
warranty 105
D
Declaration of Conformity
(DOC) 121
device
administer 33
back view 11
configuration page 41
configuring (Mac OS X) 47
configuring (Windows) 43
connection, changing 52
control panel 10
front view 10
getting started 7
lights 92
maintaining 57
management tools 34
monitoring 32
network configuration
report 41
parts 9
printer sharing 12
reinstalling software 54
resources, addtional 7
self-test page 40
sharing (Mac OS X) 47
sharing (Windows) 44
troubleshooting 57
turning off 12
uninstalling software 54
using 15
wireless communication 48
wireless status report 41
DOC. See Declaration of
Conformity
documentation, other
resources 7
dots per inch (dpi)
printing 114
dpi. See dots per inch
driver
version 102
duplexer
clearing jams 86
installation 13
locating 11
margins, minimum 22
paper types and weights
supported 20
paper-sizes supported 18
turning on in printer driver 14
using 25
duty cycle 112
E
electrical specifications. See
specifications
embedded Web server
about 34
administrator settings 33
cannot open 76
opening 34
pages 35
system requirements 114
envelopes
guidelines 17
sizes supported 19
tray supported 20
environmental programs
European Union equipment
disposal 124
material safety data 123
paper use 123
plastics 123
recycling program 123
environmental specifications.
See specifications
Ethernet
connections 11
network port, locating 11
European Union, equipment
disposal 124
131
paper to avoid 17
preventing 87
EWS. See embedded Web
server
F
L
firewalls troubleshooting 68
fonts supported 112
language, printer 112
lights on control panel
illustration 92
understanding 92
loading
tray 1 22
tray 2 23
locking trays 23
H
help. See customer support
HP Company notices 3
HP Printer Utility (Mac OS X)
administrator settings 33
opening 38
panels 39
HP Solution Center 38
I
ink cartridges
expiration dates 41
lights 92
ordering online 97
part numbers 41, 98
recycling 123
removing 107
replacing 58
status 32, 41
storing 66
supported 57, 112
warranty 100
yields 112
installation
accessories 13
Add Printer (Windows) 46
duplexer 13
hardware installation
suggestions 83
ink cartridges 58
software (Mac OS X) 47
software (Windows) 43
software installation
suggestions 84
tray 2 13
troubleshooting issues 83
Windows network
software 44
IP address
checking for device 76
static setting 67
J
jams
clearing 86
132
M
Mac OS X
borderless printing 28
HP Printer Utility 38
installing software 47
printing on special or
custom-sized paper 27
printing settings 25
sharing device 47
turning accessories on in
printer driver 14
uninstalling software 55
wireless communication
setup 50
management tools 31
margins
duplexer 22
setting, specifications 21
media. See paper
memory
specifications 112
model number 41
monitoring tools 32
N
networks
connector illustration 11
Ethernet connections 11
firewalls troubleshooting 68
Mac OS X setup 47
operating systems
supported 113
printer information 40
protocols supported 113
sharing (Mac OS X) 47
sharing (Windows) 44
solve problems 77, 84
static IP address, setting 67
system requirements 114
Windows setup 44
wireless communication
setup 48
wireless settings 49
noise information 115
O
operating environment
specifications. See
specifications
operating systems
supported 112
output tray
locating 10
paper supported 21
P
packing the device 109
pages per month (duty
cycle) 112
paper
borderless printing 28
clearing jams 86
duplexing 25
feeding troubleshooting 75
guidelines, custom-sized 18
loading tray 1 22
loading tray 2 23
locking trays 24
multiple pages are picked 75
not supported 74
ordering 98
paper-feed problems 74
printing on custom-sized 27
selecting 17
sizes supported, customsized 20
skewed pages 75
specifications 18
supported sizes 18
types and weights
supported 20
paper jams. See jams
paper-feed problems
multiple pages are picked 75
paper 75
paper not supported 74
paper stops halfway 74
recurring 74
skewed pages 75
tray 2 troubleshooting 74
PCL 3 support 112
Index
phone customer support 102
phone support 103
phone support period
period for support 103
photo paper
sizes supported 20
photos
borderless printing 28
paper guidelines 18
ports, specifications 112
power
locating input 11
power consumption 114
power requirements 114
power supply 114
troubleshooting 67
print cartridges. See ink
cartridges
print driver
version 102
printer driver
accessories settings 14
settings 24
version 102
warranty 100
printheads
aligning 61
cleaning 61
cleaning contacts
manually 62
diagnostic page, printquality 59
health check 59
lights 92
maintaining 59
ordering online 97
part numbers 98
print-quality
troubleshooting 59
removing 107
replacing 64
status 32, 41, 59
storing 66
supported 112
warranty 100
printing
borderless (Mac OS X) 28
borderless (Windows) 28
cancel 29
diagnostic page, printquality 59
double-sided 25
print-quality
troubleshooting 59
quality troubleshooting 70
resolution 114
settings 24
slow 68
troubleshooting 67
Web pages 29
processor specifications 112
product. See device
R
radio interference. See
regulatory information
readme 7
rear access panel
clearing jams 86
illustration 11
recycling
ink cartridges 123
program 123
regulatory information
Declaration of
Conformity 121
environmental stewardship
program 123
FCC statement 116
Japan 117
Korea 117
power cord, Japan 117
radio frequency
exposure 118
regulatory model
number 120
toxic and hazardous
substance 117
wireless devices 118
release notes 7
replacing
ink cartridges 58
printheads 64
resolution, printing 114
S
safety information 3
security
wireless communication 53
wireless settings 49
serial number 41
Services tab, Toolbox
(Windows) 37
settings
administrator 33
printer driver 24
printing, default 25
setup
connection types 11
Windows 43
Windows networks 44
shipping the device 107
software
accessories settings 14
connection types 11
installation (Mac OS X) 47
installation (Windows) 43
management tools 31
uninstalling (Mac OS X) 55
uninstalling (Windows) 54
warranty 100
Solution Center 38
specifications
acoustic emissions 115
electrical 114
environmental 114
humidity 114
network protocols 113
operating conditions 114
operating environment 114
paper 18
physical 111
power consumption 114
power requirements 114
power supply 114
processor and memory 112
storage environment 114
system requirements 112
temperature 114
status
self-test diagnostic page 41
supplies 32
storage environment
specifications. See
specifications
supplies
ordering online 97
self-test diagnostic page 41
status 32
storing ink cartridges 66
storing printheads 66
yields 112
support. See customer support
support process 102
system requirements 112
133
T
telephone customer support 102
Toolbox (Windows)
about 36
administrator settings 33
Estimated Ink Level tab 37
opening 36
Services tab 37
transparencies 18
tray 1
capacity 20
loading paper 22
locating 10
paper types and weights
supported 20
paper-sizes supported 18
tray 2
capacity 20
installation 13
installation
troubleshooting 74
loading paper 23
locating 10
paper types and weights
supported 20
paper-sizes supported 18
turning on in printer driver 14
trays
capacities 20
clearing jams 86
feeding troubleshooting 75
installation tray 2 13
loading paper 22
locating 10
locking 23
paper guides illustration 10
paper types and weights
supported 20
paper-sizes supported 18
setting default 23
turning on in printer driver 14
troubleshooting
colors 72
colors do not line up 73
colors, bleeding 72
colors, incorrect 72
embedded Web server 76
firewalls 68
hardware installation
suggestions 83
incomplete text or
graphics 72
ink smearing 71
134
installation issues 83
lights 68, 92
missing or incorrect
information 74
multiple pages are picked 75
nothing prints 67
paper 75
paper not picked up from
tray 75
paper stops halfway 74
paper-feed problem,
recurring 74
paper-feed problems 74
power 67
printing 67
printing quality 70
random characters 71
resources, self-test page 40
skewed pages 75
slow printing 68
software installation
suggestions 84
solve network problems 77,
84
streaked, text or graphics 74
text or graphic placement 69
tips 66
tray 2 installation 74
wireless problems 77
two-sided printing 26
two-sided printing accessory.
See duplexer
U
uninstalling software
Mac OS X 55
Windows 54
USB connection
features available 11
port, locating 10, 11
setup (Mac OS X) 47
setup Windows 43
specifications 112
V
voltage specifications. See
specifications
W
warranty
limited warranty
statement 100
Web sites
accessibilty information 9
Apple 48
customer support 99
environmental
programs 123
ordering supplies and
accessories 97
resources, addtional 7
supply yield data sheet 112
wireless security 49
Windows
Add Printer installation 46
borderless printing 28
duplexing 26
HP Solution Center 38
installing software 43
network setup 44
printing on special or
custom-sized paper 27
printing settings 25
set up wireless
communication 50
sharing device 44
system requirements 112
turning accessories on in
printer driver 14
uninstalling software 54
wireless communication
802.11 network settings 49
ad hoc connection 51
advanced wireless
troubleshooting 78
basic wireless
troubleshooting 78
firewall 51
regulatory information 118
security 53
set up 48
set up, installer (Mac OS
X) 50
set up, installer
(Windows) 50
turning off 51
© 2009 Hewlett-Packard Development Company, L.P.
www.hp.com/support
Podręcznik użytkownika
