Basic Operation Guide
For information about machine setup and software
installation, see Getting Started.
This guide describes the basic use of
the machine. Read this guide after
finishing the machine setup.
Read Important Safety Instructions
first (→p.113).
Keep this manual for future reference.
For information about advanced operations and
specifications, see the e-Manual included on the User
Software CD-ROM.
Manuals for the Machine
Getting Started
Getting Started describes setting up the machine and installing the software.
Be sure to read this manual before using the machine.
Wireless LAN Setting Guide
Wireless LAN Setting Guide describes the wireless LAN setup procedures and the causes
and solutions for troubles you might face during setup. Be sure to read this manual when
connecting the machine to a wireless LAN.
Basic Operation Guide
This Manual
Basic Operation Guide describes common use and basic functions of the copy, fax,
scan, and print functions.
e-Manual
The e-Manual includes information about all functions and configurations of the machine.
This manual is included on the User Software CD-ROM. Use the e-Manual’s search function
to easily find the information you want.
MF Driver Installation Guide
MF Driver Installation Guide describes how to install the MF Drivers, MF Toolbox, and
software included on the User Software CD-ROM.
For Macintosh Users
The examples shown in this manual are based on the operation in the Windows environment.
To view how to use printer driver, fax driver, and scanner driver, refer to the driver guides
included in the User Software CD-ROM and the driver’s help.
Displaying Driver Guides
To view the Driver Guides, double-click the HTML files from the following folders on the User
Software CD-ROM.
• Canon MF Printer Driver Guide  [Documents]  [us_eng] [Print]  [Guide] 
[index.html]
• Canon Fax Driver Guide  [Documents]  [us_eng]  [Fax]  [Guide]  [index.html]
• Canon Scanner Driver Guide  [Documents]  [us_eng]  [Scan]  [Guide]  [index.html]
Displaying from Driver’s Help System
From each driver panel, click [ 2
]
Send Setting Guide (MF8580Cdw Only)
Send Setting Guide describes how to use the Send Function Setting Tool to set up the
machine for scanning documents as e-mails (Send to E-mail) and scanning documents to
shared folders (Store to Shared Folder).
How to Use This Manual
Symbols Used in This Manual
Indicates a situation that may lead to death or injury to persons.
WARNING To use the machine safely, always pay attention to these warnings.
CAUTION
Indicates a situation that may lead to injury to persons or damage to
equipment. To use the machine safely, always pay attention to these
cautions.
Indicates an operation that must not be performed. Read these items
carefully, and make sure not to perform the described operations.
IMPORTANT
Indicates operational requirements and restrictions. Be sure to read
these items carefully to operate the machine correctly and avoid
damage to the machine or property.
Indicates a clarification of an operation or additional explanations for a
procedure. Reading these notes is highly recommended.
Keys and Buttons Used in This Manual
In this manual, the following styles are used to represent keys, messages on the display, and
buttons or other items on a computer screen.
• Operation panel keys:
[Key icon]
[Key icon] + (Key name)
Example:
[ ]
[ ] (Back)
• Display: <Message>
Example: <Specify the destination.>
• Buttons and items on a computer screen: [Item]
Example: [Preference]
Illustrations Used in This Manual
Illustrations of the MF8580Cdw are used in this manual. If a procedure or topic applies to
only one machine, this will be clearly indicated in the manual (for example, “MF8280Cw”).
Displays Used in This Manual
The display shown in this manual is the factory preset display for the MF8580Cdw.
Depending on the system configuration and product purchased, the appearance of the
display may differ.
3
Main Functions
Adjusting Quality
Adjust image quality by setting the
density, resolution, and sharpness.
•Copy → P.31
•Fax → P.52
Enlarging and Reducing
•Copy → P.31
•Print → P.40
Multiple Documents onto
Single Page
Print multiple pages onto a single page.
•Copy → P.34
•Print → P.42
2-Sided Printing*
Print copies, received faxes, or
documents on both sides of paper.
•Copy → P.33
•Print → P.41
•Fax → P.69
* MF8580Cdw only
4
Copy
1
2
3
1
2
3
1
2
3
2
2
2
3
3
3
<On>
1
1
1
<Off>
Collating Copies → P.35
Collate copies when copying multiple documents.
Copying ID Card → P.35
Copy both sides of an ID card onto a single page.
Print
Booklet Printing* → P.43
Poster Printing → P.44
page, and then print on both sides.
• Make a booklet by folding printouts
in half and binding.
image to print on multiple sheets of
paper.
• Make a poster by combining the
prints together.
• Combine two pages onto a single
• Magnify and divide a single-paged
Watermark Printing → P.45
Add watermarks, such as “COPY” or
“DRAFT”, to the document.
Scan
Scanning using the Operation Panel → P.75
Select a computer to save scanned images in and scan
images directly from the operation panel.
Remote Scanning from Computers → P.78
Set to use the remote scan from the machine, and then
scan images from a computer using MF Toolbox.
Fax
Favorites/Coded Dial/
Group Dial → P.48
Specify destination using Favorites,
Coded Dial, and Group Dial.
Receiving in the Memory → P.64
• Store received faxes in the memory.
• Print or forward the received fax after
confirming the sender.
Sequential Broadcasting →
P.58
Send the same document to multiple
destinations at a time.
* MF8580Cdw only
5
Contents
Basic Operation
Learn the Names and Functions of Each Part of the Machine… ………
Front Side and Interior… ………………………………………………
Back Side… ……………………………………………………………
Learn the Functions of the Operation Panel… …………………………
Switch to Copy/Fax/Scan/USB Print Mode………………………………
Enter Text… ……………………………………………………………
Set Date and Time… ……………………………………………………
Place Documents… ……………………………………………………
Placing Documents on the Platen Glass… ……………………………
Placing Documents in the Feeder………………………………………
Load Paper… ……………………………………………………………
Loading Paper in the Paper Drawer… …………………………………
Loading Paper in the Manual Feed Slot … ……………………………
Loading Envelopes or Paper with a Letterhead…………………………
Setting a Paper Size and Type… ………………………………………
Switch to the Sleep Mode… ……………………………………………
10
10
12
13
15
16
17
18
19
19
20
21
23
25
27
28
Copy
Make a Basic Copy… ……………………………………………………
Copy by Saving Paper……………………………………………………
Enlarge or Reduce Copies… ……………………………………………
Adjust the Image Quality for Copy………………………………………
Adjusting the Density… ………………………………………………
Selecting the Document Type… ………………………………………
Adjusting the Sharpness… ……………………………………………
Make Double-Sided Copies (MF8580Cdw Only)… ……………………
Copy Multiple Pages onto One Sheet… ………………………………
Collate Copies……………………………………………………………
Copy a Double-Sided ID Card……………………………………………
Erase Dark Borders and Frame Lines of Copies… ………………………
View and Cancel Copy Jobs… …………………………………………
Change the Default Copy Settings………………………………………
6
30
30
31
31
31
32
32
33
34
35
35
36
36
37
Print
Print a Document… ……………………………………………………
Enlarge or Reduce a Document…………………………………………
Print a Double-Sided Document (MF8580Cdw Only)… ………………
Print Multiple Pages onto One Sheet……………………………………
Print a Booklet (MF8580Cdw Only)………………………………………
Print a Poster… …………………………………………………………
Add Watermarks to a Printout… ………………………………………
View and Cancel Print Jobs………………………………………………
40
40
41
42
43
44
45
46
Fax
(→ p.109)
You can see frequently asked
questions about the receive mode.
Register Destinations in the Address Book… …………………………
Registering Destinations in Favorites……………………………………
Registering Destinations in Coded Dial…………………………………
Registering Multiple Destinations for Group Dial… ……………………
Editing and Deleting Registered Destinations… ………………………
Adjust the Image Quality for Fax… ……………………………………
Adjusting the Density… ………………………………………………
Selecting the Resolution… ……………………………………………
Adjusting the Sharpness… ……………………………………………
Specifying the Double-Sided Document Format (MF8580Cdw Only)……
Changing the Default Settings… ………………………………………
Send a Fax… ……………………………………………………………
Entering a Fax Number with the Numeric Keys…………………………
Selecting from Favorites… ……………………………………………
Selecting with Coded Dial………………………………………………
Selecting from Group Dial………………………………………………
Searching by Name for Destinations……………………………………
Redialing… ……………………………………………………………
Sending a Fax to Multiple Destinations (Sequential Broadcast)… ………
Sending a Fax to an International Destination (Adding Pauses)…………
Calling a Recipient before Sending a Fax… ……………………………
Receive a Fax (Receive Mode)……………………………………………
Using the Machine for Fax Only…………………………………………
Using the Machine for Faxing and Phoning… …………………………
Using the Answering Machine… ………………………………………
Using the Machine Primarily for Phoning… ……………………………
Receiving Faxes in Manual Mode ………………………………………
Receive a Fax from Memory… …………………………………………
Switching to Memory Lock Mode………………………………………
Viewing and Canceling Received Fax Documents………………………
Printing Received Fax Documents………………………………………
View and Cancel a Fax Job………………………………………………
Change the Fax Settings…………………………………………………
Changing Fax Sending Settings…………………………………………
Restricting Fax Sending Functions………………………………………
Changing Fax RX Settings………………………………………………
Changing Communication Management Settings… …………………
48
48
49
50
52
52
52
53
53
54
54
55
55
56
56
56
57
57
58
58
59
60
61
61
62
63
63
64
64
65
65
66
66
66
68
69
70
7
Scan
(→ p.109)
You can see frequently asked
questions about the scan function.
Understand the Scanning Method………………………………………
Scan a Document with the Operation Panel……………………………
Scanning a Document Using a Shortcut Key……………………………
Scan a Document with MF Toolbox… …………………………………
Configuring Scan Settings Using MF Toolbox… ………………………
Scan a Document with the Scanner Driver… …………………………
74
75
77
78
80
82
Maintenance and Management
Clean the Machine… ……………………………………………………
Cleaning the Exterior……………………………………………………
Cleaning the Platen Glass… ……………………………………………
Cleaning the Feeder……………………………………………………
Cleaning the Fixing Unit… ……………………………………………
Cleaning the Transfer Belt………………………………………………
Check and Replace Toner Cartridges……………………………………
Checking the Toner Level… ……………………………………………
Replacing Toner Cartridges… …………………………………………
Manage Using the Report and List Functions… ………………………
Configure Settings Using the Remote UI… ……………………………
84
84
84
85
85
85
86
86
87
90
91
Troubleshooting
Clear Jams… ……………………………………………………………
Resolve a Displayed Message……………………………………………
Resolve an Error Code……………………………………………………
Improve Output Quality…………………………………………………
Resolve a Problem… ……………………………………………………
94
105
106
107
108
FAQ……………………………………………………………………… 109
If a Power Failure Occurs…………………………………………………
Recycling Used Cartridges………………………………………………
The Clean Earth Campaign………………………………………………
Important Safety Instructions… ………………………………………
Legal Notices… …………………………………………………………
Laser Safety………………………………………………………………
8
112
112
112
113
115
118
Basic Operation
This chapter describes overall information about the machine, and how to
place the documents and load the paper. Read this chapter first.
Learn the Names and Functions of Each Part of the Machine… ………
Front Side and Interior… ………………………………………………
Back Side… ……………………………………………………………
Learn the Functions of the Operation Panel… …………………………
Switch to Copy/Fax/Scan/USB Print Mode………………………………
Enter Text… ……………………………………………………………
Set Date and Time… ……………………………………………………
Place Documents… ……………………………………………………
Placing Documents on the Platen Glass… ……………………………
Placing Documents in the Feeder………………………………………
Load Paper… ……………………………………………………………
Loading Paper in the Paper Drawer… …………………………………
Loading Paper in the Manual Feed Slot … ……………………………
Loading Envelopes or Paper with a Letterhead…………………………
Setting a Paper Size and Type… ………………………………………
Switch to the Sleep Mode… ……………………………………………
10
10
12
13
15
16
17
18
19
19
20
21
23
25
27
28
9
Learn the Names and Functions of Each Part of the Machine
Front Side and Interior
MF8580Cdw
MF8280Cw
Feeder
Automatically feeds documents into the
machine (→p.19).
Speaker
Operation panel
Emits sounds produced by the
machine.
Use the panel to control the machine
(→p.13).
Front cover
Ventilation slots
Open the cover to replace toner
cartridges or clear paper jams.
Allows heat to escape from inside
of the machine.
Power switch
Paper drawer
Turns the power ON or OFF.
Load paper here (→p.21).
MF8580Cdw
MF8280Cw
10
Paper guides
Adjust these guides to fit the paper.
Press the levers that are marked with
arrows in the illustrations to release the
locks and slide the paper guides.
Lock release lever (for extending
the paper drawer)
Press to release the lock and extend the
length of the paper drawer for Legal
size paper.
Basic Operation
Platen glass
Used to scan non-standard size
paper or books, as well as standard
size paper (→p.19).
Scanning area
Scans documents from the feeder.
USB memory port
Lift handles
Connect a USB memory device to
print or to save documents.
Hold these handles to lift or
transport the machine.
MF8580Cdw
Output tray
Printed paper is output here.
Toner cartridge tray
Install the toner cartridges (→p.87).
MF8280Cw
Manual feed slot
Manual feed transport guide
Lower the guide to remove the
jammed paper.
MF8580Cdw
MF8280Cw
Load paper manually (→p.23).
MF8580Cdw
MF8280Cw
Paper guides
Adjust these guides
to fit the paper.
Tray extension
Open the tray extension to load
paper larger than Letter size.
Paper tray
Pull out the auxiliary tray to load
paper.
11
Back Side
MF8580Cdw
MF8280Cw
External telephone jack
Ventilation slots
Connect an external telephone.
Allows heat to escape from
inside of the machine.
USB port
Connect to a computer via
a USB cable.
Rear cover
Open this cover to clear
paper jams (→p.98, 99).
LAN port
Connect to a network via a
LAN cable.
Telephone line jack
Connect a telephone line.
Rating label
Power socket
Connect the power cord.
The machine’s serial number (consists of eight
alphanumeric characters) is specified.
Write the serial number on the back
cover of this guide for reference when
contacting the Canon Customer Care
Center.
12
Function selection keys
Press to active the copy, fax, scan, or USB
Print functions (→p.15).
Address Book
Press to search for recipients registered in the Address
Book (→p.56).
Coded Dial
Press to enter a recipient’s Coded Dial number (→p.56).
Basic Operation
Learn the Functions of the Operation Panel
Display
Multi-function keys
(left/right)
Press to select or apply
the item or to proceed
to further operations.
Select Paper/Settings
Press to specify paper size and type for the
paper drawer or manual feed slot (→p.27).
Navigate the menu or options.
See “Navigating the Menu” (→p.14).
Reset
OK
▲/▼
◄/►
Back
Press to return to the standby mode.
Press to apply settings or specified details.
Press to scroll up and down, or to increase or decrease a value.
• Press to return to the previous screen, proceed to the next
screen, or move the cursor to the left or right.
• Press to decrease or increase the fax ring volume.
Press to return to the previous screen.
Processing/Data
Indicator
The indicator blinks while sending or receiving data
and remains lit when jobs are waiting in memory.
Wi-Fi Indicator
Lights up when the machine is connected to
wireless LAN.
Error Indicator
The indicator blinks or lights up when an error
occurs.
13
Menu
Press to access menu functions (see “Navigating the Menu” at the bottom of this page).
Report
Press to manually print reports and lists (→p.90).
Status Monitor Press to view or cancel jobs. You can also check the status of the machine (→p.36, p.46, p.66).
Energy Saver
Press to manually set or cancel the Sleep mode. The Energy Saver indicator lights yellow green
while in the Sleep mode.
Press to log on when Department ID Management is enabled. For details, see [Basic
Operations]  [Logging on to the Machine] in the e-Manual.
ID
Scan>PC1/Scan>PC2
Press to send the scanned documents to
the registered computer for each key.
Paper Save Copy
Press to copy with a preset setting to save
paper.
Secure Print (MF8580Cdw only)
Press to print Secure Print documents.
For details, see [Using the Machine as a
Printer]  [Printing from a Computer]
 [Printing a Document Secured by a
PIN (Secure Print) (MF8580Cdw Only)]
in the e-Manual.
Enter letters and numbers (→p.16).
0 to 9
(Numeric Press to enter letters and numbers.
Keys)
• Press to switch the character entry mode.
*
• When sending a fax, press to switch
between pulse and tone dialing.
#
Clear
Start (B&W/
Color)
Stop
Press to enter symbols.
Press to delete letters and numbers.
Press to start scanning or copying.
Press to cancel jobs.
Navigating the Menu
Example: Change the current date and time
Press [
] (Back) or [◄] to
return to the previous screen.
Press [ ].
Press [▲] or [▼] to highlight
an item, and then press [OK].
Press [▲] or [▼] to highlight
an item, and then press [OK].
If you close the menu before you press [OK], the changes made to the
settings are not saved.
14
Press [◄], [►], [▲], or [▼] to
specify the date and time,
and then press <Apply>.
Press [
setting.
] to save the
Basic Operation
Switch to Copy/Fax/Scan/USB Print Mode
Switch to Copy, Fax, Scan, or USB Print mode first to use each mode.
Press the desired mode key.
If you do not operate the machine for a while, the machine
returns to the Copy mode (standby mode) automatically.
Copy Mode
Displays the copy ratio, paper source,
paper size, and number of copies.
To change the settings:
1. Press [▲] or [▼] to highlight an item, and then press [OK].
2. Press [▲], [▼], [◄] or [►] to specify the values, and then press [OK].
Fax Mode
Displays the recipient’s number.
To change the settings:
1. Press [▲] or [▼] to highlight an item, and then press [OK].
2. Press [▲], [▼], [◄] or [►] to specify the values, and then press [OK].
Scan Mode
To select the scan method:
Press [▲] or [▼] to highlight an item, and then press [OK].
USB Print
Mode
To select the printing method:
Press [▲] or [▼] to highlight an item, and then press [OK].
• If you use the Fax mode for the first time:
Fax setup guide will appear on the display. Refer to the on-screen instructions and Getting Started to configure the settings.
• To set a frequently used mode to the standby mode:
Press [ ]  <Preferences>  <Display Settings>  <Default Screen after Startup/Restoration>
 Select the screen  [OK]  [ ].
• To specify how long the machine waits before returning to the standby mode:
Press [ ]  <Timer Settings>  <Auto Reset Time>  Specify the time  <Apply>  [ ].
15
Enter Text
Enter characters with the numeric keys.
To switch entry modes:
Press [ ] or <A/a/12> repeatedly.
<A>
Uppercase alphabetic letters and symbols
<a>
Lowercase alphabetic letters and symbols
<12>
Numbers
• Press to move the cursor.
• To enter a space, move the
cursor to the end of the text,
and then press [►].
To enter text, symbols, and numbers:
Press a key several times until the desired character is
displayed.
Key
Entry mode:
<A>
Entry mode:
<a>
Entry mode:
<12>
@.-_/
• Press to delete the last
character.
1
ABC
abc
2
DEF
def
3
GHI
ghi
4
JKL
jkl
5
MNO
mno
6
PQRS
pqrs
7
TUV
tuv
8
WXYZ
wxyz
9
(Not available)
0
(space) @ . / - _ ! ? & $ % # ( ) [
]{}<>*+=“,;:‘^`|~
(Not available)
• Press and hold to delete
all text.
Example: Enter “CANON1”
16
Press [*] to switch the entry
mode to <A>.
Press [2] until the letter “C”
appears on the screen.
Press [2] until the letter “A”
appears on the screen.
Press [6] until the letter “N”
appears on the screen.
Press [6] until the letter “O”
appears on the screen.
Press [6] until the letter “N”
appears on the screen.
Press [*] to switch the entry
mode to <12>.
Press [1] to enter “1.”
Basic Operation
Set Date and Time
If the incorrect date or time is printed on faxes or reports, change the date and time
settings.
1 Press [ ].
2 Press [▲] or [▼] to highlight <Timer Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Date/Time Settings>, and then press [OK].
4 Press [▲] or [▼] to highlight <Current Date/Time Settings>, and then
press [OK].
• To change the display format for the date or time, specify <Date Format> or <Time
Format>.
• To use daylight savings time, set <Daylight Saving Time Settings> to <On>, and
then specify the starting date and the ending date.
5 Press [▲] or [▼] to set the date and time, and then press <Apply>.
• To move the cursor, press [◄] or [►].
• To switch between <AM> or <PM>, press [▲] or [▼].
6 Press [
] to close the screen.
17
Place Documents
Choose the appropriate way to place documents according to the document’s type.
When placing non-standard documents
such as heavy paper, small paper, or
booklets:
Check available documents
11 3/4" (297 mm)
8 1/2"
(215.9 mm)
Size (Width X Length)
Maximum
Weight
Maximum 4.4 lb (2 kg)
Capacity
1 sheet
Use the platen glass (→p.19).���
When placing multiple documents
of plain paper in the same size,
thickness, and weight:
Check available documents
14" (355.6 mm)
Size (Width X Length)
Weight
Capacity (For 21 lb
Bond [80 g/m²])
5" (128 mm)
5 1/2"
(139.7 mm)
Min.
Max.
8 1/2"
(215.9 mm)
12 to 28 lb Bond (50 to 105 g/m²)
50 sheets
Use the feeder (→p.19).���
IMPORTANT
• Place a document after glue, ink, or correction fluid on the document is completely dry.
• To prevent paper jams in the feeder, place a document on the platen glass when using the following types of
paper:
--------
18
Wrinkled or creased paper
Carbon paper or carbon-backed paper
Curled or rolled paper
Torn paper
Onion skin or thin paper
Documents with staples or paper clips attached
Transparency
Basic Operation
Placing Documents on the Platen Glass
1 Open the feeder.
2 Place your document face down.
3 Align the upper left edge of your document with the arrow mark.
• If the document is a transparency, place white paper above the document.
CAUTION
When closing the
feeder, be careful not to
get your fingers caught.
4 Close the feeder.
Placing Documents in the Feeder
1 Spread the document guides a little wider than the document’s width.
• When placing large documents, pull out the tray extension.
2 Fan the document stack and align the edges of the pages.
Thoroughly fan the
paper in small batches.
Align the edges a few
times on a flat surface.
19
3 Neatly place the documents face up.
• Make sure that the paper stack does not exceed the load limit marks (
).
4 Align the document guides tightly to the width of the document.
• If the document guides are too loose or too tight, this may result in
IMPORTANT
misfeeds or paper jams.
• While scanning documents, do not add or remove documents.
• When scanning is complete, remove the document to avoid paper jams.
Load Paper
Before loading paper, check the paper is the right type. If you load inappropriate paper
repeatedly, this may cause paper jams.
Step
1
Check if the type of paper is appropriate.
Paper such as Legal, Letter, Statement, Executive, and envelopes can be used. For details
about the available paper or precautions, see [Basic Operations]  [Loading Paper] in
the e-Manual.
To prevent paper jams, do not use any of the following:
• Wrinkled or creased paper
• Curled or rolled paper
• Torn paper
• Damp paper
• Very thin paper
• Paper printed with a thermal transfer printer
(Do not copy on the reverse side.)
• Highly textured paper
• Very smooth paper
• Glossy paper
20
2
Select where to load paper, and then load the paper.
Basic Operation
Step
• Use the manual feed slot when loading a sheet of small-sized paper or heavy
paper (→p.23).
• Use the paper drawer when loading a stack of plain paper in the
same size, thickness, and weight (→p.21).
Check if the type of paper is appropriate.
If the setting is different from the size of the loaded paper, an error message
appears, or printing is not performed correctly.
Loading Paper in the Paper Drawer
This section describes how to load letter paper in the paper drawer. When loading
envelopes or paper with a letterhead, see "Loading Envelopes or Paper with a Letterhead"
(→p.25).
IMPORTANT
Make sure to load the paper in portrait orientation, as shown in the
illustration below.
1 Pull out the paper drawer.
21
2 Slide the paper guides apart.
• Press the lock release lever (
) to slide the paper guides ( ) outward. On the
MF8280Cw, there is no lock release lever for the side paper guides.
For details about loading Legal (LGL) size paper, see [Basic Operations]
 [Loading Paper]  [Loading Paper in the Paper Drawer] in the
e-Manual.
3 Gently load the paper into the paper drawer with the print side face up,
until the edge of the paper stack meets the back of the paper drawer.
• Make sure that the paper stack does not exceed the load limit marks ( ).
4 Adjust the paper guides tightly to the width and length of the paper.
• Press the lock release lever
and slide the paper guides
aligned securely against the edges of the paper.
inward until they are
IMPORTANT
If the paper guides are too loose or too tight, this may result in misfeeds
or paper jams.
5 Insert the paper drawer into the machine.
6 Specify the loaded paper size and type (→p.27).
22
Basic Operation
Loading Paper in the Manual Feed Slot
MF8580Cdw
1 Open the cover.
2 Pull out the paper tray and the tray extension.
3 Spread the paper guides apart.
4 Insert the paper into the manual feed slot until the paper stops.
5 Align the paper guides against the edges of the paper.
IMPORTANT
If the paper guides are too loose or too tight, this may result in misfeeds
or paper jams.
6 Specify the loaded paper size and type (→p.27).
23
MF8280Cw
1 Spread the paper guides apart.
2 Gently load the paper into the paper drawer with the print side face up,
and adjust the paper guides tightly to the width of the paper.
IMPORTANT
If the paper guides are too loose or too tight, this may result in misfeeds
or paper jams.
3 Specify the loaded paper size and type (→p.27).
24
Basic Operation
Loading Envelopes or Paper with a Letterhead
This section describes how to load envelopes and paper with a letterhead.
Envelopes
Before Loading
Flatten envelopes
to release any
remaining air.
Loosen any stiff corners of the
envelopes, and flatten any
curls, as shown in the figure.
Loading Orientation
Load the envelopes with the non-glued side (front side) face up.
In the Paper Drawer
Close the flap and load
the envelope.
In the Manual Feed Slot
MF8580Cdw
Close the flap and load
the envelope.
MF8280Cw
Close the flap and load
the envelope.
25
Paper with a Letterhead or Logo
Loading Orientation
Load the paper properly by following the instructions below.
In the Paper Drawer
In the Manual Feed Slot
MF8580Cdw
MF8280Cw
ABC
When printing with
portrait layout
2-sided printing (MF8580Cdw only)
Load the paper with the printed side
face down.
ABC
1-sided printing
Load the paper with the printed
side face up.
When printing with
landscape layout
When printing with When printing with
portrait layout
landscape layout
If <Print Side Priority> is selected, load the paper with the printed
side face down regardless of 1-sided or 2-sided printing. For details, see
[Setting Menu List]  [Common Settings]  [Switch Paper Feed
Method] in the e-Manual.
26
Basic Operation
Setting a Paper Size and Type
Make sure that the Paper Settings match the size and the type of the loaded paper.
1 Press [ ] (Select Paper/Settings).
2 Press [▲] or [▼] to highlight <Paper Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Drawer 1> or <Drawer 2>, and then press
[OK].
4 Press [▲] or [▼] to highlight the desired paper size, and then press [OK].
• To specify the paper size manually, select <Custom>, and then refer to
“Specify a Paper Size Manually” at the bottom of this page to specify the size.
5 Press [▲] or [▼] to highlight the desired paper type, and then press [OK].
6 Press [
] (Select Paper/Settings) to close the screen.
Specify a Paper Size Manually
For paper size, specify within the possible range of length and width (<Y> ≥ <X>).
1 Press [▲] or [▼] to highlight <X>, and then press [OK].
2 Press [▲] or [▼] to specify the width, and then press [OK] or <Apply>.
3 Press [▲] or [▼] to highlight <Y>, and then press [OK].
4 Press [▲] or [▼] to specify the length, and then press [OK] or <Apply>.
5 Press [▲] or [▼] to highlight <Apply>, and then press [OK].
27
Switch to the Sleep Mode
You can switch to and cancel the Sleep mode, by pressing [ ].
When the Processing/Data indicator is lit or blinking, the machine will not enter the
Sleep mode, because an operation is in progress or an error has occurred.
By default, the machine automatically enters the Sleep mode if you do not
perform any functions for 10 minutes for MF8580Cdw, or 20 minutes for
MF8280Cw. To change this setting, press [ ]  <Timer Settings> 
<Auto Sleep Time>  specify a time  <Apply>  [
].
28
Copy
This chapter describes basic copy functions.
Make a Basic Copy… ……………………………………………………
Copy by Saving Paper……………………………………………………
Enlarge or Reduce Copies… ……………………………………………
Adjust the Image Quality for Copy………………………………………
Adjusting the Density… ………………………………………………
Selecting the Document Type… ………………………………………
Adjusting the Sharpness… ……………………………………………
Make Double-Sided Copies (MF8580Cdw Only)… ……………………
Copy Multiple Pages onto One Sheet… ………………………………
Collate Copies……………………………………………………………
Copy a Double-Sided ID Card……………………………………………
Erase Dark Borders and Frame Lines of Copies… ………………………
View and Cancel Copy Jobs… …………………………………………
Change the Default Copy Settings………………………………………
30
30
31
31
31
32
32
33
34
35
35
36
36
37
29
Make a Basic Copy
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Enter the desired copy quantity (1 to 99) with the numeric keys.
• Press [
] to delete the entered copy quantity.
4 Press [ ].
For details about specifying the paper source that contains the paper you
want to use, see [Copying]  [Basic Copy Operations]  [Selecting
Copy Paper] in the e-Manual.
Canceling Copy Jobs
1 Press [ ].
• If the screen displays a list of documents, press [▲] or [▼] to highlight the job you
want to cancel.
2 Press [▲] or [▼] to highlight <Yes>, and then press [OK].
Copy by Saving Paper
You can save paper with [
] (Paper Save Copy) when making a copy.
1 Place your documents (→p.18)
2 Switch to the Copy mode (→p.15).
] (Paper Save Copy).
3 Press [
4 Press [▲] or [▼] to highlight the desired option, and then press [OK].
<2 on 1 1-Sided->2-Sided>*
Copy two pages onto each of both sides of paper.
<4 on 1 1-Sided->2-Sided>*
Copy four pages onto each of both sides of paper.
<2 on 1 1-Sided->1-Sided>
Copy two pages onto one side of each paper..
<4 on 1 1-Sided->1-Sided>
Copy four pages onto one side of each paper.
* MF8580Cdw only
30
5 Press [▲] or [▼] to highlight the document size, and then press [OK].
].
6 Press [
Copying starts automatically.
When placing your
documents on the
platen glass
1. Place the next page on the platen glass, and then
].
press [
• Press [
] for every scanning.
2. After scanning all your documents, press <Start Copying>.
Copy
When placing your
documents in the feeder
Enlarge or Reduce Copies
Enlarge or reduce copies using custom copy ratios.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <Copy Ratio>, and then press [OK].
4 Press [▲] or [▼] to highlight the desired ratio, and then press [OK].
• If you want to set a copy ratio in 1% increments, select <Custom Ratio>, and then
enter the copy ratio using the numeric keys or press [▲] or [▼] to specify the ratio.
5 Press [
].
Adjust the Image Quality for Copy
You can adjust the levels of colors (yellow, magenta, cyan, or black). For
details, see [Copying]  [Various Copy Settings]  [Adjusting Color
Balance] in the e-Manual.
Adjusting the Density
You can make the density brighter or darker than the original documents.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
31
3 Press [▲] or [▼] to highlight <Density>, and then press [OK].
4 Press [◄] or [►] to adjust the density , and then press <Apply>.
– : Less density (lighter)
+ : More density (darker)
You can adjust the background color. For details, see [Copying]  [Various
Copy Settings]  [Adjusting Density] in the e-Manual.
5 Press [
].
Selecting the Document Type
Select the appropriate document type.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→ p.15).
3 Press [▲] or [▼] to highlight <Original Type>, and then press [OK].
4 Press [▲] or [▼] to highlight the appropriate document type, and then
press [OK].
<Text/Photo/Map
(Speed)>
Suitable for documents that contain text, photos, and
maps. (Scanned documents are at a low resolution at
high speed.)
<Text/Photo/Map>
Suitable for documents that contain text, photos, and maps.
<Text/Photo/Map
(Quality)>
Suitable for documents that contain text, photos, and
maps. (Scanned documents are at a high resolution
at low speed.) You can also adjust the level of priority
given to the quality of the text or photos. For details,
see [Copying]  [Various Copy Settings] 
[Selecting Document Type] in the e-Manual.
<Printed Image>
Suitable for documents that contain printed photos.
<Text>
Best suited for text-only documents.
5 Press [
].
Adjusting the Sharpness
You can sharpen or soften the edges of images by adjusting the sharpness.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <Sharpness>, and then press [OK].
32
4 Press [◄] or [►] to adjust the sharpness, and then press <Apply>.
– : Less sharpness
(Suitable for photos)
+ : More sharpness
(Suitable for documents written in pen or
pencil)
].
Copy
5 Press [ Make Double-Sided Copies
(MF8580Cdw Only)
You can make double-sided copies from single-sided documents. You can also make
double-sided or single-sided copies from double-sided documents.
1 Place your documents (→p.18).
• To make double-sided copies from single-sided documents, place the documents
in the feeder or on the platen glass.
• To make double-sided or single-sided copies from double-sided documents, place
documents in the feeder.
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <2-Sided>, and then press [OK].
4 Press [▲] or [▼] to highlight the 2-sided copy format, and then press [OK].
5 Press [
].
When placing your
documents in the feeder
Copying starts automatically.
When placing your
documents on the
platen glass
1. Press [▲] or [▼] to highlight the size of the
document, and then press [OK].
2. Place the next page on the platen glass, and then
press [
].
• Press [
] for every scanning.
3. After scanning all your documents, press <Start Copying>.
Specifying the orientation
If you select <Orig/Fin. Type> at step 4 above, you may specify the orientation of your
documents and output.
<Calendar Type>
<Book Type>
33
Copy Multiple Pages onto One Sheet
You can combine multiple pages (two or four pages) onto one copy sheet.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <N on 1>, and then press [OK].
4 Press [▲] or [▼] to highlight <2 on 1> or <4 on 1>, and then press [OK].
5 Press [▲] or [▼] to highlight the desired scan size, and then press [OK].
• For example, set scan size to <LTR> to scan the entire page of an LTR-size
document.
6 Press [▲] or [▼] to highlight the paper source that contains the paper
you want to use, and then press [OK].
7 Press [
].
When placing your
documents in the feeder
Copying starts automatically.
When placing your
documents on the
platen glass
1. Place the next page on the platen glass, and then
].
press [
• Press [
] for every scanning.
2. After scanning all your documents, press <Start Copying>.
Specifying the page layout manually
If you select <Select Layout> at step 4 above, you may specify the desired page layout.
<2 on 1 (1)>
34
<2 on 1 (2)>
<4 on 1 (1)>
<4 on 1 (2)>
<4 in 1 (3)>
<4 in 1 (4)>
Collate Copies
1
2
3
1
2
3
2
2
2
3
3
3
<ON>
1
1
1
<OFF>
You can arrange copies into sets arranged in page order by using the <Collate> function
when making multiple copies of multiple documents.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <Collate>, and then press [OK].
4 Press [▲] or [▼] to highlight <On>, and then press [OK].
].
5 Press [
Copy
1
2
3
Copy a Double-Sided ID Card
You can make a copy of a double-sided ID card onto single-sided paper.
1 Place an ID card on the platen glass.
• Align the card with the top left corner of the platen glass, and close the feeder.
5mm
1/4"
A5
A5
B4
B4
A4
A4
1/4"
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <N on 1>, and then press [OK].
4 Press [▲] or [▼] to highlight <ID Card Copy>, and then press [OK].
].
5 Press [
6 Turn and place the card.
7 Press [
].
• The copy ratio is automatically set to <100%>.
• You can only use Letter size or larger paper for ID card copying.
35
Erase Dark Borders and Frame Lines of Copies
You can erase the dark borders and frame lines that may appear around the edges of the
output paper.
1 Place your documents (→p.18).
2 Switch to the Copy mode (→p.15).
3 Press [▲] or [▼] to highlight <Erase Frame>, and then press [OK].
4 Press [▲] or [▼] to highlight <On>, and then press [OK].
5 Press [▲], [▼], [◄] or [►] to specify the width of the frame to erase, and
then press <Apply>.
6 Select the document size, and then press [OK].
].
7 Press [
View and Cancel Copy Jobs
You can view or cancel copy jobs while the jobs are in progress.
] (Status Monitor).
1 Press [
2 Press [▲] or [▼] to highlight <Copy/Print Job>, and then press [OK].
3 Press [▲] or [▼] to highlight <Job Status>, and then press [OK].
4 Press [▲] or [▼] to highlight the job you want to view or cancel, and then
press [OK].
• To view the details, press [▲] or [▼].
• To cancel the job, press <Cancel>, press [▲] or [▼] to highlight <Yes>, and then
press [OK].
5 Press [
36
] (Status Monitor) to close the screen.
Change the Default Copy Settings
You can change the default copy settings that are applied when the machine is restarted,
[
] is pressed or the screen is returned to the default screen after auto reset is performed.
Copy
1 Press [ ].
2 Press [▲] or [▼] to highlight <Copy Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Change Default Settings>, and then press
[OK].
4 Press [▲] or [▼] to highlight the desired option, and then press [OK].
<Number of
Copies>
Select the copy quantity.
<Density>
Make the density lighter or darker.
<Original Type>
Select the image quality.
<2-Sided>*
Copy 1-sided document to 2 sides.
<Copy Ratio>
Select the copy ratio.
<Paper>
Specify the paper source.
<N on 1>
Copy multiple documents onto one sheet.
<Collate>
Collate copies of a complete copy job arranged in page
sequential order or by page.
<Erase Frame>
Specify the width of the frame to erase.
<Sharpness>
Emphasize the outline of the image or decrease the contrast.
<Color Balance>
Adjust the levels of yellow, magenta, cyan, or black.
* MF8580Cdw only
5 Specify the desired setting.
6 After you have specified the setting, press <Apply>.
7 Press [ ] to close the screen.
You can register frequently used combinations of copy settings as
favorite settings (modes) on this machine. For details, see [Copying]
 [Configuring Copy Settings to Your Needs]  [Registering
Combinations of Frequently Used Copy Settings] in the e-Manual.
37
Memo
38
Print
This chapter describes basic print functions.
Print a Document… ……………………………………………………
Enlarge or Reduce a Document…………………………………………
Print a Double-Sided Document (MF8580Cdw Only)… ………………
Print Multiple Pages onto One Sheet……………………………………
Print a Booklet (MF8580Cdw Only)………………………………………
Print a Poster… …………………………………………………………
Add Watermarks to a Printout… ………………………………………
View and Cancel Print Jobs………………………………………………
40
40
41
42
43
44
45
46
Before using the printing functions, connect the machine to a computer
and install the printer driver on the computer. See Getting Started to learn
how to install the printer driver.
• You cannot specify printing options with the printer driver and another
application at the same time.
• Your computer screen may differ from the images shown here,
depending on your operating system and the type and version of the
printer driver.
Other Printing Methods
You can print image files stored on a USB memory device by connecting
the device directly to the machine. The machine also can print by using
applications or services on computers or other portable devices that
support Google Cloud Print™. For details, see [Using the Machine as a
Printer] in the e-Manual.
39
Print a Document
1 Make sure that a computer and the machine are connected properly, and
the MF Drivers are installed on the computer.
2 Open a document from an application, and then open the Print window.
3 Select your printer.
4 Click [Print] to start printing.
Canceling Print Jobs
Click [Cancel] on the pop-up screen after printing starts.
You can also cancel printing from the operation panel of the machine.
For details, see [Using the Machine as a Printer]  [Printing from a
Computer]  [Canceling Prints] in the e-Manual.
Enlarge or Reduce a Document
You can enlarge or reduce the data to fit the paper size automatically, or specify a custom
ratio.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
40
3 Click the [Basic Settings] tab, and then specify the print ratio.
Select the paper size of
the document.
To automatically scale
the document to fit the
loaded paper, select an
output size.
To specify the print ratio
manually, select [Manual
Scaling], and then specify
the scaling ratio.
Print
4 Click [OK] to return to the Print window.
5 Click [Print] to start printing.
Print a Double-Sided Document
(MF8580Cdw Only)
You can print on both sides of paper.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
3 Click the [Basic Settings] tab, and then specify the settings for doublesided printing.
Select [2-sided Printing].
Select the binding edge.
4 Click [OK] to return to the Print window.
5 Click [Print] to start printing.
[2-sided Printing] may not be available with some sizes and types of paper.
For details, see [Specifications]  [Paper] in the e-Manual.
41
Print Multiple Pages onto One Sheet
You can reduce and print 2, 4, 6, 8, 9, or 16 pages of an original document onto a single
sheet of paper. This feature allows you to save paper or to view several pages at once.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
3 Click the [Basic Settings] tab, and then specify the number of pages and a
page layout.
Select the number of pages
to print on a single page.
Select the page distribution
layout.
4 Click [OK] to return to the Print window.
5 Click [Print] to start printing.
You cannot enlarge or reduce the documents manually when using this
function.
42
Print a Booklet
(MF8580Cdw Only)
You can print pages side-by-side, and then fold them to create a booklet.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
3 Click the [Basic Settings] tab, select [Booklet Printing], and then click
[Booklet].
Print
4 Specify the settings for the booklet, and then click [OK].
You can choose to print all
pages at once or print them as
multiple bundles consisting of
the number of pages specified
in [Sheets per Set].
To specify the margin for binding, select the
check box, and then enter the value.
5 Click [OK] to return to the Print window.
6 Click [Print] to start printing.
7 Make a booklet by folding the printouts in half.
43
Print a Poster
You can enlarge a one-page document and print it on multiple pages. You can then
combine the printed pages to create a large poster.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
3 Click [Basic Settings] tab, and then select [Poster [NxN]] from the
[Page Layout] drop-down menu.
Select [Poster [N×N]]
(N×N is split numbers of
divided pages wide by
high).
4 Click [OK] to return to the Print window.
5 Click [Print] to start printing.
6 Make a poster by gluing or taping the printouts together.
44
Add Watermarks to a Printout
You can add watermarks, such as “DRAFT,” to a document.
1 Open a document from an application, and then open the Print window.
2 Select your printer, and then open the Printing Preferences window.
3 Click the [Page Setup] tab, and then specify the settings for watermark
printing.
Print
Select to add
watermarks.
Select the desired
watermark.
4 To create a new watermark, click [Edit Watermark], and then enter the
new text.
Select to create a new
watermark.
Delete the selected
watermark from the list.
Enter the created watermark
name.
Specify watermark options.
5 Click [OK] to return to the Print window.
6 Click [Print] to start printing.
You can register up to 50 new watermarks, in addition to the provided
watermarks.
45
View and Cancel Print Jobs
You can view or cancel print jobs that are waiting or in progress.
1 Press [ ] (Status Monitor).
2 Press [▲] or [▼] to highlight <Copy/Print Job>, and then press [OK].
3 Press [▲] or [▼] to highlight <Job Status>, and then press [OK].
4 Press [▲] or [▼] to highlight the job you want to view or cancel, and then
press [OK].
• To view the details, press [▲] or [▼].
• To cancel the job, press <Cancel>, press [▲] or [▼] to highlight <Yes>, and then
press [OK].
5 Press [
] (Status Monitor) to close the screen.
You can also view the print logs that have already been printed. For details,
see [Using the Machine as a Printer]  [Printing from a Computer] 
[Checking the Printing Status and Log] in the e-Manual.
46
Fax
This chapter describes the basic fax functions.
(→ p.109)
You can see frequently asked
questions about the receive mode.
About PC Fax
You can fax documents directly
from a computer using PC Fax
(Fax driver). By faxing directly from
the computer, you can reserve
paper and toner, and send a
higher-quality fax document. See
[Faxing]  [Sending Faxes from
Your Computer (PC Fax)] in the
e-Manual.
Register Destinations in the Address Book… …………………………
Registering Destinations in Favorites……………………………………
Registering Destinations in Coded Dial…………………………………
Registering Multiple Destinations for Group Dial… ……………………
Editing and Deleting Registered Destinations… ………………………
Adjust the Image Quality for Fax… ……………………………………
Adjusting the Density… ………………………………………………
Selecting the Resolution… ……………………………………………
Adjusting the Sharpness… ……………………………………………
Specifying the Double-Sided Document Format (MF8580Cdw Only)……
Changing the Default Settings… ………………………………………
Send a Fax… ……………………………………………………………
Entering a Fax Number with the Numeric Keys…………………………
Selecting from Favorites… ……………………………………………
Selecting with Coded Dial………………………………………………
Selecting from Group Dial………………………………………………
Searching by Name for Destinations……………………………………
Redialing… ……………………………………………………………
Sending a Fax to Multiple Destinations (Sequential Broadcast)… ………
Sending a Fax to an International Destination (Adding Pauses)…………
Calling a Recipient before Sending a Fax… ……………………………
Receive a Fax (Receive Mode)……………………………………………
Using the Machine for Fax Only…………………………………………
Using the Machine for Faxing and Phoning… …………………………
Using the Answering Machine… ………………………………………
Using the Machine Primarily for Phoning… ……………………………
Receiving Faxes in Manual Mode ………………………………………
Receive a Fax from Memory… …………………………………………
Switching to Memory Lock Mode………………………………………
Viewing and Canceling Received Fax Documents………………………
Printing Received Fax Documents………………………………………
View and Cancel a Fax Job………………………………………………
Change the Fax Settings…………………………………………………
Changing Fax Sending Settings…………………………………………
Restricting Fax Sending Functions………………………………………
Changing Fax RX Settings………………………………………………
Changing Communication Management Settings… …………………
48
48
49
50
52
52
52
53
53
54
54
55
55
56
56
56
57
57
58
58
59
60
61
61
62
63
63
64
64
65
65
66
66
66
68
69
70
47
Register Destinations in the Address Book
You can register frequently used destinations in the Address Book and easily select them
when needed. You can also select multiple destinations and register them together as a
group.
• The MF8580Cdw is equipped with functions that enable you to
send scanned images by e-mail or save them to a shared folder. The
destinations for these functions can be registered in the Address Book. For
details, see the e-Manual.
• To set an Address Book PIN, press [ ]  <System Management
Settings>  <Restrict TX Function>  <Address Book PIN>, and
then specify the PIN. After setting the PIN, press [ ] to save the setting.
• If the Address Book is protected with a PIN, you must enter the PIN in order
to add new entries to the Address Book or edit existing entries. If a screen
appears prompting you to enter the PIN, enter the correct PIN using the
numeric keys, and press [OK].
• The Address Book can be saved as a file to your computer using the
Remote UI. The machine can read the file saved in your computer. For
more details about Remote UI, see the e-Manual.
Registering Destinations in Favorites
To send a fax to a destination registered in Favorites, see “Selecting from Favorites” (→p.56).
1 Switch to the Fax mode (→p.15), and then press [ ].
Press [◄] or [►] to switch to the menu screen
or a screen for searching registered destinations.
: Display the fax destinations registered in
the Address Book.
: Display the list of groups registered in
Group Dial.
: Display all registered destinations.
: Display the destinations registered in
Favorites.
,
,
to
: Display registered
destinations
sorted by name.
2 Press <Register Dest.>.
3 Press [▲] or [▼] to highlight <Favorites>, and then press [OK].
4 Press [▲] or [▼] to highlight <Fax>, and then press [OK].
5 Press [▲] or [▼] to highlight <Name>, and then press [OK].
6 Enter a name for the destination, and then press <Apply>.
48
7 Press [▲] or [▼] to highlight <Fax Number>, and then press [OK].
8
Enter the fax number, and then press <Apply>.
• Press <Set Details> to specify detailed options as needed.
9
Press <Apply>.
10 Press [
] (Back) to close the screen.
Fax
Registering Destinations in Coded Dial
To send a fax to a destination that is registered in Coded Dial, see “Selecting with Coded
Dial” (→p.56).
].
1 Switch to the Fax mode (→p.15), and then press [
2 Press <Register Dest.>.
3 Press [▲] or [▼] to highlight <Coded Dial>, and then press [OK].
4 Press [▲] or [▼] to highlight <Fax>, and then press [OK].
5 Press [▲] or [▼] to highlight <Name>, and then press [OK].
6 Enter a name for the destination, and then press <Apply>.
7 Press [▲] or [▼] to highlight <Fax Number>, and then press [OK].
8 Enter the fax number, and then press <Apply>.
• Press <Set Details> to specify detailed options as needed.
9
Press [▲] or [▼] to highlight <Coded Dial>, and then press [OK].
49
10 Press [▲] or [▼] to highlight the Coded Dial number you want to register
(001 to 181), and then press [OK].
• Up to 181 Coded Dial numbers are available.
11 Press <Apply>.
12 Press [
] (Back) to close the screen.
Registering Multiple Destinations for Group Dial
Multiple destinations that have been registered in Favorites or Coded Dial can be combined
into groups. It is useful when sending a fax to multiple destinations at once.
IMPORTANT
• Register group addresses to an unused Favorites or Coded Dial number.
Make sure that you leave some unused Favorites or Coded Dial number
for group dialing.
• Individual destinations must be registered in Favorites or Coded Dial
before they can be added to a group.
].
1 Switch to the Fax mode (→p.15), and then press [
2 Press <Register Dest.>.
3 Press [▲] or [▼] to highlight a destination type to register the group dial
to, and then press [OK].
• Select whether to register the group in Coded Dial or Favorites.
4 Press [▲] or [▼] to highlight <Group>, and then press [OK].
5 Press [▲] or [▼] to highlight <Name>, and then press [OK].
6 Enter a name for the destination, and then press <Apply>.
50
7 Press [▲] or [▼] to highlight <Number of Destinations>, and then press
[OK].
8
Press <Add>.
9
ress [▲] or [▼] to highlight the destination you want to add, and then
P
press [OK].
Fax
10 Press <Add>.
11 Repeat steps 9 and 10 to add more destinations as needed.
12 Press <Apply>.
13 If you selected <Coded Dial> in step 3, press [▲] or [▼] to highlight
<Coded Dial>, and then press [OK].
• If you selected <Favorites> in step 3, proceed to step 15.
14 Press [▲] or [▼] to highlight the Coded Dial number you want to register,
and then press [OK].
15 Press <Apply>.
16 Press [
] (Back) to close the screen.
51
Editing and Deleting Registered Destinations
You can edit or delete destinations registered in the Address Book.
1 Switch to the Fax mode (→p.15), and then press [ 2 Press [◄] or [►] to highlight the tab.
].
• Select < > for Favorites, or select < > for Group Dial.
• If you want to edit or delete a destination registered in Coded Dial, proceed to step
3.
3 Press [▲] or [▼] to highlight the destination, and press <Details/Edit>.
• For Favorites or Coded Dial, you can edit the name, fax number,
and Coded Dial number.
<Edit>
• For a group, you can edit the group name or add new
destinations.
<Details>
View the details for the destination.
<Delete>
Delete destinations from the Address Book.
4 Select the desired option, and then edit or delete the destination.
• To edit the destination, press [▲] or [▼] to highlight the item you want to edit,
perform editing, and then press <Apply>.
• To delete the destination, press [▲] or [▼] to highlight <Yes>, and then press [OK].
5 Press [
] (Back) to close the screen.
Adjust the Image Quality for Fax
Adjusting the Density
You can adjust the density of a fax darker or lighter.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Press [▲] or [▼] to highlight <Density>, and then press [OK].
4 Press [◄] or [►] to adjust the density, and then press <Apply>.
– : Less density (lighter)
+ : More density (darker)
5 Send a fax to the desired destination (→p.55).
52
Selecting the Resolution
You can select a resolution that is appropriate for the document. Set a higher resolution for
documents that contain small text.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Press [▲] or [▼] to highlight <Resolution>, and then press [OK].
4 Select the desired resolution, and then press [OK].
For general text documents
<200 dpi x 200 dpi (Fine)>
For fine text documents
<200 dpi x 200 dpi (Photo)>
For documents that contain photographs
<200 dpi x 400 dpi (Superfine)>
For documents that contain very fine text
<400 x 400 dpi (Ultrafine)>
Achieves an even finer resolution than
Superfine.
Fax
<200 dpi x 100 dpi (Normal)>
5 Send a fax to the desired destination (→p.55).
Adjusting the Sharpness
You can sharpen or soften the edges of images by adjusting the sharpness.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Press [▲] or [▼] to highlight <Sharpness>, and then press [OK].
4 Press [◄] or [►] to adjust the sharpness, and then press <Apply>.
– : Less sharpness
(Suitable for photos)
+ : More sharpness
(Suitable for documents written in pen or
pencil)
5 Send a fax to the desired destination (→p.55).
53
Specifying the Double-Sided Document Format
(MF8580Cdw Only)
You can set the document format to scan double-sided documents automatically.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Press [▲] or [▼] to highlight <2-Sided Original>, and then press [OK].
4 Press [▲] or [▼] to highlight the desired option, and then press [OK].
<Off>
Read only one side of documents.
<Book Type>
• Read both sides of documents.
• Select when the document is
book type.
<Calendar Type>
• Read both sides of documents.
• Select when the document is
calendar type.
5 Send a fax to the desired destination (→p.55).
Changing the Default Settings
You can change the default settings that are applied when the machine is restarted, [ pressed or the screen is returned to the default screen after auto reset is performed.
] is
1 Press [ ].
2 Press [▲] or [▼] to highlight <Fax Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <TX Function Settings>, and then press [OK].
4 Press [▲] or [▼] to highlight <Change Default Settings>, and then press
[OK].
5 Press [▲] or [▼] to highlight the desired option, and then press [OK].
<Resolution>
Make the resolution higher or lower.
<Density>
Make the density lighter or darker.
<2-Sided Original>*
Set whether to read one side of documents or both sides of
documents automatically.
<Sharpness>
Increase the sharpness to enhance the clarity of an image, or
decrease the sharpness to soften an image.
* MF8580Cdw only
54
6 Specify the desired setting.
7 After you have specified the setting, press <Apply>.
8 Press [ ] to close the screen.
Send a Fax
Entering a Fax Number with the Numeric Keys
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Enter the recipient’s fax number with the numeric keys, and <Apply>.
Fax
4 Adjust the image quality of the documents as needed (→p.52).
5 Press [ ] (B&W).
When loading documents
into the feeder
Scanning documents starts. The fax is sent after the
scanning is finished.
When placing documents
on the platen glass
1. Press [▲] or [▼] to highlight the size of the
original document, and then press [OK].
2. After placing next page, press [
] (B&W).
• Press [
] (B&W) for each page.
3. When all pages are scanned completely, press
<Start Sending>.
If the recipient’s line is busy or an error occurs, the machine automatically
redials the last destination. The default number of reattempts is 2, and the
interval between each attempt is 2 minutes.
To change the default settings, press [ ]  <Fax Settings>  <TX
Function Settings>  <Auto Redial>  <On>  specify the settings 
<Apply>  [ ].
Canceling Fax Jobs
1 Press [ ].
• If the screen displays a list of documents, press [▲] or [▼] to highlight the job you
want to cancel.
2 Press [▲] or [▼] to highlight <Yes>, and then press [OK].
55
Selecting from Favorites
You can easily send faxes to a destination registered in Favorites. You can send faxes to
multiple destinations at once, if a group is registered in Favorites.
1 Place your documents (→p.18).
].
2 Switch to the Fax mode (→p.15), and then press [ 3 Press [◄] or [►] to highlight < >.
4 Press [▲] or [▼] to highlight the destination, and then press [OK].
5 Adjust the image quality of the documents as needed (→p.52).
6 Press [ ] (B&W).
Selecting with Coded Dial
You can easily send faxes to a destination registered in Coded Dial. You can send faxes to
multiple destinations at once, if a group is registered in Coded Dial.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15), and then press [ ] (Coded Dial).
3 Enter the three-digit registration number (001 to 181) with the numeric
keys.
• The destination number registered in Coded Dial is displayed. If you accidentally
select an incorrect destination, press [ ] and then enter another dial code.
• When <Coded Dial TX Confirmation> is set to <On>, a screen is displayed that
shows the destination details. Confirm the details, press [▲] or [▼] to highlight
<OK> and press [OK].
4 Adjust the image quality of the documents as needed (→p.52).
5 Press [ ] (B&W).
Selecting from Group Dial
Specify destinations in Group Dial that have been registered in Favorites or Coded Dial.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15), and then press [ 3 Press [◄] or [►] to highlight < >.
56
].
4 Press [▲] or [▼] to highlight the destination, and then press [OK].
5 Adjust the image quality of the documents as needed (→p.52).
6 Press [ ] (B&W).
Searching by Name for Destinations
You can search a name registered in the Address Book.
].
Fax
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15), and then press [ 3 Press [◄] or [►] to search for a recipient.
Select <All> or an initial
in the recipient’s name.
4 Press [▲] or [▼] to highlight the desired recipient, and then press [OK].
5 Adjust the image quality of the documents as needed (→p.52).
6 Press [ ] (B&W).
Redialing
You can select a destination from among the most recent three destinations. When you
specify a previously used destination, the machine automatically sets the same fax settings
you used the last time you sent documents to that destination.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Press [▲] or [▼] to highlight <Previous Settings>, and then press [OK].
4 Press [▲] or [▼] to highlight the destination, and then press [OK].
57
5 Press [
] (B&W).
• When <Restrict Resending from Log> is set to <On>, this feature is not
available.
• The destinations and their fax settings in Manual Sending are not available
for this feature.
• Turning OFF the machine or setting <Restrict New Destinations> to
<On> deletes the past destinations and their fax settings, and disables this
feature.
Sending a Fax to Multiple Destinations
(Sequential Broadcast)
You can send the same document to multiple recipients at once.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Specify the destination.
• Specify the destination using the Address Book or the numeric keys.
• To specify a destination using the numeric keys, enter the fax number and press
<Apply>. To specify additional destinations, press [▲] or [▼] to select <Specify
Next Destination (New)>, and repeat the procedure.
• You can also specify the destination from an LDAP server. For details, see the
e-Manual.
4 Repeat step 3 to enter additional destinations as needed.
• <Specify Next Destination (New)> is available up to 10 destinations.
• To confirm or delete destinations, press [▲] or [▼] to highlight
<Confirm/Edit Destination>, and then press [OK].
5 Adjust the image quality of the documents as needed (→p.52).
6 Press [ ] (B&W).
Sending a Fax to an International Destination
(Adding Pauses)
When sending faxes to international destinations, it is sometimes difficult to connect to a
recipient, due to the long distance that the signal must travel. You can insert a pause after
the international access code to reduce this problem.
1 Place your documents (→p.18).
2 Switch to the Fax mode (→p.15).
3 Use the numeric keys to enter the international access code.
• For details about international access codes, contact your telephone service provider.
4 Press [▲] or [▼] to highlight <Pause>, and then press [OK].
• The letter <P> is displayed to indicate the pause.
• The default pause added before the number is two seconds. To change the pause
time, see “<Set Pause Time>” (→p.67).
• To add another pause, press [OK] again.
58
5 Use the numeric keys to enter the country code, area code, and fax
number.
6 Press [▲] or [▼] to highlight <Pause>, and then press [OK].
• A pause added to the end of the number is fixed at 10 seconds.
7 Press <Apply>.
8 Press [ ] (B&W).
Calling a Recipient before Sending a Fax
In the following cases, follow the procedure below to send faxes:
• If you want to call a recipient before sending a fax
• If the recipient’s machine cannot receive a fax automatically
Fax
To use this function, you must connect an external telephone to the
machine. If it is not connected, use another telephone to make sure the
recipient to switch the fax mode to receive fax.
1 Place your documents (→p.18).
• The machine cannot automatically scan both sides of the documents when using
Manual Sending.
• When the document is placed on the platen glass, only one page can be sent.
2 Switch to the Fax mode (→p.15).
3 Lift the telephone receiver.
• A dial tone sounds.
4 Dial the recipient’s fax number.
5 Ask the recipient to allow his or her machine to receive faxes.
6 When you hear a beep, press [ ] (B&W), and then replace the
telephone receiver.
59
Receive a Fax (Receive Mode)
Your machine provides multiple methods for automatically or manually receiving faxes. Select the receive mode that best suits
your needs.
(→ p.109)
You can see frequently asked questions about the receive mode.
Do you want to
use a telephone
(voice call)?
<Auto> mode
No
See “Using the Machine for Fax
Only” (→p.61).
Yes
Do you want to
use an answering
machine?
Yes
Connect an answering
machine to the machine.
<Answering Machine> mode
See “Using the
Answering Machine“
(→p.62).
No
Do you want to
automatically
receive faxes?
<Fax/Tel Auto Switch> mode
Yes
See “Using the
Machine for Faxing
and Phoning” (→p.61).
Connect an external
telephone to the machine.
No
<Manual> mode
See “Using the
Machine Primarily for
Phoning“ (→p.63).
• If you have subscribed to a Distinctive Ring Pattern Detection (DRPD) service provided by your telephone company, <DRPD>
is also available for the receiving mode. For details about each mode, see [Faxing]  [Receiving Faxes] in the e-Manual.
• Depending on the connected telephone, you may not normally receive a fax. If you are using an external telephone
that has fax functions, disable the external telephone’s auto receive functions.
• If <RX Mode> is set to <Auto> or <Fax/Tel Auto Switch>, you can specify whether or not the external
telephone rings when receiving an incoming call. Also, you can specify the number of rings. Press [ ]  <Fax
Settings>  <RX Function Settings>  <Incoming Ring>.
60
Using the Machine for Fax Only
Set the fax receive mode to <Auto>.
1 Switch to the Fax mode (→p.15).
2 Press [▲] or [▼] to highlight <RX Mode>, and then press [OK].
3 Press [▲] or [▼] to highlight <Auto>, and then press [OK].
Fax
When a Fax or Call Comes In
When a fax comes in, the machine automatically begins receiving the fax. If a voice call
comes in, the caller will hear a fax tone.
Using the Machine for Faxing and Phoning
Set the fax receive mode to <Fax/Tel Auto Switch>.
1 Switch to the Fax mode (→p.15).
2 Press [▲] or [▼] to highlight <RX Mode>, and then press [OK].
3 Press [▲] or [▼] to highlight <Fax/Tel Auto Switch>, and then press [OK].
4 Specify ring settings.
<Ring Start
Time>
Specify how long the machine will attempt to detect a fax tone
before the machine starts ringing (5-30 seconds).
<Incoming
Ring Time>
Specify how long the machine will ring during an incoming call
(15-300 seconds).
<After Ring>
Specify how the machine should behave when an incoming call
is not answered:
• <End>: Disconnects the call.
• <Receive>: Receives a fax.
5 After you have specified the setting, press <Apply>.
61
When a Fax or Call Comes In
The machine automatically detects whether the call is a fax or voice call after two rings.
If the call is a fax, the machine starts receiving the fax. If the call is a voice call, the machine
rings until it is answered or the caller hangs up.
To change the number of rings before the machine receives a fax, press
[ ]  <Fax Settings>  <RX Function Settings>  <Incoming
Ring>  <On>  specify the number of rings  <Apply>  [ ].
Using the Answering Machine
Set the fax receive mode to <Answering Machine>.
1 Switch to the Fax mode (→p.15).
2 Press [▲] or [▼] to highlight <RX Mode>, and then press [OK].
3 Press [▲] or [▼] to highlight <Answering Machine>, and then press [OK].
When a Fax or Call Comes In
The connected answering machine answers the call, and if the call is a fax, the machine
starts receiving the fax. If the call is a voice call, the answering machine answers and records
the caller’s message.
Before use the answering machine, set the number of rings before the
answering machine activates to at least two, and then record a greeting.
62
Using the Machine Primarily for Phoning
Set the fax receive mode to <Manual>.
1 Switch to the Fax mode (→p.15).
2 Press [▲] or [▼] to highlight <RX Mode>, and then press [OK].
3 Press [▲] or [▼] to highlight <Manual>, and then press [OK].
Fax
When a Fax or Call Comes In
The machine continuously rings in Manual mode. Pick up the receiver of the external
telephone to answer the call. If the call is a fax, you will hear a beep. See “Receiving Faxes in
Manual Mode” below to receive faxes manually.
Receiving Faxes in Manual Mode
Follow the procedure below to receive faxes manually.
1 When an incoming call rings, pick up the telephone receiver.
2 If you hear a beep, press [▲] or [▼] to highlight <Start Receiving>, and
then press [OK].
• If you do not hear a beep, start your conversation.
3 Hang up the receiver.
2
5
• When you pick up the telephone and get a fax signal, you do not need to
go to the machine to receive the fax. Just enter the remote RX ID number
(default setting: 25) with the telephone, and you can start receiving the fax.
• To change the remote RX ID, press [ ]  <Fax Settings>  <RX
Function Settings>  <Remote RX>  <On>  specify the remote
RX ID number  <Apply>  [ ].
63
Receive a Fax from Memory
If a fax is stored in memory, you can view the sender of the received fax and print or forward
the fax.
Switching to Memory Lock Mode
1 Press [ ].
2 Press [▲] or [▼] to highlight <System Management Settings>, and then
press [OK].
3 Press [▲] or [▼] to highlight <Communication Management Settings>,
and then press [OK].
4 Press [▲] or [▼] to highlight <Memory Lock Settings>, and then press
[OK].
5 Press [▲] or [▼] to highlight <On>, and then press [OK].
6 Set the details as needed.
Register a seven-digit PIN to protect the memory lock
settings.
<Memory Lock
PIN>
You can use numbers between "0" and "9," but
cannot register consecutive digits that consist of
only "0" as a PIN.
Set the RX Result Report to print automatically when faxes
are received into the memory.
• <Off>: Do not print the RX Result Report.
• <On>: Print the RX Result Report.
<Report Print>
<Memory Lock
Time>
To use this feature, you must also activate the
<RX Result Report> item:
[ ] (Report)  <Report Settings> 
<RX Result Report>
The default setting is <Off>.
Set this feature to receive faxes into the memory only for a
specified time. When the preset time starts, the machine is
switched to receive fax into the memory. When the preset
time ends, faxes stored in the memory are automatically
printed and the memory receiving feature is deactivated.
7 After you have specified the setting, press <Apply>.
8 Press [ ] to close the screen.
64
Viewing and Canceling Received Fax Documents
You can view the sender of the fax stored in memory. You can also delete unnecessary faxes
or forward them to other destinations.
1 Press [ ] (Status Monitor).
2 Press [▲] or [▼] to highlight <RX Job>, and then press [OK].
3 Press [▲] or [▼] to highlight <Job Status>, and then press [OK].
4 Press [▲] or [▼] to highlight a job to be checked or deleted, and then
press [OK].
• To delete the fax job, press <Delete>, press [▲] or [▼] to highlight <Yes>, and then
press [OK].
• To forward the fax, press <Forward>, specify the forwarding destination from the
Address Book, and then press [OK].
Fax
5 Press [ ] (Status Monitor) to close the screen.
Printing Received Fax Documents
When the memory receiving is deactivated, all faxes stored in the memory are automatically
printed.
IMPORTANT
The machine does not support the function to select fax documents to
print. Delete the unnecessary documents first.
1 Press [ ].
2 Press [▲] or [▼] to highlight <System Management Settings>, and then
press [OK].
3 Press [▲] or [▼] to highlight <Communication Management Settings>,
and then press [OK].
4 Press [▲] or [▼] to highlight <Memory Lock Settings>, and then press
[OK].
5 Press [▲] or [▼] to highlight <Off>, and then press [OK].
• All faxes stored in the memory are printed.
6 Press [ ] to close the screen.
65
View and Cancel a Fax Job
You can view or cancel fax jobs that are waiting or in progress.
1 Press [ ] (Status Monitor).
2 Press [▲] or [▼] to highlight <TX Job> or <RX Job>, and then press [OK].
3 Press [▲] or [▼] to highlight <Job Status>, and then press [OK].
4 Press [▲] or [▼] to highlight the job you want to view or cancel, and then
press [OK].
• To cancel sending, press <Cancel>, press [▲] or [▼] to highlight <Yes>, and then
press [OK].
• On the <Details> screen, press <Delete> to delete the received fax, or press
<Forward> to forward the received fax (→p.65).
5 Press [
] (Status Monitor) to close the screen.
You can also view the sending/receiving logs. For details, see [Faxing] 
[Checking Status and Log for Sent and Received Documents] in the
e-Manual.
Change the Fax Settings
You can change the fax settings for sending and receiving to suit your needs.
Changing Fax Sending Settings
1 Press [ ].
2 Press [▲] or [▼] to highlight <Fax Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Basic Settings> or <TX Function Settings>,
and then press [OK].
4 Press [▲] or [▼] to highlight the desired item, and then press [OK].
• See “Settings for Sending Faxes” (→p.67).
5 Specify the setting values, and then press <Apply> or [OK].
6 Press [ ] to close the screen.
66
Settings for Sending Faxes
Settings
Options
Bold: Default settings
Details
Register a fax number for the machine.
The number that you register will appear at the top of the fax.
<Register Unit
Telephone Number>
If you cannot send a fax, change the line type.
<Select Line Type>
<Off-Hook Alarm>
Pulse
Tone
Off
On
--Off-Hook Alarm Volume:
1 to 3
If you are not sure about your telephone line
type, contact your local telephone company.
Specify whether or not to sound an alarm when the handset
of the external telephone is left unhooked at the end of a fax
communication.
You can specify frequently used settings as the default.
<Register Unit Name
(Fax)>
Register your machine name (the name of company or the
user). The name that you register will appear at the top of the
fax.
<ECM TX>
Off
On
The Error Correction Mode (ECM) automatically detects and
corrects errors during fax communication. Using the ECM
function can diminish send errors even over poor connections.
<Set Pause Time>
1 to 2 to 15 (seconds)
Specify the length of pauses added to fax destination
numbers.
Off
On
--Redial Times: 1 to 2 to 10
<Auto Redial>
<TX Terminal ID>
(times)
--Redial Interval: 2 to 99
(minutes)
--Redial When Error Occurs:
Off, On
Off
On
--Print Position: Inside Image
Area, Outside Image Area
--Mark Number as: FAX, TEL
Set auto redialing to automatically reattempt to connect to
a destination if the line is busy or an error occurs. You can
also specify the how many times to redial a number and the
interval between attempts.
Specify whether or not to include the sender ID at the top of
recipient’s faxes. Information such as your fax number and
name is included, enabling the recipient to recognize the
sender.
Fax Number
Number's Type
Sent Time
03/03/2013 02:07 PM
<Check Dial Tone Before
Sending>
Off
On
Fax
<Change Default
Settings>
Unit Name
FAX
123XXXXXXX
CANON
Page Number
0001/0001
When sending a fax, you can specify whether or not to verify
the dial tone before dialing.
67
Restricting Fax Sending Functions
1 Press [ ].
2 Press [▲] or [▼] to highlight <System Management Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Restrict TX Function>, and then press [OK].
4 Press [▲] or [▼] to highlight the desired item, and then press [OK].
• See “Settings for Restricting Fax Sending” below.
5 Specify the setting values, and then press <Apply> or [OK].
6 Press [ ] to close the Menu screen.
Settings for Restricting Fax Sending
Settings
68
Options
Bold: Default settings
Details
<Address Book PIN>
Specify a PIN to protect the Address Book. The PIN will be
required to register, edit, or delete destinations.
<Restrict New
Destinations>
Off
On
Restrict the destinations that can be specified to those already
registered in the Address Book or those searchable from the
LDAP servers. Restricting destinations will prevent the following
operations:
• Specifying a destination with the numeric keys
• Registering new destinations in the Address Book
• Changing destinations that are registered in the Address Book
<Allow Fax Driver TX>
Off
On
Specify whether or not to allow faxes to be sent via a
computer’s fax driver.
<Restrict Resending
from Log>
Off
On
Specify whether or not to restrict sending faxes from
<Previous Settings>.
<Confirm Entered Fax
Number>
Off
On
Specify whether or not to require a confirmation before
sending a fax. If you activate this feature, you must re-enter the
fax number before sending a fax.
<Coded Dial TX
Confirmation>
Off
On
Select whether or not to require confirmation when specifying
a destination by Coded Dial.
<Restrict Sequential
Broadcast>
Off
Confirm Sequential
Broadcast
Reject Sequential Broadcast
Specify whether or not to restrict faxes to multiple recipients.
If <Confirm Sequential Broadcast> is selected, a
confirmation screen is displayed when you send a fax to
multiple recipients. If <Reject Sequential Broadcast> is
selected, you cannot send a fax to multiple recipients.
Changing Fax RX Settings
1 Press [ ].
2 Press [▲] or [▼] to highlight <Fax Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <RX Function Settings> or <RX Print Settings>, and then press [OK].
4 Press [▲] or [▼] to highlight the desired item, and then press [OK].
• See “Settings for Receiving Faxes” below.
Fax
5 Specify the setting values, and then press <Apply> or [OK].
6 Press [ ] to close the screen.
Settings for Receiving Faxes
Settings
Options
Bold: Default settings
Details
<ECM RX>
Off
On
The Error Correction Mode (ECM) automatically detects
and corrects errors during fax communication. Using the
ECM function can diminish receive errors even over poor
connections.
<Incoming Ring>
Off
On
--Ring Times: 1 to 2 to 99
(times)
<Remote RX>
Off
On
--Remote RX ID: 00 to 25 to 99
Specify whether or not the external telephone will ring during
an incoming call if <RX Mode> is set to <Auto> or
<Fax/Tel Auto Switch>.
After the external telephone rings for specified times, the
machine automatically starts receiving the fax, if the call is a fax.
If the call is a voice call, the machine rings only when
<RX Mode> is set to <Fax/Tel Auto Switch>.
Specify whether or not to remotely instruct the machine to
switch to fax mode when an external telephone is connected.
To send the instruction to the machine, you must dial the
remote RX ID from the external telephone. You can also specify
a remote RX ID.
2
5
<Switch to Auto RX>
Off
On
--Ring Time till Auto RX: 1 to 15
to 99 (seconds)
<Print on Both Sides>*
Off
On
Specify how long an incoming call should ring before the
machine automatically switches to fax mode. This option is
available when the receive mode is set to <Manual>.
Specify whether or not to print received faxes on both sides of
paper.
* MF8580Cdw only
69
Settings
Options
Bold: Default settings
Off
On
<Reduce RX Size>
Details
Set to scale images automatically so they fit the selected paper
size or to reduce the image according to the specified ratio.
--Ratio: Auto, 97%, 95%, 90%,
75%
--Direction: Vertical/Horizontal,
Vertical Only
<RX Page Footer>
Off
On
<Continue Printing
When Toner Is Low>
Off
On
Specify whether or not to print a received date, day of the
week, time, number, and page number at the bottom of the
page when printing received faxes.
Specify whether or not to continue printing received faxes and
reports when the toner is nearly out.
Changing Communication Management Settings
1 Press [ ].
2 Press [▲] or [▼] to highlight <System Management Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Communication Management Settings>, and then press [OK].
4 Press [▲] or [▼] to highlight the desired item, and then press [OK].
• If you select <Fax Settings>, you can select a sub-item.
• See “Communication Management Settings” (→p.71).
5 Specify the setting values, and then press <Apply> or [OK].
6 Press [ ] to close the screen.
70
Communication Management Settings
Settings
<TX Start Speed>
<RX Start Speed>
<Memory Lock
Settings>
Options
Bold: Default settings
Details
33600 bps
14400 bps
9600 bps
7200 bps
4800 bps
2400 bps
Change the transmission or receiving start speed if you
have difficulty sending or receiving faxes.
Off
On
--Memory Lock PIN: Seven-digit number
--Report Print: Off, On
--Memory Lock Time: Off, On
Generally, received documents are immediately printed.
However, you can specify whether or not to store
received faxes in memory before printing. You can then
print the stored faxes at any time or delete them without
printing to save paper.
Fax
71
Memo
72
Scan
This chapter describes the basic scan functions.
(→ p.109)
You can see frequently asked
questions about the scan function.
Understand the Scanning Method………………………………………
Scan a Document with the Operation Panel……………………………
Scanning a Document Using a Shortcut Key……………………………
Scan a Document with MF Toolbox… …………………………………
Configuring Scan Settings Using MF Toolbox… ………………………
Scan a Document with the Scanner Driver… …………………………
74
75
77
78
80
82
73
Understand the Scanning Method
Various scanning methods are provided.
Scan a Document with the Operation
Panel (→p.75).
Basic
Method
Connect your
computer to
the machine.
You can use the operation panel to scan an image, and
then send the image to a computer.
Scan a Document with MF Toolbox (→p.78).
You can set the various scan settings with MF Toolbox.
Scanning with
Detailed Scan
Settings
(Use a driver from a
computer)
Connect your
computer to the
machine, and
install the MF
Drivers and MF
Toolbox on the
computer.
Scan a Document with the Scanner Driver (→p.82).
You can set the various scan settings with the scanner
driver (ScanGear MF Window).
Scan a Document Using an Application
For more details, see [Using the Machine as a Scanner]
 [Scanning Documents to a Computer] 
[Scanning Using an Application] in the e-Manual.
Saving a Scanned Document to USB Memory
For more details, see [Using the Machine as a
Scanner]  [Scanning Documents to USB Memory]
in the e-Manual.
Sharing
Scanned
Images
Sending a Scanned Document by E-mail
(MF8580Cdw Only)
For more details, see [Using the Machine as a
Scanner]  [Scanning Documents to Send as
E-mails (MF8580Cdw Only)] in the e-Manual.
Saving a Scanned Document to a Shared
Folder (MF8580Cdw Only)
For more details, see [Using the Machine as a
Scanner]  [Scanning Documents to Shred
Folders (MF8580Cdw Only)] in the e-Manual.
74
Scan a Document with the Operation Panel
You can scan a document using the Scan mode.
1 Make sure that a computer and the machine are connected (See Getting
Started).
2 Place your documents (→p.18).
3 Switch to the Scan mode (→p.15).
4 Press [▲] or [▼] to highlight <Computer>, and then press [OK].
Scan
5 Press [▲] or [▼] to specify a destination, and then press [OK].
• When multiple computers are connected, the computer connected by a USB cable
is listed on the top.
6 Press [▲] or [▼] to specify the scan settings, and then press [OK].
<Color Scan>
• Scan the document in color (300 dpi), and then save as a
PDF file.
• PDF settings: Searchable/Compact
<B&W Scan>
Scan the document in black and white (300 dpi), and then
save as a TIFF file.
<Custom 1>
Scan the document in color (300 dpi), and then save as a
JPEG/Exif file.
<Custom 2>
• Scan the document in color (300 dpi), and then save as a
PDF file.
• PDF settings: Searchable/Standard
75
7 Press [OK] to start scanning.
When placing your
documents in the feeder
Scanning operation starts.
When placing your
documents on the
platen glass
1. To continuously scan the document, press [▲] or
[▼] to highlight <Scan Next Original>, and then
press [OK].
2. Press <Store & Finish>.
• If you want to check the destination computer, press [▲] or [▼] to highlight
<Confirm Destination>, and then press [OK].
• When scanning is complete, the folder that contains the scanned images is opened
on the screen of the computer.
Canceling Scan Jobs
1 Press <Cancel>.
2 Press [▲] or [▼] to highlight <Yes>, and then press [OK].
Default Folder for Saving Scanned Images
By default, a new folder named after the date you scanned is created in the [Pictures] folder.
(For Windows XP, the folder is created in the [My Pictures] folder in [My Documents].)
76
Scanning a Document Using a Shortcut Key
You can perform a scan easily by registering destinations and frequently used settings in
shortcut keys in advance.
Registering a Shortcut Key
1 Press [ ].
2 Press [▲] or [▼] to highlight <Scan Settings>, and then press [OK].
3 Press [▲] or [▼] to highlight <Shortcut Key Settings>, and then press
[OK].
4 Press [▲] or [▼] to highlight <Register>, and then press [OK].
• To confirm the destination registered in the shortcut key, select
<Confirm Destination>.
5 Press [▲] or [▼] to highlight the shortcut key that you want to register,
and then press [OK].
Scan
6 Press [▲] or [▼] to highlight the connection method, and then press [OK].
7 Press [▲] or [▼] to highlight the destination computer, and then press
[OK].
• When the machine and a computer are connected by a USB cable, proceed to step
8.
8 Press [▲] or [▼] to highlight the scan settings, and then press [OK].
<Color Scan>
• Scan the document in color (300 dpi), and then save as a
PDF file.
• PDF settings: Searchable/Compact
<B&W Scan>
Scan the document in black and white (300 dpi), and then
save as a TIFF file.
<Custom 1>
Scan the document in color (300 dpi), and then save as a
JPEG/Exif file.
<Custom 2>
9 Press [ • Scan the document in color (300 dpi), and then save as a
PDF file.
• PDF settings: Searchable/Standard
] to close the screen.
77
Performing a Scan Using a Shortcut Key
1 Make sure that the computer and machine are connected (See Getting
Started).
2 Place your documents (→p.18).
3 Switch to the Scan mode (→p.15).
] or [
] into which the desired destination is
4 Press [
registered.
When placing your
documents in the feeder
Scanning operation starts.
When placing your
documents on the
platen glass
1. To continuously scan the document, press [▲] or
[▼] to highlight <Scan Next Original>, and then
press [OK].
2. Press <Store & Finish>.
• When scanning is complete, the folder that contains the scanned images is opened
on the screen of the computer.
Scan a Document with MF Toolbox
You can specify various scan settings if you select <Remote Scanner> from the operation
panel, and then open MF Toolbox.
1 Make sure that the computer and machine are connected (See Getting
Started).
2 Place your documents (→p.18).
3 Switch to the Scan mode (→p.15).
4 Press [▲] or [▼] to highlight <Remote Scanner>, and then press [OK].
5 From your computer, double-click the [Canon MF Toolbox] icon.
78
6 When MF Toolbox appears, click the desired scan mode button.
[Mail]
• The scan preset for an e-mail attachment is displayed.
• The scanned document will be attached to a new message
in your e-mail application.
[OCR]
[Save]
• The scan preset for the OCR (Optical Character Reader) is
displayed.
• The scanned document will be read by your OCR software.
• The scan preset for a high quality scanning is displayed.
• The scanned document will be saved in the default folder
or in a destination that you specify.
[PDF]
[Color Scan]
[B&W Scan]
[Custom 1]
displayed.
• The scanned document will be saved as a PDF file.
• The custom setting is displayed.
• The scanned document will be saved in a destination that
you specify and opened in the registered application.
Scan
[Custom 2]
• The scan preset for the multiple page searchable PDF is
7 When the scan setting window appears, specify the scan settings as
needed (→p.80).
8 Click [Start] to start scanning.
• When scanning is complete, the folder in which the scanned document is saved is
opened automatically.
• The scanned document will be opened in the registered application.
9 When scanning is complete, click [
] to close MF Toolbox.
79
Configuring Scan Settings Using MF Toolbox
This section describes the layout and features of each setting dialog box of MF Toolbox.
For more details, see [Scanning]  [Scanning Documents to a
Computer]  [Scanning Using MF Toolbox] in the e-Manual.
• Set the location of a document to
be scanned.
• [Auto Mode] that detects
the source automatically is
recommended.
Example: When [Mail] or [PDF] menu is selected in MF Toolbox
• Set the input method based on
the type of document placed in
the feeder (MF8580Cdw only).
• Set the size of the document to be
scanned.
• Set the color mode.
• This setting is not available when
scanning using the [Color Scan]
or [B&W Scan] button.
• Set the maximum size limit of the
file that is attached to the e-mail.
• This item is available only when
you scan using the [Mail] mode.
• Set the scanning resolution.
• If you select a higher resolution,
the image quality becomes higher,
and the file size becomes bigger.
• Set the file name, file type, and
location to be saved for the
scanned image.
• Manually set the location to save
the scanned image by clicking
[Browse].
• Select to specify the format or
location to save the scanned
image after scanning.
80
Reset the configured settings to the
default values.
Scanning
starts.
• Select to specify the scan settings using the
scanner driver (→p.82).
• When [Start] is clicked with this check box
selected, the [ScanGear MF] dialog box
appears.
• This check box is not available when you scan
using the [OCR] button.
Set the orientation of the document.
PDF (Single
Page)
Creates a single-page
PDF file.
PDF
(Multiple
Pages)
Save all scanned
images as a single PDF
file.
Scan
Set the PDF file type to save the scanned
image.
• Add the scanned
PDF (Add
Pages)
image to the last
page of an existing
PDF file.
• Click [Browse]
for [Create PDF
File Based On] to
specify an existing
PDF file to which
to add the newly
scanned PDF file.
If you selected PDF as the file type, you
can create a searchable PDF. Also, you
can set the compression ratio.
• Set an application to display the scanned image.
• Click [Set] to select an application or drag and drop the
application icon.
• Click [Delete] to save the file without using the applications.
81
Scan a Document with the Scanner Driver
If you use the scanner driver window (ScanGear MF Window), you can use various features
and scan only the necessary part with the preview function.
1 Make sure that the computer and machine are connected (See Getting
Started).
2 Place your documents (→p.18).
3 Switch to the Scan mode (→p.15).
4 Press [▲] or [▼] to highlight <Remote Scanner>, and then press [OK].
5 From your computer, double-click the [Canon MF Toolbox] icon.
6 When MF Toolbox appears, click the desired scan mode button.
7 When the scan setting window appears, select the [Display the Scanner
Driver] check box, and then click [Start].
8 Select [Preview] on the scanner driver dialog box, and then specify
settings as needed.
Crops the borders detected in the preview image.
Deletes the selected cropping frames.
Rotates the image 90 degrees to the left.
Rotates the image 90 degrees to the right.
Specify various
scanner settings
on each tab.
You can preview the
image applied to the
scan setting values.
9 Click [Scan] to start scanning.
• When scanning is complete, the folder in which the scanned document is saved
opens automatically.
• If an application is specified, the scanned document will be opened in the
application.
10 When scanning is complete, click [
82
] to close MF Toolbox.
Maintenance and Management
This chapter describes how to clean the machine, replace the toner cartridge,
and explains the report and list functions used for managing the machine.
Clean the Machine… ……………………………………………………
Cleaning the Exterior……………………………………………………
Cleaning the Platen Glass… ……………………………………………
Cleaning the Feeder……………………………………………………
Cleaning the Fixing Unit… ……………………………………………
Cleaning the Transfer Belt………………………………………………
Check and Replace Toner Cartridges……………………………………
Checking the Toner Level… ……………………………………………
Replacing Toner Cartridges… …………………………………………
Manage Using the Report and List Functions… ………………………
Configure Settings Using the Remote UI… ……………………………
84
84
84
85
85
85
86
86
87
90
91
83
Clean the Machine
Clean the exterior and interior of the machine, feeder, and the fixing unit periodically.
Cleaning the Exterior
IMPORTANT
For safety, be sure to turn OFF the machine and disconnect all cables from
the machine before cleaning the machine. When you finish cleaning the
machine, wait for it to dry completely before reconnecting the power cord,
and then turn ON the power.
1 Turn OFF the machine and disconnect all the cables from the machine.
2 Remove any documents from the platen glass or feeder.
3 Clean the exterior of the machine and ventilation slots with a soft, well
wrung-out cloth dampened with water or a mild detergent that has been
diluted with water.
4 Wait for the machine to dry completely.
5 Reconnect all the cables, and then turn ON the power.
Cleaning the Platen Glass
If a scanned image has unexpected specks, clean the platen glass.
1 Turn OFF the machine and disconnect all the cables from the machine.
2 Remove any documents from the platen glass.
3 Open the feeder.
4 Clean the areas with a cloth dampened with water. Then, wipe the area
with a soft, dry cloth.
84
5 Wait for the machine to dry completely.
6 Close the feeder.
7 Reconnect all the cables, and then turn ON the power.
Cleaning the Feeder
Clean the feeder when smudges appear on printed pages.
1 Press [ ].
2 Press [▲] or [▼] to highlight <Adjustment/Maintenance>, and then press
[OK].
3 Press [▲] or [▼] to highlight <Clean Feeder>, and then press [OK].
4 Load Letter size plain paper in the feeder, and then press [OK].
• The cleaning process begins. Cleaning takes approximately one minute.
5 When the cleaning is complete, press [ ] to close the screen.
Cleaning the Fixing Unit
Clean the fixing unit when black streaks appear on printed pages.
Maintenance and Management
1 Press [ ].
2 Press [▲] or [▼] to highlight <Adjustment/Maintenance>, and then press
[OK].
3 Press [▲] or [▼] to highlight <Clean Fixing Unit>, and then press [OK].
4 Load Letter size plain paper drawer or manual feed slot, and then press
[OK].
• The cleaning process begins. Cleaning takes approximately one minute.
5 When the cleaning is complete, press [
] to close the screen.
Cleaning the Transfer Belt
Clean the transfer belt when print quality deteriorates.
1 Press [ ].
2 Press [▲] or [▼] to highlight <Adjustment/Maintenance>, and then press
[OK].
3 Press [▲] or [▼] to highlight <Clean ITB >, and then press [OK].
4 Press [OK].
• The cleaning process begins. Cleaning takes approximately one minute.
5 When the cleaning is complete, press [
] to close the screen.
85
Check and Replace Toner Cartridges
Toner cartridges are consumable products. When the toner has almost run out, a message
appears in the display and streaks may appear on printed pages. Check the toner level, and
replace the toner cartridge if necessary.
OR
Check the toner level, as needed. See the directions below.
When <Prepare the XXXX* toner cartridge.>
message still appears in display, or print result is not
improved, replace the toner cartridge (→p.87). (* The
toner cartridge colors black, yellow, magenta, or
cyan appear in the actual message.)
When the <Prepare the XXXX* toner cartridge.> message appears on
the display, the incoming faxes will be stored in the memory without printing.
You can also set to print the received faxes, however, the printed documents
may be light or blurred. (* The toner cartridge colors black, yellow, magenta,
or cyan appear in the actual message.)
]  <Fax Settings>  <RX Print Settings>  <Continue
Press [ Printing When Toner Is Low>  <On>, and then press [OK].
Checking the Toner Level
] (Status Monitor).
1 Press [
2 Press [▲] or [▼] to highlight <Device Status>, and then press [OK].
3 Press [▲] or [▼] to highlight <Remaining Toner>, and then press [OK].
4 Check the toner level.
• The toner level will appear as <OK>, <Low>, or <Nearly Out>.
5 Press [
86
] (Status Monitor) to close the screen.
Replacing Toner Cartridges
You can purchase replacement toner cartridges from your local authorized Canon dealer.
Supported genuine Canon toner cartridges:
MF8580Cdw
Canon Cartridge 118 Black
Canon Cartridge 118 Yellow
Canon Cartridge 118 Magenta
Canon Cartridge 118 Cyan
MF8280Cw
Canon Cartridge 131 Black
Canon Cartridge 131 H Black
Canon Cartridge 131 Yellow
Canon Cartridge 131 Magenta
Canon Cartridge 131 Cyan
1 Open the front cover and pull out the cartridge tray, and then remove the
toner cartridges.
Maintenance and Management
87
2 Prepare a new toner cartridge.
• Store the protective bag. It is required when you remove the toner cartridge for
machine maintenance or other purposes.
Shake the toner cartridge
5-6 times to evenly distribute
the toner. In this step, do not
remove the drum protective
cover ( ).
Front View
Place the toner cartridge on a
flat surface, remove the tab, and
carefully pull the sealing tape
completely out (20” (50 cm)).
IMPORTANT
When pulling out the sealing tape:
• Do not pull the sealing tape at an angle or up and down. If the tape
breaks, it may not be pulled out completely.
Top View
• Even if the sealing tape stops at midpoint, pull it out of the toner
cartridge completely.
• If any tape remains in the toner cartridge, this may result in poor print
quality. If you are using the Fax, please note that you can only print the
received data once, because the received data is deleted once it is printed.
• Dispose of the packing materials according to local regulations.
Remove the drum protective
cover.
88
3 Install the toner cartridge.
• Each toner cartridge color has its own slot in the toner cartridge tray, and this tray
is indicated with a corresponding color label (
slot that corresponds to its color.
). Place the toner cartridge into the
4 Push the toner cartridge tray back in, and close the front cover.
WARNING
Maintenance and Management
Do not dispose of a used toner cartridge in open flames.
This may cause the toner remaining inside the cartridge to ignite, resulting in burns
or a fire.
When cleaning up spilled or scattered toner:
If you accidentally spill or scatter toner, carefully gather the toner particles together
or wipe them up with a soft, damp cloth in a way that prevents inhalation.
Never use a vacuum cleaner that does not have safeguards against dust explosions
to clean up spilled toner. Doing so may cause a malfunction in the vacuum cleaner,
or result in a dust explosion due to static discharge.
CAUTION
If you get toner on your hands or clothing:
Wash them immediately with cold water. Washing with warm water sets the toner,
making it impossible to remove the toner stains.
Do not allow the toner to scatter.
Do not pull out the sealing tape forcefully or stop before it is removed, as this
may cause toner to spill out. If toner gets into your eyes or mouth, flush them
immediately with cold water and immediately consult a physician.
• Follow all local and federal regulations when disposing of the sealing tape
removed from the new toner cartridge.
• Canon will collect and recycle your used toner cartridges (→p.112).
• For more details about handling toner cartridges, see [Important Safety
Instructions]  [Consumables] in the e-Manual.
89
Manage Using the Report and List Functions
Print out reports or lists to view communication status, Address Book information, or
settings, for monitoring the machine.
] (Report).
1 Press [
2 Press [▲] or [▼] to highlight <Print List>, and then press [OK].
3 Press [▲] or [▼] to highlight a report or list, and then press [OK].
<Address Book List>
Numbers that are registered in the Address Book (Coded
Dial, favorites, and groups)
<User Data List>
Information about the machine and settings
<Communication
Management
Report>
Fax or e-mail communication history
4 Follow the on-screen instructions to print the report or list.
] (Report) to close the screen.
5 Press [
• If an error occurs while sending or receiving faxes, report is printed
automatically. Confirm the error code printed on the report and resolve the
problem (→p.106).
Error code
• For more details about the reports and lists, see [Maintenance] 
[Printing Reports and Lists] in the e-Manual.
90
Configure Settings Using the Remote UI
If the machine is connected to a network, you can monitor and configure the machine from
the computer using the Remote UI.
1 Configure the network settings for the machine (See Getting Started).
• Set the machine used on a TCP/IP network, and then connect the machine and a
computer to a network router or hub.
2 Start the web browser, enter “http://<the IP address of the machine>/” in
the address filed, and then press [Enter] key on your keyboard.
• Input Example: http://192.168.222.84/
3 Log on to the Remote UI.
Maintenance and Management
[System Manager
Mode]
You can use and configure all features and settings of
the Remote UI.
[End-User Mode]
You can check device status, confirm settings, and view
jobs. You can also enter a user name to handle jobs with
a matching user name.
4 When the setting screen is displayed, select the desired menu.
• For more details, see [Using Remote UI] in the e-Manual.
91
Memo
92
Troubleshooting
This chapter describes how to clear paper jams and offers solutions to
problems you may be having.
Clear Jams… ……………………………………………………………
Resolve a Displayed Message……………………………………………
Resolve an Error Code……………………………………………………
Improve Output Quality…………………………………………………
Resolve a Problem… ……………………………………………………
94
105
106
107
108
93
Clear Jams
If a paper jams, <Paper jammed.> is displayed on the screen. Press <Next> to display a
message that indicates where the paper is jammed. Click the corresponding link in the table
below, and remove the jammed paper.
MF8580Cdw
Message
Refer to:
<Remove original from feeder.>
Clearing Document Jams in the Feeder (→p.95)
<Open the front cover.>
Clearing Paper Jams in the Front Side (→p.97)
<Remove the paper from the tray.>
Clearing Paper Jams in the Manual Feed Slot
(→p.101)
<Pull out Drawer 1.>
<Pull out Drawer 2.>
Clearing Paper Jams in the Paper Drawer
(→p.100)
<Open the back cover.>
Clearing Paper Jams in the Back Side (→p.98)
MF8280Cdw
Message
Refer to:
<Remove original from feeder.>
Clearing Paper Jams in the Feeder (→p.96)
<Lift the control panel.>
Clearing Paper Jams in the Front and Back
Sides (→p.99)
<Pull out the drawer.> ▶ <Open the
paper cover.>
Clearing Paper Jams in the Manual Feed Slot
(→p.103)
<Pull out the drawer.> ▶ <Remove
the jammed paper.>
Clearing Paper Jams in the Paper Drawer
(→p.100)
WARNING
When removing jammed documents or paper:
Use caution to avoid paper cuts.
When removing jammed paper or inspecting the inside of the machine:
Do not allow necklaces, bracelets, or other metal objects to touch the inside of the
machine, as this may result in burns or electrical shock.
CAUTION
If loose toner comes into contact with your skin or clothing:
Wash with cold water. Do not wash with warm water, as this will set the toner and
cause it to stain your skin or clothing.
When removing jammed documents or paper:
If paper is jammed, remove it carefully so that no pieces of paper remain inside the
machine according to the displayed message. Also, do not put your hand in an
area other than indicated areas, as this may result in personal injuries or burns.
94
IMPORTANT
If the jammed paper is torn:
Remove all torn pieces to avoid further jams.
If repeated paper jams occur:
Do the following:
• Make sure that all of the orange tape and packing materials are
completely removed.
• Fan the paper stack and tap the edge on a flat surface to align the
paper before loading it into the machine.
• Make sure that the paper meets the requirements for use (→ p.20).
• Make sure that you have removed all scraps of paper from the inside
of the machine.
Clearing Document Jams in the Feeder
(MF8580Cdw)
After removing any documents placed in the feeder, follow the procedure below to remove
jammed documents.
1 Open the feeder cover.
2 Move the lever to unlock.
3 Remove any jammed document by pulling it gently.
Troubleshooting
95
4 Hold the green knob, and then open the inner cover.
5 Remove any jammed document by pulling it gently.
6 Close the inner cover.
7 Replace the lever and close the feeder cover.
Clearing Document Jams in the Feeder
(MF8280Cw)
After removing any documents placed in the feeder, follow the procedure below to remove
jammed documents.
1 Open the feeder cover.
2 Remove any jammed document by pulling it gently.
3 Close the feeder cover.
96
Clearing Paper Jams in the Front Side
(MF8580Cdw)
Step
1
Remove the jammed paper inside.
1 Open the front cover.
2 Lift the operation panel.
3 Gently pull out the paper.
Step
2
Lower the operation panel and the front cover.
Troubleshooting
97
Clearing Paper Jams in the Back Side
(MF8580Cdw)
Step
1
Open the rear cover.
Step
2
Remove the jammed paper deep in the back side.
1 Pull down the green knob toward you.
2 Gently pull out the paper.
Step
3
Remove the jammed paper close to the back side.
Hold the green knobs, and firmly close this part until it clicks ▶ Gently pull out the paper.
Step
98
Close the rear cover.
Clearing Paper Jams in the Front and Back Sides
(MF8280Cw)
Step
1
Remove the jammed paper in the front side.
Lift the operation panel ▶ Gently pull out the paper.
Step
Step
2
3
Lower the operation panel.
Remove the jammed paper in the back side.
Open the rear cover ▶ Gently pull out the paper.
Step
Close the rear cover.
Troubleshooting
99
Clearing Paper Jams in the Paper Drawer
Step
1
Remove the jammed paper inside the paper drawer.
Hold the paper drawer with both hands, and pull it out gently ▶ Gently pull out the paper.
IMPORTANT
Step
2
• Make sure to hold the paper drawer with both hands. Otherwise,
you may damage the paper drawer by dropping it, if it slides out too
easily.
• Even if an optional paper drawer (MF8580Cdw only) is installed,
remove the paper in the same way.
Set the paper drawer.
If you pulled out an optional paper drawer, set it in the same way.
Step
100
3
When the screen shown below is displayed, press [▲] or [▼]
to highlight <Yes>, and then press [OK].
Clearing Paper Jams in the Manual Feed Slot
(MF8580Cdw)
Step
Step
1
2
Remove the paper that is loaded in the tray.
Remove the jammed paper in the tray.
Do not forcibly remove jammed paper from the machine. If the jammed paper cannot be
removed easily, proceed to the next step.
1 Gently pull out the paper.
2 Close the tray.
Step
3
Remove the jammed document inside the tray.
1 Hold the paper drawer with both hands, and pull it out.
Troubleshooting
2 Hold the green knobs, and push down this part.
101
3 Gently pull out the paper.
IMPORTANT
Do not touch the rubber pad
• Touching it may deteriorate print quality.
Step
Hold the green knobs, and return this part back in place.
Step
Set the paper drawer.
Step
When the screen shown below is displayed, press [▲] or [▼]
to highlight <Yes>, and then press [OK].
Return this part back in place until it clicks.
102
Paper Jams in the Manual Feed Slot
(MF8280Cw)
Step
1
Hold the paper drawer with both hands, and pull it out.
Step
2
Remove the jammed document inside the manual feed slot.
1 Open the cover.
2 Hold the green knobs, and push down this part.
3 Gently pull out the paper.
Troubleshooting
103
Step
3
Hold the green knobs, return this part back in place, and
close the cover.
Return this part back in place until it clicks.
104
Step
Set the paper drawer.
Step
hen the screen shown below is displayed, press [▲] or [▼]
W
to highlight <Yes>, and then press [OK].
Resolve a Displayed Message
This section describes some of messages related to the toner, memory, and paper. (Where “XXXX” appears in the descriptions
below, the toner cartridge colors black, yellow, magenta, or cyan appear in the actual messages.)
For more details about other messages, see [Troubleshooting]  [When
an Error Message Appears] in the e-Manual.
Message
Action
• The toner cartridge needs to be replaced soon. Prepare the replacement toner cartridge
(→p.87).
<Prepare the XXXX
toner cartridge.>
<End of Toner Cart.
Lifetime XXXX>
If this message is displayed while receiving a fax, the incoming fax will be stored in the
memory without being printed.
Reports may not be printed, even if they are set to be printed automatically.
If <Continue Printing When Toner Is Low> in <RX Print Settings> is set to <On>,
however, printing will be continued, but faxes may fade or blur.
• It is recommended to replace the cartridge with a new one. (→p.87). You can continue
printing, but the print quality cannot be guaranteed.
<The memory is full.>
• If there are any jobs waiting to be sent or printed, wait until the jobs are complete.
• Split the job into smaller subsets or reduce the scanning resolution and try to send them
again (→p.53).
<The memory is full.
Scanning will be
canceled. Do you want
to print?>
• Print pages successfully scanned or cancel the job.
<Paper Size & Settings
Mismatch>
• Change the <Paper Settings> to the size of the loaded paper (→p.27).
• When printing with the printer driver, verify that the paper size setting on the computer is
<No paper>
Load paper (→p.20).
correct.
Troubleshooting
105
Resolve an Error Code
If an error occurs, a report that contains a three-digit error code is printed. Locate the error code in the table and follow the
recommended actions to resolve the problem.
Error code
For more details about other error codes, see [Troubleshooting] 
[When an Error Code Appears] in the e-Manual.
Error Code
Cause
Action
#001
A document jams in the feeder.
Remove the jammed document.
#003
Transmission failed due to the high
volume of data.
When sending a fax:
• Reduce the scanning resolution, and try to send the document
again.
When receiving a fax:
• Reduce the scanning resolution or ask the sender to divide the
document before sending it again.
#005
A fax recipient did not respond
within 35 seconds.
Repeat the sending procedure from the beginning. Additionally,
ask the recipient to check the fax machine. When making an
overseas call, add a pause to the fax number.
#012
The recipient’s machine has run out
of paper.
Ask the recipient to ensure that paper is loaded in their machine.
You cannot send a fax because the
line is busy or disconnected.
Wait a moment, and then try again. If you are still unable to send
the document, ask the recipient to verify that the fax machine is
ready to receive a fax.
No pause was added to the fax
number when attempting an
international fax transmission.
Add a pause after the country code or in front of the fax number,
and then redial the number.
Sending faxes from a computer is
restricted.
The restriction needs to be canceled. Contact your administrator
for more information. For details, see [Security]  [Restricting
the Machine’s Functions]  [Restricting Access to Address
Book and Sending Functions]  [Prohibiting PC Faxing] in
the e-Manual.
A fax could not be forwarded
because the specified destination
was deleted from the Address Book.
Register the forwarding destination again, and check the fax
forwarding settings. For details, see [Basic Operations] 
[Registering in the Address Book] or [Faxing]  [Sending
and Receiving Faxes According to Your Purposes] 
[Forwarding Received Faxes] in the e-Manual.
#037
The machine’s memory is full.
Print, send, or delete any documents stored in memory.
#099
Printing, sending, or receiving was
canceled.
Print, send, or receive documents again as necessary.
#995
A document waiting to be sent has
been canceled by a user.
Try to send the document again.
#018
#022
106
Improve Output Quality
Follow the recommended actions for each symptom to improve the output quality.
If you cannot solve the problem with the following actions,
see [Troubleshooting]  [Printing Results Are Not Satisfactory] in
the e-Manual.
Symptom
Example
Action
Paper curls.
• Verify that the appropriate paper is being used (→p.20).
• Print a test page with new paper.
• Verify that the paper is loaded properly (→p.20).
• Change the <Special Mode P> setting from the operation panel.
Paper creases.
• Verify that the appropriate paper is being used (→p.20).
• Print a test page with new paper.
• Verify that the paper is loaded properly (→p.20).
• Remove any foreign objects inside the machine.
The printed paper has
vertical streaks.
• Verify that the appropriate paper is being used (→p.20).
• Print a test page with new paper.
Smudge marks of
spattering toner
appear around the
text or as patterns.
• Verify that the appropriate paper is being used (→p.20).
The bottom edge of
paper has smudge
marks.
Provide a margin around the data.
A portion of the page
is not printed.
Provide a margin around the data.
Troubleshooting
107
Resolve a Problem
Follow the procedures below to resolve your problem.
WARNING
If the machine makes strange noises or emits
smoke or odors:
Turn OFF the machine immediately, disconnect the
power cord, and contact the Canon Customer Care
Center. Do not attempt to disassemble or repair the
machine yourself.
IMPORTANT
If you attempt to repair the machine by
yourself, it may void the limited warranty.
1
Verify that the cables are connected
properly and that the power is turned
ON (See Getting Started).
2
Verify that the machine is not in
Sleep mode (→ p.28).
• If the [Energy Saver] key blinks, press it to
Verify that no message appears on
the display.
• If a message appears, resolve the problem
(→p.105).
If you cannot solve the problem
See [Troubleshooting] in the e-Manual
or the Q&A from the support page of the
official Canon Web site.
If you cannot solve the problem
Contact your local authorized Canon dealer
or the Canon help line for assistance.
exit the Sleep mode.
Press [Status Monitor] to check the
status of the machine (→ p.14).
• If there are jobs in process, wait until the jobs
are finished.
Verify that the Error indicator is not
on or blinking (→ p.13).
• Make sure that paper is loaded properly
(→p.20).
• Remove any jammed paper (→p.94).
• Turn OFF the machine, wait for more than
10 seconds, and then turn it ON again.
108
Please have the following information ready when you
contact Canon.
• Product name
• Serial number
• Place of purchase
• Nature of problem
• Steps you have taken to solve the problem and the
results
FAQ
Fax
Fax
Q
Q
Can I turn off the incoming ring when receiving a fax?
└A
When using <Fax/Tel Auto Switch> mode, I often miss voice calls because the
incoming ring rings only for a short period of time. How do I increase the number
of rings when receiving a voice call?
└A
Fax
Fax
Q
Q
Yes, but you can turn off the incoming ring for faxes only when you are using
<Fax/Tel Auto Switch> mode.
To turn off the incoming ring for faxes, press [ ]  <Fax Settings> 
<RX Function Settings>  <Incoming Ring>  <Off>.
Press [ ]  <Fax Settings>  <RX Function Settings>  <Incoming Ring>  <On>,
and then specify the number of rings.
When an answering machine is connected to the machine, how do I make the
answering machine to activate only when receiving a voice call?
└A
Set the fax receive mode to <Answering Machine>, and then set the answering
machine to activate after a few rings.
The machine will detect a fax signal before the answering machine activates, if the answering
machine is set to activate after at least two rings.
For details about how to change the number of rings, see the answering machine’s manual.
The connected external telephone has fax functions, but I want to receive a fax not
with the external telephone but this machine.
└A
Troubleshooting
Set the fax receive mode to <Fax/Tel Auto Switch>, and then disable the external
telephone’s fax functions.
When both the machine and the external telephone are set to use the fax function, the machine
or device that first detects the fax signal will receive the fax. To always receive fax with the
machine, you should disable the external telephone’s fax functions.
For details, see the external telephone’s manual.
109
Q
How do I use the scan function when the machine is connected to a computer via a
network?
└A
You must register the machine to the MF Network Scan Utility first.
To register,
1. From the task tray on your desktop, click [
].
2. Place a check next to the machine, and then click [OK].
Q
Q
Can I use the scan function when using a machine and drivers that are shared by
another person?
└A
No, you may not use the scan function when sharing drivers that are installed to
another computer. To use the scan function, install the MF Drivers on your computer.
You can use the supplied user software CD-ROM or download the drivers from the official Canon
Website site (http://www.usa.canon.com).
For details about installing drivers, see Getting Started.
To which file formats can I save the scanned images?
└A
You may save scanned files to the following formats:
• BMP
• TIFF
• JPEG/Exif
• PDF
When saving as a PDF file, you can create a PDF file of a single or multiple page document, or
add a page to an existing PDF file.
110
Q
Can I change the folder that the scanned images are saved to?
└A
Yes, you can change the folder to save the scanned images when scanning with MF
Toolbox.
To change,
1. From the MF Toolbox screen, click [Browse].
2. Locate a folder to save the scanned images, and then click [OK].
Q
Can I scan multiple images and save as a single PDF file?
└A
Yes, you can save multiple images as a single PDF file when scanning with MF Toolbox.
To make a single PDF file of multiple pages,
1. From the PDF mode screen of MF Toolbox, select [PDF (Multiple Pages)] in [Save as Type].
Troubleshooting
2. Scan the documents.
111
If a Power Failure Occurs
The machine cannot be used while the power supply is cut OFF.
The fax function during a power failure :
• Faxes cannot be sent or received.
• You may not be able to make a call with the external telephone
depending on your telephone.
• You may be able to receive a call with the external telephone
depending on your telephone.
IMPORTANT
We appreciate your support of The Canon Cartridge Recycling
Program.
Working together we can make a significant contribution to a
cleaner planet.
• Cartridges collected through this program are not refilled.
• You are not entitled to a tax deduction or rebate for the return
of empty cartridges.
• This program may be modified or discontinued without notice.
Data storage for when the power supply is cut OFF
Even if power is lost due to a power failure or
accidental unplugging, any sent or received
documents stored in the memory are backed up.
Recycling Used Cartridges
Canon has instituted a worldwide recycling
program for cartridges called “The Clean
Earth Campaign”. This program preserves
precious natural resources by utilizing
a variety of materials found in the used
cartridges that are of no further use, to
remanufacture new cartridges which, at
the same time, keeps the environment
cleaner by reducing landfill waste.
Complete details concerning this program
are enclosed in each Cartridge box.
U.S.A. PROGRAM
Packaging
Option A-1: Single Box Return
• Repackage the empty cartridge utilizing the wrapper and pulp
mould end-blocks from the new cartridge’s box.
• Place the empty cartridge in the box of your new cartridge.
Seal the box.
The Clean Earth Campaign
THE Canon CARTRIDGE RECYCLING
PROGRAM
The Canon Cartridge Recycling Program fulfills the first initiative
of Canon’s Clean Earth Campaign, which supports four critical
environmental areas:
• Recycling in the Workplace
• Conserving Environmental Resources
• Scientific Research and Education
• Encouraging Outdoors Appreciation
The remaining “Clean Earth” initiatives are supported in the
U.S. through sponsorships of the National Park Foundation, the
National Wildlife Federation, and The Nature Conservancy and in
Canada through donations to the World Wildlife Fund Canada and
The Nature Conservancy of Canada.
Since its inception, The Canon Cartridge Recycling Program has
collected huge amount of cartridges that otherwise would have
been discarded into landfills or similar facilities.
Instead, this rapidly growing program returns used cartridges to
the manufacturing process, thus conserving an array of resources.
Becoming a part of this worthwhile program is easy. When your
cartridge is of no further use, simply follow the instructions
detailed for U.S. or Canadian residents.
112
Option B: Volume Box Return
We encourage you to use this option as a more efficient way to
ship cartridges.
• Place as many cartridges as possible into one box.
Carefully seal the box with tape;
or
• Call 1-800-OK-Canon to receive your free eight cartridge
collection box.
Option A-2: Multiple Box Return
We encourage you to use this option as a more efficient way to
ship cartridges.
• Complete Option A-1.
• Bundle multiple cartridge boxes together securely with tape.
Please be sure that the shipment does not exceed UPS
specifications.
Maximum weight = 70 lb. (31.8 kg)
Maximum length = 108” (2,743 mm)
Maximum girth (length + 2 x width + 2 x height) = 130” (3,302 mm)
If your shipment exceeds the above limits, please call 1-800-OKCanon for special shipping information.
Please Note:
Do not send defective cartridges for replacement.
Defective cartridges under warranty should be exchanged
by an authorized dealer or service facility as provided in the
warranty.
• Place your eight individually packaged boxes of empty
cartridges into the Canon collection box. Seal the box.
• Apply the Canon Canada Inc./Canada Post label provided in this
brochure.
• Canon’s labels are specially marked so that Canon pays the
postage.
• Deliver to any local Canada Post outlet or franchise. Customers
who hold a Commercial pick-up agreement with Canada Post
may have their collection box picked up.
Shipping
Apply the UPS authorized returning label provided in this guide.
Residents of Alaska and Hawaii, Do not use the UPS authorized
returning label. For Alaska and Hawaii: Canon set up alternative
mail service with the U.S. Postal Service.
Please call 1-800-OK-Canon to receive U.S. Postal Service
merchandise returning label.
• Give the shipment to your UPS driver when you receive your
next regular delivery; (UPS may charge a fee for customers who
call UPS to pick up a cartridge shipment if they do not already
have a delivery scheduled.)
or
• Take the shipment to your local UPS receiving point.
Working to preserve endangered species is a long-standing Canon
interest.
To this end, for every cartridge collected, Canon Canada donates
$1, shared equally between World Wildlife Fund Canada and the
Nature Conservancy of Canada. This donation is utilized in Canada.
• For further information about The Clean Earth Campaign in
Canada, please call or write to Canon.
1-800-667-2666
Canon Canada Inc.
Corporate Customer Relations
6390 Dixie Road
Mississauga, ON L5T 1P7
Important Safety Instructions
CANADA PROGRAM-CANADA PROGRAMME
Option A: Single Box Return
• Repackage the empty cartridge utilizing the wrapper and pulp
mould end-blocks from the new cartridge’s box.
• Place the empty cartridge in the box of your new cartridge.
Seal the box.
• Apply the Canon Canada Inc./Canada Post label provided in this
brochure. Canon’s labels are specially marked so that Canon
pays the postage.
• Deposit your empty cartridge in any full size street mailbox or
take it to your local Canada Post outlet or franchise.
Option B: Volume Box Return (eight or more cartridges)
We encourage you to use this option as a more efficient way to
ship cartridges.
• Call 1-800-667-2666 to receive your free Canon collection box
kit.
• The collection box can accommodate eight individual cartridge
boxes.
Please read the “Important Safety Instructions” in this manual and
in the e-Manual thoroughly before operating the machine.
As these instructions are intended to prevent injury to the user
and other persons or to prevent destruction of property, always
pay attention to these instructions and operational requirements.
Please note that you are responsible for all damages caused by
failure to follow the directions provided herein, using the
device for any purpose for which it was not intended, or repairs
or alterations made by anyone other than a Canon-approved
technician.
Installation
WARNING
• Do not install the machine near flammable substances such as
alcohol-based products or paint thinners. If these substances
come into contact to the electrical parts inside the machine
could ignite these substances and cause a fire or increase your
risk of electric shock.
• Do not place necklaces and other metal objects or containers
filled with liquid on the machine. If foreign substances come in
contact with electrical parts inside the machine, this may result
in a fire or electrical shock.
If any of these substances falls into the machine, turn off the
power to the machine immediately and contact your local
Canon dealer.
• Do not use near any medical equipment. Radiowave emitted
from this machine may interfere with medical equipments,
which may result in serious accidents.
113
CAUTION
• Do not install the machine in the following locations. Doing so
may result in personal injury, fire or electrical shock.
––Unstable location
––A location subject to excessive vibrations
––A location where block the ventilation slots (too close to walls,
bed, shaggy rug, and other similar objects)
––A damp or dusty location
––A location exposed to direct sunlight or an outside place
––A location subject to high temperatures
––A location near open flames
––A location with poor ventilation system
• Although ozone is produced by this machine is working, the
amount is too low to have any effect on the human body.
However, if you intend to use the machine for long periods of
time, ensure that the installation location is well ventilated.
• Do not connect unapproved cables to this machine. Doing so
may result in a fire or an electric shock.
Power Supply
WARNING
• Do not use power cords other than the one provided, as this can
result in a fire or electrical shock.
• Do not modify or bend the power cord and do not pull on it
with great force. Do not place heavy objects on the power cord.
Damaging the power cord may result in a fire or an electric
shock.
• Do not plug or unplug the power plug with wet hands, as this
can result in electrical shock.
• Do not use extension cords or multi-plug power strips with this
machine. Doing so may result in a fire or electric shock.
• Do not bundle up or tie up the power cord in a knot, as this can
result in a fire or electrical shock.
• Insert the power plug completely into the AC power outlet.
Failure to do so can result in a fire or electrical shock.
• Remove the power plug completely from the power outlet
during a thunder storm. Failure to do so can result in a fire,
electrical shock, or malfunction.
CAUTION
• Use only a power supply that meets the voltage requirements
listed herein. Failure to do so may result in a fire or electric
shock.
• Do not obstruct the power outlet where this machine is
connected, so that you can unplug the power cord easily in an
emergency.
Handling
WARNING
• Do not disassemble or modify the machine. There are high-
temperature and high-voltage components inside the machine
which may result in a fire or electrical shock.
• Do not allow children to touch or play with the power cord
and cables or internal or electrical parts. Doing so may result in
serious personal injury.
• Please contact an authorized Canon dealer if the machine
makes an unusual noise, emits an unusual smell, or emits smoke
or excessive heat. Continued use may result in a fire or electric
shock.
114
• Do not use flammable sprays near the machine. If flammable
substances come into contact with electrical parts inside the
machine, this may result in a fire or electric shock.
CAUTION
• For your safety, please unplug the power cord if the machine
will not be used for a long period of time.
• Use caution when opening and closing covers to avoid injury to
your hands.
• Keep hands and clothing away from the rollers in the output
area. If the rollers catch your hands or clothing, this may result in
personal injury.
• The inside of the machine and the output slot is very hot during
and immediately after use. Avoid contact with these areas to
prevent burns. Also, printed paper may be hot immediately after
being output, so use caution when handling it. Failure to do so
may result in burns.
Maintenance and Inspections
WARNING
• Turn off the machine and unplug the power cord from the
outlet before cleaning. Failure to do so may result in a fire or an
electric shock
• Unplug the power plug from the power outlet periodically and
clean the area around the base of the power plug’s metal pins
and the power outlet with a dry cloth to remove dust and grime.
When damp, accumulated dust may cause short circuiting or
fires.
• Use a damp, well wrung-out cloth to clean the machine.
Dampen cleaning cloths with water only. Do not use alcohol,
benzenes, paint thinners, or other flammable substances. If
these substances come into contact with electrical parts inside
the machine, this may result in a fire or electric shock.
• Check the power cord and plug regularly for damage. Check
the machine for rust, dents, scratches, cracks, or excessive heat
generation. Use of poorly-maintained equipment may result in a
fire or electric shock.
Consumables
WARNING
• Do not dispose of used toner cartridges in open flames. This
may cause an ignition, and result in burns or fire.
• If you accidentally spill or scatter toner, carefully wipe up the
loose toner with a damp, soft cloth and avoid inhaling any toner
dust. Never use a vacuum cleaner to clean up loose toner. Doing
so may cause a malfunction in the vacuum cleaner or result in a
dust explosion due to static discharge.
CAUTION
• Keep the toner cartridges and other consumables out of the
reach of small children. If toner is ingested, consult a physician
or poison control center immediately.
• Do not attempt to disassemble the toner cartridge. The toner
may scatter and get into your eyes or mouth. If toner gets into
your eyes or mouth, wash them immediately with cold water
and consult a physician.
• If toner spills from the toner cartridge, avoid inhaling it or
allowing it to come into contact with your skin. If the toner
comes into contact with your skin, wash immediately with soap.
If you inhale the toner or your skin becomes irritated due to
contact with the toner, consult a physician or poison control
center immediately.
Others
FCC (Federal Communications Commission)
WARNING
• If you are using a cardiac pacemaker:
Color imageCLASS MF8580Cdw: F164802
Color imageCLASS MF8280Cw: F164702
Contains Transmitter Module FCC ID: AZDFM48944
Telephone Equipment
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This machine generates a low level magnetic field. If you feel
any abnormalities in your body while using this machine, please
move away from the machine and consult your physician
immediately.
When using telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
1. Do not use this machine near water (i.e., near a bathtub, kitchen
sink, or laundry tub), or in a wet basement or near a swimming
pool.
2. Avoid using the telephone during an electrical storm, as there
may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of
the leak.
Legal Notices
Legal Limitations on the Usage of Your
Product and the Use of Images
Using your product to scan, print or otherwise reproduce certain
documents, and the use of such images as scanned, printed or
otherwise reproduced by your product, may be prohibited by law
and may result in criminal and/or civil liability.
A non-exhaustive list of these documents is set forth below. This
list is intended to be a guide only. If you are uncertain about
the legality of using your product to scan, print or otherwise
reproduce any particular document, and/or of the use of the
images scanned, printed or otherwise reproduced, you should
consult in advance with your legal advisor for guidance.
• Paper Money
• Money Orders
• Certificates of Deposit
• Postage Stamps (canceled or uncanceled)
• Identifying Badges or Insignias
• Selective Service or Draft Papers
• Checks or Drafts Issued by Governmental Agencies
• Motor Vehicle Licenses and Certificates of Title
• Travelers Checks
• Food Stamps
• Passports
• Immigration Papers
• Internal Revenue Stamps (canceled or uncanceled)
• Bonds or Other Certificates of Indebtedness
• Stock Certificates
• Copyrighted Works/Works of Art without Permission of
Copyright Owner
FCC WARNING
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
• Properly shielded and grounded cables and connectors must
be used for connection to host computers and/or peripherals in
order to meet FCC emission limits.
This equipment has been tested and found to comply
with the limits for a class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
OFF and ON, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment
and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment
should be installed and operated keeping the radiator
at least 20cm or more away from person’s body
(excluding extremities: hands, wrists, feet and ankles).
Use of shielded cables is required to comply with class
B limits in Subpart B of Part 15 of the FCC Rules. Do not
make any changes or modifications to the equipment
unless otherwise specified in this manual. If you make
such changes or modifications, you could be required
to stop operation of the equipment.
Canon U.S.A., Inc.
One Canon Park, Melville, NY 11747, U.S.A.
TEL No. 1-800-OK-CANON
115
Users in the U.S.A.
Pre-Installation Requirements for Canon Facsimile Equipment
A. Location
Supply a suitable table, cabinet, or desk for the machine. See the
e-Manual for specific dimensions and weight.
B. Order Information
1. A single telephone line (touch-tone or rotary) should be used.
2. Order an RJ11-C telephone wall jack (USOC), which should be
installed by the telephone company. If the RJ11-C wall jack is
not present, telephone/facsimile operation is not possible.
3. Order a normal business line from your telephone company’s
business representative. The line should be a regular voice
grade line or an equivalent one. Use one line per unit.
DDD (Direct Distance Dial) line
-orIDDD (International Direct Distance Dial) line if you communicate
overseas
Canon recommends an individual line following
industry standards, i.e., 2,500 (touch-tone) or 500
(rotary/pulse dial) telephones. A dedicated extension
off a PBX (Private Branch eXchange) unit without “Call
Waiting” can be used with your facsimile unit. Key
telephone systems are not recommended because
they send nonstandard signals to individual
telephones for ringing and special codes, which may
cause a facsimile error.
C. Power Requirements
The machine should be connected to a standard 120 volt AC,
three-wire grounded outlet only.
Do not connect this machine to an outlet or power line
shared with other appliances that cause “electrical noise.” Air
conditioners, electric typewriters, copiers, and machines of
this sort generate electrical noise that often interferes with
communications equipment and the sending and receiving of
documents.
Connection of the Equipment
This equipment complies with Part 68 of the FCC rules and the
requirements adopted by the ACTA. On the rear panel of this
equipment is a label that contains, among other information, a
product identifier in the format US:AAAEQ##TXXXX. If requested,
this number must be provided to the telephone company.
The REN (Ringer Equivalence Number) is used to determine the
number of devices that may be connected to a telephone line.
Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most, but not all areas,
the sum of the RENs should not exceed five (5.0).
To be certain of the number of devices that may be connected to a
line, as determined by the total RENs, contact the local telephone
company. The REN for this product is part of the product identifier
that has the format US: AAAEQ##TXXXX. The digits represented by
## are the REN without a decimal point (e.g., 10 is a REN of 1.0).
An FCC compliant telephone line cable and modular plug is
provided with this equipment. This equipment is designed to be
connected to the telephone network or premise wiring using a
compatible modular jack that is Part 68 compliant.
116
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subjected to
state tariffs.
In Case of Equipment Malfunction
Should any malfunction occur which cannot be corrected by the
procedures described in this guide or the e-Manual, disconnect
the equipment from the telephone line cable and disconnect the
power cord.
The telephone line cable should not be reconnected or the power
switch turned ON until the problem is completely resolved. Users
should contact Canon Authorized Service Facilities for servicing
of equipment, Information regarding Authorized Service Facility
locations can be obtained by calling Canon Customer Care Center
(1-800-OK-CANON).
Rights of the Telephone Company
If this equipment (Color imageCLASS MF8580Cdw/MF8280Cw)
causes harm to the telephone network, the telephone company
may temporarily disconnect service. The telephone company also
retains the right to make changes in facilities and services that may
affect the operation of this equipment. When such changes are
necessary, the telephone company is required to give adequate
prior notice to the user.
However, if advance notice is not possible, the telephone
company will notify the customer as soon as possible. Also, the
customer will be advised of his/her right to file a complaint with
the FCC if he/she believes it is necessary.
WARNING
The Telephone Consumer Protection Act of 1991 makes it
unlawful for any person to use a computer or other electronic
device, including FAX machines, to send any message unless such
message clearly contains in a margin at the top or bottom of each
transmitted page or on the first page of the transmission, the date
and time it is sent and an identification of the business or other
entity, or other individual sending the message and the telephone
number of the sending machine or such business, other entity, or
individual.
(The telephone number provided may not be a 900 number or
any other number for which charges exceed local or long-distance
transmission charges.)
In order to program this information into your
machine, you should complete the procedure for
registering your name, unit’s telephone number, time,
and date in Getting Started.
Users in Canada
Pre-Installation Requirements for Canon Facsimile Equipment
A. Location
Supply a suitable table, cabinet, or desk for the machine. See the
e-Manual for specific dimensions and weight.
B. Order Information
1. A single telephone line (touch-tone or rotary) should be used.
2. Order a CA11A modular jack, which should be installed by
the telephone company. If the CA11A jack is not present,
installation cannot occur.
3. Order a normal business line from your telephone company’s
business representative. The line should be a regular voice
grade line or an equivalent one. Use one line per unit.
DDD (Direct Distance Dial) line
-orIDDD (International Direct Distance Dial) line if you communicate
overseas
Canon recommends an individual line following
industry standards, i.e., 2,500 (touch-tone) or 500
(rotary/pulse dial) telephones. A dedicated extension
off a PBX (Private Branch eXchange) unit without “Call
Waiting” can be used with your facsimile unit. Key
telephone systems are not recommended because
they send nonstandard signals to individual
telephones for ringing and special codes, which may
cause a facsimile error.
C. Power Requirements
The power outlet should be a three-prong grounded receptacle
(Single or Duplex). It should be independent from copiers, heaters,
air conditioners, or any electric equipment that is thermostatically
controlled. The rated value is 115 volts and 15 amperes. The CA11A
modular jack should be relatively close to the power outlet to
facilitate installation.
Notice
• This product meets the applicable Industry Canada technical
specifications.
• The Ringer Equivalence Number is an indication of the
maximum number of devices allowed to be connected to a
telephone interface. The termination of an interface may consist
of any combination of devices subject only to the requirement
that the sum of the RENs of all the devices does not exceed five.
• The REN of this product is 1.0.
• Before installing this equipment, users should ensure that
it is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be
installed using an acceptable method of connection. In some
cases, the company’s inside wiring associated with a single line
individual service may be extended by means of a certified
connector assembly (telephone extension cord). The customer
should be aware that compliance with the above conditions
may not prevent deterioration of service in some situations.
• Repairs to certified equipment should be made by an
authorized Canadian maintenance facility designated by
the supplier. Any repairs or alterations made by the user to
this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to
disconnect the equipment.
• Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines, and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas.
CAUTION
Users should not attempt to make such connections themselves,
but should contact the appropriate electric inspection authority,
or electrician, as appropriate.
This equipment complies with the Canadian ICES-003
Class B limits.
Utilisation au Canada
Conditions à Remplir Préalablement à L’installation d’un
Télécopieur Canon
A. Emplacement
Prévoir une table, un meuble, ou un bureau suffisamment solide et
de taille appropriée (voir le chapitre 11, Annexe (Appendix), pour
les indications de poids et dimensions).
B. Installation téléphonique
1. Une seule ligne téléphonique (tonalités ou impulsions) doit être
utilisée.
2. Il faut commander un jack modulaire CA11A qui sera installé par
la compagnie téléphonique. Sans ce jack, la mise en place serait
impossible.
3. Si vous vous abonnez à une nouvelle ligne, demandez une
ligne d’affaires normale de qualité téléphonique courante ou
équivalente. Prenez un abonnement d’une ligne par appareil.
Ligne automatique interurbaine
ou
Ligne automatique internationale (si vous communiquez avec les
pays étrangers)
Canon vous conseille d’utiliser une ligne individuelle
conforme aux normes industrielles, à savoir:
ligne téléphonique 2,500 (pour appareil à clavier)
ou 500 (pour appareil à cadran/impulsions). Il est
également possible de raccorder ce télécopieur à
un système téléphonique à poussoirs car la plupart
de ces systèmes émettent des signaux d’appel non
normalisés ou des codes spéciaux qui risquent de
perturber le fonctionnement du télécopieur.
C. Condition d’alimentation
Raccordez le télécopieur à une prise de courant plus terre à trois
branches, du type simple ou double, et qui ne sert pas à alimenter
un copieur, un appareil de chauffage, un climatiseur ou tout autre
appareil électrique à thermostat.
L’alimentation doit être de 115 volts et 15 ampères. Pour faciliter
l’installation, le jack CA11A doit être assez proche de la prise de
courant.
Remarques
• Le présent matériel est conforme aux spécifications techniques
applicables d’Industrie Canada.
• Avant d’installer cet appareil, l’utilisateur doit s’assurer qu’il
est permis de le connecter à l’équipement de la compagnie
de télécommunication locale et doit installer cet appareil en
utilisant une méthode de connexion autorisée. Il se peut qu’il
faille étendre la circuiterie intérieure de la ligne individuelle
d’abonné, qui a été installée par la compagnie, au moyen d’un
jeu de connecteurs homologués (rallonge téléphonique).
• L’attention de l’utilisateur est attirée sur le fait que le respect des
conditions mentionnées ci-dessus ne constitue pas une garantie
contre les dégradations de qualité du service dans certaines
circonstances.
• L’indice d’équivalence de la sonnerie (IES) sert à indiquer le
nombre maximal de terminaux qui peuvent être raccordés à
une interface téléphonique. La terminaison d’une interface
peut consister en une combinaison quelconque de dispositifs,
à la seule condition que la somme d’indices d’équivalence de la
sonnerie de tous les dispositifs n’excède pas 5.
117
• Le nombre d’équivalents sonnerie (REN) de ce produit est 1,0.
• Les réparations sur un appareil certifié doivent être faites
par une société d’entretien canadienne autorisée par le
Gouvernement canadien et désignée par le fournisseur. Toute
réparation ou modification que pourrait faire l’utilisateur de
cet appareil, ou tout mauvais fonctionnement, donne à la
compagnie de télécommunication le droit de débrancher
l’appareil.
• Pour sa propre protection, l’utilisateur doit s’assurer que
les prises de terre de l’appareil d’alimentation, les lignes
téléphoniques et les tuyaux métalliques internes, s’il y en a, sont
bien connectés entre eux. Cette précaution est particulièrement
importante dans les zones rurales
CAUTION
Au lieu d’essayer de faire ces branchements eux-mêmes, les
utilisateurs sont invités à faire appel à un service d’inspection
faisant autorité en matière d’électricité ou à un électricien, selon
le cas.
Respecte les limites de la classe B de la NMB-003 du
Canada.
Laser Safety
This machine complies with 21 CFR Chapter 1 Subchapter J as
a Class 1 laser product under the U.S. Department of Health
and Human Services (DHHS) Radiation Performance Standard
according to the Radiation Control for Health and Safety Act of
1968. This means that the machine does not produce hazardous
radiation.
Since radiation emitted inside the machine is completely confined
within protective housings and external covers, the laser beam
cannot escape from the machine during any phase of user
operation.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the
U.S. Food and Drug Administration implemented regulations
for laser products on August 2, 1976. These regulations apply to
laser products manufactured from August 1, 1976. Compliance is
mandatory for products marketed in the United States.
CAUTION
Use of controls, adjustments, or performance of procedures
other than those specified in this manual may result in hazardous
radiation exposure.
The label is attached to the laser scanner machine inside the
machine and is not in a user access area.
118
Memo
119
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON MARKETING JAPAN INC.
16-6, Konan 2-chome, Minato-ku, Tokyo 108-8011, Japan
CANON U.S.A., INC.
One Canon Park, Melville, NY 11747, U.S.A.
CANON EUROPA N.V.
Bovenkerkerweg 59, 1185 XB Amstelveen, The Netherlands
CANON CHINA CO. LTD.
15F Jinbao Building No.89, Jinbao Street, Dongcheng District, Beijing 100005, PRC
CANON SINGAPORE PTE LTD
1 HarbourFront Avenue, #04-01 Keppel Bay Tower, Singapore 098632
CANON AUSTRALIA PTY LTD
1 Thomas Holt Drive, North Ryde, Sydney NSW 2113, Australia
Serial No.
CANON GLOBAL WORLDWIDE SITES
Date of Purchase
http://www.canon.com/
FT6-0109 (000)
XXXXXXXXXX
© CANON INC. 2013
PRINTED IN CHINA
