presentation &
communication
range guide
2014
www.pro.sony.eu
2
Education
4-5
Corporate
6-7
Home Cinema
8-9
Retail
10-11
Vision Presenter
12-13
Professional Displays
14-17
Home Cinema Projectors
18-21
Education and Business Projectors
22-37
Visual Communications
38-47
Professional Audio
48-49
Visual Simulation and Visual Entertainment
50-55
3
Education
delivering the
future of AV
for education
Just as teaching methods evolve, we design
our AV technology for the education sector
to meet specific requirements. Working closely
with teachers and students, we have created
a comprehensive new range of education
projectors, displays and bespoke classroom
capture solutions. Plus, our all Sony smart
presentation tool Vision Presenter transforms
learning. We ensure schools, universities
and auditoriums have reliable, long-lasting
equipment that captures attention and
enhances learning, delivering the future
of AV in education.
For further information, visit
www.pro.sony.eu/education
4
Product Highlights
E, S and F-Series Projectors
Vision Presenter
5
Corporate
delivering
the future of
corporate AV
Across the corporate sector, our vision for
the future of AV is to equip businesses of
all sizes with enabling technology that
helps them work smarter and creates
business-driving impact. We create
affordable solutions that meet every
business need, from a corporate live
meeting solution and DWZ series audio
presentation systems to a networked
range of projectors across all meeting
rooms and auditoriums. And from
individual BRAVIA Professional Displays to
stylish, portable projectors for sales teams.
6
6
Product Highlights
D-Series Projectors
C-Series Projectors
F-Series Projectors
Professional Audio
BRAVIA Professional Displays
Vision Presenter
7
Home Cinema
delivering the
future of AV
at home
8
More immersive. More exciting.
More entertaining. Delivering the future
of AV technology for the home means
delivering deeper, richer visual and aural
experiences. Which is precisely what the
Sony range does.
Our complete portfolio of 4K, Full HD and 3D Home Cinema
Projectors incorporates a host of innovative technologies
developed by Sony.
We have a new addition to our 4K Home Cinema projector range
with the VPL-VW300ES, now bringing more than four times the
resolution of Full HD to even more homes. Plus, our VPL-HW40ES
offers movie fans the next level of home entertainment.
From our advanced SXRD panels, Reality Creation, Motionflow and
Dynamic Lamp Control we’re providing enhanced entertainment
that really does bring the cinematic experience home.
Product Highlights
VPL-VW1100ES
The ultimate 4K Home Cinema Projector
VPL-VW500ES 4K Home Cinema Projector
VPL-VW300ES
4K Home Cinema Projector
VPL-HW55ES
Full HD 3D Home Cinema Projector
VPL-HW40ES
Full HD 3D Home Cinema Projector
9
Retail
delivering the
future of AV
for retail
10
Creating compelling consumer experiences is critical within
the retail environment. The Sony vision for the future of
retail AV focuses on driving sales by delivering high-impact
engagement. Working with our retail partners for definitive
insights into business needs and customer motivation, our
site-specific solutions range from edge blend and portrait
projectors to indoor and outdoor displays and a HTML5
digital signage solution.
Product Highlights
BRAVIA HTML5 Digital Signage Solution
Affordable Networked (boxless) Digital Signage
F-Series Projectors
FWD S-Series Public Displays
11
Vision Presenter
combine
everything,
inspire
everyone
Vision Presenter: PWA-VP100
The PWA-VP100 Vision Presenter is a
complete solution that brings together
a wide range of multimedia sources to
create big, bold, dynamic presentations
that you control. It’s perfect for business,
education or visitor attractions, replacing
uninspiring presentations with an exciting,
engaging and interactive audience
experience.
• Effortlessly combine and arrange
multiple types of content into one
presentation.
• Blend live camera sources, PowerPoint
presentations, web content, movies,
video conferencing systems and more
in a variety of layouts.
• Bring corporate meetings, university
lectures or big events to life.
12
A breakthrough presentation solution
•Flexible layout: display content in a variety of layouts, either on
a 4K-resolution TV/projector screen or double-sized HD-resolution
screen with blending projection.
•Display multiple video sources: a maximum of five Full HD
(1920 x 1080) videos can be played simultaneously.
•Easy to operate: control through a wireless mouse (such as Air
Mouse) and Android or iOS tablet devices for intuitive operation.
•Control Sony PTZ (Pan, Tilt, Zoom) cameras: SRG/BRC Series PTZ
cameras supported by VISCA-over-IP protocol through the system.
•Full system support from Sony: as all elements in this solution are
from Sony, it ensures smooth and reliable operation and support.
Find out more at pro.sony.eu/VP
13
Professional Displays
BRAVIA
Professional
Displays
Professional Displays you can’t ignore
Bring the reputation and style of
BRAVIA to your organisation. Whether
it’s a super-size 4K screen for a
conference room, Full HD displays
for in-store signage or high-quality
monitors for offices or schools, BRAVIA
Professional has the right solution.
14
FWD-40W600P
FWD-60W600P
FWD-48W600P
Full HD LED Displays
• Versatile control options (RS232C and IP)
• Built-in HTML5 browser for simple,
cost-effective digital signage
• Hotel Mode: lock settings and copy
easily to other displays
• High contrast, high efficiency Edge
LED backlight with Frame Dimming
• Plug-in and go: D-Sub15-pin and HDMI
input connections
• Compatible with RS232C-HDMI
converter box (optional accessory
CBX-H11/1)
• Screen-mirroring for smartphones and
tablets – transfer videos, photos and
more to your TV screen
• Energy-saving ambient light sensor
• Landscape presentation
Product
FWD-40W600P
FWD-48W600P
FWD-60W600P
Screen Size
40”
48”
60”
Application
indoor
indoor
indoor
15
15
Professional Displays
BRAVIA Professional 4K
55, 65 and 85” LED TV
The highest resolution for professional settings
Outstanding 4K resolution and all the acclaimed performance and style
of BRAVIA. Perfect for professional environments, with the highest quality
4K images and ultra-sleek design.
FWD-85X9600P
16
4K resolution with 3D capability
• Supplied with HDMI-RS232C converter
box (CBX-H11/1) for external control
• Built-in HTML5 for dynamic, box-free
signage – create your own,
media-rich content
• Includes two pairs of 3D glasses
• X-Reality PRO super-resolution
technology: upscales images for 4K
• 3-year warranty for professional use
• Integrated media player: Play videos
and other media content including 4K
direct from USB flash memory or live
streaming in a wide range of formats.
Product
FWD-55X8600P
FWD-65X8600P
FWD-85X9600P
Screen size
55”
65”
85”
Application
indoor
indoor
indoor
FWD-65X8600P
FWD-55X8600P
17
17
Home Cinema Projectors
4K and 3D Full
HD Projectors
If you’re serious about cinema,
you’ll understand the power of
4K resolution. It’s more than 4x
the quality of Full HD, producing
a stunning level of detail. Now
you can bring home the truly
immersive experience of a top
movie theatre with our 4K Home
Cinema Projectors.
VPL-VW500ES
4K Home Cinema Projector
•Advanced SXRD Panel for
4096 x 2160 native 4K resolution
•High dynamic contrast ratio of 200,000:1
•High brightness: 1,700 Lumens
•Reality Creation: upscales 2D
and 3D content for an outstanding
4K experience
18
•Unique Triluminos technology: wider
colour range for greater purity, depth
and realism
•Compact design for flexible installation
•3-year PrimeSupport cover
VPL-VW300ES
4K Home Cinema Projector
•Advanced SXRD Panel for
4096 x 2160 native 4K resolution
• High brightness: 1,500 Lumens
• Reality Creation: upscales 2D
and 3D content for an outstanding
4K experience
• Easy to control: compatible with
Creston Connected and Control 4
SDDP for easy control and enhanced
home automation capability
• Compact and functional design
for flexible installation
• 3-year PrimeSupport cover
VPL-VW300ES
19
Home Cinema Projectors
VPL-VW1100ES
4K Home Cinema Projector – flagship model
•Displays up to 4K/60p, for a smoother
viewing experience with greater
colour and realism
•4096 x 2160 native 4K resolution
•Advanced SXRD Panel and Iris3
technology achieve an incredible
dynamic contrast ratio of 1,000,000:1
•Exceptional brightness: 2,000 lumens
•Reality Creation: upscales 2D and 3D
content for an outstanding 4K experience
• Unique Triluminos technology:
wider colour range for greater purity,
depth and realism
•Suitable for a larger, dedicated
screening room
•3-year PrimeSupport cover
VPL-HW55ES
Full HD 3D Home Cinema Projector
Crisp, sharp, detailed Full HD 3D. A fantastic option for any movie lover looking for an
incredible cinematic experience at home, far beyond the reach of TV. Our advanced
SXRD panels create an ultra-smooth picture, while Reality Creation dramatically
upscales and enhances Full HD content.
•1920 x 1080 Full HD resolution
•Advanced SXRD Panel and Iris3
technology achieve a high dynamic
contrast ratio of 120,000:1
•High brightness: 1,700 lumens
•Reality Creation: upscales 2D
and 3D content
VPL-VW1100ES
20
•Long-lasting lamp: up to 5,000
hours (roughly 60% longer than our
standard Home Cinema Projectors)
•Available in black or white
•RF 3D transmitter and wireless HDMI
Unit compatible (RF 3D emitter and
glasses are optional accessories)
•3-year PrimeSupport cover
VPL-HW55ES
VPL-HW40ES
Affordable Full HD 3D Home Cinema Projector
A fantastic option for movie fans looking for a cinematic experience at home that
goes so much further than TV. With 1,700 lumens colour brightness, you can enjoy your
favourite films at their best, in 3D or 2D. Bright Cinema and Bright TV modes also ensure
optimum brightness and superb, rich colour quality.
•1920 x 1080 Full HD resolution
•Advanced cinema-quality SXRD
panels for super-sharp images
•Reality Creation
for the best
Full HD picture possible
•Wide lens shift for flexible installation
•High brightness of 1,700
lumens brightness
•Extremely low fan noise –
21db noise with improved tone
•Contrast Enhancer function for a
dynamic picture
•Built-in IR 3D transmitter
•3-year PrimeSupport cover
VPL-HW40ES
21
Education and Business Projectors
22
Projector Technologies
Every one of Sony Professional’s business projectors incorporates a 3-chip
projection system. When the LCD device is used, it is called the 3LCD
projection system. This system can project significantly bright and natural
images. Yet to maximize the performance of the 3-chip projection system,
the display device itself must provide excellent resolution, contrast, and
luminance. To ensure this, Sony developed “BrightEra” LCD panels using
the most advanced manufacturing technology available.
Sony has developed and manufactured
its own LCD panels (the largest on the
market) for many years. These 3LCD panels
are mounted onto a prism block, which
combines the red, green and blue light
signals into one picture. 3LCD projectors
feature a higher level of detail, a brighter
picture and much more natural colour.
Now on our 4th generation of technology,
BrightEra enables Sony business projectors
to feature brighter projections than ever
before using advances such as inorganic
alignment film, pixels with a large aperture
ratio and an extremely deep black level
with a high contrast ratio through the
‘Normally Black Mode’ system.
Higher level of detail
Brighter images
More natural colour
Inorganic alignment film
Pixels with a large aperture ratio
‘Normally Black Mode’ system
23
D100 Series Desktop Projectors
Clear, crisp presentation for
corporate meeting rooms
Designed for the corporate sector, D-Series projectors deliver clear, crisp
presentations with business-driving impact, in any meeting room. Selected
models are now wireless-ready for greater integration with PC’s, Macs,
smartphones and tablets (via VUEMagic App for iOS devices).
Overview
•Weighs just 2.5kg: easy to set-up
and power down
•Three brightness modes:
High, Standard, Low
•Selected models are wireless ready for
PC, Smartphone and tablet integration
(via VUEMagic App for iOS devices)
•2-year PrimeSupport with
1 year (1,000 hours) lamp cover
•Extended lamp life: up to 10,000 hours
•Power-saving features: ECO and Auto
Power modes, Lamp Dimming
24
•Optional PrimeSupport Plus available
WXGA resolution models
These models have a native WXGA (1280 x 800) 16:10 resolution
Products
VPL-DW122
VPL-DW127
Brightness
(White/Colour)
2,600
2,600
Contrast Ratio
3,000:1
3,000:1
Throw Ratio
1.36 to 1.77
1.36 to 1.77
(wireless ready)
XGA resolution models
These models have a native XGA (1024 x 768) 4:3 resolution
Products
VPL-DX122
VPL-DX127
VPL-DX142
VPL-DX147
Brightness
(White/Colour)
2,600
2,600
3,200
3,200
Contrast Ratio
3,000:1
3,000:1
3,000:1
3,000:1
Throw Ratio
1.47 to 1.77:1
1.47 to 1.77:1
1.37 to 180:1
1.37 to 180:1
VPL-DW122
VPL-DX127
(wireless ready)
VPL-DW127
VPL-DX142
(wireless ready)
VPL-DX122
VPL-DX147
25
E200 Series Portable Projectors
Engaging presentations for the classroom
With optional wireless capability, our energy-efficient E-Series Projectors
keep students engaged and save you money. Designed with input from
teachers, they’re made for today’s classrooms with great picture quality
and smart, cost-saving features.
Overview
•Compact with an A4-sized footprint;
quick, easy set-up
•Optional wireless: share homework,
images and graphics from mobile
devices like smartphones and tablets
•Choice of Picture Modes: optimises
viewing from any source
•Power-saving ECO features: Auto
Dimming, Lamp Dimming, Picture
Mute (instant on/off) plus ECO Guage
•3-year PrimeSupport with 3 years
(3,000 hours) lamp cover
•Optional Prime Support Plus
•Extended lamp life: up to 10,000 hours
VPL-EW235
VPL-EX235
26
VPL-EW255
VPL-EX255
VPL-EW295
VPL-EX295
WXGA resolution models
These models have a native WXGA (1280 x 800) 16:10 resolution
Products
VPL-EW235
VPL-EW255
VPL-EW295
Brightness
(White/Colour)
2,700
3,200
3,800
Contrast Ratio
2,700:1
2,700:1
3,700:1
Throw Ratio
1.37:1 to 1.80:1
1.40:1 to 2.27:1
1.10:1 to 1.79:1
XGA resolution models
These models have a native XGA (1024 x 768) 4:3 resolution
Products
VPL-EX235
VPL-EX255
VPL-EX295
Brightness
(White/Colour)
2,800
3,300
3,800
Contrast Ratio
3,300:1
3,300:1
3,300:1
Throw Ratio
1.37:1 to 1.80:1
1.40:1 to 2.27:1
1.40:1 to 2.27:1
27
S-Series Short Throw and
Ultra Short Throw Projectors
Shorter throw distance for smaller spaces
Ideal for smaller classrooms, S-Series projectors are easy to operate with
a long lamp life and ECO features to give you high quality with a low
total cost of ownership. All models have optional wireless capability, while
two Ultra Short Throw models have interactive features including
videocapture and video conferencing – perfect for interactive learning.
Short Throw Models: VPL-SX225, VPL-SX235, VPL-SW225 & VPL-SW235
Our Short Throw projectors allow you to project a high quality image from
approximately 75cm away.
VPL-SX225
VPL-SW225
VPL-SX235
VPL-SW235
Overview
•10,000 Hours lamp life
•Off and Go, Picture Freeze
•ECO Mode Key
•3-year PrimeSupport with 3 years
(3,000 hours) lamp cover
•3 different brightness modes
Products
VPL-SX225
VPL-SX235
VPL-SW225
VPL-SW235
Resolution
XGA (1024x768)
4:3
XGA (1024x768)
4:3
WXGA (1280x800)
16:10
WXGA (1280x800)
16:10
Brightness
(White/Colour)
2,700
3,200
2,600
3,000
Contrast Ratio
3,000:1
3,000:1
3,000:1
3,000:1
Throw Ratio
0.46:1
0.46:1
0.46:1
0.46:1
28
Ultra Short Throw Models
Our Ultra Short Throw projectors give you a high quality image from an even
closer distance.
•8,000 hours lamp life
•Lens shift function
•ECO Lamp Dimming: reduces
brightness and power consumption
•3-year PrimeSupport with 3 year
(3,000 hours) lamp cover
•ECO Picture Mute: instant on/off
feature
•Optional PrimeSupport Plus available
VPL- SW630
VPL- SW630C
VPL-SW620
VPL-SW620C
VPL-SX630
Interactive models
As well as all of the features above, the VPL-SW620C and VPL-SW630C
offer Dual Pen interactivity, Video Capture and Videoconferencing.
Products
VPL-SX630
VPL-SW620
VPL-SW630
VPL-SW620C
VPL-SW630C
Resolution
XGA
(1024x768)
4:3
WXGA
(1280x800)
16:10
WXGA
(1280x800)
16:10
WXGA
(1280x800)
16:10
WXGA
(1280x800)
16:10
Brightness (White/Colour)
3,200
2,600
3,100
2,600
3,100
Contrast Ratio
3,000:1
3,000:1
3,000:1
3,000:1
3,000:1
Throw Ratio
0.26-0.27:1
0.26-0.27:1
0.26-0.27:1
0.26-0.27:1
0.26-0.27:1
29
C-Series Installation Projectors
Installation projectors for larger boardrooms
and classrooms
With high brightness, low maintenance and powerful performance,
the C-Series is ideal for larger teaching spaces and corporate venues.
Overview
• XGA, WXGA and WUXGA resolution
•Vertical and horizontal lens shift
•HDBaseT (VPL-CH355 and VPL-CH375)
•3-year PrimeSupport with 1 year
(1,000 hours) lamp cover
• Image Warping function
•Optional PrimeSupport Plus available
•ECO Mode features
•Long lamp life
VPL-CX235
VPL-CW255
VPL-CW275
Products
VPL-CH375
VPL-CH355
VPL-CX235
VPL-CW255
VPL-CW275
Resolution
WUXGA
WUXGA
XGA
WXGA
WXGA
Brightness
(White/Colour)
5,000
4,000
4,100
4,500
5,100
Lamp life*
3,500
5,000
5,000
5,000
4,000
Contrast ratio
2,500:1
2,500:1
3,100:1
3,700:1
3,000:1
Throw ratio
1.5:1 to 2.2:1
1.5:1 to 2.2:1
1.66 to 2.41:1
1.32 to 1.91:1
1.32 to 1.91:1
*In low brightness mode
30
VPL-CH355*
VPL-CH375*
*HDBT compatible for simple connectivity
31
F-Series Installation Projectors
High performance projectors for lecture
halls and conferences
Designed to meet the needs of the most demanding venues, the
F-Series offers high brightness, the best resolution and a host of
features to boost performance.
3LCD Laser Projectors
No lamp. No maintenance. No downtime. We introduced the world’s first 3LCD laser,
the VPL-FHZ55, delivering game-changing performance and reliability for mission
critical applications. Now our latest model, the VPL-FHZ700L is our brightest ever
projector at 7,000 lumens.
VPL-FHZ700L
VPL-FHZ55
The VPL-FHZ55 and VPL-FHZ700L: 20,000 hours continuous
service with high brightness
•Sony 3LCD BrightEra™ Panel Technology
•Up to 20,000 hours operation with
virtually no maintenance
•Brightness: VPL-FHZ55 - 4,000 lumens;
VPL-FHZ700L - 7,000 lumens
•Native WUXGA 16:10 resolution:
(1920 x 1200)
•No lamp: Mercury-free
•Contrast ratio: up to 8,000:1
•360° free-angle installation capability
32
•Create super-size displays
with Edge Blending
•Project onto non-flat surfaces
with Image Warping
•Project Side by Side images: ideal for
video conferencing, image comparison
•DICOM GSDF Simulation mode
(for medical education use)
•ECO features
•5-year PrimeSupport package
Other WUXGA models
•One-way Airflow and Quad Filter System
•Native WUXGA (1920 x 1200)
16:10 resolution
•ECO features
•DICOM GSD Simulation mode
(for medical use)
•3-year PrimeSupport with 1 year
(1,000 hours) lamp cover
•Lamp/Filter replacement/cleaning
cycles synchronised
•Optional PrimeSupport Plus available
•Side by side image projection
VPL-FH31
VPL-FH36
VPL-FH500L
Products
VPL-FH31
VPL-FH36
VPL-FH500L
VPL-FHZ55
VPL-FHZ700L
Brightness
(White/Colour)
4,300
5,200
7,000
4,000
7,000
Lamp life*
(hours)
4,000
3,500
8,000
20,000**
20,000 hours
(87,000)***
Contrast Ratio
2,000:1
2,000:1
2,500:1
8,000:1
8,000:1
Throw Ratio
1.39 to 2.23:1
1.39 to 2.23:1
According
to lens
1.39 to 2.23:1
1.39 to 2.23:1
Wide zoom
range
x1.6
X1.6
According to
lens
X1.6
X1.6
(Auto-Switching Dual
Lamp capacity)
*At standard brightness mode
**Laser light source
*** Operating in Extended mode for 24/7 applications
33
F-Series Installation Projectors
XGA resolution models
•Native XGA (1024 x 768) 4:3 resolution
•ECO features
•Lamp/Filter replacement/cleaning
cycles synchronised
•3-year PrimeSupport with 1 year
(1,000 hours) lamp cover
•One-way Airflow and Quad Filter
System
•Optional PrimeSupport Plus available
Products
VPL-FX30
VPL-FX35
VPL-FX500L
Brightness (White/Colour)
4,200
5,000
7,000
Lamp life*
5,000
4,000
8,000
Contrast ratio
2,000:1
2,000:1
2,500:1
Throw ratio
1.43 to 2.27:1
1.43 to 2.27:1
According to lens
Wide zoom range
x1.6
X1.6
According to lens
VPL-FX30
VPL-FX500L
(Auto-Switching Dual
Lamp capacity)
*At standard brightness mode
VPL-FX35
34
Accessories: Lenses
From standard, fixed, short, middle and long focus to mid, wide and tele
zoom, our range of projector lenses meets the needs of every application.
Optional lenses for models: VPL-FH31, VPL-FH36, VPL-FHZ55, VPL-FX30 and VPL-FX35.
VPLL-1008
VPLL-Z1024PK
Fixed Short Focus Lens
Throw Ratio: 0:08:1
Requires special adaptor
Middle Focus Zoom Lens
Throw Ratio: 2.34 to 3.19
VPLL-2007
VPLL-Z2009
Fixed short focus Lens
Throw Ratio: 0.65:1
Short Focus Lens
Throw Ratio: 0.85 to 1.0:1 WUXGA
VPLL-Z1032PK
Long Focus Zoom Lens
Throw Ratio: 3.18 to 4.84
VPLL-1008
VPLL-2007
VPLL-Z1024PK
VPLL-Z1032PK
VPLL-Z2009
35
F-Series Installation Projectors
Lenses for VPL-FX500L, VPL-FH500L and VPL-FHZ700L
Premium series
Products
VPLL-Z4007
VPLL-4008
VPLL-Z4011
VPLL-Z4015
VPLL-Z4019
VPLL-Z4025
VPLL-Z4045
Throw Ratio
VPL-FX500L
0.69 to
0.81:1
1.1
1.4 to 2.1:1
2.06 to
2.72:1
2.67 to
3.42:1
3.36 to
6.23:1
6.19 to
10.72:1
Throw Ratio
VPL-FH500L/
VPL-FHZ700L
0.68 to
0.8:1
1.08
1.38 to
2.06:1
2.02 to
2.67:1
2.62 to
3.36:1
3.30 to
6.11:1
6.08 to
10.52:1
Value series
Products
VPLL-FM22PK
VPLL-ZM42PK
VPLL-ZM102PK
VPLL-ZM101PK
Throw Ratio VPL-FH500L
0.87
1.83 to 2.32:1
3.28 to 4.83:1
N/A
Throw Ratio VPL-FX500L
0.89
1.87 to 2.30:1
3.35 to 4.92:1
4.47 to 6.58:1
Throw ratio VPL-FHZ700L
N/A
1.87 to 2.30:1
N/A
N/A
Please note:
1: Models ending in PK include a special adaptor.
2: VPLL-FM22PK, VPLL-ZM102PK and VPLL-ZM101PK are not available for the VPL-FHZ700L.
VPLL-4008
VPLL-Z4019
36
VPLL-Z4011
VPLL-Z4015
VPLL-Z4025
VPLL-Z4007
VPLL-Z4045
Projector Input/Output Panels
For all E200 Series, Short Throw and
Ultra Short Throw Models (VPL-EW235,
VPL-EX235, VPL-EW255, VPL-EX255,
VPL-EW295, VPL-EX295, VPL-SW235,
VPL-SX235, VPL-SW225, VPL-SX225,
VPL-SW620, VPL-SW620C, VPL-SW630,
VPL-SW630C, VPL-SX630)
For:
VPL-DX127, VPL-DX147
and VPL-DW127
For:
VPL-DX122, VPL-DX142,
and VPL-DW122
For:
VPL-CX235, VPL-CW255,
VPL-CW275
For:
VPL-FX30
and VPL-FX35
For:
VPL-FH31, VPL-FH36
and VPL-FHZ55
For:
VPL-FX500L ,VPL-FH500L
and VPL-FHZ700L
37
Visual Communications
Video
Conference
Energise business communications,
distance learning and remote
consulting with easy to use video
conferencing systems by Sony.
Effortlessly share HD video plus
high-quality voice and PC
presentations across multiple sites.
38
HD videoconference systems
Complete HD videoconference systems with PTZ camera for standard-size
meeting rooms, boardrooms and spaces.
PCS-XG100H: 1080/60p resolution PCS-XG77H: 720/60p resolution*
Video conferencing system for a range of meeting room environments
•Smooth Full HD dual streaming
•Triple monitor mode: show ‘Far’ and ‘Near’ video sources on two monitors, plus a PC
presentation on a third or triple monitor emulation using 1 monitor
•Live annotation on any image source using Wacom tablets
•High quality stereo audio: using two PCS-A1 microphones and built-in echo canceller
•Built-in MultiPoint Control Unit for either six or nine sites
•HD recording direct to USB media
•Multicast streaming: stream videoconferences across your network as live webcasts
•Microsoft LyncTM compatible for easy video conferencing
•Join videoconferences and presentations on the go with the PCS-MEP
app for iOS and Android
PCS-XG100H
SRG-120DH
PCS-XG100H
PCS-XG77H
*PCS-XG77H can be upgraded to 1080p 60fps if required
39
Visual Communications
PCS-XC1
Portable wireless HD Video conferencing system
Connect wherever there’s a network available
•Light, compact and highly portable
•Highly sensitive Exmor CMOS image sensor and View DR technology
•HD video (720p) at a smooth 60 frames per second (with the further option
of 1080p at 60 frames per second)
•Pan/tilt/zoom camera with wide field of view
•Clear, crisp digital audio
•Enhanced Intelligent QoS (Quality of Service)
•Simultaneous data-sharing with SXGA quality
•Record conferences on USB memory
•Microsoft Lync™ compatible for easy video conferencing
PCS-XC1
40
PCS-MEP
IPELA Communication Mobile app for Android and iOS
Stay connected with easy, wireless video conferencing from your tablet or smartphone,
wherever you are. Compatible with Sony Xperia® Z smartphone (Model C6602), Xperia
Tablet Z (Model SGP312) iPhone 5, iPhone 5S, iPhone 5C iPad® (4th generation), iPad
mini™ with Retina display, iPad Air™*
•Join meetings from anywhere in a closed network environment (e.g. corporate LANs).
•HD video quality and crisp, clear sound.
•View shared presentations, spreadsheets and other PC documents on
your device screen
•Clear, uncluttered interface
•Instantly call a contact from ‘history’ or ‘phone book’ panes, or direct dial an
IP address from the keypad.
PCS-MEP
* When installed, compatible with Sony video conferencing endpoints and servers:
PCS-XG100S (version 1.20 and later) PCS-XG77S (version 1.20 and later) PCS-VCS (version 5.17
and later) PCS-VCSH24 (version 5.17 andlater) PLEASE NOTE: Activating mobile access feature
with PCS-XG100S, PCS-XG77S or PCS-VCS requires installation of optional PCSA-SAG8, PCSA-SAG1
or PCSA-VSA10 software respectively (available separately).
41
Visual Communications
PCS-XG80: 1080p/30 resolution | PCS-XG55: 720p/60 resolution
Video conferencing system for any meeting room environment
•Enhanced Intelligent QoS
(Quality of Service)
•Superb audio quality
•BrightFaceTM technology
(built-in PCSA-CXG80 camera)
• Video Annotation function
•ISDN support up to 768bps
(with optional ISDN box)
•ITU-T H.239 support
(video and presentation data)
PCS-XL55
All-in-one HD video conferencing system
Ideal for executive desktop or open meeting spaces.
•21.6 inch all-in-one desktop
videoconferencing
•Enhanced Intelligent QoS
(Quality of Service)
•Stunning 720p/60 HD images
• Video Annotation function
•Superb audio quality
•ISDN support up to 768bps
(with optional ISDN box)
PCS-XG80
42
PCS-XG55
PCS-XL55
PCS-VCS/EP/RS/FT
HD visual communications infrastructure systems for easily scaled communications
providing anything from PC desktop software clients, external scalable multi-point
conferencing, conference call recording and firewall traversal.
•Software-based MCU, PC clients, Recording Server or Traversal Server
•Various screen layouts and support modes: Voice Activate, Continuous Presence,
Chairman, Time Interval
•Embedded Gatekeeper
•Endpoint firmware upgrade
•Enhanced Intelligent QoS (Quality of Service)
•Shared Phone book with Presence Capability
PCS-VCS/EP/RS/FT
43
Visual Communications
EVI and SRG HD Series PTZ cameras for meeting
rooms, offices and more
SRG Series Full HD Pan/Tilt/Zoom Cameras
Full HD cameras controlled over IP, designed for remote shooting and monitoring.
SRG-300SE and SRG-300H
Easy, affordable, superbly clear: the SRG-300H and SRG-300SE both deliver
1080p 60fps with control over IP or VISCA.
Products
SRG-300SE
SRG-300H
•Excellent dynamic noise reduction
Optical zoom
X30
X30
•View-DR technology for much
greater clarity
Field of view
65 degrees
65 degrees
Colour
Black or white
Black or white
Mounting
Ceiling or
desk
Ceiling or
desk
Interface
3G-SDI
HDMI
Presets
256
16
Control
LAN/RS-422
LAN/RS-232/
RS-422
IP streaming
YES
NO
•Silent PTZ
SRG-300SE unique features
•Enhanced audio quality with
equaliser and auto lip sync function
•Capture and share high quality F
ull-HD images with simultaneous
streaming via IP and 3G-SDI
SRG-300SE
44
SRG-300H
SRG-120DH
Desktop PTZ colour camera for corporate, educational and telemedicine
applications, with 12x optical zoom and high frame rate 60fps.
•Full HD image quality with 60fps
frame rate
Products
SRG-120DH
•Clearer pictures in any lighting conditions
Optical zoom
12x
•Get closer with powerful 12x
optical zoom
Field of view
71 degree(Wide)
Colour
Silver
Mounting
No
•Wide 71-degree viewing angle
•Versatile connectivity options
•HDMI compatible
•16 programmable presets
•Easy control by PC
EVI-HD Series Pan/Tilt/Zoom Cameras
High definition cameras, controlled over VISCA, designed for remote shooting
and monitoring.
SRG-120DH
45
Visual Communications
EVI-HDI, EVI-HD3V and EVI-HD7V
•High quality image transmission
•Wide-range, Quiet and Quick Pan/Tilt movement
•10x Optical (40x Digital Zoom)
•RS-232C Remote Control (VISCATM Protocol)
•Six position presets
•Customisable settings via on-screen menu and IR
•Remote Commander® Unit
Product
EVI-HD1
EVI-HD3V
EVI-HD7V
Interface
HD-SDI, component YPbPr,
VBS and Y/C Multi-format
video outputs from NTSC/
PAL SD -> Full HD
DVI-I Multi-format video
outputs from NTSC/PAL
480 > HD
DVI-I Multi-format video
outputs from NTSC/PAL
480 Full HD
Max Resolution
1080/60
720/60
1080/60
Max Shutter
Speed
1/2 to 1/10,000 sec
1/60 to 1/10,000 sec
1/60 to 1/10,000 sec
EVI-HD7V
EVI-HD1
EVI-HD3V
46
EVI-SD Series Pan/Tilt/Zoom Cameras
Standard Definition cameras series
EVI-D70/P
•216x zoom ratio
•Superb picture quality with
EXview HAD CCD™
•RS-232C or RS-422 Serial
Control (VISCATM Command)
•Six-position preset
D80 and D90 Series
•Smart, stylish design in either black or white
•Standard mounting and ceiling mounting with E-flip function
Product
EVI-D80 Series
Optical zoom lens
18x
Sensor technology lens
¼-type CCD
NTSC models
EVI-D80N (black) EVI-D80NW (white)
PAL models
EVI-D80P (black) EVI-D80PW (white)
Product
EVI-D90 Series
Optical zoom lens
28x
Sensor technology lens
¼-type EXview HAD CCD
Other features
Wide-D technology
EVI-D70 Series
Available
in black or
white
EVI-D90 Series
EVI-D80 Series
47
Professional Audio
48
Digital wireless audio using 2.4GHz ISM band
for corporate and education presenters
•2.4GHz ISM band for transmission
•An impressive 24Bit digital audio for excellent sound quality
•128Bit AES encryption for secure transmission
•Intelligent feedback reducer to eliminate unwanted acoustic feedback noise
DWZ-B70HL
Lavalier and Headset microphone pack
•ZRX-HR70 Rack Mount Type Receiver
•ECM-LZ1UBMP Lavalier Microphone
• ZTX-B02RC Bodypack Transmitter
•ECM-HZ1UBMP Headset Microphone
DWZ-M70
Handheld microphone pack
•ZRX-HR70 Rack Mount Type Receiver
•ZTX-M02RC Handheld Microphone
BC-DWZ1
DWZ series rechargeable unit
•For use with DWZ-M70 or DWZ-B70HL
package systems
DWZ-M70
DWZ-B70HL
•Supports use of rechargeable AA
NiMH batteries
BC-DWZ1
49
Visual Simulation
and Visual Entertainment
Incredible
4K detail for
simulation and
visualisation
50
Every projector in our simulation and
visualisation line-up delivers stunning
4K images. At more than four times
the resolution of Full HD, it guarantees
an astonishingly detail-packed
experience, with richer colour and
unbeatable image quality. Whether
you’re creating a flight simulation for
pilot training, a Planetarium, or sharing
a finely-detailed visualisation for an
automotive design, all projectors can
provide you with the very best picture.
SRX-T series for professional and
industrial visualisation
SRX-T615
•Detail with true 4K SXRD picture quality
•Best in class 12,000:1 contrast ratio
and 18,000 centre lumens combined
•Efficient, easy to handle HPM
multi-lamp array
•Interleaved lamp control for longer life
•Lamp fail-safe for resilient operation
•Easy-on-the-eye 3D
Main Specification
SRX-T615
Resolution
4096 x 2160
Display device
3 x 1.48” 4K SXRD
Brightness
18,000 Centre lumens
Contrast ratio
12,000:1
Lamp technology
6 x HMP lamp
450W/330W
•Create super-sized images with
edge blending
•Flexible throw distance with
interchangeable lens
SRX-T423
Main Specification
SRX-T423
Resolution
4096 x 2160
Display device
3 x 1.48” 4K SXRD
Brightness
23,000 center lumens (Normal mode) 30,000 center lumens
(High brightness mode)
Contrast ratio
3,000:1
Lamp technology
4KW Xenon lamp
SRX-T615
SRX-T423
51
Visual Simulation
and Visual Entertainment
Professional
4K SXRD projectors
for visualisation
and simulation
Combining the best Sony technologies,
the VPL-GTZ1 is a 4K Ultra-Short Throw
projector with a laser light source for
20,000 hours of high performance,
maintenance-free operation. At 2,000
lumens brightness, it’s perfect for
museums, design simulation, industry,
education, business and can be used
to create stunning video walls.
52
VPL-GTZ1
VPL-GTZ1
• Detail-packed 4K image quality
• Quick on/off
• Projected image size: 66” to 147”
• Floor standing or ceiling mount
with front and rear projection
• No lamp: 20,000 hours maintenancefree operation
• ‘Blend in’ design to suit any environment
Product
VPL-GTZ1
Resolution
4096 x 2160 (4K)
Display device
3 x 0.74 inch 4K SXRD
Brightness
2,000 lumens
Dynamic contrast ratio
Infinity
Illumination
Laser diode
53
53
Visual Simulation
and Visual Entertainment
VPL-GT100
VPL-GT100 is a compact professional 4K SXRD projector with 2,000 lumens brightness,
ideal for simulation. It features a dual display port input for outstanding native 4096 x
2160 resolution at 60 frames per second, while Sony’s latest generation SXRD panel and
advanced Iris3 technology achieve an incredible dynamic contrast ratio of 1,000,000:1.
•Richer pictures with Wide Colour Space
(DCI, Adobe RGB)
•Smear reduction with Sony’s Dark
Frame Insertion technology
•Transport delay reduction,
for smooth images
•Compact – 20kg
•Portrait or landscape installation
Product
VPL-GT100
Resolution
4096 x 2160
Display device
3 x 0.74” 4K SXRD
Brightness
2,000 lumens
Dynamic contrast ratio
1,000,000:1
Lamp technology
330W HMP lamp
VPL-GT100
54
Accessories
Lamp
Lamp
SRX-T615
SRX-T420
LKRM-U450
LKRM-U330
LKRX-2042A
Interchangeable lens
SRX-T615
LKRL-Z511
LKRL-Z514
LKRL-Z519
Throw ratio
1.05-1.75
1.35-2.34
1.80-4.00
SRX-T423
LKRL-Z211
LKRL-Z214
LKRL-Z219
LKRL-Z140
Throw ratio
1.05-1.75
1.35-2.40
1.85-4.00
3.81-7.12
3D Lens for SRX-T615
LKRL-A502
LKRL-A503
Throw ratio
1.03-1.85
1.70-3.76
SRX-T615
SRX-T420
DVI Board
QMCB-DVI
LKRI-005
HD-SDI Board
QMCB-SDI
LKRI-003
Interface board
LKRL-Z519
LKRL-Z514
LKRL-Z511
LKRL-Z219
LKRL-Z211
55
© 2014 Sony Corporation.
All rights reserved. Reproduction in whole
or in part without permission is prohibited.
Features and specifications are subject to
change without notice. All non-metric weights
and measurements are approximate.
Sony and BrightEra and their respective
logos are trademarks of Sony Corporation.
All other trademarks are the property of their
respective owners.
Product range 2014
www.pro.sony.eu
@SonyDisplays
