Sony 19" Silver Flat Panel LCD

SDM-S95AS
IT Displays
The Sony SDM-S95AS is designed for human performance™.
Sony StylePro™ LCD’s are thoughtfully designed to optimize
comfort and enhance productivity with the ErgoStand™ design
and analog input. These latest displays are customized to meet
the demands of today’s office environments-all while remaining
true to the Sony® tradition of renowned quality, reliability and
style.
O
O
O
O
O
19.0” display (1280 x 1024) (measured diagonally)
High Performance Display: 250 cd/m2, 700:1, 16ms video response
time, 170 / 170 viewing angle
Single Analog Input (HD15)
ErgoStand™ design offering optimal fixed height position w/ 350 °
swivel
Audio Pass Through
Stylish multi-color
display
Ergonomic designed
control buttons
SDM-S95AS
IT Displays
Features and Benefits
O
O
O
O
O
O
O
O
Pass-through audio out - Convenient audio connection for
headphones that switches with PC input
5 Gamma presets - A greater ability to set proper tonal curve to match
the application
Auto-input sensing - Easy set up: connect and go without manually
switching inputs
VESA Wall Mount - Centered to allow for pivot/rotation
Tilt and Swivel - All models with a base-stand include a tilt and wide
350° swivel
Streamlined profile - Space-efficient design keeps workspace looking
organized and clutter-free
ErgoBright™ technology - Optimizes brightness at the push of a
button, reducing eyestrain
Versatile and easy to use - Sony’s automatic image adjustment
feature optimizes your display’s performance instantly. Macintosh® and
PC compatible
Specifications
PART NUMBER
SCREEN SIZE
NATIVE RESOLUTION
SCREEN TREATMENT
PIXEL PITCH
HORIZONTAL SCAN RANGE
VERTICAL REFRESH RANGE
RESPONSE TIME
LUMINANCE
CONTRAST RATIO
COLORS
VIEWING ANGLE
INPUT(S)
WALL/ARM MOUNT
CABLE MANAGEMENT SYSTEM
ON SCREEN CONTROLS
ERGOSTAND™ DESIGN
KENSINGTON LOCK
FORMAT
INPUT POWER
POWER CONSUMPTION
POWER MANAGEMENT
EMISSIONS/ERGONOMICS
PLUG & PLAY
LIMITED WARRANTY
EXTENDED WARRANTY
OPERATING SYSTEM COMPATIBILITY
WEIGHT
DIMENSIONS (WXHXD)
PACKAGE CONTENTS
WARRANTY
SDM-S95AS
19.0"
1280 x 1024
Anti-Glare / Protective Coating
0.294 mm
28k-80kHz
48-75Hz
16ms
250cd/m2
700:1
16.7 Million
170°/170°
Video Input Connector(s): Analog (HD15)
100mm
Yes
Power, Menu, Contrast, Brightness, Eco Mode, Color,
Temperature, Backlight, Auto Adjust, H/V Adjust,
Phase, Pitch, Reset, Gamma, Menu Lock, OSD
Position, Multi Lang. (Eng, Fre, Spa, Ita, Ger, Jap, Dut,
Swe, Rus, Chi)
Height: Ergonomic Fixed Height; Tilt: Yes
Swivel: Swivel Range 350º
Yes
Audio pass-thru to HPJ
Internal Power Supply 100-240Vac. 50/60Hz
50w max, 38w typ, 1w Active off, 1w Switch off
International Energy Star
TCO 03
Plug and Play: DDC/Ci
3 years (Parts, Labor, Backlight)
4th and 5th year available
Designed For: PC2001, Windows® 98, 2000, NT, XP
and Macintosh®
16.1 lbs; 11.5 lbs w/o base stand; 22.1 lbs packaged
16.3" x 17.3" x 8.9"; 16.5" x 13.7" x 2.7" w/o base
stand
CD-ROM User Manual
AC Power Cord
HD15 Video Signal Cable
Quick Setup Guide
Windows® & Macintosh® Utility Files
Warranty Card
3 years (Parts, Labor, Backlight)
4th and 5th year available
©2005 Sony Electronics Inc.
Sony and ErgoStand are trademarks of Sony. All other trademarks are property of their
respective owners. Microsoft and Windows are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries. Macintosh is a
registered trademarks of Apple Computer, Inc.
Features and specifications are subject to change without notice. Non-metric weights and
measures are approximate.
®
Sony Electronics, Inc. • 16450 West Bernardo Drive • San Diego, CA 92127 • 1-866-357-7669 • www.sony.com/businesssolutions
Last Updated 2005-05-20
