Philips
External Hard Disk
multimedia
320 GB USB 2.0
SPE9015CC
Multimedia Storage
Play all your stored files on your TV
Archive and secure your favourite home movies, music and memories instantly and enjoy
them in the comfort of your living room.
Connect directly to any TV
• Composite and S-video
Experience optimal sound quality
• Dolby digital and DTS
Easy to use
• Intuitive interface with remote control
Super fast file transfer
• Accelerated USB 2.0 connection with Prolific chip
Robust and durable
• High quality, extra thick aluminium casing
SPE9015CC/10
External Hard Disk
multimedia 320 GB USB 2.0
Specifications
Product highlights
Storage Media
•
•
•
•
•
•
Hard Disk Capacity: 320 GB
HDD Type: 3.5" HDD
Rotational speed: 7200 rpm
Transfer rate: 480 Mb/s
Access time (typical): 8.5 ms
Cache memory: 8 MB
•
•
•
•
Width: 235 mm
Gross weight: 10.96 kg
Net weight: 10.2 kg
Tare weight: 0.762 kg
Multimedia playback
Extra thick aluminium casing
The high quality aluminium casing protects the hard drive
from wear and tear - protecting your data and
guaranteeing a long working life. It also insulates the
sound of the drive to ensure quiet operation.
Accelerated USB 2.0
The Hard Drive is equipped with USB 2.0 and a Prolific
chip for super fast file transfer.
• Interface: Hi-Speed USB2.0 / AV - out
• Audio Output - Analogue: Audio L/R (cinch)
• Audio Output - Digital: AC3 over S/PDIF
(Optical)
• Video Output - Analogue: Composite video out,
S-video
• Audio formats: MP3, MPEG 4, WMA, AC3, WAV,
OGG Vorbis
• Picture formats: JPG
• Subtitles: SUB (microDVD format), SRT (SubRIP
format) SMI (SAMI), Embedded multiple subtitle
support
• Video formats: MPEG 1 (AVI, APG), MPEG 2 (AVI,
VOB), MPEG 4 (DivX, VOD), ISO, DivX Home
Theatre, Xvid
Accessories
Product dimensions
Composite and S-video
Connect to your TV instantly via Composite or S-video
with plug and play simplicity. The connectors are
compatible with almost every TV and even work with a
scart adapter (not supplied with the product).
Connectivity
•
•
•
•
•
•
•
USB cable
Quick start guide
AC Adapter
User Guide on CD-ROM
CD-ROM
AV cable
Remote control
System Requirements
• PC OS: Windows 2000, Windows XP, Windows
Vista
• Processor: Pentium 4 1 GHz, 128 MB RAM
Packaging Data
•
•
•
•
•
•
•
EAN/UPC/GTIN: 87 12581 31593 1
Height: 130 mm
Width: 215 mm
Length: 290 mm
Gross weight: 2.54 kg
Tare weight: 0.39 kg
Net weight: 2.15 kg
Outer Carton
• EAN/UPC/GTIN: 87 12581 32006 5
• Height: 320 mm
• Length: 545 mm
• Product dimensions (W x H x D):
16.7 x 4.5 x 16.7 cm
• Weight: 1.59 kg
Packaging dimensions
• Packaging dimensions (W x H x D):
21.5 x 13 x 29 cm
• Nett weight: 2.144 kg
• Gross weight: 2.54 kg
• Tare weight: 0.396 kg
• EAN: 87 12581 34703 1
• Number of products included: 1
• Packaging type: Carton
Outer Carton
•
•
•
•
•
•
•
•
•
•
Outer carton (L x W x H): 21.5 x 9.3 x 12.6 inch
Nett weight: 18.907 lb
Gross weight: 24.603 lb
Tare weight: 5.696 lb
Outer carton (L x W x H): 54.5 x 23.5 x 32 cm
Nett weight: 8.576 kg
Gross weight: 11.16 kg
Tare weight: 2.584 kg
EAN: 87 12581 34705 5
Number of consumer packagings: 4
•
Issue date 2008-01-04
© 2008 Koninklijke Philips Electronics N.V.
All Rights reserved.
Version: 3.0.6
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
12 NC: 8670 000 31663
EAN: 87 12581 34703 1
www.philips.com
Dolby digital and DTS
Get the most out of your stereo by playing your digital
music on it. The hard disk works with Dolby Digital 5.1
so you can hear superb surround sound from your digital
music and video content.
Interface with remote control
Get control of your multimedia content with the Philips
remote control. Its intuitive navigation allows you to
simply navigate through all your movies, pictures and
music.
