Desktop Class
Spinpoint F2EG
Capacity
Model
16MB
500 GB
1 TB
1.5 TB
HD502HI
HD102SI
HD153UI
HD103SI
HD154UI
32MB
FEATURES
• MAX.500GB Formatted Capacity Per Disk
• Environment friendly product with RoHS compliance
• Serial ATA 3.0Gbps Interface Support
• Improved performance with dual-ARM based firmware
• Improved recording stability over temperature with PMR
• ATA S.M.A.R.T. Compliant
• Advanced dynamic FOD control for best data integrity
• ATA Automatic Acoustic Management Feature
• Intelligent compensation of external disturbance
• ATA 48-bit Address Feature
• SATA Native Command Queuing Feature
• ATA Device Configuration Overlay Feature
• Device Initiated SATA Power Management
• NoiseGuard™
• Rotational vibration sensor
• SilentSeek™
DRIVE CONFIGURATION
ENVIRONMENTAL SPECIFICATIONS
Interface
Serial ATA 3.0Gbps
16 / 32 MB
512 bytes
Buffer DRAM Size2
Byte per Sector
PERFORMANCE SPECIFICATIONS
Average Seek time (typical)
Average Latency
Data Transfer Rate
Media to/from Buffer (Max.)
Buffer to/from Host (Max.)
Drive Ready Time (typical)
8.9 ms
5.56 ms
166 MB/sec
300 MB/sec
500 GB
8 sec
1 TB
11 sec
1.5 TB
13 sec
Temperature
Operating
0 ~ 60 °C
Non-operating
-40 ~ 70 °C
Humidity (non-condensing)
Operating
5 ~ 90 %
Non-operating
5 ~ 95 %
Linear Shock (1/2 sine pulse)
Operating (2.0ms)
70 G
Non-operating (2.0ms)
500GB ~ 1.5TB
300 G
Altitude (relative to sea level)
Operating
-300 to 3,000 m
Non-operating
-300 to 12,000 m
PHYSICAL DIMENSION
RELIABILITY SPECIFICATIONS
Non-recoverable Read Error
Start/Stop Cycles
1 sector in 1015bits
50,000
Height (Max.)
Width
Length
Weight (avg.)
ACOUSTIC Noise
Idle
500GB
1~1.5TB
500GB
1~1.5TB
Performance Seek
2.2 Bel
2.5 Bel
2.7 Bel
2.8 Bel
26.1 mm
101.5 mm
147.0 mm
500GB
470 g
1TB
610 g
1.5TB
650 g
* Note : Design and specifications are subject to change without prior not
1.1MB = 1,000,000 Bytes, 1GB=1,000,000,000 Bytes
POWER REQUIREMENTS
Voltage
Capacity1
Spin-up Current (Max
Random Seek 3
Read/Write
Idle (typical)
Standby (typical)
Sleep (typical)
2. A small portion of the 16 / 32MB buffer memory is reserved for
+5V±5%, +12V±10%
500GB
1 TB
1.5 TB
2.0A
4.8W
5.1W
3.9W
1W
1W
2.0A
5.3W
5.8W
4.6W
1W
1W
2.0A
5.7W
6.3W
5.1W
1W
1W
firmware use
3 Random seek with 30% duty cycle.(Average value)
3.5" HDD product specification Rev 0.2
Match with product manual Rev 02
