inch TFT LCD color monitor with a high resolution of 800×600, a contrast ratio of 400:1, and a viewing angle of 130°/ 110° (Horizontal/Vertical). It supports multiple input signals, including PC(VGA), AV1, AV2, HDMI, DVI, YPBPR, and S-video. It also features a built-in speaker and a remote controller for convenient operation. With its compact size, lightweight design, and versatile connectivity options, the Lilliput FA1045 is suitable for various applications, including use as a computer monitor, gaming display, or multimedia player.
advertisement
TFT LCD COLOR MONITOR
DEAR CUSTOMERS
Thank you for purchasing the liquid crystal display monitor. This product employs new integrate circuits and high quality TFT LCD modules. It is putting out with its low power consumption, emits no radiation, and other advantage characteristics. This product is shaped with modern style and is easy to be carried with. The color
TFTLCD is the most suitable display for VGA,VCD, DVD and GPS system for motorcars and ships .It also can be used in the office ,in flat ,at home also in other suitable position. You will certainly benefit from this monitor in lots of ways, to name some of them: convenience, safety, space-saving.
We hope that you will have the enjoyment of your new mini color TFT LCD.
To ensure the best use of the unit, please read this handbook carefully beforehand.
CAUTION
1. Please use the adapter attached in the accessory.
2. Do not expose this product to direct sunlight, heat or humid conditions.
3. Keep away from strong light while using this product so as to obtain the clearest and the most colorful picture.
4. Please avoid heavy impact or drop onto the ground.
5. Do not use chemical solutions to clean this unit. Please simply wipe with a clean soft cloth to keep the brightness of the surface.
6. If the product does not operate normally when the instructions are followed.
Adjust only those controls that are covered by the instructions. Improper adjustment of other controls may result in damage and will often require extensive work of a qualified technician.
CONTENTS
1. PRODUCT DESCRIPTION --------------------
2. REMOTE CONTROLLER ---------------------
3. MENU OPERATION ----------------------------
IN AV MODE--------------------------------------
IN PC MODE--------------------------------------
IN DVI&HDMI&YBPDR MODE--------------
4. MATCHED CABLES-------------------------
5. ACCESSORIES ------------------------------------
6. PARAMETER --------------------------------------
7. TROUBLESHOOTING ---------------------------
8. REMARK----------------------------------------
1. PRODUCT DESCRIPTION
1 2 3 4 5 6 7
17 16 15 14 13 12 11 10 9 8
1. - : Volume down or to adjust the value of setting function
2. +: Volume up or to adjust the value of setting function
3. <: Selection key, to select item on the OSD or push the key in PC mode directly to adjust phase automatically
4. >: To select function on OSD or to adjust the brightness directly. There aresix levels of brightness, push this button directly to change among them.
5. MENU: To activate OSD menu
(long press to underscan/overscan pictures automatically when receiving
HDMI (High-Definition Multimedia Interface) signals)
6. PC/AV: PC(VGA),AV1,AV2,HDMI,DVI,YPBPR and S-video switch
7. POWER: Power on/off
8. DC 12V
9. S connector
10. DVI port
11. HDMI port
12. YPBPR signal port
13. VGA port
14. Video 1/2 input
15. Audio L/R input
16. Audio L/R output
17. USB port(Touch connector)
2. Remote control
1. MUTE
2. PC(VGA),AV1,AV2,HDMI,DVI,YPBPR and S-video switch
3. : Left move,Volume down or to adjust the value of setting function
4. MENU: To activate OSD menu
(long press to underscan/overscan pictures automatically when receiving
HDMI (High-Definition Multimedia Interface) signals)
5. Power
6.
:UP move, To select function on OSD
7.
: Right move, Volume up or to adjust the value of setting function
8.
: Down move, to select function on OSD
3.MENU
OPERATION
Before setting the menu functions, please make sure the device is connected correctly. When power on, press MENU on the device or on the remote controller. The menu of function setting will display on the screen.
Press >/< buttons on the device or ▼/▲ buttons on the remote controller to select items on the left of the display. Then press + / – buttons on the device or ►/◄buttons on the remote controller to change the values.
The following pictures are the setting displays of different modes.
IN AV MODE & S connector IN PC
MODE
:
As follows:
OSD
MISCELLANEOU
S
IN DVI & HDMI & YPBTR MODE
(Note: DVI & HDMI optional) via item to a new page.
Icon Name
Brightness
Contrast
Saturation
Tint
OSD H-Position
Function
Adjust the level of brightness
Adjust the level of contrast
Adjust the level of saturation
Adjust the tint of image
Adjust the on-screen-display horizontally
OSD V-Position Adjust the on-screen-display vertically
PHASE
FREQUENCY to adjust the beginning point and terminal point of image to adjust the frequency range of image
OSD H-POSITION to adjust the picture position in horizontal direction
OSD H-POSITION to adjust the picture position in vertical direction
OSD AUTO
COLOR
Reset
Color temperature
Red
Green
If select “YES” it will adjust automatic color system to the best
Select “Yes” to reset the adjustment as manufacture parameters.
Choose the color temperature. Options: User,
6500ºK, 7500 ºK, or 9300 ºK.
Note: Only can available under “User” mode to meet the color value you need.
Blue
Choose language between English and Chinese
Language
Japanese(optional)
Enter to next page (See picture below) for
Miscellaneous miscellaneous selections
Exit OSD Select “Exit” to quit the on-screen-display menu.
Sharpness Adjust the sharpness of picture
Adjust the display duration of OSD from 5-100
OSD Duration seconds.
4. SPECIAL MATCHED CABLES
YPBPR signal connect cable
P signal connect cable
R signal connect cable
Y signal connect cable
YPBPR signal input
VIDEO&AUDIO input/output cable
VIDEO 1 output
VIDEO 2 output
VIDEO signal input
5. ACESSORIES
1. 4 pin Y/C signal cable 1 piece
2. HDMI type A-C 1 piece
3. Touch pen 1 piece
4. Drive disk 1 piece
5. Remote control 1 piece
6. DVI cable
1 piece
7. VGA15-pin cable 1 piece
8. VIDEO&AUDIO input/output cable 3 pieces
9. USB connection cable 1 piece
10. Home DC adapter 1 piece
11. YPBPR signal connect cable 1 piece
12. Manual 1 copy
6. PARAMETER
PANEL
TFT LCD 10.4’’
HIGH RESOLUTION
Brightness
800×600
230cd/㎡
VIEWING ANGLE
COLOR SYSTEM
INPUT VOLTAGE
INPUT SIGNAL
130°/ 110°(Horizontal/Vertical)
PAL-4.43,NTSC-3.58
DC 12V
PC(VGA),AV1,AV2,HDMI,DVI,YPBPR and S-video
POWER CONSUMPTION ≤8W
Audio Output ≤1.2W
CONTRAST
SIZE
Weight
400:1
260×200×39(mm)
902 g
7. TROUBLE
SHOOTING
Only black-and-white image
Make the level of color saturation and brightness is proper. Power on but no picture
Make sure the AV &VGA &HDMI&DVI&YPBPR&S connector cable is tightly connected from the video out connector AV &VGA
&HDMI&DVI&YPBPR&S connector signal output connector. Make sure you are using the standard power adapter coming with the monitor.
Wrong or abnormal colors
If any color is missing, check the cables to make sure it is securely connected. Broken or loose pins in the cable connector can cause a bad connection.
Remote controller doesn't work
Check the battery to make sure the battery is installed properly and make sure it is not a low battery. The signal is interfered by some obstructions.
Please try to reset if any abnormal matters happened .
8. REMARK:
If there are still any problems, you can connect with the related deals
*If interruptive image occurs, it maybe that the VGA signal frequency isn’t matched with normal standard
*It is a normal condition that some bright lines appear on the screen when you turn the unit.
Note: due to constant effort to improve products and product features, specifications may change without notice.
