MULTIMEDIA DATA / VIDEO PROJECTORS

The New WD3300U and XD3200U

Comfort Redefined

Large-screen reproduction of high-quality images. Breathtaking and powerful.

But image quality is not the only improvement to our large-screen projectors.

Mitsubishi Electric’s new projectors are designed for easy installation and maintenance, superior operability and a comfortable viewing experience.

Welcome to the future of high-lumen projectors.

4000 lm

WXGA

4500 lm

XGA

Operation simplified with Mitsubishi Electric’s user-friendly design

Low Maintenance & High Durability

New Color Wheel System

Dust would easily accumulate on the color wheel sensors of previous models. However, the sensor is now mounted in the rotary shaft motor casing, which is almost fully enclosed, making it much more resistant to dust.

Previous color wheel

Photo Sensor

Timing

Mark

Optical Signal

New color wheel

Dust would accumulate on the sensor and thick part of the timing mark, blocking the light path when using the light signal method. This dust build-up interferes with the color distinction process, causing poor color alignment.

Magnet

Fixed

Halleffect IC

Less than 1mm

Magnetic Signal

The base spins together with the color wheel.

The wind pressure created by the centrifugal force keeps dust from entering through the gap

(less than 1mm or 1/25in). The magnet is embedded in the base, so there is no protruding part for dust to accumulate on. Since a magnetic signal method is used, the signal passes through any dust without the problem of color distortion.

Filter free

DLP TM projectors are virtually airtight, therefore an intake filter isn’t needed, eliminating the need for filter changing and ultimately lowering overall cost.

Long 4000hr Lamp Life

The WD3300U/XD3200U has a lamp temperature controlling system that enables an estimated lamp life of up to 4000hours.* 1 Long-life lamps make dramatic reductions in overall cost of ownership by reducing the frequency of lamp replacement.

Lamp Replacement Frequency* 2

2,000hr lamp

Original Lamp 1st replacement

Reduced

Lamp

Replacements

4,000hr lamp

Original Lamp

2,000 hours 4,000 hours

(*1): When lamp is used in “Low” mode. Maximum life in “Standard” mode is 2000hr.

(*2): Lamp life refers to the average time required for brightness to be reduced by half, and not the time specified in the warranty. Usage time may vary widely according to the environment and conditions, and whether or not cleaning and other maintenance procedures are followed.

100%

The lamp can be accessed from the side of the projector, simplifying the replacement process, as the projector does not have to be turned around when sitting on a shelf or turned over when suspended from the ceiling. The center-set lens design makes set-up easy since the projector lens need only be aligned with the center of the screen.

New Lamp Drive System

Arc Discharge

Electrode

Initially, the gap between the electrodes is small and the arc density is high, resulting in high brightness.

The distance between the electrodes increases as they wear. This causes a decrease in arc density, which also results in a loss of brightness. Conventional Lamp

Drive System

New Lamp Drive System

0%

Total Lamp Usage in Hour

Adoption of a new lamp drive system prevents electrode wear—giving the lamp a longer service life and enabling it to retain projection brightness over a longer period of time.

Up until now, the electrodes in the lamp deteriorated quicker when using the projector for extended periods of time, resulting in a loss of brightness.

These projectors incorporate an optical design that optimizes lamp operation to realize a lamp drive that makes it possible to stabilize the shape of the electrode during long-term use. As a result, the maximum lamp service life is obtained for every projection mode and loss in projection brightness is extended over a longer period of time.

Side Access Lamp & Center Lens Designs Quick Lens Change

The top cover has a removable section around the lens. This advanced feature enables the lens to be changed without removing the entire top cover.

User Friendly

Ultra - quiet 26dBA Operation

The fan noise from a projector can be annoying during a presentation or videoconference—but with the adoption of a hermetically sealed color wheel and improved air duct path, that’s a thing of the past.

The WD3300U and XD3200U have a significantly low fan noise of only 26dBA (lamp in Low mode). As a result, audiences can enjoy presentations and conferences without the distraction of projector noise.

The air duct flow design has been improved so that fan noise doesn’t interfere with the intake-air flow. Additionally, fan noise is blocked from direct exit, resulting in a significant reduction in operation noise.

User Logo Projection

A user-created image (logo, picture, etc.) can be loaded into the projector and used as the start-up image or the stand-by screen.

Environmentally Friendly

In order to lessen our impact on natural resources, we have engineered specific eco-friendly features including:

• Low Standby Power

When in Standby mode, the projector consumes less than 1Watt* of power

&

C

O

N

S

E

RV

AT

ION

COMM

ITT

E

D

T

O

G

R

• Recycled Paper

The carton, and all paper materials within are made from recycled paper

O

N

GREENER TECHNOLOGY

C

H

GH

OU HR T GY

LO

NO

E

R

• Eco-friendly design

The use of lead-free solder further minimizes impact on the environment

* Less than 2W in Normal mode

(network turned on).

Stunning Beautiful Colors & High-quality Design

Brilliant Color

™

and Mitsubishi Electric Engineering Yield Superior Color Performance

Brilliant Color™, one of the latest innovations from

Texas Instruments, produces amazingly rich and vibrant colors. We developed a 5-segment color wheel (R, G, B, W and Y), and by combining it with

Brilliant Color™ and selective lamp-powered modulation techniques—the WD3300U and

XD3200U intelligently reproduce colors that improve the intensity and vibrancy across the entire screen. w/o-BrilliantColor TM BrilliantColor TM

4-segment (RGBW) color wheel

Yellow reproduction

improves

5-segment (RGBWY) color wheel

Lamp Power Modulation

Presentation Mode (for high brightness)

Light intensity increases for the white and yellow segments of the color wheel, giving greater emphasis to bright colors in more vivid tones.

High Power

Normal Power

Low Power

R B W

Lamp Power (Basic concept)

Auto Mode (for color reproduction)

Light intensity increases for the RGB segment on the color wheel, ensuring ample brightness while screening brilliant colors.

High Power

Normal Power

Low Power

R B W

Lamp Power (Basic concept)

G

G

Super - bright 4500lm

The XD3200U delivers super - bright 4500lm images.

It’s the ideal brightness for giving presentations in large meeting rooms and conference halls.

3000lm 4500lm

Y

Y

Precise Gradation Reproduction

Well-established DDP3020 DLP™ data processor

High-speed LVDS (low-voltage differential signal)

10-bit I/P conversion circuit eliminate jaggies

Additional useful functions

Motor-driven Lens Shift* & High Contrast of 2500:1**

* Function adjusts image in four directions (up/down/left/right)

without touching the projector.

** XD3200U only. WD3300U contrast is 2300 : 1.

LAN Control

Connect a computer with ProjectorView™ installed to a LAN for wired operation and monitoring of several different projectors.

WD3300U/XD3200U

WXGA / XGA PROJECTOR

Brilliant

Color TM

Color

Enhancer

Password

Lock

Instant

Shutdown

: Picture Perfomance sRGB

Center

Lens

3D Y/C

Digital Comb

Long-life

Lamp

PinP

*

Low Standby

Power

User Logo

Projection

Top / Side

Loading Lamp

Remote

Mouse

Control

LAN

(RJ-45)

: Presentation : User Friendly

Closed

Caption

DVI

*Only XD3200U.

10W

Speaker

HDMI

Motorized

Lens Shift

Low Fan

Noise

Input and Output Terminals

1 2 3 4 5 6

9 10 11 12

7 8

13 14 15

1 HDMI terminal

2

3

4

5

DVI-D (HDCP) terminal (DVI-D 24-pin)

Computer / Component Video IN-1 terminal

Audio IN-1 terminal (Mini jack)

6

7

Audio DVI-D terminal (Mini jack)

Video IN / Audio IN terminal

8

9

10

DC OUT [5V 1.5A (Max)]

LAN(RJ-45) terminal

Computer / Component Video IN-2 terminals

11

Monitor OUT terminal (Mini D-SUB 15-pin)

Audio OUT terminal (Mini jack)

12 Audio IN-2 terminal (Mini jack)

13

14

USB (Computer) terminal

Remote IN / OUT

15 Serial terminal (D-SUB 9-pin)

Specifications

Model

Display Technology

Resolution

Brightness

Contrast

Picture Size

Projection lens

Offset axis

Throw Ratio

Source Lamp

Computer Compatibility

WD3300U

0.65” 1-Chip DMD

1280×800 (Total 1,024,000 pixels)

4000lm

2300 : 1 (on / off)

XD3200U

0.7” 1-Chip DMD

1024×768 (Total 786,432 pixels)

4500lm

2500 : 1 (on / off)

40"~ 300" f=24.5-33.1mm, F=2.0-2.4

10 : -1 10 : 0

1.7 ~ 2.4

264W (Shut-off Time 4000hr) with Low Mode

330W (Shut-off Time 2000hr) with Standard Mode

640×400 ~ 1600×1200

True: 1280×800, Sync on Green available

640×480 ~ 1600×1200

True: 1024×768, Sync on Green available

Video Compatibility

Pc Input Terminals

Video Input

Terminals

Output Terminals

Communication

Terminals

Audio Speaker

Fan Noise

Dimensions(W×H×D)

Weight

Power Supply

Optional Accessories

NTSC / NTSC4.43 / PAL (including PAL-M, N) / SECAM / PAL-60,

Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p 50/60Hz),

1080i (1125i 50/60Hz), 1080p (1125p 50/60Hz), SCART (RGB+1V sync) mini D-sub 15pin×1, 5 BNC×1, DVI-D (with HDCP)×1

Audio: stereo mini jack(ø3.5mm)×3

Video: HDMI(ver.1.2)×1, RCA×1 or BNC×1, S-Video(4pin)×1 or S-Video Y/C(BNC)

Audio: RCA (L, R)×2

RGB: mini D-sub 15pin×1, DC Out: 5V 1.5A (MAX)

Audio: stereo mini jack (ø3.5mm)×1

LAN (RJ-45)×1, RS-232C:D-sub 9pin×1, USB×1 (Mouse control),

Wired remote in: stereo mini jack (ø3.5mm)×1 Wired remote out: stereo mini jack (ø3.5mm)×1

10W mono

26dBA (Lamp Low Mode)

450×187×373mm/17.7×7.4×14.7 in (excluding terminal cover)

10.3kg /22.7lbs (excluding detachable terminal cover)

AC100 - 240V, 50/60Hz

Lamp: VLT-XD3200LP

Lens: OL-XD2000SZ, OL-XD2000LZ, OL-XD2000TZ, OL-XD2000FR

Warranty

3-Years Parts/Labor, 3-Years Express Replacement Assistance,

1-Year or 500 hours lamp warranty (whichever comes first)

• Compliance with ISO21118-2005

• All brand names and product names are trademarks, registered trademarks or trade names of their respective holders

* Lamp life specification is an estimate based on information provided by the lamp manufacturer and is not the duration of the warranty. Lamp will shut-off automatically when usage reaches the specified estimated maximum lamp hours.

Screen Size and Projection Distance / Optional Lenses

Refer to the following table to determine the screen size.

W1 W W1

Front projection

Front projection, ceilling mounted

W1 W W1

WD3300U

XD3200U

WD3300U

XD3200U

A wide variety of optional lenses is available to suit any operating or user requirement.

OL-XD2000SZ

Short-throw Zoom Lens

OL-XD2000LZ

Long-throw Zoom Lens

OL-XD2000TZ

Tele-throw Zoom Lens

OL-XD2000FR

Rear Projection Short-thow Fixed Lens

L L

Converter Lens

(mounted on the standard lens)

Converter Lens

(mounted on the standard lens)

WD3300U

Screen size (WXGA 16:10) inch

40

60

80

100

150

200

250

300
