XEED SX7 SPECIFICATIONS
MULTIMEDIA
PROJECTOR
LCD PANEL
Product Class
Ultra-Portable
Type
Size and Number
LCOS reflective display, TFT Active Matrix
0.7” diagonal (15mm x 11mm), 3 panels
4:3
1400 x 1050 (SXGA+), 1470000 pixels
Aspect Ratio
Native Resolution
OPTICS
Lamp Type
275W NSH AC
Lens F Number and Focal F1.85 – F2.5; f=21.7 - 35.8mm
Length
Zoom Magnification and 1.7x Motorised
Control
Focus Control
Motorised Auto / Manual Focus
Lens Shift
9:1 (fixed)
IMAGE AND AUDIO
Brightness
4000 lumens (3200 lumens in Quiet Mode)
Brightness Uniformity
88%
Contrast Ratio
1000:1 (full on / full off)
Projection
Distance 1.2m – 9.0m (3.0m - 4.9m for a 100 inch image)
Coverage
Screen Size
40” - 300” (81 x 61cm - 610 x 457cm)
Digital
Zoom 1x - 12x
Magnification
Keystone
Correction Vertical: +/- 20° (Auto / Manual)
Range
Horizontal: +/- 20° (Manual)
Digital
RGB D-SXGA+ / D-SXGA / D-WXGA / D-XGA / D-SVGA / D-VGA
Compatibility
Analogue
RGB UXGA / SXGA+ / SXGA / WXGA / XGA / SVGA / VGA
Compatibility
Digital
Video
Scan 1080i / 1035i / 720p / 575p / 480p
Systems
Component
Video
Scan 1080i / 1035i / 720p / 575p / 575i / 480p / 480i
Systems
Video / S-Video Colour PAL / PAL-M / PAL-N / NTSC / NTSC4.43 / SECAM
Systems
Digital
Scanning Horizontal: 15-100kHz, Vertical: 50-100Hz, Clock: 170MHz
Frequency
Display Modes
Standard, Presentation, Movie & Photo, Adobe RGB, sRGB
Image Enhancement
12-bit Digital Gamma Correction
Built-in Speaker
1.0W RMS, Monaural
CONNECTORS
Digital RGB / Digital DVI-I 29-pin, HDCP compatible
Video /
Analogue RGB Input 1
Analogue RGB Input 2
Mini D-Sub 15-pin (Component via supplied adaptor cable)
Analogue RGB Output
Mini D-Sub 15-pin
S-Video Input
Mini DIN 4-pin
Composite Video Input
RCA x 1
Audio Input 1, Input 2, 3.5mm² stereo mini-jack x 3
Input 3
Audio Output
3.5mm² stereo mini-jack x 1 (variable level)
Mouse Control
USB Type B
Service
Port
/ Mini DIN 8-pin
Projector Control
MECHANISMS
Front
Mechanism
Elevation Mechanical foot, 10° maximum image elevation
RATINGS
Dimensions (W x H x D)
Weight
Power Source
Power Consumption
Noise Level
Operating Environment
Storage Environment
Warranty
266mm x 114mm x 336mm
4.8kg
100V - 240V AC, 50/60Hz
Normal Mode: 360W / Quiet Mode: 290W / Standby: 7W
Normal Mode: 35dBA / Quiet Mode: 31dBA
+5°C to +35°C
-30°C to +60°C
3 years
