Designed
for security.
Sony Professional
Video Security
Product Catalogue.
VERSION 4
ANALOGUE
www.pro.sony.eu/videosecurity
GO HYBRID
IP SOLUTIONS
1
Contents
Key Features
4
IP Fixed Cameras
24
IP Mini-dome Cameras
34
IP PTZ Cameras
44
CCTV Fixed Cameras
56
CCTV Mini-dome Cameras
62
Encoder
66
Recording Solutions
68
Accessories
72
Time to GO Hybrid
Our new Go Hybrid technology
integrates analogue and IP, HD and
standard definition products and
provides a host of benefits:
t Go Migrate
Migrate from analogue to IP
with hybrid recording solutions.
t Go Advance
Advance your capabilities.
Forward thinkers use the number one
software choice.
t Go Capture
You can capture everything with Sony
Professional surveillance cameras.
t Go Convert
Convert your video security network
with intelligent encoder solutions.
2
VIDEO SECURITY
INTRODUCTION
The future of video
security is here.
Sony Professional has long been recognised as one of the world’s leading video security
providers in both analogue and IP solutions. Today, we bring both together, with our
leading HYBRID technology.
As the video security world moves
from analogue to superior IP, more
and more end-users are looking for
a solution to help them migrate. Up
to 70% of the current market still uses
analogue cameras, but the undeniable
advantages of higher resolution, greater
intelligence and flexibility through
ease of installation is a major pull. If it
weren’t for legacy costs invested in their
analogue equipment, many would
make the switch tomorrow, enjoying all
the inherent IP advantages of reduced
overheads, fewer false alarms, more
efficient monitoring and clearer imagery.
Sony Professional’s hybrid video security
solutions allow your clients to make
that migration to IP without throwing
away analogue systems. And it works
generically, providing seamless
integration of old and new across Sony
Professional’s entire range and other
manufacturers’ products.
Innovation you can rely on
Sony Professional products and solutions
are developed on our unique Distributed
Enhanced Processing Architecture (DEPA™)
platform, harnessing technological
intelligence to overcome practical
challenges.
Each product in our range – recorders,
cameras, software, encoders and
monitors – bring technological benefits
designed to provide effective, reliable
and intuitive video security.
In addition, Sony Professional IP cameras
utilise our unique IPELA concept: using
the power of IP to deliver enhanced
reality, intelligence and usability. These
values mean that each Sony Professional
video security camera is designed to
use the advantages of IP to overcome
challenging conditions and deliver
spectacular results, 24/7.
A vision we can share
With technology creating outstanding
benefits in security operations, our vision
for an integrated analogue/IP solution
provides a clear strategy for your clients.
Based on future-proofed products and
innovative solutions, Sony Professional
offers a simple entry into the world of IP
and a route forward as security
demands change. From banks,
transportation, education and
government/public venues to industrial
and corporate, retail and tourism, Sony
Professional has a solution that will
enhance your clients’ security – right now.
3
VIDEO SECURITY
KEY FEATURES
DR
View-DR.
View-DR technology from Sony offers an extremely wide
dynamic range.
View-DR is a combination of Sony’s
full-capture Wide-D technology, the
high-speed ‘Exmor’ CMOS sensor and
Visibility Enhancer (VE). The full-capture
Wide-D technology captures images
using a 'standard' exposure time and
takes either one or three images using
very short exposure times depending on
the camera type. The newly developed
View-DR algorithm nearly doubles the
camera's sensitivity when compared to
conventional Wide-D technologies.
One image is taken using a standard
exposure time and either one or three
images are taken using very short
exposure times, depending on the
camera type.
(This illustration shows one standard
exposure time and three very short
exposure times.)
To capture multiple HD resolution images
at a very high speed, the ‘Exmor’ CMOS
sensor utilises its high-speed readout
characteristics. When combining multiple
images, VE is employed to provide a high
level of chrominance and luminance. With
View-DR, monitored images become very
visible; even more so than when viewed
with the naked eye.
1/60 s
1/60 s
Exposure Time
➊ Standard Exposure Time
View-DR
Dedicated
Algorithm
➋ Short Exposure Time
High-speed readout by
Exmor CMOS sensor
Captured Image by ➊
➌ Shorter Exposure Time
➍ Shortest Exposure Time
Captured Image by ➋
Captured Image by ➌
Captured Image by ➍
Visibility Enhancer
Combine the four images
to reproduce a
high-contrast image.
Apply “Visibility Enhancer” for high
chrominance and luminance.
4
VIDEO SECURITY
KEY FEATURES
IR
IR Illuminator.
Built-in Infrared (IR) Illuminator from Sony clearly captures objects
in the dark up to 15m (49 feet) away with IR Illuminators, which
allow the camera to operate in 0 lux lighting conditions.
Low visibility in dark scenes is one of the
biggest challenges of HD/Megapixel
camera for the industry. Because
the visibility performance of an HD/
Megapixel camera in dark scenes is
worse than that of modern analogue
camera, Sony has overcome or
even outperformed this limitation by
introducing cameras with embedded
IR illuminators.
With embedded IR illuminator, you can
enjoy clear visibility even under 0 lux,
ON
OFF
complete darkness. IR Illuminator has
been designed to work seamlessly along
side these technologies, True Day/Night,
XDNR, Visibility Enhancer and View-DR
and is able to capture clear pictures up
to a distance of 15m.
True Day/Night
The human eye can see between
400nm and 700nm, the Sony IR
cameras are sensitive between
400nm and 1000nm.
5
VIDEO SECURITY
KEY FEATURES
IPELA – harnessing
the power of IP.
IPELA is Sony Professional’s vision of the ultimate workplace,
revolutionising the way businesses communicate over global
IP networks
Why IPELA?
As global broadband networks have
rapidly expanded, businesses are now
able to communicate in real-time,
person-to-person, location-to-location.
Now Sony Professional is driving the future
of business communications with our
IPELA series of visual communications
products – preparing your customers for
the future.
Reality
Your clients can improve the efficiency
of their security via high-quality video
surveillance products. IPELA will enable
them to get a clearer picture of
crucial events and will cut-down false
alarms and time spent searching
through footage.
6
Our IPELA visual communication
products deliver high-resolution images
with naturally clear audio – at a
quality that has never been previously
achieved. Each new system introduced
by Sony Professional, conforms to our
three-pronged IPELA concept: reality,
intelligence and usability.
Intelligence
Our IPELA products incorporate
technology such as visual recognition,
intelligent detection methods, robust
processing techniques and advanced
search capabilities. They enhance
the operator’s surveillance and
monitoring capabilities, allowing greater
concentration on the business at hand.
Usability
With easy to use controls and intuitive
graphical user interfaces, as well as
the flexibility to meet individual user
requirements, IPELA products minimise
the learning curve – saving your clients
time and money and improving results
from day one.
VIDEO SECURITY
KEY FEATURES
DEPA – making intelligence
work harder.
Sony Professional’s Distributed Enhanced Processing
Architecture (DEPA™) platform revolutionises surveillance
monitoring for almost any application.
Taking surveillance to the next level
Our complete IP surveillance solution,
Sony Professional’s Distributed Enhanced
Processing Architecture (DEPA™)
platform, incorporates Intelligent video
analytics to help your customers identify
critical events. Unlike conventional
monitoring solutions, DEPA systems
provide enhanced intelligence to help
surveillance operators take quick action
and provide streamlined workflows.
Intelligent alarm triggers improved
performance
With triggers designed to spot motion,
DEPA-enabled surveillance equipment
assists security staff in seeing crucial
events in real-time.
The Intelligent Motion Detection and
Intelligent Object Detection functions
can be used alongside parameters set
by the user. An alarm will be triggered
when a virtual line is crossed or an object
is moved from a specific location.
This feature can also count how many
objects enter a predetermined area,
calculate an object’s size, determine the
direction in which something is moving,
and gauge its speed. These movement
filters can dramatically minimise false
alarms and target real alarms, so
improving surveillance efficiency.
The filters can also be used to quickly
and effectively retrieve images, cutting
down searching times. For example,
virtual areas can be set to search for
items that have been removed or stolen,
or the system can immediately retrieve
footage of a vehicle moving the wrong
way along a one-way street.
Intelligent processing enhances
efficiency
Unlike units that use separate image
processing and costly software, Sony
Professional’s DEPA design divides
traditional processing into two tasks.
Front-end processing is distributed to the
endpoints of systems within cameras,
while back-end processing takes place
at the recorder.
Front-end processing:
t %JTUJOHVJTIFTPCKFDUTGSPN
environmental noise
t %FUFDUTNPWJOHBOEPS
stationary objects
t $POWFSUTPCKFDUJOGPSNBUJPOJOUP
metadata and then transfers it
over the network separately from the
digital video stream
Intelligent recording minimises storage
and network resources
Users can also choose to stream
and record only the events that cause
concern when alarms are activated
– therefore streamlining storage and
conserving network resources. And
because DEPA divides up the analytic
tasks between cameras and recorders,
the amount of video data transmitted
from the camera is reduced. Together
with the reduction in the storage
capacity, this creates a far more stable
and efficient system in comparison to
conventional surveillance.
Back-end processing:
t 3FDFJWFTBOETUPSFTQSFQSPDFTTFE
object data from cameras
t &YUSBDUTPCKFDUTXIJDINBUDIUIF
filtering conditions set in the recorder
t %JTQMBZTJOGPSNBUJPOBOEDSFBUFTBO
alarm response appropriate
to specific conditions
Concept of DEPA
Server with
IMZ-NS100
Series installed
Network camera
Image data
Metadata
(Camera ID, time,
location and size of
object, etc.)
IMAGES
Metadata is
generated
in DEPAenabled
camera
METADATA
Image data is
recorded by the
trigger of the alarm
ALARM Video Motion
Filter (VMF)
The IMZ-NS100 Series
detects the alarm
by matching the
Metadata and VMF
Metadata
7
VIDEO SECURITY
KEY FEATURES
Exwave PRO™ –
enhanced image performance.
Image performance is now significantly enhanced with Sony
Professional’s innovative ExwavePRO™ technology, unique to
our fourth generation IP cameras.
Minimising motion blur,
enhancing clarity
Sony is a world-leader in the design
and manufacture of CCD (chargecoupled device) and CMOS
(complimentary metal-oxide
semiconductor) imaging devices.
At the heart of our new ExwavePRO™
technology is an all-new CCD design
– specifically developed to meet the
requirements of security applications.
Until now, CCD technology had only
been used with interlaced scanning
CCDs (typically designed for use in
camcorders), to capture fast movement
at a relatively high resolution.
For security applications, however,
motion blur can be a problem, with
the details of people or objects
becoming difficult to make out on
an interlaced image.
ExwavePRO™ CCDs use progressive
scan technology – every frame of
video is captured at full resolution with
no interlacing. When trying to read the
details of a number plate on a fastmoving car, progressive scan technology
effectively doubles the vertical resolution
of the image being analysed, giving
clear, precise results.
High sensitivity for low-light conditions
In addition, our ExwavePRO™ also uses
a new Complementary Colour Filter
technology that results in approximately
twice as much light reaching the CCD.
This produces a normal looking video
output, but the higher luminance signalto-noise ratio results in an image that
can be twice as bright as one produced
using a Primary Colour Filter – ideal for
clear results in low light conditions.
ExwavePRO™ technology is a key
feature of all of Sony Professional’s fourth
generation IP cameras. The introduction
of this technology, alongside our equally
innovative Light Funnel system, means
our security cameras deliver a higher
resolution imaging performance
than ever before.
Conventional camera in low-light conditions
ExwavePRO in low-light conditions
8
VIDEO SECURITY
KEY FEATURES
Megapixel technology
for true versatility.
From surveillance and wide area monitoring, to identification
and response, Sony Professional Megapixel cameras will give
your clients’ security teams confidence in difficult conditions.
The ideal combination of resolution
and storage
At 1.3 Megapixel resolution, our digital
lenses provide the detail and image
quality you need without creating
prohibitive file sizes.
This resolution is ideal for clear
identification of faces, detail on clothing,
or vehicle registration plates. It also
provides the depth of information you
may need for analysis of events. At the
same time, at 1.3 Megapixels, data is
kept to a manageable size for efficient
network transmission and storage.
Megapixel features
Our Megapixel surveillance range
includes indoor and outdoor cameras to
meet virtually any application.
Features include:
t FOIBODFE[PPNMFOTFT
t WJFXJOHBOHMFTPGPWFSEFHSFFT
t BVUPNBUJDEBZUPOJHIUNPEFT
t WBOEBMSFTJTUBOUIPVTJOH
t QBUFOUFECBMMKPJOUMFOTNPVOU
mechanisms
Sony Professional Megapixel cameras
are being installed in corporate, retail,
education, airport, stadium and public
applications.
1.3 Megapixel resolution
VGA resolution
9
VIDEO SECURITY
KEY FEATURES
Light Funnel technology
for increased sensitivity.
Our Light Funnel technology leads the way in 24/7
surveillance monitoring, enabling enhanced camera
sensitivity in low-light conditions.
Designed for low-light
The Light Funnel function enhances
camera sensitivity in low-light conditions.
When applied, it combines two pixels
horizontally and two pixels vertically to
create up to 4x enhanced sensitivity.
As a result, the sensor converts a
greater amount of light energy into
more electrons to produce a stronger
electrical signal.
Conventional technologies often use
slow shutter speeds to achieve higher
sensitivity, which leads to blurring and
reduced accuracy. Sony Light Funnel
function retains crisp images even when
used at night.
10
Automatic response
This function can be activated
automatically in response to the light
conditions, or on a pre-specified time
schedule, allowing operators to monitor
moving objects at dusk without manually
changing settings.
ON
This increased sensitivity with exceptional
clarity lends itself to 24/7 exterior
locations, from business perimeters,
car parks and city streets to nightclub
entrances, vandalism hot-spots and
transport hubs.
OFF
VIDEO SECURITY
KEY FEATURES
DynaView™ technology
delivers a wider range.
Incorporating the newly developed DynaView™ technology,
Sony Professional surveillance cameras offer an extremely wide
dynamic range allowing clearer images to be captured.
SNC-DF85/DF50
Camera Image*
High Shutter
Speed
Normal Shutter
Speed
In comparison to the human eye, the
dynamic range of a camera is very
limited. The difference between the
smallest and largest amount of light that
can be transformed into a viewable
video signal is relatively small – even in
the highest-performing cameras – until
the advent of Wide Dynamic Range.
Sony Professional’s DynaView™ introduces
Wide Dynamic Range to surveillance
cameras, bringing the video security range
closer to the capabilities of the human eye.
DynaView™ technology
DynaView™ improves a normal camera’s
dynamic range by over 128 times, which
is perfect for security and surveillance
applications where lighting conditions
change over time. The technology uses
an advanced Backlight Compensation
function that reduces overexposure
of the background image and so
provides optimum exposure for both the
background and the subject.
In DynaView™ mode, the image is
captured twice: the dark areas of the
shot are picked up with the normal
shutter speed, and the brighter areas by
a higher shutter speed.
Our special DSP LSI technology then
combines the two images to create one
extremely high contrast picture, which
couldn’t be obtained on a conventional
camera.
For companies that need to monitor
indoor areas with changing backlights
– such as glass-fronted buildings –
DynaView™ cameras will compensate
for the difference between inside and
out, enabling your clients to benefit
from greater detail regardless of lighting
conditions.
11
VIDEO SECURITY
KEY FEATURES
Dynamic Frame Integration –
exceptional picture clarity.
When your customers need to catch moving objects
or people on camera, our Dynamic Frame Integration
technology can help them see clearer footage.
Reducing the blur
Dynamic Frame Integration (DFI)
technology optimises the image
acquisition for both stationary and
moving image components at the same
time. So when number plates need
to be recorded or people need to be
recognised, this technology can provide
the best results.
The DFI technology detects movement
within an image and reproduces those
areas with minimal blurring.
At the same time, areas with little or no
movement are displayed naturally with
reduced jagged edges. This provides all
the benefits of progressive scan, whilst
taking advantage of improved sensitivity.
DFI, combined with the interlaced-scan
CCD, can provide clearer images than
ever before, even in low light conditions.
SNC-DF85/DF80/DF50
Camera Image
Conventional
Camera Image
Image Comparison Between SNC-DF85/DF80/DF50 Camera and a Conventional Camera
12
VIDEO SECURITY
KEY FEATURES
Dual encoding –
ideal for fixed and moving images.
With dual-encoding capabilities, our surveillance solutions
enable your clients to easily transfer images over the Internet
and across networks, without compromising on resolution.
Transferring and storing images
Your clients can transfer and store
surveillance images effectively with our
dual-encoding technology. Designed
for ease of use and to reduce file sizes,
dual-encoding cameras support two
compression formats: JPEG and MPEG-4.
The JPEG compression format is
the industry standard for high-quality
still images, while the MPEG-4 format
provides clear moving images efficiently
over networks with limited bandwidth.
Flexibility to suit your clients’ needs
This dual encoding capability enables
clients to create, transfer and store
protocols to meet their precise needs.
As an example, a Sony Professional
system can be set up to transfer MPEG-4
images over a WAN connection or an
Internet VPN where network bandwidth is
limited. And at the same time, it can store
high-resolution JPEG images on a server
configured to an organisations LAN.
Local Area Network (LAN)
WAN/VPN
ROUTER
JPEG &
MPEG-4
Images
JPEG
SNC-DF50
IMZ-RS Series Server
MPEG-4
Monitoring PC
Dual Image Encoding
13
VIDEO SECURITY
KEY FEATURES
H.264 – the latest industry standard…
as standard.
Sony Professional has adopted H.264 – the latest
compression standard – in all of its latest network cameras,
providing enhanced images with reduced bandwidth.
Better quality, reduced bandwidth
H.264 (MPEG-4 Part 10) was developed
to provide high-quality video at a much
lower bit rate than standard MPEG-4 or
JPEG. As a result, H.264 compression
represents a significant benefit to
network security camera operations,
offering enhanced images with reduced
bandwidth.
Less bandwidth
For network security users, H.264 offers all
sorts of practical benefits. Using network
cameras designed to work with H.264,
your clients will need less bandwidth.
MPEG-4 requires approximately one-third
of the bandwidth used by JPEG; H.264
requires just one-fifth. That’s a 40% saving
between standard MPEG-4 and H.264.
Reduced storage
With better compression, stored files
take up much less room on servers,
potentially saving significant sums in
network storage requirements.
Improved quality
The data capture elements of each
frame in H.264 focus on the movement
areas, which has the benefit of creating
far more accurate images with more
detail. In security applications, this
can make a real difference to the
identification of facial features, for
example, or a vehicle registration plate.
PSNR (dB)
Video Parameters:
- 10 frames/s
- QCIF
(176 x 144 pixels)
- 10 seconds of video
(100 frames)
40
38
H.264
MPEG-4
JPEG
36
35
34
32
30
28
Bit rate (Kb/s)
H.264 requires less bandwidth, while
delivering better picture quality.
14
0
100
200
300
VIDEO SECURITY
KEY FEATURES
Intelligent Motion Detection –
driving actions directly from the camera.
Intelligent Motion Detection (IMD) enables your clients to
set up automatic actions based on specific movement
parameters.
Automatic prevention
and storage capabilities
The built-in IMD function can trigger
a variety of actions for prevention,
monitoring and apprehending. For
example, a particular motion pattern
could trigger the activation of lights,
alarms or other local devices through
its output relays. Alternatively, it could
prompt the storage and transfer of
images for later analysis. False alarms
caused by noise and repeated motion
patterns are minimised thanks to an
advanced Sony algorithm.
Enhanced performance with DEPA
When used in conjunction with Sony
Professional’s DEPA™- enabled recorders
or software, a multitude of filter functions
are available. These allow your clients to
initiate alarms based on more specific
movements, such as passing a virtual
borderline.
15
VIDEO SECURITY
KEY FEATURES
IP66 – Vandal Resistant cameras
for tough applications.
Many of our models feature Vandal Resistant versions
specifically designed for outdoor use.
Meeting IP66 standard for dust
and water ingress
Our outdoor cameras are designed to
cope with tough conditions. Many of
our newest models comply with IP66
standards for protection against water
and dust, enabling your clients to enjoy
reliable security, regardless of weather
conditions or installations in dusty alleys,
streets or loading bays.
Vandal Resistant too
Our outdoor cameras are built to the
highest standards. Vandal Resistant
cameras are housed in aluminium
die-cast enclosures. Robust mini-dome
cameras feature impact-resistant
polycarbonate domes.
16
VIDEO SECURITY
KEY FEATURES
Analogue Video Output –
for fast installation and set-up.
While Sony Professional IP Cameras bring many advantages
to users, some installers prefer analogue set-up. That’s why
we’ve retained analogue video output options on all our
cameras.
Set up options to suit you
When it comes to setting up viewing
angles and focus adjustment, we know
that many installers prefer to use their
tried and tested analogue monitors.
With Sony Professional, even with the
latest IP cameras, we’ve retained
the Analogue Video Output option. You
can choose to install using PC-driven
software or analogue technology –
whichever suits you and the specific
application.
17
VIDEO SECURITY
KEY FEATURES
HD for your security cameras.
The security market continues to demand higher quality video
images, in response to these demands Sony has introduced a
range of High Definition (HD) CCTV solutions. Sony HD CCTV solutions
represent the next generation in video surveillance technology.
a variety of data formats. For maximum
flexibility and optimum performance
Sony HD CCTV solutions provides H.264,
MPEG-4 and JPEG video compression
formats.
From a surveillance solutions
perspective, the transition to HD CCTV
provides significant benefits. HD CCTV
technology delivers real time capture
and delivery of highly detailed images
over a wide field of view, highly
accurate object detection, recognition,
recording and display allow for forensic
levels of image analysis not found in
existing technology.
Sony HD CCTV solutions combine the
benefits of digital technology with the
ease of use of analogue to provide
the optimum in video security systems
performance.
HD CCTV is based upon technology
designed for use in high quality
broadcast television applications.
Video is captured using specialist High
Definition CMOS sensors, the sensors
contain a pixel array far greater than
that found in standard definition CCTV
sensors, this results in vastly superior
image quality and a greatly enhanced
field of view.
Additionally the CMOS sensors utilise a
progressive scan system which eliminates
the image flicker and blurring associated
with interlace scanning systems normally
found in standard definition CCTV
technology. The resulting images can
be transmitted via a suitable network in
18
Sony HD CCTV solutions deliver
additional enhancements to image
quality by utilising Sony’s unique
eXcellent Dynamic Noise Reduction
(XDNR) and Visibility Enhancer (VE)
technology.
XDNR provides clear images by
drastically reducing the image noise
and motion blur encountered under low
light illumination. VE optimises scene
visibility by improving wide dynamic
ranges under conditions of high
contrast illumination.
The superior image quality provided
by Sony HD CCTV solutions delivers
significant advantages when coupled
with the powerful video analytics
capability of Sony’s Advanced
Distributed Enhanced Processing
Architecture (DEPA). DEPA technology
offers advanced, intelligent alarm
functionality whilst distributing and
sharing image processing across the
network. This powerful combination
results in a reduced operator workload
through vastly improved alarm
handling, superior use of network
resources and a security solution
that’s more flexible, scalable and
economical.
Sony is the industry leader in the
provision of HD CCTV technology, our
portfolio provides for a full range of
powerful HD CCTV solutions.
Camera’s, SNT Encoder, NSR recording
and RSM monitoring software solutions
along with a comprehensive range of
accessories combine to provide the
complete HD CCTV systems solution
package.
In addition, total flexibility through
our Hybrid approach to seamless
integration of new and existing video
technology and maximum freedom
of choice via our participation in
the development of a global open
standard for network video products
via our Open Network Video Interface
Forum (ONVIF) membership ensures
that Sony HD solutions are the HD CCTV
products of choice.
VIDEO SECURITY
KEY FEATURES
eXcellent Dynamic Noise
Reduction (XDNR).
XDNR delivers superior noise and ghost free images under
low light conditions.
The ability of a camera to deliver noise
and ghost free images under low light
conditions is fast becoming an essential
requirement for IP CCTV imaging
solutions.
The delivery of high quality images under
low light conditions presents numerous
technical challenges. Increased
image noise levels resulting from signal
amplification and image ghosting
caused by slow shutter speeds are
commonly encountered issues when
using existing CCTV technology within
a low light environment.
Recognising the importance of noise
and ghost free images in low light, SONY
has developed its unique eXcellent
Dynamic Noise Reduction (XDNR)
technology specifically for the IP CCTV
environment.
Sony HD SNC-RH PTZ cameras and
SNT-EX/EP encoder solutions offer XDNR
as a standard feature.
Using SNC–RH PTZ cameras combines
the quality of high definition video
with the superior noise and ghost free
images offered by Sony’s unique XDNR
technology. By migrating to the Sony
range of SNT-EX/EP encoders, XDNR
performance can be added to any
existing cameras and offers the perfect
hybrid solution.
XDNR technology from Sony offers
the optimum in low light imaging
performance. Available from a range of
products the technology is ideal for new
or existing installations for superior image
capture in low light conditions.
ON
OFF
XDNR utilises advanced 2DNR and 3DNR
signal processing methods in order
to remove random and fixed noise
and image ghosting, eliminating the
motion blur normally associated with the
capture of moving images in low light.
Delivering superior image quality in low
light, SONY XDNR offers the optimum in
noise reduction performance for IP CCTV
solutions.
19
VIDEO SECURITY
KEY FEATURES
Distributed Enhanced Processing
Architecture (DEPA) Advanced.
Building upon the success of DEPA, DEPA Advanced is an
enhanced technology that offers high quality image analysis
and detection.
Video surveillance has historically been
dependent upon human intervention
and control, the system operator often
providing the interface between alarm
activations and required actions. The
inability of the operator to monitor and
process multiple alarm events is often
cited as the weak point in traditional
surveillance systems.
The more recent introduction of intelligent
video and alarm analysis has provided
a reduction in operator workflow by the
addition of pre-configured alarms,
linked to pre-programmed actions.
As a result of its processor intensive
requirements video analysis can however
be cost prohibitive for many systems,
especially in the analogue environment.
Introduced in 2006 Sony’s unique
Distributed Enhanced Processing
Architecture (DEPA) addresses this issue
with an innovative design approach.
SONY DEPA is an embedded technology
providing pre-processing of image data
within its camera technology and post
of processing of image data within its
recording and monitoring solutions. Alarm
and image meta data generated by
the camera is transmitted on demand to
the recording solution where appropriate
alarm actions may be initiated.
20
This distributed architecture allows for
intelligent use of network bandwidth and
reduces the bottlenecks associated with
existing video analysis systems.
Operating a continuous product
development policy SONY introduces
DEPA Advanced technology. Building
upon existing success, DEPA Advanced is
an enhanced DEPA technology and now
offers the highest quality image analysis
and detection. SONY’s embedded DEPA
Advanced technology delivers unrivalled
analytical performance within a range
of imaging, recording and monitoring
products.
Utilising SONY’s unique Intelligent Motion
Detection (IMD) to determine real or
environmental movement and Intelligent
Object Detection (IOD) to monitor the
image for violation of a predetermined
rule, DEPA Advanced provides highly
accurate image meta data to the
recording and monitoring solution for
alarm activation and processing. A
comprehensive range of enhanced
predetermined alarm filters include,
tamper alarm, virtual fence, trip wire,
missing object, people counting and anti
loiter options, audio analysis completes
the range of advanced features on offer
with DEPA advanced technology.
SONY offers a comprehensive range
of embedded DEPA Advanced
products from the Sony HD SNC-RH PTZ
cameras and SNT-EX/EP encoders to
NSR1000 recorders and RSM Advanced
monitoring software solutions. A
comprehensive range of accessories
combine to provide the complete DEPA
Advanced end to end solution.
Minimising false alarms whilst maximising
operator workflow and bandwidth
usage, SONY DEPA Advanced offers the
optimum in cost effective, flexible and
scalable video analysis solutions.
VIDEO SECURITY
KEY FEATURES
Visibility Enhancer (VE).
VE technology from Sony offers the optimum in wide
dynamic range performance.
The ability of a camera to deliver
optimised images under extreme lighting
conditions is known as its wide dynamic
range capability. Wide dynamic range
is an essential feature when considering
image capture under demanding
lighting conditions.
Video surveillance technology has
traditionally failed to deliver high
quality images under the demanding
conditions of high contrast scene
illumination. Delivering wide dynamic
range by resolving bright and dark areas
of the image challenges traditional
image processing technology.
Existing technology may be optimised for
either bright or dark areas of the scene,
but not simultaneously. The resulting effect
is the reduced visibility of target objects.
In response to this problem Sony
has developed its unique Visibility
Enhancer (VE) technology. During image
processing VE captures and dynamically
monitors signal levels, reducing the
extreme levels of brightness within
the scene and increases levels within
the darker areas. This simultaneous
processing and adjustment of both
light and dark areas of the scene
delivers improved wide dynamic range
performance with enhanced scene
visibility and superior image quality.
Sony HD SNC-RH PTZ cameras and
SNT-EX/EP encoder solutions offer VE as
a standard feature. Using SNC–RH PTZ
cameras combines the quality
of high definition video with the wide
dynamic range capability offered
by Sony’s unique VE technology.
By migrating to the Sony range of
SNT-EX/EP encoders, VE performance
can be added to any existing cameras
and offers the perfect hybrid solution.
ON
OFF
VE technology from Sony offers the
optimum in wide dynamic range
performance. Available from a range of
products the technology is ideal for new
or existing installations for superior image
capture in all lighting conditions.
21
VIDEO SECURITY
KEY FEATURES
Open Network Video Interface
Forum (ONVIF).
In recognising cross-manufacturing compatibility as the key to
widespread adoption of network video solutions, Sony along
with a number of leading manufacturers have pioneered the
establishment of ONVIF (Open Network Video Interface Forum).
The global standards for analogue
video are long established and deliver
full interconnectivity and interoperability
between manufacturer’s products. IP
cameras and network video solutions
do not however currently benefit from
a global interoperability standard. As
a result the exciting potential for the
migration from traditional analogue
systems to IP network video solutions is
restricted.
The proliferation of IP network video
solutions presents a unique set of
challenges for both end users and
system integrators alike. At a systems
integration level the wide range of
product on offer can often be limited
in its application by the differing
standards for image compression and
network video transmission found from
manufacturer to manufacturer.
This lack of a unified standard defines
an obvious limiting factor in the global
deployment of fully integrated network
video solutions. As a result we restrict
customer choice and are unable to fully
realise the clear benefits on offer from
the wide spread use of this technology.
22
In recognising cross manufacturing
compatibility as the key to wide spread
adoption of network video solutions,
SONY along with a number of leading
manufacturers have pioneered the
establishment of ONVIF (Open Network
Video Interface Forum). Established
in 2008, ONVIF is a worldwide industry
forum encompassing manufacturers,
developers, consultants, systems
integrators, and end users and is open
to any group interested in furthering the
goals of the organisation.
ONVIF is committed to promoting the
adoption of network video solutions within
the global security market. Focusing on
system interoperability, the development of
a worldwide open standard is the forums
primary mission.
SONY through its commitment to
adoption of the open standard
introduces simplicity and ease of use
to the integration of solutions delivered
by multiple manufacturers. The SONY
range of network video solutions offers
compatibility with a wide range of
manufacturing platforms making it
even easier for end users, integrators,
consultants and manufacturers to
integrate with SONY products.
Using ONVIF-enabled SONY products
unlocks freedom of customer choice
and delivers the exciting opportunities
available from integrating SONY’s truly
flexible and scalable network video
solutions.
23
VIDEO SECURITY
IP FIXED CAMERAS
SNC-P1
Enter the world of IP monitoring with the Sony SNC-P1
MPEG-4/JPEG Network Camera.
Key Features and Benefits
1
Specifications
Camera
4 1/4-type progressive scan CCD.
Image device
Clear high performance images
Number of effective pixels (HxV)
Bi-directional audio with built-in microphone.
Transmits audio in both directions, in-built microphone
transmits audio from remote site
Electronic shutter
In-built pre and post alarm image storage.
Allows internal storage of alarm images
Lens type
Dual encoding. Maximum flexibility when streaming
video data
F-number
Auto gain control (AGC)
Exposure control
White balance modes
Horizontal viewing angle
Focal length
Minimum object distance
1/4-type progressive scan CCD
330,000 (659 x 494)
Auto/Manual 1 to 1/10,000 Slow Shutter option On/Off
Auto/Manual
Auto/Shutter priority/ Manual
ATW/Indoor/Outdoor/One push auto/Manual
Fixed
Horizontal: 53.4°, Vertical: 40.0°
f=3.8mm
F2.0
500mm
Standard Features and Benefits
t Motion detection alarm trigger. External alarm
output from motion triggered alarms
Image size (H x V) MPEG-4
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Image size (H x V) JPEG
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
MPEG-4 frame rate
25fps (320x240), 15fps (640 x 480)
JPEG frame rate
25fps (320x240), 18fps (640 x 480)
Audio
Audio compression
G.711 (64kbps)/G.726 (40, 32, 24, 16kbps)
Network
t JPEG and MPEG-4 compression formats.
Allows maximum flexibility for image transmission
Protocols
Number of clients
TCP/IP, UDP, RTP, RTCP, ARP, ICMP, HTTP, FTP, SMTP, DHCP, DNS,
NTP and PPPoE, SNMP
10 (MPEG4), 20 (JPEG)
Interface
Analogue connectivity
Dimensions
Ethernet connectivity
I/O port connectivity
Audio connectivity
Mini-jack
100Base-TX/10Base-T (RJ-45)
Sensor in 1, Alarm out 1
External Microphone Input: Mini-jack, Plug-in power,
2.2kΩ Unbalanced. Line Output: Mini-jack
Analogue video output
Video system
99.5mm
Horizontal resolution
S/N ratio
Sensitivity colour
Dimensions (W x H x D)
Power requirements
Power consumption
36mm
36mm
Approx. 225g
99.5 x 36 x 138.5mm without projection
DC 12V
3.5W
0 to +35°C (32 to 95°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
System requirements
24
48dB
4.7lx (F2.0,50IRE)
Operating temperature
Operating system
138.5mm
400TVL
General
Weight
138.5mm
PAL/NTSC
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo, 2GHz or
higher. RAM: 1GB or more. Microsoft Internet Explorer Ver. 5.5
or 6.0 or 7.0
Supplied Accessories
AC Adaptor (x1), CD-ROM (x1, Setup Program and User’s
Guide), Stand (x1)
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CS10
Make the move from CCTV to IP-based monitoring
with the affordable Sony SNC-CS10.
Key Features and Benefits
Specifications
Analogue output. Ideal for use when adjusting the camera
viewing angle during installation
Camera
Dual encoding. Maximum flexibility when streaming
video data
Electronic shutter
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
Alarm function motion detection and pre/post alarm
recording modes. Ideal for interfacing to external alarm
devices. Alarm image storage capability
Standard Features and Benefits
White balance modes
Lens mount
1/4-type Progressive Scan CCD
330,000 (659 x 494)
Auto/Manual Slow Shutter ON/OFF
Auto/Manual (-3dB to +28dB)
Auto Iris Lens/Manual Iris Lens
ATW/Tungsten bulb/Daylight/One-push auto/Manual
CS Mount
Image size (H x V) MPEG-4
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Image size (H x V) JPEG
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
MPEG-4 frame rate
25fps (320x240), 15fps (640 x 480)
JPEG frame rate
25fps (320x240), 18fps (640 x 480)
Audio
t Sony progressive scan CCDs and advanced DSP
technology. Provides clear and detailed images while
maintaining high sensitivity
Audio compression
G.711 (64kbps)/ G.726 (40, 32, 24, 16kbps)
Network
Protocols
t DC Servo Auto Iris Lens capability. Ideal for both outdoor
and indoor use
Number of clients
Authentication
TCP/IP, UDP, RTP, RTCP, ARP, ICMP, HTTP, FTP, SMTP, DHCP, DNS,
NTP and PPPoE, SNMP (MIB2)
10 (MPEG4), 20 (JPEG)
IEEE802.1X
t Compact and slim design. Fits 8-inch camera housings
Interface
t Variety of power options AC 24V, DC 12V.
Ethernet connectivity
10 Base-T/100Base-TX (RJ-45)
I/O port connectivity
Sensor in x 1, Alarm out x 1
Analogue connectivity
t Five preset JPEG picture quality settings with constant
bitrate algorithm. Limits data bitrate while maintaining
high-quality images, ideal when network bandwidth is limited,
useful for calculating storage capacity and the required
bandwidth during installation
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
Dimensions (W x H x D)
Power requirements
Power consumption
Dimensions
NTSC/PAL (Composite)
400 TV lines
More than 48dB
1.7lx (50IRE, F1.0, AGC ON)
General
Weight
t Privacy masking. Ideal for masking sensitive areas of the
video image
Analogue video output BNC x1, 1.0Vp-p, 75Ω
Approx. 480g
70 x 57 x 116mm
AC 24V/DC 12V
5.7W max.
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
70mm
System requirements
66.3mm
57mm
Operating system
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo, 2GHz or
higher. RAM: 1GB or more. Microsoft Internet Explorer Ver. 5.5
or 6.0 or 7.0
Supplied Accessories
116mm
5.9mm
Screw, Wire Rope, CD-Rom (User’s Guide, IP Setup Program,
SNC Audio Upload Tool, SNC Video Player, Customer
Homepage Installer), Installation Manual, Warranty Booklet,
Warranty Sheet, AC Cable.
25
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CS11
Make the move from CCTV to IP-based monitoring
with the affordable Sony SNC-CS11.
Key Features and Benefits
Specifications
Analogue Video Output. Ideal for use when adjusting
the camera viewing angle during installation
Camera
Image device
Number of effective pixels (HxV)
Dual encoding. Maximum flexibility when streaming
video data
Electronic shutter
Auto gain control (AGC)
Exposure control
Alarm function. Motion detection and pre/post alarm
recording modes
White balance modes
Lens type
Bi-directional audio function. Allows remote transmission
of audio in both directions
1/4-type Progressive Scan CCD
330,000 (659 x 494)
Auto/Manual, Slow shutter ON/OFF
(-3dB to +28dB)
Auto Iris Lens/Manual Iris Lens
ATW/Indoor/Outdoor/One-push auto/Manual
Vari-focal zoom lens
Lens mount
CS Mount
Horizontal viewing angle
27° to 66°
Focal length
F-number
f=3.0 to 8.0mm (F1.0 to F1.4)
F1.0 (wide), F1.4 (tele)
Standard Features and Benefits
t Five preset JPEG picture-quality settings with
constant bitrate algorithm. Limits data bitrate while
maintaining high-quality images, ideal when network
bandwidth is limited, useful for calculating storage capacity
and the required bandwidth during installation
t Aspherical vari-focal lens. Eliminates spherical aberration
and minimises wide-angle distortion
t Power over ethernet. Allows remote transmission of power by
utilising installed ethernet cable, thus reducing the amount of
cable and associated costs on site
Dimensions
Image size (H x V) MPEG-4
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Image size (H x V) JPEG
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
MPEG-4 frame rate
25fps (320x240), 15fps (640 x 480)
JPEG frame rate
25fps (320x240), 18fps (640 x 480)
Audio
Audio compression
Protocols
Number of clients
TCP/IP, HTTP, ARP, ICMP, FTP, SMTP, DHCP, SNMP(MIB2), DNS,
NTP, RTP/RTCP, PPPoE
10 (MPEG4), 20 (JPEG)
Interface
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
BNC x1, 1.0Vp-p, 75Ω
10Base-T/100Base-TX (RJ-45)
Sensor in x1, Alarm out x1
External microphone input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Audio line output: Mini-jack (monaural), max
output level: 1Vrms
Analogue video output
Video system
Horizontal resolution
Sensitivity colour
66.3mm
57mm
S/N ratio
NTSC/PAL
400 TV lines
More than 48dB
1.7lx (50IRE, F1.0, AGC ON)
General
TO DRAW
Zoom ratio
Weight
Dimensions (W x H x D)
70mm
G.711 (64kbps)/ G.726 (40, 32, 24, 16kbps)
Network
116mm
5.9mm
Power requirements
Power consumption
x2.7 optical zoom
Approx. 525 g
70 x 57 x 116mm
AC 24V/DC 12V/PoE
5.7W max.
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo, 2GHz or
higher. RAM: 1GB or more. Microsoft Internet Explorer Ver. 5.5
or 6.0 or 7.0
Supplied Accessories
CS-Mount Vari Focal Lens (SNC-CS11 only), Screw, Wire Rope,
CD-Rom (User's Guide, IP Setup Program, SNC Audio Upload
Tool, SNC Video Player, Customer Homepage Installer),
Installation Manual, Warranty Booklet, Warranty Sheet,
AC Cable.
26
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CS20
Compact and slim surveillance network camera providing
excellent sensitivity and high resolution with an advanced
progressive scan CCD based on ExwavePROTM technology.
Key Features and Benefits
Specifications
1/4-type Progressive Scan CCD with ExwavePROTM
technology. The SNC-CS20 camera inherits the technical
advantages of Sony ExwaveHAD™ technology, while
incorporating advanced progressive scanning and
complementary colour filters to provide extremely high
sensitivity levels and clear and crisp images in both day
and night environments
Camera
Image device
Number of total pixels
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
1 to 1/10,000s
Auto/Manual (0db to +36dB)
Auto, BLC, Gamma correction
ATW, ATW-PRO
Lens type
Vari-focal lens
Horizontal viewing angle
Day/night function. Ideal for mono switching in
night mode
Minimum object distance
Focal length
F-number
66° to 27°
f=3.0 to 8.0mm
F1.0 (wide), F1.45 (tele)
200mm
Image size (H x V) MPEG-4
Analogue Video Output. Ideal for use when adjusting
the camera viewing angle during installation
350,000
330,000 (659 x 494)
White balance modes
Dual encoding. Maximum flexibility when streaming
video data
Bi-directional audio function. Audio transmission available
in both directions
1/4 type VGA CCD with ExwavePRO technology
Image size (H x V) JPEG
640 x 480, 384 x 288, 320 x 240
768 x 576, 640 x 480, 384 x 288, 320 x 240
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (768 x 576)
Audio
Audio compression
G.711 /G. 726 (40, 32, 24, 16kbps)
Network
Protocols
Standard Features and Benefits
Number of clients
Authentication
t Compact and slim design inherited from CCTV cameras.
Fits 8-inch camera housings
t DC Servo IR Auto Iris Lens capability. Ideal for both indoor
and outdoor use
t Slow shutter mode. Ideal for low light conditions
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
t DEPA compatible. Powerful video analytic and motion
detection capability
Sensitivity colour
Horizontal resolution
S/N ratio
Sensitivity monochrome
Weight
Dimensions (W x H x D)
135mm
10Base-T/100Base-TX (RJ-45)
Sensor in 1 Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
PAL
400 TV lines
More than 50dB
0.15lx (50IRE, F1.3, ACG 36dB)
0.021lx (50IRE, F1.0, AGC ON 36dB)
General
Zoom ratio
41.2mm
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
Analogue video output
Video system
82.5mm
10
IEEE802.1X
Interface
t Sensor in/alarm. Camera will access alarm inputs and alarm
outputs via external equipment
Dimensions
TCP/IP, ARP, ICMP, HTTP, FTP(client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP
Power requirements
Power consumption
Operating temperature
63mm
62mm
Storage temperature
x2.7 optical zoom (x2 digital zoom)
Approx. 700g
82.5 x 63 x 176.2mm including lens
AC 24V, DC 12V, PoE
8W max.
-10 to 50°C
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo, 2GHz or
higher. RAM: 1GB or more
Supplied Accessories
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer, Easy Setup Guide), Installation Manual, Wire Rope
27
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CM120
Designed for security: the first-ever fixed Sony megapixel
network camera delivers excellent sensitivity and 1.3 megapixel
resolution with an advanced progressive scan CCD employing
ExwavePROTM technology.
Key Features and Benefits
Specifications
1/3-type Progressive Scan CCD with ExwavePROTM
technology. High sensitivity levels and clear, crisp images
in both day and night environments
Camera
Image device
Number of total pixels
Number of effective pixels (HxV)
Electronic shutter
1.3 Megapixel. High resolution images
Auto gain control (AGC)
Dual encoding. Maximum flexibility when streaming
video data
Light funnel function. Unique function enables usable
images at very low light
Exposure control
1,320,000
1,250,000 (1,296 x 966)
1 to 1/10,000s
On/Off (0dB to +36dB)
Auto, Backlight compensation, Gamma settings
White balance modes
Modes ATW, ATW Pro
Lens type
Vari-focal zoom lens
Lens mount
Horizontal viewing angle
Focal length
F-number
Solid PTZ. Electronic pan, tilt and zoom capability
1/3-type Progressive Scan CCD with ExwavePRO Technology
Minimum object distance
CS Mount
100.7 to 47°
f=2.8 to 6.0mm
F1.3 (wide), F1.9 (tele)
300mm
Day/night function. Ideal for mechanical mono switching
in night mode.
Image size (H x V) MPEG-4
Image size (H x V) JPEG
640 x 480, 384 x 288, 320 x 240
1280 x 960, 960 x 720, 768 x 576, 640 x 480, 384 x 288,
320 x 240
Analogue video output. Ideal for setting up of image
during installation
MPEG-4 frame rate
15fps (640 x 480 / Light Funnel OFF), 25fps (640 x 480 / Light
Funnel ON)
JPEG frame rate
15fps (1280 x 960 / Light Funnel OFF), 25fps (640 x 480 / Light
Funnel ON)
Bi-directional audio function. Allows remote transmission
of audio in both directions
Audio
Audio compression
G.711 (64kbps)/G.726 (40, 32, 24, 16kbps)
Network
Protocols
Number of clients
Standard Features and Benefits
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP, SMTP, DHCP, DNS, NTP,
RTP/RTCP, SNMP
10
IEEE802.1X
Interface
t High frame rate. Full frame rate available
Analogue connectivity
t Cropping function. Enables flexible viewing for
required images
t DEPA compatible. Can be used with advanced video
analytics and intelligent VMD
t Privacy masking. Ideal for masking sensitive areas of the
video image
t Power over ethernet. Allows remote transmission of power
by utilising installed ethernet cable, thus reducing the
amount of cable and associated costs on site
Ethernet connectivity
I/O port connectivity
Audio connectivity
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
Sensitivity monochrome
Zoom ratio
Power requirements
41.2mm
135mm
NTSC/PAL
600 TV lines
More than 50dB (AGC OFF, Weight ON)
0.15lx (50IRE, F1.3, ACG 36dB). 0.1lx (Light Funnel ON, 50IRE,
F1.3, AGC ON 36dB)
0.01lx (50IRE, F1.3, AGC ON 30dB). 0.01lx (Light Funnel ON,
50IRE, F1.3, AGC ON 36dB)
General
Dimensions (W x H x D)
82.5mm
Sensor in x 1, Alarm out x 2
External microphone input: Mini-jack x1 (Mic in: monaural,
2.2K 2.5VDC plug-in power, Line in: monaural) Line input
Analogue video output
Weight
Dimensions
BNC x1, 1.0Vp-p, 75Ω
10Base-T/100BASE-TX (RJ-45)
Power consumption
Operating temperature
Storage temperature
x2.1 optical zoom (x2 digital zoom)
700g (1lb 9oz)
82.5 x 63 x 187.5mm including Lens
PoE (IEEE-802.3 af) AC 24V/DC 12V
8.0W
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
63mm
62mm
System requirements
Operating system
System requirements
Windows Vista®, Microsoft Windows XP
Intel® Pentium® IV 3GHz or higher, Intel Core 2 Duo 2GHz or
higher. Memory 1GB or more
Supplied Accessories
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer, Easy Setup Guide), Installation Manual, Wire Rope
28
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CS50P
The Sony SNC-CS50P network camera – an easy to operate,
high-performance colour IP network camera that takes remote
monitoring to the next level.
Key Features and Benefits
1
TM
3 1/3-type SuperExwave CCD. High resolution images with
superior sensitivity
Specifications
Camera
Image device
Number of effective pixels (HxV)
Day/night function. Ideal for mechanical switching to
monochrome in night conditions
JPEG, MPEG-4 and H.264 streaming.
JPEG, MPEG-4, H.264 encoding allows maximum image
transmission flexibility
Bi-directional audio function. Audio may be transmitted
in both directions
Analogue video output. Ideal for setting up of image
during installation
Multiple alarm functions. Allows for intelligent motion
detection, pre alarm recording and triggering via
external devices
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
1/3-type SuperExwave CCD
440,000
1/50 to 1 /10,000s
Auto/Manual (-3 to +24dB)
Auto/ Manual/ EV Compensation/ Backlight Compensation
ATW, ATW Pro, One-push
Vari-focal Zoom Lens
Lens mount
CS Mount
Horizontal viewing angle
94° to 35°
Focal length
F-number
Minimum object distance
f=2.9 to 8.0mm
F0.95 (Wide) to Fl.6 (Tele)
300mm
Image size (H x V) MPEG-4
640 x 480 (VGA), 320 x 240 (QVGA), 160 x 120 (QQVGA),
704 x 576
Image size (H x V) JPEG
640 x 480 (VGA), 320 x 240 (QVGA), 160 x 120 (QQVGA),
704 x 576
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
Dual encoding. Maximum flexibility when streaming
video data
H.264 frame rate
16fps (640 x 480), 25fps (320 x 240)
Dynamic frame integration. Reduces motion blur in high
speed images
Network
Audio
Audio compression
Protocols
Number of clients
Authentication
Standard Features and Benefits
Analogue connectivity
I/O port connectivity
Audio connectivity
t Vari-focal lens. Allows flexible image viewing
t Accessory expansion slot. External image storage
accessories available
t Privacy masking. Ideal for masking sensitive areas
of the video image
TCP/IP, HTTP, ARP, ICMP, DHCP, FTP, DNS, NTP and
SNMP (MIB-2), RTP/RTCP, RTSP
20
IEEE802.1X
Interface
Ethernet connectivity
t Image stabiliser. Reduces image shake in unstable
camera mounting conditions
G.711 (64kbps)/ G.726 (40, 32, 24, 16kbps)
Analogue video output BNC x1, 1.0Vp-p, 75Ω
10Base-T/1 00Base-TX (RJ45)
Sensor in 2, Alarm out 2
External Microphone Input: Mini-Jack (monaural, 2.2K, 2.5V
plug-in power). Line Output: Mini-Jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
PAL
540 TV lines
50dB or more
Sensitivity colour
0.4lx (F0.95, 50IRE, AGC ON)
Sensitivity monochrome
0.04lx (F0.95, 50IRE, AGC ON)
General
Zoom ratio
Dimensions
Weight
Dimensions (W x H x D)
265mm
Power requirements
Power consumption
69mm
Operating temperature
Storage temperature
x2.7 optical zoom
750 g excl. cover equipment, 880g incl.
84 x 69 x 196mm excl. cover equipment, 84 x 69 x 265mm
incl. cover equipment
AC 24V, DC 12V. PoE
9W max. (AC 24V)
0 to 50°C (32 to 122°F)
-40 to 60°C (-40 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo, 2GHz or
higher. RAM: 1GB or more. Microsoft Internet Explorer Ver. 5.5
or 6.0 or 7.0
Supplied Accessories
CD-ROM (Setup Program and User's Guide), Wire Rope,
Shoulder Screw M4, Cable Cover, Front Cover, Lens Cable
Cover, Screw for Front Cover
29
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CH140
Delivering HD resolution images in all lighting conditions and
utilising state-of-the-art image enhancement with the View-DR
wide dynamic range and XDNR noise reduction technologies,
the SNC-CH140 from Sony represents the very latest in fixed, HD
network camera technology.
Key Features and Benefits
1
Specifications
3 Sony 1/3" Exmor HD CMOS image sensor with mechanical
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
View-DR enhanced wide Dynamic range technology.
DR
Superior performance in high contrast lighting conditions
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Advanced audio detection. Monitors and stores ambient
audio levels to deliver highly accurate audio alarm triggering
Day/night function. Ideal for mechanical switching to
monochrome in night conditions
Camera
Image device
Minimum illumination
Number of effective pixels (HxV)
1s to 1/10,000s
Auto gain control (AGC)
Max gain setting LOW, MID, HIGH
Exposure control
White balance modes
Lens type
Approx. 2.9X
33.9 to 96.5°
Focal length
f=2.8 to 8.0mm
F-number
F1.2 (wide), F1.9 (tele)
Easy Focus
Yes
Easy Zoom
No
Camera Features
Day/Night*3
Wide-D
Yes
View-DR*4 (125 dB)
Image enhancement
Visibility Enhancer
Analogue video output. Ideal for setting up of image
during installation
Codec image size (H x V)
Video compression format
Maximum frame rate
XDNR
1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x
768, 1024 x 576, 800 x 480, 768 x 576, 640 x 480, 640 x 368,
384 x 288, 320 x 240, 320 x 192
H.264, MPEG-4, JPEG
H.264/MPEG-4/JPEG: 30 fps (1280 x 720)
Audio
Audio compression
G.711/G.726
Scene analytics
Intelligent motion detection
Intelligent object detection
Yes (with built-in Post Filter)
No
Advanced audio detection
Yes*5
Network
Protocols
ONVIF conformance
Wireless network
Number of clients
Standard Features and Benefits
CS Mount lens
Horizontal viewing angle
HD video at 30 fps. Superior High Definition image quality
with real time capture
Auto, EV Compensation*1, Auto Slow Shutter*2
Auto (ATW, ATW-Pro), Preset, One-push WB, Manual
Zoom ratio
Dual encoding. Maximum flexibility when streaming video data
JPEG, MPEG-4 and H.264 streaming. JPEG, MPEG-4, H.264
encoding allows maximum image transmission flexibility
Approx. 1.4 Megapixel
Electronic shutter speed
Noise reduction
Bi-directional audio function. Audio may be transmitted in
both directions
1/3 type progressive scan CMOS
Day : 0.20 lx, Night : 0.10 lx (F1.2/View-DR OFF/XDNR ON-Middle/
VE OFF/AGC High/50 IRE[IP])
Authentication
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server),
SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
Yes
Yes (with optional*6)
10
IEEE802.1X
Interface
t Triple codec support. Delivers flexible image compression
formats to overcome bandwidth limitations
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
t Onvif support. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Ethernet connectivity
Serial interface
Card slots
Analogue video output
x1
Alarm output
x2
External microphone input
Audio line output
Mini-jack (monaural), MIC IN/LINE IN: 2.47VDC plug-in power
Mini-jack (monaural), Max output level: 1 Vrms
Analogue video output
Signal system
Horizontal resolution
NTSC/PAL
600 TV lines
more than 50 dB
General
52 (2 1/8)
72 (2 7/8)
145 (5 3/4)
140 (5 5/8)
Mass
Dimensions (W x H x D)
Power requirements
63 (2 1/2)
Power consumption
62 (2 1/2)
CF card x1
Composite video (1Vp-p)
Sensor input
S/N ratio
Dimensions
10BASE-T / 100BASE-TX (RJ-45)
No
Operating temperature
Storage temperature
Approx. 600 g (1 lb 2 oz)
72 x 63 x 197 mm
PoE, AC24V, DC12V
9.0 W max.
-10 to +50 °C*7 (-14 to 122 °F)
-20 to +60 °C (-4 to 140 °F)
System requirements
152 (6)
Operating system
Processor
Memory
Web browser
Windows Vista®, Microsoft Windows XP
Intel Core2 Duo 2GHz or higher
1GB or more
Microsoft Internet Explorer Ver6.0, Ver7.0
Supplied Accessories
CD-ROM (User’s guides, SNC Toolbox), Installation manual,
Wire rope, Warranty booklet
30
*1 Visibility Enhancer off mode only *2 View-DR off mode only *3 Removable IR Cut Filter
*4 View-DR technology is a combination of Sony’s full-capture Wide-D technology, the high-speed “Exmor”
CMOS sensor, and Visibility Enhancer. *5 Available with software version 1.1 or later *6 With optional SNCACFW5 *7 Cold start temperature must be greater than 0°C.
VIDEO SECURITY
IP FIXED OUTDOOR CAMERAS
SNC-CH180
IP66-rated Network HD Bullet Camera with wide dynamic range
with built-in infrared (IR) illuminators. This camera delivers quality
images even in absolute darkness (0 lx), so is ideal for most
demanding surveillance applications.
Key Features and Benefits
IR
1
3
DR
Specifications (continued)
IR Illuminator. Clearly captures objects in the dark up to
15m (49 feet) away with IR illuminators, which allows the
camera to operate in 0 lux lighting conditions
Camera (continued)
Sony 1/3” Exmor HD CMOS image sensor with mechanical
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
View-DR enhanced wide Dynamic range technology.
Superior performance in high contrast lighting conditions
Minimum object distance
Powered Focus
Powered Zoom
IR illuminators
300 mm
Yes (Easy Focus)
Yes (Easy Zoom)
Yes (Wave Length: 850nm [Typical], IR LED: 27pcs)
Camera Features
Day/Night *3
Wide-D
Image enhancement
Noise reduction
Yes
View-DR (125dB: Theoretical)
Visibility Enhancer
XDNR
Codec image size (H x V)
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Video compression format
Codec streaming capability
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Maximum frame rate
Easy zoom function. Adjusts the focus relative to the zoom ratio
Audio
Audio compression
Scene Analytics
Intelligent motion detection
Intelligent object detection
Rule filter
Standard Features and Benefits
1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x 768,
1024 x 576, 800 x 480, 768 x 576, 720 x 576, 720 x 480, 704
x 576, 640 x 480, 640 x 368, 384 x 288, 320 x 240, 320 x 192
(H.264, MPEG-4, JPEG)
H.264, MPEG-4, JPEG
Dual streaming
H.264: 20fps (1280 x 1024) / 30 fps (1280 x 720)
MPEG-4: 25fps (1280 x 1024) / 30 fps (1280 x 720)
JPEG: 30fps (1280 x 1024) / 30 fps (1280 x 720)
G.711/G.726
Yes (with built-in Post Filter)
No
Yes
Network
t Triple codec support. Delivers flexible image compression
formats to overcome bandwidth limitations
Protocols
Number of clients
ONVIF conformance
Wireless network
Authentication
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server),
SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
10
Yes
Yes (with Option *4)
IEEE802.1X
Interface
t ONVIF support. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Ethernet
Serial interface
Card slots
Analogue video output
Sensor input
Alarm output
External microphone input
Audio line output
t IP66 Rated. Maximum environmental protection for heavy
duty outdoor monitoring applications
Dimensions
10BASE-T / 100BASE-TX (RJ-45)
No
CF card x1
BNC x 1, RCA x 1
x1
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
Analogue video output
R100
306 (12 1/8)
304 (12)
(4)
4)
ø8
ø140 (5 5/8)
5(
33
(3
90 (3 5/8)
93 (3 3/4)
/8)
3
ø9
186 (7 3/8)
334.8 (13 1/4)
3/
Signal system
Horizontal resolution
S/N ratio
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Starting temperature
Specifications
Storage temperature
Ingress protection
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Horizontal viewing angle
Focal length
F-number
Optical 2.9X (x2 Digital Zoom)
1600 g (3 lb 8 oz)
85 x 90 x 186 mm (3 3/8 x 3 5/8 x 7 3/8 inches)
140 x 140 x 334.8 mm (5 5/8 x 5 5/8 x 13 1/4 inches) (including arm)
PoE *5, AC24V, DC12V
TBD
AC24V/DC12V: -30 to +50 °C (-22 to +122°F) (Tentative)
PoE (IEEE802.3af): -10 to +50 °C (23 to 122°F) (Tentative)
AC24V/DC12V: -20 to +50 °C (-4 to +122°F) (Tentative)
PoE (IEEE802.3af): 0 to 50 °C (32 to 122°F) (Tentative)
-20 to +60 °C (-4 to +140°F)
IP66
System requirements
Camera
Image device
Minimum illumination
NTSC / PAL
600 TV lines
More than 50dB
1s to 1/10000s
Operating system
Processor
Memory
Web browser
Auto (3 levels)
Supplied Accessories
1/3 type progressive scan “Exmor” CMOS sensor
TBD
1.4 Megapixel (1329 x 1049)
Auto, EV Compensation *1, Auto Slow Shutter *2
Auto (ATW, ATW-PRO), Preset, One-push WB, Manual
Vari-focal lens
85.4 to 31.2 degrees
f=3.1 to 8.9mm
Windows XP, Windows Vista, Windows 7
Intel Core2 Duo 2 GHz or higher
1 GB or more
Microsoft Internet Explorer Ver6.0, 7.0, or 8.0
CD-ROM (User’s Guide, SNC Toolbox), Installation manual,
Wire rope, M4 screw, B&P Warranty Booklet, Template
*1 VE off mode only. *2 View-DR off mode only. *3 Removable IR Cut Filter. *4 With optional
SNCA-CFW5. *5 When used with PoE, SNC-CH180 cannot be used with a heater and a CF card
slot. The SNC-CH180 includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/).
F1.2 (Wide), F2.1 (Tele)
31
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CH240
Full-HD Network Camera delivering excellent picture quality
in 1080p HD resolution at 30 frames per second. Utilising
state-of-the-art image enhancement with View-DR, XDNR
and the “Exmor” CMOS sensor.
Key Features and Benefits
1
Specifications (continued)
3 Sony 1/3” Exmor HD CMOS image sensor with mechanical
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
Camera (continued)
Horizontal viewing angle
Focal length
101.2 to 47.0 degrees
f=2.8 to 6.0 mm
F-number
F1.3 (Wide), F1.9 (Tele)
Minimum object distance
DR
View-DR enhanced wide Dynamic range technology.
Superior performance in high contrast lighting conditions
300 mm
Powered Focus
Yes (Easy Focus)
Powered Zoom
No
Camera Features
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Day/Night *3
Wide-D
Yes
View-DR (84dB: Theoretical) (Tentative)
Image enhancement
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Visibility Enhancer
Noise reduction
XDNR
Codec image size (H x V)
1920 x 1440, 1600 x 1200, 1680 x 1056, 1920 x 1080, 1440 x
912, 1376 x 768, 1280 x 960, 1280 x 800, 1280 x 720, 1280 x
1024, 1024 x 768, 1024 x 576, 800 x 480, 768 x 576, 720 x 576,
704 x 576, 720 x 480, 640 x 480, 640x 368, 384 x 288, 320 x
240, 320 x 192 (H.264, MPEG-4, JPEG)
Video compression format
H.264, MPEG-4, JPEG
Easy zoom function. Adjusts the focus relative to the
zoom ratio
Codec streaming capability
Maximum frame rate
Standard Features and Benefits
Dual streaming
H264: 20fps (1920 x 1440) / 30fps (1920 x 1080)
MPEG-4: 15fps (1920 x 1440) / 25 fps (1920 x 1080)
JPEG: 10fps (1920 x 1440) / 15fps (1920 x 1080)
Audio
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
t ONVIF support. Maximum interoperability and flexibility with a
wide range of manufacturers’ network video products
Audio compression
Yes (with built-in Post Filter)
No
Intelligent motion detection
Intelligent object detection
Rule filter
Yes
Network
Protocols
Number of clients
Dimensions
G.711/G.726
Scene Analytics
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/
server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
10
ONVIF conformance
Yes
Yes (with option *4)
Wireless network
72 (2 7/8)
145 (7 7/8)
Authentication
IEEE802.1X
Interface
63 (2 1/2)
Ethernet
Serial interface
10BASE-T / 100BASE-TX (RJ-45)
No
Card slots
CF card x1
Analogue video output
(Tentative)
BNC x 1
Sensor input
x1
Alarm output
x2
External microphone input
Audio line output
Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
Specifications
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Zoom ratio
Weight
1/2.8 type progressive scan “Exmor” CMOS sensor
TBD
3 Megapixel (2096 × 1561) (Tentative)
1s to 1/10000s
Auto (3 levels)
Auto, EV Compensation *1, Auto Slow Shutter *2
Auto (ATW, ATW-PRO), Preset, One-push WB, Manual
CS mount lens
Dimensions (W x H x D)
Optical 2.1X (x2 Digital Zoom)
650g (1 lb 7 oz) (Tentative)
72 x 63 x 145 mm (2 7/8 x 2 1/2 x 7 7/8 inches) (Tentative)
Power requirements
PoE, AC24V, DC12V
Power consumption
Operating temperature *5
TBD
-10 to +50 °C (14 to 122 °F) (Tentative)
Storage temperature
Vandal resistant standard
-20 to +60 °C (-4 to +140 °F)
No
Yes
System requirements
Operating system
Processor
Memory
Web browser
32
More than 50 dB
General
Camera
Image device
Minimum illumination
NTSC / PAL
TBD
Windows XP, Windows Vista, Windows 7
Intel Core2 Duo 2GHz or higher
1GB or more
Microsoft Internet Explorer Ver6.0, 7.0, or 8.0
VIDEO SECURITY
IP FIXED CAMERAS
SNC-CH210
The unique compact affordable SNC-CH210 Network HD
Camera supporting H.264, MPEG-4 and JPEG compression
formats, delivers excellent and detailed pictures in HD resolution.
Key Features and Benefits
Specifications
Innovative Design. Compact, slim and two body colours
(Silver and Black); suitable for many applications where the
bulky camera would be avoided
“Stream Squared” function. Allows simultaneous streaming
of two 4:3 aspect ratio videos in user selectable SD
resolutions. You can select the entire image or a portion
of the image from the original field of view and resize to
SD resolution or lower for each stream
Camera
Image device
Minimum illumination
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Horizontal viewing angle
Focal length
1/2.8 type progressive scan “Exmor” CMOS sensor
TBD
3 Megapixel (2096 x 1561)
1s to 1/10000s
Auto
Auto Slow Shutter
Auto, Preset, One-push WB, Manual
Fixed
Approx. 90 degree (TBD)
f=3.3 mm
F-number
F2.8
Minimum object distance
TBD
Camera Features
Day/Night
Yes (electrical D/N)
Standard Features and Benefits
t Triple codec support. Delivers flexible image compression
formats to overcome bandwidth limitations
t ONVIF support. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Codec image size (H x V)
2048x1536 (JPEG Only), 1920x1080, 1600x1200, 1680x1050,
1440x900, 1280x1024, 1280x960, 1366x768, 1280x800,
1280x720, 1024x768, 1024x576, 768x576, 720x576, 704x576,
800x480, 720x480, 640x480, 640x360, 384x288, 320x240,
320x180 (H.264, MPEG-4, JPEG)
Video compression format
H.264, MPEG-4, JPEG
Codec streaming capability
Maximum frame rate
Dual streaming
H.264: 12fps (1920×1080) (TBD) / 30 fps (1280 x 720)
MPEG-4: 15fps (1920×1080) (TBD) / 30 fps (1280 x 720)
JPEG: 7fps (2048×1536) (TBD) / 30 fps (1280 x 720)
Scene Analytics
Motion detection
Tamper alarm
Dimensions
Yes (TBD)
Yes (TBD)
Network
Protocols
ONVIF conformance
Number of clients
Authentication
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/
server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
Yes
5 (TBD)
IEEE802.1X
Interface
Ethernet
Serial interface
Card slots
Analogue video output
Sensor input
10BASE-T / 100BASE-TX (RJ-45)
No
No
Mini Jack
x1
Analogue video output
Signal system
Horizontal resolution
S/N ratio
NTSC / PAL
TBD
TBD
General
93 (3 3/4)
Weight
Dimensions (ø x H )
TBD
44 x 93 mm (1 3/4 x 3 3/4 inches)
Power requirements
PoE
Power consumption
Operating temperature
Storage temperature
TBD
0 to 50 °C (32 to 122°F)
-20 to +60 °C (-4 to +140 °F)
ø44 (1 3/4)
System Requirements
Operating system Windows XP, Windows Vista, Windows 7
Processor Intel Core2 Duo 2 GHz or higher
Memory 1 GB or more
Web browser Microsoft Internet Explorer Ver6.0, 7.0, or 8.0
The SNC-CH210 includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/).
33
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DS10
New network mini-dome cameras with ExwavePROTM
technology – for clear, detailed, and amazingly sharp images.
Key Features and Benefits
Specifications
1/4-type Progressive Scan CCD with ExwavePROTM
technology. High resolution images with superior sensitivity
Camera
Image device
Number of total pixels
Dual encoding. Maximum flexibility when streaming
video data
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Voice preset can store
pre-recorded warning messages
Analogue video output. Ideal for assisting in image
set-up during installation
Exposure control
1/4-type Progressive Scan CCD with ExwavePRO Technology
Approx. 350,000
Approx. 330,000 (659 x 494)
1 to 1/10,000s
Auto/Manual (0dB to +36dB)
Auto, Backlight compensation, Gamma settings
White balance modes
ATW, ATW Pro
Lens type
Vari-focal lens
Lens mount
Horizontal viewing angle
Focal length
F-number
Minimum object distance
Ball-Joint Lens Mount
73° to 20°
f=2.8 to 10.0mm
F 1.3 (wide), F 3.0 (tele)
300mm
Image size (H x V) MPEG-4
Image size (H x V) JPEG
Standard Features and Benefits
640 x 480, 384 x 288, 320 x 240
768 x 576, 640 x 480, 384 x 288, 320 x 240
MPEG-4 frame rate
30fps (640 x 480)
JPEG frame rate
30fps (768 x 576)
t Quick focus function. Ideal for quick set up of image focus
during installation
Audio
t Privacy masking. Ideal for masking sensitive areas of
the video image
Protocols
t Flexible mounting options. May be mounted in ceiling
or wall applications
Authentication
t DEPA compatible. Allows access to powerful video analytics
and intelligent motion detection and alarm functions
Ethernet connectivity
Audio compression
G.711 /G.726 (40, 32, 24, 16kbps)
Network
Number of clients
TCP/IP, HTTP, ARP, ICMP, FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, UDP, RTSP
10
IEEE802.1X
Interface
Analogue connectivity
I/O port connectivity
Audio connectivity
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5VDC
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Dimensions
Video system
Horizontal resolution
S/N ratio
85.7m m
Sensitivity colour
Zoom ratio
85.7m m
83.5m m
118m m
Weight
R4
3.5
mm
More than 50dB
0.15lx (50IRE, F1.3 AGC 36dB)
General
83.5m m
ø140m m
PAL
400TVL
x3.6 optical zoom
Approx. 780g
Dimensions (W x H x D)
Approx. 140 x 118mm
Power requirements
AC 24V, DC 12V, PoE
Power consumption
7.5W max
Operating temperature
-0 to 50°C (32 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 2.4GHz or higher, Intel Core2 Duo, 1.8GHz
or higher. RAM: 1GB or more
Supplied Accessories
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer), Installation Manual, Bracket, Template, M4 screws
(2), Wire Rope, M4 Shoulder Screw, Audio Cable, I/O Cable,
LAN Cable, BNC Cable
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
(http://www.openssl.org) This product includes cryptographic software written by Eric Young
(eay@crytposoft.com)
34
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DM110
New network mini-dome cameras with ExwavePROTM
technology and resolution up to 1.3 megapixels for clear, detailed, and amazingly bright surveillance
monitoring images.
Key Features and Benefits
Specifications
Progressive Scan CCD With ExwavePROTM technology.
High sensitivity for crisp clear images
Camera
Image device
Number of total pixels
Megapixel. High quality 1.3 megapixel image
Number of effective pixels (HxV)
Light Funnel Function. Unique function offers usable images
in extremely low light
Electronic shutter
Dual encoding. Maximum flexibility when streaming
video data
Auto gain control (AGC)
Exposure control
1/3-type Progressive Scan CCD with ExwavePRO Technology
Approx. 1,320,000
Approx. 1,250,000 (1296 x 966) Approx. 330,000
(659 x 494)
1 to 1/10,000 s
On/Off (0dB to +36dB)
Auto, Backlight compensation, Gamma settings
White balance modes
ATW, ATW Pro
Lens type
Vari-focal lens
Analogue video output. Ideal for assisting set-up during
installation
Lens mount
Solid PTZ. Electronic pan, tilt, zoom facility with flexible
image cropping function may be linked to intelligent VMD
F-number
Intelligent Motion Detection. Highly flexible VMD may
be linked to DEPA enabled s/w
Image size (H x V) MPEG-4
Horizontal viewing angle
Focal length
Minimum object distance
Ball-Joint Lens Mount
100.3° to 29°
f=2.8 to 9.5mm
F1.3 (wide), F2.9 (tele)
300mm
Image size (H x V) JPEG
MPEG-4 frame rate
JPEG frame rate
640 x 480, 384 x 288, 320 x 240
1280 x 960, 960 x 720, 768 x 576, 640 x 480, 384 x 288,
320 x 240
25fps (640 x 480)
25fps (640 x 480), 15fps (1280 x 960, 768 x 576)
Audio
Standard Features and Benefits
Audio compression
G.711 (64kbps)/G.726 (40, 32, 24, 16kbps)
Network
t Quick focus function. Ideal for high speed focus of camera
image during installation
Protocols
Number of clients
Authentication
t Flexible mounting options. Can be ceiling or wall mounted
t Privacy zone masking. Flexible privacy masking of images
TCP/IP, HTTP, ARP, ICMP, FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, UDP, RTSP
10
IEEE802.1X
Interface
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
Dimensions
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
85.7m m
Horizontal resolution
83.5m m
ø140m m
S/N ratio
Sensitivity colour
PAL
600 TV lines
More than 50dB
0.15lx (50IRE, F1.3, ACG 36dB)
85.7m m
R4
3.5
mm
83.5m m
118m m
General
Zoom ratio
Weight
x3.4 optical zoom (x2 digital zoom)
Approx. 780g
Dimensions (W x H x D)
Approx. 140 x 118mm
Power requirements
AC 24V, DC 12V, PoE
Power consumption
Operating temperature
Storage temperature
8W max.
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 3GHz or higher, Intel Core2 Duo,
2GHz or higher. RAM: 1GB or more
Supplied Accessories
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer), Installation Manual, Bracket, Template, M4 Screws
(4), Wire Rope, M4 Shoulder Screw, Audio Cable, I/O Cable,
LAN Cable, BNC Cable
35
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DF50P
Reproducing extremely clear and detailed images –
Sony Professional’s intelligent mini-dome cameras provide
a high level of security, anytime and anywhere.
Key Features and Benefits
1
Specifications
3 1/3-type CCD. Clear high performance images
TM
DynaView
technology. High quality images even
in high contrast scenes
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
1/3-type CCD with DynaView Technology
440,000 (752 x 582)
1/50 to 1 /10,000s
Dynamic frame integration. Reduces motion blur in high
speed images
Auto gain control (AGC)
White balance modes
ATW, ATVV Pro
JPEG, MPEG-4 and H.264 streaming. Maximum flexibility
in image data streaming
Lens type
Vari-focal lens
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Pre-recorded audio
messaging also available
Focal length
In-built pre and post alarm image storage.
On-board storage of alarm image video
Image size (H x V) MPEG-4
704 x 576, 320 x 240, 160 x 120
Image size (H x V) JPEG
704 x 576, 320 x 240, 160 x 120
Image size (H x V) H.264
704 x 576, 320 x 240, 160 x 120
Standard Features and Benefits
Exposure control
Lens mount
Horizontal viewing angle
F-number
Minimum object distance
Auto, EV compensation, DynaView
Auto, Back- Light -Compensation (BLC)
Ball-Joint Lens Mount
100.8° to 27.7°
f=2.8 to 10.0mm
F 1.3 (wide), F 3.0 (tele)
300mm
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
H.264 frame rate
16fps (640 x 480), 25fps (320 x 240)
Audio
Audio compression
t Privacy masking. Ideal for masking sensitive areas of the
video image
Protocols
Number of clients
Authentication
Dimensions
G.711 (64kbps)/G.726 (40, 32, 24, 16kbps)
Network
TCP/IP, HTTP, ARP, ICMP, FFP, SMTP, DHCP, SNMP, DNS, NTP,
RTP/RTCP, RTSP
20
IEEE802.1X
Interface
Analogue connectivity
ø5m m hole x 2
Ethernet connectivity
I/O port connectivity
140m m
Audio connectivity
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
Horizontal resolution
ø126m m
BNC x l, 1.0Vp-p, 75Ω, RCA x 1
83.5m m
S/N ratio
Sensitivity colour
PAL
480 TV lines
More than 50dB
0.7lx (50 IRE, F1.3, AGC ON)
General
Zoom ratio
Weight
x3.6 optical zoom
Approx. 920g
Dimensions (W x H x D)
Approx. 126 x 140mm
Power requirements
AC 24V, DC 12V. PoE
Power consumption
9W max
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more
Supplied Accessories
Template, Wire Rope, M4 Shoulder Screw, AC Power Cord,
Monitor Cable, CD-ROM (User's Guide, IP Setup Program,
Audio Upload Tool, Privacy Masking Tool, Video Player,
Custom Homepage Installer), Installation Manual
36
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DS60
New network mini-dome camera with ExwavePROTM
technology for clear, detailed, and amazingly bright
surveillance monitoring images.
Key Features and Benefits
Specifications
1/4-type progressive scan CCD with ExwavePROTM
technology. High resolution images with superior sensitivity
Camera
Image device
Number of total pixels
Day/night function. Ideal for mechanical switching to
monochrome in night conditions
Solid PTZ. Electronic pan, tilt and zoom function allows
accurate image tracking and acquisition
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
1/4-type Progressive Scan CCD with ExwavePRO Technology
350,000
Approx. 330,000 (659 x 494)
1 to 1/10,000s
Auto/Manual (0dB to +36dB)
Auto, Backlight compensation, Gamma settings
White balance modes
ATW, ATW Pro
Dual encoding. Maximum flexibility when streaming
video data
Lens type
Vari-focal lens
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Voice preset can store
pre-recorded warning messages
F-number
Horizontal viewing angle
Focal length
Minimum object distance
73° to 20°
f=2.8 to 10.0mm
F 1.3 (wide), F 3.0 (tele)
300mm
Image size (H x V) MPEG-4
Image size (H x V) JPEG
Analogue video output. Ideal for assisting in image
set-up during installation
640 x 480, 384 x 288, 320 x 240
768 x 576, 640 x 480, 384 x 288, 320 x 240
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (768 x 576)
Audio
Audio compression
G.711 (64kbps)/G.726 (40, 32, 24, 16kbps)
Network
Protocols
Standard Features and Benefits
Number of clients
t Quick focus function. Ideal for quick set up of image focus
during installation
t DEPA compatible. Allows access to powerful video analytics
and intelligent motion detection and alarm functions
t Privacy masking. Ideal for masking sensitive areas of
the video image
Authentication
TCP/IP, HTTP, ARP, ICMP. FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, RTSP
10
IEEE802.1X
Interface
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
t Ruggedised design with flexible mounting options.
Ideal for outdoor use, may be mounted in ceiling or
wall applications
Horizontal resolution
S/N ratio
PAL
400 TV lines
More than 50dB
Sensitivity colour
0.15lx (50IRE, F1.3, ACG 36dB)
Sensitivity monochrome
0.05lx (50IRE, F1.3, AGC 36dB)
General
Zoom ratio
Dimensions
Weight
85.7m m
ø166m m
Approx. 1.4kg
Dimensions (W x H x D)
Approx. 166 x 119mm
Power requirements
AC 24V, DC 12V, PoE
Power consumption
83.5 m m
x3.6 optical zoom (x2 digital zoom)
15W max.
Operating temperature
-30 to 50°C (-22 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
85.7m m
46 m m
72.5m m
119m m
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
Intel® Pentium® IV 2.4GHz or higher, Intel Core2 Duo, 1.8GHz
or higher. RAM: 1GB or more
Supplied Accessories
5m
4.
R4
m
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer), Installation Manual, Bracket, Template, Torx Wrench,
M4 Screws (4), Wire Rope, M4 Shoulder Screw, Audio Cable,
I/O Cable, LAN Cable
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
(http://www.openssl.org)
This product includes cryptographic software written by Eric Young (eay@crytposoft.com)
37
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DM160
New network mini-dome cameras with ExwavePROTM technology
and resolution up to 1.3 megapixels - for clear, detailed, and
amazingly bright surveillance monitoring images.
Key Features and Benefits
Specifications
Progressive Scan CCD With ExwavePROTM technology.
High sensitivity for crisp clear images
Camera
Image device
Number of total pixels
Megapixel. High quality 1.3 megapixel image
Number of effective pixels (HxV)
1/3-type Progressive Scan CCD with ExwavePRO Technology
Approx. 1,320,000
1,250,000 (1296 x 966)
Light Funnel Function. Unique function offers usable images
in extremely low light
Electronic shutter
Dual encoding. Maximum flexibility when streaming
video data
White balance modes
ATW, ATW Pro
Lens type
Vari-focal lens
Analogue video output. Ideal for assisting set up
during installation
Horizontal viewing angle
Auto gain control (AGC)
Exposure control
Lens mount
Focal length
F-number
Solid PTZ. Electronic pan, tilt, zoom facility with flexible
image cropping function may be linked to intelligent VMD
Minimum object distance
Auto, Back-Light-Compensation (BLC), Gamma settings
Ball-Joint Lens Mount
100.8° to 27.7°
f=2.8 to 10.0mm
F1.3 (wide), F3.0 (tele)
300mm
Image size (H x V) MPEG-4
Intelligent Motion Detection. Highly flexible VMD may be
linked to DEPA™ enabled s/w
1 to 1/10,000s
Auto/Manual (0dB to +36dB)
Image size (H x V) JPEG
MPEG-4 frame rate
JPEG frame rate
640 x 480, 384 x 288, 320 x 240
1280 x 960, 960 x 720, 768 x 576, 640 x 480, 384 x 288,
320 x 240
25fps (640 x 480)
25fps (640 x 480), 15fps (1280 x 960, 768 x 576)
Audio
Audio compression
Standard Features and Benefits
Protocols
t Quick focus function. Ideal for high speed focus of camera
image during installation
t Ruggedised with flexible mounting options. Ideal for use in
outdoor conditions. Can be ceiling or wall mounted
t Privacy zone masking. Flexible privacy masking of images
t Power over ethernet. Allows remote transmission of power by
utilising installed ethernet cable, thus reducing the amount of
cable and associated costs on site
Number of clients
Authentication
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
85.7m m
BNC x 1, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5VDC
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Video system
PAL
600 TV lines
More than 50dB
Sensitivity colour
0.40 lx at F1.3 (50 IRE, AGC ON 30 db)
Sensitivity monochrome
0.08 lx at F1.3 (50 IRE, AGC ON 30db)
General
Zoom ratio
83.5 m m
Weight
ø166m m
Dimensions (W x H x D)
46 m m
85.7m m
Power requirements
72.5m m
10
IEEE802.1X
Analogue video output
S/N ratio
Dimensions
TCP/IP, HTTP, ARP, ICMP, FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, UDP, RTSP
Interface
Horizontal resolution
119m m
G.711 (64kbps)/ G.726 (40,32,24,16kbps)
Network
Power consumption
x3.6 optical zoom (x2 digital zoom)
Approx. 1.4kg
Approx. 166 x 119mm
PoE/AC 24V/DC 12V
15W max.
Operating temperature
-30 to 50°C (-22 to 122°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
5m
4.
R4
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
m
CPU: Intel® Pentium® IV 1.5GHz or higher.
RAM: 256MB or more
Supplied Accessories
CD-ROM (User's Guide, IP Setup Program, Audio Upload Tool,
Privacy Masking Tool, Video Player, Custom Homepage
Installer), Installation Manual, Bracket, Template, Torx Wrench,
M4 Screws (4), Wire Rope, M4 Shoulder Screw, Audio Cable,
I/O Cable, LAN Cable
38
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DF80P
Reproducing extremely clear and detailed images –
Sony Professional’s intelligent mini-dome cameras provide
a high level of security, anytime and anywhere.
Key Features and Benefits
1
TM
3 1/3-type SuperExwave CCD. Clear high performance
images
Specifications
Camera
Image device
Number of effective pixels (HxV)
Dynamic frame integration. Reduces motion blur in high
speed images
JPEG, MPEG-4 and H.264 streaming. Maximum flexibility
in image data streaming
Electronic shutter
Auto gain control (AGC)
Exposure control
1/3-type SuperExwave CCD
440,000 (752 x 582)
1 /50 to 1 /10,000s
On/Off (0dB to +24dB)
Auto, Back- Light-Compensation (BLC)
White balance modes
ATW, ATW Pro
Lens type
Vari-focal lens
Day/night function. Ideal for switching to monochrome
under night conditions
Lens mount
In-built pre and post alarm image storage. On-board
storage of alarm image video
F-number
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Pre-recorded audio
messaging also available
Image size (H x V) MPEG-4
704 x 576, 320 x 240, 160 x 120
Image size (H x V) JPEG
704 x 576, 320 x 240, 160 x 120
Image size (H x V) H.264
704 x 576, 320 x 240, 160 x 120
Standard Features and Benefits
Horizontal viewing angle
Focal length
Minimum object distance
Ball-Joint Lens Mount
100.8° to 27.7°
f=2.8 to 10.0mm
F1.3 (wide), F3.0 (tele)
300mm
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
H.264 frame rate
16fps (640 x 480), 25fps (320 x 240)
Audio
Audio compression
G.711 (64kbps) /G. 726 (40, 32, 24, 16kbps)
Network
t Ruggedised design. Ideal for hostile outdoor conditions
Protocols
t PC card expansion slot. Wide range of accessories available
Number of clients
Authentication
TCP/IP, HTTP, ARP, ICMP. FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, RTSP
20
IEEE802.1X
Interface
Analogue connectivity
Dimensions
Ethernet connectivity
I/O port connectivity
ø177.5m m
Audio connectivity
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5VDC
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
141m m
Analogue video output
Video system
Horizontal resolution
S/N ratio
Conduit hole 19mm
PAL
540 TV lines
More than 50dB
Sensitivity colour
0.6lx (50IRE, F1.3, AGC ON)
Sensitivity monochrome
0.06lx (50IRE, F1.3, AGC ON)
General
Zoom ratio
Weight
x3.6 optical zoom
Approx. 1.8kg
Dimensions (W x H x D)
Approx. 177 x 141mm
Power requirements
AC 24V, DC 12V, PoE
Power consumption
Operating temperature
Storage temperature
10W max.
-10 to 50°C (14 to 122°F)/-40 to 50°C (-40 to 122°F)
with optional heater unit
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
Bracket, Template, Torx Wrench, M4 Screws (4), Wire Rope,
M4 Shoulder Screw, Audio Cable, I/0 Cable, CD-ROM
(User's Guide, IP Setup Program, Audio Upload Tool, Privacy
Masking Tool, Video Player, Custom Homepage Installer),
Installation Manual
39
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DF85P
Reproducing extremely clear and detailed images –
Sony Professional’s intelligent mini-dome cameras provide
a high level of security, anytime and anywhere.
Key Features and Benefits
1
3 1/3-type CCD. Clear high performance images
TM
DynaView
technology. Excellent images even in
high contrast scenes
Specifications
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
1/3-type CCD SuperExwave Technology
440,000 (752 x 582)
1 /50 to 1 /10,000s
Dynamic frame integration. Reduces motion blur in high
speed images
Auto gain control (AGC)
White balance modes
ATW, ATW Pro
JPEG, MPEG-4 and H.264 streaming. Maximum flexibility
in image data streaming
Lens type
Vari-focal lens
Day/night function. Ideal for switching to monochrome
under night conditions
F-number
Exposure control
Horizontal viewing angle
Focal length
Minimum object distance
On/Off (0dB to +24dB)
Auto, Back- Light-Compensation (BLC)
100.8° to 27.7°
f=2.8 to 10.0mm
F1.3 (wide), F3.0 (tele)
300mm
In-built pre and post alarm image storage.
On-board storage of alarm image video
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Pre-recorded audio
messaging also available
Image size (H x V) MPEG-4
704 x 576, 320 x 240, 160 x 120
Image size (H x V) JPEG
704 x 576, 320 x 240, 160 x 120
Image size (H x V) H.264
704 x 576, 320 x 240, 160 x 120
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
H.264 frame rate
16fps (640 x 480)
Audio
Audio compression
G.711 (64kbps)/G. 726 (40, 32, 24, 16kbps)
Network
Standard Features and Benefits
Protocols
Number of clients
t Ruggedised design. Ideal for hostile outdoor conditions
Authentication
TCP/IP, HTTP, ARP, ICMP. FTP, SMTP, DHCP, SNMP, DNS, NTP, RTP/
RTCP, RTSP
20
IEEE802.1X
Interface
t PC card expansion slot. Wide range of accessories available
t Privacy masking. Ideal for masking sensitive areas of the
video image
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Audio connectivity
BNC xl, 1.0Vp-p, 75Ω, RCA x 1
10Base-T/100Base-TX (RJ-45)
Sensor in 1, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power) Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Dimensions
Video system
Horizontal resolution
S/N ratio
ø177.5m m
PAL
480 TVL
More than 50dB
Sensitivity colour
0.7lx (50IRE, F1.3, AGC ON)
Sensitivity monochrome
0.15lx (50IRE, F1.3 AGC ON)
141.5m m
General
Zoom ratio
Weight
Approx. 1.8kg
Dimensions (W x H x D)
Approx. 177 x 141mm
Power requirements
AC 24V, DC 12V, PoE
Power consumption
Conduit hole 19mm
x3.6 optical zoom
Operating temperature
Storage temperature
10W max.
-10 to 50°C (14 to 122°F)/-40 to 50°C (-40 to 122°F) with
optional heater unit
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
Bracket, Template, Torx Wrench, M4 Screws (4), Wire Rope,
M4 Shoulder Screw, Audio Cable, 1/0 Cable, CD-ROM
(User's Guide, IP Setup Program, Audio Upload Tool, Privacy
Masking Tool, Video Player, Custom Homepage Installer),
Installation Manual
40
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DH140 / DH140T
Delivering HD resolution images in all lighting conditions and
utilising state-of-the-art image enhancement with the View-DR
wide dynamic range and XDNR noise reduction technologies, the
SNC-DH140 from Sony represents the very latest in mini-dome, HD
network camera technology.
Key Features and Benefits
1
Specifications (continued)
3 Sony 1/3" Exmor HD CMOS image sensor with mechanical
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
DR
View-DR enhanced wide Dynamic range technology.
Superior performance in high contrast lighting conditions
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Camera (continued)
SNC-DH140
Horizontal viewing angle
Focal length
F-number
F1.2 (wide), F2.1 (tele)
Easy Focus
Yes
Easy Zoom
Yes
Camera Features
Day/Night*3
Wide-D
Yes
View-DR*4 (125 dB)
Image enhancement
Visibility Enhancer
Noise reduction
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Easy zoom function. Adjusts the focus relative to the
zoom ratio
Vandal resistant standard
XDNR
No
Yes
Codec image size (H x V)
Video compression format
Maximum frame rate
Advanced audio detection. Monitors and stores ambient
audio levels to deliver highly accurate audio alarm triggering
SNC-DH140T
31.2 to 85.4°
f=3.1 to 8.9mm
1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x
768, 1024 x 576, 800 x 480, 768 x 576, 640 x 480, 640 x 368,
384 x 288, 320 x 240, 320 x 192
H.264, MPEG-4, JPEG
H.264/MPEG-4/JPEG: 30 fps (1280 x 720)
Audio
Audio compression
G.711/G.726
Scene analytics
Standard Features and Benefits
Intelligent motion detection
Intelligent object detection
Yes (with built-in Post Filter)
No
Advanced audio detection
Yes*5
Network
Protocols
t Triple codec support. Delivers flexible image compression
formats to overcome bandwidth limitations
ONVIF conformance
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Authentication
Interface
t Onvif support. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Card slots
Wireless network
Number of clients
Ethernet connectivity
Serial interface
Analogue video output
Mini-jack (monaural), Max output level: 1 Vrms
118 (4 3/4)
S/N ratio
Mass
Dimensions (W x H x D)
(1
3/
4)
Power requirements
Power consumption
3.5
Image device
Minimum illumination
Number of effective pixels (HxV)
NTSC/PAL
600 TV lines
more than 50 dB
General
R4
Camera
White balance modes
Mini-jack (monaural), MIC IN/LINE IN: 2.47VDC plug-in power
Analogue video output
Storage temperature
Specifications
Exposure control
No
Composite video (1Vp-p)
x1
Operating temperature
Auto gain control (AGC)
10BASE-T / 100BASE-TX (RJ-45)
No
x2
Signal system
Horizontal resolution
Electronic shutter speed
10
IEEE802.1X
Alarm output
Audio line output
140 (5 5/8)
No
Sensor input
External microphone input
Dimensions
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server),
SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
Yes
Approx. 750 g (1 lb 10 oz)
140 x 118 mm
PoE, AC24V, DC12V
8.0 W max.
-10 to +50 °C*7 (-14 to 122 °F)
-20 to +60 °C (-4 to 140 °F)
System requirements
SNC-DH140
SNC-DH140T
1/3 type progressive scan CMOS
Day : 0.20 lx, Night : 0.10 lx (F1.2/View-DR OFF/XDNR
ON-Middle/VE OFF/AGC High/50 IRE[IP])
Approx. 1.4 Megapixel
1s to 1/10,000s
Max gain setting LOW, MID, HIGH
Auto, EV Compensation*1, Auto Slow Shutter*2
Operating system
Processor
Memory
Web browser
Windows Vista®, Microsoft Windows XP
Intel Core2 Duo 2GHz or higher
1GB or more
Microsoft Internet Explorer Ver6.0, Ver7.0
Supplied Accessories
CD-ROM (User’s guides, SNC Toolbox), Installation manual,
Template, Wire rope, Bracket, LAN cable, BNC cable, Power
input cable, I/O cable, Audio Cable, Warranty booklet, M4
shoulder screw, M4 screws (2)
Auto (ATW, ATW-Pro), Preset, One-push WB, Manual
Lens type
Vari-focal lens
Zoom ratio
Approx. 2.9X
*1 Visibility Enhancer off mode only *2 View-DR off mode only *3 Removable IR Cut Filter
*4 View-DR technology is a combination of Sony’s full-capture Wide-D technology, the high-speed
“Exmor” CMOS sensor, and Visibility Enhancer. *5 Available with software version 1.1 or later *6 With
optional SNCA-CFW5 *7 Cold start temperature must be greater than 0°C.
41
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DH180
Vandal-resistant HD Mini-dome camera, with wide dynamic
range and built-in infrared (IR) illuminators. This rugged camera
features state-of-the-art image enhancement technology,
View-DR and XDNR.
Key Features and Benefits
IR
1
3
Specifications (continued)
IR Illuminator. Clearly captures objects in the dark up to
15m (49 feet) away with IR illuminators, which allows the
camera to operate in 0 lux lighting conditions
Sony 1/3” Exmor HD CMOS image sensor with mechanical
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
View-DR enhanced wide Dynamic range technology.
DR
Superior performance in high contrast lighting conditions
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Easy zoom function. Adjusts the focus relative to the zoom ratio
Camera (continued)
F-number
Minimum object distance
Powered Focus
Powered Zoom
IR illuminators
SNC-DH180
F1.2 (wide), F2.1 (tele)
300 mm
Yes (Easy Focus)
Yes (Easy Zoom)
Yes (Wave Length: 850nm [Typical], IR LED: 21pcs)
Camera Features
Day/Night *3
Wide-D
Image enhancement
Noise reduction
Yes
View-DR (125dB: Theoretical)
Visibility Enhancer
XDNR
Codec image size (H x V)
Video compression format
Codec streaming capability
Maximum frame rate
1280 x 1024, 1280 x 960, 1280 x 800, 1280 x 720, 1024 x 768,
1024 x 576, 800 x 480, 768 x 576, 640 x 480, 640 x 368, 384 x
288, 320 x 240, 320 x 192 (H.264, MPEG-4, JPEG)
H.264, MPEG-4, JPEG
Dual streaming
H.264: 20fps (1280 x 1024)
MPEG-4: 25fps (1280 x 1024)
JPEG: 30fps (1280 x 1024)
H.264/MPEG-4/JPEG: 30 fps (1280 x 720)
Audio
Audio compression
Standard Features and Benefits
G.711/G.726
Scene Analytics
t Triple codec support. Delivers flexible image compression
formats to overcome bandwidth limitations
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
t ONVIF support. Maximum interoperability and flexibility with a
wide range of manufacturers’ network video products
t IP66 Rated. Maximum environmental protection for heavy
duty outdoor monitoring applications
Dimensions
Intelligent motion detection
Intelligent object detection
Rule filter
Yes (with built-in Post Filter)
No
Yes
Network
Protocols
Number of clients
ONVIF conformance
Wireless network
Authentication
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server),
SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
10
Yes
No
IEEE802.1X
Interface
Ethernet
Serial interface
Card slots
Analogue video output
Sensor input
Alarm output
External microphone input
Audio line output
10BASE-T / 100BASE-TX (RJ-45)
No
No
BNC x 1, RCA x 1
x1
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
NTSC / PAL
600 TV lines
More than 50 dB
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Specifications
Operating temperature
Camera
Image device
Minimum illumination
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Horizontal viewing angle
Focal length
42
SNC-DH180
1/3 type progressive scan “Exmor” CMOS sensor
0.2 lx (Color)
0 lx (B/W) - IR ON
(F1.2 / View-DR Off/VE Off / AGC High(48dB max.) / XDNR
Middle / 50IRE [IP])
1.4 Megapixel (1329 x 1049)
1s to 1/10000s
Auto (3 levels)
Auto, EV Compensation *1, Auto Slow Shutter *2
Auto (ATW, ATW-PRO), Preset, One-push WB, Manual
Vari-focal lens
Storage temperature
Vandal resistant standard
Optical 2.9X (x2 Digital Zoom)
1380 g (3 lb 1 oz)
166 x 119 mm (6 5/8 x 4 3/4 inches)
PoE *4, AC24V, DC12V
28 W max.
AC24V/DC12V: -30 to 50 °C (-22 to 122°F)
PoE (IEEE802.3af): -10 to 50 °C (23 to 122°F)
AC24V/DC12V: -20 to 50 °C (-4 to 122°F)
PoE (IEEE802.3af): 0 to 50 °C (32 to 122°F)
Yes
System requirements
Operating system
Processor
Memory
Web browser
Windows XP, Windows Vista
Intel Core2 Duo 2 GHz or higher
1 GB or more
Microsoft Internet Explorer Ver 6.0 or 7.0
Supplied Accessories
CD-ROM (User's Guide, SNC Toolbox), Installation manual, Wire rope,
Bracket, BNC cable, I/O cable, Audio cable, M4 shoulder screw, M4
screw x 4, Flyee, L-wranch, B&P Warranty Booklet, Template
85.4 to 31.2 degrees
f=3.1 to 8.9 mm
*1 VE off mode only. *2 View-DR off mode only. *3 Removable IR Cut Filter. *4 When used
with PoE, SNC-DH180 cannot be used with a heater. The SNC-DH180 includes software
developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).
VIDEO SECURITY
IP MINI-DOME CAMERAS
SNC-DH240 / SNC-DH240T
Full-HD Network Camera delivering excellent picture quality
in 1080p HD resolution at 30 frames per second. Utilising
state-of-the-art image enhancement with View-DR, XDNR
and the “Exmor” CMOS sensor.
Key Features and Benefits
1
Specifications (continued)
3 Sony 1/3” Exmor HD CMOS image sensor with mechanical
DR
Camera (continued)
IRC filter. Designed for security with superior HD image
resolution in all lighting conditions
Horizontal viewing angle
View-DR enhanced wide Dynamic range technology.
Superior performance in high contrast lighting conditions
Minimum object distance
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in low light conditions
Camera Features
Easy focus function. Automatic adjustment of image
focusing simplifies installation
Easy zoom function. Adjusts the focus relative to the
zoom ratio
Focal length
t ONVIF support. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
t Ruggedised design. Ideal for hostile outdoor conditions.
(on SNC-DH240T only)
300 mm
Yes (Easy Focus)
Powered Zoom
Yes (Easy Zoom)
Day/Night *3
Wide-D
Yes
View-DR (84dB: Theoretical) (Tentative)
Image enhancement
Visibility Enhancer
Noise reduction
Vandal resistant standard
XDNR
No
Yes
Codec image size (H x V)
1920 x 1440, 1600 x 1200, 1680 x 1056, 1920 x 1080, 1440 x
912, 1376 x 768, 1280 x 960, 1280 x 800, 1280 x 720, 1280 x
1024, 1024 x 768, 1024 x 576, 800 x 480, 768 x 576, 720 x 576,
704 x 576, 720 x 480, 640 x 480, 640x 368, 384 x 288, 320 x
240, 320 x 192 (H.264, MPEG-4, JPEG)
Video compression format
H.264, MPEG-4, JPEG
Dual streaming
H264: 20fps (1920 x 1440) / 30fps (1920 x 1080)
MPEG-4: 15fps (1920 x 1440) / 25 fps (1920 x 1080)
JPEG: 10fps (1920 x 1440) / 15fps (1920 x 1080)
Audio
Audio compression
G.711/G.726
Scene Analytics
Intelligent motion detection
Intelligent object detection
Rule filter
Yes (with built-in Post Filter)
No
Yes
Network
Protocols
Number of clients
ONVIF conformance
Dimensions
F1.2 (Wide), F2.1 (Tele)
Powered Focus
Maximum frame rate
t DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
f=3.1 to 8.9 mm
F-number
Codec streaming capability
Standard Features and Benefits
SNC-DH240
SNC-DH240T
88.5 to 32.3 degrees
Wireless network
Authentication
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/
server), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2)
10
Yes
No
IEEE802.1X
Interface
Ethernet
Serial interface
140 (5 5/8)
Card slots
Analogue video output
10BASE-T / 100BASE-TX (RJ-45)
No
No
BNC x 1, RCA x 1
118 (4 3/4)
Sensor input
x1
Alarm output
x2
External microphone input
Audio line output
Mini-jack (Monaural), MIC IN/LINE IN: 2.5VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
Camera
Number of effective pixels (HxV)
Zoom ratio
Weight
SNC-DH240
SNC-DH240T
1/2.8 type progressive scan “Exmor” CMOS sensor
TBD
3 Megapixel (2096 × 1561) (Tentative)
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature *5
Electronic shutter
1s to 1/10000s
Storage temperature
Auto gain control (AGC)
Auto (3 levels)
System requirements
Exposure control
White balance modes
Lens type
More than 50 dB
General
Specifications
Image device
Minimum illumination
NTSC / PAL
TBD
Auto, EV Compensation *1, Auto Slow Shutter *2
Auto (ATW, ATW-PRO), Preset, One-push WB, Manual
Vari-focal lens
Operating system
Processor
Memory
Web browser
Optical 2.9X (x2 Digital Zoom)
750g (1 lb 10 oz)
140 x 118 mm (5 5/8 x 4 3/4 inches)
PoE, AC24V, DC12V
TBD
-10 to +50 °C (14 to 122 °F) (Tentative)
-20 to +60 °C (-4 to +140 °F)
Windows XP, Windows Vista, Windows 7
Intel Core2 Duo 2GHz or higher
1GB or more
Microsoft Internet Explorer Ver6.0, 7.0, or 8.0
*1 VE off mode only. *2 View-DR off mode only. *3 Removable IR Cut Filter. *4 With optional SNCA-CFW5.
*5 Cold start must be greater than -20 degree. * The SNC-CH240 and SNC-DH240 include software
developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).
43
VIDEO SECURITY
IP PTZ CAMERAS
SNC-P5
To meet the growing demand for high quality,
affordable remote monitoring systems, Sony has
introduced a new addition to its line of network
cameras – the SNC-P5 MPEG-4 PTZ.
Key Features
1
Specifications
4 1/4-type progressive scan CCD.
Camera
Clear high performance images
Image device
Number of effective pixels (HxV)
Dual encoding. Maximum flexibility when streaming
video data
Bi-directional audio with built-in microphone.
Transmits audio in both directions, in-built microphone
transmits audio from remote site
Electronic shutter
Exposure control
White balance modes
Lens type
Horizontal viewing angle
1/4-type progressive scan CCD
330,000 (659 x 494)
Auto/Manual (1 to 1/10,000s)
Auto, Shutter priority, Manual
Auto, Indoor, Outdoor, One-push, Manual
Pan focus optical zoom lens
Horizontal 20 to 55.8°, Vertical: 15.1 to 43.3
Focal length
f=3.4mm, to 10.2mm
F-number
F2.8 (Wide) to 3.9 (Tele)
Minimum object distance
0.4m (Wide), 1.4m (Tele)
Standard Features and Benefits
t Pan/Tilt/Zoom capability. Allows coverage of large areas with
motorised pan, tilt and 3x zoom capability
t Compact flash expansion slot. Allows flexibility for additional
storage and accessories
t Motion detection alarm trigger. External alarm output from
motion triggered alarms
Image size (H x V) MPEG-4
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Image size (H x V) JPEG
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
MPEG-4 frame rate
25fps (320x240), 15fps (640 x 480)
JPEG frame rate
25fps (320x240), 18fps (640 x 480)
Audio
Audio compression
Protocols
Number of clients
t In-built pre and post alarm image storage.
Allows internal storage of alarm images
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
TCP/IP, ARP, ICMP, DHCP, DNS, HTTP, FTP, SMTP, NTP, SNMP
(MIB-2), RTP/RTCP, PPPoE
10 (MPEG4), 20 (JPEG)
Interface
Analogue connectivity
Ethernet connectivity
I/O port connectivity
Dimensions
Audio connectivity
Mini-jack (1.0V p-p, 75Ω, Sync negative)
100Base-TX/10Base-T (RJ-45)
Sensor in 2, Alarm out 1
Built-in Microphone: Electret condenser micophone
(omni-directional). External Microphone Input: Mini-jack, 2.2kΩ
Unbalanced (RCA), 2.5V plug-in power. Line Output: Mini-jack
(mono), max output level: 1Vrms
Analogue video output
Video system
Horizontal resolution
110mm
S/N ratio
Sensitivity colour
PAL
400TV Line
48dB
3.5lx (F2.8, 30IRE, AGC ON)
General
Zoom ratio
x3 optical zoom
DC IN 12V
I/O
Weight
m
5
!
Dimensions (W x H x D)
ø130mm
Power requirements
Power consumption
Stand
106mm
Approx. 380g / Stand Approx 360g
Camera:130 x 130 x 110mm/Stand: 130 x 178 x 142mm
DC 12V
6.2W
Operating temperature
0 to +35°C (32 to 95°F)
Storage temperature
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
142mm
44
178mm
113mm
130mm
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
AC Power Adaptor MPA-AC1 (Sony) (x1), Stand (x1),
Wall-Mount (x1)
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RZ25P
Effective and efficient remote network monitoring –
the SNC-RZ25NP offers MPEG-4 or JPEG compression
and PTZ (Pan/Tilt/Zoom) in a single package.
Key Features and Benefits
1
Specifications
™
4 1/4-type CCD with Exwave HAD technology.
Camera
High quality images with superior sensitivity
Image device
Number of effective pixels (HxV)
Dual encoding. Maximum flexibility when streaming
video data
Electronic shutter
Auto gain control (AGC)
Exposure control
Day/night function. Ideal for mechanical switching
to monochrome in night conditions
White balance modes
1/4-type CCD ExwaveHAD CCD
444,000 (752 x 582)
1/1 to 1/10,000s
Auto/Manual (-3dB to 28dB)
Auto, Shutter priority, Iris priority, Manual
Auto, Indoor, Outdoor, One-push, ATW, Manual
Lens type
Auto Focus Zoom Lens
Bi-directional audio. Audio may be transmitted
in both directions
Focal length
f = 4.1mm to 73.8mm
Motion detection alarm handling with pre-alarm function.
Alarms generated on image motion, can be used to trigger
external alarm device
Analogue video output. Ideal for assisting in image
MPEG-4 frame rate
25fps (320x240), 15fps (640 x 480)
set-up during installation
JPEG frame rate
25fps (320x240), 18fps (640 x 480)
F-number
Minimum object distance
F1.4 (Wide), F3.0 (Tele)
300mm (wide), 800mm (tele)
Image size (H x V) MPEG-4
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Image size (H x V) JPEG
640 x 480, 480 x 360, 384 x 288, 320 x 240, 256 x 192,
160 x 120
Audio
Audio compression
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
Standard Features and Benefits
Protocols
Number of clients
t Manual and electronic zoom functions. 18x optical,
216x with electronic function
TCP/IP, ARP, ICMP, DHCP, DNS, HTTP, FTP, SMTP, NTP, SNMP
(MIB-2), RTP/RTCP, PPPoE
10 (MPEG4), 20 (JPEG)
Interface
Analogue connectivity
t Accessory expansion slot. Allows for addition of external
image storage accessories
Ethernet connectivity
I/O port connectivity
Audio connectivity
t Image Flip function.
BNC x1, composite video 1.0Vp-p, 75Ω
10 Base-T/100Base-TX (RJ-45)
Sensor in 2, Alarm out 2
External Microphone Input: Mini-jack, 2.4V DC plug-in power,
4.7k ohm. Line Output: Mini-jack (Monaural), Max output level:
0.9Vrms
Analogue video output
Video system
Dimensions
Horizontal resolution
S/N ratio
Front
Top
Sensitivity colour
PAL
More than 460 TV lines
More than 50dB
0.7lx (50IRE, F1.4, AGC ON)
General
Zoom ratio
206mm
147mm
Weight
Dimensions (W x H x D)
170˚
Power requirements
170˚
Power consumption
Operating temperature
Storage temperature
x18 optical zoom (x216 with digital zoom)
Approx. 1.3kg
140 x 206 x 148mm
AC 24V/DC 12V
18W max.
0 to 40°C (32 to 104°F)
-20 to 60°C (-4 to 140°F)
System requirements
140mm
Operating system
Side
Bottom
90˚
System requirements
5mm
14mm
20mm
ø5, Depth
30˚
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
Ceiling Mount-Kit, CD-ROM (User’s Guide, Setup and SNC
Panorama Creator Software), Installation Manual
Tripod screw hole
1/4 -20UNC, Depth
6.5mm
70mm
148mm
12mm
45
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RZ50P
The SNC-RX series, SNC-RZ50 and SNC-CS50 third-generation
network cameras are the latest in a series of Sony network
cameras that support Intelligent Video Analytics. This efficient and
intelligent processing method can provide greater operational
efficiency and a high level of security.
Key Features and Benefits
1
Specifications
™
4 1/4-type CCD with Exwave HAD technology.
Camera
Clear high performance images
Image device
Number of total pixels
Dynamic frame integration. Reduces motion blur from
high speed images
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
JPEG, MPEG-4 and H.264 streaming. JPEG, MPEG-4, H.264
encoding allows maximum image transmission flexibility
Exposure control
White balance modes
Day/night function. Switches automatically to mono in
night conditions
Lens type
Horizontal viewing angle
Focal length
Dual encoding. Maximum flexibility when streaming
video data
F-number
Minimum object distance
1/4-type Super HAD CCD
740,000
400,000 (702 x 575)
1 to 1/10,000s
Auto/Manual (-3dB to 28dB)
Auto, Shutter-priority, Iris-priority, Manual, EV compensation,
Backlight compensation
Auto, Indoor, Outdoor, One-push, WB, ATW, Manual
Auto-focus zoom lens
1.7° to 42.0°
f=3.5 to 91.0mm
F1.6 (wide), F3.8 (tele)
320mm (wide), 1,500mm (tele)
In-built pre and post alarm image storage. On-board
storage of alarm images
Analogue video output. Ideal for assisting in image
set-up during installation
Image size (H x V) MPEG-4
704 x 576, 640 x 480, 384 x 288, 320 x 240, 160 x 120
Image size (H x V) JPEG
704 x 576, 640 x 480, 384 x 288, 320 x 240, 160 x 120
Image size (H x V) H.264
704 x 576, 640 x 480, 384 x 288, 320 x 240, 160 x 120
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
H.264 frame rate
16fps (640 x 480), 25fps (320 x 240)
Audio
Audio compression
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
Standard Features and Benefits
Protocols
Number of clients
t Pan/Tilt/Zoom capability. Wide coverage of image
scene with motorised pan, tilt and zoom functions
Authentication
TCP/IP, HTTP, ARP, ICMP, DHCP, FTP, SMTP, SNMP, RTP/RTCP, SSL
(HTTPS), DNS, NTP, RTSP
20
IEEE802.1X
Interface
t Image stabilizer. Reduces image shake
Analogue connectivity
t DEPA compatible. Powerful image analytics available
I/O port connectivity
Ethernet connectivity
Audio connectivity
t PC card expansion slot. Wide range of expansion
accessories available
x1 BNC, 1.0Vp-p, 75Ω
10Base-T/100Base-TX (RJ-45)
Sensor in 2, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
t Compact Flash expansion slot.
Video system
PAL
t Privacy masking. Ideal for masking sensitive areas
of the video image
Horizontal resolution
Sensitivity colour
2.2lx (50IRE, F1.6, AGC ON),
t Voice alerts. Voice preset can store pre-recorded
warning messages
Sensitivity monochrome
0.3lx (50IRE, F1.6, AGC ON)
S/N ratio
Zoom ratio
Dimensions (W x H x D)
Dimensions
Side
70mm
140mm
Bottom
72mm
More than 50dB
General
Weight
Front
450 TV lines
70mm
1.2kg
140 x 166 x 142mm
Power requirements
DC 12V
Power consumption
20W max.
Operating temperature
9mm
x26 optical zoom (x312 with digital zoom)
Storage temperature
0 to 40°C (32 to 104°F)
-20 to 60°C (-4 to 140°F)
1 6 6mm
50mm
System requirements
46
Screw hole
for wire rope
Operating system
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
Ceiling-Mount Bracket (A), Ceiling-Mount Bracket (B), Screws
x6, Wire Rope, AC Adaptor, AC Cable, CD-ROM (Setup
Software), Operation Manual, Installation Manual, Mount
Bracket Cover, Shoulder Screw, Plug Retainer, Rubber Feet x4
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RX530
Intelligent and feature rich – Sony high-performance multi-codec
network cameras deliver efficient 24/7 performance.
Key Features
1
Specifications
™
4 1/4-type CCD with Exwave HAD technology.
Clear high performance images
Camera
Image device
Number of effective pixels (HxV)
Dynamic frame integration. Reduces motion blur from
high speed images
JPEG, MPEG-4 and H.264 streaming. JPEG, MPEG-4, H.264
encoding allows maximum image transmission flexibility
Day/night function. Switches automatically to mono in
night conditions
Dual encoding. Maximum flexibility when streaming
video data
In-built pre and post alarm image storage. On-board
storage of alarm images
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Voice preset can store
pre-recorded warning messages
Analogue video output. Ideal for assisting in image
set-up during installation
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
1/4-type Exwave HAD CCD
440,000 (752 x 582)
1 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Auto (Full auto, Shutter-priority, Iris-priority), Manual, EV
compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push, ATW, Manual
Lens type
Auto-focus zoom lens
Horizontal viewing angle
Horizontal 2.2° to 48°
Focal length
F-number
Minimum object distance
f=4.1 to 73.8mm
F1.4 (wide), F3.0 (tele)
290mm (wide), 800mm (tele)
Image size (H x V) MPEG-4
704 x 576, 640 x 480, 384 x 288, 160 x 120
Image size (H x V) JPEG
704 x 576, 640 x 480, 384 x 288, 160 x 120
Image size (H x V) H.264
704 x 576, 640 x 480, 384 x 288, 160 x 120
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
H.264 frame rate
16fps (640 x 480)
Audio
Audio compression
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
Protocols
Number of clients
Authentication
TCP/IP, HTTP, ARP, ICMP, DHCP, FTP, SMTP, SNMP, RTP/RTCP,
RTSP
20
IEEE802.1X
Interface
Standard Features and Benefits
Analogue connectivity
Ethernet connectivity
t Pan/Tilt/Zoom capability. Wide coverage of image
scene with motorised pan, tilt and 18x zoom functions
t Image stabilizer. Reduces image shake
t DEPA compatible. Powerful image analytics available
t PC card expansion slot. Wide range of expansion
accessories available
t Memory stick slot.
t Privacy masking. Ideal for masking sensitive areas
of the video image
t Voice alerts. Voice preset can store pre-recorded
warning messages
I/O port connectivity
Audio connectivity
BNC x1, 1.0Vp-p, 75Ω
10Base-T/100Base-TX (RJ-45)
Sensor in 2, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
PAL
460 TV lines
More than 50dB
Sensitivity colour
0.7lx (50IRE, F1.4, AGC ON),
Sensitivity monochrome
0.15lx (50IRE, F1.4, AGC ON)
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
x18 optical zoom (x216 with digital zoom)
2.2kg
160 x 160 x 230mm (Excluding cover equipment)
AC 24V, DC 12V
24W max.
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
System requirements
Dimensions
Operating system
System requirements
160mm
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
230mm
Supplied Accessories
Ceiling-Mount Bracket (A), Ceiling-Mount Bracket (B), Screws
x6, Wire Rope, CD-ROM (Setup Software), Operation Manual,
Installation Manual
47
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RX550
Intelligent and feature rich – Sony high-performance multi-codec
network cameras deliver efficient 24/7 monitoring.
Key Features and Benefits
1
™
4 1/4-type CCD with Exwave HAD technology.
Clear high performance images
Dynaview wide dynamic range technology. Exceptional
images even in high contrast scenes
Specifications
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
1/4-type Exwave HAD CCD
440,000 (752 x 582)
1 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Dynamic frame integration. Reduces motion blur from
high speed images
Exposure control
JPEG, MPEG-4 and H.264 streaming. JPEG, MPEG-4, H.264
encoding allows maximum image transmission flexibility
Lens type
Auto-focus zoom lens
Horizontal viewing angle
Horizontal 2.2° to 54.2°
Day/night function. Switches automatically to mono in
night conditions
F-number
Dual encoding. Maximum flexibility when streaming
video data
White balance modes
Focal length
Minimum object distance
Auto, Shutter-priority, Iris-priority, Manual, EV compensation,
Backlight compensation
Auto, Indoor, Outdoor, One-push, ATW, Manual
f=3.5 to 91.0mm
F1.6 (wide), F3.8 (tele)
320mm (wide), 1,500mm (tele)
Image size (H x V) MPEG-4
704 x 576, 640 x 480, 384 x 288, 160 x 120
Image size (H x V) JPEG
704 x 576, 640 x 480, 384 x 288, 160 x 120
In-built pre and post alarm image storage. On-board
storage of alarm images
Image size (H x V) H.264
704 x 576, 640 x 480, 384 x 288, 160 x 120
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Voice preset can store
pre-recorded warning messages
H.264 frame rate
16fps (640 x 480), 25fps (320 x 240)
Analogue video output. Ideal for assisting in image
set-up during installation
Protocols
Audio
Audio compression
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
Number of clients
Authentication
TCP/IP, HTTP, ARP, ICMP, DHCP, FTP, SMTP, SNMP, RTP/RTCP,
RTSP
20
IEEE802.1X
Interface
Analogue connectivity
Ethernet connectivity
Standard Features and Benefits
I/O port connectivity
Audio connectivity
t Pan/Tilt/Zoom capability. Wide coverage of image
scene with motorised pan, tilt and 36x zoom functions
t Image stabilizer. Reduces image shake
t DEPA compatible. Powerful image analytics available
t Memory stick slot
t Serial Interface (VISCA)
t Privacy masking. Ideal for masking sensitive areas
of the video image
t Voice alerts. Voice preset can store pre-recorded
warning messages
x1 BNC, 1.0Vp-p, 75Ω
10Base-T/100Base-TX (RJ-45)
Sensor in 2, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
PAL
460 TV lines
More than 50dB
1lx at (50IRE, F1.6, AGC ON)
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
x26 optical zoom (x312 with digital zoom)
2.2kg
160 x 160 x 230mm (excluding cover equipment)
AC 24V, DC 12V
25W max.
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
System requirements
Dimensions
Operating system
System requirements
160mm
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
Supplied Accessories
230mm
Ceiling-Mount Bracket (A), Ceiling-Mount Bracket (B), Screws
x6, Wire Rope, CD-ROM (Setup Software), Operation Manual,
Installation Manual
48
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RX570
The SNC-RX Series has a high-speed 360° endless panning (or
rotation) capability, which allows users to capture precisely almost
any object surrounding the camera. In addition, by employing
a 1/4-type Exwave HADTM CCD, the camera delivers exceptional
picture quality for any remote monitoring application, even in lowlight conditions.
Key Features and Benefits
1
™
4 1/4-type CCD with Exwave HAD technology.
Clear high performance images
Dynaview wide dynamic range technology. Exceptional
images even in high contrast scenes
Specifications
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
1/4-type Exwave HAD CCD
440,000 (752 x 582)
1 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Dynamic frame integration. Reduces motion blur from
high speed images
Exposure control
JPEG, MPEG-4 and H.264 streaming. JPEG, MPEG-4, H.264
encoding allows maximum image transmission flexibility
Lens type
Auto-focus zoom lens
Horizontal viewing angle
Horizontal 1.7° to 57.8°
Day/night function. Switches automatically to mono in
night conditions
F-number
Dual encoding. Maximum flexibility when streaming
video data
White balance modes
Focal length
Minimum object distance
Auto (Full auto, Shutter-priority, Iris-priority), Manual,
EV compensation, Backlight Compensation
Auto, Indoor, Outdoor, One-push, ATW, Manual
f=3.4 to 122.4mm
F1.6 (wide), F4.5 (tele)
320mm (wide), 1,500mm (tele)
Image size (H x V) MPEG-4
704 x 576, 640 x 480, 384 x 288, 160 x 120
Image size (H x V) JPEG
704 x 576, 640 x 480, 384 x 288, 160 x 120
In-built pre and post alarm image storage. On-board
storage of alarm images
Image size (H x V) H.264
704 x 576, 640 x 480, 384 x 288, 160 x 120
MPEG-4 frame rate
25fps (640 x 480)
JPEG frame rate
25fps (640 x 480)
Bi-directional audio with voice alert. Audio may be
transmitted in both directions. Voice preset can store
pre-recorded warning messages
H.264 frame rate
Max. 16fps
Analogue video output. Ideal for assisting in image
set-up during installation
Protocols
Audio
Audio compression
G.711 (64kbps) / G.726 (40, 32, 24, 16kbps)
Network
Number of clients
Authentication
TCP/IP, HTTP, ARP, ICMP, DHCP, FTP, SMTP, SNMP,
RTP/RTCP, DNS, RTSP
20
IEEE802.1X
Interface
Analogue connectivity
Ethernet connectivity
Standard Features and Benefits
I/O port connectivity
Audio connectivity
t Pan/Tilt/Zoom capability. Wide coverage of image
scene with motorised pan, tilt and 36x zoom functions
t Image stabilizer. Reduces image shake
t DEPA compatible. Powerful image analytics available
t Memory stick slot
t Serial Interface (VISCA)
t Privacy masking. Ideal for masking sensitive areas
of the video image
t Voice alerts. Voice preset can store pre-recorded
warning messages
Sensor in 2, Alarm out 2
External Microphone Input: Mini-jack (monaural, 2.2K 2.5V
plug-in power). Line Output: Mini-jack (monaural), max output
level: 1Vrms
Analogue video output
Video system
Horizontal resolution
S/N ratio
PAL
530 TV lines
More than 50dB
Sensitivity colour
1.4lx (50IRE, F1.6, AGC ON),
Sensitivity monochrome
0.15lx (50IRE, F1.6, AGC ON)
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
Dimensions
x1 BNC, 1.0Vp-p, 75Ω
10Base-T/100Base-TX (RJ-45)
x36 optical zoom (x432 with digital zoom)
2.2kg
160 x 160 x 230mm (excluding cover equipment)
AC 24V, DC 12V
27W max.
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
System requirements
Operating system
160mm
System requirements
Microsoft Windows 2000/XP/Vista®
CPU: Intel® Pentium® IV 1.5GHz or higher. RAM: 256MB or
more, (Vista) Intel® Pentium® IV 3GHz or higher/Core2 Duo
2GHz or higher, RAM: 1GB or more
230mm
Supplied Accessories
Ceiling-Mount Bracket (A), Ceiling-Mount Bracket (B), Screws
x6, Wire Rope, CD-ROM (Setup Software), Operation Manual,
Installation Manual
49
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RH124
The SNC-RH124 indoor rapid dome camera delivers
unrivalled image quality at HD resolution.
Key Features and Benefits
Specifications
HD video at 30 fps. Superior High Definition image quality
with real time capture
Camera
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Image device
Day/Night
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Standard Features and Benefits
t 210 degree tilt angle. Greater image capture at high
angles of tilt
HD CMOS
Yes
No
(H x V) Approx. 2 Megapixel
1/2 to 1/10,000s
Auto/Manual (-3dB to +18dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, Manual
Auto-focus zoom lens
10x
5.4 to 50 degrees
f=5.1 to 51mm
F-number
F1.8 (wide), F2.1 (tele)
Pan angle
360 degrees endless rotation
Pan speed
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
Codec image size
t Quick Release Mechanism. Quick and easy to install
and maintain
Video compression format
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Audio
Maximum frame rate
JPEG
Audio compression
(H x V) 1280 x 720,1024 x 576, 800 x 480, 768 x 576,
640 x 480 (VGA), 640 x 368, 384 x 288, 320 x 240 (QVGA),
320 x 192
H.264, MPEG-4, JPEG
H264/MPEG-4: 30 fps (1280 x 720)
10 fps (1280 x 720)
G.711/G.726
Scene Analytics
Simple activity detection
Dimensions
Intelligent motion detection
No
Yes (with built-in Post Filter)
Intelligent object detection
No
Network
Protocols
Wireless network
226 (9)
166 (6 5/8)
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2)
Yes (Optional card)
10
IEEE802.1X
Interface
Ethernet
Serial interface
Card slots
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
S/N ratio
PAL
more than 50 dB
Sensitivity colour
1.9 (50IRE, AGC ON)
Sensitivity monochrome
0.17 (50IRE, AGC ON)
General
Weight
Dimensions
Power requirements
Approx. 2.1 kg (4 lb 10 oz)
(ø x H) 154 x 226 mm (6 1/8 x 9 inches)
hPoE, AC24V, DC12V
Power consumption
27 W max
Operating temperature
0 to 50 °C
Storage temperature
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Mounting bracket, Screws, Cables (Power
input, BNC, I/O, Serial), Installation manual, CD-ROM
(User’s guide, SNC toolbox), Mounting template, Wire rope
50
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RH164
Ideal for heavy duty, outdoor monitoring applications, the
SNC-RH164 rapid dome camera delivers unrivalled image
quality at HD resolution.
Key Features and Benefits
Specifications
HD video at 30 fps. Superior High Definition image quality
with real time capture
Camera
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Image device
Day/Night
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Yes
(H x V) Approx. 2 Megapixel
1/2 to 1/10,000s
Auto/Manual (-3 to +18dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, Manual
Auto-focus zoom lens
10x
5.4 to 50 degrees
f=5.1 to 51mm
F-number
F1.8 (wide), F2.1 (tele)
Pan angle
360 degrees endless rotation
Standard Features and Benefits
Pan speed
t IP66 Rated. Maximum environmental protection for heavy
duty outdoor monitoring applications
t Sunshade Ventilation Mechanism. Delivering optimum
performance in hot weather conditions the camera benefits
from a special ventilation mechanism
Maximum frame rate
t 210 degree tilt angle. Greater image capture at high
angles of tilt
HD CMOS
Yes
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
Codec image size
Video compression format
JPEG
(H x V) 1280 x 720, 1024 x 576, 800 x 480, 768 x 576, 640 x 480
(VGA), 640 x 368, 384 x 288, 320 x 240 (QVGA), 320 x 192
H.264, MPEG-4, JPEG
H264/MPEG-4: 30 fps (1280 x 720)
10 fps (1280 x 720)
Audio
Audio compression
G.711/G.726
Scene Analytics
Simple activity detection
Intelligent motion detection
No
Yes (with built-in Post Filter)
t Quick Release Mechanism. Quick and easy to install
and maintain
Intelligent object detection
No
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Wireless network
Network
Protocols
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2) (Tentative)
Yes (With Optional card)
10
IEEE802.1X
Interface
Dimensions
Ethernet
Serial interface
Card slots
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
S/N ratio
PAL
more than 50 dB
Sensitivity colour
2.1 (50IRE, AGC ON)
Sensitivity monochrome
0.19 (50IRE, AGC ON)
General
Weight
Dimensions
Approx. 4.5 kg (9 lb 15 oz)
(ø x H) 238 x 346 mm (9 3/8 x 13 5/8 inches)
Power requirements
AC24V
Power consumption
82 W max. (Tentative)
Operating temperature
-40 to 50 °C
Storage temperature
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Top sunshade, Rotate-and-lock coupling,
Waterproof plug, Screws, Installation manual, CD-ROM
(User’s guide, SNC toolbox), Wire rope
51
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RS44P
The SNC-RS44P indoor rapid dome camera delivers high image
quality coupled feature-rich performance
Key Features and Benefits
1
™
4 1/4" CCD with Exwave HAD technology. Superior
Specifications
Camera
image quality with extended infra red response
Image device
Day/Night
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Standard Features and Benefits
t 18 x optical zoom. Powerful optical zoom capability delivers
flexible image capture and tracking
t 210 degree tilt angle. Greater image capture at high
angles of tilt
t Quick Release Mechanism. Quick and easy to install
and maintain
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Yes
(H x V) 440,000
1/2 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, ATW, Manual
Auto-focus zoom lens
18x
2.8 to 48 degrees
f=4.1 to 73.8mm
F-number
F1.4 (wide), F3.0 (tele)
Pan angle
360 degrees endless rotation
Pan speed
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
Codec image size
Video compression format
Maximum frame rate
(H x V) 720 x 576, 640 x 480 (VGA), 384 x 288, 320 x 240 (QVGA)
H.264, MPEG-4, JPEG
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Audio
Audio compression
G.711/G.726
Scene Analytics
Simple activity detection
Intelligent motion detection
No
Yes (with built-in Post Filter)
Intelligent object detection
No
Network
Protocols
Wireless network
Dimensions
1/4-type CCD with Exwave HAD technology
Yes
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2)
Yes (Optional card)
10 (Tentative)
IEEE802.1X
Interface
Ethernet
Serial interface
Card slots
226 (9)
166 (6 5/8)
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol) (Tentative)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
Horizontal resolution
S/N ratio
PAL
530 TV lines
more than 50 dB
Sensitivity colour
0.4 (50IRE, AGC ON)
Sensitivity monochrome
0.08 (50IRE, AGC ON)
General
Weight
Dimensions
Approx. 2.1 kg (4 lb 10 oz)
(ø x H) 154 x 226 mm (6 1/8 x 9 inches)
Power requirements
hPoE, AC24V, DC12V
Power consumption
25 W max.
Operating temperature
Storage temperature
0 to 50 °C
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Mounting bracket, Screws, Cables (Power input, BNC,
I/O, Serial), Installation manual, CD-ROM (User’s guide, SNC
toolbox), Mounting template, Wire rope
52
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RS46P
The SNC-RS46P indoor rapid dome camera delivers high image
quality and feature-rich performance with an enhanced optical
zoom range capability
Key Features and Benefits
1
4
Specifications
1/4" CCD with Exwave HAD™ technology. Superior
image quality with extended infra red response
Camera
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
Image device
Day/Night
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Standard Features and Benefits
Auto-focus zoom lens
36x
1.7 to 57.8 degrees
f=3.4 to 122.4mm
Pan angle
360 degrees endless rotation
Pan speed
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
t 210 degree tilt angle. Greater image capture at high
angles of tilt
Maximum frame rate
Codec image size
Video compression format
(H x V) 720 x 576, 640 x 480 (VGA), 384 x 288, 320 x 240 (QVGA)
H.264, MPEG-4, JPEG
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Audio
Audio compression
G.711/G.726
Scene Analytics
Simple activity detection
Intelligent motion detection
No
Yes (with built-in Post Filter)
Intelligent object detection
No
Network
Protocols
Wireless network
Dimensions
1 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, ATW, Manual
F1.6 (wide), F4.5 (tele)
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Yes
(H x V) 440,000
F-number
t 36 x optical zoom. Powerful optical zoom capability delivers
flexible image capture and tracking
t Quick Release Mechanism. Quick and easy to install
and maintain
1/4-type CCD with Exwave HAD technology
Yes
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2)
Yes (Optional card)
10 (Tentative)
IEEE802.1X
Interface
Ethernet
Serial interface
226 (9)
166 (6 5/8)
Card slots
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol) (Tentative)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
Horizontal resolution
S/N ratio
PAL
530 TV lines
more than 50 dB
Sensitivity colour
0.7 (50IRE, AGC ON)
Sensitivity monochrome
0.08 (50IRE, AGC ON)
General
Weight
Dimensions
Approx. 2.1 kg (4 lb 10 oz)
(ø x H) 154 x 226 mm (6 1/8 x 9 inches)
Power requirements
hPoE, AC24V, DC12V
Power consumption
25 W max.
Operating temperature
Storage temperature
0 to 50 °C
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Mounting bracket, Screws, Cables (Power input, BNC,
I/O, Serial), Installation manual, CD-ROM (User’s guide, SNC
toolbox), Mounting template, Wire rope
53
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RS84P
Ideal for outdoor, heavy duty monitoring applications, the
SNC-RS84P rapid dome camera delivers high image quality
coupled with feature-rich performance
Key Features and Benefits
1
™
4 1/4" CCD with Exwave HAD technology.
Specifications
Camera
Superior image quality with extended infra red response
Image device
Day/Night
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Standard Features and Benefits
t 18 x optical zoom. Powerful optical zoom capability delivers
flexible image capture and tracking
t IP66 Rated. Maximum environmental protection for heavy
duty outdoor monitoring applications
1/4-type CCD with Exwave HAD technology
Yes
Yes
(H x V) 440,000
1 to 1/10,000s
Auto/Manual (-3 to +28dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, ATW, Manual
Auto-focus zoom lens
18x
2.8 to 48 degrees
f=4.1 to 73.8mm
F-number
F1.4 (wide), F3.0 (tele)
Pan angle
360 degrees endless rotation
Pan speed
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
Codec image size
Video compression format
Maximum frame rate
(H x V) 720 x 576, 640 x 480 (VGA), 384 x 288, 320 x 240 (QVGA)
H.264, MPEG-4, JPEG
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Audio
Audio compression
G.711/G.726
t 210 degree tilt angle. Greater image capture at high
angles of tilt
Scene Analytics
Intelligent motion detection
No
Yes (with built-in Post Filter)
t Quick Release Mechanism. Quick and easy to install
and maintain
Intelligent object detection
No
Simple activity detection
Network
Protocols
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Wireless network
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2)
Yes (Optional card)
10 (Tentative)
IEEE802.1X
Interface
Dimensions
Ethernet
Serial interface
Card slots
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol) (Tentative)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
Horizontal resolution
S/N ratio
PAL
530 TV lines
more than 50 dB
Sensitivity colour
0.4 (50IRE, AGC ON)
Sensitivity monochrome
0.09 (50IRE, AGC ON)
General
Weight
Dimensions
Approx. 4.5 kg (9 lb 15 oz)
(ø x H) 238 x 346 mm (9 3/8 x 15 5/8 inches)
Power requirements
AC24V
Power consumption
80 W max.
Operating temperature
-40 to 50 °C
Storage temperature
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Top Sunshade, rotate and lock coupling, Waterproof
plug, Screws, Cables (Power input, BNC, I/O, Serial), Installation
manual, CD-ROM (User’s guide, SNC toolbox), Wire rope
54
VIDEO SECURITY
IP PTZ CAMERAS
SNC-RS86P
Ideal for outdoor, heavy duty monitoring applications, the
SNC-RS86P rapid dome camera delivers high image quality and
feature-rich performance with an enhanced optical zoom range
capability
Key Features and Benefits
1
™
4 1/4" CCD with Exwave HAD technology. Superior
Specifications
Camera
image quality with extended infra red response
Image device
Day/Night
XDNR noise reduction technology. Noise and Ghost free
images with superior sensitivity in lowlight conditions
Wide-D
Visibility Enhancer. Enhanced wide dynamic range
improves performance in challenging lighting conditions
Auto gain control
Number of effective pixels
Electronic shutter speed
Exposure control
White balance mode
DEPA Advanced analytics. Advanced, powerful intelligent
video analytics deliver enhanced system performance
Lens type
Zoom ratio
Horizontal viewing angle
Focal length
Standard Features and Benefits
1/4-type CCD with Exwave HAD technology
Yes
Yes
(H x V) 440,000
1 to 1/10,000s
Auto/Manual (-3dB to +28dB)
Auto, Full auto, Shutter-priority, Iris-priority, Manual,
EV compensation, Backlight compensation
Auto, Indoor, Outdoor, One-push WB, ATW, Manual
Auto-focus zoom lens
36x
2.8 to 48.0 degrees
f=4.1 to 73.8mm
F-number
F1.4 (wide), F3.0 (tele)
Pan angle
360 degrees endless rotation
Pan speed
400 degrees/s (max.)
Tilt angle
210 degrees (with e-flip)
Tilt speed
400 degrees/s (max.)
t 36 x optical zoom. Powerful optical zoom capability delivers
flexible image capture and tracking
t IP66 Rated. Maximum environmental protection for heavy
duty outdoor monitoring applications
Maximum frame rate
t 210 degree tilt angle. Greater image capture at high
angles of tilt
Scene Analytics
Intelligent motion detection
No
Yes (with built-in Post Filter)
t Quick Release Mechanism. Quick and easy to install
and maintain
Intelligent object detection
No
t ONVIF Compliant. Maximum interoperability and flexibility with
a wide range of manufacturers’ network video products
Wireless network
Codec image size
Video compression format
(H x V) 720 x 576, 640 x 480 (VGA), 384 x 288, 320 x 240 (QVGA)
H.264, MPEG-4, JPEG
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Audio
Audio compression
Simple activity detection
G.711/G.726
Network
Protocols
Number of clients
Authentication
TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS,
NTP, RTP/RTCP, SNMP (MIB-2)
Yes (Optional card)
10 (Tentative)
IEEE802.1X
Interface
Dimensions
Ethernet
Serial interface
Card slots
Analogue video output
10BASE-T/100BASE-TX (RJ-45)
RS-232C/RS-422 (PELCO D protocol) (Tentative)
CF card x1
Composite video (1Vp-p)
Sensor input
x4
Alarm output
x2
Mini-jack (Monaural), MIC IN/LINE IN: 2.2k ohm,
2.45VDC plug-in power
Mini-jack (Monaural), Max output level: 1 Vrms
External microphone input
Audio line output
Analogue video output
Signal system
Horizontal resolution
S/N ratio
PAL
530 TV lines
more than 50 dB
Sensitivity colour
0.8 (50IRE, AGC ON)
Sensitivity monochrome
0.09 (50IRE, AGC ON)
General
Weight
Dimensions
Approx. 4.5 kg (9 lb 15 oz)
(ø x H) 238 x 346 mm (9 3/8 x 15 5/8 inches)
Power requirements
AC24V
Power consumption
80 W max.
Operating temperature
-40 to 50 °C
Storage temperature
-20 to 60 °C
System requirements
Operating system
System requirements
Web browser
Windows XP/Vista®
CPU: Intel® Pentium® IV 3GHz, Intel® Core™2 Duo 2GHz or
higher, RAM: 1GB or more
Microsoft Internet Explorer Ver6.0 or higher
Supplied Accessories
Base unit, Top Sunshade, rotate and lock coupling, Waterproof
plug, Screws, Cables (Power input, BNC, I/O, Serial), Installation
manual, CD-ROM (User’s guide, SNC toolbox), Wire rope
55
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-DC693P
A fixed camera offering wide dynamic range for the
capture of clear and detailed images even in high
contrast conditions.
Key Features and Benefits
1
Specifications
Camera
3 1/3-type image sensor. High resolution image capture in
Image device
conditions of extreme contrast
Number of effective pixels (HxV)
DynaViewTM technology. Provides excellent images under
Auto gain control (AGC)
Electronic shutter
high contrast illumination conditions
Day/night function. Automatically provides monochrome
images under lowlight conditions
Backlight compensation ON/OFF
ATW-PRO/ATW/MANUAL selectable
Lens mount
Analogue connectivity
Analogue video output
Sensitivity colour
Sensitivity monochrome
BNC, 1.0 Vp-p, 75Ω, sync. negative
PAL standard
520 TV lines
More than 50dB (AGC OFF)
0.8lx at F1.2, 50IRE, AGC=High, 2.1lx at F1.2, 50IRE, AGC=High
0.01lx at F1.2, 50IRE, AGC=High, 0.05lx at F1.2, 50IRE, AGC=High
General
131mm
Zoom ratio
Weight
LENS
56mm
CS Mount
Interface
S/N ratio
35.3mm
CUSTOM Selectable (Max :48 dB)
White balance modes
Horizontal resolution
33.5mm
720 x 540
1 to 1/10,000s
Exposure control
Video system
Dimensions
1/3-type image sensor with DynaView+ technology
Dimensions (W x H x D)
MENU/
ENTER
ADJUST
COLOR VIDEO CAMERA
x4 digital zoom
Approx 420g
56 x 68.8 x 131mm (without tripod)
Power requirements
AC 220-230V ±10%
Power consumption
Less than 8.0W
Operating temperature
-10 to 50°C
Storage temperature
-40 to 60°C
9.3
mm
Supplied Accessories
Lens Mount Cap (1), Operating Instructions (1), Menu Operations (1),
Fall-prevention Wire Rope (1), Screw (1), AC Power Cable (1, AC 220-240 V only)
SSC-DC698P
A fixed camera offering wide dynamic range for the
capture of clear and detailed images even in high
contrast conditions.
Features and Benefits
1
Specifications
3 1/3-type image sensor. High resolution image capture in
conditions of extreme contrast
Camera
Image device
Number of effective pixels (HxV)
1/3-type image sensor with DynaView+ technology
720 x 540
DynaViewTM technology. Provides excellent images under
high contrast illumination conditions
Electronic shutter
Exposure control
Backlight compensation ON/OFF
Day/night function. Automatically provides monochrome
images under lowlight conditions
White balance modes
ATW-PRO/ATW/MANUAL selectable
Auto gain control (AGC)
Lens mount
1 to 1/10,000s
CUSTOM Selectable (Max :48 dB)
CS Mount
Interface
Analogue connectivity
BNC, 1.0 Vp-p, 75Ω, sync. negative
Analogue video output
Standard Features and Benefits
Video system
Horizontal resolution
t Flexible AC and DC power requirements. Flexible power options
via automatically sensing of 12VDC or 24VAC power supplies
S/N ratio
Sensitivity colour
Sensitivity monochrome
Zoom ratio
Weight
131mm
35.3mm
Dimensions (W x H x D)
56mm
LENS
MENU/
ENTER
ADJUST
COLOR VIDEO CAMERA
0.8lx at F1.2, 50IRE, AGC=High, 2.1lx at F1.2, 50IRE, AGC=High
0.01lx at F1.2, 50IRE, AGC=High, 0.05lx at F1.2, 50IRE, AGC=High
x4 digital zoom
Approx 420g
56 x 68.8 x 131mm (without tripod)
Power requirements
AC 220-230V ±10%
Power consumption
Less than 8.0W
Operating temperature
-10 to 50°C
Storage temperature
-40 to 60°C
Supplied Accessories
Lens Mount Cap (1), Operating Instructions (1), Menu Operations (1),
Fall-prevention Wire Rope (1), Screw (1), AC Power Cable (1, AC 220-240 V only)
9.3
mm
56
520 TV lines
More than 50dB (AGC OFF)
General
Dimensions
33.5mm
PAL standard
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-DC80P
The SSC-DC80P series is a colour video camera equipped with an
Exwave HADTM* technology using a 1/2-inch type CCD.
Key Features and Benefits
1
Specifications
Camera
TM
2 1/2-Exwave HAD technology. Very high resolution, high
Image device
1/2-type CCD with Exwave HAD technology
Number of effective pixels (HxV)
sensitivity images in all lighting conditions
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Standard Features and Benefits
Lens mount
768 x 494 (440,000)
ON/OFF, 1/50 to 1/100,000 switchable
Turbo/Normal/Manual/Off
SPOT/WEIGHT/OFF switchable (BLC)
ATW PRO/ATW/3200K/5600K/MANUAL
CS/C Mount (C-Mount adaptor is supplied)
Interface
t Wide range CCD iris. Allows use of manual iris lens by automatically
adjusting image exposure under varied lighting conditions
t Privacy zones. Allows masking of sensitive image areas
Analogue connectivity
Analogue video output
Video system
PAL Internal/VS/VD
Horizontal resolution
S/N ratio
Sensitivity colour
480 TV lines
More than 57dB (AGC OFF, weight ON)
0.4lx (50IRE, F1.2, Turbo AGC ON)
General
Dimensions
Weight
Dimensions (W x H x D)
260mm
70mm
60mm
57mm
70mm
BNC, 1.0Vp-p; 75Ω, sync. negative, S-Video x 1
Power requirements
Approx 560g (1.4oz)
70 x 57 x 131mm (without front and rear covers)
Multiplexing with the YS-W170P/W270P, or DC 12V ±10%
Power consumption
4.6W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-40 to 60°C (-40 to 140°F)
Supplied Accessories
CD-ROM (Setup Program and User’s Guide), Wire Rope, Shoulder
Screw M4, Installation Manual, C-Mount Ring Adaptor
COLOR VIDEO CAMERA
131mm
SSC-DC83P / SSC-DC88P
Offering outstanding picture quality, the feature rich SSC-DC88P is ideal
for high-end video monitoring applications.
Features and Benefits
1
Specifications
TM
2 1/2-Exwave HAD technology. Very high resolution, high
sensitivity images in all lighting conditions
Camera
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
White balance mode
Lens type
Standard Features and Benefits
CCD iris
Back-Light Compensation (BLC)
t Wide range CCD iris. Allows use of manual iris lens by automatically
adjusting image exposure under varied lighting conditions
Analogue video output
t Custom templates. Allows quick and easy set up for a wide
range of applications
ON/OFF switchable, 1/50 to 1/100,000 s
SPOT/WEIGHT/OFF switchable
BNC x 1, 1.0 Vp-p, 75Ω, Sync negative, S-Video x 1
PAL
S/N ratio
Minimum illumination
480 TV lines
More than 57 dB (AGC OFF, WEIGHT ON)
0.4 lx (50IRE, F1.2, Turbo AGC ON)
General
Weight
Power consumption
70mm
60mm
ATW-pro/ATW/3200K/5600K/Manual
CS/C*-mount (* C-mount adaptor is supplied), DC/Video servo auto iris
Internal/AC Line lock/VS
Power requirements
260mm
70mm
440,000 (752 x 582)
Turbo/Normal/Manual/Off
Sync system
Dimensions (W x H x D)
Dimensions
SSC-DC88P
1/2-type CCD with Exwave HAD technology
Signal system
Horizontal Resolution
t Privacy zones. Allows masking of sensitive image areas
SSC-DC83P
approx. 550 g (1.3 oz)
approx. 600 g (1.5 oz)
70 x 57 x 260 mm (2 7/8 x 2 1/4 x 20 1/4 inches)
(including front and rear covers)
AC 24 V ±10 %, 50 Hz or
AC 220 to 240 V ±10 %, 50 Hz
DC 12 V ±10 %
4.4 W
4.2 W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-40 to 60°C (-40 to 140°F)
Supplied Accessories
57mm
Lens mount cap, Operating
instructions, Front cover, Rear
cover, Screws (2), C-mount
adaptor
Lens mount cap, Operating
instructions, Front cover, Rear
cover, Screws (2), Power cable
COLOR VIDEO CAMERA
131mm
57
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-E413P / SSC-E418P
The SSC-E413P is equipped with a 1/3-type Super HAD™ CCD II,
which offer improved sensitivity and colour reproduction
compared to the conventional Super HAD CCD.
Key Features and Benefits
1
Specifications
Camera
TM
3 1/3-type Super HAD CCD II. Very high resolution, high
Image device
sensitivity images in all lighting conditions
SSC-E413P
Number of effective pixels (HxV)
Electronic shutter
Automatic backlight compensation. Offers excellent
reproduction in varying levels of Illumination
Auto gain control (AGC)
752 x 582
ON/OFF, 1/50 to 1/100,000 switchable
TURBO/OFF switchable
Exposure control
(BLC) ON/OFF switchable
White balance modes
Auto White Balance (ATW)
Lens mount
Standard Features and Benefits
CS Mount
Interface
Analogue connectivity
t Auto CCD Iris function. Provides image clarity under extreme
background lighting conditions
1.0Vp-p, 75Ω, sync negative
Analogue video output
Video system
PAL standard Internal/Line Lock
Horizontal resolution
Dimensions
S/N ratio
Sensitivity colour
120mm
60mm
25mm
Sensitivity monochrome
9.5mm
99mm
Weight
0.3lx at F1.2 (50IRE, AGC ON)
0.05lx at F1.2 (50IRE, AGC ON)
360g (13oz)
Dimensions (W x H x D)
30mm
32mm
540 TV lines
Better than 50dB (AGC OFF, WEIGHT ON)
General
24mm
53mm
SSC-E418P
1/3-type Super HAD CCD II
Power requirements
AC 220v to 240V ±10%, 50Hz
Power consumption
45.6mm
385g (14oz)
60 x 53 x 120mm
3.5W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-40 to 60°C (-40 to 140°F)
SSC-E433P / SSC-E438P
Low voltage, 1/3-type Super HAD™ CCD II colour
video camera.
Features and Benefits
1
Specifications
™
3 1/3-type Super HAD CCD II. Very high resolution,
Camera
Day/night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
Electronic shutter
Exposure control
(BLC) ON/OFF switchable
Automatic backlight compensation. Provides image clarity
under extreme background lighting conditions
White balance modes
Auto White Balance (ATW)
Auto gain control (AGC)
S/N ratio
60mm
124mm
6.2mm
Sensitivity colour
Sensitivity monochrome
General
53mm
0.5mm
1/3-type Super HAD CCD II
752 x 582
ON/OFF, 1/50 to 1/100,000 switchable
TURBO/OFF switchable
Lens mount
Interface
Video system
Horizontal resolution
Dimensions
0.5mm
SSC-E438P
Image device
Number of effective pixels (HxV)
Analogue connectivity
Analogue video output
58
SSC-E433P
high sensitivity images in all lighting conditions
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
CS Mount
1.0Vp-p, 75Ω, sync negative
PAL standard Internal/Line Lock
540 TV lines
Better than 50dB (AGC OFF, WEIGHT ON)
0.4lx at F1.2 (50IRE, AGC ON)
0.05lx at F 1.2 (50IRE, AGC ON)
390g (14oz)
410g (14oz)
60 x 53 x 124mm
AC 24V +10%, 50Hz or DC
AC 220V to 240V +10%, 50Hz
12V +10%
4.0W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
Supplied Accessories
-40 to 60°C (-40 to 140°F)
Lens Mount Cap x1, Operating Instructions x1,
Wire Rope x1, Screw x1
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-E473P
CS-Mount colour high resolution type with day/night function.
Key Features and Benefits
Specifications
1/3-type CCD with SuperExwaveTM technology. Very high
resolution, high sensitivity images in all lighting conditions
Camera
Day/night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
Electronic shutter
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
White balance modes
Lens mount
1/3-type Interline Transfer CCD
752 x 582
1/50 to 1/100,000s (8 steps) OFF/MANUAL/CCD IRIS selectable
OFF/MANUAL/NORMAL/TURBO selectable
ON/OFF switchable
ATW / ATW Pro
CS Mount
Interface
Standard Features and Benefits
Analogue connectivity
Analogue video output
t Wide range CCD IRIS. Allows use of manual iris lens by
automatically adjusting image exposure under varied lighting
Dimensions
Video system
Horizontal resolution
S/N ratio
PAL Internal/External
540 TVL
More than 50dB (AGC OFF, weight ON)
Sensitivity colour
0.55lx at F1.2 (50IRE, AGC Turbo ON)
Sensitivity monochrome
0.05lx at F1.2 (50IRE, AGC Turbo ON)
General
Weight
Dimensions (W x H x D)
246mm
60mm
1.0Vp-p; BNC (1) 75Ω, sync. negative
53.5mm
70mm
Power requirements
53mm
Power consumption
ADJUST
LENS
COLOR VIDEO CAMERA
380g (13oz)
60 x 53 x 124mm (without front and rear covers)
AC 24V ±10% at 50Hz or DC 12V ±10%
4.0W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-40 to 60°C (-40 to 140°F)
Supplied Accessories
124mm
Lens Mount Cap x1, Operating Manual x1, Front Cover x1, Rear
Cover x1, Screws x2
9mm
SSC-E478P
CS-Mount colour high resolution type with day/night function.
Features and Benefits
1
Specifications
TM
3 1/3-type CCD with SuperExwave technology. Very high
Camera
resolution, high sensitivity images in all lighting conditions
Image device
Day/night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
Electronic shutter
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
White balance modes
Lens mount
Analogue connectivity
Analogue video output
t Wide range CCD IRIS. Allows use of manual iris lens by
automatically adjusting image exposure under varied lighting
TURBO/OFF switchable
(BLC) ON/OFF switchable
Auto White Balance Pro (ATW Pro) Auto White
Balance (ATW)
CS Mount
Video system
Horizontal resolution
S/N ratio
BNC, 1.0Vp-p; 75Ω, sync. negative
PAL standard Internal/Line Lock
540 TV lines
Better than 50dB (AGC OFF, WEIGHT ON)
Sensitivity colour
0.55lx at F1.2 (50IRE, AGC ON, Turbo mode)
Sensitivity monochrome
0.05lx at F1.2 (50IRE, AGC ON, Turbo mode)
General
Dimensions
Weight
Dimensions (W x H x D)
246mm
53.5mm
70mm
Power requirements
Power consumption
53mm
752 x 582
ON/OFF, 1/60 to 1/100,000 switchable
Interface
Standard Features and Benefits
60mm
1/3-type CCD with SuperExwave technology
ADJUST
LENS
COLOR VIDEO CAMERA
400g (14oz)
60 x 53 x 124mm (without front/rear cover)
AC 220V to 240V ±10%, 50Hz
4.0W
Operating temperature
-10 to 50°C (14 to 122°F)
Storage temperature
-40 to 60°C (-40 to 140°F)
Supplied Accessories
124mm
9mm
Lens Mount Cap x1, Operating Manual x1, Front Cover x1, Rear
Cover x1, Screws x2
59
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-G923 / SSC-G928
Delivering the highest resolution images in all lighting conditions
and with a powerful array of unique and added value features
and technology, the SSC-G923 and SSC-G928 from Sony
represent the very latest in fixed camera technology.
Key Features and Benefits
1
3
Specifications
Latest 1/3" Super HAD™ CCD II sensor. The very latest sensor
technology delivers superior image performance for ultra
lowlight and extended IR applications
Camera
Image Device
Unique intelligent Face Detection function. Using an
intelligent and face detection library, the camera can be
used to detect a facial image and output an appropriate
detection alarm. Combining this unique feature with an
access control or detection system adds a powerful
verification function and delivers significant benefits and
added value to new and existing security systems
976(H) x 582(V)
DC servo or VIDEO servo Auto
VIDEO Level
Variable
AGC
Shutter
OFF/Normal/Turbo/MANUAL
1/50 to 1/100,000 (12 steps)
OFF/MANUAL/CCD-IRIS selectable
BLC
OFF/DynaViewEX/iBLC/SPOT
Dynamic Range
More than 75dB measured by JEITA method
Minimum Illumination
Colour:
0.22 lx at F1.2 (50 IRE, AGC ON, Turbo mode)
0.11 lx at F1.2 (30 IRE, AGC ON, Turbo mode)
B/W:
0.06 lx at F1.2 (50 IRE, AGC ON, Turbo mode)
0.03 lx at F1.2 (30 IRE, AGC ON, Turbo mode)
Analogue video output
Signal System
PAL standard
Horizontal Resolution
S/N
Variable Gamma
White Balance
650 TVL
Better than 50dB (AGC OFF)
OFF/SCENE1/SCENE2/SCENE3/SCENE4 selectable
ATW/ATW-PRO/3200K/5600K/Manual
Sharpness
Standard Features and Benefits
t 650 TVL resolution. Highest image resolution for the optimum
in image quality
t Mechanical IRC filter. Perfect for use in lowlight and extended
IR applications
t Adaptive DNR (Digital Noise Reduction).
Utilises advanced 2D and 3D filter technology to greatly
reduce noise, providing superior image quality and detail in
lowlight conditions
SSC-G928
1/3 type Interline Transfer CCD with
DynaViewEX technology
Picture Elements
Auto Iris Lens
Ultra wide dynamic range capability with new DynaView
EX technology. New, enhanced wide dynamic range
technology delivers advanced three stage processing to
provide the optimum imaging performance in the most
challenging lighting conditions
SSC-G923
SOFT/NORMAL/SHARP
Colour Saturation
L to H (4 steps)
Optical Day/Night
Auto/External/Colour/B/W selectable
Activity Detection
ON/OFF selectable
Face Detection
ON/OFF selectable
Privacy Masking
Camera Title
ON/OFF selectable (with area setting function)
Up to 24 characters (Alphabet, Arabic numeral and some
marks) ON/OFF selectable (with 4 prepositions)
User Preset
Custom Templates
Flip
A/B Reset selectable
ENTRANCE/OFFICE/PARKIING/SUBWAY/LOBBY/STATION
OFF/VERT/HORIZ/BOTH selectable
Digital Noise Reduction
Slow Shutter
L to H (5 steps)
FF/X2/X4/X8/X16/X32/X64/X128/X256/X512
Back Focus Adjustment
Synch System
YES
Internal/AC line lock selectable
RS-485 Address
1-255
General
Dimensions
Weight
400g
Dimensions
55
14
420g
W:63×H:57×L:129.1mm
Operating Temperature
-10 to +50°C
Storage Temperature
-40 to +60°C
Operating Humidity
20 to 80%
Storage Humidity
20 to 95%
Power Requirement
DC 12 V ±10% or AC 24 V
+10% -40%, 50 Hz
AC 220 V-240 V ±10%, 50 Hz
Power Consumption
2.8W
3.5W
63
Supplied Accessories
Operating instructions
Menu operations
Fall-prevention wire rope
Screw
57
1/4”-20 UNC
Lens mount cap
AC power cable (AC 220 V to 240 V only)
60
VIDEO SECURITY
CCTV FIXED CAMERAS
SSC-G813 / SSC-G818
Delivering excellent picture quality and user-friendly features,
the SSC-G803 and SSC-G808 are the perfect choice for many
surveillance applications.
Key Features and Benefits
1
2
Specifications
1/2 –Exwave HAD™ technology. Very high resolution, high
sensitivity images in all lighting conditions
Camera
SSC-G813
Image Device
1/2-type CCD with Exview HAD technology
Day/night function. Automatically provides monochrome
images under lowlight conditions
Auto Iris Lens
BLC
Minimum Illumination
Unique intelligent Face Detection function. Using an
intelligent and face detection library, the camera can be
used to detect a facial image and output an appropriate
detection alarm. Combining this unique feature with an
access control or detection system adds a powerful
verification function and delivers significant benefits and
added value to new and existing security systems
Standard Features and Benefits
Digital zoom
Variable
OFF/Normal/Turbo/Manual
1/50 sec to 1/100,000 sec (12 steps),
OFF/MANUAL/CCD-IRIS selectable
OFF/iBLC/SPOT
Color: 0.28 lx at F1.2 (50 IRE, AGC ON, Turbo mode),
B/W: 0.005 lx at F1.2 (50 IRE, AGC ON, Turbo mode)
OFF/x2/x4/x8/x16
Analogue video output
PAL standard
Signal System
540 TV lines
Horizontal Resolution
S/N
Variable Gamma
White Balance
Better than 57 dB (AGC OFF)
OFF/SCENE1/SCENE2/SCENE3/SCENE4 selectable
ATW/ATW-PRO/3200K/5600K/Manual
SOFT/NORMAL/SHARP
Sharpness
Colour Saturation
L to H (4 steps)
Optical Day/Night
Auto/External/Color B/W selectable
Activity detection
ON/OFF selectable
Face detection
ON/OFF selectable
Privacy Masking
ON/OFF selectable (with area setting function)
Up to 24 characters (Alphabet, Arabic numeral and some
marks, and Simplified Chinese character),ON/OFF selectable
(with 4 prepositions)
A/B Reset selectable
Camera Title
t Adaptive DNR (Digital Noise Reduction). Utilises advanced
2D and 3D filter technology to greatly reduce noise, providing
superior image quality and detail in lowlight conditions
DC servo or VIDEO servo auto
VIDEO Level
Shutter
Automatic backlight compensation. Offers excellent
reproduction in varying levels of Illumination
752 x 582 (H x V)
Picture Elements
AGC
User Preset
Custom Templates
Flip
ENTRANCE/OFFICE/PARKING/SUBWAY/LOBBY/STATION
OFF/VERT/HORIZ/BOTH selectable
L to H (5 steps)
Digital Noise Reduction
t Auto CCD Iris function. Provides image clarity under extreme
background lighting conditions
Slow Shutter
OFF/x2/x4/x8/x16/x32/x64/x128/x256/x512
YES
Back Focus Adjustment
Synch System
Internal/AC line lock selectable
RS-485 address
Weight
Dimensions
55
14
-10ºC to +50ºC
-40ºC to +60ºC
Power Requirement
63
Power Consumption
1/4” -20 UNC
420 g
W:63×H:57×L:124mm
Storage Temperature
Storage Humidity
57
400 g
Operating Temperature
Operating Humidity
SSC-G813
1-255
General
Dimensions
M4
SSC-G818
20% to 80%
20% to 95%
DC 12 V ±10% or
220-240VAC ±10%, 50Hz
AC 24 V +10% to -40%, 50 Hz
2.8 W
3.1 W
Unit: mm
M4
SSC-G818
61
VIDEO SECURITY
CCTV MINI-DOME CAMERAS
SSC-CD13VP
A fixed indoor mini dome camera offering high performance
in a competitive package.
Key Features and Benefits
1
Specifications
TM
4 1/4 type Super HAD CCD. High resolution image capture
with lowlight performance
Camera
Image device
Number of effective pixels (HxV)
Automatic backlight compensation. Meets a wide range of
viewing angle requirements under varying lighting conditions
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Standard Features and Benefits
Lens mount
t 3.0 – 8mm vari-focal lens with Auto Iris capability.
CS lens options offer the maximum flexibility to match
installation requirements
Focal length
t Optional interchangeable lens options available.
High performance image capture in high contrast
scene conditions
Analogue connectivity
Horizontal viewing angle
1/4 type Super HAD CCD
752 x 582
1/50 to 1/100,000 sec (when using manual iris lens)
Turbo AGC/OFF switchable
BLC - ON (Centre measured) / OFF switchable
ATW, 2,200K to 10,000K
Auto iris vari-focal lens
CS Mount
W=84.7° (D), 66.6° (H), 49.3° (V). T=33.6° (D), 26.9° (H), 20.1°
(V)
f=3.0 to 8.0mm
F-number
F1.0
Minimum object distance
0.2m
Interface
BNC, 1.0Vp-p, 75Ω, sync negative. Internal or AC line lock
(for AC 24V)
Analogue video output
Video system
t Easy installation with four different mounting styles.
Wide range of mounting options allows ease of installation
and mounting flexibility
Horizontal resolution
S/N ratio
Sensitivity colour
Dimensions
More than 50dB (AGC OFF, Weight ON)
0.4lx at F1.0 (30IRE, AGC ON) 0.8lx at F1.0 (50IRE, AGC ON)
General
Weight
t Flexible AC and DC power requirements. Flexible power
options via automatically sensing of 12VDC or 24VAC power
supplies
PAL
480 TV lines
Dimensions (W x H x D)
Power requirements
Power consumption
Approx. 440g (16oz)
121 x 106 x 123mm
AC 24V ±10% or DC 12V ±10 %
3.3W
Operating temperature
-20 to +50°C (-4 to +122°F)
Storage temperature
-40 to +60°C (-40 to +140°F)
Supplied Accessories
Operating instructions(1), Dome Cover Screw(1)
Top View
Rear View
ø
2–
m
5m
83.5mm
121mm
123mm
62
106mm
Front View
61mm
Side View
VIDEO SECURITY
CCTV MINI-DOME CAMERAS
SSC-CD45P
This compact and discreet analogue mini-dome camera delivers
superior indoor security and surveillance monitoring with features
such as a 1/3-type Super HAD CCD.
Key Features and Benefits
1
Specifications
Camera
TM
3 1/3-type Super HAD CCD. High resolution,
high sensitivity images
Standard Features and Benefits
t Sony-patented ball-joint lens mount mechanism.
Allows flexibility in camera positioning
t Flexible and easy installation. Simple yet flexible mounting options
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Lens mount
Horizontal viewing angle
Focal length
F-number
Minimum object distance
Interface
Analogue connectivity
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
General
Dimensions
ø5mm hole x 2
97.5m m
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
Supplied Accessories
83.5m m
ø126m m
CD77 Super HAD technology
440,000 (752 x 582)
ON/OFF
Backlight Compensation ON/OFF
ATW (2,000K - 10,000K)/ATW Pro (2,500K - 6,500K)
Auto iris vari-focal lens
Ball-Joint Mount
100.8° to 27.7°
f=2.8 . 10mm
F1.3 (Wide end), F3.0 (Tele end)
300mm
Composite video (1Vp-p). Line Lock/Internal
PAL
540 lines
More than 50dB (AGC OFF)
0.9lx (50IRE, F1.3, AGC ON)
x3.6 optical zoom (x1.5 digital zoom)
Approx. 440g
126 x 97.5mm
AC 24V, DC 12V
4.0W max.
-20 to +50°C (-4 to +122°F)
-40 to +60°C (-40 to +140°F)
Operating Instructions, Template, M4 Shoulder Screw, Wire Rope
SSC-CD49P
The SSC-CD49P is a compact and discreet dome camera designed
for indoor security and surveillance monitoring applications.
Features and Benefits
1
Specifications
3 1/3-type CCD. High resolution, high sensitivity images under
wide-ranging illumination conditions
DynaViewTM technology. Provides excellent images under
high contrast illumination conditions
Camera
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Lens mount
Standard Features and Benefits
Horizontal viewing angle
Focal length
TM
t Wide dynamic range With DynaView technology.
t Sony patented Ball-Joint Lens Mount mechanism.
Allows flexible camera positioning
t 24V AC and 12V DC operation. Flexible power supply options
with auto voltage detect function
Easy
mounting and installation. Simple yet flexible mounting options
t
Analogue connectivity
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
ON/OFF
DynaView ON/OFF (BLC)
ATW/ATW Pro
Auto iris vari-focal lens
Ball-Joint Mount
100.8° to 27.7°
f=2.8 to 10.0mm
BNC x1, 1.0Vp-p, 75Ω, RCA x1
PAL (Composite) AC Line Lock/Internal Lock
480 TV lines
More than 50dB (AGC ON/Weight ON)
0.7lx (50IRE, F1.3, AGC ON)
General
x3.6 optical zoom (x1.5 digital zoom)
Weight
Approx. 440g (15lb)
Dimensions (W x H x D)
Approx. 126 x 97mm
Power requirements
ø5mm hole x 2
440,000 (752 x 582)
Interface
Zoom ratio
Dimensions
1/3-type CCD with DynaView Technology
Power consumption
AC 24V/DC 12V
4.2W max.
Operating temperature
-20 to +50°C (-4 to +122°F)
Storage temperature
-40 to +60°C (-40 to +140°F)
97.5m m
Supplied Accessories
CD-ROM (Setup Program and User’s Guide), Wire Rope, Shoulder
Screw M4, Installation Manual
63
ø126m m
83.5m m
VIDEO SECURITY
CCTV MINI-DOME CAMERAS
SSC-CD73VP
Superior sensitivity, vandal-resistant, day/night fixed
mini-dome camera.
Key Features and Benefits
1
Specifications
TM
4 1/4-type Super HAD CCD. High resolution, high sensitivity images
Day/night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
IP66 rated with ruggedised design. Ideal for use in outdoor conditions
Standard Features and Benefits
t 24V AC and 12V DC operation. Flexible power supply options with
auto voltage detect function
t Easy mounting and installation. Simple yet flexible mounting options
Dimensions
Front View
m
24.6mm
m
Side View
147mm
65mm
4.5
24.6mm
ø
4–
111mm
Rear View
85.7mm
Top View
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Lens mount
Horizontal viewing angle
Focal length
F-number
Minimum object distance
Interface
Analogue connectivity
Analogue video output
BNC, 1.0Vp-p, 75Ω, sync negative
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
Sensitivity monochrome
General
PAL Internal or AC line lock (for AC 24V)
480 TV lines
More than 50dB (AGC OFF, Weight ON)
0.4lx at F1.0 (30IRE, AGC ON). 0.9lx at F1.0 (50IRE, AGC ON)
0.1lx at F1.0 (30IRE, AGC ON). 0.2lx at F1.0 (50IRE, AGC ON)
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
Supplied Accessories
Approx 1150g (2lb 10oz)
Base: 147 x 111 x 148mm Bubble: 94mm
AC 24V/DC 12V (automatic switching)
3.6W
-20 to +50°C (-4 to +122°F)
-40 to +60°C (-40 to +140°F)
85.7mm
148mm
1/4-type Super HAD CCD
752 x 582
1/50 to 1/100,000s (CCD IRIS)
Turbo AGC (up to 24dB)/OFF switchable
ON (Centre measured)/OFF switchable (BLC)
ATW, 2,000K to 10,000K
Vari-focal auto iris lens
CS Mount
(H) 66.6° (wide), 26.9° (tele) (V) 49.3° (wide), 20.2° (tele)
f=3.0 to 8.0mm
F 1.0
0.2m
Screw x4, Operating Instructions, Monitor Cable x1, Screwdriver x1
SSC-CD75P
Vandal-resistant mini-dome camera for indoor or outdoor use with
a 1/3-type Super HAD CCD that provides high sensitivity levels and
picture quality.
Features and Benefits
1
TM
3 1/3-type CCD with Super HAD Technology. High resolution,
high sensitivity images
IP66 rated with ruggedised design. Ideal for use in outdoor conditions
Additional analogue output. Allows simple access to set-up
video images during installation
Specifications
Camera
Image device
440,000 (752 x 582)
Auto gain control (AGC)
ON/OFF (switchable)
Exposure control
White balance modes
Lens type
Lens mount
Standard Features and Benefits
1/3-type CCD with Super HAD Technology
Number of effective pixels (HxV)
Horizontal viewing angle
Focal length
ON/OFF (BLC)
ATW/ATW Pro
Auto iris vari-focal lens
Ball Joint Mount
100.8° to 27.7°
f=2.8 to 10.0mm
Interface
t 24V AC and 12V DC operation. Flexible power supply options with
auto voltage detect function
Analogue connectivity
Analogue video output
t Easy mounting and installation. Simple yet flexible mounting options
Horizontal resolution
Video system
S/N ratio
Sensitivity colour
Dimensions
Zoom ratio
Weight
141.5m m
Dimensions (W x H x D)
64
PAL (Composite) AC Line Lock/Internal Lock
540 TV lines
More than 50dB (AGC ON/Weight ON)
0.9lx (50IRE, F1.3, AGC ON)
General
ø177.5m m
m
4.5
R4
BNC x1, 1.0Vp-p, 75Ω, RCA x1
x3.6 optical zoom (x1.5 digital zoom)
Approx 1.75kg (3lb 11oz)
Approx. 177 x 141mm
Power requirements
AC 24V/DC 12V
Power consumption
4W max. (16W with heater option)
Operating temperature
-20 to +50°C (-4 to +122°F)
Storage temperature
-40 to +60°C (-40 to +140°F)
Supplied Accessories
Bracket x1, Template x1, Torx Wrench x1, M4 Screws x4, Wire Rope
x1, M4 Shoulder Screw x1, Operating Instructions
m
Conduit hole (19mm)
VIDEO SECURITY
CCTV MINI-DOME CAMERAS
SSC-CD77P
Superior sensitivity, vandal-resistant, day/night fixed
mini-dome camera with SuperExwave technology.
Key Features and Benefits
1
TM
3 1/3-type CCD with SuperExwave technology. Very high
resolution, high sensitivity images in all lighting conditions
Day/Night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
IP66 rated with ruggedised design. Ideal for use in outdoor conditions
Standard Features and Benefits
t Sony-patented Ball-Joint Lens Mount mechanism.
Allows flexible camera positioning
Dimensions
Camera
Image device
Number of effective pixels (HxV)
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Lens mount
Horizontal viewing angle
Focal length
F-number
Minimum object distance
Interface
Analogue connectivity
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
General
Zoom ratio
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
Supplied Accessories
141.5m m
ø177.5m m
m
4.5
R4
Specifications
m
1/3-type Super Exwave Technology
440,000 (752 x 582)
ON/OFF
ON/OFF (BLC)
ATW/ATW Pro
Auto iris vari-focal lens
Ball-Joint Mount
100.8° to 27.7°
f=2.8 to 10.0mm
F1.3 (wide), F3.0 (tele)
300mm
BNC x1, 1.0Vp-p, 75Ω, RCA x1
PAL (Composite) AC Line Lock/Internal Lock
540 TV lines
More than 50dB (AGC ON, weight ON)
0.6lx (50IRE, F1.3, AGC ON) B&W : 0.06lx (50IRE, F1.3, AGC ON)
x3.6 optical zoom (x1.5 digital zoom)
Approx 1.75kg (3lb 11oz)
Approx. 177 x 141mm
AC 24V/DC 12V
4W max. (16W with heater option)
-20 to 50°C (-4 to 122°F), -40 to 50°C (-40 to 122°F) with heater unit
-40 to +60°C (-40 to +140°F)
Bracket x1, Template x1, Torx Wrench x1, M4 Screws x4, Wire Rope
x1, M4 Shoulder Screw x1, Operating Instructions
Conduit hole (19mm)
SSC-CD79P
Vandal-resistant mini-dome camera designed for either indoor
or outdoor use. Incorporates DynaView technology, providing clear
images even in extreme high-contrast environments.
Features and Benefits
1
TM
3 1/3-type CCD with DynaView technology. High resolution, high
sensitivity images under wide-ranging illumination conditions
Day/Night function. Mechanical ICR filter provides excellent
b/w images in lowlight conditions
IP66 rated with ruggedised design. Ideal for use in outdoor conditions
Standard Features and Benefits
t Wide dynamic range with DynaView technology.
Provides excellent images under high contrast illumination conditions
Camera
Image device
Number of effective pixels (HxV)
Electronic shutter
Auto gain control (AGC)
Exposure control
White balance modes
Lens type
Lens mount
Horizontal viewing angle
Focal length
F-number
Minimum object distance
Interface
Analogue connectivity
Analogue video output
Video system
Horizontal resolution
S/N ratio
Sensitivity colour
General
Dimensions
22.5m m
119m m
ø150m m
R4
4.5
mm
Specifications
Conduit hole (19mm)
Weight
Dimensions (W x H x D)
Power requirements
Power consumption
Operating temperature
Storage temperature
Supplied Accessories
1/3-type CCD with DynaView Technology
440,000 (752 x 582)
Auto
ON/OFF
ON/OFF (BLC)
ATW/ATW Pro
Auto iris vari-focal lens
N/A
100.8° to 27.7°
f=2.8 to 10.0mm
F1.3 (wide), F3.0 (tele)
300mm
BNC x1, 1.0Vp-p, 75Ω, RCA x 1
PAL (Composite) AC Line Lock/Internal Lock
480 TV lines
More than 50dB (AGC ON, weight ON)
0.7lx (50IRE, F1.3, AGC ON)
Approx 1.3kg
Approx. 150 x 119mm
AC 24V/DC 12V
4W max
-20 to +50°C (-4 to +122°F)
-40 to +60°C (-40 to +140°F)
Bracket x1, Template x1, Torx Wrench x1, M4 Screws x4, Wire
Rope x1, M4 Shoulder Screw x1, Operating Instructions
65
VIDEO SECURITY
ENCODER
SNT-EX/EP Series
Offering single channel, four channel and highly flexible and scalable blade
solutions, the SONY SNT–EX/EP series delivers a unique encoding concept which
adds significant value and performance advantages not previously available to
traditional analogue camera systems. By simply adding SNT-EX/EP encoders to an
existing analogue system, users can immediately benefit from Sony’s unique imageenhancing and advanced analytics technology. Converting analogue video
signals into digital video streams for transmission via IP-based networks, the SNT-EX/EP
encoders offer unrivalled network flexibility coupled with D1 resolution support.
Key Features
Benefits
t %SFTPMVUJPOTVQQPSU
t "EWBODFEBVEJPEFUFDUJPO
t Delivers the highest possible image quality
t X
DNR noise reduction
technology
t 7PJDFBMFSU
t Existing analogue cameras benefit from noise and ghost-free images
with superior sensitivity in lowlight conditions
t 7FSTBUJMFUFMFNFUSZJOUFSGBDF
t 7JTJCJMJUZ&OIBODFS
t &YUFSOBMTUPSBHFTPMVUJPOT
t %
'*%ZOBNJD'SBNF*OUFHSBUJPO
t 0OWJGTVQQPSU
t Enhanced wide dynamic range improves performance for existing
analogue cameras in challenging lighting conditions
t Produces superior images from dynamic scenes containing both still
and moving objects
t %
&1""EWBODFEBOBMZUJDT
t 5 SJQMFDPEFDTVQQPSU
t Advanced, powerful intelligent video analytics deliver enhanced
system performance to existing analogue systems
Peripherals
Optional Accessories
t Delivers flexible image compression formats to overcome bandwidth
limitations. The encoders generate JPEG/MPEG and H.264 images
at 30FPS.
t Monitors and stores ambient audio levels to deliver highly accurate
audio alarm triggering
SNT-RS3U
SNTA-RP1
3U rack station, houses up to
12 SNT-EX/EP154 blade encoders
to provide a maximum of 48
analogue input channels
Rack station power supply unit,
provides a redundant power
supply system for the SNT-RS1U
t Stores up to three pre-recorded messages which may be replayed via
manual or alarm activation
t Flexible support for third-party telemetry cameras via RS-422, RS-485 and
Coaxitron interfaces
t Continuous, pre-and post-event recording may be stored using USB
memory devices
SNT-RS1U
3U rack station, houses up to 4
SNT-EX154/EP154 blade encoders
to provide a maximum of 16
analogue input channels.
t Maximum interoperability and flexibility with a wide range of
manufacturers’ network video products
Configurations
System Configuration
Microphone
Speaker
HDMI/RGB Monitor
NSR-1000 Series
Video out
(Coaxial cable)
System Controller
RM-NS1000
IMZ-NS100 Series
RS-485
PTZ Camera
Analogue
Video
Cameras
Video out
(Coaxial cable)
LAN
Video out
(Coaxial cable)
Video out
(Coaxial cable)
SNT-EX104
Ethernet
Ethernet
PC
Remote Control
Unit RM-NS1000
66
Sony’s unique XDNR (eXcellent Dynamic Noise Reduction),VE (Visibility Enhancer), DFI (Dynamic Frame Integration) technology and DEPA
Advanced (Distributed Enhanced Processing Architecture), combine with RS-485 and Coaxitron telemetry options to deliver superior
image quality, powerful video and audio analytics and advanced telemetry support to existing analogue systems. Delivering advanced
features, superior image quality from existing analogue video signals and the significant benefits of intelligent video and audio
analytics, the SONY SNT-EX/EP series encoders are the obvious choice when migrating from an existing analogue system, to an IP based
surveillance solution.
Specifications
SNT-EX101
SNT-EX101E
SNT-EX104
SNT-EP104
SNT-EX154
SNT-EP154
No
Yes
No
RS-485
–
Encoder Features
Visibility enhancer
Yes
XDNR
Yes
Coaxitron control
Yes
Interface
Analogue video input
x1
x4
Composite buffered
throughout
x1
–
Ethernet
Serial interface
10Base-T/100Base-TX (RJ-45)
RS-422/RS-485
RS-485
USB Memory slots
x1
x4
Sensor input
x2
x4
–
x4
Alarm output
x2
x4
–
x4
–
IN x1, OUT x1
IN x4, OUT x4
–
IN x1, OUT x1
–
Mini-jack (monaural), MIC IN/LINE IN: oover 2.2kohm, 2.45VDC plug-in power
–
Mini-jack (monaural), MIC
IN/LINE IN: over 2.2kohm,
2.45VDC plug-in power
–
Mini-jack (monaural), Max output level: 1,5Vp-p
–
Mini-jack (monaural), Max
output level: 1,5Vp-p
–
Audio interface (IN/OUT)
External microphone input
Audio line output
–
–
–
Codec image size (HxV)
D1 (NTSC: 720 x 480, PAL: 720 x 576), VGA (640 x 480), CIF (384 x 288), QVGA (320 x 240)
Video compression format
H.264, MPEG-4, JPEG
Maximum frame rate
H264/MPEG-4/JPEG: 30 fps (NTSC: 720 x 480, PAL: 720 x 576)
Audio
Audio compression
G.711/G.726
G.711/G.726
–
–
Scene Analytics
Intelligent motion
detection
Yes (with built-in Post Filter)
No
Yes
(with built-in Post Filter)
No
Motion detection
No
Advanced audio
detection
Yes
Yes
No
Yes
No
Yes
No
Network
Protocols
IPv4, IPv6, TCP, UDP, ARP, ICMP. IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SNMP (MB-2)
Number of clients
10
Authentication
IEEE802.1X
Number of IP address/Mac
address
x1
x4
General
Weight
Dimensions (W x H x D)
Power requirements
Approx. 0.4kg (14 oz)
73 x 34 x 155 mm
2 7/8 x 1 3/8 x 6 1/8 inches)
AC 24V (In ±20%, Out)
Power consumption
9.6W max.
Operating temperature
0 to 50°C
Approx. 1.4kg (2 lb 3 oz)
PoE (802.af)
Storage temperature
Approx. 1.3kg (2 lb 3 oz)
210 x 44 x 250 mm
8 3/8 x 1 3/4 x 9 7/8 inches)
Approx. 0.4kg (14 oz)
78 x 34 x 382 mm
3 1/8 x 1 3/8 x 15 1/8 inches)
DC 12V
From Rack Station
14.4W max.
12W max.
0 to 45°C
-20 to 60°C
System requirements
Microsoft Windows Vista®
Operating system
Intel® Core™2 Duo, 1.8GHz or higher.
Processor
Memory
1GB or more
Web browser
Microsoft Internet Explorer Ver. 6.0, Ver. 7.0
Supplied Accessories
CD-ROM (User’s Guide and supplied programs) (1),
Installation Manual (1), B&P Warranty Booklet (1), I/O
port connector (1), 24V AC connector (1), Attachment
brackets (4), Attachment screws (8)
CD-ROM (User’s Guide and supplied programs) (1),
Installation Manual (1), B&P Warranty Booklet (1), AC
adaptor (AC-NB 12A) (1), Power cord (1),
I/O port connector (SNT-EX104 only) (1)
Installation Manual (1), B&P Warranty Booklet (1),
I/O port connector (Only SNT-EX154) (1),
Attachment screws (2)
67
VIDEO SECURITY
RECORDING SOLUTIONS
IMZ-NS100 Series
Real Shot Manager Advanced: simple, flexible, powerful
and scalable – HD-ready Intelligent Monitoring Software
from Sony Professional.
Key Features
Benefits
t&BTZUPVTFBOEVOEFSTUBOE
graphical user interface
t "VUPNBUJDDBNFSB
registration
t 4JNQMFZFUQPXFSGVM
recording capabilities
t )PUTQPUNPOJUPSJOHGVODUJPO
t Minimal operator training required
t 'MFYJCMFDVTUPNTDSFFO
layouts
t Quick and easy set up of Sony IP cameras
t 5PUBMMZTDBMBCMFXJUINVMUJQMF
camera options
t Locate required images quickly and easily
t 0QFOQMBUGPSN
t "EWBODFJNBHFTFBSDI
functions
t Manual, event and scheduled recording available
t Provides detailed view for area of interest
t Allows user defined graphical interface options
t System expansion to meet your requirement via
IMZ-NS101, NS104, NS109 and NS116, 1, 4, 9 and
32 channels options
t Powerful system flexibility via support of third-party
IP cameras
Configurations
Standalone Configuration
Sony
Professional’s
Network
Cameras
Server with
IMZ-NS100 Series installed
Network
Third Party
Network
Cameras
AXIS 206
Network Camera
AXIS
Client-Server Configuration
Server with
IMZ-NS100 Series installed
Sony
Professional’s
Network
Cameras
Monitoring Room
Controller with
IMZ-NS100 Series installed
Network
Third Party
Network
Cameras
Network
AXIS 206
Network Camera
AXIS
Analogue Cameras
68
SNT-V704
Server with
IMZ-NS100 Series installed
Intelligent search functions
Post VMD Search
VMF Search
Specifications
System Requirements
Operating system *1
Microsoft® Windows Vista® Business
Microsoft Windows Vista Enterprise
Microsoft Windows® XP Professional SP2
Microsoft Windows Server 2003
Standard Edition SP2
Intel® CoreTM 2Duo 2.0-GHz or higher
CPU
Main memory
HDD 2
Easy-to-use monitoring functions
1 GB or more
10GB spare capacity
(or more depending on the video that is to be stored)
Video card
1024 x 768, 16/24 bit colour
Network interface card (NIC)
100BASE-TX or higher
Display (Resolution)
1024 x 768 or higher
Specifications
Server
Client
Video compression
JPEG/MPEG-4
JPEG/MPEG-4
Audio compression
G711/G726
G711/G726
Number of cameras to
be connected *2
32
—
Number of clients to be
connected *3
10
—
Maximum number of layouts
100
100
Maximum number of users
100
100
—
64
Maximum number of
servers to a client *4
Double-clicking a Frame
Hot spot monitoring/Dual monitor support
*1 x 64 edition is not supported.
*2 This is a recommended value to assure high performance. It is technically possible to
connect more than 32 units by installing on the PC a corresponding number of licences.
Display/recording performance basically depends on PC performance, but an increase
in cameras may deteriorate overall performance.
*3 This is a recommended value to assure high performance. It is technically possible to
connect more than 10 clients, but this increase may deteriorate overall performance.
*4 This is a recommended value to assure high performance. It is technically possible to
connect more than 64 servers, but this increase may deteriorate overall performance.
Monitor 1
Monitor 2 (Hot spot)
RSM Advanced Series software packages
IMZ-NS101
Control PC software for
one networked video source.
IMZ-NS109
Control PC software for up to
nine networked video sources.
IMZ-NS104
Control PC software for up to
four networked video sources.
IMZ-NS116
Control PC software for up to
16 networked video sources.
IMZ-NS132
Control PC software for up to
32 networked video sources
images to be searched quickly.
69
VIDEO SECURITY
RECORDING SOLUTIONS
NSR-1000 Series
The NSR 1000 series offers a highly scalable range of hybrid network
recording solutions. Simplified operation and set up coupled with an
open platform offers the maximum in flexibility and ease of use.
Key Features
Benefits
t MPEG-4/JPEG dual stream
t DEPA compatible
t )%.*PVUQVUT
t "EEJUJPOBMTUPSBHF
of 2TB x 7
t 3FNPUFWJFXJOHCZ
controller software
t View images in full HD, when using Sony megapixel cameras
t *.;/44FSJFT
compatible
t Advanced video analytics capability
t 'MFYJCMFIZCSJEDPOOFDUJWJUZ
and recording
t Capable of encoding dual streams simultaneously
t Up to 11TB of additional storage in raid 5 mode.
Optional NSRE-S200 storage accessories will be required
t Remote control and viewing via bundled software
t Capability of remote control of network cameras and
NSR1000 via IMZ-NS100 series software
t Can record and display both analogue and IP cameras
offering the maximum in flexibility and migration capability
Configurations
Standalone Configuration
Analogue Cameras (Max. 16 Units)
NSR-1000 Series
HDMI/
RGB Monitor*2
*1
Network
NSRE-S200HDD
Expansion Unit(Max. 7
Units)
AXIS 206
Network Camera
AXIS
Third-Party
Network
Cameras
Sony’s Network
Cameras
HDMI/
RGB Monitor*2
*1 The NSR-1050H can be directly
connected with 16 analogue
cameras as standard. The NSR1100/1200 requires an optional
NSBK-A16 Analogue Encoding Kit.
*2 The NSR-1000 Series has two
analogue RGB and two HDMI
monitor output connectors on the
rear panel. You can use two out of
the four outputs simultaneously in
any combination.
Client-Server Configuration
Sony’s Network
Cameras
Machine Room
NSR-1000 Series
Monitoring Room
Controller Software Installed PC
Network
Third-Party
Network
Cameras
Analogue Cameras
70
AXIS 206
Network Camera
AXIS
SNT-V704
Network
Specifications
Video/Recording
NSR-1200
Number of Cameras Supported
(IP/Analogue Total)
Analogue Camera Input
Max. 64
Hard Disk Drives (RAID Level)
Hard Disk Drives (Recording Capacity)
Expansion Storage
Max. 32
Max. 20
16ch Video
Input/ 4ch
Audio Input
(Supplied
Cable)
H.264/MPEG-4/JPEG
Video Compression (Analogue-Camera)
Hard Disk Drives (Physical Capacity)
NSR-1050H
Option (NSBK-A16)
Video Compression (IP-Camera)
Maximum Recording Rate
NSR-1100
MPEG-4
480fps
240fps
120fps
2000GB (500GB
x4)
1000GB
(500GB x2)
500GB (500GB
x1)
RAID 5
RAID 0
–
1366GB
886GB
443GB
Supports NSRE-S200 (2000GB) (Max. 7 Units)
Analogue RGB
Output
HDMI Output
Analogue RGB
Output
NSR-1100
x3 (Front), x3 (Rear)
Serial Interface (for UPS)
Serial Interface (for Analogue Camera
Control)
HDMI (A-type) x1
D-sub 15pin x1 (Front) or D-sub 15pin x1
(Rear) *2
RS-232C x1
RS-232C x1, RS-422/485 x1 (Either one to be
selected)
SFF-8088 type x1
General
Dimensions (W x H x D)
Mass
Power Requirements
Power Consumption
Operating Humidity
430mm x 87mm x 417mm (17 x 3 1/2 x 16 1/2
inches) (exclusive projections)
Approx. 13.5kg
(29lb 12oz)
Approx. 12kg
(26lb 7oz)
Approx. 11.5kg
(25lb 6oz)
100V to 127V/200V to 240V AC (50/60Hz)
265W (typical)
185W (typical)
175W (typical)
5 to 40ºC (41 to 104ºF)
10 to 80% (Max. wet-bulb temperature 30°C,
non-condensing)
Supplied Accessories
Analogue Camera Cable x1 (NSR-1050H Only),
Front panel key x2, Rubber Feet x4, Recovery CD
x1, Manual/Tool/Source Codes CD x1
Supported Languages
English, German, French, Spanish, Italian, Chinese,
Japanese, Russian.
HDMI (A-type) x1
D-sub 15pin x1
NSR-1050H
1000Base-T/100Base-TX/10Base-T x4 (Auto
switching)
USB 2.0
Operating Temperature
HDMI Output
Monitor Out #2
(HDMI or Analogue)
Ethernet *1
NSR-1200
SAS 1.1 (Serial Attached SCSI)
MPEG-4
Video Interface
Monitor Out #1
(HDMI or Analogue)
Other Interfaces
Audio Interface
Line Out
RCA-pin, L/R x1 stereo pair
Sensor/Alarm
Sensor In
8-channel photo-coupler (DC3.3-24V)
Alarm Out
8-channel relay (Max. 24V 1A)
Storage Capacity
Hard Disk Drives (Physical Capacity)
Hard Disk Drives (RAID Level)
Hard Disk Drives (Recording Capacity)
NSR-1200
2000GB (500GB x4)
RAID 5
1366GB
Interfaces
*1 Port #1 to #3 can be used as ordinary LAN ports. Port #4 cannot be used alone. Channel Bond
is supported by #3 and #4.
*2 The D-sub 15-pin (Front) and D-sub 15-pin (Rear) Connectors cannot be used simultaneously.
Encoding Card
Number of Analogue Cameras Supported
Number of Audio Inputs
NSBK-A16
Max. 16
Max. 4 inputs
Video Compression
MPEG-4
Input Video Format
NTSC or PAL
SAS (Serial Attached SCSI) 1.1 Input
SFF-8088 type x1
Mass
Approx. 72g (2.5oz)
SAS (Serial Attached SCSI) 1.1 Output
SFF-8088 type x2
Input Connector
DVI-I Connector x1
Ethernet (For Maintenance)
Serial Interface (For Maintenance)
100Base-TX/10Base-T auto x1
RS-232C x1
General
Dimensions (W x H x D)
Mass
Power Requirements
Power Consumption
Operating Temperature
Operating Humidity
Serial Interface (For Maintenance)
Host Interface
Input Connector (Video)
430mm x 87mm x 417mm (17 x 3½ x 16½ inches)
(exclusive projections)
Approx. 13.5Kg (29lbs 12oz)
100V to 127V/200V to 240V, AC (50/60Hz)
265W (typical)
5 to 40ºC (41 to 104ºF)
10 to 80% (Max. wet-bulb temperature 30°C
non-condensing)
RS-232C x1
Supplied Accessories
Front panel key x2, Rubber foot x4, CD x1
PCI
Analogue Camera Cable (Supplied)
Input Connector (Audio)
Output Connector
Mass
Length
BNC x16
RCA x4
DVI-I Connector x1
Approx. 235g (8.3oz)
300mm (11 7/8 inches)
General
Operating Temperature
Operating Humidity
5 to 40ºC (41 to 104ºF)
10 to 80% (Max. wet-bulb temperature 30°C,
non-condensing)
Supplied Accessories
Analogue Camera Cable x1,
CD x1
71
VIDEO SECURITY
ACCESSORIES - RECORDING SOLUTIONS
NSR Accessories
Expand your NSR storage with a selection of cost-effective storage
solutions to enable you to keep your data longer, while allowing
fast access and reliable data protection.
Features & Benefits
NSRE-Si8/1
NSRE-Si16/1
NSRE-SJBOD16/1
t 8 hot-swappable SAS/SATA drive bays in a robust
2U chassis
t 16 hot-swappable SAS/SATA drive bays in a robust
3U chassis
t 16 hot-swappable drive bays in a robust
3U chassis
t Quad-port iSCSI 1Gb access with link aggregation t Quad-port iSCSI 1Gb access with link aggregation
and jumbo frames support
and jumbo frames support
t Supports Serial Attached SCSI (SAS)
and SATA drives
t iSCSI, SMB/CIFS, NFS, FTP support
t Online Volume Clone, Box-to-Box Replication,
and NAS Fusion
t iSCSI, SMB/CIFS, NFS, FTP support
t Online Volume Clone, Box-to-Box Replication,
and NAS Fusion
t Single SAS JBOD I/O module
t Single power supply unit with 80-PLUS
Bronze Certified
t Single power supply unit with 80-PLUS Bronze
Certified
t SAS expansion for easy scalability
t Single power supply unit with 80-PLUS Bronze
Certified
t SES-2 compliant enclosure management
t Fully compatible with PROMISE HBAs and
RAID subsystems
t OPAS and UPS Monitor via USB service
t Comprehensive embedded web-based
management via Ethernet – WebPAM PROe
t Wake-on-SAS support (WOS)
t OPAS and UPS Monitor via USB service
t Comprehensive embedded web-based
management via Ethernet – WebPAM PROe
t Power Scheduler Operation
t MAID 2.0 support
t PerfectRAID and Predictive Data Migration
technology for robust error handling and recovery
t LCD Panel support (optional)
t Wake-on-LAN support (VessRAID)
t Power Scheduler Operation
t MAID 2.0 support
t PerfectRAID and Predictive Data Migration
technology for robust error handling and recovery
t LCD Panel support (optional)
t Wake-on-LAN support (VessRAID)
t Wake-on-SAS support (VessJBOD)
t Wake-on-SAS support (VessJBOD
Dimensions
NSRE-Si8/1
NSRE-Si16/1
NSRE-SJBOD16/1
Peripherals
72
NSRE-RM1
NSRE-RM2
M2
NSRE-RM3
3
NSRE-SASCABLEE
Rackmount kit for the following products
- NSR-1100, NSR-1200 & NSR-1050H.
Rackmount kit for NSRE-Si8/1,
NSRE-Si8/1 for the
installation in a standard 19" rack housing.
Rackmount kit for NSRE
NSRE-Si16/1 and NSRE-SJBOD16/1
for installation in a standard 19" rack housing.
This is a 1M cable used
d to connect the
NSRE-SJBOD16/1 with the NSRE-Si16/1.
Specifications
System and Controller Features
Form Factor
Drive Support
Controller
Host Channel
Promise Expansion Enclosure
Data Cache
iSCSI Features
Command Queue Depth
NSRE-Si8/1
JBOD I/O Module Features
NSRE-Si16/1
2U
3U
8 Drives (3.5")
16 Drives (3.5")
SAS(3Gb/s), SATAII(3Gb/s), NCQ, TCQ
Single (Intel® IOP348 1.2GHz)
Quad Ports full-duplex 1Gb iSCSI
One Port SAS-wide (x4)
N/A
for VessJBOD series
512MB~2GB ECC cache memory with Optional
BBU (Battery Backup Unit)
Error Recovery Level 0
Link Aggregation and Jumbo Frames w/ up to 64
Concurrent Sessions
CHAP, iSNS and DHCP
Microsoft iSCSI MPIO Support
1024
Form Factor
Drive Support
Controller
Host Channel
Promise RAID HBA
Promise RAID Storage System
Variable Block and Sector Size
Disk Data Formats
Background Activities
RAID Robustness
Management Function
SMB/CIFS (Apple, Microsoft), NFS (Linux/Unix)
FTP
Online Volume Clone, Box Replication, NAS Fusion
Supported OS
0, 1, 1E, 3, 5, 6, 10 (0+1), 30, 50, 60
Global or Dedicated w/ revertible option
256
32
64KB ~ 1MB stripe block sizes
512B, 1KB, 2KB, 4KB sector size
Supports Disk Data Format (DDF) for drive roaming
between VTrak and VessRAID series systems.
Media Patrol
Background Synchronizing; Initialization
Rebuild; Redundancy Check
SMART Condition Pooling, OCE (Online Capacity
Expansion)/RLM (RAID Level Migration)
Priority Control; Throttle Rate Control and
watermarking per BGA (background activities) in
Disk and NVRAM
PDM (Predictive Data Migration)
PerfectRAID™ advanced error handling
Array Error Recovery
Read/Write Check Table, Write Hole Table, Bad
Sector Re-map Table, NVRAM event logging
Management Interfaces
Management Protocols
Management Tools
Management Interfaces/Protocols
Event Notification
VessRAID 1000 iSCSI/SAS Series
SAS Features
Full SAS domain Topology Management
SAS Management Protocol
In-band Access to Expander and PHY
Statistic Counters and Performance Monitors
Statistic Counters and Performance Monitors
SES Enclosure Management
Windows 2000, XP, 2003, Vista, 2008
Windows 2000, XP, 2003, Vista, 2008
RedHat Linux, SuSE Linux, FreeBSD 7.0
LED Status Indicator
In-band SES Enclosure Management
In-band SES Enclosure Management
SES over in-band SAS
System Information
AC Input
Current (Max)
Power Supply
FAN
Temperature
Relative Humidity
Dimensions (H x W x D)
Weight
Safety/EMI
1
Windows 2000, XP, 2003, Vista, 2008
RedHat Linux, SuSE Linux, FreeBSD 7.0
VMWare ESX Server 4.0
WebPAM PROe/SNMP via Ethernet
CLI/CLU via RJ-11 or Ethernet
LCD Control Panel (Optional)
OPAS/UPS Monitor via USB service
Power Scheduler Control
Ethernet, RJ-11 Serial Port, USB
SNMP, SSL, Telnet, SLP
Email , SNMP, NETSEND, Buzzer, LEDs,
LCD Control Panel
SuperTrak EX8654, SuperTrak EX8658
SuperTrak TX8658
System Management
System Management
Supported OS
Dual, IN/OUT SAS-wide(x4) port over SFF-8088
SAS Features
Operational Features
RAID Levels
Hot spares
Max LUNs per subsystem
Max LUNs per array
3U
16 Drives (3.5")
SAS(3Gb/s), SATAII(3Gb/s)
Single
Host Options
NAS Features
File Sharing Protocol
Network Protocol
Data Services
NSRE-SJBOD16/1
Base Configuration
90 ~ 264 VAC, 47 ~ 63Hz
7A (100V); 3.5A (240V)
Single 450W
90-264V auto-ranging w/PFC
80PLUS® Bronze
N+1 Design
5° ~ 40°C1 (-40° ~ 60°C non operational)
10% to 80% non-condensing
131 x 446.2 x 460.5 mm
5.1 x 17.6 x 18.1 in
13.8 kg (30.42 lbs) w/o drives
13.8 kg (30.42 lbs) w/o drives
CE, FCC Class B, VCCI, BSMI, CB, KCC, C-Tick, UL/cUL, TUV
VessJBOD 2U/3U Unit w/ Drive Carrier
RJ11-to-DB9 Serial Data Cable, Power Cord
Quick Start Guide, Set of Screws, CD (Product
Manual, Firmware Update Tool, QSG)
Warranty and Option
Warranty
Supported Hardware Options
3 years limited warranty2
Front Bezel, Sliding Rail, SAS Cable
1
Operational Temperature between 5° ~ 35°C if BBU installed.
BBU is covered by one year limited warranty
2
System Information
AC Input
Current (Maximum)
Power Supply
Power Consumption
FAN
Temperature
Relative Humidity
Dimensions (H x W x D)
Weight
Safety/EMI
Base Configuration
90 ~ 264 VAC, 47 ~ 63Hz
6A (100V); 3A (240V)
7A (100V); 3.5A (240V)
Single 450W
Single 350W
90-264V full-ranging w/PFC 90-264V full-ranging w/PFC
®
80PLUS Bronze
80PLUS® Bronze
167.3 Watts (w/ SAS drives) 242.8 Watts (w/ SAS drives)
73.2Watts (w/o drives)
72.2Watts (w/o drives)
N+1 Design
2
5° ~ 40°C (-40° ~ 60°C non operational)
10% to 80% non-condensing
88.2 x 446.2 x 461 mm 130.1 x 446.2 x 461 mm
3.5 x 17.6 x 18.1 in
130.1 x 446.2 x 461 mm
10.8 kg (23.81 lbs) w/o drives 13.2 kg (29.1 lbs) w/o drives
16kg (35.27 lbs) w/ drives 23.6 kg (52.03 lbs) w/ drives
CE, FCC Class B, VCCI, BSMI, CB, KCC, C-Tick, UL/cUL, TUV
VessRAID 2U/3U Unit w/ Drive Carrier
VessRAID 2U/3U Unit w/ Drive Carrier
RJ11-to-DB9 Serial Data Cable, Power Cord
Warranty and Support
Warranty
Supported Hardware Options
3 years limited warranty3
LCD Panel, Front Bezel, Sliding Rail,
Battery Backup Unit, SAS Cable
1
Microsoft® WHQL for Windows Server 2003 and 2008. 2Operational Temperature between 5° ~ 35°C
if BBU installed. 3BBU is covered by one year limited warranty.
73
VIDEO SECURITY
ACCESSORIES - RECORDING SOLUTIONS
NSR Accessories continued
Features & Benefits
NSRE-S200
RM-NS1000
t The NSR-1200/1100/1050H has an internal storage capacity of up to 2 TB/1
TB/0.5 TB respectively. For additional storage requirements, each server can
connect up to seven NSRE-S200 units via its SAS interface. The NSRE-S200 is
a 2 TB hard disk storage device with RAID 5 capability. With the NSR-1200 in
RAID 5 configuration and with seven connected NSRE-S200 units, its total
maximum recording capacity is approximately 11 TB.
t An optional RM-NS1000 System Controller – which connects to the
NSR-1000 Series or a client PC via USB cable – allows the user to control
multiple servers and cameras. A wide range of operations can be
performed from this unit, including camera selection, Pan/Tilt/Zoom (PTZ)
with preset controls, snapshot capturing, video exporting, and event
search and playback. Equipped with a three-axis joystick with a mouse
emulator, three-line LCD, and feature-rich control panel, the RM-NS1000
is the ideal tool for easy operation of your system.
1
2
3 4 5
6
7
8
9 10 11
12
13
Dimensions
Rear Panel NSRE-S200
Height
Width
Height 3.4" (87mm)
Width 16.9" (430mm)
Depth 16.4" (417mm)
14
1.
2.
3.
4.
5.
6.
7.
8.
9.
15
16 18 20
23
17 19 21 22
JOG/SHUTTLE LED BUTTON
PAUSE
LOCK BUTTON
PANIC BUTTON
PLAY BUTTON
ALARM BUTTON
LCD/MULTI FUNCTION BUTTON
ALL SELECT BUTTON
PRESET/SET BUTTON
25 26
24
10. CUSTOM FUNCTION BUTTON
11. DIGITAL ZOOM BUTTON
12. CURSOR LED BUTTON
13. JOYSTICK
14. JOG/SHUTTLE DIAL
15. LIVE BUTTON
16. CAMERA TOUR BUTTON
17. STILL CAPTURE BUTTON
18. LAYOUT TOUR BUTTON
19. MIC BUTTON
20. MONITOR SELECT BUTTON
21. FULL SCREEN BUTTON
22. BUILT-IN MIC
23. CAMERA SELECT BUTTON
24. NUMERIC KEY
25. IRIS BUTTON
26. FOCUS BUTTON
Specifications
Storage Capacity
Hard disk drive
Physical capacity
Interface
RAID level
Recording capacity
NSRE-S200
Interfaces
RM-NS1000
2 TB (500 GB x4)
Serial ATA
Interface
USB 2.0 low-speed device
(Cable Length - Approx 3m; 9ft. 10in.)
RAID 5
USB 2.0 (2)
Approx. 1396 GB
Microphone stereo mini jack (plug-in power) (1)
External Interface
Interfaces
Ethernet
Serial interface
Serial attached SCSI (SAS1.1)
Headphone stereo mini jack (1)
100BASE-TX/10BASE-T x1 (Auto switching)
(For maintenance)
RS-232C x1 (For maintenance)
SFF-8088 (mini-SAS 26pin): input x1, output x2
General
Dimensions (W x H x D)
Mass
AC 100 to 127 V/200 to 240 V (50/60 Hz)
Power consumption
Approx. 80 W (typical) (Max. 350 W)
Operating humidity
Supplied accessories
74
Dimensions
Mass
430 x 87 x 417 mm (16.9 x 3.4 x 16.4 inches)
(Excluding protrusions)
Approx. 12 kg (26 lb 7 oz)
Power requirements
Operating temperature
RS-485 port
General
5 to 40 ºC (41 to 104 ºF)
Power Requirement
Power Consumption
AC Adapter
Operating Temperature
Operating Humidity
20 to 80 %
Mini-SAS cable (1 m), Front panel key (2),
Installation manual,
Safety regulations, WEEE booklet, Warranty booklet,
Rubber foot (4)
Supplied Accessories
409.0 (W) x 111.5 (H) x 170.0 (D) mm
(16 1/8 x 4 1/2 x 6 3/4 inches)
1.200 g (2.6 lb)
DC 12V
1A
100-240V AC, 50/60Hz
5 to 40 degrees C (41 to 104 degrees F)
20 to 80 % (max. wet bulb temperature :
32 decrees C (90 degrees F))
AC Adapter (1), First Step Guide (1), CD-ROM
(User’s Guide) (1), Warranty (1)
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HRX550/EXT
The SNCA-HRX550/EXT Dome offers versatility, easy
installation and camera protection in a compact size.
This inconspicuous dome housing is specifically designed
to accommodate Sony’s SNC-RX550, SNC-RZ25,
SNC-RS44/46 and SNC-RH124 cameras.
Features and Benefits
Dimensions
t Easy camera installation in an IP66 rated dome
t Designed to support the SNC-RX550, SNC-RZ25, SNC-RS44/46
and SNC-RH124 cameras in outdoor installations
t Constructed of durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear .118” (3mm) thick aspheric polycarbonate dome
t 24 Hour fan operation for effective heating and condensation protection
t Thermostatically controlled 24VAC heater
t Separate power input for H&B and camera power
Model
SNCA-HRX550/EXT
Description
Outdoor dome
camera housing
Rating
Operating
temperature
IP66
-29 to +50°C
-44 to +50°C with
optional heater/blower
kit added
(SNCA-HEATER)
Operating voltage
Applicable
Camera Models
Optional
accessories
Colour
24VAC
SNC-RX550P
SNC-RX530P
SNC-RX570P
SNC-RZ25
SNC-RS44/46
SNC-RH124
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
DuPont
Sky White
PFW-510-S9
Operating voltage
Applicable
Camera Models
Optional
accessories
Colour
24VAC
SNC-RX550P
SNC-RX530P
SNC-RX570P
SNC-RZ25N
SNC-RS44/46
SNC-RH124
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
DuPont
Sky White
PFW-510-S9
SNCA-HRX550/INT
The SNCA-HRX550/INT 7” Dome offers versatility, easy
installation and camera protection in a compact size for
indoor installations. This inconspicuous dome housing is
specifically designed to accommodate Sony’s SNC-RX550N,
SNC-RZ25N, SNC-RS44/46 and SNC-RH124 cameras
Features and Benefits
Dimensions
t Easy camera installation
t Designed for the SNC-RX550, SNC-RZ25N, SNC-RS44/46
and SNC-RH124 cameras
t Constructed of Durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear.118” (3mm) thick aspheric
polycarbonate dome
Model
SNCA-HRX550/INT
Description
Indoor dome
camera housing
Rating
IP66
Operating
temperature
0 to 50°C
75
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HRX550EXT/R
The SNCA-HRX550EXT/R 7” Dome offers heavy duty, vandal
resistant protection for the camera. This tough dome
housing is specifically designed to accommodate Sony’s
SNC-RX550,SNC-RZ25N, SNC-RS44/46 and SNC-RH124
cameras. The housing offers versatility, easy installation and
outstanding camera protection in a compact size.
Features and Benefits
Dimensions
t Easy camera installation in an IP66 outdoor dome
t Offers IK-10 level protection for the SNC-RZ25N and SNC-RX550
series cameras
t Outdoor dome, UV protected
t Strong cast aluminum top and trim ring for IK10 rated protection
t Optically clear 118” (3mm) thick aspheric polycarbonate dome
t Thermostatically controlled 24VAC heater
t 24 Hour fan operation for effective heating and condensation protection
t Separate power input for H&B and camera power
t Pendant mount, 1½” NPT quick connect coupling
Model
SNCA-HRX550EXT/R
Description
Heavy duty, outdoor
dome housing
Rating
Operating
temperature
IP66
-29 to +50°C
-44 to +50°C with
optional heater/
blower kit added
(SNCA-HEATER)
Operating voltage
Applicable
Camera Models
Optional
accessories
Colour
24VAC
SNC-RX550P
SNC-RX530P
SNC-RX570P
SNC-RH124
SNC-Z25N
SNC-RS44/46
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
DuPont
Sky White
PFW-510-S9
SNCA-HRX550EXT/W
The SNCA-HRX550EXT/W 7” Dome offers versatility, easy installation and
camera protection in a compact size. This inconspicuous dome housing
is specifically designed to accommodate Sony’s SNC-RX550 and SNC-RZ25
cameras when equipped for wireless operation. The SNCA-HRX550EXT/W
includes a pre-run wireless antenna cable that works with the SNCA-CFW1
wireless card & SNCA-AN1 antenna.
Features and Benefits
Dimensions
t Easy camera installation in an IP66 rated dome
t Designed to support the SNC-RX550 and SNC-RZ25 cameras
in outdoor, wireless installations
t Constructed of Durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear.118” (3mm) thick aspheric polycarbonate dome
t 24 Hour fan operation for effective heating and condensation protection
t Thermostatically controlled 24VAC heater
t Separate power input for H&B and camera power
t Wireless antenna cable included with housing
76
Model
Description
SNCA-HRX550EXT/W
External dome
housing (wireless)
Rating
Operating
temperature
Operating voltage
Applicable
Camera Models
Optional
accessories
Colour
IP66
-29 to +50°C
-44 to +50°C with
optional heater/
blower kit added
(SNCA-HEATER)
24VAC
SNC-RX550P
SNC-RX530P
SNC-RX570P
SNC-RZ25
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
DuPont
Sky White
PFW-510-S9
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-RX550EXT12V
The SNCA-RX550EXT Dome offers versatility, easy
installation and camera protection in a compact
size. This inconspicuous dome housing is specifically
designed as a 12vdc input enclosure for outdoor
installations.
Features and Benefits
Dimensions
t Easy camera installation in an IP66 rated dome
t Designed as a 12vdc input model for outdoor installations
t Constructed of durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear.118” (3mm) thick aspheric polycarbonate dome
t 24 Hour fan operation for effective heating and condensation protection
t Thermostatically controlled 12vdc heater
t Separate power input for H&B and camera power
Model
Description
SNCA-RX550EXT12V
External dome
housing (12V)
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
12VDC
SNC-RX-550P
N/A
Clear
Approx.
Dimensions
SNCA-HRZ25
The SNCA-HRZ25 outdoor dome housing with clear dome,
24 VAC input, with heater & blower offers versatility and
camera protection in a compact size. This inconspicuous
dome housing is specifically designed to accomodate
Sony’s SNC-RZ25 Network camera.
Features and Benefits
Dimensions
t Easy camera installation
t Constructed of a durable engineered plastic top,
94VO, with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear 118” (3mm) thick aspheric
polycarbonate dome
t 24 Hour fan operation for effective heating and
condensation protection
t Thermostatically controlled 24VAC heater
t Separate power input for H&B and camera power
Model
Description
Rating
Operating
temperature
Operating voltage
Applicable Camera
Models
Colour
SNCA-HRZ25
Outdoor 8” dome housing,
pendant mount with clear
dome for SNC-RZ25 camera
IP66
-6.67 to +40°C
24VAC, 75W
SNC-RZ25
DuPont
Sky White
PFW-510-S9
77
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HRZ50/EXT
The SNCA-HRZ50/EXT Dome offers versatility and camera
protection in a compact size. This inconspicuous dome
housing is specifically designed to accommodate Sony’s
SNC-RZ30 and SNC-RZ50 cameras. The housing offers
versatility, easy installation and outstanding camera
protection in a compact size.
Features and Benefits
Dimensions
t Easy camera installation
t Constructed of a durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear 118” (3mm) thick aspheric polycarbonate dome
t 24 Hour fan operation for effective heating and condensation
protection
t Thermostatically controlled 24VAC heater
t Separate power input for H&B and camera power
Model
Description
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
SNCA-HRZ50/EXT
External dome
housing
IP66
-29 to +50°C
(-44 to +50°C with
optional heater
blower kit)
24VAC
SNC-RZ30P
SNC-RZ50P
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
DuPont
Sky White
PFW-510-S9
Approx.
Dimensions
SNCA-HRZ50/EXT/R
The SNCA-HRZ50/EXT/R 7” Dome offers heavy duty, vandal
resistant, IK10 rated protection for the camera. This tough
dome housing is specifically designed to accommodate
Sony’s SNC-RZ30N and SNC-RZ50N cameras. This housing
offers versatility, easy installation and outstanding camera
protection in a compact size.
Features and Benefits
Dimensions
t Easy camera installation
t Outdoor dome, UV protected
t Strong cast aluminum top and trim ring offers IK10 vandal
protection
t Optically clear 118” (3mm) thick aspheric polycarbonate dome
t Thermostatically controlled 24VAC heater
t 24 Hour fan operation for effective heating and condensation protection
t Separate power input for H&B and camera power
t Pendant mount, 1½” NPT quick connect coupling
t Accepts the SNC-RZ25N and SNC-RZ30N cameras
78
Model
Description
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
SNCA-HRZ50/EXT/R
Heavy duty, indoor
dome housing
IP66
-29 to +50°C
(-44 to +50°C with
optional heater
blower kit)
24VAC
SNC-RZ30P
SNC-RZ50P
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
DuPont
Sky White
PFW-510-S9
Approx.
Dimensions
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HRZ50/EXT/W
The SNCA-HRZ50/EXT/W Dome offers versatility and camera protection in a
compact size. This inconspicuous dome housing includes a pre-run wireless
antenna cable that works with the SNCA-CFW1 wireless card & SNCA-AN1
antenna. This housing offers versatility, easy installation and outstanding
camera protection in a compact size.
Features and Benefits
Dimensions
t Easy camera installation
t Constructed of a durable engineered plastic top, 94VO,
with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear 118” (3mm) thick aspheric polycarbonate dome
t 24 Hour fan operation for effective heating and condensation
protection
t Thermostatically controlled 24VAC heater
t Separate power input for H&B and camera power
t Wireless ready model
Model
Description
SNCA-HRZ50/EXT/W
External dome
housing (wireless)
Rating
Operating
temperature
IP66
-29 to +50°C
(-44 to +50°C with
optional heater
blower kit)
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
24VAC
SNC-RZ30P
SNC-RZ50P
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
SNCA-CFW1
SNCA-AN1
DuPont
Sky White
PFW-510-S9
Approx.
Dimensions
SNCA-HRZ50/INT
The SNCA-HRZ50/INT Dome offers versatility and camera
protection in a compact size. This inconspicuous dome
housing is specifically designed to support Sony’s SNC-RZ30
and SNC-RZ50 cameras in indoor installations. The housing
offers versatility, easy installation and outstanding camera
protection in a compact size.
Features and Benefits
Dimensions
t Easy camera installation
t Constructed of a durable engineered plastic top,
94VO, with UV protected lower dome
t Cast aluminum pendant mount is standard
t Optically clear 118” (3mm) thick aspheric
polycarbonate dome
Model
Description
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
SNCA-HRZ50/INT
Internal dome
housing
IP66
0 to +50°C
12VDC
SNC-RZ30P
SNC-RZ50P
SNCA-CLEAR/2
(included)
SNCA-TINTED/2
SNCA-HEATER
DuPont
Sky White
PFW-510-S9
Approx.
Dimensions
79
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HFIXSML/230
A 115VAC/230VAC Polycarbonate Housing with a Cable Managed
Aluminium bracket, designed for use with the smaller cameras.
This IP66 aesthetically pleasing housing should protect the camera
against all that the elements can throw at it.
Dimensions
Model
Description
SNCA-HFIXSML/230
Fixed housing, c/w
sunshield, heater,
wall bracket
Rating
IP66
Operating
temperature
-28 to 48°C
Operating
voltage
230VAC, 50Hz
Applicable Camera
Models
SNC-CS10
SNC-CS11
SSC-DC172P
SSC-DC198P
SSC-DC372P
SSC-DC378P
SSC-E453P
SSC-E458P
SSC-E473P
SSC-E478P
SSC-M383CE
SSC-M388CE
Optional
accessories
Colour
Approx.
Dimensions
Additional camera
PSU may be
required
(SNCA-PSVTSML230)
when using
230VAC model
DuPont
Sky White
PFW-510-S9
L400 x H106
x W127.5mm
SNCA-HFIXSML/24
A 12VDC/24VAC Polycarbonate Housing with a Cable
Managed Aluminium bracket, designed for use with the
smaller cameras. This IP66 aesthetically pleasing housing
should protect the camera against all that the elements
can throw at it.
Dimensions
80
Model
Description
SNCA-HFIXSML/24
Fixed housing, c/w
sunshield, heater,
wall bracket
Rating
IP66
Operating
temperature
-28 to 48°C
Operating
voltage
24VAC, 50Hz
Applicable Camera
Models
SNC-CS10
SNC-CS11
SSC-DC172P
SSC-DC198P
SSC-DC372P
SSC-DC378P
SSC-E453P
SSC-E458P
SSC-E473P
SSC-E478P
SSC-M383CE
SSC-M388CE
Optional
accessories
Colour
Approx.
Dimensions
DuPont
Sky White
PFW-510-S9
L400 x H106
x W127.5mm
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-HFIXSTD/230
A 115VDC/230VAC die cast aluminium side opening housing
with a cable managed bracket designed to the highest
specification, IP66 rated to protect cameras against the
weather.
Dimensions
Model
SNCA-HFIXSTD/230
Description
Fixed housing, c/w
sunshield, heater,
wall bracket
Rating
IP66
Operating
temperature
-28 to 48°C
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
Approx.
Dimensions
230VAC, 50Hz
SNC-CS3P
SNC-CS10P
SNC-CS11P
SNC-Z20P
SNC-CS20
SNC-CM120
SNC-CS50P
SNC-CH140
SSC range
Additional camera
PSU may be
required
(SNCA-PSVTSTD230)
when using
230VAC model
DuPont
Sky White
PFW-510-S9
L514 x H131
x W176mm
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
Approx.
Dimensions
24VAC, 50Hz
SNC-CS3P
SNC-CS10P
SNC-CS11P
SNC-Z20P
SNC-CS20
SNC-CM120
SNC-CS50P
SNC-CH140
SSC Range
DuPont
Sky White
PFW-510-S9
L514 x H131
x W176mm
SNCA-HFIXSTD/24
A 12VDC/24VAC die cast aluminium side opening
housing with a cable managed bracket designed
to the highest specification, IP66 rated to protect
cameras against the weather.
Dimensions
Model
SNCA-HFIXSTD/24
Description
Fixed housing, c/w
sunshield, heater,
wall bracket
Rating
IP66
Operating
temperature
-28 to 48°C
81
VIDEO SECURITY
ACCESSORIES - HOUSINGS
SNCA-ICPTZ/C & SNCA-ICPTZ/T
The SNCA-ICPTZ/C is a low profile indoor ceiling housing.
It features a 7” optically clear polycarbonate dome, which
accommodates Sony PTZ Cameras. The upper body is
made of steel with a white powder coat trim ring and an
injection molded 3mm thick, optically clear thermoplastic
polycarbonate dome.
Features and Benefits
Dimensions
t 7” polycarbonate dome for easy installation and servicing from
below the ceiling
t Housing extends only 3.5” below ceiling
t For the SNC-RZ25, SNC-RZ30, SNC-RZ50, SNC-RS44/46, SNC-RH124
and SNC-RX series ptz cameras
t Includes a decorative trim ring with quick-release pressure springs
t Optically clear .118” (3mm) thick aspheric polycarbonate dome
t A tinted lower dome is available as p/n SNCA-TINTED/2
Model
Description
Rating
Operating
temperature
Operating
voltage
SNCA-ICPTZ/C
Clear dome in
ceiling bracket
N/A
N/A
N/A
SNCA-ICPTZ/T
Tinted dome in
ceiling bracket
N/A
N/A
N/A
Applicable Camera
Models
SNC-RX530P
SNC-RX550P
SNC-RX570P
SNC-RZ50P
SNC-RX530P
SNC-RX550P
SNC-RX570P
SNC-RZ50P
Optional
accessories
Colour
Approx.
Dimensions
N/A
Clear
H9.1" x W12"
x D12"
N/A
Tinted
H9.1" x W12"
x D12"
SNC-RZ25P
SNC-RZ30P
SNC-RS44/46
SNC-RH124
SNC-RZ25P
SNC-RZ30P
SNC-RS44/46
SNC-RH124
SNCA-HP5
The SNCA-HP5 is a unique outdoor housing
for the SNC-P5 camera.
Features and Benefits
Dimensions
t Easy camera installation
t Waterproof to IP x 3
t Operating Temperature -10C to +50C
82
Model
Description
SNCA-HP5
Camera housing
for SNC-P5
Rating
Operating
temperature
-10 to +50°C
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
Approx.
Dimensions
SNC-P5
N/A
DuPont
Sky White
PFW-510-S9
187 x 238
x 257mm
(wall mounted)
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-CEILING
The SNCA-CEILING is a ceiling mount adapter
with Junction Box and 1½" NPT coupling
Features and Benefits
Dimensions
t Constructed of heavy duty steel
t RoHS compliant
Model
SNCA-CEILING
Description
Applicable/compatible
housing models
Optional accessories
Dimensions
Colour
Ceiling mounting kit
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
SNCA-POLE30
(Ceiling mount adapter)
N/A
Black
SNCA-POLE30
Extension pipe, 305mm (12") long for use with SNCA-CEILING
Features and Benefits
Dimensions
t RoHS compliant
Model
SNCA-POLE30
Description
Applicable/compatible
housing models
Dimensions
Colour
Extension pole for
ceiling mount housings
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
L30cm
Black
83
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-WM20G
The SNCA-WM20G is an aluminum gooseneck wall
mount bracket for use with all dome enclosures,
Features and Benefits
Dimensions
t RoHS compliant
THREADS
Model
SNCA-WM20G
Description
Gooseneck wall mount
Applicable/compatible
housing models
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
SNCA-HRZ25
SNC-RS/RH Series
Optional accessories
Colour
SNCA-PM3
(Pole mount adaptor)
SNCA-CA2 (Corner adaptor)
SNCA-POWERBOX
DuPont
Sky White
PFW-510-S9
SNCA-WM20FC
The SNCA-WM20FC is an aluminum gooseneck wall mount
bracket with fixed coupling for use with all dome enclosures.
Features and Benefits
Dimensions
t RoHS compliant
Weld all around
water tight
0.25" Dia Pilot Hole
Do not go through
wall
84
Model
Description
SNCA-WM20FC
Wall mounted bracket with
fixed coupling
Applicable/compatible
housing models
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
SNC-RS/RH Series
Elliptical cutout
should match the
inside diameter at
the angle created
on this plane
Optional accessories
Colour
SNCA-PM3
(Pole mount adaptor)
SNCA-CA2 (Corner adaptor)
SNCA-POWERBOX
DuPont
Sky White
PFW-510-S9
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-WM30G
The SNCA-WM30G is a roof top parapet bracket designed to
mount the camera dome out & away from the roof top for
an unobstucted view. It features a 1½" pipe thread to mount
to any Sony dome. The design allows the dome to be swung
back over the roof for servicing.
Features and Benefits
Dimensions
t All aluminum construction
Access plug for
installation and
servicing
t Durable powder coat finish
t 1½" pipe thread for quick and easy mounting
1 1/2" NPT PIPE
THREADS
t 50 lb load rating
Incoming wiring
Applicable/compatible
housing models
Model
Description
SNCA-WM30G
Gooseneck wall mount
Optional accessories
Wiring going to
the camera
Dimensions
Colour
SNCA-WM40
Heavy-duty wall mount with removable panel. Durable
off-white polyurethane powder coat finish for corrosion
resistance in outdoor use.
Features and Benefits
Dimensions
t Heavy duty wall mount for use with all Sony domes
Model
Description
SNCA-WM40
Extended wall mount
bracket
Applicable/compatible
housing models
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
Optional
accessories
Dimensions
Colour
SNCA-PM3
(Pole mount adapter)
SNCA-CA2 (Corner
adapter)
L53cm
DuPont
Sky White
PFW-510-S9
85
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-CAFIX1 SNCA-PMFIX1
SNCA-WMFIX10PC
This is a Corner mount fixing for the
Housings and wall brackets to fit to.
A Camera Bracket for indoor usage, it is 14cm
long and has an adjustment that allows for Wall
or Ceiling mounting.
This pole mount adaptor allows the Housing
range with Brackets to be attached to a pole
of Diameter between 65mm and 110mm.
Model
Description
SNCA-CAFIX1
Corner mount adapter
SNCA-PMFIX1
Pole mount adapter
SNCA-WMFIX10PC
Wall/ceiling camera bracket
Applicable/compatible
housing models
Optional accessories
Dimensions
N/A
L22cm
N/A
L17.27cm
N/A
H14.1cm
SNCA-HFIXSML/24
SNCA-HFIXSML/230
SNCA-HFIXSTD/24
SNCA-HFIXSTD/230
SNCA-HFIXSML/24
SNCA-HFIXSML/230
SNCA-HFIXSTD/24
SNCA-HFIXSTD/230
SNC-CS10
SNC-CS11
SNC-CS20
SNC-CS50P
SNC-CM120
SNC-Z20P
Colour
SNCA-CA2
The SNCA-CA2 is an aluminum corner mount bracket with female inserts,
which can accommodate the SNCA-WM20G, SNCA-WM20FC and SNCA-WM40
SNCA-PM3
The SNCA-PM3 is an aluminum pole mount adapter.
Features and Benefits
Dimensions
SNCA-CA2
t RoHS compliant
SNCA-PM3
THREADED INSERTS
THREADED
INSERTS
86
Applicable/compatible
housing models
Model
Description
SNCA-CA2
Corner mount bracket,
22Kg max load rating
SNCA-WM20G
SNCA-WM40
SNCA-WMMD1
SNCA-WMMD2
SNCA-WM20FC
SNCA-WMMD4
SNCA-PM3
Pole mount
adaptor bracket
SNCA-WM20G
SNCA-WM40
SNCA-WMMD1
SNCA-WMMD2
Optional accessories
Colour
DuPont
Sky White
PFW-510-S9
SNCA-PM3
SNCA-CA2
White
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-WMMD1
The SNCA-WMMD1 is a cast aluminum mini dome bracket kit that bolts
directly the SSC-CD73 or SNCDF70 to allow the camera to be wall
or pendant mounted. A 1” NPT pipe thread, aluminum gooseneck
wall mount is included. The wall mount can be combined with the
SNCA-CA2 for corner mount applications and with the SNCA-PM3 for
pole mount applications. The kit includes Teflon thread sealant tape,
gaskets and a sealing grommet for protection outdoors.
Features and Benefits
Dimensions
t Wall mount or pendant mount the SSC-CD73V
or SNCDF70N
t All aluminum construction
t 1” pipe thread for pendant mounting
t Gooseneck bracket for wall mounting
t Outdoor or indoor use
Model
Description
Applicable/compatible
housing models
Optional accessories
SNCA-WMMD1
Wall mounted mini dome
bracket DF70/CD73
SNC-DF70
SSC-CD73
SNCA-PM3
(Pole mount adapter)
SNCA-CA2 (Corner adapter)
Dimensions
Colour
DuPont
Sky White
PFW-510-S9
SNCA-WMMD2
The SNCA-WMMD2 is a cast aluminum mini dome bracket kit that bolts
directly the SNC-DF80, SNC-DF85, SNC-CD75 and SNC-CD77 cameras
to allow for wall or pendant mounting. A 1” NPT pipe thread, aluminum
gooseneck wall mount is included. The wall mount can be combined
with the SNCA-CA2 for corner mount applications and with the SNCA-PM3
for pole mount applications. The kit includes Teflon thread sealant tape,
gaskets and a sealing grommet for protection outdoors.
Features and Benefits
Dimensions
t Wall mount or pendant mount the SNCDF80N
t All aluminum construction
t 1” pipe thread for pendant mounting
t Gooseneck bracket for wall mounting
t Indoor or outdoor use
THREAD
ASSEMBLED
Model
Description
Applicable/compatible
housing models
Optional accessories
SNCA-WMMD2
Wall mounted mini dome
bracket DF80/CD75/77
SNC-DF80P
SNC-DF85P
SNC-CD75P
SNC-CD77P
SNCA-PM3
(Pole mount adapter)
SNCA-CA2 (Corner adapter)
Dimensions
Colour
DuPont
Sky White
PFW-510-S9
87
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
SNCA-WMMD3
The SNCA-WMMD2 is a cast aluminum mini dome bracket kit that
bolts directly the SNC-DM160 and SNC-DS60 cameras to allow
for wall or pendant mounting. A 1” NPT pipe thread, aluminum
gooseneck wall mount is included. The wall mount can be
combined with the SNCA-CA2 for corner mount applications and
with the SNCA-PM3 for pole mount applications. The kit includes
Teflon thread sealant tape, gaskets and a sealing grommet for
protection outdoors.
Features and Benefits
Dimensions
t Wall mount or pendant mount the SNC-DM160 & SNC-DS60
t All aluminum construction
t 1” pipe thread for pendant mounting
t Gooseneck bracket for wall mounting
t Indoor or outdoor use
THREAD
ASSEMBLED
Model
Description
Applicable/compatible
housing models
Optional accessories
SNCA-WMMD3
Mini dome mounting kit,
can be used internally or
externally. Includes bracket
and seal kit
SNC-DM160
SNC-DS60
DuPont Sky White PFW-510-S9
Dimensions
Colour
DuPont
Sky White PFW-510-S9
SNCA-WMMD4
The SNCA-WMMD4 is a mini-dome bracket kit that bolts the
cameras directly to the wall.
Model
SNCA-WMMD4
88
Description
Applicable/compatible
housing models
Optional accessories
Wall mounted bracket
SNC-DH140/DH240,
SNC-DH120/DH220
SNC-DS10/DM110
SNC-DF50
SNC-RH124
SNC-RS44/RS46
N/A
Dimensions
Colour
VIDEO SECURITY
ACCESSORIES - MOUNTING HARDWARE
Description
Applicable/
compatible housing
models
Optional
accessories
Dimensions
Colour
In Ceiling Bracket
SNC-RS46N
SNC-RS44N
SNC-RS44P
SNC-RS46P
SNC-RH124
YT-LD124
L226 x H152
x W270 mm
N/A
In Ceiling bracket
SNC-DH140
SSC-CD45
SSC-CD45P
SSC-CD49
SSC-CD49P
SNC-DF50N
SNC-DF50P
SNC-DS10
SNC-DM110
White
YT-ICB45
In ceiling bracket
SSC-CD45P
SSC-CD49P
SSC-CD75P
SSC-CD77P
SSC-CD79P
SNC-DF50P
SNC-DF80P
SNC-DF85P
SNC-DS10
SNC-DM110
SNC-DS60
SNC-DM160
White
YT-ICB73V
In ceiling bracket for
Ssc-cd73vp
SSC-CD73VP
Silver
YT-LD124C
Clear
Dome Cover
YT-ICB124
Clear
YT-LD124S
Tinted
Dome Cover
YT-ICB124
Tinted
YT-ICB550/T
Tinted in-ceiling bracket
for SNC-RX550P
SNC-RX550P
Tinted
YT-ICB550/C
Clear in-ceiling bracket
for SNC-RX550P
SNC-RX550P
Clear
Model
YT-ICB124
YT-ICB140
89
VIDEO SECURITY
ACCESSORIES - POWER SUPPLIES
SNCA-POWERBOX
The SNCA-POWERBOX is a rugged, outdoor NEMA rated, cast
aluminum power supply with 220/115Vac input converting
to 24Vac and 96w output power. Pole mounting clips
included.
Features and Benefits
Dimensions
t Rugged cast aluminum NEMA 4 enclosure
t Meets IP 66 standards to prevent the induction
of minute particles
t Designed for direct conduit connections
t The SNCA-WM20G and SNCA-WM20FC mount directly
to the door for simple installation and a clean look
t Provides 4 amps of power at 24Vac
t Pole mounting clips included
Model
Description
Applicable/
compatible
camera models
Key features
Operating voltage
SNCA-POWERBOX
IP66 rated
power supply
with bracket
connetion
SNCA-WM20G
SNCA-WM20FC
SNCA-WM40
SNCA-WMMD1
SNCA-WMMD2
Ideal for powering
24VAC housings and
the cameras
110VAC / 230VAC
(selectable)
Approx. Weight
Approx.
Dimensions
Colour
White
SNCA-POE1
Compact and Cost-Effective 1-Port Power over Ethernet Midspan. Power over
Ethernet (PoE) single port Midspan (PoE injector) offers a compact and cost effective,
fully IEEE 802.3af compliant solution for remote powering of wireless LAN (WLAN)
access points, and other low port density installations. The 3001 PoE Midspan
eliminates the need for external power supply and its associated AC/DC power
cabling, providing a compact, affordable, safe and reliable power solution over
existing Ethernet infrastructure.
Features and Benefits
t Cost-effective power distribution for WLAN access point installations
t Safe powering of standard compliant,as well as Pre-standard
end-terminals
t Investment protection of existing Ethernet switches and cabling
infrastructure
t Saves time and reduces installation costs
t Easy plug-and-play installation
t Several units can be mounted adjacently for powering more
than one Ethernet terminal
t Cleans up low-density wireless LAN deployment and eliminates
the need for multiple one-port PoE solutions
t Supports Gigabit Ethernet data transmission for applications suvh as
Wi-Max access points, Gig IP phones, and IP cameras
Dimensions
Specifications
General
No. of Ports
Data Rates
Power over Ethernet Output
Output Power Voltage
User Port Power
Input Power Requirements
AC Input Current
AC Frequency
48
15.4W min.
AC Input Voltage: 90 to 264 Vac
0.5A @110–220 Vac
47 to 63 Hz
Dimensions
60 mm (W)x 31 mm (H)x 145 mm (L)
Weight
Indicators
1 lbs (450 g)
System Indicator
User Indicator
Connectors
Environmental Conditions
Operating Ambient Temeprature
Operating Humidity
Storage Temperature
Storage Humidity
Operating Altitude
Regulatory Compliance
90
1
3001/AC: 10/100 Mbps
3001G/AC: 10/100/1000 Mbps
Pin Assignment and Polarity: 4/5 (+),7/8 (–)
Electromagnetic Emission &
Immunity
AC Power (Green)
Channel Power (Green)
Shielded RJ–45,EIA 568A and 568B
32° to 104°F (0 to 40°C)
Maximum 90%, non-condensing
–4° to 158°F (–20° to 70°C)
Maximum 93%, Non-condensing
–1000 to 10,000 ft.(–304.8 to 3048 m)
FCC Part 15, Class B with FTP cabling
EN 55022 (CISPR 22)Class B with FTP Cabling
EN 55024 (CISPR 24), VCCI Safety Approval
UL/cUL per EN 60950
GS Mark per EN 60950
VIDEO SECURITY
ACCESSORIES - POWER SUPPLIES
SNCA-HPOE1
The SNCA-HPOE1 is a single port, high-power solution for remote powering
of current and emerging high power applications.Generating
up to 30W, the SNCA-HPOE1 enables remote power for a new range
of applications including 802.11 Access Points, pan-tilt-zoom (PTZ)
cameras and video-phones. It complies to IEEE 802.3at PoE standard
and is backward compatible to IEEE802.3af. It can power both existing
10/100Base-T network devices and emerging wireless 1000Base-T devices
such as Wi-MAX and wireless IEEE 802.11n access points.
Features and Benefits
t Up to 30W of Power on 2-pairs
t IEEE 802.3at Compliant with 2-event classification
t IEEE 802.3af backward compatible
t Compatible With All IEEE 802.3af or Legacy
Cisco-Powered Devices
t Safe: Low Power Devices Receive Only the Power
They Need
t Safe and Reliable Power to WLAN Access Points
t Automatic Detection and Protection of Non–standard
Ethernet Terminals
t Supports 10/100/1000Base-T applications
t Compact Design Fits Easily in WLAN Access Point
Installations
Specifications
General
No. of Ports
Pass Through Data Rates
Power over Ethernet Output
Output Power Voltage
User Port Power
Input Power Requirements
AC Input Current
AC Frequency
Dimensions
Weight
Indicators
System Indicator
User Indicator
Connectors
Environmental Conditions
Operating Ambient Temeprature
Operating Humidity
Storage Temperature
Storage Humidity
Operating Altitude
Reliability
MTBF
Thermal Rating
Warranty
Regulatory Compliance
Electromagnetic Emission &
Immunity
1
10/100/1000 Mbps
Pin Assignment and Polarity, Output 4/5 (+), 7/8 (–)
55Vdc
30Watts
AC Input Voltage: 100 to 240 Vac
0.8A @ 100-240 Vac
50 to 60 Hz
87.9 mm x 51.3 mm x 166 mm, 3.46 in. x 2.0 in. x 6.53 in
.771 lbs (350g)
AC Power (Green)
Channel Power (Green)
Shielded RJ-45, EIA 568A and 568B
14º to 113ºF -(-10 to 45ºC)
Maximum 90%, Non-condensing
32º to 104ºF (0º to 40ºC)
Maximum 95%, Non-condensing
–1000 to 10,000 ft. (–304.8 to 3048 m)
100,000 hrs. @25ºC
27 BTU/Hr (@240VAC)
1-year
IEEE 802.3at, IEEE 802.3af, RoHS Compliant, WEEE Compliant, CE
FCC Part 15, Class B, EN 55022 Class B (Emissions)
EN 55024 (Immunity), VCCI, Safety Approvals: UL/cUL Per EN
60950-1, GS Mark Per EN 60950-1
SNCA-POE6 / SNCA-POE12
The SNCA-POE6 & POE12 offers a cost effective, fully IEEE 802.3af
compliant solution to upgrade existing infrastructure with PoE,
providing a maximum of 15.4 Watts of power through each port and
ensuring safe operation of any standard PoE data terminal. It allows IP
telephones, wireless LAN access points, security network cameras and
IP terminals to receive power, along with data, over standard Ethernet
cables, leaving network infrastructure completely unaltered.
Features and Benefits
t A cost-effective solution to upgrade existing
infrastructure to PoE
t Safe & reliable power over existing Ethernet infrastructure
t Safe solution that Protects network infrastructure
t Scalable 6 & 12 port models for optimized installation
t Fully 802.3af standard compliant
t Cisco and legacy PoE support
Specifications
General
No. of Ports
Pass Through Data Rates
Power over Ethernet Output
Output Power Voltage
User Port Power
Aggregate Power
Input Power Requirements
AC Input Current
AC Frequency
Dimensions
Weight
Indicators
System Indicator
User Indicator
Connectors
Environmental Conditions
Operating Ambient Temeprature
Operating Humidity
Storage Temperature
Storage Humidity
Operating Altitude
Reliability
MTBF
Thermal Rating
Warranty
Regulatory Compliance
Electromagnetic Emission &
Immunity
6 or 12
10/100 Mbps
Pin Assignment and Polarity, 4/5 (+), 7/8 (–)
48Vdc
15.4Watts Max.
up to 200Watts
AC Input Voltage: 90 to 264 Vac
4A @ 110 Vac, 2A @ 240 Vac
50 to 60 Hz
438 mm x 272 mm x 44 mm, 17.3 in. x 17.7 in. x 1.73 in
8.8 lbs (4 kg)
AC Power (Green)
Channel Power (Green)
Shielded RJ-45, EIA 568A and 568B
32º to 104ºF (0 to 40ºC)
Maximum 90%, Non-condensing
–4º to 158ºF (–20º to 70ºC)
Maximum 95%, Non-condensing
–1000 to 10,000 ft. (–304.8 to 3048 m)
100,000 hrs. @25ºC
300 BTU/Hr (@240VAC)
1-year
IEEE 802.3af (PoE), RoHS Compliant WEEE Compliant, CE
FCC Part 15, Class B with FTP cabling
EN 55022 Class B (Emissions)
EN 55024 (Immunity), VCCI
Safety Approvals: UL/cUL Per EN 60950, GS Mark Per EN 60950
91
VIDEO SECURITY
ACCESSORIES - POWER SUPPLIES
SNCA-PS12/1
A 12V DC 500mA in-line power supply that provides a single
regulated DC output. The unit's mains and output leads are wire
ended to allow easy connection to terminal blocks etc. ABS
cased. These power supplies are intended for CCTV use and their
size makes them suitable for mounting inside a camera housing,
space permitting.
Features and Benefits
t 12V DC in-line PSU
t 1 x 500mA output
t Output leads are wire ended
t Suitable for mounting inside camera housings etc.
t ABS cased
t Dimensions are 65 x 115 x 45
Model
SNCA-PS12/1
Description
Applicable/compatible
camera models
SSC-DC83
SSC-DC593
An indoor, in-line
SSC-E473
power supply with
SSC-E453
one output rated at 1 SSC-DC374
Amp, 12VDC
SSC-DC174
SSC-DC193P
SSC-M383
SSC-M183
SSC-CD43VP
SSC-CD73VP
SNC-CS50P
SNC-DF40P
SNC-DF70P
SNC-Z20P
SNC-CS3P
Key features
Current
(Amps)
Voltage
(nominal)
Case
Approx.
Weight
Approx.
Dimensions
WxHxD
Colour
Ideal for powering
12VDC cameras
1A
12V DC
ABS
0.8Kg
70 x 102 x 60
Black
SNCA-PS24/1
A 1 Amp 24V AC in-line power supply. Ideal for powering 24V
AC CCTV cameras and camera housing heaters. The unit has
a black plastic case that can be wall mounted or placed
directly inside the camera housing (space permitting). It is
pre-wired with a Euro mains plug and terminals for connecting
to the output are provided inside the case.
Features and Benefits
t 24V AC in-line PSU
t 1 x 1A output
t Suitable for mounting inside camera housings etc.
t ABS cased
t Dimensions are 68 x 115 x 70mm
Model
SNCA-PS24/1
92
Description
An indoor,
in-line power supply
with one output rated
at 1 Amp,
24VAC, 50Hz
Applicable/compatible
camera models
SSC-DC83
SSC-DC593
SSC-E473
SSC-E453
SSC-DC374
SSC-DC174
SSC-DC193P
SSC-M383
SSC-M183
SSC-CD43VP
SSC-CD73VP
SNC-CS50P
SNC-DF40P
SNC-DF70P
SNC-Z20P
SNC-CS3P
SNC-RX550P
SNC-RZ25P
Key features
Current
(Amps)
Ideal for powering
24VAC cameras
1A
Supply
Output
Voltage
Voltage
(nominal) (nominal)
240V AC
50Hz
24V AC
Case
Approx.
Weight
Approx.
Dimensions
WxHxD
Colour
Plastic
1Kg
68 x 115 x 70
Black
VIDEO SECURITY
ACCESSORIES - POWER SUPPLIES
SNCA-PS24/4
A 4 Amp 24V AC power supply with 1 x 4 Amp fused output. Ideal for powering
24V AC CCTV cameras and camera housing heaters. Steel cased.
SNCA-PS24/4E
A 4 Amp 24V AC power supply with 1 x 4 Amp fused outputs in an IP66 enclosure. Ideal
for powering 24V AC CCTV cameras and camera housing heaters. Grey ABS cased.
Features and Benefits
t Comes with wall mounting kit
t Comes with wall mounting kit
t Individually fused outputs
t Weather proof enclosure
t Individually fused outputs
Model
SNCA-PS24/4
SNCA-PS24/4E
Description
An indoor,
in-line power
supply with
one output rated at
4 Amps,
24VAC, 50Hz
An external,
in-line power
supply with
one output rated at
4 Amps,
24VAC, 50Hz
Model
Applicable/compatible
camera models
Key features
Current
(Amps)
Supply
Output
Voltage
Voltage
(nominal) (nominal)
Case
Approx.
Weight
Approx.
Dimensions
WxHxD
Colour
SNCA-HFIXED
SNCA-HRZ25
SNCA-HRZ30
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/EXT/R
SNCA-HRX550/INT
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/EXT/R
SNCA-HRZ50/INT
Ideal for powering
24VAC cameras
1 x 4A
240V AC
50Hz
24V AC
Metal
2.05Kg
118 x 200 x
70mm
White
SNCA-HFIXED
SNCA-HRZ25
SNCA-HRZ30
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/EXT/R
SNCA-HRX550/INT
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/EXT/R
SNCA-HRZ50/INT
Ideal for powering
24V AC housings
and the cameras
1 x 4A
240V AC
50Hz
24V AC
Grey ABS
2.13Kg
150 x 250 x
100
White
Approx.
Dimensions
Colour
Description
This camera power supply converts 230VAC to
SNCA-PSVTSML24 24VAC to power the camera and fits perfectly
inside the SNCA-HFIXSML/230 Housing.
Applicable/compatible
camera models
Key
features
Operating
voltage
SNCA-HFIXSML/230
Can be
mounted in
housing
230VAC,
50Hz
N/A
SNCA-HFIXSTD/230
Can be
mounted in
housing
230VAC,
50Hz
N/A
SNCA-PSVTSTD24
The OHOVPS2B converts 230VAC to
24VAC and is designed to fit into the
SNCA-HFIXSTD/230
SNCA-POWER/PCB
Red network camera power PCB with
12vdc output for all outdoor model dome
enclosures.
YS-W170P
Camera adaptor
(DC power + video/sync)
240V
Camera adaptor
(DC power + video/sync)
240V
Approx.
Weight
Controls the
blower and
heater
YS-W270A
YS-W270P
93
VIDEO SECURITY
ACCESSORIES - LIGHTING
SNCA-IR20
The SNCA-IR20 Infra-Red illuminator is designed to provide dediated
lighting for network cameras via a PoE (Power over Ethernet) enabled
infrastructure. Installation is as simple as plugging in the PoE enabled
network cable. With an in-built photocell plus internal Command and
Control™ electronics the SNCA-IR20 is truly 'plug and play'.
Features and Benefits
Dimensions
t Operates from PoE
t In Built Photocell
t Command and Control™ technology
t 24/7 Illumination
t 20m range
t 30° spread
Model
Description
Key features
Operating Voltage
IP Rating
Colour
SNCA-IR20
IR light indoor 20m
20m range, 30° spread
PoE, 12-24V AC/DC
N/A
Black
SNCA-IR20/OUTDR
The SNCA-IR20/OUTDR Infra-Red illuminator is designed to work
in conjunction with B&W or Day and Night Cameras for short
range applications, includes PSU with photcell.
Features and Benefits
Dimensions
t Surface Mount LED Technology
t Active LED Life Control
t Vandal Resistant
t Low Running Cost
t 5 Year Warranty
t 20m range
t 30° spread
94
Model
Description
Key features
Operating Voltage
IP Rating
Colour
SNCA-IR20/OUTDR
IR light outdoor 20m
20m range, 30° spread
110-230V AC
IP66
Black
VIDEO SECURITY
ACCESSORIES - LIGHTING
SNCA-IR40/OUTDR
The SNCA-IR40/OUTDR Infra-Red illuminator is designed to
work in conjunction with B&W or Day and Night Cameras for
short - medium distance applications. Adaptive Illumination™
allows for the onsite adjustment of beam patterns from 30-60°,
includes PSU with photocell.
Features and Benefits
Dimensions
t Adaptive Illumination™
t Surface Mount LED Technology
t Active LED Life Control
t Vandal Resistant
t Low Running Cost
t 5 Year Warranty
t 40m range
t 30-60° spread
Model
Description
Key features
Operating Voltage
IP Rating
Colour
SNCA-IR40/OUTDR
IR light outdoor 40m
40m range
110-230V AC
IP66
Black
Operating Voltage
IP Rating
Colour
110-230V AC
IP66
Black
SNCA-IR80/OUTDR
The SNCA-IR80/OUTDR Infra-Red illuminator is designed
specifically to work in conjunction with B&W or Day and Night
Dome Cameras. Ultimate Adaptive Illumination™ allows
for the onsite adjustment of beam patterns from 50-180°
achieving 360° with only 2 units. Includes PSU with photocell.
Features and Benefits
Dimensions
t Adaptive Illumination™
t Surface Mount LED Technology
t Active LED Life Control
t Vandal Resistant
t Low Running Cost
t 5 Year Warranty
t max 100m range
t 50-180° spread
Model
Description
SNCA-IR80/OUTDR
IR light for PTZ
Key features
95
VIDEO SECURITY
ACCESSORIES - LIGHTING
SNCA-WL15/OUTDR
The SNCA-WL15/OUTDR illuminator is designed to work in conjunction
with colour CCTV systems providing a visible White-Light with accurate
colour representation for the CCTV camera, includes PSU with
photocell.
Features and Benefits
Dimensions
t Acurate Colour Representation
t Surface Mount LED Technology
t Active LED Life Control
t Vandal Resistant
t Low Running Cost
t 5 Year Warranty
t 20m range
t 30° spread
Model
Description
Key features
Operating Voltage
IP Rating
Colour
SNCA-WL15/OUTDR
White light outdoor 15m
15m range
110-230V AC
IP66
Silver
VIDEO SECURITY
ACCESSORIES - NETWORK CONNECTIVITY
Network and Connectivity
96
Applicable/compatible
Key features
Operating
Temperature
IP Rating
SNCA-CFW1
SNCA-CFW5
50Ω Impedance
Fixing pole included
-20°C to 60°C
IP66
Wireless CF LAN card
SNC-CS50P
(SNCA-CFADAPT req’d)
SNC-RZ50P
SNC-RX550P
(SNCA-CFADAPT req’d)
SNC-RZ25P
SNC-P5
11Mb/s, 2.4GHz Powered by camera
Built-in antenna External antenna connector
Supports WEP/WPA/WPA2 IEEE-802.1
authentication Wireless diversity mode (TX/RX)
-20°C to 60°C
N/A
SNCA-CFW5
Sim compact flash
(Sony MESH compatible)
SNC-CS50P
(SNCA-CFADAPT req’d)
SNC-RZ50P
SNC-RX550P
(SNCA-CFADAPT req’d)
54Mb/s, 2.4GHz Powered by camera
Built-in antenna External antenna
connector Supports WEP/WPA/WPA2
IEEE-802.1 authentication Wireless diversity
mode (TX)
-20°C to 60°C
N/A
SNCA-CW5
Outdoor Antenna Kit
SNCA-CFW5
SNCA-CFADAPT
CF to PCMCIA adaptor
SNCA-CFW1
SNCA-CFW5
Powered by the
connecting device
-20°C to 60°C
N/A
Model
Description
SNCA-AN1
Wireless Outdoor LAN Antenna
SNCA-CFW1
camera models
VIDEO SECURITY
ACCESSORIES - AUDIO
SCA-M30
The SCA-M30 is a ceiling microphone, designed to work
with Sony Security Network Cameras for indoor use.
Features and Benefits
Specifications
t Compatible with Sony Network Cameras
General
t Clearly picks up sound
Capsule type
Directivity
Electret condenser
Uni-directional
t Strong structure against external vibration
Frequency response
Sensitivity (at 1 kHz)
-40dB*1 ±3.5dB
t Easy installation
Signal-to-noise ratio
60dB and more (IEC179 A weighted, 1KHz, 1Pa)
t Input sensitivity can be selected
Current consumption
Power supply
Output connector
Dimensions
Connector cable length
Dimensions
Mass
Supplied accessories
300 Hz to 10kHz
Plug in Power DC 1.5 V - 9 V
0.5mA and less
φ3.5mm mini-plug (3poles)
Tip-Ring short connected
Approx.300 cm
φ126 X 55 mm
Approx. 146g (Not included cable)
Approx. 225g with Bracket (Not included cable)
Bracket(1), +BV 4 x 20(2), +K 2.6 x 20(3), Operating
instruction(1), Warranty booklet(1)
Applicable/compatible models
SNC-DH180, SNC-RS84P, SNC-DH140, SNC-RS84N, SNC-RH164,
SNC-CH140, SNC-RS44N, SNC-RS44P, SNC-RS46N, SNC-RS46P,
SNC-RH124
SCA-S30
The SCA-S30 is a highly durable speaker for outdoor
environments. It is designed to work with Sony Network
cameras and can generate loud sound by it's high
efficiency digital amplifier.
Features and Benefits
Specifications
t Built-in high efficiency digital amplifier
General
t Seamless integration with Sony Network Cameras.
Frequency response
Reference input level (at 1 kHz)
t Reliable and durable in outdoor environments.
Output
t Easy Installation (wall/pole fixing)
Input impedance
Maximum Output
Distortion
Signal to Noise ratio
Power supply
Power consumption
Dimensions
Dimensions
Mass
Operating temperature
Storage temperature
Supplied accessories
100 Hz to 15,000Hz (at 5W output power)
-10dBu (0dBu = 0.775Vrms)
30W and more (AC24V, 1kHz -10dBu input)
35W and more (AC24V, 1kHz input)
20kohm +/-20% (at 1kHz)
Less than 1% (AC24V, 30W output at 1kHz)
80dB and more (IEC179A weighted, 30W,1kHz)
AC24 V +/- 10% 50Hz/60Hz
8W (AC24V, 1/8 output power)
φ150 x 245mm (included mount frame)
Approx. 2.4kg (included mount frame)
0°C to 50°C
-20°C to +60°C
Wire rope (1), +M4 x 16(1), Operating instruction(1),
Warranty booklet(1)
Applicable/compatible models
SNC-DH180, SNC-DH140, SNC-RS84P, SNC-RS84N, SNC-RH164,
SNC-CH140, SNC-RS44N, SNC-RS44P, SNC-RS46N, SNC-RS46P,
SNC-RH124
97
VIDEO SECURITY
ACCESSORIES - MISC
SNCA-JOYSTICK1
The IP Desktop USB joystick provides security professionals
with intuitive P/T/Z camera control for network video
surveillance applications. Featuring a three axis Hall
effect joystick, twelve programmable pushbutton switches
and USB interface, the IP Desktop integrates seamlessly
with any software application recognizing joystick inputs
via Microsoft's DirectX.
Features and Benefits
Dimensions
tThree axes joystick for P/T/Z control
tProgrammable pushbuttons
tUSB 1.1 HID compliant “game controller” device
tEasy to use and operate
98
Model
Centering
Housing
HFX Series I,
Model 1400
Option 5
Single spring,
omnidirectional
High impact,
glass-filled
nylon
Breakout Operation Maximum Operating
Life cycles
force
force
force
temperature
.109Nm
.151Nm
.169Nm
-40°C to +85°C
10,000,000
Supply
voltage
(USB bus)
Vdd = 5V
± .5V
Supply
Approx. Dimensions
current
WxLxH
(USB bus)
32mA
15.6 x 16.9 x 12.6 cm
(6.15" x 6.65" x 4.97")
Colour
N/A
SNCA-HEATER
SNCA-CONNECTOR/PCB YT-HU75
The SNCA-HEATER is a 24Vac Cold Weather Kit for
an additional heater and blower. It is designed
for outdoor dome housings in extremely cold
weather. Extends the low temperature operating
conditions by approx. 15°C
Green control PCB board.
Model
Description
SNCA-HEATER
Heater blower kit
SNCA-CONNECTOR/
PCB
PC board
YT-HU75
Heater unit
Key features
Controls the blower
and heater
For outdoor
models only
Replacement part
Operating
temperature
Operating
voltage
Applicable Camera Models
Optional
accessories
Colour
Approx.
Dimensions
Extends lower operating
temperature of housing/
device by 15°C
24V, 25W
SNCA-HRX550/EXT
SNCA-HRX550EXT/W
N/A
N/A
N/A
SNCA-HRX550/EXT
SNCA-HRZ50/EXT/W
SNCA-HRX550/EXT/W
SNCA-HRZ50/EXT/R
SNCA-HRX550/EXT/R
SNCA-HRZ25
SNCA-HRX550/EXT/PRE
SNCA-HRZ30
SNCA-HRZ50/EXT
VIDEO SECURITY
ACCESSORIES - MISC
SNCA-TINTED
Tinted Replacement capsule for SNCA-HRZ25 & SNCA-HRZ30
SNCA-TINTED/2
Tinted replacement capsule for Sony 7" dome housings.
Features and Benefits
SNCA-TINTED
SNCA-TINTED/2
t Acrylic construction
t Polycarbonate construction
Model
Description
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
Approx.
Dimensions
SNCA-TINTED
Tinted dome
N/A
N/A
N/A
SNCA-HRZ25
SNCA-HRZ30
N/A
Tinted
8" (20.32cm)
Diameter
N/A
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
N/A
Tinted
7" (17.78cm)
Diameter
SNCA-TINTED/2
Tinted dome,
new 7" version
N/A
N/A
SNCA-CLEAR
Clear replacement capsule for SNCA-HRZ25 & SNCA-HRZ30
SNCA-CLEAR/2
Clear replacement capsule for Sony 7" dome housings.
Features and Benefits
SNCA-CLEAR
SNCA-CLEAR/2
t Acrylic construction
t Polycarbonate construction
Model
Description
Rating
Operating
temperature
Operating
voltage
Applicable
Camera Models
Optional
accessories
Colour
Approx.
Dimensions
SNCA-CLEAR
Clear dome
N/A
N/A
N/A
SNCA-HRZ25
SNCA-HRZ30
N/A
Clear
8" (20.32cm)
Diameter
N/A
SNCA-HRX550/EXT
SNCA-HRX550/EXT/W
SNCA-HRX550/INT
SNCA-HRX550/EXT/R
SNCA-HRX550/EXT/PRE
SNCA-HRZ50/EXT
SNCA-HRZ50/EXT/W
SNCA-HRZ50/INT
SNCA-HRZ50/EXT/R
N/A
Clear
7" (17.78cm)
Diameter
SNCA-CLEAR/2
Clear dome,
new 7" version
N/A
N/A
99
VIDEO SECURITY
ACCESSORIES
Compatibility Tables
Guide on which camera's fit into each housing
and which housings fit with which brackets.
Cameras, Housings & Bracket Table
89
YT-ICB124
89
YT-ICB140
89
YT-ICB550/T
89
YT-ICB550/C
89
SNCA-ICPTZ/C
82
SNCA-ICPTZ/T
82
SNCA-WMFIX10PC
86
SNCA-WMMD2
87
SNCA-WMMD3
88
SNCA-WMMD4
88
SNC-CS11
SNC-CS20
SNC-CS50
SNC-CM120
SNC-CH140
SNC-CH180
SNC-CH210
SNC-CH240
SNC-DS10
SNC-DS60
SNC-DF50
SNC-DF80
SNC-DF85
SNC-DM110
SNC-DM160
SNC-DH140
SNC-DH180
SNC-DH240
SNC-P5
SNC-RZ25
SNC-RZ50
SNC-RX530
SNC-RX550
SNC-RX570
SNC-RH124
SNC-RS44
SNC-RS46
SNC-RH164
SNC-RS84
SNC-RS86
Page No
IP PTZ CAMERAS
SNC-CS10
In-Ceiling Mount Bracket
YT-ICB45
IP MINI-DOME CAMERAS
SNC-P1
IP FIXED CAMERAS
24
25
26
27
29
28
30
31
33
32
34
37
36
39
40
35
38
41
42
43
44
45
46
47
48
49
50
52
53
51
54
55
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Outdoor Housing
SNCA-HP5
82
SNCA-HRZ25
77
SNCA-HRZ50/EXT
78
SNCA-HRZ50/EXT/R
78
SNCA-HRZ50/EXT/W
79
SNCA-HRZ50/INT
79
SNCA-HRX550/EXT
75
SNCA-RX550EXT12V
77
SNCA-HRX550EXT/R
76
SNCA-HRX550EXT/W
76
SNCA-HRX550/INT
75
SNCA-HFIXSTD/230
81
SNCA-HFIXSTD/24
81
SNCA-HFIXSML/24
80
SNCA-HFIXSML/230
80
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Power Supplies & Misc
SNCA-PS12/1
92
SNCA-PS24/1
92
SNCA-PS24/4
93
SNCA-PS24/4E
93
SNCA-POE1
90
SNCA-HPOE1
91
SNCA-POE6
91
SNCA-POE12
91
SNCA-CFW1
96
SNCA-CFW5
96
SNCA-CFADAPT
96
YT-HU75
98
100
100
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Housing & accessory table
SNCA-HRX550/INT
SNCA-HFIXSTD/230
SNCA-HFIXSTD/24
SNC-RH164
SNC-RS84
75
77
76
76
75
81
81
51
54
t
t
t
t
t
t
t
t
t
SNCA-POLE30
83
SNCA-WM20G
84
SNCA-WM20FC
84
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
85
t
t
t
t
t
t
t
t
SNCA-WM30G
t
t
t
t
t
SNCA-WM40
85
SNCA-CAFIX1
86
SNCA-PMFIX1
86
SNCA-WMMD1
87
SNCA-WMMD2
87
SNCA-WMMD3
88
SNCA-WMMD4
88
YT-LD124C
89
YT-LD124S
89
t
t
t
SCA-S30
SNCA-HRX550EXT/W
79
t
SNCA-POWERBOX
SNCA-HRX550EXT/R
79
t
SNCA-WM20FC
SNCA-RX550EXT12V
78
t
SNCA-WM20G
SNCA-HRX550/EXT
78
t
SNCA-CA2
SNCA-HRZ50/INT
77
83
Mount Bracket
AUDIO
SNCA-PM3
SNCA-HRZ50/EXT/W
Page No
SNCA-CEILING (must be
used with POLE30)
POWER
SNC-RS86
SNCA-HRZ50/EXT/R
BRACKETS
SNCA-HRZ50/EXT
PTZ CAMERAS
SNCA-HRZ25
CAMERA HOUSINGS
55
86
86
84
84
90
97
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Power Supply
SNCA-PS24/4E
93
SNCA-PS24/4
93
SNCA-POWERBOX
90
SNCA-PSVTSTD24
93
SNCA-PSVTSML24
93
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Wireless, others
SNCA-AN1
96
SNCA-CFW5
96
SNCA-HEATER
98
SNCA-TINTED
99
SNCA-TINTED/2
99
SNCA-CLEAR
99
SNCA-CLEAR/2
99
SNCA-POWER/PCB
93
SNCA-CONNECTOR/PCB
98
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
101
101
VIDEO SECURITY
ACCESSORIES
Index
A comprehensive range of indoor, outdoor and specialist housings
to compliment the SONY range of camera products.
Key Features
View-DR
IP Mini-dome Cameras
4
SNC-DS10
Infrared Illuminator (IR)
5
SNC-DM110
35
IPELA - harnessing the power of IP.
6
SNC-DF50P
36
DEPA - making intelligence work harder.
7
SNC-DS60
37
Exwave PRO™ - enhanced image performance.
8
SNC-DM160
38
Megapixel technology for true versatility.
9
SNC-DF80P
39
Light Funnel technology for increased sensitivity.
10
SNC-DF85P
40
DynaView™ technology delivers a wider range.
11
SNC-DH140 & SNC-DH140T
41
Dynamic France Integration - exceptional picture quality.
12
SNC-DH180
42
Dual encoding - ideal for fixed and moving images.
13
SNC-DH240 & SNC-DH240T
43
H.264 - the latest industry standard … as standard.
14
Intelligent Motion Detection driving actions directly from the camera.
15
IP66 - Vandal Resisistent cameras for tough applications.
16
Analogue Video Output - for fast installtion and set-up.
17
HD for your security cameras.
18
eXcellent Dynamic Noise Reduction (XDNR)
19
Distributed Enhanced Processing Architecture
(DEPA) Advanced.
20
Visibility Enhancer (VE)
21
Open Network Video Interface Forum (ONVIF)
22
IP Fixed Cameras
SNC-P1
SNC-CS10
25
SNC-CS11
26
SNC-CS20
27
SNC-CM120
28
SNC-CS50P
29
SNC-CH140
30
SNC-CH180
31
SNC-CH240
32
SNC-CH210
33
102
102
24
34
IP PTZ Cameras
SNC-P5
44
SNC-RZ25P
45
SNC-RZ50P
46
SNC-RX530
47
SNC-RX550
48
SNC-RX570
49
SNC-RH124
50
SNC-RH164
51
SNC-RS44P
52
SNC-RS46P
53
SNC-RS84P
54
SNC-RS86P
55
CCTV Fixed Cameras
SSC-DC693P & SSC-DC698P
56
SSC-DC80P
57
SSC-DC83P & SSC-DC88P
57
SSC-E413P & SSC-E418P
58
SSC-E433P & SSC-E438P
58
CCTV Fixed Cameras Continued
Accessories Continued
SSC-E473P & SSC-E478P
59
SNCA-HRZ50/EXT/W & SNCA-HRZ50/INT
79
SSC-G923 & SSC-G928
60
SNCA-HFIXSML/230 & SNCA-HFIXSML/24
80
SSC-G813 & SSC-G818
61
SNCA-HFIXSTD/230 & SNCA-HFIXSTD/24
81
SNCA-ICPTZ/C & SNCA-ICPTZ/T
82
SNCA-HP5
82
CCTV Mini-dome Cameras
Mounting Hardware
SNCA-CEILING & SNCA-POLE30
83
SSC-CD13VP
62
SNCA-WM20G & SNCA-WM20FC
84
SSC-CD45P & SSC-CD49P
63
SNCA-WM30G & SNCA-WM40
85
SSC-CD73P & SSC-CD75P
64
SNCA-CAFIX1, SNCA-PMFIX1 & SNCA-WMFIX10PC
86
SSC-CD77P & SSC-CD79P
65
SNCA-CA2 & SNCA-PM3
86
SNCA-WMMD1 & SNCA-WMMD2
87
SNCA-WMMD3 & SNCA-WMMD4
88
Misc Mounting Hardware
89
Encoder
Power Supplies
SNT-EX/EP SERIES
66
Recording Solutions
SNCA-POWERBOX & SNCA-POE1
90
SNCA-HPOE1, SNCA-POE6 & SNCA-POE12
91
SNCA-PS12-1 & SNCA-PS24-1
92
SNCA-PS24-4 & SNCA-PS24-4E
93
Misc Power Supplies
93
IMZ-NS100 SERIES
68
Lighting
NSR-1000 SERIES
70
SNCA-IR20 & SNCA-IR20/OUTDR
94
SNCA-IR40/OUTDR & SNCA-IR80/OUTDR
95
SNCA-WL15/OUTDR
96
Network Connectivity
96
Accessories
Audio
Recording Solutions
SCA-M30 & SCA-S30
97
NSRE-Si8/1, NSRE-Si16/1 & NSRE-SJBOD16/1
72
Misc
NSRE-RM1, NSRE-RM2, NSRE-RM3 & NSRE-SASCABLE
72
SNCA-JOYSTICK1
NSRE-S200 & RM-NS1000
74
SNCA-HEATER
98
SNCA-CONNECTOR/PCB
98
Housings
98
SNCA-HRX550/EXT & SNCA-HRX550/INT
75
YT-HU75
98
SNCA-HRX550EXT/R & SNCA-HRX550EXT/W
76
SNCA-TINTED & SNCA-TINTED/2
99
SNCA-HRX550EXT12V & SNCA-HRZ25
77
SNCA-CLEAR & SNCA-CLEAR/2
SNCA-HRZ50/EXT & SNCA-HRZ50/EXT/R
78
Compatibility Table
99
100
103
103
At Sony Professional we believe images
have immeasurable power
Images nurture life
connect cultures
grow economies
deliver justice
inspire education
energise entertainment
advance science
liberate imagination
capture history
even promote peace
We use the power of images to increase
business value
We turn images into assets
This is Visual Wealth
© 2010 Sony Corporation. All rights reserved. Reproduction in whole or in part without permission is prohibited. Features and specifications are subject to change without notice. All non-metric weights and measurements are
approximate. Sony, make.believe, IPELA, DynaView, Exwave PRO, SuperExwave, Exwave HAD, Super HAD and DEPA are trademarks of Sony Corporation. All other trademarks are the property of their respective owners.
Distributed by
104
About Sony Professional
Sony Professional is the leading supplier of AV/IT solutions to businesses across a wide variety of sectors including, Media and Broadcast, Video
Security and Retail, Transport & Large Venue markets. It delivers products, systems and applications to enable the creation, manipulation and
distribution of digital audio-visual content that add value to businesses and their customers. With over 25 years’ experience in delivering innovative
market-leading products, Sony Professional is ideally placed to deliver exceptional quality and value to its customers. Sony’s Professional Services
division, its systems integration arm, offers its customers access to the expertise and local knowledge of skilled professionals across Europe.
Collaborating with a network of established technology partners, Sony Professional delivers end to end solutions that address the customer’s needs,
integrating software and systems to achieve each organisations’ individual business goals. For more information please visit www.pro.sony.eu
