Large Format Media
Product Information Document
1933B Matt Coated Paper 90 g/m²
Description
This high quality base paper has been developed for high-accuracy inkjet printing
involving the CAD & GIS environment and a lower cost solution for graphic art
reproductions.
The coating on this paper produces brilliant colours and outstanding image contrast,
which allows for use with graphic applications. This is a perfect choice for everyday
color printing.
Features
Fast drying time, dye & pigment ink compatible, excellent colour & image
reproduction, outstanding contrasts, high resolution.
Applications
CAD, GIS, low cost graphics, presentations, desktop publishing
Available widths
Article
number
97003009
97003010
97003011
97003012
Width
(mm)
432
610
914
1067
Length
(m)
45
45
45
45
Order
Multiple
1
1
1
1
Mercury
Code
1933B05AA
1933B05AA
1933B05AA
1933B05AA
Compatibility and profiles
Advised Driver / panel settings: Matte Coated Paper 90 / Matte Coated 90
Refer for Onyx and other profiles to www.mediaguide.oce.com
Select your Canon printer to find matching media and media profiles.
Printing
For optimum results select the best possible print settings. Ink saturation limits can
vary due to the ink drop volume and the environmental humidity. Ink saturation levels
should be optimized for specific printer, ink and software combinations. Too much ink
will cause paper cockle and possible head strike. Longer ink drying times will occur in
higher humidity environments.
Lamination
Hot or cold laminating is possible, although cold laminates are preferred because of
the better adhesion. Images must be dry before laminating. Too much ink can cause
cockling which can cause problems with laminating. For mounting on a board, an
encapsulating edge of 5-6mm around the image is recommended. This prevents
against moisture and paper splitting because of the tension of the laminate. If the
laminate is not spread evenly over the surface of the paper then this can cause curling
problems.
Physical Properties
Weight
96 ± 5 g/m²
Calliper
128 ± 5 microns
Opacity
> 91 %
Whiteness
150 ± 3 CIE
Storage Conditions
Store paper only in original boxes, out of direct sunlight and under normal climatic
conditions ( 23 Deg C, 50% RH ) until ready to use.
Allow material to adapt to room conditions before use. Papers can absorb moisture in
humid conditions or lose moisture in low humidity conditions.
Highly humid conditions make the ink drying time longer and this could interfere with
proper laminate adhesion.
March 2011
Shelf Life
2 years from shipping date when stored under ideal conditions (see above)
March 2011
