2
Brochure
Accessories and peripherals for Samsung products
Samsung quality from start to finish
Samsung provides a variety of accessories to enhance the Samsung SMART Signage experience. Samsung’s control of all processes involved
in creating Samsung SMART Signage accessories and peripherals results in high performance and reliability.
Deep and direct oversight of each manufacturing and quality assurance step at Samsung facilities ensures that Samsung’s lofty internal
standards and requirements are met. And, because Samsung designs accessories and peripherals specifically for each Samsung product,
customers can be assured of high efficiency, simple, easy connectivity, and enhanced content playing and scalability.
3
Brochure
Samsung SMART Signage Stands
"Display easily and more effectively with Samsung stands"
Overview
Available in various designs and height variations, Samsung SMART Signage Stands firmly support the displays on a flat surface. They are
easy to install for convenient set up and serve as swift way to display signage.
A basic stand for simple installation
A reliable, easy-to-set up stand
The STN-L75D stand provides the most basic and simple way of
The STN-L75E, STN-L3240E, STN-L4655E, STN-L6500E come as
standing up the display using a small but solid installation piece. In
two separate stands that can be easily attached to the back of the
addition, the stand can support the use of optional touch overlay with
display using the VESA mount holes. Each stand is designed with
the display.
Y-shaped feet for convenient placement and stability. This stand also
supports the use of an optional display touch overlay.
Figure 2. STN-L75E
Figure 1. STN-L75D
Figure 3. STN-L4655E
4
Brochure
Samsung SMART Signage Stands
"Display easily and more effectively with Samsung stands"
Specifications
L75D
L75E
L3240E
L4655E
L6500E
VESA
compatibility
Not applicable
Not applicable
200 x 200
400 x 400
200 x 200
400 x 400
200 x 200
400 x 400
SBB/PIM
compatibility
Supported
Supported
Supported
Supported
Supported
Touch Overlay
compatibility
Supported
Supported
Supported
Supported
Supported
Landscape only
Landscape only
Landscape
and Portrait
Landscape
and Portrait
Landscape
and Portrait
Installation
orientation
L7585F
Dimension
(mm/in.)
Weight (kg/lb)
Color
PE
40
46
MD
55
40
46
ME
55
65
32
40
46
ED
55
75
40
46
55
DM
65
75
32
75D
75E
3240E
4655E
6500E
7585F
: Landscape/Portrait
: Landscape only
: Portrait only
5
40
48
DB
55
65
75
32
40
DH
48
55
32
40
UD
48
55
46
UE
55
46
QM
55
55
PQ
85
46C
Brochure
Samsung SMART Signage Wall Mounts
"Display to maximum effect on wall mounts"
Overview
Samsung offers two types of wall mounts, categorized by usage: standalone mounts and video wall mounts. Both types can be installed on
flat-surface walls, and are available in various designs. Simple hanging mounts and multi-jointed arm mounts are available, as are specialized
wall mounts that make it easy to access the back of the video wall displays. The wall mounts hold up to four times the weight of supported
display products, and provide secure mounting in either landscape or portrait positions.
A slim, mini wall mount
Wall mounting flexibility and stability
Ultra-slim WMN350M standalone wall mount offers minimal
The WMN-4070SD and WMN-4270SD are standalone-only wall
installation requirements due to its light weight, fixture and
mounts that once fully installed allows for not only variable depth by
configuration. Varying depths can be implemented at the time of
pulling the display in or out but swivel options as well. This enhanced
installation by using included brackets.
flexibility provides the optimal viewing angle on a sturdy wall mount.
Figure 4. WMN350M
Figure 6. WMN-4270SD
A dedicated videowall mount
Versatile wall mount capabilities
Specialized for videowall displays and configurations, WMN-4675MD
The WMN-6575SD and WMN-9500SD are highly versatile wall
wall mount enables easy upkeep by allowing for individual displays to
mounts that provide not only solid support for standalone but video
be replaced or removed for maintenance without having to dismantle
wall configurations. Its slim profile and post-installation cable inset
the entire videowall. It also allows for vertical (front and rear) micro-
capability deliver a clutter-free, ergonomic display area.
adjustments.
Figure 5. WMN-4675MD
Figure 7. WMN-9500SD
6
Brochure
Samsung SMART Signage Wall Mounts
"Display to maximum effect on wall mounts"
Specifications
5770D
4070SD
4270SD
4277S
4675MD
VESA compatibility
600 x 400
400 x 600
800 x 400
400 x 800
200 x 200
400 x 400
400 x 400
400 x 400
600 x 400
400 x 600
SBB/PIM
compatibility
Supported
Not supported
Supported
Supported
Supported
Touch Overlay
compatibility
Supported
Supported
Supported
Supported
Supported
(Landscape only for ED
Series)
Landscape and Portrait
Landscape and Portrait
Landscape and Portrait
Landscape only
Landscape and Portrait
732.4 x 534.5 x 46
(28.8 x 21 x 1.8)
248 x 255 x 30
(9.7 x 10 x 1.1)
465 x 460 x 24.5
(18.3 x 18.1 x 0.9)
465 x 460 x 24.5
(18.3 x 18.1 x 0.9)
533.2 x 538.5 x 43.4
(20.0 x 21.2 x 1.7)
2.4 (5.2)
5.5 (12.1)
5.5 (12.1)
3.2 (7)
46 (1.8)
30 (1.1)
24.5 (0.9)
24.5 (0.9)
43.5 (1.7)
Standalone
Standalone
Standalone
Standalone
Video wall
10 degrees tilt
20 degrees swivel
10 degrees tilt
20 degrees swivel
10 degrees tilt
20 degrees swivel
Installation
orientation
Dimension (mm/in.)
Weight (kg/lb)
Minimum wall
thickness (mm/in.)
Recommended
Usage
Maintainability
Tilt/Swivel
Lift and pull to remove
Not supported
Not supported
450M
6575SD
9500SD
22UDPD
VESA compatibility
200 x 200
400 x 400
400 x 400
900 x 600
300 x 300
SBB/PIM
compatibility
Supported
Supported
Supported
Supported
Touch Overlay
compatibility
Supported
Supported
Not supported
Not applicable
Installation
orientation
Landscape and Portrait
Landscape and Portrait
Landscape and Portrait
Landscape and Portrait
Dimension (mm / in.)
Only depth:
17 (ultra slim option)
40 (w/ adjustable BRKT)
564 x 580 x 100
(22.2 x 22.8 x 3.9)
1,064 x 1,080 x 28
(41.8 x 42.5 x 1.1)
394 x 394 x 95
(15.5 x 15.5 x 3.7)
3.2 (7)
5 (11)
3.2 (7)
WMN Weight (kg/lb)
Minimum wall
thickness (mm)
15 (0.5)
100 (3.9)
28 (1.1)
95 (3.7)
Recommended
Usage
Standalone
Standalone & Video wall
Standalone & Video wall
Video wall
Maintainability
Tilt/Swivel
Push-to-popup mechanism
Not applicable
Not applicable
7
Not applicable
Not applicable
Brochure
Samsung SMART Signage Wall Mounts
"Display to maximum effect on wall mounts"
Specifications
PE
40
46
MD
55
32
40
46
ME
55
65
32
40
1
1
46
ED
55
75
95C
32
40
46
HD
55
65
75
2
2
32
40
46
55
5570D
4070SD
1
4270SD
/
1
1
1
4277S
4675MD
2000AD
2000BD
450M
2
6575SD
1
9500SD
DM
32
40
DB
48
55
3
3
65
75
32
40
DH
48
55
3
3
40
UD
48
55
3
3
5570D
4070SD
4270SD
4277S
4675MD
2000AD
2000BD
450M
6575SD
2
3
9500SD
1
: Landscape/Portrait
: Landscape only
: Portrait only
Compatible with CY-TM, 2 Compatible with CY-TE, 3 Compatible with CY-TD
8
46
UE
55
46
QM
55
55
85D
SL
PQ
46B
46C
