Canon C7010VPS/C6010VPS/C6010S Owner's Manual

-
Perfect Binder-B1
User's Guide
Please read this guide before operating this product.
After you finish reading this guide, store it in a safe place for future reference.
Copyright
Copyright 2011 by Canon Inc. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying and recording, or by any information
storage or retrieval system without the prior written permission of Canon Inc.
© 2011, Océ
All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted
in any form or by any means without written permission from Océ.
Océ makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
Furthermore, Océ reserves the right to revise this publication and to make changes from
time to time in the content hereof without obligation to notify any person of such revision
or changes.
Edition: 07-2011
Contents
Contents
Chapter 1
Introduction.........................................................................................................5
Introduction.................................................................................................6
How to use this manual.............................................................................7
Notes for the reader.............................................................................7
Trademarks...........................................................................................9
Legal notices.............................................................................................10
Important safety instructions..................................................................11
Introduction.........................................................................................11
Installation precautions......................................................................12
Main power.........................................................................................15
Handling..............................................................................................16
Maintenance / Inspections.................................................................18
Consumables......................................................................................19
Other warnings...................................................................................20
Periodic test of the breaker......................................................................21
How to check the breaker..................................................................21
Check sheet for periodic testing of the Perfect Binder-B1..............23
Chapter 2
Before you start using this machine...............................................................25
Parts and their functions..........................................................................26
Exterior view.......................................................................................26
Outline of the binder's mechanisms.................................................28
Outline of bookbinding procedure....................................................30
Sheet inserter......................................................................................32
Main power...............................................................................................33
How to turn the main power on........................................................33
How to turn the main power off........................................................34
Energy saver and energy save mode...............................................35
Chapter 3
Basic operations................................................................................................37
Make a perfect-bound book.....................................................................38
Paper and finished sizes..........................................................................39
Types of paper that can be used.......................................................39
Finished sizes of booklets..................................................................42
Load paper into the sheet inserter..........................................................45
Remove finished booklets.......................................................................49
Discard cuttings........................................................................................52
3
Contents
Replenish glue..........................................................................................54
Clean the binder.......................................................................................57
Chapter 4
Troubleshooting................................................................................................59
Job cannot be perfect-bound error scenario.........................................60
Clearing paper jams.................................................................................61
Clear a paper jam inside the top cover.............................................61
Clear a paper jam inside the front cover..........................................65
Clear a paper jam in the stacker........................................................71
Clear a paper jam in the sheet inserter.............................................73
Check the status of the trimmer waste unit...........................................78
Check the status of the glue....................................................................79
Adjust cover position...............................................................................80
Adjust glue amount..................................................................................81
Alarm list...................................................................................................83
Reduce frequent paper jams or errors...................................................84
Power does not turn on...........................................................................86
When the main power is turned off during operations (check the stacker)...............................................................................................................87
Chapter 5
Appendix............................................................................................................89
Specifications............................................................................................90
Glossary....................................................................................................93
4
Chapter 1
Introduction
Introduction
Introduction
Thank you for purchasing the Perfect Binder-B1.
Please read this manual thoroughly before operating the machine in order to familiarize
yourself with its capabilities and to make the most of its many functions. After reading
this manual, store it in a safe place for future reference.
This manual describes the basic operations of this binder. For information regarding
printer settings refer to the manual for the printer.
Also you may not be able to set or use some of the types and functions of booklets and
paper described in this manual if the printer does not support them.
6
Chapter 1 - Introduction
Notes for the reader
How to use this manual
Notes for the reader
Introduction
This manual helps you to use the Perfect Binder-B1. The manual contains a description
of the product and guidelines to use and operate the Perfect Binder-B1.
Definition
Attention-Getters
Parts of this manual require your special attention. These parts can provide the following:
• Additional general information, for example, information that is useful when you
perform a task.
• Information to prevent personal injuries or property damage.
Symbols used in this manual
The following symbols are used in this manual to explain procedures, restrictions, handling
precautions, and instructions that should be observed for safety.
Overview of the attention-getters#
Word
Icon
Indicates
WARNING
Indicates a warning concerning operations
that may lead to death or injury to persons if
not performed correctly. To use the machine
safely, always pay attention to these warnings.
CAUTION
Indicates a caution concerning operations that
may lead to injury to persons if not performed
correctly. To use the machine safely, always
pay attention to these cautions.
IMPORTANT
Indicates operational requirements and restrictions. Be sure to read these items carefully to
operate the machine correctly and to avoid
damaging the machine or property.
NOTE
Indicates a clarification of an operation or
contains additional explanations for a procedure. Reading these notes is highly recommended.
Chapter 1 - Introduction
7
Notes for the reader
Word
Icon
Indicates
Indicates an operation that must not be performed. Read these items carefully and make
sure not to perform the described operations.
8
Chapter 1 - Introduction
Trademarks
Trademarks
List of trademarks
• Canon and the Canon logo are trademarks of Canon Inc.
• Other product and company names herein may be trademarks of their respective
owners.
Chapter 1 - Introduction
9
Legal notices
Legal notices
Product name
Safety regulations require the product's name to be registered.
In some regions where this product is sold, the following name(s) in ( ) may be registered
instead.
Perfect Binder-B1 (F270300)
FCC (Federal Communications Commission)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate, radio frequency
energy and, if not installed and used in accordance with the Operator's Manual, may
cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Use of shielded cables is required to comply with Class A limits in Subpart B of Part 15
of the FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified
in the manual. If you make such changes or modifications, you could be required to stop
operation of the equipment.
If your equipment malfunctions, please contact your local authorized dealer from whom
you purchased the equipment (if under warranty), or with whom you have a servicing
contract. if you are not sure who to contact, and have both purchased and are using the
equipment in the U.S.A., please refer to the "SUPPORT" page on Canon U.S.A.'s Web
site (http://www.usa.canon.com).
10
Chapter 1 - Introduction
Introduction
Important safety instructions
Introduction
Please read these "Important safety instructions" thoroughly before operating the machine.
As these instructions are intended to prevent injury to the user or other persons or destruction of property, always pay attention to them. Also, since it may result in unexpected
accidents or injuries, do not perform any operation unless otherwise specified in the
manual. Improper operation or use of this machine could result in personal injury and/or
damage requiring extensive repair that may not be covered under your Limited Warranty.
Chapter 1 - Introduction
11
Installation precautions
Installation precautions
#
WARNING
• Do not install the machine near alcohol, paint thinner, or other flammable
substances. If flammable substances come into contact with electrical parts
inside the machine, it may result in a fire or electrical shock.
• Do not place the following items on the machine. If these items come into
contact with high-voltage areas inside the machine, it may result in a fire or
electrical shock. If these items are dropped or spoilt into the machine, immediately turn OFF the main power switch, and disconnect the power cord from
the power outlet according to the instruction in ‘How to turn the main power
off’ on page 34 . Then contact your local retailer where you purchased the
machine or an authorized dealer.
- Necklaces and other metal objects.
- Cups, vases, flowerpots, and other containers filled with water or liquids.
12
Chapter 1 - Introduction
Installation precautions
#
CAUTION
• Do not install the machine in unstable locations, such as unsteady platforms
•
•
•
•
or inclined floors, or in locations subject to excessive vibrations, as this may
cause the machine to fall or tip over, resulting in personal injury.
Never block the ventilation slots and levers on the machine. These openings
are provided for proper ventilation of working parts inside the machine.
Blocking these openings can cause the machine to overheat. Never place the
machine on a soft surface, such as a sofa or rug.
The machine may emit gas when the glue is melting that could irritate the
eyes, nose and throat, however this gas is not harmful to humans. Keep the
room ventilated to maintain a comfortable work environment.
Do not install the machine in the following locations:
- A damp or dusty location.
- A location near water faucets or water.
- A location exposed to direct sunlight.
- A location subject to high temperatures.
- A location near open flames.
Do not remove the machine's leveling feet after the machine has been installed,
as this may cause the machine to fall or tip over, resulting in personal injury.
Chapter 1 - Introduction
13
Installation precautions
#
CAUTION
• Provide adequate installation space to the front and back of the machine.
Back of the machine (1): 900 mm or more.
Front of the machine (2): 800 mm or more.
When the front cover, stacker and trimmer waste unit are open (3): 1407 mm
• Contact your local authorized dealer to move the machine.
14
Chapter 1 - Introduction
Main power
Main power
#
WARNING
• Do not walk on the power cord and do not place heavy objects on it. Doing
so could damage the card after which continued use could result in a fire or
electrical shock or some other malfunction.
• Do not damage or modify the power cord. Also, do not place heavy objects
on the power cord, or pull on or excessively bend it, as this could cause electrical damage an result in a fire or electrical shock.
• Do not connect or disconnect the power cord with wet hands, as this may
result in electrical shock.
• Do not bundle up or tie the power cord in a knot, as this may result in a fire
or electrical shock.
#
CAUTION
•
•
•
•
Use a power supply with specifications compatible with 220-240 V AC.
Make sure that the power supply and the voltage are stable.
Do not plug other equipment into the same outlet as the machine.
Do not connect the power cord to a multi-port power strip or overload a
single power outlet with too many power cords, as this may cause a fire or
electrical shock.
• Leave sufficient space around the power plug so that it can be unplugged
easily. If objects are placed around the power plug, you will be unable to
unplug it in an emergency.
• Turn off the power switch for safety when the machine will not be used for
a long period of time, such as overnight. Also, turn off the power switch and
disconnect the power cord for safety when the machine will not be used for
an extended period of time, such as during consecutive holidays. See ‘How to
turn the main power off’ on page 34.
• If the power cord is disconnected from power outlet such as during service
maintenance, be sure to put a tag which warns other persons not to operate
the power source, in order to avoid inadvertent connection of the power cord.
Chapter 1 - Introduction
15
Handling
Handling
#
WARNING
• Do not attempt to disassemble or modify the machine.
• There are high-temperature components inside the machine which may result
in a fire. Be very careful when inspecting the interior of the machine. Also,
do not do any operations not described in this manual.
• If the machine makes strange noises, or gives off smoke, heat or strange smells,
immediately turn off the power switch and disconnect the power cord from
the power outlet. Contact your local retailer where you purchased the machine
or an authorized dealer. Using the machine under these conditions may result
in a fire or electrical shock. See ‘How to turn the main power off’ on page 34.
• Do not use highly flammable sprays near the machine. If gas from these sprays
comes into contact with the electrical components inside the machine, it may
result in fire or electrical shock.
• Do not drop paper clips, staples, or other metal objects inside the machine.
Also, do not spill water or liquids inside the machine. If these items come
into contact with a high-voltage area inside the machine, it may result in a
fire or electrical shock.
16
Chapter 1 - Introduction
Handling
#
CAUTION
• When closing the top cover, be careful not to get your fingers caught, as this
may result in personal injury.
• The following caution label is attached to the machine. To use the machine
safely, pay attention indicated on the caution labels.
Chapter 1 - Introduction
17
Maintenance / Inspections
Maintenance / Inspections
#
WARNING
• When cleaning the machine, first turn off the power switch, then disconnect
the power cord. See ‘How to turn the main power off’ on page 34. Failure to
follow these steps may result in a fire or electrical shock.
• Disconnect the power cord from the power outlet regularly, and clean the
area around the base of the power plug's metal pins and the power outlet
with a dry cloth to ensure that all dust and grime is removed. If the power
cord is connected for a long period of time in a damp, dusty or smoky location,
dust can build up around the power plug and become damp. This may cause
a short circuit and result in a fire.
• Clean the machine using a slightly dampened cloth with a mild detergent
mixed with water. Do not use alcohol, benzene, paint thinner, or other
flammable substances. The volatile or flammable materials could come in
contact with the machine's electronic components and cause a fire or a short
circuit.
18
Chapter 1 - Introduction
Consumables
Consumables
#
WARNING
• Do not expose the glue to fire. The glue is flammable and may cause burns
or a fire.
• Do not store the glue near an open flame. The glue and paper are flammable
and may cause burns or a fire.
#
CAUTION
• Store the glue someplace that is out of the reach of children. Contact a doctor
immediately if anyone drinks the glue.
• Glue that has been spilt may have some dirt in it and should not be used in
the machine.
• Do not store the glue in a location that is subject to high temperatures or
humidity, as doing so could cause the glue to melt.
• Contact your local retailer if you need the material safety data sheet (MSDS)
for the glue. Be sure to get the latest version of the MSDS as some of the information may have changed.
Chapter 1 - Introduction
19
Other warnings
Other warnings
If you intend to dispose of the machine, contact your local authorized dealer beforehand.
20
Chapter 1 - Introduction
How to check the breaker
Periodic test of the breaker
How to check the breaker
Introduction
A breaker that detects over current and short circuits is equipped in order to prevent
electric shock on the product.
Be sure to perform the following procedure once or twice a month to periodically test
the breaker.
#
IMPORTANT
• Periodic testing of the breaker should be performed with the binder's power switch
turned on. Turn off the power to the printer so that the binder does not operate
during the test.
• If a breaker test reveals that it is not operating normally, contact your local authorized dealer.
How to check the breaker
1. Use a ballpoint pen or some other thin, pointed object to press the breaker test button
on the back of the unit.
#
IMPORTANT
Do not keep the test button depressed. Press and immediately release it.
#
NOTE
The breaker is located on the back of the unit.
Chapter 1 - Introduction
21
How to check the breaker
2. Confirm that the breaker switch toggles to the OFF (O) side and the power turns off.
#
IMPORTANT
• The test button is not intended to be used to turn power on and off.
• If the breaker switch does not toggle to the OFF (O) side, perform step 1 again.
• If the breaker switch does not toggle to the OFF (O) side even though you perform
step 1 two or three times, contact your local authorized dealer.
3. After performing the above test, turn off the power switch.
4. Return the breaker switch to the ON (I) side.
5. Turn on the power switch.
6. Enter the date and time of the test into the next available entry of the breaker test
checklist sheet.
22
Chapter 1 - Introduction
Check sheet for periodic testing of the Perfect Binder-B1
Check sheet for periodic testing of the Perfect Binder-B1
Introduction
Copy the breaker test checklist sheet and use the copy to record entries. After recording
entries, store the checklist sheet in a safe place next to the product.
1. Periodic breaker test.
Perform the test of the breaker (see ‘How to check the breaker’ on page 21) once or twice
a month.
2. Filling in the breaker test checklist sheet.
Fill in the date of the test and the name of the person performing it.
Put a check in the "OK" column if the test results are normal. If test results are not normal,
put a check in the "NG" column and contact your local authorized dealer.
#
Test date
Tester
Test result
OK
NG
Chapter 1 - Introduction
23
Check sheet for periodic testing of the Perfect Binder-B1
24
Chapter 1 - Introduction
Chapter 2
Before you start using this
machine
Exterior view
Parts and their functions
Exterior view
Illustration
Parts and their functions
#
26
Part
Function
1
Top cover
Open this cover when clearing a paper jam from the gathering tray.
‘Clear a paper jam inside the top cover’ on page 61
2
Sheet inserter
For loading paper used for covers or insert sheets.
‘Load paper into the sheet inserter’ on page 45
3
Power switch
Turns power on and off.
‘How to turn the main power on’ on page 33
‘How to turn the main power off’ on page 34
4
Energy
saver/LED
Enters and exits the energy save mode. Also, it lights green
in energy save mode and flashes when adjustment of the
glue temperature starts.
‘Energy saver and energy save mode’ on page 35
5
Glue unit
Open when replenishing glue.
‘Replenish glue’ on page 54
Chapter 2 - Before you start using this machine
Exterior view
Part
Function
6
Front cover
(left/right)
Open these covers when clearing a paper jam.
‘Clear a paper jam inside the top cover’ on page 61
‘Clear a paper jam inside the front cover’ on page 65
7
Front cover
LED
Lights orange during a binding operation to indicate that
the front cover is locked. Remains unlit to indicate that the
cover is unlocked when clearing a paper jam is required or
the binder is not doing a binding operation.
8
Breaker
Use to do periodic tests of the breaker. This breaker is to
completely prevent short circuits.
‘How to check the breaker’ on page 21
9
Test button
Press when performing testing breaker inspection.
‘How to check the breaker’ on page 21
10
Trimmer
waste unit
Open to discard cuttings.
‘Discard cuttings’ on page 52
11
Stacker
Holds completed booklets
‘Remove finished booklets’ on page 49
12
Stacker open
button/LED
Press when removing booklets from the finished booklets
receptacle. Also, it lights green when the stacker is open
and flashes while preparing to open/close.
13
Full LED
Lights green when the stacker is full and flashes while a
binding operation is in progress.
Chapter 2 - Before you start using this machine
27
Outline of the binder's mechanisms
Outline of the binder's mechanisms
Illustration
Parts and functions
#
28
Part
Function
1
Sheet inserter
For loading paper used for covers or insert
sheets.
2
Gathering tray
Gathers and collates finished booklet paper.
3
Gathering tray transfer section
Transfers paper supplied from the printer
or from the sheet inserter to the gathering
tray.
Chapter 2 - Before you start using this machine
Outline of the binder's mechanisms
Part
Function
4
Binder/pass-through transfer
section
Transfers covers up to the binding position. When the booklet finishing function
is not being used, passes paper supplied
from the printer over to the next device.
5
Inserter transfer section
Transfers paper supplied from the sheet
inserter.
6
Gluing section
Applies glue to a stack of collated paper.
7
Binding position
Binds stacks of paper with cover.
8
Cutter section
Cuts stacks of paper and transports finished booklets to the booklet receptacle.
9
Stacker
Holds booklets.
10
Trimmer waste tray
Holds paper cuttings.
Chapter 2 - Before you start using this machine
29
Outline of bookbinding procedure
Outline of bookbinding procedure
Illustration
Bookbinding procedure
#
30
Stage
Description
1
Paper from the printer or the sheet inserter is transferred to the
gathering tray.
2
Paper stack is collated by the gathering tray.
3
Collated paper stack is transported to the gluing section.
4
Transfers covers from the printer or the sheet inserter.
5
Glue is applied to the spine of the paper stack.
6
Paper stack with glue applied is bound with a cover.
Chapter 2 - Before you start using this machine
Outline of bookbinding procedure
Stage
Description
7
Paper stack bound with cover is transported to the cutter section.
8
Paper stack bound with cover is rotated and cut.
9
Finished item is transported to the stacker.
10
Cuttings are discharged to the trimmer waste tray.
Chapter 2 - Before you start using this machine
31
Sheet inserter
Sheet inserter
Illustration
Component - function table
#
32
Part
Function
1
Lower tray
For loading cover papers and slip sheets.
2
Upper tray
For loading slip sheets. Accepts small size
paper only.
3
Top cover
Open this cover when clearing an internal
paper jam.
4
Inner cover
Open this cover when clearing paper jams
in the lower tray.
5
Right guide
Open this guide when clearing a paper
jam.
6
Slider guide
Adjust the position of the guide to match
the width of the paper loaded in the tray.
Chapter 2 - Before you start using this machine
How to turn the main power on
Main power
How to turn the main power on
Introduction
This product has two switches for controlling power: a main power switch and a Energy
saver. A breaker is also equipped to detect over current and short circuits.
How to turn on power
1. Confirm that the power plug is plugged securely into a power outlet.
#
WARNING
Never plug in or unplug the power plug while your hands are wet. Doing so
creates the risk of electric shock.
2. Open the power switch cover and press the ON side (I) of the power switch to turn on
power.
#
IMPORTANT
If the unit does not operate when you turn on the power switch, check if the breaker
is OFF. See ‘Power does not turn on’ on page 86.
#
NOTE
The binder goes to energy save mode immediately after the power switch is turned
on. To turn off the energy save mode, press the energy saver. See ‘Energy saver and
energy save mode’ on page 35.
3. Close the power switch cover.
Chapter 2 - Before you start using this machine
33
How to turn the main power off
How to turn the main power off
How to turn off power
1. Open the power switch cover and press the OFF side (O) of the power switch to turn off
power.
2. Close the power switch cover.
#
CAUTION
If the power cord is disconnected from power outlet such as during service
maintenance, be sure to put a tag which warns other persons not to operate the
power source, in order to avoid inadvertent connection of the power cord.
#
IMPORTANT
To completely cut off the power to the binder, disconnect the power plug.
34
Chapter 2 - Before you start using this machine
Energy saver and energy save mode
Energy saver and energy save mode
Introduction
Turning on the energy saver (LED lights) enters the energy save mode and cuts electric
power in order to melt glue and adjust temperature. Use the energy saver when you want
to keep only the functions that transport paper (pass-through transfer) to the next device
operational, without performing binding.
The energy save mode also is entered automatically for the amount of time set from the
settings editor, when a prescribed amount of time has passed following completion of a
booklet, etc. To recover from the energy save mode, press the energy saver.
The time for entering the energy save mode following completion of a booklet can be set
from the settings editor.
Adjust the time for entering the energy save mode from the settings editor. Consult the
manual that comes with the printer for the procedure.
The energy saver LED indicates the following.
• Lit: Glue temperature adjustment is not being done, the binder is in energy save mode.
• Flashing: Glue temperature is being adjusted to the correct binding temperature.
• Off: Binding is possible, the glue is at the correct temperature for binding.
Energy save mode
1. Press the energy saver to enter the energy save mode.
The energy save LED will light and glue temperature adjustment will stop.
2. To recover from the energy save mode, press the energy saver again.
The energy save LED will flash and then go out, indicating binding can now be done.
#
NOTE
When you do binding settings on the printer, the Perfect Binder-B1 automatically
recovers from the energy save mode.
Chapter 2 - Before you start using this machine
35
Energy saver and energy save mode
36
Chapter 2 - Before you start using this machine
Chapter 3
Basic operations
Make a perfect-bound book
Make a perfect-bound book
Introduction
The perfect binder is an optional finisher. This finisher enables you to create a perfectbound book.
#
NOTE
• Perfect binding is only available for print jobs, not for copy jobs.
• Perfect binding can only be applied to a job via job preparation software like the
driver, PRISMAPrepare, or other job preparation applications.
• On the operator panel perfect binding can only be disabled for a job, but can not
be enabled for a job.
Before you begin
Load the media for the body sets and, if needed, the covers.
Make a perfect-bound book
1. Define the book that you want to be perfect-bound, via the driver, PRISMAPrepare, or
other job preparation applications.
2. Send it to the printer.
3. Change job properties, if needed.
#
NOTE
You are only allowed to change the trimming, or the used paper (but not the paper
size). See the manual of the printer how to change these properties.
And of course you can disable perfect-binding in the job properties.
4. Print the perfect-bound book.
38
Chapter 3 - Basic operations
Types of paper that can be used
Paper and finished sizes
Types of paper that can be used
Introduction
Use the appropriate paper to get the best results from the binder. If the wrong type of
paper is used, it could cause defect in binding or paper jams.
This machine can use the following types of paper for perfect binding.
Types of paper that can be used
+: available; -: unavailable#
Paper type
Types of paper that can be used
Cover
Body pages/Slip
sheets
Thin paper
-
+
Plain paper
+
+
Heavy paper
+
+
Recycled paper
+
+
Color paper
+
+
Coated paper
+
+
Texture paper
+
-
Bond paper
-
+
#
NOTE
All of the available paper in the printer can go through the pass-through transfer
section.
Chapter 3 - Basic operations
39
Types of paper that can be used
Paper weight
#
Paper Weight
Cover
Body pages/Slip sheets
90 to 300 g/m2 *1
60 to 163 g/m²
Paper weights and the number of sheets that can
be bound are listed below.
• 60 to 63 g/m²: 20 to 200 sheets (booklet
thickness: 25mm or less)
• 64 to 80 g/m²: 10 to 200 sheets (booklet
thickness: 25mm or less)
• 81 to 105 g/m²: 10 to 150 sheets (booklet
thickness: 25mm or less)
• 106 to 163 g/m²: 1 to 10 sheets (slip sheets
only)
*1
Use grain short paper for covers if the paper has a paper weight that is 251 g/m² or
higher.
#
IMPORTANT
• Do not use curled paper. Using curled paper may cause defect in binding or paper
jams.
• If the position of the images or text on the body pages or the slip sheets is crooked,
the bound booklets will be poorly finished, with uneven thickness. To produce
nicely finished booklets keep the position of the images and text on the body pages
and slip sheets centered.
#
NOTE
Do not use the cover that contains images or text in the bound portion. It may cause
defect in a binding, since they impede adhesion of the glue.
Paper size
The binder can use the following paper sizes as covers and body pages / slip sheets.
• Cover
Width (1): 257.0 (B4) to 330.2 mm (13")
Length (3): 364.0 (B4) to 487.7 mm (19.2")
40
Chapter 3 - Basic operations
Types of paper that can be used
• Body page / slip sheets
Width (1): 257.0 (B5) to 320.0 mm (12.60")
Length (2): 182.0 (B5) to 228.6 mm (9")
+: can be used; -: can not be used#
Paper size
Possible uses
Cover
Body pages / Slip
sheets
A3
+
-
B4
+
-
13" x 19" (330 x 483 mm)
+
-
12" x 18" (305 x 457 mm)
+
-
11" x 17" (ledger)
+
-
SRA3 (320 x 450 mm) (12.50"
x 17.72")
+
-
A4
-
+
B5
-
+
LTR
-
+
SRA4 (225 x 320 mm) (8.86" x
12.60")
-
+
#
NOTE
If the paper size is not registered in the printer, be sure to use it after registering in
the printer as an irregular paper size.
Chapter 3 - Basic operations
41
Finished sizes of booklets
Finished sizes of booklets
Introduction
This machine can bind various sizes of booklets.
The sizes of the finished booklets differ according to the cutting method. The following
table shows relations between sizes of the finished booklets and sizes of cover and body
pages / slip sheets.
Be sure to confirm the cutting range is within the available ranges shown below.
Top/bottom cutting range is the total of top cutting range and bottom cutting range.
therefore, half the value of top/bottom cutting range is equal to each value of the top
range and the bottom range.
Top/bottom cutting range (C1): 13 to 79 mm (0.52" to 3.11")
Foredge cutting range (C2): 6.5 to 49.5 mm (0.26" to 1.94")
Booklet thickness (D): less than 25 mm (1")
Cutting method and paper size
#
Cutting method
3-direction cutting (top, bottom,
foredge cutting)
Size of finished
booklet
Size of body
pages / slip sheets
Size of cover
Width:
*1
W
Length:
L
Width:
W1
Length:
L1
Width:
W2
Length:
L2
203 to
297
mm
138 to
216
mm
W + C1
L + C2
W + C1
364.0 to
L1 x 2 +
30.5 mm
*2
*3
1-direction cutting (foredge cutting)
No cutting
42
257
[B5] to
297
mm
138 to
216
mm
257
[B5] to
297
mm
182
[B5] to
216
mm
Chapter 3 - Basic operations
W mm
L + C2
W mm
364.0 to
L1 x 2 +
30.5 mm
*3
W mm
L mm
W mm
364.0 to
L1 x 2 +
30.5 mm
*3
Finished sizes of booklets
*1
If the length (L) defined as 1, be sure to set the ration of the width (W) between 1.25
and 1.5.
*2
Be sure to make the width of W1 (width of body pages / slip sheets) less than the width
of W2 (width of cover), when 3-direction cutting is done.
*3
For good looking finished booklets, the maximum length of cover you can set is 487.7
mm. 487.7 mm includes the total of the following values.
Length of body pages / slip sheets x 2, maximum booklet thickness (25 mm), and maximum value of cover image placement adjustment (5 mm).
#
IMPORTANT
Be sure to use paper that is less than 297 mm wide when cutting in one direction or
when not cutting.
Cutting range
For good looking finished booklets, be sure to set the top/bottom cutting range and
foredge cutting range as follows.
#
Top/bottom cutting range
C1 = W2 - W
Cutting range is width of
cover minus width of finished booklet.
Foredge cutting range.
If length of cover is longer
than the length of body
pages / slip sheets.
C2 = (L2 - D) / 2 - L
Cutting range is length of
cover minus the booklet
thickness, divided by two.
And the length of the finished booklet is subtracted
from the result.
Foredge cutting range.
If length of cover is shorter
than the length of body
pages / slip sheets.
C2 = L1 - L
Cutting range is length of
body pages / slip sheets
minus length of finished
booklet.
Examples of finished size of booklets (3-direction cutting)
The following table shows examples that the combination of cover and body pages / slip
sheets when 3-direction cutting is done.
Chapter 3 - Basic operations
43
Finished sizes of booklets
The paper sizes inside the wide frame of the table are the finished size of the booklets
#
Cover
13" x 19"
Body
pages /
slip sheets
9" x 12"
SRA4
(320 x
225 mm)
A4
LTR
B5
SRA3
(320 x 450
mm)
A3
11" x 17"
B4
LTR
A4
B5
7" x 9"
7" x 9"
A5
#
NOTE
If the paper size is not registered in the printer, be sure to use it after registering in
the printer as an irregular paper size.
#
IMPORTANT
• The edges of bound booklets may be folded when binding booklets with covers
that are larger than the body pages if cutting is not done.
• Use body pages and slip sheets that are the same size.
• The top/bottom cutting range of this machine is 13 to 79 mm, and the foredge
cutting range is 6.5 to 49.5 mm. If the finished sizes of booklets set on the printer
or printer driver go over the cutting range of this machine, the cutting will not
operate correctly. Be sure to adjust the printer's cutting range within the available
value of this machine.
44
Chapter 3 - Basic operations
Load paper into the sheet inserter
Load paper into the sheet inserter
Introduction
Paper loaded into the sheet inserter can be supplied as covers or slip sheets. The sheet
inserter is able to use paper that cannot be supplied from the printer or side paper deck
(color copied paper, etc.) as cover paper and slip sheets.
#
IMPORTANT
• Be sure to fan paper before loading it.
• If paper is curled (particular color copied paper), be sure to remove the curl before
using the paper.
• Do not use the following types of paper.
- Paper that is torn or has holes or other openings in it.
- Badly curled or creased paper.
- Paper that is clipped, stapled, etc.
- Paper that has correcting fluid, paper, tape, etc. on it.
#
NOTE
Note that the left-right orientation of paper loaded in the sheet inserter differs as
shown below.
#
- Leftward orientation
<Top>
<Foredge>
Inserter feed direction
<Bottom>
- Rightward orientation
<Bottom>
<Foredge>
Inserter feed direction
<Top>
Purpose
This section explains how to load paper into the upper and lower trays of the sheet inserter.
Chapter 3 - Basic operations
45
Load paper into the sheet inserter
Loading paper into the trays
1. Adjust the slide guide to fit the loaded paper.
• When using the upper tray.
- Align with the slide guide scale.
• When using the lower tray.
- Align with the slide guide scale.
2. Load the paper into the sheet inserter.
#
IMPORTANT
To prevent paper jams when loading multiple sheets of paper, fan the stack of paper
a number of times and then even up its edges before loading it.
46
Chapter 3 - Basic operations
Load paper into the sheet inserter
#
NOTE
• You cannot load paper of different sizes.
• Paper loaded in the sheet inserter cannot be used for copying.
• A maximum of 200 sheets (80 g/m2) can be loaded at one time.
• Paper is fed from the top sheet.
• Loading paper in the upper tray.
- The following paper sizes can be loaded.
Width (side to side): 257.0 to 320.0 mm
Length (in direction of transfer): 182.0 to 228.6 mm
- Load the paper with the surface that will be the cover facing up and with the sheets
aligned against the back of the tray. (The following illustration shows the paper loaded
for leftward orientation.)
#
NOTE
• You can load paper to be used as slip sheets in the upper tray. Do not load paper
to be used as covers.
Chapter 3 - Basic operations
47
Load paper into the sheet inserter
• Loading paper into the lower tray.
- The following paper sizes can be loaded.
Width (side to side): 257.0 to 330.2 mm
Length (in direction of transfer): 182.0 to 487.7 mm
- Load the paper with the surface that will be the cover facing up and with the sheets
aligned against the back of the tray. Make sure that the back edge of the loaded paper
aligns with the indicator on the tray. (The following illustration shows the paper
loaded for leftward orientation.)
#
NOTE
• You can load paper to be used as covers or slip sheets in the lower tray.
• A part of the upper tray can be raised when small sheets of paper are loaded.
3. On the printer display, select the size and type of the paper loaded in the sheet inserter.
#
IMPORTANT
• Select the same size and type as the paper loaded in the sheet inserter.
48
Chapter 3 - Basic operations
Remove finished booklets
Remove finished booklets
Introduction
Use the following procedure to remove bound booklets from the stacker.
#
CAUTION
• Do not do operations other than removing booklets. Putting your hand into
the binder from the stacker may cause an injury.
• Take care to avoid cutting your hands on the edges of the booklets when re-
moving them.
• Do not use the stacker as storage. Using the stacker as storage could cause a
malfunction.
#
IMPORTANT
The cuttings may enter into the stacker. If this happens, remove the cuttings from
the stacker.
Chapter 3 - Basic operations
49
Remove finished booklets
#
NOTE
• This operation can be performed while the device is operating.
• The stacker can hold up to approximately 127 mm (equivalent to 10 booklets of
100 pages of 64 g/m2 body pages / slip sheets and a cover of one 128 g/m2 sheet)
or approximately 1000 sheets as a total. However, if the booklets contain body
pages / slip sheets that are heavier than 81 g/m2, the stacker may not be able to
hold booklets up to approximately 127.
• The stacker has two LED's: a full LED and an open LED. Each LED indicates
the following.
- Full LED
Lit: The stacker is full or almost full.
Flashing: Binding operation is in progress.
- Open LED
Lit: the stacker is open.
Flashing: The stacker is preparing to open or close.
Off: The stacker is closed.
Removing finished booklets
1. Press the open button and pull out the stacker.
The open LED flashes, then lights and the stacker automatically opens. Pull the stacker
out all the way until it stops.
#
NOTE
If the cutting is being operated inside the machine, the stacker may need some time
to open.
50
Chapter 3 - Basic operations
Remove finished booklets
2. Remove the booklets from the stacker.
#
CAUTION
Do not move the stacker's guide with your hand. Moving the guide may cause
a malfunction.
#
IMPORTANT
Be sure to remove all the booklets when the stacker is open. The stacker is recognized
as full if any booklets are left in it.
3. Close the stacker.
Close it until it clicks into place.
#
CAUTION
Be careful not to pinch your fingers in the gaps when the stacker is closing.
#
NOTE
If you open the stacker while the binder is operating, quickly remove the booklets
and close the stacker. If the stacker is open, binding operations, except transferring
paper to the gathering tray and gluing, stop. If this happens, remove all booklets from
the stacker and then close it to restart binding operations.
Chapter 3 - Basic operations
51
Discard cuttings
Discard cuttings
Introduction
Use the following procedure to remove cuttings from the trimmer waste unit.
#
CAUTION
• Do not place a plastic bag or other secondary container in the trimmer waste
tray. Doing so reduces the capacity of the trimmer waste tray and does not
allow it to collect enough cuttings. It might also cause a malfunction.
• Do not use the trimmer waste unit as storage. Using the trimmer waste unit
as storage could cause a malfunction.
#
NOTE
This operation can be performed while the device is operating.
Discard cuttings
1. Pull out the trimmer waste unit.
#
NOTE
The trimmer waste unit may lock so you cannot open it during binding operations.
If this happens, wait a short time and try again.
52
Chapter 3 - Basic operations
Discard cuttings
2. Remove the trimmer waste tray and discard the cuttings.
3. Place back the trimmer waste tray and close the trimmer waste unit.
Close the trimmer waste unit by pressing until it clicks into place.
#
NOTE
If you open the trimmer waste unit while the binder is operating, quickly remove the
cuttings and close the trimmer waste unit. If the cuttings for a single booklet cannot
be discharged to the trimmer waste unit, binding operations stop until it can be discharged to the trimmer waste unit. If this happens, remove the cuttings from the
trimmer waste unit and then close it to restart binding operations.
Chapter 3 - Basic operations
53
Replenish glue
Replenish glue
Introduction
Use the following procedure to refill the glue.
#
CAUTION
Use the genuine glue for this binder to replenish the glue. Using a type of glue
other than the genuine glue may cause the binder to malfunction.
#
IMPORTANT
Note the following precautions when storing the glue.
• Avoid places near open flame.
• Avoid locations subject to high temperature or humidity.
• Store it someplace that is out of reach of children.
#
NOTE
Glue can be replenished even while the device is operating.
Replenish glue
1. Pull on the handle to open the glue container.
Extend the glue container until it stops.
2. Open the glue container's lid and its inner lid and replenish the glue.
54
Chapter 3 - Basic operations
Replenish glue
Fill the glue container with glue so it is even and level and does not go over the limit
mark.
#
CAUTION
• Do not allow glue to get into the binder's mechanical parts through the gaps
in the binder. If glue gets into the binder's mechanical parts it could cause a
malfunction.
• Do not put anything other than glue into the glue container. If something
other than glue gets into the glue container it could cause a fire or a malfunction.
• Do not add so much glue that it goes over the limit mark. Doing so may
prevent the glue container from closing or cause glue to spill inside the mechanical parts of the binder.
• When the glue is filled up, it may be difficult to open the glue container. If
this happens, open the glue container slowly again and again. Opening it too
hard might cause a malfunction.
#
IMPORTANT
• Use the supplied scoop to replenish the glue. Do not use the supplied scoop except
for replenishing the glue. Also store the scoop in a safe place for future use.
• Do not use glue that has fallen on the floor because it might have dust or dirt in
it.
3. Close the glue container's lid and its inner lid and close the glue container by pressing
until you hear it click into place.
Chapter 3 - Basic operations
55
Replenish glue
#
NOTE
The glue that is added to the glue container is transferred to the binder as the glue
in the binder is consumed. The binder can hold about 380 g of glue.
56
Chapter 3 - Basic operations
Clean the binder
Clean the binder
Introduction
Clean the outside of the machine if it gets dirty after using it for a long period of time.
Please note the following points to prevent malfunctions or electric shock when cleaning
the machine.
#
WARNING
• Turn off the power switch and unplug the power plug (see ‘How to turn the
main power off’ on page 34). It may result in a fire or electric shock.
• Never plug in or unplug the power plug while your hands are wet. Doing so
creates the risk of electric shock.
• Do not use alcohol, benzene, paint thinner, or other flammable substances.
The volatile or flammable materials could come in contact with the machine's
electronic components and cause a fire or a short circuit.
#
IMPORTANT
• Do not use any cleanser other than water or a neutral cleanser diluted with water.
Doing so may cause the machine's plastic parts to deteriorate or crack.
• Be sure to dilute any neutral cleanser with water.
• The machine does not need to be lubricated. Do not lubricate the machine.
Clean the binder
1. Open the power switch cover and press the OFF side of the power switch to turn off the
power before removing the power plug.
2. Dampen a soft cloth in water or neutral cleanser that has been diluted with water and
thoroughly wring it out before wiping any dirt from the machine.
After cleaning the machine with a neutral cleanser, be sure to wipe off the neutral cleanser
with a cloth that has been dampened with water.
3. After cleaning the machine, use a soft dry cloth to dry it.
4. Plug the power plug into to power outlet and press the ON side of the power switch and
then close the power switch cover.
Chapter 3 - Basic operations
57
Clean the binder
58
Chapter 3 - Basic operations
Chapter 4
Troubleshooting
Job cannot be perfect-bound error scenario
Job cannot be perfect-bound error scenario
Introduction
In some case a perfect bound book cannot be handled by the perfect binder. An error
scenario is given on the operator panel.
When to do
Error scenario is present on the operator panel.
Solve the perfect-bound error scenario
1. Delete the job, or move the job to the 'Waiting jobs'. In the latter case you can disable
perfect binding.
Open the job properties and disable perfect binding. See the manual of the printer how
to do this. Then you can print the job again, without perfect binding.
60
Chapter 4 - Troubleshooting
Clear a paper jam inside the top cover
Clearing paper jams
Clear a paper jam inside the top cover
Introduction
When a paper jam occurs, the printer display will indicate its location. The display will
continue to indicate the location until the paper jam is cleared.
#
CAUTION
• When clearing a paper jam, take care that you do not cut your hands on the
edges of the paper.
• When removing jammed paper from inside the product, take care that you
do not cut your hands on internal components. If you experience difficulties
removing paper, contact your local authorized dealer.
• Frequent paper jams at the same location can mean that there are pieces of
torn paper inside the mechanism. If you experience difficulties removing
pieces of torn paper, contact your local authorized dealer.
#
NOTE
If paper jams at multiple locations, clear each one in the sequence indicated on the
printer display.
When to do
Perform this procedure when a paper jam occurs on the transfer path to the gathering
tray in the top cover.
Chapter 4 - Troubleshooting
61
Clear a paper jam inside the top cover
Clear a paper jam inside the top cover
1. Remove the loaded paper and then open the sheet inserter.
2. Open the top cover.
#
NOTE
When the top cover is opened, the interlock switch is activated, power to the gathering
tray is cut off, and then the gathering tray stops operating.
3. Lift the gatherings tray's guide (A1).
#
NOTE
The gathering tray's guide (A1) returns to its normal position automatically during
operations.
62
Chapter 4 - Troubleshooting
Clear a paper jam inside the top cover
4. Remove the jammed paper from the gathering tray (A1).
#
NOTE
If there are many sheets of paper in the gathering tray, remove them from the left
side of the gathering tray without pulling on them too hard.
5. Open the guide of he gathering tray transfer section (A2).
Remove any jammed paper if there is any.
6. Close the guide of the gathering tray transfer section (A2).
Chapter 4 - Troubleshooting
63
Clear a paper jam inside the top cover
7. Close the top cover.
#
CAUTION
Be careful not to pinch your fingers in the gaps when the top cover is closing.
8. Close the sheet inserter.
#
CAUTION
When closing the sheet inserter, be careful not to get your fingers caught, as this
may result in personal injury.
9. Load the paper back into the sheet inserter.
10. Perform operations in accordance with the instructions that appear on the printer display.
#
NOTE
If the display continues to indicate a paper jam clearing procedure, continue to perform
the applicable procedure until the paper jam is cleared.
64
Chapter 4 - Troubleshooting
Clear a paper jam inside the front cover
Clear a paper jam inside the front cover
Introduction
When a paper jam occurs, the printer display will indicate its location. The display will
continue to indicate the location until the paper jam is cleared.
#
CAUTION
• When clearing a paper jam, take care that you do not cut your hands on the
edges of the paper.
• When removing jammed paper from inside the product, take care that you
do not cut your hands on internal components. If you experience difficulties
removing paper, contact your local authorized dealer.
• Frequent paper jams at the same location can mean that there are pieces of
torn paper inside the mechanism. If you experience difficulties removing
pieces of torn paper, contact your local authorized dealer.
#
NOTE
• The front cover LED is on the front cover
- Lit: The front cover is locked and cannot be opened.
- Off: The front cover is unlocked and can be opened.
• If paper jams at multiple locations, clear each one in the sequence indicated on
the printer display.
Clear a paper jam inside the front cover
1. Open the front right cover.
Make sure that the front cover LED is off.
Chapter 4 - Troubleshooting
65
Clear a paper jam inside the front cover
#
NOTE
• The front cover is locked during binding operations. It unlocks when a paper jam
occurs.
• When the front cover is opened, the interlock switch is activated and power to all
the operating parts of the binder is cut off. However, power to the stacker and
trimmer waste unit is not cut off. Therefore, even if the front cover is opened, you
can remove finished booklets from the stacker and remove cuttings from the
trimmer waste unit.
2. Open the lower guide for gathering tray transfer section (B).
3. Remove any paper jammed inside the lower guide for gathering tray transfer section (B),
and then close the guide.
4. Open the entrance transfer guide (C).
66
Chapter 4 - Troubleshooting
Clear a paper jam inside the front cover
5. Remove any paper jammed inside the entrance transfer guide (C), and then close it.
6. Open the inserter transfer section upper guide (D1).
7. Open the inserter transfer section lower guide (D2).
8. Remove any paper jammed inside the lower guide (D2), and then close the lower guide
(D2).
Chapter 4 - Troubleshooting
67
Clear a paper jam inside the front cover
9. Close the upper guide (D1).
10. Open the front left cover.
11. Open the left guide (E1) of the binder/pass-through transfer section.
12. Open the exit guide (E2).
13. Remove any paper jammed inside the guide.
68
Chapter 4 - Troubleshooting
Clear a paper jam inside the front cover
14. Close the exit guide (E2).
15. Close the left guide (E1) of the binder/pass-through transfer section.
16. Open the right guide (E3) of the binder/pass-through transfer section.
17. Remove any paper jammed inside the guide.
Chapter 4 - Troubleshooting
69
Clear a paper jam inside the front cover
18. If the paper is under the guide or is difficult to remove, turn the dial (E4) to the right to
shift the paper out.
19. Close the right guide (E3) of the binder/pass-through transfer section.
20. Close the front left cover and then close the front right cover.
#
CAUTION
Close the front cover carefully so you do not pinch your fingers in the gaps when
it is closing. Failure to do so could cause injury.
21. Perform operations in accordance with the instructions that appear on the printer display.
#
NOTE
If the display continues to indicate a paper jam clearing procedure, continue to perform
the applicable procedure until the paper jam is cleared.
70
Chapter 4 - Troubleshooting
Clear a paper jam in the stacker
Clear a paper jam in the stacker
Introduction
When a paper jam occurs, the printer display will indicate its location. The display will
continue to indicate the location until the paper jam is cleared.
#
CAUTION
• When clearing a paper jam, take care that you do not cut your hands on the
edges of the paper.
• When removing jammed paper from inside the product, take care that you
do not cut your hands on internal components. If you experience difficulties
removing paper, contact your local authorized dealer.
• Frequent paper jams at the same location can mean that there are pieces of
torn paper inside the mechanism. If you experience difficulties removing
pieces of torn paper, contact your local authorized dealer.
#
NOTE
If paper jams at multiple locations, clear each one in the sequence indicated on the
printer display.
When to do
Perform this procedure when a paper jam occurs in the stacker.
Clear a paper jam in the stacker
1. Press the open button and pull out the stacker.
Pull the stacker out all the way until it stops.
Chapter 4 - Troubleshooting
71
Clear a paper jam in the stacker
2. Remove all booklets from the stacker.
#
CAUTION
Do not move the stacker's guide with your hand. Moving the guide may cause
a malfunction.
3. Close the stacker.
Close the stacker until it clicks into place.
#
CAUTION
Be careful not to pinch your fingers in the gaps when the stacker is closing.
#
NOTE
If the paper jam has occurred again even though you remove all booklets from the
stacker, pull out the trimmer waste unit to discard the cuttings.
72
Chapter 4 - Troubleshooting
Clear a paper jam in the sheet inserter
Clear a paper jam in the sheet inserter
Introduction
When a paper jam occurs, the printer display will indicate its location. The display will
continue to indicate the location until the paper jam is cleared.
#
CAUTION
• When clearing a paper jam, take care that you do not cut your hands on the
edges of the paper.
• When removing jammed paper from inside the product, take care that you
do not cut your hands on internal components. If you experience difficulties
removing paper, contact your local authorized dealer.
• Frequent paper jams at the same location can mean that there are pieces of
torn paper inside the mechanism. If you experience difficulties removing
pieces of torn paper, contact your local authorized dealer.
#
NOTE
If paper jams at multiple locations, clear each one in the sequence indicated on the
printer display.
When to do
Perform this procedure when a paper jam occurs on the transfer path to the sheet inserter.
Clear a paper jam when loading paper from the upper tray
1. Open the top cover of the sheet inserter.
Chapter 4 - Troubleshooting
73
Clear a paper jam in the sheet inserter
#
NOTE
When the top cover is opened, the interlock switch is activated, power to the sheet
inserter is cut off, and then the sheet inserter stops operating.
2. Open the right guide (I2).
3. Remove any paper that is on the upper tray.
4. Remove any paper jammed there.
5. Close the right guide (I2) and then close the top cover.
74
Chapter 4 - Troubleshooting
Clear a paper jam in the sheet inserter
#
CAUTION
When closing the cover and guide, be careful not to get your fingers caught, as
this may result in personal injury.
6. Load the paper back into the upper tray.
7. Do the operations according to the instructions on the printer's display.
#
NOTE
If the display continues to indicate a paper jam clearing procedure, continue to perform
the applicable procedure until the paper jam is cleared.
Clear a paper jam when loading paper from the lower tray
1. Open the top cover of the sheet inserter.
#
NOTE
When the top cover is opened, the interlock switch is activated, power to the sheet
inserter is cut off, and then the sheet inserter stops operating.
Chapter 4 - Troubleshooting
75
Clear a paper jam in the sheet inserter
2. Open the inner cover (I1) and the right guide (I2).
3. Remove any paper that is on the lower tray.
4. Remove any paper jammed there.
5. Close the right guide (I2) and then close the inner cover (I1) and the top cover.
#
CAUTION
When closing the cover and guide, be careful not to get your fingers caught, as
this may result in personal injury.
76
Chapter 4 - Troubleshooting
Clear a paper jam in the sheet inserter
6. Load the paper back into the lower tray.
7. Do the operations according to the instructions on the printer's display.
#
NOTE
If the display continues to indicate a paper jam clearing procedure, continue to perform
the applicable procedure until the paper jam is cleared.
Chapter 4 - Troubleshooting
77
Check the status of the trimmer waste unit
Check the status of the trimmer waste unit
Introduction
The perfect binder contains a trimmer waste unit. The trimmer waste unit contains the
cuttings that result from the trimming process. You can check the status of the trimmer
waste unit in the dashboard (see manual of the printer) and in the 'System' view of the
printer. The icons in the following table indicate the status of the trimmer waste unit.
#
NOTE
Only when the trimmer waste unit is full, the status is visible in the dashboard.
The meaning of the trimmer waste unit icons
The waste box icons#
Trimmer waste
unit icon
Description
The trimmer waste unit icon is blue. The waste box inside the
icon is grayed out. The trimmer waste unit status is: 'Absent'.
The trimmer waste unit icon is blue. The trimmer waste unit
is not full. The trimmer waste unit status is: 'OK'.
The trimmer waste unit icon is red. The trimmer waste unit
status is: 'Full'. The printer stops.
To continue printing, empty the trimmer waste unit (see ‘Discard cuttings’ on page 52).
Check the status of the trimmer waste unit
1. Check the trimmer waste unit icon in the dashboard.
#
NOTE
Only when the trimmer waste unit is full, the status is visible in the dashboard.
2. Touch the 'System' button.
3. Press 'Printer'.
The 'System' view displays the status of the trimmer waste unit.
78
Chapter 4 - Troubleshooting
Check the status of the glue
Check the status of the glue
Introduction
The perfect binder contains a glue container. You can check the status of the glue container in the dashboard (see manual of the printer) and in the 'System' view of the
printer. The icons in the following table indicate the status of the glue container.
#
NOTE
Only when the glue container is empty, the status is visible in the dashboard.
The meaning of the status of the glue container icons
The glue container icons#
Glue container
icon
Description
The glue container icon is blue. The glue container is not
empty. The glue container status is: 'OK'.
The glue container icon is red. The glue container is empty.
The glue container status is: 'Empty'. The printer stops.
To continue printing, refill the glue (see ‘Replenish glue’ on page
54).
Check the status of the glue container
1. Check the glue container icon in the dashboard.
#
NOTE
Only when the glue container is empty, the status is visible in the dashboard.
2. Touch the 'System' button.
3. Press 'Printer'.
The 'System' view displays the status of the glue container.
Chapter 4 - Troubleshooting
79
Adjust cover position
Adjust cover position
Introduction
You can adjust the cover position, if the cover is out of position in relation to the stacked
body pages.
When to do
If the cover is out of position in relation to the stacked body pages.
Before you begin
Be sure that the system is in standby.
Adjust cover position
1. Touch the 'System' button.
2. Press 'Maintenance'.
3. Touch 'Start maintenance' to open the list of 'Maintenance tasks'.
In the list of 'Maintenance tasks' the task to adjust the cover position can be selected.
4. Touch this task and follow the instructions.
80
Chapter 4 - Troubleshooting
Adjust glue amount
Adjust glue amount
Introduction
When you make a booklet in the perfect binding mode, you must use the correct amount
of glue, or the bound booklets may be poorly finished, as shown below.
#
Amount of glue
Finishing condition
Figures
Normal
Too much glue
Glue protrudes from
booklet.
Booklet jam occurs.
Too little glue
Spine is not attached
evenly to the main document.
Main document detaches
from the cover.
Chapter 4 - Troubleshooting
81
Adjust glue amount
#
NOTE
When you adjust the amount of glue, make a booklet every time you change the
amount of glue in one level increments, and check the finishing condition of the
bound booklet.
When to do
When the bound booklets are poorly finished.
Adjust glue amount
1. Touch the 'System' button.
2. Press 'Maintenance'.
3. Touch 'Start maintenance' to open the list of 'Maintenance tasks'.
In the list of 'Maintenance tasks' the task to adjust the glue amount can be selected.
4. Touch this task and follow the instructions.
82
Chapter 4 - Troubleshooting
Alarm list
Alarm list
Introduction
This section explains the alarm that can occur with this product.
Alarm will be indicated on the printers display. See the manual that comes with the
printer for information about alarm message or required action.
Alarm list
#
Alarm timing
Required action
More information
Paper remaining in
the gathering tray.
Error scenario
Remove the paper
from the gathering
tray.
‘Clear a paper jam
inside the top cover’
on page 61
‘Clear a paper jam
inside the front cover’ on page 65
‘Clear a paper jam
in the stacker’ on
page 71
Out of glue.
Status in the dashboard (see ‘Check
the status of the glue’
on page 79)
Replenish the glue.
‘Replenish glue’ on
page 54
Trimmer waste
unit is full.
Status in the dashboard (see ‘Check
the status of the
trimmer waste unit’
on page 78)
Remove cuttings
from the trimmer
waste tray.
‘Discard cuttings’ on
page 52
Defective booklets.
Error scenario
Remove the paper
stack of the defective booklets from
the stacker.
‘Remove finished
booklets’ on page
49
Stacker is full.
Error scenario
Remove the finished booklets from
the stacker.
‘Remove finished
booklets’ on page
49
Chapter 4 - Troubleshooting
83
Reduce frequent paper jams or errors
Reduce frequent paper jams or errors
Introduction
Frequent paper jams, errors or defect in binding such as follow can mean that paper is
curled or paper weight is out of available range for this machine.
• Defect in attaching the glue.
• Unequal cutting size.
• Folded bonding area in corner of inserted paper.
If paper jams, errors or defect in binding occur frequently, refer to the instructions described below to confirm paper curl and perform the curl correction, or see ‘Specifications’
on page 90 to confirm available paper weight of this machine. Also before performing
perfect binding, we recommend you to check the curl state of the used paper.
• Loaded from the sheet inserter.
Confirm the paper does not curl. If paper is curled, be sure to remove the curl before
loading it into the sheet inserter again.
• Loaded from the printer.
If the paper which is loaded from the printer is curled, follow the procedure below to
perform curl correction.
Reduce frequent paper jams or errors
1. Select the paper source in the printer used for perfect binding.
2. Make copies without performing perfect binding and discharge the paper to the finisher.
3. Confirm the curl is in the range of specified value.
The specified values are as follows:
• Height of curl (1): -10 to +10 mm.
• Length of curl (2): More than 50mm
#
NOTE
If downward curl is measured, it may cause incorrect value since the curl is negated.
Be sure to measure upward curl.
84
Chapter 4 - Troubleshooting
Reduce frequent paper jams or errors
4. If the curl state of paper exceeds specified value, adjust the curl correction to make it an
appropriate range.
You can adjust the curl correction for a specific paper in the Settings Editor, section
'Media management', option 'Printer adjustment'.
#
NOTE
If the curl can not be corrected within the specified range by following the adjustment
above, or paper jams, errors or defects in bindings occur frequently, load other paper
type into the paper source.
Chapter 4 - Troubleshooting
85
Power does not turn on
Power does not turn on
Power does not turn on (breaker test)
1. If the product does not operate when you turn on the power switch, be sure to check if
the breaker is OFF.
2. If the breaker is OFF, do not reset it. Contact your local authorized dealer.
#
WARNING
If the product's breaker is tripped, do not reset it.
Doing so creates the risk of electric shock, fire, smoke, or tripping the room's
breaker.
86
Chapter 4 - Troubleshooting
When the main power is turned off during operations (check the stacker)
When the main power is turned off during operations (check
the stacker)
Introduction
If the main power is tuned off during operations, the cuttings may remain in the stacker.
When the main power is turned off during operations (check the stacker)
1. After turning the main power on again, open the stacker and check if the cuttings remain
in it.
2. If the cuttings remain in the stacker, remove all of the cuttings from the stacker.
#
CAUTION
Do not operate the machine when the cuttings remain in the stacker, as this may
result in a malfunction.
Chapter 4 - Troubleshooting
87
When the main power is turned off during operations (check the stacker)
88
Chapter 4 - Troubleshooting
Chapter 5
Appendix
Specifications
Specifications
Specifications of the Perfect Binder-B1
Perfect Binder-B1#
Item
Specifications
Binding
method
Perfect binding
Cutting
method
Stack rotation 3-direction or 1-direction (foredge)
cut
(no cutting is also possible)
Booklet size
(after 3-direction cutting)
Width: 203 to 297 mm
Length: 138 to 216 mm
Booklet thickness
Approximately 1 to 25 mm (not including covers)
Cutting range
Top/bottom: 13 to 79 mm, foredge: 6.5 to 49.5
mm
Body pages /
slip sheets
Number of
sheets
• Paper weight 60 to 63 g/m2: 30 to 200 sheets
(booklet thickness: 25 mm or less)
• Paper weight 64 to 80 g/m2: 10 to 200 sheets
(booklet thickness: 25 mm or less)
• Paper weight 81 to 105 g/m2: 10 to 150 sheets
(booklet thickness: 25 mm or less)
• Paper weight 106 to 163 g/m2: 1 to 10 sheets
(slip sheets only)
90
Chapter 5 - Appendix
Sizes
Width: 257.0 to 320.0 mm
Length: 182.0 to 228.6 mm
LTR, A4, B5, SRA4 (225 x 320 mm) (8.86" x
12.60")
Paper weight *1
60 to 163 g/m2
Specifications
Item
Covers
Paper that can
go through the
binder/passthrough transfer section
Specifications
Number of
sheets
1 sheet
Sizes
Width: 257.0 to 330.2 mm
Length: 364.0 to 487.7 mm
A3, 11" x 17", B4, SRA3 (320 x 450 mm) (12.60"
x 17.72")
Paper weight *2
90 to 300 g/m2
Sizes
According to the printer specifications
Paper weight *1
60 to 325 g/m2
Glue capacity
Approximately 380 g (Enough for approximately
135 booklets when binding 100 sheets of A4 80
g/m2 *3
*
Including the capacity of the glue container.
Trimmer
waste unit capacity
When binding 100 A4 pages and cutting them to
B5 size: Space for cuttings from approximately 15
booklets. *3
Stacker capacity
Approximately 127 mm (equivalent to 10 booklets
of 100 pages of 64 g/m2 body / slip sheets and a
cover of one 128 g/m2 sheet *3) or approximately
1000 sheets as a total.
Warm up time
440 seconds max. (Temperature: 20°C, Humidity:
50% RH)
Installation environment
Temperature 15 to 27°C
Humidity 20 to 80% RH (no condensation)
Power
208 V AC, 60Hz, 2.6A
Maximum
power consumption
Approximately 623 W
Dimensions *4
922 mm (W) x 791 mm (D) x 1360 mm (H)
(including document insertion unit)
Weight
Approximately 323 kg (including document insertion unit)
Chapter 5 - Appendix
91
Specifications
*1
Paper weight differs depending in the connected host machine.
Use grain short paper for covers if the paper has a weight that is 251 g/m2 or higher.
*3
These values are for reference purposes. They may differ from actual values.
*4
These values do not include the size of the port and the power cord on the back of the
machine.
*2
Specifications of the Document Insertion Unit
Document Insertion Unit#
92
Item
Specifications
Paper size
Upper tray
Width (side to side): 257.0 to 320.0 mm
Length (in direction of transfer): 182.0
to 228.6 mm
Lower tray
Width (side to side): 257.0 to 330.2 mm
Length (in direction of transfer): 182.0
to 487.7 mm
Paper feed capacity
Upper tray: 200 sheets (80 g/m²)
Lower tray: 200 sheets (80 g/m²)
Power
Supplied from Perfect Binder
Maximum power consumption
Operating: 72 W or less
In standby: 1 W or less
Chapter 5 - Appendix
Glossary
Glossary
#
Description
Perfect binding
A binding method that used glue to bind the body pages into a
cover.
This machine does not need to mill (grind) the body pages to firmly
attach the covers to the body pages.
Foredge
The outside edge of the book where the book opens (opposite of
the spine).
Cut when doing 3-direction of 1-direction cutting.
Slip sheets
Paper that separates part of the body pages into text blocks or
chapter pages.
Bottom
The lower edge of the book.
Cut when doing 3-direction cutting.
Top
The upper edge of the book.
Cut when doing 3-direction cutting.
Grain short
Paper whose fibers run parallel to the short dimension of the sheet.
Use grain short paper for covers if the paper has a paper weight that
is 251 g/m² (140 lb Index) or higher.
Chapter 5 - Appendix
93
Index
Index
Adjust
Glue amount ..................................................82
B
Binder
Cleaning .........................................................57
Binder transfer section
Binder transfer section ....................................28
Binding position
Binding position .............................................28
Blade
Status ..............................................................83
Blade receptor
Status ..............................................................83
Body page
Number of sheet .............................................90
Paper ..............................................................39
Paper weight ...................................................90
Size .................................................................90
Bookbinding procedure
Bookbinding procedure ..................................30
Booklet
Finished ..........................................................49
Size ..........................................................42, 90
Thickness .......................................................90
Bottom
Bottom ...........................................................93
Breaker
Breaker .......................................21, 23, 26, 86
Checklist sheet ................................................23
Test .........................................................21, 23
Test button .....................................................26
C
Capacity
Document Insertion Unit ...............................92
Glue ...............................................................90
Stacker ............................................................90
Trimmer waste unit ........................................90
Caution label
Caution label ..................................................16
Cleaning
Cleaning ..................................................18, 57
94
Consumables
Consumables ..................................................19
Cover
Cover ..............................................................80
Number of sheet .............................................90
Paper ..............................................................39
Paper weight ...................................................90
Size .................................................................90
Cover position
Cover position ................................................80
Adjust .............................................................80
Curl
Curl ................................................................84
Cutter section
Cutter section .................................................28
Cutting method
Cutting method .......................................42, 90
Cutting range
Cutting range ...........................................43, 90
Cuttings
Cuttings .........................................................52
Remove ..........................................................52
D
Define
Perfect binding ...............................................38
Dimension
Perfect binder .................................................90
Disable perfect binding
Disable perfect binding ............................38, 60
Disposing of the machine
Disposing of the machine ...............................20
Document Insertion Unit
Capacity .........................................................92
Paper size ........................................................92
Power .............................................................92
Specifications ..................................................92
E
Energy save mode
Energy save mode ...........................................35
Energy saver
Energy saver ...................................................35
LED .........................................................26, 35
Error
Error ...............................................................84
Reduce ...........................................................84
Error handling
Index
Error handling .....................61, 65, 71, 73, 83
Breaker ...........................................................86
Perfect binding ...............................................60
Power .......................................................86–87
Stacker ............................................................87
Error scenario
Error scenario .................................................83
Perfect binding ...............................................60
F
FCC
FCC ...............................................................10
Finished booklet
Finished booklet ................................42, 49, 81
Defective ........................................................83
Problem ..........................................................81
Foredge
Foredge ...........................................................93
Front cover
LED ...............................................................26
Left .................................................................26
Paper jam .......................................................65
Right ..............................................................26
G
Gathering tray
Gathering tray ................................................28
Transfer section ..............................................28
Glue
Glue ...........................................19, 54, 79, 81
Capacity .........................................................90
Refill ...............................................................54
Replenish ........................................................54
Status .......................................................79, 83
Glue amount
Glue amount ..................................................81
Adjust .............................................................82
Glue container
Glue container .........................................54, 79
Status .......................................................79, 83
Glue container icon
Glue container icon ........................................79
Glue icon
Glue icon ........................................................79
Glue unit
Glue unit .................................................26, 54
Gluing section
Gluing section ................................................28
Grain short
Grain short .....................................................93
I
Inner cover
Sheet inserter ..................................................32
Inserter transfer section
Inserter transfer section ...................................28
Installation
Installation .....................................................12
Environment ..................................................90
Location .........................................................12
L
Legal notices
Legal notices ...................................................10
Load paper
Lower tray ......................................................46
Orientation .....................................................45
Sheet inserter ..................................................45
Upper tray ......................................................46
Lower tray
Load paper ......................................................46
Paper jam .......................................................75
Sheet inserter ..................................................32
M
Main power
Main power ..........................15, 33–34, 86–87
Perfect Binder .................................................90
N
Number of sheets
Body page .......................................................90
Cover ..............................................................90
Slip sheet ........................................................90
O
Orientation
Load paper ......................................................45
P
Paper
95
Index
Paper ..............................................................39
Body page .......................................................39
Cover ..............................................................39
Curl ................................................................84
Size .................................................................40
Slip sheet ........................................................39
Type ...............................................................39
Weight ...........................................................40
Paper jam
Paper jam ......................61, 65, 71, 73, 83–84
Front cover .....................................................65
Lower tray ......................................................75
Reduce ...........................................................84
Sheet inserter ..................................................73
Stacker ............................................................71
Top cover .......................................................61
Upper tray ......................................................73
Paper size
Document Insertion Unit ...............................92
Paper weight
Body page .......................................................90
Cover ..............................................................90
Slip sheet ........................................................90
Pass-through transfer section
Pass-through transfer section ..........................28
Perfect Binder
Specifications ..................................................90
Perfect binder
Cleaning .........................................................57
Dimension ......................................................90
Weight ...........................................................90
Perfect binding
Perfect binding .........................................38, 93
Define ............................................................38
Disable ...........................................................38
Troubleshooting .............................................60
Perfect-bound book
Perfect-bound book ........................................38
Power
Power ...................................15, 33–34, 86–87
Cord ...............................................................15
Document Insertion Unit ...............................92
Perfect Binder .................................................90
Supply ............................................................15
Power consumption
Document Insertion Unit ...............................92
Perfect Binder .................................................90
Power switch
Power switch ..................................................26
96
R
Right guide
Sheet inserter ..................................................32
S
Sheet inserter
Sheet inserter ..............................26, 28, 32, 45
Inner cover .....................................................32
Load paper ......................................................45
Lower tray ......................................................32
Paper jam .......................................................73
Right guide .....................................................32
Slide guide ......................................................32
Top cover .......................................................32
Upper tray ......................................................32
Size
Body page .......................................................90
Cover ..............................................................90
Slip sheet ........................................................90
Slide guide
Sheet inserter ..................................................32
Slip sheet
Slip sheet ........................................................93
Number of sheets ............................................90
Paper ..............................................................39
Paper weight ...................................................90
Size .................................................................90
Specifications
Specifications ..................................................90
Document Insertion Unit ...............................92
Perfect Binder .................................................90
Stacker
Stacker .....................................................26, 28
Capacity .........................................................90
Error handling ................................................87
Full .................................................................83
Full LED ........................................................26
Open button ..................................................26
Open button LED ..........................................26
Paper jam .......................................................71
Remove booklet ..............................................49
Status
Blade ..............................................................83
Blade receptor .................................................83
Glue .........................................................79, 83
Glue container .........................................79, 83
Trimmer waste unit .................................78, 83
