Canon Satellite TV System DT 9500 CI User's Manual

Digital Satellite Receiver
CryptoWorks Embedded
User's Manual
The product image may differ from the actual product.
Notice
Thank you for purchasing a HUMAX product. Please read this user manual carefully, to be able to safely install, use and maintain the
product at maximum performance. Keep this user manual next to your product for future reference.
Throughout the whole manual, Note indicates additional product operation information to make the user aware of possible problems and
information of any importance to help the user understand, use and maintain the installation.
**
Manufactured under license from Dolby Laboratories.
**
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
**
All other trademarks are the properties of their respective owners.
**
Copyright © 2006 HUMAX Corporation
**
Not to be copied, used or translated in part or whole without HUMAX's prior consent in writing except approval of ownership of copyright
and copyright law.
**
The information in this document is subject to change without notice.
GB 1
Safety Warning
**
The product has been manufactured to satisfy international safety standards. Please read the following safety precautions and
warnings carefully.
**
•
•
•
•
•
•
•
•
•
•
•
Disconnect the product from the mains before you start any maintenance or installation procedures.
Do not overload a wall outlet, extension cord or adapter as this may result in electric fire or shock.
The product should not be exposed to liquid of any kind. In addition, no objects filled with liquid, such as vases, should be placed on
the apparatus.
Do not stand the product on soft furnishings or carpets. Do not stack electronic equipments on top of the product.
Do not use any unsupported attachments as these may be hazardous or cause damage to the product.
Disconnect the product from the mains before connecting or disconnecting the cable from the antenna or TV.
The LNB cable must be earthed to the system earth for the satellite dish.
Place the product indoors to avoid exposing it to lightening, rain or sun. Do not place it near a radiator or heat register. Make sure it
has more than 10 cm clearance from any appliances susceptible to electromagnetic influences, such as a TV or a VCR.
Do not block these openings with any object, and do not place the product on a bed, sofa, rug or other similar surface. If you place the
product on a rack or bookcase, ensure that there is adequate ventilation and that you have followed the manufacturer's instructions for
mounting.
Do not place the product on an unstable cart, stand, tripod, bracket or table where it can fall. A falling product can cause serious injury
to a child or adult, and serious damage to the appliance.
Unplug the product from the wall outlet and disconnect the antenna during a thunderstorm or when left unattended and unused for
long periods of time.
Do not insert anything through the openings in the unit, where they can touch dangerous voltage points or damage parts.
When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those
that have the same characteristics as the original part. Unauthorised substitution may result in additional damage to the unit.
GB 2
Contents
1. Before Using the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Conditional Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB5
GB5
GB6
GB7
GB8
GB10
2. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Connecting Antenna/TV/VCR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Connecting Audio System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Powering On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB12
GB12
GB15
GB16
3. Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Viewing Programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Subtitle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Soundtrack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB17
GB17
GB18
GB19
GB19
GB20
4. Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB21
5. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 DIGITURK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Advanced Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Organise Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB23
GB23
GB24
GB29
GB32
6. System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 Time and Date Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3 A/V Output Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.4 UHF Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.5 Other Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.6 System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB33
GB33
GB33
GB34
GB34
GB35
GB36
GB 3
Contents
7. Parental Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 Parental Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2 Modify PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3 Front Panel Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB37
GB37
GB37
GB37
8. Channel List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.1 Switching Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2 Setting Property of Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.3 Favourite List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GB38
GB38
GB39
GB40
9. Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB41
10. Programme Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB42
11. Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB44
12. Conditional Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB45
13. Common Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB46
14. Software Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB47
14.1 OTA (Over the Air) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB47
15. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB49
16. Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB51
GB 4
1. Before Using the Product
1. Before Using the Product
This chapter provides detailed instructions on the product and its accessories.
1.1 Package Contents
When you unpack your package contents, make sure you have all the necessary items shown in the figure below. If any of the items are
missing or damaged, please contact your local product distributor for replacement.
**
**
Remote Control
**
Batteries
**
User's Manual
**
Warranty Card
**
SCART Cable
**
RCA Cable
**
RF Cable
**
**
Note: The product image may differ from the actual product.
GB 5
1. Before Using the Product
1.2 Front Panel
**
**
1. STANDBY Button
Switches between operation and standby modes.
**
5. DIGITURK CH LED
Amber light is emitted when viewing DIGITURK channel.
**
**
2. MODE Button
Switches between DIGITURK and OTHER modes.
**
**
6. STANDBY LED
Red light is emitted when the product is in standby mode.
**
**
3. CH-/CH+ Button
Moves the TV/radio channel up/down.
**
**
4. MAIL LED
Green light is emitted when the mail was received.
**
**
7. SMARTCARD SLOT
Slot for a Smartcard.
8. CI MODULE SLOT
Slot for a CI module.
**
Note: Refer to 1.4 Conditional Access when you insert the Smartcard.
GB 6
**
**
1.3 Rear Panel
**
**
1. LNB IN
7. AUDIO L/R
**
**
Connects to a satellite antenna cable.
Connects to the TV or VCR and outputs audio signals.
**
2. LNB OUT
**
8. RF OUT
**
**
Connects to another digital Set-Top Box.
Connects the RF output jack of the product and the RF
input jack on the TV with the RF cable.
The default UHF channel is 36.
**
3. RS-232C
**
Connects to your PC to update software.
**
4. TV SCART
**
Connects a TV SCART cable.
**
5. VCR SCART
**
Connects a VCR SCART cable.
**
6. VIDEO
**
9. RF IN
**
Connects the general aerial antenna and the RF input
jack of the product with the RF cable.
**
10. S/PDIF
**
Outputs digital audio signals (S/PDIF).
**
**
Connects to the TV or VCR and outputs video signals.
GB 7
1. Before Using the Product
1.4 Conditional Access
Although some TV and radio channels are free to air, most TV and radio/music channels are available on a subscription basis and can
only be enjoyed via Conditional Access component.
**
1. Inserting Smartcard
**
A Smartcard looks similar to a credit card and entitles you to view and listen to all the channels you choose to subscribe to. The
Smartcard slot on the product can be used for CryptoWorks Smartcard only.
**
1. Open the right-hand flap on the front panel of the product.
2. Hold the Smartcard horizontally with the electronic chip (small squared-shape, gold in colour) facing upwards.
3. Insert the Smartcard into the top slot.
**
GB 8
2. Inserting CI (Common Interface) Module
**
Your product is equipped with a slot for Common Interface (CI).
**
1. Open the right-hand flap on the front panel of the product.
2. Insert the Smartcard into the CI module, and the CI module into the slot.
**
GB 9
1. Before Using the Product
1.5 Remote Control
1. AV
**
Selects the input source between TV and the
product.
**
2. MODE
**
Switches between DIGITURK and OTHER modes.
**
3. NUMERIC BUTTONS
**
Enter a TV/radio channel number.
**
4. GUIDE (EPG)
**
Displays the programme guide.
**
5. i (INFORMATION) - WHITE
**
Displays the information about the channel and
programme.
**
6. ARROW BUTTONS
**
Changes channels or moves the cursor up, down, left
or right in menu option.
**
7. TIME – RED
**
Displays the current time on the screen.
**
8. FAV (Favourite channel) – GREEN
**
Displays Favourite channel list.
**
GB 10
9. CH-/CH+
17. LANGUAGE (SOUNDTRACK) – BLUE
**
**
Changes the channel.
Displays the a soundtrack list where available.
**
10. PP (Recall)
**
18. TXT (SUBTITLE) – YELLOW
**
**
Returns to the previous channel in each mode.
Displays the subtitle language list where available.
**
11. FREEZE
**
19. V-/V+
**
Freezes the scene you are watching. Does not cease
audio.
**
Adjusts the audio volume.
20. MUTE
**
**
12. WIDE
Mutes or unmutes the audio temporarily.
**
Changes the display format.
**
21. ZOOM
**
13. STANDBY
**
Switches between operation and standby modes.
**
Enlarges the picture.
22. TV/RADIO
**
**
Switches between TV and radio. Does not work in
DIGITURK mode.
14. OPTS
**
Displays the main menu.
**
15. BACK
**
Returns to the menu option.
16. OK
**
**
** COLOUR BUTTONS (R/G/B/Y/W)
**
Select color keys for interactive applications.
**
Selects a menu or confirms the selection. Displays
the channel list while watching a programme.
**
GB 11
2. Setup
2. Setup
This chapter describes how to set up the product. Select the most appropriate procedure depending on your requirements. Before you
connect the product to any other equipment, you must disconnect all equipments from their power sources.
Note: If you encounter any problem when setting up the product, please contact your local product distributor.
2.1 Connecting Antenna/TV/VCR
1. Using SCART Cable
**
**
1. Connect the antenna to the LNB IN of the product.
2. The SCART cable is connected as in the figure above.
GB 12
2. Using RCA Cable
**
**
1. Connect the antenna to the LNB IN of the product.
2. The RCA cable is connected as in the figure above.
GB 13
2. Setup
3. Using RF Cable
**
**
1. Connect the antenna to the LNB IN of the product.
2. The RF cable is connected as in the figure above.
**
Note: The default UHF channel is 36.
GB 14
2.2 Connecting Audio System
**
**
1. Connect the optical S/PDIF terminal and Dolby Digital decoder to listen to higher quality sound.
2. Connect VIDEO on the product and VIDEO IN on the TV using the RCA cable.
3. Connect AUDIO L/R on the product and AUDIO IN L/R on the audio system using the RCA cable.
GB 15
2. Setup
2.3 Powering On
**
1. Connect the power cord of the product to a wall outlet.
**
**
2. Press the STANDBY button on the front of the product or on the remote control.
**
GB 16
3. Basic Operation
3. Basic Operation
3.1 Installation Wizard
When powering on your product for the first time after purchase, the selecting
country screen is automatically displayed.
Select the required country using the
button and press the OK button. If
you select "Turkey", the DIGITURK Installation menu will be displayed. And if
you select other countries, the Advanced Installation menu will be displayed.
Note: For detailed information about searching channels, refer to 5.1.1
DIGITURK Installation and 5.2 Advanced Installation.
GB 17
3. Basic Operation
3.2 Viewing Programme
You can change the channel using the CH-/CH+,
You can adjust the audio volume using the V-/V+ or
or NUMERIC buttons. You can also use the Channel List or Programme Guide.
button.
**
Banner (Programme Information)
The banner is always displayed for a specific period of time whenever you switch channels. You can view the programme information by
pressing the i button while watching a programme. You can see the detailed information about the current programme by pressing the i
button twice. If the detailed information is more than one page, use the
button to move to the previous or next page. Press the
BACK button to hide the banner. You can adjust the display time of banner in MENU-System Settings-Other Setting-Banner Duration.
**
**
Represents parental level. Indicates the minimum level of
ages that the programme is targeted at.
**
Displayed only the programme is reserved.
**
Displayed only when the channel is a locked channel.
**
The channel group the programme is included in. Moves to
the channels within the group when the channel is switched.
GB 18
Displayed only when the channel is a scrambled channel.
**
Displayed only when subtitle information is available.
**
Displayed only when there is any teletext information.
**
Displayed only when the programme is braodcast in Dolby Digital.
3.3 Subtitle
If the current programme provides subtitle information, the subtitle icon will appear on the banner. You can select the language for the
subtitle using the TXT (SUBTITLE) button. You can select a default subtitle language in MENU-System Settings-Language
Setting-Subtitle Language.
**
3.4 Soundtrack
If the current programme is available in multiple audio languages, you can
select the language that you wish to listen in using the LANGUAGE
(SOUNDTRACK) button. You can select the default audio language in
MENU-System Settings-Language Setting-Audio Language.
GB 19
3. Basic Operation
3.5 Teletext
**
When the channel supports teletext, the teletext icon is displayed on the banner. To enter Teletext mode, use the TXT (SUBTITLE)
button to display teletext.
button and press the
To display teletext menu, press the OPTS button in teletext mode. Select your desired teletext function using the
OK button. To view the teletext page, use the CH-/CH+,
, PP or NUMERIC buttons.
GB 20
4. Menu Map
4. Menu Map
**
GB 21
4. Menu Map
Menu structure varies according to the item and its operation. You can easily navigate the menu using the following instructions:
**
1. Press the OPTS button to display the main menu screen.
**
2. Select the item you want using the
button.
**
3. Press the OK button to move from a menu to a sub-menu.
**
4. Press the
button to select option values.
**
5. Press the NUMERIC buttons to enter the option values.
**
6. Press the BACK button to return to the parent-menu.
**
7. Press the OPTS button to exit the menu screen.
**
**
Note: Some menu items are access controlled. When accessing to the protected menu, you will be prompted to enter the PIN
code. Enter the PIN code using the NUMERIC buttons. The default PIN code is set to "0000".
GB 22
5. Installation
5. Installation
5.1 DIGITURK
1. DIGITURK Installation
You can automatically search the channel without entering any other
information.
2. Change CAS Slot of All DIGITURK Channels
You can check the CAS slot currently in use and change the CAS slot of all
DIGITURK channels. Select the CAS slot you want using the
button and
press the OK button.
GB 23
5. Installation
5.2 Advanced Installation
You can search other channels except DIGITURK channel.
Enter the PIN code using the NUMERIC buttons. The default PIN code is set to "0000".
1. Antenna Setting
You can set antenna and LNB information to search channels using Antenna Setting (MENU-Installation-Advanced
Installation-Antenna Setting).
**
•
•
•
•
•
•
•
•
Antenna Alternative: Select antenna alternative which has different
combinations of settings for search. Antenna Alternative 16 is predefined
for SMATV.
Satellite Name: Displays the satellite list in name order. If the desired
satellite name is not listed, then select "User Defined". You can enter the
Satellite Name using the keyboard displayed on the screen.
LNB Frequency: Select the L.O (Local Oscillator) Frequency of the LNB.
22KHz Tone: When using the 22HKz tone switch, select "Enabled".
Otherwise, select "Disabled".
DiSEqC Input: If you are using DiSEqC (Digital Satellite Equipment
Control) switch to connect multiple antennas or LNBs, select DiSEqC input
to connect to antenna or LNB.
Motorised System: When using motorised system, select “Enabled”.
Otherwise, select “Disabled”. When Motorised System is set to “Enabled”
DiSEqC Input is disabled.
LNB Voltage: You can select "Standard" voltage or "High" voltage.
LNB Power: You can select "On" or "Off".
**
When you complete the settings, press the OK button to move to the Manual Search menu.
GB 24
2. Manual Search
You can search channels of the selected satellite by transponders using the transponder information.
**
•
•
•
•
•
•
•
•
Antenna Alternative: Select antenna alternative which has different
combinations of settings for search. Antenna Alternative 16 is predefined
for SMATV.
Frequency: Enter transponder frequency.
Polarisation: Select the type of polarisation.
Symbol Rate: Select or enter transponder symbol rate.
FEC: Select FEC (Forward Error Correction).
Network Search: If you want to search channels for multiple
transponders, select "Yes". Otherwise, select "No".
Automatic Skip: When skipping all scrambled channel search, select
"Yes". Otherwise, select "No".
Advanced: In advanced mode, enter Video Packet ID (PID), Audio PID,
and PCR PID.
**
After setting the parameters of search, press the OK button to start channel search. Wait until the operation is completed. After finishing
search operation, the result window will be displayed. You can delete the channels using the
and the RED button. To cancel
deleting operation, press the RED button again. The screen also shows the number of the channels found and the transponder
information.
To save the found channels, press the OK button.
**
Note:
• If the antenna is properly set up, the signal strength bar and quality bar level, located at the bottom of the screen moves up.
• Press the BACK button to stop search.
GB 25
5. Installation
3. Satellite Setting
This menu appears only when you enable Motorised System in Antenna Setting menu and press the OK button while Antenna
Alternative in Manual Search menu is selected.
**
•
Satellite Name: Select a satellite to identify a motor antenna. If the desired satellite name is not listed, then select "other".
**
•
Movement: In user mode, this is used to fine-tune the position of the motor. In installer mode, this is used to search for the position of
the satellite manually.
•
Motor Control: You can select one option among "Search", "Go to",
"Store" or "Reset".
**
- Search: Searches for channels on the selected transponder.
- Go to: Moves the motor to the saved position of the selected satellite.
- Store: Saves the current position of the motor for the selected satellite.
- Reset: Resets all saved positions of the motor relative to the 0 position.
(Installer Mode Only)
**
•
DiSEqC Command Mode: Select "Installer" or "User mode".
**
The following table shows the value of the motor setting options.
**
DiSEqC Command Mode
Movement
Motor Control
Installer
East / Stop / West
Search / Go to / Store / Reset
User
Stop(60E) ~Stop(0) ~Stop(60W)
Search / Go to / Store
GB 26
**
To initialise the satellite position saved at Motor Antenna, set DiSEqC Command Mode to "Installer", set Motor Control to "Reset", then
press the OK button. You will see a warning message. To continue the procedure, press the OK button.
To set the motor position for each satellite manually, select the Satellite Name, set DiSEqC Command Mode to "Installer", and then set
Movement to one option among "East", "Stop" or "West". The motor starts moving. The level of signal strength and quality bar at the
bottom of the screen will indicate the best position of the dish. Set Motor Control to "Store" when you find the best position, then press
the OK button to save the position.
To move the motor to the pre-set position of the satellite, select the desired Satellite Name, set DiSEqC Command Mode to "User", set
Motor Control to "Goto", and set Movement to the desired value. Movement is used to fine-tune the position of the motor. Press the OK
button. The motor will move to the position of the selected satellite.
**
4. Motor Limit Setting
To enter this menu, press the RED button in Satellite Setting menu. You can set the maximum for both East and West to prevent
damage to the antenna.
**
•
Limit Setting: When Limit setting is set to "Enabled", the motor does not
move exceeding the limit. When Limit setting is set to "Disabled", the
setting is released.
**
•
Movement: You can select one among "East", "Stop" or "West".
**
•
Store East Limit: You can save the East Limit.
**
•
Store West Limit: You can save the West Limit.
GB 27
5. Installation
5. Automatic Search
If you select the satellite to search channels according to Antenna Setting, you can automatically search the channel without entering
any other information.
To enter Automatic Search menu, press the OPTS button, then select Installation-Advanced Installation-Automatic Search.
**
•
Antenna Alternative: Select antenna alternative which has different
combinations of settings for search. The Satellite Name is automatically
displayed. Antenna Alternative 16 is predefined for SMATV.
**
•
Automatic Skip: When skipping all scrambled channel search, select
"Yes". Otherwise, select "No".
**
•
Search Type: If you want to search channels through all field of tuner
(950~2150MHz), select "Manual". Otherwise, select "Auto" to search
channels with the preset parameters. In detail mode, you can add the
desired Symbol Rate.
**
•
Network Search: If you want to search channels for multiple
transponders, select "Yes". Otherwise, select "No". When you complete
the setting, press the OK button to start channel search.
**
Note: Channels found during Advanced Installation menu shall be stored to the OTHER mode To switch between
DIGITURK and OTHER channels press the MODE button on remote control.
GB 28
5.3 Organise Channels
1. Organise All Channels
You can edit TV or radio channels using Organise TV/Radio Channels
(MENU-Installation-Organise Channels-Organise TV/Radio
Channels-Organise All Channels).
You will be prompted to enter the PIN code. The default PIN code is "0000".
Before leaving Organise TV/Radio Channels screen, you will be prompted to
save the changes. If you would like to save the changes, select OK and press
the OK button.
**
You can delete, move, lock or unlock, skip and rename channels. You can
select a channel and press the COLOUR button to execute the corresponding
operation as described on the screen.
When you rename a channel, the keyboard will appear on the screen. You can change the name using the keyboard. Select a character
using the
button and press the OK button to enter the selected character. After entering the new name, press the YELLOW
button to save it.
• To delete a character, press the BLUE button.
• To switch to the standard keyboard, press the RED button.
• To switch to the extended keyboard, press the GREEN button.
Note:
• You must enter the PIN code using the NUMERIC buttons to view the locked channels. The default PIN code is set to "0000".
• You are not allowed to organize DIGITURK channels, except of lock feature.
GB 29
5. Installation
2. Organise Favourite A~B
You can add channels to Favourite groups using Organise Favourite TV/Radio Channels (MENU-Installation-Organise
Channels-Organise TV/Radio Channels-Organise Favourite A~B). Before leaving Organise Favourite TV/Radio Channels screen,
you will be prompted to save the changes. If you would like to save the changes, select OK and press the OK button.
The Organise Favourite TV/Radio Channels screen consists of Favourite
Group and Favourite List on the left side of the screen and Channel List on
the right side. You can move the highlighter in order of Favourite Group,
Favourite List and Channel List using the button. You can move the
highlighter in reverse direction using the button.
To add channels to Favourite List, select a channel in Channel List using the
button, and press the OK button.
For more information about how to edit the channels in Favourite List, refer to
5.3.1 Organise All Channels.
GB 30
3. Organise Satellites
You can delete satellites and transponders.
To enter Organise Satellites menu, go to MENU-Installation-Organise
Channels-Organise Satellites.
The Organise Satellites screen consists of Satellite List on the left side of the
screen and Transponder List and Channel List on the right side. You can
move the highlighter in order of Satellite List, Transponder List and Channel
List using the button. You can move the highlighter in reverse direction using
the button.
You can select a satellite in Satellite List or transponder in Transponder List
using the
button. Press the RED button to delete the selected satellite or
transponder.
GB 31
5. Installation
5.4 Factory Settings
You can restore the product to the factory settings using the Factory Settings
menu (MENU-Installation-Factory Settings). You will be prompted to enter
the PIN code. The default PIN code is "0000".
For more information, refer to 5.1.1 DIGITURK Installation.
Warning: Please note that once you perform the factory setting, all data
except the customised PIN code will be restored to the factory
settings.
GB 32
6. System Settings
6. System Settings
The System Settings menu (MENU-System Settings) lets you customise your product according to your perference.
6.1 Language Setting
You can set the default language for menu, audio and subtitle.
**
6.2 Time and Date Setting
You can set the current time and turn the product on or off automatically.
Once you set the Wakeup time and Sleep time, the product is turned on and
off everyday.
Warning: When setting Wakeup Channel No., press the MODE button to
change the channel mode.
GB 33
6. System Settings
6.3 A/V Output Setting
This menu lets you adjust the audio and video output, set Dolby Digital, match
the screen ratio to your TV, select the display format according to the screen
ratio, select the TV standard and set the NTSC mode.
Note: You can choose the Dolby Digital audio stream whenever possible
by selecting "ON" in the Dolby Digital setting.
6.4 UHF Tuning
You can select UHF Channels for your TV and adjust fine tuning setting. The channel range and frequency change according to PAL
Standard. The default UHF channel is 36.
GB 34
6.5 Other Setting
You can adjust the transparency level of On-Screen Display (OSD), set the
duration of the banner when switching channels, select automatic or manual
mode for changing to reserved channel and set the duration of the reminder.
GB 35
6. System Settings
6.6 System Information
The System Information menu (MENU-System Settings-System
Information) provides information such as STB status, signal level of channel
and software upgrade.
Note:
• You can also display STB Status by pressing i and OK button.
• For more information about software upgrade, refer to 14. Software
Upgrade.
GB 36
7. Parental Control
7. Parental Control
The Parental Control menu (MENU-Parental Control) lets you control the
access to programmes by programme rating.
Note: Enter the PIN code using the NUMERIC buttons. The default PIN
code is set to "0000".
7.1 Parental Rating
Set Parental Rating by age level. “no block” allows you to watch programmes without any blocking. You can block all programmes
regardless of age level. The blocked programmes require the PIN code.
**
7.2 Modify PIN code
We recommend you to change the old PIN code to a new one periodically to ensure. If you have forgotten your PIN code, please contact
your local product distributor. The default PIN code is set to "0000".
**
7.3 Front Panel Lock
You can lock the front panel. When setting “Lock”, all buttons on the front panel except the STANDBY button do not work.
GB 37
8. Channel List
8. Channel List
There are five types of channel lists – All, Favourite, Network, Satellite, Alphabet - to find channels you are interested in quickly and
easily. All channel lists display all searched TV or radio channels sorted by channel number. Favourite channel list displays favourite
channels with three predefined sub-groups and two user defined sub-groups. Network channel list displays channels with several network
subgroups. Satellite channel list displays channels classified by satellites. Alphabet channel list displays all searched TV or radio channels
sorted by channel name.
8.1 Switching Channels
1. Press the OK button while watching a programme to display the channel
list. You can also display the channel list using the MENU-Channel
List-Simple (or Advanced).
2. Press the COLOUR button to display the corresponding channel list. RED
(All channel list), GREEN (Favourite channel list), YELLOW (Network
channel list), BLUE (Satellite channel list), WHITE (Alphabet channel list)
3. Select a channel using the
, CH-/CH+ or NUMERIC buttons and
press the OK button to change to the selected channel.
**
Note:
• Press the MODE button to switch between DIGITURK and OTHER
channel list.
• Except in DIGITURK channel list, whenever you press the TV/RADIO
button while the channel list is displayed, the channel list will be switched
between TV and radio channel list.
• There are four user defined sub-groups (A~D) in DIGITURK Favourite
channel list.
GB 38
8.2 Setting Property of Channel
You can add the current channel to Favourite group. In addition, you can lock, unlock, skip or delete the current channel while watching a
programme.
The operation is as follows:
1. Press the OK button while watching a programme. The channel list will
appear on the screen. You can also display the channel list using the
MENU-Channel List-Simple (or Advanced). You can select the type of
the channel lists (All, Favourite, Network, Satellite, Alphabet) by pressing
the COLOUR button.
2. Press the OPTS button while the channel list is displayed.
3. Select an option (Favourites/Lock or Unlock/Skip/Delete) using the
button and press the OK or
button.
4. After setting property of a channel, press the OK or BACK button to save
the changes.
Note:
• There are two sub-groups in the TV and radio Favourite channel list.
• When unlocking a channel, you will be prompted to enter the PIN code. The default PIN code is set to "0000".
• When switching to a locked channel, you must enter the PIN code to view the channel.
• You will not be able to watch skipped channels by using the CH-/CH+ button. However, you can watch the skipped channels using the
NUMERIC buttons or Channel List.
• For detailed information about how to register all channels as Favourite Channel, refer to 5.3.2 Organise Favourite A~B and 8.3
Favourite List.
• Skip and Delete are not available for DIGITURK channels.
GB 39
8. Channel List
8.3 Favourite List
You can check and edit Favourite list quickly and easily.
1. Press the FAV button to display Favourite list while watching a
programme.
2. Press the RED button to display the all channel list. Select the channel
you want to add to Favourite list and press the OK button. Press the
BLUE button to view the channel you select. To close the all channel list,
press the BACK button.
3. Press the GREEN button while displaying Favourite list to switch between
Favourite A and B.
4. Press the YELLOW button to move the channel to the location you want.
**
Note:
• Press the MODE button to switch between DIGITURK and OTHER channel list.
• There are four user defined sub-groups (A~D) in DIGITURK Favourite channel list.
GB 40
9. Utility
9. Utility
The product provides various utilities: calendar, biorhythm and games. To use
utilities, go to MENU-UTILITY.
1.Calendar
You can see the monthly calendar. Press the
button to change the year.
Press the
button to change the month. Press the OK or BACK button to
return to the previous menu.
2. Biorhythm
You can adjust your birth year and date to see your current biorhythm status.
Press the
button to move to the next step. Press the
button to
change a value in the step. Press the BACK button to return to the previous
menu.
3. Games
You can select games using the
the screen.
button. Use the
, OK, COLOUR or BACK button according to the instructions displayed on
GB 41
10. Programme Guide
10. Programme Guide
The programme guide provides the programme information for all channels,
based on date and time. In addition, it provides convenient ways to view
programmes in "Now", "Next", "Weekly" or "Quick" mode - to search your
desired programme and to watch or reserve it.
You can go to the programme guide screen by just pressing the GUIDE button
or by using MENU-EPG. To close the guide screen, press the GUIDE or BACK
button.
**
You can navigate the guide using the following instructions:
• Press the RED button to display the current or next programme list.
• Press the GREEN button to display the programme list for a week.
• Press the YELLOW button to display the reserved programme list.
• Press the BLUE button to display the simple Guide. This is also called
Quick Guide.
GB 42
**
•
•
•
•
Press the WHITE button to reserve the selected programme in "Now",
"Next", "Weekly" or "Quick" mode.
Press the WHITE button to change the reservation mode or to cancel the
reservation in Reserved mode.
Select a channel using the
or CH-/CH+ button. When switching
channels using the
button, press the OK button to display the selected
channel on the right side of the screen.
Select a day in "Weekly" mode using the
button, and press the OK
button.
**
Note:
• Press the TV/RADIO button to switch to Radio Guide.
• The reservation icons on the reserved programmes in the guide differ according to the reservation type.
•
•
•
Once
Reserve the programme once.
Daily
Reserve the programme everyday.
Weekly
Reserve the programme once a week.
If the programme is overlapped with another programme, adjust the reservation appropriately. If the channel is locked, restricted by
watching time, you will be prompted to enter your PIN code to complete the reservation.
Press the MODE button to switch between DIGITURK and TV Guide.
Press i button in the selected programme to view the detail information. And you can also make a reservation in the detail information
screen.
GB 43
11. Mail
11. Mail
You receive mails sent by broadcasting company. When a new mail arrives, the
envelope icon will appear on the screen. Sometimes a new message will be
directly displayed on the screen while you are watching a programme. The old
mails will be deleted automatically when your mail box overflows. Select a mail
using the
button, then press the OK button to read the mail. The message
will be displayed. If you would like to delete the read mail, select Delete, and
press the OK button.
GB 44
12. Conditional Access
12. Conditional Access
You can check the information of Internal or External Smartcard using the
MENU-Conditional Access.
GB 45
13. Common Interface
13. Common Interface
You can check the information of CI module using the MENU-Common
Interface.
GB 46
14. Software Upgrade
14. Software Upgrade
In order to maintain proper performance of the product, it is essential to have the most up-to-date software.
14.1 OTA (Over the Air)
OTA, an abbreviation of Over–the-Air, is a standard for the transmission of software through a broadcast system.
OTA is simply an alternative method for downloading software versions. However, the manufacturers reserve the right for deciding the
release of the software for their products by beaming the latest software versions over the air via satellite. Note that OTA is only limited to
certain geographical regions mainly due to different antennas having different footprints(area where the signal can be received). The
software update via satellite will only occur under the following circumstances.
**
1. The equipment should have appropriate loader software.
Caution:
Please note that if normal loader software is not equipped, the product may not be updated or operate
properly after software update.
2. The manufacturer decides to release the software via a designated satellite.
3. The equipment must be tuned properly to the same antenna equivalent to that of the manufacturer.
4. Update software when the signal strength and quality is high. If the weather is not favorable, and the signal strength and quality are
not recommendable, perform the software update later.
**
Caution:
• Please be careful to keep the power on and the power cord plugged in during software update. If the power is off during software
update, fatal damage may be caused to the product.
• Please be careful not to pull out the signal line (LNB cable) during software update. Update may be interrupted and the product may
not operate.
**
Note
• Other functions will not activate while software update takes place.
• It may take 5 ~10 minutes to update software.
• Scheduling operation cannot work during software update.
GB 47
14. Software Upgrade
Updating software is largely divided into two ways, automatic and manual search in MENU-System Settings-System
Information-Software Upgrade.
Select Automatic Search to search pre-defined DIGITURK TPs for new software automatically. When new software is available to
download, the product will be automatically powered off and on.
If new software is not found by automatic update, use manual update.
For more information about how to set the manual search, refer to 5.2.2 Manual Search.
GB 48
15. Troubleshooting
15. Troubleshooting
Before contacting your local service, please read the following instructions. If the product does not work normally after completing the
following troubleshooting, please contact your local product distributor or service centre.
**
1. The LED on the front panel does not light.
- Check the main power cable and make sure that it is plugged into a suitable power outlet.
**
2. No picture
- Make sure that the product is in operation mode.
- Make sure that the AV Cable is firmly connected to the TV.
- Make sure that the antenna line is correctly connected to the equipment.
- Check the brightness level of TV.
- Check if the channel is on air.
**
3. Poor picture or sound quality
- Make sure there is no mobile phone or microwave oven near the equipment.
- Check the signal strength and quality which can be influenced by weather.
- Change satellite dish into a bigger one if it is small.
- Replace the LNB with a one with low noise factor if the noise factor is high.
- Replace the LNB with a new one if it is damaged or out of order.
**
4. No or poor sound
- Check the volume level of the TV and product.
- Check the mute status of the TV and product.
- Press the SOUNDTRACK button to change the audio type.
GB 49
15. Troubleshooting
5. Remote control does not operate
- To manipulate the equipment with the remote control, its emitting part should directly point towards its receiving part of the product.
- Check the battery of the remote control.
**
6. Reservation is unavailable
- Check if it is not overlapped with other reservation.
- Check if the power is off.
**
7. Watching scrambled channel is not available
- Make sure the correct Smartcard is plugged in.
- Make sure the Smartcard is correctly inserted, and insert the Smartcard again.
- Check if the Smartcard is damaged.
- Make sure you have subscribed to the channel.
GB 50
16. Specification
16. Specification
**
MPEG Transport Stream A/V Decoding
Power Supply
Aspect Ratio
Video Resolution
Audio Mode
Input Voltage
Type
4:3, 16:9
720 x 576, 720 x 480
Single /Dual mono/ Stereo /Joint
stereo
Power Consumption
Memory
Protection
Flash Memory
Graphics(MPEG) &
System Memory
EEPROM
2 Mbytes
16 Mbytes
8 Kbytes
RF-Modulator
Output Channel
TV standard
Preset Channel
CH 21 ~ 69
PAL I/G/B/D/K
CH 36
AC 90 ~ 250V, 50/60Hz
Switching Mode Power Supply
(SMPS)
Operation mode: Max. 30 W
Standby mode: Max. 30 W
Separate internal fuse & Lightning
protection
Physical Specification
Size
Weight (Net)
Operating
Temperature
Storage Humidity
310 mm X 60 mm X 237 mm
1.8 kg
0 to +45
5% ~ 95% RH (Non-condensing)
A/V & Data In/Out
TV SCART
VCR SCART
S/PDIF
Video Output (CVBS, RGB, S-Video)
Audio Output
Video Output (CVBS, S-Video)
Video Input (CVBS, RGB, S-Video)
Audio Output
Digital Audio Output, Fiber-Optic
(Resolution: 20 bits)
GB 51
