Electrolux Dito 603310 User's Manual

KE180
KE180 variable speed food
processor has a vertical spindle
and is designed for use in catering
kitchens and the food preparation
industry. This allows mixing and
mincing to be performed in a
matter of seconds which preserves
the texture and flavour of the
products.
603310
FEATURES
V The standard version is equipped with a 400 V
three phase variable speed motor, situated at the
rear of the food processor with the transmission
at the bottom of the machine.
V The motor drives the angled cutter at variable
speed from 300 to 3000 rpm.
V The speed of rotation allows all sorts of
preparations to be carried out in a matter of
seconds:
- Mincing meats (tartare, sausage meat, pâtés,
stuffing, mousses, etc.)
- Chopping condiments (parsley, garlic, onions,
shallots, spices, etc.).
- Preparation of mayonnaise, mashes, flavoured
butters, purées, compotes, etc.
- Liquidising frozen foodstuffs, fish soups with
shellfish, etc.
- Preparation of all types of pastry.
- Pastrywork (almond paste, sugared almonds,
half and half, etc.).
Food Processors
Item
Model
ProjectName
V The stainless steel bowl is supplied complete with
V Operator safety is guaranteed by the presence of
a leak resistant spout and has a transparent lid with
a watertight seal and a large central rotating shaft
that allows liquids to be mixed without overflowing.
V The spout allows products to be added in
mid-cycle without stopping the machine.
V The blades are angled and the base of the bowl is
conical to ensure consistent mixing every time.
a magnetic microswitch which stops the machine
whenever the lid or the bowl are not correctly
positioned.
V A safety device stops the machine from restarting
after a power cut until the operator presses the start
button.
V Touch control panel allows the entire machine to
be cleaned with a jet of water (IP66 water
protection).
Specifications
MODEL
External dimensions - mm
width
depth
height
Chopping capacity - kg/cycle
condiments
Mincing capacity - kg/cycle
meats
Preparation mayonnaise/sauces - kg/cycle
mayonnaise
Pastry preparation - kg/cycle
Power - kW
installed-electric
Net weight - kg.
Supply voltage
KE180F
603310
416
680
603
5
8
8
6
3
68
380/440 V, 3, 50/60
Included accessories
CODE
653272
653119
DESCRIPTION
17.5 LITRE S/S BOWL FOR CUTTER-MIXER
SMOOTH BLADE ROTOR FOR 17.5 CUTTER-MIXER
1
1
Optional accessories
CODE
653272
653279
653017
653120
653539
653119
DESCRIPTION
17.5 LITRE S/S BOWL FOR CUTTER-MIXER
EQUIPPED SCRAPER FOR 17.5L CUTTER-MIXER
S/S MOBILE STAND
SERRATED BLADE ROTOR -17.5L CUTTER-MIXER
SERRATED ROTOR-MEAT-17.5L CUTTER-MIXER
SMOOTH BLADE ROTOR FOR 17.5 CUTTER-MIXER
✓
✓
✓
✓
✓
✓
Installation drawings
XXX
I
726
820
1245
I
430
680
KE180F
603310
380/440 V, 3, 50/60
MODEL
I - Electrical connection
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
www.dito-electrolux.com
ABH010
590
416
Food Processors
603310
