ITEM #
MODEL #
NAME #
Spin Dryers
Vegetable Washer & Spin
Dryer, 2/6kg
SIS #
AIA #
Main Features
Spin Dryers
Vegetable Washer & Spin Dryer, 2/6kg
660072 (LVA100B)
Vegetable Washer & Spin
Dryer, 2/6 Kg - 230V/1/50
• Lid microswitch prevents the maching from operating
with the lid open.
• Electromagnetic device stops the machine if lid is lifted
during operation.
• Easy to clean, efficient filter system.
• Three automatic washing cycles (with or without
sanitation), manual draining and manual spinning.
• Two turbulence levels (soft for light vegetables, and
strong for heavy vegetables).
• Immersion wash or spray wash (tub filled at low level).
• Drain through solenoid valve.
• Peristaltic dispenser to add sanitizing during
immersion wash.
• Supplied with:
-304 stainless steel basket with small square roundish
holes (5x5 mm) - 921014.
• 500 ml tank placed in front of the machine to be filled
with the sanitizing product.
• Self-braking motor to stop the basket rotation as soon
as the cover is lifted (magnetic micro).
• Load per cycle: 2-3 kg (light vegetables); 6 kg (heavy
vegetables).
Construction
• Bearing frame, external panelling, lid and extractable
basket in 304 AISI stainless steel.
• Basket support in corrosion resistant aluminum.
• Spin rotation speed of 270 rpm.
• Two speeds pump for immersion wash and spray
wash.
Short Form Specification
Item No.
Included Accessories
• 1 of Basket with square holes (5x5
mm) for vegetable washer
Optional Accessories
PNC 921014
• Basket with square holes (5x5 mm) for PNC 921014
vegetable washer
❑
APPROVAL:
Electrolux Professional
www.electrolux.com/foodservice
foodservice@electrolux.com
Spin Dryers
Vegetable Washer & Spin Dryer, 2/6kg
Combi machine to wash and dry in a unique compact footprint. Constructed
in 304 AISI stainless steel, it provides 3 automatic washing cycles with or
without sanitation, manual draining and manual spinning. The washing
effect is obtained by combining basket rotation and water turbulence
generated by a two speeds pump. Equipped with a 500 ml frontal tank, to
be filled with the sanitising product, automatically introduced via peristaltic
pump during the washing. Flat and waterproof (IPX5) touch button control
panel. Lid safety micro switch prevents operation when the lid is open during
use. Self braking motor is stopping the basket rotation immediately. Very
efficient and easy to clean filter system. Rounded corners of the well facilitate
cleaning operations.
Supplied with 304 AISI stainless steel basket with small squared holes (5x5
mm).
Load per cycle: 2-3 kg (light vegetables); 6 kg (heavy vegetables). Washing
speed: 60 rpm - Spin drying speed: 270 rpm.
Spin Dryers
Vegetable Washer & Spin
Dryer, 2/6kg
Front
Electric
Supply voltage:
660072(LVA100B)
230 V/1N ph/50 Hz
Key Information:
Top
Well Capacity:
Usable well capacity:
Load per cycle - light vegetables:
Load per cycle - heavy vegetables:
Rotation Speed:
External dimensions, Height:
External dimensions, Width:
External dimensions, Depth:
Shipping weight:
30 lt
30 litres
2-3
6
270 RPM
1000 mm
700 mm
700 mm
117 kg
CWI
= Cold Water inlet
D = Drain
EI = Electrical connection
Side
Spin Dryers
Vegetable Washer & Spin Dryer, 2/6kg
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2013.03.11
