Getting Started
The only warranties for Hewlett-Packard products and services are set forth in the express
statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
HP assumes no responsibility for the use or reliability of its software on equipment that is not
furnished by HP.
This document contains proprietary information that is protected by copyright. No part of this
document may be photocopied, reproduced, or translated to another language without the prior
written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
Copyright © 2007 Hewlett-Packard Development Company, L.P.
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited pay-per-view viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Microsoft and Windows Vista are U.S. registered trademarks of Microsoft Corporation.
The Windows logo and Windows Vista are trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries/regions.
HP supports lawful use of technology and does not endorse or encourage the use of our products
for purposes other than those permitted by copyright law.
The information in this document is subject to change without notice.
Table of Contents
Setting Up the Computer ..........................................................................1
Putting the Computer Together .................................................................................1
Placing the computer in the proper location ..........................................................2
Using surge protection .......................................................................................2
Connecting to the computer ................................................................................3
Using DVI Connectors with SLI Technology ................................................................5
Connecting a Digital Camera (Photo or Video)...........................................................6
Connecting Other Devices .......................................................................................8
Storing Documentation and Recovery Discs................................................................8
Adjusting the Monitor..............................................................................................8
Adjusting the screen resolution by using Vista .......................................................8
Adjusting the screen resolution by using the NVIDIA Control Panel ..........................9
Setting Up a Local Area Network .............................................................................9
Setting Up a Wired (Ethernet) Connection ...............................................................10
Connecting a Modem ...........................................................................................10
Connecting Speakers or Microphone ......................................................11
Sound Connector Types ........................................................................................11
Connecting a Microphone .....................................................................................14
Speaker Configurations.........................................................................................15
Speaker types .................................................................................................15
Connecting 2/2.1 (Two speakers and a subwoofer) audio speakers......................16
Connecting 4.1 (Four speakers and a subwoofer) audio speakers .........................17
Connecting 5.1 (Five speakers and a subwoofer) audio speakers ..........................18
Connecting 7.1 (Seven speakers and a subwoofer) audio speakers .......................20
Connecting your home stereo system (optional) ...................................................21
2.1 home stereo installation ..............................................................................22
5.1 home audio installation ..............................................................................23
5.1 home audio installation procedure ...............................................................23
7.1 home audio installation ..............................................................................25
7.1 home audio installation procedure ...............................................................26
Connecting digital audio ..................................................................................27
Table of Contents
iii
Connecting Headphones .......................................................................................28
Using a 2.1 speaker system with headphones .....................................................28
Using a 5.1 to 7.1 speaker system with headphones ...........................................28
Connecting Speakers Using the Creative Sound Blaster X-Fi Sound Card .....................28
Connecting the speakers ..................................................................................29
Connecting the FlexiJack connector....................................................................30
Getting Help ..........................................................................................31
Finding Support and Information ............................................................................31
Finding Guides on the Web...................................................................................31
Using the Onscreen Help and Support Center ..........................................................32
Using the PC Help & Tools Folder ...........................................................................32
Using the hardware diagnostic tools ..................................................................32
Turning On the Computer for the First Time ............................................33
Turning Off the Computer ......................................................................................34
Using the Reset button ......................................................................................35
Using Shut Down .............................................................................................35
Using Lock ......................................................................................................36
Using Sleep mode ...........................................................................................36
Using Hibernate mode .....................................................................................37
Automatic Sleep, Hibernate, or Away mode .......................................................37
Restarting the Computer ........................................................................................38
Connecting to the Internet ......................................................................................38
Using the Computer with Safety and Comfort ...........................................................39
Setting Up User Accounts ......................................................................................40
Protecting the Computer ........................................................................................41
Using passwords .............................................................................................41
Using antivirus software....................................................................................42
Using firewall software.....................................................................................43
Configuring the computer for automatic Microsoft software updates.......................43
Installing critical security updates.......................................................................44
Guidelines for Installing Software and Hardware Devices..........................................45
Transferring Files and Settings from an Old Computer to a New Computer..................46
Using the Keyboard ...............................................................................47
Identifying Keyboard Features................................................................................47
Alphanumeric keys ..........................................................................................47
Function keys ..................................................................................................48
Edit keys.........................................................................................................48
Arrow keys .....................................................................................................48
Numeric keys ..................................................................................................49
Keyboard indicators ........................................................................................49
Special keyboard buttons .................................................................................50
iv
Getting Started (features vary by model)
Using the Mouse ....................................................................................51
Using the Mouse Buttons .......................................................................................51
Scrolling.........................................................................................................52
Autoscrolling...................................................................................................52
Panning..........................................................................................................52
Changing Mouse Settings......................................................................................53
Switching mouse button functions.......................................................................53
Changing mouse pointer speed .........................................................................53
Changing the double-click speed .......................................................................53
Turning on the ClickLock option .........................................................................54
Changing the scroll wheel speed .......................................................................54
Configuring Speaker and Sound Options ...............................................55
Adjusting speaker volume .................................................................................55
Selecting a microphone....................................................................................56
Configuring audio output..................................................................................57
Using the Creative Sound Blaster X-Fi or X-Fi Fatality audio card............................57
Configuring the FlexiJack connector ...................................................................58
Sound Blaster X-Fi configuration modes ..............................................................58
Configuring speakers with Realtek HD Audio Manager ........................................60
The Realtek HD Audio Manager control screens ..................................................60
Configuring sound for recording with the Realtek HD Audio Manager....................63
Retasking front panel audio connectors ..............................................................63
Configuring multistreaming audio ......................................................................64
When to use multistreaming audio .....................................................................65
Setting up multistreaming audio.........................................................................66
Configuring audio for Windows Media Center ...................................................67
Selecting recording devices ..............................................................................67
Resolving sound issues .....................................................................................68
Introducing Your Computer Software .....................................................69
Learning More About Software...............................................................................69
Using the Desktop.................................................................................................69
Removing desktop icons ...................................................................................70
Retrieving desktop icons ...................................................................................70
Removing files permanently...............................................................................70
Using the Windows Start Button Menu ....................................................................70
Using the All Programs menu ............................................................................70
Organizing the All Programs list ........................................................................71
Using the Control Panel.........................................................................................71
Resizing Windows................................................................................................72
Working with Digital Images .................................................................................72
About the Internet .................................................................................................73
Table of Contents
v
Using a Browser...................................................................................................74
Searching the Internet ......................................................................................74
Restricting Internet content.................................................................................74
Using the AVG Antivirus Software ..........................................................................75
Opening AVG software....................................................................................75
Manually running a system scan........................................................................76
Scheduling a full system scan time .....................................................................76
Setting up a custom scan ..................................................................................77
Sending and Receiving E-Mail................................................................................77
Using Windows Mail .......................................................................................78
Using the e-mail program provided by your ISP ...................................................78
Software Quick Reference Table.............................................................................78
Managing Files ......................................................................................81
Organizing Files with Folders.................................................................................81
Creating Folders...................................................................................................82
Moving Files ........................................................................................................82
Finding Files ........................................................................................................83
Renaming Files.....................................................................................................84
Deleting Files .......................................................................................................84
Retrieving Files from the Recycle Bin .......................................................................84
Copying Files.......................................................................................................85
Using a Printer .....................................................................................................85
Using CD and DVD Media Drives ............................................................87
Using the CD and DVD Drives................................................................................87
Handling CDs and DVDs ..................................................................................88
Inserting and removing CDs and DVDs...............................................................88
Compatibility Information ......................................................................................89
Disc Features and Compatibility Table ....................................................................90
Optical Drive Quick Reference Table ......................................................................91
Using Blu-ray and HD Disc Drives ...........................................................................92
Using the Memory Card Reader .............................................................93
Media Insertion Guide ..........................................................................................94
Understanding the Activity Light .............................................................................96
Formatting a Memory Card ...................................................................................96
Troubleshooting the Memory Card Reader...............................................................97
Using Windows Media Center ................................................................99
Setting Up Windows Media Center ......................................................................100
Completing the setup wizard........................................................................... 100
Windows Media Center Start Menu......................................................................101
Windows Media Center Start menu items ......................................................... 102
vi
Getting Started (features vary by model)
Windows Media Center Features ......................................................................... 102
The right music for the moment ........................................................................ 103
Playing Internet radio ..................................................................................... 103
Sharing your digital memories......................................................................... 103
Transforming your living space into a theater .................................................... 104
Online media................................................................................................ 104
Navigating Windows Media Center ..................................................................... 104
Opening Windows Media Center with a mouse................................................104
Using the Windows Media Center menu bars ................................................... 105
Selecting items in Windows Media Center........................................................ 105
Windows Media Center control menu .............................................................. 106
Changing Windows Media Center Settings ...........................................................107
Windows Media Center Settings categories...................................................... 107
Using Windows Media Center power settings................................................... 109
Playing CDs, DVDs, or VCDs .................................................................111
Using Music....................................................................................................... 111
Using Music with Windows Media Center............................................................. 112
Using the music library........................................................................................ 113
Adding music to the music library .................................................................... 113
Adding music files from the hard disk drive....................................................... 113
Adding music files from a CD.......................................................................... 114
Deleting music files from the music library......................................................... 115
Using supported music file types ......................................................................115
Playing Music Files in Windows Media Center....................................................... 115
Changing the visualization settings .................................................................. 116
Playing an album in Windows Media Center .................................................... 117
Playing a song in Windows Media Center ....................................................... 117
Creating a Queue in Windows Media Center........................................................ 117
Finding and Playing an Album in Windows Media Center ...................................... 118
Using album details ....................................................................................... 118
Using Search in Windows Media Center............................................................... 119
Searching for music tracks and files ................................................................. 119
Creating a Playlist in Windows Media Center........................................................ 120
Copying Music Files to CD in Windows Media Center............................................ 121
Listening to Online Radio Stations......................................................................... 122
Playing Music CDs ............................................................................................. 122
Playing CDs with Windows Media Player.............................................................. 123
Playing DVDs ..................................................................................................... 123
Using Windows Media Center to play DVDs..................................................... 124
Troubleshooting poor playback when playing DVDs .......................................... 124
Using country/region codes............................................................................ 125
Playing DVD Movies in Windows Media Center .................................................... 125
Table of Contents
vii
Changing the DVD Settings.................................................................................. 126
Changing the DVD movie language................................................................. 126
Changing DVD closed captioning.................................................................... 127
Changing DVD Audio Settings ............................................................................. 128
Playing DVDs with Windows Media Player............................................................ 128
Using DVD Play to Play DVDs, Videos, High-Definition DVDs, and Blu-ray DVDs......... 129
Playing Video CDs (VCDs)................................................................................... 131
Playing video CDs (VCDs) with Windows Media Player .....................................131
Creating Audio and Data Discs .............................................................133
Erasing Rewritable Discs Before Recording ............................................................ 134
Working with Audio CDs ....................................................................................134
Audio CD tips ...............................................................................................135
Before you begin creating discs....................................................................... 135
Creating audio CDs ....................................................................................... 136
Creating video discs ...................................................................................... 136
Copying a disc ............................................................................................. 137
Creating data discs........................................................................................ 138
Making a disc label using LightScribe Technology ............................................. 139
Making a paper disc label.............................................................................. 140
Working with Pictures and Videos .......................................................143
Working with Digital Images ............................................................................... 143
Viewing Pictures in Windows Media Center .......................................................... 144
Adding Pictures in Windows Media Center ...........................................................144
Adding picture files from the hard disk drive ..................................................... 144
Viewing Pictures in Windows Media Center .......................................................... 145
Viewing pictures as a slide show ..................................................................... 145
Viewing a slide show with music ..................................................................... 146
Using supported picture file types in Windows Media Center.............................. 147
Editing Pictures in Windows Media Center ............................................................ 147
Fixing red eye or contrast ............................................................................... 147
Cropping pictures in Windows Media Center ................................................... 148
Rotating pictures............................................................................................ 149
Printing Pictures in Windows Media Center ...........................................................149
Copying Pictures to CDs and DVDs in Windows Media Center ................................ 150
Playing Videos in Windows Media Center ............................................................ 150
Playing digital videos..................................................................................... 151
Using supported video file types ......................................................................151
Transferring and Recording Video Files ................................................................. 152
Recording analog and digital video files .......................................................... 152
Creating a DVD from Video Files in Windows Media Center ................................... 152
Index...................................................................................................153
viii
Getting Started (features vary by model)
Setting Up the Computer
WARNING: The power supply is preset for the country/region in which you
purchased your computer. If you move, please check the voltage requirements
for your new location before plugging the computer into an AC power outlet.
WARNING: Please read “Safety Information” in the Limited Warranty
and Support Guide before installing and connecting the computer to
the electrical power system.
Putting the Computer Together
Follow the steps on the setup poster to set up the computer. Read the topics in this section
to learn more about the location of components and connectors on the computer, and to
learn about some setup alternatives.
Look in the computer box for printed details or updates regarding the computer.
Setting Up the Computer
1
Placing the computer in the proper location
All Blackbird 002 systems ship with a base stabilizer (computer stand), which you must
install when you set up your computer. Once you install the base stabilizer, the system
meets safety standards for product stability in either floor-standing or desktop-mounted
setups. See the instructions for attaching the base stabilizer in the Attaching the Computer
Stand document that came with the computer.
When setting up your new computer, place it where ventilation openings are unobstructed.
Make sure that all connections are secure and that all cabling is out of the way. Do not
place cabling in walkways or where it can be stepped on or damaged from placing
furniture on it.
WARNING: Setting up the computer without the base stabilizer is not
recommended because it is more susceptible to being knocked over, which can
cause serious personal injury and hardware damage. For instructions on how
to install the base stabilizer, see the Attaching the Computer Stand document
that came with the computer.
Using surge protection
Help protect the monitor, computer, and accessories by connecting all power cords for the
computer and peripheral devices (such as a monitor, printer, or scanner) to a surge
protection device, such as a power strip with surge protection or an uninterruptible power
supply (UPS). Many surge protection devices have surge protection inputs and outputs for
modem or telephone lines. Telephone lines are a common path for lightning spikes to get
into the system. Some surge protection devices have surge protection for television cable
connections as well. Use those if the computer has a television tuner installed.
Not all power strips provide surge protection; the power strip must be specifically labeled
as having this capability. Use a power strip whose manufacturer offers a damage
replacement policy that replaces the equipment if surge protection fails.
2
Getting Started (features vary by model)
Connecting to the computer
Connect the main hardware devices, such as the monitor, keyboard, and mouse, to the
back of the computer. Other peripheral devices, such as a printer, scanner, or camera,
also plug into connectors on the back of the computer. Some computers also have
connectors on the front of the computer. The following table shows some, but not all,
connectors:
NOTE: The location, availability, and number of connectors on the computer may vary.
NOTE: For more information about the computer connectors, LEDs, and buttons, see the
motherboard documentation that came with the computer.
Connector/LED/Button
Description and function
Mouse (PS/2 connector).
Keyboard (PS/2 connector).
4-pin Universal Serial Bus (USB) connectors for
connecting USB 2.0 devices, such as a mouse,
keyboard, or digital camera.
External Serial Advanced Technology Attachment
(eSATA) connector enables SATA hard disk drives to be
attached externally.
For more information, see the motherboard
documentation.
NOTE: An eSATA connection requires its own power
connector.
Four DVI (Digital video output) connectors to connect a
TV or monitor. You may need to use a VGA-to-DVI or a
HDMI-to-DVI adapter to connect the display to the
computer.
See the documentation that came with your display
device.
S-video connector for connecting a TV display.
Setting Up the Computer
3
Connector/LED/Button
Description and function (continued)
Audio Line Out (to powered speakers).
Microphone (pink) connector.
Headphones (green) connector.
Optical Out/Microphone In to connect to a
microphone. The Mic connector also functions as a
center/subwoofer Line Out when a multichannel audio
configuration is activated.
IEEE 1394a connector. This 6-pin connector provides
high-speed connectivity for audio/video devices,
storage peripherals, PCs, or portable devices with very
fast transfer rates.
Coaxial S/PDIF Out (orange) port connects an external
audio output device via an optical S/PDIF cable.
Optical Out connector. Optical SPDIF output connects to
the Optical In on a set of digital speakers.
The digital speakers would then split up the audio
signal to the correct speaker.
Power cord connector.
Computer power LED.
Power switch to be turned on before the power button
on the front of the computer is pressed.
Power button. Press the power button after the power
switch on the back of the computer is turned on.
LAN 1 and LAN 2 (RJ-45) connectors. Supported by
NV Gigabit LAN controller, this connector allows
gigabit connection to a local area network (LAN)
through a network hub.
4
Getting Started (features vary by model)
Connector/LED/Button
Description and function (continued)
LCD Poster display window displays system activity
such as boot error messages.
Hard disk drive is active LED.
Onboard LED SW button turns internal motherboard
LEDs on and off.
These blue lights are strategically located beside key
motherboard connectors to allow you to install
components conveniently without a flashlight. See the
following Warning.
Reset button allows you to restart the computer without
turning off the power.
WARNING: Before you install or remove any component, make sure to press
the onboard LED SW button first, and make sure the standby power LED is off.
Failure to do so may cause injury or severe damage to the motherboard,
peripherals, and/or components.
Using DVI Connectors with SLI Technology
The computer models that include dual graphics cards come configured with Scalable Link
Interface (SLI) enabled. Dual graphics cards with SLI technology work together to render
3D applications to create a better performance experience.
IMPORTANT: In SLI mode only one of the top two DVI connectors is active. This means
you cannot use the other three DVI connectors. If you do not have SLI mode enabled, you
can use up to four of the DVI connectors on the back of the computer.
If you are not sure if you have SLI Mode, you can find out by completing the
following steps:
1 Right-click anywhere on the desktop, and then click NVIDIA Control Panel.
2 On the left-hand side of the window, under 3D Settings, click Set SLI
configuration.
3 From the menu bar, click 3D settings.
4 Click the drop-down menu and select Show SLI Visual Indicators. This window
helps you to determine if SLI technology is enabled and working.
Setting Up the Computer
5
Connecting a Digital Camera (Photo or Video)
The following instructions apply only to digital photo cameras and digital video cameras.
NOTE: When connecting an analog video camera to the computer, use the Video and
Audio In connectors on the front or back of the computer.
Refer to the documentation that came with your digital photo camera or digital video
camera.
To connect a digital photo camera or a digital video camera:
1 Turn on the computer, and wait for the Microsoft® Windows Vista® operating system
to start.
NOTE: If a Digital Video Device AutoPlay window appears when you connect the
camera, click Cancel.
2 Connect the 6-pin video camera transfer cable into the camera, and then into an open
port on the front or back of the computer. Most digital video cameras use either the
FireWire® (IEEE 1394) port or the USB port.
3 A Found New Hardware message appears. Wait 2 or 3 minutes for Windows Vista to
make the necessary settings for the new device. When installation is complete, a
message appears, indicating that the camera is ready to use.
6
Getting Started (features vary by model)
4 You may need to install driver software for your camera. If so, Windows displays a
message asking if you want to locate and install driver software. Insert the driver
software CD, click Locate and install driver software, and then follow any
onscreen instructions to install the software.
If the computer does not recognize the digital photo camera or the digital video camera:
1 Click the Windows Start Button®
Control Panel.
on the taskbar, and then click
2 Click System and Maintenance, and then click System.
3 Click Device Manager.
4 Click the plus sign (+) next to the camera port. If the name of the camera appears, the
device is ready. If the name is not there, try the following:
Click Action, and then click Scan for hardware changes. Look in Device
Manager for a new addition under the port.
Unplug the video camera transfer cable from the computer, and plug it into a
different port. Look in Device Manager for a new addition under the port.
Setting Up the Computer
7
Connecting Other Devices
Other peripheral devices can be connected to the front or back of the computer by using
USB or FireWire (IEEE 1394) ports. These peripheral devices include printers, scanners,
video cameras, digital photo cameras, memory card readers, and PDAs (personal digital
assistants) or handheld computers. Refer to the documentation that came with your device.
NOTE: Some peripheral devices are not included with the computer.
NOTE: You must use a 6-pin (not a 4-pin) FireWire (IEEE 1394) cable with the 6-pin
FireWire (IEEE 1394) connector on the computer.
Storing Documentation and Recovery Discs
Store all computer user manuals and warranty information in an easy-to-find, safe location.
It is a good idea to store the system recovery discs with the documentation. This allows
easy access to all important computer documents and files.
Adjusting the Monitor
Adjusting the screen resolution by using Vista
To change the screen resolution by using Vista:
1 Right-click an empty area of the desktop, and then click Personalize.
2 Click Display Settings.
3 If necessary, select the monitor, and then adjust the screen resolution by using the
slider under Resolution.
4 Click Apply.
8
Getting Started (features vary by model)
5 Click Yes, if it is present.
6 Click OK.
NOTE: You can connect more than one display device (CRT monitor, flat panel monitor,
TV, and so on) to the computer at a time (select models only). You can quickly change
which device displays the computer desktop by pressing Alt+F5. Each time you press
Alt+F5, the computer desktop appears on the next device. If pressing Alt+F5 does not
work, restart the computer and try again.
Adjusting the screen resolution by using the
NVIDIA Control Panel
To change the screen resolution by using the NVIDIA Control Panel:
1 Right-click an empty area of the desktop, and then click NVIDIA Control Panel.
2 Select Standard or Advanced and then click OK.
3 Under Display, click Change resolution.
4 If necessary, select the display, and then adjust the screen resolution by using the
slider under Display resolution.
5 Click Apply, and then click Yes if you want to apply that resolution.
Or
Click No, and change the resolution by using the slider under Display resolution
again, click Apply and then click Yes.
Setting Up a Local Area Network
A home local area network (LAN) may consist of either a wired or a wireless network that
you can use to connect the computer to other devices on the network, including other
computers. The network components may include a hub or a switch, which can connect
multiple devices to the network, or a router, which can connect computers or a broadband
Internet connection to the network. This network connection also enables you to share data
and printers or other devices among your computers. The network connection to the
Internet is usually through a dial-up or cable modem.
A wired network uses Ethernet cables to connect the devices on the network. For example,
the Ethernet cable plugs into the computer network interface adapter and the router.
A wireless network uses radio waves to connect the devices on the network. For example,
both the computer and the router have an antenna and adapter that use the same
Wi-Fi industry standard: 802.11n, 802.11b, 802.11g, or 802.11a.
Setting Up the Computer
9
Setting Up a Wired (Ethernet) Connection
The Ethernet connection, which may be called network interface adapter, Network
Interface Card, or NIC, provides a high-speed or broadband connection to an
Ethernet (10BaseT) or Fast Ethernet (100BaseT) network. After you connect this interface to
a network, such as a LAN, you can connect to the Internet through the network.
1 Connect an Ethernet cable to the Ethernet connector (A) on the back of the computer,
and to the network router or LAN device.
NOTE: Your computer may not come with an Ethernet connector.
A Ethernet connector (RJ-45 port)
B
Ethernet indicator lights
2 With the computer turned on, check the indicator lights (B) next to the Ethernet
connector for the status:
ACTIVITY — Lit yellow during network data transfer activity
LINK — Lit green when there is a valid network connection
NOTE: Your Ethernet connector may have only one indicator light.
Connecting a Modem
For information on connecting to the Internet, see “Connecting to the Internet” in this guide.
10
Getting Started (features vary by model)
Connecting Speakers or Microphone
Speakers are included with the monitor (select models only), or they are sold separately.
NOTE: For product information on the HP Support Web site, go to:
http://www.hp.com/support
For details about connecting stereo speakers to the computer, see the setup poster.
NOTE: Speakers may be passive (no power button or power cord) or active (power button
or power cord). Your computer supports only active (powered) speaker systems; the
speaker system must have its own power cord.
A stereo speaker set is a left-right, two-channel speaker system. A multichannel audio
speaker system is a system with more than two channels, and it may include a subwoofer.
For example, 5.1 channels, referred to as six-speaker mode, uses two front speakers
(left-right), two rear speakers (left-right), a center speaker, and a subwoofer.
If the computer has multichannel audio speaker capacity (select models only), you can
connect four channels for four-speaker output, or six channels for 5.1 speaker output.
Connect the speaker system to the computer, and then configure the audio software for
sound output.
Sound Connector Types
Your model may include one of three analog sound connector types on the back of
the computer:
Three connectors
Six connectors
Audio card
The connectors are 3.5 mm (1/8-inch) stereo mini-jacks that connect from the back of the
computer to speakers and microphones.
Connecting Speakers or Microphone
11
Your system may also have a separate Digital Out connector (select models only).
Software configuration is different for each connector type, as noted in the instructions.
NOTE:
Type 3 has three connectors.
Type 6 has six connectors.
Type S has audio card.
Sound connector
Three
connectors
Illustration
Your computer model may include three
sound connectors. You can connect up
to a 5.1 audio system to the computer.
Six connectors Your computer model may include six
sound connectors on the back of your
computer. You can connect up to a
7.1 audio system to the computer.
Audio card
connector
Your computer may include a audio
See the following
card. You can connect up to a
illustrations.
5.1 audio system (7.1 audio system for
select models) or digital speakers to the
audio card on the computer.
Type
3
6
S
When installing cables, use the sound connectors that match your computer model, as
shown in the installation procedure steps.
12
Getting Started (features vary by model)
The following table shows the sound connectors on the back panel of computer systems.
Sound connector
Type 3
Type 6
Type S
Description
Line Side (gray) connects to side left and right
analog speakers in an eight-speaker system (7.1).
Line C/Sub (gold) connects to front center/
subwoofer speakers in a multichannel audio
configuration.
Line Rear (black) connects to rear left and right
analog speakers in a multichannel audio
configuration.
Line Out (lime green) connects to front left and right
analog speakers.
Mic (pink) connects to a microphone. (Type 3 also
functions as center/subwoofer Line Out when a
multichannel audio configuration is enabled.)
Line In (light blue) connects to an analog audio
device such as a CD player for input into computer.
(Type 3 also functions as rear Line Out when a
multichannel audio configuration is enabled.)
Digital Audio Out or SPDIF Out (orange)
connects to a digital audio device with digital input
(such as a home audio receiver/amplifier) or to
digital speakers (select models only).
FlexiJack (pink) connects to analog Line In devices
or a microphone.
The FlexiJack supports two functions. You must select
either the microphone or the Line In function in the
Creative Console Launcher. See “Configuring the
FlexiJack connector.”
FlexiJack (blue) connects to analog Line In devices
or a microphone.
The FlexiJack supports two functions. You must select
either the microphone or the Line In function in the
Creative Console Launcher. See “Configuring the
FlexiJack connector.”
Connecting Speakers or Microphone
13
Sound connector (continued)
Type 3
Type 6
Type S
Description
Optical In (optical SPDIF input) connects recording
devices such as a mini disc recorder, digital audio
tape recorder, or external hard disk recorder.
Optical Out (optical SPDIF output) connects
playback devices such as a mini disc player, digital
audio tape player, or DVD player.
NOTE:
Type 3 has three connectors.
Type 6 has six connectors.
Type S has audio card.
Connecting a Microphone
Your computer comes with one microphone connector in the back of the computer. Some
models have a second microphone connector in the front of the computer. Only one
microphone connector works at a time, and the back connector is ready to use unless you
have the multichannel audio speakers option. For computers with the multichannel audio
speakers option, the microphone connector in the front of the computer, if present, is ready
to use.
To use a microphone connected to the front of your computer (select models only), select
the working microphone. See “Selecting a microphone.”
HP computers support many different audio options, sound connections, and speaker
configurations. You may set up your computer for two stereo speakers or for multichannel
audio speaker systems. Connect your speaker system to the computer, and then configure
the audio software for sound output. For more details about connecting stereo speakers to
the computer, see the setup poster.
This chapter describes the most typical options. Your system may have different
components.
Speakers are included with the monitor (select models only) or are sold separately.
NOTE: For additional information on connecting the speakers, refer to the setup poster
that came with the computer and the documentation that came with your speakers.
14
Getting Started (features vary by model)
Speaker Configurations
You may set up your computer for the following supported configurations:
Name
Speaker system
See
Headphones
None, muted.
“Connecting Headphones.”
2 (stereo)
Left speaker, right speaker.
“Connecting 2/2.1 (Two speakers and
a subwoofer) audio speakers.”
2.1
Left speaker, right speaker,
and a subwoofer.
“Connecting 2/2.1 (Two speakers and
a subwoofer) audio speakers.”
4.1
Two front speakers, two
rear speakers, and a
subwoofer.
“Connecting 4.1 (Four speakers and a
subwoofer) audio speakers.”
6/5.1
Two front speakers, two
rear speakers, a center
speaker, and a subwoofer.
“Connecting 5.1 (Five speakers and a
subwoofer) audio speakers.”
8/7.1
Two front speakers, two
rear speakers, two side
speakers, a center
speaker, and a subwoofer
(select models only).
“Connecting 7.1 (Seven speakers and
a subwoofer) audio speakers.”
Home audio
system
Home stereo or home
theater audio system with
passive speakers.
“Connecting your home stereo system
(optional).”
Digital audio
Digital speakers or digital
input connector on audio
system.
“Connecting digital audio.”
Multistreaming
audio
Two front speakers, two
rear speakers, two side
speakers, a center
speaker, and a subwoofer
(select models only).
“Configuring multistreaming audio.”
Speaker types
Speakers may be included with the monitor (select models only) or are sold separately.
Refer to the product documentation for your speakers.
Your computer supports only an active (powered) speaker system. An active speaker
system must have its own power cord. A home audio system does not require active
speakers, because the receiver provides amplification.
Connecting Speakers or Microphone
15
A stereo speaker set is a left-right, two-channel speaker system. A multichannel audio
speaker system has a left-right front and left-right rear channel, and it may include a
subwoofer and a center speaker. Side speakers are included in more advanced systems. A
subwoofer provides enhanced bass sounds.
“.1” indicates a subwoofer. For example, 7.1 channels refers to an eight-speaker mode
and uses two front speakers (left-right), two side speakers (left-right), two rear speakers
(left-right), a center speaker, and a subwoofer.
Connecting 2/2.1 (Two speakers and a
subwoofer) audio speakers
To connect simple left/right stereo active speakers or two speakers and a subwoofer for
two-channel (2.1 speaker) output:
1 Turn off the computer.
2 Connect the speaker cable to the lime green Audio Line Out connector that matches
the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
3 Connect the cable to the audio system. For 2.1 speakers that were shipped with your
computer (select models only), connect the Audio Line Out connector to the subwoofer.
4 Connect the left and right speakers to the subwoofer. Refer to the speaker
documentation.
5 Turn on the computer.
NOTE: Always turn on the computer before you turn on the speaker system.
6 Plug in the speaker system power.
7 Turn on the speaker system.
Step 8 is optional for a two-speaker setup.
8 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Connecting Speakers or Microphone.”
16
Type 3: See “Configuring speakers with Realtek HD Audio Manager.”
Type 6: See “Configuring speakers with Realtek HD Audio Manager.”
Type S (audio card): See “Using the Creative Sound Blaster X-Fi or X-Fi Fatality
audio card.”
Getting Started (features vary by model)
The following diagram shows a typical 2.1 audio installation:
Connecting 4.1 (Four speakers and a subwoofer)
audio speakers
To connect two front speakers, two rear speakers, and a subwoofer for four-channel
(4.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector that
matches the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
3 Connect the rear speaker cable to the black connector that matches the back of
your computer.
3
6
S
Type 3: See “Configuring speakers with Realtek HD Audio Manager.”
Type 6: See “Configuring speakers with Realtek HD Audio Manager.”
Type S (audio card): See “Using the Creative Sound Blaster X-Fi or X-Fi Fatality
audio card.”
Connecting Speakers or Microphone
17
The following diagram shows a typical 4.1 audio installation:
Connecting 5.1 (Five speakers and a subwoofer)
audio speakers
To connect two front speakers, two rear speakers, a center speaker, and a subwoofer for
six-channel (5.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector that
matches the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
3 Connect the rear speaker cable to the black connector that matches the back of
your computer.
3
6
S
For type 3-connector systems, the blue Audio Line In connector functions as a Rear Line
Out when a multichannel audio configuration is activated.
18
Getting Started (features vary by model)
4 Connect the center/subwoofer speaker cable to the gold (or pink Mic) connector that
matches the back of your computer.
3
6
S
For type 3-connector systems, the pink Mic connector functions as a center/subwoofer
speaker Line Out when a multichannel audio configuration is activated.
5 Connect the cables to the audio system.
6 Connect the front, rear, and center speakers to the subwoofer. Refer to the speaker
documentation.
7 Turn on the computer.
NOTE: Always turn on the computer before you turn on the speaker system.
8 Plug in the speaker system power.
9 Turn on the speaker system.
10 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Configuring Speaker and Sound
Options.”
Type 3: See “Configuring speakers with Realtek HD Audio Manager.”
Type 6: See “Configuring speakers with Realtek HD Audio Manager.”
Type 6 — multistreaming: See “Configuring multistreaming audio.”
Type S (audio card): See “Using the Creative Sound Blaster X-Fi or X-Fi Fatality
audio card.”
The following diagram shows a typical 5.1 audio installation:
Connecting Speakers or Microphone
19
Connecting 7.1 (Seven speakers and a
subwoofer) audio speakers
(Select models only)
To connect two front speakers, two side speakers, two rear speakers, a center speaker,
and a subwoofer for eight-channel (7.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector on the
back of your computer.
3 Connect the rear speaker cable to the black Audio Line Rear connector on the back of
your computer.
4 For type 6 connectors only, connect the side speaker cable to the gray Audio Line Side
connector on the back of your computer.
5 Connect the center speaker and subwoofer speaker cable to the gold Audio
Line C/Sub connector on the back of your computer.
6 Connect the cables to the audio system.
7 Connect the front, rear, side, and center speakers to the subwoofer. Refer to the
speaker documentation.
8 Turn on the computer.
NOTE: Always turn on the computer before the speaker system.
9 Connect the speaker system to the power.
10 Turn on the speaker system.
11 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model.
20
Getting Started (features vary by model)
The following diagram shows a typical 7.1 audio installation.
Color
Description
1
Lime green
Front audio input
2
Black
Rear audio input
3
Orange
Center/subwoofer audio input
4
Gray
Side audio input (not shown)
Connecting your home stereo system (optional)
Most home receivers/amplifiers have RCA-type input connectors. You must connect
Y adapter cables between your computer and your receiver/amplifier. Y adapter cables
have one 3.5 mm (1/8-inch) stereo mini-jack on one end, and two RCA connectors on the
other. These cables are purchased separately.
The number of Y adapter cables that you need to connect to your home stereo system
depends on the number of speakers that you install:
2/2.1 speaker system: One Y adapter cable
4/4.1 speaker system: Two Y adapter cables
6/5.1 speaker system: Three Y adapter cables
8/7.1 speaker system: Four Y adapter cables
Connecting Speakers or Microphone
21
Connecting a home stereo system to a computer requires audio cables that are long
enough to reach from the computer to the stereo. You also must purchase Y adapter or
mini-extension cables.
NOTE: Y adapter and mini-extension cables are purchased separately.
2.1 home stereo installation
The following diagram shows a typical two-channel (2.1 speaker) installation that uses
passive stereo speakers and plugs into a home stereo standard left and right input.
This is only a suggested configuration. Your system may be different.
A
B
C
E
C
D
E
Computer to 2.1 multichannel audio system connection
A Computer back-panel connectors (type 3, type 6, or sound card)
B Y adapter cables
C Receiver/amplifier (audio input jacks)
D Subwoofer
E
22
Front speakers (left and right)
Getting Started (features vary by model)
5.1 home audio installation
The following diagram shows a typical advanced home theater audio six-channel
(6/5.1 speaker) installation that requires multichannel inputs on a receiver/amplifier.
This is only a suggested configuration. Your system may be different.
A
B
C
F
E
C
D
G
Computer to 5.1 multichannel audio system connection
A Computer back-panel connectors (type 3, type 6, or sound card)
B Y adapter cables
C Receiver/amplifier (audio input jacks)
D Subwoofer
E
Center speaker
F
Front speakers (left and right)
G Rear speakers (left and right)
5.1 home audio installation procedure
To connect a six-channel (5.1 speaker) home audio system to the computer:
1 Turn off the computer.
2 Turn off the receiver/amplifier.
Connecting Speakers or Microphone
23
3 Connect the front stereo mini-jack end of a Y adapter cable into the lime green Audio
Line Out connector that matches the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
NOTE: Receiver/amplifier input connectors may be labeled Surround, 5.1 Channel
inputs, 6 Channel inputs, CD, DVD, or DVD In.
Connect the left and right ends of the Y adapter cable into the front left (L) and right (R)
inputs on the back of the receiver/amplifier.
4 If you have rear speakers, connect the rear stereo mini-jack end of a Y adapter cable
into the Audio Line In (blue) or the Rear Speaker Out (black) connector that matches
the back of your computer.
3
6
S
Connect the left and right ends of the Y adapter cable into the rear left (L) and
right (R) inputs on the back of the receiver/amplifier.
5 If you have a center/subwoofer speaker, connect the stereo mini-jack of a Y adapter
cable into the microphone (pink) connector or the center speaker/subwoofer (gold)
connector that matches the back of your computer.
3
6
S
Connect the left and right ends of the Y adapter cable into the center/subwoofer
inputs on the back of the receiver/amplifier (6/5.1 or higher-channel system).
Plug the Y adapter cable into the subwoofer connector on the back of the receiver
even if a subwoofer is not used.
6 Turn on the receiver/amplifier.
7 Select the receiver/amplifier input that the Y adapter cables are plugged into.
24
Getting Started (features vary by model)
8 Turn on the computer.
9 After the audio system is connected to the computer, configure the audio software for
sound output for your computer model. See “Connecting Speakers or Microphone.”
Type 3: See “Configuring speakers with Realtek HD Audio Manager.”
Type 6: See “Configuring speakers with Realtek HD Audio Manager.”
Type S (audio card): See “Using the Creative Sound Blaster X-Fi or X-Fi Fatality
audio card.”
7.1 home audio installation
The following diagram shows a typical advanced home theater system with an
eight-channel 8/7.1 speaker installation that requires multichannel inputs on a
receiver/amplifier.
This is only a suggested configuration. Your system may be different.
A
B
C
F
E
C
D
G
Computer to 7.1 multichannel audio system connection
A Computer back-panel connectors (type 3, type 6, or type S)
B Y adapter cables
C Receiver/amplifier (audio input jacks)
D Subwoofer
E
Center speaker
F
Front speakers (left and right)
G Rear speakers (left and right)
Connecting Speakers or Microphone
25
7.1 home audio installation procedure
To connect an eight-channel (7.1 speaker) home audio system to the computer:
1 Turn off the computer.
2 Turn off the receiver/amplifier.
3 Connect the front stereo mini-jack end of a Y adapter cable into the lime green Audio
Line Out connector on the back of your computer.
3
6
S
NOTE:
Type 3 has three connectors.
Type 6 has six connectors.
Type S has audio card.
NOTE: Receiver/amplifier input connectors may be labeled Surround, 7.1 Channel
inputs, 6 Channel inputs, CD, DVD, or DVD In.
Connect the left and right ends of the Y adapter cable into the front left (L) and right (R)
inputs on the back of the receiver/amplifier.
4 If you have rear speakers, connect the rear stereo mini-jack end of a Y adapter cable
into the Audio Line In (light blue) or the Rear Speaker Out (black) connector on the
back of your computer.
3
6
S
Connect the left and right ends of the Y adapter cable into the rear left (L) and right (R)
inputs on the back of the receiver/amplifier.
5 If you have a center/subwoofer speaker, connect the stereo mini-jack of a Y adapter
cable into the microphone (pink) connector or the center speaker/subwoofer (gold)
connector on the back of your computer.
3
6
S
Connect the left and right ends of the Y adapter cable into the center/subwoofer
inputs on the back of the receiver/amplifier (8/7.1 or higher-channel system).
Connect the Y adapter cable to the subwoofer connector on the back of the receiver,
even if you are not using a subwoofer.
26
Getting Started (features vary by model)
6 Turn on the receiver/amplifier.
7 Select the receiver/amplifier input to which the Y adapter cables are connected.
8 Turn on the computer.
9 After the audio system is connected to the computer, configure the audio software for
sound output for your computer model. See “Configuring Speaker and Sound
Options.”
Connecting digital audio
(Select models only)
If you have a audio card and you are connecting your home stereo AV receiver via digital
out, connect the 3.5 mm (1/8-inch) stereo plug to the Digital Audio Out connector on the
audio card. Connect the red RCA stereo plug on the 3.5 mm (1/8-inch) Y adapter cable to
the AV receiver’s digital input connector on the AV receiver. If the red RCA stereo plug
does not work, try the white stereo plug. Only one of the connectors is needed.
To connect digital audio, your computer must include a Digital Audio Out connector on
either the audio card or the back panel. You must connect multichannel speaker outputs if
you connect the digital output.
To connect digital audio speakers:
1 Turn off the computer.
2 Connect the orange Digital Audio Out connector on the back panel of
your computer to the digital input (S/PDIF) on the digital speakers or a
digital audio system.
3 Turn on the computer.
NOTE: Always turn on the computer before the speaker system.
4 Connect the speaker system to the power.
5 Turn on the speaker system.
6 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Configuring Speaker and Sound
Options.”
Audio card with digital output and type 3 connectors: See “Configuring speakers
with Realtek HD Audio Manager.” Follow the instructions to enable digital audio
output.
Audio card with digital output and type 6 connectors: See “Configuring speakers
with Realtek HD Audio Manager.” By default, digital audio output is already
enabled.
Audio card: Follow the instructions to enable digital audio output.
Connecting Speakers or Microphone
27
Connecting Headphones
Your computer comes with a headphones connector (lime green) on the front of the
computer. The headphones connector is labeled with a headphones icon.
You can also connect headphones to the Line Out connector (lime green) on the
back of your computer.
Using a 2.1 speaker system with headphones
For select models with the 2.1 speaker system, look for the headphones connector on the
right side of the main speaker. When headphones are plugged in, the sound to the
speakers and the subwoofer is muted.
Using a 5.1 to 7.1 speaker system with
headphones
For select models that include a 5.1 or higher speaker system, a headphones connector is
located on the right side of the control tower.
If the control tower displays HP (for headphones), the headphones are enabled; the sound
to the speakers and the subwoofer is muted.
Push and hold the On button on the control tower for several seconds to enable sound
from the speakers.
Press the On button briefly to enable the headphones.
Connecting Speakers Using the Creative Sound
Blaster X-Fi Sound Card
This section provides an overview of connecting to the Creative Sound Blaster X-Fi
sound card.
NOTE: For additional information on connecting the speakers, refer to the documentation
that came with your speakers.
28
Getting Started (features vary by model)
Connecting the speakers
Connector
Description
AD-Link for AD_Link X-Fi I/O Console (the X-Fi console is sold separately)
Line Out_3 (orange or yellow)
5.1 audio setup: Front center, subwoofer
6.1 audio setup: Front center, subwoofer, and rear center
7.1 audio setup: Front center, subwoofer, and side left
Line Out_2 (black)
4.1, 5.1, 6.1 audio setup: Rear left and right
7.1 audio setup: Rear left, rear right, and side right
Line Out_1 (lime green)
2/2.1 audio setup: Front left and right
FlexiJack (white) for Line In, Microphone, Digital In/Out
The FlexiJack supports three functions. You must select the function in the
Creative Console Launcher. See “Connecting the FlexiJack connector.”
To connect the X-Fi sound card to your speakers:
1 Use the audio connection table to connect your audio system to the sound card.
2 Turn on the computer.
3 Plug in and turn on the speaker system power.
After connecting the speaker system to the sound card, follow the steps in “Configuring the
FlexiJack connector” to configure the speaker settings in the Creative Sound Blaster X-Fi
software.
Connecting Speakers or Microphone
29
Connecting the FlexiJack connector
The FlexiJack connector performs three functions:
Digital Input/Output
Line In
Microphone
You must select the function in the Creative Console Launcher.
NOTE: If you are using the FlexiJack as your Digital In connection and you want to
connect digital speakers as your output device, you will need a special connector from
Creative.
30
Getting Started (features vary by model)
Getting Help
Finding Support and Information
You can find troubleshooting support and information specific for your computer by using
the Internet to access the HP Blackbird Web site.
Go to http://www.hp.com/blackbird and
http://www.hp.com/blackbird/support in your Web browser.
Finding Guides on the Web
You can find guides and information for your computer by using the Internet to access the
Support Web site.
1 Go to http://www.hp.com/support in your Web browser.
2 Select your country/region and language.
3 Click Support and Drivers.
4 Click See support and troubleshooting information, enter the model number
of your computer, and then click Search
.
5 Click Manuals.
6 Locate the manual you want, and then do one of the following:
Click the title to display the file in Adobe Acrobat Reader (which you can
download from the Manuals page if it is not currently installed on your computer).
Right-click the title, click Save Target As, specify a location on the computer
where you want to save the file, rename the file (retaining the .pdf extension), and
then click Save.
Getting Help
31
Using the Onscreen Help and Support Center
Information about your computer is in the onscreen Help and Support Center (select
models only). Here, you can find links to driver updates, access to technical support
options, and information about commonly asked questions.
To open the Help and Support Center:
Press the Help button (select models only) on your keyboard.
Or
Click the Windows Start Button
and Support.
on the taskbar, and then click Help
Using the PC Help & Tools Folder
The PC Help & Tools folder contains special utilities for computer owners, such as
support information and programs.
To see the items in the PC Help & Tools folder:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
3 Click PC Help & Tools.
4 Click Hardware Diagnostic Tools to view or use these tools.
Using the hardware diagnostic tools
The hardware diagnostic tools help you to do the following:
32
View the computer system information, such as memory usage, drive capacity
and CPU usage.
Find alerts about your computer.
Show information, and run diagnostic tests on computer hardware and some
computer peripheral hardware, such as printers, monitors, speakers, and
network adapters.
Run a computer system test.
Getting Started (features vary by model)
Turning On the Computer for the First Time
WARNING: Before you install or remove any component, make sure to press
the onboard LED SW button first, and make sure the standby power LED is off.
Failure to do so may cause injury or severe damage to the motherboard,
peripherals, and/or components.
After making all the connections, replace the system case cover.
1 Make sure that all buttons and switches are turned off.
NOTE: Ensure that the LED SW button is not pushed in, or the computer will
not turn on.
2 Connect the power cord to the power connector at the back of the computer.
3 Connect the power cord to a power outlet that is equipped with a surge protector.
4 Turn on the devices in the following order:
a
Press the Power button on the monitor.
b
Turn on all external SCSI devices starting with the last device on the chain.
c
Press the Power switch to the powered on position on the back of the
computer, and then press the On button on the front of the computer.
NOTE: You do not need to turn the Power switch to the powered off
position on the back of the computer to turn off the computer.
5 After applying power, the system power LED on the system front panel case lights up.
The computer runs the power-on self tests or POST. While the tests are running, the
BIOS beeps or additional messages appear on the LCD poster screen on the back of
the computer. If you do not see anything within 30 seconds from the time you turned
on the power, the system may have failed a power-on test. Call HP Support for
assistance.
Turning On the Computer for the First Time
33
6 At power on, hold down the Delete key to enter the BIOS Setup. Follow the BIOS setup
instructions in the printed guide for the motherboard that came with the computer.
7 Turn on the speakers, if they are present.
8 Set up the computer by following the onscreen instructions. If prompted, select the
country/region where you are physically located, and wait while the computer makes
preparations. (When you select an alternate language, it may take up to 30 minutes
for this one-time language setup on the computer.)
9 Set up Microsoft Windows Vista by following the onscreen instructions.
10 Follow the onscreen instructions to register with HP, sign up for updates, and get
online. See “Connecting to the Internet.”
Turning Off the Computer
For best results, when using Microsoft Windows Vista, do not shut down the computer,
except when you must turn off the power for safety reasons, such as to make repairs, install
new hardware or cards in the computer chassis, or change a battery.
As an alternative to shutting down the computer, you can lock it or put it into either Sleep
or Hibernate mode, if it is available. You can set the power management timers to put the
computer automatically into Sleep or Hibernate mode.
Sleep and Hibernate modes are power states. Sleep mode saves your work to memory, so
you can resume quickly; saves your work to the hard disk; and then goes to a
reduced-power state. During Sleep mode, the computer hardware light remains on, and
the computer is ready to wake quickly and resume your work where you left off. Hibernate
mode saves the system memory to a temporary file on the hard disk and then turns off the
hardware.
Some computers also have a reduced-power state called Away mode. Away mode turns
off the display and mutes the audio, but otherwise keeps the computer operational. During
Away mode, the computer can perform tasks such as recording a scheduled TV program
or streaming video and music files to a remote location.
34
Getting Started (features vary by model)
Using the Reset button
The Reset button (A) is located on the front of the computer across from the power
button (B). The Reset button can be used to restart the computer without turning off
the power.
NOTE: The power switch on the back of the computer must be set to the
powered on position in order to use the power and the reset buttons.
Using Shut Down
For best results, when using Windows Vista, turn off the computer without pressing any
buttons on the computer chassis.
NOTE: For information on the Windows Start Button
Button Menu.”
, see “Using the Windows Start
1 Close any open software programs by clicking the X at the upper-right corner of each
program window.
2 Click the Windows Start Button
on the taskbar.
3 Click the Arrow button next to the Lock button.
4 Click Shut Down.
5 Turn off the monitor.
To turn on the computer after a shut down:
1 Press the power button on the monitor.
2 Press the On button on the front of the computer.
Turning On the Computer for the First Time
35
Using Lock
If you lock the computer, only you or the administrator can log on to it.
1 Click the Windows Start Button
on the taskbar.
2 Click the Lock button.
3 To unlock this computer, you must enter your password.
Using Sleep mode
When the computer is in Sleep mode, it goes into a reduced-power state. The monitor is
blank, as if it were turned off. By using Sleep mode:
You save time, because you do no have to wait for the computer to go through the
normal startup routine when you wake it again. The next time that you use the
computer, any programs, folders, and documents that were open before you put the
computer into Sleep mode are available.
The computer can receive faxes, if you set it to do so.
The computer can retrieve e-mail messages and download information from the
Internet automatically, if you set it to do so.
To put the computer into Sleep mode manually:
Press the Sleep button on the keyboard, if it is present.
Or
1 Click the Windows Start Button
on the taskbar.
2 Click the Power button.
Or
1 Click the Windows Start Button
on the taskbar.
2 Click the Arrow button next to the Lock button.
3 Click Sleep.
To wake the computer from Sleep mode:
Press the Sleep button on the keyboard.
Or
Quickly press the On button on the front of the computer.
If the computer does not work properly when you wake it from Sleep mode, restart the
computer.
1 Click the Windows Start Button
on the taskbar.
2 Click the Arrow button next to the Lock button.
36
Getting Started (features vary by model)
3 Click Restart.
Or
Quickly press the On or Reset button on the front of the computer.
Using Hibernate mode
Hibernate mode is available as an advanced power setting. When the computer is in
Hibernate mode, it saves to the hard disk drive everything that is in computer memory,
turns off the monitor and the hard disk drive, and then turns itself off. When you turn on the
computer again, your programs, folders, and documents are restored to the screen.
To put the computer into Hibernate mode manually:
1 Click the Windows Start Button
on the taskbar.
2 Click the Arrow button next to the Lock button.
3 Click Hibernate, if it is present.
NOTE: If Hibernate is not present, you can set up the computer to go into Hibernate
mode automatically; see “Automatic Sleep, Hibernate, or Away mode.”
To wake the computer from Hibernate mode, press the On button on the front of the
computer.
If the computer does not work properly when you wake it from Hibernate mode, restart the
computer.
1 Click the Windows Start Button
on the taskbar.
2 Click the Arrow button next to the Lock button.
3 Click Restart.
Automatic Sleep, Hibernate, or Away mode
You can set the computer to go into Sleep, Hibernate, or Away modes automatically when
it is idle for a specified number of minutes. To put the computer into a mode automatically,
modify the power management settings.
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click System and Maintenance.
4 Click Power Options.
5 Click Change when the computer sleeps.
Turning On the Computer for the First Time
37
6 For Sleep or Away mode, select an option from the Put the computer to sleep
drop-down menu, and click Save changes.
Or
For Hibernate or Away mode:
a
Click Change advanced power settings.
b
Click the plus sign (+) next to Sleep.
c
Click an item and make selections, and then click Apply.
d
Click OK.
Restarting the Computer
When you restart the computer, the computer clears some settings and starts over using the
operating system and software in its memory. Restarting is the easiest and most effective
way to solve many software issues for the computer.
Also, you may want to install additional software programs or hardware devices onto the
computer, and doing so may require that you restart the computer after installation.
1 Click the Windows Start Button
on the taskbar.
2 Click the Arrow button next to the Lock button.
3 Click Restart.
Or
Quickly press the On or Reset button on the front of the computer.
Connecting to the Internet
The computer can connect to the Internet through the telephone modem. There are other
ways to connect to the Internet that do not use the telephone modem, such as a LAN (local
area network) or DSL (digital subscriber line). Check with your Internet Service Provider
(ISP) for specific information on the connection. See “About the Internet” for more
information about using the Internet.
Refer to the “Setting Up the Computer” chapter of this guide to make the hardware
connections: for a modem, see “Connecting a Modem” and for a network see “Setting Up
a Local Area Network.”
To connect to the Internet, you must have:
38
A computer.
A dial-up modem, a cable modem, or a DSL modem for high-speed broadband
connections. Contact your ISP for any specific software and hardware that you
may need.
Internet service with an ISP.
A Web browser.
Getting Started (features vary by model)
To connect to the Internet:
1 Sign up with an ISP. If you already have an account with an ISP, skip this step and
follow the instructions provided by the ISP.
2 Connect to the Internet. You must connect through your ISP.
Double-click the ISP-provided icon on the desktop, and log in.
3 Open your Web browser and browse the Internet.
You can use any Web browser; most computers have Microsoft Internet Explorer. To
open Internet Explorer:
a
Click the Windows Start Button
b
Click Internet Explorer.
on the taskbar.
NOTE: If you have questions, contact your ISP directly.
Using the Computer with Safety and Comfort
WARNING: To reduce the risk of serious injury, read the Safety & Comfort
Guide. It describes proper workstation setup, posture, and health and work
habits for computer users. It also provides important electrical and mechanical
safety information.
Before you begin using the computer, arrange the computer and your work area to
maintain your comfort and productivity. Refer to the Safety & Comfort Guide for important
ergonomic information:
Click the Windows Start Button
on the taskbar, click All Programs, click
User Guides, and then click Safety & Comfort Guide.
Or
Type
http://www.hp.com/ergo
into the Web browser address box, and then press Enter on the keyboard.
Turning On the Computer for the First Time
39
Setting Up User Accounts
User accounts enable you to set the privileges for each user of the computer. For example,
you can set the software programs that each user is allowed to access.
Windows Vista provides three types of user accounts:
Administrator:
Is allowed to change account types for other users, change passwords, change
system-wide settings, access all files on the computer, and install software and drivers
that are compatible with Windows Vista.
Limited - Standard User:
Is not allowed to change other user settings or passwords. A Limited account may
not be able to install or run some software.
Is allowed to change the limited account picture, and to create, edit, or delete the
account password.
Guest:
Is allowed to use most software and change system settings that do not affect other
users or the security of the computer.
Is not allowed to change other user settings or passwords, or install software.
Does not have access to password-protected files, folders, and settings.
Creating multiple user accounts on the same computer has certain advantages, as well as
some drawbacks.
40
Advantages to multiple user accounts:
Ability to create individual user settings
Ability to limit access to software for certain users
Drawbacks to multiple user accounts:
More memory (RAM) usage
Multiple Temporary Internet Files folders to remove during Disk Cleanup
More data to back up
Longer time to complete virus scan
Getting Started (features vary by model)
Protecting the Computer
Protect the computer, personal settings, and data from a variety of risks by using:
Passwords.
Antivirus software.
Firewall software.
Critical security updates.
NOTE: Security solutions are designed to act as deterrents, but they may not be able to
prevent software attacks or to prevent the computer from being mishandled or stolen.
Computer risk
Security feature
Unauthorized use of the computer
or user account
User password
Computer viruses
AVG antivirus
Unauthorized access to data
AVG (antivirus and firewall program)
Windows Vista updates
Unauthorized access to Setup
Utility, BIOS settings, and other
system identification information
Administrator password
Ongoing or future threats to the
computer
Critical security updates from Microsoft
Using passwords
A password is a group of characters that you choose to secure the computer information.
Several types of passwords can be set, depending on how you want to control access to
your information. Passwords can be set in the Microsoft Windows Vista operating system
on the computer.
CAUTION: To avoid being locked out of the computer, record each password
you set. Because passwords are not displayed as they are set, changed, or
deleted, it is essential to record each password immediately and store it in a
secure place.
Use the following list as a basic guide when choosing a password:
Choose a password that is easy for you to remember but difficult for others to guess.
Choose a long password (minimum of six characters).
Use a combination of uppercase and lowercase letters, numbers, and symbols.
Turning On the Computer for the First Time
41
Don’t use personal information that others can easily figure out, such as your birthday,
child’s name, or phone number.
Don’t write down passwords unless you store them in a secure place away from the
computer. Do not store passwords in a file on the computer.
You can use the same password for more than one Windows Vista security feature.
A password can have any combination of up to eight letters and numbers, and it is not
case sensitive.
A password must be set and entered with the same keys. For example, if you set the
password with number keys on the keyboard, the password is not recognized if you
subsequently try to enter it with the embedded numeric keypad.
NOTE: Select models include a separate numeric keypad, which functions exactly like
the keyboard number keys, except in the case of passwords.
A password set in Windows Vista must be entered at a Windows Vista prompt.
The following table lists the Windows Vista passwords and describes their functions. For
information on how to set passwords, see “Using passwords.” For additional information
on Windows Vista passwords, such as screen saver passwords, type passwords into the
Search Help box in the Help and Support Center.
Password
Function
Windows Vista Administrator
password
Protects administrator-level access to
computer contents.
Windows Vista User password
Protects access to a Windows Vista user account and
the computer contents. It must be entered when you
resume from Sleep or Away mode.
CAUTION: If you forget the Administrator password, you cannot access
Setup Utility.
Using antivirus software
When you use the computer for e-mail, network, or Internet access, you expose it to
computer viruses. Computer viruses can disable the operating system, software programs,
or utilities, or cause them to function abnormally.
Antivirus software can detect most viruses, destroy them, and in most cases repair any
damage that viruses may have caused. To provide ongoing protection against newly
discovered viruses, antivirus software must be kept up to date.
42
Getting Started (features vary by model)
The AVG Antivirus program, which is preinstalled on the computer, includes antivirus,
anti-spyware, anti-spam, and firewall components. The software includes a free update
period. It is strongly recommended that you protect the computer against new viruses
beyond the free period by purchasing extended update service. Instructions for using and
updating AVG software, and for purchasing extended update service, are provided within
the program.
To open and access AVG:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
3 Click AVG 7.5, and then click AVG Test Center.
See “Using the AVG Antivirus Software” for more information about using the AVG
antivirus software.
For more information about computer viruses, type viruses into the Search Help box in the
Help and Support Center.
Using firewall software
When you use the computer for e-mail, network, or Internet access, unauthorized persons
may be able to gain access to information about you, the computer, and your data. To
protect your privacy, use firewall software. Microsoft Windows Vista includes firewall
software preinstalled on the computer.
Also, AVG, which is preinstalled on the computer, includes a firewall program.
Firewall features include logging, reporting, and automatic alarms to monitor all incoming
and outgoing communications.
To open and access AVG:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
3 Click AVG 7.5, and then click AVG Test Center.
Under some circumstances, a firewall can block access to Internet games, interfere with
printer or file sharing on a network, or block authorized e-mail attachments. To solve the
problem temporarily, disable the firewall, perform the task that you want to perform, and
then enable the firewall again. To resolve the problem permanently, reconfigure the
firewall.
Configuring the computer for automatic Microsoft
software updates
Microsoft continually updates the Windows Vista operating system. HP recommends that
you run Windows Vista Update monthly to install these updates. One way to keep the
operating system up to date is to use the Automatic Updates feature.
Turning On the Computer for the First Time
43
When you are connected to the Internet, Windows Vista Update automatically notifies you
through a pop-up message or icon in the notification area when critical updates are
available. When you see the Windows Vista Update message, allow the updates to
download to your system. If you update the system weekly, or even monthly, the time
required for download is minimal.
To configure Automatic Updates:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Security.
4 Click Windows Update.
5 Click Change settings.
6 Select the desired configuration:
Install updates automatically (recommended) — This is the default
setting, and it enables you to specify a day and time to automatically download
and install recommended updates.
Download updates but let me choose whether to install them
Check for updates but let me choose whether to download and
install them
Never check for updates (not recommended) — This option makes the
computer more vulnerable to security threats and performance problems and is not
recommended.
7 Click OK.
Installing critical security updates
CAUTION: To reduce the risk of information damage or loss from security
breaches and computer viruses, install all critical updates from Microsoft as
soon as you receive an alert.
Additional updates to the operating system and other software may have become
available after the computer was shipped. Download all available updates and install
them onto the computer.
44
Getting Started (features vary by model)
Guidelines for Installing Software and Hardware
Devices
After you set up the computer, you may want to install additional software programs or
hardware devices. Keep in mind the following important guidelines:
Before installation, make a restore point by using the Microsoft System Restore
program.
a
Make sure you are logged in as an Administrator.
b
Click the Windows Start Button
c
Click Control Panel.
d
Click System and Maintenance.
e
Click Backup and Restore Center.
f
Click Create a restore point or change settings.
g
In the System Properties window, on the System Protection tab, click Create.
Follow the onscreen instructions.
on the taskbar.
The restore point is a snapshot of the computer settings. By using System Restore, you
ensure that you have a stable set of settings to use. For information on System Restore,
go to the Microsoft Web site at: http://www.microsoft.com/worldwide
Choose software that is compatible with the computer; check the operating system,
memory, and other requirements listed for the new software.
Install the new software according to the directions provided by the software
manufacturer. If you need help, check the manufacturer’s documentation or customer
service information.
If you need to restore factory settings after you install a program that is incompatible:
a
Make sure you are logged in as an Administrator.
b
Click the Windows Start Button
c
Click Help and Support.
d
Click Recover factory settings.
e
Choose an option, and then follow the onscreen instructions.
on the taskbar.
For antivirus software, uninstall the existing software program before reinstalling it or
installing a new antivirus program.
NOTE: Use only licensed original software. Installing copied software may be illegal, or it
may result in an unstable installation or infect the computer with a virus.
Turning On the Computer for the First Time
45
Transferring Files and Settings from an Old
Computer to a New Computer
You can copy files from the old computer to a new computer by using media such as CDs
or DVDs, memory sticks, or personal media drives. You can also copy certain settings such
as Web browser Favorites and address books by using Windows Easy Transfer software,
which is included with Microsoft Windows Vista.
To transfer your files and settings:
1 Click the Windows Start Button
on the taskbar.
2 Click Help and Support.
3 Type transfer files into the Search Help box.
4 Click the overview article Transfer files and settings from another computer.
This article describes a Microsoft solution for moving your files to your new computer.
5 Click Windows Easy Transfer.
6 Follow the onscreen instructions in the Windows Easy Transfer wizard to transfer your
files from an old computer to a new one.
46
Getting Started (features vary by model)
Using the Keyboard
IMPORTANT: Please see the documentation that came with the keyboard for additional
information about using the keyboard, customizing keyboard buttons, and using any
special keyboard keys. You may need to install keyboard software and drivers to access
all the special features and functions of the keyboard.
Your computer may include either a standard keyboard or a wireless keyboard. Using the
keyboard is the primary way that you enter text and commands for the computer.
A standard keyboard connects to the keyboard connector in the back of the computer.
A wireless keyboard (select models only) uses a receiver/transmitter, instead of a
connector cable, to communicate with the computer. A light on the receiver indicates
receiver activity.
Identifying Keyboard Features
The keyboard contains an arrangement of standard keys, indicator lights, and special
buttons (select models only). Your keyboard may vary from the illustrations that follow.
Alphanumeric keys
The alphanumeric keys are the main keys found on a standard typewriter.
Using the Keyboard
47
Function keys
The function keys, located above the main keys, are labeled F1 through F12. Most function
key operations vary by software program. F1 and F3 are available at all times:
Pressing F1 opens a Help window for the software program being used.
Pressing F3 opens a search window.
Edit keys
The edit keys are Insert, Home, Page Up, Delete, End, and Page Down. Use these keys to
insert and delete text, and to quickly move the cursor on the screen. The edit keys function
differently with some software programs.
Arrow keys
The arrow keys are controls for moving up, down, right, and left. You can use these keys
instead of the mouse to move the cursor for navigation on a Web page, in a document, or
in a game.
48
Getting Started (features vary by model)
Numeric keys
Press the Num Lock key to lock and unlock the numeric key functions:
When the Num Lock light on the keyboard is on, the numeric keys work in the same
way as the number keys and arithmetic functions found on a basic calculator.
When the Num Lock light on the keyboard is off, the numeric keys are directional keys
used to move the cursor or play games.
Keyboard indicators
Each keyboard indicator is a light labeled with a name or with an icon for its status:
Icon
Name
Description
Num Lock
When lit, numeric keys are locked as number keys and
arithmetic functions.
Caps Lock
When lit, alphanumeric keys are locked to uppercase.
Scroll Lock
When lit, scroll function is locked.
Using the Keyboard
49
Special keyboard buttons
There are special buttons (select models only) at the top of the keyboard. These buttons
operate a CD or DVD player, control speaker volume, connect you to the Internet, or
provide quick access to specific functions. (Some keyboard models have some of these
special buttons to the left side of the main keys, some do not have the Internet buttons, and
some use a different layout on the top right.)
Media control or playback buttons
Icon
Label
Description
Eject 1 and
Eject 2
Opens or closes upper and lower optical drive trays.
Rec
Starts recording to selected media.
Stop
Stops media.
Play/Pause
Plays or pauses media.
Prev
Rewinds media.
Next
Fast-forwards media.
Volume
Volume knob controls speaker volume: Turn clockwise to
increase speaker volume and counterclockwise to decrease
volume.
NOTE: The Volume knob can continue to be turned, even
after maximum volume has been reached.
Volume Up and Down buttons control speaker volume:
Press the Volume Up button to increase volume and the
Volume Down button to decrease volume.
Or
–+
Mute
Or
50
Getting Started (features vary by model)
Turns speaker sound on and off.
Using the Mouse
IMPORTANT: Please see any documentation that came with the mouse for additional
information about using the mouse, customizing mouse buttons, and using special buttons
or features that are included with the mouse. You may need to install mouse software and
drivers to access all the special features and functions of the mouse.
Your computer includes a mouse for directing the cursor (pointer) on the Windows Vista
desktop. The mouse uses a roller ball or optics (a light and sensor) to sense movement and
cause the cursor on the screen to move. Use the mouse on a flat surface.
NOTE: The optical mouse cannot work on a glass, translucent, or reflective surface.
Using the Mouse Buttons
The mouse has two or three buttons on the top:
Click the left mouse button (A) to position the cursor or select
an item.
Click the right mouse button (C) to display a menu of
commands for the item you clicked.
On select models, use the scroll wheel button (B) in the center
for scrolling and panning.
NOTE: Your mouse may look different from the one
shown here.
You see these terms for using the mouse:
Click means to press and release the left mouse button once.
Double-click means to click the left mouse button and then
quickly click it again.
Right-click means to press and release the right button once.
To select an item, click it.
Using the Mouse
51
To select sequential items in a list or group, click the first item in the list, and then press and
hold the Shift key on the keyboard while you click the last item.
To select non-sequential items, click the first item, and then press and hold the Ctrl key on
the keyboard while you click the additional items.
You can switch the function of the left and right buttons for left-handed use. See “Changing
Mouse Settings.”
Scrolling
Click the left mouse button to place the cursor in a document, and then:
To scroll toward the beginning of the document, roll the scroll wheel button up
(away from you).
To scroll toward the end of the document, roll the scroll wheel button down
(toward you).
Autoscrolling
1 Place the cursor anywhere in the document, and then press the scroll wheel
button once. An autoscroll icon appears.
2 Move the mouse in the direction you want to scroll. The farther you move the
mouse from the starting point, the faster the document scrolls.
3 To stop autoscrolling, press the scroll wheel button again.
NOTE: Autoscrolling does not work with some software programs.
Panning
1 Place the cursor anywhere in the document, and then press and hold down the scroll
wheel button.
2 Slowly move the mouse in the direction you want to pan. The farther that you move the
mouse from the starting point, the faster the document pans.
3 To stop panning, release the scroll wheel button.
NOTE: Panning works only if the horizontal scroll bar in the window is active. Panning
does not work with some software programs.
52
Getting Started (features vary by model)
Changing Mouse Settings
Switching mouse button functions
To switch the functions of the right and left mouse buttons for left-handed use:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, if it is present.
4 Click Mouse.
5 Click the Buttons tab, and check Switch primary and secondary buttons.
6 Click Apply (using the new primary button), and then click OK.
Changing mouse pointer speed
To change the speed of the cursor on the screen relative to the motion of the mouse:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, if it is present.
4 Click Mouse.
5 Click the Pointer Options tab.
6 In the Motion area, use the slider to adjust the pointer speed. You can select other
pointer options by placing a check in the check box next to the setting that you want.
7 Click Apply, and then click OK.
Changing the double-click speed
To change the double-click speed of the right mouse button:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, if it is present.
4 Click Mouse.
5 Click the Buttons tab.
6 In the Double-click speed area, use the slider to adjust the double-click speed.
7 Click Apply, and then click OK.
Using the Mouse
53
Turning on the ClickLock option
ClickLock enables you to highlight or drag an object without holding down the
mouse button.
To turn on the ClickLock option:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, if it is present.
4 Click Mouse.
5 Click the Buttons tab.
6 In the ClickLock area, place a check in the Turn on ClickLock check box.
7 Click Apply, and then click OK.
Changing the scroll wheel speed
To change the scroll wheel speed:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, if it is present.
4 Click Mouse.
5 Click the Wheel tab.
6 In the Vertical Scrolling area, adjust the number of lines per scroll by clicking the
arrow buttons.
Or
In the Horizontal Scrolling area, adjust the number of lines per scroll by clicking the
arrow buttons.
7 Click Apply, and then click OK.
54
Getting Started (features vary by model)
Configuring Speaker and Sound Options
Speakers are included with the monitor (select models only), or they are sold separately.
For details about connecting stereo speakers to the computer, see the setup poster. For
details about connecting multichannel speakers, see “Connecting Speakers or
Microphone.”
NOTE: Speakers may be passive (no power button or power cord) or active (power button
or power cord). Your computer supports only active (powered) speaker systems; the
speaker system must have its own power cord.
A stereo speaker set is a left-right, two-channel speaker system. A multichannel audio
speaker system is a system with more than two channels, and it may include a subwoofer.
For example, a 5.1 channel speaker system, referred to as six-speaker mode, uses two
front speakers (left-right), two rear speakers (left-right), a center speaker, and a subwoofer.
If your computer has multichannel audio speaker capacity (select models only), you can
connect four channels for four-speaker output, or six channels for 5.1 speaker output.
Your model may include one of three sound card types on the back of the computer:
Creative Sound Blaster X-Fi
Creative Sound Blaster X-Fi Fatality
Analog Devices, Inc (ADI)
Your system may also have a separate Digital Out connector (select models only).
See “Connecting Speakers or Microphone” for more information about connecting your
speaker system, and then configure the audio software for sound output as described in
this section.
Adjusting speaker volume
1 Right-click the white Microsoft Volume icon on the taskbar, and then click
Open Volume Mixer. The Volume Mixer settings window opens.
2 Adjust the volume by clicking the slider and moving it.
Configuring Speaker and Sound Options
55
3 When you are satisfied with the sound level, click the Close box (the X in the
upper-right corner) to close this window.
Selecting a microphone
Your computer comes with one microphone connector on the back of the computer. Some
models have a second microphone connector on the front of the computer. Only one
microphone connector works at a time, and the back connector is ready to use unless you
have the multichannel audio speakers option. For computers with the multichannel audio
speakers option, the microphone connector on the front of the computer, if it is present, is
ready to use.
To use a microphone connected to the front of your computer (select models only), select
the working microphone:
NOTE: If you connect your microphone to the back of your computer, you do not need to
perform this procedure.
1 Right-click the white Microsoft Volume icon on the taskbar, and then click
Recording Devices. The Sound window opens.
2 Select the Recording tab.
3 Double-click Microphone, and select the General tab.
4 Click the microphone connector that you want to use, and then click Apply.
5 Click OK.
56
Getting Started (features vary by model)
Configuring audio output
You can configure your speaker audio output by using the following software. Use the
software that applies to your computer model:
Creative Sound Blaster X-Fi or X-Fi Fatality Speaker Settings Configuration
(audio card)
Windows Media Center (all systems)
Using the Creative Sound Blaster X-Fi or X-Fi
Fatality audio card
This section provides an overview of configuring and recording with the Creative Sound
Blaster X-Fi or X-Fi Fatality audio card (select models).
Configuring the audio card software
After you have installed and connected the speakers, follow these steps to configure
multichannel audio output for computers:
NOTE: Three modes are available; Entertainment Mode is selected here. For information
about the other modes, see “Sound Blaster X-Fi configuration modes.”
1 Click the Windows Start Button
on the taskbar.
2 Point to All Programs.
3 Click Creative, Sound Blaster X-Fi, and then click Creative Console
Launcher.
4 The Entertainment Mode window opens. If a different mode displays, click the Mode
button, and then select Entertainment Mode.
5 Click the Windows Start Button
Creative Console Launcher.
, All Programs, Creative, and then
6 Click the Speakers button.
Configuring Speaker and Sound Options
57
7 Click Auto Detect. Creative automatically detects the type of speakers that are
connected to your system.
8 Click X to close the window.
Now that you have configured the audio card software, you must configure audio output
for your media software program. The procedure is different for each program. Refer to
the instructions that came with the media software program.
Configuring the FlexiJack connector
Your audio device may have a FlexiJack connector that supports both microphone and Line
input. If so, you can change the FlexiJack mode, if necessary. To do this, you must select
the function in the Creative Console Launcher after you connect the audio cable to the
FlexiJack connector on the audio card.
NOTE: If you are using the FlexiJack as your Digital In connection, and you want to
connect digital speakers as your output device, you need a special connector from
Creative.
1 Connect your audio cable to the FlexiJack connector on the audio card.
2 Click the Windows Start Button
Creative Console Launcher.
, All Programs, Creative, and then
3 Click the Jacks button.
4 Under FlexiJack Mode, select either Digital I/O or Mic-In/Line-In.
5 Close the window.
Sound Blaster X-Fi configuration modes
The Sound Blaster X-Fi audio card includes three modes: Audio Creation Mode,
Entertainment Mode, and Game Mode.
The main functions, such as speaker configuration, equalizer, and volume control, are
available in all three modes. However, each mode optimizes the audio card resources to
provide the best audio performance for different activities.
58
Getting Started (features vary by model)
Using Audio Creation Mode
The Audio Creation Mode enables advanced recording functions.
Available features:
Recording from several audio sources
Applying studio-quality effects
Mixer settings
Equalizer settings
Using Entertainment Mode
The Entertainment Mode optimizes the audio card for playing movies and music.
Available features:
Configuring speakers and headphones
Configuring surround sound, DTS, and THX
Volume, bass, and treble controls
Mixer settings
Using Game Mode
The Game Mode optimizes the audio card for playing games.
Available features:
Volume, bass, and treble controls
Mixer settings
Configuring speakers and headphones
Configuring surround sound
More information
For more information about configuring and using the audio card, go to the Creative
Sound Blaster X-Fi documentation:
1 Click the Windows Start Button
on the taskbar.
2 Point to All Programs.
3 Click Creative, Sound Blaster X-Fi, and then click Documentation.
4 Click Online Manual.
Configuring Speaker and Sound Options
59
Configuring speakers with Realtek HD Audio
Manager
After you have installed and connected your speakers, complete the following steps if your
computer model has type 6 connectors and is capable of multistreaming audio:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound.
4 Click Realtek HD Audio Manager. The window opens.
NOTE: You must have your speakers connected for Realtek to display the
Speakers tab.
5 Click the Speakers tab to open that control screen.
6 Click the Speaker Configuration tab.
7 Select your type of speakers from the drop-down menu.
8 Click OK.
The Realtek HD Audio Manager control screens
60
Digital Output: Enables you to select the Environment and Equalizer settings. You
can select an environment, such as Stone Room or Auditorium. Under Equalizer,
you can either click a preset button, such as Pop or Live, or manually adjust the
settings and then save them for easy selection later.
Getting Started (features vary by model)
Speakers: Enables you to select the number of speakers, view whether the
connectors are analog or digital, and select the digital audio output and digital audio
input devices. Only speakers that are currently being used are displayed.
Microphone: Enables fine control over the recording volume and playback volume
of the microphone. Includes buttons for noise suppression and acoustic echo
cancellation.
Configuring Speaker and Sound Options
61
62
Line In (Digital Input): Enables control over volume, playback, mute, recording,
and multistreaming audio.
HDMI Output: Enables you to select the Environment and Equalizer settings. You
can select an environment, such as Stone Room or Auditorium. Under Equalizer,
you can either click a preset button, such as Pop or Live, or manually adjust the
settings and then save them for easy selection later.
Getting Started (features vary by model)
Configuring sound for recording with the
Realtek HD Audio Manager
The microphone connector is ready to use for recording sound. If you want to use another
connector for recording, such as the Digital Audio In connector, complete the following
steps to select it:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, and then Realtek HD Audio Manager.
4 Click the Line In tab.
5 Click Digital In tab, and then select Set Default Device.
6 Click OK to close the window.
NOTE: You can retask the front pink, blue, and green connectors to perform other audio
functions; see “Retasking front panel audio connectors.”
Retasking front panel audio connectors
You can retask the Line In, Mic In, Headphone, and Front Speaker Out connectors on the
front of the computer, as necessary.
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Hardware and Sound, and then click Realtek HD Audio Manager.
4 Click a front connector icon that you want to retask.
NOTE: Only the connectors that are not dimmed are able to be retasked.
Configuring Speaker and Sound Options
63
5 Place a check in the device check box that you want to select, and then click OK.
You can now use the front connectors as either input or output devices.
Configuring multistreaming audio
The Realtek HD Audio Manager software enables you to listen to two different audio
sources on two different speaker sets.
For example, you can hear one audio source through a rear-panel speaker connection,
and a second source through a front-panel headphone or speaker connection. You must
configure multistreaming audio for the system if you want to hear two audio sources on
separate speakers.
Audio output overview
The front-panel audio output is the green stereo headphone connector only.
The rear-panel outputs are the speaker connectors that can be set up as multichannel out
from stereo 2.0 to 7.1 (select models only) configurations. Refer to your user
documentation for information about setting up powered speakers or your AV receiver.
64
Getting Started (features vary by model)
Audio input overview
You can select two of the following audio sources to play through front-panel headphone
and rear-panel speaker connectors:
1 From an externally connected device source, such as:
A microphone with cable connected to Mic In (pink).
An MP3 player with cable connected to Line In (blue).
2 From an internal source inside, or directly connected to, the computer, audio files may
reside on: hard disk drives, DVDs, CDs, USB drives, HP Personal Media Drives, or
any connected device. Play internal media files through programs such as:
Microsoft Windows Media Player.
Other installed media player software.
NOTE: Digital Audio In cannot be multistreamed.
When to use multistreaming audio
You may multistream two audio sources as described in the following typical examples:
1 For online gaming:
You hear 5.1 game sound on AV receiver or powered speakers.
You also hear gaming conversation on a headset.
See “Example 1: For online gaming.”
2 For digital home entertainment:
You hear DVD sound on a living room TV/display or AV receiver from the
rear-speaker connections.
You also hear sound on the computer or powered speakers that are connected to
the front-panel green headphone jack, from one of the following external
computer audio sources:
a
Front-panel Line In
b
Internal source residing on a hard disk drive, DVD, CD, USB drive, or other
external device
See “Example 2: For digital home entertainment.”
Configuring Speaker and Sound Options
65
Setting up multistreaming audio
Example 1: For online gaming
To configure multistreaming audio output for online gaming with Realtek HD Audio
Manager, you must enable Voice-over-IP software (software used to converse over the
Internet). Other players hear your voice from the microphone via the Internet, and you hear
the game audio from the rear speakers.
1 Connect the audio input and output connectors as follows:
A headphone set to the front Headphone Out (green) connector
A microphone to the front Mic In (pink) connector for online conversation
A set of powered stereo 5.1 or 7.1 speakers to the rear Speaker Out connectors
for gaming sound output
2 Click the Realtek HD Audio Manager icon on the taskbar to open the
Realtek HD Audio Manager window.
3 Click the Device Advanced Settings button.
4 Select Make front and rear output devices playback two different audio
streams simultaneously.
5 Place a check in the Output Mic In/Line In to front panel check box, and
click OK.
Or
Place a check in the Output Mic In/Line In to rear panel check box, and
click OK.
Example 2: For digital home entertainment
To configure multistreaming audio output for digital home entertainment with Realtek HD
Audio Manager:
1 Connect the audio output connectors as follows:
A headphone set or powered speakers to the front Headphone Out (green)
connector for stereo music playback
A set of powered stereo 5.1 or 7.1 speakers to the rear Speaker Out connectors
for DVD playback sound output
2 Click the Realtek HD Audio Manager icon on the taskbar to open the
Realtek HD Audio Manager window.
3 Click the Device Advanced Settings button.
66
Getting Started (features vary by model)
4 Select Make front and rear output devices playback two different audio
streams simultaneously.
5 Place a check in the Output Mic In/Line In to front panel check box, and then
click OK.
Or
Place a check in the Output Mic In/Line In to rear panel check box, and then
click OK.
Configuring audio for Windows Media Center
After you have installed, connected, and configured the speakers, follow these steps to
configure multichannel audio output for Windows Media Center:
1 Click the Windows Start Button
on the taskbar.
2 Click Windows Media Center.
3 Under Tasks, click settings, General, and then click Windows Media
Center Setup.
4 Click Set Up Your Speakers. The Welcome to Speaker Setup window opens.
5 Click Next.
6 Choose the speaker connection type, and then click Next.
7 Select the number of speakers, and then click Next.
8 Click Test to test the speakers.
9 Click Finish.
Selecting recording devices
(Type 6 connectors only)
To select a sound recording device:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
3 Click Sounds and Audio Devices (or Sounds, Speech and Audio Devices).
The Sounds and Audio Devices window opens.
4 Click the Audio tab.
5 Under Sound Recording, select a recording device, such as Realtek HD Front
Pink Jack.
6 Click OK.
7 Close the window.
Configuring Speaker and Sound Options
67
Resolving sound issues
If you do not have sound from the speakers, try the following:
68
Check the volume and mute settings. See “Connecting Headphones.”
Use active (powered) speakers, or speakers with an amplifier.
Check the sound cable connections.
Ensure that the software program and sound software are properly configured.
Some software programs may result in low volume, even when the Volume is turned to
the maximum value. If this is the case, click the Volume icon on the taskbar, and
increase the system volume.
Reconfigure the sound software for surround sound.
Reinstall the audio card drivers by using application reinstallation program; refer to
the Troubleshooting and Maintenance Guide that came with the computer.
Getting Started (features vary by model)
Introducing Your Computer Software
The operation of your computer is controlled by two kinds of software:
The Microsoft Windows Vista operating system, which displays the desktop on the
monitor and controls your computer’s hardware, peripherals, and software programs.
Software programs that perform specific functions, such as word processing.
The software programs included with the computer may vary by model and by
country/region.
Learning More About Software
You can find information on using software and on the Microsoft Windows Vista operating
system in this guide and the onscreen Help. For Microsoft Windows Vista, you can also
open the built-in Help and Support Center.
Press the Help button (labeled with a question-mark icon) on your keyboard (select
models only).
Or
Click the Windows Start Button
Support.
on the taskbar, and then click Help and
For help with specific software, refer to the onscreen Help within the program.
Using the Desktop
The desktop is the work area that appears on the monitor screen. It includes the taskbar
along one edge, and shortcut icons that make it easy to find the things you need.
The taskbar shows the Windows Start Button
; a button for each open window, so that
you can switch between programs; and the notification area that includes the time.
A shortcut icon is a small picture that you click to open a folder or start a program. One
icon on the desktop that performs a special function is for the Recycle Bin, which collects
files or shortcuts that you delete. When you empty the Recycle Bin, the files or shortcuts are
permanently deleted. You can retrieve items from the Recycle Bin until you empty it.
Introducing Your Computer Software
69
Removing desktop icons
You can remove most desktop icons by deleting them.
To delete a desktop icon:
1 Right-click the desktop icon.
2 Click Delete. The icon is placed in the Recycle Bin.
Retrieving desktop icons
1 Double-click the Recycle Bin icon on your desktop.
2 Drag the icon onto the desktop.
Removing files permanently
1 Right-click a file, and then click Delete.
2 Right-click the Recycle Bin icon on the desktop, and then click Empty Recycle Bin.
Using the Windows Start Button Menu
Click the Windows Start Button
Start menu, you can:
on the taskbar to open the Start menu. From the
Open programs or documents.
Open the Help and Support Center.
Start a search.
Open the Control Panel to view or change settings.
Using the All Programs menu
To find the software programs on your computer:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
The All Programs menu displays a list of folders organized according to task
(select models only).
A folder contains a list of items. Each item is actually a shortcut, or link, to a program, a
document, or another folder. The Music folder, for example, contains shortcuts to the
programs that you use to play music CDs.
70
Getting Started (features vary by model)
Organizing the All Programs list
To change the name of an item:
1 Right-click the item.
2 Click Rename.
3 Type the new name, and then press Enter on the keyboard.
4 Click Yes in the message that appears.
To copy an item:
1 Right-click the item.
2 Click Copy.
3 Go to the desktop or folder, right-click an empty area, and then click Paste.
If you use Add or Remove Programs in the Control Panel to delete a software program, the
shortcut in All Programs may not be removed. To remove a shortcut:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
3 Click the folder.
4 Right-click the shortcut, and then click Delete.
Using the Control Panel
The Control Panel is where you can set up or change properties and settings for the
monitor, the keyboard, the mouse, the modem, a network connection, and other
components and features of the computer. The Control Panel also provides tools for
changing system performance, adding hardware, adding or removing programs, and
other tasks.
To open the Control Panel:
1 Click the Windows Start Button
on the taskbar.
2 Click Control Panel.
Introducing Your Computer Software
71
Resizing Windows
All windows have three buttons in the upper-right corner. The middle
button is either the Maximize button or the Restore Down button,
depending on the state of the window.
Feature
Name
Description
Minimize
Collapses the window to the taskbar (but does not close it). To
bring the window back up, click the taskbar button with the
name of the window.
Maximize
Expands the window to the full-screen size.
Restore
Down
Reduces the window from full-screen size, so that it covers
only a portion of the screen.
Close
Closes the window, and stops the program or task.
Resize
Resizes a window (not available when window is
maximized). Move your mouse cursor over any window
border until the cursor becomes a double-headed arrow. Click
and hold down the left mouse button. Drag the border to the
left or right to change the width. Drag the border up or down
to change the height.
Scroll bar
Appears in a window when the information does not fit on
one screen. Clicking and dragging a vertical scroll bar moves
the screen up and down. Clicking and dragging a horizontal
scroll bar moves the screen left and right.
Working with Digital Images
You can connect a digital image source, such as a digital camera or a digital video
camera, to the computer either directly or through a docking station. Digital picture files
that you copy or download from the device appear in the Pictures folder.
Digital cameras and other digital imaging devices use memory cards, or media, to store
digital picture files. You can copy digital picture files from the memory cards used by
digital cameras and other digital imaging devices by using the memory card reader (select
models only).
72
Getting Started (features vary by model)
About the Internet
This section describes connecting to and using the Internet, including how to use a Web
browser and electronic mail (e-mail).
Use the Internet to search for information or services on the Web, or to retrieve, read, or
send e-mail messages.
The Internet is a group of computers that communicate with each other through telephone
lines, digital services, or cable lines. Each Internet computer is independent, and its
operators choose which files to make available to users of the Internet. To connect your
computer to the Internet and use the information and services available there, you need an
Internet Service Provider (ISP).
ISPs are businesses that give you access to the Internet, and most of them provide e-mail
service. ISPs usually charge a monthly fee for their services. When your computer connects
to the Internet, it is actually communicating with the Internet computer belonging to the ISP.
The ISP verifies your account, and then provides you access to the Internet. You use a Web
browser program to search for and display Web site information. Some ISPs allow you to
choose a browser program, while others provide their own browser.
Your connection to an ISP may be through a traditional telephone dial-up modem, local
area network (LAN), cable modem, digital subscriber line (DSL), or asymmetric digital
subscriber line (ADSL). (DSL, ADSL, and cable ISPs are not available in all
countries/regions.)
The World Wide Web (WWW), also called the Web, is a public part of the Internet used
by individuals, companies, governments, and organizations. These individuals and groups
have created millions of Web sites in support of their activities. A Web site consists of one
or more Web pages. A Web page is a file or group of files that a user can access by
entering the file location, or Uniform Resource Locator (URL).
The URL identifies a Web site location, typically in the form http://www.name.extension
(for example, http://www.hp.com). The URL may include the path to a specific file
within that site. Each period, or dot, in the URL separates elements within the address. For
example, you will see the URL extension .com used by companies. When you enter the URL
into your browser address box and press the Enter key on your keyboard, the browser
contacts that location and opens the Web page for you.
Imagine that you are reading a newspaper. On page 1, you may read something like “For
more details, see page 3, column 2.” You turn the page for more information. A hyperlink
on a Web page works the same way, except that you move to the new page by clicking
the hyperlink. The way that a hyperlink links files together is what gives the Web its name,
because the Web weaves together and connects ideas from all over the world.
Your e-mail address identifies the electronic post office box where people can send you
electronic mail. E-mail addresses have the form name@domain.extension. The domain is
usually the name of the ISP or organization. The extension usually identifies the type of
organization. For example, if your name is Jane Jones, and XYZ is your ISP, your e-mail
address might be JaneJones@xyz.com, with the extension .com indicating that XYZ is a
company. For information on using e-mail, see “Sending and Receiving E-Mail.”
Introducing Your Computer Software
73
Using a Browser
A Web browser program searches for and displays Web site information. How you
explore the Internet depends on whether your ISP provides the browser or allows you to
choose your own.
Once you are connected to the Internet, your browser opens the home Web page. You can
go to a different Web site by entering its address (such as http://www.hp.com) into
the address box in the browser, and then pressing Enter on your keyboard. Or you can
use the browser search feature to search for references to a specific word or phrase on
the Web.
Searching the Internet
Most Web browser programs include a search feature. You may need to click a button or
select a menu option to display the search feature, depending on the type of browser
program. Type a question, or a word that describes the information that you want to find,
into the Search box, and then press Enter.
The Windows search feature includes direct use of Internet Explorer Search.
NOTE: If your ISP provides the browser, you may not be able to use Internet Explorer to
search the Internet.
To begin a search:
1 Click the Windows Start Button
on the taskbar.
2 Type a word or question; what you type automatically appears in the Start Search
box. As you type, the search results appear in the left pane.
3 Do one of the following:
Click a result to open it.
Click the X in the search window to clear the results of the search and return to the
main list of programs.
Click See all results to display a list of all found search items on the computer
and for advanced options.
Click Search the Internet to search the Internet by opening your browser.
Restricting Internet content
The Internet provides you with a wide variety of information, but some information may
not be suitable for every viewer. With Content Advisor (a feature of Internet Explorer),
you can:
74
Set up a password.
Control Internet access.
Set up a list of Web sites that people who use your computer cannot view.
Adjust the type of content people can view with and without your permission.
Getting Started (features vary by model)
Once you set up restricted rating levels in Content Advisor, users can view Web sites and
other pages that you have specified under the rating setup. However, to view unrated Web
sites or pages, users must enter the Content Advisor password that you have set. This
means that any unrated page, even Help and Support or Internet Explorer, is not viewable
if the user does not know the password.
To enable Content Advisor:
1 Click the Windows Start Button
on the taskbar.
2 Click Internet Explorer.
3 Click Tools, and then click Internet Options.
4 Click the Content tab.
5 In the Content Advisor area, click Enable.
6 Click the General tab, click Create password, and type a password.
7 Click OK, and then click OK again.
To allow access to an unrated site or page you approve of:
1 Open the Web site.
2 When the password window appears, select the Always allow viewing or
Allow viewing only this time option.
Using the AVG Antivirus Software
When you use the computer for e-mail, network, or Internet access, you expose it to
computer viruses. Computer viruses can disable or damage your operating system,
software programs, or computer utilities.
Antivirus software can detect most viruses, remove them, and, in most cases, repair any
damage that they have caused. To provide ongoing protection against newly discovered
viruses, you must keep antivirus software up to date.
AVG, an antivirus software program, is preinstalled on your computer and includes a free
trial subscription of protection updates. You can quickly check for updates in the AVG Test
Center window. Hewlett-Packard strongly recommends that you protect the computer
against new viruses beyond the trial period by purchasing an extended update service.
Opening AVG software
When you first set up the computer, AVG helps you to configure and register your copy
of AVG.
Ensure that you set up AVG before you start using the Internet.
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
Introducing Your Computer Software
75
3 Click AVG, and then click AVG Test Center.
4 Click the Check for Updates button to get the latest AVG updates, which
keep your computer protected.
5 For more information about using and updating the AVG software, press F1
on your keyboard to open the AVG Help window.
Manually running a system scan
To scan all hard drives on your computer for viruses and security risks:
1 Double-click the AVG icon on the desktop.
Or
Click the Windows Start Button
and then click AVG Test Center.
on the taskbar, All Programs, AVG,
2 Click the Scan Computer button. Depending on the number of files on
your computer, this may take several minutes. If a virus is found, AVG
removes it or provides instructions for removal.
3 When the scan is complete, click Close. AVG lists any security risks or
viruses found in the Security status window.
Scheduling a full system scan time
To set up the time for a full system scan:
1 Click the Windows Start Button
on the taskbar, All Programs, AVG,
and then click AVG Control Center.
2 Select Scheduler from the Security status window.
3 Double-click the Scheduled Tasks button.
4 Click New Schedule.
5 Click the Task tab.
6 Type a name for your scan in the Name window.
76
Getting Started (features vary by model)
7 Use the drop-down arrows to select what type of task to schedule, such as Test or
Update.
8 Click the Perform Task tab. Use the drop-down arrows to select frequency of task
settings and a start date.
9 Click Apply, and then OK.
10 Click the Close button.
NOTE: If the computer is in Sleep mode, the AVG program does not perform a scheduled
antivirus scan. AVG displays a message asking if you want to Start Task as soon as the
computer is out of Sleep mode.
Setting up a custom scan
To create a custom scan for specific files, folders, CDs, and drives:
1 Click the Windows Start Button
then click AVG Test Center.
on the taskbar, All Programs, AVG, and
2 Click the Scan Selected Areas button.
3 Place a check in the check box next to each drive or folder you want
to scan.
4 Click Scan Selected Areas button. Depending on the number of files on your
computer, this may take several minutes. If a virus is found, AVG will remove it or
provide instructions for its removal.
5 When the scan is complete, click Close. AVG lists any security risks or viruses found
in the Security status window.
NOTE: If the computer is in Sleep mode, the AVG program does not perform a scheduled
antivirus scan. AVG displays a message asking if you want to Start Task as soon as the
computer is out of Sleep mode.
Sending and Receiving E-Mail
E-mail enables you to send and receive letters, pictures, postcards, and even music and
video clips.
NOTE: E-mail may contain a virus in the message itself or as an attachment. To protect
your computer, do not open any message that originates from an unfamiliar source or that
appears suspect to you. Instead, delete such messages.
Your computer comes with an e-mail program from Microsoft called Windows Mail (select
models only). You may also use e-mail programs from other vendors. Some ISPs provide
their own e-mail programs. You use an e-mail program to send, receive, and organize your
messages. You can organize, read, and create new messages even when you are offline
(not connected to the Internet).
Introducing Your Computer Software
77
Using Windows Mail
To set up Windows Mail, you first need some information from your ISP: your e-mail
address, user name, password, the names of your incoming and outgoing e-mail servers,
and perhaps some other details.
The first time you start Windows Mail, make sure the computer is connected to the Internet,
and follow the wizard to set up your account.
To add an account in Windows Mail:
1 Click the Windows Start Button
on the taskbar.
2 Click All Programs.
3 Click Windows Mail.
4 Click Tools, and then click Accounts.
5 Click Add, E-mail Account, and then click Next.
6 Follow the onscreen instructions to add your account.
Using the e-mail program provided by your ISP
Follow the instructions provided by your ISP to install its Web browser and e-mail program,
and to set up and use your e-mail account. You can then send and receive e-mail when
your computer is connected to your ISP.
Software Quick Reference Table
(Select models only)
Your computer includes a number of software programs that:
Record and play CDs.
Record data CDs.
Import and edit video files.
Record video CDs and DVDs.
Organize digital media files.
The following table describes the functionality that is specific to each of these programs.
Use the table to determine which program to use to perform a task.
Note that some of the programs that are listed may not be included with your model, and
that this is not a complete list of all included software.
To open any of these programs, click the Windows Start Button
on the taskbar,
click All Programs, select the program folder (for example, DVD Play), and then click
the program name to open the software.
78
Getting Started (features vary by model)
With this program:
DVD Play
(select models only)
CyberLink Power2Go
(select models only)
CyberLink
PowerProducer
(select models only)
CyberLink LabelPrint
(select models only)
Microsoft Windows
Movie Maker
(select models only)
You can:
Play DVD movies and video CDs (VCDs).
Play Blu-ray and High-Definition DVDs if the computer has a Blu-ray and
HD DVD disc drive.
Use the Zoom and Pan features.
Create viewing bookmarks.
Record data and music files.
Record a copy of an existing music or data CD to use on the computer.
Create customized music CDs from CDs in your collection, or from .wav, .mp3,
or .wma files. These CDs can be played in your home or car stereo.
Copy and share data files.
Create archive CDs or DVDs from files on your computer.
Copy video files.
Verify that the disc has been created without errors.
Record movie files to create VCDs and DVDs that you can play on some DVD
players.
Copy and share video files.
Capture video files.
Edit video files.
Burn a label directly onto LightScribe-enabled CDs, DVDs, and mini-discs by
using LightScribe technology.
Burn a label directly onto the disc’s label side by using Labelflash technology.
Print labels to attach directly onto a disc.
Import audio, video, and other media files from videotape, audiotape, Web
cameras, or television broadcasts.
Record audio and video files to create a video project that becomes a
Microsoft Windows Media source file with a .wmv extension.
Edit and preview files.
Send a movie in an e-mail or upload it to a Web server.
Add music files (.mp3).
Import audio files such as .mp3, .asf, or .wma; video files such
as .wmv, .asf, .avi, or .mpg; or image files such as .jpg or .gif.
Create .avi and .wmv (Windows Media Video) files.
NOTE: You may have a software update CD included with your computer. You may need to install this CD before
using the DVD Writer/CD Writer drive. To do this, follow the installation instructions that came with the CD.
Introducing Your Computer Software
79
80
Getting Started (features vary by model)
Managing Files
A file is any unit of information that is named and stored on the computer hard disk drive
or other electronic storage media, such as a CD, diskette, or even in a digital camera. A
file can be a document, picture, music, video, or other data. Almost everything that you do
on the computer involves working with files.
The computer can copy files to other storage media within component drives, such as
diskettes, memory cards, CDs or DVDs, or it can send them to output devices, such as a
printer.
Organizing Files with Folders
In Windows Vista, folders enable you to organize the files on the computer. Like paper
folders within a filing cabinet, folders on the computer provide a way to group related files
together.
A folder can contain any type of file, and it can even contain other folders. Each file within
a folder must have a unique name, but two different folders can have files with the
same name.
There are two methods for working with files and folders on the computer:
The Computer view enables you to quickly see all the files and folders within a specific
folder on the computer. It also contains links to common tasks for managing files, such
as copying, moving, deleting, and renaming.
To open the Computer view, click the Windows Start Button
and then click Computer.
on the taskbar,
Windows Explorer enables you to quickly see all the folders and files on the computer.
It also makes it easy to move or copy files from one folder to another.
To open Windows Explorer, click the Windows Start Button
and then click Windows Explorer.
on the taskbar,
To navigate the Computer and Windows Explorer views, double-click folders to open and
display their contents. Click the Back arrow button to retrace the path through the opened
folders.
Managing Files
81
Creating Folders
1 Click the Windows Start Button
on the taskbar, and then click Computer.
Or
Click the Windows Start Button
Explorer.
on the taskbar, and then click Windows
2 Navigate to the location where you want to place the new folder.
3 Click Organize, and then click New Folder.
4 Type a name for the folder, and then press Enter on the keyboard.
Moving Files
CAUTION: Do not move any file that is part of an installed program. Doing so
can cause the program to become unusable.
1 Click the Windows Start Button
on the taskbar, and then click Computer.
Or
Click the Windows Start Button
Explorer.
on the taskbar, and then click Windows
2 Find the file that you want to move, and then click it to select it.
3 Click Organize, and then Cut.
4 Find and open the folder in which you want to put the file.
5 Click Organize, and then Paste.
NOTE: You can also move files by dragging them into a new location. (You can have two
or more Windows Explorer windows open at one time.) Select an item in Computer or in
Windows Explorer, and then press and hold the right mouse button while moving the item
into another folder. Release the mouse button and click Move Here to place the item in
the new location.
82
Getting Started (features vary by model)
Finding Files
To find a file, you can use the Search box at the top of every folder, or the search box on
the Windows Start Button menu, which searches the whole computer.
To search from a folder Search box:
1 Click the Windows Start Button
on the taskbar, and then click Computer.
Or
Click the Windows Start Button
Explorer.
on the taskbar, and then click Windows
2 Find the folder that you want to search. Search looks in the current folder and all
subfolders.
3 Click in the search box at the top of the window, and begin to type.
The Search box filters according to what you type. It displays files if your term matches
the file name, tags, or other file properties. It displays text documents if the term occurs
in any of the text inside the document file.
To search from the Windows Start Button menu:
1 Click the Windows Start Button
on the taskbar.
2 Type a word or question; what you type automatically appears in the Start Search
box. As you type, the search results appear in the left pane.
3 Do one of the following:
Click a result to open it.
Click the X to clear the results of the search and return to the main list of
programs.
Click See all results to show the results in a folder for advanced options.
Click Search the Internet to search the Internet by opening the browser.
Managing Files
83
Renaming Files
CAUTION: Do not change the file name extension (the last three characters of a
file name, after the period). Doing so could make the file unrecognizable to
the computer.
1 Click the Windows Start Button
on the taskbar, and then click Computer.
Or
Click the Windows Start Button
Explorer.
on the taskbar, and then click Windows
2 Find the file or folder you want to rename, and then click it to select it.
3 Click Organize, and then Rename.
4 Type the new name, and then press Enter on the keyboard.
NOTE: Another way to rename a file is to right-click the file, and then click Rename.
Deleting Files
CAUTION: Do not delete any file that is part of an installed program. Doing so
can cause the program to become unusable.
1 Find the file that you want to delete, and then click it to select it.
2 Click Organize, and then Delete.
3 Click Yes to confirm the delete and send the file to the Recycle Bin.
If you make a mistake and need to retrieve the deleted file, see “Retrieving Files from the
Recycle Bin.”
NOTE: Another way to delete a file is to right-click the file, and then click Delete.
Retrieving Files from the Recycle Bin
If you discover that you need a file that you have deleted, you can usually retrieve it from
the Recycle Bin. When a file is deleted, it goes to the Recycle Bin and stays there until the
Recycle Bin is emptied manually or it is cleared to make room for more recently
deleted files.
1 Double-click the Recycle Bin icon on the desktop.
2 Right-click the file that you want to retrieve, and then click Restore this item.
The file is removed from the Recycle Bin and goes back to its previous location.
84
Getting Started (features vary by model)
Copying Files
1 Click the Windows Start Button
on the taskbar, and then click Computer.
Or
Click the Windows Start Button
Explorer.
on the taskbar, and then click Windows
2 Find the file that you want to copy, and then click it to select it.
3 Click Organize, and then Copy.
4 Find and open the folder in which you want to put the file.
5 Click Organize, and then Paste.
NOTE: You can also copy files by dragging them into a new location. Select an item in
Computer or in Windows Explorer, and then press and hold the right mouse button while
moving the item into another folder. Release the mouse button, and then select Copy
Here to copy the item to the new location.
Using a Printer
For instructions on connecting and using a printer, refer to the user manual that came with
the printer.
Printers receive instructions from the computer by means of software programs called
printer drivers. In many cases, the computer automatically finds the necessary printer
driver for your particular printer to work with the computer. If it does not, follow the
instructions that came with the printer to install the specific printer driver manually.
You can print text and graphics from most software programs and Web sites if you have
a printer connected to the computer, and if the computer has the necessary software
installed for the printer.
To print:
1 Click File on the program menu bar, and then click Print.
2 Select your printing options:
Select the printer.
Choose the page range (for example: all pages, current page, or range of
pages).
Determine the number of copies.
3 Click OK or Print.
Managing Files
85
86
Getting Started (features vary by model)
Using CD and DVD Media Drives
Using the CD and DVD Drives
Your computer can come with several types of CD or DVD drives that allow you to perform different tasks. What
you can do depends on what kind of drive you have.
Allows you to:
CD-ROM
CD-RW
DVD-ROM
DVD+RW/+R
Blu-ray
DVD+RW/+R
HD
DVD+RW/+R
Read data
from CDs.
•
•
•
•
•
•
Play music CDs.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Read DVDs.
Record (burn) data
or music to discs.
Play DVD movies.
Record (burn) DVD
movies.
•
•
Read Blu-ray discs.
•
Record data to
Blu-ray discs.
•
Read HD discs.
•
The combination (combo) drive is available on select models only. It combines the functions of two drives into one:
either a DVD+RW/+R drive (DVD writer) and a CD-RW drive (CD writer), or a DVD-ROM drive and a
CD-RW drive.
Using CD and DVD Media Drives
87
Handling CDs and DVDs
To avoid damaging a disc, follow these guidelines:
Return the disc to the case when you are finished using it.
Handle the disc by its outside edges or center hole only.
Do not touch the unlabeled side of a disc or place the unlabeled side down on a desk.
Doing so could scratch the surface of the disc.
Store discs at room temperature.
Inserting and removing CDs and DVDs
CAUTION: Use only standard-shaped (circular) discs in the drives. Using
non-standard discs, such as heart-shaped discs or business-card discs, may
damage the drive.
To insert a CD or DVD:
1 With the computer turned on, press the Eject button near the front of the drive to open
the disc tray.
NOTE: On some computers, the drive is located behind a door on the front of the
computer. On other computers, the drive is a slot that does not include a disc tray.
2 Remove the CD or DVD from its case, holding the disc edges or center hole only.
3 Gently place the disc in the tray or press the disc into the slot drive with the label
facing up or facing right if the drive is vertically positioned in the computer.
NOTE: If you have a slot drive, you can skip step 4 because the drive does not
include a disc tray.
NOTE: On a double-sided DVD, read the text around the center hole to determine
which side (A versus B or Standard versus Widescreen) to play. Place the disc in the
tray with the label facing up for the side that you want to play. If the CD drive is
vertically positioned in the computer, place the disc with the label facing right for the
side that you want to play.
88
Getting Started (features vary by model)
4 Close the disc tray by:
Gently pushing the tray into the computer.
Or
Clicking the open/close button on the control panel for the program that controls
the drive.
Or
Pressing the media control open/close button or Eject button on the keyboard
(select models only).
Or
Pressing the Eject button on the drive, if it is accessible.
To remove a CD or DVD:
1 With the computer turned on, open the disc tray by pressing the Eject button.
2 Holding on to the disc edges or center hole only, lift the disc out of the disc tray or out
of the slot drive.
NOTE: If you have a slot drive, you can skip step 4 because the drive does not
include a disc tray.
3 Place the disc in its case.
4 Close the disc tray by gently pushing the tray into the computer.
Compatibility Information
An important feature of a DVD Writer/CD Writer drive is its high level of compatibility
with other optical drives and CD and DVD players:
The CDs that you create play in most home and car stereos as well as most computer
DVD-ROM and CD-ROM drives.
The DVDs that you create are compatible with some DVD video players and with most
computer DVD-ROM drives.
CD-R discs are more compatible with home and car stereos than CD-RW discs are.
Blu-ray disc drives are required to play Blu-ray discs.
Blu-ray disc drives can read Blu-ray discs and record to Blu-ray discs.
HD disc drives are capable of playing HD discs but not recording HD data to disc.
The DVD Writer/CD Writer drive is able to read from and record to almost every type of
optical disc. Writing speed rates for the DVD Writer/CD Writer drive are fast, allowing
quick recording times.
Using CD and DVD Media Drives
89
Disc Features and Compatibility Table
Disc
File type
CD-ROM
Can be
recorded
onto
Plays in
computer
Plays in
home or car
stereo
Plays in
home DVD
player
Data
No
Yes
No
No
Music
No
Yes
Yes
Varies by model
Data
Yes
Yes
No
No
Music
Yes
Yes
Varies by model
Varies by model
Data
Yes
Yes
No
No
Music
Yes
Yes
Varies by model
Varies by model
Data
No
Yes
No
No
DVD movie
No
Yes
No
Yes
Data
Yes
Varies by model
No
No
DVD movie
Yes
Varies by model
No
Varies by model
DVD+R and
DVD-R
Data
Yes
Yes
No
No
DVD movie
Yes
Yes
No
Varies by model
Double-layer
DVD+R/DVD-R
Data
Yes
Varies by model
No
Varies by model
DVD movie
Yes
Varies by model
No
Varies by model
DVD+RW and
DVD-RW
Data
Yes
Yes
No
No
DVD movie
Yes
Yes
No
Varies by model
Blu-ray DVD
Data
Yes
Yes
No
Varies by model
Movie
Yes
Yes
No
Varies by model
Data
No
Yes
No
Varies by model
Movie
No
Yes
No
Varies by model
DVD movie
No
Yes
No
Varies by model
CD-R
CD-RW
DVD-ROM
DVD-RAM
HD DVD
VCD
NOTE: Some computers come with the double-layer DVD Writer. It supports single-layer and double-layer DVD media. Double-layer
technology gives you greater capacity and allows you to store up to 8 GB* of data on double-layer DVD+R or DVD-R media.
Double-layer is a new technology. Double-layer media compatibility varies widely with some home DVD players and DVD-ROM drives.
*1 GB is defined as 1 billion bytes. 1 GB = 1 billion bytes when referring to hard disk drive capacity. Actual formatted capacity
is less.
For the latest disc compatibility information for your computer, go to the HP Support Web site at: http://www.hp.com/support
NOTE: Double-layer DVD technology is supported by select models only.
90
Getting Started (features vary by model)
Optical Drive Quick Reference Table
Optical
drive can:
CD-ROM CD-RW
DVDROM
DVDRAM
DoubleDVD+RW/+R layer
DVD-RW/-R DVD
Combo
CD-RW/
DVD
LightScribe
BD HD
DVD+RW/+R DVD+RW/+R
Read CDs,
CD-Rs, and
CD-RWs.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Read DVDs.
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Read data on
a CD.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Play music.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Record data
or music to
disc for
storage or
backup.
No
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
View DVD
movies.
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Record DVD
movies.
No
No
No
Yes
Yes
Yes
No
Yes
Yes
Play games.
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Create
LightScribe
label.
No
No
No
No
No
No
No
Yes
Yes
Play
Blu-ray DVD.
No
No
No
No
No
No
No
No
Yes
Play
HD DVD.
No
No
No
No
No
No
No
No
Yes
Record
data to
Blu-ray disc.
No
No
No
No
No
No
No
No
Yes
Record HD
data to DVD.
No
No
No
No
No
No
No
No
No
Using CD and DVD Media Drives
91
Using Blu-ray and HD Disc Drives
If the computer came with a Blu-ray (BR) and high-definition (HD) disc drive, there are three
programs that are designed specifically for use with this drive:
DVD Play plays Blu-ray, high-definition (HD), and regular commercial DVD discs.
PowerProducer is a video editing program for creating Blu-ray or DVD discs.
PowerToGo is a Blu-ray disc recording (burning) program for different types of data
storage, such as video, music, pictures, and other data. This program enables you to
record data to Blu-ray, HD DVD, and other recordable DVD discs.
NOTE: The BD HD DVD+RW/+R drive does not support recording high-definition data
to disc.
For more information about using these programs, see “Playing DVDs” and “Creating
Audio and Data Discs.”
92
Getting Started (features vary by model)
Using the Memory Card Reader
Digital cameras and other digital imaging devices use memory cards, or media, to store
digital picture files. The optional memory card reader (select models only) can read from
and write to a variety of types of memory cards and the IBM Microdrive disk drive.
The card reader is accessible directly on the front of the computer. It has four or two
horizontal card slots, which accept the memory cards and the Microdrive disk drive.
You can place media in one or more of the card slots and use each media independently.
Place only one piece of media in a slot at one time.
Each card slot has its own drive letter and icon. When you insert media, the display label
may change to the title of the media, if a title is present.
When you insert media, the Safely Remove Hardware window may appear. If it opens, or
if you open the Safely Remove Hardware window by mistake, click Close.
CAUTION: Do not click Stop in the Safely Remove Hardware window with the
USB Mass Storage Device selected. Doing so removes the operating system
recognition of the memory card reader from your computer, and you must
restart the computer to see your memory card reader again.
To use the memory card reader:
1 Insert the media into the card slot until it stops.
The activity light (A) on the memory card reader lights, and the computer
automatically detects the media.
NOTE: You must insert media correctly. Note the direction of the notched corner on
the media. For more information, see “Media Insertion Guide.” CompactFlash and
Microdrive are keyed and cannot be inserted incorrectly. Insert the receptacle edge
(holes) of this media into the slot.
Using the Memory Card Reader
93
2 Select a program to access your files. The computer opens a program, so that you can
access the media contents. You can copy files from or to the media.
Or
If the AutoPlay window does not open, click the Windows Start Button
on the
taskbar, click Computer, and then double-click the Memory Card icon to display
the files on the memory card.
3 When you are finished, right-click the drive icon, click Eject, check that the activity
light is on but not blinking, and then remove the media. A steady activity light
indicates that the computer is not reading or writing the media card.
CAUTION: Do not try to remove media when the activity light is blinking. Doing
so may cause loss of data.
Media Insertion Guide
4-slot memory card reader (select models only)
A Activity light
B Upper-left slot
C Lower-left slot
D Upper-right slot
E
94
Lower-right slot
Getting Started (features vary by model)
Card
Insert the media
4-slot reader
location
SmartMedia (SM) memory card
Facing up
B (upper-left) SM
xD media
Facing up
B (upper-left) xD
CompactFlash Type I media
Receptacle edge (holes)
C (lower-left) CF/l
CompactFlash Type II media
Receptacle edge (holes)
C (lower-left) CF/II
Microdrive disk drive
Receptacle edge (holes)
C (lower-left) MD
Secure Digital (SD) memory card
Facing up
D (upper-right) SD
Mini Secure Digital (MiniSD)
Memory Card*
Facing up
D (upper-right)
MiniSD
MultiMediaCard (MMC)
Facing up
D (upper-right) MMC
Reduced size MultiMediaCard
(RSMMC)*
Facing up
D (upper-right)
RSMMC
MultiMediaCard Plus (MMC +)*
Facing up
D (upper-right)
MMC Plus
MultiMediaCard Mobile
(MMC Mobile)*
Facing up
D (upper-right)
MMC Mobile
Memory Stick (MS) memory card
Facing up
E (lower-right) MS
Memory Stick (MS-Pro)
memory card
Facing up
E (lower-right) PRO
Memory Stick (MS-Pro Duo)
memory card*
Facing up
E (lower-right)
PRO Duo
Memory Stick (MS-Duo)
memory card*
Facing up
E (lower-right)
MS Duo
*Select models only. Not available in all countries/regions.
NOTE: Some memory cards, such as CF Ultra/III, are not compatible with the memory
card reader that came with the computer.
Using the Memory Card Reader
95
Understanding the Activity Light
The memory card reader activity light is off when there are no media cards plugged into
the slots.
The light turns on when a media card is inserted into a slot.
The light blinks when data is being transferred between the card and the computer.
Formatting a Memory Card
If you have not used the memory card before, or if the card has become corrupted, you
may need to format the card before using it.
NOTE: Some memory cards have a lock position. To view or edit your picture files, make
sure that the memory card is in the unlocked position.
1 Format the memory card in your digital camera. Follow the instructions that came with
your digital camera.
Or
Insert the media into the correct card slot on the reader until it stops and locks into
place. The activity light on the memory card reader lights, and the computer
automatically detects the media.
2 Click the Windows Start Button
on the taskbar, and then click Computer.
3 In the Devices with Removable Storage area, right-click the correct memory card icon.
4 Select Format, and then type a label name into the label box.
5 For best compatibility, select FAT as the file system settings.
6 Click Start.
7 Click OK in the Format Complete window, and then click Close.
96
Getting Started (features vary by model)
Troubleshooting the Memory Card Reader
If you are having problems reading from or writing to a memory card, try the following:
Some cards have a read/write or security switch on the card. Make sure that the
read/write switch is set to Write Enabled before attempting to write data to the card.
Make sure that the amount of data that you want to store is not larger than the storage
limit of the memory card.
Make sure that the memory card is one of the supported types: CompactFlash
Type I and II, Microdrive, Memory Stick, Memory Stick Pro, MultiMediaCard, Secure
Digital, SmartMedia, or xD media.
Make sure that the memory card is fully inserted into the correct slot.
Remove the memory card when the activity light is not blinking, and shine a flashlight
into the empty slot. If any of the pins are bent, replace the memory card reader, or
have the computer serviced if a pin is touching another pin. To straighten slightly bent
pins, use the tip of a fine-point retracted ballpoint pen with the computer off.
Inspect the ends of the memory cards for anything that could be blocking a proper
connection. Clean the contacts with a lint-free cloth and small amounts of alcohol.
Replace the memory card, if necessary.
The memory card reader is a device that uses the Safely Remove Hardware task. This
appears as a taskbar icon next to the time. Do not click Stop in the Safely Remove
Hardware window. Doing so disconnects the drive. If this happens, restart
the computer.
Do not insert or remove memory cards when the activity light is blinking. Doing so
may cause data loss, or it may permanently damage the card reader.
Format a memory card before you use it. See “Formatting a Memory Card.”
Using the Memory Card Reader
97
98
Getting Started (features vary by model)
Using Windows Media Center
Microsoft Windows Media Center lets you do amazing things with your computer. With a
full range of easy-to-use digital entertainment features, you can experience movies, music,
and photos like never before.
Windows Media Center is simple and convenient to use. You can easily find and choose
your media. You can play movies, listen to music, and view photos with a single remote
control (select models only). Combine the powerful features of your computer with a home
theater receiver to enjoy an even more dynamic entertainment experience.
Windows Media Center is optimized for widescreen and high-definition displays. With the
new onscreen layout of your photos, music, and videos, you can now see up to three times
more content on a widescreen display than with previous versions of Windows Media
Center.
Using Windows Media Center
99
Setting Up Windows Media Center
The first time that you start Windows Media Center on the computer, a Windows Media
Center setup wizard opens. You must complete each step in the setup wizard to be able to
use all the features in Windows Media Center. The Windows Media Center setup wizard
may take several minutes to complete. If there are steps that you still need to complete, you
can go to the Settings menu to do so. See “Completing the setup wizard.”
NOTE: For more information about setting up the computer, refer to the setup instructions
that came with the computer.
Completing the setup wizard
If you did not complete the Windows Media Center setup wizard steps the first time
through, you can complete or change your selections by using the following procedure.
You need to complete all of the required setup steps to access all of the Windows Media
Center features.
1 Press the Windows Media Center Start button
mouse, click the Windows Start Button
Windows Media Center.
on the remote control, or, with the
on the taskbar, and then click
2 Scroll up or down to the Tasks menu, and then select settings. Use the arrow keys on
the keyboard or on the remote control to scroll right and left to see all of the Tasks
menu items.
3 Select General, Windows Media Center Setup, and then Run Setup Again.
Follow the onscreen instructions to complete the wizard.
The following are some of the items that are included in the setup wizard:
Check for your Internet connection. An Internet connection allows you to
access media links, display information about your music CDs and DVDs, and
download the Television Program Guide if your computer came with a TV tuner.
NOTE: You must subscribe to an Internet Service Provider to have an Internet
connection.
100
Getting Started (features vary by model)
Optimize how Windows Media Center looks on your display. You can:
Change display settings such as brightness, contrast, color, and centering.
Test and adjust the display settings of the monitor, TV, or other display.
Use the Windows Media Center video to help you change onscreen centering,
sizing, aspect ratio (shape), brightness, contrast, color, and sharpness of the
display with either the TV remote control or the monitor controls.
Set up your speakers. Select how many speakers you have, and test them.
Speakers are sold separately for some models.
Set up your Music, Picture, and Video Libraries. Set up Windows Media
Center to scan your Music, Picture, and Video folders for new media files. Windows
Media Center can then automatically add these files to your media libraries. You can
have Windows Media Center scan other folders or stop scanning a folder.
Windows Media Center Start Menu
A Open the Windows Media Center Start menu.
B Go back one screen.
C Minimize the Windows Media Center window.
D Resize the Windows Media Center window.
E
Close the Windows Media Center window.
F
Use arrow keys to scroll up and down, left and right through the submenu items.
G Use media playback controls: Play, Stop, Pause, Skip, Fast-forward, Replay, Rewind,
Record, Volume Up/Down, Mute, and Channel Up/Down.
Using Windows Media Center
101
Windows Media Center Start menu items
HD DVD Play or Play DVD — See “Playing DVD Movies in Windows Media
Center.”
Online Media — Get access to various photo, video, radio, TV, and various media
providers.
Pictures + Videos — View digital pictures, play a slide show, or print photos.
Watch home videos. See “Playing video CDs (VCDs) with Windows Media Player.”
Music — Play music files or music CDs, create and edit playlists, and record music
files to CD. See “Using Music with Windows Media Center” and “Copying Music
Files to CD in Windows Media Center.” Listen to internet radio station. See “Listening
to Online Radio Stations.”
Tasks — Change program settings. See “Changing Windows Media Center
Settings.” Add a Windows Media Center Extender device. Synchronize content from
another device with the computer. Burn CDs and DVDs. See “Copying Music Files to
CD in Windows Media Center.” Find utilities and programs.
Shutdown — Get access to the Shutdown, Restart, Sleep, Close, Log Off, and
Media Only menus. Media Only mode gives you access to Windows Media
Center, but not to the rest of the computer. See “Windows Media Center
control menu.”
NOTE: Some of the features and programs that are listed are for select models only.
Windows Media Center Features
You can control the Windows Media Center functions and navigate Windows Media
Center windows by using the remote control (select models only), keyboard, or mouse. You
can easily switch back and forth between them by either moving the mouse, or by pressing
a button on the remote control or the keyboard.
NOTE: Some of the Windows Media Center features listed are for select models only.
Some of the components listed in the computer documentation, such as speakers and TV
tuners, are optional or sold separately.
You can run Windows Media Center side-by-side with other Windows software programs.
It is possible to browse through your pictures, watch videos, and play music while using
other Windows programs.
With Windows Media Center, you can:
102
Play back your digital videos.
View your digital pictures or play them as a slide show with music.
Easily print your photos.
Browse, select, and play music CD files with full-screen visualizations.
Record CD tracks to your media library.
Getting Started (features vary by model)
Play DVD movies. Resume playing your DVDs where you left off.
NOTE: If your computer came with a rewritable DVD drive, the drive is able to read
and record to DVD+/-R/-RW media.
Listen to Internet radio stations.
Access streaming music and video subscription services. Some music and video
subscription services may not be available in all countries/regions.
Open specific windows in Windows Media Center by using the shortcut buttons on
the remote control.
Easily back up your media files to CD, DVD, or another hard disk drive, such as the
HP Personal Media Drive and HP Pocket Media Drive (sold separately).
Use the Optimization setting to keep the computer running smoothly.
Use Sleep mode to save power when the computer is not in use. Then, you can
display the computer desktop instantly by touching a keyboard key or a remote
control button.
The right music for the moment
In the Music section, you can quickly browse the entire music library by artist, song, or
album title, as well as by genre, composer, or year. Windows Media Center automatically
downloads thumbnails of album art, giving you a very visual way to find the albums that
you want to hear. You can shuffle and repeat your music, create playlists, apply
visualizations, and burn playlists to CD or DVD with the push of a button.
You can also start a picture slide show directly from your music library when you are
selecting or playing your music. If you subscribe to music services, you can now add this
option directly to the Start menu, next to the Music Library.
It is easy to search for and add music to your library from another Windows-based
computer in your home.
Playing Internet radio
Windows Media Center can also play Internet radio. You can access various Internet
radio Web sites.
Sharing your digital memories
With Windows Media Center, you can turn your simple photo collection into a cinematic
slide show that can be shared on the computer or the television in the living room. The Play
All option on the Start menu enables a full slide show of photos at the click of a button, and
you can even enjoy the slide show with music from your music collection for a truly
memorable experience.
If you want to create a slide show with a soundtrack, you can easily create a playlist of
photos and music to burn to DVD.
Using Windows Media Center
103
In the Picture Library, you can navigate easily through your photos by folder or by the date
on which they were taken, with thumbnails and highlighting that help you quickly identify
the specific images or folders that you want to see. You can also perform basic editing
functions, such as rotating or touching up pictures, either from within the Picture Library or
during a slide show.
Transforming your living space into a theater
In the Videos Library, you can easily play any of the home movies that have been imported
from your video recorder. Windows Media Center has built-in support for
high-definition video.
Whether you are watching a DVD movie or your own home videos, Windows Media
Center delivers a rich viewing experience with a high-quality digital sound system. Sit
back, and enjoy the show.
Online media
Online Media is a link to various media providers, where you can find various media
offers and services. The Online Media window is periodically updated by Microsoft. Some
of the services that are listed may not be available in certain countries/regions.
Your computer must be connected to the Internet to access the Online Media Web sites.
Navigating Windows Media Center
Opening Windows Media Center with a mouse
You can use either the remote control or the mouse to open and navigate Windows
Media Center.
To use the mouse:
1 Click the Windows Start Button
Media Center
on the taskbar, and then click Windows
.
2 Move the mouse over the Windows Media Center Start menu items, and click a
category to select it. To scroll the list of Start menu items, move the mouse pointer over
the list until an item is selected, then continue moving the pointer up or down the list to
see the items that are not displayed.
3 After you select a menu category, scroll the mouse left or right, and then click an item
to open that window.
4 Move the mouse to display the Windows Media Center menu bar, and then
click the back arrow at the top of the window to go to a previous window.
5 Click the Windows Media Center Start
icon at the top of the Windows
Media Center window to return to the Windows Media Center Start menu.
104
Getting Started (features vary by model)
Using the Windows Media Center menu bars
When you move the mouse, the Windows Media Center menu bars appear. These menu
bars allow you to access:
Media controls (play, fast-forward, rewind, stop, and others).
The back arrow.
Window-control icons (minimize, maximize, and close).
The Windows Media Center icon that takes you to the main Windows Media
Center menu.
If you use the remote control, or if you stop using the mouse (after 5 seconds), the
Windows Media Center menu bars become hidden.
NOTE: You can use the resize buttons to switch to the desktop or to run Windows Media
Center side-by-side with another program.
Selecting items in Windows Media Center
You can control the Windows Media Center functions and navigate Windows Media
Center windows by using the remote control, the keyboard, or a mouse.
In the Windows Media Center windows, a selected item such as a folder, file, or menu
item is either highlighted or moves to a zoomed-out position.
To select items in Windows Media Center, use the mouse, the arrow keys on the keyboard
or the arrow buttons on the remote control, and then press the Enter key on the keyboard
or the OK button on the remote control to enter your selection.
Using Windows Media Center
105
If you have media playing, such as music or a slide show, it appears in an inset window in
the lower-left corner. To switch from watching media in the inset window to watching it in
full-screen mode, use the arrow buttons on the remote control or the arrow keys on the
keyboard to select it, and then press the OK button on the remote control or the Enter key
on the keyboard.
Inset window
Full-screen mode
Windows Media Center control menu
To access the control menu in Windows Media Center, move the mouse to display the
menu bars:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click shutdown to open the window with the menu
items that are listed in the following table. Use the arrow keys on the remote
control or the keyboard to scroll to the right or left of the screen to select the
other options.
Icon
Action
Closes Windows Media Center.
Logs off and ends your Windows Media Center session and switches
users.
Shuts down the computer.
Restarts the computer.
106
Getting Started (features vary by model)
Icon
Action (continued)
Puts the computer in a power-reduced or Sleep mode.
Puts the computer in Media Only mode, which gives you access to
Windows Media Center, but not to the rest of the computer.
NOTE: This option is listed in the Tasks menu.
Changing Windows Media Center Settings
In the Windows Media Center settings window, you can change settings for viewing your
pictures and slide shows, and for controlling sound and the display of all of the Windows
Media Center windows.
To change your Windows Media Center settings:
1 Press the Windows Media Center Start button
mouse, click the Windows Start Button
Windows Media Center.
on the remote control, or, with the
on the taskbar, and then click
2 From the Tasks menu, select settings.
3 Select a settings category.
4 Select one of the settings listed. Then, use the arrow keys on the keyboard or the
arrow buttons on the remote control to select an option, or follow the onscreen
instructions.
5 Select Save to save your changes.
Windows Media Center Settings categories
General
Startup and Window behavior.
Visual and Sound Effects to set transition animations, sounds, and
background colors when navigating in Windows Media Center.
Program Library Options to allow programs in the Program Library to control
the media experience and access media information in Windows Media Center.
Also, you can hide Internet security warnings.
Windows Media Center Setup to configure an Internet connection and
speakers, run Windows Media Center setup again, and configure the TV display
or monitor.
Using Windows Media Center
107
Parental Controls to block unwanted TV channels and movie ratings, change
access code, and reset parental controls.
NOTE: The parental controls, captions display, radio, and TV settings listed in
Windows Media Center do not apply to computer models that do not include a
TV tuner.
Automatic Downloads Options to get media information about CDs, DVDs,
and movies from the Internet.
Optimization to keep the computer running smoothly by performing various
tasks on a regularly scheduled basis. The Optimization setting closes and then
opens Windows Media Center at a specific time each day that you determine.
TV to set up TV signal, audio, and closed captioning (not all channels support closed
captioning). You can download or edit the Television Program Guide, set hard disk
drive recorder storage space, configure the display, and set recording defaults.
Pictures to set slide show settings.
Music to select visualizations or song information to display when playing a song.
DVD to select a language for subtitles, audio tracks, and menus of your DVDs;
program the Skip and Replay buttons on the remote control for your DVDs; and select
closed captioning.
Library Setup to have Windows Media Center scan specified computer folders for
media files.
Radio to organize or delete preset radio stations.
To view information for your computer, go to the Support Web address that is listed in the
Limited Warranty and Support Guide, and search for your model’s name and number. The
product model is on the lower front of the computer.
To find the online documentation for your product, search for your model number, and then
click Manuals.
NOTE: Information and guides are associated with specific computer model numbers.
Some models do not have guides or manuals available on the Web site.
108
Getting Started (features vary by model)
Using Windows Media Center power settings
When the computer is in Sleep mode, it appears off, but you can actually still perform
tasks such as recording TV programs or music files. Sleep mode turns off the display and
mutes the audio.
NOTE: The audio or video of TV recordings is not affected when the computer is in
Sleep mode.
You can activate Sleep mode by pressing the Sleep button on the computer,
keyboard, or remote control.
You can return to the desktop almost instantly by pressing any Sleep button again,
by pressing any key on the keyboard, by moving the mouse, or by pressing any button on
the remote control.
To change the computer power settings:
1 Click the Windows Start Button
Panel.
on the taskbar, and then click Control
2 Click System and Maintenance.
3 Click Power Options.
4 Select the Balanced, Power saver, or High performance option.
5 Click Change plan settings.
6 Click the drop-down arrow next to turn off the display to select a time span to turn off
the display.
7 Click the drop-down arrow next to put the computer to sleep to select a time span for
putting the computer into Sleep mode.
8 Click Save changes.
Using Windows Media Center
109
110
Getting Started (features vary by model)
Playing CDs, DVDs, or VCDs
This section describes how to play CDs, DVDs, or VCDs by using Windows Media Center,
Windows Media Player, or other audio and video programs.
This section also describes using Music and radio, and changing DVD and audio settings.
Using Music
The Music area in Windows Media Center is a great way to play, organize, and back up
your music files. It is designed to work with the Windows Media Player program.
You can find and play your favorite music files and CDs that you have added to the music
library and the Windows Media Player music library. In addition, you can listen to various
Internet radio stations.
There are several Windows Media Center music menus from which you can choose:
Music library
Play all
Radio
Search
All these menu options are described in detail in this section.
Playing CDs, DVDs, or VCDs
111
Using Music with Windows Media Center
You can copy digital music files and organize a music library by using music library in the
Windows Media Center or by using the Windows Media Player program.
Music files that are added to music library in the Windows Media Center and in the
Windows Media Player are accessible from within Windows Media Center and the
Windows Media Player.
In Windows Media Center Music, you can:
112
Play CDs or selected music tracks from your created music library in the Windows
Media Center or the Windows Media Player.
Select and edit a personalized list of songs in the playlist from the music library.
Delete songs from a music library or a queue list.
Burn your favorite songs to CDs.
Back up your music tracks to a DVD or to an HP Personal Media Drive or other
storage device.
Listen to Internet Radio (select models only).
Search music tracks and files.
Organize your music by artist, album, song, composer, year, playlist, and genre.
Getting Started (features vary by model)
Using the music library
Adding music to the music library
When you add music files to the music library, they are placed into the music library in the
Windows Media Center and the Windows Media Player. The added music files can
immediately be found and played back using Music in Windows Media Center or the
Windows Media Player.
You can also add music files to the music library from within the Windows Media Player
program. For more information about adding and deleting music files to the library, use
the Windows Media Player Help menu.
Adding music files from the hard disk drive
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click settings.
3 Click Library Setup.
4 Click Add folder to watch, and then click Next.
Playing CDs, DVDs, or VCDs
113
5 Click Add folders on this computer, and then click Next.
6 Use the arrow buttons on the keyboard or the remote control to select a location.
When you find the folder that contains the music folder, select it by making sure an
arrow appears next to the folder. Repeat this step to add additional folders, click
Next, and then click Finish.
7 Click OK.
Adding music files from a CD
To add the CD tracks to the Windows Media Center music library:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Music.
3 Click music library.
4 Insert a CD into the CD drive.
5 Select albums.
6 Select the album CD you want to add to the music library.
7 Click Copy CD. The first time that you copy a music CD, you must select the
copy-protection option, and then follow any onscreen instructions.
8 After selecting the choices for copy options in the next few windows, click Next.
9 Click Yes to begin copying tracks to the music library. This process may take several
minutes, depending on the length of the music tracks.
10 Click OK.
114
Getting Started (features vary by model)
Deleting music files from the music library
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Music.
3 Click music library.
4 Click albums.
5 Select the album that you would like to delete, and then click Delete.
6 Click Yes when the Confirm Delete window is displayed.
Using supported music file types
You can play the following types of digital audio files in Music. Refer to Windows Media
Player Help for more information about supported file types.
Playing Music Files in Windows Media Center
To open Windows Media Center, select Music by scrolling up or down in the Windows
Media Center window, and then by clicking music library. You will find a few music
albums and tracks listed in the Windows Media Center and Windows Media Player music
library.
To play music, click one or more songs, and then click play. You can also click play all
to hear all of the tracks that are stored in Music.
NOTE: You may not find any audio files when you click playlists for the first time unless
you have already added audio files to your Windows Media Center and Windows Media
Player music libraries. When you copy music files using Windows Media Center or
Windows Media Player, the CD information is copied and displayed in Windows Media
Center and in the Windows Media Player music library.
Playing CDs, DVDs, or VCDs
115
If you insert a music CD when Windows Media Center is not open, the AutoPlay window
appears and lists various options. You can select the Audio CD options by using the
Windows Media Center or Windows Media Player. If you have another program set as
the default audio player, Windows opens the program and begins playing the CD. You
can set the AutoPlay defaults in the Control Panel.
Changing the visualization settings
You can change the visualization settings such as the alchemy, bars and waves, and
battery settings. You can also set the visualization options to start visualizations when the
music plays at the beginning of the song, always, or never.
Click the Windows Start Button
Center.
on the taskbar, and then click Windows Media
1 From the Tasks menu, click settings, and then click Music.
2 Click Visualizations or Visualization Options.
3 After making the changes, click Save.
116
Getting Started (features vary by model)
Playing an album in Windows Media Center
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Music.
3 Click music library.
4 Insert a music CD into the CD drive.
5 Click albums.
6 Select the album that you want to play.
7 Click Play Album.
Playing a song in Windows Media Center
You can play a song from anywhere in Music. You can select it from the songs list, or from
the albums, artists, genres, composers and other lists. You can also play a single song from
a playlist:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Music.
3 Click music library.
4 Click songs. The list displays all of the songs in the library.
5 Use the arrow buttons on the remote control or the arrow keys on the keyboard or
select a song by moving the mouse and clicking the song.
6 Click Play Song to play it.
Creating a Queue in Windows Media Center
A queue is a temporary list of songs that is created in Music as you select songs, albums,
or playlists to play. You can continue to add songs, or you can delete songs from
the queue.
You can create a queue and save it as a playlist that you can access in Windows Media
Center or the Windows Media Player.
1 From the Music window:
Select music library, select songs, and then use the arrow keys to select a song
you want, or move the mouse over the songs. Click the song that you would like to
add to the queue, and then click Add to Queue.
Or
Select albums or playlists, select an album or a playlist, and then select Add
to Queue to add the entire album or playlist to the queue.
Playing CDs, DVDs, or VCDs
117
2 Use the Back button on the remote control or the Backspace key on the
keyboard to go back to the songs, albums, or playlists menus if you want to
select more songs to add to the queue list. Repeat step 1. Or click the mouse on
the left arrow on the top left of the screen to go back.
3 After you add the last song for the queue list, select play all. All of the songs in the
queue list are played in the order you have selected them.
4 While the queue is being played, you can view the queue by selecting
View Queue. You can edit or clear a queue, save it as a playlist or burn a queue list
on a CD or a DVD. You can also select to shuffle the songs in the queue list.
Finding and Playing an Album in
Windows Media Center
1 From Windows Media Center, click Music, and then click music library.
2 Use the arrow buttons on the remote control, or the arrow keys on the keyboard or the
mouse, to select an album, and then press OK on the remote control. Press the Enter
key on the keyboard or click the album to select the album and see the album details.
Using album details
In the album details window, you can select from:
Play to play the album.
Add to Queue to add to a queue list.
Burn to burn the tracks on a CD or a DVD.
Edit to edit the information of the album.
Delete to delete the album.
1 Click Play Album to play the album from the album details window.
2 The now playing window opens, and the album starts playing.
118
Getting Started (features vary by model)
3 In the now playing window, you can also select:
View Queue to view an ordered list of all tracks that will be played on the
album.
Visualize to view a moving picture while listening to a song.
Play Slide Show to play a slide show while the album is playing.
Shuffle to rearrange the play order.
Repeat to play the album again.
Buy Music to connect to the Internet, find CD information, and buy music CDs.
To go back to Windows Media Center, press Start on the remote control, or click
the left arrow on the top left of the screen.
4 To return to the previous window, press the Back button on the remote control
or the Backspace key on the keyboard, or click the left arrow on the top left of
the screen to go back.
Using Search in Windows Media Center
Searching for music tracks and files
You can search for music files if you cannot locate them:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Music, and then double-click search.
3 To search, enter letters by using either the alphanumeric keypad on the remote or the
keyboard. The search begins when you enter the first letter.
Playing CDs, DVDs, or VCDs
119
Creating a Playlist in Windows Media Center
A playlist is a customized list of songs that you can keep to play later or record to a CD.
Using playlists, you can group various digital music files together and determine the order
in which you want the files to play.
You can create a playlist that includes several tracks from various CDs or even a playlist
that contains background music for a slide show.
You can create playlists in Windows Media Center or the Windows Media Player.
To create a playlist:
1 Select Music, select music library, and then select either albums, artists,
playlists, songs, or genres.
2 Use the arrow buttons on the remote control, or the arrow keys on the keyboard, or
use the mouse to navigate to and select the music that you want to add to the playlist.
3 Press OK on the remote control, or press the Enter key on the keyboard, or click the
selection to select a song.
4 Click Add to Queue to add the music to the list of music in the queue.
5 Go back to the Windows Media Center. Click the mouse on the left arrow on
the top left of the screen to go back to Windows Media Center.
120
Getting Started (features vary by model)
6 Click play all.
7 Click View Queue.
8 Click Save As Playlist, and give the playlist a name.
9 Use the alphanumeric keypad to enter a name for the playlist, and then click Save.
Copying Music Files to CD in Windows Media Center
To copy the music files to CD:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Tasks, and then click burn cd/dvd.
3 A message opens asking you to insert media. Insert a blank CD-R disc, and then click
Retry.
4 Select a disc format, either Audio CD or Data CD, and then click Next.
5 Use the arrow keys on the keyboard to select the Untitled text box.
6 Use the alphanumeric keypad buttons on the remote control or the keyboard to enter a
name for the CD, and then click Next. This will take you to the Choose Music
window.
Playing CDs, DVDs, or VCDs
121
7 Use the arrow keys to scroll through songs. You can select more songs by clicking
albums, playlists, and other music menu options. A check mark appears next to
the song when it is selected. Press the Back button on the remote control or click Add
More in the Review & Edit List to select more songs from different menus. You can also
change the name of the CD by clicking Change Name, and clear all selections by
clicking Clear All in this window.
8 Click Next when you have selected all the songs to record to CD.
9 Click Burn CD to record your music to disc.
10 Click Yes to confirm you want to burn a disc with these files.
11 Click OK to do other things while the disc is being burned.
12 Click Done when the recording is complete.
Listening to Online Radio Stations
In the radio area of Windows Media Center, you can play, listen, and preset various
online radio stations.
1 From the Windows Media Center, click Music, and then click radio twice.
2 Click presets to preset and organize your favorite radio stations.
3 By clicking sources, you can access the Music and Radio menu.
4 Click the right mouse button to view a list and to go to the settings menu.
5 Click the right mouse button for the icons to appear to go to the previous menu.
Playing Music CDs
To play music CDs, you must have either a CD or DVD drive.
122
Insert the music CD into the CD or DVD drive.
The default audio program opens. If a dialog window opens, choose the program you
want to use from the list. You may have to scroll down in the window to see all
available programs.
The music CD automatically begins to play.
Getting Started (features vary by model)
Playing CDs with Windows Media Player
NOTE: Some commercial music CDs are copy-protected and cannot be played with
Windows Media Player. Such CDs come with their own (built-in) player that must be used.
1 Insert the music CD or DVD movie into the drive.
When the AutoPlay window opens, select Windows Media Player from the
list. You may have to scroll down in the window to see Windows Media Player.
Or
If the Windows Media Player window does not automatically open, click the
Windows Start Button
on the taskbar, click All Programs, and then click
Windows Media Player.
2 To play the CD or DVD, click the Now Playing tab on the Windows Media Player
taskbar. You can also control playback by using the media control buttons on the
keyboard (select models only).
NOTE: The computer must have a connection to the Internet to see CD information such as
artist name, song titles, and album art.
For more information on using Windows Media Player, click the drop-down arrow on the
Player taskbar, and then click Help.
Playing DVDs
The computer must have a DVD drive to play DVD movies. Some computer models include
a DVD drive that can also play Blu-ray DVDs (BD) and High-Definition DVDs (HD DVD).
To play a DVD, you must have a DVD drive:
1 Insert the DVD into the DVD drive.
2 When the DVD dialog window opens, choose the program you want to use from the
list. You may have to scroll down in the window to see all available programs.
Or
If the dialog window does not appear, click the Windows Start Button
on the
taskbar, click All Programs, and then click HP DVD Play or DVD Play BD/HD,
or Power Cinema depending on the type of DVD drive and computer model that
you have.
3 Use the controls in the DVD program to play the DVD.
4 To reduce the DVD Play window, double-click anywhere in the window. To return the
display to full-size, double-click anywhere in the window again.
Playing CDs, DVDs, or VCDs
123
Using Windows Media Center to play DVDs
1 Click the Windows Start Button
on the taskbar.
2 Click Windows Media Center to open Windows Media Center.
3 Scroll to TV+ Movies, and then click HP DVD Play.
4 Use the mouse to operate the media controls to control the movie.
5 To play the DVD in full-screen mode, double-click anywhere in the DVD Play window.
Troubleshooting poor playback when
playing DVDs
If you experience poor playback, such as skipping, when playing DVDs with DVD Play or
Power Cinema, try the following solutions in the order listed:
1 If the computer includes Windows Media Center, try playing the DVD from within
Windows Media Center. Windows Media Center automatically adjusts the display for
the best screen resolution to allow optimal DVD playback.
a
Click the Windows Start Button
on the taskbar, click All Programs, and
then click Windows Media Center.
b
Scroll up to the TV + Movies menu, and then select HP DVD Play.
c
Use the DVD controls to play the movie.
2 Change the resolution of the display until the issue is resolved.
a
Click the Windows Start Button
on the taskbar, click Control Panel, and
then, under Appearance and Personalization, click Adjust screen resolution.
b
Move the Resolution slider to a slightly lower resolution, and then click Apply.
c
Click Yes.
d
Try playing the DVD again. If the playback is still poor, repeat steps a to d until a
better display resolution is found.
3 Try reducing the size of the playback window.
NOTE: Having a higher-end computer graphics (video) card and increasing computer
memory may also improve DVD playback.
124
Getting Started (features vary by model)
Using country/region codes
Most DVD discs have country/region codes embedded in the disc data that limit where the
DVD movie can be played.
The country/region number is usually placed over a world globe that is printed on the
DVD packaging and disc. DVDs without country/region codes play on any player or drive
in any country/region.
WARNING: You can change countries/regions only five times before the
country/region code locks and becomes permanent. Once the code locks, you
can play DVDs from that country/region only. If the country/region code locks
and you need help, contact Support.
Playing DVD Movies in Windows Media Center
(Select models only)
Watching DVDs in Windows Media Center allows you to control the playback with the
remote control. If you play the DVD in another program outside of Windows Media
Center, you will not be able to use the remote control.
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Insert the DVD into the drive. If you have other media playing, Windows Media
Center asks if you want to play the DVD. Select HP DVD Play. If you don’t select an
option, the DVD automatically plays in full-screen mode after a few seconds.
Or
If the DVD is already in the drive, select HP DVD Play. The DVD movie begins
playing in full-screen mode.
3 If a DVD menu appears, use the remote control or the mouse to select the DVD menu
items and control the DVD movie playback.
Playing CDs, DVDs, or VCDs
125
4 To stop playing the DVD, press Stop on the remote control or move the mouse to
display the media controls, and then click the Stop button.
5 Move the mouse for other icons to appear.
NOTE: To view additional controls, click the right mouse button. A window pops up,
displaying additional options such as: zoom, movie details, title menu, eject, and settings.
Changing the DVD Settings
You can change the DVD settings such as the DVD language, closed captioning, and
remote control options.
Click the Windows Start Button
Center.
on the taskbar, and then click Windows Media
1 From the Tasks menu, click settings.
2 In the Settings window, select DVD.
3 Click DVD Language, Closed Captioning, or Remote Control Options.
4 Select the settings, and then click Save.
Changing the DVD movie language
To select DVD language settings for subtitles, audio track and menu:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click settings, DVD, and then DVD Language.
3 Use the arrow buttons on the remote control or the arrow keys on the keyboard to
select (+) or (–). Press OK on the remote control, or press the Enter key on the
keyboard, to scroll through the languages available.
126
Getting Started (features vary by model)
4 When you find the language you want, click Save.
5 To return to the main settings window, press the Backspace key on the
keyboard or press the Back button on the remote control, or click the left arrow
on the top left of the screen.
Changing DVD closed captioning
You can change the DVD closed captioning options:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click settings.
3 In the settings window, click DVD.
4 In the DVD Settings window, click Closed Captioning.
5 After making the changes, click Save.
Playing CDs, DVDs, or VCDs
127
Changing DVD Audio Settings
To select DVD audio settings for viewing the DVD:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click settings.
3 Click TV.
4 Click Audio. The TV Audio window opens.
5 Select the speaker and sound options. Select the speaker output and the channel
mode, if applicable. Click Save.
Playing DVDs with Windows Media Player
The computer must have a DVD drive to play DVD movies.
1 Insert the DVD movie into the drive.
When the AutoPlay window opens, select Windows Media Player from the
list. You may have to scroll down in the window to see Windows Media Player.
Or
If the Windows Media Player window does not automatically open, click the
Windows Start Button
on the taskbar, click All Programs, and then click
Windows Media Player.
2 To play the DVD, click the Now Playing tab on the Player taskbar, and then click the
Play button. You can also control playback by using the media control buttons on the
keyboard (select models only).
For more information on using Windows Media Player, click the drop-down arrow on
the Player taskbar, and then click Help.
3 In the List pane, click a DVD title or chapter name. You can double-click a chapter to
begin playing the movie at that point. You can also right-click a chapter and click
Find DVD Info to find online information about the movie.
128
Getting Started (features vary by model)
Using DVD Play to Play DVDs, Videos,
High-Definition DVDs, and Blu-ray DVDs
Depending on the type of DVD drive that is included with the computer, you can play
DVDs, HD DVDs, or Blu-ray discs. The front of the drive is labeled with the type of discs
that the DVD drive can play. Some drives can play both Blu-ray and HD DVDs. This means
a better movie viewing experience, greater picture quality, and more bonus content.
Keep the following in mind when playing Blu-ray and HD DVDs:
The DVD Play BD/HD DVD player software is capable of playing standard DVD
movie discs; however, the enhanced features are available only with Blu-ray and
HD DVD discs.
HD DVD and Blu-ray movies play only through the DVD Play BD/HD DVD software.
CPU power is dedicated to support HD DVD and Blu-ray playback functions. It is
recommended that you close all other applications before and during HD DVD and
Blu-ray playback.
AACS keys are integrated into the computer for copy protection purposes. Occasional
renewal of the AACS key is required, and easily done by connecting to the Internet.
Some HD DVD and Blu-ray advanced features may not be supported.
As HD DVD and Blu-ray are new formats containing new technologies, certain disc,
digital connection, compatibility, and/or performance issues may arise, and do not
constitute defects in the product. Flawless playback on all systems is not guaranteed.
For some HD-DVD and Blu-ray titles to play, they may require a DVI or HDMI digital
connection, and the display may require HDCP support.
Playing CDs, DVDs, or VCDs
129
To play a DVD, you must have a DVD drive:
1 Insert the DVD into the DVD drive.
The default DVD program opens. If the DVD wizard window opens,
choose the program that you want to use from the list. You may have to
scroll down the window to see all available programs.
2 Use the controls in the DVD program to play the DVD.
NOTE: To use the DVD Play controls, you must use the mouse.
NOTE: The Advanced Access Content System (AACS) key that DVD Play uses must be
updated every seventeen months in order for it to play DVD titles. For more information
about playing video clips, click the ? (Help) button in the DVD Play control bar.
130
Getting Started (features vary by model)
Playing Video CDs (VCDs)
To play a VCD you must have either a CD or DVD drive:
1 Insert the VCD into the CD or DVD drive.
The default video CD program opens. If the Video CD wizard window opens, choose
the program you want to use from the list. You may have to scroll down in the window
to see all available programs.
2 Use the controls in the VCD program to play the VCD.
Playing video CDs (VCDs) with
Windows Media Player
To play VCDs with Windows Media Player you must have either a CD or DVD drive:
1 Insert the (VCD) into the DVD or CD drive.
2 Select Play using Windows Media Player, and then click OK.
Or
If the program doesn’t open, click the Windows Start Button
Programs, and then click Windows Media Player.
, click All
3 To play the VCD, click the Now Playing tab on the Player taskbar, and then click
Play VCD. You can also control playback by using the media control buttons on the
keyboard (select models only).
For more information on using Windows Media Player, click the drop-down arrow on
the Windows Media Player taskbar and then click Help.
4 In the List pane, double-click a VCD chapter to start playing the VCD at that point.
Playing CDs, DVDs, or VCDs
131
132
Getting Started (features vary by model)
Creating Audio and Data Discs
This chapter contains the procedures that you must perform to record (or burn) files to
recordable CD and DVD discs. It also includes information about labeling the discs by
using the LightScribe labeling technology that is available on select models or by creating
a paper label.
The computer includes one or more CD, DVD, or combination optical drives that are
capable of recording. Additionally, the computer may include the following software
programs for recording to CDs or DVDs:
CyberLink Power2Go (select models only)
CyberLink PowerProducer (select models only)
CyberLink LabelPrint (select models only)
Windows Vista
Windows Media Center
These programs include features that enable you to copy, archive, and manage music,
video, image, and data files, and then record the files to CDs or DVDs. You can also use
Windows Media Player to download and copy music files to a portable device or
memory card.
IMPORTANT: HP supports the lawful use of technology and does not endorse
or encourage the use of our products for purposes other than those permitted by
copyright law.
NOTE: Burn is an industry term used to describe the recording of information onto a DVD
or CD. Optical recording uses a laser beam to place information onto the disc, thus the
term burning.
Creating Audio and Data Discs
133
Erasing Rewritable Discs Before Recording
Previously recorded files on rewritable discs (CD-RW, DVD-RW, or DVD+RW) must be
erased before recording new files. CD-R, DVD-R, and DVD+R discs cannot be erased.
To erase a rewritable disc in CyberLink Power2Go:
1 Click the Windows Start Button
on the taskbar, All Programs, CyberLink
Power2Go, and then click Power2Go.
2 Click Tools, and then click Erase Disc.
3 Insert the rewritable disc that you want to erase.
4 Click the Quick erase or Full erase option, and then click the Erase button.
5 Click OK when the disc has been erased.
Working with Audio CDs
You can create audio CDs that play in the car or home CD player, and on computers. You
can create two main types of music CDs:
Uncompressed — Typical CD format, like you would purchase on a commercial
CD. This type of CD holds 10 to 20 songs, depending on their length.
Uncompressed files can be burned on CD-Rs (which play in most home and
car stereos, DVD players, and computers) or CD-RWs (which play only in some
stereos, DVD players, and computers).
The procedure for creating this type of CD is described in “Creating audio CDs.”
Compressed — Files are burned to a disc using a compressed file format
(.mp3, wma, or .m4a). The smaller file format enables you to fit approximately ten
times as many songs onto the disc (depending on length and format).
Compressed files can be burned to CD-Rs, CD-RWs, DVDs, DVD-RWs, or DVD+RWs
(select models only). Compressed files can only be played on computers, CD players,
or DVD players that support the file format that you use to create the disc (.mp3 is most
commonly supported). For file format compatibility, check the documentation for the
device in which you intend to play the disc. You may hear a slight loss of sound
quality using compressed audio files.
For more compatibility information, see “Disc Features and Compatibility Table.”
134
Getting Started (features vary by model)
CyberLink Power2Go allows you to create closed-session or multisession CDs and DVDs.
For closed-session CDs and DVDs, you must record or copy all files on one disc in one
recording session. For multisession CDs and DVDs, you can record or copy files in several
sessions until the disc is filled or until you close the session.
NOTE: Music files can be recorded repeatedly on a rewritable CD-RW disc, but all
previously recorded files must be erased first. CD-R discs cannot be erased.
IMPORTANT: HP supports the lawful use of technology and does not endorse
or encourage the use of our products for purposes other than those permitted by
copyright law.
Audio CD tips
When recording music files, it is important to note that:
As you add music files in the recording session, the software calculates and displays
the amount of recording time that is available to record additional music files. If you
try to record more than a standard CD can hold, a message opens warning you that
all the tracks may not fit on the disc.
If the recording fails, manually select a slower recording speed, if available, each time
you make a recording. Refer to the Help menu in the selected software program
for more information about selecting a slower recording speed.
If you change the write speed of the recording, run a Write Simulation test to verify
that the burner can burn to the disc at the selected speed without causing recording
errors.
You can select the “Enable buffer underrun protection” option when burning a disc to
ensure that data is written to disc without interruption. An interruption in data can
result in an unusable disc.
You can select the “Verify recorded data” option to compare recorded data to the
source data to ensure accurate burning.
IMPORTANT: HP supports the lawful use of technology and does not endorse
or encourage the use of our products for purposes other than those permitted by
copyright law.
Before you begin creating discs
Save all work, and close all open programs.
Turn off the screen saver.
Creating Audio and Data Discs
135
Creating audio CDs
This section provides instructions for burning an audio CD that can be played in most
home and car CD players.
To create an audio CD:
1 Insert a writable CD into the disc-burning drive.
CD-R discs play in most home and car stereos, DVD players, and computers. CD-RW
discs play only in some stereos, DVD players, and computers.
2 Click the Windows Start Button
and then click Power2Go.
, All Programs, CyberLink Power2Go,
3 Select the Music Disc icon.
4 Select the disc type, CD or DVD, select the content type, and then click OK.
5 Locate the music files that you want to add, and then click them and drag them to the
bottom half of the Power2Go window.
6 When you are done adding files, click the Burn icon in the toolbar.
NOTE: For more help using CyberLink Power2Go, click the Help icon in the
program.
7 Select the recording options. See “Audio CD tips.”
8 Click Burn to begin recording your music files to disc.
9 Click OK when the audio CD is completed.
Creating video discs
This section provides instructions for creating a video disc. You can create a video disc
from files on the computer hard disk drive or directly from a digital video camera.
1 Insert a writable disc into the disc-burning drive.
2 Open the CyberLink PowerProducer program by clicking the Windows Start
Button
, All Programs, CyberLink PowerProducer, and then clicking
PowerProducer.
3 Click the Produce Movie Disc icon.
4 Select the disc type, DVD or HD DVD. Use the drop-down arrows to select
recording format, disc capacity, and playback aspect ratio settings. Click
the arrow button when you are done.
5 Under Import, click Video files. Locate the video files, and then click Open.
Or
Under Capture, click Video to add a video file from the computer hard disk drive or
from a digital video camera.
136
Getting Started (features vary by model)
6 If desired, use the tools that are available in the Edit area to make changes to the
video.
7 Click the check button when you are done, and then click the arrow button
to proceed to the Final Output window.
8 Select the burn options, and then click the Burn Disc icon.
9 When ready to create the video disc, click Burn.
NOTE: For more help using CyberLink PowerProducer, click the Help icon.
Copying a disc
The following section explains how to make a copy of an existing CD or DVD.
Copying a disc using two disc drives
If you have two disc drives, you can copy a CD or DVD directly from one drive to the
other. To copy a DVD by using this method, you must have two DVD drives. Otherwise, use
the steps in the next section to copy the DVD.
To copy a CD or DVD using two disc drives:
1 Insert a writable CD or DVD into a disc-burning drive.
2 Insert the disc that you want to copy into the other disc drive.
3 Click the Windows Start Button
and then click Power2Go.
, All Programs, CyberLink Power2Go,
4 Click the Copy Disc icon, and then click OK.
5 Ensure that the correct disc drives are selected.
6 Click the Copy button.
NOTE: For more help using CyberLink Power2Go, click the Help icon in the
program.
Copying a disc using one disc drive
If you have only one disc drive, CyberLink Power2Go stores an image file of the disc
temporarily on the computer hard disk drive.
Use these steps to copy a CD or DVD using one disc drive:
1 Insert the disc that you want to copy into the disc-burning drive.
NOTE: If a CD-playing program opens automatically, close it before going to step 2.
2 Click the Windows Start Button
and then click Power2Go.
, All Programs, CyberLink Power2Go,
Creating Audio and Data Discs
137
3 Click the Copy Disc icon, and then click OK.
4 Select the burn options, and then click the Copy button.
Power2Go creates an image file of the disc. This file is temporarily stored on the
computer hard disk drive.
5 When you are prompted, insert a writable CD or DVD into the disc-burning drive, and
then click OK.
6 When the message Copy Disc: Completed successfully appears, click OK. The disc is
ejected automatically.
Creating data discs
This section provides instructions for burning data files onto a disc.
To create a data disc:
1 Insert a writable disc into the disc-burning drive.
2 Click the Windows Start Button
and then click Power2Go.
, All Programs, CyberLink Power2Go,
3 Click the Data Disc icon.
4 Select disc type, and then click OK.
5 Locate files from the hard disk drive, and then click and drag them to the lower section
of the window.
6 When you are done adding files, click the Burn icon in the toolbar.
NOTE: For more help using CyberLink Power2Go, click the Help icon in the
program.
7 Select the recording options.
8 Click Burn to begin recording your music files to disc.
9 Click OK when the data disc is completed.
138
Getting Started (features vary by model)
Making a disc label using LightScribe Technology
(Select models only)
The following section provides instructions for making a disc label by using LightScribe
technology. For instructions on making a paper label, refer to “Making a paper disc
label.”
What is LightScribe?
LightScribe is an innovative technology that uses a special disc drive, special media
(CDs or DVDs), and label-making software to burn labels directly onto CDs and DVDs. A
LightScribe-enabled CD or DVD disc drive uses the optical laser in the drive to burn a label
onto a thin dye coating on the label side of the disc. There is no ink to smear or paper to
curl, and there are no adhesives to loosen.
LightScribe requirements
Burning a label with LightScribe requires three things:
A LightScribe-enabled disc drive (select models only), identified by the
LightScribe logo
Labeling software that supports LightScribe
A writable LightScribe disc (sold separately)
Making a LightScribe label by using CyberLink LabelPrint
You may burn data, music, and videos to the disc before or after labeling the disc. See
“Creating audio CDs” and “Creating data discs.”
To make a LightScribe label:
1 Place the disc into the disc drive with the top of the disc facing down. The top is the
gold non-reflective side of the disc, opposite of the side that you record data onto.
2 Close the drive.
3 Open CyberLink LabelPrint by clicking the Windows Start Button
Programs, CyberLink LabelPrint, and then clicking LabelPrint.
, All
4 Under Step 1: Select the type of label you want to print, select one of
following:
Disc Label (LightScribe label)
Or
MiniDisc Label (LightScribe label)
5 Click the arrow button at the bottom of the window to continue.
Creating Audio and Data Discs
139
6 Under Step 2: Edit titles and other information, design the disc label:
a
Type in a disc title, author, and date.
b
Type in song titles, artist/author and time/size of the files.
c
You can click the Import icon to import MP3 information, if desired.
7 Click the arrow button at the bottom of the window to continue.
8 Under Step 3: Select the label’s layout and background:
a
Select a layout style by clicking the arrows under Layout Style to scroll
through the different label layouts available, and then click the Select button
when you find the one that you want.
b
Select a background image by clicking the arrows under Background Image to
scroll through the different background images that are available, and then click
the Select button when you find the one that you want.
c
If you are creating a paper label, select a paper size under Paper Template by
using the drop-down arrow.
9 Click the arrow button at the bottom of the window to continue.
10 When you are ready to create the LightScribe label, click the Print icon.
11 Click OK to create the LightScribe label. The estimated time to complete
the label displays, along with a progress bar. It is possible to continue to
work on the computer while the LightScribe label is created.
For more help using CyberLink LabelPrint, click the Help icon to open the Help
information.
Making a paper disc label
The following section provides instructions for creating a paper label for the disc. To create
a LightScribe label, refer to “Making a disc label using LightScribe Technology.”
1 Load the printer with adhesive label paper. You can purchase label paper at most
office-supply stores.
2 Open CyberLink LabelPrint by clicking the Windows Start Button
Programs, CyberLink LabelPrint, and then clicking LabelPrint.
, All
3 Under Step 1: Select the type of label you want to print, select one of
following:
Front Cover (paper insert label)
Back of Front Cover (paper insert label)
Disc Inlay (paper insert label)
4 Click the arrow button at the bottom of the window to continue.
140
Getting Started (features vary by model)
5 Under Step 2: Edit titles and other information, design the disc label:
a
Type in a disc title, author, and date.
b
Type in song titles, artist/author, and time/size of the files.
c
Click the Import icon to import MP3 information.
6 Click the arrow button at the bottom of the window to continue.
7 Under Step 3: Select the label’s layout and background:
a
Select a layout style by clicking the arrows under Layout Style to scroll through the
different label layouts available, and then click the Select button when you find
the one that you want.
b
Select a background image by clicking the arrows under Background Image to
scroll through the different background images that are available, and then click
the Select button when you find the one that you want.
c
If you are creating a paper label, select a paper size under Paper Template by
using the drop-down arrow.
8 Click the arrow button at the bottom of the window to continue.
9 When you are ready to create the LightScribe label, click the Print icon.
For more help using CyberLink LabelPrint, click the Help icon to open the
Help information.
Creating Audio and Data Discs
141
142
Getting Started (features vary by model)
Working with Pictures and Videos
You can view, copy, edit, print, and share digital images and videos by using the
computer.
You can transfer digital images and videos to the computer by using the following
methods:
CD or DVD: Insert the disc into the CD or DVD drive.
Digital camera or digital video camera: Connect the device to the computer by using
the transfer cable that came with the device. (Select models have a digital camera
docking bay.)
Memory card: Insert the memory card into the memory card reader (select
models only).
Digital images that you copy or transfer to the computer may appear in the Pictures folder
by default.
Working with Digital Images
You can connect a digital image source, such as a digital photo or video camera, directly
to the computer or through a docking station. Most digital picture files that you copy or
download from the device appear in the Pictures folder.
NOTE: When transferring pictures from a digital photo camera to the computer, set the
camera’s USB setting to disk drive instead of digital camera.
Windows Vista detects the external device and opens a message, asking if you want to
view the images.
You can copy digital picture files from the memory cards that are used by digital cameras
and other digital imaging devices by using the memory card reader (select models only).
Working with Pictures and Videos
143
Viewing Pictures in Windows Media Center
With Windows Media Center, you can view, sort, edit, print, and create a CD or DVD of
the pictures from the folders that you create in the Pictures directory in Windows Explorer.
Pictures is a folder on the hard disk drive in the Documents window, and it is also a
Windows Media Center menu item that enables you to view and search for the digital
images by using the remote control or the keyboard and mouse.
The Pictures + Videos menu in Windows Media Center provides all the tools that you need
for viewing, organizing, editing, printing, sharing, and protecting the digital images.
.
Adding Pictures in Windows Media Center
Adding picture files from the hard disk drive
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos.
3 Click picture library.
4 Press Ctrl+D on the keyboard or the i (More information) button on the remote
control, and then click Library Setup.
5 Click Add folder to watch, and then click Next.
6 Click Add folders on this computer, and then click Next.
7 Place a check mark next to the folders that you want Windows Media Center to check,
and then click Next.
8 Click Finish.
144
Getting Started (features vary by model)
Viewing Pictures in Windows Media Center
After you organize your pictures in the Pictures folder in Windows Explorer, open
Windows Media Center to view them:
1 Click the Windows Start Button
Windows Media Center.
on the taskbar, and then click
2 Click Pictures + Videos and then click picture library.
3 Select a folder, tags, or date taken. The window shows a small picture image
(thumbnail) of each photo.
Select date taken to view each photo with the date it was taken.
Select folders if you have organized your pictures into folders. Each folder icon
displays a thumbnail of photos. The pictures are displayed just as you organized
them in the Pictures folder in Windows Explorer.
4 Use the arrow keys on the keyboard to move through the picture files and folder files,
and select a picture.
5 Press the Enter key on the keyboard to select a picture or folder to view. The selected
picture opens in full-screen mode.
6 Press the Enter key on the keyboard again to zoom to 150 percent; press it again to
zoom to 225 percent. Use the remote control arrow buttons to pan across a picture.
Press Enter or OK a third time to return the picture to its original size.
NOTE: While viewing a picture, you can press the i (More information) button on the
remote control or Ctrl+D on the keyboard, click Picture Details, click Settings, and
then click Pictures to:
Select a slide transition, a slide time delay, and a background color.
Include picture folders you have created.
Show captions.
Display pictures randomly.
Show song information during a slide show.
Viewing pictures as a slide show
1 Click the Windows Start Button
Windows Media Center.
on the taskbar, and then click
2 Click Pictures + Videos, and then click picture library.
3 Select the folder of pictures that you want to view as a slide show, and then press
Enter on the keyboard.
4 Click play slide show, and then press Enter on the keyboard.
Working with Pictures and Videos
145
5 Press Ctrl+D on the keyboard or the i (More information) button on the remote
control, and then click Picture Details. The picture name, location, and last
modification date are displayed, if they are available.
6 Press the Backspace key on the keyboard or the Back button on the remote control to
go to a previous screen.
7 Use the arrow keys on the keyboard or the arrow buttons on the remote control to
display the next or previous pictures.
If you do not select the pictures that you want to view as a slide show, Windows Media
Center uses the first folder that is listed. If you have picture files that are not stored in
folders that you created, Windows Media Center plays all of the files that are stored in the
Pictures folder.
Viewing a slide show with music
1 Click the Windows Start Button
Windows Media Center.
on the taskbar, and then click
2 Click Music, and then click music library.
3 Select the music that you want, and then press Enter on the keyboard.
NOTE: If the music does not start automatically, move the mouse to display the media
control menu bar, and then click the Play button, or press the Play button on the
remote control.
4 Press the Backspace key on the keyboard until you are back at the Windows Media
Center Start menu.
5 Click Pictures + Videos, and then click picture library.
6 Select the folder of pictures that you want to view as a slide show, and then press
Enter on the keyboard.
7 Click play slide show, and then press the Enter key on the keyboard. When
Windows Media Center switches to full-screen mode, the inset window disappears,
but the music continues to play.
146
Getting Started (features vary by model)
Using supported picture file types in Windows
Media Center
You can view the following types of image files in Windows Media Center.
File extension
File type
.jpg, .jpeg
Joint Photographic Experts Group
.tif, .tiff
Tagged Image File Format
.gif
Graphics Interchange Format
.bmp
Bitmap
.wmf
Windows MetaFile
.png
Portable Network Graphics
Only supported image file types display in the Pictures + Videos area of Windows
Media Center. Unsupported files are skipped in a slide show.
NOTE: If the message Image cannot be displayed appears, the file may be corrupted,
or it may be an unsupported file type. You may need to edit the image with a photo
editor and save it in a supported file format.
Folder icons appear even if the images inside them cannot be displayed.
Corrupted and unsupported image file types display a generic image icon, but they
cannot be displayed.
Some file types are supported only if appropriate filters and software are installed.
Editing Pictures in Windows Media Center
Fixing red eye or contrast
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos, and then click picture library.
3 Select a picture to edit.
4 Press the i (More information) button on the remote control or Ctrl+D on the
keyboard, and then select Picture Details.
Working with Pictures and Videos
147
5 Click Touch Up.
6 Click Contrast or Red Eye.
7 Click Preview to see the result.
8 After you select the options that you want to fix, click Save. The picture displays with
the new settings.
9 Click Yes to save changes and replace the original picture file.
Cropping pictures in Windows Media Center
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos, and then click picture library.
3 Select a picture to edit.
4 Press the i (More information) button on the remote control or Ctrl+D on the
keyboard, and then select Picture Details.
5 Click Touch Up.
6 Click Crop.
148
Getting Started (features vary by model)
7 Use the mouse and keyboard to do one or more of the following:
Select the arrows under the picture to move the picture side to side, or up
or down.
Select the magnifying glass tools to move the cropping tool in or out.
Select the rotate tool to move the cropping tool to a vertical or horizontal position.
8 After you select the settings that you want to fix, click Save. Once you save the
picture, you cannot revert to the original picture.
9 Click Yes to save changes and replace the original picture file.
Rotating pictures
If the picture appears horizontally or vertically, and you want to change the orientation,
you can change it in Windows Media Center:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos.
3 Select the picture you want to rotate.
4 Press the i (More information) button on the remote control or Ctrl+D on the keyboard,
and then select Picture Details.
5 Click Rotate. Rotation occurs clockwise in 90° increments.
Printing Pictures in Windows Media Center
NOTE: You must set up the printer before you try to print from Windows Media Center;
otherwise, by default, the file is saved to the Documents folder when you try to print the
picture.
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos, and then click picture library.
3 Select the picture that you want to print.
4 Press Ctrl+D on the keyboard or the i (More information) button on the remote
control, and then click Picture Details. Click Print, and then click Print again.
5 Follow any onscreen instructions.
Working with Pictures and Videos
149
Copying Pictures to CDs and DVDs in
Windows Media Center
NOTE: In Windows Media Center, all pictures are copied to CDs as .jpg files.
1 Click the Windows Start Button
Media Center.
on the taskbar and then click Windows
2 From the Tasks menu, click burn cd/dvd.
3 Insert writable media (CD-R, CD-RW, DVD+/-R, or DVD+/-RW) into the drive.
4 Click Data CD/DVD, and then click Next.
NOTE: If you are using a writable disc that contains data, you must select Erase
Disc to continue.
5 Select the Untitled area, enter the name of the disc by using the numeric keys on the
keyboard or the remote control, and then select Next. Use the Backspace key on the
keyboard or the Clear button on the remote control to delete letters.
6 Click Picture Library, and then click Next.
7 Select the pictures that you want to copy, and then click Next. A check mark appears
next to a picture when you select it.
8 Click Add More to add more pictures to the disc.
9 After you have selected all of your pictures, select Burn CD.
10 Click Yes. Windows Media Center opens a message if you need to insert an
additional disc to complete the recording. Windows Media Center opens a message
when the disc has been created.
11 Click Done when the disc has been created.
Playing Videos in Windows Media Center
The Pictures + Videos area in Windows Media Center makes it easy to play home video
files that you created or video files that you downloaded from the Internet.
In Pictures + Videos you can:
150
Play videos that are stored anywhere on the hard disk drive.
Create a CD or DVD of your video files.
View your videos in full-screen mode or from an inset window in Windows Media
Center.
View small thumbnail images and the titles of your video files.
Getting Started (features vary by model)
Playing digital videos
After you organize the videos in the Videos folder or Shared Video folder in Windows
Explorer, open Windows Media Center to watch them:
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 Click Pictures + Videos.
3 Click video library.
4 Select the video folder that you want. The video folder opens, displaying a list of
video files. You may need to use the scroll arrows at the bottom of the window to
display all videos.
NOTE: Use the mouse to select the up arrows and down arrows at the bottom of the
window, to scroll to other pages of video files and folders.
5 Click the video file. The video plays in full-screen mode. Use the mouse to resize the
window if you want to watch the video while doing something else on the desktop.
6 To exit full-screen mode and return to the previous window, press the Back button on
the remote control or the Backspace key on the keyboard. The video continues to play
in the inset window.
7 When the video is finished, click Restart to replay the video, or click Done to close
the file and return to the Videos area.
NOTE: You can maximize the media that is playing in the inset window by using the
arrow buttons to select the inset window and then pressing OK on the remote control or
Enter on the keyboard, or you can just click the inset window.
Using supported video file types
You can view the following types of video files in Windows Media Center. Other file types
are supported if the computer has the correct software installed:
File extension
File type
.avi
Windows Video file (Audio Video Interleaved)
.dvr-ms
Digital Video Recording—Microsoft (TV file format)
.mpeg, .mpg, .mpe,
.m1v, .mp2, .mpv2
Movie file
.wm, .asf
Windows Media file
.wmv
Windows Media Video file
NOTE: For more information about supported video file types, refer to Help and Support.
Click the Windows Start Button
on the taskbar, and then click Help and
Support.
Working with Pictures and Videos
151
Transferring and Recording Video Files
Once you capture the video by using video capture and editing software, you can use
Windows Media Center to find it and add it to the Videos area.
Recording analog and digital video files
Refer to Help and Support for more information about capturing and recording video files
from analog and digital video cameras.
To find information in Help and Support:
1 Click the Windows Start Button
Support.
on the taskbar, and then click Help and
2 Type in search words such as recording video.
Creating a DVD from Video Files in
Windows Media Center
1 Click the Windows Start Button
Media Center.
on the taskbar, and then click Windows
2 From the Tasks menu, click burn cd/dvd.
3 Insert writable media (CD-R, CD-RW, DVD+/-R, or DVD+/-RW) into the drive.
4 Select Video DVD, and then click Next.
NOTE: If you are using a rewritable disc that contains data, you must select Erase
Disc to continue.
5 Select the Untitled area, enter the name of the disc by using the numeric keys on the
keyboard or the remote control, and then click Next. Use the Backspace key on the
keyboard or the Clear button on the remote control to delete letters.
6 Click Video Library, and then click Next.
7 Select the files you want to copy, and then click Next. A check mark appears next to
a file when you select it.
8 Click Add More to add more files to the disc.
9 After you have selected all of the files, click Burn DVD.
10 Click Yes. Windows Media Center opens a message if you need to insert an
additional disc to complete the recording. Windows Media Center opens a message
when the disc has been created.
11 Click Done when the disc has been created.
152
Getting Started (features vary by model)
Index
A
adding
CD tracks to the music library 114
music files to the music library
from the hard disk drive 113
adjusting monitor 8, 9
antivirus, installing program 45
audio connector
retasking (multistreaming) 63
autoscroll 52
B
Blu-ray
compatibility 89
DVD 92
using a Blu-ray drive 87, 90, 92
burning
audio and data disc 134–138
buttons
media control or playback 50
Off, See turning off computer 35
C
cable modem, using 9, 38, 73
card reader, memory 93
carpal tunnel syndrome 39
CDs
erasing rewritable 134
playing 118
change the speed of the cursor 53
CompactFlash media 95
troubleshooting memory card reader 97
computer
front-panel connectors 3
Help & Tools 32
setting up 1
transferring files 46
turning off 35
connecting
devices 8
digital camera 6
digital video camera 6
headphones 28
peripherals 3
connection
wired network 10
connector
computer 3
monitor 3
country/region codes 125
Creative Sound Blaster X-Fi Sound Card
audio modes 58
configuring 57
cursor speed 53
CyberLink LabelPrint
creating a LightScribe label 139
features 79
CyberLink Power2Go
burning a music CD 136
copying a disc 137
erasing discs 134
features 79
CyberLink PowerProducer
creating video disc 136
features 79
Index
153
D
H
desktop
switching from Windows Media Center 105
devices
connecting 8
digital camera
connecting 6, 8
digital images 143
digital picture 93, 143
digital video camera
connecting to a computer 6
recording videos 136
troubleshooting 7
discs
drive compatibility 89
erasing rewritable 134
features and compatibility 90
DVD movies
changing
audio settings 128
language 126
playing
in Windows Media Center 125
DVD Play, features 79
DVDs
erasing rewritable 134
High-Definition 91
playing Blu-ray DVDs 123
playing HD DVDs 123
DVI connector, using with SLI technology 5
E
erasing rewritable discs 134
error messages
Image cannot be displayed 147
errors
reducing recording speed 135
Ethernet connection 10
F
file type
picture 147
video 151
Found New Hardware message, connecting a digital
camera 6
154
Getting Started (features vary by model)
headphones
using 28
Help and Support 32
High-Definition 92
disc drives 90
home videos 136
I
Internet security 43
K
keyboard
types of buttons 47
using 47
L
LAN (local area network) 9
setting up 10
using Local Area Network 4, 9
LightScribe, creating a LightScribe disc label 139
local area network (LAN) 9
M
manuals
storing 8
memory card reader 143
card types 93
in-use light 96
troubleshooting 97
using 93
memory card, formatting 96
Memory Stick (MS) 95
Memory Stick (MS-Duo) 95
Memory Stick (MS-Pro Duo) 95
Memory Stick (MS-Pro) 95
Microdrive disk drive 95
microphone connector 4
Mini Secure Digital (MiniSD) 95
mini-jack 11
monitor
adjusting 8, 9
monitor connector 3
mouse
autoscroll 52
cursor speed 53
panning 52
switching button functions 53
MultiMediaCard (MMC) 95
MultiMediaCard Plus (MMC +) 95
Music 111
deleting music from the Music library 115
finding and playing an album 118
playing a song 117
supported file types 115
music
playing with Windows Media Player 123, 128
music library
adding CD tracks 114
creating 113
Mute button 50
N
Network Interface Card (NIC) 10
O
Off button, See turning off computer 35
optical drive quick reference 91
Optimization setting 103, 108
P
panning with the mouse 52
peripherals 3
pictures 143
copying pictures to CD 150
editing 147
printing 147
rotating 149
turning captions on or off 145
types of files it can display 147
viewing 145
viewing a slide show with music 146
viewing pictures as a slide show 145
playing
digital music files 115
digital videos 151
DVDs in Windows Media Center 125
music CDs 122
music CDs in Windows Media Center 115
songs 119
playlist
creating in Music 120
PowerProducer, features 79
printer
connecting 8
R
recording
videos from digital video camera 136
with Realtek HD Audio Manager 63
reduced size MultiMediaCard (RSMMC) 95
repetitive strain injury (RSI), see Safety & Comfort Guide
rewritable discs, erasing 134
S
Safety & Comfort Guide 39
safety warnings 39
Scalable Link Interface (SLI), using 5
scanner, connecting 8
scrolling with the mouse 52
Secure Digital (SD) memory card 95
setting up computer 1
settings
for sound 107
general 107
Internet connections 107
Shared Video folder 150
shutting down computer 35
SLI technology, using 5
slide show
displaying information about pictures 146
viewing pictures 145
viewing with music 146
software programs
CyberLink LabelPrint 79, 139
CyberLink Power2Go 79, 134
CyberLink PowerProducer 79, 136
DVD Play 79
Windows Movie Maker 79
speaker systems 15
speakers
connecting multichannel audio speakers to
the computer 11, 13–27
multichannel audio
connecting 60
resolving sound issues 68
Start menu
Windows Media Center 104
surge protector 2
switching mouse button functions 53
T
transferring information to your new computer 46
turning off computer 35
Index
155
U
W
update, Windows Vista 43
updating, system 43
user accounts
creating 40
V
VCD
playing with Windows Media Player 131
video movies
transferring and recording 152
videos 150
creating a DVD 152
playing 150
playing digital videos 151
transferring videos 152
working with home videos 6
visualization settings 116
volume
controls 50
Windows Media Center
menu bars 105
navigating 105
playing DVDs 125
playing videos 150
resizing window 105
using with another program open 105
viewing your pictures 145
what you can do in Music 111
Windows Media Player
playing DVDs 128
playing music CDs 123
playing video CDs 131
setting as default player 115
types of files 115
Windows Movie Maker, features 79
Windows Vista update 43
wired network connection 10
working in comfort 39
Y
Y adapter cables 21
Part number: 5992-3585
156
Getting Started (features vary by model)
