Samsung IPOLIS SNP-3300 User's Manual

Real-time Network
Dynamic 30X
Pan & Tilt
30X PTZ Network Camera SNP-3300 User’s Manual
5IBOLZPVGPSQVSDIBTJOHB4".46/(J10-J4/FUXPSL$BNFSB
#FGPSFBUUFNQUJOHUPDPOOFDUPSPQFSBUFUIJTQSPEVDU
QMFBTFSFBEUIFTFJOTUSVDUJPOTDBSFGVMMZBOETBWFUIJTNBOVBMGPSGVUVSFVTF
ENGLISH
Preface
A brand that is integrated into Samsung's network products,
stands for a convenient world (Polis) made safe
(Police) through Samsung's superior network performance(Internet
protocol).
With
products'
clear
digital
images
transmitted over the internet, real-time monitoring is possible
anywhere with an internet connection. Easy remote control
functions and the use of existing networks minimize installation
costs. With
, experience a world of convenience
connected anytime, anywhere.
Preface
Thanks for purchasing of 30X PTZ Network Camera SNP-3300.
This is a user instruction manual for a 30X PTZ Network Camera
SNP-3300 that employs Samsung Techwin’s SVⅢ DSP system
with superior low light capability.
The user who installs and operates the product shall be aware of this
manual and other manuals referenced by this manual before the
installation and operation and use properly.
This manual and the software and hardware explained here are
protected by copyright law.
So the copy, reprint and translation to other languages of a part of or
all
contents
of
this
user
manual
without
permission
of
SamsungTechwin Co., LTD are not allowed except for the copy for
general use within the scope of copyright law.
i
Contents
Contents
Preface .............................................................................. i
Contents ...........................................................................1
Note to User .....................................................................5
Product Warranty and Limitations ....................................7
Warning Symbols .............................................................8
Danger..............................................................................8
Caution ...........................................................................10
Ch1. Overview .......................................................................12
1.1. 30X PTZ Network Camera SNP-3300 Introduction.........13
1.2. Features ..................................................................13
Ch2. Section names and functions .....................................16
2.1. Body ........................................................................17
2.2. Camera Holder ........................................................18
2.3. Camera Holder connection......................................19
Ch3. Installation and Network Setup...................................21
3.1. Connecting to Monitor (For installation) ..................22
3.2. Connecting to Power ...............................................24
3.3. Installation of SNP-3300..........................................25
3.4. Network configuration and connection method using Web page 33
Ch4. How to Use Web Viewer...............................................39
4.1. How to Use Web Viewer..........................................40
1
30X PTZ Network Camera SNP-3300
4.1.1. Login ...................................................................... 40
4.1.2. Web Viewer screen ................................................ 41
4.2. Using Administration page.......................................47
4.2.1. Initialization Screen after Connecting ..................... 47
4.2.2. Live ........................................................................ 48
4.2.3. Basic ...................................................................... 49
4.2.4. Network.................................................................. 51
4.2.5. User ....................................................................... 52
4.2.6. Pan/Tilt/Zoom......................................................... 55
4.2.7. Motion Detection .................................................... 57
4.2.8. Alarm/Sensor ......................................................... 58
4.2.9. Time ....................................................................... 61
4.2.10. LOG ..................................................................... 62
4.2.11. Upgrade ............................................................... 63
4.2.12. System Reboot..................................................... 64
Ch5. How to Operate Camera...............................................65
5.1. OSD Menu Oganization ..........................................66
5.2. Camera Setting .......................................................70
5.2.1. White Balance ........................................................ 70
5.2.2. Exposure................................................................ 71
5.2.3. Back Light .............................................................. 73
5.2.4. AGC ....................................................................... 74
5.2.5. SSNR (Samsung Super Noise Reduction) ............. 75
5.2.6. Day & Night............................................................ 75
5.2.7. Others .................................................................... 77
5.3. Sequence Setting ....................................................78
5.3.1 Preset ..................................................................... 78
2
Contents
5.3.2. Swing SEQ............................................................. 80
5.3.3. Group SEQ ............................................................ 81
5.3.4. Tour........................................................................ 81
5.3.5. PTZ Trace .............................................................. 82
5.3.6. Auto Run ................................................................ 82
5.3.7. Power On Resume................................................. 83
5.4. P/T Setting...............................................................84
5.4.1. Pan Limit ................................................................ 84
5.4.2. Tilt Limit.................................................................. 84
5.4.3. Area Setting ........................................................... 85
5.4.4. Area Masking ......................................................... 86
5.4.5. Prop. P/T................................................................ 86
5.4.6. Digital Flip .............................................................. 87
5.4.7. Image Hold............................................................. 87
5.5. OSD Setting ............................................................88
5.5.1. Camera Name........................................................ 88
5.5.2. Preset Number ....................................................... 89
5.5.3. Preset Name .......................................................... 89
5.5.4. Sequence Status .................................................... 90
5.5.5. Area Name ............................................................. 90
5.5.6. PTZ Position .......................................................... 91
5.5.7. Language ............................................................... 91
5.6. Initialization Setting .................................................92
5.7. Status.......................................................................93
Ch6. Troubleshooting ...........................................................94
Appendix A. DDNS Usage.................................................... 99
3
30X PTZ Network Camera SNP-3300
Specifications ...............................................................107
Dimension .................................................................... 110
If you refer to the enclosed Quick guide and the
Note
Manual in the CD, you can learn how to use Network
Manager.
4
Note to User
Note to User
This machine’s electromagnetic waves have been registered as
suitable for business purposes; the retailer and consumer should be
aware of this registration. If in the case of wrongful purchases,
please exchange the product for a home use product.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other
European countries with separate collection
systems)
This marking shown on the product or its literature, indicates that it
should not be disposed with other household wastes at the end of its
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Household users should
contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take
this item for environmentally safe recycling. Business users should
contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other
commercial wastes for disposal.
5
30X PTZ Network Camera SNP-3300
Samsung Techwin cares for the environment at all
product manufacturing stages to preserve the
environment, and is taking a number of steps to
provide customers with more environment-friendly
products.The Eco mark represents Samsung
Techwin s will to create environment-friendly
products, and indicates that the product satisfies
the EU RoHS Directive.
6
Product Warranty and Limitations
Product Warranty and Limitations
The manufacturers of this product do not take any responsibility for
this product; therefore, the manufacturer does not authorize the
third-party, but allows that retailer is responsible.
The product warranty does not extend to cover accidents, negligence,
abuse, or wrongful use for the whole or any part of the product.
Additionally, the manufacturer does not provide warranty for any
additional parts or affiliations.
The warranty is for one year from the purchase date. During the
period, warranty does not extend to malfunction in these areas.
y Malfunction due to user’s negligence
y Dismantlement or replacement by the user
y Connection to alternate power source
y Malfunction due to natural disasters (fire, flood, tsunami, etc.)
y Replacement due to wear and tear
y Instability of network
7
30X PTZ Network Camera SNP-3300
Warning Symbols
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for
future use.
Danger :
Misuse or wrongful operation of the product may
result in death, injury or bring about other fatal
results. It indicates absolute caution when operating.
Caution :
Misuse or wrongful operation of the product may
result in slight injury or damage to the product. It
indicates caution when operating.
Note :
Indication that the user needs to be aware of certain
matters, or will find matters helpful in operating the
product.
Danger
Before Setup
y Please set up the proper voltage before connecting to power
source.
y Please be sure the power is turned off before setup.
8
Danger
y There is risk of shock or fire; be sure to avoid setup in places
with high humidity.
y To prevent shocks, please connect the ground wire.
y Do not install the camera on a surface that can not support it.
y Unless the surface is suitable, it could cause falling or other
hazards.
During Use
y When opening the product cover, there is a risk of electric
shock. Only a professional should open the cover.
y Please use only in an environment with standard temperature
and humidity.
y Please do not plug in multiple products to a power source; it is
often the cause of fires.
y Please do not place water or heavy objects on the product; it is
often a cause of malfunction.
y Please do not use in a location with propane gas, gasoline or
other flammable substances to avoid risk of explosion or fire.
y Please do not touch the power plug with wet hands to avoid
electric shock.
y Do not pull on the power plug with too much force; a damaged
plug may cause electric shock or fires.
y Don’t connect the RJ-45 cable to a terminal by constraint.
y Stop using your camera when you find a malfunction.
If you use your camera around smoke or unusual heat for a
long time, Fire may be caused.
9
30X PTZ Network Camera SNP-3300
y Random replacement of built-in battery by other types of
batteries may cause explosion. The battery shall be replaced by
the same battery. The used batteries shall be disposed carefully
because they can cause environment pollutions.
y The battery shall be replaced by the same battery.
y The used batteries shall be disposed carefully because they can
cause environment pollutions.
Disassembly and Cleaning
y There is a risk of malfunction, shock or other dangers. Please
do not disassemble or attempt to fix the product.
y To prevent malfunction or shock, please do not use a wet cloth
or oil-based cleaning product to clean the product exterior.
Clean the exterior of the product with a dry cloth.
Caution
y Do not install under extreme temperature conditions
Use only under temperature conditions between -0°C and
+40°C. Provide good ventilation when using in high
temperature conditions.
10
Caution
y Do not install under unstable lighting conditions.
Severe lighting changes or flickering may hinder normal
camera operation.
y Do not drop the camera or subject it to physical shock.
May cause a product malfunction.
y Never keep the camera face to strong light directly.
May damage the CCD.
y Avoid touching the camera lens.
The lens is the most important component of the camera. Be
careful not to smear it with fingerprints.
y Do not expose the camera to rain or other types of liquids
Wipe dry any liquids. Liquids may contain minerals that are
corrosive to Electronic components.
y Do not expose the camera to radioactivity.
Radioactivity exposure may damage the CCD.
y Do not disassemble the camera.
If you disassemble the product as you please, a Repair Center
doesn’t repair it for free.
y Please check the created network place first, before trying to
connect to a network.
y Please use only the power adapter that is provided with the
product.
y Please check national laws to be sure that using the product for
monitoring purposes is not illegal.
11
C h 1.
Overview
1.1. 30X PTZ Network Camera SNP-3300 Introduction
1.1. 30X PTZ Network Camera SNP-3300 Introduction
The SNP-3300 is a high-tech network camera that uses MPEG-4
codec technology to allow high compression rates and clear picture
quality by allowing for high frame rates to be transmitted through
the network.
By using the network, remote connection, monitoring, and control is
possible from any location for simple use; additionally, set-up
requires only a network.
The 30X PTZ Network Camera SNP-3300 utilizes embedded
software solutions (Embedded Web Server, Embedded Streaming
Server, Network Protocol) developed by SamsungTechwin, and
guarantees performance and safety while offering various solutions
through Internet integration.
1.2. Features
€ 30X Zoom Lens with Auto-Focus Function
The 30X zoom lens having Auto-focus function magnifies
the image up to 240 times when used with the digital 8X
zoom function.
€ Variable Auto Surveillances
•
Individual Preset Saving mode
11 camera adjustment function can be saved independently in
each Preset menu to provide optimum images.
•
Image Hold
Images can be held while moving between Presets to reduce
13
30X PTZ Network Camera SNP-3300
visual fatigue of observers.
•
Various Protocols
Five different makers protocols are supported: Samsung
Techwin, Pelco, Samsung Electronics, Panasonic and Vicon.
•
PTZ Tracking
4 patterns operated with the joystick can be saved and
replayed by users.
•
Auto Swing
Pan or Tilt is operated in sequence between 2 designated
positions.
•
Group Search
•
Tour Search
Maximum 128 Preset positions are toured in order.
Maximum 6 Group Search functions are toured in order.
€ Smart P/T
Even when the Zoom-In function is On for the Pan and Tilt
speed correction function linked to the zoom position, fine
manual operation is possible.
€ Day & Night
Day & Night function of ICR(IR Cut-Filter Removal) and
Sens-Up function can achieve optimum images during
day and night.
*Sens-Up function improves the CCD sensitivity by
lengthening the exposure time using electricity.
*Day & Night function enables users to select and adjust
the color and black and white images according to the
light level.
14
1.2. Features
128 Preset Position
A maximum of 128 Preset positions can be set up. This
function enables users to set up the monitoring place any
time..
€ Digital Flip
When you want to monitor the moving object below the
camera, you can execute the Digital Flip using the Webpage or Viewer. The moving object can be monitored
without screen reverse.
€ Area Masking
For privacy protection, a maximum of 8 areas can be
masked among the surveillance areas preventing them to
be displayed on the screen.
€ High Data Compression ratio
With high data compression ratio based on MPEG-4,
transmission speed is fast and relatively large number of
frame can be transmitted on the same network bandwidth.
15
C h 2.
Section names and functions
2.1. Body
2.1. Body
① POWER Switch
Power ON/OFF. (Factory setting : OFF)
17
30X PTZ Network Camera SNP-3300
2.2. Camera Holder
② RJ-45 ETHERNET Connection Input
③ AC 24V Input
④ AUDIO INPUT
⑤ AUDIO OUTPUT
⑥ Alarm Connection Input
1. IN1
5.IN4
9.1N.C
18
2.IN2
6.GND
10.COM2
3.GND
7.COM
11.2N.O
4.IN3
8.1N.O
12.2N.C
2.3. Camera Holder connection
2.3. Camera Holder connection
19
30X PTZ Network Camera SNP-3300
Alarm Connection Terminal(Camera Holder)
NAME
UP3-#1
UP3-#2
UP3-#3
UP3-#4
UP3-#5
UP3-#6
UP3-#7
UP3-#8
UP3-#9
UP3-#10
UP3-#11
UP3-#12
20
IN1
IN2
GND
IN3
IN4
GND
COM1
1N.O
1N.C
COM2
2N.O
2N.C
Purpose
Alarm input sensor connection terminal1
Alarm input sensor connection terminal2
GND
Alarm input sensor connection terminal3
Alarm input sensor connection terminal4
GND
Alarm Output1 Common
Alarm Output1(for Normal Open)
Alarm Output1(for Normal Close)
Alarm Output1
Alarm Output2(for Normal Open)
Alarm Output2(for Normal Close)
C h 3.
Installation and Network Setup
30X PTZ Network Camera SNP-3300
3.1. Connecting to Monitor (For installation)
Please connect the video output terminal located on the back of the
camera to the monitor.
30X PTZ Network Camera SNP-3300
Monitor
y The connection method varies depending on the type of
monitor and accessories. Please refer to the user's manual for
each instrument.
y Please turn off the power when connecting.
y Please select Hi-Z on the 75Ω/Hi-Z switch for the intermediate
video TV set and select 75Ωfor the Intermediate device as
shown in the picture below.
30X PTZ Network Camera SNP-3300 Intermediate
22
End monitor
3.1. Connecting to Monitor (For installation)
Caution
ƒ This product is the network camera which
transmits video through network, video output
terminal is for installation and used to
determine imaging range when installing the
product.
ƒ It could have a trouble, like a falling-off in
video quality, if you use for monitoring.
23
30X PTZ Network Camera SNP-3300
3.2. Connecting to Power
AC24V 2.5A can be used for the input power of this product.
Connect the Power Adapter Cable. Use a driver (-) to screw one part
of the Power Adapter consisting of two lines to the holder.
Connect the Power Adapter’s plug to the Power Outlet.
Table 3-1. When the resistance value of copper wire is at [20℃(68℉)]
Copper wire size
(AWG)
#24
(0.22㎟)
#22
(0.33㎟)
#20
(0.52㎟)
#18
(0.83㎟)
Resistance value
(Ω/m)
0.078
0.050
0.030
0.018
Voltage drop(V/m)
0.028
0.018
0.011
0.06
y As shown in the Table3-1, voltage decreases as the wire gets
longer. Therefore use of an excessively long adaptor output
line for connection to the camera may affect the performance
of the camera.
※ Standard voltage for camera operation: DC 12V±10%, AC
24V±20%
※ There may be some deviation in voltage drop depending on the
24
3.3. Installation of SNP-3300
3.3. Installation of SNP-3300
„ Installation Precautions
y Check out the installation place. It should be strong enough to
support more than 4 times the total product weight including
30X PTZ Network Camera (SNP-3300) and installation
structure.
y Install the camera in a place having more than 500mm of space
above the ceiling board.
y Install the camera holder using the provided installation guide
tab, screw and fastening cable.
y There is a risk of camera falling during installation. Prevent the
fall using the fastening cable while installing the camera. Also,
access of other people to the place should not be allowed
during installation.
„ Accessories Sold Separately
Use the following accessories sold separately for convenient
installation
ƒ
Ceiling Bracket(STB-330PC)
This mount is used to install the camera on the ceiling.
25
30X PTZ Network Camera SNP-3300
ƒ
Embedded Housing(STH-330PEV)
This housing is used to
attach the speed dome
camera to the ceiling for
installation.
ƒ
Indoor and Outdoor Housing(STH-330PIV, STH-320PO)
This housing is used to
attach the speed dome
camera to the ceiling for
installation.
26
3.3. Installation of SNP-3300
ƒ
Wall Bracket(STB-270PWV)
This item is used to install
the indoor or outdoor
housing for speed dome
on the wall.
ƒ
Pendant Bracket(STB-496PPV)
This item is used to install
the indoor and outdoor
housing for speed dome
on a concrete ceiling.
.
27
30X PTZ Network Camera SNP-3300
„ Camera Installation(Outdoor Housing)
1.
Fasten the ceiling mount
on the ceiling.
2.
Pull outside of the housing the safety wire fastened to the
outdoor housing.
3.
Match the arrow sign
marked on the camera
holder to the arrow
marked inside the
housing and then
install the camera
holder in the housing.
28
3.3. Installation of SNP-3300
4.
Match the arrow sign
marked on the camera
holder to the arrow
marked inside the
housing and then
install the camera
holder in the housing.
5.
Connect the heater and
fan cables within the
housing to the fan
heater PCB.
6.
Adjust and make the arrows marked on the bottom of the
camera body face each other.
29
30X PTZ Network Camera SNP-3300
7.
Insert the camera into the
housing by matching the
installation pin on the
bottom of the camera and
the arrow inside the
housing, and then fasten
the camera by inserting
into the fastening hole,
turning the screw
clockwise for fastening.
8.
Remove the camera dome cover and then the attach the housing
dome cover.
9.
Connect the housing safety wires to the fixture inside the mount
installed on the ceiling.
30
3.3. Installation of SNP-3300
10. Connect the video cable, LAN cable and the power adapter
cable to the camera holder.
11. Check out the connection
of all parts and the camera
and install the completed
outdoor housing on the
ceiling mount.
31
30X PTZ Network Camera SNP-3300
Caution
ƒ Check out the input voltage of the power
adapter before connecting the power.
ƒ For an installation without housing, the camera
can be installed with installation template,
fastening the cable and screw provided
separately.
ƒ It is necessary to tighten the screw to prevent
unfastening.
ƒ If the screw to prevent unfastening is not tight,
the camera installed may fall due to vibration or
shock from the environment.
32
3.4. Network configuration and connection method using Web page
3.4. Network configuration and connection method
using Web page
Use when there is one 30X PTZ Network Camera SNP-3300 to be
installed.
1.
Please connect user’s PC to 30X PTZ Network Camera SNP3300 using cross cable.
Note
To configure network, the internal IP must be
registered in the user’s PC.
33
30X PTZ Network Camera SNP-3300
ƒ After
pressing
internet
protocol
(TCP/IP)
properties, press the ‘advanced’ button to go into
advanced configurations.
Add with 192.168.1.XXX.
2.
34
Please launch a Web browser on user’s PC and enter
[192.168.1.100] in the URL address field and push <Enter>
button. Connect to Webviewer login window of 30X PTZ
Network Camera SNP-3300.
3.4. Network configuration and connection method using Web page
3.
Please login with administrator’s authorization and move to
‘Setup-Network’ page.
Note
4.
Default value is ID : admin, PW : 11111111
Please configure according to the network environment where
30X PTZ Network Camera SNP-3300 will be installed and
push <Save> button to save the configuration.
35
30X PTZ Network Camera SNP-3300
36
3.4. Network configuration and connection method using Web page
① LAN / xDSL/ DHCP Configuration
Item
LAN Use
xDSL
Video Quality
Description
When network product is connected to normal
local LAN or when connected to static IP, the
network data to be allotted to the IP is configured.
When using xDSL dynamic IP, enter the ID and
PW.
When automatically receiving IP through DHCP
server, the DHCP functions are activated.
‘DHCP’ is used in the LAN environment where the
DHCP is activated. Generally, for mid/large scale,
DHCP servers are operated through LAN and for
small-scales, IP sharers use DHCP functions.
② Port Configuration
Item
Port Setting
Description
The connection port and http, ftp port
configurations can be set here and the DDNS use
can be checked.
37
30X PTZ Network Camera SNP-3300
Note
38
Use DDNS changes its IP address every time the
user attempts to connect to the ISP and when the
product is connected to a cable modem or xDSL
modem. In this case, the user cannot know the
changed IP address. When a product that uses
dynamic IP is registered on the DDNS server, when
wishing to connect to the product, the changed IP
address can be easily recognized. In order to register
the IP address to the DDNS server, set Use DDNS as
Enabled.
C h 4.
How to Use Web Viewer
30X PTZ Network Camera SNP-3300
4.1. How to Use Web Viewer
4.1.1. Login
To connect to the login page, enter network camera IP address on
the internet web browser and press the enter key.
Enter user ID and password and push <Login> button, it then moves
to the appropriate Web page.
Note
Default value is ID: admin, PW: 11111111
If you click <Guest> button, it moves to WebViewer page under the
Guest authenticated status. However, administrator has to permit
guest access for this.
Note
40
If you logged in first in administrator mode, please
change the password of administrator. It can
prevent other users from connecting to the
administration page.
4.1. How to Use Web Viewer
4.1.2. Web Viewer screen
Web Viewer screen is composed of menu area for camera/video
configuration and screen area for displaying input video from
camera.
„ Controls
Flip Image
Vertical reversal of channel screen
41
30X PTZ Network Camera SNP-3300
Stretch Image
When selecting resolution with Half D1 and CIF, stretches
channel screen to resolution D1 size.
Save Image
Saves channel screen to ‘JPEG file’.
Quad
Converts to 4 split screens (applied only to 4 channel server).
Channel
Video server channels (applies only to
4channel servers)
- CH1~CH4
Compression
Video compression mode (the mode of
compressing video)
- MPEG, JPEG
Resolution
Video resolution (the size of video screen
transmitted)
- NTSC : D1(704x480), Half D1(704x240),
CIF(352x240)
- PAL : D1(704x576), Half D1(704x288),
CIF(352x288)
Frame Rate
The number of maximum video frame
transmitted for each second.
- 1, 5, 10, 15, 20, 25, 30
Quality
Quality Configures video quality
- Very High, High, Normal, Low, Very Low
42
4.1. How to Use Web Viewer
Pause
Stops video for a while.
OSD
Displays related information.
Displays the title
Removes the title
43
30X PTZ Network Camera SNP-3300
Deinterlace
On/off function of Deinterlace.
Screen where
Deinterlace is not
applied
Screen where
Deinterlace is not
applied
Deinterlace is a function to adjust the video quality
Note
softly by eliminating the border line which was made
by an interlace function. The interlace function draws
an even line and an odd line of the Image one after
the other.
44
4.1. How to Use Web Viewer
Camera Setup
Displays OSD control button of camera.
Camera OSD
control button is
displayed
Camera OSD is
displayed
Day&Night
Day&Night configuration function
(Color, B/W configuration)
PTZ Control
PTZ control function
Screen where
camera PTZ
control window is
displayed
45
30X PTZ Network Camera SNP-3300
Note
The left/right slide bar can control focus (left slide
bar) / zoom (right slide bar)
The “+” displayed in the middle can be pressed using
the mouse as the base point of the Pan / Tilt and it
will Pan /Tilt according to that point.
Instruction for Camera OSD control button
<↑>, <↓> button
Moves selection displaying arrows up and down on
camera OSD menu.
<←>, <→> button
Changes configuration of selected field on camera OSD
menu.
<Set> button
Displays camera OSD or moves to upper/lower menu of
selected field.
<Exit> button
Terminates camera OSD.
For configuring the function and detail operating method of 30X PTZ
Network Camera SNP-3300, refer ‘Ch5. How to Operate Camera’.
46
4.2. Using Administration page
4.2. Using Administration page
4.2.1. Initialization Screen after Connecting
When connection is successful, the below screen will be displayed.
47
30X PTZ Network Camera SNP-3300
4.2.2. Live
Please Move to Web Viewer page
[Web Viewer live screen]
48
4.2. Using Administration page
4.2.3. Basic
Configures basic information for camera.
Video/Audio Setup
Item
Description
Compression
Video compression mode
(Compression mode of video in the camera)
Video Size
If the type of installed camera (NTSC/PAL) is
selected, then the size of screen on the
camera becomes selectable.
Video Quality
Selects the quality of video screen. In case of
low speed internet, lower the video quality to
see seamless video.
49
30X PTZ Network Camera SNP-3300
Item
Description
Video FrameRate
Configures the number of transmitted frame
per second in the camera.
Video Channel
Selects the video channel to be used in the
camera.
Selects whether to use the audio input
channel in the camera or not.
Selects whether to use the audio output in the
camera or not.
Configures the number of users who can be
connected to the camera through the
network(1~20 persons)
Audio amplifying function
onfigures Low for the microphone which has
amplifying function and High for the
microphone which has no amplifying function.
(In case of Line-In signal, configure Low)
Audio-In Channel
Audio-Out Channel
Max User Count
Mic. Sensitivity
Product Information
Item
Description
Model
Mac Address
Displays model name of the camera.
Displays MAC Address of the camera.
Camera Name
onfigures name of the camera, it help to classify
several cameras.
Location
Description
Memo
50
The location of the installed camera can be
entered.
Additional description related to the camera can be
entered.
The contact of camera administrator can be
entered.
4.2. Using Administration page
4.2.4. Network
Configures network information of the camera.
Network Configuration
According to the user’s network environment, it is classified into
LAN, xDSL, DHCP.
Item
LAN
xDSL
DHCP
Description
In case the camera is connected to the local
network or xDSL with a static IP address, configure
network information to be assigned to the camera.
In case of xDSL with a dynamic IP address, enter
password in UserName and Password field.
This case is selected in case of using IP sharing
box/ cable modem.
51
30X PTZ Network Camera SNP-3300
Port/DDNS Configuration
Item
Connection
Port
HTTP Port/
FTP Port
Use SWR
Use DDNS
Description
This controls communication with camera.
(Default : 4000)
This helps to connect to web page or FTP server.
(Default : http=80, ftp=21)
Select if use of SWR function is available. The way
of connection which used ID does not support.
Select if DDNS server is available. DDNS server is
connected to server without reference to changed
IP because there is possibility that floating IP
constantly is changed.
※ A detailed explanation about DDNS usage refers to <Appendix A.
DDNS Usage>.
4.2.5. User
This describes password change for administrator or user
registration.
52
4.2. Using Administration page
Item
Description
Administrator
Password Change
Change password of administrator
Guest Setup
User clicks ‘Guest’ button to decide whether
allowing guest to connect Main Viewer.
Current User
You can register new user or delete, and set up
user’s authority.
※ Set up user authority
User’s authorities set up at ‘Current User’ are as follows.
Item
Video
Control
Description
Use video related setup function
(Compression, Resolution, Framerate, Quality)
Pan, Tilt, Zoom, Audio output, Alarm output
Audio
Audio Input
USE
Whether relevant account is used
(If not checked, not allowed log-in)
53
30X PTZ Network Camera SNP-3300
Example 1) In case control function is limited (Do not check
Controls box)
※ Pan, tilt, zoom, audio output, alarm output function icon is
inactivated
Example 2) In case video function is limited (Do not check Video)
※ Compression, Resolution, Framerate, Quality set up icon is
inactivated.
54
4.2. Using Administration page
4.2.6. Pan/Tilt/Zoom
Configures PTZ Swing and Preset of the camera.
55
30X PTZ Network Camera SNP-3300
Item
Channel
PTZ Display
OSD Display
PTZ
Camera
Configura
tion
Preset
Swing
Group
First Setup
Swing
Setup
Group
Setup
56
Second Setup
Mode
Speed
Duration
Group No.
Preset No.
Travel Speed
Dwell Time
Description
Select the channel of camera.
Display PTZ menu.
Display OSD.
Set or delete(delete, delete all) the
Preset. Screen move the position of
Preset.
Surveille Pan/Tilt Swing at the position
of preset, set up the swing menu.
Surveille repeatedly at the position of
preset, set up the Group menu.
Indicate the first position of surveillant
Preset
Indicate the second position of
surveillant Preset
Select Pan/Tilt Mode.
Set Swing speed between Presets.
Set interval time on Preset.
Set Group Number among 1~6
Set Preset included the Group.
Set swing Speed between preset.
Set interval time on Preset.
4.2. Using Administration page
4.2.7. Motion Detection
This sets up motion detection function of camera.
Item
Grid Display
Select Area
MD Enable
MD Sensitivity
Description
Basic grid, used to choose area on the screen, is
displayed or hidden.
When selecting motion detection area, click <Select
All> button to select all areas, or click <Deselect>
button to cancel the selected area.
Decide whether you use motion detection function.
Setting up sensitivity to detect motion to adjust input
video by situation. You can select 1-5, and 5 is the
highest.
57
30X PTZ Network Camera SNP-3300
4.2.8. Alarm/Sensor
This sets up necessary information when using alarm function by
attaching sensor to camera.
58
4.2. Using Administration page
Alarm/Sensor Setup
◊ Digital In Setup
Item
Description
Sensor Type
Types of sensors are ‘Normal open’ and ‘Normal
close.’ This selects up type of connected sensor.
◊ Digital Out Setup
Item
Description
Set up Alarm Out responding when event is
recognized by connected sensor (Sensor 1) or
Motion Detection (MD)
Set up time to operate relay. It means the period
from the time when sensor detects event to the
time when relay is released.
In case event occurs by sensor (Sensor 1) or
Motion Detection (MD) on the screen, decide
whether transferring related information to FTP.
Alarm
Duration
FTP
In case event occurs by sensor (Sensor 1) or
Motion Detection (MD) on the screen, decide
whether transferring related information by e-mail.
E-mail
E-mail/FTP Setup
Set up FTP server and e-mail information to which related
information is transferred in case alarm occurs.
Item
Mode
Server Name
FTP
Description
Select media for data transfer.
Home Directory
User ID
User Password
Enter domain or IP address of FTP
server.
Set up home directory to save relevant
data at FTP server.
Enter ID to connect FTP server.
Enter PW to connect FTP server.
59
30X PTZ Network Camera SNP-3300
Item
Description
Recipient E-mail
Address 1
Recipient E-mail
Address 2
Server Name
E-mail
ID
Password
Mail Subject
Mail Body
Note
You can designate up to two e-mail
address receiving data when alarm
occurs.
In case you use outside e-mail server,
enter the name of the outside e-mail
server.
Enter ID to connect the outside e-mail
server.
Enter PW to connect the outside email server.
Enter the subject of mail to be
transferred.
Enter the body of mail to be
transferred.
If motion is detected, the contents transferred by email or to FTP are varied according to the set-up of
‘Video Compression’ at Admin page (Basic).
ƒ MPEG : Video length is set by ‘Duration’ of ‘Digital
Out Setup’.
File extension is ‘ste’, you can play this by
supplied Player.
ƒ JPEG : JPG type image file attached.
60
4.2. Using Administration page
4.2.9. Time
Current Time
Item
Date
Time
Description
Current setup date displayed
Current setup time displayed
Time Setup
Item
Set Manually
Time Server
Description
Adjust time manually.
Set up address of time server for Server 1 - 5.
61
30X PTZ Network Camera SNP-3300
4.2.10. LOG
Recent activities made for camera are displayed as log.
Item
Lines
View
Clear
62
Description
Set up number of lines of the list.
Log is viewed with number of lines you set up most
recently.
Delete logs.
4.2. Using Administration page
4.2.11. Upgrade
Upgrade program of 30X PTZ Network Camera SNP-3300.
System Upgrade Configuration.
Item
Firmware/Web
Description
Upgrade firmware and Web-page of 30X PTZ
Network Camera SNP-3300.
Factory Mode Setup
If you click <Reset> button, server is returned to initial value when
shipped from the factory after confirmation procedure by
administrator.
63
30X PTZ Network Camera SNP-3300
4.2.12. System Reboot
Server is rebooted after confirmation procedure of administrator.
Click <OK> button to reboot server.
64
C h 5.
How to Operate Camera
30X PTZ Network Camera SNP-3300
5.1. OSD Menu Oganization
Dome camera can be set up on the OSD(On Screen Display) menu
displayed on the video monitor by Network.
Menu
TILT UP
TILT DOWN
Function
Move up on the OSD
menu
Move down on the
OSD menu
Menu
PAN LEFT
PAN RIGHT
Function
Move left on the OSD
menu
Move right on the
OSD menu
① Camera Setting
P1
P2
①Focus
P3
①Focus Mode
②Zoom Tracking
➌Digital Zoom
AWB Mode
➋White
Balance
➊Brightness
➋Iris
③Exposure
➌Shutter
➍Sens-Up
➍Back Light
WDR
➎AGC
➏SSNR
➐Day
Off
High/Middle/Low/Off
High/Middle/Low/Off
Auto
B/W
B/W Burst: On/Off
Color
Burst Level
Night
66
P4
Auto/Manual/
One Shot AF
Mode: On/Off
Speed: Slow/Fast
Off/2X/4X/8X
ATW/AWC/MANUAL
►ATW
-ATW(I): Indoor
-ATW(O): Outdoor
►Manual
-Temperature
2000K/3200K/5100
K
-Red
-Blue
50
Auto
Manual: Iris Level
--A.FLK
Manual: 1/60~1/120,
000, x2~x128
Auto: Sens-Up Limit
x1~x128
&
WDR Limit:
High/Middle/Low
Defaults
OneShot
AF
ON
Fast
OFF
ATW
3200
100
100
050
Auto
050
ESC
1/60
X4
ESC
Middle
OFF
Middle
MIDDLE
Burst
ON
150
5.1. OSD Menu Oganization
P1
P2
⑧Others
➊Sync
P3
②Image Adj.
➌Freeze
P4
Internal
Line Lock:
Line Lock Phase
Tone
Sharpness
Color
On/Off
Defaults
225
005
050
050
Off
② Sequence Setting
P1
P2
①Preset
②Swing SEQ
③Group SEQ
④Tour SEQ
⑤PTZ Trace
⑥Auto Run
⑦Power On
Resume
P3
P4
①Setting ②Edit ③Execute ④Clear ⑤Status
①Pan Swing
①Setting ②Execute ③Clear
②Tilt Swing
①Setting ②Execute ③Clear
③P/T Swing
①Setting ②Execute ③Clear
①Group1
①Setting ②Execute ③Clear
②Group2
①Setting ②Execute ③Clear
③Group3
①Setting ②Execute ③Clear
④Group4
①Setting ②Execute ③Clear
⑤Group5
①Setting ②Execute ③Clear
⑥Group6
①Setting ②Execute ③Clear
①Setting ②Execute ③Clear
①Trace1
①Replay ②Memorize
②Trace2
①Replay ②Memorize
③Trace3
①Replay ②Memorize
④Trace4
①Replay ②Memorize
①Mode
➊Off
➋Preset: Preset No
③Swing: Swing Mode
Pan/Tile/P&T
➍Group: Group No
➎Tour
➏Trace: Trace1~Trace4
⑦A.Pan
- ①Auto Pan Speed: 20~50
- ②Tilt Angle: 10~45
➋Time
1~59(Sec), 1~59(Min)
On/Off
초기값
OFF
32
25
30sec
OFF
67
30X PTZ Network Camera SNP-3300
③ P/T Setting
P1
P2
①Pan Limit
②Tilt Limit
③Area Setting
④Area Masking
➎Prop.P/T
➏Digital Flip
➐Image Hold
P3
➊Position
➋ON/OFF
➊Position
➋ON/OFF
①Area1
②Area2
③Area3
④Area4
⑤Area5
⑥Area6
⑦Area7
⑧Area8
①Mask1
②Mask2
③Mask3
④Mask4
⑤Mask5
⑥Mask6
⑦Mask7
⑧Mask8
ON/OFF
ON/OFF
ON/OFF
P4
초기값
➊Area Name
➋Position
➌ON/OFF
➊Position
➋ON/OFF
ON
ON
OFF
④ OSD Setting
P1
68
P2
①Camera Name
➋Preset Number
③Preset Name
➍Sequence Status
➎Area Name
➏PTZ Position
➐Language
P3
①Edit ②ON/OFF
ON/OFF
①Edit ②ON/OFF
ON/OFF
ON/OFF
ON/OFF
English/中文
P4
초기값
ON
ON
OFF
ON
English
5.1. OSD Menu Oganization
⑤ Initialize
P1
P2
①Power On Reset
②Factory Default Set
③Camera Default Set
➍Auto Refresh
P3
➊Cancel ➋Execute
➊Cancel ➋Execute
➊Cancel ➋Execute
P4
OFF, 1~7Days
초기값
OFF
➏ Status
P1
P2
P3
P4
초기값
Preset setting is only possible on the OSD menu or
Note
using the Webpage.
Symbol Description
Note
ƒ When there are sub menus under the selected
OSD menu.
Numbers are displayed in white color like ➊ on
the right top of the screen.
ƒ When there is no sub menu under the selected
OSD menu.
Numbers are displayed in black color like ① on
the right top of the screen.
69
30X PTZ Network Camera SNP-3300
5.2. Camera Setting
5.2.1. White Balance
The White Balance function corrects the abnormal white color into
the normal white color under any color temperature lighting.
Select the mode among ATW, AWC and Manual. ATW is selected
by default.
„ WB Mode
ƒ ATW
Balances the color automatically depending on the source of light
from 1,800~10,500K color temperature
- Indoor[ATW(I)] : Use this mode in the area under the limited
color temperature.
- Outdoor[ATW(O)] : Use this mode in the area under the broad
color temperature.
ƒ AWC:
Set up the lighting to the objects and corrects the right color
temperature to that of a white object. Camera works under the
setup conditions. For the most appropriate condition under the
current illumination, capture the white paper and then change the
mode into AWC. Press the Enter key and then AWC Start will be
displayed. When the adjustment is completed after pressing the
Enter key for AWC Start, go to the upper menu. When conditions
change, adjust the white balance function again
70
5.2. Camera Setting
ƒ Manual
Fine tuning is possible through this manual control mode. Select
the color temperature and increase or decrease the Red or Blue
values to shift the color of the object.
Temperature: Select one temperature among 2,000K, 3,200K and
5,100K.
- Red: Red Gain can be changed.
- Blue: Blue Gain can be changed.
White Balance may not function properly under the
Note
following conditions.
ƒ When the color temperature surrounding the
object is very high. (e.g. clear sky or sunset)
ƒ When it is dark around the object.
ƒ When the camera is pointing towards a fluorescent
lamp directly or when lighting conditions change a
lot.
5.2.2. Exposure
Camera exposure can be controlled.
➊Brightness
The brightness of the screen can be adjusted.
71
30X PTZ Network Camera SNP-3300
➋Iris
Auto mode or manual mode can be selected.
ƒ Auto: The brightness of the image signal can be adjusted
automatically depending on the amount of light.
ƒ Manual: The brightness of the image can be adjusted.
➌Shutter
ƒ ---: Electronic shutter mode is enabled. The shutter speed is
controlled automatically according to the brightness of the screen.
ƒ A.FLK: Use this mode when the screen flickers because of
inconsistent frequency with the surrounding lights.
ƒ Manual
- Select any function you wish to operate by using the UP and
DOWN buttons.
- Shutter speed can be adjusted from 1/60 second to 1/120,000
second.
- Sens-Up function can be operated manually from x2 ~ x128.
Note
ƒ Do not use this function with WDR of Back Light
menu at the same time for effective A.FLK
function.
ƒ If the Shutter mode is ESC in the inner
synchronization mode and the camera faces to the
bright fluorescent lamp directly, the image may be
unstable. Be careful to select the installation
location.
ƒ If the Manual or A.FLK mode is selected for the
Shutter menu, the Sens-Up function is disabled.
72
5.2. Camera Setting
➍Sens-Up
ƒ Auto: The low light level of the night or dark condition is detected
automatically and the bright and clear image can be maintained.
- Sens-Up Limit: Maximum accumulated magnification can be
selected.
ƒ Off: Sens-Up function is cancelled.
As the accumulated magnification increases, the
Note
screen goes bright. But, the after image of the
moving object also becomes larger and the optimum
Auto Focus function may not work
5.2.3. Back Light
As Samsung’s own SV-III DSP chip technology is adopted, even
under excessive backlight condition, both the object and the
background can be displayed clearly unlike other cameras.
ƒ WDR : When both, bright and dark areas exist, the objects of the
two areas can be seen clearly.
- WDR Limit: High, Middle or Low mode can be selected.
ƒ Off : WDR function is cancelled.
73
30X PTZ Network Camera SNP-3300
Note
ƒ When the Shutter menu is in Manual mode, WDR
function cannot be used.
ƒ When the WDR function is used, the following
results may occur depending on lightning
conditions. Under these conditions, turn off the
WDR mode.
- Unnatural color change or unnatural screen
may occur.
- There may be noises in the bright area of
the screen.
ƒ WDR performance may vary depending on the
bright areas on the screen. Thus, optimize the
camera installation angle for optimized WDR
function.
ƒ If the WDR Limit is increased, the screen may
become unnatural.
5.2.4. AGC
When the brightness of the image taken under dark light is under a
certain level, the AGC (Automatic Gain Control) functions to define
whether to control the Gain automatically or not.
ƒ Select one mode among High, Middle, Low or Off.
74
5.2. Camera Setting
5.2.5. SSNR (Samsung Super Noise Reduction)
SSNR function reduces background noise under low light conditions
differently in different modes. The noise reduction effect grows in
Off, Low, Middle and High modes in order.
ƒ OFF : No noise reduction effect.
ƒ LOW : Noise reduction effect is small but there is little afterimage.
ƒ MIDDLE: Noise reduction effect is generally effective in this mode.
Noise can be reduced properly and the afterimage is not strong.
ƒ HIGH : Noise reduction effect is excellent but afterimage is also
strong.
When you select the AGC mode as “OFF”, you
Note
cannot use the SSNR function.
5.2.6. Day & Night
The darkness level is detected automatically under low light
conditions such as at night or under dark light to keep the screen
bright and clear.
75
30X PTZ Network Camera SNP-3300
ƒ COLOR : Output images are displayed in color all the time. Burst
signal size can be adjusted.
ƒ B/W : Output images are displayed in black and white all the time.
Burst signal can be kept or removed.
ƒ AUTO : Under day condition, the mode is automatically changed
into the COLOR mode to keep an optimum color. At night, the
mode is automatically changed into the B/W mode to distinguish
dark images clearly.
Note
76
ƒ If the AGC is in OFF mode, the Auto mode cannot
be used. Only COLOR or B/W mode can be used.
ƒ If the sunlight or halogen lamp is used in B/W mode,
the focus may be blurred compared with the general
illumination.
5.2. Camera Setting
5.2.7. Others
➊Sync
Internal Sync or Line Lock can be selected. Internal Sync is
selected by default. Line Sync function can adjust the output
phase of more than 1 unit without using sync signal generator.
When the AC Line Lock is selected, the phases can be adjusted
from 0 to 360 levels. Accordingly, the phase can be adjusted up to
360°.
ƒ Internal : Internal synchronization
ƒ Line Lock : Power line synchronization
ƒ Line Lock Phase : The phase of line sync can be selected from
0° to 360°. Initial value is 225°.
②Image Adj.
Brightness, sharpness and color density of the image signal can
be adjusted.
ƒ Tone : The overall brightness of the screen can be adjusted.
ƒ Sharpness : The overall sharpness of the image can be adjusted.
ƒ Color : The overall color density of the image can be adjusted.
➌Freeze
Moving image can be stopped and replayed.
ƒ ON: Image can be frozen.
ƒ OFF: Frozen image is released and the film is replayed.
77
30X PTZ Network Camera SNP-3300
5.3. Sequence Setting
Sequence Setting Menu
5.3.1 Preset
12 items such as Pan/Tilt location, Zoom and Focus are selected
among camera functions and they can be called for monitoring.
Total 128 points can be preset.
ƒ Edit : You can edit the 11 preset items such as Pan/Tilt location,
Zoom and Focus, which are selected among camera functions.
ƒ Execute : Select the Preset number for execution.
ƒ Clear : Select the Preset number to delete for clearing.
ƒ Status : The current Preset number setup is displayed.
78
5.3. Sequence Setting
„ Preset Menu Setting
1.
Select the Preset item on the Sequence Setting Menu.
2.
Select the Setting item.
3.
Select the Preset number.
4.
Set up the Zoom and Focus.
5.
If you want to edit the camera function setup items, go to each
item and select it.
6.
If you select the Scene Adj. item, such items as Shutter, AGC,
SSNR, Sens-Up and White Balance can be set up differently in
every Preset item.
79
30X PTZ Network Camera SNP-3300
5.3.2. Swing SEQ
Swing surveillance can be executed and set up and the data can be
deleted.
ƒ Pan Swing : Swing surveillance for the Pan direction is executed
and set up. Data is deleted.
ƒ Tilt Swing : Swing surveillance for the Tilt direction is executed
and set up. Data is deleted.
ƒ P&T Swing : Swing surveillance both for the Pan and the Tilt
directions are executed and set up simultaneously. Data is
deleted.
- Setting : Preset Position for Swing is selected and confirmed.
SPD is the moving speed (1-64 °/sec). DWL is the stop time
(1-128 sec).
- Execute : Swing surveillance is executed.
- Clear : Data in the Swing function is deleted.
80
5.3. Sequence Setting
5.3.3. Group SEQ
Sequence surveillance can be executed and set up and data can be
deleted. Up to 6 groups can be registered.
ƒ Setting : Preset position for swing is selected and confirmed.
SPD is the moving speed (1-64 °/sec). DWL is the stop time (1128 sec).
ƒ Execute : Swing surveillance can be executed.
ƒ Clear : Swing data can be deleted.
5.3.4. Tour
Group surveillance can be executed and set up and data can be
deleted.
ƒ Setting : The registered Group Sequence is selected and
confirmed. If the selected number is not registered, it cannot be
input.
ƒ Execute : Group surveillance is executed.
ƒ Clear : Group surveillance data are deleted.
81
30X PTZ Network Camera SNP-3300
5.3.5. PTZ Trace
Maximum 4 patterns of the manual operation paths (for Pan, Tilt,
Zoom and Focus) are memorized and replayed.
Note
If the operation range is limited using ①Pan Limit
and ②Tilt Limit, please note that other operations
beyond the limited operation range are not possible.
ƒ Memorize: Manual operations for minimum 120 seconds after
executing this function are memorized into the internal memory.
Nevertheless, the memorizing time becomes different depending
on the PTZ operation. OVER mark will finish this function.
Note
If the operation range is limited using ①Pan Limit
and ②Tilt Limit, only the operations within the limited
range are memorized.
5.3.6. Auto Run
If there is no operation by the user for a certain time, the sequence
operation designated by the user will be executed.
ƒ Mode:
- OFF : Auto Run will be cancelled.
- Preset : Auto Run in the corresponding Preset number
82
5.3. Sequence Setting
- Swing : Auto Run in the corresponding Swing mode
- Group : Auto Run in the corresponding Group number
- Tour : Auto Run in the corresponding Tour number
- Trace : Auto Run in the corresponding Trace number
- A. Pan : 360° Auto Run in Pan direction
Auto Pan Speed: Pan operation in the speed designated by
the user
Tilt Angle: The tilt angle set up by the user is kept.
ƒ Time : Auto Run operation is executed after a certain time
designated by the user.(Time can be set up by the unit of 1-59
sec and 1-59 min.)
5.3.7. Power On Resume
When the power supply for the camera is stopped for some reason,
such as electricity failure, and resumed, the Sequence Settings
before the power off are restored.
83
30X PTZ Network Camera SNP-3300
5.4. P/T Setting
5.4.1. Pan Limit
The moving range in the Pan direction can be limited.
ƒ Position : Moving range can be set up. Set the position from the
left. The stop position may change due to the initialization by
such operation as power resumption depending on position
setting. This does not mean it is out of order.
ƒ On/Off : When this function is on, the limit is effective. Default
setting is Off.
5.4.2. Tilt Limit
Moving range in the tilt direction can be limited.
ƒ Position : Moving range can be set up. Set the position from the
top direction. The stop position may change due to initialization
by such operation as power resumption depending on position
setting. This does not mean it is out of order.
84
5.4. P/T Setting
ƒ On/Off : The application of limitation will be determined. Default
setting is Off.
5.4.3. Area Setting
Areas can be indicated. Areas can be designated up to 8.
ƒ Area Name : Area name can be set up. A maximum of 12 letters
(English, Chinese, numbers) can be entered. When you finish
inputting the name, adjust the position mark to "SET".
ƒ Area Position : Area range can be designed. If the area range is
overlapped, the smaller area number will indicate the overlapping
part.
ƒ On/Off : It can be determined whether or not to activate the area
mark. The activation becomes effective as soon as the position
moves from the current area to other areas. Set up the OSD
Setting as ON. If it is in OFF mode, this function does not work.
Default setting is OFF.
85
30X PTZ Network Camera SNP-3300
5.4.4. Area Masking
If you want to exclude some areas for surveillance, they can be
turned into black. You can mask 8 parts of one screen (maximum 32
parts).
ƒ Position : Detect the position for screen operation from the left.
ƒ On/Off : Operation of screen area masking can be determined.
Default setting is OFF.
5.4.5. Prop. P/T
Pan and Tilt speeds can be changed depending on zoom
magnification. Tele will slow down the speed of Pan/Tilt and Wide
will increase the Pan/Tilt speed. It will take about 15 seconds for 1
cycle in Tele mode and about 1.5 seconds in the Wide mode. Default
setting is ON.
86
5.4. P/T Setting
5.4.6. Digital Flip
When you operate the Tilt up to 90° limit and keep it for a certain
time, the image gets reversed automatically and the opposite Tilt
area is seen. When you want to monitor the moving object under the
camera, execute the Digital Flip function. You can observe the
moving object without reversing of the screen.
5.4.7. Image Hold
When moving from one Preset item to another Preset item, the
Preset image before moving can be held before the camera direction
reaches to the new Preset position. This function is for visual
convention of monitoring observer.
87
30X PTZ Network Camera SNP-3300
5.5. OSD Setting
5.5.1. Camera Name
Camera ID indication is set up.
If you want to edit the item, move the cursor. Then
Note
select the character.
ƒ Edit : A maximum of 12 characters consisting of English (or
Chinese), numbers and special characters can be input for
Camera Name.
ƒ On/Off : The operation of this function is preset. Default setting is
On.
88
5.5. OSD Setting
5.5.2. Preset Number
Preset numbering is set up. (Default setting is ON.)
5.5.3. Preset Name
ƒ Edit : A maximum of 12 characters consisting of English (or
Chinese), numbers and special characters can be input for
Preset Name.
89
30X PTZ Network Camera SNP-3300
ƒ On/Off : The operation of this function is predetermined. Default
setting is On.
5.5.4. Sequence Status
Display of the Sequence Group is set up. (Default setting is ON.)
5.5.5. Area Name
Display of Area Name is set up.
90
5.5. OSD Setting
5.5.6. PTZ Position
Pan and Tilt position and Zoom magnification are displayed.
PTZ positions are not displayed in the OFF mode. (Only manual
operation can display them.)
5.5.7. Language
It selects a language.(English, Chinese)
91
30X PTZ Network Camera SNP-3300
5.6. Initialization Setting
Initialization Menu
①Power On Reset
Camera is initialized into the original status of power input.
②Factory Default Settings
Camera is initialized into the factory default settings. Data including
Preset is deleted. This function is used for initialization all settings.
③Camera Default Settings
If only the camera module is replaced due to camera module failure,
the new camera module can be set up with the settings of the old
camera module.
➍ Auto Refresh
The electric circuit and the status of the equipment parts within the
camera are optimized regularly. (The cycle can be set up.) If camera
faces toward a certain source of light or if the settings cannot be
kept because of the long time rotation filming of a certain area, the
Auto Refresh function is used to maintain and re-set the existing
camera settings. Default setting is OFF.
ƒ OFF, 1-7 Days : This function is disabled in the OFF mode. 1-7
Days enables the Auto Refresh operation in the interval of the
selected days. Auto Refresh takes less than 10 seconds. The
message “Auto Refresh” disappears after finishing the operation.
92
5.7. Status
5.7. Status
The status of dome camera setting is displayed.
CAM MODEL= 30NC
CAM VERSION= 03.06
DOME VERSION= 00.1
DOME ID= 001
CONTROLLER= Duplex-9600
Camera Model
Camera S/W Version
Control Board S/W Version
Dome Camera ID
Communication Mode Setup
93
C h 6.
Troubleshooting
Troubleshooting
If there are problems in operation, please refer to the items below. If
the problem persists, please contact the agent you purchased this
product from.
Problem
Nothing appears on the
screen.
Solution
ƒ Please check the power connection.
ƒ Please check the video signal line
connection.
ƒ Open MS-DOS window to check
whether 30X PTZ Network Camera
SNP-3300 is connected to network.
※ In case of ping 192.168.1.100,
replace it with IP address set up at
server
The video image is not
clear.
ƒ Please check if the lens is clean.
Please clean the lens with a clean
cloth or brush.
ƒ Please adjust the contrast feature of
the monitor.
ƒ Please make sure that the screen is
not exposed directly to a bright light.
Please move the camera if necessary.
The screen is dark.
ƒ Please adjust the contrast feature of
the monitor.
ƒ If you have an intermediate device, set
the 75Ω/Hi-z properly, and check the
terminals.
There is a problem with
the camera operation.
The camera surface is
too hot and black
stripes appear on the
screen.
ƒ Please check if an appropriate power
source to the camera complies with
the
manufacturer's
standard
requirement, or if the voltage keeps
changing.
95
30X PTZ Network Camera SNP-3300
Problem
The MOTION
DETECTION function is
not working.
Solution
ƒ Please check if 'MOTION
DETECTION' mode is turned on.
ƒ Please check if the MD LEVEL is too
low.
ƒ Please check the setting of the MD
AREA.
When camera cannot
be controlled for Pan/
Tilt/ Zoom
ƒ Inspect the cables(power or network)
connected to the device.
Colors are not quite
right.
ƒ Please check
setting.
The screen is
flickering.
ƒ Please check if the camera is facing
directly into sunlight or fluorescent
light.
L/L mode isn't able to
be selected.
ƒ Please check the frequency of power
supply (60Hz for NTSC, 50Hz for
PAL).
DAYNIGHT(Auto) mode
is not working.
ƒ Please check if the AGC menu is set
to the OFF position.
SENS-UP function is
not working.
ƒ Please check if the AGC menu is set
to the OFF position.
ƒ Connect to Admin page to check
whether user control is selected.
the
'WHITE
BAL'
ƒ Please check if the SHUTTER menu
is set to MANUAL mode.
ƒ Please check the limit of SENS-UP
AUTO mode.
96
Troubleshooting
Problem
Audio is not working
Solution
ƒ Please check the audio is selected
from admin page.
ƒ Please check speaker volume from
the viewer.
ƒ In case input sound through
microphone at Viewer is not outputted
through Audio Out of server, please
check whether Audio Out channel is
selected at admin page. Or check
whether microphone is available at
Viewer.
ƒ Please check audio driver is working
in user’s PC.
Video is stopped
ƒ Please check whether network cable
of 30X PTZ Network Camera SNP3300 is correctly connected
ƒ In case user uses hub or IP router,
check
whether
these
network
equipments are working properly.
ƒ Open MS-DOS window and check
whether 30X PTZ Network Camera
SNP-3300 is connected to network.
No image from web
viewer
ƒ Click ‘refresh (shortcut; F5) ’ button at
browser to recall the page
ƒ Check whether power of camera and
network cable is properly connected.
ƒ Check whether computer is connected
to network.
ƒ If you use hub or router, check
whether such equipments are properly
operated.
(Note: Open MS-DOS window and
enter network ID of camera at ping
192.168.1.100)
ƒ Connect to Admin page to check
whether video output is selected.
97
30X PTZ Network Camera SNP-3300
Problem
Image transferred to
FTP or by E-mail
cannot be viewed
98
Solution
ƒ Video may not be viewed since Divx
codec is not installed in user’s PC.
Divx codec can decode video
compressed with MPEG4. Download
and install the latest Divx codec, and
check video.
http://www.divx.com/divx/download
Appendix A. DDNS Usage
30X PTZ Network Camera SNP-3300
Registration process of DDNS is as following:
€ Step1) Complete the registration form in iPOLiS
website.
The website is ‘www.samsungipolis.com’.
Figure A-1. Website of iPOLiS
100
DDNS Usage
Figure A-2. Membership Registration: SIGNUP
Figure A-3. Membership Registration: Input your information.
101
30X PTZ Network Camera SNP-3300
€ Step2) Register the equipment after login.
Figure A-4. Login
Figure A-5. The list of registered equipment.
102
DDNS Usage
Figure A-6. The list of registered equipment.
Figure A-7. Product Registration.
(Confirm repetition certainly at domain registration.)
103
30X PTZ Network Camera SNP-3300
€ Step3) Configure DDNS information in the
equipment.
Click the part of Network Configuration in website of Network
Camera.
Click “USE DDNS” in order to do “Enable” and input the address of
DDNS Server.
(Default: www.samsungipolis.com )
Enter the ID and Password that is written when register product is in
iPOLiS website.
The Configuration of DDNS in SNP-3300 is Completed.
104
DDNS Usage
€ Step4) Confirm the connection status of
relevant product in product list of iPOLiS
website.
Figure A-8. The List of Product.
Be able to confirm the information of connected
equipment if click <check> button of ‘Product information’.
105
30X PTZ Network Camera SNP-3300
Figure A-9. Product information
Move to Login website of relevant product if click <view>
button of ‘ view’.
The buttons which are <Edit> and <Delete> of ‘product
management’ move to relevant page through input
password to item that fertilize or erase information of
registered equipment in List of product.
Only, ‘ID(Domain)’ of product should establishes again as
‘ID(Domain)’ after deleting because it can’t be fertilized.
Figure A-10. Edit/Delete
106
Specifications
Specifications
Items
Imaging device
TV
Total Number of Pixels
Valid Pixel
Horizontal Scan
Frequency
Vertical Scan
Frequency
Synchronization
Image Output
S/N Ratio
Horizontal Resolution
Minimum Light for
Object
Electronic Shutter
Sens-Up
Day & Night
WDR
White Balance
Flickerless Adjustment
Iris
Gain Control
OSD Display
Outline Correction
Contact Point Distance
Digital Zoom
Maximum Aperture
Rate
Coverage Angle
Proximity Distance
Horizontal Rotation
Angle
Horizontal Rotation
Horizontal Rotation
Speed
Horizontal Minimum
Moving Angle
Accuracy of Horizontal
Rotation Stop
Vertical Rotation Angle
SNP-3300N
SNP-3300P
1/4” Color Vertical Double Density Interline CCD.
410.000pixel
NTSC
PAL
811(H) X 508(V)
795(H) X 596(V)
768(H) X 494(V)
752(H) X 582(V)
15.734kHz
15.625KHz
59.94Hz
50Hz
Internal Sync/External Sync(AC Line Lock)
1.0p-p/75Ω
Higher than 50dB (AGC OFF)
520 TV Lines (Color)/570 TV Lines(B/W)
0.4Lux(Color),0.08Lux(B/W)/(@50IRE),
0.0006Lux (Day & Night is On.)/(@50IRE)
Auto/Manual (1/60 - 1/120.000)
ON (x2 - x128 Fields) / OFF
ICR(Filter Switching) ON/OFF
52dB ON/OFF
ATW(Indoor/Outdoor Selection)/AWC/
Manual (1,800K - 10,500K)
Fixed Shutter Speed
Fixed Shutter Speed
(1/100)
(1/120)
Auto/Manual (Iris Level Adjustment Mode)
Low, Middle, High, Off
ON/OFF
Adjustable Level
F3.3 ~ 99.0mm(30X Optical Zoom)
OFF, 2X, 4X, 8X(Total 240X Zoom)
Light Angle 1:1.6 Telescopic 1:3.7
F=3.3mm 58°(Horizontal) X 44.8°(Vertical)
f=99.0.mm 2.22°(Horizontal) X 1.68°(Vertical)
1.2m(Tele level)
360°
Manual/Program
Manual: 0.5° ~ 120°/s(64 levels)
Preset: 0.5° ~ 240°/s(64 levels)
0.05°
0.30°
-4°~ 184° (Digital Flip)
107
30X PTZ Network Camera SNP-3300
Items
Vertical Rotation
Vertical Rotation Speed
Vertical Minimum
Moving Angle
Accuracy of Vertical
Rotation Stop
Preset Position
Area Masking
Alarm
Operating Temperature
Operating Humidity
Power, Voltage
Consumption Electricity
Dimension
Weight
Installation Conditions
Output Video Format
Output Resolution
Video Compression
Stage
Audio Format
Ethernet
Protocol
Dynamic IP
DDNS
Max. User
PC Viewer
Web Page
S/W
Web ActiveX
Control
SNP-3300N
SNP-3300P
Manual/Program
Manual: 0.5° - 120°/s(64 levels) Preset: 0.5° 240°/s(64 levels)
0.04°
0.30°
Max 128 points
Max 8 locations
4 Alarm Inputs
2 Alarm Outputs
(Relay: NC/NO/COM, 0.5A 125VAC, 2A 30VDC Max)
0°C - +40°C
30% ~ 80%(Except for dew condensation)
AC 24V±10%
Max 18W
Ø155 X 243.4mm
Less than 2.5kg
- Ceiling Bracket: STB-330PC
- Indoor: Indoor Housing (STH-330PIV),
Embedded Housing(STH-330PEV)
- Outdoor: Outdoor Housing (STH-320PO)
- Wall Bracket: STB-270PWV
- Pendant Bracket: STB-496PPV
MPEG4 / MJPEG Selectable
NTSC :
704 x 480(D1), 704 x 240(Half D1), 352 x 240(CIF)
PAL :
704 x 576(D1), 704 x 288(Half D1), 352 x 288(CIF)
5 stages (Very Low, Low, Middle, High, Very High)
Bi-directional audio, 8KHz ADPCM
10/100Mbps
HTTP, TCP/IP, PPPOE, FTP, SMTP, DHCP, DNS,
DDNS, NTP
Supports XDSL and DHCP
Supports DDNS
20 Users
Supplied
Embedded Web Server
※ The product design and dimensions may change without
previous notice for improvement of performance.
108
Specifications
Note
ƒ The copyright of this manual belongs to Samsung
Techwin Co. Ltd.
ƒ Parts or the whole of this manual cannot be
reproduced or transmitted by any electric,
mechanic or audio method without the authorized
written approval of Samsung Techwin.
ƒ The contents of this manual may be changed for
an improvement of functions.
109
30X PTZ Network Camera SNP-3300
Dimension
110
